Samsung Electronics Co Ltd Single-Mode Cellular Phone (CDMA) 0 COVER 1
Users Manual
* Some of the contents in this manual may differ from your phone,
depending on the software installed or your service provider.
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No. : GH68-05542A
English. 08/2004. Rev.1.0
ELECTRONIC
S
PORTABLE CELLULAR
TELEPHONE
SCH-X839
3
Table of contents
Important safety precautions.................................7
Unpacking ..............................................................9
Your phone...........................................................10
Phone layout........................................................... 10
Display................................................................... 13
Backlight ................................................................ 15
Service light............................................................ 15
Camera.................................................................. 15
Flash...................................................................... 16
Getting started .....................................................17
Using a battery........................................................ 17
Switching on or off the phone.................................... 20
Using the soft keys .................................................. 22
Your phone’s modes................................................. 23
Call functions........................................................25
Making a call........................................................... 25
Ending a call ........................................................... 26
Emergency dialing ................................................... 26
Using the recent call logs.......................................... 27
Making a call from Phonebook ................................... 27
Prepend dialing ....................................................... 28
Speed dialing .......................................................... 29
Pause dialing........................................................... 29
Adjusting the volume during a call ............................. 31
Answering a call ...................................................... 33
Silencing an incoming call......................................... 33
Rejecting a call........................................................ 34
Viewing missed calls ................................................ 34
Options during a call ................................................ 34
Three-way calling .................................................... 35
Call waiting............................................................. 36
Call forwarding........................................................ 36
Entering text ........................................................37
Changing the text input mode ................................... 37
Table of contents
4
Using T9 Word, T9 Hebrew mode............................... 38
Using ABC, Hebrew mode ......................................... 40
Using Symbol mode ................................................. 43
Using 123 mode ...................................................... 43
Using the menus...................................................44
Accessing a menu function by scrolling ....................... 44
Using shortcuts ....................................................... 45
List of menu functions .............................................. 46
Calls .....................................................................51
Missed
(Menu 1-1)
.................................................... 51
Incoming
(Menu 1-2)
................................................ 52
Outgoing
(Menu 1-3)
................................................. 53
Air Time
(Menu 1-4)
.................................................. 53
Phonebook............................................................54
Find
(Menu 2-1)
....................................................... 54
Add
(Menu 2-2)
........................................................ 57
Group Set
(Menu 2-3)
............................................... 61
My Phone #
(Menu 2-4)
............................................. 62
Message ...............................................................63
Text Msg
(Menu 3-1)
................................................. 63
MMS
(Menu 3-2)
....................................................... 68
Voice mail
(Menu 3-3)
............................................... 73
Msg Setup
(Menu 3-4)
............................................... 74
Scheduler .............................................................78
Calendar
(Menu 4-1)
................................................. 78
Alarm Set
(Menu 4-2)
............................................... 81
Calculator
(Menu 4-3)
............................................... 82
Today
(Menu 4-4)
..................................................... 82
To Do List
(Menu 4-5)
............................................... 83
World Time
(Menu 4-6)
............................................. 84
Countdown
(Menu 4-7)
.............................................. 85
Memo Pad
(Menu 4-8)
............................................... 86
Games ..................................................................87
ChickenRun
(Menu 5-1)
............................................. 88
MobileCop
(Menu 5-2)
............................................... 88
Voice Tools ...........................................................90
Table of contents
5
Voice Memo
(Menu 6-1)
............................................. 90
Voice Answer
(Menu 6-2)
............................................ 92
Settings................................................................95
Sounds
(Menu 7-1)
.................................................... 95
Display
(Menu 7-2)
................................................... 99
Auto Retry
(Menu 7-3)
............................................ 103
Answer Mode
(Menu 7-4)
......................................... 103
Roam Option
(Menu 7-5)
......................................... 104
Security
(Menu 7-6)
................................................ 105
Data Option
(Menu 7-7)
........................................... 109
Data/Fax Mode
(Menu 7-8)
...................................... 109
Memory Status
(Menu 7-9)
...................................... 111
VAS.....................................................................112
Internet Portal
(Menu 8-1)
....................................... 112
Games & App
(Menu 8-2)
......................................... 116
Multimedia
(Menu 8-3)
............................................ 118
Ringtone
(Menu 8-4)
............................................... 119
Animation
(Menu 8-5)
............................................. 119
Voice portal
(Menu 8-6)
........................................... 120
SMS info
(Menu 8-7)
............................................... 120
What’s new?
(Menu 8-8)
.......................................... 121
Camera...............................................................122
Take Photo
(Menu 9-1)
............................................ 122
Record Video
(Menu 9-2)
......................................... 126
Photo Album
(Menu 9-3)
.......................................... 128
Video Album
(Menu 9-4)
.......................................... 129
MMS
(Menu 9-5)
..................................................... 131
Settings
(Menu 9-6)
................................................ 134
Memory Status
(Menu 9-7)
...................................... 134
Health and safety information ............................135
Exposure to radio frequency (RF) signals .................. 135
For body operation................................................. 137
Precautions when using batteries............................. 138
Road safety .......................................................... 139
Operating environment........................................... 140
Electronic devices .................................................. 140
Potentially Explosive Environments .......................... 142
Emergency calls .................................................... 143
Other important safety information .......................... 144
Care and maintenance............................................ 145
Table of contents
6
Glossary .............................................................147
Index..................................................................149
Quick reference card...........................................153
7
Important safety
precautions
Read these guidelines before using your wireless
phone. Failure to comply with them may be
dangerous or illegal.
Road safety at all times
Do not use a hand-held phone while driving; park
the vehicle first.
Switching off when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switching off in an aircraft
Wireless phones can cause interference. Using them
in an aircraft is both illegal and dangerous.
Switching off in hospitals
Switch off your phone near medical equipment.
Follow any regulations or rules in force.
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Special regulations
Meet any special regulations in force in any area
and always with off your phone whenever it is
forbidden to use it, or when it may cause
interference or danger (in a hospital for example).
Important safety precautions
8
Sensible use
Use only in the normal position (held to the ear).
Avoid unnecessary contact with the antenna when
the phone is switched on.
Emergency call
Ensure the phone is switched on and in service. Key
in the emergency number for your present location,
then press the key. You must deactivate any
unnecessary features in use before you can make
an emergency call. Give all necessary information
as accurately as possible. Do not end the call until
given permission to do so.
Water resistance
Your phone is not water-resistant. Keep it dry.
Accessories and batteries
Use only Samsung-approved accessories and
batteries. Use of any unauthorized accessories
could damage your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see “Health
and safety information” on page 135.
CAUTION
RISK OF EXPLOSION IF A BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO
THE INSTRUCTIONS.
9
Unpacking
Your package contains the following items. The
illustrations below may look different from your
phone and accessories:
Handset Travel adapter
Battery Wearable ear microphone
Hand strap
User’s manual
10
Your phone
Phone layout
The following illustrations show the main elements
of your phone:
With the phone open
Earpiece
Display
Microphone
Headset jack
Navigation (Up/
Down/Left/
Right) keys
VAS key
Soft key (right)
Soft key (left)
Volume/menu
browse keys
Dial key
Power On/Off/
menu exit key
Cancel/
correction ley
Alphanumeric
keys
Special
function keys
Your phone
11
With the phone closed
Key
(s)
Description
(soft keys)
Performs the functions indicated by the
screen text above them, on the bottom
line of the display.
In Menu mode, scrolls through menu
options.
In Standby mode; quickly enters the
following menu respectively:
• Up:
AGPS
• Down:
Games & App
• Left:
Message
• Right:
Find
Enters the
VAS
menu.
Makes or answers a call.
In Standby mode, retrieves the most
recent numbers dialed, received, or
missed. Redials the last number when
pressed and held.
Camera
Antenna
External display
Flash Camera key
Service light
Your phone
12
Ends a call. Also switches the phone on
and off when pressed and held.
In Menu mode, cancels your input and
returns to Standby mode.
Deletes characters from the display.
In Menu mode, returns you to the
previous menu level.
Enters numbers, letters, and some
special characters.
In Standby mode, allows you to change
the call ringer when pressed and held.
In the text entry mode, changes the
case of letters.
In Standby mode, quickly enters or
exits Silent mode when pressed and
held.
In the text entry mode, inserts a space.
(on the right side of the phone)
Allows you to quickly access the
Camera
menu. Turns on the camera
when pressed and held.
(on the left side of the phone)
During a call, adjust the voice volume.
In Standby mode, adjusts the Key Tone
volume.
Key
(s)
Description
(continued)
Your phone
13
Display
The display has three areas: the top line of icons,
the text and graphic area, and the bottom line of
soft key indicators.
Icons
Icon Description
Signal strength
: Shows the received
signal strength. The greater the number
of bars, the better the signal.
Service
: Appears when a call is in
progress.
No service
: Appears when you are
outside a service area. When it displays,
you cannot make or receive calls. Wait a
little while for a better signal or move into
an open area to regain service.
Roaming
: Appears when you are out of
your home area and have logged onto a
different network; for example, when
traveling in other countries.
Icons
Text and
graphics area
Soft key function
indicators
Menu
VM
Your phone
14
External display
Your phone has an external display on the phone.
When you close the phone, it turns on and indicates
when you have an incoming call or a message. It
also alerts you at the specified time when you have
set an alarm by turning its backlight and showing
the corresponding icon on it.
Alarm mode
: Appears when you set an
alarm to ring at a specified time.
New message
: Indicates that there is a
new message waiting to be checked.
Vibration mode
: Appears when the
ringer volume for call is set to
Vibrate
or
when your phone is in Silent mode.
Restriction on
: Appears when any option
of the Restriction feature is activated.
Lock mode
: Appears when your phone is
locked.
Ringer silent
: Appears when the ringer
volume for calls is set to
Silent
.
New voice mail message
: Indicates
that there is a new voice mail message
waiting to be checked.
VAS message
: Indicates that there is a
new message waiting to be checked.
Battery status
: Shows the level of your
battery. The more bars you see, the more
power you have remaining.
Icon Description
(continued)
Your phone
15
When the display is off, press and hold one of the
Volume keys on the left side of the phone to turn on
the display.
Backlight
The backlight illuminates the display and keypad.
When you press any key or open the phone, the
backlight illuminates. It turns off if no key is
pressed within a given period of time, depending on
the
Backlight
menu (
Menu 7-2-3
) set in the
Display
menu.
To specify the length of time the phone waits before
the backlight turns off, set the
Backlight
menu.
See page 100 for further details.
Service light
The service light on the front of the phone, on the
right side of the camera, flashes to indicate an
incoming call, message, or alarm and flashes for a
few seconds when you turn on or off the phone. It
blinks while the battery is charging with the travel
adapter; the color of the light turns green when the
battery is fully charged.
Camera
The camera module on the front of the phone
allows you to take a photo or record a video while
on the move.
For further details about the Camera feature, see
page 122.
Your phone
16
Flash
You can use the built-in flash on the front of the
phone, on the left side of the camera, to take
photos when it is dark.
17
Getting started
Using a battery
Your phone is powered by a rechargeable Li-ion
battery. Use only approved batteries and chargers.
Ask your local Samsung dealer for further details.
Note
: You must fully charge the battery before using
your phone for the first time. A discharged
battery recharges fully in approximately 120
minutes for a standard battery.
Installing the battery
1. Place the battery so that the tabs on the end
align with the slots at the bottom of the phone.
Getting started
18
2. Press the battery until it clicks into place.
Make sure that the battery is properly installed
before switching on the phone.
Removing the battery
1. If necessary, switch off the phone by pressing
and holding the key down until the power-
off image displays.
2. To remove the battery. To do so:
➀
Slide the battery lock towards the top of the
phone.
➁
Lift away the battery, as shown.
➀
➁
Getting started
19
Charging the battery
A travel adapter and a battery charger are provided
for charging your batteries.
Using the travel adapter
The travel adapter allows you to use the phone
while the battery is charging, but this will cause the
battery to charge more slowly.
1. With the battery in position on the phone, plug
the connector of the travel adapter into the jack
at the bottom of the phone.
Make sure that the arrow on the connector is
facing toward the front of the phone.
2. Plug the adapter into a standard AC wall outlet.
The battery strength icon on the display shows
that the battery is charging.
Getting started
20
3. When charging is finished, unplug the adapter
from both the power outlet and the phone by
pressing the buttons on both sides of the
connector and pulling the connector out.
Note
: Do not remove the battery from the phone
without unplugging the adapter while it is
charging. Otherwise, the phone may be
damaged.
Low battery indicator
When the battery is weak and only a few minutes of
talk time remain, the battery sensor will let you
know by blinking the empty Battery Strength icon
( ) and you will hear a warning tone and a ”LOW
BATTERY WARNING!” message will be repeated at
regular intervals on the display. When the battery
becomes too weak for the phone to operate, it
switches off automatically.
Switching on or off the phone
1. Open the phone.
2. Press and hold the key for more than one
second to switch on the phone.
➀
➀
➁
Getting started
21
3. The service light flashes and then the idle screen
appears on the display when the system locates
services.
If the phone is out of the service area, the No
Service icon ( ) appears on the display. In this
case, you cannot place and receive calls. You
can try again later when service is available.
Note
: You can change the display language in the
Language/
menu (
Menu 7-2-7
).
See page 103.
4. When you wish to switch off the phone, press
and hold the key for more than one seconds
until the power-off image displays.
WARNING!
Do not switch on the phone when mobile phone use
is prohibited or when it may cause interference or
danger.
Note
: Do not touch the antenna on the phone
unnecessarily when the phone is switched on.
Contact with the antenna affects the call quality
and may cause the phone to operate at a
higher power level than otherwise needed.
Getting started
22
Using the soft keys
Your phone offers a set of functions that allows you
to customize it. These functions are arranged in
menus and submenus, accessed using the two soft
keys, and . Each menu and submenu allows
you to view and alter the settings of a particular
function.
The roles of the soft keys vary, depending on the
current function you are using; the labels on the
bottom line of the display just above each key
indicate their current role.
Example:
Menu
VM
09:58 Mon Jun25
SAMSUNG
Press the left soft
key to access Menu
mode.
Press the right soft
key to access the
Voice Answer
menu.
Getting started
23
Your phone’s modes
Standby mode
Standby mode is the most basic state of your
phone. The phone goes into Standby mode soon
after you turn it on, or whenever you briefly press
the key. When your phone is in Standby mode,
you will typically see the current time and date. If
you enter a phone number, you can press the
key to dial it, or press the
Save
soft key to save it
in the internal phonebook.
Press the key at any time to return to Standby
mode. Be careful; if you are on a call when you
press the key, your phone disconnects the call
and returns to Standby mode. Press the
C
key
several times or hold it to return to Standby mode
without ending the call.
Talk mode
You can place and answer calls only when your
phone is turned on. During a call, the phone is in
Talk mode. While you are in Talk mode, pressing
the
Menu
soft key gives you a list of options. See
page 34 for details on the options.
