PORTABLE CELLULAR
TELEPHONE
SCH-620
Owner’s Manual
1
Contents
GETTING STARTED
Unpacking .............................................................................................. 7
Phone Layout ......................................................................................... 8
Key Functions ...................................................................................... 9
Display ................................................................................................. 10
Icons ................................................................................................. 10
Installing Battery ................................................................................... 11
To Install the Battery ......................................................................... 11
To Remove the Battery ...................................................................... 12
Charging a Battery ................................................................................ 13
Low Battery Indicator ........................................................................ 14
Switching the Phone On/Off .................................................................. 15
GENERAL FUNCTIONS
Making a Call ........................................................................................16
Correcting the Number ...................................................................... 16
Ending a Call ..................................................................................... 16
Emergency Dialing ............................................................................ 17
Prepend Dialing ................................................................................ 17
Making a Call from the Phone Book .................................................. 18
Voice Dialing ..................................................................................... 19
Last Number Redial ...............................................................................20
Answering a Call .................................................................................... 21
Viewing Missed Calls .............................................................................. 22
In-Call Options .......................................................................................23
Call Waiting ...................................................................................... 23
Three-Way Calling.............................................................................. 23
Call Forwarding.................................................................................. 24
Microphone Gain................................................................................ 24
Adjusting the Volume..............................................................................24
Quick Switching to Vibration Mode ......................................................... 25
Recording Voice Memo ........................................................................... 25
Table of Contents
2Contents 3
Contents
USINGTHE MENUS
Using the Scroll Keys .............................................................................26
Using the Index System ......................................................................... 27
Menu Map ............................................................................................. 28
CALLS
Outgoing (MENU 1-1) ..................................................................... 30
Incoming (MENU 1-2) ..................................................................... 31
Erase Logs (MENU 1-3) ................................................................... 32
Air Time (MENU 1-4) ...................................................................... 32
PHONE BOOK
Find Name (MENU 2-1) ................................................................... 33
My Phone Number (MENU 2-2) ....................................................... 34
Add Entry (MENU 2-3) .................................................................... 34
Storing Phone Numbers at Call End .....................................................34
Entering a Name ................................................................................ 35
Find Entry (MENU 2-4) .................................................................... 35
SOUNDS
Ring (MENU 3-1) ............................................................................ 36
Ring Volume ......................................................................................36
Ring Type ........................................................................................... 36
Ring Tone ........................................................................................... 37
Key Volume (MENU 3-2) ................................................................. 37
Alert (MENU 3-3) ............................................................................ 37
Minute Beep ..................................................................................... 37
Service Area ..................................................................................... 37
Alarm (MENU 3-4) .......................................................................... 37
Differential Ring (MENU 3-5) .......................................................... 38
Power On/Off (MENU 3-6) .............................................................. 38
Data/Fax (MENU 3-7) .................................................................... 38
DISPLAY
Backlight (MENU 4-1) ..................................................................... 39
Greeting (MENU 4-2) ...................................................................... 39
DISPLAY(Continued...)
Version (MENU 4-3) ........................................................................ 39
Language (MENU 4-4) .................................................................... 40
VOICE MEMO
Review (MENU 5-1) ........................................................................ 40
Record (MENU 5-2) ......................................................................... 41
Erase All (MENU 5-3) ...................................................................... 41
VOICE DIAL
Record (MENU 6-1) ......................................................................... 42
Tips on Recording Name .....................................................................42
Review/Erase (MENU 6-2) .............................................................. 43
Erase All (MENU 6-3) ...................................................................... 44
Set Active (MENU 6-4) .................................................................... 44
SETUP
Auto Retry (MENU 7-1) ................................................................... 45
Auto Receive (MENU7-2) ................................................................. 45
Auto Hyphen (MENU 7-3) ............................................................... 45
Any Key Answer (MENU 7-4) ........................................................... 45
Tone Length (MENU 7-5) ................................................................. 46
Tone (MENU 7-6) ............................................................................ 46
Set Time (MENU 7-7) ...................................................................... 46
InData/Fax (MENU 7-8) ................................................................. 46
SECURITY
Lock (MENU 0-1) ............................................................................ 47
Restrict (MENU 0-2) ........................................................................ 48
Lock Code (MENU 0-3) .................................................................... 48
Emergency Number (MENU 0-4) ..................................................... 48
Send PIN (MENU 0-5) ..................................................................... 49
Clear Memory (MENU 0-6) .............................................................. 49
NAM Mode (MENU 0-7) ................................................................... 50
Block Own Number (MENU 0-8) ...................................................... 50
Reset Phone (MENU 0-0) ................................................................. 50
4 Contents 5
Safety Precautions
Safety Precautions and Important Notices
Read these simple guidelines. Failure to comply with these
guidelines may be dangerous or illegal.
For more detailed safety information, see Safety Information
on page 57.
ROAD SAFETY COMES FIRST
Do not use a hand-held phone while driving; park the vehicle
first.
SWITCH OFF IN AIRCRAFT
Mobile phones can cause interference. Using them on aircraft
is illegal.
SWITCH OFF NEAR BLASTING
Do not use the phone where a blasting operation is in
progress. Observe restrictions, and follow any regulations or
rules in force.
SWITCH OFF WHEN REFUELLING
Do not use the phone at a refuelling point or near fuels or
chemicals.
INTERFERENCE
All mobile phone may be subject to radio interference, which
may affect their performance.
MESSAGES
Voicemail( 1)...............................................................................51
Page( 2)......................................................................................52
Text( 3).......................................................................................53
Alert( 4).......................................................................................53
Erase All( 5).................................................................................53
ACCESSORIES
Batteries ...............................................................................................54
Cigarette Lighter Adapter .......................................................................54
Travel Charger .......................................................................................54
Hands-Free Car Kit ................................................................................54
Ear-Microphone .....................................................................................54
RS-232C Cable .......................................................................................54
USINGTHEBATTERIES
Precautions When Using Batteries ..........................................................55
SAFETY INFORMATION
Road Safety ..........................................................................................57
Operating Environment ..........................................................................57
Care and Maintenance ...........................................................................59
Emergency Calls ....................................................................................60
GLOSSARY OF TERMS ........................................................................61
QUICK REFERENCE CARD...................................................................65
6Safety Precautions 7
Getting Started
Unpacking
Your package contains the following items.
