Samsung Electronics Co GTC3200 Cellular/PCS GSM Phone with Bluetooth User Manual
Samsung Electronics Co Ltd Cellular/PCS GSM Phone with Bluetooth Users Manual
Users Manual
Printed in Korea
Code No.:GH68-xxxxx
English (EU). 05/2010. Rev. 1.0
Some of the contents in this manual may differ from your phone
depending on the software of the phone or your service provider.
www.samsungmobile.com
GT-C3200
user manual
Draft only
2
Using this manual
This user manual has been specially designed to
guide you through the functions and features of
your mobile phone. To get started quickly, refer to
"Introducing your mobile phone," "Assembling and
preparing your mobile phone," and "Using basic
functions."
Instructional icons
Note: notes, usage tips, or additional
information
→
Followed by: the order of options or menus
you must select to perform a step; for example:
In Menu mode, select Messages → Create
message (represents Messages, followed by
Create message)
[ ] Square brackets: phone keys; for example:
[] (represents the Power/End key)
< >
Angled brackets: softkeys that control different
functions at each screen; for example: <OK>
(represents the OK softkey)
►Refer to: pages with related information; for
example: ► p. 12 (represents "see page 12")
3
Copyright information
Rights to all technologies and products that
comprise this phone are the property of their
respective owners:
Bluetooth•
®
is a registered trademark of the
Bluetooth SIG, Inc. worldwide.
Java™ is a trademark of Sun Microsystems, •
Inc.
4
Contents
Introducing your mobile phone ...............................6
Phone layout ...............................................................6
Icons ............................................................................8
Assembling and preparing your mobile phone ...10
Install the SIM card and battery ................................10
Charge the battery .................................................... 11
Insert a memory card (optional) ................................12
Using basic functions.............................................13
Turn your phone on or off ..........................................13
Access menus ...........................................................13
Customise your phone ..............................................14
Use basic call functions ............................................16
Send and view messages .........................................18
Enter text ...................................................................19
Add and nd contacts ...............................................20
Use basic camera functions ......................................21
Listen to music ..........................................................23
Browse the web.........................................................25
Using advanced functions .....................................26
Use advanced call functions .....................................26
Use advanced phonebook functions ........................30
Use advanced messaging functions .........................31
Use advanced camera functions ..............................32
Use advanced music functions .................................35
5
Using tools and applications .................................38
Use the Bluetooth wireless feature ...........................38
Activate and send an SOS message ........................40
Activate the mobile tracker ........................................41
Make fake calls .........................................................42
Record and play voice memos .................................43
View photos and videos on the web .........................43
Use Java-powered games and applications .............44
Create a world clock .................................................44
Set and use alarms ...................................................45
Use the calculator .....................................................46
Convert currencies or measurements ......................46
Set a countdown timer ..............................................46
Use the stopwatch ....................................................47
Create a text memo ..................................................47
Manage your calendar ..............................................48
Back up your data .....................................................49
Troubleshooting ......................................................50
Safety and usage information ...............................56
6
Introducing your
mobile phone
In this section, learn about your mobile phone’s
layout, keys, and icons.
Phone layout
4
5
1 0
9
1
3
2 6
7
8
7
1
4-way navigation key
In ldle mode, access user-
dened menus; Make a fake
call (down); In Menu mode,
scroll through menu options
Depending on your service
provider, pre-dened menus
may differ
► " Make fake calls"
2
Volume key
In Idle mode, adjust the key
tone volume; Send an SOS
message
► Activate and send an SOS
message
3
Dial key
Make or answer a call; In Idle
mode, retrieve recently dialled,
missed, or received numbers;
4
Voice mail service key
In ldle mode, access voice
mails (press and hold)
5
Keypad lock key
In Idle mode, lock the keys
6
Softkeys
Perform actions indicated at
the bottom of the display
7
Conrm key
In Idle mode, access Menu
mode; Launch the web
browser (press and hold);
In Menu mode, select the
highlighted menu option or
conrm an input
Depending on your service
provider or region, the key may
perform differently
8
Power/End key
Turn the phone on or off
(press and hold); End a call; In
Menu mode, cancel input and
return to Idle mode
9
Alphanumeric keys
1 0
Silent prole key
In ldle mode, activate or
deactivate the silent prole
(press and hold)
8
Icons
Icons shown on the display may vary depending
on your region or service provider.
Icon Denition
Signal strength
SOS message feature activated
GPRS network connected
EDGE network connected
Call in progress
Bluetooth activated
Music playback in progress
Music playback paused
FM radio on
FM radio suspended
Memory card inserted
Connected with PC
Alarm activated
Browsing the web
9
Icon Denition
Connecting to secured web page
Call diverting activate
Roaming (outside of normal area)
Normal prole activated
Silent prole activated
New text message (SMS)/New multimedia
message (MMS)
New email message
New voice mail message
Battery power level
Current time
10
Assembling and
preparing your mobile
phone
Get started by assembling and setting up your
mobile phone for its first use.
Install the SIM card and battery
Remove the back cover and insert the SIM 1.
card.
Back cover SIM card
Insert the battery and replace the back cover.2.
Battery
11
Charge the battery
Plug the small end of the supplied travel 1.
adapter into the multifunction jack.
Plug the large end of the travel adapter into a 2.
power outlet.
When charging is finished, unplug the travel 3.
adapter.
Do not remove the battery from the phone before
unplugging the travel adapter rst. Otherwise, the
phone may be damaged.
12
Insert a memory card (optional)
Your phone accepts microSD™ or microSDHC™
memory cards up to 8 GB (depending on memory
card manufacturer and type).
Formatting the memory card on a PC may cause •
incompatibility with your phone. Format the
memory card only on the phone.
Frequent writing and erasing of data will shorten •
the lifespan of memory cards.
Open the cover to the memory card slot on the 1.
left side of the phone.
Insert a memory card with the gold-coloured 2.
contacts facing up.
Push the memory card into the memory 3.
cardslot until it locks in place.
Memory card
Memory card cover
13
Using basic functions
Learn how to perform basic operations and use the
main features of your mobile phone.
Turn your phone on or off
To turn your phone on,
Press and hold [1. ].
Enter your PIN and press <2. OK> (if necessary).
When the setup wizard opens, customise your 3.
phone as desired by following the screen.
To turn your phone off, repeat step 1 above.
Access menus
To access your phone's menus,
In Idle mode, press <1. Menu> to access Menu
mode.
You may need to press the Conrm key to access
Menu mode depending on your region or service
provider. When you are using the smart home
screen, you cannot use the Conrm key to access
Menu mode.
Use the Navigation key to scroll to a menu or 2.
option.
14
Press <3. Select>, <Save>, or the Confirm key to
confirm the highlighted option.
Press <4. Back> to move up one level; Press
[] to return to Idle mode.
When you access a menu requiring the PIN2, •
you must enter the PIN2 supplied with the SIM
card. For details, contact your service provider.
Samsung is not responsible for any loss of •
passwords or private information or other
damages caused by illegal software.
Customise your phone
To switch to or from the silent prole
In Idle mode, press and hold [ ] to silence or
unsilence your phone.
To set the sound prole
To switch to sound profile,
In Menu mode, select 1. Settings → Sound
profiles.
Select a profile you want.2.
To edit a sound profile,
In Menu mode, select 1. Settings → Sound
profiles.
15
Scroll to a user profile and press <2. Edit>.
Customise the sound settings as desired.3.
To set menu shortcuts
In Menu mode, select 1. Settings → Phone →
Shortcuts.
Select a key to use as a shortcut.2.
Select a menu to assign to the shortcut key.3.
When you are using the smart home screen, the
Navigation keys do not work as shortcuts.
To use the recycle bin
With the recycle bin, the data you deleted, such as
messages, contacts, and tasks, will be sent to the
recycle bin instead of being deleted permanently.
You can later restore the data or empty your
recycle bin to permanently delete.
To move an item to the recycle bin, you must
delete one item at a time.
To activate the recycle bin,
In Menu mode, select 1. Settings → Recycle
bin.
Press <2. Options> → Recycle bin activation.
16
Scroll to an application you want and press the 3.
Confirm key.
Press <4. Save>.
To restore the deleted data,
In Menu mode, select 1. Settings → Recycle
bin.
Scroll to an application you want.2.
Press the Confirm key to restore your data.3.
To empty the recycle bin,
In Menu mode, select 1. Settings → Recycle
bin.
Scroll to an application you want.2.
Press <3. Options> → Empty Recycle bin.
