Users Manual

* Depending on the software installed or your service provider or country, some of the descriptions in

this guide may not match your phone exactly.

* Depending on your country, your phone and accessories may appear different from the illustrations in

this guide.

World Wide Web

http://www.samsungmobile.com

Printed in Korea

Code No.:GH68-XXXXXA

English. 09/2006. Rev. 1.0

SCH-F519

User’s Guide

Indian_Draft

2006. 09. 14

Important

safety

precautions

Failure to comply with the following

precautions may be dangerous or

illegal.

Drive safely at all times

Do not use a hand-held phone while driving. Park the

vehicle first.

Switch off the phone when refuelling

Do not use the phone at a refuelling point (service

station) or near fuels or chemicals.

Switch off in an aircraft

Wireless phones can cause interference. Using them in

an aircraft is both illegal and dangerous.

Switch off the phone near all medical equipment

Hospitals or health care facilities may be using

equipment that could be sensitive to external radio

frequency energy. Follow any regulations or rules in

force.

Interference

All wireless phones may be subject to interference,

which could affect their performance.

Important safety precautions

Be aware of special regulations

Meet any special regulations in force in any area

and always switch off your phone whenever it is

forbidden to use it, or when it may cause

interference or danger.

Water resistance

Your phone is not water-resistant. Keep it dry.

Sensible use

Use only in the normal position (held to the ear).

Avoid unnecessary contact with the antenna when

the phone is switched on.

Emergency calls

Key in the emergency number for your present

location, then press .

Keep your phone away from small children

Keep the phone and all its parts, including

accessories, out of the reach of small children.

Accessories and batteries

Use only Samsung-approved batteries and

accessories, such as headsets and PC data cables.

Use of any unauthorised accessories could damage

you and your phone and may be dangerous.

Qualified service

Only qualified service personnel may repair your

phone.

For more detailed safety information, see "Health

and safety information" on page 109.

• The phone could explode if the battery is

replaced with an incorrect type.

• Dispose used batteries according to the

manufacturer’s instructions.

At very high volumes, prolonged listening

to a headset can damage your hearing.

About this Guide

This User’s Guide provides you with condensed

information about how to use your phone. To

quickly learn the basics for your phone, please refer

to “Get started” and “Step outside the phone.”

In this guide, the following instruction icons

appear:

Indicates that you need to pay careful attention

to the subsequent information regarding safety

or phone features.



Indicates that you can get more information on

the referenced page.

→

Indicates that you need to press the Navigation

keys to scroll to the specified option and then

select it.

[ ]

Indicates a key on the phone. For example, [ ]

< >

Indicates a soft key, whose function is displayed

on the phone screen. For example, <

• Camera and camcorder

Use the camera module on your

phone to take a photo or record a

video.

Special

features of your phone

•MP3 player

Play music files using your phone

as an MP3 player.

• Melody composer

Make your own melodies for your

phone.

• Answering machine

Record a caller’s message on your

phone when you are unable to

answer an incoming call.

Special features of your phone

• File viewer

Open documents in various

formats on the phone without

corruption.

•Bluetooth

Connect to a headset or hands-

free car kit using wireless

Bluetooth technology.

•WAP browser

Access the wireless web to get up-

to-the-minute information and a

wide variety of media content.

• Multimedia Message Service

(MMS)

Send and receive MMS messages

with a combination of text,

images, video, and audio.

• SOS message

Send SOS messages to your

family or friends for help in an

emergency.

•Name card

Create name cards with your

number and profile. Whenever

introducing yourself to others, use

this convenient name card.

•Calendar

Keep track of your daily, weekly,

and monthly schedule.

•Memory disk

Connect your phone to a

computer to copy files directly to

and from it.

Contents

Unpack 6

Make sure you have each item

Your phone 6

Keys, features, and locations

Get started 7

First steps to operating your phone

Install and charge the phone ........................... 7

Power on or off.............................................. 9

Keys and display........................................... 10

Access menu functions .................................. 13

Customise your phone................................... 14

Make/Answer calls ........................................ 16

Step outside the phone 17

Begin with your camera, the MP3 player, the WAP

browser, and other special features

Use the camera ............................................ 17

Play music ................................................... 18

Use melody composer ................................... 19

Browse the WAP........................................... 20

Use Contacts ............................................... 21

Send messages ............................................ 22

View messages ............................................ 23

Send SOS messages ..................................... 24

Use Bluetooth .............................................. 25

Use My Menu ............................................... 26

Enter text 27

T9 English, T9 Hindi, ABC, Hindi, 123, Symbol modes

Call functions 30

Advanced calling features

Menu functions 34

All menu options listed

Solve problems 107

Help and personal needs

Health and safety information 109

1 Calls

p.34

1 Missed

2 Incoming

3 Outgoing

4 Rejected

5 Air time

6 International

7 Call reject

p.34

p.35

p.36

2 Contacts

p.36

1 Find

2 Add

3 Group settings

4 Speed dial

5 Name card

6 My phone #

7 Memory info

p.37

p.38

p.39

p.40

p.41

p.42

3 Multimedia

p.42

1 Take photo

2 My album

3 Photo studio

4 Settings

p.42

p.48

p.52

p.56

4 Display

p.56

1 Wallpaper

2 Banner

3 Functional screen

4 Menu type

5 Power on/off

6 Dialing effect

7 Time setting

8 Backlight

9 Lighting

p.56

p.57

p.58

5 Message

p.59

1 Multimedia

message

2 Text message

p.59

p.63

6 Sounds

p.69

1 Ringer

2 Ringer vol./Type

3 Key tone

4 Function alert

5 Hour alert

p.69

p.70

7 do mOre

p.71

1 Games

2 MP3

3 Melody composer

4 VOD

5 TATA Zone

6 Mobile browser

7 SMS Services

p.71

p.75

p.78

p.79

p.80

p.83

8 Utilities

p.83

1 Today

2 Calendar

3 Task list

4 Alarm

5 User memory

6 Voice tools

7 Memo pad

8 Calculator

9 Countdown

0 Clock

* Bluetooth

p.83

p.84

p.87

p.88

p.89

p.92

p.94

p.95

p.96

p.97

p.98

9 Settings

p.100

1 Security

2 Input method

3 Language setup

4 Call settings

5 Domains preset

6 Contents status

p.100

p.104

p.106

Overview of menu functions

To access Menu mode, press <

> in Idle mode.

Unpack

Make sure you have each item

• Phone

•Travel Adapter

•Battery

•User’s Guide

The items supplied with your

phone and accessories available

at your Samsung dealer may

vary, depending on your country

or service provider.

Your phone

Keys, features, and locations

Get started

First steps to operating your phone

UIM card information

When you subscribe to a cellular network, you

receive a plug-in UIM (User Identification

Module) card loaded with your subscription

details, such as your PIN, and available optional

services.

Install and charge the phone

Remove the battery

cover.

If the phone is

already on, first turn

it off by pressing and

holding [ ].

Insert the UIM card.

Make sure that the

gold-coloured

contacts on the card

are face down.

Install the battery.

Reattach the

battery cover.

Plug the travel

adapter into the

phone.

Plug the adapter into a standard AC power

outlet.

Get started

Low battery indicator

When the battery is low:

• a warning tone sounds,

• the battery low message displays, and

• the empty battery icon blinks.

If the battery level becomes too low, the phone

automatically turns off. Recharge your battery.

Power on or off

Keypad lock

When you close the phone, the keypad lock

feature locks the exposed keys to avoid

accidental key presses.

1. Press and hold [ ].

When the phone is completely charged (the

battery icon becomes still), unplug the

charger from the power outlet.

Remove the adapter

from the phone.

Switch on

Do not turn on

the phone when

mobile phone use

is prohibited.

1. Open the phone.

2. Press and hold [ ].

3. If necessary, enter the

PIN and press <

Switch off

1. Open the phone.

2. Press and hold [ ].

Get started

2. Press [Up] to unlock the keys or [Down] to

keep the keys locked.

Airplane mode

You can switch the phone to Airplane mode, in

which the phone functions requiring network

connection are deactivated. This mode is helpful

when you want to use your phone in a place

where you are not allowed to use mobile

devices, such as in an airplane and at a

hospital.

To switch to Airplane mode, press <

> and

select

Settings

→

Call settings

→

Airplane

mode

→

In Airplane mode, you can use non-wireless

functions, such as games, camera, and MP3

player.

Keys and display

Keys

Soft

keys

Perform the function indicated on

the bottom line of the display.

Naviga

tion

keys

In Idle mode, access the following

menus directly:

• Up: My Menu mode

•Down:

Mobile browser

•Left:

Calendar

•Right:

Message

;

New message

Text message

when held

down

In Menu mode, scroll through menu

options.

