Users Manual
GT-M7500C
Copyright information
•Bluetooth
®
is a registered trademark of
the Bluetooth SIG, Inc. worldwide.
Bluetooth QD ID: BXXXXXX
•Java
TM
is a trademark or registered
trademark of Sun Microsystems, Inc.
• Windows Media
Player
®
is a registered
trademark of Microsoft Corporation.
2
Important safety
precautions
Drive safely at all times
Do not use a hand-held phone while driving. Park your
vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using them in
an aircraft is both illegal and dangerous.
Switch off the phone near all medical equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is forbidden to
use it, or when it may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Failure to comply with the following
precautions may be dangerous or illegal.
3
Sensible use
Use only in the normal position (held to your ear). Avoid
unnecessary contact with the antenna when the phone
is switched on.
Emergency calls
Key in the emergency number for your present location,
then press .
Keep your phone away from small children
Keep the phone and all its parts, including accessories,
out of the reach of small children.
Accessories and batteries
Use only Samsung-approved batteries and accessories,
such as headsets and PC data cables. Use of any
unauthorised accessories could damage you or your
phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your phone.
For more detailed safety information, see "Health and
safety information" on page 53.
• The phone could explode if the battery is replaced
with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.
At very high volumes, prolonged listening
to a headset can damage your hearing.
4
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone.
In this guide, the following instruction icons appear:.
Indicates that you need to pay careful
attention to the subsequent information
regarding safety or phone features.
→
Indicates that you need to press the
Navigation keys to scroll to the specified
option and then select it.
[ ] Indicates a key on the phone. For example,
[]
< > Indicates a soft key, whose function is
displayed on the phone screen. For example,
<
Select
>
•3G
Your phone is capable of operating
in a 3G environment, allowing
much greater data transfer speed,
video streaming, and video
conferencing.
Special
features of your phone
•User created theme
Create your own theme using your
favourite background images and
colours.
•MobileBlog
Share your photos and videos on
photo sharing websites and blogs.
5
•RSS reader
Use RSS reader to get the latest
news from your favourite websites.
• Camera and camcorder
Use the camera module on your
phone to take a photo or record a
video.
• Synchronisation with Windows
Media Player
Transfer music files to your phone
directly from Windows Media
Player.
• Music player
Play music files on your phone. You
can use other phone functions
while listening to music.
• FM radio
Listen to your favourite radio
stations anytime, anywhere.
• Digital data printing
Print images, messages, and
personal data directly from your
phone.
• Bluetooth
Transfer media files and personal
data, and connect to other devices
using wireless Bluetooth
technology.
•Web browser
Access the wireless web to get up-
to-the-minute information and a
wide variety of media content.
6
Contents
Unpack 8
Make sure you have each item
Get started 9
First steps to operating your phone
Assemble and charge the phone.................................... 9
Power on or off ......................................................... 10
Phone layout ............................................................ 10
Keys and icons.......................................................... 11
Access menu functions............................................... 15
Use shortcut icons..................................................... 16
Enter text ................................................................ 17
Customise your phone ............................................... 19
Use an optional memory card ..................................... 22
Step outside the phone 24
Begin with call functions, camera, music player, web
browser, and other special features
Make or answer calls ................................................. 24
Use the camera ........................................................ 26
Upload photos and videos to the web........................... 27
Play music ............................................................... 29
Listen to the FM radio ................................................ 32
Browse the web ........................................................ 34
Use Phonebook ......................................................... 34
Send messages......................................................... 35
View messages ......................................................... 37
Use Bluetooth ........................................................... 38
Switch applications.................................................... 41
Menu functions 42
All menu options listed
Health and safety information 53
7
Overview of menu functions
To access Menu mode, Press <
Menu
> in Idle mode. (Depending
on your region, press [Centre] in Idle mode).
8 Camera
9 FM radio
* Applications
1 Image editor
2 Games and more
3 Voice recorder
4 Bluetooth
5 Synchronise
2
6 Timer
7 Stopwatch
8 RSS reader
9 SIM Services
4
0 Alarms
# Settings
1 Phone profiles
2 Display and light
3 Time and date
4 Phone settings
5 Application settings
6 Security
7 Network settings
8 PC connections
9 Setup wizard
10 Memory settings
11 Reset settings
1. Labelled differently
depending on your service
provider.
2. Available only if supported
by your region or service
provider.
3. Additional folders will be
available if you insert a
memory card.
4. Available only if supported
by your USIM or SIM card.
1 Call log
2 Phonebook
3 Music
1 Music player
2 Music recognition
4 Browser1
1 Go to homepage
2 Enter URL
3 Bookmarks
4 Saved pages
5 History
6 Settings
5 Messages
1 Create message
2 Inbox
3 Email inbox
4 Drafts
5 Outbox
6 Sentbox
7 My folders
8 Templates
9 Delete by folders
10 Settings
11 SOS messages
2
12 Memory status
6 My files3
Images
Videos
Sounds
Other files
Memory status
7 Organiser
1 Calendar
2 Memo
3 Task
4 World clock
5 Calculator
6 Convertor
8
Unpack
Make sure you have each item
• Phone
• Travel adapter
• Battery
• User’s Guide
You can obtain various accessories from your local
Samsung dealer.
The items supplied with your phone and the
accessories available at your Samsung dealer may
vary, depending on your region or service
provider.
9
Get started
First steps to operating your phone
Assemble and charge the phone
Removing the battery cover
To AC power outl et
10
Get started
Power on or off
Phone layout
Front view
* For micro USB stereo headset
Switch on
1. Press and hold [ ].
2. If necessary, enter the PIN and
press <
Confirm
>.
3. When the setup wizard opens,
customise your phone
according to your preferences.
Switch off
Press and hold [ ].
Front camera
lens
Confirm key (Centre)/
Navigation keys
(Up/Down/Left/Right)
Dial key
Power/
Menu exit key
Right soft key
Special function
keys
Earpiece
Mouthpiece
Display
Alphanumeric
keys
Left soft key
Multifunction
jack*
Light sensor
External
light
11
Rear view
* For 3.5 mm headset
Keys and icons
Keys
You can lock the keypad to prevent any unwanted
phone operations, from accidentally pressing any
of the keys. To lock or unlock the keypad, press
and hold [ ].
Perform the function indicated on the
bottom line of the display.
In Idle mode, scroll through shortcut
icons.
In Menu mode, scroll through menu
options.
Select the highlighted option or
confirm input.
Camera/
Application
switch key
Speaker
Rear camera
lens
Headset jack*
Music control
keys
Volume keys
External light
Internal antenna
12
Get started
Make or answer a call.
In Idle mode, retrieve the numbers
recently dialled, missed, or received.
Press and hold to switch the phone on
or off.
End a call.
In Menu mode, cancel input and
return the phone to Idle mode.
Enter numbers, letters, and some
special characters.
In Idle mode, press and hold [
1
] to
access your voicemail server. Press
and hold [
0
] to enter an international
call prefix.
Enter special characters or perform
special functions.
In Idle mode, press and hold [ ] to
activate or deactivate the Silent
profile. Press and hold [ ] to lock or
unlock the keypad. Press and hold
[ ] to enter a pause between
numbers.
Adjust the phone volume.
In Idle mode, press and hold to turn
on the external light in red, green,
and blue for a few seconds.
13
Icons
The following icons may appear on the top line of
the screen to indicate your phone’s status.
Depending on your region or service provider, the
icons shown on the display may vary.
During playback, skip to the next file.
Press and hold to scan forward in a
file.
Press and hold to launch the music
player. Begin, pause, or resume
playback.
