Samsung Electronics Co SGHD820 Dual-Band GSM/ EDGE Phone with Bluetooth User Manual 1 1 D820 RF block diagram
Samsung Electronics Co Ltd Dual-Band GSM/ EDGE Phone with Bluetooth 1 1 D820 RF block diagram
Users Manual
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-XXXXXA
English. 10/2005. Drf. 1.0
*
Depending on the software installed or your service provider or country,
some of the descriptions in this guide may not match your phone exactly.
* Depending on your country, your phone and accessories may appear
different from the illustrations in this guide.
SGH-D820
User’s Guide
Draft
2005. 10. 05
D820XAEG2
Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or illegal.
Drive safely at all times
Do not use a hand-held phone while driving. Park
the vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using them
in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.
Important safety precautions
1
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is forbidden
to use it, or when it may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear). Avoid
unnecessary contact with the antenna when the phone
is switched on.
Emergency call
Key in the emergency number for your present
location, then press .
Keep your phone away from small children
Keep the phone and all its parts, including accessories,
out of the reach of small children.
Accessories and batteries
Use only Samsung-approved accessories and
batteries. Use of any unauthorised accessories could
damage your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health and
safety information" on page 89.
• The phone could explode if the battery is
replaced with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.
2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone. To quickly
learn the basics for your phone, please refer to “Get
started” and “Step outside the phone.”
In this guide, the following instruction icons appear:
Indicates that you need to pay careful attention
to the subsequent information regarding safety or
phone features.
Indicates that you can get more information on
the referenced page.
→
Indicates that you need to press the Navigation
keys to scroll to the specified option and then
select it.
[
]
Indicates a key on the phone. For example,
[]
<
>
Indicates a soft key, whose function is displayed
on the phone screen. For example, <
Menu
>
• Camera and camcorder
Use the camera module on your
phone to take a photo or record a
video.
Special
features of your phone
• Phone to TV
View photos and video clips
captured with the phone on your
TV screen.
• Image editor
Crop, resize, rotate, and decorate
your photos.
•MP3 player
Play MP3 music files using your
phone as an MP3 player.
3
Special features of your phone
• File viewer
Open documents in various formats
on the phone without corruption.
•Bluetooth
Transfer media files and personal
data and connect to other devices
using free, wireless Bluetooth
technology. You can also use a
stereo Bluetooth headset to let you
enjoy music with high quality
stereo sound.
• Get personal with photo caller
ID
See who’s calling you when their
very own photo displays.
• Multimedia Message Service (MMS)
Deliver MMS messages with a combination of
text, images, video, and audio.
• Voice clarity
Use the voice clarity feature to increase the
volume and clarity of an incoming call, even in the
midst of a crowd.
•E-mail
Deliver e-mails with images, video, and audio
attachments.
•• Name card
Create name cards with your
number and profile. Whenever
introducing yourself to others, use
this convenient electronic name
card.
•Java
Enjoy Java
™
-based embedded
games and download new games.
4
Contents
Unpack 6
Make sure you have each item
Your phone 6
Buttons, features, and locations
Get started 7
First steps to operating your phone
Install and charge the phone..................................... 7
Power on or off........................................................ 8
Keys and display ..................................................... 9
Access menu functions ............................................ 11
Customise your phone............................................. 12
Make/Answer calls .................................................. 14
Step outside the phone 14
Begin with your camera, music, and other special features
Use the camera ...................................................... 14
Play MP3s.............................................................. 15
Browse the web...................................................... 16
Use Phonebook ...................................................... 17
Send messages...................................................... 18
View messages....................................................... 19
Use Bluetooth wirelsess........................................... 20
Use a memory card................................................. 21
Enter text 23
ABC, T9, Number, and Symbol modes
Call functions 25
Advanced calling features
Menu functions 29
All menu options listed
Solve problems 87
Help and personal needs
Health and safety information 89
Index 111
5
1 Call records
p.29
1 Recent contacts
2 Missed calls
3 Dialled calls
4 Received calls
5 Delete all
6 Call time
7 Call costs
*
p.29
p.30
p.30
p.30
p.30
p.30
p.31
2 Phonebook
p.31
1 Contact list
2 FDN list
3 Add new contact
4 Group
5 Speed dial
6 My name card
7 Own number
8 Management
9 Service number
*
p.31
p.32
p.32
p.33
p.34
p.34
p.35
p.35
p.35
3 Applications
p.36
1 MP3 Player
2 Voice recorder
3 Image editor
4 Java world
5 World time
6 Alarm
7 Calculator
8 Convertor
9 Timer
10 Stopwatch
11 SIM-AT
*
p.36
p.38
p.39
p.40
p.40
p.41
p.41
p.42
p.42
p.43
p.43
4 Browser
p.43
1 Home
2 Bookmarks
3 Go to URL
4 Clear cache
5 Profile settings
6 Current profile
p.43
p.44
p.45
p.45
p.45
p.46
5 Messages
p.46
1 Create new message
2 My messages
3 Templates
4 Delete all
5 Settings
6 Broadcast messages
7 Memory status
p.46
p.49
p.53
p.54
p.54
p.59
p.60
6 File manager
p.60
Images
Videos
Music
Sounds
Other files
Memory card
**
Memory status
p.60
p.62
p.63
p.63
p.64
p.66
p.66
7 Calendar
p.66
1 Month view
2 Week view
3 Day view
p. 66
p. 69
p. 69
8 Camera
p.70
1 Take a photo
2 Record video
3 Go to photos
4 Go to videos
p.70
p.73
p.75
p.76
9 Settings
p.76
1 Time & Date
2 Phone settings
3 Display settings
4 Sound settings
5 Network services
6 Bluetooth
7 Security
8 Memory status
9 Reset settings
10 Key management
p.76
p.76
p.78
p.79
p.80
p.83
p.85
p.86
p.86
p.87
* Shows only if supported by your
SIM card.
** Shows only if a memory card is
inserted into the phone.
Overview of menu functions
To access Menu mode, press <
Menu
> in Idle mode.
6
Unpack
Make sure you have each item
You can obtain various accessories from your local
Samsung dealer.
Phone Travel Adapter
Battery User’s Guide
The items supplied with your phone and the
accessories at your Samsung dealer may vary,
depending on your country or service provider.
Your phone
Buttons, features, and locations
Left soft key
Volume keys
Dial key
Special
function keys
Earpiece
Display
Power on/off/
Menu exit key
Alphanumeric
keys
Right soft key
Microphone
Navigation keys
(Up/Down/Left/
Right)
Web access/
Confirm key
Delete key Memory card slot
Camera lens
Headset/
Power jack
7
Get started
First steps to operating your phone
SIM card information
When you subscribe to a cellular network, you receive
a plug-in SIM (Subscriber Identity Module) card
loaded with your subscription details, such as your
PIN, and available optional services.
Install and charge the phone
Remove the battery
cover.
If the
phone is already
on, first turn it off by
holding [ ].
Insert the SIM card.
Make sure that the gold-
coloured contacts on the
card face down into the
phone.
Install the battery. Replace the battery
cover.
Plug the travel adapter into the phone.
Plug the adapter into a standard AC wall outlet.
8
Get started
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the battery low message displays, and
• the empty battery icon blinks.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
Power on or off
Keypad lock
When you close the phone, the keypad lock feature
locks the exposed keys so that nothing will happen if
the keys are accidentally pressed.
To unlock the keypad, press <
Unlock
> and press
<
OK
>.
When the phone is completely charged (the
battery icon becomes still), unplug the adapter
from the power outlet.
Remove the adapter from the phone.
Power on
Do not turn on
the phone when
mobile phone
use is prohibited.
