Samsung Electronics Co SCHS369 Cellular CDMA Phone User Manual S259
Samsung Electronics Co Ltd Cellular CDMA Phone S259
Users Manual
* Depending on the software installed or your service provider or country, some of the descriptions in this guide
may not match your phone exactly.
* Depending on your country, your phone and accessories may appear different from the illustrations in this guide.
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-XXXXXA
English. 10/2007. Rev. 1.0
SCH-S369
User’s Guide
Draft 01
2007. 10. 9
Important safety
precautions
Drive safely at all times
Do not use a hand-held phone while driving. Park
your vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using
them in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Failure to comply with the following
precautions may be dangerous or illegal.
1
Be aware of special regulations
Meet any special regulations in force in any area
and always switch off your phone whenever it is
forbidden to use it, or when it may cause
interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to your ear).
Avoid unnecessary contact with the antenna when
the phone is switched on.
Emergency calls
Key in the emergency number for your present
location, then press .
Keep your phone away from small children
Keep the phone and all its parts, including
accessories, out of the reach of small children.
Accessories and batteries
Use only Samsung-approved batteries and
accessories, such as headsets and PC data cables.
Use of any unauthorised accessories could damage
you or your phone and may be dangerous.
Use of authorised software
Use only Samsung-authorised software. The use of
any unauthorised software could damage your
phone.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health
and safety information" on page 35.
• The phone could explode if the battery is
replaced with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.
At very high volumes, prolonged listening
to a headset can damage your hearing.
2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone.
In this guide, the following instruction icons
appear:
Indicates that you need to pay careful
attention to the subsequent information
regarding safety or phone features.
→
Indicates that you need to press the
Navigation keys to scroll to the specified
option and then select it.
[ ] Indicates a key on the phone.
For example, [ ]
< > Indicates a soft key, whose function is
displayed on the phone screen. For
example, <
Menu
>
• Camera and camcorder
Use the camera module on
your phone to take a photo or
record a video.
Special
features of your phone
•MP3 player
Play music files using your
phone as an MP3 player.
•FM radio
Listen to your favourite radio
stations anytime, anywhere.
3
• Photo studio
Add a frame or apply special
effects to decorate your
photos.
• Flight mode
Switch your phone to Flight
mode to use its non-wireless
functions while on an airplane.
•Web browser
Access the wireless web to get
up-to-the-minute information
and a wide variety of media
content.
•SOS message
Send SOS messages to your
family or friends for help in an
emergency.
•Memory disk
Connect your phone to a PC to
copy files directly to and from
it.
•Calendar
Keep track of your daily,
weekly, and monthly schedule.
4
Contents
Unpack 6
Make sure you have each item
Get started 6
First steps to operating your phone
Assemble and charge the phone ...................... 6
Power on or off.............................................. 7
Phone layout ................................................. 7
Keys and icons .............................................. 8
Access menu functions .................................. 11
Enter text .................................................... 11
Customise your phone................................... 15
Use an optional memory card ......................... 17
Step outside the phone 18
Begin with call functions, camera, MP3 player, web
browser, and other special features
Make or answer calls..................................... 18
Use the camera............................................ 19
Play music................................................... 20
Listen to the FM radio ................................... 22
Browse the web ........................................... 23
Use Contacts ............................................... 24
Send or view messages................................. 25
Menu functions 26
All menu options listed
Health and safety information 35
5
1 Calls
1 Missed
2 Incoming
3 Outgoing
4 Air time
5 Call forward
6 Call waiting
7 Area code
8 Call reject
9 Int’l call prefix
2 Contacts
1 Find
2 Add
3 Group settings
4 Speed dial
5 My phone #
6 Memory info
3 Camera
1 Take photo
2 My album
3 Camera
4 Photo studio
5 Settings
4 Display
1 Animation
2 Banner
3 Backlight
4 Set time
5 Contrast
6 Dialing font
5 Message
1 New message
2 Inbox
3 Outbox
4 Drafts
5 Settings
6 SOS message
7 Memory info
6 Sounds
1 Ringer
2 Ringer Vol./Type
3 Function alert
7 Entertainment
1 FM radio
2 Games
3 Voice memo
8 Utilities
1 View month
2 Date
3 Alarm
4 User memory
5 Calculator
6 Today
7 Task list
8 Memo pad
9 Countdown
0 World time
9 Settings
1 Auto key lock
2 Answer mode
3 Flight mode
4 Security
5 Entry method
6 Thai/Language
7 Contents status
8 Domain preset
Overview of menu functions
To access Menu mode, press <
Menu
> in Idle mode.
6
Unpack
Make sure you have each item
• Phone
•Travel adapter
•Battery
•User’s Guide
You can obtain various accessories from your
local Samsung dealer.
Get started
First steps to operating your phone
Assemble and charge the phone
• The items supplied with your phone and the
accessories available at your Samsung dealer
may vary, depending on your country or
service provider.
• Use the purchased accessories with only
Samsung-authorised devices. The use of
these accessories with other devices could
cause problems and any repair costs would
not be covered by the warranty.
7
Removing the battery cover
Power on or off
Phone layout
Front view
Switch on
1. Press and hold [ ].
2. If necessary, enter the
PIN and press <
OK
>.
Switch off
Press and hold [ ].
Get started
8
Rear view
Keys and icons
Keys
You can lock the keypad to prevent any
unwanted phone operations from accidentally
pressing any of the keys. In Idle mode, press
and hold [ ]. To unlock the keypad, press the
left soft key and then [ ].
Soft
keys
Perform the function indicated on
the bottom line of the display.
Navigat
ion
keys
In Idle mode, access the following
menus:
•Up:
FM radio
•Down:
Magic
•Left:
Message
• Right: your favourite menus
In Menu mode, scroll through menu
options.
9
Wap
key
In Idle mode, launch the web
browser.
In Menu mode, perform the
functions indicated on the bottom
line of the display.
Send
key
Make or answer a call.
In Idle mode, retrieve the numbers
recently dialled, missed, or received.