Power Save mode
Your phone comes with a power save feature that
will automatically be activated if your phone is
unable to find a signal after 15 minutes of
searching. While this feature is active, the phone’s
battery charge is conserved. To return to Standby
mode, press any key.
Getting started
24
Lock mode
When you lock your phone using the
Phone Lock
menu (
Menu 7-6-1
), you can receive messages
and calls, but you cannot place a call until you
unlock the phone.
For further details about locking and unlocking the
phone, see page 105.
Silent mode
Silent mode disables all sounds except for the
camera shutter sound. This feature is best used in
situations where the phone might disturb others,
such as in a meeting, a library, and a theater.
To enter Silent mode, press and hold the key
until “Entering Silent Mode” and the Silent mode
icon ( ) appears.
To exit and reactive the previous sound settings,
press and hold the key until “Exit Silent Mode”
appears. The Silent mode icon no longer displays.
Note
: If you turn off the phone in Silent mode, the
Silent mode is still activated when you turn on
the phone.
25
Call functions
Making a call
To make a call:
1. In Standby mode, enter the area code, and
phone number.
While entering a phone number, press the
Pause
soft key to insert a hard pause. For more
information on pause dialing, see page 29.
2. Press the key. The phone places the call to
the entered phone number.
Note
: If you have set the time interval for automatic
redialing in the
Auto Retry
menu (
Menu 7-
3
), the phone will automatically retry to make
the call when no one answers or the line is
busy. See page 103 for further details.
Correcting the number
To clear Press the
the last digit
displayed
C
key.
the whole display
C
key for more than one
second.
Call functions
26
Ending a call
When you want to finish your call, press the
key.
The call time, the length of the call, displays along
with the phone number of the called person. If the
number is stored in your Phonebook, the name
displays. If there is no match, you can press the
Save
soft key and store the number in Phonebook.
For further details about storing the number in
Phonebook, see page 57.
Alternatively, simply close the phone to end a call.
Emergency dialing
You can place emergency calls from your
emergency numbers list, even if your phone is
locked or all outgoing calls are restricted. For
further details on emergency numbers, see
page 106.
Call functions
27
Using the recent call logs
The phone stores up to 90 of the calls dialed,
received, or missed chronologically. The last call is
saved in the first position.
To recall any of these numbers:
1. If there are any characters on the display, return
to Standby mode by pressing the key.
2. Press the key. The list of recent calls
displays.
• : Outgoing calls
• : Incoming calls
• : Missed calls
3. Press the Up and Down keys, or the Volume
keys on the left side of the phone to scan
through the list until the number you want
highlights.
4. Press to dial the highlighted number.
Making a call from Phonebook
You can store the phone numbers regularly in
memory, which is called the Phonebook. You then
simply recall the number to dial. For further details
on Phonebook, see page 54.
Call functions
28
Prepend dialing
The Prepend option lets you add digits, such as area
codes and network feature activation codes, to a
phone number that is in your call logs before dialing
it.
To prepend the phone numbers stored in the call
logs:
1. Access a call log in the Recent Calls list referring
to page 27 or in the
Calls
menu (
Menu 1
).
2. When the phone number you want to dial
highlights, press the
Select
soft key.
The display shows the details of the number.
3. Press the
Menu
soft key to access the Menu
pop-up list.
4. Press the
3
key to select the
Prepend
option.
5. Enter the area code or feature code.
6. Press the key to dial the number.
Call functions
29
Speed dialing
Once you have stored phone numbers in
Phonebook, you can dial them easily with the few
presses of the keys.
One-touch dial
: Memory locations 001 through
009 are special one-touch locations. You can dial
the phone numbers stored in the Phonebook
memory from 001 through 009 simply by pressing
one key.
Press and hold the third digit of the memory
location containing the number to be dialed.
For example: Location no. 009
Press the
9
key and hold.
The number (and name) stored displays, then dials.
Two-touch dial
: For memory locations of two
digits.
Press the second digit briefly, then hold down the
third digit of the memory cell.
For example: Location no. 023
Press the
2
key briefly and hold down
the
3
key.
The number (and name) stored displays, then dials.
Pause dialing
When you call an automated system, like a banking
service, you are often required to enter a password
or an account number. Instead of manually entering
the numbers each time, you can store the numbers
in your Phonebook, separated by pauses.
Call functions
30
Storing pauses in a Phonebook entry
To store a number in your Phonebook that contains
pauses:
1. Enter the phone number you want to store, such
as a bank’s teleservice phone number.
2. Press the
Pause
soft key to insert a pause. A “P”
displays, meaning that a hard pause will occur at
that point in the dialing sequence.
The “P” stops the dialing and waits for the
teleservice to prompt you for a number. The
number following the “P” is your account
number, etc.
3. Enter the digits that need to follow the pause,
such as your account number.
4. Repeat steps 2 and 3 to add more pauses and
numbers, if necessary.
5. Store the number in your Phonebook as you
normally would by pressing the
Save
soft key
and following from step 4 on page 57.
Pause dialing from a stored Phonebook entry
1. Call the number from Phonebook.
2. Wait for the appropriate prompt from the
number you are calling.
3. When prompted, press the key to send the
DTMF (Dual Tone Multi Frequency) number that
follows your pause.
“SEND DTMF” flashes on the display and the
transmitted tone sounds.
Call functions
31
Manual pause dialing
You can enter pauses manually during the dialing
process.
1. Enter the phone number of the service you want
to call, such as a bank’s teleservice phone
number.
2. Press the
Pause
soft key to insert a pause.
The screen displays a “P” indicating a pause.
3. Enter the number to be sent after the pause by
pressing the digit keys, and then press the
key.
4. After connecting, wait for the prompt from
teleservice. Press the key again after the
prompt to send the additional number.
Adjusting the volume during a call
During a call, if you want to adjust the voice
volume, use the Volume keys on the left side of the
phone.
Press the key to increase the volume level and
the key to decrease the level. The image on the
Call functions
32
display shows all five levels; the more bars you see,
the higher the level is.
In Standby mode, you can also adjust the key tone
volume using these keys.
Call functions
33
Answering a call
When somebody calls you, the phone alerts you by
ringing and blinking the service light.
If the caller can be identified, the caller’s phone
number or name, if stored in your Phonebook,
displays.
There are many ways to answer a call, depending
on your setting in the
Answer Mode
menu (
Menu
7-4
);
To end the call, close the phone or press the
key.
Note
: You can answer a call while using Phonebook or
menu features. The current operation stops.
Silencing an incoming call
You can silence the ringer when a call comes. Press
one of the Volume keys when the phone is closed. If
it is open, press the left soft key.
Setting option To answer the call,
By send key press the key.
By folder open open the phone. If it is
already open, press the
key.
By any key open the phone or press any
key except the soft keys, the
key or the Volume key.
Call functions
34
Rejecting a call
To reject an incoming call, press the right soft key
or the key.
Press and hold one of the Volume keys on the left
side of the phone with the phone closed.
Viewing missed calls
If you fail to answer a call for any reason, the phone
indicates a missed call by displaying a text
notification on the screen. Additionally, if caller
information is available, a Missed entry is created,
and the screen displays the phone number of the
last missed call.
When the display informs you of the missed call,
press the key to call the displayed number, or
the key to clear the message and return to
Standby mode.
To view the list of the missed calls, refer to “Missed”
on page 51.
Options during a call
Your phone provides a number of functions that you
can use during a call. As many of these options are
network services, you may not be able to use all of
them at all times.
Press the
Menu
soft key during a call to access the
following options:
Call functions
35
Mute/Quit
: allows you to switch your phone’s
microphone off, so that the other person cannot
hear you.
Example: You wish to say something to another
person in the room, but do not want the other
person to hear you.
Calls
: allows you to access the
Calls
menu. See
page 51.
Phonebook
: allows you to access the
Phonebook
menu. See page 54.
Silent/Quit
: does not transmit the key tones. It
allows you to press keys without hearing annoying
key tones during a call.
Send My #
: sends your phone number to the
calling person or automated services.
DTMF Length
: manipulates the audible DTMF
(Dual-Tone Multi-Frequency) tones. You can choose
either
long
or
normal
.
Three-way calling
This feature enables you to conduct conference calls
with two separate people at the same time. The
phone records both calls in the Outgoing call log.
You are billed airtime for each of the outgoing calls
separately. Contact your service provider to activate
Three-Way Calling.
To make a three-way call:
1. During a conversation, enter the phone number
for the third person and press the key.
2. When the third person answers, press the
key again to begin your three-way call.
Call functions
36
During a three-way call, if one of the callers hangs
up, you and the remaining caller will stay
connected. If you initiated the call and you hang up
first, all calls are disconnected.
Call waiting
Call waiting lets you receive a second call during
conversation. Your phone notifies you of a call
waiting by beeping and displaying “Call Waiting.”
Note: Contact your service provider to activate the
Call waiting service.
To answera waiting call:
To answer the call, press . The phone connects
the calling party, and places the current party on
hold.
Press again to switch between two parties.
Note: If you do not respond to a Call waiting
notification, the phone will forward the call to
voicemail or another number that you have set up.
Contact your service provider for more information.
Call forwarding
This feature provides the option of forwarding
incoming calls to another phone number, enen
while your phone is off. Activating call forwarding
does not affect outgoing calls made from this
phone. Contact your service provider to activate call
forwarding.
37
Entering text
At many times when using your phone, you will
need to enter text; for example, when storing a
name in phonebook, writing a text message, or
scheduling events in your calendar. You can enter
alphanumeric characters into your phone by using
your phone’s keypad.
Your phone has the following text input modes:
•
T9 Word
: allows you to enter English characters
with only one keypress per character.
•
ABC
: allows you to enter English characters by
pressing the key labeled with the character you
want until it displays.
•
Symbol
: allows you to enter many different
symbols and special characters.
•
123
: allows you to enter numbers.
•T9 Hebrew
: allows you to enter Hebrew letters
using the T9 input method.
•Hebrew
: allows you to enter Hebrew letters as
you would in ABC mode.
Note
: Not in 123 mode, To enter a number, press and
hold down the corresponding key.
Changing the text input mode
Example: Writing a text message
In the text entry screen, press the
Mode
soft key.
1. Scroll to the mode you want by pressing the
Navigation keys.
Entering text
38
Note
: If you want to exit the Mode list without
changing to a new mode, press the
C
key.
You can change between
T9 Hebrew
,
Hebrew,
T9 Word, Alphabet
and
Number
mode to
enter words. To include a symbol between
characters,
Symbol
mode is also available.
2. To select the highlighted mode, press the
Select
soft key.
You will find the selected text input mode
indicator on the display.
Using T9 Word, T9 Hebrew mode
To type a word, press the keys corresponding to the
letters you need. Remember the following as you
are typing:
1. Press keys on the phone just once per letter. For
example, to enter “Hello,” press the
4
,
3
,
5
,
5
,
and
6
keys.
2. The word you are typing appears on the display.
It may change with each key press.
Text input
mode indicator
Mode OK
Message 119
Entering text
39
3. Type to the end of the word before editing or
deleting any keystrokes.
If the word does not display correctly, press the
0
key once or repeatedly to display alternative
word choices for the keys you have typed.
For example, both “of” and “me” have the
sequence of the
6
and
3
keys. The phone
displays the most commonly used choice first.
4. Insert a space between words by pressing the
key.
Smart punctuation
You can insert periods, hyphens, and apostrophes
by pressing the
1
key. T9 Word applies rules of
grammar to insert the correct punctuation. Notice
that
1
key is used twice in this example to display
two punctuation marks:
Changing the letter-case
Note
: This feature is available only in T9 Word
mode.
To shift case of the next letter(s) that you type,
press the key. There are three cases:
• Initial Capital (
T9Word
)
• Capitals Lock (
T9WORD
)
•Lower Case (
T9word
)
L e t ‘ s e a t .
Entering text
40
Including a number
You can include a number between letters without
exiting T9 Word mode. Press and hold the
corresponding number key.
Scrolling
To move the cursor to the left or right through your
text, press the Left or Right key.
Clearing letters and words
Press the
C
key once or repeatedly to clear letters
one by one to the left. Press and hold the
C
key to
erase all of the letters on the display.
Using ABC, Hebrew mode
When typing in
ABC
and
Hebrew
mode, you
should press the key labeled with the letter you
want:
- once for the first letter
- twice for the second letter
- and so on.
This method is called Multi-tap typing.
For example, you need to press the
2
key three
times quickly to display the letter “C” and the
5
key
two times quickly to display the letter “K.”
Refer to the table below for the list of characters
assigned to each key.
Entering text
41
List of characters available:
(Capital Lock)
The cursor moves to the right when you press a
different key. When entering the same letter twice
or a different letter on the same key, just wait for
about four seconds, and enter the next letter.
Changing the letter-case
Note
: This feature is available only in Alphabet
mode.
To shift case of the next letter(s) that you type,
press the key. There are three cases:
• Initial Capital (
Abc
)
• Capitals Lock (
ABC
)
•Lower Case (
abc
)
key Characters in the Order Displayed
. @ , : ? - ; ’ / ( ) ! % &
< > _ + = ” \ { } $ [ ] 1
Entering text
42
Inserting a space
Press the key to insert a space between words.
Including a number
You can quickly include a number between letters.
Press and hold the corresponding number key.
Scrolling
To move the cursor to the left or right through your
text message, press the Left or Right key.
Clearing letters and words
Press the
C
key once or repeatedly to clear letters
one by one to the left. Press and hold the
C
key to
erase all of the letters on the display.
Entering text
43
Using Symbol mode
Symbol mode enables you to enter symbols into
your text.
Press the Left or Right key to display more symbol
sets.
Press the keys corresponding to the mark you want,
and manually switch back to the text entry mode of
your choice. See page 37 for changing the text
input mode.
Using 123 mode
123 mode enables you to enter numbers into your
text. Press the keys corresponding to the digits you
want, and manually switch back to the text entry
mode of your choice. See page 37 for changing the
text input mode.
To enter a stroke, press the key printed with the
stroke that most closely represents the exact stroke
44
Using the menus
The phone offers a range of functions that allows
you to tailor it to your needs. These functions are
arranged in menus and submenus.
The menus and submenus can be accessed by
scrolling or using the shortcuts.
Accessing a menu function by
scrolling
1. In Standby mode, press the
Menu
soft key to
access the main menu mode.
2. Scroll using the Navigation keys to reach a main
menu, for example,
Settings
. Press the
Select
soft key to enter the menu.
3. Find the menu option you want, for example,
Display
, by scrolling using the Up or Down key.
Press the
Select
soft key to enter the menu
option.
If the menu you have selected contains
submenus, such as
Language/
, repeat
this step.
4. Scroll using the Navigation keys to select the
setting of your choice.
5. Press the
Save
soft key to confirm the chosen
setting.
Notes
:
• To return to the previous menu level, press the
C
key.
