Samsung Electronics Co OTR15M3 Microwave Oven User Manual
Samsung Electronics Co Ltd Microwave Oven Users Manual
Users Manual
Spacemaker Microwave Oven
Owner’s Manual
Models: JVM1540
JNM1541
HVM1540
LVM1540
2
30
Helpful Information
Microwave Terms 30
Care and Cleaning 31
36
If Something Goes Wrong
Before You Call For Service 36
GE Service Numbers 38
Warranty Back Cover
ge.com
10
Important Safety Information
Precautions to Avoid Possible Exposure
to Excessive Microwave Energy 2
Special Notes About Microwaving 5
Operating Instructions
Features of Your Microwave 10
The Controls on Your Microwave 11
Time Cooking 14
Automatic Cooking 20
Other Features 24
Oven Shelf 29
Write the model and serial numbers here:
Model# ______________________________
Serial# ______________________________
Find these numbers on a label inside the oven.
49-40571 v05 9/7/07 11:31 AM Page 1
2
IMPORTANT SAFETY INFORMATION
READ ALL SAFETY
INFORMATION BEFORE USING
FOR YOUR
SAFETY
PRECAUTIONS
TO AVOID
POSSIBLE
EXPOSURE
TO EXCESSIVE
MICROWAVE
ENERGY
For your safety, the information in this manual
must be followed to minimize the risk of fire
or explosion or to prevent property damage,
personal injury or loss of life.
Do Not Attempt
to operate this oven
with the door open
since open-door
operation can result
in harmful exposure
to microwave energy.
It is important not to
defeat or tamper with
the safety interlocks.
Do Not Place any object
between the oven front
face and the door or
allow soil or cleaner
residue to accumulate
on sealing surfaces.
Do Not Operate the oven
if it is damaged. It is
particularly important
that the oven door
close properly and
that there is no
damage to the:
1door (bent),
2hinges and latches
(broken or loosened),
3door seals and sealing
surfaces.
The Oven Should Not
be adjusted or repaired
by anyone except
properly qualified
service personnel.
WARNING!
For your safety, the information in this manual must be followed to minimize the risk of fire or
explosion, electric shock, or to prevent property damage, personal injury, or loss of life.
49-40571 v05 9/7/07 11:31 AM Page 2
3
When using electrical appliances, basic safety precautions should be followed, including
the following:
WARNING
•Read and follow the
specific “Precautions to
Avoid Possible Exposure
to Excessive Microwave
Energy” on page 2.
•This appliance must be
grounded. Connect only
to properly grounded
outlet. See Grounding
Instructions section on
page 9.
•Do not mount this
appliance over a sink.
•Install or locate this
appliance only in
accordance with the
provided Installation
Instructions.
•This over-the-range oven
was designed for use over
ranges no wider than 36″.
It may be installed over
both gas and electric
cooking equipment.
•Do not operate this
appliance if it has a
damaged power cord or
plug, if it is not working
properly, or if it has been
damaged or dropped.
If the power cord is
damaged, it must be
replaced by General
Electric Service or an
authorized service agent
using a power cord from
General Electric.
•Do not cover or block
any openings on the
appliance.
•Use this appliance only
for its intended use as
described in this manual.
Do not use corrosive
chemicals or vapors in
this appliance. This
microwave oven is
specifically designed to
heat, dry or cook food,
and is not intended
for laboratory or
industrial use.
This microwave oven is
intended for household
use and is UL listed for
installation over electric
and gas ranges.
This microwave oven is
not approved or tested
for marine use.
SAFETY
PRECAUTIONS
49-40571 v05 9/7/07 11:31 AM Page 3
•Do not store this appliance
outdoors. Do not use this
product near water—
for example, in a wet
basement, near a
swimming pool, near a
sink or in similar locations.
•Keep power cord away
from heated surfaces.
•Do not immerse power
cord or plug in water.
•To reduce the risk of fire
in the oven cavity:
— Do not overcook
food. Carefully attend
appliance when paper,
plastic or other
combustible materials
are placed inside the
oven while cooking.
— Remove wire twist-ties
and metal handles
from paper or plastic
containers before placing
them in the oven.
— Do not use the oven
for storage purposes.
Do not leave paper
products, cooking
utensils or food in the
oven when not in use.
— If materials inside oven
ignite, keep the oven
door closed, turn the
oven off and disconnect
the power cord, or shut
off power at the fuse or
circuit breaker panel.
If the door is opened,
the fire may spread.
— Do not use the
Sensor Features twice in
succession on the same
food portion. If food is
under cooked after the
first countdown, use
Time Cook for additional
cooking time.
•See door surface cleaning
instructions in the Care
and Cleaning section(s)
of this manual.
•This appliance must only
be serviced by qualified
service personnel. Contact
nearest authorized service
facility for examination,
repair or adjustment.
•As with any appliance,
close supervision is
necessary when used
by children.
• Do not store anything
directly on top of the
microwave oven surface
when the microwave oven
is in operation.
SAVE THESE INSTRUCTIONS
4
IMPORTANT SAFETY INFORMATION
READ ALL SAFETY
INFORMATION BEFORE USING
49-40571 v05 9/7/07 11:31 AM Page 4
SPECIAL NOTES ABOUT MICROWAVING
Arcing is the microwave
term for sparks in the
oven. Arcing is caused by:
•The metal shelf (if
included) not installed
correctly so it touches the
microwave wall.
•The temperature probe
(if included) in the
microwave but not
inserted in the food.
•Metal or foil touching
the side of the oven.
•Foil not molded to food
(upturned edges act like
antennas).
•Metal, such as twist-ties,
poultry pins or gold-
rimmed dishes, in the
microwave.
•Recycled paper towels
containing small metal
pieces being used in the
microwave.
If you see arcing, press
the CLEAR/OFF pad and
correct the problem.
ARCING
•Do not pop popcorn in
your microwave oven
unless in a special
microwave popcorn
accessory or unless you
use popcorn labeled for
use in microwave ovens.
•Some products such as
whole eggs and sealed
containers—for example,
closed jars—are able to
explode and should not
be heated in this
microwave oven. Such use
of the microwave oven
could result in injury.
•Do not boil eggs in a
microwave oven. Pressure
will build up inside egg
yolk and will cause it to
burst, possibly resulting
in injury.
•Operating the microwave
with no food inside for
more than a minute or
two may cause damage
to the oven and could
start a fire. It increases
the heat around the
magnetron and can
shorten the life of
the oven.
•Foods with unbroken
outer “skin” such as
potatoes, hot dogs,
sausages, tomatoes,
apples, chicken livers
and other giblets, and
egg yolks should be
pierced to allow steam
to escape during
cooking.
FOODS
5
49-40571 v05 9/7/07 11:31 AM Page 5
SAFETY FACT
SUPERHEATED WATER
Liquids, such as water,
coffee or tea, are able to
be overheated beyond
the boiling point without
appearing to be boiling.
Visible bubbling or boiling
when the container is
removed from the microwave
oven is not always present.
