Samsung Electronics Co OTR10STS Microwave Oven User Manual 49 401163v01
Samsung Electronics Co Ltd Microwave Oven 49 401163v01
Users Manual
Microwave Oven
164D3370P113 49-40116-3 12-00 JR
JVM2050
Owner’s
Manual
Safety Information
Arcing . . . . . . . . . . . . . . . . .4
Foods . . . . . . . . . . . . . . .4, 5
Grounding
Instructions . . . . . . . . . . . .8
Microwave-Safe
Cookware . . . . . . . . . . . .6, 7
Precautions to Avoid
Possible Exposure to
Excessive Microwave
Energy . . . . . . . . . . . . . . . . .2
Safety Precautions . . . .2, 3
Vent Fan . . . . . . . . . . . . . . .9
Operating Instructions
Auto Feature . . . . . . . . . .20
Care and
Cleaning . . . . . . . . . .34, 35
Changing the
Power Level . . . . . . . . . . .13
Convenience
Features . . . . . . . . . . .21–25
Cooking Guide . . . . .15, 16
Defrosting Guide . . . . . .18
Exhaust Feature . . . .37, 38
Features of Your
Microwave Oven . . .11, 12
Microwave Terms . . . . . .33
Other Features . . . . 26–32
Replacing Bulbs . . . . . . .36
Time Features . . . . .14–19
Troubleshooting Tips
Before You Call
For Service . . . . . . . . . . . .39
Things That Are
Normal With Your
Microwave Oven . . . . . . .39
Consumer Support
Consumer
Support . . . . . .Back Cover
Optional Kits . . . . . . . . .10
Product
Registration . . . . . . .41, 42
Warranty . . . . . . . . . . . . .43
Español
For a Spanish version of this
manual, visit our Website at
www.GEAppliances.com.
Para consultar una version
en español de este manual
de instrucciones, visite
nuestro sitio de internet
www.GEAppliances.com.
www.GEAppliances.com
SpacemakerXL
Write the model and serial numbers here:
Model #
________________________
Serial #
________________________
Find these numbers on a label inside
the oven.
49-401163v01 12/6/00 5:46 PM Page 1
■Read and follow the specific
precautions in the
Precautions
to Avoid Possible Exposure to
Excessive Microwave Energy
section above.
■This appliance must be
grounded. Connect only
to a properly grounded
outlet. See the
Grounding
Instructions
section on page 8.
■Install or locate this
appliance only in accordance
with the provided Installation
Instructions.
■
Do Not Attempt
to operate
this oven with the door open
since open-door operation
can result in harmful
exposure to microwave
energy. It is important not to
defeat or tamper with the
safety interlocks.
■
Do Not Place
any object
between the oven front
face and the door or allow
soil or cleaner residue to
accumulate on sealing
surfaces.
■
Do Not Operate
the oven if it is
damaged. It is particularly
important that the oven door
close properly and that there
is no damage to the:
door (bent),
hinges and latches
(broken or loosened),
door seals and sealing
surfaces.
■
The Oven Should Not
be
adjusted or repaired by
anyone except properly
qualified service personnel.
3
2
1
PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
Safety InformationOperating InstructionsTroubleshooting TipsConsumer Support
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
2
For your safety, the information in this manual must be
followed to minimize the risk of fire or explosion, electric
shock, or to prevent property damage, personal injury, or
loss of life.
WARNING!
This microwave oven is UL listed for installation over
electric and gas ranges. This microwave oven is not
approved or tested for marine use.
SAFETY PRECAUTIONS
49-401163v01 12/6/00 5:46 PM Page 2
www.GEAppliances.com
3
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
Use this appliance only for its intended purpose as
described in this Owner’s Manual.
■Do not mount this
appliance over a sink.
■This over-the-range oven
was designed for use over
ranges no wider than 36″.
It may be installed over
both gas and electric
cooking equipment.
■Do not operate this
appliance if it has a
damaged power cord or
plug, if it is not working
properly, or if it has been
damaged or dropped.
■Do not cover or block any
openings on the appliance.
■Use this appliance only
for its intended use as
described in this manual.
Do not use corrosive
chemicals or vapors in this
appliance. This microwave
oven is specifically designed
to heat, dry or cook food,
and is not intended for
laboratory or industrial use.
■Do not store this appliance
outdoors. Do not use this
product near water—
for example, in a wet
basement, near a swimming
pool or near a sink.
■Keep power cord away from
heated surfaces.
■Do not immerse power cord
or plug in water.
■To reduce the risk of fire
in the oven cavity:
— Do not overcook food.
Carefully attend appliance
if paper, plastic or other
combustible materials are
placed inside the oven
while cooking.
— Remove wire twist-ties and
metal handles from paper
or plastic containers before
placing them in the oven.
— Do not use the oven for
storage purposes. Do not
leave paper products,
cooking utensils or food in
the oven when not in use.
