Samsung Electronics Co SGHD300 Single-Band PCS GSM/ EDGE Phone with Bluetooth User Manual
Samsung Electronics Co Ltd Single-Band PCS GSM/ EDGE Phone with Bluetooth Users Manual
Users Manual
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-xxxxxA
English. 04/2006. Rev. 1.0
* Depending on the software installed or your service provider or country,
some of the descriptions in this guide may not match your phone exactly.
* Depending on your country, your phone and accessories may appear
different from the illustrations in this guide.
SGH-D300
User’s Guide
'Draft'
Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or illegal.
Drive safely at all times
Do not use a hand-held phone while driving. Park
the vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using them
in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.
Important safety precautions
1
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is forbidden
to use it, or when it may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear). Avoid
unnecessary contact with the antenna when the phone
is switched on.
Emergency calls
Key in the emergency number for your present
location, then press .
Keep your phone away from small children
Keep the phone and all its parts, including accessories,
out of the reach of small children.
Accessories and batteries
Use only Samsung-approved batteries and
accessories, such as headsets and PC data cables
.
Use
of any unauthorised accessories could damage
you or
your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health and
safety information" on page 74.
• The phone could explode if the battery is
replaced with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.
At very high volume, prolonged listening to a
headset can damage your hearing.
2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone. To quickly
learn the basics for your phone, please refer to “Get
started” and “Step outside the phone.”
In this guide, the following instruction icons appear:
Indicates that you need to pay careful
attention to the subsequent information
regarding safety or phone features.
Indicates that you can get more information
on the referenced page.
→
Indicates that you need to press the
Navigation keys to scroll to the specified
option and then select it.
< > Indicates a soft key, whose function is
displayed on the phone screen. For example,
<
Menu
>
•Bluetooth
Transfer media files and personal
data and connect to other devices
using free, wireless Bluetooth
technology.
Special
features of your phone
• Voice recognition
Just say a command to dial a phone
number or access a menu function.
•
Multimedia Message Service (MMS)
Send and receive MMS messages with a
combination of text, images, video, and audio.
3
Special features of your phone
•
E-mail
Send and receive e-mails with images, video, and
audio attachments.
•Web browser
Access the wireless web to get
up-to-the-minute information and a
wide variety of media content.
•Java
Enjoy Java
™
-based embedded
games and download new games.
• Calendar and To do list
Keep track of your daily and
monthly schedule and tasks.
•
Keyboard
Enter characters using an enhanced keyboard.
• Voice recorder
Record memos or sounds.
•Alarm
Use your phone as an alarm clock to
wake you up in the morning or
notify you to an event.
•Calculator
Perform basic calculations.
4
Contents
Unpack 6
Make sure you have each item
Your phone 6
Keys, features, and locations
Get started 7
First steps to operating your phone
Install and charge the phone ..................................... 7
Power on or off........................................................ 9
Keys ...................................................................... 9
Display.................................................................. 11
Access menu functions ............................................ 13
Customise your phone............................................. 14
Make/Answer calls .................................................. 15
Step outside the phone 16
Begin with your web, messages, and other special features
Browse the web...................................................... 16
Use Phone Book ..................................................... 16
Send messages ...................................................... 17
View messages....................................................... 18
Use Bluetooth ........................................................ 19
Use voice recognition .............................................. 21
Enter text 22
ABC, T9, Number, and Symbol modes
Call functions 25
Advanced calling features
Menu functions 29
All menu options listed
Solve problems 72
Help and personal needs
Health and safety information 74
Index 81
5
Overview of menu functions
To access Menu mode, press <
Menu
> in Idle mode.
1 Call Records
p.35
1 Missed Calls
2 Received Calls
3 Dialled Calls
4 Voice Mail
5 Delete All
6 Call Time
7 Call Cost
*
p.35
p.35
p.35
p.35
p.36
p.36
p.36
2 Messaging
p.37
1 Create New
Message
2 My Messages
3 Templates
4 Delete All
5 Settings
6 Memory Status
p.37
p.40
p.43
p.43
p.44
p.45
3 Games & Apps
p.46
1 Games
2 Calculator
3 Voice Memo
4 Currency
Conversion
5 World Time
6 SIM-AT
*
p.46
p.46
p.47
p.48
p.48
p.48
4 Organiser
p.49
1 Alarm
2 Calendar
3 To Do List
p.49
p.50
p.52
5 Browser
p.53
1 Home
2 Favorites
3 http://
4 Settings
5 Clear Cache
p.53
p.54
p.54
p.54
p.54
6 Bluetooth
p.55
7 File Manager
p.58
1 Sounds
2 Images
3 Videos
4 Other Files
5 Delete All
6 Memory Status
p.58
p.58
p.59
p.59
p.59
p.59
8 Phone Book
p.60
1 Search
2 New Entry
3 Group Search
4 Group Edit
5 Speed Dial
6 Delete All
7 Own Number
8 Memory Status
9 SDN
*
p.60
p.60
p.61
p.61
p.61
p.62
p.62
p.62
p.62
9 Settings
p.63
1 Time & Date
2 Phone Settings
3 Display Settings
4 Sound Settings
5 Network Services
6 Voice Recognition
7 Security
8 Connection Settings
9 Reset Settings
p.63
p.63
p.64
p.65
p.66
p.68
p.69
p.71
p.72
* Shows only if supported by your
SIM card.
6
Unpack
Make sure you have each item
You can obtain various accessories from
your local Samsung dealer.
Phone Travel Adapter
Battery User’s Guide
The items supplied with your phone
and the accessories at your Samsung
dealer may vary, depending on your
country or service provider.
Your phone
Keys, features, and locations
Voice
Recognition/
Speaker key
External
display
Dial key
Special
function keys
Volume keys
Alphanumeric
keys
Left soft key
Headset jack
power on/off/
Menu exit key
Web access/
Confirm key
Delete/
Cancel key
Earpiece
Main display
Right soft key
Navigation keys
(Up/Down/Left/
Right)
Microphone
7
You can use additional menus in Landscape
mode.
p. 29
Get started
First steps to operating your phone
SIM card information
When you subscribe to a cellular network, you receive
a plug-in SIM (Subscriber Identity Module) card
loaded with your subscription details, such as your
PIN, and available optional services.
Install and charge the phone
Landscape view mode
Navigation keys
(Up/Down/Left/Right)
Shift key
Left soft key
Menu access key
Shortcut keys
Space key
Symbol key
Right soft/
Back key
Confirm key
Remove the battery
cover.
If the
phone is already
on, first turn it off by
pressing and holding
.
Insert the SIM card.
Make sure that the gold-
coloured contacts on the
card are face down.
8
Get started
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the low battery message displays, and
• the empty battery icon blinks.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
Install the battery.
Plug the travel adapter
into the phone.
Plug the adapter into a standard AC wall outlet.
When the phone is completely charged (the
battery icon becomes still), unplug the adapter
from the power outlet.
Remove the adapter from the phone.
9
Get started
Power on or off Keys
In Portrait mode
Switch on
Do not turn on
the phone when
mobile phone
use is prohibited.
1. Open the phone.
2. Press and hold to turn on
the phone.
3. If necessary, enter the PIN and
press <
OK
>.
Switch off
1. Open the phone.
2. Press and hold .
Perform the function indicated on the bottom
line of the display.
In Idle mode, access your favourite menus
directly.
p. 63
In Menu mode, scroll through menu options.
In Idle mode, launch the web browser.
In Menu mode, select the highlighted menu
option or confirm input.
Delete characters from the display.
In Menu mode, return to the previous menu
level.
Make or answer a call.
In Idle mode, retrieve the recent numbers
dialled, missed, or received.
10
Get started
In Landscape mode
End a call.
Press and hold to switch the phone on or off.
In Menu mode, cancel input and return the
phone to Idle mode.
Enter numbers, letters, and some special
characters.
In Idle mode, press and hold to access
your voicemail server. Press and hold to
enter an international call prefix.
Enter special characters.
In Idle mode, press and hold to activate or
deactivate Quite mode. Press and hold to
enter a pause between numbers.
Adjust the phone volume.
In Idle mode, with the phone open, adjust the
keytone volume.
In Idle mode, activate the Voice Recognition
feature.
During a call, activate the speakerphone
feature.
Perform the function indicated on the bottom
line of the display.
In Menu mode, scroll through menu options.
In Menu mode, scroll through menu options.
In text input mode, move the cursor.
Access main Menu mode.
In the Menu mode screen, access the
following menus:
•
T
:
Call Log
•
Y
:
Bluetooth
•
G
:
Phone Book
•
H
:
Email
•
B
:
Todo
•
N
:
SMS
You can change shortcut menus.
p. 33
11
Get started
Display
In Menu mode, select the highlighted menu
option or confirm input.
In Idle mode, enter letters.
In the text input mode, enter a period.
Select the highlighted menu option or
selected item.
In the text input mode, enter a carriage
return code.
Delete the selected item in an application.
In the text input mode, delete characters.
In the text input mode, change letter case.
In the text input mode, enter special
characters. Press and hold to display the
symbol screen.
In the text input mode, insert spaces.
During a call, switch the phone’s microphone
on or off.
Layout
Text and graphics
display messages,
instructions, and
information you enter.
Soft key function
indicators
show the current functions
assigned to the soft keys.
Menu Contacts
Icons
display various icons.
12
Get started
Icons
*
Received signal strength
GPRS network
Roaming network
Call diverting feature active
p. 66
Home Zone, if registered for the
appropriate service
Office Zone, if registered for the
appropriate service
Connected to the Internet
Quiet mode
Mute mode, during a call
Call in progress
Out of your service area; you
cannot make or receive a call
Speakerphone feature active
Bluetooth feature active
p. 55
Connected to Bluetooth hands-free
car kit or headset
Alarm set
p. 49
New text message
New multimedia message
New e-mail
New voicemail
New SMS + MMS message
Battery power level
* Depending on your country or service provider, the
icons shown on the display may vary.
13
Get started
Access menu functions
Use the soft
keys
The roles of the soft keys vary
depending on the function you are
using. The bottom line of the
display indicates their current role.
Press the left soft
key to select the
highlighted option.
Press the right soft
key to return to the
previous menu
level.
Select
Select an
option
1. Press a desired soft key.
2. Press the Navigation keys to
move to the next or previous
option.
3. Press <
Select
>, <
OK
>, or
to confirm the function
displayed or option highlighted.
4. To exit, choose either of the
following methods.
• Press < > to move up one
level.
• Press to return to Idle
mode.
Use shortcuts
Press the number key
corresponding to the option you
want.
14
Get started
Customise your phone
1. In Idle mode, press <
Menu
>
and select
Settings
→
Phone
Settings
→
Language
.
2. Select a language.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Sound
Settings
→
Ring Tone
.
2. Select
Default Ringtones
.
3. Select a ringtone.
You can set wallpaper for the idle
screen.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Display
Settings
→
Wallpaper
.
2. Select an image category.
3. Select the image name you
want.
Display
language
Call ringer
melody
Idle mode
wallpaper
4. Scroll through images until you
see the one you want.
5. Press <
Select
>.
You can set the Navigation keys to
function as shortcuts to access
your favourite menus.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Phone
Settings
→
Short Cut
.
2. Select a key.
3. Select a menu to be assigned to
the key.
You can switch the phone to Quiet
mode to avoid disturbing other
people.
Press and hold in Idle mode.
Menu
shortcuts
Quiet mode
15
Make/Answer calls
You can protect the phone against
unauthorised use with a phone
password. The phone will require
the password on power-up.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Security
→
Change
Password
.
2. Enter the default password,
00000000
, and press <
OK
>.
3. Enter a new 4- to 8-digit
password and press <
OK
>.
4. Enter the new password again
and press <
OK
>.
5. Select
Phone Lock
.
6. Select
Enable
.
7. Enter the password and press
<
OK
>.
Phone lock
1. In Idle mode, enter an area
code and phone number.
2. Press .
3. To end the call, press .
1. When the phone is ringing,
press .
2. To end the call, press .
Press .
Make a call
Answer a call
Adjust the
volume during
a call
16
Step outside the phone
Begin with your web, messages, and other special
features
Browse the web
Using a built-in web browser, you can easily access the
wireless web to get a variety of up-to-date services
and information and to download web content.
Use Phone Book
In Idle mode, press .
• To scroll through browser
items, press or .
• To select an item, press .
• To return to the previous page,
press , or press <
Options
>
and select
Back
.
• To access browser options,
press <
Menu
>.
Launch the
web browser
Navigate the
web
To the phone’s memory:
1. In Idle mode, enter a phone
number and press <
Save
>.
2. Select a number type.
3. Select
Phone Memory
.
4. Enter a name and press <
OK
>.
To t he SI M c ar d:
1. In Idle mode, enter a phone
number and press <
Save
>.
2. Select a number type.
3. Select
SIM Memory
.
4. Enter a name and press <
OK
>.
Add an entry
17
Step outside the phone
Send messages
1. In Idle mode, press
<
Contacts
> and select
Search
.
2. Enter the first few letters of the
name you want.
3. Select an entry.
4. Scroll to a number and press
or to dial.
1. In Idle mode, press <
Menu
>
and select
Messaging
→
Create New Message
→
Text
Message
.
