Users Manual
2
About this manual
This device provides high quality mobile communication and entertainment using Samsung’s
high standards and technological expertise. This user manual is specially designed to detail
the device’s functions and features.
•
Please read this manual before using the device to ensure safe and proper use.
•
Descriptions are based on the device’s default settings.
•
Images and screenshots may differ in appearance from the actual product.
•
Content may differ from the final product, or from software provided by service providers
or carriers, and is subject to change without prior notice. For the latest version of the
manual, refer to the Samsung website,
www.samsung.com
.
•
Content (high quality content) that requires high CPU and RAM usage will affect the
overall performance of the device. Applications related to the content may not work
properly depending on the device’s specifications and the environment that it is used in.
•
Available features and additional services may vary by device, software, or service
provider.
•
Applications and their functions may vary by country, region, or hardware specifications.
Samsung is not liable for performance issues caused by applications from any provider
other than Samsung.
•
Samsung is not liable for performance issues or incompatibilities caused by edited
registry settings or modified operating system software. Attempting to customise the
operating system may cause the device or applications to work improperly.
•
Software, sound sources, wallpapers, images, and other media provided with this device
are licensed for limited use. Extracting and using these materials for commercial or other
purposes is an infringement of copyright laws. Users are entirely responsible for illegal
use of media.
•
You may incur additional charges for data services, such as messaging, uploading and
downloading, auto-syncing, or using location services. To avoid additional charges, select
an appropriate data tariff plan. For details, contact your service provider.
About this manual
3
•
Default applications that come with the device are subject to updates and may no longer
be supported without prior notice. If you have questions about an application provided
with the device, contact a Samsung Service Centre. For user-installed applications,
contact service providers.
•
Modifying the device’s operating system or installing softwares from unofficial sources
may result in device malfunctions and data corruption or loss. These actions are violations
of your Samsung licence agreement and will void your warranty.
Instructional icons
Warning: situations that could cause injury to yourself or others
Caution: situations that could cause damage to your device or other equipment
Note: notes, usage tips, or additional information
Copyright
Copyright © 2013 Samsung Electronics
This guide is protected under international copyright laws.
No part of this guide may be reproduced, distributed, translated, or transmitted in any form or
by any means, electronic or mechanical, including photocopying, recording, or storing in any
information storage and retrieval system, without the prior written permission of Samsung
Electronics.
About this manual
4
Trademarks
•
SAMSUNG and the SAMSUNG logo are registered trademarks of Samsung Electronics.
•
The Android logo, Google™, Google Maps™, Google Mail™, YouTube™, Google Play™
Store, and Google Talk™ are trademarks of Google, Inc.
•
Bluetooth® is a registered trademark of Bluetooth SIG, Inc. worldwide.
•
Wi-Fi®, Wi-Fi Protected Setup™, Wi-Fi Direct™, Wi-Fi CERTIFIED™, and the Wi-Fi logo are
registered trademarks of the Wi-Fi Alliance.
•
All other trademarks and copyrights are the property of their respective owners.
DivX®, DivX Certified® and associated logos are trademarks
of Rovi Corporation or its subsidiaries and are used under
licence.
ABOUT DIVX VIDEO
DivX® is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation. This is
an official DivX Certified® device that has passed rigorous testing to verify that it plays DivX
video. Visit
www.divx.com
for more information and software tools to convert your files into
DivX videos.
ABOUT DIVX VIDEO-ON-DEMAND
This DivX Certified® device must be registered in order to play purchased DivX Video-on-
Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in
your device setup menu. Go to
vod.divx.com
for more information on how to complete your
registration.
DivX Certified® to play DivX® video up to HD 720p, including premium content.
5
Table of Contents
Getting started
7 Device layout
8 Buttons
9 Package contents
10 Installing the SIM or USIM card
11 Charging the battery
13 Inserting a memory card
15 Turning the device on and off
15 Holding the device
16 Locking and unlocking the device
16 Adjusting the volume
16 Switching to silent mode
Basics
17 Indicator icons
18 Using the touch screen
21 Rotating the screen
21 Notifications
22 Quick setting panel
22 Home screen
25 Using applications
26 Applications screen
27 Help
27 Entering text
29 Connecting to a Wi-Fi network
30 Setting up accounts
31 Transferring files
32 Securing the device
34 Upgrading the device
Communication
35 Phone
40 Contacts
44 Messaging
45 Email
47 Google Mail
48 Talk
49 Google+
49 ChatON
50 Messenger
Web & network
51 Internet
52 Chrome
53 Bluetooth
54 Smart Remote
Media
56 Music Player
57 Camera
Table of Contents
6
Travel & local
87 Maps
88 Local
89 Navigation
Settings
90 About Settings
90 Wi-Fi
91 Bluetooth
91 Data usage
92 More settings
93 Blocking mode
94 Sound
94 Display
95 Storage
96 Power saving mode
96 Battery
96 Application manager
96 Location services
97 Lock screen
97 Security
99 Language and input
101 Backup and reset
101 Add account
101 Voice control
102 Accessory
102 Date and time
103 Accessibility
104 Developer options
106 About device
Troubleshooting
64 Gallery
66 Paper Artist
67 Video Player
68 YouTube
70 Flipboard
Application & media stores
71 Play Store
72 Samsung Apps
72 Game Hub
73 Play Books
73 Play Movies
73 Play Music
74 Video Hub
74 Readers Hub
74 Learning Hub
Utilities
75 Memo
76 S Planner
78 Polaris Office
81 Dropbox
81 Alarm
82 World Clock
83 Calculator
83 S Voice
84 Google
85 Voice Search
85 My Files
86 Downloads
86 TripAdvisor
7
Getting started
Device layout
Back button
Home button
Speaker
Light sensor
Menu button
Multipurpose
jacke
Touch screen
Front camera
Power button Volume button
Microphone
SIM card slot
Rear camera
IrLED
Memory card
slot
Speaker
Headset jack
•
Do not cover the antenna area with your hands or other objects. This may cause
connectivity problems or drain the battery.
•
Do not use a screen protector. This causes sensor malfunctions.
•
Do not allow water to contact the touch screen. The touch screen may malfunction
in humid conditions or when exposed to water.
Getting started
8
Buttons
Button Function
Power
•
Press and hold to turn the device on or off.
•
Press and hold for more than 7 seconds to reset the device if
it has fatal errors or hang-ups, or freezes.
•
Press to lock or unlock the device. The device goes into lock
mode when the touch screen turns off.
Menu
•
Tap to open a list of options available for the current screen.
•
Tap and hold on the Home screen to launch Google search.
Home
•
Press to return to the Home screen.
•
Press and hold to open the list of recent applications.
•
Press twice to launch
S Voice
.
Back
•
Tap to return to the previous screen.
Volume
•
Press to adjust the device volume.
Getting started
9
Package contents
Check the product box for the following items:
•
Device
•
Quick start guide
Use only Samsung-approved software. Pirated or illegal software may cause damage
or malfunctions, which are not covered by the warranty.
•
The items supplied with the device and any available accessories may vary
depending on the region or service provider.
•
The supplied items are designed only for this device and may not be compatible
with other devices.
•
Appearances and specifications are subject to change without prior notice.
•
You can purchase additional accessories from your local Samsung retailer. Make
sure they are compatible with the device before purchase.
•
Other accessories may not be compatible with your device.
•
Use only Samsung-approved accessories. Malfunctions caused by using
unapproved accessories are not covered by the warranty service.
•
Availability of all accessories is subject to change depending entirely on
manufacturing companies. For more information about available accessories, refer
to the Samsung website.
Getting started
10
Installing the SIM or USIM card
Insert the SIM or USIM card provided by the mobile telephone service provider.
Only microSIM cards work with the device.
1 Open the cover of the SIM card slot.
2 Insert the SIM or USIM card with the gold-coloured contacts facing downwards.
Do not insert a memory card into the SIM card slot. If a memory card happens to be
lodged in the SIM card slot, take the device to a Samsung Service Centre to remove
the memory card.
3 Push the SIM or USIM card into the slot until it lock in place.
4 Close the cover of the SIM card slot.
Removing the SIM or USIM card
1 Open the cover of the SIM card slot.
2 Push the SIM or USIM card until it disengages from the device, and then pull it out.
Getting started
11
Charging the battery
Use the charger to charge the battery before using it for the first time. A computer can be also
used to charge the device by connecting them via the USB cable.
Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or
cables can cause the battery to explode or damage the device.
•
When the battery power is low, the device emits a warning tone and displays a low
battery power message.
•
If the battery is completely discharged, the device cannot be turned on
immediately when the charger is connected. Allow a depleted battery to charge for
a few minutes before turning on the device.
Charging with the charger
Connect the USB cable to the USB power adaptor and then plug the end of the USB cable into
the multipurpose jack.
Connecting the charger improperly may cause serious damage to the device. Any
damage caused by misuse is not covered by the warranty.
•
The device can be used while it is charging, but it may take longer to fully charge
the battery.
•
If the device receives an unstable power supply while charging, the touch screen
may not function. If this happens, unplug the charger from the device.
•
While charging, the device may heat up. This is normal and should not affect the
device’s lifespan or performance. If the battery gets hotter than usual, the charger
may stop charging.
•
If the device is not charging properly, take the device and the charger to a
Samsung Service Centre.
Getting started
12
After fully charging, disconnect the device from the charger. First unplug the charger from the
device, and then unplug it from the electric socket.
To save energy, unplug the charger when not in use. The charger does not have a
power switch, so you must unplug the charger from the electric socket when not in
use to avoid wasting power. The device should remain close to the electric socket
while charging.
Checking the battery charge status
When you charge the battery while the device is off, the following icons will show the current
battery charge status:
Charging Fully charged
Reducing the battery consumption
Your device provides options that help you save battery power. By customising these options
and deactivating features in the background, you can use the device longer between charges:
•
When you are not using the device, switch to sleep mode by pressing the Power button.
•
Close unnecessary applications with the task manager.
•
Deactivate the Bluetooth feature.
•
Deactivate the Wi-Fi feature.
•
Deactivate auto-syncing of applications.
•
Decrease the backlight time.
•
Decrease the brightness of the display.
Getting started
13
Inserting a memory card
Your device accepts memory cards with maximum capacities of 16 GB. Depending on the
memory card manufacturer and type, some memory cards may not be compatible with your
device.
•
Some memory cards may not be fully compatible with the device. Using an
incompatible card may damage the device or the memory card, or corrupt the data
stored in it.
•
Use caution to insert the memory card right-side up.
•
The device supports only the FAT file system for memory cards. When inserting a
card formatted in a different file system, the device asks to reformat the memory
card.
•
Frequent writing and erasing of data shortens the lifespan of memory cards.
•
When inserting a memory card into the device, the memory card’s file directory
appears in the
extSdCard
folder under the internal memory.
1 Open the cover of the memory card slot.
2 Insert a memory card with the gold-coloured contacts facing downwards.
3 Push the memory card into the slot until it locks in place.
4 Close the cover of the memory card slot.
Getting started
14
Removing the memory card
Before removing the memory card, first unmount it for safe removal. On the Home screen, tap
→
Settings
→
Storage
→
Unmount SD card
.
1 Open the cover of the memory card slot.
2 Push the memory card until it disengages from the device, and then pull it out.
3 Close the cover of the memory card slot.
Do not remove the memory card while the device is transferring or accessing
information. Doing so can cause data to be lost or corrupted or damage to the
memory card or device. Samsung is not responsible for losses that result from the
misuse of damaged memory cards, including the loss of data.
Formatting the memory card
A memory card formatted on a computer may not be compatible with the device. Format the
memory card on the device.
On the Home screen, tap
→
Settings
→
Storage
→
Format SD card
→
Format SD card
→
Erase everything
.
Before formatting the memory card, remember to make backup copies of all
important data stored on the device. The manufacturer’s warranty does not cover loss
of data resulting from user actions.
Getting started
15
Turning the device on and off
When turning on the device for the first time, follow the on-screen instructions to set up your
device.
