Users Manual

4G LTE SMARTPHONE

User Manual

Please read this manual before operating your

phone, and keep it for future reference.

SCH-R950 Logo Here

This document is watermarked because certain important information in the

document has not yet been verified.This document has been sent to you as

a draft and for informational purposes only.The document should only be

used for internal purposes and may not be distributed outside of Samsung,

except to Samsung's carrier customer for testing purposes. Distributing

the document outside of Samsung, except to Samsung's carrier customer for

testing purposes could result in legal exposure to the company if the

preliminary, unverified information in the draft turns out to be inaccurate.

DRAFT - Internal Use Only

This device is capable of operating in 802.11a/n mode. For 802.11a/n devices operating in the frequency

range of 5.15 - 5.25 GHz, they are restricted to indoor operations to reduce any potential harmful

interference for Mobile Satellite Services (MSS) in the US. WIFI Access Points that are capable of

allowing your device to operate in 802.11a/n mode (5.15 - 5.25 GHz band) are optimized for indoor

use only. If your WIFI network is capable of operating in this mode, please restrict your WIFI use

indoors to not violate federal regulations to protect Mobile Satellite Services.

SCH-R950_UM_English_UCPLG1_CH_090412_D1

Intellectual Property

All Intellectual Property, as defined below, owned by or which is otherwise the property of Samsung or its respective suppliers

relating to the SAMSUNG Phone, including but not limited to, accessories, parts, or software relating there to (the “Phone

System”), is proprietary to Samsung and protected under federal laws, state laws, and international treaty provisions. Intellectual

Property includes, but is not limited to, inventions (patentable or unpatentable), patents, trade secrets, copyrights, software,

computer programs, and related documentation and other works of authorship. You may not infringe or otherwise violate the

rights secured by the Intellectual Property. Moreover, you agree that you will not (and will not attempt to) modify, prepare

derivative works of, reverse engineer, decompile, disassemble, or otherwise attempt to create source code from the software. No

title to or ownership in the Intellectual Property is transferred to you. All applicable rights of the Intellectual Property shall remain

with SAMSUNG and its suppliers.

Open Source Software

Some software components of this product, including but not limited to 'PowerTOP' and 'e2fsprogs', incorporate source code

covered under GNU General Public License (GPL), GNU Lesser General Public License (LGPL), OpenSSL License, BSD License and

other open source licenses. To obtain the source code covered under the open source licenses, please visit:

http://opensource.samsung.com

Disclaimer of Warranties; Exclusion of Liability

EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH THE PRODUCT, THE

PURCHASER TAKES THE PRODUCT "AS IS", AND SAMSUNG MAKES NO EXPRESS OR IMPLIED WARRANTY OF ANY KIND

WHATSOEVER WITH RESPECT TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE MERCHANTABILITY OF THE PRODUCT OR

ITS FITNESS FOR ANY PARTICULAR PURPOSE OR USE; THE DESIGN, CONDITION OR QUALITY OF THE PRODUCT; THE

PERFORMANCE OF THE PRODUCT; THE WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS CONTAINED THEREIN; OR

COMPLIANCE OF THE PRODUCT WITH THE REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING

DRAFT - Internal Use Only

THERETO. NOTHING CONTAINED IN THE INSTRUCTION MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS OR IMPLIED

WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR

ANY DAMAGES OF ANY KIND RESULTING FROM THE PURCHASE OR USE OF THE PRODUCT OR ARISING FROM THE BREACH OF

THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS OF ANTICIPATED PROFITS

OR BENEFITS.

SAMSUNG IS NOT LIABLE FOR PERFORMANCE ISSUES OR INCOMPATIBILITIES CAUSED BY YOUR EDITING OF REGISTRY SETTINGS,

OR YOUR MODIFICATION OF OPERATING SYSTEM SOFTWARE.

USING CUSTOM OPERATING SYSTEM SOFTWARE MAY CAUSE YOUR DEVICE AND APPLICATIONS TO WORK IMPROPERLY.

SAFE™ ("Samsung Approved For Enterprise") TO THE FULL EXTENT PERMITTED BY LAW SAMSUNG ELECTRONICS CO., LTD.,

SAMSUNG TELECOMMUNICATIONS AMERICA, LLC, AND THEIR AFFILIATES (COLLECTIVELY REFERRED TO HEREIN AS THE

"SAMSUNG ENTITIES") EXPRESSLY DISCLAIM ANY AND ALL WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY OF

MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, INTEROPERABILITY OR NON-INFRINGEMENT, WITH RESPECT TO

INFORMATION TECHNOLOGY SECURITY PROTECTION, SAFE™ APPROVED DEVICES AND SAFE™ APPROVED APPLICATIONS. IN NO

EVENT SHALL THE SAMSUNG ENTITIES BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, PUNITIVE, OR CONSEQUENTIAL

DAMAGES OF ANY KIND WHATSOEVER WITH RESPECT TO INFORMATION TECHNOLOGY SECURITY PROTECTION, SAFE™

APPROVED DEVICES OR SAFE™ APPROVED APPLICATIONS. In addition, information technology security protection will be affected

by features or functionality associated with, among other things the e-mail platform, master data management, and virtual private

network solutions selected by the software provider, solution provider or user. Choice of an e-mail, master data management,

and virtual private network solution is at the sole discretion of the software provider, solution provider or user and any associated

effect on information technology security protection is solely the responsibility of the software provider, solution provider or user.

For complete statement of limited warranty, please refer to

www.samsung.com/us/safe

, available on the web and where Samsung

smartphone and Galaxy Tab™ devices are sold.

DRAFT - Internal Use Only

Samsung Telecommunications America (STA), LLC

Do you have questions about your Samsung Mobile Phone? For 24 hour information and assistance, we offer a new FAQ/ARS

System (Automated Response System) at:

http://www.samsung.com/us/support.

Nuance®, VSuite™, T9® Text Input, and the Nuance logo are trademarks or registered trademarks of Nuance Communications,

Inc., or its affiliates in the United States and/or other countries.

The Bluetooth® word mark, figure mark (stylized “B Design”), and combination mark (Bluetooth word mark and “B Design”) are

registered trademarks and are wholly owned by the Bluetooth SIG.

microSD™ and the microSD logo are Trademarks of the SD Card Association.

Openwave® is a registered Trademark of Openwave, Inc.

and are trademarks of SRS Labs, Inc. CS Headphone and WOW HD technologies are incorporated under license

from SRS Labs, Inc.

Headquarters:

1301 E. Lookout Drive

Richardson, TX 75082

Toll Free Tel:

Customer Care Center:

1000 Klein Rd.

Plano, TX 75074

1.888.987.HELP (4357)

Internet Address:

http://www.samsungusa.com

DRAFT - Internal Use Only

, DivX®, DivX Certified® and associated logos are trademarks of Rovi Corporation or its subsidiaries and are used under

license.

DivX Certified® to play DivX® video up to HD 720p, including premium content.

ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation. This is an official DivX

Certified® device that plays DivX video. Visit

www.divx.com

for more information and software tools to convert your files into DivX

videos.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered in order to play purchased DivX Video-on-

Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu (tap

Apps >

Settings > About device > Legal information > License settings > DivX® VOD > Register

). Go to

vod.divx.com

for more information on

how to complete your registration.

Google, the Google logo, Android, the Android logo, Google Play, Gmail, Google Mail, Google Maps, Google Music, Google Talk,

Picasa, YouTube and other marks are trademarks of Google Inc.

Wi-Fi is a registered trademark of the Wireless Fidelity Alliance, Inc.

DRAFT - Internal Use Only

Devices purchased for use on USCC's system are designed for use exclusively on 's system. You agree that you won't make any

modifications to the Equipment or programming to enable the Equipment to operate on any other system. A voice plan is

required on all voice-capable devices, unless specifically noted otherwise in the terms governing your agreement. Some devices

or plans may require you to subscribe to a data plan.

Your phone is designed to make it easy for you to access a wide variety of content. For your protection, USCC wants you to be

aware that some applications that you enable may involve the location of your phone being shared. For applications available

through USCC, USCC offers privacy controls that let you decide how an application may use the location of your phone and

other phones on your account. However, USCC's privacy tools do not apply to applications available outside of USCC. Please

review the

terms and conditions and the associated privacy policy for each location-based service to learn how location information will be

used and protected.

Your phone features earSmart™, an intelligent voice processor that delivers a clear voice experience, allowing you to

hear and be

heard

™ in nearly any environment. earSmart technology uses the science of human hearing to distinguish sounds, identify your

voice and suppress surrounding noise, for clear conversations just about anywhere.

How Does It Work?

•

The earSmart voice processor in your phone captures your voice and all the sounds around you.

•

Working like the human ear, it processes and distinguishes these sounds, isolates your voice conversation, and removes background noise -

from both ends of a call.

•

It also automatically equalizes and adjusts voice volume so you can hear and talk naturally, even in the noisiest places.

•

With earSmart technology, you can talk where you want, and have clear conversations for mobile calls, video chats, even speakerphone calls,

without worrying about surrounding noise.

DRAFT - Internal Use Only

Your phone may be used to access the Internet and to download, and/or purchase goods, applications, and services from USCC

or elsewhere from third parties. USCC provides tools for you to control access to the Internet and certain Internet content. These

controls may not be available for certain devices which bypass USCC controls.

USCC may collect certain types of information from your device when you use USCC services to provide customer support

and to improve its services. For more information on USCC's Privacy Policy, visit

http://www.uscellular.com

Table of Contents

Section 1: Getting Started .............................6

Setting Up Your Phone . . . . . . . . . . . . . . . . . . . . .6

Charging a Battery . . . . . . . . . . . . . . . . . . . . . . . .9

Switching the Phone On or Off . . . . . . . . . . . . . .11

Locking and Unlocking the Touch Screen . . . . . .12

Setting up your Phone with Ready2Go . . . . . . . .12

Creating a Samsung Account . . . . . . . . . . . . . . .12

Creating a New Google Account . . . . . . . . . . . . .13

Retrieving your Google Account Password . . . . .13

Setting Up Your Voice Mail . . . . . . . . . . . . . . . . .13

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . .14

Section 2: Understanding Your Phone ........15

Features of Your Phone . . . . . . . . . . . . . . . . . . .15

Front View of Your Phone . . . . . . . . . . . . . . . . . .16

Side Views of Your Phone . . . . . . . . . . . . . . . . .17

Rear View of Your Phone . . . . . . . . . . . . . . . . . .18

S Pen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Display Layout . . . . . . . . . . . . . . . . . . . . . . . . . .22

Menu Navigation . . . . . . . . . . . . . . . . . . . . . . . .31

Customizing Your Home Screen . . . . . . . . . . . . .36

Notification Bar . . . . . . . . . . . . . . . . . . . . . . . . 42

Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Section 3: Call Functions ............................46

Displaying Your Phone Number . . . . . . . . . . . . 46

Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Making Emergency Calls . . . . . . . . . . . . . . . . . 47

Making a Call Using Speed Dial . . . . . . . . . . . . 48

Making a Call from the Address Book . . . . . . . . 49

Answering a Call . . . . . . . . . . . . . . . . . . . . . . . 49

Dialing Options . . . . . . . . . . . . . . . . . . . . . . . . 50

Call Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Call Duration . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Options During a Call . . . . . . . . . . . . . . . . . . . . 53

Call Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Section 4: Entering Text ..............................64

Text Input Methods . . . . . . . . . . . . . . . . . . . . . 64

Entering Text Using the Samsung Keyboard . . . 64

Changing the Text Input Mode - Keypad . . . . . . 65

Using ABC Mode . . . . . . . . . . . . . . . . . . . . . . . 65

Using Symbol/Numeric Mode . . . . . . . . . . . . . . 66

DRAFT - Internal Use Only

Predictive Text . . . . . . . . . . . . . . . . . . . . . . . . . 66

Samsung Keyboard Settings . . . . . . . . . . . . . . . 67

Using the Google Voice Typing Feature . . . . . . . 67

Section 5: Accounts and Contacts ............. 68

Accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Section 6: Multimedia ................................. 79

Media Hub . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Music Player . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Using Playlists . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Google Play Music . . . . . . . . . . . . . . . . . . . . . . . 84

Video Player . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Play Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Gallery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Using the Camera . . . . . . . . . . . . . . . . . . . . . . . 87

Camera Options . . . . . . . . . . . . . . . . . . . . . . . . 88

Using the Camcorder . . . . . . . . . . . . . . . . . . . . 91

Camcorder Options . . . . . . . . . . . . . . . . . . . . . . 92

Section 7: Messaging ................................. 95

Types of Messages . . . . . . . . . . . . . . . . . . . . . . 95

Creating and Sending Messages . . . . . . . . . . . . 95

Message Options . . . . . . . . . . . . . . . . . . . . . . . 96

Viewing New Received Messages . . . . . . . . . . . 98

Deleting Messages . . . . . . . . . . . . . . . . . . . . . .99

Message Search . . . . . . . . . . . . . . . . . . . . . . . .99

Messaging Settings . . . . . . . . . . . . . . . . . . . . .100

Using Email . . . . . . . . . . . . . . . . . . . . . . . . . . .101

Using Gmail . . . . . . . . . . . . . . . . . . . . . . . . . . .103

Google Talk . . . . . . . . . . . . . . . . . . . . . . . . . . .104

ChatON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

Section 8: Changing Your Settings .......... 108

Accessing Settings . . . . . . . . . . . . . . . . . . . . .108

Wi-Fi Settings . . . . . . . . . . . . . . . . . . . . . . . . . 108

Bluetooth settings . . . . . . . . . . . . . . . . . . . . . . 109

Sharing and Transferring Files . . . . . . . . . . . . .109

More Settings... . . . . . . . . . . . . . . . . . . . . . . . .112

Lock Screen Settings . . . . . . . . . . . . . . . . . . . 116

More Settings (Personalization) . . . . . . . . . . . . 116

Data Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

More... Settings . . . . . . . . . . . . . . . . . . . . . . . .118

Sound Settings . . . . . . . . . . . . . . . . . . . . . . . .124

Display Settings . . . . . . . . . . . . . . . . . . . . . . .127

Wallpaper . . . . . . . . . . . . . . . . . . . . . . . . . . . .127

DRAFT - Internal Use Only

LED indicator . . . . . . . . . . . . . . . . . . . . . . . . . .128

Motion Settings . . . . . . . . . . . . . . . . . . . . . . . .128

Dormant Mode . . . . . . . . . . . . . . . . . . . . . . . . .130

Power Saving . . . . . . . . . . . . . . . . . . . . . . . . .130

Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .130

Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .131

Application Manager . . . . . . . . . . . . . . . . . . . .131

Accounts and Sync . . . . . . . . . . . . . . . . . . . . .133

Location Services . . . . . . . . . . . . . . . . . . . . . .133

Security Settings . . . . . . . . . . . . . . . . . . . . . . .134

Language and Input . . . . . . . . . . . . . . . . . . . . .138

Voice Settings . . . . . . . . . . . . . . . . . . . . . . . . .141

Back up and reset . . . . . . . . . . . . . . . . . . . . . .142

Pen Settings . . . . . . . . . . . . . . . . . . . . . . . . . .143

Accessory Settings . . . . . . . . . . . . . . . . . . . . .143

Date and Time . . . . . . . . . . . . . . . . . . . . . . . . .144

Accessibility . . . . . . . . . . . . . . . . . . . . . . . . . .144

Hearing options . . . . . . . . . . . . . . . . . . . . . . . .146

Developer Options . . . . . . . . . . . . . . . . . . . . . .146

Allow mock locations . . . . . . . . . . . . . . . . . . . .147

User interface . . . . . . . . . . . . . . . . . . . . . . . . .147

About Device . . . . . . . . . . . . . . . . . . . . . . . . . .148

Section 9: Connections .............................150

Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150

Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156

NFC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160

Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160

PC Connections . . . . . . . . . . . . . . . . . . . . . . . 163

NFC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165

Section 10: Applications ...........................166

AllShare Play . . . . . . . . . . . . . . . . . . . . . . . . . 166

Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . 170

Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170

Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172

ChatON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172

Chrome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172

Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172

Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175

Downloads . . . . . . . . . . . . . . . . . . . . . . . . . . . 176

Email . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176

Gallery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176

Gmail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176

Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176

Kies air . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176

DRAFT - Internal Use Only

Latitude . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177

Local . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178

Maps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179

Media Hub . . . . . . . . . . . . . . . . . . . . . . . . . . . 180

Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . 180

Music Player . . . . . . . . . . . . . . . . . . . . . . . . . . 180

My Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180

Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181

Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183

Play Books . . . . . . . . . . . . . . . . . . . . . . . . . . . 183

Play Movies . . . . . . . . . . . . . . . . . . . . . . . . . . 183

Play Music . . . . . . . . . . . . . . . . . . . . . . . . . . . 184

Play Store . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184

Point& . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184

Polaris Office 4.0 . . . . . . . . . . . . . . . . . . . . . . 184

S Note . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185

S Suggest . . . . . . . . . . . . . . . . . . . . . . . . . . . . 186

S Voice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 186

Samsung Apps . . . . . . . . . . . . . . . . . . . . . . . . 187

Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187

Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187

Talk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187

Video Player . . . . . . . . . . . . . . . . . . . . . . . . . .187

Voice Recorder . . . . . . . . . . . . . . . . . . . . . . . .187

YouTube . . . . . . . . . . . . . . . . . . . . . . . . . . . . .188

Section 11: Health and Safety Information 190

Exposure to Radio Frequency (RF) Signals . . . .190

Specific Absorption Rate (SAR) Certification

Information . . . . . . . . . . . . . . . . . . . . . . . . .195

FCC Part 15 Information to User . . . . . . . . . . .196

Smart Practices While Driving . . . . . . . . . . . . . 197

Battery Use and Safety . . . . . . . . . . . . . . . . . .198

Samsung Mobile Products and Recycling . . . .200

UL Certified Travel Charger . . . . . . . . . . . . . . . 201

Display / Touch-Screen . . . . . . . . . . . . . . . . . .201

GPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .202

Emergency Calls . . . . . . . . . . . . . . . . . . . . . . .202

Care and Maintenance . . . . . . . . . . . . . . . . . .203

Responsible Listening . . . . . . . . . . . . . . . . . . .204

Operating Environment . . . . . . . . . . . . . . . . . . 206

FCC Hearing Aid Compatibility (HAC)

Regulations for Wireless Devices . . . . . . . . .208

Restricting Children's Access to Your

Mobile Device . . . . . . . . . . . . . . . . . . . . . . . 210

DRAFT - Internal Use Only

FCC Notice and Cautions . . . . . . . . . . . . . . . . .210

Other Important Safety Information . . . . . . . . .211

Section 12: Warranty Information ............213

Standard Limited Warranty . . . . . . . . . . . . . . .213

End User License Agreement for Software . . . .218

Section 13: Samsung Product Registration 224

Index ........................................................ 225

DRAFT - Internal Use Only

Section 1: Getting Started

This section explains how to start using your phone by first

configuring your hardware, activating your service, and then

setting up your voice mail.

Setting Up Your Phone

Prior to use it is necessary to install both the battery and SIM

into their corresponding internal compartments. The

microSD™ card slot is also located in this same internal

area.

1. Remove the back cover by inserting a fingernail into

the slot on the top of your phone (1).

2. Lift the cover up (2) and away from the phone (3).

Caution!

Do not bend or twist the back cover excessively.

Doing so may damage the cover.

USCC

Graphic Placement

USCC

Graphic Placement

DRAFT - Internal Use Only

Getting Started 7

Installing the SIM Card

When you subscribe to a cellular network, you are provided

with a plug-in SIM card loaded with your subscription details,

such as your PIN, available optional services, and many

others features.

Important!

You can easily damage the plug-in SIM card

information and its contacts by scratching or

bending the card, so be careful when handling,

inserting, or removing the card. Keep all SIM cards

out of reach of small children.



Carefully slide the SIM card into the SIM card socket

(as shown) until the card locks into place.

•

Make sure that the card’s gold contacts face into the phone

and that the upper-left angled corner of the card is positioned

as shown

Note:

If the card is not inserted correctly, the phone will not

detect the SIM card. Re-orient the card back into the slot

if the SIM is not detected.

USCC

Graphic Placement

DRAFT - Internal Use Only

Installing the Battery

1. Insert the battery into the opening on the back of the

phone, making sure the connectors align (1).

2. Gently press down to secure the battery (2).

Removing and Installing the Memory Card

You can use a microSD (SD) or microSDHC card to

expand available memory space if you desire. This secure

digital card enables you to exchange images, music, and

data between SD-compatible devices. This type of memory

card is designed for use with this mobile phone and other

devices.

Note:

Your phone has been tested to support up to a 64GB

memory card.

Installing the Memory Card



Push the microSD card into the slot until it clicks (as

shown).

•

Make sure the microSD’s gold contact pins face downward and

the card is securely inserted.

For more information on Memory Cards, see “Memory Card”

on page 44.

USCC

Graphic Placement

USCC

Graphic Placement

DRAFT - Internal Use Only

Getting Started 9

Removing the Memory Card

1. Push on the memory card until it clicks and is released.

2. Grasp the memory card and remove it from the phone.

Installing the Back Cover

1. Place the battery cover onto the back of the phone (1)

and press down (2).

2. Press along the edge of the back cover (3) until you

have a secure seal.

Note:

Make sure the battery is properly installed before

switching on the phone.

Charging a Battery

Your device is powered by a rechargeable Li-ion battery. The

Travel Charger that is used to charge the battery, is included

with your device. Use only Samsung-approved batteries and

chargers.

Note:

You must fully charge the battery before using your

phone for the first time. A discharged battery recharges

fully in approximately 4 hours.

USCC

Graphic Placement

USCC

Graphic Placement

DRAFT - Internal Use Only

Note:

Long backlight settings, searching for service, vibrate

mode, web browser use, and other variables may

reduce the battery’s talk and standby times.

Although you can use the phone while the battery is

charging, doing so will require additional charging time.

Using the Travel Charger

Important!

Verify that the handset battery is installed prior to

connection. If the battery is not properly installed

and the wall charger is connected, the handset

may power off and on continuously, preventing

proper operation. 1. Plug the flat end of the Travel Charger into the Power/

Accessory Interface connector and the other end into a

standard AC wall outlet.

2. When charging is finished, remove the flat end from

the interface connector jack on the phone.

USCC

Graphic Placement

DRAFT - Internal Use Only

Getting Started 11

Warning!

If your handset has a touch screen display, please

note that a touch screen responds best to a light

touch from the pad of your finger. Using excessive

force or a metallic object when pressing on the touch

screen may damage the tempered glass surface and

void the warranty. For more information, refer to

“Standard Limited Warranty” on page 213.

Note:

Failure to unplug the wall charger before you remove the

battery, can cause damage to the phone.

Low Battery Indicator

When the battery is weak and only a few minutes of talk time

remain, the battery icon ( ) blinks and the device sounds a

warning tone at regular intervals. In this condition, your

phone conserves its remaining battery power, not by turning

off the backlight, but by entering the dimming mode. For a

quick check of your battery level, glance at the battery

charge indicator located in the upper-right corner of your

device’s display. Solid color ( ) indicates a full charge.

When the battery level becomes too low, the phone

automatically turns off.

Switching the Phone On or Off

1. Press and hold until the phone switches on.

2. Swipe your finger across the screen to unlock the

phone.

Note:

The display language is preset to English at the factory.

To change the language, use the Language menu. For

more information, refer to “Changing Your Settings” on

page 108.

3. To switch off the phone, press and hold , until

the

Device options

screen displays.

USCC

Graphic Placement

DRAFT - Internal Use Only

4. Tap

Power off

to switch off the phone.

5. At the

Power off

prompt, tap

Locking and Unlocking the Touch

Screen

1. Press to lock the touch screen.

2. Press again to display the lock screen then

swipe your finger across the screen to unlock.

2. Touch

Get Started

to begin.

– or –

Creating a Samsung Account

An active Samsung account is required to begin accessing

applications such as ChatON and AllShare Play.

1. From the home screen, touch and hold the Notification

Bar until the pull-down displays, then drag down

vertically. For more information, refer to “Notification

Bar” on page 42.

2. Tap

Samsung account

3. Tap

Create new account

4. Tap

Terms and conditions

to read them and tap

5. Tap the

I accept all the terms

above

checkbox.

6. Tap

and read the policy and tap

7. Tap

Agree

8. Enter the required information and tap

9. At the Welcome screen, tap

10. Follow the on-screen instructions to verify your email

address and activate your account.

DRAFT - Internal Use Only

Getting Started 13

Creating a New Google Account

In order to utilize your device to the fullest extent, you will

need to create a Google™ Account when you first use your

device. With a Google Account, Google applications will

always be in sync between your phone and computer.

If you did not create a new account during the setup

procedure when you first turned your phone on, follow these

steps:

1. From the Home screen, tap ➔

Gmail

The

Add a Google Account

screen displays.

2. Tap

New

to create a new Google account.

– or –

If you already have a Google account, tap

Existing

3. Follow the on-screen instructions to add a Google

Account.

Note:

Once you have created a Google account, you only need

to sign in.

Retrieving your Google Account

Password

A Google account password is required for Google

applications. If you misplace or forget your Google Account

password, follow these instructions to retrieve it:

1. From your computer, use an Internet browser and

navigate to

http://google.com/accounts.

2. Click on the

Can’t access your account?

link.

3. Tap the

I forgot my password

radio button.

4. Enter your Email address and click

Continue

5. Follow the password recovery procedure.

Setting Up Your Voice Mail

1. From the Home screen, tap , then tap .

2. Follow the tutorial to create a password, record a

greeting, and record your name.

Note:

These steps may be different depending on your

network.

DRAFT - Internal Use Only

Accessing Your Voice Mail

1. From the Home screen, tap , then tap .

You may be prompted to enter a password.

2. When connected, follow the voice prompts from the

voice mail center.

Accessing Your Voice Mail From Another Phone

1. Dial your wireless phone number.

2. When you hear your voicemail greeting, press the

asterisk key on the phone you are using.

3. Enter your password.

Troubleshooting

If your device has fatal errors, hangs up, or freezes, you may

need to reset the device to regain functionality.



If your device is frozen and unresponsive, press and

hold the Power/Lock Key for 8 to 10 seconds.

DRAFT - Internal Use Only

Understanding Your Phone 15

Section 2: Understanding Your Phone

This section outlines some key features of your phone and

describes the screen and the icons that display when the phone

is in use. It also shows how to navigate through the phone and

provides information on using a memory card.

Features of Your Phone

Your phone is lightweight, easy-to-use and offers many

useful features. The following list outlines a few of the

features included in your phone.

•

4G LTE network with 1.5 gigahertz quad-core processor

•

Android v 4.1.1, Jelly Bean Platform

•

Touch screen provides quick response to a variety of in-phone

menus and options including applications and seven home

screens

•

Virtual (on-screen) QWERTY keyboard

•

Ready access to the Internet

•

Built-in Bluetooth and advanced Wi-Fi

technology

•

USB Tethering-capable

•

Mobile Hotspot Capability

•

Brilliant 5.5” HD SuperAMOLED plus display

•

8 Megapixel camera and camcorder with 2 Megapixel Front

Facing camera

•

GPS Navigation functionality provides real-time navigation

•

Up to 32 GB expandable memory slot

•

Corporate and Personal Email

•

Sync and update social network applications

•

Over 250,000 Apps available to download

•

Access to Movies and TV Shows with Samsung Media Hub

•

Full Integration of Google Mobile™ Services (Gmail, YouTube,

Google Maps, Google Voice Search)

•

Multiple Messaging Options: Text/Picture/Video Messaging, and

Instant Messaging with Google Talk™

•

DivX Certified

to play DivX

video up to HD 1080p, including

premium content

•

AllShare™ Play to share your media content across DLNA

certified devices

DRAFT - Internal Use Only

Front View of Your Phone

Status light

: displays red when charging, green when

fully charged, blue when powering up, and orange

when a notification has arrived.

External speaker

: allows you to hear the caller.

3. Application icons: you can place shortcuts to your

favorite applications on the Home screen.

4. Primary shortcuts: allows quick access to important

features such as Phone, Contacts, Messaging, Internet,

and Apps. For more information, refer to “Primary

Shortcuts” on page 22.

5. Menu key: allows you to access sub-menus with

additional options for different features and

applications such as Home screen, Phone, Contacts,

Messaging, and Web.

6. Home key: allows you to return to the main Home

screen from any Home screen or menu. Press and hold

to display Task Manager. Quickly press twice to

activate the S Voice application.

7. Back key: allows you step backwards when navigating

a menu or web page.

113

USCC

Graphic Placement

DRAFT - Internal Use Only

Understanding Your Phone 17

Home screen indicator

: shows which Home screen is

presently displayed.

9. Google Quick Search bar: a shortcut to Google Search

that allows you to search for items on the internet.

10. AccuWeather screen: displays Time, Day, Date,

Temperature and weather conditions for your area.

11. Indicator icons: shows the information needed to

operate your phone, such as the received signal

strength, phone battery level, time, unread Emails,

missed calls, etc.

12.

Front facing camera

: allows you to take pictures of

yourself when you set the camera shooting mode to

Self shot.

13.

Proximity and Light sensors

: uses the ambient light

level to adjust keypad access. If the light path is

blocked, for example, when holding the phone close to

your ear, the touch screen will turn off.

Side Views of Your Phone

USCC

Graphic Placement

DRAFT - Internal Use Only

3.5mm Headset jack

: allows you to plug in headphones.

Volume keys

: allow you to adjust the ringer volume

while in standby mode or adjust the voice volume

during a call. When receiving an incoming call, briefly

press down either volume key ( ) to mute the

ring tone. Adjusts text size when reading a message or

using the browser in the Apps folder.

3. Power/Accessory Interface connector: allows you to

connect a Travel Charger or other optional accessories

such as a USB/data cable or a hands-free headset for

convenient, hands-free conversations.

Microphone

: allows other callers to hear you when you

are speaking to them. It also used for the

Speakerphone.

5. Power/Lock key: ( ) lets you power your phone

on and off. Also allows you to lock or unlock the touch

screen. For more information on locking your phone,

see “Locking and Unlocking the Phone” on page 34.

Microphone

: used for noise cancellation and stereo

recording.

Rear View of Your Phone

Flash

: is used to provide adequate light when taking

pictures in dark places.

External speaker

: allows you to hear when the

Speakerphone is turned on.

Camera lens

: is used to take pictures and shoot videos.

USCC

Graphic Placement

DRAFT - Internal Use Only

Understanding Your Phone 19

S Pen

The S Pen is a stylus that assists you in performing different

functions. By using the Pen button, you can minimize having

to switch between touch and pen input.

Pen button

: by pressing the Pen button, you can add

functionality to the S Pen. For more information, refer

to “Using the S Pen” on page 20.

Stylus tip

: the tip of the S Pen is used for tapping the

screen.

Removing the S Pen from your Phone

The S Pen is stored in your phone to make it easier to keep

track of.

To remove the S Pen, follow these steps:

1. Use your fingernail or a sharp object to pull the end of

the S Pen out of the phone (1).

2. Pull the S Pen out of the phone (2).

USCC

Graphic Placement

USCC

Graphic Placement

DRAFT - Internal Use Only

Using the S Pen

There are several different functions you can perform by

using the S Pen.

Back Button

To move to a previous screen, hold the S Pen button and

touch and drag the screen to the left. The previous screen

displays.

Menu Button

To display the menu from any screen, hold the S Pen button

and touch and drag the screen upward. The menu displays.

Press S Pen button

USCC

Graphic Placement

Press

S Pen

button

USCC

Graphic Placement

DRAFT - Internal Use Only

Understanding Your Phone 21

Launch S Note

S Note is an application that you can launch from any screen

to take quick notes or jot down ideas. To open S Note, hold

the S Pen button and double-tap the screen. ???cross ref

here.

Screen Capture

To take a screen capture, hold the S Pen button and press

and hold the S Pen anywhere on the screen. Files are saved

in the

My Files

➔

sdcard0

➔

Screenshots

folder.

USCC

Graphic Placement

USCC

Graphic Placement

DRAFT - Internal Use Only

Write on any Screen after Capture

To write on a screen capture, use the pen to draw or write.

Files are saved in the

My files

➔

sdcard0

➔

Screenshots

➔

IMG_Edited

folder.

Display Layout

Your display screen provides a wealth of information about

the phone’s status and options, as well as providing access

to application icons. For more information, refer to “Front

View of Your Phone” on page 16.

Primary Shortcuts

There are four non-movable Application Shortcuts that

display at the bottom of all Home screens. The default

shortcuts are:

•

Phone

for dialing a number.

•

Messaging

for creating and viewing Messages.

•

S Note

for

creating notes using the keypad or S Pen

•

Internet

for surfing the Internet.

•

Apps

for accessing the applications on your phone.

You can change the Phone, Messaging, S Note, and Internet

application shortcuts to any icon that displays in the Apps

menu.

For more information, refer to “Adding and Removing

Primary Shortcuts” on page 37.

USCC

Graphic Placement

DRAFT - Internal Use Only

Understanding Your Phone 23

Indicator Icons

This list identifies the symbols you’ll see on your phone’s

display and Indicator area:

Displays your current signal strength. The greater

the number of bars, the stronger the signal.

Indicates that the Airplane Mode is active. You

cannot send or receive any calls or access online

information.

Displays when there is no SIM card in the phone.

Displays when there is no network available.

Displays when there is a system error or alert.

Displays when a call is in progress.

Displays when a call is on hold.

Displays when the speakerphone is on.

Displays when a call has been missed.

Displays when a call has been muted.

Displays when Call forwarding is set to Always

forward. For more information, refer to “Call

forwarding” on page 60.

Displays your battery charge level. Icon shown is

fully charged.

Displays when your battery is charging. Also

displays battery charge level.

Device Power Very Low – Shows your current

battery only has between 5 and 15 percent power

remaining.

Device Power Critical – Shows your current battery

only has less than 5 percent power remaining and

will immediately shutdown.

DRAFT - Internal Use Only

Displays when your connection to a 4G LTE network

is active.

Displays when your phone is communicating with

the 4G LTE network.

Displays when your phone is downloading or has

downloaded a file. It will blink green when it is

installing.

Displays when the an outbound file transfer is in

progress.

Displays when a Play Store download has

completed.

Displays when updates are available for download.

Displays when the phone is connected to a

computer via a supported USB cable connection.

Displays when the phone is tethered via a

supported USB cable connection.

Displays when a new text or multimedia message

is received.

Displays when a new voice mail is received.

Displays when Email is received.

Displays when the time and date for a Calendar Event

has arrived. For more information, refer to

“Calendar” on page 170.

Displays when you set an alarm to ring at a specified

time. For more information, refer to “Alarm” on page

172.

Displays when the Sound profile is set to Mute.

Displays when the Sound profile is set to Vibrate.

DRAFT - Internal Use Only

Understanding Your Phone 25

Displays when Bluetooth is activated.

Displays when a Bluetooth device has been paired

with the phone.

Displays briefly when Bluetooth is on but is not

connected to a Bluetooth device.

Displays when Wi-Fi is connected, active, and

communicating with a Wireless Access Point

(WAP).

Displays when Wi-Fi is active but there is a

communication issue with the target Wireless

Access Point (WAP).

Displays when Wi-Fi Direct is active and your phone

is connected to another device.

Displays when your phone as been configured as a

portable Wi-Fi hotspot.

Displays when your phone is connected to a PC

using Kies air.

Displays when your phone is connected to a Digital

Living Network Alliance (DLNA) certified device

using the AllShare Play application.

Displays when GPS is active and acquiring a signal.

Displays when data synchronization and

application sync is active and synchronization is in

progress for Gmail, Calendar, and Contacts.

Displays when your phone is connecting to the

Device Management server when you first turn on

your phone.

Displays when your device is connected to control

streaming media and is connected to a

Digital Living Network Alliance (DLNA) certified

device using the AllShare Play application.

Displays when a file is being uploaded or sync’d

between your device and an external Web storage

location.

Displays when the uploaded or transferred file was

successfully delivered.

DRAFT - Internal Use Only

For more details on configuring your phone’s settings, see

“Changing Your Settings” on page 108.

Application Icons

The Apps menu provides quick access to the items you use

most frequently.

The following table contains a description of each

application. If the application is already described in another

section of this user manual, then a cross reference to that

particular section is provided.

For information on navigating through the Apps icons, see

“Navigating Through the Application Menus” on page 35.

1. From the Home screen, tap , then tap one of the

application icons.

2. Follow the on-screen instructions.

3. To return to the main Home screen, tap .

The following applications are available:

Displays when TTY device has been inserted.

Displays when a screen capture has been taken.

Displays when the keypad is active.

Displays when you have not yet set up a Samsung

Account.

Displays when an emergency call is taking place.

AllShare Play

: AllShare Play allows your phone to

stream photos, music and videos from its memory to

other Digital Living Network Alliance (DLNA) certified

devices. Your phone can also play digital content

streamed from other DLNA certified devices. For more

information, refer to “AllShare Play” on page 166.

Calculator

: Using this feature you can use the phone as

a calculator. The calculator provides the basic

arithmetic functions; addition, subtraction,

multiplication, and division. You can also use this as a

scientific calculator. For more information, refer to

“Calculator” on page 170.

DRAFT - Internal Use Only

Understanding Your Phone 27

Calendar

: With the Calendar application, you can

consult the calendar by day, week, month, year, create

events, and set an alarm to act as a reminder, if

necessary. For more information, refer to “Calendar”

on page 170.

Camera

: Use your 8.0 megapixel camera feature to

produce photos and videos. For more information, refer

to “Camera” on page 87.

ChatON

: With the ChatON application, you can interact

with friends and family with text, images, hand-written

notes and video shared instantly. You can also chat in

groups. For more information, refer to “ChatON” on

page 172.

Chrome

: The Google Chrome app allows you to use the

Google Chrome web browser on your phone. ???

Clock

: The Clock application allows you to access

alarms, view the World Clock, set a stopwatch, use a

timer, and setup a Desk Clock. For more information,

refer to “Clock” on page 172.

Contacts

: You can manage your daily contacts by

storing their name and number in your Address Book.

Address Book entries can be sorted by name, entry, or

group. For more information, refer to “Accounts and

Contacts” on page 68.

Downloads

: The Downloads application allows you to

manage all of your downloads from the Play Store and

the Browser. For more information, refer to

“Downloads” on page 176.

: Email enables you to review and create email

using various email services. You can also receive text

message alerts when you receive an important email.

For more information, refer to “Using Email” on page

101.

Gallery

: The Gallery is where you view photos and play

back videos. For photos, you can also perform basic

editing tasks, view a slideshow, set photos as

wallpaper or contact image, and share as a picture

message. For more information, refer to “Gallery” on

page 86.

DRAFT - Internal Use Only

Gmail

: Gmail is a web-based email service. Gmail is

configured when you first set up your phone.

Depending on your synchronization settings, Gmail

can automatically synchronize with your Gmail

account on the web. For more information, refer to

“Using Gmail” on page 103.

Internet

: Open the web browser to start surfing the

web. The browser is fully optimized and comes with

advanced functionality to enhance the Internet

browsing feature on your phone. For more information,

refer to “Internet” on page 150.

Kies air

: Kies air allows you to sync your Windows PC

wirelessly with your phone provided they are both on

the same Wi-Fi network. You can view call logs, videos,

photos, bookmarks, IMs, and even send SMS

messages from your home computer. For more

information, refer to “Kies air” on page 164.

Latitude

: With Google Latitude, you can see the location

of all of your friends on a map or on a list. You can also

share or hide your location. For more information, refer

to “Latitude” on page 177.

Local

: Local is an application that uses Google Maps

and your location to help you find Restaurants, Cafes,

Bars, Attractions, and more. You can also add your own

locations. For more information, refer to “Local” on

page 178.

Maps

: Depending on your location, you can view basic,

custom, and satellite maps and local business

information, including locations, contact information,

and driving directions. You can also post public

messages about a location and track your friends. For

more information, refer to “Maps” on page 179.

Media Hub

: Samsung Media Hub is your one stop for the

hottest movie and TV content. You can rent or purchase

your favorite content and watch from the convenience

of anywhere. For more information, refer to “Media

Hub” on page 79.

Messaging

: You can send and receive different types of

messages. For more information, refer to “Messaging”

on page 95.

DRAFT - Internal Use Only

Understanding Your Phone 29

Music Player

: Music Player allows you to play music

files that you have stored on your phone and memory

card. You can also create playlists. For more

information, refer to “Music Player” on page 81.

My Files

: My Files allows you to manage your sounds,

images, videos, bluetooth files, Android files, and other

memory card data in one convenient location. For more

information, refer to “My Files” on page 180.

Navigation

: Navigation is an internet-connected GPS

navigation system with voice guidance. You can type or

speak your destination. For more information, refer to

“Navigation” on page 181.

Phone

: Allows you to access the dialer keypad, call

logs, and favorites. For more information, refer to “Call

Functions” on page 46.

Play Books

: With Google Play Books, you can find

more than 3 million free e-books and hundreds of

thousands more to buy in the eBookstore. For more

information, refer to “Play Books” on page 183.

Play Movies

: With Google Play Movies, you can rent

thousands of different movies and television shows.