2. Enter the message text and
press .
3. Enter a destination number and
press <
OK
>.
4. Press <
Options
> and select
Send Message
.
Find an entry
Send a text
message (SMS)
1. In Idle mode, press <
Menu
>
and select
Messaging
→
Create New Message
→
Multimedia Message
.
2. Press <
Options
> and select
Add subject
.
3. Enter the message subject and
press <
OK
>.
4. Press <
Options
> and select
Add Text
.
5. Enter the message text and
press .
6. Press <
Options
> and select
Add Image
,
Add Video
, or
Add Sound
.
7. Add an image, video clip, or
sound clip.
8. When you have finished, press
<
Options
> and select
Send
.
Send a
multimedia
message
(MMS)
18
Step outside the phone
View messages
9. Select a destination type.
10. Select
Phone Number
,
Email
Address
, or
Phone Book
.
11. Enter destination numbers or
e-mail addresses and press
<
OK
>.
12. Select
Send message
to send
the message.
1. With the phone closed, open
the display from left to right.
2. Select
Email
.
3. Press <
New Email
>.
4. Enter an e-mail subject and
press <
Next
>.
5. Enter the e-mail text.
6. Press <
Options
> and select
Send
.
Send an e-mail
7. Select a destination type.
8. Select
Manual Entry
,
Phone
Book
, or
History
.
9. Enter a destination e-mail
address, or select an address
from Phone Book or recent
message list and press <
OK
>.
10. Press <
Send
> to send the
e-mail.
When a notification appears:
Press <
View
>. The message
displays.
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messaging
→
My
Messages
→
Inbox
.
2. Select the text message ( ).
View a text
message
19
Step outside the phone
Use Bluetooth
Your phone is equipped with Bluetooth technology,
enabling you to connect the phone wirelessly to other
Bluetooth devices and exchange data with them, talk
hands-free, or control the phone remotely.
When a notification appears:
1. Press <
View
>.
2. Press <
Options
> and select
Retrieve
.
3. Select a message from the
Inbox.
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messaging
→
My
Messages
→
Inbox
.
2. Select the multimedia message
().
1. With the phone closed, open
the display from left to right.
2. Select
Email
.
View a
multimedia
message
View an e-mail
3. Select an e-mail or a header
from the message list.
4. If you selected a header, press
<
Options
> and select
Retrieve
to view the body of
the e-mail.
1. In Idle mode, press <
Menu
>
and select
Bluetooth
→
Activation
→
On
.
2. Select
My Phone’s Visibility
→
On
to allow other devices to
find your phone.
Turn on
Bluetooth
20
Step outside the phone
1. In Idle mode, press <
Menu
>
and select
Bluetooth
→
My
Devices
→
Search New
Device
.
2. Select a device.
3. Enter a Bluetooth PIN or the
other device’s Bluetooth PIN, if
it has one, and press <
OK
>.
When the owner of the other
device enters the same code,
pairing is complete.
Search for and
pair with a
Bluetooth
device
1. Access
File Manager
.
2. Select an item.
3. Press <
Options
> and select
Send via Bluetooth
.
4. Select a device.
5. If necessary, enter the
Bluetooth PIN and press <
OK
>.
To receive data via Bluetooth, your
phone’s Bluetooth feature must be
active.
If necessary, press <
Yes
> to
confirm that you are willing to
receive.
Send data
Receive data
21
Step outside the phone
Use voice recognition
Your phone can recognise specific voice commands to
dial numbers or access features.
1. In Idle mode, press .
2. Say “Call.”
3. Say a name or number.
4. If the name you hear is not
what you want, say “No.”
5. Say “Yes” when you hear what
you want.
6. Say the number type, if the
name has more than one
number.
Voice dialling
1. In Idle mode, press .
2. Say one of the following
commands.
•
Lookup
: say the contact
name you want to find.
•
Go To
: say the application
you want to access.
Access features
22
Enter text
ABC, T9, Number, and Symbol modes
You can enter text for some features, such as
Messaging, Phone Book, or Calendar, using ABC mode,
T9 mode, Number mode, and Symbol mode.
Changing the text input mode
The text input mode indicator displays when the
cursor is in a text field.
Example
: Writing a text message
Press the right soft key to change the input mode.
Using ABC mode
Press the appropriate key until the character you want
appears on the screen.
Write new
Options
Text input mode
•: T9 mode •: ABC mode
• : Number mode • None: Symbol mode
Characters in order displayed
Keys Upper case Lower case
Enter text
23
Other ABC mode operations
• To enter the same letter twice or to enter a
different letter on the same key, wait for the cursor
to move to the right automatically or press .
Then, enter the next letter.
• Press to insert a space.
• Press to shift case. Capital lock ( ), Lower
case ( ), and Initial capital ( ) are available.
• Press the Navigation keys to move the cursor.
• Press to delete characters one by one. Press
and hold to clear the display.
• Depending on your country, you may be able to
access an input mode for your specific language by
holding .
Using T9 mode
T9 is a predictive text input mode that allows you to
key in any character using single keystrokes.
Entering a word in T9 mode
1. Press or
to start entering a word. Press
each key once for each letter.
For example, press , , , , and to
enter HELLO in T9 mode.
T9 predicts the word that you are typing, and it
may change with each key that you press.
2. Enter the whole word before editing or deleting
characters.
3. When the word displays correctly, go to step 4.
Otherwise, press to display alternative word
choices for the keys that you have pressed.
For example, OF and ME use and .
4. Press to insert a space and enter the next
word.
T9 is not available in Landscape mode.
24
Enter text
Other T9 mode operations
• Press to enter periods or apostrophes
automatically.
• Press to insert a space.
• Press to shift case. Initial capital ( ), Capital
lock ( ), and Lower case ( ) are available.
• Press or to move the cursor.
• Press to delete characters one by one. Press
and hold to clear the display.
Adding a new word to the T9 dictionary
This feature may not be available for some languages.
1. Enter the word that you want to add.
2. Press to display alternative words for your key
presses. When there are no more alternative
words,
Add
appears on the bottom line.
3. Press <
Add
>.
4. Enter the word you want using ABC mode and
press <
OK
>.
Using Number mode
Number mode enables you to enter numbers.
Press the keys corresponding to the digits you want.
Using Symbol mode
Symbol mode enables you to insert symbols.
To Press
display more symbols or .
select a symbol the corresponding
number key.
clear the entered symbols .
insert the symbols <
OK
>.
25
Call functions
Advanced calling features
Making a call
1. In Idle mode, enter the area code and phone
number.
2. Press .
3. When you want to end the call, press .
Making an international call
1. In Idle mode, press and hold . The
+
character
appears.
2. Enter the country code, area code, and phone
number, then press .
Redialling recent numbers
1. In Idle mode, press to display the list of recent
numbers.
2. Scroll to the number you want and press .
Making a call from Phone Book
Once you have stored a number in Phone Book, you
can dial the number by selecting it from Phone
Book.
p. 60
You can also use the speed dial feature to assign your
most frequently called numbers to specific number
keys.
p. 61
You can quickly dial a number from the SIM card using
its location number assigned when stored.
1. In Idle mode, enter a location number and press
.
2. Press or to scroll through other numbers.
3. Press <
Dial
> or to dial the number you want.
• Press to clear the last digit or press and
hold to clear the whole display. You can
move the cursor to edit an incorrect digit.
• Press and hold to enter a pause
between numbers.
26
Call functions
Voice dialling
You can dial a number stored in Phone Book by
speaking the associated name into the microphone.
p. 21
Answering a call
When you receive an incoming call, the phone rings
and displays the incoming call image.
Press <
Accept
> or to answer the call.
Tips for answering a call
• When
Anykey
Answer
is active, you can press
any key, except for <
Reject
> and .
p. 64
• When
Active Folder
is active, you can simply
open the phone.
p. 64
•Press <
Reject
> or to reject a call.
Viewing missed calls
If you have missed calls, the screen displays how
many calls you have missed.
1. Press <
View
>.
2. If necessary, scroll through the missed calls.
3. Press to dial the number you want.
Using the headset
Use the headset to make or answer calls without
holding the phone.
Connect the headset to the jack on the left side of the
phone. The button on the headset works as follows:
To Press
redial the last call and hold the button twice.
answer a call the button.
end a call the button.
Call functions
27
Options during a call
You can access a number of functions during a call.
Adjusting the volume during a call
Use to adjust the earpiece volume during a call.
Press to increase the volume level and to
decrease the volume level.
Placing a call on hold/Retrieving
Press <
Hold
> or <
Retrieve
> to place a call on hold
or retrieve the call.
Making a second call
You can make another call if your network supports
this function.
1. Press <
Hold
> to put the call on hold.
2. Make the second call in the normal way.
3. Press <
Swap
> to switch between the calls.
4. Press <
Options
> and select
End
held
call
to end
the call on hold.
5. To end the current call, press .
Answering a second call
You can answer an incoming call while already on the
phone, if your network supports this function and you
have activated the call waiting feature.
p. 67
1. Press to answer the call. The first call is
automatically put on hold.
2. Press <
Swap
> to switch between the calls.
3. Press <
Options
> and select
End
held
call
to end
the call on hold.
4. To end the current call, press .
Using the speakerphone feature
Use the speakerphone feature to talk and listen with
the phone a short distance away.
Press to activate the speakerphone feature. Press
the key again to switch back to the earpiece.
28
Call functions
Using In-call options
Press <
Options
> to access the following options
during a call:
•
Menu
: access the phone's menu functions.
•
Mute
/
Unmute
: switch off the phone's microphone
so that the other person on the phone cannot hear
you, or switch it back on.
•
Mute Keys
/
Send Keys
: switch the key tones on
or off.
•
Send DTMF
: send the DTMF (Dual tone multi-
frequency) tones as a group. The DTMF tones are
the tones used in phones for tone dialling,
sounding when you press the number keys. This
option is helpful for entering a password or an
account number when you call an automated
system, like a banking service.
•
Phone Book
: access the contact list.
•
Join
: set up a multi-party call by adding a caller
on hold to a currently active call. You can include
up to 5 people on a multi-party call.
•
Select One
: select one of multi-party call
participants. You can then use the following
options:
Private
: have a private conversation with one
multi-party call participant. The other participants
can converse with each other. After the private
conversation, select
Join
to return to the multi-
party call.
Remove
: disconnect one multi-party call
participant.
•
End Held Call
: disconnect the call currently on
hold.
To communicate with answering machines or
computerised telephone systems,
Send
Keys
must be selected.
29
Menu functions
All menu options listed
Menus in Landscape mode
You can check call records, make memos and tasks,
and organise your Phone Book. You can also use the
E-mail services, Short Message Service (SMS), and
Bluetooth feature, and customise Landscape mode as
your preferences.
Accessing menus in Landscape mode
To access Landscape mode, open the display from left
to right. When you access Landscape mode, menu list
screen opens.
Navigating menus in Landscape mode
You can scroll through Landscape mode menus, and
confirm your selection or input by using the following
methods:
To Press
access the menu list .
scroll through menus , , , or , or
, , , .
select a menu item <
Select
>, , or .
delete the selected item .
return to the previous
menu level
<
Back
> or
30
Menu functions
Email
You can send and receive e-mails using the Email
feature.
Creating an e-mail
1. Select
Email
.
2. Press <
New Email
>.
3. Enter the subject of the e-mail and press <
Next
>.
4. Enter the e-mail text.
Press <
Options
> to access the following options:
•
Add Entry
: add a template, Phone Book entry,
or bookmark item.
•
Save As
: save the e-mail in the
Draft
box.
5. When you have finished, press <
Options
> and
select
Send
.
6. Select a destination type (To, Cc, Bcc).
7. Select one of
Manual Entry
,
Phone Book
, or
History
.
8. Enter an e-mail address or select an e-mail
address from the Phone Book list or recent
message list and press <
OK
>.
9. To send the e-mail to more destinations, repeat
steps 6 and 8.
10. When you have finished, press <
Send
>.
Viewing an e-mail
1. Select an e-mail or header from the message list.
2. Press [Left] or [Right] to view other pages in the
e-mail.
While viewing an e-mail or header, press <
Options
>
to access the following options:
•
Retrieve
: retrieve the body of the e-mail from the
e-mail server.
•
Reply
: send a reply to the sender or all of the
other recipients.
•
Forward
: forward the e-mail to other people.
• Press to change the letter case.
• Press to enter a special character. Press
and ho ld t o disp lay the sy mbol s creen .
• Press to enter a period.
•
Press to enter a space.
Menu functions
Menus in Landscape mode
31
•
Delete
: delete the e-mail.
•
Add to filtering list
: add the sender’s e-mail
address or subject to the Block list to reject
e-mails from that address or containing that
subject.
•
Copy entry
: extract URLs, e-mail addresses, or
phone numbers from the e-mail.
•
Copy media
: save the attached files from the
e-mail to your phone’s memory.
•
Protection
: protect the e-mail from being deleted.
•
Details
: access the e-mail properties.
SMS
Use this menu to access the list of the SMS messages
and create a new message.
• To view a message, select a message from the
message list.
p. 40
•Press <
New SMS
> to create a new text message.
p. 37
Call Log
Use this menu to access the list of call logs.
p. 35
Phone Book
Use this menu to access Phone Book.