Press and hold the Power button for a few seconds to turn on the device.
•
Follow all posted warnings and directions from authorised personnel in areas
where the use of wireless devices is restricted, such as aeroplanes and hospitals.
•
Press and hold the Power button and tap
Flight mode
to disable the wireless
features.
To turn off the device, press and hold the Power button, and then tap
Power off
.
Holding the device
Do not cover the antenna area with your hands or other objects. This may cause connectivity
problems or drain the battery.
Getting started
16
Locking and unlocking the device
When not in use, lock the device to prevent unwanted operation. Pressing the Power button
turns off the screen and puts the device into lock mode. The device automatically gets locked
if it is not used for a specified period.
To unlock the device, press the Power button or the Home button and flick your finger in any
direction within the unlock screen area at the right part of the screen.
Adjusting the volume
Press the Volume button left or right to adjust the ringtone volume, or to adjust the sound
volume when playing music or video.
Switching to silent mode
Use one of the following methods:
•
Press and hold the left Volume button until it switches to silent mode.
•
Press and hold the Power button, and then tap
Mute
or
Vibrate
.
•
Open the quick setting panel at the top right of the screen, and then tap
Sound
or
Vibrate
.
17
Basics
Indicator icons
The icons displayed at the top of the screen provide information about the status of the
device. The icons listed in the table below are most common.
Icon Meaning
No signal
Signal strength
Roaming (outside of normal service area)
GRPS network connected
EDGE network connected
UMTS network connected
HSDPA network connected
Wi-Fi connected
Bluetooth feature activated
GPS activated
Call in progress
Missed call
Synced with the web
Connected to computer
No SIM or USIM card
New text or multimedia message
Alarm activated
Silent mode activated
Vibration mode activated
Flight mode activated
Error occurred or caution required
Battery power level
Basics
18
Using the touch screen
Use only fingers to use the touch screen.
•
Do not allow the touch screen to come into contact with other electrical devices.
Electrostatic discharges can cause the touch screen to malfunction.
•
Do not allow the touch screen to contact water. The touch screen may malfunction
in humid conditions or when exposed to water.
•
To avoid damaging the touch screen, do not tap it with anything sharp or apply
excessive pressure to it with your fingertips.
•
Leaving the touch screen idle for extended periods may result in afterimages
(screen burn-in) or ghosting. Turn off the touch screen when you do not use the
device.
Finger gestures
Tapping
To open an application, to select a menu item, to press an on-screen button, or to enter a
character using the on-screen keyboard, tap it with a finger.
Basics
19
Dragging
To move an icon, thumbnail, or preview to a new location, tap and hold it and drag it to the
target position.
Double-tapping
Double-tap on a webpage, map, or image to zoom in a part. Double-tap again to return.
Basics
20
Flicking
Flick left or right on the Home screen or the Applications screen to see another panel. Flick up
or down to scroll through a webpage or a list, such as contacts.
Pinching
Spread two fingers apart on a webpage, map, or image to zoom in a part. Pinch to zoom out.
Basics
21
Rotating the screen
Many applications allow display in either portrait or landscape orientation. Rotating the
device causes the display to automatically adjust to fit the new screen orientation.
To prevent the display from rotating automatically, open the quick setting panel and deselect
Screen rotation
.
•
Some applications do not allow screen rotation.
•
Some applications display a different screen depending on the orientation. The
calculator turns into a scientific calculator when rotated to landscape.
Notifications
Notification icons appear on the status bar at the top of the screen to report new messages,
calendar events, device status, and more. Drag down from the top left of the status bar to
open the notifications panel. Scroll through the list to see additional alerts. To close the
notifications panel, drag up the bar at the bottom of the screen.
Basics
22
Quick setting panel
From the quick setting panel, you can view your device’s current settings. Drag down from
the top right of the status bar to open the quick setting panel and use the following options:
•
Wi-Fi
: Activate or deactivate the Wi-Fi feature.
•
GPS
: Activate or deactivate the GPS feature.
•
Sound
: Activate or deactivate silent mode. You can vibrate or mute your device in silent
mode.
•
Screen rotation
: Allow or prevent the interface from rotating when you rotate the device.
•
Bluetooth
: Activate or deactivate the Bluetooth feature.
•
Mobile data
: Activate or deactivate the data connection.
•
Blocking mode
: Activate or deactivate blocking mode. In blocking mode, the device will
block notifications. To select which notifications will be blocked, tap
Settings
→
Blocking
mode
.
•
Power saving
: Activate or deactivate power-saving mode.
•
Sync
: Activate or deactivate auto-syncing of applications.
The available options may vary depending on the region or service provider.
Home screen
The Home screen is the starting point to access all of the device’s features. It displays indicator
icons, widgets, shortcuts to applications, and others.
The Home screen can have multiple panels. To view other panels, scroll left or right.
Basics
23
Rearranging items
Adding an application icon
On the Home screen, tap , tap and hold an application icon, and then drag it into a panel
preview.
Adding an item
Customise the Home screen by adding widgets, folders, or pages.
Tap and hold the empty area on the Home screen, and then select one of the following
categories:
•
Apps and widgets
: Add widgets to the Home screen.
•
Folder
: Create a new folder.
•
Page
: Create a new page.
Moving an item
Tap and hold an item and drag it to a new location. To move it to another panel, drag it to the
side of the screen.
Removing an item
Tap and hold an item, and drag it to the rubbish bin that appears at the top of the Home
screen. When the rubbish bin turns red, release it.
Basics
24
Rearranging panels
Adding a new panel
Tap
→
Edit page
→
.
Moving a panel
Tap
→
Edit page
, tap and hold a panel preview, and then drag it to a new location.
Removing a panel
Tap
→
Edit page
, tap and hold a panel preview, and then drag it to the rubbish bin at the
top of the screen.
Setting wallpaper
Set an image or photo stored in the device as wallpaper for the Home screen.
On the Home screen, tap
→
Set wallpaper
→
Home screen
, and then select one of the
following:
•
Gallery
: See photos taken by the device’s camera or images downloaded from the
Internet.
•
Live wallpapers
: See animated images.
•
Wallpapers
: See wallpaper images.
Then, select an image and tap
Set wallpaper
. Or, select an image, resize it by dragging the
frame, and then tap
Done
.
Basics
25
Using widgets
Widgets are small applications that provide convenient functions and information on your
Home screen. To use them, add widgets from the widgets panel to the Home screen.
•
Some widgets connect to web services. Using a web-based widget may result in
additional charges.
•
The widgets available may vary depending on the region or service provider.
Adding widgets to the Home screen
On the Home screen, tap
→
Widgets
. Scroll left or right on the widgets panel, and then
tap and hold a widget to add it to the Home screen.
Using the setting shortcut widget
On the Home screen, tap
→
Widgets
, and then tap and hold
Settings Shortcut
to open a
list of setting options. Select a setting option to add it to the Home screen as a shortcut.
Using applications
This device can run many different types of applications, ranging from media to Internet
applications.
Opening an application
On the Home screen or the Applications screen, select an application icon to open it.
Opening from recently-used applications
Press and hold the Home button to open the list of recently-used applications.
Select an application icon to open.
Basics
26
Closing an application
Close applications not in use to save battery power and maintain device performance.
Press and hold the Home button, tap
Task manager
, and then tap
End
next to an application
to close it. To close all running applications, tap
End all
. Alternatively, press and hold the
Home button, and then tap
Remove all
.
Applications screen
The Applications screen displays icons for all applications, including any new applications
installed.
On the Home screen, tap to open the Applications screen.
To view other panels, scroll left or right.
Rearranging applications
Tap
→
Edit
, tap and hold an application, and then drag it to a new location. To move it to
another panel, drag it to the side of the screen.
Organising with folders
Put related applications together in a folder for convenience.
Tap
→
Edit
, tap and hold an application, and then drag it to
Create folder
. Enter a folder
name and then tap
OK
. Put applications into the new folder by dragging, and then tap
Save
to save the arrangement.
Rearranging panels
Pinch on the screen, tap and hold a panel preview, and then drag it to a new location.
Installing applications
Use application stores, such as
Samsung Apps
, to download and install applications.
Basics
27
Uninstalling applications
Tap
→
Uninstall
, and then select an application to uninstall it.
Default applications that come with the device cannot be uninstalled.
Sharing applications
Share downloaded applications with other users via email, Bluetooth, or other methods.
Tap
→
Share apps
, select applications, tap
Done
, and then select a sharing method. The
next steps vary depending on the method selected.
Help
Access help information to learn how to use the device and applications or configure
important settings.
Tap
Help
on the Applications screen. Select an item to view tips.
Entering text
Use the Samsung keyboard or the voice input feature to enter text.
Text entry is not supported in some languages. To enter text, you must change the
input language to one of the supported languages.
Changing the keyboard type
Tap any text field, open the notifications panel, tap
Choose input method
, and then select
the type of keyboard to use.
Basics
28
Using the Samsung keyboard
Enter a space.
Break to the next line.
Delete a preceding
character.
Enter punctuation
marks.
Enter uppercase.
Set options for the
Samsung keyboard.
Enter uppercase.
Add an item from the
clipboard.
Entering uppercase
Tap before entering a character. For all caps, tap it twice.
Changing the keyboard type
Tap and hold , and then tap to change the keyboard type. Tap and hold and move
the floating keyboard to another location.
To switch to the fixed keyboard, tap .
Changing language keyboards
Add languages to the keyboard, and then slide the space key left or right to change language
keyboards.
Handwriting
Tap and hold , tap , and then write a word with a finger. Suggested words appear as
characters are entered. Select a suggested word.
Basics
29
Entering text by voice
Activate the voice input feature and then speak into the microphone. The device displays
what you speak.
If the device does not recognise your words correctly, tap the underlined text and select an
alternative word or phrase from the dropdown list.
To change the language or add languages for the voice recognition, tap the current language.
When you are finished, tap
Tap to pause
.
Copying and pasting
Tap and hold over text, drag or to select more or less text, and then tap
Copy
to copy or
Cut
to cut. The selected text is copied to the clipboard.
To paste it into a text entry field, tap and hold at the point where it should be inserted, and
then tap
Paste
.
Connecting to a Wi-Fi network
Connect the device to a Wi-Fi network to use the Internet or share media files with other
devices. (p. 90)
Turning Wi-Fi on and off
Open the quick setting panel, and then tap
Wi-Fi
to turn it on or off.
•
Your device uses a non-harmonised frequency and is intended for use in all
European countries. The WLAN can be operated in the EU without restriction
indoors, but cannot be operated outdoors.
•
Turn off Wi-Fi to save the battery when not in use.
Basics
30
Joining Wi-Fi networks
On the Applications screen, tap
Settings
→
Wi-Fi
, and then drag the
Wi-Fi
switch to the right.
Select a network from the list of detected Wi-Fi networks, enter a password if necessary, and
then tap
Connect
. Networks that require a password appear with a lock icon. After the device
connects to a Wi-Fi network, the device will automatically connect to it any time it is available.
Adding Wi-Fi networks
If the desired network does not appear in the networks list, tap
Add Wi-Fi network
at the
bottom of the networks list. Enter the network name in
Network SSID
, select the security
type and enter the password if it is not an open network, and then tap
Connect
.
Forgetting Wi-Fi networks
Any network that has ever been used, including the current network, can be forgotten so the
device will not automatically connect to it. Select the network in the networks list, and then
tap
Forget
.
Setting up accounts
Google applications, such as
Play Store
, require a Google account, and
Samsung Apps
requires a Samsung account. Create Google and Samsung accounts to have the best
experience with the device.
Adding accounts
Follow the instructions that appear when opening a Google application without signing in to
set up a Google account.
To sign in with or sign up for a Google account, on the Applications screen, tap
Settings
→
Add account
→
Google
. After that, tap
New
to sign up, or tap
Existing
, and then follow on-
screen instructions to complete the account setup. More than one Google account can be
used on the device.
