Samsung Electronics Co MW8584N Microwave Oven User Manual
Samsung Electronics Co Ltd Microwave Oven Users Manual
Users Manual
Microwave
Oven
Owner’s Manual
MW8584W
CODE NO. : DE68-00211A
MW8490W(mini) 9/28/00 4:33 AM Page 1
S
AFETY
2S
AFETY
PRECAUTIONS TO
AVOID POSSIBLE
EXPOSURE TO
EXCESSIVE
MICROWAVE ENERGY
:
(a) Do not attempt to operate this oven
with the door open since open-door
operation can result in harmful
exposure to microwave energy. It is
important not to defeat or tamper with
the safety interlocks.
(b) Do not place any object between the
front face of the oven and the door or
allow soil or cleaner residue to accu-
mulate on sealing surfaces.
(c) Do not operate the oven if it is dam-
aged. It is particularly important that the
oven door close properly and that there
is no damage to the
1) Door (bent or dented),
2) Hinges and latches (broken or
loosened),
3) Door seals and sealing surfaces.
(d) The oven should not be adjusted or
repaired by anyone except properly
qualified service personnel.
WARNING
Always observe Safety Precautions
when using your oven. Never try to
repair the oven on your own – there is
dangerous voltage inside. If the oven
needs to be repaired, call 1-800-SAM-
SUNG for the name of an authorized
service center near you.
IMPORTANT SAFETY
INSTRUCTIONS
WARNING
• Some items, like whole eggs and food in sealed
containers, may explode if heated in this oven.
• Use this appliance only for its intended use as
described in the manual. Do not use corrosive
chemicals or vapors in this appliance. This type
of oven is specifically designed to heat, cook, or
dry food. It is not designed for industrial or labo-
ratory use.
• As with any appliance, close supervision is nec-
essary when used by children.
To reduce risk of burns, electric
shock, fire, personal injury or expo-
sure to excessive microwave energy:
• Read all safety instructions before using the
appliance.
• Read and follow the specific “Precautions to
Avoid Exposure to Excessive Microwave
Energy” on this page.
• This appliance must be grounded. Connect
only to properly grounded outlets. See
“Important Grounding Instructions” on page 4
of this manual.
• Install or place this appliance only in accor
dance with the installation instructions
provided.
SAVE THESE INSTRUCTIONS
When using any electrical appliance,
basic safety precautions should be
followed, including the following:
MW8490W(mini) 9/28/00 4:33 AM Page 2
S
AFETY
3
S
AFETY
Important Safety Instructions,
continued
• Do not operate this appliance if it has a damaged
cord or plug, if it is not working properly, or if it
has been damaged.
• This appliance should be serviced only by quali-
fied service personnel. Contact the nearest autho-
rized service facility for examination, repair, or
adjustment.
• Do not cover or block any of the openings on this
appliance.
• Do not store this appliance outdoors. Do not use
near water – for example, near a kitchen sink, in a
wet basement, or near a swimming pool, etc.
• Keep the inside of the oven clean. Food particles
or spattered oils stuck to the oven walls or floor
can cause paint damage and reduce the efficien-
cy of the oven.
• Do not immerse cord or plug in water.
• Keep cord away from heated surfaces.
• Do not let cord hang over edge of table or
counter.
• When cleaning door and oven surfaces, use only
mild, nonabrasive soaps or detergents applied
with a sponge or soft cloth.
• To reduce the risk of fire in the oven:
a.Do not overcook food. Watch appliance care
fully if paper, plastic, or other combustible
materials are inside.
b. Remove wire twist-ties from plastic cooking bags
before placing bags in oven.
c.If materials inside the oven ignite, keep the
oven door closed, turn the oven off, disconnect
the power cord, or shut off the power at the
fuse or circuit breaker panel.
d.Do not use the oven compartment for storage
purposes. Do not leave paper products, cooking
utensils, or food in the oven when not in use.
• Do not try to preheat oven or operate while empty.
• Do not cook without the glass tray in place on the
oven floor. Food will not cook properly without the
tray.
• Do not defrost frozen beverages in narrow-necked
bottles. The containers can break.
• Dishes and containers can become hot. Handle
with care.
• Carefully remove container coverings, directing
steam away from hands and face.
• Remove lids from bay food before heating. After
heating baby food, stir well and test temperature
by tasting before serving.
• A short power-supply cord is provided to reduce
the risk of becoming entangled in or tripping over
a longer cord. Longer cord sets or extension
cords are available and may be used
with caution.
• Do not operate any other heating or cooking appli-
ance beneath this appliance.
• Do not mount unit over or near any portion of a
heating or cooking appliance.
• Do not mount over a sink.
• Do not store anything directly on top of the appli-
ance when it is in operation.
SAVE THESE INSTRUCTIONS
MW8490W(mini) 9/28/00 4:33 AM Page 3
S
AFETY
4S
AFETY
Important Grounding
Instructions
This appliance must be grounded. In the event of
an electrical short circuit, grounding reduces the
risk of electric shock by providing an escape wire
for the electrical current. This appliance is
equipped with a cord that includes a grounding
wire and a grounding plug. The plug must be
plugged into an outlet that is properly installed and
grounded. Plug the three-prong power cord into a
properly grounded outlet of standard 115-120 volt-
age, 60 Hz. Your oven should be the only appliance
on this circuit.
WARNING
Improper use of the grounding plug can result
in a risk of electric shock. Consult a qualified
electrician or servicer if you do not understand
the grounding instructions or if you are not
sure if the appliance is properly grounded.
Use of Extension Cords
A short power-supply cord is provided to reduce
the risk of becoming entangled in or tripping over
a longer cord. Longer cord sets or extension cords
are available and may be used if care is exercised
in their use. If a long cord or extension cord is
used:
1. The marked electrical rating of the cord set or
extension cord should be at least as great as
the electrical rating of the appliance.
2. The extension cord must be a grounding-type 3-
wire cord and it must be plugged into a 3-slot
outlet.
3. The longer cord should be arranged so that it
will not drape over the counter top or tabletop
where it can be pulled on by children or tripped
over accidentally. If you use an extension cord,
the interior light may flicker and the blower
may vary when the microwave oven is on.
Cooking times may be longer, too.
WARNING
Do not cut or remove the third (ground) prong
from the power cord under any circum-
stances.