Desktop Charger
In addition, you can obtain the
accessories for your phone
from your local SAMSUNG
dealer. For information on the
accessories, see page 54.
Handset
Battery
User’s Manual
Hand Strap
Getting Started
QUALIFIED SERVICE
Only qualified service personnel must install or repair cellular
equipment. Use only approved accessories and batteries.
USE SENSIBLY
Use only in the normal position (to ear).
Avoid unnecessary contact with the antenna when the phone
is switched on.
IMPORTANT! Use only accessories approved by the phone
manufacturer. This apparatus is intended for use when
supplied with power from SAMSUNG approved Travel adapter
and Desktop charger. The use of any other types will invali-
date any approval or warranty applying to the phone, and may
be dangerous.
When you disconnect the power cord of any accessory, grasp
and pull the plug, not the cord.
8Getting Started 9
Getting Started
Phone Layout
The following illustrations shows the main elements of your
phone.
Key Functions
Enters the menu facility. Also, scrolls through the menu
options.
In the menu facility, scrolls through the menu options.
In the idle mode, displays Phone Book names.
In the idle mode, enters RX Message menu.
In the menu facility, selects a menu function or stores
information that you have entered (such as a name in
the phone memory).
Makes or answers call.
In the idle mode, enters Outgoing call log.
Deletes characters from the display.In the menu
facility, returns to the previous menu level.
Ends a call. Also switches the phone on and off when
pressed and held. In the menu facility, returns to the
idle mode and cancels your input.
Enters numbers, letters and some special characters.
In the idle mode , enters Voice Dial mode when pressed
and held. In name input mode, moves cursor to left.
In the idle mode, quickly changes to Vibration mode
when pressed and held. In name input mode, moves
cursor to right.
(On the side of the phone)
Enters Voice Memo menu. Holding down the key starts
recording voice memo.
Adjusts voice volume during conversation and key beep
volume in the idle mode. In the menu facility, scrolls
through the menu options.
Antenna
Lamp
Earphone jack
Strap hole
Memo key
Volume keys
Earpiece
Display
Alphanumeric
keys
Vibration mode
key
See the opposite
page
Voice Dial key
Microphone
Flip Cover
~
10 Getting Started 11
Getting Started
Display
The display comprises two areas: an upper line of static icons,
and the lower text and graphic area. The following icons dis-
play at power-on:
Icons
Shows the received signal strength. The greater the
number of bars, the better the signal strength.
Indicates that the phone is outside a service area
and cannot send or receive calls.
Appears when you are out of your home area and
have registered with a different network (when
travelling in other countries, for example).
Appears when a new message has been received.
Indicates a Digital mode.
Indicates a Vibrate mode.
Shows the level of your battery. The more bars you
see, the more power you have left.
Icons
Text and
graphic area
Installing Battery
To Install the Battery
1. Hold the battery so that the metal contacts on the bottom
of the battery line up with the metal contacts on the back
of the phone.
2. Place the battery on the back of the phone with the top pf
the battery about a quarter of an inch from the latch.
3. Gently slide the battery toward the top of the phone until
snaps into place.
13
Getting Started
12 Getting Started
To Remove the Battery
If you want to remove the battery, do as follows:
1. If necessary, switch off the phone by holding down the
key until Bye Bye message is displayed.
2. Push and hold down the catch above the battery on the
back of the phone, and slide the battery down the phone.
Then lift the battery away.
Your phone is powered by a rechargeable Li-ion battery.
A desk top charger is provided with your phone. Use only
approved batteries and chargers. Ask you local SAMSUNG
dealer for further details.
The phone can be used while the battery is charging.
Note: You must fully charge the battery before using your phone
for the first time. A discharged battery is fully recharged in
approximately 180 minutes.
1. Plug the power cord of the charger into a standard wall
outlet.
2. Remove the battery from the phone and place it in the rear
compartment of the charger. The red lamp marked BATT on
the front of the charger lights up.
14 Getting Started 15
Getting Started
3. If you do not wish to use your phone while charging the
battery, you can leave the battery attached to the phone.
Place the phone with the battery attached in the front com-
partment of charger with the keypad facing forward. The
red lamp marked PHONE on the front of the charger lights
up.
Low Battery Indicator
When the battery is weak and only a few minutes of talk time
remain, a clear battery icon (no bars displayed) flashes in the
upper right corner of the screen. You will hear a warning tone.
When the battery become too weak for the phone to operate,
it switches off automatically.
Switching the Phone On/Off
1. Open the flip cover.
2. Hold down key for more than one second to switch
the phone on.
The red light flashes, an alert sounds:
•When the system locates services, the greeting message
displays along with the date and time. You can now
place and receive calls.
•If the system cannot locate service, the greeting
message displays without the date and time. In this
case, you cannot place and receive calls. Power off the
phone, then try again later when service is available.
•If your phone is locked, ‘-Locked-’ displays. Press
key, and enter the four-digit lock code to unlock
the phone.
3. When you wish to switch the phone off, hold down the
key for more than two seconds.
[ M O N ]
S A M S U N G
0 6 / 2 1 1: 45A
16 General Functions 17
General Functions
Making a Call
When the idle screen is displayed, key in the area code and
phone number and press key.
Note: If you have set Auto Retry option (7-1) to On (see page 45)
and the call does not connect, the phone
automatically retries to make the call.
Correcting the Number
To clear... Then
The last digit displayed Press the key.
The whole display Hold down the key for
more than one seconde.
Ending a Call
When you have finished you call, briefly press the key
or close the flip.
