Users Manual
SCH-L160
User’s Guide
Draft23-May-06
Use road safety at all times
Do not use a hand-held phone while driving. Park the
vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using them
in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or illegal.
1
Important safety precautions
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is forbidden
to use it, or when it may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear). Avoid
unnecessary contact with the antenna when the phone
is switched on.
Emergency call
Key in the emergency number for your present
location, then press .
Keep your phone away from small children
Keep the phone and all its parts, including accessories,
out of the reach of small children.
Accessories and batteries
Use only Samsung-approved batteries and
accessories, such as headsets and PC data cables. Use
of any unauthorised accessories could damage you or
your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health and
safety information" on page 45.
• The phone could explode if the battery is replaced with
an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.
At very high volumes, prolonged listening to a
headset can damage your hearing.
2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone. To quickly
learn the basics for your phone, please refer to “Get
started” and “Step outside the phone.”
In this guide, the following instruction icons appear:
Indicates that you need to pay careful attention
to the subsequent information regarding safety
or phone features.
Indicates that you can get more information on
the referenced page.
→
Indicates that you need to press the Navigation
keys to scroll to the specified option and then
select it.
[ ]
Indicates a key on the phone. For example, [ ]
< >
Indicates a soft key, whose function is displayed
on the phone screen. For example, <
Menu
>
• Simple, sleek design with Intenna
Samsung’s powerful intenna technology allows
the best call quality without an annoying external
antenna.
Special
features of your phone
•Countdown
Use your phone as a countdown
timer for an important event.
3
Special features of your phone
•Calendar
Keep track of your daily, weekly,
and monthly schedule.
•Contacts
Store up home, office, or cellular
phone numbers for your contacts.
•Alarm
Use your phone as an alarm clock
to wake you up in the morning or
notify you of an event.
•Calculator
Perform basic calculations and do
currency conversions.
•SOS message
Send SOS messages to your family or friends for
help in an emergency.
• Short Message Service (SMS)
Chat and share interest with your friends, family,
or co-workers by SMS messages.
4
Contents
Unpack 3
Make sure you have each item
Your phone 3
Keys, features, and locations
Get started 4
First steps to operate your phone
Install and charge the phone ..................................... 4
Power on or off........................................................ 5
Keys and display ..................................................... 6
Access menu functions ............................................. 8
Customize your phone.............................................. 9
Make/answer calls .................................................. 11
Step outside the phone 11
Begin with your Contacts, Messages, Calendar, and Alarm
Use Contacts.......................................................... 11
Send messages ...................................................... 12
View messages....................................................... 12
Manage schedule.................................................... 13
Use the alarm clock ................................................ 14
Enter text 17
Call functions 19
Menu functions 22
Health and safety information 45
5
1 Calls
p. 24
1 Outgoing
2 Incoming
3 Missed
4 Erase History
5 Air Time
p. 24
p. 25
p. 25
p. 25
p. 25
2 Downloads
p. 26
3 Torpedo SMS
p. 27
1 New Message
2 Voice Mail
3 Inbox
4 Outbox
5 Drafts
6 Saved
7 Erase Msg
8 Setting
p. 27
p. 28
p. 28
p. 29
p. 29
p. 30
p. 30
p. 30
4 Tones/Images
p. 32
1 Display
2 Sounds
p. 32
p. 33
5 Meu Vivo
p. 35
1 Launch Pad
2 Ringer Type
3 Menu Style
4 Banner
5 Wallpaper
6 Orig. Settings
7 Msg Setting
8 Auto CSP
p. 35
p. 35
p. 35
p. 35
p. 35
p. 35
p. 35
p. 35
6 Voice Mail
p. 36
7 Voice Portal
p. 36
8 Planner
p. 36
1 Today
2 Calendar
3 Task List
4 Memo Pad
5 Alarm
6 Calculator
7 World Time
8 Count Down
9 Set Time
p. 36
p. 36
p. 38
p. 38
p. 39
p. 39
p. 40
p. 40
p. 40
9 Settings
p. 41
1 Auto CSP
2 Auto Answer
3 Call Answer
4 Auto Retry
5 Idioma/Language
6 System
7 Help
8 Security
p. 41
p. 41
p. 41
p. 41
p. 42
p. 42
p. 43
p. 43
Overview of menu functions
To access Menu mode, press <
Menu
> in Idle mode.
6
Unpack
Make sure you have each item
You can obtain various accessories from
your local Samsung dealer.
Phone Travel Adapter
Battery User’s Guide
The items supplied with your phone and the
accessories available at your Samsung
dealer may vary, depending on your country
or service provider.
Your phone
Keys, features, and locations
Headset jack
Dial key
Special function keys
Display
Power on/off/
Menu exit key
Alphanumeric keys
Service light
Microphone
Navigation keys
(Up/Down/ Left/Right)
Web access/
Confirm key
Cancel/Correct key
Volume keys
Earpiece
Left soft key Right soft key
7
Get started
First steps to operate your phone
UIM card information
UIM card informationWhen you subscribe to a cellular
network, you receive a plug-in UIM (User Identification
Module) card loaded with your subscription details,
such as your PIN, and available optional services.
Install and charge the phone
Remove the battery
cover.
If the phone is already
on, first turn it off by
pressing and holding
[].
Insert the UIM card.
Make sure that the gold-
coloured contacts on the
card are face down.
Install the battery. Reattach the battery
cover.
Plug the travel adapter into the phone.
Plug the adapter into a standard AC wall outlet.
8
Get started
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the battery low message displays, and
• the empty battery icon blinks.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
Power on or off
When the phone is completely charged (the
battery icon becomes still), unplug the adapter
from the wall outlet.
Remove the adapter from the phone.
Switch on
Do not turn on
the phone when
mobile phone
use is prohibited.
1. Open the phone.
2. Press and hold [ ].
3. If necessary, enter the PIN and
press [
OK
].
Switch off
1. Open the phone.
2. Press and hold [ ].
9
Get started
Keys and display
Keys
Perform the function indicated on the
bottom line of the display.
In Idle mode, access your favorite
menus directly.
p. 32
In Menu mode, scroll through the menu
options.
In Menu mode, select the highlighted
menu option or confirm input.
Delete characters from the display.
In Menu mode, return the display to
the previous menu level.
Make or answer a call.
In Idle mode, retrieve numbers recently
dialled, missed, or received.
Press and hold to switch the phone on
and off.
End a call.
In Menu mode, cancel input and return
the phone to Idle mode.
Enter numbers, letters, and some
special characters.
Enter special characters.
Press and hold [ ] to activate or
deactivate Silent mode.
10
Get started
Display
Layout
Icons
*
Received signal strength
Call in progress
Out of your service area; you
cannot send or receive calls
SOS message feature active
p.xx
Auto answer mode
p.41
New text message
Text and graphics
display messages,
instructions, and
information you enter.
Soft key function indicators
show the current functions
assigned to the soft keys.
Icons
display various icons.
Menu Contacts
New voice mail
Alarm set
p.39
Ringer on/High+Vib/1 Beep mode
Ringer off
Silent / Vibration mode
Roaming network
Digital mode
1x RTT mode
Battery power level
* Depending on your conuntry or service provider, the icons
shown on the display may vary.
11
Get started
Access menu functions
Use the soft
keys
The roles of the soft keys vary
depending on the function you are
using. The bottom line of the
display indicates their current role.
Press the left soft
key to access
Menu mode.
Press the right soft
key to access
Contacts
.
Menu Contacts
Select an
option
1. Press a desired soft key.
2. Press the Navigation keys to
move to the next or previous
option.
3. Press [
OK
] to confirm the
function displayed or option
highlighted.
4. To exit, choose either of the
following methods.
•Press <
Back
> or [
C
] to
move up one level.
• Press [ ] to return to Idle
mode.
Use shortcuts
Press the number key
corresponding to the option you
want.
12
Get started
Customize your phone
1. In Idle mode, press <
Menu
>
and select
Settings
→
Idioma/Language
.
2. Select a language.
1. In Idle mode, press <
Menu
>
and select
Tones/Images
→
Sounds
→
Ringer
Type
→
Calls
.
2. Select a ringer category.
3. Select a ringer melody.
4. Press [
OK
].
Display
language
Call ringer
melody
You can set a wallpaper for the
display.
1. In Idle mode, press <
Menu
>
and select
Tones/Images
→
Display
→
Wallpaper
.
2. Scroll to an image by pressing
[Left] or [Right].
3. Press [
OK
].
You can change the banner on the
display.
1. In Idle mode, press <
Menu
>
and select
Tones/Images
→
Display
→
Banner
.
2. Enter your banner.
3. Press [
OK
].
13
Get started
You can set the Navigation keys to
function as shortcuts to access
your favourite menus.
1. In Idle mode, press <
Menu
>
and select
Tones/Images
→
Display
→
Launch pad
.
2. Select a key.
3. Select a menu to be assigned to
the key.
You can switch the phone to Silent
mode to avoid disturbing other
people with your phone sound.
Press and hold
[
]
in Idle mode.
Menu
shortcuts
Silent mode
You can protect the phone against
unauthorized use with a phone
password.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Security
.
2. Enter the default password,
0000
.
3. Select
Change Lock
.
4. Enter a new password and
press [
OK
].
5. Enter the new password again
and press [
OK
].
6. Select
Lock Phone
.
7. Select
On Power-Up
or
Lock
Now
.
Phone lock
14
Make/answer calls
Step outside the phone
Begin with your Contacts, Messages, Calendar, and Alarm
Use Contacts
1. Enter an area code and a phone
number.
2. Press
[]
.
3. To end the call, press
[]
.
1. When the phone rings, press
[]
.
2. To end the call, press
[]
.
Make a call
Answer a call
1. In Idle mode, enter a phone
number and press <
Save
>.
2. Select
Add
New Entry
→
a
number type.
3. Specify contact information:
Name, Entry, Home, Work,
Mobile, Pager, Fax, No label,
Speed dial, E-mail, URL, Group,
Caller Ringer, Birthday, Secret,
and Image.
4. Press [
OK
].
5. Select
Yes
to save the entry.
Add an entry
15
Step outside the phone
Send messages
View messages
1. In Idle mode, press
<
Contacts
>.
2. Select an entry.
3. Select a number and press [ ]
to dial, or press [
OK
] to access
options.
1. In Idle mode, press <
Menu
>
and select
Torpedo SMS
→
New Message
.
2. Enter destination numbers and
press <
Next
>.
3. Enter the message text and
press <
Next
>.
4. Press <
Send
>.
Find an entry
Send a text
message (SMS)
When a notification appears:
Press [
OK
]. The message displays.
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Torpedo SMS
→
Inbox
.
2. Select a message.
View a text
message
16
Step outside the phone
Send SOS messages
You can send an SOS message to your family or
friends for help in an emergency.
