Samsung Electronics Co SCHN356 Single-Mode Cellular Phone (CDMA) User Manual SCH N213 FCC
Samsung Electronics Co Ltd Single-Mode Cellular Phone (CDMA) SCH N213 FCC
Users Manual
* Some of the contents of this manual may differ from your phone,
depending on the software installed or your service provider.
World Wide Web
http://www.samsungmobile.com
Printed in China
Code No.: GH68-XXXXX
English. 04/2004. Rev.1.0
ELECTRONIC
S
PORTABLE CELLULAR
TELEPHONE
SCH-N356
User’s Manual
3
1
Contents
IMPORTANT SAFETY PRECAUTIONS ............. 5
UNPACKING ................................................. 7
YOUR PHONE................................................ 8
Phone Layout ............................................. 8
Display.................................................... 11
Backlight ................................................. 12
GETTING STARTED ..................................... 13
Installing a Battery ................................... 13
Charging the Battery................................. 14
Switching On or Off the Phone.................... 16
Using the Soft Keys................................... 17
Your Phone’s Modes .................................. 18
CALL FUNCTIONS ....................................... 21
Making a Call ........................................... 21
Answering a Call....................................... 28
Silencing the Call Ringer............................ 28
Options During a Call ................................ 29
Using Caller ID ......................................... 30
Viewing Missed Calls ................................. 30
Call Forwarding ........................................ 31
Call Waiting ............................................. 31
Three-Way Calling .................................... 32
ENTERING TEXT ......................................... 33
Changing the Text Input Mode.................... 34
Using T9(English) Mode ............................. 35
Using Alphabet Mode................................. 36
Using Symbol Mode................................... 38
Using Number Mode.................................. 38
Contents
2
USING THEMENUS...................................... 39
Accessing a Menu Function by Scrolling....... 39
Using Shortcuts........................................ 40
List of the Menu Functions.......................... 41
PHONE BOOK ............................................. 45
Find
(Menu 1-1)
.......................................... 45
Add Entry
(Menu 1-2)
.................................. 48
Groups
(Menu 1-3)
...................................... 51
Memory Status
(Menu 1-4)
........................... 52
MESSAGE ................................................... 53
Write
(Menu 2-1)
........................................ 53
Inbox
(Menu 2-2)
........................................ 56
Outbox
(Menu 2-3)
...................................... 57
Draft
(Menu 2-4)
......................................... 57
Templates
(Menu 2-5)
................................. 58
Erase Messages
(Menu 2-6)
.......................... 59
Settings
(Menu 2-7)
.................................... 59
Voice Mail
(Menu 2-8)
.................................. 61
SMS Groups
(Menu 2-9)
.............................. 62
CALL HISTORY ........................................... 63
Missed
(Menu 3-1)
...................................... 63
Received
(Menu 3-2)
................................... 65
Dialled
(Menu 3-3)
...................................... 65
Erase History
(Menu 3-4)
............................. 65
Call Duration
(Menu 3-5)
.............................. 66
SOUND ....................................................... 67
Ring Tones
(Menu 4-1)
................................ 67
Ringer Volume
(Menu 4-2)
............................ 68
Alerts
(Menu 4-3)
........................................ 69
Key Tone
(Menu 4-4)
................................... 69
Power On/Off Melody
(Menu 4-5)
.................. 70
Contents
3
DISPLAY .................................................... 71
Language
(Menu 5-1)
.................................. 71
Service Area
(Menu 5-2)
.............................. 71
Wallpaper
(Menu 5-3)
.................................. 71
Banner
(Menu 5-4)
...................................... 72
Backlight
(Menu 5-5)
................................... 72
LCD Contrast
(Menu 5-6)
............................. 73
ORGANISER ............................................... 74
Scheduler
(Menu 6-1)
.................................. 74
Task List
(Menu 6-2)
.................................... 78
Memo Pad
(Menu 6-3)
................................. 79
Alarm
(Menu 6-4)
........................................ 80
Calculator
(Menu 6-5)
.................................. 81
World Time
(Menu 6-6)
................................ 82
Countdown
(Menu 6-7)
................................ 83
SETTINGS................................................... 85
Call
(Menu 7-1)
........................................... 85
Phone/System
(Menu 7-2)
............................ 88
Security
(Menu 7-3)
.................................... 90
GAME ......................................................... 93
Settings
(Menu 8-1)
.................................... 93
Games
(Menu 8-2)
...................................... 94
HEALTH AND SAFETY INFORMATION ......... 95
Exposure to Radio Frequency (RF) Signals.... 95
For Body Operation................................... 97
Precautions When Using Batteries ............... 98
Road Safety ............................................. 99
Operating Environment............................ 100
Electronic Devices................................... 100
Potentially Explosive Envirionments........... 102
Contents
4
Emergency Calls..................................... 103
Other Important Safety Information .......... 104
Care and Maintenance............................. 105
GLOSSARY................................................ 107
INDEX ...................................................... 111
5
Important Safety
Precautions
Read these guidelines before using your wireless
phone. Failure to comply with them may be
dangerous or illegal.
Road Safety at All Times
Do not use a hand-held phone while driving; park
the vehicle first.
Switching Off When Refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switching Off in Aircraft
Wireless phones can cause interference. Using
them in an aircraft is both illegal and dangerous.
Switching Off in Hospitals
Switch off your phone near medical equipment.
Follow any regulations or rules in force.
Interference
All wireless phones may be subject to
interference, which could affect their performance.
Special Regulations
Meet any special regulations in force in any area
and always with off your phone whenever it is
forbidden to use it, or when it may cause
interference or danger (in a hospital for example).
Important Safety Precautions
6
Sensible Use
Use only in the normal position (held to the ear).
Avoid unnecessary contact with the antenna when
the phone is switched on.
Emergency Call
Ensure the phone is switched on and in service.
Key in the emergency number for your present
location, then press . You must deactivate any
unnecessary features before you can make an
emergency call. Give all the necessary information
as accurately as possible. Do not cut off the call
until given permission to do so.
Water Resistance
Your phone is not water-resistant. Keep it dry.
Accessories and Batteries
Use only Samsung-approved accessories and
batteries. Use of any unauthorised accessories
could damage your phone and may be dangerous.
Qualified Service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see “Health
and Safety Information” on page 95.
CAUTION
RISK OF EXPLOSION IF A BATTERY IS
REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO
THE INSTRUCTIONS.
7
Unpacking
Your package contains the following items. The
illustrations below may look different from your
phone and accessories:
In addition, you can obtain the following
accessories for your phone from your local
Samsung dealer:
• Standard Battery
•Travel Adapter
• PC Link Cable
• Car Charger
• Straight Headset
Handset Travel Adapter
User’s Manual &
Warranty Card Battery
8
Your Phone
Phone Layout
The following illustrations shows the main
elements of your phone.
Earpiece
Display
Adapter jack
Headset
jack
Microphone
Soft key
(left)
Send key
Soft key (right)
Power on/off/
End key
Alphanumeric
keys
Special
function keys
Cancel/
Clear key
Navigation
keys
Your Phone
9
Keys
Key
(s)
Description
(soft keys)
Performs the functions indicated by
the text above them, on the bottom
line of the display.
In Menu mode, scrolls through the
menu options.
In Standby mode, quickly enters the
following menus respectively:
• :
Messages
• :
Phone Book
• :
Scheduler
• :
Sound
Deletes characters from the display.
In Menu mode, returns to the
previous menu level.
Makes or answers a call.
In Standby mode, retrieves the most
recent numbers dialled, received, or
missed. Redials the last number when
pressed and held.
Ends a call. Also switches on and off
the phone when pressed and held.
In Menu mode, cancels your input
and returns to Standby mode.
Your Phone
10
Enters numbers, letters, and some
special characters.
Enters 1-Beep mode when pressed
and held.
In Standby mode, activates Key
Guard mode when pressed and held.
In the text entry mode, changes the
case of letters.
In Standby mode, quickly enters or
exits Vibrate mode when pressed and
held.
In the text entry mode, inserts a
space.
Key
(s)
Description
(continued)
Your Phone
11
Display
The display has three areas: the top line of icons,
the text and graphic area, and the bottom line of
soft key indicators.
Icons
Icon Description
Signal Strength
: Shows the received
signal strength. The greater the number
of bars, the better the signal.
Service
: Appears when a call is in
progress.
No Service
: Appears when you are
outside a service area. When it displays,
you cannot make or receive calls. Wait a
little while for a better signal or move
into an open area to regain service.
Roaming
: Appears when you are out of
your home area and have logged onto a
different network; for example, when
travelling in other countries.
Icons
Text and graphic
area
Soft key
indicators
Your Phone
12
Backlight
The backlight illuminates the display and keypad.
When you press any key, the backlight illuminates.
It turns off if no key is pressed within a given
period of time, depending on your setting in the
Backlight
menu (
Menu 5-5
).
To specify the length of time the phone waits
before the backlight turns off, set the
Backlight
menu; see page 72 for further details.
New Message
: Indicates that there is a
new message waiting to be checked.
Alarm
: Appears when you set an alarm
to ring at a specified time.
Vibration
: Appears when your phone is
in Vibrate mode or it is set to vibrate
when a call comes in the
Ringer
Volume
menu.
1x
: Appears when your phone is in 1x
mode.
Battery Status
: Shows the level of
your battery. The more bars you see,
the more power you have remaining.
Icon Description
(continued)
13
Getting Started
Installing a Battery
Your phone is powered by a rechargeable Li-ion
battery. Use only approved batteries and
chargers. Ask your local Samsung dealer for
further details.
Note
: You must fully charge the battery before using
your phone for the first time. A discharged
battery is fully recharged in approximately
120 minutes for a standard battery.
Installing the Battery
1. Remove the battery cover by pressing down
the groove and then sliding the cover out.
2. Place the battery into the battery slot, making
sure that the metal contacts is facing down.
Getting Started
14
3. Place the battery cover, as shown, and slide it
toward the top of the phone until it clicks into
place.
Charging the Battery
Your phone is powered by a rechargable Li-ion
battery. A travel adapter comes with your phone.
Use only approved batteries and chargers. Ask
your local Samsung dealer.
You can use the phone while the battery is being
charged, but this will cause the battery to charge
more slowly.
1. With the battery in position on the phone, plug
the connector of the travel adapter into the
adapter jack at the bottom of the phone.
Getting Started
15
2. Plug the adapter into a standard AC wall outlet.
The Battery Strength icon on the display
repeats filling and emptying itself to indicate
that the battery is charging.
3. When charging is finished, unplug the adapter
from both the power outlet and the phone by
pressing the buttons on both sides of the
connector and pulling the connector out.
Note
: Do not remove the battery from the phone
without unplugging the adapter while it is
charging. Otherwise, the phone may be
damaged.
Low Battery Indicator
When the battery is weak and only a few minutes
of talk time remain, the battery sensor will let you
know by blinking the empty Battery Strength icon
( ). You will hear a warning tone and a “Battery
is low” message will be repeated at regular
intervals on the display.