Use basic call functions
To make a call
In Idle mode, enter an area code and a phone 1.
number.
Press [2. ] to dial the number.
To end the call, press [3. ].
To answer a call
When a call comes in, press [1. ].
17
To end the call, press [2. ].
To adjust the volume of voice during a call
While a call is in progress, press the Navigation
key up or down to adjust the volume.
To use the speakerphone feature
During a call, press the Confirm key → <1. Yes>
to activate the speaker.
To switch back to the earpiece, press the 2.
Confirm key again.
In noisy environments, you may have difculty
hearing the calls while using the speakerphone
feature. For better audio performance, use the
normal phone mode.
To use the headset
By plugging the supplied headset into the
multifunction jack, you can make and answer calls:
To redial the last call, press and hold the •
headset button.
To answer a call, press the headset button.•
To end a call, press and hold the headset •
button.
18
Send and view messages
To send a text or multimedia message
In Menu mode, select 1. Messages → Create
message.
Enter a recipient number and scroll down.2.
Enter your message text. ► p. 3. 19
For sending as a text message, skip to step 5.
For attaching multimedia, continue with step 4.
Press <4. Options> → Add multimedia and add
an item.
Press the Confirm key to send the message.5.
To view text or multimedia messages
In Menu mode, select 1. Messages → Inbox.
Select a text or multimedia message.2.
19
Enter text
You can enter text by pressing keys on the keypad.
Available text input modes may vary depending
on your region.
To change the text input mode
Press and hold [• ] to switch between T9 and
ABC modes.
Press [• ] to change case or switch to Number
mode.
Press [• ] to switch to Symbol mode.
Press and hold [• ] to select an input mode or
change the input language.
T9 mode
Press appropriate alphanumeric keys to enter 1.
an entire word.
When the word displays correctly, press [2. 0]
to insert a space. If the correct word does not
display, press the Navigation key up or down to
select an alternate word.
ABC mode
Press an appropriate alphanumeric key until the
character you want appears on the display.
20
Number mode
Press an appropriate alphanumeric key to enter a
number.
Symbol mode
Press an appropriate alphanumeric key to enter
a symbol.
To move the cursor, press the Navigation key.•
To delete characters one by one, press <• Clear>.
To quickly delete characters, press and hold
<Clear>.
To insert a space between characters, press [• 0].
To enter punctuation marks, press [• 1].
Add and nd contacts
The memory location to save new contacts may
be preset depending on your service provider.
To change the memory location, in Menu mode,
select Contacts → <Options> → Settings →
Save new contact to → a memory location.
To add a new contact
In Idle mode, enter a phone number and press 1.
<Options>.
21
Select 2. Add to Contacts → Create contact →
a memory location (if necessary).
Select a number type (if necessary).3.
Enter contact information.4.
Press the Confirm key to add the contact to 5.
memory.
To nd a contact
In Menu mode, select 1. Contacts.
Enter the first few letters of the name you want 2.
to find.
Select the contact’s name from the contact list.3.
Use basic camera functions
To capture photos
In Menu mode, select 1. Camera to turn on the
camera.
Aim the lens at the subject and make any 2.
adjustments.
Press the Confirm key to take a photo. The 3.
photo is saved automatically.
Press <4. Back> to take another photo (step 2).
22
To view photos
In Menu mode, select My files → Images → a
photo file.
To capture videos
In Menu mode, select 1. Camera to turn on the
camera.
Press <2. Options> → Camcorder to switch to
the camcorder.
Aim the lens at the subject and make any 3.
adjustments.
Press the Confirm key to start recording.4.
Press 5. to stop recording. The video is saved
automatically.
To view videos
In Menu mode, select My files → Videos → a
video file.
23
Listen to music
To listen to the FM radio
Plug the supplied headset into the phone.1.
In Menu mode, select 2. Apps → FM radio.
Press the Confirm key to start the FM radio.3.
Press <4. Yes> to start automatic tuning.
The radio scans and saves available stations
automatically.
The rst time you turn on the FM radio, you will be
prompted to start automatic tuning.
Control the FM radio using the following keys:5.
Key Function
Conrm Turn the FM radio on or off
Navigation
Left/Right: Search for an available •
radio station; Search for an available
radio station. When the key is
released, the selected station will be
tuned automatically (press and hold)
Up/Down: Select a radio station saved •
in the favourites list
24
To listen to music les
Start by transferring files to your phone or memory
card:
Download from the wireless web. ► p. • 25
Download from a PC with the optional •
Samsung Kies. ► p. 35
Receive via Bluetooth. ► p. • 38
Copy to your memory card. ► p. • 35
After transferring music files to your phone or
memory card,
In Menu mode, select 1. Music.
Select a music category → a music file.2.
Control playback using the following keys:3.
Key Function
Conrm Pause or resume playback
/Adjust the volume
Navigation
Left: Restart playback; Skip backward •
(press within 2 seconds); Scan
backward in a le (press and hold)
Right: Skip forward; Scan forward in a •
le (press and hold)
Up: Open the playlist•
Down: Change the repeat mode•
25
Browse the web
The web browser menu may be labelled differently
depending on your service provider.
To browse web pages
In Menu mode, select 1. Internet to launch your
service provider’s homepage.
Navigate web pages using the following keys:2.
Key Function
Navigation Scroll up or down on a web page
Conrm Select an item
<Back>Return to the previous page
<Options>Access a list of browser options
To bookmark your favourite web pages
In Menu mode, select 1. Internet.
Press <2. Options> → Bookmarks.
Press <3. Options> → Add bookmark.
Enter a page title and a web address (URL) 4.
and press the Confirm key.
26
Using advanced
functions
Learn how to perform advanced operations and
use additional features of your mobile phone.
Use advanced call functions
To view and dial missed calls
Your phone will display calls you have missed on
the display. To dial the number of a missed call,
Press <1. Open>.
Scroll to the missed call you want to dial.2.
Press [3. ] to dial.
To call a recently dialled number
In Idle mode, press [1. ].
Scroll left or right to a call type.2.
Scroll up or down to a number or name.3.
Press the Confirm key to view details of the call 4.
or [ ] to dial the number.
27
To hold a call or retrieve a held call
Press <Hold> to place a call on hold or press
<Retrieve> to retrieve a held call.
To dial a second call
If your network supports this function, you can dial
another number during a call:
Press <1. Hold> to place the first call on hold.
Enter the second number to dial and press 2.
[].
Press <3. Swap> to switch between the two calls.
To answer a second call
If your network supports this function, you can
answer a second incoming call:
Press [1. ] to answer the second call.
The first call is automatically placed on hold.
Press <2. Swap> to switch between the calls.
28
To make a multiparty call (conference call)
Call the first party you want to add to the 1.
multiparty call.
While connected to the first party, call the 2.
second party.
The first party is automatically placed on hold.
When connected to the second party, press 3.
<Options> → Join.
To call an international number
In Idle mode, press and hold [1. 0] to insert the +
character.
Enter the complete number you want to dial 2.
(country code, area code, and phone number),
and then press [ ] to dial.
To call a contact from the phonebook
In Menu mode, select 1. Contacts.
Scroll to the number you want to dial and press 2.
[] to dial.
29
To reject a call
To reject an incoming call, press [ ]. The caller
will hear a busy tone.
To reject calls from certain numbers automatically,
use auto rejection. To activate auto rejection and
set up the reject list,
In Menu mode, select 1. Settings → Call → All
calls → Auto reject.
Press the Confirm key to activate auto 2.
rejection.
Scroll down and select 3. Reject list.
Press <4. Options> → Create.
Enter a number to reject.5.
Press the Confirm key.6.
To add more numbers, repeat steps 4-6 above.7.
Select the numbers to reject.8.
Press <9. Options> → Save.
30
Use advanced phonebook
functions
To create your namecard
In Menu mode, select 1. Contacts.
Press <2. Options> → Settings → My
namecard.
Enter your personal details and press the 3.
Confirm key.
To create a group of contacts
In Menu mode, select 1. Contacts → Groups.
Press <2. Options> → Create group.
Enter a group name and press the Confirm key.3.
To set a group ringtone, press <4. Options> →
Group ringtone → the Confirm key.
Select a ringtone category → a ringtone.5.
31
Use advanced messaging
functions
To create a text template
In Menu mode, select 1. Messages → My
folders → Templates.
Press <2. Create> to open a new template
window.
Enter your text and press the Confirm key to 3.
save the template.