SAVE THESE INSTRUCTIONS
MW8490W(mini) 9/28/00 4:33 AM Page 4
C
ONTENTS
5
C
ONTENTS
Your New Microwave Oven . . . . . .6
Checking Parts . . . . . . . . . . . . . . . . . . . .6
Setting Up Your Microwave Oven . . . .6
Control Panel Buttons . . . . . . . . . . . . . .7
Operation . . . . . . . . . . . . . . . . . . . . .8
Turning on the Power and Selecting a
Display Language . . . . . . . . . . . . . . . . . .8
Setting the Clock . . . . . . . . . . . . . . . . . .8
Using the Pause/Cancel Button . . . . . .8
Using the Help System . . . . . . . . . . . . .9
Using the Instant Cook Buttons . . . . . .9
Using the One Minute+ Button . . . . . .10
Using the Gentle Cook Button . . . . . .10
Using the Dual Cook Buttons . . . . . . .10
Setting and Using the Custom Cook
Button . . . . . . . . . . . . . . . . . . . . . . . . . .11
Defrosting Automatically . . . . . . . . . . .11
Reheating Automatically . . . . . . . . . .12
Setting Cooking Times &
Power Levels . . . . . . . . . . . . . . . . . . . .13
One-stage Cooking . . . . . . . . . . . .13
Multi-stage Cooking . . . . . . . . . . .13
Using the More/Less Button . . . . . . . .14
Adjusting the Volume . . . . . . . . . . . . . .14
Using the Kitchen Timer . . . . . . . . . . .15
Setting the Child Protection Lock . . . .15
Demonstration Mode . . . . . . . . . . . . . .15
Cooking Instructions . . . . . . . . . . . .16
Cooking Utensils . . . . . . . . . . . . . . . . . .16
Testing Utensils . . . . . . . . . . . . . . . . . .16
Cooking Techniques . . . . . . . . . . . . . . .17
General Tips . . . . . . . . . . . . . . . . . . . . .17
Cooking Guides . . . . . . . . . . . . . . . .18-19
Defrosting Guide . . . . . . . . . . . . . . . . .20
Recipes . . . . . . . . . . . . . . . . . . . . . . . . .21
Appendix . . . . . . . . . . . . . . . . . . . . .23
Troubleshooting Guide . . . . . . . . . . . . .23
Care and Cleaning . . . . . . . . . . . . . . . .23
Warranty Information . . . . . . . . . . . . .24
Specifications . . . . . . . . . . . . . . . . . . . .24
Guía de Consulta Rápida en
Español . . . . . . . . . . . . . . . . . . . . . .25
Manual Block Warranty Card
. . . . . . . . . . . . . . . . . .Inside Back Cover
Quick Guide . . . . . . . . . . . . .Back Cover
MW8490W(mini) 9/28/00 4:33 AM Page 5
Y
OUR
N
EW
M
ICROWAVE OVEN
6
Y
OUR
N
EW
M
ICROWAVE
O
VEN
Checking Parts
Unpack your microwave oven and check to make
sure that you have all the parts shown here. If any
part is missing or broken, call your dealer.
Thank You for Choosing
Samsung
Your new oven represents the latest in microwave
cooking technology. This oven is a full-featured,
easy-to-use appliance built to strict quality stan-
dards set by Samsung — the highest in the indus-
try. We’re proud to offer you a product that will
provide convenient, dependable service for years
to come.
Please record the serial number from the inside or
back of your Samsung microwave oven and the
date of purchase in the space provided below. We
recommend that you keep your purchase receipt
with this manual for easy warranty service.
Model Number _________________________
Serial Number _________________________
Date Purchased _________________________
Dealer _________________________
Setting Up Your Microwave Oven
1Place the oven on a flat, sturdy surface
and plug the cord into a grounded outlet.
Once plugged in, the display on your
oven will show:
Make sure there is adequate ventilation for your
oven by leaving at least four inches of space
behind, above, and to the side of the oven.
2Open the oven door by pressing the but-
ton below the control panel.
3Wipe the inside of the oven with a damp
cloth.
4Place the pre-assembled roller guide in
the indentation in the center of the oven.
5Place the glass tray on top of the roller
guide so that the three glass tabs in the
center of the tray fit securely into the
tabs on the floor of the oven.
microwave oven
glass tray
roller guide ring
instruction manual
registration card
MW8490W(mini) 9/28/00 4:33 AM Page 6
Y
OUR
N
EW
M
ICROWAVE OVEN
7Y
OUR
N
EW
M
ICROWAVE
O
VEN
Control Panel Buttons
One Minute+ p. 10
Press once for every minute of cooking at
High power.
Instant Cook Buttons p. 9
Instant settings to cook popular foods.
Auto Reheat p. 12
Shows type and quantity of food to be reheat-
ed.
Number Buttons
Sets cooking times or amounts and power
levels other than high.
More/Less Button p. 14
Increases or decreases cooking time.
Kitchen Timer p. 15
Start
Press to start cooking.
Auto Defrost p. 11
Sets weight of food to be defrosted.
Power Level p. 13
Sets power to level other than high.
Clock p. 8
Sets current time.
Pause/Cancel p. 8
Press to pause oven or correct a mistake.
123
456
789
0
MW8490W(mini) 9/28/00 4:33 AM Page 7
O
PERATION
8O
PERATION
Turning on the Power and Selecting a
Display Language
The first time you plug the power cord into an out-
let, or after there has been an interruption in
power, the display shows “SAMSUNG SO
SIMPLE.” At this point, you can select a language
and weight system for the display. You can choose
from English, French, Spanish and Portuguese and
between pounds (LBS) or kilograms (KG). To do so,
1 Press START immediately after plugging in
your Microwave. The display shows “ ENG-
LISH/LBS”. If the display does not show “ENG-
LISH/LBS”, you will need to unplug the
Microwave and then plug it in again to change
the language.
2 Press START repeatedly to select the lan-
guage and weight system you wish to
use:
• ENGLISH/LBS,
• ENGLISH/KG,
• FRENCH/KG,
• SPANISH/LBS, or SPANISH/KG
• PORTUGUESE/KG.
If you continue to press START, the set-
tings will cycle in the order shown here.
When you have selected the language and weight sys-
tem you want to use, press the PAUSE/CANCEL button
to end this procedure, or press CLOCK/START to set the
clock.
Setting the Clock
1 Press the Clock button. The display will
show:
2 Use the number buttons to enter the cur-
rent time. You must press at least three
numbers to set the clock. If the current
time is 5:00 enter, 5,0,0.
3 Press Clock again. A colon will appear,
indicating that the time is set.
If there is a power interruption, you will need to
reset the clock.
You can check the current time while cooking is in
progress by pressing the Clock button.
Using the Pause/Cancel Button
The Pause/Cancel button allows you to clear
instructions you have entered. It also allows you to
pause the oven’s cooking cycle, so that you can
check the food.
• Pause the oven during cooking: press
Pause/Cancel once. To restart, press Start.
• Stop cooking, erase instructions, and return the
oven display to the time of day: press
Pause/Cancel twice.
• Correct a mistake you have just entered: press
Pause/Cancel once, then re-enter the instruc-
tions.
• Cancel a timer setting: press Pause/Cancel
once.
MW8490W(mini) 9/28/00 4:34 AM Page 8
O
PERATION
9
O
PERATION
Using the Help system
Your microwave offers helpful instructions for many
procedures.