You can watch instantly, or download your movie or

show for offline viewing at a later time. For more

information, refer to “Play Movies” on page 85.

Play Music

With the Music application, while online, you can

play music that you have added to your music file as well as

any music you copied from your PC. While offline, you can

listen to music you have copied from your PC.

For more

information, refer to “Google Play Music” on page 84.

Play Store

: The Play Store provides access to

downloadable applications and games to install on

your phone. For more information, refer to “Play Store”

on page 184.

Point&

: Require information for this application. ???

Polaris Office 4.0

: Polaris® Office 4.0 is a Microsoft

Office compatible office suite. This application

provides a central place for managing your

documents online or offline. For more information,

refer to “Polaris Office 4.0” on page 184.

DRAFT - Internal Use Only

S Note

: The S Note application allows you to create

notes using the keypad, the S Pen tool, or both. You can

add images, voice recordings, and text all in one place.

???

S Suggest

: This application recommends popular

applications when connected to a Wi-Fi network. All

recommended applications are guaranteed to be

compatible with your device. For more information,

refer to “S Suggest” on page 186.

S Voice

: With the S Voice application you can use your

voice to perform operations that you would normally

have to do by hand such as dialing a phone number,

texting a message, playing music, etc. For more

information, refer to “S Voice” on page 186.

Samsung Apps

: ???

: The Google Search application is the same on-

screen Internet search engine that is on the Google

Search Bar on your main Home screen. For more

information, see “Google Search Bar” on page 31.

Settings

: This icon navigates to the sound and phone

settings for your phone. It includes such settings as:

display, security, memory, and any extra settings

associated with your phone. For more information,

refer to “Changing Your Settings” on page 108.

Talk

: Google Talk is a free Windows and web-based

application for instant messaging offered by Google.

Conversation logs are automatically saved to a Chats

area in your Gmail account. This allows you to search

a chat log and store them in your Gmail accounts. For

more information, refer to “Google Talk” on page 104.

Video Player

: The Video Player application plays video

files stored on your microSD card. For more

information, refer to “Video Player” on page 84.

Voice recorder

: The Voice recorder allows you to record

an audio file up to one minute long and then

immediately send it as a message. For more

information, refer to “Voice Recorder” on page 187.

YouTube

: YouTube is a video sharing website on which

users can upload and share videos, and view them in

MPEG-4 format. For more information, refer to

“YouTube” on page 188.

DRAFT - Internal Use Only

Understanding Your Phone 31

Tip:

To open applications quickly, add the icons of frequently-

used applications to the Home screen or to the folders you

created. For details, see “Customizing Your Home Screen”

on page 36.

Google Search Bar

The Google Search Bar provides you an on-screen Internet

search engine powered by Google™.

1. From the main home screen, tap the Google Search bar

2. Use the on-screen keypad to enter the item you want

to search for, then tap .

3. Tap to use Google Voice Search. For more

information, refer to “S Voice” on page 186.

Menu Navigation

You can tailor the phone’s range of functions to fit your needs

using both menus and widgets. Menus, sub-menus, and

features can be accessed by scrolling through the available

on-screen menus. Your phone originally has five home

screens.

Command Keys

Menu Key

Press

to display a context-sensitive menu of

options for the current screen or feature.

Home Key

Press

Home

to display the main Home screen. Press

and hold to display recently used apps and access the Task

manager.

Back Key

Press

Back

to return to the previous screen, option or

step.

Terms used in this user manual

Tap

Lightly touch items to select or launch them. For example:

•

Tap the on screen keyboard to enter characters or text.

•

Tap a menu item to select it.

•

Tap an application’s icon to launch the application.

Touch and Hold

Activate on-screen items by a touch and hold gesture. For

example:

•

Touch and hold a widget on the home screen to move it.

DRAFT - Internal Use Only

•

Touch and hold on a field to display a pop-up menu of options.

Swipe and Palm Swipe

To swipe, lightly drag your finger vertically or horizontally

across the screen. Use swipe when:

•

Unlocking the screen

•

Scrolling through the Home screen or a menu

To palm swipe, swipe the side of your hand horizontally

across the screen. Use palm swipe when:

•

Capturing the screen

Panning

To pan, touch and hold a selected icon, then move the device

to the left or right to reposition it to another page. You must

first activate Motion on your device. Use panning to:

•

Move icons on your Home screens or Application Menus to

another page.

For more information, refer to “Power Saving” on page 130.

Tilt

To activate the tilt feature, press and hold two points on the

screen then tilt the device back and forth to reduce or

enlarge the screen. Use tilt to:

•

Reduce or enlarge the screen in the Gallery or Browser.

For more information, refer to “Power Saving” on page 130.

Turn over

Turn your phone over so that the screen faces downward. For

example:

•

Mute incoming calls and playing sounds by turning your phone

over.

Using Gestures

By activating the various gesture features you can access a

variety of time saving functions.

To activate motion:

1. From the Home screen, press and then tap

Settings

➔

Motion

2. Tap the ON/OFF icon located at the top of

the screen to activate motion.

3. Tap the checkboxes located to the right of each motion

option to activate the motions you wish. A checkmark

displays to indicate activation.

The following is a description of the available gestures:

•

Quick glance

: Once enable, you can check key information at a

glance by reaching towards your device.

DRAFT - Internal Use Only

Understanding Your Phone 33

•

Direct call

: Once enabled, the device will dial the currently

displayed on-screen Contact entry as soon as you place the

device to your ear.

•

Smart alert

: Once enabled, pickup the device to be alerted and

notified of you have missed any calls or messages.

•

Double tap to top

: Once enabled, double tap the top of the

device to be taken to the top of the current on-screen list.

•

Tilt to zoom

: Once enabled, you must be on a screen where

content can be zoomed. In a single motion, touch and hold two

points on the display then tilt the tilt the device back and forth to

zoom in or out.

•

Pan to move icon

: Once enabled, touch and hold a desired

application shortcut icon or widget on the screen. Once it

detaches, move the device left or right to migrate it to a new

location.

•

Pan to browse images

: Once enabled, touch and hold a desired

on-screen image to pan around it. Move the device left or right to

pan vertically or up and down to pan horizontally around the large

on-screen image.

•

Shake to update

: Once enabled, shake your device to rescan for

Bluetooth devices, rescan for Wi-Fi devices, Refresh a Web page,

etc.

•

Turn over to mute/pause

: Once enabled, mute incoming calls

and any playing sounds by turning the device display down on a

surface. This is the opposite of the Pickup to be Notified Gesture.

•

Palm swipe to capture

: Once enabled, you can capture any

on-screen information swiping across the screen. In a single

motion, press the side of your hand on the screen and swipe form

left to right. The image is then copied to the clipboard.

•

Palm touch to mute/pause

: Once enabled, you can pause any

on-screen video or mute any current sound by simply covering

the screen with your hand. Once you remove your hand from the

screen, the device goes back to normal by either continuing to

play the current video or unmuting the current sound.

For more information, refer to “Power Saving” on page 130.

DRAFT - Internal Use Only

Locking and Unlocking the Phone

To unlock your phone:

1. Press the lock button located on the upper right

side of your phone.

2. The lock screen will display with

Swipe screen to

unlock

displayed at the bottom of the screen.

3. Swipe the touch screen in any direction.

4. The Home screen will display as shown above.

Note:

There are several additional ways you can lock your

screen. For more information, refer to “Lock Screen

Settings” on page 116.

Home Screen Overview

The main home screen is the starting point for many

applications and functions, and it allows you to add items

like application icons, shortcuts, folders, or Google widgets

to give you instant access to information and applications.

This is the default page and accessible from any menu by

pressing .

Navigating Through the Home Screens

Your phone initially has five home screens. If you like, you

can place different applications on each of the home

screens.



From the main Home screen, sweep the screen with

your finger in either direction. The main Home Screen

is located in the middle with two Home screens on

each side.

USCC

Graphic Placement

DRAFT - Internal Use Only

Understanding Your Phone 35

Navigating Through the Application Menus

Your phone initially has three Application Menus available.

Follow these steps to navigate through the Application

Menus:

1. At the Home screen, tap . The first Application

Menu displays.

2. Sweep the screen left or right to access the other two

menus.

3. Tap one of the application icons.

Note:

As you add applications, the number of Application

menus that you have available will increase.

Navigating Using Sub-Menus

Sub-menus are available when you are at any Home screen

or have selected a feature or application such as Phone,

Contacts, Messaging, or Internet.

To access a sub-menu:

1. Press .

A sub-menu displays at the bottom of the phone

screen.

USCC

Graphic Placement

DRAFT - Internal Use Only

2. Tap an option.

Accessing Recently-Used Apps

1. Press and hold from any screen to open the

recently-used applications window.

2. Tap an icon to open the selected application.

– or –

Tap

Task manager

to go to the Task manager.

Customizing Your Home Screen

You can customize your Home screen by doing the following:

•

Creating Shortcuts

•

Adding and Removing Widgets on the Home Screen

•

Repositioning Widgets

•

Creating Folders

•

Changing the Wallpaper

•

Adding and Deleting Home Screens

Creating Shortcuts

Shortcuts are different than the current Home screen

Widgets that only launch an application. Shortcuts activate a

feature, action, or launch an application.

Note:

To move a shortcut from one screen to another, it must

first be deleted from its current screen. Navigate to the

new screen, then add the shortcut.

Adding a shortcut from the Apps Menu

1. Press to activate the main Home screen.

2. Navigate to the desired Home Page.

3. Tap to display your current applications.

Sub-Menu items

USCC

Graphic Placement

DRAFT - Internal Use Only

Understanding Your Phone 37

4. Scroll through the list and locate your desired

application.

5. Touch and hold the application icon. This creates an

immediate shortcut of the selected icon and closes the

Apps

tab.

6. While still holding the on-screen icon, position it on the

current page. Once complete, release the screen to

lock the new shortcut into its new position on the

current screen.

Adding a shortcut via the Add to Home screen

1. Press to activate the main Home screen.

2. Navigate to the desired Home Page.

3. Touch and hold on an empty area of the Home screen.

4. Tap

Add to Home screen

5. Tap

Apps and widgets

Folder

, or

Page

6. Press and hold a shortcut from the available list and

position it on the current screen.

Deleting a shortcut

1. Press to activate the main Home screen.

2. Touch and hold the desired shortcut. This unlocks it

from its location on the current screen.

3. Drag the icon over the Delete icon and release it.

As you place the shortcut into the Trash, both items

turn red.

Note:

This action does not delete the shortcut, it just removes

it from the current screen.

Adding and Removing Primary Shortcuts

You can change any of your primary shortcuts with the

exception of the

Apps

shortcut.

1. Press to activate the main Home screen.

2. Touch and hold the primary shortcut you want to

replace, then drag it to an empty space on any Home

screen.

3. Scroll through the Home screen to find the shortcut you

want to add as the new primary short cut.

4. Touch and hold the new shortcut, then drag it to the

empty space in the row of primary shortcuts.

The new primary shortcut will now display on all Home

screens.

DRAFT - Internal Use Only

Adding and Removing Widgets

Widgets are self-contained applications that reside in either

your Widgets tab or on the main or extended Home screens.

Unlike a shortcut, the Widget displays as an on-screen

application.

Adding a Widget

1. Press to activate the main Home screen.

2. Navigate to the desired Home Page.

3. Touch and hold on an empty area of the screen.

4. Tap

Apps

5. Tap the

Widgets

tab at the top of the screen.

6. Press and hold an available Widget to position it on the

current screen.

Removing a Widget

1. Touch and hold a Widget until you can move it around

on the screen.

2. Drag the Widget over the Delete icon and release

it.

As you place the Widget into the Trash, both items turn

red.

Note:

This action does not actually delete the Widget, it just

removes it from the current Home screen.

Moving Icons in the Apps Menu

1. Press to activate the main Home screen.

2. Tap to display your current applications.

3. Tap the

Apps

tab at the top of the screen if it is not

already selected.

4. Press and tap

View type

5. Tap

Customizable grid

. A green circle displays next to

the option.

6. Press and tap

Edit

7. Scroll through the list and locate the icon you wish to

move.

8. Touch and drag the icon to the position that you want.

To move to a different page, drag the icon to the edge

of the page until the page scrolls to the desired page.

9. Tap

Save

10. Press to return to the Home screen.

DRAFT - Internal Use Only

Understanding Your Phone 39

Creating Application Folders

You can create application folders to hold similar applications

if you wish.

To create a folder follow these steps:

1. Press to activate the main Home screen.

2. Tap to display your current applications.

3. Tap the

Apps

tab at the top of the screen if it is not

already selected.

4. Press and tap

Edit

5. Touch and hold the first application that you would like

to move to a folder.

6. Drag the icon down to the icon.

7. A folder displays in the original place of the application

icon with the application icon displayed on top of it.

8. Repeat steps 5 - 7 to add additional apps to the folder.

9. Drag the icon down to the icon to view

information on the application.

10. Tap

Save

Adding a New Page to the Application Menu???

You can add a new page to your application menu by

following these steps:

1. Press to activate the main Home screen.

2. Tap to display your current applications.

3. Tap the

Apps

tab at the top of the screen if it is not

already selected.

4. Press and tap

Edit

5. Touch and hold the first application that you would like

to move to a new page.

6. Drag the icon down to the icon.

The app displays on a new page.

Changing the Wallpaper

You can change the Wallpaper (background) of your home

screens by following these steps:

1. From any Home screen, touch and hold on an empty

area of the screen.

The

Home screen

window displays.

2. Tap

Set wallpaper for

3. Select the location where you would like to change the

wallpaper. Tap

Home screen

Lock screen

, or

Home and

lock screens

4. Tap one of the following options:

DRAFT - Internal Use Only

• Gallery

: select a wallpaper from photographs you have taken

with your camera.

• Live wallpapers

: select an animated wallpaper. This option is

not available for the Lock screen option.

• Wallpapers

: select from many still-life wallpapers.

5. Select a wallpaper and tap

Set wallpaper

Done

, or

Cancel

Moving Home Screens

Your phone comes with seven Home screens. You can

arrange the screens in any order that you want.

To move a Home screen, follow these steps:

1. Press to activate the main Home screen.

2. Press and tap

Edit page

3. Touch and hold the Home screen you want to move.

4. Drag it to the location that you would like to place it.

In this example, the YP app screen is moved to the last

position.

When you move a Home screen, the other Home

screens will be re-ordered automatically.

USCC

Graphic Placement

DRAFT - Internal Use Only

Understanding Your Phone 41

5. Press to return to the main Home screen.

Adding and Deleting Home Screens

You can delete Home screens and then add Home screens

later if you want.

To delete a Home screen, follow these steps:

1. Press to activate the main Home screen.

2. Press and tap

Edit page

3. Touch and hold the Home screen you want to delete.

4. Drag it to the trash can located at the bottom of the

screen.

5. If there are items on the Home screen that you want to

delete, the

Remove home screen page

prompt displays.

6. Tap

to delete the page and its contents, otherwise

tap

Cancel

7. Press to return to the main Home screen.

USCC

Graphic Placement

USCC

Graphic Placement

DRAFT - Internal Use Only

To add a Home screen, follow these steps:

1. Press to activate the main Home screen.

2. Press and tap

Edit page

3. Touch and hold the Home screen that contains and

drag it to the new location.

Note:

The icon will only be displayed if a Home screen has

previously been deleted.

4. Press to return to the main Home screen.

You can now add items to your new Home screen.

Notification Bar

The Notification Bar includes a pull-down list to show

information about processes that are running, recent

notifications, and alerts. To display the Status indicator:



On the Home screen, touch and hold the Notification

Bar until the pull-down displays, then drag down

vertically.

USCC

Graphic Placement

DRAFT - Internal Use Only

Understanding Your Phone 43

Clearing Notifications

To clear all notifications from the Notification panel:

1. From the Home screen, touch and hold the Notification

Bar until the pull-down displays, then drag down

vertically.

2. Tap the

Clear

button.

The notifications are cleared and the panel closes.

Accessing Additional Panel Functions

In addition to notifications, this panel also provides quick and

ready access to separate device functions. These can be

quickly activated or deactivated by toggling them on or off.

The following functions can either be activated (green) or

deactivated (gray): Wi-Fi, Bluetooth, GPS, Sound, Screen

rotation, Mobile data, Power saving, Airplane mode, Driving

mode, and Sync.

Clear Button

DRAFT - Internal Use Only

Memory Card

Your device lets you use a microSD (SD) or microSDHC

card to expand available memory space. This secure digital

card enables you to exchange images, music, and data

between SD-compatible devices. This section addresses the

features and options of your device’s SD functionality. The

device has a USB SD card mode.

Mounting the SD Card

To store additional photos, music, videos, and other

applications, you must mount (install) the SD card prior to

use. Mounting the SD card establishes a USB connection

with your computer.

1. Insert the SD card into the external, SD card slot. For

more information, refer to “Removing and Installing the

Memory Card” on page 8.

2. Your SD card is scanned to see the available

information on it.

Unmounting the SD card

Unmounting the SD card prevents corruption and damage to

the SD card while removing it from the slot.

1. From the Home screen, tap ➔

Settings

➔

Storage

2. Scroll to the bottom of the display and tap

Unmount SD

card

3. Tap

For more information, refer to “Removing and Installing

the Memory Card” on page 8.

SD card Available Memory Status

To view the memory allocation for your external SD card:

1. From the Home screen, tap ➔

Settings

➔

Storage

2. The available memory for Device and SD card displays

under the

Total space

and

Available space

headings.

DRAFT - Internal Use Only

Understanding Your Phone 45

Erasing Files from the SD card

You can erase files from the SD card using the phone.

1. Ensure the SD card is mounted. For more information,

refer to “Mounting the SD Card” on page 44.

1. From the Home screen, tap ➔

Settings

➔

Storage

2. Tap

Format SD card

3. At the

Format SD card

confirmation prompt, tap

Format

SD card

Warning!

Performing the next step erases all data stored on

the SD card.

4. Tap

Delete all

to format or press to cancel.

DRAFT - Internal Use Only

Section 3: Call Functions

This section describes how to make or answer a call. It also

includes the features and functionality associated with

making or answering a call.

For more information, refer to “Sound Settings” on page

124.

Displaying Your Phone Number



Tap ➔

Settings

➔

About device

➔

Status

. Your

phone number displays in the

My phone number

field.

Making a Call

1. From the Home screen, tap and use the on-screen

keypad to enter the number you wish to dial.

2. Tap to make the call.

Note:

When you activate the

Auto redial

option in the Voice Call

menu, the phone will automatically redial up to 10 times

when the person does not answer the call or is already

on the phone. For more information, refer to “Call

Settings” on page 57.

Making an International Call

1. From the Home screen, tap , then touch and hold

. The + character displays.

2. Use the on-screen keypad to enter the country code,

area code, and phone number.

•

If you make a mistake, tap

until the desired numbers have

been deleted.

3. Tap to make the call.

Manual Pause Dialing

To manually call a number with pause(s) without storing it in

your Contacts list:

1. From the Home screen, tap and use the on-screen

keypad to enter the phone number.

2. Press to display the dialer sub-menu.

3. Tap

Add 3-sec pause

to add a three second pause, and

use the keypad to enter the additional numbers.

Tip:

You can create pauses longer than three seconds by

entering multiple three second pauses.

DRAFT - Internal Use Only

Call Functions 47

4. Select

Add wait

to add a wait. A wait will pause the

calling sequence until you enter a number or press a

key.

5. Tap to make the call.

For more information, refer to “Manual Pause Dialing” on

page 46.

Correcting an Entered Number

Use the following steps to correct a mis-typed entry when

dialing.



After entering a number using the keypad:

•

If you make a mistake, tap

to erase a single character.

•

Press and hold

to erase the entire string of numbers.

Ending a Call



Tap the key.

Dialing a Recent Number

All incoming, outgoing and missed calls are recorded in the

Call log. If the number or caller is listed in your Address

Book, the associated name also displayed.

1. From the Home screen, tap .

2. Tap the Logs tab.

A list of recent calls displays.

3. Tap the desired Contact to enter the

Details

page, then

tap to make a call.

Making Emergency Calls

If you do not have a SIM card installed the first time you turn

on the phone, the

Insert SIM card to make calls

message

displays and an animated tutorial shows you how to install

the SIM card.

Without a SIM card, you can only make an emergency call

with the phone; normal cell phone service is not available.

Making an Emergency Call without a SIM card

1. Tap

Emergency call

from the on-screen display to make

an emergency call.

2. Enter 9-1-1 and tap . Complete your call. During

this type of call, you will have access to the Speaker

mode, Keypad, and End Call features.

3. Tap to exit this calling mode.

DRAFT - Internal Use Only

Making an Emergency Call with a SIM card

The Emergency calling mode makes redialing an emergency

number a 1-tap process. Before you can resume normal

calling operations, you should first exit this mode.

1. From the Home screen, tap .

2. Enter the emergency number (ex: 911) and then tap

3. Complete your call. During this type of call, you will

have access to the Speaker mode, Keypad, and End

Call features.

•

After completing your emergency call, displays in the

Notification area until you exit the Emergency calling mode.

Note:

This mode can drain your battery power more rapidly

than a normal calling mode.

4. At the Emergency Callback screen:

•

Tap to callback 911 with a single tap.

•

Touch and slide to the right to exit this mode.

•

Touch and slide to the left return to the Home screen. This

allows you to access other applications while staying in this

mode.

Making a Call Using Speed Dial

You can assign a short cut number to a phone number in your

Contacts List for speed dialing.

1. From the Home screen, tap

Contacts

to display

your Contacts List.

2. Press to display the Contacts List sub-menu.

3. Tap

Speed dial setting

4. The

Speed dial setting

screen displays showing the

numbers 1 through 100. The number 1 is reserved for

Voicemail.

5. Tap an unused number and the

Select contact

screen

displays.

6. Select a contact to assign to the number. The selected

contact number will display in the speed dial number

box.

7. To remove a speed dial number or change the order,

press to display the Speed dial setting sub-menu.

8. Tap

Change order

Remove

DRAFT - Internal Use Only

Call Functions 49

9. To make a call using Speed Dial, tap ➔

Keypad

and from the Dialer, touch and hold the speed dial

number.

Making a Call from the Address Book

You can store phone numbers that you use regularly on the

SIM card or in the phone’s memory. These entries are

collectively called the Address Book.

Answering a Call

When a call is received the phone rings and displays the

caller’s phone number, or name if stored in the Address

Book.

1. At the incoming call screen:

•

Touch and drag

in any direction to answer the call.

•

Touch and drag

in any direction to reject the call and

send it to your voicemail.

•

Touch and drag the

Reject call with message

tab upward and

tap a predefined text message to send to the caller.

– or –

–

Tap

Create new message

to compose a new message.

– or –

–

Tap

Remind me later

and then set a time that you would like to

be reminded.

2. Tap to end the call.

• I’m driving • I’m in a meeting

• I’m at the cinema • Sorry, I’m busy. Call

back later.

• I’m in class

DRAFT - Internal Use Only

Note:

You can answer a call while using the Address Book or

other menu feature. After ending the call, the phone

returns to the previously active function screen.

Dialing Options

From the Home screen and Application menus, you have the

option to access the Dialer and initiate a call by tapping

➔

Keypad

. From the Dialer and the Contacts screen, the

following tabs are located at the top of your screen:

•

Keypad

: dials the current number entered using the on-screen

keypad.

•

Logs

: displays a list of all dialed, received, and missed calls.

•

Favorites

: displays your contacts that you have marked as

Favorites.

•

Contacts

: takes you to your Address Book where you can select a

contact to call.

After you begin to enter numbers, the

Add to Contacts

option

displays so you can save the Contact if needed.

Call Log

The phone stores the numbers of the calls you’ve dialed,

received, or missed in the Call log. The Call log displays the

details of the call.

1. From the Home screen, tap .

2. Tap the Logs tab.

A list of recent calls displays. If the number or caller is

listed in your Address Book, the associated name

displays.

All calls made, received, and missed are listed. Types of calls

are identified by the following icons:

•

Incoming Calls

•

Outgoing Calls

•

Missed Calls

•

Rejected Calls

•

Auto Rejected Calls

DRAFT - Internal Use Only

Call Functions 51

Viewing Missed Calls from the Lock Screen

The number of calls you have missed displays on the Home

screen.

1. Touch the missed call icon with the number of missed

calls on it and move it in any direction.

Note:

If there is a voicemail sent by the same number,

associated icons are displayed and can then be

selected.

2. The Call log displays. Missed calls are identified by the

icon next to the number

Calling Back a Missed Call

To call back a missed call number:

1. From the Home screen, tap ➔ Logs.

A list of recent calls displays. If the number or caller is

listed in your Address Book, the associated name

displays.

2. Swipe the desired missed call to the right to call.

– or –

Swipe the desired missed call to the left to message.

Saving a Recent Call to your Address Book

1. From the Home screen, tap ➔ Logs.

A list of recent calls displays.

2. Tap the call you want to save to your Address Book.

3. The call detail page displays. Tap

Create contact

to add

the call to your Address Book.

The Create contact screen displays.

– or –

DRAFT - Internal Use Only

If you want to replace the number for an existing

contact, tap

Update existing

4. Enter information into the various fields using the

keypad.

5. Tap

Save

to save when you are finished.

For further details about the Address Book feature, see

“Adding Contacts” on page 69.

Sending a Message to a Recent Call

1. From the Home screen, tap ➔ Logs.

A list of recent calls displays.

2. Swipe the entry you want to message to the left.

3. At the Message screen, tap the empty text field and

use the on-screen keypad to type in a message.

4. When you are done with your message, tap to

send.

For more information, refer to “Creating and Sending

Messages” on page 95.

Deleting a Call from the Call Log

1. From the Home screen, tap ➔ Logs.

A list of recent calls displays.

2. Touch and hold the call you want to delete from the Call

log.

3. Tap Delete.

4. At the

Delete

prompt, tap

The call is deleted from the Call log.

Add as new

Call the number Send a message

contact

Update an existing

contact

DRAFT - Internal Use Only

Call Functions 53

Adding a Call to the Reject List

1. From the Home screen, tap ➔ Logs.

A list of recent calls displays.

2. Touch and hold the call you want to add to the Reject

List.

3. Tap Add to reject list.

4. At the Add to reject list prompt, tap

Future calls from this number will be rejected and sent

to your voicemail.

Call Duration

1. From the Home screen, tap ➔ Logs.

2. Press ➔

Call duration

3. The following times are displayed for Voice and Data:

•Last call

: shows the length of time for the last call.

• Dialed calls

: shows the total length of time for all calls made.

• Received calls

: shows the total length of time for all calls

received.

• All calls

: shows the total length of time for all calls made and

received.

4. You may reset these times to zero by pressing

then tapping

Reset

Options During a Call

Your phone provides a number of control functions that you

can use during a call.

Adjusting the Call Volume

During a call, to adjust the earpiece volume, use the

Volume

keys on the left side of the phone.



Press the

volume key to increase the volume level

and press the

Down

volume key to decrease the

volume level.

From the Home screen, you can also adjust the ringer volume

using these same keys.

In-Call Options

During an active call there are several functions available by

tapping a corresponding on-screen button.

•

Hold

place the current active call on hold.

•

Add call

: displays the dialer so you can call another person.

•

Keypad

: displays the on-screen keypad, where you can

enter number using DTMF (Dual Tone Multi-Frequency).

•

End call

: terminates the call.

DRAFT - Internal Use Only

•

Speaker

: routes the phone’s audio through either the speaker or

through the earpiece.

–

Tap

Speaker

to route the audio through the speaker. (You can

adjust the speaker volume using the volume keys.) A green line

displays under the Speaker button.

–

Tap

Speaker

again

to use the phone’s earpiece (see

“Using

the Speakerphone During an Active Call”

on page 56). The

green line displays when Speaker is not activated.

•

Mute/Unmute

turn the onboard microphone either on or off.

–

Tap

Mute

during a call to mute the microphone. A green line

displays under the Mute button.

–

Tap

Mute

again to unmute the microphone. The green line will

disappear when Mute is not activated.

•

Headset

connects to a Bluetooth headset.

–

Tap

Headset

during a call to activate a Bluetooth headset. A

green line displays under the Headset button.

–

Tap

Headset

again to de-activate the Bluetooth headset. The

green line will disappear when the Headset is not activated.

•

Press

for more options:

–

Contacts

: allows you to go to your Contact list.

–

Memo

: allows you to jot down a memo during a call.

–

Noise Suppression On/Off

: allows you to turn on the Noise

Suppression feature when you are in a noisy area. Turn it Off

when not needed to conserve battery power.

–

In-call sound EQ

: assigns a sound equalizer preset for use

during an active call. Sometimes you might need the sound to

be softer, clearer, or optimized for one ear or the other.

Placing a Call on Hold

You can place the current call on hold at any point during a

conversation. You can also make another call while you have

a call in progress if your network supports this service.

1. While on a call, tap

Hold

. This action places

the current caller on hold.

2. You can later reactivate this call by tapping Unhold

To make a new call while you have a call in progress

1. Tap

Hold

2. Tap

Add call

to display the dialer.

3. Enter the new number and tap .

Once connected, the active call displays in a large box

at the top of your screen and the call on hold displays

in a smaller box in the middle of your screen.

Hold

Unhold

Hold

DRAFT - Internal Use Only

Call Functions 55

Switching Between Calls

When you have an active call and a call on hold, you may

switch between the two calls, changing the one on hold to

active and placing the other on hold.

1. Tap Swap.

The current call (caller #2) is placed on hold and the

previous call on hold (caller #1) is then reactivated so

that you can continue conversing with that person. The

active call displays in a green box.

2. Tap to end the currently active call.

To end a specific call

1. Tap

Swap

until the call you want to end displays in a

green box.

2. Tap to end the specific call.

3. Tap to end the remaining call.

To answer a call while you have a call in progress

1. Tap and slide to the right to answer another call.

2. Tap

Putting "Name/Number" on hold

to put the first call

on hold.

– or –

Tap

Ending call with "Name/Number"

to end the first

call.

3. To switch between the two calls, tap Swap.

•Swap

: Places the current call on hold and then activates the

previous call. The active call displays in a green box. Tap

Swap

again to switch back.

To end a call on hold

1. Tap to disconnect the active call.

2. The call on hold will now become the active call. Tap

to end the call.

3-Way Calling (Multi-Party Calling)

The 3-Way or Multi-Party feature allows you to answer a

series of incoming calls and place them on hold. If this

service is supported by the network, all calls can be joined

together. You are notified of an incoming call by a call waiting

tone.

Note:

The Merge option combines all of the calls you have

established with your phone (both active and on hold).

Swap places the current call on hold and then activates

the previous call.

DRAFT - Internal Use Only

This feature joins all of the calls you have established with

your phone (both active and on hold) into a multi-party call.

1. Tap and slide to the right to answer the call.

2. Tap and slide to the right to answer the next call.

3. Tap

Putting "Number" on hold

to put the first call on

hold.

4. Join the first two callers into a single multi-party call by

tapping Merge .

5. To temporarily leave the conference call, tap

Hold

To rejoin the conference call tap

Unhold

6. Tap to end the call.

Using the Speakerphone During an Active Call

While in an active call, it is possible to enable the

speakerphone feature.

1. Tap

Speaker

The

Speaker

button now displays as and the

speakerphone is activated.

2. Use the

Volume

keys (located on the left side of your

phone) to adjust the volume.

3. To deactivate the speakerphone, tap

Speaker

Important!

For more information, see “Responsible Listening”

on page 204.

Merge

Hold

Unhold

Speaker

DRAFT - Internal Use Only

Call Functions 57

Switching off the Microphone (Mute)

You can temporarily switch your phone’s microphone off, so

that the other person cannot hear you.

Example:

You wish to say something to person in the room,

but do not want the person on the phone to hear

you.

To mute your phone during a call

1. Tap Mute .

The

Mute

button now displays as and Mute is

activated.

2. Tap Mute to deactivate the Mute function and

reactivate the microphone.

Bluetooth headset

1. Tap Headset .

2. The phone will scan for your Bluetooth headset. When

found, connect to the headset.

The

Headset

button now displays as and the

Bluetooth headset is activated.

3. Tap Headset to deactivate the Bluetooth headset

and reactivate the phone speaker.

Searching for a Number in Address Book

1. During the active call, press then tap

Contacts

2. Tap the Address Book entry.

For further details about the Address Book feature.

Call Waiting

The Call Waiting feature allows you to answer an incoming

call while you have a call in progress, if this service is

supported by the network, and you must first activate the

Call Waiting feature:



From the Home screen, tap ➔

➔

Call settings

➔

Additional settings

➔

Call waiting

You are notified of an incoming call by a call waiting

tone.

Call Settings

To access the Call settings menu:



From the Home screen, tap ➔ ➔

Call

settings

Mute

Headset

DRAFT - Internal Use Only

Call rejection

1. From the Call settings screen, tap

Call rejection

2. Tap the

OFF / ON

icon to turn Auto reject mode on

3. Tap

Auto reject mode

and tap one of the following

options:

• All numbers

: to reject all calls.

• Auto reject numbers

: to reject all calls in your Reject list.

4. Tap

Auto reject list

5. Tap to manually add numbers to the Reject list.

6. Tap

Unknown

, to automatically reject all calls that are

not in your Contacts list.

Set reject messages

1. From the Home screen, tap ➔ ➔

Call settings

➔

Set reject messages

2. Tap to manually add a reject message.

– or –

Tap one of the pre-written messages to display when

you want to reject the call. You can also edit the

message.

3. Tap

Save

to save the reject message.

Ringtones and keypad tones

1. From the Home screen, tap ➔ ➔

Call settings

➔

Ringtones and keypad tones

2. Tap

Device ringtone

, select a ringtone, and tap

3. Tap

Device vibration

, select a vibration type, and tap

4. Tap

Incoming call vibration

to if you want your phone to

vibrate when a call is incoming.

5. Tap

Keytones

to play a tone when you press the

keypad.

Reminder tone

1. From the Home screen, tap ➔ ➔

Call settings

➔

Reminder tone

2. Tap a tone to hear it played.

3. Select a tone and tap

Call alert

1. From the Home screen, tap ➔ ➔

Call settings

➔

Call alert

DRAFT - Internal Use Only

Call Functions 59

2. Tap

Call vibrations

to enable your phone to vibrate

when the called party answers the phone.

3. Tap

Call status tones

to set the sound settings during a

call then tap

4. Tap

Alerts on call

to turn off alarm and message

notifications during a call.

Call answering/ending

1. From the Home screen, tap ➔ ➔

Call settings

➔

Call answering/ending

2. The following options are available:

• Answering key

: Tap this option to be able to accept incoming

calls by pressing the Home key.

• The power key ends calls

: This option will allow you to end a

call by pressing the power key without turning off the screen.

Auto screen off during calls

This option turns on the proximity sensor during calls so that

your phone will know to turn the screen off to save power.



From the Home screen, tap ➔ ➔

Call

settings

➔

Auto screen off during calls

to enable the

feature.

Accessory settings for call

1. From the Home screen, tap ➔ ➔

Call settings

➔

Accessory settings for call

2. The following options are available:

• Automatic answering

: configures the device to automatically

answer and incoming call when a headset is detected.

• Automatic answering timer

: configures the time delay before

the device automatically accepts the incoming call.

• Outgoing call conditions

: allows you to make calls even when

the device is locked.

My call sound

This option allows you to personalize the sounds you hear

during a call with and without earphones.

1. From the Home screen, tap ➔ ➔

Call settings

➔

My call sound

2. Tap

My call sound settings

3. Tap

Personalize call sound

and follow the detailed

on-screen instructions.

DRAFT - Internal Use Only

Use extra vol. for calls

This option allows you to see an extra volume button on the

screen during calls.



From the Home screen, tap ➔ ➔

Call

settings

➔

Use extra vol. for calls

to enable the feature.

Increase volume in pocket

This option increases the ringtone volume when the device is

in a pocket or a bag. It uses the proximity sensor to detect its

location.



From the Home screen, tap ➔ ➔

Call

settings

➔

Increase volume in pocket

to enable the

feature.

Call forwarding

1. From the Home screen, tap ➔ ➔

Call settings

➔

Call forwarding

➔

Voice call

2. Tap one of the following options:

• Always forward

: allows you to forward all voice calls.

• Forward when busy

allows you to forward voice calls to a

designated number instead of your voice mail number if you

are on another phone call.

• Forward when unanswered

: allows you to forward voice calls

to a designated number instead of your voicemail number

when there is no answer on your phone. You can also select

the amount of time that the phone delays before forwarding.

• Forward when unreachable

: allows you to forward voice calls

to a designated number instead of your voicemail number

when you are not in an area covered by your service provider or

when your phone is switched off.

Additional settings

1. From the Home screen, tap ➔ ➔

Call settings

➔

Additional settings

2. Tap one of the following options:

•Caller ID

: allows you to choose how your Caller ID displays.

Select Network default, Hide number, or Show number.

• Call waiting

: the network service informs you when someone

is trying to reach you during another call. Tap to activate.

• Auto redial

: automatically redials the last number if the call

was either cut off or was unable to connect. Tap to activate.

•Noise reduction

: allows you to suppress background noise

from your side during calls.

DRAFT - Internal Use Only

Call Functions 61

• Fixed Dialing Numbers

: allows you to restrict outgoing calls to

a limited set of phone numbers.

• Auto area code

: allows you to automatically prepend a specific

area code to all outbound calls. Slide the slider to the on

position.

Using Fixed Dialing Numbers

Enabling FDN

1. From the Home screen, tap ➔ ➔

Call settings

➔

Additional settings

➔

Fixed dialing numbers

2. Tap

Enable FDN

3. At the prompt, enter your PIN2 code and tap

FDN is enabled.

4. To enable FDN after it has been disabled, tap

Disable

FDN

, enter your PIN2 code and tap

Important!

Not all SIM cards use a PIN2 code. If your SIM card

does not, this menu does not display.

The PIN2 code is provided by your carrier. Entering

an incorrect PIN2 code could cause the phone to

lock. Contact customer service for assistance.

Changing the PIN2 Code

1. From the Home screen, tap ➔ ➔

Call settings

➔

Additional settings

➔

Fixed dialing numbers

2. Tap

Change PIN2

3. At the prompt, enter your old PIN2 code.

4. At the prompt, enter a new PIN2 code.

5. Confirm your PIN2 code.

Managing the FDN List

When this feature is enabled, you can make calls only to

phone numbers stored in the FDN list on the SIM card.

Note:

Before you can manage an FDN list a list must be

created.

1. From the Home screen, tap ➔ ➔

Call settings

➔

Additional settings

➔

Fixed dialing numbers

2. Tap

FDN list

3. A list of all existing FDN numbers displays.

DRAFT - Internal Use Only

Voicemail service

1. From the Home screen, tap ➔ ➔

Call settings

➔

Voicemail Service

Voicemail service provided by your carrier is the

default.

2. Tap

My carrier

to remove the carrier Voicemail service.

Voicemail settings

You can view or modify your voicemail number from this

menu.

1. From the Home screen, tap ➔ ➔

Call settings

➔

Voicemail settings

2. Tap the

Voice mail number

field, backspace to erase the

digits, and enter a new voicemail number using the

keypad, then tap

3. Tap

Ringtone

1. From the Home screen, tap ➔ ➔

Call settings

➔

Ringone

2. Tap a ringtone to hear it played.

3. Select a ringtone and tap

Vibrate

This option allows you to configure vibration settings.

1. From the Home screen, tap ➔ ➔

Call settings

➔

Vibrate

2. Tap

Always

Only in silent mode

, or

Never

TTY Mode

A TTY (also known as a TDD or Text Telephone) is a

telecommunications device that allows people who are deaf,

hard of hearing, or who have speech or language disabilities,

to communicate by telephone.

Your phone is compatible with select TTY devices. Please

check with the manufacturer of your TTY device to ensure

that it is compatible with digital cell phones.

Your phone and TTY device will connect via a special cable

that plugs into your phone’s headset jack. If this cable was

not provided with your TTY device, contact your TTY device

manufacturer to purchase the connector cable.

1. From the Home screen, tap ➔ ➔

Call settings

➔

TTY mode

2. Tap

TTY Full

TTY HCO

, or

TTY VCO

. A green checkmark

displays to indicate selection. Tap

TTY Off

to turn it off.

DRAFT - Internal Use Only

Call Functions 63

Accounts

SIP (Session Initiation Protocol) is an Internet protocol used

for live communication sessions such as phone calls. This

menu will allow you to set up your SIP accounts for Internet

calling.

1. From the Home screen, tap ➔ ➔

Call

settings

. ➔

Accounts

2. Tap

Receive incoming calls

to allow calls to be received

while using internet call. This will use more battery

power.

3. Tap

Add account

4. Enter the required information. Contact your SIP

account representative for the necessary information.

Use Internet calling

Your device can make calls over the Internet using VoIP

(Voice over Internet Protocol) using a SIP account.

1. From the Home screen, tap ➔ ➔

Call settings

➔

Use Internet calling

2. Tap one of the following options:

• For all calls when mobile network available

: your phone will

always use Internet calling when there is an available network.

• Only for Internet calls

: the phone will only use Internet calling

when you specify directly.

• Ask for every call

: the phone will prompt you every time you

make a call.