Set up a Samsung account as well.
Basics
31
Removing accounts
On the Applications screen, tap
Settings
, select an account name under
Accounts
, select the
account to remove, and then tap
Remove account
.
Transferring files
Move audio, video, image, or other types of files from the device to the computer, or vice
versa.
The following file formats are supported by some applications. Some file formats are
not supported depending on the version of the device’s software.
•
Music: mp3, m4a, mp4, 3gp, 3ga, wma, ogg, oga, aac, and flac
•
Image: bmp, gif, jpg, and png
•
Video: 3gp, mp4, avi, wmv, flv, and mkv
•
Document: doc, docx, xls, xlsx, ppt, pptx, pdf, and txt
Connecting with Samsung Kies
Samsung Kies is a computer application that manages media libraries, contacts, and
calendars, and syncs them with Samsung devices. Download the latest Samsung Kies from
the Samsung website.
1 Connect the device to the computer using the USB cable.
Samsung Kies launches on the computer automatically. If Samsung Kies does not launch,
double-click the Samsung Kies icon on the computer.
2 Transfer files between your device and the computer.
Refer to the Samsung Kies help for more information.
Basics
32
Connecting with Windows Media Player
Ensure that Windows Media Player is installed on the computer.
1 Connect the device to the computer using the USB cable.
2 Open Windows Media Player and sync music files.
Connecting as a media device
1 Connect the device to the computer using the USB cable.
2 Open the notifications panel, and then tap
Connected as a media device
→
Media
device (MTP)
.
Tap
Camera (PTP)
if your computer does not support Media Transfer Protocol (MTP) or
not have any appropriate driver installed.
3 Transfer files between your device and the computer.
Securing the device
Prevent others from using or accessing personal data and information stored in the device by
using the security features. The device requires an unlock code whenever unlocking it.
Setting a face unlock
On the Applications screen, tap
Settings
→
Lock screen
→
Screen lock
→
Face unlock
.
Fit your face in the frame to be captured. Then, set a backup unlock PIN or pattern to unlock
the screen in case the face unlock fails.
Basics
33
Setting a pattern
On the Applications screen, tap
Settings
→
Lock screen
→
Screen lock
→
Pattern
.
Draw a pattern by connecting four dots or more, and then draw the pattern again to verify it.
Set a backup unlock PIN to unlock the screen when you forget the pattern.
Setting a PIN
On the Applications screen, tap
Settings
→
Lock screen
→
Screen lock
→
PIN
.
Enter at least four numbers, and then enter the password again to verify it.
Setting a password
On the Applications screen, tap
Settings
→
Lock screen
→
Screen lock
→
Password
.
Enter at least four characters including numbers and symbols, and then enter the password
again to verify it.
Unlocking the device
Turn on the screen by pressing the Power button or the Home button, and enter the unlock
code.
If the unlock code is forgotten, take the device to a Samsung Service Centre to reset it.
Basics
34
Upgrading the device
The device can be upgraded to the latest software.
This feature may not be available depending on the region or service provider.
Upgrading with Samsung Kies
Launch Samsung Kies and connect the device to the computer. Samsung Kies automatically
recognises the device and shows available updates in a dialogue box, if any. Click the Update
button in the dialogue box to start upgrading. Refer to the Samsung Kies help for details on
how to upgrade.
•
Do not turn off the computer or disconnect the USB cable while the device is
upgrading.
•
While upgrading the device, do not connect other media devices to the computer.
Doing so may interfere with the update process.
Upgrading over the air
The device can be directly upgraded to the latest software by the firmware over-the-air
(FOTA) service.
On the Applications screen, tap
Settings
→
About device
→
Software update
→
Update
.
35
Communication
Phone
Use this application to make or answer a call.
Tap
Phone
on the Applications screen.
Making calls
Making a call
Use one of the following methods:
•
Keypad
: Enter the number using the keypad, and then tap .
•
Logs
: Make a call from the history of incoming and outgoing calls and messages.
•
Favourites
: Make a call from the list of favourite contacts.
•
Contacts
: Make a call from the contacts list.
Speed dial numbers
For speed dial numbers, tap and hold the corresponding digit.
Number prediction
When entering numbers on the keypad, automatic predictions appear. Select one of these to
make a call.
Communication
36
Finding contacts
Enter a name, phone number, or email address to find a contact in the contacts list. As
characters are entered, predicted contacts appear. Select one to place a call to it.
Making an international call
Tap and hold 0 until the + sign appears. Enter the country code, area code, and phone
number, and then tap .
During a call
The following actions are available:
•
Add call
: Dial a second call.
•
Keypad
: Open the keypad.
•
Speaker
: Activate the speakerphone. Keep the device away from your ears when using
the speakerphone.
•
Mute
: Turn off the microphone so that the other party cannot hear you.
•
Headset
: Switch to a Bluetooth headset if it is connected to the device.
•
Swap
: Switch between two calls.
•
Merge
: Make a multiparty call when connected to two calls. Repeat this to add more
parties. This feature is available only if the multiparty call service is active.
•
→
Contacts
: Open the contacts list.
•
→
Message
: Send a message.
•
→
Memo
: Create a memo.
•
→
Transfer
: Connect the first party to the second party. This disconnects you from
the conversation.
•
→
Manage conference call
: Have a private conversation with one party during a
multiparty call or disconnect one party form the multiparty call.
Communication
37
Adding contacts
To add a phone number to the contacts list from the keypad, enter the number and tap .
Sending a message
Tap
Message
to send a message to the number on display.
Viewing call logs
Tap
Logs
to view the history of incoming and outgoing calls.
To filter a call log, tap
→
View by
, and then select an option.
Fixed dialling number
The device can be set to restrict outgoing calls only to numbers with specified prefixes. Those
prefixes are stored in the SIM or USIM card.
Tap
→
Call settings
→
Additional settings
→
Fixed Dialling Numbers
→
Enable FDN
,
and then enter the PIN2 supplied with the SIM or USIM card. Tap
FDN list
and add numbers.
Call barring
The device can be set to prevent certain calls from being made. For example, international
calling can be disabled.
Tap
→
Call settings
→
Additional settings
→
Call barring
, select a call type, select a call
barring option, and then enter a password.
Receiving calls
Answering a call
When a call comes in, drag outside the circle, or press the headset button.
If the call waiting service is active, another call can be made. When the second call is
answered, the first call is put on hold.
Communication
38
Rejecting a call
When a call comes in, drag outside the circle, or press and hold the headset button.
To send a message when rejecting an incoming call, tap
Reject call with message
. To create
the rejection message, tap
→
Call settings
→
Set reject messages
.
Automatically rejecting calls from unwanted numbers
Tap
→
Call settings
→
Call rejection
, drag the
Auto reject mode
switch to the right, and
then tap
Auto reject list
. Tap , enter a number, assign a category, and then tap
Save
.
Missed calls
If a call is missed, appears on the status bar. Open the notifications panel to view the list of
missed calls.
Call waiting
Call waiting is a service provided by the service provider. A user can use this service to
suspend a current call and switch to an incoming call. This service is not available for video
calls.
To make use of this service, tap
→
Call settings
→
Additional settings
→
Call waiting
.
Call forwarding
The device can be set to send incoming calls to a specified number.
Tap
→
Call settings
→
Additional settings
→
Call forwarding
, and then select a call
type and condition. Enter a number and tap
Enable
.
Ending a call
Tap
End call
to end a call. Or press the headset button.
Communication
39
Video calls
Making a video call
Enter the number or select a contact from the contacts list, and then tap
Video call
to make a
video call.
During a video call
The following actions are available:
•
Hide me
: Hide your image from the other party.
•
Mute
: Turn off the microphone so that the other party cannot hear you.
•
Headset
: Switch to a Bluetooth headset if it is connected to the device.
•
Switch camera
: Switch between the front and rear camera.
•
Keypad
: Open the keypad.
•
→
Outgoing image
: Select an image to show it to the other party.
•
→
Animated emotions
: Apply emotional icons to your image.
•
→
Theme view
: Apply decorative icons to your image.
•
→
Enable cartoon view
: Change the view mode to the cartoon view.
Tap and hold the other party’s image to access the following options:
•
Capture image
: Capture the other party’s image.
•
Record video
: Take a video of the other party’s images.
It is illegal in many countries to record a call without the other party’s prior
permission.
Tap and hold your image to access the following options:
•
Switch camera
: Switch between the front and rear camera.
•
Outgoing image
: Select an image to show it to the other party.
Communication
40
Swapping images
Drag an image of either party onto the other party’s image to swap the images.
Contacts
Use this application to manage contacts, including phone numbers, email addresses, and
others.
Tap
Contacts
on the Applications screen.
Managing contacts
Creating a contact
Tap and enter contact information.
•
: Add an image.
•
/ : Add or delete a contact field.
Communication
41
Editing a contact
Select a contact to edit, and then tap .
Deleting a contact
Tap .
Selecting a speed dial number
Tap
→
Speed dial setting
, select a speed dial number, and then select a contact for it. To
remove a speed dial number, tap
→
Speed dial setting
→
→
Remove
.
Searching for contacts
Use one of the following search methods:
•
Scroll up or down the contacts list.
•
Use the index at the left side of the contacts list for quick scrolling, by dragging a finger
along it.
•
Tap the search field at the top of the contacts list and enter search criteria.
Once a contact is selected, take one of the following actions:
•
: Add to favourite contacts.
•
/ : Make a voice or video call.
•
: Compose a message.
•
: Compose an email.
Displaying contacts
By default, the device shows all saved contacts on the device, the SIM or USIM card, or
another account.
Tap
→
Contacts to display
, and then select a location where contacts are saved.
Communication
42
Importing and exporting contacts
Syncing with Google Contacts
Tap
→
Merge accounts
→
Merge with Google
.
Contacts synced with Google Contacts appear with in the contacts list.
If a contact is added or deleted on the device, it is also added to or deleted from Google
Contacts, and vice versa.
Syncing with Samsung Contacts
Tap
→
Merge accounts
→
Merge with Samsung
.
Contacts synced with Samsung Contacts appear with in the contacts list.
If a contact is added or deleted on the device, it is also added to or deleted from Samsung
Contacts, and vice versa.
Importing contacts
Tap
→
Import/Export
→
Import from USB storage
,
Import from SD card
, or
Import
from SIM card
.
Exporting contacts
Tap
→
Import/Export
→
Export to USB storage
,
Export to SD card
, or
Export to SIM
card
.
Sharing contacts
Tap
→
Import/Export
→
Share namecard via
, select contacts, tap
Done
, and then select
a sharing method.
Favourite contacts
Tap
Contacts
→
Favourites
.
Tap , and then take one of the following actions:
•
Search
: Search for contacts.
•
Add to Favourites
: Add contacts to favourites.
•
Remove from Favourites
: Remove contacts from favourites.
Communication
43
Contact groups
Tap
Contacts
→
Groups
.
Adding contacts to a group
Select a group, and then tap
→
Add member
. Select contacts to add, and then tap
Done
.
Managing groups
Tap , and then take one of the following actions:
•
Search
: Search for contacts.
•
Delete groups
: Select user-added groups, and then tap
Delete
. Default groups cannot be
deleted.
•
Edit
: Change the group settings.
•
Add member
: Add members to the group.
•
Remove member
: Remove members from the group.
•
Send message
: Send a message to a group’s members.
•
Send email
: Send an email to a group’s members.
•
Change order
: Tap and hold next to the group name, drag it up or down to another
position, and then tap
Done
.
Sending a message or email to a group’s members
Select a group, tap
→
Send message
or
Send email
, select members, and then tap
Done
.
Business card
Create a business card and send it to others.
Tap
Set up my profile
, enter details, such as phone number, email address, and postal
address, and then tap
Save
. If user information has been saved when you set up the device,
select the business card in
ME
, and then tap to edit.
Tap
→
Share namecard via
, and then select a sharing method.
Communication
44
Messaging
Use this application to send text messages (SMS) or multimedia messages (MMS).