Manage schedule
1. In Idle mode, press <
Menu
>
and select
Torpedo SMS
→
Settings
→
SOS Message
.
2. Select
On
.
3. Select the
Recipients
line.
4. Enter the phone numbers to
which you want to send the
SOS message and press
<
Save
>.
5. Press [Down] and select the
Number of times.
6. Press [
OK
] to save your
settings.
Set up SOS
message
options
In Idle mode, with the phone
closed, press [ / ] 4 times.
The phone sends the SOS
message.
1. In Idle mode, press <
Menu
>
and select
Planner
→
Calendar
.
2. Select a date from the calendar.
3. Enter the details about the
appointment and press
<
Next
>.
4. Enter the starting and ending
time.
5. Select an alarm option.
6. Press <
Save
>.
Send the SOS
message
Create a new
appointment
17
Step outside the phone
Use the alarm clock
1. In Idle mode, press <
Menu
>
and select
Planner
→
Calendar
.
2. Select a date.
3. Select an appointment from the
list.
1. In Idle mode, press <
Menu
>
and select
Planner
→
Alarm
.
2. Select the type of the alarm.
3. Select
On
and press [Down].
4. Enter the alarm time.
5. Selet a meoldy for the alarm.
6. Select a repeat option and
press <
Save
>.
Check your
schedule
Set an alarm
When the alarm sounds, press any
key.
Stop an alarm
18
Enter text
T9 English, Alphabet, Symbol, and Number modes
You can enter text in some features such as Torpedo
SMS, Contacts, or Planner using T9 English mode,
Alphabet mode, Number mode, and Symbols mode.
Changing the text input mode
Press <
Menu
> and select the input mode you want.
Using T9 English mode
T9 is a predictive text input mode that allows you to
key in any character using single keystrokes.
Entering a word in T9 English mode
1. Press [
2
] to [
9
]
to start entering a word. Press
each key once for each letter.
For example, press [
4
], [
3
], [
5
], [
5
], and [
6
] to
enter Hello in T9 English mode.
T9 predicts the word that you are typing, and it
may change with each key that you press.
2. Enter the whole word before editing or deleting
characters.
3. When the word displays correctly, go to step 4.
Otherwise, press [
0
] to display alternative word
choices for the keys that you have pressed.
For example, Of and Me use [
6
] and [
3
].
4. Press [ ] to insert a space and enter the next
word.
Other T9 English mode operations
• Press [
1
] to enter periods or apostrophes
automatically.
• Press [ ] to insert a space.
• Press [ ] to change case. Lower case (
T9word
),
Initial capital (
T9Word
), and Capital lock
(
T9WORD
) are available.
• Press the Navigation keys to move the cursor.
• Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
19
Enter text
Using Alphabet mode
Press the appropriate key until the character you want
appears on the screen.
Other Alphabet mode operations
• To enter the same letter twice or to enter a
different letter on the same key, wait for the cursor
to move to the right automatically or press [Right].
Then, enter the next letter.
• Press [ ] to insert a space.
• Press [ ] to change case. Lower case (
abc
),
Initial capital (
Abc
), and Capital lock (
ABC
) are
available.
• Press [Left] or [Right] to move the cursor.
• Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
Using Number mode
Number mode enables you to enter numbers.
Press the keys corresponding to the digits you want.
Using Symbol mode
Symbol mode enables you to insert symbols.
Characters in order displayed
Key Upper case Lower case
To Press
display more symbols [Left] or [Right].
select a symbol the corresponding
number key.
clear the symbols [
C
].
20
Call functions
Advanced calling features
Making a call
1. In Idle mode, enter the area code and a phone
number.
2. Press [ ].
3. When you want to end the call, press [ ]
Using dialing options
While entering a number, press <
Menu
> to access the
following options:
•
4-digit Dial
: use the four digit dialing feature.
This option is only available when you enter four
digits.
•
Speed Dial
: use the speed dialing feature. This
option is only available when you enter a number
corresponding to a Contacts location.
•
Talk
: place a call to the number.
•
Save
: save the number to Contacts.
•
Find
: find the number from Contacts.
•
Hard Pause
: insert a hard pause. Numbers after
the pause will be sent when you press [ ].
•
2sec Pause
: insert a 2-second pause. Numbers
after the pause will be sent automatically.
Redialing recent numbers
1. In Idle mode, press [ ] to display the list of
recent numbers.
2. Scroll to the number you want and press [ ].
Making a call from Contacts
Once you have stored a number in Contacts, you can
dial the number by selecting it from Contacts.
p. 23
Making an emergency call
You can make calls to standard emergency numbers,
such as 190, 192, or 193 on the Emergency # list,
even if your phone is locked or all outgoing calls are
restricted.
p. 45
Press
[
C
]
to clear the last digit or press and hold
[
C
]
to clear the whole display.
21
Call functions
Speed dialing
When you store a number in Contact, a location
number is assigned to the number so that you can dial
it by entering its location number.
• For 1-digit locations, press and hold the
corresponding number key.
• For other locations, press the first number key and
press and hold the last number key.
Answering a call
When you receive an incoming call, the phone rings
and displays the incoming call image.
Press [ ] to answer the call.
Tips for answering a call
• When
Any key
in the
Call Answer
menu is
selected, you can press any key except for [ ]
and [ / ].
p. 42
• When
Send Key
in the
Call Answer
menu is
selected, you can press [ ].
p. 42
• When
Folder open
in the
Call Answer
menu is
selected, you can simply open the phone.
p. 42
• Press [ ] to silence a call.
Viewing missed calls
If you have missed calls, the screen displays how
many calls you have missed.
Press [ ] to dial the last number.
Using the headset
Use the headset to make or answer calls without
holding the phone. Connect the headset to the jack on
the left side of the phone. The button on the headset
works as follows:
To Press
redial the last call the button twice.
answer a call the button.
end a call the button.
22
Call functions
Options during a call
You can access a number of functions during a call.
Answering a second call
You can answer an incoming call while already on the
phone, if your network supports this function.
1. Press [ ] to answer the call. The first call is
automatically put on hold.
2. Press [ ] to switch between the calls.
Using the In-call menu options
During a call, press <
Menu
> to access the following
options:
•
SPK phone
: turn on the speakerphone feature or
switch back to Normal mode.
•
Contacts
: access the
Contacts
menu to locate or
store entries.
p. 23
•
Mute
/
Quit
: switch off your phone’s microphone,
so that the other person cannot hear you.
•
Silent
/
Quit
: mute the DTMF (Dual-Tone Multi-
Frequency) tones of the keys.
•
Send Tel#
: send your phone number as the DTMF
(Dual tone multi-frequency) tones.
•
Calls
: access the
Calls
menu.
p. 25
•
Torpedo SMS
: access the
Torpedo SMS
menu.
p. 28
•
Planner
: access the
Planner
menu.
p. 37
To communicate with answering machines or
computerized telephone systems, key tones
must be turned on.
23
Menu functions
All menu options listed
Contacts
You can store phone numbers with associated names
in your phone’s memory called Contacts to make it
easy for you to make a call without having to
remember the phone number.
To access this menu, press <
Contacts
> in Idle mode.
Find
Use this menu to search for numbers in Contacts.
Finding an entry
1. Press [Left] or [Right] to select a search method.
2. Enter the first few letters of the name you want, or
select a memory location or a caller group.
3. Select the name you want.
4. Press [ ] to dial the number, or <
Menu
> to
access Contacts options.
Using Contacts options
While viewing a contact, press <
Menu
> to access the
following options:
•
Talk
: dial the selected number.
•
Edit
: edit the selected contact.
•
Prepend
: add an additional number, such as an
area code or feature code, to the phone number.
•
Erase
: erase the selected contact.
Add New Entry
Use this menu to add a new contact to Contacts.
1. Enter a phone number and press <
Next
>.
2. When
Add New Entry
is highlighted, press [
OK
].
3. Select a category type of the number.
4. Enter a name and press <
Next
>.
Press <
Contacts
> in Idle mode to quickly access
this menu.
24
Menu functions
5. Change the settings or enter information about the
contact.
Name
: assign a name, if one has not already been
entered.
Entry
: enter the location number, if necessary.
Home
/
Work
/
Mobile
/
Pager
/
Fax
/
No label
: add a
number in any category.
Speed dial
: select one of the stored numbers for
speed dialing.
E-mail
: assign an e-mail address.
URL
: enter an URL address of the person.
Group
: assign the number to a caller group.
Caller Ringer
: assign a ringer melody to alert you
to a call from the number.
Birthday
: enter the birthday of the person.
Secret
: prevent a number from being displayed
when it is accessed or dialed by unauthorized
users.
: assign an image as a caller ID image to
alert you to a call from the number.
6. When you have finished, press [
OK
].
7. Select
Yes
to save the contact.
Group Edit
Use this menu to change the settings for the caller
groups.
Changing the caller group name
1. Scroll to the group you want.
2. Press <
Menu
> and select
Rename
.
3. Clear the old name and enter a new name you
want.
4. Press <
Save
>.
Changing the ringer melody
1. Scroll to the group you want.
2. Press <
Menu
> and select
Ringer
.
3. Select the ringer category and press [Down].
4. Select the ringer melody.
5. Press [
OK
].
25
Menu functions
Calls
(Menu 1)
My Phone#
Use this menu to check your phone number.
Memory Info
Use this menu to display the number of contacts you
have stored in Contacts.
Calls
(Menu 1)
Use this menu to view the calls you have missed,
received, or dialled, and the length of your calls.
To access this menu, press <
Menu
> in Idle mode and
select
Calls
.
Outgoing
(Menu 1.1)
This menu displays the most recent calls you have
dialled.
Accessing a call record
1. Press [Up] or [Down] to scroll through the call list.
2. Press <
View
> to view the details of a call, or [ ]
to dial a number.
Using call record options
While viewing call details, press <
Menu
> to access
the following options:
•
Talk
: dial the number.
•
Save
: save the number in Contacts, if not saved.
26
Menu functions
•
Show Entry
: display the phone number and
memory location number.
•
Prepend
: add an additional number, such as area
code or feature code, to the phone number.
•
Erase
: erase the selected number.
•
Send Msg
: send the message to the phone
number.
Incoming
(Menu 1.2)
This menu displays the most recent calls you have
received.
Missed
(Menu 1.3)
This menu displays the most recent calls that you did
not answer.
Erase History
(Menu 1.4)
Use this menu to delete all of the records in each call
type.
1. Select a call type to be cleared.
2. Select
Yes
to confirm the deletion.
Air Time
(Menu 1.5)
Use this menu to display the time log for calls made
and received. The actual time invoiced by your service
provider will vary.
•
Last Call
: check the length of your last call.
•
Total
: check the total length of all the calls you
have dialed and received.