When the battery becomes too weak for the phone
to operate, it switches off automatically.
➀
➁
➀
Getting Started
16
Switching On or Off the Phone
1. Press and hold for more than one second
to switch on the phone.
The power-on image displays and an alert
sounds. When the your phone locates services,
it displays the current time and date. You can
now place and receive calls.
If the phone is out of the service area, the No
Service icon ( ) appears on the display. In
this case, you cannot place and receive calls.
You can try again later when service is
available.
Note
: You can change the display language in
the
Language
menu (
Menu 5-1
). See
page 71.
2. When you wish to switch off the phone, press
and hold for more than two seconds.
WARNING!
Do not switch on the phone when mobile phone
use is prohibited or when it may cause
interference or danger.
Note
: If your phone is in Key Guard mode, you first
need to unlock the keys by pressing and
.
Getting Started
17
Using the Soft Keys
Your phone offers a set of functions that allows
you to customise it. These functions are arranged
in menus and submenus, accessed using the two
soft keys marked and . Each menu and
submenu allows you to view and alter the settings
of a particular function.
The roles of the soft keys vary according to the
current function you are using; the labels on the
bottom line of the display just above each key
indicates its current role.
Example:
Press the left soft
key to access the
Menu mode.
Press the right soft
key to find a name
or number from
Phone Book.
Getting Started
18
Your Phone’s Modes
Standby Mode
Standby is the most basic state of your phone.
The phone goes into Standby mode soon after you
turn it on, or whenever you briefly press .
When your phone is in Standby mode, you will
typically see a wallpaper or banner message and
the current date and time. If you enter a phone
number, you can press to dial it, or press the
Save
soft key to save it in the internal Phone
Book.
Press at any time to return to Standby mode.
Be careful; if you are on a call when you press the
key, your phone disconnects the call and returns
to Standby mode.
Menu mode can be accessed when you are in
Standby mode.
Talk Mode
You can place and answer calls only when your
phone is turned on. During a call, the phone is in
the Talk mode. While you are in Talk mode,
pressing the
Menu
soft key gives you a list of
options. See page 29 for details on the options.
Getting Started
19
Power Save Mode
Your phone comes with a power save feature that
will automatically be activated if your phone is
unable to find a signal after 15 minutes of
searching.
While this feature is active, the phone’s battery
charge is conserved. The phone will automatically
recheck for a signal periodically. To manually force
the phone to recheck for a signal, press any key. A
message on the display lets you know when your
phone is operating in Power Save mode
Key Guard Mode
You can lock the keypad by pressing and holding
in Standby mode. By doing this, you can
prevent accidental key pressing.
To unlock the keypad, press and then . The
Lock icon ( ) displays in the soft key indicator
field.
When you have an incoming call or an alarm
occurs in Key Guard mode, the mode is
automatically deactivated and the phone goes to
Standby mode.
Note
: You can set the phone to automatically lock
the keypad after a specified period of time, in
the
Key Guard
menu (
Menu 7-2-1
). See
page 88.
Getting Started
20
Lock Mode
When you lock your phone using the
Lock
Mode
menu (
Menu 7-3-1
), you can receive messages
and calls, but you cannot place a call until you
unlock the phone.
For further details about locking and unlocking the
phone, see page 90.
Vibrate Mode
Vibrate mode disables all sounds on the phone.
This feature is best used in situations where the
phone might disturb others, such as in a meeting,
a library, or a theatre. You can switch your phone
to Vibrate mode with one touch of a key.
In Standby mode, press and hold down until
“Enter! Vibrate Mode” and the Vibrator icon ( )
display.
To exit and reactivate the previous sound settings,
press and hold again until “Exit! Vibrate
Mode” appears. The Vibrator icon no longer
displays.
1-Beep Mode
In 1-Beep mode, your phone beeps only once
when a call is incoming. You can switch your
phone to the 1-Beep mode with one touch of a
key.
In Standby mode, press and hold until “Enter!
1-Beep Mode” displays.
To exit and reactivate the previous sound settings,
press and hold again until “Exit! 1-Beep
Mode” displays.
21
Call Functions
Making a Call
To make a call:
1. In Standby mode, enter the area code and
phone number.
2. Press . The phone places the call to the
entered phone number.
Note
: If you have activated the
Auto Redial
menu
(
Menu 7-1-2
), the phone automatically
retries to make the call up to 10 times when a
connection fails. See page 85 for more
information.
Using the Dialling Options
While entering a phone number, you can use the
following options by pressing the
Options
soft
key.
Speed Dial
: allows you to use the speed dialling
feature. For details, see page 24. This option
displays only when you enter a number which can
be a Phone Book memory location.
4-digit Dial
: allows you to use the 4-digit dialling
feature. For details, see page 25. This option
displays only when you enter a 4-digit number.
Call
: places a call to the number you entered.
Save
: allows you to save the number you entered
in Phone Book. For details, see page 48.
Call Functions
22
Find
: allows you to find a number from Phone
Book. For details, see page 45.
Hard Pause
: enters a hard pause. For details
about pause-dialling, see page 25.
Correcting the Number
Ending a Call
When you want to finish your call, briefly press
.
The call time, or the length of the call, displays
briefly and the phone returns to Standby mode.
Making a Call from Phone Book
You can store the phone numbers that you use
regularly in the phone’s memory, which are
collectively called Phone Book. Simply select the
required name to recall the associated number to
dial.
For more information about the Phone Book
feature, see page 45.
To clear Press
the last digit
displayed .
the whole display for more than one
second.
Call Functions
23
Redialling the Last Number
To redial the last call you made, press twice or
press and hold it down.
Your phone stores the most recent 10 numbers
you dialled. To redial any of these numbers:
1. If you have typed any characters on the
display, press to return to Standby mode.
2. Press to display the list of the dialled
numbers.
You can scroll to the other types of calls,
missed and received calls, if any, by pressing
or .
3. Use and to scroll through the list until
the required number highlights.
4. To dial the number, press .
Emergency Dialling
You can place emergency call from your
emergency number list even if your phone is
locked. For more information on emergency
numbers, see page 91.
Call Functions
24
Speed Dialling
Once you have stored phone numbers in Phone
Book, you can dial them easily whenever you
want. You can assign up to 2000 numbers for
Speed Dialling.
For the Memory Locations of One Digit
Press and hold the digit of the memory location
containing the number to be dialled.
For example: Location no. 009
press and hold .
The stored number and name display and then the
phone dials the number.
For the Other Memory Locations
Press the first digit(s) briefly, then hold down the
last digit of the memory location.
For example: Location no. 023
Press briefly and hold down
.
The stored number and name display and then the
phone dials the number.
Note
: When several numbers are saved in one
location, only the phone number which is
specified with the Speed Dial label will be
automatically dialled. For details, refer to
page 49.
Call Functions
25
4-digit Dialling
You can quickly dial a phone number in Phone
Book by entering its last four consecutive digits.
Your phone searches Phone Book for the entire
number for you.
1. Enter the last consecutive digits of the number
you want to dial.
2. Press the
Options
soft key.
3. Select
4-digit Dial
and press the
Select
soft
key.
The phone displays the first entry matching
your input.
4. If there is more than one matching entry, scroll
to the number by pressing the Navigation
keys.
5. Press or
Call
soft key.
Pause Dialling
When you call automated systems, like banking
services, you are often required to enter a
password or an account number. Instead of
manually entering the numbers each time, you
can store them in your Phone Book or enter all of
them before dialling, separated by pauses.
Storing a number in your Phone Book that
contains pauses
1. Enter the phone number you want to store,
such as a bank’s teleservice phone number.
Call Functions
26
2. Press the
Options
soft key and then select
Hard Pause
.
The letter “P” displays within the number,
meaning that a hard pause will occur at that
point in the calling sequence.
3. Enter a number to follow the pause, such as
you account number or password.
4. Continue entering numbers by repeating steps
2 and 3.
5. Store the number in your Phone Book as you
normally would by pressing the
Save
soft key
and following the screen prompts.
Pause Dialling from a Stored Phone Book
Entry
1. Dial the number from the Phone Book.
2. Wait for the appropriate prompt for the
number, such as a credit card number or a
bank account number.
3. When prompted, press to send the DTMF
(Dual-tone Multi-frequency) number that
follows your pause.
Manual Pause Dialling
You can enter pauses manually during the dialling
process.
1. Enter the phone number of the service you
want to connect to, such as a bank’s
teleservice phone number.
Call Functions
27
2. Press the
Options
soft key and then select
Hard Pause
.
The letter “P” displays within the number,
meaning that a hard pause will occur at that
point in the calling sequence.
3. Enter a number to follow the pause, such as
you account number or password.
4. Continue entering numbers by repeating steps
2 and 3.
5. When the number is completed, press to
make a call to the number.
6. Each time you are prompted, press to send
the DTMF number that follows your pause.
Call Functions
28
Answering a Call
When someone calls you, the phone rings and
displays the incoming call image.
When the caller can be identified, the caller’s
phone number or name, if it is stored in your
Phone Book, displays. If the caller cannot be
identified, “Blocked ID” displays.
1. To answer a call, press .
If the
Answer Mode
menu (
Menu 7-1-1
) is
set to
Any Key
, you can answer the call by
pressing any key, except for and the
Silence
soft key.
If the menu is set to
Call Key
, you must press
to answer the call. For further details on
the
Answer Mode
menu, see page 85.
2. To end an answered call press .
Note
: You can answer a call while using the Phone
Book or menu features. The current operation
will be interrupted.
Silencing the Call Ringer
If you press or the
Silence
soft key once,
when a call is received, the phone stops ringing or
vibrating depending on the mode it is in.
You can still answer the call by pressing , or
press or the
End
soft key to disconnect
without answering the call.
Call Functions
29
Options During a Call
Your phone provides a number of control functions
that you can use during a call.
Press the
Menu
soft key during a call to access
the following options:
Phone Book
: allows you to access the
Phone
Book
menu. See page 45 for details.
Mute/Quit
: allows you to switch your phone’s
microphone off or on. When you mute the
microphone, the person with whom you are talking
cannot hear you.
For example: You wish to say something to
another person in the room but do not want the
the person with whom you are talking to hear you.
Silent/Quit
: allows you to switch the key tones
off or on. By switching the tones off, you can press
the keys without hearing annoying key tones
during a call.
Call History
: allows you to access the
Call
History
menu. See page 63 for details.
Messages
: allows you to use the
Messages
menu. See page 53 for details.
Organiser
: allows you to access the
Organiser
menu. See page 74 for details.
Voice Privacy
: encrypts the voice channel so that
people cannot eavesdrop on your conversation.
For further details, see page 92.
Call Functions
30
Using Caller ID
This feature tells you who is calling you by
displaying the caller’s number when the phone
rings. If a caller’s name and number are stored in
your Phone Book, the corresponding name
displays along with the number. If you call
someone whose phone is available with this
feature, your phone number displays on her or his
phone.
Note
: For further details about the Caller ID service,
contact your service provider.
