Samsung Electronics Co SGHC240 Single-Band PCS GSM Phone User Manual

Samsung Electronics Co Ltd Single-Band PCS GSM Phone Users Manual

Users Manual

* Depending on the software installed or your service provider or country,
some of the descriptions in this guide may not match your phone exactly.
* Depending on your country, your phone and accessories may appear
different from the illustrations in this guide.
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-xxxxxA
English (EU). 05/2006. Rev. 1.0
SGH-C240
User’s Guide
Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or illegal.
Drive safely at all times
Do not use a hand-held phone while driving. Park the
vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using them in
an aircraft is both illegal and dangerous.
Switch off the phone near all medical equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.
Interference
All wireless phones may be subject to interference,
which could affect their performance.
1
Important safety precautions
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is forbidden
to use it, or when it may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear). Avoid
unnecessary contact with the antenna when the phone
is switched on.
Emergency calls
Key in the emergency number for your present
location, then press .
Keep your phone away from small children
Keep the phone and all its parts, including accessories,
out of the reach of small children.
Accessories and batteries
Use only Samsung-approved batteries and
accessories, such as headsets and PC data cables. Use
of any unauthorised accessories could damage you or
your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health and
safety information" on page 64.
• The phone could explode if the battery is replaced
with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.
At very high volumes, prolonged listening to a
headset can damage your hearing.
2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone. To quickly
learn the basics for your phone, please refer to “Get
started” and “Step outside the phone.”
In this guide, the following instruction icons appear:
Indicates that you need to pay careful attention
to the subsequent information regarding safety
or phone features.
Indicates that you can get more information on
the referenced page.
→
Indicates that you need to press the Navigation
keys to scroll to the specified option and then
select it.
[ ] Indicates a key on the phone. For example,
[]
< > Indicates a soft key, whose function is
displayed on the phone screen. For example,
<
Menu
>
• Tri-band operation
Use your phone in worldwide GSM networks, in
any of 900, 1800, and 1900 bands.
Special
features of your phone
•FM radio
Listen to your favourite radio
stations anytime, anywhere.
•IrDA
Send and receive Phonebook
entries via an infrared port.
4
Contents
Unpack 6
Make sure you have each item
Your phone 6
keys, features, and locations
Get started 7
First steps to operating your phone
Install and charge the phone..................................... 7
Power on or off........................................................ 8
Keypad lock ............................................................ 8
Keys and display ..................................................... 9
Access menu functions ............................................ 11
Customise your phone............................................. 12
Make/Answer calls .................................................. 14
Step outside the phone 14
Begin with games, the web, the FM radio, and other special
features
Play games............................................................ 14
Browse the web...................................................... 15
Listen to the FM radio ............................................. 15
Use Phonebook ...................................................... 16
Send messages...................................................... 17
View messages....................................................... 18
Enter text 19
ABC, T9, Number, and Symbol modes
Call functions 22
Advanced calling features
Menu functions 26
All menu options listed
Solve problems 62
Help and personal needs
Health and safety information 64
Index 71
5
Overview of menu functions
To access Menu mode, press <
Menu
> in Idle mode.
1 SIM AT
*
p. 29
2
2 Call records
p. 29
1 Missed calls
2 Received calls
3 Dialled calls
4 Delete all
5 Call time
6 Call cost*
p. 29
p. 30
p. 30
p. 30
p. 30
p. 31
3 Network services
p. 31
1 Call diverting
2 Call barring
3 Call waiting
4 Network selection
5 Caller ID
6 Closed user group
7 Band selection
p. 31
p. 32
p. 32
p. 33
p. 33
p. 33
p. 34
4 Sound settings
p. 34
1 Ring tone
2 Ring volume
3 Alert type
4 Keypad tone
5 Message tone
6 Alert on call
7 Power on/off
8 Extra tones
p. 34
p. 34
p. 34
p. 34
p. 35
p. 35
p. 35
p. 35
5 Messages
p. 36
1 Text messages
2 Multimedia
messages
3 Push messages
p. 36
p. 40
p. 45
6 Funbox
p. 45
1 WAP browser
2 Games
3 Sounds
4 Images
5 Delete all
6 Memory status
p. 45
p. 48
p. 49
p. 49
p. 49
p. 49
7 Organiser
p. 50
1 Alarm
2 Calendar
3 Time & Date
4 Calculator
5 To do list
6 Voice memo
7 Currency exchange
p. 50
p. 51
p. 52
p. 52
p. 53
p. 53
p. 54
8 FM Radio
p. 55
9 Phone settings
p. 56
1 Infrared activate
2 Display settings
3 Greeting message
4 Own number
5 Language
6 Security
7 Extra settings
8 Volume key
9 Short cut
0 Reset settings
p. 56
p. 58
p. 59
p. 59
p. 59
p. 59
p. 61
p. 61
p. 61
p. 61
Press <
Phonebook
> in Idle
mode.
Phonebook
p. 26
1 Search
2 New entry
3 Group search
4 Edit group
5 Speed dial
6 Delete all
7 Memory status
8 SDN
*
* Shows only if supported by your
SIM card.
p. 26
p. 26
p. 27
p. 27
p. 28
p. 28
p. 28
p. 29
6
Unpack
Make sure you have each item
You can obtain various accessories from your
local Samsung dealer.
Phone Travel Adapter
Battery User’s Guide
The items supplied with your phone and the
accessories available at your Samsung dealer
may vary, depending on your country or
service provider.
Your phone
keys, features, and locations
Left soft key
Dial key
Special
function keys
Display
Power on/off/
Menu exit key
Alphanumeric
keys
Right soft key
Microphone
Navigation keys
(Up/Down/
Left/Right)
Web access/
Confirm key
Cancel/Correct
key
Volume keys
Infrared port
Earpiece
7
Get started
First steps to operating your phone
SIM card information
When you subscribe to a cellular network, you receive
a plug-in SIM (Subscriber Identity Module) card
loaded with your subscription details, such as your
PIN, and available optional services.
Install and charge the phone
Remove the battery
cover.
If the
phone is already
on, first turn it off by
pressing and holding
[].
Insert the SIM card.
Make sure that the
gold-coloured contacts
on the card are face
down.
Install the battery. Reattach the cover.
Plug the travel adapter into the phone.
Plug the adapter into a standard AC wall outlet.
8
Get started
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the battery low message displays, and
• the empty battery icon blinks.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
Power on or off
Keypad lock
You can lock the keypad to prevent accidental key
presses from affecting phone operations.
In Idle mode, press and hold [ ] and then press
<
Yes
>. To unlock the keypad, press the left soft key
and then [ ].
When the phone is completely charged (the
battery icon becomes still), unplug the adapter
from the power outlet.
Remove the adapter from the phone.
Switch on
Do not turn on
the phone when
mobile phone
use is
prohibited.
1. Press and hold [ ].
2. If necessary, enter the PIN
and press <
OK
>.
Switch off
Press and hold [ ].
9
Get started
Keys and display
Keys
Perform the function indicated on the
bottom line of the display.
In Idle mode, access the following
menus:
•Down:
FM Radio
• Up/Left/Right: your favourite menus
p. 61
In Menu mode, scroll through menu
options.
In Idle mode, launch the web browser.
In Menu mode, select the highlighted
menu option or confirm input.
Make or answer a call.
In Idle mode, retrieve numbers recently
dialled, missed, or received.
Delete characters from the display.
In Menu mode, return to the previous
menu level.
Press and hold to switch the phone on or
off.
End a call.
In Menu mode, cancel input and return
the phone to Idle mode.
Enter numbers, letters, and some
special characters.
In Idle mode, press and hold
[1]
to
access your voicemail server. Press and
hold [
0
] to enter an international call
prefix.
Enter special characters.
In Idle mode, press and hold
[]
to
activate or deactivate Silent mode. Press
and hold
[]
to enter a pause between
numbers.
Adjust the phone volume.
In Idle mode, adjust the key tone
volume.
10
Get started
Display
Layout
Icons
*
Received signal strength
Call in progress
Ou t o f y o u r se r v ice a r ea; y o u
cannot make or receive calls
GPRS network
Roaming network
Text and graphics
display messages,
instructions, and
information you enter.
Soft key function
indicators
show the current
functions assigned to
the soft keys.
Icons
display various icons.
Menu Phonebook
Keypad lock
Call diverting feature active

p. 31
IrDA feature active
p. 56
Silent mode or call ringer set to
vibrate
p. 13, p. 34
Mute mode
p. 25
New text message
New voicemail message
New multimedia message
Alarm set
p. 50
Battery power level
* Depending on your country or service provider, the icons
shown on the display may vary.
11
Get started
Access menu functions
Use the soft
keys
The roles of the soft keys vary
depending on the function you are
using. The bottom line of the
display indicates their current role.
Press the left soft
key to select the
highlighted option.
Press the right soft
key to return to the
previous menu
level
Select
Select an
option
1. Press the appropriate soft key.
2. Press the Navigation keys to
move to the next or previous
option.
3. Press <
Select
> or [
OK
]
to
confirm the function displayed
or option highlighted.
4. To exit, choose either of the
following methods:
•Press <> or [
C
] to move
up one level.
• Press [ ] to return to Idle
mode.
Use shortcuts
Press the number key
corresponding to the option you
want.
12
Get started
Customise your phone
1. In Idle mode, press <
Menu
>
and select
Phone settings
→
Language
.
2. Select a language.
1. In Idle mode, press <
Menu
>
and select
Sound settings
→
Ring tone
.
2. Select a ringtone.
3. Select
Ring volume
.
4. Adjust the volume level.
5. Press <
OK
>.
Display
language
Call ringer
melody and
volume
You can set wallpaper for the idle
screen.
1. In Idle mode, press <
Menu
>
and select
Phone settings
→
Display settings
→
Wallpaper
→
Wallpaper list
.
2. Select the image name you
want.
3. Scroll through images until you
find the one you want.
4. Press <
Select
>.
Idle mode
wallpaper
13
Get started
You can set [Up], [Left], and
[Right] to function as shortcuts to
access your favourite menus.
1. In Idle mode, press <
Menu
>
and select
Phone settings
→
Short cut
.
2. Select a key.
3. Select a menu to be assigned to
the key.
You can switch the phone to Silent
mode to avoid disturbing other
people.
Press and hold [ ] in Idle mode.
Menu
shortcuts
Silent mode
You can protect the phone against
unauthorised use with a phone
password. The phone will require
the password on power-up.
1. In Idle mode, press <
Menu
>
and select
Phone settings
→
Security
→
Change
password
.
2. Enter the default password,
00000000
, and press <
OK
>.
3. Enter a new 4- to 8-digit
password and press <
OK
>.
4. Enter the new password again
and press <
OK
>.
5. Select
Phone lock
.
6. Select
Enable
.
7. Enter the password and press
<
OK
>.
Phone lock
14
Make/Answer calls
Step outside the phone
Begin with games, the web, the FM radio, and other
special features
Play games
1. Enter an area code and phone
number.
2. Press [ ].
3. To end the call, press [ ].
1. When the phone rings, press
[].
2. To end the call, press [ ].
Press [ / ].
Make a call
Answer a call
Adjust the
volume during
a call
1. In Idle mode, press <
Menu
>
and select
Funbox
→
Games
→
a game.
2. Scroll to
START GAME
and
press [
OK
].
3. Select a game mode or press
any key to start the game.
4. To end the game, press [ ]
and then <
Yes
>.
Launch a
game
15
Step outside the phone
Browse the web
Using a built-in web browser, you can easily access the
wireless web to get a variety of up-to-date services
and information and to download web content.
Listen to the FM radio
In Idle mode, press [
OK
].
• To scroll through browser items,
press [Up] or [Down].
• To select an item, press [
OK
].
• To return to the previous page,
press [
C
].
•To access the bookmark list,
press and hold [ ].
• To access options, press and
hold [ ].
Launch the
web browser
Navigate the
web
1. Plug the connector of the
supplied headset into the jack
on the right side of the phone.
2. In Idle mode, press [Down].
3. Press <
Options
> and select
Power on/off
→
On
.
4. Press [Left] or [Right] to find
available radio stations.
5. To turn off the radio, disconnect
the headset from the phone.
Listening to the
radio
16
Step outside the phone
Use Phonebook
1. From the station list on the FM
Radio screen, select an empty
location.
2. Select
Add
.
3. Enter the station title and press
<
OK
>.
4. Enter the frequency of the
station and press <
OK
>.
5. Select a location in which you
want to store the station.
Storing a radio
station
1. In Idle mode, enter a phone
number and press <
Save
>.
2. Select a number type.
3. Select
Phone
or
SIM
.
4. Enter a name and press <
OK
>.
5. Press <
OK
> to save the entry.
1. In Idle mode, press
<
Phonebook
> and select
Search
.
2. Enter the first few letters of the
name you want.
3. Select an entry.
4. Scroll to a number and press
[ ] to dial, or press
<
Options
> to access options.
Add an entry
Find an entry
17
Step outside the phone
Send messages
1. In Idle mode, press <
Menu
>
and select
Messages
→
Text
messages
→
Write new
.
2. Enter the message text.
3. Press <
Options
> and select
Save and send
or
Send only
.
4. If you selected
Save and send
,
select a memory location.
5. Enter a destination number and
press <
OK
>.
1. In Idle mode, press <
Menu
>
and select
Messages
→
Multimedia messages
→
Write new
.
2. Enter the message subject
press <
OK
>.
3. Select
Add here
.
Send a text
message (SMS)
Send a
multimedia
message
(MMS)
4. Select an adding option and add
message contents.
5. When you have finished, press
<
Options
> and select
Send
.
6. Select a destination type.
7. Select one of
Phone number
,
E-mail address
, or
Phonebook
.