During playback, return to the
previous file. Press and hold to scan
backward in a file.
In Idle mode, press and hold to turn
on the camera.
In Camera mode, take a photo or
record a video.
If you change a default function for
the key, you can open the application
switch window to access other
applications without exiting the
current application.
Signal strength
Connecting to GPRS (2.5G) network or
transferring data in GPRS (2.5G)
network
14
Get started
Connecting to EDGE network or
transferring data in EDGE network
Connecting to UMTS (3G) network or
transferring data in UMTS (3G) network
Connecting to HSDPA (3G+) network or
transferring data in HSDPA (3G+)
network
Voice call in progress
Video call in progress
SOS message feature activated
Profile setting:
•: Normal
•: Silent
• : Driving
• : Meeting
• : Outdoor
• : Offline
Browsing Internet
Connected to secured web page
Bluetooth active
Bluetooth headset or hands-free car kit
connected
Connected with PC via USB port
15
Access menu functions
New message:
• : Text message
• : Multimedia message
•: Email
•: Voicemail
• : Push message
• : Configuration message
Memory card inserted
Battery power level
Current time
Select an
option
1. Press a desired soft key.
2. Press the Navigation keys to
move to the next or previous
option.
3. Press <
Select
>, <
OK
>, or
[Centre] to confirm the
function displayed or option
highlighted.
4. Press <
Back
> to move up one
level.
Press [ ] to return to Idle
mode.
16
Get started
Use shortcut icons
In Idle mode, there are icons on the display, which
give you easy access to popular menus.
Use menu
numbers
Press the number key
corresponding to the option you
want.
Navigate
shortcut
icons
• To move among the shortcut
icons, press [Left] or [Right].
• To access a highlighted menu,
press [Centre].
Available
shortcut
icons
• : create a new message.
• : access the
Music player
menu.
• : select a profile.
• : open the calendar.
• : set a colour of the
external light.
Available shortcut icons may vary
depending on your region.
17
Enter text
Set your
favourite
shortcut
menus
1. In Idle mode, press <
Menu
>
and select
Settings
→
Phone
settings
→
Shortcuts
.
2. Scroll to a menu to be
changed.
3. Press <
Change
>.
4. Select the menu you want.
5. Press <
Save
>.
Change the
text input
mode
• Press and hold [ ] to switch
between T9 mode and ABC
mode. Depending on your
region, you may be able to
access an input mode for your
specific language.
• Press [ ] to change case or
switch to Number mode.
• Press and hold [ ] to switch
to Symbol mode.
ABC mode
To enter a word:
Press the appropriate key until
the character you want appears
on the display.
18
Get started
T9 mode
To enter a word:
1. Press [
2
] to [
9
]
to start
entering a word.
2. Enter the whole word before
editing or deleting characters.
3. When the word displays
correctly, press [ ] to insert a
space.
Otherwise, press [
0
] to
display alternate word
choices.
Number
mode
Press the keys corresponding to
the digits you want.
Symbol mode
Press the keys corresponding to
the symbols you want.
Other
operations
•Press [
1
] to enter punctuation
marks or special characters.
• Press [ ] to insert a space.
• Press the Navigation keys to
move the cursor.
•Press <
Clear
> to delete
characters one by one.
• Press and hold <
Clear
> to
clear the entire display.
19
Customise your phone
1. In Idle mode, press <
Menu
>
and select
Settings
→
Phone
settings
→
Language
→
Screen text
.
2. Select a language.
3. Press <
OK
>
→
<
Save
>.
To change the profile properties:
1. In Idle mode, press <
Menu
>
and select
Settings
→
Phone
profiles
.
2. Scroll to the sound profile you
are using.
3. Press <
Options
> and select
Edit
.
4. Select
Voice call ringtone
→
a category
→
a ringtone.
5. Select
Video call ringtone
→
a category
→
a ringtone.
6. Press <
Options
> and select
Save
.
To change the profile:
1. In Idle mode, press <
Menu
>
and select
Settings
→
Phone
profiles
.
2. Select the profile you want.
3. Press [Centre].
Display
language
Call ringer
melody
20
Get started
In Idle mode, press [ ] to
adjust the key tone volume.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Display and light
→
Display
→
Home screen
.
2. Scroll left or right to
.
3. Scroll down and select
Wallpaper
.
4. Select an image category.
5. Select an image.
6. Press <
OK
>.
7. Press <
Options
> and select
Save
.
To create a theme:
1. In Idle mode, press <
Menu
>
and select
Settings
→
Display and light
→
Display
→
My theme
.
2. Press <
Options
> and select
Create
→
Easy
or
Expert
.
3. Customise the theme as
desired by following the
screen.
4. When you have finished, enter
a name for the theme and
press <
Save
>.
5. Press <
Yes
> to apply the
theme.
Key tone
volume
Idle mode
wallpaper
Themes for
the display
21
To apply a theme:
1. In Idle mode, press <
Menu
>
and select
Settings
→
Display and light
→
Display
→
My theme
.
2. Select a theme.
3. Press <
Save
>.
To restore the default theme quickly, enter [ ],
[], [
8
], [
2
], [
7
], and [ ] in Idle mode and
press <
Yes
>. Your phone restarts automatically
and uses the default theme.
You can activate the Silent profile
to avoid disturbing other people.
In Idle mode, press and hold [ ].
1. In Idle mode, press <
Menu
>
and select
Settings
→
Security
→
Phone lock
.
2. Select
On
.
3. Press <
Save
>.
4. Enter a new 4- to 8-digit
password and press
<
Confirm
>.
5. Enter the new password again
and press <
Confirm
>.
Silent profile
Phone lock
22
Get started
Use an optional memory card
• Frequent erasing and writing
will shorten a card's lifespan.
• Do not remove a card from the
phone or turn off the phone
while data is being accessed or
transferred. This could result in
loss of data and/or damage to
the card or phone.
• Do not subject cards to strong
shocks.
• Do not touch card terminals
with your fingers or metal
objects. If dirty, wipe the card
with a soft cloth.
• Keep cards away from small
children or pets.
• Do not expose cards in a place
subject to electrostatic
discharge and/or electrical
noise.
Important
memory card
information
23
1. Remove the battery cover.
2. Insert the card into the card
slot, with the label side face up.
3. Attach the battery cover.
Remove the card from the slot.
Insert a
memory card
Remove the
memory card
24
Step outside the phone
Begin with call functions, camera, music player, web
browser, and other special features
Make or answer calls
To make a voice call:
1. In Idle mode, enter an area
code and phone number.
2. Press [ ].
Press [ ] to adjust the
volume.
3. Press [ ] to end the call.
To ma ke a v ideo c all:
1. In Idle mode, enter an area
code and phone number.
2. Press <
Options
> and select
Video call
.
3. Press [ ] to end the call.
1. When the phone rings, press
[].
If it is a video call, press
<
Show me
> to allow the
caller to see you via the
camera.
2. Press [ ] to end the call.
Make a call
Answer a call
25
During a voice call, press [Centre]
and then <
Yes
> to activate the
speaker.
Press [Centre] again to switch
back to the earpiece.
In noisy environments, you may have difficulty
hearing the calls while using the speakerphone
feature. For better audio performance, use the
normal phone mode.
1. During a call, call the second
participant.
The first call is put on hold.
2. Press <
Options
> and select
Conference call
.
3. Repeat step 1 and 2 to add
more participants.
4. During a multi-party call:
•Press <
Options
> and select
Private call
to have a
private conversation with
one participant.
•Press <
Options
> and select
End
→
Select participant
→
a participant
→
Drop
to
drop one participant.