Get started

WAP

key

In Idle mode, enter the

do mOre

menu. Press and hold to enter the

TATA Zone

menu.

In Menu mode, perform the

functions indicated on the bottom

line of the display.

MP3

key

In the MP3 player, play or pause

music.

Return to the previous file during

music playback.

Skip to the next file during music

playback.

Send

key

Make or answer a call.

In Idle mode, retrieve numbers

recently dialled, missed, or

received.

End

key

Delete characters from the display.

In Menu mode, return to the

previous menu level.

Numeri

c keys

Enter numbers, letters, and some

special characters.

In Idle mode, press and hold [

] to

enter an international call prefix.

Special

key

Enter special characters.

In Idle mode, press and hold [ ] to

activate or deactivate Silent mode.

End

key

Press and hold to switch the phone

on or off.

End a call.

In Menu mode, cancel input and

return the phone to Idle mode.

Get started

Display

Camer

a key

In Idle mode, enter the

Multimedia

menu. Press and hold to turn on the

camera.

In Camera mode, take a photo or

record a video.

During a call, press and hold to

record your call conversation.

Volum

e key

Adjust the volume.

In Idle mode, with the phone open,

adjust the key tone volume. With

the phone closed, press and hold

[ ] to turn on the flashlight, if

activated.

In Menu mode, scroll through menu

options.

MP3

key

In Idle mode, enter the

MP3

menu.

Press and hold to launch the MP3

player.

Layout

The display has three areas.

Icons

Received signal strength

Roaming

Call in progress

Text and graphics

display messages,

instructions, and

information you enter.

Soft key function

indicators

show the current

functions assigned to

the soft keys.

Icons

display various icon.

Menu Find

Get started

Out of your service area or

Airplane mode; you cannot

make or receive calls

Restriction on



p. 102

SOS message feature active



p. 68

Lock mode



p. 100

Bluetooth active



p. 98

New message

New voicemail

Urgent message

Alarm set



p. 88

Ringer type setting



p. 69

• : Ringer only

•: Silent

•: 1 Beep

•: Vibration

•: Vib. & ringer

• : Vib. then ringer

• : Ringer then vib.

Silent mode



p. 15

Answering machine feature

active



p. 93

Battery power level

Get started

Access menu functions

Use the

soft keys

The roles of the soft keys vary

depending on the function you

have selected. The bottom line of

the display indicates their current

role.

Press the left soft

key to access

Menu mode.

Press the right

soft key to access

Find

in the

Contacts

menu.

Select an

option

1. Press a desired soft key.

2. Press the Navigation keys to

move to the next or previous

option.

3. Press <

Select

>, <

>, or

Save

> to confirm the

function displayed or option

highlighted.

4. To exit, choose either of the

following methods:

•Press [ ] to move up one

level.

• Press [ ] to return to Idle

mode.

Get started

Customise your phone

Use

shortcuts

Press the number key

corresponding to the option you

want.

Use My

You can set up a menu of your

own using your favourite menu

items, which can then be

accessed by specific number

keys.



p. 26

1. In Idle mode, press

> and select

Settings

→

Language

setup

2. Select a language.

Display

language

1. In Idle mode, press

> and select

Sounds

→

Ringer

2. Press [Down] and press

[Left] or [Right] to select a

ringtone category.

3. Press [Up] or [Down] to

scroll to a ringtone.

4. Press <

Play

> to listen to

the selected ringtone.

5. When you find the melody

you want, press <

Save

Call ringer

melody

Get started

You can set wallpaper for the

idle screen.

1. In Idle mode, press

> and select

Display

→

Wallpaper

2. Select an image or video

category.

3. Select an image or video

clip.

You can switch the phone to

Silent mode to avoid disturbing

other people.

Press and hold [ ] in Idle

mode.

Idle mode

wallpaper

Silent mode

You can protect the phone

against unauthorised use with

a phone password.

1. In Idle mode, press

> and select

Settings

→

Security

2. Enter the default password,

0000

, and press <

3. Select

Change password

4. Enter a new 4-digit

password and press <

5. Enter the new password

again and press <

6. Select

Lock mode

7. Select

Once

Phone lock

Get started

Make/Answer calls

1. Enter an area code and

phone number.

2. Press [ ].

3. To end the call, press

[].

1. When the phone rings,

press [ ].

2. To end the call, press [ ].

Make a call

Answer

a call

Press [ / ].

Adjust the

volume

during a call

Step outside the phone

Begin with your camera, the MP3 player, the WAP

browser, and other special features

Use the camera

1. Open the phone.

2. In Idle mode, press and

hold [ ] to turn on the

camera.

3. Press [

] and then [

], to

select a camera mode.

4. Aim the lens at the subject

and make any desired

adjustments.

Take a photo

5. Press <

Capture

> or

[ ] to take a photo.

6. Press <

Save

The phone returns to

Capture mode

automatically.

1. In Idle mode, press [ ]

and select

My album

→

Gallery

2. Select a photo.

1. In Idle mode, press and

hold [ ] to turn on the

camera.

2. Press [

] and then [

], to

select the icon.

View a photo

Record a

video

Step outside the phone

Play music

3. Press < > or [ ] to

start recording.

4. Press < > or [ ] to

stop recording.

5. Press <

Save

The phone returns to

Camcorder mode

automatically.

1. In Idle mode, press [ ]

and select

My album

→

Gallery

2. Select a video clip ( ).

3. Press <

Play

Record a

video

(continued)

Play a video

Use these methods:

• Download from the wireless

web



p. 80

• Copy directly from a

computer



p. 89

1. In Idle mode, press [

MP3

]

and

MP3 files

2. Press <

Options

> and

select

Add to play list

3. Press <

Check

> to select

the files you want.

4. Press <

Add

5. Press <

Play

> to begin

playback.

Save MP3

files to the

phone

Create the

play list

Step outside the phone

Use melody composer

1. In Idle mode, press and

hold [

MP3

2. Press [ ].

3. During playback, use the

following keys:

• [ ]: pauses or resumes

playback.

• [ ]: moves to the

previous file or the

beginning of the file.

Moves backward in a file

when held down.

• [ ]: skips to the next

file. Moves forward in a

file when held down.

• [ ]: repeats the section

of the lyrics.

•<

Options

>: opens the

option list.

Play music

•<

List

>: opens the play

list.

• [ / ]: adjusts the

volume.

•<

A-B

>: sets a section in

a file to play the section

repeatedly.

1. In Idle mode, press

and select

→

Melody

composer

→

Compose

melody

2. Move the selection point up

or down.

Create a

melody

Step outside the phone

Browse the WAP

Using a built-in WAP browser, you can get easy

access to the wireless web to receive a variety

of up-to-the-minute information and services,

and to enjoy downloads of web content.

3. Press <

Input

4. Select a note or rest.

5. Repeat steps 2 to 4 to add

more notes and rests.

6. Press <

Save

7. Enter a melody name and

press <

Save

1. In Idle mode, press

and select

→

Melody

composer

→

melodies

2. Scroll to the melody you

want and press <

Play

3. To stop the melody, press

Stop

Create a

melody

(continued)

Play a

melody

In Idle mode, press <

and select

do mOre

→

Mobile

browser

• To scroll through browser

items, press the Navigation

keys.

• To select an item, press

<>.

• To return to the previous

page, press [ ].

• To return to the homepage,

press and hold [ ].

Launch the

browser

Navigate

the web

Step outside the phone

Use Contacts

To the phone’s memory:

1. In Idle mode, enter a

phone number and press

Save

2. Select

New entry

3. Press <

Edit

4. Enter a name and press

5. Press [Left] or [Right] to

select

Phone

6. Select a number type.

7. Specify contact

information: Mobile, Home,

Office, Pager, Fax, Image,

E-mail1, E-mail2, URL,

Group, Ringer, and Etc.

Add a

contact

8. Press

Save

to save the

contact.

To the UIM card:

1. In Idle mode, enter a phone

number and press <

Save

2. Select

New entry

3. Press <

Edit

4. Enter a name and press

5. Press <

Save

> to save the

contact.

1. In Idle mode, press

Find

2. Enter the first few letters of

the name you want.

3. Select a contact.

Find a

contact

Step outside the phone

Send messages

4. Press <

Select

5. Scroll to a number and

press [ ] to dial, or press

Edit

> to edit contact

information.

1. In Idle mode, press

> and select

Contacts

→

Name card

→

My Name Card.vcf

2. Press <

Options

> and

select

Edit

3. Specify your contact

information.

4. Press <

Save

> to save the

name card.

Find a

contact

(continued)

Create and

send a name

card

5. To send the name card,

press <

Send

> and select

SMS

1. In Idle mode, press [Right]

and select

Text message

→

New message

2. Enter the message text and

press <

3. Press

4. Enter destination numbers.

5. Press <

Send

> to send the

message.