•
Life Time
: check the number and total duration of
all the calls you have dialed and received since the
phone was shipped from the factory.
•
Erase Total
: erase the total call timers, except for
Life Time.
27
Menu functions
Downloads
(Menu 2)
Downloads
(Menu 2)
Use this menu to download a variety of Brew
applications from the preset Brew server and change
the browser settings. You can also play the
downloaded media files, as well as view help
information.
To access this menu, press <
Menu
> in Idle mode and
select
Downloads
.
Downloading an application
You can access the Brew server and download
applications.
1. Select
Download Center
.
The following menus are available:
•
Catalog
: browse and purchase items.
•
Search
: search for an application by entering a
keyword.
•
About Download
: get help information for
using the
Download Center
menu.
2. Select
Catalog
. You are connected to the
associated website preset by your service provider
and you can browse the available applications.
3. Select the application you want and follow the
onscreen instructions to download it.
Changing browser settings
You can change the settings for using the Brew server
and downloaded applications.
1. Select
Settings
.
2. Select a setting option.
•
Order Apps
: change the list order of the
downloaded applications.
•
Move Apps
: move an application to another
folder.
•
Manage Apps
: check the amount of memory
used for downloaded applications.
•
Main Menu View
: change the view mode of
the main menu screen.
When
Airtime Warnings
is set to
All Enabled
,
you are prompted to connect to the server.
28
Menu functions
•
Screen Savers
: activate the screen saver
application, if downloaded.
•
Airtime Warnings
: set the phone to alert you
each time you access the Brew server.
•
View Log
: show the records of your browsing.
Viewing help information
You can view help information for using the Brew
server.
1. Select
Help
.
2. Select a help item.
3. Press [Up] or [Down] to scroll through help
information.
4. Press [
OK
] to go back to the main help screen.
Torpedo SMS
(Menu 3)
Use this menu to store all of the SMS messages you
have received, sent, or failed to send, or saved.
To access this menu, press <
Menu
> in Idle mode and
select
Torpedo SMS
.
New Message
(Menu 3.1)
You can create a short text message and send it to
other mobile phones.
1. Enter a destination number and press <
Next
>.
To send the message to more than one recipient,
press [Right] and add additional numbers.
2. Enter your message and press <
Next
>.
3. Specify the following settings:
•
Send To
: change the destination number or
add more destination numbers.
•
Msg
: change the message text you have
already entered.
•
Call Back #
: change the callback number.
•
Options
: change the SMS settings for sending
the message.
29
Menu functions
Torpedo SMS
(Menu 3)
Priority
: select a priority level.
Delivery Ack
: set the network to inform you
when your message is delivered.
Message Save
: set how the phone acts for
sent messages.
-
Auto Save
: the phone immediately saves a
copy of the message.
-
Do Not Save
: the phone does not save the
message in the Outbox.
-
Prompt Save
: the phone prompts you to
save the message.
•
Draft
: save the message in the Drafts folder.
4. When you have finished, press <
Send
> to send
the message.
Voice Mail
(Menu 3.2)
When you access this menu, the display shows the
latest voice mail notification. Scroll to the notification
you want by pressing the Navigation keys.
• Press <
Call
> to access the voice mail server to
listen to the message.
• Press <
Options
> to access the following options:
Listen
: access the voice mail server to listen to
the message.
Clear Icon
: clear the selected notification.
Inbox
(Menu 3.3)
This folder stores all of the messages you have
received.
Viewing a message
The following icons may appear on the message list:
• has been read
• has not been read
• Urgent messages (Red: unread messages,
Blue: read message)
30
Menu functions
From the message list, select the message you want
to view.
While viewing a message, press <
Options
> to access
the following options:
•
Reply
: reply to the sender.
•
Forward
: forward the message to other people.
•
Erase
: erase the message.
•
Talk
: call the sender.
•
Save
: save the sender’s number to Contacts.
•
Move
: move the message from the Inbox to the
Saved box.
•
Extract#’s
: extract phone numbers from the
message text.
Outbox
(Menu 3.4)
This folder stores messages that the phone is
attempting to send, or has failed to send.
The following icons are available to show the message
status:
• has been sent
• has been opened
While viewing a message, press <
Options
> to access
the following options:
•
Resend
: send the message.
•
Erase
: erase the message.
Drafts
(Menu 3.5)
This folder stores messages you have saved to send at
a later time.
While viewing a message, press <
Options
> to access
the following options:
•
Resend
: send the message.
•
Erase
: erase the message.
31
Menu functions
Torpedo SMS
(Menu 3)
Saved
(Menu 3.6)
This folder stores messages you have sent from the
Inbox to this folder.
While viewing a message, press <
Options
> to access
the following options:
•
Resend
: send the message.
•
Erase
: erase the message.
Erase Msg
(Menu 3.7)
Use this menu to erase all of the messages in each
message folder.
1. Select the message folder to be cleared.
2. Select
Yes
to confirm the deletion.
Setting
(Menu 3.8)
Use this menu to set up options for using SMS
messages.
•
Scroll Timer
: select the scrolling time. When you
select
Off
, you need to manually scroll the screen.
•
Msg Reminder
: set how often the phone reminds
you of new messages.
•
Auto Erase
: set what happens if new messages
arrive when the Inbox is full.
On
: the phone automatically erases old messages
in order to receive new messages.
Off
: the phone alerts you that new messages are
being rejected because the Inbox is full.
•
New Message
: change the settings for new
messages.
Callback #
: enter a callback number.
Save Message
: set how the phone acts for sent
messages.
- Do Not Save
: the phone does not save the
message in the Outbox.
32
Menu functions
- Prompt Save
: the phone prompts you to save
the message.
- Auto Save
: the phone immediately saves a copy
of the message.
Entry Method
: select a default text input mode
when creating a new message.
Delivery Ack
: set the network to inform you when
your message is delivered.
•
Canned Msg
: edit the preset canned messages
and make new canned messages. You can use the
messages when writing a message.
•
Msg Alert
: set how the phone alerts you to new
messages during a call.
On
: the phone alerts you with a beep and displays
the corresponding icon.
Off
: the phone does not actively alert you to new
messages, but displays the corresponding icon.
•
SOS message
: set wether or not to use the SOS
message feature. In an emergency, you can send
SOS messages to your family or friends for help.
Use this menu to specify options for sending and
receiving SOS messages.
On
: activate or deactivate the SOS message
feature. To send an SOS message, press [ / ] 4
times in Idle mode, with the phone closed.
Recipients
: specify the phone numbers to which
you want to send SOS messages.
Number of sending
: set the number of times the
phone repeats sending SOS messages.
Message
: check the preset SOS message text.
While the phone is attempting to send an SOS
message, you cannot access menu functions. Use
the phone as normal when the icon becomes
still, or press [ ] to exit Emergency mode.
33
Menu functions
Ton es / Im a ge s
(Menu 4)
Tones/Images
(Menu 4)
Use this menu to change settings for the display and
the sounds.
To access this menu, press <
Menu
> in Idle mode and
select
Tones/Images
.
Display
(Menu 4.1)
Use this menu to change settings for the display and
light.
Menu Style
(Menu 4.1.1)
Use this menu to select a menu style.
Wallpaper
(Menu 4.1.2)
Use this menu to change the background image to be
displayed in Idle mode.
Backlight
(Menu 4.1.3)
Use this menu to customize settings for backlight.
•
Main Display
: change the display backlight
settings.
Duration
: specify the length of time the display
backlight stays on.
Brightness
: adjust the brightness of the display
for varying lighting conditions.
•
Keypad
: specify the length of time the keypad
backlight stays on.
•
Pwr Save Mode
: set the phone to turn the display
off when you do not use the phone.
Banner
(Menu 4.1.4)
Use this menu to set a banner message to be
displayed at the bottom of the display in Idle mode.
Launch Pad
(Menu 4.1.5)
Use this menu to set the shortcut assignments for the
Navigation keys.
1. Select the key you want.
2. Select the menu to be assigned to the key.
34
Menu functions
Dual Clock
(Menu 4.1.6)
Use this menu to select two time zones to be displayed
when you select
Dual Clock
for the wallpaper image.
p. 33
1. Scroll to
Location
by pressing [Left] or [Right].
2. Scroll to the
P1
field and press [Left] or [Right] to
select the time zone for the left clock.
3. Scroll to the
P2
field and press [Left] or [Right] to
select the time zone for the right clock.
4. Press [
OK
].
Contrast
(Menu 4.1.7)
You can adjust the contrast of the brightness for the
display. Adjust the setting with the display brightness
to see the display clearly in different lighting
conditions.
Sounds
(Menu 4.2)
Use this menu to customize various sound settings.
Ringer Volume
(Menu 4.2.1)
Use this menu to select a ringer volume for incoming
calls, message alert, alarm settings, and scheduler
alarm.
•
Silent
: the phone neither vibrates nor rings.
•
Vibrate
: the phone vibrates.
•
1-Beep
: the phone sound a beep.
•
Level 1
~
8
: you can select a volume for the call
ringer.
•
High+Vib
: the phone vibrates and then rings at
the same time.
Ringer Type
(Menu 4.2.2)
Use this menu to select the ringer type for incoming
calls, message alert, or scheduler alarm.
You can apply the daylight saving time for each
clock. Scroll to
DST
by pressing
[Left] or [Right]
and scroll to the
P1
or
P2
field. Select
On
and
press [
OK
]
.
35
Menu functions
Ton es / Im a ge s
(Menu 4)
Keytone
(Menu 4.2.3)
Use this menu to set up the key tone that the phone
sounds when you press a key.
•
Type
: select a tone that the phone sounds when
you press a key.
•
Volume
: adjust the keytone volume.
Alerts
(Menu 4.2.4)
Use this menu to set up audible alerts to inform you
that certain things have happened.
•
Minute Beep
: set the phone to beep every minute
during an outgoing call to keep you informed of the
length of your call.
•
Service Alert
: set the phone to beep when you
exit a service area or return to a service area.
•
Call Connect
: set the phone to beep when your
call is connected to the system.
•
Call Disconnect
: set the phone to beep when
your call is disconnected from the system.
•
Signal Fade
: set the phone to beep when a
dropped call occurs during conversation in
response to fading signal strength.
•
Roaming Alerts
: set the phone to beep when
your phone starts roaming.
Roam Ringer
(Menu 4.2.5)
Use this menu to set the phone to sound a distinctive
ring when your phone starts roaming.
Tone Length
(Menu 4.2.6)
Use this menu to set short or long DTMF (dual-tone
multi-frequency) tones to be sent to access
teleservices, such as a bank account. If the service is
digital, as most are, short DTMF tones will almost
always work.
Power On/Off
(Menu 4.2.7)
Use this menu to turn on or off the tone that the
phone sounds when it is switched on or off.
