Samsung Electronics Co SGHD500 Single-Band PCS GSM Phone w/ Bluetooth User Manual
Samsung Electronics Co Ltd Single-Band PCS GSM Phone w/ Bluetooth Users Manual
Users Manual
* Some of the contents of this manual may differ from your phone,
depending on the software installed or your service provider.
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-XXXXXA
English. 09/2004. Rev 1.0
GPRS TELEPHONE
SGH-D500
Draft version
(2004. 09. 14)
FCC RF EXPOSURE INFORMATION
In August 1996 the Federal Communications Commission (FCC) of
the United States with its action in Report and Order FCC 96-326
adopted an updated safety standard for human exposure to radio
frequency electromagnetic energy emitted by FCC regulated
transmitters. Those guidelines are consistent with the safety
standards previously set by both U.S. and international standards
bodies. The design of this phone complies with the FCC guidelines
and these international standards.
Use only the supplied antenna or one that is approved.
Unauthorized antennas, modifications, or attachments could impair
call quality, damage the phone, or result in a violation of FCC
regulations.
Do not use the phone with a damaged antenna. If a damaged
antenna comes into contact with the skin, a minor burn may result.
Please contact your local dealer for a replacement antenna.
Body-worn Operation
This device was tested for typical body-worn operations with the back
of the phone kept 1.5 cm. from the body. To maintain compliance
with FCC RF exposure requirements, use only belt-clips, holsters
or similar accessories that maintain at least a 0.59 inch (1.5 cm.) separation
distance, between the user's body and the back of the phone, including
the antenna. The use of belt-clips, holsters and similar accessories
should not contain metallic components in its assembly. The use of
accessories that do not satisfy these requirements may not comply
with FCC RF exposure requirements, and should be avoided.
Vehicle Mounted External Antenna (optional, if
available.)
A minimum separation distance of 7.9 inches (20cm) must be
maintained between a person and the vehicle mounted external
antenna to satisfy FCC RF exposure requirements.
For more information about RF exposure, please visit the FCC web
site at http://www.fcc.gov/oet/rfsafety/
3
Contents
Important safety precautions........................... 7
Unpacking ........................................................ 9
Your phone..................................................... 10
Phone layout........................................................... 10
Display................................................................... 13
Camera .................................................................. 16
Flash...................................................................... 16
Getting started............................................... 17
Installing the SIM card ............................................. 17
Charging the battery................................................ 19
Switching on or off the phone.................................... 21
Using the Keypad Lock feature .................................. 22
Call functions ................................................. 23
Making a call........................................................... 23
Adjusting the volume ............................................... 29
Answering a call ...................................................... 30
Viewing missed calls ................................................ 31
Quickly switching to Quiet mode ................................ 32
Using the headset.................................................... 33
Selecting functions and options...................... 34
Using the soft keys .................................................. 34
Selecting options ..................................................... 35
Entering text .................................................. 36
Changing the text input mode ................................... 37
Using ABC mode...................................................... 38
Using T9 mode........................................................ 39
Using Number mode................................................. 41
Using Symbolic mode............................................... 41
Options during a call ...................................... 42
Putting a call on hold................................................ 42
Using the speaker.................................................... 43
Call waiting............................................................. 43
Using the Bluetooth headset...................................... 44
Switching on or off the Voice Clarity feature ................ 45
Switching off the microphone (Mute).......................... 45
Contents
4
Muting or sending key tones...................................... 46
Using Phonebook..................................................... 46
Sending a sequence of DTMF tones ............................ 47
Using the message service........................................ 47
Using SIM services................................................... 48
Making a multi-party call .......................................... 48
Using the menus ............................................ 50
Accessing a menu function by scrolling ....................... 50
Using shortcuts ....................................................... 51
List of menu functions .............................................. 52
Call records .................................................... 58
All calls
(Menu 1.1)
................................................... 58
Dialled calls
(Menu 1.2)
............................................. 59
Received calls
(Menu 1.3)
.......................................... 60
Missed calls
(Menu 1.4)
............................................. 60
Delete all
(Menu 1.5)
................................................ 60
Call time
(Menu 1.6)
................................................. 61
Call costs
(Menu 1.7)
................................................ 62
Phonebook ..................................................... 63
Contact list
(Menu 2.1)
............................................. 63
Add new contact
(Menu 2.2)
....................................... 65
Group
(Menu 2.3)
.................................................... 68
Speed dial
(Menu 2.4)
.............................................. 71
My name card
(Menu 2.5)
.......................................... 72
Own number
(Menu 2.6)
............................................ 73
Management
(Menu 2.7)
............................................ 73
Service number
(Menu 2.8)
........................................ 75
Applications ................................................... 76
Java world
(Menu 3.1)
............................................... 76
MP3 player
(Menu 3.2)
.............................................. 84
Voice recorder
(Menu 3.3)
.......................................... 88
World time
(Menu 3.4)
.............................................. 91
Alarm
(Menu 3.5)
..................................................... 92
Calculator
(Menu 3.6)
................................................ 94
Converter
(Menu 3.7)
................................................. 95
Timer
(Menu 3.8)
...................................................... 96
Stopwatch
(Menu 3.9)
............................................... 97
SIM AT
(Menu 3.10)
.................................................. 97
Contents
5
Browser.......................................................... 98
Home
(Menu 4.1)
...................................................... 98
Bookmarks
(Menu 4.2)
............................................ 101
Go to URL
(Menu 4.3)
.............................................. 102
Clear cache
(Menu 4.4)
............................................ 102
Settings
(Menu 4.5)
................................................ 102
Current proxy
(Menu 4.6)
........................................ 105
Messages...................................................... 106
Short message
(Menu 5.1)
....................................... 106
Multimedia messages
(Menu 5.2)
.............................. 116
Email
(Menu 5.3)
.................................................... 133
Push messages
(Menu 5.4)
...................................... 150
Voice mail
(Menu 5.5)
............................................. 151
Text template
(Menu 5.6)
........................................ 152
Broadcast messages
(Menu 5.7)
............................... 152
Memory status
(Menu 5.8)
....................................... 154
Funbox ......................................................... 155
Images................................................................. 155
Videos.................................................................. 157
Music ................................................................... 160
Sounds................................................................. 163
Memory status ...................................................... 166
Organiser ..................................................... 167
Month view
(Menu 7.1)
............................................ 167
Week view
(Menu 7.2)
............................................ 172
Day view
(Menu 7.3)
............................................... 172
Schedule
(Menu 7.4)
............................................... 174
Anniversary
(Menu 7.5)
........................................... 175
Miscellaneous
(Menu 7.6)
........................................ 176
To do
(Menu 7.7)
.................................................... 178
Missed alarm event
(Menu 7.8)
................................ 179
Memo
(Menu 7.9)
................................................... 180
Memory status
(Menu 7.10)
..................................... 181
Camera......................................................... 182
Take a photo
(Menu 8.1)
......................................... 182
Record video
(Menu 8.2)
.......................................... 188
Photos
(Menu 8.3)
.................................................. 192
My photos
(Menu 8.4)
............................................. 194
Video clips
(Menu 8.5)
............................................. 194
My video clips
(Menu 8.6)
........................................ 196
Contents
6
Settings........................................................ 197
Time & Date
(Menu 9.1)
.......................................... 197
Phone settings
(Menu 9.2)
....................................... 198
Display settings
(Menu 9.3)
...................................... 201
Sound settings
(Menu 9.4)
....................................... 203
Network services
(Menu 9.5)
.................................... 207
Connectivity
(Menu 9.6)
.......................................... 213
Security
(Menu 9.7)
................................................ 218
Memory status
(Menu 9.8)
....................................... 222
Reset settings
(Menu 9.9)
........................................ 224
Solving problems.......................................... 225
Access codes ................................................ 228
Phone password .................................................... 228
PIN...................................................................... 229
PUK ..................................................................... 229
PIN2 .................................................................... 230
PUK2 ................................................................... 230
Barring password................................................... 231
Health and safety information...................... 232
SAR certification information ................................... 232
Precautions when using batteries............................. 233
Road safety .......................................................... 235
Operating environment........................................... 235
Electronic devices .................................................. 236
Potentially explosive environments........................... 238
Emergency calls .................................................... 239
Other important safety information .......................... 240
Care and maintenance............................................ 241
Glossary ....................................................... 243
Index ........................................................... 250
Qnuick reference card .................................. 255
7
Important safety
precautions
Read these guidelines before using your wireless
phone. Failure to comply with them may be
dangerous or illegal.
Road safety at all times
Do not use a hand-held phone while driving; park
the vehicle first.
Switching off when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switching off in an aircraft
Wireless phones can cause interference. Using them
in an aircraft is both illegal and dangerous.
Switching off near all medical equipment
Switch off your phone near medical equipment.
Hospitals or health care facilities may be using
equipment that could be sensitive to external RF
energy. Follow any regulations or rules in force.
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Special regulations
Meet any special regulations in force in any area
and always switch off your phone whenever it is
forbidden to use it, or when it may cause
interference or danger (in a hospital for example).
Water resistance
Your phone is not water-resistant. Keep it dry.
Important safety precautions
8
Sensible use
Use only in the normal position (held to the ear).
Avoid unnecessary contact with the antenna when
the phone is switched on.
Emergency call
Key in the emergency number for your present
location, then press the key. Give all necessary
information as accurately as possible. Do not end
the call until given permission to do so.
Keeping small children away from your phone
Keep the phone and all its parts including
accessories out of the reach of small children.
Accessories and batteries
Use only Samsung-approved accessories and
batteries. Use of any unauthorised accessories
could damage your phone and may be dangerous.
Use only Smsung-approved batteries and recharge
your battery only with Samsung-approved
chargers.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see “Health
and safety information” on page 232.
CAUTION
RISK OF EXPLOSION IF A BATTERY IS REPLACED
BY AN INCORRECT TYPE
.
DISPOSE USED BATTERIES ACCORDING TO THE
INSTRUCTIONS.
9
Unpacking
Your package contains the following items:
You can obtain the following accessories for your
phone from your local Samsung dealer:
Note
: The items supplied with your phone and
available accessories may be different,
depending on your country or service provider.
Handset Travel Adapter
Battery User’s Manual
Straight Headset Hand strap
• Standard battery • Hand strap
• Car charger • Car cradle
• Travel charger • PC data link kit
• B/T Handsfree car kit • Straight headset
• USB dongle • Bluetooth headset kit
• Holster charger • External speaker
10
Your phone
Phone layout
The following illustrations show the main elements
of your phone:
Earpiece
Display
Power on/off/
menu exit key
Alphanumeric
keys
Soft key (right)
Microphone
Soft key (left)
IrDA port
Special function
keys
Navigation (Up/
Down/Left/Right)
keys
WAP access/confirm
key
Volume keys
Cancel/correct key
Dial key
Headset jack
Camera key
Camera Flash
Your phone
11
Key
(s)
Description
(soft keys)
Performs the functions indicated by the
screen text above them, on the bottom
line of the display.
In Idle mode, allows you to access your
favourite menu options directly. For
further details about shortcuts, see
page 199.
In Menu mode, scrolls through the
menu options and Phonebook.
When entering text, moves the cursor,
depending on which side you push.
In Idle mode, launches the WAP
(Wireless Application Protocol) browser.
In Menu mode, selects the highlighted
menu options.
Deletes characters from the display.
In Menu mode, returns you to the
previous menu level.
Makes or answers a call.
In Idle mode, retrieves the last number
dialled, missed, or received.
Ends a call. Also switches the phone on
and off when held down.
In Menu mode, cancels your input and
returns the phone to Idle mode.
Your phone
12
In Idle mode, accesses your voice mail
when held down.
Enters numbers, letters, and some
special characters.
Enters special characters.
Performs various functions.
(on the left side of the phone)
Adjusts the ringer volume when the
phone is ringing and the earpiece
volume during a call.
In Idle mode, with the phone open,
adjusts the keypad tone volume. With
the phone closed, turns on the
backlight when held down.
In Menu mode, scrolls through menu
options and Phonebook.
(on the right side of the phone)
In Idle mode, accesses the
Camera
menu. Turns on the camera when held
down.
In Capture mode, takes a photo.
Key
(s)
Description
(continued)
Your phone
13
Display
Display layout
The display has 3 areas:
Area Description
First line Displays various icons. See
page 14.
Middle Displays messages, instructions,
and any information that you
enter, such as the number you are
dialling.
Last line Shows the current functions
assigned to the two soft keys.
Text and
graphics area
Soft key function
indicators
Menu Contacts
Icons
Your phone
14
Icons
Icon Description
Shows the received signal strength. The
greater the number of bars, the stronger
the signal.
Appears when a call is in progress.
Appears when you are out of your service
area. When it displays, you cannot make or
receive a call.
Appears when you set an alarm to ring at a
specified time. For further details, see
page 92.
Appears when a new text message has
been received.
Appears when a new voice mail message
has been received.
Appears when a new multimedia message
has been received.
Appears when a new e-mail has been
received or sent.
When
@
is blinking in red, an e-mail is
being retrieved from the e-mail server.
When
@
is blinking in blue, an e-mail is
being sent.
Flash alternatively when the e-mail Inbox
is full.
Appears when the Call Diverting feature is
active. For further details, see page 207.
Your phone
15
Appears when the IrDA port is active. For
details, see page 217.
Appears when the Bluetooth feature is
active For further details, see page 213.
Appears when you synchronise personal
information stored in your phone with
corresponding PC applications by using the
PC suite software.
Appears when you are connected to the
GPRS network.
Appears when you are in the Home Zone if
you have registered for the service.
Appears when you are in the Office Zone if
you have registered for the service.
Appears when you set the phone to vibrate
for an incoming call. For further details,
page 203.
Appears when Quiet mode is active. For
further details, see page 32.
Shows the level of your battery. The more
bars you see, the more power you have
remaining.
Icon Description
(continued)
Your phone
16
Backlight
The backlight illuminates the display and the
keypad. When you press any key or open the
phone, the backlight comes on. It goes off when no
keys are pressed within a given period of time,
depending on the setting in the
Backlight
menu
(
Menu 9.3.5
). After a specified time, the display
shows the current time and date on a digital clock.
To turn on the backlight, press and hold the Volume
keys.
To specify the length of time the backlight is active,
go to the
Backlight
menu. See page 203 for
further details.
Camera
The camera module on the back of your phone
allows you to take a photo and record a video while
on the move.
For further details about the Camera feature, see
page 182.
Flash
You can use the built-in flash on the back of your
phone, to the right of the camera, to take photos
when it is dark.
17
Getting started
Installing the SIM card
When you subscribe to a cellular network, you are
provided with a plug-in SIM card loaded with your
subscription details, such as your PIN, any optional
services available, and so on.
Important!
The plug-in SIM card and its contacts
can be easily damaged by scratches or
bending, so be careful when handling,
inserting, or removing the card.
Keep all SIM cards out of the reach of
small children.
1. If necessary, switch off the phone by holding
down the key until the power-off image
displays.
2. Remove the battery. To do so:
➀
Press the catch above the battery and hold it
in that position.
➁
Lift the battery away, as shown.
➀➁
Getting started
18
3. Slide the SIM card into the SIM card socket, as
shown, so that the card locks into position.
Make sure the gold coloured contacts on the
card face into the phone.
Note
: When you need to remove the SIM card,
slide it upwards, as shown, and take it out
of the socket.
4. Place the battery so that the tabs on the end
align with the slots at the bottom of the phone.
Getting started
19
5. Press the battery until it clicks into place. Make
sure that the battery is properly installed before
switching the power on.
Charging the battery
Your phone is powered by a rechargeable Li-ion
battery. A travel adapter comes with your phone for
charging the battery. Use only approved batteries
and chargers. Ask your local Samsung dealer for
further details.
The travel adapter allows you to use the phone
while the battery is charging, but this causes the
phone to charge more slowly.
Note
: You must fully charge the battery before using
your phone for the first time. A discharged
battery recharges fully in approximately 90
minutes.
1. With the battery in position on the phone, plug
the connector of the travel adapter into the jack
at the bottom of the phone.
Getting started
20
2. Plug the charger into a standard AC wall outlet.
3. When charging is finished, unplug the charger
from the power outlet and disconnect it from the
phone by pressing the buttons on both sides of
the connector and pulling out the connector.
Note
: You must unplug the charger before removing
the battery from the phone during charging;
otherwise, the phone could be damaged.
Low battery indicator
When the battery is weak and only a few minutes of
talk time remain, a warning tone sounds and the
“Warning low battery” message repeats at regular
intervals on the display. In this case, your phone
turns off the backlight to conserve the remaining
battery power.
If the battery level becomes too low, the phone
automatically turns off.
➁
➀
➀
Getting started
21
Switching on or off the phone
1. Open the phone.
2. Press and hold the key until the phone
switches on.
3. If the phone asks you to enter a password, enter
the password and press the
OK
soft key. The
password is preset to “00000000” at the factory.
For further details, see page 228.
4. If the phone asks for a PIN, enter the PIN and
press the
OK
soft key. For further details, see
page 229.
The phone searches for your network and, after
finding it, the idle screen appears on the display.
Now, you can dial or receive calls.
Note
: To change languages, use the
Language
menu (
Menu 9.2.1
). For further details,
see page 198.
5. When you wish to switch off the phone, press
and hold the key until the power-off image
displays.
Note
: When your phone is closed, you first need to
open the phone to activate the display and the
keypad.
Getting started
22
Using the Keypad Lock feature
You can open the phone to use the number keypad
and close the phone so that it takes up less space.
When you close the phone, the display turns off and
the phone automatically locks the exposed function
keys so that even if they are pressed accidentally,
nothing will happen.
To unlock the keypad, press and hold the
Unlock
soft key or the left soft key and then press the
OK
soft key. The keypad is activated and you can use
the phone’s functions.
23
Call functions
Making a call
When the idle screen displays, enter the area code
and phone number, then press the key.
Note
: When you activate the
Auto
redial
option in
the
Extra
settings
menu (
Menu 9.2.5
), the
phone will automatically redial up to 10 times if
the person does not answer the call or is
already on the phone. See page 200 for further
details.
Making an international call
1. Press and hold the
0
key.
The
+
character appears.
2. Enter the country code, area code, and phone
number and press the key.
Correcting the number
T
o clear Press the
the last digit displayed
C
key.
any other digit in the
number Left or Right key until the
cursor is immediately to
the right of the digit to be
cleared and press the
C
key. You can also insert a
missing digit.
the whole display
C
key and hold it for more
than one second.
Call functions
24
Ending a call
When you want to end your call, briefly press the
key or close the phone.
Redialling the last number
The phone stores the numbers of the calls you’ve
dialled, received, or missed, if the call recipient or
caller can be identified. See “Call records” on
page 58 for further details.
To recall any of these numbers:
1. If you have entered characters on the display,
press the key to return to Idle mode.
2. Press the key to display a list of the most
recent numbers used, in the order you dialled,
missed, or received them.
3. Press the Up or Down key to scroll through the
numbers until the number you want highlights.
4. Press the key to dial the displayed number.
Making a call from Phonebook
You can store phone numbers that you use
regularly on the SIM card or in the phone’s memory.
These entries are collectively called Phonebook. You
then do not need to remember all of your numbers;
simply select the required name to recall the
associated number.
Once you have stored a number in Phonebook, you
can dial it by pressing a few keys. You can also
assign your most frequently-used numbers to
number keys using the Speed Dial feature.
Call functions
25
For further details about the Phonebook feature,
see page 63.
Storing a number in Idle mode
As soon as you start to enter a number,
Save
appears above the left soft key to allow you to store
the number in Phonebook.
Note
: You can select a default memory location in
which you want to save your numbers. For
further details, see page 65
To store a number in the phone’s memory:
1. Enter the number you want to store.
Note
: If you make a mistake while entering a
number, correct it using the
C
key. For
further details, see page 23.
2. When you are sure that it is correct, press the
Save
soft key.
3. Select
Phone
and press the
Select
soft key.
4. Select an icon to identify the category in which
the number is to be stored. 5 categories are
available:
•
Mobile
•
Home
•
Office
•
Fax
•
Other
To select the category, press the Up or Down key
and press the
Select
soft key.
Call functions
26
5. Press the Down key to move and change the
setting or enter more information, if necessary.
•
Last name
/
First name
: Enter the entry
name. For further details about how to enter
characters, see page 36.
•
Mobile
/
Home
/
Office
/
Fax
/
Other
: Add a
number for any category.
•
E-mail
: Enter an e-mail address.
•
Graphic ID
: Assign an image as a caller ID
image to be displayed when you receive a call
from the selected number.
•
Alert
: Select a unique ringer melody for the
entry. By selecting a different tone for each
entry, incoming voice calls having a caller ID
can be distinguished from each other.
•
Group
: Select one of the default relation
groups, where the entry is included. Grouping
the entries enables you to search for a number
within the group. See page 69.
•
Notes
: Add a memo about the person.
6. When you have finished entering the Phonebook
information for the entry, press the key.
Alternatively, press the
Options
soft key and
select
Save
.
After storing, the phone displays information
about the entry you just saved.
Call functions
27
To store a number on the SIM card:
1. Enter the number you want to store.
2. When you are sure that it is correct, press the
Save
soft key.
3. Select
SIM
and press the
Select
soft key.
Note
: When you change phones, any numbers
stored in your SIM card memory are
automatically available with the new phone,
whereas any numbers stored in the phone’s
memory will need to be reentered.
4. Enter a name and press the Down key.
5. If necessary, change the phone number and
press the Down key.
6. If you do not want to save the number and
name in the suggested location, press the
C
key
to clear the location number and enter another
location by pressing the number keys.
7.
To Press the
use the entry
options
Options
soft key. For further
details, see page 64.
dial a number Down key to scroll to a
number and press the key.
return to the idle
screen
Back
soft key or the key.
Call functions
28
7. When you have finished entering the Phonebook
information for the entry, press the key.
Alternatively, press the
Options
soft key and
select
Save
.
After storing, the phone displays information
about the entry you just saved.
Dialling a number from the SIM card
Once you have stored phone numbers on the SIM
card, you can dial them easily and quickly by using
the location numbers that were assigned to them in
Phonebook.
Note
: If you cannot remember a location number or if
you want to dial a number in the phone’s
memory, you must go into the
Contact list
menu (
Menu 2.1
) to search for the entry by
name. For details, see page 63.
1. In Idle mode, enter the location number for the
phone number you want to dial and press the
key.
The entry appears.
2. You can press the Left or Right key to find other
numbers.
8.
To Press the
use the entry
options
Options
soft key. For further
details, see page 64.
dial a number Down key to scroll to a
number and press the
key.
return to the idle
screen
Back
soft key or the key.
Call functions
29
3. Press the
Dial
soft key, the key, or the key
when you have found the number you want.
Adjusting the volume
During a call, if you want to adjust the earpiece
volume, use the Volume keys on the left side of the
phone.
Press the key to increase the volume level and
the key to decrease the level.
In Idle mode, you can also adjust the keypad tone
volume using these keys.
Call functions
30
Answering a call
When somebody calls you, the phone rings and
displays the incoming call image.
The caller’s phone number or name, if stored in
Phonebook, displays.
1. Press the key or the
Accept
soft key to
answer the incoming call.
When the
Anykey
answer
option in the
Extra
settings
menu (
Menu 9.2.5
) is active, you can
press any key to answer a call except for the
key and the
Reject
soft key. See
page 200
.
Notes
:
• To reject the call, press the
Reject
soft key or
key.
• You can mute the ringer by pressing and holding
the Volume keys.
2. End the call by closing the phone or pressing the
key.
Note
: You can set how the phone reacts when you
close the phone in the
Slide settings
menu (
Menu 9
.
2
.
3
).
For further details,
see page 199. While you are using a
headset, the call is not ended by closing the
phone even though the
Down
option of the
menu is set to
Stop operation
.
Note
: You can answer a call while using menu
features or Phonebook. After ending the call,
the display returns to the function screen you
were using.
Call functions
31
Viewing missed calls
When you are unable to answer a call for any
reason, you can find out who called you so that you
can call the person back.
The number of calls you have missed displays on
the idle screen immediately after a call is missed.
To view a missed call immediately:
1. If the phone is closed, open the phone.
2. Press the
View
soft key.
The number for the last missed call displays, if
available.
When you press the
Options
soft key, you can
access the following options:
Details
: shows information about the call, such as
the number or name, if available, and the time and
date it was received.
Call
: dials the number.
Paste
: allows you to save the number in your
Phonebook. For further details about storing a
number, see page 65.
3.
To Press the
scroll through the
missed calls Up or Down key.
access the options
Options
soft key.
See below.
call the number
displayed key.
Call functions
32
Send message
: allows you to send an SMS (Short
Message Service) or MMS (Multimedia Message
Service) message to the number. For further details
about sending a message, see page 107 or
page 116, respectively.
Delete
: deletes the current call.
Delete all
: deletes all calls.
Quickly switching to Quiet mode
Quiet mode is convenient when you wish to stop the
phone from ringing, in a theatre for example.
In Idle mode, press and hold the
key until the
“Quiet mode activated” message and the Quiet
mode icon ( ) display.
In Quiet mode, instead of sounds, your phone will
vibrate, or do nothing, depending on the function
and the situation.
To exit and reactivate the previous sound settings,
press and hold the
key again until “Quiet mode
deactivated” appears. The Quiet mode icon ( ) no
longer displays.
Note
: Activating Quiet mode will not turn off the
camera shutter sound.
Call functions
33
Using the headset
With the headset, you can make or answer a call
without holding the phone.
When you connect the headset to the jack on the
right side of the phone, the button on the headset
works as listed below:
To Press the
redial the last call button twice in Idle mode.
answer a call and hold the button when
you receive the call.
end a call and hold the button.
34
Selecting functions
and options
Your phone offers a set of functions that allow you
to customise it. These functions are arranged in
menus and sub-menus, accessed using the two soft
keys, and . Each menu and sub-menu allows
you to view and alter the settings of a particular
function.
Using the soft keys
The roles of the soft keys vary, depending on the
function you are currently using; the labels on the
bottom line of the display just above each key
indicate their current role.
Example:
Menu Contacts
Service Provider
ADM 12000
04 Nov
Tue.
07:30
Press the left soft
key to access Menu
mode.
Press the right soft key to
access the
Contact list
in the
Phonebook
menu.