DRAFT - Internal Use Only

Section 4: Entering Text

This section describes how to select the desired text input

method when entering characters into your phone. This

section also describes the predictive text entry system that

reduces the amount of key strokes associated with entering

text.

Your phone comes equipped with an orientation detector that

can tell if the phone is being held in an upright (Portrait) or

sideways (Landscape) orientation. This is useful when

entering text.

Text Input Methods

There are two text input methods available:

•

Samsung keyboard (default)

: Samsung’s on-screen

QWERTY keypad that can be used in both portrait and

landscape orientation.

•

Google Voice typing

: allows you to enter text by speaking.

To change the input method, see “Keyboards and Input

Methods” on page 138.

Entering Text Using the Samsung

Keyboard

From a screen where you can enter text, rotate your phone

counterclockwise to a Landscape orientation. The on-screen

QWERTY keypad will display.

New

Paragraph

Text Input Mode

Shift

Key Delete

Key

Space Bar

Voice Typing

DRAFT - Internal Use Only

Entering Text 65

Changing the Text Input Mode - Keypad

There are two main keypad layout keys that change on the

keyboard display.

The available Text Input modes are:

Sym

and

Abc

Note:

When in

Abc

mode, the

Sym

button displays. When in

Sym

mode, the

Abc

ABC

abc

button displays.

Using ABC Mode

1. If desired, rotate your phone counterclockwise to a

Landscape orientation.

2. When you tap the

Enter message

field, the following

screen displays:

3. Tap the desired alphabetic characters.

4. The screen initially opens in ABC mode. After typing the

first letter, the shift key ( ) will change to

and following letters will be lowercase.

5. Tap to input another upper-case letter or tap

twice to switch to ABC mode. The shift key will

change to in ABC mode. All following letters

will be uppercase until you tap the shift key again.

Symbol/Numeric Mode

: activates the number,

symbol, and emoticon keys.

ABC Mode

: activates the default alphabet keys.

Can also be set to

Abc

abc

by using the shift

() key.

123

Sym

ABC

DRAFT - Internal Use Only

Using Symbol/Numeric Mode

Use Symbol/Numeric Mode to add numbers, symbols, or

emoticons.

1. Rotate your phone counterclockwise to a Landscape

orientation.

2. Tap at the bottom of the screen. The following

screen displays:

3. Tap the desired number, symbol, or emoticon

characters.

4. Tap the button to access additional symbols.

5. Tap to return to Abc mode.

Predictive Text

By using the Predictive Text option, you can have next-letter

prediction and regional error correction, which compensates

for pressing the wrong keys on the QWERTY keyboard.

1. To turn Predictive Text on or off, tap ➔

Settings

➔

More settings (System)

➔

Language and input

2. Tap the icon next to

Samsung keyboard

3. Tap the ON/OFF slider, located to the right of the

Predictive text

field, to .

4. In the text portion of the message screen, begin typing

a word. A list of word options is displayed. Tap one of

the words to replace the word that has already been

typed or scroll the line of words to the left for more

word choices.

123

Sym

1/3

ABC

DRAFT - Internal Use Only

Entering Text 67

5. Continue typing your message. Tap to send the

message or press for more options. For more

information, refer to “Creating and Sending Messages”

on page 95.

Note:

You can also use Predictive Text mode in the portrait

orientation.

Samsung Keyboard Settings

For information on how you can configure your Samsung

keyboard settings, see “Samsung Keyboard settings” on

page 139.

Using the Google Voice Typing Feature

You can use your voice to enter text using the Google Voice

typing feature.

1. From the keypad, touch the top of the screen and drag

it down to display your notification panel.

2. Tap

Choose input method

3. Tap

Google voice typing

4. At the

Listening

prompt, speak clearly and distinctly

into the microphone.

5. The text is displayed in the message as you are

speaking.

6. Tap

Done

when you are finished.

Note:

The feature works best when you break your message

down into smaller segments.

DRAFT - Internal Use Only

Section 5: Accounts and Contacts

Accounts

Your phone provides the ability to synchronize information,

from from a variety of accounts, including Email, Facebook,

Google, and your Samsung account. Depending on the

account, you can choose to synchronize your calendar,

contacts, and other types of content.

Contacts from your accounts display in your phone’s

Contacts.

With synchronization, you can ensure that information on

your phone is updated with any information that changes in

your accounts.

Controlling Synchronization

You can choose to have your phone automatically

synchronize with your accounts, or manually synchronize

each account when you want to check messages.

You may also choose to limit automatic or background

synchronization to extend battery life.

1. From the Home screen, touch

, then touch

Settings

2. Under

Personal

, touch

Accounts and sync

3. To control synchronization:

•

Touch

Accounts and sync

to allow

synchronization automatically, at any time.

•

Touch

Accounts and sync

to disable automatic

synchronization.

With automatic synchronization disabled, you can manually

sync accounts with the

Sync

option available in each account.

Tip:

You can also control synchronization from Notifications,

with the Sync toggle. Cross reference Notifications ???.

Setting Up Your Accounts

Set up and manage your accounts with the

Accounts and

sync

settings.

For information about setting up other, non-synchronized

email accounts, see “Configuring Email Accounts” on

page 82.

Tip:

For more information on setting up your email, contact

your Wireless Provider.

DRAFT - Internal Use Only

Accounts and Contacts 69

Adding an account

1. From the Home screen, touch

, then touch

Settings

2. Under

Personal

, touch

Accounts and sync

➔

Add account

3. Select an account provider, then follow the prompts to

enter your credentials and sign in.

4. The phone communicates with the provider’s server to

set up your account on the phone.

Managing accounts

1. From the Home screen, touch

, then touch

Settings

2. Under

Personal

, touch

Accounts and sync

3. Select an account, then touch a setting to enable or

disable synchronization. A check mark displays to

indicate activation.

Contacts

To access Contacts:



From the Home screen, touch

Contacts

Contact tips:

•

Swipe your finger left-to-right across a contact to make a call to

the contact.

•

Swipe right-to-left across a contact to create a message

addressed to the contact.

Adding Contacts

1. From the Home screen, touch

Contacts

➔

Add contact

•

If you have defined accounts (Google, Samsung, and so on),

the Save contact to pop-up displays:

•

If you have not defined any accounts, the

Save contact

pop-

up displays. The following options are available:

–

: Saves your contacts in

“my device contacts”

–

Add new account

: Lets you define an account to which your

device saves your contacts. The

Add new account

screen

displays. (For more information, refer to

“Setting Up Your

Accounts”

on page 68..)

DRAFT - Internal Use Only

2. At the

Save contact to

prompt, select a save option for

the contact (available options depend on accounts you

define to your device):

• Microsoft Exchange ActiveSync

: Save to your Corporate

account.

•Google

: Save to your Google account.

• Samsung

: Save to your Samsung account.

• Phone

: Save to “my device contacts”.

3. Touch contact fields to enter information:

•

Touch

Photo ID

to choose a picture to identify the

contact.

•

Touch

Name

to enter a name for the contact. Touch to

enter

Name prefix

First

name

Middle name

Last name,

Name suffix

•

Touch

Phone number

to enter a phone number, then touch the

Label

button to choose a label, from

Mobile

Home

Work

Work Fax

Home Fax

Pager

Other

, or

Custom

. To add

another number, touch .

•

Touch

Email address

to enter an email address, then touch the

Label

button to choose a label, from

Home

Work

Other

, or

Custom

to create a new label. To add an address, touch .

•

Touch

Address

to enter an email address, then touch the

Label

button to choose a label, from

Home

Work

Other

, or

Custom

to create a new label. To add an address, touch .

•

Touch next to

Events

to enter a special date, then touch

the

Label

button to choose a label, from

Birthday

Anniversary

Other

, or

Custom

to create a new label.

•

Touch

Groups

to assign the contact to a group. For more

information about Groups, see

“Groups”

on page 75.

•

Touch

Ringtone

to choose a ringtone for the contact.

•

Touch

Vibration pattern

to choose a vibration pattern to play

along with the ringtone when this contact calls or sends you a

message.

•

Touch

Add another field

to add more fields, including

Phonetic Name

Organization

Notes

Nickname

Website

, or

Relationship

4. When you finish entering information, touch

Save

DRAFT - Internal Use Only

Accounts and Contacts 71

Creating Contacts from Recent calls

Save a phone number from a recent call to create a new

contact, or update an existing contact.

For more information, see “Creating or Updating Contacts

Using Recent calls” on page 44.

Creating Contacts from the Phone Keypad

Enter a phone number with the Phone Keypad, then save it.

1. From the Home screen, touch

Phone

2. Touch the digits of the phone number on the

Keypad

3. Touch

Add to Contacts

, then select

Create contact

from

the pop-up menu.

4. Continue entering contact information. For more

information, see “Adding Contacts” on page 69.

Tip:

While entering a phone number, you can add waits or

pauses. Enter the number up to the pause or wait, then

touch

to select

Add 2 sec pause

Add wait

Updating Contacts

Make changes to update an existing contact.

1. From the Home screen, touch

Contacts

2. Touch a contact to view its information, then touch

Edit

– or –

Touch and hold a contact, then select

Edit

from the

menu.

3. Continue entering contact information. For more

information, see “Adding Contacts” on page 69.

Updating Contacts from the Phone Keypad

Enter a phone number with the Phone Keypad, then save it.

1. From the Home screen, touch

Phone

2. Touch the digits of the phone number on the

Keypad

3. Touch

Add to Contacts

, then select

Update existing

from the pop-up menu.

4. Select a contact to update, then continue entering

contact information. For more information, see “Adding

Contacts” on page 69.

DRAFT - Internal Use Only

Updating Contacts from Recent calls

Save a phone number from a recent call to create a new

contact, or update an existing contact.

For more information, see “Creating or Updating Contacts

Using Recent calls” on page 44.

Choosing Contacts to Display

1. From the Home screen, touch

Contacts

2. Touch

, then touch

Contacts to display

•

Choose

All contacts

to show all contacts.

•

Choose an account to only display contacts from that account.

•

Touch

Phone

to show only show contacts saved to the phone.

•

Choose

Customized list

to select contact types for each

account, or the phone.

Contacts Settings

1. From the Home screen, touch

Contacts

2. Touch

, then touch

Settings

•

Select

Only contacts with phones

to show contacts with at

least one stored phone number.

•

Touch

List by

to sort contacts by first or last name.

•

Touch

Display contacts by

to list contacts by first or last name.

•

Touch

Send contact

to set your preference for transferring

contacts by Bluetooth contacts. For more information about

sending contacts, see

“Sending Namecards (vCards)”

page 74.

Other Contacts Options

1. From the Home screen, touch

Contacts

2. Touch a contact to display it, then touch

•History

: View calls and messages to and from this contact.

•Edit

: Modify contact information. For more information, see

“Updating Contacts”

on page 71.

•Delete

: Erase the contact record.

• Join contact/Separate contact

: Manage multiple contacts as

one. For information, see

“Joining Contacts”

on page 73.

• Mark as default

: Set a default phone number or other field

(such as IM or email address). Defaults are the contact method

used when creating a message or calling a contact. You can

also set a default by touching and holding on a contact field.

• Share namecard via

: Send the namecard. For information,

see

“Sending Namecards (vCards)”

on page 74.

DRAFT - Internal Use Only

Accounts and Contacts 73

• Add to reject list

: Mark the contact so that calls or messages

from the contact are rejected automatically. To remove a

contact form the reject list, touch and hold on the contact in the

main contacts screen, then choose

Remove from reject list

• Print namecard

: Print the namecard via Bluetooth to a

compatible Samsung Bluetooth-enabled printer.

My Local Profile

My local profile is your own contact record, listed under

in Contacts. You can send My local profile as a vCard via

Bluetooth or as an attachment.

Creating My Local Profile

1. From the Home screen, touch

Contacts

2. Under

touch

Set up profile

3. Enter your information

in the contact fields.

For more

information, refer to “Adding Contacts” on page 69..

Sending My Local Profile

You can send your profile as a vCard via Bluetooth to other

Bluetooth devices, or as an attachment.

1. From the Home screen, touch

Contacts

2. Touch your profile to display your contact information.

3. Touch

, then touch

Share namecard via

4. Choose a sending method, then follow the prompts to

send the profile.

Joining Contacts

Your phone can synchronize with multiple accounts,

including Google, Corporate, and other providers, plus social

networking sites like Facebook. When you synchronize

contacts from these accounts with your phone, you may have

multiple contacts for one person.

Joining contact records allows you to see all the contact’s

numbers and addresses together. Joining also helps you

keep your contacts updated, because any changes to

information in the respective accounts is automatically

updated the next time you synchronize with the account.

Joining contacts

1. From the Home screen, touch

Contacts

2. Touch a contact to display its information.

3. Touch

, then touch

Join contact

. A list of

available contacts displays.

4. Select a contact to join to the displayed contact. The

joined contact displays.

DRAFT - Internal Use Only

5. To join another contact, touch the

Connection

field. The

Joined contact screen displays.

Touch

Join another contact

. A list of available contacts

displays.

Select a contact to join to the displayed contact. The

joined contact displays.

Separating contacts

1. From the Home screen, touch

Contacts

2. Touch a contact to display its information.

3. Touch the

Connection

field to display joined contacts.

4. Touch to the right of a contact to remove it from

the selected joined contact.

Exporting and Importing Contacts

You can export your contact list to an installed memory card,

or import a list of contacts (previously exported) from a

memory card.

1. From the Home screen, touch

Contacts

2. Touch

, then touch

Import/Export

3. Select an option, then follow the prompts to complete

the operation:

• Import from USB storage

: Copy contacts that are saved in

installed mass storage.

• Export to USB storage

: Copy contacts to installed mass

storage.

• Import from SD card

: Copy contacts that are saved on an

installed memory card.

• Export to SD card

: Copy contacts to an installed memory card.

• Send namecard via

: Share contacts as vCards. For more

information, see

“Sending Namecards (vCards)”

page 74.

Sending Namecards (vCards)

You can send a contact namecard as a vCards via Bluetooth

to other Bluetooth devices, or as an attachment via Gmail or

Email.

Important!

Not all Bluetooth devices accept contacts, and not

all devices support transfers of multiple contacts.

Check the target device’s documentation.

1. From the Home screen, touch

Contacts

2. Touch

, then touch

Import/Export

➔

Send

namecard via

DRAFT - Internal Use Only

Accounts and Contacts 75

3. Touch contacts to mark them for sending, or touch

Select all

to mark all contacts. A check mark displays

for marked contacts.

4. Touch

Done

. At the prompt, choose a sending method,

then follow the prompts to send the namecard:

• Bluetooth

: For more information about sending via Bluetooth,

see

“Bluetooth”

on page 153.

•Dropbox

: For more information about sending via Dropbox, see

“Dropbox”

on page 132.

•Email

: For more information about sending email, see

“Email”

on page 82.

•Gmail

: For more information about sending Gmail, see

“Composing and Sending Gmail”

on page 83.

• Messaging

: For more information about sending messages,

see

“Creating and Sending Messages”

on page 78.

• Wi-Fi Direct

: For more information about using Wi-Fi Direct,

see see

“Wi-Fi Direct”

on page 151.

Favorites

Mark contacts with a

star to identify them as Favorites.

Favorites display on the

Favorites

tab in the

Phone

and

Contacts

screens for fast dialing or messaging, and are

indicated by the .

Creating Favorites

1. From the Home screen, touch

Contacts

2. Touch and hold on a contact, then select

Add to

favorites

from the pop-up menu.

– or –

Touch a contact to display it, then touch at the top

right of the screen, it changes color to .

Groups

Assign contacts to Groups to make searching for contacts

faster, or to quickly call or send messages to group

members. Your phone comes with pre-loaded groups you

can use to add your contacts.

DRAFT - Internal Use Only

Adding a New Group

1. From the Home screen, touch

Contacts

➔

Groups

2. Touch

➔

Create

, then enter information:

•

Touch

Group name

to enter a Group Name.

•

Touch

Group ringtone

to choose a ringtone for calls from

members of this group.

•

Touch

Vibration pattern

to choose a vibration to play for calls

from members of this group.

•

Touch

Add member

to select members from Contacts.

3. Touch

Save

to save the new group.

Editing a Group

1. From the Home screen, touch

Contacts

➔

Groups

2. Touch a Group to display it.

3. Touch

➔

Edit

, then update information for

the group. For more information, see “Adding a New

Group” on page 76.

Deleting a Group

1. From the Home screen, touch

Contacts

➔

Groups

2. Touch

➔

Delete

3. Touch a Group to mark it for deletion, or touch

Select all

to mark all groups. A check mark displays to indicate

selection. You cannot delete pre-loaded groups.

4. Touch

Delete

, then choose

Group only

Group

and

group members

Adding Contacts to a Group

1. From the Home screen, touch

Contacts

➔

Groups

2. Touch a Group to display it, then touch .

3. Touch contact(s) to mark them for addition, or touch

Select all

to mark all contacts. A check mark displays to

indicate selection.

4. Touch

Done

to add the selected contact(s).

DRAFT - Internal Use Only

Accounts and Contacts 77

Removing Contacts from a Group

1. From the Home screen, touch

Contacts

➔

Groups

2. Touch a Group to display it.

3. Touch

➔

Remove member

4. Touch contact(s) to mark them for removal, or touch

Select all

to mark all contacts. A check mark displays

to indicate selection.

5. Touch

Done

to remove the selected contact(s).

Sending a Message to Group Members

Create a new text or email message, addressed to the

group’s members.

1. From the Home screen, touch

Contacts

➔

Groups

2. Touch and hold a Group, then touch

Send message

Send email

3. Touch contacts to mark them for the new message,

then touch

Done

4. The new message opens, with recipients marked

recipients marked. Create the message. For more

information, see “Creating and Sending Messages” on

page 78, or see “Composing and Sending Email” on

page 82.

Speed Dials

Speed dials are 1-, 2-, or 3-digit shortcuts (1 to 100) you

assign to contacts.

For more information about using speed dials to call, see

“Making Calls using Speed Dials” on page 40.

Note:

Some speed dials are reserved and cannot be assigned:

Speed dial 1 is reserved for Voicemail.

Speed dial 100 is reserved for Directory Assistance.

Assigning Speed Dials

1. From the Home screen, touch

Contacts

2. Touch

, then touch

Speed dial setting

3. A list of speed dials displays.Touch a speed dial, then

touch a contact to assign the speed dial to the contact.

DRAFT - Internal Use Only

Removing or Reassigning a Speed Dial

1. From the Home screen, touch

Contacts

2. Touch

, then touch

Speed dial setting

3. Touch and hold an assigned Speed dial setting, the

following options pop-up:

• Replace

: Touch a new speed dial location to assign it to the

contact.

•Remove

: Unassign the speed dial from the contact.

DRAFT - Internal Use Only

Multimedia 79

Section 6: Multimedia

This section explains how to use the multimedia features of

your phone, including Media Hub, Music Player, Google Play

Music, Video Player, Play Movies, Gallery, Camera, and

Camcorder.

Media Hub

Samsung Media Hub is your one stop for the hottest movie

and TV content. With hundreds of titles available at your

fingertips, entertaining yourself or your kids on the go has

never been easier. You can rent or purchase your favorite

content and watch from the convenience of anywhere.

Featuring the stunning viewing quality Samsung is known

for, Samsung Media Hub is your gateway to mobile video like

you've never experienced it before.

Note:

Media Hub usage is based on service availability.

Using Media Hub

1. From the Home screen, tap ➔

Settings

➔

Security

and lock screen

➔

Unknown sources

to allow the

Samsung app to run.

2. At the warning prompt, tap

3. Tap

Home

➔ ➔

Media Hub

4. Read the

Terms and Conditions

screen and tap the

agree to the Terms and Conditions

checkbox.

5. Tap

to continue or

Decline

to exit.

The Media Hub screen displays.

6. At the Media Hub screen,

What’s New

is displayed with

recently added media that you can rent or purchase.

7. The following tabs are displayed at the top of the

screen:

•Home

: displays the Media Hub main screen.

•Movies

: displays movies that are available for rent or purchase.

Scroll through the top navigation bar and select a movie

category. The movies of that type displays below.

• TV Shows

: displays TV shows that are available for purchase.

Scroll through the top navigation bar and select a TV category.

The TV shows of that type displays below.

•My Media

: allows you to view all of the media that you have

purchased or rented. Tap a media entry to view it.

DRAFT - Internal Use Only

8. Scroll through the media listings and tap on an item

you would like to purchase or rent.

9. At the Details screen, follow the on-screen instructions

to create a Samsung account and make a purchase.

10. The media will be stored in the My Media folder.

Media Hub Notices

•

Any media item (Media Content) may be rented or purchased after

you create an account in Media Hub.

•

Media Content that is downloaded may be viewed concurrently on

up to five (5) devices with Media Hub that are also registered to

the same account.

•

You may choose to remove a device from your account no more

than once every 90 days.

•

You may remove Media Content from a device as many times as

you’d like. You will have the ability to re-download the Media

Content at a later point in time subject to content re-download

availability and studio permissions.

•

You MUST be in network coverage to license Media Content you

have acquired through the Service.

•

You can use 3G, 4G, or Wi-Fi connectivity in order to download

Media Content.

•

Unlike purchased Media Content, rented Media Content will be

viewable on only 1 device in your account.

•

Media Content is downloaded and saved onto the SD card.

•

Your Media Content may pause/stop or not download in networks

where there is a weak signal.

•

You may begin watching downloaded Media Content as soon as a)

license acquisition has occurred and b) sufficient amount of the

Media Content has been buffered.

•

You must finish watching rented Media Content within 24

consecutive hours of the start of playback.

•

Stopping, pausing or restarting rented Media Content does not

extend the available viewing time.

•

In no event will rented Media Content be available for a period

of more than thirty (30) days (or shorter on a title-by-title basis)

after the Media Content has been rented (e.g., if you begin

viewing rented Media Content on the 29th day after the rental

transaction, but do not finish viewing the entire title, that rented

Media Content may not be available for the entire twenty-four

(24) consecutive hour period if such period would extend the

viewable time beyond the thirty (30) day rental window).

DRAFT - Internal Use Only

Multimedia 81

•

You cannot play any media content downloaded from Media Hub

through any output on your mobile phone, including All Share.

Music Player

The Music Player is an application that can play music files.

The Music Player supports files with extensions AAC, AAC+,

eAAC+, MP3, WMA, 3GP, MP4, and M4A. Launching the

Music Player allows you to navigate through your music

library, play songs, and create playlists (music files bigger

than 300 KB are displayed).

Playing Music

1. Tap ➔

Music Player

2. Tap a library category at the top of the screen (All,

Playlists, Albums, Artists, Music square, or Folders) to

view the available music files.

3. Scroll through the list of songs and tap an entry to

begin playback.

4. The following Music Player controls are available:

Pause the song.

Start the song after being paused.

Press and hold to rewind the song. Tap to go to

previous song.

Press and hold to fast-forward the song. Tap to go

to next song.

Volume control.

Repeat one: repeats the currently playing song.

Repeat all: replays the current list when the list

ends.

Play All: plays the current song list once.

Shuffle On: the current list of songs are randomly

shuffled for playback.

Shuffle Off: songs play in order and are not

shuffled.

Provides access to the Music square.

Lists the current playlist songs.

Displays the current song in the player window.

Provides access to the SoundAlive feature.

DRAFT - Internal Use Only

Music Player Options

To access additional options, follow these steps:

1. While in the Music Player, press .

2. The follow options are available:

• Add to quick list

: adds the current music file to the Quick list.

• Via Bluetooth

: scans for devices and pairs with a Bluetooth

headset.

•Share music via

: allows you to share your music by using

Bluetooth, Email, Gmail, Group Cast, Messaging, or Wi-Fi

Direct.

• Add to playlist:

allows you to add the current music file to a

selected playlist.

•Details

: allows you to view media info such as Artist, Title,

Biography, and other information.

•Set as:

allows you to set a music file to Phone ringtone, Caller

ringtone, or Alarm tone.

• Settings

: allows you to change your Music Player settings. For

more information, refer to

“Music Player Settings”

page 82.

•End

: allows you to end the Music Player app.

Music Player Settings

The Music Player Settings menu allows you to set

preferences for the Music Player such as whether you want

the music to play in the background, sound effects, and how

the music menu displays.

1. From the Home screen, tap ➔

Music Player

2. Press ➔

Settings

3. Select one of the following settings:

•SoundAlive

: set a type of equalization such as Normal, Pop,

Rock, Jazz, Dance, Classic, etc.

•Play speed

: set the play speed anywhere between 0.5X and

2.0X using the slider.

• Music menu

: this menu allows you to select which categories

you want to display. Choices are: Albums, Artists, Genres,

Music square, Folders, Composers, Years, Most played,

Recently played, or Recently added. Tap each item that you

want to display in the Music menu.

•Lyrics

: when activated, the lyrics of the song are displayed if

available.

• Music auto off

: when activated, music will automatically turn

off after a set interval.

DRAFT - Internal Use Only

Multimedia 83

Using Playlists

Playlists are used to assign songs to a list of preferred media

which can then be grouped into a list for later playback. You

can create these playlists either from the handset’s Music

Player options menu or from within a 3rd party music

application (such as Windows Media Player) and then

downloaded to the handset.

Creating a Playlist

1. From the Home screen, tap ➔

Music Player

2. Tap the

Playlists

tab.

3. Press ➔

Create playlist

4. Type a name for this playlist in the field and tap

Adding Music to a Playlist

To add files to the playlist:

1. From the Home screen, tap ➔

Music Player

2. Tap the

Playlists

tab.

3. Tap the playlist name in which to add music.

4. Tap

Add music

5. Tap a music file, or tap

Select all

to add all the music

tracks to this playlist then tap

Done

Removing Music from a Playlist

To remove music files from a playlist:

1. From the Home screen, tap ➔

Music Player

2. Tap the

Playlists

tab.

3. Tap the playlist name in which to delete music.

4. Press ➔

Remove

5. Tap the checkbox to the left of each track you want to

remove from this playlist, or tap

Select all

to remove all

the music tracks from this playlist, then tap

Remove

Editing a Playlist

Besides adding and removing music files in a playlist, you

can also rename the playlist.

To edit a playlist:

1. From the Home screen, tap ➔

Music Player

2. Tap

Playlists

3. Press ➔

Edit title

4. Tap a playlist name to edit.

5. Enter a new name for the playlist then tap

For information on downloading music for your phone, see

“Google Play Music” on page 84.

DRAFT - Internal Use Only

Google Play Music

With Google Play Music, you can play music that you have

added to your music file as well as any music you copied

from your PC. While offline, you can listen to music you have

copied from your PC.

1. From the Home screen, tap ➔

Play Music

2. At the Welcome screen, tap

3. At the

Select an account

screen, tap an account that

you would like to link to Google Play Music or tap

Add

Account

4. At the

Get free music

screen, tap

Get free songs

Skip

5. Follow the on-screen instructions for getting your free

music.

All music on your device and external SD card is

displayed including Music folders that may contain

multiple songs.

6. Tap a song to start playback.

7. From the main Play Music screen, you can tap any of

the following tabs for a more detailed listing of songs:

Recent, Artists, Albums, Songs, Playlists, and Genres.

8. Tap for the following options:

•Shuffle all

: allows you to play all of your music in a shuffled

order.

• Make available offline

: allows you play your music without

being online or connected to the network.

• Offline music only

: only allows you to play music offline.

• Settings

: allows you to view Open source licenses and the

music version for the Play Music application.

•Help

: allows you to view a help file on the Google Support

website.

Video Player

The Video Player application plays video files stored on your

microSD card.

1. Tap ➔

Video Player

2. All videos that you have on your phone and memory

card displays. Tap the video that you want to play.

3. The video will begin to play.

4. The following video controls are available:

Pause the video.

Start the video after being paused.

DRAFT - Internal Use Only

Multimedia 85

Note:

The screen view icons are a three-way toggle. The icon

that is displayed, is the mode that displays after tapping

the icon.

For more information on downloading videos for your phone,

see “Media Hub” on page 79.

Play Movies

With Google Play Movies, you can rent thousands of different

movies. You can watch instantly, or download your movie for

offline viewing at a later time.

1. From the Home screen, tap ➔

Play Movies

2. Log on to your Google account if you have not already

done so.

3. Following the on-screen instructions for renting and

viewing movies.

4. Tap the

MY RENTALS

tab to view movies you have

rented.

5. Tap the

PERSONAL VIDEOS

tab to view movies you have

on your phone or memory card.

6. Press for additional options.

Press and hold to rewind the video. Tap to

go to previous video.

Press and hold to fast-forward the video.

Tap to go to next video.

Volume control.

PIP (Picture In Picture) view. T

he video will

be played in a small window so you can use

your phone for other purposes while watching

the video. Double-tap screen to return to

previous size.

Original size view. T

he video will be played in

its original size.

Full-screen in ratio view. T

he video is

enlarged as much as possible without

becoming distorted.

Full-screen view. T

he entire screen is used,

which may cause some minor distortion.

DRAFT - Internal Use Only

Gallery

The Gallery is where you view photos and play back videos.

For photos, you can also perform basic editing tasks, view a

slideshow, set photos as wallpaper or contact image, and

share as a picture message.

1. Tap ➔

Gallery

All of the Albums that hold your pictures and videos

displays with folder name and number of files.

2. Tap an Album and thumbnails of the contents displays.

Note:

If your device displays that the memory is full when you

access Gallery, delete some of the files by using

My files

or other file management applications and try again. For

more information, refer to “My Files” on page 180.

Viewing Pictures

1. Tap a thumbnail to view the picture.

Note:

If no control icons are displayed on the screen in

addition to the picture, tap anywhere on the screen to

display them.

2. The following options are available at the top of the

screen:

• Slideshow

: allows you to see your photos in a slideshow.

You can also select Slideshow settings to set Effects, Music,

and Speed.

•Share via

: allows you to share the picture via Group Cast,

ChatON, Flipboard, Picasa, Google+, S Memo, Bluetooth, Wi-Fi

Direct, Messaging, Gmail, or Email.

• Delete

: allows you to delete the picture.

3. Press for additional options.

Viewing Videos

Note:

If no control icons are displayed on the screen in

addition to the picture, tap anywhere on the screen to

display them.

1. Tap a video to select it.

2. Tap to play the video.

3. Press for additional options.

For video player controls, see “Video Player” on

page 84.

DRAFT - Internal Use Only

Multimedia 87

Camera

This section explains how to use the camera on your phone.

You can take photographs and shoot video by using the built-

in camera functionality. Your 8 megapixel camera produces

photos in JPEG format.

Important!

Do not take photos of people without their

permission.

Do not take photos in places where cameras are

not allowed.

Do not take photos in places where you may

interfere with another person’s privacy.

Using the Camera

Taking Photos

Taking pictures with your device’s built-in camera is as

simple as choosing a subject, pointing the camera, then

pressing the camera key.

Note:

When taking a photo in direct sunlight or in bright

conditions, shadows may display on the photo.

1. From the main Home screen, tap ➔

Camera

to activate the camera mode.

2. Using the phone’s main display screen as a viewfinder,

adjust the image by aiming the camera at the subject.

3. Before you take a picture, use the

and

Down

Volume

keys to zoom in or out. You can magnify the picture up

to x4 (400 percent).

– or –

Pinch the screen to zoom out or pinch outwards to

zoom in.

4. If desired, before taking the photo, you can tap

on-screen icons to access various camera options and

settings.

5. You can also tap the screen to move the focus to the

area you touch.

6. Press the Camera key ( ) until the shutter sounds.

(The picture is automatically stored to your designated

storage location. If no microSD is installed, all pictures

are stored on the Phone.) For more information, refer to

“Camera Options” on page 88.

DRAFT - Internal Use Only

7. While viewing a picture, after you have taken it, pinch

the screen outwards to zoom in or pinch the screen

inwards to zoom out.

You can magnify the picture up to x4.

8. Press to return to the viewfinder.

Camera Options

Options are represented by icons across both sides of the

screen.

Display Image

Settings

Storage Location

Camera

Key


Viewer

Mode

Front

Flash

Facing

Camera

Charger on

Mode

Shooting

Effects

Camera / Camcorder Mode

: allows you to take a photo

in various modes. Once you change the mode, the

corresponding indicator displays at the top left of the

display. Slide the button up for Camera, or down for

Camcorder.

Self-portrait

: allows you to activate the front facing

camera so you can take pictures of yourself or video

chat.

Flash

: allows you to set the flash options to Off, On, or

Auto flash.

DRAFT - Internal Use Only

Multimedia 89

Shooting mode

: allows you to set the shooting mode to

one of the following:

•

Single shot

: takes a single photo and view it before

returning to the shooting mode.

•

Burst shot

: allows several photographs to be

captured in quick succession by pressing and

holding the shutter button.

•

HDR

: takes pictures in HDR (High Dynamic Range)

mode to increase image detail.

•

Face detection

: double tap on a face to zoom in or

out.

•

Smile shot

: the camera focuses on the face of your

subject. Once the camera detects the person’s

smile, it takes the picture.

•

Beauty

: adjusts the contrast to smooth facial

features.

•

Panorama

: takes a landscape photo by taking an

initial photo and then adding additional images to

itself. The guide box lets you view the area where

the second part of the panoramic picture should

display.

•

Cartoon

: gives your photo a cartoon look.

•

Share shot

: uses Wi-Fi Direct to share your

pictures quickly with your friends.

•

Buddy photo share

: uses face recognition from

pictures in your contacts to send your friends or

family pictures of themselves.

Effects

: allows you to change the color tone or apply

special effects to the photo. Options include: None,

Negative, Black and white, Sepia, Washed out, Cold

vintage, Warm vintage, Posterize, Solarize, Blue point,

Green point, and Red-yellow point.

Settings:

Edit shortcuts

: allows you to set shortcut icons for the

settings that you use the most.

Self-portrait

: allows you to set the front camera so you

can take pictures of yourself.

Flash

: allows you to set the flash options to Off, On, or

Auto flash.

Shooting mode

: allows you to set the shooting mode.

DRAFT - Internal Use Only

Scene mode

: allows you to set the Scene to help take the

best pictures possible. Options include None, Portrait,

Landscape, Night, Sports, Party/Indoor, Beach/Snow,

Sunset, Dawn, Fall Color, Firework, Text, Candlelight,

and Backlight. Helpful tips are shown for each scene

mode at the bottom of the display screen.

Settings: (continued)

Exposure value

: allows you to adjust the brightness

level by moving the slider.

Focus mode

: allows you to set this option to Auto focus

or Macro. Use Macro mode to take close-up pictures.

Timer

: allows you to set a timer for how long to wait

before taking a picture. Options include: Off, 2 sec, 5

sec, and 10 sec.

Effects

: allows you to change the color tone or apply

special effects to the photo. Options include: None,

Negative, Black and white, Sepia, Washed out, Cold

vintage, Warm vintage, Posterize, Solarize, Blue point,

Green point, and Red-yellow point.

Resolution

: allows you to set the image size to either:

8M (3264x2448), W6M (3264x1836),

3.2M (2048x1536), W2.4M (2048x1152),

W0.9M (1280x720), or 0.3M (640x480).

White balance

: allows you to set this option to one of the

following choices: Auto, Daylight, Cloudy,

Incandescent, or Fluorescent.

ISO

: ISO determines how sensitive the light meter is on

your digital camera. Choose from Auto, 100, 200, 400,

or 800. Use a lower ISO number to make your camera

less sensitive to light, a higher ISO number to take

photos with less light, or Auto to let the camera

automatically adjust the ISO for each of your shots.

Metering

: allows you to set how the camera measures

or meters the light source: Centre-weighted, Spot, or

Matrix.

Anti-Shake

: reduces image blur due to the movement

of the subject of the photo or hand movement.

DRAFT - Internal Use Only

Multimedia 91

Viewing your Pictures

After you take a photo, you can access various options from

the Image Viewer. The Image Viewer uses your Gallery. For

more information, refer to “Gallery” on page 86.

Using the Camcorder

In addition to taking photos, the camera also doubles as a

camcorder that also allows you to record, view, and send

videos.

Note:

The camera may not be able to properly record videos to

a memory card with a slow transfer speed.

Auto contrast

: provides a clear image even under

backlight circumstances where intensity of

illumination can vary excessively.

Guidelines

: allows you to turn the guidelines On or Off.

Image quality

: allows you to set the image quality to:

Superfine, Fine, or Normal.

Settings: (continued)

GPS tag

: allows you to turn GPS On or Off (also known

as Geotagging). The location of where the picture is

taken is attached to the picture. (Only available in

Camera mode.) Before you can use the GPS tag

(Geotagging), from the Home screen tap ➔

Settings

➔

Location services

and tap

Use GPS satellites

Shutter sound

: allows you to set the Shutter sound to On

or Off.

Storage

: allows you to configure the default storage

location for images or videos as either Phone or

Memory card (if inserted).

Reset

: allows you to reset all camera or camcorder

settings to the default values.

Image viewer

: allows you to access the Image viewer

and the various viewing options for a selected picture.

Image viewer options are described in the following

section. The last picture you took, displays as a

thumbnail in the Image viewer icon.

DRAFT - Internal Use Only

Shooting Video

Tip:

When shooting video in direct sunlight or in bright

conditions, it is recommended that you provide your

subject with sufficient light by having the light source

behind you.

1. From the main Home screen, tap

Camera

activate the camera mode.

2. Touch and drag the Camera mode button down to

Camcorder Mode.

3. Using the phone’s main display screen as a viewfinder,

adjust the image by aiming the camcorder at the

subject.

4. Before you take a video, use the

and

Down

Volume

keys to zoom in or out. You can magnify the video up to

x4 (400 percent).

– or –

Pinch the screen to zoom out or pinch outwards to

zoom in.

5. Tap the Video key ( ) to begin shooting video. The red

light will blink while recording.

6. You can tap the screen to move the focus to the area

you touch.

7. Tap to turn on auto focus. This will automatically

focus on the middle of the screen.

8. To capture an image from the video while recording,

tap . This feature is not available when the anti-

shake feature is activated.

9. Tap the Video key ( ) again to stop the recording and

save the video file to your Camera folder.

10. Once the file has been saved, tap the image viewer,

then tap to play your video for review.

11. Press to return to the viewer.

Camcorder Options

Options are represented by icons across both sides of the

screen.

Camera / Camcorder Mode

: allows you to take a photo

in various modes. Once you change the mode, the

corresponding indicator displays at the top left of the

display. Slide the button up for Camera, or down for

Camcorder.

DRAFT - Internal Use Only

Multimedia 93

Live Shooting

: takes a photo during a video recording

session in Camcorder mode. You can view the photo in

your image viewer or Gallery.

Self portrait

: allows you to activate the front facing

camera so you can take videos of yourself or video chat.

Flash

: allows you to set the flash options to Off or On.

When you set the flash to On, it stays on continually

while you are taking a video.

Recording mode

: allows you to set the recording mode

to: Normal, which is limited only by available space on

the destination location and to Limit for MMS, which is

limited by MMS size restrictions.

Effects

: allows you to change the color tone or apply

special effects to the video. Options include: None,

Negative, Black and white, Sepia, Washed out, Cold

vintage, Warm vintage, Posterize, Solarize, Blue point,

Green point, and Red-yellow point.

Settings:

Edit shortcuts

: allows you to set shortcut icons for the

settings that you use the most.

Self-recording

: allows you to set the front camera so

you can take videos of yourself or video chat.

Flash

: allows you to set the flash options to Off or On.

When you set the flash to On, it stays on continually

while you are taking a video.

Recording mode

: allows you to set the recording mode

to: Normal, which is limited only by available space on

the destination location or Limit for MMS, which is

limited by MMS size restrictions.

Exposure value

: allows you to adjust the brightness

level by moving the slider.

DRAFT - Internal Use Only

Viewing your Videos

After you take a video, you can access various options from

the Image Viewer. The Image Viewer uses your Gallery and

the Video Player. For more information, refer to “Gallery” on

page 86. Also, see“Video Player” on page 84.

Timer

: allows you to set a timer for how long to wait

before taking a video. Options include: Off, 2 sec, 5 sec,

and 10 sec.

Effects

: allows you to change the color tone or apply

special effects to the photo. Options include: None,

Negative, Black and white, Sepia, Washed out, Cold

vintage, Warm vintage, Posterize, Solarize, Blue point,

Green point, and Red-yellow point.

Resolution

: allows you to set the image size to either:

1920x1080, 1280x720, 720x480, 640x480, or

320x240.

Settings: (continued)

White balance

: allows you to set this option to one of the

following choices: Auto, Daylight, Cloudy,

Incandescent, or Fluorescent.

Anti-Shake

: reduces image blur due to the movement

of the subject of the video or hand movement.

Guidelines

: allows you to turn the guidelines On or Off.

Video quality

: allows you to set the image quality to:

Superfine, Fine, or Normal.

Storage

: allows you to configure the default storage

location for images or videos as either Phone or

Memory card (if inserted).

Reset

: allows you to reset all camera or camcorder

settings to the default values.

Image viewer

: allows you to access the Image viewer

and the various viewing options for a selected video.

Image viewer options are described in the following

section. The last video you took, displays as a

thumbnail in the Image viewer icon.

