Samsung Electronics Co SCHW619 Cellular CDMA Phone with Bluetooth User Manual SCH W619 FCC
Samsung Electronics Co Ltd Cellular CDMA Phone with Bluetooth SCH W619 FCC
Users Manual
* Depending on the software installed or your service provider or country, some of the descriptions in this guide
may not match your phone exactly.
* Depending on your country, your phone and accessories may appear different from the illustrations in this guide.
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-xxxxxA
English (CHN). 06/2007. Rev. 1.0
SCH-W619
User’s Guide
Draft
2007. 06. 05
Important safety
precautions
Drive safely at all times
Do not use a hand-held phone while driving. Park
your vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using
them in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Failure to comply with the following
precautions may be dangerous or illegal.
Copyright information
• Bluetooth
®
is a registered trademark
of the Bluetooth SIG, Inc. worldwide.
Bluetooth QD ID: BO12689
•Java
TM
is a trademark or registered trademark
of Sun Microsystems, Inc.
• Picsel and Picsel Viewer
TM
are trademarks of
Picsel Technologies, Inc.
1
Be aware of special regulations
Meet any special regulations in force in any area
and always switch off your phone whenever it is
forbidden to use it, or when it may cause
interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to your ear).
Avoid unnecessary contact with the antenna when
the phone is switched on.
Emergency calls
Key in the emergency number for your present
location, then press .
Keep your phone away from small children
Keep the phone and all its parts, including
accessories, out of the reach of small children.
Accessories and batteries
Use only Samsung-approved batteries and
accessories, such as headsets and PC data cables.
Use of any unauthorised accessories could damage
you or your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health
and safety information" on page 41.
• The phone could explode if the battery is
replaced with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.
At very high volumes, prolonged listening
to a headset can damage your hearing.
2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone.
In this guide, the following instruction icons
appear:
Indicates that you need to pay careful
attention to the subsequent information
regarding safety or phone features.
→
Indicates that you need to press the
Navigation keys to scroll to the specified
option and then select it.
[ ] Indicates a key on the phone.
For example, [ ]
< > Indicates a soft key, whose function is
displayed on the phone screen. For
example, <
Menu
>
•Dual standby mode
Your phone operates on both
GSM and CDMA networks,
anytime, anywhere. Select a
network before making calls or
sending messages.
Special
features of your phone
• Touch screen
Your phone has a touch-
sensitive display. You can
access a desired function with a
touch on the screen.
• Camera and camcorder
Use the camera module on your
phone to take a photo or record
a video.
3
•MP3 player
Play music files using your
phone as an MP3 player.
• Melody composer
Make your own melodies for
your phone.
• Photo studio
Add a frame or apply special
effects to decorate your photos.
•Bluetooth
Transfer media files and
personal data, and connect to
other devices using wireless
Bluetooth technology.
•Web browser
Access the wireless web to get
up-to-the-minute information
and a wide variety of media
content.
• Messenger
Have a conversation with other
people by sending and
receiving instant messages.
•SOS message
Send SOS messages to your
family or friends for help in an
emergency.
•Memory disk
Connect your phone to a
computer to copy files directly
to and from it.
4
Contents
Unpack 6
Make sure you have each item
Get started 6
First steps to operating your phone
Assemble and charge the phone ..................... 6
Power on or off.............................................. 7
Phone layout ................................................. 8
Keys and icons .............................................. 9
Access menu functions .................................. 12
Enter text .................................................... 13
Customise your phone................................... 17
Use an optional memory card ......................... 19
Step outside the phone 21
Begin with call functions, camera, MP3 player, web
browser, and other special features
Make or answer calls ..................................... 21
Use the camera............................................ 21
Play music................................................... 23
Browse the web ........................................... 24
Use Contacts ............................................... 24
Send or view messages................................. 25
Use Bluetooth .............................................. 26
Use Sketch memo ........................................ 28
Menu functions 30
All menu options listed
Health and safety information 41
5
1 Call history
1 Missed
2 Incoming
3 Outgoing
4 Air time
5 GSM call cost
6 Area code
7 Call reject
8 Int’l call prefix
9 Answer mode
0 Flight mode
2 Contacts
1 Find
2 Add
3 Group settings
4 Speed dial
5 Name card
6 My phone #
7 Memory info
3 Multimedia
1 Take photo
2 Namecard recognition
3 My album
3 Multimedia
4 External album
5 Photo studio
6 Settings
4 Display
1 Screen saver
2 Functional screen
3 Power on/off
4 Dialing font
5 Time settings
6 Backlight
5 Messages
1 New message
2 Inbox
3 Outbox
4 Drafts
5 Msg. setup
6 SOS message
7 Msg. wallpaper
8 Memory info
6 Sounds
1 Ringer
2 Ringer vol./type
3 Key tone
6 Sounds
4 Function alert
5 Hour alert
7 Entertainment
1 Games
2 MP3
3 Melody composer
4 Karaoke
5 Fun box
6 Samsung messenger
8 Utilities
1 Today
2 Calendar
3 Task list
4 Alarm
5 User memory
6 Voice tools
7 Memo
8 Calculator
9 Countdown
0 Clock
* Dictionary
# Bluetooth
9 Settings
1 COMA network services
2 GSM network services
3 Shortcut settings
4 Security
5 Network selection
6 Input method
7 Stylus adjust
8
语言
/Language
9 Domains preset
0 Contents status
# My phone info
Overview of menu functions
To access Menu mode, tap or press <
Menu
> in Idle mode.
Tap or press <
Menu
>
→
<
Favorites
> in Idle mode.
uni
1 Mail
2 Magic
3 Info
4 Music street
5 Bookmarks
6
Unpack
Make sure you have each item
• Phone
•Travel charger
•Battery
•User’s Guide
•Stylus pen
You can obtain various accessories from your
local Samsung dealer.
Get started
First steps to operating your phone
Assemble and charge the phone
The items supplied with your phone and the
accessories available at your Samsung dealer
may vary, depending on your country or service
provider.
Use the slot 1 for
UIM cards only. Use
the slot 2 for either
UIM or SIM cards.
7
Removing the battery
Power on or off
Switch on
1. Open the phone.
2. Press and hold [ ].
3. Select a default
network.
4. If necessary, enter the
PIN and tap or press
<
OK
>.
Switch off
1. Open the phone.
2. Press and hold [ ].
Get started
8
Phone layout
Front view
Rear view
9
Keys and icons
Keys
Soft keys Perform the function indicated on
the bottom line of the display.
Network
selection
key
In Idle mode, enter the
Set mode
menu in
Network selection
.
Navigatio
n keys
In Idle mode, access the following
menus:
•Left:
Messages
;
Mail
when held
down
• Up/Down/Right: your favourite
menus
In Menu mode, scroll through menu
options.
Uni key In Idle mode, launch the web
browser.
In Menu mode, perform the
functions indicated on the bottom
line of the display.
Send key Make or answer a call.
In Idle mode, retrieve the numbers
recently dialled, missed, or received.
C (Clear)
key
Delete characters from the display.
In Idle mode, initiate the voice
recognition feature. Start voice
dialling when held down.
In Menu mode, return the display to
the previous menu level.
Get started
10
Bluetooth
key
In Idle mode, enter the
Bluetooth
menu.
End key Press and hold to switch the phone
on or off.
End a call.
In Menu mode, cancel input and
return the phone to Idle mode.
Numeric
keys
Enter numbers, letters, and some
special characters.
In Idle mode, press and hold [
1
] to
access your voicemail server. Press
and hold [
0
] to enter an
international call prefix.
