Samsung Electronics Co SGHC210 Single-Band PCS GSM Phone User Manual C s and Settings Admin
Samsung Electronics Co Ltd Single-Band PCS GSM Phone C s and Settings Admin
Users Manual
* Some of the descriptions in this manual may differ from your
phone, depending on the software installed or your service
provider.
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-0xxxxA
English. 02/2005. Rev 1.0
SGH-C210
User’s Guide
Use road safety at all times
Do not use a hand-held phone while driving. Park
the vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using them
in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.
Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or illegal.
Important safety precautions
1
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is forbidden
to use it, or when it may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear). Avoid
unnecessary contact with the antenna when the phone
is switched on.
Emergency calls
Key in the emergency number for your present
location, then press .
Keep your phone away from small children
Keep the phone and all its parts, including accessories,
out of the reach of small children.
Accessories and batteries
Use only Samsung-approved accessories and
batteries. Use of any unauthorised accessories could
damage your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health and
safety information" on page 57.
• The phone could explode if the battery is
replaced with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.
2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone. To quickly
learn the basics for your phone, please refer to “Get
started” and “Step outside the phone.”
In this guide, the following instruction icons appear:
Indicates that you need to pay careful
attention to the subsequent information
regarding safety or phone features.
Indicates that you can get more information
on the referenced page.
→
Indicates that you need to press the
Navigation keys to scroll to the specified
option and then select it.
[ ]
Indicates a key on the phone. For example,
[]
< >
Indicates a soft key, whose function is
displayed on the phone screen. For example,
<
Menu
>
•Tri-band operation
Use your phone in worldwide GSM networks, in
any of 900, 1800, and 1900 bands.
Special
features of your phone
• Simple, bar-typed design with Intenna
Samsung’s powerful intenna technology allows
the best call quality without an annoying
external antenna.
•WAP browser
Access the wireless web and
access various services and up-
to-the-minute information.
3
Special features of your phone
•Phonebook
Store up to 1000 home, office,
or cellular phone numbers for
your contacts.
• Multimedia Message Service (MMS)
Send and receive MMS messages with a
combination of text, images, and sounds.
• Calendar and To do list
Keep track of your daily and
monthly schedules and tasks.
•Alarm
Use your phone as an alarm
clock to wake you up in the
morning or notify you to an
event.
•Calculator
Perform basic calculations and
do currency conversions.
• Voice recorder
Record memos or sounds.
•Java
Enjoy Java
™
-based embedded
games and download new
games.
4
Contents
Unpack 6
Make sure you have each item
Your phone 6
Buttons, features, and locations
Get started 7
First steps to operating your phone
Install and charge the phone..................................... 7
Power on or off........................................................ 8
Keys and display ..................................................... 9
Access menu functions ............................................ 11
Customise your phone............................................. 12
Make/answer calls .................................................. 14
Step outside the phone 14
Begin with your games, WAP, messages, and other special
features
Play games............................................................ 14
Browse WAP........................................................... 16
Use Phonebook ...................................................... 16
Send messages...................................................... 17
View messages....................................................... 18
Enter text 19
ABC, T9, Number, and Symbol mode
Call functions 22
Advanced calling features
Menu functions 26
All menu options listed
Solve problems 55
Health and safety information 57
Index 64
5
Overview of menu functions
To access Menu mode, press <
Menu
> in Idle mode.
1 SIM AT
p.26
2
2 Call records
p.26
1 Missed calls
2 Received calls
3 Dialled calls
4 Delete all
5 Call time
6 Call cost
*
p.27
p.27
p.27
p.27
p.27
p.28
3 Network services
p.28
1 Call diverting
2 Call barring
3 Call waiting
4 Network selection
5 Caller ID
6 Closed user group
7 Band selection
p.28
p.28
p.30
p.30
p.28
p.30
p.31
4 Sound settings
p.31
1 Ring tone
2 Ring volume
3 Alert type
4 Keypad tone
5 Keypad volume
6 Message tone
7 Alert on call
8 Power on/off
9 Extra tones
p.31
p.31
p.31
p.32
p.32
p.32
p.32
p.32
p.32
5 Messages
p.33
1 Text messages
2 Multimedia
messages
3 Push messages
p.33
p.37
p.39
6 Funbox
p.41
1 WAP browser
2 Games
3 Sounds
4 Images
5 Delete all
6 Memory status
p.41
p.43
p.44
p.44
p.44
p.44
7 Organiser
p.44
1 Alarm
2 Calendar
3 Time & Date
4 Calculator
5 To do list
6 Voice memo
7 Currency exchange
p.45
p.45
p.46
p.46
p.47
p.47
p.48
8 Phonebook
p.49
1 Search
2 New entry
3 Group search
4 Edit group
5 Speed dial
6 Delete all
7 Memory status
p.49
p.49
p.50
p.50
p.50
p.51
p.51
9 Phone settings
p.52
1 Display settings
2 Greeting message
3 Own number
4 Language
5 Security
6 Extra settings
7 Short cut
8 Reset settings
p.52
p.53
p.53
p.53
p.53
p.54
p.55
p.55
*Shows only if supported by your
SIM card.
6
Unpack
Make sure you have each item
You can obtain various accessories from your local
Samsung dealer.
Your phone
Buttons, features, and locations
Phone Travel adapter
Battery User’s manual
The items supplied with your phone and the accessories
at your Samsung dealer may vary, depending on your
country or service provider.
Left soft key
Dial/Confirm
key
Special
function keys
Headset jack
Earpiece
Display
Power on/off/
Menu exit key
Alphanumeric
keys
Right soft key
Microphone
Navigation keys
(Up/Down/Left/
Right)
WAP access/
Confirm key
Cancel/Correct
key
7
Get started
First steps to operating your phone
SIM card information
When you subscribe to a cellular network, you receive
a plug-in SIM (Subscriber Identity Module) card
loaded with your subscription details, such as your
PIN, and available optional services.
Install and charge the phone
Remove the battery.
If the
phone is already
on, first turn it off by
holding [ ].
Insert the SIM card.
Make sure that the
gold-coloured contacts
on the card face down
into the phone.
1 2
Install the battery. Plug the travel
adapter into the
phone.
Plug the adapter into a standard AC wall outlet.
When the phone is completely charged (the
battery icon stops blinking), unplug the adapter
from the power outlet.
3 4
5
6
8
Get started
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the battery low message displays, and
• the empty battery icon ( ) blinks.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
Power on or off
Remove the adapter from the phone.
7
Power on
Do not turn on
the phone when
mobile phone
use is prohibited.
1. Press and hold [ ] to turn on
the phone.
2. If necessary, enter the PIN and
press <
OK
>.
Power off
1. Press and hold [ ].
9
Get started
Keys and display
Key(s) Description
Performs the function indicated on the
bottom line of the display.
In Idle mode, access your favourite menu
options.
p. 55
In Menu mode, scroll through the menu
options.
In Idle mode, launches the Wireless
Application Protocol (WAP) browser.
In Menu mode, works the same functions as
the left soft key.
Sends or answers a call.
In Idle mode, retrieves the last number
dialled, missed, or received.
In Menu mode, select the highlighted menu
option.
Key(s) Description
Deletes characters from the display.
In Menu mode, returns to the previous menu
level.
Ends a call.
Hold down to switch the phone on and off.
In Menu mode, cancels input and returns the
phone to Idle mode.
Enter numbers, letters, and some special
characters.
In Idle mode, hold
[1]
down to access your
voicemail.
Enter special characters.
In Idle mode, hold
[]
down to lock the
keypad. Hold
[]
down to activate or
deactivate Silent mode.
10
Get started
Display
Layout
The display has the three areas.
Icons
Received signal strength
Call diverting feature is active
p. 28
GPRS network
Roaming
Keypad Lock mode is active
p. 13, p. 52
Call in progress
Text and graphics
displays messages,
instructions, and
information you enter.
Soft key function
indicators
shows the current
functions assigned to the
two soft keys.
Icons
displays various icons.
Menu Phonebook
Icons
(continued)
Out of your service area; you
cannot send or receive calls
New text message
New voicemail message
New multimedia message
Active Silent mode or call ringer set
to vibrate
p. 12, p. 31
Mute mode is active
p. 24
Alarm set
Battery power level
11
Get started
Access menu functions
Use the soft
keys
The roles of the soft keys vary
depending on the function you are
using. The bottom line of the
display indicates their current role.
Press the left soft
key to access
Menu
mode.
Press the right soft
key to access the
Phonebook
menu.
Menu Phonebook
Select an
option
1. Press the appropriate soft key.
2. Press the Navigation keys to
move to the next or previous
option.
3. Press <
Select
> or [ ] to
confirm the function displayed
or option highlighted.
4. To exit, choose either of the
following methods:
• Press < > or [
C
] to move
up one level.
• Press [ ] to return to Idle
mode.
Use shortcuts
Press the number key
corresponding to the option you
want.
12
Get started
Customise your phone
1. In Idle mode, press <
Menu
>
and select
Phone settings
→
Language
.
2. Select a language.
1. In Idle mode, press <
Menu
>
and select
Sound settings
→
Ring tone
.
2. Select a ringer melody.
3. Select
Ring volume
.
4. Adjust the volume level.
5. Press <
OK
>.
Display
language
Call ringer
melody and
volume
You can set a wallpaper for the idle
screen.
1. In Idle mode, press <
Menu
>
and select
Phone settings
→
Display settings
→
Wallpaper
→
Wallpaper list
.
2. Select an image.
3. Scroll to the image you want.
4. Press <
Select
>.
You can switch the phone to Silent
mode to avoid disturbing other
people with your phone sounds.
Press and hold [ ] in Idle mode.
Idle mode
wallpaper
Switch to
Silent mode
13
Get started
You can lock the keypad so that
accidental key presses does not
affect the phone functions.
To lock the keypad:
1. In Idle mode, press and hold
[].
2. Press <
Yes
>.
To unlock the keypad:
1. Press <
Unlock
>
2. Press [ ].
Key lock
You can protect the phone against
unauthorised use with a phone
password.
1. In Idle mode, press <
Menu
>
and select
Phone
settings
→
Security
→
Change
password
.
2. Enter the default password,
“00000000” and press <
OK
>.
3. Enter a new 4- to 8- digit
password and press <
OK
>.
4. Enter the new password again
and press <
OK
>.
5. Select
Phone lock
.
6. Select
Enable
.
7. Enter the password and press
<
OK
>.
Phone lock
14
Make/answer calls
Step outside the phone
Begin with your games, WAP, messages, and other special
features
Play games
1. Enter an area code and phone
number.
2. Press [ ].
3. To end the call, press [ ].
1. When the phone is ringing,
press [ ].
2. To end the call, press [ ].
Press [Up] or [Down].
Make a call
Answer a call
Adjust the
volume during
a call
1. Press <
Menu
> and select
Fun
box
→
Games
→
the game you
want.
2. Press [ ].
3. Select game modes or press
any key.
1. Press the Navigation keys to
move the selection.
2. Press [
1
] or [
3
] to make a
horizontal or vertical line of
three identical bubbles.
Select a game
Play
BubbleSmile
15
Step outside the phone
1. Press the Navigation keys to
move the selection to the
position you want to connect
the pipe.
2. Press [ ] to insert a pipe.
3. Repeat until you complete the
pipeline.
1. Press the Navigation keys to
check the field.
2. Press [ ] to go to the stroke
mode
3. Press [ ], and press the key
again when the red bar moves
up to the top of the scale.
This selects the stroke strength.
Play Fun2link
Play MIDPUGC
4. When the red bar falls down to
the line on the scale, press [ ].
This selects the direction.
The nearer the bar to the line,
the more exact the storke.
5. Repeat until you finish the
entire holes.
1. Press [ ] to select a horse.
2. Press the Navigation keys and
then [ ] to select the location
you want to place the horse.