Tap
Messaging
on the Applications screen.
You may incur additional charges for sending or receiving messages while you are
outside your home service area. For details, contact your service provider.
Sending messages
Tap , add recipients, enter a message, and then tap .
Use the following methods to add recipients:
•
Enter a phone number.
•
Tap , select contacts, and then tap
Done
.
Use the following methods to make a multimedia message:
•
Tap and attach images, videos, contacts, memos, events, and others.
•
Tap
→
Add subject
to enter a subject.
Sending scheduled messages
While composing a message, tap
→
Scheduling
. Set a time and date, and then tap
OK
.
The device will send the message at the specified time and date.
•
If the device is turned off at the scheduled time, is not connected to the network,
or the network is unstable, the message will not be sent.
•
This feature is based on the time and date set on the device. The time and date
may be incorrect if you move across time zones and the network does not update
the information.
Communication
45
Viewing incoming messages
Incoming messages are grouped into message threads by contact.
Select a contact to view the person’s message.
Listening to a voice message
Tap and hold 1 on the keypad, and then follow the instructions from your service provider.
Email
Use this application to send or view email messages.
Tap
Email
on the Applications screen.
Setting up email accounts
Set up an email account when opening
Email
for the first time.
Enter the email address and password. Tap
Next
for a private email account, such as Google
Mail, or tap
Manual setup
for a company email account. After that, follow on-screen
instructions to complete the setup.
To set up another email account, tap
→
Settings
→
Add account
.
Sending messages
Tap the email account to use, and then tap at the top of the screen. Enter recipients,
subject, and message, and then tap
Send
.
Tap to add a recipient from the contacts list.
Tap
+Cc/Bcc
to add more recipients.
Tap
+Me
to add yourself as a recipient.
Tap to attach images, videos, contacts, memos, events, and others.
Tap to insert images, events, contacts, and location information into the message.
Communication
46
Sending scheduled messages
While composing a message, tap . Tick
Schedule sending
, set a time and date, and then
tap
Done
. The device will send the message at the specified time and date.
•
If the device is turned off at the scheduled time, is not connected to the network,
or the network is unstable, the message will not be sent.
•
This feature is based on the time and date set on the device. The time and date
may be incorrect if you move across time zones and the network does not update
the information.
Reading messages
Select an email account to use, and new messages are retrieved. To manually retrieve new
messages, tap .
Tap a message to read.
Open attachments.
Add this email address
to the contacts list.
Delete the message.
Mark the message as a
reminder.
Forward the message.
Reply to all recipients.
Reply to the message.
Compose a message.
Retrieve new
messages.
Search for a message.
Tap the attachment tab to open attachments, and then tap next to an attachment to save
it.
Communication
47
Google Mail
Use this application to quickly and directly access the Google Mail service.
Tap
Google Mail
on the Applications screen.
•
This application may not be available depending on the region or service provider.
•
This application may be labelled differently depending on the region or service
provider.
Sending messages
In any mailbox, tap , enter recipients, a subject, and a message, and then tap
SEND
.
Tap
+CC/BCC
to add more recipients.
Tap to attach images.
Tap
→
Save draft
to save the message for later delivery.
Tap
→
Attach video
to attach videos.
Tap
→
Discard
to start over.
Reading messages
Keep this message for
long-term storage.
Mark the message as a
reminder.
Delete this message.
Search for a message.
Compose a message.
Reply to this message.
Reply to all recipients.
Add this email address
to the contacts list.
Forward this message
to others.
Communication
48
Labels
Google Mail does not use actual folders, but uses labels instead. When Google Mail is
launched, it displays messages labelled Inbox.
To add a label to a message, select the message, tap
→
Change labels
, and then select
the label to assign.
Talk
Use this application to chat with others via Google Talk.
Tap
Talk
on the Applications screen.
This application may not be available depending on the region or service provider.
Public profile
Tap the account ID at the top of the friends list to change the availability status, image, or
status message.
Adding friends
Tap , enter the email address of the friend to add, and then tap
DONE
.
Chatting with friends
Select a friend from the friends list, enter a message in the field at the bottom of the screen,
and then tap .
To add a friend to chat, tap
→
Add to chat
.
To end the chat, tap
→
End chat
.
Communication
49
Switching between chats
Select a friend from the friends list.
Deleting chat history
Chats are automatically saved. To delete chat history, tap
→
Clear chat history
.
Google+
Use this application to stay connected with people via Google’s social network service.
Tap
Google+
on the Applications screen.
This application may not be available depending on the region or service provider.
Tap
All circles
to change the category, and then scroll left or right to view posts from your
circles.
ChatON
Use this application to chat with any device that has a mobile phone number.
Tap
ChatON
on the Applications screen.
This application may not be available depending on the region or service provider.
Create the buddies list by entering phone numbers or email addresses of Samsung accounts,
or selecting buddies from the list of suggestions.
Select a buddy to start chatting.
To sync contacts on the device with ChatON, tap
Settings
→
Sync Contacts
.
Communication
50
Messenger
Use this application to chat with others via Google+ instant messaging service.
Tap
Messenger
on the Applications screen.
This application may not be available depending on the region or service provider.
Select a friend from the friends list, enter a message in the field at the bottom of the screen,
and then tap .
51
Web & network
Internet
Use this application to browse the Internet.
Tap
Internet
on the Applications screen.
Viewing webpages
Tap the address field, enter the web address, and then tap
Go
.
Tap to share, save, or print the current webpage while viewing a webpage.
To change the search engine, tap
→
Advanced
→
Set search engine
.
Opening a new page
Tap .
To go to another webpage, scroll left or right on the title field, and tap the page to select it.
Searching the web by voice
Tap the address field, tap , speak a keyword, and then select one of the suggested keywords
that appear.
This feature may not be available depending on the region or service provider.
Bookmarks
To bookmark the current webpage, tap .
To open a bookmarked webpage, tap , and then select one.
Web & network
52
History
Tap
→
History
to open a webpage from the list of recently-visited webpages. To clear the
history, tap
→
Clear history
.
Tap
→
History
→
Most visited
to open a webpage from the list of most visited webpages.
Saved pages
To view saved webpages, tap
→
Saved pages
.
Links
Tap and hold a link on the webpage to open it in a new page, save, or copy.
To view saved webpages, tap
→
Downloads
.
Sharing webpages
To share a webpage address with others, tap
→
Share page
.
To share a part of a webpage, tap and hold the desired text, and then tap
Share
.
Chrome
Use this application to search for information and browse webpages.
Tap
Chrome
on the Applications screen.
This application may not be available depending on the region or service provider.
Viewing webpages
Tap the address field, and then enter a web address or search criteria.
Opening a new page
Tap
→
New tab
.
To go to another webpage, scroll left or right on the title field, and tap the page to select it.
Web & network
53
Bookmarks
To bookmark the current webpage, tap , enter details, such as name and web address, and
then tap
Save
.
To open a bookmarked webpage,
→
Bookmarks
, and then select one.
Searching the web by voice
Tap , speak a keyword, and then select one of the suggested keywords that appear.
Syncing with other devices
Sync open tabs and bookmarks to use with Chrome on another device, when you are logged
in with the same Google account.
To view open tabs on other devices, tap
→
Other devices
. Select a webpage to open. To
view bookmarks, tap .
Bluetooth
Bluetooth creates a direct wireless connection between two devices over short distances. Use
Bluetooth to exchange data or media files with other devices.
•
Samsung is not responsible for the loss, interception, or misuse of data sent or
received via the Bluetooth feature.
•
Always ensure that you share and receive data with devices that are trusted
and properly secured. If there are obstacles between the devices, the operating
distance may be reduced.
•
Some devices, especially those that are not tested or approved by the Bluetooth
SIG, may be incompatible with your device.
•
Do not use the Bluetooth feature for illegal purposes (for example, pirating copies
of files or illegally tapping communications for commercial purposes).
Samsung is not responsible for the repercussion of illegal use of the Bluetooth
feature.
To activate Bluetooth, on the Applications screen, tap
Settings
→
Bluetooth
, and then drag
the
Bluetooth
switch to the right.
Web & network
54
Pairing with other Bluetooth devices
On the Applications screen, tap
Settings
→
Bluetooth
→
Scan
, and detected devices are
listed. Select the device you want to pair with, and then accept the auto-generated passkey
on both devices to confirm.
Sending and receiving data
Many applications support data transfer via Bluetooth. An example is
Gallery
. Open
Gallery
,
select an image, tap
→
Bluetooth
, and then select one of the paired Bluetooth devices.
After that, accept the Bluetooth authorisation request on the other device to receive the
image. The transferred file is saved in the
Bluetooth
folder. If a contact is received, it is added
to the contacts list automatically.
Smart Remote
Use this application to use the device as a remote control for TVs and entertainment systems.
Tap
Smart Remote
on the Applications screen.
You must first connect the device to a Wi-Fi AP and ensure that the device’s infrared port is
facing the TV.
Setting the device as a remote control for a TV
Tap
Choose Your Country or Region
, select a country or a region, and then follow on-screen
instructions to complete the setup process.
To open the remote control panel, tap the panel handle at the bottom right edge of the
screen.
To add another room, tap >
Add New Room
.
Web & network
55
Customising remote control settings
Tap and use the following options:
•
Edit channels
: Hide channels.
•
Rooms & Devices
: Change connection settings.
–
Provider
: Hide channels.
–
TV
: Change command codes when there are problems with particular controls.
–
Add New Device
: Add connections for peripheral devices connected to the TV.
•
Profile
: Enter user profile so that Peel can help you find top picks you can enjoy.
•
Favorite Programs
: View favourite programs.
•
Cut programs
: Restore previously hidden programs.
•
Genres
: Hide or change the order of genres.
•
Sports
: Hide or change the order of sports.
•
Send Feedback
: Report your opinions for application development.
•
Reset Peel
: Reset the connection settings.
56
Media
Music Player
Use this application to listen to music.
Tap
Music Player
on the Applications screen.
•
Some file formats are not supported depending on the device’s software version.
•
Some files may not play properly depending on the encoding used.
Playing music
Select a music category, and then select a song to play.
Tap the album image to open the music player screen.
Skip to the next song.
Tap and hold to move
forwards quickly.
Pause and resume
playback.
Open the playlist.
Select a sound effect.
View file details.
Change the repeat
mode.
Restart the
currently-playing song
or skip to the previous
song. Tap and hold to
move backwards
quickly.
Turn on shue.
Set the le as your
favourite track.
Mute the sound.
Adjust the volume.
Media
57
Setting a song as ringtone or alarm tone
To use the currently-playing song as ringtone or alarm tone, tap
→
Set as
, and select an
option.
Creating playlists
Make an own selection of songs.
Tap
→
New playlist
. Enter a title and tap
OK
. Select songs to include, and then tap
Done
.
To add the currently-playing song to a playlist, tap
→
Add to playlist
.
Playing music by mood
Play music grouped by mood. The playlist is automatically created by the device. When a new
song is added, tap
Music square
→
.
Tap
Music square
and select a cell of mood. Or select multiple cells by dragging your finger.
Camera
Use this application to take photos or videos.
Use
Gallery
to view photos and videos taken with the device’s camera. (p. 64)
Tap
Camera
on the Applications screen.
The camera automatically shuts off when unused.
Camera etiquette
•
Do not take photos or videos of other people without their permission.
•
Do not take photos or videos where legally prohibited.
•
Do not take photos or videos in places where you may violate other people’s privacy.
Media
58
Taking photos
Taking a photo
Tap the image on the preview screen where the camera should focus. When the subject is in
focus, the focus frame turns green. Tap to take the photo.
Indicates which storage
is in use.
Switch between still
and video mode.
Open the image viewer
to display photos.
Switch between the
front and rear camera.
Change the shooting
mode.
Set delayed-time
shots.
Determine how much
light the camera’s
sensor receives.
Change the camera
settings.
Select among various
eects that are
available.