THIS COULD RESULT
IN VERY HOT LIQUIDS
SUDDENLY BOILING OVER
WHEN THE CONTAINER IS
DISTURBED OR A SPOON
OR OTHER UTENSIL IS
INSERTED INTO THE LIQUID.
To reduce the risk of injury
to persons:
— Do not overheat the
liquid.
— Stir the liquid both
before and halfway
through heating it.
— Do not use straight-
sided containers with
narrow necks.
— After heating, allow the
container to stand in
the microwave oven for
a short time before
removing the container.
— Use extreme care when
inserting a spoon or
other utensil into the
container.
•Avoid heating baby food
in glass jars, even with the
lid off. Make sure all
infant food is thoroughly
cooked. Stir food to
distribute the heat evenly.
Be careful to prevent
scalding when warming
formula or breast milk.
The container may feel
cooler than the milk really
is. Always test the milk
before feeding the baby.
•Don’t defrost frozen
beverages in narrow-
necked bottles (especially
carbonated beverages).
Even if the container is
opened, pressure can
build up. This can cause
the container to burst,
possibly resulting in
injury.
•Hot foods and steam
can cause burns. Be
careful when opening
any containers of hot
food, including popcorn
bags, cooking pouches
and boxes. To prevent
possible injury, direct
steam away from hands
and face.
•Do not overcook
potatoes. They could
dehydrate and catch
fire, causing damage
to your oven.
•Cook meat and poultry
thoroughly—meat to
at least an INTERNAL
temperature of 160°F
and poultry to at least an
INTERNAL temperature
of 180°F. Cooking to
these temperatures
usually protects against
foodborne illness.
IMPORTANT SAFETY INFORMATION
SPECIAL NOTES ABOUT MICROWAVING
6
49-40571 v05 9/7/07 11:31 AM Page 6
7
Make sure all cookware
used in your microwave
oven is suitable for
microwaving. Most glass
casseroles, cooking dishes,
measuring cups, custard
cups, pottery or china
dinnerware which does not
have metallic trim or glaze
with a metallic sheen can
be used. Some cookware
is labeled “suitable for
microwaving.”
•If you are not sure if
a dish is microwave-safe,
use this test: Place in the
oven both the dish you
are testing and a glass
measuring cup filled with
1 cup of water—set the
measuring cup either
in or next to the dish.
Microwave 30–45 seconds
at high. If the dish heats,
it should not be used for
microwaving.
If the dish remains cool
and only the water in the
cup heats, then the dish
is microwave-safe.
•If you use a meat
thermometer while
cooking, make sure it is
safe for use in microwave
ovens.
•Do not use recycled
paper products. Recycled
paper towels, napkins
and waxed paper can
contain metal flecks
which may cause arcing
or ignite. Paper products
containing nylon or
nylon filaments should
be avoided, as they may
also ignite.
•Some styrofoam trays
(like those that meat is
packaged on) have a thin
strip of metal embedded
in the bottom. When
microwaved, the metal can
burn the floor of the oven
or ignite a paper towel.
•Do not use the microwave
to dry newspapers.
•Not all plastic wrap
is suitable for use in
microwave ovens.
Check the package
for proper use.
•Paper towels, waxed
paper and plastic wrap
can be used to cover
dishes in order to retain
moisture and prevent
spattering. Be sure to
vent plastic wrap so
steam can escape.
•Cookware may become
hot because of heat
transferred from the
heated food. Pot holders
may be needed to handle
the cookware.
•“Boilable” cooking
pouches and tightly
closed plastic bags should
be slit, pierced or vented
as directed by package.
If they are not, plastic
could burst during or
immediately after
cooking, possibly resulting
in injury. Also, plastic
storage containers should
be at least partially
uncovered because they
form a tight seal. When
cooking with containers
tightly covered with
plastic wrap, remove
covering carefully and
direct steam away from
hands and face.
MICROWAVE-
SAFE
COOKWARE
How to test for a microwave-
safe dish.
49-40571 v05 9/7/07 11:31 AM Page 7
•Use foil only as directed in
this manual. When using
foil in the microwave
oven, keep the foil at least
1″away from the sides of
the oven.
•Plastic cookware—Plastic
cookware designed for
microwave cooking is very
useful, but should be used
carefully. Even microwave-
safe plastic may not be as
tolerant of overcooking
conditions as are glass or
ceramic materials and
may soften or char if
subjected to short periods
of overcooking. In longer
exposures to overcooking,
the food and cookware
could ignite.
Follow these guidelines:
1Use microwave-safe
plastics only and use
them in strict compliance
with the cookware
manufacturer’s
recommendations.
2Do not microwave empty
containers.
3Do not permit children
to use plastic cookware
without complete
supervision.
The fan will operate
automatically under
certain conditions (see
Automatic Fan feature).
Take care to prevent the
starting and spreading of
accidental cooking fires
while the vent fan is in use.
•Clean the underside of
the microwave often.
Do not allow grease
to build up on the
microwave or the
fan filter.
•In the event of a grease
fire on the surface units
below the microwave
oven, smother a flaming
pan on the surface unit
by covering the pan
completely with a lid, a
cookie sheet or a flat tray.
•Use care when cleaning
the vent fan filter.
Corrosive cleaning
agents, such as lye-based
oven cleaners, may
damage the filter.
•When preparing
flaming foods under
the microwave, turn the
vent fan on.
•Never leave surface units
beneath your microwave
oven unattended at high
heat settings. Boilovers
cause smoking and greasy
spillovers that may ignite
and spread if the
microwave vent fan is
operating. To minimize
automatic fan operation,
use adequate sized
cookware and use high
heat on surface units
only when necessary.
THE VENT
FAN
IMPORTANT SAFETY INFORMATION
SPECIAL NOTES ABOUT MICROWAVING
8
49-40571 v05 9/7/07 11:31 AM Page 8
GROUNDING INSTRUCTIONS/OPTIONAL KITS
WARNING
Improper use of the
grounding plug can result
in a risk of electric shock.
This appliance must be
grounded. In the event of
an electrical short circuit,
grounding reduces the
risk of electric shock by
providing an escape wire
for the electric current.
This appliance is equipped
with a power cord having
a grounding wire with a
grounding plug. The plug
must be plugged into an
outlet that is properly
installed and grounded.
Consult a qualified
electrician or service
technician if the grounding
instructions are not
completely understood,
or if doubt exists as to
whether the appliance is
properly grounded.
If the outlet is a standard
2-prong wall outlet, it is
your personal responsibility
and obligation to have it
replaced with a properly
grounded 3-prong wall
outlet.
Do not, under any
circumstances, cut or
remove the third (ground)
prong from the power cord.
Do not use an adapter plug
with this appliance.
Do not use an extension
cord with this appliance.
If the power cord is too
short, have a qualified
electrician or service
technician install an outlet
near the appliance.
For best operation, plug
this appliance into its own
electrical outlet to prevent
flickering of lights, blowing
of fuse or tripping of circuit
breaker.
GROUNDING
INSTRUCTIONS
Ensure proper ground
exists before use.