C(Clear
)
key
Delete characters from the display.
In Menu mode, return the display to
the previous menu level.
End
key
Press and hold to switch the phone
on or off.
End a call.
In Menu mode, cancel input and
return the phone to Idle mode.
Numeri
c keys
Enter numbers, letters, and some
special characters.
In Idle mode, press and hold [
0
] to
enter an international call prefix.
Special
key
Enter special characters or perform
special functions.
In Idle mode, press and hold [ ] to
lock the keypad.
In Idle mode, press and hold [ ] to
activate or deactivate Silent mode.
Camera
key
In Idle mode, enter the
Multimedia
menu. Press and hold to turn on the
camera.
In Camera mode, take a photo or
record a video.
Volume
key
Adjust the phone volume.
Get started
10
Icons
The following icons may appear on the top line
of the screen to indicate your phone’s status.
Depending on your country or service provider,
the icons shown on the display may vary.
Signal strength
Roaming network
Call in progress
Out of your service area or Flight
mode
Transferring data in 1X network
Connected to a secured web page
Memory card inserted
Lock mode
Keys locked
New message:
•: Text message
•: Email in Inbox
• : Urgent text message
•: Web alert
SOS message feature active
Alarm status
Ringer type:
•: Ringer only
• : Silent
•: Vibration
•: Vib. & ringer
• : Vib. then ringer
• : Ringer then vib.
Silent mode
11
Access menu functions
Enter text
SSR (Simple Smart Ringtone) mode
Battery power level
Select an
option
1. Press a desired soft key.
2. Press the Navigation keys
to move to the next or
previous option.
3. Press <
Select
>, <
Save
>
to confirm the function
displayed or option
highlighted.
4. Press [
C
] to move up one
level.
Press [ ] to return to Idle
mode.
Use menu
numbers
Press the number key
corresponding to the option
you want.
Change the
text input
mode
1. In the text entry screen,
press the right soft key.
2. Select the mode you want.
ABC mode
To e nt er a wo rd :
Press the appropriate key until
the character you want appears
on the display.
Get started
12
English
word mode
To enter a w ord :
1. Press [
2
] to [
9
] to start
entering a word.
2. Enter the whole word before
editing or deleting
characters.
3. When the word displays
correctly, press [ ] to insert
a space.
Otherwise, press [
0
] to
display alternative word
choices.
Number
mode
Press the keys corresponding to
the digits you want.
Symbol
mode
Press the corresponding number
key to select a symbol.
Copy and
paste text
1. In a text input field, press
<
Options
> and select
Copy/Paste
→
Manual
copy
.
To copy the whole text,
select
Full copy
.
2. Highlight the text you want
and press <
Select
>.
3. Press <
Options
> and select
Copy/Paste
→
Paste
to
paste the copied text.
13
Customise your phone
Other
operations
•Press [
1
] to enter
punctuation marks or special
characters in ABC mode and
English word mode.
• Press [ ] to change case in
ABC mode and English word
mode.
• Press and hold [ ] to quickly
switch to Symbol mode.
• Press the Navigation keys to
move the cursor.
•Press [
C
] to delete
characters one by one.
•Press and hold [
C
] to clear
the characters on the left
side of the cursor.
1. In Idle mode, press
<
Menu
> and select
Settings
→
Thai/
Language
.
2. Select a language.
1. In Idle mode, press
<
Menu
> and select
Sounds
→
Ringer
.
2. Press [Left] or [Right] to
select an item type.
3. Press [Down] and then
Press [Left] or [Right] to
select a ringtone category.
Display
language
Call ringer
melody
Get started
14
4. Scroll to a ringtone and
press <
Play
> to listen to a
melody.
5. Press <
Save
>.
In Idle mode, press [Volume]
to adjust the key tone volume.
1. In Idle mode, press
<
Menu
> and select
Display
→
Screen saver
→
.
2. Select a category.
3. Press [Left] or [Right] to
select an image.
4. Press <
Save
> or <
Select
>.
Key tone
volume
Idle mode
wallpaper
To set a shortcut:
1. In Idle mode, press [Right].
2. Scroll to an empty location.
3. Press <
Options
> and
select
Register
.
4. Select a menu to be
assigned to the key and
press <
Regist
>.
5. Select an icon for the
menu.
To access a menu:
In Idle mode, press [Right]
and select the menu icon you
want.
Shortcuts for
your
favourite
menus
15
You can switch the phone to
Silent mode to avoid disturbing
other people. In Idle mode,
press and hold [ ].
You can use SSR (Simple Smart
Ringtone) mode. The phone will
alert you to incoming calls in
noisy places by simultaneously
vibrating and ringing at the
highest volume. In Idle mode,
press and hold [
C
].
Silent mode
SSR mode
1. In Idle mode, press
<
Menu
> and select
Settings
→
Security
.
2. Enter a new 4- to 8-digit
password and press
<
Done
>.
3. Enter the new password
again and press <
Done
>.
4. Select
Lock mode
.
5. Select
Once
or
On
.
Phone lock
16
Step outside the phone
Begin with call functions, camera, web browser,
and other special features
Make or answer calls
1. In Idle mode, enter an area
code and phone number.
2. Press [ ].
Press [Volume] to adjust
the volume.
3. Press [ ] to end the call.
1. When the phone rings,
press [ ].
2. Press [ ] to end the call.
Make a call
Answer a call
If you subscribe to the three-
way calling service, you can
have a conversation with two
other people simultaneously.
1. During a call, make
another call. The first call
is put on hold.
2. Press [ ] to begin the
three-way call.
Make a
three-way
call
17
Use the camera
1. In Idle mode, press and
hold [Camera] to turn on
the camera.
2. Aim the lens at the subject
and make any desired
adjustments.
3. Press[Camera] to take a
photo.
4. Press <
Save
>.
1. In Idle mode, press
[Camera] and select
My
album
→
Single
or
Multi
.
2. Select the photo you want.
Take a photo
View a photo
1. In Idle mode, press and
hold [Camera] to turn on
the camera.