Scene mode
Predefined settings make point-and-shoot photos easier to take.
Tap
→
Scene mode
.
•
Landscape
: Use this setting to take photos of blue skies and landscapes with richer
colours.
•
Sports
: Use this setting for fast-moving subjects.
•
Party/Indoor
: Use this setting for well-lit indoor scenes.
•
Beach/Snow
: Use this setting for well-lit or sunny outdoor scenes.
Media
59
•
Sunset
: Use this setting for richer colours and sharper contrasts.
•
Dawn
: Use this setting for very subtle colours.
•
Autumn colour
: Use this setting for red-shifted background scenery.
•
Candlelight
: Use this setting for images of bright light against a dark background.
•
Firework
: Use this setting for high-contrast scenes.
•
Backlight
: Use this setting for subjects with bright lights behind them.
•
Night
: Use this setting for images taken in darker conditions.
Shooting mode
Several photo effects are available.
Tap
→
Shooting mode
.
•
Single shot
: Take a single photo.
•
Panorama
: Take a photo composed of many photos strung together.
•
Share shot
: Send a photo directly to another device via Wi-Fi Direct.
•
Buddy photo share
: Set the device to recognise a person’s face that you have tagged
in a photo and send it to that person. Face recognition may fail depending on the face
angle, face size, skin colour, facial expression, light conditions, or accessories the subject
is wearing.
Panoramic photos
A panoramic photo is a wide landscape image consisting of multiple shots.
Tap
→
Shooting mode
→
Panorama
.
Tap and move the camera in one direction. When the blue frame aligns with the
viewfinder, the camera automatically takes another shot in a panoramic sequence. To stop
shooting, tap .
Media
60
Taking videos
Taking a video
Slide the still-video switch to the video icon, and then tap to take a video. To pause
recording, tap . To stop recording, tap .
Manual focus is not available in video mode.
Recording mode
Indicates which storage
is in use.
Switch between still
and video mode.
Open the video player
to play videos.
Switch between the
front and rear camera.
Change recording
mode.
Set delayed-time
shots.
Determine how much
light the camera’s
sensor receives.
Change the camera
settings.
Select among various
eects that are
available.
Media
61
Tap to change recording mode.
•
Normal
: Use this mode for normal quality.
•
Limit for MMS
: Use this mode to lower quality for sending via messaging.
•
Limit for Email
: Use this mode to lower quality for sending via email.
Zooming in and out
Use one of the following methods:
•
Use the Volume button to zoom in or out.
•
Spread two fingers apart on the screen to zoom in, and pinch to zoom out.
The zoom in/out effect is available when using the zoom feature while shooting
video.
Media
62
Configuring settings for Camera
Tap to configure settings for Camera. Not all of the following options are available in both
still camera and video camera modes. The available options vary depending on the mode
used.
•
Edit shortcuts
: Reorganise shortcuts to frequently-used options.
•
GPS tag
: Attach a GPS location tag to the photo.
•
To improve GPS signals, avoid shooting in locations where the signal may be
obstructed, such as between buildings or in low-lying areas, or in poor weather
conditions.
•
Your location may appear on your photos when you upload them to the Internet.
To avoid this, deactivate the GPS tag setting.
•
Self portrait
: Take a photo of yourself.
•
Self recording
: Take a video of yourself.
•
Shooting mode
: Change the shooting mode.
•
Recording mode
: Change recording mode.
•
Effects
: Select among various photo effects that are available.
•
Scene mode
: Change the scene mode.
•
Exposure value
: Change the exposure value. This determines how much light the
camera’s sensor receives. For low-light situations, use a higher exposure.
•
Timer
: Use this for delayed-time shots.
•
Resolution
: Select a resolution. Use higher resolution for higher quality. But it takes up
more memory.
•
White balance
: Select an appropriate white balance, so images have a true-to-life colour
range. The settings are designed for specific lighting situations. These settings are similar
to the heat range for white-balance exposure in professional cameras.
Media
63
•
Metering
: Select a metering method. This determines how light values are calculated.
Centre-weighted
measures background light in the centre of the scene.
Spot
measures
the light value at a specific location.
Matrix
averages the entire scene.
•
Outdoor visibility
: Use this for bright, outdoor conditions.
•
Guidelines
: Display viewfinder guides to help composition when selecting subjects.
•
Save as flipped
: Invert the image to create a mirror-image of the original scene.
•
Image quality
: Set the quality level for photos. Higher quality images require more
storage space.
•
Video quality
: Set the quality level for videos.
•
Storage
: Select the memory location for storage.
•
Reset
: Reset the camera settings.
Shortcuts
Reorganise shortcuts for easy access to the camera’s various options.
Tap
→
Edit shortcuts
.
Tap and hold an option and drag it to a slot at the left of the screen. The other icons can be
moved within the list by tapping and dragging them.
Media
64
Gallery
Use this application to view images and videos.
Tap
Gallery
on the Applications screen.
•
Some file formats are not supported depending on the software installed on the
device.
•
Some files may not play properly depending on how they are encoded.
Viewing images
Launching
Gallery
displays available folders. When another application, such as
Email
, saves
an image, the
Download
folder is automatically created to contain the image. Likewise,
capturing a screenshot automatically creates the
Screenshots
folder. Select a folder to open
it.
In a folder, images are displayed by creation date. Select an image to view it in full screen.
Scroll left or right to view the next or previous image.
Zooming in and out
Use one of the following methods to zoom in an image:
•
Double-tap anywhere to zoom in.
•
Spread two fingers apart on any place to zoom in. Pinch to zoom out, or double-tap to
return.
Playing videos
Video files show the icon on the preview. Select a video to watch it and tap .
Media
65
Editing images
When viewing an image, tap and use the following functions:
•
Slideshow
: Start a slideshow with the images in the current folder.
•
Photo frame
: Use this to write a note below the image. The edited image is saved in the
Photo frame
folder.
•
Photo note
: Use this to write a note on the back of the image. Tap to edit the note.
•
Copy to clipboard
: Copy to clipboard.
•
Rotate left
: Rotate anti-clockwise.
•
Rotate right
: Rotate clockwise.
•
Crop
: Resize the blue frame to crop and save the image in it.
•
Set as
: Set the image as a wallpaper or a contact image.
•
Buddy photo share
: Send the image to a person whose face is tagged in the image.
•
Print
: Print via a USB or Wi-Fi connection. The device is only compatible with some
Samsung printers.
•
Rename
: Rename the file.
•
Scan for nearby devices
: Search for devices that have media sharing activated.
•
Details
: View image details.
•
Settings
: Change the Gallery settings.
Favourite images
When viewing an image, tap to add the image to the favourites list.
Deleting images
Use one of the following methods:
•
In a folder, tap
→
Select item
, select images by ticking, and then tap .
•
When viewing an image, tap .
Media
66
Sharing images
Use one of the following methods:
•
In a folder, tap
→
Select item
, select images by ticking, and then tap to send them
to others.
•
When viewing an image, tap to send it to others or share it via social network services.
Setting as wallpaper
When viewing an image, tap
→
Set as
to set the image as wallpaper or to assign it to a
contact.
Paper Artist
Use this application to make images look like illustrations with fun effects or frames.
Tap
Paper Artist
on the Applications screen.
Use artistic tools to edit an image. The edited image is saved in the
Gallery
→
Paper Pictures
folder.
Select an existing
image.
Share the image.
Apply effects to the
image.
Change the pen
thickness.
Take a photo.
Change the brush
thickness.
Save the image.
Apply frames to the
image.
Change the eraser size.
Media
67
Video Player
Use this application to play video files.
Tap
Video Player
on the Applications screen.
•
Avoid locking the device’s screen while playing a DivX Video-On-Demand. Each
time you lock the screen while playing a DivX Video-On-Demand, one of your
available rental counts is lost.
•
Some file formats are not supported depending on the device's software.
•
Some files may not play properly depending on how they are encoded.
Playing videos
Select a video to play.
Change screen ratio.
Move forwards or
backwards by
dragging the bar.
Adjust the volume.
Mute the sound.
Restart the current
video or skip to the
previous video. Tap
and hold to move
backwards quickly.
Skip to the next video.
Tap and hold to move
forwards quickly.
Reduce the size of the
video screen.
Select a sound effect.
Insert a bookmark.
Pause and resume
playback.
Media
68
Deleting videos
Tap
→
Delete
, select videos by ticking, and then tap
Delete
.
Sharing videos
Tap
→
Share via
, select a sharing method, select videos by ticking, and then tap
Share
.
Using Popup Video player
Use this feature to use other applications without closing the video player. While watching
videos, tap to use the pop-up player.
Spread two fingers apart on the screen to enlarge the player or pinch to reduce it. To move
the player, drag the player to another location.
YouTube
Use this application to watch videos from the YouTube website.
Tap
YouTube
on the Applications screen.
This application may not be available depending on the region or service provider.
Media
69
Watching videos
Tap , and then enter a keyword. Select one of the returned search results to watch a video.
Tap to display full screen.
Pause or resume
playback.
Move forwards or
backwards by
dragging the bar.
Change display
quality.
Add the video to the
playlist.
Exit full screen.
Send the URL to
others.
Search for videos.
Sharing videos
Select the video to view, tap , and then select a sharing method.
Uploading videos
Select your account, tap , select a video, enter information for the video, and then tap
UPLOAD
.
Media
70
Flipboard
Use this application to access your personalised magazines.
Tap
Flipboard
on the Applications screen.
This application may not be available depending on the region or service provider.
To start your Flipboard, flick left on the greeting page, tap
Get Started
, select news topics,
and then tap
Build Your Flipboard
.
Select a cover story or a topic, flick through the Flipboard pages, and then select an article to
read.
While reading an article, use the following icons:
•
: Go to the previous page.
•
: Set the article as your likes in Facebook.
•
: View others’ comments about the article.
•
: Share the article with others.`
71
Application & media stores
Play Store
Use this application to purchase and download applications and games that are able to run
on the device.
Tap
Play Store
on the Applications screen.
This application may not be available depending on the region or service provider.
Installing applications
Browse applications by category, or tap to search with a keyword.
Select an application to view information. To download it, tap
Install
. If there is a charge for
the application, tap the price, and follow on-screen instructions to complete the purchase
process.
•
When a new version is available for any installed application, an update icon
appears at the top of the screen to alert you to the update. Open the notifications
panel and tap the icon to update the application.
•
To install applications that you downloaded from other sources, on the
Applications screen, tap
Settings
→
Security
→
Unknown sources
.
Uninstalling applications
Uninstall the applications purchased from
Play Store
.
Tap , select an application to delete in the list of installed applications, and then tap
Uninstall
.
Application & media stores
72
Samsung Apps
Use this application to purchase and download dedicated Samsung applications. For more
information, visit
www.samsungapps.com
.
Tap
Samsung Apps
on the Applications screen.
This application may not be available depending on the region or service provider.
Installing applications
Browse applications by category. Tap to select a category.
To search for an application, tap at the top of the screen, and then enter a keyword in the
search field.
Select an application to view information. To download it, tap
Get
or
Buy
.
When a new version is available for any installed application, an update icon appears
at the top of the screen to alert you to the update. Open the notifications panel and
tap the icon to update the application.
Game Hub
Use this application to access games.
Tap
Game Hub
on the Applications screen.
This application may not be available depending on the region or service provider.
Scroll left or right and select a game to download from
Samsung Apps
.
Application & media stores
73
Play Books
Use this application to read and download book files.
Tap
Play Books
on the Applications screen.
This application may not be available depending on the region or service provider.
Select a book file by scrolling left or right. While reading a book file, tap to access
additional options.
To purchase book files, tap .
Play Movies
Use this application to watch, download, and rent movies or TV shows.
Tap
Play Movies
on the Applications screen.
This application may not be available depending on the region or service provider.
Select a category at the top of the screen, and then select a movie, TV programme, or video to
play or rent.
Play Music
Use this application to listen to music from the device or stream music from the Google cloud
service.
