Samsung Electronics Co ATP110 Wireless Bluetooth Speaker User Manual
Samsung Electronics Co Ltd Wireless Bluetooth Speaker
Users Manual
Contents
1. Check the contents of your box . . . . . . . . . . . . . . . . . . . . . . . . . 2
2. Your speaker, an overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3. Button functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
4. Charging the speaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5. Installing the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
» Getting started
10. Using call functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
11. Using music control functions . . . . . . . . . . . . . . . . . . . . . . . . . . 13
12. Answering a call while listening to music . . . . . . . . . . . . . . . 14
» Using your speaker
13. Frequently asked questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
14. FCC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
15. Warranty and parts replacement . . . . . . . . . . . . . . . . . . . . . . . 18
16. Correct disposal of this product . . . . . . . . . . . . . . . . . . . . . . . . 19
17. Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
18. Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
» Appendix
6. Turning the speaker on/off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
7. Indicators (LED) description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
8. Pairing the speaker with SPH-M620. . . . . . . . . . . . . . . . . . . . . . 9
9. Connecting the paired speaker to SPH-M620 . . . . . . . . . . . . 10
» Before using your speaker
1
Using a mobile phone while driving creates a distraction to the driver which
may increase the likelihood of an accident.
When using the phone while driving, keep conversations short and do not make
notes or read documents. Before answering calls consider your circumstances.
Pull off the road and park before making or answering calls when driving
conditions require. (e.g. bad weather, high traffic density, presence of children in
the car, difficult junctions or maneuvers)
Remember, driving comes first, not the call!
Abide by local laws.
Drive safely
!
!
Thank you for purchasing the Samsung Bluetooth Stereo Speaker ATP110.
We know you will be delighted with its operation.
Please read the user manual before using the speaker to make the best use of
the speaker’s features.
Thank you
The ATP110 is dedicated to the SPH-M620 phone. It also supports Bluetooth¹
version 1.1 or higher specification and support Headset profile, Hands-free
profile, Advanced Audio Distribution profile, and Audio/Video Remote
Control profile², but may not be fully compatible with models other than
SPH-M620.
Check phone compatibility
!
2
Check the contents of your box
1
Getting started
Your speaker, an overview
2
Phone cradle
Function buttons
Speaker Charging Indicator Light
Microphone
Phone Charging Indicator Light
Volume up/down, Mute
Speaker
Speaker
Make sure you have the following items with your speaker :
Travel adapter, Battery, User manual
Charger connector
Indicator Light
3
3
Button functions
Talk button
In Standby mode
When a call comes in
Press to answer the call.
During a call
Press and hold to answer a second call.
Press and hold to switch between the active call and the held call.
To Reconnect
Press to connect the speaker to the phone, if speaker has already been
paired, via the Hands-Free or Headset profile.
Press and hold to turn the speaker on or off.
Power on/off button
Press to redial the last number.
During a call
Press to end the call.
4
When the music player is launched
Press to stop playing music.
When the music player is launched
Press to begin playing music.
Press to pause or resume playback.
Press to adjust the speaker volume during playback.
Press to adjust the voice volume during a call.
Press and hold the middle of this button to mute voice during a call.
Press to move to the previous or next track during music playback.
Press and hold to rewind or fast forward during music playback.
Play/Pause button
Volume Up/Down/Mute button
When a call comes in
Press and hold to reject the call.
REW/FF button
5
4
Please make sure that you fully charge the battery before using the speaker for the
first time.
Charging the speaker
Press the “SAMSUNG” labeled button to place your phone in the pop up component.
The phone and the speaker can be charged separately or simultaneously using the
provided charger.
While the speaker and the phone are being charged Bluetooth features can be utilized.
1. Plug the charger into the speaker’s charger connector.
2. Plug the charger into the electrical outlet.
The red charging indicator light turns on. When the battery is fully
charged, the charging indicator light changes to green.
6
Checking the battery level
A warning sound beeps and the red indicator light flashes.
