Users Manual
Code No.: DE68-00172A
Microwave Oven
Owner’s Manual
ME1260SA
Start
Pause
Cancel
Popcorn Beverage
Potato
Bacon
Frozen
Dinner
Baby
Food
Frozen
Breakfast
Boil
Water
Fresh
Vegetables Frozen
Vegetables
Pizza
Reheat Soften
Ice Cream
Help Clock
One
Minute
+
1.
Melt Chocolate
2.
Soften Cream Cheese
3.
Melt Butter
1.
Chicken Nuggets
2.
Hot Dogs
3.
French Fries
4.
Frozen Sandwich
1.
Nachos
2.
Chicken Wings
3.
Potato Skins
4.
C
heese Sticks
Handy
Helper Snack
Bar
Kids
Meals
Auto
Defrost Auto
Reheat
1.Plate of Food
2.Casserole
3.Pasta Reheat
123
456
8
79
0
Power
Level Kitchen
Timer
Less
More
XGt~XW]WzhihzhUGGwGXGGtSGzGXWSGYWWXGGXYa\ZGwt
2
S
AVE
T
HESE
I
NSTRUCTIONS
Safety
P
RECAUTIONS TO
A
VOID
P
OSSIBLE
E
XPOSURE TO
E
XCESSIVE
M
ICROWAVE
E
NERGY
:
(a) Do not attempt to operate this oven with the door open
since open-door operation can result in harmful exposure to
microwave energy. It is important not to defeat or tamper
with the safety interlocks.
(b) Do not place any object between the front face of the oven
and the door or allow soil or cleaner residue to accumulate
on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly
important that the oven door close properly and that there is
no damage to the
1) Door (bent or dented),
2) Hinges and latches (broken or loosened),
3) Door seals and sealing surfaces.
(d) The oven should not be adjusted or repaired by anyone
except properly qualified service personnel.
WARNING
Always observe Safety Precautions when using your
oven. Never try to repair the oven on your own – there
is dangerous voltage inside. If the oven needs to be
repaired, call 1-800-SAMSUNG for the name of an
authorized service center near you.
I
MPORTANT
S
AFETY
I
NSTRUCTIONS
When using any electrical appliance, basic safety precautions
should be followed, including the following:
WARNING
To reduce risk of burns, electric shock, fire, personal
injury or exposure to excessive microwave energy:
• Read all safety instructions before using the appliance.
• Read and follow the specific “
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE ENERGY
” on this page.
• This appliance must be grounded. Connect only to properly grounded
outlets. See “
IMPORTANT GROUNDING INSTRUCTIONS
” on page
4 of this manual.
• Install or place this appliance only in accordance with the installation
instructions provided.
• Some items, like whole eggs and food in sealed containers, may
explode if heated in this oven.
• Use this appliance only for its intended use as described in the
manual. Do not use corrosive chemicals or vapors in this appliance.
This type of oven is specifically designed to heat, cook, or dry food. It
is not designed for industrial or laboratory use.
• As with any appliance, close supervision is necessary when used by
children.
• Do not operate this appliance if it has a damaged cord or plug, if it is
not working properly, or if it has been damaged.
• This appliance should be serviced only by qualified service
personnel. Contact the nearest authorized service facility for
examination, repair, or adjustment.
• Do not cover or block any of the openings on this appliance.
XGt~XW]WzhihzhUGGwGYGGtSGzGXWSGYWWXGGXYa\ZGwt
3
S
AVE
T
HESE
I
NSTRUCTIONS
Safety
Important Safety Instructions, continued
• Do not store this appliance outdoors. Do not use near water – for
example, near a kitchen sink, in a wet basement, or near a swimming
pool, etc.
• Keep the inside of the oven clean. Food particles or spattered oils
stuck to the oven walls or floor can cause paint damage and reduce
the efficiency of the oven.
• Do not immerse cord or plug in water.
• Keep cord away from heated surfaces.
• Do not let cord hang over edge of table or counter.
• When cleaning door and oven surfaces, use only mild, nonabrasive
soaps or detergents applied with a sponge or soft cloth.
• To reduce the risk of fire in the oven:
a. Do not overcook food. Watch appliance carefully if paper, plastic,
or other combustible materials are inside.
b. Remove wire twist-ties from plastic cooking bags before placing
bags in oven.
c. If materials inside the oven ignite, keep the oven door closed, turn
the oven off, disconnect the power cord, or shut off the power at
the fuse or circuit breaker panel.
d. Do not use the oven compartment for storage purposes. Do not
leave paper products, cooking utensils, or food in the oven when
not in use.
• Do not try to preheat oven or operate while empty.
• Do not cook without the glass tray in place on the oven floor. Food will
not cook properly without the tray.
• Do not defrost frozen beverages in narrow-necked bottles. The
containers can break.
• Dishes and containers can become hot. Handle with care.
• Carefully remove container coverings, directing steam away from
hands and face.
• Remove lids from baby food before heating. After heating baby food,
stir well and test temperature by tasting before serving.
• A short power-supply cord is provided to reduce the risk of becoming
entangled in or tripping over a longer cord. Longer cord sets or
extension cords are available and may be used with caution.
• Do not operate any other heating or cooking appliance beneath this
appliance.
• Do not mount unit over or near any portion of a heating or cooking
appliance.
• Do not mount over a sink.
• Do not store anything directly on top of the appliance when it is in
operation.
• If materials inside oven should ignite, keep the oven door closed, turn
the oven off and disconnect the power cord, or shut off power at the
fuse or circuit breaker panel. If the door is opened, the fire may
spread.
XGt~XW]WzhihzhUGGwGZGGtSGzGXWSGYWWXGGXYa\ZGwt
4
S
AVE
T
HESE
I
NSTRUCTIONS
Safety
I
MPORTANT
G
ROUNDING
I
NSTRUCTIONS
This appliance must be grounded. In the event of an electrical
short circuit, grounding reduces the risk of electric shock by
providing an escape wire for the electrical current. This
appliance is equipped with a cord that includes a grounding wire
and a grounding plug. The plug must be plugged into an outlet
that is properly installed and grounded. Plug the three-prong
power cord into a properly grounded outlet of standard 115-120
voltage, 60 Hz. Your oven should be the only appliance on this
circuit.
WARNING
Improper use of the grounding plug can result in a risk
of electric shock. Consult a qualified electrician or
servicer if you do not understand the grounding
instructions or if you are not sure if the appliance is
properly grounded.
Use of Extension Cords
A short power-supply cord is provided to reduce the risk of
becoming entangled in or tripping over a longer cord. Longer
cord sets or extension cords are available and may be used if
care is exercised in their use. If a long cord or extension cord is
used:
1. The marked electrical rating of the cord set or extension cord should
be at least as great as the electrical rating of the appliance.
2. The extension cord must be a grounding-type 3-wire cord and it must
be plugged into a 3-slot outlet.
3. The longer cord should be arranged so that it will not drape over the
counter top or tabletop where it can be pulled on by children or
tripped over accidentally. If you use an extension cord, the interior
light may flicker and the blower may vary when the microwave oven
is on. Cooking times may be longer, too.
WARNING
Do not cut or remove the third (ground) prong from the
power cord under any circumstances.
Note
Connect the oven to a 20A circuit . When connecting
the oven to a 15A circuit, make sure that circuit
breaker is operable.