Using the menus
45
• You can exit the menu without changing the menu
settings by pressing the
key
.
Using shortcuts
The menu items, such as menus, submenus, and
setting options, are numbered and can be accessed
quickly by using their shortcut numbers.
Note
: The numbers assigned to each menu function
are indicated on the list on page 46.
1. In Standby mode, press the
Menu
soft key to
access the menu mode.
2. Enter the first digit of the shortcut number.
Repeat this for each digit of the shortcut
number.
Example: Changing the display language
Press the
7
,
2
, and
7
keys.
7
enters
Settings
,
2
selects
Display
, and
7
selects
Language/
.
3. Scroll using the Navigation keys to select the
setting of your choice.
4. Press the
Save
soft key to confirm the chosen
setting.
Using the menus
46
List of menu functions
The following list shows the menu structure and
indicates the number assigned to each option.
1. Calls
(see page 51)
1.1 Missed
1.2 Incoming
1.3 Outgoing
1.4 Air Time
1.4.1 Last Call
1.4.2 Total
1.4.3 Life Time
1.4.4 Erase Total
2. Phonebook
(see page 54)
2.1 Find
2.2 Add
2.3 Group Set
2.4 My Phone #
3. Message
(see page 63)
3.1 Text Msg
3.1.1 New Message
3.1.2 Inbox
3.1.3 Outbox
3.1.4 Saved Msg
3.2 MMS
3.2.1 New Message
3.2.2 Inbox
3.2.3 Outbox
3.2.4 Draftbox
3.2.5 MMS Alert
3.3 Voice mail
3.4 Msg Setup
3.4.1 Scroll Timer
3.4.2 Msg. Reminder
3.4.3 Alert on call
3.4.4 SMS Message
3.4.5 MMS Message
3.4.6 MSG Templates
Using the menus
47
4. Scheduler
(see page 78)
4.1 Calendar
4.2 Alarm Set
4.3 Calculator
4.4 Today
4.5 To Do List
4.6 World Time
4.7 Countdown
4.8 Memo Pad
5. Games
(see page 87)
5.1 ChickenRun
5.2 MobileCop
6. Voice Tools
(see page 90)
6.1 Voice Memo
6.1.1 Record
6.1.2 Review
6.1.3 Erase All
6.2 Voice Answer
6.2.1 On/Off
6.2.2 Voice Messages
6.2.3 Setting
6.2.3.1 Greeting
6.2.3.2 Screening
6.2.3.3 Wait Time
7. Settings
(see page 95)
7.1 Sounds
7.1.1 Ringer
7.1.1.1 Voice Calls
7.1.1.2 Messages
7.1.1.3 Alarm/Scheduler
7.1.2 Key Tone
7.1.3 Function Alert
7.1.4 Hour Alert
7.1.5 Power On/Off
7.1.6 Voice Volume
Using the menus
48
7. Settings
(continued)
7.2 Display
7.2.1 Image Box
7.2.1.1 Opening
7.2.1.2 Closing
7.2.1.3 Wallpaper
7.2.2 Banner
7.2.3 Backlight
7.2.4 Set Time
7.2.4.1 Main Clock
7.2.4.2 Dual Clock
7.2.5 External Clock
7.2.6 Service LED
7.2.7 Language/
7.3 Auto Retry
7.4 Answer Mode
7.5 Roam Option
7.6 Security
7.6.1 Phone Lock
7.6.2 Change Lock
7.6.3 Emergency #
7.6.4 Voice Privacy
7.6.5 Restriction
7.6.5.1 Outgoing
7.6.5.2 Incoming
7.6.5.3 Phone Book
7.6.6 Clear Memory
7.6.6.1 Phonebook
7.6.6.2 Messages
7.6.7 Reset Phone
7.6.7.1 Function Only
7.6.7.2 All
7.7 Data Option
7.8 Data/Fax Mode
7.9 Memory Status
7.9.1 Total
7.9.2 Music
7.9.3 Image
Using the menus
49
8. VAS
(see page 112)
8.1 Internet Portal
8.2 Games & App
8.3 Multimedia
8.3.1 Watch movies
8.3.2 D/L movies
8.4 Ringtone
8.4.1 Activate
8.4.2 Download
8.5 Animation
8.5.1 Activate
8.5.2 Download
8.6 Voice portal
8.7 SMS info
8.7.1 News
8.7.2 Sport
8.7.3 Entertainment
8.7.4 Fun
8.7.5 Finance
8.7.6 Astrology
8.8 What’s new?
9. Camera
(see page 122)
9.1 Take Photo
9.2 Record Video
9.3 Photo Album
9.4 Video Album
9.5 MMS
9.5.1 New Photo
9.5.2 Album
9.6 Settings
9.6.1 Resolution
9.6.2 Fun Frames
9.6.3 Color Tones
9.6.4 Shutter Sound
9.6.5 Quality
9.7 Memory Status
Using the menus
50
In-Call menu
(see page 34)
1: Mute/Quit
2: Calls2.1: Missed
2.2: Incoming
2.3: Outgoing
2.4: Air Time
3: Phonebook
3.1: Find
3.2: Add
3.3: Group Set
3.4: My Phone #
4: Silent/Quit
5: Send My #
6: DTMF Length
51
Calls
You can use the
Calls
menu to:
• view and dial the last missed, outgoing, or
incoming numbers.
• view the duration of calls.
• set the phone to receive the second call or to
forward incoming calls to the preset number.
Missed
(Menu 1-1)
If Caller Line Identification is available, your phone
keeps a list of the 30 most recent incoming calls
that you failed to answer. Contact your service
provider for the availability.
When you press the
Menu
soft key on the call log
list, the following options are available:
Erase
: erases the selected number.
Erase all
: erases all of numbers.
1. Press the Up and Down keys to find a number or
name, if saved in Phonebook.
2. Press the
Select
soft key to select the
highlighted number. The dialed number, or
name if stored in Phonebook, displays.
Calls
52
When you access the menu options, the following
options are available:
Talk
: dials the selected number.
Save
: allows you to save the number in
Phonebook.
Prepend
: allows you to add an area code or
feature code to the number before calling the
number.
Erase
: allows you to erase the selected number.
Incoming
(Menu 1-2)
This menu lets you view up to 30 of the most recent
calls you have received if you are subscribed to the
Caller Line Identification service. Contact your
service provider for more information about this
service. When you access this menu, the list of the
incoming calls displays.
For further details about scrolling through the list
and accessing the call log, see “Missed” on page 51.
3.
To Press the
place a call key.
use the menu
options
Menu
soft key. For
details about the options,
see the next page.
view other calls Navigation keys.
return to Standby
mode. key.
Calls
53
Outgoing
(Menu 1-3)
The phone stores up to 30 of the most recent calls
you have dialed. When you access this menu, a list
of the outgoing calls displays.
For further details about scrolling through the list
and accessing the call log, see “Missed” on page 51.
Air Time
(Menu 1-4)
Your phone records the amount of air time, or talk
time, used. Using this option, you can view the
number of the calls to or from your phone and the
air time for all calls. You can easily erase the air
time record at any time.
Note
: This feature is not intended to be used for
billing purposes.
The following options are available:
Last Call
: shows the air time of the last call.
Total
: shows the number of all calls you have made
to or from your phone and the total duration of the
calls since the air time counter was last set to zero
by using the
Erase Total
option.
Life Time
: shows the number and total duration of
all calls you have made to or from your phone since
the phone was shipped from the factory.
Erase Total
: erases the “Total” air time
measurement and resets the air time counter.
54
Phonebook
You can store phone numbers and their
corresponding names in the memories of your
phone. The phone memories, although physically
separate, are used as if they were a single entity,
called Phonebook.
Find
(Menu 2-1)
This menu allows you to find an entry using a
person’s name, entry number, group name, or
memory location.
Note
: You can quickly access this menu by pressing
the Right key in standby mode.
To change the finding method, press Left or Right
key until the option you want to use displays;
By
Name
,
By Entry
, or
By Group
.
Finding an entry by name
When you select this method, the whole list of all of
Phonebook entries appears in alphabetical order.
1. If necessary, press the Left or Right key to scroll
to
By Name
.
2. If necessary, press the Down key to highlight
the name input box.
3. Enter the first few letters of the name you want
to find.
Your phone highlights the first matching name.
If you want to find a Hebrew name, press the
Menu
soft key and select Hebrew and press the
Select
soft key.
Phonebook
55
4. If necessary, press the Up or Down key to scroll
through the entries.
5. When an entry highlights:
• Press the key to place a call to the entry’s
speed-dial number.
• Press the
Menu
soft key to access the
following options:
-
Edit
: edits the entry’s phone number, name,
location number, and other information.
-
Erase
: erases the entry.
-
Add New
: adds a number to Phonebook.
You can create a new entry or add it to an
existing entry. For more information on how
to add a number, see page 57.
• Press the
OK
soft key to select the entry.
Information about the entry displays. Move to
each item by pressing the Up or Down key.
Press the
Menu
soft key to use one of the
following options:
-
Talk
: dials the number labeled as speed-dial
number.
-
Edit
: allows you to change the selected item.
-
Erase
: erases the entry. If you select one of
numbers for the entry, only the number is
erased.
• Press the
C
key to return to the previous
screen.
• Press the key to exit the menu.
Phonebook
56
Finding an entry by entry number
When you select this method, the whole list of all of
the Phonebook entries appears in numeric order.
1. Press the Left or Right key to scroll to
By Entry
.
2. Press the Down key to highlight the number
input box.
3. Enter the location number of the entry you want
to find.
4. Follow the procedure from step 4 on page 55.
Finding an entry by group
When you select this method, a list of the
Phonebook entries in a group appears.
1. Press the Left or Right key to scroll to
By
Group
.
2. Press the Down key to move the group selection
field.
3. Press the Left or Right key to select the group
you want.
Each time you select a group, a list of the
associated entries displays.
4. Follow the procedure from step 4 on page 55.
Phonebook
57
Add
(Menu 2-2)
This menu allows you to add a new entry to your
Phonebook by saving a phone number, an e-mail
address, or a memo.
Adding a new entry using a number
1. After accessing the
Add
menu (
Menu 2-2
),
select
Number
from the pop-up list and press
the
Select
soft key.
2. Enter a number you want to save and press the
Save
soft key.
3. When
New Entry
highlights, press the
Select
soft key.
4. Enter a name and press the
OK
soft key.
For more information about how to enter
characters, see page 37.
5. Choose a type icon,
Home
,
Office
,
Mobile
,
Pager
, or
Fax
, using the Navigation keys and
press the
Select
soft key.
6. Press the Up or Down key and change the
setting or enter more information, if necessary.
•
Name
: Press the
Edit
soft key to change the
name.
•
Location number
: shows the location
number.
Phonebook
58
•
Home
/
Office
/
Mobile
/
Pager
/
Fax
: You can
add numbers for each category or change the
current number.
•
E-Mail1
/
E-Mail2
: Press the
Edit
soft key to
enter an e-mail address. For more information
about how to enter characters, see page 37.
•
URL
: Press the
Edit
soft key to enter an URL
address. For more information about how to
enter characters, see page 37.
•
ETC
: Press the
Edit
soft key to store
additional information about the person.
•
Speed Dial
: allows you to select one of the
stored numbers for speed dialling.
•
Group
: Select one of the default relation
groups, where the entry is included. Grouping
the entries enables you to search for a number
in the group. See page 61.
•
Ringer
: Press the
Menu
soft key to select a
unique ringer melody for the entry. By
selecting a different tone for each entry,
incoming voice calls having a caller ID can be
distinguished from those that do not.
•
Caller Image
: Press the
Menu
soft key to
select a character image to show on the
external display when a call comes in from the
number.
7. Repeat step 6 until you complete the contact
information of the entry.
8. Press the
Save
soft key to save the entry.
After storing, the phone displays the memory
status of Phonebook for a few seconds and goes
to the Phonebook list.
Phonebook
59
Saving a phone number from Standby
mode
1. In Standby mode, enter a number you want to
save.
Or, press the key to end the call. The call
time and the phone number display.
2. Press the
Save
soft key.
3. When
New Entry
highlights, press the
Select
soft key.
If you want to add a number into an existing
entry, select
Find
and press the
Select
soft key.
To complete storing the number, follow the
procedure from step 4 on page 60
.
4. Enter a name and press the
OK
soft key.
For more information about how to enter
characters, see page 37.
5. Follow the procedure from step 5 on page 57.
Adding a number into an existing entry
You can store up to 5 numbers for a name saved in
the phone’s memory by assigning them to the
different types.
1. After accessing the
Add
menu (
Menu 2-2
),
select
Number
from the pop-up list and press
the
Select
soft key.
2. Enter a number you want saved and press the
Save
soft key.
3. Select
Find
and press the
Select
soft key.
Phonebook
60
4. Find the name you want using the Up and Down
keys and press the
OK
soft key.
5. Select a type icon by pressing the Navigation
keys and press the
Select
soft key.
6. Follow the procedure from step 6 on page 57.
When the confirmation message to overwrite the
entry appears, select
Yes
and press the
Select
soft key.
Adding a new entry using an e-mail
address
You can store an e-mail address as a Phonebook
entry.
1. After accessing the
Add
menu (
Menu 2-2
),
select
E-mail
from the pop-up list and press the
Select
soft key.
2. Enter the e-mail address and press the
OK
soft
key.
For more information about how to enter
characters, see page 37.
3. When
New Entry
highlights, press the
Select
soft key.
Note
: To add the address to an existing entry,
select
Find
. Find the name from the
Phonebook list and press the
OK
soft key.
4. Enter a name and press the
OK
soft key.
5. Follow the procedure from step 6 on page 57.
Adding a new entry using a memo
Phonebook
61
You can make a memo about a person as a
Phonebook entry.
1. After accessing the
Add
menu (
Menu 2-2
),
select
ETC
from the pop-up list and press the
Select
soft key.
2. Enter a memo and press the
OK
soft key.
For more information about how to enter
characters, see page 37.
3. When
New Entry
highlights, press the
Select
soft key.
Note
: To add the memo to an existing entry, select
Find
. Find the name from the Phonebook
list and press the
OK
soft key.
4. Enter a name and press the
OK
soft key.
5. Follow the procedure from step 6 on the page 57
Group Set
(Menu 2-3)
This menu allows you to change a relation group’s
name.
Note
: You can change the name of the default group.
1. On the Group Set list, press the Up or Down key
to select the group you want to rename and
press the
Select
soft key.
2. Press the
C
key to erase the old group name.
3. Enter a name and press the
OK
soft key to save
the new name.
For more information on how to enter
characters, see page 37.
Phonebook
62
My Phone #
(Menu 2-4)
This menu shows your phone number.
This number is sent when you choose the
Send My #
option during a call.
63
Message
Your phone can receive voice mail messages, text
messages, and web messages from your web
server. Your phone can also send text messages if
your system supplier provides this service.