Send a text

message

Step outside the phone

View messages

1. In Idle mode, press [Right]

and select

Multimedia

message

→

New

Message

2. Enter a destination phone

number and address and

press <

3. Select

Add Pic/Video

→

Add Image

Add Video

4. Add an image or a video

clip.

5. Select

Add Sound

and add

a sound clip or a voice

memo.

6. Select

Add Message

7. Enter the message text and

press <

Save

8. Select

Add Subject

Send a

multimedia

message

9. Enter the message subject

and press <

Save

10.Press <

Send

> to send the

message.

When a notification appears:

Press <

Select

>. The message

displays.

From the Inbox:

1. In Idle mode, press

> and select

Message

→

Text message

→

Inbox

→

a memory

location.

2. Select a message.

View a text

message

Step outside the phone

Send SOS messages

When a notification appears:

Press <

Select

>. The message

displays.

From the Inbox:

1. In Idle mode, press

> and select

Message

→

Multimedia

message

→

Inbox

→

memory location.

2. Select a message.

View a

multimedia

message

1. In Idle mode, press [Right]

and select

Text message

→

SOS message

2. Select

to activate the

SOS message feature.

3. Move to the

Recipients

line

and press

Add

4. Enter the phone numbers to

which you want to send

SOS messages and press

Save

5. When you have finished,

press <

Save

The phone sends the

notification to the

registered numbers.

Set up the

SOS

message

options

Step outside the phone

Use Bluetooth

Your phone is equipped with Bluetooth

technology which enables you to connect the

phone wirelessly to a Bluetooth headset or

hands-free car kit.

In Idle mode, with the phone

closed, press [ / ] 4 times.

The phone sends the message.

1. In Idle mode, press

> and select

Utilities

→

Bluetooth

→

Activation

→

2. Select

Visibility

→

allow other devices to find

your phone.

Send an SOS

message

Turn on

Bluetooth

1. In Idle mode, press

> and select

Utilities

→

Bluetooth

→

My Devices

2. Press <

3. Scroll to a device and press

Add

4. Enter a Bluetooth PIN or the

other device’s Bluetooth

PIN, if it has one, and press

When the owner of the

other device enters the

same code, paring is

complete.

Search for

and connect

to a

Bluetooth

device

Step outside the phone

Use My Menu

5. Scroll to the device you

want and press

Connect

Your phone enables an

Internet connection when the

phone is connected to a

computer via Bluetooth

dongle.

Search for

and connect

to a

Bluetooth

device

(continued)

1. In Idle mode, press [Up].

2. Scroll to a key to be used as

a shortcut.

3. Press <

Options

> and

select

Assign

4. Scroll to the menu item you

want and press <

Assign

5. Scroll to an icon for the item

and press <

Save

1. In Idle mode, press [Up].

2. Press the appropriate

number key.

Set up My

Menu item

access

Access My

Menu item

Enter text

T9 English, T9 Hindi, ABC, Hindi, 123, Symbol

modes

You can enter text for some features such as

Messages, Contacts, or Calendar, usingT9

English mode, T9 Hindi mode, ABC mode, Hindi

mode, 123 mode, and Symbol mode.

Changing the text input mode

1. In the text entry screen, press <

Mode

2. Select the mode you want.

Example

: Writing a text message

Using T9 English mode

T9 is a predictive text input mode that allows

you to key in any character using single

keystrokes.

Entering a word in T9 English mode

1. Press [

] to [

]

to start entering a word.

Press each key once for each letter.

Example

: Press [

], [

], and [

]

to enter Hello.

Text i n put

mode indicator

ons

ext

Enter text

T9 predicts the word that you are typing,

and it may change with each key that you

press.

2. Enter the whole word before editing or

deleting the characters.

3. When the word displays correctly, go to step

4. Otherwise, press [

] to display alternative

word choices for the keys that you have

pressed.

For example, Of and Me use [

] and [

4. Press [ ] to insert a space and enter the

next word.

Other T9 English mode operations

• Press [

] to enter periods or apostrophes

automatically.

• Press [ ] to change case. Initial capital

(

Eng

), Lower case (

eng

), and Capital

lock (

ENG

) are available.

• Press the Navigation keys to move the

cursor.

• Press [ ] to delete characters one by one.

Press and hold [ ] to clear the characters

on the left side of the cursor.

Adding words to the T9 dictionary

1. Enter the word that you want to add.

2. Press [

] to display alternative words for

your key presses. When there are no more

alternative words,

Add word

appears on the

bottom line.

3. Press <

Add word

4. Enter the word you want using ABC mode

and press <

Save

Enter text

Using ABC mode

Press the appropriate key until the character

you want appears on the screen.

Other ABC mode operations

• To enter the same letter twice or to enter a

different letter on the same key, wait for the

cursor to move to the right automatically, or

press [Right]. Then, enter the next letter.

• Press [ ] to insert a space.

• Press [ ] to change case. Initial capital

(

Abc

), Lower case (

abc

), and Capital

lock (

ABC

) are available.

• Press the Navigation keys to move the

cursor.

• Press [ ] to delete characters one by one.

Press and hold [ ] to clear the characters

on the left side of the cursor.

Using 123 mode

123 mode enables you to enter numbers. Press

the keys corresponding to the digits you want.

Characters in order displayed

Key Upper case Lower case

Using Symbol mode

Symbol mode enables you to enter symbols.

1. Press [Up] or [Down] to display more symbol

sets.

2. Press the key corresponding to the symbol

you want.

Using Hindi mode

You can use Hindi mode by pressing <

Mode

in the text input mode and select a Hindi input

mode.

Call functions

Advanced calling features

Making a call

1. In Idle mode, enter the area code and phone

number.

2. Press [ ].

The phone locks the keypad to avoid

accidental key presses during a call. To use a

key, first unlock the keypad by pressing

[

MP3

3. When you want to end the call, press [ ] or

close the phone.

• Press [ ] to clear the last digit or press

and hold [ ] to clear the whole display.

• Press <

Options

> and select

Pause

enter a pause between numbers.

Call functions

Redialling recent numbers

1. In Idle mode, press [ ] to display the list of

recent numbers.

2. Scroll to the number you want and press

[].

Making an international call

1. In Idle mode, press and hold [

The + character appears.



p. 105

2. Enter the area code and phone number and

press [ ].

Making a call from Contacts

Once you have stored a number in Contacts,

you can dial the number by selecting it from

Contacts.



p. 36

You can also use the speed dialling feature to

assign number keys to your most frequently

dialled numbers.



p. 40

Answering a call

When you receive an incoming call, the phone

rings and displays the incoming call image.

Press [ ] to answer the call.

Tips for answering a call

• You can change the method for answering a

call in the

Call receive

menu.



p. 104

•Press <

Reject

> or [ ], or press and hold

[ / ] to reject a call.

•Press <

Silent

> or [ / ] to mute the ringer.

Viewing missed calls

If you have missed calls, the screen displays

the number of the calls and the phone number

of the last call.

Press [ ] to dial the displayed number.

Call functions

Using the headset

Use the headset to make or answer calls

without holding the phone.

Connect the headset to the jack on the right

side of the phone. The button on the headset

works as follows:

Options during a call

You can access a number of functions during a

call.

Adjusting the volume during a call

Use [ / ] to adjust the earpiece volume during

a call.

Press [ ] to increase the volume level and [ ]

to decrease the volume level.

Answering a second call

If you have activated the call waiting feature,

you can answer another call during a call.

1. Press [ ] to answer a second call. The first

caller is placed on hold and you are

connected with the second caller.

2. Press [ ] again to switch between the calls.

Making a three-way call

If you have subscribed the three-way calling

service, you can have a conversation with two

people simultaneously.

To Press

redial the last call and hold the button

twice.

answer a call and hold the button.

end a call and hold the button.

Call functions

1. During a call, press [ ] and make another

call. The first caller is placed on hold.

2. Press [ ] to begin the three-way call.

Recording your call conversation

You can record your conversation during a call.

Press and hold [ ] to start recording.



p. 92

Using In-call options

During a call, press <

Options

> to access the

following options:

•

Voice mute

: switch off your phone’s

microphone, so that the other person cannot

hear you.

•

Key mute

: mute key tones that the keypad

generates each time you press a key.

•

Voice memo

: record your call conversation

during a call.



p. 92

•

Noise cancellation

: activate the noise

cancellation feature, which removes noise

from your surroundings so that the other

person on the phone can hear you more

clearly. You can also press [Up].

•

Calls

: access the

Calls

menu.



p. 34

•

Contacts

access the

Contacts

menu.



p. 36

•

Message

: access the

Message

menu.



p. 59

•

Utilities

: access the

Utilities

menu.



p. 83

•

DTMF length

: manipulate the audible DTMF

tones.