5. Press [ ] to end the multi-
party call.
Use the
speakerphone
feature
Make a multi-
party call
26
Step outside the phone
Use the camera
1. In Idle mode, press and hold
[Camera].
2. Rotate the phone to the left for
landscape view.
3. Aim the lens at the subject and
make any desired
adjustments.
4. Press [Centre] or [Camera] to
take a photo. The photo is
saved automatically.
5. Press < > or [Camera] to
take another photo.
1. In Idle mode, press <
Menu
>
and select
My files
→
Images
→
My photos
.
2. Select the photo you want.
1. In Idle mode, press and hold
[Camera].
2. Press [
1
] repeatedly to switch
to Record mode.
3. Rotate the phone to the left for
landscape view.
4. Press [Centre] or [Camera] to
start recording.
Take a photo
View a photo
Record a
video
27
Upload photos and videos to the
web
5. Press < > or [Camera] to
stop recording. The video is
saved automatically.
6. Press < > or [Camera] to
record another video.
1. In Idle mode, press <
Menu
>
and select
My files
→
Videos
→
My video clips
.
2. Select the video you want.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Application settings →
MobileBlog → ShoZu
activation
.
2. Select
On
.
3. Follow the on-screen
instructions to activate the
account.
View a video
Activate
the ShoZu
account
28
Step outside the phone
1. In Idle mode, press <
Menu
>
and select
Settings
→
Application settings →
MobileBlog →
Destinations.
2. Press <
Options
> and select
Create new
.
3. Follow the on-screen
instructions to add a new
destination site.
1. Access an application, such as
My files
or
Camera
.
2. Select or capture a photo or
video.
3. Press <
Options
> or < > and
select
Upload to web
.
4. Select a destination.
5. Enter the title and description,
and select a tag.
6. Press <
Upload
>.
Set a
destination
site
Upload a file
29
Play music
Use these methods:
• Download from the wireless
web.
• Download from a PC using the
optional Samsung PC Studio.
See Samsung PC Studio User’s
Guide.
• Receive via Bluetooth.
• Copy to a memory card. See
the next section.
• Synchronise music files with
Windows Media Player. See
page 30.
• Your phone accepts microSD™ memory cards up
to 8 GB (depending on memory card manufacturer
and type).
• When inserting a memory card with a large
amount of files, your phone might work rather
slowly for a few minutes while database updates.
This may also affect some phone functions. This
problem is temporary and is not a phone defect.
1. Insert a memory card into the
phone.
2. In Idle mode, press <
Menu
>
and select
Settings
→
PC
connections
→
Mass
storage
.
3. Press <
Save
>.
Prepare
music files
Copy music
files to a
memory card
30
Step outside the phone
4. Press [ ] to return to Idle
mode.
5. Connect your phone and PC
with an optional PC data cable.
6. Select
Open folder to view
files
when a pop-up window
appears on your PC.
7. Copy files from the PC to the
memory card.
8. When you have finished,
disconnect the phone from the
PC.
You can copy music files to your
phone by synchronising with
Windows Media Player 11.
1. In Idle mode, press <
Menu
>
and select
Settings
→
PC
connections
→
Media player
.
2. Press <
Save
>.
3. Press [ ] to return to Idle
mode.
4. Connect your phone and PC
with an optional PC data cable.
5. Select
Sync digital media
files to this device
when a
pop-up window appears on
your PC.
Synchronise
with
Windows
Media Player
31
6. Enter the name of your phone
and click
Finish
.
7. Select and drag the music files
you want to the sync list.
8. Click
Start Sync
.
9. When synchronisation is
finished, disconnect the phone
from the PC.
1. In Idle mode, press <
Menu
>
and select
Music
→
Music
player
.
2. Select a music category
→
a
music file.
3. During playback, use the
following keys:
• Centre: pause or resume
playback.
• Left: return to the previous
file. Press and hold to scan
backward in a file.
• Right: skip to the next file.
Press and hold to scan
forward in a file.
•: adjust the volume.
4. Press [ ] twice to stop
playback.
Play music
files
32
Step outside the phone
Listen to the FM radio
1. From the music player screen,
press <
Options
> and select
Open playlist
→
Library
→
Playlists
→
Create playlist
.
2. Enter the title of the playlist
and press <
Save
>.
3. Select the added playlist.
4. Select
Add
.
5. Select the files you want and
press <
OK
>.
6. Scroll to a file and press
[Centre] to play music.
Use a micro USB stereo headset only to listen to
the radio.
1. Plug the connecter of a
headset into the multifunction
jack on the phone.
2. In Idle mode, press <
Menu
>
and select
FM radio
.
Create a
playlist
Listen to
the radio
33
3. When you turn on the FM radio
for the first time, press <
Yes
>
to start automatic tuning.
Available radio stations are
automatically saved.
4. Press [Left] or [Right] to find
available radio stations.
Alternatively, press [Up] or
[Down] to select a stored radio
station.
5. Press [Centre] to turn off the
radio.
By automatic tuning:
1. From the radio screen, press
<
Options
> and select
Self-
tuning
.
2. Press <
Yes
> to confirm.
Available radio stations are
automatically saved.
By manual setup:
1. From the radio screen, press
[Left] or [Right] to select the
radio station you want.
2. Press <
Options
> and select
Add to Favourites
.
Store radio
stations
34
Step outside the phone
Browse the web
Use Phonebook
In Idle mode, press <
Menu
> and
select
Browser
→
Go to
homepage
. The homepage of
your service provider opens.
• To scroll through browser
items, press [Up] or [Down].
• To select an item, press
[Centre].
• To return to the previous page,
press <
Back
>.
• To access browser options,
press <
Options
>.
The browser options may differ depending on your
service provider.
1. In Idle mode, enter a phone
number and press <
Options
>.
2. Select
Add to Phonebook
→
a memory location
→
New
.
3. For
Phone
, select a number
type.
4. Specify contact information.
5. Press [Centre], or press
<
Options
> and select
Save
to
save the contact.
Launch the
web browser
Navigate
the web
Add a
contact
35
Send messages
1. In Idle mode, press
<
Phonebook
>.
2. Enter the first few letters of
the name you want.
3. Select a contact.
4. Scroll to a number and press
[ ] to dial, or press
<
Options
> and select
Edit
to
edit contact information.
1. In Idle mode, press <
Menu
>
and select
Messages
→
Create message
→
Message
.
2. Enter the message text.
3. Press [Up] to move to the
recipient field.
4. Enter destination numbers.
5. Press <
Options
> and select
Send
to send the message.
Find a
contact
Send a text
message
36
Step outside the phone
1. In Idle mode, press <
Menu
>
and select
Messages
→
Create message
→
Message
.
2. Enter the message text.
3. Press <
Options
> and select
Add multimedia
, or
Advanced
→
Add
attachment
.
4. Add a media file, contact,
calendar item, task, memo, or
bookmark item.
5. Press <
Options
> and select
Advanced
→
Add subject
.
6. Enter the message subject.
7. Press [Up] to move to the
recipient field.
8. Enter destination numbers or
email addresses.
9. Press <
Options
> and select
Send
to send the message.
Send a
multimedia
message
37
View messages
1. In Idle mode, press <
Menu
>
and select
Messages
→
Create message
→
Email
.
2. Enter the email text.
3. Press <
Options
> and select
Attach multimedia
or
Attach
organiser
.
4. Add a media file, contact,
calendar item, task, memo, or
bookmark item.
5. Press [Up] to move to the
subject field.
6. Enter the email subject.
7. Press [Up] to move to the
recipient field.