• To view an entry, select an entry from the Phone
Book list.
p. 60
• Press <
New PhoneBook
> to add new entries.
p. 60
Todo
Use this menu to access the list of tasks for the
current date.
• To view a task, select a task from the task
list.
p. 52
• Press <
New Todo
> to add a new task.
p. 52
32
Menu functions
Calendar
Use this menu to access the list of appointments.
• To view a memo, select a memo from the
appointment list.
p. 51
•Press <
New Calendar
> to add a new
appointment.
p. 50
Bluetooth
Use this menu to use the Bluetooth feature.
p. 55
Services
Use this menu to customise settings for using the
Blackberry services.
•
BlackBerry On
: refreshe the network connection
to the BlackBerry server..
•
Reconcile
: synchronise e-mails in the phone’s
memory with the Blackberry server.
•
Purge Msg
: delete all of the e-mails on the
Blackberry server.
•
Service Book
: display the available Blackberry
services.
Settings
Use this menu to access BlackBerry service
information, or customise settings for using Landscape
mode.
•
Blackberry
: access the settings for the Blackberry
service.
Email
: set up the options for synchronising with
the e-mail server.
-
Delete on
: delete an e-mail in the phone’s
memory or on the server after retrieving it. If you
select
Prompt
, the phone will ask you if you
want t delete the e-mail.
-
Wireless reconcillation
: set wheter or not the
phone automatically connects to the email server
at regular internals to check for new emails.
-
On conflicts
: set the priority of synchronisation
when your e-mail data in the phone and on the
server is not reconciled.
Menu functions
Menus in Landscape mode
33
Host routing table
: register your device to a
BlackBerry infrastructure so that the device is
properly connected to a cellular network. Please
contact your service provider for further details on
the Host routing table (HRT).
Review GPRS Setup
: check GPRS information,
such as MMC, MNC, IMEI, IMSI, ICC, your phone’s
Blackberry PIN number, model name, device type,
and system and stack versions.
IT Policy
: access available Blackberry service
information.
Other Setup
: access other setup features.
Default Setup
: reset the e-mail settings to the
default setup or the last working setup.
•
Landscape
: customise the settings for using
Landscape mode:
Menu Style
: select the number of lines to be used
when displaying menus on your phone.
Short Cut
: display the functions assigned to the
keypad. You can change the shortcut menus.
Landscape Keypad Tone
: select a keypad tone.
Using Landscape mode menu options
When you access a menu, you can access the
following options by pressing <
Options
>:
•
Mail
: manage the e-mails you have received.
•
SMS
: delete the selected SMS message or all
messages, or access an SMS message stored in
another message box.
•
Call log
: dial or edit the selected number. You can
also delete the selected call log or all logs.
•
Phone Book
: dial or edit the selected entry. You
can also delete the selected number or all call
numbers.
•
Todo
: edit the selected calendar item or delete the
selected item or all items.
•
Calendar
: view the selected item or lock or unlock
the item. You can also delete the selected item or
all items.
•
New
: create a new e-mail, text message,
multimedia message, Phone Book entry, task,
calendar item, or template.
34
Menu functions
•
List
: access the list of e-mails, SMS messages, call
records, Phone Book entries, tasks, or calendar
items.
•
Search Mail
: search for mails stored in your
phone.
•
GAL
: search for specific addresses on the
Blackberry server by entering an e-mail address
and save them in Phone Book.
•
Bluetooth
: access the
Bluetooth
menu.
p. 55
•
Services
: access the
Services
menu.
p. 32
•
Settings
: access the
Settings
menu.
p. 32
•
About
: access the software, hardware, and
Blackberry version specifications for your phone.
Using shortcut menus
You can quickly access some menus by pressing the
shortcut keys in Landscape mode.
You can access the following menus:
•:
Call Log
•:
Bluetooth
•:
Address
•:
Email
•:
Calendar
•:
SMS
You can change the shortcut menus.
p. 33
Menu functions
Call Records
(Menu 1)
35
Call Records
(Menu 1)
Use this menu to view the calls you have dialled,
received, or missed, the length of your calls, and the
cost of your calls, if your SIM card supports this
function.
To access this menu, press <
Menu
> in Idle mode and
select
Call Records
.
Missed Calls
(Menu 1.1)
This menu displays the most recent calls you did not
answer.
Accessing a call record
1. Press or to scroll through the call list.
2. Press <
Select
> to view the details of a call, or
to dial the number.
Using call record options
While viewing call details, press <
Options
> to access
the following options:
•
Edit
: edit the number.
•
Delete
: delete the selected call record.
Received Calls
(Menu 1.2)
This menu displays the most recent calls you have
received.
Dialled Calls
(Menu 1.3)
This menu displays the most recent calls you have
dialled.
Voice Mail
(Menu 1.4)
Use this menu to store the number of the voicemail
server and access your voicemails.
•
Connect to Voice Mail
: connect to the voicemail
server to listen to your messages.
•
Voice Mail Number
: enter the voicemail server
number.
You must store the voicemail server number
before accessing the server. Your service
provider can give you the number.
36
Menu functions
Delete All
(Menu 1.5)
Use this menu to delete all of the records in each call
type.
1. Press to select the call types to be cleared.
2. Press <
Delete
>.
3. Press <
OK
> to confirm the deletion.
Call Time
(Menu 1.6)
This menu displays the time log for calls made and
received. The actual time invoiced by your service
provider will vary.
•
Last
Call
: check the length of your last call.
•
Total
Dialled
: check the total length of all the
calls you have dialled.
•
Total
Received
: check the total length of all the
calls you have received.
•
Reset Timers
: reset the call timers. You need to
enter the phone password.
Call Cost
(Menu 1.7)
This network feature displays the cost of calls. This
menu is available only if supported by your SIM card.
Note that this is not intended to be used for billing
purposes.
•
Last Call Cost
: check the cost of your last call.
•
Total Cost
: check the total cost of all of your calls.
If the total cost exceeds the maximum cost set in
Set Max Cost, you must reset the counter before
you can make another call.
•
Max Cost
: check the maximum cost limit set in
Set Max Cost.
•
Reset Counters
: reset the cost counters.
•
Set Max Cost
: set the maximum cost authorised
for your calls.
•
Price/Unit
: set the price per unit that is applied
when the cost of your calls is calculated.
The password is preset to
00000000
. You
can change this password.
p. 70
Menu functions
Messaging
(Menu 2)
37
Messaging
(Menu 2)
Use the
Messaging
menu to send and receive text
messages, multimedia messages, and e-mails. You
can also use Push message and Cell broadcast
message features.
To access this menu, press <
Menu
> in Idle mode and
select
Messaging
.
Create New Message
(Menu 2.1)
Use this menu to create and send messages.
Creating and sending a text message
Short Message Service (SMS) allows you to send or
receive text messages that may include simple
pictures, animated images, and melodies.
1. From the Create New Message screen, select
Text
Message
.
2. Enter your message and press .
3. Enter a destination number and press <
OK
>.
To send the message to more than one recipient,
repeat this step.
4. When you have finished, press <
Options
> and
select
Send Message
to send the message.
Using options while composing an SMS
message
While composing an SMS message, press <
Options
>
to access the following options:
•
Send to Number
: enter destination phone
numbers.
• The maximum number of characters
allowed in a message varies by service
provider. If your message exceeds the
maximum number of characters, the phone
will split the message.
•
You can use various message composing
options by pressing <
Options
> in each
field.
next section
38
Menu functions
•
Send to Email
: enter destination e-mail
addresses to send the message via e-mail.
p. 39
•
Insert
: add a template, Phone Book entry, or
bookmark item.
•
Add Media
: attach an animated image, melody, or
downloaded item.
•
Attach
: attach name cards or calender data as a
data format attachment.
•
Save Message to
: save the message in another
message box.
•
Language select
: change the language to be
used in T9 mode.
•
Text Style
: change the text attributes.
Creating and sending a multimedia message
Multimedia Message Service (MMS) delivers messages
containing a combination of text, image, video, and
audio, from phone to phone or from phone to e-mail.
1. From the Create New Message screen, select
Multimedia Message
.
2. Press <
Options
> and select
Add subject
.
3. Enter the message subject and press <
OK
>.
4. Press <
Options
> and select
Add Text
.
5. Enter the message text and press .
6. Press <
Options
> and select
Add Image
,
Add
Video
, or
Add Sound
.
7. Add an image, video clip, or sound clip.
8. When you have finished, press <
Options
> and
select
Send
.
9. Select a destination type (To, Cc, Bcc).
10. Select
Phone Number
,
Email Address
, or
Phone
Book
.
11. Enter a destination number or an e-mail address
and press <
OK
>.
12. When you have finished, select
Send message
.
You can use various message composing
options by pressing <
Options
> in each
field.
next section
Menu functions
Messaging
(Menu 2)
39
Using options while composing an MMS
message
While composing a message, press <
Options
> to
access the following options:
•
Add Text
: add the message text.
•
Add Image
: add an image to the message.
•
Add Video
: add a video clip to the message.
•
Add Sound
: add a sound clip to the message.
•
Add Subject
: add the message subject.
•
Add Page
: add pages. Move to each page by
pressing or .
•
Edit Text
: edit the message text.
•
Edit Picture
/
Edit Video
/
Edit Sound
: replace an
added item.
•
Delete
: delete the selected item.
•
Duration
: set how long one page displays. After
the specified time, the display automatically scrolls
to the next page.
•
Send
: send the message.
•
Save to
: save the message to another message
box.
•
Settings
: change the message settings.
p. 44
•
Add Destination
: enter destination numbers or
addresses.
•
Preview
: view the message as it will be shown on
the recipient’s phone.
Creating and sending an e-mail
You can send and receive e-mails that include text,
audio, and images.
1. From the Create New Message screen, select
Text
Message
.
2. Create an e-mail as you would create a text
message.
3. When you have finished, press <
Options
> and
select
Send to Email
.
4. Enter a destination e-mail address and press
to send the e-mail.
40
Menu functions
My Messages
(Menu 2.2)
Use this menu to access messages you have received,
sent, or failed to send.
Inbox
(Menu 2.2.1)
This folder stores all of the messages you have
received, except for e-mails.
Viewing a message
The following icons may appear on the message list to
show the message type:
• SMS
• MMS
• MMS notification ( : Being retrieved,
: Failed to retrieve)
• Voicemail
• Push message
• Cell broadcast message
Using message options
While viewing a message, press <
Options
> to access
the following options:
SMS messages
•
Reply
: send a reply to the sender.
•
Forward
: forward the message to other people.
•
Delete
: delete the message.
•
Callback
: call the sender.
•
Move to Myfolder
: move the message to another
message box.
•
Move to Phone/SIM
: move the message
between the SIM card and the phone’s memory.
•
Cut
Address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Cut Media/Attach
: save media content from the
message into your phone’s memory.
•
Protection
: protect the message from being
deleted.
A
!
icon next to a message means that a
message is of high priority. A grey-coloured
message icon is of low priority.
Menu functions
Messaging
(Menu 2)
41
MMS messages
•
Retrieve
: retrieve the MMS message from the
MMS server.
•
Reply
: send a reply to the sender.
•
Reply all
: send a reply to the sender or all
recipients.
•
Forward
: forward the message to other people.
•
Delete
: delete the message.
•
Callback
: call the sender.
•
Move to Myfolder
: move the message to another
message box.
•
Cut
Address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Cut Media/Attach
: save media content from the
message into your phone’s memory.
•
Properties
: access the message properties.
Sent
(Menu 2.2.2)
This folder stores messages that you have sent.
While viewing a message, press <
Options
> to access
the following options:
•
Delete
: delete the message.
•
Send
: send the message to other people.
•
Edit Message
: edit the message.
•
Move to Myfolder
: move the message to another
message box.
•
Cut Address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Call
: dial the number.
•
Protection
: protect the message from being
deleted.
42
Menu functions
Outbox
(Menu 2.2.3)
This folder stores messages that the phone is
attempting to send or has failed to send.
The following icons are available to show the message
status:
• Being sent
• Failed to send
While viewing a message, press <
Options
> to access
the following options:
•
Delete
: delete the message.
•
Send
: retry to send the message.
•
Move to Myfolder
: move the message to another
message box.
•
Cut Address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Callback
: dial the number.
•
Protection
: protect the message from being
deleted.
Draft
(Menu 2.2.4)
This folder stores messages you have saved to send at
a later time.
While viewing a message, press <
Options
> to access
the following options:
•
Delete
: delete the message.
•
Send
: send the message to other people.
•
Edit Message
/
Edit Email
: edit the message.
•
Move to Myfolder
/
Save to
: move the message
to another message box.
•
Cut Address
/
Extract Address
/
Save Address
:
extract URLs, e-mail addresses, or phone numbers
from the message.
•
Protection
: protect the message from being
deleted.
•
Properties
: access the message properties.
Menu functions
Messaging
(Menu 2)
43
My Folders
(Menu 2.2.5)
Use this menu to create new folders and organise your
messages.
Creating a folder
1. Press <
Yes
>.
2. Enter a folder name and press <
OK
>.
Using folder options
On the folder list, press <
Options
> to access the
following options:
•
Select
: open the selected folder.
•
Create Folder
: add a new folder.