9
Filler Panel Kits
JX48WH—White
JX48BL—Black
When replacing a 36″
range hood, filler panel
kits fill in the additional
width to provide a custom
built-in appearance.
For installation between
cabinets only; not for
end-of-cabinet installation.
Each kit contains two
3″-wide filler panels.
JX81A— Recirculating
Charcoal Filter Kit
Filter kits are used when
the microwave oven cannot
be vented to the outside.
Available at extra cost from
your GE supplier, or see
GE Service Numbers.
Optional Kits
JX81A
JX48
49-40571 v05 9/7/07 11:31 AM Page 9
Operating Instructions
Features of Your Microwave
(Throughout this manual, features and appearance
may vary from your model.)
1 Door Handle. Pull to
open the door. The
door must be securely
latched for the
microwave to operate.
2 Door Latches.
3 Window with Metal
Shield. Screen allows
cooking to be viewed
while keeping
microwaves confined
in the oven.
4 Touch Control Panel.
5 Cooktop Light.
6 Grease Filter.
7 Removable Turntable.
Turntable and support
must be in place
when using the oven.
The turntable may be
removed for cleaning.
8 Convenience Guide.
9 Shelf (on some models).
Lets you microwave
several foods at once.
Food microwaves best
when placed directly
on the turntable.
10 Rating Plate. Located
on the inside wall of
the microwave oven.
Features
321
4
10
9
5
87
6
10
49-40571 v05 9/7/07 11:31 AM Page 10
11
Time Features
Time Cooking
Press Enter
TIME COOK I & II (Press once or twice) Amount of cooking time.
DEFROST AUTO/TIME (Press twice) Amount of defrosting time.
EXPRESS COOK Starts immediately!
POWER LEVEL Power level 1–10.
ADD 30 SEC Starts immediately!
Quick Start
The Controls on Your Microwave Oven
(Throughout this manual, features and appearance may vary from your model.)
1
You can microwave
by time, temperature
or with the
convenience
features.
49-40571 v05 9/7/07 11:31 AM Page 11
Convenience Features
Press Enter Option
COOK (on some models) Food type 1–9 + weight
POPCORN Starts immediately! more/less time
serving size
REHEAT (See Reheat Guide) serving size
BEVERAGE Starts immediately! serving size
POTATO Starts immediately! serving size
VEGETABLE (on some models) Food type 1–3 + weight
DEFROST AUTO/TIME Food weight
(Press once)
2
GUIDE ON MICROWAVE
Before you begin, check
the guide located on the
inside front of the oven
when you open the door.
GUIDES IN BOOK
•Cooking
•Time Defrost
•Reheat
12
Quick Start
49-40571 v05 9/7/07 11:31 AM Page 12
13
Operating Instructions
Variable power levels add
flexibility to microwave
cooking. The power levels
on the microwave oven
can be compared to the
surface units on a range.
High (power level 10) or
full power is the fastest way
to cook and gives you
100% power. Each power
level gives you microwave
energy a certain percent of
the time. Power level 7 is
microwave energy 70% of
the time. Power level 3 is
energy 30% of the time.
A high setting (10) will
cook faster but food may
need more frequent
stirring, rotating or turning
over. Most cooking will be
done on High (power level
10). A lower setting will
cook more evenly and need
less stirring or rotating of
the food.
Some foods may have
better flavor, texture or
appearance if one of the
lower settings is used. Use
a lower power level when
cooking foods that have a
tendency to boil over, such
as scalloped potatoes.
Rest periods (when the
microwave energy cycles
off) give time for the food
to “equalize” or transfer
heat to the inside of the
food. An example of this
is shown with power level
3—the defrost cycle. If
microwave energy did not
cycle off, the outside of the
food would cook before
the inside was defrosted.
Here are some examples
of uses for various power
levels:
Power Level Best Uses
High 10 Fish, bacon,
vegetables,
boiling liquids.
Med-High 7 Gentle
cooking of
meat and
poultry;
baking
casseroles
and reheating.
Medium 5 Slow cooking
and tenderizing
such as stews
and less tender
cuts of meat.
Low 2 or 3 Defrosting
without
cooking;
simmering;
delicate sauces.
Warm 1 Keeping food
warm without
overcooking;
softening
butter.
How to Change the
Power Level
The power level may be
entered or changed
immediately after
entering the feature
time for TIME COOK,
TIME DEFROST or
EXPRESS COOK. The
power level may also be
changed during time
countdown.
1 Press TIME COOK or
select Time Defrost.
2 Enter cooking or
defrosting time.
3 Press POWER LEVEL.
4 Select desired power
level 1–10.
5 Press START.
Changing Power
Levels
49-40571 v05 9/7/07 11:31 AM Page 13
Time Cook I
Allows you to microwave
for any time up to 99
minutes and 99 seconds.
Power level 10 (High)
is automatically set, but
you may change it for
more flexibility.
You may open the door
during Time Cook to
check the food. Close the
door and press START
to resume cooking.
Time Cook II
Lets you change power
levels automatically during
cooking. Here’s how to
do it:
1Press TIME COOK.
2Enter the first cook time.
3Change the power level
if you don’t want full
power. (Press POWER
LEVEL. Select a desired
power level 1–10.)
4Press TIME COOK
again.
5Enter the second cook
time.
6Change the power level
if you don’t want full
power. (Press POWER
LEVEL. Select a power
level 1–10.)
7Press START.
At the end of Time Cook I,
Time Cook II counts down.
1 Press TIME COOK.
2 Enter cooking time.
3 Change power level
if you don’t want full
power. (Press POWER
LEVEL. Select a
desired power level
1–10.)
4 Press START.
Time Cook
Operating Instructions
Time Features
14
49-40571 v05 9/7/07 11:31 AM Page 14
15
Cooking Guide for Time Cook I &II
NOTE: Use power level High (10) unless otherwise noted.
Vegetable Amount Time Comments
Asparagus
(fresh spears) 1 lb. 6 to 9 min., In 1
1
⁄
2
-qt. oblong glass baking dish,
Med-High (7) place 1/4 cup water.
(frozen spears) 10-oz. package 5 to 7 min. In 1-qt. casserole.
Beans
(fresh green) 1 lb. cut in half 9 to 11 min. In 1
1
⁄
2
-qt. casserole, place 1/2 cup water.
(frozen green) 10-oz. package 6 to 8 min. In 1-qt. casserole, place 2 tablespoons
water.
(frozen lima) 10-oz. package 6 to 8 min. In 1-qt. casserole, place 1/4 cup water.
Beets
(fresh, whole) 1 bunch 17 to 21 min. In 2-qt. casserole, place 1/2 cup water.
Broccoli
(fresh cut) 1 bunch 7 to 10 min. In 2-qt. casserole, place 1/2 cup water.
(1
1
⁄
4
to 1
1
⁄
2
lbs.)
(fresh spears) 1 bunch 9 to 13 min. In 2-qt. oblong glass baking dish, place
(1
1
⁄
4
to 1
1
⁄
2
lbs.) 1/4 cup water.