8. Enter a destination number or
e-mail address and press
<
OK
>, or select a number from
Phonebook.
9. To add other destinations,
select
Add destination
and
repeat from step 7.
10.When you have finished, select
Send message
.
18
Step outside the phone
View messages
When a notification appears:
1. Press <
View
>.
2. Select the message from the
Inbox.
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messages
→
Text
messages
→
Inbox
.
2. Select a message.
When a notification appears:
1. Press <
View
>.
2. Press <
Options
> and select
Retrieve
.
3. Select the message from the
Inbox.
View a text
message
View a
multimedia
message
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messages
→
Multimedia messages
→
Inbox
.
2. Select a message.
19
Enter text
ABC, T9, Number, and Symbol modes
You can enter text in some features, such as
Messages, Phonebook, or Organiser, using ABC mode,
T9 mode, Number mode, and Symbol mode.
Changing the text input mode
The text input mode indicator displays when the
cursor is in a text field
Example
: Writing an SMS message
Press the right soft key to change the input mode:
•: ABC mode
•: T9 mode
•: Number mode
• None: Symbol mode
Using ABC mode
Press the appropriate key until the character you want
appears on the display.
(Creating an SMS message with GSM-alphabet encoding)
Write new
Options Text input mode
indicator
Characters in order displayed
Key Upper case Lower case
space
20
Enter text
Other ABC mode operations
• To enter the same letter twice or to enter a
different letter on the same key, wait for the cursor
to move to the right automatically or press [Right].
Then, enter the next letter.
• Press [ ] to insert a space.
• Press [ ] to change case. Initial capital ( ),
Capital lock ( ), and Lower case ( ) are
available.
• Press the Navigation keys to move the cursor.
•Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
• Depending on your country, you may be able to
access an input mode for your specific language by
pressing and holding [ ].
Using T9 mode
T9 is a predictive text input mode that allows you to
enter any character using single keystrokes.
Entering a word in T9 mode
1. Press [
2
] to [
9
] to start entering a word. Press
each key once for each letter.
For example, press [
4
], [
3
], [
5
], [
5
], and [
6
] to
enter Hello in T9 mode.
T9 predicts the word that you are typing, and it
may change with each key that you press.
2. Enter the whole word before editing or deleting
characters.
3. When the word displays correctly, go to step 4.
Otherwise, press [
0
] to display alternative word
choices for the keys that you have pressed.
For example, Of and Me use [
6
] and [
3
].
4. Press [ ] to insert a space and enter the next
word.
21
Enter text
Other T9 mode operations
•Press [
1
] to enter periods or apostrophes
automatically.
• Press [ ] to change case. Initial capital ( ),
Capital lock ( ), and Lower case ( ) are
available.
• Press [Left] or [Right] to move the cursor.
•Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
Adding a new word to the T9 dictionary
This feature may not be available for some languages.
1. Enter the word that you want to add.
2. Press [
0
] to display alternative words for your key
presses. When there are no more alternative
words,
Add
displays on the bottom line.
3. Press <
Add
>.
4. Enter the word you want using ABC mode and
press <
OK
>.
Using Number mode
Number mode enables you to enter numbers.
Press the keys corresponding to the digits you want.
Using Symbol mode
Symbol mode enables you to insert symbols.
To Press
display more symbols [Up] or [Down].
select a symbol the corresponding
number key.
clear the symbol(s) [
C
].
insert the symbol(s) <
OK
>.
22
Call functions
Advanced calling features
Making a call
1. In Idle mode, enter the area code and phone
number.
2. Press [ ].
3. When you want to end the call, press [ ].
Making an international call
1. In Idle mode, press and hold [
0
]. The
+
character
appears.
2. Enter the country code, area code, and phone
number, then press [ ].
Redialling recent numbers
1. In Idle mode, press [ ] to display the list of
recent numbers.
2. Scroll to the number you want and press [ ].
Making a call from Phonebook
Once you have stored a number in Phonebook, you
can dial the number by selecting it from
Phonebook.
p. 26
You can also use the Speed dial feature to assign your
most frequently dialled numbers to specific number
keys.
p. 28
You can quickly dial a number from Phonebook using
its location number assigned when stored.
To dial a number from the phone’s memory:
1. In Idle mode, press and hold [
0
]. The
+
character
appears.
2. Enter the location number for the phone number
you want and press [ ].
3. Press [Up] or [Down] to scroll through other
numbers, if necessary.
• Press [
C
] to clear the last digit or press and
hold [
C
] to clear the whole display. You can
move the cursor to edit an incorrect digit.
• Press and hold [ ] to enter a pause between
numbers.
23
Call functions
4. Press <
Dial
> or [ ] to dial the number you want.
To dial a number from the SIM card:
1. In Idle mode, enter the location number for the
phone number you want and press [ ].
2. Press [Up] or [Down] to scroll through other
numbers, if necessary.
3. Press <
Dial
> or [ ] to dial the number you want.
Answering a call
When you receive an incoming call, the phone rings
and displays the incoming call image.
Press <
Accept
> or [ ] to answer the call.
Tips for answering a call
• When
Anykey answer
is active, you can press
any key to answer a call, except for <
Reject
> and
[].
p. 61
•Press <
Reject
> or [ ] to reject a call.
• Press and hold [ / ] to reject a call or mute the
ringer, depending on the
Volume key
setting.
p. 61
Viewing missed calls
If you have missed calls, the screen displays how
many calls you have missed.
1. Press <
View
>.
2. If necessary, scroll through the missed calls.
3. Press [ ] to dial the number you want.
Using the headset
Use the headset to make or answer calls without
holding the phone.
Connect the headset to the jack on the right side of
the phone. The button on the headset works as
follows:
To Press
redial the last call the button twice.
answer a call the button.
end a call the button.
24
Call functions
Options during a call
You can access a number of functions during a call.
Adjusting the volume during a call
Use [ / ] to adjust the earpiece volume during a call.
Press [ ] to increase the volume level and [ ] to
decrease the volume level.
Placing a call on hold/Retrieving
Press <
Hold
> or <
Unhold
> to place the call on hold
or retrieve the call.
Making a second call
You can make another call if your network supports
this function.
1. Press <
Hold
> to put the call on hold.
2. Make the second call in the normal way.
3. Press <
Swap
> to switch between the calls.
4. To end the current call, press [ ].
Answering a second call
You can answer an incoming call, if your network
supports this function and you have activated the Call
waiting feature.
p. 32
1. Press [ ] to answer the call. The first call is
automatically put on hold.
2. Press <
Swap
> to switch between the calls.
3. To end the current call, press [ ].
Using the speakerphone feature
Use the speakerphone feature to talk and listen with
the phone a short distance away.
Press [
OK
] and then <
Yes
> to activate the
speakerphone feature. Press [
OK
] again to switch
back to the earpiece.
25
Call functions
Using In-call options
Press <
Options
> to access the following options
during a call:
•
Menu
: access the phone's menu functions.
•
Mute
/
Unmute
: switch off the phone's microphone
so that the other person on the phone cannot hear
you, or switch it back on.
•
Mute keys
/
Send keys
: switch the key tones on
or off.
•
Send DTMF
: send the DTMF (Dual tone
multi-frequency) tones as a group. The DTMF
tones are the tones used in phones for tone
dialling, sounding when you press the number
keys. This option is helpful for entering a password
or an account number when you call an automated
system, like a banking service.
•
Phonebook
: access the contact list.
•
Join
: set up a multi-party call by adding a caller
on hold to a currently active call. You can include
up to 5 people on a multi-party call.
•
Select one
: select one of multi-party call
participants. You can then use the following
options:
Private
: have a private conversation with one
multi-party call participant. The other participants
can converse with each other. After the private
conversation, select
Join
to return both private
participants to the multi-party call.
Remove
: disconnect one multi-party call
participant.
To communicate with answering machines or
computerised telephone systems,
Send keys
must be selected.
26
Menu functions
All menu options listed
Phonebook
You can store phone numbers on your SIM card and in
your phone’s memory. The SIM card and phone’s
memory are physically separate, but they are used as
a single entity called Phonebook.
To access this menu, press <
Phonebook
> in Idle
mode.
Search
Use this menu to search for numbers in Phonebook.
Finding an entry
1. Enter the first few letters of the name that you
want to find.
2. Select a name from the list.
3. Scroll to a number and press [ ] to dial, or press
<
Options
> to access Phonebook options.
Using Phonebook options
While viewing an entry, press <
Options
> to access
the following options:
•
Paste
: paste the selected number into the dialling
screen.
•
Edit
: edit entry information.
•
Delete
: delete the selected entry from the name.
•
Copy
: copy the number to the phone’s memory or
to the SIM card.
•
Caller group
: assign the selected number to a
caller group.
•
Add entry
: add a new entry to the selected name.
•
Send via IrDA
: send the selected number or all
numbers in the entry via the infrared port.
p. 56
New entry
Use this menu to add a new entry to Phonebook.
27
Menu functions
Phonebook
Storing an entry in the phone’s memory
1. Select an entry type.
• : Mobile phone number
• : Office phone number
• : Home phone number
• : E-mail address; an e-mail address can be
stored only in the phone’s memory.
2. Select
Phone
.
3. Enter a name and press <
OK
>.
4. Enter a number or an e-mail address and press
<
Save
>.
5. Change the location number, if you want, and
press <
OK
>.
Storing an entry on the SIM card
1. Select an entry type.
2. Select
SIM
.
3. Enter a name and press <
OK
>.
4. Enter a number and press <
Save
>
5. Change the location number, if you want, and
press <
OK
>.
Group search
Use this menu to search for your numbers in
Phonebook in caller groups.
1. Enter the first few letters of the group name.
2. Select a group.
3. Select the name you want.
4. Press [ ] to dial the number or <
Options
> to
access Phonebook options.
Edit group
Use this menu to edit your caller groups’ properties.
Select a group and change the group settings by using
the following options:
•
Call ring tone
: set a ringtone for incoming calls
from the group members.
•
SMS tone
: set a ringtone for incoming messages
from the group members.
•
Graphic
: set a graphic icon for incoming calls from
the group members.
•
Group name
: assign a name to the group.
28
Menu functions
Speed dial
Use this menu to assign speed dial numbers (2 to 9) to
eight of your most frequently dialled numbers.
Assigning speed dial entries
1. Select a key location from
2
to
9
. Key
1
is reserved
for your voicemail server.
2. Select a name from the Phonebook list.
3. Select the number you want.
Managing speed dial entries
From the Speed dial list, press <
Options
> to access
the following options:
•
Change
: assign a different number to a key.
•
Delete
: clear the speed dial setting for a key.
•
Delete all
: clear the speed dial settings for all
keys.
•
Number
: check the number assigned to a key.
Dialling speed dial entries
In Idle mode, press and hold the appropriate key.
Delete all
Use this menu to delete all of the entries from your
phone’s memory, your SIM card, or both.
1. Press [
OK
] to select the memory locations to be
cleared.
2. Press <
Delete
>.
3. Enter the phone password and press <
OK
>.
4. Press <
Yes
> twice to confirm the deletion.
Memory status
Use this menu to check the number of entries you
have stored in the phone’s memory and on the SIM
card.
The password is preset to
00000000
. You can
change this password.
p. 60
29
Menu functions
SIM AT
(Menu 1)
SDN
Use this menu to view the list of Service Dialling
Numbers (SDN) assigned by your service provider,
including emergency numbers and numbers for
directory enquiries. This menu is available if your SIM
card supports SDN.
Scroll to the number you want and press <
Dial
> or
[].
SIM AT
(Menu 1)
This menu is available if you use a SIM AT card that
supports SIM Application Toolkit menus and provides
additional services, such as news, weather, sports,
entertainment, and location services. Available
services may vary, depending on your service
provider’s plans. For details, see your SIM card
instructions or contact your service provider.
To access this menu, press <
Menu
> in Idle mode and
select
SIM AT
.
Call records
(Menu 2)
Use this menu to view the calls you have dialled,
received, or missed, and the length of calls. You can
also check the cost of your calls,
G
if your SIM card
supports this function.
To access this menu, press <
Menu
> in Idle mode and
select
Call records
.
Missed calls
(Menu 2.1)
This menu displays the most recent calls you did not
answer.
Accessing a call record
1. Select a call record.
2. Press [Up] or [Down] to move to another call
record.
3. Press [ ] to dial, or <
Options
> to access call
record options.
30
Menu functions
Using call record options
While viewing call details, press <
Options
> to access
the following options:
•
Edit
: change the number of the selected call
record.
•
Delete
: delete the selected call record.
Received calls
(Menu 2.2)
This menu displays the most recent calls you have
received.
Dialled calls
(Menu 2.3)
This menu displays the most recent calls you have
dialled.
Delete all
(Menu 2.4)
Use this menu to delete all of the records in each call
type.
1. Press [
OK
] to select the call types to be cleared.
2. Press <
Delete
>.
3. Press <
Yes
> twice to confirm the deletion.
Call time
(Menu 2.5)
This menu displays the time log for calls made and
received. The actual time invoiced by your service
provider will vary.
•
Last call time
: check the length of your last call.
•
Total sent
: check the total length of all the calls
you have dialled.
•
Total received
: check the total length of all the
calls you have received.
•
Reset timers
: reset the call timers. You need to
enter the phone password.
The password is preset to
00000000
. You can
change this password.
p. 60
31
Menu functions
Network services
(Menu 3)
Call cost
(Menu 2.6)
This network feature displays the cost of calls. This
menu is available only if your SIM card supports this
feature. Note that this is not intended to be used for
billing purposes.
•
Last call cost
: check the cost of your last call.
•
Total cost
: check the total cost of all of your calls.
