Users Manual
DIGITAL CELLULAR
TELEPHONE
SCH-N182
User’s Manual
Printed in Korea
Code No. : GH68-00000A
English. 2002/04. Rev.1.0
World Wide Web
http://www.samsungmobile.com
Please read this manual before operating your
phone, and keep it for future reference .
Safety Quick Guide
Read these guidelines before using your wireless
phone. Failure to comply with these guidelines may
be dangerous or illegal. For more detailed safety
information, see “Health and Safety Information” on
page xx.
Road safety comes first
Do not use a hand-held phone while driving; park the
vehicle first.
Switch off when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off on aircraft
Wireless phones can cause interference. Using them
on aircraft is both illegal and dangerous.
Switch off in hospital
Switch off your phone near medical equipment.
Follow any regulations or rules in force.
Interference
All wireless phones may get interference which
could affect performance.
Respect special regulations
Follow any special regulations in force in any area
and always switch off your phone whenever it is
forbidden to use it, or when it may cause
interference or danger (in a hospital for example).
1
YOUR PHONE
Key Descriptions................................................................................... 5
Display ................................................................................................ 6
Service light .......................................................................................... 8
GETTING STARTED
Charging a Battery .................................................................................9
Low Battery Indicator ..........................................................................10
Switching the Phone On/Off ................................................................11
CALL FUNCTIONS
Making a Call ......................................................................................12
Answering a Call..................................................................................18
In-Call Options ....................................................................................19
Using Caller ID ....................................................................................20
Viewing Missed Calls ...........................................................................21
Three-Way Calling ...............................................................................22
Call Waiting ........................................................................................23
Call Forwarding ....................................................................................23
Adjusting the Volume...........................................................................24
Quick Switching to Slient Mode ............................................................24
ENTERING TEXT
Changing Text Input Mode ...................................................................25
T9 Mode ..............................................................................................26
Alpha Mode ..........................................................................................27
Symbol Mode ......................................................................................29
Number Mode .....................................................................................29
Table of Contents
Radio frequency exposure information
The design of this phone complies with the ACA
requirements for RF Exposure. To maintain compliance
with the requirements, use the Samsung supplied or
approved accessory. Use of non-approved accessories
may violate the requirements.
Use sensibly
Use only in the normal position (to ear). Avoid unnessary
contact with the antenna when the phone is switched
on.
Accessories and batteries
Use only SAMSUNG-approved accessories and
batteries.
Use qualified service
Only qualified service personnel may install or repair
your phone.
2 3
USING THEMENUS
Accessing a Menu Functions by Scrolling .............................................. 30
Accessing a Menu Functions by Using its Shortcut.................................. 31
Your Phone’s Main Menu .................................................................... 32
CALLS
Outgoing (MENU 1-1) ................................................................... 34
Incoming (MENU 1-2) ................................................................... 35
Missed (MENU 1-3) ....................................................................... 36
Erase Logs (MENU 1-4) .................................................................. 37
Airtime (MENU 1-5)....................................................................... 37
PHONE BOOK
Find (MENU 2-1) ........................................................................... 38
Add Entry(MENU 2-2) .................................................................. 39
Find Entry (MENU 2-3) ................................................................. 42
Relation Search (MENU 2-4) ........................................................... 42
Add E-mail (MENU 2-5) .................................................................. 43
WEB
Get In Web (MENU 3-1) ................................................................ 44
Prompt (MENU 3-2) ...................................................................... 45
SCHEDULER
Today (MENU 4-1) ........................................................................ 46
View Month (MENU 4-2) .............................................................. 47
Jump To Date (MENU 4-3) ............................................................ 49
To Do List (MENU 4-4) ................................................................... 49
Count Down (MENU 4-5) ................................................................ 50
World Time (MENU 4-6) ................................................................. 52
Calculator (MENU 4-7) ................................................................... 52
Alarm (MENU 4-8) ......................................................................... 53
SOUNDS
Ringer Vol (MENU 5-1) ................................................................. 54
Sounds Type (MENU 5-2) .............................................................. 55
Alerts Set (MENU 5-3) .................................................................. 56
DISPLAY
Backlight (MENU 6-1) ................................................................... 57
Banner (MENU 6-2) ...................................................................... 58
Animation (MENU 6-3) ................................................................. 58
My Phone Number (MENU 6-4) ..................................................... 59
Language (MENU 6-5) .................................................................. 59
Set Time (MENU 6-6) .................................................................... 59
Auto Hyphen (MENU 6-7) ............................................................. 60
Version (MENU 6-8) ...................................................................... 60
Menu Style (MENU 6-9) ................................................................ 60
GAME.................................................................................................61
SETUP
Auto Retry (MENU 8-1) ................................................................. 62
Auto Answer (MENU 8-2) .............................................................. 62
Answer Mode (MENU 8-3) ............................................................. 63
Tone Length (MENU 8-4) ............................................................... 63
Set Nam (MENU 8-5) .................................................................... 64
Set System (MENU 8-6) ................................................................ 64
Data/Fax (MENU 8-7) .................................................................. 65
Set Network (MENU 8-8) .............................................................. 67
Whisper Mode (MENU 8-9) ........................................................... 67
Key Guard (MENU 8-0) ................................................................. 68
5
MENU : Enters the menu facility. Also, scrolls
through the menu options.
: In the menu facility, scroll through the
menu tions and phonebook memory.
Key Functions
OK :In the menu facility, selects a menu function or
stores information that you have entered (such
as a name) in the phone memory. In Standby
mode, enters the Mail Kit Menu.
Your Phone
Key Descriptions
CLR : Deletes characters from the display.
In the menu facility, returns to the previous
menu level.
In Standby mode, quickly enters the Web
Menu.
Makes or answers a call.
In Standby mode, redials the last outgoing
number when pressed twice.
Ends a call. Also switches the phone on and
off when pressed and held.
In the menu facility, returns to Standby mode
and cancels your input.
Volume :During a call, adjusts the voice
volume. In Standby mode with the phone open,
adjusts the ringer volume. In the menu facility,
scrolls through the menu options.
4
SECURITY
Lock Mode (MENU 9-1) ................................................................. 69
Restrict (MENU 9-2) ...................................................................... 70
Lockcode (MENU 9-3) ................................................................... 70
Emergency Number (MENU 9-4) ................................................... 70
Send PIN (MENU 9-5) ................................................................... 71
Clear Memory (MENU 9-6) ........................................................... 72
Reset Phneo (MENU 9-7) .............................................................. 72
Voice Privacy (MENU 9-8) ............................................................. 72
MESSAGE
New Message (MENU -1) .......................................................73
Voice (MENU -2) ................................................................... 75
Inbox (MENU -3) ................................................................. 76
Outbox (MENU -4) ................................................................. 77
Filed Msg (MENU -5) .............................................................. 78
Web Alerts (MENU -6) ............................................................ 78
Erase Msg (MENU -7) ............................................................. 78
Meg Setup (MENU -8) ............................................................ 78
HEALTH AND SAFETY INFORMATION.............................................81
GLOSSARY.........................................................................................93
76
Your Phone
New Message: Appears when a new text
message has been received.
Battery strength: Shows the level of your
battery. The more bars you see, the more
power you have left.
Vibrator on: Appears when a vibrate mode
is on. An incoming call will vibrate the
phone rather than ring it.
Roaming: Appears When you are out of
your home area and have registered with a
different network (when travelling in other
countries, for example).
Alarm on: appears when you set an alarm.
Your Phone
Display
Layout
The display comprises two areas; an upper line of fixed
icons, and the lower text and graphic area. The
following icons display at power-on:
Icons
Text and
graphic area
Signal strength : Shows the received
signal strength. The greater the number of
bars, the better the signal strength.
Icons
Service: Appears when a call is in
progress.
No service indicator: Appears when you
are outside a service area. When it
appears, you cannot make or receive calls.
Wait a little while for a signal or move into
an open area.
*: Use this key for special star calling feature.
Key Functions
#:When held down to toggle between the silent
mode on and off
Key Descriptions (continue...)
8
Your Phone
Backlight
The display is illuminated by a backlight. When you
press any key, the backlight illuminates. It turns off if no
key is pressed within a given period of time.
Service Light
The service light is at the top right of the phone. It
flashes to indicate incoming call or message. Also, the
service light flashes for a few seconds when you turn on
the phone.
9
Getting Started
Charging a Battery
Your phone is powered by a rechargeable Li-ion battery.
A travel adapter is provided with your phone. Use only
approved batteries and chargers. Ask your local
SAMSUNG dealer for further details.
The phone can be used while the battery is charging.
N o t e: You must fully charge the battery before using
your phone for the first time.
1. Connect the lead from the travel adapter to the
bottom of the phone. Check that the arrow on
the lead connector is facing towards the front of the
phone.
2. Connect the adapter to a standard AC wall outlet.
The LEDs on the front of the charger indicate the following:
Red indicates that the battery is charg i n g .
G r een indicates that the battery is fully charg e d .