— If materials inside the oven
should ignite, keep the oven
door closed, turn the oven
off and disconnect the
power cord, or shut off
power at the fuse or circuit
breaker panel. If the door is
opened, the fire may spread.
■See door surface cleaning
instructions in the
Care and
cleaning of the microwave
oven
section of this manual.
■This appliance should be
serviced only by qualified
service personnel. Contact
nearest authorized service
facility for examination,
repair or adjustment.
■As with any appliance, close
supervision is necessary
when used by children.
49-401163v01 12/6/00 5:46 PM Page 3
Arcing is the microwave term
for sparks in the oven. Arcing
is caused by:
■The metal shelf not
installed correctly so it
touches the microwave wall.
■Metal or foil touching the
side of the oven.
■Foil not molded to food
(upturned edges act like
antennas).
■Metal, such as twist-ties,
poultry pins, or gold-
rimmed dishes, in the
microwave.
■Recycled paper towels
containing small metal
pieces being used in the
microwave.
■Do not pop popcorn in your
microwave oven unless in a
special microwave popcorn
accessory or unless you use
popcorn labeled for use in
microwave ovens.
■Some products such as
whole eggs and sealed
containers—for example,
closed jars—will explode
and should not be heated in
this microwave oven. Such
use of the microwave oven
could result in injury.
■Do not boil eggs in a
microwave oven. Pressure
will build up inside egg yolk
and will cause it to burst,
possibly resulting in injury.
■Operating the microwave
with no food inside for
more than a minute or two
may cause damage to the
oven and could start a fire.
It increases the heat around
the magnetron and can
shorten the life of the oven.
■Foods with unbroken outer
“skin” such as potatoes, hot
dogs, sausages, tomatoes,
apples, chicken livers and
other giblets, and egg yolks
should be pierced to allow
steam to escape during
cooking.
FOODS
Safety InformationOperating InstructionsTroubleshooting TipsConsumer Support
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
4
WARNING!
If you see arcing, press the CLEAR/OFF pad and correct
the problem.
ARCING
49-401163v01 12/6/00 5:46 PM Page 4
www.GEAppliances.com
5
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
■
SUPERHEATED WATER
Microwaved water and other
liquids do not always bubble
when they reach the boiling
point. They can actually get
superheated and not bubble
at all.
Superheated liquid will bubble
up out of the cup when it is
moved or when something
like a spoon or tea bag is put
into it.
To prevent this from
happening and causing injury,
do not heat any liquid for
more than 2 minutes per cup.
After heating, let the cup
stand in the microwave for
30 seconds before moving it
or putting anything into it.
■Avoid heating baby food in
glass jars, even with the lid
off. Make sure all infant
food is thoroughly cooked.
Stir food to distribute the
heat evenly. Be careful to
prevent scalding when
warming formula or breast
milk. The container may
feel cooler than the milk
really is. Always test the milk
before feeding the baby.
■Don’t defrost frozen
beverages in narrow-necked
bottles (especially
carbonated beverages).
Even if the container is
opened, pressure can build
up. This can cause the
container to burst, possibly
resulting in injury.
■Spontaneous boiling—
Under certain special
circumstances, liquids may
start to boil during or shortly
after removal from the
microwave oven. To prevent
burns from splashing liquid,
we recommend the
following: before removing
the container from the oven,
allow the container to stand
in the oven for 30 to 40
seconds after the oven has
shut off. Do not boil liquids
in narrow-necked containers
such as soft drink bottles,
wine flasks and especially
narrow-necked coffee cups.
Even if the container is
opened, excessive steam
can build up and cause it
to burst or overflow.
■Hot foods and steam can
cause burns. Be careful
when opening any
containers of hot food,
including popcorn bags,
cooking pouches and
boxes. To prevent possible
injury, direct steam away
from hands and face.
■Do not overcook potatoes.
They could dehydrate and
catch fire, causing damage
to your oven.
■Cook meat and poultry
thoroughly—meat to at
least an INTERNAL
temperature of 160°F.
and poultry to at least an
INTERNAL temperature
of 180°F. Cooking to
these temperatures
usually protects against
foodborne illness.
49-401163v01 12/6/00 5:46 PM Page 5
Make sure all cookware used
in your microwave oven is
suitable for microwaving.
Most glass casseroles, cooking
dishes, measuring cups,
custard cups, pottery or china
dinnerware which does not
have metallic trim or glaze
with a metallic sheen can be
used. Some cookware is
labeled “suitable for
microwaving.”
■If you are not sure if a dish
is microwave-safe, use this
test: Place in the oven both
the dish you are testing and
a glass measuring cup filled
with 1 cup of water—set the
measuring cup either in or
next to the dish. Microwave
30–45 seconds at high. If
the dish heats, it should not
be used for microwaving.