•
Delete Folder
: delete the selected folder.
•
Rename Folder
: change the folder name.
•
Delete All
: delete all folders.
Templates
(Menu 2.3)
Use this menu to make and use templates of
frequently used text messages or passages.
Creating a template
1. Select an empty location.
2. Enter a message and press <
OK
>.
Using template options
From the template list, press <
Options
> to access
the following options:
•
Edit
: edit the selected template.
•
Send Message
: create and send a new message.
•
Delete
: delete the selected template.
•
Add New
: add a new template.
Delete All
(Menu 2.4)
Use this menu to delete messages in each message
folder.
1. Press to select the message folders to be
cleared.
2. Press <
Delete
>.
3. Press to select the check box to delete
protected messages.
4. Press <
Yes
> to confirm the deletion.
44
Menu functions
Settings
(Menu 2.5)
Use this menu to set up various options for using the
messaging service.
Text Message
(Menu 2.5.1)
You can configure default SMS settings.
•
Sending Profile
: set the properties of each
profile. Press <
Options
> and select
Edit
to access
the following options:
Service Center
: store or change the number of
your SMS server.
Default Destination
: enter the default
destination. It will be displayed on the first field on
the Recipients field.
Default Type
: set the default message type. The
network can convert the messages into the
selected format.
Default Validity
: set the length of time your
messages are stored in the SMS server.
Setting Name
: enter a profile name.
•
Reply Path
: allow recipients to reply to you
through your SMS server.
•
Delivery report
: set the network to inform you
when messages have been delivered.
•
Bearer selection
: select either
GSM
or
GPRS
,
depending on your network.
•
Preferred memory
: select the memory location
where messages will be saved after sending them.
Multimedia Message
(Menu 2.5.2)
You can configure default MMS settings.
•
Delivery Report
: set the network to inform you
when a message has been delivered.
•
Read Reply
: send a read-reply request along with
your messages.
•
Auto Download
: set the phone to automatically
retrieve messages from the server.
•
Message Acceptance
: select the category of
messages you want to retrieve.
•
Expiry Date
: set the length of time messages are
stored in the MMS server.
Menu functions
Messaging
(Menu 2)
45
•
Delivery Time
: set a time delay before messages
are sent.
•
Priority
: set the priority level of messages.
•
Report Allowed
: set the network to inform the
sender when a message has been delivered.
•
Page Duration
: set how long one page in your
outgoing messages displays. After a specified time,
the display automatically scrolls to the next page.
•
Profile
: select a connection profile to be used for
MMS.
Push Message
(Menu 2.5.3)
You can change the settings for receiving push
messages from the wireless web server.
•
Receive
: set how your phone receives push
messages.
•
White list
: select the wireless web server from
which you receive push messages.
Broadcast
(Menu 2.5.4)
You can change the settings for receiving CB
messages.
•
Receive
: select the reception of CB messages.
•
Channel List
: indicate the channels from which
you wish to receive CB messages. You can also
add, edit, or delete channels. Please contact your
service provider for further details.
•
Language
: select the preferred languages in
which CB messages display.
Default Text Input Mode
(Menu 2.5.5)
Use this menu to select the default text input mode to
be used when you create a message.
Memory Status
(Menu 2.6)
Use this menu to view the number of the messages or
the amount of memory currently in use for each
message type in each folder. You can access other
message types by pressing <
Next
>.
46
Menu functions
Games & Apps
(Menu 3)
Use this menu to play Java games, to record voice
memos, or to use convenient features, such as
calculator, converter, and world time.
To access this menu, press <
Menu
> in Idle mode and
select
Games & Apps
.
Games
(Menu 3.1)
Use this menu to access the embedded Java games
and downloaded Java applications.
Launching a game
Select a game from the game list and follow the
onscreen instructions. The procedure may differ from
game to game.
Using Java application options
From the Games list, press <
Options
> to access the
following options:
•
Launch
: launch the selected application.
•
Delete
: delete the selected application or all
applications, except for the embedded games.
•
Properties
: access the application properties.
•
Upgrade
: upgrade the application to the latest
version, except for embedded games.
•
Send Information
: send the URL containing the
application via SMS.
•
Memory status
: display the amount of total and
used memory for Java games.
Calculator
(Menu 3.2)
Use this menu to perform basic arithmetic functions,
such as addition, subtraction, multiplication, and
division.
1. Enter the first number.
•Press <
.()
> to insert a decimal point or
bracket.
•
Press
or
to move the cursor.
2. Press one of the Navigation keys to access the
math function you want.
3. Enter the second number.
4. Press to view the result.
Menu functions
Games & Apps
(Menu 3)
47
5. If necessary, repeat from step 2 to continue the
calculation.
Voice Memo
(Menu 3.3)
Use this menu to record and play voice memos.
Record Voice
(Menu 3.3.1)
1. Press <
Record
> to start recording.
2. Speak into the microphone.
3. When you press <
Stop
>, or if the recording time
expires, the following options display:
•
Replay
: play back your memo.
•
Re-record
: discard the memo and record
another one.
•
Save
: save the memo.
•
Quit
: cancel your recording and exit the
Record
menu.
4. Select
Save
to save the voice memo.
5. Enter a name for the voice memo and press
<
OK
>.
Voice List
(Menu 3.3.2)
Use this menu to access the list of voice memos you
have recorded.
Playing a memo
1. Scroll to a memo.
2. Press <
Options
> and select
Play
. The selected
memo plays.
Using memo options
Press <
Options
> to access the following options:
•
Play
: play the selected file.
•
Send
: send the file via MMS.
•
Rename
: change the file name.
•
Properties
: access the file properties.
•
Delete
: delete the file.
Delete All
(Menu 3.3.3)
Use this menu to delete all of the voice memos you
have recorded.
48
Menu functions
Memory Status
(Menu 3.3.4)
You can check the total amount of memory and the
amount of memory currently in use for voice memos.
Currency Conversion
(Menu 3.4)
Use this menu to do currency conversions.
1. Enter the exchange rate of foreign currency and
press <
OK
>.
2. Enter the amount of the foreign currency you want
to convert and press <
OK
>.
The amount you entered and its equivalent value
in the local currency display.
World Time
(Menu 3.5)
Use this menu to set your local time zone and find out
what time it is in another part of the world.
1. From the world map, press or to scroll to
the city you want. As the time line moves, the time
and date of the given zone display.
2. Press <
Set
> to save the city as your local time
zone.
SIM-AT
(Menu 3.6)
This menu is available if you use a SIM-AT card that
supports SIM Application Toolkit menus and provides
additional services, such as news, weather, sports,
entertainment, and location services. Available
services may vary, depending on your service
provider’s plans. For details, see your SIM card
instructions or contact your service provider.
Menu functions
Organiser
(Menu 4)
49
Organiser
(Menu 4)
The
Organiser
menu enables you to keep track of
your schedule and tasks. You can also set alarms or
create a task list.
To access this menu, press <
Menu
> in Idle mode and
select
Organiser
.
Alarm
(Menu 4.1)
Use this menu to set alarms to sound at a specific
time.
Setting an alarm
1. Select the type of alarm.
2. Enter the time for the alarm.
Press <
Options
> and select
Alarm Tone
to
change the alarm tone.
3. Press to save the alarm.
4. If you selected
Morning Call
in step 1, choose
Monday to Friday
or
Monday to Saturday
.
Stopping an alarm
When the alarm sounds, press any key.
Deactivating alarms
When you do not need an alarm to sound any longer,
you can deactivate it.
• To remove an alarm set, access it, press
<
Options
> and select
Remove Alarm
.
• To remove all alarm sets, select
Remove Alarm
from the
Alarm
menu.
Setting the alarm to sound when the phone is
off
From the Alarm screen, select
Autopower
→
Enable
.
If the phone is off when it is time for the alarm to
sound, the phone switches on and sounds the alarm.
50
Menu functions
Calendar
(Menu 4.2)
Use this menu to write appointments on your
schedule, or set alarms to act as a reminder.
Selecting a day on the calendar
When you access the
Calendar
menu, the calendar in
Month view appears with today’s date highlighted.
• Press or to move by day.
• Press or to move by week.
• Press to move by month.
Entering an appointment
1. Select a date on the calendar.
2. Press <
Options
> and select
Create
Appointment
.
3. Enter information or change the settings:
•
Subject
: enter the title of the appointment.
•
Details
: enter appointment details.
•
All Day
: set the phone to beep everyday.
•
Start Date
and
Start Time
: enter the starting
date and time for the appointment.
•
End Date
and
End Time
: enter the ending
date and time for the appointment.
•
Location
: enter information about the
appointment location.
•
Alarm
: set the following alarm options:
Set Alarm
: activate the alarm for the
appointment.
Before Time
: set how log before the
appointment the alarm is to alert you.
Alarm Tone
: select an alarm tone.
•
Time Zone
: set a local time zone.
•
Recurrence
: select to set the appointment to
recur and a repeat unit.
4. To add a To or Cc address to the appointment,
press <
Options
> and select
Add Required
or
Add Optional
. Enter an e-mail address.
5. When you have finished, press <
Options
> and
select
Send
.
Menu functions
Organiser
(Menu 4)
51
Consulting the calendar
The colour of the date on the calendar changes to blue
to indicate that an appointment exists for that date.
Viewing an appointment
1. Select a date which has appointments from the
calendar.
2. Press or to view other appointments
scheduled for that day.
From the appointment list, press <
Options
> to
access the following options:
•
View
: open the selected appointment.
•
Create Appointment
: add a new appointment.
•
Lock On
/
Lock Off
: lock the appointment to
protect it from being deleted, or unlock the
appointment.
•
View Mode
: change the view mode of the
calendar.
•
Delete
: delete the selected appointment or all
appointments stored on that date.
Using calendar options
On the calendar screen, press <
Options
> to access
the following options:
•
View Mode
: change the view mode of the
calendar.
•
Create Appointment
: enter a new appointment.
•
Go to
: select today’s date or enter a specific date.
•
Delete
: delete the appointments stored on that
day or the current month. You can also delete all
appointments stored on the calendar.
Viewing appointments in a different mode
You can change the calendar display to Day view or
Week view. Press <
Options
> and select
View mode
→
a view mode.
Day view
You can view items for the selected date. Select an
appointment to view its details.
52
Menu functions
Week view
You can view items for the selected week. A cell on the
timetable indicates the presence of an appointment.
Select a cell in the day you want.
To Do List
(Menu 4.3)
Use this menu to create tasks.
Creating a task
1. Press <
New
>.
2. Enter the task and press <
OK
>.
3. Select a priority level.
4. Enter your deadline and press <
OK
>.
Viewing the task list
When you select the
To Do List
menu, the tasks
display with a check mark, if the task has been done,
and a priority level indicator; for High, for
Normal, and for Low.
While viewing a task, press <
Options
> to access the
following options:
•
New
: add a new task.
•
Mark
: change the status of the task.
•
Edit
: edit the task.
•
Sort
: sort tasks by priority or status.
•
Copy
: copy the task.
•
Copy to Calendar
: copy the task to the calendar
as an appointment.
•
Delete
: delete the task.
•
Delete All
: delete all tasks.
•
Exit
: exit the
To Do List
menu.
You can change the status of a specific task by
pressing .
Menu functions
Browser
(Menu 5)
53
Browser
(Menu 5)
The Wireless Application Protocol (WAP) browser on
your phone allows you to access the wireless web.
From the wireless web, you can access up-to-date
information and a wide variety of media content, such
as games, wallpapers, ringtones, and music files.
To access this menu, press <
Menu
> in Idle mode and
select
Browser
.
Home
(Menu 5.1)
Use this menu to connect your phone to the network
and load the homepage of the wireless web service
provider. You can also press in Idle mode.
Navigating the web browser
Using page options
From any web page, press <
Options
> to access the
following options:
•
Favorite
: bookmark the current page or access
the bookmark list.
•
Reload
: reload the current page with updated
information.
•
Home
: return to the homepage.
•
Go to URL
: access the linked web page.
•
Show URL
: display the URL address of the page to
which you are currently connected.
•
Enter URL
: enter a URL address manually.
•
Go
: move backward or forward through pages in
history.
•
Clear Cache
: change the cache mode, set disk
cache use, or clear the cache. A cache is a
temporary memory that stores recently accessed
web pages.
•
Inbox
: access the messages received from the
web server.
To Press
scroll through browser items or .
select a browser item .
return to the previous page , or <
Options
>
and select
Back
.
54
Menu functions
•
Show Images
: show images stored on the
current web page.
•
Text Message
: send messages using web server.
•
Certificates
: access certificate information.
Exiting the web browser
Press to end the network connection and exit the
browser.
Favorites
(Menu 5.2)
Use this menu to save URL addresses in order to
quickly access web pages.
Accessing a bookmarked page
Select a bookmark item and choose
Goto URL
.
Using bookmark options
Press <
Options
> to access the following options:
•
Goto URL
: access the bookmarked web page.
•
Edit
: edit the URL address and title of the
bookmark.
•
Delete
: delete the selected bookmark.
•
Send URL
: send the URL via SMS/e-mail
message.
http://
(Menu 5.3)
Use this menu to manually enter a URL address and
access the associated web page.
Settings
(Menu 5.4)
Use this menu to select a connection profile to be used
for accessing the wireless web.