Selecting functions and options
35
Selecting options
To view the various functions and options available
and to select the one you want:
1. Press the appropriate soft key.
In some functions, you may be asked for a
password or PIN. Enter the code and press the
OK
soft key.
Note
: When you access a list of options, your phone
highlights the currently active option. If,
however, there are only 2 options, such as
On
/
Off
or
Enable
/
Disable
, your phone highlights
the option that is not currently active, so that
you can select it directly.
2.
To Press the
select the:
• function displayed
• option highlighted
Select
soft key or the
key.
view the next function
or highlight the next
option on a list
Down key.
move back to the
previous function or
option on a list
Up key.
move back up one
level in the menu
structure
Back
soft key or the
C
key.
exit the menu
structure without
changing the settings
key.
36
Entering text
When using your phone, you will often need to
enter text, such as when storing a name in
Phonebook, creating your personal greeting, or
scheduling events on your calendar. You can enter
alphanumeric characters by using your phone’s
keypad.
Your phone has the following text input modes:
•ABC mode
This mode allows you to enter letters by pressing
the key labelled with the letter you want. Press
the key once, twice, three, or four times until the
desired letter displays.
•T9 mode
This mode allows you to enter words with only
one keystroke per letter. Each key on the keypad
has more than one letter; for example, pressing
the
5
key can enter J, K, or L. However, T9 mode
automatically compares the series of keystrokes
you make with an internal linguistic dictionary to
determine the most likely word, thus requiring far
fewer keystrokes than the traditional Alphabet
mode.
• Number mode
This mode allows you to enter numbers.
• Symbolic mode
This mode allows you to enter various symbols
and punctuation marks.
Entering text
37
Changing the text input mode
When you are in a field that allows characters to be
entered, you will notice the text input mode
indicator on the display.
Example: Writing a text message
Note
: Additional text input modes may be available,
depending on your country. To use a text input
mode for your specific country, press and hold
the
key while in Alphabet mode.
To select Press the right soft key
until
ABC mode displays. See
page 38.
T9 mode displays. See
page 38.
Number mode displays. See
page 41.
Symbolic mode displays. See
page 41.
Text input mode
indicator
options
Entering text
38
Using ABC mode
Use the
1
to
0
keys to enter your text.
1. Press the keys labelled with the letter you want:
- Once for the first letter
- Twice for the second letter
- And so on
2. Select the other letters in the same way.
Note
: The cursor moves to the right when you press a
different key. When entering the same letter
twice or a different letter on the same key, just
wait for a few seconds for the cursor to move to
the right automatically, and then select the
next letter.
Refer to the table below for further details about
available characters:
Note
: The characters available in Alphabet mode may
be different, depending on the selected
language.
Entering text
39
• To insert a space, press the key.
• To shift case in ABC mode, use the key. There
are 3 cases: Lower case (No indicator), Initial
capital ( ), and Capital lock ( ).
• You can move the cursor by pressing the Left or
Right key. To delete letters, press the
C
key. Press
and hold the
C
key to clear the entire display.
Note
: To enter or exit an input mode specific to your
country, press and hold the
key.
Using T9 mode
T9 is a predictive text input mode that allows you to
key in any character using single keystrokes. This
text input mode is based on a built-in dictionary.
To enter a word in T9 mode:
1. When you are in T9 mode, start entering a word
by pressing the
2
to
9
keys. Press each key only
once for each letter.
Example: To enter “HELLO” in T9 mode,
press the
4
,
3
,
5
,
5
, and
6
keys.
The word that you are typing appears on the
display. It may change with each key that you
press.
2. Enter the whole word before editing or deleting
the keystrokes.
3. When the word displays correctly, go to step 4.
If the word doesn’t display correctly, press the
0
key repeatedly to display alternative word
choices for the keys that you have pressed.
Entering text
40
Example: Both “OF” and “ME” use the
6
and
3
keys. The phone displays the most
commonly used choice first.
4. Insert a space by pressing the key and start
entering the next word.
To add a new word into the T9 dictionary:
1. After pressing the keys corresponding to the
word you want to add, press the
0
key to display
the alternative words.
2. When there are no more alternative words, the
display shows
Spell
on the bottom line. Press
the
Spell
soft key or the key.
3. Enter the word you want to add using ABC
mode; see page 38.
4. Press the
OK
soft key.
The word is added to the T9 dictionary and
becomes the first word for the associated
keypress series.
Note
: This feature may not be available for some
languages.
• To enter periods, hyphens, or apostrophes, press
the
1
key. T9 mode applies grammar rules to
choose the correct punctuation.
• To shift case in T9 mode, use the key. There
are 3 cases: Initial capital ( ), Capital lock ( ),
and Lower case (No indicator).
• You can move the cursor by pressing the Left or
Right key. To delete letters, press the
C
key. Press
and hold the
C
key to clear the entire display.
Entering text
41
Using Number mode
Number mode enables you to enter numbers into a
text message. Press the keys corresponding to the
digits you want to enter.
Using Symbolic mode
Symbolic mode enables you to insert symbols into a
text message.
To Press the
select a symbol corresponding number
key.
display more symbols Up or Down key.
clear the symbol(s)
C
key.
insert the symbol(s)
into your message
OK
soft key.
42
Options during a call
Your phone provides a number of control functions
that you can use during a call.
Putting a call on hold
You can place the current call on hold whenever you
want. You can make another call while you have a
call in progress if your network supports this
service.
To place a call on hold, simply press the
Hold
soft
key. You can reactivate the call whenever you want,
by pressing the
Retrieve
soft key.
To make a call while you have a call in progress:
1. Enter the phone number that you wish to dial, or
look it up in Phonebook.
For details about searching for a number in
Phonebook, see page 63.
2. Press the key to dial the second call.
The first call is automatically put on hold.
Or,
1. Put the current call on hold by pressing the
Hold
soft key.
2. Make the second call in the normal way.
Options during a call
43
When you have an active call and a call on hold, you
may switch between the 2 calls, changing the one
on hold to active and placing the other on hold.
To switch between the 2 calls, simply press the
Swap
soft key.
The current call is placed on hold and the call on
hold is reactivated so that you can continue
conversing with that person.
When you want to finish, end each call normally by
pressing the key.
Using the speaker
You can speak and listen to the phone from a short
distance without having to hold the phone to your
ear, for example, having it on a table nearby. To use
this feature, press the key during a call. A
icon appears on the bottom line of the screen. To
return to the normal phone mode, press the key
again and a icon appears on the bottom line of
the screen.
Call waiting
You can answer an incoming call while you have a
call in progress, if your network supports this
service and you have set the
Call
waiting
menu
(
Menu 9.5.3
) to
Activate
; see page 210. You are
notified of an incoming call by a call waiting tone.
To answer a call while you have a call in progress:
1. Press the key to answer the incoming call.
The first call is automatically put on hold.
Options during a call
44
2. To switch between the 2 calls, press the
Swap
soft key.
3. To end the call on hold, press the
Options
soft
key and select the
End
held
call
option.
To end the current call, press the key.
Using the Bluetooth headset
Using the Bluetooth headset, you can converse with
the person on the phone without having to hold the
phone to your ear during a call. To use this feature,
you first need to register your headset and connect
it to the phone. For further details, see page 214.
To use the Bluetooth headset:
1. Put on the headset.
2. Press the
Options
soft key.
3. Select the
Bt headset on
option.
4. Press the
Select
soft key.
Now you can talk to the other person via the
headset.
To return to the normal phone mode, press the
Options
soft key and select the
Bt headset off
option.
Options during a call
45
Switching on or off the Voice Clarity
feature
You can increase the microphone’s sensitivity to
allow the other person on the phone to hear your
voice even though you may be whispering.
To switch the Voice Clarity feature on:
1. Press the
Options
soft key.
2. Select the
Voice clarity on
option.
3. Press the
Select
soft key.
To switch the Voice Clarity feature off:
1. Press the
Options
soft key.
2. Select the
Voice clarity off
option.
3. Press the
Select
soft key.
Switching off the microphone (Mute)
You can temporarily switch off your phone’s
microphone so that the person on the phone cannot
hear you.
Example: You wish to say something to person in
the room, but do not want the person on
the phone to hear you.
To switch the microphone off temporarily:
1. Press the
Options
soft key.
2. Select the
Mute
option.
3. Press the
Select
soft key.
The person can no longer hear you.
Options during a call
46
To switch the microphone back on:
1. Press the
Options
soft key.
2. Select the
Unmute
option.
3. Press the
Select
soft key.
The person can hear you again.
Muting or sending key tones
These options allow you to turn off or on the key
tones. If the
Mute
keys
option is selected, your
phone does not transmit the DTMF (Dual Tone Multi-
Frequency) tones of the keys, which allows you to
press keys without hearing annoying key tones
during a call.
Note
: To communicate with answering machines or
computerised telephone systems, the
Send
keys
option must be selected.
Using Phonebook
You can use the
Phonebook
menu during a call, so
that you can search for or store entries.
For further details about the Phonebook feature,
see page 63.
Options during a call
47
Sending a sequence of DTMF tones
You can send DTMF tones as a group after entering
the entire number you need to send or retrieving a
number from the Phonebook list.
This option is helpful for entering a password or an
account number when you call an automated
system, like a banking service.
To send DTMF tones:
1. While connected to the teleservice system, press
the
Options
soft key.
2. Select the
Send
DTMF
option.
3. Press the
Select
soft key.
4. Enter the number you want to send and press
the
OK
soft key.
The tones are sent.
Using the message service
If you receive a message during a call, the Message
icon ( ) appears on the display. The
Message
option enables you to read the message. You can
also send a new message.
For further details about the Messages feature, see
page 106.
Options during a call
48
Using SIM services
The
SIM service
menu is available if you use a SIM
card that provides additional services, such as
news, weather, sports, entertainment, and location
services. Available services may vary, depending on
your service provider’s service plans.
For further details, see your SIM card instructions
or contact your service provider.
Making a multi-party call
A multi-party call is a network service that allows
up to 6 people to take part simultaneously in a
multi-party or conference call. For further details
about subscribing to this service, contact your
service provider.
Setting up a multi-party call
1. Call the first participant in the normal way.
2. Call the second participant in the normal way.
The first call is automatically put on hold.
3. To join the first participant to the multi-party
call, press the
Options
soft key and select the
Join
option. Press the
Select
soft key.
4. To add a new person to the multi-party call, call
the new person in the normal way and press the
Options
soft key. Select the
Join
option and
press the
Select
soft key.
You can add incoming callers by answering the call,
pressing the
Options
soft key and selecting the
Join
option. Repeat as required.
Options during a call
49
Having a private conversation with one
participant
1. Press the
Options
soft key and choose the
Split
option. Press the
Select
soft key.
The list of call participants appears.
2. Highlight a person from the list by pressing the
Up or Down key, and press the
Select
soft key.
Now you can talk privately to that person. The
other participants can still converse with each
other.
3. To return to the multi-party call, press the
Options
soft key and select the
Join
option.
Press the
Select
soft key.
All the multi-party call participants can now hear
each other.
Dropping one participant
1. Press the
Options
soft key and choose the
Remove
option. Press the
Select
soft key.
The list of call participants appears.
2. Highlight a person from the list by pressing the
Up or Down key, and press the
Select
soft key.
The call with that participant ends, but you can
continue to talk to the others.
3. When you want to end the multi-party call, close
the phone or press the key.
50
Using the menus
The phone offers a range of functions that allow you
to tailor it to your needs. These functions are
arranged in menus and sub-menus.
The menus and sub-menus can be accessed by
scrolling or by using shortcuts.
Accessing a menu function by scrolling
1. In Idle mode, press the
Menu
soft key to access
Menu mode.
2. Select
Settings
using the Navigation keys and
press the
Select
soft key.
3. Scroll by pressing the Up or Down key to reach a
main menu,
Phone
settings
for example. Press
the
Select
soft key.
4. If the menu contains sub-menus,
Language
for
example, you can access them by pressing the
Up or Down key and press the
Select
soft key.
If the menu that you have selected contains
further options, repeat this step.
5.
To Press the
scroll through the
menus Up or Down key.
confirm the chosen
setting
Select
soft key or the
key.
return to the previous
menu level
Back
soft key or the
C
key.
exit the menu without
changing the settings key.
Using the menus
51
Using shortcuts
Menu items, such as menus, sub-menus, and
options, can be accessed quickly by using their
shortcut numbers. For the main menus, you can
access any one of them by pressing the number keys
(
1
to
9
) corresponding to their location
on the screen.
Press the
Menu
soft key and enter the number of
the menu you want.
Notes
:
• The numbers assigned to each menu are indicated
on the list on page 52. They may not match the
menu on your phone, depending on the services
supported by your SIM card.
• For menu number 10, use the
0
key.
Example: Accessing the
Language
menu
1. Press the
Menu
soft key.
2. Press the
9
key for
Settings
.
3. Press the
2
key for
Phone
settings
.
4. Press the
1
key for
Language
.
The languages available display.
Using the menus
52
List of menu functions
The following list shows the menu structure and
indicates the number assigned to each option and
the page where you can find a description of each
feature.
1. Call records
(see page 58)
1.1 All calls
1.2 Dialled calls
1.3 Received calls
1.4 Missed calls
1.5 Delete all
1.6 Call time
1.6.1 Last call time
1.6.2 Total sent
1.6.3 Total received
1.6.4 Reset timers
1.7 Call costs
*
1.7.1 Last call cost
1.7.2 Total cost
1.7.3 Max cost
1.7.4 Reset counters
1.7.5 Set max cost
1.7.6 Price/Unit
2.
Phonebook
(see page 63)
2.1 Contact list
2.2 Add new contact
2.3 Group
2.4 Speed dial
2.5 My name card
2.6 Own number
2.7 Management
2.7.1 Default saving
2.7.2 Copy all to phone
2.7.3 Delete all
2.7.4 Memory status
2.8 Service number
*
* Shows only if supported by your SIM card.
Using the menus
53
3. Applications
(see page 76)
3.1 Java world
3.1.1 Downloads
3.1.2 Settings
3.1.3 Memory status
3.2 MP3 player
3.3 Voice recorder
3.4 World time
3.5 Alarm
3.6 Calculator
3.7 Converter
3.7.1 Currency
3.7.2 Length
3.7.3 Weight
3.7.4 Volume
3.7.5 Area
3.7.6 Temperature
3.8 Timer
3.9 Stopwatch
3.10 SIM AT
*
4. Browser
(see page 98)
4.1 Home
4.2 Bookmarks
4.3 Go to URL
4.4 Clear cache
4.5 Settings
4.6 Current proxy
* Shows only if supported by your SIM card.
Using the menus
54
5. Messages
(see page 106)
5.1 Short messages
5.1.1 Create
5.1.2 Inbox
5.1.3 Outbox
5.1.4 Draft
5.1.5 Settings
5.1.6 Block number
5.1.7 Delete all
5.2 Multimedia messages
5.2.1 Create
5.2.2 Inbox
5.2.3 Outbox
5.2.4 Draft
5.2.5 My folder
5.2.6 Template
5.2.7 Settings
5.2.8 Delete all
5.3 Email
5.3.1 Create
5.3.2 Inbox
5.3.3 Outbox
5.3.4 Draft
5.3.5 My folder
5.3.6 Settings
5.3.7 Block address
5.3.8 Delete all
5.4 Push messages
5.4.1 Inbox
5.4.2 Setting
5.4.3 Delete all
5.5 Voice mail
5.5.1 Connect to voice mail
5.5.2 Voice server number
5.6 Text template
Using the menus
55
5. Messages
(continued)
5.7 Broadcast messages
5.7.1 Read
5.7.2 Receive
5.7.3 Channel
5.7.4 Language
5.8 Memory status
6. Funbox
(see page 155)
7. Organiser
(see page 167)
7.1 Month view
7.2 Week view
7.3 Day view
7.4 Schedule
7.5 Anniversary
7.6 Miscellaneous
7.7 To do
7.8 Missed alarm events
7.9 Memo
7.10 Memory status
8. Camera
(see page 182)
8.1 Take a photo
8.2 Record video
8.3 Photos
8.4 My photos
8.5 Video clips
8.6 My video clips
Using the menus
56
9. Settings
(see page 197)
9.1 Time & Date
9.2 Phone settings
9.2.1 Language
9.2.2 Greeting message
9.2.3 Slide settings
9.2.4 Shortcut
9.2.5 Extra settings
9.3 Display settings
9.3.1 Wallpaper
9.3.2 Text display
9.3.3 Skin
9.3.4 LCD brightness
9.3.5 Backlight
9.4 Sound settings
9.4.1 Incoming call
9.4.2 Keypad tone
9.4.3 Message tone
9.4.4 Power on/off
9.4.5 Slide tone
9.4.6 Quiet mode
9.4.7 Extra tones
9.5 Network services
9.5.1 Call diverting
9.5.2 Call barring
9.5.3 Call waiting
9.5.4 Network selection
9.5.5 Caller ID
9.5.6 Band selection
9.5.7
Active line
9.6 Connectivity
9.6.1 Bluetooth
9.6.2 Infrared
Using the menus
57
9. Settings
(continued)
9.7 Security
9.7.1 PIN check
9.7.2 Change PIN
9.7.3 Phone lock
9.7.4 Change password
9.7.5 Privacy
9.7.6 SIM lock
9.7.7 FDN mode
*
9.7.8 Change PIN2
*
9.8 Memory status
9.8.1 Shared memory
9.8.2 Messages
9.8.3 Funbox
9.8.4 Organiser
9.8.5 Phonebook
9.8.6 JAVA world
9.9 Reset settings
* Shows only if supported by your SIM card.
58
Call records
In this menu, you can view the:
• calls you have dialled, received, or missed.
• length of your calls.
• cost of your calls, depending on your SIM card.
Notes
:
• You can access the call records of all 3 types of calls
by pressing the
key in Idle mode.
• The number of call records the phone can store may
vary, depending on your SIM card.
All calls
(Menu 1.1)
In this menu, you can view the 20 most recent calls
used, in the order you’ve dialled, received, or
missed them.
The numbers or names, if saved in your phone,
display.
To Press the
select a call type Left or Right key.
scroll through the list Up or Down key.
view details of a call key.
call a number key.
exit the current screen
Back
soft key.
Call records
59
On the call list or details view, press the
Options
soft key to access the following options:
Details
: shows details about the call, such as the
number or name, if available, the time and date it
was dialled, received, or missed. This option shows
only in the call list.
Call back
: dials the number.
Paste
: allows you to save the number in your
Phonebook. For further details about storing a
number, see page 65.
Send message
: allows you to send an SMS or MMS
message to the number. For further details about
sending a message, see page 107 or page 116
respectively.
Delete
: deletes the number.
Delete all
: deletes all calls.
Dialled calls
(Menu 1.2)
This menu lets you view the 20 most recent calls
you have dialled. When you access this menu, the
list of dialled calls displays.
For further details about scrolling through the list
and accessing the call log, see “All calls” on page
58.
Call records
60
Received calls
(Menu 1.3)
This menu lets you view the 20 most recent calls
you have received. When you access this menu, the
list of received calls displays.
For further details about scrolling through the list
and accessing the call log, see “All calls” on page
58.
Missed calls
(Menu 1.4)
This menu lets you view the 20 most recent calls
you have received, but did not answer. When you
access this menu, the list of missed calls displays.
For further details about scrolling through the list
and accessing the call log, see “All calls” on page
58.
Delete all
(Menu 1.5)
This menu allows you to delete all of the records in
each call record separately. You can also delete all
of your call records at one time.
1.
To Press the
select a call record
to clear Up or Down key. To
delete all of your call
records, select
All
calls
.
place or remove a
check mark key.
Call records
61
2. Press the
OK
soft key to delete the marked
records.
3. When a confirmation message appears, press
the
Yes
soft key.
Call time
(Menu 1.6)
This menu lets you view the time log for calls made
and received.
Note
: The actual time invoiced by your servi
ce
provider may vary, depending on network
features, rounding-off for billing purposes, and
so on.
The following time logs are available:
Last
call
time
: shows the length of the last call.
Total
sent
: shows the total length of all calls you
have made since the timer was last reset.
Total
received
: shows the total length of all calls
you have received since the timer was last reset.
Reset
timers
: allows you to reset the call timers.
After confirming the reset, you must enter the
phone password and then press the
OK
soft key.
Note
: The password is preset to “00000000” at the
factory. To change this password, see
page 219.
Call records
62
Call costs
(Menu 1.7)
This network feature lets you view the cost of calls.
This menu may not be available, depending on your
SIM card.
The following options are available:
Last
call
cost
: shows the cost of the last call you
made.
Total
cost
: shows the total cost of all calls you
have made since the cost counter was last reset. If
the total cost exceeds the maximum cost set in the
Set
max
cost
option, you can no longer make any
calls until you reset the counter.
Max
cost
: shows the maximum cost set in the
Set
max
cost
option.
Reset
counters
: allows you to reset the cost
counter. You must first enter your PIN2 (see
page 230) and then press the
OK
soft key.
Set
max
cost
: allows you to enter the maximum
cost authorised for your calls. You must first enter
your PIN2 (see page 230) and then press the
OK
soft key.
Price/Unit
: allows you to set the cost of one unit;
this price per unit is applied when calculating the
cost of your calls. You must first enter your PIN2
(see page 230) and then press the
OK
soft key.
63
Phonebook
You can store phone numbers and their
corresponding names in both your SIM card and
your phone’s memories. They are physically
separate but are used as a single entity, called
Phonebook.
Note
: Depending on your particular SIM card, the
maximum number of phone numbers the SIM
card can store may differ.
Contact list
(Menu 2.1)
In this menu, you can search for numbers in
Phonebook by entering names.
Note
: You can quickly enter this menu by pressing the
Contacts
soft key in Idle mode.
1. Enter the first few letters of the name that you
want to find or scroll to a name by pressing the
Up or Down key.
The names in Phonebook are listed, starting with
the one that most closely matches your input.
2.
To Press the
view the highlighted
name key.
select a different
name Up or Down key until
the name you want
highlights.
look for a name
starting with a
different letter
key labelled with the
letter you want.
Phonebook
64
3. Once you have found the number, press the
key to dial.
Alternatively, press the
Options
soft key to
access the Phonebook entry options; for further
details, see below.
On the Contacts list screen, press the
Options
soft
key to access the following options:
View
: shows information about the selected name.
Delete
: allows you to delete the selected name.
Using Phonebook options
While viewing any name in Phonebook, press the
Options
soft key to access the following options for
the name.
Note
: Available options may vary, depending on the
field you selected.
Edit
:
allows you to edit the name and number.
Send message
: allows you to send an SMS,
MMS, or e-mail message to the selected number
or e-mail address. For further details about
sending a message, see page 107, page 116, or
page 133, respectively.
Copy
: allows you to copy the number to another
location, either
Phone
or
SIM
.
Send
: allows you to access the following sending
options:
Via SMS: allows you to send the selected name as a
business card by SMS message. For details, see
page 107
.
Phonebook
65
Via MMS: allows you to send the selected name as a
business card by MMS message. For details, see
page 116
.
Via Email: allows you to send the selected name as
a business card by e-mail. For details, see
page 133
.
Via Bluetooth: allows you to send the selected
name as a business card via the Bluetooth feature.
For further details, see page 216.
Via infrared: allows you to send the selected name
as a business card via the infrared port. For further
details, see page 217.
Delete
: allows you to delete the selected name
from Phonebook. You are asked to confirm that you
wish to delete the name by pressing the
Yes
soft
key.
Add new contact
(Menu 2.2)
This menu allows you to add a new entry into
Phonebook. In the phone’s memory, a name can
contain up to 5 numbers in different categories:
Mobile, Home, Office, Fax, and Other. You can save
only one number in a SIM card entry.
Note
: You can select a default memory location in
which you want to save the number. For further
details, see page 73.
Storing a number in the phone’s memory
1. When
Phone
highlights, press the
Select
soft
key.
Phonebook
66
2. Press the Down key to move and change the
setting, or enter more information, if necessary.
Note
: Depending on the selected memory,
information or settings you can enter may
be different.
•
Last name
/
First name
: Enter the entry
name. For further details about how to enter
characters, see page 36.
•
Mobile
/
Home
/
Office
/
Fax
/
Other
: Add a
number for any category.
•
Email
: Enter an e-mail address.
•
Graphic ID
: Assign an image as a caller ID
image to be displayed when you receive a call
from the selected number.
•
Alert
: Select an unique ringer melody for the
entry. By selecting a different tone for each
entry, incoming voice calls having a caller ID
can be distinguished from each other.
•
Group
: Select one of the relation groups you
have created, where the entry is included.
Grouping the entries enables you to search for
an entry within the group. See page 68.
•
Notes
: Add a memo about the person.
3. When you have finished entering the contact
information for the entry, press the key.
Alternatively, press the
Options
soft key and
select
Save
.
After storing, the phone displays information
about the entry you just created.
Phonebook
67
Storing a number on the SIM card
1. Select
SIM
and press the
Select
soft key.
Note
: When you change phones, any numbers
stored on your SIM card memory are
automatically available with the new phone,
whereas any numbers stored in the phone’s
memory will need to be reentered.
2. Enter a name and press the Down key.
3. Enter a phone number.
4. Press the Down key to move to the location
field.
5. If you do not want to save the number and
name in the suggested location, press the
C
key
to clear the location number and enter another
location by pressing the number keys.
6. Press the key.
Alternatively, press the
Options
soft key and
select
Save
.
4.
To Press the
access the options
Options
soft key. For
further details, see
page 64.
dial a number Down key to scroll to a
number and press the
key.
Phonebook
68
Group
(Menu 2.3)
In this menu, you can organise your Phonebook
entries in caller groups.
Creating a new caller group
1. On the Group screen, press the
Options
soft
key.
2. Select the
Add
option and press the
Select
soft
key.
3. Enter a name for your group and press the
Down key.
For further details about how to enter
characters, see page 36.
4. When the Graphic ID field highlights, press the
key.
After selecting an image, the display returns to
the Edit screen.
5. Press the Down key to move to the Alert field
and press the key.
After selecting a melody or sound, the display
returns to the Edit screen.
7.
To Press the
access the options
Options
soft key. For
further details, see
page 64.
exit the current screen
Back
soft key or the
C
key.
Phonebook
69
6. If you want to change the added items, press
the Up or Down key to highlight a field and press
the
Options
soft key.