Emergency Dialing
You can place calls to 100 or one of the three emergency
numbers that are in your emergency number list even if your
phone is locked. For further information on emergency number
list, refer to page 48.
Prepend Dialing
The Prepend option enables you to add up to three digits,
such as area codes and network feature activation codes, to a
phone number of up to 10 digits. You can prepend an existing
entry in the Phone Book or Call Logs before dialing.
To prepend existing phone numbers in the Phone Book or Call
Logs:
1. Access the phone number entry.
2. When the desired phone number displays, press key
to access Options.
3. Press key to select Prepend option.
4. Enter the area code or feature code.
5. Press key to dial the number.
General Functions
18 General Functions 19
General Functions
Making a Call from the Phone Book
You can store the phone numbers called regularly in memory,
called the Phone Book. You then simply recall the number to
dial.
For further information on Phone Book, refer to page 33.
FINDING ENTRIES BY NAME, THEN DIAL
1. Press key in the idle mode.
The screen shows the names stored in the Phone Book in
the alphabetical order.
2. Use key to find the desired name. You can also enter
the first letter of the name by pressing the associated
alphanumeric key.
3. Press key to dial the stored number with the name.
ONE-TOUCH DIALING BY MEMORY LOCATION
Memory locations 01 through 09 are special one-touch
locations. You can dial the phone numbers stored in the Phone
Book memory from 01 through 09 simply by pressing one
button.
1. Press and hold the second digit of the memory location
containing the number to be dialed.
For example: Location no. 09
Press and hold.
The number (and name) stored is displayed, then dialed.
Voice Dialing
1. To place the call, press and hold key, or open the
flip, depending on the Set Active option (see page 44).
2. At the voice prompt, say the name into the phone.
•If the phone recognizes the name, the phone attempts a
connection.
•If the phone does not recognize the name, the screen
prompts for the name again.
•If the phone is unable to recognize the name after two
attempts, the message Cannot Recognize Name.
Please check name displays. Try the call again later, or
check the recorded name.
TWO-TOUCH DIALING BY MEMORY LOCATION
Once you have stored phone numbers in the phone book
memory, you can dial them easily whenever you want.
1. Press the first digit briefly, then hold down the second digit
of the memory cell.
For example: Location no. 23
Press briefly and hold down .
The number (and name) stored is displayed, then dialed.
21
General Functions
20 General Functions
The phone stores the last 10 numbers dialled. To recall any of
these numbers, proceeds follows.
1. If there are any characters on the display, clear the display
by holding down the key for more than one second.
2. Press key. The list of outgoing calls are displayed.
3. Use the key (or or key on the left side of the
phone) to scroll through the numbers until you select the
required number.
4. Press key to dial the number displayed.
Last Number Redial
When somebody calls you, the phone rings and CALL in the
middle of the screen is displayed.
If the caller can be identified, the caller’s phone number (or
name if stored in your Phone Book) is displayed. If the caller
cannot be identified, only the CALL message appears.
1. To answer a call, open the flip cover. If the flip is already
open, press key.
If the Any key Ans menu option (7-4) is set to On, you can
press any key to answer a call except for key.
2. End the call by closing the flip cover or pressing key.
Note: You can answer a call while using the phone book or
menu features.
Answering a Call
CALL
23
General Functions
22 General Functions
Viewing Missed Calls
If you are unable to answer a call for any reason, you can find
out who was calling you, if this service is available. In this
way, you can call the person back, if necessary.
The number of missed calls is displayed on the idle screen
immediately after the call was missed.
To view the missed call, refer to ‘Incoming’ (1-2) under
‘Calls’ on page 31.
In-Call Options
Call Waiting
This feature enables you to receive a second call during
conversation. When a Call Waiting call comes, the incoming
call alert sounds, when set, and a text notification displays.
Contact you service provider to activate Call Waiting call.
To answer a Call Waiting call:
1. To answer the call, Press key. The phone connects the
calling party, and places the current party on hold.
2. Press key again to switch between two parties.
Three-Way Calling
This feature enables you to conduct conference calls with two
separate parties at the same time. You are billed airtime for
each outgoing call separately.
Contact your service provider to activate Three-Way Calling.
To place a Three-Way call:
1. During conversation, press key, enter the phone
number for the third party, and then press key again.
The phone places the other party on hold.
2. When the third party answers, press key again, to
connect with the original party.
Missed 001
06/21 1:45P
24 General Functions 25
General Functions
During a call, if you want to adjust the earpiece volume, use
the volume keys on the left side of the phone. Press key
to increase and key to decrease the volume.
In the idle mode, you can adjust the key tone volume using
the same keys.
Adjusting the Volume
Press the keys to adjust
the volume.
Quick Switching to Vibration Mode
You can quickly switch your phone to Vibration mode with a
touch of key. Press and hold the key until the icon
and -Vibrate- appears in the display. Your phone goes to the
vibration mode immediately.
Press and hold key again to resume the phone’s alert
type which was previously set through the Ring menu under
SOUND menu; see page 36 for further details.
This feature is convenient when you are in a hurry to mute the
phone’s ringer in a theater for example.
You can access VOICE MEMO menu by pressing key on
the left side of the phone in the idle mode.
If you want to record voice memo, press and hold the key.
Your phone records voice up to 60 seconds while the key is
pressed and held.
For more information on VOICE MEMO menu, refer to page 40.
Recording Voice Memo
Press the key when
you record a memo.
Call Forwarding
This feature provides the option of forwarding incoming calls
to another phone number, even while your phone is off.
Activating Call Forwarding does not affect outgoing calls
made from this phone. Contact your service provider to
activate Call Forwarding.
Microphone Gain
During a call, when the remote party cannot hear you clearly,
adjust your microphone gain. Press the key, key,
then adjust the gain with or key (or or key
on the phone) until the remote party obtains an improved
sound quality.