If the total cost exceeds the maximum cost set in
Set max cost
, you must reset the counter before
you can make another call.
•
Max cost
: check the maximum cost limit set in
Set max cost
.
•
Reset counters
: reset the cost counters.
•
Set max cost
: set the maximum cost authorised
for your calls.
•
Price/Unit
: set the price per unit that is applied
when the cost of your calls is calculated.
Network services
(Menu 3)
Use this menu to access network services. Please
contact your service provider to check their availability
and subscribe to them, if you wish.
To access this menu, press <
Menu
> in Idle mode and
select
Network services
.
Call diverting
(Menu 3.1)
This network service reroutes incoming calls to a
phone number that you specify.
1. Select a call diverting option:
•
Divert always
: divert all calls.
•
Busy
: divert calls when you are on another
call.
•
No reply
: divert calls when you do not answer
the phone.
•
Unreachable
: divert calls when you are not in
an area covered by your service provider or
when your phone is switched off.
•
Cancel all
: cancel all call diverting options.
32
Menu functions
2. Select the type of calls to be diverted.
3. Press <
Activate
>. To deactivate call diverting,
press <
Remove
>.
4. Enter the number to which calls are to be diverted
and press <
OK
>.
5. If you selected
No reply
, select the length of time
the network delays before diverting a call.
Call barring
(Menu 3.2)
This network service allows you to restrict your calls.
1. Select a call barring option:
•
All outgoing
: prohibit all outgoing calls.
•
International
: prohibit international calls.
•
International except home
: only allow calls
to numbers within the current country when
you are abroad, and to your home country.
•
All incoming
: prohibit incoming calls.
•
Incoming while abroad
: prohibit incoming
calls when you use your phone outside of your
service area.
•
Cancel all
: cancel all call barring settings,
allowing calls to be sent and received normally.
•
Change barring password
: change the call
barring password obtained from your service
provider.
2. Select the type of calls to be barred.
3. Press <
Activate
>. To deactivate call barring,
press <
Deactivate
>.
4. Enter the call barring password supplied by your
service provider and press <
OK
>.
Call waiting
(Menu 3.3)
This network service informs you when someone is
trying to reach you while you are on another call.
1. Select the type of calls to which the call waiting
option will apply.
2. Press <
Activate
>. To deactivate call waiting,
press <
Deactivate
>.
33
Menu functions
Network services
(Menu 3)
Network selection
(Menu 3.4)
This network service allows you to select the network
used when roaming outside of your home area, or let
the network to be chosen automatically.
You can select a network other than your home
network only if there is a valid roaming agreement
between the two.
Caller ID
(Menu 3.5)
This network service allows you to prevent your phone
number from being displayed on the phone of the
person being called. If you select
Default
, the phone
will use the default setting provided by the network.
Closed user group
(Menu 3.6)
Use this menu to set incoming and outgoing calls to be
restricted to a selected user group. For details about
how to create a closed user group (CUG), contact your
service provider.
•
Index list
: add, delete, or activate CUG index
numbers. Press <
Options
> to access the options
for setting up an index list.
•
Outside access
: enable calls to numbers other
than those in the closed user group. This feature
depends on the nature of your CUG subscription.
•
Default group
: enable the default CUG, if you
have set one with your service provider. When
making a call, you are given the option of using
your default CUG, instead of selecting one from the
list.
Some networks do not allow the user to change this
setting.
34
Menu functions
Band selection
(Menu 3.7)
For the phone to make and receive phone calls, it
must register with an available network. Your phone
can handle any of the following types of networks:
GSM 1900 and Combined GSM 900/1800.
The country where you purchased your phone
determines the default band that it uses. When you
travel abroad, you must remember to change to an
appropriate band.
Sound settings
(Menu 4)
Use this menu to customise various sound settings.
To access this menu, press <
Menu
> in Idle mode and
select
Sound settings
.
Ring tone
(Menu 4.1)
Use this menu to select a ringtone to be used for the
call ringer. You can select one of the embedded
ringtones or downloaded sounds.
Ring volume
(Menu 4.2)
Use this menu to adjust the ringtone volume.
Alert type
(Menu 4.3)
Use this menu to specify how you are to be informed
of incoming calls.
•
Melody
: the phone rings using the selected
ringtone.
•
Vibration
: the phone vibrates but not rings.
•
Vibra+melody
: the phone vibrates three times
and then starts ringing.
Keypad tone
(Menu 4.4)
Use this menu to select the tone that the phone
sounds when you press a key.
You can adjust the key tone volume using
[/]
in
Idle mode.
35
Menu functions
Sound settings
(Menu 4)
Message tone
(Menu 4.5)
Use this menu to change the sound settings for
incoming SMS messages, MMS messages, and
broadcast messages individually.
•
SMS tone
: specify how you are informed of new
SMS messages.
•
SMS-CB tone
: specify how you are informed of
new broadcast messages.
•
MMS tone
: specify how you are informed of new
MMS messages.
•
Repetition
: set whether or not the phone repeats
alerting you to new messages. If you selected
Periodic
, the phone alerts you every 2 minutes
until you view the message.
Alert on call
(Menu 4.6)
Use this menu to select whether or not the phone
informs you when you receive a new message or when
the time for an alarm comes during a call.
Power on/off
(Menu 4.7)
Use this menu to select the melody that the phone
plays when it is switched on or off.
Extra tones
(Menu 4.8)
Use this menu to customise additional tones for the
phone.
•
Error tone
: set the phone to beep when you make
a mistake.
•
Minute minder
: set the phone to beep every
minute during an outgoing call to keep you
informed of the length of your call.
•
Connect tone
: set the phone to beep when an
outgoing call is connected to the system.
36
Menu functions
Messages
(Menu 5)
Use the
Messages
menu to send and receive short
messages, and multimedia messages. You can also
access push messages from web servers.
To access this menu, press <
Menu
> in Idle mode and
select
Messages
.
Text messages
(Menu 5.1)
Short Message Service (SMS) allows you to send or
receive text messages including simple pictures,
melodies, and animated images.
Inbox
(Menu 5.1.1)
Use this menu to access SMS messages you have
received.
While viewing a message, press <
Options
> to access
the following options:
•
Delete
: delete the message.
•
Send
: forward the message to other people.
•
Text reply
: reply to the sender.
•
Call back
: make a call to the sender.
•
Cut address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Move to phone
/
Move to SIM
: move the
message between the SIM card and the phone’s
memory.
•
Select objects
: save images or sounds from the
message into your phone’s memory.
Outbox
(Menu 5.1.2)
Use this menu to access SMS messages that you have
sent or have saved to send at a later time.
While viewing a message, press <
Options
> to access
the following options:
•
Delete
: delete the message.
•
Send
: forward the message to other people.
•
Cut address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Move to phone
/
Move to SIM
: move the
message between the SIM card and the phone’s
memory.
37
Menu functions
Messages
(Menu 5)
•
Select objects
: save images or sounds from the
message into your phone’s memory.
Write new
(Menu 5.1.3)
Use this menu to create and send an SMS message.
1. Enter your message.
2. Press <
Options
> to access the following options:
•
Send only
: just send the message.
•
Save and send
: save the message in
Outbox
and then send it.
•
Save only
: save the message in
Outbox
to
send it later.
•
Text formatting
: change the text attributes.
•
Add objects
: add a sound, melody, picture, or
animated image to the message.
•
Add templates
: add one of text templates.
•
Add emoticon
: add one of preset emoticons.
•
Add phonebook
: add a phone number or
e-mail address from Phonebook.
•
Add bookmark
: add a web page’s address
from the Favorite list.
•
Language
: change the language to be used in
T9 mode.
3. When you have finished, press <
Options
> and
select
Send only
or
Save and send
.
4. If you selected
Save and send
, select a memory
location.
5. Enter a destination number.
6. Press <
OK
> to send the message.
Templates
(Menu 5.1.4)
Use this menu to create templates with the sentences
you use frequently so that you can retrieve and insert
them when composing an SMS message.
Creating a template
1. Select an empty location.
2. Select
Edit
.
3. Enter a message and press <
OK
>.
The maximum number of characters allowed in a
message varies by service provider. If your
message exceeds the maximum number of
characters, the phone will split the message.
38
Menu functions
Using template options
From the template list, press <
Options
> to access
the following options:
•
Edit
: create a new template or edit the selected
template.
•
Send message
: create and send a new message
using the template.
•
Delete
: delete the selected template.
Emoticon templates
(Menu 5.1.5)
Your phone provides preset emoticons so that you can
retrieve and insert them when composing an SMS
message. Use this menu to create or edit emoticons.
Creating an emoticon
1. Select a category.
2. Press <
Options
> and select
Add
.
3. Enter an emoticon and press <
Save
>.
Using emoticon options
From the emoticon list, press <
Options
> to access
the following options:
•
Add
: add a new emoticon.
•
Edit
: edit the selected emoticon.
•
Send
: create and send a new message using the
emoticon.
•
Delete
: delete the selected emoticon.
Settings
(Menu 5.1.6)
Use this menu to customise the SMS settings.
•
Setting x
(where
x
is the setting group number):
set the properties of each setting group. The group
accessed last is activated for sending or receiving
subsequent messages.
Service centre
: store or change the number of
your message centre.
The setting options available in this menu may vary
depending on your service provider.
39
Menu functions
Messages
(Menu 5)
Default destination
: store a default destination
number. It will be displayed in the Destination
field.
Default type
: set the default message type. The
network can convert the messages into the
selected format.
Default validity
: set the length of time your
messages are stored in the SMS server.
Setting name
: change the name of the setting
group.
•
Common settings
: the following options are
available:
Reply path
: allow recipients to reply to you
through your SMS server.
Delivery reports
: set the network to inform you
when your messages have been delivered.
Bearer selection
: select either
GSM
or
GPRS
preferred
, depending on your network.
Character support
: select a character encoding
type. If you select
Automatic
, the phone switches
the encoding type from GSM-alphabet to Uni-code
if you enter a uni-code character.
Use of uni-code encoding will reduce the maximum
number of characters in a message to about half. If
this menu is not shown, your phone provides the
automatic character encoding by default.
Delete all
(Menu 5.1.7)
Use this menu to delete SMS messages in each
message folder all at once.
1. Press [
OK
] to select the message folders to be
cleared.
2. Press <
Delete
>.
3. Press <
Yes
> twice to confirm the deletion.
Memory status
(Menu 5.1.8)
Use this menu to check the amount of memory
currently in use in each message folder.
40
Menu functions
Voice mail
(Menu 5.1.9)
Use this menu to store the number of the voicemail
server and access your voicemails.
•
Connect to voice server
: connect to the
voicemail server to allow you to listen to your
messages. You can also connect to the voicemail
server by pressing and holding [
1
] in Idle mode.
•
Voice server number
: change the voicemail
server number.
Broadcast
(Menu 5.1.0)
Your phone receives broadcast messages, which are
messages related to various topics, such as weather
forecast, traffic, and news report, from network. Use
this menu to access broadcast messages or change
the settings for the service.
•
Read
: open received broadcast messages.
The
Volatile
box saves messages until the phone
is switched off.
The
Archive
box saves messages indefinitely.
Press <
Options
> and select
Save
when a text
notification appears or while viewing a broadcast
message in the Volatile box. The message is saved
in the
Archive
box.
•
Receive
: select to receive broadcast messages, or
not.
•
Channel list
: specify the channels from which you
receive broadcast messages.
•
Language
: select the preferred languages in
which broadcast messages display.
Please contact your service provider for details.
Multimedia messages
(Menu 5.2)
Multimedia Message Service (MMS) delivers messages
containing a combination of text, an image, and an
audio, from phone to phone or from phone to e-mail.
You must enter the voicemail server number before
accessing the server. Your service provider can give
you the number.
41
Menu functions
Messages
(Menu 5)
Inbox
(Menu 5.2.1)
Use this menu to access MMS messages that you have
received. The following icons tell you the message
status:
•Read notification
• Unread notification
• Retrieving from the server
• Processing your request
• Failed to retrieve
• Read message
• Unread message
While viewing a message, press <
Options
> to access
the following message options:
Notifications
•
Retrieve
: retrieve the message from the MMS
server.
•
Delete
: delete the notification.
•
More properties
: access the message properties.
Messages
•
Delete
: delete the message.
•
Reply
: reply to the sender.
•
Callback
: make a call to the sender.
•
Cut address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Forward
: forward the message to other people.
•
Save picture
: save an image from the message
into the
Images
folder.
•
Save sound
: save a sound from the message into
the
Sounds
folder.
•
Properties
: access the message properties.
Outbox
(Menu 5.2.2)
Use this menu to access MMS messages that you have
sent. The following icons tell you the message status:
• Being sent
• Sent
• Failed to send
• To be sent
42
Menu functions
While viewing a message, press <
Options
> to access
the following options:
•
Delete
: delete the message.
•
Cut address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Send
: send or resend the message.
•
Edit message
: edit the message.
•
Properties
: access the message properties.
Draft
(Menu 5.2.3)
Use this menu to access MMS messages you have
saved to send at a later time.
You can view a message and use the options the same
as in
Outbox
.
Write new
G
(Menu 5.2.4)
Use this menu to create and send an MMS message.
1. Enter the message subject and press <
OK
>.
2. Press <
Options
> to access the following options:
•
Add text
: add message text.
•
Add picture
: add a picture to the message.
•
Add sound
: add a sound clip to the message.
•
Send
: send the message.
•
Save
: save the message in
Draft
or
Templates
.
•
Settings
: change the message settings.
p. 44
•
Add destination
: enter destination numbers
or addresses.
•
Preview
: view the message as it will be shown
on the recipient’s phone.