The following options are available:
•
Edit
: allows you to edit the group image or
melody.
•
Save
: saves the caller group you created.
•
Cancel
: deletes the caller group.
7. Select the
Save
option and press the
Select
soft key.
The new group is added to the Group list.
Adding members to a caller group
Once you have created caller groups on the Group
list, do as follows to add members to a group:
1. Scroll to the group you want and press the
key.
2. Press the
Add
soft key or the key to open the
Contact list screen.
Note
: You can add entries stored in the phone’s
memory to a group.
3. Scroll to the name you want to add to the group
and press the
Select
soft key.
The selected name is added to the group.
4. To add more members, press the
Options
soft
key, select
Add
, and select a name from the
Phonebook list. Repeat this step as often as
necessary.
You can delete an added member by selecting
Delete
.
Phonebook
70
5. When you have finished, press the key.
Managing caller groups
After creating caller groups and adding members to
the groups, the Group list shows the group names
and the numbers of members in each group.
Press the
Options
soft key to access the following
options:
View
: shows the list of the members in the group.
Add
: allows you to add a new group.
Edit
: allows you to change the properties of the
currently selected group, such as the name, image,
and melody.
Delete
: allows you to delete the currently selected
group. When you delete a group, the members in
the group are not deleted from Phonebook.
To view the names in a caller group, scroll to the
group and press the key. The list of the members
in the group appears.
Press the
Options
soft key to access the following
options:
View
: shows you entry details stored in Phonebook.
Add
: allows you to add a member to the group.
Delete
: allows you to delete a name from the group.
Phonebook
71
Speed dial
(Menu 2.4)
You can assign up to 8 of your most frequently used
phone numbers from your Phonebook list to the
number keys (
2
to
9
), and then dial them easily
whenever you want, simply by pressing and holding
the associated number key.
Setting up speed dial entries
1. Select the key to which you wish to assign the
speed dialling number, from the
2
to
9
keys, and
press the key.
Note
: Memory location 1 is reserved for your
Voice Mail server number.
2. Enter the name you want to find, or scroll to a
number using the Up or Down key.
3. Press the
Select
soft key.
When you select a key on the Speed dial screen,
you can access the following options by pressing
the
Options
soft key:
Add
: allows you to assign a number to the key. This
option shows for an empty key.
Change
: allows you to assign a different number to
the key. This option shows for an occupied key.
Remove
: allows you to clear the setting so that no
number is assigned to the key.
Speed dialling
To speed dial the numbers assigned to the
2
to
9
keys, press and hold the appropriate key in Idle
mode.
Phonebook
72
My name card
(Menu 2.5)
In this menu, you can create a name card for
yourself. After creating a name card, you can send
it to other people via several different routes.
Create your name card as you would for saving a
number in Phonebook. For further details, see
page 65.
After saving a name card, press the
Options
soft
key to access the following options:
Edit
: allows you to edit your name card.
Send
: allows you to access the following sending
options:
via SMS: allows you to attach your name card to a
text message. For further details, see
page 107
.
via MMS: allows you to attach your name card to an
MMS message. For further details, see
page 116
.
via Email: allows you to attach your name card to
an e-mail. For further details, see
page 133
.
via Bluetooth: allows you to send your name card
via the Bluetooth feature. For further details, see
page 216.
via infrared: allows you to send your name card via
the infrared port. For further details, see page 217.
Delete
: allows you to clear your name card.
Phonebook
73
Own number
(Menu 2.6)
This function is a memory aid, which you can use to
check your own phone numbers if you need to do so.
You can:
• assign a name to each of your own phone
numbers registered on your SIM card.
• delete the names and numbers.
Any changes made here do not in any way affect
the actual subscriber numbers on your SIM card.
Management
(Menu 2.7)
In this menu, you can:
• select the default memory location to which
numbers are saved.
• copy all of the Phonebook entries in your SIM
card to your phone’s memory.
• delete all of the entries in Phonebook.
• check the memory status of Phonebook.
Default saving
(Menu 2.7.1)
You can select a default memory location to which
you want names and numbers saved.
The following options are available:
Phone
: saves names and numbers in the phone’s
memory.
SIM
: saves names and numbers on the SIM card.
Ask on saving
: displays the Save to screen to
allow you to select a memory location manually.
Phonebook
74
Copy all to phone
(Menu 2.7.2)
You can copy all of the names stored on the SIM
card to the phone’s memory. When a confirmation
message appears, press the
Yes
soft key.
Delete all
(Menu 2.7.3)
You can delete all of the names from your phone’s
memory, your SIM card, or both.
1. To place a check mark by the memory location
you want to empty,
All
,
SIM
, or
Phone
, press
the key.
You can remove the check mark by pressing the
key again.
2. When you have finished marking, press the
Delete
soft key to delete the entries in the
selected memory location(s).
3. When a confirmation message appears, press
the
Yes
soft key.
4. Enter the phone password and press the
OK
soft
key.
Note
: The password is preset to “00000000” at
the factory. To change this password, see
page 219.
Phonebook
75
Memory status
(Menu 2.7.4)
You can check how many names are stored in
Phonebook, in both the phone’s memory and on the
SIM card.
The display shows you the number of entries you
have stored and the total number of the entries you
can store in the phone’s memory and on the SIM
card.
Service number
(Menu 2.8)
You can view the list of Service Dialling Numbers
(SDN) assigned by your service provider. These
numbers include emergency numbers, directory
enquiries, and voice mail numbers.
1. Scroll through the numbers by pressing the Up
or Down key.
2. Press the
Dial
soft key to dial the number
displayed.
Note
: This menu is available only when your SIM card
supports Service Dialling Numbers.
76
Applications
In this menu, you can:
•enjoy various Java games.
• play music files using your phone as an MP3
player.
• record a voice memo.
• set your time zone and check world time.
• set an alarm so that the phone alerts you at a
specific time.
• use the phone as a calculator for basic
mathematical equations, or as a convertor.
• use the phone as a timer or stopwatch.
Java world
(Menu 3.1)
You can enjoy Java games. You can also change the
DNS setting required for accessing Java services, if
necessary, and view the memory status for Java
games.
Downloads
(Menu 3.1.1)
When you access the
Java games
menu, the list of
default games appears. Once you have downloaded
games, they are added to the list.
Note
: Java services may not be available, depending
on your service provider.
Applications
77
Using Java game options
On the Downloads screen, press the
Options
soft
key to access the following options:
Launch
: launches the selected MIDlet.
Application Settings
: allows you to select
whether or not to continue a game when an event,
such as incoming messages or alarms, occurs on
the phone during the game. You can also select
whether or not you exchange game information
with the network while playing an on-line game or
when you need to connect to the Internet.
Delete
: allows you to delete the MIDlet.
Properties
: shows you properties about the
MIDlet.
Playing ForgottenWarrior
1. On the Downloads screen, select
ForgottenWarrior
and press the key.
2. Press any key twice to launch the game.
3. Press the
PLAY
soft key.
Alternatively, press the
OPTIONS
soft key to
access the following options:
•
StartGame
: starts a new game.
•
Continue
: allows you to continue the last
game you played.
•
Instruction
: shows how to play the game and
the key functions for the game.
•
Setting
: allows you to change the default
settings for the game.
SOUND: allows you to turn the game sound on
or off.
Applications
78
VIBRATION: allows you to set the phone to
vibrate when you move to another stage.
SPEED: allows you to select a game speed
using the Left or Right key.
•
Quit
: exits the game.
4. Select
StartGame
or
Continue
and press the
OK
soft key to start playing.
If necessary, press the
SKIP
soft key on the
start screen.
During a game, press the
OPTIONS
soft key to
access the following options:
RESUME
: resumes the game.
INSTRUCTIONS
: shows how to play the game and
the key functions for the game.
SOUND ON/OFF
: allows you to turn the game
sound on or off.
MAIN MENU
: returns to the main menu screen of
the game.
QUIT
: quits the game.
Playing Freekick
1. On the Downloads screen, select
Freekick
and
press the key.
2. Press any key to display the following options:
•
Game
: allows you to select a game mode,
Training Mode
,
Stage Mode
, or
Striker
Mode
.
Applications
79
•
Option
: allows you to change the default
settings for the game:
Sound: allows you to turn the game sound on
or off.
Vibration: allows you to set the phone to
vibrate when you kick the ball.
•
HELP
: allows you to access the following
options:
Instruction: shows the goal of the game.
How to play: shows how to play the game.
Game Mode: shows explanations of each game
mode.
Control: shows the key functions for the game.
•
EXIT
: exits the current screen.
3. Select
Game
and press the key.
4. Select a game mode,
Training Mode
,
Stage
Mode
, or
Striker Mode
, and press the key.
5. Select a team and press the key.
To return to the previous screen, press the
key.
6. Select a player and press the key.
7. To start a game, press the key.
Now the game is loaded and starts.
Applications
80
During a game, press the key to access the
following options:
RESUME
: resume the game.
OPTION
: allows you to change the default settings
for the game:
Sound: allows you to turn the game sound on or off.
Vibration: allows you to set the phone to vibrate
when you kick the ball.
Help
: allow you to access following options:
Instruction: shows the goal of the game.
How to play: shows how to play the game.
Game Mode: shows explanations of each game
mode.
Control: shows the key function for the game.
QUIT
: quits the game.
Playing ArchAngel
1. On the Downloads screen, select
ArchAngel
and press the key.
2. Press any key to display the following options:
•
NEW GAME
: allows you to start a new game.
•
LOAD GAME
: allows you to restart a saved
game.
3. Select either of the options and press the
OK
soft key.
4. Select a game mode,
EASY MODE
or
HARD
MODE
and press the
OK
soft key.
Applications
81
5. Press the
NEXT
soft key or the key repeatedly
until the following options display:
Alternatively, press the
SKIP
soft key to go to
the options screen. The following options
display:
•
Briefing
: shows the mission for the game.
•
Mission Start
: starts a new game.
•
System
: allows you to access the following
options:
Save Game: allows you to save the game.
Load Game: allows you to restart a saved
game.
Sound: allows you to turn the game sound on
or off.
Plasma Canon: allows you to set whether or
not missiles are automatically fired.
Information: allows you to view information
about the game screen, return to the Menu
list, or start a game.
Quit: quits the game.
•
Information
: shows you information about
the game.
•
Machine Shop
: allows you to buy items, such
as weapons or armour.
6. Press the
Play
soft key.
7. Press the
Next
soft key or the key repeatedly
until you see the mission information.
Alternatively, when you press the
Skip
soft key
to start a game.
Applications
82
8. If necessary, press the
Start
soft key to start a
game.
9. To pause the game, press the
PAUSE
soft key.
To resume the game, press the
RESUME
soft
key.
During a game, press the
OPTIONS
soft key to
access the following options:
RESUME
: resumes the game.
SOUND
: allows you to turn the game sound on or
off.
PLASMA
: allows you to select whether or not
missiles are automatically fired.
INSTRUCTIONS
: shows how to play the game and
the key functions for the game.
MAIN MENU
: returns to the main menu screen of
the game.
QUIT
: quits the game.
Entering text
If you need to enter text while using a MIDlet, you
can use the following input modes:
Upper-case character mode
(
A
): allows you to
enter upper-case English characters.
Lower-case character mode
(
a
): allows you to
enter lower-case English characters.
Number mode
(
1
): allows you to enter numbers.
Symbol mode
: allows you to enter symbols. After
highlighting a symbol by pressing the Navigation
keys, press the key to insert it.
Applications
83
T9 mode
(
T9
): allows you to enter English
characters by pressing one key per letter. In this
mode, you can change the case by pressing the
0
key.
To change the text input mode, press the key
until the appropriate indicator appears on the soft
key area of the display.
Setting
(Menu 3.1.2)
In this menu, you can change the settings for
accessing Java services.
The following options are available:
APN
: Enter the access point name.
Login ID
: Enter the User ID.
Password
: Enter the password.
DNS1
: Enter the primary DNS address.
DNS2
: Enter the secondary DNS address.
Memory status
(Menu 3.1.3)
In this menu, you can view the total and used
memory amounts for Java games.
Applications
84
MP3 player
(Menu 3.2)
You can enjoy music using your phone as an MP3
player.
Before using the MP3 player, you first need to save
MP3 music files in your phone’s memory.
Downloading and receiving MP3 music
files
You can download or receive music files using the
following methods:
• from the Wireless Web.
• from a computer. You can download music files
from your computer to the phone through the
EasyStudio programme.
• from received multimedia messages or e-mails.
•Via IrDA.
• Via Bluetooth. For further details about receiving
data via Bluetooth, see page 216.
The downloaded or received files are stored in the
Music
folder. See page 160.
Creating the play list
Before playing MP3 music files, you need to add
them to the play list.
1. On the MP3 player screen, press the
Options
soft key.
Applications
85
2. Select
Add to list
and press the
Select
soft key.
The following options are available:
•
Add all
: adds all of the music files stored in
the
Music
folder to the play list.
•
Add a file
: allows you to add a music file to
the play list. Continue to next steps.
3. If you select
Add a file
in step 2, scroll to a
music file and press the
Add
soft key or the
key.
4. To add more files to the play list, press the
Options
soft key. Follow the procedure from
step 2.
5. When the play list is complete, you can go back
to the MP3 player screen by pressing the
Back
soft key.
After adding files to the play list, press the
Options
soft key to access the following options:
Play
: plays the file.
Add to list
: allows you to add a file or all of the
files stored in your phone to the play list.
Move list
: allows you to move the selected file to
the position you want within the play list.
Remove
: allows you to remove the file from the
play list.
Remove all
: allows you to remove all of the files
stored in the play list.
Applications
86
Playing MP3 files
On the MP3 player screen, press the key to play
the file(s) in the play list.
You can use the following options while playing a
file:
• Scroll to a function button on the screen and
press the key. The following buttons are
available:
• Press the Volume keys to adjust the volume.
• Press the
Options
soft to access the options.
For details, see page 86.
• Press the
Stop
soft key to stop the playback.
Using MP3 file options
You can access the following options by pressing the
Options
soft key on the MP3 player screen:
Play
/
Pause
: begins/pauses playback.
Buttons Function
pauses.
resumes.
stops.
returns to the previous file.
skips to the next file.
/ / changes repeat mode style.
Applications
87
Send
: allows you to access the following sending
options:
via MMS: allows you to send the file to another
person as part of an MMS message. For details, see
page 116
.
via Email: allows you to send the file to another
person as part of an e-mail. For details, see
page 133
.
via Bluetooth: allows you to send the file to another
person via the Bluetooth feature. For details, see
page 216.
via infrared: allows you to send the file to another
person via the infrared port. For details, see
page 217.
Open play list
: shows the play list.
Set as
: allows you to set the file as your ring tone
or as a caller alert melody for an entry in
Phonebook.
Delete
: allows you to delete the file.
Settings
: allows you to change the default settings
for playing MP3 files. To change settings, press the
Left or Right key. The following options are
available:
Repeat: allows you to select a repeat mode,
One
,
All
, or
Off
.
Shuffle: allows you to select a playing order,
Normal
or
Random
.
Volume: allows you to select a volume level.
Volume key unlock: allows you to lock the Volume
keys on the left side of the phone so that you can
prevent an accidental press of the Volume keys
from affecting playback volume.
Applications
88
Equalizer value
: allows you to select an equalizer
value.
Properties
: shows information about the file.
Voice recorder
(Menu 3.3)
You can record voice memos. After recording, you
can send the memo to other people using various
sending options. You can record voice memos of up
to 1 hour in duration.
Recording a voice memo
1. To start recording, press the key.
2. Record a memo by speaking into the
microphone.
You can pause recording by selecting and
resume by selecting . You can also adjust
the volume by pressing the Volume keys.
3. When you have finished, scroll to and press
the key or press the
stop
soft key.
If the recording time expires, the phone will
automatically stop.
The voice memo is automatically saved.
4.
To Press the
use the options
Options
soft key. See
the following page.
return to the Voice
record screen
Back
soft key or the
C
key.
Applications
89
After recording a voice memo, you can access the
following options by pressing the
Options
soft key:
Play
: plays back your voice memo.
Send
: allows you to access the following sending
options:
via MMS: allows you to send the voice memo as
part of an MMS message. For further details, see
page 116
.
via Email: allows you to send the voice memo as
part of an e-mail. For further details, see
page 133
.
via Bluetooth: allows you to send the voice memo
to another person via the Bluetooth feature. For
further details, see page 216.
via infrared: allows you to send the voice memo to
another person via the infrared port. For further
details, see page 217.
Rename
: allows you to change the name of the
voice memo.
Delete
: allows you to delete the voice memo.
Protection
: protects the voice memo from being
deleted.
Properties
: shows you the properties of the voice
memo, such as the file name, the time and date it
was saved, format, recording duration, size, and
protection status.
Applications
90
Using the voice record options
On the Voice record screen, press the
Options
soft
key to access the following options:
Record
: begins recording a new voice memo.
Settings
: allows you to change the default settings
for recording a voice memo. To change settings,
press the Left or Right key. The following options
are available:
Recording time: allows you to select a recording
time,
1 hour
,
30 sec
, or
1 min
.
Volume: allows you to select a volume level for
recording voice memos.
Default name: allows you to change the default
prefix of the voice memo.
Equalize value: allows you to change the equalizer
image on the Voice record screen.
Go to voice list
: shows you the list of the voice
memos you have recorded.
Playing a voice memo
1. On the Voice record screen, press the
Options
soft key.
2. Select the
Go to voice list
option and press the
key.
3. Scroll to a voice memo and press the
Select
soft
key.
The selected memo plays.
Applications
91
4. You can pause playing by selecting and
resume by selecting . You can also adjust
the volume by pressing the Volume keys.
To stop, select or press the
Stop
soft key.
After playing a voice memo, you can access the
voice memo options by pressing the
Options
soft
key. For further details, see page 89.
World time
(Menu 3.4)
This menu allows you to find out what time it is in
another part of the world and apply Daylight
Savings Time, the summer time adjustment used in
many countries.
The screen shows the selected city name, and
current time and date.
To select your time zone:
1. Select the city corresponding to your home time
zone by pressing the Left or Right key one or
more times.
The corresponding time line moves and the local
time and date display.
2. Press the Down key.
3. Select the foreign time zone you want to check
by pressing the Left or Right key.
4. Press the key.
Alternatively, press the
Options
soft key and
select
Save
.
Applications
92
To apply Daylight Savings Time:
1. On the world map, press the
Options
soft key.
2. Select
Set daylight saving time
and press the
Select
soft key.
3. Scroll to the time zone to which you want to
apply the adjustment using the Up or Down key.
4. Press the key to place a check mark.
To remove a check mark, press the key again.
5. If necessary, repeat steps 3 and 4.
6. Press the
Save
soft key.
Alarm
(Menu 3.5)
This feature allows you to:
• set an alarm to ring at a specific time.
• set the phone to switch on automatically and ring
the alarm even if the phone is off.
To set an alarm:
1. Choose the type of alarm,
Morning call
,
Alarm1
, or
Alarm2
and press the
Select
soft
key.
2. Select
On
in the Alarm field by pressing the Left
or Right key and press the Down key.
3. Enter the time for the alarm to sound and press
the Down key.
Note
: Your phone is preset to a 24-hour format.
To change the format, see page 197.
Applications
93
4. If applicable, select
AM
or
PM
.
5. Press the Down key and press the key.
6. Select the day for which you need the alarm and
press the key to place a check mark. If you
want to set a one time alarm, select
Once
alarm
.
To remove a check mark, press the key again.
7. When you have finished selecting days, press
the
OK
soft key.
8. Press the Down key to move to the Alarm tone
field and press the key.
9. Select the alarm melody you want and press the
Select
soft key.
10.Press the
Save
soft key.
11.When a confirmation message appears, press
the
Yes
soft key.
When the time for an alarm comes, use either of
the two soft keys to stop the alarm:
• Press the
Confirm
soft key.
• Press the
Snooze
soft key or any key to stop the
alarm for 5 minutes, after which it will resume.
You can do this a maximum of 5 times.
Using the
Auto power
option, you can set your
alarms to ring at the specified time, even if the
phone is off.
1. On the Alarm screen, scroll to the
Auto power
option and press the
Select
soft key
.
2. Select
On
and press the
Select
soft key
.
Applications
94
If the time for an alarm comes and the phone is off,
the phone automatically switches on and rings the
alarm.
Calculator
(Menu 3.6)
With this feature, you can use the phone as a
calculator. The calculator provides basic arithmetic
functions: addition, subtraction, multiplication, and
division.
1. Enter the first number using the numeric keys.
Note
: To include a decimal point, press the
key.
2. Enter the operation for your calculation by
pressing the key until the symbol you want
displays.
3. Enter the second number.
4. To view the result, press the
Equal
soft key or
the key.
5. Repeat steps 1 to 4 as many times as required.
Applications
95
Converter
(Menu 3.7)
Using this menu, you can do currency and other
conversions.
1. Select the convertor type you want and press
the
Select
soft key.
2. Select the original unit by pressing the Left or
Right key and press the Down key.
3. Enter the value to be converted and press the
Down key.
Notes
:
• You can insert a decimal point by pressing
the
key
.
• For a temperature conversion, you can change
the sign of a number to above zero(+) or below
zero(-) by pressing the
key.
4. Select the unit you want to change into by
pressing the Left or Right key.
The equivalent value for the amount you entered
displays.
5. Press the
Back
soft key or the
C
key to exit the
current screen.
Applications
96
Timer
(Menu 3.8)
In this menu, you can set a period of time for the
phone to count down. The phone will alert you with
an alarm when the specified period of time has
expired.
1. Press the
Set
soft key.
2. Enter the length of time you want to count
down.
3. Press the
OK
soft key.
4. To start counting down, press the key.
Even if you exit the Timer screen, the timer will
continue running. When the specified time has
expired, the phone informs you by sounding a
melody and displaying a text notification.
To stop the timer melody when it rings, open and
close the phone or press any key.
To stop the timer before the end, press the key
on the Timer screen.
Notes
:
• The timer uses power from the battery, and
consequently the phone’s operating time is reduced.
• If the phone is in Quiet mode, it will vibrate when the
countdown ends.
Applications
97
Stopwatch
(Menu 3.9)
The stopwatch can be used to measure elasped
time for various sports.
Example: Running or swimming races
The precision of the stopwatch is one
one-hundredth of a second. The maximum
measurement time is 10 hours.
1. To start timing something, press the key.
2. To check an interval, for example, one lap, press
the key. You can repeat this step for a total of
4 intervals.
3. Press the
Reset
soft key to reset.
To exit, press the
Back
soft key or the
C
key.
SIM AT
(Menu 3.10)
This menu is available if you use a SIM AT card that
provides additional services, such as news, weather,
sports, entertainment, and location services.
Available services may vary, depending on your
service provider’s plans.
For further details, see your SIM card instructions
or contact your service provider.
98
Browser
Your phone is equipped with a WAP (Wireless
Application Protocol) browser to allow you to access
and navigate the Wireless Web using your phone.
Home
(Menu 4.1)
Selecting this menu connects the phone to the
network and loads the homepage of the Wireless
Web service provider. You can also press the key
in Idle mode to launch the browser.
The contents of the WAP Browser startup homepage
depends on your Wireless Web service provider. To
scroll through the screen, use the Up or Down key.
Note
: To go to the startup homepage from any other
screen in the WAP browser, use the
Home
option. For further details about the WAP
Browser menus, see page 99.
Exiting the WAP browser
To exit the browser at any time, simply press the
key.
Browser
99
Navigating the WAP browser
Entering text in the WAP browser
When you are prompted to enter text, the currently
active text input mode is indicated on the screen.
For further details about how to enter characters,
see page 36.
Selecting and using browser menu
options
Various menu options are available when you are
using the WAP browser to navigate the Wireless
Web.
To access a menu option:
1. Press the
Menu
soft key. A menu list displays.
You can also press the Up key to select the
Openwave icon and press the soft key.
2. Select the
Menu
option and press the soft
key.
To Press the
scroll through
browser items Up or Down key.
select a browser
item soft key.
return to the
previous page
Back
soft key or the
C
key.
return to the
startup homepage
C
key for more than two
seconds. For further details
about this option, see
page 100.
Browser
100
3. Highlight a menu by pressing the Up or Down
key.
4. Select an option by pressing the soft key.
5. If necessary, select a secondary option by
pressing the Up or Down key, and press the
Select
soft key to confirm.
Note
: The menus may vary, depending on your
version of the WAP browser.
The following options are available:
Back
: goes to the previous page.
Home
: takes you back at any time to the home
page of the Wireless Web service provider.
Exit
: exits the WAP browser.
Reload
: reloads the current page.
Show
URL
: displays the URL address of the Web
page to which you are currently connected. It also
enables you to set the current site as the startup
home page.
About...
: provides you with information about your
version of the WAP browser.
Using the WAP page options
When you are using the WAP browser, you can
access the following options by pressing the key.
Go to URL
: switches to the
Go to URL
menu. For
details, see page 102.
Bookmark
: switches to the
Bookmarks
menu. For
details, see page 101.
Browser
101
Messages
: allows you to check your Inbox,
Outbox, and Draft in the
Short messages
menu.
You can also create and send a new text message.
Funbox
: switches to the
Funbox
menu. For
details, see page 155.
Bookmarks
(Menu 4.2)
This menu allows you to store the URL addresses of
up to 15 of your favourite web sites.
To store a URL address:
1. Select an empty location or the item you want to
change and press the
Select
soft key.
2. Enter a name for the bookmark and press the
Down
key.
3. Enter the address and press the key or press
the
Options
soft key and select
Save
.
After saving an item, you can access the following
options by pressing the
Options
soft key:
Go
: quickly takes you to the site.
Edit
: allows you to edit the address and name of
the bookmark.
Delete
: allows you to delete the bookmark.
To access a bookmarked page, scroll to an item by
pressing the Up or Down key and press the key.
Browser
102
Go to URL
(Menu 4.3)
This menu allows you to manually enter the URL
address of a Web site that you wish to access.
For further details about how to enter characters,
see page 36.
Clear cache
(Menu 4.4)
Selecting this menu clears the information stored in
the cache, the phone’s temporary memory in which
the most recently accessed Web pages are stored.
When a confirmation message appears, press the
Yes
soft key.
Settings
(Menu 4.5)
This menu allows you to set up 5 servers for the
WAP browser. Contact your service provider for
details about your settings options.