Viewing Missed Calls
Your phone keeps a list of calls that you do not
answer when the phone is on and service is
available. The phone indicates a missed call by
displaying a text notification on the screen.
Additionally, if caller information is available, the
screen displays the phone number of the most
recent missed call.
Press to call the displayed number.
Press the
Save
soft key to save the displayed
number
To view missed calls, access the
Missed
menu
(
Menu 3-1
). For further details, see page 63.
Call Functions
31
Call Forwarding
When the
Call Forward
menu (
Menu 7-1-3
) is
enabled, your phone forwards incoming calls to
another phone or voice mail centre that you have
specified, even if your phone is turned off. For
further details, see page 86.
Activating Call Forwarding does not effect
outgoing calls made from your phone.
Note
: Contact your service provider for its
availability.
Call Waiting
When the
Call Waiting
menu (
Menu 7-1-4
) is
enabled, you can answer an incoming call while
you have a call in progress. For further details,
see page 87.
When a waiting call is detected, your phone alerts
you to a call waiting by beeping and displaying
“Call Waiting.”
Note
: Contact your service provider for its
availability.
To answer a waiting call:
1. Press and the current call is put on hold
and you can answer the waiting call.
2. Press again to switch between the two
calls.
Note
: If you do not answer a waiting call, the phone
will forward the call to voice mail centre or
another number that you have set up. Contact
your service provider for more information.
Call Functions
32
Three-Way Calling
This feature allows up to three people to take part
simultaneously in a call. The phone records each
call into the Dialled call history.
To place a Three-way call:
1. Enter a phone number of the second
participant, and press .
2. When you are connected to the second
participant, press to begin the three-way
call.
If one of the callers hangs up, the call ends with
that participant, but you can continue to talk with
the other participant. If you initiated the call and
you hang up first, all three people are
disconnected.
33
Entering Text
When using your phone, you will need to enter
text at many times; for example, when storing a
name in Phone Book, creating a text message, or
scheduling events in your calendar. You can enter
alphanumeric characters into your phone by using
your phone’s keypad.
Your phone has the following text input modes:
•
T9(English)
: This mode allows you to enter
words with only one keypress per letter. Each
key on a keypad has more than one letter; for
example, when you press once, J,K or L
displays. The T9(English) mode automatically
compares your key presses to an internal
linguistic database to determine the correct
word thus requiring far fewer keystrokes than
the traditional multi-tap method, Alphabet
mode.
•
Alphabet
: This mode allows you to enter
letters by pressing the key labelled with the
letter you want once, twice, or three times until
the letter displays.
•
Symbol
: This mode allows you to enter various
symbols, punctuation marks, and special
characters.
•
Number
: This mode allows you to enter
numbers.
Entering Text
34
Changing the Text Input Mode
When you are in a field that allows characters to
be entered, you will notice the text input mode
indicator on the display.
Example: When you are entering a name
To change the text input mode:
1. Press the
Options
soft key.
2. Scroll to the mode you want by pressing or
.
Note
: If you want to exit the menu without
changing to a new mode, press .
3. Press the
Select
soft key.
You will find the indicator of the selected text
input mode on the display.
Text input
mode indicator
Entering Text
35
Using T9(English) Mode
T9 is a predictive text input mode which allows
you to enter any character using single
keystrokes. This text input mode is based on a
built-in dictionary.
1. When you are in T9(English) mode, start
entering a word by pressing keys to .
Press each key only once for one letter.
Example: To enter “Hello” in T9 mode, press
, , , , and .
The word you are typing appears on the
display. It may change with each key press.
2. Type to the end of the word before editing or
deleting any keystrokes.
3. When the word displays correctly, skip to step
4.
If the word is not correct, press to display
alternative word choices for the keys that you
have pressed.
Example: both “Of” and “Me” have the
sequence of and . The phone
displays the most commonly used
choice first.
4. Put a space between words by pressing .
• To type words not found in T9(English) mode,
change the text input mode to Alphabet mode.
• To enter full stops, hyphens or apostrophes,
press . T9(English) mode applies grammar
rules to ensure that the correct punctuation is
used.
Entering Text
36
• To change the case in T9(English) mode, use
. There are three cases:
Word
: initial letter is capitalised.
word
: all letters are lower-cased.
WORD
: all letters are capitalised.
• You can enter a space by pressing .
• You can move the cursor through your text by
pressing the Navigation keys.
• To delete letters, press . Press and hold down
to clear the display.
• To enter a number between letters without
exiting T9 input mode, press and hold the
number key.
Using Alphabet Mode
When typing in Alphabet mode, you should press
the keys labelled with the letter you want:
- once for the first letter
- twice for the second letter
- and so on.
This method is called Multi-tap typing.
For example, you press three times to display
the letter “C” and two times to display the
“K.”
Note
: The cursor moves to the right when you press
a different key. When entering the same letter
twice or a different letter on the same key,
just wait for a few seconds for the cursor to
move to the right automatically, and then
select the next letter.
Entering Text
37
Refer to the table below for the list of characters
assigned to each key.
(Caps Lock mode)
• To change the case of the next letters that you
type, press . There are three cases:
: initial letter is capitalised.
: all letters are lower-cased.
: all letters are capitalised
• You can enter a space between words by
pressing .
• You can move the cursor through your text by
pressing the Navigation keys.
Key Characters in the Order Displayed
1 ! @ # % & < > _ +
= : ” ’ ( ) \ ? . , { } [
] ; - / $ ‘ ~ l ^
AB C 2
DE F 3
GH I 4
JKL 5
MN O 6
PQR S 7
TU V 8
WX Y Z 9
0
Entering Text
38
• To delete letters, press . Press and hold to
clear the display.
• To quickly enter a number between letters,
press and hold the number key.
Using Symbol Mode
Symbol mode allows you to enter symbols.
Press or to display more symbols.
Press the number keys corresponding to the
symbol you want. The phone automatically
switches back to the text entry mode used just
prior to selecting Symbol mode.
Using Number Mode
Number mode enables you enter numbers. Press
the keys corresponding to the digits you want, and
manually switch back to text input mode of
choice; see page 34 for changing the text input
mode.
39
Using theMenus
The phone offers a range of functions that allows
you to tailor it to your needs. These functions are
arranged in menus and submenus.
The menus and submenus can be accessed by
scrolling or by using the shortcuts.
Accessing a Menu Function by
Scrolling
1. In Standby mode, press the
Menu
soft key to
access Menu mode.
2. Press the Navigation keys to reach a main
menu; for example,
Display
. Press the
Select
soft key to enter the
Display
menu.
3. If the menu contains any submenus; for
example,
Language
, find the one you want by
pressing or . Press the
Select
soft key to
enter the submenu.
If the selected menu contains submenus,
repeat this step.
4. Press the Navigation keys to find the setting of
your choice.
5. Press the
OK
or
Select
soft key to confirm the
chosen setting.
Notes
:
• You can return to the previous menu level by
pressing the Back soft key or .
• You can exit the menu without changing the menu
settings by pressing .
Using theMenus
40
Using Shortcuts
The menu items, such as menus, submenus and
setting options, are numbered and can be
accessed quickly by using their shortcut numbers.
Note
: The numbers assigned to each menu function
are indicated on the list on page 41.
In Standby mode, press the
Menu
soft key to
access Menu mode.
6. Enter the first digit of the shortcut number.
Repeat this for each digit of the shortcut
number.
Example: Changing the display language
Press and .
5
selects
Display
and
1
selects the
Language
menu function.
7. Press the Navigation keys to find the setting of
your choice.
8. Press the
OK
or
Select
soft key to confirm the
chosen setting.
Using theMenus
41
List of Menu Functions
The following list shows the menu structure
available and indicates the number assigned to
each option.
1. Phone Book
(see page 45)
1.1 Find
1.2 Add Entry
1.2.1 Add Number
1.2.2 Add Email
1.2.3 Add URL
1.3 Groups
1.4 Memory Status
2. Message
(see page 53)
2.1 Write
2.2 Inbox
2.3 Outbox
2.3.1 Sent
2.3.2 Unsent
2.4 Draft
2.5 Templates
2.6 Erase Messages
2.6.1 Inbox
2.6.2 Outbox
2.6.3 Draft
2.6.4 All Messages
2.6.5 Voice Mail
2.7 Settings
2.7.1 Auto Scroll
2.7.2 Msg Reminder
2.7.3 New Messages
2.7.3.1 Save Messages
2.7.3.2 Entry Method
2.7.3.3 Delivery Ack
2.7.4 Alert On Call
2.8 Voice Mail
2.9 SMS Groups
Using theMenus
42
3. Call History
(see page 63)
3.1 Missed
3.2 Received
3.3 Dialled
3.4 Erase History
3.4.1 Missed
3.4.2 Received
3.4.3 Dialled
3.4.4 All
3.5 Call Duration
3.5.1 Last Call
3.5.2 Total Dialled Calls
3.5.3 Total Received Calls
3.5.4 Reset All
3.5.5 Life Time
4. Sound
(see page 67)
4.1 Ring Tones
4.1.1 Calls
4.1.2 Messages
4.1.3 Schedules
4.2 Ringer Volume
4.2.1 Calls
4.2.2 Messages
4.2.3 Alarm/Schedules
4.3 Alerts
4.3.1 Call Connect
4.3.2 Call Disconnect
4.3.3 Privacy
4.4 Key Tone
4.4.1 Tone Volume
4.4.2 Tone Length
4.5 Power On/Off Melody
Using theMenus
43
5. Display
(see page 71)
5.1 Language
5.2 Service Area
5.3 Wallpaper
5.4 Banner
5.5 Backlight
5.6 LCD Contrast
6. Organiser
(see page 74)
6.1 Scheduler
6.1.1 Today
6.1.2 All
6.2 Task List
6.3 Memo Pad
6.4 Alarm
6.4.1 Daily Alarm
6.4.2 Weekly Alarm
6.5 Calculator
6.6 World Time
6.7 Countdown
7. Settings
(see page 85)
7.1 Call
7.1.1 Answer Mode
7.1.2 Auto Redial
7.1.3 Call Forward
7.1.4 Call Waiting
7.2 Phone/System
7.2.1 Key Guard
7.2.2 Set Time
7.2.3 Set NAM
7.2.4 Version
7.3 Security
7.3.1 Lock Mode
7.3.2 Change Code
7.3.3 Emergency Numbers
7.3.4 Voice Privacy
7.3.5 Clear Phone Book
7.3.6 Reset Phone
Using theMenus
44
8. Game
(see page 93)
8.1 Settings
8.1.1 Volume
8.1.2 Backlight
8.2 Games
8.2.1 Child Monk Adventure
8.2.2 Black Planet
8.2.3 Cushion Tank
8.2.4 Hello Monkey
8.2.5 Bowling
8.2.6 Othello
During a Call + Menu
1: Phone Book
2: Mute/Quit
3: Silent/Quit
4: Call History
5: Messages
6: Organiser
7: Voice Privacy
45
Phone Book
The Phone Book allows you to store frequently-
used phone numbers and the associated names in
your personal directory to make it easy for you to
make a call without remembering or entering the
phone number. You can store up to 2000 entries.