1. Open the phone.
2. Press and hold
[]
to turn on
the phone.
3. If necessary, enter the PIN and
press <
OK
>.
Power off
1. Open the phone.
2. Press and hold
[]
.
9
Get started
Keys and display
Keys
Perform the function indicated on the
bottom line of the display.
In Idle mode, access menu options
directly.
p. 77
In Menu mode, scroll through the menu
options.
In Idle mode, launch the web browser.
In Menu mode, select the highlighted menu
option.
Send or answer a call.
In Idle mode, retrieve the recent numbers
dialled, missed, or received.
Delete characters from the display and
selected item in an application.
End a call. Press and hold to switch the
phone on and off.
In Menu mode, cancel input and return the
phone to Idle mode.
Enter numbers, letters, and some special
characters.
In Idle mode,
press and hold
[1]
to access
your voicemail.
Press and hold
[
0
] to enter
an international call prefix.
Enter special characters.
In Idle mode,
press and hold
[
]
to
activate or deactivate Quiet mode.
Press
and hold
[
]
to enter a pause between
numbers.
Adjust the phone volume.
In Idle mode, with the phone open, adjust
the keypad tone volume. With the phone
closed,
press and hold
to turn on the
display.
In Menu mode, scroll through the menu
options.
10
Get started
Display
Layout
The display has three areas.
Icons
*
Received signal strength
Call in progress
Out of your service area; you
cannot send or receive calls
Alarm set
New text message
New voicemail
New multimedia message
New e-mail
Text and graphics
displays messages,
instructions, and
information you enter.
Soft key function
indicators
shows the current
functions assigned to
the two soft keys.
Icons
displays various icons.
Menu Contacts
Icons
One of the message Inboxes is
full
Call diverting feature active
p. 80
Bluetooth feature is active
p. 83
Connected to Bluetooth
hands-free car kit or headset
Synchronised with a PC
GPRS network
Home Zone, if registered for the
appropriate service
Office Zone, if registered for the
appropriate service
Memory card inserted
Call ringer set to vibrate
p. 79
Quiet mode
p. 13
Battery power level
* Depending on your country or service provider, the
icons shown on the display may vary.
11
Get started
Access menu functions
Use the soft
keys
The roles of the soft keys vary
depending on the function you are
using. The bottom line of the
display indicates their current role.
Press the left soft
key to select the
highlighted
option.
Press the right soft
key to return to the
previous menu
level.
Select Back
Select an
option
1. Press the appropriate soft key.
2. Press the Navigation keys to
move to the next or previous
option.
3. Press <
Select
> or [ ] to
confirm the function displayed or
option highlighted.
4. To exit, choose either of the
following methods:
•Press <
Back
> to move up
one level.
• Press [ ] to return to Idle
mode.
Use shortcuts
Press the number key
corresponding to the option you
want.
12
Get started
Customise your phone
1. In Idle mode, press <
Menu
>
and select
Settings
→
Phone
settings
→
Language
.
2. Select a language.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Sound
settings
→
Incoming call
→
Ring tone
.
2. Select a ringtone category.
3. Select a ringtone.
4. Press <
Save
>.
Display
language
Call ringer
melody
You can set a wallpaper for the idle
screen.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Display
settings
→
Wallpaper
.
2. Select an image category.
3. Select an image.
You can change the colour for the
display components, such as title
bars and highlight bars.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Display
settings
→
Skin
.
2. Select a colour pattern.
Idle mode
Wallpaper
Menu mode
skin colour
13
Get started
You can set the Navigation keys as
shortcuts to access your favourite
menus.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Phone
settings
→
Short cut
.
2. Select a key.
3. Select a menu to be assigned to
the key.
You can switch the phone to Quite
mode to avoid disturbing other
people.
Press and hold [ ] in Idle mode.
Menu
shortcuts
Quiet mode
You can protect the phone against
unauthorised use with a phone
password. The phone will require
the password on power-up.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Security
→
Change
password
.
2. Enter the default password,
00000000
, and press <
OK
>.
3. Enter a new 4- to 8-digit
password and press <
OK
>.
4. Enter the new password again
and press <
OK
>.
5. Select
Phone lock
.
6. Select
Enable
.
7. Enter the password and press
<
OK
>.
Phone lock
14
Make/Answer calls
Step outside the phone
Begin with your camera, music, and other special features
Use the camera
1. Enter an area code and phone
number.
2. Press [ ].
3. To end the call, press [ ].
1. When the phone is ringing,
press [ ].
2. To end the call, press [ ].
Press [ / ].
Make a call
Answer a call
Adjust the
volume during
a call
1. Open the phone.
2. In Idle mode, press <
Menu
>
and select
Camera
→
Take a
.
3. Adjust the image by rotating
the camera lens and aiming it
at the subject.
4. Press [ ] to take a photo. The
photo is saved automatically.
5. Press <
Back
> to take another
photo.
Take a photo
15
Step outside the phone
Play MP3s
1. In Idle mode, press <
Menu
>
and select
Camera
→
Go to
photos
.
2. Select the photo you want.
1. In Idle mode, press <
Menu
>
and select
Camera
→
Record
video
.
2. Press [ ] to start recording.
3. Press the right soft key to stop
recording. The video is
automatically saved.
4. Press the right soft key to
record another video.
1. In Idle mode, press <
Menu
>
and select
Camera
→
Go to
videos
.
2. Select the video clip you want.
View a photo
Record a video
Play a video
Use these methods:
• Download from the wireless
web
p. 43
• Download from a computer using
Samsung PC Studio
Samsung
PC Studio User’s Guide
• Receive via Bluetooth
p. 83
• Copy files to a memory card and
insert the card into the phone
p. 21
1. In Idle mode, press <
Menu
>
and select
Applications
→
MP3 Player
.
2. Press <
Options
> and select
Open
→
Current album
.
3. Press <
Options
> and select
Add music from
→
Phone
or
Memory card
.
Copy MP3 files
to the phone
Create a play
list
16
Step outside the phone
Browse the web
Using a built-in web browser, you can get easy access
to the wireless web to get a variety of up-to-date
services and information and to enjoy downloads of
web content.
4. Press [ ] to select the files you
want and press <
Add
>.
5. Press <
Back
> to return to the
MP3 player screen.
1. From the MP3 player screen,
press
[]
.
2. During playback, use the
following keys:
•
:
pauses or resumes
playback.
• Up: opens the current play
list.
• Left: goes back to the
previous file. Goes backward
in a file when pressed and
held.
• Right: skips to the next file.
Goes forward in a file when
pressed and held.
•
/
: adjust the volume.
• Down: stops playback.
Play MP3 music
In Idle mode, press
[]
.
• To scroll through browser items,
press [Up] or [Down].
• To scroll page by page, press
[/
]
.
• To select an item, press < >.
• To return to the previous page,
press <
Back
> or [
C
].
• To return to the homepage, press
and hold [
C
].
• To use browser menu options,
select or press [ ].
Launch the
web browser
Navigate the
web
17
Step outside the phone
Use Phonebook
To the phone’s memory:
1. In Idle mode, enter a phone
number and press
[]
.
2. Select
Phone
→
a number type.
3. Specify the contact information:
First name, Last name, Mobile,
Home, Office, Fax, Other, Email,
Graphic ID, Alert, Group, and
Notes.
4. Press <
Save
>
to save the
entry.
To the SIM card:
1. In Idle mode, enter a phone
number and press
[]
.
2. Select
SIM
.
3. Enter a name.
4. Press
[]
to save the entry.
Add an entry
1. In Idle mode, press
<
Contacts
>.
2. Select an entry.
3. Scroll to a number and press
[ ] to dial, or [ ] to edit the
contact information.
