Samsung Electronics Co EO-AG900 Samsung Level over User Manual
Samsung Electronics Co Ltd Samsung Level over
User Manual
GH68-00000A Rev.1.0
2013/11
4
Images may differ in appearance
from the actual product. Content
is subject to change without prior
notice.
Package contents
Check the product box for the following
items. The items supplied with the device
and any available accessories may vary
depending on the region or service
provider.
• Device
• Hard case
• Soft case (Acc. kit)
• USB cable
• 3.5 mm audio cable
• 6.3 mm stereo plug
• Flight adaptor
• User manual
Getting started
Device layout
TBD
TBD
5
Getting started
TBD
After fully charging, disconnect the
device from the charger. First unplug the
charger from the device, and then unplug
it from the electric socket.
• To save energy, unplug the
charger when not in use. The
charger does not have a power
switch, so you must unplug the
charger from the electric socket
when not in use to avoid wasting
power. The charger should
remain close to the electric
socket and easily accessible while
charging.
• The socket-outlet shall be
installed near the equipment and
shall be easily accessible.
Charging the battery
This device has a built-in battery. Before
using the device for the first time or
when the battery has been unused for
extended periods, you must charge the
battery.
Use only Samsung-approved
chargers and cables. Unapproved
chargers or cables can cause the
battery to explode or damage the
device.
Charge the device by connecting it to the
computer or the USB power adaptor via
the USB cable.
• The notification light turns red while
the device is being charged. The
notification light turns green when
charging is complete.
6
Getting started
Turning the device on or off
Slide the power switch up to turn on the
device. When the device is turned on, the
notification light flashes blue.
TBD
Slide the power switch down to turn off
the device. When the device is turned off,
the notification light turns blue and then
flashes red before turning off.
Charging time and standard run
times (800 mAh)
Charging
time Approx. 2.5 hrs
Standard
run times
Call time Approx.
15 hrs
Play time Approx.
15 hrs
Standby
time
Approx.
2,000 hrs
• Charging time is measured
after charging with a Samsung-
approved charger.
• Battery run time is results of tests
performed in the manufacturer's
laboratory. Standby time was
measured at the time of first
shipment.
• The battery charging time and
run time may vary depending
on the environment the device
is used in.
7
Getting started
Connecting via the NFC feature
1
Activate the NFC feature on the other
device.
2
Turn on the device and place the other
device’s NFC antenna near the NFC
antenna area on the left earpiece of
your device.
If you are connecting to other
devices, ensure that the screen on
the connected device is unlocked.
The NFC feature does not work
when the connected device's
screen is locked.
TBD
Connecting to other devices
You can connect the device to other
Bluetooth-enabled devices, such as
smartphones or computers.
You can connect to an other
Bluetooth-enabled device only
after disconnecting a previously
connected device.
Connecting via the Bluetooth
feature
1
Turn on the device. Press and hold the
Bluetooth button for about 3 seconds.
The device enters the Bluetooth
pairing mode and the notification light
flashes red, green, and then blue.
2
On the Bluetooth-enabled device,
access the Bluetooth setup mode and
search for Bluetooth devices.
3
From the search results, select the
device name.
When pairing is complete, the device's
name appears in the device list.
8
Using the device
Use one of the following methods to
disconnect a device:
• Turn off the device.
• Disconnect the Bluetooth feature
between your device and the
connected device.
• Place another device's NFC antenna
near the NFC antenna area on the left
earpiece of your device.
Using the device
Enjoying multimedia files with
the device
You can enjoy multimedia files on other
devices with your device.
Play multimedia files on a connected
device and use the touch panel on the
right earpiece of your device to control
functions.
You can control connected devices
with the touch panel when they
are connected via Bluetooth.
• When two devices are
connected, place your device
near to the connected device.
Otherwise, the device may not
work properly or be affected by
noise interference.
• The connection methods or
NFC antenna area may differ
depending on the connected
devices. For more information,
refer to the user manual of the
connected device.
Disconnecting from other
devices
You can connect to another device
only after disconnecting a previously
connected device.