(frozen, 10-oz. package 5 to 7 min. In 1-qt. casserole.
chopped)
(frozen spears) 10-oz. package 5 to 7 min. In 1-qt. casserole, place 3 tablespoons
water.
Cabbage
(fresh) 1 medium head 8 to 11 min. In 1
1
⁄
2
- or 2-qt. casserole, place 1/4 cup
(about 2 lbs.) water.
(wedges) 7 to 10 min. In 2- or 3-qt. casserole, place 1/4 cup
water.
Carrots
(fresh, sliced) 1 lb. 7 to 9 min. In 1
1
⁄
2
-qt. casserole, place 1/4 cup water.
(frozen) 10-oz. package 5 to 7 min. In 1-qt. casserole, place 2 tablespoons
water.
Cauliflower
(flowerets) 1 medium head 9 to 14 min. In 2-qt. casserole, place 1/2 cup water.
(fresh, whole) 1 medium head 10 to 17 min. In 2-qt. casserole, place 1/2 cup water.
(frozen) 10-oz. package 5 to 7 min. In 1-qt. casserole, place 2 tablespoons
water.
49-40571 v05 9/7/07 11:31 AM Page 15
Vegetable Amount Time Comments
Corn
(frozen kernel) 10-oz. package 5 to 7 min. In 1-qt. casserole, place 2 tablespoons
water.
Corn on the cob
(fresh) 1 to 5 ears 3 to 4 min. In 2-qt. oblong glass baking dish, place
per ear corn. If corn is in husk, use no water;
if corn has been husked, add 1/4 cup
water. Rearrange after half of time.
(frozen) 1 ear 5 to 6 min. Place in 2-qt. oblong glass baking dish.
2 to 6 ears 3 to 4 min. Cover with vented plastic wrap.
per ear Rearrange after half of time.
Mixed
vegetables
(frozen) 10-oz. package 5 to 7 min. In 1-qt. casserole, place 3 tablespoons
water.
Peas
(fresh, shelled) 2 lbs. unshelled
9 to 12 min.
In 1-qt. casserole, place 1/4 cup water.
(frozen) 10-oz. package 5 to 7 min. In 1-qt. casserole, place 2 tablespoons
water.
Potatoes
(fresh, cubed, 4 potatoes
9 to 12 min.
Peel and cut into 1 inch cubes. Place
white) (6 to 8 oz. each) in 2-qt. casserole with 1/2 cup water.
Stir after half of time.
(fresh, whole, 1 (6 to 8 oz.) 3 to 4 min. Pierce with cooking fork. Place in
sweet or white) center of the oven. Let stand 5 minutes.
Spinach
(fresh) 10 to 16 oz. 5 to 7 min. In 2-qt. casserole, place washed spinach.
(frozen, 10-oz. package 5 to 7 min. In 1-qt. casserole, place 3 tablespoons
chopped water.
and leaf)
Squash
(fresh, summer 1 lb. sliced 5 to 7 min. In 11⁄2-qt. casserole, place 1/4 cup water.
and yellow)
(winter, acorn, 1 to 2 squash 8 to 11 min. Cut in half and remove fibrous
butternut)
(about 1 lb. each)
membranes. In 2-qt. oblong glass
baking dish, place squash cut-side-
down. Turn cut-side-up after 4 minutes.
16
Operating Instructions
Cooking Guide for Time Cook I &II
49-40571 v05 9/7/07 11:31 AM Page 16
17
Time Features
Allows you to defrost for the
length of time you select.
See the Defrosting Guide
for suggested times.
Power level 3 is
automatically set, but
you may change this for
more flexibility. You may
defrost small items more
quickly by raising the power
level after entering the time.
However, they will need
more frequent attention
than usual.
Power level 7 cuts the total
defrosting time in about
half; power level 10 cuts the
total time to approximately
1/3. Rotate or stir food
frequently.
At one half of selected
defrosting time, the oven
signals TURN. At this time,
turn food over and break
apart or rearrange pieces
for more even defrosting.
Shield any warm areas with
small pieces of foil.
A dull thumping noise may
be heard during defrosting.
This sound is normal when
the oven is not operating at
High power.
Defrosting Tips
•Foods frozen in paper or
plastic can be defrosted in
the package. Tightly closed
packages should be slit,
pierced or vented AFTER
food has partially
defrosted. Plastic storage
containers should be at
least partially uncovered.
•Family-size, prepackaged
frozen dinners can be
defrosted and microwaved.
If the food is in a foil
container, transfer it
to a microwave-safe dish.
•Foods that spoil easily, such
as milk, eggs, fish, stuffings,
poultry and pork, should
not be allowed to sit out
for more than one hour
after defrosting. Room
temperature promotes
the growth of harmful
bacteria.
•For more even defrosting
of larger foods, such as
beef, lamb and veal roasts,
use Auto Defrost.
•Be sure large meats are
completely defrosted
before cooking.
•When defrosted, food
should be cool but
softened in all areas. If still
slightly icy, return to the
microwave very briefly, or
let it stand a few minutes.
1 Press DEFROST
AUTO/TIME twice.
2 Enter defrosting time.
3 Press START.
4 Turn food over when
the oven signals.
5 Press START.
(Auto Defrost explained
in the section on
Convenience Features.)
Time Defrost
49-40571 v05 9/7/07 11:31 AM Page 17
Food Time Comments
Breads, Cakes
Bread, buns or rolls (1 piece) 1 min.
Sweet rolls (approx. 12 oz.) 3 to 5 min.
Fish and Seafood
Fillets, frozen (1 lb.) 6 to 8 min.
Shellfish, small pieces (1 lb.) 5 to 7 min. Place block in casserole. Turn over and
break up after half the time.
Fruit
Plastic pouch—1 to 2 3 to 6 min.
(10-oz. package)
Meat
Bacon (1 lb.) 2 to 5 min. Place unopened package in oven.
Let stand 5 minutes after defrosting.
Franks (1 lb.) 2 to 5 min. Place unopened package in oven.
Microwave just until franks can be
separated. Let stand 5 minutes,
if necessary, to complete defrosting.
Ground meat (1 lb.) 5 to 7 min. Turn meat over after half the time.
Roast: beef, lamb, veal, pork 12 to 16 min. Use power level 1.
per lb.
Steaks, chops and cutlets 5 to 7 min. Place unwrapped meat in cooking dish.
per lb. Turn over after half the time and shield
warm areas with foil. When finished,
separate pieces and let stand to complete
defrosting.
Poultry
Chicken, broiler-fryer 15 to 19 min. Place wrapped chicken in dish. Unwrap
cut up (21⁄2to 3 lbs.) and turn over after half the time. When
finished, separate pieces and microwave
2–4 minutes more, if necessary. Let stand
to finish defrosting.
Chicken, whole 17 to 21 min. Place wrapped chicken in dish. After half
(21⁄2to 3 lbs.) the time, unwrap and turn chicken over.
Shield warm areas with foil. Finish
defrosting. If necessary, run cold water in
the cavity until giblets can be removed.