Yellow indicates that the battery is operating at a
t e m p e r a t u re that is too high or too low, or that something
is not plugged in corre c t l y. Check the charger and battery
for proper connections.
11
Getting Started
Switching the Phone On/Off
1. Open the phone.
2. Hold down the key for more than one second to
switch the phone on.
The service light on the right of the phone flashes,
and an alert sounds. When the system locates
services, the greeting message displays along with
the date and time.
If the phone is out of service, the icon appears in
the display. In this case, you cannot place and receive
calls. You can try again later when service is
available.
3. When you wish to switch the phone off, hold down
the key for more than two seconds.
10
Getting Started
3. When charging is finished, disconnect the adapter
from the power outlet.
Disconnect the adapter from the phone by pressing
the grey tabs on either side of the connector and
pulling the connector out.
Low Battery Indicator
You can easily tell if your battery needs to be recharged
by checking the battery strength indicator in the
upper-right corner of your phone’s display. The presence
of all three bars indicates a full charge, two bars
indicates a smaller charge, and one bar indicates an
even smaller charge. No bars (the battery icon is empty)
means your battery must be charged.
When the battery charge level gets low, the battery
sensor blinks an empty battery icon ( ), sounds a
tone. If the battery level gets too low, the phone will
turn off automatically. Unfortunately, if this happens
you’ll lose whatever you are doing, including dropping
your call. Watch the battery strength icon and make sure
your battery is adequately charged.
13
Getting Started
12
Redialing the Last Call
To redial the last call you made, press twice
quickly.
Your phone stores the last 10 incoming or outgoing
calls. To recall any of these numbers, proceed as
follows.
1. If there are any characters on the display, clear the
display by holding down CLR for more than one
second.
2. Press . The list of outgoing calls are displayed.
3. Use the navigation key to scroll through the list until
you select the required name or number.
4. Press to dial the number displayed.
Call Functions
Call Functions
Making a Call
In Standby mode, key in the area code and phone number
and press the key.
Correcting the Number
To clear ... Then ....
The last digit displayed Press the CLR key.
The whole display Hold down theCLR key for
more than one second.
Ending a Call
When you have finished your call, briefly press or
close the phone.
If you press , the call time (length of the call)
displays briefly and the phone returns to Standby mode.
15
Call Functions
14
Call Functions
Speed Dialing
Once you have stored phone numbers in the phone book
memory, you can dial them easily whenever you want.
You can dial the stored phone number automatically
without pressing the key. See below.
One-Touch Dial
Memory locations 01 through 09 are special one-touch
locations. You can dial the phone numbers stored in the
Phone Book memory from 01 through 09 simply by
pressing one button.
Press and hold the third digit of the memory location
containing the number to be dialed.
For example: Location no. 009
Press and hold 9.
The number (and name) stored is displayed, then dialed.
Two-Touch Dial
Memory locations 10 through 99 are special two-touch
locations.
Press the second digit briefly, then hold down the third
digit of the memory cell.
For example: Location no. 023
Press 2 briefly and hold down 3.
The number (and name) stored is displayed, then dialed.
Three-Touch Dial
Memory locations 100 through 169 are special three-
touch locations.
Press the first and the second digit briefly, then hold
down the third digit of the memory cell.
For example: Location no. 123
Press 1 and 2 briefly, then hold down 3.
The number (and name) stored is displayed, then dialed.
Pause Dialing
When you call automated system, like banking services,
you are often required to enter a password or account
number. Instead of manually entering the numbers each
time, you can store the numbers in your Phone Book,
separated by special characters called pauses.
Your phone has two pause dialing methods:
• Pause dialing from the Phone Book
• Manual pause dialing
Storing Pauses in a Phone Book Entry
To store a number in your Phone Book that contains
pauses:
1. Enter the phone number you want to store (such as
the bank’s tele-service phone number).
2. Press the MENU key.
The letter “p” displays in the number, meaning that a
hard pause will occur at that point in the dialing
sequence.
N o t e : The digits before the “p” dial the tele-serv i c e .
The “p” stops the dialing and waits for the tele-
s e r vice to prompt you for a number. The number
following the “p” is your account number, PIN, etc.
3. Enter the digits that need to follow the pause (such as
your account number).
4. Store the number in your Phone Book as you normally
would by pressing the OK key and following the
screen prompts.
17
Call Functions
16
Call Functions
Pause Dialing from a Stored Phone Book Entry
1. Dial the number from the Phone Book.
2. Wait for the appropriate prompt for the number (credit
card number, bank account number, etc.).
3. When prompted, press the key to send the DTMF
number that follows your hard pause.
“SENDING DTMF” flashed on the display and the
transmitted tone sounds.
Manual Pause Dialing
You can enter pauses manually during the dialing
process.
1. Enter the phone number of the service you want to
connect to (such as a bank’s tele-service phone
number).
2. Press the MENU key to insert a pause.
The phone displays a “p” meaning a pause. Enter the
number to be sent after the pause and then press the
k e y.
3. After connecting, press the key again to transmit
the additional number at the prompt from the tele-
service.
19
Call Functions
18
Call Functions
In-Call Options
Your phone provides a number of functions that you can
use during a call. You may not utilize all of these
functions at all times. Many of the in-call options are
network services.
Press the MENU key during a call to access the
following in-call options:
Mute/Quit: allows you to switch your phone’s
microphone off, so that the other party cannot hear you.
Example: You wish to say something to another person
in the room but do not want the other party to hear you.
Calls: allows you to access the Calls menu.
Phone Book: allows you to access the Phone Book
menu.
Silent /Quit: does not transmit the key tones. It allows
you to press keys without hearing annoying key tones
during a call.
N o t e: To communicate with answering machines or
computerized telephony systems, the Silent keys o p t i o n
must be disabled.
Send Tel #: sends DTMF tones of your number.
My Phone #: shows your phone number.
Version: allows you to view the software and hardware
version of your phone.
Answering a Call
When somebody calls you, the phone rings and the
phone icon is displayed in the middle of the external
display.
If the caller can be identified, the caller’s phone number
(or name if pre-stored in your Phone Book) is displayed.
If the caller cannot be identified, only the phone icon
appears.
1. To answer a call, open the phone. If the phone is
already open, press the key.
2. End the call by closing the phone or pressing the
key.
N o t e : You can answer a call while using the phone
book or menu features. The current operation will be
i n t e rru p t e d .
21
Call Functions
20
Call Functions
Viewing Missed Calls
Your phone keeps a list of calls that you do not answer
when the phone is on and service is available. The
phone indicates a missed call by displaying a text
notification on the screen. Additionally, if caller
information is available, the screen displays the phone
number of the most recent missed call.
Press to call the displayed number, or the OK key
to save the number in Phone Book.
Dropped Calls
A dropped call can occur during a conversation in
response to a signal fade or leaving a service area. In
this case, the call ends and “Call Dropped” displays.
Failed Calls
A failed call can occur if your phone is out of calling
range or the network is temporarily busy. Your phone
responds to a failed call by displaying an appropriate
message: “Call Failed Out of Range” or “Call Failed
Network Busy.”
Voice Privacy: For this option to work correctly, you
must have the enhanced privacy option set in the
Security option.
SND: sends DTMF tones of the currently displayed
number. DTMF (Dual Tone Multi Frequency) tones can be
used to control electronic phone services such as bank-
by-phone or voicemail. During a call, key in the digits
you want to send as DTMF tones, for example, the bank
account number and password. Then select this in-call
option.
Using Caller ID
This feature tells you who is calling you by displaying
the caller’s number when the phone rings. If a caller’s
name and number are stored in your Phone Book, the
corresponding name is also displayed. If you call
someone who has this feature, your phone number will
be displayed on the their phone.
N o t e : Contact your service provider to setup the Caller
ID serv i c e .
23
Call Functions
22
Call Functions
Call Waiting
Call Waiting lets you receive a second call during
conversation. Your phone notifies you of a call waiting
by beeping an displaying “Call Waiting.”
Your phone provides the option of turning the Call
Waiting feature on and off (if you have subscribed to the
service). Call Waiting is on by default in the phone. If
you choose to have a undisturbed conversation, simply
turn off the feature for the current call.
N o t e : Contact your service provider to activate the Call
Waiting serv i c e .
To answer a waiting call:
1. To answer the call, press . The phone connects
the calling party, and places the current party on hold.
2. Press again to switch between two parties.
N o t e : If you do not respond to a Call Wa i t i n g
notification, the phone will forw a rd the call to voicemail
or another number that you have set up. Contact your
s e r vice provider for more information.
Call Forwarding
This feature provides the option of forwarding incoming
calls to another phone number, even while your phone is
off. Activating Call Forwarding does not affect outgoing
calls made from this phone. Contact your service
provider to activate Call Forwarding.
Three-Way Calling
This feature enables you to conduct conference calls
with two separate parties at the same time. The phone
records each party into the Outgoing Calls Log. Also,
You are billed airtime for each outgoing call separately.
N o t e : Contact your service provider to activate Thre e -
Way Calling.
To place a Three-Way call:
1. During a conversation, press . The phone places
the other party on hold.