To insert text templates in new messages
In Menu mode, select 1. Messages → Create
message.
In the text input field, press <2. Options> → Add
text → Template → a template.
To use the instant messenger
In Menu mode, select 1. Comms. → Instant
messenger.
Enter your user name and password, and press 2.
<Sign In>.
Chat with your family or friends instantly.3.
32
To use the Bluetooth messenger
In Menu mode, select 1. Comms. → Bluetooth
messenger.
Press the Confirm key.2.
Press <3. Yes> to turn on the Bluetooth wireless
feature (if necessary).
Press <4. Search>.
Select a device.5.
Enter a PIN for the Bluetooth wireless feature 6.
or the other device's Bluetooth PIN, or press
<Send> to send the message.
Use advanced camera functions
To capture photos with decorative frames
In Menu mode, select 1. Camera to turn on the
camera.
Press <2. Options> → Shooting mode →
Frames.
Select a frame and press the Confirm key.3.
Make any necessary adjustments.4.
Press the Confirm key to take a photo with the 5.
frame.
33
To use camera options
Before capturing a photo, press <Options> to
access the following options:
Option Function
Mode Switch to camera or camcorder
Shooting mode Change the shooting mode
Resolution Change the resolution
White balance Adjust the colour balance according
to lighting conditions
Effects Apply a special effect
Night mode on/
Night mode off Set whether to use Night shot mode
Before capturing a video, press <Options> to
access the following options:
Option Function
Mode Switch to camera or camcorder
Recording mode Change the recording mode
White balance Adjust the colour balance according
to lighting conditions
Effects Apply a special effect
34
To customise camera settings
Before capturing a photo, press <Options> →
Settings to access the following settings:
Option Function
Quality Set the quality level for your photos
Viewnder mode Change the preview screen
Review Set the camera to display the
captured image
Shutter sound Set the camera shutter to make a
sound when capturing a photo
Storage Select a memory location for storing
captured photos
Shortcut info View the shortcut information
Before capturing a video, press <Options> →
Settings to access the following settings:
Option Function
Quality Set the quality level of your videos
Viewnder mode Change the preview screen
Audio recording Turn the audio on or off
Storage Select a memory location for storing
captured videos
Shortcut info View the shortcut information
35
Use advanced music functions
To copy music les via Samsung Kies
In Menu mode, select 1. Settings → PC
connections → Samsung Kies or Mass
storage.
Using a PC data cable, connect the 2.
multifunction jack on your phone to a PC.
Run Samsung Kies and copy files from the PC 3.
to the phone.
To transfer data from a PC to your phone, you
need Windows XP Service Pack 2.
To copy music les to a memory card
Insert a memory card.1.
In Menu mode, select 2. Settings → PC
connections → Mass storage.
Using an PC data cable, connect the 3.
multifunction jack on your phone to a PC.
When connected, a pop-up window will appear
on the PC.
Open a folder to view files.4.
Copy files from the PC to the memory card.5.
36
To create a playlist
In Menu mode, select 1. Music → Library →
Playlists.
Press <2. Create>.
Enter a title for your new playlist and press the 3.
Confirm key.
Select the new playlist.4.
Press <5. Options> → <Add> → Tracks.
Select the files you want to include and press 6.
<Add>.
To customise your music player settings
In Menu mode, select 1. Music → Settings →
Player settings.
Adjust the settings to customise your music 2.
player.
Press <3. Save>.
37
To record songs from the FM radio
In Menu mode, select 1. Apps → FM radio.
Press the Confirm key to start the FM radio.2.
Select a radio station you want.3.
Press <4. Options> → Record to start recording.
When you are finished recording, press 5.
<Stop>.
To set up your favourite station list
In Menu mode, select 1. Apps → FM radio.
Select a radio station to add to the favourite 2.
station list.
Press <3. Options> → Add to → Favourites.
Select an empty location you want to set.4.
You can access your favourite stations by pressing
the location number on the FM radio screen.
38
Using tools and
applications
Learn how to work with your mobile phone’s tools
and additional applications
Use the Bluetooth wireless feature
To turn on the Bluetooth wireless feature
In Menu mode, select 1. Apps → Bluetooth.
Press <2. Options> → Settings.
Scroll left or right to 3. On.
To allow other devices to locate your phone, 4.
select On under My phone's visibility → a
visibility option.
If you selected Custom, set duration that your
phone is visible.
Press <5. Save>.
To nd and pair with other Bluetooth-enabled
devices
In Menu mode, select 1. Apps → Bluetooth.
Press <2. Search>.
39
Select a device.3.
Enter a PIN for the Bluetooth wireless feature 4.
or the other device’s Bluetooth PIN, if it has
one, and press <OK>.
When the owner of the other device enters the
same code or accepts the connection, pairing
is complete.
You may not need to enter a PIN depending on
the device.
To send data using the Bluetooth wireless
feature
Select the file or item from one of your phone’s 1.
applications that you want to send.
Press <2. Options> → Send via or Send
namecard via → Bluetooth (when sending
contact data, specify which data to send).
To receive data using the Bluetooth wireless
feature
Enter the PIN for the Bluetooth wireless feature 1.
and press <OK> (if necessary).
Press <2. Yes> to confirm that you are willing to
receive data from the device (if necessary).
40
Activate and send an SOS
message
In an emergency, you can send SOS messages to
your family or friends for help.
To activate the SOS message
In Menu mode, select 1. Messages → Settings
→ SOS messages → Sending options.
Scroll left or right to 2. On.
Scroll down and press the Confirm key to open 3.
the recipient list.
Press <4. Options> → Search to open your
contact list.
Select a contact.5.
Select a number (if necessary).6.
When you are finished selecting contacts, 7.
press the Confirm key to save the recipients.
Scroll down and set the number of times to 8.
repeat the SOS message.
Press <9. Back> → <Yes>.
41
To send an SOS message
With the phone closed and the key locked, 1.
press [ /] four times to send an SOS message
to preset numbers.
The phone switches to SOS mode and sends
the preset SOS message.
To exit SOS mode, press [2. ].
Activate the mobile tracker
When someone inserts a new SIM card in your
phone, the mobile tracker feature will automatically
send the contact number to specified recipients to
help you locate and recover your phone.
In Menu mode, select 1. Settings → Security →
Mobile tracker.
Enter your password and press <2. OK>.
The rst time you access Mobile tracker, you will
be prompted to create and conrm a password.
Scroll left or right to 3. On.
Scroll down and press the Confirm key to open 4.
the recipient list.
Press <5. Options> → Contacts to open your
contact list.
Select a contact.6.
42
Select a number.7.
When you are finished setting the recipients, 8.
press <Select>.
Press the Confirm key to save the recipients.9.
Scroll down and enter a sender’s name.10.
Press <11. Save> → <Accept>.
Make fake calls
You can simulate an incoming call when you want
to get out of meetings or unwanted conversations.
To activate the fake call feature
In Menu mode, select Settings → Call → Fake
Call → Fake call hot key → On.
To make a fake call
In Idle mode, press and hold the navigation •
key down.
With the keys locked, press the navigation key •
down four times.
43
Record and play voice memos
To record a voice memo
In Menu mode, select 1. Apps → Voice recorder.
Press the Confirm key to start recording.2.
Speak your memo into the microphone.3.
When you are finished speaking, press 4.
<Stop>.
To play a voice memo
From the voice recorder screen, press 1.
<Options> → Go to My voice clips.
Select a file.2.
View photos and videos on the
web
Learn to access photo sharing websites and blogs
and view photos and videos.
The feature may be unavailable depending on
your region or service provider.
In Menu mode, select 1. Comms.
Select a website or blog you want to view.2.
Enter your user ID and password of the 3.
destination (if necessary).
44
Use Java-powered games and
applications
In Menu mode, select 1. Apps → Games and
more.
Select a game or application from the list and 2.
follow the on-screen instructions.
The download of Java games or applications •
may not be supported depending on the
software of the phone.
Available games may vary depending on your •
service provider or region. Game controls and
options may vary.
Create a world clock
In Menu mode, select 1. Organiser → World
clock.
Press <2. Add>.
Scroll left or right to a time zone and press 3.
<Save>.
To add more world clocks, repeat steps 2-3 4.
above.
45
Set and use alarms
Learn to set and control alarms for important
events.
To set a new alarm
In Menu mode, select 1. Alarms.
Press <2. Create>.
Set the details of the alarm.3.
Press <4. Save>.
To stop an alarm
When the alarm sounds,
Press <• Confirm> or the Confirm key to stop
the alarm.