•

Voice privacy

: encrypt the voice channel so

that people cannot eavesdrop on your

conversation.

Menu functions

All menu options listed

Calls

(Menu 1)

Use the

Calls

menu to access call logs, view the

duration of calls, and set options for call

functions.

To access this menu, press <

> in Idle

mode and select

Calls

Missed

(Menu 1.1)

This menu displays the most recent calls you

did not answer.

Incoming

(Menu 1.2)

This menu displays the most recent calls you

have received.

Outgoing

(Menu 1.3)

This menu displays the most recent calls you

have dialled.

Rejected

(Menu 1.4)

This menu displays the most recent calls you

have rejected. Calls rejected by the

Call reject

setting are also recorded in this menu.

Air time

(Menu 1.5)

This menu displays the time log for calls you

have made or received. Actual time invoiced by

your service provider will vary.

International

(Menu 1.6)

Use this menu to find and retrieve country

codes to quickly and easily dial phone numbers.

This feature is not intended to be used for

billing purposes.

Menu functions

Contacts

(Menu 2)

Call reject

(Menu 1.7)

Use this menu to make a list of numbers and

groups from which you want to reject calls, and

set how to reject those calls.

To access this menu, you must enter the 4-digit

password and press <

>. It is preset to

0000

at the factory.

Contacts

(Menu 2)

You can store phone numbers and their

corresponding names in your card and the

phone’s memory. The card and phone’s

memory, although physically separate, are used

as if they were a single entity, called Contacts.

To access this menu, press <

> in Idle

mode and select

Contacts

Find

(Menu 2.1)

Use this menu to find a contact using a person’s

name, group name, memory location, or speed

dial location number.

Add

(Menu 2.2)

Use this menu to add a new contact to

Contacts.

In the phone’s memory, a name can contain up

to 5 numbers in different categories: Mobile,

Home, Office, Pager, and Fax. You can save only

a single number with a name on the UIM card.

Group settings

(Menu 2.3)

Use this menu to set up a caller group list.

You can quickly access this menu by pressing

Find

> in Idle mode.

Menu functions

Speed dial

(Menu 2.4)

Once you have stored phone numbers in

Contacts, you can set up to 99 speed dial

entries and then dial them easily by pressing

the associated one or two number keys.

Name card

(Menu 2.5)

Use this menu to create your name card and

send it to other people.

You can also send a

Contacts entry in name card format.

My phone #

(Menu 2.6)

Use this menu to view and change your phone

number.

Press <

Edit

> and enter your phone number.

Memory info

(Menu 2.7)

Use this menu to check the number of contacts

you have stored in the phone’s memory and on

the UIM card.

Multimedia

(Menu 3)

Using the camera module built into your phone,

you can take photos of people or events while

on the move. You can also record videos by

using your phone as a camcorder.

In the

Multimedia

menu, you can take photos,

record videos, and access your photos and

video clips.

To access this menu, press <

> in Idle

mode and select

Multimedia

, or press [ ]

in Idle mode.

Menu functions

Multimedia

(Menu 3)

Take photo

(Menu 3.1)

Use this menu to take a single photo or a series

of photos, or record a video. The camera

produces JPEG photos and MP4 video clips.

My album

(Menu 3.2)

Use this menu to review the photos you have

taken and the videos you have recorded.

Photo studio

(Menu 3.3)

Photo studio is a great tool for managing

photos. Use this menu to edit photos by

applying special effects and adding comments.

Settings

(Menu 3.4)

Use this menu to change the default camera

settings.

• Do not take photos of people without their

permission.

• Do not take photos in a place where cameras

are not allowed.

• Do not take photos in a place where you may

interfere with another person’s privacy.

When you take a photo in direct sunlight or in

bright conditions, shadows may appear on the

photo.

Photos and videos captured on other devices,

such as digital cameras, may not display

correctly.

Menu functions

Display

(Menu 4)

The

Display

menu enables you to change

various settings for the display and light.

To access this menu, press <

> in Idle

mode and select

Display

Wallpaper

(Menu 4.1)

Use this menu to change the background image

to be displayed in Idle mode.

Banner

(Menu 4.2)

Use this menu to set a banner message to be

displayed at the bottom of the display in Idle

mode.

Functional screen

(Menu 4.3)

Use this menu to select a function screen, such

as calendar memo, today, memo pad, or

panchang, to be displayed in Idle mode.

Menu type

(Menu 4.4)

Use this menu to select the menu display style.

Power on/off

(Menu 4.5)

Use this menu to select the image that the

phone displays when it is switched on or off.

A function screen cannot be used with video

wallpaper.

Menu functions

Display

(Menu 4)

Dialing effect

(Menu 4.6)

Use this menu to select a font style for digits to

be displayed when you enter a phone number

for dialling.

Time setting

(Menu 4.7)

Use this menu to set the current time and date

or set up the time zones for the Dual Clock

wallpaper.

Backlight

(Menu 4.8)

Use this menu to customise settings for

backlight.

Lighting

(Menu 4.9)

Use this menu to activate or deactivate the

flashlight function. When the function is

activated, you can use the phone as a

flashlight.

To turn on the flashlight:

Menu functions

Message

(Menu 5)

Use the

Message

menu to send or receive text

messages. You can also use the voicemail and

web alert features.

To access this menu, press <

> in Idle

mode and select

Message

, or press [Right].

Multimedia message

(Menu 5.1)

Multimedia Message Service (MMS) delivers

messages containing a combination of text,

image, video, and audio, from phone to phone

or from phone to e-mail.

Text message

(Menu 5.2)

Short Message Service (SMS) allows you to

send text messages.

Sounds

(Menu 6)

The

Sounds

menu allows you to customise

various sound settings.

To access this menu, press <

> in Idle

mode and select

Sounds

Ringer

(Menu 6.1)

Use this menu to set the ringer for voice calls,

messages, alarms, and schedule alarms

separately.

Ringer vol./Type

(Menu 6.2)

Use this menu to adjust the ringer volume for

voice calls, messages, alarms, scheduler

alarms, and function alerts. You can also set the

ringer type for voice calls.

Even if the phone is in Silent mode, it will sound

while you customise the sound settings.

Menu functions

do mOre

(Menu 7)

Key tone

(Menu 6.3)

Use this menu to select the type of tones that

the keypad sounds each time you press a key.

Function alert

(Menu 6.4)

Use this menu to set up audible alerts at a

specified time to inform you that certain things

have happened.

Hour alert

(Menu 6.5)

Use this menu to set phone to sound an alert

every hour on the hour.

do mOre

(Menu 7)

Using the

do mOre

menu, you can play games

or MP3 files and VOD files, launch the WAP

browser, or create own melodies.

To access this menu, press <

> in Idle

mode and select

do mOre

Games

(Menu 7.1)

You can enjoy fun games on your phone.

MP3

(Menu 7.2)

Use this menu to enjoy MP3 music.

You can adjust the key tone volume using

[/]

in Idle mode.

You can quickly access this menu by pressing

[

MP3

] in Idle mode and launch the MP3 player

by pressing and holding the key.

Menu functions

Melody composer

(Menu 7.3)

Melody composer is a great tool that allows you

to compose your own melodies using a variety

of musical components.

VOD

(Menu 7.4)

In the

VOD

(Video On Demand) menu, you can

download video or sound clips from the wireless

web and play them.

TATA Zone

(Menu 7.5)

Use this menu to download applications and

change the browser settings. You can also view

help information.

Mobile browser

(Menu 7.6)

Your phone comes equipped with a WAP

(Wireless Application Protocol) browser which

makes it possible for you to access the wireless

web. Using the WAP browser, you can access

up-to-date information and a wide variety of

media content, such as wallpapers, ringtones,

and music files.

SMS Services

(Menu 7.7)

This menu is available only when you use a UTK

UIM card that provides additional services. For

further details, see your UTK UIM card

instructions.

Utilities

(Menu 8)

The

Utilities

menu enables you to keep track of

your schedule and tasks, set alarms, or use

convenient features, such as a calculator, voice

tools, and countdown timer. You can also use

the Bluetooth feature and connect the phone to

a computer.

To access this menu, press <

> in Idle

mode and select

Utilities

Menu functions

Utilities

(Menu 8)

Today

(Menu 8.1)

Use this menu to view information of tasks,

countdown timer, and scheduled events for the

current day. The following icons may be shown

according to the types of items:

• Countdown timer

• Personal

• Business

• Anniversary

• Event

Calendar

(Menu 8.2)

Use this menu to view the current month, as

well as the past or future months in the

calendar format. You can be alerted by the

Calendar function before an event commences.

Task list

(Menu 8.3)

Use this menu to make a list of tasks you need

to do.

Alarm

(Menu 8.4)

Use this menu to set the alarm to sound at a

specific time.