Play
MobileChess
16
Step outside the phone
Browse WAP
Using a built-in WAP (Wireless Access Protocol)
browser, you can get easy access to the wireless web
to receive a variety of updated services and
information and to enjoy downloads of web contents.
Use Phonebook
In Idle mode, press [ ].
• To scroll through browser items,
press [Up] or [Down].
• To select an item, press [ ].
• To return to the previous page,
press [
C
].
• To access browser options,
press <
Menu
>.
Launch the
browser
Navigate
the web
To the phone’s memory:
1. In Idle mode, enter a phone
number and press <
Save
>.
2. Select a number type.
3. Select
Phone
.
4. Enter a name and press <
OK
>.
5. Press <
OK
> to save the entry.
To the SIM card:
1. In Idle mode, enter a phone
number and press <
Save
>.
2. Select a number type.
3. Select
SIM
.
4. Enter a name and press <
OK
>.
5. Press <
OK
> to save the entry.
Add an entry
17
Step outside the phone
Send messages
1. In Idle mode, press
<
Phonebook
>
and select
Search
.
2. Select an entry.
3. Select a number.
4. Press [ ] to dial, or
<
Options
> to access options.
1. In Idle mode, press <
Menu
>
and select
Messages
→
Text
messages
→
Write new
.
2. Enter the message text.
3. Press <
Options
> and select
Save and send
or
Send only
.
4. If you selected
Save and send
,
select a memory location.
5. Enter a destination number and
press <
OK
>.
Find an entry
Send a text
message (SMS)
1. In Idle mode, press <
Menu
>
and select
Messages
→
Multimedia messages
→
Write new
.
2. Enter the message subject
press <
Next
>.
3. Select
Add here
and add
message contents.
4. When you have finished, press
<
Options
> and select
Send
.
5. Select a destination type.
6. Select one of
Phone number
,
E-mail
, or
Phonebook
.
7. Enter a destination number or
an e-mail address, or select
from Phonebook and press
<
OK
>.
Send a
multimedia
message (MMS
)
18
Step outside the phone
View messages
8. To add other destinations,
select
Add destination
and
repeat from step 6.
9. To add destinations of other
types, press < > and repeat
from step 5.
10.When you have finished, select
Send message
.
When a notification appears:
Press <
View
>. The message
displays.
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messages
→
Text
messages
→
Inbox
.
2. Select a message.
Send a
multimedia
message (MMS)
(continued)
View a text
message
When a notification appears:
1. Press <
View
>.
2. Press <
Options
> and select
Retrieve
. The message
displays.
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messages
→
Multimedia messages
→
Inbox
.
2. Select a message.
View a
multimedia
message
19
Enter text
ABC, T9, Number, and Symbol mode
You can enter text for some features such as
messaging, Phonebook, or Organiser, using ABC
mode, T9 mode, Number mode, and Symbol mode.
Changing the text input mode
The text input mode indicator displays when the
cursor is in a text field.
Example:
Writing a text message
Press the right soft key to change the input mode:
•: ABC mode
•: T9 mode
• : Number mode
• No indicator: Symbol mode
Using ABC mode
Press the appropriate key until the character you want
appears on the screen.
Text input mode
indicator
Write new
Options
Characters in order displayed
Key
Upper case Lower case
space
20
Enter text
Tips for using ABC mode
• To enter the same letter twice or to enter a
different letter on the same key, wait for the cursor
to move to the right automatically or press [Right].
Then, enter the next letter.
• Press [ ] to insert a space.
• Press [ ] to change case. Capital lock ( ), Lower
case ( ), and Initial capital ( ) are available.
• Press [Left] or [Right] to move the cursor.
•Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
• Depending on your country, you may be able to
access an input mode for your specific language by
holding [ ].
Using T9 mode
T9 is a predictive text input mode that allows you to
key in any character using single keystrokes.
Entering a word in T9 mode
1. Press [
2
] to [
9
]
to start entering a word. Press
each key once for each letter.
For example, press [
4
], [
3
], [
5
], [
5
], and [
6
] to
enter Hello in T9 mode.
T9 predicts the word that you are typing, and it
may change with each key that you press.
2. Enter the whole word before editing or deleting
characters.
3. When the word displays correctly, go to step 4.
Otherwise, press [
0
] to display alternative word
choices for the keys that you have pressed.
For example, Of and Me use [
6
] and [
3
].
4. Press [ ] to insert a space and enter the next
word.
Tips for using T9 mode
• Press [
1
] to enter periods or apostrophes
automatically.
• Press [ ] to change case in T9 mode. Capital lock
( ), Lower case ( ), and Initial capital ( ) are
available.
• Press [Left] or [Right] to move the cursor.
• Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
Enter text
21
Adding a new word to the T9 dictionary
This feature may not be available for some languages.
1. Enter the word that you want to add.
2. Press [
0
] to display alternative words for your key
presses. When there are no more alternative
words,
Add
displays on the bottom line.
3. Press <
Add
>.
4. Enter the word you want using ABC mode and
press <
OK
>.
Using Number mode
Number mode enables you to enter numbers.
Press the keys corresponding to the digits you want.
Using Symbol mode
Symbol mode enables you to insert symbols.
To Press
display more symbols [Up] or [Down].
select a symbol the corresponding
number key.
clear the symbol(s) [
C
].
insert the symbol(s) <
OK
>.
22
Call functions
Advanced calling features
Making a call
1. In Idle mode, enter the area code and phone
number.
2. Press [ ].
Making an international call
1. In Idle mode, press and hold [
0
]. The
+
character
appears.
2. Enter the country code, area code, and phone
number, then press [ ].
Redialling recent numbers
1. In Idle mode, press [ ] to display the list of
recent numbers.
2. Scroll to the number you want and press [ ].
Making a call from Phonebook
Once you have stored a number in Phonebook, you
can dial the number by selecting it from
Phonebook.
p. 49
You can also use the speed dial feature to assign your
most frequently called numbers to specific number
keys.
p. 50
Dialling a number from the phone’s memory
1. In Idle mode, press and hold [
0
]. A + appears.
2. Enter the location number for the phone number
you want and press [ ].
3. Press [Up] or [Down] to scroll through other
numbers.
4. Press <
Dial
> or [ ] to dial the number you
want.
Dialling a number from the SIM card
1. In Idle mode, enter the location number for the
phone number you want and press [ ].
Press [
C
]
to clear the last digit or press and hold
[
C
] to clear the whole display. You can move the
cursor to edit an incorrect digit.
Call functions
23
2. Press [Up] or [Down] to scroll through other
numbers.
3. Press <
Dial
> or [ ] to dial the number you
want.
Ending a call
Press [ ].
Answering a call
When you receive an incoming call, the phone rings
and displays the incoming call image.
Press [ ] or <
Accept
> to answer the call.
Tips for answering a call
• When
Anykey
answer
in the
Extra
settings
menu is active, you can press any key to answer
a call, except for [ ] and <
Reject
>.
p. 54
•Press <
Reject
> or [ ] to reject a call.
Viewing missed calls
If you have missed calls, the screen displays how
many calls you have missed.
1. Press <
View
>.
2. If necessary, scroll through the missed calls.
3. Press [ ] to dial the number you want.
Using the headset
Use the headset to make or answer calls without
holding the phone.
Connect the headset to the jack on the left side of the
phone.
The buttons on the headset work as listed below:
To Press
redial the last call the button twice.
answer a call and hold the button.
end a call and hold the button.
24
Call functions
Options during a call
You can access a number of functions during a call.
Adjusting the volume during a call
Use [Up/Down] to adjust the earpiece volume during a
call.
Press [Up] to increase the volume level and [Down] to
decrease the volume level.
Placing a call on hold/Retrieving
Press <
Hold
> or <
Unhold
> to place the call on hold
or retrieve the call.
Using the menu functions
Press <
Options
> and select
Menu
.
Switching off the microphone
(
Mute mode
)
You can temporarily switch off your phone’s
microphone so that the other person on the phone
cannot hear you.
Press <
Options
> and select
Mute
or
Unmute
.
Muting or sending key tones
You can turn the key tones off or on.
Press <
Options
> and select
Mute keys
or
Send
keys
.
Sending a sequence of DTMF tones
Dual tone multi-frequency (DTMF) tones are the tones
used in phones for tone dialling.
You can send DTMF tones as a group after entering the
entire number you need to send or retrieving a
number from Phonebook. This feature is helpful for
entering a password or an account number when you
call an automated system, like a banking service.
1. When connected with a teleservice system, press
<
Options
> and select
Send
DTMF
.
2. Enter the number you need to send and press
<
OK
>.
To communicate with answering machines or
computerised telephone systems,
Send keys
must
be selected.
Call functions
25
Using Phonebook
You can access the
Phonebook
menu to locate or
store entries.
p. 49
Press <
Options
> and select
Phonebook
.
Answering a second call
You can answer an incoming call, if your network
supports it and you have activated the call waiting
feature.
p. 30
1. Press [ ] to answer the call. The first call is
automatically put on hold.
2. Press <
Swap
> to switch between the calls.
3. Press <
Options
> and select
End
held
call
to end
the call on hold.
4. To end the current call, press [ ].
Making a multi-party call
Use this feature to allow as many as six people to join
a multi-party call, or conference call.
Your service provider must support multi-party calls
for you to use this feature.
Setting up a multi-party call
1. Call the first participant.
2. Call the second participant. The first call is
automatically put on hold.
3. Press <
Options
> and select
Join
. The first
participant is added to the multi-party call.
4. If desired, call another person or answer an
incoming call.
5. Press <
Options
> and select
Join
.
6. Repeat steps 4 and 5 as desired.
Having a private conversation with one
participant
1. Press <
Options
> and select
Select one
.
2. Select a name or number from the participant list.
3. Select
Private
.
You can talk privately with that person, while the
other participants converse with each other.
4. To return to the multi-party call, press <
Options
>
and select
Join
.
26
Dropping one participant
1. Press <
Options
> and select
Select one
.
2. Select a name or number from the participant list.
3. Press [Down] and select
Remove
.
The participant is dropped from the call, but the
call continues with the other parties.
4. Press [ ] to end the multi-party call.
Menu functions
All menu options listed
SIM AT
(Menu 1)
This menu is available if you use a SIM AT card that
provides additional services, such as news, weather,
sports, entertainment, and location services. Available
services may vary, depending on your service
provider’s plans.
For details, see your SIM card instructions or contact
your service provider.
Call records
(Menu 2)
Use this menu to view the calls you have dialled,
received, or missed, the length of your calls, and the
cost of your calls.
To access this menu, press <
Menu
> in Idle mode and
select
Call records
.
Menu functions
Call records
(Menu 2)
27
Missed calls
(Menu 2.1)
This menu displays the most recently received calls
that you did not answer.
Accessing a call record
1. Select a call record.
2. Press [ ] to dial or <
Options
> to access call
record options.
Using call options
When you press <
Options
>, the following options are
available:
Edit
: change the number of the selected call record.
Delete
: delete the selected call record.
Delete all
: delete all call records
Received calls
(Menu 2.2)
This menu displays the most recent calls you have
received.
Dialled calls
(Menu 2.3)
This menu displays the most recent calls you have
dialled.
Delete all
(Menu 2.4)
Use this menu to delete all of the records in each call
type.
1. Press [ ] to check the call type(s) to be cleared.
2. Press <
Delete
>.
3. Press <
Yes
> twice to confirm the deletion.
Call time
(Menu 2.5)
This menu displays the time log for calls made and
received. The actual time invoiced by your service
provider will vary.
•
Last
call
time
: check the length of your last call.
•
Total
sent
: check the total length of all the calls
you have dialled.
•
Total
received
: check the total length of all the
calls you have received.
28
Menu functions
•
Reset
timers
: reset the call timers. You need to
enter the phone password.
Call cost
(Menu 2.6)
This network feature displays the cost of calls. This
menu is available only if your SIM card supports this
feature. Note that this is not intended to be used for
billing purposes.