2. Enter the phone number for the third party, and then
press . The phone dials the third party.
3. When you are connected to the third party, press
again to begin your three-way call.
If one of the callers (not you) hangs up, you and
remaining caller stay connected. If you initiated the call
and you hang up first, all three parties are disconnected.
2524
Call Functions Entering Text
Changing Text Input Mode
When using your phone, you will need to enter text at
many times. For example, when storing a name in the
Phone Book, creating your personal greeting or
scheduling events in your calendar. You can enter
alphanumeric characters into your phone by using your
phone’s keypad.
When you are prompted to enter text, the current text entry
method will appear in the bottom of the display as T9, Abc,
123 or SYM.
To change the input mode, press
MENU
and then press the
navigation key to scroll to the mode you want and press
OK
.
Adjusting the Volume
During a call, if you want to adjust the voice volume,
use the volume keys on the left side of the phone.
In Standby mode, you can adjust the ring volume using
the same keys.
Quick Switching to Slient Mode
You can quickly switch your phone to the silent mode
with a touch of #. Press and hold the key. The silent
icon appears in the display.
Press and hold # again to exit the silent mode.
This feature is convenient when you are in a hurry to
mute the phone sound such as when in a theater.
27
Entering Text
26
Entering Text
Alpha Mode
When typing in Alpha mode, you should press key
labeled with the required letter:
-Once for the first letter
-Twice for the second letter
-And so on.
For example, you press 2 three times quickly to
display the letter “C” , 5two times quickly to display the
letter “K”. So, this method is called Multi-tap typing.
Refer to the table on next page for the list of characters
assigned on each key.
A B C 2
D E F 3
G H I 4
J K L 5
M N O 6
P Q R S 7
T U V 8
W X Y Z 9
0
(Caps Lock mode)
List of characters available:
1 . - ? ’ : @ ( ) ! / \ ; [ ] ” < > $ ~ _ = + % * & #
Key Characters in the Order Displayed
1
2
3
4
5
6
7
8
9
0
T9 Mode
The T9 predictive text input mode allows you to enter
words easily with a minimum of key presses. As you
press each key, the phone selects a letter that makes up
the word that it thinks you are typing, based on a built-
in dictionary. As a new letter is added, the word
changes based on the key that you have pressed.
1. When you are in the T9 predictive text input mode,
start entering a word by pressing keys 2to 9. Press
each key only once for one letter.
The word that you are typing appears in the display. It
may change with each key that you pre s s .
2. Enter the whole word before editing or deleting any
keystrokes.
3. If the word is correct, start entering the next word.
Otherwise, press 0repeatedly to display alternate
word choices for the keys that you have pressed.
4. Complete each word with a space by pressing the #
key.
To type words not found in the T9 mode, change the text
input mode to the ABC mode.
To delete letters, press CLR. Press and hold down CLR
to erase entire words.
29
Entering Text
28
Entering Text
Symbol Mode
Symbol mode enables you enter symbols into a text
message.
Press the navigation key to display more symbols up to
Set 6.
Press keys corresponding to the desired mark, then the
phone automatically switches back to the text entry
mode used just prior to selecting the Symbol mode.
Number Mode
Number mode enables you to enter numbers into a text
message. Press keys corresponding to the desired digits,
and manually switch back to text entry mode of choice.
To shift the case of the next letter(s) that you type, press
*one or more times. There are three shift states: Lower
Case is indicated by abc in the right corner of the
display, Initial Capital is Abc, and Capitals Lock is ABC.
The cursor moves to the right when you press a different
key. When entering the same letter twice (or a different
letter on the same key), just wait for a few seconds for
the cursor to move right automatically, and then select
the next letter.
If you enter a specific word in this mode the first time,
the word is automatically added to your phone’s
database, and offers the new word as an option for its
keystroke sequence when you are in the T9(English)
mode.
•Press # to insert a space.
• To move the cursor left or right through your text
message, press the navigation key.
• Press CLR one or more times to clear letters to the
left.
Name
MENU:Options
1 2 3 4 5 6 7 8 9
!@#%&* < > -
31
Call Functions
30
Accessing a Menu Functions by Using its
Shortcut
The menu items (menu, submenus and setting options)
are numbered and can be accessed quickly by using
their shortcut number.
1. In Standby mode, press the MENU key to access the
main menu.
2. Within three seconds, key in the first digit of the
shortcut number. Repeat this for each digit of the
shortcut number.
3. Find the setting of your choice pressing the navigation
key and then press the OK key.
N o t e : The numbers assigned to each menu function are
indicated on the list on the next page.
Using the Menus
The phone offers a range of functions that allows you to
tailor the phone to your needs. These functions are
arranged in menus and submenus.
The menus and submenus can be accessed by scrolling
or by using the shortcuts.
Accessing a Menu Functions by Scrolling
1. In Standby mode, press the MENU key to access the
menu facility. Scroll with the navigation key to reach
the desired main menu. Press the OK key.
2. If the menu contains any submenus,find the one you
want by scrolling with the navigation key.
Press the OK key to enter the submenu.
If the menu you have selected contains submenus,
repeat this step.
3. Scroll with the navigation key to find the setting of
your choice. Press the OK key to confirm the chosen
setting.
N o t e s :
• You can re t u rn the previous menu level by pre s s i n g
the C L R k e y.
• You can exit the menu without changing the menu
settings by pressing .
3332
Main menu Main menu 1 Main menu 2
6. Display 1. Backlight
2. Banner
3. Animation 1. Power On
2. Power Off
3. Idle Mode
4. My Phone #
5. Language
6. Set Ti m e
7. Auto Hyphone
8. Ve r s i o n
9. Menu Style
7. Games 1. Flying tight
2. Run for Money
3. Racing
8. Setup 1. Auto Retry
2. Auto Answer
3. Answer Mode
4. Tone Length
5. Set NAM
6. Set System
7. Data/Fax
8. Set Network
9. Whisper Mode
0. Key Guard
9. Security 1. Lock Mode
2. Restict
3. Lock Code
4. Emerg e n c y
5. Send Pen
6. Clear MEM
7. Reset Phone
8. Voice Privacy
Using the Menus
Main menu Main menu 1 Main menu 2
1. Calls 1. Outgoing
2. Incoming
3. Missed
4. Erase History 1. Outgoing
2. Incoming
3. Missed
4. All
5. Air Ti m e 1. Last Call
2. To t a l
3. Life Ti m e
4. Erase To t a l
2. Phone Book 1. Find Name
2. Add Entry
3. Find Entry
4. RelationSrc h
5. Add E-mail
3. We b 1. Get In We b
2. Pro m p t
4. Planner 1. To d a y
2. View Month
3. Jump To Date
4. To Do List
5. Count Down
6. World Ti m e
7. Caldulator
8. Alarm 1. Set
2. Release
5. Sounds 1. Vo l u m e 1. Voice Vo l
2. Calls Vo l
3. Alarm Vo l
4. Key Vo l
5. Message Vo l
2. Sounds Ty p e 1. Calls
2. Alarm
3. Data/Fax In
4. Schedul
3. Alerts Set 1. Minute Beep
2. Serv i c e
3. Connect
4. Disconnect
5. Fade
6. Roam
7. Power On/Off
Your Phone’s Main Menu
Using the Menus
34
C a l l s
You can use the Calls menu to:
• View and dial the last outgoing or incoming numbers.
•Erase the numbers in the Call Log memory.
• View the duration of calls.
Outgoing Menu 1-1
The phone stores up to 10 outgoing calls you dialed.
When you access this menu, the list of outgoing calls is
displayed.
To ... Press ...
Select an entry up or down naviagiton key
Dial the selected entry
View the details OK
When you press the OK key, you can view the date/time
stamp for the selected entry. If there is a Phone Book
match, the name and the label display.
Press the MENU key to access Options. The following
options are available:
Talk: dials the selected number.
Show Entry (or Save if the phone number is not
currently stored in the Phone Book): shows
the phone book entry or stores the number
in the Phone Book.
Prepend:allows to add an area code or feature code to
the number before calling the number.
35
C a l l s
Incoming Menu 1-2
This option lets you view the last 10 calls received. (if
you are subscribed to the caller ID service). When you
access this menu, the last incoming calls are displayed.
To... Press ...
Select entry up or down navigation key
Dial the selected entry
View the details OK
When you press the OK key, you can view the date/time
stamp for the selected entry. If there is a Phone Book
match, the name and the label display.
Press MENU to access Options. The following options
are available:
Talk: dials the selected number.
Show Entry (or Save if the phone number is not
currently stored in the Phone Book): shows
the phone book entry (or stores the
number) in the Phone Book.
Prepend:allows to add an area code or feature code to
the number before calling the number.
3736
C a l l s
Erase Logs Menu 1-4
You can erase the numbers stored in the Call Log
memory.
Outgoing: The numbers you called are erased.
Incoming: The numbers you received are erased.
Missed: The numbers you missed are erased.
All: All calls you dialed and received are erased.
Airtime Menu 1-5
Using this option, you can view the call time of the last
call, as well as total air time for all calls since you last
reset the timer.