DRAFT - Internal Use Only

Messaging 95

Section 7: Messaging

This section describes how to send and receive different

types of messages. It also includes the features and

functionality associated with messaging.

Types of Messages

Your phone provides the following message types:

•

Text Messages

•

Multimedia (Picture, Video, and Audio) Messages

•

Email and Gmail Messages

•

Google Talk

•

Messenger Messages

•

ChatON

The Short Message Service (SMS) lets you send and receive

text messages to and from other mobile phones or email

addresses. To use this feature, you may need to subscribe to

your service provider’s message service.

The Multimedia Messaging Service (MMS) lets you send and

receive multimedia messages (such as picture, video, and

audio messages) to and from other mobile phones or email

addresses. To use this feature, you may need to subscribe to

your service provider’s multimedia message service.

Important!

When creating a message, adding an image, a

sound file, or a video clip to a text message

changes the message from a text message to a

multimedia message.

Messaging icons are displayed at the top of the screen and

indicate when messages are received and their type. For

more information, refer to “Indicator Icons” on page 23.

Creating and Sending Messages

1. From the main Home screen, tap

Messaging

➔

Compose

Note:

The main Home screen initially contains the

Messaging

icon. If you delete it, or if you want to access

Messaging from another Home screen, you must tap

Apps

➔

Messaging

2. Tap on the

Enter recipient

field to manually enter a

recipient or tap to select a recipient from your

Contacts.

DRAFT - Internal Use Only

3. If adding a recipient from your Contacts, tap the

contact then tap

Done

. A checkmark indicates

selection.

The contact displays in the recipient field.

Note:

For the Group option, if the number of recipients is less

than 10, all members in the group will be added. You will

need to delete any unnecessary members in the list by

selecting the trash can icon and deleting unwanted

entries.

Note:

Enter additional recipients by separating each entry with

a semicolon (;) then using the previous procedure.

4. Tap the

Enter message

field and use the on-screen

keypad to enter a message. For more information, refer

to “Entering Text” on page 64.

5. Add more recipients by tapping the recipient field.

6. Review your message and tap

Send

Note:

If you exit a message before you send it, it will be

automatically saved as a draft.

Message Options

Options before composing a message

1. From the main Home screen, tap

Messaging

2. Before composing a message, press to reveal

additional messaging options:

•Search

: allows you to search through all of your messages for

a certain word or string of words. Enter a search string in the

Messaging Search window and tap .

• Settings

: allows you to access Messaging settings. For more

information, refer to

“Messaging Settings”

on page 100.

• Delete threads

: allows you to delete any message thread.

Select the messages to delete. A checkmark indicates

selection. Tap

Delete

Options while composing a message

1. While composing a message, press to reveal

additional messaging options.

•Call

: allows you to call the contact. This option only displays if

you have entered a phone number for the recipient.

• Insert smiley

: allows you to add emoticons, such as a happy

face to your message.

DRAFT - Internal Use Only

Messaging 97

•Add text

: allows you to copy text from your contacts, calendar,

or from a memo to add to your message. This is a convenient

feature for adding names, phone numbers, events, etc. to your

message.

For more information, refer to “Adding

Additional Text”

on page 98.

• Add to Contacts

: allows you to add the recipient to your

Contacts list. This option only displays if the recipient is not

already in your Contacts list.

•View contact

: allows you to see information on the recipient.

This option only displays if the recipient is in your Contacts list.

• Add slide

: allows you to add a new page to a message.

• Delete message

: allows you to delete the message.

Adding attachments to a message

To add an attachment to your message, tap and select

one of the following options:

•

Pictures

: allows you to tap an existing image from your Pictures

list to add it to your message.

•

Take picture

: allows you to temporarily exit the message, take a

photo with phone’s camera, and then add it to your message by

tapping

Save

•

Videos

: allows you to choose an existing video from the Videos

list,

then add it to your message

•

Capture video

: allows you to temporarily exit the message,

record a video clip using the phone’s camera, and then add it

to your message by tapping

Save

•

Audio

: allows you to choose an existing audio file from the

Audio list, then add it to your message by tapping the circle to

the right of the audio so that it turns green, then tapping

Done

•

Record audio

: allows you to temporarily exit the message and

record an audio clip using the phone’s microphone. It is then

automatically attached to the message.

•

S Memo

: allows you to add an S Memo that you have created.

•

Calendar

: allows you to add an event from your calendar. Select

the desired event and tap

Done

•

Location

: allows you to attach a thumbnail of a map showing

your location.

•

Contacts

: allows you to tap on an existing Address Book entry,

then add it to your message by tapping

Done

DRAFT - Internal Use Only

Adding Additional Text

You can copy text such as names, phone numbers, and

events from your Contacts, Calendar or a Memo.

1. While composing a message, press ➔

Add text

2. At the Add text screen, select one of the following:

•S Memo

: allows you to insert text from an existing S Memo.

•Calendar

: allows you to add the name, date, and time of a

calendar event to your message.

•Location

: allows you to add an address and the link to the

location on Google Maps.

•Contacts

: allows you to add the name and phone number of

any of your contacts to your message.

• Text templates

: allows you to add pre-defined phrases and

sentences.

The information is added to your message.

Viewing New Received Messages

1. When you receive a new message, the new message

icon displays at the top of your screen.

2. Open the Notification Bar and select the message. For

more information, refer to “Notification Bar” on page

42.

– or –

From the main Home screen, tap

Messaging

then

tap the new message to view it.

The selected message displays on the screen.

3. To play a multimedia message, tap .

•

To pause playback of the multimedia message, tap

4. To scroll through the message (if additional text pages

have been added), touch the screen and in a single

motion, scroll up or down the page.

Message Threads

Sent and received text and picture messages are grouped

into message threads. Threaded messages allow you to see

all the messages exchanged (similar to a chat program) and

displays a contact on the screen. Message threads are listed

in the order in which they were received, with the latest

message displayed at the top.

DRAFT - Internal Use Only

Messaging 99

To open a threaded message follow these steps:

1. From the main Home screen, tap

Messaging

Tap the message thread you want to view.

2. Touch and hold the message thread to display the

following options:

•View contact

: displays the contact’s information. This option

only displays if the sender is in your Contacts list.

• Add to Contacts

: displays the Contacts information screen.

This option only displays if the sender is not in your Contacts

list.

• Delete thread

: displays a confirmation dialog box that when

pressed, deletes the entire thread.

Deleting Messages

Deleting a single message thread

1. From the main Home screen, tap

Messaging

2. Touch and hold a message, then tap

Delete thread

3. At the

Delete

prompt, tap

to delete or

Cancel

cancel.

Deleting multiple message threads

1. From the main Home screen, tap

Messaging

2. Press ➔

Delete threads

3. Tap each message you want to delete. A checkmark

displays beside each selected message.

4. Tap

Delete

5. At the

Delete

prompt, tap

to delete or

Cancel

cancel.

Message Search

You can search through your messages by using the

Message Search feature.

1. From the main Home screen, tap

Messaging

2. Tap ➔

3. Use the on-screen keypad to enter a word or phrase to

search for, then tap .

4. All messages that contain the search string you

entered are displayed.

DRAFT - Internal Use Only

100

Messaging Settings

To configure the settings for text messages, multimedia

messages, Voice mails, and Push messages.

1. From the main Home screen, tap

Messaging

➔

Settings

2. The following Messaging settings are available:

Display:

• Bubble style

: allows you to choose from several bubble styles

for your messages. Bubbles are the rounded boxes that

surround each message.

• Background style

: allows you to choose from several

background styles for your messages.

• Use the volume key

: allows you to change the text size by

using the up or down volume keys.

Storage settings:

• Delete old messages

: deletes old messages when the limit is

reached, rather than having them overwritten.

• Text message limit

: allows you to set a limit on how many text

messages can be in one conversation.

• Multimedia message limit

: allows you to set a limit on how

many multimedia messages can be in one conversation.

• Set text templates

: allows you to edit or add new text

templates to use in your messaging.

Text message (SMS) settings:

• Manage SIM card messages

: allows you to manage the

messages that you have stored on your SIM card.

• Message center

: allows you to enter the number of your

Message center where your messages reside while the system

is attempting to deliver them.

• Input mode

: allows you to set the input mode for your text

messages. Choose between GSM Alphabet, Unicode, or

Automatic.

Multimedia message (MMS) settings:

•Auto-retrieve

: allows the message system to retrieve

messages automatically.

•Creation mode

: allows you to select the creation mode, Free,

Restricted, or Warning.

–

Restricted

: you can only create and submit messages with

content belonging to the Core MM Content Domain.

–

Warning

: the phone will warn you via pop up messages that

you are creating a multimedia message which does not fit the

Core MM Content Domain.

DRAFT - Internal Use Only

Messaging 101

–

Free

: you may add any content to the message.

Push message settings:

• Push messages

: allows you to receive push messages from

the network.

Cell Broadcast (CB) settings:

• CB activation

: allows you to receive Cell Broadcast (CB)

messages.

• Channel configuration

: allows you to set up the channel that

you will receive CB messages on.

Notifications settings:

• Notifications

: allows you to see message notifications on your

status bar.

• Select ringtone

: allows you to set the ringtone for your

message notifications.

Using Email

Email enables you to review and create email using various

email services. You can also receive text message alerts

when you receive an important email.

Creating an Email Account

1. From the Home screen, tap ➔

Your accounts screen displays with an Email setup

screen displayed.

2. Enter you email address in the

address

field.

3. Enter your password in the

Password

field.

4. If you want to see your password as it is being typed,

tap

Show password

to enable the feature.

5. Tap

6. At the

Account options

screen, tap the

Email check

frequency

drop-down list box and select how often you

would like your email to be checked.

7. Tap any of the other options you would like to enable.

8. Tap

9. Enter a name for this email account (optional).

10. Tap

Done

DRAFT - Internal Use Only

102

Creating a Corporate Email Account

Use the following procedure to configure your phone to

synchronize with a corporate email account.

1. From the Home screen, tap ➔

Your accounts screen displays with an Email setup

screen displayed.

2. Enter you email address in the

address

field.

3. Enter your password in the

Password

field.

4. If you want to see your password as it is typed, tap

Show password

5. Tap

Manual setup

6. Tap the

Microsoft Exchange ActiveSync

field.

7. Enter all the Exchange server information, Domain,

User name and Password, then tap

8. At the

Activation

prompt, tap

The

Account options

screen displays.

9. Enter the desired information in the different fields,

then tap

10. Enter an Account name for this account (Optional) and

tap

Done

Wait for the Inbox to synchronize before use.

11. Press ➔

Settings

to change the account settings.

Creating Additional Email Accounts

To create additional email accounts after setting up your first

account, follow these steps:

1. From the Home screen, tap ➔

Your Email screen displays showing your emails from

the active account.

2. Press ➔

Settings

3. Tap to add another email account.

4. Enter the information required to set up another

account. For more information, refer to “Creating an

Email Account” on page 101.

Switching Between Email Accounts

1. From the Home screen, tap ➔

Your Email screen displays showing your emails from

the active account.

DRAFT - Internal Use Only

Messaging 103

2. Tap the Inbox button at the top of your screen that

displays the optional name you assigned to your active

email account, for example, Work, Gmail, etc.

Your Email accounts screen displays.

3. Tap the Email account you would like to switch to. You

can also select

Combined view

which will display email

messages from all accounts.

4. The new Email account displays.

Using Gmail

Gmail is Google’s web-based email. When you first setup the

phone, Gmail is configured. Depending on the

synchronization settings, Gmail is automatically synchronized

with your Gmail account.

Signing into Your Gmail

Note:

You must sign in to your Gmail account in order to

access Gmail.

1. Sign on to your Google account if you are not already

signed on. For more information, refer to “Creating a

New Google Account” on page 13.

2. From the Home screen, tap ➔

Gmail

3. Follow the on-screen instructions.

The Inbox loads conversations and email.

Creating a Gmail Message

1. From the Gmail Inbox, tap at the bottom of the

screen to create a new message.

2. Enter the recipients Email address in the

field.

Separate multiple recipient email addresses with a

comma.

3. Tap and select

Add Cc/Bcc

to add a carbon or blind

copy.

4. Enter the subject of this message in the

Subject

field.

5. Tap the

Compose email

field and begin composing your

message.

6. Tap to send.

Viewing a Gmail Message

1. From the Gmail Inbox, tap a message to view it.

2. The following options are available at the bottom of the

screen after a message has been selected:

•Archive

: archives the selected message.

• Delete

: deletes the message.

DRAFT - Internal Use Only

104

•Labels

: allows you to attach labels to a message. This is

similar to putting it in a folder.

•Mark Unread

: after reading a message, marks as unread.

•Newer

: swipe your screen to the right to see newer messages.

•Older

: swipe your screen to the left to see older messages.

3. Press to select one of the following additional

options:

• Mark important/not important

: allows you to set the

importance of a message.

•Mute

: allows you to mute the sound in a message if applicable.

•Report spam

: allows you to report a message as spam. Tap

the UNDO option if you change your mind.

• Settings

: displays Email settings that you can modify.

•Help

: displays the Google.com webpage so you can search the

web for help.

• Send feedback

: allows you to send feedback or report a

problem.

Other Gmail Options

1. Tap at the bottom of the screen to refresh the

screen, send and receive new emails, and synchronize

your email with the Gmail account.

2. Tap at the bottom of the screen to set up and

manage Labels for your Gmail messages.

3. Tap at the bottom of the screen to search through

your Gmail messages.

Google Talk

Google Talk is a free Windows and web-based application for

instant messaging offered by Google. Conversation logs are

automatically saved to a Chats area in your Gmail account.

This allows you to search a chat log and store them in your

Gmail accounts.

1. Log on to your Google account if you have not already

done so. For more information, refer to “Creating a

New Google Account” on page 13.

2. From the Home screen, tap ➔

Talk

3. Begin using Google Talk.

4. Press ➔

Help

for more information on using

Google Talk.

DRAFT - Internal Use Only

Messaging 105

Note:

The Network confirms your login and processes. This

could take up to 5 minutes to complete.

ChatON

Provides a global mobile communication service where you

can chat with more than 2 buddies via a group chat. Share

things such as pictures, videos, animation messages

(Scribbles), audio, Contacts, Calendar entries, and Location

information.

Important!

The Samsung account manages the access

information (username/password) to several

applications, such as AllShare Play, ChatON, and

Media Hub.

For more information, visit:

https://web.samsungchaton.com

Registering with the Service

1. Confirm you have already logged in to your Samsung

account.

Note:

There should be no (

Samsung account

icon) in the

Notifications area of the screen.

2. From the Home screen, tap ➔

ChatON

3. Read the on-screen notification about data charges

and tap

4. Select either the

Terms and conditions

and read the on-screen information. Tap

continue.

5. Select a country code, enter your current phone

number to register with the service, and tap

Done

6. Choose to receive the verification code via either

SMS

(text message) or

Voice

to your device.

Note:

If you opt to receive the verification code via SMS, this

information is sent directly to your device. Once

received, the

Verification

field is automatically filled in.

7. Enter your real name and tap

DRAFT - Internal Use Only

106

Adding Your First Chat On Buddy

1. From the Home screen, tap ➔

ChatON

2. Tap

Add buddy

and choose a search method.

• Address

: to search by Country code and phone number.

• Search by Samsung Account ID

: to search by using

a known samsung account ID.

3. Enter the information and tap . Once the recipient

is matched, their entry displays in the

Results

area.

4. Tap (

Add buddy

) and confirm your new buddy

displays in the Buddies tab.

Note:

For more information, press and tap

General

➔

Help

Using ChatON for Chatting

1. From the Home screen, tap ➔

ChatON

2. Tap the Buddies tab and select a buddy to initiate your

chat.

3. Enter your message using the on-screen text entry

method.

4. Tap to send the message.

To reply to a ChatON message:

1. While the chat session is active, tap the

Enter message

field and then type your reply message.

2. Compose your reply.

Your texts are colored Blue and your buddy’s messages

are white.

3. Tap to deliver your reply.

Send

Buddy’s Bubble

My Bubble

Text Message

Thread

Send

DRAFT - Internal Use Only

Messaging 107

Deleting a single message bubble

1. From the Home screen, tap ➔

ChatON

2. Launch a chat session to reveal the message string.

3. Touch and hold a message bubble, then select

Delete

DRAFT - Internal Use Only

108

Section 8: Changing Your Settings

This section explains the settings used for customizing your

device.

Accessing Settings



From any Home screen, tap ➔

Settings

– or –

From any Home screen, press ➔

Settings

The Settings screen displays.

Wi-Fi Settings

This section describes the Wi-Fi settings. For information on

how to use Wi-Fi, see “Wi-Fi” on page 156.

Activating Wi-Fi

1. From the Home screen, tap ➔

Settings

➔

Wi-Fi

2. Tap the ON/OFF slider, located to the right of the Wi-Fi

fi eld, to turn Wi-Fi ON .

3. Tap

Scan

to scan for available Wi-Fi networks. For more

information, refer to “Connect to a Wi-Fi Network” on

page 157.

Advanced Wi-Fi Settings

The advanced Wi-Fi settings allow you to set up and manage

wireless access points.

1. From the Home screen, tap ➔

Settings

➔

Wi-Fi

2. Tap

Advanced

The following options are available:

• Network notification

: alerts you when a new WAP is available.

• Keep Wi-Fi on during sleep

: allows you to specify when to

disconnect from Wi-Fi.

• Check for Internet service

: Checks if Wi-Fi internet service is

available when connected to an AP (Access Point).

• Auto connect

: allows you to be automatically connected to an

when connecting to some secured networks (not configurable).

•IP address

: view your device’s IP address.

DRAFT - Internal Use Only

USCC

Wi-Fi Hotspot as soon as your phone detects it.

• MAC address

: view your device’s MAC

address, required

Changing Your Settings 109

Bluetooth settings

In this menu you can activate Bluetooth, view or assign a

device name, activate your phone so other Bluetooth devices

can discover it, or scan for other, available Bluetooth devices

with which to pair.

Activating Bluetooth

1. From the Home screen, tap ➔

Settings

2. Tap the ON/OFF slider, located to the right of the

Bluetooth field, to turn Bluetooth ON .

The Bluetooth icon is displayed.

Additional Bluetooth Settings

When Bluetooth is on, additional settings are available.

1. From the Home screen, tap ➔

Settings

➔

Bluetooth

2. Tap

Scan

to scan for nearby discoverable devices. After

searching, tap a device to pair with it. For more

information, refer to “Pairing Bluetooth Devices” on

page 162.

3. Press and select a Bluetooth setting to configure:

• Rename device

: Your device’s default name displays on

screen. Tap to change the device name. Available when

Bluetooth is turned On.

• Visible time-out

: Use this setting to control when to

automatically turn off the Discoverable option: 2 minutes, 5

minutes, 1 hour, or Never timeout.

• Received files

: Show the list of files received by using

Bluetooth.

4. Tap the checkbox next to

SGH-I317

if you do not want

your phone visible to other Bluetooth devices.

Sharing and Transferring Files

This section describes ways that you can share and transfer

data on your device to other people and devices.

NFC

NFC (Near Field Communication) allows data exchange when

you touch your device with another compatible device. This

is used for applications such as Android Beam and S Beam.

To activate NFC, follow these steps:

1. From the Home screen, tap ➔

Settings

➔

and transfer

DRAFT - Internal Use Only

110

2. Tap the ON/OFF slider, located to the right of the NFC

field, to turn NFC ON .

S Beam

When S Beam is activated, you can beam files to another

NFC-capable device by holding the devices close together.

You can beam images and videos from your Gallery, music

files from your Music Player, and more.

1. From the Home screen, tap ➔

Settings

➔

settings

➔

S Beam

2. Tap the

OFF / ON

icon to turn S Beam on .

3. Touch the back of your device with another

NFC-capable device and the content transfers.

Nearby devices

This option allows you to share your media files with nearby

devices using DLNA and connected to the same Wi-Fi.

1. Connect to a Wi-Fi network. For more information, refer

to “Activating Wi-Fi” on page 108.

2. From the Home screen, tap ➔

Settings

➔

settings

➔

Nearby devices

3. Verify Wi-Fi Direct is enabled and you are paired with

the device you wish to detect and share content with.

4. Tap the

OFF / ON

icon to turn File sharing ON .

5. Verify (

Nearby devices

) displays at the top of the

screen.

6. At the Nearby devices prompt, tap

7. Tap

Shared contents

, then check the media you would

like to share. Tap

8. Tap

Device name

, then use the on-screen keyboard to

change the name shown to others. Tap

Save

9. Tap

Access control

, then what devices are allowed

access. Choose from Allow all or Only allowed devices.

The allowed devices are configured in the following

Allowed devices list.

10. Tap

Allowed devices list

, then select the connected

devices you would like to allow.

11. Tap

Not-allowed devices list

, then select the connected

devices you would like to not allow.

12. Tap

Download to

, then select the destination of any

downloaded (shared) content. Choose from USB

storage (phone) or SD card.

DRAFT - Internal Use Only

Changing Your Settings 111

13. Tap

Upload from other devices

, then select the actions

you’ll take when you upload content from other

devices. Choose from either Always accept, Always

ask, or Always reject.

AllShare Cast

With AllShare Cast, you can wirelessly share your phone's

screen with Wi-Fi-enabled TV using the AllShare Cast Hub

accessory.

1. Confirm you have already logged in to your Samsung

account. There should be no icon in the

Notifications area of the screen.

2. From the Home screen, tap ➔

Settings

➔

and transfer

➔

AllShare Cast

3. Tap the

OFF / ON

icon to turn AllShare Cast on

4. Make sure you and the device you want to share with

are connected to the same Wi-Fi network. For more

information, refer to “Connect to a Wi-Fi Network” on

page 157.

Your phone automatically scans for other compatible

devices.

5. Follow the on-screen instructions to connect with the

TV.

Note:

This feature allows a connection between your phone

and the optional AllShare Cast Hub, via a shared Wi-Fi

connection. The AllShare Cast Hub then allows the

communicating TV to mirror what is being shown on the

phone's display.

Kies via Wi-Fi

Kies via Wi-Fi allows you to sync your PC wirelessly with your

device provided they are both on the same Wi-Fi network.

You can view and share videos, photos, music, ringtones,

and more.

1. From your PC, download the Samsung Kies application

if you don’t already have it. You can find it at

samsung.com

2. From your PC, launch the Samsung Kies application.

3. From your PC, connect to a Wi-Fi network.

4. From the Home screen, tap ➔

Settings

➔

and transfer

➔

Kies via Wi-Fi

DRAFT - Internal Use Only

112

5. From your device, connect to the same Wi-Fi network

that your PC is connected to if you have not already

done so. For more information, refer to “Connect to a

Wi-Fi Network” on page 157.

More Settings...

This option displays additional Connectivity information.

1. From the Home screen, tap ➔

Settings

2. Tap

More settings

located under the Connectivity

heading.

Options display for Airplane mode, Mobile networks,

Tethering and portable hotspots, Wi-Fi Direct, Location

services, and VPN.

Airplane mode

Airplane mode allows you to use many of your phone’s

features, such as Camera, Games, and more, when you are

in an airplane or in any other area where making or receiving

calls or data is prohibited.

Important!

When your phone is in Airplane Mode, it cannot

send or receive any calls or access online

information or applications.

1. From the Home screen, tap ➔

Settings

2. Tap

More settings

located under the Connectivity

heading.

3. Tap

Airplane mode

. A check mark displayed next to the

feature indicates Airplane mode is active.

4. At the

Airplane mode

prompt, tap

The Airplane mode icon is displayed at the top of

your screen.

Mobile networks

Before you use applications such as Google Maps and find

your location or search for places of interest, you must

enable the Mobile networks options.

Mobile data

To enable data access over the mobile network, this option

must be selected. It is set on by default.

1. From the Home screen, tap ➔

Settings

➔

settings

➔

Mobile networks

2. Tap

Mobile data

to activate the feature.

DRAFT - Internal Use Only

Changing Your Settings 113

Data Roaming

Data roaming allows you to connect to your service

provider’s partner networks and access data services when

you are out of your service providers area of coverage.

1. From the Home screen, tap ➔

Settings

➔

settings

➔

Mobile networks

2. Tap

Data roaming

to activate the feature.

Access Point Names

To use Wi-Fi you need access to a wireless access point

(hotspot).

1. From the Home screen, tap ➔

Settings

➔

settings

➔

Mobile networks

2. Tap

Access Point Names

A list of the Access Point names display. The active

access point displays a green, filled circle to the right

of the name.

Network Operators

Using this feature you can view the current network

connection. You can also scan and select a network operator

manually, or set the network selection to Automatic.

1. From the Home screen, tap ➔

Settings

➔

settings

➔

Mobile networks

2. Tap

Network operators

The current network connection displays at the bottom

of the list.

Important!

You must deactivate data service prior to searching

for an available network.

3. Tap

Search networks

to manually search for a network.

4. Tap

Select automatically

to automatically select a

network connection.

Note:

Connecting to 2G networks slows the data transfer

speed and time.

Default setup options

Your phone default is set to Automatic (to automatically

search for an available network. You can set this option to

Manual to select a network each time you connect.

1. From the Home screen, tap ➔

Settings

➔

settings

➔

Mobile networks

2. Tap

Network operators

DRAFT - Internal Use Only

114

3. Tap

Default setup

4. Tap

Manual

to locate and connect to a network

manually, or tap

Automatic

to allow the device to

automatically select a network.

Tethering & portable hotspot

This option allows you to share your phones’s mobile data

connection via USB or as a portable Wi-Fi hotspot.

USB tethering

1. From the Home screen, tap ➔

Settings

➔

settings

➔

Tethering and portable hotspots

2. Connect your phone to your PC using a USB cable.

3. Tap

USB tethering

to activate the feature. The USB

tethering icon is displayed at the top of your

screen.

Portable Wi-Fi hotspot

1. From the Home screen, tap ➔

Settings

➔

settings

➔

Tethering and portable hotspots

➔

Portable

Wi-Fi hotspot

2. Turn Portable Wi-Fi hotspots on by tapping the slider so

that it changes to the ON position .

The Portable Wi-Fi hotspot icon displays at the top

of your screen.

3. Tap

Configure

at the bottom of the screen.

4. Enter or edit the Network SSID, Hide my device,

Security setting, and Password.

5. Tap

Show password

and

Show advanced options

to see

them displayed.

6. Tap

Save

7. Press for the following options:

• Timeout settings

: allows you to set the time your device will be

available as a portable Wi-Fi hotspot.

•Help

: provides additional information.

Connecting to Portable Wi-Fi hotspot from other

devices

1. Activate Wi-Fi on the device that wants to connect to

your phone.

2. Find

[SGHI317_xxxx]

in the Wi-Fi network list and

connect to it. XXXX are four randomly generated digits

that displays when you set up a Portable Wi-Fi hotspot

on your device.

DRAFT - Internal Use Only

Changing Your Settings 115

The connected device can now use internet through

your Portable Wi-Fi hotspot.

Note:

Activating Wi-Fi and connecting to your phone will be

different depending on the type of the other device.

Help



From the

Tethering and portable hotspot

menu, tap

Help

for additional information

Activating Wi-Fi Direct

Wi-Fi Direct allows device-to-device connections so you can

transfer large amounts of data over a Wi-Fi connection.

1. From the Home screen, tap ➔

Settings

➔

settings

➔

Wi-Fi Direct

2. Tap the

OFF / ON

icon to turn Wi-Fi Direct on .

For more information, refer to “Wi-Fi Direct” on page

158.

VPN settings

The VPN settings menu allows you to set up and manage

Virtual Private Networks (VPNs).

Important!

Before you can use a VPN you must establish and

configure one.

Adding a Basic VPN

Before you add a VPN you must determine which VPN

protocol to use: PPTP (Point-to-Point Tunneling Protocol),

L2TP (Layer 2 Tunneling Protocol), L2TP/IPSec PSK (Pre-

shared key based L2TP/IPSec), or L2TP/IPSec CRT

(Certificate based L2TP/IPSec).

1. Before using VPN, you must first set up a screen unlock

PIN or password. For more information, refer to “Lock

Screen Settings” on page 116.

2. From the Home screen, tap ➔

Settings

➔

settings

➔

VPN

3. Tap

Basic VPN

4. Tap

Add VPN network

5. Enter a name for the VPN network in the

Name

field.

DRAFT - Internal Use Only

116

6. Select a VPN type from the

Type

drop-down menu. The

options are:

•

PPTP (Point-to-Point Tunneling Protocol)

•

L2TP/IPSec PSK (Layer 2 Tunneling Protocol / Internet Protocol

Security Pre-Shared Key)

•

L2TP/IPSec RSA

•

IPSec Xauth PSK

•

IPSec Xauth RSA

•

IPSec Hybrid RSA

7. Enter the Server address and any other required fields

that are dependent upon the

Type

you entered

previously.

8. Tap the

Show advanced options

check box to display

additional VPN options.

9. Tap

Save

to save your VPN settings.

Adding an IPsec VPN

1. Before using VPN, you must first set up a screen unlock

PIN or password. For more information, refer to “Lock

Screen Settings” on page 116.

2. From the Home screen, tap ➔

Settings

➔

settings

➔

VPN

3. Tap

Advanced IPsec VPN

4. Tap

Add VPN connection

5. Enter a password and tap

6. Enter a name for the VPN connection in the

VPN

connection name

field.

7. Select a IPsec type from the drop-down menu.

8. Enter any other required information.

9. Tap the

Show advanced options

check box to display

additional VPN options.

10. Tap

Save

to save your VPN settings.

Lock Screen Settings

Choose settings for unlocking your screen. For more

information about using the lock and unlock features, see

“Locking and Unlocking the Touch Screen” on page 12.

More Settings (Personalization)

This option displays additional phone personalization

information.

1. From the Home screen, tap ➔

Settings

2. Tap

More settings

located under the Personalization

heading.

DRAFT - Internal Use Only

Changing Your Settings 117

Options display for Home screen mode, LED indicator,

Dormant mode, One-handed operation, and Touch key

light duration.

Home screen mode

Home sceen mode allows you to set your display to the

conventional layout of

Basic mode

or provide an easier user

experience for the first-time smartphone users using

Easy

mode

1. From the Home screen, tap ➔

Settings

➔

settings

(Personalization).

2. Tap

Home screen mode

3. Tap the pull-down dropbox and select one of the

following options:

•Basic mode

: provides conventional layout for the apps and

widgets on your home screens.

• Easy mode

: provides easier user experience for first-time

smartphone users on the home screens.

4. Tap

Apply

One-handed operation

The one-handed operation settings help you to use your

phone keypads easily with only one hand.

1. From the Home screen, tap ➔

Settings

➔

settings

(Personalization) ➔

One-handed operation

2. The following options are available:

• Keypad & in-call buttons

: allows you to adjust the position of

the dialing keypad and in-call buttons to the left or the right to

make it easier to use with one hand.

• Samsung keyboard

: allows you to adjust the position of the

Samsung keyboard to the left or the right to make it easier to

use with one hand.

•Calculator

: allows you to adjust the position of the calculator

keypad to the left or the right to make it easier to use with one

hand.

• Unlock pattern

: allows you to adjust the scale of the unlock

pattern for use with one hand.

• Learn about on-handed operation

: provides more information

about using one-handed operation.

DRAFT - Internal Use Only

118

Touch key light duration

This option allows you to adjust the delay before the Touch

key light automatically turns off.

1. From the Home screen, tap ➔

Settings

➔

settings

(Personalization) ➔

Touch key light duration

2. Tap one of the Touch key light durations.

Data Usage

From this screen you can view your Mobile data usage and

turn your Mobile data capability On or Off.

1. From the Home screen, tap ➔

Settings

➔

Data

usage

2. Tap

Mobile data

to activate Mobile data usage.

3. Tap

Set mobile data limit

to set a data limit.

4. Touch and drag the red limit bar to the GB limit that you

desire.

5. Tap the

Data usage cycle

drop-down menu and select a

date.

The data usage displays as a visual (chart) and also

displays a list of each application with a breakdown of

how much data was used per application.

Note:

Data is measured by your device. Your service provider

may account for data usage differently.

6. Press to display additional options. Tap to activate.

• Data roaming

: enables Data roaming on your device.

• Restrict background data

: restricts some apps and services

from working unless you are connected to a Wi-Fi network.

•Show Wi-Fi usage

: displays a Wi-Fi tab that shows Wi-Fi

usage.

More... Settings

This tab displays additional wireless and network

information.



From the Home screen, touch

➔

Settings

➔

More settings

Options display for Airplane mode, Mobile networks,

Tethering and portable hotspot, NFC, Android Beam,

S Beam, Wi-Fi Direct, AllShare Cast, VPN, Kies via

Wi-Fi, and Nearby devices.

DRAFT - Internal Use Only

Changing Your Settings 119

Airplane mode

When airplane mode is enabled, all your phone’s wireless

connections are disabled, and you cannot make or receive

calls [except for Emergency (E911) calls] or messages. You

can, however, make Wi-Fi and Bluetooth connections.

While in airplane mode, you can use other features of your

phone, such as playing music, watching videos, or using

other applications.

1. From the Home screen, touch

➔

Settings

➔

More settings

. The

Wireless and networks

displays.

2. Touch

Airplane mode

to enable or disable airplane

mode.

A check mark displays to indicate activation.

Mobile networks

Before you use applications such as Google Maps and find

your location or search for places of interest, you must

enable the Mobile networks options.

Tethering

Use Tethering to share your phone’s internet connection with

a computer that connects to your device via USB cable, or by

Bluetooth.

For more information about connecting computers to your

phone via Tethering, see “Tethering” on page 154.

1. From the Home screen, touch

➔

Settings

➔

More settings

➔

Tethering and portable hotspot

. The

Tethering and portable hotspot

screen displays.

2. Choose a tethering method:

• USB tethering

: Connect the computer to the phone via USB

cable, then touch

USB Tethering

to turn tethering On or Off. A

check mark displays to indicate activation.

• Bluetooth tethering

: Pair your phone with the computer via

Bluetooth. Consult the computer’s documentation for more

information about configuring your computer to pair via

Bluetooth. Touch

Bluetooth Tethering

to turn tethering On or

Off. A check mark displays to indicate activation.

Note:

Using Tethering requires a subscription to your Wireless

Provider’s mobile data service.

DRAFT - Internal Use Only

120

Portable Wi-Fi Hotspot

Use Portable Wi-Fi Hotspot to share your phone’s internet

connection with up to 5 other devices, through Wi-Fi.

You can control whether devices connect to your Portable Wi-

Fi Hotspot with the Allowed device list.

For more information about using your phone as a mobile

hotspot, see “Portable Wi-Fi Hotspot” on page 149.

Note:

Using Portable Wi-Fi Hotspot requires a subscription to

data service. For more information, contact your

Wireless Provider.

Using your phone as a mobile hotspot consumes battery

power and uses data service. While Portable Wi-Fi

Hotspot is active, your phone’s applications use your

Wireless Provider’s data service. Roaming while using

your phone as a mobile hotspot incurs extra data

charges.

Turning Portable Wi-Fi Hotspot On or Off

1. From the Home screen, touch

➔

Settings

➔

Tethering and portable hotspot

➔

Portable Wi-Fi hotspot

2. Touch

Portable Wi-Fi Hotspot

and follow the

prompts to turn Portable Wi-Fi Hotspot On, or touch

Portable Wi-Fi Hotspot

to turn Portable Wi-Fi

Hotspot Off.

Note:

Using your phone as a mobile hotspot consumes battery

power and uses data service. While Portable Wi-Fi

Hotspot is active, your phone’s applications use your

Wireless Provider’s data service. Roaming while using

your phone as a mobile hotspot incurs extra data

charges.

Configuring Portable Wi-Fi Hotspot

1. From the Home screen, touch

➔

Settings

➔

More settings

➔

Tethering and portable hotspot

➔

Portable Wi-Fi hotspot

. The

Portable Wi-Fi hotspot

screen displays.

2. Touch

Configure

to access the following options:

• Network SSID

: View and change the name of your Mobile

Hotspot.

DRAFT - Internal Use Only

Changing Your Settings 121

• Hide my device

: When enabled, your Portable Wi-Fi Hotspot is

not visible to other Wi-Fi devices during a scan. Other devices

can still connect to your Portable Wi-Fi Hotspot, but must set

up the connection manually with your Network SSID and

Password.

•Security

: Choose the security level for your Portable Wi-Fi

Hotspot.

•Password

: If you choose a security level that uses a password,

enter the password. By default, the password is your mobile

telephone number.

• Show password

: Enable to make the Password field visible.

• Show advanced options

: Enable to access advanced options,

including Broadcast channel, to specify the channel your device

uses for Portable Wi-Fi Hotspot.

Allowed Device List

Control whether devices connect to your Portable Wi-Fi

Hotspot with the Allowed device list. After you add devices to

the list, they can scan for your device and connect using your

device’s Wi-Fi hotspot name (SSID) and password.

Note:

Using your phone as a mobile hotspot consumes battery

power and uses data service. While Portable Wi-Fi

Hotspot is active, your phone’s applications use your

Wireless Provider’s data service. Roaming while using

your phone as a mobile hotspot incurs extra data

charges.

1. From the Home screen, touch

➔

Settings

➔

Tethering and portable hotspot

➔

Portable Wi-Fi hotspot

The

Portable Wi-Fi hotspot

screen displays.

2. Touch

Allowed devices

, then tap the in the upper,

right corner of the screen and enter a device name and

MAC address.

3. Touch

to add the device to the

Allowed devices

list.

Tip:

For information about connecting to your Portable Wi-Fi

Hotspot, see “Connecting a Device via Portable Wi-Fi

Hotspot” on page 150.

DRAFT - Internal Use Only

122

NFC

Use NFC (Near Field Communication) to share information

between your phone and another NFC device by touching the

devices together, typically back-to-back.

For more information about sharing information with NFC,

see “Android Beam” on page 122 and “S Beam” on page

122.

1. From the Home screen, touch

➔

Settings

➔

More settings

2. Touch

NFC

to turn NFC On or Off.

Note:

NFC must be turned on to use Android Beam or S Beam.

Android Beam

You can bean application content to another NFC-capable

device by holding the devices close together. You can beam

browser pages, YouTube videos, contacts, and more. Just tap

the devices back-to-back, then tap your screen. The

application determines what beams.

Android Beam works in the background. Use the sharing

options from your favorite apps to select content to share via

Android Beam.

1. From the Home screen, touch

➔

Settings

➔

More settings

2. Touch

NFC

to enable NFC. NFC must be enabled to use

Android Beam.

A check mark displays to indicate activation.

3. Touch

Android Beam

4. Touch to turn Android Beam On, or touch

to turn Android Beam Off.

S Beam

S Beam uses your phone’s NFC (Near Field Communication)

to send, or “beam”, content to other NFC and Wi-Fi Direct

devices, by holding the devices close together.

S Beam works in the background. To share pictures or videos

from Gallery, videos from Video player, or songs from Music

player. Just bring the devices together (typically back-to-

back), then tap the screen.

Turning S Beam On or Off

1. From the Home screen, touch

➔

Settings

➔

More settings

2. Touch

NFC

to enable NFC. NFC must be enabled to use

S Beam.

A check mark displays to indicate activation.

DRAFT - Internal Use Only

Changing Your Settings 123

3. Touch

S Beam

to turn S Beam On, or

touch

SBeam

to turn S Beam Off.

Wi-Fi Direct

Wi-Fi Direct allows devices to connect to each other directly

via Wi-Fi, without a Wi-Fi network or hotspot, and without

having to set up the connection. For example, some printers

support Wi-Fi Direct, and you could print from your phone via

Wi-Fi Direct.

Turning Wi-Fi Direct On or Off

1. From the Home screen, touch

➔

Settings

➔

More settings

2. Touch

Wi-Fi Direct

to turn Wi-Fi Direct On, or

touch

Wi-Fi Direct

to turn Wi-Fi Direct Off.

The

Wi-Fi Direct

screen displays, and your phone scans

for available Wi-Fi Direct devices and lists them under

Available devices

Configuring Wi-Fi Direct

1. From the Home screen, touch

➔

Settings

➔

More settings

2. Touch

Wi-Fi Direct

to configure settings:

When you turn on Wi-Fi Direct, your device

automatically searches for available Wi-Fi Direct

devices nearby.

3. Touch

Scan

to start a new search.

4. After scanning for nearby devices, touch a device to

connect to it, then follow the prompts to complete the

connection.

– or –

Touch

Multi-connect

to create a connection to devices

that support multi-connect. Touch

Scan

to search for

available mult-connect devices, then touch the devices

you want to connect to and follow the prompts to

complete the connection.

AllShare Cast

AllShare Cast lets your phone share the contents of its

display with other Digital Living Network Alliance (DLNA)

certified devices, such as Smart televisions.

For more information, refer to “AllShare Cast” on page 157.

Note:

To view more information about DLNA certified products

visit

http://www.dlna.org/home

DRAFT - Internal Use Only

124

VPN

Set up and manage Virtual Private Networks (VPNs). For

more information about using VPNs, see “VPN” on page 155

Adding a VPN

1. Set a screen unlock pattern, PIN, or password before

using credential storage.