Clear Cache
(Menu 5.5)
Use this menu to clear information stored in the cache.
The cache is a temporary memory that stores recently
accessed web pages.
Menu functions
Bluetooth
(Menu 6)
55
Bluetooth
(Menu 6)
Using the Bluetooth feature, you can connect the
phone wirelessly to other Bluetooth devices and
exchange data with them, talk hands-free, or control
the phone remotely.
Bluetooth technology allows free wireless connections
between all Bluetooth-compliant devices within a
range of 10 meters. Since the devices communicate
using radio waves, they do not need to be in line of
sight to each other.
Setting up the Bluetooth feature
The
Bluetooth
menu provides the following options:
•
Activation
: activate or deactivate the Bluetooth
feature.
•
My Devices
: search for connectable Bluetooth
devices.
•
My Phone’s Visibility
: allow other Bluetooth
devices to locate your phone, or not.
•
My Phone’s Name
: assign a Bluetooth device
name to your phone, which is then displayed on
other devices.
•
Secure Mode
: determine if the phone asks for
your confirmation when other devices access your
data.
•
Bluetooth Services
: display available Bluetooth
services.
• If there are obstacles between the devices, the
operating distance may be reduced.
• It is recommended that you do not use the
Bluetooth feature while using multimedia
features, such as voice recorder or vice versa,
for better performance.
• Some devices may not be compatible with
your phone.
56
Menu functions
Searching for and pairing with a Bluetooth
device
1. From the Bluetooth setting options, select
My
Devices
.
2. Select
Search New Device
.
After searching, a list of devices to which you can
connect displays. The following icons indicate the
type of devices:
The colour of the icon indicates the status of the
the device:
• Grey for unpaired devices
• Blue for paired devices
• Red for devices that are currently connected to
your phone
3. Select a device.
4. Enter a Bluetooth PIN and press <
OK
>.
This code
is used just once and you do not need to memorise it.
When the owner of the other device enters the
same code, pairing is complete.
Using device options
From the device list, press <
Options
> to access the
following options:
•
Connect
: connect to a headset or hands-free car
kit.
•
Disconnect
: end the connection with the
connected device.
•
Browse Files
: search for data from the device and
import data directly to your phone.
•
Service List
: access the Bluetooth service list of
the device.
•
Rename
: rename the paired device.
• Headset • Hands-free car kit
• Computer • PDA
• Mobile phone • Unknown device
Some devices, especially headsets or hands-free
car kits, may have a fixed Bluetooth PIN, such as
0000
. If the other device has a code, you must
enter it.
Menu functions
Bluetooth
(Menu 6)
57
•
Authorize Device
/
Unauthorize Device
:
determine whether or not the phone asks you to
permit connection when other devices try to
connect to your phone.
•
Delete
: remove the selected device or all devices
from the list.
Sending data via Bluetooth
1. Activate the Bluetooth feature.
2. Select the application in which the item you want
to send is stored.
3. Select the item you want and press <
Options
>.
4. Select
Send via Bluetooth
.
The phone searches for devices within range and
displays a list of available devices.
5. Select a device.
6. If necessary, enter the Bluetooth PIN needed for
pairing and press <
OK
>.
Receiving data via Bluetooth
To receive data via Bluetooth, your phone’s Bluetooth
feature must be active and its visibility must be
enabled.
1. If an unauthorised Bluetooth device sends data to
your phone, press <
Yes
> to allow the device to
access your phone.
2. Press <
Yes
> to receive data.
58
Menu functions
File Manager
(Menu 7)
The
File Manager
menu allows you to access images,
video clips, and sound clips stored in the phone’s
memory.
To access this menu, press <
Menu
> in Idle mode and
select
File Manager
.
Sounds
(Menu 7.1)
This menu displays sound clips you have downloaded,
received in messages, or imported from your
computer.
While reviewing a file, press <
Options
> to access the
following options:
•
Rename
: change the file name.
•
Delete
: delete the selected file.
•
Send via MMS
: send the file via MMS.
•
Send via Bluetooth
: send the file via Bluetooth.
•
Set as Ring Tone
: set the sound clip as your
ringtone.
•
Properties
: access the file properties.
Images
(Menu 7.2)
This menu displays images downloaded, received in
messages, or imported from your computer.
While reviewing a file, press <
Options
> to access the
following options:
•
Rename
: change the file name.
•
Delete
: delete the file.
•
Send via MMS
: send the file via MMS.
•
Send via Bluetooth
: send the file via Bluetooth.
•
Set as Wallpaper
: set the image as your
wallpaper.
•
Properties
: access the file properties.
As a result of the DRM (Digital Rights
Management) system, some of the media items
you download from the Internet or receive by
MMS may require a license key to access them or
forward them to other people.
Menu functions
File Manager
(Menu 7)
59
Video
(Menu 7.3)
This menu displays video clips you have downloaded,
received in messages, or imported from your
computer.
While reviewing a file, press <
Options
> to access the
following options:
•
Rename
: change the file name.
•
Delete
: delete the file.
•
Send via MMS
: send the file via MMS.
•
Send via Bluetooth
: send the file via Bluetooth.
•
Properties
: access the file properties.
Other Files
(Menu 7.4)
Files that you have received but which are not
supported by your phone are stored in this folder. You
cannot open these files on the phone. Unsupported file
formats include DOC, XLS, PPT, PDF, and TXT.
From the file list, press <
Options
> to access the
following options:
•
Rename
: change the file name.
•
Delete
: delete the file.
•
Send via Bluetooth
: send the file via Bluetooth.
•
Properties
: access the file properties.
Delete All
(Menu 7.5)
Use this menu to delete media files in each media
folder.
1. Press to select the media folders to be cleared.
2. Press <
Delete
>.
3. Press <
Yes
> to confirm your deletion.
Memory Status
(Menu 7.6)
Use this menu to view memory information for media
items in each folder. You can scroll through other
media folders by pressing <
Next
>.
60
Menu functions
Phone Book
(Menu 8)
You can store phone numbers on your SIM card and in
your phone’s memory. The SIM card and phone’s
memory are physically separate, but they are used as
a single entity called Phone Book.
To access this menu, press <
Menu
> in Idle mode and
select
Phone Book
.
Search
(Menu 8.1)
Use this menu to search for numbers in Phone Book.
Finding an entry
1. Enter the first few letters of the name that you
want to find.
2. Select the name you want from the list.
3. Press to dial the number.
Using Phone Book options
While viewing an entry, press <
Options
> to access
the following options:
•
Edit
: edit entry information.
•
Send Message
: send a message to the number.
•
Paste
: paste the number into the normal dialling
mode.
•
Delete
: delete the number from Phone Book.
•
Copy
: copy the number to the phone’s memory or
SIM card.
•
Caller Group
: assign a caller group.
•
Add Entry
: add a new entry.
New Entry
(Menu 8.2)
Use this menu to add a new entry to Phone Book.
Storing an entry in the phone’s memory
1. Select an entry type.
• : Mobile phone number
• : Office phone number
• : Home phone number
• : E-mail address; an e-mail address can be
stored only in the phone’s memory
2. Select
Phone
Memory
.
3. Enter a name and press <
OK
>.
4. Enter a number or an e-mail address and press
<
Save
>.
Menu functions
Phone Book
(Menu 8)
61
Storing an entry on the SIM card
1. Select an entry type.
2. Select
SIM
Memory
.
3. Enter a name and press <
OK
>.
4. Enter a number and press <
Save
>
Group Search
(Menu 8.3)
Use this menu to search for your entries in Phone
Book in caller groups.
1. Enter the first few letters of the group name.
2. Select a group.
3. Select the name you want.
4. Press to dial the number or <
Options
> to
access Phone Book options.
Group Edit
(Menu 8.4)
Use this menu to edit your caller groups’ properties.
From the group list, press <
Options
> to access the
following options:
•
Call Ring Tone
: set a ringtone for incoming calls
from the group.
•
SMS Tone
: set a ringtone for incoming messages
from the group.
•
: set a graphic icon for incoming calls from
the group.
•
Group Name
: assign a name to the group.
Speed Dial
(Menu 8.5)
Use this menu to assign speed dial numbers (2 to 9) to
8 of your most frequently called numbers.
Assigning speed dial entries
1. Select a key location from
2
to
9
. Key
1
is reserved
for your voice mail server.
2. Select the name you want from the Phone Book
list.
62
Menu functions
3. Select the number you want.
Managing speed dial entries
From the Speed dial list, press <
Options
> to access
the following options:
•
Change
: assign a different number to a key.
•
Delete
: delete the speed dial setting for the key.
•
Delete All
: delete the speed dial settings for all
keys.
•
Number
: check the number assigned to a key.
Dialling speed dial numbers
In Idle mode, press and hold the appropriate key.
Delete All
(Menu 8.6)
Use this menu to delete all of the entries from Phone
Book.
1. Press to check the locations to be cleared.
2. Press <
Delete
>.
3. Enter the phone password and press <
OK
>.
4. Press <
Yes
> to confirm the deletion.
Own Number
(Menu 8.7)
Use this feature to check your phone numbers, or to
assign a name to each of the numbers. Changes made
here do not affect the actual subscriber numbers on
your SIM card.
Memory Status
(Menu 8.8)
Use this menu to check the total number of entries
you can store and the number of the entries you have
stored in Phone Book.
SDN
(Menu 8.9)
Use this menu to view the list of Service Dialling
Numbers (SDN) assigned by your service provider,
including emergency numbers and numbers for
directory enquiries. This menu is available if your SIM
card supports SDN.
1. Scroll to the number you want.
2. Press <
Dial
> or .
Menu functions
Settings
(Menu 9)
63
Settings
(Menu 9)
The
Settings
menu provides you with various setting
options to customise the phone as your preferences
and needs. You can also reset the settings to their
default values.
To access this menu, press <
Menu
> in Idle mode and
select
Settings
.
Time & Date
(Menu 9.1)
Use this menu to change the time and date displayed
on your phone. Before setting the time and date,
specify your time zone in the
World Time
menu.
p. 48
•
Set Time
: enter the current time.
•
Set Date
: enter the current date.
•
Time Format
: select a time format.
Phone Settings
(Menu 9.2)
Many different features of your phone’s system can be
customised to suit your preferences.
Language
(Menu 9.2.1)
Use this menu to select one of several languages for
the display text. If you select
Automatic
, the phone
uses the same language as the SIM card.
Greeting Message
(Menu 9.2.2)
Use this menu to enter the greeting that is displayed
briefly when the phone is switched on.
Short Cut
(Menu 9.2.3)
You can use the Navigation keys as shortcuts to access
specific menus directly from Idle mode. Use this menu
to assign a shortcut to a key.
1. Select a key to be used as a shortcut key.
2. Select a menu to be assigned to the key.
Some menus may not be available, depending on
your service provider.
64
Menu functions
Extra Settings
(Menu 9.2.4)
You can turn the automatic redialling or answering
feature on or off.
•
Auto Redial
: set the phone to make up to ten
attempts to redial a phone number after an
unsuccessful call.
•
Active Folder
: answer an incoming call by
opening the phone.
•
Anykey
Answer
: answer an incoming call by
pressing any key, except <
Reject
> and .
Display Settings
(Menu 9.3)
Use this menu to change settings for the display and
light.
Wallpaper
(Menu 9.3.1)
Use this menu to select an image to be displayed on
the idle screen.
Front LCD Display
(Menu 9.3.2)
Use this menu to change settings for the external
display.
•
Clock
: select a clock type.
•
LCD Brightness
: adjust the brightness of the
external display for varying lighting conditions.
Text Display
(Menu 9.3.3)
Use this menu to set the phone to display the time and
date on the idle screen.
Text Color
(Menu 9.3.4)
Use this menu to select a font colour.
Dialing Font Color
(Menu 9.3.5)
Use this menu to select a font colour for the numbers
entered while dialling.
Menu Style
(Menu 9.3.6)
You can select display style for the main menu screen.
Back Light
(Menu 9.3.7)
You can select the length of time the backlight or
display stays on.
•
On
: select the length of time the backlight stays
on.
Menu functions
Settings
(Menu 9)
65
•
Dim
: select the length of time the display stays in
Dim mode after the backlight turns off. After a
specified time, the display turns off.
Graphic Logo
(Menu 9.3.8)
Use this menu to set the phone to display a graphic
icon instead of the service provider’s logo on the idle
screen. This is only available if a graphic icon has been
received in a message.
Sound Settings
(Menu 9.4)
Use this menu to customise various sound settings.
Ring Tone
(Menu 9.4.1)
Use this menu to select a volume level and alert type
for incoming calls.
•
Default Ringtones
/
Downloaded Ringtones
:
select a ringtone for the call ringer.
•
Ring Volume
: select a ringer volume.
•
Alert Type
: specify how you are to be informed of
incoming calls.
Keypad Tone
(Menu 9.4.2)
Use this menu to select the tone type or volume that
the phone sounds when you press a key.
Message Tone
(Menu 9.4.3)
Use this menu to change the sound settings for
incoming text messages or multimedia messages.
•
Tone
: select one of several message tones.
•
Mode
: specify how you are to be informed that a
message comes in.
•
Repetition
: specify how often the phone informs
you of a new message.