Each entry can contain up to 32 digits including
hard pauses, with an associated name of up to 20
characters.
Note
: You can quickly access this menu by pressing
in Standby mode.
Find
(Menu 1-1)
In this menu, you can search Phone Book for an
entry using a name, entry number, and group
name.
Note
: You can quickly access this menu by pressing
the
Find
soft key in Standby mode.
Press a search method by pressing or .
By Name
This option allows you to find an entry by entering
a person’s name.
1. Press or to scroll to the name you want.
To find an entry with a name, enter the first
letters of the name you want to find. The
phone searches for the first entry starting with
that character.
Phone Book
46
2. When the entry highlights, press the
Select
soft key to access the entry.
Note
: All of the numbers stored for the entry
display, including numbers stored into
different categories. Press
or
to
find the number you want.
When you press the
Options
soft key, the
following options are available:
Edit
: allows you to edit the phone number, name,
location number, label category and so on.
Prepend
: allows you to add digits such as area
codes and network feature activation codes to the
phone number before dialling it.
Erase
: erases the number.
Send Msg
: allows you to write and send a
message to the number. For details, see page 53.
By Entry
This option allows you to find an entry by entering
its entry number.
1. Enter the location by pressing the numeric
keys.
3.
To Press
place a call to the
number or the
Call
soft key.
use the menu
options the
Options
soft key.
For details, see below.
Phone Book
47
By Group
This option allows you to find an entry by selecting
its caller group.
1. Press to highlight the group selection field.
2. Select the group containing the entry you want
to find by pressing or .
The phone displays the list of all entries in the
selected group.
3. Scan through the list using or to find the
entry you want and press the
Select
soft key.
2.
To Press
place a call to the
number or the
Call
soft key.
use the menu
options the
Options
soft key.
For details, see
page 46.
4.
To Press
place a call to the
number or the
Call
soft key.
use the menu
options the
Options
soft key. For
details, see page 46.
Phone Book
48
Add Entry
(Menu 1-2)
This menu allows you to store a number with a
name in your Phone Book. You can save a person’s
numbers, such as workplace number, mobile
phone number and fax number, into one entry. A
Phone Book entry can contain up to six numbers,
one in each category.
Add Number
(Menu 1-2-1)
1. Enter a phone number and press the
Save
soft
key.
2. Press the
Select
soft key to confirm adding a
new entry.
When you are storing a number for the first
time, skip to step 3.
Note
: If you want to add the number to an
existing entry, select it from the list.
3. Enter a name and press the
Next
soft key.
For further details about entering characters,
see page 33.
4. Select an icon to label the category of the
number to be stored using the Navigation keys
and press the
Select
soft key.
5. To select an option, scroll to it by pressing
or . Press the
Edit
soft key to enter
information or use or to change the
setting.
Phone Book
49
The following options are available for the
entry:
•
Enter Name
: allows you to edit a name of
up to 20 characters.
•
Entry
: The first available location displays. If
necessary, enter the entry number using the
number keys.
•
Home
/
Office
/
Mobile
/
Pager
/
Fax
/
No
Label
: allows you to store more numbers for
each category.
•
Speed Dial
: allows you to select one of the
stored numbers to be dialled when you press
or the
Call
soft key after selecting the
entry or when you use the Speed Dialling
feature.
•
Email
: allows you to store an e-mail
address.
•
URL
: allows you to store a URL address.
•
Group
: allows you to assign an entry to a
caller group. To remove the entry from a
group, select
No Group
.
•
Name Ringer
: allows you to select the
unique ringer to be used for alerting you to
an incoming call from the person.
•
Secret
: allows you to prevent a number from
being displayed when it is accessed or dialled
by unauthorised users. When this option is
set to
On
, only people with your phone’s lock
code can view the secret number.
Phone Book
50
6. When you finish setting the options, press the
Save
soft key to store the entry.
After storing, the phone displays the name that
you just saved and then the total number of
the Phone Book entries you have stored.
Add Email
(Menu 1-2-2)
This menu allows you to add a new entry by
entering an e-mail address.
1. Enter an e-mail address and press the
Next
soft key.
For further details about entering characters,
see page 33.
2. Enter a name and press the
Next
soft key.
3. To complete storing the e-mail address, follow
the procedure from step 5 in “Add Number” on
page 48.
Add URL
(Menu 1-2-3)
This menu allows you to add a new entry by
entering a URL address of a web page.
1. Enter an URL address and press the
Next
soft
key.
2. Enter a name. For further details about
entering characters, see page 33.
3. Press the
Next
soft key.
4. To complete storing an URL address, follow
from step 5 in “Add Number” on page 48.
Phone Book
51
Groups
(Menu 1-3)
This menu allows you to change the ringers and
the names for the caller groups.
To change the ringer for a caller group:
1. Scroll to the group you want to edit using
or
.
2. Press the
Ringer
soft key to select a ringer
melody to indicate when a call comes in from
any members of the group.
3. Select the ringer category you want by
pressing or and press .
4. Select the ringer melody you want by pressing
or .
5. Press the
Select
soft key.
To change the name of a caller group:
1. Press or to scroll to the group you want
to edit.
2. Press the
Rename
soft key.
3. Press to clear the current group name.
4. Enter a new name and press the
Save
soft
key.
For further details about entering characters,
see page 33.
Phone Book
52
Memory Status
(Menu 1-4)
This menu shows the total number of entries that
currently stored in your Phone Book.
53
Message
Your phone can send and receive text messages.
It can also receive voice mail notifications.
When the phone receives a message, an alert
sounds and a text notification displays along with
the name and phone number of the sender, if
available. The New Message icon ( ) remains on
the screen until you read the new text messages
or you listen to the new voice mail messages.
Messages are received even when your phone is in
Lock mode. However, the screen does not display
information about the message. To access a
message, you must unlock the phone.
If you receive an incoming message during a call,
your phone automatically mutes the ringer. This is
to avoid ringing in your ear while you are trying to
converse.
Note
: You can quickly access the
Message
menu
by pressing in Standby mode.
Write
(Menu 2-1)
You can create a text message of up to 140
characters and send it to other mobile phones.
To write a new message:
1. Enter the message text.
For further details about how to enter text, see
page 33.
Press the
Options
soft key and select
Templates
to add a message template. For
further details about templates, see page 58.
Message
54
2. When you finish entering text, press the
Next
soft key.
3. Enter a destination number using the numeric
keys.
Pressing the
Find
soft key allows you to search
your Phone Book for a number.
Note
: You can enter more numbers by entering a
space between them using . You can
send to 10 destinations at the same time.
4. When you finish entering, press the
Next
soft
key.
5. To select an option, press or and press
the
Edit
soft key and enter information or
change the setting. The following options are
available:
•
Msg
: allows you to change the message
contents you’ve already entered.
•
Send To
: allows you to change the
destination phone number.
•
Settings
: allows you to change the message
options in order.
After changing the first option, press the
Next
soft key. You can then set the next
options. When you set the last option and
press the
OK
soft key, the settings are saved
and the display returns to the New message
screen.
Priority: you can select a message priority.
Validity: you can select the length of time for
which your message is stored at the message
centre while attempts are made to deliver
them to the recipient.
Message
55
Send Later: you can select the length of time
for which the delivery of the message will be
delayed at the message centre, if you don’t
want to send it immediately.
Delivery Ack: select
Yes
to be informed
whether or not your message has been
delivered to the recipient by your network.
Save Message: you can set whether or not
the phone saves the message in the Outbox.
When you select
Prompt Save
, the phone
asks if you want to save the message when
you attempt to send it.
Note
: The
Delivery Ack
,
Save Message
options can be preset in the
New
Messages
menu (
Menu 2-7-3
); for
details, see page 60.
•
Save Msg
: to store the message in the
Draft
menu (
Menu 2-4
) for future use,
press the
Save
soft key.
6. After changing the setting options, press or
the
Send
soft key to send the message.
Message
56
Inbox
(Menu 2-2)
Your phone can store up to 50 messages total in
Inbox, Outbox and the Draft box. When the
memory is full, a warning message displays and
the phone rejects additional messages until you
erase the obsolete ones.
When you access the
Inbox
menu option, the
message list appears.
To view details, press or to scroll to one of
the messages on the list and press the
Select
soft
key. You can scan through the message contents
by pressing or .
While viewing a message, press the
Reply
soft
key to send a reply message to the sender.
Press the
Options
soft key to use the following
options:
Erase
: erases the message from the Inbox.
Forward
: allows you to forward the message to
another person.
Call
: places a call to the callback number of the
message.
Save
: allows you to save the callback number of
the message.
Message
57
Outbox
(Menu 2-3)
Your phone can store up to 50 messages total in
Inbox, Outbox and the Draft box.
In the
Outbox
menu option, you can review
outgoing messages separately depending on their
message type,
Sent
or
Unsent
. When you select
a message type, the message list appears.
To review a message, press or to scroll to it
and press the
Select
soft key. You can scan
through the message contents by pressing or
.
While reviewing a message, press the
Resent
soft
key to resent the message. Press the
Erase
soft
key to erases it from Outbox.
Draft
(Menu 2-4)
Your phone can store draft messages that are yet
to be sent in the Saved message box. If you save
the message content using the
Save Msg
menu
option before sending it (see page 55), you can
access them using this menu.
To review a stored message. press or to
scroll to it and press the
Select
soft key. You can
scan through the message contents by pressing
or .
While reviewing a message, press the
Send
soft
key to send the message. Press the
Erase
soft
key to erases it.
Message
58
Templates
(Menu 2-5)
Using this menu, you can preset up to ten
messages that you use most frequently and send
a new message using one of them.
When you access this menu, the preset message
list displays.
To preset a message:
1. Scroll to a message or an empty entry by
pressing or .
2. Press the
Edit
soft key.
3. If necessary, clear the text by pressing and
enter your message.
For further details about how to enter
characters, see page 33.
4. When you are finished, press the
Save
soft
key.
To send a new message using a message
template:
1. Scroll to the message you want by pressing
or .
2. Press the
Select
soft key to send the
message.
3. Follow step 3 on page 54.
Message
59
Erase Messages
(Menu 2-6)
Using this menu, you can erase the messages in
each message box; Voice Mail box, Inbox, Outbox,
and Draft box. For the Inbox, you can erase only
the messages you read or all of the messages. For
the Outbox, you can erase only the message the
phone sent or couldn’t send, or all misusages
You can also erase all of the messages at one time
by selecting
All Messages
.
When a confirmation message appears, press the
Yes
soft key.
Settings
(Menu 2-7)
In this menu, you can preset several options for
using the messaging features.
Auto Scroll
(Menu 2-7-1)
If an incoming message is too long for the display,
the phone displays it by scrolling the screen
automatically. You can set how often the phone
scrolls the message to the next screen.
If you select
Off
, you need to scroll to the next
screen manually by pressing or .
Message
60
Msg Reminder
(Menu 2-7-2)
When a message is received, the phone alerts you
by sounding the selected ringer. You can set how
often you want to be alerted.