•
Last
call
cost
: check the cost of your last call.
•
Total
cost
: check the total cost of all of your calls.
If the total cost exceeds the maximum cost set in
Set
max
cost
, you must reset the counter before
you can make another call.
•
Max
cost
: check the maximum cost limit set in
Set
max
cost
.
•
Reset
counters
: reset the cost counters. You
need to enter your PIN2.
•
Set
max
cost
: set the maximum cost authorised
for your calls. You need to enter your PIN2.
•
Price/Unit
: set the price per unit that is applied
when the cost of your calls is calculated. You need
to enter your PIN2.
Network services
(Menu 3)
Use this menu to access network services. Please
contact your service provider to check their availability
and subscribe to them, if you wish.
To access this menu, press <
Menu
> in Idle mode and
select
Network services
.
Call diverting
(Menu 3.1)
This network service reroutes incoming calls to a
phone number that you specify.
1. Select a call diverting option:
•
Divert always
: divert all calls.
•
Busy
: diver calls when you are on another call.
•
No
reply
: divert calls when you do not answer
the phone.
The password is preset to
00000000
. You can
change this password.
p. 54
Menu functions
Network services
(Menu 3)
29
•
Unreachable
: divert calls when you are not in
an area covered by your service provider or
when your phone is switched off.
•
Cancel
all
: cancel all call diverting options.
2. Select the type of calls to be diverted.
3. To activate call diverting, press <
Activate
>.
Otherwise, press <
Options
> and select
Remove
.
4. Enter the number to which calls are to be diverted
and press <
OK
>.
5. If you selected
No reply
, select the length of time
the network delays before diverting a call and
press <
Select
>.
Call barring
(Menu 3.2)
This network service allows you to restrict your calls.
1. Select a call barring option:
•
All
outgoing
: prohibit all outgoing calls.
•
International
: prohibit international calls.
•
International
except
to
home
: only allow
calls to numbers within the current country
when you are abroad, and to your home
country, defined as where your home network
provider is located.
•
All
incoming
: prohibit incoming calls.
•
Incoming
while
abroad
: prohibit incoming
calls when you use your phone outside of your
home country.
•
Cancel
all
: cancel all call barring settings,
allowing calls to be sent and received normally.
•
Change barring password
: change the call
barring password obtained from your service
provider.
2. Select the type of calls to be barred.
3. Press <
Activate
>. To deactivate call barring,
press <
Deactivate
>.
4. Enter the call barring password supplied by your
service provider and press <
OK
>.
30
Menu functions
Call waiting
(Menu 3.3)
This network service informs you when someone is
trying to reach you while you are on another call.
1. Select the type of calls to which the call waiting
option will apply.
2. Press <
Activate
>. To deactivate call waiting,
press <
Deactivate
>.
Network selection
(Menu 3.4)
This network service allows you to either automatically
or manually select the network used when roaming
outside of your home area.
You can select a network other than your home
network only if there is a valid roaming agreement
between the two.
•
Automatic
: connect to the first available network
when roaming.
•
Manual
: select the network you want.
Caller ID
(Menu 3.5)
This network service allows you to prevent your phone
number from being displayed on the phone of the
person being called. However, some networks do not
allow the user to change this setting.
•
Default
: use the default setting provided by the
network.
•
Hide
number
: ensure your number does not
display on the other person’s phone.
•
Send
number
: send your number each time you
make a call.
Closed user group
(Menu 3.6)
Use this menu to set incoming and outgoing calls to be
restricted to a selected user group. For details about
how to create a closed user group, contact your
service provider.
•
Index list
: list, add, or delete CUG index
numbers. Press <
Options
> to access the options
for setting up an index list.
Menu functions
Sound settings
(Menu 4)
31
•
Outside access
: enable calls to numbers other
than those in the Closed user group. This feature
depends on the nature of your CUG subscription.
•
Default group
: enable the default CUG, if you
have set one with your service provider. When
making a call, you are given the option of using
your default CUG, instead of selecting one from the
list.
•
Deactivate
: deactivate the CUG function, if the
default group is enabled or a CUG index is
selected.
Band selection
(Menu 3.7)
For the phone to make and receive phone calls, it
must register with an available network.
Your phone can handle any of the following types of
networks: GSM 1900 and Combined GSM 900/1800.
The country where you purchased your phone
determines the default band that it uses. When you
travel abroad, you must remember to change to an
appropriate band.
When you select a new band, your phone
automatically searches for all available networks. Your
phone registers with a preferred network within the
band.
Sound settings
(Menu 4)
Use this menu to customise various sound settings.
Ring tone
(Menu 4.1)
Use this menu to select a ring tone for the call ringer.
You can select one of the default ring melodies,
downloaded sounds, or the melodies you have
created.
Ring volume
(Menu 4.2)
Use this menu to adjust the ringer volume.
Alert type
(Menu 4.3)
Use this menu to specify how you are to be informed
of incoming calls.
•
Melody
: the phone rings using the selected ring
tone.
32
Menu functions
•
Vibration
: the phone vibrates but not rings.
•
Vibra+melody
: the phone vibrates three times
and then starts ringing.
Keypad tone
(Menu 4.4)
Use this menu to select the tone that the phone
sounds when you press a key.
Keypad volume
(Menu 4.5)
Use this menu to adjust the keypad tone volume.
Message tone
(Menu 4.6)
Use this menu to select a ring tone or alert type for
incoming messages.
•
SMS tone
: specify how you are informed of a new
SMS message.
•
SMS-CB tone
: specify how you are informed of a
new cell broadcast (CB) message.
•
MMS tone
: specify how you are informed of a new
MMS message.
Alert on call
(Menu 4.7)
Use this menu to select whether or not the phone
informs you when you receive a new message or when
the time for an alarm comes during a call.
Power on/off
(Menu 4.8)
Use this menu to select the melody that the phone
plays when it is switched on or off.
Extra tones
(Menu 4.9)
Use this menu to customise additional tones for the
phone.
•
Error tone
: set the phone to beep when you make
a mistake.
•
Minute
minder
: set the phone to beep every
minute during an outgoing call to keep you
informed of the length of your call.
•
Connect
tone
: set the phone to beep when it is
connected to the system.
Menu functions
Messages
(Menu 5)
33
Messages
(Menu 5)
Use the
Messages
menu to send and receive short
messages, and multimedia messages. You can also
use WAP push message, Voice mail, and Cell broadcast
message features.
To access this menu, press <
Menu
> in Idle mode and
select
Messages
.
Text messages
(Menu 5.1)
Short Message Service (SMS) allows you to send or
receive text messages including pictures, audio clips,
and animated images.
Inbox
(Menu 5.1.1)
You can view received text messages in this menu.
While viewing a message, press <
Options
> to access
the following options:
•
Delete
: delete the message.
•
Send
: forward the message.
•
Text reply
: reply to the sender.
•
Call
back
: call the sender.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Move to phone
: move the message from the SIM
card to the phone’s memory.
•
Move to SIM
: move the message from the
phone’s memory to the SIM card.
•
Select objects
: save images or sounds from the
message into your phone.
Outbox
(Menu 5.1.2)
You can view sent or saved text messages.
While viewing a message, press <
Options
> to access
the following options:
•
Delete
: delete the message.
•
Send
: forward the message.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
The maximum number of characters allowed in a
short message varies by service provider. If your
message exceeds the maximum number of
characters, the phone will split the message.
34
Menu functions
•
Move to phone
: move the message from the SIM
card to the phone’s memory.
•
Move to SIM
: move the message from the
phone’s memory to the SIM card.
•
Select objects
: save images or sounds from the
message into your phone.
Write new
(Menu 5.1.3)
You can create and send a text message.
1. Enter your message.
You can enter up to 918 standard characters, or
approximately 400 Unicode characters, such as ‘â’.
2. Press <
Options
> to access the following options:
•
Text formatting
: change the text attributes.
•
Add objects
: add a sound, melody, picture, or
animated image to the message.
•
Add templates
: retrieve a text template.
•
Add emoticon
: retrieve an emoticon.
•
Add phonebook
: add a Phonebook entry.
•
Add bookmark
: add a web page’s address.
•
Language
: change the language used in T9
input mode.
3. Press <
Options
> and select
Save and send
or
Send only
.
4. If you select
Save and send
, select a memory
location.
5. Enter a destination number.
6. Press <
OK
>
to send the message.
Templates
(Menu 5.1.4)
You can preset maximum 5 templates to write a text
message.
While viewing the templates list, press <
Options
> to
access the following options:
•
Edit
: edit the template.
•
Send message
: send the template as an SMS
message.
•
Delete
: delete the template.
Emoticon template
(Menu 5.1.5)
Your phone provides preset emoticons so that you can
use when writing a message. Use this menu to create
or edit emoticons.
Menu functions
Messages
(Menu 5)
35
While viewing the emoticon list, press <
Options
> to
access the following options:
•
Add
: add a new emoticon.
•
Edit
: edit the selected emoticon.
•
Send
: send a message using the emoticon.
•
Delete
: delete the emoticon.
Settings
(Menu 5.1.6)
Use this menu to customise the SMS settings.
•
Setting x
(where
x
is the setting group number):
each group has its own submenu.
Service centre
: store or changes the number of
your message centre.
Default destination
: store a default destination
number.
Default type
: set the default message type.
Default validity
: set the length of time your
messages are stored in the message centre while
the network attempts to deliver them.
Setting name
: change the name of the setting
group.
•
Common setting
: The following options are
available.
Reply path
: allow the recipient to reply to you
through your message centre.
Delivery reports
: set the network to inform you
when your message has been delivered.
Bearer selection
: select the
GSM
or
GPRS
preferred
bearer type.
Character support
: select a character encoding
type. If you select
Automatic
, the phone switches
the encoding type from GSM-alphabet to Unicode if
you enter a Unicode character. Use of Unicode
encoding will reduce the maximum number of
characters in a message to about half. If this menu
is not shown, your phone provides the Automatic
character encoding by default.
Delete all
(Menu 5.1.7)
Use this menu to delete all of SMS messages in each
message box.
The setting options available in this menu may vary
depending on your service provider.
36
Menu functions
1. Press [ ] to check the message box(es) to be
cleared.
2. Press <
Delete
>.
3. Press <
Yes
> twice to confirm the deletion.
Memory status
(Menu 5.1.8)
Use this menu to check the number of SMS messages
you have stored and total number of SMS messages
you can store in each message box.
Voice mail
(Menu 5.1.9)
Use this menu to store the number of the voice mail
server and access your voice mails.
•
Connect to voice server
: connect to the voice
server to allow you to listen to your messages. You
can also connect to the voice mail server by
pressing and holding [
1
] in Idle mode.
•
Voice server number
: change the voice mail
server name or number.
Broadcast
(Menu 5.1.0)
The Cell Broadcast service delivers short messages on
various topics such as the weather or traffic.
Use this menu to change the settings for the service
and access broadcast messages.
•
Read
: open received messages.
The
Volatile
box saves network messages until
the phone is switched off.
The
Archive
box saves network messages
indefinitely. Press <
Options
> and select
Save
when a text notification appears. The message is
saved in the
Archive
box.
•
Receive
: enable or disable the reception of
broadcast messages.
•
Channel
list
: specify the channels from which you
receive broadcast messages.
•
Language
: select the language in which broadcast
messages display.
Please contact your service provider for details.
You must enter the voice server number before you
can access your voice mails. Your service provider
can give the voice server number.
Menu functions
Messages
(Menu 5)
37
Multimedia messages
(Menu 5.2)
Multimedia Message Service (MMS) delivers messages
containing a combination of text, picture, and sound,
from phone to phone or from phone to e-mail.
Inbox
(Menu 5.2.1)
This menu displays MMS messages that you have
received. The following icons tell you the message
status:
• notification that you have read
• notification that you have not read
• you are retrieving from the server
• the server is processing your request
• the server is failed to send
• you have read
• you have not read
While viewing a message, press <
Options
> to access
the following message options:
•
Delete
: delete the message.
