Users Manual Part I
USER MANUAL
1
English
Contents
» Getting started
1. Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. Headset Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3. Button Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4. Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
5. Putting on the headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
» Before using your headset
6. Turning the headset On or Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
7. Pairing the headset with a compatible phone . . . . . . . . . . . . . 9
8. Connecting the paired headset to the phone . . . . . . . . . . . . 10
» Using the headset
9. Making and answering a call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
10. Rejecting a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
11. Switching the call between phone and headset . . . . . . . . . 13
12. Adjusting the speaker volume . . . . . . . . . . . . . . . . . . . . . . . . . . 13
13. Muting an ongoing call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
14. Listening to music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
15. Answering a call while listening to music . . . . . . . . . . . . . . . 15
» Care and Maintenance
16. Storing the headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
17. Frequently asked questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
18. Certification and safety approvals . . . . . . . . . . . . . . . . . . . . . . 19
19. Warranty and parts replacement . . . . . . . . . . . . . . . . . . . . . . . 21
20. Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
21. Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2
English
3
English
» Left
Ear Hook
Speaker
Stereo Headset Carrying Case Charger User Manual
Unpacking
1
Talk Button
Indicator Light
Microphone
Volume Up Button
Play/Pause/Stop
Button
REW Button
On/Off Button
Charger
Connector
FF Button
Volume Down Button
Speaker
Getting Started
Using a mobile phone while driving creates a distraction to the
driver which may increase the likelihood of an accident.
When using the phone while driving, keep conversations short
and do not make notes or read documents. Before answering calls
consider your circumstances. Pull off the road and park before
making or answering calls when driving conditions require (e.g.
bad weather, high traffic density, presence of children in the car,
difficult junctions or manoeuvres.)
Remember, driving comes first, not the call!
Abide by local laws.
Drive safely
!
Headset Overview
2
» Right
Explains what to remember for a proper use of your Bluetooth headset.
Thank you for purchasing the Samsung Bluetooth Headset SBH100,
we hope you will be delighted with its operation.
Please read the instruction manual to get started and to make best
use of the headset’s many features.
Thank you
The Samsung Bluetooth headset SBH100 is compatible with
most Bluetooth¹ (see Glossary) phones that are compliant
with Bluetooth version 1.1 or higher specification and support
Advanced Audio Distribution profile, Audio Video Remote Control
Profile headset profile and hands-free profile².
Ensure that your phone has Bluetooth capability by visiting your
phone manufacturer’s web site.
Check phone compatibility
!
4
English
5
English
Button Functions
3
Answers / ends
a call Press the button to answer or end a call.
Switching an active
call from the headset
to the phone
During a phone call, press and hold the
button to switch the call to the phone.
- Available only when your headset and the phone
are connected as Hands-free Bluetooth profile.
Switching an active
call from the phone
to the headset
During a phone call, press and hold the
button to switch the call to the headset.
Redialling the last dialed number by pressing once or twice.
Connecting the headset in connectable mode to the phone by
pressing once or twice.
Talk Button
Adjusts the speaker volume while the music is on.
Adjusts the speaker volume during a phone call.
Mutes the microphone during a call if pressed and held while
the call is in progress.
Resume the call if pressed again.
Rejects the call if pressed and held when a call comes in.
- Available only when your headset and the phone are connected as
Hands-free Bluetooth profile, and the phone supports the incoming call
rejecting function.
Voice dials if pressed and held while connected to the phone.
- Available only when your headset and the phone are connected as
Hands-free Bluetooth profile, and the phone supports the voice dialing
function.
Volume Up/Down Button
Starts MP3 player if pressed in standby mode.
(Available only when you have completed proper settings
on your phone)
Pauses if pressed while the music is on, starts the song from the
paused part if pressed once again.
Stops the music if pressed and held while the music is on, starts
the song from the very first part if pressed once again.
Play/Pause/Stop Button
Starts the previous/next song from the very first part if pressed
while the music is on.
Rewind/Fast Forward functions if pressed and held.
REW/FF Button
6
English
7
English
+ (Switch on) Gets ready for pairing.
(While turned on)
Press and hold (FF) +
(Volume Down Button)
Red light is flashing to notify the
remained battery amount.
- Flashes once : Approx. 5~20% charged
- Flashes twice : Approx. 20~50% charged
- Flashes three times : Approx. 50~80% charged
- Flashes four times : Approx. 80~100% charged
If press these buttons together
Press several buttons together to activate these functions.
Charging the Battery
4
This device has an internal battery which is non-removable and rechargeable. Please make
sure that you should charge the battery fully before using the headset for the first time.