36
Menu functions
Meu Vivo
(Menu 5)
Vivo Menu mode, provided by your service provider,
contains the customizing menus to allow you to
change your phone's settings, such as display and
sound setting.
In Vivo Menu mode, you can more quickly and easily
access the menus and change the settings as your
preferences.
To access this menu, press <
Menu
> in Idle mode and
select
Meu vivo
.
Launch Pad
(Menu 5.1)
Use this menu to set the shortcut assignments for the
Navigation keys.
p. 33
Ringer Type
(Menu 5.2)
Use this menu to select the ringer type for incoming
calls, message alert, or scheduler alarm.
Menu Style
(Menu 5.3)
Use this menu to select a menu style.
Banner
(Menu 5.4)
Use this menu to set a banner message to be
displayed at the bottom of the display in Idle mode.
Wallpaper
(Menu 5.5)
Use this menu to change the background image to be
displayed in Idle mode.
Orig. Settings
(Menu 5.6)
Use this menu to reset the display settings and sound
settings individually.
Msg Setting
(Menu 5.7)
Use this menu to customize settings for using SMS
messages.
p. 31
Auto CSP
(Menu 5.8)
Use this menu to set the phone to automatically add
the CSP (Carrier Selection Code) of your long distance
call service to the entered number when making a call.
p. 42
37
Menu functions
Voice Mail
(Menu 6)
Voice Mail
(Menu 6)
Use this menu to connect to the voice mail server to
access your voice mails.
To access this menu, press <
Menu
> in Idle mode and
select
Voice Mail
.
For further details, contact your service provider.
Voice Portal
(Menu 7)
Use this menu to access this voice-activated service
and get audio content, such as headline news,
information on movies, the weather, finance, and
traffic, supplied by your service provider.
To access this menu, press <
Menu
> in Idle mode and
select
Voice Portal
.
For further details, contact your service provider.
Planner
(Menu 8)
The Planner feature enables you to keep track of your
schedule and tasks. You can also use convenient
features, such as a calculator, memo pad, and count
down timer.
It also enables you to use the phone as a calculator, to
count down to a specified day, and to set the current
time and date.
Today
(Menu 8.1)
Use this menu to display Planner items stored for the
current day.
For further details about storing items, see the
Calendar
menu.
Calendar
(Menu 8.2)
When you enter the
Calendar
menu, the calendar in
Month view appears with today’s date indicated by a
colored box.
You must enter the voice server number before you
access your voice mails. Your service provider can
give the voice server number.
38
Menu functions
Selecting a day on the calendar
• Press [Left] or [Right] to move by day.
• Press [Up] or [Down] to move by week.
• Press [ / ] to move by month.
Entering a new item
1. Scroll to a date on the calendar.
2. Press <
Menu
> and select
Add New
.
3. Enter item details and press <
Nex
t>.
4. Enter the starting and ending time and date for the
item.
5. Select when an alarm alerts you to your item.
6. Press [
OK
] or <
Save
> to save the item.
Viewing an item
Square brackets on a calendar date indicate items
scheduled for that day:
1. Select a date on the calendar to display the items
for the day.
2. Select an item to view its details.
While viewing an item, press <
Menu
> to access the
following options:
•
Edit
: edit item information.
•
Erase
: erase the selected item.
•
Add New
: add a new item.
Using calednar options
On the calendar, press <
Menu
> to access the
following options:
•
View
: access the stored items for that date.
•
Add New
: add a new item.
•
Erase All
: erase all of the items.
•
Jump to date
: go to a specific date you entered.
You can change between AM and PM in 12-
hour time format. Press [
2
] for
A
(AM) or [
7
]
for
P
(PM).
39
Menu functions
Planner
(Menu 8)
Task List
(Menu 8.3)
Use this menu to create a list of tasks that need to be
done.
Creating a new task
1. Enter the task content and press <
Next
>.
2. Enter a deadline time and date.
3. Select a priority from the
Priority
line.
4. Press <
Save
>.
Viewing a task
Select a task from the list.
While viewing a task, press <
Menu
> to access the
following options:
•
Edit
: edit the selected task.
•
Erase
: erase the selected task.
•
Add New
: add a new task.
Memo Pad
(Menu 8.4)
Use this menu to make memos of important things
you need to remember.
Creating a new memo
1. Enter a memo.
2. Press <
Save
>.
Viewing a memo
1. Select a memo from the list.
2. Press [
OK
] to view the memo details.
While viewing a memo, press <
Menu
> to access the
following options:
•
Edit
: edit the memo.
•
Erase
: erase the selected memo.
•
Add New
: add a new memo.
40
Menu functions
Alarm
(Menu 8.5)
Use this menu to set alarms to sound at specific times.
Setting an alarm
1. Select the type of alarm.
2. Select
On
and press [Down].
3. Enter the alarm time to sound.
4. Select a melody for the alarm and press [Down].
5. Select a repeat option and press <
Save
>.
Stopping an alarm
• Press any key to stop the alarm.
• To deactivate an alarm setting, select an alarm you
have set and select
Off
and press <
Save
>.
Calculator
(Menu 8.6)
Use this menu to perform basic arithmetic functions,
such as addition, subtraction, multiplication, and
division.
1. Enter the first number.
• Press [ ] to insert a decimal point.
• Press [ ] to change the sign of a number to a
negative (-).
2. Press one of the Navigation keys to access the
math function you want.
3. Enter the second number.
4. Press [
OK
] to view the result.
5. If necessary, repeat from step 2 to continue the
calculation.
41
Menu functions
Planner
(Menu 8)
World Time
(Menu 8.7)
Use this menu to find out the current time in another
part of the world.
Scroll through the map by pressing the Navigation
keys.
To apply the DST (Daylight Saving Time) setting, press
<
Set
DST
>.
Count Down
(Menu 8.8)
Use this menu to set a timer to count down how many
days are left until a target date and to sound an alarm
at a specified date and time to alert you to a specific
event.
1. Enter information for the count down timer and
press <
Next
>.
2. Enter the date you want to count down from and
press <
Save
>.
While viewing a timer, press <
Menu
> to access the
following options:
•
Edit
: edit the selected timer.
•
Erase
: erase the selected timer.
•
Add new
: add a new timer.
Set Time
(Menu 8.9)
When you need to manually enter the current time
and date in specific area where call service reception is
weak, use this menu to set the time and date on the
Idle mode. Enter the time and date and press [
OK
].
42
Menu functions
Setup
(Menu 9)
Many different features of your phone’s system can be
customized to suit your preferences.
To access this menu, press <
Menu
> in Idle mode and
select
Setup
.
Auto CSP
(Menu 9.1)
Use this menu to set the phone to automatically add
the CSP (Carrier Selection Code) of your long distance
call service to the entered number when making a call.
On/Off
(Menu 9.1.1)
You can set whether or not to activate the Auto CSP
feature.
Code Setting
(Menu 9.1.2)
You can set the 2 digit carrier code to be added to the
phone number. Enter the carrier code you want and
press [
OK
].
Auto Answer
(Menu 9.2)
Use this menu to set the phone to automatically
answer calls after a specified time when you use the
headset.
Call Answer
(Menu 9.3)
Use this menu to set how to answer incoming calls.
•
Any Key
: the phone answers calls when you press
any key except for [ ] and [ / ].
•
Send Key
: the phone answers calls only when you
press [ ].
•
Folder Open
: the phone answers when you open
the phone. If the phone is already open, press
[].
Auto Retry
(Menu 9.4)
Use this menu to set the phone to automatically redial
calls after a specified length of time when a connection
fails.
B
efore setting the carrier code, you should enable
the
On/Off
menu first. The code is added only
when the phone number has 6,7,10, or 11 digits
and starts with 0xx, for example, 012 or 015.
43
Menu functions
Setup
(Menu 9)
Idioma/Language
(Menu 9.5)
Use this menu to select a language for the display
text.
System
(Menu 9.6)
This menu provides you with options for selecting a
network.
Select NAM
(Menu 9.6.1)
Your phone can have two NAMs (Numerical
Assignment Module), essentially your phone number.
Use this menu to switch your service back and forth
between the two.
If you change the NAM, the phone turns off by itself
and then back on to acquire service using the new
NAM.
Set System
(Menu 9.6.2)
Roaming allows you to register your phone on other
networks and use the facilities, if your own network is
not available. Roaming is only relevant in areas where
there are at least two cellular service providers having
valid roaming agreements.
When you are using another network, the Roaming
icon ( ) appears.
•
Home Only
: you cannot roam. When your home
system is not available, and the No service icon
( ) appears and you cannot make or receive
calls.
•
Standard
: your phone automatically searches for
the first available service.
PRL Enable
(Menu 9.6.3)
Your phone can find a cellular service provider's
network on the Preferred Roaming List (PRL), a graded
list of bands and channels which the phone uses when
it attempts to locate and connect to a network while
roaming. Use this menu to activate or deactivate the
use of the PRL.
44
Menu functions
•
Yes
: the phone searches and lists all of the
network providers' networks available for your
area.
•
No
: the phone searches for the default channel to
locate your own network.
Help
(Menu 9.7)
Use this menu to view information about your phone.
Customer Care Center
(Menu 9.7.1)
Use this menu to connect to the customer care centre.
Phone Info
(Menu 9.7.2)
Use this menu to check your phone information, such
as the version of the software and hardware or your
phone number.
Security
(Menu 9.8)
Use this menu to protect the phone against
unauthorized use.
To access the
Security
menu, you must enter the
phone password. The password is preset to
0000
.
Lock Phone
(Menu 9.8.1)
Use this menu to lock the phone.
•
Unlocked
: the phone remains unlocked.
•
On Power-Up
: the phone is locked automatically
each time you turn it on.
•
Lock Now
: the phone is locked immediately.
When the phone is locked, you must enter your phone
password each time you access menu functions.
Change Lock
(Menu 9.8.2)
Use this menu to change your phone password. The
password is preset to
0000
.
45
Menu functions
Setup
(Menu 9)
Call Restriction
(Menu 9.8.3)
Use this menu to restrict all outgoing call functions on
the phone and access to your Contacts.
When this feature is enabled, you must enter the
phone password to access restricted functions. The
password is preset to
0000
.
Emergency #
(Menu 9.8.4)
Use this menu to store emergency numbers, which
can be manually dialed at any time even if all call
functions are restricted or your phone is in Lock mode.
To make a emergency call in Lock mode, enter a
programmed number and then press [ ].
IMPORTANT NOTICE
Emergency calling may not be available on all wireless
networks at all times. A connection cannot always be
guaranteed, due to various transmission methods,
network parameters, and user settings used to
complete a call from your wireless phone.
DO NOT depend on this phone as a primary method of
dialing 190, 192, 193 or for any other essential or
emergency communications.
Remember to always turn your phone on and check for
adequate signal strength before placing a call.