Press <• Snooze> to silence the alarm for the
snooze period.
To deactivate an alarm
In Menu mode, select 1. Alarms.
Select the alarm you want to deactivate.2.
Scroll to 3. Alarm activation.
Press the Confirm key to select 4. Deactivate.
Press <5. Save>.
46
Use the calculator
In Menu mode, select 1. Organiser →
Calculator.
Use the keys that corresponds to the calculator 2.
display to perform basic mathematical
operations.
Convert currencies or
measurements
In Menu mode, select 1. Organiser → Convertor
→ a conversion type.
Enter the currencies measurements and units 2.
in the appropriate fields.
Set a countdown timer
In Menu mode, select 1. Apps → Timer.
Enter the time to count down and press 2.
<Start>.
When the timer expires, press <3. OK> to stop
the alert.
47
Use the stopwatch
In Menu mode, select 1. Apps → Stopwatch.
Press <2. Start> to begin the stopwatch.
Press the Confirm key to record lap times.3.
When you are finished, press <4. Stop>.
Press <5. Reset> to clear recorded times.
While recording the lap times, the interval between
lap times is recorded. To check the interval, scroll
left or right to Split.
Create a text memo
In Menu mode, select 1. Organiser → Memo.
Press <2. Create>.
Enter your memo text and press the Confirm 3.
key.
48
Manage your calendar
To change the calendar view
In Menu mode, select 1. Organiser → Calendar.
Press <2. Options> → View by week or View
by month.
To create an event
In Menu mode, select 1. Organiser → Calendar.
Press <2. Options> → Create → an event type.
Enter the details of the event as required.3.
Press <4. Save>.
To view events
In Menu mode, select 1. Organiser → Calendar.
Select a date on the calendar.2.
Select an event to view its details.3.
49
Back up your data
Use Backup manager to back up your data, such
as messages, contacts, and tasks to your memory
card or My files. If necessary, you can restore
them to your phone.
To back up your data
In Menu mode, select 1. Settings → Backup
manager.
Select 2. Backup.
Select a category and select items to back up.3.
Press <4. Backup>.
To restore your data
In Menu mode, select 1. Settings → Backup
manager.
Select 2. Register.
Select a category and select items to restore.3.
Press <4. Register>.
50
Troubleshooting
When you turn on your phone or while you are
using the phone, it prompts you to enter one of
the following codes:
Code Try this to solve the problem:
Password
When the phone lock feature is enabled,
you must enter the password you set for
the phone.
PIN
When using the phone for the rst time or
when the PIN requirement is enabled, you
must enter the PIN supplied with the SIM
card. You can disable this feature by using
the PIN lock menu.
PUK
Your SIM card is blocked, usually as a
result of entering your PIN incorrectly
several times. You must enter the PUK
supplied by your service provider.
PIN2
When you access a menu requiring the
PIN2, you must enter the PIN2 supplied
with the SIM card. For details, contact your
service provider.
51
Your phone displays "Service unavailable" or
"Network error"
When you are in areas with weak signals or poor •
reception, you may lose reception. Move to another
area and try again.
You cannot access some options without a •
subscription. Contact your service provider for more
details.
Calls are being dropped
When you are in areas with weak signals or poor
reception, you may lose your connection to the
network. Move to another area and try again.
Outgoing calls are not connected
Ensure that you have pressed the Dial key.•
Ensure that you have accessed the right cellular •
network.
Ensure that you have not set call barring for the •
phone number you are dialling.
Incoming calls are not connected
Ensure that your phone is turned on.•
Ensure that you have accessed the right cellular •
network.
Ensure that you have not set call barring for the •
incoming phone number.
52
Others cannot hear you speaking on a call
Ensure that you are not covering the built-in •
microphone.
Ensure that the microphone is close to your mouth.•
If using a headset, ensure that it is properly •
connected.
Audio quality is poor
Ensure that you are not blocking the phone's internal •
antenna.
When you are in areas with weak signals or poor •
reception, you may lose reception. Move to another
area and try again.
When dialling from contacts, the call is not
connected
Ensure that the correct number is stored in the •
contact list.
Re-enter and save the number, if necessary.•
Ensure that you have not set call barring for the •
contact's phone number.
The phone beeps and the battery icon ashes
Your battery is low. Recharge or replace the battery to
continue using the phone.
53
The battery does not charge properly or the
phone turns off
The battery terminals may be dirty. Wipe both gold-•
coloured contacts with a clean, soft cloth and try
charging the battery again.
If the battery will no longer charge completely, •
dispose of the old battery properly and replace it
with a new battery (refer to your local ordinances for
proper disposal instructions).
Your phone is hot to the touch
When you use applications that require more power or
use applications on your phone for an extended period
of time, your phone may feel hot to the touch. This is
normal and should not affect your phone's lifespan or
performance.
Error messages appear when launching the
camera
Your Samsung mobile phone must have sufcient
available memory and battery power to operate the
camera application. If you receive error messages
when launching the camera, try the following:
Charge the battery or replace it with a battery that is •
fully charged.
Free some memory by transferring les to a PC or •
deleting les from your phone.
Restart the phone. If you are still having trouble with •
the camera application after trying these tips, contact
a Samsung Service Centre.
54
Error messages appear when launching the
FM radio
The FM radio application on your Samsung mobile
phone uses the headset cable as an antenna. Without
a headset connected, the FM radio will be unable to
receive radio stations. To use the FM radio, rst ensure
that the headset is properly connected. Next, scan for
and save the available radio stations.
If you still cannot use the FM radio after performing
these steps, try accessing your desired station with
another radio receiver. If you can hear the station with
another receiver, your phone may require service.
Contact a Samsung Service Centre.
Error messages appear when opening music
les
Some music les may not play on your Samsung
mobile phone for a variety of reasons. If you receive
error messages when opening music les on your
phone, try the following:
Free some memory by transferring les to a PC or •
deleting les from your phone.
Ensure that the music le is not Digital Rights •
Management (DRM)-protected. If the le is DRM-
protected, ensure that you have the appropriate
license or key to play the le.
Ensure that your phone supports the le type.•
55
Another Bluetooth device is not located
Ensure that the Bluetooth wireless feature is •
activated on your phone.
Ensure that the Bluetooth wireless feature is •
activated on the device you wish to connect to, if
necessary.
Ensure that your phone and the other Bluetooth •
device are within the maximum Bluetooth range (10
metres/30 feet).
If the tips above do not solve the problem, contact a
Samsung Service Centre.
A connection is not established when you
connect the phone to a PC
Ensure that the PC data cable you are using is •
compatible with your phone.
Ensure that you have the proper drivers installed and •
updated on your PC.
63
Health and safety
information
Exposure to Radio Frequency (RF)
Signals
Certification Information (SAR)
Your wireless phone is a radio transmitter
and receiver. It is designed and
manufactured not to exceed the exposure
limits for radio frequency (RF) energy set by
the Federal Communications Commission
(FCC) of the U.S. government. These FCC
exposure limits are derived from the
recommendations of two expert
organizations, the National Counsel on
Radiation Protection and Measurement
(NCRP) and the Institute of Electrical and
Electronics Engineers (IEEE). In both cases,
Memory status Check memory information
for each items in the
phone’s memory or on a
memory card.
Reset settings Reset the phone’s settings
you have changed.
Key
management
Manage the licence keys
you have acquired to
activate media files locked
by DRM systems.
Menu Description
E840-2.fm Page 41 Monday, May 14, 2007 9:04 AM
Health and safety information
64
the recommendations were developed by
scientific and engineering experts drawn
from industry, government, and academia
after extensive reviews of the scientific
literature related to the biological effects of
RF energy.
The exposure limit set by the FCC for
wireless mobile phones employs a unit of
measurement known as the Specific
Absorption Rate (SAR). The SAR is a
measure of the rate of absorption of RF
energy by the human body expressed in
units of watts per kilogram (W/kg). The FCC
requires wireless phones to comply with a
safety limit of 1.6 watts per kilogram (1.6
W/kg). The FCC exposure limit incorporates
a substantial margin of safety to give
additional protection to the public and to
account for any variations in measurements.