Special
key
Enter numbers, letters, and some
special characters.
In Idle mode, press and hold [ ] to
activate or deactivate the Silent
mode.
Volume
key
Adjust the phone volume.
MP3 key In Idle mode, enter the
MP3
menu.
Press and hold to launch the MP3
player.
Camera
key
In Idle mode, enter the
Multimedia
menu. Press and hold to turn on the
camera.
In Camera mode, take a photo or
record a video.
11
Icons
The following icons may appear on the top line
of the screen to indicate your phone’s status.
Depending on your country or service provider,
the icons shown on the display may vary. You
can change settings or open a message by
tapping some icons.
Signal strength in a CDMA network
No signal strength in a CDMA
network
Inactive UIM card or no UIM card
inserted
Signal strength in a GSM network
No signal strength in a GSM network
Inactive SIM card or no SIM card
inserted
Roaming network
Call in progress
SOS message feature active
Transferring data in 1X network
Connected to a secured web page
New message:
• : Text message
• : Urgent text message
•: Voicemail
Messenger invitation
Get started
12
Access menu functions
Alarm status
Ringer type
•: Ringer only
• : Silent
• : 1 Beep
•: Vibration
•: Vib. & ringer
• : Vib. then ringer
• : Ringer then vib.
Silent mode
Bluetooth status
Battery power level
Select an
option
By tapping on the touch
screen:
1. Tap a desired soft key
indicator.
2. Tap the left or right arrow
to scroll left or right.
Tap and drag the scroll bar
to scroll up or down.
3. Tap a displayed option or
function.
4. Tap to move up one
level.
13
Enter text
By pressing the soft keys and
Navigation keys:
1. Press a desired soft key.
2. Press the Navigation keys
to move to the next or
previous option.
3. Press <
Select
> or <
Save
>
to confirm the function
displayed or option
highlighted.
4. Press [ ] to move up
one level.
Press [ ] to return to Idle
mode.
By pressing the number keys:
Press the number key
corresponding to the option
you want.
Change the
text input
mode
1. In the text entry screen,
press the right soft key.
2. Select the mode you want.
Use Pen
Stroke
mode
To ent e r a wo rd:
1. Write a character at a time
on the pen stroke field.
Tap to enter numbers or
symbols.
2. If the phone does not
correctly recognise your
writing, select a character
from the character selection
field.
3. Tap to insert a space and
enter the next character.
Get started
14
Use the
onscreen
keyboards
To enter a word:
1. Tap in Pen Stroke mode
to open the onscreen
keyboard.
2. Tap a character on the
keyboard.
• Tap to open the
numeric keyboard.
• Tap to open the
symbolic keyboard.
3. Tap to insert a space and
enter the next character.
Use Chinese
Pinyin mode
To enter a word:
1. Press the keys corresponding
to the Chinese phonetic
spelling, pinyin.
2. Press [Left] or [Right] to
select alternative pinyins.
3. If necessary, press [Up] or
[Down] to find the character
you want.
4. Press [
1
]. Numbers are
added to each character.
5. Press the number key
corresponding to the
character.
To use the tones:
1. Press the keys corresponding
to the pinyin of the letter you
need.
2. If necessary, press [Left] or
[Right] to select the pinyin.
3. Press [ ] for tones.
15
4. If necessary, press [Up] or
[Down] to find the character
you want.
5. Press [
1
]. Numbers are
added to each character.
6. Press the number key
corresponding to the
character.
Rapid character entry
To enter the word zhong guo
( ), enter the first character
using the following keystrokes;
[
9
], [
4
], [
6
], [
6
], [
4
], [
1
], and
[
1
]. You do not have to
complete the Pinyin spelling to
include guo ( ). The character
displays automatically.
Use Chinese
Stroke
mode
To ent e r a wo rd:
1. Press the keys corresponding
to a character’s component
strokes.
2. If necessary, press [Up] or
[Down] to find the character
you want.
3. Press the number key
corresponding to the
character you want.
Rapid character entry
Try entering the characters
zhong guo () using the
following keystrokes: [
2
], [
8
],
and [
7
]. You can enter the
complete pair in only three key
presses.
Get started
16
Use ABC
mode
To enter a word:
Press the appropriate key until
the character you want appears
on the display.
Use English
word (T9)
mode
To enter a word:
1. Press [
2
] to [
9
] to start
entering a word.
2. Enter the whole word before
editing or deleting
characters.
3. When the word displays
correctly, press [ ] to insert
a space.
Otherwise, press [
0
] to
display alternative word
choices.
Use Number
mode
Press the keys corresponding to
the digits you want.
Use Symbol
mode
Press the corresponding
number key to select a symbol.
Copy and
paste text
1. Tap or press <
Options
> and
select
Copy/Paste
→
Copy
.
To copy the whole text,
select
Full copy
.
2. Highlight the text you want
to copy, and tap or press
<
Select
>.
3. Tap or press <
Options
> and
select
Copy/Paste
→
Paste
to paste the copied text.
17
Customise your phone
Other
operations
• Press [
1
] to enter
punctuation marks or special
characters in ABC mode and
T9 mode.
• Press [ ] to insert a space.
• Press [ ] to change case.
• Press the Navigation keys to
move the cursor.
• Press [ ] to delete
characters one by one. In
Pen Stroke mode and on the
onscreen keyboard, tap .
• Press and hold [ ] to
clear the characters on the
left side of the cursor.
1. In Idle mode, tap or press
<
Menu
> and select
Settings
→
语言
/Language
.
2. Select a language.
1. In Idle mode, tap or press
<
Menu
> and select
Sounds
→
Ringer
.
2. Press [Down].
3. Press [Left] or [Right] to
select a ringtone category.
4. Scroll to a ringtone.
5. Tap or press <
Play
> to
listen to a melody.
6. Tap or press <
Save
>.
Display
language
Call ringer
melody
Get started
18
1. In Idle mode, press [ / ]
to adjust the key tone
volume.
2. Tap or press <
Save
>.
1. In Idle mode, tap or press
<
Menu
> and select
Display
→
Screen saver
→
.
2. Select a category.
3. Scroll to an image.
4. Tap or press <
Save
> or
<
Select
>.
Key tone
volume
Idle mode
wallpaper
You can switch the phone to
Silent mode to avoid disturbing
other people. In Idle mode,
press and hold [ ].
1. In Idle mode, tap or press
<
Menu
> and select
Settings
→
Security
.
2. Enter the default password,
00000000
, and tap or
press <
Done
>.
3. Select
Change password
.
4. Enter a new 4- to 8-digit
password and tap or press
<
Done
>.
Silent mode
Phone lock
19
Use an optional memory card
5. Enter the new password
again and tap or press
<
Done
>.
6. Select
Lock mode
.
7. Select
Once
or
On
.
You can select a default
network to be used for making
calls or sending messages.
1. In Idle mode, press [
C/G
].
2. Scroll to
Main
on the
network you want to use
and tap or press <
Check
>.
3. Tap or press <
Save
>.
Select a
network
• Frequent erasing and
writing will shorten a card’s
lifespan.
• Do not remove a card from
the phone or turn off the
phone while data is being
accessed or transferred.
This could result in loss of
data and/or damage to the
card or phone.
• Do not subject cards to
strong shocks.
• Do not touch card terminals
with your fingers or metal
objects. If dirty, wipe the
card with a soft cloth.
• Keep cards away from small
children or pets.
Important
memory card
information
Get started
20
• Do not expose cards in a
place subject to
electrostatic discharge and/
or electrical noise.