Erase Contacts
(Menu 9.8.5)
Use this menu to erase all data stored in the phone’s
memory.
Reset Phone
(Menu 9.8.6)
Use this menu to reset the original phone settings,
display settings, and sound settings individually.
46
Health and safety information
Exposure to radio frequency (RF) signals
Your wireless phone is a radio transmitter and receiver. It
is designed and manufactured not to exceed the emission
limits for exposure to radio frequency (RF) energy set by
the Federal Communications Commission (FCC) of the
U.S. Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for
the general population. The guidelines are based on the
safety standards that were developed by independent
scientific organizations through periodic and through
evaluation of scientific studies.
The standards include a substantial safety margin
designed to assure the safety of all persons, regardless of
age and health.
The exposure standard for wireless phones employs a unit
of measurement known as Specific Absorption Rate (SAR).
The SAR limit recommended by the FCC is 1.6W/kg.
*
SAR tests are conducted using standard operating
positions specified by the FCC with the phone transmitting
at its highest certified power level in all tested frequency
bands. Although the SAR is determined at the highest
certified power level, the actual SAR level of the phone
while operating can be well below the maximum value.
This is because the phone is designed to operate at
multiple power levels so as to use only the power required
to reach the network. In general, the closer you are to a
wireless base station antenna, the lower the power output
of the phone.
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that it
does not exceed the limit established by the government
adopted requirement for safe exposure. The tests are
performed in positions and locations (e.g., at the ear and
worn on the body) as required by the FCC for each model.
While there may be differences between the SAR levels of
various phones and at various positions, they all meet the
government requirement.
* In the U.S. and Canada, the SAR limit for mobile phones
used by the public is 1.6 watts/kg (W/kg) averaged
over one gram of tissue. The standard incorporates a
substantial margin of safety to give additional
protection for the public and to account for any
variations in measurements.
E760.book Page 20 Tuesday, May 23, 2006 1:59 PM
Health and safety information
47
The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as in
compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC
and can be found under the Display Grant section of http:/
/www.fcc.gov/oet/fccid after searching on FCC ID printed
in the label on the phone.
For body operation
For body worn operation, this model phone has been
tested and meets the FCC RF exposure guidelines when
used with a Samsung-supplied or approved accessory
designated for this product or when used with and
accessory that contains no metal and that positions the
handset a minimum from the body.
The minimum distance for this model phone is written in
the FCC certification information from the body. None
compliance with the above conditions may violate FCC RF
exposure guidelines.
For more Information concerning exposure to radio
frequency signals, see the following websites:
Federal Communications Commission (FCC)
http://www.fcc.gov
Cellular Telecommunications Industry Association (CTIA):
http://www.wow-com.com
U.S.Food and Drug Administration (FDA)
http://www.fda.gov/cdrh/consumer
World Health Organization (WHO)
http://www.who.int/peh-emf/en
Precautions when using batteries
Never use any charger or battery that is damaged in any
way.
Use the battery only for its intended purpose.
If you use the phone near the network’s base station, it
uses less power; talk and standby time are greatly
affected by the signal strength on the cellular network and
the parameters set by the network operator.
Battery charging time depends on the remaining battery
charge, the type of battery and the charger used. The
battery can be charged and discharged hundreds of times,
but it will gradually wear out. When the operation time
E760.book Page 21 Tuesday, May 23, 2006 1:59 PM
48
(talk time and standby time) is noticeably shorter than
normal, it is time to buy a new battery.
If left unused, a fully charged battery will discharge itself
over time.
Use only Samsung-approved batteries and recharge your
battery only with Samsung-approved chargers. When a
charger is not in use, disconnect it from the power source.
Do not leave the battery connected to a charger for more
than a week, since overcharging may shorten its life.
Extreme temperatures will affect the charging capacity of
your battery: it may require cooling or warming first.
Do not leave the battery in hot or cold places, such as in a
car in summer or winter conditions, as you will reduce the
capacity and lifetime of the battery. Always try to keep the
battery at room temperature. A phone with a hot or cold
battery may temporarily not work, even when the battery
is fully charged. Li-ion batteries are particularly affected
by temperatures below 0 °C (32 °F).
Do not short-circuit the battery. Accidental short-circuiting
can occur when a metallic object (coin, clip or pen) causes
a direct connection between the + and – terminals of the
battery (metal strips on the battery), for example when
you carry a spare battery in a pocket or bag. Short-
circuiting the terminals may damage the battery or the
object causing the short-circuiting.
Dispose of used batteries in accordance with local
regulations. Always recycle. Do not dispose of batteries in
a fire.
Road safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime. But an
important responsibility accompanies the benefits of
wireless phones, one that every user must uphold.
When driving a car, driving is your first responsibility.
When using your wireless phone behind the wheel of a car,
practice good common sense and remember the following
tips:
Get to know your wireless phone and its features, such as
speed dial and redial. If available, these features help you
to place your call without taking your attention off the
road.
When available, use a hands-free device. If possible, add
an extra layer of convenience and safety to your wireless
E760.book Page 22 Tuesday, May 23, 2006 1:59 PM
Health and safety information
49
phone with one of the many hands-free accessories
available today.
Position your wireless phone within easy reach. Be able to
access your wireless phone without removing your eyes
from the road. If you get an incoming call at an
inconvenient time, let your voice mail answer it for you.
Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy traffic or
hazardous weather conditions. Rain, sleet, snow, ice, and
even heavy traffic can be hazardous.
Do not take notes or look up phone numbers while driving.
Jotting down a To Do list or flipping through your Address
Book takes your attention away from your primary
responsibility, driving safely.
Dial sensibly and assess the traffic; if possible, place calls
when you are not moving or before pulling into traffic. Try
to plan calls when your car will be stationary. If you need
to make a call while moving, dial only a few numbers,
check the road and your mirrors, then continue.
Do not engage in stressful or emotional conversations that
may be distracting. Make the people with whom you are
talking aware that you are driving and suspend
conversations that have the potential to divert your
attention from the road.
Use your wireless phone to call for help. Dial the
emergency number in the case of fire, traffic accident or
medical emergencies. Remember, it is a free call on your
wireless phone!
Use your wireless phone to help others in emergencies. If
you see a car accident, crime in progress or other serious
emergency where lives are in danger, call the emergency
number, as you would want others to do for you.
If you see a broken-down vehicle posing no serious
hazard, a broken traffic signal, a minor traffic accident
where no one appears injured, or a vehicle you know to be
stolen, call roadside assistance or any other special non-
emergency wireless number.
Operating environment
Remember to follow any special regulations in force in any
area and always switch off your phone whenever it is
forbidden to use it, or when it may cause interference or
danger.
E760.book Page 23 Tuesday, May 23, 2006 1:59 PM
50
Health and safety information
When connecting the phone or any accessory to another
device, read its user’s guide for detailed safety
instructions. Do not connect incompatible products.
As with other mobile radio transmitting equipment, users
are advised that for the satisfactory operation of the
equipment and for the safety of personnel, it is
recommended that the equipment should only be used in
the normal operating position (held to your ear with the
antenna pointing over your shoulder).
Electronic devices
Most modern electronic equipment is shielded from radio
frequency (RF) signals. However, certain electronic
equipment may not be shielded against the RF signals
from your wireless phone. Consult the manufacturer to
discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a minimum
distance of 15 cm (6 inches) be maintained between a
wireless phone and a pacemaker to avoid potential
interference with the pacemaker. These recommendations
are consistent with the independent research and
recommendations of Wireless Technology Research.
Persons with pacemakers:
should always keep the phone more than 15 cm (6 inches)
from their pacemaker when the phone is switched on.
should not carry the phone in a breast pocket.
should use the ear opposite the pacemaker to minimize
potential interference.
If you have any reason to suspect that interference is
taking place, switch off your phone immediately.
Hearing aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you may
wish to consult your hearing aid manufacturer to discuss
alternatives.
Other medical devices
If you use any other personal medical devices, consult the
manufacturer of your device to determine if it is
adequately shielded from external RF energy. Your
physician may be able to assist you in obtaining this
E760.book Page 24 Tuesday, May 23, 2006 1:59 PM
Health and safety information
51
information. Switch off your phone in health care facilities
when any regulations posted in these areas instruct you to
do so. Hospitals or health care facilities may be using
equipment that could be sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles. Check with
the manufacturer or its representative regarding your
vehicle. You should also consult the manufacturer of any
equipment that has been added to your vehicle. You
should also consult the manufacturer of any equipment
that has been added to your vehicle.
Posted facilities
Switch off your phone in any facility where posted notices
require you to do so.
Potentially explosive environments
Switch off your phone when in any area with a potentially
explosive atmosphere and obey all signs and instructions.
Sparks in such areas could cause an explosion or fire
resulting in bodily injury or even death.
Users are advised to switch off the phone while at a
refueling point (service station). Users are reminded of the
need to observe restrictions on the use of radio equipment
in fuel depots (fuel storage and distribution areas),
chemical plants or where blasting operations are in
progress.
Areas with a potentially explosive atmosphere are often
but not always clearly marked. They include the areas
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas (such as
propane or butane), areas where the air contains
chemicals or particles, such as grain, dust or metal
powders, and any other area where you would normally be
advised to turn off your vehicle engine.
Emergency calls
This phone, like any wireless phone, operates using radio
signals, wireless and landline networks as well as user-
programmed functions, which cannot guarantee
connection in all conditions. Therefore, you should never
rely solely on any wireless phone for essential
communications (medical emergencies, for example).
E760.book Page 25 Tuesday, May 23, 2006 1:59 PM
52
Health and safety information
Remember, to make or receive any calls the phone must
be switched on and in a service area with adequate signal
strength. Emergency calls may not be possible on all
wireless phone networks or when certain network services
and/or phone features are in use. Check with local service
providers.
To make an emergency call:
If the phone is not on, switch it on.
Key in the emergency number for your present location
(for example, 911 or other official emergency number).
Emergency numbers vary by location.
Press .
If certain features are in use (call barring, for example),
you may first need to deactivate those features before you
can make an emergency call. Consult this document and
your local cellular service provider.
When making an emergency call, remember to give all the
necessary information as accurately as possible.
Remember that your phone may be the only means of
communication at the scene of an accident; do not end the
call until given permission to do so.
FCC Notice and Cautions
FCC Notice
• The device complies with Part 15 of the FCC Rules.
Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
• This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses and
can radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will occur in a
particular installation.
E760.book Page 26 Tuesday, May 23, 2006 1:59 PM
Health and safety information
53
The phone may cause TV or radio interference if used in
close proximity to receiving equipment. The FCC can
require you to stop using the phone if such interference
cannot be eliminated.
Vehicles using liquefied petroleum gas (such as propane or
butane) must comply with the National Fire Protection
Standard (NFPA-58). For a copy of this standard, contact
the National Fire Protection Association, One Battery
march Park, Quincy, MA 02269, Attn: Publication Sales
Division.