Incoming messages are received even when your
phone is in Lock mode. The screen displays
information about the message. To access the
message, you need to unlock the phone.
If you receive an incoming message during a call
conversation, your phone sounds an alert tone or
vibrates, depending on your sound settings.
Note
: You can quickly access the Message menu by
pressing Left key in standby mode.
Text Msg
(Menu 3-1)
You can create an SMS(Short Message Service)
message and send it to other mobile phones.
New Message
(Menu 3-1-1)
You can create short text messages and send them
to multiple mobile phones.
Note
: Message transmission is available only when
your phone is operating in a digital network and
if service is supported by your service provider.
1. Enter the message contents and press the
OK
soft key.
For more information on how to enter
characters, see page 37.
Message
64
You can use up to 20 canned messages by
pressing the
Mode
soft key and selecting
MSG
Templates
For details, see page 77.
2. Select one of the following options, and press
the
OK
soft key.
•
Send
: allows you to send the message. You
can read the message in your Outbox.
•
Save
: allows you to save the message so that
it can be sent later. You can read the message
in your Saved Msg box.
3. Enter a phone number.
If you press the
Menu
soft key, you can search
your Phonebook for a number.
4. To send the message to multiple destinations,
press the Down key and enter another number.
Repeat this step to add more destinations. You
can send the message to up to 10 destinations
at one time.
5. When you have finished entering the numbers,
press the
OK
soft key to send or save the
message.
Your phone informs you of whether or not the
message was successfully sent, and returns to
the Text Msg menu screen.
Message
65
Inbox
(Menu 3-1-2)
Your phone can store SMS messages and their
corresponding Caller ID in your phone’s memories.
When your memory is full, the screen displays a
text notification and rejects additional incoming
messages until you erase the obsolete ones.
When the phone receives a text message, the New
Text Message icon ( ) and a text notification with
the call back number appear. Press the
Select
soft
key to view the message immediately.
When you access the
Inbox
menu, a list of the
received message displays. An icon displayed in the
list means the message’s status:
• : displays when you have read the message.
• : indicates that a duplicated message.
While viewing the message list, press the Up or
Down key to scroll to a message and:
•Press the
View
soft key to view the message you
want. The phone displays the contents. If
necessary, press the Up or Down key to scan
through the message.
While viewing a message, press the
Menu
soft
key to use the following options:
Reply
: allows you to send a reply message to
the sender.
Forward
: allows you to send the message to
other people.
Call/Save
: shows the sender’s number of the
message. Press the key to make a call to the
sender’s phone number. Press the
Save
soft key
to save it.
Erase
: erases the message from your Inbox.
Message
66
Protect
: the
Locked
option allows you to keep
the message from being deleted. They will not
be erased until you unlock by using the
Unlocked
option.
• Press the
Reply
soft key to send a reply message
to the sender.
• Press the
Menu
soft key to access the following
options:
Erase
: allows you to erase the selected
message.
Erase Multi
: allows you to erase the messages
you selected by pressing the
Check
soft key.
Erase all
: allows you to erase all of the
messages.
Outbox
(Menu 3-1-3)
Your phone can store your outgoing SMS messages
in your phone’s memories.
When you access the
Outbox
menu, you can see
the message list. An icon displayed in the list means
the message’s status:
• : indicates that the message was successfully
delivered.
• : indicates that the message was not sent.
While viewing the message list, press the Up or
Down key to scroll to a message and:
• Press the
View
soft key to view the message you
want. The phone displays the contents. If
necessary, press the Up or Down key to scan
through the message.
Message
67
While viewing a message, press the
Menu
soft
key to use the following options:
Resend
: allows you to send the message to
other people.
Call/Save
: shows the destination number of
the message. Press the key to make a call to
the recipient’s phone number. Press the
Save
soft key to save it.
Erase
: erases the message from your Outbox.
• Press the
Resend
soft key to send the message
to other people.
• Press the
Menu
soft key to use the following
options:
Erase
: erases the selected message.
Erase Multi
: erases the messages you selected
by pressing the
Check
soft key.
Erase all
: erases all of the messages.
Saved Msg
(Menu 3-1-4)
Your phone can store draft messages that are yet to
be sent in the Draft box. If you save the message
contents before sending, you can access them using
this menu.
To review a stored message, press Up or Down key
to scroll to it and press
OK
soft key.
While viewing a message, press the
Menu
soft
key to use the following options:
Resend
: allows you to send the message to
other people.
Message
68
Call/Save
:shows the sender’s number of the
message. Press the key to make a call to the
sender’s phone number. Press the
Save
soft key
to save it.
Erase:
erases the message from your Outbox.
• Press the
Menu
soft key to access the following
options:
Erase
: allows you to erase the selected
message.
Erase Multi
: allows you to erase the messages
you selected by pressing the
Check
soft key.
Erase All
: allows you to erase all of the
messages.
MMS
(Menu 3-2)
MMS (Multimedia Message Service) allows you to
send or receive a message containing an image or a
sound. It provides delivery of multimedia messages
from phone to phone or from phone to e-mail.
New Message
(Menu 3-2-1)
In this menu, you can create and send a new
message.
1. When the
Send to
field highlights, press the
Menu
soft key.
Note:
You can select a address type, Send To, Cc,
or Bcc, by pressing the Left or Right key.
Message
69
2. Select
Phonebook
to retrieve a phone number
or an e-mail address from your Phonebook, or
Edit
to an enter one.
3. Choose a number or an address or enter one,
and then press the
OK
soft key.
4. Press the Down key to move to the
Subject
field
and press the
Edit
soft key.
5. Enter a subject and press the
OK
soft key.
6. Press the Down key to move the
field
and press the
Menu
soft key.
The following options are available:
•
Take Photo
: allows you to take a new photo
using the camera.
•
Album
: allows you to select a photo from the
Photo Album.
•
Saved Img
: allows you to select an image
downloaded from the Internet.
•
Erase
: remove the image from the slide.
7. Select an option and take a photo or add an
image.
For details about the camera, see page 119.
8. Press the Down key to move the
Message
field
and press the
Edit
soft key.
9. Enter a message text and press the
OK
soft key.
10. Press the Down key to move to the
Sound
field
and press the
Menu
soft key.
The following options are available:
•
Voice Rec
: allows you to record a new voice
memo.
Message
70
•
Voice Memo
: allows you to select a photo
from the Voice Memo.
•
Melody
: allows you to select one of the
default melodies.
•
Saved Snd
: allows you to select a sound
downloaded from the Internet.
•
Erase
: remove the sound from the slide.
11. Select an option and then record a memo or
select a sound.
For details about the voice memo, see page 90.
12. If you want to add or remove a slide, move to
the
Slide
field and press the
Menu
soft key.
The following options are available:
•
Add
: adds a new slide.
•
Erase
: erases any added slides.
•
Duration
: allows you to set the length of time
the currently selected slide displays.
13. When you have finished the MMS message,
press the
OK
soft key.
The following options are available:
•
Preview
: shows the message you created.
•
MMS Edit
: allows you to change the message.
•
Options
: allows you to set message options;
for details on each option, see page 75.
•
Save in Draft
: saves the message in the Draft
box.
14. When you are satisfied, press
1
or select
preview
and press the
OK
soft key.
Message
71
The phone displays your message.
15. Press the
Send
soft key to send it.
Inbox
(Menu 3-2-2)
When a new MMS message has arrived, an MMS
alert appears. You can select
Yes
to download the
message from the MMS server or
No
to check the
message at a later time. If you select
Yes
, the
message will be saved in the Inbox.
When you access the Inbox, the list of the retrieved
messages displays. On the message list, you can
access the following options by pressing the
Menu
soft key:
Erase
: allows you to erase the currently selected
message.
Erase All
: allows you to erase all of the messages
in the Inbox.
Select a message from the list and press the
OK
soft key to read it. The phone presents the message
contents. If a sound file is attached, it plays. You
can stop the playback by pressing the
Stop
soft
key. On the message presentation screen, you can
access the following options by pressing the
Menu
soft key:
Reply
: allows you to send a reply to the sender.
Reply all
: allows you to send a reply to the sender
and all of the recipients.
Forward
: allows you to forward the message to
other people.
Erase
: allows you to erase the message.
Info
: shows the information of the message.
Message
72
Save Img
: saves an image from the message to
the phone's memory.
Save Snd
: allows you to save a sound from the
message to the phone's memory.
Lock
/
Release
: locks/unlocks the message so that
it will not be erased.
Outbox
(Menu 3-2-3)
From this menu, you can access the list of the
messages you have sent. On the message list, you
can access the following options by pressing the
Menu
soft key:
Erase
: allows you to erase the currently selected
message.
Erase All
: allows you to erase all of the messages
in the Inbox.
Select a message from the list and press the
OK
soft key. The phone presents the message contents.
If a sound file is attached, it plays. You can stop by
the playback pressing the
Stop
soft key. On the
message presentation screen, you can access the
following options by pressing the
Menu
soft key:
Resend
: allows you to resend the message.
Erase
: allows you to erase the message.
Info
: shows the information of the message.
Lock
/
Release
: locks/unlocks the message so that
it is not erased.
Message
73
Draftbox
(Menu 3-2-4)
From this menu, you can access the messages you
have saved before sending or you have tried.
Select a message from the list and press the
OK
soft key. the message opens in Edit mode so that
you can change and send it.
MMS Alert
(Menu 3-2-5)
When a new MMS message has arrived, an MMS
alert appears. You can select
Yes
to download the
message from the MMS server or
No
to check the
message at a later time. If you select
No
, the alert
saved in the MMS Alert box.
Select an alert from the list and press the
OK
soft
key. Then you can access the following options by
pressing the
Menu
soft key:
Download
: retrieves the message from the MMS
server.
Erase
: earses the MMS alert.
Voice mail
(Menu 3-3)
When you receive a voice message the corresponding text
notification displays. Press
and the phone dials the
voice mail center.
If multiple new voice messages are received but not
checked, information of the last one will be displayed. The
information of the last one will be displayed. The
Message
74
information display includes the time/date stamp and the
number of new voice messages.
•
Press
the
Menu
soft key to use the following
options:
Listen
: allows you to listen to the voice message. The
phone automatically dials the number of your voicemail
center.
Erase
: clears the New Message icon and resets the
counter for a new voice message, if necessary. The
system resets the couter automatically after you listen to
all of the new messages.
Msg Setup
(Menu 3-4)
Using this menu, you can set up various options for
receiving or sending messages.
Scroll Timer
(Menu 3-4-1)
If an incoming message is too long for the display,
the phone scrolls the screen automatically. You can
set the time interval in which the phone scrolls to
the next screen,
1
through
5
seconds.
When this option is set to
Off
, you need to
manually scroll to the next screen using the Up or
Down key.
Msg. Reminder
(Menu 3-4-2)
Message
75
When a message is received, your phone alerts you
by sounding the specified ringer. You can set how
often this will happen.
Off
: The phone alert only once when you receive an
incoming message.
Once
: The phone alerts you when you receive an
incoming message and then alert you again after 2
minutes.
Every 2 min
: The phone alerts you every 2
minutes when you receive an incoming message.
Alert on call
(Menu 3-4-3)
This menu allows you to choose whether or not the
phone informs you when you receive a new
message during a call.
Off
: the phone doesn’t actively alert you to
incoming messages. It only displays the
corresponding notification.
On
: the phone alerts you with a beep and displays
the corresponding notification.
SMS Message
(Menu 3-4-4)
You can set up the following options as default
settings when creating a new message.
Delivery Ack
: allows you to activate or deactivate
the delivery acknowledgement feature. When this
feature is activated, the network informs you when
your message is delivered to the recipient. Select
On
to turn the feature on, or
Off
to turn it off.
MMS Message
(Menu 3-4-5)
You can change the default settings for sending and
receiving MMS messages.
Message
76
Priority
: allows you to select a message priority.
Expiry
: allows you to set the lengh of time your
messages are stored in the MMS server while
attemps to deliver them.
Delivery Time
: allows you to select time delay
before the MMS server sends messages.
Sender Visibility
: allows you to set whether your
phone number will be seen on recipients’ phones.
Delivery Report
: allows you to request that the
network inform you when your message has been
delivered.
Read reply
: allows you to request that the network
inform you when the recipient reads your message.
Retrival mode
: allows you to set how you want to
retrieve incoming MMS messages. With this option
is set to
Auto
, the phone retrieves MMS messages
from the MMS server immediately at the time of
their arrival. When you select
Prompt
, the phone
shows a prompt so that you can choose to retrieve
the message.
Message
77
MSG Templates
(Menu 3-4-6)
Your phone has 11 preset messages to enable you
to use them when writing a new message. You can
change them, if necessary.
You can also add up to 9 messages.
1. Press the Navigation keys to highlight the
message you want to change.
To add a new message, select an empty
location.
2. Press the
Select
soft key.
3. Clear the existing message using the
C
key, if
necessary, enter a new message.
For further information on how to enter text, see
page 37
4. Press the
OK
soft key to save the message.
78
Scheduler
The Scheduler feature enables you to:
• keep track of important dates and events.
• set the phone to ring at a specified time.
• use the phone as a calculator.
• create a list of things to do or memos.
• check the current time in another part of the
world.
• set and count down to a particular day or event.
• make a memo.
Note
: When you are out of your service area, you
cannot use some of the features in the
Scheduler
menu.
Calendar
(Menu 4-1)
This menu allows you to view the current month, as
well as the past or future month in the calendar
format. You can be alerted by the Calendar function
before an event commences. When you access this
menu, today’s date is automatically selected the
date in lunar calendar displays on the bottom.
Note
: You can quickly access this menu by pressing
the Right key in Standby mode.
Selecting a day on the calendar
• You can move to the next or the previous day by
pressing the Left or Right key.
• You can move up or down the Calendar one week
by pressing the Up or Down key.
• To display the next or previous month, use the
Volume keys on the left side of the phone.
Scheduler
79
On the Calendar screen, press the
Menu
soft key to
use the following options:
View
: allows you to view the scheduled events of
the day.
Add new
: allows you to add a new event on the
selected day.
Scheduling an event
You can schedule up to 9 events for one day and 20
events total.
1. Select a day from the calendar, referring to
“Selecting a day on the calendar” on page 78,
and press the
OK
soft key.
2. Enter your event contents and press the
OK
soft
key.
For more information about how to enter
characters, see page 37.
3. Enter the start time and date using the numeric
keys and press the Down key.
Notes
:
• You need to enter the time in 24-hour format.
• You can move through the input fields using the
Left or Right key.
4. Enter the end time and date using the numeric
keys and press the Down key.
5. Specify when an alarm will inform you of your
event by pressing the Left or Right key. If you
select
No
alarm
, the phone does not ring the
alarm.
6. Press the
Save
soft key to save your event.
Scheduler
80
Viewing your schedule
Days with scheduled events are seen in a rectangle
on the calendar when you access the
Calendar
menu (
Menu 4-1
). Select one of them and press
the
OK
soft key. The first of the events for date
appears.