1. In Idle mode, press <
Menu
>
and select
Phonebook
→
My
name card
.
2. Specify your contact
information.
3. Press <
Save
> to save the
name card.
4. To send the name card to other
people, press <
Options
> and
select
Send via
→
a sending
method.
Find an entry
Create and
send a name
card
18
Step outside the phone
Send messages
1. In Idle mode, press <
Menu
>
and select
Messages
→
Create
new message
→
Text
message
.
2. Enter the message text and
press
[]
.
3. Enter destination numbers.
4. Press
[]
.
1. In Idle mode, press <
Menu
>
and select
Messages
→
Create
new message
→
Multimedia
message
.
2. Select
Subject
.
3. Enter the message subject and
press
[]
.
4. Select
Picture & Video
or
Sound
.
Send a text
message (SMS)
Send a
multimedia
message
(MMS)
5. For
Picture & Video
, select
Pictures
or
Videos
and add an
image or video clip.
For
Sound
, select a sound
category and add a sound clip.
6. Select a media file and press
<
Add
>.
7. Select
Message
.
8. Enter the message text and
press
[]
.
9. Press <
Options
> and select
Send
.
10.Enter destination numbers or
e-mail addresses.
11.Press
[]
.
19
Step outside the phone
View messages
1. In Idle mode, press <
Menu
>
and select
Messages
→
Create
new message
→
Email
.
2. Select
Subject
.
3. Enter the e-mail subject and
press
[]
.
4. Select
Message
.
5. Enter the e-mail text and press
[]
.
6. Select
File attach
.
7. Add image, video, sound, music
files, or document files.
8. Press <
Options
> and select
Send
.
9. Enter e-mail addresses.
10.Press
[]
.
Send an e-mail
When a notification appears:
1. Press <
View
>.
2. Select the message from the
Inbox.
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messages
→
My
messages
→
Inbox
.
2. Select the text message ( ).
When a notification appears:
1. Press <
View
>.
2. Select the message from the
Inbox.
View a text
message
View a
multimedia
message
20
Step outside the phone
Use Bluetooth wirelsess
Your phone is equipped with Bluetooth technology
which enables you to connect the phone wirelessly to
other Bluetooth devices and exchange data with them,
talk hands-free, or control the phone remotely.
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messages
→
My
messages
→
Inbox
.
2. Select the MMS message ( ).
1. In Idle mode, press <
Menu
>
and select
Messages
→
My
messages
→
Email
box
.
2. Select
Check new mail
.
3. Select an e-mail or header.
4. If you selected a header, press
<
Options
> and select
Retrieve
.
View an e-mail
In Idle mode, press <
Menu
> and
select
Settings
→
Bluetooth
→
Activation
→
On
.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Bluetooth
→
My devices
→
Search new device
.
2. Select a device.
3. Enter a Bluetooth PIN or the
other device’s Bluetooth PIN, if
it has one, and press <
OK
>.
When the owner of the other
device enters the same code,
the pairing is complete.
Turn on
Bluetooth
Search for and
pair with a
Bluetooth
device
21
Step outside the phone
Use a memory card
You can use a memory card to enlarge your phone’s
capacity.
1. Access an application,
Phonebook
,
File manager
, or
Calendar
.
2. Select the item you want to
send.
3. Press <
Options
> and select
Send
via
→
Bluetooth
.
4. Select a device.
5. If necessary, enter the
Bluetooth PIN and press <
OK
>.
To receive data via Bluetooth, your
phone’s Bluetooth feature must be
active.
If necessary, press <
Yes
> to
confirm the reception.
Send data
Receive data
• Frequent erasing and writing will
shorten a memory card’s lifespan.
• Do not remove a memory card
from the phone or turn off the
phone while data is being accessed
or transferred. This could result in
loss of data and/or damage to the
card or phone.
• Do not subject memory cards to
strong shocks.
• Do not touch memory card
terminals with your fingers or
metal objects. If dirty, wipe the
card with a soft cloth.
• Keep memory cards away from
small children or pets.
• Do not expose memory cards in a
place subject to electro static
discharge and/or electrical noise.
Important
memory card
information
22
Step outside the phone
1. Slide a memory card into the
memory card slot, with the
label side face down.
2. Press the card until it locks into
place.
1. Press the memory card so that
it is disengaged from the
phone.
2. Slide the card out of the slot.
Insert a
memory card
Remove the
memory card
Using a card adapter and a USB
card reader/writer, you can read
the card on a PC.
1. Insert a memory card into a
card adapter, and then the
adapter into a card
reader/writer.
2. Plug the USB connector of the
card reader/writer into the USB
port on your PC.
3. Access the appropriate memory
disk and copy to and from the
card.
Use a card
adapter
If a file name is more than 51
characters, the file will not
display on the phone.
23
Enter text
ABC, T9, Number, and Symbol modes
You can enter text for some features such as
messaging, Phonebook, or Calendar, using ABC mode,
T9 mode, Number mode, and Symbol mode.
Changing the text input mode
The text input mode indicator displays when the
cursor is in a text field.
• Press and hold [ ] to switch between T9 ( )
and ABC ( ) modes.
• Press [ ] to change case ( / / ) or
to switch to Number mode ( ).
• Press and hold [ ] to switch to Symbol mode
().
Using ABC mode
Press the appropriate key until the character you want
appears on the screen.
(creating an SMS message with GSM-alphabet encoding)
Key Characters in order displayed
Upper case Lower case
1
. , - ? ! ’ @ : 1
2
A B C 2 a b c 2
3
D E F 3 d e f 3
4
G H I 4 g h i 4
5
J K L 5 j k l 5
6
M N O 6 m n o 6
7
P Q R S 7 p q r s 7
8
T U V 8 t u v 8
9
W X Y Z 9 w x y z 9
0
0
24
Enter text
Tips for using ABC mode
• To enter the same letter twice or to enter a
different letter on the same key, wait for the cursor
to move to the right automatically or press [Right].
Then, enter the next letter.
• Press [ ] to insert a space.
• Press the Navigation keys to move the cursor.
•Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
Using T9 mode
T9 is a predictive text input mode that allows you to
key in any character using single keystrokes.
Entering a word in T9 mode
1. Press [
2
] to [
9
]
to start entering a word. Press
each key once for each letter.
For example, press [
4
], [
3
], [
5
], [
5
], and [
6
] to
enter HELLO in T9 mode.
T9 predicts the word that you are typing, and it
may change with each key that you press.
2. Enter the whole word before editing or deleting
characters.
3. When the word displays correctly, go to step 4.
Otherwise, press [
0
] to display alternative word
choices for the keys that you have pressed.
For example, OF and ME use [
6
] and [
3
].
4. Press [ ] to insert a space and enter the next
word.
Tips for using T9 mode
• Press [
1
] to enter periods or apostrophes
automatically.
• Press the Navigation keys to move the cursor.
• Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
Adding a new word to the T9 dictionary
This feature may not be available for some languages.
1. Enter the word that you want to add.
2. Press [
0
] to display alternative words for your key
presses. When there are no more alternative
words,
Spell
displays on the bottom line.
3. Press <
Spell
>.
25
4. Enter the word you want using ABC mode and
press <
Add
>.
Using Number mode
Number mode enables you to enter numbers.
Press the keys corresponding to the digits you want.
Using Symbol mode
Symbol mode enables you to insert symbols.
Call functions
Advanced calling features
Making a call
1. In Idle mode, enter the area code and phone
number.
2. Press [ ].
Making an international call
1. In Idle mode, press and hold [
0
]. The + character
appears.
2. Enter the country code, area code, and phone
number, then press [ ].