Cornish hen 7 to 13 min. Place unwrapped hen in the oven breast-
per lb. side-up. Turn over after half the time.
Run cool water in the cavity until giblets
can be removed.
Turkey breast (4 to 6 lbs.) 5 to 9 min. Place unwrapped breast in dish breast-
per lb. side-down. After half the time, turn over
and shield warm areas with foil. Finish
defrosting. Let stand 1–2 hours in
refrigerator to complete defrosting.
Operating Instructions
Defrosting Guide
18
49-40571 v05 9/7/07 11:31 AM Page 18
Time Features
19
You can use this feature
two ways:
•It will add 30 seconds to
the time counting down
each time the pad is
pressed.
•It can be used as a quick
way to set 30 seconds of
cooking time.
Add 30 Seconds
This is a quick way to set
cooking time for 1–6 minutes.
Press one of the Express
Cook pads (from 1 to 6)
for 1 to 6 minutes of
cooking at power level 10.
For example, press the
2 pad for 2 minutes of
cooking time.
The power level can
be changed as time is
counting down. Press
POWER LEVEL and
enter 1–10.
Express Cook
49-40571 v05 9/7/07 11:31 AM Page 19
Operating Instructions
Convenience Features
20
The Cook feature
automatically sets the
cooking times and power
levels for a variety of foods.
1Press COOK.
2Select food type 1–9 (see
the Cook Guide below).
3Enter weight in ounces.
4Press START.
Hint: Press and hold the
COOK pad during cooking
to display the food type
and remaining cook time.
Cook (On some models)
1 Canned Vegetables 4 to 20 oz. Use microwave-safe casserole or bowl.
Cover with lid or vented plastic wrap.
2 Frozen Vegetables 4 to 20 oz. Use microwave-safe casserole or bowl.
Follow package instructions for adding
water. Cover with lid or vented
plastic wrap.
3 Fresh Vegetables 4 to 16 oz. Use microwave-safe casserole or bowl.
Add 2 tablespoons water for each serving.
Cover with lid or vented plastic wrap.
4 Potatoes 8 to 40 oz. Pierce skin with fork. Place potatoes on
oven floor or turntable.
5Fish 4 to 16 oz. Use oblong, square or round dish. Cover
with vented plastic wrap or wax paper.
6 Chicken Pieces 4 to 40 oz. Use oblong, square or round dish. Cover
with vented plastic wrap.
7 Ground Meat 8 to 48 oz. Use round casserole dish. Crumble meat
(beef, pork, turkey)
into dish. Cover with lid or vented plastic
wrap. Drain and stir at signal.
8 Bacon 2 to 10 oz. Layer strips on a plate, 4 to a layer.
Cover each layer with a paper towel.
9 Pizza 4 to 16 oz. Follow package instructions to prepare
(frozen, microwaveable) pizza for microwaving.
Food Type Weight Comments
Cook Guide
49-40571 v05 9/7/07 11:31 AM Page 20
Convenience Features
21
How to Use the Popcorn
Feature
1Follow package
instructions, using Time
Cook if the package is
less than 3.0 ounces or
larger than 3.5 ounces.
Place the package of
popcorn in the center
of the microwave.
2Press POPCORN. The
oven starts immediately.
Tap POPCORN to select
the bag size you are
cooking.
Popcorn
NOTE: Do not use the metal
shelf when cooking popcorn.
The Reheat feature reheats
servings of many previously
cooked foods.
1Press REHEAT.
2Select food type 1–6 for
one serving (see Reheat
Guide below). On some
models, the oven starts
immediately.
3On some models, press
START.
4Press 2 or 3 to change the
serving size.
NOTE: The serving size may
be changed or added after
the oven starts. Press
number pad 2 or 3. On some
models, the serving size
for food type 6 cannot be
changed.
Reheat
1 Pasta Cover with lid or vented plastic wrap.
2 Meats Cover with lid or vented plastic wrap.
3 Veggies Cover with lid or vented plastic wrap.
4 Beverages Works best with wide mouth mug—do not cover.
5 Sauces Cover with lid or vented plastic wrap.
6 Plate of leftovers Cover with vented plastic wrap.
Food Type Comments
Reheat Guide
NOTE: Do not use the metal
shelf when using the Reheat
feature.
Use only with
prepackaged microwave
popcorn weighing
3.0 to 3.5 ounces.
49-40571 v05 9/7/07 11:31 AM Page 21
22
Operating Instructions
Convenience Features
The Potato feature cooks
up to four 8–10 ounce
potatoes.
Press POTATO once for
one potato, twice for two
potatoes, three times for
three potatoes and four
times for four potatoes.
The oven will start
immediately after
POTATO is pressed.
Potato
The Vegetable feature
automatically sets the
cooking times and power
levels to cook fresh, frozen
or canned vegetables.
1Press VEGETABLE.
“Select Veggie type 1–3”
will be displayed.
2Select food type 1–3
(see chart below).
3Enter weight in ounces
(see chart below).
4Press START.
Vegetable (on some models)
The Beverage feature heats
servings of any beverage.
Press BEVERAGE. The
oven starts immediately.
On some models, the serving
size is automatically set at
1, but can be changed by
pressing 2 or 3 right after
pressing BEVERAGE.
Drinks heated with the
Beverage feature may be
very hot. Remove the
container with care.
Beverage
Code Food Weight
1Canned 4–20 oz.
2Frozen 4–20 oz.
3Fresh 4–16 oz.
49-40571 v05 9/7/07 11:32 AM Page 22
Convenience Features
23
Auto Defrost
The Defrost Auto/Time
feature gives you two ways
to defrost frozen foods.
Press DEFROST
AUTO/TIME once for
Auto Defrost or twice for
Time Defrost.
Use Auto Defrost for meat,
poultry and fish. Use Time
Defrost for most other
frozen foods.
Auto Defrost automatically
sets the defrosting times
and power levels to give
even defrosting results for
meats, poultry and fish
weighing up to six pounds.
There is a handy guide
located on the inside front
of the oven.
•Remove meat from
package and place on
microwave-safe dish.
•Twice during defrost,
the oven signals TURN.
At each TURN signal,
turn the food over.
Remove defrosted meat
or shield warm areas with
small pieces of foil.
•After defrosting, most
meats need to stand
5 minutes to complete
defrosting. Large roasts
should stand for about
30 minutes.
Conversion Guide
If the weight of food is
stated in pounds and
ounces, the ounces must
be converted to tenths
(.1) of a pound.
Weight of Enter Food
Food in Weight
Ounces (tenths of
a pound)
1–2 .1
3.2
4–5 .3
6–7 .4
8.5
9–10 .6
11 .7
12–13 .8
14–15 .9
1 Press DEFROST
AUTO/TIME once.
2 Using the Conversion
Guide at right, enter
food weight. For
example, press pads 1
and 2 for 1.2 pounds
(1 pound, 3 ounces).
3 Press START.
(Time Defrost is
explained in the Time
Features section.)