1 When you need feature information and
helpful hints, press the Help Screen
button and then press the button that you
want to get information on. Help informa-
tion is available in 4 languages (English,
French, Spanish and Portuguese). The
“HELP” indicator appears in the display
while you are using this feature.
Using the Instant Cook Buttons
1 Press the Instant Cook button corre-
sponding to the food you are cooking
(Popcorn, for example). The display
shows the first serving size:
2 Press the button repeatedly to select the
serving size you want. The display will
cycle through all available serving sizes.
Once you select the correct serving size,
the microwave will begin cooking auto-
matically.
If you don’t need to read all the MENU options,
simply press the Start button to begin cooking.
Item Weight Remarks
Popcorn 3.5 oz
• Use one microwave-only bag
3.0-
3.5 oz
of popcorn.
1.75 oz • Use caution when removing
1.5-
1.75 oz
and opening hot bag from
oven.
Potato 1 EA
• Prick each potato several
2 EA
times with fork.
3 EA
• Place on turntable in spoke-
4 EA
like fashion.
5 EA
• Remove from oven, wrap in
6 EA
foil and let stand 3-5 min.
Fresh 1 cup
• Place the vegetables into a
Vegetables 2 cups
casserole and add a small
3 cups
amount of water(2-4 Tbsp).
4 cups
Cover during cooking and stir
before standing.
Frozen 7-10 oz
• Remove package from outer
Dinner 10-12 oz wrapping and follow package
12-18 oz instructions for covering and
Diet Cook 7-10 oz
standing. After cooking, let
(Low Calorie 10-12 oz stand 1-3 min.
Frozen Dinner) 12-18 oz
Baby Food 2.5 oz
• Remove lid from baby food
4 oz
and heat (heating time is very
6 oz
short). Check temperature
and stir well before serving.
• The More/Less key cannot be
used with the baby food key
Instant Cook Chart
MW8490W(mini) 9/28/00 4:34 AM Page 9
Using the One Minute+ Button
This button offers a convenient way to heat food in
one-minute increments at the High power level.
1Press the One Minute+ button once for
each minute you wish to cook the food.
For example, press it twice for two min-
utes. The time will display, and the oven
starts automatically.
Add minutes to a program in progress by pressing
the One Minute+ button for each minute you
want to add.
Using the Gentle Cook Button
This button is for slower, gentler cooking with
reduced power.
1 Use the Number button to set a cooking
time.
For example, to set 10 minutes, enter
1,0,0,0.
2Press the Gentle Cook button. The time
will display and the oven will start auto-
matically.
O
PERATION
10 O
PERATION
Defrosting Automatically
To thaw frozen food, set the weight of the food and
the microwave automatically sets the defrosting
time, power level and standing time.
1 Press the Auto Defrost button. The dis-
play shows “0.5 LB.”(0.2Kg if you have
set your oven for metric measure).
2 To set the weight of your food, press the
Auto Defrost button repeatedly. This
increases the weight by 0.5 lb incre-
ments, up to 6.0 lbs.
You can also use the number buttons to
enter the weight of the food directly.
The oven calculates the defrosting time
and starts automatically. Twice during
defrosting, the oven will beep and the
display will read “TURN THE FOOD
OVER.”
3Press the Pause/Cancel button, open the
oven door, and turn the food over.
4 Press the Start button to resume
defrosting.
• See page 20 for the Auto Defrosting
Guide
MW8490W(mini) 9/28/00 4:34 AM Page 10
O
PERATION
11
O
PERATION
Reheating Automatically
To reheat food, select the type of dish and the num-
ber of servings you want to reheat, and the
microwave automatically sets the reheating time.
1 Press the Auto Reheat button repeatedly
to select the type of dish you wish to
reheat. The initial serving size for each
dish is one serving.
You can select up to four servings for
casseroles and soup. Only one serving is
available for a plate of food.
The display shows the dish and quantity you
have chosen, then “PRESS START.”
2 Use the Number buttons to increase the
serving size. For example, for three serv-
ings, press the“3” button. The display
shows the number of servings you have
selected:
3Press the Start button. The display will
show “REHEAT.”
Plate of food
Casserole
Soup /Sauce
Auto Reheat Chart
Item Weight Remarks
Plate of 1 serving
• Cover plate with vented
Food plastic wrap or wax paper
• Contents
- 3-4 oz. meat, poultry or
fish (up to 6 oz. With bone)
- 1/2 cup starch (potatoes,
pasta, rice, etc.)
- 1/2 cup vegetable (about
3-4 oz.)
Casse- 1 to 4 servings
• Cover with lid or vented
role (8 oz./serving) plastic wrap.
Soup/ 1 to 4 servings
• Stir foods once before
Sauce
(8 oz./serving) serving.
MW8490W(mini) 9/28/00 4:34 AM Page 11
O
PERATION
12 O
PERATION
Setting Cooking Times & Power
Levels
Your microwave allows you to set up to three differ-
ent stages of cooking, each with its own time length
and power level. The power level lets you control
the heating intensity from Warm (1) to High (0).
One-stage Cooking
For simple one-stage cooking, you only need to set a
cooking time. The power level is automatically set at
High. If you want the power set at any other level,
you must set it using the Power Level button.
1Use the number buttons to set a cooking
time. You can set a time from one second
to 99 minutes, 99 seconds. To set a time
over one minute, enter the seconds too.
For example, to set 20 minutes, enter
2, 0, 0, 0 .
2 If you want to set the power level to
something other than High, press the
Power Level button, then use the number
buttons to enter a power level.
Power Levels:
1 = warm 6 = simmer
2 = low 7 = medium high
3 = defrost 8 = reheat
4 = medium low 9 = sauté
5 = medium 0 = high
The display shows “PRESS START OR ENTER NEXT
STAGE COOKING TIME”
3 Press the Start button to begin cooking.
If you want to change the power level,
press Pause/Cancel before you press
Start, and reenter all of the instructions.
Setting Cooking Times, continued
Some recipes require different stages of cooking at
different temperatures. You can set multiple stages
of cooking with your microwave.
Multi-stage Cooking
1 Follow steps 1 and 2 in the “One-Stage
Cooking” section on this page. The dis-
play shows “PRESS START OR ENTER
NEXT STAGE COOKING TIME.”
When entering more than one cooking stage, the
Power Level button must be pressed before the
second cooking stage can be entered.
To set the power level at High for a stage of cook-
ing, press the Power Level button twice.
2 Use the Number buttons to set a second
cooking time.
3 Press the Power Level button, then use
the number buttons to set the power
level of the second stage of cooking.
The display shows the power level you
have set and then “PRESS START OR
NEXT STAGE COOKING TIME.”
4 Press Start to begin cooking, or repeat
steps 2 and 3 to set a cooking time and
power level for a third stage of cooking.
When finished, press Start.