Cautions
Changes or modifications made in the radio phone, not
expressly approved by Samsung, will void the user’s
authority to operate the equipment.
Only use approved batteries, antennas and chargers. The
use of any unauthorized accessories may be dangerous
and void the phone warranty if said accessories cause
damage or a defect to the phone.
Although your phone is quite sturdy, it is a complex piece
of equipment and can be broken. Avoid dropping, hitting,
bending or sitting on it.
Other important safety information
Only qualified personnel should service the phone or
install the phone in a vehicle. Faulty installation or service
may be dangerous and may invalidate any warranty
applicable to the device.
Check regularly that all wireless phone equipment in your
vehicle is mounted and operating properly.
Do not store or carry flammable liquids, gases, or
explosive materials in the same compartment as the
phone, its parts or accessories.
If this equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment off and on,
the user is encouraged to try to correct the
interference by one or more of the following
measures:
- Reorient or relocate the receiveing antenna.
- Increase the separation between the equipment
and receiver.
- Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV
technician for help.
E760.book Page 27 Tuesday, May 23, 2006 1:59 PM
54
Health and safety information
For vehicles equipped with an air bag, remember that an
air bag inflates with great force. Do not place objects,
including both installed or portable wireless equipment in
the area over the air bag or in the air bag deployment
area. If wireless equipment is improperly installed and the
air bag inflates, serious injury could result.
Switch off your phone before boarding an aircraft. The use
of wireless phones in aircraft is illegal and may be
dangerous to the aircraft’s operation.
Failure to observe these instructions may lead to the
suspension or denial of telephone services to the offender,
or legal action, or both.
Care and maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for many
years:
Keep the phone and all its parts and accessories out of the
reach of small children’s.
Keep the phone dry. Precipitation, humidity and liquids
contain minerals that will corrode electronic circuits.
Do not use the phone with a wet hand. Doing so may
cause an electric shock to you or damage to the phone.
Do not use or store the phone in dusty, dirty areas, as its
moving parts may be damaged.
Do not store the phone in hot areas. High temperatures
can shorten the life of electronic devices, damage
batteries, and warp or melt certain plastics.
Do not store the phone in cold areas. When the phone
warms up to its normal operating temperature, moisture
can form inside the phone, which may damage the
phone’s electronic circuit boards.
Do not drop, knock or shake the phone. Rough handling
can break internal circuit boards.
Do not use harsh chemicals, cleaning solvents or strong
detergents to clean the phone. Wipe it with a soft cloth
slightly dampened in a mild soap-and-water solution.
Do not paint the phone. Paint can clog the device’s moving
parts and prevent proper operation.
E760.book Page 28 Tuesday, May 23, 2006 1:59 PM
Health and safety information
55
Do not put the phone in or on heating devices, such as a
microwave oven, a stove or a radiator. The phone may
explode when overheated.
Use only the supplied or an approved replacement
antenna. Unauthorized antennas or modified accessories
may damage the phone and violate regulations governing
radio devices.
If the phone, battery, charger or any accessory is not
working properly, take it to your nearest qualified service
facility. The personnel there will assist you, and if
necessary, arrange for service.
Acknowledging special precautions
and the FCC and industry canada
notice
Cautions
Modifications not expressly approved by the party
responsible for compliance could void the user's authority
to operate the equipment.
FCC Compliance information
This device complies with Part 15 of FCC Rules. Operation
is subject to the following two conditions:
This device may not cause harmful interference, and
This device must accept any interference received.
Including interference that may cause undesired
operation.
Information to user
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation.
E760.book Page 29 Tuesday, May 23, 2006 1:59 PM
56
Health and safety information
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/ TV technician
for help.
Appendix A: CERTIFICATION
INFORMATION (SAR)
THIS MODEL PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It
is designed and manufactured not to exceed the emission
limits for exposure to radio frequency (RF) energy set by
the Federal Communications Commission of the U.S.
Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for
the general population. The guidelines are based on safety
standards that were developed by independent scientific
organizations through periodic and thorough evaluation of
scientific studies. The standards include a substantial
safety margin designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless mobile phones
employs a unit of measurement known as the Specific
Absorption Rate (SAR). The SAR limit set by the FCC is 1.6
W/kg. SAR Tests are conducted using standard operating
positions accepted by the FCC with the phone transmitting
at its highest certified power level in all tested frequency
bands. Although the SAR is determined at the highest
certified power level, the actual SAR level of the phone
E760.book Page 30 Tuesday, May 23, 2006 1:59 PM
Health and safety information
57
while operating can be well below the maximum value.
This is because the phone is designed to operate at
multiple power levels so as to use only the power required
to reach the network. In general, the closer you are to a
wireless base station antenna, the lower the power
output.
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that it
does not exceed the exposure limit established by the
FCC. Tests for each model phone are performed in
positions and locations (e.g. at the ear and worn on the
body) as required by the FCC.
The highest SAR values for this model phone as reported
to the FCC are
Head: 1.39 W/Kg, Body-worn: 0.868 W/Kg.
For body worn operation, this model phone has been
tested and meets the FCC RF exposure guidelines
whenused with a Samsung accessory designated for this
product or when used with an accessory that contains no
metal and that positions the handset a minimum of 1.5 cm
from the body. Non-compliance with the above restrictions
may result in violation of FCC RF exposure guidelines.
The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as in
compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC
and can be found under the Display Grant section of http:/
/www.fcc.gov/oet/fccid after searching on FCC ID
A3LSCHL160.
In the United States and Canada, the SAR limit for mobile
phones used by the public is 1.6 watts/kilogram (W/kg)
averaged over one gram of tissue. The standard
incorporates a substantial ma gin of safety to give
additional protection for the public and to account for any
variations in measurements.
E760.book Page 31 Tuesday, May 23, 2006 1:59 PM
58
Health and safety information
Appendix B: Guide to safe and
responsible wireless phone use
Cellular Telecommunications & Internet Association
“Safety is the most important call you will ever make.”
A guide to safe and responsible wireless phone
use
TENS OF MILLIONS OF PEOPLE IN THE U.S. TODAY
TAKE ADVANTAGE OF THE UNIQUE COMBINATION OF
CONVENIENCE, SAFETY AND VALUE DELIVERED BY
THE WIRELESS TELEPHONE. QUITE SIMPLY, THE
WIRELESS PHONE GIVES PEOPLE THE POWERFUL
ABILITY TO COMMUNICATE BY VOICE-ALMOST
ANYWHERE, ANYTIME-WITH THE BOSS, WITH A
CLIENT, WITH THE KIDS, WITH EMERGENCY
PERSONNEL OR EVEN WITH THE POLICE. EACH YEAR,
AMERICANS MAKE BILLIONS OF CALLS FROM THEIR
WIRELESS PHONES, AND THE NUMBERS ARE RAPIDLY
GROWING.
But an important responsibility accompanies those
benefits, one that every wireless phone user must uphold.
When driving a car, driving is your first responsibility. A
wireless phone can be an invaluable tool, but good
judgment must be exercised at all times while driving a
motor vehicle whether on the phone or not.
The basic lessons are ones we all learned as teenagers.
Driving requires alertness, caution and courtesy. It
requires a heavy dose of basic common sense-keep your
head up, keep your eyes on the road, check your mirrors
frequently and watch out for other drivers.
It requires obeying all traffic signs and signals and staying
within the speed limit. It means using seat belts and
requiring other passengers to do the same.
But with wireless phone use, driving safely means a little
more. This brochure is a call to wireless phone users
everywhere to make safety their first priority when behind
the wheel of a car. Wireless telecommunications is keeping
us in touch, simplifying our lives, protecting us in
emergencies and providing opportunities to help others in
need. When it comes to the use of wireless phones, safety
is your most important call.
E760.book Page 32 Tuesday, May 23, 2006 1:59 PM
Health and safety information
59
Wireless phone “Safety Tips”
Below are safety tips to follow while driving and using a
wireless phone which should be easy to remember:
Get to know your wireless phone and its features such as
speed dial and redial. Carefully read your instruction
manual and learn to take advantage of valuable features
most phones offer, including automatic redial and memory.
Also, work to memorize the phone keypad so you can use
the speed dial function without taking your attention off
the road.
When available, use a hands free device. A number of
hands free wireless phone accessories are readily available
today. Whether you choose an installed mounted device
for your wireless phone or a speaker phone accessory,
take advantage of these devices if available to you.
Position your wireless phone within easy reach. Make sure
you place your wireless phone within easy reach and
where you can grab it without removing your eyes from
the road. If you get an incoming call at an inconvenient
time, if possible, let your voice mail answer it for you.
Suspend conversations during hazardous driving
conditions or situations. Let the person you are speaking
with know you are driving; if necessary, suspend the call
in heavy traffic or hazardous weather conditions. Rain,
sleet, snow and ice can be hazardous, but so is heavy
traffic. As a driver, your first responsibility is to pay
attention to the road.
Do not take notes or look up phone numbers while driving.
If you are reading an address book or business card, or
writing a “to do” list while driving a car, you are not
watching where you are going. It’s common sense. Don’t
get caught in a dangerous situation because you are
reading or writing and not paying attention to the road or
nearby vehicles.
Dial sensibly and assess the traffic; if possible, place calls
when you are not moving or before pulling into traffic. Try
to plan your calls before you begin your trip or attempt to
coincide your calls with times you may be stopped at a
stop sign, red light or otherwise stationary. But if you need
to dial while driving, follow this simple tip-dial only a few
numbers, check the road and your mirrors, then continue.
Do not engage in stressful or emotional conversations that
may be distracting. Stressful or emotional conversations
and driving do not mix-they are distracting and even
dangerous when you are behind the wheel of a car. Make
E760.book Page 33 Tuesday, May 23, 2006 1:59 PM
60
Health and safety information
people you are talking with aware you are driving and if
necessary, suspend conversations which have the
potential to divert your attention from the road.
Use your wireless phone to call for help. Your wireless
phone is one of the greatest tools you can own to protect
yourself and your family in dangerous situations-with your
phone at your side, help is only three numbers away. Dial
9-1-1 or other local emergency number in the case of fire,
traffic accident, road hazard or medical emergency.
Remember, it is a free call on your wireless phone!
Use your wireless phone to help others in emergencies.
Your wireless phone provides you a perfect opportunity to
be a “Good Samaritan” in your community. If you see an
auto accident, crime in progress or other serious
emergency where lives are in danger, call 9-1-1 or other
local emergency number, as you would want others to do
for you.
Call roadside assistance or a special wireless non
emergency assistance number when necessary. Certain
situations you encounter while driving may require
attention, but are not urgent enough to merit a call for
emergency services. But you still can use your wireless
phone to lend a hand. If you see a broken-down vehicle
posing no serious hazard, a broken traffic signal, a minor
traffic accident where no one appears injured or a vehicle
you know to be stolen, call roadside assistance or other
special non-emergency wireless number.