Guide
49-40571 v05 9/7/07 11:32 AM Page 23
To remind you that you
have food in the oven, the
oven will display “FOOD IS
READY” or “END” and
beep once a minute until
you either open the oven
door or press CLEAR/OFF.
Cooking Complete
Reminder
Press to enter the time of
day or to check the time
of day while microwaving.
1Press CLOCK.
2Enter time of day.
3On some models, select
AM or PM.
4Press START or CLOCK.
Clock
Operating Instructions
Other Features Your Model May Have
24
49-40571 v05 9/7/07 11:32 AM Page 24
Other Features Your Model May Have
25
(On some models)
The scroll speed of the
display can be changed.
Press and hold the AM/PM
pad about 3 seconds to
bring up the display.
Select 1–5 for slow to
fast scroll speed.
Scroll Speed
To turn the clock display
off, press and hold 0 for
about three seconds.
To redisplay the clock,
repeat.
Display On/Off
Delay Start allows you to
set the microwave to delay
cooking up to 24 hours.
1Press DELAY START.
2Enter the time you want
the oven to start. (Be
sure the microwave clock
shows the correct time
of day.)
3On some models, select
AM or PM.
4Select any combination
of Defrost Auto/Time
or Time Cook I & II.
5Press START.
The Delay Start time will
be displayed. The oven will
automatically start at the
delayed time.
The time of day may be
displayed by pressing
CLOCK.
Delay Start
49-40571 v05 9/7/07 11:32 AM Page 25
In addition to starting many
functions, START/PAUSE
allows you to stop cooking
without opening the door
or clearing the display.
Start/Pause
The Reminder feature can
be used like an alarm clock
and can be used at any
time, even when the oven is
operating. The Reminder
time can be set up to
24 hours later.
1Press REMINDER.
2Enter the time you want
the oven to remind you.
(Be sure the microwave
clock shows the correct
time of day.)
3On some models, select
AM or PM.
4Press REMINDER. When
Reminder signal occurs,
press REMINDER to turn
it off. The Reminder
time may be displayed by
pressing REMINDER.
NOTE: The REM indicator
will remain lit to show that
the Reminder is set. To
clear the Reminder before
it occurs, press REMINDER,
then 0. The REM indicator
will no longer be lit.
Reminder
Timer On/Off operates as
a minute timer and can be
used at any time, even
when the oven is operating.
1Press TIMER ON/OFF.
2Enter time you want to
count down.
3Press TIMER ON/OFF
to start.
When time is up, the oven
will signal. To turn off the
timer signal, press TIMER
ON/OFF.
NOTE: The timer indicator
will be lit while the timer
is operating.
Timer On/Off
Operating Instructions
Other Features Your Model May Have
26
49-40571 v05 9/7/07 11:32 AM Page 26
Other Features Your Model May Have
27
You may lock the control
panel to prevent the
microwave from being
accidentally started or
used by children.
To lock or unlock the
controls, press and hold
CLEAR/OFF for about
3 seconds. When the
control panel is locked, “L”
or “LOC” will be displayed
to the extreme right.
Child Lock-Out
For best cooking results,
leave the turntable on.
It can be turned off for
large dishes. Press
TURNTABLE to turn
the turntable on or off.
Sometimes the turntable
can become too hot to
touch. Be careful touching
the turntable during and
after cooking.
Turntable
Press to turn the surface
light on or off.
On some models, there is
a night light option.
Press SURFACE LIGHT
once for bright light, twice
for the night light or three
times to turn the light off.
Surface Light
49-40571 v05 9/7/07 11:32 AM Page 27
When the microwave oven
is off, you may operate the
vent fan:
1Press the Vent Fan pad
once for high fan speed.
2Press the Vent Fan pad a
second time for low fan
speed.
3Press the Vent Fan pad
a third time to turn the
fan off.
When the microwave
is on, the vent fan will
automatically turn on at
low fan speed, stay on while
the microwave is operating
and automatically turn off
after the microwave goes
off if the Vent Fan pad is
not pressed.
When the microwave oven
is on you may also:
1Press the Vent Fan pad
once for high fan speed.
2Press the Vent Fan pad a
second time for low fan
speed.
3Press the Vent Fan pad
a third time to set the fan
to turn off automatically
after the microwave
goes off.
If the vent fan is still
operating after the
microwave goes off, press
the Vent Fan pad until it
turns off.
NOTE: The vent fan cannot
be turned off while the
microwave is operating.
Vent Fan
Operating Instructions
Other Features Your Model May Have
28
49-40571 v05 9/7/07 11:32 AM Page 28
Other Features Your Model May Have
29
How to Use the Shelf
When Microwaving
Food microwaves best
when placed on the
turntable or on the shelf
in the lower position.
NOTE: Only use the shelf
when reheating on more than
one level. Do not store the
shelf inside the oven cavity.
Use the lower shelf
supports when cooking one
oblong or oversized dish.
Use the upper shelf
supports for two-level
cooking.
Shelf and Reheating
•To reheat on 2 levels
or
•To reheat 2 dishes on the
lower level:
1Multiply reheat time
by 11
/2.
2Switch places after 1/2
the time.
• To reheat on 3 levels
(on some models)
1Double the reheating
time.
2Switch places twice and
give the dishes a 1/2 turn
during reheating. (Place
dense foods, or those
that require a longer
cook time, on the
upper shelf first.)
•Make sure the shelf is
positioned properly
inside the microwave
to prevent damage to
the oven from arcing.
•Do not use a
microwave browning
dish on the shelf.
The shelf could
overheat.
•Do not use the oven
with the shelf on the
microwave floor. This
could damage the
microwave.
•Use pot holders when
handling the shelf—
it may be hot.
•Do not use the shelf
when cooking
popcorn.
For best results
Uneven results
2-level reheating
Shelf (on some models)
Switch places after 1/2 time.
Switch places after 1/2 time.
Switch places twice
49-40571 v05 9/7/07 11:32 AM Page 29
30
Helpful Information
Microwave Terms
Arcing Arcing is the microwave term for sparks in the oven. Arcing is
caused by:
•the metal shelf being installed incorrectly and touching the
microwave walls.
•metal or foil touching the side of the oven.
•foil that is not molded to food (upturned edges act like
antennas).
•metal such as twist ties, poultry pins, gold-rimmed dishes.
•recycled paper towels containing small metal pieces.
Covering Covers hold in moisture, allow for more even heating and reduce
cooking time. Venting plastic wrap or covering with wax paper
allows excess steam to escape.
Shielding In a regular oven, you shield chicken breasts or baked foods to
prevent over-browning. When microwaving, you use small strips
of foil to shield thin parts, such as the tips of wings and legs on
poultry, which would cook before larger parts.
Standing Time When you cook with regular ovens, foods such as roasts or cakes
are allowed to stand to finish cooking or to set. Standing time is
especially important in microwave cooking. Note that a microwaved
cake is not placed on a cooling rack.
Venting After covering a dish with plastic wrap, you vent the plastic wrap by
turning back one corner so excess steam can escape.