XGt~XW]WzhihzhUGGwG[GGtSGzGXWSGYWWXGGXYa\ZGwt
5
Your New Microwave oven
Table of Contents
Safety........................................................................................... 2
Your New Microwave oven ........................................................ 5
Checking Parts.......................................................................... 5
Warranty and Service Information............................................. 6
Setting Up Your Microwave Oven .............................................6
Control Panel Buttons ............................................................... 7
Operation..................................................................................... 8
Setting the Clock....................................................................... 8
Using the Pause/Cancel Button ................................................ 8
Using the Help Button ...............................................................8
Using the One Minute + Button................................................. 8
Using the Instant Cook Buttons................................................. 8
Reheating Automatically ......................................................... 10
Defrosting Automatically .........................................................11
Using the Handy Helper Button ...............................................11
Using the Kids Meals Button................................................... 12
Using the Snack Bar Button ....................................................12
Setting Cooking Times & Power Levels ..................................13
Using the More/Less Buttons ..................................................14
Using the Kitchen Timer ..........................................................14
Cooking Instructions................................................................ 15
Cooking Utensils ..................................................................... 15
Testing Utensils....................................................................... 15
Cooking Techniques ............................................................... 16
General Tips ............................................................................16
Cooking Guide ........................................................................ 17
Auto Defrosting Guide............................................................. 19
Recipes ................................................................................... 20
Appendix ................................................................................... 22
Troubleshooting Guide............................................................ 22
Care and Cleaning .................................................................. 22
Specifications.......................................................................... 23
Warranty.................................................................................... 24
Warranty Information............................................................... 24
Guíd de Consulta Rápida en Español..................................... 26
Quick Reference ....................................................... Back Cover
Checking Parts
Unpack your microwave oven and check to make sure that you have all
the parts shown here. If any part is missing or broken, call your dealer.
Start
Pause
Cancel
Popcorn Beverage
Potato
Bacon
Frozen
Dinner
Baby
Food
Frozen
Breakfast
Boil
Water
Fresh
Vegetables Frozen
Vegetables
Pizza
Reheat Soften
Ice Cream
Help Clock
One
Minute
+
1.
Melt Chocolate
2.
Soften Cream Cheese
3.
Melt Butter
1.
Chicken Nuggets
2.
Hot Dogs
3.
French Fries
4.
Frozen Sandwich
1.
Nachos
2.
Chicken Wings
3.
Potato Skins
4.
C
heese Sticks
Handy
Helper Snack
Bar
Kids
Meals
Auto
Defrost Auto
Reheat
1.Plate of Food
2.Casserole
3.Pasta Reheat
123
456
8
79
0
Power
Level Kitchen
Timer
Less
More
microwave oven
glass tray
roller guide ring instruction manual
registration card
XGt~XW]WzhihzhUGGwG\GGtSGzGXWSGYWWXGGXYa\ZGwt
6
Your New Microwave oven
Warranty and Service Information
To help us better serve you, please complete the enclosed registration
card and promptly return it by mail. If the registration card is missing, you
can call Samsung Electronics America, Inc., at 1-800- SAMSUNG
(1-800-726-7864), or register on-line at WWW.SAMSUNGUSA.COM
When contacting Samsung, please provide the specific model and serial
number information which is usually located on the back or bottom of the
product. Please record these numbers below, along with the other
requested information. Keep this information in a safe place as a perma-
nent record of your purchase to aid in identification in case of theft or
loss, and a copy of your sales receipt as a proof of purchase if warranty
service is needed.
MODEL NUMBER ____________________
SERIAL NUMBER ____________________
DATE PURCHASED ____________________
PURCHASED FROM ____________________
Warranty service can only be performed by a Samsung Authorized
Service Center. If you should require warranty service, provide the
above information with a copy of your sales receipt to the Samsung
Authorized Service Center.
For service assistance and the location of the nearest service center,
please call 1-800-SAMSUNG (1-800-726-7864), or go on-line to
WWW.SAMSUNGSUPPORT.COM
Setting Up Your Microwave Oven
1Place the oven on a flat, sturdy surface and plug the cord into a
grounded outlet. Once plugged in, the display on your oven will
show;
Make sure there is adequate ventilation for your oven by leaving at
least four inches of space behind, above, and to the sides of the
oven.
2Open the oven door by pressing the button below the control panel.
3Wipe the inside of the oven with a damp cloth.
4Place the pre-assembled ring in the indentation in the center of the
oven.
5Place the glass tray on top of the ring so that the three glass tabs in
the center of the tray fit securely into the tabs on the floor of the
oven.
MICRO BROIL AMPM CONV. COMBO. HELP POWER
XGt~XW]WzhihzhUGGwG]GGtSGzGXWSGYWWXGGXYa\ZGwt
7
Your New Microwave oven
Control Panel Buttons 1. Help p.8
Press to see help information about the feature you are using.
2. Clock p.8
Sets current time.
3. One Minute + p.8
Press once for every minute of cooking at High power.
4. Instant Cook Buttons p.8
Instant settings to cook popular foods.
5. Handy Helper, Kids Meals, Snack Bar p.11
Selects type of dish to be reheated.
6. Auto Defrost p.11
Sets weight of food to be defrosted.
7. Auto Reheat p.10
Selects type of dish to be reheated.
8. Number Buttons
Set cooking times or amounts and power levels other than high.
9. More/Less p.14
Increase or decrease cooking time.
10. Power Level p.13
Press this pad to set a power level other than high.
11. Kitchen Timer p.14
Sets kitchen or convenience timer.
12. Pause/Cancel p.8
Press to pause oven or correct a mistake.
13. Start
Press to start cooking.
Start
Pause
Cancel
Popcorn Beverage
Potato
Bacon
Frozen
Dinner
Baby
Food
Frozen
Breakfast
Boil
Water
Fresh
Vegetables Frozen
Vegetables
Pizza
Reheat Soften
Ice Cream
Help Clock
One
Minute
+
1.
Melt Chocolate
2.
Soften Cream Cheese
3.
Melt Butter
1.
Chicken Nuggets
2.
Hot Dogs
3.
French Fries
4.
Frozen Sandwich
1.
Nachos
2.
Chicken Wings
3.
Potato Skins
4.
C
heese Sticks
Handy
Helper Snack
Bar
Kids
Meals
Auto
Defrost Auto
Reheat
1.Plate of Food
2.Casserole
3.Pasta Reheat
123
456
8
79
0
Power
Level Kitchen
Timer
Less
More
1
4
5
6
8
10
12
23
7
11
13
9
XGt~XW]WzhihzhUGGwG^GGtSGzGXWSGYWWXGGXYa\ZGwt
8
Operation
Setting the Clock
1Press the Clock button. The display will show:
2Use the Number buttons to enter the current time. You must press
at least three numbers to set the clock. For example, if the current
time is 5:00, enter 5,0,0.
3Press Clock again. A colon will appear, indicating that the time is
set.
If there is a power interruption, you will need to reset the clock.
You can check the current time while cooking is in progress by
pressing the Clock button.
Using the Pause/Cancel Button
The Pause/Cancel button allows you to clear instructions you have
entered. It also allows you to pause the oven’s cooking cycle, so that
you can check the food.
•To pause the oven during cooking : press Pause/Cancel once. To
restart, press Start.
•To stop cooking, erase instructions, and return the oven display to
the time of day: Press Pause/Cancel twice.
•To clear instructions you have just entered: press Pause/Cancel
once, then re-enter the instructions.