For each server, the following options are available:
Profile
name
: enter a name that you wish to
assign to the server profile.
Homepage
URL
: set the address of your startup
homepage. When the default homepage displays,
you can delete it using the
C
key and enter your
own choice.
Bearer
: select a bearer to be used for each type of
network address accessed:
GPRS only
,
GSM
,
or
GPRS First only
.
Browser
103
Proxy
: select whether or not you use a proxy
server when you connect to the WAP browser.
Depending on the setting, options in the GPRS
settings and GSM settings vary.
When the proxy is set to
Enable
:
GPRS settings
: the following options are available:
IP address: enter the WAP gateway address
required to connect to the GPRS network.
Port: enter the port number required to connect to
the GPRS network.
APN: enter the access point name used for the
address of the GPRS network gateway.
Login ID: enter the User ID required to connect to
the GPRS network.
Password: enter the password required to connect
to the GPRS network.
GSM settings
: the following options are available:
IP address: enter the WAP gateway address
required to connect to the GSM network.
Port: enter the port number required to connect to
the GSM network.
Dial number: enter the PPP server phone number.
Login ID: enter user ID required to connect to the
GSM network.
Password: enter the password required to connect
to the GSM network.
Data call type: select a data call type:
ISDN
or
Analogue
.
Browser
104
When the proxy is set to
Disable
:
GPRS setting
: the following options are available:
DNS 1: enter the primary address to connect to the
GPRS network.
DNS 2: enter the secondary address to connect to
the GPRS network.
APN: enter the access point name used for the
address of the GPRS network gateway.
Login ID: enter the user ID required to connect to
the GPRS network.
Password: enter the password required to connect
to the GPRS network.
GSM settings
: the following options are available:
DNS 1: enter the primary address to connect to the
GSM network.
DNS 2: enter the secondary address to connect to
the GSM network.
Dial number: enter the PPP server phone number.
Login ID: enter the user ID required to connect to
the GSM network.
Password: enter the password required to connect
to the GSM network.
Data call type: select a data call type,
ISDN
or
Analogue
.
Note
: The WAP browser settings may vary, depending
on the service provider. Contact your service
provider for further details.
Browser
105
Current proxy
(Menu 4.6)
You can activate one of the proxies you have set up
to use the WAP connection.
106
Messages
Using the
Messages
menu, you can use various
message formats, such as:
• text messages
• multimedia messages
• E-mail messages
•WAP push messages
•voice mail
• cell broadcast messages
Short message
(Menu 5.1)
Short Message Service (SMS) allows you to send
and receive short text messages to and from other
GSM mobile phones. In addition, your phone
supports the Enhanced Messaging Service (EMS),
which enables you to include pictures, melodies,
and animated images in your messages. To use this
feature, you must subscribe to your service
provider’s message service.
The Text Message icon ( ) appears when you have
received new text messages. If the memory is full,
an error message displays and you will be unable to
receive any new messages. Use the
Delete
option
in each message box to delete unwanted messages.
Messages
107
Create
(Menu 5.1.1)
In this menu, you can write and send text
messages.
Creating a simple text message
1. Create your message.
You can create a message using standard
Alphabet characters or special Unicode
characters, depending on the setting in the
Character support
menu; see page 113.
Notes
:
• For further details about entering characters, see
page 34.
• You can enter up to 160 standard Alphabet
characters in your message. When you enter text
using Unicode characters, the maximum number
of characters in a message is reduced by
approximately half.
2. When you finish entering the message, press the
Options
soft key. The following options are
available:
Note
: when you press
the key
, the phone
automatically selects the
Send only
option.
Skip to step 4.
•
Send and save
: allows you to first save a copy
of the message and then sends the message.
You can read the message in your Outbox.
•
Send
only
: allows you to send the message.
The message is then deleted after sending.
•
Save message
: allows you to save the
message in the
Draft
box (
Menu 5.1.4
).
• For further details about
Text style
,
Add
media
,
Text
template
, and
Language select
options, see page 108.
Messages
108
3. Select
Send and
save
,
Send
only
, or
Save
message
, and press the
Select
soft key.
If you want to just save the message, select
Save message
.
4. Enter a destination number.
5. If you want to send the message to more than
one person, press the Down and fill in another
destination field.
6. If necessary, repeat steps 4 and 5 to add more
phone numbers. You can enter up to 10
numbers.
7. Press the key or the
Options
soft key and
then select
Send
. Press the
Select
soft key.
The message is sent.
Note
: When the phone fails to send the message, it
asks you if you want to retry. Press the
Retry
soft key to confirm. Otherwise, press the
No
soft key or
the key and press the
Save
soft
key
to save the message in the Draft box.
Creating a message using options
1. Create a message.
2. Press the
Options
soft key.
3. Select one of the following options by pressing
the Up or Down key and press the
Select
soft
key:
•
Text style
: allows you to format the style of
the text.
For the
Text size
attribute,
Small
,
Medium
,
and
Large
sizes are available.
For the
Text mode
attribute,
Normal
,
Underline
, and
Strikethrough
are available.
Messages
109
For the
Bold
and
Italic
attributes, place a
check mark by pressing the key to use a
particular text style.
For the
Alignment
attribute,
Left
,
Center
, and
Right
are available.
These attributes can combined.
•
Add
media
: allows you to add a picture,
animated image, or melody to the message.
Select the category of the content to be added.
In each category, you can select from the
various factory-set items or choose an item
received from other sources, such as the
Internet or other phones.
Note
: When you add media items to a message,
the number of characters you are allowed
to enter decreases.
•
Text
template
: allows you to apply one of the
preset message templates to the text. Select
one of 10 items stored in the
Templates
menu
(
Menu 5.6
). For further details, see page 152.
•
Language select
: allows you to change the
language to be used in T9 input mode. Select
the language to be used.
4. Complete the message, and send or save it by
following the procedure from step 2 on page 107.
Creating a long text message
When you write a text message, the phone
automatically splits it into several messages if your
message exceeds the maximum number of
characters allowed for sending. The number of split
messages to be sent is shown each time your
message is split. Depending on your service
provider, the maximum number of characters may
vary.
Messages
110
Inbox
(Menu 5.1.2)
This message box is used to store messages that
you have received.
When you select this menu, the list of messages in
the box displays with the senders’ phone numbers
or names, if available in Phonebook.
1. Select a message from the list and press the
key to read the message contents.
2. Press the Up or Down key to scroll through the
contents.
3. Press the Left or
Right
key to scroll to the
previous or next message.
Using the message options
While reading a message, you can choose the
following options by pressing the
Options
soft key:
Reply
: allows you to send a reply to the sender.
Send
: allows you to send/resend the message. For
further details about how to send a message, see
page 107
Call
back
: allows you to call the sender.
Edit
: allows you to edit the message.
Delete
: allows you to delete the message.
Cut media
: allows you to save media items, such
as sounds or images, from the message to your
phone. You can then use these items when writing a
message. For details, see page 109.
Cut
address
: allows you to extract URL, e-mail
addresses, or phone numbers from the message
text.
Messages
111
Transfer
: allows you to move the message from
the SIM card to the phone’s memory or vice versa.
Block number
: allows you to add the sender’s
number to the
Block number
folder (
Menu 5.1.6
)
so that you can reject a message from the number.
Protection
: allows you to protect the message
from being deleted.
On the message list, press the
Options
soft key to
access the following options:
View
: shows you the message.
Reply
: allows you to send a reply to the sender.
Send
: allows you to send/resend the message. For
further details about how to send a message, see
page 107.
Delete
: deletes the message.
Delete all
: allows you to delete all of the messages
stored in the Inbox.
Call back
: allows you to call the sender.
Outbox
(Menu 5.1.3)
This message box is used to store messages that
you have sent.
When you access this menu, a list of messages in
the box displays with the recipients’ phone numbers
or names, if available in Phonebook.
1. Select a message from the list and press the
key to read the message contents.
2. Press the Up or Down key to scroll through the
contents.
Messages
112
3. Press the Left or
Right
key to scroll to the
previous or next message.
Using the message options
While reading a message, you can choose the
following options by pressing the
Options
soft key
Send
: allows you to send/resend the message. For
further details about how to send a message, see
page 107.
Edit
: allows you to edit the message.
Delete
: allows you to delete the message.
Cut
address
: allows you to extract URL, e-mail
addresses, or phone numbers from the message
text.
Transfer
: allows you to move the message from
the SIM card to the phone’s memory or vice versa.
Protection
: allows you to protect the message
from being deleted.
On the message list, press the
Options
soft key to
access the following options:
View
: shows you the message.
Send
: allows you to send/resend the message. For
further details about how to send a message, see
page 107.
Edit
: allows you to edit the message.
Delete
: allows you to delete the message.
Delete all
: allows you to delete all of the messages
stored in the Outbox.
Messages
113
Draft
(Menu 5.1.4)
After creating a text message, you can store it in
this message box to be sent at a later time.
For further details about viewing a message, see
“Outbox” on page 111.
Settings
(Menu 5.1.5)
In this menu, you can set up default message
information. A setting group is a collection of
settings required to send messages.
Notes
:
• The setting options available in this menu may vary,
depending on your service provider.
• The last setting you accessed is automatically
activated for sending subsequent messages.
The following options are available:
Reply path
: allows the recipient of your message
to send you a reply through your message centre, if
your network supports this service.
Delivery report
: allows you to activate or
deactivate the report function. When this function is
activated, the network informs you whether or not
your message has been delivered.
Character support
: allows you to select a
character encoding type, either
GSM-alphabet
,
Unicode
, or
Auto
. If you select
Auto
, the phone
automatically changes the encoding type from
GSM-alphabet to Unicode when you enter a Unicode
character.
Messages
114
When you select
Unicode
, the maximum number of
characters in a message is reduced by
approximately half. If your recipient’s phone does
not support Unicode characters, he/she may not be
able to read your message correctly. For details
about Unicode characters, see page 248.
Validity period
: allows you to set the length of
time your text messages are stored in the message
centre while attempts are made to deliver them.
Message type
: allows you to set the default
message type to
Text
,
Fax
,
Voice
,
ERMES
,
X400
,
or
Email
. The network can convert the messages
into the selected format.
Service centre
: allows you to store or change the
number of your message centre, which is required
when sending messages. You must obtain this
number from your service provider.
Block number
(Menu 5.1.6)
Using this menu, you can set up a message filter
by entering phone numbers so that the phone
rejects messages from those numbers.
1. Enter the phone number.
2. If you want to add more phone numbers, press
the Down key.
3. If necessary, repeat step 1 and 2 to add more
phone numbers.
You can enter up to 10 numbers.
4. Press the
Options
soft key or the key.
Messages
115
5. Select the
Save
option and press the
Select
soft key.
On the Filtering list screen, press the
Options
soft
key to access the following options:
Save
: allows you to save the number.
Phonebook
: allows you to search for a number in
Phonebook.
Delete
: deletes the currently selected phone
number.
Delete all
: deletes all of the numbers stored in the
Block number list.
Delete all
(Menu 5.1.7)
This menu allows you to delete all of the text
messages in each message box separately. You
can also delete all of your messages at one time.
2. Press the
Delete
soft key to delete the marked
messages.
3. When a confirmation message displays, press
the
Yes
soft key to confirm.
1.
To Press the
select a message
box to clear Up or Down key. To delete
all of your messages,
select
All
.
place or remove a
check mark key.
Messages
116
Multimedia messages
(Menu 5.2)
Multimedia Message Service (MMS) is a service
providing delivery of personal multimedia messages
from phone to phone or from phone to e-mail. In
addition to the familiar text content, multimedia
messages can contain images, video clips, audio
clips, and combinations of these things. Images
could include downloads and photos you have
taken, while audio clips could be downloads or could
be recorded sounds or voice memos. Using MMS,
your phone can send and receive these multimedia
messages.
This function is available only if it is supported by
your service provider. Only phones that offer
multimedia messaging features can receive and
display multimedia messages.
Note
: When you buy media content from the Internet,
this content is delivered to you in MMS
messages. You can retrieve the messages from
the server and then save the items in your
phone’s memory. You cannot forward these
messages to other people or add the saved
items to an MMS message.
Create
(Menu 5.2.1)
In this menu, you can create a new MMS message.
Creating and sending a multimedia message
1. When
Subject
highlights, press the key.
2. Enter the subject of your message and press the
OK
soft key.
For further details about how to enter
characters, see page 36.
Messages
117
3. Press the Down key to move to the Picture &
Video field, and press the key.
Add a photo or video to the message by using
the following options:
•
Pictures
: allows you to add a photo or
downloaded image. You can take a new photo,
or select one of the photos you have taken, or
select images downloaded from the Wireless
Web. For further details about the Camera
feature, see page 182.
•
Videos
: allows you to add a video clip. You
can record a new video clip or select one of the
video clips you have recorded or downloaded
from the Wireless Web. For further details
about the Camera feature, see page 182.
Note
: When you add a video clip to a message,
you are unable to add a sound clip to the
message.
After adding an image, the display returns to the
message screen.
4. Press the Down key to move to the Sound field
and press the key.
Add a sound clip by using the following options:
•
Record
: allows you to record a new voice
memo. For details, see page 88.
•
Voices
: allows you to select one of the voice
memos you have recorded.
•
My sounds
: allows you to select a sound
downloaded from the Wireless Web.
•
Music
: allows you to select one of the MP3
files stored in your phone.
After adding a sound, the display returns to the
message screen.
Messages
118
5. Press the Down key to move to the Message
field and press the key.
6. Enter the message text.
You can press the
Options
soft key to access
the following options:
•
Done
: allows you to save your message text
and returns to the message screen.
•
Template
: allows you to retrieve a message
template from the
Text templates
folder
(
Menu 5.6
).
•
Language select
: allows you to change the
language to be used in T9 input mode. Select
the language to be used.
•
Save message
: allows you to save the
message in the
Draft
,
My folder
, or
Templates
folder.
7. When you have finished writing the message
text, press the key.
8. If you want to change the any of added items,
press the Up or Down key to highlight a field and
press the
Options
soft key.
Note
: Available options are different, depending
on the whether the field you select on the
message screen is the Subject, Picture &
Video, Sound, or Message field.
The following options are available:
•
Edit
: allows you to edit the subject of your
message or message text.
•
Add media
/
sound
: allows you to add more
photos, videos, or sounds to the message.
•
Preview
: shows the message you created.
•
Send
: allows you to send the message.
Messages
119
•
Add page
: allows you to add more pages. You
can move to each page by pressing the Left or
Right key on the message screen.
•
Page timing
: allows you to set how long a
page displays on the message presentation
screen. After a specified time, the display
automatically scrolls to the next page.
•
Text style
: allows you to format the style of
the text.
For the
Text color
attribute,
Black
,
Blue
,
Green
,
Red
, or
Yellow
is available.
For the
Text size
attribute,
Medium
,
Large
,
or
Small
sizes are available.
For the
Bold
,
Italic
, or
Underline
attributes,
place a check mark by pressing the key to
use a particular text style.
•
Clear subject
/
Picture & Video
/
sound
/
message
: clears the subject of your message,
added images, sounds, or message text.
•
Delete page
: allows you to delete the added
page.
•
Save message
: allows you to save the
message in the
Draft
,
My folder
, or
Templates
folder.
9. When you have finished creating the message,
choose the
Send
option and press the
Select
soft key.
10.Enter a destination number or e-mail address.
While entering a destination phone number or e-
mail address, you can access the following
options by pressing the
Options
soft key:
•
Send
: allows you to send the message.
Messages
120
•
Phonebook
: allows you to retrieve a number
from Phonebook.
•
Change recipient
: allows you to change the
recipient’s type to To, Bcc, or Cc.
•
Save message
: allows you to save the
message in the
Draft
,
My folder
, or
Templates
folder.
•
Back
: returns to the message screen.
11.If you want to send the message to more than
one person, press the Down key and fill in
another destination field.
Note
: You will be billed for each phone number or
e-mail address.
12.If necessary, repeat steps 10 and 11. You can
enter up to 20 numbers.
13.Choose the
Send
option and press the
Select
soft key.
Your phone sends the message.
Inbox
(Menu 5.2.2)
When a new multimedia message comes in, the
display shows the MMS icon ( ). A list of
multimedia messages you have received displays
with the senders' phone numbers, if they are
available in Phonebook, or subjects. The icons on the
left tell you the status of the messages:
• : MMS notifications that you have read.
• : MMS notifications that you have not read.
• : Messages that you have read.
• : Messages that you have not read.
Messages
121
Note
: When the
Home reception
or
Roaming
reception
option is set to
Manual
, text
notifications are automatically saved to the
Inbox. If the option is set to
Automatic
,
messages are automatically saved to the Inbox
without notifications. By default, these options
are set to
Automatic
.
Retrieving a message
1. Scroll to a notification using the Up or Down key
and press the key.
2. Press the Up or Down key to scroll through the
message information.
3. Press the
Options
soft key or the key to
access the following options:
•
View
: opens the notification message.
•
Retrieve
: retrieves the message from the
MMS server.
•
Delete
: deletes the message.
•
Delete all
: deletes all notification messages.
4. To read the message, press the
Select
soft key
when
Retrieve
is highlighted.
Your phone retrieves the message contents from
the server and displays it.
5. Press the Up or Down key to scroll through the
message.
6. When you are finished, press the key.
Messages
122
Viewing a message
1. Select a message on the list and press the
key.
The message displays and scrolls to the next
page, if it has one, after a specified time.
2. Press the Up or Down key to scroll through the
message.
If the message has more than one page, you
can scroll through the pages by using the Left
and Right keys.
Using message options
While viewing a message, you can access Message
options by pressing the
Options
soft key:
Replay
: allows you to replay the message.
Reply
: allows you to send a reply to the sender by
sending a multimedia message.
Reply all
: allows you to send a reply to the sender,
and entries in the To and Cc fields by sending a
multimedia message.
Forward
: allows you to forward the message to
another person. When the message contains media
contents you have bought on the Internet,
forwarding is not available.
Call back
: allows you to call the sender.
Delete
: allows you to delete the message.
Cut media
: allows you to save media contents,
such as pictures, videos, sounds, Vcards, and
Vcalendar entries, from the message into your
phone.
Messages
123
Cut
address
: allows you to extract the sender’s
number or e-mail address and URL, other e-mail
addresses, or phone numbers from the message
text.
Move to my folder
: allows you to move the
message to the
My folder
box (
Menu 5.2.5
).
Save as template
: allows you to save a copy of the
message in the
Template
box (
Menu 5.2.6
).
Properties
: shows you the properties of the
message, such as the subject, the time and date the
message was retrieved, sender’s and recipient’s e-
mail address or phone number, message size, the
number of attached files, its priority, and the
message class.
On the message list, press the
Options
soft key to
access the following options:
View
: shows you the message.
Reply
: allows you to send a reply to the sender by
sending a text or multimedia message.
Reply all
: allows you to send a reply to the sender,
and to the Bcc and Cc addresses.
Forward
: allows you to forward the message to
another person. When the message contains media
contents you have bought on the Internet,
forwarding is not available.
Call back
: allows you to call the sender.
Delete
: allows you to delete the message.
Delete all
: allows you to delete all of the messages
stored in the Inbox.
Move to my folder
: allows you to move the
message to the
My folder
box (
Menu 5.2.5
).
Messages
124
Save as template
: allows you to save a copy of
the message in the
Template
folder (
Menu 5.2.6
).
Properties
: shows you the properties of the
message, such as the subject, the time and date
the message was retrieved, sender’s and recipient’s
e-mail address or phone number, message size, the
number of attached files, its priority, and the
message class.
Outbox
(Menu 5.2.3)
When you access this menu, the list of multimedia
messages that you have sent or saved displays. The
icons on the left tell you the status of each
message.
• : Messages currently being sent
• : Messages sent
• : Messages your phone couldn’t send or
stopped sending
To view a message:
1. Select a message on the list and press the
key.
The message displays and scrolls to the next
page, if it has one, after a specified time.
2. Press the Up or Down key to scroll through the
message.
If the message has more than one page, you
can scroll through the pages by pressing the Left
or Right key.
Messages
125
Using the message options
While viewing a message, you can access the
following options by pressing the
Options
soft key:
Replay
: allows you to replay the message.
Delete
: allows you to delete the message.
Send
: allows you to send/resend the message.
Edit
: allows you to change the message contents,
subject, image, sound, or text.
Cut
address
: allows you to extract the destination
numbers or e-mail addresses and URL, e-mail
addresses, or phone numbers from the message
text.
Move to my folder
: allows you to move the
message to the
My folder
box (
Menu 5.2.5
).
Set as templates
: allows you to save the copy of
the message in the
Template
folder (
Menu 5.2.6
).
Properties
: shows you the properties of the
message, such as the status, subject, sender’s e-
mail address or phone number, message size,
transaction ID, MMS version, and the time and date
the message was sent.
On the message list, press the
Options
soft key to
access the following options:
View
: shows you the message.
Send
: allows you to send/resend the message.
Edit
: allows you to change the message contents,
subject, image, sound, or text.
Delete
: allows you to delete the message.
Delete all
: allows you to delete all of the messages
stored in the Outbox.
Messages
126
Properties
: shows you the properties of the
message, such as the subject, the time and date
the message was sent, sender’s and recipient’s e-
mail address or phone number, message size, the
number of attached files, its priority, and the
message class.
Draft
(Menu 5.2.4)
After creating a multimedia message, you can store
it in this message box to be sent at a later time.
For further details about viewing a message, see
“Outbox” on page 124.
My folder
(Menu 5.2.5)
In this menu, you can view the messages you have
moved to or saved in this message box.
1. Scroll to a message and press the key.
The message displays and scrolls to the next
page, if it has one, after a specified time.
2. Press the Up or Down key to scroll through the
message.
If the message has more than one page, you
can scroll through the pages by pressing the Left
or Right key.
Using the message options
While viewing a message, you can access the
following options by pressing the
Options
soft key:
Replay
: allows you to replay the message.
Send
: allows you to send/resend the message.
Messages
127
Edit
: allows you to change the message contents,
subject, image, sound, or text.
Delete
: allows you to delete the message.
Cut media
: allows you to save media contents,
such as pictures, videos, Vcards, and Vcalendar
entries from the message into your phone.
Cut
address
: allows you to extract e-mail
addresses and URL, or phone numbers from the
message text.
Properties
: shows you the properties of the
message, such as the date the message was saved,
recipient’s e-mail addresses or phone numbers,
message size, its priority, and message class.
On the message list, press the
Options
soft key to
access the following options:
View
: shows you the message.
Send
: allows you to send/resend the message.
Edit
: allows you to change the message contents,
subject, image, sound, or text.
Delete
: allows you to delete the message.
Delete all
: allows you to delete all of the messages
stored in the My folder box.
Properties
: shows you the properties of the
message, such as the date the message was saved,
recipient’s e-mail addresses or phone numbers,
message size, its priority, and message class.
Messages
128
Template
(Menu 5.2.6)
You phone has 11 preset messages that you can
use when writing a new message. You are unable to
delete the preset messages.
You can also save up to xx of your own template
messages.
1. Scroll through the template list using the Up and
Down keys.
2. When the message template you want
highlights, press the key.
3. Press the Up or Down key to scroll through the
message.
If the message has more than one page, you
can scroll through the pages by using the Left
and Right keys.
4. Press the
Options
soft key to access the
following options:
•
Replay
: allows you to replay the message.
•
Send
: allows you to send a message using the
template. For further details about how to
send a message, see page 116.
•
Edit
: allows you to change the message
contents, subject, image, sound, or text.
•
Delete
: allows you to delete the message
template. This option is not available for
preset message templates.
5. Press the
Back
soft key to exit the current
screen.
Messages
129
On the Template list, press the
Options
soft key to
access the following options:
View
: shows the message template.
Send
: allows you to send a message using the
template. For further details about how to send a
message, see page 116.
Edit
: allows you to change the message contents,
subject, image, sound, or text.
New
: allows you to create a new message
template.
Delete
: allows you to delete the message template.
You are unable to delete the preset message
templates.
Delete all
: allows you to delete all of the message
templates except for the preset message templates
stored in the Template box.
Settings
(Menu 5.2.7)
You can change the default settings for sending or
receiving multimedia messages. You can also
configure various network settings that are required
when you send or receive multimedia messages.
Send settings
You can set the default settings for sending a
multimedia message.
The following options are available:
Priority
: you can select the priority level of your
messages.
Validity period
: you can select the length of time
your messages are stored in the message centre
after they are sent.
Messages
130
Delivery after
: you can select the time delay
before messages are sent.
Address hiding
: when this option is enabled, your
phone number is not displayed on the recipient’s
phone.
Delivery report
: when this option is enabled, the
network informs you whether or not your message
has been delivered.
Read reply
: when this option is enabled, your
phone sends a request for a reply along with your
message to the recipient.
Receive settings
You can set the default settings for receiving a
multimedia message.
The following options are available:
Home reception
/
Roaming reception
: you can
set whether or not your phone retrieves new
incoming messages from the MMS server without
notifications when you are in your home service
area or when you are roaming in another network.
Automatic: the phone automatically retrieves new
messages from the server.
Reject: the phone rejects all incoming messages.
Manual: the phone receives notifications and you
need to manually download new messages by using
the
Retrieve
option.
Anonymous reject
: when this option is enabled,
the phone rejects messages from anonymous
senders.
Messages
131
Adverts reject
: when this options is enabled, the
phone rejects advertisement messages.
Report allowed
: when this option is enabled, the
sender of an incoming message receives a delivery
report from the network.
MMS profiles
You can configure various network settings that are
required when you send or receive multimedia
messages.
Notes
:
• The last profile you accessed is automatically
activated for sending subsequent messages.
• If you change the MMS settings without first
checking with your service provider, the MMS feature
may not work properly.
The following options are available:
Current profile
: allows you to select one of the
profiles.
Profile setting
: for each profile, the following
options are available:
Profile name: enter the name that you wish to
assign to the MMS server.
Server URL: enter the address of your MMS server.
Bearer: select a bearer to be used for each type of
network address accessed:
GSM only
or
GPRS
only
.
GPRS settings: the following options are available:
- Proxy ip: enter the gateway address required
to connect to the GPRS network.
- Proxy port: enter the port number required to
connect to the GPRS network.
Messages
132
- APN: enter the access point name used for the
address of the GPRS network.