Power On/Off
(Menu 9.4.4)
Use this menu to select the melody that the phone
sounds when it is switched on or off.
Folder Tone
(Menu 9.4.5)
Use this menu to select the tone that the phone
sounds when you open or close the phone.
You can adjust the keypad tone volume using
in Idle mode.
66
Menu functions
Alerts on Call
(Menu 9.4.6)
Use this menu to set the phone to beep when you
receive a new message or when the time for an alarm
comes during a call.
Quiet Mode
(Menu 9.4.7)
Use this menu to set how the phone acts to alert you
to a specific event in Quiet mode, instead of making
sounds.
Extra Tones
(Menu 9.4.8)
Use this menu to customise additional tones for the
phone.
•
Error
Tone
: set the phone to beep when you have
made a mistake or something wrong happens on
the phone.
•
Minute
Minder
: set the phone to beep every
minute during an outgoing call to keep you
informed of the length of your call.
•
Connect
Tone
: set the phone to beep when an
outgoing call is connected to the system.
Network Services
(Menu 9.5)
Use this menu to access network services. Please
contact your service provider to check their availability
and subscribe to them, if you wish.
Call Diverting
(Menu 9.5.1)
This network service reroutes incoming calls to a
phone number that you specify.
1. Select a call diverting option:
•
Divert always
: divert all calls.
•
Busy
: divert calls when you are on another
call.
•
No
reply
: divert calls when you do not answer
the phone.
•
Unreachable
: divert calls when you are not in
an area covered by your service provider or
when your phone is switched off.
•
Cancel
all
: cancel all call diverting options.
2. Select the type of calls to be diverted.
3. Press <
Activate
>. To deactivate call diverting,
press <
Deactivate
>.
Menu functions
Settings
(Menu 9)
67
4. Move to the
Divert to
line.
5. Enter the number to which calls are to be diverted.
6. If you selected
No Reply
, move to the
Seconds
line and select the length of time the network
delays before diverting a call.
7. Press <
Select
>.
Call Barring
(Menu 9.5.2)
This network service allows you to restrict your calls.
1. Select a call barring option:
•
All
Outgoing
: prohibit all outgoing calls.
•
International
: prohibit international calls.
•
International
Except to Home
: only allow
calls to numbers within the current country
when you are abroad, and to your home
country.
•
All
receiving
: prohibit incoming calls.
•
Receiving
While
Abroad
: prohibit incoming
calls when you use your phone outside of your
home country.
•
Cancel
all
: cancel all call barring settings,
allowing calls to be sent and received normally.
•
Change Barring Password
: change the call
barring password obtained from your service
provider.
2. Select the type of calls to be barred.
3. Press <
Activate
>. To deactivate call barring,
press <
Deactivate
>.
4. Enter the call barring password supplied by your
service provider and press <
Select
>.
Call Waiting
(Menu 9.5.3)
This network service informs you when someone is
trying to reach you while you are on another call.
1. Select the type of calls to which call waiting option
will apply.
2. Press <
Activate
>. To deactivate call waiting,
press <
Deactivate
>.
68
Menu functions
Network Selection
(Menu 9.5.4)
This network service allows you to manually select the
network to be used while roaming outside of your
home area, or to let the network be chosen
automatically.
You can select a network other than your home
network only if there is a valid roaming agreement
between the two.
Caller ID
(Menu 9.5.5)
This network service allows you to prevent your phone
number from being displayed on the phone of the
person being called. If you select
Default
, the phone
will use the default setting provided by the network.
Closed User Group
(Menu 9.5.6)
Use this menu to set incoming and outgoing calls to be
restricted to a selected user group. For details about
how to create a closed user group, contact your
service provider.
•
Index List
: add, delete, or activate CUG index
numbers.
•
Outside Access
: enable calls to numbers other
than those in the closed user group. This feature
depends on the nature of your CUG subscription.
•
Default Group
: enable the default CUG, if you
have set one with your service provider. When
making a call, you are given the option of using
your default CUG, instead of selecting one from the
list.
Band Selection
(Menu 9.5.7)
For the phone to make and receive phone calls, it
must register with an available network. Your phone
can handle any of the following types of networks:
GSM 1900 and Combined GSM 900/1800.
Some networks may not allow you to change this
setting.
69
The country where you purchased your phone
determines the default band that it uses. When you
travel abroad, you may need to change to an
appropriate band.
Voice Recognition
(Menu 9.6)
Use this menu to customise the settings for using the
Voice Recognition feature. The following options are
available:
•
Choice Lists
: use a choice list to review and
confirm names and numbers when you use the
Name
and
Lookup
commands. For each
command, the following options are available:
Automatic
: the phone displays a choice list only
when it is not sure if it has correctly recognised the
name or number.
Always On
: the phone always displays a choice
list, even when there is only one choice.
Always Off
: the phone never displays a choice
list.
•
Sensitivity
: adjust the sensitivity in which your
phone recognises your voice commands.
•
Digit Dialing
: change the settings for digit
dialling.
Adapt Digits
: adapt your voice for digits.
Reset Digits
: reset settings for digit dialling.
•
Sound
: change the sound settings for the Voice
Recognition feature.
Prompts
: turn on or off the prompt beep.
Digits
: turn on or off the number playback.
Names
: turn on or off the name playback.
Name Settings
: change the speed of the name
playback or adjust the volume of the name
playback.
•
Language
: select a country for your language.
•
About
: show information about the Voice
Recognition feature.
70
Menu functions
Security
(Menu 9.7)
Use this menu to protect the phone against
unauthorised use by managing the several access
codes of your phone and SIM card.
PIN Check
(Menu 9.7.1)
The 4- to 8-digit PIN (Personal Identification Number)
protects your SIM card against unauthorised use.
When this feature is enabled, the phone requires your
PIN each time it is switched on.
Change PIN
(Menu 9.7.2)
Use this menu to change your PIN. The PIN Check
feature must be enabled to use this feature.
Phone Lock
(Menu 9.7.3)
Use this menu to lock the phone from unauthorised
use.
When this feature is enabled, you must enter a 4- to
8-digit phone password each time the phone is
switched on.
The password is preset to
00000000
. To change the
password, use the
Change Password
menu.
Change Password
(Menu 9.7.4)
Use this menu to change your phone password.
Privacy
(Menu 9.7.5)
Use this menu to lock access to messages, files, or all
menu functions on the phone, except for call
functions.
When a privacy option is enabled, you must enter the
phone password to access the locked items or
functions.
If you enter an incorrect PIN/PIN2 three times in
succession, the SIM card is blocked. To unblock
it, you need to enter your PUK/PUK2 (Personal
Unblocking Key). The codes are supplied by your
service provider.
71
SIM Lock
(Menu 9.7.6)
The SIM Lock feature allows your phone to work only
with the current SIM by assigning a SIM lock code. You
must enter the SIM lock code to use a different SIM
card.
FDN Mode
(Menu 9.7.7)
If supported by your SIM card, Fixed Dialling Number
(FDN) mode restricts your outgoing calls to a limited
set of phone numbers. When this feature is enabled,
you can make calls only to phone numbers stored on
the SIM card.
Change PIN2
(Menu 9.7.8)
If supported by your SIM card, use this feature to
change your current PIN2.
Connection Settings
(Menu 9.8)
Use this menu to create and customise the profiles
containing the settings for connecting your phone to
the network. You need these settings to use the web
browser or send MMS messages or SMS/e-mail
messages.
Editing a profile
1. Scroll to the profile you want.
2. Press <
Options
> and select
Edit
.
3. Specify profile parameters:
•
Profile Name
: enter a profile name.
•
Homepage URL
: enter the address of the web
homepage of your service provider.
Your phone is suited for connecting to the
network by default. If you change the settings
without first checking with your service provider,
the web browser, MMS, e-mail features may not
work properly.
72
•
Bearer
: select a bearer for each type of
network address accessed;
GPRS
or
DATA
.
•
Proxy Setting
: set the IP address and port
number for the proxy server.
•
User Name
: enter the user name.
•
Password
: enter the login password.
•
APN
: enter the access point name.
•
Proxy Status
: activate or deactivate the proxy
server.
•
Primary DNS
: enter the primary address.
•
Secondary DNS
: enter the secondary
address.
Reset Settings
(Menu 9.9)
Use this menu to reset the phone’s settings you have
changed.
Enter the 4- to 8-digit phone password and press
<
OK
>.
Solve problems
Help and personal needs
To save the time and expense of an unnecessary service
call, perform the simple checks in this section before
contacting a service professional.
When you switch on your phone, the following
messages may appear:
“Insert SIM card”
• Be sure that the SIM card is correctly installed.
“Phone locked Enter password”
• The automatic locking function has been enabled.
You must enter the phone’s password before you
can use the phone.
“Enter PIN”
• You are using your phone for the first time. You
must enter the PIN supplied with the SIM card.
• The PIN check feature is enabled. Every time the
phone is switched on, the PIN has to be entered.
To disable this feature, use the
PIN Check
menu.
Solve problems
73
“Enter PUK”
• The PIN code has been entered incorrectly three
times in succession, and the phone is now blocked.
Enter the PUK supplied by your service provider.
“No service,” “Network failure,” or “Not done”
displays
• The network connection has been lost. You may be
in a weak signal area. Move and try again.
• You are trying to access an option for which you
have no subscription with your service provider.
Contact the service provider for further details.
You have entered a number but it was not dialled
• Be sure that you have pressed .
• Be sure you have accessed the right cellular
network.
• Be sure that you have not set an outgoing call
barring option.
Your correspondent cannot reach you
• Be sure that your phone is switched on. (
pressed for more than one second.)
• Be sure that you are accessing the correct cellular
network.
• Be sure that you have not set an incoming call
barring option.
Your correspondent cannot hear you speaking
• Be sure that you have switched on the
microphone.
• Be sure that you are holding the phone close
enough to your mouth. The microphone is located
at the bottom of the phone.
The phone starts beeping and “Warning low
battery” flashes on the display
• Your battery is insufficiently charged. Recharge the
battery.
The audio quality of the call is poor
• Check the signal strength indicator on the display
( ). The number of bars indicates the signal
strength from strong ( ) to weak ( ).
• Try moving the phone slightly or moving closer to a
window if you are in a building.
74
No number is dialled when you re-call a Phone
Book entry
•Use the
Search
feature to ensure the number has
been stored correctly.
• Re-store the number, if necessary.
The battery doesn’t charge properly or the phone
sometimes turns itself off
• Wipe the charging contacts both on the phone and
on the battery with a clean soft cloth.
If the above guidelines do not help you to solve
the problem, take note of:
• The model and serial numbers of your phone
•Your warranty details
• A clear description of the problem
Then contact your local dealer or Samsung after-sales
service.
Health and safety information
75
Health and safety information
Exposure to Radio Frequency (RF) Signals
Certification Information (SAR)
Your wireless phone is a radio transmitter and receiver.
It is designed and manufactured not to exceed the
exposure limits for radio frequency (RF) energy set by
the Federal Communications Commission (FCC) of the
U.S. government. These FCC exposure limits are
derived from the recommendations of two expert
organizations, the National Counsel on Radiation
Protection and Measurement (NCRP) and the Institute
of Electrical and Electronics Engineers (IEEE). In both
cases, the recommendations were developed by
scientific and engineering experts drawn from
industry, government, and academia after extensive
reviews of the scientific literature related to the
biological effects of RF energy.
The exposure limit set by the FCC for wireless mobile
phones employs a unit of measurement known as the
Specific Absorption Rate (SAR). The SAR is a measure
of the rate of absorption of RF energy by the human
body expressed in units of watts per kilogram (W/kg).
The FCC requires wireless phones to comply with a
safety limit of 1.6 watts per kilogram (1.6 W/kg). The
FCC exposure limit incorporates a substantial margin
of safety to give additional protection to the public and
to account for any variations in measurements.
SAR tests are conducted using standard operating
positions accepted by the FCC with the phone
transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is
determined at the highest certified power level, the
actual SAR level of the phone while operating can be
well below the maximum value. This is because the
phone is designed to operate at multiple power levels
so as to use only the power required to reach the
network. In general, the closer you are to a wireless
base station antenna, the lower the power output.
76
Health and safety information
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that
it does not exceed the exposure limit established by
the FCC. Tests for each model phone are performed in
positions and locations (e.g. at the ear and worn on
the body) as required by the FCC.
The highest SAR values for this model phone as
reported to the FCC are Head: 0.611W/Kg, Body-worn:
0.932W/Kg.
For body worn operations, this model phone has been
testde and meets the FCC exposure guidelines when
used with a Samsung accessory designated for this
product or when used with an accessroy that contains
no metal and that positons the handset a minimum
1.5 cm from the body.
Non-compliance with the above restrictions may result
in violation of FCC RF exposure guidelines.
SAR information on this and other model phones can
be viewed on-line at www.fcc.gov/oet/fccid. This site
uses the phone FCC ID number A3LSGHD300.
Sometimes it may be necessary to remove the battery
pack to find the number. Once you have the FCC ID
number for a particular phone, follow the instructions
on the website and it should provide values for typical
or maximum SAR for a particular phone. Additional
product specific SAR information can also be obtained
at www.fcc.gov/cgb/sar.