1. Remove the battery cover
and the battery.
2. Unlock the card cover and
lift it.
3. Insert the card into the card
slot, with the label side face
up.
Insert a
memory card
4. Close the card cover and
lock it.
5. Attach the battery and the
battery cover.
1. Remove the battery cover
and the battery, then open
the card cover.
2. Remove the card from the
slot.
3. Attach the battery and the
battery cover.
Remove the
memory card
21
Step outside the phone
Begin with call functions, camera, MP3 player, web
browser, and other special features
Make or answer calls
Use the camera
1. In Idle mode, enter an area
code and phone number.
2. Select the network you
want, or .
3. Press [ ].
Press [ / ] to adjust the
volume.
During a call, press any key
to activate the display when
it turns off.
4. Press [ ] to end the call.
Make a call
1. When the phone rings,
press [ ].
2. Press [ ] to end the call.
1. During a call, call the
second participant. The first
call is put on hold.
2. Press [ ] to begin the
three-way call.
1. In Idle mode, press and
hold [ ] to turn on the
camera.
Answer a
call
Make a
three-way
call
Take a photo
Step outside the phone
22
2. To change the shooting
mode, press [
1
] once for a
series shot, or twice for a
divided shot (mosaic shot).
3. Aim the lens at the subject
and make any desired
adjustments.
4. Press [ ] or [ ] to take
a photo.
5. Tap or press <
Save
>.
1. In Idle mode, press [ ]
and select
My album
→
Gallery
.
2. Select the photo you want.
View a photo
1. In Idle mode, press and
hold [ ] to turn on the
camera.
2. Press [
1
] three times to
switch to Record mode.
3. Tap or press < >, or press
[ ] to start recording.
4. Tap or press < >, or press
[ ] to stop recording.
5. Tap or press <
Save
>.
1. In Idle mode, press [ ]
and select
My album
→
Gallery
.
2. Select the video you want.
3. Tap or press <
Play
>.
Record a
video
View a video
23
Play music
Use these methods:
• Download from the wireless
web.
• Copy directly from a PC.
• Receive via Bluetooth.
• Copy to a memory card and
insert the card into the
phone.
1. In Idle mode, press [
MP3
]
and select
MP3 files
.
2. Tap or press <
Options
>
and select
Add to play list
.
3. Tap or press <
Check
> to
select files.
4. Tap or press <
Add
>.
Copy music
files to the
phone
Create a
playlist
1. In Idle mode, press [
MP3
]
and select
MP3 player
.
2. Tap or press [ ] to
begin playback.
3. During playback, use the
following functions:
• To pause playback, tap
or press [ ].
• To return to the previous
file, tap or press
[Left].
• To skip to the next file,
tap or press [Right].
• To change the repeat
mode, tap or press
[Up].
• To open the playlist, tap
LIST
or press [Down].
Play music
files
Step outside the phone
24
Browse the web Use Contacts
• To set a section in a file
to play the section
repeatedly, tap or press
<
A-B
>.
•
To adjust the volume,
press
[/].
4. Press [ ] to stop
playback.
In Idle mode, press [ ].
The homepage of your service
provider opens.
Launch the
web browser
• To scroll through browser
items, press [Up] or
[Down].
• To select an item, press
<
OK
> or <
✓
>.
• To return to the previous
page, press [ ].
• To access browser options,
press [ ].
1. In Idle mode, enter a phone
number and tap or press
<
Save
>.
2. Select
New entry
.
Navigate
the web
Add a contact
25
Send or view messages
3. Tap or press <
Edit
>.
4. Enter a name and tap or
press <
Save
>.
5. To add a contact to the
phone’s memory, press
[Left] or [Right] and select
a number type.
6. Specify contact information.
7. Tap or press <
Save
> to
save the contact.
1. In Idle mode, tap or press
<
Find
>.
2. Select a search method and
press [Down].
Find a
contact
3. Enter the first few letters of
the name of the contact or
the digit of the speed dial
entry, or select a contact
group or memory location.
4. Select a contact.
5. Scroll to a number and
press [ ] to dial or tap or
press <
Edit
> to edit
contact information.
1. In Idle mode, tap or press
<
Menu
> and select
Messages
→
New
message
.
Send a text
message
Step outside the phone
26
Use Bluetooth
Your phone is equipped with Bluetooth
technology, enabling you to connect the phone
wirelessly to other Bluetooth devices and
exchange data with them, talk hands-free, or
control the phone remotely.
2. Select the network type you
want to use.
3. Enter the message text and
tap or press <
Next
>.
4. Tap or press <
Next
> again.
5. Enter destination numbers.
6. Tap or press <
Send
> to
send the message.
1. In Idle mode, tap or press
<
Menu
> and select
Messages
→
Inbox
→
Text
.
2. Select a text message.
View a text
message
1. In Idle mode, press [ ] and
select
Activation
→
On
.
2. Select
Visibility
→
On
to
allow other devices to find
your phone.
1. In Idle mode, press [ ]
and select
My Devices
.
2. Tap or press <
Search
>.
Turn on
Bluetooth
Search for
and pair with
a Bluetooth
device
27
3. Scroll to a device and tap or
press <
Add
>.
4. Enter a Bluetooth PIN or the
other device’s Bluetooth
PIN, if it has one, and tap or
press <
Done
>.
When the owner of the
other device enters the
same code, the pairing is
complete.
1. From the paired device list,
scroll to the device you
want.
2. Tap or press <
Menu
> and
select
Send files
.
Send data
3. Select a memory location.
4. Tap or press <
Check
> to
select files and tap or press
<
Put
>.
5. Scroll to the folder you want
and tap or press <
Put
>.
To receive from another device:
1. From the paired device list,
scroll to the device you
want.
2. Tap or press <
Menu
> and
select
Get files
.
3. Select a file folder.
Receive data
Step outside the phone
28
Use Sketch memo
4. Tap or press <
Check
> to
select files and tap or press
<
Get
>.
5. Scroll to the folder you want
and tap or press <
Get
>.
To receive sent files:
1. When a device attempts to
access your phone, tap or
press <
Yes
> to permit the
connection.
2. If necessary, tap or press
<
Yes
> to confirm that you
are willing to receive.
1. In Idle mode, tap or press
<
Menu
> and select
Utilities
→
Memo
→
Sketch memo
→
Sketch
memo
.
2. To use a paint brush, tap
.
To use a sketch pen, tap .
3. Draw a sketch using the
stylus pen on the screen.
Create a new
sketch memo
29
4. You can use the following
sketch tools on the screen:
• : erase the drawing as
you move the pen.
• : cancel your last
action.
•: change the line
thickness. This option is
not available when you
use a paint brush.
• : change the pen or
brush colour.
• : Access the
View
menu.
5. Tap or press <
Save
> to
save the sketch memo.
6. Tap or press <
Yes
>.
1. In Idle mode, tap or press
<
Menu
> and select
Utilities
→
Memo
→
Sketch memo
→
View
.
2. Tap the memo you want to
view.
View a sketch
memo
30
Menu functions
All menu options listed
This section provides brief explanations of
menu functions on your phone.
uni
The contents available in each menu option may
be different, depending on the service provider.
For further details, contact your service provider.
Menu Description
Mail Access the Mail service,
which allows you to send or
receive emails containing
various media items, such
as images, sounds, name
cards, and applications.
Magic Download and use various
Brew applications.
Info This menu is available only
when you use a UTK UIM
card that provides
additional services.
Music street Access various audio
services supported by your
service provider.
Bookmarks Save URL addresses in
order to quickly access web
pages.