- Login ID: enter the user ID required to connect
to the GPRS network.
- Password: enter the password required to
connect to the GPRS network.
- Proxy use: when this option is enabled, you can
connect to the GPRS network using the proxy
server.
GSM settings: the following options are available:
- Proxy ip: enter the gateway address required
to connect to the GSM network.
- Proxy port: enter the port number required to
connect to the GSM network.
- Dial number: enter the PPP server phone
number.
- Login ID: enter the user ID required to connect
to the GSM network.
- Password: enter the password required to
connect to the GSM network.
- Data call type: select a data call type:
ISDN
or
Analog
.
- Proxy use: when this option is enabled, you can
connect to the GSM network using the proxy
server.
For further details, contact your service provider.
Messages
133
Delete all
(Menu 5.2.8)
This menu allows you to delete all of the multimedia
messages in each message box separately. You can
also delete all of your messages at one time.
2. Press the
Delete
soft key to delete the marked
messages.
3. When a confirmation message displays, press
the
Yes
soft key to confirm.
Email
(Menu 5.3)
You can send or receive e-mail messages directly
using your phone. Using the Email feature, you can
receive or send sounds and pictures, as well as
Phonebook entries or calendar memos.
To use this feature, you need to subscribe to an e-
mail message service and set up your email profile
and account in the
Email account
and
Email
profile
menus. See page 146 and page 148.
Create
(Menu 5.3.1)
To write and send an e-mail message:
1. When
Subject
highlights, press the key.
1.
To Press the
select a message
box to clear Up or Down key. To
delete all of your
messages, select
All
.
place or remove a
check mark key.
Messages
134
2. Enter the subject of your e-mail.
For further details about entering characters,
see page 36.
On the Subject screen, press the
Options
soft
key to access the following options:
•
Save
: allows you to save the subject of your
e-mail and returns you to the message screen.
•
Language select
: allows you to change the
language to be used in T9 input mode. Select
the language to be used.
•
Back
: returns you to the message screen.
3. Press the key.
4. Press the Down key to move to the Message
field and press the key.
5. Enter the e-mail text.
On the Message screen, press the
Options
soft
key to access the following options:
•
Save
: allows you to save the message text
and returns you to the message screen.
•
Text template
: allows you to retrieve a
message template from the
Text template
folder (
Menu 5.6
).
•
Language select
: allows you to change the
language to be used in T9 input mode. Select
the language to be used.
•
Back
: returns you to the message screen.
6. Press the key.
Messages
135
7. Press the Down key to move to the File attach
field and press the key.
You can attach files of various types from the
Images, Videos, Music, and Sounds folders.
After attaching a file, the display returns to the
message screen.
8. If you want to change added items, press the Up
or Down key to highlight a field or an attached
file and press the
Options
soft key.
Note
: Available options are different, depending
on the whether the field you select on the
message screen is the Subject, Message, or
File attach field.
The following options are available:
•
Edit
: allows you to edit the subject of your e-
mail or message text.
•
Add
: allows you to add subjects, e-mail text,
and media files.
•
View
: shows the attached file.
•
Send
: allows you to send the e-mail.
•
Delete
: allows you to delete the attached file.
•
Save Email
: saves the e-mail in the
Draft
(
Menu 5.3.4
) or
My folder
box (
Menu
5.3.5
).
•
Clear subject
/
message
: clears the subject of
your e-mail or message text.
•
Remove all attachments
: deletes all
attached files.
9. When you have finished creating the e-mail,
choose the
Send
option and press the
Select
soft key.
Messages
136
10.Enter an e-mail address.
You can access the following options by pressing
the
Options
soft key while entering an address:
•
Send
: allows you to send the e-mail you have
created.
•
Phonebook
: allows you to retrieve an e-mail
address from Phonebook.
•
Change recipient
: allows you to change the
recipient’s type to To, Bcc, or Cc.
•
Save Email
: allows you to save the e-mail in
the
Draft
(
Menu 5.3.4
) or the
My folder
box
(
Menu 5.3.5
).
•
Back
: returns you to the New screen.
11.If you want to send the message to more than
one person, press the Down key and fill in
another destination field.
12.If necessary, repeat step 11 to add more e-mail
addresses. You can enter up to 15 e-mail
addresses.
13.Select the
Send
option and press the
Select
soft
key.
Your phone sends the e-mail.
After sending the e-mail, it is automatically
saved in the Outbox.
Messages
137
Inbox
(Menu 5.3.2)
This menu allows you to check the e-mail server for
new e-mails and review the e-mail messages you
have receiveds.
The icons on the left you the status of the
messages:
• : E-mail that has been retrieved from the e-
mail server.
• : E-mail with attachments that has been
retrieved from the e-mail server.
• : E-mail that has not been retrieved from the
e-mail server.
• : E-mail with attachments that has not been
retrieved from the e-mail server.
Notes
:
• When you have read the e-mail, the icon changes to
an open envelope.
• A
!
icon next to a message means that the message
is of high priority.
Viewing an e-mail header
1. Press the
Select
soft key when
Check new
mail
highlights to retrieve e-mail headers from
the server.
Note
: You can set the phone to retrieve headers
only or whole
e-mail
s including headers
and bodies in the
Retrieve
option.
The list of e-mail messages you have received
displays.
2. Press the Up or Down key to scroll to an e-mail
message.
3. Press the key to read the header.
Messages
138
While viewing an e-mail header, press the
Options
soft key to access the following options:
Retrieve
: allows you to retrieve one or all e-mail
messages from the e-mail server.
Reply
: allows you to send a reply to the sender or
all of the recipients including the sender of the e-
mail.
Delete
: allows you to delete the header. You can
select to either delete it from your phone or from
both the phone and the e-mail server.
Cut address
: allows you to extract e-mail
addresses, URLs, and phone numbers, so that you
can save them in Phonebook or go to the URL.
Block address
: allows you to add the sender’s e-
mail address to the
Block address
folder (
Menu
5.3.7
) so that you can reject messages from that e-
mail address.
On the message list, press the
Options
soft key to
access the following options:
View
: opens the header.
Retrieve
: allows you to retrieve one or all e-mail
messages from the e-mail server.
Reply
: allows you to send a reply to the sender or
all of the recipients including the sender of the e-
mail.
Delete
: allows you to delete the currently selected
header. You can select to either delete it from your
phone or from both the phone and the e-mail
server.
Messages
139
Delete all
: allows you to delete all of the e-mail
messages, but only but from your phone.
Sort
: allows you to sort the e-mail messages by
size, subject, data, or sender’s e-mail addresses.
Viewing an entire e-mail
1. Press the
Select
soft key when
Check new mail
highlights to retrieve e-mail headers from the
server.
Note
: You can set the phone to retrieve headers
only or whole e-mails including headers and
bodies in the
Retrieve
option.
The list of e-mail messages you have received
displays.
2. Press the Up or Down key to scroll to an e-mail
message.
3. Press the key to read the message.
4. Press the Up or Down key to scroll through the
message.
If the e-mail has more than one page, press the
Volume keys to scroll to a page one by one. You
can move to the first or last page in the e-mail
by pressing the key or the key
respectively.
5. When you select an attached file, you can view
or play the attached file in the e-mail.
Messages
140
Using the message options
Note
: While you are retrieving e-mails from the e-
mail server, some options are not available.
While viewing an e-mail message, press the
Options
soft key to access the following options:
Open file
: opens the attached file.
Save file
: allows you to save the attached file in
your phone’s memory.
Reply
: allows you to send a reply to the sender or
to all recipients including the sender of the e-mail.
Forward
: allows you to send/resend the e-mail.
Delete
: allows you to delete the e-mail. You can
select to either delete it from your phone or from
both the phone and the e-mail server.
Cut address
: allows you to extract e-mail
addresses, URLs, and phone numbers, so that you
can save them in Phonebook or go to the URL.
Block address
: allows you to add the sender’s e-
mail address to the
Block address
folder (
Menu
5.3.7
) so that you can reject messages from that e-
mail address.
Move to my folder
: allows you to move the e-mail
to the
My folder
box (
Menu 5.3.5
).
Properties
: shows you the properties of the e-
mail, such as the subject, the time and date it was
retrieved, sender’s and recipient’s e-mail addresses,
message size, the number of attached files, its
priority, and server address.
Messages
141
On the message list, press the
Options
soft key to
access the following options:
View
: opens the e-mail messages.
Reply
: allows you to send a reply to the sender or
to all recipients including the sender of the e-mail.
Forward
: allows you to send/resend the e-mail.
Delete
: allows you to delete the e-mail. You can
select to either delete it from your phone or from
both the phone and the e-mail server.
Delete all
: allows you to delete all of the e-mail
messages, but only from your phone.
Outbox
(Menu 5.3.3)
When you select this menu, the list of the e-mail
messages you have sent or tried to send displays,
along with the subject and the recipient’s e-mail
address. The following icons on the left tell you the
messages’ status:
• : E-mail you haven’t read.
• : E-mail with attachments you haven’t read.
• : E-mail your phone couldn’t send.
• : E-mail your phone successfully sent.
indicates that the e-mail is being sent.
Notes
:
• When you have read the e-mail, the icon changes to
an open envelope.
• A
!
icon next to a message means that the message
is of high priority.
Messages
142
To view an e-mail:
1. Press the Up or Down key to scroll to an e-mail
message.
2. Press the key to read the message.
3. Press the Up or Down key to scroll through the
message.
If the e-mail has more than one page, press the
Volume keys to scroll through pages one by one.
You can move to the first or last page in the e-
mail by pressing the key or the key
respectively.
Using the message options
Note
: While the phone is sending e-mails, some
options are not available.
While reading a message press the
Options
soft
key to access the following options:
Open file
: opens the attached file. This option is
only available when the e-mail has attachments.
Save file
: allows you to save the attached file in
your phone’s memory. This option is only available
when the e-mail has attachments.
Cancel
: stops sending the e-mail. This option is
only available when you select an e-mail currently
being sent.
Send
: allows you to send/resend the e-mail.
Edit
: allows you to edit the e-mail.
Delete
: allows you to delete the e-mail.
Move to my folder
: allows you to move the e-mail
to the
My folder
box (
Menu 5.3.5
).
Messages
143
Properties
: shows you the properties of the e-
mail, such as the subject, the time and date it was
sent, sender’s and recipient’s e-mail addresses,
message size, the number of attached files, its
priority, and server address.
On the message list, press the
Options
soft key to
access the following options:
View
: opens the e-mail.
Send
: allows you to send/resend the e-mail.
Cancel
: stops sending the e-mail. This option is
only available when you select an e-mail currently
being sent.
Edit
: allows you to edit the e-mail.
Delete
: allows you to delete the e-mail.
Delete all
: allows you to delete all e-mails stored
in the Outbox.
Sort
: allows you to change the sort order by size,
subject, date, or sender’s e-mail addresses.
Properties
: shows you the properties of the e-
mail, such as the subject, the time and date it was
sent, sender’s and recipient’s e-mail addresses,
message size, the number of attached files, its
priority, and server address.
Draft
(Menu 5.3.4)
After creating an e-mail, you can store it in this
message box to be sent at a later time.
When you send an e-mail stored in this message
box, the e-mail is deleted from this message box.
For further details about viewing a message, see
“Outbox” on page 141.
Messages
144
My folder
(Menu 5.3.5)
You can view the messages you have moved from
the Inbox, Outbox, or Draft to this message box.
For further details about viewing a message, see
“Outbox” on page 141.
Settings
(Menu 5.3.6)
You can change the default setting options for using
the Email feature.
Send settings
You can change the default settings for sending an
e-mail. The following options are available:
Send copy to self
: when this option is checked,
your phone sends a copy of the outgoing e-mail to
the e-mail address specified in your account as
yours.
Delivery confirm
: when this option is checked, the
network informs you whether or not your message
has been delivered.
Read confirm
: when this option is checked, your
phone sends a request for a reply along with your
message to the recipient.
Priority
: you can select the priority level of your
messages.
Include signature
: when this option is checked,
you can attach your name, phone number, a simple
memo, or tag line as a signature to your e-mail
messages.
Edit name
: you can change the name in your
signature.
Messages
145
Edit telephone number
: you can change the
phone number in your signature.
Edit note
: you can save your signature.
Receiving settings
You can change the default settings for receiving an
e-mail. The following options are available:
Check interval
: you can select how often the
phone checks the server for incoming messages.
If this option is set to
Not used
, you need to
manually check the server by selecting
Check new
mail
in the Inbox.
Read reply
: if this option is set to
Announce
, the
phone asks you to send a read-reply request along
with your message to the sender.
If this option is set to
No
, the phone ignores read-
reply requests.
If this option is set to
Yes to all
, the phone sends a
read-reply request without asking to you.
Retrieve option
: you can select whether or not the
phone retrieves headers only or whole e-mails
including the headers and bodies.
Delete option
: when this option is set to
Immediately
, the phone deletes the e-mail from
both the phone and the e-mail server.
When this option is set to
During next
connection
, the phone deletes e-mails from both
the phone and e-mail server the next time you
connect to the e-mail server.
Reject if over
: you can set the maximum message
size for incoming messages. Your phone will reject
messages which are over the specified size.
Messages
146
Email account
Note
: When an e-mail is being sent or retrieved from
the e-mail server, you are unable to change the
e-mail account settings.
The following options are available:
Current account
: you can check your current
account and select one of the accounts.
Account setting
: you can configure up to 5 e-mail
accounts using different e-mail servers. The
following options are available for each account:
Account name: enter a name for the selected
account.
In use: select this option to use the selected
account. You need to check this option to display
this account in the Inbox.
User name: enter the name to be displayed in your
outgoing messages as the sender’s name.
Email address: enter your e-mail address.
SMTP server: enter the IP address or domain name
of the server to be used for receiving messages.
Your e-mail service provider can give you this
information.
SMTP port: enter the SMTP port number.
Protocol type: specify an e-mail protocol type for
the incoming server, either
POP3
or
IMAP4
.
Contact your e-mail service provider for more
information.
The remaining options depend on the protocol type
setting.
Messages
147
When the protocol type is set to
POP3
:
POP3 server: enter the IP address or domain name
of the server to be used for receiving messages.
Your e-mail service provider can give you this
information.
POP3 port: enter the POP3 port number.
APOP login: when this option is checked, you can
connect to the server by using the APOP login
scheme.
Security: set whether or not you protect your data
by using SSL (Secure Socket Layer).
User ID: enter your e-mail ID.
Password: enter your e-mail password.
When the protocol type is set to
IMAP4
:
IMAP4 server: enter the IP address or domain name
of the server to be used for sending messages.
IMAP4 port: enter the IMAP4 port number.
Security: set whether or not you protect your data
by using SSL (Secure Socket Layer).
Retrieve headers: set the number of headers you
will retrieve from the server.
Retrieve attachment: when this option is checked,
you can receive attachments with e-mails from the
server.
User ID: enter your e-mail ID.
Password: enter your e-mail password.
Messages
148
Email profile
You can configure various network settings that are
required when you send or receive e-mails.
Note
: When an e-mail is being sent or retrieved from
the e-mail server, you are unable to change the
e-mail profile settings.
The following options are available:
Current profile
: allows you to select one of the
profiles.
Profile setting
: you can configure up to 5 e-mail
profiles. For each profile, the following options are
available:
Profile: enter the name that you wish to assign to
the e-mail server.
APN: enter the access point name used for the
address of the GPRS network.
Login ID: enter the User ID required to connect to
the GPRS network.
Password: enter the password required to connect
to the GPRS network.
DNS1: enter the primary address required to
connect to the GPRS network.
DNS2: enter the secondary address required to
connect to the GPRS network.
Messages
149
Block address
(Menu 5.3.7)
Using this menu, you can set up a message filter by
entering e-mail addresses so that the phone rejects
message from those e-mail addresses.
1. Enter an e-mail address.
2. If you want to add more e-mail addresses, press
the Down key.
3. If necessary, repeat step 1 and 2 to add more e-
mail addresses.
You can enter up to 10 e-mail addresses.
4. Press the key.
Alternatively, press the
Options
soft key and
select
Save
.
On the Filtering list screen, press the
Options
soft
key to access the following options:
Save
: allows you to save the e-mail address.
Phonebook
: allows you to search for an e-mail
address.
Delete
: deletes the currently selected e-mail
address.
Delete all
: deletes all of the e-mail addresses
stored in the filtering list.
Back
: exits the current screen.
Messages
150
Delete all
(Menu 5.3.8)
This menu allows you to delete all of the e-mail
messages in each message box. You can also delete
all of your messages at one time.
When a confirmation message displays, press the
Yes
soft key to confirm.
Note
: When an
e-mail
is being sent or retrieved from
the e-mail server, you are temporarily unable
to select the Inbox or Outbox.
Push messages
(Menu 5.4)
In this menu, you can receive and access messages
from the WAP server.
The following options are available:
Inbox
: allows you to read the push messages you
have received.
Setting
: allows you to set whether or not your
phone receives push messages. The following
options are available:
Always: the phone receives push messages.
To Press the
select a message
box to clear Up or Down key. To delete
all of your messages, select
All
.
place or remove a
check mark key.
delete the marked
messages
Delete
soft key.
Messages
151
Never: the phone rejects push messages.
Optional: the phone receives push messages from
the service centre set in this option. You can change
the service centre number to be used when you
receive new incoming push messages.
Delete all
: allows you to delete all of the push
messages.
Voice mail
(Menu 5.5)
This menu allows you to access your voice mailbox,
if your network supports this service.
The following options are available:
Connect to voice mail
: before using the Voice Mail
feature, you must enter the voice server number
obtained from your service provider. You can then
select this menu and press the
Select
soft key to
listen to your messages.
You can quickly connect to the voice server by
pressing and holding the
1
key in Idle mode.
Voice server number
: this menu allows you to
change the voice mail server name or number, if
necessary.
Note
: Voice mail is a network feature. Please contact
your service provider for further details.
Messages
152
Text template
(Menu 5.6)
Using this menu, you can preset a maximum of 10
messages that you use most frequently.
1. Select an empty location or the message
template you want.
2. Press the key.
3. Enter the message you want and press the
key.
Alternatively, press the
Options
soft key, and
select
Save
.
On the message template list, press the
Options
soft key to access the following options:
Edit
: allows you to write a new message template
or edit an existing message template.
Send message
: allows you to retrieve the
message template for sending an SMS or MMS
message. For further details about sending a
message, see page 107 or page 116 respectively
Delete
: allows you to delete the message template.
Broadcast messages
(Menu 5.7)
This network service allows you to receive text
messages on various topics, such as the weather or
traffic. Cell Broadcast (CB) messages display as
soon as they are received, provided that:
• the phone is in Idle mode.
•the
Receive
option is set to
On
.
• the message channel is currently active on the
channel list.
Messages
153
The following options are available:
Read
: lets you view the received messages.
The
Temporary
box displays messages from the
network, but loses its contents as soon as the
phone is switched off. Scroll through the message
by using the Up and Down keys.
You can save a CB message in the
Archive
box for
later retrieval. When a text notification appears,
press the
Options
soft key and select
Save
.
Receive
: allows you to enable or disable the
reception of broadcast messages.
Channel
: allows you to indicate the channels from
which you wish to receive broadcast messages. The
following options are available:
All channels: allows you to enable or disable all
channels.
Respective channels: shows you to channels stored
on your SIM card. You can also save, delete, edit,
and add channels. This option is only available
when the All channels option is enabled.
Language
: allows you to select the preferred
languages in which to display the cell broadcast
messages.
Please contact your service provider for further
details.
Messages
154
Memory status
(Menu 5.8)
In this menu, you can view the memory status for
text, multimedia, e-mail, or push messages.
To access the following options, press the Left or
Right key:
SMS
: You can view the number of messages you
have stored and the total number of messages you
can store in the phone’s memory and on the SIM
card individually. You can also view the number of
messages currently stored in each message box.
Press the up or Down key to scroll through the
screen.
MMS
: You can check the total amount of memory
for MMS messages and the amount of memory
currently occupied by each message box. Press the
Up or Down key to scroll through the screen.
Email
: You can check the total amount of memory
for e-mail messages and the amount of memory
currently occupied by each message box. Press the
Up or Down key to scroll through the screen.
Push message
: You can view the number of
messages you have stored and the total number of
messages you can store.
155
Funbox
The
Funbox
menu stores photos you have taken,
videos you have recorded, and voice memos you
have recorded. You can also view images, videos,
music files, and sounds downloaded from the
Wireless Web or received in messages.
Images
In this menu, you can view the photos you have
taken and images downloaded from a web server or
received in messages.
Photos
You can view the photos you have taken using your
phone.
Scroll to a photo and press the key to view the
photo.
Using photo options
Press the
Options
soft key to access the following
options:
Note
: Available options vary depending on whether
you are looking at the photo list or viewing a
photo.
View
: shows the photo.
List
: shows the photo list.
Send
: allows you to access the following sending
options:
via MMS: allows you to send the photo to another
person as part of a multimedia message. For further
details, see
page 116
.
Funbox
156
via Email: allows you to send the photo to another
person as part of an e-mail. For further details, see
page 133
.
via Bluetooth: allows you to send the photo to
another person via the Bluetooth feature. For
further details, see page 216.
via infrared: allows you to send the photo to
another person via the infrared port. For further
details, see page 217.
Move to my photos
: allows you to move the photo
to the
My photos
folder. See page 157.
Set as
: allows you to set the photo as your
wallpaper or as a caller ID image for an entry in
Phonebook.
Edit
: allows you to access the following options:
Emoticons: allows you to add an emoticon to the
photo. After selecting an emoticon, you can move
the emoticon by pressing the Navigation keys or the
2
,
4
,
6
, and
8
keys.
Frames: allows you to select a decorative frame.
Slide show
: allows you to set all photos to
automatically display as a slide show. You can select
the time interval between photos.
Rename
: allows you to change the photo name.
Delete
: allows you to delete the photo.
Delete all
: allows you to delete all of the photos.
Protection
: protects the photo from being deleted.
Properties
: shows you the properties of the photo,
such as the file name, the time and date it was
saved, file format, resolution, size, quality, and
protection status.
Funbox
157
My photos
You can view the photos you have moved from the
Photos folder to this image box.
For further details about viewing an image or using
the image options, see “Photos” on page 155.
Downloaded images
When you access this menu, a list of the images
you have downloaded from the Wireless Web or
received in messages.
The icons on the images list tell you the status of
the files:
• : files that you can forward to other people.
• : files that you are unable to forward to other
people.
For further details about viewing an image or using
the image options, see “Photos” on page 155.
Videos
In this menu, you can view the videos you have
recorded or downloaded from the Wireless Web or
received in messages.
Video clips
You can view the videos you have recorded using
your phone.
To play a video clip, scroll to the video clip you want
and press the key.
Funbox
158
You can use the following options while playing a
file:
• Scroll to a button and press the key. The
following buttons are available:
• Press the Volume keys to adjust the volume.
Using video clip options
Press the
Options
soft key to access the following
options:
Note
: Available options vary depending on whether
you are looking at the video list or viewing a
still image of a video clip.
Play
: plays the video clip.
Send
: allows you to access the following sending
options:
via MMS: allows you to send the video clip to
another person as part of an multimedia message.
For further details, see
page 116
.
via Email: allows you to send the video clip to
another person as part of an e-mail. For further
details, see
page 133
.
Buttons Function
plays or resumes.
pauses.
stops.
skips backward through a file.
skips forward through a file.
sets the repeat mode.
Funbox
159
via Bluetooth: allows you to send the video clip to
another person via the Bluetooth feature. For
further details, see page 216.
via infrared: allows you to send the video clip to
another person via the infrared port. For further
details, see page 217.
Move to my video clips
: allows you to move the
video clip to the
My video clips
folder. See
page 159.
Rename
: allows you to change the name of the
video clip.
Delete
: allows you to delete the video clip.
Delete all
: allows you to delete all of the video
clips stored in the Video clips folder.
Protection
: protects the video clip from being
deleted.
Properties
: shows you the properties of the video
clip, such as the file name, the time and date it was
recorded, file format, resolution, size, recording
duration, quality, and protection status.
My video clips
You can view the video clips you have moved from
the Video clips folder to this image box.
For further details about viewing a video clip or
using the video options, see “Video clips” on
page 157.
Funbox
160
Downloaded video
When you access this menu, you can view a list of
the video clips downloaded from the Wireless Web
or recevied in messages.
The icons on the video list tell you the status of the
files:
• : files that you can forward to other people.
• : files that you are unable to forward to other
people.
For further details about viewing a video clip or
using the video options, see “Video clips” on
page 157.
Music
In this menu, you can view the list of music files
downloaded from the Wireless Web, or imported
from your computer to the phone through the
EasyStudio programme.
Scroll to a file using the Up or Down key and press
the key.
You can use the following options while playing a
file:
• Scroll to a function button and press the
key. The following buttons are available:
Buttons Function
plays or resumes.
pauses.
stops.
Funbox
161
• Press the Volume keys to adjust the volume.
• Press the
Options
soft key to access MP3
player options. For details, see below.
• Press the
Stop
soft key to stop.
Using music file options
Press the
Options
soft key to access the following
options:
Note
: Available options vary depending on whether
you are looking at the music file list, or at the
MP3 player screen.
Play
/
Pause
: begins/pauses the playing.
Send
: allows you to access the following sending
options:
via MMS: allows you to send the music file to
another person as part of a multimedia message.
For further details, see
page 116
.
via Email: allows you to send the music file to
another person as part of an e-mail. For further
details, see
page 133
.
via Bluetooth: allows you to send the music file to
another person via the Bluetooth feature. For
further details, see page 216.
via infrared: allows you to send the music file to
another person via the infrared port. For further
details, see page 217.
returns to the previous file.
skips to the next file.
/ / changes the repeat mode.
Buttons Function
Funbox
162
Add play list
: allows you to add the music file to
the play list.
Open playlist
: shows you the play list.
Set as
: allows you to set the file as your ring tone
or as a caller melody for an entry in Phonebook.
Rename
: allows you to change the file name.
Delete
: allows you to delete the music file.
Settings
: allows you to change the default settings
for playing MP3 files:
Repeat: allows you to select a repeat mode,
All
,
Off
,
or
One
.
Shuffle: allows you to select a playing order,
Normal
or
Random
.
Volume: allows you to select a volume level.
