Users Manual
Qwerty Remote (RMC-QTD1)
Remote Side View
PRE-CH
CH
LIST
1
4
23
56
7 8 9
0
MUTE
M
MENU
m
SOURCE
SMART
HUB
l
B
YAHOO!
E-MANUAL
P.SIZE
CC
SOCIAL
TV
C D
VOL
<
<
CH
SLEEP
Turns the TV on and off.
Displays and selects the available video
sources.
Turns the remote control light on or
off. When on, the buttons become
illuminated for a moment when pressed.
(Using the remote control with this button
set to On will reduce the battery usage
time.)
Returns to the previous channel.
MUTE: Cuts off the sound temporarily.
CH LIST: Displays channel lists on the
screen.
Changes channels.
Automatically shuts off the TV at a preset
time.
Displays information on the TV screen.
Exits the menu.
Gives direct access to channels.
Press to select additional digital channels
being broadcast by the same station. For
example, to select channel ‘54-3’, press
‘54’, then press ‘-’ and ‘3’.
Adjusts the volume.
Opens the OSD.
Quickly select frequently used functions.
Link to various application services.
Returns to the previous menu.
Selects the on-screen menu items and
changes the values seen on the menu.
Buttons used in the Channel and
SMART HUB menu, etc.
Use these buttons in SMART HUB and
Anynet+ (HDMI-CEC) modes.
SOCIAL TV: Connect to Social TV
application.
YAHOO!: Runs Yahoo widget.
X
: Turns the 3D image on or off.
E-MANUAL: Displays the e-Manual.
P.SIZE: Lets you select the Picture Size.
CC: Displays digital subtitles.
QWERTY-Remote.indd 2 2011-01-19 오후 9:16:37
Qwerty Side View
✎
NOTE
yThe Remote side doesn't work when the Qwerty side is up, and vice versa.
Insert Batteries
1 2
ySlide out the battery cover. yPush the button right.
3 4
yPull the battery tray out. yInsert 4 AAA batteries in the tray and then insert the
battery tray into the Qwerty Remote and put the cover.
Initial Pairing
1. When the user inserts batteries into the Qwerty Remote, then "NEED PAIRING PRESS @+TAB" will be displayed
repetitively on the screen.
2. Press @ and TAB buttons at the same time.
✎
A TV can be paired with only one Qwerty Remote.
To perform the pairing process again
1.
2. Follow the initial pairing process.
MENU
SMART
HUB SEARCH
BA C
ESC
CAPS SHIFT SHIFTSYM SYM.COM
@
21 3
54 6
8
0
7 9
#!
$
@
^%
& (*
)
-
_+
~`
<
][ {
;
/
>,
#} $ |
‘: “
?
.
WQ E
SA D
Z
TAP ENTER
DEL
X
TR Y
GF H
VC B
IU O
KJ L
P
MN
D
Convenient qwerty keyboard to type characters in the SMART HUB and
SOCIAL TV menu, etc.
SYM: Enables the blue symbol printed on the lower right side of each buttons.
Display the characters user typed.
When user press ENTER
E
button, all the
characters on the screen are removed.
QWERTY-Remote.indd 3 2011-01-19 오후 9:16:39
Press MUTE, 0, MUTE and 0 buttons on the Remote side of new Qwerty Remote facing the TV.
Specifications - Qwerty Remote
Model Name RMC-QTD1
Battery AAA x 4
To extend the battery life, use of alkaline battery is recommended.
Dimension(WxDxH) 2.4 X 1.0 X 6.0 inches
(60.9 x 24.36 x 152.2 mm)
Weight 0.295 lbs (134 g)
Notice
FCC Statement
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the
following measures:
yReorient or relocate the receiving antenna.
yIncrease the separation between the equipment and receiver.
yConnect the equipment into an outlet on a circuit different from that to which the receiver is connected.
yConsult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
IC Statement
This Class B digital apparatus complies with Canadian ICES-003.
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept
any interference, including interference that may cause undesired operation of the device.
Cet appareil numérique de la classe B est conforme á la norme NMB-003 du Canada.
This device and its antenna(s) must not be co-located or operation in conjunction with any other antenna or transmitter.