2. Press [
1
] three times to
switch to Record mode.
3. Press [Camera] to start
recording.
4. Press [Camera] to stop
recording.
5. Press <
Save
>.
1. In Idle mode, press
[Camera] and select
My
album
→
Video cam
.
2. Select the video you want.
3. Press <
Play
>.
Record
a video
View a video
18
Listen to the FM radio
1. Plug the connecter of the
supplied headset into the
multi-function jack on the
phone.
2. In Idle mode, press [Up].
3. Press <
On
> to turn on the
radio.
4. Press [Left] or [Right] to
find available radio
stations.
You can also press and hold
[Left] or [Right].
5. Press <
Off
> to turn off the
radio.
Listen to
the radio
By automatic tuning:
1. From the radio screen,
press <
Options
> and
select
Self tuning
.
2. Press <
Yes
> to confirm.
Available radio stations are
automatically saved.
By manual setup:
1. From the radio screen,
press [Left] or [Right] to
select the station you want.
2. Press <
Options
> and
select
Save channel
.
3. Select a location in which
you want to store the
station.
Store radio
stations
19
Use Contacts
1. In Idle mode, enter a phone
number and press <
Save
>.
2. Select
New entry
.
3. Press <
Edit
>.
4. Enter a name and press
<
Save
>.
5. To add a contact to the
phone’s memory, press
[Left] or [Right] and select
a number type.
6. Specify contact information.
7. Press
<
Save
>
to save the
contact.
Add a contact
1. In Idle mode, press
<
Search
>.
2. Select a search method.
3. Enter the first few letters of
the name you want, select
a contact group, or select a
memory location.
4. Select a contact.
5. Scroll to a number and
press [ ] to dial, or press
<
Edit
> to edit contact
information.
Find a
contact
Step outside the phone
20
Send or view messages
1. In Idle mode, press [Left]
and select
New message
.
2. Enter the message text and
press <
Next
>.
3. Press <
Next
> again.
4. Enter destination numbers.
5. Press <
Send
> to send the
message.
1. In Idle mode, press [Left]
and select
Inbox
→
Text
.
2. Select a text message.
Send a text
message
View a text
message
21
Menu functions
All menu options listed
This section provides brief explanations of
menu functions on your phone.
Calls
Menu Description
Missed,
Incoming,
Outgoing,
Rejected
Check the most recent calls
dialled, received, missed,
or rejected.
Air time Check the time record for
calls made and received.
Area code Find and retrieve area or
country codes to quickly
and easily dial phone
numbers.
Call reject Make a list of numbers and
groups from which you
want to reject calls, and set
how to reject those calls.
Call settings Set up various settings for
making or answering a call.
You can also switch the
phone to Flight mode, in
which the phone functions
requiring network
connection are deactivated.
Menu Description
Menu functions
22
Contacts Camera
Menu Description
Find Search for contact
information stored in
Contacts.
Add Add a new contact to
Contacts.
Group settings Set up a caller group list
for organising contacts.
Speed dial Assign a speed dial number
for your most frequently
dialled numbers.
My phone # Check your phone number,
or edit your number.
Memory info Check memory information
for contacts.
Menu Description
Take photo Take photos and record
videos.
My album Access the photos you
have taken and the videos
you have recorded.
Photo studio Edit photos by applying
special effects or adding
frames.
Settings Change the default settings
for the options when using
the camera.
23
Display
Menu Description
Screen saver Change the background
image or set a banner
message to be displayed
on the idle screen.
Functional
screen
Select a function screen to
be displayed in Idle mode.
Power On/Off Select the image that the
phone displays when it is
switched on or off.
Dialing font Select a font colour for
digits to be displayed when
you enter a phone number
for dialling.
Time settings Set the current time and
date or set up the time
zones for the dual clock
wallpaper.
Backlight
→
Main
LCD
Select the length of time
the backlight stays on
when the phone is not
used.
Backlight
→
LCD
brightness
Adjust the brightness of
the display for varying
lighting conditions.
Backlight
→
Keypad
Set how the phone controls
the use of the keypad light.
Menu Description
Menu functions
24
Message
Sounds
Menu Description
New message Create and send text
messages.
Inbox, Outbox,
Drafts
Access messages that you
have received, sent, saved
to send at a later time, or
that have failed during
sending.
Settings Set up various options for
using the messaging
services.
SOS message Specify options for sending
and receiving an SOS
message. You can send an
SOS message by pressing
[Volume] 4 times when the
exposed keypad is locked.
Memory info Check the number of
messages you have stored
on the UIM card or in the
phone’s memory.
Menu Description
Ringer Set a ringer for calls,
messages, or alarms.
Ringer Vol./Type Adjust the ringer volume
for calls, messages, or
alarms.
Function alert Set up audible alerts at a
specified time to inform
you that certain things
have happened.
Menu Description
25
Entertainment
Utilities
Menu Description
FM radio Listen to music or news via
the FM radio on your
phone.
Games
1
1. All rights and responsibilities for the Java-based games
embedded in your phone and media contents provided by
Samsung Fun Club, such as images, sounds, and Java
applications, belong to their respective owners.
Play various games.
Menu Description
Today View information of
scheduled items for the
current day.
Calendar Keep track of your
schedule.
Task list Make a list of tasks you
need to do.
Alarm Set a wake-up call to wake
you up in the morning or
an alarm to alert you to an
event at a specific time.
User memory
→
Phone memory
View memory information
in the phone’s memory.
Menu Description
Menu functions
26
User memory
→
Memory card
Connect the phone to a PC,
as you would use an
external memory disk and
access the file folder of a
memory card. This menu is
available only if you insert
a memory card into the
phone.
Memo pad Make memos for things
that are important and
manage them.
Calculator Use the phone as a
calculator or converter.
Menu Description
Countdown Measure how long it takes
you to do something or
how many days remain
until a specific event
occurs. The alarm for the
timer will sound at 9 AM on
the target date.
Clock Use your phone as a world
clock or stopwatch.