8. Enter email addresses.
9. Press <
Options
> and select
Send
to send the email.
1. In Idle mode, press <
Menu
>
and select
Messages
→
Inbox
.
2. Select a text message.
Send an
email
View a text
message
38
Step outside the phone
Use Bluetooth
Your phone is equipped with Bluetooth technology,
enabling you to connect the phone wirelessly to
other Bluetooth devices and exchange data with
them, talk hands-free, or control the phone
remotely.
1. In Idle mode, press <
Menu
>
and select
Messages
→
Inbox
.
2. Select a multimedia message.
1. In Idle mode, press <
Menu
>
and select
Messages
→
Email
inbox
.
2. Press <
Options
> and select
Download
.
3. Select an email or a header.
4. If you selected a header, press
<
Options
> and select
Retrieve
to view the body of
the email.
View a
multimedia
message
View an email
39
1. In Idle mode, press <
Menu
>
and select
Applications
→
Bluetooth
.
2. Press <
Options
> and select
Settings
.
3. Scroll down to
Activation
and
scroll left or right to
On
.
4. Scroll down to
My phone’s
visibility
and scroll left or
right to
On
.
5. Press <
Save
>.
1. In Idle mode, press <
Menu
>
and select
Applications
→
Bluetooth
→
Search for new
device
.
2. Select a device.
3. Enter a Bluetooth PIN or the
other device’s Bluetooth PIN, if
it has one, and press <
OK
>.
When the owner of the other
device enters the same code,
pairing is complete.
Turn on
Bluetooth
Search for
and pair with
a Bluetooth
device
40
Step outside the phone
1. Access an application, such as
Phonebook
,
My files
,
Calendar
,
Memo
,
Task
, or
Browser
.
2. Select an item.
3. Press <
Options
> and select
Send namecard via
,
Send
via
, or
Send URL via
→
Bluetooth
.
4. Search for and select a device.
5. If necessary, enter the
Bluetooth PIN and press
<
OK
>.
1. If necessary, enter the
Bluetooth PIN and press
<
OK
>.
2. Press <
Yes
> to confirm that
you are willing to receive.
Send data
Receive data
41
Switch applications
You can switch to other applications from a menu,
without closing the menu screen you are using.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Phone
settings
→
Camera key
.
2. Select
Switch
.
3. Press <
Save
>.
1. While using a menu, press
[Application switch].
2. Select an application.
•
Call
: open the dialling screen.
•
Messages
: access the
Messages
menu.
•
Browser
: launch the web
browser.
•
Games and more
: open a list
of games.
1. Press [Application switch].
2. Scroll to
End all?
3. Press <
Yes
>.
Change the
camera key
function
Switch to an
application
Available
applications
Close all
running
applications
42
Menu functions
All menu options listed
This section provides brief explanations of menu
functions on your phone.
Call log
Check the most recent calls dialled, received, or
missed.
Phonebook
Search for contact information stored in Phonebook.
Music
Menu Description
Music player Access and listen to all music
files sorted by criteria. You can
also make your own music
playlists.
Music
recognition
Download information for your
music files from the online
database and browse
recognition results. You can
also get information on how to
buy the music files.
43
Browser
Menu Description
Go to homepage Connect your phone to the
network and load the
homepage of the wireless web
service provider.
Enter URL Enter a URL address and
access the associated web
page.
Bookmarks Save URL addresses in order to
quickly access web pages.
Saved pages Access the list of pages you
have saved while online.
History Access the list of pages you
have accessed recently.
Settings Clear the cache. Delete
cookies or set whether or not
they are stored. Change the
settings for the web browser
and access version and
copyright information about it.
Select a connection profile to
be used for accessing the
wireless web.
44
Menu functions
Messages
Menu Description
Create message Create and send text,
multimedia, or email
messages.
Inbox Access messages that you
have received.
Email inbox Access emails that you have
received.
Drafts Access messages that you
have saved to send at a later
time.
Outbox Access messages that the
phone is attempting to send or
has failed to send.
Sentbox Access messages that you
have sent.
My folders Create new folders and
organise your messages.
Templates Make and use templates of
frequently used messages or
passages.
Delete by
folders
Delete messages in each
message folder all at once.
Settings Set up various options for
using the messaging services.
45
My files
SOS messages Specify options for sending
and receiving an SOS
message. You can send an
SOS message by pressing
[ ] 4 times when the
exposed keys are locked.
This feature may not be
available depending on your
region or service provider.
Memory status Check information about the
memory currently in use.
Menu Description
Images, Videos,
Sounds, Other
files
Access media files and other
files stored in the phone’s
memory.
Memory status Check information about the
memory currently in use.
Additional folders will be available if you insert a memory
card.
Menu Description
46
Menu functions
Organiser
Camera
Use the camera embedded in your phone to take
photos and record videos.
FM radio
Listen to music or news via the FM radio on your
phone.
Menu Description
Calendar Keep track of your schedule.
Memo Make memos for things that
are important and manage
them.
Task Make a list of tasks you need
to complete.
World clock Set your local time zone and
find out the current time in
another part of the world.
Calculator Perform arithmetic functions.
Convertor Do conversions, such as length
and temperature.
47
Applications
Menu Description
Image editor Edit your images using various
editing tools.
Games and
more
Access the embedded Java
games and download Java
applications.
Voice recorder Record voice memos and any
other sounds.
Bluetooth Connect the phone wirelessly
to other Bluetooth devices.
Synchronise Synchronise personal data,
such as contacts, calendar
items, tasks, and memos with
the specified web server.
This feature may not be
available depending on your
region or service provider.
Timer Set a period of time for the
phone to count down.
Stopwatch Measure elapsed time.
RSS reader Save your favourite news
channels or blogs to libraries
and get the latest news and
updated information from
them whenever you want.
48
Menu functions
Alarms
Set a wake-up alarm to wake you up in the morning
or an alarm to alert you to an event at a specific
time.
Settings
SIM Services Use a variety of additional
services offered by your
service provider. Depending on
your USIM or SIM card, this
menu may be available but
labelled differently.
Menu Description
Phone profiles Change the sound settings of
the phone for different events
or situations.
Display and light
→
Display
→
Home screen
Change the background image
that is displayed in Idle mode
and select a clock type.
Display and light
→
Display
→
My
theme
Select or create a theme for
the phone display.
Menu Description
49
Display and light
→
Display
→
Main menu style
Select a display style for the
main menu screen.
Display and light
→
Display
→
Dialling display
Customise the settings for the
display while dialling.
Display and light
→
Display
→
Greeting
message
Enter the greeting that is
displayed briefly when the
phone is switched on.
Display and light
→
Light
→
LCD
brightness
Adjust the brightness of the
display for varying lighting
conditions.
Display and light
→
Light
→
Backlight time
Select the length of time the
backlight or display stays on
when the phone is not used.
Display and light
→
Light
→
Keypad light
Set how the phone controls the
use of the keypad light.
Display and light
→
External light
Select a colour and adjust the
brightness of the external
light.
Time and date Change the time and date
displayed on your phone.
Phone settings
→
Language
Select a language to be used
for the display text or T9 input
mode.
Menu Description
50
Menu functions
Phone settings
→
Shortcuts
Select shortcut menus to be
displayed in Idle mode.
Phone settings
→
Keypad auto-
lock
Set the phone to lock the
keypad automatically when the
display turns off.
Phone settings
→
Camera key
Set a default function for
[Camera/Application switch].
Application
settings
Customise the settings for
using applications available on
the phone.
Security
→
Phone lock
Activate your phone password
to protect your phone against
unauthorised use.