Menu Description
31
Call history
Menu Description
Missed,
Incoming,
Outgoing
Check the most recent calls
dialled, received, or
missed.
Air time Check the time record for
voice calls and data calls
made and received.
GSM call cost Check the cost of your calls
in a GSM network, if
supported by your SIM
card.
Area code Find and retrieve area or
country code to quickly and
easily dial phone numbers.
Call reject Make a list of the phone
numbers from which you
do not want to accept calls.
Int’l call prefix Set international call
service numbers.
Answer mode Select how to answer an
incoming call.
Flight mode Switch the phone to Flight
mode, in which the phone
functions requiring network
connection are deactivated.
Menu Description
Menu functions
32
Contacts
Multimedia
Menu Description
Find Search for contact
information stored in
Contacts.
Add Add a new contact to
Contacts.
Group settings Set up a caller group list
for organising contacts.
Speed dial Assign a speed dial number
for your most frequently
dialled numbers.
Name card Save name cards as data
file format and send them
to other people.
My phone # Check your phone number
or edit your number.
Memory info Check information about
the memory currently in
use.
Menu Description
Take photo Use the camera embedded
in your phone to take
photos and record videos.
Namecard
recognition
Take a name card photo
and save it as a new
contact in Contacts.
Menu Description
33
Display
My album Access the photos you
have taken and the videos
you have recorded.
External album Access photos and videos
on a memory card, when
you insert a memory card
into the phone.
Photo studio Edit photos by applying
special effects or adding
comments.
Settings Change the default settings
for the options when using
the camera.
Menu Description
Menu Description
Screen saver Change the background
image or set a banner
message to be displayed
on the idle screen.
Functional
screen
Select a function screen to
be displayed in Idle mode.
Power on/off Select an image to be
displayed when the phone
is switched on or off.
Dialing font Select a font style for digits
to be displayed when you
enter a phone number for
dialling.
Time settings
→
Single clock
Set the current time and
date.
Menu functions
34
Messages
Time settings
→
Dual clock
Set up the time zones for
the Dual clock wallpaper.
Time settings
→
Auto timezone
Set your phone to update
the current time
automatically when you
travel abroad. Time
information may not be
updated when you move to
one time zone to another
within a country.
Backlight
→
Main
LCD
Select the length of time
the backlight or display
stays on when the phone is
not used.
Backlight
→
LCD
brightness
Adjust the brightness of
the display for varying
lighting conditions.
Menu Description
Backlight
→
Keypad
Set how the phone controls
the use of the keypad light.
Menu Description
New message Create and sent text
messages.
Inbox, Outbox,
Drafts
Access messages that you
have received, sent, saved
to send at a later time, or
that have failed during
sending.
Msg. setup Set up various options for
using the messaging
services.
Menu Description
35
Sounds
SOS message Specify options for sending
and receiving an SOS
message. You can send an
SOS message by pressing
[ / ] 4 times in Idle
mode, with the phone
closed.
Msg. wallpaper Select a background image
to be displayed on the
message screen so that
you can view message with
the image.
Memory info Check information about
the memory currently in
use.
Menu Description
Menu Description
Ringer Set a ringer for calls,
messages, alarms, or
scheduler.
Ringer vol./type Adjust the ringer volume
for calls, messages,
alarms, or scheduler.
Key tone Select the tone that the
phone sounds when you
press a key.
Function alert Set up audible alerts at a
specified time to inform
you that certain things
have happened.
Hour alert Set the phone to sound an
alert every hour on the
hour.
Menu functions
36
Entertainment
Utilities
Menu Description
Games
1
Play various games.
MP3 Listen to music.
Melody
composer
Compose your own
melodies using a variety of
musical components.
Karaoke Enjoy karaoke video files
you have downloaded as
you would in a karaoke.
Fun box
1
Access Samsung Fun Club,
the preset website
providing Samsung mobile
phone users with attractive
download services.
Samsung
messenger
Have a conversation with
your friends, family, or co-
workers by sending and
receiving instant
messages.
1. All rights and responsibilities for the Java-based games
embedded in your phone and media contents provided by
Samsung Fun Club, such as images, sounds, and Java
applications, belong to their respective owners.
Menu Description
Today View information of
scheduled items for the
current day.
Menu Description
37
Calendar Keep track of your
schedule.
Task list Make a list of tasks you
need to do.
Alarm Set a wake-up call to wake
you up in the morning or
an alarm to alert you to an
event at a specific time.
You can also set the alarm
to sound when the phone is
off.
User memory Connect the phone to a PC,
as you would use an
external memory disk drive
and access files of your
phone’s memory or a
memory card.
Menu Description
Voice tools Use the voice recognition
feature or record voice
memos.
Memo Make memos or sketch
memos for things that are
important and manage
them.
Calculator Perform arithmetic
functions and do
conversions, such as length
and temperature.
Countdown Measure how long it takes
you to do something or
how many days remain
until a specific event
occurs. The alarm for the
timer will sound at 9 AM on
the target date.
Menu Description
Menu functions
38
Settings
Clock Find out the current time in
another part of the world
and measure elapsed time.
Dictionary Search for words and
organise your own
dictionary.
Bluetooth Connect the phone
wirelessly to other
Bluetooth devices.
Menu Description
CDMA network
services
→
Call
forward
Set the phone to reroute
incoming calls to a phone
number that you specify.
Menu Description
CDMA network
services
→
Call
waiting
Set the phone to inform
you when someone is
trying to reach you while
you are on another call.
CDMA network
services
→
Emergency #
Store three emergency
numbers or edit them. You
can dial these numbers,
even if your phone is
locked.
CDMA network
services
→
Voice
privacy
Use an encrypted high
security line so that people
cannot eavesdrop on your
conversation, or use a
standard line.
Menu Description
39
CDMA network
services
→
Dialup
networking
Set whether or not to use
your phone as an external
modem for a PC via USB.
GSM network
services
→
Call
diverting
Set the phone to reroute
incoming calls to a phone
number that you specify.
GSM network
services
→
Call
barring
Set the phone to restrict
your calls.
GSM network
services
→
Call
waiting
Set the phone to inform
you when someone is
trying to reach you while
you are on another call.
Menu Description
GSM network
services
→
Network
selection
Allow you to either
automatically or manually
select the network used
when roaming outside of
your home area.
GSM network
services
→
Band
selection
Register with an available
network for the phone to
make and receive phone
calls.
GSM network
services
→
Caller
ID
Set the phone to hide your
phone number from the
person you are calling.
Shortcut
settings
→
Shortcuts
Use the Navigation keys as
shortcuts to access specific
menus directly from Idle
mode. [Left] is fixed as a
shortcut to
Messages
.
Menu Description
Menu functions
40
Shortcut
settings
→
My
menu
Set up a menu of your own
using your favourite menu
items.
Security
→
Lock
mode
Activate your phone
password to protect your
phone against
unauthorised use.
Security
→
Change
password
Change the phone
password.
Security
→
Contacts
restriction
Restrict the use of
Contacts.
Security
→
Clear
memory
Delete contacts or
messages stored on the
SIM card or the UIM card,
or in the phone’s memory.
Menu Description
Security
→
Reset
phone
Reset the phone’s settings
you have changed.
Security
→
Card
slot1 setup or
Card slot2 setup
Access the security options
for the currently used card.
Network
selection
Switch between GSM and
CDMA networks. You can
also set how to select a
network type the next time
the phone turns on.
Input method
→
Mode setting
Select a default text input
mode.