Menu Description
27
Settings
Menu Description
Auto key lock Set the phone to lock the
keypad automatically when
the display turns off or lock
the keypad by manually
pressing and holding [ ]
in Idle mode.
Security
→
Lock
mode
Activate your phone
password to protect your
phone against
unauthorised use.
Security
→
Change
password
Change the phone
password.
Security
→
Emergency #
Store emergency numbers
or edit them. You can dial
these numbers, even if
your phone is locked or all
outgoing calls are
restricted.
Security
→
Voice
privacy
Use an encrypted high
security line so that people
cannot eavesdrop on your
conversation, or use a
standard line.
Security
→
Restriction
Restrict all outgoing and
incoming calls and the use
of contacts.
Menu Description
Menu functions
28
Security
→
Clear
memory
Delete contacts or
messages stored on the
UIM card or in the phone’s
memory.
Security
→
Reset
phone
Reset the phone’s settings
you have changed or clear
information in the phone’s
memory.
Security
→
Card
setup
Access the security options
for the UIM card.
Entry method Select a default text input
mode.
Thai
/Language Change the language of the
display text.
Domain preset Change the default domain
name extensions.
Menu Description
Contents status Check the amount of
memory currently in use
for storing media content.
My device info Access your phone’s
information.
Menu Description
29
Health and safety information
Exposure to Radio Frequency (RF)
Signals
Certification Information (SAR)
Your wireless phone is a radio transmitter and
receiver. It is designed and manufactured not to
exceed the exposure limits for radio frequency
(RF) energy set by the Federal Communications
Commission (FCC) of the U.S. government.
These FCC exposure limits are derived from the
recommendations of two expert organizations,
the National Counsel on Radiation Protection
and Measurement (NCRP) and the Institute of
Electrical and Electronics Engineers (IEEE). In
both cases, the recommendations were
developed by scientific and engineering experts
drawn from industry, government, and
academia after extensive reviews of the
scientific literature related to the biological
effects of RF energy.
The exposure limit set by the FCC for wireless
mobile phones employs a unit of measurement
known as the Specific Absorption Rate (SAR).
The SAR is a measure of the rate of absorption
of RF energy by the human body expressed in
units of watts per kilogram (W/kg). The FCC
requires wireless phones to comply with a
safety limit of 1.6 watts per kilogram (1.6 W/
kg). The FCC exposure limit incorporates a
substantial margin of safety to give additional
protection to the public and to account for any
variations in measurements.
SAR tests are conducted using standard
operating positions accepted by the FCC with
the phone transmitting at its highest certified
power level in all tested frequency bands.
Although the SAR is determined at the highest
certified power level, the actual SAR level of the
phone while operating can be well below the
maximum value. This is because the phone is
Health and safety information
30
designed to operate at multiple power levels so
as to use only the power required to reach the
network. In general, the closer you are to a
wireless base station antenna, the lower the
power output.
When approval test is done, no Samsung
supplied accessories are avialable but maybe
available later after approval.
Before a new model phone is available for sale
to the public, it must be tested and certified to
the FCC that it does not exceed the exposure
limit established by the FCC. Tests for each
model phone are performed in positions and
locations (e.g. at the ear and worn on the body)
as required by the FCC.
The highest SAR values for this model phone as
reported to the FCC are:
• Head: 0.929W/Kg.
• Bodyworn: 0.504 W/Kg.
For body worn operation, this model phone has
been tested and meets the FCC RF exposure
guidelines whenused with a Samsung accessory
designated for this product or when used with
an accessory that contains no metal and that
positions the handset a minimum of 1.5 cm
from the body.
Non-compliance with the above restrictions
may result in violation of FCC RF exposure
guidelines.
SAR information on this and other model
phones can be viewed on-line at www.fcc.gov/
oet/fccid. This site uses the phone FCC ID
number, A3LSCHS369. Sometimes it may be
necessary to remove the battery pack to find
the number. Once you have the FCC ID number
for a particular phone, follow the instructions on
the website and it should provide values for
typical or maximum SAR for a particular phone.
Additional product specific SAR information can
also be obtained at www.fcc.gov/cgb/sar.
31
Consumer Information on Wireless
Phones
The U.S. Food and Drug Administration (FDA)
has published a series of Questions and
Answers for consumers relating to radio
frequency (RF) exposure from wireless phones.
The FDA publication includes the following
information:
What kinds of phones are the subject
of this update?
The term wireless phone refers here to hand-
held wireless phones with built-in antennas,
often called “cell,” “mobile,” or “PCS” phones.
These types of wireless phones can expose the
user to measurable radio frequency energy (RF)
because of the short distance between the
phone and the user's head. These RF exposures
are limited by Federal Communications
Commission safety guidelines that were
developed with the advice of FDA and other
federal health and safety agencies. When the
phone is located at greater distances from the
user, the exposure to RF is drastically lower
because a person's RF exposure decreases
rapidly with increasing distance from the
source. The so-called “cordless phones,” which
have a base unit connected to the telephone
wiring in a house, typically operate at far lower
power levels, and thus produce RF exposures
well within the FCC's compliance limits.
Do wireless phones pose a health
hazard?
The available scientific evidence does not show
that any health problems are associated with
using wireless phones. There is no proof,
however, that wireless phones are absolutely
safe. Wireless phones emit low levels of radio
frequency energy (RF) in the microwave range
while being used. They also emit very low levels
Health and safety information
32
of RF when in the stand-by mode. Whereas high
levels of RF can produce health effects (by
heating tissue), exposure to low level RF that
does not produce heating effects causes no
known adverse health effects. Many studies of
low level RF exposures have not found any
biological effects. Some studies have suggested
that some biological effects may occur, but such
findings have not been confirmed by additional
research. In some cases, other researchers
have had difficulty in reproducing those studies,
or in determining the reasons for inconsistent
results.
What is FDA's role concerning the
safety of wireless phones?
Under the law, FDA does not review the safety
of radiation-emitting consumer products such
as wireless phones before they can be sold, as
it does with new drugs or medical devices.