26 Using the Menus 27
Using the Menus
Using the Scroll Keys
The following keys are used to set menu option by scrolling
then selecting an option.
Key Purpose
Enters the menu structure.
In the idle mode, moves to the next menu
in the main menu level and moves to the
next screen in the sub-menu levels.
In the menu mode, moves to the next
menu or option.
You can also use the or key on the
left side of the phone to move to the next
or previous option.
Access the menu displayed or the
highlighted option.
A three-level menu structure is available to set the various
options available on your phone. You can set the menu
options in two different ways.
Using the Menus
Example: Connecting the Record option in VOICE DIAL menu
1. Press key to access the main menu.
2. Press or key repeatedly until VOICE DIAL is
displayed, then press key. The VOICE DIAL menus
are displayed.
3. Press key to select Record highlighted. You are
connected to Record option.
Using the Index System
Each menu option is assigned a hierarchical number. You can
use this number to access the corresponding option directly.
Simply press and key in the required number.
Example: Connecting the Record option in VOICE DIAL menu.
1. Press key to access the main menu.
2. Press key to access VOICE DIAL menu. The VOICE
DIAL menus are displayed.
3. Press key to select Record. You are automatically
connected to Record option.
The numbers assigned to each option are indicated on the
following menu map.
Main Menu Menu Level 1 Menu Level 2
1. CALLS 1: Outgoing
2: Incoming
3: Erase Logs 1: Outgoing
2: Incoming
3: All
4: Air Time 1: Last Call
2: Total
3: Erase ToTal
2. PHONE BOOK 1: Find Name
2: My Phone #
3: Add Entry
4: Find Entry 1: Talk
2: Edit
3: Prepend
4: Erase
3. SOUNDS 1: Ring 1: Ring Vol
2: Ring Type
3: Ring Tone
2: Key Vol
3: Alert 1: MinuteBeep
2: SVC Area
4: Alarm 1: Set
2: Release
5: Diff. Ring
6: Power On/Off
7: Data/Fax
4. DISPLAY 1: Backlight
2: Greeting
3: Version
4: Language 29
Using the Menus
28 Using the Menus
Menu Map Main Menu Menu Level 1 Menu Level 2
5. VOICE MEMO 1: Review 1: Replay
2: Erase
3: Next Memo
2: Record
3: Erase All
6. VOICE DIAL 1: Record
2: REv/Erase
3: Erase All
4: Set Active
7. SETUP 1: Auto Retry
2: Auto Recv
3: AutoHyphen
4: Anykey Ans
5: ToneLength
6: Tone
7: Set Time
8. InData/FAx
0. SECURITY 1: Lock
2: Restrict 1: Phone Book
2: Incoming
3: Outgoing
3: Lock Code
4: Emergency #
5: Send PIN
6: Clr Memory
7: NAM Mode 1: Manual NAM
2: Auto NAM
8: Block Own #
0: ResetPhone
30 Calls 31
Calls
Outgoing
The phone stores up to nine outgoing calls you dialed. When
you access this menu, the list of outgoing calls are displayed.
To... Press...
Select an entry key
Dial the selected entry key
View the date and time key
at which the call was dialed
and use option features
When you press key, you can view the date/time stamp
for the selected entry. If there is a Phone Book match, the
name displays.
Press key to access Options. The following options are
available:
Talk: dials the selected number.
Show Entry (or Store if the phone number is not currently
stored in the Phone Book): shows Phone Book
entry or stores the number in the Phone Book.
Prepend:allows to add an area code or feature code to the
number before calling or saving the number.
You can use the CALLS menu to:
• View and dial the last outgoing or incoming numbers.
•Erase the numbers in the CallLog memory
• View the duration of calls.
Calls
MENU 1-1
Incoming
This option lets you view the last 9 calls received. When you
access this menu, the last of incoming calls are displayed.
To... Press...
Select entry key
Dial the selected entry key
View the date and time key
at which the call was received
and use option features
When you press key, you can view the date/time
stamp for the selected entry. If there is a Phone Book match,
the name displays.
Press key to access Options. The following options are
available:
Talk: dials the selected number.
Show Entry (or Store if the phone number is not currently
stored in the Phone Book): shows Phone Book
entry or stores the number in the Phone Book.
Prepend:allows to add an area code or feature code to the
number before calling or saving the number.
MENU 1-2
32 Calls 33
Phone Book
Find Name
The Phone book allows you to store frequently used phone
numbers and the associated names in your personal directory to
make it easy for you to make a call without having to remember
or enter the phone number. You can store up to 79 numbers.
Phone Book
Air Time
Using this option, you can view the call time of the last call,
as well as total air time for all calls since you last reset
thetimer.
Last Call: length of the last call
Total Call: total length of all calls made since the timer was
last reset.
EraseTotal: resets the call timers.
Erase Logs
You can erase the numbers stored in the Call Log memory.
Outgoing: The numbers you called are erased.
Incoming: The numbers you received are erased.
All: All calls you dialled and received are erased.
MENU 1-3
MENU 2-1
MENU 1-4
This option displays the stored names in the Phone Book in
alphabetical list.
Press key to scroll to the desired name. You can also
enter the first letter of the name by pressing the associated
alphanumeric key. Using this method, the phone searches for
the names in the list beginning with that letter, and then
displays the first name in that section of the list. If desired,
you can also enter the second letter in the name by pressing
the associated alphanumeric key.
When the desired entry displays, press key to place a
call. If you press key, you can access the following
options:
Talk: dials the number.
Edit: allows you to edit phone number, name, or entry
number. Secret option prevents the number from being
displayed in the screen.
Prepend: prepends the number to add an area code or
feature code to the number before dialing.
Erase: erases the number.
Note: You can locate Phone Book entries quickly when the phone
is in the idle mode. Press key to access Find Name
menu in one step and then press key to scan
entries.
35
Phone Book
34 Phone Book
My Phone Number
You can check your own phone number. If you have more than one
own phone number, press key to check the next number.