Security
→
SIM
lock
Set the phone to work only
with the current USIM or SIM
card by assigning a SIM lock
password.
Security
→
PIN
lock
Activate your PIN to protect
your USIM or SIM card against
unauthorised use.
Security
→
Privacy lock
Lock access to messages, files,
call logs, contacts, calendar,
memos, or tasks.
Security
→
Fixed
dialling mode
Set the phone to restrict calls
to a limited set of phone
numbers, if supported by your
USIM or SIM card.
Menu Description
51
Security
→
Change phone
password
Change the phone password.
Security
→
Change PIN
code
Change the PIN.
Security
→
Change PIN2
code
Change the PIN2.
Security
→
Mobile tracker
Set the phone to send the
preset tracking message to
your family or friends when
someone tries to use your
phone with another USIM or
SIM card. This feature may be
unavailable due to certain
features supported by your
service provider.
Network
settings
→
Network
selection
Select the network to be used
while roaming outside of your
home area, or let the network
be chosen automatically.
Network
settings
→
Network mode
Change to an appropriate band
when you travel abroad.
Menu Description
52
Menu functions
Network
settings
→
Preferred
networks
Add a new network to your
preferred network list, if your
USIM or SIM card supports it.
Network
settings
→
Connections
Create and customise the
profiles containing the settings
for connecting your phone to
the network.
PC connections Select a USB mode that will be
used when you connect your
phone to a PC via USB
interface.
Setup wizard Quickly customise basic
settings of your phone. Select
the option you want for each
setting by following the on-
screen instructions.
Memory settings Check information about the
memory currently in use. You
can also clear the memory.
Reset settings Reset the phone’s settings you
have changed.
Menu Description
53
Health and safety information
Exposure to Radio Frequency (RF)
Signals
Certification Information (SAR)
Your wireless phone is a radio transmitter and
receiver. It is designed and manufactured not to
exceed the exposure limits for radio frequency (RF)
energy set by the Federal Communications
Commission (FCC) of the U.S. government. These
FCC exposure limits are derived from the
recommendations of two expert organizations, the
National Counsel on Radiation Protection and
Measurement (NCRP) and the Institute of Electrical
and Electronics Engineers (IEEE). In both cases, the
recommendations were developed by scientific and
engineering experts drawn from industry,
government, and academia after extensive reviews
of the scientific literature related to the biological
effects of RF energy.The exposure limit set by the
FCC for wireless mobile phones employs a unit of
measurement known as the Specific Absorption
Rate (SAR). The SAR is a measure of the rate of
absorption of RF energy by the human body
expressed in units of watts per kilogram (W/kg).
The FCC requires wireless phones to comply with a
safety limit of 1.6 watts per kilogram (1.6 W/kg).
The FCC exposure limit incorporates a substantial
margin of safety to give additional protection to the
public and to account for any variations in
measurements.SAR tests are conducted using
standard operating positions accepted by the FCC
with the phone transmitting at its highest certified
power level in all tested frequency bands. Although
the SAR is determined at the highest certified power
level, the actual SAR level of the phone while
54
operating can be well below the maximum value.
This is because the phone is designed to operate at
multiple power levels so as to use only the power
required to reach the network. In general, the closer
you are to a wireless base station antenna, the
lower the power output. Before a new model phone
is available for sale to the public, it must be tested
and certified to the FCC that it does not exceed the
exposure limit established by the FCC. Tests for
each model phone are performed in positions and
locations (e.g. at the ear and worn on the body) as
required by the FCC.
The FCC has granted an Equipment Authorization for
this mobile phone with all reported SAR levels evaluated
as in compliance with the FCC RF exposure guidelines.
The maximum SAR values for this model phone as
reported to the FCC are:
GSM850
• Head:0.362W/kg
• Body-worn:0.656W/kg
GSM1900
• Head:0.674W/kg
• Body-worn:0.733W/kg
Body worn operation, this model phone has been
tested and meets the FCC RF exposure guidelines
whenused with a Samsung accessory designated for
this product or when used with an accessory that
contains no metal and that positions the handset a
minimum of 1.5 cm from the body.
Non-compliance with the above restrictions may
55
result in violation of FCC RF exposure guidelines.
SAR information on this and other model phones
can be viewed on-line at www.fcc.gov/oet/fccid.
This site uses the phone FCC ID number,
A3LGTM7500C. Sometimes it may be necessary to
remove the battery pack to find the number. Once
you have the FCC ID number for a particular phone,
follow the instructions on the website and it should
provide values for typical or maximum SAR for a
particular phone. Additional product specific SAR
information can also be obtained at www.fcc.gov/
cgb/sar.
UL Certified Travel Adapter
The Travel Adaptor for this phone has met
applicable UL safety requirements. Please adhere to
the following safety instructions per UL
guidelines.FAILURE TO FOLLOW THE
INSTRUCTIONS OUTLINED MAY LEAD TO SERIOUS
PERSONAL INJURY AND POSSIBLE PROPERTY
DAMAGEIMPORTANT SAFETY INSTRUCTIONS -
SAVE THESE INSTRUCTIONS.DANGER - TO REDUCE
THE RISK OF FIRE OR ELECTRIC SHOCK,
CAREFULLY FOLLOW THESE INSTRUCTIONS.FOR
CONNECTION TO A SUPPLY NOT IN NORTH
AMERICA, USE AN ATTACHMENT PLUG ADAPTOR OF
THE PROPER CONFIGURATION FOR THE POWER
OUTLET. THIS POWER UNIT IS INTENDED TO BE
CORRECTLY ORIENTATED IN A VERTICAL OR
HORIZONTAL OR FLOOR MOUNT POSITION.
56
Health and safety information
Consumer Information on Wireless
Phones
The U.S. Food and Drug Administration (FDA) has
published a series of Questions and Answers for
consumers relating to radio frequency (RF)
exposure from wireless phones. The FDA publication
includes the following information:
What kinds of phones are the subject of this
update?
The term wireless phone refers here to hand-held
wireless phones with built-in antennas, often called
“cell,” “mobile,” or “PCS” phones. These types of
wireless phones can expose the user to measurable
radio frequency energy (RF) because of the short
distance between the phone and the user's head.
These RF exposures are limited by Federal
Communications Commission safety guidelines that
were developed with the advice of FDA and other
federal health and safety agencies. When the phone
is located at greater distances from the user, the
exposure to RF is drastically lower because a
person's RF exposure decreases rapidly with
increasing distance from the source. The so-called
“cordless phones,” which have a base unit
connected to the telephone wiring in a house,
typically operate at far lower power levels, and thus
produce RF exposures well within the FCC's
compliance limits.
57
Do wireless phones pose a health hazard?
The available scientific evidence does not show that
any health problems are associated with using
wireless phones. There is no proof, however, that
wireless phones are absolutely safe. Wireless
phones emit low levels of radio frequency energy
(RF) in the microwave range while being used. They
also emit very low levels of RF when in the stand-by
mode. Whereas high levels of RF can produce health
effects (by heating tissue), exposure to low level RF
that does not produce heating effects causes no
known adverse health effects. Many studies of low
level RF exposures have not found any biological
effects. Some studies have suggested that some
biological effects may occur, but such findings have
not been confirmed by additional research. In some
cases, other researchers have had difficulty in
reproducing those studies, or in determining the
reasons for inconsistent results.
58
Health and safety information
What is FDA's role concerning the safety of
wireless phones?