The music streaming function is disabled when the charge in the battery
gets too low.
Checking the current battery level
Press and hold at the same time.
- The red speaker charging indicator light flashes once when the remaining battery
capacity is 5~30%.
- The red speaker charging indicator light flashes twice when the remaining battery
capacity is 30~80%.
- The red speaker charging indicator light flashes 3 times when the remaining battery
capacity is 80~100%.
Disconnect the charger from the power source or the speaker after charging is
completed.
Use only a Samsung-approved charger.
Unauthorised chargers may cause an explosion or damage to the speaker.
Always try to keep the speaker at room temperature (0°C ~ +40°C).
The battery will gradually wear out over time with charging/discharging.
When the speaker is using other functions, it will take longer to charge.
7
5
Installing the battery
123
Remove the battery
cover.
Insert the battery. Close the battery
cover.
Before using your speaker
6
Turning the speaker on/off
Press and hold the Power On/Off button
to turn the speaker on.
When the speaker is ready to be paired, the blue indicator light turns on.
If the speaker has not been paired with SPH-M620, the purple indicator light flashes.
Press and hold the Power On/Off button
to turn the speaker off.
The indicator light sequentially flashes blue and red.
8
Status Light
Power on
Flashes purple
Power off
Flashes blue and red
Pairing mode
Turns blue
Standby mode
3Flashes blue every 3 seconds
Active mode4Flashes blue every 8 seconds
7
Indicators(LED) description
Bluetooth Status Indicator (LED)
Status Light
Low battery Flashes red
Charging the battery Turns red
Fully charged battery Turns green
Charging Indicators (LED)
9
Pairing5 will create a unique and encrypted wireless link between two Bluetooth
enabled devices. To use the speaker with SPH-M620, both devices must be paired.
During pairing, keep the speaker and the phone close together.
8
Pairing the speaker with SPH-M620
1. Getting your speaker ready to pair.
There are 2 ways your speaker would be ready to pair.
When turning on the speaker for the first time.
After turning on the speaker press and hold
until the indicator light turns blue.
2.
Search for the speaker on your phone, following instructions in the phone’s
user guide. Your phone should find “Samsung ATP110.” If it doesn’t try
re-search (this may need to be done a few times).
3. Select Samsung ATP110 on your handset.
4. When the phone asks if you want to pair with it,
confirm by selecting Yes or OK.
5. Enter the speaker passkey or PIN6, “0000(4 zeros)”.
Once pairing is completed, the speaker and the Bluetooth phone connection is made
automatically. If the device fails to connect, make the connection yourself from the
Bluetooth phone. (Refer to 9. Connecting the paired speaker to SPH-M620 page 10.)
10
If two Bluetooth devices are disconnected by a power failure, you will need to
reconnect them. When you reconnect a previously paired speaker and handset,
you will not be asked for a passkey.
9
Connecting the paired speaker to SPH-M620
1. Be sure that the speaker is turned on.
2. Choose the connection method you want.
To connect from the phone, follow the phone’s user guide.
To connect from the speaker, both the phone and speaker must have been
previously paired.
Press to re-connect.
11
Answering a call
Press
when the phone rings.
Ending a call
Press
when you have finished the conversation.
Rejecting a call
Press and hold
as a call comes in.
10
Using call functions
Making a call
Redialling the last dialled number
Press
to redial the last number.
Press and hold to redial the last number.
Using your speaker
This section explains how to use various functions, such as making or answering a call,
using menus that you can use while a call is in progress, and listening to music.
12
Using options during a call
You can use the following functions to control your call while a call is in progress.
Adjusting the volume
Press the volume key to adjust the volume while talking.
Muting the microphone
Press and hold the middle of the volume
to turn off the microphone
so that the person with whom you are speaking cannot hear you.
Press and hold the middle of the volume to turn the microphone
back on.
Answering a second call
When you hear a call waiting tone press and hold
to answer a call.