Note:You can block this feature by setting Block Own Number
option to ON. Refer to page 50.
MENU 2-2
Add Entry
Using this option, you can store a phone number with a name
in your Phone Book.
Enter the phone number and press key. The first
available location displays.
To accept the displayed location, press key. To select
another location, press key to scroll to the desired
location or enter the location number using number keys, then
press key.
To include a name with the phone number entry, enter the
desired name, then press key. For information on how
to enter a name, see page 35.
Storing Phone Numbers at Call End
To store a phone number following conversation:
1. Press key to end the call. The call time and the
phone number display.
2. To store the phone number, press key. The first
available location displays.
3. To finish this process, follow above mentioned instructions.
MENU 2-3
Find Entry
This option allows you to find an entry by location number.
Enter the location by pressing the number keys or press
key to scroll to the desired location, then press key to
display the selected entry.
When the desired entry displays, press key to place a
call.
If you press key, you can access Options. For details on
Options, refer to Find Name menu on page 33.
MENU 2-4
Entering a Name
1. Press the key labeled with required letter.
Since each key has three or more letters, press the key
repeatedly the desired letter appears in the display.
2. Select the other letters in the same way.
Note: The cursor moves to the right when you press a different
key. When entering the same letter twice (or a different
letter on the same key), just wait for a second for the
cursor to move right automatically, and then select the
next letter. You can also move the cursor by using
and keys. To delete letters, press key.
37
Sounds
36 Sounds
Ring
Ring Volume
This option allows you to adjust the ringing volume to one of
nine levels. You can also turn the ringer off. Use the or
key on the left side of the phone. The greater the number of
bars, the greater the volume. You will also hear a sample
tone.
Note: During an incoming call, you can mute the ringer by press-
ing key.
Ring Type
This option allows you to indicate how you are to be informed
of any incoming calls. The following options are available.
Bell: The phone rings using the ring tone selected via the
menu option.
Lamp: Only the backlight is switched on; the phone neither
rings nor vibrates.
Vibrator: The phone vibrates but does not ring.
Vib + Bell: The phone both rings and vibrates.
You can use the Sounds feature to customize various sound
settings, such as the:
• Ring volume, type, and tone
• Alert sounds
Sounds
MENU 3-1
Ring Tone
This option allows you to select the required ringing tone. You
can choose between 20 different tones or melodies. Each time
you select a tone, it is played for a few seconds.
Key Volume
This option allows you to adjust the tone volume that the
keypad generates when you press a key. You can also use
or key on the left side of the phone to adjust key
volume in the idle mode.
MENU 3-2
Alert
Minute Beep
With this menu option set to ON, the phone beeps every
minute during an outgoing call to keep you informed of the
length of your call.
Service Area
With this menu option set to ON, the phone beeps when you
are out of service area or when you return to a service area.
MENU 3-3
Alarm
The option allows you to set the alarm to ring at a specific
time.
The following options are available.
Daily: the alarm rings every day at the same time.
One Time: the alarm rings only once and is then deactivated.
MENU 3-4
39
Display
38 Sounds
Differential Ring
This option allows you to activate a unique ring to signal an
incoming call by a stored caller number.
You can specify up to 5 callers and select a unique ring type
for each caller from 20 different tones and melodies.
MENU 3-5
Power On/Off
With this menu set to ON, the phone rings a tone each time
the phone is switched on or off.
MENU 3-6
Data/Fax
This option allows you to be alerted with a distinct ringing
tone when you are faxed or received a data through the
phone. You can choose between 20 different tones or
melodies. Each time you select a tone, it is played for a few
seconds.
MENU 3-7
Backlight
You can select whether or not the phone uses the LCD
backlight. The following options are available.
8 SECONDS: The backlight comes on when you press a key
or receive a call and switches off 8 seconds
after the last key is pressed.
OFF: The backlight is not used.
Greeting
This option allows you to set a greeting message to be
displayed in the idle mode. It is preset to SAMSUNG.
You can change the greeting message according to your own
preference.
Enter your personal greeting up to 12 digits by using the
alphanumeric keys. For more information on entering a name,
refer to page 35.
Display
MENU 4-1
MENU 4-2
To set the alarm, proceed as follows.
1. Select Set.
2. Choose the alarm frequency option.
3. Enter the required time.
4. Press key.
To stop the alarm when it rings, simply open the flip cover or
press the key.
To deactivate the alarm, select Release.
Version
This option allows you to view the software version of your
phone.
Language
You can select a display language on your phone.
MENU 4-3
MENU 4-4
Voice Memo
Voice Memo 4140
Review
This option allows you to play back all memos recorded,
starting with the most recent memo. The screen displays the
label if you have entered. If not, the screen displays the date
and time when the memo was recorded.
While the memos are playing, the following options are
available.
Replay: plays the current memo once again.
Erase: erases the memo currently being played.
Next Memo: skips to the next memo.
You can use the Voice Memo feature to:
• Record up to 10 voice memos
• Play the recorded voice memos
• Erase one or all voice memos
Voice Memo
MENU 5-1
Record
This option allows you to record a memo. You can record up
to 10 different memos.
Press and hold key on the left side of the phone. While
you hold down the key, you can record a memo for a
maximum of 60 seconds.
To stop recording, just release the key. The following options
display.
Add Label:allows you to add a label for the memo you have
just recorded. Enter a proper name up to 12 digits
using the number keypad. If you do not add label,
the recorded date and time will be used to
identify the memo.
Continue: allows you to continue recording the memo.
Erase:allows you to erase the memo you have just
recorded.
Erase All
This option allows you to erase all the memos. Press
key when you are asked to confirm.
MENU 5-2
MENU 5-3
Voice DialVoice Dial 4342
Record
This option allows you to register numbers for subsequent
voice dialing. The phone provides voice prompts and screen
displays to guide you through the recording process.
Respond to the prompt by saying the name you want to save.