Lock volume key: allows you to lock the Volume
keys on the left side of the phone so that if the
Volume keys are pressed accidentally, no change in
volume will occur.
Delete all
: allows you to delete all music files.
Protection
: protects the music file from being
deleted.
Properties
: shows you information about the
music file.
Funbox
163
Sounds
In this menu, you can view the sound files you have
recorded or downloaded from a web server, or
received in multimedia messages.
Voice list
You can view the list of the voice memos you have
recorded.
Scroll to a voice memo and press the key to play
the voice memo.
You can pause playing by selecting and
resume by selecting . You can also adjust the
volume by pressing the Volume keys. To stop, select
or press the
Stop
soft key.
Using voice memo options
On the voice memo list, press the
Options
soft key
to access the following options:
Play
: plays the voice memo.
Send
: allows you to access the following sending
options:
via MMS: allows you to send the voice memo to
another person as part of a multimedia message.
For further details, see
page 116
.
via Email: allows you to send the voice memo to
another person as part of an e-mail. For further
details, see
page 133
.
via Bluetooth: allows you to send the voice memo
to another person via the Bluetooth feature. For
further details, see page 216.
Funbox
164
via infrared: allows you to send the voice memo to
another person via the infrared port. For further
details, see page 217.
Rename
: allows you to change the name of the
voice memo.
Delete
: allows you to delete the voice memo.
Delete all
: allows you to delete all of the voice
memos.
Protection
: protects the voice memo from being
deleted.
Properties
: shows you the properties of the voice
memo, such as the memo name, the time and date
it was recorded, file format, recording duration,
size, and protection status.
Downloaded sounds
You can view the list of sounds you have
downloaded from the Wireless Web or received in
messages.
The icons on the sounds list tell you the status of
the files:
• : files that you can forward to other people.
• : files that you are unable to forward to other
people.
Scroll to a sound file and press the to listen to the
sound. To adjust the volume, press the Volume
keys.
Funbox
165
Using sound file options
Press the
Options
soft key to access the following
options:
Note
: Available options vary depending on whether
you are looking at the sound list or playing a
sound.
Play
: plays the sound.
List
: shows the sound list.
Send
: allows you to access the following sending
options:
via MMS: allows you to send the sound to another
person as part of a multimedia message. For further
details, see page page 116.
via Email: allows you to send the sound to another
person as part of an e-mail. For further details, see
page 133.
via Bluetooth: allows you to send the sound to
another person via the Bluetooth feature. For
further details, see page 216.
via infrared: allows you to send the sound to
another person via the infrared port. For further
details, see page 217.
Set as
: allows you to set the sound as your ring
tone or as a caller melody for an entry in
Phonebook.
Rename
: allows you to change the name of the
sound.
Delete
: allows you to delete the sound.
Delete all
: allows you to delete all sounds.
Funbox
166
Protection
: protects the sound from being deleted.
Properties
: shows you information about the
sound.
Memory status
You can check the total amount of memory for
media items and the amount of memory currently
occupied by each media box.
167
Organiser
The Organiser feature enables you to:
• keep track of your schedule and tasks.
• view missed alarm events.
• make a memo.
• check memory amounts for scheduled items.
Month view
(Menu 7.1)
With the Month View feature, you can:
• consult the calendar and check your events.
• write memos to keep track of your schedule.
• set an alarm to act as a reminder.
Consulting the calendar
When you select the
Month view
menu (
Menu
7.1
), the calendar displays with today’s date
indicated by red box. At the bottom of the calendar,
the number of events scheduled for that day
displays. The following icons tell you what kind of
events they are:
• : schedule events
• : anniversaries
•: tasks
• : miscellaneous events
The following options are available when you press
the
Options
soft key:
View
: displays the stored memo(s) for that date.
Create
: allows you to add a new event,
anniversary, miscellaneous event, or task.
Organiser
168
Week view
: switches to the week view screen.
Go to today
: allows you to go to the current date.
Go to date
: allows you to go to a specific date.
Delete
: allows you to access the following deleting
options:
Selected date: allows you to delete items stored on
the currently selected date.
Preceding events: allows you to delete the items
you have made for the days before the currently
selected date.
Delete all
: allows you to delete all scheduled
events.
Scheduling a new event
You can schedule up to 400 events for the calendar.
More than one event per day can be scheduled.
Entering a new schedule event
1. After selecting a day on the calendar, press the
key.
2. Press the
Options
soft key and select
Create
.
3. Select
Schedule
or
Miscellaneous
and press
the
Select
soft key.
4. Scroll through the entry fields by pressing the
Up or Down key. Enter the information you want
or select the settings you want.
•
Subject
: enter the title of the event. See
page 36 for more information about entering
characters.
Organiser
169
•
Details
: enter the event details.
•
Start date
: enter the starting date.
•
Start time
: enter the starting time of the
event.
•
AM/PM
: select
AM
or
PM
. This option is only
available when the time format is set to
12-
hour
.
•
End date
: enter the ending date of the event.
•
End time
: enter the ending time.
•
AM/PM
: select
AM
or
PM
. This option is only
available when the time format is set to
12-
hour
.
•
Location
: enter information about the event
location. This option is only available for
Schedule
.
•
Alarm
: press the key to set an alarm to
remind you of the event.
•
before
: set when the alarm will alert you
before the event starts; enter the number you
want and select a unit,
min.
,
hour
,
day
, or
week
, using the Left or Right key.
•
Alarm tone
: select an alarm tone.
•
Repeat
: if you are making a recurring event,
press the key. Select the repeat unit,
every
day
,
every week
, or
every month
. This
option is only available for
Schedule
.
•
Until
: set the ending date for the repeat entry.
This option is only available for
Schedule
.
5. When you finish entering the event, press the
Save
soft key.
Organiser
170
Entering a new anniversary
1. After selecting a day on the calendar, press the
key.
2. Press the
Options
soft key and select
Create
.
3. Select
Anniversary
and press the
Select
soft
key.
4. Scroll through the entry fields by pressing the
Up or Down key. Enter the information you want
or select the settings you want.
•
Occasion
: enter information about the
occasion. See page 36 for more information
about entering characters.
•
Date
: enter the date.
•
Alarm
: press the key to set an alarm to
remind you of the event
•
before
: set when the alarm will alert you
before the day arrives; enter the number you
want and select a unit,
day
or
week
, using
the Left and Right keys.
•
Alarm time
: enter the time when the alarm
sounds.
•
AM/PM
: select
AM
or
PM
. This option is only
available when the time format is set to
12-
hour
.
•
Alarm tone
: select an alarm tone.
•
Repeat every year
: press the key to
remind you every year.
5. When you finish entering the anniversary, press
the
Save
soft key.
Organiser
171
Entering a task
1. After selecting a day on the calendar, press the
key.
2. Press the
Options
soft key and select
Create
.
3. Select
To do
and press the
Select
soft key.
4. Scroll through the entry fields by pressing the
Up or Down key. Enter the information you want
or select the settings you want.
•
To do
: enter information about the task.
•
Start date
: enter the starting date.
•
Due date
: enter the ending date.
•
Priority
: select a priority level,
High
,
Normal
, or
Low
.
5. When you finish entering the task, press the
Save
soft key.
Viewing an event
Square brackets on each corner of a calendar day
indicate the type of events scheduled for that day:
•Blue: schedule
• Orange: anniversary
• Green: miscellaneous event
•Red: task
When you select a day for which an event already
exists on the calendar, a list of the events you have
created displays. Scroll to an event and press the
key. For further details about viewing an event, see
page 172.
Organiser
172
Week view
(Menu 7.2)
In this menu, the calendar entries for the selected
week are shown in seven day boxes. Today’s day of
the week is marked in red. On the week view
screen, blue boxes means that schedule events are
stored and green boxes means that miscellaneous
events are stored.
To view an item, scroll to the cell that contains the
item and press the key.
For further details about using options, see “Month
view” on page 167.
Day view
(Menu 7.3)
This menu allows you to schedule new events for
the current day. Events scheduled for future dates
automatically appear on your Day’s event display
for that particular day.
The following icons tell you what kind of events they
are:
• : schedule events
• : anniversaries
•: tasks
• : miscellaneous events
If more than one event is stored, scroll to an event
using the Up or Down key and press the key to
view the event.
Organiser
173
On the Day’s event screen, press the
Options
soft
key to access the following options:
View
: shows the selected event.
Send
: allows you to access the following sending
options:
via SMS: allows you to send the event to other
people as part of a text message. For details, see
page 107
.
via MMS: allows you to send the event to other
people as part of an MMS message. For details, see
page 116
.
via Email: allows you to send the event to other
people as part of an e-mail. For further details, see
page 133
.
via Bluetooth: allows you to send the event to other
people via the Bluetooth feature. For further details,
see page 216.
via infrared: allows you to send the event to other
people via the infrared port. For further details, see
page 217.
Create
: allows you to add a new event,
anniversary, miscellaneous event, or task.
Month view
: switches to the calendar screen.
Week view
: switches to the week view screen.
Done
/
Undone
: allows you to change the status of
the event.
Delete
: allows you to delete the selected event.
Delete all
: allows you to delete all of the events
stored on that date.
Organiser
174
Schedule
(Menu 7.4)
In this menu, you can view a list of the schedule
events. If you have set the Repeat and Alarm
options, the and icons are activated.
Scroll to an event and press the key to view the
schedule event. To scroll through the screen, press
the Up or down key.
Press the
Options
soft key to access the following
options:
View
: shows the selected event.
Edit
: allows you to edit the event. This option is
available when you are viewing an event.
Send
: allows you to access the following sending
options:
via SMS: allows you to send the event to another
person as part of an SMS message. For further
details, see
page 107
.
via MMS: allows you to send the event to another
person as part of a multimedia message. For further
details, see
page 116
.
via Email: allows you to send the event to another
person as part of an e-mail. For further details, see
page 133
.
via Bluetooth: allows you to send the event to
another person via the Bluetooth feature. For
further details, see page 216.
via infrared: allows you to send the event to
another person via the infrared port. For further
details, see page 217.
Organiser
175
Create
: allows you to create a new event. For
further details about creating a new event, see
page 168.
Month view
: switches to the calendar screen.
Week view
: switches to the week view screen.
Delete
: allows you to delete the selected event.
Delete all
: allows you to delete all events.
Anniversary
(Menu 7.5)
In this menu, you can view a list of anniversaries
you have created. If you have set the Repeat an
Alarm options, the and icons are activated.
Scroll to an event and press the key to view the
anniversary. To scroll through the screen, press the
Up or down key.
Press the
Options
soft key to access the following
options:
View
: shows the selected anniversary.
Edit
: allows you to edit the anniversary. This option
is available when you are viewing an anniversary.
Send
: allows you to access the following sending
options:
via SMS: allows you to send the anniversary to
another person as part of an SMS message. For
further details, see
page 107
.
via MMS: allows you to send the anniversary to
another person as part of an MMS message. For
further details, see
page 116
.
Organiser
176
via Email: allows you to send the anniversary to
another person as part of an e-mail. For further
details, see
page 133
.
via Bluetooth: allows you to send the anniversary to
another person via the Bluetooth feature. For
further details, see page 216.
via infrared: allows you to send the anniversary to
another person via the infrared port. For further
details, see page 217.
Create
: allows you to create a new anniversary. For
further details about creating a new anniversary,
see page 170.
Month view
: switches to the calendar screen.
Week view
: switches to the week view screen.
Delete
: allows you to delete the selected
anniversary.
Delete all
: allows you to delete all anniversaries.
Miscellaneous
(Menu 7.6)
In this menu, you can view a list of miscellaneous
events you have created. If you have set the Alarm
option, the icon is activated.
Scroll to a miscellaneous event and press the key
to view the miscellaneous event. To scroll through
the screen contents, press the Up or down key.
Press the
Options
soft key to access the following
options:
View
: shows the miscellaneous event.
Organiser
177
Edit
: allows you to edit the miscellaneous event.
This option is only available when you are viewing
an miscellaneous event.
Send
: allows you to access the following sending
options:
via SMS: allows you to send miscellaneous event to
another person as part of an SMS message. For
further details, see
page 107
.
via MMS: allows you to send the miscellaneous
event to another person as part of an MMS
message. For further details, see
page 116
.
via Email: allows you to send the miscellaneous
event to another person as part of an e-mail. For
further details, see
page 133
.
via Bluetooth: allows you to send the miscellaneous
event to another person via the Bluetooth feature.
For further details, see page 216.
via infrared: allows you to send the miscellaneous
event to another person via the infrared port. For
further details, see page 217.
Create
: allows you to create a new miscellaneous
event. For further details about creating a new
miscellaneous event, see page 168.
Month view
: switches to the calendar screen.
Week view
: switches to the week view screen.
Delete
: deletes the selected miscellaneous event.
Delete all
: allows you to delete all miscellaneous
events.
Organiser
178
To do
(Menu 7.7)
When you select the
To do
menu, a list of tasks you
have created displays with the status mark,
!
, in red
for High, blue for Normal, and grey for Low, and the
status check box. If the task has been completed, a
check mark appears in this box.
Scroll to a task and press the key to view the
task. To scroll through the screen, press the Up or
Down key.
Press the
Options
soft key to access the following
options:
View
: shows the selected task.
Edit
: allows you to edit the task. This option is only
available when you are viewing a task.
Send
: allows you to access the following sending
options:
via SMS: allows you to send the task to another
person as part of an SMS message. For further
details, see
page 107
.
via MMS: allows you to send the task to another
person as part of an MMS message. For further
details, see
page 116
.
via Email: allows you to send the task to another
person as part of an e-mail. For further details, see
page 133
.
via Bluetooth: allows you to send the task to
another person via the Bluetooth feature. For
further details, see page 170.
via infrared: allows you to send the task to another
person via the infrared port. For further details, see
page 217
Organiser
179
Create
: allows you to create a new task. For
further details about creating a new task, see
page 171.
Month view
: switches to the calendar screen.
Week view
: switches to the week view screen.
Done
/
Undone
: changes the status of the task.
Delete
: deletes the task.
Delete all
: allows you to delete all tasks.
Missed alarm event
(Menu 7.8)
When you are unable to acknowledge an alarm for
an event you have set, the phone displays a
notification about the missed alarm. When a
notification appears, press the
View
soft key to
view the corresponding event. Otherwise, press the
Exit
soft key.
When you access this menu, you can view a list of
missed alarm events.
To view a missed alarm event:
1. Scroll to an event and press the key.
2. Press the Up or Down key to scroll through the
screen.
3. Press the
Confirm
soft key.
After pressing the
Confirm
soft key, the event is
deleted from the missed alarm event list.
Organiser
180
On the event list, press the
options
soft key to
access the following options:
View
: shows you the event.
Delete
: allows you to delete the event.
Delete all
: allows you to delete all events.
Memo
(Menu 7.9)
In this menu, you can create memos and view the
memos you have stored.
Creating a new memo
1. Press the key.
Alternatively, press the
Options
soft key and
select
Create
.
2. Enter the memo.
For further details about how to enter
characters, see page 36.
While entering text, press the
Options
soft key
to access the following options:
•
Save
: allows you to save the memo.
•
Language select
: allows you to change the
language to be used in T9 input mode. Select
the language to be used.
•
Back
: returns you to the Memo screen.
3. Press the key.
Alternatively, press the
Options
soft key and
select
Save
.
Organiser
181
Viewing a memo
Scroll to a memo and press the key to view the
memo.
On the memo list, press the
Options
soft key to
access the following options:
Edit
: allows you to edit the memo.
Create
: allows you to add a new memo.
Delete
: deletes the selected memo.
Delete all
: allows you to delete all memos.
Memory status
(Menu 7.10)
You can check the total amount of memory for the
calendar, the number of events you have created
and the total number of events you can store. You
can view how many events are currently stored in
each type. Press the Up or Down key to scroll
through the screen. If your organiser memory is
full, you can select an event type to open it
immediately from this menu and then delete some
events to free up memory.
182
Camera
Using the camera module embedded in your phone,
you can take photos of people or events while on
the move. You can also send photos to other people
using various sending options, or set one as
wallpaper or as a caller ID image for an entry in
Phonebook.
You can also record videos using the phone as a
camcorder.
CAUTION
:
• Do not take photos of people without their
permission.
• Do not take photos in a place where cameras are not
allowed.
• Do not take photos in a place where you may
interfere with another person’s privacy.
Take a photo
(Menu 8.1)
The camera produces JPEG photos.
Note
: When you take a photo in direct sunlight or in
bright conditions, shadows may appear on the
photo.
Taking a photo
1. If the phone is closed, open the phone.
2. Access the
Take a photo
menu, or you can also
press and hold the
Camera key ( )
on the right
side of the phone in Idle mode.
The image to be captured appears on the
display.
Camera
183
3. Adjust the image by aiming the camera at the
subject.
When you press the left soft key, you can use
the camera options. For details, see page 185.
You can change the image settings or switch to
other modes by using the keypad. For details,
see page 183.
4. Press the key or the Camera key to take the
photo.
The photo automatically saves in the
Photos
folder (
Menu 8.3
).
Note
: Hold the phone still for 1 or 2 seconds after
pressing the camera shutter key. It may
take some time to process the image data.
Using the keypad in Capture mode
You can use the keypad to customise your camera
settings when you are in Capture mode.
5.
To Press the
use photo options
Options
soft key. For
further details, see
page 187.
delete the photo
Delete
soft key.
return to Capture
mode
C
key or the key.
Key Function
flips the image vertically.
shows the mirror image.
Camera
184
Left/
Right adjusts the brightness of the image.
Up/
Down zooms in or out.
1
switches to Record mode. See
page 188.
2
changes the image size.
3
changes the image quality.
4
changes the camera mode.
5
changes the colour tone or applies a
special effect to the photo.
6
reduces the distortion on the image to
maximise detail and sharpness.
7
selects a decorative frame.
8
sets the timer.
9
allows you to view the photos stored in
the
photos
(
Menu 8.3
) or
My photos
folder (
Menu 8.4
)
0
turns the flash on or off.
shows the real image size to be
captured.
Key Function
Camera
185
Using camera options in Capture mode
In Capture mode, you can access various options by
pressing the left soft key.
The following options are available:
Shooting mode
: allows you to take a photo in
various modes. Once you change the mode, its
indicator appears at the top left.
Single shot: allows you to take a photo in the
normal mode.
Multi shot: allows you to take a series of action
stills. Select the number of photos the camera will
take. When you press the key or the Camera key,
the camera takes the photos successively.
Note
: Depending on the specified image size, the
shutter speed for series shots may vary. The
larger the image, the slower the shutter speed.
Mosaic shot: allows you to take several stills and
save them in one frame. Select the number of still
images the camera will take. The images will be
saved in one frame, consisting of the multiple stills
taken.
Night shot: allows you to take a photo of the best
quality when it is dark.
Automatic save: returns you to the preview screen
automatically after taking a photo.
Effects
: allows you to change the colour tone or
apply a special effect to the photo.
Frames
: allows you to use a decorative frame.
Select a frame from the list using the Navigation
keys.
Camera
186
Timer
: allows you to set a time delay before the
camera takes a photo. Select the length of delay
you want.
Photo album
: allows you to view the photos stored
in the
Photos
(
Menu 8.3
) or
My photos
folder
(
Menu 8.4
).
Settings
: allows you to change the default settings
for taking a photo.
Size: allows you to select the image size.
Quality: allows you to select the image quality.
Shutter sound: allows you to select the sound that
you hear when you press the shutter, the Camera
key, or the key.
Spot focus: allows you to adjust the exposure of an
image based on a specific area of the image. When
you select
On
, the spot focus frame appears in the
middle of the image. Change the exposure
according to the brightness of the image in the
frame.
ISO: allows you to change the ISO setting, which
controls the sensitivity of your camera. For low light
situations, such as night scenes, indoors, or in dark
shade, when using the flash is undesirable, lower
the ISO number to increase the image quality.
The higher the ISO number, the faster the camera
shutter functions and the more sensitive the
camera is to light. Note that higher ISO settings
may bring some distortion to an image. When you
select
Auto
, the phone is set to the ISO 100
standard, ideal for normal daylight conditions.
Default name: allows you to change the default
prefix of the photo name.
Camera
187
Flash
: allows you to turn on or off the flash.
Camera short cuts
: shows you the functions of
the keys you can use.
Using photo options
After saving a photo, press the
Options
soft key to
access the following options:
Take another
: returns to Capture mode.
Send
: allows you to access the following sending
options:
via MMS: allows you to send the photo to other
people as part of an MMS message. For further
details, see
page 116
.
via Email: allows you to send the photo to other
people as part of an e-mail. For further details, see
page 133
.
via Bluetooth: allows you to send the photo to other
people via the Bluetooth feature. For further details,
see page 216.
via infrared: allows you to send the photo to
another person via the infrared port. For further
details, see page 217.
Set as
: allows you to set the photo as your
wallpaper or as a caller ID image for an entry in
Phonebook.
Go to photo album
: allows you to view the photos
stored in the
Photos
(
Menu 8.3
) or
My photos
folder (
Menu 8.4
).
Camera
188
Rename
: allows you to change the name of the
photo.
Protection
: protects the photo from being deleted.
Properties
: shows you the properties of the photo,
such as the file name, the time and date it was
saved, format, resolution, size, quality, and
protection status.
Record video
(Menu 8.2)
You can record a video of what is currently
displayed on the camera screen and save it as a
.3gp file.
1. When the camera turns on, adjust the image by
aiming the camera at the subject.
When you press the
Options
soft key, you can
use the Camera options. For details, see
page 189.
You can change the image settings or switch to
other modes by using the keypad. For details,
see page 189.
2. Press the key to start recording.
3. When you are finished, press the
Stop
soft key
or the key. Or, recording stops when the
recording time expires.
The video automatically saves in the
Video
clips
folder (
Menu 8.5
).
Camera
189
Using the keypad in Record mode
You can use the keypad to customise your camera
settings when you are in Record mode:
4.
To Press the
play back the video
clip key. For details, see
page 194.
use the video options
Options
soft key. For
further details, see
page 191.
delete the video clip
Delete
soft key.
return to Record
mode
C
key.
Key Function
flips the image vertically.
shows the mirror image.
Up/
Down zooms in or out.
Left/
Right adjusts the brightness of the image.
1
switches to Capture mode. See
page 182.
2
changes the frame size.
3
changes the image quality.
4
switches to between Limit for MMS mode
and Normal mode.
Camera
190
Using camera options in Record mode
When you press the
Options
soft key in Record
mode, you can access the following options for
recording a video:
Effects
: allows you to change the colour tone or
apply a special effect to the video.
Timer
: allows you to set a time delay before the
camera starts recording the video. Select the length
of delay you want.
Go to video album
: allows you to view the video
clips stored in the
Video clips
(
Menu 8.5
) or
My
video clips
folder (
Menu 8.6
).
Settings
: allows you to change the default settings
for recording a video.
Recording mode: allows you to select a video
recording mode.
When this option is set to
Limit for
MMS
, you can
record a video for adding to an MMS message.
5
changes the colour tone or applies a
special effect to the video.
6
reduces the distortion on the image to
maximise detail and sharpness.
7
mutes or unmutes the audio.
8
sets the timer.
9
allows you to view the video clips stored
in the
Video clips
(
Menu 8.5
) or
My
video clips
(
Menu 8.6
) folder.
0
turns the flash on or off.
Key Function
Camera
191
When this option is set to
Normal
, you can record a
video within the limit of the current available
memory. How long your video can be depends on
how much memory has been used.
Size: allows you to select the image size.
Quality: allows you to select the image quality.
Audio rec.: allows you to record audio with a video
clip.
Default name: allows you to change the default
prefix of the video name.
Flash
: allows you to turn the flash on or off.
Camcoder short cuts
: shows you the functions of
the keys you can use.
Using video options
When you press the
Options
soft key after saving a
video clip, the following options are available:
Record another
: returns to Record mode.
Send
: allows you to access the following sending
options:
via MMS: allows you to send the video clip to
another person as part of a multimedia message.
For further details, see
page 116
.
via Email: allows you to send the video clip to
another person as part of an e-mail. For further
details, see
page 133
.
via Bluetooth: allows you to send the video clip to
another person using the Bluetooth feature. For
further details, see page 216.
Camera
192
via infrared: allows you to send the video clip to
another person via the infrared port. For further
details, see page 217.
Go to video album
: allows you to move to the
Video clips
(
Menu 8.5
) or
My video clips
folder
(
Menu 8.6
).
Rename
: allows you to change the name of the
video clip.
Protection
: protects the video clip from being
deleted.
Properties
: shows you the properties of the video
clip, such as the file name the time and date it was
recorded, file format, resolution, size, recording
duration, quality, and protection status.
Photos
(Menu 8.3)
You can view the photos you have taken. When you
access this menu, a list of photos you have taken
displays.
Scroll through the list using the Up or Down key. To
view the selected photo, press the key. To go
back to the photo list, press the key, the
Back
soft key, or the
C
key.
Press the
Options
soft key to access the following
options:
Note
: Available options vary depending on whether
you are looking at the photo list or viewing a
photo.
View
: shows the photo.
List
: returns you to the photo list.
Camera
193
Send
: allows to access the following sending
options:
via MMS: allows you to send the photo to another
person as part of a multimedia message. For further
details, see
page 116
.
via Email: allows you to send the photo to another
person as part of an e-mail. For further details, see
page 133
.
via Bluetooth: allows you to send the photo to
another person via the Bluetooth feature. For
further details, see page 216.
via infrared: allows you to send the photo to
another person via the infrared port. For further
details, see page 217.
Move to my photos
: allows you to move the photo
to the
My photos
folder (
Menu 8.4
).
Set as
: allows you to set the photo as your
wallpaper or as a caller ID image for an entry in
Phonebook.
Edit
: allows you to access the following options:
Emoticons: allows you to add an emoticon to the
photo. After selecting an emoticon, you can move
the emoticon by pressing the Navigation keys or the
2
,
4
,
6
and
8
keys.
Frames: allows you to select a decorative frame.
Slide show
: set all photos to automatically display
one after another as a slide show. You can select a
time interval between photos.
Rename
: allows you to change the name of the
photo.
Delete
: allows you to delete the photo.
Camera
194
Delete all
: allows you to delete all photos.
Protection
: protects the photo from being deleted.
Properties
: shows the properties of the photo,
such as the file name, the time and date it was
saved, format, resolution, size, quality, and
protection status.