•
Reply
: reply to the sender.
•
Callback
: call the sender.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Forward
: forward the message to another person.
•
Save picture
: save an image from the message
into the
Images
folder.
•
Save sound
: save a sound from the message into
the
Sounds
folder.
•
Properties
: view the message properties.
Outbox
(Menu 5.2.2)
This menu displays MMS messages that you have
sent. The following icons tell you the message status:
• currently being sent
• sent
• your phone couldn’t send
• to be sent
• deferred
When you select a notification, you can access
Retrieve
to retrieve the message from the MMS
server.
38
Menu functions
While viewing a message, press <
Options
> to access
the following options:
•
Delete
: delete the message.
•
Cut address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Send
: send or resend the message.
•
Edit message
: edit the message.
•
Properties
: view the message properties.
Draft
(Menu 5.2.3)
After creating a multimedia message, you can store it
in this message box for sending later.
You can view a message and use the options the same
as in
Outbox
.
Write new
(Menu 5.2.4)
You can create and send an MMS message.
1. Enter a message subject and press <
OK
>.
2. Press <
Options
> and add message contents using
one of the following options:
•
Add text
: add message text.
•
Add picture
: add a picture to the message.
•
Add sound
: add a sound clip to the message.
•
Send
: send the message.
•
Save
: save the message in the
Draft
or
Templates
box.
•
Settings
: change the message settings.
•
Add destination
: enter destination numbers
or addresses.
•
Preview
: view the message you created.
3. If you want to change the added items, highlight
one and press <
Options
> to access the following
options:
•
Edit text
/
/
sound
: edit the text,
picture, or sound.
•
Add page
: add pages. Move to each page by
pressing [Left] or [Right] on the message
screen.
•
Delete
: delete the item from your message.
•
Duration
: set how long one page displays.
After the specified time, the display
automatically scrolls to the next page.
4. When you have finished, select
Send
from the
options.
Menu functions
Messages
(Menu 5)
39
5. Select a destination type (To, Cc, Bcc).
6. Select one of
Phone number
,
E-mail
, or
Phonebook
.
7. Enter a destination number or an e-mail address,
or select a number from Phonebook and press
<
OK
>.
8. To add more destinations, select
Add destination
and repeat from step 6.
9. To enter additional numbers or addresses to other
destination types, press < >and repeat from step
5.
10.When you have finished, select
Send message
.
Templates
(Menu 5.2.5)
This menu stores messages you saved as templates so
that you can use them to create new messages.
While viewing a message template, press <
Options
>
to access the following options:
•
Edit message
: send the message using the
template.
•
Delete
: delete the template.
Delete all
(Menu 5.2.6)
Use this menu to delete all of the messages in each
message box.
1. Press [ ] to check the message box(es) to be
cleared.
2. Press <
Delete
>.
3. Press <
Yes
> twice to confirm the deletion.
Memory status
(Menu 5.2.7)
Use this menu to view the amount of memory
available for MMS messages and memory currently in
use in each message box.
Setup
(Menu 5.2.8)
You can customise the settings for sending and
receiving MMS messages.
•
Delivery report
: set the network to inform you
when your message has been delivered.
•
Read reply
: request a reply from the recipient.
•
Auto download
: set whether or not your phone
retrieves new incoming messages from the MMS
server without notifications.
40
Menu functions
•
Message acceptance
: select the category of
messages you want to receive.
•
Hide ID
: hide your phone number on the
recipient’s phone.
•
Expiry date
: set the length of time your messages
are stored in the message centre.
•
Delivery time
: set the time
delay before
messages are sent.
•
Priority
: set the priority level of your messages.
•
Report allowed
: send a delivery report from the
network to the sender.
•
Page duration
: set how long one page in your
outgoing messages displays. After a specified time,
the display automatically scrolls to the next page.
MMS profile
(Menu 5.2.9)
You can configure required network settings for MMS.
The last profile accessed is automatically activated for
sending or receiving subsequent messages.
•
Profile name
: assign a name to the MMS profile.
•
Connection URL
: enter the address of your MMS
server.
•
Security
: select a data transmission mode.
•
IP address
: enter the gateway address.
•
User name
: assign the user ID.
•
Password
: enter the password.
•
APN
: enter the access point name used for the
address of the MMS server.
Push messages
(Menu 5.3)
Use this menu to access messages from the WAP
server.
•
Inbox
: view push messages you have received.
•
Receive
: determine whether or not your phone
receives push messages.
Never
: the phone rejects push messages.
Always
: the phone receives all push messages.
•
Delete all
: delete all of push messages.
Check with your service provider before you change
any MMS settings on your phone.
Menu functions
Funbox
(Menu 6)
41
Funbox
(Menu 6)
The
Funbox
menu allows you to use the WAP browser,
play Java games, and access images and sounds
stored in the phone’s memory.
To access this menu, press <
Menu
> in Idle mode and
select
Funbox
.
WAP browser
(Menu 6.1)
The Wireless Application Protocol (WAP) browser on
your phone allows you to access the wireless web.
Using the WAP browser, you can access updated
information and a wide variety of media content, such
as wallpapers and ring tones.
Home
(Menu 6.1.1)
Use this menu to connect your phone to the network
and load the homepage of the wireless web service
provider. You can also press [ ] in Idle mode.
Navigating with the WAP browser
Selecting and using browser menu options
From any web page, press <
Menu
> to access the
following browser options:
•
Bookmarks
: open the bookmarks list.
•
Reload
: reload the current page.
•
Home
: go back to the homepage.
•
Go to URL
: enter a URL address manually.
•
Show URL
: view the URL address of the current
web page.
•
Clear cache
: delete information stored in the
cache.
•
Security info
: view security information.
To Press
scroll through browser items [Up] or [Down].
select a browser item [ ].
return to the previous page [
C
].
42
Menu functions
•
Inbox
: read messages received from a web
server.
•
Show image
: view the image on the current web
page in order.
Exiting the WAP browser
Press [ ] to exit the browser.
Favorite
(Menu 6.1.2)
Use this menu to save URL addresses to quickly access
a website.
Adding a bookmark
1. Select an empty location.
2. Enter a URL address and press <
Enter
>.
3. Enter a name for the bookmark and press
<
Enter
>.
Using bookmark options
After saving an item, press <
Options
> to access the
following options:
•
Go
to URL
: access the website.
•
Edit
: edit the address and name of the bookmark.
•
Delete
: delete the bookmark.
http://
(Menu 6.1.3)
Use this menu to manually enter the URL address of a
website and access the website.
Settings
(Menu 6.1.4)
Use this menu to set up servers for the WAP browser.
Contact your service provider for details about your
settings options.
For each server, the following options are available:
•
Profile
name
: assign a name to the server profile.
•
Homepage
URL
: set the address of your
homepage.
•
Security
: select a data transmission mode.
•
Bearer
: select a bearer for each type of network
address accessed;
GPRS
or
Data
.
When the bearer is set to
GPRS
:
•
IP address
: enter the WAP gateway address.
•
User name
: enter the user ID.
•
Password
: enter the password.
•
APN
: enter the access point name of the GPRS
network gateway.
Menu functions
Funbox
(Menu 6)
43
When the bearer is set to
Data
:
•
IP address
: enter the WAP gateway address.
•
Login name
: enter the User ID.
•
Password
: enter the password.
•
Dial-up number
: enter the PPP server phone
number.
•
Data call type
: select a data call type.
Clear cache
(Menu 6.1.5)
Use this menu to clear the cache, which is the
temporary memory that stores the web pages you
have recently accessed.
Games
(Menu 6.2)
You can download MIDlets (Java applications that run
on mobile phones) from various sources using the
WAP browser, and store them in your phone.
Launching a game
1. Select the game you want on the Games list.
2. On the startup screen of the game, you can access
the following options:
•
START GAME
: start a new game.
•
CONTINUE
: continue the last game you
played.
•
HIGH SCORE
: view the high score table. This
option may not be available for some games.
•
HOW TO PLAY
: view how to play the game
and the key functions for the game.
•
OPTION
: switch on or off the game sound.
3. Press [ ] to confirm your selection.
Viewing game information
Scroll to the game you want and press <
Info
>.
Changing DNS settings
You may need to change the DNS setting of the Java
server at your service provider’s instructions.
1. Select
Setting
on the Games list.
Java services may not available, depending on your
service provider.
44
Menu functions
2. Enter the primary address and press <
OK
>.
3. Enter the secondary address and press <
OK
>.
Sounds
(Menu 6.3)
This menu displays sounds downloaded from the
wireless web or received in messages.
While accessing a sound, press <
Options
> to access
the following options:
•
Rename
: change the name of the sound.
•
Delete
: delete the sound.
•
Set as ringtone
: set the sound as your ring tone.
Images
(Menu 6.4)
This menu displays images downloaded from the
wireless web or received in messages.
While accessing an image, press <
Options
> to access
the following options:
•
Rename
: change the name of the image.
•
Delete
: delete the image.
•
Set as wallpaper
: set the image as your
wallpaper for the idle screen.
Delete all
(Menu 6.5)
You can delete all of the downloaded items in the
Games
,
Sounds
, and
Images
folders.
1. Press [ ] to check the folder(s) to be cleared.
2. Press <
Delete
>.
3. Press <
Yes
> twice to confirm the deletion.
Memory status
(Menu 6.6)
You can check the total amount of memory for media
items and the amount of memory currently in use in
each media box.
Organiser
(Menu 7)
The Organiser feature enables you to keep track of
your schedule and tasks, and to make a voice memo.
You can also set the time and date and use convenient
features, such as alarms, calculator, and currency
converter.
To access this menu, press <
Menu
> in Idle mode and
select
Organiser
.
Menu functions
Organiser
(Menu 7)
45
Alarm
(Menu 7.1)
Use this menu to set alarms to ring at a specific time.
Setting an alarm
1. Select the type of alarm.
2. Enter the time for the alarm to sound.
3. Select
AM
or
PM
in 12-hour time format.
4. If you selected
Morning call
in step 1, choose
Monday to friday
or
Monday to saturday
.
Stopping an alarm
• When the alarm sounds, press any key.
• To remove an alarm set, access it, press
<
Options
> and select
Remove alarm
.
• To remove all alarm sets, select
Remove alarm
from the
Alarm
menu.
Setting the alarm to ring even if the phone is
off
From the Alarm screen, select
Autopower
→
Enable
.
If the phone is off when it is time for the alarm to ring,
the phone switches on and sounds the alarm.
Calendar
(Menu 7.2)
Use this menu to consult the calendar, write memos,
or set alarms to act as a reminder.
Writing a memo
1. Select a date on the calendar.
2. Enter your memo and press <
OK
>.
3. Press [ ] to set an alarm to ring on the chosen
day.
Otherwise, press <
Skip
>.
4. Enter the time for the alarm.
To select an alarm melody, press <
Melody
>.
5. Select
AM
or
PM
in 12-hour format.
Your phone is preset to a 24-hour format. You
can change the time format.
p. 46
Your phone is set to a 24-hour format. You can
change the format.
p. 46
46
Menu functions
The colour of the date on the calendar changes to
green to indicate that a memo exists for that date.
Viewing a memo
1. Select a date which has memos from the calendar.
2. Press [Left] or [Right] to view other memos
scheduled for that day.
Using calendar memo options
On the calendar screen, press <
Options
> to access
the following options:
•
Search all
: view all of the memos you created.
•
Delete all
: delete all memos.
•
Go to date
: go to a specific date.
•
Exit
: exit the
Calendar
menu.
While viewing a memo, press <
Options
> to access
the following options:
•
New
: add a new memo.
•
Edit
: edit the memo.
•
Alarm
: set an alarm for the memo.
•
Delete
: delete the memo.
•
Copy to
: copy the memo to another date.