Input method
→
Fuzzy pinyin
Select Fuzzy pinyin pairs so
that you can easily enter
characters that are similar
in phonetic spelling
Menu Description
41
Health and safety information
The names and content of toxic and
hazardous substances or elements
O: Indicates that the toxic or hazardous substance contained in
all of the homogeneous materials for this part is below the
limit requirement in SJ/T11363-2006.
X: Indicates that the toxic or hazardous substance contained in
at least one of the homogeneous materials used for this part
is above the limit requirement in SJ/T11363-2006.
Stylus adjust Calibrate your phone’s
touch screen by tapping
the cross hair object firmly
and precisely.
语言
/Language Change the language of the
display text.
Domains preset Change the default domain
name extensions.
Contents status Check information about
the memory currently in
use.
My phone info View your phone
information.
Menu Description
Part
Toxic and hazardous substances or
elements
Pb Hg Cd Cr
6+
PBB PBDE
PBA XOOOOO
Plastic OOOOOO
Metal XOOOOO
Battery XOOOOO
Accessory X O O O O O
Health and safety information
42
The information provided in this table is based on
figures presented by supply manufacturers and tests
conducted by Samsung. All toxic and hazardous
substances or elements are used at the minimum level
allowed by current technology. Samsung continues to
make every effort to reduce the need for these
substances or elements through improved technology.
Exposure to Radio Frequency (RF)
Signals
Certification Information (SAR)
Your wireless phone is a radio transmitter and
receiver. It is designed and manufactured not to
exceed the exposure limits for radio frequency
(RF) energy set by the Federal Communications
Commission (FCC) of the U.S. government.
These FCC exposure limits are derived from the
recommendations of two expert organizations,
the National Counsel on Radiation Protection
and Measurement (NCRP) and the Institute of
Electrical and Electronics Engineers (IEEE). In
both cases, the recommendations were
developed by scientific and engineering experts
drawn from industry, government, and
academia after extensive reviews of the
scientific literature related to the biological
effects of RF energy.
The “environmental protection use period”
for this product is 20 years and the
corresponding logo is as shown on the left.
Exchangeable parts, such as batteries, may
have different periods of warranty. The
“environmental protection use period” is
valid only when the product is used under
normal conditions, as described in the user’s
guide.
43
The exposure limit set by the FCC for wireless
mobile phones employs a unit of measurement
known as the Specific Absorption Rate (SAR).
The SAR is a measure of the rate of absorption
of RF energy by the human body expressed in
units of watts per kilogram (W/kg). The FCC
requires wireless phones to comply with a
safety limit of 1.6 watts per kilogram (1.6 W/
kg). The FCC exposure limit incorporates a
substantial margin of safety to give additional
protection to the public and to account for any
variations in measurements.
SAR tests are conducted using standard
operating positions accepted by the FCC with
the phone transmitting at its highest certified
power level in all tested frequency bands.
Although the SAR is determined at the highest
certified power level, the actual SAR level of the
phone while operating can be well below the
maximum value. This is because the phone is
designed to operate at multiple power levels so
as to use only the power required to reach the
network. In general, the closer you are to a
wireless base station antenna, the lower the
power output.
When approval test is done, no Samsung
supplied accessories are avialable but maybe
available later after approval.
Before a new model phone is available for sale
to the public, it must be tested and certified to
the FCC that it does not exceed the exposure
limit established by the FCC. Tests for each
model phone are performed in positions and
locations (e.g. at the ear and worn on the body)
as required by the FCC.
The highest SAR values for this model phone as
reported to the FCC are: CDMA800
Head:
0.397W/Kg; Body Worn: 0.614W/Kg.
For body worn operation, this model phone has
been tested and meets the FCC RF exposure
guidelines whenused with a Samsung accessory
Health and safety information
44
designated for this product or when used with
an accessory that contains no metal and that
positions the handset a minimum of 1.5 cm
from the body.
Non-compliance with the above restrictions
may result in violation of FCC RF exposure
guidelines.
SAR information on this and other model
phones can be viewed on-line at www.fcc.gov/
oet/fccid. This site uses the phone FCC ID
number, A3LSCHW619. Sometimes it may be
necessary to remove the battery pack to find
the number. Once you have the FCC ID number
for a particular phone, follow the instructions on
the website and it should provide values for
typical or maximum SAR for a particular phone.
Additional product specific SAR information can
also be obtained at www.fcc.gov/cgb/sar.
Consumer Information on Wireless
Phones
The U.S. Food and Drug Administration (FDA)
has published a series of Questions and
Answers for consumers relating to radio
frequency (RF) exposure from wireless phones.
The FDA publication includes the following
information:
What kinds of phones are the subject
of this update?
The term wireless phone refers here to hand-
held wireless phones with built-in antennas,
often called “cell,” “mobile,” or “PCS” phones.
These types of wireless phones can expose the
user to measurable radio frequency energy (RF)
because of the short distance between the
phone and the user's head. These RF exposures
are limited by Federal Communications
Commission safety guidelines that were
developed with the advice of FDA and other
45
federal health and safety agencies. When the
phone is located at greater distances from the
user, the exposure to RF is drastically lower
because a person's RF exposure decreases
rapidly with increasing distance from the
source. The so-called “cordless phones,” which
have a base unit connected to the telephone
wiring in a house, typically operate at far lower
power levels, and thus produce RF exposures
well within the FCC's compliance limits.
Do wireless phones pose a health
hazard?
The available scientific evidence does not show
that any health problems are associated with
using wireless phones. There is no proof,
however, that wireless phones are absolutely
safe. Wireless phones emit low levels of radio
frequency energy (RF) in the microwave range
while being used. They also emit very low levels
of RF when in the stand-by mode. Whereas high
levels of RF can produce health effects (by
heating tissue), exposure to low level RF that
does not produce heating effects causes no
known adverse health effects. Many studies of
low level RF exposures have not found any
biological effects. Some studies have suggested
that some biological effects may occur, but such
findings have not been confirmed by additional
research. In some cases, other researchers
have had difficulty in reproducing those studies,
or in determining the reasons for inconsistent
results.
What is FDA's role concerning the
safety of wireless phones?
Under the law, FDA does not review the safety
of radiation-emitting consumer products such
as wireless phones before they can be sold, as
it does with new drugs or medical devices.
However, the agency has authority to take
action if wireless phones are shown to emit
radio frequency energy (RF) at a level that is
hazardous to the user. In such a case, FDA
Health and safety information
46
could require the manufacturers of wireless
phones to notify users of the health hazard and
to repair, replace or recall the phones so that
the hazard no longer exists.
Although the existing scientific data do not
justify FDA regulatory actions, FDA has urged
the wireless phone industry to take a number of
steps, including the following:
• “Support needed research into possible
biological effects of RF of the type emitted
by wireless phones;
• “Design wireless phones in a way that
minimizes any RF exposure to the user that
is not necessary for device function; and
• “Cooperate in providing users of wireless
phones with the best possible information
on possible effects of wireless phone use on
human health.
FDA belongs to an interagency working group of
the federal agencies that have responsibility for
different aspects of RF safety to ensure
coordinated efforts at the federal level. The
following agencies belong to this working
group:
• “National Institute for Occupational Safety
and Health
• “Environmental Protection Agency
• “Federal Communications Commission
• “Occupational Safety and Health
Administration
• “National Telecommunications and
Information Administration
The National Institutes of Health participates in
some interagency working group activities, as
well.
FDA shares regulatory responsibilities for
wireless phones with the Federal
Communications Commission (FCC). All phones
that are sold in the United States must comply
with FCC safety guidelines that limit RF
exposure. FCC relies on FDA and other health
47
agencies for safety questions about wireless
phones.