Last Call: the date, time, and length of your last call.
Total: the total number of calls and total airtime. You
can reset the total airtime by Erase Totaloption.
Lifetime: the total air time for your phone since it was
purchased. This airtime log is kept for
historical and maintenance reasons, and
cannot be erased.
Erase Total: resets the call timers.
The counter is reset to zero and begins counting
the next time you make or receive a call.
Missed Menu 1-3
This option lets you view the last 10 calls missed. (if you
are subscribed to the caller ID service). When you
access this menu, the last missed calls are displayed.
To... Press ...
Select entry up or down navigation key
Dial the selected entry
View the details OK
When you press the OK key, you can view the date/time
stamp for the selected entry. If there is a Phone Book
match, the name and the label display.
Press MENU to access Options. The following options
are available:
Talk: dials the selected number.
Show Entry (or Save if the phone number is not
currently stored in the Phone Book): shows
the phone book entry (or stores the
number) in the Phone Book.
Prepend:allows to add an area code or feature code to
the number before calling the number.
C a l l s
3938
Phone Book
3. The phone shows the details on the name.
Press to place a call.
With an entry selected, if you press MENU, you can
access the following options:
Talk: dials the number.
Add #:allows you to add a new entry or a number to an
existing entry.
Edit: allows you to edit phone number, name, location
number, label category and so on.
Prepend: allows you to add digits such as area codes
and network feature activation codes to a
phone number .
Erase: erases the number.
Name Ring:allows you to designate a unique ring tone
to signal an incoming call from the number.
E-mail addr:allows you to store an email address in
the entry.
Add Entry Menu 2-2
This menu allows you to store a number with a name in
your Phone Book. You can save a person’s various
numbers, such as workplace number, mobile number and
fax number, into one entry. Using this feature, you can
keep someone’s information together. It also helps you
to find numbers easily in the Phone Book.
Phone Book
The Phone book allows you to store frequently used
phone numbers and the associated names in your
personal directory to make it easy for you to make a call
without having to remember or enter the phone number.
You can store up to 500 numbers.
Find Name Menu 2-1
This option allows you to find an entry by its name.
1. Press up or down navigation to scroll to the desired
name.
To find an entry with a character(s). Press MENU
and enter the character you want with the desire d
Input mode. Then press OK.
The phone searches for the first entry in the list
containing that character(s).
2. When the desired entry is highlighted, press OK to
access the entry.
N o t e: If you have stored the several numbers into
d i ff e r ent categories under one entry, they are listed
under the name. Press up or down navigation key to
find the number you want.
4140
Phone Book
4. Press MENU to edit the setting for the selected
option.
5. Repeat steps 3 and 4 to customize another option.
6. Press OK to save the entry.
After storing, the phone displays the phonebook entry
number you saved and the remaining entries you can
further store phone numbers, then automatically
returns to Standby mode.
Storing Phone Numbers at Call End
To store a phone number at your call end:
1. Press to end the call. The call time and the
phone number display.
2. To store the phone number, press OK.
3. To complete storing the number, follow the
instructions in “Creating a New Entry.”
Phone Book
Creating a New Entry
1. Enter a phone number and press OK .
2. Highlight the desired option you want to customize by
using the navigation key. The following options are
available:
•New Name: Enter the desired name. You can
enter up to 12 characters. For further information
on how to enter text, see page xx.
•Entry: The first available location displays. If
necessary, enter the location number using the
number keys.
•Secret: To set the number in secret, select On.
Setting Secret prevents a number from being
displayed when it is accessed by unauthorized user,
or dialed. When you have made the number secret,
only a person with your phone’s lock code can view
the number.
•Category: Select the label for the number. The
available categories are Speed Dial, Home, Mobile,
Office, Pager, Fax, or No Label.
•Relation: Select the desired one of the four
predefined relation groups, where the entry is
included. Grouping the entries enables you to
locate only the numbers in the desired group.
•Ringtype: Select the unique ring type for the entry.
By selecting different tones, incoming voice calls
which have caller ID can be distinguished from
those that do not.
4342
Add E-mail Menu 2-5
This option allows you to store an e-mail address as a
phonebook entry.
1. Enter the e-mail address and press OK.
For further information on entering text, see page 36.
2. The phone asks if you want to make a new entry.
Press OK and complete storing the address.
Phone BookPhone Book
Find Entry Menu 2-3
This option allows you to find an entry by its location
number.
1. Enter the location by pressing the numeric keys.
2. When the desired entry highlighted, press OK to view
the details, press to make a call to the number.
If you press MENU , you can access the options. For
further information on Options, refer to the Find Name
menu on page 51.
Relation Search Menu 2-4
This option allows you to find an entry by its relation
group.
1. Select the group containing the entry you want to find
using up or down navigation key and press OK.
The phone lists all entries in the selected group.
2. Scan through the list using up or down navigation key
to find the desired entry.
4544
Web
W e b
Your phoen comes equipped with Wireless Web Internet
acess through a Browser. The Browser displays
immediate information through your phoen. You can
view specially designed versions of popular sites which
include sprots, weather, news, stock quotes, etc.
Browsing the Web through your phone is not the same
as using your PC since site providers have only selected
certain aspects of the available sites to present to the
wireless phone users and have removed most graphics.
Each time you launch the Browser, the phone will
connect tot he Internet. Rates and pricing vary according
to your service option. For further information contact
your service provider.
Note: The phone mnust be in a digital network to use
the Browser.
Get In Web Menu 3-1
This menu allows you to launch the Browser.
You can also launch the Browser by pressing the
internet hot key in idle mode.
Once connected, the Home page (or the last page
visited), will be displayed.
To exit the Browser press or close the phone’s flip
cover.
Prompt Menu 3-2
Your phone can be set to view a prompt each time you
start or end a Browser session. You have the option to
change this default prompt setting. The default setting
amy differ as it is based upon the carrier’s requirement.
This menu allows you to change the settings.
None: This prompt is never displayed.
To Start: You will see this prompt when you enter the
browser, but not when you exit it.
To End: You will see this prompt only when you exit the
browser.
Both: You will be prompted when you enter or exit the
browser.
47
P l a n n e r
Adding, Editing, or Erasing an Event
If you already scheduled events when you select the
Today menu option (4-1),
the events are displayed. Press
to select the event you want to view. If necessary,
press OK to display more contents in the selected to do
item.
The following options are available when you press
MENU .
Add new: allows you to add a new event.
Edit : allows you to edit a scheduled event.
Erase : allows you to erase a selected event.
Erase all : allows you to erase all events.
After you select an option, press OK . Then follow the
screen prompt.
View Month Menu 4-2
You can to enter the scheduler menu by pressing
in standby mode.
This option allows you to view in calendar format the
current month, or a past of future month. In this option,
the current date is highlighted on the calendar. Days
with the scheduled events are underlined.
46
S c h e d u l e r
The Scheduler feature enables you to:
•Keep track of important dates and events
•Create a list of things to do
•Check the time in another part of the world
•Use the phone as a calculator
Today Menu 4-1
You can schedule up to 9 events for the current day
indicating each event’s start and end time. You can even
have your phone's calendar alert you before an event is
to start. Events scheduled for future dates automatically
appear on your Today events schedule on that day.
Scheduling an Event
1. Enter your event information. You can enter up to 32
characters. For more information on entering letters,
see page 36.
2. Press OK to accept your entry.
3. Enter the Start Time and Date using the numeric keys
and press OK.
4. Enter the End Time and Date using the numeric keys
and press OK.
5. Select when an alarm will notify you of your event by
pressing up or down navigation key. Selecting No
alarm does not ring the alarm.
6. Press OK to save your event.
49
P l a n n e r
48
P l a n n e r
Jump To Date Menu 4-3
This feature allows you to specify the calendar date you
want to view. Once at your desired date you can enter,
edit and delete events in your calendar.
Enter the date using the numeric keys, and press OK.
To create, edit or erase the events, refer to “View
Month” on page 63.
To Do List Menu 4-4
This feature allows you to draw up a list of tasks to be
done and assign a priority and deadline to each task.
Creating the To Do Item
1. Enter the first task.
N o t e : You can enter up to 32 characters. For furt h e r
details on how to enter characters, see page 36.
2. Press OK to confirm.
3. Enter your deadline using the numeric keys.
4. Select high or low priority using up or down
navigation key and then press OK to store the task.
• You can move up or down the Calendar by one week
by pressing or .
• You can move right or left one day by pressing *or #.
• To display the next or previous month, press or .
The following options are available when you pre s s
MENU.
View: allows you to view the scheduled events of the
selected day.
Add new: allows you to add a new event on the
selected day.
Creating a New Event
Scroll to the desired date in the calendar using the
navigation keys and volume keys and then press OK
to confirm the selected date. And schedule a new event
referring “Today” on page 62.
Adding, Editing, or Erasing a Event
When a stored memo is displayed, press MENU to
access the
Options
.
For further details on Options, refer “Today” on page 62.