The phone stores the name as a first sample, and then
prompts for the name again.
Respond to the prompt by repeating the name after the beep.
The phone stores the name as a second sample, and then
requests the phone number.
Enter the phone number by pressing the digit keys.
To store the phone number, press key. The name (if
matched up to Phone Book) and number display, along with
the notification Recorded.
Tips on Recording Name
• Avoid recording similar names phonetically. If you record a
similar name to the one already in memory, the phone
requests another name.
You can call up to 20 stored entries by speaking the name into
the microphone. Before using the Voice Dialing feature, you
must record the name in your phone.
Voice Dial
MENU 6-1
• Speak clearly and natural.
•The person who will use the phone should record the name.
The phone does not recognize the name if the voice sounds
differently.
• Avoid too long or too short name. It is recommended to con-
tain 2 to 5 syllables.
• Voice dial feature is available only in CDMA mode.
•If this feature does not work properly, erase the name, and
record with another name.
•It is recommended to practice several times to obtain best
result.
• You can record up to 20 names. If you record more than 20,
the phone announces ’Memory is full’.
Review/Erase
This option allows you to check or erase an individual voice
dial entry. A list of entries displays.
Press the digit key to select the desired entry, or press the
key to scan entries
When you select the desired entry, the recorded name plays
audibly.
If you want to erase the selected entry, press key
while the name is playing.
MENU 6-2
45
Setup
44 Voice Dial
Erase All
This option allows you to delete all voice dialing entries.
Press key, when you asked to confirm. Otherwise, press
or key to exit the function without deleting the
voice dialing entries.
MENU 6-3
Set Active
Voice Dialing is always active once you have recorded a name
and have entered the associated phone number. To place a
call using Voice Dialing, simply press and hold key in
the idle mode and then say the name into the phone after you
hear the prompt.
You can also initiate a Voice Dialing call just by opening the
flip, when you select this option.
[ ] only: Enables Voice Dialing only by pressing and holding
key.
[ ]/Flip: Enables Voice Dialing by pressing and holding
key or by opening the flip.
MENU 6-4
Auto Retry
With this menu option set to ON, when you place a call and
the call does not connect, your phone continues to place the
call to the entered phone number.
Many different features of your phone can be customized to
suit your preferences.
Setup
MENU 7-1
Auto Receive
With this menu option set to ON, the phone automatically
answers calls.
When a call comes in, your phone will answer the call
automatically after 2 rings. The feature does not work if you
have chosen Vibrate or Off as your ring volume.
MENU 7-2
Auto Hyphen
With this menu option set to ON, your phone automatically
hyphenates numbers as follows: 012-345-6789.
Digits following a pause are not hyphenated.
MENU 7-3
Any Key Answer
With this menu option set to ON, you can answer an incom-
ing call by pressing any key except key.
MENU 7-4
47
Security
46 Setup
Tone Length
Some phones you call can recognize only longer tones. You
may have to change the length to LONG for some calls.
When calling a paging system, your phone should be in the
SHORT mode.
MENU 7-5
Tone
Release Tone: You can set your phone to sound the release
tone when a call is released or dropped.
Connect Tone: You can set your phone to sound the connect
tone when your call is connected to the sys-
tem.
MENU 7-6
Set Time
The option enables you to set the current date and time. Enter
the time and date.
The current time, if set, displays. The month, day, hour and
minute must be entered with 2 digits. The year requires all
four digits. If you do not input the time or you input the wrong
time, Invalid Time displays.
MENU 7-7
InData/Fax
To send or receive data or fax through the phone, you have to
set this option to Data or Fax. When you want to use the
phone for a normal voice call, set to Voice Call.
The following options are available:
Voice Call: receives a call.
Data: receives or sends data.
Fax: receives or sends fax.
MENU 7-8
Lock
Locking the phone restricts outgoing calls to emergency num-
bers.
The following options are available:
OFF: the phone remains unlocked.
NOW: the phone locks immediately
ON POWER-UP:the phone locks automatically at the next
power-up.
To place an emergency call on Lock mode:
• To call an emergency number, enter the number and then
press key.
• To place normal outgoing calls, press key to display
the Lock Code screen, and then enter the lock code. When
the Standby screen displays, enter the phone number, and
then press key.
Your phone provides many security options, including a
user-programmable lock code, and call restriction features.
To access the security menu, you must enter a four-digit lock
code.
Security
MENU 0-1
48 Security 49
Security
Lock Code
This feature allows you to change your current lock code to a
new one. The lock code is preset to 0000 at factory.
Enter a new, four-digit lock code.
Restrict
This feature allows you to restrict your calls. Call Restriction
can be set up in the following ways.
Phone Book: the phone restricts the use of the Phone Book.
Incoming Call: calls cannot be received.
Outgoing Call: calls cannot be made.
Each option can be restricted or unrestricted individually.
MENU 0-3
MENU 0-2
Emergency Number
This feature allows you to call to emergency numbers when
the phone is locked or when the outgoing call is restricted.
This menu provides the option of storing three emergency
numbers. Select a location and enter the desired number.
To dial emergency numbers in Lock mode; enter the
emergency number, then press key.
MENU 0-4
Clear Memory
This menu option allows you to erase all numbers in the
Phone Book memory.
Send PIN
This feature prevents the phone from being used by
unauthorized persons. The feature is only available when if
your system supplier provides this service and you have a PIN
assigned by the system supplier.
These options are available:
Never: The option is not activated
Prompt:When you make a call, you are asked to send PIN.
For information in this service in detail, contact your service
provider.
MENU 0-6
MENU 0-5
50 Security 51
Messages
Block Own Number
This feature allows you to block your own number display, and
others cannot view your phone number. If you turn this feature
on, the message Blocked for phone number displays when
the My phone # feature is accessed.
MENU 0-8
NAM Mode
The NAM (Number Assignment Module) enables you to
subscribe to one or more service networks.