FCC also regulates the base stations that the
wireless phone networks rely upon. While these
base stations operate at higher power than do
the wireless phones themselves, the RF
exposures that people get from these base
stations are typically thousands of times lower
than those they can get from wireless phones.
Base stations are thus not the primary subject
of the safety questions discussed in this
document.
What are the results of the research
done already?
The research done thus far has produced
conflicting results, and many studies have
suffered from flaws in their research methods.
Animal experiments investigating the effects of
radio frequency energy (RF) exposures
characteristic of wireless phones have yielded
conflicting results that often cannot be repeated
in other laboratories. A few animal studies,
however, have suggested that low levels of RF
could accelerate the development of cancer in
laboratory animals. However, many of the
studies that showed increased tumor
development used animals that had been
genetically engineered or treated with cancer-
causing chemicals so as to be pre-disposed to
develop cancer in absence of RF exposure.
Other studies exposed the animals to RF for up
to 22 hours per day. These conditions are not
similar to the conditions under which people
use wireless phones, so we don't know with
certainty what the results of such studies mean
for human health.
Three large epidemiology studies have been
published since December 2000. Between
them, the studies investigated any possible
association between the use of wireless phones
and primary brain cancer, glioma, meningioma,
or acoustic neuroma, tumors of the brain or
salivary gland, leukemia, or other cancers.
Health and safety information
48
None of the studies demonstrated the existence
of any harmful health effects from wireless
phones RF exposures. However, none of the
studies can answer questions about long-term
exposures, since the average period of phone
use in these studies was around three years.
What research is needed to decide
whether RF exposure from wireless
phones poses a health risk?
A combination of laboratory studies and
epidemiological studies of people actually using
wireless phones would provide some of the data
that are needed. Lifetime animal exposure
studies could be completed in a few years.
However, very large numbers of animals would
be needed to provide reliable proof of a cancer
promoting effect if one exists. Epidemiological
studies can provide data that is directly
applicable to human populations, but ten or
more years' follow-up may be needed to
provide answers about some health effects,
such as cancer. This is because the interval
between the time of exposure to a cancer-
causing agent and the time tumors develop - if
they do - may be many, many years. The
interpretation of epidemiological studies is
hampered by difficulties in measuring actual RF
exposure during day-to-day use of wireless
phones. Many factors affect this measurement,
such as the angle at which the phone is held, or
which model of phone is used.
What is FDA doing to find out more
about the possible health effects of
wireless phone RF?
FDA is working with the U.S. National
Toxicology Program and with groups of
investigators around the world to ensure that
high priority animal studies are conducted to
address important questions about the effects
of exposure to radio frequency energy (RF).
FDA has been a leading participant in the World
Health Organization international
49
Electromagnetic Fields (EMF) Project since its
inception in 1996. An influential result of this
work has been the development of a detailed
agenda of research needs that has driven the
establishment of new research programs
around the world. The Project has also helped
develop a series of public information
documents on EMF issues.
FDA and Cellular Telecommunications &
Internet Association (CTIA) have a formal
Cooperative Research and Development
Agreement (CRADA) to do research on wireless
phone safety. FDA provides the scientific
oversight, obtaining input from experts in
government, industry, and academic
organizations. CTIA-funded research is
conducted through contracts to independent
investigators. The initial research will include
both laboratory studies and studies of wireless
phone users. The CRADA will also include a
broad assessment of additional research needs
in the context of the latest research
developments around the world.
What steps can I take to reduce my
exposure to radio frequency energy
from my wireless phone?
If there is a risk from these products - and at
this point we do not know that there is - it is
probably very small. But if you are concerned
about avoiding even potential risks, you can
take a few simple steps to minimize your
exposure to radio frequency energy (RF). Since
time is a key factor in how much exposure a
person receives, reducing the amount of time
spent using a wireless phone will reduce RF
exposure.
• “If you must conduct extended
conversations by wireless phone every day,
you could place more distance between
your body and the source of the RF, since
the exposure level drops off dramatically
Health and safety information
50
with distance. For example, you could use a
headset and carry the wireless phone away
from your body or use a wireless phone
connected to a remote antenna.
Again, the scientific data do not demonstrate
that wireless phones are harmful. But if you are
concerned about the RF exposure from these
products, you can use measures like those
described above to reduce your RF exposure
from wireless phone use.
What about children using wireless
phones?
The scientific evidence does not show a danger
to users of wireless phones, including children
and teenagers. If you want to take steps to
lower exposure to radio frequency energy (RF),
the measures described above would apply to
children and teenagers using wireless phones.
Reducing the time of wireless phone use and
increasing the distance between the user and
the RF source will reduce RF exposure.
Some groups sponsored by other national
governments have advised that children be
discouraged from using wireless phones at all.
For example, the government in the United
Kingdom distributed leaflets containing such a
recommendation in December 2000. They
noted that no evidence exists that using a
wireless phone causes brain tumors or other ill
effects. Their recommendation to limit wireless
phone use by children was strictly
precautionary; it was not based on scientific
evidence that any health hazard exists.
Do hands-free kits for wireless phones
reduce risks from exposure to RF
emissions?
Since there are no known risks from exposure
to RF emissions from wireless phones, there is
no reason to believe that hands-free kits reduce
51
risks. Hands-free kits can be used with wireless
phones for convenience and comfort. These
systems reduce the absorption of RF energy in
the head because the phone, which is the
source of the RF emissions, will not be placed
against the head. On the other hand, if the
phone is mounted against the waist or other
part of the body during use, then that part of
the body will absorb more RF energy. Wireless
phones marketed in the U.S. are required to
meet safety requirements regardless of
whether they are used against the head or
against the body. Either configuration should
result in compliance with the safety limit.
Do wireless phone accessories that
claim to shield the head from RF
radiation work?
Since there are no known risks from exposure
to RF emissions from wireless phones, there is
no reason to believe that accessories that claim
to shield the head from those emissions reduce
risks. Some products that claim to shield the
user from RF absorption use special phone
cases, while others involve nothing more than a
metallic accessory attached to the phone.
Studies have shown that these products
generally do not work as advertised. Unlike
“hand-free” kits, these so-called “shields” may
interfere with proper operation of the phone.
The phone may be forced to boost its power to
compensate, leading to an increase in RF
absorption. In February 2002, the Federal trade
Commission (FTC) charged two companies that
sold devices that claimed to protect wireless
phone users from radiation with making false
and unsubstantiated claims. According to FTC,
these defendants lacked a reasonable basis to
substantiate their claim.
What about wireless phone
interference with medical equipment?
Health and safety information
52
Radio frequency energy (RF) from wireless
phones can interact with some electronic
devices. For this reason, FDA helped develop a
detailed test method to measure
electromagnetic interference (EMI) of implanted
cardiac pacemakers and defibrillators from
wireless telephones. This test method is now
part of a standard sponsored by the Association
for the Advancement of Medical instrumentation
(AAMI). The final draft, a joint effort by FDA,
medical device manufacturers, and many other
groups, was completed in late 2000. This
standard will allow manufacturers to ensure
that cardiac pacemakers and defibrillators are
safe from wireless phone EMI. FDA has tested
wireless phones and helped develop a voluntary
standard sponsored by the Institute of Electrical
and Electronic Engineers (IEEE). This standard
specifies test methods and performance
requirements for hearing aids and wireless
phones so that no interference occurs when a
person uses a compatible phone and a
compatible hearing aid at the same time. This
standard was approved by the IEEE in 2000.