MW8490W(mini) 9/28/00 4:34 AM Page 12
O
PERATION
13
O
PERATION
Using the More/Less Button
The More/Less button allows you to adjust pre-set
cooking times. It only works with Auto Reheat , the
Instant-cook buttons and Dual Cook button. Use
the More/Less button only after you have already
begun cooking with one of these procedures.
The More/Less key cannot be used with the Baby
Food key.
1 To ADD more time to an automatic cook-
ing procedure: Press the More/Less but-
ton once. The word “MORE” will appear
in the display.
2 To REDUCE the time of an automatic
cooking procedure: Press the More/Less
button twice. The word “LESS” will
appear in the display.
3 To return to the NORMAL time set for an
automatic cooking procedure: Press the
More/Less button until the word
“NORMAL” appears in the display.
Adjusting the Volume
The Sound button on the microwave allows you to
adjust the volume of the microwave’s chime
sound. The sound is initially set to its highest set-
ting. To change the volume:
1 Press the Sound button. The display
shows
“0-OFF 1-LOW 2-MED 3-HIGH”
2 Press “0” to turn the volume off, “1” for
low volume, “2” for medium volume, or
“3” for high volume.
The display will show the volume you
have chosen, then shows “PRESS
START”
3 Press Start:
The display returns to the time of day.
MW8490W(mini) 9/28/00 4:34 AM Page 13
O
PERATION
14 O
PERATION
Using the Kitchen Timer
1Use the Number buttons to set the length
of time you want the timer to run.
2Press the Kitchen Timer button.
3 The display counts down and beeps
when the time has elapsed.
Setting the Child Protection Lock
You can lock your microwave oven so it can’t be
used by unsupervised children.
1 Press the “0” button. The display shows
“PRESS 1-DEMO 2- CHILD LOCK.”
2Press the “2” button. The display shows
“PRESS START.”
3Press the Start button. The display
shows “LOCK” then return to the time of
day.
At this point, the microwave oven cannot be used
until it is unlocked. To unlock it, repeat steps 1–3
above.
Demonstration Mode
You can use the Demonstration Mode to see how
your microwave oven operates without the oven
heating.
1Press the “0” button. The display shows
“PRESS 1-DEMO 2- CHILDLOCK.”
2 Press the “1” button. The display shows
“PRESS START”.
3Press the Start button. The display
shows “DEMO MODE ON”.
To turn demo mode off, repeat steps 1–3 above.
MW8490W(mini) 9/28/00 4:34 AM Page 14
C
OOKING
I
NSTRUCTIONS
15
C
OOKING
I
NSTRUCTIONS
Cooking Utensils
Recommended Use
• Glass and glass-ceramic bowls and dishes —
Use for heating or cooking.
• Microwave browning dish — Use to brown the
exterior of small items such as steaks, chops, or
pancakes. Follow the directions provided with
your browning dish.
• Microwavable plastic wrap — Use to retain
steam. Leave a small opening for some steam to
escape and avoid placing it directly on the food.
• Wax paper — Use as a cover to prevent spatter-
ing.
• Paper towels and napkins — Use for short-term
heating and covering; they absorb excess mois-
ture and prevent spattering. Do not use recycled
paper towels, which may contain metal and can
catch fire.
• Paper plates and cups — Use for short-term
heating at low temperatures. Do not use recy-
cled paper, which may contain metal and can
catch fire.
• Thermometers — Use only those labeled
“Microwave Safe” and follow all directions.
Check the food in several places. Conventional
thermometers may be used once the food has
been removed from the oven.
Limited Use
• Aluminum foil — Use narrow strips of foil to pre-
vent overcooking of exposed areas. Using too
much foil can damage your oven, so be careful.
• Ceramic, porcelain, and stoneware — Use these
if they are labeled “Microwave Safe.” If they
are not labeled, test them to make sure they can
be used safely. Never use dishes with metallic
trim.
• Plastic — Use only if labeled “Microwave Safe.”
Other plastics can melt.
• Straw, wicker, and wood — Use only for short-
term heating, as they can be flammable.
Not Recommended
• Glass jars and bottles — Regular glass is too
thin to be used in a microwave, and can shatter.
• Paper bags — These are a fire hazard, except
for popcorn bags that are designed for
microwave use.
• Styrofoam plates and cups — These can melt
and leave an unhealthy residue on food.
• Plastic storage and food containers —
Containers such as margarine tubs can melt in
the microwave.
• Metal utensils — These can damage your oven.
Remove all metal before cooking.
Testing Utensils
If you are not sure whether a dish is microwave-
safe or not, you can perform this test:
1Fill a 1 cup glass measuring cup with
water and put it inside your oven, next to
the dish you want to test.
2Press the One Minute+ button once to
heat them for one minute at High power.
The water should be warm and the dish you are
testing should be cool. If the dish is warm, then it is
absorbing microwave energy and is not acceptable
for use in the microwave.
MW8490W(mini) 9/28/00 4:34 AM Page 15
Cooking Techniques
Stirring
Stir foods such as casseroles and vegetables while
cooking to distribute heat evenly. Food at the out-
side of the dish absorbs more energy and heats
more quickly, so stir from the outside to the center.
The oven will turn off when you open the door to
stir your food.
Arrangement
Arrange unevenly shaped foods, such as chicken
pieces or chops, with the thicker, meatier parts
toward the outside of the turntable where they
receive more microwave energy. To prevent over-
cooking, place thin or delicate parts toward the
center of the turntable.
Shielding
Shield food with narrow strips of aluminum foil to
prevent overcooking. Areas that need shielding
include poultry wing-tips, the ends of poultry legs,
and corners of square baking dishes. Use only
small amounts of aluminum foil. Larger amounts
can damage your oven.
Turning
Turn foods over midway through cooking to expose
all parts to microwave energy. This is especially
important with large items such as roasts.
Standing
Foods cooked in the microwave build up internal
heat and continue to cook for a few minutes after
the oven stops. Let foods stand to complete cook-
ing, especially foods such as roasts and whole
vegetables. Roasts need this time to complete
cooking in the center without overcooking the
outer areas. All liquids, such as soup or hot choco-
late, should be shaken or stirred when cooking is
complete. Let liquids stand a moment before serv-
ing. When heating baby food, stir well and test the
temperature before serving.
Adding Moisture
Microwave energy is attracted to water molecules.
Food that is uneven in moisture content should be
covered or allowed to stand so that the heat dis-
perses evenly. Add a small amount of water to dry
food to help it cook.
General Tips
• Dense foods, such as potatoes, take longer to
heat than lighter foods. Foods with a delicate
texture should be heated at a low power level to
avoid becoming tough.
• Altitude and the type of cookware you are using
can affect cooking time. When using a new
recipe, use the minimum cooking time and
check the food occasionally to prevent over-
cooking.