Plug the charger into the
headset’s charger connector. Plug the charger into the
electrical outlet.
– Disconnect the charger from the power source or the headset
after completing the charging.
- Use only Samsung-approved charger. Unauthorized charger
may cause an explosion or damage on the headset.
- Always try to keep the battery at room temperature (0 ~ +40°C).
- The battery will gradually wear out if charging/discharging are
repeated because it is a consumable part.
- The headset is not able to operate while charging.
- Try connecting again after charging is completed.
About the charging
> Battery charging and standard operation time
charging time Standard operation time
Battery
operation
time
Approximately
3hr.
Talk time Standby time Play time
More than
8hr.
Maximum of
200hr. More than 7hr.
> Warning sound beeps and the red indicator light flashes every 10
seconds.
> If the warning sound beeps, switch the call from the headset to
the phone.
> If the warning sound beeps, the headset will be automatically
turned off.
When the battery charge falls low
8
English
9
English
Putting on the headset
5
Check the RIGHT/LEFT sign at the bottom of the ear-hook to put on the
headset properly.
Slide the headset onto your ear
while opening wide the ear-hook
to be easy to wear on.
- Move the ear hook to place the headset
to the most comfortable position.
Turning the headset On or Off
6
> Push the On/Off Button to turn the
headset on.
> Push the On/Off Button to turn the
headset off.
If the headset is ready to be paired, the blue indicator light
flashes per second.
Pairing the headset with a compatible phone
7
> Pairing
3
will create a unique and encrypted wireless link
between two Bluetooth enabled devices such as our Bluetooth
phone and Bluetooth headset. To use the headset with other
Bluetooth devices, both devices must be paired. When trying
pairing, keep the headset and the phone close-by.
Before using your headset
Explains the basic operation and set-ups of your Bluetooth headset.
Grip the headset body and
jostle it to back of the ear for
it to be fixed well.
> Press the (FF) Button and (Volume Down) Button at the
same time.
> The red indicator light flashes from 1 to 4 times according to
the remaining battery amount.
> The more it flashes, the more the battery is remained.
(Refer to page 6. If press these buttons together section.)
To check the charging status
There are 2 cases for being ready to be paired.
When being ready to be paired
> When turning the headset on for the first time after
purchasing.
>When turning the headset on by vpressing .
10
English
11
English
- You can see the Bd Address marked on the label if you
take off the speaker cover on the left side.
- If there is no Bluetooth device to be connected in
3 minutes, the blue indicator light will flash per
3 seconds. In that case, turn the headset off and on
again to try pairing from the first step by following
Pairing the headset with a compatible phone section.
Connecting the paired headset to the phone
8
If two Bluetooth Devices are disconnected by being turned off, you need to
reconnect them. When you reconnect a paired headset, you are not asked for
its passkey.
To connect from the phone
> Follow your phone’s user guide
To connect from the headset
> To answer or make a call, press .
– Available only when your Bluetooth phone supports the headset or
Hands-free Bluetooth profile.
To connect from the headset, your phone and the headset have had to be
connected more than once.
3. If connected successfully, you can make or answer a call on the headset.
- The blue indicator light will not flash in active mode.
- If the connection fails, the blue indicator light will flash every 3 seconds. In
that case, try connecting again from the beginning.
1. Turn on the headset.
- The blue indicator light will flash per 3 seconds if it is ready to bepaired.
- The headset can connect to your phone automatically if the pairing is
completed depending on the types of the phone.
2. Choose the connection method you want.
1. Turn on the headset.
- The blue indicator light will flash per second if the headset is ready to
be paired.
2. Prepare your phone according to the phone’s user manual on
Pairing.
3. Your phone will find “Samsung Stereo Headset” and ask if you
want to pair with it. Confirm this by selecting “Yes” or “OK”.
- You can see the Bd Address of the product at the bottom of the LCD
screen. If there are many headsets connected with your phone, choose
the Bd Address of the right one.
4. Enter passkey or PIN
4
= 0000(4zeros).
5. If the headset and the phone are connected successfully,
the blue indicator light will flash per 6 seconds.
Indicator light status
When ready for pairing Flashes per second
When the pairing is completed Flashes per 3 seconds
In standby mode5Flashes per 6 seconds
In active mode6 Not flash
12
English
13
English
Making and answering a call
9
Redialing the last dialed number
> Press to check the latest call numbers list.
> Press once again to make a call to the last dialed number.
- The headset can make a call to the last dialed number by
pressing once depending on the types of the phone.
Voice dialing
> Press and hold or Button.
> Say a name into the microphone.