Highlight to the event you want to view by pressing
the Left or Right key. If necessary, press the Down
key to display the end time of the event.
While viewing an event, press the
Menu
soft key to
use the following options:
Add new
: adds a new event.
Edit
: edits the selected event.
Erase
: erases the selected event.
Erase All
: erases all of the events.
Scheduler
81
Alarm Set
(Menu 4-2)
This menu allows you to set the alarm to ring at a
specific time.
To set the alarm:
1. Select the alarm frequency option by pressing
the Navigation keys.
•
Once
: The alarm rings only once and is then
deactivated.
•
Daily
: The alarm rings everyday at the same
time.
2. Press the
Save
soft key.
3. Enter the time for the alarm to ring by using the
numeric keys.
Notes
:
• You need to enter the time in 24-hour format.
• You can move through the input fields using the
Left or Right key.
4. Press the
Save
soft key.
To stop the alarm when it rings, simply open and
close the phone or press any key.
To deactivate the alarm, access the
Alarm Set
menu, and select
Off
and press the
Save
soft key.
Scheduler
82
Calculator
(Menu 4-3)
Using this feature, you can use the phone as a
calculator. The calculator provides the basic
arithmetic functions; addition, subtraction,
multiplication, and division.
To perform a calculation:
1. Enter the first number using the numeric keys.
Note
: Use the key to enter a decimal point and
the key to change the sign of a number
to a negative (-).
2. Select the operation for your calculation by
pressing the Navigation keys according to the
illustration on the display;
+
(add),
-
(subtract),
x
(multiply),
÷
(divide).
3. Enter the second number.
4. To get the result, press the
OK
soft key.
5. Repeat steps 1 to 4 as many times as required.
Today
(Menu 4-4)
This menu allows you to schedule new events for
the current day, indicating each event’s start and
end time. Events scheduled for future dates
automatically appear on your Today display for that
particular day.
For further details about scheduling and viewing
events, refer to “Calendar” on page 78.
Scheduler
83
To Do List
(Menu 4-5)
This feature allows you to enter up a list of tasks
you need to do and assign both a priority and a
deadline to them. You can store up to 20 tasks.
Creating a to-do item
1. Enter the task contents and press the
OK
soft
key.
For more information about how to enter
characters, see page 37.
2. Select High or Low priority using the Left or
Right key and press the Down key.
3. Enter the time and the date when your task
needs to be done using the numeric keys.
Notes
:
• You need to enter the time in 24-hour format.
• You can move through the input fields using the
Left or Right key.
4. Press the
Save
soft key to save the task.
Viewing a task
When you access the
To Do List
menu (
Menu 4-
5
), the list of tasks displays along with deadline and
the associated priority highlighted: for high
priority or for low priority.
Scroll to the task you want to view by pressing the
Left or Right key.
While viewing a task, press the
Menu
soft key to
use the following options:
Scheduler
84
Add new
: adds a new task.
Edit
: edits the selected task.
Erase
: erases the selected task.
Erase All
: erases all of the task.
World Time
(Menu 4-6)
You can use this menu to find out what time it is in
another part of the world and apply the DST
(Daylight Saving time).
Press the Navigation keys to scroll to the time zone
you want to check.
To apply the daylight saving time:
1. After selecting the time zone you want to apply
the DST, press the
DST
soft key.
2. When a confirmation message appears, select
Yes
and press the
Select
soft key. The DST icon
appears on the left side of the time.
Scheduler
85
Countdown
(Menu 4-7)
This menu helps you know how much time it takes
for you to do something or how many months,
days, hours, and/or minutes until a specific event
occurs. You can create up to 20 Countdown timers
using this feature.
Creating a countdown timer
1. Enter a name for your Countdown timer and
press the
OK
soft key.
For more information about how to enter
characters, see page 37.
2. Enter the time and date from which you want to
count down.
Notes
:
• You need to enter the time in 24-hour format.
• You can move through the input fields using the
Left or Right key.
• You can enter between 1981 and 2099 for the
year.
3. Press the
Save
soft key to save the timer.
Viewing a countdown timer
The list of Countdown timers displays when you
access the
Countdown
menu (
Menu 4-7
).
Scroll to the timer you want to view by pressing the
Left or Right key.
While viewing a timer, press the
Menu
soft key to
use the following options:
Add new
: creates a new timer.
Scheduler
86
Edit
: edits the selected timer.
Erase
: erases the selected timer.
Erase All
: erases all of timers.
Memo Pad
(Menu 4-8)
This feature allows you to make memos of
important things you need to remember.
Writing a new memo
1. Enter what you need to remember.
For further details on how to enter characters,
see page 44.
2. Press the
OK
soft key to save the memo.
Viewing a memo
The list of your memos displays when you access
the
Memo Pad
menu (
Menu 4-8
).
To view details, press the Navigation keys to scroll
to the memo you want to view from the list and
press the
Select
soft key.
On the Memo pad list, press the
Menu
soft key to
use the following options:
Add new
: adds a new memo.
Edit
: edits the selected memo.
Erase
: erases the selected memo.
Erase All
: erases all of memos.
87
Games
Using the
Games
, you can enjoy games using your
phone.
You can enjoy games using your phone.
To start a game:
1. Press the Navigation keys to scroll to one of the
games and press the
Select
soft key.
2. Press any key except for the key.
The phone displays the following options:
•
NEW GAME
: allows you to start a new game.
•
HIGH SCORE
: shows you the high score
table.
•
HELP
: gives you the information about how to
play the game.
•
KEY INFO
: gives you the key helper screen to
play the game.
•
CONTINUE
: allows you to continue the last
game you played. This option is activated only
when you have played a game.
3. While playing a game:
To Press the
pause/resume the game
C
key.
exit the game key.
Games
88
ChickenRun
(Menu 5-1)
The goal of this game is to move eggs or chicks to
the destination carefully.
When you select
NEW GAME
menu, the first screen
displays two menus.
Select
START
menu to start a new game.
Select
OPTION
menu to change following options.
DIFFICULTY
: allows you to change the game’s
level of difficulty.
SOUND
: allows you to turn the game sound on or
off.
VIBRATION
: allows you to turn the vibration on or
off.
: allows you to exit the current screen.
Once the game starts, you need to control blue and
red control items to move eggs or chicks carefully.
To control the blue items, press
1
or Left key, and
press
3
or Right key for the red ones. When you
complete the given aims, the level goes up and the
speed goes up.
MobileCop
(Menu 5-2)
The goal of this game is to shoot the enemies.
When you select
NEW GAME
menu, the first screen
displays three menus.
Select
START
menu to start a new game.
Select
OPTION
menu to change following options.
Games
89
SOUND
: allows you to turn the game sound on or
off.
VIBRATION
: allows you to turn the vibration on or
off.
: allows you to exit the current screen.
Select
HELP
menu to see the simple guide.
Once the game starts, enemies in red appear at
target position. Check the position and press
appropriate number key to shoot the enemy.
Sometimes hostages may appear. If you shoot the
hostage, you will lose the bonus points.
After running out of the bullets, press
7
,
8
or
9
to
reload them.
Whenever you kill all the enemies for one stage,
you can go to the next stage.
1 2 3
4 5 6
90
Voice Tools
In this menu, you can use the phone’s voice
features, allowing you to:
• record a voice memo.
• set the phone to answer a call and record the
caller’s message.
Voice Memo
(Menu 6-1)
Record
(Menu 6-1-1)
You can record up to voice memos of 4 minutes
total. This feature shares the memory with the
Voice Answer feature and the amount of time for
memos are dependent on the available memory
less any callers’ messages; for example, if your
phone has the callers’ messages of 4 minutes total,
you cannot record any voice memo.
1. Record a memo by speaking to the microphone.
When you are recording, a timer displays to
show you the elapsed time.
You can pause recording by pressing
Paused
soft key and then
Resumed
soft key.
2. Press the
OK:End
soft key to end recording. The
screen provides you with the following choices.
Scroll to an option and press the
Select
soft
key.
•
Review
: allows you to review the voice memo.
The screen displays the length of the memo along
with the date and time.
Voice Tools
91
•
Rerecord
: allows you to discard the current
memo and record another one.
•
Save
: allows you to save the voice memo.
•
Quit
: allows you to quit recording the memo and
exit the
Record
menu.
3. When you are satisfied, select the
Save
option
and press the
Select
soft key.
4. Enter a title for the memo and press the
OK
soft
key.
Review
(Menu 6-1-2)
When a list of your voice memos displays, scroll to
the memo you want to review and press the
Select
soft key. The phone plays back the memo.
On the memo list, press the
Menu
soft key to use
the following options:
Play
: plays back the memo.
Info
: shows detailed information about the memo,
such as title, length, memory size and date and
time when the memo was recorded.
Erase
: erases the selected memo.
Erase All
(Menu 6-1-3)
This menu allows you to erase all of the voice
memos and voice answers. When a confirming
message displays, select Yes and press the
Select
soft key.
Voice Tools
92
Voice Answer
(Menu 6-2)
If you are not able to answer an incoming call, you
can set your phone to answer a call with the default
greeting message and record the caller’s message.
As this feature shares the memory with voice
memos, the total length of messages is dependent
on the available memory less any voice memos.
Note
: You can quickly access this menu by pressing
the
VM
soft key in standby mode.
On/Off
(Menu 6-2-1)
This option allows you to enable or disable the
answering machine mode.
Voice Messages
(Menu 6-2-2)
You can listen to the callers’ messages recorded in
your phone. When you access this option, a list of
the recorded messages appears.
Note
: If the phone has the callers’ messages waiting
to be checked, it displays the total number of
the messages when the last message was
recorded.
On the message list, press the Menu soft key to the
following options:
Play
: plays the selected message.
Note
: You can pause the playback by pressing
Paused
soft key and then resume by pressing
Resumed
soft key.
Erase
: erases the selected message.
Voice Tools
93
Info
:shows detailed information about the
message, such as caller’s number if identified,
elapsed time, memory size and date and time when
the message was recorded.
Dial
: Places a call to the caller’s number, if
identified.
Erase All
: erases all of the voice memos and voice
answers.
Setting
(Menu 7-1-1)
You can change the settings for the voice answer
mode. The following options are available:
Greeting
: Your phone provides you with the
default greeting message to be played when a call
comes in. You can also record your own greeting
message.
To record a greeting message:
1. Select
Record
and press the
Select
key.
2. Wait until a beeping prompt sounds and record a
greeting message by speaking into the
microphone.
You can pause recording by pressing
Paused
soft key and then resume by pressing
Resumed
soft key.
3. When recording is complete, press the
OK:End
soft key. The phone automatically saves and
activates the message.
If you want to play back the currently selected
message, highlight Play and press the
Select
soft
key.
Voice Tools
94
To enable or disable your own greeting message:
1. Highlight
Select
and press the
Select
soft key.
2. Select
Enable
to use your message or
Disable
to use the default message.
3. Press the
Select
soft key to save your selection.
Note: Once you have recorded your own message and
then have changed the greeting to the default
message, your message is deleted.
Screening
: allows you to enable or disable the
screening speaker which allows you to listen to the
caller’s message while the caller is leaving it.
Wait Time
: allows you to set how long the phone
waits before answering a call with the greeting
message. Selecting
Off
means that the phone plays
back the message as son as a call comes in.
95
Settings
Many different features of your phone can be
customized to suit your preferences.
Sounds
(Menu 7-1)
You can use this menu to customize various sound
settings, such as the:
• ringer volume.
•key tone.
• tones that sound while using the phone’s
functions.
• tone that alerts you every hour on the hour.
• tone that the phone sounds when you turn on or
off the phone.
•voice volume.
Ringer
(Menu 7-1-1)
This menu allows you to set the unique ringer
melodies for calls, messages, and alarms. You can
select default melodies or ones downloaded from
the wireless web or using the PC link programme.
•
Voice Calls
: allows you to select a ringer for the
incoming calls.
Note
: You can adjust the volume using the Volume
keys on the left side of the phone is Standby
mode.
•
Messages
: allows you to select a ringer for
incoming messages.
Settings
96
•
Alarm/Scheduler
: allows you to select a ringer
for alarm and scheduler.
To select a ringer melody:
1. Select the item you want and press the
Select
soft key.
2. Press the Down key.
3. Select the melody you want using the Up or
Down key.
4. Press the Save soft key.
To adjust a ringer volume, select the item you want
to adjust the volume level and press the Volume
keys to adjust the volume level. The following
options are available:
Silent
: The phone does not sound a ring.
1 Beep
: The phone sounds a beep.
Vibrate
: The phone vibrates for incoming calls.
Level 1 ~ 5
: You can adjust the volume level. The
graphic shows the volume level; the more bars, the
louder the volume.
Note
: Available options may vary, depending on the
item you select.
Key Tone
(Menu 7-1-2)
This menu allows you to select a type of key tones
that the keypad generates each time you press a
key.
Settings
97
Function Alert
(Menu 7-1-3)
Your phone gives audible alerts (beeps) at a
specified time to inform you that certain things
have happened. The alerts only occur in your
earpiece so the other person on the phone does not
hear them.
The following alerts are available:
Minute Beep
: When this alert is selected, the
phone sounds an alert 10 seconds before each
elapsed minute to remind you of the length of the
current call.
Service Area
: When this alert is selected, the
phone sounds an alert when you exit your service
area or when you return to the service area.
Connect
: When this alert is selected, the phone
sounds a connect tone when your call is connected
to the system.
Disconnect
: When this alert is selected, the phone
sounds a disconnect tone when a call is
disconnected.
Fade
: When this alert is selected, the phone
sounds an alert when a dropped call occurs during
conversation in response to a signal fade.
Roam Area
: When this alert is selected, the phone
sounds an alert when your phone starts roaming.
Folder
: When this alert is selected, the phone
sounds an alert when you open or close the phone.
To turn on an alert:
1. Select an alert using the Navigation keys and
press the
Select
soft key.
Settings
98
2. When a confirming message displays, select
On
and press the
Select
soft key.
Hour Alert
(Menu 7-1-4)
You can set your phone to sound an alert every
hour on the hour.
1. Enter the period of time using the numeric keys
and press the Down key.
2. Select the alert type,
Cuckoo
or
Voice
, using
the Left or Right key.
3. Press the Down key and select
On
using the Left
or Right key.
If you don’t want to use the hour alert, select
Off
.
4. Press the
Save
soft key.
Power On/Off
(Menu 7-1-5)
You can select the tone that the phone sounds
when you turn on or off the phone.
To turn off the sound, select
Off
.
Voice Volume
(Menu 7-1-6)
This menu enables you to adjust the voice volume
of the earpiece.
Press the Navigation keys to adjust the volume. You
can also use the Volume keys on the left side of the
phone. The graphic shows the volume level; the
more bars you see, the louder the volume.