Off
: the message alert sounds once when the
message is received.
Once
: the message alert sounds once when the
message is received and sounds again after 2
minutes.
Every 2 min
: the message alert sounds every 2
minutes until you check the message.
New Messages
(Menu 2-7-3)
You can set up the default settings of the options
for creating a new message. The following options
are available:
Save Message
: allows you to set whether or not
you want the transmitted message to be saved in
the Outbox.
Do Not Save: the phone does not save the
message.
Prompt Save: the phone asks you if you want to
save the message or not.
Auto Save: the phone automatically saves the
message.
Entry Method
: allows you to select the text input
mode, either T9 (English) mode or Alphabet
mode.
Delivery Ack
: allows you to receive a delivery
report to let you know that your message is
correctly delivered.
Message
61
Alert On Call
(Menu 2-7-4)
This menu allows you to choose whether or not
the phone informs you when you receive a new
message during a call.
On
: the phone alerts you with a beep and displays
the corresponding notification.
Off
: the phone doesn’t actively alert you to
incoming messages. It only displays the
corresponding notification.
Voice Mail
(Menu 2-8)
When multiple new voice messages are received
but you haven’t checked them, information of the
last one displays. The information display includes
the time/date stamp, the number of new voice
messages and the callback number.
While reviewing the message, press the soft key
to access the following options:
Listen
: allows you to listen to the voice message.
The phone automatically dials the number of your
voice mail centre.
Reset
: clears the New Message icon and resets
the counter for a new voice message, if necessary.
The phone resets the counter automatically after
you listen to all of the new messages.
Message
62
SMS Groups
(Menu 2-9)
Using this menu, you can preset up to 5 SMS
groups that you send a message most frequently.
Scroll to the group you want by pressing the or
key.
• Press the
Options
soft key to view members,
clear or rename the group. You can add
members to the group at View Members option.
• Press the
Send
soft key to send the message to
the group.
63
Call History
You can use the
Call History
menu to:
• view and dial the most recent calls you dialled,
received, or missed.
• erase the numbers in the call log memory.
• view the length of calls.
Note
: You can quickly access the history of all the
three call types by pressing in Standby
mode.
Missed
(Menu 3-1)
If Caller Line Identification service is available,
your phone keeps a list of the most recent 10
incoming calls that you failed to answer. Contact
your service provider for more information about
the service.
When you access this menu, a list of the missed
calls displays.
1. Press or to find a number or name, if it
is saved in Phone Book.
2. Press the
Select
soft key to confirm the
highlighted number.
The missed number or name, if it is saved in
Phone Book, displays along with the time and
date when the call was received.
Call History
64
When you press the
Options
soft key on the call
log list, the following options are available:
Save
: (shows when the number is not stored in
your Phone Book) allows you to save the number
in Phone Book.
Show Entry:
(shows when the number is stored
in your Phone Book) displays the detailed
information stored in the Phone Book entry, such
as a name, entry number, phone numbers, speed
dial number, and other settings.
Edit
: allows you to change the phone number and
then dial it or save it in Phone Book.
Erase
: erases the selected number.
Send Msg
: allows you to send a message. See
page 53 for more information.
3.
To Press
place a call to the
selected number or the
Call
soft key.
use the options the
Options
soft key.
For details, see below.
exit the call log .
Call History
65
Received
(Menu 3-2)
This option lets you view up to 10 of the most
recent calls you received, if you are subscribed to
the Caller Line Identification service. Contact
service provider for more information about this
service.
When you access this menu, a list of the incoming
calls displays.
For more information about scrolling through the
list and accessing the call log, see “Missed” on
page 63.
Dialled
(Menu 3-3)
The phone stores up to 10 of the most recent calls
you dialled. When you access this menu, a list of
the outgoing calls displays.
For more information about scrolling through the
list and accessing the call log, see “Missed” on
page 63.
Erase History
(Menu 3-4)
You can erase the entries stored in each of the
three call histories or all three histories at once.
When a confirmation message displays, press the
Yes
soft key.
Call History
66
Call Duration
(Menu 3-5)
Your phone records the amount of air time, or talk
time, used. Using this option, you can view the
number of the calls to or from your phone, and the
air time for all of the calls. You can easily erase
the air time records at any time. This option is
convenient for estimating your usage.
Note
: This feature is not intended to be used for
billing purposes.
The following options are available:
Last Call
: shows information about the last call,
such as the duration of the call, the other person’s
phone number and the date and time when the
call was made.
Total Dialled Calls
: shows the number of all calls
you have made and the total duration of the calls
since the time counter was last set to zero by
using the
Reset All
option.
Total Received Calls
: shows the number of all
calls you have received and the total duration of
the calls since the time counter was last set to
zero by using the
Reset All
option.
Reset All
: erases the last call, the “Total
received/dialled calls” time measurements, and
resets the air time counters.
Life Time
: shows the number and total duration
of all calls made to or from your phone since the
phone was shipped from the factory.
67
Sound
You can use the
Sound
menu to customise
various sound settings, such as the:
• ringer volume, type, and tone.
• key tone and alert sounds.
• sound which plays when the phone is switched
on or off.
Note
: You can quickly enter this menu by pressing
in the standby mode.
Ring Tones
(Menu 4-1)
This menu allows you to set the unique ringer
melodies for the following items:
Calls
: allows you to set a unique ring for incoming
calls.
Messages
: allows you to have a distinctive ring
for incoming text and voice mail messages
independently.
Schedules
: allows you to have a distinctive ringer
for schedule alarms.
1. Select a ringer category for
Calls
, or select a
message type for
Messages
by pressing or
.
For
Schedules
, skip to step 2.
2. Select a ringer by pressing or .
Each time you select a ringer, the phone plays
the ringer.
3. Press the
Select
soft key.
Sound
68
Ringer Volume
(Menu 4-2)
This menu allows you to adjust the ringer volume.
Calls
: allows you to adjust the ringer volume for
incoming calls.
Messages
: allows you to adjust the ringer volume
for incoming messages.
Alarm/Schedules
: allows you to adjust the
ringer volume for alarm settings and schedule
alarms.
To adjust the volume level for each item, the
following options are available:
Light: the phone does not sound a ring.
Vibrate: an incoming call vibrates the phone.
1-Beep: the phone sounds a beep.
Level 1 ~ 5: adjust the volume level. The more
bars, the louder.
Low + Vib/High + Vib: the phone rings in the
lowest/highest volume level and then vibrates.
This option is only shown for
Calls
.
Note
: When “Emergency call only” appears after you
end an emergency call, the ringer volume for
calls and messages is automatically set to
Level 4
.
Sound
69
Alerts
(Menu 4-3)
Your phone gives audible alerts (beeps) at a
specified time to inform you that certain things
have happened. The alerts only occur in your
earpiece so that the person with whom you are
talking does not hear them.
The following alerts are available:
Call Connect
: when this option is set to
On
, the
phone sounds the connect tone when your call is
connected to the system.
Call Disconnect
: when this option is set to
On
,
the phone sounds the disconnect tone when a call
is disconnected.
Privacy
: when this option is set to
On
, the phone
sounds an audible beep when you loose a private
encrypted CDMA line. For this option to work
correctly, you need to set the
Voice Privacy
menu (
Menu 7-3-4
) to
Enhanced
.
Key Tone
(Menu 4-4)
In this menu, you can set up the sound your
phone generates when you press a key.
The following options are available:
Tone Volume
: you can adjust the key tone
volume using the Navigation keys.
Note
: When “Emergency call only” appears after
ending an emergency call, the key tone is
automatically set to
Level 4
.
Sound
70
Tone Length
: you can select
Short
or
Long
DTMF (Dual-tone Multi-frequency) tones. DTMF
tones are sent by your phone to access
teleservices, such as a bank account. The system
used by the bank or other service determines if
you need short or long DTMF tones. If the service
is digital, as most are, short DTMF tones will
almost always work.
Power On/Off Melody
(Menu 4-5)
You can activate or deactivate the tone that the
phone sounds when it is switched on or off.
71
Display
The Display feature enables you to customize
various settings for the display and the light.
Language
(Menu 5-1)
This menu allows you to change the display and
input language.
Service Area
(Menu 5-2)
This menu displays the current service area the
user is in. The service area is also displayed for
about 2 seconds when your phone is registered
onto a network or when you make or receive a
call.
Wallpaper
(Menu 5-3)
You can select the background image (wallpaper)
to be displayed in Standby mode.
When you set this menu to
Banner
, the phone
displays the text message you entered using the
Banner
menu (
Menu 5-4
) in Standby mode.
Display
72
Banner
(Menu 5-4)
This option allows you to set a banner message to
display at the bottom of the display in Standby
mode.
1. If necessary, press repeatedly to delete
each letter of the old greeting. Press are hold
to clear the display.
2. Enter your banner message of up to 15
characters.
For further information about how to enter
characters, see page 33.
3. When you finish entering the message, press
the
Save
soft key to store the new banner.
Backlight
(Menu 5-5)
You have several options for setting how the
backlight operates. Remember that backlight use
drains your battery faster.
The following options are available:
Always On
: the backlight is always on.
15 seconds
: the backlight switches on when you
press a key and switches off after 15 seconds if
you don’t press any key.
8 seconds
: the backlight switches on when you
press a key and switches off after 8 seconds if you
don’t press any key.
Always Off
: the backlight is always off.
Display
73
LCD Contrast
(Menu 5-6)
The menu allows you to adjust the brightness of
the LCD screen.
Press to make the screen brighter, and to
make the screen darker.
Each time you press the key, you will see the
selected status of the screen.
74
Organiser
The Organiser feature enables you to:
• keep track of important dates and events
• create a list of things to do
• make a memo
• set an alarm to ring at a specific time
• use the phone as a calculator
• check the time in another part of the world
• use the countdown timer.
Scheduler
(Menu 6-1)
In this menu, you can keep track of your daily or
monthly schedule.
Today
(Menu 6-1-1)
You can schedule events for the current day
indicating each event’s start and end time. You
can even have your phone's calendar alert you
before an event starts. Events scheduled for
future dates automatically appear on your Today
display for that particular day.
Scheduling a New Event
1. Enter your event contents and press the
Next
soft key.
For more information about entering letters,
see page 33.
Organiser
75
2. Enter the start time and date and press the
Next
soft key.
Notes
:
• Your phone uses 24-hour format.
• You can move through the input fields using the
Navigation keys.
3. Enter the end time and date and press the
Next
soft key.
4. Select when an alarm will inform you of the
event by pressing or .
Selecting
No Alarm
means that the phone
doesn’t ring the alarm.
5. Press the
Save
soft key to store your event.
Viewing Your Today’s Schedule
The list of the events stored on the current day
displays when you select the
Today
menu (
Menu
6-1-1
).
While viewing the schedule list:
• Press the
Options
soft key to use the following
options:
Add New
: allows you to add a new event.
Erase
: allows you to erase the selected event.
Erase All
: allows you to erase all of the events.