51
P l a n n e r
Creating a Count Down Timer
1. Enter a name for your new Count down item and press
OK. For details on entering text, see page 36.
2. Enter the date and time that you want to Count down
to or from.
Notes: You can enter the years between 1980 and
2099 for dates.
3. Press OK to save the item.
Adding, Editing and Erasing a Count Down Timer
If a Count Down timer is already defined when you select
the Count Down menu option (4-5), the defined Count
Down timer is displayed.
If there are more than one items defined in the menu,
scroll to the desired item by pressing left or right soft key.
The following options are available when you press
M E N U
.
Add new: allows you to create a new item.
Edit : allows you to edit the item.
Erase : allows you to delete the item.
Erase all : allows you to delete the item.
After you select an option, press OK. Then follow the
screen prompt.
50
P l a n n e r
Adding, Editing and Erasing an To Do Item
If tasks are already defined in the To Do List when you
select the To Do List menu option (4-4), the current
contents are displayed with the deadline and the
associated priority (High or Low).
Scroll to the desired item by pressing
left or right
navigation key.
The following options available when you press MENU.
Add new: allows you to add a new task.
Edit: allows you to edit a saved task.
Erase: allows you to erase the selected task.
Erase all: allows you to erase all tasks.
After you select an option, press OK. Then follow the
screen prompt.
Count Down Menu 4-5
This menu help you know how much time it takes you to
do something, or how many months, days, hours and
minutes until a specific day. You can create up to 20
Count down timers using this menu.
53
P l a n n e r
Alarm Menu 4-8
This option allows you to set or release the alarm to ring
at a specific time. Press MENU to access the options.
Set: to set the alarm, proceed as follows:
1. Select the alarm frequency option by pressing up or
down navigation key and press OK.
•Once: the alarm rings only once and is then
deactivated.
•Daily: the alarm rings every day at the same time.
2. Enter the required time when an alarm rings using the
numeric keys.
3. Press OK to save the setting.
To stop the alarm when it rings, press any key.
Release: to release the alarm, press OK.
52
P l a n n e r
World Time Menu 4-6
This menu allows you to check the current time for
Greenwich Mean Time (GMT) and major cities around the
world.
Select the city corresponding to your time zone by
pressing the navigation keys one or more times. The local
date and time are displayed.
Calculator Menu 4-7
Using this feature, you can use the phone as a
calculator. The calculator provides the basic arithmetic
functions: addition, subtraction, multiplication and
division.
1. Enter the first number using the numeric keys.
2. Set the operator for your calculation by pressing the
navigation keys until the required arithmetic symbol
appears: + (add), - (subtract), x (multiply), / (divide).
3. Enter the second number.
4. To calculate the result, press OK.
5. Repeat steps 1 to 4 as many times as required.
Each time you change the operator, the previous
calculation is performed and the result is displayed as
the top number in the display.
N o t e :
• To erase any mistakes and clear the display, press C L R.
• Use *to enter a decimal point and #to change the sign
of a number to a negative (-).
55
S o u n d s
54
Sounds Type Menu 5-2
This option allows you to set a unique ring for voice calls,
messages, data/fax, alarm, and schedule. Select a unique
ring tone from 25 melodies. As you change it, it sounds
for a few seconds.
Calls:allows you to set a unique ring for incoming voice
calls.
Alarm:allows you to have a distinctive ring for an alarm.
Data/Fax In:allows you to be alerted with a distinctive
ring tone when you are faxed or received a
data through the phone (dependent on the
network ).
Schedule:allows you to have a distinctive ring for an
schedule alarm.
N o t e : You can select Bell, Melody, Music Bell and My
M e l o d y
S o u n d s
You can use the Sounds menu to customize various sound
settings, such as the:
• Ringer volume, type, and tone
• Key beep and voice volume
• Alert sounds and a ringer for the roaming calls
•The ringer which sounds when the phone is switched
on or off
Ringer Vol Menu 5-1
This menu option allows you to adjust the ringer volume.
Voice:allows you to adjust the voice volume during a call.
Calls:allows you to adjust the ringer volume for the
incoming calls.
Alarm:allows you to adjust the ringer volume for an
alarm.
Key Beep:allows you to adjust the volume for the key
beep. you can adjust the the volume using the
volume keys on the left side of the phone in
standby mode.
Messages:allows you to adjust the ringer volume for the
messages.
Press up or down navigation key to adjust the volume or
select the type.
Volume Level: adjust the volume level (the more bars,
the louder).
Vibrate: switches the phone to vibration mode. An
incoming call vibrates the phone.
1 Beep: sounds a beep.
Silent: does not sound the ring.
5756
S o u n d s
Alerts Set Menu 5-3
Your phone gives audible alerts (beeps) at a specified
time to inform you that certain things have happened.
The alerts only occur in your earpiece so the other party
does not hear them.
The available alerts are:
Minute Beep: With this menu option set to ON, the
phone sounds an alert 10 seconds before
each elapsed minute to remind you of
the length of the current call.
Service : With this menu option set to ON, the phone
beeps when you exit service area or when
you return to a service area.
Connect : You can set your phone to sound the connect
tone when your call is connected to the
system.
Disconnect: You can set your phone to sound the
connect tone when a call is disconnected
or dropped.
Fade: You can set your phone to sound when it’s fade.
Roam: You can set your phone to sound when it’s
roaming.
Power On/Off: You can set your phone to sound when
Power On/Off.
D i s p l a y
The Display feature enables you to:
•Set the length of time for backlight.
•Create your own greeting, and select an animation to
be displayed in Standby mode or when powered on
or off.
• View the version of your phone.
Backlight Menu 6-1
You have several options for setting how the LCD
backlight operates. Remember that backlight use drains
your battery faster.
The following options are available:
30 (/15/7)seconds: The backlight comes on when you
press a key or receive a call and
switches off 30(/15/7) seconds
after the last key is pressed.
Always off: The backlight is always off.
5958
Banner Menu 6-2
This option allows you to set a banner message to be
displayed at the bottom of the display in Standby mode.
To change the banner:
1. If necessary, press CLR repeatedly to delete each
letter of the old greeting.
Press are hold CLR to clear off the old greeting.
2. Enter your banner message up to 28 characters in
English or 14 characters in Chinese by using the
alphanumeric keys. For further information on how to
enter letters, refer to page 36.
3. When entering is completed, press OK to save the
new banner.
Animation Menu 6-3
Your phone displays graphics images when you set this
option. This setting is just for fun and grins so have fun
with it.
The following options are available:
Power On: You can select an image to be displayed
when you switch the phone on.
Power Off: You can select an image to be displayed
when you switch the phone off.
Idle Mode: You can select an image to be displayed in
idle mode.
D i s p l a yD i s p l a y
My Phone Number Menu 6-4
This option shows your phone number.
After viewing the number, pressing OK returns to
Standby mode.
Language Menu 6-5
Sets the language of voice prompts, menus and key
input.
Select the desired language by pressing the navigation
key.
N o t e : This setting does not affect the Web Bro w s e r.
Set Time Menu 6-6
This option allows you to set the current date and time.
To set the date and time, proceed as follows:
1. Enter the current time and date using the numeric
keys.
The month, day, hour and minute must be entered
with 2 digits. The year requires all four digits. And
you must enter the hour in 24-hour format.
3. When entering is completed, press OK to save the
time and date.
If you enter a wrong time, the phone displays ‘Invalid
time’ and prompts you to enter again.
60
D i s p l a y
Auto Hyphen Menu 6-7
With this menu option set to Yes, your phone
automatically hyphenates numbers when you dial a
number. This hyphenates numbers as follows: 000-000-
0000. Digits following a pause are not hyphenated.
Version Menu 6-8
This option allows you to view the software and
hardware versions of your phone. This feature is helpful
if you have to call customer care.
Menu Style Menu 6-9
This option allows you to set the style of showing main
menu list.
Horizontal and Vertical are available.
61
G a m e
This menu allows you to play games.
Press the navigation key to scroll the entries, and then
to select the desired one.
When the game start screen is displayed, press MENU
to get help in playing the game.
The following options are displayed:
KEY HELP : displays each key function.
GAME HELP :gives you a demo play to show how the
game is played.
GAME EXIT : allows you to exit the game. You are
asked to confirm. Selecting Yes returns to
Standby mode.
Press END to return to the game start screen, and play
the game.
63
S e t u p
62
Answer Mode Menu 8-3
This menu option allows you to select how to answer an
incoming call. The following options are available:
By any Key: The phone answers when you press any
key except .
By send key:The phone answers only when you press
.
Tone Length Menu 8-4
The tone length setting enables you to select normal or
long DTMF (dual-tone multi-frequency) tones. When you
use a teleservice (such as your bank account) and press
the keys to enter numbers into the teleservice, you are
sending DTMF tones. The system used by the bank or
other service determines if you need short or long DTMF
tones. If the service is digital (which most are these
days) short DTMF will almost always work. However,
some new systems and almost all older (analog)
systems require you to use long DTMF tones. Many
home answering machines require long DTMF tones.
S e t u p
Many different features of your phone can be
customized to suit your preferences.