3. After adding items, highlight one and press
<
Options
> to access the following options for
editing the message:
•
Edit text
/
Edit picture
/
Edit sound
: edit the
text, picture, or sound.
•
Add page
: add pages. Move to each page by
pressing [Left] or [Right].
The maximum size allowed for a message can
differ, depending on your service provider.
43
Menu functions
Messages
(Menu 5)
•
Delete
: remove the added item.
•
Duration
: set how long one page displays.
After the specified time, the display
automatically scrolls to the next page.
4. When you have finished, press <
Options
> and
select
Send
.
5. Select a destination type (To, Cc, Bcc).
6. Select one of
Phone number
,
E-mail address
, or
Phonebook
.
7. Enter a phone number or an e-mail address and
press <
OK
>, or select one from Phonebook.
8. To add more destinations, select
Add destination
and repeat from step 6.
9. To enter additional numbers or addresses to other
destination types, press < >and repeat from step
5.
10.When you have finished, select
Send message
.
Templates
G
(Menu 5.2.5)
Use this menu to access MMS templates you have
saved as templates so that you can use them for
composing an MMS message.
From the template list, select a template and press
<
OK
> to access the following options:
•
Edit message
: create and send a new message
using the template.
•
Delete
: delete the selected template.
Delete all
G
(Menu 5.2.6)
Use this menu to delete MMS messages in each
message folder all at once.
1. Press [
OK
] to select the message folders to be
cleared.
2. Press <
Delete
>.
3. Press <
Yes
> twice to confirm the deletion.
44
Menu functions
Memory status
G
(Menu 5.2.7)
Use this menu to check the amount of memory
currently in use in each message folder.
Setup
G
(Menu 5.2.8)
Use this menu to customise the MMS settings.
•
Delivery report
: set the network to inform you
when your messages have been delivered.
•
Read reply
: send a read-reply request along with
your messages.
•
Auto download
: set whether or not your phone
retrieves new incoming messages from the MMS
server without notifications.
•
Message acceptance
: select the categories of
messages you want to receive.
•
Hide ID
: set whether to hide your phone number
from the recipient’s phone.
•
Expiry date
: set the length of time your messages
are stored in the message server.
•
Delivery time
: set the time delay before
messages are sent.
•
Priority
: set the priority level of your messages.
•
Report allowed
: set the network to inform the
sender when a message has been delivered to you.
•
Page duration
: set how long one page in your
outgoing messages displays. After a specified time,
the display automatically scrolls to the next page.
MMS profile
(Menu 5.2.9)
You can configure required network connection
settings for MMS. The profile accessed last is
automatically activated for sending or receiving
subsequent messages.
For each profile, set the following parameters:
•
Profile name
: assign a name to the MMS profile.
•
Connection URL
: enter the URL address of your
MMS server.
•
Security
: select a security mode for data
transmission.
Check with your service provider before you change
any MMS settings on your phone.
45
Menu functions
Funbox
G
(Menu 6)
•
IP address
: enter the IP address of the MMS
server.
•
User name
: enter the login ID.
•
Password
: enter the login password.
•
APN
: enter the access point name of the MMS
server.
Push messages
G
(Menu 5.3)
Use this menu to access push messages from the
wireless web server or change the settings for
receiving push messages.
•
Inbox
: view push messages you have received.
•
Receive
: determine whether or not your phone
receives push messages.
Never
: the phone rejects push messages.
Always
: the phone receives all push messages.
•
Delete all
: delete all push messages.
Funbox
G
(Menu 6)
The
Funbox
menu allows you to use the web browser,
play Java games, and access images and sounds
stored in the phone’s memory.
To access this menu, press <
Menu
> in Idle mode and
select
Funbox
.
WAP browser
G
(Menu 6.1)
The Wireless Application Protocol (WAP) browser on
your phone allows you to access the wireless web.
From the wireless web, you can access up-to-date
information and a wide variety of media content, such
as games, wallpapers, and ringtones.
Home
(Menu 6.1.1)
Use this menu to connect your phone to the network
and load the homepage of the wireless web service
provider. You can also press [
OK
] in Idle mode.
46
Menu functions
Navigating the web browser
Using page options
From any web page, press and hold [ ] to access the
following options:
•
Reload
: reload the current page with updated
information.
•
Home
: return to the homepage.
•
Go to URL
: enter a URL address manually.
•
Show URL
: view the URL address of the current
web page.
•
Edit home
: change the page to be used for your
homepage.
•
Clear cache
: delete information stored in the
cache. The cache is a temporary memory site that
stores recently accessed web pages.
•
Inbox
: read messages received from a web
server.
Exiting the web browser
Press [ ] to end the network connection and exit the
browser.
Favorite
G
(Menu 6.1.2)
Use this menu to save URL addresses as bookmarks in
order to quickly access web pages.
Adding a bookmark
1. Select an empty location.
2. Enter a URL address and press <
Enter
>.
3. Enter a title for the bookmark and press <
Enter
>.
Using bookmark options
After saving an item, press <
Options
> to access the
following options:
•
Go to URL
: access the bookmarked web page.
To Press
scroll through browser items [Up] or [Down].
select a browser item [
OK
].
return to the previous page [
C
].
access the bookmark list and hold [ ].
47
Menu functions
Funbox
G
(Menu 6)
•
Edit
: edit the URL address and title of the
bookmark.
•
Delete
: delete the bookmark.
http://
(Menu 6.1.3)
Use this menu to manually enter a URL address and
access the associated web page.
Settings
(Menu 6.1.4)
Use this menu to set up connection profiles to be used
for the web browser. The profile accessed last is
automatically activated for accessing the wireless web.
For each server, set the following parameters:
•
Profile name
: enter a profile name.
•
Homepage URL
: enter the URL address of the
page to be used as your homepage.
•
Security
: select a security mode for data
transmission.
•
Bearer
: select the network bearer type;
GPRS
or
Data
. Remaining options depend on the bearer
setting.
When the bearer is set to
GPRS
:
•
IP address
: enter the IP address of the proxy
server.
•
User name
: enter the login ID.
•
Password
: enter the login password.
•
APN
: enter the access point name of the GPRS
network gateway.
When the bearer is set to
Data
:
•
IP address
: enter the IP address of the proxy
server.
•
Login name
: enter the login ID.
•
Password
: enter the login password.
•
Dial-up number
: enter the PPP phone number.
•
Data call type
: select a call type for data
transmission.
Check with your service provider before you change
any browser settings on your phone.
48
Menu functions
Clear cache
(Menu 6.1.5)
Use this menu to clear information stored in the cache.
Games
(Menu 6.2)
You can download Java applications from various
sources using the web browser, and store them in your
phone. Use this menu to access and play Java games.
Accessing an embedded game
1. Select the game you want on the Games list.
On the startup screen of the game, you can access
the following options:
•
START GAME
: start a new game.
•
CONTINUE
: continue the last game you
played.
•
HIGH SCORE
: view the high score table. This
option may not be available for some games.
•
HOW TO PLAY
: view how to play the game
and the key functions for the game.
•
OPTION
: switch on or off the game sound.
2. Select
START GAME
or
CONTINUE
to start a
game.
3. Follow the onscreen instructions.
Viewing game information
Scroll to the game you want and press <
Info
>.
Changing the DNS settings
You may need to change the DNS (Domain Name
Server) settings of the Java server at your service
provider’s instructions.
1. Select
Setting
on the Games list.
2. Enter the primary address and press <
OK
>.
3. Enter the secondary address and press <
OK
>.
Java services may not be available, depending on
your service provider.
49
Menu functions
Funbox
G
(Menu 6)
Sounds
(Menu 6.3)
Use this menu to access sounds downloaded from the
wireless web or received in messages.
While reviewing a file, press <
Options
> to access the
following options:
•
Rename
: change the file name.
•
Delete
: delete the file.
•
Set as ring tone
: set the sound as your call
ringtone.
Images
(Menu 6.4)
Use this menu to access images downloaded from the
wireless web or received in messages.
While reviewing a file, press <
Options
> to access the
following options:
•
Rename
: change the file name.
•
Delete
: delete the file.
•
Set as wallpaper
: set the image as wallpaper for
the idle screen.
Delete all
(Menu 6.5)
Use this menu to delete all of the downloaded items in
each media folder.
1. Press [
OK
] to select the folders to be cleared.
2. Press <
Delete
>.
3. Press <
Yes
> twice to confirm the deletion.
Memory status
(Menu 6.6)
Use this menu to check the total amount of memory
for media items and the amount of memory currently
in use in each media folder.
50
Menu functions
Organiser
(Menu 7)
The
Organiser
menu enables you to keep track of
your schedule and tasks, and to record voice memos.
You can also set the time and date and use convenient
features, such as an alarm clock, a calculator, and a
currency converter.
To access this menu, press <
Menu
> in Idle mode and
select
Organiser
.
Alarm
(Menu 7.1)
Use this menu to set alarms to sound at a specific
time.
Setting an alarm
1. Select the type of alarm.
2. Enter the time for the alarm to sound.
Press <
Options
> and select
Alarm tone
to
change the alarm tone.
3. Press [
OK
].
4. Select
AM
or
PM
in 12-hour time format.
5. If you selected
Morning call
in step 1, select a
schedule for the alarm to work.
Stopping an alarm
When the alarm sounds, press any key.
Deactivating alarms
When you do not need an alarm to sound any longer,
you can deactivate it.
• To remove an alarm set, select it from the Alarm
screen, press <
Options
>, and select
Remove
alarm
.
• To remove all alarm sets, select
Remove alarm
from the Alarm screen.
Setting the alarm to sound when the phone is
off
From the Alarm screen, select
Autopower
→
Enable
.
If the phone is off when it is time for the alarm to
sound, the phone switches on and sounds the alarm.
51
Menu functions
Organiser
(Menu 7)
Calendar
(Menu 7.2)
Use this menu to write memos on your schedule or set
alarms to act as a reminder.
When you access the
Calendar
menu, the calendar in
Month view appears with today’s date highlighted.
Selecting a day
• Press [Left] or [Right] to move by day.
• Press [Up] or [Down] to move by week.
• Press [ / ] to move by month.
Using calendar options
From the calendar, press <
Options
> to access the
following options:
•
Search all
: view all of the memos you have
created.
•
Delete all
: delete all memos.
•
Go to date
: enter the specific date you want to
access.
•
Exit
:return the display to the Idle mode.
Entering a new memo
1. Select a date on the calendar.
2. Enter your memo and press <
OK
>.
3. Press [
OK
] to set an alarm to sound on the chosen
day. Otherwise, press <
Skip
>.
4. Enter the time for the alarm to sound.
Press <
Melody
> and select an alarm tone.
5. Press [
OK
].
6. Select
AM
or
PM
in 12-hour time format.
The colour of the date on the calendar changes to
green to indicate that a memo exists for that date.
Viewing a memo
1. Select a date which has memos on the calendar.
If more than one memo exists, they will display in
order of their alarm times.
2. Press [Left] or [Right] to access the other memos
scheduled for the selected day.
52
Menu functions
Using calendar memo options
While viewing a memo, press <
Options
> to access
the following options:
•
New
: add a new memo.
•
Edit
: edit the selected memo.
•
Alarm
: set an alarm for the memo.
•
Delete
: delete the memo.
•
Copy to
: copy the memo to another date.
•
Move to
: change the date of the memo.
Time & Date
(Menu 7.3)
Use this menu to change the time and date displayed
on your phone.
•
Set time
: enter the current time.
•
Set date
: enter the current date.
•
World time
: set your local time zone and find out
the current time in another part of the world.
•
Time format
: select 12-hour or 24-hour time
format.
Calculator
(Menu 7.4)
Use this menu to perform basic arithmetic functions
such as addition, subtraction, multiplication, and
division.
1. Enter the first number.
•Press <
.()
> to insert a decimal point or a
bracket.
•
Press
[
] or [ ] to move the cursor.
2. Press the Navigation keys to access the math
function you want.
3. Enter the second number.
4. Press [
OK
] to view the result.
5. If necessary, repeat from step 2 to continue the
calculation.
To apply daylight saving time to time zones,
press <
Options
> and select
Set daylight
saving time
.
53
Menu functions
Organiser
(Menu 7)
To do list
(Menu 7.5)
Use this menu to create tasks and manage them.
Creating a task
1. Press <
New
>.
2. Enter a task and press <
OK
>.
3. Select a priority level.
4. Enter your deadline and press [
OK
].
Viewing the task
When you access the
To do list
menu, the tasks
display with a check mark, if the task has been done,
and a priority level indicator; for High, for
Normal, and for Low.
While viewing a task, press <
Options
> to access the
following options:
•
New
: add a new task.
•
Mark
: change the status of the selected task.
•
Edit
: edit the task.
•
Sort
: sort the tasks by priority or status.
•
Copy
: copy the selected task.
•
Copy to calendar
: copy the task to the calendar
as a memo.
•
Delete
: delete the task.
•
Delete all
: delete all tasks.
•
Exit
:return the display to the Idle mode.
Voice memo
(Menu 7.6)
Use this menu to record and play voice memos.
Voice record
(Menu 7.6.1)
You can record a voice memo of up to 30 seconds.
1. Press <
Record
> to start recording.
2. Speak into the microphone.
3. When you have finished, press <
Stop
>. The
following options display:
•
Replay
: play back your memo.
You can change the status of a specific task by
pressing [
]
.
54
Menu functions
•
Re-record
: discard the memo and record
another one.
•
Save
: save the memo.
•
Quit
: cancel your recording and exit the
Voice
record
menu.
4. Select
Save
to save the voice memo.
5. Enter a name of the voice memo and press <
OK
>.