Settings
99
Note
: During a call, you can adjust the volume using
the Volume keys on the left side of the phone.
Display
(Menu 7-2)
The Display feature enables you to:
• change a background image or an image to be
displayed when the phone turns on or off.
• set a banner message.
• set the length of time for the backlight.
• set the current time and date.
• set the external clock type.
• turn the service light on or off.
• change the display language.
Image Box
(Menu 7-2-1)
This menu allows you to change the background
image to be displayed in Standby mode or when the
phone is turned on or off. You can also erase
downloaded or captured images.
The following options are available:
Opening
: You can select an image to display when
you turn on the phone.
Closing
: You can select an image to display when
you turn off the phone.
Wallpaper
: You can select an image to display on
the idle screen.
To select an image:
1. Select an item you want and press the
Select
soft key.
Settings
100
2. Select the image category you want and press
the
Select
soft key.
You can select one of the default images, ones
downloaded from the web, or photos you took.
3. Scroll through the images using the Navigation
keys.
4. Press the
Select
soft key when you find the
image you want.
Banner
(Menu 7-2-2)
This menu allows you to set a banner message to
be displayed at the bottom of the display in Standby
mode.
To change the banner:
1. If necessary, press the
C
key to clear the old
message.
2. Enter a new banner message using the
alphanumeric keys.
For more information about how to enter
characters, see page 37.
3. When you finish entering the message, press
the
OK
soft key to save it.
Backlight
(Menu 7-2-3)
This menu allows you to select the length of time
the backlight remains on.
Settings
101
When the phone is closed, the backlight turns off,
thus conserving battery power. When the phone is
open, the backlight remains on for the specified
length of time after the last key is pressed or you
open the phone. Remember that backlight use
drains your battery faster.
Set Time
(Menu 7-2-4)
This menu allows you to set the current date and
time. The following options are available:
Main Clock
You can set the current time. When you select this
menu, the current settings, if set, displays. In a
service area, you don’t need to change the time and
date setting.
1. Enter the current time and date using the
numeric keys.
The month, day, hour, and minute must each be
entered using 2 digits and the year requires all
four digits.
Notes
:
• You need to enter the time in 24-hour format.
• You can move through the input fields using the
Up or Down key.
2. When you finish, press the
Save
soft key.
Settings
102
Dual Clock
You can choose two time zones to be displayed
when you select
Dual clock
for the wallpaper
image in the
Wallpaper
menu (
Menu 7-2-1-3
).
You can also set the daylight saving time for the
selected time zones.
To select time zones for the dual clock:
1. When
Location
highlights, press the Down key.
2. Select the time zone for the left clock by
pressing the Left or Right key and press the
Down key.
3. Select the time zone for the right clock by
pressing the Left or Right key.
4. Press the
Save
key.
To apply the daylight savings:
1. When
Location
highlights, press the Left or
Right key to select
Summer Time
. Press the
Down key.
2. Select
On
to use the daylight saving time for the
left clock. Otherwise, select
Off
.
3. Press the Down key and repeat step 2 for the
right clock.
4. Press the
Save
key.
External Clock
(Menu 7-2-5)
You can change the type of clock to be displayed on
the external display in Standby mode.
Select one of the four options;
Digital clock
and
Analog
clock 1
through
Analog clock 3
.
Settings
103
Service LED
(Menu 7-2-6)
The service light on the front of the phone blinks to
indicate the service status. In this menu, you can
activate or deactivate the feature of the service
lights.
Language/
(Menu 7-2-7)
You can change the language of the menu display.
Select either or
English
.
Auto Retry
(Menu 7-3)
When this menu is set to
On
, your phone
automatically redials the number when a connection
fails.
Depending on your location, the number of times
your phone automatically redials may be different.
Answer Mode
(Menu 7-4)
This menu allows you to select how to answer an
incoming call.
The following options are available:
By Send Key
: The phone answers only when you
press the key.
By Folder Open
: The phone answers when you
open the phone. If the phone is already open, press
the key.
By Any Key
: When the phone is open, you can
press any key except for the key, the soft keys,
Settings
104
and the Volume keys. When the phone is closed,
you can answer the call by opening the phone.
Roam Option
(Menu 7-5)
Roaming is a feature which is only relevant in areas
where there are at least two cellular service
providers having valid roaming agreements.
Roaming allows you to register your phone on one
of the networks, but use the facilities of the other if
your own network is not available. This system
priority feature allows you to program your phone
for optimum operation within or outside your home
service area.
You should always check your phone’s display
because it will let you know when you’re outside the
service provider network and whether your phone is
operating in another network; the roaming icon
( ) appears.
You have the following options which allows you to
control the phone’s roaming ability:
Home only
: With this setting, you cannot roam. If
your home system is not available, your call will not
be connected and the No Service indicator ( )
displays.
Automatic
: Your phone automatically search for a
first available one of all types of service according
to the Preferred Roaming List supplied by the
service provider.
Settings
105
Security
(Menu 7-6)
Your phone provides you with various security
options, including a user-programmable lock code
and emergency numbers.
To access the
Security
menu, you must enter the
4-digit lock code. It is preset to “0000” at the
factory.
Phone Lock
(Menu 7-6-1)
In Lock mode, you cannot dial numbers, except for
making an emergency call, or accessing menu
options. The phone can receive incoming calls and
messages, even though the phone is in Lock mode.
The following options are available:
On
: You are not asked to enter the lock code when
you switch on the phone.
Off
: You are required to enter the lock code when
you switch on the phone.
To place an emergency call in Lock mode, enter a
programmed number and then press the key.
The phone recognizes standard emergency
numbers, such as 100, or three numbers
programmed in the
Emergency #
menu (
Menu 7-
6-3
); see page 106.
To unlock the phone, press one of the soft keys and
the Navigation keys and enter the 4-digit lock code.
The phone is immediately unlocked.
Settings
106
Change Lock
(Menu 7-6-2)
This feature allows you to change your current lock
code to a new one. The lock code is preset to
“0000” at the factory.
Enter a new, four-digit lock code and enter the code
once again at the prompt.
Note
: Your phone does not allow viewing of the lock
code for security reasons, so be sure to write
the lock code down or memorize it if you have
changed.
Emergency #
(Menu 7-6-3)
Your phone provides the option of storing three
emergency numbers. All of these numbers can be
manually dialed at any time, even if your phone is
locked or all outgoing calls are restricted.
IMPORTANT NOTICE!
Emergency calling may not be available on all
wireless networks at all times, due to the various
transmission methods, network parameters and
user settings used to complete a call from your
wireless phone. A connection cannot always be
guaranteed.
DO NOT depend on this phone as a primary method
of dialing 100 or for any other essential or
emergency communications.
Remember to always turn on your phone and check
for the adequate signal strength before placing a
call.
Settings
107
To store an emergency number:
1. Press the Up or Down key to select a location
and press the
Select
soft key.
2. Press the
C
key to clear the existing number.
3. Enter a number and press the
Save
soft key to
save the number.
Note
: 100, 101, 102 and *166 will remain as
emergency numbers, even if you change them
on the emergency number list.
To make an emergency call in Lock mode, simply
enter one of the programmed emergency numbers
and press the key.
Voice Privacy
(Menu 7-6-4)
Used only in digital networks, Voice privacy
encrypts the voice channel so that people cannot
eavesdrop on your conversation.
The following options are available:
Standard
: The phone uses a standard line for calls.
Enhanced
: The phone makes and receives calls on
an encrypted high security line.
Note
: This feature may not be available in all areas.
Contact your service provider for details and its
availability.
Settings
108
Restriction
(Menu 7-6-5)
This feature allows you to restrict the use of your
phone.
The following options are available:
Outgoing
: restricts outgoing calls from your
phone, except emergency calls by standard
emergency numbers, such as 100, 101, 102 and
*166, or three programmed numbers in
Emergency
#
(
Menu 7-6-3
).
Incoming
: restricts incoming calls.
Phonebook
: restricts access to your Phonebook.
You cannot also add a new entry.
When a confirmation message displays, select
Yes
to turn it on or
No
turn it off.
Clear Memory
(Menu 7-6-6)
This feature allows you to clear all of the numbers
in your Phonebook.
You can also erase all of the messages by selecting
Messages
.
When a confirmation message appears, select
Yes
and press the
Select
soft key.
Reset Phone
(Menu 7-6-7)
This menu allows you to restores the default
settings of all of user-selectable options, or the
phone’s memory.
The following options are available:
Function Only
: allows you to restores the default
settings of all of user-selectable options.
Settings
109
All
: allows you to restores information stored in the
phone’s memory.
When a confirmation message displays, select
Yes
and press the
Select
soft key to confirm. The
phone reboots, turning itself off and then back on,
and returns to Standby mode.
Select
No
to cancel your selection.
Data Option
(Menu 7-7)
You may sometimes need to switch the network to
another, according to the service status in your
area. In this menu, you can select the network type
you prefer.
If the network is not available with the current
setting, try again after changing the option.
The following options are available:
Auto selection
: allows your phone to select an
available data transmission type automatically.
1X Only
: allows your phone to use only 1X type.
95A Only
: allows your phone to use only 95A type.
Data/Fax Mode
(Menu 7-8)
Your phone is capable of sending and receiving
digital data and fax call when connected to a
computing device(laptop, desktop, handheld,
palmtop, etc.) running Windows 95, Windows 98,
Windows NT or later versions. The phone functions
just like a typical modem on your PC, enabling you
Settings
110
to use wireless data involving a wide variety of
Windows software applications.
To use digital data or fax services with your phone,
you will need to obtain a digital data/fax kit from
your service provider. This kit contains the
necessary cables, software, and user’s guide
required for you to connect and use your phone
with your computing device.
Note
: The phone must be on a digital network to
receive or send faxes and data.
The following options are available:
Data/Fax off
: Your phone dosen’t receive Data
and Fax.
Fax for next call
: Your phone receives Fax when
next call is incoming.
Fax until powered off
: Your phone receives Fax
until your phone is powered off.
Data for next call
: Your phone receives Data
when next call is incoming.
Data until powered off
: Your phone receives Data
until your phone is powered off.
Receiving a fax or data
To receive a fax or data, ensure that your phone is
connected to your PC and is powered on. Select one
of the Data/Fax options. When you receive a fax
call, set up the
Answer
mode in the fax program
on your PC and click on
Receive
and select one of
the following:
• Automatic Receive (recommended)
• Manual Receive
Settings
111
Sending a fax or data file
When connected to a computing device, your phone
allows wireless fax and data transmissions. Your
computing device software initiates the call to the
destination phone number. The phone funtions as a
wireless modem to send the fax or data file to the
number designated by your PC software.
Memory Status
(Menu 7-9)
This menu allows you to check the amount of the
memory being used or memory remaining for
downloaded contents, such as melodies and
images.
Total
: shows the total space including the used and
free space.
Music
: shows the list of downloaded music files,
such as bells or melodies.
: shows the list of downloaded image files,
including photos and animated image.
You can also delete obsolete contents from the
content list to free up memory space for storing a
new item.
112
VAS
This menu allows you to use a variety of services
supplied by your service provider, such as the:
•WAP browser
• Voice potal service
• SMS information service
Note
: You can quickly access this menu by pressing
the key in Standby mode.
Internet Portal
(Menu 8-1)
Your phone is equipped with a WAP (Wireless
Application Protocol) browser which allows you to
access and navigate the wireless web.
Selecting the
Internet Portal
menu launches the
WAP browser. Once you are connected to the
network, the homepage of your service provider.
Note
: You can quickly access this menu by pressing
the Down key in standby mode.
Navigating the browser
To Press
Scroll through
browser items Up and Down keys.
Scroll through
browser items by
one page
Volume keys.
VAS
113
Entering text in the browser
When you are in a text input field, you can use the
following input mode; to change the input mode,
press the
abc
soft key and select a mode:
Hebrew
:allows you to enter Hebrew letters as you
would in ABC mode.
Sym
: allows you to enter symbols or punctuation
marks.
123
: allows you to enter numbers.
abc
: allows you enter English characters by
pressing the key one or more times until the letter
you want appears.
Choose an item soft key, or press the
Menu
soft key and select
Done
.
Return to the
previous page
Dismiss
or
Cancel
soft key.
Access browser
menus
Menu
soft key and select
Browser menu
. For details
about each option, see “Using
the browser menus”.
Exit the browser key.
To Press
VAS
114
Using the browser menus
When you access the browser menu list, the
follwoing options are available:
Home
: accesses the homepage.
Bookmarks
: allows you to make a bookmark for
the current page, or use th bookmark list to quickly
access a page.
Reload
: refreshes the current page using the
updated information.
Go To URL
: allows you to enter a URL address of
the web page you want to access.
Save items
: allows you to save images or sounds
of the current page.
Show URL
: shows the URL address of the current
page.
Exit
: exits the browser.
Advanced
: provides you with further options.
Restart browser: restarts the browser without
exiting it.
Delete cookies: deletes all of the cookies and files.
A cookie is a piece of user’s information that is
entered when you use a web site.
Homepage: allows you to change the startup
homepage manually.
Scroll mode: lets you set the scroll mode to either
Block
or
Smooth
, or set the speed for scrolling to
the next screen, to either
Fast
,
Medium
, or
Slow
.
Send referrer: allows you to set the browser to send
HTTP referrer information to the web server each
time the browser is launched.
VAS
115
Connection timeout: allows you to set how long the
phone keeps connection to the current web page
when you don’t use the web page. You can select
30secods
or
60seconds
.
Key press timeout: allows you to set how long the
phone waits after you have pressed a key in the
text entry mode before moving the cursor to the
right. You can select
Fast
,
Medium
, or
Slow
. If
you don’t want to set the timeout, select
Off
.
Security: displays all security-related information,
such as Secure Prompt, Authentication, and Current
Certificate.
Clear Memory
: allows you to clear information
stored in memory, such as history, cache, cookies,
and auto fill information.
About
: shows the WAP browser version and
copyright, encryption, and certificate information.
VAS
116
Games & App
(Menu 8-2)
In this menu, you can use Brew applications. On the
main screen of the menu, there are three default
applications available:
•
MobileShop
: allows you to buy and download
Brew applications from the WAP browser.
•
Settings
: allows you to change the application
settings and to check the memory status.
•
Help
: gives you help for using applications.
Downloading multimedia files
1. Press the key when the
MobileShop
icon is
selected.
The following options are available:
•
Catalog
: allows you to browse and purchase
application.
•
Search
: allows you to search for an
application by entering a keyword.
•
About Download
: provides you with the help
information about using the
MobileShop
menu.
2. Press the key when the
Catalog
option is
selected.
You are accessed to the associated web site
preset by your service provider and you can
browse available applications.
3. Select the application you want to download and
follow the instructions on the screen.
Downloaded applications will display on the
main screen of the
Brew
menu.
VAS
117
Changing the application settings
1. Select the
Settings
icon using the Left or Right
key and press the key.