Under the law, FDA does not review the safety of
radiation-emitting consumer products such as
wireless phones before they can be sold, as it does
with new drugs or medical devices. However, the
agency has authority to take action if wireless
phones are shown to emit radio frequency energy
(RF) at a level that is hazardous to the user. In such
a case, FDA could require the manufacturers of
wireless phones to notify users of the health hazard
and to repair, replace or recall the phones so that
the hazard no longer exists.
Although the existing scientific data do not justify
FDA regulatory actions, FDA has urged the wireless
phone industry to take a number of steps, including
the following:
• “Support needed research into possible
biological effects of RF of the type emitted by
wireless phones;
• “Design wireless phones in a way that minimizes
any RF exposure to the user that is not
necessary for device function; and
• “Cooperate in providing users of wireless phones
with the best possible information on possible
effects of wireless phone use on human health.
FDA belongs to an interagency working group of the
federal agencies that have responsibility for
different aspects of RF safety to ensure coordinated
efforts at the federal level. The following agencies
belong to this working group:
• “National Institute for Occupational Safety and
Health
• “Environmental Protection Agency
• “Federal Communications Commission
59
• “Occupational Safety and Health Administration
• “National Telecommunications and Information
Administration
The National Institutes of Health participates in
some interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless
phones with the Federal Communications
Commission (FCC). All phones that are sold in the
United States must comply with FCC safety
guidelines that limit RF exposure. FCC relies on FDA
and other health agencies for safety questions
about wireless phones.
FCC also regulates the base stations that the
wireless phone networks rely upon. While these
base stations operate at higher power than do the
wireless phones themselves, the RF exposures that
people get from these base stations are typically
thousands of times lower than those they can get
from wireless phones. Base stations are thus not the
primary subject of the safety questions discussed in
this document.
60
Health and safety information
What are the results of the research done
already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws
in their research methods. Animal experiments
investigating the effects of radio frequency energy
(RF) exposures characteristic of wireless phones
have yielded conflicting results that often cannot be
repeated in other laboratories. A few animal studies,
however, have suggested that low levels of RF could
accelerate the development of cancer in laboratory
animals. However, many of the studies that showed
increased tumor development used animals that
had been genetically engineered or treated with
cancer-causing chemicals so as to be pre-disposed
to develop cancer in absence of RF exposure. Other
studies exposed the animals to RF for up to 22
hours per day. These conditions are not similar to
the conditions under which people use wireless
phones, so we don't know with certainty what the
results of such studies mean for human health.
Three large epidemiology studies have been
published since December 2000. Between them, the
studies investigated any possible association
between the use of wireless phones and primary
brain cancer, glioma, meningioma, or acoustic
neuroma, tumors of the brain or salivary gland,
leukemia, or other cancers. None of the studies
demonstrated the existence of any harmful health
effects from wireless phones RF exposures.
However, none of the studies can answer questions
about long-term exposures, since the average
period of phone use in these studies was around
three years.
61
What research is needed to decide whether
RF exposure from wireless phones poses a
health risk?
A combination of laboratory studies and
epidemiological studies of people actually using
wireless phones would provide some of the data
that are needed. Lifetime animal exposure studies
could be completed in a few years. However, very
large numbers of animals would be needed to
provide reliable proof of a cancer promoting effect if
one exists. Epidemiological studies can provide data
that is directly applicable to human populations, but
ten or more years' follow-up may be needed to
provide answers about some health effects, such as
cancer. This is because the interval between the
time of exposure to a cancer-causing agent and the
time tumors develop - if they do - may be many,
many years. The interpretation of epidemiological
studies is hampered by difficulties in measuring
actual RF exposure during day-to-day use of
wireless phones. Many factors affect this
measurement, such as the angle at which the phone
is held, or which model of phone is used.
What is FDA doing to find out more about the
possible health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology
Program and with groups of investigators around
the world to ensure that high priority animal studies
are conducted to address important questions about
the effects of exposure to radio frequency energy
(RF). FDA has been a leading participant in the
World Health Organization international
Electromagnetic Fields (EMF) Project since its
inception in 1996. An influential result of this work
has been the development of a detailed agenda of
research needs that has driven the establishment of
62
Health and safety information
new research programs around the world. The
Project has also helped develop a series of public
information documents on EMF issues.
FDA and Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative
Research and Development Agreement (CRADA) to
do research on wireless phone safety. FDA provides
the scientific oversight, obtaining input from experts
in government, industry, and academic
organizations. CTIA-funded research is conducted
through contracts to independent investigators. The
initial research will include both laboratory studies
and studies of wireless phone users. The CRADA will
also include a broad assessment of additional
research needs in the context of the latest research
developments around the world.
What steps can I take to reduce my exposure
to radio frequency energy from my wireless
phone?
If there is a risk from these products - and at this
point we do not know that there is - it is probably
very small. But if you are concerned about avoiding
even potential risks, you can take a few simple
steps to minimize your exposure to radio frequency
energy (RF). Since time is a key factor in how much
exposure a person receives, reducing the amount of
time spent using a wireless phone will reduce RF
exposure.
• “If you must conduct extended conversations by
wireless phone every day, you could place more
distance between your body and the source of
the RF, since the exposure level drops off
dramatically with distance. For example, you
could use a headset and carry the wireless
63
phone away from your body or use a wireless
phone connected to a remote antenna.
Again, the scientific data do not demonstrate that
wireless phones are harmful. But if you are
concerned about the RF exposure from these
products, you can use measures like those
described above to reduce your RF exposure from
wireless phone use.
What about children using wireless phones?
The scientific evidence does not show a danger to
users of wireless phones, including children and
teenagers. If you want to take steps to lower
exposure to radio frequency energy (RF), the
measures described above would apply to children
and teenagers using wireless phones. Reducing the
time of wireless phone use and increasing the
distance between the user and the RF source will
reduce RF exposure.
Some groups sponsored by other national
governments have advised that children be
discouraged from using wireless phones at all. For
example, the government in the United Kingdom
distributed leaflets containing such a
recommendation in December 2000. They noted
that no evidence exists that using a wireless phone
causes brain tumors or other ill effects. Their
recommendation to limit wireless phone use by
children was strictly precautionary; it was not based
on scientific evidence that any health hazard exists.
Do hands-free kits for wireless phones
reduce risks from exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason
to believe that hands-free kits reduce risks. Hands-
free kits can be used with wireless phones for
64
Health and safety information
convenience and comfort. These systems reduce the
absorption of RF energy in the head because the
phone, which is the source of the RF emissions, will
not be placed against the head. On the other hand,
if the phone is mounted against the waist or other
part of the body during use, then that part of the
body will absorb more RF energy. Wireless phones
marketed in the U.S. are required to meet safety
requirements regardless of whether they are used
against the head or against the body. Either
configuration should result in compliance with the
safety limit.
Do wireless phone accessories that claim to
shield the head from RF radiation work?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason
to believe that accessories that claim to shield the
head from those emissions reduce risks. Some
products that claim to shield the user from RF
absorption use special phone cases, while others
involve nothing more than a metallic accessory
attached to the phone. Studies have shown that
these products generally do not work as advertised.
Unlike “hand-free” kits, these so-called “shields”
may interfere with proper operation of the phone.
The phone may be forced to boost its power to
compensate, leading to an increase in RF
absorption. In February 2002, the Federal trade
Commission (FTC) charged two companies that sold
devices that claimed to protect wireless phone users
from radiation with making false and
unsubstantiated claims. According to FTC, these
defendants lacked a reasonable basis to
substantiate their claim.
65
What about wireless phone interference with
medical equipment?