User memory

(Menu 8.5)

Use this menu to connect the phone to a

computer, as you would use an external

memory disk, and access the file folder of your

phone’s memory.

Voice tools

(Menu 8.6)

Use this menu to record voice memos and use

the answering machine feature.

You can create a new item of the selected type

by pressing <

New



p. 85

Menu functions

Memo pad

(Menu 8.7)

Use this menu to make memos of important

things you need to remember.

Calculator

(Menu 8.8)

Use this menu to use the phone as a calculator

or converter.

Countdown

(Menu 8.9)

This menu helps you measure how long it takes

you to do something or how many days remain

until a specific event occurs. The alarm for the

timer you set will sound at 9 AM on the

specified day.

•

Erase all

: erase all timers.

Clock

(Menu 8.0)

You can use your phone as a world time clock or

stopwatch.

Menu functions

Settings

(Menu 9)

Bluetooth

(Menu 8.

)

Use this menu to connect your phone to other

compatible devices wirelessly using Bluetooth

technology.

Bluetooth technology allows free wireless

connections between all Bluetooth-compliant

devices within a range of 10 metres. Since the

devices communicate using radio waves, they

do not need to be in line of sight to each other.

Settings

(Menu 9)

Many different features of your phone can be

customised to suit your preferences.

To access the menu, press <

> in Idle

mode and select

Settings

Security

(Menu 9.1)

Use this menu to protect your phone against

unauthorised use by managing the several

access codes of your phone and the card.

To access the

Security

menu, you must enter

the 4-digit password and press <

>. It is

preset to

0000

at the factory.

Input method

(Menu 9.2)

Use this menu to select the default text input

mode.

• If there are obstacles between the phone and

the headset or hands-free car kit, the

maximum operating distance may be

reduced.

• Some devices, especially those that are not

tested or approved by SIG, may be

incompatible with your phone.

Menu functions

Language setup

(Menu 9.3)

Use this menu to change the language of the

display.

Call settings

(Menu 9.4)

Use this menu to set up various settings for

making or answering a call.

Domains preset

(Menu 9.5)

You phone has domain name extensions that

you can retrieve when composing a message.

Use this menu to change default domain name

extensions and add new domain name

extensions, if necessary.

Contents status

(Menu 9.6)

Use this menu to check the amount of memory

currently in use or memory remaining for media

content, such as applications, melodies,

images, and videos.

Solve problems

Help and personal needs

To save the time and expense of an

unnecessary service call, perform the simple

checks in this section before contacting a

service professional.

When you switch on your phone, the

following messages may appear:

“Card is empty. Insert card”

• Be sure that the card is correctly installed.

“Enter PIN”

• You are using your phone for the first time.

You must enter the PIN supplied with the

UIM card.

• The PIN check feature is enabled. Every time

the phone is switched on, the PIN has to be

entered. To disable this feature, use the

check

menu.

Solve problems

“No service,” “Network down,” or “Not

done” displays

• The network connection has been lost. You

may be in a weak signal area. Move and try

again.

• You are trying to access an option for which

you have no subscription with your service

provider. Contact the service provider for

further details.

You have entered a number but it was not

dialled

• Be sure that you have pressed [ ].

• Be sure that you have accessed the right

cellular network.

• Be sure that you have not restricted

outgoing calls.

Your correspondent cannot reach you

• Be sure that your phone is switched on.

([ ] pressed for more than one second.)

• Be sure that you have accessed the right

cellular network.

• Be sure that you have not restricted

incoming calls.

Your correspondent cannot hear you

speaking

• Be sure that you have switched off the

microphone.

• Be sure that you are holding the phone close

enough to your mouth. The microphone is

located at the bottom of the phone.

The phone starts beeping and display “Low

battery! Please recharge!”

• Your battery is insufficiently charged.

Recharge the battery.

The audio quality of the call is poor

• Check the signal strength indicator on the

display ( ). The number of bars indicates

the signal strength from strong ( ) to

weak ( ).

Health and safety information

Settings

(Menu

• Try moving the phone slightly or moving

closer to a window if you are in a building.

No number is dialled when you re-call a

Contacts entry

•Use the

Find

menu to ensure the number

has been stored correctly.

• Re-store the number, if necessary.

The battery does not charge properly or

the phone sometimes turns itself off

• Wipe the charging contacts both on the

phone and on the battery with a clean soft

cloth.

If the above guidelines do not help you to

solve the problem, take note of:

• The model and serial numbers of your phone

• Your warranty details

• A clear description of the problem

Then contact your local dealer or Samsung

after-sales service.

Health and safety information

Exposure to Radio Frequency (RF)

Signals

Certification Information (SAR)

Your wireless phone is a radio transmitter and

receiver. It is designed and manufactured not to

exceed the exposure limits for radio frequency

(RF) energy set by the Federal Communications

Commission (FCC) of the U.S. government.

These FCC exposure limits are derived from the

recommendations of two expert organizations,

the National Counsel on Radiation Protection

and Measurement (NCRP) and the Institute of

Electrical and Electronics Engineers (IEEE). In

both cases, the recommendations were

developed by scientific and engineering experts

drawn from industry, government, and

academia after extensive reviews of the

Health and safety information

scientific literature related to the biological

effects of RF energy.

The exposure limit set by the FCC for wireless

mobile phones employs a unit of measurement

known as the Specific Absorption Rate (SAR).

The SAR is a measure of the rate of absorption

of RF energy by the human body expressed in

units of watts per kilogram (W/kg). The FCC

requires wireless phones to comply with a

safety limit of 1.6 watts per kilogram (1.6 W/

kg). The FCC exposure limit incorporates a

substantial margin of safety to give additional

protection to the public and to account for any

variations in measurements.

SAR tests are conducted using standard

operating positions accepted by the FCC with

the phone transmitting at its highest certified

power level in all tested frequency bands.

Although the SAR is determined at the highest

certified power level, the actual SAR level of the

phone while operating can be well below the

maximum value. This is because the phone is

designed to operate at multiple power levels so

as to use only the power required to reach the

network. In general, the closer you are to a

wireless base station antenna, the lower the

power output.

When approval test is done, no Samsung

supplied accessories are avialable but maybe

available later after approval.

Before a new model phone is available for sale

to the public, it must be tested and certified to

the FCC that it does not exceed the exposure

limit established by the FCC. Tests for each

model phone are performed in positions and

locations (e.g. at the ear and worn on the body)

as required by the FCC.

The highest SAR values for this model phone as

reported to the FCC are Head: 0.650W/Kg,

Bodyworn: 1.11W/Kg.

For body worn operation, this model phone has

been tested and meets the FCC RF exposure

Health and safety information

Settings

(Menu

guidelines whenused with a Samsung accessory

designated for this product or when used with

an accessory that contains no metal and that

positions the handset a minimum of 1.5 cm

from the body.

Non-compliance with the above restrictions

may result in violation of FCC RF exposure

guidelines.

SAR information on this and other model

phones can be viewed on-line at www.fcc.gov/

oet/fccid. This site uses the phone FCC ID

number, A3LSCHS129. Sometimes it may be

necessary to remove the battery pack to find

the number. Once you have the FCC ID number

for a particular phone, follow the instructions on

the website and it should provide values for

typical or maximum SAR for a particular phone.

Additional product specific SAR information can

also be obtained at www.fcc.gov/cgb/sar.

Consumer Information on Wireless

Phones

The U.S. Food and Drug Administration (FDA)

has published a series of Questions and

Answers for consumers relating to radio

frequency (RF) exposure from wireless phones.

The FDA publication includes the following

information:

What kinds of phones are the subject of

this update?

The term wireless phone refers here to hand-

held wireless phones with built-in antennas,

often called “cell,” “mobile,” or “PCS” phones.

These types of wireless phones can expose the

user to measurable radio frequency energy (RF)

because of the short distance between the

phone and the user's head. These RF exposures

are limited by Federal Communications

Commission safety guidelines that were

Health and safety information

developed with the advice of FDA and other

federal health and safety agencies. When the

phone is located at greater distances from the

user, the exposure to RF is drastically lower

because a person's RF exposure decreases

rapidly with increasing distance from the

source. The so-called “cordless phones,” which

have a base unit connected to the telephone

wiring in a house, typically operate at far lower

power levels, and thus produce RF exposures

well within the FCC's compliance limits.

Do wireless phones pose a health

hazard?

The available scientific evidence does not show

that any health problems are associated with

using wireless phones. There is no proof,

however, that wireless phones are absolutely

safe. Wireless phones emit low levels of radio

frequency energy (RF) in the microwave range

while being used. They also emit very low levels

of RF when in the stand-by mode. Whereas high

levels of RF can produce health effects (by

heating tissue), exposure to low level RF that

does not produce heating effects causes no

known adverse health effects. Many studies of

low level RF exposures have not found any

biological effects. Some studies have suggested

that some biological effects may occur, but such

findings have not been confirmed by additional

research. In some cases, other researchers

have had difficulty in reproducing those studies,

or in determining the reasons for inconsistent

results.

