Device layout
Front
Status indicator
[Play/Stop] button
[Volume (-)] button
[Volume (+)] button
[Talk] button
NFC antenna
Microphone
4
Back
[Pairing ( )] button
[Power] switch
Audio input jack
Power connection
jack
• Check the product box for the wireless speaker, charger (USB power
adapter, USB cable), 3.5 mm audio cable, and user manual. The
items supplied with the device and available accessories may vary
by region.
• The status indicator is visible only when it is turned on.
5
Use only the battery charger
supplied with the product.
Using unapproved chargers
may slow down the
charging process or cause
damage to the product.
Charging the device
This device has a built-in battery.
Charge the battery completely
before using the device for the first
time or after it has not been used for
an extended period.
Connect the charger to the
Bluetooth speaker and plug the
power cord into the power outlet.
6
• The socket-outlet shall
be installed near the
equipment and shall be
easily accessible.
• The status indicator turns red
while the device is being charged.
The status indicator turns blue
when charging is complete.
• To save energy, unplug
the charger when not
in use. The charger does
not have a power switch,
so you must unplug the
charger from the electric
socket when not in use
to avoid wasting power.
The device should remain
close to the electric socket
while charging.
7
• Battery run time is
based on results of tests
performed with factory
default settings.
• The battery charging time
and run times may vary,
depending on the usage
environment.
Charging time and
standard run times
(3,600 mAh)
Charging
time Approx. 2.5 hrs
Standard
run times
Call time Approx.
15 hrs
Play time Approx.
15 hrs
Standby
time
Approx.
2,000 hrs
8
Charge level Indicator
colour
More than
80 % Blue
30–80 % Purple
Less than 30 % Red
Measuring the battery
charge
Press and hold the [Talk] and
[Volume (-)] buttons simultaneously.
The status indicator flashes 4 times
in different colours, according to the
charge left in the battery.
9
• When the device is turned on,
the status indicator flashes blue
4 times.
• When the device is turned off,
the status indicator turns blue
and then flashes red before
turning off.
Power on
Power off
Turning the device on
or off
Slide the [Power] switch to turn the
device on or off. When you turn on
the device for the first time, it enters
the Bluetooth pairing mode.
10
When connecting for the first time,
pair the wireless speaker with the
other Bluetooth-enabled device.
Keep the devices close to each other
while pairing or using the wireless
speaker.
Instructions for Bluetooth
connection or Bluetooth
connection via NFC may
vary by device. Refer to the
device’s user manual for
additional information.
Connecting to other
devices
You can connect the wireless
speaker to other Bluetooth-enabled
devices, such as smartphones,
tablets, or PCs. Also, if you have
devices that support the near field
communication (NFC) feature, you
can control the Bluetooth feature to
connect the devices to the wireless
speaker.
11
2
On the Bluetooth-enabled
device, access the Bluetooth
setup mode and search for
Bluetooth devices.
3
From the search results, select
the product name.
• When pairing is complete,
the wireless speaker appears
as “Connected” in the device
list.
Connecting via Bluetooth
1
Turn on the wireless speaker.
Press and hold the [Pairing ( )]
button for about 3 seconds.
• The wireless speaker enters
the Bluetooth pairing mode
and the status indicator turns
on blue.
12
Connecting via the NFC
function
1
Enable the NFC feature on the
other device.
2
Turn on the wireless speaker
and bring the other device’s
NFC antenna close to the NFC
antenna on the wireless speaker.
13
Ending the Bluetooth
connection
To disconnect the wireless speaker,
turn it off or disable the Bluetooth
functionality on the Bluetooth-
enabled device.
You can also bring the NFC antennas
together to end the Bluetooth
connection between the devices.
• If you are connecting a
smartphone to the device,
unlock the screen. The NFC
feature may not work when
the smartphone screen is
locked.
• End the Bluetooth
connection between the
product and any other device
first. The NFC function is
not available while another
device is connected to the
Bluetooth speaker.
14
Connecting via an audio
cable
You can connect your smartphone
or a media player to the wireless
speaker with an audio cable.
End the Bluetooth connection
between the product and any other
device before making a connetion
with the audio cable.