FDA continues to monitor the use of wireless
phones for possible interactions with other
medical devices. Should harmful interference
be found to occur, FDA will conduct testing to
assess the interference and work to resolve the
problem.
Additional information on the safety of RF
exposures from various sources can be
obtained from the following organizations:
• FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
• Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
• Occupational Safety and Health
Administration's (OSHA):
http://www.osha.gov/SLTC/
radiofrequencyradiation/index.html
53
• National institute for Occupational Safety
and Health (NIOSH):
http://www.cdc.gov/niosh/emfpg.html
• World health Organization (WHO):
http://www.who.int/peh-emf/
• International Commission on Non-Ionizing
Radiation Protection:
http://www.icnirp.de
• National Radiation Protection Board (UK):
http://www.nrpb.org.uk
• Updated 4/3/2002: US food and Drug
Administration
http://www.fda.gov/cellphones
Road Safety
Your wireless phone gives you the powerful
ability to communicate by voice, almost
anywhere, anytime. But an important
responsibility accompanies the benefits of
wireless phones, one that every user must
uphold.
When driving a car, driving is your first
responsibility. When using your wireless phone
behind the wheel of a car, practice good
common sense and remember the following
tips:
1. Get to know your wireless phone and its
features, such as speed dial and redial. If
available, these features help you to place
your call without taking your attention off
the road.
2. When available, use a hands-free device. If
possible, add an additional layer of
convenience and safety to your wireless
Health and safety information
54
phone with one of the many hands free
accessories available today.
3. Position your wireless phone within easy
reach. Be able to access your wireless
phone without removing your eyes from the
road. If you get an incoming call at an
inconvenient time, let your voice mail
answer it for you.
4. Let the person you are speaking with know
you are driving; if necessary, suspend the
call in heavy traffic or hazardous weather
conditions. Rain, sleet, snow, ice and even
heavy traffic can be hazardous.
5. Do not take notes or look up phone
numbers while driving. Jotting down a “to
do” list or flipping through your address
book takes attention away from your
primary responsibility, driving safely.
6. Dial sensibly and assess the traffic; if
possible, place calls when you are not
moving or before pulling into traffic. Try to
plan calls when your car will be stationary.
If you need to make a call while moving,
dial only a few numbers, check the road and
your mirrors, then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting. Make
people you are talking with aware you are
driving and suspend conversations that
have the potential to divert your attention
from the road.
8. Use your wireless phone to call for help.
Dial 9-1-1 or other local emergency number
in the case of fire, traffic accident or
medical emergencies. Remember, it is a free
call on your wireless phone!
9. Use your wireless phone to help others in
emergencies. If you see an auto accident,
crime in progress or other serious
emergency where lives are in danger, call 9-
1-1 or other local emergency number, as
you would want others to do for you.
55
10. Call roadside assistance or a special non-
emergency wireless assistance number
when necessary. If you see a broken-down
vehicle posing no serious hazard, a broken
traffic signal, a minor traffic accident where
no one appears injured, or a vehicle you
know to be stolen, call roadside assistance
or other special non-emergency number.
“The wireless industry reminds you to
use your phone safely when driving.”
For more information, please call 1-888-901-
SAFE, or visit our web-site www.wow-com.com
Provided by the Cellular Telecommunications &
Internet Association
Operating Environment
Remember to follow any special regulations in
force in any area and always switch your phone
off whenever it is forbidden to use it, or when it
may cause interference or danger. When
connecting the phone or any accessory to
another device, read its user's guide for
detailed safety instructions. Do not connect
incompatible products.
As with other mobile radio transmitting
equipment, users are advised that for the
satisfactory operation of the equipment and for
the safety of personnel, it is recommended that
the equipment should only be used in the
normal operating position (held to your ear with
the antenna pointing over your shoulder).
Using Your Phone Near Other
Electronic Devices
Most modern electronic equipment is shielded
from radio frequency (RF) signals. However,
certain electronic equipment may not be
shielded against the RF signals from your
wireless phone. Consult the manufacturer to
discuss alternatives.
Health and safety information
56
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be
maintained between a wireless phone and a
pacemaker to avoid potential interference with
the pacemaker.
These recommendations are consistent with the
independent research and recommendations of
Wireless Technology Research.
Persons with pacemakers:
• should always keep the phone more than 15
cm
(6 inches) from their pacemaker when the
phone is switched on.
• should not carry the phone in a breast
pocket.
• should use the ear opposite the pacemaker
to minimize potential interference.
If you have any reason to suspect that
interference is taking place, switch your phone
off immediately.
Hearing Aids
Some digital wireless phones may interfere with
some hearing aids. In the event of such
interference, you may wish to consult your
hearing aid manufacturer to discuss
alternatives.
Other Medical Devices
If you use any other personal medical devices,
consult the manufacturer of your device to
determine if it is adequately shielded from
external RF energy. Your physician may be able
to assist you in obtaining this information.
Switch your phone off in health care facilities
when any regulations posted in these areas
instruct you to do so. Hospitals or health care
facilities may be using equipment that could be
sensitive to external RF energy.
57
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in
motor vehicles. Check with the manufacturer or
its representative regarding your vehicle. You
should also consult the manufacturer of any
equipment that has been added to your vehicle.
Posted Facilities
Switch your phone off in any facility where
posted notices require you to do so.
Potentially Explosive Environments
Switch your phone off when in any area with a
potentially explosive atmosphere and obey all
signs and instructions. Sparks in such areas
could cause an explosion or fire resulting in
bodily injury or even death.
Users are advised to switch the phone off while
at a refueling point (service station). Users are
reminded of the need to observe restrictions on
the use of radio equipment in fuel depots (fuel
storage and distribution areas), chemical plants
or where blasting operations are in progress.
Areas with a potentially explosive atmosphere
are often but not always clearly marked. They
include below deck on boats, chemical transfer
or storage facilities, vehicles using liquefied
petroleum gas (such as propane or butane),
areas where the air contains chemicals or
particles, such as grain, dust or metal powders,
and any other area where you would normally
be advised to turn off your vehicle engine.
Health and safety information
58
Emergency Calls
This phone, like any wireless phone, operates
using radio signals, wireless and landline
networks as well as user programmed
functions, which cannot guarantee connection
in all conditions. Therefore, you should never
rely solely on any wireless phone for essential
communications (medical emergencies, for
example).
Remember, to make or receive any calls the
phone must be switched on and in a service
area with adequate signal strength. Emergency
calls may not be possible on all wireless phone
networks or when certain network services and/
or phone features are in use. Check with local
service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your
present location (for example, 911 or other
official emergency number). Emergency
numbers vary by location.
3. Press .
If certain features are in use (call barring, for
example), you may first need to deactivate
those features before you can make an
emergency call. Consult this document and
your local cellular service provider.
When making an emergency call, remember to
give all the necessary information as accurately
as possible. Remember that your phone may be
the only means of communication at the scene
of an accident; do not cut off the call until given
permission to do so.
Restricting Children's access to your
Phone
Your phone is not a toy. Children should not be
allowed to play with it because they could hurt
themselves and others, damage the phone or
make calls that increase your phone bill.
59
FCC Notice and Cautions
FCC Notice
•
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) this device
may not cause harmful interference, and
(2) this device must accept any interference
received, including interference that may
cause undesired operation.
• This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation. This equipment generates, uses
and can radiate radio frequency energy and,
if
not installed and used in accordance with
the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user
is encouraged to try to correct the
interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the
equipment and receiver.
-Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced
radio/TV technician for help.