Memo list
(Menu 7.6.2)
You can access the list of voice memos you have
recorded.
Press <
Options
> to access the following options:
•
Play
: play the selected voice memo.
•
Send
: send the voice memo as part of an MMS
message.
•
Rename
: change the file name.
•
Information
: access the file properties.
•
Delete
: delete the voice memo.
Delete all
(Menu 7.6.3)
You can delete all of the voice memos you have
recorded at one time.
Memory status
(Menu 7.6.4)
You can check the total amount of memory currently
in use for storing voice memos and the number of
voice memos.
Currency exchange
(Menu 7.7)
Use this menu to do currency conversions.
1. Enter the rate of foreign currency and press
<
OK
>.
2. Enter the amount of the source currency you want
to convert and press <
OK
>.
The amount you entered and its equivalent value
in the foreign currency display.
55
Menu functions
FM Radio
(Menu 8)
FM Radio
(Menu 8)
Use this menu to listen to music or news via the FM
radio on your phone.
To access this menu, press <
Menu
> in Idle mode and
select
FM Radio
, or press [Down].
Turning on and listening to the radio
First, you must connect your phone with the headset,
which serves as a radio antenna.
1. Plug the connector of the supplied headset into the
jack on the right side of the phone.
2. From the FM Radio screen, press <
Options
> and
select
Power on/off
→
On
.
3. Press [Left] or [Right] to find the radio station you
want.
You can also press and hold [Left] or [Right] to
scan through available radio stations.
4. To exit the
FM Radio
menu without turning off the
radio, press [ ]. This enables you to access other
functions while listening to the radio.
Setting up a radio station list
You can store your favourite radio stations to quickly
access them without searching through noisy
frequencies.
1. Connect the headset to the phone and turn on the
radio.
2. Select an empty location and select
Add
.
3. Enter a title for the station you want and press
<
OK
>.
4. Enter the frequency of the station and press
<
OK
>.
5. Select a location in which you want to store the
station.
6. Repeat from step 2 to store other stations.
To listen to the stored stations, press [Up] or [Down]
from the FM Radio screen.
Turning off the radio
To turn off the radio, press <
Options
> from the radio
screen and select
Power on/off
→
Off
, or disconnect
the headset.
56
Menu functions
Using radio options
On the FM radio screen, press <
Options
> to access
the following options:.
•
Power on/off
: turn the radio on or off.
•
Add
: store a radio station.
•
Edit
: edit the title or frequency for a saved radio
station.
•
Self tuning
: let the phone automatically scan
through and save available radio stations.
•
Remove
: remove the selected station or all
stations.
•
Pop-up alert
: set the phone to alert you to listen
to the radio at a specified time. When the pop-up
notification appears on the screen, press
<
Accept
> to turn on the specified radio station.
•
Settings
: change the radio settings.
Volume
: select the radio volume.
Mode
: change the audio mode to the phone’s
speaker or headset.
Phone settings
(Menu 9)
The
Phone settings
menu provides you with various
setting options to customise the phone to your
preferences and needs. You can also reset the settings
to their default status.
To access this menu, press <
Menu
> in Idle mode and
select
Phone settings
.
Infrared activate
(Menu 9.1)
Use this menu to activate the infrared port on your
phone to receive data from another IrDA-compatible
device.
Connecting with a computer
Select
With PC
to use the IrDA feature with a
computer.
To use an infrared connection, you must:
• configure and activate an IrDA-compliant infrared
port on your PC.
57
Menu functions
Phone settings
(Menu 9)
• activate the infrared feature on the phone; the
IrDA icon ( ) appears on the top line of the
display.
• align the IrDA port on the phone with the IrDA port
on your phone computer or another phone.
The connection is ready for data transmission.
If there is no communication between your phone and
the IrDA-compliant device within 30 seconds
activating the feature, it is automatically deactivated.
Receiving Phonebook data from another
phone
1. Align the IrDA ports on both phones with each
other.
2. Select
With other phone
from the
Infrared
activate
menu.
3. When the list of the received data displays, select
one of the two options:
To save an individual item:
a. Select the item you want from the list.
b. Press <
Options
> and select
Save
to save the
data. Otherwise, select
Discard
to delete the
data.
To save all data:
From the item list, press <
Options
> and select
Save all vCard
to save all Phonebook entries.
Otherwise, select
Discard all vCard
to delete all
Phonebook entries.
Sending your Phonebook to another phone
1. Align the IrDA ports on both phones with each
other.
2. Access
Phonebook
→
Search
.
3. Select a name.
Position only
58
Menu functions
4. Scroll to a number or e-mail address.
5. Press <
Options
> and select
Send via IrDA
.
6. Select a sending option.
•
Selected data
: send the selected number.
•
All data
: send all of the numbers and e-mail
addresses in the name.
The number is sent to the other phone.
Deactivating the infrared port
To end the IrDA connection and deactivate the infrared
port, select
Deactivate IrDA
from the
Infrared
activate
menu.
Display settings
(Menu 9.2)
Use this menu to change settings for the display and
light.
Wallpaper
(Menu 9.2.1)
You can change the background image and the
settings for the text of Idle mode.
•
Wallpaper list
: select a background image.
•
Text display
: determine if the phone displays the
time and date.
•
Text colour
: select a text colour.
Keypad lock
(Menu 9.2.2)
Use this menu to set the phone to lock the keypad
automatically turns off.
Brightness
(Menu 9.2.3)
You can adjust the brightness of the display for
varying lighting conditions.
Contrast
(Menu 9.2.4)
You can adjust the contrast of the brightness for the
display. Adjust this setting with the display brightness
to see the display clearly in different lighting
conditions.
Backlight
(Menu 9.2.5)
Use this menu to change the settings for the backlight
for the display.
59
Menu functions
Phone settings
(Menu 9)
•
Backlight on
: select the length of time the
backlight stays on.
•
Backlight dim
: select the length of time the
display is in Dim mode after the backlight turns off.
After a specified time, the display turns off.
Graphic logo
(Menu 9.2.6)
Use this menu to set the phone to display a graphic
icon instead of your service provider’s logo on the idle
screen. This is only available if a graphic icon has been
received in a message.
Dialling font colour
(Menu 9.2.7)
Use this menu to select a font colour for the numbers
entered while dialling.
Greeting message
(Menu 9.3)
Use this menu to enter the greeting that is displayed
briefly when the phone is switched on.
Own number
(Menu 9.4)
Use this feature to check your phone numbers, or to
assign a name to each of the numbers. Changes made
here do not affect the actual subscriber numbers on
your SIM card.
Language
(Menu 9.5)
Use this menu to select one of several languages for
the display text. If you select
Automatic
, the phone
uses the same language as the SIM card.
Security
(Menu 9.6)
Use this menu to protect the phone against
unauthorised use by managing the several access
codes of your phone and SIM card.
If you enter an incorrect PIN/PIN2 three times, the
SIM card is blocked. To unblock it, you need to enter
your PUK/PUK2 (Personal Unblocking Key). The
codes are supplied by your network operator.
60
Menu functions
PIN check
(Menu 9.6.1)
The 4- to 8-digit PIN (Personal Identification Number)
protects your SIM card against unauthorised use.
When this feature is enabled, the phone requires your
PIN each time it is switched on.
Change PIN
(Menu 9.6.2)
Use this menu to change your PIN. The PIN check
feature must be enabled to change the PIN.
Phone lock
(Menu 9.6.3)
Use this menu to lock the phone from unauthorised
use. When this feature is enabled, you must enter a 4-
to 8-digit phone password each time the phone is
switched on.
The password is preset to
00000000
. To change the
password, use the
Change password
menu.
Change password
(Menu 9.6.4)
Use this menu to change your phone password.
Privacy
(Menu 9.6.5)
Use this menu to lock your media content, including
MMS messages, voice memos, images, and sounds.
1. Press [
OK
] to select the items to be locked.
2. Press <
OK
> to lock the marked items.
3. Enter the phone password and press <
OK
>.
To access a locked item, you need to enter the phone
password.
SIM lock
(Menu 9.6.6)
This menu allows your phone to work only with the
current SIM by assigning a SIM lock code. You must
enter the SIM lock code to use a different SIM card.
FDN mode
(Menu 9.6.7)
If supported by your SIM card, Fixed Dialling Number
(FDN) mode restricts your outgoing calls to a limited
set of phone numbers. When this feature is enabled,
you can make calls only to phone numbers stored on
the SIM card.
61
Menu functions
Phone settings
(Menu 9)
Change PIN2
(Menu 9.6.8)
If supported by your SIM card, the Change PIN2
feature changes your current PIN2.
Extra settings
(Menu 9.7)
You can turn the automatic redialling or answering
feature on or off.
•
Auto redial
: set the phone to make up to ten
attempts to redial a phone number after an
unsuccessful call.
•
Anykey answer
: answer an incoming call by
pressing any key, except for <
Reject
> or [ ].
Volume key
(Menu 9.8)
Use this menu to set whether the phone mutes the call
ringer or rejects a call if you press and hold [ / ]
when a call comes in.
Short cut
(Menu 9.9)
You can use the Navigation keys as shortcut keys to
access specific menus directly from Idle mode. Use
this menu to change the shortcut assignments for
[Up], [Left], and [Right]. [Down] is fixed as a shortcut
to
FM Radio
.
1. Select a key to be used as a shortcut key.
2. Select a menu to be assigned to the key.
Reset settings
(Menu 9.0)
Use this menu to reset the phone to its default
settings.
Enter the 4- to 8-digit phone password and press
<
OK
>.
The password is preset to
00000000
. You can
change this password.
p. 60
62
Solve problems
Help and personal needs
To save the time and expense of an unnecessary
service call, perform the simple checks in this section
before contacting a service professional.
When you switch on your phone, the following
messages may appear:
“Insert SIM card”
• Be sure that the SIM card is correctly installed.
“Phone locked”
• The automatic locking function has been enabled.
You must enter the phone’s password before you
can use the phone.
“Enter PIN”
• You are using your phone for the first time. You
must enter the PIN supplied with the SIM card.
• The PIN check feature is enabled. Every time the
phone is switched on, the PIN has to be entered.
To disable this feature, use the
PIN check
menu.
“Enter PUK”
• The PIN code has been entered incorrectly three
times, and the SIM card is now blocked. Enter the
PUK supplied by your service provider.
“No service,” “Network failure,” or “Not done”
displays
• The network connection has been lost. You may be
in a weak signal area. Move and try again.
• You are trying to access an option for which you
have no subscription with your service provider.
Contact the service provider for further details.
You have entered a number but it was not dialled
• Be sure that you have pressed [ ].
• Be sure that you have accessed the right cellular
network.
• Be sure that you have not set an outgoing call
barring option.
Your correspondent cannot reach you
• Be sure that your phone is switched on. ([ ]
pressed for more than one second.)
63
Solve problems
• Be sure that you are accessing the correct cellular
network.
• Be sure that you have not set an incoming call
barring option.
Your correspondent cannot hear you speaking
• Be sure that you have switched on the
microphone.
• Be sure that you are holding the phone close
enough to your mouth. The microphone is located
at the bottom of the phone.
The phone starts beeping and “Warning Low
battery” flashes on the display
• Your battery is insufficiently charged. Recharge the
battery.
The audio quality of the call is poor
• Check the signal strength indicator on the display
( ). The number of bars indicates the signal
strength from strong ( ) to weak ( ).
• Try moving the phone slightly or moving closer to a
window if you are in a building.
No number is dialled when you re-call a
Phonebook entry
•Use the
Search
menu to ensure the number has
been stored correctly.
• Re-store the number, if necessary.
The battery does not charge properly or the
phone sometimes turns itself off
• Wipe the charging contacts both on the phone and
on the battery with a clean soft cloth.
If the above guidelines do not help you to solve
the problem, take note of:
• The model and serial numbers of your phone
•Your warranty details
• A clear description of the problem
Then contact your local dealer or Samsung after-sales
service.
64
Health and safety information
Exposure to radio frequency (RF) signals
Your wireless phone is a radio transmitter and receiver. It
is designed and manufactured not to exceed the emission
limits for exposure to radio frequency (RF) energy set by
the Federal Communications Commission (FCC) of the
U.S. Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for
the general population. The guidelines are based on the
safety standards that were developed by independent
scientific organizations through periodic and through
evaluation of scientific studies.
The standards include a substantial safety margin
designed to assure the safety of all persons, regardless of
age and health.
The exposure standard for wireless phones employs a unit
of measurement known as Specific Absorption Rate (SAR).
The SAR limit recommended by the FCC is 1.6W/kg.
*
SAR tests are conducted using standard operating
positions specified by the FCC with the phone transmitting
at its highest certified power level in all tested frequency
bands. Although the SAR is determined at the highest
certified power level, the actual SAR level of the phone
while operating can be well below the maximum value.
This is because the phone is designed to operate at
multiple power levels so as to use only the power required
to reach the network. In general, the closer you are to a
wireless base station antenna, the lower the power output
of the phone.
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that it
does not exceed the limit established by the government
adopted requirement for safe exposure. The tests are
performed in positions and locations (e.g., at the ear and
worn on the body) as required by the FCC for each model.
While there may be differences between the SAR levels of
various phones and at various positions, they all meet the
government requirement.
* In the U.S. and Canada, the SAR limit for mobile phones
used by the public is 1.6 watts/kg (W/kg) averaged
over one gram of tissue. The standard incorporates a
substantial margin of safety to give additional
protection for the public and to account for any
variations in measurements.
E760.book Page 20 Tuesday, May 23, 2006 1:59 PM
Health and safety information
65
The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as in
compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC
and can be found under the Display Grant section of http:/
/www.fcc.gov/oet/fccid after searching on FCC ID printed
in the label on the phone.