Careless, distracted individuals and people driving
irresponsibly represent a hazard to everyone on the road.
Since 1984, the Cellular Telecommunications Industry
Association and the wireless industry have conducted
educational outreach to inform wireless phone users of
their responsibilities as safe drivers and good citizens. As
we approach a new century, more and more of us will take
advantage of the benefits of wireless telephones.
And, as we take to the roads, we all have a responsibility
to drive safely.
“The wireless industry reminds you to use your phone
safely when driving.”
Cellular Telecommunications & Internet Association For
more information, please call 1-888-901-SAFE.
For updates: http://www.wow-com.com/consumer/issues/
driving/articles.cfm?ID =85
E760.book Page 34 Tuesday, May 23, 2006 1:59 PM
Health and safety information
61
Appendix C: consumer update
on wireless phones
U.S. Food and Drug Administration
What kinds of phones are the subject of this update?
The term wireless phone refers here to hand-held wireless
phones with built-in antennas, often called cell, mobile, or
PCS phones. These types of wireless phones can expose
the user to measurable radio frequency energy (RF)
because of the short distance between the phone and the
user s head. These RF exposures are limited by Federal
Communications Commission safety guidelines that were
developed with the advice of FDA and other federal health
and safety agencies. When the phone is located at greater
distances from the user, the exposure to RF is drastically
lower because a person’s RF exposure decreases rapidly
with increasing distance from the source. The so-called
“cordless phones,” which have a base unit connected to
the telephone wiring in a house, typically operate at far
lower power levels, and thus produce RF exposures well
within the FCC’s compliance limits.
Do wireless phones pose a health hazard?
The available scientific evidence does not show that any
health problems are associated with using wireless
phones. There is no proof, however, that wireless phones
are absolutely safe. Wireless phones emit low levels of
radio frequency energy (RF) in the microwave range while
being used. They also emit very low levels of RF when in
the stand-by mode. Whereas high levels of RF can produce
health effects (by heating tissue), exposure to low level RF
that does not produce heating effects causes no known
adverse health effects. Many studies of low level RF
exposures have not found any biological effects. Some
studies have suggested that some biological effects may
occur, but such findings have not been confirmed by
additional research. In some cases, other researchers
have had difficulty in reproducing those studies, or in
determining the reasons for inconsistent results.
What is FDA’s role concerning the safety of wireless
phones?
Under the law, FDA does not review the safety of radiation
emitting consumer products such as wireless phones
before they can be sold, as it does with new drugs or
medical devices. However, the agency has authority to
take action if wireless phones are shown to emit radio
frequency energy (RF) at a level that is hazardous to the
user. In such a case, FDA could require the manufacturers
of wireless phones to notify users of the health hazard and
E760.book Page 35 Tuesday, May 23, 2006 1:59 PM
62
Health and safety information
to repair, replace or recall the phones so that the hazard
no longer exists.
Although the existing scientific data do not justify FDA
regulatory actions, FDA has urged the wireless phone
industry to take a number of steps, including the
following:
Support needed research into possible biological effects of
RF of the type emitted by wireless phones;
Design wireless phones in a way that minimizes any RF
exposure to the user that is not necessary for device
function; and
Cooperate in providing users of wireless phones with the
best possible information on possible effects of wireless
phone use on human health
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at the
federal level. The following agencies belong to this
working group:
National Institute for Occupational Safety and Health
Environmental Protection Agency Federal Communications
Commission
Occupational Safety and Health Administration
National Telecommunications and Information
Administration
The National Institutes of Health participates in some
interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless phones
with the Federal Communications Commission (FCC). All
phones that are sold in the United States must comply
with FCC safety guidelines that limit RF exposure. FCC
relies on FDA and other health agencies for safety
questions about wireless phones.
FCC also regulates the base stations that the wireless
phone networks rely upon. While these base stations
operate at higher power than do the wireless phones
themselves, the RF exposures that people get from these
base stations are typically thousands of times lower than
those they can get from wireless phones. Base stations
are thus not the primary subject of the safety questions
discussed in this document.
What is FDA doing to find out more about the possible
health effects of wireless phone RF?
E760.book Page 36 Tuesday, May 23, 2006 1:59 PM
Health and safety information
63
FDA is working with the U.S. National Toxicology Program
and with groups of investigators around the world to
ensure that high priority animal studies are conducted to
address important questions about the effects of exposure
to radio frequency energy (RF).
FDA has been a leading participant in the World Health
Organization International Electromagnetic Fields (EMF)
Project since its inception in 1996. An influential result of
this work has been the development of a detailed agenda
of research needs that has driven the establishment of
new research programs around the world. The Project has
also helped develop a series of public information
documents on EMF issues.
FDA and the Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative Research
and Development Agreement (CRADA) to do research on
wireless phone safety. FDA provides the scientific
oversight, obtaining input from experts in government,
industry, and academic organizations. CTIA-funded
research is conducted through contracts to independent
investigators. The initial research will include both
laboratory studies and studies of wireless phone users.
The CRADA will also include a broad assessment of
additional research needs in the context of the latest
research developments around the world.
What steps can I take to reduce my exposure to radio
frequency energy from my wireless phone?
If there is a risk from these products—and at this point we
do not know that there is—it is probably very small. But if
you are concerned about avoiding even potential risks,
you can take a few simple steps to minimize your
exposure to radio frequency energy (RF). Since time is a
key factor in how much exposure a person receives,
reducing the amount of time spent using a wireless phone
will reduce RF exposure.
If you must conduct extended conversations by wireless
phone every day, you could place more distance between
your body and the source of the RF, since the exposure
level drops off dramatically with distance. For example,
you could use a headset and carry the wireless phone
away from your body or use a wireless phone connected to
a remote antenna
Again, the scientific data do not demonstrate that wireless
phones are harmful. But if you are concerned about the RF
exposure from these products, you can use measures like
E760.book Page 37 Tuesday, May 23, 2006 1:59 PM
64
Health and safety information
those described above to reduce your RF exposure from
wireless phone use.
What about children using wireless phones?
The scientific evidence does not show a danger to users of
wireless phones, including children and teenagers. If you
want to take steps to lower exposure to radio frequency
energy (RF), the measures described above would apply
to children and teenagers using wireless phones. Reducing
the time of wireless phone use and increasing the distance
between the user and the RF source will reduce RF
exposure.
Some groups sponsored by other national governments
have advised that children be discouraged from using
wireless phones at all. For example, the government in the
United Kingdom distributed leaflets containing such a
recommendation in December 2000. They noted that no
evidence exists that using a wireless phone causes brain
tumors or other ill effects. Their recommendation to limit
wireless phone use by children was strictly precautionary;
it was not based on scientific evidence that any health
hazard exists.
Do hands-free kits for wireless phones reduce risks from
exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that hands-free kits reduce risks. Hands-free kits
can be used with wireless phones for convenience and
comfort. These systems reduce the absorption of RF
energy in the head because the phone, which is the source
of the RF emissions, will not be placed against the head.
On the other hand, if the phone is mounted against the
waist or other part of the body during use, then that part
of the body will absorb more RF energy. Wireless phones
marketed in the U.S. are required to meet safety
requirements regardless of whether they are used against
the head or against the body. Either configuration should
result in compliance with the safety limit.
Do wireless phone accessories that claim to shield the
head from RF radiation work?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that accessories that claim to shield the head from
those emissions reduce risks. Some products that claim to
shield the user from RF absorption use special phone
cases, while others involve nothing more than a metallic
accessory attached to the phone. Studies have shown that
these products generally do not work as advertised. Unlike
E760.book Page 38 Tuesday, May 23, 2006 1:59 PM
Health and safety information
65
“hand-free” kits, these so-called “shields” may interfere
with proper operation of the phone. The phone may be
forced to boost its power to compensate, leading to an
increase in RF absorption. In February 2002, the Federal
trade Commission (FTC) charged two companies that sold
devices that claimed to protect wireless phone users from
radiation with making false and unsubstantiated claims.
According to FTC, these defendants lacked a reasonable
basis to substantiate their claim.
What about wireless phone interference with medical
equipment?
Radio frequency energy (RF) from wireless phones can
interact with some electronic devices. For this reason, FDA
helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted cardiac
pacemakers and defibrillators from wireless telephones.
This test method is now part of a standard sponsored by
the Association for the Advancement of Medical
instrumentation (AAMI). The final draft, a joint effort by
FDA, medical device manufacturers, and many other
groups, was completed in late 2000. This standard will
allow manufacturers to ensure that cardiac pacemakers
and defibrillators are safe from wireless phone EMI.
FDA has tested hearing aids for interference from
handheld wireless phones and helped develop a voluntary
standard sponsored by the Institute of Electrical and
Electronic Engineers (IEEE). This standard specifies test
methods and performance requirements for hearing aids
and wireless phones so that no interference occurs when a
person uses a compatible phone and a compatible hearing
aid at the same time. This standard was approved by the
IEEE in 2000.
FDA continues to monitor the use of wireless phones for
possible interactions with other medical devices. Should
harmful interference be found to occur, FDA will conduct
testing to assess the interference and work to resolve the
problem.
What are the results of the research done already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws in their
research methods. Animal experiments investigating the
effects of radio frequency energy (RF) exposures
characteristic of wireless phones have yielded conflicting
results that often cannot be repeated in other laboratories.
A few animal studies, however, have suggested that low
levels of RF could accelerate the development of cancer in
laboratory animals. However, many of the studies that
E760.book Page 39 Tuesday, May 23, 2006 1:59 PM
66
Health and safety information
showed increased tumor development used animals that
had been genetically engineered or treated with cancer
causing chemicals so as to be pre-disposed to develop
cancer in the absence of RF exposure. Other studies
exposed the animals to RF for up to 22 hours per day.
These conditions are not similar to the conditions under
which people use wireless phones, so we don t know with
certainty what the results of such studies mean for human
health.
Three large epidemiology studies have been published
since December 2000. Between them, the studies
investigated any possible association between the use of
wireless phones and primary brain cancer, gioma,
meningioma, or acoustic neuroma, tumors of the brain or
salivary gland, leukemia, or other cancers. None of the
studies demonstrated the existence of any harmful health
effects from wireless phone RF exposures. However, none
of the studies can answer questions about long-term
exposures, since the average period of phone use in these
studies was around three years.
What research is needed to decide whether RF exposure
from wireless phones poses a health risk?
A combination of laboratory studies and epidemiological
studies of people actually using wireless phones would
provide some of the data that are needed. Lifetime animal
exposure studies could be completed in a few years.