However, the agency has authority to take
action if wireless phones are shown to emit
radio frequency energy (RF) at a level that is
hazardous to the user. In such a case, FDA
could require the manufacturers of wireless
phones to notify users of the health hazard and
to repair, replace or recall the phones so that
the hazard no longer exists.
Although the existing scientific data do not
justify FDA regulatory actions, FDA has urged
the wireless phone industry to take a number of
steps, including the following:
• “Support needed research into possible
biological effects of RF of the type emitted
by wireless phones;
• “Design wireless phones in a way that
minimizes any RF exposure to the user that
is not necessary for device function; and
• “Cooperate in providing users of wireless
phones with the best possible information
on possible effects of wireless phone use on
human health.
33
FDA belongs to an interagency working group of
the federal agencies that have responsibility for
different aspects of RF safety to ensure
coordinated efforts at the federal level. The
following agencies belong to this working
group:
• “National Institute for Occupational Safety
and Health
• “Environmental Protection Agency
• “Federal Communications Commission
• “Occupational Safety and Health
Administration
• “National Telecommunications and
Information Administration
The National Institutes of Health participates in
some interagency working group activities, as
well.
FDA shares regulatory responsibilities for
wireless phones with the Federal
Communications Commission (FCC). All phones
that are sold in the United States must comply
with FCC safety guidelines that limit RF
exposure. FCC relies on FDA and other health
agencies for safety questions about wireless
phones.
FCC also regulates the base stations that the
wireless phone networks rely upon. While these
base stations operate at higher power than do
the wireless phones themselves, the RF
exposures that people get from these base
stations are typically thousands of times lower
than those they can get from wireless phones.
Base stations are thus not the primary subject
of the safety questions discussed in this
document.
What are the results of the research
done already?
The research done thus far has produced
conflicting results, and many studies have
suffered from flaws in their research methods.
Health and safety information
34
Animal experiments investigating the effects of
radio frequency energy (RF) exposures
characteristic of wireless phones have yielded
conflicting results that often cannot be repeated
in other laboratories. A few animal studies,
however, have suggested that low levels of RF
could accelerate the development of cancer in
laboratory animals. However, many of the
studies that showed increased tumor
development used animals that had been
genetically engineered or treated with cancer-
causing chemicals so as to be pre-disposed to
develop cancer in absence of RF exposure.
Other studies exposed the animals to RF for up
to 22 hours per day. These conditions are not
similar to the conditions under which people
use wireless phones, so we don't know with
certainty what the results of such studies mean
for human health.
Three large epidemiology studies have been
published since December 2000. Between
them, the studies investigated any possible
association between the use of wireless phones
and primary brain cancer, glioma, meningioma,
or acoustic neuroma, tumors of the brain or
salivary gland, leukemia, or other cancers.
None of the studies demonstrated the existence
of any harmful health effects from wireless
phones RF exposures. However, none of the
studies can answer questions about long-term
exposures, since the average period of phone
use in these studies was around three years.
What research is needed to decide
whether RF exposure from wireless
phones poses a health risk?
A combination of laboratory studies and
epidemiological studies of people actually using
wireless phones would provide some of the data
that are needed. Lifetime animal exposure
studies could be completed in a few years.
However, very large numbers of animals would
35
be needed to provide reliable proof of a cancer
promoting effect if one exists. Epidemiological
studies can provide data that is directly
applicable to human populations, but ten or
more years' follow-up may be needed to
provide answers about some health effects,
such as cancer. This is because the interval
between the time of exposure to a cancer-
causing agent and the time tumors develop - if
they do - may be many, many years. The
interpretation of epidemiological studies is
hampered by difficulties in measuring actual RF
exposure during day-to-day use of wireless
phones. Many factors affect this measurement,
such as the angle at which the phone is held, or
which model of phone is used.
What is FDA doing to find out more
about the possible health effects of
wireless phone RF?
FDA is working with the U.S. National
Toxicology Program and with groups of
investigators around the world to ensure that
high priority animal studies are conducted to
address important questions about the effects
of exposure to radio frequency energy (RF).
FDA has been a leading participant in the World
Health Organization international
Electromagnetic Fields (EMF) Project since its
inception in 1996. An influential result of this
work has been the development of a detailed
agenda of research needs that has driven the
establishment of new research programs
around the world. The Project has also helped
develop a series of public information
documents on EMF issues.
FDA and Cellular Telecommunications &
Internet Association (CTIA) have a formal
Cooperative Research and Development
Agreement (CRADA) to do research on wireless
phone safety. FDA provides the scientific
oversight, obtaining input from experts in
government, industry, and academic
Health and safety information
36
organizations. CTIA-funded research is
conducted through contracts to independent
investigators. The initial research will include
both laboratory studies and studies of wireless
phone users. The CRADA will also include a
broad assessment of additional research needs
in the context of the latest research
developments around the world.
What steps can I take to reduce my
exposure to radio frequency energy
from my wireless phone?
If there is a risk from these products - and at
this point we do not know that there is - it is
probably very small. But if you are concerned
about avoiding even potential risks, you can
take a few simple steps to minimize your
exposure to radio frequency energy (RF). Since
time is a key factor in how much exposure a
person receives, reducing the amount of time
spent using a wireless phone will reduce RF
exposure.
• “If you must conduct extended
conversations by wireless phone every day,
you could place more distance between
your body and the source of the RF, since
the exposure level drops off dramatically
with distance. For example, you could use a
headset and carry the wireless phone away
from your body or use a wireless phone
connected to a remote antenna.
Again, the scientific data do not demonstrate
that wireless phones are harmful. But if you are
concerned about the RF exposure from these
products, you can use measures like those
described above to reduce your RF exposure
from wireless phone use.
What about children using wireless
phones?
The scientific evidence does not show a danger
to users of wireless phones, including children
and teenagers. If you want to take steps to
lower exposure to radio frequency energy (RF),
37
the measures described above would apply to
children and teenagers using wireless phones.
Reducing the time of wireless phone use and
increasing the distance between the user and
the RF source will reduce RF exposure.