•To cancel a timer setting: press Pause/Cancel once.
Using the Help Button
Your microwave offers helpful instructions for many procedures.
1When you need feature information and helpful hints, press the
Help button and then press the button that you want to get
information on.
Using the One Minute + Button
This button offers a convenient way to heat food in one minute incre-
ments at the High power level.
1Press the One Minute+ button once for each minute you wish to
cook the food. For example, press it twice for two minutes. The time
will display, and the oven starts automatically.
Add minutes to a program in progress by pressing the
One Minute+ button for each minute you want to add.
Using the Instant Cook Buttons
1Press the Instant Cook button corresponding to the food you are
cooking (Bacon, for example). The display will show: (BACON 2
SLICES):
2Press the button repeatedly to select the serving size you want.
The display will cycle through all available serving sizes. Once you
select the correct serving size, the microwave will begin cooking
automatically.
If you don’t need to read all the menu options, simply press the
Start button to begin cooking.
If you want to check the cooking time, press the Instant Cook
button.
When the cooking times are over, the oven will beep. The oven will
then beep every minute.
XGt~XW]WzhihzhUGGwG_GGtSGzGXWSGYWWXGGXYa\ZGwt
9
Operation
Instant Cook Chart
Item Weight Remarks
Popcorn Butter
(3.5 oz),
Light
(3.0-3.5 oz)
•Use one microwave-only bag of popcorn. Pop
only one bag at a time.
•Use caution when removing and opening hot
bag from oven.
Potato 1 EA, 2 EA
3 EA, 4 EA
5 EA, 6 EA
•Prick each potato several times with fork.
•Place on turntable in spoke-like fashion.
•Remove from oven, wrap in foil and let stand
3-5 min.
Beverage ½ cup
1 cup
2 cups
•Use measuring cup or mug; do not cover.
•Place the beverage in the oven.
•After heating, stir well.
Boil water ½ cup
1 cup
2 cups
•Measure liquid; pour into microwave-safe
container that is 2 times larger than amount of
liquid. Example: For 1 cup liquid use a 2 cup or
larger dish.
•Stir well before and after heating to prevent boil
over.
Fresh
vegetables 1 serving
2 servings
3 servings
4 servings
•Place the vegetables into a casserole
bowl and add a small amount of water (2-
4Tbsp).
•Cover during cooking and stir before
standing.
Frozen
vegetables 1 serving
2 servings
3 servings
4 servings
•Remove from package.
•Place the vegetables into a casserole
bowl and add a small amount of water (2-
4Tbsp).
•Cover during cooking and stir before
standing.
Frozen
breakfast 2-4 oz
4-6 oz
6-8 oz
•Remove package from outer wrapping
and follow package instructions for
covering and standing.
•After cooking, let stand 1-3 min.
Frozen
dinner 7-10 oz
10-12 oz
12-14 oz
•Remove package from outer wrapping and
follow package instructions for covering and
standing.
•After cooking, let stand 1-3 min.
Pizza
reheat 1 Slice
2 Slices
3 Slices
4 Slices
•Put the pizza on a microwave-safe plate
with wide end of slice towards the outside
edge of the plate.
•Do not let slices overlap. Do not cover.
•Before serving, let stand 1-2 min.
Bacon 2 Slices
4 Slices
6 Slices
•Place 2 paper towels on plate and arrange
bacon on towels, do not overlap. Cover
with additional paper towel. Remove
paper towel immediately after cooking.
•Use More or Less button for desired
crispness.
Baby food 2.5 oz
4 oz
6 oz
•Remove lid from baby food and place in
the center of oven.
•Check temperature and stir well before
serving.
•The More/Less key cannot be used with
the baby food key.
Soften ice
cream 1 pint
½ gallon •Remove top of carton. Place carton in
center of microwave oven.
•Let stand 2 min. after microwaving.
XGt~XW]WzhihzhUGGwG`GGtSGzGXWSGYWWXGGXYa\ZGwt
10
Operation
Reheating Automatically
To reheat food, select the type of dish and the number of servings you
want to reheat, and the microwave automatically sets the reheating time.
1Press the Auto Reheat button repeatedly to select the type of dish
you wish to reheat. The initial serving size for each dish is one
serving.
You can select up to four servings for casseroles and pasta
reheat. Only one serving is available for a plate of food.
2Use the Number buttons to increase the serving size.
For example, for three servings, press the“3” button(Refer to
the Auto Reheat Chart to the right for the servings). The display
shows the number of servings you have selected:
3Press the Start button. The display will show;
If you want to check the cooking time, press the Auto Reheat
button.
Auto Reheat Chart
MICRO
Item Weight Remarks
Plate of
food 1 serving •Use only pre-cooked, refrigerated
foods.
•Cover plate with vented plastic wrap
or wax paper.
•Contents
- 3-4 oz. meat, poultry or fish ( up to
6 oz. with bone)
- ½ cup starch (potatoes, pasta,
rice, etc.)
- ½ cup vegetables (about 3-4 oz.)
Casserole 1 to 4 servings
(8 oz./serving) •Use only refrigerated foods.
•Cover with lid or vented plastic
wrap.
•Stir foods well before serving.
Pasta
Reheat 1 to 4 servings
(8 oz./serving)
XGt~XW]WzhihzhUGGwGXWGGtSGzGXWSGYWWXGGXYa\ZGwt
11
Operation
Defrosting Automatically
To thaw frozen food, set the weight of the food and the microwave auto-
matically sets the defrosting time, power level and standing time.
1Press the Auto Defrost button. The display shows “0.5 LB”.
2To set the weight of your food, press the Auto Defrost button
repeatedly. This increases the weight by 0.5 lb increments, up to
6.0 lbs. You can also use the number buttons to enter the weight of
the food directly. The oven calculates the defrosting time and starts
automatically. Twice during defrosting, the oven will beep and the
display will read “TURN THE FOOD OVER”.
3Press the Pause/Cancel button, open the oven door, and turn the
food over.
4Press the Start button to resume defrosting.
• See page 19 for the Auto Defrosting Guide
Using the Handy Helper Button
1. Press the Handy Helper button corresponding to the food you are
cooking. The display shows “Melt Chocolate”.
Press the Handy Helper button repeatedly to select the item you
want.(Refer to the Handy Helper Chart below)
2. Press the number button to select the serving size you want. You
can press the “1” or “2” button to select the serving size. Only the
“1” button(serving) is available for Soften Cream Cheese and Melt
Chocolate items.(Refer to the Handy Helper Chart below for the
serving)
3. Press the Start button to begin cooking.
Handy Helper Chart
Note:
Melt chocolate
- Unless stirred at half time, the
Chocolate keeps its shape even when heating time is
over.
MICRO
Item Weight Remarks
Melt
Chocolate 2 squares
or 1 cup
chips
•Place chocolate chips or square in a
microwave-safe dish.
•Stir well at half time when the oven
beeps, and re-start the oven.
Soften Cream
Cheese 1
package
(8 oz.)
•Unwrap cream cheese and place on
microwave-safe dish.
•Let stand 1-2 min.
Melt Butter 1 stick
(1/4 lb.)
2 sticks
(1/2 lb.)
•Remove wrapping and cut butter in half
vertically.
•Place butter in dish, cover with wax
paper.
•Stir well after finishing and let stand 1-2
min.