Auto Retry Menu 8-1
With this menu option activated, your phone will
automatically retry the call up to 10 times when a
connection fails.
To activate this feature, select how often the phone will
automatically retry the call. every 60 sec,every 30
sec, and every 10 sec are available.
Select Off deactivates this feature.
Auto Answer Menu 8-2
With this menu option activated, the phone
automatically answers calls after predefined rings. This
option is useful while driving, for instance.
To activate this feature, select how many times your
phone rings before answering an incoming call. after 1
sec,after 3 sec and after 5 sec are available.
With this menu option set to Off, the phone does not
answer an incoming call, and if you do not answer the
call, it is stored in Missed Call log (see page 49).
65
S e t u p
64
S e t u p
A Only : In a wireless service area, there are usually
two service providers which are referred to as A and B.
Your service provider will provide you information about
this when you setup service. With this setting, you will
only be able to roam in the “A” network or system.
B Only : This works just like the “A Only” seting except
you will only be able to roam in the “B” network or
system. To select the system.
Digital Only : This setting forces the phone to seek an
digital roaming system. The previous setting is restored
the next time the phone is turned on.
Data/Fax Menu 8-7
Your phone is capable of sending and receiving digital
data and fax call when connected to a computing device
(laptop, desktop, handheld, palmtop, etc.) running
Windows 95, Windows 98, or Windows NT. The phone
functions just like a typical modem on your PC, enabling
you to use wireless data involving a side variety of
Windows software applications.
To use digital data or fax services with your phone, you
will need to obtain digital data/fax kit from your service
provider. This kit will contain the necessary cables,
software, and documentation required for your to
connect and use your phone with your computing device.
Note: The phone must be on a digital network to
receive or send fax and data.
The following options are available:
Set Nam Menu 8-5
Your Samsung phone can store two NAMs (NAM stands
for numerical assignment module - essentially your
telephone number). This means you can have two phone
numbers on your phone, and you can quickly and easily
switch your service back and forth between the two
numbers.
Press up or down navigation key to select NAM 1 or
NAM 2. If you change the NAM, the phone will reboot
and acquire service using the new NAM setting.
Set System Menu 8-6
The system selection feature of your phone enables you
to choose how your phone will roam. Roaming is a
feature which is only relevant in areas where there are
usually at least two cellular service providers which are
referred to as “A” and “B” and have valid roaming
agreements. Your service provider will provide you
information about this service or the best roaming
methods for you.
Home Only : With this setting, you cannot roam. If your
home system is not available then your call will not be
connected and the No Service Indicator ( ) is
displayed. In some service areas an operator may come
on line asking you how you would like to pay for the
call.
Standard : This option allows you to provide the best
system automatically.
67
S e t u p
66
S e t u p
Set Network Menu 8-8
Your phone is preset to digital mode. If you wish to
place a call in analog mode use this menu. Your phone
allows you to search for analog service.
The following options ar e available:
Automatic: Automatically looks for all forms of service
according to the PRL(Preferred Roaming List) supplied by
the carrier.
1-Time Analog Call: Automatically switches the phone
into analog mode for one call. When the call is
completed, the phone automatically resets to the normal
setting.
Whisper Mode Menu 8-9
Whisper mode automatically increases the receiving
sensitivity of the microphone to obtain the maximum
quality of a call even when you speak in a softer voice
so that the caller can hear you as if you are speaking
normally.
N o t e : It is not recommended that the ear piece be used
while using Whisper mode. Audio level may incre a s e
without notice depending on the surro u n d i n g
c o n d i t i o n s .
Select On to use this mode, or Off not to use it.
Data/Fax Off: Your phone receives voice calls only.
Fax for Next Call: Your phone receives fax calls for
next 10 minutes.
Fax until Powered Off: Your phone receives fax calls
until you power off and back
on the phone.
Data for Next Call: Your phone receives data calls for
next 10 minutes.
Data until Powered Off: Your phone receives data
calls until you power off and
back on the phone.
Receiving a Fax or Data File
To receive a fax or data, ensure that your phone is
connected to your PC and is powered on and select a
desired option.
When you receive a fax call, setup the Answer mode in
the Fax program on your PC and click on Receive and
select one of the following:
• Automatic Receive (recommended)
• Manual Receive
Sending a Fax or Data File
When connected to a computing device, your phone
allows wireless fax and data transmissions. Your
computing device software initiates the call to the
destination phone number. The phone functions as a
wireless modem to send the fax or data file to the
number designated by your PC software.
69
S e c u r i t y
S e c u r i t y
Your phone provides many security options, including a
user-programmable lock code and call restriction
features.
To access the security menu, you must enter a four-digit
lock code. The lock code is preset to 0000 at factory.
Lock Mode Menu 9-1
When the phone is locked, you cannot operate the
phone until you enter the lock code.
The following options are available:
Never: the phone remains unlocked.
Now: the phone locks immediately.
On Power up:the phone locks automatically at the
next time your phone turned on.
To place a call on Lock mode:
• To place an emergency call, enter the number and
then press . The phone recognizes emergency
numbers and the seven emergency numbers of menu
0-4.
• To place normal outgoing calls, press MENU to
display the Lock Code screen, and then enter the lock
code. When the Standby screen displays, enter the
phone number, and then press .
To unlock the phone, press MENU and enter the lock
code. The phone returns to Standby mode.
68
S e t u p
Key Guard Menu 8-0
You can make the keypad lock manually by pressing and
holding MENU in standy mode.
When the Key Guard menu option is set to On, in
standyby mode key guard will activate automatically
after the predetermind amount of time.
To unlock you keypad, press CLR and hold MENU.
71
S e c u r i t y
70
S e c u r i t y
To store an emergency number, select a location using a
numeric keys or up or down navigation key and enter the
desired number. Each priority number can be up to ten
digits long. The number already stored in the location is
automatically deleted when you enter the new number.
To make an emergency call in Lock mode, simply enter
the emergency number, then press .
Send PIN(Personal Identification Number) Menu 9-5
N o t e : Your service provider must enable this feature
and assign you a PIN in order for this feature to work.
This feature prevents your phone from being used by
unauthorized persons. Contact your service provider for
complete information on this feature. Your PIN is
programmable and can be up to 24 digits.
These options are available:
Never: The option is not activated.
Prompt:When you make a call, you are asked to send a
PIN.
Restrict Menu 9-2
This feature allows you to restrict your calls.
Yes:the phone restricts your calls.
No: the phone doesn’t restricts your calls.
Lockcode Menu 9-3
This feature allows you to change your current lock code
to a new one. The lock code is preset to 0000 at factory.
Enter a new, four-digit lock code, then press OK.
Emergency Number Menu 9-4
Your phone provides the option of storing emergency
numbers. All emergency numbers can be manually
dialed at any time even when your phone is locked or all
default priority numbers are depending on your service
provider.
72
S e c u r i t y
Clear Memory Menu 9-6
This menu allows you to erase all the numbers in your
Phone Book.
When a confirmation message displays, press OK to
clear the memory.
Reset Phone Menu 9-7
Resetting the phone erases all of your saved options
and returns them to the factory default settings, and
erases your Phone Book, Call Logs, and SMS messages.
The phone reboots (turns itself off then on), restores the
default settings, and then returns to Standby mode.
Voice Privacy Menu 9-8
When in an area that supports the voice privacy option
and it is enabled, the phone makes an audible beep.
Your servic e provider must enable this feature. Contact
your service provider verify if this feature is available on
their network.
73
M e s s a g e
Your phone can receive voicemail notification, text messages,
and pages. Also, your phone can send text messages and
pages if you system supplier provides this service.
When the phone receives a message, an alert sounds, a
text notification displays and the name and phone
number of the caller if available. The New Message
icon remains on the screen until you read the new text,
numeric page or WebBrowser message, or until you
listen to the new voicemail messages.
Incoming messages are received even when your phone
is in Lock mode. However, the screen will not display
information about the message. To access a message, or
to return a call other than an emergency or priority
number, unlock the phone to proceed.
If you are on a conversation, and you receive an
incoming message, your phone automatically mutes the
ringer (this is to avoid ringing in your ear while you are
trying to converse).
New Messages Menu -1
You can create short text messages, and numeric pages,
to send to other mobile numbers.
N o t e: Transmitting message is only supported in digital
networks, and if service is provided by your serv i c e
p ro v i d e r.
75
M e s s a g e s
74
M e s s a g e s
5. Press OK to send the message.
N o t e : Closing the phone or pressing SEND b e f o re
message is transmitted will terminate the message
t r a n s m i s s i o n .
Voice Menu -2
When the voicemail notification displays, press OK or
to scroll to the desired voice mail and press
to review and re-review the message. If multiple new
voicemails are received but not reviewed, then only the
last received voicemail information will be displayed.
The display information will include time / date stamp,
number of new voicemails, and callback number.
While reviewing the message, press MENU to access
the following options.
Listen:allows you to listen to voicemail message. The
phone will automatically dial your voicemail box.