To Press
display more symbols [Up] or [Down].
select a symbol the corresponding
number key.
clear the symbol(s) [
C
].
insert the symbol(s) <
OK
>.
• Press [
C
] to clear the last digit or press and hold
[
C
] to clear the whole display. You can move the
cursor to edit an incorrect digit.
• Press and hold
[ ] to enter a pause between
numbers.
26
Call functions
Redialling recent numbers
1. In Idle mode, press [ ] to display the list of
recent numbers.
2. Scroll to the number you want and press [ ].
Making a call from Phonebook
Once you have stored a number in Phonebook, you
can dial the number by selecting it from
Phonebook.
p. 31
You can also use the speed dial feature to assign your
most frequently called numbers to specific number
keys.
p. 34
You can quickly dial a number from the SIM card using
the location number assigned when stored.
1. In Idle mode, enter the location number for the
phone number you want and press [ ].
2. Press [Left] or [Right] to scroll through other
numbers.
3. Press <
Dial
> or [ ] to dial the number you want.
Ending a call
Close the phone or press [ ].
Answering a call
When you receive an incoming call, the phone rings
and displays the incoming call image.
Press [ ] or <
Accept
> to answer the call.
Tips for answering a call
• When
Anykey
answer
is active, you can press
any key to answer a call, except for [ ] and
<
Reject
>.
p. 78
• Press <
Reject
> or [ ] to reject a call.
• Press and hold [ / ] to reject a call or mute the
ringer, depending on the
Volume key
setting.
p. 77
Viewing missed calls
If you have missed calls, the screen displays how
many calls you have missed.
1. Press <
View
>.
2. If necessary, scroll through the missed calls.
3. Press [ ] to dial the number you want.
Call functions
27
Using the headset
Use the headset to make or answer calls without
holding the phone.
Connect the headset to the jack on the right side of
the phone.
The button on the headset works as listed below:
Options during a call
You can access a number of functions during a call.
Adjusting the volume during a call
Use [/] to adjust the earpiece volume during a
call.
Press [ ] to increase the volume level and [ ] to
decrease the volume level.
Placing a call on hold/Retrieving
Press <
Hold
> or <
Retrieve
> to place the call on hold
or retrieve the call.
Making a second call
You can make another call if your network supports it.
1. Press <
Hold
> to put the call on hold.
2. Make the second call in the normal way.
3. Press <
Swap
> to switch between the calls.
4. Press <
Options
> and select
End
held
call
to end
the call on hold.
5. To end the current call, press [ ].
Answering a second call
You can answer an incoming call while already on the
phone, if your network supports it and you have
activated the call waiting feature.
p. 82
1. Press [ ] to answer the call. The first call is
automatically put on hold.
2. Press <
Swap
> to switch between the calls.
To Press
redial the last call the button twice.
answer a call and hold the button.
end a call and hold the button.
28
Call functions
Using the Speakerphone feature
Use the Speakerphone feature to talk and listen with
the phone a short distance away.
Press [ ] to activate the Speakerphone feature. Press
the key again to switch back to the earpiece.
Using In-call options
Press <
Options
> to access the following options
during a call:
•
Voice clarity on
/
Voice clarity off
: remove
extraneous noise and increase call quality so that
the person with whom you are speaking can hear
you clearly even if you are in a noise place.
•
Mute
/
Unmute
: switch off the phone's microphone
so that the other person on the phone cannot hear
you, or switch it back on.
•
Mute keys
/
Send keys
: switch the key tones on
or off.
•
Phonebook
: access the contact list.
•
Send DTMF
: send the DTMF (Dual tone multi-
frequency) tones as a group. The DTMF tones are
the tones used in phones for tone dialling,
sounding when you press the number keys. This
option is helpful for entering a password or an
account number when you call an automated
system, like a banking service.
•
Message
: read an incoming message and send a
new message.
p. 46
•
Join
: set up a multi-party call by adding a caller
on hold to a currently active call. You can include
up to five people on a multi-party call.
•
Split
: have a private conversation with one multi-
party call participant. The other participants can
converse with each other. After the private
conversation, select
Join
to return to the
multi-party call.
•
Transfer
: transfer the currently active call to a
caller on hold. The two callers can talk to each
other, but you are disconnected from the call.
To communicate with answering machines or
computerised telephone systems,
Send keys
must be selected
.
29
•
Remove
: disconnect one multi-party call
participant.
•
End held call
: disconnect the call currently on
hold.
•
SIM service
: access special services, such as
news, weather forecasts, entertainment, and
location services, provided by your SIM card. This
option is available when you use a SIM card
supporting SIM AT menus.
•
Switch to headset
/
Switch to phone
: switch the
call to a Bluetooth headset or hands-free car kit or
back to the phone.
Menu functions
All menu options listed
Call records
(Menu 1)
Use this menu to view the calls you have dialled,
received, or missed, and the length of your calls. You
can also check the cost of your calls, if the SIM card
supports this function.
To access this menu, press <
Menu
> in Idle mode and
select
Call records
.
Recent contacts
(Menu 1.1)
This menu displays the most recent calls dialled,
received, or missed.
Accessing a call record
1. Press [Left] or [Right] to select a call type.
2. Press [Up] or [Down] to scroll through the call list.
3. Press [ ] to dial a number, or [ ] to view the
details of a call.
30
Menu functions
Using call record options
While viewing call details, press <
Options
> to access
the following options:
•
Save as contacts
: save the number in
Phonebook.
•
Send message
: send an SMS or MMS message.
•
Delete
: delete the selected call record or all
records.
Missed calls
(Menu 1.2)
This menu displays the most recent received calls that
you did not answer.
Dialled calls
(Menu 1.3)
This menu displays the most recent calls you have
dialled.
Received calls
(Menu 1.4)
This menu displays the most recent calls you have
received.
Delete all
(Menu 1.5)
Use this menu to delete all of the records in each call
type.
1. Press [ ] to check the call types to clear.
2. Press <
Delete
>.
3. Press <
Yes
> to confirm the deletion.
Call time
(Menu 1.6)
This menu displays the time log for calls made and
received. The actual time invoiced by your service
provider will vary.
•
Last
call
time
: check the length of your last call.
•
Total
sent
: check the total length of all the calls
you have dialled.
•
Total
received
: check the total length of all the
calls you have received.
•
Reset
timers
: reset the call timers. You need to
enter the phone password.
The password is preset to
00000000
. You can
change this password.
p. 86
Menu functions
Phonebook
(Menu 2)
31
Call costs
(Menu 1.7)
This network feature displays the cost of calls. This
menu is available only if your SIM card supports this
feature. Note that this is not intended to be used for
billing purposes.
•
Last
call
cost
: check the cost of your last call.
•
Total
cost
: check the total cost of all your calls. If
the total cost exceeds the maximum cost set in
Set
max
cost
, you must reset the counter before
you can make another call.
•
Max
cost
: check the maximum cost limit set in
Set
max
cost
.
•
Reset
counters
: reset the cost counters.
•
Set
max
cost
: set the maximum cost authorised
for your calls.
•
Price/Unit
: set the price per unit that is applied
when the cost of your calls is calculated.
Phonebook
(Menu 2)
You can store phone numbers on your SIM card and in
your phone’s memory. The SIM card and phone’s
memory are physically separate, but they are used as
a single entity called Phonebook.
To access this menu, press <
Menu
> in Idle mode and
select
Phonebook
.
Contact list
(Menu 2.1)
Use this menu to search for numbers in Phonebook.
Finding an entry
1. Enter the first few letters of the name that you
want to find.
2. Select the name you want from the list.
3. Scroll to a number and press [ ] to dial, or [ ]
to edit the contact information.
