Users Manual
12.USERSMANUAL
1
SCH-410/411
Series CDMA
DIGITAL PORTABLE
CELLULAR TELE PHONE
User’s Manual
Please read this manual before operating the phone,
and keep it for future reference.
2
Safety Precautions
Compliance with Safety Standards
The Samsung CDMA Cellular Phone meets all standards and recommendations for the protection of the
public from exposure to radio frequency (RF) electromagnetic energy established by governmental
bodies and other qualified organizations. To reduce the risk of fire, electric shock, serious personal
injury, or property damage, please follow these guidelines:
Driving
Using a wireless phone while driving is illegal in some states and countries. Know the laws and
regulations for your area, and pull off the road and park if you need to make a call.
If you must use the phone while driving, purchase and install the optional Hands-Free Car Kit.
Electronic Devices
Your wireless telephone is a radio transmitter and receiver. When the power is on, the phone receives
and sends out RF energy. Most modern electronic equipment, such as equipment in hospitals and cars,
contains an RF signal shield. RF energy may affect some inadequately shielded electronic equipment.
Turn off your phone in health care facilities, and always request permission before using the phone near
medical equipment.
Consult the manufacturer of any personal medical devices, such as pacemakers and hearing aids, to
determine if they are shielded adequately from external RF signals.
Note if there are any regulations posted in the area regarding the operation of wireless phones, and learn
where you can use them safely within the facility.
Aircraft
Turn off your phone before boarding any aircraft. The Federal Aviation Administration (FAA) requires
that you have prior permission from the crew to use your phone while the plane is on the ground. FCC
regulations prohibit using your phone while the plane is in the air. Do not use your phone at any time
while traveling on board a plane.
Blasting Areas
Construction crews often use remote-control RF devices to set off explosives. To avoid interfering with
blasting operations, turn off your phone when you are in a blasting area or in any area with signs posted
that read “Turn off two-way radio.”
3
Other Dangerous Areas
Turn off your phone in any area with a potentially explosive atmosphere. It is rare, but your phone or its
accessories could generate sparks, which could cause explosion or fire.
Areas with a potentially explosive atmosphere may not always be clearly marked. These areas may
include:
Ÿ Fueling areas, such as gas stations
Ÿ Below deck on boats
Ÿ Fuel or chemical transfer or storage facilities
Ÿ Areas where the air contains chemicals or particles such as grain, dust, or metal powders
Ÿ Any other area where you would normally be advised to turn off your vehicle engine
Do not transport or store flammable gas, liquid, or explosives in the compartment of a vehicle
containing your phone or accessories.
FCC/IC Notice
This device compiles with part 15 of the FCC rules. Operation is subject to the following two condition:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
4
Getting Started
Introduction to SCH-410/411
Congratulations on the purchase of your new CDMA cellular phone. Your cellular phone features the
latest CDMA digital technology. The phone operates in a similar manner to other wireless phones, while
providing superior resonance and tone quality.
The following features provide a range of user options that make the phone both fun and easy to use.
Ÿ Active Flip
Ÿ Phone Book Memory - 79 Locations
Ÿ Voice Dialing - 20 Locations
Ÿ Programmable Lock
Ÿ Short Message Services (SMS)
Ÿ 6 Ring Types, 4 Melody Options, Vibrator Alert
Ÿ Call Logs - 10 Locations Each: Outgoing and Incoming Calls
Ÿ Pause Dialing
Ÿ Ringer Mute During Incoming Call
Ÿ Alarm
Ÿ EVRC ( SCH-411 only )
5
Key Functions
Press SEND to:
Ÿ place a call after dialing the number,
Ÿ answer an incoming call,
Ÿ initiate Three-way calling,
Ÿ access Call Logs or the Phone Book.
Press CLR to:
Ÿ erase one character at a time while entering names and numbers,
Ÿ go back one menu level at a time while viewing menu options,
Ÿ initiate Voice Dialing when the flip is open.
Press and hold CLR to:
Ÿ erase all displayed characters while entering names and numbers,
Ÿ return to Standby mode while viewing menu options.
Press END to:
Ÿ end a call,
Ÿ exit the current menu and return to Standby mode,
Ÿ mute the ringer on an incoming call.
Press MENU to display the Main Menu and to scroll through menus.
Press and hold MESSAGES to access messages.
Press OK to save menu option settings.
Press the arrow keys to scan menu options.
Press PWR to turn the phone on and off.
SEND
CLR
END
MENU
OK
PWR
6
Press the Volume button to:
Ÿ adjust voice volume during conversation,
Ÿ adjust key beep volume in Standby mode,
Ÿ mute the ringer during an incoming call,
Ÿ scroll Call Logs and Phone Book entries.
Status / Alert Indicators
Signal Strength
Indicates current signal strength
No Service
Indicates that the phone is outside a service area and cannot send or
receive
calls.
Battery Change
Indicates battery change level
Message
Indicates messages
Roaming
Displays when the phone is outside the home service area but within the
network
Digital
Indicates Digital mode
Vibrate
Indicates Vibrate mode
7
Basic Operations of the CDMA Cellular Phone
Power On / Off
Menu Scrolling
Make Calls
Correct Mistakes
Redial Call
Speed Dialing
End Call
Answer Call
Save Numbers
Outgoing Number
Incoming Number
Press and hold .
Press , and then press or .
Enter number, and then press .
Press .
Press twice.
Enter memory location, and then press .
Press , or close flip.
Press , or open flip.
Enter phone number, press , and then follow screen prompts.
Press , , in sequence to review last 10
outgoing calls.
Press , , in sequence to review last 10
incoming calls.