Reset: resets the message icon and the counter for new
voicemail messages, if desired. (The system
resets the counter automatically after you listen
to all new messages.)
1. Enter the Send-To phone number using the numeric
keys and press OK .
2. Enter the message contents, or a numeric page. For
further details on how to enter text, see page 36.
N o t e : A total of 180 characters, including e-mail
a d d ress character length if send-to destination is an
e-mail address, can be entered for each message, can
be entered for each message.
3. When entering is finished, press OK .
4. If you wish to edit the following available options
before transmitting the message, press MENU.
•Send To: Edit the send-to phone number.
•Message: Edit the message contents already
entered.
•Callback : Edits the callback number. Enter the new
number to replace the current number.
•Options: edits following options.
Priority: Urgent/Normal
Validity: None/30min/1,2 or 12Hours/1,2,or 3days
Send Later: None/30min/1,2,or 12 Hours/1,2 or
3days
Delivery Ack: On/Off
Message: Do not save/Prompt save/Auto save
•Action: shows the button commands.
N o t e : Callback, Delivery ACK, and Priority are alre a d y
p r eset to default values in the Msg Setup menu .
77
M e s s a g e s
76
M e s s a g e s
Outbox Menu -4
Your phone can store up up to 95 transmitted messages
until the total length of the message exceeds 16 kbytes.
You can review or resend the messages stored in
Outbox, if needed.
When you enter the Outbox menu, you can see the
message list. The marker !next to the message means
that it is urgent.
Press up or down navigation to scroll to the desired
message and press OK to review the message. The
display shows the date and time when the message is
created, the designated number (and name if saved in
Phonebook) and message contents.
If necessary, press up or down navigation to scan
through the contents.
While reviewing a message, press MENU to access the
following options.
Re-send:allows you to resend the message. For further
information on sending a message, see page
94.
Delete: deletes the message from Outbox.
Inbox Menu -3
Your phone can store up to 100 pages and text
messages, depending on the length of the message. If
the message memory is full, a message is displayed and
the phone rejects additional messages until you erase
the stored messages.
Press up or down navigation key to scroll to the desired
one of the messages in the list and press OK. The
phone displays the message contents. If necessary,
press up or down navigation key to scan through the
contents.
While viewing a message, press MENU to access the
following options.
Reply:allows you to send a reply message to the
sender.
Forward:allows you to send the message to the other
person.
Delete: deletes the message.
Save addr: allows you to save the sender’s phone
number into your Phonebook. For further
information on storing a number, see page
52.
Save cb#:allows you to save the call back number of
the message.
79
M e s s a g e s
78
M e s s a g e s
Msg Setup Menu -8
Via this menu, you can preset several options for new
message transmission and delete all messages.
Scroll Timer
You can set the screen to scroll automatically or not.
1~5 seconds: If an incoming message is too long
for the display, the phone displays it by scrolling the
s c reen automatically. You can set the time when the
phone scrolls to the next screen.
O ff: It does not scroll automatically. You should scroll
to next screen manually using up or down navigation key.
Msg.Reminder
Off: It doesn’t alerts when you receive an incomming
call.
Once: It alert just once when you receive an
incomming call.
Every 2 min: It alert every 2 minutes when you
receive an incomming call.
Message Volume
You can set the volume level or type using the up or
down navigation key.
Ringer Type
You can set the ringer type for Voice Mail, Page, Text,
Browser Msg.
Filed Msg Menu -5
Your phone can store draft messages that are yet to be
sent in the filed message folder. You can access this
folder at a later time to edit and send the message.
To store unsent message to the filed message folder;
1. follow the process of writing a new message.
2. When you finish inputing the message press MENU
for option.
3. Select Action, and press OK .
Press up or down navigation key to scroll to the desired
message and press OK to review it. Press MENU for
further options.
Select Edit to edit it, and select Delete to delete it.
Web Alerts Menu -6
The phone alerts you when a browser message is
received. You can choose how often you want to be
alerted.
Press up or down navigation key to scroll to the desired
message and press OK to review it. Press MENU for
further options.
Select Edit to edit it, and select Delete to delete it.
Erase Msg Menu -7
Using this menu option, you can erase all messages in
each of three message boxes; Voice mail box, Inbox and
Outbox.
You can also erase all of the messages at one time.
80
M e s s a g e s
New Message
You can set up the following options as default setting
when creating a new message.
Call Back #: You can set the call back number. Your
phone number is preset at factory.
Save Message:allows you to set whether you want
the transmitted message to be saved
in Outbox or not.
- Do not save : not to save automatically
- Prompt Save: asks you to save it or not
- Auto Save: save the message automatically
Entry Method: You can select the text input mode
between T9 Word and Alphabet (ABC).
Delivery Ack:allows you to activate or deactivate the
delivery acknowledgement feature.
When this is activated, the network
informs you whether your message has
been read or not by the recipient.Select
On to turn on the feature or Off to turn it
off.
Canned Msg: allows you to set the one of canned
messages.
81
Health and Safety
I n f o r m a t i o n
Exposure to Radio-Frequency Energy
(SAR Information)
This model phone meets the ACA(Australian
Communication Authority) requirements
(AS/NZS 2772) for exposure to radio waves.
Your mobile phone is a radio transmitter and receiver.
It is designed and manufactured not to exceed the
limits for exposure to radio-frequency(RF) energy
recommended by the ACA. These limits are part of
comprehensive guidelines and establish permitted
levels of RF energy for the general population. The
guidelines were developed by independent scientific
organisations through periodic and through
evaluation of scientific studies. The limits include a
substantial safety margin designed to ensure the
safety of all persons, regardless of age and health.
The exposure standard for mobile phones employes a
unit of measurement known as SAR(the Specific
Absorption Rate). The SAR limit recommended by the
ACA is 1.6W/Kg *.
* The SAR limit for mobile phones used by the public is 1.6 watts/kilogram (W/kg) averaged
over one gram of body tissue. The limit incorporates a substantial margin of safety to give
additional protection for the public and to account for any variations in measurements. The SAR
values may vary depending on the national reporting requirements and the network band.
8382
•Extreme temperatures will affect the charging
capacity of your battery: it may require cooling or
warming first.
• Do not leave the battery in hot or cold places, such
as in a car in summer or winter conditions, as you
will reduce the capacity and life-time of the
b a t t e ry. Always try to keep the battery at ro o m
t e m p e r a t u r e. A phone with a hot or cold battery
may temporarily not work, even when the battery
is fully charged. Li-ion batteries are part i c u l a r l y
a ffected by temperatures below 0 °C (32 °F).
•Do not short-circuit the battery. Accidental short
circuiting can occur when a metallic object (coin,
clip or pen) causes a direct connection between
the + and - terminals of the battery (metal strips
on the back of the battery), for example when
you carry a spare battery in a pocket or bag.
Short-circuiting the terminals may damage the
battery or the object causing the short-circuit.
•Dispose of used batteries in accordance with local
regulations. Always recycle. Do not dispose of
batteries in a fire.
Precautions When Using Batteries
Your phone is powered by a re c h a rgeable Li-ion
s t a n d a rd battery.
•Never use any charger or battery that is damaged
in any way.
•Use the battery only for its intended purpose.
• If you use the phone near the network’s base
station, it uses less power; talk and standby time
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
•Battery charging time depends on the remaining
battery charge and the type of battery and charger
used. The battery can be charged and discharged
hundreds of times, but it will gradually wear out.
When the operation time (talk time and standby
time) is noticeably shorter than normal, it is time
to buy a new battery.
•If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries and
re c h a rge your battery only with Samsung-appro v e d
c h a r gers. When a charger is not in use, disconnect
it from the power source. Do not leave the battery
connected to a charger for more than a week,
since overc h a rging may shorten its life.
Health and Safety Information Health and Safety Information
8584
6. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan calls when your car
will be stationary. If you need to make a call while
moving, dial only a few numbers, check the road and
your mirrors, then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting. Make people
you are talking with aware you are driving and
suspend conversations that have the potential to
divert your attention from the road.
8. Use your wireless phone to call for help. Dial
emergency number in the case of fire, traffic
accident or medical emergencies. Remember, it is a
free call on your wireless phone!
9. Use your wireless phone to help others in
emergencies. If you see an auto accident, crime in
progress or other serious emergency where lives are
in danger, call emergency number, as you would
want others to do for you.
10. Call roadside assistance or a special non-
emergency wireless assistance number when
necessary. If you see a broken-down vehicle posing
no serious hazard, a broken traffic signal, a minor
traffic accident where no one appears injured, or a
vehicle you know to be stolen, call roadside
assistance or other special non-emergency wireless
number.
Road Safety
Your wireless phone gives you the powerful ability to
communicate by voice - almost anywhere, anytime.
But an important responsibility accompanies the
benefits of wireless phones, on that every user must
uphold.
When driving a car, driving is your first responsibility.
When using your wireless phone behind the wheel of
a car, practice good common sense and remember
the following tips:
1. Get to know your wireless phone and its features
such as speed dial and redial. If available, these
features help you to place your call without taking
your attention off the road.