What is FDA's role concerning the

safety of wireless phones?

Under the law, FDA does not review the safety

of radiation-emitting consumer products such

as wireless phones before they can be sold, as

it does with new drugs or medical devices.

However, the agency has authority to take

Health and safety information

Settings

(Menu

action if wireless phones are shown to emit

radio frequency energy (RF) at a level that is

hazardous to the user. In such a case, FDA

could require the manufacturers of wireless

phones to notify users of the health hazard and

to repair, replace or recall the phones so that

the hazard no longer exists.

Although the existing scientific data do not

justify FDA regulatory actions, FDA has urged

the wireless phone industry to take a number of

steps, including the following:

• “Support needed research into possible

biological effects of RF of the type emitted by

wireless phones;

• “Design wireless phones in a way that

minimizes any RF exposure to the user that

is not necessary for device function; and

• “Cooperate in providing users of wireless

phones with the best possible information on

possible effects of wireless phone use on

human health.

FDA belongs to an interagency working group of

the federal agencies that have responsibility for

different aspects of RF safety to ensure

coordinated efforts at the federal level. The

following agencies belong to this working

group:

• “National Institute for Occupational Safety

and Health

• “Environmental Protection Agency

• “Federal Communications Commission

• “Occupational Safety and Health

Administration

• “National Telecommunications and

Information Administration

The National Institutes of Health participates in

some interagency working group activities, as

well.

FDA shares regulatory responsibilities for

wireless phones with the Federal

Communications Commission (FCC). All phones

Health and safety information

that are sold in the United States must comply

with FCC safety guidelines that limit RF

exposure. FCC relies on FDA and other health

agencies for safety questions about wireless

phones.

FCC also regulates the base stations that the

wireless phone networks rely upon. While these

base stations operate at higher power than do

the wireless phones themselves, the RF

exposures that people get from these base

stations are typically thousands of times lower

than those they can get from wireless phones.

Base stations are thus not the primary subject

of the safety questions discussed in this

document.

What are the results of the research

done already?

The research done thus far has produced

conflicting results, and many studies have

suffered from flaws in their research methods.

Animal experiments investigating the effects of

radio frequency energy (RF) exposures

characteristic of wireless phones have yielded

conflicting results that often cannot be repeated

in other laboratories. A few animal studies,

however, have suggested that low levels of RF

could accelerate the development of cancer in

laboratory animals. However, many of the

studies that showed increased tumor

development used animals that had been

genetically engineered or treated with cancer-

causing chemicals so as to be pre-disposed to

develop cancer in absence of RF exposure.

Other studies exposed the animals to RF for up

to 22 hours per day. These conditions are not

similar to the conditions under which people

use wireless phones, so we don't know with

certainty what the results of such studies mean

for human health.

Three large epidemiology studies have been

published since December 2000. Between

Health and safety information

Settings

(Menu

them, the studies investigated any possible

association between the use of wireless phones

and primary brain cancer, glioma, meningioma,

or acoustic neuroma, tumors of the brain or

salivary gland, leukemia, or other cancers.

None of the studies demonstrated the existence

of any harmful health effects from wireless

phones RF exposures. However, none of the

studies can answer questions about long-term

exposures, since the average period of phone

use in these studies was around three years.

What research is needed to decide

whether RF exposure from wireless

phones poses a health risk?

A combination of laboratory studies and

epidemiological studies of people actually using

wireless phones would provide some of the data

that are needed. Lifetime animal exposure

studies could be completed in a few years.

However, very large numbers of animals would

be needed to provide reliable proof of a cancer

promoting effect if one exists. Epidemiological

studies can provide data that is directly

applicable to human populations, but ten or

more years' follow-up may be needed to

provide answers about some health effects,

such as cancer. This is because the interval

between the time of exposure to a cancer-

causing agent and the time tumors develop - if

they do - may be many, many years. The

interpretation of epidemiological studies is

hampered by difficulties in measuring actual RF

exposure during day-to-day use of wireless

phones. Many factors affect this measurement,

such as the angle at which the phone is held, or

which model of phone is used.

What is FDA doing to find out more

about the possible health effects of

wireless phone RF?

FDA is working with the U.S. National

Toxicology Program and with groups of

investigators around the world to ensure that

Health and safety information

high priority animal studies are conducted to

address important questions about the effects

of exposure to radio frequency energy (RF).

FDA has been a leading participant in the World

Health Organization international

Electromagnetic Fields (EMF) Project since its

inception in 1996. An influential result of this

work has been the development of a detailed

agenda of research needs that has driven the

establishment of new research programs

around the world. The Project has also helped

develop a series of public information

documents on EMF issues.

FDA and Cellular Telecommunications &

Internet Association (CTIA) have a formal

Cooperative Research and Development

Agreement (CRADA) to do research on wireless

phone safety. FDA provides the scientific

oversight, obtaining input from experts in

government, industry, and academic

organizations. CTIA-funded research is

conducted through contracts to independent

investigators. The initial research will include

both laboratory studies and studies of wireless

phone users. The CRADA will also include a

broad assessment of additional research needs

in the context of the latest research

developments around the world.

What steps can I take to reduce my

exposure to radio frequency energy

from my wireless phone?

If there is a risk from these products - and at

this point we do not know that there is - it is

probably very small. But if you are concerned

about avoiding even potential risks, you can

take a few simple steps to minimize your

exposure to radio frequency energy (RF). Since

time is a key factor in how much exposure a

person receives, reducing the amount of time

spent using a wireless phone will reduce RF

exposure.

Health and safety information

Settings

(Menu

• “If you must conduct extended

conversations by wireless phone every day,

you could place more distance between your

body and the source of the RF, since the

exposure level drops off dramatically with

distance. For example, you could use a

headset and carry the wireless phone away

from your body or use a wireless phone

connected to a remote antenna.

Again, the scientific data do not demonstrate

that wireless phones are harmful. But if you are

concerned about the RF exposure from these

products, you can use measures like those

described above to reduce your RF exposure

from wireless phone use.

What about children using wireless

phones?

The scientific evidence does not show a danger

to users of wireless phones, including children

and teenagers. If you want to take steps to

lower exposure to radio frequency energy (RF),

the measures described above would apply to

children and teenagers using wireless phones.

Reducing the time of wireless phone use and

increasing the distance between the user and

the RF source will reduce RF exposure.

Some groups sponsored by other national

governments have advised that children be

discouraged from using wireless phones at all.

For example, the government in the United

Kingdom distributed leaflets containing such a

recommendation in December 2000. They

noted that no evidence exists that using a

wireless phone causes brain tumors or other ill

effects. Their recommendation to limit wireless

phone use by children was strictly

precautionary; it was not based on scientific

evidence that any health hazard exists.

Do hands-free kits for wireless phones

reduce risks from exposure to RF

emissions?

Health and safety information

Since there are no known risks from exposure

to RF emissions from wireless phones, there is

no reason to believe that hands-free kits reduce

risks. Hands-free kits can be used with wireless

phones for convenience and comfort. These

systems reduce the absorption of RF energy in

the head because the phone, which is the

source of the RF emissions, will not be placed

against the head. On the other hand, if the

phone is mounted against the waist or other

part of the body during use, then that part of

the body will absorb more RF energy. Wireless

phones marketed in the U.S. are required to

meet safety requirements regardless of

whether they are used against the head or

against the body. Either configuration should

result in compliance with the safety limit.

Do wireless phone accessories that

claim to shield the head from RF

radiation work?

Since there are no known risks from exposure

to RF emissions from wireless phones, there is

no reason to believe that accessories that claim

to shield the head from those emissions reduce

risks. Some products that claim to shield the

user from RF absorption use special phone

cases, while others involve nothing more than a

metallic accessory attached to the phone.

Studies have shown that these products

generally do not work as advertised. Unlike

“hand-free” kits, these so-called “shields” may

interfere with proper operation of the phone.

The phone may be forced to boost its power to

compensate, leading to an increase in RF

absorption. In February 2002, the Federal trade

Commission (FTC) charged two companies that

sold devices that claimed to protect wireless

phone users from radiation with making false

and unsubstantiated claims. According to FTC,

these defendants lacked a reasonable basis to

substantiate their claim.

Health and safety information

Settings

(Menu

What about wireless phone interference

with medical equipment?