For body operation
For body worn operation, this model phone has been
tested and meets the FCC RF exposure guidelines when
used with a Samsung-supplied or approved accessory
designated for this product or when used with and
accessory that contains no metal and that positions the
handset a minimum from the body.
The minimum distance for this model phone is written in
the FCC certification information from the body. None
compliance with the above conditions may violate FCC RF
exposure guidelines.
For more Information concerning exposure to radio
frequency signals, see the following websites:
Federal Communications Commission (FCC)
http://www.fcc.gov
Cellular Telecommunications Industry Association (CTIA):
http://www.wow-com.com
U.S.Food and Drug Administration (FDA)
http://www.fda.gov/cdrh/consumer
World Health Organization (WHO)
http://www.who.int/peh-emf/en
Precautions when using batteries
Never use any charger or battery that is damaged in any
way.
Use the battery only for its intended purpose.
If you use the phone near the network’s base station, it
uses less power; talk and standby time are greatly
affected by the signal strength on the cellular network and
the parameters set by the network operator.
Battery charging time depends on the remaining battery
charge, the type of battery and the charger used. The
battery can be charged and discharged hundreds of times,
but it will gradually wear out. When the operation time
E760.book Page 21 Tuesday, May 23, 2006 1:59 PM
66
(talk time and standby time) is noticeably shorter than
normal, it is time to buy a new battery.
If left unused, a fully charged battery will discharge itself
over time.
Use only Samsung-approved batteries and recharge your
battery only with Samsung-approved chargers. When a
charger is not in use, disconnect it from the power source.
Do not leave the battery connected to a charger for more
than a week, since overcharging may shorten its life.
Extreme temperatures will affect the charging capacity of
your battery: it may require cooling or warming first.
Do not leave the battery in hot or cold places, such as in a
car in summer or winter conditions, as you will reduce the
capacity and lifetime of the battery. Always try to keep the
battery at room temperature. A phone with a hot or cold
battery may temporarily not work, even when the battery
is fully charged. Li-ion batteries are particularly affected
by temperatures below 0 °C (32 °F).
Do not short-circuit the battery. Accidental short-circuiting
can occur when a metallic object (coin, clip or pen) causes
a direct connection between the + and – terminals of the
battery (metal strips on the battery), for example when
you carry a spare battery in a pocket or bag. Short-
circuiting the terminals may damage the battery or the
object causing the short-circuiting.
Dispose of used batteries in accordance with local
regulations. Always recycle. Do not dispose of batteries in
a fire.
Road safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime. But an
important responsibility accompanies the benefits of
wireless phones, one that every user must uphold.
When driving a car, driving is your first responsibility.
When using your wireless phone behind the wheel of a car,
practice good common sense and remember the following
tips:
Get to know your wireless phone and its features, such as
speed dial and redial. If available, these features help you
to place your call without taking your attention off the
road.
When available, use a hands-free device. If possible, add
an extra layer of convenience and safety to your wireless
E760.book Page 22 Tuesday, May 23, 2006 1:59 PM
Health and safety information
67
phone with one of the many hands-free accessories
available today.
Position your wireless phone within easy reach. Be able to
access your wireless phone without removing your eyes
from the road. If you get an incoming call at an
inconvenient time, let your voice mail answer it for you.
Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy traffic or
hazardous weather conditions. Rain, sleet, snow, ice, and
even heavy traffic can be hazardous.
Do not take notes or look up phone numbers while driving.
Jotting down a To Do list or flipping through your Address
Book takes your attention away from your primary
responsibility, driving safely.
Dial sensibly and assess the traffic; if possible, place calls
when you are not moving or before pulling into traffic. Try
to plan calls when your car will be stationary. If you need
to make a call while moving, dial only a few numbers,
check the road and your mirrors, then continue.
Do not engage in stressful or emotional conversations that
may be distracting. Make the people with whom you are
talking aware that you are driving and suspend
conversations that have the potential to divert your
attention from the road.
Use your wireless phone to call for help. Dial the
emergency number in the case of fire, traffic accident or
medical emergencies. Remember, it is a free call on your
wireless phone!
Use your wireless phone to help others in emergencies. If
you see a car accident, crime in progress or other serious
emergency where lives are in danger, call the emergency
number, as you would want others to do for you.
If you see a broken-down vehicle posing no serious
hazard, a broken traffic signal, a minor traffic accident
where no one appears injured, or a vehicle you know to be
stolen, call roadside assistance or any other special non-
emergency wireless number.
Operating environment
Remember to follow any special regulations in force in any
area and always switch off your phone whenever it is
forbidden to use it, or when it may cause interference or
danger.
E760.book Page 23 Tuesday, May 23, 2006 1:59 PM
68
Health and safety information
When connecting the phone or any accessory to another
device, read its user’s guide for detailed safety
instructions. Do not connect incompatible products.
As with other mobile radio transmitting equipment, users
are advised that for the satisfactory operation of the
equipment and for the safety of personnel, it is
recommended that the equipment should only be used in
the normal operating position (held to your ear with the
antenna pointing over your shoulder).
Electronic devices
Most modern electronic equipment is shielded from radio
frequency (RF) signals. However, certain electronic
equipment may not be shielded against the RF signals
from your wireless phone. Consult the manufacturer to
discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a minimum
distance of 15 cm (6 inches) be maintained between a
wireless phone and a pacemaker to avoid potential
interference with the pacemaker. These recommendations
are consistent with the independent research and
recommendations of Wireless Technology Research.
Persons with pacemakers:
should always keep the phone more than 15 cm (6 inches)
from their pacemaker when the phone is switched on.
should not carry the phone in a breast pocket.
should use the ear opposite the pacemaker to minimize
potential interference.
If you have any reason to suspect that interference is
taking place, switch off your phone immediately.
Hearing aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you may
wish to consult your hearing aid manufacturer to discuss
alternatives.
Other medical devices
If you use any other personal medical devices, consult the
manufacturer of your device to determine if it is
adequately shielded from external RF energy. Your
physician may be able to assist you in obtaining this
E760.book Page 24 Tuesday, May 23, 2006 1:59 PM
Health and safety information
69
information. Switch off your phone in health care facilities
when any regulations posted in these areas instruct you to
do so. Hospitals or health care facilities may be using
equipment that could be sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles. Check with
the manufacturer or its representative regarding your
vehicle. You should also consult the manufacturer of any
equipment that has been added to your vehicle. You
should also consult the manufacturer of any equipment
that has been added to your vehicle.
Posted facilities
Switch off your phone in any facility where posted notices
require you to do so.
Potentially explosive environments
Switch off your phone when in any area with a potentially
explosive atmosphere and obey all signs and instructions.
Sparks in such areas could cause an explosion or fire
resulting in bodily injury or even death.
Users are advised to switch off the phone while at a
refueling point (service station). Users are reminded of the
need to observe restrictions on the use of radio equipment
in fuel depots (fuel storage and distribution areas),
chemical plants or where blasting operations are in
progress.
Areas with a potentially explosive atmosphere are often
but not always clearly marked. They include the areas
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas (such as
propane or butane), areas where the air contains
chemicals or particles, such as grain, dust or metal
powders, and any other area where you would normally be
advised to turn off your vehicle engine.
Emergency calls
This phone, like any wireless phone, operates using radio
signals, wireless and landline networks as well as user-
programmed functions, which cannot guarantee
connection in all conditions. Therefore, you should never
rely solely on any wireless phone for essential
communications (medical emergencies, for example).
E760.book Page 25 Tuesday, May 23, 2006 1:59 PM
70
Health and safety information
Remember, to make or receive any calls the phone must
be switched on and in a service area with adequate signal
strength. Emergency calls may not be possible on all
wireless phone networks or when certain network services
and/or phone features are in use. Check with local service
providers.
To make an emergency call:
If the phone is not on, switch it on.
Key in the emergency number for your present location
(for example, 911 or other official emergency number).
Emergency numbers vary by location.
Press .
If certain features are in use (call barring, for example),
you may first need to deactivate those features before you
can make an emergency call. Consult this document and
your local cellular service provider.
When making an emergency call, remember to give all the
necessary information as accurately as possible.
Remember that your phone may be the only means of
communication at the scene of an accident; do not end the
call until given permission to do so.
FCC Notice and Cautions
FCC Notice
• The device complies with Part 15 of the FCC Rules.
Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
• This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses and
can radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will occur in a
particular installation.
E760.book Page 26 Tuesday, May 23, 2006 1:59 PM
Health and safety information
71
The phone may cause TV or radio interference if used in
close proximity to receiving equipment. The FCC can
require you to stop using the phone if such interference
cannot be eliminated.
Vehicles using liquefied petroleum gas (such as propane or
butane) must comply with the National Fire Protection
Standard (NFPA-58). For a copy of this standard, contact
the National Fire Protection Association, One Battery
march Park, Quincy, MA 02269, Attn: Publication Sales
Division.
Cautions
Changes or modifications made in the radio phone, not
expressly approved by Samsung, will void the user’s
authority to operate the equipment.
Only use approved batteries, antennas and chargers. The
use of any unauthorized accessories may be dangerous
and void the phone warranty if said accessories cause
damage or a defect to the phone.
Although your phone is quite sturdy, it is a complex piece
of equipment and can be broken. Avoid dropping, hitting,
bending or sitting on it.
Other important safety information
Only qualified personnel should service the phone or
install the phone in a vehicle. Faulty installation or service
may be dangerous and may invalidate any warranty
applicable to the device.
Check regularly that all wireless phone equipment in your
vehicle is mounted and operating properly.
Do not store or carry flammable liquids, gases, or
explosive materials in the same compartment as the
phone, its parts or accessories.
If this equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment off and on,
the user is encouraged to try to correct the
interference by one or more of the following
measures:
- Reorient or relocate the receiveing antenna.
- Increase the separation between the equipment
and receiver.
- Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV
technician for help.
E760.book Page 27 Tuesday, May 23, 2006 1:59 PM
72
Health and safety information
For vehicles equipped with an air bag, remember that an
air bag inflates with great force. Do not place objects,
including both installed or portable wireless equipment in
the area over the air bag or in the air bag deployment
area. If wireless equipment is improperly installed and the
air bag inflates, serious injury could result.
Switch off your phone before boarding an aircraft. The use
of wireless phones in aircraft is illegal and may be
dangerous to the aircraft’s operation.
Failure to observe these instructions may lead to the
suspension or denial of telephone services to the offender,
or legal action, or both.
Care and maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for many
years:
Keep the phone and all its parts and accessories out of the
reach of small children’s.
Keep the phone dry. Precipitation, humidity and liquids
contain minerals that will corrode electronic circuits.
Do not use the phone with a wet hand. Doing so may
cause an electric shock to you or damage to the phone.
Do not use or store the phone in dusty, dirty areas, as its
moving parts may be damaged.
Do not store the phone in hot areas. High temperatures
can shorten the life of electronic devices, damage
batteries, and warp or melt certain plastics.
Do not store the phone in cold areas. When the phone
warms up to its normal operating temperature, moisture
can form inside the phone, which may damage the
phone’s electronic circuit boards.
Do not drop, knock or shake the phone. Rough handling
can break internal circuit boards.
Do not use harsh chemicals, cleaning solvents or strong
detergents to clean the phone. Wipe it with a soft cloth
slightly dampened in a mild soap-and-water solution.
Do not paint the phone. Paint can clog the device’s moving
parts and prevent proper operation.
E760.book Page 28 Tuesday, May 23, 2006 1:59 PM
Health and safety information
73
Do not put the phone in or on heating devices, such as a
microwave oven, a stove or a radiator. The phone may
explode when overheated.
Use only the supplied or an approved replacement
antenna. Unauthorized antennas or modified accessories
may damage the phone and violate regulations governing
radio devices.
If the phone, battery, charger or any accessory is not
working properly, take it to your nearest qualified service
facility. The personnel there will assist you, and if
necessary, arrange for service.
Acknowledging special precautions
and the FCC and industry canada
notice
Cautions
Modifications not expressly approved by the party
responsible for compliance could void the user's authority
to operate the equipment.
FCC Compliance information
This device complies with Part 15 of FCC Rules. Operation
is subject to the following two conditions:
This device may not cause harmful interference, and
This device must accept any interference received.
Including interference that may cause undesired
operation.
Information to user
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation.
E760.book Page 29 Tuesday, May 23, 2006 1:59 PM
74
Health and safety information
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/ TV technician
for help.
Appendix A: CERTIFICATION
INFORMATION (SAR)
THIS MODEL PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It
is designed and manufactured not to exceed the emission
limits for exposure to radio frequency (RF) energy set by
the Federal Communications Commission of the U.S.
Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for
the general population. The guidelines are based on safety
standards that were developed by independent scientific
organizations through periodic and thorough evaluation of
scientific studies. The standards include a substantial
safety margin designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless mobile phones
employs a unit of measurement known as the Specific
Absorption Rate (SAR). The SAR limit set by the FCC is 1.6
W/kg. SAR Tests are conducted using standard operating
positions accepted by the FCC with the phone transmitting
at its highest certified power level in all tested frequency
bands. Although the SAR is determined at the highest
certified power level, the actual SAR level of the phone
E760.book Page 30 Tuesday, May 23, 2006 1:59 PM
Health and safety information
31
while operating can be well below the maximum value.
This is because the phone is designed to operate at
multiple power levels so as to use only the power required
to reach the network. In general, the closer you are to a
wireless base station antenna, the lower the power
output.
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that it
does not exceed the exposure limit established by the
FCC. Tests for each model phone are performed in
positions and locations (e.g. at the ear and worn on the
body) as required by the FCC.
