Samsung Electronics Co EJCT810 Bluetooth Keyboard User Manual FT810 QSG E indb
Samsung Electronics Co Ltd Bluetooth Keyboard FT810 QSG E indb
User manual
QUICK
START
GUIDE
EJ-CT810
Printed in Korea
GH68-XXXXXA Rev.1.0
E Type 10/2015
Draf
t
c
d
a
b
e
1
Copyright © 2015 Samsung Electronics
Bluetooth
®
is a registered trademark of Bluetooth SIG, Inc.
worldwide.
•
Please read this manual before using the device to ensure safe
and proper use.
•
Images may differ in appearance from the actual product.
Content is subject to change without prior notice. You
can access the full user manual for more information. Visit
www.samsung.com to view device information, the user manual,
and more.
Device layout
Touchpad Caps Lock indicator light
Power switch Notification light
Charging port
English
Draft
English
Charging the battery
Before using the keyboard for the first time, you must charge the
battery.
Connect the keyboard to a charger.
•
Chargers are sold separately.
•
The charger should remain close to the electric socket
and easily accessible while charging.
•
The socket-outlet shall be installed near the equipment
and shall be easily accessible.
Turning the keyboard on and off
Slide the Power switch to turn on or off the keyboard.
When you turn on the keyboard for the first time, it
automatically enters Bluetooth pairing mode.
Connecting devices via Bluetooth
1. Turn on the keyboard, and then press and hold the (F11 or
F12) key for about three seconds to enter Bluetooth pairing
mode.
The notification light will flash red, green, and blue.
2. On your other device, activate the Bluetooth feature and tap
Samsung Tab S2 Keyboard from the list of available devices.
3. On the keyboard, enter the passkey displayed on your other
device’s screen and press the Enter key.
The keyboard can pair with up to two Bluetooth-enabled
devices and you can easily switch connections between
the paired devices. For more information, refer to the
user manual.
Draft
Using the cover
Attach the cover to your tablet and use it as a stand.
1. Open the cover.
2. Align and connect the cover’s push clips to the push clips on
the back of your tablet.
3. Fold the back of the cover into a triangular shape. Then, stand
the tablet in landscape orientation.
4. Place the keyboard on the front of the cover as shown in the
image.
►
1
Safety information
Read all safety information before using the device to ensure safe
and proper use. To view the full safety information, refer to the
Samsung website.
The device contains magnets. The American Heart Association
(US) and the Medicines and Healthcare Products Regulatory
Agency (UK) both warn that magnets can affect the operation
of implanted pacemakers, cardioverters, defibrillators, insulin
pumps or other electro medical devices (collectively, “Medical
Device”) within the range of 15 cm (6 inches). If you are a user
of any of these Medical Devices, DO NOT USE THIS DEVICE
UNLESS YOU HAVE CONSULTED WITH YOUR PHYSICIAN
Use manufacturer-approved batteries, chargers, accessories,
and supplies
Do not touch the device with wet hands
Do not drop or cause an impact to the charger or the device
The device can be used in locations with an ambient
temperature of 0°C to 35°C. You can store the device at an
ambient temperature of -20°C to 50°C. Using or storing the
device outside of the recommended temperature ranges may
damage the device or reduce the battery’s lifespan
Prevent the multipurpose jack and the small end of the
charger from contact with conductive materials, such as
liquids, dust, metal powders, and pencil leads
Do not allow children or animals to chew or suck the device
Do not disassemble, modify, or repair your device
Draft
English
Correct disposal
This marking on the product, accessories or
literature indicates that the product and its
electronic accessories (e.g. charger, headset,
USB cable) should not be disposed of with other
household waste.
This product is RoHS compliant.
This marking on the battery, manual or packaging
indicates that the batteries in this product should
not be disposed of with other household waste.
Removing the battery
•
To remove the battery, you must visit an authorised service
centre with the provided instructions.
•
For your safety, you must not attempt to remove the battery.
If the battery is not properly removed, it may lead to damage to
the battery and device, cause personal injury, and/or result in the
device being unsafe.
•
Samsung does not accept liability for any damage or loss
(whether in contract or tort, including negligence) which
may arise from failure to precisely follow these warnings and
instructions, other than death or personal injury caused by
Samsung’s negligence.
1. Turn the keyboard over and remove four rubber feet.
2. Loosen and remove the four screws.
3. Use a flat-edged tool between the keyboard and back cover to
pry them apart.
4. Gently lever the battery away from the main body of the unit.
5. Use a nipper to cut the connections between the battery and
the circuit board.
Do not short-circuit the keyboard by cutting the black and
red wires at the same time. Doing so may cause electric
shock or fire, or the battery may malfunction or explode.
Draft
FCC Statement
Part 15.19
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Part 15.21
Any changes or modifications (including the antennas) to this
device that are not expressly approved by the manufacturer may
void the user’s authority to operate the equipment.
IC Statement
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference
that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