2. From the Home screen, touch

➔

Settings

➔

More settings

➔

VPN

3. Touch

Add VPN network

to set up a connection to a

VPN, using the following settings:

•Name

: Enter a name for the VPN connection.

•Type

: Choose the type of VPN from the pull-down menu.

• Server address

: Enter the IP address of the VPN server.

• PPP encryption (MPPE)

: Touch to enable or disable

encryption.

• Show advanced options

: Touch to show more options.

Available options depend on the type of VPN you are adding.

Note:

You must enable at least Pattern security before setting

up a VPN. If you have not yet enabled security, you’ll be

prompted to do so the first time you launch VPN

settings.

Sound Settings

Sound



From the Home screen, touch

➔

Settings

➔

Sound

. The

Sound

menu displays.

Sound Profiles

Use Silent modes to temporarily silence the sounds your

phone makes, except for media playback and alarms, or

replace them with vibration.

1. From the Home screen, touch

➔

Settings

➔

Sound

➔

Sound profiles

2. Select a profile:

•Sound

: Use your sound settings.

•Vibrate

: Enable Vibrate mode, to replace sounds with vibration.

You can also enable Vibrate mode by pressing the Volume Key

down from the Home screen, by pressing and holding the # key

on the Phone keypad, or from the Notifications panel.

DRAFT - Internal Use Only

Changing Your Settings 125

•Mute

: Enable Mute mode, to silence all sounds.

Tip:

You can easily enable Silent mode by pressing and holding

the Power/Lock Key, then selecting Silent mode from the

Device options menu.

Silent mode is also available from the Notifications panel.

Volume

Set the system volume level, and set default volume for call

ringtones, notifications, and media playback.

Note:

You can also set System volume from the Home screen

by pressing the

Volume

key Up or Down.

1. From the Home screen, touch

➔

Settings

➔

Sound

➔

Volume

. The

Volume

menu displays.

2. Touch and drag the sliders for:

• Music, video, games, and other media

: Set the default

volume level for audio playback. You can also adjust volume

from this default inside the apps.

•Ringtone

: Set the volume for incoming call ringtones.

• Notifications

: Set the volume for notifications, such as new

messages and event reminders.

• System

: Set the volume for all other system sounds, such as

keytones played for screen touches. You can control whether

tones play for screen touches with other sound settings.

3. Touch

to save your settings.

Vibration intensity

Set the level for vibration to accompany ringtones and

notifications.

1. From the Home screen, touch

➔

Settings

➔

Sound

➔

Vibration intensity

. The

Vibration intensity

menu displays.

2. Touch and drag the sliders for:

• Incoming call

: Set the vibration level for incoming call

ringtones.

• Notification

: Set the vibration level for notifications, such as

new messages and event reminders.

• Haptic feedback

: Set the vibration level vibrations to

accompany screen touches.

3. Touch

to save your settings.

DRAFT - Internal Use Only

126

Device ringtone

This option allows you to set the ringtone.

1. From the Home screen, tap ➔

Settings

➔

Sound

➔

Device ringtone

2. Tap a ringtone and tap

Device vibration

This option allows you to set your phone to vibrate and ring.

1. From the Home screen, tap ➔

Settings

➔

Sound

➔

Device vibration

2. Select a vibration pattern and tap

Default notifications

This option allows you to set the ringtone that will sound for

notifications and alarms.

1. From the Home screen, tap ➔

Settings

➔

Sound

➔

Default

notifications

2. Tap a ringtone and tap

Sound and vibration

This option allows you to enable all sounds and vibrations.

1. From the Home screen, tap ➔

Settings

➔

Sound

2. Tap

Sound and vibration

to enable the feature.

System Tone Settings

The System tone settings are used when you use the dialing

pad, make a screen selection, lock your screen, or tap the

screen.

1. From the Home screen, tap ➔

Settings

➔

Sound

2. Tap any of the following options to activate the feature:

•Keytones

: makes a sound when you tap a key on the

keyboard.

• Touch sounds

: makes a sound when you touch the screen.

• Screen lock sound

: makes a sound when your screen is

locked or unlocked.

• Haptic feedback

: makes a vibration when you tap soft keys

and on certain UI interactions.

•Emergency tone

: sounds a tone, or vibrates when you receive

an emergency message.

DRAFT - Internal Use Only

Changing Your Settings 127

Display Settings

In this menu, you can change various settings for the display.



From the Home screen, tap ➔

Settings

➔

Display

The following options display:

•Brightness

: configures the LCD Brightness levels. Tap

Automatic brightness to allow the phone to self-adjust or drag

the slider and tap OK.

• Screen timeout

: adjusts the delay time before the screen

automatically turns off. Selections are: 15 seconds, 30

seconds, 1 minute, 2 minutes, 5 minutes, and 10 minutes.

•Smart stay

: disables the screen timeout if your phone detects

that your face is watching the screen.

• Smart rotation

: disables the auto screen rotation by checking

the orientation of your face and the device.

• Auto-rotate screen

: allows you to switch the display

orientation automatically when you rotate the phone.

• Key backlight duration

: adjusts the delay before the key

backlight automatically turns off.

• Font style

: allows you to set the font style that your phone will

use. You can also tap Get fonts online to choose from a wider

selection.

•Font size

: allows you to select which size of font is displayed.

• Screen mode

: allows you to select from several different color

modes.

• Auto adjust screen tone

: allows you to save power because

the phone analyzes the displayed screen image and adjusts the

LCD brightness.

• Display battery percentage

: allows you to see the battery

charge percentage next to the battery charge icon at the top of

the display.

• Gyroscope calibration

: maintains the stability and

performance of the gyroscope for applications that rely on the

gyroscope or motion sensors on the phone (such as when the

phone toggles from portrait to landscape mode automatically

while viewing a web page).

Wallpaper

You can change the Wallpaper (background) of your home

screens by following these steps:

1. From any Home screen, touch and hold on an empty

area of the screen.

The

Home screen

window displays.

2. Tap

Set wallpaper for

DRAFT - Internal Use Only

128

3. Select the location where you would like to change the

wallpaper. Tap

Home screen

Lock screen

, or

Home and

lock screens

4. Tap one of the following options:

• Gallery

: select a wallpaper from photographs you have taken

with your camera.

• Live wallpapers

: select an animated wallpaper. This option is

not available for the Lock screen option.

• Wallpapers

: select from many still-life wallpapers.

5. Select a wallpaper and tap

Set wallpaper

Done

, or

Cancel

LED indicator

This option allows you to turn on your LED lights for charging,

missed events, and incoming notifications. The light will turn

on by default unless you turn them off.

1. From the Home screen, tap ➔

Settings

➔

settings

(Personalization) ➔

LED indicator

2. Tap the following LED indicator options to turn them on

or off:

•Charging

: LED lights up when the device is connected to the

charger.

•Low battery

: LED lights up when the battery level is low.

• Missed event

: LED lights up when you have missed calls,

messages, or application events.

• Voice recording

: LED lights up when you create a voice

recording. The LED only lights when the screen is off.

Motion Settings

The Motion settings allow you to set up various Motion

activation services. For more information on using gestures,

see “Using Gestures” on page 32.

1. From the Home screen, tap ➔

Settings

➔

Motion

2. Tap the ON/OFF icon at the top of your

screen to activate Motion.

3. The following options are available. Tap an option to

activate the feature. A checkmark displays.

• Quick glance

: Once enable, you can check key information

at a glance by reaching towards your device.

•Direct call

: Once enabled, the device will dial the currently

displayed on-screen Contact entry as soon as you place the

device to your ear.

•Smart alert

: Once enabled, pickup the device to be alerted and

notified of you have missed any calls or messages.

DRAFT - Internal Use Only

Changing Your Settings 129

• Double tap to top

: Once enabled, double tap the top of the

device to be taken to the top of the current on-screen list.

• Tilt to zoom

: Once enabled, you must be on a screen where

content can be zoomed. In a single motion, touch and hold two

points on the display then tilt the tilt the device back and forth to

zoom in or out.

• Pan to move icon

: Once enabled, touch and hold a desired

application shortcut icon or widget on the screen. Once it

detaches, move the device left or right to migrate it to a new

location.

• Pan to browse images

Once enabled, touch and hold a

desired on-screen image to pan around it. Move the device left

or right to pan vertically or up and down to pan horizontally

around the large on-screen image.

• Shake to update

: Once enabled, shake your device to rescan

for Bluetooth devices, rescan for Wi-Fi devices, Refresh a Web

page, etc.

• Turn over to mute/pause

: Once enabled, mute incoming calls

and any playing sounds by turning the device display down on

a surface. This is the opposite of the Pickup to be Notified

Gesture.

• Advanced settings

: allows you to access additional settings

for Quick glance, Gyroscope calibration, Tilt to zoom, Pan to

move icon, and Pan to browse images.

• Learn about motions

: provides additional help on using the

different motions.

• Palm swipe to capture

: Once enabled, you can capture any

on-screen information swiping across the screen. In a single

motion, press the side of your hand on the screen and swipe

form left to right. The image is then copied to the clipboard.

• Palm touch to mute/pause

: Once enabled, you can pause any

on-screen video or mute any current sound by simply covering

the screen with your hand. Once you remove your hand from

the screen, the device goes back to normal by either continuing

to play the current video or unmuting the current sound.

• Learn about hand motions

: provides additional help on the

hand motions such as Palm swipe to capture and Palm touch

to mute/pause.

DRAFT - Internal Use Only

130

Dormant Mode

Dormant mode allows you to disable calls, notifications, and

features on your phone.

1. From the Home screen, tap ➔

Settings

➔

settings

(Personalization) ➔

Dormant mode

2. Tap the

OFF / ON

icon to turn Dormant mode on

3. Select the features you want to disable.

4. Tap Always to always disable the selected features or

tap the

From

and

fields to set a time range.

Power Saving

Power Saving Mode allows you to manage your phone to

conserve power.

1. From the Home screen, tap ➔

Settings

➔

Power

saving

2. Tap the

OFF / ON

icon next to

Power saving

to turn

Power saving mode on .

3. Tap the following options to conserve power:

• CPU power saving

: allows you to limit the maximum

performance of the CPU.

• Screen power saving

: allows you to lower the screen power

level.

• Background color

: allows you to change the background color

on email and internet to save power.

• Turn off haptic feedback

: allows you to turn off vibration when

you tap or touch the screen.

4. Tap

Learn about power saving

to learn about various

ways to conserve battery power.

Storage

From this menu you can view the memory allocation for the

memory card and USB as well as mount or unmount the SD

card.

For more information about mounting or unmounting the SD

card, see “Memory Card” on page 44.

To view the memory allocation for your external SD card:



From the Home screen, tap ➔ Settings ➔

Storage.The available memory displays under the

Total

space

and

Available

space

headings for both Device

memory and SD card.

DRAFT - Internal Use Only

Changing Your Settings 131

SD card



Tap

Unmount SD card

to unmount your SD card so that

you can safely remove it, then tap

– or –

1. Tap

Format SD card

to re-format your SD card. This will

delete all data on your SD card including music, videos,

and photos.

2. Tap

Format SD card

again.

3. Tap

Delete all

to continue or press to cancel.

Note:

The

Format SD card

option is only available when your

SD card is mounted.

Battery

See how much battery power is used for device activities.

1. From a Home screen, tap ➔ Settings ➔ Battery.

The battery level displays in percentage. The amount

of time the battery was used also displays. Battery

usage displays in percentages per application.

2. Tap

Screen

Cell standby

Android System

Android OS

or any other listed application to view how it is

affecting battery use.

Note:

Other applications may be running that affect battery

use.

Application Manager

You can download and install applications from Play Store or

create applications using the Android SDK and install them

on your device. Use Application manager settings to manage

applications.

Warning!

Because this device can be configured with system

software not provided by or supported by Google or

any other company, end-users operate these devices

at their own risk.

Memory Usage

See how memory is being used by Downloaded or Running

applications.

1. From a Home screen, tap ➔ Settings ➔

Application manager

DRAFT - Internal Use Only

132

2. Tap

Downloaded

Running

, or

All

to display memory

usage for that category of applications.

The graph at the bottom of the Downloaded tab shows

used and free device memory. The graph at the bottom

of the Running tab shows used and free RAM.

Downloaded

Displays apps you have downloaded onto your device.

1. From a Home screen, tap ➔ Settings ➔

Application manager

2. Tap the

Downloaded

tab to view a list of all the

downloaded applications on your device.

3. To switch the order of the lists displayed in the

Downloaded tabs, press ➔

Sort by size

Sort by

name

4. Tap an application to view and update information

about the application, including memory usage, default

settings, and permissions.

Running Services

View and control services running on your device.

1. From a Home screen, tap ➔ Settings ➔

Application manager

2. Tap the

Running

tab. All the applications that are

currently running on the device display.

3. Tap

Show cached processes

to display all the cached

processes that are running. Tap

Show services in use

switch back.

4. Tap one of the applications to view application

information.

The following options display:

•Stop

: Stops the application from running on the device. This is

usually done prior to uninstalling the application.

Warning!

Not all services can be stopped. Stopping services

may have undesirable consequences on the

application or Android System.

•Report

: Report failure and other application information.

Note:

Options vary by application.

DRAFT - Internal Use Only

Changing Your Settings 133

Accounts and Sync

This menu allows you to set up, manage, and synchronize

accounts, including your Google and email accounts.

Adding an Account

1. From a Home screen, tap ➔ Settings ➔

Add

account

2. Tap one of the account types.

3. Use the keyboard and follow the prompts to enter your

credentials and set up the account.

A green circle displays next to the account type once

you have created an account. Your email account will

also be displayed in the

Accounts

section of the main

Settings menu.

Removing an Account

Important!

Removing an account also deletes all of its

messages, contacts, and other data from the

device.

1. From a Home screen, tap ➔ Settings.

2. Tap the account which is located in the

Accounts

section.

3. Tap the account name.

4. Tap

Remove account

, then tap

Remove

account

at the

prompt to remove the account and delete all its

messages, contacts, and other data.

Synchronizing Accounts

Select the items you want to synchronize on your account

such as Books, Calendar, Contacts, and more.

1. From a Home screen, tap ➔ Settings.

2. Tap the account which is located in the

Accounts

section.

3. Tap the account name.

4. Tap

Sync now

to synchronize your account or tap

Sync

all

to synchronize all your accounts. Tap

Cancel sync

stop the synchronization.

5. Tap

Settings

to access your account settings.

Location Services

The Location services settings allow you to set up how the

phone determines your location and the sensor settings for

your phone.

1. From the Home screen, tap ➔

Settings

➔

settings

➔

Location services

DRAFT - Internal Use Only

134

2. Tap any of the following options to activate the service:

• Use wireless networks

: allows applications to use data from

mobile networks and Wi-Fi to help determine your location.

• Use GPS satellites

: allows applications to use GPS to pinpoint

your location.

• Location and Google search

: allows Google to use your

location data for improved search results and other services.

Security Settings

Screen security

Choose settings for locking and unlocking your phone.

1. From the Home screen, tap ➔

Settings

➔

Lock

screen

2. Tap

Screen lock

for these options:

•Swipe

: Swipe the screen to unlock it.

•Motion

: While tapping and holding the screen, tilt the device

forward to unlock.

• Face unlock

: Look at your phone to unlock it.

• Face and voice

: Look at your phone and speak to unlock.

• Pattern

: A screen unlock pattern is a touch gesture you create

and use to unlock your device. Follow the prompts to create or

change your screen unlock pattern.

•PIN

: Select a PIN to use for unlocking the screen.

• Password

: Create a password for unlocking the screen.

•None

: No pattern, PIN, or password is required. The screen will

never lock.

Lock screen options

Activate or deactivates various Unlock screen functions.

Note:

The Lock screen options are only available when the

Screen lock

option is set to

Swipe

Motion

1. From the Home screen, tap ➔

Settings

➔

Lock

screen

➔

Lock screen options

2. The following options are available:

•Shortcuts

sets shortcuts to display at the bottom of the Lock

screen.

• Information ticker

sets the news and stock information ticker

to display across the bottom of the Lock screen.

• Camera quick access

provides you with quick access to the

camera function from the Lock screen. When this option has

been activated, touch and hold the lock screen while rotating

the device to the landscape position then release the screen.

DRAFT - Internal Use Only

Changing Your Settings 135

•Clock

allows you to display the digital clock while the Lock

screen is active. Enabled by default.

•Dual clock

displays a set of dual digital clock on the Lock

screen while you are traveling. Tap the entry to set your home

city. This time zone then becomes the time used by one of

these on-screen clocks.

• Weather

displays the current area weather on the Lock screen.

Tap and set both the temperature units (F or C) and a refresh

time.

• Ripple effect

activates/deactivates the ripple effect on the lock

screen when you tap it.

•Help text

shows help information on the Lock screen.

• Wake up in lock screen

requires that you say a command to

wake-up S Voice.

•Set wake-up command

designates your S Voice wake-up

commands. Tap Wake-up S Voice and follow the on-screen

prompts to create a new verbal command.

Note:

These options vary depending on the selected Lock

settings.

Owner information

This option allows you to show owner information on the lock

screen. You can also enter text to display on the lock screen.

1. From the Home screen, tap ➔

Settings

➔

Lock

screen

➔

Owner information

2. Tap the

Show owner info on lock screen

checkbox if you

want your owner information displayed.

3. Enter text that you would like displayed on your

lockscreen and tap

Encryption

To require a numeric PIN or password to decrypt your phone

each time you power it on or encrypt the data on your SD

card each time it is connected:

1. From the Home screen, tap ➔

Settings

➔

settings

(System) ➔

Security

2. Tap

Encrypt device

. For more information, read the

displayed help screen.

3. Tap

Encrypt external SD card

to enable the encryption

on SD card data that requires a password be entered

each time the microSD card is connected.

DRAFT - Internal Use Only

136

Tip:

Make sure your battery is charged more than 80 percent.

Encryption may take an hour or more.

Passwords

When enabled, password characters display briefly as you

touch them while entering passwords.

1. From the Home screen, tap ➔

Settings

➔

settings

(System) ➔

Security

2. Tap

Make passwords visible

to nable or disable the

display of password characters.

Device Administration

The Device Administration feature allows you to select one or

more administration applications that control your device for

security purposes (for example, if your phone is lost of

stolen). These applications enforce remote or local device

security policies.

Some of the features a device administration application

might control are:

•

Setting the number of failed password attempts before the

device is restored to factory settings.

•

Automatically locking the device.

•

Restoring factory settings on the device.

Note:

If a device uses multiple enabled administration

applications, the strictest policy is enforced.

1. From the Home screen, tap ➔

Settings

➔

settings

(System) ➔

Security

2. Tap

Device administrators

3. Select a device administrator and follow the prompts. If

no device administrators are listed, you can download

them from the Play Store.

Unknown sources

This feature allows you to download and install non-Market

applications.

1. From the Home screen, tap ➔

Settings

➔

settings

(System) ➔

Security

2. Tap

Unknown sources

A check mark is displayed to indicate it is active.

Warning!

Enabling this option causes your phone and personal

data to be more vulnerable to attack by applications

from unknown sources.

DRAFT - Internal Use Only

Changing Your Settings 137

Credential Storage

Trusted Credentials

If a certificate authority (CA) certificate gets compromised or

for some other reason you do not trust it, you can disable or

remove it.

1. From the Home screen, tap ➔

Settings

➔

settings

(System) ➔

Security

2. Tap

Trusted credentials

The trusted credentials screen has two tabs:

• System

: Displays CA certificates that are permanently installed

in the ROM of your device.

•User

: Displays any CA certificates that you installed, for

example, in the process of installing a client certificate.

3. Tap a CA certificate to examine its details.

A scrolling screen displays the details.

4. Scroll to the bottom of the details screen and tap

Disable

to disable a System certificate or

Remove

remove a User certificate.

Caution!

When you disable a system CA certificate, the

Disable

button changes to

Enable

, so you can enable the

certificate again, if necessary. When you remove a

user-installed CA certificate, it is permanently

deleted and must be re-installed, if needed.

5. Tap

to return to the certificate list.

When enabled, a check mark displays in the check

box.

Install from device storage

Install encrypted certificates from an installed memory card.

Note:

You must have installed a memory card containing

encrypted certificates to use this feature.

1. From the Home screen, tap ➔

Settings

➔

settings

(System) ➔

Security

2. Tap

Install from device storage

, then choose a

certificate and follow the prompts to install.

DRAFT - Internal Use Only

138

Clear credentials

Clear stored credentials.

Note:

This setting only displays if you installed encrypted

certificates.

1. From the Home screen, tap ➔

Settings

➔

settings

(System) ➔

Security

2. Tap

Clear credentials

to remove all certificates.

Language and Input

This menu allows you to configure the language in which to

display the menus. You can also set onscreen keyboard

options.

Language

You can change the language used by your device by

following these steps:

1. From the Home screen, tap ➔

Settings

➔

settings

(System) ➔

Language and input

➔

Language

2. Tap a language from the list.

Keyboards and Input Methods

You can change the keyboard used by your device by

following these steps:

1. From the Home screen, tap ➔

Settings

➔

settings

(System) ➔

Language and input

2. Tap

Default

and select a keyboard.

Select Samsung keyboard.

3. Tap

Set up input methods

4. Tap the icon next to the input method that you

would like to configure the settings for.

5. Based on your selection of input method, the

appropriate settings displays and are explained below.

Google voice typing settings

From this menu you can set Samsung keyboard options.

1. From the Home screen, tap ➔

Settings

➔

settings

(System) ➔

Language and input

2. Tap the icon next to

Google voice typing

3. The following options are available:

• Choose input languages

: tap on a language that you want to

input. Select

Automatic

to use the local language or select a

language from the list.

DRAFT - Internal Use Only

Changing Your Settings 139

• Block offensive words

tap to enable the blocking of

recognized offensive words from the results of your voice-input

Google typing.

• Download offline speech recognition

: Enables voice input

while offline.

Samsung Keyboard settings

From this menu you can set Samsung keyboard options.

1. From the Home screen, tap ➔

Settings

➔

settings

(System) ➔

Language and input

2. Tap the icon next to

Samsung keyboard

• Portrait keypad types

allows you to choose a keypad

configuration (Qwerty [default] or 3x4 Keyboard).

• Input languages

sets the input language. Tap a language from

the available list. The keyboard is updated to the selected

language.

• Predictive text

enables predictive text entry mode. This must

be enabled to gain access to the advanced settings. Touch and

hold to access the advanced settings.

•T9 Trace

like using Swype, allows you to type words by swiping

between on-screen keys.

• Handwriting

enables the device to recognize on-screen

handwriting and convert it to text.

• Voice input

activates the Voice input feature. This is an

experimental feature that uses Google’s networked speech

recognition application.

•Auto capitalization

automatically capitalizes the first letter of

the first word in each sentence (standard English style).

• Auto-punctuate

automatically inserts a full stop in a sentence

by tapping the space bar twice when using the on-screen

QWERTY keyboard.

• Character preview

provides an automatic preview of the

current character selection in the text string. This is helpful

when multiple characters are available on one key.

• Key-tap vibration

enables vibration feedback when you tap an

on-screen key.

•Key-tap sound

enables auditory feedback when you tap an

on-screen key.

•Tutorial

launches a brief on-screen tutorial covering the main

concepts related to the Samsung keyboard.

• Reset settings

resets the keyboard settings back to their

original configuration.

DRAFT - Internal Use Only

140

Predictive Text Settings

From this menu you can set Predictive Text settings.

1. From the Home screen, tap ➔

Settings

➔

settings

(System) ➔

Language and input

2. Tap the icon next to

Samsung keyboard

3. Tap

Predictive text

4. Tap the

Word completion

field to enable word

completion. Your phone will predict how to complete

the word you have started.

5. Tap the

Word completion point

field to set how many

letters should be entered before a prediction is made.

6. Tap the

Spell correction

field. This option corrects

typographical errors by selecting from a list of possible

words that reflect the characters of the keys you

tapped as well as the characters of nearby keys.

7. Tap the

Next word prediction

field to enable word

prediction for the next word.

8. Tap the

Auto-append

field to automatically add

predictions to the word you are typing.

9. Tap the

Auto-substitution

field to automatically replace

words that you are typing. This option will help for

accidental misspellings.

10. Tap the

Regional correction

field. This option sets the

device to automatically correct mistyped words

according to normal spelling for your region.

11. Tap the

Recapture

field. This option sets the device to

re-display the word suggestion list when you select the

wrong word from the list.

12. To add a new word to the Predictive text dictionary:

Tap the

My word list

field, then tap . Enter the new

word, then tap

Done

to save.

13. To add words to substitute (for example youve

becomes you’ve) tap

Auto substitution list

14. A list of substitutions is displayed. If you don’t see the

substitution you want, tap , and then input the

Shortcut word and Substitution word. Then tap

Done

save.

DRAFT - Internal Use Only

Changing Your Settings 141

Voice Commands for Applications

This setting activates voice commands to control your

device.

1. From the Home screen, tap ➔

Settings

➔

settings

(System) ➔

Language and input

2. Tap the Voice cmd for apps OFF/ON toggle to use voice

commands in order to control the device.

Voice Settings

This menu allows you to set the speech settings for Voice

input.

1. From the Home screen, tap ➔

Settings

➔

Voice

2. Tap

S Voice settings

to access the settings associated

with the S Voice application.

3. Tap

Voice recognizer

and select either

Google

Samsung powered by Vlingo

as your Voice recognition

engine.

4. Tap

Voice search

to configure:

• Language

: Choose a language for your voice input.

• SafeSearch

: Set the sensitivity for filtering of explicit images

from the results of your voice-input Google searches.

• Block offensive words

: Enable or disable blocking of

recognized offensive words from the results of your voice-input

Google searches.

• Hotword detection

: Enable to being able to launch voice

search by saying the word “Google”.

• Download offline speech recognition

: Enables voice input

while offline.

5. Tap

Text-to-speech output

and select

Google Text-to-

speech Engine

Samsung TTS

6. Tap next to the preferred TTS engine configure the

following settings:

• Language

: allows you to set the language for spoken text.

• Settings for Google Text-to-speech Engine

: allows you to

view Open Source Licenses.

• Install voice data

: allows you to install voice data for speech

synthesis.

7. From the

Text-to speech output

screen, scroll down to

access the following options:

• Speech rate

: Set the speed at which the text is spoken.

• Listen to an example

: Play a sample of speech synthesis

(available if voice data is installed).

DRAFT - Internal Use Only

142

8. Tap the ON/OFF icon next to

Driving mode

turn it on and enable incoming calls and notifications to

be read out automatically.

Mouse/trackpad

This option sets your Pointer speed.

1. From the Home screen, tap ➔

Settings

➔

settings

(System) ➔

Language and input

2. Tap

Pointer speed

then drag the slider to the right to go

faster or to the left to go slower.

3. Tap

to save your setting.

Back up and reset

The Back up and reset option allows you to back up your

data, back up accounts, automatically restore your phone,

and reset your phone settings to the factory settings.

Back Up My Data

By setting this option, the Google server will back up all of

your settings and data.

1. From the Home screen, tap ➔

Settings

➔

settings

(System) ➔

Backup and reset

2. Tap

Back up my data

to enable or disable back up of

application data, WI-Fi passwords, and other settings

to the Google server.

Backup Account

If you have enabled the

Back up my data

option, then the

Backup account

option is available.

1. From the Home screen, tap ➔

Settings

➔

settings

(System) ➔

Backup and reset

2. Tap

Backup account

and tap your Google Gmail account

or tap

Add account

to set your Google Gmail account to

be backed up to the Google server.

Automatic Restore

By setting this option, when you reinstall an application, all of

your backed up settings and data will be restored.

1. From the Home screen, tap ➔

Settings

➔

settings

(System) ➔

Backup and reset

2. Tap

Automatic restore

to enable or disable automatic

restoration of settings from the Google server.

DRAFT - Internal Use Only

Changing Your Settings 143

Factory Data Reset

From this menu you can reset your phone and sound settings

to the factory default settings.

1. From the Home screen, tap ➔

Settings

➔

settings

(System) ➔

Backup and reset

2. Tap

Factory data reset

The Factory data reset screen displays reset

information.

3. Tap

Reset device

, then follow the prompts to perform

the reset.

Warning!

Performing a Factory data reset will erase all data

from your phone and internal SD card, including your

Google account, system and application data and

settings, and downloaded applications. It will not

erase current system software, bundled

applications, and external SD card files such as

music and photos.

Pen Settings

This menu allows you to customize settings for the S Pen.

1. From the Home screen, tap ➔

Settings

➔

Pen

2. The following options are available:

•Dominant hand

: allows you to set your phone to Left handed

or Right handed.

• Pen attach/detach sound

: allows you to select a sound to be

played whenever the pen is attached or detached.

• Battery saving

: disables the pen detection feature while the

pen is attached to save battery power.

•Hovering

: When the S pen tip is near the screen for a while,

the pen hovering feature will be provided.

• Missing pen alert

: sounds an alert and displays a pop-up

when you move the device without attaching the pen.

• S Pen help

: provides additional information about S Pen.

Accessory Settings

This menu allows you to select the Audio output mode when

using a car or desk dock.

1. From the Home screen, tap ➔

Settings

➔

Accessory

DRAFT - Internal Use Only

144

2. Tap

Contextual page

creates an accessory related

home screen when accessory event occurs.

3. Tap

Dock sound

to play sounds when inserting or

removing the phone from the dock.

4. Tap

Audio output mode

to use the external dock

speakers when the phone is docked.

5. Tap

Desk home screen display

to display the desk home

screen when the phone is docked.

6. Tap

Audio output

to set your Audio output to Stereo or

Surround.

Date and Time

This menu allows you to change the current time and date

displayed.

1. From the Home screen, tap ➔

Settings

➔

settings

(System) ➔

Date and time

2. Tap

Automatic date and time

to allow the network to set

the date and time.

3. Tap

Automatic time zone

to allow the network to set the

time zone.

Important!

Deactivate

Automatic date and time

to manually set

the rest of the options.

4. Tap

Set date

and tap the up and down arrows to set the

Month

Day

, and

Year

then tap

Set

5. Tap

Set time

and tap the up and down arrows to set the

Hour

Minute

, and

, then tap

Set

6. Tap

Select time zone

, then tap a time zone.

7. Optional: Tap

Use 24-hour format

. If this is not selected

the phone automatically uses a 12-hour format.

8. Tap

Select date format

and tap the date format type.

Accessibility

Accessibility services are special features to make using the

device easier for those with certain physical disabilities. Use

the Accessibility settings to activate these services.

Note:

You can download accessibility applications from Play

Store and manage their use here.

1. From the Home screen, tap ➔

Settings

➔

Accessibility

DRAFT - Internal Use Only

Changing Your Settings 145

2. Tap the

Auto-rotate screen

to automatically rotate the

screen from landscape to portrait when you rotate your

phone.

3. Tap the

Speak passwords

option to activate this feature

which reads out password information.

4. Tap the

Call answering/ending

option to be able to

accept incoming calls by pressing the home key or end

calls using the power key.

5. Tap the

Accessibility shortcut

option to allow the

accessibility shortcut under the device options to be

used by pressing and holding the power key.

6. Tap the

Screen timeout

option to timeout the

accessibility feature after a defined amount of time.

7. Tap the

TalkBack

option to activate the TalkBack

feature.

Note:

TalkBack, when installed and enabled, speaks feedback

to help blind and low-vision users.

Important!

TalkBack can collect all of the text you enter,

except passwords, including personal data and

credit card numbers. It may also log your user

interface interactions with the device.

8. Tap the

Font size

field to change the size of the fonts

used on the device in menus, options, etc. Choose

from: Tiny, Small, Normal, Large, or Huge.

9. Tap the

Negative colors

field to reverse the display of

on-screen colors from White text on a Black

background to Black text on a White background.

10. Tap

Enhance Web accessibility

if want to allow apps to

install scripts from Google that make their Web content

more accessible. Tap

Allow

11. Tap the

Sound balance

field and use the slider to set the

Left and Right balance when using a stereo device.

12. Tap the

Mono audio

field to enable stereo audio to be

compressed into a single mono audio stream for use

with a single earbud/earphone.

DRAFT - Internal Use Only

146

13. Tap the

Turn off all sounds

field to mute every sound

made by the device during taps, selections,

notifications, etc.

14. Tap the

Press and hold delay

field to select a time

interval for this action. Choose from: Short, Medium, or

Long.

Vision options



From the Home screen, touch

➔

Settings

➔

Accessibility

, under the

Vision

heading, touch the

check box next to each of the following options to

enable: (A check mark indicates activation.)

• Install Web scripts

: Does not allow / Allows apps to install

scripts from Google that make their Web content more

accessible.

• Negative colors

: Reverses the colors on the screen.

•Font size

: Set the font size for screen displays (Tiny, Small,

Normal, Large, Huge).

Hearing options



From the Home screen, touch

➔

Settings

➔

Accessibility

, under the

Hearing

heading, touch the

check box next to each of the following options to

enable: (A check mark indicates activation.)

•Mono audio

: Delivers monophonic sound to support listening

with a wired or Bluetooth headset with one earphone.

• Turn off all sounds

: Disables all sounds, including the voice

portion of calls.

Mobility option



From the

Accessibility

screen, under

Mobility

, touch the

following option:

• Tap and hold delay

: Select the length of time the phone

considers a screen touch before interpreting a touch as touch-

and-hold (Short, Medium, Long).

Developer Options

Use the Developer options to set options for application

development.

DRAFT - Internal Use Only

Changing Your Settings 147

USB Debugging

When enabled, allows debugging when the device is

attached to a PC by a USB cable.

Note:

This setting is used for development purposes.

1. From the Home screen, tap ➔

Settings

➔

settings

(System) ➔

Developer options

2. Tap

USB debugging

to enable or disable the setting.

When enabled, a check mark displays in the check

box.

Development device ID

The identification number for your device when using it as a

development tool displays in this field.

Allow mock locations

This setting is used by developers when developing

location-based applications.



From the Home screen, touch

➔

Settings

➔

Developer options

➔

Allow mock locations

to enable

or disable the setting.

A check mark indicates activation.

Desktop backup password

Protect the desktop with a backup password ID.

1. From the Home screen, touch

➔

Settings

➔

Developer options

➔

Desktop backup password

2. In the Settings screen, enter the current full backup

password, the new password for full backups, then

enter the new password again.

3. Touch

Set backup password

to save the password

change.

User interface

Configure the user interface by setting the behavior for the

way the screen behaves when using applications or

displaying data.



From the Home screen, touch

➔

Settings

➔

Developer options

, under the

User interface

heading,

touch the check box next to each of the following

options to enable: (A check mark indicates activation.)

• Strict mode

: The screen flashes when applications perform

long operations on the main thread.

• Show pointer location

: Highlights the data that was touched

on the screen.

DRAFT - Internal Use Only

148

• Show touches

: Displays touch interactions on the screen.

• Show screen updates

: Areas of the screen flash when they

update.

• Show CPU usage

: Screen highlights the current CPU usage.

• Force GPU rendering

: Uses a 2D acceleration in applications.

• Window animation scale

: Configure the scale for animation

(ranges from off to 10x).

• Transition animation scale

: Configure the scale for

transitioning when using animation (ranges from Off to 10x).

Apps



From the Home screen, touch

➔

Settings

➔

Developer options

, under the

Apps

heading touch the

check box next to each of the following options to

enable: (A check mark indicates activation.)

• Do not keep activities

: Destroys every activity as soon as the

application is closed.

• Limit background processes

: Set the number of processes

that can run in background. Options are: Standard limit, No

background processes, and 1 to 4 processes at most.

•Show all ANRs

: Displays a prompt when applications running

in background are not responding.

About Device

This menu contains legal information, system tutorial

information, and other phone information such as the model

number, firmware version, baseband version, kernal version,

and software build number.

To access phone information:

1. From the Home screen, tap ➔

Settings

➔

settings

(System) ➔

About device

2. The following information displays:

• Status

: displays the battery status, the level of the battery

(percentage), network, signal strength, mobile network type,

service state, roaming status, mobile network state, the phone

number for this device, ERI version, IMEI number, IMEISV, IP

address, Wi-Fi MAC address, Bluetooth address, Serial

number, Up time, and Device status.

• Legal information

: This option displays information about

Open source licenses as well as Google legal information. This

information clearly provides copyright and distribution legal

information and facts as well as Google Terms of Service,

pertinent information as a reference. Read the information and

terms, then press

to return to the Settings menu.

DRAFT - Internal Use Only

Changing Your Settings 149

• Model number

: displays the phone’s model number.

• Android version

: displays the android version loaded on this

handset.

• Baseband version

: displays the baseband version loaded on

this handset.

• Kernel version

: displays the kernel version loaded on this

handset.

• Build number

: displays the software, build number.

DRAFT - Internal Use Only

Note:

Baseband, kernal and build numbers are usually used

for updates to the handset or support. For additional

information please contact your USCC service

representative.

150

Section 9: Connections

This section describes the various connections your phone

can make including accessing the Internet with your

Browser, Wi-Fi, Bluetooth, and Connecting your PC.

Internet

The Browser is your access to the mobile web. This section

explains how to navigate the Browser and introduces you to

the basic features.

Accessing the Mobile Web

To access the Browser:



From the Home screen, tap

Internet

Navigating with the Browser

1. To select an item, tap an entry.

2. To scroll through a website, sweep the screen with

your finger in an up or down motion.

3. Sweep the screen left to right to move laterally across

a web page.

4. To return to a previous page, press .

5. To move forward to a web page, press .

Zooming in and out of the Browser

There are several ways to Zoom in and out on your browser.

After tapping on a link or article, use one of these methods:

•

Tilting

: Tap and hold the screen at two points then tilt the device

back and forth to reduce or enlarge the screen. You must first

enable motion in the Settings section. For more information, refer

“Power Saving”

on page 130.

•

Double tap

: Quickly tap the screen twice on the web page to

zoom in or out.

•

Pinching

: Sweep in opposite directions at the same time to zoom

in or out (use a pinching-in or pinching-out motion).

Browser Options

1. From the home page, press to access the

following options:

• New window

: displays a new window so you can browse

multiple URLs. For more information, refer to

“Adding and

Deleting Windows”

on page 151.

•Add bookmark

: allows you to add a URL to your bookmark list

DRAFT - Internal Use Only

The USCC mobile homepage displays.

Connections 151

• Add shortcut to home

: allows you to add a shortcut to your

Home screen.

• Share page

: allows you to share the page using Gmail or as a

message.

• Find on page

: allows you to search in the current page.

• Desktop view

: allows you to assign the browser to display the

current page in the desktop view (to closely mimic the display

as it displays on a desktop computer).

• Save for offline reading

: allows you to store the current page

in memory so that it can be read later even if you loose your

Internet connection.

• Downloads

: displays the download history.

•Print

: allows you to print the screen or web page on a

Samsung printer using Wi-Fi.

•Settings

: allows you to modify your web settings. For more

information, refer to

“Browser Settings”

on page 154.

Enter a URL

You can access a website quickly by entering the URL.

Websites are optimized for viewing on your phone.

To enter a URL and go to a particular website, follow these

steps:

1. Tap the URL field at the top of your screen.

2. Enter the URL using the on-screen keypad.

The website displays.

Search the Internet

To perform an internet search using keywords, follow these

steps:

1. From the Google homepage, tap the URL field.

2. Enter the keyword(s) to search using the on-screen

keypad and tap

3. Tap a link to view the website.

Adding and Deleting Windows

You can have up to eight Internet windows open at one time.

To add a new window, follow these steps:

1. From your browser, press ➔

New window

A new browser window is opened.

2. Tap (

Windows

) to see thumbnails of all open

windows.

3. Tap a window listing to open up that Internet window.

DRAFT - Internal Use Only

152

4. Tap at the top right corner of the web page

thumbnail to delete the window.

Going Incognito

The incognito feature allows you to view Internet sites

outside of the normal browsing. Pages viewed in this

incognito window won’t display in the browser history or

search history, and no traces (such as cookies) are left on

your device.

Note:

Any downloaded files will be preserved and will stay on your

device after you exit the incognito mode.

To add a new incognito window:

1. From your browser window, tap (

Windows

) ➔

(

Incognito

2. A new browser window displays.

Note:

The incognito icon displays in the upper-left of the new

browser window while you are in this mode.

To exit from the incognito window:

1. From your browser window, tap (

Windows

) ➔

(

New window

2. Scroll across the available windows and locate the

incognito window.

3. Tap next to the incognito listing to delete this

window.

Using Bookmarks

While navigating a website, you can bookmark a site to

quickly and easily access it at a future time. The URLs

(website addresses) of the bookmarked sites are displayed in

the Bookmarks page. From the Bookmarks page you can

also view your Most visited websites and view your History.

1. From the Home webpage, tap (

Bookmarks

The Bookmarks page is displayed.

2. Press to display the following options:

• List/Thumbnail view

: Select

Thumbnail view

(default) to view

a thumbnail of the webpage with the name listed, or select

List

view

to view a list of the bookmarks with Name and URL listed.

• Create folder

: Creates a new folder in which to store new

bookmarks.

DRAFT - Internal Use Only

Connections 153

• Change order

: Rearranges the current bookmarks.

• Move to folder

: Selected bookmarks are moved to a selected

folder.