Using Phonebook options
While viewing contact details, press <
Options
> to
access the following options:
•
Edit
: edit the contact information.
32
Menu functions
•
Send message
: send an SMS, MMS, or e-mail
message to the selected number.
•
Copy
: copy the number to the phone’s memory, to
SIM card, or to FDN list.
•
Send via
: send the contact via SMS, MMS, e-mail,
or Bluetooth.
•
Delete
: delete the selected entry.
•
Print via Bluetooth
: print the contact information
by connecting the phone to a printer via Bluetooth.
FDN list
(Menu 2.2)
Use this menu to create a list of contacts to be used in
FDN (Fixed Dialling Number) mode, in which the
phone allows outgoing calls only to the specified
phone numbers, if your SIM card supports this
feature. You can activate FDN mode in the
FDN mode
menu.
p. 86
Adding a contact
1. From the FDN list, press <
Options
> and select
Add
.
2. Enter your PIN2 and press <
OK
>.
3. Enter information about the contact:
•
Name
: assign a name.
•
Phone number
: add a number.
•
Location
: assign a location number.
4. Press <
Save
>.
Using contact options
You can access contact options by pressing
<
Options
> in Contact list.
Add new contact
(Menu 2.3)
Use this menu to add a new contact to Phonebook.
Storing a number in the phone’s memory
1. Select
Phone
.
2. Change the settings or enter information about the
contact:
•
First name
/
Last name
: assign a name.
•
Mobile
/
Home
/
Office
/
Fax
/
Other
: add a
number in any category.
•
Email
: assign an e-mail address.
Menu functions
Phonebook
(Menu 2)
33
•
Graphic ID
: assign an image or a video clip as
a caller ID image to alert you to a call from the
person.
•
Alert
: assign a unique ringtone to alert you to
a call from the person.
•
Group
: assign the number to a caller group.
•
Notes
: add a memo about the person.
3. Press <
Save
> to save the contact.
Storing a number on the SIM card
1. Select
SIM
.
2. Enter information about the contact:
•
Name
: assign a name.
•
Phone number
: add a number.
•
Location
: assign a location number.
3. Press <
Save
> to save the contact.
Group
(Menu 2.4)
Use this menu to organise your contacts in caller
groups.
Adding members to a caller group
1. Select a group.
2. Press <
Add
>.
3. Press [ ] to check the contacts you want.
4. Press <
Add
>.
Managing caller groups
While viewing the group list, press <
Options
> to
access the following options:
•
View
: access the members of the selected group.
•
Add
: add a new group.
•
Edit
: change the properties of the selected group.
•
Send message
: send an SMS, MMS, or e-mail
message to the members you want.
•
Delete
: delete the selected group. Group
members, however, will not be deleted from
Phonebook.
The settings specified in
Graphic ID
and
Alert
are given priority over group settings.
To assign a caller ID image, ringtone, or group, the
contact must be saved to the phone’s memory.
34
Menu functions
Speed dial
(Menu 2.5)
Use this menu to assign speed dial numbers (2 to 9)
for eight of your most frequently called numbers.
Assigning speed dial entries
1. Select a key location from
2
to
9
. Key
1
is reserved
for your voice mail server.
2. Select the contact you want from the contact list.
3. Scroll to a number, if it has more than one number.
4. Press <
Select
>.
Managing speed dial entries
While viewing the Speed dial screen, press
<
Options
> to access the following options:
•
Add
: assign a number to an unassigned key. You
can select a contact from Phonebook or the FDN
list.
•
View
: display the number assigned to the key.
•
Change
: assign a different number to an assigned
key.
•
Remove
: clear the speed dial setting.
Dialling speed dial entries
In Idle mode, press and hold the appropriate key.
My name card
(Menu 2.6)
Use this menu to create a name card and send it to
other people.
Saving your name card
The procedure for creating your name card is the
same as the one for saving a number in the phone’s
memory.
p. 32
Using name card options
After saving your name card, press <
Options
> to
access the following options:
•
Edit
: edit the name card.
•
Send via
: send the name card via SMS, MMS,
e-mail, or Bluetooth.
•
Exchange namecard
: exchange the name card
with another person’s name card via Bluetooth.
•
Remove
: remove the name card information.
Menu functions
Phonebook
(Menu 2)
35
•
Print via Bluetooth
: print the name card
information by connecting the phone to a printer
via Bluetooth.
Own number
(Menu 2.7)
Use this feature to check your phone numbers, or to
assign a name to each of the numbers.
Changes made here do not affect the actual subscriber
numbers on your SIM card.
Management
(Menu 2.8)
Use this menu to manage Phonebook.
•
Default saving
: select a default memory location
for saving contacts. If you select
Ask on saving
,
the phone will ask you to select a memory location
each time you save a number.
•
Copy all to phone
: copy all of the contacts stored
on the SIM card to the phone’s memory.
•
Sort by contacts
: sort your contacts by the first
name or last name.
•
Delete all
: delete all of the contacts from your
phone’s memory, your SIM card, or the FDN list.
•
Memory status
: display the number of contacts
you have stored in Phonebook.
Service number
(Menu 2.9)
Use this menu to view the list of Service Dialling
Numbers (SDN) assigned by your service provider,
including emergency numbers and numbers for
directory enquiries. This menu is available if your SIM
card supports SDN.
1. Scroll to the number you want and press <
View
>.
2. Press <
Dial
> or [ ].
36
Menu functions
Applications
(Menu 3)
Use this menu to play Java games, play MP3 music
files, or edit photos. You can also use convenient
features, such as a voice recorder, alarm clock,
calculator, converter, and stopwatch.
To access this menu, press <
Menu
> in Idle mode and
select
Applications
.
MP3 Player
(Menu 3.1)
Use this menu to enjoy music. First, you need to save
music files in your phone’s memory or a memory card.
To enjoy high quality music, you can use an optional
Bluetooth stereo headset.
Downloading or receiving music files
Use these methods to save music files to your phone:
• Download from the wireless web
p. 43
• Download from a computer using the Samsung PC
Studio programme
Samsung PC Studio User’s
Guide
• Receive via Bluetooth
p. 83
• Copy files to a memory card and insert the card
into the phone.
Creating a play list
Add the music files to the play list so you can play
them.
1. From the MP3 player screen, press <
Options
>
and select
Open
→
Current album
.
2. Press <
Options
> and select
Add music from
→
Phone
or
Memory card
.
3. Press [ ] to select the files you want and press
<
Add
>.
4. Press <
Back
> to go back to the MP3 player
screen.
Playing music files
1. From the MP3 player screen, press <
Options
>
and select
Play via
.
2. Select
Phone
to use the phone speaker.
Select
A/V headset
to use a Bluetooth headset
and then search for and connect to the headset.
Normal headsets are not compatible with the MP3
player.
Menu functions
Applications
(Menu 3)
37
During playback, you can use the following keys:
Using MP3 player options
From the MP3 player screen, press <
Options
> to
access the following options:
•
Play
/
Pause
: begin or pause playback.
•
Play via
: select a sound output mode,
Phone
or
A/V headset
.
•
Open
: access the current play list or album list.
•
Send via
: send the file via e-mail or Bluetooth.
•
Set as
: set the file as your ringtone, as a ringtone
for a Phonebook entry, or alarm melody.
•
Remove from play list
: remove the selected file
from the play list.
Key Function
Pauses or resumes playback.
Up Opens the current play list.
Left Goes to the previous file. Moves
backward in a file when pressed and
held.
Right Skips to the next file. Skips forward
in a file when pressed and held.
/ Adjusts the volume.
1
Changes the equaliser mode.
2
Changes the playback animation.
3
Changes the repeat mode.