Some groups sponsored by other national
governments have advised that children be
discouraged from using wireless phones at all.
For example, the government in the United
Kingdom distributed leaflets containing such a
recommendation in December 2000. They
noted that no evidence exists that using a
wireless phone causes brain tumors or other ill
effects. Their recommendation to limit wireless
phone use by children was strictly
precautionary; it was not based on scientific
evidence that any health hazard exists.
Do hands-free kits for wireless phones
reduce risks from exposure to RF
emissions?
Since there are no known risks from exposure
to RF emissions from wireless phones, there is
no reason to believe that hands-free kits reduce
risks. Hands-free kits can be used with wireless
phones for convenience and comfort. These
systems reduce the absorption of RF energy in
the head because the phone, which is the
source of the RF emissions, will not be placed
against the head. On the other hand, if the
phone is mounted against the waist or other
part of the body during use, then that part of
the body will absorb more RF energy. Wireless
phones marketed in the U.S. are required to
meet safety requirements regardless of
whether they are used against the head or
against the body. Either configuration should
result in compliance with the safety limit.
Health and safety information
38
Do wireless phone accessories that
claim to shield the head from RF
radiation work?
Since there are no known risks from exposure
to RF emissions from wireless phones, there is
no reason to believe that accessories that claim
to shield the head from those emissions reduce
risks. Some products that claim to shield the
user from RF absorption use special phone
cases, while others involve nothing more than a
metallic accessory attached to the phone.
Studies have shown that these products
generally do not work as advertised. Unlike
“hand-free” kits, these so-called “shields” may
interfere with proper operation of the phone.
The phone may be forced to boost its power to
compensate, leading to an increase in RF
absorption. In February 2002, the Federal trade
Commission (FTC) charged two companies that
sold devices that claimed to protect wireless
phone users from radiation with making false
and unsubstantiated claims. According to FTC,
these defendants lacked a reasonable basis to
substantiate their claim.
What about wireless phone
interference with medical equipment?
Radio frequency energy (RF) from wireless
phones can interact with some electronic
devices. For this reason, FDA helped develop a
detailed test method to measure
electromagnetic interference (EMI) of implanted
cardiac pacemakers and defibrillators from
wireless telephones. This test method is now
part of a standard sponsored by the Association
for the Advancement of Medical instrumentation
(AAMI). The final draft, a joint effort by FDA,
medical device manufacturers, and many other
groups, was completed in late 2000. This
standard will allow manufacturers to ensure
that cardiac pacemakers and defibrillators are
39
safe from wireless phone EMI. FDA has tested
wireless phones and helped develop a voluntary
standard sponsored by the Institute of Electrical
and Electronic Engineers (IEEE). This standard
specifies test methods and performance
requirements for hearing aids and wireless
phones so that no interference occurs when a
person uses a compatible phone and a
compatible hearing aid at the same time. This
standard was approved by the IEEE in 2000.
FDA continues to monitor the use of wireless
phones for possible interactions with other
medical devices. Should harmful interference
be found to occur, FDA will conduct testing to
assess the interference and work to resolve the
problem.
Additional information on the safety of RF
exposures from various sources can be
obtained from the following organizations:
• FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
• Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
• Occupational Safety and Health
Administration's (OSHA):
http://www.osha.gov/SLTC/
radiofrequencyradiation/index.html
• National institute for Occupational Safety
and Health (NIOSH):
http://www.cdc.gov/niosh/emfpg.html
• World health Organization (WHO):
http://www.who.int/peh-emf/
• International Commission on Non-Ionizing
Radiation Protection:
http://www.icnirp.de
• National Radiation Protection Board (UK):
http://www.nrpb.org.uk
• Updated 4/3/2002: US food and Drug
Administration
http://www.fda.gov/cellphones
Health and safety information
40
Road Safety
Your wireless phone gives you the powerful
ability to communicate by voice, almost
anywhere, anytime. But an important
responsibility accompanies the benefits of
wireless phones, one that every user must
uphold.
When driving a car, driving is your first
responsibility. When using your wireless phone
behind the wheel of a car, practice good
common sense and remember the following
tips:
1. Get to know your wireless phone and its
features, such as speed dial and redial. If
available, these features help you to place
your call without taking your attention off
the road.
2. When available, use a hands-free device. If
possible, add an additional layer of
convenience and safety to your wireless
phone with one of the many hands free
accessories available today.
3. Position your wireless phone within easy
reach. Be able to access your wireless
phone without removing your eyes from the
road. If you get an incoming call at an
inconvenient time, let your voice mail
answer it for you.
4. Let the person you are speaking with know
you are driving; if necessary, suspend the
call in heavy traffic or hazardous weather
conditions. Rain, sleet, snow, ice and even
heavy traffic can be hazardous.
5. Do not take notes or look up phone
numbers while driving. Jotting down a “to
do” list or flipping through your address
book takes attention away from your
primary responsibility, driving safely.
6. Dial sensibly and assess the traffic; if
possible, place calls when you are not
41
moving or before pulling into traffic. Try to
plan calls when your car will be stationary.
If you need to make a call while moving,
dial only a few numbers, check the road and
your mirrors, then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting. Make
people you are talking with aware you are
driving and suspend conversations that
have the potential to divert your attention
from the road.
8. Use your wireless phone to call for help.
Dial 9-1-1 or other local emergency number
in the case of fire, traffic accident or
medical emergencies. Remember, it is a free
call on your wireless phone!
9. Use your wireless phone to help others in
emergencies. If you see an auto accident,
crime in progress or other serious
emergency where lives are in danger, call 9-
1-1 or other local emergency number, as
you would want others to do for you.
10. Call roadside assistance or a special non-
emergency wireless assistance number
when necessary. If you see a broken-down
vehicle posing no serious hazard, a broken
traffic signal, a minor traffic accident where
no one appears injured, or a vehicle you
know to be stolen, call roadside assistance
or other special non-emergency number.
“The wireless industry reminds you to
use your phone safely when driving.”