•
Move to
: change the date of the memo.
Time & Date
(Menu 7.3)
Use this menu to change the time and date displayed
on your phone. Before setting the time and date,
specify your time zone in
World time
.
•
Set time
: enter the current time.
•
Set date
: enter the current date.
•
World time
: set your local time zone and find out
what time it is in another part of the world.
•
Time format
: select 12-hour or 24-hour time
format.
Calculator
(Menu 7.4)
Use this menu to perform basic arithmetic functions
such as addition, subtraction, multiplication, and
division.
1. Enter the first number.
Press <
.()
> to insert a decimal point and a
bracket.
Menu functions
Organiser
(Menu 7)
47
2. Press the Navigation keys to access the math
function you want.
3. Enter the second number.
4. Press [ ] to view the result.
To do list
(Menu 7.5)
Use this menu to create tasks and manage them.
Creating the To do list
1. Press <
New
>.
2. Enter the first task and press <
OK
>.
3. Select a priority level.
4. Enter your deadline and press [ ].
Viewing the To do list
When you select the To do list menu, the tasks display
with a check mark, if the task has been done, and a
priority level indicator; for High, for Normal,
and for Low.
While viewing a task or the task list, press <
Options
>
to access the following options:
•
New
: add a new task.
•
Mark
: change the status of the task.
•
Edit
: edit the task.
•
Sort
: sort the task by priority or status.
•
Copy
: copy the task.
•
Copy to calendar
: copy the task to the calendar
as a memo.
•
Delete
: delete the task.
•
Delete all
: delete all tasks.
•
Exit
: exit the
To do list
menu.
Voice memo
(Menu 7.6)
Use this menu to record voice memos. A voice memo
can be up to 30 seconds.
Voice record
(Menu 7.6.1)
1. Press <
Record
> to start recording.
2. Speak into the microphone.
Press
[
] or [ ] to move the cursor.
To change the status of a specific task, press [
]
.
48
Menu functions
3. When you press <
Stop
>, or if the recording time
expires, the following options display:
•
Replay
: play back your memo.
•
Re-record
: discard the memo and records
another one.
•
Save
: save the memo.
•
Quit
: cancel your recording and exits the
Record voice
menu.
4. Select
Save
to save the voice memo.
5. Enter a name of the voice memo and press <
OK
>.
Memo list
(Menu 7.6.2)
Use this menu to access the list of voice memos you
have recorded. Select a memo to play it
Press <
Options
> to access the following options:
•
Play
: play back your voice memo.
•
Send
: send the voice memo via MMS.
•
Rename
: change the name of the voice memo.
•
Information
: view the properties of the voice
memo.
•
Delete
: delete the voice memo.
Delete all
(Menu 7.6.3)
Use this menu to delete all of the voice memos you
have recorded at one time.
Memory status
(Menu 7.6.4)
You can check the total amount of memory and the
amount of memory currently in use for voice memos.
Currency exchange
(Menu 7.7)
Use this menu to do currency conversions.
1. Enter the rate of foreign currency and press
<
OK
>.
2. Enter the amount of the source currency you want
to convert and press <
OK
>.
The amount you entered and its equivalent value
in the foreign currency display.
Menu functions
Phonebook
(Menu 8)
49
Phonebook
(Menu 8)
You can store phone numbers on your SIM card and in
your phone’s memory. The SIM card and phone’s
memory are physically separate, but they are used as
a single entity called Phonebook.
To access this menu, press <
Menu
> in Idle mode and
select
Phonebook
, or press <
Phonebook
>.
Search
(Menu 8.1)
Use this menu to search for numbers in Phonebook.
Finding an entry
1. Enter the first few letters of the name that you
want to find.
2. Select the name you want from the list.
3. Press [ ] to dial the number, or <
Options
> to
access Phonebook options.
Using Phonebook options
While viewing an entry in Phonebook, press
<
Options
> to access the following options:
•
Paste
: paste the number into the normal dialling
mode.
•
Edit
: edit the entry information.
•
Delete
: delete the number from Phonebook.
•
Copy
: copy the number to the phone’s memory or
SIM card.
•
Caller group
: assign a caller group.
•
Add entry
: add a new entry.
New entry
(Menu 8.2)
Use this menu to add a new entry to Phonebook.
Storing an entry in the phone’s memory
1. Select a number type.
2. Select
Phone
.
3. Enter a name and press
<OK
>.
4. Enter a number or an e-mail address and press
<
Save
>.
5. Change the location number, if you want, and
press <
OK
>.
50
Menu functions
Storing an entry on the SIM card
1. Select a number type.
2. Select
SIM
.
3. Enter a name and press <
OK
>.
4. Enter a number and press <
Save
>
5. Change the location number, if you want, and
press <
OK
>.
Group search
(Menu 8.3)
Use this menu to search your entries in Phonebook in
caller groups.
1. Enter the first few letters of the group name.
2. Select a group and press <
View
>.
3. Select the name you want.
4. Press [ ] to dial the number or <
Options
> to
access Phonebook options.
Edit group
(Menu 8.4)
Use this menu to edit your caller groups’ properties.
From the group list, press <
Options
> to access the
following options:
•
Call ring tone
: set a ring tone for incoming calls
from the group.
•
SMS tone
: set a ring tone for incoming messages
from the group.
•
Graphic
: set a graphic icon for incoming calls from
the group.
•
Group name
: assign a name to the group.
Speed dial
(Menu 8.5)
Use this menu to assign speed dial numbers (2 to 9) to
eight of your most frequently called numbers.
Assigning speed dial entries
1. Select a key location from
2
to
9
. Key
1
is reserved
for your voice mail server.
2. Select the name you want from the Phonebook list.
3. Select the number you want.
Menu functions
Phonebook
(Menu 8)
51
Managing speed dial entries
While viewing the Speed dial screen, press
<
Options
> to access the following options:
•
Change
: assign a different number to an assigned
key.
•
Delete
: delete the setting for the key.
•
Delete all
: delete the settings for all the keys.
•
Number
: view the number assigned to the key.
Dialling speed dial entries
Press and hold the appropriate key in Idle mode.
Delete all
(Menu 8.6)
Use this menu to delete all of the entries from
Phonebook.
1. Press [ ] to check the location(s) to be cleared.
2. Press <
Delete
>.
3. Enter the phone password and press <
OK
>.
4. Press <
Yes
> twice to confirm the deletion.
Memory status
(Menu 8.7)
Use this menu to check the total number of entries
you can store and the number of the entries you have
stored in Phonebook.
SDN
(Menu 8.8)
This menu is available if your SIM card supports
Service Dialling Numbers (SDN). Use this menu to
view the list of SDNs assigned by your service
provider, including emergency numbers, directory
enquiries, and voice mail numbers.
Scroll to the number you want and press <
Dial
> or
[].
52
Menu functions
Phone settings
(Menu 9)
Use this menu to customise your phone settings. You
can also reset the settings to their default values.
To access this menu, press <
Menu
> in Idle mode and
select
Phone settings
.
Display settings
(Menu 9.1)
Use this menu to change settings for the display and
light.
Wallpaper
(Menu 9.1.1)
You can change the background image and the
settings for the text of Idle mode.
•
Wallpaper list
: select a background image.
•
Text display
: determine the phone displays the
time and date.
•
Text colour
: select a colour of the text
Keypad lock
(Menu 9.1.2)
Your phone is equipped with Keypad Lock function, to
prevent accidental key presses from affecting the
phone.
Use this menu to set whether the phone locks the
keypad automatically if no key has been pressed
within a given period of time, or you lock the keypad
manually by holding [ ].
Contrast
(Menu 9.1.3)
You can adjust the brightness of the display for
varying lighting conditions.
Backlight
(Menu 9.1.4)
You can select the length of time the backlight and the
display stay on.
•
On
: select the length of time the backlight stays
on.
•
Dim
: select the length of time the display is in
Dimming mode after the backlight turns off. After a
specified time, the display turns off and the
analogue clock displays.
Graphic logo
(Menu 9.1.5)
Use this menu to display your service provider’s logo
instead of its name.
Menu functions
Phone settings
(Menu 9)
53
Greeting message
(Menu 9.2)
Use this menu to enter the greeting that is displayed
briefly when the phone is switched on.
Own number
(Menu 9.3)
Use this feature to check your phone numbers, or to
assign a name to each of the numbers. Changes made
here do not affect the actual subscriber numbers on
your SIM card.
Language
(Menu 9.4)
Use this menu to select one of several languages for
the display text.
When you select
Automatic
, the phone uses the
language that the SIM card uses.
Security
(Menu 9.5)
Use this menu to protect the phone against
unauthorised use by managing the several access
codes of your phone and SIM card.
PIN check
(Menu 9.5.1)
The 4-to 8-digit PIN (Personal Identification Number)
protects your SIM card against unauthorised use.
When this feature is enabled, the phone requires your
PIN each time it is switched on.
Change PIN
(Menu 9.5.2)
Use this menu to change your PIN. The PIN Check
feature must be enabled to use this feature.
Phone lock
(Menu 9.5.3)
The Phone lock feature locks the phone from
unauthorised use.
When this feature is enabled, you must enter a 4- to
8-digit phone password each time the phone is
switched on.
The password is preset to
00000000
. To change the
password, use the
Change password
menu.
If you enter an incorrect PIN /PIN 2 three times in
succession, the SIM card is blocked. To unblock it
you need to enter your PUK/PUK2 (Personal
Unblocking Key). The codes are supplied by your
network operator.
54
Menu functions
Change Password
(Menu 9.5.4)
Use this menu to change your phone password. The
password is preset to
00000000
.
Privacy
(Menu 9.5.5)
Use this menu to lock your media contents, including
MMS messages, voice memos, images, and sounds.
1. Press [ ] to check the item(s) to be locked.
2. Press <
OK
> to lock the marked items.
3. Enter the phone password and press <
OK
>.
To access a locked item, you need to enter the phone
password.
SIM lock
(Menu 9.5.6)
The SIM lock feature allows your phone to work only
with the current SIM by assigning a SIM lock code. You
must enter the SIM lock code to use a different SIM
card.
FDN mode
(Menu 9.5.7)
If supported by your SIM card, Fixed Dialling Number
(FDN) mode restricts your outgoing calls to a limited
set of phone numbers. When this feature is enabled,
you can make calls only to phone numbers stored on
the SIM card. To use this feature, you must enter your
PIN2.
Change PIN2
(Menu 9.5.8)
If supported by your SIM card, the Change PIN2
feature changes your current PIN2.
Extra settings
(Menu 9.6)
You can turn the automatic redialling or answering
features on or off.
•
Auto redial
: make up to ten attempts to redial a
phone number after an unsuccessful call.
•
Anykey
answer
: answer an incoming call by
pressing any key, except [ ] or <
Reject
>.
When this option is set to
Off
, you must press
[] or <
Accept
> to answer a call.
55
Short cut
(Menu 9.7)
You can use the Navigation keys as shortcut keys to
access specific menus directly from Idle mode. Use
this menu to change the shortcut assignments for the
keys.
1. Select the key to be used as a shortcut key.
2. Select the menu that will be assigned to the key.
Reset settings
(Menu 9.8)
Use this menu to reset the phone to its default
settings.
Enter the 4- to 8-digit phone password and press
<
OK
>.
Solve problems
To save the time and expense of an unnecessary service
call, perform the simple checks in this section before
contacting a service professional.
When you switch on your phone, the following
messages may appear:
“Insert SIM card”
• Be sure that the SIM card is correctly installed.
“Phone locked Enter password”
• The automatic locking function has been enabled.
You must enter the phone’s password before you
can use the phone.
“Enter PIN”
• You are using your phone for the first time. You
must enter the PIN supplied with the SIM card.
• The PIN Check feature is enabled. Every time the
phone is switched on, the PIN has to be entered.
To disable this feature, use the
PIN check
menu.