However, very large numbers of animals would be needed
to provide reliable proof of a cancer promoting effect if
one exists. Epidemiological studies can provide data that
is directly applicable to human populations, but 10 or
more years follow-up may be needed to provide answers
about some health effects, such as cancer. This is because
the interval between the time of exposure to a cancer-
causing agent and the time tumors develop - if they do -
may be many, many years. The interpretation of
epidemiological studies is hampered by difficulties in
measuring actual RF exposure during day-to-day use of
wireless phones. Many factors affect this measurement,
such as the angle at which the phone is held, or which
model of phone is used.
Which other federal agencies have responsibilities related
to potential RF health effects?
Additional information on the safety of RF exposures from
various sources can be obtained from the following
organizations.
E760.book Page 40 Tuesday, May 23, 2006 1:59 PM
Health and safety information
67
FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
Occupational Safety and Health Administration’s (OSHA):
http://www.osha-slc.gov/SLTC/radiofrequencyradiation/
index.html
National Institute for Occupational Safety and Health
(NIOSH):
http://www.cdc.gov/niosh/emfpg.html
World health Organization (WHO):
http://www.who.int/peh-emf/
International Commission on Non-Ionizing Radiation
Protection:
http://www.icnirp.de
National Radiation Protection Board (UK):
http://www.nrpb.org.uk
Updated 4/3/2002: US Food and Drug Administration
http://www.fda.gov/cellphones
STANDARD LIMITED WARRANTY
What is Covered and For How Long?
SAMSUNG
TELECOMMUNICATIONS AMERICA, L.P. (SAMSUNG)
warrants to the original purchaser ("Purchaser") that
SAMSUNG’s Phones and accessories ("Products") are
free from defects in material and workmanship under
normal use and service for the period commencing
upon the date of purchase and continuing for the
following specified period of time after that date:
Phone 1 Year
Batteries 1 Year
Leather Case/Pouch 90 Days
Other Phone Accessories 1 Year
What is Not Covered?
This Limited Warranty is
conditioned upon proper use of Product by Purchaser.
This Limited Warranty does not cover: (a) defects or
damage resulting from accident, misuse, abuse,
neglect, unusual physical, electrical or
electromechanical stress, or modification of any part
of Product, including antenna, or cosmetic damage;
(b) equipment that has the serial number removed or
made illegible; (c) any plastic surfaces or other
E760.book Page 41 Tuesday, May 23, 2006 1:59 PM
68
Health and safety information
externally exposed parts that are scratched or
damaged due to normal use; (d) malfunctions
resulting from the use of Product in conjunction with
accessories, products, or ancillary/peripheral
equipment not furnished or approved by SAMSUNG;
(e) defects or damage from improper testing,
operation, maintenance, installation, or adjustment;
(f) installation, maintenance, and service of Product,
or (g) Product used or purchased outside the United
States or Canada.
This Limited Warranty covers batteries only if battery
capacity falls below 80% of rated capacity or the
battery leaks, and this Limited Warranty does not
cover any battery if (i) the battery has been charged
by a battery charger not specified or approved by
SAMSUNG for charging the battery, (ii) any of the
seals on the battery are broken or show evidence of
tampering, or (iii) the battery has been used in
equipment other than the SAMSUNG phone for which
it is specified.
What are SAMSUNG’s Obligations?
During the
applicable warranty period, SAMSUNG will repair or
replace, at SAMSUNG’s sole option, without charge to
Purchaser, any defective component part of Product.
To obtain service under this Limited Warranty,
Purchaser must return Product to an authorized phone
service facility in an adequate container for shipping,
accompanied by Purchaser’s sales receipt or
comparable substitute proof of sale showing the date
of purchase, the serial number of Product and the
sellers’ name and address. To obtain assistance on
where to deliver the Product, call Samsung Customer
Care at 1-888-987-4357. Upon receipt, SAMSUNG will
promptly repair or replace the defective Product.
SAMSUNG may, at SAMSUNG’s sole option, use
rebuilt, reconditioned, or new parts or components
when repairing any Product or replace Product with a
rebuilt, reconditioned or new Product. Repaired/
replaced leather cases and pouches will be warranted
for a period of ninety (90) days. All other repaired/
replaced Product will be warranted for a period equal
to the remainder of the original Limited Warranty on
the original Product or for 90 days, whichever is
longer. All replaced parts, components, boards and
equipment shall become the property of SAMSUNG.
If SAMSUNG determines that any Product is not
covered by this Limited Warranty, Purchaser must pay
E760.book Page 42 Tuesday, May 23, 2006 1:59 PM
Health and safety information
69
all parts, shipping, and labor charges for the repair or
return of such Product.
What Are the Limits On SAMSUNG’s Liability?
EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY
CONTAINED HEREIN, PURCHASER TAKES THE
PRODUCT “AS IS,” AND SAMSUNG MAKES NO
WARRANTY OR REPRESENTATION AND THERE ARE NO
CONDITIONS, EXPRESS OR IMPLIED, STATUTORY OR
OTHERWISE, OF ANY KIND WHATSOEVER WITH
RESPECT TO THE PRODUCT, INCLUDING BUT NOT
LIMITED TO:
THE MERCHANTABILITY OF THE PRODUCT OR ITS
FITNESS FOR ANY PARTICULAR PURPOSE OR USE;
WARRANTIES OF TITLE OR NON-INFRINGEMENT;
DESIGN, CONDITION, QUALITY, OR PERFORMANCE OF
THE PRODUCT;
THE WORKMANSHIP OF THE PRODUCT OR THE
COMPONENTS CONTAINED THEREIN; OR
COMPLIANCE OF THE PRODUCT WITH THE
REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION
OR CONTRACT PERTAINING THERETO.
NOTHING CONTAINED IN THE INSTRUCTION MANUAL
SHALL BE CONSTRUED TO CREATE AN EXPRESS
WARRANTY OF ANY KIND WHATSOEVER WITH
RESPECT TO THE PRODUCT. ALL IMPLIED
WARRANTIES AND CONDITIONS THAT MAY ARISE BY
OPERATION OF LAW, INCLUDING IF APPLICABLE THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY
LIMITED TO THE SAME DURATION OF TIME AS THE
EXPRESS WRITTEN WARRANTY STATED HEREIN.
SOME STATES/PROVINCES DO NOT ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY
TO YOU. IN ADDITION, SAMSUNG SHALL NOT BE
LIABLE FOR ANY DAMAGES OF ANY KIND RESULTING
FROM THE PURCHASE, USE, OR MISUSE OF, OR
INABILITY TO USE THE PRODUCT OR ARISING
DIRECTLY OR INDIRECTLY FROM THE USE OR LOSS
OF USE OF THE PRODUCT OR FROM THE BREACH OF
THE EXPRESS WARRANTY, INCLUDING INCIDENTAL,
SPECIAL, CONSEQUENTIAL OR SIMILAR DAMAGES,
OR LOSS OF ANTICIPATED PROFITS OR BENEFITS, OR
FOR DAMAGES ARISING FROM ANY TORT (INCLUDING
NEGLIGENCE OR GROSS NEGLIGENCE) OR FAULT
COMMITTED BY SAMSUNG, ITS AGENTS OR
E760.book Page 43 Tuesday, May 23, 2006 1:59 PM
70
Health and safety information
EMPLOYEES, OR FOR ANY BREACH OF CONTRACT OR
FOR ANY CLAIM BROUGHT AGAINST PURCHASER BY
ANY OTHER PARTY. SOME STATES/PROVINCES DO
NOT ALLOW THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE
ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY
TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS,
WHICH VARY FROM STATE TO STATE/PROVINCE TO
PROVINCE.
THIS LIMITED WARRANTY SHALL NOT
EXTEND TO ANYONE OTHER THAN THE ORIGINAL
PURCHASER OF THIS PRODUCT AND STATES
PURCHASER’S EXCLUSIVE REMEDY. IF ANY PORTION
OF THIS LIMITED WARRANTY IS HELD ILLEGAL OR
UNENFORCEABLE BY REASON OF ANY LAW, SUCH
PARTIAL ILLEGALITY OR UNENFORCEABILITY SHALL
NOT AFFECT THE ENFORCEABILITY FOR THE
REMAINDER OF THIS LIMITED WARRANTY WHICH
PURCHASER ACKNOWLEDGES IS AND WILL ALWAYS
BE CONSTRUED TO BE LIMITED BY ITS TERMS OR AS
LIMITED AS THE LAW PERMITS.
THE PARTIES UNDERSTAND THAT THE PURCHASER
MAY USE THIRD-PARTY SOFTWARE OR EQUIPMENT IN
CONJUNCTION WITH THE PRODUCT. SAMSUNG
MAKES NO WARRANTIES OR REPRESENTATIONS AND
THERE ARE NO CONDITIONS, EXPRESS OR IMPLIED,
STATUTORY OR OTHERWISE, AS TO THE QUALITY,
CAPABILITIES, OPERATIONS, PERFORMANCE OR
SUITABILITY OF ANY THIRD-PARTY SOFTWARE OR
EQUIPMENT, WHETHER SUCH THIRD-PARTY
SOFTWARE OR EQUIPMENT IS INCLUDED WITH THE
PRODUCT DISTRIBUTED BY SAMSUNG OR
OTHERWISE, INCLUDING THE ABILITY TO INTEGRATE
ANY SUCH SOFTWARE OR EQUIPMENT WITH THE
PRODUCT.
THE QUALITY, CAPABILITIES, OPERATIONS,
PERFORMANCE AND SUITABILITY OF ANY SUCH
THIRD-PARTY SOFTWARE OR EQUIPMENT LIE SOLELY
WITH THE PURCHASER AND THE DIRECT VENDOR,
OWNER OR SUPPLIER OF SUCH THIRD-PARTY
SOFTWARE OR EQUIPMENT, AS THE CASE MAY BE.
This Limited Warranty allocates risk of Product failure
between Purchaser and SAMSUNG, and SAMSUNG’s
Product pricing reflects this allocation of risk and the
limitations of liability contained in this Limited
Warranty. The agents, employees, distributors, and
dealers of SAMSUNG are not authorized to make
modifications to this Limited Warranty, or make
E760.book Page 44 Tuesday, May 23, 2006 1:59 PM
Health and safety information
71
additional warranties binding on SAMSUNG.
Accordingly, additional statements such as dealer
advertising or presentation, whether oral or written,
do not constitute warranties by SAMSUNG and should
not be relied upon.
Samsung Telecommunications America (STA), Inc.
1301 East Lookout Drive
Richardson, TX 75082
Phone: 1-800-SAMSUNG
Phone: 1-888-987-HELP (4357)
©2005 Samsung Telecommunications America. All
rights reserved.
No reproduction in whole or in part allowed without
prior written approval.
Specifications and availability subject to change
without notice. [080802]
E760.book Page 45 Tuesday, May 23, 2006 1:59 PM