SEND
CLR
END
OK
PWR
MENU
MENU
MENU
SEND
SEND
SEND
2ABC
1
1
1
8
Main Menu Structure
Samsung SCH-410/411 CDMA Cellular Phone Standby Menu
Main Menu Menu Level 1 Menu Level 2
1. Calls => 1. Outgoing
2. Incoming
3. Erase Logs => 1. Outgoing
2. Incoming
3. All
4. Air Time => 1. Last Call
2. Total
3. Erase Total
2. Phone Book => 1. Find Name
2. My Phone #
3. Add Entry
4. Find Entry
3. Sounds => 1. Ring => 1. Ring Vol.
2. Ring Type
3. Ring Tone
2. Key Beep
3. Alerts => 1. Minute Beep
2. Service Area
4. Remind Call => 1. Set
2.Release
5. Differential Ring
4. Display => 1. Back Light
2. Greeting
3. Version
4. Language Select
9
Main Menu Menu Level 1 Menu Level 2
5. Analog Call
6. Voice Dial => 1. Recording
2. Voice Dial
3. Delete One
4. Play All
5. Delete All
6. Auto Vdial
7. Setup => 1. Automatic Retry
2. Automatic Receiving
3. Automatic Hyphenation
4. Any Key Answer
5. Tone Length
6. Tone => 1. Release Tone
2. Connect Tone
7. Set Time
0. Security => 1. Lock Phone
2. Restrict Use => 1. Phone Book
2. Incoming
3. Outgoing
3. Lock Code
4. Emergency #s
5. Send PIN
6. Clear Memory
7. NAM Mode => 1. Manual NAM
2. Auto NAM
8. Block Own #
9. System Select => 1. FM
2. CDMA
0. Reset Phone
10
Overview of Calling Options
Your CDMA Cellular phone provides a variety of calling options. For detailed information on each of
the following calling options, see the special section in this manual:
Ÿ Enter the phone number by pressing the digit keys, and then press .
Ÿ Access a phone number stored in the Call Logs, and then press .
Ÿ Access and entry in the Internal Phone Book, and then press .
Ÿ Activate the Speed Dial option.
Ÿ Call emergency or special numbers in Lock mode.
Ÿ Initiate Three-way Calling during conversation.
Overview of the Internal Phone Book
The Internal Phone Book provides the following features and options:
Ÿ 79 memory locations
Ÿ Optional name entry
Ÿ Notification when overwriting, or erasing entries
Ÿ Automatic scrolling to the next available location, with manual location selection option
Ÿ Adding / Editing entries by name or location
Ÿ Direct access retrieval of entries by name or location
Ÿ Searching entries by name or location
Ÿ Speed Dialing
Ÿ Placing a call to the displayed Phone Book entry
Ÿ Prepending phone numbers
Ÿ Phone Book match for incoming / outgoing calls, Call Waiting, 3-way Calling,
SMS messages, and Caller ID
Ÿ Name / number display when entry includes name
SEND
SEND
SEND
11
Overview of Short Message Services (SMS)
Your CDMA Cellular phone receives voice mail notification and text messages and pages. When the
phone receives an incoming message, an alert sounds, and a text notification displays (“Message from:”).
“Urgent!” displays to signal an incoming urgent message. The Messages indicator remains on the
display until you read the pending or voice mail notification messages.
When message memory reaches 75 percent capacity, the screen displays a text notification and a prompt
to erase old messages. At full capacity, the screen displays a text notification and rejects additional
incoming messages until you erase some of the stored messages.
The phone treats duplicate messages as one incoming message entry. For example, if the phone receives
the same name and callback number in sequence, the phone records the more recent date and time
information, and then displays “Duplicate” on the message header.
The phone automatically adjusts the incoming message alert volume to the lowest setting when the
phone is in Conversation mode.
Incoming voice mail notification and text message s transmit even when the phone is in Lock mode. To
access the message, or to return a call other than an emergency or special number, enter the lock code.
12
Advanced Features
Pause Dialing
Pause Dialing enables you to send numbers as DTMF (Dual Tone Modulated Frequency) signals after
placing a call. This feature is helpful when using electronic communications, such as sending back
account or credit card numbers over the phone.
Voice Dialing
Voice Dialing enables you to call up to 20 stored name and number sets by speaking the name into the
microphone.
Using the Voice Dialing option requires that you first train the phone to recognize the name and then
activate the feature through the Main Menu.
Lock Mode
Locking the phone restricts outgoing calls to emergency numbers (911, 911, #911) and three user-
programmable special numbers. For security purposes, asterisk (*) display in place of the special
numbers. Dialing user-programmable special numbers requires that you remember these numbers. If you
dial an incorrect special number while the phone is in Lock mode, the screen displays an error message.
You can lock the phone manually during use, or set the phone to lock automatically at power-on. When
the phone is in Lock mode, you can answer incoming calls, but you must enter the lock code to place
outgoing calls.
13
Call Restriction Options
Your CDMA Cellular phone provides the following call restriction options in the Security menu:
Ÿ Limit Phone Book Use
Ÿ Limit Incoming Calls
Ÿ Limit Outgoing Calls
To restrict calls:
0. Press to display the Main Menu.
1. Press for Security.
2. Press for Restrict.
3. Press the associated digit key to select an option:
Ÿ Press to restrict the Phone Book.
Ÿ Press to restrict Incoming calls.
Ÿ Press to restrict Outgoing calls.
4. After selecting the desired option, press the scroll keys to select context-specific options.
5. Press to save the setting.
Emergency and Special Numbers
Emergency numbers (911, 911, #911) are programmed into your CDMA Cellular phone. The Security
menu provides the option of storing three additional special numbers.
You can place calls to emergency and special numbers even when the phone is locked or when “Limit
Outgoing Calls” is active.
OK
MENU
2ABC
3DEF
0OPER
1
2ABC