The password is preset to
00000000
. You can
change this password.
p. 54
56
Solve problems
“Enter PUK”
• The PIN code has been entered incorrectly three
times in succession, and the phone is now blocked.
Enter the PUK supplied by your service provider.
“No service,” “Network failure,” or “Not done”
displays
• The network connection has been lost. You may be
in a weak signal area. Move and try again.
• You are trying to access an option for which you
have no subscription with your service provider.
Contact the service provider for further details.
You have entered a number but it was not
dialled
• Be sure that you have pressed [ ].
• Be sure you have accessed the right cellular
network.
• Be sure that you have not set an outgoing call
barring option.
Your correspondent cannot reach you
• Be sure your phone is switched on. ([ ] pressed
for more than one second.)
• Be sure you are accessing the correct cellular
network.
• Be sure that you have not set an outgoing call
barring option.
Your correspondent cannot hear you speaking
• Be sure you have switched off the microphone.
• Be sure you are holding the phone close enough to
your mouth. The microphone is located at the
bottom of the phone.
The phone starts beeping and “Low battery”
flashes on the display
• Your battery is insufficiently charged. Recharge the
battery.
57
The audio quality of the call is poor
• Check the signal strength indicator on the display
( ). The number of bars indicates the signal
strength from strong ( ) to weak ( ).
• Try moving the phone slightly or moving closer to a
window if you are in a building.
No number is dialled when you re-call a
Contacts entry
• Use the Phonebook Search feature to ensure the
number has been stored correctly.
• Re-store the number, if necessary.
If the above guidelines do not help you to
solve the problem, take note of:
• The model and serial numbers of your phone
•Your warranty details
• A clear description of the problem
Then contact your local dealer or Samsung after-sales
service.
Health and safety information
125
Health and Safety
Information
Exposure to Radio Frequency (RF) Signals
Your wireless phone is a radio transmitter and receiver.
It is designed and manufactured not to exceed the
emission limits for exposure to radio frequency (RF)
energy set by the Federal Communications Commission
(FCC) of the U.S. Government. These limits are part of
comprehensive guidelines and establish permitted
levels of RF energy for the general population. The
guidelines are based on the safety standards that were
developed by independent scientific organizations
through periodic and through evaluation of scientific
studies.
The standards include a substantial safety margin
designed to assure the safety of all persons, regardless
of age and health.
The exposure standard for wireless phones employs a
unit of measurement known as Specific Absorption
Rate (SAR). The SAR limit set by the FCC is 1.6W/kg *.
*In the U.S. and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kg (W/kg)
averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give
additional protection for the public and to account for any variations in measurements.
safety-end-NorthA 1/27/03 2:05 PM Page 125
126
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
127
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
SAR tests are conducted using standard operating
positions specified by the FCC with the phone
transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is
determined at the highest certified power level, the
actual SAR level of the phone while operating can be
well below the maximum value. This is because the
phone is designed to operate at multiple power levels
so as to use only the power required to reach the
network. In general, the closer you are to a wireless
base station antenna, the lower the power output of
the phone.
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that
it does not exceed the limit established by the
government-adopted requirement for safe exposure.
The tests are performed in positions and locations
(e.g., at the ear and worn on the body) as required by
the FCC for each model. While there may be
differences between the SAR levels of various phones
and at various positions, they all meet the government
requirement.
The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as in
compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC
and can be found under the Display Grant section of
http://www.fcc.gov/oet/fccid after searching on FCC ID
printed in the label on the phone.
FCC certification information for this model phone is
attached separation paper.
For Body Operation
To maintain compliance with FCC RF exposure require-
ments, use only belt-clips, holsters or similar accessories
that maintain a 1.5 cm. separation distance between the
user's body and the back of the phone, including the
antenna. The use of belt-clips, holsters and similar
accessories should not contain metallic components in
its assembly. The use of accessories that do not satisfy
these requirements may not comply with FCC RF
exposure requirements, and should be avoided.
For more Information concerning exposure to radio
frequency signals, see the following websites:
Federal Communications Commission (FCC)
http://www.fcc.gov/rfsafety
Cellular Telecommunications Industry Association (CTIA):
http://www.wow-com.com
U.S.Food and Drug Administration (FDA)
http://www.fda.gov/cdrh/consumer
World Health Organization (WHO)
http://www.who.int/peh-emf/en
safety-end-NorthA 1/27/03 2:05 PM Page 126
129
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
• Do not leave the battery in hot or cold places, such
as in a car in summer or winter conditions, as you
will reduce the capacity and lifetime of the battery.
Always try to keep the battery at room
temperature. A phone with a hot or cold battery
may temporarily not work, even when the battery
is fully charged. Li-ion batteries are particularly
affected by temperatures below 0 °C (32 °F).
• Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object (coin,
clip or pen) causes a direct connection between
the + and – terminals of the battery (metal strips
on the battery), for example when you carry a
spare battery in a pocket or bag. Short-circuiting
the terminals may damage the battery or the
object causing the short-circuiting.
• Dispose of used batteries in accordance with local
regulations. Always recycle. Do not dispose of
batteries in a fire.
Road Safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime.
But an important responsibility accompanies the
benefits of wireless phones, one that every user
must uphold.
When driving a car, driving is your first responsibility.
When using your wireless phone behind the wheel of
a car, practice good common sense and remember
the following tips.
128
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
Precautions When Using Batteries
• Never use any charger or battery that is damaged in
any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network’s base
station, it uses less power; talk and standby time
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
• Battery charging time depends on the remaining
battery charge and the type of battery and charger
used. The battery can be charged and discharged
hundreds of times, but it will gradually wear out.
When the operation time (talk time and standby
time) is noticeably shorter than normal, it is time to
buy a new battery.
• If left unused, a fully charged battery will discharge
itself over time.
• Use only Samsung-approved batteries and recharge
your battery only with Samsung-approved chargers.
When a charger is not in use, disconnect it from the
power source. Do not leave the battery connected to
a charger for more than a week, since overcharging
may shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling or
warming first.
safety-end-NorthA 1/27/03 2:05 PM Page 128
131
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
130
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
7. Do not engage in stressful or emotional
conversations that may be distracting. Make the
people with whom you are talking aware that you
are driving and suspend conversations that have
the potential to divert your attention from the
road.
8. Use your wireless phone to call for help. Dial the
emergency number in the case of fire, traffic
accident or medical emergencies. Remember, it is
a free call on your wireless phone!
9. Use your wireless phone to help others in
emergencies. If you see a car accident, crime in
progress or other serious emergency where lives
are in danger, call the emergency number, as you
would want others to do for you.
10. Call roadside assistance or a special non-
emergency wireless assistance number when
necessary. If you see a broken-down vehicle
posing no serious hazard, a broken traffic signal,
a minor traffic accident where no one appears
injured, or a vehicle you know to be stolen, call
roadside assistance or any other special non-
emergency wireless number.
1. Get to know your wireless phone and its features,
such as speed dial and redial. If available, these
features help you to place your call without taking
your attention off the road.
2. When available, use a hands-free device. If
possible, add an extra layer of convenience and
safety to your wireless phone with one of the
many hands-free accessories available today.
3. Position your wireless phone within easy reach. Be
able to access your wireless phone without
removing your eyes from the road. If you get an
incoming call at an inconvenient time, let your
voice mail answer it for you.
4. Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy
traffic or hazardous weather conditions. Rain,
sleet, snow, ice and even heavy traffic can be
hazardous.
5. Do not take notes or look up phone numbers while
driving. Jotting down a To Do list or flipping
through your phonebook takes your attention away
from your primary responsibility, driving safely.
6. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan calls when your car
will be stationary. If you need to make a call while
moving, dial only a few numbers, check the road
and your mirrors, then continue.
safety-end-NorthA 1/27/03 2:05 PM Page 130
133
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonnHHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
Wireless Technology Research.
Persons with pacemakers:
• Should always keep the phone more than 15 cm (6
inches) from their pacemaker when the phone is
switched on
• Should not carry the phone in a breast pocket
• Should use the ear opposite the pacemaker to
minimize potential interference
If you have any reason to suspect that interference is
taking place, switch off your phone immediately.
Hearing Aids
Some digital wireless phones may interfere with
some hearing aids. In the event of such interference,
you may wish to consult your hearing aid
manufacturer to discuss alternatives.
Other Medical Devices
If you use any other personal medical devices,
consult the manufacturer of your device to determine
if it is adequately shielded from external RF energy.
Your physician may be able to assist you in obtaining
this information. Switch off your phone in health care
facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care
facilities may be using equipment that could be
sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
Operating Environment
Remember to follow any special regulations in force
in any area and always switch off your phone
whenever it is forbidden to use it, or when it may
cause interference or danger.
When connecting the phone or any accessory to
another device, read its user’s guide for detailed
safety instructions. Do not connect incompatible
products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation
of the equipment and for the safety of personnel, it is
recommended that the equipment should only be
used in the normal operating position (held to your
ear with the antenna pointing over your shoulder).
Electronic Devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against
the RF signals from your wireless phone. Consult the
manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be maintained
between a wireless phone and a pacemaker to avoid
potential interference with the pacemaker. These
recommendations are consistent with the
independent research and recommendations of
safety-end-NorthA 1/27/03 2:05 PM Page 132
135
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
134
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
Emergency Calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well
as user-programmed functions, which cannot guarantee
connection in all conditions. Therefore, you should
never rely solely on any wireless phone for essential
communications (medical emergencies, for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not be
possible on all wireless phone networks or when
certain network services and/or phone features are in
use. Check with local service providers.
To make an emergency call, proceed as follows.
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location. Emergency numbers vary by
location.
3. Press the <SEND> key.
If certain features are in use (call barring, for example),
you may first need to deactivate those features before
you can make an emergency call. Consult this
document and your local cellular service provider.
When making an emergency call, remember to give all
the necessary information as accurately as possible.
Remember that your phone may be the only means of
communication at the scene of an accident; do not cut
off the call until given permission to do so.
representative regarding your vehicle.
You should also consult the manufacturer of any
equipment that has been added to your vehicle.
Posted Facilities
Switch off your phone in any facility where posted
notices require you to do so.
Potentially Explosive Atmospheres
Switch off your phone when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause an
explosion or fire resulting in bodily injury or even
death.
Users are advised to switch off the phone while at a
refueling point (service station). Users are reminded
of the need to observe restrictions on the use of
radio equipment in fuel depots (fuel storage and
distribution areas), chemical plants or where blasting
operations are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas
(such as propane or butane), areas where the air
contains chemicals or particles, such as grain, dust
or metal powders, and any other area where you
would normally be advised to turn off your vehicle
engine.
safety-end-NorthA 1/27/03 2:05 PM Page 134
137
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonnHHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for
many years.
• Keep the phone and all its parts and accessories
out of the reach of small children’s.
• Keep the phone dry. Precipitation, humidity and
liquids contain minerals that will corrode
electronic circuits.
• Do not touch the phone with a wet hand while it is
charging. Doing so may cause an electric shock to
you or damage to the phone.
• Do not use or store the phone in dusty, dirty areas,
as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the phone,
which may damage the phone’s electronic circuit
boards.
Other Important Safety Information
• Only qualified personnel should service the phone or
install the phone in a vehicle. Faulty installation or
service may be dangerous and may invalidate any
warranty applicable to the device.
• Check regularly that all wireless phone equipment in
your vehicle is mounted and operating properly.
• Do not store or carry flammable liquids, gases or
explosive materials in the same compartment as the
phone, its parts or accessories.
• For vehicles equipped with an air bag, remember
that an air bag inflates with great force. Do not
place objects, including both installed or portable
wireless equipment in the area over the air bag or in
the air bag deployment area. If wireless equipment
is improperly installed and the air bag inflates,
serious injury could result.
• Switch off your phone before boarding an aircraft.
The use of wireless phones in aircraft may be
dangerous to the operation of the aircraft, and is
illegal.