XGt~XW]WzhihzhUGGwGXXGGtSGzGXWSGYWWXGGXYa\ZGwt
12
Operation
Using the Kids Meals Button
1. Press the Kids Meals button corresponding to the food you are
cooking. The display shows “Chicken Nuggets”.
Press the Kids Meals button repeatedly to select the item you
want.(Refer to the Kids Meals Chart below)
2. Press the Number button to select the serving size you want. You
can press the “1” or “2” button to select the serving size.(Refer to
the Kids Meals Chart below for the serving.)
3. Press the Start button to begin cooking.
Kids Meals Chart
Note
Hot Dogs
- For the best texture of buns should be
added to hot dogs when the oven beeps.
Using the Snack Bar Button
1. Press the Snack Bar button corresponding to the food you are
cooking. The display shows “Nachos” .
Press the Snack Bar button repeatedly to select the item you
want.(Refer to the Snack Bar Chart below)
2. Press the Number button to select the serving size you want.
You can press the “1” or “2” button to select the serving size.
Only the “1” button(serving) is available for Nachos.
(Refer to the Snack Bar Chart below for the serving)
3. Press the Start button to begin cooking.
Snack Bar Chart
Item Weight Remarks
Chicken
Nuggets 4-5 oz
6-7 oz •Put a paper towel on top of plate and
arrange nuggets in spoke fashion on paper
towel.
•Do not cover. Let stand 1 min.
Hot Dogs 2 EA
4 EA •Prick hot dogs, place on plate. When the
oven beeps, add buns and re-start the oven.
French Fries 4-5 oz
6-7 oz •Place 2 paper towels on plate and arrange
french fries on towels, do not overlap.
•Blot with additional paper towel after
removal from oven.
Frozen
Sandwich 1 EA
2 EA •Place frozen sandwich in susceptor "sleeve"
(which is in package) and put on plate.
Item Weight Remarks
Nachos 1 serving •Place tortilla chips on plate without
overlapping.
•Sprinkle evenly with cheese.
•Contents :
- 2 cups tortilla chips
- 1/3 cup grated cheese
Chicken Wings 5-6 oz
7-8 oz •Use pre-cooked, refrigerated chicken
wings.
•Place chicken wings around plate in
spoke fashion and cover with wax paper.
Potato Skins 1 cooked
potato
2 cooked
potatoes
•Cut cooked potato into 4 even wedges.
Scoop or cut out potato flesh, leaving
about 1/4" of skin.
•Place skins in spoke fashion around
plate.
•Sprinkle with bacon, onions and cheese.
Do not cover.
Cheese Sticks 5-6 pcs
7-10 pcs •Place cheese sticks on plate in spoke
fashion.
•Do not cover.
XGt~XW]WzhihzhUGGwGXYGGtSGzGXWSGYWWXGGXYa\ZGwt
13
Operation
Setting Cooking Times & Power Levels
Your microwave allows you to set up to three different stages of cooking,
each with its own time length and power level. The power level lets you
control the heating intensity from Warm (1) to High (0).
One-stage Cooking
For simple one-stage cooking, you only need to set a cooking time. The
power level is automatically set at High. If you want the power set at any
other level, you must set it using the Power Level button.
1Use the Number buttons to set a cooking time. You can set a time
from one second to 99 minutes, 99 seconds. To set a time over one
minute, enter the seconds too.
For example, to set 20 minutes, enter 2, 0, 0, 0 .
2If you want to set the power level to something other than High,
press the Power Level button, then use the number buttons to
enter a power level.
Power Levels:
1 = Warm 6 = Simmer
2 = Low 7 = Medium High
3 = Defrost 8 = Reheat
4 = Medium Low 9 = Sauté
5 = Medium 0 = High
The display shows “PRESS START OR ENTER NEXT STAGE
COOKING TIME”.
3Press the Start button to begin cooking. If you want to change the
power level, press Pause/Cancel before you press Start, and
reenter all of the instructions.
Setting Cooking Times, continued
Some recipes require different stages of cooking at different tempera-
tures. You can set multiple stages of cooking with your microwave.
Multi-stage Cooking
1Follow steps 1 and 2 in the “One-Stage Cooking” section on this
page. The display shows “PRESS START OR ENTER NEXT
STAGE COOKING TIME”.
When entering more than one cooking stage, the Power Level
button must be pressed before the second cooking stage can be
entered.
To set the power level at High for a stage of cooking, press the
Power Level button twice.
2Use the Number buttons to set a second cooking time.
3Press the Power Level button, then use the number buttons to set
the power level of the second stage of cooking. The display shows
the power level you have set and then “PRESS START OR ENTER
NEXT STAGE COOKING TIME.”.
4Press Start to begin cooking, or repeat steps 2 and 3 to set a
cooking time and power level for a third stage of cooking.
When finished, press Start.
XGt~XW]WzhihzhUGGwGXZGGtSGzGXWSGYWWXGGXYa\ZGwt
14
Operation
Using the More/Less Buttons
The More/Less buttons allow you to adjust pre-set cooking times.
They only work in the Auto Reheat, Instant Cook, Handy Helper,
Kids Meals, Snack Bar or Time Cook modes. Use the More/Less but-
ton only after you have already begun cooking with one of these proce-
dures.
1To ADD more time to an automatic cooking procedure: Press the
More(9) button.
2To REDUCE the time of an automatic cooking procedure: Press the
Less(1) button.
If you wish to increase/decrease the cooking time in 10 second
increments in the Time Cook mode, press the More(9) or Less(1)
button.
Using the Kitchen Timer
1Use the Number buttons to set the length of time you want the
timer to run.
2Press the Kitchen Timer button.
3The display counts down and beeps when the time has elapsed.
XGt~XW]WzhihzhUGGwGX[GGtSGzGXWSGYWWXGGXYa\ZGwt
15
Cooking Instructions
Cooking Utensils
Recommended Use
•Glass and glass-ceramic bowls and dishes — Use for heating or
cooking.
•Microwavable browning dish — Use to brown the exterior of small
items such as steaks, chops, or pancakes. Follow the directions
provided with your browning dish.
•Microwavable plastic wrap — Use to retain steam. Leave a small
opening for some steam to escape and avoid placing it directly on
the food.
•Wax paper — Use as a cover to prevent spattering.
•Paper towels and napkins — Use for short-term heating and
covering; they absorb excess moisture and prevent spattering. Do
not use recycled paper towels, which may contain metal and can
catch fire.
•Paper plates and cups — Use for short-term heating at low
temperatures. Do not use recycled paper, which may contain metal
and can catch fire.
•Thermometers — Use only those labeled “Microwave Safe” and
follow all directions. Check the food in several places. Conventional
thermometers may be used once the food has been removed from
the oven.
Limited Use
•Aluminum foil — Use narrow strips of foil to prevent overcooking of
exposed areas. Using too much foil can damage your oven, so be
careful.
•Ceramic, porcelain, and stoneware — Use these if they are
labeled “Microwave Safe”. If they are not labeled, test them to make
sure they can be used safely. Never use dishes with metallic trim.
•Plastic — Use only if labeled “Microwave Safe”. Other plastics can
melt.
•Straw, wicker, and wood — Use only for short-term heating, as
they can be flammable.
Not Recommended
•Glass jars and bottles — Regular glass is too thin to be used in a
microwave, and can shatter.
•Paper bags — These are a fire hazard, except for popcorn bags that
are designed for microwave use.
•Styrofoam plates and cups — These can melt and leave an
unhealthy residue on food.