SAR tests are conducted using standard
operating positions accepted by the FCC with
the phone transmitting at its highest
certified power level in all tested frequency
bands. Although the SAR is determined at
the highest certified power level, the actual
SAR level of the phone while operating can
be well below the maximum value. This is
because the phone is designed to operate at
E840-2.fm Page 42 Monday, May 14, 2007 9:04 AM
E840-2.fm Page 43 Monday, May 14, 2007 9:04 AM
65
For body worn operations, this model phone
has been tested and meets the FCC
exposure guidelines when used with a
Samsung accessory designated for this
product or when used with an accessroy that
contains no metal and that positons the
handset a minimum 1.5 cm from the body.
Non-compliance with the above restrictions
may result in violation of FCC RF exposure
guidelines.
SAR information on this and other model
phones can be viewed on-line at
www.fcc.gov/oet/fccid. This site uses the
phone FCC ID number A3LGTC3200.
Sometimes it may be necessary to remove
the battery pack to find the number. Once
you have the FCC ID number for a particular
phone, follow the instructions on the website
and it should provide values for typical or
maximum SAR for a particular phone.
Additional product specific SAR information
can also be obtained at www.fcc.gov/cgb/
sar.
43
multiple power levels so as to use only the
power required to reach the network. In
general, the closer you are to a wireless
base station antenna, the lower the power
output.
Before a new model phone is available for
sale to the public, it must be tested and
certified to the FCC that it does not exceed
the exposure limit established by the FCC.
Tests for each model phone are performed in
positions and locations (e.g. at the ear and
worn on the body) as required by the FCC.
Health and safety information
66
Consumer Information on Wireless
Phones
The U.S. Food and Drug Administration
(FDA) has published a series of Questions
and Answers for consumers relating to radio
frequency (RF) exposure from wireless
phones. The FDA publication includes the
following information:
What kinds of phones are the subject
of this update?
The term wireless phone refers here to
hand-held wireless phones with built-in
antennas, often called “cell,” “mobile,” or
“PCS” phones. These types of wireless
phones can expose the user to measurable
radio frequency energy (RF) because of the
short distance between the phone and the
user's head. These RF exposures are limited
by Federal Communications Commission
safety guidelines that were developed with
the advice of FDA and other federal health
and safety agencies. When the phone is
located at greater distances from the user,
the exposure to RF is drastically lower
because a person's RF exposure decreases
rapidly with increasing distance from the
source. The so-called “cordless phones,”
which have a base unit connected to the
telephone wiring in a house, typically
operate at far lower power levels, and thus
produce RF exposures well within the FCC's
compliance limits.
Do wireless phones pose a health
hazard?
The available scientific evidence does not
show that any health problems are
associated with using wireless phones. There
is no proof, however, that wireless phones
are absolutely safe. Wireless phones emit
low levels of radio frequency energy (RF) in
the microwave range while being used. They
E840-2.fm Page 44 Monday, May 14, 2007 9:04 AM
67
also emit very low levels of RF when in the
stand-by mode. Whereas high levels of RF
can produce health effects (by heating
tissue), exposure to low level RF that does
not produce heating effects causes no
known adverse health effects. Many studies
of low level RF exposures have not found
any biological effects. Some studies have
suggested that some biological effects may
occur, but such findings have not been
confirmed by additional research. In some
cases, other researchers have had difficulty
in reproducing those studies, or in
determining the reasons for inconsistent
results.
What is FDA's role concerning the
safety of wireless phones?
Under the law, FDA does not review the
safety of radiation-emitting consumer
products such as wireless phones before
they can be sold, as it does with new drugs
or medical devices. However, the agency has
authority to take action if wireless phones
are shown to emit radio frequency energy
(RF) at a level that is hazardous to the user.
In such a case, FDA could require the
manufacturers of wireless phones to notify
users of the health hazard and to repair,
replace or recall the phones so that the
hazard no longer exists.
Although the existing scientific data do not
justify FDA regulatory actions, FDA has
urged the wireless phone industry to take a
number of steps, including the following:
E840-2.fm Page 45 Monday, May 14, 2007 9:04 AM
Health and safety information
68
• “Support needed research into possible
biological effects of RF of the type
emitted by wireless phones;
• “Design wireless phones in a way that
minimizes any RF exposure to the user
that is not necessary for device function;
and
• “Cooperate in providing users of wireless
phones with the best possible
information on possible effects of
wireless phone use on human health.
FDA belongs to an interagency working
group of the federal agencies that have
responsibility for different aspects of RF
safety to ensure coordinated efforts at the
federal level. The following agencies belong
to this working group:
• “National Institute for Occupational
Safety and Health
• “Environmental Protection Agency
• “Federal Communications Commission
• “Occupational Safety and Health
Administration
• “National Telecommunications and
Information Administration
The National Institutes of Health participates
in some interagency working group
activities, as well.
FDA shares regulatory responsibilities for
wireless phones with the Federal
Communications Commission (FCC). All
phones that are sold in the United States
must comply with FCC safety guidelines that
limit RF exposure. FCC relies on FDA and
other health agencies for safety questions
about wireless phones.
FCC also regulates the base stations that the
wireless phone networks rely upon. While
these base stations operate at higher power
E840-2.fm Page 46 Monday, May 14, 2007 9:04 AM
69
than do the wireless phones themselves, the
RF exposures that people get from these
base stations are typically thousands of
times lower than those they can get from
wireless phones. Base stations are thus not
the primary subject of the safety questions
discussed in this document.
What are the results of the research
done already?
The research done thus far has produced
conflicting results, and many studies have
suffered from flaws in their research
methods. Animal experiments investigating
the effects of radio frequency energy (RF)
exposures characteristic of wireless phones
have yielded conflicting results that often
cannot be repeated in other laboratories. A
few animal studies, however, have
suggested that low levels of RF could
accelerate the development of cancer in
laboratory animals. However, many of the
studies that showed increased tumor
development used animals that had been
genetically engineered or treated with
cancer-causing chemicals so as to be pre-
disposed to develop cancer in absence of RF
exposure. Other studies exposed the
animals to RF for up to 22 hours per day.
These conditions are not similar to the
conditions under which people use wireless
phones, so we don't know with certainty
what the results of such studies mean for
human health.
Three large epidemiology studies have been
published since December 2000. Between
them, the studies investigated any possible
association between the use of wireless
phones and primary brain cancer, glioma,
meningioma, or acoustic neuroma, tumors
E840-2.fm Page 47 Monday, May 14, 2007 9:04 AM
Health and safety information
70
of the brain or salivary gland, leukemia, or
other cancers. None of the studies
demonstrated the existence of any harmful
health effects from wireless phones RF
exposures. However, none of the studies can
answer questions about long-term
exposures, since the average period of
phone use in these studies was around three
years.
What research is needed to decide
whether RF exposure from wireless
phones poses a health risk?
A combination of laboratory studies and
epidemiological studies of people actually
using wireless phones would provide some
of the data that are needed. Lifetime animal
exposure studies could be completed in a
few years. However, very large numbers of
animals would be needed to provide reliable
proof of a cancer promoting effect if one
exists. Epidemiological studies can provide
data that is directly applicable to human
populations, but ten or more years' follow-
up may be needed to provide answers about
some health effects, such as cancer. This is
because the interval between the time of
exposure to a cancer-causing agent and the
time tumors develop - if they do - may be
many, many years. The interpretation of
epidemiological studies is hampered by
difficulties in measuring actual RF exposure
during day-to-day use of wireless phones.
Many factors affect this measurement, such
as the angle at which the phone is held, or
which model of phone is used.
What is FDA doing to find out more
about the possible health effects of
wireless phone RF?
E840-2.fm Page 48 Monday, May 14, 2007 9:04 AM
71
FDA is working with the U.S. National
Toxicology Program and with groups of
investigators around the world to ensure
that high priority animal studies are
conducted to address important questions
about the effects of exposure to radio
frequency energy (RF).
FDA has been a leading participant in the
World Health Organization international
Electromagnetic Fields (EMF) Project since
its inception in 1996. An influential result of
this work has been the development of a
detailed agenda of research needs that has
driven the establishment of new research
programs around the world. The Project has
also helped develop a series of public
information documents on EMF issues.
FDA and Cellular Telecommunications &
Internet Association (CTIA) have a formal
Cooperative Research and Development
Agreement (CRADA) to do research on
wireless phone safety. FDA provides the
scientific oversight, obtaining input from
experts in government, industry, and
academic organizations. CTIA-funded
research is conducted through contracts to
independent investigators. The initial
research will include both laboratory studies
and studies of wireless phone users. The
CRADA will also include a broad assessment
of additional research needs in the context
of the latest research developments around
the world.
What steps can I take to reduce my
exposure to radio frequency energy
from my wireless phone?