2. Select a setting option using the Up or Down key
and press the key.
The following options are available:
•
Order Apps
: allows you to change the order
of the downloaded applications.
•
Move Apps
: allows you to move an
application to another folder.
•
Manage Apps
: shows the amount of the
memory used for downloaded applications.
•
Main Menu View
: allows you to change the
view mode of the main menu screen.
•
Screen Savers
: allows you to use one of
screen savers downloaded.
•
View Log
: shows the records of your browsing
and downloading.
3. When you have finished, press the
C
or or
key.
Viewing help information
1. Select the
Help
icon using the Left or Right key
and press the key.
2. Select a help item using the Up or Down key and
press the key.
3. Press the Up or Down key to scroll through the
information.
4. To go back to the main help screen, press the
or
C
key.
VAS
118
Multimedia
(Menu 8-3)
In this menu, you can download movie files, from
the WAP browser and play the downloaded
contents.
Watch movies
(Menu 8-3-1)
Use this menu to play a movie file.
When you access this menu, the list of the
downloaded movies displays. Scroll to the item you
want to play and press the
OK
soft key.
Press the ?? key to pause playback and the ?? key
to resume.
You can access the following options by pressing the
Menu
soft key on the file list:
Delete
: deletes the currently selected movie file.
Delete all
: allows to delete all of the movie files.
D/L movies
(Menu 8-3-2)
Selecing this menu loads the WAP page preset by
your service provider so that you can download a
variety of multimedia contents.
VAS
119
Ringtone
(Menu 8-4)
In this menu, you can download ring tones and
melodies from the WAP browser and play the
downloaded contents.
Activate
(Menu 8-4-1)
In this menu, you can set one of the downloaded
ring tones or melodies as your ringer.
1. Scroll to the tone or melody you want and press
the
OK
soft key.
2. Press the
OK
soft key to set the sound as your
ringer.
Download
(Menu 8-4-2)
Selecing this menu loads the WAP page preset by
your service provider so that you can download a
variety of ring tones and melodies.
Animation
(Menu 8-5)
In this menu, you can download animation images
from the WAP browser and play the downloaded
contents.
Activate
(Menu 8-5-1)
In this menu, you can set one of the downloaded
animation image as your wallpaper for Standby
mode.
VAS
120
1. Scroll to the image you want and press the
OK
soft key.
2. Press the
OK
soft key to set the image as your
wallpaper.
Download
(Menu 8-5-2)
Selecing this menu loads the WAP page preset by
your service provider so that you can download a
variety of animation images.
Voice portal
(Menu 8-6)
This menu allows you to access your service
provider’s voice-activated service. You can get
headline news, get information on movies, the
weather, finance, traffic, or restaurants in many
cities, plus other features; it's similar to the kind of
content that's available on a web portal.
Note
: Voice Portal is a network feature. Please
contact your service provider for further details.
SMS info
(Menu 8-7)
You can send an SMS query to receive information
you want from the web server. A variety of topics
are avilable, such as news, sports, entertainment,
finance, and etc.
Once you select a topic, your phone sends a query
with the code associated with the selected topic,
and the server will send you the requested
information in an SMS message.
VAS
121
What’s new?
(Menu 8-8)
Selecting this menu loads the WAP page preset by
your service provider so that you can get
information about your service provider’s latest
offerings, such as downlods, pricing plans,
entertainment, technical help, and customer
services.
122
Camera
Using the camera module built into your phone, you
can take photos of people or events while on the
move. You can send photos to other people using a
message or set photos as a wallpaper image or an
image to be displayed when you turn on or off the
phone.
You can also record a video by using your phone as
a camcorder.
Note
: You can quickly enter this menu by pressing the
key on the right side of the phone in Standby
mode.
CAUTION
:
• Do not take photos of people without their
permission.
• Do not take photos in a place where cameras are not
allowed.
• Do not take photos in a place where you may
interfere with another person’s privacy.
Take Photo
(Menu 9-1)
The camera produces JPEG photos.
Note
: When you take a photo in direct sunlight or in
bright conditions, shadows may appear on the
photo.
Taking a photo with the phone open
1. In Standby mode, press and hold the
key on
the right side of the phone.
Camera
123
The image to be captured appears on the
display.
2. Adjust the image by aiming the camera at the
subject.
Note
: If resolution is set as high, zooming cannot be
used.
4. Press the
Capture
soft key or
key
to take the
photo.
When you are taking multi-shot images, the
camera takes photos successively.
5. Press the
Save
soft key.
To discard the photo and go back to Capture
mode, press the
Cancel
soft key.
6. Enter the photo name you want.
For details about entering characters, see
page 37.
7. Press the
OK
soft key.
3.
To Press the
flip the image
vertically key.
view the mirror image key.
zoom in or out Left or Right key.
change the image
brightness Up or Down Key.
view the real image
size
0
key.
use the options the
Option
soft key.
See page 124.
Camera
124
The phone saves the photo(s) in the
Album
menu (
Menu 9-3
) and returns to
Capture mode.
Using the options in Capture mode
When you press the
Option
soft key in Capture
mode, the following options are available for the
current shot:
Video Mode
Selecting this option switches the phone to Record
mode. See page 126.
Flash
The following options are available:
Off: allows you to turn off the flash.
This Shot only: allows you to turn on the flash for
the current shot. After you take a photo, the flash
turns off.
Always On: allows you to use the flash when you
take a photo.
Self timer
You can set the camera to take a photo at a
predefined time. You can view the timer icon on the
bottom line of the display. When you press the
key or the
Capture
soft key, the timer starts
counting down.
Multi Shot
This option allows you to take successive action
stills up to seven shots. Select the interval between
shots,
Off
,
Short
,
Normal
, or
Long
. After taking
photos, the phone automatically saves them.
Camera
125
Brightness
You can adjust the brightness of the image. When
Auto
is selected, the phone automatically
determines the setting.
Fun Frames
This option allows you to use a decorated frame
with the photo. Press the Navigation keys to find
the frame format you want to use.
Color Tones
This option allows you to change the color tone or
apply special effects to the photo.
Resolution
This option allows you to select an image
resolution.
Taking a photo with the phone closed
1. When the phone is closed, press and hold the
key on the right side of the phone.
The image to be captured displays on the
external display.
2. Adjust the image by aiming the camera module.
To use the options, press the key until the
option icon is selected. You can change the
settings by pressing the key. The following
options are available:
• : allows you to flip the image vertically.
• : allows you to adjust the brightness of the
image.
• :allows you to select the image quality.
Camera
126
• : allows you to enlarge the image.
3. Press the key to take the photo.
The phone saves the photo in the
Photo Album
menu (
Menu 9-3
) and returns to Capture
mode.
Record Video
(Menu 9-2)
To record a video:
1. Accessing the
Record Video
menu turns on the
camera.
The image to be captured appears on the
display.
2. Adjust the image by aiming the camera at the
subject.
4. Press the
Record
soft key or the key to start
recording.
5. When you have finished, press the
Stop
soft
key.
3.
To Press the
flip the image vertically key.
view the mirror image key.
zoom in or out Left or Right key.
change the brightness
of the image Up or Down key.
use the options the
Option
soft key.
For details, see
page 127.
Camera
127
Otherwise, the phone will automatically stop
when the recording time expires.
6. Press the
Save
soft key.
You can review your recording by pressing the
Review
soft key.
7. Enter the video name you want.
For further details about entering characters,
see page 37.
8. Press the
OK
soft key.
The phone saves the video in the
Video Album
menu (
Menu 9-4
), and returns to Record mode.
Using the options in Record mode
When you press the
Option
soft key in Record
mode, the following options are available:
Photo Mode
Selecting this option switches the phone to Capture
mode. See page 122.
Voice REC.
This option allows you to record audio with the
video.
Self timer
You can set the phone to start a video at a
predefined time. You can view the timer icon on the
bottom line of the display. When you press the
Record
soft key or the key, the timer starts
counting down.
Camera
128
Brightness
You can adjust the brightness of the image. When
Auto
is selected, the phone automatically
determines the setting.
Color Tones
This option allows you to change the color tone or
apply a special effect to the video.
Photo Album
(Menu 9-3)
In this menu, you can review the photos you have
taken. By default, your phone displays the last
photo you took on the full screen, Expand mode.
Use the Left and Right keys to scroll through the
photos.
To view the photos as small images, press the
Thumbnail
soft key. In this mode, you can scroll
through the photos by using the Navigation keys
keys. To go back to Expand mode, press
Expand
soft key.
Using the photo options
Press the
Option
soft key to use the following
options:
Note
: The available options are different, depending
on the current view mode, Thumbnail or
Expand mode.
Send
MMS
This option allows you to send the photo to another
person’s phone. For further details about sending
MMS, see page 131
Camera
129
Assign
This option allows you to set the photo as your
wallpaper for the idle screen or an image to be
displayed when you turn on or off the phone.
Rename
This option allows you to change the name of the
photo.
Lock
This option allows you to lock the photo so that
other people cannot access the photo without your
lock code.
Erase
This option allows you to erase the photo.
Erase All
This option allows you to erase all of the photos
stored in the phone.
Photo Info
This option shows you information about the
current photo, such as the name, the time and date
it was taken, image size, and image quality.
Video Album
(Menu 9-4)
In this menu, you can play the video files you
recorded. When you access this menu, the still
image of the last video you recorded displays.
Camera
130
To play a video:
1. Press the Left or Right key to scroll to the video
you want to view.
Using the video options
Press the
Option
soft key on the Video album
screen to use the following options:
Rename
This option allows you to change the name of the
video.
Lock
This option allows you to lock the video so that
other people cannot access the video without your
lock code.
Erase
This option allows you to erase the video.
Erase All
This option allows you to erase all of the videos.
Video Info
This option shows you information about the
current video, such as the name, the time and date
it was recorded, video size, and image quality.
2.
To Press the
start
Play
soft key.
stop right soft key.
return to Standby mode key.
Camera
131
MMS
(Menu 9-5)
In this menu, you can send a photo to other people
as a part of an MMS message.
New Photo
(Menu 9-5-1)
You can take a new photo and then create and send
an MMS message. Selecting this menu turns on the
camera and switches to Capture mode.
1. After adjusting the image, press the
Capture
soft key to take a photo.
For more information about the options available
in the camera, see page 122.
2. Press the
Save
soft key.
3. Enter a photo name and press the
OK
soft key.
A new message screen containing the taken
photo appears.
4. When the
Send to
field highlights, press the
Menu
soft key.
Note:
You can select a address type, Send To, Cc,
or Bcc, by pressing the Left or Right key.
5. Select
Phonebook
to retrieve a phone number
or an e-mail address from your Phonebook, or
Edit
to enter one.
6. Choose a number or an address or enter one,
and then press the
OK
soft key.
7. Press the Down key to move to the
Subject
field and press the
Edit
soft key.
Camera
132
8. Enter a subject and press the
OK
soft key.
9. Press the Down key to move the
field
and press the
Menu
soft key.
The following options are available:
•
Take Photo
: allows you to take a new photo
using the camera.
•
Album
: allows you to select a photo from the
Photo Album.
•
Saved Img
: allows you to select an image
downloaded from the Internet.
•
Erase
: remove the image from the slide.
10.Press the Down key to move the
Message
field
and press the
Edit
soft key.
11.Enter a message text and press the
OK
soft key.
12.Press the Down key to move to the
Sound
field
and press the
Menu
soft key.
The following options are available:
•
Voice Rec
: allows you to record a new voice
memo.
•
Voice Memo
: allows you to select a photo
from the Voice Memo.
•
Melody
: allows you to select one of the
default melodies.
•
Saved Snd
: allows you to select a sound
downloaded from the Internet.
•
Erase
: remove the sound from the slide.
13.Select an option and then record a memo or
select a sound.
Camera
133
14.If you want to add or remove a slide, move to
the
Slide
field and press the
Menu
soft key.
The following options are available:
•
Add
: adds a new slide.
•
Erase
: erases any added slides.
•
Duration
: allows you to set the length of time
the slide displays.
15.When you have finished the MMS message,
press the
OK
soft key.
The following options are available:
•
Preview
: shows the message you created.
•
MMS Edit
: allows you to change the message.
•
Options
: allows you to set message options.
•
Save in Draft
: saves the message in the Draft
box.
16.When you are satisfied, press the
OK
soft key.
The phone displays your message.
17.Press the
Send
soft key to send it.
Album
(Menu 9-5-2)
You can create and send an MMS message using
one of photos stored in Photo Album. Selecting this
menu opens the Photo Album screen.
1. Scroll to the photo you want by pressing the Left
or Right key and press the
Select
soft key.
A new message screen containing the selected
photo appears.
2. Follow from step 4 on page 131 to create and
send the message.
Camera
134
Settings
(Menu 9-6)
This menu allows you to change the default settings
of the options for using the camera.
The following options are available:
Resolution
: allows you to adjust the resolution of
the image. You can select either
High:640*480
,
Medium:320*240
,
Full:128*160
, or
Low:160*96
.
Fun Frames
: allows you to use a frame with the
photo. Press the Navigation keys to find the frame
format you want to use.
Color Tones
:
allows you to change the color tone
or apply a special effect to the image.
Shutter Sound
: allows you select the tone that
sounds when you press the
Capture
soft key or
key.
Quality
: allows you to change the image quality.
You can select either
Fine
,
Normal
, or
Economy
.
Memory Status
(Menu 9-7)
You can check the amount of the memory being
used and the memory remaining for the Camera
feature.
The display shows the total, free, and used space.
135
Health and safety
information
Exposure to radio frequency (RF)
signals
Your wireless phone is a radio transmitter and
receiver. It is designed and manufactured not to
exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal
Communications Commission (FCC) of the U.S.
Government. These limits are part of
comprehensive guidelines and establish permitted
levels of RF energy for the general population. The
guidelines are based on the safety standards that
were developed by independent scientific
organizations through periodic and through
evaluation of scientific studies.
The standards include a substantial safety margin
designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless phones employs
a unit of measurement known as Specific
Absorption Rate (SAR). The SAR limit set by the
FCC is 1.6W/kg.
*
*. In the U.S. and Canada, the SAR limit for mobile phones
used by the public is 1.6 watts/kg (W/kg) averaged over
one gram of tissue. The standard incorporates a substantial
margin of safety to give additional protection for the public
and to account for any variations in measurements.
Health and safety information
136
SAR tests are conducted using standard operating
positions specified by the FCC with the phone
transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is
determined at the highest certified power level, the
actual SAR level of the phone while operating can
be well below the maximum value. This is because
the phone is designed to operate at multiple power
levels so as to use only the power required to reach
the network. In general, the closer you are to a
wireless base station antenna, the lower the power
output of the phone.
Before a new model phone is available for sale to
the public, it must be tested and certified to the FCC
that it does not exceed the limit established by the
government-adopted requirement for safe
exposure. The tests are performed in positions and
locations (e.g., at the ear and worn on the body) as
required by the FCC for each model. While there
may be differences between the SAR levels of
various phones and at various positions, they all
meet the government requirement.