15
Playing audio
Play audio from your smartphone,
multimedia player, or PC.
• Adjust the volume with the
[Volume (+)/(-)] buttons.
• A notification will sound when
the speaker volume reaches its
maximum value. If the sound is
not loud enough even with the
speaker volume set to maximum,
adjust the volume of the
connected device.
Using the wireless
speaker
When the wireless speaker is
connected to a Bluetooth or NFC-
enabled device, you can play audio
on the wireless speaker or use it as
a speaker phone. While a device is
connected to the Bluetooth speaker,
you can press the [Talk] button
to turn on the voice recognition
feature of the connected device (if
available).
16
• Some device may allow
you to control only the
volume.
• The audio cable
connection allows you to
control only the volume.
Receiving a call
If a smartphone is connected to the
wireless speaker, you can press the
[Talk] button to answer a call.
• Press the [Play/Stop] button to
pause or resume playback.
• Press the [Play/Stop] button twice
to skip to the next file.
17
If an incoming call is detected
during a call, the indicator flashes
blue 2 times and the ringtone will
sound.
• Press the [Talk] button to end
the current call and answer the
incoming call.
• Press and hold the [Talk] button to
hold the current call and answer
the incoming call.
• Press and hold the [Talk] button to
switch between calls.
• Press and hold the [Talk] button to
reject a call.
• Press the [Talk] button to end
a call.
• Press the [Volume (+)/(-)] buttons
to adjust the volume.
• Press the [Play/Stop] button to
mute or unmute the microphone.
• Press and hold the [Talk] button to
pause or resume a call.
18
• The Samsung Level
application is compatible
with Samsung mobile
devices running Android
operating system 4.2.2 or
later. Depending on your
device’s specifications, a
partially blank screen may
appear or some functions
may not work on your
device.
• To use the application,
ensure that the devices
are connected via the
Bluetooth feature.
Samsung Level
On the connected device, download
the Samsung Level application
from Google Play Store or Samsung
Apps. Launch this application to use
various functions.
19
Bluetooth
version
Supported
Bluetooth
profile
Wireless
connection
range
NFC
frequency
Operating
temperature
Specifications and
features
Dimensions
(mm)
Weight
Transmission
power
Bluetooth
frequency
20
Safety information
This safety information contains
content for mobile devices. Some
content may be not applicable to
your device. To prevent injury to
yourself and others or damage
to your device, read the safety
information about your device
before using the device.
Do not touch the power cord with
wet hands or disconnect the charger
by pulling the cord
The wireless connection
range may vary, depending
on the usage environment.
21
Do not store your device in very hot
or very cold areas. It is recommended
to use your device at temperatures
from 5 °C to 35 °C
Do not store your device near
magnetic fields
Do not disassemble, modify, or
repair your device
Any changes or modifications to your
device can void your manufacturer’s
warranty. If your device needs
servicing, take your device to a
Samsung Service Centre.
Use manufacturer-approved
batteries, chargers, accessories, and
supplies
Do not drop or cause an impact to
the device
Do not store your device near or in
heaters, microwaves, hot cooking
equipment, or high pressure
containers
Keep your device dry
22
Correct disposal of this
product
(Waste Electrical &
Electronic Equipment)
(Applicable in countries
with separate collection
systems)
This marking on the
product, accessories or literature
indicates that the product and its
electronic accessories (e.g. charger,
headset, USB cable) should not be
disposed of with other household
waste.
When cleaning your device, mind
the following
• Wipe your device or charger with a
towel or an eraser.
• Do not use chemicals or detergents.
Doing so may discolour or corrode
the outside the device or may result
in electric shock or fire.
23
Business users should contact their
supplier and check the terms and
conditions of the purchase contract.
This product and its electronic
accessories should not be mixed with
other commercial wastes for disposal.
This EEE is compliant with RoHS.
To prevent possible harm to the
environment or human health from
uncontrolled waste disposal, please
separate these items from other types
of waste and recycle them responsibly
to promote the sustainable reuse of
material resources.