•Plastic storage and food containers — Containers such as
margarine tubs can melt in the microwave.
•Metal utensils — These can damage your oven. Remove all metal
before cooking.
Testing Utensils
If you are not sure whether a dish is microwave-safe or not, you can per-
form this test:
1Fill a 1 cup glass measuring cup with water and put it inside your
oven, next to the dish you want to test.
2Press the One Minute + button once to heat them for one minute at
High power.
The water should be warm and the dish you are testing should be cool. If
the dish is warm, then it is absorbing microwave energy and is not
acceptable for use in the microwave.
XGt~XW]WzhihzhUGGwGX\GGtSGzGXWSGYWWXGGXYa\ZGwt
16
Cooking Instructions
Cooking Techniques
Stirring
Stir foods such as casseroles and vegetables while cooking to distribute
heat evenly. Food at the outside of the dish absorbs more energy and
heats more quickly, so stir from the outside to the center. The oven will
turn off when you open the door to stir your food.
Arrangement
Arrange unevenly shaped foods, such as chicken pieces or chops, with
the thicker, meatier parts toward the outside of the turntable where they
receive more microwave energy. To prevent overcooking, place thin or
delicate parts toward the center of the turntable.
Shielding
Shield food with narrow strips of aluminum foil to prevent overcooking.
Areas that need shielding include poultry wing-tips, the ends of poultry
legs, and corners of square baking dishes. Use only small amounts of
aluminum foil. Larger amounts can damage your oven.
Turning
Turn foods over midway through cooking to expose all parts to micro-
wave energy. This is especially important with large items such as
roasts.
Standing
Foods cooked in the microwave build up internal heat and continue to
cook for a few minutes after the oven stops. Let foods stand to complete
cooking, especially foods such as roasts and whole vegetables. Roasts
need this time to complete cooking in the center without overcooking the
outer areas. All liquids, such as soup or hot chocolate, should be shaken
or stirred when cooking is complete. Let liquids stand a moment before
serving. When heating baby food, stir well and test the temperature
before serving.
Adding Moisture
Microwave energy is attracted to water molecules. Food that is uneven
in moisture content should be covered or allowed to stand so that the
heat disperses evenly. Add a small amount of water to dry food to help it
cook.
General Tips
•Dense foods, such as potatoes, take longer to heat than lighter
foods. Foods with a delicate texture should be heated at a low power
level to avoid becoming tough.
•Altitude and the type of cookware you are using can affect cooking
time. When using a new recipe, use the minimum cooking time and
check the food occasionally to prevent overcooking.
•Foods with a non-porous skin such as potatoes or hot dogs, should
be pierced to prevent bursting.
•Frying with heating oil or fat is not recommended. Fat and oil can
suddenly boil over and cause severe burns.
•Some ingredients heat faster than others. For example, the jelly
inside a jelly doughnut will be hotter than the dough. Keep this in
mind to avoid burns.
•Home canning in the microwave oven is not recommended because
all harmful bacteria may not be destroyed by the microwave heating
process.
•Although microwaves do not heat the cookware, the heat from the
food is often transferred to the cookware. Always use pot holders
when removing food from the microwave and instruct children to do
the same.
•Making candy in the microwave is not recommended as candy can
heat to very high temperatures. Keep this in mind to avoid injury.
XGt~XW]WzhihzhUGGwGX]GGtSGzGXWSGYWWXGGXYa\ZGwt
17
Cooking Instructions
Cooking Guide
Guide for Cooking Meat in Your Microwave
•Place meat on a microwave-safe roasting rack in a microwave-safe
dish.
•Start meat fat-side down. Use narrow strips of aluminum foil to shield
any bone tips or thin meat areas.
•Check the temperature in several places before letting the meat
stand the recommended time.
•The following temperatures are removal temperatures. The
temperature of the food will rise during the standing time.
Guide for Cooking Poultry in Your Microwave
•Place poultry on a microwave-safe roasting rack in a microwave-safe
dish.
•Cover poultry with wax paper to prevent spattering.
•Use aluminum foil to shield bone tips, thin meat areas, or areas that
start to overcook.
•Check the temperature in several places before letting the poultry
stand the recommended time.
Food Cook Time/Power Level Directions
Roast
Beef
Boneless
Up to 4 lbs.
Cooking Time:
7-11 min. / lb. for 115° F -
Rare
8-12 min. / lb. for 120° F -
Medium
9-14 min. / lb. for 145° F -
Well Done
Power Level: High(0) for
first 5 min., then
Medium(5).
Place roast fat-side down on
roasting rack. Cover with wax
paper. Turn over when
cooking time is half up. Let
stand 10 min.
Pork
Boneless
or bone-in
Up to 4 lbs.
Cooking Time:
11-15 min. / lb. for 160° F
Well Done
Power Level: High(0) for
first 5 min., then
Medium(5).
Place roast fat-side down on
roasting rack. Cover with
vented plastic wrap. Turn
over when cooking time is
half up. Let stand 10 min.
Food Cook Time/Power Level Directions
Whole
Chicken
Up to 4 lbs.
Cooking Time:
6-9 min. / lb.180°F
Power Level: Medium
High(7).
Place chicken breast-side
down on roasting rack. Cover
with wax paper. Turn over
when the cooking time is half
up. Cook until juices run clear
and meat near the bone is no
longer pink. Let stand 5-10
min.
Chicken
Pieces
Up to 2 lbs.
Cooking Time:
6-9 min. / lb.
180°F dark meat
170°F light meat
Power Level: Medium
High(7).
Place chicken bone-side
down on dish, with the
thickest portions towards the
outside of the dish. Cover
with wax paper. Turn over
when the cooking time is half
up. Cook until juices run clear
and meat near the bone is no
longer pink. Let stand 5-10
min.
XGt~XW]WzhihzhUGGwGX^GGtSGzGXWSGYWWXGGXYa\ZGwt
18
Cooking Instructions
Guide for Cooking Seafood in Your Microwave
•Cook fish until it flakes easily with a fork.
•Place fish on a microwave-safe roasting rack in a microwave-safe
dish.
•Use a tight cover to steam fish. A lighter cover of wax paper or paper
towel provides less steaming.
•Do not overcook fish; check it at minimum cooking time.
Guide for Cooking Eggs in Your Microwave
•Never cook eggs in the shell, and never warm hard-cooked eggs in
the shell; they can explode.
•Always pierce whole eggs to keep them from bursting.
•Cook eggs just until set; they become tough if overcooked.
Guide for Cooking Vegetables in Your Microwave
•Vegetables should be washed just before cooking. Often, no extra
water is needed. If dense vegetables such as potatoes, carrots and
green beans are being cooked, add about ¼ cup water.
•Small vegetables (sliced carrots, peas, lima beans, etc.) will cook
faster than larger ones.
•Whole vegetables, such as potatoes, acorn squash or corn on the
cob, should be arranged in a circle on the turntable before cooking.
They will cook more evenly if turned over after half the cooking time.
•Always place vegetables like asparagus and broccoli with the stem
ends pointing towards the edge of the dish and the tips toward the
center.
•When cooking cut vegetables, always cover the dish with a lid or
vented microwavable plastic wrap.
•Whole, unpeeled vegetables such as potatoes, squash, eggplant,
etc., should have their skin pricked in several spots before cooking to
prevent them from bursting.
•For more even cooking, stir or rearrange whole vegetables halfway
through the cooking time.
•Generally, the denser the food, the longer the standing time.