My photos
(Menu 8.4)
In this menu, you can view the photos you have
moved from the Photos folder to this image box.
For further details about viewing a photo or using
the photo options, see “Photos” on page 192.
Video clips
(Menu 8.5)
When you access this menu, a list of the videos you
have recorded displays.
To play a video clip:
1. Scroll to a video using the Up or Down key and
press the key.
The selected video clip plays.
2. You can access the following options while
playing a video clip:
Camera
195
• Scroll to a function button on the screen and
press the key. The following buttons are
available:
• Press the Volume keys to adjust the volume.
Press the
Options
soft key to access the following
options:
Play
: plays the video clip.
Send
: allows you to access the following sending
options:
via MMS: allows you to send the video clip to other
people as part of an MMS message. For further
details, see
page 116
.
via Email: allows you to send the video clip to other
people as part of an e-mail. For further details, see
page 133
.
via Bluetooth: allows you to send the video clip to
other people via the Bluetooth feature. For further
details, see page 216.
via infrared: allows you to send the video clip to
other people via the infrared port. For further
details, see page 217.
Buttons Function
pauses.
resumes.
stops.
skips backward through a file.
skips forward through a file.
repeats the playing.
Camera
196
Move to my video clips
: allows you to move the
video clip to the
My video clips
folder (
Menu 8.6
).
Rename
: allows you to change the name of the
video clip.
Delete
: allows you to delete the video clip.
Delete all
: allows you to delete all of the video
clips. This option appears on the video clip list.
Protection
: protects the video clip from being
deleted.
Properties
: shows you the properties of the video
clip, such as the file name, the time and date it was
recorded, file format, resolution, size, recording
duration, quality, and protection status.
My video clips
(Menu 8.6)
In this menu, you can view the video clips you have
moved from the Video clips folder to this image box.
For further details about viewing a video clip or
using the video options, see “Video clips” on
page 194.
197
Settings
In this menu, you can customise your phone’s
various settings, such as:
• time and date
• phone settings
• display settings
• sound settings
• network services
• connectivity settings
• security settings
You can also reset the settings to their default
values.
Time & Date
(Menu 9.1)
This menu allows you to change the current time
and date displayed.
The following options are available:
Set time
: allows you to enter the current time
using the number keys.
Note
: Before setting the time, you must specify your
time zone in the
World
time
menu
(
Menu
3.4
).
AM/PM
: allows you to select
AM
or
PM
. This
option is only available when the
Time format
is
set to
12 hours
.
Time format
: allows you to select a time format,
12 hours
or
24 hours
.
Settings
198
Set date
: allows you to enter the current date
using the number keys.
Date format
: allows you to select a date format.
Phone settings
(Menu 9.2)
Many different features of your phone can be
customised to suit your preferences.
Language
(Menu 9.2.1)
You can select a language for the display text.
Select one of several languages.
Greeting message
(Menu 9.2.2)
This menu allows you to set a greeting to be
displayed briefly when the phone is switched on.
1. If necessary, clear the default greeting message
using the
C
key.
2. Enter the greeting message you want.
For further details about how to enter
characters, see page 36.
3. Press the key to save.
On the Enter greeting screen, press the
Options
soft key to access the following options:
Save
: allows you to save your greeting message.
Language select
: allows you change the language
to be used for the message.
Cancel
: allows you to exit the current screen.
Settings
199
Slide settings
(Menu 9.2.3)
In this menu, you can set how the phone reacts
when you open it for an incoming call, and when
you close it while using a function.
The following options are available:
Up
: selects whether or not you answer a call simply
by opening the phone.
Down
: selects whether or not the phone maintains
the menu or functions you are currently using when
you close the phone.
Note
: While you are using a headset, the call is not
ended by closing the phone even though the
Down
option of the menu is set to
Stop
operation
.
Short cut
(Menu 9.2.4)
The Navigation keys can be used as shortcut keys.
In Idle mode, they allow you to access specific
menus directly.
To assign a shortcut to a key:
1. Select the key to be used as a shortcut key by
pressing the Navigation keys and press the
key.
2. Select the menu to be assigned by pressing the
Up or Down key.
3. Press the
Save
soft key.
On the Short cut screen, press the
Options
soft key
to access the following options:
Change
: allows you to change a shortcut menu.
Settings
200
Remove
: deactivates the shortcut key assignment
to the selected key.
Remove all
: deactivates all of the shortcut
assignments.
Extra settings
(Menu 9.2.5)
You can turn the automatic redialling or answering
features on or off.
The following options are available:
Auto redial
: when this option is set to
On
, the
phone makes up to 10 attempts to redial a phone
number after an unsuccessful call.
Note
: The interval between attempts varies.
Anykey
answer
: when this option is set to
On
,
you can answer an incoming call by pressing any
key, except the key or the
Reject
soft key. To
reject the call, press the key or the
Reject
soft
key.
When this option is set to
Off
, you must press the
key or the
Accept
soft key to answer a call.
Voice clarity
: when this option is set to
On
, the
microphone’s sensitivity increases to allow the
person on the phone to hear your voice even
though you may be whispering during the call.
Settings
201
Display settings
(Menu 9.3)
In this menu, you can change various settings for
the display or the backlight.
Wallpaper
(Menu 9.3.1)
This menu allows you to change the background
image to be displayed in Idle mode.
To change the background image:
1. Select an image category and press the
Select
soft key.
The following options are available:
•
Default wallpapers
: allows you to select
various preset images.
•
Photos
: allows you to select one of the photos
you have taken.
•
My photos
: allows you to select one of the
photos stored in the
My photos
folder (
Menu
8.4
).
•
Downloaded images
: allows you to select
one of the images downloaded from the
Wireless Web.
2. Scroll to an image.
If you selected
Default wallpapers
in step 1,
skip to step 4.
3. Press the key to view the image.
Alternatively, press the
Options
soft key to
access the following options:
•
View
: shows you the image.
•
Save
: sets the image as your wallpaper.
Settings
202
4. When the image displays, press the
Save
soft
key to display it on the idle screen.
Text display
(Menu 9.3.2)
In this menu, you can change the display settings
for the text displayed on the idle screen.
The following options are available:
Text position
: allows you to select a text position.
If you don’t want text to display in Idle mode, select
Off
.
Text style
: allows to select a text style.
Text colour
: allows you to select the colour of the
text.
Skin
(Menu 9.3.3)
In this menu, you can select a skin colour pattern
for Menu mode. Select one of the 4 patterns.
LCD brightness
(Menu 9.3.4)
You can adjust the brightness of the display to see it
better in different lighting conditions.
Press the Left or Right key or the Volume keys to
adjust the brightness.
Settings
203
Backlight
(Menu 9.3.5)
In this menu, you can select the length of time the
backlight is on and the phone is in Dimming mode.
The following options are available:
On
: allows you to select the length of time the
backlight is on.
The backlight turns on when you press a key, open
the phone, or receive a call or message, and
remains on for the specified length of time.
Dim
: allows you to select the length of time the
phone is in Dimming mode. After the backlight is
off, the phone's display dims. The analogue clock
displays after a specified time.
Sound settings
(Menu 9.4)
You can customise various sound settings.
Note
: If the phone is in Quiet mode (see page 32), a
confirmation message appears. Press the
Yes
soft key to listen to a sound when you change a
sound setting. Otherwise press the
No
soft key.
Incoming call
(Menu 9.4.1)
In this menu, you can select a volume level and
alert type for incoming calls. The following options
are available:
Ring tone
: allows you to select a ring melody.
Select one of the default melodies, or downloaded
sounds and music files.
Volume
: allows you to select a ringer volume.
Settings
204
Alert type
: allows you to specify how you are to be
informed of incoming calls.
Melody: the phone rings using the selected ring
tone.
Vibration: the phone vibrates but does not ring.
Vibration then melody: the phone first vibrates 3
times and then starts ringing.
Keypad tone
(Menu 9.4.2)
This menu allows you to select the tone that the
phone sounds when you press a key.
To turn off the sound, select
Off
.
Message tone
(Menu 9.4.3)
This menu allows you to set up the ringer for
incoming messages, text messages, multimedia
messages, and e-mails.
For each message, the following options are
available:
Tone
: allows you to use one of several message
tones.
Alert type
: allows you to specify how you are
informed of any incoming messages.
Melody: the phone rings using the tone selected
under the
Tone
option.
Vibration: the phone vibrates.
Vibration then melody: the phone first vibrates 6
times and then starts ringing.
Silence: the phone neither rings nor vibrates.
Settings
205
Repetition
: allows you to specify how often the
phone informs you of a new message. The following
options are available:
Every 1 min.: the phone alerts you to a new
message every 1 minute until you open the
message.
Every 2 min.: the phone alerts you to a new
message every 2 minutes until you open the
message.
Once: the phone alerts you to a new message just
once at the time of its receipt.
Power on/off
(Menu 9.4.4)
This menu allows you to select the melody that the
phone sounds when it is switched on or off.
To turn off the sound, select
Off
.
Slide tone
(Menu 9.4.5)
This menu allows you to select the tone that the
phone sounds when you open or close the phone.
To turn off the sound, select
Off
.
Quiet mode
(Menu 9.4.6)
In this menu, you can select an alert type for
incoming calls or messages when the phone is in
Quiet mode.
The following options are available:
Vibration
: the phone vibrates in Quiet mode.
Mute
: the phone mutes all sound settings in Quiet
mode.
Settings
206
Extra tones
(Menu 9.4.7)
You can customise additional tones for the phone.
To turn on an alert:
1. Select an alert using the Up or Down key.
The following options are available:
•
Minute
minder
: when this alert is checked,
the phone beeps every minute during an
outgoing call to keep you informed of the
length of your call.
•
Connection
tone
: when this alert is checked,
your phone beeps when your call is connected
to the system.
•
Alerts on call
: when this alert is checked, the
phone informs you when you receive a new
message or when the time for an alarm comes
during a call.
•
Indicative
tones
: when this alert is checked,
the phone beeps when a pop-up window
displays.
2. Press the key to place a check mark in front of
the alert you want to activate.
To remove a check mark, press the key again.
3. To select more alerts, repeat steps 1 and 2.
4. When you are finished, press the
Save
soft key.
Settings
207
Network services
(Menu 9.5)
These menu functions access network services.
Please contact your service provider to check their
availability and then subscribe to them, if you wish.
Call diverting
(Menu 9.5.1)
This network service enables incoming calls to be
rerouted to a number that you specify.
Example: You may wish to divert your business calls
to a colleague while you are on holiday.
To set your call diverting options:
1. Select a call diverting option by pressing the Up
or Down key, and then press the
Select
soft
key.
The following options are available:
•
Divert always
: all calls are diverted.
•
Busy
: calls are diverted when you are already
on another call.
•
No
reply
: calls are diverted when you do not
answer the phone.
•
Unreachable
: calls are diverted when you are
not in an area covered by your service
provider or when your phone is switched off.
•
Cancel
all
: all call diverting options are
cancelled.
2. Select the type of calls, voice or data, by
pressing the Up or Down key, and then press the
Select
soft key.
The current status displays. If the option has
already been set, the number to which the calls
are diverted displays.
Settings
208
4. Enter the number to which the calls are to be
diverted and press the
OK
soft key.
To enter an international code, press the
0
key
until the
+
sign displays.
5. If you selected
No reply
in step 1, select the
length of time the network waits before diverting
a call.
The phone sends your settings to the network
and the network’s acknowledgement displays.
Call barring
(Menu 9.5.2)
The call barring network service allows you to
restrict your calls.
To set your call barring options:
1. Select a call barring option by pressing the Up or
Down key, and then press the
Select
soft key.
The following options are available:
•
All
outgoing
: calls cannot be made.
•
International
: international calls cannot be
made.
3.
To Press the
activate call
diverting
Activate
soft key. Go to
step 4.
change the number
to be called
Change
soft key. Go to
step 4.
deactivate call
diverting
Remove
soft key.
Settings
209
•
International
except
to
home
: when
abroad, calls can be made only to numbers
within the current country and to your home
country, which is the country where your home
network provider is located.
•
All
incoming
: calls cannot be received.
•
Incoming
while
abroad
: calls cannot be
received when you are using your phone
outside of your home country.
•
Cancel
all
: all call barring settings are
deactivated; calls can be made and received
normally.
•
Change barring password
: you can set and
change the call barring password obtained
from your service provider.
2. Select the type of calls, voice or data, by
pressing the Up or Down key, and then press the
Select
soft key.
3. Press the
Activate
soft key to confirm your
settings.
4. Enter the call barring password supplied by your
service provider.
The phone sends your settings to the network
and the network’s acknowledgement displays.
To deactivate specific call barring settings:
1. Select the call barring option to be deactivated.
2. Select the type of calls to which this option
applies.
3. Press the
Deactivate
soft key.
Settings
210
4. Enter the call barring password supplied by your
service provider.
The phone sends your settings to the network
and the network’s acknowledgement displays.
Call waiting
(Menu 9.5.3)
This network service informs you when someone is
trying to reach you during another call.
You can specify individual call waiting options for
voice calls and/or data calls.
To set your call waiting options:
1. Select the type of calls, voice or data, to which
you want to apply the call waiting option by
pressing the Up or Down key, and then press the
Select
soft key.
The screen informs you whether call waiting is
activated or deactivated.
2. You can activate or deactivate the call waiting
feature as necessary by using the
Activate
or
Deactivate
soft key respectively.
To return to the previous screen, press the
Exit
soft key.
You can also deactivate all call waiting settings by
selecting the
Cancel
all
option.
Settings
211
Network selection
(Menu 9.5.4)
The Network Selection feature enables you to
automatically or manually select the network used
when roaming outside of your home area.
Note
: You can select a network other than your home
network only if there is a valid roaming
agreement between the two.
To automatically or manually select the network to
be used when roaming:
1. Press the Up or Down key until the appropriate
option highlights and then press the
Select
soft
key.
If you select
Automatic
, you are connected to
the first available network when roaming.
If you select
Manual
, go to step 2.
2. Press the Up or Down key until the network you
want highlights and then press the
OK
soft key.
The phone will scan for that network and you
will be connected.
Caller ID
(Menu 9.5.5)
You can prevent your phone number from being
displayed on the phone of the person being called.
Note
: Some networks do not allow the user to change
this setting.
The following options are available:
Default
: the default setting provided by the
network is used.
Hide
number
: your number does not display on
the other person’s phone.
Settings
212
Send
number
: your number is sent each time you
make a call.
Band selection
(Menu 9.5.6)
For the phone to make and receive phone calls, it
must register with an available network. Your phone
can handle any of the following types of networks:
• GSM 1900
• Combined GSM 900/1800
• GSM 900/1800/1900
The country where you purchased your phone
determines the default band that it uses. When you
travel abroad, you must remember to change to an
appropriate band.
1. Press the Up or Down key until the appropriate
option highlights and press the
Select
soft key.
2. When the display confirms the network band
you selected, press the
Yes
soft key.
To cancel the selection, press the
No
soft key.
When you select a new band, your phone
automatically searches for all available networks.
Your phone registers with a preferred network
within the band.
Active line
(Menu 9.5.7)
some SIM cards may used with 2 subscriber
numbers. This function is available only if your SIM
card supports it. This menu allows you to select the
line to be used to make calls. However, calls can be
answered on both lines, regardless of the selected
line.
Settings
213
Connectivity
(Menu 9.6)
In this menu, you can use the IrDA port or the
Bluetooth feature for connecting to other devices
wirelessly.
Bluetooth
(Menu 9.6.1)
Bluetooth technology enables cost-free wireless
connections between electronic devices within a
maximum range of 10 meters. A Bluetooth
connection can be used to send photos, images,
videos, messages, scheduled items, and to connect
wirelessly to devices using Bluetooth technology,
such as computers.
Since Bluetooth devices communicate using radio
waves, your phone and the other Bluetooth device
do not need to be in line of sight to each other.
The 2 devices only need to be within a maximum of
10 meters of each other, although the connection
can be subjected to interference from obstructions,
such as walls or other electronic devices. In some
countries, there may be restrictions on using
Bluetooth devices. Please contact your service
provider.
Setting up the Bluetooth feature
When you access this menu, you can access the
following options:
Activation
: allows you to activate the Bluetooth
feature. When this option is set to
On
, the
Bluetooth icon ( ) appears.
My devices
: allows you to search for connectable
Bluetooth devices. For details, see below.
Settings
214
My phone’s visibility
: allows you to set whether
or not your phone is available to other Bluetooth
devices.
My phone’s name
: allows you to change your
phone’s Bluetooth device name, which is displayed
on other devices. You can enter up to 32 characters.
Secure mode
: allows you to select whether or not
the phone asks for your confirmation when other
devices access your data.
Bluetooth services
: shows a list of the Bluetooth
services you can use.
Searching for and pairing a Bluetooth device
1. Select
My devices
from the Bluetooth setting
options and press the
Select
soft key.
2. Press the
Select
soft key when
Search new
device
highlights.
If you have searched for devices before, the
phone displays the
More devices
option along
with the devices you have searched for
previously. To search for new devices, select the
More devices
option and press the
Select
soft
key.
If you want to stop searching, press the
Stop
soft key.
3. Scroll to a device and press the
Select
soft key
to connect to the paired device.
After searching for connectable devices, a list of
devices you can connect to displays. The icon on
the left of the device tells you the kind of device:
• for a handsfree or headset
• for a mobile phone
Settings
215
• for a computer
• for a PDA
• for an unknown device
Note
: The colour of the icon tells you the status of
the device; grey for unpaired devices, blue
for paired devices, and red for devices that
are currently connected to your phone.
4. Enter the PIN code and press the
OK
soft key.
Using device options
When you press the
Options
soft key on the device
list, you can access the following options:
Connect
: allows you to connect to the selected
device. You first need to enter your PIN (see
page 229) and then press the
OK
soft key. This
option is only available for headsets or handsfree
devices.
Browse files
: allows you to search for data from
other devices and take data directly to your phone.
Rename
: allows you to change the name of the
paired device.
Authorise device
/
Unauthorise device
: allows
you to set whether or not the phone asks you to
permit connection when other devices try to
connect to your phone.
Delete
: allows you to delete the device.
Delete all
: allows you to delete all of the devices.
Settings
216
Sending data via Bluetooth
1. Make sure that the Buletooth feature is active.
2. Select the application in which the item you
want to send is stored.
For example
: To send a photo to another device,
access the
Photos
menu (
Menu
8.3
).
3. Scroll to the item you want to send and press
the
Options
soft key.
4. Select
Send
and choose
via
Bluetooth
.
The phone searches for connectable devices
within range, when there is no paired devices.
After searching, a list of available devices
displays.
5. Scroll to a device and press the
Select
soft key.
6. If necessary, enter your PIN and press the
OK
soft key.
The data will be sent to that device.
Receiving data via Bluetooth
You can receive data from other people or you can
take data from other devices directly via Bluetooth.
To receive data, your phone’s Bluetooth feature
must be active.
Note
: When a Bluetooth device sends data to your
phone, the phone displays a confirmation
message if the other device is unauthorised
(see page 215). To receive data, press the
Yes
soft key.
Settings
217
Infrared activate
(Menu 9.6.2)
This feature allows you to send or receive data
through the infrared port. To use an infrared
connection, you must:
• configure and activate an IrDA-compliant infrared
port on another device.
• activate the infrared feature on the phone; the
IrDA icon ( ) appears on the top line of the
display.
• align the IrDA port on the phone with the IrDA
port on another device.
The connection is ready for data transmission.
If there is no communication between your phone
and the IrDA-compliant device within 60 seconds of
activating the feature, it is automatically
deactivated.
Note
: For optimal performance, use the data link cable
supplied with your phone.
IrDA port
IrDA port
Settings
218
Security
(Menu 9.7)
The Security feature enables you to restrict the use
of your phone by others and to restrict the types of
calls made.
Various codes and passwords are used to protect
the features of your phone. They are described in
the following sections. Also see pages 228-230.
PIN check
(Menu 9.7.1)
When the PIN Check feature is enabled, you must
enter your PIN each time you switch on the phone.
Consequently, any person who does not have your
PIN cannot use your phone without your approval.
Note
: Before disabling the PIN Check feature, you
must enter your PIN.
The following options are available:
Disable
: the phone connects directly to the
network when you switch it on.
Enable
: you must enter the PIN each time the
phone is switched on.
Change PIN
(Menu 9.7.2)
This feature allows you to change your current PIN
to a new one, provided that the PIN Check feature is
enabled. You must enter the current PIN before you
can specify a new one.
Once you have entered a new PIN, you are asked to
confirm it by entering it again.
Settings
219
Phone lock
(Menu 9.7.3)
When the Phone Lock feature is enabled, the phone
is locked and you must enter a 4- to 8-digit phone
password each time the phone is switched on.
The password is preset to “00000000” at the
factory. To change the phone password, see the
Change password
menu (
Menu 9.7.4
).
Once the correct password has been entered, you
can use the phone until you switch it off.
The following options are available:
Disable
: you are not asked to enter the phone
password when you switch on the phone.
Enable
: you are required to enter the phone
password when you switch on the phone.
Change password
(Menu 9.7.4)
The Change Password feature allows you to change
your current phone password to a new one. You
must enter the current password before you can
specify a new one.
The password is preset to “00000000” at the
factory. Once you have entered a new password,
you are asked to confirm it by entering it again.
Settings
220
Privacy
(Menu 9.7.5)
Using this menu, you can lock your media contents,
such as multimedia messages, e-mails, images,
videos, music files, and sounds. Once you have
locked the contents, you must enter the phone’s
password to access the associated menus.
When the phone asks for the password, enter the
password and press the
OK
soft key.
Note
: The password is preset to “00000000” at the
factory. To change this password, see
page 219.
SIM lock
(Menu 9.7.6)
When the SIM Lock feature is enabled, your phone
only works with the current SIM. You must enter
the SIM lock code to use a different SIM card.
Once you have entered the lock code, you are
asked to confirm it by entering it again.
To unlock the SIM, you must enter the SIM lock
code.
To Press the
select an item to
lock Up or Down key. To lock all
contents, select
All
.
place or remove a
check mark key.
lock the marked
items
Save
soft key.
Settings
221
FDN mode
(Menu 9.7.7)
FDN (Fixed Dial Number) mode, if supported by
your SIM card, allows you to restrict your outgoing
calls to a limited set of phone numbers.
The following options are available:
Disable
: you can call any number.
Enable
: you can only call phone numbers stored in
Phonebook. You must enter your PIN2.
Note
: Not all SIM cards have a PIN2. If your SIM card
does not, this menu does not display.
Change PIN2
(Menu 9.7.8)
The Change PIN2 feature allows you to change your
current PIN2 to a new one. You must enter the
current PIN2 before you can specify a new one.
Once you have entered a new PIN2, you are asked
to confirm it by entering it again.
Note
: Not all SIM cards have a PIN2. If your SIM card
does not, this menu does not display.
Settings
222
Memory status
(Menu 9.8)
You can check the amount of memory being used
for storing data in the menus.
Shared memory
(Menu 9.8.1)
You can check the used memory space for
Messages, Funbox, Organiser, Phonebook, and JAVA
world.
If your phone’s memory is full, you can select a
menu to open it immediately from this menu and
then delete some items to free up memory.
Messages
(Menu 9.8.2)
You can view the number of text messages you
have stored and the total number of text messages
you can store in the phone’s memory or on the SIM
card. You can also view the number of push
messages you have stored and the total number of
push messages you can store. Press the Up or
Down key to scroll through the screen.
If your message boxes are full, you can select a
message box to open it immediately from this menu
and then delete some items to free up memory.
Funbox
(Menu 9.8.3)
You can check the total and used memory space,
including how much space is currently occupied by
Image, Videos, Music, or Sounds. Press the Up or
Down key to scroll through the screen.
If your media boxes are full, you can select a menu
box to open it immediately from this menu and then
delete some items to free up memory.
Settings
223
Organiser
(Menu 9.8.4)
You can check the number of scheduled events you
have stored and the total number of events you can
store on your calendar, including how many events
are currently stored in each item. Press the Up or
Down key to scroll through the screen.
If your organiser memory is full, you can select an
event type to open it immediately from this menu
and then delete some events to free up memory.
Phonebook
(Menu 9.8.5)
You can check how may names and numbers are
stored in Phonebook. You can view the number of
entries you have stored and the total number of
entries you can store in the phone’s memory or on
the SIM card.
JAVA world
(Menu 9.8.6)
You can check the total and used memory space for
JAVA games.
Settings
224
Reset settings
(Menu 9.9)
Using this menu, you can reset the
Phone
settings
,
Display settings
, and
Sound settings
menus individually. You can also reset all the
settings in your phone at one time.
2. Press the
Select
soft key to reset the marked
items.
3. When a confirmation message appears, press
the
Yes
soft key.
4. Enter the 4- to 8-digit phone password and
press the
OK
soft key.
Note
: The password is preset to “00000000” at the
factory. To change this password, see
page 219.
1.
To Press the
select an item to
reset Up or Down key. To reset
all of the phone’s settings,
select
All
.
place or remove
a check mark key.
225
Solving problems
If you are experiencing problems with your phone,
perform the following simple checks, before
contacting a service professional. This may save
you the time and expense of an unnecessary
service call.
When you switch your phone on, the
following messages may appear:
Insert SIM card
• Check that the SIM card is correctly installed.
Phone locked enter password
• The automatic locking function has been enabled.
You must enter the phone’s password before you
can use the phone.
Enter PIN
• You are using your phone for the first time. You
must enter the Personal Identification Number
(PIN) supplied with the SIM card.
• The PIN Check feature is enabled. Every time the
phone is switched on, the PIN has to be entered.
To disable this feature, use the
PIN check
menu
(
Menu 9.7.1
).
Enter PUK
• The PIN code was entered incorrectly three times
in succession and the phone is now blocked.
Enter the PUK supplied by your service provider.
Solving problems
226
“No Service,” “Network Failure” or “Not
Done” displays
• The network connection has been lost. You may
be in a weak signal area (in a tunnel or
surrounded by buildings). Move and try again.
• You are trying to access an option for which you
have not taken out a subscription with your
service provider. Contact the service provider for
further details.
You have entered a number but it was
not dialled
• Have you pressed the key?
• Are you accessing the right cellular network?
• You may have set an outgoing call barring option.