Household users should contact either
the retailer where they purchased this
product, or their local government
office, for details of where and
how they can take these items for
environmentally safe recycling.
24
If batteries are not properly disposed
of, these substances can cause harm to
human health or the environment.
To protect natural resources and
to promote material reuse, please
separate batteries from other types of
waste and recycle them through your
local, free battery return system.
Correct disposal of batteries
in this product
(Applicable in countries
with separate collection
systems)
This marking on the
battery, manual or
packaging indicates that the batteries
in this product should not be disposed
of with other household waste. Where
marked, the chemical symbols Hg, Cd
or Pb indicate that the battery contains
mercury, cadmium or lead above the
reference levels in EC Directive 2006/66.
Declaration of Conformity
Product details
For the following
Product : Samsung Level Box mini
Model(s) : EO-SG900
Declaration & Applicable standards
[We hereby declare, that the product above is in compliance with the essential requirements of the R&TTE Directive
(1999/5/EC) by application of:]
EN 301 489-1 V1.9.2
EN 301 489-3 V1.4.1
EN 301 489-17 V2.2.1
EN 55013:2001/A2 :2006
EN 55020:2007/A11:2011
EN 300 328 V1.8.1
EN 302 291-2 V1.1.1
EN 302 291-1 V1.1.1
EN 60950-1:2006+A1:2010+A11:2009+A12:2011
and the Directive (2011/65/EU) on the restriction of the use of certain hazardous substances in electrical and electronic
equipment [and the Eco-Design Directive (2009/125/EC) implemented by Regulations (EC) No 1275/2008]
Representative in the EU
Samsung Electronics Euro QA Lab. (YEAR TO BEGIN AFFIXING CE MARKING 2013)
Blackbushe Business Park, Saxony Way,
Yateley, Hampshire, GU46 6GG, UK
4 November 2013 Joong-Hoon Choi / Lab. Manager
(Place and date of issue) (Name and signature of authorised person)
* This is not the address of Samsung Service Centre. For the address or the phone number of Samsung Service Centre, see
the warranty card or contact the retailer where you purchased your product.
FCC ID: A3LEO-SG900
FCC Part 15.19
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC Part 15.21
Any changes or modifications (including the antennas) to this device that are not expressly approved by the
manufacturer may void the user's authority to operate the equipment.
RF Exposure Statement (2.1091)
FCC RF Radiation Exposure Statement: FCC RF Radiation Exposure Statement: This equipment complies with FCC RF
Radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co-
located or operating in conjunction with any other antenna or transmitter.
This equipment should be installed and operated with a minimum distance of 20cm between the radiator and your
body.
RF du FCC d'exposition aux radiations: Cet équipement est conforme à l'exposition de la FCC rayonnements RF limites
établies pour un environnement non contrôlé. L’antenne pour ce transmetteur ne doit pas être même endroit avec
d’autres émetteurs sauf conformément à la FCC procédures de produits Multi-émetteur.
Cet équipement doit être installé et utilisé avec une distance minimale de 20cm entre le radiateur et votre corps.
FCC Part 15.105 (B)
Note : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in a residential installation This
equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications,
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult
the dealer or an experienced radio/TV technician for help.
Modifications not expressly approved by the manufacturer could void the user a uthority to operated the
equipment under FCC rules.
IC: 649E-EOSG900
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this
device must accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de
licence.
L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
Industry Canada RF Radiation Exposure Statement
This equipment complies with Industry Canada RF Radiation exposure limits set forth for an uncontrolled
environment. This device and its antenna must not be co-located or operating in conjunction with any other
antenna or transmitter.
This equipment should be installed and operated with a minimum distance of 20cm between the radiator
and your body.
RF de l'Industrie Canada d'exposition aux radiations: Cet équipement est conforme à l'exposition de
l'Industrie Canada rayonnements RF limites établies pour un
environnement non contrôlé. L’antenne pour ce transmetteur ne doit pas être meme endroit avec d’autres
émetteurs sauf conformément à l'Industrie Canada procedures de produits Multi-émetteur.
Cet équipement doit être installé et utilisé avec une distance minimale de 20cm entre le radiateur et votre
corps.