(Standing time refers to the time necessary for dense, large foods
and vegetables to finish cooking after they come out of the oven.) A
baked potato can stand on the counter for five minutes before
cooking is completed, while a dish of peas can be served
immediately.
Food Cook Time/Power
Level Directions
Steaks
Up to 1.5 lbs.
Cooking Time:
6-10 min. / lb.
Power Level: Medium-
High(7).
Arrange steaks on roasting
rack with meaty portions
towards the outside of rack.
Cover with wax paper. Turn
over and rearrange when
cooking time is half up. Cook
until fish flakes easily with a
fork. Let stand 3-5 min.
Fillets
Up to 1.5 lbs.
Cooking Time:
3-7 min. / lb
Power Level: Medium-
High(7).
Arrange fillets in a baking
dish, turning any thin pieces
under Cover with wax paper.
If over ½ inch thick, turn over
and rearrange when cooking
time is half up. Cook until
fish flakes easily with a fork.
Let stand 2-3 min.
Shrimp
Up to 1.5 lbs.
Cooking Time:
3-5 ½ min. / lb.
Power Level: Medium-
High(7).
Arrange shrimp in a baking
dish without overlapping or
layering. Cover with wax
paper. Cook until firm and
opaque, stirring 2 or 3 times.
Let stand 5 min.
XGt~XW]WzhihzhUGGwGX_GGtSGzGXWSGYWWXGGXYa\ZGwt
19
Cooking Instructions
Auto Defrosting Guide
•Follow the instructions below when defrosting different types of food.
Notes
Check foods when the oven signals. After the final stage, small sections
may still be icy; let them stand to continue thawing. Do not defrost until
all ice crystals have thawed. Shielding roasts and steaks with small
pieces of foil prevents the edges from cooking before the center of the
food has defrosted. Use narrow, flat, smooth strips of aluminum foil to
cover the edges and thinner sections of the food.
Food Standard
Amount Procedure
Roast
Beef, Pork 2.5-6.0 lbs. Start with the food placed fat side down.
After each stage, turn the food over and
shield any warm portions with narrow
strips of aluminum foil.
Steaks,
Chops,
Fish
0.5-3.0 lbs. After each stage, rearrange the food. If
there are any warm or thawed portions of
food, shield them with narrow flat pieces
of aluminum foil. Remove any pieces of
food that are nearly defrosted. Let stand,
covered, for 5-10 minutes.
Ground
Meat 0.5-3.0 lbs. After each stage, remove any pieces of
food that are nearly defrosted. Let stand,
covered with foil, for 5–10 minutes.
Whole
Chicken 2.5-6.0 lbs. Remove giblets before freezing poultry.
Start defrosting with the breast side
down. After the first stage, turn the
chicken over and shield any warm
portions with narrow strips of aluminum
foil. After the second stage, again shield
any warm portions with narrow strips of
aluminum foil. Let stand, covered, for
30–60 minutes in the refrigerator.
Chicken
Pieces 0.5-3.0 lbs. After each stage, rearrange or remove
any pieces of food that are nearly
defrosted. Let stand for 10-20 minutes.
XGt~XW]WzhihzhUGGwGX`GGtSGzGXWSGYWWXGGXYa\ZGwt
20
Cooking Instructions
Recipes
Beef and Barley Stew
1½ lbs. beef stew cubes, cut into ½-inch pieces
½ cup chopped onion
2 Tbs. all-purpose flour
1 Tbs Worcestershire sauce
1 can (13.75-14.5 oz.) beef broth
2 medium carrots, cut into ½-inch slices (about 1 cup)
½ cup barley
1 bay leaf
¼ tsp. pepper
1 pkg. (9-10 oz.) frozen peas, thawed
1. In a 2-quart casserole, combine beef, onion, flour, and
Worcestershire; mix well. Cover with lid. Cook at High for 6 to 8
minutes until beef is no longer pink, stirring once.
2. Stir in beef broth, carrots, barley, bay leaf, and pepper. Cover with
lid. Cook at Medium for 1 to 1½ hours until carrots and beef are
tender, stirring 2 to 3 times.
3. Stir in peas. Cover with lid. Cook at Medium for 10 minutes. Let
stand for 10 minutes. Remove bay leaf before serving. Makes 6
servings.
Broccoli and Cheese Casserole
¼ cup butter or margarine
¼ cup chopped onion
1½ Tbs. flour
½ tsp. salt
¼ tsp. dry mustard
1/8 tsp. pepper
1½ cups milk
¼ cup chopped red pepper
8 oz. (2 cups) cheddar cheese, shredded
1 pkg. (9-10 oz.) frozen chopped broccoli, thawed
4 cups cooked spiral shaped pasta (8 oz. dry)
1. In a 2-quart casserole, cook butter and onion at High for 1 to 2
minutes until onion is soft, stirring once.
2. Add flour, salt, mustard, and pepper; mix well. Cook at High for 30 to
60 seconds until mixture boils. Stir in milk until smooth.
3. Stir in red pepper. Cook at High for 2 to 3 minutes until mixture boils
and thickens slightly, stirring twice. Stir in cheese until melted.
4. Add broccoli and pasta, mix well. Cover with lid. Cook at High for 4 to
6 minutes until heated through, stirring once. Stir before serving.
Makes 6 servings.
XGt~XW]WzhihzhUGGwGYWGGtSGzGXWSGYWWXGGXYa\ZGwt
21
Cooking Instructions
Warm Potato Salad
2 lbs. small red potatoes, cut into ½-inch pieces
4 slices bacon (uncooked), cut into ½-inch pieces
¼ cup chopped onion
2 tsp. sugar
1 tsp. salt
1 tsp. flour
½ tsp. celery seed
1/8 tsp. pepper
2½ Tbs. apple cider vinegar
1. In a 2-quart casserole, combine potatoes and ¼ cup water. Cover
with lid. Cook at High until potatoes are tender (7-10 min.); stir twice.
Drain and set aside to cool slightly.
2. In a medium bowl, cook bacon at High until crisp (2½-3½ min.); stir
once. Place bacon on a paper towel. Reserve 1 Tbs. drippings.
3. Combine drippings and onion. Cover with plastic wrap; turn back a
corner to vent steam. Cook at High until tender (1½-2½ min.); stir
once.
4. Stir in sugar, salt, flour, celery seed, and pepper. Cook at High until
mixture boils (30-40 sec.). Stir in vinegar and ½ cup water. Cook at
High until liquid boils and thickens slightly (1-2 min.); stir once. Add
bacon to dressing. Pour dressing over potatoes. Stir well.
Makes 6 servings.
Black Bean Soup
1 cup chopped onion
1 clove garlic, minced
2 cans (15 oz. each) black beans, drained
1 can (14-16 oz.) stewed tomatoes, chopped
1 can (13.75-14.5 oz.) chicken broth
1 can (7-8.5 oz.) corn
1 can (4 oz.) chopped green chilies
1-2 tsp. ground cumin, or to taste
1. Place onion and garlic in a 3-quart casserole. Cover with lid. Cook at
High for 2 to 4 minutes until tender.
2. Add one can of beans, mash beans with a fork. Add remaining
ingredients; mix well.
3. Cook uncovered, at High for 10 minutes; stir. Reduce power to
Medium and cook for 5 minutes. Stir before serving.
Makes about 2 quarts.