Health and safety information
Consumer Information on Wireless Phones
The U.S. Food and Drug Administration (FDA) has
published a series of Questions and Answers for
consumers relating to radio frequency (RF) exposure
from wireless phones. The FDA publication includes
the following information:
What kinds of phones are the subject of this
update?
The term wireless phone refers here to hand-held
wireless phones with built-in antennas, often called
“cell,” “mobile,” or “PCS” phones. These types of
wireless phones can expose the user to measurable
radio frequency energy (RF) because of the short
distance between the phone and the user's head.
These RF exposures are limited by Federal
Communications Commission safety guidelines that
were developed with the advice of FDA and other
federal health and safety agencies. When the phone is
located at greater distances from the user, the
exposure to RF is drastically lower because a person's
RF exposure decreases rapidly with increasing
distance from the source. The so-called “cordless
phones,” which have a base unit connected to the
telephone wiring in a house, typically operate at far
lower power levels, and thus produce RF exposures
well within the FCC's compliance limits.
Do wireless phones pose a health hazard?
The available scientific evidence does not show that
any health problems are associated with using
wireless phones. There is no proof, however, that
wireless phones are absolutely safe. Wireless phones
emit low levels of radio frequency energy (RF) in the
microwave range while being used. They also emit
very low levels of RF when in the stand-by mode.
Whereas high levels of RF can produce health effects
(by heating tissue), exposure to low level RF that does
not produce heating effects causes no known adverse
health effects. Many studies of low level RF exposures
have not found any biological effects. Some studies
have suggested that some biological effects may
occur, but such findings have not been confirmed by
additional research. In some cases, other researchers
have had difficulty in reproducing those studies, or in
determining the reasons for inconsistent results.
77
78
Health and safety information
What is FDA's role concerning the safety of
wireless phones?
Under the law, FDA does not review the safety of
radiation-emitting consumer products such as wireless
phones before they can be sold, as it does with new
drugs or medical devices. However, the agency has
authority to take action if wireless phones are shown
to emit radio frequency energy (RF) at a level that is
hazardous to the user. In such a case, FDA could
require the manufacturers of wireless phones to notify
users of the health hazard and to repair, replace or
recall the phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA
regulatory actions, FDA has urged the wireless phone
industry to take a number of steps, including the
following:
• “Support needed research into possible biological
effects of RF of the type emitted by wireless
phones;
• “Design wireless phones in a way that minimizes
any RF exposure to the user that is not necessary
for device function; and
• “Cooperate in providing users of wireless phones
with the best possible information on possible
effects of wireless phone use on human health.
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at
the federal level. The following agencies belong to this
working group:
• “National Institute for Occupational Safety and
Health
• “Environmental Protection Agency
• “Federal Communications Commission
• “Occupational Safety and Health Administration
• “National Telecommunications and Information
Administration
The National Institutes of Health participates in some
interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless
phones with the Federal Communications Commission
(FCC). All phones that are sold in the United States
must comply with FCC safety guidelines that limit RF
Health and safety information
exposure. FCC relies on FDA and other health agencies
for safety questions about wireless phones.
FCC also regulates the base stations that the wireless
phone networks rely upon. While these base stations
operate at higher power than do the wireless phones
themselves, the RF exposures that people get from
these base stations are typically thousands of times
lower than those they can get from wireless phones.
Base stations are thus not the primary subject of the
safety questions discussed in this document.
What are the results of the research done
already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws in
their research methods. Animal experiments
investigating the effects of radio frequency energy
(RF) exposures characteristic of wireless phones have
yielded conflicting results that often cannot be
repeated in other laboratories. A few animal studies,
however, have suggested that low levels of RF could
accelerate the development of cancer in laboratory
animals. However, many of the studies that showed
increased tumor development used animals that had
been genetically engineered or treated with cancer-
causing chemicals so as to be pre-disposed to develop
cancer in absence of RF exposure. Other studies
exposed the animals to RF for up to 22 hours per day.
These conditions are not similar to the conditions
under which people use wireless phones, so we don't
know with certainty what the results of such studies
mean for human health.
Three large epidemiology studies have been published
since December 2000. Between them, the studies
investigated any possible association between the use
of wireless phones and primary brain cancer, glioma,
meningioma, or acoustic neuroma, tumors of the brain
or salivary gland, leukemia, or other cancers. None of
the studies demonstrated the existence of any harmful
health effects from wireless phones RF exposures.
However, none of the studies can answer questions
about long-term exposures, since the average period
of phone use in these studies was around three years.
79
80
Health and safety information
What research is needed to decide whether RF
exposure from wireless phones poses a health
risk?
A combination of laboratory studies and
epidemiological studies of people actually using
wireless phones would provide some of the data that
are needed. Lifetime animal exposure studies could be
completed in a few years. However, very large
numbers of animals would be needed to provide
reliable proof of a cancer promoting effect if one
exists. Epidemiological studies can provide data that is
directly applicable to human populations, but ten or
more years' follow-up may be needed to provide
answers about some health effects, such as cancer.
This is because the interval between the time of
exposure to a cancer-causing agent and the time
tumors develop - if they do - may be many, many
years. The interpretation of epidemiological studies is
hampered by difficulties in measuring actual RF
exposure during day-to-day use of wireless phones.
Many factors affect this measurement, such as the
angle at which the phone is held, or which model of
phone is used.
What is FDA doing to find out more about the
possible health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology
Program and with groups of investigators around the
world to ensure that high priority animal studies are
conducted to address important questions about the
effects of exposure to radio frequency energy (RF).
FDA has been a leading participant in the World Health
Organization international Electromagnetic Fields
(EMF) Project since its inception in 1996. An influential
result of this work has been the development of a
detailed agenda of research needs that has driven the
establishment of new research programs around the
world. The Project has also helped develop a series of
public information documents on EMF issues.
FDA and Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative
Research and Development Agreement (CRADA) to do
research on wireless phone safety. FDA provides the
scientific oversight, obtaining input from experts in
government, industry, and academic organizations.
CTIA-funded research is conducted through contracts
Health and safety information
to independent investigators. The initial research will
include both laboratory studies and studies of wireless
phone users. The CRADA will also include a broad
assessment of additional research needs in the
context of the latest research developments around
the world.
What steps can I take to reduce my exposure
to radio frequency energy from my wireless
phone?
If there is a risk from these products - and at this
point we do not know that there is - it is probably very
small. But if you are concerned about avoiding even
potential risks, you can take a few simple steps to
minimize your exposure to radio frequency energy
(RF). Since time is a key factor in how much exposure
a person receives, reducing the amount of time spent
using a wireless phone will reduce RF exposure.
• “If you must conduct extended conversations by
wireless phone every day, you could place more
distance between your body and the source of the
RF, since the exposure level drops off dramatically
with distance. For example, you could use a
headset and carry the wireless phone away from
your body or use a wireless phone connected to a
remote antenna.
Again, the scientific data do not demonstrate that
wireless phones are harmful. But if you are concerned
about the RF exposure from these products, you can
use measures like those described above to reduce
your RF exposure from wireless phone use.
What about children using wireless phones?
The scientific evidence does not show a danger to
users of wireless phones, including children and
teenagers. If you want to take steps to lower exposure
to radio frequency energy (RF), the measures
described above would apply to children and
teenagers using wireless phones. Reducing the time of
wireless phone use and increasing the distance
between the user and the RF source will reduce RF
exposure.
Some groups sponsored by other national
governments have advised that children be
81
Health and safety information
Settings
discouraged from using wireless phones at all. For
example, the government in the United Kingdom
distributed leaflets containing such a recommendation
in December 2000. They noted that no evidence exists
that using a wireless phone causes brain tumors or
other ill effects. Their recommendation to limit
wireless phone use by children was strictly
precautionary; it was not based on scientific evidence
that any health hazard exists.
Do hands-free kits for wireless phones reduce
risks from exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that hands-free kits reduce risks. Hands-free
kits can be used with wireless phones for convenience
and comfort. These systems reduce the absorption of
RF energy in the head because the phone, which is the
source of the RF emissions, will not be placed against
the head. On the other hand, if the phone is mounted
against the waist or other part of the body during use,
then that part of the body will absorb more RF energy.
Wireless phones marketed in the U.S. are required to
meet safety requirements regardless of whether they
are used against the head or against the body. Either
configuration should result in compliance with the
safety limit.
Do wireless phone accessories that claim to
shield the head from RF radiation work?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that accessories that claim to shield the head
from those emissions reduce risks. Some products
that claim to shield the user from RF absorption use
special phone cases, while others involve nothing
more than a metallic accessory attached to the phone.
Studies have shown that these products generally do
not work as advertised. Unlike “hand-free” kits, these
so-called “shields” may interfere with proper operation
of the phone. The phone may be forced to boost its
power to compensate, leading to an increase in RF
absorption. In February 2002, the Federal trade
Commission (FTC) charged two companies that sold
devices that claimed to protect wireless phone users
from radiation with making false and unsubstantiated
82
Health and safety information
claims. According to FTC, these defendants lacked a
reasonable basis to substantiate their claim.
What about wireless phone interference with
medical equipment?
Radio frequency energy (RF) from wireless phones can
interact with some electronic devices. For this reason,
FDA helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted
cardiac pacemakers and defibrillators from wireless
telephones. This test method is now part of a standard
sponsored by the Association for the Advancement of
Medical instrumentation (AAMI). The final draft, a joint
effort by FDA, medical device manufacturers, and
many other groups, was completed in late 2000. This
standard will allow manufacturers to ensure that
cardiac pacemakers and defibrillators are safe from
wireless phone EMI. FDA has tested wireless phones
and helped develop a voluntary standard sponsored by
the Institute of Electrical and Electronic Engineers
(IEEE). This standard specifies test methods and
performance requirements for hearing aids and
wireless phones so that no interference occurs when a
person uses a compatible phone and a compatible
hearing aid at the same time. This standard was
approved by the IEEE in 2000.
FDA continues to monitor the use of wireless phones
for possible interactions with other medical devices.
Should harmful interference be found to occur, FDA
will conduct testing to assess the interference and
work to resolve the problem.
Additional information on the safety of RF exposures
from various sources can be obtained from the
following organizations:
• FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
• Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
• Occupational Safety and Health Administration's
(OSHA):
http://www.osha.gov/SLTC/
radiofrequencyradiation/index.html
83
Health and safety information
Settings
• National institute for Occupational Safety and
Health (NIOSH):
http://www.cdc.gov/niosh/emfpg.html
• World health Organization (WHO):
http://www.who.int/peh-emf/
• International Commission on Non-Ionizing
Radiation Protection:
http://www.icnirp.de
• National Radiation Protection Board (UK):
http://www.nrpb.org.uk
• Updated 4/3/2002: US food and Drug
Administration
http://www.fda.gov/cellphones
Road Safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime.
But an important responsibility accompanies the
benefits of wireless phones, one that every user must
uphold.
When driving a car, driving is your first responsibility.
When using your wireless phone behind the wheel of a
car, practice good common sense and remember the
following tips:
1. Get to know your wireless phone and its features,
such as speed dial and redial. If available, these
features help you to place your call without taking
your attention off the road.
2. When available, use a hands-free device. If
possible, add an additional layer of convenience
and safety to your wireless phone with one of the
many hands free accessories available today.
84
Health and safety information
3. Position your wireless phone within easy reach. Be
able to access your wireless phone without
removing your eyes from the road. If you get an
incoming call at an inconvenient time, let your
voice mail answer it for you.
4. Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy
traffic or hazardous weather conditions. Rain,
sleet, snow, ice and even heavy traffic can be
hazardous.
5. Do not take notes or look up phone numbers while
driving. Jotting down a “to do” list or flipping
through your address book takes attention away
from your primary responsibility, driving safely.
6. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan calls when your car
will be stationary. If you need to make a call while
moving, dial only a few numbers, check the road
and your mirrors, then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting. Make
people you are talking with aware you are driving
and suspend conversations that have the potential
to divert your attention from the road.
8. Use your wireless phone to call for help. Dial 9-1-1
or other local emergency number in the case of
fire, traffic accident or medical emergencies.
Remember, it is a free call on your wireless phone!
9. Use your wireless phone to help others in
emergencies. If you see an auto accident, crime in
progress or other serious emergency where lives
are in danger, call 9-1-1 or other local emergency
number, as you would want others to do for you.
10. Call roadside assistance or a special non-
emergency wireless assistance number when
necessary. If you see a broken-down vehicle
posing no serious hazard, a broken traffic signal, a
minor traffic accident where no one appears
injured, or a vehicle you know to be stolen, call
roadside assistance or other special non-
emergency number.
85
Health and safety information
Settings
“The wireless industry reminds you to use your
phone safely when driving.”
For more information, please call 1-888-901-SAFE, or
visit our web-site www.wow-com.com
Provided by the Cellular Telecommunications &
Internet Association
Operating Environment
Remember to follow any special regulations in force in
any area and always switch your phone off whenever it
is forbidden to use it, or when it may cause
interference or danger. When connecting the phone or
any accessory to another device, read its user's guide
for detailed safety instructions. Do not connect
incompatible products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation of
the equipment and for the safety of personnel, it is
recommended that the equipment should only be used
in the normal operating position (held to your ear with
the antenna pointing over your shoulder).