If there is a risk from these products - and
at this point we do not know that there is - it
E840-2.fm Page 49 Monday, May 14, 2007 9:04 AM
Health and safety information
72
is probably very small. But if you are
concerned about avoiding even potential
risks, you can take a few simple steps to
minimize your exposure to radio frequency
energy (RF). Since time is a key factor in
how much exposure a person receives,
reducing the amount of time spent using a
wireless phone will reduce RF exposure.
• “If you must conduct extended
conversations by wireless phone every
day, you could place more distance
between your body and the source of the
RF, since the exposure level drops off
dramatically with distance. For example,
you could use a headset and carry the
wireless phone away from your body or
use a wireless phone connected to a
remote antenna.
Again, the scientific data do not demonstrate
that wireless phones are harmful. But if you
are concerned about the RF exposure from
these products, you can use measures like
those described above to reduce your RF
exposure from wireless phone use.
What about children using wireless
phones?
The scientific evidence does not show a
danger to users of wireless phones,
including children and teenagers. If you
want to take steps to lower exposure to
radio frequency energy (RF), the measures
described above would apply to children and
teenagers using wireless phones. Reducing
the time of wireless phone use and
increasing the distance between the user
and the RF source will reduce RF exposure.
Some groups sponsored by other national
governments have advised that children be
discouraged from using wireless phones at
all. For example, the government in the
E840-2.fm Page 50 Monday, May 14, 2007 9:04 AM
73
United Kingdom distributed leaflets
containing such a recommendation in
December 2000. They noted that no
evidence exists that using a wireless phone
causes brain tumors or other ill effects. Their
recommendation to limit wireless phone use
by children was strictly precautionary; it was
not based on scientific evidence that any
health hazard exists.
Do hands-free kits for wireless phones
reduce risks from exposure to RF
emissions?
Since there are no known risks from
exposure to RF emissions from wireless
phones, there is no reason to believe that
hands-free kits reduce risks. Hands-free kits
can be used with wireless phones for
convenience and comfort. These systems
reduce the absorption of RF energy in the
head because the phone, which is the source
of the RF emissions, will not be placed
against the head. On the other hand, if the
phone is mounted against the waist or other
part of the body during use, then that part
of the body will absorb more RF energy.
Wireless phones marketed in the U.S. are
required to meet safety requirements
regardless of whether they are used against
the head or against the body. Either
configuration should result in compliance
with the safety limit.
Do wireless phone accessories that
claim to shield the head from RF
radiation work?
Since there are no known risks from
exposure to RF emissions from wireless
phones, there is no reason to believe that
accessories that claim to shield the head
from those emissions reduce risks. Some
products that claim to shield the user from
E840-2.fm Page 51 Monday, May 14, 2007 9:04 AM
Health and safety information
74
RF absorption use special phone cases, while
others involve nothing more than a metallic
accessory attached to the phone. Studies
have shown that these products generally do
not work as advertised. Unlike “hand-free”
kits, these so-called “shields” may interfere
with proper operation of the phone. The
phone may be forced to boost its power to
compensate, leading to an increase in RF
absorption. In February 2002, the Federal
trade Commission (FTC) charged two
companies that sold devices that claimed to
protect wireless phone users from radiation
with making false and unsubstantiated
claims. According to FTC, these defendants
lacked a reasonable basis to substantiate
their claim.
What about wireless phone
interference with medical equipment?
Radio frequency energy (RF) from wireless
phones can interact with some electronic
devices. For this reason, FDA helped develop
a detailed test method to measure
electromagnetic interference (EMI) of
implanted cardiac pacemakers and
defibrillators from wireless telephones. This
test method is now part of a standard
sponsored by the Association for the
Advancement of Medical instrumentation
(AAMI). The final draft, a joint effort by FDA,
medical device manufacturers, and many
other groups, was completed in late 2000.
This standard will allow manufacturers to
ensure that cardiac pacemakers and
defibrillators are safe from wireless phone
EMI. FDA has tested wireless phones and
helped develop a voluntary standard
sponsored by the Institute of Electrical and
Electronic Engineers (IEEE). This standard
specifies test methods and performance
E840-2.fm Page 52 Monday, May 14, 2007 9:04 AM
75
requirements for hearing aids and wireless
phones so that no interference occurs when
a person uses a compatible phone and a
compatible hearing aid at the same time.
This standard was approved by the IEEE in
2000.
FDA continues to monitor the use of wireless
phones for possible interactions with other
medical devices. Should harmful
interference be found to occur, FDA will
conduct testing to assess the interference
and work to resolve the problem.
Additional information on the safety of RF
exposures from various sources can be
obtained from the following organizations:
• FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
• Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
• Occupational Safety and Health
Administration's (OSHA):
http://www.osha.gov/SLTC/
radiofrequencyradiation/index.html
• National institute for Occupational Safety
and Health (NIOSH):
http://www.cdc.gov/niosh/emfpg.html
• World health Organization (WHO):
http://www.who.int/peh-emf/
• International Commission on Non-
Ionizing Radiation Protection:
http://www.icnirp.de
• National Radiation Protection Board
(UK):
http://www.nrpb.org.uk
• Updated 4/3/2002: US food and Drug
Administration
http://www.fda.gov/cellphones
E840-2.fm Page 53 Monday, May 14, 2007 9:04 AM
Health and safety information
76
Road Safety
Your wireless phone gives you the powerful
ability to communicate by voice, almost
anywhere, anytime. But an important
responsibility accompanies the benefits of
wireless phones, one that every user must
uphold.
When driving a car, driving is your first
responsibility. When using your wireless
phone behind the wheel of a car, practice
good common sense and remember the
following tips:
1. Get to know your wireless phone and its
features, such as speed dial and redial. If
available, these features help you to
place your call without taking your
attention off the road.
2. When available, use a hands-free device.
If possible, add an additional layer of
convenience and safety to your wireless
phone with one of the many hands free
accessories available today.
E840-2.fm Page 54 Monday, May 14, 2007 9:04 AM
77
3. Position your wireless phone within easy
reach. Be able to access your wireless
phone without removing your eyes from
the road. If you get an incoming call at
an inconvenient time, let your voice mail
answer it for you.
4. Let the person you are speaking with
know you are driving; if necessary,
suspend the call in heavy traffic or
hazardous weather conditions. Rain,
sleet, snow, ice and even heavy traffic
can be hazardous.
5. Do not take notes or look up phone
numbers while driving. Jotting down a
“to do” list or flipping through your
address book takes attention away from
your primary responsibility, driving
safely.
6. Dial sensibly and assess the traffic; if
possible, place calls when you are not
moving or before pulling into traffic. Try
to plan calls when your car will be
stationary. If you need to make a call
while moving, dial only a few numbers,
check the road and your mirrors, then
continue.
E840-2.fm Page 55 Monday, May 14, 2007 9:04 AM
Health and safety information
78
7. Do not engage in stressful or emotional
conversations that may be distracting.
Make people you are talking with aware
you are driving and suspend
conversations that have the potential to
divert your attention from the road.
8. Use your wireless phone to call for help.
Dial 9-1-1 or other local emergency
number in the case of fire, traffic
accident or medical emergencies.
Remember, it is a free call on your
wireless phone!
9. Use your wireless phone to help others in
emergencies. If you see an auto
accident, crime in progress or other
serious emergency where lives are in
danger, call 9-1-1 or other local
emergency number, as you would want
others to do for you.
10. Call roadside assistance or a special non-
emergency wireless assistance number
when necessary. If you see a broken-
down vehicle posing no serious hazard, a
broken traffic signal, a minor traffic
accident where no one appears injured,
or a vehicle you know to be stolen, call
roadside assistance or other special non-
emergency number.
“The wireless industry reminds you to
use your phone safely when driving.”
For more information, please call 1-888-
901-SAFE, or visit our web-site www.wow-
com.com
Provided by the Cellular Telecommunications
& Internet Association
Operating Environment
E840-2.fm Page 56 Monday, May 14, 2007 9:04 AM
79
Remember to follow any special regulations
in force in any area and always switch your
phone off whenever it is forbidden to use it,
or when it may cause interference or danger.
When connecting the phone or any
accessory to another device, read its user's
guide for detailed safety instructions. Do not
connect incompatible products.
As with other mobile radio transmitting
equipment, users are advised that for the
satisfactory operation of the equipment and
for the safety of personnel, it is
recommended that the equipment should
only be used in the normal operating
position (held to your ear with the antenna
pointing over your shoulder).