The FCC has granted an Equipment Authorization
for this model phone with all reported SAR levels
evaluated as in compliance with the FCC RF
exposure guidelines. SAR information on this model
phone is on file with the FCC and can be found
under the Display Grant section of http://
www.fcc.gov/oet/fccid after searching on FCC ID
printed in the label on the phone.
FCC certification information for this model phone is
attached separation paper.
Health and safety information
137
For body operation
To maintain compliance with FCC RF exposure requirements,
use only belt-clips, holsters or similar accessories that
maintain a 1.5 cm. separation distance between the user's
body and the back of the phone, including the antenna,
whether extended or retracted. The use of belt-clips,
holsters and similar accessories should not contain metallic
components in its assembly. The use of accessories that
do not satisfy these requirements may not comply with
FCC RF exposure requirements, and should be avoided.
For more Information concerning exposure to radio
frequency signals, see the following websites:
Federal Communications Commission (FCC) http://
www.fcc.gov/oet/rfsafety
Cellular Telecommunications Industry Association
(CTIA): http://www.wow-com.com
U.S.Food and Drug Administration (FDA) http://
www.fda.gov/cdrh/consumer
World Health Organization (WHO) http://
www.who.int/peh-emf/en
Health and safety information
138
Precautions when using batteries
• Never use any charger or battery that is damaged
in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network’s base
station, it uses less power; talk and standby time
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
Battery charging time depends on the remaining
battery charge and the type of battery and charger
used. The battery can be charged and discharged
hundreds of times, but it will gradually wear out.
When the operation time (talk time and standby
time) is noticeably shorter than normal, it is time to
buy a new battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not in use,
disconnect it from the power source. Do not leave
the battery connected to a charger for more than
a week, since overcharging may shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling or
warming first.
Do not leave the battery in hot or cold places, such
as in a car in summer or winter conditions, as you
will reduce the capacity and lifetime of the battery.
Always try to keep the battery at room
temperature. A phone with a hot or cold battery
may temporarily not work, even when the battery is
Health and safety information
139
fully charged. Li-ion batteries are particularly
affected by temperatures below 0 °C (32 °F).
• Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object (coin,
clip or pen) causes a direct connection between
the + and – terminals of the battery (metal strips
on the battery), for example when you carry a
spare battery in a pocket or bag. Short-circuiting
the terminals may damage the battery or the
object causing the short-circuiting.
• Dispose of used batteries in accordance with local
regulations. Always recycle. Do not dispose of
batteries in a fire.
Road safety
Your wireless phone gives you the powerful ability
to communicate by voice, almost anywhere,
anytime. But an important responsibility
accompanies the benefits of wireless phones, one
that every user must uphold.
When driving a car, driving is your first
responsibility. When using your wireless phone
behind the wheel of a car, make sure that you are
following the special regulations in a given area or
country.
Health and safety information
140
Operating environment
Remember to follow any special regulations in force
in any area and always switch your phone off
whenever it is forbidden to use it, or when it may
cause interference or danger.
When connecting the phone or any accessory to
another device, read its user’s guide for detailed
safety instructions. Do not connect incompatible
products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation
of the equipment and for the safety of personnel, it
is recommended that the equipment should only be
used in the normal operating position (held to your
ear with the antenna pointing over your shoulder).
Electronic devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against
the RF signals from your wireless phone. Consult
the manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be
maintained between a wireless phone and a
pacemaker to avoid potential interference with the
pacemaker. These recommendations are consistent
with the independent research and
recommendations of Wireless Technology Research.
Health and safety information
141
Persons with pacemakers:
• Should always keep the phone more than 15 cm
(6 inches) from their pacemaker when the phone is
switched on
• Should not carry the phone in a breast pocket
• Should use the ear opposite the pacemaker to
minimize potential interference
If you have any reason to suspect that interference
is taking place, switch your phone immediately off.
Hearing aids
Some digital wireless phones may interfere with
some hearing aids. In the event of such
interference, you may wish to consult your hearing
aid manufacturer to discuss alternatives.
Other medical devices
If you use any other personal medical devices,
consult the manufacturer of your device to
determine if it is adequately shielded from external
RF energy. Your physician may be able to assist you
in obtaining this information. Switch your phone off
in health care facilities when any regulations posted
in these areas instruct you to do so. Hospitals or
health care facilities may be using equipment that
could be sensitive to external RF energy.
Health and safety information
142
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle.
You should also consult the manufacturer of any
equipment that has been added to your vehicle.
Posted facilities
Switch your phone off in any facility where posted
notices require you to do so.
Potentially Explosive Environments
Switch your phone off when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause
an explosion or fire resulting in bodily injury or even
death.
Users are advised to switch off the phone while at a
refuelling point (service station). Users are
reminded of the need to observe restrictions on the
use of radio equipment in fuel depots (fuel storage
and distribution areas), chemical plants or where
blasting operations are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas
(such as propane or butane), areas where the air
contains chemicals or particles, such as grain, dust
or metal powders, and any other area where you
Health and safety information
143
would normally be advised to turn off your vehicle
engine.
Emergency calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well
as user-programmed functions, which cannot
guarantee connection in all conditions. Therefore,
you should never rely solely on any wireless phone
for essential communications (medical
emergencies, for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not
be possible on all wireless phone networks or when
certain network services and/or phone features are
in use. Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location (for example, 100 or any other official
emergency number). Emergency numbers vary
by location.
3. Press .
If certain features are in use (call barring, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult this document and your local cellular
service provider.
Health and safety information
144
When making an emergency call, remember to give
all the necessary information as accurately as
possible. Remember that your phone may be the
only means of communication at the scene of an
accident; do not cut off the call until given
permission to do so.
Other important safety information
• Only qualified personnel should service the phone
or install the phone in a vehicle. Faulty
installation or service may be dangerous and may
invalidate any warranty applicable to the device.
• Check regularly that all wireless phone equipment
in your vehicle is mounted and operating
properly.
• Do not store or carry flammable liquids, gases or
explosive materials in the same compartment as
the phone, its parts or accessories.
• For vehicles equipped with an air bag, remember
that an air bag inflates with great force. Do not
place objects, including both installed or portable
wireless equipment in the area over the air bag or
in the air bag deployment area. If wireless
equipment is improperly installed and the air bag
inflates, serious injury could result.
• Switch your phone off before boarding an aircraft.
The use of wireless phones in aircraft may be
dangerous to the operation of the aircraft, and is
illegal.
• Failure to observe these instructions may lead to
the suspension or denial of telephone services to
the offender, or legal action, or both.
Health and safety information
145
Care and maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for
many years.
• Keep the phone and all its parts and accessories
out of the reach of small children’s.
• Keep the phone dry. Precipitation, humidity and
liquids contain minerals that will corrode
electronic circuits.
• Do not use the phone with a wet hand. Doing so
may cause an electric shock to you or damage to
the phone.
• Do not use or store the phone in dusty, dirty
areas, as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the
phone, which may damage the phone’s electronic
circuit boards.
• Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the phone. Wipe it
with a soft cloth slightly dampened in a mild
soap-and-water solution.
Health and safety information
146
• Do not paint the phone. Paint can clog the
device’s moving parts and prevent proper
operation.
• Do not put the phone in or on heating devices,
such as a microwave oven, a stove or a radiator.
The phone may explode when overheated.
• Use only the supplied or an approved
replacement antenna. Unauthorized antennas or
modified accessories may damage the phone and
violate regulations governing radio devices.
• If the phone, battery, charger or any accessory is
not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
Glossary
147
Glossary
Air Time
- Actual time spent talking on the wireless
phone. Most carriers bill customers based on how
many minutes of airtime they use each month.
Antenna
- A device for transmitting or receiving
signals. The size and shape of antennas is
determined, in part, by the frequency of the signal
they receive. Wireless phones and the base station
must have antennas.
Base Station
- The fixed radio transmitter/receiver
that maintains communications with mobile radio
telephones within a given area. (Typically called a
cell or cell site)
CDMA
- (Code Division Multiple Access) A spread-
spectrum approach to digital transmission. With
CDMA, each conversion is digitized and then tagged
with a code. The mobile phone deciphers only a
particular code to pick the right conversation off the
air. The transmitted signal is just above noise level
across the available bandwidth.
Channel
- Communications signals transmit along
paths called channels.
Codec Coder/Decorder
- Compression &
decompression.
Deactivation
- The process of rendering a wireless
phone inactive.
DTMF
- (Dual-Tone Multi- Frequency ) You send
DTMF signals when you enter numbers by pressing
the digit keys.
Glossary
148
EVRC
- (Enhanced Variable Rate Codec) EVRC is a
new global standard for compressing and
decompressing voice signals. EVRC uses a lower bit
rate (the number of bits sent per second) than
existing CDMA vocoders, while providing significant
improvements in voice quality. This technology
enables your phone to provide superb voice quality
while benefiting from the ability to process more
cellular voice calls using less bandwidth than the
voice codecs in CDMA networks today.
Frequency
- A measure based on time, as one or
more waves per second, in an electrical or light
wave information signal. A signal’s frequency is
stated in cycles-per-second or Hertz (Hz).
Hands-Free
- A feature that permits a driver to
use a wireless phone without lifting or holding the
handset - an important safety feature for
automobiles, tractors and most other motorized
vehicles.
LCD
- (Liquid Crystal Display) Commonly used to
refer to the screen display on the wireless phone.
Prepend
- The addition of a prefix, such as an area
code, to a phone number.
RF
- Radio Frequency
Roaming
- The ability to use a wireless phone to
make and receive calls in places outside of the
home service area.
Service Charge
- The amount paid each month to
receive wireless service.
Glossary
149
Standby Time
- The amount of time a fully
charged wireless portable or transportable phone
can be on and idle without being in use. (See Talk
Time)
Talk Time
- The length of time a person can talk on
a portable or transportable wireless phone without
recharging the battery.
Vocoder
- Voice Coder. A device used to convert
speech into digital signals.
Wireless
- Radio-based Systems that allow
transmission of telephone or data signals through
the air without a physical connection, such as a
metal wire (copper) or fiber optic cable.
149
Index
A
Accessories
9
Add
from Standby mode
59
into an existing entry
59
using a memo
60
using a number
57
using an e-mail
address
60
Adjusting the volume during
a call
31
Air time
53
Alarm
81
Alert
connect
97
disconnect
97
fade
97
folder
97
hour alert
98
minute Beep
97
roam area
97
service area
97
Animation
119
Answer mode
103
Auto retry
103
B
Backlight
100
Banner
100
Battery
charging
19
Installing
17
low battery indicator
20
removing
18
C
Calculator
82
Calls
answering
33
emergency
26
ending
26
from Phonebook
27
incoming
52
making
25
missed
34
,
51
outgoing
53
recent call
27
rejecting
34
silencing
33
three-way
35
Camera
122
Change lock
106
Characters, entering
37
Charging
19
Charging batteries
19
Charging battery •
19
Clear memory
108
Countdown
85
D
D/L movies
118
Data Option
109
Data option
109
Data/Fax Mode
109
Dialing
pause
29
prepend
28
speed
29
Display
99
icons •
13
DTMF
147
E
Emergency #
106
External clock
102
F
Find
by entry number
56
by name
54
entry by group
56
Flash
16
Index
150
G
Games
87
I
Icons, description •
13
Image box
99
In-call option
34
Internet Portal
112
K
Keys
description •
11
location •
10
L
Language
103
Lock mode
24
Low battery indicator
20
M
Memo pad
86
Menus
list
46
scrolling
44
shortcuts
45
Message
draftbox
67
inbox
65
new message
63
outbox
66
MMS
68
MSG Templates
77
Multimedia
118
My phone #
62
N
Navigating the browser
112
P
Phondbook
find
54
Phone
display •
13
icons •
13
keys •
11
layout •
10
unpacking •
9
Phone lock
105
Phonebook
add
57
group set
61
Photo album
128
Power Save mode
23
R
Removing the battery
18
Reset phone
108
Restriction
108
Roam option
104
S
Safety
precautions
7
Scheduler
78
Security
105
Service LED
103
Service light
15
Set time
101
Silent mode
24
SMS info
120
Soft keys
22
Sounds
95
Standby mode
23
Switching on/off phone
20
T
T9 Word, T9 Hebrew
38
Talk mode
23
To do list
83
Today
82
V
VAS
112
Index
151
Video album
129
Voice Answer
92
Voice memo
90
Voice portal
120
Voice privacy
107
W
What’s new?
121
World time
84
Writing new message
63
153
Internal Phonebook
Store a new
number into
memory
Phone number +
Save
+ Name
+
OK
+ Choose Category +
Select
+ Up/Down (Name/
Location/Home/Office/Mobile/
Pager/Fax/E-mail1/E-mail2/URL/
ETC/Speed dial/Group/Ringer/
Caller Image) +
Edit
and enter
information or Left/Right +
Save
Speed dial Location number +hold the last
digit
Scan
memories
Find
+ Up/Down/Left/Right +
OK
SCH-X839 Quick Reference Card
Basic Operation
Make a call Phone number +
End a call
Receuve a call or open the phone
Adjust the key
volume (in Standby mode)
/ on the left side
Adjust the voice
volume (during a call)
/ on the left side
Redial the last call twice or Hold
Switch to Silent
mode (in Standby mode)
Hold
Take a photo • With the phone open
Hold the Camera key +
Capture
+
Save
+ Enter a
photo name +
OK
• With the phone closed
Hold the Camera key + the
Camera key
Quick reference card
SCH-X839
154
1: Calls 1: Missed
2: Incoming
3: Outgoing
4: Air Time
2: Phonebook 1: Find
2: Add
3: Group Set
4: My Phone #
3: Message 1: Text Msg
2: MMS
3: Voice Mail
4: Msg Setup
4: Scheduler 1: Calendar
2: Alarm Set
3: Calculator
4: Today
5: To Do List
6: World Time
7: Countdown
8: Memo Pad
5: Games 1: ChickenRun
2: MobileCop
6: Voice Tools 1: Voice Memo
2: Voice Answer
7: Setting 1: Sounds
2: Display
3: Auto Retry
4: Answer Mode
5: Roam option
6: Security
7: Data Option
8: Data/Fax Mode
9: Memory Status
8: VAS 1: Internet Portal
2: Games & App
3: Multimedia
4: Ringtone
5: Animation
6: Voice portal
7: SMS info
8: What’s new?
9: Camera 1: Take Photo
2: Record Video
3: Photo Album
4: Video Album
5: MMS
6: Settings
7: Memory Status
Main Menu
(To access, press the
Menu
soft key.)
Licensed by QUALCOMM incorporated under one or more
of the following Patents.
U.S Patent No. 4,901,307 5,056,109 5,099,204
5,101,501 5,103,459 5,107,225
5,109,390