4
Turns 3D sound on or off.
5
Changes the skin image.
6
Sets the MP3 player to play music at
random.
7
Repeats a section of your choice.
Pressing this key begins a search for
the starting point. To search for the
end point, press this key again. To
stop repeating, press this key.
Down Stops playback.
Key Function
38
Menu functions
•
Settings
: change the default settings for playing
music files.
Repeat
: select a repeat mode.
Shuffle
: set the MP3 player to play music at
random.
Equalize
: change the equaliser setting.
3D sound
: turn 3D sound on or off
Visualization
: change the playback animation.
MP3 skin
: select a skin type
Volume
: select a volume level.
•
Properties
: access the file properties.
Accessing the play list
From the MP3 player screen, press [Up].
Press <
Options
> to access the following options:
•
Play
: play the currently selected file.
•
Add music from
: add files to the play list.
•
Go to album list
: access the album list.
•
Move to
: move the selected file to another play
list.
•
Copy to
: copy the selected file to another play list.
•
Change order
: move the selected file to the
position you want within the play list.
•
Remove
: remove the selected file or all files from
the play list.
•
Properties
: access the file properties.
Voice recorder
(Menu 3.2)
Use this menu to record voice memos. A voice memo
can be up to one hour long.
Recording a voice memo
1. Press [ ] to start recording.
2. Speak into the microphone.
Press [ ] to pause or resume the recording.
3. When you have finished, press <
Save
> or
[Down]. The voice memo is automatically saved.
4. Press [ ] to review the voice memo.
Playing a voice memo
1. From the Voice record screen, press <
Options
>
and select
Go to voice list
.
2. Select a voice memo. The memo plays.
Menu functions
Applications
(Menu 3)
39
During playback, use the following keys:
Changing the voice recorder settings
You can change the recording settings for the voice
recorder. Before recording a voice memo, press
<
Options
> and select
Settings
to access the
following options:
•
Recording time
: select a recording time.
1 hour
: record a voice memo of up to one hour.
Limit of MMS
: record a voice memo for adding to
an MMS message.
•
Volume
: select a volume level.
•
Default name
: change the default prefix of the
voice memo.
•
Visualization
: select an equalizer image.
Image editor
(Menu 3.3)
Use this menu to edit your photos using various
editing tool options.
1. Press <
Options
> and select
New image
→
Open
or
Take a photo
2. Select a photo or take a new photo.
3. Press <
Options
> to access the following options
and edit the photo:
•
Effects
: change the colour tone or apply a
special effect to the photo.
•
Adjust
: adjust the image brightness, contrast,
or colour balance.
•
Transform
: rotate or flip the photo.
•
Insert
: add a decorative frame, an emoticon,
or a clip art to the photo.
•
Undo
: cancel your selection.
4. When you have finished, press <
Options
> and
select one of the following options:
•
Save as
: save the file as a different name.
Key Function
Pauses or resumes playback.
Left Goes backward in a memo.
Right Skips forward in a memo.
/ Adjusts the volume.
Down Stops playback.
40
Menu functions
•
Set as
: set the file as your wallpaper or as a
caller ID image for a Phonebook entry.
•
Send via
: send the file via MMS, e-mail, or
Bluetooth.
•
Print via
: print the file by connecting the
phone to a printer via USB or Bluetooth.
Java world
(Menu 3.4)
Use this menu to access the default Java games and
downloaded Java applications.
Playing a default game
1. Select a game.
2. Press any key except [ ] to launch the game.
3. Follow the onscreen instructions.
Using Java game options
From the game list, press <
Options
> to access the
following options:
•
Start
: launch the selected game.
•
Delete
: delete the game.
•
Properties
: access the game properties.
•
Permission
: set permission settings for services
charging you additional costs, such as network
access and SMS.
•
Upgrade
: upgrade the application to the latest
version.
•
Send information via SMS
: send the URL
containing the application via SMS.
•
Memory status
: access memory information for
applications.
•
Network settings
: select a connection profile to
be used for applications requiring network access.
You can also add or edit a profile.
p. 45
World time
(Menu 3.5)
Use this menu to set your local time zone and find out
what time it is in another part of the world.
Viewing world time
1. From the world map, press [Left] or [Right] to
select the foreign time zone you want to view.
2. To set another time zone, press [Down].
Menu functions
Applications
(Menu 3)
41
3. Press [Left] or [Right] to select the time zone you
want to view.
4. Press [ ].
Applying Daylight Savings Time
1. From the world map, press <
Options
> and select
Set daylight saving time
.
2. Press [ ] to check the time zones you want.
3. Press <
Save
>.
Alarm
(Menu 3.6)
Use this menu to set alarms. The alert type for a
normal alarm corresponds to the call alert type
settings. A wake up alarm is not affected by your
sound settings.
Setting an alarm
1. Select the type of alarm.
2. Select an alarm option.
•
Alarm
: activate the alarm.
•
Alarm time
: enter the time for the alarm to
ring.
•
AM/PM
: set
AM
or
PM
in 12-hour format.
•
Alarm day
: check the days for the alarm.
•
Alarm tone
: select an alarm tone.
3. Press <
Save
>.
Stopping an alarm
• For an alarm, press any key.
• For a wake-up alarm, press <
OK
> or [ ].
Press any key, except <
OK
> and [ ], to cause it
to sound again after 5 minutes. You can do this a
maximum of 5 times.
Setting the alarm to ring even if the phone is
off
From the Alarm screen, select
Auto power
→
On
.
If the phone is off when it is time for the alarm to ring,
the phone switches on and sounds the alarm.
Calculator
(Menu 3.7)
Use this menu to perform basic arithmetic functions
such as addition, subtraction, multiplication, and
division.
1. Enter the first number.
42
Menu functions
• Press <
.()
> to insert a demical point or
bracket.
• Press [] or [] to move the cursor.
2. Enter the operation for your calculation by pressing
the Navigation keys.
3. Enter the second number.
4. Press [ ] to view the result.
5. If necessary, repeat from step 2 to continue the
calculation.
Convertor
(Menu 3.8)
Use this menu for common conversions, such as
currency and temperature.
Performing a conversion
1. Select the convertor type you want.
2. Press [Left] or [Right] to select the original unit
and press [Down].
3. Enter the value to be converted and press [Down].
• Press [ ] to insert a decimal point.
• Press [ ] to change the temperature to above
zero (+) or below zero (-).
4. Press [Left] or [Right] to select the unit to which
you want to convert.
The equivalent value for the amount you entered
displays.
Using converter options
Press <
Options
> to access the following options:
•
Clear
: clear the current values.
•
Reverse
: reverse the conversion.
•
Currency rates
: edit the currency rate list.
Timer
(Menu 3.9)
Use this menu to set a period of time for the phone to
count down. The phone will sound an alarm when the
specified period of time has expired.
Starting the timer
1. Press <
Set
>.
2. Enter the length of time you want to count down
and press <
OK
>.
3. Press [ ] to start counting down.
Menu functions
Browser
(Menu 4)
43
Stopping the timer
• Press any key to stop the timer when it rings.
• Press [ ] on the Timer screen to stop the timer
before it rings.
Stopwatch
(Menu 3.10)
Use this menu to measure elapsed time. The
maximum time is 10 hours.
1. Press [ ] to start the stopwatch.
2. Press [ ] to check an interval. You can repeat this
step for a total of 4 intervals.
3. To reset the stopwatch, press <
Reset
>.
SIM-AT
(Menu 3.11)
This menu is available if you use a SIM-AT card that
supports SIM Application Tool kit menus and provides
additional services, such as news, weather, sports,
entertainment, and location services. Available
services may vary, depending on your service
provider’s plans. For details, see your SIM card
instructions or contact your service provider.
