Samsung Electronics Co EOBG950 Samsung U Flex User Manual
Samsung Electronics Co Ltd Samsung U Flex
User Manual
QUICK
START
GUIDE
EO-BG950
Samsung U Flex Headphones
Printed in Korea
GH68-47707B Rev.1.0
EU/ASIA Type 03/2017
QUICK
START
GUIDE
EO-BG950
Samsung U Flex Headphones
3
4
English
f
h
e
b
a
d
cg
l
i
j
km
l
A
21
5
English
Copyright © 2017 Samsung Electronics
Bluetooth
®
is a registered trademark of
Bluetooth SIG, Inc. worldwide.
•
Please read this manual before using the device
to ensure safe and proper use.
•
Images may differ in appearance from the
actual product. Content is subject to change
without prior notice. You can access the
full user manual for more information. Visit
www.samsung.com
to view device information,
the user manual, and more.
•
Before using the headset, make sure it is
compatible with your device.
Device layout
Notification light Volume (-) button
Neckband Active button
Volume (+) button Play button
Left earphone Charger port
cover
Right earphone Fastening magnet
Power switch Charger port
Microphone
6
Charging the battery
Before using the headset for the first time, you
must charge the battery.
Open the charger port cover. Connect the
headset to a computer or the USB power adaptor
via the USB cable. Plug the USB power adaptor
into an electric socket. ( )
Use only Samsung-approved chargers
and cables.
•
You can charge the headset using the
charger (sold separately).
•
The charger should remain close to the
electric socket and easily accessible
while charging.
•
The socket-outlet shall be installed
near the equipment and shall be easily
accessible.
Indicator light identification
•
Red: When charging
•
Green: When fully charged
7
English
Turning the headset on or off
Bluetooth pairing mode
ON
OFF
Connecting devices via Bluetooth
You can receive incoming calls or listen to
multimedia files when your headset is connected
to Bluetooth-enabled devices.
1. Slide the Power switch towards and hold
it for approximately three seconds to enter
Bluetooth pairing mode.
The notification light flashes red, green,
and blue.
Way 1
2. On your other device, activate the Bluetooth
feature and tap Samsung U Flex (0000)
from the list.
The PIN for the headset is the four-digit
number in parenthesis displayed on the
other device’s Bluetooth settings screen.
The number differs depending on the
headset.
8
Way 2
2. Bring the headset and other device closer
together to connect them if the device
supports Easy pairing.
The connection pop-up window appears on
the mobile device.
Tap Connect to connect the headset and the
mobile device.
Ensure that there are no obstacles
between the headset and other device.
The connection pop-up window may
not appear.
Connecting additional devices
The headset can connect to up to two Bluetooth-
enabled devices at the same time. For more
information, refer to the user manual.
9
English
Safety information
Read all safety information before using the
device to ensure safe and proper use. To view
the full safety information, refer to the Samsung
website.
The headset contains magnets in its earbuds.
The American Heart Association (US) and
the Medicines and Healthcare Products
Regulatory Agency (UK) both warn that
magnets can affect the operation of implanted
pacemakers, cardioverters, defibrillators,
insulin pumps or other electro medical
devices (collectively, “Medical Device”) within
the range of 15 cm (6 inches). If you are a user
of any of these Medical Devices, DO NOT USE
THE HEADSET UNLESS YOU HAVE CONSULTED
WITH YOUR PHYSICIAN
Use manufacturer-approved batteries,
chargers, accessories, and supplies
Do not touch the device with wet hands
Do not drop or cause an impact to the charger
or the device
Do not bend or twist the device excessively
10
The device can be used in locations with an
ambient temperature of 0°C to 35°C. You can
store the device at an ambient temperature
of -20°C to 50°C. Using or storing the device
outside of the recommended temperature
ranges may damage the device or reduce the
battery’s lifespan
Do not allow children or animals to chew or
suck the device
Do not disassemble, modify, or repair your
device
Do not use a headset while driving or
riding. Doing so may distract your attention
and cause an accident, or may be illegal
depending on your region
To prevent possible hearing
damage when using a headset, do
not listen to sound at high volume
for long periods.
11
English
Correct disposal
This marking on the product,
accessories or literature indicates
that the product and its electronic
accessories (e.g. charger, headset,
USB cable) should not be disposed
of with other household waste.
This product is RoHS compliant.
This marking on the battery,
manual or packaging indicates
that the batteries in this product
should not be disposed of with
other household waste.
For information on Samsung’s environmental
commitments and product specific regulatory
obligations, e.g. REACH, WEEE, Batteries, visit
samsung.com/uk/aboutsamsung/
samsungelectronics/corporatecitizenship/
data_corner.html
12
Removing the battery
•
To remove the battery, contact an
authorised service centre. To obtain
battery removal instructions, please visit
www.samsung.com/global/
ecodesign_energy.
•
For your safety, you must not attempt to
remove the battery. If the battery is not
properly removed, it may lead to damage to
the battery and device, cause personal injury,
and/or result in the device being unsafe.
•
Samsung does not accept liability for any
damage or loss (whether in contract or tort,
including negligence) which may arise from
failure to precisely follow these warnings and
instructions, other than death or personal
injury caused by Samsung’s negligence.
13
English
Declaration of Conformity
Product details
For the following
Product : Bluetooth Stereo Headset
Model(s) : EO-BG935
Declaration & Applicable standards
We hereby declare, that the product above is in compliance with
the essential requirements of the R&TTE Directive (1999/5/EC) by
application of:
SAFETY EN 60950-1 : 2006 + A11 : 2009 + A1 : 2010 + A12 : 2011 +
A2 : 2013
SAR EN 62479 : 2010
EMC EN 301 489-1 V1.9.2 (09-2011)
EN 301 489-17 V2.2.1 (09-2012)
RADIO EN 300 328 V1.9.1 (02-2015)
and the Directive (2011/65/EU) on the restriction of the use of certain
hazardous substances in electrical and electronic equipment by
application of EN 50581:2012.
Representative in the EU
Samsung Electronics Euro QA Lab.
Blackbushe Business Park
Saxony Way, Yateley, Hampshire
GU46 6GG, UK
2015.09.14 Stephen Colclough / EU Representative
(Place and date of issue) (Name and signature of authorised person)
* This is not the address of Samsung Service Centre. For the address or
the phone number of Samsung Service Centre, see the warranty card or
contact the retailer where you purchased your product.
FCC Warning Statement
FCC Part 15.19
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
FCC Part 15.21
Any changes or modifications (including the antennas) to this device that are not expressly approved by the manufacturer may void the user’s authority
to operate the equipment.
IC Warning Statement
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux
conditions suivantes : (1) L'appareil ne doit pas produire de brouillage, et (2) L'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même
si le brouillage est susceptible d'en compromettre le fonctionnement.
RF Exposure Statement
FCC and IC RF Radiation Exposure Statement: This equipment complies with FCC and IC RF Radiation exposure limits set forth for an uncontrolled
environment.
This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter.
RF du FCC et IC d'exposition aux radiations: Cet équipement est conforme à l'exposition de FCC et IC rayonnements RF limites é-tablies pour un
environnement non contrôlé.
L’antenne pour ce transmetteur ne doit pas être même endroit avec d’autres émetteur sauf conformément à FCC et IC procédures de produits Multi-émetteur.