- Available only when your phone supports the voice recognition function.
Making a call
> Make a call with your Bluetooth phone.
- Press and hold after dialing and sending a call.
-
Depending on the types of the phone, it switches the call from the phone
to the headset automatically.
- Available only when your phone and the headset are
connected as Hands-free Bluetooth profile.
Using the headset
Explains how to use the various functions such as making/answering a call,
menus that you can use while the call is in progress, and listening to music
that SBH100 provides.
Switching the call between phone and headset
11
> Press and hold to switch the call to the phone while talking
on the headset
> Press and hold to switch the call to the headset while
talking on the phone.
- Available only if your headset and the phone are
connected as Hands-free Bluetooth profile.
Adjusting the speaker volume
12
> Press to adjust the speaker volume while talking.
> Press to adjust the speaker volume while listening to music.
Rejecting a call
10
> Press and hold or if a call comes in.
- Available only when your headset and the phone are
connected as Hands-free Bluetooth profile, and the
phone supports the incoming call rejecting function.
Answering a call
> Press if the phone rings.
- Press once again to hang up the phone.
14
English
15
English
Muting an ongoing call
13
> Press and hold or to mute the microphone of your
headset during a call.
> Press or to cancel the Muting mode.
Listening to music
14
Listening to music
> Press while being connected to your Bluetooth phone.
> Press while the music is stopped.
Stopping music
> Press and hold while listening to music.
> Press again to listen to the song from the very first part.
- Depending on the types of your Bluetooth phone, it may
read MP3 files only. Make sure that you have the right
file format (*.mp3) for your music files.
Pausing music
> Press while listening to music.
> Press again to listen to the song from the paused part.
Settings to play MP3 files may differ depending on your Bluetooth phone.
So please make sure that you make proper setting for MP3 playback on your
phone by following the phone’s user guide.
Listening to the previous/next song
> Press while music is on.
Rewinding/Fast Forwarding
> Press and hold while music is on.
Answering a call while listening to music.
15
> Available only when your phone supports the Advanced Audio
distribution profile, A/V Remote control profile, and headset
profile or hands-free profile.
> Settings to play MP3 files may differ depending on your Bluetooth
phone. So please make sure that you make proper setting for MP3
playback on your phone by following the phone’s user guide.
Making a call while listening to music
> Press and hold to stop the music.
> Press to check the latest call numbers list.
> Press once again to make a call to the last dialed number.
- The headset can make a call to the last dialed number without showing
the latest call number list by pressing once depending on the types
of the phone.
Answering a call while listening to music
> Press .
Ending a call
> Press .
16
English
17
English
Storing the headset
16
Place the each side of the
headset in the net tidily.
Care and Maintenance
- Be careful for the headset not to be scratched nor cracked by
applying excessive force or giving damage.
- Always store the Samsung SBH100 with power off and safely
protected.
- Avoid storage at high temperatures (above 60°C / 134 °F)- such as
in a hot vehicle or in direct sunlight. (Storage at high temperatures
can degrade performance and reduce battery life).
- Do not expose the headset or any of its supplied parts to rain or
other liquids.
Frequently asked questions
17
1. How far away from my phone will my Samsung SBH100 work?
The operating range is typically up to 30 feet (10 metres).
2. Will Samsung SBH100 work with my cordless phone at home?
Samsung SBH100 is not designed for use with cordless phones.
3. Will Samsung SBH100 work with laptops, PCs, and PDAs?
Samsung SBH100 will work with devices that are compliant with Bluetooth version
1.2 and support Advanced Audio Distribution profile, A/V Remote Control profile,
Headset profile and/or Hands-free profile(s).
4. Will anything cause interference with my conversation when I’m using my
Samsung SBH100?
Appliances such as cordless phones and wireless networking equipment may
cause interference with your conversation, usually adding a crackling noise.
To reduce any interference, keep the headset away from other devices that use or
produce radio waves.
5. Will my Samsung SBH100 interfere with my car’s electronics, radio,
or computer?
Samsung SBH100 produces significantly less power than a typical mobile phone.
It also only emits signals that are in compliance with the international Bluetooth
standard. Therefore, you should not expect any interference with standard
consumer-grade electronics equipment.
6. Can other Bluetooth phone users hear my conversation?
When you pair your headset to your Bluetooth phone, you are creating a private
link between only these two Bluetooth devices. The wireless Bluetooth technology
used in your headset is not easily monitored by third parties because Bluetooth
wireless signals are significantly lower in radio frequency power than those
produced by a typical mobile phone.
7. Can I use the headset while charging?
The headset is not able to operate while charging.