Your correspondent cannot reach you
• Is your phone switched on (the key pressed
for more than one second)?
• Are you accessing the right cellular network?
• You may have set an incoming call barring option.
Your correspondent cannot hear you
speaking
• Have you switched off the microphone?
• Are you holding the phone close enough to your
mouth? The microphone is located at the bottom
of the phone.
Solving problems
227
The phone starts beeping and
“**Warning** Low Battery” flashes on
the display
• Your battery is insufficiently charged. Recharge
the battery.
The audio quality of the call is poor
• Check the signal strength indicator on the display
( ); the number of bars indicates the signal
strength from strong ( ) to weak ( ).
• Try moving the phone slightly or moving closer to
a window if you are in a building.
No number is dialled when you recall a
Contacts entry
• Check that the number has been stored correctly,
by using the Contacts Search feature.
• Re-store the number, if necessary.
If the above guidelines do not help you to solve
the problem, take note of:
• the model and serial numbers of your phone
• your warranty details
• a clear description of the problem
Then contact your local dealer or Samsung after-
sales service.
228
Access codes
There are several access codes that are used by
your phone and its SIM card. These codes help you
protect the phone against unauthorised use.
When requested for any of the codes explained
below, enter the appropriate code (displayed as
asterisks) and press the
OK
soft key. If you make a
mistake, press the
C
key one or more times until
the incorrect digit is cleared and then continue
entering the correct code.
The access codes, except for the PUK and PUK2
codes, can be changed using the
Security
menu
(
Menu 9.7
). See page 218 for further details.
Important!
Avoid using access codes resembling
emergency numbers, such as 112, so
that you do not accidentally dial an
emergency number.
Phone password
The Phone Lock feature uses the phone password to
protect your phone against unauthorised use. The
phone password is supplied with the phone and is
preset to “00000000” at the factory.
To See
activate/deactivate the
Phone Lock feature page 219 (
Menu 9.7.3
).
change the phone
password page 219 (
Menu 9.7.4
).
Access codes
229
PIN
The
P
ersonal
I
dentification
N
umber or PIN (4 to
8 digits) protects your SIM card against
unauthorised use. It is usually supplied with the
SIM card.
If you enter an incorrect PIN three times in
succession, the code is disabled and cannot be used
until you re-enable it by entering the PUK (see
below).
PUK
The 8-digit PUK (
P
IN
U
nblocking
K
ey) is required to
change a disabled PIN. The PUK may be supplied
with the SIM card. If not, or if you have lost it,
contact your service provider.
To re-enable your PIN:
1. Enter the PUK and press the
OK
soft key.
2. Enter a new PIN of your choice and press the
OK
soft key.
3. When the
Confirm New PIN
message displays,
enter the same code again and press the
OK
soft key.
If you enter an incorrect PUK ten times in
succession, the SIM card becomes invalid. Contact
your service provider for a new card.
To See
activate/deactivate the
PIN Check feature page 218 (
Menu 9.7.1
).
change the PIN page 218 (
Menu 9.7.2
).
Access codes
230
PIN2
The PIN2 (4 to 8 digits), supplied with some SIM
cards, is required to access specific functions, such
as setting the maximum cost of a call. These
functions are available if supported by your SIM
card.
If you enter an incorrect PIN2 three times in
succession, the code is disabled and you cannot
access the functions until you re-enable it by
entering the PUK2.
To change the PIN2, see page 221 (
Menu 9.7.8
).
PUK2
The 8-digit PUK2 (
P
IN
U
nblocking
K
ey
2
), supplied
with some SIM cards, is required to change a
disabled PIN2. If you lose the code, contact your
service provider.
To re-enable your PIN2:
1. Enter the PUK2 and press the
OK
soft key.
2. Enter a new PIN2 of your choice and press the
OK
soft key.
3. When the
Confirm PIN2
message displays,
enter the same code again and press the
OK
soft key.
If you enter an incorrect PUK2 ten times in
succession, you will not be able to access the
functions requiring the PIN2. Contact your service
provider for a new card.
Access codes
231
Barring password
A 4-digit barring password is required when you use
the Call Barring function. You can obtain the
password from your service provider when you
subscribe to this function.
You can change this password in the
Call
barring
menu (
Menu 9.5.2
). See page 208 for further
details.
232
Health and safety
information
125
Exposure to Radio Frequency (RF) Signals
Your wireless phone is a radio transmitter and receiver.
It is designed and manufactured not to exceed the
emission limits for exposure to radio frequency (RF)
energy set by the Federal Communications Commission
(FCC) of the U.S. Government. These limits are part of
comprehensive guidelines and establish permitted
levels of RF energy for the general population. The
guidelines are based on the safety standards that were
developed by independent scientific organizations
through periodic and through evaluation of scientific
studies.
The standards include a substantial safety margin
designed to assure the safety of all persons, regardless
of age and health.
The exposure standard for wireless phones employs a
unit of measurement known as Specific Absorption
Rate (SAR). The SAR limit set by the FCC is 1.6W/kg *.
*In the U.S. and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kg (W/kg)
averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give
additional protection for the public and to account for any variations in measurements.
SAR Values
1. Head : 0.920(W/kg)
2. Bady-worn : 0.215(W/kg)
Health and safety information
233
SAR tests are conducted using standard operating
positions with the phone transmitting at its highest
certified power level in all tested frequency bands.
Although the SAR is determined at the highest
certified power level, the actual SAR level of the
phone while operating can be well below the
maximum value. This is because the phone is
designed to operate at multiple power levels so as
to use only the power required to reach the
network. In general, the closer you are to a base
station, the lower the power output of the phone.
Before a new model phone is available for sale to
the public, compliance with the European R&TTE
Directive must be shown. This directive includes as
one of its essential requirements the protection of
the health and safety of the user and any other
person.
Precautions when using batteries
• Never use any charger or battery that is damaged
in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network’s base
station, it uses less power; talk and standby time
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
• Battery charging time depends on the remaining
battery charge, the type of battery and the
charger used. The battery can be charged and
discharged hundreds of times, but it will gradually
wear out. When the operation time (talk time and
Health and safety information
234
standby time) is noticeably shorter than normal,
it is time to buy a new battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not in use,
disconnect it from the power source. Do not leave
the battery connected to a charger for more than
a week, since overcharging may shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling or
warming first.
• Do not leave the battery in hot or cold places,
such as in a car in summer or winter conditions,
as you will reduce the capacity and lifetime of the
battery. Always try to keep the battery at room
temperature. A phone with a hot or cold battery
may temporarily not work, even when the battery
is fully charged. Li-ion batteries are particularly
affected by temperatures below 0 °C (32 °F).
• Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object (coin,
clip or pen) causes a direct connection between
the + and – terminals of the battery (metal strips
on the battery), for example when you carry a
spare battery in a pocket or bag. Short-circuiting
the terminals may damage the battery or the
object causing the short-circuiting.
• Dispose used batteries in accordance with local
regulations. Always recycle. Do not dispose of
batteries in a fire.
Health and safety information
235
Road safety
Your wireless phone gives you the powerful ability
to communicate by voice, almost anywhere,
anytime. But an important responsibility
accompanies the benefits of wireless phones, one
that every user must uphold.
When driving a car, driving is your first
responsibility. When using your wireless phone
behind the wheel of a car, make sure that you are
following the special regulations in a given area or
country.
Operating environment
Remember to follow any special regulations in force
in any area and always switch your phone off
whenever it is forbidden to use it, or when it may
cause interference or danger.
When connecting the phone or any accessory to
another device, read its user’s guide for detailed
safety instructions. Do not connect incompatible
products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation
of the equipment and for the safety of personnel, it
is recommended that the equipment should only be
used in the normal operating position (held to your
ear with the antenna pointing over your shoulder).
Health and safety information
236
Electronic devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against
the RF signals from your wireless phone. Consult
the manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be
maintained between a wireless phone and a
pacemaker to avoid potential interference with the
pacemaker. These recommendations are consistent
with the independent research and
recommendations of Wireless Technology Research.
Persons with pacemakers:
• Should always keep the phone more than 15 cm
(6 inches) from their pacemaker when the phone
is switched on
• Should not carry the phone in a breast pocket
• Should use the ear opposite the pacemaker to
minimise potential interference
If you have any reason to suspect that interference
is taking place, switch your phone off immediately.
Hearing aids
Some digital wireless phones may interfere with
some hearing aids. In the event of such
interference, you may wish to consult your hearing
aid manufacturer to discuss alternatives.
Health and safety information
237
Other medical devices
If you use any other personal medical devices,
consult the manufacturer of your device to
determine if it is adequately shielded from external
RF energy. Your physician may be able to assist you
in obtaining this information. Switch your phone off
in health care facilities when any regulations posted
in these areas instruct you to do so. Hospitals or
health care facilities may be using equipment that
could be sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle.
You should also consult the manufacturer of any
equipment that has been added to your vehicle.
Posted facilities
Switch your phone off in any facility where posted
notices require you to do so.
Health and safety information
238
Potentially explosive environments
Switch your phone off when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause
an explosion or fire resulting in bodily injury or even
death.
Users are advised to switch the phone off while at a
refuelling point (service station). Users are
reminded of the need to observe restrictions on the
use of radio equipment in fuel depots (fuel storage
and distribution areas), chemical plants or where
blasting operations are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
the areas below decks on boats, chemical transfer
or storage facilities, vehicles using liquefied
petroleum gas, such as propane or butane, areas
where the air contains chemicals or particles, such
as grain, dust or metal powders, and any other area
where you would normally be advised to turn off
your vehicle engine.
Health and safety information
239
Emergency calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well
as user-programmed functions, which cannot
guarantee connection in all conditions. Therefore,
you should never rely solely on any wireless phone
for essential communications (medical
emergencies, for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not
be possible on all wireless phone networks or when
certain network services and/or phone features are
in use. Check with local service providers.
To make an emergency call, proceed as follows.
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location (for example, 112 or any other official
emergency number). Emergency numbers vary
by location.
3. Press the key.
If certain features are in use (call barring, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult this document and your local cellular
service provider.
When making an emergency call, remember to give
all the necessary information as accurately as
possible. Remember that your phone may be the
only means of communication at the scene of an
accident; do not cut off the call until given
permission to do so.
Health and safety information
240
Other important safety information
• Only qualified personnel should service the phone
or install the phone in a vehicle. Faulty
installation or service may be dangerous and may
invalidate any warranty applicable to the device.
• Check regularly that all wireless phone equipment
in your vehicle is mounted and operating
properly.
• Do not store or carry flammable liquids, gases or
explosive materials in the same compartment as
the phone, its parts or accessories.
• For vehicles equipped with an air bag, remember
that an air bag inflates with great force. Do not
place objects, including both installed or portable
wireless equipment in the area over the air bag or
in the air bag deployment area. If wireless
equipment is improperly installed and the air bag
inflates, serious injury could result.
• Switch your phone off before boarding an aircraft.
The use of wireless phones in an aircraft may be
dangerous to the operation of the aircraft, and is
illegal.
• Failure to observe these instructions may lead to
the suspension or denial of telephone services to
the offender, or legal action, or both.
Health and safety information
241
Care and maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for
many years.
• Keep the phone and all its parts and accessories
out of the reach of small children.
• Keep the phone dry. Precipitation, humidity and
liquids contain minerals that corrode electronic
circuits.
• Do not use the phone with a wet hand. Doing so
may cause an electric shock to you or damage to
the phone.
• Do not use or store the phone in dusty, dirty
areas, as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the
phone, which may damage the phone’s electronic
circuit boards.
• Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the phone. Wipe it
with a soft cloth slightly dampened in a mild
soap-and-water solution.
Health and safety information
242
• Do not paint the phone. Paint can clog the
device’s moving parts and prevent proper
operation.
• Do not put the phone in or on heating devices,
such as a microwave oven, a stove or a radiator.
The phone may explode when overheated.
• Use only the supplied or an approved
replacement antenna. Unauthorised antennas or
modified accessories may damage the phone and
violate regulations governing radio devices.
• If the phone, battery, charger or any accessory is
not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
243
Glossary
To help you understand the main technical terms
and abbreviations used in this booklet, and to take
full advantage of the features of your mobile phone,
here are a few definitions:
Active folder
Ability to answer a call simply by opening the
phone.
Call barring
Ability to restrict outgoing and incoming calls.
Call diverting
Ability to reroute calls to another number.
Call holding
Ability to put one call on standby while answering or
making another call; you can then switch between
the two calls, as required.
Call waiting
Informs you that you have an incoming call when
you are engaged on another call.
Caller line identification services (Caller ID)
Services allowing subscribers to view or block the
telephone numbers of callers.
Glossary
244
EMS (Enhanced Message Service)
An adaptation of the Short Message Service (SMS)
that allows you to send and receive ring tones and
the service provider’s logo, as well as combinations
of simple media to and from EMS-compliant
handsets. Because EMS is based on SMS, it can use
SMS centres the same way that SMS does. EMS
works on all Global System for Mobile
communications (GSM) networks. EMS senders can
use text, melodies, photos, sounds, and animations
to enhance the expressive power of messages that
are limited by the display constraints of mobile
devices.
GPRS (General Packet Radio Service)
New non-voice value-added service that allows
information to be sent and received across a mobile
telephone network. GPRS provides continuous
connection to the Internet for mobile phone and
computer users. It is based on the Global System
for Mobile Communication (GSM) circuit-switched
cellular phone connections and the Short Message
Service (SMS).
GSM (Global System for Mobile
Communication)
International standard for cellular communication,
guaranteeing compatibility between the various
network operators. GSM covers most European
countries and many other parts of the world.
Glossary
245
Java
Programming language generating applications that
can run on all hardware platforms, whether small,
medium or large, without modification. It has been
promoted for and geared heavily to the Web, both
for public Web sites and Intranets. When a Java
program runs from a Web page, it is called a Java
applet. When it is run on a mobile phone or pager, it
is called a MIDlet.
MMS (Multimedia Message Service)
A message service for the mobile environment,
standardized by the WAP Forum and the 3rd
Generation Partnership Program (3GPP). For phone
users, MMS is similar to Short Message Service
(SMS)-it provides automatic, immediate delivery of
user-created content from phone to phone. The
message addressing used is primarily phone
numbers, thus the traffic goes from phone to
phone. MMS also provides support for e-mail
addressing, so that messages can be sent by e-
mail. In addition to the text content of SMS, MMS
messages can contain still images, voice or audio
clips, and also video clips and presentation
information.
Multi-party calling
Ability to establish a conference call involving up to
five additional parties.
Phone password
Security code used to unlock the phone when you
have selected the option to lock it automatically
each time it switches on.
Glossary
246
PIN (Personal Identification Number)
Security code that protects the phone against
unauthorised use. The PIN is supplied by the
service provider with the SIM card. It may be a four
to eight-digit number and can be changed, as
required.
Proxy server
A proxy server resides between a Web client, such
as a web browser, and a real Web server and acts
as an intermediary between them. When some
people browse a web site, their browser is not
actually connecting to the web server. The request
from their browser goes to a proxy server, and the
proxy server makes the request to the web server.
A proxy server can improve performance for groups
of users because it caches the results of all requests
for a certain amount of time. If a user requests a
web page that it already loaded for another user, it
reloads the page instead of forwarding the request
to the Web server, which can be a time-consuming
operation.
PUK (PIN Unblocking Key)
Security code used to unlock the phone when an
incorrect PIN has been entered three times in
succession. The eight-digit number is supplied by
the service provider with the SIM card.
Roaming
Use of your phone when you are outside your home
area (when travelling for example).
Glossary
247
SDN (Service Dialling Numbers)
Telephone numbers supplied by your network
provider and giving access to special services, such
as voice mail, directory inquiries, customer support
and emergency services.
SIM (Subscriber Identification Module)
Card containing a chip with all the information
required to operate the phone (network and
memory information, as well as the subscriber’s
personal data). The SIM card fits into a small slot
on the back of the phone and is protected by the
battery.
SMS (Short Message Service)
Network service sending and receiving messages to
and from another subscriber without having to
speak to the correspondent. The message created
or received can be displayed, received, edited or
sent.
Soft keys
Two keys marke
d
and on the phone, the
purpose of which:
• varies according to the function that you are
currently using.
• is indicated on the bottom line of the display just
above the corresponding key.
Glossary
248
Tri band
Ability to handle any of the following types of
network; GSM 900, GSM 1800, combined GSM 900/
1800 and GSM 1900 MHz bands, for greater call
success and wider roaming.
Your phone automatically searches for the last
network used. If, for any reason, this network is
unavailable, your phone will attempt to register
with a different network.
Uni-code encoding
A character coding system designed to support the
worldwide interchange, processing, and display of
the written text of the diverse languages and
technical disciplines of the world. Uni-code encoding
provides data transmission to any other platforms
without corruption, especially when you use special
Alphabet that are used for languages other than
English. Please refer to the following table for the
major characters requiring Uni-code encoding:
To change the character encoding type in your
phone, use the
Character support
menu. Keep in
mind that the maximum number of characters
which can be in a message will be reduced to
approximately half in length if you enter text using
Uni-code characters.
Glossary
249
Voice mail
Computerised answering service that automatically
answers your calls when you are not available,
plays a greeting (optionally in your own voice) and
records a message.
250
Index
A
Access codes •
228
Alarm •
92
Alphabet mode, text input •
38
Answering
call •
30
second call •
43
Anykey answer •
200
Auto redial •
200
B
Backlight
description •
16
time, set •
203
Band selection •
212
Barring, calls •
208
Battery
charging •
19
installing •
18
low indicator •
20
precautions •
233
removing •
17
Bluetooth
receiving, data •
216
sending, data •
216
settings •
213
talking on headset •
44
Broadcast messages •
152
Browser, WAP •
98
C
Calculator •
94
Call back, message •
110
,
123
Call costs •
62
Call records
dialled •
59
missed •
31
,
60
received •
60
Call time •
61
Caller group
creating •
68
managing •
70
Caller ID •
211
Calls
answering •
30
barring •
208
diverting •
207
ending •
24
holding •
42
making •
23
redialling •
24
rejecting •
30
transfering to
Bluetooth headset
•
44
waiting •
43
,
210
Camera
options •
185
,
190
CB (Cell Broadcast) messages
•
152
Characters, enter •
36
Charging battery •
19
Conference call •
48
Connect tone •
206
Conversion •
95
Cost, calls •
62
Creating
anniversaries •
170
events •
168
tasks •
171
D
Deleting
anniversaries •
176
call records •
58
miscellaneous items •
177
multimedia messages
•
122
,
125
,
127
phonebook •
65
scheduled events •
175
tasks •
179
text messages •
110
,
112
Delivery reports, message •
113
Index
251
Dialled calls •
59
Display
backlight •
16
icons •
14
layout •
13
settings •
201
Diverting, calls •
207
DTMF tones, send •
47
E
Earpiece volume •
29
E-mail messages
creating/sending •
133
reading •
137
,
141
setting •
144
Emergency calls •
239
EMS (Enhanced Message
Service) •
106
F
FDN (Fixed Dial Number)
mode •
221
Forwarding
e-mail messages •
140
multimedia messages
•
122
Funbox •
155
G
Greeting message •
198
H
Health and safety •
232
Holding, call •
42
I
Icons, description •
14
Images, downloaded •
155
Inbox, messages
e-mail •
137
multimedia •
120
text •
110
Infrared, connect •
217
International calls •
23
Internet •
98
K
Key volume •
29
Keypad tones
selecting •
204
sending •
46
Keys
description •
11
location •
10
L
Language, select •
198
Last number, redial •
24
Locking
media contents •
220
phone •
219
SIM card •
220
Loudspeaker •
43
Low battery indicator •
20
M
Memory status
camera •
154
downloaded items •
166
phonebook •
75
scheduled events •
181
Menus
accessing •
50
list •
52
Message tone •
204
Messages
cell broadcast •
152
e-mail •
133
greeting •
198
multimedia •
116
ring tone •
204
text •
106
voice •
151
Index
252
web •
150
Minute minder •
206
Missed alarm events •
179
Missed calls •
31
,
60
MMS (Multimedia Messages
Service) •
116
MP3 player •
84
Multimedia messages
deleting •
122
,
125
,
127
editing •
125
,
127
reading •
120
,
124
Multi-party calls •
48
Muting
all sounds •
32
key tones •
46
microphone •
45
My name card •
72
N
Names
entering •
36
Network band, select •
212
Network selection •
211
Network services •
207
O
Organiser •
167
Outbox, messages
e-mail •
141
multimedia •
124
text •
111
Own number •
73
P
Password
call barring •
231
phone •
219
,
228
Phone
care and maintenance
•
241
display •
13
icons •
14
keys •
11
layout •
10
locking •
219
password •
219
,
228
resetting •
224
switching on/off •
21
unpacking •
9
Phonebook
copying •
64
deleting •
64
editing •
64
managing •
73
options •
64
speed-dialling •
71
Photos
taking •
182
viewing •
192
PIN
changing •
218
description •
229
PIN2
changing •
221
description •
230
Power on/off tone •
205
Privacy •
220
Problems, solve •
225
PUK •
229
PUK2 •
230
R
Received calls •
60
Received messages
e-mail •
137
multimedia •
120
Recording
videos •
188
voice memos •
88
Redialling
automatically •
200
manually •
24
Resetting phone •
224
Ringer
incoming calls •
203
messages •
204
Road safety •
235
Roaming •
211
Index
253
S
Safety
information •
232
precautions •
7
Security, calls •
218
Sent messages
e-mail •
141
multimedia •
124
text •
111
SIM card
installing •
17
locking •
220
SMS (Short Message Service)
•
106
Soft keys •
34
Sound settings •
203
Sounds, downloaded •
163
Speed-dial •
71
Stopwatch •
97
Switching on/off
microphone •
45
phone •
21
T
T9 mode, text input •
38
Templates
multimedia •
128
Text input mode •
37
Text message
creating/sending •
107
deleting •
110
,
112
reading •
111
setting •
113
Text templates •
152
Text, enter •
36
Timer •
96
Tone
connect •
206
folder •
205
keypad •
204
message •
204
minute minder •
206
power on/off •
205
Travel adapter •
19
V
Videos
playing •
194
recording •
188
Voice clarity, microphone •
45
Voice mail •
151
Voice memos
playing •
90
recording •
88
Voicemail server •
151
Volume, adjust
earpiece •
29
keypad tone •
29
W
Waiting call •
43
,
210
WAP browser
access •
98
bookmarks •
101
cache, clear •
102
World time •
91
Writing messages
e-mail•
133
multimedia •
116
text •
107
254
255
Access
the menu
functions
➀
Press the
Menu
soft key.
➁
Scroll by pressing the
Navigation keys through
the list of the menus until
you reach the menu you
want.
➂
Press the
Select
soft key.
➃
Scroll by pressing the Up
and Down keys through
the list of the options until
the one you want is
selected.
➄
Press the
Select
soft key.
Each of the two soft keys (
and )
perform the function indicated by the text
above it, on the bottom line of the display.
Switch on/off Press and hold the
key.
Make a call
➀
Enter the number.
➁
Press the key.
End a call Briefly press the
key.
View missed
calls
immediately
after missing
them
➀
Open the phone and
press the
View
soft
key.
➁
Scroll by pressing the
Up and Down keys
through the missed
calls.
➂
To return the call, press
the key.
Answer a call Open the phone
or
Press the key.
Adjust the
volume Press the or key on
the left side of the phone.
SGH-D500 GPRS Telephone
Qnuick reference card
256
Store
numbers in
Phonebook
(continued)
➄
If necessary, change the
location number.
➅
Press the key.
Search for a
number in
Phonebook
➀
Press the
Contacts
soft
key.
➁
Enter the first few letters
of the name.
➂
To scroll through the
names, press the Up or
Down key.
➃
Press the key.
➄
To scroll through the
numbers, press the Up
or Down key.
➅
Press the key to dial.
Take a
➀
In Idle mode, press and
hold the Camera key.
➁
Press the key.
Play the
MP3 file(s)
➀
Access the
MP3 player
menu (
Menu 3.2
).
➁
Press the key.
Store
numbers in
Phonebook
• In the phone’s memory.
➀
Enter the number and
press the
Save
soft key.
➁
Select
Phone
.
➂
Select an icon.
➃
Scroll through the items
using the Up or Down key.
(Last name/First name/
Mobile/Home/Office/Fax/
Other/Email/Graphic ID/
Alert/Group/Notes)
➄
Enter information or press
the Left or Right key.
➅
Press the key.
• In the SIM card.
➀
Enter the number and
press the
Save
soft key.
➁
Select
SIM
.
➂
Enter the name and press
the Down key.
➃
If necessary, change the
phone number and press
the Down key.
Declaration of Conformity (R&TTE)
For the following product:
GSM900/GSM1800/GSM1900 Triband Digital
Portable Cellular Telephone
(Product Name)
SGH-D500
(Model Number)
Manufactured at:
Samsung Electronics Co., Ltd, 94-1 Imsu-Dong, Gumi City, Kyung Buk, Korea, 730-350
(factory name, address
*
)
to which this declaration relates, is in conformity with the following
standards and/or other normative documents.
Safety : EN 60950:2000
EMC : EN 301 489-01 v1.4.1 (2002-08)
EN 301 489-07 v1.2.1 (2002-08)
SAR : EN 50360:2001
EN 50361:2001
Network : EN 301 511 V9.0.2 (2003-03)
We hereby declare the [all essential radio test suites have been carried out
and that] the above named product is in conformity to all the essential
requirements of Directive 1999/5/EC.
The conformity assessment procedure referred to in Article 10 and detailed in
Annex[
IV
] of Directive 1999/5/EC has been followed with the involvement of
the following Notified Body(ies):
BABT, Claremont House, 34 Molesey Road,
Walton-on-Thames, KT12 4RQ, UK
Identification mark: 168
The technical documentation kept at:
Samsung Electronics Euro QA Lab.
which will be made available upon request.
(Representative in the EU)
Samsung Electronics Euro QA Lab.
Blackbushe Business Park, Saxony Way,
Yateley, Hampshire, GU46 6GG, UK
2003. 12. 11 In-Seop Lee / S. Manager
(place and date of issue) (name and signature of authorised person)
* This is not the address of the Samsung Service Centre. For the address or the phone
number of the Samsung Service Centre, see the warranty card or contact the retailer where
you purchased your phone.