Using Your Phone Near Other
Electronic Devices
Most modern electronic equipment is
shielded from radio frequency (RF) signals.
However, certain electronic equipment may
not be shielded against the RF signals from
your wireless phone. Consult the
manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that
a minimum distance of 15 cm (6 inches) be
maintained between a wireless phone and a
pacemaker to avoid potential interference
with the pacemaker.
These recommendations are consistent with
the independent research and
recommendations of Wireless Technology
Research.
Persons with pacemakers:
E840-2.fm Page 57 Monday, May 14, 2007 9:04 AM
Health and safety information
80
• should always keep the phone more than
15 cm
(6 inches) from their pacemaker when
the phone is switched on.
• should not carry the phone in a breast
pocket.
• should use the ear opposite the
pacemaker to minimize potential
interference.
If you have any reason to suspect that
interference is taking place, switch your
phone off immediately.
Hearing Aids
Some digital wireless phones may interfere
with some hearing aids. In the event of such
interference, you may wish to consult your
hearing aid manufacturer to discuss
alternatives.
Other Medical Devices
If you use any other personal medical
devices, consult the manufacturer of your
device to determine if it is adequately
shielded from external RF energy. Your
physician may be able to assist you in
obtaining this information. Switch your
phone off in health care facilities when any
regulations posted in these areas instruct
you to do so. Hospitals or health care
facilities may be using equipment that could
be sensitive to external RF energy.
E840-2.fm Page 58 Monday, May 14, 2007 9:04 AM
81
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in
motor vehicles. Check with the
manufacturer or its representative regarding
your vehicle. You should also consult the
manufacturer of any equipment that has
been added to your vehicle.
Posted Facilities
Switch your phone off in any facility where
posted notices require you to do so.
Potentially Explosive Environments
Switch your phone off when in any area with
a potentially explosive atmosphere and obey
all signs and instructions. Sparks in such
areas could cause an explosion or fire
resulting in bodily injury or even death.
Users are advised to switch the phone off
while at a refueling point (service station).
Users are reminded of the need to observe
restrictions on the use of radio equipment in
fuel depots (fuel storage and distribution
areas), chemical plants or where blasting
operations are in progress.
Areas with a potentially explosive
atmosphere are often but not always clearly
marked. They include below deck on boats,
chemical transfer or storage facilities,
vehicles using liquefied petroleum gas (such
as propane or butane), areas where the air
contains chemicals or particles, such as
grain, dust or metal powders, and any other
E840-2.fm Page 59 Monday, May 14, 2007 9:04 AM
Health and safety information
82
area where you would normally be advised
to turn off your vehicle engine.
Emergency Calls
This phone, like any wireless phone,
operates using radio signals, wireless and
landline networks as well as user
programmed functions, which cannot
guarantee connection in all conditions.
Therefore, you should never rely solely on
any wireless phone for essential
communications (medical emergencies, for
example).
Remember, to make or receive any calls the
phone must be switched on and in a service
area with adequate signal strength.
Emergency calls may not be possible on all
wireless phone networks or when certain
network services and/or phone features are
in use. Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your
present location (for example, 911 or
other official emergency number).
Emergency numbers vary by location.
3. Press .
If certain features are in use (call barring,
for example), you may first need to
deactivate those features before you can
make an emergency call. Consult this
document and your local cellular service
provider.
When making an emergency call, remember
to give all the necessary information as
accurately as possible. Remember that your
E840-2.fm Page 60 Monday, May 14, 2007 9:04 AM
83
phone may be the only means of
communication at the scene of an accident;
do not cut off the call until given permission
to do so.
Restricting Children's access to your
Phone
Your phone is not a toy. Children should not
be allowed to play with it because they could
hurt themselves and others, damage the
phone or make calls that increase your
phone bill.
FCC Notice and Cautions
FCC Notice
• This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) this device
may not cause harmful interference, and
(2) this device must accept any
interference received, including
interference that may cause undesired
operation.
• This equipment has been tested and found
to comply with the limits for a Class B
digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation.This equipment generates, uses
and can radiate radio frequency energy
and,f not installed and used in accordance
with the instructions, may cause harmful
interference to radio communications
E840-2.fm Page 61 Monday, May 14, 2007 9:04 AM
Health and safety information
84
The phone may cause TV or radio
interference if used in close proximity to
receiving equipment. The FCC can require
you to stop using the phone if such
interference cannot be eliminated.
Vehicles using liquefied petroleum gas (such
as propane or butane) must comply with the
National Fire Protection Standard (NFPA-58).
For a copy of this standard, contact the
National Fire Protection Association, One
Battery march Park, Quincy, MA 02269,
Attn: Publication Sales Division.
Cautions
Changes or modifications made in the radio
phone, not expressly approved by Samsung,
will void the user’s authority to operate the
equipment.
Only use approved batteries, antennas and
chargers. The use of any unauthorized
accessories may be dangerous and void the
phone warranty if said accessories cause
damage or a defect to the phone.
Although your phone is quite sturdy, it is a
complex piece of equipment and can be
broken. Avoid dropping, hitting, bending or
sitting on it.
However, there is no guarantee that
interference will not occur in a particular
installation.If this equipment does cause
harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is
encouraged to try to correct theinterference
by one or more of the following measures:-
Reorient or relocate the receiving antenna. -
Increase the separation between the
equipment and receiver.-Connect the
equipment into an outlet on a circuit different
from that to which the receiver is connected. -
Consult the dealer or an experienced radio/TV
technician for help.
E840-2.fm Page 62 Monday, May 14, 2007 9:04 AM
85
Other Important Safety
Information
• Only qualified personnel should service
the phone or install the phone in a
vehicle. Faulty installation or service may
be dangerous and may invalidate any
warranty applicable to the device.
• Check regularly that all wireless phone
equipment in your vehicle is mounted
and operating properly.
• Do not store or carry flammable liquids,
gases or explosive materials in the same
compartment as the phone, its parts or
accessories.
• For vehicles equipped with an air bag,
remember that an air bag inflates with
great force. Do not place objects,
including both installed or portable
wireless equipment in the area over the
air bag or in the air bag deployment
area. If wireless equipment is improperly
installed and the air bag inflates, serious
injury could result.
• Switch your phone off before boarding an
aircraft. The use of wireless phone in
aircraft is illegal and may be dangerous
to the aircraft's operation.
• Failure to observe these instructions may
lead to the suspension or denial of
telephone services to the offender, or
legal action, or both.
E840-2.fm Page 63 Monday, May 14, 2007 9:04 AM
Health and safety information
86
Product Performance
Getting the Most Out of Your Signal
Reception
The quality of each call you make or receive
depends on the signal strength in your area.
Your phone informs you of the current signal
strength by displaying a number of bars next
to the signal strength icon. The more bars
displayed, the stronger the signal.
If you're inside a building, being near a
window may give you better reception.
Understanding the Power Save
Feature
If your phone is unable to find a signal after
15 minutes of searching, a Power Save
feature is automatically activated. If your
phone is active, it periodically rechecks
service availability or you can check it
yourself by pressing any key.
Anytime the Power Save feature is activated,
a message displays on the screen. When a
signal is found, your phone returns to
standby mode.
Maintaining Your Phone's Peak
Performance
For the best care of your phone, only
authorized personnel should service your
phone and accessories. Faulty service may
void the warranty.
There are several simple guidelines to
operating your phone properly and
maintaining safe, satisfactory service.
• Hold the phone with the antenna raised,
fully-extended and over your shoulder.
E840-2.fm Page 64 Monday, May 14, 2007 9:04 AM
87
• Try not to hold, bend or twist the phone's
antenna.
• Don't use the phone if the antenna is
damaged.
• Speak directly into the phone's receiver.
• Avoid exposing your phone and
accessories to rain or liquid spills. If your
phone does get wet, immediately turn
the power off and remove the battery. If
it is inoperable, call Customer Care for
service.
Availability of Various Features/
Ring Tones
Many services and features are network
dependent and may require additional
subscription and/or usage charges. Not all
features are available for purchase or use in
all areas. Downloadable Ring Tones may be
available at an additional cost. Other
conditions and restrictions may apply. See
your service provider for additional
information.
E840-2.fm Page 65 Monday, May 14, 2007 9:04 AM
Health and safety information
88
Battery Standby and Talk Time
Standby and talk times will vary depending
on phone usage patterns and conditions.
Battery power consumption depends on
factors such as network configuration, signal
strength, operating temperature, features
selected, frequency of calls, and voice, data,
and other application usage patterns.