The first call will be placed on hold.
To reject a second call, press
briefly.
Switching between two calls
Press and hold
to switch between an active call and one on hold.
Switching a call from the phone to the speaker
Press
to switch the call from the phone to the speaker.
13
11
Please make sure that you fully charge the battery before using the speaker for the
first time.
Using music control functions
Listening to music
Press .
The music player launches and sound output switches to the speaker.
Pausing and resuming music
1. Press to pause playback.
2. Press to resume playback.
Stopping music
Press .
Listening to the previous/next track
Press
/
to move to the previous track or to the next track.
Rewinding/Fast forwarding
Press and hold
/
while music is on.
14
12
When a call comes in while music is playing, your speaker will alert you so that you
can answer the call.
Answering a call while listening to music
1. When the phone rings, press . The music stops and you are
connected with the caller.
2. When you have finished a conversation, press .
After terminating the call the display needs to be flipped and the music will start
back automatically.
You are not able to make a call while music is playing.
Adjusting the volume
Push to increase or decrease the volume level.
15
Appendix
13
Frequently asked questions
How far away from my
phone will the speaker
work?
The operating range is typically up to 10m(30ft).
Will the speaker work
with my cordless phone
at home?
ATP110 is not designed for use with cordless phones.
Will the speaker work
with laptops, PCs, and
PDAs?
The speaker will work with devices that are compliant
with Bluetooth version 1.1 or higher, and support Headset
profile, Hands-free profile, Advanced Audio Distribution
profile and/or Audio/Video Remote Control profile.
Will anything cause
interference when
used with or near the
speaker?
Using the speaker in close proximity to receiving
equipment (i.e., TV, wireless LAN, microwaves) may cause
interference with the speaker. To reduce any interference,
you should keep the speaker away from other devices that
use or produce radio waves.
Will my speaker interfere
with a car’s electronics,
radio, or computer?
Samsung ATP110 produces significantly less power than
a typical mobile phone. It also only emits signals that are
in compliance with the international Bluetooth standard
therefore, you should not expect any interference with
standard consumer-grade electronics equipment.
16
Can other Bluetooth
phone users hear my
conversation?
When you pair your speaker to your Bluetooth phone,
you are creating a private link between only these two
Bluetooth devices. The wireless Bluetooth technology used
in your speaker is not easily monitored by third parties
because Bluetooth wireless signals are significantly lower
in radio frequency power than those produced by a typical
mobile phone.
Can I use the speaker
while charging?
The speaker is usable while charging.
Battery operation time
doesn’t match the one
stated in the user manual.
The battery will gradually wear out because it is a
consumable part.
If you place the battery in extreme heat or cold, the
operation time is shortened.
Can I replace the battery
if it died?
The battery is covered under warranty for one year after the date
of purchase. Should it become faulty within the one year, we will
replace it at no charge. If you want to replace a dead battery with
a new one, please contact your nearest service centre.
The sound echoes when
you talk using the speaker.
Adjust the speaker volume or try moving to another
position and try again.
Music files are not
accessible.
Depending on the model of Bluetooth phone, it may not
read other file formats other than MP3 files (such as *.wav,
*.wma and *.avi). Make sure that your music files are of a
compatible file format (*.mp3).
How do I take care of my
speaker?
To clean the speaker, use a clean and soft cloth that is
slightly damp.
17
FCC
14
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected
• Consult the dealer or an experienced radio/TV technician for help
The device and its antenna must not be co-located or operating in conjunction with any
other antenna or transmitter.
Users are not permitted to make changes or modify the device in any way. Changes or
modifications not expressly approved by Samsung will void the user’s authority to operate
the equipment.
18
Samsung warrants this product as free of defects in material, design and workmanship for
the period of one year from the original date of purchase.
If during the period of warranty this product proves defective under normal use and service
you should return the product to the retailer from whom it was originally purchased or
qualified service center. The liability of Samsung and its appointed aintenance company is
limited to the cost of repair and/or replacement of the unit under warranty.