• Failure to observe these instructions may lead to the
suspension or denial of telephone services to the
offender, or legal action, or both.
safety-end-NorthA 1/27/03 2:05 PM Page 136
139
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
138
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
• Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the phone. Wipe it with a
soft cloth slightly dampened in a mild soap-and-water
solution.
• Do not paint it. Paint can clog the device’s moving
parts and prevent proper operation.
• Do not put the phone in or on heating devices, such as
a microwave oven, a stove or a radiator. The phone
may explode when overheated.
• Use only the supplied or an approved replacement
antenna. Unauthorized antennas or modified
accessories may damage the phone and violate
regulations governing radio devices.
• If the phone, battery, charger or any accessory is not
working properly, take it to your nearest qualified
service facility. The personnel there will assist you,
and if necessary, arrange for service.
Acknowledging Special Precautions and the FCC
and Industry Canada Notice
Cautions
Modifications not expressly approved by the party
responsible for compliance could void the user's authority
to operate the equipment. FCC Compliance Information
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received.
Including interference that may cause undesired
operation.
Information to User
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following measures:
safety-end-NorthA 1/27/03 2:05 PM Page 138
141
AAppppeennddiixx
Appendix A: CERTIFICATION INFORMATION (SAR)
THIS MODEL PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR
EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver.
It is designed and manufactured not to exceed the
emission limits for exposure to radio frequency(RF)
energy set by the Federal Communications Commission
of the U.S. Government. These limits are part of
comprehensive guidelines and establish permitted
levels of RF energy for the general population. The
guidelines are based on safety standards that were
developed by independent scientific organizations
through periodic and thorough evaluation of scientific
studies. The standards include a substantial safety
margin designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless mobile phones
employs a unit of measurement known as the Specific
Absorption Rate(SAR). The SAR limit set by the FCC is
1.6 W/kg. SAR Tests are conducted using standard
operating positions accepted by the FCC with the
phone transmitting at its highest certified power level
in all tested frequency bands. Although the SAR is
determined at the highest certified power level, the
actual SAR level of the phone while operating can be
well below the maximum value. This is because the
phone is designed to operate at multiple power levels
so as to use only the power required to reach the
network. In general, the closer you are to a wireless
base station antenna, the lower the power output.
140
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/ TV
technician for help.
safety-end-NorthA 1/27/03 2:05 PM Page 140
143
Appendix B: Guide to Safe and Responsible Wireless
Phone Use
Cellular Telecommunications & Internet Association
“Safety is the most important call you will ever make.”
A Guide to Safe and Responsible Wireless Phone Use
TENS OF MILLIONS OF PEOPLE IN THE U.S. TODAY TAKE
ADVANTAGE OF THE UNIQUE COMBINATION OF
CONVENIENCE, SAFETY AND VALUE DELIVERED BY THE
WIRELESS TELEPHONE. QUITE SIMPLY, THE WIRELESS
PHONE GIVES PEOPLE THE POWERFUL ABILITY TO
COMMUNICATE BY VOICE-ALMOST ANYWHERE,
ANYTIME-WITH THE BOSS, WITH A CLIENT, WITH THE
KIDS, WITH EMERGENCY PERSONNEL OR EVEN WITH
THE POLICE. EACH YEAR, AMERICANS MAKE BILLIONS
OF CALLS FROM THEIR WIRELESS PHONES, AND THE
NUMBERS ARE RAPIDLY GROWING.
But an important responsibility accompanies those
benefits, one that every wireless phone user must
uphold. When driving a car, driving is your first
responsibility. A wireless phone can be an invaluable
tool, but good judgment must be exercised at all times
while driving a motor vehicle-whether on the phone or
not.
The basic lessons are ones we all learned as teenagers.
Driving requires alertness, caution and courtesy. It
requires a heavy dose of basic common sense-keep your
head up, keep your eyes on the road, check your mirrors
frequently and watch out for other drivers. It requires
obeying all traffic signs and signals and staying within
the speed limit. It means using seatbelts and requiring
other passengers to do the same.
142
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that it
does not exceed the limit established by the government-
adopted requirement for safe exposure. The tests are
performed in positions and locations(e.g., at the ear and
worn on the body) as required by the FCC for each
model.
The highest SAR values for this model phone as reported
to the FCC are Head: 0.205W/Kg, Body-worn: 0.356W/Kg.
The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as
in compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC
and can be found under the Display Grant section of
http://www.fcc.gov/oet/fccid after searching on FCC ID
A3LSGHC210.
In the United States and Canada, the SAR limit for
mobile phones used by the public is 1.6
watts/kilogram(W/kg) averaged over one gram of tissue.
The standard incorporates a substantial margin of safety
to give additional protection for the public and to
account for any variations in measurements.
AAppppeennddiixxAAppppeennddiixx
safety-end-NorthA 1/27/03 2:05 PM Page 142
145
4. Suspend conversations during hazardous driving
conditions or situations. Let the person you are speaking
with know you are driving; if necessary, suspend the call
in heavy traffic or hazardous weather conditions. Rain,
sleet, snow and ice can be hazardous, but so is heavy
traffic. As a driver, your first responsibility is to pay
attention to the road.
5. Do not take notes or look up phone numbers while
driving. If you are reading an address book or business
card, or writing a “to do” list while driving a car, you are
not watching where you are going. It’s common sense.
Don’t get caught in a dangerous situation because you
are reading or writing and not paying attention to the
road or nearby vehicles.
6. Dial sensibly and assess the traffic; if possible, place
calls when you are not moving or before pulling into
traffic. Try to plan your calls before you begin your trip or
attempt to coincide your calls with times you may be
stopped at a stop sign, red light or otherwise stationary.
But if you need to dial while driving, follow this simple
tip-dial only a few numbers, check the road and your
mirrors, then continue.
7. Do not engage in stressful or emotional conversations
that may be distracting. Stressful or emotional
conversations and driving do not mix-they are distracting
and even dangerous when you are behind the wheel of a
car. Make people you are talking with aware you are
driving and if necessary, suspend conversations which
have the potential to divert your attention from the road.
144
But with wireless phone use, driving safely means a
little more. This brochure is a call to wireless phone
users everywhere to make safety their first priority when
behind the wheel of a car. Wireless telecommunications
is keeping us in touch, simplifying our lives, protecting us
in emergencies and providing opportunities to help
others in need. When it comes to the use of wireless
phones, safety is your most important call.
Wireless Phone “Safety Tips”
Below are safety tips to follow while driving and using a
wireless phone which should be easy to remember.
1. Get to know your wireless phone and its features such
as speed dial and redial. Carefully read your instruction
manual and learn to take advantage of valuable features
most phones offer, including automatic redial and
memory. Also, work to memorize the phone keypad so
you can use the speed dial function without taking your
attention off the road.
2. When available, use a hands free device. A number of
hands free wireless phone accessories are readily
available today. Whether you choose an installed
mounted device for your wireless phone or a speaker
phone accessory, take advantage of these devices if
available to you.
3. Position your wireless phone within easy reach. Make
sure you place your wireless phone within easy reach
and where you can grab it without removing your eyes
from the road. If you get an incoming call at an
inconvenient time, if possible, let your voice mail answer
it for you.
AAppppeennddiixxAAppppeennddiixx
safety-end-NorthA 1/27/03 2:05 PM Page 144
146
8. Use your wireless phone to call for help. Your wireless
phone is one of the greatest tools you can own to
protect yourself and your family in dangerous situations-
with your phone at your side, help is only three numbers
away. Dial 9-1-1 or other local emergency number in the
case of fire, traffic accident, road hazard or medical
emergency. Remember, it is a free call on your wireless
phone!
9. Use your wireless phone to help others in
emergencies. Your wireless phone provides you a perfect
opportunity to be a “Good Samaritan” in your community.
If you see an auto accident, crime in progress or other
serious emergency where lives are in danger, call 9-1-1
or other local emergency number, as you would want
others to do for you.
10. Call roadside assistance or a special wireless non-
emergency assistance number when necessary. Certain
situations you encounter while driving may require
attention, but are not urgent enough to merit a call for
emergency services. But you still can use your wireless
phone to lend a hand. If you see a broken-down vehicle
posing no serious hazard, a broken traffic signal, a minor
traffic accident where no one appears injured or a
vehicle you know to be stolen, call roadside assistance
or other special non-emergency wireless number.
Careless, distracted individuals and people driving
irresponsibly represent a hazard to everyone on the road.
Since 1984, the Cellular Telecommunications Industry
Association and the wireless industry have conducted
educational outreach to inform wireless phone users of
147
their responsibilities as safe drivers and good citizens.
As we approach a new century, more and more of us will
take advantage of the benefits of wireless telephones.
And, as we take to the roads, we all have a
responsibility to drive safely.
“The wireless industry reminds you to use your phone
safely when driving.”
Cellular Telecommunications & Internet Association
For more information, please call 1-888-901-SAFE.
For updates: http://www.wow-
com.com/consumer/issues/driving/articles.cfm?ID=85
AAppppeennddiixxAAppppeennddiixx
safety-end-NorthA 1/27/03 2:05 PM Page 146
149
low level RF that does not produce heating effects
causes no known adverse health effects. Many studies
of low level RF exposures have not found any biological
effects. Some studies have suggested that some
biological effects may occur, but such findings have not
been confirmed by additional research. In some cases,
other researchers have had difficulty in reproducing
those studies, or in determining the reasons for
inconsistent results.
3. What is FDA’s role concerning the safety of wireless
phones?
Under the law, FDA does not review the safety of
radiation-emitting consumer products such as wireless
phones before they can be sold, as it does with new
drugs or medical devices. However, the agency has
authority to take action if wireless phones are shown to
emit radiofrequency energy (RF) at a level that is
hazardous to the user. In such a case, FDA could require
the manufacturers of wireless phones to notify users of
the health hazard and to repair, replace or recall the
phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA
regulatory actions, FDA has urged the wireless phone
industry to take a number of steps, including the
following:
Support needed research into possible biological effects
of RF of the type emitted by wireless phones;
Design wireless phones in a way that minimizes any RF
exposure to the user that is not necessary for device
function; and
Cooperate in providing users of wireless phones with the
148
Appendix C: Consumer Update on Wireless Phones
U.S. Food and Drug Administration
1. What kinds of phones are the subject of this update?
The term wireless phone refers here to hand-held
wireless phones with built-in antennas, often called cell,
mobile, or PCS phones. These types of wireless phones
can expose the user to measurable radiofrequency
energy (RF) because of the short distance between the
phone and the user s head. These RF exposures are
limited by Federal Communications Commission safety
guidelines that were developed with the advice of FDA
and other federal health and safety agencies. When the
phone is located at greater distances from the user, the
exposure to RF is drastically lower because a person’s RF
exposure decreases rapidly with increasing distance
from the source. The so-called “cordless phones,” which
have a base unit connected to the telephone wiring in a
house, typically operate at far lower power levels, and
thus produce RF exposures well within the FCC’s
compliance limits.
2. Do wireless phones pose a health hazard?
The available scientific evidence does not show that any
health problems are associated with using wireless
phones. There is no proof, however, that wireless phones
are absolutely safe. Wireless phones emit low levels of
radiofrequency energy (RF) in the microwave range while
being used. They also emit very low levels of RF when in
the stand-by mode. Whereas high levels of RF can
produce health effects (by heating tissue), exposure to
AAppppeennddiixxAAppppeennddiixx
safety-end-NorthA 1/27/03 2:05 PM Page 148
151
4. What is FDA doing to find out more about the possible
health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology
Program and with groups of investigators around the
world to ensure that high priority animal studies are
conducted to address important questions about the
effects of exposure to radiofrequency energy (RF).
FDA has been a leading participant in the World Health
Organization International Electromagnetic Fields (EMF)
Project since its inception in 1996. An influential result
of this work has been the development of a detailed
agenda of research needs that has driven the
establishment of new research programs around the
world. The Project has also helped develop a series of
public information documents on EMF issues.