• Foods with a non-porous skin or shell, such as
potatoes, eggs, or hot dogs, should be pierced
to prevent bursting.
• Frying with heating oil or fat is not recommend-
ed. Fat and oil can suddenly boil over and
cause severe burns.
• Some ingredients heat faster than others. For
example, the jelly inside a jelly doughnut will be
hotter than the dough. Keep this in mind to avoid
burns.
• Home canning in the microwave oven is not
recommended because all harmful bacteria may
not be destroyed by the microwave heating
process.
• Although microwaves do not heat the cook-
ware, the heat is often transferred to the cook-
ware. Always use pot holders when removing
food from the microwave and instruct children
to do the same.
C
OOKING
I
NSTRUCTIONS
16 C
OOKING
I
NSTRUCTIONS
MW8490W(mini) 9/28/00 4:34 AM Page 16
C
OOKING
I
NSTRUCTIONS
17
C
OOKING
I
NSTRUCTIONS
GUIDE for Cooking Meat in Your Microwave
• Place meat on a microwave-safe roasting rack in a microwave-safe dish.
• Start meat fat-side down. Use narrow strips of aluminum foil to shield any bone tips or thin meat areas.
• Check the temperature in several places before letting the meat stand the recommended time.
• The following temperatures are removal temperatures. The temperature of the food will rise during the
standing time.
Roast Beef
Boneless
Up to 4 lbs.
Cook Time /Power Level Directions
Pork
Boneless or
bone-in
Up to 4 lbs.
Bacon
2-6 slices
Food
Whole
Chicken
Up to 4 lbs.
Cook Time /Power Level Directions
Chicken
Pieces
Up to 11/2 lbs.
Cooking Time:
5-8 min. / lb. 170° -180°F
Power Level: Medium High(7).
Place chicken breast-side down on
roasting rack. Cover with wax paper.
Turn over whenthe cooking time is half
up. Cook until juices run clear and meat
near the bone is no longer pink. Let
stand 5-10 min.
Food
Cooking Time:
5-8 min. / lb.
180°F dark meat
170°F light meat
Power Level: Medium High(7).
Place chicken bone-side down on dish,
with the thickest portions towards the
outside of the dish. Cover with wax
paper. Turn over when the cooking time
is half up. Cook until juices run clear and
meat near the bone is no longer pink. Let
stand 5-10 min.
GUIDE for Cooking Poultry in Your Microwave
• Place poultry on a microwave-safe roasting rack in a microwave-safe dish.
• Cover poultry with wax paper to prevent spattering.
• Use aluminum foil to shield bone tips, thin meat areas, or areas that start to overcook.
• Check the temperature in several places before letting the poultry stand the recommended time.
Cooking Time:
8-11 min. / lb. for 115° F - Rare
9-13 min. / lb. for 120° F - Medium
10-15 min. / lb. for 145° F - Well Done
Power Level: High(10) for first 5 min., then Medium(5).
Place roast fat-side down on roast-
ing rack. Cover with wax paper.
Turn over when cooking time is half
up. Let stand 10 min.
Cooking Time:
11-15 min. / lb. for 160° F Well Done
Power Level: High(10) for first 5 min., then Medium(5).
Place roast fat-side down on roast-
ing rack. Cover with vented plastic
wrap. Turn over when cooking time
is half up. Let stand 10 min.
Cooking Time:
2 slices: 1- 13/4 min.
4 slices: 3- 31/2 min.
6 slices: 41/2-51/2 min.
Power Level: High(10).
Arrange slices on roasting rack or a
dish lined with paper-towel. Cover
with paper towel. Microwave until
crisp.
MW8490W(mini) 9/28/00 4:34 AM Page 17
C
OOKING
I
NSTRUCTIONS
18 C
OOKING
I
NSTRUCTIONS
19
• Vegetables should be washed just before cooking.
Often, no extra water is needed. If dense vegeta-
bles such as potatoes, carrots and green beans
are being cooked, add about 1/4 cup water.
• Small vegetables (sliced carrots, peas, lima beans,
etc.) will cook faster than larger ones.
• Whole vegetables, such as potatoes, acorn
squash or corn on the cob, should be arranged in
a circle on the turntable before cooking. They will
cook more evenly if turned over after half the
cooking time.
• Always place vegetables like asparagus and broc-
coli with the stem ends pointing towards the edge
of the dish and the tips toward the center.
• When cooking cut vegetables, always cover the
dish with a lid or vented microwavable plastic
wrap.
• Whole, unpeeled vegetables such as potatoes,
squash, eggplant, etc., should have their skin
pricked in several spots before cooking to prevent
them from bursting.
• For more even cooking, stir or rearrange whole
vegetables halfway through the cooking time.
• Generally, the denser the food, the longer the
standing time. (Standing time refers to the time
necessary for dense, large foods and vegetables
to finish cooking after they come out of the oven.)
A baked potato can stand on the counter for five
minutes before cooking is completed, while a dish
of peas can be served immediately.
GUIDE for Cooking Eggs in Your Microwave
• Never cook eggs in the shell, and never warm hard-cooked eggs in the shell; they can explode.
• Always pierce whole eggs to keep them from bursting.
• Cook eggs just until set; they become tough if overcooked.
GUIDE for Cooking Vegetables in Your Microwave
GUIDE for Cooking Seafood in Your Microwave
• Cook fish until it flakes easily with a fork.
• Place fish on a microwave-safe roasting rack in a microwave-safe dish.
• Use a tight cover to steam fish. A lighter cover of wax paper or paper towel provides less steaming.
• Do not overcook fish; check it at minimum cooking time.
Steaks
Up to 1.5 lbs.
Cook Time /Power Level Directions
Fillets
Up to 1.5 lbs.
Shrimp
Up to 1 lb.
Cooking Time:
6-10 min. / lb.
Power Level: Medium High(7).
Arrange steaks on roasting rack with
meaty portions towards the outside of
rack. Cover with wax paper. Turn over
and rearrange when cooking time is half
up. Cook until fish flakes easily with a
fork. Let stand 3-5 min.
Food
Cooking Time:
3-7 min. / lb.
Power Level: Medium High(7).
Arrange fillets in a baking dish, turning any
thin pieces under. Cover with wax paper. If
over 1/2 inch thick, turn over and rearrange
when cooking time is half up. Cook until fish
flakes easily with a fork. Let stand 2-3 min.
Cooking Time:
3-5 1/2min. / lb.
Power Level: Medium High(7).
Arrange shrimp in a baking dish without
overlapping or layering. Cover with wax
paper. Cook until firm and opaque, stir-
ring 2 or 3 times. Let stand 5 min.
MW8490W(mini) 9/28/00 4:34 AM Page 18
C
OOKING
I
NSTRUCTIONS
19
C
OOKING
I
NSTRUCTIONS
AUTO DEFROSTING GUIDE
• Follow the instructions below when defrosting defferent types of food.