Radio frequency energy (RF) from wireless phones
can interact with some electronic devices. For this
reason, FDA helped develop a detailed test method
to measure electromagnetic interference (EMI) of
implanted cardiac pacemakers and defibrillators
from wireless telephones. This test method is now
part of a standard sponsored by the Association for
the Advancement of Medical instrumentation
(AAMI). The final draft, a joint effort by FDA,
medical device manufacturers, and many other
groups, was completed in late 2000. This standard
will allow manufacturers to ensure that cardiac
pacemakers and defibrillators are safe from wireless
phone EMI. FDA has tested wireless phones and
helped develop a voluntary standard sponsored by
the Institute of Electrical and Electronic Engineers
(IEEE). This standard specifies test methods and
performance requirements for hearing aids and
wireless phones so that no interference occurs when
a person uses a compatible phone and a compatible
hearing aid at the same time. This standard was
approved by the IEEE in 2000.
FDA continues to monitor the use of wireless phones
for possible interactions with other medical devices.
Should harmful interference be found to occur, FDA
will conduct testing to assess the interference and
work to resolve the problem.
Additional information on the safety of RF exposures
from various sources can be obtained from the
following organizations:
• FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
• Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
66
Health and safety information
• Occupational Safety and Health Administration's
(OSHA):
http://www.osha.gov/SLTC/
radiofrequencyradiation/index.html
• National institute for Occupational Safety and
Health (NIOSH):
http://www.cdc.gov/niosh/emfpg.html
• World health Organization (WHO):
http://www.who.int/peh-emf/
• International Commission on Non-Ionizing
Radiation Protection:
http://www.icnirp.de
• National Radiation Protection Board (UK):
http://www.nrpb.org.uk
• Updated 4/3/2002: US food and Drug
Administration
http://www.fda.gov/cellphones
Road Safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime.
But an important responsibility accompanies the
benefits of wireless phones, one that every user
must uphold.
When driving a car, driving is your first
responsibility. When using your wireless phone
behind the wheel of a car, practice good common
sense and remember the following tips:
1. Get to know your wireless phone and its
features, such as speed dial and redial. If
available, these features help you to place your
call without taking your attention off the road.
2. When available, use a hands-free device. If
possible, add an additional layer of convenience
67
and safety to your wireless phone with one of
the many hands free accessories available today.
3. Position your wireless phone within easy reach.
Be able to access your wireless phone without
removing your eyes from the road. If you get an
incoming call at an inconvenient time, let your
voice mail answer it for you.
4. Let the person you are speaking with know you
are driving; if necessary, suspend the call in
heavy traffic or hazardous weather conditions.
Rain, sleet, snow, ice and even heavy traffic can
be hazardous.
5. Do not take notes or look up phone numbers
while driving. Jotting down a “to do” list or
flipping through your address book takes
attention away from your primary responsibility,
driving safely.
6. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan calls when your
car will be stationary. If you need to make a call
while moving, dial only a few numbers, check
the road and your mirrors, then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting. Make
people you are talking with aware you are
driving and suspend conversations that have the
potential to divert your attention from the road.
8. Use your wireless phone to call for help. Dial 9-
1-1 or other local emergency number in the case
of fire, traffic accident or medical emergencies.
Remember, it is a free call on your wireless
phone!
9. Use your wireless phone to help others in
emergencies. If you see an auto accident, crime
in progress or other serious emergency where
68
Health and safety information
lives are in danger, call 9-1-1 or other local
emergency number, as you would want others to
do for you.
10. Call roadside assistance or a special non-
emergency wireless assistance number when
necessary. If you see a broken-down vehicle
posing no serious hazard, a broken traffic signal,
a minor traffic accident where no one appears
injured, or a vehicle you know to be stolen, call
roadside assistance or other special non-
emergency number.
“The wireless industry reminds you to use
your phone safely when driving.”
For more information, please call 1-888-901-SAFE,
or visit our web-site www.wow-com.com Provided
by the Cellular Telecommunications & Internet
Association.
Operating Environment
Remember to follow any special regulations in force
in any area and always switch your phone off
whenever it is forbidden to use it, or when it may
cause interference or danger. When connecting the
phone or any accessory to another device, read its
user's guide for detailed safety instructions. Do not
connect incompatible products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation
of the equipment and for the safety of personnel, it
is recommended that the equipment should only be
used in the normal operating position (held to your
ear with the antenna pointing over your shoulder).
69
Using Your Phone Near Other Electronic
Devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against
the RF signals from your wireless phone. Consult
the manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be
maintained between a wireless phone and a
pacemaker to avoid potential interference with the
pacemaker.
These recommendations are consistent with the
independent research and recommendations of
Wireless Technology Research.
Persons with pacemakers:
• should always keep the phone more than 15 cm
(6 inches) from their pacemaker when the
phone is switched on.
• should not carry the phone in a breast pocket.
• should use the ear opposite the pacemaker to
minimize potential interference.
If you have any reason to suspect that interference
is taking place, switch your phone off immediately.
Hearing Aid Compatibility with Mobile
Phones
When some mobile phones are used near some
hearing devices (hearing aids and cochlear
implants), users may detect a buzzing, humming, or
whining noise. Some hearing devices are more
immune than others to this interference noise, and
phones also vary in the amount of interference they
generate.
70
Health and safety information
The wireless telephone industry has developed
ratings for some of their mobile phones, to assist
hearing device users in finding phones that may be
compatible with their hearing devices. Not all
phones have been rated. Phones that are rated have
the rating on their box or a label on the box.
The ratings are not guarantees. Results will vary
depending on the user’s hearing device and hearing
loss. If your hearing device happens to be
vulnerable to interference, you may not be able to
use a rated phone successfully. Trying out the phone
with your hearing device is the best way to evaluate
it for your personal needs.
M-Ratings
: Phones rated M3 or M4 meet FCC
requirements and are likely to generate less
interference to hearing devices than phones that are
not labeled. M4 is the better/higher of the two
ratings.
T-Ratings
: Phones rated T3 or T4 meet FCC
requirements and are likely to be more usable with
a hearing device°Øs telecoil (°×T Switch°± or
°×Telephone Switch°±) than unrated phones. T4 is
the better/higher of the two ratings. (Note that not
all hearing devices have telecoils in them.)Hearing
devices may also be measured for immunity to this
type of interference. Your hearing device
manufacturer or hearing health professional may
help you find results for your hearing device. The
more immune your hearing aid is, the less likely you
are to experience interference noise from mobile
phones.
Other Medical Devices
If you use any other personal medical devices,
consult the manufacturer of your device to
determine if it is adequately shielded from external
RF energy. Your physician may be able to assist you
71
in obtaining this information. Switch your phone off
in health care facilities when any regulations posted
in these areas instruct you to do so. Hospitals or
health care facilities may be using equipment that
could be sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle. You should
also consult the manufacturer of any equipment
that has been added to your vehicle.
Posted Facilities
Switch your phone off in any facility where posted
notices require you to do so.
Potentially Explosive Environments
Switch your phone off when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause
an explosion or fire resulting in bodily injury or even
death.
Users are advised to switch the phone off while at a
refueling point (service station). Users are reminded
of the need to observe restrictions on the use of
radio equipment in fuel depots (fuel storage and
distribution areas), chemical plants or where
blasting operations are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas
(such as propane or butane), areas where the air
contains chemicals or particles, such as grain, dust
or metal powders, and any other area where you
72
Health and safety information
would normally be advised to turn off your vehicle
engine.
Emergency Calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well
as user programmed functions, which cannot
guarantee connection in all conditions. Therefore,
you should never rely solely on any wireless phone
for essential communications (medical emergencies,
for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not
be possible on all wireless phone networks or when
certain network services and/or phone features are
in use. Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location (for example, 911 or other official
emergency number). Emergency numbers vary
by location.