FDA and the Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative Research
and Development Agreement (CRADA) to do research on
wireless phone safety. FDA provides the scientific
oversight, obtaining input from experts in government,
industry, and academic organizations. CTIA-funded
research is conducted through contracts to independent
investigators. The initial research will include both
laboratory studies and studies of wireless phone users.
The CRADA will also include a broad assessment of
additional research needs in the context of the latest
research developments around the world.
5. What steps can I take to reduce my exposure to
radiofrequency energy from my wireless phone?
150
best possible information on possible effects of wireless
phone use on human health
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at the
federal level. The following agencies belong to this
working group:
National Institute for Occupational Safety and Health
Environmental Protection Agency
Federal Communications Commission
Occupational Safety and Health Administration
National Telecommunications and Information
Administration
The National Institutes of Health participates in some
interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless
phones with the Federal Communications Commission
(FCC). All phones that are sold in the United States must
comply with FCC safety guidelines that limit RF exposure.
FCC relies on FDA and other health agencies for safety
questions about wireless phones.
FCC also regulates the base stations that the wireless
phone networks rely upon. While these base stations
operate at higher power than do the wireless phones
themselves, the RF exposures that people get from these
base stations are typically thousands of times lower than
those they can get from wireless phones. Base stations
are thus not the primary subject of the safety questions
discussed in this document.
AAppppeennddiixxAAppppeennddiixx
safety-end-NorthA 1/27/03 2:05 PM Page 150
153
Some groups sponsored by other national governments
have advised that children be discouraged from using
wireless phones at all. For example, the government in
the United Kingdom distributed leaflets containing such
a recommendation in December 2000. They noted that no
evidence exists that using a wireless phone causes brain
tumors or other ill effects. Their recommendation to limit
wireless phone use by children was strictly
precautionary; it was not based on scientific evidence
that any health hazard exists.
7. Do hands-free kits for wireless phones reduce risks
from exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that hands-free kits reduce risks. Hands-free kits
can be used with wireless phones for convenience and
comfort. These systems reduce the absorption of RF
energy in the head because the phone, which is the
source of the RF emissions, will not be placed against
the head. On the other hand, if the phone is mounted
against the waist or other part of the body during use,
then that part of the body will absorb more RF energy.
Wireless phones marketed in the U.S. are required to
meet safety requirements regardless of whether they are
used against the head or against the body. Either
configuration should result in compliance with the safety
limit.
8. Do wireless phone accessories that claim to shield the
head from RF radiation work?
152
If there is a risk from these products—and at this point
we do not know that there is—it is probably very small.
But if you are concerned about avoiding even potential
risks, you can take a few simple steps to minimize your
exposure to radiofrequency energy (RF). Since time is a
key factor in how much exposure a person receives,
reducing the amount of time spent using a wireless
phone will reduce RF exposure.
If you must conduct extended conversations by wireless
phone every day, you could place more distance between
your body and the source of the RF, since the exposure
level drops off dramatically with distance. For example,
you could use a headset and carry the wireless phone
away from your body or use a wireless phone connected
to a remote antenna
Again, the scientific data do not demonstrate that
wireless phones are harmful. But if you are concerned
about the RF exposure from these products, you can use
measures like those described above to reduce your RF
exposure from wireless phone use.
6. What about children using wireless phones?
The scientific evidence does not show a danger to users
of wireless phones, including children and teenagers. If
you want to take steps to lower exposure to
radiofrequency energy (RF), the measures described
above would apply to children and teenagers using
wireless phones. Reducing the time of wireless phone
use and increasing the distance between the user and
the RF source will reduce RF exposure.
AAppppeennddiixxAAppppeennddiixx
safety-end-NorthA 1/27/03 2:05 PM Page 152
155
FDA has tested hearing aids for interference from
handheld wireless phones and helped develop a
voluntary standard sponsored by the Institute of
Electrical and Electronic Engineers (IEEE). This standard
specifies test methods and performance requirements for
hearing aids and wireless phones so that that no
interference occurs when a person uses a compatible
phone and a compatible hearing aid at the same time.
This standard was approved by the IEEE in 2000.
FDA continues to monitor the use of wireless phones for
possible interactions with other medical devices. Should
harmful interference be found to occur, FDA will conduct
testing to assess the interference and work to resolve
the problem.
10. What are the results of the research done already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws in
their research methods. Animal experiments
investigating the effects of radiofrequency energy (RF)
exposures characteristic of wireless phones have yielded
conflicting results that often cannot be repeated in other
laboratories. A few animal studies, however, have
suggested that low levels of RF could accelerate the
development of cancer in laboratory animals. However,
many of the studies that showed increased tumor
development used animals that had been genetically
engineered or treated with cancer-causing chemicals so
as to be pre-disposed to develop cancer in the absence
of RF exposure. Other studies exposed the animals to RF
for up to 22 hours per day. These conditions are not
similar to the conditions under which people use
wireless phones, so we don t know with certainty what
154
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that accessories that claim to shield the head
from those emissions reduce risks. Some products that
claim to shield the user from RF absorption use special
phone cases, while others involve nothing more than a
metallic accessory attached to the phone. Studies have
shown that these products generally do not work as
advertised. Unlike “hand-free” kits, these so-called
“shields” may interfere with proper operation of the
phone. The phone may be forced to boost its power to
compensate, leading to an increase in RF absorption. In
February 2002, the Federal trade Commission (FTC)
charged two companies that sold devices that claimed to
protect wireless phone users from radiation with making
false and unsubstantiated claims. According to FTC,
these defendants lacked a reasonable basis to
substantiate their claim.
9. What about wireless phone interference with medical
equipment?
Radiofrequency energy (RF) from wireless phones can
interact with some electronic devices. For this reason,
FDA helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted cardiac
pacemakers and defibrillators from wireless telephones.
This test method is now part of a standard sponsored by
the Association for the Advancement of Medical
instrumentation (AAMI). The final draft, a joint effort by
FDA, medical device manufacturers, and many other
groups, was completed in late 2000. This standard will
allow manufacturers to ensure that cardiac pacemakers
and defibrillators are safe from wireless phone EMI.
AAppppeennddiixxAAppppeennddiixx
safety-end-NorthA 1/27/03 2:05 PM Page 154
157156
the results of such studies mean for human health.
Three large epidemiology studies have been published
since December 2000. Between them, the studies
investigated any possible association between the use of
wireless phones and primary brain cancer, glioma,
meningioma, or acoustic neuroma, tumors of the brain or
salivary gland, leukemia, or other cancers. None of the
studies demonstrated the existence of any harmful
health effects from wireless phone RF exposures.
However, none of the studies can answer questions
about long-term exposures, since the average period of
phone use in these studies was around three years.
11. What research is needed to decide whether RF
exposure from wireless phones poses a health risk?
A combination of laboratory studies and epidemiological
studies of people actually using wireless phones would
provide some of the data that are needed. Lifetime
animal exposure studies could be completed in a few
years. However, very large numbers of animals would be
needed to provide reliable proof of a cancer promoting
effect if one exists. Epidemiological studies can provide
data that is directly applicable to human populations, but
10 or more years follow-up may be needed to provide
answers about some health effects, such as cancer. This
is because the interval between the time of exposure to
a cancer-causing agent and the time tumors develop - if
they do - may be many, many years. The interpretation of
epidemiological studies is hampered by difficulties in
measuring actual RF exposure during day-to-day use of
wireless phones. Many factors affect this measurement,
such as the angle at which the phone is held, or which
model of phone is used.
12. Which other federal agencies have responsibilities
related to potential RF health effects?
Additional information on the safety of RF exposures from
various sources can be obtained from the following
organizations.
FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
Occupational Safety and Health Administration’s (OSHA):
http://www.osha-
slc.gov/SLTC/radiofrequencyradiation/index.html
National Institute for Occupational Safety and Health
(NIOSH):
http://www.cdc.gov/niosh/emfpg.html
World health Organization (WHO):
http://www.who.int/peh-emf/
International Commission on Non-Ionizing Radiation
Protection:
http://www.icnirp.de
National Radiation Protection Board (UK):
http://www.nrpb.org.uk
Updated 4/3/2002: US Food and Drug Administration
http://www.fda.gov/cellphones
AAppppeennddiixxAAppppeennddiixx
safety-end-NorthA 1/27/03 2:05 PM Page 156
64
Index
A
ABC mode, text input • 19
Alarm • 45
Alert • 31, 32
Answering
call • 23
second call • 25
Anykey answer • 54
Auto redial • 54
B
Backlight time, set • 52
Band selection • 31
Barring, calls • 29
Battery
charging • 7
low indicator • 8
precautions • 58
Broadcast messages • 36
Browser, WAP • 41
C
Calculator • 46
Call costs • 28
Call records
dialled • 27
missed • 27
received • 27
Call time • 27
Caller ID • 30
Calls answering • 23
barring • 29
holding • 24
redialling • 22
rejecting • 23
waiting • 30
CB (Cell Broadcast) messages •
36
Characters, enter • 19
Conference call • 25
Connection tone • 32
D
Deleting
call records • 26
MMS • 37, 38
phonebook • 51
SMS • 33
Delivery reports, message • 39
Dialled calls • 27
Display
layout • 10
settings • 52
DTMF tones, send • 24
E
Emergency calls • 61
Extra tones 32
F
FDN (Fixed Dial Number) mode
• 54
Funbox • 41
G
Games • 43
Greeting message • 53
H
Holding, call • 24
I
Icons, description • 10
Images, downloaded • 44
Inbox, messages
MMS • 37
SMS • 33
International calls • 22
Internet • 41
K
Key tones
sending • 24
setting • 32
Keys, description • 9
L
Language, select • 53
Last number, redial • 22
Locking
phone • 53
SIM card • 54
Low battery indicator • 8
M
Memory status
downloaded items • 44
messages • 39
phonebook • 51
Message tone • 32
Messages
65
Index
cell broadcast • 36
greeting • 53
MMS • 37
SMS • 33
voice • 36
web • 40
Minute minder • 32
Missed calls • 27
MMS messages
creating/sending • 38
deleting • 38
setting • 39
viewing • 37
Multi-party calls • 25
Muting
key tones • 24
microphone • 24
N
Names
entering • 19
searching • 49
Network selection • 30
Network services • 28
Number
dialling/searching • 22
storing • 49
O
Organiser • 44
Outbox, messages
MMS • 37
SMS • 33
Own number • 53
P
Password
call barring • 29
phone • 54
Phonecare and maintenance •
62
display • 10
icons • 10
locking • 53
resetting • 55
switching on/off • 8
unpacking • 6
Phonebook
copying • 49
deleting • 51
editing • 49
options • 49
speed-dialling • 50
PIN
changing • 53
locking • 53
PIN2, change • 54
Power on/off tone • 32
Privacy • 54
R
Received calls • 27
Recording
voice memos • 47
Redialling
automatically • 54
manually • 22
Resetting phone • 55
Ring tone • 31
volume • 31
Road safety • 59
S
Safety
information • 57
precautions • 3
SDN(Service Dialling Numbers)
• 51
Security, calls • 53
Sent messages
MMS • 37
SMS • 33
SIM card
inserting • 7
locking • 54
SMS messages
creating/sending • 34
viewing • 33
Sound settings • 31
Sounds, downloaded • 44
Speed-dial • 50
Switching on/off
microphone • 24
phone • 8
T
Templates
MMS • 38
SMS • 34
Text input mode, change • 19
Text, enter • 19
Tone call ringer • 31
connect • 32
extra • 32
keypad • 32
message • 32
power on/off • 32
66
Index
V
Voice mail • 36
Voice memos
recording • 47
Voicemail server • 36
W
Waiting call • 30
WAP browser
access • 41
bookmarks • 42
cache, clear • 43
World time • 45