XGt~XW]WzhihzhUGGwGYXGGtSGzGXWSGYWWXGGXYa\ZGwt
22
Appendix
Troubleshooting Guide
Before you call a repair person for your oven, check this list of possible
problems and solutions.
Neither the oven’s display nor the oven operate.
•Properly insert the plug into a grounded outlet.
•If the outlet is controlled by a wall switch, make sure the wall switch
is turned on.
•Remove the plug from the outlet, wait ten seconds, then plug it in
again.
•Reset the circuit breaker or replace any blown fuse.
•Plug another appliance into the outlet; if the other appliance doesn’t
work, have a qualified electrician repair the outlet.
•Plug the oven into a different outlet.
The oven’s display works, but the power won’t come
on.
•Make sure the door is closed securely.
•Check to see if packing material or other material is stuck to the door
seal.
•Check for door damage.
•Press Cancel twice and re-enter all cooking instructions.
The power goes off before the set time has elapsed.
•If there has not been a power outage, remove the plug from the
outlet, wait ten seconds, then plug it in again. If there was a power
outage, the time indicator will display “ ” Reset the clock and
any cooking instructions.
•Reset the circuit breaker or replace any blown fuse.
The food is cooking too slowly.
•Make sure the oven is on its own 20 amp circuit line. Operating
another appliance on the same circuit can cause a voltage drop. If
necessary, move the oven to its own circuit.
You see sparks or arcing.
•Remove any metallic utensils, cookware, or metal ties. If using foil,
use only narrow strips and allow at least one inch between the foil
and interior oven walls.
The turntable makes noises or sticks.
•Clean the turntable, roller ring and oven floor.
•Make sure the turntable and roller ring are positioned correctly.
Using your microwave causes TV or radio interference.
•This is similar to the interference caused by other small appliances,
such as hair dryers. Move your microwave further away from other
appliances, like your TV or radio.
Care and Cleaning
Follow these instructions to clean and care for your oven.
•Keep the inside of the oven clean. Food particles and spilled liquids
can stick to the oven walls, causing the oven to work less efficiently.
•Wipe up spills immediately. Use a damp cloth and mild soap. Do not
use harsh detergents or abrasives.
•To help loosen baked on food particles or liquids, heat two cups of
water (add the juice of one lemon if you desire to keep the oven
fresh) in a four-cup measuring glass at High power for five minutes
or until boiling. Let stand in the oven for one or two minutes.
•Remove the glass tray from the oven when cleaning the oven or tray.
To prevent the tray from breaking, handle it carefully and do not put it
in water immediately after cooking. Wash the tray carefully in warm
sudsy water or in the dishwasher.
•Clean the outside surface of the oven with soap and a damp cloth.
Dry with a soft cloth. To prevent damage to the operating parts of the
oven, don’t let water seep into the openings.
•Wash the door window with very mild soap and water. Be sure to use
a soft cloth to avoid scratching.
•If steam accumulates inside or outside the oven door, wipe with a
soft cloth. Steam can accumulate when operating the oven in high
humidity and in no way indicates microwave leakage.
•Never operate the oven without food in it; this can damage the
magnetron tube or glass tray. You may wish to leave a cup of water
in the oven when it is not in use to prevent damage if the oven is
accidentally turned on.
If you have a problem you cannot solve,
please call our service line:
1-800-SAMSUNG
(1-800-726-7864)
MICRO BROIL AMPM CONV. COMBO. HELP POWER
XGt~XW]WzhihzhUGGwGYYGGtSGzGXWSGYWWXGGXYa\ZGwt
23
Appendix
Specifications
Model Number ME1260SA
Oven Cavity 1.2cuft
Controls 10 power levels, including defrost
Timer 99 minutes, 99 seconds
Power Source 120 VAC, 60 Hz
Power Output 1050 Watts
Outside Dimensions 2019/32”(W) X 1145/64”(H) X 161/4”(D)
Oven Cavity Dimensions 1431/64”(W) X 91/64”(H) X 1519/32”(D)
Net/Gross Weight 33/36 lbs
XGt~XW]WzhihzhUGGwGYZGGtSGzGXWSGYWWXGGXYa\ZGwt
24
Warranty
Warranty Information
SAMSUNG MICROWAVE OVEN
This SAMSUNG brand product, as supplied and distributed by
SAMSUNG ELECTRONICS AMERICA, INC. (SAMSUNG) and
delivered new, in the original carton to the original consumer purchaser,
is warranted by SAMSUNG against manufacturing defects in materials
and workmanship for a limited warranty period of:
One (1) Year Parts and Labor, Eight (8) Years Parts Warranty for Magnetron
This limited warranty begins on the original date of purchase, and is
valid only on products purchased and used in the United States. To
receive warranty service, the purchaser must contact SAMSUNG for
problem determination and service procedures. Warranty service can
only be performed by a SAMSUNG authorized service center. The
original dated bill of sale must be presented upon request as proof of
purchase to SAMSUNG or SAMSUNG’s authorized service center.
Transportation of the product to and from the service center is the
responsibility of the purchaser.
SAMSUNG will repair or replace this product, at our option and at no
charge as stipulated herein, with new or reconditioned parts or products
if found to be defective during the limited warranty period specified
above. All replaced parts and products become the property of
SAMSUNG and must be returned to SAMSUNG. Replacement parts
and products assume the remaining original warranty, or ninety (90)
days, whichever is longer.
This limited warranty covers manufacturing defects in materials and
workmanship encountered in normal, non-commercial use of this
product and shall not apply to the following, including, but not limited to:
damage which occurs in shipment; delivery and installation; applications
and uses for which this product was not intended; altered product or
serial numbers; cosmetic damage or exterior finish; accidents, abuse,
neglect, fire, water, lightning or other acts of nature; use of products,
equipment, systems, utilities, services, parts, supplies, accessories,
applications, installations, repairs, external wiring or connectors not
supplied or authorized by SAMSUNG which damage this product or
result in service problems; incorrect electrical line voltage, fluctuations
and surges; customer adjustments and failure to follow operating
instructions, cleaning, maintenance and environmental instructions that
are covered and prescribed in the instruction book; product removal and
reinstallation; problems caused by pest infestations, and overheating or
overcooking by user; glass tray or turntable; reduced magnetron power
output related to normal aging. SAMSUNG does not warrant
uninterrupted or error-free operation of the product.
THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE
LISTED AND DESCRIBED ABOVE, AND NO WARRANTIES
WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED
TO, ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE, SHALL APPLY AFTER
THE EXPRESS WARRANTY PERIODS STATED ABOVE, AND NO
OTHER EXPRESS WARRANTY OR GUARANTY GIVEN BY ANY
PERSON, FIRM OR CORPORATION WITH RESPECT TO THIS
PRODUCT SHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL
NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS, FAILURE
TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER
SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED
BY THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT,
REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS
BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. NOR SHALL RECOVERY OF
ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN
THE PURCHASE PRICE OF THE PRODUCT SOLD BY SAMSUNG
AND CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING THE
FOREGOING, PURCHASER ASSUMES ALL RISK AND LIABILITY
FOR LOSS, DAMAGE OR INJURY TO PURCHASER AND
PURCHASER’S PROPERTY AND TO OTHERS AND THEIR
PROPERTY ARISING OUT OF THE USE, MISUSE OR INABILITY TO
USE THIS PRODUCT SOLD BY SAMSUNG NOT CAUSED DIRECTLY
BY THE NEGLIGENCE OF SAMSUNG. THIS LIMITED WARRANTY
SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL
PURCHASER OF THIS PRODUCT, IS NONTRANSFERABLE AND
STATES YOUR EXCLUSIVE REMEDY.