Using Your Phone Near Other Electronic
Devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against the
RF signals from your wireless phone. Consult the
manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be maintained
between a wireless phone and a pacemaker to avoid
potential interference with the pacemaker.
These recommendations are consistent with the
independent research and recommendations of
Wireless Technology Research.
Persons with pacemakers:
• should always keep the phone more than 15 cm
(6 inches) from their pacemaker when the phone is
switched on.
• should not carry the phone in a breast pocket.
86
Health and safety information
• should use the ear opposite the pacemaker to
minimize potential interference.
If you have any reason to suspect that interference is
taking place, switch your phone off immediately.
Hearing Aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you
may wish to consult your hearing aid manufacturer to
discuss alternatives.
Other Medical Devices
If you use any other personal medical devices, consult
the manufacturer of your device to determine if it is
adequately shielded from external RF energy. Your
physician may be able to assist you in obtaining this
information. Switch your phone off in health care
facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care facilities
may be using equipment that could be sensitive to
external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle. You should also
consult the manufacturer of any equipment that has
been added to your vehicle.
Posted Facilities
Switch your phone off in any facility where posted
notices require you to do so.
Potentially Explosive Environments
Switch your phone off when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause an
explosion or fire resulting in bodily injury or even
death.
Users are advised to switch the phone off while at a
refueling point (service station). Users are reminded of
the need to observe restrictions on the use of radio
equipment in fuel depots (fuel storage and distribution
87
Health and safety information
Settings
areas), chemical plants or where blasting operations
are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas (such
as propane or butane), areas where the air contains
chemicals or particles, such as grain, dust or metal
powders, and any other area where you would
normally be advised to turn off your vehicle engine.
Emergency Calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well as
user programmed functions, which cannot guarantee
connection in all conditions. Therefore, you should
never rely solely on any wireless phone for essential
communications (medical emergencies, for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not be
possible on all wireless phone networks or when
certain network services and/or phone features are in
use. Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location (for example, 911 or other official
emergency number). Emergency numbers vary by
location.
3. Press .
If certain features are in use (call barring, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult this document and your local cellular service
provider.
When making an emergency call, remember to give all
the necessary information as accurately as possible.
Remember that your phone may be the only means of
communication at the scene of an accident; do not cut
off the call until given permission to do so.
88
Health and safety information
Restricting Children's access to your Phone
Your phone is not a toy. Children should not be allowed
to play with it because they could hurt themselves and
others, damage the phone or make calls that increase
your phone bill.
FCC Notice and Cautions
FCC Notice
• This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
• This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses and
can radiate radio frequency energy and,
if not installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try
to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment
and receiver.
-Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV
technician for help
89
The phone may cause TV or radio interference if used
in close proximity to receiving equipment. The FCC
can require you to stop using the phone if such
interference cannot be eliminated.
Vehicles using liquefied petroleum gas (such as
propane or butane) must comply with the National Fire
Protection Standard (NFPA-58). For a copy of this
standard, contact the National Fire Protection
Association, One Battery march Park, Quincy, MA
02269, Attn: Publication Sales Division.
103
Cautions
Changes or modifications made in the radio phone, not
expressly approved by Samsung, will void the user’s
authority to operate the equipment.
Only use approved batteries, antennas and chargers.
The use of any unauthorized accessories may be
dangerous and void the phone warranty if said
accessories cause damage or a defect to the phone.
Although your phone is quite sturdy, it is a complex
piece of equipment and can be broken. Avoid
dropping, hitting, bending or sitting on it.
90
91
Health and safety information
Settings
Other Important Safety Information
• Only qualified personnel should service the phone
or install the phone in a vehicle. Faulty installation
or service may be dangerous and may invalidate
any warranty applicable to the device.
• Check regularly that all wireless phone equipment
in your vehicle is mounted and operating properly.
• Do not store or carry flammable liquids, gases or
explosive materials in the same compartment as
the phone, its parts or accessories.
• For vehicles equipped with an air bag, remember
that an air bag inflates with great force. Do not
place objects, including both installed or portable
wireless equipment in the area over the air bag or
in the air bag deployment area. If wireless
equipment is improperly installed and the air bag
inflates, serious injury could result.
• Switch your phone off before boarding an aircraft.
The use of wireless phone in aircraft is illegal and
may be dangerous to the aircraft's operation.
• Failure to observe these instructions may lead to
the suspension or denial of telephone services to
the offender, or legal action, or both.
Product Performance
Getting the Most Out of Your Signal Reception
The quality of each call you make or receive depends
on the signal strength in your area. Your phone
informs you of the current signal strength by
displaying a number of bars next to the signal strength
icon. The more bars displayed, the stronger the signal.
If you're inside a building, being near a window may
give you better reception.
Understanding the Power Save Feature
If your phone is unable to find a signal after 15
minutes of searching, a Power Save feature is
automatically activated. If your phone is active, it
periodically rechecks service availability or you can
check it yourself by pressing any key.
Anytime the Power Save feature is activated, a
message displays on the screen. When a signal is
found, your phone returns to standby mode.
92
Health and safety information
Understanding How Your Phone Operates
Your phone is basically a radio transmitter and
receiver. When it's turned on, it receives and transmits
radio frequency (RF) signals. When you use your
phone, the system handling your call controls the
power level. This power can range from 0.006 watts to
0.2 watts in digital mode.
Maintaining Your Phone's Peak Performance
For the best care of your phone, only authorized
personnel should service your phone and accessories.
Faulty service may void the warranty.
There are several simple guidelines to operating your
phone properly and maintaining safe, satisfactory
service.
• Hold the phone with the antenna raised, fully-
extended and over your shoulder.
• Try not to hold, bend or twist the phone's antenna.
• Don't use the phone if the antenna is damaged.
• Speak directly into the phone's receiver.
• Avoid exposing your phone and accessories to rain
or liquid spills. If your phone does get wet,
immediately turn the power off and remove the
battery. If it is inoperable, call Customer Care for
service.
Availability of Various Features/Ring
Tones
Many services and features are network dependent
and may require additional subscription and/or usage
charges. Not all features are available for purchase or
use in all areas. Downloadable Ring Tones may be
available at an additional cost. Other conditions and
restrictions may apply. See your service provider for
additional information.
Battery Standby and Talk Time
Standby and talk times will vary depending on phone
usage patterns and conditions. Battery power
consumption depends on factors such as network
configuration, signal strength, operating temperature,
93
Health and safety information
Settings
features selected, frequency of calls, and voice, data,
and other application usage patterns.
Battery Precautions
• Never use any charger or battery that is damaged
in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network's base
station, it uses less power; talk and standby time
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
• Battery charging time depends on the remaining
battery charge and the type of battery and charger
used. The battery can be charged and discharged
hundreds of times, but it will gradually wear out.
When the operation time (talk time and standby
time) is noticeably shorter than normal, it is time
to buy a new battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not in use,
disconnect it from the power source. Do not leave
the battery connected to a charger for more than a
week, since overcharging may shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling or
warming first.
• Do not leave the battery in hot or cold places, such
as in a car in summer or winter conditions, as you
will reduce the capacity and lifetime of the battery.
Always try to keep the battery at room
temperature. A phone with a hot or cold battery
may temporarily not work, even when the battery
is fully charged. Li-ion batteries are particularly
affected by temperatures below 0 °C (32 °F).
• Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object (coin,
clip or pen) causes a direct connection between the
+ and - terminals of the battery (metal strips on
the battery), for example when you carry a spare
94
Health and safety information
battery in a pocket or bag. Short-circuiting the
terminals may damage the battery or the object
causing the short-circuiting.
• Dispose of used batteries in accordance with local
regulations. In some areas, the disposal of
batteries in household or business trash may be
prohibited. For safe disposal options for Li-Ion
batteries, contact your nearest Samsung
authorized service center. Always recycle. Do not
dispose of batteries in a fire.
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for
many years.
• Keep the phone and all its parts and accessories
out of the reach of small children.
• Keep the phone dry. Precipitation, humidity and
liquids contain minerals that will corrode electronic
circuits.
• Do not use the phone with a wet hand. Doing so
may cause an electric shock to you or damage to
the phone.
• Do not use or store the phone in dusty, dirty areas,
as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the phone,
which may damage the phone's electronic circuit
boards.
• Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the phone. Wipe it with
a soft cloth slightly dampened in a mild soap-and-
water solution.
95
Health and safety information
Settings
• Do not paint the phone. Paint can clog the device's
moving parts and prevent proper operation.
• Do not put the phone in or on heating devices,
such as a microwave oven, a stove or a radiator.
The phone may explode when overheated.
• When the phone or battery gets wet, the label
indicating water damage inside the phone changes
color. In this case, phone repairs are no longer
guaranteed by the manufacturer's warranty, even
if the warranty for your phone has not expired.
• If your phone has a flash or light, do not use it too
close to the eyes of people or animals. This may
cause damage to their eyes.
• Use only the supplied or an approved replacement
antenna. Unauthorized antennas or modified
accessories may damage the phone and violate
regulations governing radio devices.
• If the phone, battery, charger or any accessory is
not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
Index
A
ABC mode, text input • 22
Active folder • 64
Alarm • 49
Answering
call • 26
second call • 27
Anykey answer • 64
Auto redial • 64
B
Background image • 64
Backlight time, set • 64
Band selection • 68
Barring, calls • 67
Battery
charging • 7
low indicator • 8
precautions • 75
BlackBerry
activating • 32
settings • 32
Bluetooth
receiving, data • 57
sending, data • 57
settings • 55
Broadcast messages • 45
Browser, web • 53
C
Calculator • 46
Calendar • 49
Call cost • 36
Call records
dialled • 35
missed • 35
received • 35
Call time • 36
Caller ID • 68
Calls
answering • 26
barring • 67
diverting • 66
holding • 27
redialling • 25
rejecting • 26
waiting • 67
CB (Cell Broadcast message) •
45
Characters, enter • 22
Connection tone • 66
Converter • 48
Creating messages
e-mail • 30, 39
MMS • 38
SMS • 37
CUG (Closed User Group) • 68
D
Date, set • 63
Deleting
call records • 35
contacts • 62
e-mail • 31
MMS • 41
SMS • 40
Dialled calls • 35
Dialling font, set • 64
Display
backlight, set • 64
brightness • 64
icons • 12
language • 63
layout • 11
settings • 64
Diverting, calls • 66
DRM (Digital Rights
Management) • 58
DTMF tones, send • 28
E
E-mails
creating/sending • 30, 39
deleting • 31
viewing • 30
Emergency calls • 78
F
FDN (Fixed Dialling Number)
mode • 71
File manager • 58
Folder tone • 65
G
Games • 46
Greeting message • 63
H
Health and safety • 74
Holding, call • 27
96
Index
I
Icons, description • 11
Images, downloaded • 58
Inbox, messages
MMS/SMS • 40
International calls • 25
Internet • 53
J
Java applications • 46
K
Keypad tones
selecting • 65
sending/muting • 28
volume • 65
L
Landscape mode • 29
Language, select • 63
Last number, redial • 25
Locking
menu functions • 70
phone • 70
SIM card • 71
Low battery indicator • 8
M
Memory status
downloaded items • 59
file manager • 59
messages • 45
phonebook • 62
Menu style • 64
Message tone • 65
Messages
e-mail • 30, 39
greeting • 63
MMS • 38
SMS • 37
Minute minder • 66
Missed calls • 35
MMS messages
creating/sending • 38
deleting • 41
setting • 44
viewing • 40
Multiparty-call • 28
N
Names
entering • 22
searching • 60
Network band, select • 68
Network selection • 68
Network services • 66
Number
searching • 60
storing • 60
O
Outbox, messages • 42
P
Password
call barring • 67
phone • 70
Phone
care and maintenance •
79
display • 11
icons • 11
locking • 70
password • 70
resetting • 72
switching on/off • 9
unpacking • 6
Phonebook
adding • 60
deleting • 62
editing • 60
options • 60
searching • 60
speed dialling • 61
PIN, change • 70
PIN2, change • 71
Power on/off tone • 65
Privacy • 70
Problems, solve • 72
Q
Quiet mode
entering • 14
setting • 66
R
Received calls • 35
Received messages
e-mail • 30
MMS/SMS • 40
Recording, voice memos • 47
Redialling
automatically • 64
manually • 25
Resetting phone • 72
Ringer
incoming calls • 65
messages • 65
Road safety • 76
Roaming • 68
S
Safety
information • 74
97
98
Index
precautions • 1
Security, calls • 70
Sentbox • 41
Short cut • 63
SIM card
inserting • 7, 8
locking • 71
SMS messages
creating/sending • 37
deleting • 40
setting • 44
viewing • 40
Sound settings • 65
Sounds, downloaded • 58
Speakerphone • 27
Speed dial • 61
Switching on/off
microphone • 28
phone • 9
T
T9 mode, text input • 23
Templates, message • 43
Text, enter • 22
Time, set • 63
V
Videos, downloaded • 59
Voice recognition
name dialling • 21
settings • 69
Voice recorder, memos
playing • 48
recording • 47
Voicemail server • 35
W
Waiting call • 67
Wallpaper • 64
Web browser
access • 53
bookmarks • 54
World time • 48, 49