Browser
(Menu 4)
The Wireless Application Protocol (WAP) on your
phone allows you to access the wireless web. Using
the web browser, you can access up-to-date
information and a wide variety of media content, such
as wallpapers, ringtones, and music files.
To access this menu, press <
Menu
> in Idle mode and
select
Browser
.
Home
(Menu 4.1)
Use this menu to connect your phone to the network
and load the homepage of the wireless web service
provider. You can also press [ ] in Idle mode.
Navigating the web browser
To Press
scroll through browser items [Up] or [Down].
scroll page by page [ / ].
select a browser item < >.
44
Menu functions
Using browser menu options
1. Select or press [ ].
2. Select one of the following browser options:
•
Back
: go back to the previous page.
•
Home
: go back to the homepage.
•
Exit
: exit the web browser.
•
Reload
: reload the current page.
•
Show URL
: display the URL address of the
current web page. You can also set the current
page as the homepage for the web browser.
•
About...
: access the properties of your web
browser.
Using web page options
From any web page, press [ ] to access the following
options:
•
Go to URL
: enter a URL address manually.
•
Bookmarks
: switch to the
Bookmarks
menu.
•
Messages
: check the message stored in the
My
messages
folder. You can also create and send a
new SMS message.
p. 49
•
File manager
: switch to the
File manager
menu.
p. 60
Exiting the browser
Press [ ] to exit the browser.
Bookmarks
(Menu 4.2)
Use this menu to save URL addresses to quickly access
a website.
Adding a bookmark
1. Select an empty location.
2. Enter a name for the bookmark and press [Down].
3. Enter a URL address.
4. Press [ ] to save the bookmark.
Accessing a bookmarked page
Selecting a bookmark item launches the web browser
and access the associated web page.
return to the previous page <
Back
> or [
C
].
return to the homepage and hold [
C
].
To Press
Menu functions
Browser
(Menu 4)
45
Using bookmark options
After saving an item, press <
Options
> to access the
following options:
•
Go
: access the website.
•
Edit
: edit the address and name of the bookmark.
•
Delete
: delete the selected bookmark or all
bookmarks.
Go to URL
(Menu 4.3)
Use this menu to manually enter the URL address of a
website and access the website.
Clear cache
(Menu 4.4)
Use this menu to clear the cache, which is the
temporary memory that stores the web pages you
have recently accessed.
Profile settings
(Menu 4.5)
Use this menu to set up servers for the web browser.
Contact your service provider for details about your
settings options.
For each server, the following options are available:
•
Profile
name
: assign a name to the server profile.
•
Home
URL
: enter the address of your homepage.
•
Bearer
: select a bearer for each type of network
address accessed.
•
Proxy
: select whether or not the phone uses a
proxy server to launch the web browser. Your
service provider can tell you if your network
requires a proxy server, and they can give you the
appropriate settings.
•
GPRS settings
: customise the following GPRS
network settings:
When the proxy is set to
Enable
:
Proxy IP
: enter the web gateway address.
Proxy port
: enter the port number.
APN
: enter the access point name of the GPRS
network gateway.
Login ID
: enter the user ID.
Password
: enter the password.
46
Menu functions
When the proxy is set to
Disable
:
DNS1
: enter the primary address.
DNS2
: enter the secondary address
.
APN
: enter the access point name of the GPRS
network gateway.
Login ID
: enter the user ID
.
Password
: enter the password
.
•
GSM settings
: customise the following GSM
network settings:
When the proxy is set to
Enable
:
Proxy IP
: enter the web gateway address.
Proxy port
: enter the port number.
Dial number
: enter the PPP server phone number.
Login ID
: enter the user ID.
Password
: enter the password.
Data call type
: select a data call type.
When the proxy is set to
Disable
:
DNS1
: enter the primary address.
DNS2
: enter the secondary address.
Dial number
: enter the PPP server phone number.
Login ID
: enter the user ID.
Password
: enter the password.
Data call type
: select a data call type.
Current profile
(Menu 4.6)
Use this menu to activate one of the proxy servers you
have set up.
Messages
(Menu 5)
Use the
Messages
menu to send and receive short
messages, multimedia messages, and e-mails. You
can also use push message, Voice mail, and Cell
broadcast message features.
To access this menu, press <
Menu
> in Idle mode and
select
Messages
.
Create new message
(Menu 5.1)
Use this menu to create and send text messages,
multimedia messages, or e-mails.
Menu functions
Messages
(Menu 5)
47
Text message
(Menu 5.1.1)
Short Message Service (SMS) allows you to send or
receive text messages including pictures, audio clips,
and animated images.
1. Enter your message.
2. Press <
Options
> to access the following options
for creating a message:
•
Insert
: add a template, Phonebook entry, or
bookmark.
•
Add picture
/
Add animation
/
Add melody
:
attach a simple image, animated image, or a
melody.
•
Attach
: add name cards or calendar data as
data format attachments.
•
Text style
: change the text attributes.
3. When you have finished, press <
Options
> and
select
Send only
or
Save and send
.
4. Enter a destination number.
To send the message to more than one recipient,
fill in the destination fields.
5. Press [ ].
Multimedia message
(Menu 5.1.2)
Multimedia Message Service (MMS) delivers messages
containing a combination of text, image, video, and
audio, from phone to phone or from phone to e-mail.
1. Select the
Subject
line.
2. Enter the subject and press [ ].
3. Select the
& Video
or
Sound
line and add
an image, a video, or a sound file.
4. Select the
Message
line.
5. Enter the text and press [ ].
The maximum number of characters allowed in a
short message varies by your service provider. If
your message exceeds the maximum number of
characters, the phone will split the message.
• The maximum size allowed for a message can
differ, depending on the your service provider.
• Depending on the file type or DRM (Digital
Rights Management) system, some files may
not be able to be forwarded.
48
Menu functions
6. Press <
Options
> to access the following options
for editing the message:
•
Edit
: edit the subject or text of your message.
•
Change image
/
Change video
/
Change
sound
: replace the added image, video clip, or
audio to another one.
•
Add page
: add pages. Move to each page by
pressing [Left] or [Right] on the message
screen.
•
Delete page
: delete the added page.
•
Edit page
: set the page duration or move the
current page to the next or previous page.
•
Attach
: attach name cards or calender data as
a data format attachment, or document files
stored in the
Other files
folder.
•
Remove subject
/
Remove media
/
Remove
sound
/
Remove message
: clear the subject,
image, audio, or text.
7. When you have finished, press <
Options
> and
select
Send
.
8. Enter a phone number or e-mail address.
To send the message to more than one recipient,
fill in additional destination fields.
9. Press [ ].
Email
(Menu 5.1.3)
You can send and receive e-mails that include text,
audio, and images. To use this feature, you need to
subscribe to an e-mail service and set up your e-mail
profile and account.
p. 59
1. Select the
Subject
line.
2. Enter the subject of your e-mail and press [ ].
3. Select the
Message
line.
4. Enter the e-mail text and press [ ].
5. Select the
File attach
line and select one of the
following options to add files:
•
Add image
/
Add videos
/
Add sounds
/
Add
music
: add items stored in the phone’s
memory:
Depending on the file type or DRM (Digital
Rights Management) system, some files may
not be able to be forwarded.
Menu functions
Messages
(Menu 5)
49
•
Add other files
: add document files stored in
the
Other files
folder.
•
Add from memory card
: add files stored on a
memory card.
•
Attach
: attach name cards or calender data as
data format attachments.
6. Press <
Options
> to access the following options
to edit the e-mail:
•
Edit
: edit the subject or text.
•
Remove subject
/
Remove message
: clear
the subject or text.