The following options are available:
Manual NAM: You set the phone to the network you want to
use. You can select a NAM from a maximum
of 4 NAMs. If you select a new network
manually, the phone shows the greeting
message and sounds the starting beep, and
then returns to the Standby mode. For details,
contact your service provider.
Auto NAM:The phone selects the networks automatically
based on system information for the area you are
in.
MENU 0-7
Reset Phone
With this menu option, you can easily reset your phone to its
default configuration. Also, all phone memories are cleared.
MENU 0-0
Voicemail
The screen displays Voicemail, the time, date and the
number of new, unread messages.
Press key to access the following options.
Listen: You can listen to the voicemail.
Reset: You can reset the counter for voicemail messages, if
desired. (The system resets the counter automatically
after you listen to all new messages.)
Your phone receives voicemail notification, text messages,
and pages. And your phone transmits text messages and
pages if your system supplier provides this service. When the
phone receives a message, an alert sounds, and a text notifi-
cation displays. The icon remains on the screen until you
read the pending text messages or until you listen to the
voicemail notification messages
Your phone can store up to 20 pages and text messages,
depending on the length of the message. If the message
memory is full, an error message is displayed and you cannot
receive any new messages. Delete obsolete messages.
Messages
1
52 Messages 53
Messages
An indexed list of page messages displays. An exclamation
point next to an entry indicates an urgent message. A check
mark next to an entry indicates that you have read and stored
the message.
Select the desired message to review, then press key.
After reviewing the message, press key to access the
following options.
Talk: To call the phone number.
Save: To store the phone number in your Phone Book.
Next: To review the next message.
Previous: To review the previous message.
Page 2
Alert
The phone alerts you when a message is received. You can
choose how frequently this happens. The three options are :
EVERY 2 MIN,OFF,ONCE.
4
Erase All
This menu option allows you to erase all stored messages.
5
Text
An indexed list of text messages displays. An exclamation
point next to an entry indicates an urgent message. A check
mark next to an entry indicates that you have read and stored
the message.
Select the desired message to review, then press key.
After reviewing the message, press key to access the
following options.
Talk: To call the phone number.
Save: To store the phone number in your Phone Book.
Next: To review the next message.
Previous: To review the previous message.
3
55Using the Batteries
54 Accessories
Your phone is powered by a rechargeable Li-ion 1000 mAh
standard battery.
The following batteries are also available (ask your
SAMSUNG dealer for further details):
– SLIM Battery (674 mAh)
– STANDARDBattery (1000 mAh)
– EXTENDED Battery (1600 mAh)
Precautions When Using Batteries
•Never use any charger or battery that is damaged in any
way.
•Use the battery only for its intended purpose.
•If you use the phone near the network’s base station, it
uses less power; talk and standby times are greatly affect-
ed by the signal strength on the cellular network and the
parameters set by the network operator.
•Battery charging times depend on the remaining battery
charge and the type of battery and charger used. The bat-
tery can be charged and discharged hundreds of times, but
it will gradually wear out. When the operation time (talk
time and standby time) is noticeably shorter than normal, it
is time to buy a new battery.
•If left unused, a fully charged battery will discharge itself
over time.
Using the Batteries
Batteries
Three types of Li-ion batteries are available for use with your
phone:
• SLIM Battery
• STANDARD Battery
• EXTENDED Battery
Cigarette Lighter Adapter
The Cigarette Lighter Adapter charges your phone in a vehicle
while you drive and enables you to operate the phone from a
vehicle cigarette lighter socket.
Travel Charger
The Travel Charger plugs into a wall outlet and enables you to
charge a single battery at your home or office or while traveling.
Hands-Free Car Kit
The Hands-Free Car Kit provides safety, freedom and conve-
nience in your vehicle. (Kit includes Cradle and Microphone.)
Ear-Microphone
The Ear-Microphone includes both the earpiece and microphone
in a convenient, lightweight unit.
RS-232C Cable
The RS-232C Cable connects your SCH-611 to your computer
port, allowing you to use Internet or other communication
programs.
Accessories
Road Safety
• Remember, road safety always comes first!
•Do not use a hand-held phone while driving a vehicle.
Always park the vehicle before having a conversation.
•Make sure that the phone is stored safely and will not fall
or be broken in the event of a collision or emergency stop.
•The use of an alert device to operate a vehicle’s lights or
horn on public roads is not permitted.
•Only qualified personnel should install or service the phone
in a vehicle. Faulty installation or service may be danger-
ous and may invalidate any warranty applicable to the unit.
•Electronic fuel injection, anti-skid braking, electronic cruise
control or any other electronic systems may malfunction
due to the lack of protection from radio signals. Check
regularly that all cellular phone equipment in your vehicle
is mounted and operating correctly.
Operating Environment
•Remember to follow any special regulations in force in any
area and always switch off your phone whenever it is for-
bidden to use it, or when it may cause interference or dan-
ger (in a hospital for example).
Safety Information
•Use only Samsung-approved batteries and recharge your
battery only with Samsung-approved chargers. When a
charger is not in use, disconnect it from the power source.
Do not leave the battery connected to a charger for more
than a week, since overcharging may shorten its life.
•Extreme temperatures will affect the charging capacity of
your battery: it may require cooling or warming first.
•Do not leave the battery in hot or cold places, such as in a
car in summer or winter conditions, as you will reduce the
capacity and life-time of the battery. Always try to keep
the battery at room temperature. A phone with a hot or
cold battery may temporarily not work, even when the bat-
tery is fully charged. Li-ion batteries are particularly
affected by temperatures below 0 °C (32 °F).
•Do not short-circuit the battery. Accidental short circuiting
can occur when a metallic object (coin, clip or pen) causes
a direct connection between the + and - terminals of the
battery (metal strips on the back of the battery), for exam-
ple when you carry a spare battery in a pocket or bag.
Short-circuiting the terminals may damage the battery or
the object causing the short-circuit.