Term Definition
49-40571 v05 9/7/07 11:32 AM Page 30
31
Care and Cleaning
An occasional thorough
wiping with a solution of
baking soda and water
keeps the inside fresh.
NOTE: Be certain the power
is off before cleaning any
part of this oven.
Helpful Hints
Walls, Floor, Inside Window,
Metal and Plastic Parts on
the Door
Some spatters can be
removed with a paper
towel, others may require
a damp cloth. Remove
greasy spatters with a sudsy
cloth, then rinse with a
damp cloth. Do not use
abrasive cleaners or sharp
utensils on oven walls.
Never use a commercial
oven cleaner on any part
of your microwave.
Temperature Probe
(if included)
Clean immediately after
using. To clean, wipe with
a sudsy cloth, then rub
lightly with a plastic
scouring ball if necessary.
Rinse and dry. The probe
can also be washed in the
dishwasher.
Removable Turntable and
Turntable Support
To prevent breakage,
do not place the turntable
into water just after
cooking. Wash it carefully
in warm, sudsy water or
in the dishwasher. The
turntable and support
can be broken if dropped.
Remember, do not operate
the oven without the
turntable and support
in place.
Shelf (if included)
Clean with mild soap and
water or in the dishwasher.
Do not clean in a
self-cleaning oven.
How to Clean
the Inside
49-40571 v05 9/7/07 11:32 AM Page 31
Helpful Information
Care and Cleaning
Case
Clean the outside of the
microwave with a sudsy
cloth. Rinse and then dry.
Wipe the window clean
with a damp cloth.
Control Panel
Wipe with a damp cloth.
Dry thoroughly. Do not
use cleaning sprays, large
amounts of soap and water,
abrasives or sharp objects
on the panel—they can
damage it. Some paper
towels can also scratch
the control panel.
Door Panel
Before cleaning the front
door panel, make sure you
know what type of panel
you have. Refer to the
eighth digit of the model
number. “S” is stainless
steel, “G” is Graphite, “L”
is CleanSteel and “B”, “W”
or “C” are plastic colors.
Stainless Steel
The stainless steel panel
can be cleaned with
Stainless Steel Magic or a
similar product using a
clean, soft cloth. Apply
stainless cleaner carefully
to avoid the surrounding
plastic parts. Do not use
appliance wax, polish,
bleach or products
containing chlorine on
Stainless Steel finishes.
CleanSteel or Graphite
Use a clean, soft, light and
lightly dampened cloth,
then dry thoroughly. Do
not use appliance wax,
polish, bleach or products
containing any chemical
agent on the CleanSteel
or Graphite surfaces.
Plastic Color Panels
Use a clean, soft, lightly
dampened cloth, then dry
thoroughly.
Door Seal
It’s important to keep the
area clean where the door
seals against the microwave.
Use only mild, non-abrasive
detergents applied with a
clean sponge or soft cloth.
Rinse well.
Bottom
Clean off the grease and
dust on the bottom often.
Use a solution of warm
water and detergent.
We recommend against
using cleaners with
ammonia or alcohol,
as they can damage
the appearance of the
microwave oven. If you
choose to use a common
household cleaner, first
apply the cleaner directly
to a clean cloth, then
wipe the soiled area.
How to Clean
the Outside
32
49-40571 v05 9/7/07 11:32 AM Page 32
Light Bulb Replacement
33
1To replace the bulb(s),
first disconnect the power
at the main fuse or circuit
breaker panel or pull
the plug.
2Remove the screw at the
front of the light cover
and lower the cover.
3Be sure the bulb(s) to be
replaced are cool before
removing. After breaking
the adhesive seal, remove
the bulb by gently turning.
Replace with the same size
and type bulb.
4Raise the light shield
and replace the screw.
Connect electrical power
to the oven.
Replace the burned-out
bulb with a 120 volt,
40-watt incandescent
bulb (WB36X10003),
available from your
GE supplier.
Cooktop Light
1To replace the oven light,
first disconnect the power
at the main fuse or circuit
breaker panel or pull
the plug.
2Remove the top grille by
taking out the 2 screws
that hold it in place.
3Remove the charcoal
filter (if present) to
access the light cover
(see Remove Charcoal
Filter section).
4Remove the light cover
located near the center
of the oven that holds
the bulb. After breaking
the adhesive seal,
remove the bulb by
gently turning. Replace
with the same size and
type bulb.
5Replace the light cover
and charcoal filter
(if present).
6Replace the grille and
screws. Connect electrical
power to the oven.
Replace the burned-out
bulb with a 120 volt,
40-watt incandescent
bulb (WB36X10003),
available from your
GE supplier.
Oven Light
Remove screw
Screws
Light cover
49-40571 v05 9/7/07 11:32 AM Page 33
Helpful Information
The Exhaust Feature
34
The vent fan has a metal
reusable grease filter.
Models that recirculate air
back into the room also
use a charcoal filter.
The Vent Fan
Charcoal Filter
(on some models)
Reusable Grease Filter
(on all models)
The reusable grease filter
traps grease released by
foods on the cooktop. It
also prevents flames from
foods on the cooktop from
damaging the inside of
the microwave.
For this reason, the filter
must ALWAYS be in place
when the hood is used.
The grease filter should be
cleaned once a month, or
as needed.
Reusable
Grease Filter
To remove, slide it to the
side using the tab. Pull it
down and out.
To clean the grease filter,
soak it and then swish it
around in hot water and
detergent. Don’t use
ammonia or ammonia
products because they will
darken the metal. Light
brushing can be used to
remove embedded dirt.
Rinse, shake and let it dry
before replacing.
To replace, slide the filter
in the frame slot on the
left side of the opening.
Pull up and to the right
to lock into place.
Removing and
Cleaning the Filter
49-40571 v05 9/7/07 11:32 AM Page 34
35
If the model is not vented
to the outside, the air will
be recirculated through a
disposable charcoal filter
that helps remove smoke
and odors.
The charcoal filter should
be replaced when it is
noticeably dirty or
discolored (usually after
6–12 months, depending
on hood usage). See
“Optional Kits,” page 9,
for more information.
The charcoal filter
cannot be cleaned. It
must be replaced. Order
Part No. WB02X10943
from your GE supplier.
Charcoal Filter
(on some models)
To remove the charcoal
filter, disconnect power
at the main fuse or circuit
breaker panel or pull
the plug.
Remove the top grille by
removing the 2 screws that
hold it in place. Pull the
filter at the bottom until it
comes free of the locking
tabs. Slide the filter down
and out.
To Remove
Charcoal Filter
Remove 2 grille screws
to remove the grille.
To install a new filter,
remove plastic and other
outer wrapping from the
new filter.
1Insert the top of the filter
up and into the grooves
on the inside of the top
opening.
2Push the bottom of the
filter in until it snaps
into place behind the
locking tabs.