3. Press .
If certain features are in use (call barring, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult this document and your local cellular service
provider.
When making an emergency call, remember to give
all the necessary information as accurately as
possible. Remember that your phone may be the
only means of communication at the scene of an
accident; do not cut off the call until given
permission to do so.
73
Restricting Children's access to your Phone
Your phone is not a toy. Children should not be
allowed to play with it because they could hurt
themselves and others, damage the phone or make
calls that increase your phone bill.
FCC Notice and Cautions
FCC Notice
• This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
• This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation.This equipment generates, uses and
can radiate radio frequency energy and,if not
installed and used in accordance with the instruc-
tions, may cause harmful interference to radio
communications.
74
Health and safety information
The phone may cause TV or radio interference if used in
close proximity to receiving equipment. The FCC can
require you to stop using the phone if such interference
cannot be eliminated.
Vehicles using liquefied petroleum gas (such as propane
or butane) must comply with the National Fire Protection
Standard (NFPA-58). For a copy of this standard, contact
the National Fire Protection Association, One Battery
march Park, Quincy, MA 02269, Attn: Publication Sales
Division.
Cautions
Changes or modifications made in the radio phone, not
expressly approved by Samsung, will void the user’s author-
ity to operate the equipment.
Only use approved batteries, antennas andchargers. The
use of any unauthorized accessories may be dangerous and
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be deter-
mined by turning the equipment off and on, the
user is encouraged to try to correct the interfer-
ence by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment
and receiver.
-Connect the equipment into an outlet on a cir-
cuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV
technician for help
75
void the phone warranty if said accessories cause damage
or a defect to the phone. Although your phone is quite
sturdy, it is a complex piece of equipment and can be bro-
ken. Avoid dropping, hitting, bending or sitting on it.
Other Important Safety Information
• Only qualified personnel should service the
phone or install the phone in a vehicle. Faulty
installation or service may be dangerous and
may invalidate any warranty applicable to the
device.
• Check regularly that all wireless phone
equipment in your vehicle is mounted and
operating properly.
• Do not store or carry flammable liquids, gases or
explosive materials in the same compartment as
the phone, its parts or accessories.
• For vehicles equipped with an air bag, remember
that an air bag inflates with great force. Do not
place objects, including both installed or
portable wireless equipment in the area over the
air bag or in the air bag deployment area. If
wireless equipment is improperly installed and
the air bag inflates, serious injury could result.
• Switch your phone off before boarding an
aircraft. The use of wireless phone in aircraft is
illegal and may be dangerous to the aircraft's
operation.
• Failure to observe these instructions may lead to
the suspension or denial of telephone services to
the offender, or legal action, or both.
76
Health and safety information
Product Performance
Getting the Most Out of Your Signal
Reception
The quality of each call you make or receive
depends on the signal strength in your area. Your
phone informs you of the current signal strength by
displaying a number of bars next to the signal
strength icon. The more bars displayed, the
stronger the signal.
If you're inside a building, being near a window may
give you better reception.
Understanding the Power Save Feature
If your phone is unable to find a signal after 15
minutes of searching, a Power Save feature is
automatically activated. If your phone is active, it
periodically rechecks service availability or you can
check it yourself by pressing any key.
Anytime the Power Save feature is activated, a
message displays on the screen. When a signal is
found, your phone returns to standby mode.
Maintaining Your Phone's Peak Performance
For the best care of your phone, only authorized
personnel should service your phone and
accessories. Faulty service may void the warranty.
There are several simple guidelines to operating
your phone properly and maintaining safe,
satisfactory service.
• Hold the phone with the antenna raised, fully-
extended and over your shoulder.
• Try not to hold, bend or twist the phone's
antenna.
• Don't use the phone if the antenna is damaged.
• Speak directly into the phone's receiver.
77
• Avoid exposing your phone and accessories to
rain or liquid spills. If your phone does get wet,
immediately turn the power off and remove the
battery. If it is inoperable, call Customer Care for
service.
Availability of Various Features/Ring
Tones
Many services and features are network dependent
and may require additional subscription and/or
usage charges. Not all features are available for
purchase or use in all areas. Downloadable Ring
Tones may be available at an additional cost. Other
conditions and restrictions may apply. See your
service provider for additional information.
Battery Standby and Talk Time
Standby and talk times will vary depending on
phone usage patterns and conditions. Battery power
consumption depends on factors such as network
configuration, signal strength, operating
temperature, features selected, frequency of calls,
and voice, data, and other application usage
patterns.
Battery Precautions
• Never use any charger or battery that is
damaged in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network's base
station, it uses less power; talk and standby
time are greatly affected by the signal strength
on the cellular network and the parameters set
by the network operator.
• Battery charging time depends on the remaining
battery charge and the type of battery and
78
Health and safety information
charger used. The battery can be charged and
discharged hundreds of times, but it will
gradually wear out. When the operation time
(talk time and standby time) is noticeably
shorter than normal, it is time to buy a new
battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not in
use, disconnect it from the power source. Do not
leave the battery connected to a charger for
more than a week, since overcharging may
shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling
or warming first.
• Do not leave the battery in hot or cold places,
such as in a car in summer or winter conditions,
as you will reduce the capacity and lifetime of
the battery. Always try to keep the battery at
room temperature. A phone with a hot or cold
battery may temporarily not work, even when
the battery is fully charged. Li-ion batteries are
particularly affected by temperatures below 0 °C
(32 °F).
• Do not short-circuit the battery. Accidental
short- circuiting can occur when a metallic
object (coin, clip or pen) causes a direct
connection between the + and - terminals of the
battery (metal strips on the battery), for
example when you carry a spare battery in a
pocket or bag. Short-circuiting the terminals
may damage the battery or the object causing
the short-circuiting.
79
• Dispose of used batteries in accordance with
local regulations. In some areas, the disposal of
batteries in household or business trash may be
prohibited. For safe disposal options for Li-Ion
batteries, contact your nearest Samsung
authorized service center. Always recycle. Do not
dispose of batteries in a fire.
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for
many years.
• Keep the phone and all its parts and accessories
out of the reach of small children.
• Keep the phone dry. Precipitation, humidity and
liquids contain minerals that will corrode
electronic circuits.
• Do not use the phone with a wet hand. Doing so
may cause an electric shock to you or damage to
the phone.
• Do not use or store the phone in dusty, dirty
areas, as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the
phone, which may damage the phone's
electronic circuit boards.
• Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
80
Health and safety information
• Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the phone. Wipe it
with a soft cloth slightly dampened in a mild
soap-and-water solution.
• Do not paint the phone. Paint can clog the
device's moving parts and prevent proper
operation.
• Do not put the phone in or on heating devices,
such as a microwave oven, a stove or a radiator.
The phone may explode when overheated.
• When the phone or battery gets wet, the label
indicating water damage inside the phone
changes color. In this case, phone repairs are no
longer guaranteed by the manufacturer's
warranty, even if the warranty for your phone
has not expired.
• If your phone has a flash or light, do not use it
too close to the eyes of people or animals. This
may cause damage to their eyes.
• Use only the supplied or an approved
replacement antenna. Unauthorized antennas or
modified accessories may damage the phone
and violate regulations governing radio devices.
• If the phone, battery, charger or any accessory
is not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
* Depending on the software installed or your service provider
or region, some of the descriptions in this guide may not
match your phone exactly.
* Depending on your region, your phone and accessories may
appear different from the illustrations in this guide.
www.armanisamsungmobile.com