The highest SAR values for this model phone as reported
to the FCC are
Head: 0.823 W/Kg, Body-worn: 0.589 W/Kg.
For body worn operation, this model phone has been
tested and meets the FCC RF exposure guidelines
whenused with a Samsung accessory designated for this
product or when used with an accessory that contains no
metal and that positions the handset a minimum of 1.5 cm
from the body. Non-compliance with the above restrictions
may result in violation of FCC RF exposure guidelines.
The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as in
compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC
and can be found under the Display Grant section of http:/
/www.fcc.gov/oet/fccid after searching on FCC ID
A3LSGHC240.
In the United States and Canada, the SAR limit for mobile
phones used by the public is 1.6 watts/kilogram (W/kg)
averaged over one gram of tissue. The standard
incorporates a substantial ma gin of safety to give
additional protection for the public and to account for any
variations in measurements.
E760.book Page 31 Tuesday, May 23, 2006 1:59 PM
76
Health and safety information
Appendix B: Guide to safe and
responsible wireless phone use
Cellular Telecommunications & Internet Association
“Safety is the most important call you will ever make.”
A guide to safe and responsible wireless phone
use
TENS OF MILLIONS OF PEOPLE IN THE U.S. TODAY
TAKE ADVANTAGE OF THE UNIQUE COMBINATION OF
CONVENIENCE, SAFETY AND VALUE DELIVERED BY
THE WIRELESS TELEPHONE. QUITE SIMPLY, THE
WIRELESS PHONE GIVES PEOPLE THE POWERFUL
ABILITY TO COMMUNICATE BY VOICE-ALMOST
ANYWHERE, ANYTIME-WITH THE BOSS, WITH A
CLIENT, WITH THE KIDS, WITH EMERGENCY
PERSONNEL OR EVEN WITH THE POLICE. EACH YEAR,
AMERICANS MAKE BILLIONS OF CALLS FROM THEIR
WIRELESS PHONES, AND THE NUMBERS ARE RAPIDLY
GROWING.
But an important responsibility accompanies those
benefits, one that every wireless phone user must uphold.
When driving a car, driving is your first responsibility. A
wireless phone can be an invaluable tool, but good
judgment must be exercised at all times while driving a
motor vehicle whether on the phone or not.
The basic lessons are ones we all learned as teenagers.
Driving requires alertness, caution and courtesy. It
requires a heavy dose of basic common sense-keep your
head up, keep your eyes on the road, check your mirrors
frequently and watch out for other drivers.
It requires obeying all traffic signs and signals and staying
within the speed limit. It means using seat belts and
requiring other passengers to do the same.
But with wireless phone use, driving safely means a little
more. This brochure is a call to wireless phone users
everywhere to make safety their first priority when behind
the wheel of a car. Wireless telecommunications is keeping
us in touch, simplifying our lives, protecting us in
emergencies and providing opportunities to help others in
need. When it comes to the use of wireless phones, safety
is your most important call.
E760.book Page 32 Tuesday, May 23, 2006 1:59 PM
Health and safety information
77
Wireless phone “Safety Tips”
Below are safety tips to follow while driving and using a
wireless phone which should be easy to remember:
Get to know your wireless phone and its features such as
speed dial and redial. Carefully read your instruction
manual and learn to take advantage of valuable features
most phones offer, including automatic redial and memory.
Also, work to memorize the phone keypad so you can use
the speed dial function without taking your attention off
the road.
When available, use a hands free device. A number of
hands free wireless phone accessories are readily available
today. Whether you choose an installed mounted device
for your wireless phone or a speaker phone accessory,
take advantage of these devices if available to you.
Position your wireless phone within easy reach. Make sure
you place your wireless phone within easy reach and
where you can grab it without removing your eyes from
the road. If you get an incoming call at an inconvenient
time, if possible, let your voice mail answer it for you.
Suspend conversations during hazardous driving
conditions or situations. Let the person you are speaking
with know you are driving; if necessary, suspend the call
in heavy traffic or hazardous weather conditions. Rain,
sleet, snow and ice can be hazardous, but so is heavy
traffic. As a driver, your first responsibility is to pay
attention to the road.
Do not take notes or look up phone numbers while driving.
If you are reading an address book or business card, or
writing a “to do” list while driving a car, you are not
watching where you are going. It’s common sense. Don’t
get caught in a dangerous situation because you are
reading or writing and not paying attention to the road or
nearby vehicles.
Dial sensibly and assess the traffic; if possible, place calls
when you are not moving or before pulling into traffic. Try
to plan your calls before you begin your trip or attempt to
coincide your calls with times you may be stopped at a
stop sign, red light or otherwise stationary. But if you need
to dial while driving, follow this simple tip-dial only a few
numbers, check the road and your mirrors, then continue.
Do not engage in stressful or emotional conversations that
may be distracting. Stressful or emotional conversations
and driving do not mix-they are distracting and even
dangerous when you are behind the wheel of a car. Make
E760.book Page 33 Tuesday, May 23, 2006 1:59 PM
78
Health and safety information
people you are talking with aware you are driving and if
necessary, suspend conversations which have the
potential to divert your attention from the road.
Use your wireless phone to call for help. Your wireless
phone is one of the greatest tools you can own to protect
yourself and your family in dangerous situations-with your
phone at your side, help is only three numbers away. Dial
9-1-1 or other local emergency number in the case of fire,
traffic accident, road hazard or medical emergency.
Remember, it is a free call on your wireless phone!
Use your wireless phone to help others in emergencies.
Your wireless phone provides you a perfect opportunity to
be a “Good Samaritan” in your community. If you see an
auto accident, crime in progress or other serious
emergency where lives are in danger, call 9-1-1 or other
local emergency number, as you would want others to do
for you.
Call roadside assistance or a special wireless non
emergency assistance number when necessary. Certain
situations you encounter while driving may require
attention, but are not urgent enough to merit a call for
emergency services. But you still can use your wireless
phone to lend a hand. If you see a broken-down vehicle
posing no serious hazard, a broken traffic signal, a minor
traffic accident where no one appears injured or a vehicle
you know to be stolen, call roadside assistance or other
special non-emergency wireless number.
Careless, distracted individuals and people driving
irresponsibly represent a hazard to everyone on the road.
Since 1984, the Cellular Telecommunications Industry
Association and the wireless industry have conducted
educational outreach to inform wireless phone users of
their responsibilities as safe drivers and good citizens. As
we approach a new century, more and more of us will take
advantage of the benefits of wireless telephones.
And, as we take to the roads, we all have a responsibility
to drive safely.
“The wireless industry reminds you to use your phone
safely when driving.”
Cellular Telecommunications & Internet Association For
more information, please call 1-888-901-SAFE.
For updates: http://www.wow-com.com/consumer/issues/
driving/articles.cfm?ID =85
E760.book Page 34 Tuesday, May 23, 2006 1:59 PM
Health and safety information
79
Appendix C: consumer update
on wireless phones
U.S. Food and Drug Administration
What kinds of phones are the subject of this update?
The term wireless phone refers here to hand-held wireless
phones with built-in antennas, often called cell, mobile, or
PCS phones. These types of wireless phones can expose
the user to measurable radio frequency energy (RF)
because of the short distance between the phone and the
user s head. These RF exposures are limited by Federal
Communications Commission safety guidelines that were
developed with the advice of FDA and other federal health
and safety agencies. When the phone is located at greater
distances from the user, the exposure to RF is drastically
lower because a person’s RF exposure decreases rapidly
with increasing distance from the source. The so-called
“cordless phones,” which have a base unit connected to
the telephone wiring in a house, typically operate at far
lower power levels, and thus produce RF exposures well
within the FCC’s compliance limits.
Do wireless phones pose a health hazard?
The available scientific evidence does not show that any
health problems are associated with using wireless
phones. There is no proof, however, that wireless phones
are absolutely safe. Wireless phones emit low levels of
radio frequency energy (RF) in the microwave range while
being used. They also emit very low levels of RF when in
the stand-by mode. Whereas high levels of RF can produce
health effects (by heating tissue), exposure to low level RF
that does not produce heating effects causes no known
adverse health effects. Many studies of low level RF
exposures have not found any biological effects. Some
studies have suggested that some biological effects may
occur, but such findings have not been confirmed by
additional research. In some cases, other researchers
have had difficulty in reproducing those studies, or in
determining the reasons for inconsistent results.
What is FDA’s role concerning the safety of wireless
phones?
Under the law, FDA does not review the safety of radiation
emitting consumer products such as wireless phones
before they can be sold, as it does with new drugs or
medical devices. However, the agency has authority to
take action if wireless phones are shown to emit radio
frequency energy (RF) at a level that is hazardous to the
user. In such a case, FDA could require the manufacturers
of wireless phones to notify users of the health hazard and
E760.book Page 35 Tuesday, May 23, 2006 1:59 PM
80
Health and safety information
to repair, replace or recall the phones so that the hazard
no longer exists.
Although the existing scientific data do not justify FDA
regulatory actions, FDA has urged the wireless phone
industry to take a number of steps, including the
following:
Support needed research into possible biological effects of
RF of the type emitted by wireless phones;
Design wireless phones in a way that minimizes any RF
exposure to the user that is not necessary for device
function; and
Cooperate in providing users of wireless phones with the
best possible information on possible effects of wireless
phone use on human health
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at the
federal level. The following agencies belong to this
working group:
National Institute for Occupational Safety and Health
Environmental Protection Agency Federal Communications
Commission
Occupational Safety and Health Administration
National Telecommunications and Information
Administration
The National Institutes of Health participates in some
interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless phones
with the Federal Communications Commission (FCC). All
phones that are sold in the United States must comply
with FCC safety guidelines that limit RF exposure. FCC
relies on FDA and other health agencies for safety
questions about wireless phones.
FCC also regulates the base stations that the wireless
phone networks rely upon. While these base stations
operate at higher power than do the wireless phones
themselves, the RF exposures that people get from these
base stations are typically thousands of times lower than
those they can get from wireless phones. Base stations
are thus not the primary subject of the safety questions
discussed in this document.
What is FDA doing to find out more about the possible
health effects of wireless phone RF?
E760.book Page 36 Tuesday, May 23, 2006 1:59 PM
Health and safety information
81
FDA is working with the U.S. National Toxicology Program
and with groups of investigators around the world to
ensure that high priority animal studies are conducted to
address important questions about the effects of exposure
to radio frequency energy (RF).
FDA has been a leading participant in the World Health
Organization International Electromagnetic Fields (EMF)
Project since its inception in 1996. An influential result of
this work has been the development of a detailed agenda
of research needs that has driven the establishment of
new research programs around the world. The Project has
also helped develop a series of public information
documents on EMF issues.
FDA and the Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative Research
and Development Agreement (CRADA) to do research on
wireless phone safety. FDA provides the scientific
oversight, obtaining input from experts in government,
industry, and academic organizations. CTIA-funded
research is conducted through contracts to independent
investigators. The initial research will include both
laboratory studies and studies of wireless phone users.
The CRADA will also include a broad assessment of
additional research needs in the context of the latest
research developments around the world.
What steps can I take to reduce my exposure to radio
frequency energy from my wireless phone?
If there is a risk from these products—and at this point we
do not know that there is—it is probably very small. But if
you are concerned about avoiding even potential risks,
you can take a few simple steps to minimize your
exposure to radio frequency energy (RF). Since time is a
key factor in how much exposure a person receives,
reducing the amount of time spent using a wireless phone
will reduce RF exposure.
If you must conduct extended conversations by wireless
phone every day, you could place more distance between
your body and the source of the RF, since the exposure
level drops off dramatically with distance. For example,
you could use a headset and carry the wireless phone
away from your body or use a wireless phone connected to
a remote antenna
Again, the scientific data do not demonstrate that wireless
phones are harmful. But if you are concerned about the RF
exposure from these products, you can use measures like
E760.book Page 37 Tuesday, May 23, 2006 1:59 PM
82
Health and safety information
those described above to reduce your RF exposure from
wireless phone use.
What about children using wireless phones?
The scientific evidence does not show a danger to users of
wireless phones, including children and teenagers. If you
want to take steps to lower exposure to radio frequency
energy (RF), the measures described above would apply
to children and teenagers using wireless phones. Reducing
the time of wireless phone use and increasing the distance
between the user and the RF source will reduce RF
exposure.
Some groups sponsored by other national governments
have advised that children be discouraged from using
wireless phones at all. For example, the government in the
United Kingdom distributed leaflets containing such a
recommendation in December 2000. They noted that no
evidence exists that using a wireless phone causes brain
tumors or other ill effects. Their recommendation to limit
wireless phone use by children was strictly precautionary;
it was not based on scientific evidence that any health
hazard exists.
Do hands-free kits for wireless phones reduce risks from
exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that hands-free kits reduce risks. Hands-free kits
can be used with wireless phones for convenience and
comfort. These systems reduce the absorption of RF
energy in the head because the phone, which is the source
of the RF emissions, will not be placed against the head.
On the other hand, if the phone is mounted against the
waist or other part of the body during use, then that part
of the body will absorb more RF energy. Wireless phones
marketed in the U.S. are required to meet safety
requirements regardless of whether they are used against
the head or against the body. Either configuration should
result in compliance with the safety limit.
Do wireless phone accessories that claim to shield the
head from RF radiation work?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that accessories that claim to shield the head from
those emissions reduce risks. Some products that claim to
shield the user from RF absorption use special phone
cases, while others involve nothing more than a metallic
accessory attached to the phone. Studies have shown that
these products generally do not work as advertised. Unlike
E760.book Page 38 Tuesday, May 23, 2006 1:59 PM
Health and safety information
83
“hand-free” kits, these so-called “shields” may interfere
with proper operation of the phone. The phone may be
forced to boost its power to compensate, leading to an
increase in RF absorption. In February 2002, the Federal
trade Commission (FTC) charged two companies that sold
devices that claimed to protect wireless phone users from
radiation with making false and unsubstantiated claims.