• To view details, press the Navigation keys to
scroll to an event and press the
View
soft key.
The event displays along with its start time and
date. To view the end time, press .
While viewing the event, press the
Edit
soft key
to edit it. Press the
Erase
soft key to erase it.
Organiser
76
All
(Menu 6-1-2)
This menu allows you to view the current month,
as well as past or future months, in calendar
format. On the calendar, the current day is
highlighted.
Note
: You can to quickly access this menu by
pressing in Standby mode.
Scrolling Through the Calendar
• You can move to the left or right by one day by
pressing or and or .
• You can move up or down by one week by
pressing or and or .
On the calendar, press the
View
soft key to view
the scheduled events of the selected day.
Press the
Options
soft key to use the following
options:
Add New
: allows you to add a new event for the
selected day.
Erase All
: allows you to erase all of the events.
Creating a New Schedule
You can store up to 70 events total in the
scheduler, with up to 9 events for one day.
1. Select a day on the calendar, referring to
“Scrolling through the calendar” above.
2. Press the
Options
soft key and select
Add
New
option.
Organiser
77
3. Enter your event contents and press the
Next
soft key.
For more information about entering letters,
see page 33.
4. Enter the start time and date and press the
Next
soft key.
Notes
:
• Your phone uses 24-hour format.
• You can move through the input fields using the
Navigation keys.
5. Enter the end time and date and press the
Next
soft key.
6. Select when an alarm will inform you of the
event by pressing or .
Selecting
No Alarm
means that the phone
doesn’t ring the alarm.
7. Press the
Save
soft key to store your event.
Viewing Your Schedule
Select a day with scheduled events on the
calendar, referring to “Scrolling Through the
Calendar” on page 76 and press the
View
soft
key.
To view details, press the Navigation keys to scroll
to an event and press the
View
soft key. The
event displays along with its start time and date.
To view the end time, press .
While viewing the event, press the
Edit
soft key to
edit it. Press the
Erase
soft key to erase it.
Organiser
78
Task List
(Menu 6-2)
This menu allows you to enter up a list of tasks to
be done and assign a deadline to each task.
Creating a New Task
1. Enter the first task and press the
Next
soft
key.
For further details on how to enter characters,
see page 33.
2. Enter the time and date by which the task
needs to be done.
Notes
:
• Your phone uses 24-hour format.
• You can move through the input fields using the
Navigation keys.
3. Press the
Save
soft key to store the task.
Viewing a Task
The list of the tasks displays when you access the
Task List
menu (
Menu 6-2
).
While viewing the task list:
• Press the
Options
soft key to use the following
options:
Add New
: allows you to add a new task.
Erase
: allows you to erase the selected task.
Erase All
: allows you to erase all of the tasks.
Organiser
79
• To view details, press or to scroll to a
task and press the
View
soft key.
While viewing the task, press the
Edit
soft key
to edit it. Press the
Erase
soft key to erase it
Memo Pad
(Menu 6-3)
This menu allows you to write down memos about
anything you need to remember.
Writing a New Memo
1. Enter the memo.
For further details on how to enter characters,
see page 33.
2. Press the
Save
soft key to store the memo.
Viewing a Memo
The list of your memos displays when you access
the
Memo Pad
menu (
Menu 6-3
).
While viewing the memo list:
• Press the
Options
soft key to use the following
options:
Add New
: allows you to add a new memo.
Erase
: allows you to erase the selected memo.
Erase All
: allows you to erase all of the memos.
Organiser
80
• To view details, press or to scroll to a
memo and press the
View
soft key.
While viewing the memo, press the
Edit
soft
key to edit the memo. Press the
Erase
soft key
to erase the memo.
Alarm
(Menu 6-4)
This menu allows you to set up to an alarm to ring
at a specific time.
To set an alarm:
1. Select an alarm type,
Daily Alarm
or
Weekly
Alarm
, and press the
Select
soft key.
2. Select
On
by pressing or .
3. Press and enter the time for the alarm to
ring.
Notes
:
• Your phone uses 24-hour format.
• You can move through the input fields using the
Navigation keys.
4. Press the
Next
soft key.
5. Select a repeat option by pressing or .
You can choose either
Daily
or
Once
for the
daily alarm, or select a day of the week for the
weekly alarm. In case of weekly alarm, press
to select a day and to deselect a day.
6. Press and select an alarm melody by
pressing or .
Organiser
81
7. Press the
Save
soft key to save the alarm
setting.
To stop the alarm when it rings, press the
Stop
soft key, , or . If you stop the alarm using
other keys, the Snooze function is activated and
the phone alerts you to the alarm after 10
minutes. To deactivate the Snooze function, press
the
Stop
soft key, , or .
To deactivate an alarm setting, access it from the
alarm list and select
Off
.
Calculator
(Menu 6-5)
Using this feature, you can use the phone as a
calculator. The calculator provides the basic
arithmetic functions; addition, subtraction,
multiplication and division.
1. Enter the first number using the numeric keys.
Notes
:
• To erase any mistakes or clear the display,
press .
• Use to enter a decimal point and to
change the sign of a number to a negative (-).
2. Enter the operation for your calculation on the
second line by pressing the Navigation keys,
according to the graphic on the display.
3. Enter the second number.
4. Repeat steps 2 and 3 as many times, if
necessary.
Organiser
82
5. To view the result, press the
Result
soft key.
6. To perform another calculation, press to
reset the calculator and repeat from step 1.
World Time
(Menu 6-6)
This menu allows you to check the current times
for 24 major cities around the world or set DST
(Daylight Savings Time).
To check the world time and set your time zone:
1. Select the city corresponding to your time zone
by pressing the Navigation keys one or more
times.
The local time and date display.
2. Press the
Save
soft key to set the time as the
default time zone.
To turn on or off the DST setting:
1. After selecting the time zone to which you
want to apply the DST, press the
DST
soft key.
2. Press the
On
soft key.
To cancel the DST setting, press the
Off
soft
key.
Organiser
83
Countdown
(Menu 6-7)
This menu helps you know how much time it takes
for you to do something, or how many months,
days, hours and minutes until a specific day
arrives. You can create up to 9 counters.
Creating a New Counter
1. Enter the contents for your counter and press
the
Next
soft key.
For details about entering text, see page 33.
2. Enter the time and date you want to count
down from.
Notes
:
• Your phone uses 24-hour format.
• You can move through the input fields using the
Navigation keys.
• Enter a year between 1980 and 2099.
3. Press the
Save
soft key to store the counter.
Viewing a Counter
The list of the counters displays when you access
the
Countdown
menu option (
Menu 6-7
).
While viewing the counter list:
• Press the
Options
soft key to use the following
options:
Add New
: allows you to add a new counter.
Erase
: allows you to erase the selected counter.
Erase All
: allows you to erase all of the
counters.
Organiser
84
• To view details, press or to scroll to a
counter and press the
View
soft key.
While viewing a counter, press the
Edit
soft key
to edit it. Press the
Erase
soft key to erase it.
85
Settings
Many different features of your phone can be
customised to suit your preferences.
Call
(Menu 7-1)
This menu contains the suboptions for answering
or redialling a call.
Answer Mode
(Menu 7-1-1)
This menu allows you to select how to answer an
incoming call.
The following options are available:
Any Key
: the phone answers when you press any
key except for and the
Silence
soft key.
Call Key
: the phone answers only when you press
.
Auto Redial
(Menu 7-1-2)
When this menu is activated, your phone
automatically redials the call up to 10 times when
a connection fails.
To activate this feature, select how often the
phone automatically retries the call; 60, 30 and
10 seconds are available.
Select
Off
to deactivate the Auto Redial feature.
Settings
86
Call Forward
(Menu 7-1-3)
This network service allows incoming calls to be
forwarded to another number.
Note
: This feature is only available when your
service provider supports it. Contact your
service provider to check its availability.
The following options are available:
Immediate
: calls are forwarded immediately
when they are received.
When Busy
: calls are forwarded if you are
already on the phone.
No Reply/Not Rch
: calls are forwarded if you
don’t answer or when your phone is switched off.
Disable All:
all of the call forward settings are
cancelled.
To set your forwarding options:
1. Select the type of call forwarding and press the
Select
soft key.
2. Select
Enable
and press the
Select
soft key.
3. Select
Voice Mail
to forward calls to your
voice mail centre or
Other Number
to set
another phone number, and press the
Select
soft key.
4. Change the number for the voice mail centre, if
necessary, or enter a phone number to which
calls are forwarded.
5. Press the
OK
soft key.
The phone sends your setting to your network.
Settings
87
Once call forwarding is enabled, a notification text
appears to inform you that your call will be
diverted, each time a call is forwarded or you
switch the phone on.
To deactivate the call forward setting:
1. Select the call forwarding option and press the
Select
soft key.
2. Select
Disable
and press the
Select
soft key.
The phone sends your setting to your network.
Call Waiting
(Menu 7-1-4)
The Call Waiting feature alerts you of incoming
calls while you are on a call.
To enable the feature, select
Enable
by using the
Navigation keys and press the
Select
soft key.
The phone sends your setting to your network.
When this feature is enabled, you can respond to
an incoming call by pressing while you are on
a call. This puts the first caller on hold and
answers the second call. To switch to the first
caller, press again.
To disable Call Waiting, select
Disable
and press
the
Select
soft key.The phone sends your setting
to your network.
Settings
88
Phone/System
(Menu 7-2)
Key Guard
(Menu 7-2-1)
You can prevent accidental key pressing by using
Key Guard mode.
To activate the Key Guard feature, select the
period of time your phone waits for before locking
the keypad. If you do not want to use the feature,
set this menu to
Off
.
When you have an incoming call or the time for an
alarm comes in Key Guard mode, the mode is
automatically deactivated and the phone goes to
Standby mode. It will be automatically activated
after the specified amount of time when you end
the call or stop the alarm.
Once Key Guard mode is activated, you can
temporarily unlock your keypad by pressing
and .
Note
: You can lock the keypad manually by pressing
and holding in Standby mode.
Set Time
(Menu 7-2-2)
To display the correct date and time on the idle
screen or to use the Organiser features, such as
Scheduler, Task List, Countdown, Alarm and World
Time, you need to set the current time and date
using this menu.
Enter the time and date using the numeric keys.
Each of the hour, minute, day, and month must be
entered using 2 digits and the year requires all 4
digits. You need to enter the hour in 24-hour
format.
Settings
89
Set NAM
(Menu 7-2-3)
NAM stands for Numerical Assignment Module,
essentially your phone number. Your phone can
have two NAMs. This means that you can have
two phone numbers for using your phone and can
quickly and easily switch your service back and
forth between the two numbers.
Do not change the setting and use NAM1
only.
Version
(Menu 7-2-4)
This option allows you to view the software and
hardware versions of your phone. This feature is
helpful if you need to the call customer care.
Settings
90
Security
(Menu 7-3)
Your phone provides you with many security
options, including a user-programmable lock code.
To access the
Security
menu, you need to enter a
lock code.
The lock code is preset to “0000” at
the factory
.