For more information, please call 1-888-901-
SAFE, or visit our web-site www.wow-com.com
Provided by the Cellular Telecommunications &
Internet Association
Operating Environment
Remember to follow any special regulations in
force in any area and always switch your phone
off whenever it is forbidden to use it, or when it
may cause interference or danger. When
Health and safety information
42
connecting the phone or any accessory to
another device, read its user's guide for
detailed safety instructions. Do not connect
incompatible products.
As with other mobile radio transmitting
equipment, users are advised that for the
satisfactory operation of the equipment and for
the safety of personnel, it is recommended that
the equipment should only be used in the
normal operating position (held to your ear with
the antenna pointing over your shoulder).
Using Your Phone Near Other
Electronic Devices
Most modern electronic equipment is shielded
from radio frequency (RF) signals. However,
certain electronic equipment may not be
shielded against the RF signals from your
wireless phone. Consult the manufacturer to
discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be
maintained between a wireless phone and a
pacemaker to avoid potential interference with
the pacemaker.
These recommendations are consistent with the
independent research and recommendations of
Wireless Technology Research.
Persons with pacemakers:
• should always keep the phone more than 15
cm
(6 inches) from their pacemaker when the
phone is switched on.
• should not carry the phone in a breast
pocket.
• should use the ear opposite the pacemaker
to minimize potential interference.
43
If you have any reason to suspect that
interference is taking place, switch your phone
off immediately.
Hearing Aids
Some digital wireless phones may interfere with
some hearing aids. In the event of such
interference, you may wish to consult your
hearing aid manufacturer to discuss
alternatives.
Other Medical Devices
If you use any other personal medical devices,
consult the manufacturer of your device to
determine if it is adequately shielded from
external RF energy. Your physician may be able
to assist you in obtaining this information.
Switch your phone off in health care facilities
when any regulations posted in these areas
instruct you to do so. Hospitals or health care
facilities may be using equipment that could be
sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in
motor vehicles. Check with the manufacturer or
its representative regarding your vehicle. You
should also consult the manufacturer of any
equipment that has been added to your vehicle.
Posted Facilities
Switch your phone off in any facility where
posted notices require you to do so.
Potentially Explosive Environments
Switch your phone off when in any area with a
potentially explosive atmosphere and obey all
signs and instructions. Sparks in such areas
could cause an explosion or fire resulting in
bodily injury or even death.
Users are advised to switch the phone off while
at a refueling point (service station). Users are
reminded of the need to observe restrictions on
Health and safety information
44
the use of radio equipment in fuel depots (fuel
storage and distribution areas), chemical plants
or where blasting operations are in progress.
Areas with a potentially explosive atmosphere
are often but not always clearly marked. They
include below deck on boats, chemical transfer
or storage facilities, vehicles using liquefied
petroleum gas (such as propane or butane),
areas where the air contains chemicals or
particles, such as grain, dust or metal powders,
and any other area where you would normally
be advised to turn off your vehicle engine.
Emergency Calls
This phone, like any wireless phone, operates
using radio signals, wireless and landline
networks as well as user programmed
functions, which cannot guarantee connection
in all conditions. Therefore, you should never
rely solely on any wireless phone for essential
communications (medical emergencies, for
example).
Remember, to make or receive any calls the
phone must be switched on and in a service
area with adequate signal strength. Emergency
calls may not be possible on all wireless phone
networks or when certain network services and/
or phone features are in use. Check with local
service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your
present location (for example, 911 or other
45
official emergency number). Emergency
numbers vary by location.
3. Press .
If certain features are in use (call barring, for
example), you may first need to deactivate
those features before you can make an
emergency call. Consult this document and
your local cellular service provider.
When making an emergency call, remember to
give all the necessary information as accurately
as possible. Remember that your phone may be
the only means of communication at the scene
of an accident; do not cut off the call until given
permission to do so.
Restricting Children's access to your
Phone
Your phone is not a toy. Children should not be
allowed to play with it because they could hurt
themselves and others, damage the phone or
make calls that increase your phone bill.
FCC Notice and Cautions
FCC Notice
•
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) this device
may not cause harmful interference, and
(2) this device must accept any interference
received, including interference that may
cause undesired operation.
• This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation. This equipment generates, uses
and can radiate radio frequency energy and,
Health and safety information
46
The phone may cause TV or radio interference if
used in close proximity to receiving equipment.
The FCC can require you to stop using the
phone if such interference cannot be
eliminated.
Vehicles using liquefied petroleum gas (such as
propane or butane) must comply with the
National Fire Protection Standard (NFPA-58).
For a copy of this standard, contact the National
Fire Protection Association, One Battery march
Park, Quincy, MA 02269, Attn: Publication Sales
Division.
Cautions
Changes or modifications made in the radio
phone, not expressly approved by Samsung, will
void the user’s authority to operate the
equipment.
Only use approved batteries, antennas and
chargers. The use of any unauthorized
accessories may be dangerous and void the
if
not installed and used in accordance with
the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user
is encouraged to try to correct the
interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the
equipment and receiver.
-Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced
radio/TV technician for help.
47
phone warranty if said accessories cause
damage or a defect to the phone.
Although your phone is quite sturdy, it is a
complex piece of equipment and can be broken.
Avoid dropping, hitting, bending or sitting on it.
Other Important Safety
Information
• Only qualified personnel should service the
phone or install the phone in a vehicle.
Faulty installation or service may be
dangerous and may invalidate any warranty
applicable to the device.
• Check regularly that all wireless phone
equipment in your vehicle is mounted and
operating properly.
• Do not store or carry flammable liquids,
gases or explosive materials in the same
compartment as the phone, its parts or
accessories.
• For vehicles equipped with an air bag,
remember that an air bag inflates with
great force. Do not place objects, including
both installed or portable wireless
equipment in the area over the air bag or in
the air bag deployment area. If wireless
equipment is improperly installed and the
air bag inflates, serious injury could result.
• Switch your phone off before boarding an
aircraft. The use of wireless phone in
aircraft is illegal and may be dangerous to
the aircraft's operation.