Some states do not allow limitations on how long an implied warranty
lasts, or the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to you.
This warranty gives you specific legal rights, and you may also have
other rights which vary from state to state.
To obtain warranty service, please contact: SAMSUNG
ELECTRONICS AMERICA, INC. - WWW.SAMSUNGUSA.COM
SAMSUNG CUSTOMER SERVICE
400 VALLEY ROAD, SUITE 201,
MT. ARLINGTON, NJ 07856
Tel: 973-601-6000, Fax: 973-601-6001
1-800-SAMSUNG (1-800-726-7864)
WWW.SAMSUNGSUPPORT.COM
LIMITED WARRANTY TO ORIGINAL PURCHASER
XGt~XW]WzhihzhUGGwGY[GGtSGzGXWSGYWWXGGXYa\ZGwt
25
Warranty
SAMSUNG ELECTRONICS
Subject to the requirements, conditions, exclusions and limitations of the
Original Limited Warranty supplied with Samsung Electronics (SAM-
SUNG) products, and the requirements, conditions, exclusions and limi-
tations contained herein, SAMSUNG will additionally provide Warranty
Repair Service in the United States on SAMSUNG products purchased
in Canada, and in Canada on SAMSUNG products purchased in the
United States, for the warranty period originally specified, and to the
Original Purchaser only.
The above described warranty repairs must be performed by a SAM-
SUNG Authorized Service Center. Along with this Statement, the Origi-
nal Limited Warranty Statement and a dated Bill of Sale as Proof of
Purchase must be presented to the Service Center. Transportation to
and from the Service Center is the responsibility of the purchaser.
Conditions covered are limited only to manufacturing defects in material
or workmanship, and only those encountered in normal use of the prod-
uct.
Excluded, but not limited to, are any original specified provisions for, in-
home or on-site services, minimum or maximum repair times,
exchanges or replacements, accessories, options, upgrades, or con-
sumables.
For the locations of a SAMSUNG Authorized Service Center in the
United States and Canada, please contact SAMSUNG at:
1-800-SAMSUNG (1-800-726-7864)
Or on-line at:
WWW.SAMSUNGUSA.COM and WWW.SAMSUNGCANADA.COM
Note
NORTH AMERICAN LIMITED WARRANTY ADDENDUM
XGt~XW]WzhihzhUGGwGY\GGtSGzGXWSGYWWXGGXYa\ZGwt
26
Guíd de Consulta Rápida en Español
Usando el Botón PAUSE/CANCEL
•Para pausar mientras está cocinando, oprima una vez al botón
PAUSE/CANCEL.
•Para detener el horno y borrar las instrucciones para cocinar, oprima
dos veces al botón PAUSE/CANCEL.
•Para corregir un error de programación, oprima una vez al botón
PAUSE/CANCEL y vuelva a programr las instrucciones.
•Para cancelar un ajuste del cronómetro, oprima una vez al botón
PAUSE/CANCEL.
Poniendo el Reloj
•Oprima una vez al botón CLOCK.
•Utilice los botones numéricos 0–9 para seleccionar la hora correcta.
•Oprima una vez más al botón CLOCK para fijar la hora.
Ajustando el Tiempo de Concinar y Niveles de
Potencia – Cocinando en una Etapa
•Utilice los botones numéricos 0–9 para ajustar el tiempo de cocinar.
•Oprima el botón POWER LEVEL, y los botones numéricos 0–9 para
seleccionar la potencia de cocinar (si es diferente a 0).
•Oprima el botón START para comenzar a cocinar.
Ajustando el Tiempo de Concinar y Niveles de
Potencia – Cocinando en Etapas Múltiples
•Utilice los botones numéricos 0–9 para ajustar el tiempo de cocinar.
•Oprima el botón POWER LEVEL, y los botones numéricos 0–9 para
seleccionar la potencia de cocinar (si es diferente a 0).
•Utilice los botones numéricos 0–9 para ajustar el segundo tiempo de
cocinar.
•Oprima el botón POWER LEVEL, y los botones numéricos 0–9 para
seleccionar la potencia de cocinar (si es diferente a 0).
•Utilice los botones numéricos 0–9 para ajustar el tercer tiempo de
cocinar.
•Oprima el botón POWER LEVEL, y los botones numéricos 0–9 para
seleccionar la potencia de cocinar (si es diferente a 0).
•Oprima el botón START para comenzar a cocinar.
XGt~XW]WzhihzhUGGwGY]GGtSGzGXWSGYWWXGGXYa\ZGwt
27
Guíd de Consulta Rápida en Español
Descongelado Automático
•Oprima repetidamente al botón AUTO DEFROST para ajustar el
peso correcto de la comida que va descongelar.
Cocinando Con un Bóton
•Oprima el botón ONE MINUTE + una vez para cada minuto que
desea cocinar.
Ajustando el Tiempo de Cocinado
•Si desea ajustar el tiempo de cocinado mientras el horno está en
operación, oprima el botón MORE/LESS repetidamente hasta llegar
al tiempo deseado.
Usando el Cronómetro
•Oprima los botones numéricos 0–9 para ajustar el tiempo, luego
oprima el botón KITCHEN TIMER.
Handy Helper, Kids Meals, Snack Bar
•Presione HANDY HELPER(KIDS MEALS, SNACK BAR)
repetidamente pare seleccionar tipo de platillo.
•Para incrementar tamaño de porción, presione los botones
numéricos.
•Presione START para comenzar.
XGt~XW]WzhihzhUGGwGY^GGtSGzGXWSGYWWXGGXYa\ZGwt
Quick Reference
Feature Operation
Set Clock 1. Press CLOCK.
2. Use number buttons to enter the current time.
3. Press CLOCK again.
One Stage
Cooking 1. Use number buttons to set cooking time.
2. Set power level or leave at High.
3. Press START.
One Minute+
Cooking 1. Press the ONE MINUTE + button once for each
minute of cooking.
2. The time will display and the oven will start.
Instant Cook
Buttons 1. Press button that corresponds to the food you
are cooking (for example, BACON).
2. Press the button repeatedly to select serving
size.
Auto Defrost 1. Press AUTO DEFROST.
2. Enter weight of food by pressing AUTO
DEFROST button repeatedly or using the
number buttons.
3. When the oven beeps, press PAUSE/CANCEL
button and turn food over. Press START to
resume defrosting cycle.
Set Cooking
Time and
Power Levels
1. Use number buttons to set cooking time.
2. To set power level at other than HIGH, press
POWER LEVEL and use the number buttons to
enter the power level.
3. Press START to begin cooking.
Handy Helper,
Kids Meals,
Snack Bar
1. Press HANDY HELPER(KIDS MEALS, SNACK
BAR) repeatedly to select type of dish to reheat.
2. To increase serving size, press the
corresponding number button.
3. Press START to begin cooking.
ELECTRONICS
SAMSUNG ELECTRONICS AMERICA, INC.
HEADQUARTERS
105 CHALLENGER ROAD
RIDGEFIELD PARK, NEW JERSEY 07660-0511
Samsung Electronics Co., Ltd.
September. 2001
Printed in Korea
XGt~XW]WzhihzhUGGwGY_GGtSGzGXWSGYWWXGGXYa\ZGwt