• The warranty is limited to the original purchaser
• A copy of your receipt or other proof of purchase is required for a proper warranty service
• The warranty is void if the serial number, date code label or product label is removed, or
if the product has been subject to physical abuse, improper installation, modification, or
repair by unauthorised third parties
• The responsibility of Samsung products shall be limited to the repair or replacement of
the product at its sole discretion
• Specifically exempt from any warranty are limited-life consumable components such as
batteries and other accessories
• Samsung is not liable to for any incidental or consequential damages arising from the use
or misuse of any Samsung product
• This warranty gives you specific rights and you may have other rights which vary from
area to area
• Unless otherwise instructed in the User Guide, the user may not, under any circumstances,
attempt to perform service, adjustments or repairs on the unit, whether in or out of
warranty. It must be returned to the purchase point, factory or authorised service agency
for all such work
• Samsung will not assume any responsibility for any loss or damage incurred in shipping.
All repair work on Samsung products by unauthorised third parties voids any warranty
Warranty and parts replacement
15
19
Correct disposal of this product
16
(Waste Electrical & Electronic Equipment)
This marking shown on the product or its literature, indicates that it should not be
disposed with other household wastes at the end of its working life.
To prevent possible harm to the environment or human health from uncontrolled
waste disposal, please separate this from other types of wastes and recycle it
responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this
product, or their local government office, for details of where and how they can take
this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions
of the purchase contract. This product should not be mixed with other commercial
wastes for disposal.
20
1 Bluetooth is a radio technology developed to connect devices, such as mobile phones
and speaker, without wires or cords over a short distance of approximately 10 metres.
More information is available at www.bluetooth.com
2 Bluetooth profiles are protocols through which Bluetooth devices communicate with
other devices. Bluetooth phones support different sets of profiles-most support the
Headset profile but some support the Hands-free profile and others support both
profiles. In order to support a certain profile, a phone manufacturer has to implement
certain mandatory features within the phone’s software.
3 Standby mode is when the speaker is passively waiting for a call or music playback.
When you “end” the call or music playback on your mobile phone, the speaker will go
into standby mode.
4 Active mode is when the speaker has an active call in progress or music is being played.
5 Pairing creates a unique and encrypted communication link between two
Bluetooth-enabled devices and allows them to communicate with each other. Bluetooth
devices will not work if the devices have not been paired with each other.
6 Passkey or PIN is a secret code that needs to be entered on the phone in order to pair
the Bluetooth mobile phone with a Bluetooth speaker. When you have already paired
your mobile phone with speaker, the phone and speaker will recognize each other
and the phone will bypass the discovery and authentication process and automatically
accept the transmission.
Glossary
17
21
Specifications
18
Bluetooth version
Version 2.0
Bluetooth QDID (Qualified Design ID)
B012353
Bluetooth profile support
Advanced Audio Distribution profile,
Audio/Video Remote Control profile,
Headset profile, Hands-Free profile
Frequency range
2.402 ~ 2.408GHz
Power consumption for transmission
0.25 ~ 2.5mW
Bluetooth-available distance
10m
Dimensions (W
x
L
x
H)
104.0mm x 44.6 mm x 19.5mm
Weight
69g
Operating temperature range
0˚C (32˚F) ~ 40˚C (104˚F)
Typical standby time
Up to 400 hr
Typical talk time
Up to 16 hr
Typical play time
Up to 11 hr
Battery charging time
Approximately 3.5 hr
Adapter input
AC100 ~ 240V, 50/60Hz
Adapter output
DC 5V, 1000mA
The speaker’s battery operation time may shorten, depending on your speaker’s usage and
charging status.
The Bluetooth device, ATP110 stereo speaker, that may cause the possibility for interference
while using cannot be required to services related to the safety of human life.
Printed in Korea
03/2007. Rev. 1.0
World Wide Web
http://www.samsungmobile.com