• Failure to observe these instructions may
lead to the suspension or denial of
telephone services to the offender, or legal
action, or both.
Health and safety information
48
Product Performance
Getting the Most Out of Your Signal
Reception
The quality of each call you make or receive
depends on the signal strength in your area.
Your phone informs you of the current signal
strength by displaying a number of bars next to
the signal strength icon. The more bars
displayed, the stronger the signal.
If you're inside a building, being near a window
may give you better reception.
Understanding the Power Save
Feature
If your phone is unable to find a signal after 15
minutes of searching, a Power Save feature is
automatically activated. If your phone is active,
it periodically rechecks service availability or
you can check it yourself by pressing any key.
Anytime the Power Save feature is activated, a
message displays on the screen. When a signal
is found, your phone returns to standby mode.
Understanding How Your Phone
Operates
Your phone is basically a radio transmitter and
receiver. When it's turned on, it receives and
transmits radio frequency (RF) signals. When
you use your phone, the system handling your
call controls the power level. This power can
range from 0.006 watts to 0.2 watts in digital
mode.
Maintaining Your Phone's Peak
Performance
For the best care of your phone, only authorized
personnel should service your phone and
accessories. Faulty service may void the
warranty.
49
There are several simple guidelines to operating
your phone properly and maintaining safe,
satisfactory service.
• Hold the phone with the antenna raised,
fully-extended and over your shoulder.
• Try not to hold, bend or twist the phone's
antenna.
• Don't use the phone if the antenna is
damaged.
• Speak directly into the phone's receiver.
• Avoid exposing your phone and accessories
to rain or liquid spills. If your phone does
get wet, immediately turn the power off and
remove the battery. If it is inoperable, call
Customer Care for service.
Availability of Various Features/
Ring Tones
Many services and features are network
dependent and may require additional
subscription and/or usage charges. Not all
features are available for purchase or use in all
areas. Downloadable Ring Tones may be
available at an additional cost. Other conditions
and restrictions may apply. See your service
provider for additional information.
Battery Standby and Talk Time
Standby and talk times will vary depending on
phone usage patterns and conditions. Battery
power consumption depends on factors such as
network configuration, signal strength,
operating temperature, features selected,
frequency of calls, and voice, data, and other
application usage patterns.
Battery Precautions
• Never use any charger or battery that is
damaged in any way.
Health and safety information
50
• Use the battery only for its intended
purpose.
• If you use the phone near the network's
base station, it uses less power; talk and
standby time are greatly affected by the
signal strength on the cellular network and
the parameters set by the network operator.
• Battery charging time depends on the
remaining battery charge and the type of
battery and charger used. The battery can
be charged and discharged hundreds of
times, but it will gradually wear out. When
the operation time (talk time and standby
time) is noticeably shorter than normal, it is
time to buy a new battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not
in use, disconnect it from the power source.
Do not leave the battery connected to a
charger for more than a week, since
overcharging may shorten its life.
• Extreme temperatures will affect the
charging capacity of your battery: it may
require cooling or warming first.
• Do not leave the battery in hot or cold
places, such as in a car in summer or winter
conditions, as you will reduce the capacity
and lifetime of the battery. Always try to
keep the battery at room temperature. A
phone with a hot or cold battery may
temporarily not work, even when the
battery is fully charged. Li-ion batteries are
particularly affected by temperatures below
0 °C (32 °F).
• Do not short-circuit the battery. Accidental
short- circuiting can occur when a metallic
object (coin, clip or pen) causes a direct
connection between the + and - terminals
51
of the battery (metal strips on the battery),
for example when you carry a spare battery
in a pocket or bag. Short-circuiting the
terminals may damage the battery or the
object causing the short-circuiting.
• Dispose of used batteries in accordance
with local regulations. In some areas, the
disposal of batteries in household or
business trash may be prohibited. For safe
disposal options for Li-Ion batteries, contact
your nearest Samsung authorized service
center. Always recycle. Do not dispose of
batteries in a fire.
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care.
The suggestions below will help you fulfill any
warranty obligations and allow you to enjoy this
product for many years.
• Keep the phone and all its parts and
accessories out of the reach of small
children.
• Keep the phone dry. Precipitation, humidity
and liquids contain minerals that will
corrode electronic circuits.
• Do not use the phone with a wet hand.
Doing so may cause an electric shock to you
or damage to the phone.
• Do not use or store the phone in dusty, dirty
areas, as its moving parts may be
damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of
electronic devices, damage batteries, and
warp or melt certain plastics.
• Do not store the phone in cold areas. When
the phone warms up to its normal operating
temperature, moisture can form inside the
Health and safety information
52
phone, which may damage the phone's
electronic circuit boards.
• Do not drop, knock or shake the phone.
Rough handling can break internal circuit
boards.
• Do not use harsh chemicals, cleaning
solvents or strong detergents to clean the
phone. Wipe it with a soft cloth slightly
dampened in a mild soap-and-water
solution.
• Do not paint the phone. Paint can clog the
device's moving parts and prevent proper
operation.
• Do not put the phone in or on heating
devices, such as a microwave oven, a stove
or a radiator. The phone may explode when
overheated.
• When the phone or battery gets wet, the
label indicating water damage inside the
phone changes color. In this case, phone
repairs are no longer guaranteed by the
manufacturer's warranty, even if the
warranty for your phone has not expired.
• If your phone has a flash or light, do not
use it too close to the eyes of people or
animals. This may cause damage to their
eyes.
• Use only the supplied or an approved
replacement antenna. Unauthorized
antennas or modified accessories may
damage the phone and violate regulations
governing radio devices.
• If the phone, battery, charger or any
accessory is not working properly, take it to
your nearest qualified service facility. The
personnel there will assist you, and if
necessary, arrange for service.
53
Licensed by QUALCOMM incorporated under one
or more of the following Patents.
U.S Patent No. 4,901,307 5,056,109
5,099,204 5,101,501
5,103,459 5,107,225
5,109,390