•Delete

: Erases selected bookmarks.

3. Tap a bookmark to view the webpage, or touch and

hold a bookmark for the following options:

•Open

: Opens the webpage of the selected bookmark.

• Open in new window

: Opens the webpage in a new window.

• Edit bookmark

: Allows you to edit the name or URL of the

bookmark. For more information, refer to

“Editing

Bookmarks”

on page 153.

• Add shortcut to home

: Adds a shortcut to the bookmarked

webpage to your phone’s Home screen.

• Share link

: Allows you to share a URL address using many

different options.

•Copy link URL

: Allows you to copy the URL address to use in a

message.

• Delete bookmark

: Allows you to delete a bookmark. For more

information, refer to

“Deleting Bookmarks”

on page 153.

• Set as homepage

: Sets the bookmark to your new homepage.

Adding Bookmarks

1. From any webpage, tap ➔ .

2. Use the on-screen keypad to enter the Name, Address,

and the Folder.

3. Tap

Save

Saved to bookmarks

displays at the bottom of the page.

Editing Bookmarks

1. From the Bookmarks page, tap and hold the bookmark

you want to edit.

2. Tap

Edit bookmark

3. Use the on-screen keypad to edit the Name, Address,

and the Folder.

4. Tap

Save

Deleting Bookmarks

1. From the Bookmarks page, tap and hold the bookmark

you want to delete.

2. Tap

Delete bookmark

3. At the

Delete

confirmation window, tap

DRAFT - Internal Use Only

154

Emptying the Cookies

A cookie is a small file which is placed on your phone by a

website during navigation. In addition to containing some

site-specific information, it can also contain some personal

information (such as a username and password) which can

pose a security risk if not properly managed. You can clear

these cookies from your phone at any time.

1. From the Home webpage, press ➔

Settings

➔

Privacy and security

➔

Clear all cookie data

2. At the

Clear

prompt, tap

to delete the cookies or tap

Cancel

to exit.

Using your History

The History list provides you with a list of the most recently

visited websites. These entries can be used to return to

previously unmarked web pages.

1. From the Home webpage, tap ➔

History

tab.

A list of your most recently visited websites is

displayed with Name and URL address.

2. Tap on a category such as

Today

Last 7 days

Most

visited

3. Tap any entry to display the webpage.

4. Press ➔

Clear history

to delete the History list.

Saved Pages

The Saved pages list provides you with a list of the websites

that you have saved.

1. From the Home webpage, tap ➔

Saved pages

tab.

A list of your saved webpages is displayed with Name

and URL address. The webpages that have been visited

the most displays at the top.

2. Tap any entry to display the webpage.

Browser Settings

To make adjustments in your browser settings, follow these

steps:

1. Tap

Internet

➔ ➔

Settings

2. The following options are available:

General

• Set home page

: Sets the current home page for the Web

browser.

•Form auto-fill

: allows you to fill in web forms with a single tap.

• Auto-fill text

: allows you to enter text to be used in the Form

auto-fill feature.

DRAFT - Internal Use Only

Connections 155

Privacy and security

• Clear cache

: Deletes all currently cached data. Tap

complete the process.

•Clear history

: Clears the browser navigation history. Tap

complete the process.

• Show security warnings

: Notifies you if there is a security

issue with the current website.

• Accept cookies

: Allows sites, that require cookies, to save and

read cookies from your device.

• Clear all cookie data

: Deletes all current browser cookie files.

• Remember form data

: Allows the device to store data from

any previously filled out forms. Tap the option again to disable

this function.

• Clear form data

: Deletes any stored data from previously filled

out forms. Tap OK to complete the process.

• Enable location

: Allows websites to request access to your

location.

• Clear location access

: Clears location access for all websites.

Tap

to complete the process.

• Remember passwords

: Stores usernames and passwords for

visited sites. Tap the option again to disable this function.

• Clear passwords

: Deletes any previously stored usernames or

passwords. Tap

to complete the process.

• Enable notifications

: Allows website notifications. Select

Always on, On demand, or Off.

• Clear notifications

: Deletes website notification access

information.

Accessibility

• Force zoom

: allows you to override the website’s request to

control zoom.

• Text size

: allows you to preview the text size, scale the text size

using a slider bar, set the zoom amount on double tap, and

minimize the font size using a slider bar.

• Inverted rendering

: allows you to preview a website page,

select Inverted rendering (black becomes white and vice versa),

and adjust the Contrast using a slider bar.

Advanced

• Select search engine

: allows you to set your default search

engine to Google, Yahoo!, or Bing.

• Open in background

: New pages are launched in a separate

page and displayed behind the current one. Tap the option

again to disable this function.

DRAFT - Internal Use Only

156

• Enable JavaScript

: Enables Javascript for the current Web

page. Without this feature, some pages may not display

properly. Tap the option again to disable this function.

• Enable plug-ins

: Allows the download of plug-ins such as

Adobe Flash.

•Default storage

: Allows you to set your default storage to

Phone or Memory Card.

• Website settings

: View advanced settings for individual

websites.

• Default zoom

: Adjusts the zoom feature. Set to Far, Medium,

or Close.

• Open pages in overview

: Shows an overview of newly opened

web pages.

• Auto-fit pages

: Allows web pages to be resized to fit as much

of the screen as possible.

• Block pop-ups

: Prevents popup advertisement or windows

from displaying onscreen. Tap the option again to disable this

function.

• Text encoding

: Adjusts the current text encoding.

• Reset to default

: Clears all browser data and resets all settings

to default.

Bandwidth management

• Preload search results

: Allows the browser to preload high

confidence search results in the background to help speed up

searches.

•Load images

: Allows web page images to be loaded along

with the other text components of a loaded website.

Labs

• Quick controls

: allows you to open quick controls and hide the

app and URL bars by swiping your thumb from the left or right

edge of the screen.

• Full screen

: allows you to access Full screen mode and hide

the status bar.

Wi-Fi

About Wi-Fi

Wi-Fi (short for "wireless fidelity"and sometimes referred to

as wifi) is a term used for certain types of Wireless Local

Area Networks (WLAN). These device types use an 802.11

wireless specification to transmit and receive wireless data.

Wi-Fi communication requires access to an existing and

accessible Wireless Access Point (WAP). These WAPs are

DRAFT - Internal Use Only

Connections 157

either Open (unsecured) used with most Hot Spots, or

Secured (requiring knowledge of the Router name and

password).

Turning Wi-Fi On

By default, your device’s Wi-Fi feature is turned off. Turning

Wi-Fi on makes your device able to discover and connect to

compatible in-range WAPs.

1. From the Home screen, tap ➔

Settings

2. Tap the ON/OFF slider, located to the right of the Wi-Fi

field, to turn Wi-Fi ON .

Connect to a Wi-Fi Network

1. From the Home screen, tap ➔

Settings

➔

Wi-Fi

The network names and security settings (Open

network or Secured with WEP) of detected Wi-Fi

networks are displayed in the Wi-Fi networks section.

2. Tap the network you want to connect to.

Note:

When you select an open network, you automatically

connect to the network.

3. Enter a wireless password if necessary.

Manually add your new network connection

1. Tap

Add network

2. Enter the

Network SSID

. This is the name of your

Wireless Access Point.

3. Tap the

Security

field and select a security option. This

must match the current security setting on your target

WAP.

4. If secured, you will also need to enter your WAP’s

password.

5. Tap

Save

to store the new information and connect to

your target WAP.

Note:

The next time your device connects to a previously

accessed or secured wireless network, you are not

prompted to enter the WAP key again, unless you reset

your device back to its factory default settings.

Turning Wi-Fi Off

1. From the Home screen, tap ➔

Settings

2. Tap the ON/OFF slider, located to the right of the Wi-Fi

field, to turn Wi-Fi OFF .

OFF

DRAFT - Internal Use Only

158

Note:

Use of wireless data connections such as Wi-Fi and

Bluetooth can cause an added drain to your battery and

reduce your use times.

Manually Scan for a Wi-Fi Network

1. From the Home screen, tap ➔

Settings

➔

Wi-Fi

2. Tap

Scan

All available Wi-Fi networks are displayed.

Wi-Fi Status Indicators

The following icons show your Wi-Fi connection status at a

glance:

Displays when Wi-Fi is connected, active, and

communicating with a Wireless Access Point

(WAP).

Displays when Wi-Fi is active but there is a

communication issue with the target Wireless

Access Point (WAP).

Displays when connected to another device using

Wi-Fi Direct. For more information, refer to “Wi-Fi

Direct” on page 158.

Wi-Fi Advanced Settings

The Advanced Wi-Fi menu allows you to set up many of your

device’s Wi-Fi service, including:

•

Network notification when an open network is available

•

Setting your Wi-Fi sleep policy

•

Checking for Wi-Fi Internet service

•

Specifying your Wi-Fi frequency band

•

Viewing your device’s MAC and IP Address

To access the Advanced Wi-Fi menu:

1. From the Home screen, tap ➔

Settings

➔

Wi-Fi

2. Tap

Advanced

For more information, refer to “Advanced Wi-Fi Settings” on

page 108.

Wi-Fi Direct

Wi-Fi Direct allows device-to-device connections so you can

transfer large amounts of data over a Wi-Fi connection.

Note:

See your service plan for applicable charges for Wi-Fi

Direct.

DRAFT - Internal Use Only

•

Automatically connecting to an

USCC

Wi-Fi hotspot when detected

Connections 159

1. From the Home screen, tap ➔

Settings

➔

settings

2. Tap the ON/OFF slider, located to the right of the Wi-Fi

Direct field, to turn Wi-Fi Direct ON .

3. From the Settings screen, tap

Wi-Fi Direct

4. Repeat

steps 1 - 4

on the other device you want to

connect with. The steps on a different model of phone,

may be different.

5. On your phone, tap

Scan

The device scans for other Wi-Fi Direct devices.

6. Once the device you want to connect to is displayed,

tap on it.

7. The other device has 2 minutes to tap

for the

connection to be made.

8. Once connected, the other device will show as

Connected

in your list of Wi-Fi Direct devices and the

icon will display at the top of your screen.

9. To change your Device name, press ➔

Device

name

10. For additional information about Wi-Fi Direct, press

➔

Help

Sharing Information with Connected Device

To share Videos, Photos, or other information with the

connected device, follow these steps:

1. View the information that you want to share. For

example, if you want to share a photo, find the photo in

your camera viewer or

My Files

folder, then tap the

Share,

Share via,

Send via

option.

2. Tap the

Wi-Fi Direct

option.

3. Tap the connected device name. For example,

Android_49ba.

4. The other device will receive a prompt to receive the

information and must tap

5. The file is transferred and the other device will receive

a screen notification that a Wi-Fi file has been

received. The file can be found in

My files

➔

SD card

the

ShareViaWifi

folder.

Note:

Depending on the other device model, the prompts and

shared folder information may differ.

DRAFT - Internal Use Only

160

NFC

NFC (Near Field Communication) allows data exchange when

you touch your device with another compatible device. This

is used for applications such as Android Beam and S Beam.

To activate NFC on your device, see “NFC” on page 109.

Android Beam

When Android Beam is activated, you can beam application

content to another NFC-capable device by holding the

devices close together. You can beam browser pages,

YouTube videos, contacts, and more. For more information,

refer to “Android Beam” on page 122.

S Beam

When S Beam is activated, you can beam files to another

NFC-capable device by holding the devices close together.

You can beam images and videos from your Gallery, music

files from your Music Player, and more. For more information,

refer to “S Beam” on page 110.

Bluetooth

About Bluetooth

Bluetooth is a short-range communications technology that

allows you to connect wirelessly to a number of Bluetooth

devices, such as headsets and hands-free car kits, and

Bluetooth-enabled handhelds, computers, printers, and

wireless devices. The Bluetooth communication range is

usually up to approximately 30 feet.

Turning Bluetooth On and Off

To turn Bluetooth on:

1. From the Home screen, tap ➔

Settings

2. Tap the ON/OFF slider, located to the right of the

Bluetooth field, to turn Bluetooth ON .

When active, displays in the Status area.

To turn Bluetooth off:

1. From the Home screen, tap ➔

Settings

2. Tap the ON/OFF slider, located to the right of the

Bluetooth field, to turn Bluetooth OFF .

Bluetooth Status Indicators

The following icons show your Bluetooth connection status

at a glance:

Displays when Bluetooth is active.

Displays when Bluetooth is connected (paired) and

communicating.

OFF

DRAFT - Internal Use Only

Connections 161

Displays briefly when Bluetooth is on but is not

connected to a Bluetooth device.

Bluetooth Settings

The Bluetooth settings menu allows you to set up many of

the characteristics of your device’s Bluetooth service,

including:

•

Entering or changing the name your device uses for Bluetooth

communication and description

•

Setting your device’s visibility (or “discoverability”) for other

Bluetooth devices

•

Displaying your device’s Bluetooth address

To access the Bluetooth Settings menu:

1. From the Home screen, tap ➔

Settings

2. Verify your Bluetooth is ON .

3. Tap

Bluetooth

To change your Bluetooth name:

1. From the Bluetooth settings page, press ➔

Device

name

2. Enter a new name.

3. Tap

to complete the rename process.

To make your device visible:

1. From the Bluetooth settings page, press ➔

Visible

time-out

•

Making your device visible allows it to be detected by other

devices for pairing and communication.

2. Select a time that you would like your device visibility

to time-out.

To show received files:



From the Bluetooth settings page, press ➔

Show

received files

A list of all files received from Bluetooth is displayed.

To scan for Bluetooth devices:

1. Verify your Bluetooth is active.

2. From the Bluetooth settings page, tap

Scan

to search

for visible external Bluetooth-compatible devices such

as headsets, devices, printers, and computers.

DRAFT - Internal Use Only

162

Pairing Bluetooth Devices

The Bluetooth pairing process allows you to establish trusted

connections between your device and another Bluetooth

device. When you pair devices, they share a passkey,

allowing for fast, secure connections while bypassing the

discovery and authentication process.

To pair your device with another Bluetooth device:

1. Verify your Bluetooth is active.

2. Tap

Scan

. Your device will display a list of discovered

in-range Bluetooth devices.

3. Tap a device from the list to initiate pairing.

4. Enter the passkey or PIN code, if needed, and tap

5. The external device will then have to also accept the

connection and enter your device’s PIN code.

Once successfully paired to an external device,

displays in the Status area.

Note:

Due to different specifications and features of other

Bluetooth-compatible devices, display and operations

may be different, and functions such as transfer or

exchange may not be possible with all Bluetooth

compatible devices.

Note:

Pairing between two Bluetooth devices is a one-time

process. Once a pairing has been created, the devices

will continue to recognize their partnership and

exchange information without having to re-enter a

passcode again.

Disconnecting a paired device

Disconnecting a paired device breaks the connection

between the device and your phone, but retains the

knowledge of the pairing. At a later point when you wish to

reconnect the device, there is no need to setup the

connection information again.

1. Verify your Bluetooth is active.

2. From the Bluetooth settings page, tap the previously

paired device (from the bottom of the page).

3. Tap

to confirm disconnection.

Note:

Disconnections are manually done but often occur

automatically if the paired device goes out of range of

your phone or it is powered off.

DRAFT - Internal Use Only

Connections 163

Deleting a paired device (unpair)

Deleting a device from your list removes its “connection

record” and upon reconnection would require that you re-

enter all the previous pairing information.

1. Verify your Bluetooth is active.

2. From the Bluetooth settings page, tap next to the

previously paired device. This opens the connected

device’s menu options.

3. Tap

Unpair

to delete the paired device.

4. Tap

Rename

to change the name of the paired device.

5. Tap

Call audio

to enable or disable call audio from the

paired device.

6. Tap

Media audio

to enable or disable media audio from

the paired device.

Sending Contacts via Bluetooth

Depending on your paired devices’ settings and capabilities,

you may be able to send pictures, Contact information, or

other items using a Bluetooth connection.

Note:

Prior to using this feature, Bluetooth must first be

enabled, and the recipient’s device must be visible.

1. Verify your Bluetooth is active.

2. From the Home screen, tap ➔

Contacts

3. Press ➔

Import/Export

➔

Send namecard via

4. Tap each contact that you would like to send via

Bluetooth. A green checkmark displays next to each

selected entry.

5. Tap

Done

6. Tap

Bluetooth

7. Select the paired device to send the contacts to.

Note:

The external Bluetooth device must be visible and

communicating for the pairing to be successful.

8. A Bluetooth share notification displays in your

notifications list.

PC Connections

You can connect your device to a PC using your PC data

cable using various USB connection modes.

Storage

: allows you to use the onboard storage capacity of

the phone to store and upload files. This option allows your

computer to detect the phone as a removable storage drive.

DRAFT - Internal Use Only

164

Kies air

: this application allows you to sync your Windows PC

wirelessly with your phone provided they are both on the

same Wi-Fi network.

Kies

: allows you to manage music, movies and photos. You

can also backup precious contacts and calendars, download

apps and podcasts and automatically upgrade device

firmware. Kies conveniently syncs your life across all your

devices.

Note:

To sync your device to your PC, it is highly

recommended that you install Samsung Kies which is

available at

http://www.samsung.com/kies

(for Windows/

Mac).

Note:

If you are a Windows XP user, ensure that you have

Windows XP Service Pack 3 or higher installed on your

computer. Also, ensure that you have Samsung Kies 2.0

or Windows Media Player 10 or higher installed on your

computer.

Connecting as a Storage Device

You can connect your device to a PC as a removable disk and

access the file directory. If you insert a memory card in the

device, you can also access the files directory from the

memory card by using the device as a memory card reader.

Note:

The file directory of the memory card displays as a

removable disk, separate from the internal memory.

1. Connect the USB cable to the device and connect the

cable to the computer. After a few seconds, a pop-up

window displays on the PC when connected.

2. On the PC pop-up, click

Open device to view files

3. Copy files from the PC to the memory card.

Kies air

Kies air allows you to sync your Windows PC wirelessly with

your phone provided they are both on the same Wi-Fi

network. You can view and share call logs, videos, photos,

music, bookmarks, ringtones, and even send SMS messages

from your PC.

DRAFT - Internal Use Only

Connections 165

To use the Kies air, follow these steps:

1. Sign onto the same Wi-Fi network from your phone and

from your PC.

2. On your phone, from the Home screen, tap ➔

Kies air

3. From the Kies air homescreen, tap

Start

A web URL is displayed on your phone screen.

4. From your PC, enter the URL in your web browser.

5. On your phone, an Access Request prompt is

displayed. Tap

Allow

to continue.

6. Tap the

Remember for today

checkbox if you will be

using Kies air with the same PC later.

7. From your PC, a security warning may be displayed

asking if you want to run this application. Click

Run

continue.

8. On your PC, the Kies air screen is displayed. On your

phone, the icon displays at the top of your screen.

9. Follow the on-screen instructions to view and share

information between your phone and PC.

10. To exit the Kies air application, tap

Stop

on your phone,

then close out the web browser on your PC.

NFC

NFC (Near Field Communication) allows data exchange when

you touch your device with another compatible device. This

is used for applications such as Android Beam and S Beam.

For information on NFC and NFC related features, see “NFC”

on page 109.

DRAFT - Internal Use Only

166

Section 10: Applications

This section contains a description of each application that is

available in the Apps Menu, its function, and how to navigate

through that particular application. If the application is

already described in another section of this user manual,

then a cross reference to that particular section is provided.

Tip:

To open applications quickly, add the icons of frequently-

used applications to one of the Home screens. For details,

see “Customizing Your Home Screen” on page 36.

You can also add an application icon as a Primary

Shortcut that will display on all Home screens. If you add

an application as a primary shortcut, the application icon

will not be displayed in the Apps menu. For more

information, refer to “Adding and Removing Primary

Shortcuts” on page 37.

AllShare Play

This application wirelessly synchronizes your Samsung

device with your TV, streams content, and even keeps tabs

on who calls or sends text messages with real-time,

on-screen monitoring. Samsung’s AllShare makes staying

connected easy.

AllShare Play allows users to share their in-device media

content with other external devices using DLNA certified™

(Digital Living Network Alliance) Devices. These external

devices must also be DLNA-compliant. Wi-Fi capability can

be provided to TVs via a digital multimedia streamer.

Important!

You must first connect both of your communicating

devices to the same Wi-Fi and be using an

active/registered Samsung account prior to using

this application. For more information, refer to “Wi-

Fi Settings” on page 108. For more information,

refer to “Creating a Samsung Account” on page

12.

Important!

The Samsung account manages the access

information (username/password) to several

applications, such as AllShare Play, ChatON, and

Media Hub.

DRAFT - Internal Use Only

Applications 167

1. Confirm you have already logged in to your Samsung

account. There should be no icon in the

Notifications area of the screen.

2. From the Home screen, tap ➔

AllShare Play

The AllShare Play screen displays.

3. If prompted, read the on-screen message about

network charges and tap

to continue and return to

the main AllShare Play screen.

4. Tap

Start

and follow the on-screen prompts.

The application contains two separate streaming media

options:

•Registered Storage

: allows you to receive and playback media

stored externally (server, laptop, etc.) directly on your device by

allowing you to add a Web storage service for streaming

content.

• Registered Devices

: allows you to stream/share selected

multimedia content from your device to DLNA compliant device

connected to the same Wireless Access Point.

Configuring AllShare Settings

The AllShare Play™ application must first be configured

prior to its initial use. You must setup parameters such as

connected Wi-Fi, Items to share, source server address, and

external device acceptance rights.

1. From the Home screen, tap ➔

AllShare Play

2. Press and then tap

Settings

and configure the

following settings as desired:

•Registered Storage

: allows you to add a Web storage location.

Without a storage service/location added, you will not be able

to use AllShare Play.

• Registered Devices

: defaults to your phone. This indicates the

source of the streaming images and videos. Use the main

screen to add more external devices.

• Setting up web services

: allows you to set up external Web

services by signing in to external sites such as Facebook,

Twitter, YouTube, etc.

• Auto Upload photos from mobile

: allows you to setup

automatic upload of images from your device to those storage

locations specified in the Web storage list.

• Video quality settings

: allows you to setup the video quality for

streamed video content.

DRAFT - Internal Use Only

168

• Lock AllShare Play

: allows you to restrict access to AllShare

Play by requiring a user enter the currently active and

associated Samsung account password. Tap

Locking

AllShare Play

to activate/deactivate the feature.

• Language

: allows you to select a display language.

• About

: displays application information.

•Contact Us

: allows you to contact the AllShare team via a new

email from an available email account.

Setting Up Web Storage

SugarSync is a Web storage service that allows you to use up

to 5GB of storage space to store your files and share them on

the “Cloud”.

Note:

If you are using another Web storage service, log into

that service first before using AllShare Play.

1. From the Home screen, tap ➔

AllShare Play

2. From the main screen, select

(

Add storage

) and

then tap on the media that you would like to share.

3. If this is your first time to use the service, set up a new

account by tapping

➔

SugarSync Sign Up

Note:

If you already have a current Sugar Sync account, tap

4. Enter in your Email address and your password.

5. Agree to the terms of service and tap

your on-screen keyboard.

Important!

After you enter your passwords, do not press

to hide the keyboard. This action erases the

password fields.

6. You can choose to download the SugerSync app or tap

Skip

to continue.

7. Once the process is successfully completed, the Web

storage icon or name displays in the Web storage area

of the main screen.

DRAFT - Internal Use Only

Applications 169

Sharing Media via AllShare Play to a Target

Device

Important!

Make sure all communicating devices are

connected to the same Wi-Fi.

1. Launch AllShare on the target device (such as an

Internet TV, Samsung Tablet, etc.).

2. From the Home screen, tap ➔

AllShare Play

3. Tap your device name from the

Devices

list.

4. Tap an available category tab (Pictures, Music, Movies,

Files, or Info) and select a file.

•

Touch and hold to select multiple files.

•

A file with in the upper-left indicates it is stored remotely

on a web storage location. Selecting this media causes your

device to access the file currently stored on your services’

servers.

5. Tap an available on-screen file, image, or video to

place a green check mark alongside it.

6. Tap (

Stream to connected devices

) to begin

streaming the selected files.

7. On a target device (ex: Internet TV) select the on-

screen Allow button to continue.

Note:

At this stage your device is requesting access to share

media with the external source.

8. Confirm (

AllShare Controller enabled

) displays in

the Notification area at the top of the device to indicate

you are using your device as the media source.

AllShare Play Screen Sharing via Group Cast

Important!

Verify all of your recipients are connected to the

same Wi-Fi.

1. From the Home screen, tap ➔

Gallery

2. Tap ➔

Group Cast

3. If prompted, read the on-screen notification and tap

to continue and return to the main AllShare Play

screen.

4. Enter a security PIN and tap

Done

. This process makes

sure only desired recipients can view your shared

image.

DRAFT - Internal Use Only

170

5. Re-enter you PIN and tap

Done

. The device then waits

for other connected recipients to accept the connection

and enter the PIN on their screens.

– or –

Tap

Start Group Cast anyway

to continue the process

while your users connect.

You can now interact and draw with the on-screen image,

users will instantaneously see the same gestures and also be

able to interact.

Note:

The newly altered image (with markups and comments)

can not be saved, but you can take a screen shot of the

current image and save it to your Clipboard. For more

information, refer to “Using Gestures” on page 32.

Calculator

With this feature, you can use the phone as a calculator. The

calculator provides the basic arithmetic functions; addition,

subtraction, multiplication, and division. The Calculator also

keeps a history of recent calculations.

1. From the Home screen, tap ➔

Calculator

2. Enter the first number using the on-screen numeric

keys.

3. Enter the operation for your calculation by tapping the

corresponding on-screen arithmetic function key.

4. Enter the second number.

5. To view the result, tap equals (

6. To view calculator history, tap located at the

top of the calculator buttons. A history of your past

calculations displays. Tap again to display the

calculator keypad.

7. To clear the calculator history, press ➔

Clear

history

8. To change the text size, press ➔

Text size

. Tap

Small, Medium, or Large.

Calendar

With the Calendar feature, you can consult the calendar by

day, week, or month, create events, and set an alarm to act

as a reminder, if necessary.

To access the Calendar:

1. From the Home screen, tap ➔

Calendar

DRAFT - Internal Use Only

Applications 171

2. Tap (

) to display these tabs:

•Year

: displays the Year view.

•Month

: displays the Month view.

• Week

: displays the Week view.

•Day

: displays the Day view.

• Agenda

: displays the Agenda view.

•Task

: allows you to search for tasks.

3. Tap (

Create event

) to create a new Calendar

event.

4. Tap

Today

to display the current date indicated by a

blue box.

5. Tap

Calendars

to select the calendar options that you

want displayed.

6. Press and select one of the following options:

•Go to

: displays a specific date.

•Delete

: allows you to delete All events, All events before today,

or an individual event.

•Search

: allows you to search current events.

•Sync

: allows you to synchronize your calendar with one or all of

your accounts. This option only displays when an account was

opened.

•Settings

: displays a list of configurable settings.

Calendar Settings

1. From any Calendar view, press ➔

Settings

2. Tap

Week view

and select a type:

Timeline

Analog

3. Tap

First day of week

and select either

Local default,

Saturday, Sunday

Monday

4. Tap

Hide declined events

to activate this option. A check

mark indicates selection.

5. Tap

Lock time zone

(to lock event time based on your

current user-selected time zone). Select a time zone

from the

Select time zone

field.

6. Tap

Show week number

to display the week numbers

along the side of the week entries.

7. Tap

Calendars

and select the type of general

synchronization settings you want. A check mark

indicates selection.

8. Tap

Set alerts & notifications

to adjust the event

notification method. Choose from:

Alert

Status bar

notification

, and

Off

DRAFT - Internal Use Only

172

9. Tap

Select ringtone

to assign a ringtone to a calendar

event notification.

10. Tap

Vibration

to set the Event notification tone to

vibrate.

11. Tap

Default reminder time

to assign a default time

frame for event reminders.

12. Tap

Notifications while screen is off

to display

notifications on the full screen while it is turned off.

13. Tap

Sync events/tasks

to select those calendar events

and task to sync based on current accounts.

14. Tap

Swipe with two fingers

to change the way events

are displayed when swiped.

Camera

Use your 8.0 megapixel camera feature to produce photos in a

JPEG format. Your phone also functions as a Camcorder to take

videos.

For more information, refer to “Camera” on page 87.

ChatON

With the ChatON application, you can interact with friends

and family with text, images, hand-written notes and video

shared instantly. You can chat in groups, while a Web client

will allow the easy sharing of content and conversations

between your phone and PC. For more information, refer to

“ChatON” on page 105.

Chrome

Google Chrome is a browser that combines a minimal design

with sophisticated technology to make the web faster, safer,

and easier.

1. From the Home screen, tap ➔

Chrome .

2. Require additional information and instructions here.

???

Clock

The Clock application allows you to access alarms, view the

World Clock, set a stopwatch, and use a timer.

Alarm

This feature allows you to set an alarm to ring at a specific

time.

1. From the Home screen, tap ➔

Clock

➔

Alarm

➔

Create alarm

. The following options

display:

•Time

: tap

(

) or (

Down

)

to set the new time for the

alarm to sound. Tap AM or PM.

DRAFT - Internal Use Only

Applications 173

• Alarm repeat

: use this option to set the repeating status for the

alarm by tapping one the days that you want the alarm to

sound. Tap the Repeat weekly checkbox to have the alarm

repeat weekly.

•Alarm type

: sets the way in which the alarm sounds when

activated (Melody, Vibration, Vibration and melody, and

Briefing).

• Alarm volume

: drag the slider to adjust the alarm’s volume.

•Alarm tone

: sets the sound file which is played when the alarm

is activated. Select

Sounds

Go to My files

• Snooze

: use this option to set a Duration (3, 5, 10, 15, or 30

Minutes) and Snooze repeat (1, 2, 3, 5, or 10 Times). Tap the

ON/OFF slider to activate.

• Smart alarm

: tracks body movements and calculates the best

time for sounding the alarm. Place the phone somewhere on

your bed then the phone's movement sensor (also known as

accelerometer) is sensitive enough to work from any part of the

bed. Set the Duration and the Tone. Tap the ON/OFF slider to

activate.

•Name

: allows you to use a specific name for the alarm. The

name displays on the screen when the alarm activates.

2. Tap

Save

to store the alarm details.

Turning Off an Alarm



To stop an alarm when it sounds, touch and sweep the

icon to the right.

Setting the Snooze Feature



To activate the Snooze feature after an alarm sounds,

touch and sweep the icon to the left. Snooze must

first be set in the alarm settings. For more information,

refer to “Alarm” on page 172.

Deleting Alarms

To delete an alarm, follow these steps:

1. From the Home screen, tap ➔

Clock

➔

Alarm

➔

Delete

2. Tap the alarm or alarms you wish to delete. A green

checkmark displays next to each selection. Tap

Select

all

to delete all alarms.

3. Tap

Done

DRAFT - Internal Use Only

174

World Clock

World Clock allows you to view the time of day or night in

other parts of the world. World Clock displays time in

hundreds of different cities, in all 24 time zones around the

world.

1. From the Home screen, tap ➔

Clock

➔

World clock

. The clock for your time zone displays.

2. Tap

Add city

to add another city to the World Clock.

3. Scroll through the list of cities to find the city you want

to add, or tap the Search bar and use the keypad to

enter a city to search for.

4. Tap the city you want to add. The clock for that city will

display.

5. To set Daylight Savings time, press and hold a city,

then tap

DST settings

6. Select

Automatic

Off

1 hour

, or

2 hours

7. If Daylight Savings Time is selected, the sun symbol on

the World Clock listing displays orange.

Deleting a World Clock Entry

1. From the Home screen, tap ➔

Clock

➔

World clock

➔

Delete

2. Tap the city clocks you wish to delete.

3. Tap

Done

Stopwatch

You can use this option to measure intervals of time.

1. From the Home screen, tap ➔

Clock

➔

Stopwatch

2. Tap

Start

to start the stopwatch and tap

Lap

to mark a

unit of time per lap.

3. Tap

Stop

to stop the stopwatch.

4. Tap

Restart

to continue or tap

Reset

to erase all times

recorded.

Timer

You can use this option to set a countdown timer. Use a timer

to count down to an event based on a preset time length

(hours, minutes, and seconds).

1. From the Home screen, tap ➔

Clock

➔

Timer

DRAFT - Internal Use Only

Applications 175

2. The

Minutes

field is highlighted and set to 1 minute.

Use the keypad to set the number of minutes you want.

3. Tap the

Hours

field to set hours if desired. As you tap

different fields, they will become highlighted.

4. Tap the

Seconds

field to set seconds.

5. Tap

Start

to begin the timer and tap

Stop

to pause the

timer.

6. After stopping, tap

Restart

to continue or tap

Reset

set the timer back to the original setting.

Desk clock

You can use the Desk clock when you have a desk dock and

you want your phone to display the time, day, date, location,

and weather conditions when it is docked.

1. From the Home screen, tap ➔

Clock

➔

Desk clock

The default Desk clock displays.

2. Tap to display the Desk clock in full-screen mode.

3. To make changes, tap

➔

Settings

4. The following options are displayed while in full-screen

mode:

•Hide status bar

: when this is checked, the status bar is hidden

from view.

• Wallpaper

: tap to select Desk clock wallpaper from Default,

Gallery, or Same as home screen.

• Time/Calendar display

: when this is checked, the time, day,

and date displays. Tap to uncheck.

• AccuWeather

: when this is checked, the location,

temperature, and weather condition displays. Tap to uncheck.

•Brightness

: sets your Desk clock brightness by dragging the

slider bar to the desired level.

•Dock

: allows you to set your Dock settings such as Dock

sound, Audio output mode, and Desk home screen display.

Contacts

You can manage your daily contacts by storing their name

and number in your Address Book. Address Book entries can

be sorted by name, entry, or group.

For more information, refer to “Accounts and Contacts” on

page 68.

DRAFT - Internal Use Only

176

Downloads

The Downloads application allows you to manage all of your

downloads from the Play Store and the Browser.

1. From the Home screen, tap ➔

Downloads

All of your downloads are listed.

2. Tap the

Internet Downloads

tab to see all of the

downloads you have made from the Browser.

3. Tap the

Other Downloads

tab to see all other

downloads.

4. Tap

Sort by size

to see your downloads sorted in size

order.

5. Tap

Sort by date

to see your downloads sorted in time

order.

Email enables you to review and create email using various

email services. You can also receive text message alerts

when you receive an important email. For more information,

refer to “Using Email” on page 101.

Gallery

The Gallery is where you view photos and play back videos.

For photos, you can also perform basic editing tasks, view a

slideshow, set photos as wallpaper or contact image, and

share as a picture message. For more information, refer to

“Gallery” on page 86.

Gmail

Gmail is a web-based email service. Gmail is configured

when you first set up your phone. Depending on your

synchronization settings, Gmail can automatically

synchronize with your Gmail account on the web. For more

information, refer to “Using Gmail” on page 103.

Internet

Open the web browser to start surfing the web. The browser

is fully optimized and comes with advanced functionality to

enhance the Internet browsing feature on your phone. For

more information, refer to “Internet” on page 150.

Kies air

Kies air allows you to sync your Windows PC wirelessly with

your phone provided they are both on the same Wi-Fi

network. For more information, refer to “Kies air” on page

164.

DRAFT - Internal Use Only

Applications 177

Latitude

With Google Latitude, you can see the location of all of your

friends on a map or on a list. You can also share or hide your

location.

You must first set up your phone to use wireless networks to

help pinpoint your location. Also, Latitude works best when

Wi-Fi is enabled.

1. Log on to your Google account. For more information,

refer to “Creating a New Google Account” on page 13.

2. From the Home screen, tap ➔

Latitude

Your location displays on the map, accurate to 40

meters.

Sharing your Location with Friends

1. From the Latitude map screen, tap

FRIENDS LIST

display your Latitude friends. At first, only your name

displays.

2. Tap .

3. Tap

Select from Contacts

Add via email address

4. Tap a contact or enter an email address and tap

Add

friends

5. At the

Send sharing requests

prompt, tap

Yes

Your friend will receive an email or text message with

your location marked on a map. They will also receive

instructions on how to view your location from the web

or use Latitude on their phone or tablet provided it is

available. Once they acknowledge your request, their

location will display on your phone. They can share

their location from their computer, phone, or tablet. For

more information, go to

http://www.google.com/latitude

6. To view the map, tap

MAP VIEW

Latitude Options



From the map display, press to display the

following options:

• Clear Map

: allows you to remove all markings and layers from

the map.

•Search

: allows you to search for a place of interest.

• Directions

: displays navigation directions to a location from a

starting point.

•Layers

: Layers are additional items that you can have

displayed on your map. They include Traffic, Satellite, Terrain,

Transit Lines, Latitude, My Maps, Bicycling, and Wikipedia.

DRAFT - Internal Use Only

178

• Settings

: the following Latitude options are available:

–

Display

: allows you to display the Zoom Buttons and Scale Bar

on the screen.

–

Cache

: allows you to set options to pre-fetch map tiles when

not using WiFi and to clear the cache that holds the map tiles.

–

Location settings

: allows you to manage the settings for your

Background location reporting, Location history, Latitude

location sharing, and Check-ins.

–

Labs

: this is a testing ground for experimental features that

aren’t ready for primetime. They may change, break or

disappear at any time. Click on a Lab to enable or disable it.

–

What’s New

: allows you to see the latest changes in Play Store

and update your app.

–

About

: displays general information about Google maps such

as Version, Platform, Locale, Total data sent, Total data received,

Free memory, etc.

–

Feedback

: allows you to send feedback to Google.

–

Terms, Privacy & Notices

: displays the Terms and Conditions,

information from the pop-up menu.

•Help

: displays the Google Mobile Help web page where you

can receive help on Google Maps.

Local

Local is an application that uses Google Maps and your

location to help you find Restaurants, Cafes, Bars,

Attractions, and other businesses. You can also add your own

locations.

1. From the Home screen, tap ➔

Local

2. Tap on one of the business categories to search for a

particular business.

All of the business categories that are close to you

displays.

3. Tap on a business that you want to see the details for.

4. The business details such as address, phone, website,

and location are displayed. You can also see reviews

from around the web and from Google users.

DRAFT - Internal Use Only

Applications 179

Maps

Depending on your location, you can view basic, custom, and

satellite maps and local business information, including

locations, contact information, and driving directions. You

can also post public messages about a location and track

your friends.

Important!

Before using Google Maps you must have at least

an active data (3G) connection. The Maps

application does not cover every country or city.

Enabling a Location Source

Before you use Google Maps and find your location or search

for places of interest, you must enable a location source. To

enable the location source you must enable the wireless

network, or enable the GPS satellites.

1. From the Home screen, tap ➔

Settings

➔

Location services

2. Tap the

Use GPS satellites

field. A green displays next to

the field.

Note:

Selecting

Use GPS satellites

allows you to locate places

of interest at the street-level. However, this also requires

a clear view of the sky and uses more battery power.

To receive better GPS signals, avoid using your device in the

following conditions:

•

inside a building or between buildings

•

in a tunnel or underground passage

•

in poor weather

•

around high-voltage or electromagnetic fields

•

in a vehicle with tinted windows

Using Maps

1. From the Home screen, tap ➔

Maps

A map will display with your location in the very center.

2. Press to display the following options:

• Clear Map

: allows you to remove all markings and layers from

the map.

•Settings

: the following Map options are available:

–

Display

: allows you to display the Zoom Buttons and Scale Bar

on the screen.

DRAFT - Internal Use Only

180

–

Cache

: allows you to set options to pre-fetch map tiles when

not using WiFi and to clear the cache that holds the map tiles.

–

Location settings

: allows you to manage the settings for your

Background location reporting, Location history, Latitude

location sharing, and Check-ins.

–

Labs

: this is a testing ground for experimental features that

aren’t ready for primetime. They may change, break or

disappear at any time. Click on a Lab to enable or disable it.

–

What’s New

: allows you to see the latest changes in Play Store

and update your app.

–

About

: displays general information about Google maps such

as Version, Platform, Locale, Total data sent, Total data received,

Free memory, etc.

–

Feedback

: allows you to send feedback to Google.

–

Terms, Privacy & Notices

: displays the Terms and Conditions,

information from the pop-up menu.

•Help

: displays the Google Mobile Help web page where you

can receive help on Google Maps.

Media Hub

Samsung Media Hub is your one stop for the hottest movie

and TV content. You can rent or purchase your favorite

content and watch from the convenience of anywhere. For

more information, refer to “Media Hub” on page 79.

Messaging

You can send and receive different types of messages. For

more information, refer to “Messaging” on page 95.

Music Player

Music Player allows you to play music files that you have

stored on your phone and memory card. You can also create

playlists. For more information, refer to “Music Player” on

page 81.

My Files

My Files allows you to manage your sounds, images, videos,

bluetooth files, Android files, and other memory card data in

one convenient location.

1. From the Home screen, tap ➔

My files

2. Tap

sdcard

to see the contents of your internal SD card.

3. The following folders may display:

•Alarms

: this folder contains any alarm files you may have.

DRAFT - Internal Use Only

Applications 181

•Android

: the Android folder stores files that are used in Android

applications.

•Application

: this folder contains app info for S Memo.

