Samsung Electronics Co EPN5100 WIRELESS CHARGER User Manual

Samsung Electronics Co Ltd WIRELESS CHARGER

User manual

QUICK
START
GUIDE
EP-N5100
Wireless Charger
Printed in Korea
GH68-48972A Rev.1.0
EU/ASIA Type 12/2017
2
a
b
c
d
e
f
1
3
Copyright © 2017 Samsung Electronics
•
Please read this guide before using the device
to ensure safe and proper use.
•
Images may differ in appearance from the
actual product. Content is subject to change
without prior notice. You can access the
full user manual for more information. Visit
www.samsung.com
to view device information,
the user manual, and more.
•
Before using the wireless charger, make sure it
is compatible with your device.
•
Your consumer rights are governed by the law
of the country in which you purchased the
product. Please contact your service provider
for more information.
Device layout
Wireless charging
surface Indicator light
Charging coil Fan vent
Phone stand Charger port
(Type-C)
4
Using the wireless charger
1. Connect the charger to the wireless charger.
2. Place a supported mobile device on the
phone stand. ( )
Charging will begin when the wireless
charging surface comes into contact with the
mobile device’s wireless charging coil.
3. When the mobile device is fully charged,
remove the mobile device from the wireless
charger.
•
Use only Samsung-approved chargers
above the rated input voltage.
•
Do not place foreign materials, such
as metal objects, magnets, and
magnetic stripe cards, between the
mobile device and the wireless charger.
The mobile device may not charge
properly or may be damaged due to
overheating.
5
•
You may need to purchase a charger
separately depending on the wireless
charger you bought.
•
Wireless charging covers are sold
separately.
•
Depending on the location of the
mobile device’s wireless charging coil,
your mobile device may not charge
properly.
•
Wireless charging may not work
properly if you have attached a thick
case to your mobile device. If your case
is thick, remove it before placing your
mobile device on the wireless charger.
•
If you connect a charger to the mobile
device during wireless charging,
the wireless charging feature will be
unavailable.
•
If you use the wireless charger in areas
with weak network signals, you may
lose network reception.
•
The charger should remain close to the
electric socket and easily accessible
while charging.
•
The socket-outlet shall be installed
near the equipment and shall be easily
accessible.
6
Fast wireless charging
To begin fast wireless charging, place a mobile
device that supports fast wireless charging on the
wireless charger. For more information, refer to
the mobile device’s user manual.
Use only Samsung-approved chargers
that support fast charging (9 V/1.67 A,
9 V/2 A, 12 V/2.1 A).
A fan inside the charger may produce
noise during fast wireless charging.
Safety information
Read all safety information before using the
device to ensure safe and proper use. To view
the full safety information, refer to the Samsung
website.
Use manufacturer-approved batteries,
chargers, accessories, and supplies
Do not touch the device with wet hands
Do not drop or cause an impact to the charger
or the device
7
The device can be used in locations with an
ambient temperature of 0 °C to 35 °C. You can
store the device at an ambient temperature
of -20 °C to 50 °C. Using or storing the device
outside of the recommended temperature
ranges may damage the device or reduce the
battery’s lifespan
Prevent the multipurpose jack, the small end
of the charger, and the fan vent from coming
into contact with conductive materials, such
as liquids, dust, metal powders, and pencil
leads
Do not cover or block the device’s fan vent
Do not allow children or animals to chew or
suck the device
Do not disassemble, modify, or repair your
device
Magnetic stripe cards, including credit cards,
phone cards, passbooks, and boarding passes,
may be damaged by magnetic fields
8
Correct disposal
This marking on the product,
accessories or literature indicates
that the product and its electronic
accessories (e.g. charger, headset,
USB cable) should not be disposed
of with other household waste.
This product is RoHS compliant.
For information on Samsung’s environmental
commitments and product-specific regulatory
obligations, e.g. REACH, WEEE, Batteries, visit
samsung.com/uk/aboutsamsung/
samsungelectronics/corporatecitizenship/
data_corner.html
Declaration of Conformity
Samsung Electronics declares that this device
complies with the essential requirements and
relevant provisions of Directive 2014/53/EU.
Go to
www.samsung.com/mobile_doc
to view
the Declaration of Conformity.
Band and mode
Band and mode Output power
Wireless Charging
110 kHz–148 kHz
H field of
37.7 dBµA/m at 10 m