According to FTC, these defendants lacked a reasonable
basis to substantiate their claim.
What about wireless phone interference with medical
equipment?
Radio frequency energy (RF) from wireless phones can
interact with some electronic devices. For this reason, FDA
helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted cardiac
pacemakers and defibrillators from wireless telephones.
This test method is now part of a standard sponsored by
the Association for the Advancement of Medical
instrumentation (AAMI). The final draft, a joint effort by
FDA, medical device manufacturers, and many other
groups, was completed in late 2000. This standard will
allow manufacturers to ensure that cardiac pacemakers
and defibrillators are safe from wireless phone EMI.
FDA has tested hearing aids for interference from
handheld wireless phones and helped develop a voluntary
standard sponsored by the Institute of Electrical and
Electronic Engineers (IEEE). This standard specifies test
methods and performance requirements for hearing aids
and wireless phones so that no interference occurs when a
person uses a compatible phone and a compatible hearing
aid at the same time. This standard was approved by the
IEEE in 2000.
FDA continues to monitor the use of wireless phones for
possible interactions with other medical devices. Should
harmful interference be found to occur, FDA will conduct
testing to assess the interference and work to resolve the
problem.
What are the results of the research done already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws in their
research methods. Animal experiments investigating the
effects of radio frequency energy (RF) exposures
characteristic of wireless phones have yielded conflicting
results that often cannot be repeated in other laboratories.
A few animal studies, however, have suggested that low
levels of RF could accelerate the development of cancer in
laboratory animals. However, many of the studies that
E760.book Page 39 Tuesday, May 23, 2006 1:59 PM
84
Health and safety information
showed increased tumor development used animals that
had been genetically engineered or treated with cancer
causing chemicals so as to be pre-disposed to develop
cancer in the absence of RF exposure. Other studies
exposed the animals to RF for up to 22 hours per day.
These conditions are not similar to the conditions under
which people use wireless phones, so we don t know with
certainty what the results of such studies mean for human
health.
Three large epidemiology studies have been published
since December 2000. Between them, the studies
investigated any possible association between the use of
wireless phones and primary brain cancer, gioma,
meningioma, or acoustic neuroma, tumors of the brain or
salivary gland, leukemia, or other cancers. None of the
studies demonstrated the existence of any harmful health
effects from wireless phone RF exposures. However, none
of the studies can answer questions about long-term
exposures, since the average period of phone use in these
studies was around three years.
What research is needed to decide whether RF exposure
from wireless phones poses a health risk?
A combination of laboratory studies and epidemiological
studies of people actually using wireless phones would
provide some of the data that are needed. Lifetime animal
exposure studies could be completed in a few years.
However, very large numbers of animals would be needed
to provide reliable proof of a cancer promoting effect if
one exists. Epidemiological studies can provide data that
is directly applicable to human populations, but 10 or
more years follow-up may be needed to provide answers
about some health effects, such as cancer. This is because
the interval between the time of exposure to a cancer-
causing agent and the time tumors develop - if they do -
may be many, many years. The interpretation of
epidemiological studies is hampered by difficulties in
measuring actual RF exposure during day-to-day use of
wireless phones. Many factors affect this measurement,
such as the angle at which the phone is held, or which
model of phone is used.
Which other federal agencies have responsibilities related
to potential RF health effects?
Additional information on the safety of RF exposures from
various sources can be obtained from the following
organizations.
E760.book Page 40 Tuesday, May 23, 2006 1:59 PM
Health and safety information
85
FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
Occupational Safety and Health Administration’s (OSHA):
http://www.osha-slc.gov/SLTC/radiofrequencyradiation/
index.html
National Institute for Occupational Safety and Health
(NIOSH):
http://www.cdc.gov/niosh/emfpg.html
World health Organization (WHO):
http://www.who.int/peh-emf/
International Commission on Non-Ionizing Radiation
Protection:
http://www.icnirp.de
National Radiation Protection Board (UK):
http://www.nrpb.org.uk
Updated 4/3/2002: US Food and Drug Administration
http://www.fda.gov/cellphones
STANDARD LIMITED WARRANTY
What is Covered and For How Long?
SAMSUNG
TELECOMMUNICATIONS AMERICA, L.P. (SAMSUNG)
warrants to the original purchaser ("Purchaser") that
SAMSUNG’s Phones and accessories ("Products") are
free from defects in material and workmanship under
normal use and service for the period commencing
upon the date of purchase and continuing for the
following specified period of time after that date:
Phone 1 Year
Batteries 1 Year
Leather Case/Pouch 90 Days
Other Phone Accessories 1 Year
What is Not Covered?
This Limited Warranty is
conditioned upon proper use of Product by Purchaser.
This Limited Warranty does not cover: (a) defects or
damage resulting from accident, misuse, abuse,
neglect, unusual physical, electrical or
electromechanical stress, or modification of any part
of Product, including antenna, or cosmetic damage;
(b) equipment that has the serial number removed or
made illegible; (c) any plastic surfaces or other
E760.book Page 41 Tuesday, May 23, 2006 1:59 PM
86
Health and safety information
externally exposed parts that are scratched or
damaged due to normal use; (d) malfunctions
resulting from the use of Product in conjunction with
accessories, products, or ancillary/peripheral
equipment not furnished or approved by SAMSUNG;
(e) defects or damage from improper testing,
operation, maintenance, installation, or adjustment;
(f) installation, maintenance, and service of Product,
or (g) Product used or purchased outside the United
States or Canada.
This Limited Warranty covers batteries only if battery
capacity falls below 80% of rated capacity or the
battery leaks, and this Limited Warranty does not
cover any battery if (i) the battery has been charged
by a battery charger not specified or approved by
SAMSUNG for charging the battery, (ii) any of the
seals on the battery are broken or show evidence of
tampering, or (iii) the battery has been used in
equipment other than the SAMSUNG phone for which
it is specified.
What are SAMSUNG’s Obligations?
During the
applicable warranty period, SAMSUNG will repair or
replace, at SAMSUNG’s sole option, without charge to
Purchaser, any defective component part of Product.
To obtain service under this Limited Warranty,
Purchaser must return Product to an authorized phone
service facility in an adequate container for shipping,
accompanied by Purchaser’s sales receipt or
comparable substitute proof of sale showing the date
of purchase, the serial number of Product and the
sellers’ name and address. To obtain assistance on
where to deliver the Product, call Samsung Customer
Care at 1-888-987-4357. Upon receipt, SAMSUNG will
promptly repair or replace the defective Product.
SAMSUNG may, at SAMSUNG’s sole option, use
rebuilt, reconditioned, or new parts or components
when repairing any Product or replace Product with a
rebuilt, reconditioned or new Product. Repaired/
replaced leather cases and pouches will be warranted
for a period of ninety (90) days. All other repaired/
replaced Product will be warranted for a period equal
to the remainder of the original Limited Warranty on
the original Product or for 90 days, whichever is
longer. All replaced parts, components, boards and
equipment shall become the property of SAMSUNG.
If SAMSUNG determines that any Product is not
covered by this Limited Warranty, Purchaser must pay
E760.book Page 42 Tuesday, May 23, 2006 1:59 PM
Health and safety information
87
all parts, shipping, and labor charges for the repair or
return of such Product.
What Are the Limits On SAMSUNG’s Liability?
EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY
CONTAINED HEREIN, PURCHASER TAKES THE
PRODUCT “AS IS,” AND SAMSUNG MAKES NO
WARRANTY OR REPRESENTATION AND THERE ARE NO
CONDITIONS, EXPRESS OR IMPLIED, STATUTORY OR
OTHERWISE, OF ANY KIND WHATSOEVER WITH
RESPECT TO THE PRODUCT, INCLUDING BUT NOT
LIMITED TO:
THE MERCHANTABILITY OF THE PRODUCT OR ITS
FITNESS FOR ANY PARTICULAR PURPOSE OR USE;
WARRANTIES OF TITLE OR NON-INFRINGEMENT;
DESIGN, CONDITION, QUALITY, OR PERFORMANCE OF
THE PRODUCT;
THE WORKMANSHIP OF THE PRODUCT OR THE
COMPONENTS CONTAINED THEREIN; OR
COMPLIANCE OF THE PRODUCT WITH THE
REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION
OR CONTRACT PERTAINING THERETO.
NOTHING CONTAINED IN THE INSTRUCTION MANUAL
SHALL BE CONSTRUED TO CREATE AN EXPRESS
WARRANTY OF ANY KIND WHATSOEVER WITH
RESPECT TO THE PRODUCT. ALL IMPLIED
WARRANTIES AND CONDITIONS THAT MAY ARISE BY
OPERATION OF LAW, INCLUDING IF APPLICABLE THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY
LIMITED TO THE SAME DURATION OF TIME AS THE
EXPRESS WRITTEN WARRANTY STATED HEREIN.
SOME STATES/PROVINCES DO NOT ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY
TO YOU. IN ADDITION, SAMSUNG SHALL NOT BE
LIABLE FOR ANY DAMAGES OF ANY KIND RESULTING
FROM THE PURCHASE, USE, OR MISUSE OF, OR
INABILITY TO USE THE PRODUCT OR ARISING
DIRECTLY OR INDIRECTLY FROM THE USE OR LOSS
OF USE OF THE PRODUCT OR FROM THE BREACH OF
THE EXPRESS WARRANTY, INCLUDING INCIDENTAL,
SPECIAL, CONSEQUENTIAL OR SIMILAR DAMAGES,
OR LOSS OF ANTICIPATED PROFITS OR BENEFITS, OR
FOR DAMAGES ARISING FROM ANY TORT (INCLUDING
NEGLIGENCE OR GROSS NEGLIGENCE) OR FAULT
COMMITTED BY SAMSUNG, ITS AGENTS OR
E760.book Page 43 Tuesday, May 23, 2006 1:59 PM
88
Health and safety information
EMPLOYEES, OR FOR ANY BREACH OF CONTRACT OR
FOR ANY CLAIM BROUGHT AGAINST PURCHASER BY
ANY OTHER PARTY. SOME STATES/PROVINCES DO
NOT ALLOW THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE
ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY
TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS,
WHICH VARY FROM STATE TO STATE/PROVINCE TO
PROVINCE.
THIS LIMITED WARRANTY SHALL NOT
EXTEND TO ANYONE OTHER THAN THE ORIGINAL
PURCHASER OF THIS PRODUCT AND STATES
PURCHASER’S EXCLUSIVE REMEDY. IF ANY PORTION
OF THIS LIMITED WARRANTY IS HELD ILLEGAL OR
UNENFORCEABLE BY REASON OF ANY LAW, SUCH
PARTIAL ILLEGALITY OR UNENFORCEABILITY SHALL
NOT AFFECT THE ENFORCEABILITY FOR THE
REMAINDER OF THIS LIMITED WARRANTY WHICH
PURCHASER ACKNOWLEDGES IS AND WILL ALWAYS
BE CONSTRUED TO BE LIMITED BY ITS TERMS OR AS
LIMITED AS THE LAW PERMITS.
THE PARTIES UNDERSTAND THAT THE PURCHASER
MAY USE THIRD-PARTY SOFTWARE OR EQUIPMENT IN
CONJUNCTION WITH THE PRODUCT. SAMSUNG
MAKES NO WARRANTIES OR REPRESENTATIONS AND
THERE ARE NO CONDITIONS, EXPRESS OR IMPLIED,
STATUTORY OR OTHERWISE, AS TO THE QUALITY,
CAPABILITIES, OPERATIONS, PERFORMANCE OR
SUITABILITY OF ANY THIRD-PARTY SOFTWARE OR
EQUIPMENT, WHETHER SUCH THIRD-PARTY
SOFTWARE OR EQUIPMENT IS INCLUDED WITH THE
PRODUCT DISTRIBUTED BY SAMSUNG OR
OTHERWISE, INCLUDING THE ABILITY TO INTEGRATE
ANY SUCH SOFTWARE OR EQUIPMENT WITH THE
PRODUCT.
THE QUALITY, CAPABILITIES, OPERATIONS,
PERFORMANCE AND SUITABILITY OF ANY SUCH
THIRD-PARTY SOFTWARE OR EQUIPMENT LIE SOLELY
WITH THE PURCHASER AND THE DIRECT VENDOR,
OWNER OR SUPPLIER OF SUCH THIRD-PARTY
SOFTWARE OR EQUIPMENT, AS THE CASE MAY BE.
This Limited Warranty allocates risk of Product failure
between Purchaser and SAMSUNG, and SAMSUNG’s
Product pricing reflects this allocation of risk and the
limitations of liability contained in this Limited
Warranty. The agents, employees, distributors, and
dealers of SAMSUNG are not authorized to make
modifications to this Limited Warranty, or make
E760.book Page 44 Tuesday, May 23, 2006 1:59 PM
Health and safety information
89
additional warranties binding on SAMSUNG.
Accordingly, additional statements such as dealer
advertising or presentation, whether oral or written,
do not constitute warranties by SAMSUNG and should
not be relied upon.
Samsung Telecommunications America (STA), Inc.
1301 East Lookout Drive
Richardson, TX 75082
Phone: 1-800-SAMSUNG
Phone: 1-888-987-HELP (4357)
©2005 Samsung Telecommunications America. All
rights reserved.
No reproduction in whole or in part allowed without
prior written approval.
Specifications and availability subject to change
without notice. [080802]
E760.book Page 45 Tuesday, May 23, 2006 1:59 PM

Navigation menu