• Bluetooth

: this folder stores files sent via a Bluetooth device.

•DCIM

: this is the default location for pictures and videos taken

by the device. Tap

DCIM

➔

Camera

to view the picture or

video files. For more information, refer to

“Viewing Pictures”

on page 86. Also, see

“Viewing Videos”

on page 86.

• Download

: this folder contains downloads you have made.

•Movies

: this folder contains your Video and Movie files.

•Music

: this folder contains your Music files.

• Notifications

: this folder contains all of the notifications you

have received.

•Pictures

: this folder contains your photos.

•Podcasts

: this folder contains all of your podcasts.

•Ringtones

: this folder contains any ringtones you have

purchased.

4. If you have an external SD card inserted, tap

extSdcard

to see the contents of your external SD card (memory

card).

Note:

Different folders may display depending on how the

phone was configured.

Navigation

Navigation is an internet-connected GPS navigation system

with voice guidance. You can type or speak your destination.

Note:

For voice-guided navigation, you need to install text-to-

speech support from the Play Store.

To receive better GPS signals, avoid using your device in the

following conditions:

•

inside a building or between buildings

•

in a tunnel or underground passage

•

in poor weather

•

around high-voltage or electromagnetic fields

•

in a vehicle with tinted windows

DRAFT - Internal Use Only

182

Launching Navigation

1. From the Home screen, tap ➔

Navigation

2. Read the Navigation information page and tap

to continue or

Don’t accept

to exit.

3. Select one of the following options:

• Speak destination

: allows you to speak your destination.

•Type destination

: allows you to use the keypad to enter your

destination.

•Go home

: takes you to your home address. The first time you

are prompted to enter it.

•Map

: takes you to the map location of your present location

using GPS.

• Recent Destinations

: allows you to access information on

previous destinations you have used. This option only displays

after you have entered one or more destinations.

Navigation Options



The map displays with your location in the center.

Press for the following options:

• Set Destination

: displays the Choose Destination screen

where you can speak or type your destination.

•Search

: allows you to speak or type a destination, place, or

service to search for.

•Layers

: are additional items that you can have displayed on

your map. They include:

–

Traffic view

: displays real-time traffic conditions so you can

plan the fastest route.

–

Satellite

: allows you to see you the map as a satellite image.

–

Parking

: allows you to see registered parking areas.

–

Gas stations

: allows you to see registered gas stations.

–

ATMs & banks

: allows you to see registered ATMs and Banks.

–

Restaurants

: allows you to see registered restaurants.

• Settings

: includes the following options:

–

Screen Dimming

: set this option to dim the screen between

instructions in order to conserve battery power.

–

Terms, privacy & notices

: displays Terms and Conditions for

Google mobile products, the Google Privacy Policy, and Google

legal notices.

• Exit Navigation

: exits the Navigation application and returns

you to the Application Menu screen.

•Help

: takes you to the Google Mobile Help web page.

DRAFT - Internal Use Only

Applications 183

Obtaining Driving Directions

Your phone’s built-in GPS hardware allows you to get real-

time driving directions to selected locations or

establishments based on your current location.

Using a Physical Address

1. From the Home screen, tap ➔

Navigation

2. Tap either

Speak Destination

Type Destination

3. If typing in the address, enter the address, City, and

State using the keypad. As you type, possible

addresses displays. Tap on one when you see the

address you want.

The route displays.

4. If speaking the address, the Voice guidance screen

displays. For voice-guided navigation you need to

install text-to-speech support from the Play Store. Tap

Install

to install the application or tap

Skip

to exit.

Note:

You will need to be signed on to your Google account

before downloading applications from the Play Store. For

more information, refer to “Creating a New Google

Account” on page 13.

5. As you drive the route display will be updated and you

will receive voice-guided navigation directions.

Phone

The Phone application allows you to access the dialer

keypad, call logs, and favorites. For more information, refer

to “Call Functions” on page 46.

Play Books

With Google Play Books, you can find more than 3 million

free e-books and hundreds of thousands more to buy in the

eBookstore.

1. From the Home screen, tap ➔

Play Books

2. Log on to your Google account. For more information,

refer to “Creating a New Google Account” on page 13.

3. Follow the on-screen instructions for using the Play

Books application.

Play Movies

With Google Play Movies, you can rent thousands of different

movies. You can watch instantly, or download your movie for

offline viewing at a later time. For more information, refer to

“Play Movies” on page 85.

DRAFT - Internal Use Only

184

Play Music

With Google Play Music, you can play music that you have

added to your music file as well as any music you copied

from your PC. While offline, you can listen to music you have

copied from your PC. For more information, refer to “Google

Play Music” on page 84.

Play Store

Play Store provides access to downloadable applications and

games to install on your phone. Play Store also allows you to

provide feedback and comments about an application, or flag

an application that might be incompatible with your phone.

Before using the Play Store you must have a Google Account.

For more information, refer to “Using Gmail” on page 103.

1. From the main Home screen, tap

Play Store

2. Sign in to your Google account.

3. The first time you sign in, the Play Store Terms of

Service displays. Tap

to continue or

Decline

exit.

4. Tap

Apps

, or

Games

to download or purchase games or

applications. You can also download updates to

existing applications.

5. Follow on the on-screen instructions.

Point&

??? Required description information here.

Polaris Office 4.0

Polaris® Office Mobile for Android is a Microsoft Office

application that provides a central place for managing your

documents online or offline.

The application can also open Adobe PDF (Portable

Document Format) files.

1. From the main Home screen, tap

Polaris Office

2. Enter your Email information (if desired) and touch

to complete the process.

– or –

Touch

Later

to ignore this registration.

The main Polaris Office screen displays.

My files

displays a list of all the files on your phone.

3. Touch

to search for document files by

using a text string.

4. Several options are listed under

Category

. Touch one of

the following:

DRAFT - Internal Use Only

Applications 185

•My Files

: Where you keep documents on this device. You can

manage documents or send them to others, and upload the

documents. For more information, refer to

“My Files”

page 180.

• Recent documents

: Displays documents that you have

recently created or modified.

•Web files

: Provides your online storage information at

Box.net

You can also share your documents to others without using

email attachments.

5. Press

➔ to access these additional options:

• Manage files

: allows you to manage your files. You can Move,

Copy, and Delete.

•Sort by

: Allows you to sort by File name, Date, Size, or Type.

•Settings

: Displays the following options:

–

Create back-up file

: Touch the check box to enable creating a

back-up file when you save documents.

–

Display file extensions

: Touch the check box to enable the

display of file extensions.

–

Pivot lock

: allows you to lock the screen so that it won’t move

between landscape and portrait mode when you rotate your

phone.

–

Custom zoom

: allows you to enter a customized zoom level

between 50 and 200 that you can access from the zoom

option.

–

Accounts

: Touch to manage the accounts you have created.

–

Live update

: Touch to make sure you have the latest version of

Polaris Office.

About

: Displays the Polaris Office version and build numbers.

S Note

The S Note application allows you to create notes. Choose a

template, then add images, voice recordings, and text all in

one place.

Creating a New Note

1. From the Home screen, tap ➔

S Note

The S Note screen displays.

2. Requires addition information about this

application.???

DRAFT - Internal Use Only

186

S Suggest

This application provides on-screen recommendations for

applications that are specifically supported and made for use

on your device.

Note:

Access to this feature requires that you already be

logged in to your Samsung account application. For

more information, refer to “Creating a Samsung

Account” on page 12.

1. From the Home screen, tap ➔

S Suggest

2. Read the terms and conditions.

3. Place a check mark in the

Agree

field then tap

Agree

4. Select an application from one of the available

categories (Picks, Categories, Games, Friends, and

Info.

5. Follow the on-screen download and installation

instructions.

S Voice

With the S Voice application you can use your voice to

perform operations that you would normally have to do by

hand such as dialing a phone number, texting a message,

playing music, etc.

1. From the Home screen, tap ➔

S Voice

2. Read the Samsung Disclaimer then tap

Confirm

continue.

3. Read the Vlingo Terms of Service then tap

Agree

continue.

4. Read the information on the

About S Voice

screen, then

tap

5. Read the information on the

Say what you want

screen,

then tap

6. Read the information on the

Wake up S Voice

screen,

then tap

7. Read the information on the

What Can I Say?

screen,

then tap

Finish

8. At the S Voice screen, say “Hi Galaxy” to wake up

S voice.

DRAFT - Internal Use Only

Applications 187

9. Speak into the phone and follow the on-screen

instructions.

Samsung Apps

Insert additional Samsung Applications information here???

The Search application is the same on-screen Internet

search engine that is on the Google Search Bar on your main

Home screen. For more information, refer to “Google Search

Bar” on page 31.

Settings

This widget navigates to the sound and phone settings for

your phone. It includes such settings as: display, security,

memory, and any extra settings associated with your phone.

For more information, refer to “Changing Your Settings” on

page 108.

Talk

Google Talk is a free Windows and web-based application for

instant messaging offered by Google. Conversation logs are

automatically saved to a Chats area in your Gmail account.

This allows you to search a chat log and store them in your

Gmail accounts. For more information, refer to “Google Talk”

on page 104.

Video Player

The Video Player application plays video files stored on your

memory card. For more information, refer to “Video Player”

on page 84.

Voice Recorder

The Voice Recorder allows you to record an audio file up to

one minute long and then immediately share it using

AllShare Play, Messaging, Gmail, or via Bluetooth. Recording

time will vary based on the available memory on the phone.

1. From the Home screen, tap ➔

Voice Recorder

2. To start recording, tap

Record

and speak into the

microphone.

3. During the recording process you can either tap

Stop

to stop and save the recording or

Pause

temporarily halt the recording. After pausing, tap

Record

to resume recording. Once the audio

recording has stopped, the message is automatically

saved. Tap

Cancel

to cancel the recording

without saving.

4. Tap

List

to display a list of all your voice

recordings. Tap a voice recording to play it.

DRAFT - Internal Use Only

188

5. Press

to display the following options:

•Share via

: allows you to share your recording using Bluetooth,

Email, Gmail, Group Cast, Messaging, or Wi-Fi Direct.

•Delete

: allows you to delete 1 or more voice recordings. Tap

the recordings to delete and tap

Delete

•Rename

: allows you to rename your recordings.

• Settings

: the following settings are available:

–

Storage

: allows you to choose where your recordings will be

saved. Select between Phone or memory card.

–

Default name

: allows you to choose the name prefix for your

recordings. For example, if your Default name is Voice, your

recordings would be named Voice 001, Voice 002, Voice 003,

etc.

–

Recording quality

: allows you to set the recording quality to

High or Normal.

–

Limit for MMS

: allows you to select On or Off. If you Limit for

MMS by selecting On, you will be assured that the recording can

be sent in a message.

Tip:

Tap to access the Voice Recorder settings.

YouTube

YouTube™ is a video sharing website on which users can

upload and share videos. The site is used to display a wide

variety of user-generated video content, including movie

clips, TV clips, and music videos, as well as video content

such as video blogging, informational shorts and other

original videos.

Note:

YouTube is a data-intensive feature. It is recommended

that you upgrade to a large data plan to avoid additional

data charges.

1. From the Home screen, tap ➔

YouTube

2. Tap the search field to search for specific videos,

scroll down to browse through the main page

thumbnails, or scroll to the bottom to explore additional

options.

3. To view a video, tap an available preview thumbnail or

tap the title link.

4. If you prefer high quality video, as the video starts to

play, tap

DRAFT - Internal Use Only

Applications 189

5. Tap to go to your camcorder so you can take your

own videos. For more information, refer to “Using the

Camcorder” on page 91.

Note:

It is not necessary to sign in to the YouTube site to view

content. However, if you wish to sign in to access

additional options, access the page via the Web browser

and tap

at the top right corner, enter your

YouTube or Google username and password, and tap

DRAFT - Internal Use Only

190

Section 11: Health and Safety Information

This section outlines the safety precautions associated with

using your phone. The terms “mobile device” or “cell phone”

are used in this section to refer to your phone.

Read this

information before using your mobile device

Exposure to Radio Frequency (RF)

Signals

The U.S. Food and Drug Administration (FDA) has published

information for consumers relating to Radio Frequency (RF)

exposure from wireless phones. The FDA publication

includes the following information:

Do cell phones pose a health hazard?

Many people are concerned that cell phone radiation will

cause cancer or other serious health hazards. The weight of

scientific evidence has not linked cell phones with any health

problems.

Cell phones emit low levels of Radio Frequency (RF) energy.

Over the past 15 years, scientists have conducted hundreds

of studies looking at the biological effects of the radio

frequency energy emitted by cell phones. While some

researchers have reported biological changes associated

with RF energy, these studies have failed to be replicated.

The majority of studies published have failed to show an

association between exposure to radio frequency from a cell

phone and health problems.

The low levels of RF cell phones emit while in use are in the

microwave frequency range. They also emit RF at

substantially reduced time intervals when in the stand-by

mode. Whereas high levels of RF can produce health effects

(by heating tissue), exposure to low level RF that does not

produce heating effects causes no known adverse health

effects.

The biological effects of radio frequency energy should not

be confused with the effects from other types of

electromagnetic energy.

Very high levels of electromagnetic energy, such as is found

in X-rays and gamma rays, can ionize biological tissues.

Ionization is a process where electrons are stripped away

from their normal locations in atoms and molecules. It can

permanently damage biological tissues including DNA, the

genetic material.

DRAFT - Internal Use Only

Health and Safety Information 191

The energy levels associated with radio frequency energy,

including both radio waves and microwaves, are not great

enough to cause ionization of atoms and molecules.

Therefore, RF energy is a type of non-ionizing radiation.

Other types of non-ionizing radiation include visible light,

infrared radiation (heat), and other forms of electromagnetic

radiation with relatively low frequencies.

While RF energy does not ionize particles, large amounts can

increase body temperatures and cause tissue damage. Two

areas of the body, the eyes and the testes, are particularly

vulnerable to RF heating because there is relatively little

blood flow in them to carry away excess heat.

Research Results to Date: Is there a connection

between RF and certain health problems?

The results of most studies conducted to date say no. In

addition, attempts to replicate and confirm the few studies

that have shown a connection have failed.

The scientific community at large therefore believes that the

weight of scientific evidence does not show an association

between exposure to Radio Frequency (RF) from cell phones

and adverse health outcomes. Still the scientific community

has supported additional research to address gaps in

knowledge. Some of these studies are described below.

Interphone Study

Interphone is a large international study designed to

determine whether cell phones increase the risk of head and

neck cancer. A report published in the International Journal

of Epidemiology (June, 2010) compared cell phone usage for

more than 5,000 people with brain tumors (glioma and

meningioma) and a similar number of healthy controls.

Results of this study did NOT show that cell phones caused

brain cancer. In this study, most people had no increased risk

of brain cancer from using cell phones. For people with the

heaviest use of cell phones (an average of more than ½ hour

per day, every day, for over 10 years) the study suggested a

slight increase in brain cancer. However, the authors

determined that biases and errors prevented any conclusions

being drawn from this data. Additional information about

Interphone can be found at

http://www.iarc.fr/en/media-centre/pr/2010/pdfs/pr200_E.pdf.

Interphone is the largest cell phone study to date, but it did

not answer all questions about cell phone safety. Additional

research is being conducted around the world, and the FDA

continues to monitor developments in this field.

DRAFT - Internal Use Only

192

International Cohort Study on Mobile Phone Users

(COSMOS)

The COSMOS study aims to conduct long-term health

monitoring of a large group of people to determine if there

are any health issues linked to long-term exposure to radio

frequency energy from cell phone use. The COSMOS study

will follow approximately 300,000 adult cell phone users in

Europe for 20 to 30 years. Additional information about the

COSMOS study can be found at

http://www.ukcosmos.org/index.html

Risk of Brain Cancer from Exposure to Radio

Frequency Fields in Childhood and Adolescence

(MOBI-KIDS)

MOBI-KIDS is an international study investigating the

relationship between exposure to radio frequency energy

from communication technologies including cell phones and

brain cancer in young people. This is an international

multi-center study involving 14 European and non-European

countries. Additional information about MOBI-KIDS can be

found at

http://www.creal.cat/programes-recerca/en_projectes-creal/

view.php?ID=39.

Surveillance, Epidemiology, and End Results (SEER)

Program of the National Cancer Institute

The National Cancer Institute (NCI) actively follows cancer

statistics in the United States to detect any change in rates of

new cases for brain cancer. If cell phones play a role in risk

for brain cancer, rates should go up, because heavy cell

phone use has been common for quite some time in the U.S.

Between 1987 and 2005, the overall age-adjusted incidence

of brain cancer did not increase. Additional information about

SEER can be found at

http://seer.cancer.gov/

Cell Phone Industry Actions

Although the existing scientific data do not justify FDA

regulatory actions, the FDA has urged the cell phone industry

to take a number of steps, including the following:

•

Support-needed research on possible biological effects of RF

for the type of signal emitted by cell phones;

•

Design cell phones in a way that minimizes any RF exposure to

the user; and

•

Cooperate in providing users of cell phones with the current

information on cell phone use and human health concerns.

DRAFT - Internal Use Only

Health and Safety Information 193

The FDA also is working with voluntary standard-setting

bodies such as the Institute of Electrical and Electronics

Engineers (IEEE), the International Commission on

Non-Ionizing Radiation Protection (ICNIRP), and others to

assure that safety standards continue to adequately protect

the public.

Reducing Exposure: Hands-Free Kits and Other

Accessories

Steps to Reduce Exposure to Radio Frequency Energy

If there is a risk from being exposed to radio frequency

energy (RF) from cell phones - and at this point we do not

know that there is - it is probably very small. But, if you are

concerned about avoiding even potential risks, you can take

a few simple steps to minimize your RF exposure.

•

Reduce the amount of time spent using your cell phone;

•

Use speaker mode or a headset to place more distance between

your head and the cell phone.

Hands-Free Kits

Hands-free kits may include audio or Bluetooth® headsets

and various types of body-worn accessories such as

belt-clips and holsters. Combinations of these can be used to

reduce RF energy absorption from cell phones.

Headsets can substantially reduce exposure because the

phone is held away from the head in the user's hand or in

approved body-worn accessories. Cell phones marketed in

the U.S. are required to meet RF exposure compliance

requirements when used against the head and against the

body.

Because there are no known risks from exposure to RF

emissions from cell phones, there is no reason to believe that

hands-free kits reduce risks. Hands-free kits can be used for

convenience and comfort. They are also required by law in

many states if you want to use your phone while driving.

Cell Phone Accessories that Claim to Shield the Head

from RF Radiation

Because there are no known risks from exposure to RF

emissions from cell phones, there is no reason to believe that

accessories which claim to shield the head from those

emissions reduce risks. Some products that claim to shield

the user from RF absorption use special phone cases, while

others involve nothing more than a metallic accessory

attached to the phone.

DRAFT - Internal Use Only

194

Studies have shown that these products generally do not

work as advertised. Unlike “hands-free” kits, these so-called

“shields” may interfere with proper operation of the phone.

The phone may be forced to boost its power to compensate,

leading to an increase in RF absorption.

Children and Cell Phones

The scientific evidence does not show a danger to any users

of cell phones from RF exposure, including children and

teenagers. The steps adults can take to reduce RF exposure

apply to children and teenagers as well.

•

Reduce the amount of time spent on the cell phone;

•

Use speaker mode or a headset to place more distance between

the head and the cell phone.

Some groups sponsored by other national governments have

advised that children be discouraged from using cell phones

at all. For example, The Stewart Report from the United

Kingdom made such a recommendation in December 2000.

In this report, a group of independent experts noted that no

evidence exists that using a cell phone causes brain tumors

or other ill effects. Their recommendation to limit cell phone

use by children was strictly precautionary; it was not based

on scientific evidence that any health hazard exists.

Additional information on the safety of RF exposures from

various sources can be obtained from the following

organizations (updated 10/1/2010):

•

FCC RF Safety Program:

http://www.fcc.gov/oet/rfsafety/.

•

Environmental Protection Agency (EPA):

http://www.epa.gov/radtown/wireless-tech.html.

•

Occupational Safety and Health Administration (OSHA):

http://www.osha.gov/SLTC/radiofrequencyradiation/.

(Note: This web address is case sensitive.)

•

National Institute for Occupational Safety and Health (NIOSH):

http://www.cdc.gov/niosh/.

•

World Health Organization (WHO):

http://www.who.int/peh-emf/en/.

•

International Commission on Non-Ionizing Radiation Protection:

http://www.icnirp.de.

•

Health Protection Agency:

http://www.hpa.org.uk/Topics/Radiation/.

DRAFT - Internal Use Only

Health and Safety Information 195

•

US Food and Drug Administration:

http://www.fda.gov/Radiation-EmittingProducts/

RadiationEmittingProductsandProcedures/

HomeBusinessandEntertainment/CellPhones/default.htm.

Specific Absorption Rate (SAR)

Certification Information

Your wireless phone is a radio transmitter and receiver. It is

designed and manufactured not to exceed the exposure

limits for Radio Frequency (RF) energy set by the Federal

Communications Commission (FCC) of the U.S. Government.

These FCC RF exposure limits are derived from the

recommendations of two expert organizations: the National

Council on Radiation Protection and Measurement (NCRP)

and the Institute of Electrical and Electronics Engineers

(IEEE). In both cases, the recommendations were developed

by scientific and engineering experts drawn from industry,

government, and academia after extensive reviews of the

scientific literature related to the biological effects of RF

energy.

The RF exposure limit set by the FCC for wireless mobile

phones employs a unit of measurement known as the

Specific Absorption Rate (SAR). The SAR is a measure of the

rate of absorption of RF energy by the human body

expressed in units of watts per kilogram (W/kg). The FCC

requires wireless phones to comply with a safety limit of 1.6

watts per kilogram (1.6 W/kg).

The FCC SAR limit incorporates a substantial margin of safety

to give additional protection to the public and to account for

any variations in measurements.

SAR tests are conducted using standard operating positions

accepted by the FCC with the phone transmitting at its

highest certified power level in all tested frequency bands.

Although the SAR is determined at the highest certified

power level, the actual SAR level of the phone while

operating can be well below the maximum reported value.

This is because the phone is designed to operate at multiple

power levels so as to use only the power required to reach

the network. In general, the closer you are to a wireless base

station antenna, the lower the power output of the phone.

Before a new model phone is available for sale to the public,

it must be tested and certified to the FCC that it does not

exceed the SAR limit established by the FCC. Tests for each

model phone are performed in positions and locations (e.g. at

the ear and worn on the body) as required by the FCC. For

body-worn operation, this phone has been tested and meets

DRAFT - Internal Use Only

196

FCC RF exposure guidelines when used with an accessory

that contains no metal and that positions the mobile device a

minimum of X.X cm from the body.

Use of other accessories may not ensure compliance with

FCC RF exposure guidelines. The FCC has granted an

Equipment Authorization for this mobile phone with all

reported SAR levels evaluated as in compliance with the FCC

RF exposure guidelines. The maximum SAR values for this

model phone as reported to the FCC are:

•

Head: X.XX W/kg.

•

Body-worn: X.XX W/kg.

SAR information on this and other model phones can be

accessed online on the FCC's website through

http://

transition.fcc.gov/oet/rfsafety/sar.html

. To find information that

pertains to a particular model phone, this site uses the phone

FCC ID number which is usually printed somewhere on the

case of the phone. Sometimes it may be necessary to

remove the battery pack to find the number. Once you have

the FCC ID number for a particular phone, follow the

instructions on the website and it should provide values for

typical or maximum SAR for a particular phone. Additional

SAR information can also be obtained at

http://www.fcc.gov/encyclopedia/specific-absorption-rate-sar-

cellular-telephones

FCC Part 15 Information to User

Pursuant to part 15.21 of the FCC Rules, you are cautioned

that changes or modifications not expressly approved by

Samsung could void your authority to operate the device.

This device complies with part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1) This

device may not cause harmful interference, and (2) this

device must accept any interference received, including

interference that may cause undesired operation.

Note: This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to part

15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception,

DRAFT - Internal Use Only

1.0

0.22

0.50

Health and Safety Information 197

which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference

by one or more of the following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

Smart Practices While Driving

On the Road - Off the Phone

The primary responsibility of every driver is the safe

operation of his or her vehicle.

Responsible drivers understand that no secondary task

should be performed while driving whether it be eating,

drinking, talking to passengers, or talking on a mobile phone

- unless the driver has assessed the driving conditions and is

confident that the secondary task will not interfere with their

primary responsibility.

Do not engage in any activity while

driving a moving vehicle which may cause you to take your

eyes off the road or become so absorbed in the activity that

your ability to concentrate on the act of driving becomes

impaired

. Samsung is committed to promoting responsible

driving and giving drivers the tools they need to understand

and address distractions.

Check the laws and regulations on the use of mobile devices

and their accessories in the areas where you drive. Always

obey them. The use of these devices may be prohibited or

restricted in certain areas. For example, only hands-free use

may be permitted in certain areas.

Before answering calls, consider your circumstances. Let the

call go to voicemail when driving conditions require.

Remember, driving comes first, not the call!

If you consider a call necessary and appropriate, follow these

tips:

•

Use a hands-free device;

•

Secure your phone within easy reach;

•

Place calls when you are not moving;

•

Plan calls when your car will be stationary;

•

Do not engage in stressful or emotional conversations;

•

Let the person with whom you are speaking know that you are

driving and will suspend the call if necessary;

•

Do not take notes or look up phone numbers while driving;

DRAFT - Internal Use Only

198

Notice regarding legal restrictions on mounting this device in

an automobile:

Laws in some states may prohibit mounting this device on or

near the windshield of an automobile. In other states, the law

may permit mounting this device only in specific locations in

the automobile. Be sure to consult the state and local laws or

ordinances where you drive before mounting this device in

an automobile. Failure to comply with these restrictions could

result in fines, penalties, or other damages.

Never mount this device in a manner that will obstruct the

driver's clear view of the street and traffic.

Never use wireless data services such as text messaging, Web

browsing, or e-mail while operating a vehicle.

Never watch videos, such as a movie or clip, or play video

games while operating a vehicle.

For more information, go to

http://www.ctia.org

Battery Use and Safety

Important! Handle and store batteries properly to avoid injury or

damage

. Most battery issues arise from improper

handling of batteries and, particularly, from the

continued use of damaged batteries.

•

Do not disassemble, crush, puncture, shred, or otherwise

attempt to change the form of your battery

. Do not put a high

degree of pressure on the battery. This can cause leakage or an

internal short-circuit, resulting in overheating.

•

Do not let the phone or battery come in contact with liquids.

Liquids can get into the phone's circuits, leading to corrosion.

Even when the phone appears to be dry and appears to operate

normally, the circuitry could slowly corrode and pose a safety

hazard. If the phone and/or battery get wet, have them checked

by your service provider or contact Samsung, even if they appear

to be working properly.

•

Do not place your battery in or near a heat source

. Excessive

heating can damage the phone or the battery and could cause the

phone or the battery to explode. Do not dry a wet or damp battery

with an appliance or heat source such as a microwave oven, hair

dryer, iron, or radiator. Avoid leaving your phone in your car in

high temperatures.

•

Do not dispose of the phone or the battery in a fire

. The phone

or the battery may explode when overheated.

DRAFT - Internal Use Only

Health and Safety Information 199

•

Do not handle a damaged or leaking battery

. Do not let leaking

battery fluid come in contact with your eyes, skin or clothing. For

safe disposal options, contact your nearest Samsung-authorized

service center.

•

Avoid dropping the cell phone

. Dropping the phone or the

battery, especially on a hard surface, can potentially cause

damage to the phone and battery. If you suspect damage to the

phone or battery, take it to a service center for inspection.

•

Never use any charger or battery that is damaged in any way

•

Do not allow the battery to touch metal objects

. Accidental

short-circuiting can occur when a metallic object (coin, key,

jewelry, clip, or pen) causes a direct connection between the +

and - terminals of the battery (metal strips on the battery), for

example when you carry a spare battery in a pocket or bag.

Short-circuiting the terminals may damage the battery or the

object causing the short-circuiting.

Important!

Use only Samsung-approved batteries, and

recharge your battery only with

Samsung-approved chargers which are

specifically designed for your phone.

WARNING!

Use of a non-Samsung-approved battery or charger may

present a risk of fire, explosion, leakage, or other hazard

Samsung's warranty does not cover damage to the phone

caused by non-Samsung-approved batteries and/or

chargers.

•

Do not use incompatible cell phone batteries and chargers

Some websites and second-hand dealers not associated with

reputable manufacturers and carriers, might be selling

incompatible or even counterfeit batteries and chargers.

Consumers should purchase manufacturer or

carrier-recommended products and accessories. If unsure about

whether a replacement battery or charger is compatible, contact

the manufacturer of the battery or charger.

•

Misuse or use of incompatible phones, batteries, and

charging devices could result in damage to the equipment

and a possible risk of fire, explosion, or leakage, leading to

serious injuries, damages to your phone, or other serious

hazard

DRAFT - Internal Use Only

200

Samsung Mobile Products and

Recycling

Samsung cares for the environment and encourages its

customers to recycle Samsung mobile devices and genuine

Samsung accessories.

Proper disposal of your mobile device and its battery is not

only important for safety, it benefits the environment.

Batteries must be recycled or disposed of properly.

Recycling programs for your mobile device, batteries, and

accessories may not be available in your area.

We've made it easy for you to recycle your old Samsung

mobile device by working with respected take-back

companies in every state in the country.

Drop It Off

You can drop off your Samsung-branded mobile device

and batteries for recycling at one of our numerous

Samsung Recycling Direct (SM) locations. A list of these

locations may be found at:

http://pages.samsung.com/us/recyclingdirect/

usactivities_environment_samsungrecyclingdirect_locations.jsp

Samsung-branded devices and batteries will be accepted

at these locations for no fee.

Consumers may also recycle their used mobile device or

batteries at many retail or carrier-provided locations

where mobile devices and batteries are sold. Additional

information regarding specific locations may be found at:

http://www.epa.gov/epawaste/partnerships/plugin/cellphone/

index.htm

or at

http://www.call2recycle.org/

Mail It In

The Samsung Mobile Take-Back Program will provide

Samsung customers with a free recycling mailing label.

Just go to

http://www.samsung.com/us/aboutsamsung/citizenship/

usactivities_environment_samsungrecyclingdirect.html?INT=ST

A_recyle_your_phone_page

and follow the instructions to

print out a free pre-paid postage label and then send your

old mobile device or battery to the address listed, via U.S.

Mail, for recycling.

Dispose of unwanted electronics through an approved

recycler.

To find the nearest recycling location, go to our website:

www.samsung.com/recyclingdirect

Or call, (877) 278-0799.

DRAFT - Internal Use Only

Health and Safety Information 201

Follow local regulations regarding disposal of mobile

devices and batteries

Dispose of your mobile device and batteries in accordance

with local regulations. In some areas, the disposal of these

items in household or business trash may be prohibited. Help

us protect the environment - recycle!

Warning!

Never dispose of batteries in a fire because they may

explode.

UL Certified Travel Charger

The Travel Charger for this phone has met applicable UL

safety requirements. Please adhere to the following safety

instructions per UL guidelines:

FAILURE TO FOLLOW THE INSTRUCTIONS OUTLINED MAY

LEAD TO SERIOUS PERSONAL INJURY AND POSSIBLE

PROPERTY DAMAGE.

IMPORTANT SAFETY INSTRUCTIONS - SAVE THESE

INSTRUCTIONS.

DANGER - TO REDUCE THE RISK OF FIRE OR

ELECTRIC SHOCK, CAREFULLY FOLLOW THESE

INSTRUCTIONS.

FOR CONNECTION TO A SUPPLY NOT IN NORTH

AMERICA, USE AN ATTACHMENT PLUG ADAPTOR

OF THE PROPER CONFIGURATION FOR THE

POWER OUTLET.

THIS POWER UNIT IS INTENDED TO BE

CORRECTLY ORIENTED IN A VERTICAL OR

HORIZONTAL OR FLOOR MOUNT POSITION.

Display / Touch-Screen

Please note the following information when using your

mobile device:

WARNING REGARDING DISPLAY

The display on your mobile device is made of glass or

acrylic and could break if your mobile device is

dropped or if it receives significant impact. Do not use

if screen is broken or cracked as this could cause

injury to you.

DRAFT - Internal Use Only

202

WARRANTY DISCLAIMER: PROPER USE OF A

TOUCH-SCREEN MOBILE DEVICE

If your mobile device has a touch-screen display,

please note that a touch-screen responds best to a

light touch from the pad of your finger or a non-metallic

stylus. Using excessive force or a metallic object when

pressing on the touch-screen may damage the

tempered glass surface and void the warranty. For

more information, please refer to the “Standard

Limited Warranty”.

GPS

Certain Samsung mobile devices can use a Global Positioning

System (GPS) signal for location based applications. A GPS

uses satellites controlled by the U.S. Government that are

subject to changes implemented in accordance with the

Department of Defense policy and the 2008 Federal Radio

navigation Plan (FRP). Changes may affect the performance

of location-based technology on your mobile device.

Even with GPS, when you make an emergency call:

•

Always tell the emergency responder your location to the best of

your ability; and

•

Remain on the mobile device for as long as the emergency

responder instructs you.

Navigation

Maps, directions, and other navigation-data, including data

relating to your current location, may contain inaccurate or

incomplete data, and circumstances can and do change over

time. In some areas, complete information may not be

available.

Therefore, you should always visually confirm that

the navigational instructions are consistent with what you see

before following them. All users should pay attention to road

conditions, closures, traffic, and all other factors that may

impact safe driving or walking. Always obey posted road signs.

Emergency Calls

This mobile device, like any wireless mobile device, operates

using radio signals, wireless and landline networks, as well

as user-programmed functions, which cannot guarantee

connection in all conditions, areas, or circumstances.

Therefore, you should never rely solely on any wireless

mobile device for essential communications (medical

emergencies, for example). Before traveling in remote or

underdeveloped areas, plan an alternate method of

contacting emergency services personnel. Remember, to

DRAFT - Internal Use Only

Health and Safety Information 203

make or receive any calls, the mobile device must be

switched on and in a service area with adequate signal

strength.

Emergency calls may not be possible on all wireless mobile

device networks or when certain network services and/or

mobile device features are in use. Check with local service

providers.

To make an emergency call:

1. If the phone is not on, switch it on.

2. From the Home screen, tap . The dialer is

displayed.

3. Key in the emergency number for your present location

(for example, 911 or other official emergency number).

Emergency numbers vary by location.

4. Tap the key.

If certain features are in use (call blocking, for example), you

may first need to deactivate those features before you can

make an emergency call. Consult your User Manual and your

local cellular service provider. When making an emergency

call, remember to give all the necessary information as

accurately as possible. Remember that your mobile device

may be the only means of communication at the scene of an

accident; do not cut off the call until given permission to do

so.

Care and Maintenance

Your mobile device is a product of superior design and

craftsmanship and should be treated with care. The

suggestions below will help you fulfill any warranty

obligations and allow you to enjoy this product for many

years:

Keep your Samsung Mobile Device away from:

Liquids of any kind

Keep the mobile device dry. Precipitation, humidity, and

liquids contain minerals that will corrode electronic

circuits. If the mobile device does get wet, do not

accelerate drying with the use of an oven, microwave, or

dryer, because this may damage the mobile device and

could cause a fire or explosion.

Do not use the mobile device with a wet hand. Doing so

may cause an electric shock to you or damage to the

mobile device.

DRAFT - Internal Use Only

204

Extreme heat or cold

Avoid temperatures below 0°C / 32°F or above 45°C /

113°F.

Microwaves

Do not try to dry your mobile device in a microwave oven.

Doing so may cause a fire or explosion.

Dust and dirt

Do not expose your mobile device to dust, dirt, or sand.

Cleaning solutions

Do not use harsh chemicals, cleaning solvents, or strong

detergents to clean the mobile device. Wipe it with a soft

cloth slightly dampened in a mild soap-and-water

solution.

Shock or vibration

Do not drop, knock, or shake the mobile device. Rough

handling can break internal circuit boards.

Paint

Do not paint the mobile device. Paint can clog the

device’s moving parts or ventilation openings and prevent

proper operation.

Responsible Listening

Caution! Avoid potential hearing loss

Damage to hearing occurs when a person is exposed to loud

sounds over time. The risk of hearing loss increases as

sound is played louder and for longer durations. Prolonged

exposure to loud sounds (including music) is the most

common cause of preventable hearing loss. Some scientific

research suggests that using portable audio devices, such as

portable music players and cell phones, at high volume

settings for long durations may lead to permanent

noise-induced hearing loss.

This includes the use of headphones (including headsets,

earbuds, and Bluetooth® or other wireless devices).

Exposure to very loud sound has also been associated in

some studies with tinnitus (a ringing in the ear),

hypersensitivity to sound, and distorted hearing. Individual

susceptibility to noise-induced hearing loss and potential

hearing problem varies. Additionally, the amount of sound

produced by a portable audio device varies depending on the

nature of the sound, the device settings, and the headphones

DRAFT - Internal Use Only

Health and Safety Information 205

that are used. As a result, there is no single volume setting

that is appropriate for everyone or for every combination of

sound, settings, and equipment.

You should follow some common sense recommendations

when using any portable audio device:

•

Always turn the volume down before plugging the earphones into

an audio source.

•

Set the volume in a quiet environment and select the lowest

volume at which you can hear adequately.

•

Be aware that you can adapt to higher volume settings over time,

not realizing that the higher volume may be harmful to your

hearing.

•

When using headphones, turn the volume down if you cannot

hear the people speaking near you or if the person sitting next to

you can hear what you are listening to.

•

Do not turn the volume up to block out noisy surroundings. If you

choose to listen to your portable device in a noisy environment,

use noise-cancelling headphones to block out background

environmental noise. By blocking background environment noise,

noise cancelling headphones should allow you to hear the music

at lower volumes than when using earbuds.

•

Limit the amount of time you listen. As the volume increases, less

time is required before you hearing could be affected.

•

Avoid using headphones after exposure to extremely loud noises,

such as rock concerts, that might cause temporary hearing loss.

Temporary hearing loss might cause unsafe volumes to sound

normal.

•

Do not listen at any volume that causes you discomfort. If you

experience ringing in your ears, hear muffled speech, or

experience any temporary hearing difficulty after listening to your

portable audio device, discontinue use and consult your doctor.

You can obtain additional information on this subject from the

following sources:

American Academy of Audiology

11730 Plaza American Drive, Suite 300

Reston, VA 20190

Voice: (800) 222-2336

Email: info@audiology.org

Internet:

http://www.audiology.org/Pages/

default.aspx

DRAFT - Internal Use Only

206

Operating Environment

Remember to follow any special regulations in force in any

area, and always switch your mobile device off whenever it is

forbidden to use it, or when it may cause interference or

danger. When connecting the mobile device or any accessory

to another device, read its user's guide for detailed safety

instructions. Do not connect incompatible products.

Using Your Mobile Device Near Other Electronic

Devices

Most modern electronic equipment is shielded from Radio

Frequency (RF) signals. However, certain electronic

equipment may not be shielded against the RF signals from

your wireless mobile device. Consult the manufacturer to

discuss alternatives.

National Institute on Deafness and Other

Communication Disorders

National Institutes of Health

31 Center Drive, MSC 2320

Bethesda, MD 20892-2320

Email: nidcdinfo@nih.gov

Internet:

http://www.nidcd.nih.gov/

National Institute for Occupational Safety

and Health (NIOSH)

395 E Street, S.W., Suite 9200

Patriots Plaza Building

Washington, DC 20201

Voice: 1-800-35-NIOSH

(1-800-356-4674)

1-800-CDC-INFO (1-800-232-4636)

Outside the U.S. 513-533-8328

Email: cdcinfo@cdc.gov

Internet:

http://www.cdc.gov/niosh/topics/noise/

default.html

1-888-232-6348 TTY

DRAFT - Internal Use Only

Health and Safety Information 207

Implantable Medical Devices

A minimum separation of six (6) inches should be maintained

between a handheld wireless mobile device and an

implantable medical device, such as a pacemaker or

implantable cardioverter defibrillator, to avoid potential

interference with the device.

Persons who have such devices:

•

Should ALWAYS keep the mobile device more than six (6) inches

from their implantable medical device when the mobile device is

turned ON;

•

Should not carry the mobile device in a breast pocket;

•

Should use the ear opposite the implantable medical device to

minimize the potential for interference;

•

Should turn the mobile device OFF immediately if there is any

reason to suspect that interference is taking place;

•

Should read and follow the directions from the manufacturer of

your implantable medical device. If you have any questions about

using your wireless mobile device with an implantable medical

device, consult your health care provider.

For more information see:

http://www.fcc.gov/oet/rfsafety/rf-

faqs.html#

Other Medical Devices

If you use any other personal medical devices, consult the

manufacturer of your device to determine if it is adequately

shielded from external RF energy. Your physician may be able

to assist you in obtaining this information. Switch your

mobile device off in health care facilities when any

regulations posted in these areas instruct you to do so.

Hospitals or health care facilities may be using equipment

that could be sensitive to external RF energy.