•Dispose of used batteries in accordance with local regula-
tions. Always recycle. Do not dispose of batteries in a fire.
57Safety Information
56 Using the Batteries
59
Safety Information
58 Safety Information
Care and Maintenance
Your phone is a product of superior design and craftsmanship
and should be treated with care. The suggestions below will
help you fulfill the warranty obligations and enjoy this product
for many years.
•Keep the phone and all its parts and accessories out of the
reach of small children.
• Keep the phone dry. Precipitation, humidity and liquids con-
taining minerals will corrode the electronic circuits.
•Do not use or store the phone in dusty, dirty areas as its
components may be damaged.
•Do not store the phone in hot areas. High temperatures can
shorten the life of electronic devices, damage batteries and
warp or melt certain plastics.
•Do not store the phone in cold areas. When the phone
warms up (to its normal temperature), moisture can form
inside the phone, which may damage the electronic cir-
cuits.
•Do not attempt to open the phone. Non-expert handling of
the phone may damage it.
•Do not drop or knock the phone. Rough handling may
damage the internal circuits.
•Operation of any radio transmitting equipment, including
cellular phones, may interfere with inadequately protected
medical devices. Consult a physician or the manufacturer
of the medical device if you have any questions. Other
electronic equipment may also be subject to interference.
•As with other mobile radio transmitting equipment, you are
advised that for satisfactory operations and personal
safety, the equipment should only be used in the normal
operating position.
•Always switch off the phone when at a refuelling point
(service station). You are reminded of the need to observe
restrictions on the use of radio equipment in fuel depots
(fuel storage and distribution areas), chemical plants or
where blasting operations are in progress.
•Do not store or carry flammable liquids, gases or explosive
materials in the same compartment as the phone, its parts
or accessories.
•Switch off your cellular phone when in an aircraft. The use
of cellular phones in an aircraft is illegal and may be
dangerous to the operation of the aircraft or disrupt the
cellular network. Failure to observe these instructions may
lead to the suspension or denial of cellular telephone ser-
vices to the offender, legal action or both.
61
Glossary of Terms
60 Safety Information
Airtime -Actual time spent talking on the wireless phone.
Most carriers bill customers based on how many
minutes of airtime they use each month.
Antenna -A device for transmitting or receiving signals. The
size and shape of antennas is determined, in part,
by the frequency of the signal they receive.
Wireless phones and the base station must have
antennas.
Base Station - The fixed radio transmitter/receiver that main-
tains communications with mobile radio tele-
phones within a given area. (Typically seen as
cell or cell site)
CDMA -(Code Division Multiple Access) A spread-spectrum
approach to digital transmission. With CDMA, each
conversion is digitized and then tagged with a code.
The mobile phone deciphers only a particular code to
pick the right conversation off the air. The transmit-
ted signal is just above noise level across the avail-
able bandwidth.
Channel - Communications signals transmit along paths
called channels.
Codec - Compression & Decompression.
Deactivation -The process of rendering a wireless phone
inactive.
DTMF - (Dual-tone Modulated Frequency ) You send DTMF
signals when you enter numbers by pressing the digit
keys.
Glossary of Terms
•Do not use harsh chemicals, cleaning solvents or strong
detergents to clean the phone. Wipe it with a soft cloth
slightly dampened in mild, soapy water.
•If the phone or any of its accessories are not working
properly, take them to your nearest qualified service centre.
The personnel there will assist you, and if necessary,
arrange for the phone to be repaired.
Emergency Calls
Important!This phone, like any cellular phone, uses radio
signals, cellular and landline networks, as well
as user-programmed functions that cannot
guarantee connection in all conditions.
Therefore, you should never rely solely on any
cellular phone for essential communications
(medical emergencies for example).
Remember, to make or receive any calls, the phone must be
switched on and in a service area with adequate cellular
signal strength.
Emergency calls may not be possible on all cellular phone
networks or when certain network services and/or phone
features are in use. Check with local cellular service
providers.
63
Glossary of Terms
62 Glossary of Terms
EVRC -(Enhanced Variable Rate Codec) EVRC is a new global
standard for compressing and decompressing voice
signals. EVRC uses a lower bit rate (the number of bits
sent per second) than existing CDMA vocoders, while
providing significant improvements in voice quality.
This technology enables your phone to provide superb
voice quality while benefiting from the ability to
process more cellular voice calls using less bandwidth
than the voice codecs in CDMA networks today.
Frequency -A measure based on time, as one or more waves
per second, in an electrical or light wave infor-
mation signal. A signal’s frequency is stated in
cycles-per-second or Hertz (Hz).
Hands-Free -A feature that permits a driver to use a wire-
less phone without lifting or holding the
handset - an important safety feature for
automobiles, tractors and most other motorized
vehicles.
LCD -(Liquid Crystal Display) Commonly used to refer to the
screen display on the wireless phone.
LED -(Light Emitting Diode) Commonly used to refer to a
small light on the wireless phone or on the Desktop
Charger. The LED lights on the phone to indicate an
incoming call. The lights on the charger to indicate that
battery charging is taking place.
Prepend -The addition of a prefix, such as an area code, to a
phone number.
RF - Radio Frequency
Roaming -The ability to use a wireless phone to make and
receive calls in places outside of the home service
area.
Service Charge -The amount paid each month to receive
wireless service.
Standby Time -The amount of time a fully charged wireless
portable or transportable phone can be on
and idle without being in use. (See Talk Time)
Talk Time -The length of time a person can talk on a
portable or transportable wireless phone without
recharging the battery.
Vocoder - Voice Coder. A device used to convert speech into
digital signals.
Voicemail -A computerized answering service that answers
a call, plays a greeting and records a message.
Depending on the sophistication of the service, it
can notify the subscriber, via a pager, of an
incoming call or message. (Also called voice
messaging)
Wireless -Radio-based Systems that allow transmission of
telephone or data signals through the air without
a physical connection, such as a metal wire
(copper) or fiber optic cable.