Notes
Check foods when the oven signals. After the final stage, small sections may still be icy; let them stand to
continue thawing. Do not defrost until all ice crystals have thawed.
Shielding roasts and steaks with small pieces of foil prevents the edges from cooking before the center of
the food has defrosted. Use narrow, flat, smooth strips of aluminum foil to cover the edges and thinner
sections of the food.
Roast Beef, Pork 2.5-5.0 lbs. Start with the food placed fat side down. After each stage,
turn the food over and shield any warm portions with narrow
strips of aluminum foil.
Ground Meat 0.5-3.0 lbs. After each stage, remove any pieces of food that are nearly
defrosted. Let stand, covered with foil, for 5–10 minutes.
Whole Chicken 2.5-6.0 lbs. Remove giblets before freezing poultry. Start defrosting with
the breast side down. After the first stage, turn the chicken
over and shield any warm portions with narrow strips of alu-
minum foil. After the second stage, again shield any warm
portions with narrow strips of aluminum foil. Let stand, cov-
ered, for 30–60 minutes in the refrigerator.
Chicken Pieces 0.5-2.0 lbs. After each stage, rearrange or remove any pieces of food that
are nearly defrosted. Let stand for 10-20 minutes.
Steaks, Chops, Fish 0.5-3.0 lbs. After each stage, rearrange the food. If there are any warm or
thawed portions of food, shield them with narrow flat pieces
of aluminum foil. Remove any pieces of food that are nearly
defrosted. Let stand, covered, for 5-10 minutes.
Food Amount Procedure
MW8490W(mini) 9/28/00 4:34 AM Page 19
C
OOKING
I
NSTRUCTIONS
20 C
OOKING
I
NSTRUCTIONS
Recipes
Beef and Barley Stew
1 1/2 lbs. beef stew cubes, cut into 1/2-inch pieces
1/2 cup chopped onion
2 Tbs. all-purpose flour
1 Tbs Worcestershire sauce
1 can (13.75-14.5 oz.) beef broth
2 medium carrots, cut into 1/2-inch slices (about 1
cup)
1/2 cup barley
1 bay leaf
1/4 tsp. pepper
1 pkg. (9-10 oz.) frozen peas, thawed
1. In a 2-quart casserole, combine beef, onion,
flour, and Worcestershire; mix well. Cover with
lid. Cook at High for 6 to 8 minutes until beef is
no longer pink, stirring once.
2. Stir in beef broth, carrots, barley, bay leaf, and
pepper. Cover with lid. Cook at Medium for 1 to
11/2 hours until carrots and beef are tender, stir-
ring 2 to 3 times.
3. Stir in peas. Cover with lid. Cook at Medium for
10 minutes. Let stand for 10 minutes. Remove
bay leaf before serving. Makes 6 servings.
Broccoli and Cheese Casserole
1/4 cup butter or margarine
1/4 cup chopped onion
1 1/2 Tbs. flour
1/2 tsp. salt
1/4 tsp. dry mustard
1/8 tsp. pepper
1 1/2 cups milk
1/4 cup chopped red pepper
8 oz. (2 cups) cheddar cheese, shredded
1 pkg. (9-10 oz.) frozen chopped broccoli, thawed
4 cups cooked spiral shaped pasta (8 oz. dry)
1. In a 2-quart casserole, cook butter and onion at
High for 1 to 2 minutes until onion is soft, stirring
once.
2. Add flour, salt, mustard, and pepper; mix well.
Cook at High for 30 to 60 seconds until mixture
boils. Stir in milk until smooth.
3. Stir in red pepper. Cook at High for 2 to 3 min-
utes until mixture boils and thickens slightly,
stirring twice. Stir in cheese until melted.
4. Add broccoli and pasta, mix well. Cover with lid.
Cook at High for 4 to 6 minutes until heated
through, stirring once. Stir before serving.
Makes 6 servings.
MW8490W(mini) 9/28/00 4:34 AM Page 20
C
OOKING
I
NSTRUCTIONS
21
C
OOKING
I
NSTRUCTIONS
Warm Potato Salad
2 lbs. small red potatoes, cut into 1/2-inch pieces
4 slices bacon (uncooked), cut into 1/2-inch pieces
1/4 cup chopped onion
2 tsp. sugar
1 tsp. salt
1 tsp. flour
1/2 tsp. celery seed
1/8 tsp. pepper
2 1/2 Tbs. apple cider vinegar
1. In a 2-quart casserole, combine potatoes and
1/4 cup water. Cover with lid. Cook at High until
potatoes are tender (7-10 min.); stir twice. Drain
and set aside to cool slightly.
2. In a medium bowl, cook bacon at High until
crisp (21/2-31/2 min.); stir once. Place bacon on a
paper towel. Reserve 1 Tbs. drippings.
3. Combine drippings and onion. Cover with plastic
wrap; turn back a corner to vent steam. Cook at
High until tender (11/2-21/2 min.); stir once.
4. Stir in sugar, salt, flour, celery seed, and pepper.
Cook at High until mixture boils (30-40 sec.). Stir
in vinegar and 1/2 cup water. Cook at High until
liquid boils and thickens slightly (1-2 min.); stir
once. Add bacon to dressing. Pour dressing
over potatoes. Stir well. Makes 6 servings.
Black Bean Soup
1 cup chopped onion
1 clove garlic, minced
2 cans (15 oz. each) black beans, drained
1 can (14-16 oz.) stewed tomatoes, chopped
1 can (13.75-14.5 oz.) chicken broth
1 can (7-8.5 oz.) corn
1 can (4 oz.) chopped green chilies
1-2 tsp. ground cumin, or to taste
1. Place onion and garlic in a 3-quart casserole.
Cover with lid. Cook at High for 2 to 4 minutes
until tender.
2. Add one can of beans, mash beans with a fork.
Add remaining ingredients; mix well.
3. Cook uncovered, at High for 10 minutes; stir.
Reduce power to Medium and cook for 5 min-
utes. Stir before serving. Makes about 2 quarts.
Recipes
MW8490W(mini) 9/28/00 4:34 AM Page 21
Using your microwave causes TV or radio
interference.
• This is similar to the interference caused by
other small appliances, such as hair dryers.
Move your microwave further away from other
appliances, like your TV or radio.
Care and Cleaning
Follow these instructions to clean and care for
your oven.
• Keep the inside of the oven clean. Food parti-
cles and spilled liquids can stick to the oven
walls, causing the oven to work less efficiently.
• Wipe up spills immediately. Use a damp cloth
and mild soap. Do not use harsh detergents or
abrasives.
• To help loosen baked on food particles or liq-
uids, heat two cups of water (add the juice of
one lemon if you desire to keep the oven fresh)
in a four-cup measuring glass at High power for
five minutes or until boiling. Let stand in the
oven for one or two minutes.