To Install
Charcoal Filter
49-40571 v05 9/7/07 11:32 AM Page 35
If Something Goes Wrong
Before You Call For Service
Oven will not
start
Floor of the oven is
warm, even when
the oven has not
been used
“LOC” appears
on display
Vent fan will not
turn off
“BAD PROBE”
appears on display
“PLEASE INSERT
PROBE
“ appears
on display
“SENSOR ERROR”
appears on display
Problem Possible Cause What to Do
A fuse in your home •Replace fuse or reset circuit breaker.
may be blown or the
circuit breaker tripped.
Power surge. •Unplug the microwave oven, then plug
it back in.
Plug not fully inserted •Make sure the 3-prong plug on the
into wall outlet. oven is fully inserted into wall outlet.
Door not securely closed. •Open the door and close securely.
The cooktop light is •This is normal.
located below the oven
floor. When the light
is on, the heat it
produces may make the
oven floor get warm.
The control has been •Press and hold CLEAR/OFF for
locked. about 3 seconds to unlock the control.
The vent fan •The vent fan cannot be turned off
automatically turns on while the microwave is operating.
to cool internal parts This is normal. Wait for the microwave
while the microwave to turn off and the fan will either go
is on. off automatically or you will need to
turn it off by pressing the Vent Fan
pad after the microwave is off.
The probe has not been •Insert the probe properly into the
completely inserted into oven wall outlet.
the oven wall outlet.
The probe is defective. •Replace the probe.
Probe has been •Insert the probe properly into the
forgotten or not oven wall outlet.
inserted properly.
When using a Sensor •Do not open door until steam is
feature, the door was sensed and time is shown counting
opened before steam down on display.
could
be detected.
Steam was not detected •Use Time Cook to heat for more time.
in maximum amount
of time.
36
49-40571 v05 9/7/07 11:32 AM Page 36
37
•Moisture on the oven
door and walls while
cooking. Wipe the
moisture off with a paper
towel or soft cloth.
•Moisture between the
oven door panels when
cooking certain foods.
Moisture should dissipate
shortly after cooking is
finished.
•Steam or vapor escaping
from around the door.
•Light reflection around
door or outer case.
•Dimming oven light and
change in the blower
sound at power levels
other than high.
•Dull thumping sound
while oven is operating.
•The vent fan operating
while the microwave is
operating. The vent fan
will not go off nor can it
be turned off until the
microwave is off.
•TV-radio interference
might be noticed while
using the microwave.
Similar to the interference
caused by other small
appliances, it does not
indicate a problem with
the microwave. Plug the
microwave into a different
electrical circuit, move the
radio or TV as far away
from the microwave as
possible or check the
position and signal of
the TV/radio antenna.
Things That
Are Normal
Before You Call For Service
49-40571 v05 9/7/07 11:32 AM Page 37
38
ge.com
Have a question or
need assistance with
your appliance? Try the
GE Appliances Website
24 hours a day, any day
of the year!
For greater convenience
and faster service, you can
now download Owner’s
Manuals, order parts or
even schedule service
on-line.
GE Appliances
Website
ge.com
800.GE.CARES
(800.432.2737)
Expert GE repair service
is only one step away
from your door. Get
on-line and schedule
your service at your
convenience any day
of the year!
Or call 800.GE.CARES
(800.432.2737) during
normal business hours.
Schedule Service
ge.com
800.TDD.GEAC
(800.833.4322)
GE supports the Universal
Design concept—products,
services and environments
that can be used by people
of all ages, sizes and
capabilities. We recognize
the need to design for
a wide range of physical
and mental abilities and
impairments.
For details of GE’s
Universal Design
applications, including
kitchen design ideas for
people with disabilities,
check out our Website
today. For the hearing
impaired, please call
800.TDD.GEAC
(800.833.4322).
Real Life
Design Studio
GE Service Numbers
We’ll Be There!
ge.com
800.626.2224
Purchase a GE extended
warranty and learn about
special discounts that
are available while your
warranty is still in effect.
You can purchase it
on-line anytime, or call
800.626.2224 during
normal business hours.
GE Consumer Home
Services will still be there
after your warranty expires.
Extended Warranties
49-40571 v05 9/7/07 11:32 AM Page 38
ge.com
800.626.2002
Individuals qualified
to service their own
appliances can have
parts or accessories sent
directly to their home.
(VISA, MasterCard and
Discover cards are
accepted.)
Order on-line today,
24 hours every day or
by phone at 800.626.2002
during normal business
hours.
Instructions contained
in this manual cover
procedures to be
performed by any user.
Other servicing generally
should be referred
to qualified service
personnel. Caution
must be exercised, since
improper servicing may
cause unsafe operation.
Parts and
Accessories
39
Register Your
Appliance
ge.com
Register your new
appliance on-line—
at your convenience!
Timely product registration
will allow for enhanced
communication and
prompt service under the
terms of your warranty,
should the need arise.
You may also mail in the
pre-printed registration
card included in the
packing material.
49-40571 v05 9/7/07 11:32 AM Page 39
Printed in Malaysia
LIMITED ONE-YEAR WARRANTY
For one year from date of original purchase,
GE will replace any part in the microwave oven
that fails due to a defect in materials or
workmanship. During this limited one-year warranty,
GE will provide, free of charge, all labor and related
service costs to replace the defective part.
************************************
All warranty service will be provided by our Factory
Service Centers or by our authorized Customer
Care®servicers during normal working hours.
Should your appliance need service, during
warranty period or beyond, call 800.GE.CARES
(800.432.2737).
Please have serial and model numbers available
when calling for service.
MICROWAVE OVEN
WARRANTY
What Is Covered
What Is Not Covered
Staple sales slip or cancelled check here. Proof of original
purchase date is needed to obtain service under warranty.
•Service trips to your home to teach you how to
use the product.
•Improper installation, delivery or maintenance.
If you have an installation problem, contact your
dealer or installer. You are responsible for
providing adequate electrical, exhausting and
other connecting facilities.
•Product not accessible to provide required
service.
•Replacement of house fuses or resetting of
circuit breakers.
•Replacement of the cooktop light bulbs.
•Failure of the product or damage to
the product if it is abused, misused (for
example, cavity arcing from wire rack or
metal/foil), or used for other than the intended
purpose or used commercially.
•Damage to product caused by accident, fire,
floods or acts of God.
•Incidental or consequential damage caused
by possible defects with this appliance.
•Damage caused after delivery.
This warranty is extended to the original purchaser and any succeeding owner for products purchased for home
use within the USA. If the product is located in an area where service by a GE Authorized Servicer is not available,
you may be responsible for a trip charge or you may be required to bring the product to an Authorized GE Service
Location for service. In Alaska, the warranty excludes the service calls to your home.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may also have
other rights which vary from state to state. To know what your legal rights are in your state, consult your local or
state consumer affairs office or your state’s Attorney General.
Warrantor: General Electric Company. Louisville, KY 40225
EXCLUSION OF IMPLIED WARRANTIES—Your sole and exclusive remedy is product
repair as provided in this Limited Warranty. Any implied warranties, including the implied
warranties of merchantability or fitness for a particular purpose, are limited to one year or
the shortest period allowed by law.
DE68-03467A
49-40571
09-07 JR
49-40571 v05 9/7/07 11:32 AM Page 40