If the dish remains cool
and only the water in the
cup heats, then the dish is
microwave-safe.
■If you use a meat
thermometer while cooking,
make sure it is safe for use in
microwave ovens.
■Do not use recycled paper
products. Recycled paper
towels, napkins and waxed
paper can contain metal
flecks which may cause
arcing or ignite. Paper
products containing nylon
or nylon filaments should
be avoided, as they may
also ignite.
■Some styrofoam trays (like
those that meat is packaged
on) have a thin strip of
metal embedded in the
bottom. When microwaved,
the metal can burn the
floor of the oven or ignite
a paper towel.
■Do not use the microwave
to dry newspapers.
■Not all plastic wrap is
suitable for use in microwave
ovens. Check the package
for proper use.
■Paper towels, waxed paper
and plastic wrap can be
used to cover dishes in
order to retain moisture
and prevent spattering.
Be sure to vent plastic wrap
so steam can escape.
■Cookware may become hot
because of heat transferred
from the heated food. Pot
holders may be needed to
handle the cookware.
MICROWAVE-SAFE COOKWARE
Safety InformationOperating InstructionsTroubleshooting TipsConsumer Support
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
6
WARNING!
49-401163v01 12/6/00 5:46 PM Page 6
www.GEAppliances.com
7
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
■“Boilable” cooking pouches
and tightly closed plastic
bags should be slit, pierced
or vented as directed by
package. If they are not,
plastic could burst during
or immediately after
cooking, possibly resulting
in injury. Also, plastic
storage containers should
be at least partially
uncovered because they
form a tight seal. When
cooking with containers
tightly covered with plastic
wrap, remove covering
carefully and direct steam
away from hands and face.
■Use foil only as directed in
this manual. TV dinners
may be microwaved in foil
trays less than 3/4″high;
remove the top foil cover
and return the tray to the
box. When using foil in the
microwave oven, keep the
foil at least 1″away from
the sides of the oven.
■Plastic cookware—Plastic
cookware designed for
microwave cooking is very
useful, but should be used
carefully. Even microwave-
safe plastic may not be as
tolerant of overcooking
conditions as are glass or
ceramic materials and may
soften or char if subjected
to short periods of
overcooking. In longer
exposures to overcooking,
the food and cookware
could ignite.
Follow these guidelines:
Use microwave-safe
plastics only and
use
them in strict
compliance
with
the cookware
manufacturer’s
recommendations.
Do not microwave
empty containers.
Do not permit children
to use plastic cookware
without complete
supervision.
3
2
1
49-401163v01 12/6/00 5:46 PM Page 7
This appliance must be grounded. In the event of an electrical
short circuit, grounding reduces the risk of electric shock by
providing an escape wire for the electric current.
This appliance is equipped with a power cord having a
grounding wire with a grounding plug. The plug must be
plugged into an outlet that is properly installed and grounded.
Consult a qualified electrician or service technician if the
grounding instructions are not completely understood, or if
doubt exists as to whether the appliance is properly grounded.
If the outlet is a standard 2-prong wall outlet, it is your personal
responsibility and obligation to have it replaced with a properly
grounded 3-prong wall outlet.
Do not under any circumstances cut or remove the third
(ground) prong from the power cord.
Do not use an adapter plug with this appliance.
Do not use an extension cord with this appliance. If the power
cord is too short, have a qualified electrician or service technician
install an outlet near the appliance.
For best operation, plug this appliance into its own electrical
outlet to prevent flickering of lights, blowing of fuse or tripping
of circuit breaker.
GROUNDING INSTRUCTIONS
Safety InformationOperating InstructionsTroubleshooting TipsConsumer Support
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
8
WARNING!
Improper use of the grounding plug can result in a risk of
electric shock.
49-401163v01 12/6/00 5:46 PM Page 8
www.GEAppliances.com
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
9
The fan will operate automatically under certain conditions (see
Automatic Fan feature). Take care to prevent the starting and
spreading of accidental cooking fires while the vent fan is in use.
■Clean the underside of the microwave often. Do not allow
grease to build up on the microwave or the fan filters.
■In the event of a grease fire on the surface units below the
microwave oven, smother a flaming pan on the surface unit
by covering the pan completely with a lid, a cookie sheet or
a flat tray.
■Use care when cleaning the vent fan filters. Corrosive
cleaning agents, such as lye-based oven cleaners, may damage
the filters.
■When preparing flaming foods under the microwave, turn
the fan on.
■Never leave surface units beneath your microwave oven
unattended at high heat settings. Boilovers cause smoking
and greasy spillovers that may ignite and spread if the
microwave vent fan is operating. To minimize automatic fan
operation, use adequate sized cookware and use high heat
on surface units only when necessary.
THE VENT FAN
READ AND FOLLOW THIS SAFETY
INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
49-401163v01 12/6/00 5:46 PM Page 9