• Remove the glass tray from the oven when
cleaning the oven or tray. To prevent the tray
from breaking, handle it carefully and do not put
it in water immediately after cooking. Wash the
tray carefully in warm sudsy water or in the
dishwasher.
• Clean the outside surface of the oven with soap
and a damp cloth. Dry with a soft cloth. To pre-
vent damage to the operating parts of the oven,
don’t let water seep into the openings.
• Wash the door window with very mild soap and
water. Be sure to use a soft cloth to avoid
scratching.
• If steam accumulates inside or outside the oven
door, wipe with a soft cloth. Steam can accumu-
late when operating the oven in high humidity
and in no way indicates microwave leakage.
• Never operate the oven without food in it; this
can damage the magnetron tube or glass tray.
You may wish to leave a cup of water in the
oven when it is not in use to prevent damage if
the oven is accidentally turned on.
Troubleshooting Guide
Before you call a repair person for your oven,
check this list of possible problems and solutions.
Neither the oven’s display nor the oven operate.
• Properly insert the plug into a grounded outlet.
• If the outlet is controlled by a wall switch, make
sure the wall switch is turned on.
• Remove the plug from the outlet, wait ten sec-
onds, then plug it in again.
• Reset the circuit breaker or replace any blown
fuse.
• Plug another appliance into the outlet; if the
other appliance doesn’t work, have a qualified
electrician repair the outlet.
• Plug the oven into a different outlet.
The oven’s display works, but the power won’t
come on.
• Make sure the door is closed securely.
• Check to see if packing material or other materi-
al is stuck to the door seal.
• Check for door damage.
• Press Cancel twice and re-enter all cooking
instructions.
The power goes off before the set time has
elapsed.
• If there has not been a power outage, remove
the plug from the outlet, wait ten seconds, then
plug it in again. If there was a power outage, the
time indicator will display “SAMSUNG SO SIM-
PLE” Reset the clock and any cooking instruc-
tions.
• Reset the circuit breaker or replace any blown
fuse.
The food is cooking too slowly.
• Make sure the oven is on its own 20 amp circuit
line. Operating another appliance on the same
circuit can cause a voltage drop. If necessary,
move the oven to its own circuit.
You see sparks or arcing.
• Remove any metallic utensils, cookware, or
metal ties. If using foil, use only narrow strips
and allow at least one inch between the foil and
interior oven walls.
The turntable makes noises or sticks.
• Clean the turntable, roller ring and oven floor.
• Make sure the turntable and roller ring are posi-
tioned correctly.
A
PPENDIX
22 A
PPENDIX
If you have a problem you cannot solve,
please call our service line:
1-800-SAMSUNG
(1-800-726-7864)
MW8490W(mini) 9/28/00 4:34 AM Page 22
A
PPENDIX
23
A
PPENDIX
Warranty Information
Limited Warranty for Original Purchaser
This Samsung product is warranteed by Samsung
Electronics America, Inc. (hereafter referred to as
SEA) against manufacturing defects in material or
workmanship for the following periods:
Labor: One year (carry-in)
Parts: One year
Magnetron: Eight years
SEA further warrants that if this product fails to
operate properly within the specified warranty
period and the failure is due to improper workman-
ship or defective material, SEA will repair or
replace the product at its option.
All warranty repairs or part replacements must be
performed by a SEA Authorized Service Center. (To
find the nearest SEA Service Center, call 1-800-
SAMSUNG.)
Obligation to the Original Owner
The original dated sales receipt must be retained
by the customer and is the only acceptable proof
of purchase. It must be presented to an SEA
Authorized Service Center at the time service is
requested before warranty services are rendered.
On all carry-in models, transportation to and from
the Authorized Service Center is the responsibility
of the customer.
Exclusions of the Warranty
This warranty does not cover damage due to acci-
dent, fire, flood, and/or other Acts of God: misuse,
incorrect line voltage, improper installation,
improper or unauthorized repairs, commercial use,
or damage that occurs during shipping. Customer
adjustments which are explained in this owner’s
manual are not covered under the terms of this
warranty. This warranty will automatically be void-
ed for any unit found with a missing or altered seri-
al number. This warranty is valid only on products
purchased and used in the United States and
Puerto Rico. Some states do not allow the exclu-
sion or limitations of incidental or consequential
damages, or allow limitations on how long an
implied warranty lasts, so the above limitations or
exclusions may not apply to you. This warranty
gives you specific legal rights and you may also
have other rights which vary from state to state.
Specifications
Model Number
Oven Cavity
Controls
Timer
Power Source
Power Output
Oven Cavity Dimensions
Outside Dimensions
Net/Gross Weight
MW8584W
1.6cuft
10 power levels, including defrost
99 minutes, 99 seconds
120 VAC, 60 Hz
1000 Watts
2121/32”(W) X 135/16”(H) X 1811/32”(D)
161/2”(W) X 93/16”(H) X 179/32”(D)
44/50 bs
MW8490W(mini) 9/28/00 4:34 AM Page 23
G
UÍA DE
C
ONSULTA
R
ÁPIDA EN
E
SPAÑOL
24 G
UÍA DE
C
ONSULTA
R
ÁPIDA EN
E
SPAÑOL
Usando el Botón PAUSE/CANCEL
• Para pausar mientras está cocinando, opri-
ma una vez al botón PAUSE/CANCEL.
• Para detener el horno y borrar las instruc-
ciones para cocinar, oprima dos veces al
botón PAUSE/CANCEL.
• Para corregir un error de programación,
oprima una vez al botón PAUSE/CANCEL y
vuelva a programr las instrucciones.
• Para cancelar un ajuste del cronómetro,
oprima una vez al botón PAUSE/CANCEL.
Encendiendo el Horno y Seleccionando el
Idioma del desPliegue
• Enchufe el horno de microondas y oprima
el botón START repetidamente hasta que
vea el idioma y sistema de medida que
desea utilizar.
Poniendo el Reloj
• Oprima una vez al botón CLOCK.
• Utilice los botones numéricos 0–9 para
seleccionar la hora correcta.
• Oprima una vez más al botón CLOCK para
fijar la hora.
Ajustando el Tiempo de Concinar y Niveles
de Potencia – Cocinando en una Etapa
• Utilice los botones numéricos 0–9 para
ajustar el tiempo de cocinar.
• Oprima el botón POWER LEVEL, y los
botones numéricos 0–9 para seleccionar la
potencia de cocinar (si es diferente a 0).
• Oprima el botón START para comenzar a
cocinar.
Ajustando el Tiempo de Concinar y Niveles
de Potencia – Cocinando en Etapas Múltiples
• Utilice los botones numéricos 0–9 para
ajustar el tiempo de cocinar.
• Oprima el botón POWER LEVEL, y los
botones numéricos 0–9 para seleccionar la
potencia de cocinar (si es diferente a 0).