Tap
Play Music
on the Applications screen.
This application may not be available depending on the region or service provider.
Play music by selecting a music category or share songs with others by uploading them to
the Google cloud storage.
Application & media stores
74
Video Hub
Use this application to access and purchase videos.
Tap
Video Hub
on the Applications screen.
This application may not be available depending on the region or service provider.
Select a category, and then select a video.
Readers Hub
Use this application to purchase books or subscribe to newspapers or magazines.
Tap
Readers Hub
on the Applications screen.
This application may not be available depending on the region or service provider.
Select a category, find a book file, and then download it.
Learning Hub
Use this application to access learning material.
Tap
Learning Hub
on the Applications screen.
This application may not be available depending on the region or service provider.
Select a category, and then select a video lecture or book.
75
Utilities
Memo
Use this application to record important information to save and view at a later date.
Tap
Memo
on the Applications screen.
Composing memos
Tap , enter a memo, and then tap
Save
.
To change the background colour, tap
→
Colour
. Each category has different background
colour.
To lock the memo so that others cannot view it, tap
→
Lock
.
Browsing notes
Browse memo thumbnails by scrolling up or down.
To edit the memo, tap the memo.
To search for a memo, tap .
To change the view mode, tap .
To delete memos, tap .
To send memos to others, tap
→
Share via
.
To print memos via a USB or Wi-Fi connection, tap
Print
. The device is only compatible with
some Samsung printers.
To sync memos with a Google account, tap
→
Memo sync
.
Utilities
76
Viewing a memo
Tap the memo thumbnail to open it. Scroll left or right to see more memos.
Tap and use the following:
•
Delete
: Delete the memo.
•
Colour
: Change the background colour.
•
Lock
: Lock the memo so that others cannot view it.
•
Print
: Print the memo via a USB or Wi-Fi connection. The device is only compatible with
some Samsung printers.
•
Share via
: Send the memo to others.
S Planner
Use this application to manage events and tasks.
Tap
S Planner
on the Applications screen.
Creating events or tasks
Tap , and then use one of the following methods:
•
Add event
: Enter an event with an optional repeat setting.
•
Add task
: Enter a task with an optional priority setting.
To add an event or task more briefly, tap a date to select it and tap it again.
Utilities
77
Enter a title and specify which calendar to use or sync with. Then tap
Edit event details
or
Edit task details
to add more details, such as how often the event repeats, when it has an
advance alert, or where it takes place.
Attach a map showing the location of the event. Enter the location in the
Location
field, tap
next to the field, and then pinpoint the precise location by tapping and holding on the
map that appears.
Attach an image. Tap
Images
, and then take a photo or select one of the existing images.
Syncing with Google Calendar
On the Applications screen, tap
Settings
→
Google
under
Accounts
→
a Google account
→
Sync Calendar
. To manually sync for updating, on the Applications screen, tap
S Planner
→
→
Sync
.
To display synced event or task, tap
→
Settings
→
View settings
→
Calendars
, select the
Google account, and then tap
OK
.
Changing calendar type
Select one from among different types of calendars including year, month, week, and others.
A pinch gesture can be used to change calendar type. For example, pinch to change from the
monthly calendar to the yearly calendar, and spread apart to change yearly calendar back to
monthly calendar.
Searching for events
Tap , and then enter a keyword to search for.
To view today’s events, tap
Today
.
Utilities
78
Deleting events
Select an event, and then tap
→
Delete
.
Sharing events
Select an event, tap
→
Share via
, and then select a sharing method.
Polaris Office
Use this application to edit documents in various formats, including spreadsheets and
presentations.
Tap
Polaris Office
on the Applications screen.
Some functions may not be available, depending on the file type.
View favourite
documents.
View and manage
documents online.
Browse folders.
Browse by document
formats.
Create a document.
Creating documents
Tap , and then select a document type.
Use the editing toolbar at the top of the screen to edit the document.
To finish, tap
→
, enter a filename, select a folder to save to, and then tap
Save
.
Utilities
79
Reading documents
Tap
Browser
,
Clouds
,
Form type
, or
Favourites
, and then select a file to open.
To start a slideshow, tap .
Tap , and then use one of the following functions:
Document
•
Save as
: Save the document with a different name.
•
PDF export
: Save the document as a PDF file.
•
Find & Replace
: Search for or replace text.
•
Page layout
: Change the layout of pages.
•
Full width view
: View the document contents only, without margins.
•
Zoom
: Change the view size.
•
Reflow text
: Rearrange the text to fit the screen.
•
View Comment
: View comments in the document.
•
TTS
: Read the document via the text-to-speech feature.
•
Print
: Print the document via a USB or Wi-Fi connection. The device is only compatible
with some Samsung printers.
Presentation
•
Save as
: Save the document with a different name.
•
PDF export
: Save the document as a PDF file.
•
Find & Replace
: Search for or replace text.
•
Continuous view
: View slides continuously.
•
Zoom
: Change the view size.
•
Print
: Print the document via a USB or Wi-Fi connection. The device is only compatible
with some Samsung printers.
Utilities
80
Spreadsheet
•
Save as
: Save the document with a different name.
•
Find & Replace
: Search for or replace text.
•
Protect worksheet
: Lock the sheet so that others cannot edit it.
•
Freeze frame
: Keep the selected row in place.
•
Recalculation
: Recalculate the functions on the sheet.
•
Sort
: Sort cells by specific criteria.
•
Filter
: View cells filtered by specific criteria.
•
Zoom
: Change the view size.
•
Print
: Print the document via a USB or Wi-Fi connection. The device is only compatible
with some Samsung printers.
Text
•
Save as
: Save the document with a different name.
•
TTS
: Read the document via the text-to-speech feature.
•
Print
: Print the document via a USB or Wi-Fi connection. The device is only compatible
with some Samsung printers.
Utilities
81
Dropbox
Use this application to save and share files with others via the Dropbox cloud storage. When
you save files to Dropbox, your device automatically syncs with the web server and any other
computers that have Dropbox installed.
Tap
Dropbox
on the Applications screen.
This application may not be available depending on the region or service provider.
When running Dropbox for the first time, tap
Start
to activate it. Follow the on-screen
instructions to complete the setup.
To upload files to Dropbox, tap
→
→
Upload here
→
Photos or videos
or
Other files
.
To open a file in Dropbox, tap , and then select a file. While viewing the file, tap to add it
to the favourites list.
To open favourite files, tap .
Alarm
Use this application to set alarms for important events.
Tap
Alarms
on the Applications screen.
Turn this alarm on or
off.
Utilities
82
Setting alarms
Tap , set a time for the alarm to go off, select days for the alarm to repeat, and then tap
Save
.
•
Snooze
: Set an interval and the number of times for the alarm to repeat after the preset
time.
•
Smart alarm
: Set a time for the alarm to go off before the preset time.
Stopping alarms
Drag outside the large circle to stop an alarm. Drag outside the large circle to repeat
the alarm after a specified length of time.
Deleting alarms
Tap and hold the alarm, and then tap
Delete
.
World Clock
Use this application to check the time of many major cities in the world.
Tap
World Clock
on the Applications screen.
Creating clocks
Tap , enter a city name or select a city from the globe, and then tap .
To apply summer time, tap and hold a clock, and then tap
DST settings
.
Deleting clocks
Tap , select clocks, and then tap
Delete
.
Utilities
83
Calculator
Use this application for simple or complex calculations.
Tap
Calculator
on the Applications screen.
To see calculation history, tap to hide the keypad.
To clear history, tap
→
Clear history
.
To change the character size for history, tap
→
Text size
.
S Voice
Use this application to command the device by voice to send a message, write a memo, and
more.
Tap
S Voice
on the Applications screen.
This application may not be available depending on the region or service provider.
Here are several examples of spoken commands:
•
Open music
•
Launch calculator
•
Call Lulu mobile
•
Dial Lulu work
•
Check schedule
Tips for better voice recognition
•
Speak clearly.
•
Speak in quiet places.
•
Do not use offensive or slang words.
•
Avoid speaking in dialectal accents.
The device may not recognise your commands or may perform unwanted commands
depending on your surroundings or how you speak.
Utilities
84
Google
Use this application to search not only the Internet, but also applications and their contents
on the device as well.
Tap
Google
on the Applications screen.
Searching the device
Tap the search field, and then enter a keyword. Alternatively, tap , speak a keyword, and
then select one of the suggested keywords that appear.
If no results are returned from the applications, the web browser appears, displaying the
search results.
Search scope
To select what applications to search, tap
→
Settings
→
Tablet search
, and then tick the
items to search for.
Google Now
Launch Google search to view Google Now cards that show the current weather, public
transit info, your next appointment, and more when you are most likely to need it.
Join Google Now when opening Google search for the first time. To change Google Now
settings, tap
→
Settings
→
Google Now
.
This feature may not be available depending on the region or service provider.
Utilities
85
Voice Search
Use this application to search webpages by speaking.
Tap
Voice Search
on the Applications screen.
This application may not be available depending on the region or service provider.
Speak a keyword or phrase when
Speak now
appears on the screen. Select one of the
suggested keywords that appear.
My Files
Use this application to access all kinds of files stored in the device, including images, videos,
songs, and sound clips.
Tap
My Files
on the Applications screen.
Select a folder to open it. To go back to the parent folder, tap . To return to the root
directory, tap .
In a folder, use one of the following functions:
•
: Search for files.
•
: Change the view mode.
•
: Create a folder.
•
Time
: Sort files or folders.
Select a file or folder by ticking, and then use one of the following functions:
•
: Copy files or folders to another folder.
•
: Move files or folders to another folder.
•
: Delete files or folders.
•
: Send files to others.
•
→
Rename
: Rename a file or folder.
•
→
Details
: View file or folder details.
Utilities
86
Downloads
Use this application to see what files are downloaded through the applications.
Tap
Downloads
on the Applications screen.
This application may not be available depending on the region or service provider.
To see the files downloaded from the Internet, tap
Internet downloads
, otherwise, tap
Other
downloads
to see the files downloaded from other applications, such as
Email
.
Select a file to open it with an appropriate application.
TripAdvisor
Use this application to get travel information such as destination, flight, or hotel. You can also
book for a room or flight and share your reviews with others.
Tap
TripAdvisor
on the Applications screen.
87
Travel & local
Maps
Use this application to pinpoint the location of the device, search for places, or get directions.
Tap
Maps
on the Applications screen.
This application may not be available depending on the region or service provider.
Searching for locations
Tap
Search Maps
, enter an address, and then tap . Select a location to view the detailed
location information. To search for nearby locations, tap .
Once the location is found, tap and use one of the following functions:
•
Clear Map
: Clear the map.
•
Make available offline
: Save the map of a specified area to view it offline.
•
Latitude
: Share location information with friends.
•
My Places
: View search history.
•
Settings
: Change the map settings.
•
Help
: View information about using the map.
To view current location, tap .
To zoom in or out the map, spread two fingers apart on the screen to zoom in, and pinch to
zoom out.
Travel & local
88
Getting directions for a destination
1 Tap .
2 Tap , and then select a method to enter starting and ending locations:
•
My current location
: Use current location for starting location.
•
Contacts
: Select from the contacts list.
•
Point on map
: Pinpoint by tapping on the map.
•
My Places
: Select from the list of favourite places.
3 Select a travel method, such as driving, public transit, or walking, and then tap
Go
.
4 Select one of the routes that appear.
Local
Use this application to search for nearby restaurants, banks, bus stops, and more.
Tap
Local
on the Applications screen.
This application may not be available depending on the region or service provider.
Select a place category, and then select a place from the list of search results.
•
Map
: Pinpoint the place on the map.
•
Directions
: Search for a route to the place.
•
Call
: Call the place’s phone number.
To add a place category, tap
→
Add a search
on the category list, enter a keyword to
search into the text field.
Travel & local
89
Navigation
Use this application to search for a route to a destination.
Tap
Navigation
on the Applications screen.