Vehicles

RF signals may affect improperly installed or inadequately

shielded electronic systems in motor vehicles. Check with

the manufacturer or its representative regarding your vehicle

before using your mobile device in a motor vehicle. You

should also consult the manufacturer of any equipment that

has been added to your vehicle.

Posted Facilities

Switch your mobile device off in any facility where posted

notices require you to do so.

Potentially Explosive Environments

Switch your mobile device off when in any area with a

potentially explosive atmosphere and obey all signs and

instructions. Sparks in such areas could cause an explosion

DRAFT - Internal Use Only

208

or fire resulting in bodily injury or even death. Users are

advised to switch the mobile device off while at a refueling

point (service station).

Users are reminded of the need to observe restrictions on the

use of radio equipment in fuel depots (fuel storage and

distribution areas), chemical plants, or where blasting

operations are in progress. Areas with a potentially explosive

atmosphere are often, but not always, clearly marked. They

include below deck on boats, chemical transfer or storage

facilities, vehicles using liquefied petroleum gas (such as

propane or butane), areas where the air contains chemicals

or particles, such as grain, dust, or metal powders, and any

other area where you would normally be advised to turn off

your vehicle engine.

When your Device is Wet

Do not turn on your device if it is wet. If your device is

already on, turn it off and remove the battery immediately (if

the device will not turn off or you cannot remove the battery,

leave it as-is). Then, dry the device with a towel and take it

to a service center.

FCC Hearing Aid Compatibility (HAC)

Regulations for Wireless Devices

The U.S. Federal Communications Commission (FCC) has

established requirements for digital wireless mobile devices

to be compatible with hearing aids and other assistive

hearing devices.

When individuals employing some assistive hearing devices

(hearing aids and cochlear implants) use wireless mobile

devices, they may detect a buzzing, humming, or whining

noise. Some hearing devices are more immune than others

to this interference noise, and mobile devices also vary in the

amount of interference they generate.

The wireless telephone industry has developed a rating

system for wireless mobile devices to assist hearing device

users find mobile devices that may be compatible with their

hearing devices. Not all mobile devices have been rated.

Mobile devices that are rated have the rating on their box or

a label located on the box.

The ratings are not guarantees. Results will vary depending

on the user's hearing device and hearing loss. If your hearing

device happens to be vulnerable to interference, you may not

DRAFT - Internal Use Only

Health and Safety Information 209

be able to use a rated mobile device successfully. Trying out

the mobile device with your hearing device is the best way to

evaluate it for your personal needs.

M-Ratings

: Wireless mobile devices rated M3 or M4 meet

FCC requirements and are likely to generate less interference

to hearing devices than mobile devices that are not labeled.

M4 is the better/higher of the two ratings. M-ratings refer to

enabling acoustic coupling with hearing aids that do not

operate in telecoil mode.

T-Ratings

: Mobile devices rated T3 or T4 meet FCC

requirements and are likely to generate less interference to

hearing devices than mobile devices that are not labeled. T4

is the better/higher of the two ratings. T-ratings refer to

enabling inductive coupling with hearing aids operating in

telecoil mode.

Hearing devices may also be rated. Your hearing aid

manufacturer or hearing health professional may help you

find this rating. Higher ratings mean that the hearing device

is relatively immune to interference noise.

Under the current industry standard, American National

Standards Institute (ANSI) C63.19, the hearing aid and

wireless mobile device rating values are added together to

indicate how usable they are together. For example, if a

hearing aid meets the M2 level rating and the wireless

mobile device meets the M3 level rating, the sum of the two

values equals M5.

Under the standard, this should provide the hearing aid user

with normal use while using the hearing aid with the

particular wireless mobile device. A sum of 6 or more would

indicate excellent performance.

However, these are not guarantees that all users will be

satisfied. T ratings work similarly.

M3 + M2 = 5

T3 + T2 = 5

DRAFT - Internal Use Only

210

The HAC rating and measurement procedure are described in

the American National Standards Institute (ANSI) C63.19

standard.

HAC for Newer Technologies

This phone has been tested and rated for use with hearing

aids for some of the wireless technologies that it uses.

However, there may be some newer wireless technologies

used in this phone that have not been tested yet for use with

hearing aids.

It is important to try the different features of this phone

thoroughly and in different locations, using your hearing aid

or cochlear implant, to determine if you hear any interfering

noise. Consult your service provider or the manufacturer of

this phone for information on hearing aid compatibility. If you

have questions about return or exchange policies, consult

your service provider or phone retailer.

Restricting Children's Access to Your

Mobile Device

Your mobile device is not a toy. Do not allow children to play

with it because they could hurt themselves and others,

damage the mobile device, or make calls that increase your

mobile device bill.

Keep the mobile device and all its parts and accessories out

of the reach of small children.

FCC Notice and Cautions

FCC Notice

The mobile device may cause TV or radio interference if used

in close proximity to receiving equipment. The FCC can

require you to stop using the mobile device if such

interference cannot be eliminated. Vehicles using liquefied

petroleum gas (such as propane or butane) must comply with

the National Fire Protection Standard (NFPA-58). For a copy

of this standard, contact the National Fire Protection

Association.

Cautions

Any changes or modifications to your mobile device not

expressly approved in this document could void your

warranty for this equipment and void your authority to

operate this equipment. Only use approved batteries,

antennas, and chargers. The use of any unauthorized

accessories may be dangerous and void the mobile device

warranty if said accessories cause damage or a defect to the

mobile device.

DRAFT - Internal Use Only

Health and Safety Information 211

Although your mobile device is quite sturdy, it is a complex

piece of equipment and can be broken. Avoid dropping,

hitting, bending, or sitting on it.

Other Important Safety Information

•

Only qualified personnel should service the mobile device or

install the mobile device in a vehicle. Faulty installation or service

may be dangerous and may invalidate any warranty applicable to

the device.

•

Ensure that any mobile devices or related equipment installed in

your vehicle are securely mounted.

•

Check regularly that all wireless mobile device equipment in your

vehicle is mounted and operating properly.

•

When using a headset in dry environments, static electricity can

build up in the headset and cause a small quick static electrical

shock. To minimize the risk of electrostatic discharge from the

headset avoid using the headset in extremely dry environments or

touch a grounded unpainted metal object to discharge static

electricity before inserting the headset.

•

Do not store or carry flammable liquids, gases, or explosive

materials in the same compartment as the mobile device, its

parts, or accessories.

•

For vehicles equipped with an air bag, remember that an air bag

inflates with great force. Do not place objects, including installed

or portable wireless equipment near or in the area over the air

bag or in the air bag deployment area. If wireless equipment is

improperly installed and the air bag inflates, serious injury could

result.

•

Switch your mobile device off before boarding an aircraft. The use

of wireless mobile devices in aircraft is illegal and may be

dangerous to the aircraft's operation. Check with appropriate

authorities before using any function of a mobile device while on

an aircraft.

•

Failure to observe these instructions may lead to the suspension

or denial of cell phone services to the offender, or legal action, or

both.

•

While using your device, leave some lights on in the room and do

not hold the screen too close to your eyes.

•

Seizures or blackouts can occur when you are exposed to flashing

lights while watching videos or playing games for extended

periods. If you feel any discomfort, stop using the device

immediately.

DRAFT - Internal Use Only

212

•

Reduce risk of repetitive motion injuries. When you repetitively

perform actions, such as pressing keys, drawing characters on a

touch screen with your fingers, or playing games, you may

experience occasional discomfort in your hands, neck, shoulders,

or other parts of your body. When using your device for extended

periods, hold the device with a relaxed grip, press the keys lightly,

and take frequent breaks. If you continue to have discomfort

during or after such use, stop use and see a physician.

•

If your device has a camera flash or light, do not use the flash or

light close to the eyes of people or pets. [122011]

DRAFT - Internal Use Only

Warranty Information 213

Section 12: Warranty Information

Standard Limited Warranty

What is covered and for how long?

SAMSUNG TELECOMMUNICATIONS AMERICA, LLC

(“SAMSUNG”) warrants that SAMSUNG’s handsets and

accessories (“Products”) are free from defects in material

and workmanship under normal use and service for the

period commencing upon the date of purchase by the first

consumer purchaser and continuing for the following

specified period of time after that date:

What is not covered?

This Limited Warranty is conditioned upon proper use of the

Product.

This Limited Warranty does not cover: (a) defects or damage

resulting from accident, misuse, abnormal use, abnormal

conditions, improper storage, exposure to liquid, moisture,

dampness, sand or dirt, neglect, or unusual physical,

electrical or electromechanical stress; (b) scratches, dents

and cosmetic damage, unless caused by SAMSUNG;

of a metallic object when pressing on a touch screen;

(d) equipment that has the serial number or the

enhancement data code removed, defaced, damaged,

altered or made illegible; (e) ordinary wear and tear;

(f) defects or damage resulting from the use of Product in

conjunction or connection with accessories, products, or

ancillary/peripheral equipment not furnished or approved by

SAMSUNG; (g) defects or damage resulting from improper

testing, operation, maintenance, installation, service, or

adjustment not furnished or approved by SAMSUNG;

(h) defects or damage resulting from external causes such as

collision with an object, fire, flooding, dirt, windstorm,

lightning, earthquake, exposure to weather conditions, theft,

blown fuse, or improper use of any electrical source;

(i) defects or damage resulting from cellular signal reception

Phone 1 Year

Batteries 1 Year

Case/Pouch/Holster 90 Days

Other Phone Accessories 1 Year

DRAFT - Internal Use Only

214

or transmission, or viruses or other software problems

introduced into the Product; or (j) Product used or purchased

outside the United States. This Limited Warranty covers

batteries only if battery capacity falls below 80% of rated

capacity or the battery leaks, and this Limited Warranty does

not cover any battery if (i) the battery has been charged by a

battery charger not specified or approved by SAMSUNG for

charging the battery; (ii) any of the seals on the battery are

broken or show evidence of tampering; or (iii) the battery has

been used in equipment other than the SAMSUNG phone for

which it is specified.

What are SAMSUNG’s obligations?

During the applicable warranty period, provided the Product

is returned in accordance with the terms of this Limited

Warranty, SAMSUNG will repair or replace the Product, at

SAMSUNG’s sole option, without charge. SAMSUNG may, at

SAMSUNG’s sole option, use rebuilt, reconditioned, or new

parts or components when repairing any Product, or may

replace the Product with a rebuilt, reconditioned or new

Product.

Repaired/replaced cases, pouches and holsters will be

warranted for a period of ninety (90) days. All other repaired/

replaced Products will be warranted for a period equal to the

remainder of the original Limited Warranty on the original

Product or for ninety (90) days, whichever is longer. All

replaced Products, parts, components, boards and

equipment shall become the property of SAMSUNG. Except to

any extent expressly allowed by applicable law, transfer or

assignment of this Limited Warranty is prohibited.

What must you do to obtain warranty service?

To obtain service under this Limited Warranty, you must

return the Product to an authorized phone service facility in

an adequate container for shipping, accompanied by the

sales receipt or comparable proof of sale showing the

original date of purchase, the serial number of the Product

and the seller’s name and address.

To obtain assistance on where to deliver the Product, please

call SAMSUNG Customer Care at 1-888-987-4357. If

SAMSUNG determines that any Product is not covered by this

Limited Warranty, you must pay all parts, shipping, and labor

charges for the repair or return of such Product.

You should keep a separate backup copy of any contents of

the Product before delivering the Product to SAMSUNG for

warranty service, as some or all of the contents may be

deleted or reformatted during the course of warranty service.

DRAFT - Internal Use Only

Warranty Information 215

What are the limits on SAMSUNG’s liability?

THIS LIMITED WARRANTY SETS OUT THE FULL EXTENT OF

SAMSUNG’S RESPONSIBILITIES, AND THE EXCLUSIVE

REMEDY REGARDING THE PRODUCTS.

ALL IMPLIED WARRANTIES, INCLUDING WITHOUT

LIMITATION, IMPLIED WARRANTIES OF MERCHANTABILITY

AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO

THE DURATION OF THIS LIMITED WARRANTY. IN NO EVENT

SHALL SAMSUNG BE LIABLE FOR DAMAGES IN EXCESS OF

THE PURCHASE PRICE OF THE PRODUCT OR FOR, WITHOUT

LIMITATION, COMMERCIAL LOSS OF ANY SORT; LOSS OF

USE, TIME, DATA, REPUTATION, OPPORTUNITY, GOODWILL,

PROFITS OR SAVINGS; INCONVENIENCE; INCIDENTAL,

SPECIAL, CONSEQUENTIAL OR PUNITIVE DAMAGES; OR

DAMAGES ARISING FROM THE USE OR INABILITY TO USE THE

PRODUCT. SOME STATES AND JURISDICTIONS DO NOT

ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY

LASTS, OR THE DISCLAIMER OR LIMITATION OF INCIDENTAL

OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS

AND DISCLAIMERS MAY NOT APPLY TO YOU.

SAMSUNG MAKES NO WARRANTIES OR REPRESENTATIONS,

EXPRESS OR IMPLIED, STATUTORY OR OTHERWISE, AS TO

THE QUALITY, CAPABILITIES, OPERATIONS, PERFORMANCE

OR SUITABILITY OF ANY THIRD-PARTY SOFTWARE OR

EQUIPMENT USED IN CONJUNCTION WITH THE PRODUCT, OR

THE ABILITY TO INTEGRATE ANY SUCH SOFTWARE OR

EQUIPMENT WITH THE PRODUCT, WHETHER SUCH

THIRD-PARTY SOFTWARE OR EQUIPMENT IS INCLUDED WITH

THE PRODUCT DISTRIBUTED BY SAMSUNG OR OTHERWISE.

RESPONSIBILITY FOR THE QUALITY, CAPABILITIES,

OPERATIONS, PERFORMANCE AND SUITABILITY OF ANY

SUCH THIRD-PARTY SOFTWARE OR EQUIPMENT RESTS

SOLELY WITH THE USER AND THE DIRECT VENDOR, OWNER

OR SUPPLIER OF SUCH THIRD-PARTY SOFTWARE OR

EQUIPMENT.

Nothing in the Product instructions or information shall be

construed to create an express warranty of any kind with

respect to the Products. No agent, employee, dealer,

representative or reseller is authorized to modify or extend

this Limited Warranty or to make binding representations or

claims, whether in advertising, presentations or otherwise,

on behalf of SAMSUNG regarding the Products or this Limited

Warranty.

This Limited Warranty gives you specific legal rights, and you

may also have other rights that vary from state to state.

DRAFT - Internal Use Only

216

What is the procedure for resolving disputes?

ALL DISPUTES WITH SAMSUNG ARISING IN ANY WAY FROM

THIS LIMITED WARRANTY OR THE SALE, CONDITION OR

PERFORMANCE OF THE PRODUCTS SHALL BE RESOLVED

EXCLUSIVELY THROUGH FINAL AND BINDING ARBITRATION,

AND NOT BY A COURT OR JURY.

Any such dispute shall not be combined or consolidated with

a dispute involving any other person’s or entity’s Product or

claim, and specifically, without limitation of the foregoing,

shall not under any circumstances proceed as part of a class

action. The arbitration shall be conducted before a single

arbitrator, whose award may not exceed, in form or amount,

the relief allowed by the applicable law. The arbitration shall

be conducted according to the American Arbitration

Association (AAA) Commercial Arbitration Rules applicable to

consumer disputes. This arbitration provision is entered

pursuant to the Federal Arbitration Act. The laws of the State

of Texas, without reference to its choice of laws principles,

shall govern the interpretation of the Limited Warranty and all

disputes that are subject to this arbitration provision. The

arbitrator shall decide all issues of interpretation and

application of this arbitration provision and the Limited

Warranty.

For any arbitration in which your total damage claims,

exclusive of attorney fees and expert witness fees, are

$5,000.00 or less (“Small Claim”), the arbitrator may, if you

prevail, award your reasonable attorney fees, expert witness

fees and costs as part of any award, but may not grant

SAMSUNG its attorney fees, expert witness fees or costs

unless it is determined that the claim was brought in bad

faith. In a Small Claim case, you shall be required to pay no

more than half of the total administrative, facility and

arbitrator fees, or $50.00 of such fees, whichever is less, and

SAMSUNG shall pay the remainder of such fees.

Administrative, facility and arbitrator fees for arbitrations in

which your total damage claims, exclusive of attorney fees

and expert witness fees, exceed $5,000.00 (“Large Claim”)

shall be determined according to AAA rules. In a Large Claim

case, the arbitrator may grant to the prevailing party, or

apportion among the parties, reasonable attorney fees,

expert witness fees and costs. Judgment may be entered on

the arbitrator’s award in any court of competent jurisdiction.

This arbitration provision also applies to claims against

SAMSUNG’s employees, representatives and affiliates if any

such claim arises from the Product’s sale, condition or

performance.

DRAFT - Internal Use Only

Warranty Information 217

You may opt out of this dispute resolution procedure by

providing notice to SAMSUNG no later than 30 calendar days

from the date of the first consumer purchaser’s purchase of the

Product. To opt out, you must send notice by e-mail to

optout@sta.samsung.com, with the subject line: “Arbitration

Opt Out.” You must include in the opt out e-mail (a) your name

and address; (b) the date on which the Product was purchased;

or MEID or Serial Number, as applicable, if you have it (the IMEI

or MEID or Serial Number can be found (i) on the Product box;

(ii) on the Product information screen, which can be found

under “Settings;” (iii) on a label on the back of the Product

beneath the battery, if the battery is removable; and (iv) on the

outside of the Product if the battery is not removable).

Alternatively, you may opt out by calling 1-888-987-4357 no

later than 30 calendar days from the date of the first consumer

purchaser’s purchase of the Product and providing the same

information. These are the only two forms of notice that will be

effective to opt out of this dispute resolution procedure. Opting

out of this dispute resolution procedure will not affect the

coverage of the Limited Warranty in any way, and you will

continue to enjoy the benefits of the Limited Warranty.

Severability

If any portion of this Limited Warranty is held to be illegal or

unenforceable, such partial illegality or unenforceability shall

not affect the enforceability of the remainder of the Limited

Warranty.

Precautions for Transfer and Disposal

If data stored on this device is deleted or reformatted using

the standard methods, the data only appears to be removed

on a superficial level, and it may be possible for someone to

retrieve and reuse the data by means of special software.

To avoid unintended information leaks and other problems of

this sort, it is recommended that the device be returned to

Samsung’s Customer Care Center for an Extended File

System (EFS) Clear which will eliminate all user memory and

return all settings to default settings. Please contact the

Samsung Customer Care Center

for details.

Important!

Please provide warranty information (proof of

purchase) to Samsung’s Customer Care Center in

order to provide this service at no charge. If the

warranty has expired on the device, charges may

apply.

DRAFT - Internal Use Only

218

Samsung Telecommunications America, LLC

1301 E. Lookout Drive

Richardson, Texas 75082

Phone: 1-800-SAMSUNG

Phone: 1-888-987-HELP (4357)

rights reserved.

No reproduction in whole or in part allowed without prior

written approval. Specifications and availability subject to

change without notice. [111611]

End User License Agreement for

Software

IMPORTANT. READ CAREFULLY: This End User License

Agreement (“EULA”) is a legal agreement between you

(either an individual or a single entity) and Samsung

Electronics Co., Ltd. for software owned by Samsung

Electronics Co., Ltd. and its affiliated companies and its third

party suppliers and licensors that accompanies this EULA,

which includes computer software and may include

associated media, printed materials, “online” or electronic

documentation (“Software”).

BY CLICKING THE “I ACCEPT” BUTTON (OR IF YOU BYPASS

OR OTHERWISE DISABLE THE “I ACCEPT”, AND STILL

INSTALL, COPY, DOWNLOAD, ACCESS OR OTHERWISE USE

THE SOFTWARE), YOU AGREE TO BE BOUND BY THE TERMS

OF THIS EULA. IF YOU DO NOT ACCEPT THE TERMS IN THIS

EULA, YOU MUST CLICK THE “DECLINE” BUTTON, AND

DISCONTINUE USE OF THE SOFTWARE.

1. GRANT OF LICENSE. Samsung grants you the following

rights provided that you comply with all terms and conditions

of this EULA: You may install, use, access, display and run

one copy of the Software on the local hard disk(s) or other

permanent storage media of one computer and use the

Software on a single computer or a mobile device at a time,

and you may not make the Software available over a network

where it could be used by multiple computers at the same

time. You may make one copy of the Software in

machine-readable form for backup purposes only; provided

that the backup copy must include all copyright or other

proprietary notices contained on the original.

2. RESERVATION OF RIGHTS AND OWNERSHIP. Samsung

reserves all rights not expressly granted to you in this EULA.

The Software is protected by copyright and other intellectual

DRAFT - Internal Use Only

Warranty Information 219

property laws and treaties. Samsung or its suppliers own the

title, copyright and other intellectual property rights in the

Software. The Software is licensed, not sold.

3. LIMITATIONS ON END USER RIGHTS. You may not reverse

engineer, decompile, disassemble, or otherwise attempt to

discover the source code or algorithms of, the Software

(except and only to the extent that such activity is expressly

permitted by applicable law not withstanding this limitation),

or modify, or disable any features of, the Software, or create

derivative works based on the Software. You may not rent,

lease, lend, sublicense or provide commercial hosting

services with the Software.

4. CONSENT TO USE OF DATA. You agree that Samsung and

its affiliates may collect and use technical information

gathered as part of the product support services related to

the Software provided to you, if any, related to the Software.

Samsung may use this information solely to improve its

products or to provide customized services or technologies to

you and will not disclose this information in a form that

personally identifies you.

5. UPGRADES. This EULA applies to updates, supplements

and add-on components (if any) of the Software that

Samsung may provide to you or make available to you after

the date you obtain your initial copy of the Software, unless

we provide other terms along with such upgrade. To use

Software identified as an upgrade, you must first be licensed

for the Software identified by Samsung as eligible for the

upgrade. After upgrading, you may no longer use the

Software that formed the basis for your upgrade eligibility.

6. SOFTWARE TRANSFER. You may not transfer this EULA or

the rights to the Software granted herein to any third party

unless it is in connection with the sale of the mobile device

which the Software accompanied. In such event, the transfer

must include all of the Software (including all component

parts, the media and printed materials, any upgrades, this

EULA) and you may not retain any copies of the Software.

The transfer may not be an indirect transfer, such as a

consignment. Prior to the transfer, the end user receiving the

Software must agree to all the EULA terms.

7. EXPORT RESTRICTIONS. You acknowledge that the

Software is subject to export restrictions of various countries.

You agree to comply with all applicable international and

national laws that apply to the Software, including the U.S.

Export Administration Regulations, as well as end user, end

use, and destination restrictions issued by U.S. and other

governments.

DRAFT - Internal Use Only

220

8. TERMINATION. This EULA is effective until terminated. Your

rights under this License will terminate automatically without

notice from Samsung if you fail to comply with any of the

terms and conditions of this EULA. Upon termination of this

EULA, you must cease all use of the Software and destroy all

copies, full or partial, of the Software.

9. THIRD-PARTY APPLICATIONS. Certain third-party

applications may be included with, or downloaded to this

mobile device. SAMSUNG makes no representations

whatsoever about any of these applications. Since SAMSUNG

has no control over such applications, Purchaser

acknowledges and agrees that SAMSUNG is not responsible

for the availability of such applications and is not responsible

or liable for any content, advertising, products, services, or

other materials on or available from such applications.

Purchaser expressly acknowledges and agrees that use of

third-party applications is at Purchaser’s sole risk and that

the entire risk of unsatisfactory quality, performance,

accuracy and effort is with Purchaser. It is up to Purchaser to

take precautions to ensure that whatever Purchaser selects

to use is free of such items as viruses, worms, Trojan horses,

and other items of a destructive nature. References on this

mobile device to any names, marks, products, or services of

any third-parties are provided solely as a convenience to

Purchaser, and do not constitute or imply an endorsement,

sponsorship, or recommendation of, or affiliation with the

third-party or its products and services. Purchaser agrees

that SAMSUNG shall not be responsible or liable, directly or

indirectly, for any damage or loss caused or alleged to

caused by, or in connection with, use of or reliance on any

such third-party content, products, or services available on

or through any such application. Purchaser acknowledges

and agrees that your use of any third-party application is

governed by such third-party application provider’s Terms of

Use, License Agreement, Privacy Policy, or other such

agreement and that any information or personal data you

provide, whether knowingly or unknowingly, to such third-

party application provider, will be subject to such third-party

application provider’s privacy policy, if such a policy exists.

SAMSUNG DISCLAIMS ANY RESPONSIBILITY FOR ANY

DISCLOSURE OF INFORMATION OR ANY OTHER PRACTICES

OF ANY THIRD-PARTY APPLICATION PROVIDER.

10. Disclaimer of Warranty Regarding Third-Party

Applications. SAMSUNG DOES NOT WARRANT OR MAKE ANY

REPRESENTATIONS REGARDING THE AVAILABILITY, USE,

TIMELINESS, SECURITY, VALIDITY, ACCURACY, OR

RELIABILITY OF, OR THE RESULTS OF THE USE OF, OR

OTHERWISE RESPECTING, THE CONTENT OF ANY

DRAFT - Internal Use Only

Warranty Information 221

THIRD-PARTY APPLICATION WHETHER SUCH THIRD-PARTY

APPLICATION IS INCLUDED WITH THE PRODUCT

DISTRIBUTED BY SAMSUNG, IS DOWNLOADED, OR

OTHERWISE OBTAINED. USE OF ANY THIRD-PARTY

APPLICATION IS DONE AT PURCHASER’S OWN DISCRETION

AND RISK AND PURCHASER IS SOLELY RESPONSIBLE FOR

ANY DAMAGE TO YOUR MOBILE DEVICE OR LOSS OF DATA

THAT RESULTS FROM THE DOWNLOADING OR USE OF SUCH

THIRD-PARTY APPLICATIONS. SAMSUNG EXPRESSLY

DISCLAIMS ANY WARRANTY REGARDING WHETHER

PURCHASER’S PERSONAL INFORMATION IS CAPTURED BY

ANY THIRD-PARTY APPLICATION PROVIDER OR THE USE TO

WHICH SUCH PERSONAL INFORMATION MAY BE PUT BY

SUCH THIRD-PARTY APPLICATION PROVIDER. ANY

THIRD-PARTY APPLICATIONS PROVIDED WITH THIS MOBILE

DEVICE ARE PROVIDED “AS IS” AND ON AN “AS AVAILABLE”

BASIS, WITHOUT WARRANTIES OF ANY KIND FROM

SAMSUNG, EITHER EXPRESS OR IMPLIED. TO THE FULLEST

EXTENT POSSIBLE PURSUANT TO APPLICABLE LAW,

SAMSUNG DISCLAIMS ALL WARRANTIES EXPRESS, IMPLIED,

OR STATUTORY, INCLUDING, BUT NOT LIMITED TO, IMPLIED

WARRANTIES OF MERCHANTABILITY, SATISFACTORY

QUALITY OR WORKMANLIKE EFFORT, FITNESS FOR A

PARTICULAR PURPOSE, RELIABILITY OR AVAILABILITY,

ACCURACY, LACK OF VIRUSES, QUIET ENJOYMENT,

NON-INFRINGEMENT OF THIRD PARTY RIGHTS OR OTHER

VIOLATION OF RIGHTS. SAMSUNG DOES NOT WARRANT

AGAINST INTERFERENCE WITH YOUR ENJOYMENT OF THE

THIRD-PARTY APPLICATION, THAT THE FUNCTIONS

CONTAINED IN THE THIRD-PARTY APPLICATION WILL MEET

PURCHASER’S REQUIREMENTS, THAT THE OPERATION OF

THE THIRD-PARTY APPLICATION WILL BE UNINTERRUPTED

OR ERROR-FREE, OR THAT DEFECTS IN THE THIRD-PARTY

APPLICATION WILL BE CORRECTED. PURCHASER ASSUMES

THE ENTIRE COST OF ALL NECESSARY SERVICING, REPAIR,

OR CORRECTION. SOME JURISDICTIONS DO NOT ALLOW

EXCLUSIONS OR LIMITATIONS ON HOW LONG AN IMPLIED

WARRANTY LASTS, SO THE ABOVE LIMITATIONS OR

EXCLUSIONS MAY NOT APPLY TO YOU. NO ADVICE OR

INFORMATION, WHETHER ORAL OR WRITTEN, OBTAINED BY

PURCHASER FROM SAMSUNG SHALL BE DEEMED TO ALTER

THIS DISCLAIMER OF WARRANTY REGARDING THIRD-PARTY

APPLICATIONS, OR TO CREATE ANY WARRANTY.

11. Limitation of Liability. SAMSUNG WILL NOT BE LIABLE

FOR ANY DAMAGES OF ANY KIND ARISING OUT OF OR

RELATING TO THE USE OR THE INABILITY TO USE ANY

THIRD-PARTY APPLICATION, ITS CONTENT OR

FUNCTIONALITY, INCLUDING BUT NOT LIMITED TO DAMAGES

DRAFT - Internal Use Only

222

CAUSED BY OR RELATED TO ERRORS, OMISSIONS,

INTERRUPTIONS, DEFECTS, DELAY IN OPERATION OR

TRANSMISSION, COMPUTER VIRUS, FAILURE TO CONNECT,

NETWORK CHARGES, AND ALL OTHER DIRECT, INDIRECT,

SPECIAL, INCIDENTAL, EXEMPLARY, OR CONSEQUENTIAL

DAMAGES EVEN IF SAMSUNG HAS BEEN ADVISED OF THE

POSSIBILITY OF SUCH DAMAGES. SOME JURISDICTIONS DO

NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL

OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION

OR EXCLUSION MAY NOT APPLY TO YOU. NOT

WITHSTANDING THE FOREGOING, SAMSUNG’S TOTAL

LIABILITY TO PURCHASER FOR ALL LOSSES, DAMAGES,

CAUSES OF ACTION, INCLUDING BUT NOT LIMITED TO THOSE

BASED ON CONTRACT, TORT, OR OTHERWISE, ARISING OUT

OF PURCHASER’S USE OF THIRD-PARTY APPLICATIONS ON

THIS MOBILE DEVICE, OR ANY OTHER PROVISION OF THIS

EULA, SHALL NOT EXCEED THE AMOUNT PURCHASER PAID

SPECIFICALLY FOR ANY SUCH THIRD-PARTY APPLICATION

THAT WAS INCLUDED WITH THIS MOBILE DEVICE. THE

FOREGOING LIMITATIONS, EXCLUSIONS, AND DISCLAIMERS

(INCLUDING SECTIONS 9, 10, AND 11) SHALL APPLY TO THE

MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, EVEN IF

ANY REMEDY FAILS ITS ESSENTIAL PURPOSE.

12. U.S. Government End Users Restricted Rights. The

Software is licensed only with "restricted rights" and as

"commercial items" consisting of "commercial software"

and "commercial software documentation" with only those

rights as are granted to all other end users pursuant to the

terms and conditions herein. All Software and Products

provided to the United States Government pursuant to

solicitations issued on or after December 1, 1995 is provided

with the commercial rights and restrictions described

elsewhere herein. All Software and Products provided to the

United States Government pursuant to solicitations issued

prior to December 1, 1995 are provided with RESTRICTED

RIGHTS as provided for in FAR, 48 CFR 52.227-14 (JUNE

1987) or DFAR, 48 CFR 252.227-7013 (OCT 1988), as

applicable.

13. APPLICABLE LAW. This EULA is governed by the laws of

TEXAS, without regard to conflicts of laws principles. This

EULA shall not be governed by the UN Convention on

Contracts for the International Sale of Goods, the application

of which is expressly excluded. If a dispute, controversy or

difference is not amicably settled, it shall be finally resolved

by arbitration in Seoul, Korea in accordance with the

DRAFT - Internal Use Only

Warranty Information 223

Arbitration Rules of the Korean Commercial Arbitration Board.

The award of arbitration shall be final and binding upon the

parties.

14. ENTIRE AGREEMENT; SEVERABILITY. This EULA is the

entire agreement between you and Samsung relating to the

Software and supersedes all prior or contemporaneous oral

or written communications, proposals and representations

with respect to the Software or any other subject matter

covered by this EULA. If any provision of this EULA is held to

be void, invalid, unenforceable or illegal, the other provisions

shall continue in full force and effect.

DRAFT - Internal Use Only

Samsung Product Registration 224

Section 13: Samsung Product Registration

www.samsung.com/register

Get More

• Latest info on promotions, events and special oers on related products

• Review Samsung products and share your opinion

• Great deals on downloads

Customize your Samsung device experience

• Activate product warranty

• Access to a personalized My Samsung Mobile account

• No monthly fees

Scan this code to go

directly to the registration page.

DRAFT - Internal Use Only

225

Index

Abc mode 65

Accounts 133

adding a Google account 69

setting up 68

Add accounts 133

Airplane mode 112, 119, 124

Alarm 172

AllShare Cast 111

AllShare Play 166

Configuring Settings 167

Group Cast 169

Sharing Media 169

Web Storage Setup 168

Applications

Using the Camcorder 91

Using the Camera 87

World Clock 174

Applications settings

allow mock locations 147

managing 132

running services 132

stay awake 147

USB debugging 147

Back key 31

Battery

charging 9

Installing 8

Low Battery Indicator 11

Battery Use & Safety 198

Bigger Font

Setting 145

Bluetooth

Outgoing Headset Condition 59

Sending contacts 163

Books

Play Books 183

Calculator 170

Calendar 170

Call Functions 46

3-Way Calling (Multi-Party Calling)

Address Book 49

Adjusting the Call Volume 53

Answering a Call 49

Call Back Missed Call 51

Call Duration 53

Call Log 50

Call Waiting 57

Correcting the Number 47

Dialing a Recent Number 47

Ending a Call 47

International Call 46

Making a Call 46

Manual Pause Dialing 46

Options During a Call 53

Putting a Call on Hold 54

Saving a recent call number to

Address Book 51

Searching for a Number in

Address Book 57

DRAFT - Internal Use Only

226

Using the Speakerphone 56

Viewing All Calls 51

Viewing Missed Calls 51

Camcorder 91

Camcorder Options 92

Shooting Video 92

Camcorder Options

Camcorder Options after a Video is

Taken 94

Camera 87

Camera Options 88

Lock Screen Shortcut 134

Taking Pictures 87

Camercorder

Taking Pictures During Video 93

Care and Maintenance 203

Changing Your Settings 108

Charging battery 9

ChatON 105

Adding a Buddy 106

Using 106

Children and Cell Phones 194

Clock 135, 172

Contacts

creating 69

creating from Call log 71

creating from the Keypad 71

exporting and importing 74

groups 75

joining 73

My Profile 73

namecards 74

speed dials 77

starred contacts 75

updating 71

updating from Call log 72

updating from Keypad 71

Emptying 154

Creating a Playlist 83

Dialing Options 50

Display

icons 23

Using Negative Colors 145

Display / Touch-Screen 201

Do cell phones pose a health

hazard? 190

Downloads 176

Email 101

Creating a Corporate Email

Account 102

Creating Additional Email

Accounts 102

Switching Between Email

Accounts 102

Emergency Calls 202

Making 47

With SIM 48

Without SIM 47

Entering Text 64

Changing the Text Entry Mode 65

Using 123Sym Mode 66

Using Abc Mode 65

Using Swype 67

Using Symbol/Numeric Mode 66

Exposure to Radio Frequency (RF)

Signals 190

DRAFT - Internal Use Only

227

FCC Hearing Aid Compatibility (HAC)

Regulations for Wireless Devices 208

FCC Notice and Cautions 210

Featured Apps 176

Font Size

Changing 145

Gallery 86

viewing pictures 86

viewing videos 86

Gestures

Browse Image 33, 129

Overview 32

Screen Capture 33, 129

Shake to Update 33, 129

Tilt to Zoom 33, 129

Getting Started 6

Setting Up Your Phone 6

Voice mail 13

Gmail 103

Google

managing an account 69

setting up an account 69

Google Maps 179

Google Play Music 84

Google Voice Typing 67

Google voice typing settings 138

GPS 202

Group Cast 169

Groups

adding contacts 76

creating 76

sending a message 77

Health and Safety Information 190

Home City

Setting 135

Home key 31

Home screen mode 117

Hotspot Guru 160

Hotspots 160

Icons

Application 26

Indicator 23

Icons, description 23

In-Call Options 53

Incognito 152

Create Window 152

Exit Window 152

Information Ticker 134

International Call 46

Internet 150

Keyboard Input Methods 138

Keyboard settings 139

Keypad

Changing Text Input 65

Kies via Wi-Fi 114

Landscape 64

Language and keyboard settings

select locale 138

Latitude 177

Local 178

Location services settings 133

Lock Screen

Camera Quick Access 134

Clock 135

Dual Clock 135

Ripple Effect 135

DRAFT - Internal Use Only

228

Say Wake-Up Command 135

Shortcuts 134

Ticker 134

Weather 135

Maps 179

Media Hub 28, 79

Memory Card 44

Memory Card Installation 8

key 31

Menu Navigation 31

Message

Reply 106

Message Options 96

Message Search 99

Messaging

Creating and Sending Text

Messages 95

Deleting a message 99

Gmail 103

Options 96

Settings 100

Signing into Email 101

Signing into Gmail 103

Types of Messages 95

microSD card 8, 44

Installing 8

Removing 9

microSDHC card 8, 44

Mobile networks

settings 119

Mobile Web 150

Entering Text in the Mobile Web

Browser 151

Navigating with the Mobile Web

150

Using Bookmarks 152

Mono

Audio Setup 145

Motion 130

Movies 85

Multimedia 79

Music File Extensions

3GP 81

AAC 81

AAC+ 81

eAAC+ 81

M4A 81

MP3 81

MP4 81

WMA 81

Music Player 81

adding music 83

creating a playlist 83

removing music 83

Mute 54, 57

My Files 180

My Profile 73

sending 73

Namecards

sending 74

Navigation 181

command keys 31

context-sensitive menus 32

terms used 31

touch gestures 31

Navigation Options 182

Negative Colors 145

NFC 165

DRAFT - Internal Use Only

229

One-handed operation 117

Operating Environment 206

Other Important Safety Information

211

Owner information 135

PC Connections 163

Pen Settings 143

Phone

Front View 16

icons 23

Rear View 18

Side View 17

Switching On/Off 11

Pictures 86

Gallery 86

Places 183

Play Books 183

Play Movies 85

Play Music 84

Play Store 184

Polaris® Office 29

Portable Wi-Fi hotspot 114

Powering

Off 11

On 11

Privacy settings

factory data reset 143

QWERTY keypad 64

Ready2Go 12

Reducing Exposure

Hands-Free Kits and Other

Accessories 193

Reject list 53

Reset

factory data 143

Responsible Listening 204

Restricting Children's Access to Your

Mobile device 210

Ripple 135

Ripple Effect

Lock Screen 135

S Memo

Creating a New Memo 185

S Pen

Settings 143

S Suggest 186

S Voice 186

Set Wake-Up Command 135

Samsung Apps 187

Samsung Mobile Products and Recy-

cling 200

Screen Capture 33, 129, 170

SD Card 44

Security settings

trusted credentials 137

Settings 108

Shortcuts 22

SIM card

installation 7

Installing 7

SIP account 63

Smart Practices While Driving 197

Snooze 173

Speakerphone Key 56

DRAFT - Internal Use Only

230

Specific Absorption Rate (SAR)

Certification Information 195

Speed Dials

assigning 77

removing or reassigning 78

Standard Limited Warranty 213

Stopwatch 174

SugarSync

Setup 168

Swap 55

SWYPE

entering text using 67

Symbol/Numeric mode 66

Synchronization settings

auto-sync 133

T9 Trace 139

see Swype 139

Tethering 114

Text Input

Abc mode 65

Methods 64

numeric mode 66

symbol mode 66

Timer 174

Automatic Answering 59

Touch key light duration 118

Touch Screen 12

Lock/Unlock 12

Travel Charger 9

Using 10

TTY Mode 62

UL Certified Travel Charger 201

Understanding Your Phone 15

Features of Your Phone 15

Front View 16

Rear View 18

Side Views 17

Unmute 54

USB settings

mass storage device 164

USB Tethering 114

Using Favorites

Adding Favorites 153

Deleting a Favorite 153

Editing Favorites 153

Video Player 84

Voice Mail

Accessing 14

From Another Phone 14

Setup 13

Voice Recorder 187

Voice Settings 141

VPN

settings 124

Warranty Information 213

Weather

Setting 135

Web 150

Widgets

Calculator 26

Camera 27

Email 27

Gmail 28, 176

Settings 30, 187

Video Player 30

Voice Recorder 30, 187

YouTube 30

DRAFT - Internal Use Only

231

Wi-Fi 156

using Kies via Wi-Fi 111

Wi-Fi Direct 115, 158

World Clock

Deleting an Entry 174

World clock 174

YouTube 188

DRAFT - Internal Use Only

Samsung Electronics Co SCHR950 Cellular/ AWS/ PCS CDMA Phone with LTE, WLAN, Bluetooth and RFID User Manual i317 M

Samsung Electronics Co Ltd Cellular/ AWS/ PCS CDMA Phone with LTE, WLAN, Bluetooth and RFID i317 M

Users Manual

Navigation menu

Namespaces

Views

Navigation