• Utilice los botones numéricos 0–9 para
ajustar el segundo tiempo de cocinar.
• Oprima el botón POWER LEVEL, y los
botones numéricos 0–9 para seleccionar la
potencia de cocinar (si es diferente a 0).
• Utilice los botones numéricos 0–9 para
ajustar el tercer tiempo de cocinar.
• Oprima el botón POWER LEVEL, y los
botones numéricos 0–9 para seleccionar la
potencia de cocinar (si es diferente a 0).
• Oprima el botón START para comenzar a
cocinar.
Descongelado Automático
• Oprima repetidamente al botón AUTO
DEFROST para ajustar el peso correcto de
la comida que va descongelar.
MW8490W(mini) 9/28/00 4:34 AM Page 24
G
UÍA DE
C
ONSULTA
R
ÁPIDA EN
E
SPAÑOL
25
G
UÍA DE
C
ONSULTA
R
ÁPIDA EN
E
SPAÑOL
Recalentamiento Automático
• Oprima repetidamente al botón AUTO
REHEAT para seleccionar el tipo de comi-
da.
• Utilice los botones numéricos 0-9 para pro-
gramar las porciones (si son más de una
porción).
• Oprima el botón START para comenzar a
cocinar.
Cocinando Con un Bóton
• Oprima el botón ONE MINUTE una vez para
cada minuto que desea cocinar.
Usando el Teclado de Cocina Instantánea
• Selecione el botón “Instant-cook” (POP-
CORN, FROZEN DINNER, etc.) apropiado
para el tipo de comida que desea cocinar,
oprima este botón repetidamente para pro-
gramar el tamaño de la porción.
Ajustando el Tiempo de Cocinado
• Si desea ajustar el tiempo de cocinado
mientras el horno está en operación, opri-
ma el botón MORE/LESS repetidamente
hasta llegar al tiempo deseado.
Usando el Cronómetro
• Oprima los botones numéricos 0–9 para
ajustar el tiempo, luego oprima el botón
KITCHEN TIMER.
Utilizando el Seguro Para Evitar que Niños
Utilicen el Horno
• Oprima los botones 0, 2 y START. Repita
para pagar el seguro.
MW8490W(mini) 9/28/00 4:34 AM Page 25
Q
UICK
R
EFERENCE
SAMSUNG ELECTRONICS
NORTH AMERICAN LIMITED WARRANTY STATEMENT
Subject to the requirements, conditions, exclusions and limitations of
the Original Limited Warranty supplied with Samsung Electronics
(SAMSUNG) products, and the requirements, conditions, exclusions
and limitations contained herein, SAMSUNG will additionally provide
Warranty Repair Service in the United States on SAMSUNG
products purchased in Canada, and in Canada on SAMSUNG
products purchased in the United States, for the warranty period orig-
inally specified, and to the Original Purchaser only.
The above described warranty repairs must be performed by a
SAMSUNG Authorized Service Center. Along with this Statement,
the Original Limited Warranty Statement and a dated Bill of Sale as
Proof of Purchase must be presented to the Service Center.
Transportation to and from the Service Center is the responsibility of
the purchaser.
Conditions covered are limited only to manufacturing defects in
material or workmanship, and only those encountered in normal use
of the product.
Excluded, but not limited to, are any original specified provisions for,
in-home or on-site services, minimum or maximum repair times,
exchanges or replacements, accessories, options, upgrades, or
consumables.
For the locations of a SAMSUNG Authorized Service Center, please
call toll-free:
In the United States: 1-800-SAMSUNG ( 1-800-726-7864 )
In Canada: 1-800-SAMSUNG
MW8490W(mini) 9/28/00 4:34 AM Page 26
Q
UICK
R
EFERENCE
SAMSUNG ELECTRONICS
GARANTIE LIMITÉE POUR L’AMÉRIQUE DU NORD
Assujettie aux exigences, conditions, exclusions et limitations
de la garantie limitée originale fournie avec les produits de
Samsung Electronics (SAMSUNG) et les exigences,
conditions, exclusions et limitations de la présente garantie,
SAMSUNG offrira en plus un service de réparation sous
garantie aux États-Unis pour les produits achetés au Canada
et un service
de réparation sous garantie au Canada pour les produits
achetés aux États-Unis pendant la période de garantie
précisée à l’origine et pour l’acheteur inital seulement.
Les réparations sous garantie décrites ci-dessus doivent
être effectuées dans un centre de réparation agréé
SAMSUNG. En plus de la présente garantie, la garantie lim-
itée originale et une facture datée en tant que preuve d’achat
doivent être présentées au centre de réparation. Le transport
de l’appareil au et à partir du centre de réparation demeure
la responsabilité de l’acheteur.
Les conditions couvertes ne sont limitées qu’aux vices de
matériaux et de fabrication dans des conditions d’utilisation
normale.
Exclues, mais non pas limitées à, sont les dispositions
précisées à l’origine pour le service à domicile ou sur place,
durées de réparation minimales et maximales, échanges ou
remplacements, accessoires, options, extensions ou
produits non durables.
Pour obtenir le nom d’un centre de réparation agréé
Samsung, appelez sans frais :
Aux États-Unis : 1-800-SAMSUNG (1-800-726-7864)
Au Canada : 1-800-SAMSUNG
MW8490W(mini) 9/28/00 4:34 AM Page 27
Q
UICK
R
EFERENCE
ELECTRONICS
Operation
1. Press CLOCK.
2. Use number buttons to enter time.
3. Press CLOCK again.
1. Use number buttons to set cooking time.
2. Set power level or leave at high.
3. Press START.
1. Press the ONE MINUTE + button once for each minute of cooking.
2. The time will display and the oven will start.
1. Press button that corresponds to the food you are cooking
(for example, POPCORN).
2. Press the button repeatedly to select serving size.
1. Press AUTO DEFROST.
2. Enter weight of food by pressing AUTO DEFROST button
repeatedly or using the number buttons.
3. When prompted by oven display, press PAUSE/CANCEL button
and turn food over. Press START to resume defrosting cycle.
1. Press AUTO REHEAT repeatedly to select type of dish to reheat.
2. To increase serving size, press the corresponding number button.
3. Press START to begin reheating cycle.
1. Use number buttons to set cooking time.
2. To set power level at other than HIGH, press POWER LEVEL and
use the number buttons to enter the power level.
3. Press START to begin cooking.
Feature
Set Clock
One Stage Cooking
One Minute+ Cooking
Instant Cook Buttons
Auto Defrost
Auto Reheat
Set Cooking Time and
Power Levels
SAMSUNG ELECTRONICS AMERICA, INC.
HEADQUARTERS
105 CHALLENGER ROAD
RIDGEFIELD PARK, NEW JERSEY 07660-0511
Dec. 1998
Printed in Korea
MW8490W(mini) 9/28/00 4:34 AM Page 28