•
Navigation maps, your current location, and other navigational data may differ
from actual location information. You should always pay attention to road
conditions, traffic, and any other factors that may affect your driving. Follow all
safety warnings and regulations while driving.
•
This application may not be available depending on the region or service provider.
Specify the destination by using one of the following methods:
•
Speak the destination address.
•
Enter the destination address.
•
Select the destination address from the contacts list.
•
Select the destination from the list of starred places.
Once a route is found, follow on-screen instructions to navigate to the destination.
90
Settings
About Settings
Use this application to configure the device, set application options, and add accounts.
Tap
Settings
on the Applications screen.
Wi-Fi
Activate the Wi-Fi feature to connect to a Wi-Fi network and access the Internet or other
network devices.
To use options, tap .
•
Advanced
: Customise Wi-Fi settings.
•
WPS push button
: Connect to a secured Wi-Fi network with a WPS button.
•
WPS PIN entry
: Connect to a secured Wi-Fi network with a WPS PIN.
Setting Wi-Fi sleep policy
On the Settings screen, tap
Wi-Fi
→
→
Advanced
→
Keep Wi-Fi on during sleep
.
When the screen is turned off, the device automatically turns off Wi-Fi connections.
When this happens, the device automatically accesses data networks if it is set to use
them. This may incur data transfer fees. To avoid data-usage bills, set this option to
Always
.
Setting Network notification
The device can detect open Wi-Fi networks and display an icon on the status bar to notify
when available.
On the Settings screen, tap
Wi-Fi
→
→
Advanced
and tick
Network notification
to
activate this feature.
Settings
91
Bluetooth
Activate the Bluetooth feature to exchange information over short distances.
Data usage
Keep track of your data usage amount, and customise the settings for the limitation.
•
Mobile data
: Set the device to use data connections on any mobile network.
•
Set mobile data limit
: Set a limit for the mobile data usage.
•
Data usage cycle
: Enter monthly reset date to monitor your data usage.
To use more options, tap .
•
Data roaming
: Set the device to use data connections when you are roaming.
•
Restrict background data
: Set the device to disable sync in the background while using
a mobile network.
•
Auto sync data
: Set the device to sync contact, calendar, email, bookmark, and social
network image data automatically.
•
Show Wi-Fi usage
: Set the device to show your data usage via Wi-Fi.
•
Mobile hotspots
: Search for and use another device’s mobile network.
Settings
92
More settings
Customise settings to control connections with other devices or networks.
Flight mode
This disables all wireless functions on your device. You can use only non-network services.
Mobile networks
•
Mobile data
: Use to allow packet switching data networks for network services.
•
Data roaming
: Use the device to connect to another network when you are roaming or
your home network is not available.
•
Access Point Names
: Set up access point names (APNs).
•
Network mode
: Select a network type.
•
Network operators
: Search for available networks and select a network for roaming.
Tethering and portable hotspot
•
Portable Wi-Fi hotspot
: Use the portable Wi-Fi hotspot to share the device’s mobile
network connection with computers or other devices through the Wi-Fi network.
•
USB tethering
: Use USB tethering to share the device’s mobile network connection with
a computer via USB. When connected to a computer, the device is used as a wireless
modem for the computer.
•
Bluetooth tethering
: Use the Bluetooth tethering to share the device’s mobile network
connection with other devices via Bluetooth.
•
Help
: Learn more about USB, Wi-Fi, and Bluetooth tethering.
VPN
Set up and connect to virtual private networks (VPNs).
Settings
93
Nearby devices
•
File sharing
: Activate media sharing to allow other DLNA-enabled devices to access
media files on your device.
•
Shared contents
: Set the device to share your content with other devices.
•
Device name
: Enter a media server name for your device.
•
Allowed devices list
: View the list of devices that can access your device.
•
Not-allowed devices list
: View the list of devices that are blocked from accessing your
device.
•
Download to
: Select a memory location for saving media files.
•
Upload from other devices
: Set the device to accept uploads from other devices.
Kies via Wi-Fi
Connect the device to Samsung Kies via a Wi-Fi network.
Blocking mode
Select which notifications will be blocked or set to allow notifications for calls from specified
contacts in blocking mode.
Settings
94
Sound
Change settings for various sounds on the device.
•
Volume
: Adjust the volume level for music and videos, system sounds, and notifications.
•
Ringtone
: Select a ringtone to alert you to incoming calls and notifications.
•
Vibration
: Add or select a vibration pattern.
•
Notifications
: Select a ringtone for events, such as incoming messages and alarms.
•
Vibrate when ringing
: Set the device to vibrate and play a ringtone for incoming calls.
•
Dialling keypad tone
: Set the device to sound when tapping the buttons on the keypad.
•
Touch sounds
: Set the device to sound when selecting an application or option on the
touch screen.
•
Screen lock sound
: Set the device to sound when locking or unlocking the touch screen.
•
My sound
: Personalise the sound for ear you use most during calls or while listening to
music.
Display
Change the settings for the display.
•
Wallpaper
:
–
Home screen
: Select a background image for the Home screen.
–
Lock screen
: Select a background image for the locked screen.
–
Home and lock screens
: Select a background image for the Home screen and the
locked screen.
•
Notification panel
: Customise the items that appear on the quick setting panel.
Settings
95
•
Screen mode
:
–
Dynamic
: Use this mode to make the display tone more vivid.
–
Standard
: Use this mode for normal surroundings.
–
Movie
: Use this mode for dim surroundings, such as in a dark room.
•
Brightness
: Set the brightness of the display.
•
Screen timeout
: Set the length of time the device waits before turning off the display’s
backlight.
•
Daydream
: Set the device to launch a screensaver when docking or charging.
•
Smart rotation
: Set the interface not to rotate according to the orientation of your face.
•
Font style
: Change the font type for display text.
•
Font size
: Change the font size.
•
Touch key light duration
: Set the duration for the touch button backlight.
•
Display battery percentage
: Set the device to display the remaining battery life.
•
Edit after screen capture
: Set the device to edit the screenshot after capturing it.
Storage
View memory information for your device and memory card, or format a memory card.
Formatting a memory card permanently deletes all data from it.
The actual available capacity of the internal memory is less than the specified
capacity because the operating system and default applications occupy part of the
memory.
Settings
96
Power saving mode
Activate power-saving mode and change the settings for power-saving mode.
•
CPU power saving
: Set the device to limit some system resource usage.
•
Screen power saving
: Set the device to decrease the brightness of the display.
•
Learn about Power saving mode
: Discover how to reduce battery consumption.
Battery
View the amount of battery power consumed by your device.
Application manager
View and manage the applications on your device.
Location services
Change settings for location information permissions.
•
Access to my location
: Set this to allow applications to use location information.
•
Use GPS satellites
: Set the device to use the GPS satellite for finding the current location.
•
Wi-Fi & mobile network location
: Set the device to allow location data collection and to
determine the location of your lost or stolen device via Wi-Fi or mobile network.
Settings
97
Lock screen
Change settings for the locked screen.
•
Screen lock
: Activate the screen lock feature.
•
Lock screen widget options
: Change the settings for the locked screen. These settings
are applied only when you set the swipe lock option.
–
Clock
: Set the device to show the clock on the locked screen.
–
Dual clock
: Set the device to show the dual clock on the locked screen.
•
Ripple effect
: Set the device to show the ripple effect on the locked screen.
•
Help text
: Set the device to show the help text on the locked screen.
•
Wake up in lock screen
: Set the device to recognise your wake up command when the
screen is locked.
•
Set wake-up command
: Set a wake up command to launch
S Voice
or perform a
specified function.
•
Owner information
: Enter your information that is shown on the locked screen.
Security
Change settings for securing the device.
•
Encrypt device
: Set a password to encrypt data saved on the device. You must enter the
password each time you turn on the device.
Charge the battery before enabling this setting because it may take more than an
hour to encrypt your data.
•
Encrypt external SD card
:
–
Encrypt
: Set the device to encrypt files when you save them to a memory card.
–
Full encryption
: Set the device to encrypt all files on a memory card.
–
Exclude multimedia files
: Set the device to encrypt all files on a memory card, except
for media files.
If you reset your device to the factory defaults with this setting enabled, the device
will not be able to read your encrypted files. Disable this setting before resetting the
device.
Settings
98
•
Remote controls
: Set the device to allow control of your lost or stolen device remotely
via the Internet. To use this feature, you must sign in to your Samsung and Google
accounts.
–
Add account
: Add or view your Samsung account.
–
Wi-Fi & mobile network location
: Set the device to allow location data collection and
to determine the location of your lost or stolen device via Wi-Fi and mobile networks.
•
SIM Change Alert
: Activate or deactivate the Find my mobile feature which helps locate
the device when lost or stolen.
•
Find my mobile web page
: Access the SamsungDive website (
www.samsungdive.com
).
You can track and control your lost or stolen device on the SamsungDive website.
•
Set up SIM card lock
:
–
Lock SIM card
: Activate or deactivate the PIN lock feature to require the PIN before
using the device.
–
Change SIM PIN
: Change the PIN used to access SIM or USIM data.
•
Make passwords visible
: By default, the device hides passwords for security. Set the
device to display passwords as they are entered.
•
Device administrators
: View device administrators installed on the device. You can allow
device administrators to apply new policies to the device.
•
Unknown sources
: Choose to install applications from any source. If not chosen,
download applications only from
Play Store
.
•
Verify apps
: Set this to allow Google to check the application for harmful behaviour
before installing it.
•
Trusted credentials
: Use certificates and credentials to ensure secure use of various
applications.
•
Install from device storage
: Install encrypted certificates stored on the USB storage.
•
Clear credentials
: Erase the credential contents from the device and reset the password.
Settings
99
Language and input
Change the settings for text input. Some options may not be available depending on the
selected language.
Language
Select a display language for all menus and applications.
Default
Select a default keyboard type for text input.
Google voice typing
To change the voice input settings, tap .
•
Choose input languages
: Select input languages for text input.
•
Block offensive words
: Set the device to prevent the device from recognising offensive
words in voice inputs.
Samsung keyboard
To change the Samsung keyboard settings, tap .
The available options may vary depending on the region or service provider.
•
Input languages
: Select languages for text input.
•
Predictive text
: Activate predictive text mode to predict words based on your input and
show word suggestions. You can also customise the word prediction settings.
•
Continuous input
: Set the device to enter text by sweeping on the keyboard.
•
Handwriting
: Customise settings for handwriting mode, such as recognition time, pen
thickness, or pen colour.
Settings
100
•
Advanced
:
–
Auto capitalisation
: Set the device to automatically capitalise the first character after
a final punctuation mark, such as a full stop, question mark, or exclamation mark.
–
Auto spacing
: Set the device to automatically insert a space between words.
–
Auto-punctuate
: Set the device to insert a full stop when you double-tap the space
bar.
–
Character preview
: Set the device to display a large image of each character tapped.
–
Key-tap sound
: Set the device to sound when a key is touched.
•
Tutorial
: Learn how to enter text with the Samsung keyboard.
•
Reset settings
: Reset Samsung keyboard settings.
Voice search
•
Language
: Select a language for the voice recognition.
•
Speech output
: Set the device to provide voice feedback to alert you to the current
action.
•
Block offensive words
: Hide offensive words from voice search results.
Text-to-speech output
•
Preferred TTS engine
: Select a speech synthesis engine. To change the settings for
speech synthesis engines, tap .
•
Speech rate
: Select a speed for the text-to-speech feature.
•
Listen to an example
: Listen to the spoken text for an example.
Settings
101
Driving mode
Activate driving mode to set the device to read contents aloud and specify applications to
use in driving mode.
Pointer speed
Adjust the pointer speed for the mouse or trackpad connected to your device.
Backup and reset
Change the settings for managing settings and data.
•
Back up my data
: Set the device to back up settings and application data to the Google
server.
•
Backup account
: Set up or edit your Google backup account.
•
Automatic restore
: Set the device to restore settings and application data when the
applications are reinstalled on the device.