Lock Mode
(Menu 7-3-1)
When the phone is locked, you cannot operate the
phone until you enter the Lock code.
The following options are available:
Never
: the phone remains unlocked.
On Power-Up
: the phone locks automatically the
next time you turn it on.
Now
: the phone locks immediately.
To place an emergency call, enter the number and
then press . The phone recognises three
emergency numbers stored in the
Emergency
Numbers
menu (
Menu 7-3-3
).
To unlock the phone, press the
Unlock
soft keys
and enter the lock code. The phone returns to
Standby mode.
Change Code
(Menu 7-3-2)
This feature allows you to change your current
lock code to a new one. The lock code is preset to
“0000” at the factory.
Enter a new four-digit lock code and then enter
the code again to confirm.
Settings
91
Emergency Numbers
(Menu 7-3-3)
Your phone provides you with the option for
storing three emergency numbers.The default
numbers are 100, 101, and 102. All of these
numbers can be manually dialled at any time even
when your phone is locked.
IMPORTANT NOTICE!
Emergency calling may not be available on all
wireless networks at all times. A connection
cannot always be guaranteed, due to various
transmission methods, network parameters and
user settings used to complete a call from your
wireless phone.
DO NOT depend on this phone as a primary
method of dialling 100 or for any other essential
or emergency communications.
Remember to always turn your phone on and
check for the adequate signal strength before
placing a call.
To store an emergency number:
1. Press or to select a location and press
the
Select
soft key.
2. Enter the number you want to use.
Each emergency number can be up to 32 digits
long. The number already stored in the
selected location is automatically deleted when
you enter a new number.
3. Press the
Save
soft key to store the number.
To make an emergency call in Lock mode, simply
enter a programmed number, and then press .
Settings
92
Voice Privacy
(Menu 7-3-4)
Used only in digital networks, Voice Privacy
encrypts the voice channel so that people cannot
eavesdrop on your conversation.
The following options are available:
Standard
: The phone will use a standard line for
calls.
Enhanced
: The phone will make and receive calls
on an encrypted high security line.
When this option is enabled and you are located in
an area that supports the privacy option, the
Privacy icon appears on the display.
Note
: This feature may not be available in all areas.
Contact your service provider for its details
and availability.
Clear Phone Book
(Menu 7-3-5)
This menu allows you to erase all of the numbers
in your Phone Book.
When a confirmation message displays, press the
Yes
soft key.
Reset Phone
(Menu 7-3-6)
Resetting the phone cancels all of your selection in
the user-selectable setting options and returns
them to the factory default settings.
When a confirmation message appears, press the
Yes
soft key. The phone turns itself off and back
on and then returns to Standby mode.
93
Game
You can experience the fun of playing games on
your phone.
Settings
(Menu 8-1)
This menu allows you to change the volume for
the game sound and turn on or off the backlight
during a game.
Volume
(Menu 8-1-1)
This menu allows you to adjust the volume of the
game sound.
Silent
: the game is played in a vibrate mode.
Level 1
~
5
: adjust the volume level. The more
bars you see, the louder the volume is.
Backlight
(Menu 8-1-2)
Playing a game consumes the battery power more
than using other functions of your phone. This
menu allows you to activate or deactivate the
backlight during the game to conserve your
battery.
Game
94
Games
(Menu 8-2)
You can enjoy six fun games on your phone:
To start a game:
1. Select a game by pressing the Navigation keys
and press the
Select
key.
2. On the startup screen, press any key. For
Othello
, press the right soft key.
The following options are available:
•
NEW GAME
: starts a new game.
•
LOAD GAME
: loads the last game you
played, if you are interrupted during a game.
•
KEY CONTROL
: opens the screen showing
the key operations for the game.
•
GAME INFO
: opens the help screen for the
game.
3. Select
NEW GAME
or
LOAD GAME
and press
the left soft key.
4. Depending on the selected game, follow the
directions on the game screen.
During the game, press the right soft key to
see the game options.
5. To end the game, press .
Note
: If the battery power is low, the
Games
menu
would not be accessed. Charge the battery
before using the menu.
95
Health and Safety
Information
Exposure to Radio Frequency (RF)
Signals
Your wireless phone is a radio transmitter and
receiver. It is designed and manufactured not to
exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal
Communications Commission (FCC) of the U.S.
Government. These limits are part of
comprehensive guidelines and establish permitted
levels of RF energy for the general population. The
guidelines are based on the safety standards that
were developed by independent scientific
organizations through periodic and through
evaluation of scientific studies.
The standards include a substantial safety margin
designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless phones
employs a unit of measurement known as Specific
Absorption Rate (SAR). The SAR limit set by the
FCC is 1.6W/kg
*
.
* In the U.S. and Canada, the SAR limit for mobile
phones used by the public is 1.6 watts/kg (W/kg)
averaged over one gram of tissue. The standard
incorporates a substantial margin of safety to give
additional protection for the public and to account
for any variations in measurements.
Health and Safety Information
96
SAR tests are conducted using standard operating
positions specified by the FCC with the phone
transmitting at its highest certified power level in
all tested frequency bands. Although the SAR is
determined at the highest certified power level,
the actual SAR level of the phone while operating
can be well below the maximum value. This is
because the phone is designed to operate at
multiple power levels so as to use only the power
required to reach the network. In general, the
closer you are to a wireless base station antenna,
the lower the power output of the phone.
Before a new model phone is available for sale to
the public, it must be tested and certified to the
FCC that it does not exceed the limit established
by the government-adopted requirement for safe
exposure. The tests are performed in positions
and locations (e.g., at the ear and worn on the
body) as required by the FCC for each model.
While there may be differences between the SAR
levels of various phones and at various positions,
they all meet the government requirement.
The FCC has granted an Equipment Authorization
for this model phone with all reported SAR levels
evaluated as in compliance with the FCC RF
exposure guidelines. SAR information on this
model phone is on file with the FCC and can be
found under the Display Grant section of http://
www.fcc.gov/oet/fccid after searching on FCC ID
printed in the label on the phone.
FCC certification information for this model phone
is attached separation paper.
Health and Safety Information
97
For Body Operation
This device was tested for typical body-worn operations with the
back of the phone kept 1.5 cm. from the body. To maintain
compliance with FCC RF exposure requirements, use only
belt-clips, holsters or similar accessories that maintain a
1.5 cm. separation distance between the user's body and the
back of the phone, including the antenna. The use of belt-clips,
holsters and similar accessories should not contain metallic
components in its assembly. The use of accessories that
do not satisfy these requirements may not comply with FCC
RF exposure requirements, and should be avoided.
For more Information concerning exposure to
radio frequency signals, see the following
websites:
Federal Communications Commission (FCC)
http://www.fcc.gov/oet/rfsafety
Cellular Telecommunications Industry Association
(CTIA): http://www.wow-com.com
U.S.Food and Drug Administration (FDA)
http://www.fda.gov/cdrh/consumer
World Health Organization (WHO)
http://www.who.int/peh-emf/en
Health and Safety Information
98
Precautions When Using Batteries
• Never use any charger or battery that is
damaged in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network’s base
station, it uses less power; talk and standby
time are greatly affected by the signal strength
on the cellular network and the parameters set
by the network operator.
• Battery charging time depends on the remaining
battery charge and the type of battery and
charger used. The battery can be charged and
discharged hundreds of times, but it will
gradually wear out. When the operation time,
including talk time and standby time, is
noticeably shorter than normal, it is time to buy
a new battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not in
use, disconnect it from the power source. Do
not leave the battery connected to a charger for
more than a week, since overcharging may
shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling
or warming first.
Health and Safety Information
99
• Do not leave the battery in hot or cold places,
such as in a car in summer or winter conditions,
as you will reduce the capacity and life-time of
the battery. Always try to keep the battery at
room temperature. A phone with a hot or cold
battery may temporarily not work, even when
the battery is fully charged. Li-ion batteries are
particularly affected by temperatures below 0
°C (32 °F).
• Do not short-circuit the battery. Accidental short
circuiting can occur when a metallic object
(coin, clip or pen) causes a direct connection
between the + and – terminals of the battery
(metal strips on the battery), for example when
you carry a spare battery in a pocket or bag.
Short-circuiting the terminals may damage the
battery or the object causing the short-circuit.
• Dispose of used batteries in accordance with
local regulations. Always recycle. Do not dispose
of batteries in a fire.
Road Safety
Your wireless phone gives you the powerful ability
to communicate by voice, almost anywhere,
anytime. But an important responsibility
accompanies the benefits of wireless phones, one
that every user must uphold.
When driving a car, driving is your first
responsibility. When using your wireless phone
behind the wheel of a car, make sure that you are
following the special regulations in a given area or
country.
Health and Safety Information
100
Operating Environment
Remember to follow any special regulations in
force in any area and always switch off your phone
whenever it is forbidden to use it, or when it may
cause interference or danger.
When connecting the phone or any accessory to
another device, read its user’s guide for detailed
safety instructions. Do not connect incompatible
products.
As with other mobile radio transmitting
equipment, users are advised that for the
satisfactory operation of the equipment and for
the safety of personnel, it is recommended that
the equipment should only be used in the normal
operating position (held to your ear with the
antenna pointing over your shoulder).
Electronic Devices
Most modern electronic equipment are shielded
from radio frequency (RF) signals. However,
certain electronic equipment may not be shielded
against the RF signals from your wireless phone.
Consult the manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be
maintained between a wireless phone and a
pacemaker to avoid potential interference with the
pacemaker. These recommendations are
consistent with the independent research and
recommendations of Wireless Technology
Research.
Health and Safety Information
101
Persons with pacemakers:
• should always keep the phone more than 15 cm
(6 inches) from their pacemaker when the
phone is switched on;
• should not carry the phone in a breast pocket;
• should use the ear opposite the pacemaker to
minimise potential interference.
If you have any reason to suspect that
interference is taking place, switch off your phone
immediately.
Hearing Aids
Some digital wireless phones may interfere with
some hearing aids. In the event of such
interference, you may wish to consult your
hearing aid manufacturer to discuss alternatives.
Other Medical Devices
If you use any other personal medical devices,
consult the manufacturer of your device to
determine if it is adequately shielded from
external RF energy. Your physician may be able to
assist you in obtaining this information. Switch off
your phone in health care facilities when any
regulations posted in these areas instruct you to
do so. Hospitals or health care facilities may be
using equipment that could be sensitive to
external RF energy.
Health and Safety Information
102
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle.
You should also consult the manufacturer of any
equipment that has been added to your vehicle.
Posted Facilities
Switch off your phone in any facility where posted
notices require you to do so.
Potentially Explosive Envirionments
Switch off your phone when in any area with a
potentially explosive atmosphere and obey all
signs and instructions. Sparks in such areas could
cause an explosion or fire resulting in bodily injury
or even death.
Users are advised to switch off the phone while at
a refuelling point (service station). Users are
reminded of the need to observe restrictions on
the use of radio equipment in fuel depots (fuel
storage and distribution areas), chemical plants or
where blasting operations are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas
(such as propane or butane), areas where the air
contains chemicals or particles, such as grain,
dust or metal powders, and any other area where
you would normally be advised to turn off your
vehicle engine.