Radio frequency energy (RF) from wireless

phones can interact with some electronic

devices. For this reason, FDA helped develop a

detailed test method to measure

electromagnetic interference (EMI) of implanted

cardiac pacemakers and defibrillators from

wireless telephones. This test method is now

part of a standard sponsored by the Association

for the Advancement of Medical instrumentation

(AAMI). The final draft, a joint effort by FDA,

medical device manufacturers, and many other

groups, was completed in late 2000. This

standard will allow manufacturers to ensure

that cardiac pacemakers and defibrillators are

safe from wireless phone EMI. FDA has tested

wireless phones and helped develop a voluntary

standard sponsored by the Institute of Electrical

and Electronic Engineers (IEEE). This standard

specifies test methods and performance

requirements for hearing aids and wireless

phones so that no interference occurs when a

person uses a compatible phone and a

compatible hearing aid at the same time. This

standard was approved by the IEEE in 2000.

FDA continues to monitor the use of wireless

phones for possible interactions with other

medical devices. Should harmful interference

be found to occur, FDA will conduct testing to

assess the interference and work to resolve the

problem.

Additional information on the safety of RF

exposures from various sources can be

obtained from the following organizations:

• FCC RF Safety Program:

http://www.fcc.gov/oet/rfsafety/

• Environmental Protection Agency (EPA):

http://www.epa.gov/radiation/

• Occupational Safety and Health

Administration's (OSHA):

Health and safety information

http://www.osha.gov/SLTC/

radiofrequencyradiation/index.html

• National institute for Occupational Safety

and Health (NIOSH):

http://www.cdc.gov/niosh/emfpg.html

• World health Organization (WHO):

http://www.who.int/peh-emf/

• International Commission on Non-Ionizing

Radiation Protection:

http://www.icnirp.de

• National Radiation Protection Board (UK):

http://www.nrpb.org.uk

• Updated 4/3/2002: US food and Drug

Administration

http://www.fda.gov/cellphones

Road Safety

Your wireless phone gives you the powerful

ability to communicate by voice, almost

anywhere, anytime. But an important

responsibility accompanies the benefits of

wireless phones, one that every user must

uphold.

When driving a car, driving is your first

responsibility. When using your wireless phone

behind the wheel of a car, practice good

common sense and remember the following

tips:

1. Get to know your wireless phone and its

features, such as speed dial and redial. If

available, these features help you to place

your call without taking your attention off

the road.

2. When available, use a hands-free device. If

possible, add an additional layer of

convenience and safety to your wireless

phone with one of the many hands free

accessories available today.

3. Position your wireless phone within easy

reach. Be able to access your wireless phone

Health and safety information

Settings

(Menu

without removing your eyes from the road. If

you get an incoming call at an inconvenient

time, let your voice mail answer it for you.

4. Let the person you are speaking with know

you are driving; if necessary, suspend the

call in heavy traffic or hazardous weather

conditions. Rain, sleet, snow, ice and even

heavy traffic can be hazardous.

5. Do not take notes or look up phone numbers

while driving. Jotting down a “to do” list or

flipping through your address book takes

attention away from your primary

responsibility, driving safely.

6. Dial sensibly and assess the traffic; if

possible, place calls when you are not

moving or before pulling into traffic. Try to

plan calls when your car will be stationary. If

you need to make a call while moving, dial

only a few numbers, check the road and your

mirrors, then continue.

7. Do not engage in stressful or emotional

conversations that may be distracting. Make

people you are talking with aware you are

driving and suspend conversations that have

the potential to divert your attention from

the road.

8. Use your wireless phone to call for help. Dial

9-1-1 or other local emergency number in

the case of fire, traffic accident or medical

emergencies. Remember, it is a free call on

your wireless phone!

9. Use your wireless phone to help others in

emergencies. If you see an auto accident,

crime in progress or other serious

emergency where lives are in danger, call 9-

1-1 or other local emergency number, as you

would want others to do for you.

10.Call roadside assistance or a special non-

emergency wireless assistance number when

necessary. If you see a broken-down vehicle

posing no serious hazard, a broken traffic

Health and safety information

signal, a minor traffic accident where no one

appears injured, or a vehicle you know to be

stolen, call roadside assistance or other

special non-emergency number.

“The wireless industry reminds you to

use your phone safely when driving.”

For more information, please call 1-888-901-

SAFE, or visit our web-site www.wow-com.com

Provided by the Cellular Telecommunications &

Internet Association

Operating Environment

Remember to follow any special regulations in

force in any area and always switch your phone

off whenever it is forbidden to use it, or when it

may cause interference or danger. When

connecting the phone or any accessory to

another device, read its user's guide for

detailed safety instructions. Do not connect

incompatible products.

As with other mobile radio transmitting

equipment, users are advised that for the

satisfactory operation of the equipment and for

the safety of personnel, it is recommended that

the equipment should only be used in the

normal operating position (held to your ear with

the antenna pointing over your shoulder).

Using Your Phone Near Other

Electronic Devices

Most modern electronic equipment is shielded

from radio frequency (RF) signals. However,

certain electronic equipment may not be

shielded against the RF signals from your

wireless phone. Consult the manufacturer to

discuss alternatives.

Pacemakers

Pacemaker manufacturers recommend that a

minimum distance of 15 cm (6 inches) be

maintained between a wireless phone and a

Health and safety information

Settings

(Menu

pacemaker to avoid potential interference with

the pacemaker.

These recommendations are consistent with the

independent research and recommendations of

Wireless Technology Research.

Persons with pacemakers:

• should always keep the phone more than 15

(6 inches) from their pacemaker when the

phone is switched on.

• should not carry the phone in a breast

pocket.

• should use the ear opposite the pacemaker

to minimize potential interference.

If you have any reason to suspect that

interference is taking place, switch your phone

off immediately.

Hearing Aids

Some digital wireless phones may interfere with

some hearing aids. In the event of such

interference, you may wish to consult your

hearing aid manufacturer to discuss

alternatives.

Other Medical Devices

If you use any other personal medical devices,

consult the manufacturer of your device to

determine if it is adequately shielded from

external RF energy. Your physician may be able

to assist you in obtaining this information.

Switch your phone off in health care facilities

when any regulations posted in these areas

instruct you to do so. Hospitals or health care

facilities may be using equipment that could be

sensitive to external RF energy.

Vehicles

RF signals may affect improperly installed or

inadequately shielded electronic systems in

Health and safety information

motor vehicles. Check with the manufacturer or

its representative regarding your vehicle. You

should also consult the manufacturer of any

equipment that has been added to your vehicle.

Posted Facilities

Switch your phone off in any facility where

posted notices require you to do so.

Potentially Explosive Environments

Switch your phone off when in any area with a

potentially explosive atmosphere and obey all

signs and instructions. Sparks in such areas

could cause an explosion or fire resulting in

bodily injury or even death.

Users are advised to switch the phone off while

at a refueling point (service station). Users are

reminded of the need to observe restrictions on

the use of radio equipment in fuel depots (fuel

storage and distribution areas), chemical plants

or where blasting operations are in progress.

Areas with a potentially explosive atmosphere

are often but not always clearly marked. They

include below deck on boats, chemical transfer

or storage facilities, vehicles using liquefied

petroleum gas (such as propane or butane),

areas where the air contains chemicals or

particles, such as grain, dust or metal powders,

and any other area where you would normally

be advised to turn off your vehicle engine.

Emergency Calls

This phone, like any wireless phone, operates

using radio signals, wireless and landline

networks as well as user programmed

functions, which cannot guarantee connection

in all conditions. Therefore, you should never

rely solely on any wireless phone for essential

Health and safety information

Settings

(Menu

communications (medical emergencies, for

example).

Remember, to make or receive any calls the

phone must be switched on and in a service

area with adequate signal strength. Emergency

calls may not be possible on all wireless phone

networks or when certain network services and/

or phone features are in use. Check with local

service providers.

To make an emergency call:

1. If the phone is not on, switch it on.

2. Key in the emergency number for your

present location (for example, 911 or other

official emergency number). Emergency

numbers vary by location.

3. Press .

If certain features are in use (call barring, for

example), you may first need to deactivate

those features before you can make an

emergency call. Consult this document and

your local cellular service provider.

When making an emergency call, remember to

give all the necessary information as accurately

as possible. Remember that your phone may be

the only means of communication at the scene

of an accident; do not cut off the call until given

permission to do so.

Restricting Children's access to your

Phone

Your phone is not a toy. Children should not be

allowed to play with it because they could hurt

themselves and others, damage the phone or

make calls that increase your phone bill.

FCC Notice and Cautions

Health and safety information

FCC Notice

• This device complies with Part 15 of the

FCC Rules. Operation is subject to the

following two conditions: (1) this device may

not cause harmful interference, and (2) this

device must accept any interference

received, including interference that may

cause undesired operation.

• This equipment has been tested and found

to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules.