•
Factory data reset
: Reset settings to the factory default values and delete all data.
Add account
Add email or SNS accounts.
Voice control
Change settings to control options by voice commands.
Settings
102
Accessory
Change the accessory settings.
•
Dock sound
: Set the device to play a sound when your device is connected to or
removed from a desktop dock.
•
Audio output mode
: Set the device to use the dock speaker when your device is
connected to a desktop dock.
•
Audio output
: Select a sound output format to use when connecting your device to
HDMI devices. Some devices may not support the surround sound setting.
Date and time
Access and alter the following settings to control how the device displays the time and date.
If the battery remains fully discharged or removed from the device, the time and date
is reset.
•
Automatic date and time
: Automatically update the time and date when moving across
time zones.
•
Set date
: Set the current date manually.
•
Set time
: Set the current time manually.
•
Automatic time zone
: Set the device to receive time zone information from the network
when you move across time zones.
•
Select time zone
: Set the home time zone.
•
Use 24-hour format
: Display time in 24-hour format.
•
Select date format
: Select a date format.
Settings
103
Accessibility
Accessibility services are special features for those with certain physical disabilities. Access
and alert the following settings to improve accessibility to the device.
•
Auto-rotate screen
: Set the interface to rotate automatically when you rotate the device.
•
Screen timeout
: Set the length of time the device waits before turning off the display’s
backlight.
•
Speak passwords
: Set the device to read aloud passwords you enter with Talkback.
•
Answering/ending calls
:
–
The home key answers calls
: Set the device to answer an incoming call when
pressing the Home button.
–
Answer calls with the accept call button
: Set the device to answer an incoming call
when tapping the call accept button twice.
–
The power key ends calls
: Set the device to end a call when pressing the Power
button.
•
Add shortcut
: Add a shortcut to
Accessibility
on the quick menu that appears when you
press and hold the Power button.
•
TalkBack
: Activate Talkback, which provides voice feedback.
•
Font size
: Change the font size.
•
Magnification gestures
: Set this to zoom in and out with finger gestures.
•
Negative colours
: Reverse the display colours to improve visibility.
•
Accessibility shortcut
: Set the device to activate Talkback when you press and hold the
Power button, and then tap and hold the screen with two fingers.
Settings
104
•
Text-to-speech output
:
–
Preferred TTS engine
: Select a speech synthesis engine. To change the settings for
speech synthesis engines, tap .
–
Speech rate
: Select a speed for the text-to-speech feature.
–
Listen to an example
: Listen to the spoken text for an example.
•
Enhance web accessibility
: Set applications to install web scripts to make their web
content more accessible.
•
Sound balance
: Adjust the sound balance when using a dual headset.
•
Mono audio
: Enable mono sound when listening to audio with one earbud.
•
Turn off all sounds
: Mute all device sounds.
•
Tap & hold delay
: Set the recognition time for tapping and holding the screen.
Developer options
Change the settings for application development.
•
Take bug report
: Collect information on the device and send it via email.
•
Desktop backup password
: Set a password to secure your backup data.
•
Stay awake
: Set the screen to remain on while you are charging the battery.
•
Protect SD card
: Set the device to request a confirmation when reading data from a
memory card.
•
USB debugging
: Activate USB debugging mode to connect your device to a computer
with a USB cable.
•
Power menu bug reports
: Set the device to display the bug reporting option on the
device’s power menu.
Settings
105
•
Allow mock locations
: Allow mock locations and service information to be sent to a
Location Manager service for testing.
•
Select debug app
: Select applications to debug and prevent errors when you pause
debugging.
•
Wait for debugger
: Set the device to prevent the selected application from loading until
the debugger is ready.
•
Verify apps over USB
: Set the device to check the application for harmful behaviour
before installing it.
•
Show touches
: Set the device to show the pointer when you touch the screen.
•
Show pointer location
: Set the device to show the coordinates and traces of the pointer
when you touch the screen.
•
Show layout boundaries
: Set the device to show boundaries.
•
Show GPU view updates
: Set the device to flash areas of the screen when they are
updated with the GPU.
•
Show hardware layers updates
: Set the device to flash areas of the screen when
hardware layers updates.
•
Show GPU overdraw
: Set the device to paint areas of the screen in different colours to
indicate where overdraw occurs.
•
Show screen updates
: Set the device to flash areas of the screen when they are updated.
•
Window animation scale
: Select a speed for opening and closing pop-up windows.
•
Transition animation scale
: Select a speed for switching between screens.
•
Animator duration scale
: Select how long pop-up windows will be shown.
•
Disable hardware overlays
: Set the device to hide hardware overlays.
Settings
106
•
Force GPU rendering
: Set the device to use 2D hardware acceleration to improve graphic
performance.
•
Enale 4x MSAA
: Set the device to enable 4x multisample anti-aliasing (MSAA) in OpenGL
applications to improve image quality.
•
Simulate secondary displays
: Set the device to show one or more overlay windows.
•
Strict mode
: Set the device to flash the screen when applications perform long
operations.
•
Show CPU usage
: Set the device to list all active processes.
•
Profile GPU rendering
: Set the device to check the time of GPU rendering time.
•
Enable OpenGL traces
: Set the device to capture traces of OpenGL application activity.
•
Enable traces
: Set the device to capture traces of application and system performance.
•
Do not keep activities
: Set the device to end a running application when you launch a
new application.
•
Limit background processes
: Set the device to limit the number of processes that can
run in the background.
•
Show all ANRs
: Set the device to alert you to unresponsive applications that are running
in the background.
About device
Access device information and update device software.
107
Troubleshooting
When you turn on your device or while you are using the device, it
prompts you to enter one of the following codes:
•
Password: When the device lock feature is enabled, you must enter the password you set
for the device.
•
PIN: When using the device for the first time or when the PIN requirement is enabled, you
must enter the PIN supplied with the SIM or USIM card. You can disable this feature by
using the Lock SIM card menu.
•
PUK: Your SIM or USIM card is blocked, usually as a result of entering your PIN incorrectly
several times. You must enter the PUK supplied by your service provider.
•
PIN2: When you access a menu requiring the PIN2, you must enter the PIN2 supplied with
the SIM or USIM card. For details, contact your service provider.
Your device displays network or service error messages
•
When you are in areas with weak signals or poor reception, you may lose reception. Move
to another area and try again.
•
You cannot access some options without a subscription. Contact your service provider for
more details.
The touch screen responds slowly or improperly
If your device has a touch screen and the touch screen is not responding properly, try the
following:
•
Remove any protective covers from the touch screen. Protective covers may prevent the
device from recognising your inputs and are not recommended for touch screen devices.
•
Ensure that your hands are clean and dry when tapping the touch screen.
•
Restart your device to clear any temporary software bugs.
•
Ensure that your device software is upgraded to the latest version.
•
If the touch screen is scratched or damaged, take it to your local Samsung Service Centre.
Troubleshooting
108
Your device freezes or has fatal errors
If your device freezes or hangs, you may need to close programs or reset the device to regain
functionality. If your device is frozen and unresponsive, press and hold the Power button for
8-10 seconds. The device reboots automatically.
If this does not solve the problem, perform a factory data reset. On the Applications
screen, tap
Settings
→
Backup and reset
→
Factory data reset
→
Reset device
→
Erase
everything
.
Calls are being dropped
When you are in areas with weak signals or poor reception, you may lose your connection to
the network. Move to another area and try again.
Outgoing calls are not connected
•
Ensure that you have pressed the Dial key.
•
Ensure that you have accessed the right cellular network.
•
Ensure that you have not set call barring for the phone number you are dialling.
Incoming calls are not connected
•
Ensure that your device is turned on.
•
Ensure that you have accessed the right cellular network.
•
Ensure that you have not set call barring for the incoming phone number.
Others cannot hear you speaking on a call
•
Ensure that you are not covering the built-in microphone.
•
Ensure that the microphone is close to your mouth.
•
If using a headset, ensure that it is properly connected.
Troubleshooting
109
Audio quality is poor
•
Ensure that you are not blocking the device’s internal antenna.
•
When you are in areas with weak signals or poor reception, you may lose reception. Move
to another area and try again.
When dialling from contacts, the call is not connected
•
Ensure that the correct number is stored in the contact list.
•
Re-enter and save the number, if necessary.
•
Ensure that you have not set call barring for the contact’s phone number.
The device beeps and the battery icon is empty
Your battery is low. Recharge or replace the battery to continue using the device.
The battery does not charge properly or the device turns off
•
The battery terminals may be dirty. Wipe both gold-coloured contacts with a clean, soft
cloth and try charging the battery again.
•
If the battery no longer charges completely, dispose of the old battery properly
and replace it with a new battery (refer to your local ordinances for proper disposal
instructions).
Your device is hot to the touch
When you use applications that require more power or use applications on your device for an
extended period of time, your device may feel hot to the touch. This is normal and should not
affect your device’s lifespan or performance.
Troubleshooting
110
Error messages appear when launching the camera
Your Samsung device must have sufficient available memory and battery power to operate
the camera application. If you receive error messages when launching the camera, try the
following:
•
Charge the battery or replace it with a battery that is fully charged.
•
Free some memory by transferring files to a computer or deleting files from your device.
•
Restart the device. If you are still having trouble with the camera application after trying
these tips, contact a Samsung Service Centre.
Error messages appear when opening music files
Some music files may not play on your Samsung device for a variety of reasons. If you receive
error messages when opening music files on your device, try the following:
•
Free some memory by transferring files to a computer or deleting files from your device.
•
Ensure that the music file is not Digital Rights Management (DRM)-protected. If the file is
DRM-protected, ensure that you have the appropriate licence or key to play the file.
•
Ensure that your device supports the file type.
Another Bluetooth device is not located
•
Ensure that the Bluetooth wireless feature is activated on your device.
•
Ensure that the Bluetooth wireless feature is activated on the device you wish to connect
to, if necessary.
•
Ensure that your device and the other Bluetooth device are within the maximum
Bluetooth range (10 m).
If the tips above do not solve the problem, contact a Samsung Service Centre.
Troubleshooting
111
A connection is not established when you connect the device to a
computer
•
Ensure that the USB cable you are using is compatible with your device.
•
Ensure that you have the proper drivers installed and updated on your computer.
•
If you are a Windows XP user, ensure that you have Windows XP Service Pack 3 or higher
installed on your computer.
•
Ensure that you have Samsung Kies 2.0 or Windows Media Player 10 or higher installed
on your computer.
A small gap appears around the outside of the device case
•
This gap is a necessary manufacturing feature and some minor rocking or vibration of
parts may occur.
•
Over time, friction between parts may cause this gap to expand slightly.
FCC Notice and Cautions
FCC Notice
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
The device may cause TV or radio interference if used in close proximity to
receiving equipment. The FCC can require you to stop using the device if such
interference cannot be eliminated. Vehicles using petroleum gas (such as
propane or butane) must comply with the National Fire Protection Standard
(NFPA-58). For a copy of this standard, contact the National Fire Protection
Association, One Battery march Park, Quincy, MA 02269, Attn: Publication Sales
Division.
Cautions
Changes or modifications made in the radio device, not expressly approved by
Samsung, will void the user’s authority to operate the equipment.
The use of any unauthorized accessories may be dangerous and void the device
warranty if said accessories cause damage or a defect to the device. Although
your device is quite sturdy, it is a complex piece of equipment and can be broken.
Avoid dropping, hitting, bending or sitting on it.
This device is capable of operating in 802.11a/n mode. For 802.11a/n devices operating in the
frequency range of 5.15 - 5.25 GHz, they are restricted for indoor operations to reduce any
potential harmful interference for Mobile Satellite Services (MSS) in the US. WIFI Access
Points that are capable of allowing your device to operate in 802.11a/n mode (5.15 - 5.25 GHz
band) are optimized for indoor use only. If your WIFI network is capable of operating in this
mode, please restrict your WIFI use indoors to not violate federal regulations to protect
Mobile Satellite Services.