Health and safety information
60
The phone may cause TV or radio interference if
used in close proximity to receiving equipment.
The FCC can require you to stop using the
phone if such interference cannot be
eliminated.
Vehicles using liquefied petroleum gas (such as
propane or butane) must comply with the
National Fire Protection Standard (NFPA-58).
For a copy of this standard, contact the National
Fire Protection Association, One Battery march
Park, Quincy, MA 02269, Attn: Publication Sales
Division.
Cautions
Changes or modifications made in the radio
phone, not expressly approved by Samsung, will
void the user’s authority to operate the
equipment.
Only use approved batteries, antennas and
chargers. The use of any unauthorized
accessories may be dangerous and void the
phone warranty if said accessories cause
damage or a defect to the phone.
Although your phone is quite sturdy, it is a
complex piece of equipment and can be broken.
Avoid dropping, hitting, bending or sitting on it.
Other Important Safety
Information
• Only qualified personnel should service the
phone or install the phone in a vehicle.
Faulty installation or service may be
dangerous and may invalidate any warranty
applicable to the device.
• Check regularly that all wireless phone
equipment in your vehicle is mounted and
operating properly.
• Do not store or carry flammable liquids,
gases or explosive materials in the same
compartment as the phone, its parts or
accessories.
61
• For vehicles equipped with an air bag,
remember that an air bag inflates with
great force. Do not place objects, including
both installed or portable wireless
equipment in the area over the air bag or in
the air bag deployment area. If wireless
equipment is improperly installed and the
air bag inflates, serious injury could result.
• Switch your phone off before boarding an
aircraft. The use of wireless phone in
aircraft is illegal and may be dangerous to
the aircraft's operation.
• Failure to observe these instructions may
lead to the suspension or denial of
telephone services to the offender, or legal
action, or both.
Product Performance
Getting the Most Out of Your Signal
Reception
The quality of each call you make or receive
depends on the signal strength in your area.
Your phone informs you of the current signal
strength by displaying a number of bars next to
the signal strength icon. The more bars
displayed, the stronger the signal.
If you're inside a building, being near a window
may give you better reception.
Understanding the Power Save
Feature
If your phone is unable to find a signal after 15
minutes of searching, a Power Save feature is
automatically activated. If your phone is active,
it periodically rechecks service availability or
you can check it yourself by pressing any key.
Health and safety information
62
Anytime the Power Save feature is activated, a
message displays on the screen. When a signal
is found, your phone returns to standby mode.
Understanding How Your Phone
Operates
Your phone is basically a radio transmitter and
receiver. When it's turned on, it receives and
transmits radio frequency (RF) signals. When
you use your phone, the system handling your
call controls the power level. This power can
range from 0.006 watts to 0.2 watts in digital
mode.
Maintaining Your Phone's Peak
Performance
For the best care of your phone, only authorized
personnel should service your phone and
accessories. Faulty service may void the
warranty.
There are several simple guidelines to operating
your phone properly and maintaining safe,
satisfactory service.
• Hold the phone with the antenna raised,
fully-extended and over your shoulder.
• Try not to hold, bend or twist the phone's
antenna.
• Don't use the phone if the antenna is
damaged.
• Speak directly into the phone's receiver.
• Avoid exposing your phone and accessories
to rain or liquid spills. If your phone does
get wet, immediately turn the power off and
remove the battery. If it is inoperable, call
Customer Care for service.
Availability of Various Features/
Ring Tones
Many services and features are network
dependent and may require additional
63
subscription and/or usage charges. Not all
features are available for purchase or use in all
areas. Downloadable Ring Tones may be
available at an additional cost. Other conditions
and restrictions may apply. See your service
provider for additional information.
Battery Standby and Talk Time
Standby and talk times will vary depending on
phone usage patterns and conditions. Battery
power consumption depends on factors such as
network configuration, signal strength,
operating temperature, features selected,
frequency of calls, and voice, data, and other
application usage patterns.
Battery Precautions
• Never use any charger or battery that is
damaged in any way.
• Use the battery only for its intended
purpose.
• If you use the phone near the network's
base station, it uses less power; talk and
standby time are greatly affected by the
signal strength on the cellular network and
the parameters set by the network operator.
• Battery charging time depends on the
remaining battery charge and the type of
battery and charger used. The battery can
be charged and discharged hundreds of
times, but it will gradually wear out. When
the operation time (talk time and standby
time) is noticeably shorter than normal, it is
time to buy a new battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not
in use, disconnect it from the power source.
Do not leave the battery connected to a
charger for more than a week, since
overcharging may shorten its life.
Health and safety information
64
• Extreme temperatures will affect the
charging capacity of your battery: it may
require cooling or warming first.
• Do not leave the battery in hot or cold
places, such as in a car in summer or winter
conditions, as you will reduce the capacity
and lifetime of the battery. Always try to
keep the battery at room temperature. A
phone with a hot or cold battery may
temporarily not work, even when the
battery is fully charged. Li-ion batteries are
particularly affected by temperatures below
0 °C (32 °F).
• Do not short-circuit the battery. Accidental
short- circuiting can occur when a metallic
object (coin, clip or pen) causes a direct
connection between the + and - terminals
of the battery (metal strips on the battery),
for example when you carry a spare battery
in a pocket or bag. Short-circuiting the
terminals may damage the battery or the
object causing the short-circuiting.
• Dispose of used batteries in accordance
with local regulations. In some areas, the
disposal of batteries in household or
business trash may be prohibited. For safe
disposal options for Li-Ion batteries, contact
your nearest Samsung authorized service
center. Always recycle. Do not dispose of
batteries in a fire.
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care.
The suggestions below will help you fulfill any
warranty obligations and allow you to enjoy this
product for many years.
• Keep the phone and all its parts and
accessories out of the reach of small
children.
• Keep the phone dry. Precipitation, humidity
and liquids contain minerals that will
corrode electronic circuits.
65
• Do not use the phone with a wet hand.
Doing so may cause an electric shock to you
or damage to the phone.
• Do not use or store the phone in dusty, dirty
areas, as its moving parts may be
damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of
electronic devices, damage batteries, and
warp or melt certain plastics.
• Do not store the phone in cold areas. When
the phone warms up to its normal operating
temperature, moisture can form inside the
phone, which may damage the phone's
electronic circuit boards.
• Do not drop, knock or shake the phone.
Rough handling can break internal circuit
boards.
• Do not use harsh chemicals, cleaning
solvents or strong detergents to clean the
phone. Wipe it with a soft cloth slightly
dampened in a mild soap-and-water
solution.
• Do not paint the phone. Paint can clog the
device's moving parts and prevent proper
operation.
• Do not put the phone in or on heating
devices, such as a microwave oven, a stove
or a radiator. The phone may explode when
overheated.
• When the phone or battery gets wet, the
label indicating water damage inside the
phone changes color. In this case, phone
repairs are no longer guaranteed by the
manufacturer's warranty, even if the
warranty for your phone has not expired.
• If your phone has a flash or light, do not
use it too close to the eyes of people or
animals. This may cause damage to their
eyes.
Health and safety information
66
• Use only the supplied or an approved
replacement antenna. Unauthorized
antennas or modified accessories may
damage the phone and violate regulations
governing radio devices.
• If the phone, battery, charger or any
accessory is not working properly, take it to
your nearest qualified service facility. The
personnel there will assist you, and if
necessary, arrange for service.
Licensed by QUALCOMM incorporated under one
or more of the following Patents.
U.S Patent No. 4,901,307 5,056,109
5,099,204 5,101,501
5,103,459 5,107,225
5,109,390