These limits are designed to provide

reasonable protection against harmful

interference in a residential installation. This

equipment generates, uses and can radiate

radio frequency energy and,

• if not installed and used in

accordance with the instructions, may

cause harmful interference to radio

communications. However, there is no

guarantee that interference will not

occur in a particular installation. If this

equipment does cause harmful

interference to radio or television

reception, which can be determined

by turning the equipment off and on,

the user is encouraged to try to

correct the interference by one or

more of the following measures:

-Reorient or relocate the receiving

antenna.

-Increase the separation between the

equipment and receiver.

-Connect the equipment into an outlet

on a circuit different from that to

which the receiver is connected.

-Consult the dealer or an experienced

radio/TV technician for help.

Health and safety information

Settings

(Menu

The phone may cause TV or radio interference if

used in close proximity to receiving equipment.

The FCC can require you to stop using the

phone if such interference cannot be

eliminated.

Vehicles using liquefied petroleum gas (such as

propane or butane) must comply with the

National Fire Protection Standard (NFPA-58).

For a copy of this standard, contact the National

Fire Protection Association, One Battery march

Park, Quincy, MA 02269, Attn: Publication Sales

Division.

Cautions

Changes or modifications made in the radio

phone, not expressly approved by Samsung,

will void the user’s authority to operate the

equipment.

Only use approved batteries, antennas and

chargers. The use of any unauthorized

accessories may be dangerous and void the

phone warranty if said accessories cause

damage or a defect to the phone.

Although your phone is quite sturdy, it is a

complex piece of equipment and can be broken.

Avoid dropping, hitting, bending or sitting on it.

Other Important Safety Information

• Only qualified personnel should service the

phone or install the phone in a vehicle.

Faulty installation or service may be

dangerous and may invalidate any warranty

applicable to the device.

• Check regularly that all wireless phone

equipment in your vehicle is mounted and

operating properly.

• Do not store or carry flammable liquids,

gases or explosive materials in the same

compartment as the phone, its parts or

accessories.

• For vehicles equipped with an air bag,

remember that an air bag inflates with great

Health and safety information

force. Do not place objects, including both

installed or portable wireless equipment in

the area over the air bag or in the air bag

deployment area. If wireless equipment is

improperly installed and the air bag inflates,

serious injury could result.

• Switch your phone off before boarding an

aircraft. The use of wireless phone in aircraft

is illegal and may be dangerous to the

aircraft's operation.

• Failure to observe these instructions may

lead to the suspension or denial of telephone

services to the offender, or legal action, or

both.

Product Performance

Getting the Most Out of Your Signal

Reception

The quality of each call you make or receive

depends on the signal strength in your area.

Your phone informs you of the current signal

strength by displaying a number of bars next to

the signal strength icon. The more bars

displayed, the stronger the signal.

If you're inside a building, being near a window

may give you better reception.

Understanding the Power Save Feature

If your phone is unable to find a signal after 15

minutes of searching, a Power Save feature is

automatically activated. If your phone is active,

it periodically rechecks service availability or

you can check it yourself by pressing any key.

Anytime the Power Save feature is activated, a

message displays on the screen. When a signal

is found, your phone returns to standby mode.

Health and safety information

Settings

(Menu

Understanding How Your Phone

Operates

Your phone is basically a radio transmitter and

receiver. When it's turned on, it receives and

transmits radio frequency (RF) signals. When

you use your phone, the system handling your

call controls the power level. This power can

range from 0.006 watts to 0.2 watts in digital

mode.

Maintaining Your Phone's Peak

Performance

For the best care of your phone, only authorized

personnel should service your phone and

accessories. Faulty service may void the

warranty.

There are several simple guidelines to operating

your phone properly and maintaining safe,

satisfactory service.

• Hold the phone with the antenna raised,

fully-extended and over your shoulder.

• Try not to hold, bend or twist the phone's

antenna.

• Don't use the phone if the antenna is

damaged.

• Speak directly into the phone's receiver.

• Avoid exposing your phone and accessories

to rain or liquid spills. If your phone does get

wet, immediately turn the power off and

remove the battery. If it is inoperable, call

Customer Care for service.

Availability of Various Features/Ring

Tones

Many services and features are network

dependent and may require additional

subscription and/or usage charges. Not all

features are available for purchase or use in all

areas. Downloadable Ring Tones may be

available at an additional cost. Other conditions

Health and safety information

and restrictions may apply. See your service

provider for additional information.

Battery Standby and Talk Time

Standby and talk times will vary depending on

phone usage patterns and conditions. Battery

power consumption depends on factors such as

network configuration, signal strength,

operating temperature, features selected,

frequency of calls, and voice, data, and other

application usage patterns.

Battery Precautions

• Never use any charger or battery that is

damaged in any way.

• Use the battery only for its intended

purpose.

• If you use the phone near the network's

base station, it uses less power; talk and

standby time are greatly affected by the

signal strength on the cellular network and

the parameters set by the network operator.

• Battery charging time depends on the

remaining battery charge and the type of

battery and charger used. The battery can

be charged and discharged hundreds of

times, but it will gradually wear out. When

the operation time (talk time and standby

time) is noticeably shorter than normal, it is

time to buy a new battery.

• If left unused, a fully charged battery will

discharge itself over time.

• Use only Samsung-approved batteries and

recharge your battery only with Samsung-

approved chargers. When a charger is not in

use, disconnect it from the power source. Do

not leave the battery connected to a charger

for more than a week, since overcharging

may shorten its life.

Health and safety information

Settings

(Menu

• Extreme temperatures will affect the

charging capacity of your battery: it may

require cooling or warming first.

• Do not leave the battery in hot or cold

places, such as in a car in summer or winter

conditions, as you will reduce the capacity

and lifetime of the battery. Always try to

keep the battery at room temperature. A

phone with a hot or cold battery may

temporarily not work, even when the battery

is fully charged. Li-ion batteries are

particularly affected by temperatures below

0 °C (32 °F).

• Do not short-circuit the battery. Accidental

short- circuiting can occur when a metallic

object (coin, clip or pen) causes a direct

connection between the + and - terminals of

the battery (metal strips on the battery), for

example when you carry a spare battery in a

pocket or bag. Short-circuiting the terminals

may damage the battery or the object

causing the short-circuiting.

• Dispose of used batteries in accordance with

local regulations. In some areas, the

disposal of batteries in household or

business trash may be prohibited. For safe

disposal options for Li-Ion batteries, contact

your nearest Samsung authorized service

center. Always recycle. Do not dispose of

batteries in a fire.

Care and Maintenance

Your phone is a product of superior design and

craftsmanship and should be treated with care.

The suggestions below will help you fulfill any

warranty obligations and allow you to enjoy this

product for many years.

• Keep the phone and all its parts and

accessories out of the reach of small

children.

Health and safety information

• Keep the phone dry. Precipitation, humidity

and liquids contain minerals that will corrode

electronic circuits.

• Do not use the phone with a wet hand. Doing

so may cause an electric shock to you or

damage to the phone.

• Do not use or store the phone in dusty, dirty

areas, as its moving parts may be damaged.

• Do not store the phone in hot areas. High

temperatures can shorten the life of

electronic devices, damage batteries, and

warp or melt certain plastics.

• Do not store the phone in cold areas. When

the phone warms up to its normal operating

temperature, moisture can form inside the

phone, which may damage the phone's

electronic circuit boards.

• Do not drop, knock or shake the phone.

Rough handling can break internal circuit

boards.

• Do not use harsh chemicals, cleaning

solvents or strong detergents to clean the

phone. Wipe it with a soft cloth slightly

dampened in a mild soap-and-water

solution.

• Do not paint the phone. Paint can clog the

device's moving parts and prevent proper

operation.

• Do not put the phone in or on heating

devices, such as a microwave oven, a stove

or a radiator. The phone may explode when

overheated.

• When the phone or battery gets wet, the

label indicating water damage inside the

phone changes color. In this case, phone

repairs are no longer guaranteed by the

manufacturer's warranty, even if the

warranty for your phone has not expired.

• If your phone has a flash or light, do not use

it too close to the eyes of people or animals.

This may cause damage to their eyes.

Health and safety information

Settings

(Menu

• Use only the supplied or an approved

replacement antenna. Unauthorized

antennas or modified accessories may

damage the phone and violate regulations

governing radio devices.

• If the phone, battery, charger or any

accessory is not working properly, take it to

your nearest qualified service facility. The

personnel there will assist you, and if

necessary, arrange for service.

Licensed by QUALCOMM incorporated under one or

more of the following Patents.

U.S Patent No. 4,901,307 5,056,109 5,099,204

5,101,501 5,103,459

5,107,225 5,109,390

Samsung Electronics Co SCHF519 Single-Band CDMA Phone with Bluetooth User Manual

Samsung Electronics Co Ltd Single-Band CDMA Phone with Bluetooth Users Manual

Users Manual

Navigation menu

Namespaces

Views

Navigation
