Samsung Electronics Co EJPW700 Galaxy TabPro PEN User Manual

Samsung Electronics Co Ltd Galaxy TabPro PEN

User manual

QUICK
START
GUIDE
EJ-PW700
Bluetooth C Pen
Printed in Korea
XXXXX Rev.1.0
E Type 03/2016
2
Copyright © 2016 Samsung Electronics
Bluetooth
®
is a registered trademark of
Bluetooth SIG, Inc. worldwide.
•
Please read this manual before using the device
to ensure safe and proper use.
•
Images may differ in appearance from the
actual product. Content is subject to change
without prior notice. You can access the
full user manual for more information. Visit
www.samsung.com
to view device information,
the user manual, and more.
•
Your consumer rights are governed by the law
of the country in which you purchased the
product. Please contact your service provider
for more information.
d
e
c
a
b
3
Device layout
Up button Charger port
Down button Indicator light
Pen nib
3. Reattach the lid by aligning the clip on the lid
with the buttons.
•
If the clip and the buttons are not
aligned, the lid cannot be reattached
properly.
•
Do not apply excessive pressure on the
nib. Doing so may cause damage to the
C Pen and the nib.
Charging the battery
Charge the battery before using the BT C Pen
for the first time or when the BT C Pen has been
unused for extended periods.
Connect the BT C Pen to a charger.
•
Chargers are sold separately.
•
The charger should remain close to the
electric socket and easily accessible
while charging.
•
The socket-outlet shall be installed
near the equipment and shall be easily
accessible.
4
Checking the remaining battery power
Press and hold the Up button and the Down
button simultaneously for three seconds. The
indicator lights alerts you to the remaining
battery power.
Colour Battery power
Red Less than 30%
Violet 30–60%
Blue More than 60%
Connecting devices via Bluetooth
1. Press and hold the Up button or the Down
button for approximately three seconds to
enter Bluetooth pairing mode.
The indicator light will flash red and blue.
2. On your other device, activate the Bluetooth
feature and tap Bluetooth C-Pen from the list
of available devices.
Using the C Pen
Various features, such as performing touch
actions, writing on a connected device’s screen,
or launching apps, are available when the C Pen
is connected to another device.
Refer to the user manual for more information.
5
Safety information
Read all safety information before using the
device to ensure safe and proper use. To view
the full safety information, refer to the Samsung
website.
Use manufacturer-approved batteries,
chargers, accessories, and supplies
Do not touch the device with wet hands
Do not drop or cause an impact to the charger
or the device
The device can be used in locations with an
ambient temperature of 0°C to 35°C. You can
store the device at an ambient temperature
of -20°C to 50°C. Using or storing the device
outside of the recommended temperature
ranges may damage the device or reduce the
battery’s lifespan
Do not allow children or animals to chew or
suck the device
Do not disassemble, modify, or repair your
device
6
Correct disposal
This marking on the product,
accessories or literature
indicates that the product and
its electronic accessories (e.g.
charger, headset, USB cable)
should not be disposed of with
other household waste.
This product is RoHS compliant.
This marking on the battery,
manual or packaging indicates
that the batteries in this product
should not be disposed of with
other household waste.
For information on Samsung’s environmental
commitments and product-specific regulatory
obligations, e.g. REACH, WEEE, Batteries, visit
samsung.com/uk/aboutsamsung/
samsungelectronics/corporatecitizenship/
data_corner.html
FCC Statement
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
Caution: Any changes or modifications not expressly
approved by Samsung Electronics Co., Ltd. could void the
user's authority to operate the equipment.
FCC Radiation Exposure Statement
This equipment complies with FCC Radiation exposure
limits set forth for an uncontrolled environment. This
equipment must not be co-located or operating in
conjunction with any other antenna or transmitter.
7
Industry Canada Statement
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause
undesired operation of the device.
IC Radiation Exposure Statement
This equipment complies with IC radiation exposure limits set forth
for an uncontrolled environment. This equipment must not be co-
located or operating in conjunction with any other antenna or
transmitter.
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts de licence. 'exploitation
est autorisée aux deux conditions suivantes : (1) l'appareil ne doit
pas produire de brouillage, et (2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d'en compromettre le fonctionnement.
Déclaration d'Industrie Canada sur l'exposition aux radiations
Cet équipement est conforme aux limites établies par Industrie
Canada en matière d'exposition aux radiations dans un
environnement non contrôlé. Cet équipement ne doivent pas être
colocalisés ou fonctionner en conjonction avec tout autre
antenne ou émetteur.
8
9
Samsung Electronics (UK) Ltd, Euro QA
Lab. Blackbushe Business Park. Saxony
Way, Yateley, Hampshire, GU46 6GG,
United Kingdom