Health and Safety Information
103
Emergency Calls
This phone, like any wireless phone, operates
using radio signals, wireless and landline networks
as well as user-programmed functions, which
cannot guarantee connection in all conditions.
Therefore, you should never rely solely on any
wireless phone for essential communications
(medical emergencies, for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may
not be possible on all wireless phone networks or
when certain network services and/or phone
features are in use. Check with local service
providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location. Emergency numbers vary by location.
3. Press .
When making an emergency call, remember to
give all the necessary information as accurately as
possible. Remember that your phone may be the
only means of communication at the scene of an
accident; do not cut off the call until given
permission to do so.
Health and Safety Information
104
Other Important Safety Information
• Only qualified personnel should service the
phone or install the phone in a vehicle. Faulty
installation or service may be dangerous and
may invalidate any warranty applicable to the
device.
• Check regularly that all wireless phone
equipment in your vehicle is mounted and
operating properly.
• Do not store or carry flammable liquids, gases
or explosive materials in the same compartment
as the phone, its parts or accessories.
• For vehicles equipped with an air bag,
remember that an air bag inflates with great
force. Do not place objects, including both
installed or portable wireless equipment in the
area over the air bag or in the air bag
deployment area. If wireless equipment is
improperly installed and the air bag inflates,
serious injury could result.
• Switch off your phone before boarding an
aircraft. The use of wireless phones in aircraft
may be dangerous to the operation of the
aircraft, and is illegal.
• Failure to observe these instructions may lead
to the suspension or denial of telephone
services to the offender, or legal action, or both.
Health and Safety Information
105
Care and Maintenance
• Your phone is a product of superior design and
craftsmanship and should be treated with care.
The suggestions below will help you fulfill any
warranty obligations and allow you to enjoy this
product for many years.
• Keep the phone and all its parts and accessories
out of the reach of small children.
• Keep the phone dry. Precipitation, humidity and
liquids contain minerals that will corrode
electronic circuits.
• Do not touch the phone with a wet hand. Doing
so may cause an electric shock to you or
damage to the phone.
• Do not use or store the phone in dusty, dirty
areas, as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the
phone, which may damage the phone’s
electronic circuit boards.
• Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents
or strong detergents to clean the phone. Wipe it
with a soft cloth slightly dampened in a mild
soap-and-water solution.
Health and Safety Information
106
• Do not paint the phone. Paint can clog the
device’s moving parts and prevent proper
operation.
• Do not put the phone in or on heating devices,
such as a microwave oven, a stove or a radiator.
The phone may explode when overheated.
• Use only the supplied or an approved
replacement antenna. Unauthorized antennas or
modified accessories may damage the phone
and violate regulations governing radio devices.
• If the phone, battery, charger or any accessory
is not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
107
Glossary
To help you understand the main technical terms
and abbreviations used in this booklet, and to take
full advantage of the features of your mobile
phone, here are a few definitions:
Airtime
Actual time spent talking on the wireless phone.
Most carriers bill customers based on how many
minutes of airtime they use each month.
Antenna
A device for transmitting or receiving signals. The
size and shape of antennas is determined, in part,
by the frequency of the signal they receive.
Wireless phones and the base station must have
antennas.
Base Station
The fixed radio transmitter/receiver that maintains
communications with mobile radio telephones
within a given area. (Typically called a cell or cell
site)
CDMA (Code Division Multiple Access)
A spread-spectrum approach to digital
transmission. With CDMA, each conversation is
digitized and then tagged with a code. The mobile
phone deciphers only a particular code to pick the
right conversation off the air. The transmitted
signal is just above noise level across the available
bandwidth.
Glossary
108
Channel
Communications signals transmit along paths
called channels.
Codec
Compression & Decompression.
Deactivation
The process of rendering a wireless phone
inactive.
DTMF (Dual-tone Multi-Frequency )
You send DTMF signals when you enter numbers
by pressing the digit keys.
EVRC
(Enhanced Variable Rate Codec) EVRC is a new
global standard for compressing and
decompressing voice signals. EVRC uses a lower
bit rate (the number of bits sent per second) than
existing CDMA vocoders, while providing
significant improvements in voice quality. This
technology enables your phone to provide superb
voice quality while benefiting from the ability to
process more cellular voice calls using less
bandwidth than the voice codecs in CDMA
networks today.
Frequency
A measure based on time, as one or more waves
per second, in an electrical or light wave
information signal. A signal’s frequency is stated
in cycles-per-second or Hertz (Hz).
Glossary
109
Hands-Free
A feature that permits a driver to use a wireless
phone without lifting or holding the handset - an
important safety feature for automobiles, tractors
and most other motorized vehicles.
LCD (Liquid Crystal Display)
Commonly used to refer to the screen display on
the wireless phone.
LED (Light Emitting Diode)
Commonly used to refer to a small light on the
wireless phone or on the Desktop Charger. The
LED lights on the phone to indicate an incoming
call. The lights on the charger indicate that battery
charging is taking place.
Prepend
The addition of a prefix, such as an area code, to a
phone number.
RF
Radio Frequency
Roaming
The ability to use a wireless phone to make and
receive calls in places outside of the home service
area.
Service Charge
The amount paid each month to receive wireless
service.
Glossary
110
Standby Time
The amount of time a fully charged wireless
portable or transportable phone can be on and idle
without being in use. (See Talk Time)
Talk Time
The length of time a person can talk on a portable
or transportable wireless phone without
recharging the battery.
Vocoder
Voice Coder. A device used to convert speech into
digital signals.
Wireless
Radio-based Systems that allow transmission of
telephone or data signals through the air without a
physical connection, such as a metal wire (copper)
or fiber optic cable.
111
Index
123
1-beep mode
20
4-digit dialling
25
A
Accessories
7
Air time
66
Alarm
80
Alert tones, set
69
Alphabet mode, text input
36
Answer mode
85
Auto redial
85
B
Background image
71
Backlight
12
,
72
Banner
72
Battery
charging
14
installing
13
low battery indicator
15
precautions
98
C
Calculator
81
Calendar
76
Call
answering
28
ending
22
forwarding
31
,
86
from Phone Book
22
making
21
waiting
31
,
87
Call duration
66
Call history
dialled calls
65
missed calls
63
received calls
65
Caller group
changing
51
finding
47
Caller ID
30
Characters, enter
33
Charging battery
14
Connect tone
69
Contrast, display
73
Countdown
83
D
Date, set
88
Delivery reports, message
55
,
60
Dialled calls
65
Dialling options
21
Disconnect tone
69
Display
backlight
12
contrast
73
icons
11
language
71
layout
11
DST (Daylight Savings
Time), set
82
DTMF tones, send
25
E
Emergency calls
23
,
103
Emergency numbers
91
Erasing
call history
64
,
65
countdown
83
memos
79
messages
59
phone book
46
,
92
schedule
75
,
76
tasks
78
G
Games
93
Groups
caller
51
SMS
62
Index
112
H
Health and safety
95
I
Icons, description •
11
Inbox, messages
56
Installing battery
13
K
Key guard mode
19
,
88
Key tone
length
70
swithching on/off
29
volume
69
Keys
description
9
location
8
L
Language, select
71
Last number, redial
23
Lock code, change
90
Lock mode
20
,
90
Low battery indicator
15
M
Memo pad
79
Menus
accessing
39
list
41
shortcuts
40
Messages
draft
57
inbox
56
outbox
57
settings
59
templates
58
writing
53
Missed calls
30
,
63
N
NAM, set
89
Name
finding
45
storing
48
Number, phone
finding
45
storing
48
O
On/Off switch, phone
16
Organiser
74
Outbox, messages
57
P
Phone
care and maintenance
105
display
11
icons
11
keys
9
layout
8
locking
90
modes
18
resetting
92
switching on/off
16
unpacking
7
Phone book
adding entry
48
clearing
92
finding entry
45
memory status
52
Power on/off melody
70
Power save mode
19
R
Radio frequency
95
Receivec calls
65
Received messages
56
Redialling
automatically
85
manually
23
Resetting phone
92
Ring tones
67
Index
113
Ringer volume
68
Road safety
99
S
Safety
information
95
precautions
5
Scheduler
74
Security
90
Sent messages
57
Service area, display
71
SMS groups
62
Soft keys
17
Sound settings
67
Speed dialling
24
Standby mode
18
Switching on/off phone
16
T
T9(English) mode, text input
35
Talk mode
18
Task list
78
Templates, message
58
Text input modes
33
Text messages
53
Text, enter
33
Three-way calling
32
Time, set
88
Today schedule
74
Tone
connect
69
disconnect
69
key
69
power on/off
70
privacy
69
ringer
67
Travel adapter
14
U
Unpacking
7
V
Version
89
Vibrate mode
20
Voice mail
61
Voice privacy
29
,
92
W
Waiting call
31
,
87
Wallpaper
71
World time
82
Writing a message
53
114
115
Internal Phone book
Save a
number Enter number +
Save
+
Select
+ Enter name +
Next
+ / (Category)
+
Select
+ / (Entry
option) + / to
change the settings or
Edit
enter information +
Save
Speed dial • For the entry numbers
of one digit, press and
hold the corresponding
digit key.
• For the other entry
numbers, press the
first digit key(s) briefly,
and hold down the last
digit key.
Phone book
Search Press the
Find
soft key +
/ + / +
Select
or
Basic Operation
Make a call Phone number +
End a call
Answer a call
Redial the last
call twice
Switch to
Vibrate mode (in Standby mode)
Hold
Switch to 1-
Beep mode (in Standby mode)
Hold
0
Lock the
keypad (in Standby mode)
Hold
Unlock the
keypad
C
+
SCH-N356 Quick Reference Card
116
1: Phone Book 1: Find
2: Add Entry
3: Groups
4: Memory Status
2: Message 1: Write
2: Inbox
3: Outbox
4: Draft
5: Templates
6: Erase Messages
7: Settings
8: Voice Mail
9: SMS Groups
3: Call History 1: Missed
2: Received
3: Dialled
4: Erase History
5: Call Duration
4: Sound 1: Ring Tones
2: Ringer Volume
3: Alerts
4: Key Tone
5: Power On/Off Melody
5: Display 1: Language
2: Service Area
3: Wallpaper
4: Banner
5: Backlight
6: LCD Contrast
6: Organiser 1: Scheduler
2: Task List
3: Memo Pad
4: Alarm
5: Calculator
6: World Time
7: Countdown
7: Setting 1: Call
1: Answer Mode
2: Auto Redial
3: Call Forward
4: Call Waiting
2: Phone/System
1: Key Guard
2: Set Time
3: Set NAM
4: Version
3: Security
1: Lock Mode
2: Change Mode
3: Emergency Numbers
4: Voice Privacy
5: Clear Phone Book
6: Reset Phone
8: Game 1: Settings
2: Games
Main Menu
(To access, press the
Menu
soft key.)