9
Using the device
• Tap and hold on the touch panel and
draw a circle anticlockwise to decrease
the volume.
TBD
When the device is adjusted to
full volume an alert will sound to
notify you. Adjust the volume on
the connected device when you
cannot hear sounds on your device
at full volume.
• Tap the touch panel to play or pause
playback.
• On the touch panel, drag your finger to
the left to play the previous file or drag
it to the right to play the next file.
TBD
• Tap and hold on the touch panel and
draw a circle clockwise to increase the
volume.
TBD
10
Using the device
Receiving a call
If a smartphone is connected to the
device, you can answer a call.
Use the touch panel on the right earpiece
of your device and use one of the
following methods to control calls:
• Tap the touch panel to answer a call.
• Tap and hold the touch panel to reject
a call.
• Tap and hold on the touch panel and
draw a circle clockwise to increase the
volume.
• Tap and hold on the touch panel and
draw a circle anticlockwise to decrease
the volume.
Connecting via an audio cable
You can connect a smartphone or media
player to the device with an audio cable.
TBD
• Before connecting a device via
the audio cable, disconnect any
other connected devices.
• When the device is turned off,
you can adjust the volume when
playing multimedia files with the
connected device only.
11
Appendix
Specifications and features
Dimensions(mm) 164.3 X 62.3 X 69.2
Weight(±1 g) 350 g
Transmission
power 1 mW
Bluetooth
frequency 2402 ~ 2480 MHz
Bluetooth
version 3.0
Supported
Bluetooth profile
A2DP, HSP, HFP,
AVRCP
Identification
code
MSIP-CMM-SEC-
EO-AG900
Wireless
connection
range
10 m
NFC frequency 13.56 MHz
Operating
temperature 5 °C ~ 35 °C
The wireless connection range
may vary depending on the
environment the device is used in.
12
Appendix
Safety information
To prevent injury to yourself and others
or damage to your device, read the safety
information about your device before using the
device. Some content may be not applicable to
your device.
Do not touch the power cord with wet hands or
disconnect the charger by pulling the cord
Use manufacturer-approved batteries, chargers,
accessories, and supplies
Do not drop or cause an impact to the charger
or the device
Do not store your device near or in heaters,
microwaves, hot cooking equipment, or high
pressure containers
Keep your device dry
Do not store your device in very hot or very cold
areas. It is recommended to use your device at
temperatures from 5 °C to 35 °C
Do not store your device near magnetic fields
Do not disassemble, modify, or repair your
device
Any changes or modifications to your device can
void your manufacturer’s warranty. If your device
needs servicing, take your device to a Samsung
Service Centre.
When cleaning your device, mind the following
• Wipe your device or charger with a towel or an
eraser.
• Do not use chemicals or detergents. Doing so
may discolour or corrode the outside the device
or may result in electric shock or fire.
Correct disposal of this product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate
collection systems)
This marking on the product, accessories
or literature indicates that the product
and its electronic accessories (e.g. charger, headset,
USB cable) should not be disposed of with other
household waste.
To prevent possible harm to the environment or
human health from uncontrolled waste disposal,
please separate these items from other types of
waste and recycle them responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer
where they purchased this product, or their local
government office, for details of where and how
they can take these items for environmentally safe
recycling.
Business users should contact their supplier and
check the terms and conditions of the purchase
contract. This product and its electronic accessories
should not be mixed with other commercial wastes
for disposal.
This EEE is compliant with RoHS.
13
Appendix
Correct disposal of batteries in this
product
(Applicable in countries with separate
collection systems)
This marking on the battery, manual or
packaging indicates that the batteries in
this product should not be disposed of with other
household waste.
Where marked, the chemical symbols Hg, Cd or
Pb indicate that the battery contains mercury,
cadmium or lead above the reference levels in EC
Directive 2006/66.
The battery incorporated in this product is not user
replaceable. For information on its replacement,
please contact your service provider. Do not
attempt to remove the battery or dispose it in a fire.
Do not disassemble, crush, or puncture the battery.
If you intend to discard the product, the waste
collection site will take the appropriate measures
for the recycling and treatment of the product,
including the battery.