2. When available, use a hands free device. If
possible, add an additional layer of convenience and
safety to your wireless phone with one of the many
hands free accessories available today.
3. Position your wireless phone within easy reach. Be
able to access your wireless phone without removing
your eyes from the road. If you get an incoming call
at an inconvenient time, if possible, let your voice
mail answer it for you.
4. Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy traffic
or hazardous weather conditions. Rain, sleet, snow,
ice, and even heavy traffic can be hazardous.
5. Do not take notes or look up phone numbers while
driving. Jotting down a “to do” list or flipping
through your address book takes attention away from
your primary responsibility, driving safely.
Health and Safety Information Health and Safety Information
8786
with the independent research by and recommen-
dations of Wireless Technology Research.
Persons with pacemakers:
•Should always keep the phone more than 6
inches (15cm) from their pacemaker when the
phone is switched on;
• Should not carry the phone in a breast pocket;
•Should use the ear opposite the pacemaker to
minimize the potential for interference.
•If you have any reason to suspect that
interference is taking place, switch off your
phone immediately.
Hearing Aids
Some digital wireless phones may interfere with
some hearing aids. In the event of such interference,
you may want to consult your hearing aid
manufacturer to discuss alternatives.
Other Medical Devices
If you use any other personal medical devices,
consult the manufacturer of your device to determine
if they are adequately shielded from external RF
energy. Your physician may be able to assist you in
obtaining this information. Switch off your phone in
health care facilities when any regulations posted in
these areas instruct you to do so.Hospitals or health
care facilities may be using equipment that could be
sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
Operating Environment
Remember to follow any special regulations in force
in any area and always switch off your phone
whenever it is forbidden to use it, or when it may
cause interference of danger.
When connecting the phone or any accessory to
another device, read its user’s guide for detailed
safety instructions. Do not connect incompatible
products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation
of the equipment and for the safety of personnel, it is
recommended that the equipment should only be
used in the normal operating position (held to your
ear with the antenna pointing over your shoulder).
Electronic Devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against
the RF signals from your wireless phone.
consult the manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum separation of 6 inches (15 cm) be
maintained between a wireless phone and a
pacemaker to avoid potential interference with the
pacemaker. These recommendations are consistent
Health and Safety Information Health and Safety Information
8988
Emergency Calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well
as user-programmed functions which cannot guarantee
connection in all conditions. Therefore, you should
never rely solely upon any wireless phone for essential
communications (for example, medical emergencies).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not be
possible on all wireless phone networks or when
certain network services and/or phone features are in
use. Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location (for example, 000 or other official emergency
number). Emergency numbers vary by location.
3. Press the <SEND> key.
If certain features are in use (keyguard, restrict calls,
etc.), you may first need to turn those features off
before you can make an emergency call. Consult this
document and your local cellular service provider.
When making an emergency call, remember to give all
the necessary information as accurately as possible.
Remember that your phone may be the only means of
communication at the scene of an accident - do not cut
off the call until given permission to do so.
representative regarding your vehicle.
You should also consult the manufacturer of any
equipment that has been added to your vehicle.
Posted Facilities
Switch off your phone in any facility where posted
notices so require.
Potentially Explosive Atmospheres
Switch off your phone when in any area with a
potentially explosive atmosphere and obey all signs
and instrutions. Sparks in such areas could cause an
explosion or fire resulting in bodily injury or even
death.
Users are advised to switch off the phone while at a
refueling point (service station). Users are reminded
of the need to observe restrictions on the use of
radio equipment in fuel depots (fuel storage and
distribution areas), chemical plants or where blasting
operations are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
below deck on boats; chemical transfer or storage
facilities; vehicles using liquefied petroleum gas
(such as propane or butane); areas where the air
contains chemicals or particles, such as grain, dust
or metal powders; and any other area where you
would normally be advised to turn off your vehicle
engine.
Health and Safety Information Health and Safety Information
9190
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you to fulfill any
warranty obligations and allow you to enjoy this
product for many years. When using your phone,
battery, charger, or any accessory:
•Keep it and all its parts and accessories out of
small children’s reach.
• Keep it dry. Precipitation, humidity and liquids
contain minerals that will corrode electronic
circuits.
•Do not use or store it in dusty, dirty areas as its
moving parts can be damaged.
•Do not store it in hot areas. High temperatures
can shorten the life of electronic devices, damage
batteries, and warp or melt certain plastics.
•Do not store it in cold areas. When the phone
warms up (to its nomal operating temperature),
moisture can form inside the phone, which may
damage the phone’s electronic circuit boards.
•Do not drop, knock or shake it. Rough handling
can break internal circuit boards.
Other Important Safety Information
• Only qualified personnel should service the
phone, or install the phone in a vehicle. Faulty
installation or service may be dangerous and
may invalidate any warranty which may apply to
the unit.
• Check regularly that all wireless phone
equipment in your vehicle is mounted and
operating properly.
• Do not store or carry flammable liquids, gases or
explosive materials in the same compartment as
the phone, its parts or accessories.
• For vehicles equipped with an air bag, remember
that an air bag inflates with great force. Do not
place objects, including both installed or
portable wireless equipment in the area over the
air bag or in the air bag deployment area. If in
vehicle wireless equipment is improperly
installed and the air bag inflates, serious injury
could result.
• Switch off your phone before boarding an
aircraft. The use of wireless phones in aircraft
may be dangerous to the operation of the
aircraft, and may be illegal.
• Failure to observe these instructions may lead to
the suspension or denial of telephone services
to the offender, or legal action, or both.
Health and Safety Information Health and Safety Information
92
•Do not use harsh chemicals, cleaning solvents, or
strong detergents to clean it. Wipe it with a soft
cloth slightly dampened in a mild soap-and-water
solution.
•Do not paint it. Paint can clog the device’s moving
parts and prevent proper operation.
•Use only the supplied or an approved replacement
antenna. Unauthorized antennas, modifications of
attachments could damage the phone and may
violate regulations governing radio devices.
• If the phone, battery, charger, or any accessory is
not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if neccessary, arrange for service.
Health and Safety Information
93
G l o s s a r y
Airtime -Actual time spent talking on the wireless
phone. Most carriers bill customers based on
how many minutes of airtime they use each
month.
Antenna -A device for transmitting or receiving
signals. The size and shape of antennas is
determined, in part, by the frequency of the
signal they receive. Wireless phones and the
base station must have antennas.
Base Station - The fixed radio transmitter/receiver that
maintains communications with mobile
radio telephones within a given area.
(Typically called a cell or cell site)
CDMA -(Code Division Multiple Access) A spread-
spectrum approach to digital transmission.
With CDMA, each conversion is digitized and
then tagged with a code. The mobile phone
deciphers only a particular code to pick the
right conversation off the air. The transmitted
signal is just above noise level across the
available bandwidth.
Channel - Communications signals transmit along paths
called channels.
Codec - Compression & Decompression.
Deactivation -The process of rendering a wireless
phone inactive.
95
G l o s s a r y
94
G l o s s a r y
LED -(Light Emitting Diode) Commonly used to refer to
a small light on the wireless phone or on the
Desktop Charger. The LED lights on the phone to
indicate an incoming call. The lights on the
charger indicate that battery charging is taking
place.
Prepend -The addition of a prefix, such as an area
code, to a phone number.
RF - Radio Frequency
Roaming -The ability to use a wireless phone to make
and receive calls in places outside of the
home service area.
Service Charge -The amount paid each month to
receive wireless service.
Standby Time -The amount of time a fully charged
wireless portable or transportable
phone can be on and idle without being
in use. (See Talk Time)
Talk Time -The length of time a person can talk on a
portable or transportable wireless phone
without recharging the battery.
Vocoder - Voice Coder. A device used to convert speech
into digital signals.
Wireless - Radio-based Systems that allow
transmission of telephone or data signals
through the air without a physical
connection, such as a metal wire (copper) or
fiber optic cable.
DTMF - (Dual-tone Modulated Frequency ) You send
DTMF signals when you enter numbers by
pressing the digit keys.
EVRC -(Enhanced Variable Rate Codec) EVRC is a new
global standard for compressing and
decompressing voice signals. EVRCuses a lower
bit rate (the number of bits sent per second)
than existing CDMA vocoders, while providing
significant improvements in voice quality. This
technology enables your phone to provide
superb voice quality while benefiting from the
ability to process more cellular voice calls using
less bandwidth than the voice codecs in CDMA
networks today.
Frequency -A measure based on time, as one or more
waves per second, in an electrical or light
wave information signal. A signal’s
frequency is stated in cycles-per-second or
Hertz (Hz).
Hands-Free -A feature that permits a driver to use a
wireless phone without lifting or holding
the handset - an important safety feature
for automobiles, tractors and most other
motorized vehicles.
LCD -(Liquid Crystal Display) Commonly used to refer to
the screen display on the wireless phone.
Licensed by QUALCOMM Incorporated under one or more
of the following Patents.
U.S Patent No. 4,901,307 5,056,109 5,099,204
5,101,501 5,103,459 5,107,225
5,109,390