Battery Precautions
• Never use any charger or battery that is
damaged in any way.
• Use the battery only for its intended
purpose.
• If you use the phone near the network's
base station, it uses less power; talk and
standby time are greatly affected by the
signal strength on the cellular network
and the parameters set by the network
operator.
• Battery charging time depends on the
remaining battery charge and the type of
battery and charger used. The battery
can be charged and discharged hundreds
of times, but it will gradually wear out.
When the operation time (talk time and
standby time) is noticeably shorter than
normal, it is time to buy a new battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries
and recharge your battery only with
Samsung-approved chargers. When a
charger is not in use, disconnect it from
the power source. Do not leave the
battery connected to a charger for more
E840-2.fm Page 66 Monday, May 14, 2007 9:04 AM
89
than a week, since overcharging may
shorten its life.
• Extreme temperatures will affect the
charging capacity of your battery: it may
require cooling or warming first.
• Do not leave the battery in hot or cold
places, such as in a car in summer or
winter conditions, as you will reduce the
capacity and lifetime of the battery.
Always try to keep the battery at room
temperature. A phone with a hot or cold
battery may temporarily not work, even
when the battery is fully charged. Li-ion
batteries are particularly affected by
temperatures below 0 °C (32 °F).
• Do not short-circuit the battery.
Accidental short- circuiting can occur
when a metallic object (coin, clip or pen)
causes a direct connection between the
+ and - terminals of the battery (metal
strips on the battery), for example when
you carry a spare battery in a pocket or
bag. Short-circuiting the terminals may
damage the battery or the object causing
the short-circuiting.
• Dispose of used batteries in accordance
with local regulations. In some areas, the
disposal of batteries in household or
business trash may be prohibited. For
safe disposal options for Li-Ion batteries,
contact your nearest Samsung
authorized service center. Always
recycle. Do not dispose of batteries in a
fire.
Care and Maintenance
Your phone is a product of superior design
and craftsmanship and should be treated
E840-2.fm Page 67 Monday, May 14, 2007 9:04 AM
Health and safety information
90
with care. The suggestions below will help
you fulfill any warranty obligations and allow
you to enjoy this product for many years.
• Keep the phone and all its parts and
accessories out of the reach of small
children.
• Keep the phone dry. Precipitation,
humidity and liquids contain minerals
that will corrode electronic circuits.
• Do not use the phone with a wet hand.
Doing so may cause an electric shock to
you or damage to the phone.
• Do not use or store the phone in dusty,
dirty areas, as its moving parts may be
damaged.
• Do not store the phone in hot areas.
High temperatures can shorten the life of
electronic devices, damage batteries,
and warp or melt certain plastics.
• Do not store the phone in cold areas.
When the phone warms up to its normal
operating temperature, moisture can
form inside the phone, which may
damage the phone's electronic circuit
boards.
• Do not drop, knock or shake the phone.
Rough handling can break internal circuit
boards.
• Do not use harsh chemicals, cleaning
solvents or strong detergents to clean
the phone. Wipe it with a soft cloth
slightly dampened in a mild soap-and-
water solution.
• Do not paint the phone. Paint can clog
the device's moving parts and prevent
proper operation.
• Do not put the phone in or on heating
devices, such as a microwave oven, a
E840-2.fm Page 68 Monday, May 14, 2007 9:04 AM
91
stove or a radiator. The phone may
explode when overheated.
• When the phone or battery gets wet, the
label indicating water damage inside the
phone changes color. In this case, phone
repairs are no longer guaranteed by the
manufacturer's warranty, even if the
warranty for your phone has not expired.
• If your phone has a flash or light, do not
use it too close to the eyes of people or
animals. This may cause damage to their
eyes.
• Use only the supplied or an approved
replacement antenna. Unauthorized
antennas or modified accessories may
damage the phone and violate
regulations governing radio devices.
• If the phone, battery, charger or any
accessory is not working properly, take it
to your nearest qualified service facility.
The personnel there will assist you, and
if necessary, arrange for service.
E840-2.fm Page 69 Monday, May 14, 2007 9:04 AM
Health and safety information
92
• When the phone or battery gets wet, the label
indicating water damage inside the phone
changes colour. In this case, phone repairs are
no longer guaranteed by the manufacturer's
warranty, even if the warranty for your phone
has not expired.
• If your phone has a flash or light, do not use it
too close to the eyes of people or animals. This
may cause damage to their eyes.
• Use only the supplied or an approved
replacement antenna. Unauthorised antennas or
modified accessories may damage the phone
and violate regulations governing radio devices.
• If the phone, battery, charger, or any accessory
is not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
E840-2.fm Page 70 Monday, May 14, 2007 9:04 AM
58
Correct disposal of this product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and
other European countries with separate
collection systems)
This marking on the product, accessories
or literature indicates that the product and
its electronic accessories (e.g. charger, headset, USB
cable) should not be disposed of with other household
waste at the end of their working life.
To prevent possible harm to the environment or human
health from uncontrolled waste disposal, please
separate these items from other types of waste and
recycle them responsibly to promote the sustainable
reuse of material resources.
Household users should contact either the retailer
where they purchased this product, or their local
government ofce, for details of where and how
they can take these items for environmentally safe
recycling.
Business users should contact their supplier and check
the terms and conditions of the purchase contract. This
product and its electronic accessories should not be
mixed with other commercial wastes for disposal.
This EEE is compliant with RoHS.
59
Correct disposal of batteries in this product
(Applicable in the European Union and
other European countries with separate
battery return systems)
This marking on the battery, manual or
packaging indicates that the batteries in this product
should not be disposed of with other household waste
at the end of their working life. Where marked, the
chemical symbols Hg, Cd or Pb indicate that the
battery contains mercury, cadmium or lead above the
reference levels in EC Directive 2006/66. If batteries
are not properly disposed of, these substances can
cause harm to human health or the environment.
To protect natural resources and to promote material
reuse, please separate batteries from other types of
waste and recycle them through your local, free battery
return system.
60
Disclaimer
Some content and services accessible through this
device belong to third parties and are protected by
copyright, patent, trademark and/or other intellectual
property laws. Such content and services are provided
solely for your personal noncommercial use. You
may not use any content or services in a manner
that has not been authorised by the content owner
or service provider. Without limiting the foregoing,
unless expressly authorised by the applicable content
owner or service provider, you may not modify, copy,
republish, upload, post, transmit, translate, sell, create
derivative works, exploit, or distribute in any manner
or medium any content or services displayed through
this device.
"THIRD PARTY CONTENT AND SERVICES
ARE PROVIDED "AS IS." SAMSUNG DOES
NOT WARRANT CONTENT OR SERVICES SO
PROVIDED, EITHER EXPRESSLY OR IMPLIEDLY,
FOR ANY PURPOSE. SAMSUNG EXPRESSLY
DISCLAIMS ANY IMPLIED WARRANTIES,
INCLUDING BUT NOT LIMITED TO, WARRANTIES
OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. SAMSUNG DOES
NOT GUARANTEE THE ACCURACY, VALIDITY,
TIMELINESS, LEGALITY, OR COMPLETENESS
OF ANY CONTENT OR SERVICE MADE
AVAILABLE THROUGH THIS DEVICE AND
UNDER NO CIRCUMSTANCES, INCLUDING
NEGLIGENCE, SHALL SAMSUNG BE LIABLE,
WHETHER IN CONTRACT OR TORT, FOR ANY
61
DIRECT, INDIRECT, INCIDENTAL, SPECIAL
OR CONSEQUENTIAL DAMAGES, ATTORNEY
FEES, EXPENSES, OR ANY OTHER DAMAGES
ARISING OUT OF, OR IN CONNECTION WITH, ANY
INFORMATION CONTAINED IN, OR AS A RESULT
OF THE USE OF ANY CONTENT OR SERVICE BY
YOU OR ANY THIRD PARTY, EVEN IF ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES."
Third party services may be terminated or interrupted
at any time, and Samsung makes no representation
or warranty that any content or service will remain
available for any period of time. Content and services
are transmitted by third parties by means of networks
and transmission facilities over which Samsung
has no control. Without limiting the generality of
this disclaimer, Samsung expressly disclaims
any responsibility or liability for any interruption or
suspension of any content or service made available
through this device.
Samsung is neither responsible nor liable for customer
service related to the content and services. Any
question or request for service relating to the content
or services should be made directly to the respective
content and service providers.