•
Remove
: delete the selected attachment or all
attachments.
•
Remove all attachments
: delete all
attachments.
7. When you have finished, press <
Options
> and
select
Send
.
8. Enter an e-mail address.
To send the e-mail to more than one recipient, fill
in additional destination fields.
9. Press [ ].
My messages
(Menu 5.2)
Use this menu to access messages you have received,
sent, or which have failed in sending.
Inbox
(Menu 5.2.1)
This folder stores all of the messages you have
received, except for e-mails.
Viewing a message
The following icons may appear on the message list to
show the message type:
•SMS
• MMS
• MMS notifications
• Push messages
• Depending on the DRM (Digital Rights Management)
system, messages having web content may not be
able to be forwarded. They are indicated by .
•
A
!
icon next to a message means that the
message is of high priority. A grey-coloured
message icon indicates low priority.
50
Menu functions
Using message options
While viewing a message, press <
Options
> to access
the following options:
SMS messages
•
Reply via
: reply to the sender via SMS or MMS.
•
Forward
: forward the message to other people.
•
Delete
: delete the message.
•
Move to phone
/
Move to SIM
: move the
message between the SIM card and the phone’s
memory.
•
Add to block list
: add the sender’s number to the
Block list.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Cut media
: save media content from the message
into your phone’s memory.
•
Print via Bluetooth
: print the message by
connecting the phone to a printer via Bluetooth.
•
Protection
: protect the message from being
deleted.
MMS notifications/MMS messages
•
Retrieve
: retrieve the MMS message from the
server.
•
Reply via SMS
: send a reply message via SMS.
•
Reply via MMS to
: send a reply message via MMS
to the sender or all recipients.
•
Forward
: forward the message to other people.
•
Delete
: delete the message.
•
Add to block list
: add the sender’s number to the
Block list.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Cut media
: save media content from the message
into your phone’s memory.
•
Properties
: access the message properties.
Push messages
•
Go to URL
: connect to the URL specified in the
message.
•
Delete
: delete the message.
•
Cut address
: extract URLs, e-mail addresses, or
phone numbers from the message.
Menu functions
Messages
(Menu 5)
51
Delivery reports
•
Delete
: delete the report.
Configuration messages
•
Install
: apply the configuration value in the
message to the phone.
•
Delete
: delete the message.
•
Cut address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Protection
: protect the message from being
deleted.
Draft
(Menu 5.2.2)
This folder stores messages you have saved to send at
a later time.
When you select an SMS or e-mail message, it opens
in Edit mode so that you can edit and/or send the
message.
When you select an MMS message, it opens in Preview
mode as would a message from the Inbox. To edit the
MMS message, press <
Options
> and select
Edit
.
Outbox
(Menu 5.2.3)
This folder stores messages that the phone is
attempting to send or has failed to send.
While viewing a message, press <
Options
> to access
the following options:
•
Open file
: open the attached file.
•
Save file
: save the attached file in your phone’s
memory.
•
Send again
: retry sending the message.
•
Forward
: forward the message to other people.
•
Delete
: delete the message.
•
Move to phone
/
Move to SIM
: move the
message between the SIM card and the phone’s
memory.
•
Print via Bluetooth
: print the message by
connecting the phone to a printer via Bluetooth.
•
Protection
: protect the message from being
deleted.
•
Properties
: access the file properties.
52
Menu functions
Sentbox
(Menu 5.2.4)
This folder stores messages that you have sent
successfully.
While viewing a message, press <
Options
> to access
the following options:
•
Open file
: open the attached file.
•
Save file
: save the attached file in your phone’s
memory.
•
Forward
: forward the message to other people.
•
Delete
: delete the selected message.
•
Move to phone
/
Move to SIM
: move the
message between the SIM card and the phone’s
memory.
•
Print via Bluetooth
: print the message by
connecting the phone to a printer via Bluetooth.
•
Protection
: protect the message from being
deleted.
•
Properties
: access the file properties.
Email box
(Menu 5.2.5)
This folder stores e-mails that you have received.
Viewing an e-mail
1. Press <
Select
> when
Check new mail
is
displayed to get new e-mails from the server. The
phone checks the e-mail server and downloads
new e-mails.
The following icons may appear on the list to show
the e-mail status:
• Retrieved from the server
• Being retrieved
• Failed to retrieve
2. Select an e-mail or header.
3. Press [ / ] to view other pages in the e-mail.
Press and hold [ / ] to move to the first or last
page in the e-mail.
4. Press [ ] or [ ] to view the next or previous
e-mail.
A
!
icon next to a message means that the
message is of high priority. A grey-coloured
message icon indicates low priority.
Menu functions
Messages
(Menu 5)
53
Using e-mail options
While viewing the e-mail or header, press <
Options
>
to access the following options:
•
Retrieve
: retrieve the body of the e-mail from the
e-mail server.
•
Open file
: open the attached file.
•
Save file
: save the attached file in your phone’s
memory.
•
Reply to
: send a reply to the sender or all
recipients.
•
Forward
: forward the e-mail to other people.
•
Delete
: delete the e-mail from the phone’s
memory or from both the phone’s memory and the
e-mail server.
•
Add to block list
: add the sender’s e-mail
address or subjects to the Block list.
•
Cut address
: extract URLs, e-mail addresses, and
phone numbers.
•
Cut attachment
: save the selected attachment or
all attachments from the e-mail to your phone’s
memory.
•
Print via Bluetooth
: print the message by
connecting the phone to a printer via Bluetooth.
•
Protection
: protect the message from being
deleted.
•
Properties
: access the e-mail properties.
My folder
(Menu 5.2.6)
Use this menu to view the messages you have moved
to this folder using the
Move to my folder
option
while viewing a message list.
Templates
(Menu 5.3)
Use this menu to make and use templates of
frequently used messages.
Text template
(Menu 5.3.1)
You can create SMS templates with the sentences you
use frequently so that you can retrieve and insert
them when composing an SMS message.
Creating a template
1. Select an empty location.
2. Enter a message and press [ ].
54
Menu functions
Using template options
From the text template list, press <
Options
> to
access the following options:
•
Edit
: edit the template.
•
Send message
: create and send a new message.
•
Delete
: delete the selected template.
MMS template
(Menu 5.3.2)
When you access this menu, you can view the list of
templates.
From the template list, press <
Options
> to access
the following options:
•
View
: open the selected template.
•
Send message
: create and send a new message.
•
Edit
: edit the selected template.
•
Add new
: add a new template.
•
Delete
: delete the selected template or all
templates. You cannot delete the preset templates.
Delete all
(Menu 5.4)
Use this menu to delete all messages in each message
type at once.
1. Press [ ] to select the message folders you want.
2. Press <
Delete
>.
3. Press <
Yes
> to confirm the deletion.
Settings
(Menu 5.5)
Use this menu to set up various options for using the
messaging service.
Text message
(Menu 5.5.1)
You can configure SMS settings.
•
Send settings
: set up the options for sending
SMS messages:
Reply path
: allow recipients to reply to you
through your SMS server.
Delivery report
: set the network to inform you
when messages have been delivered.
Character support
: select a character encoding
type. If you select
Auto
, the phone switches the
Menu functions
Messages
(Menu 5)
55
encoding type from
GSM-alphabet
to
Unicode
if
you enter an
Unicode
character. Use of
Unicode
encoding will reduce the maximum number of
characters in a message to about half. If this menu
is not shown, your phone provides the
Auto
character encoding by default.
Validity period
: set the length of time your
messages are stored in the SMS server.
Message type
: set the default message type. The
network can convert messages into the selected
format.
Service centre
: store or change the number of
SMS server.
•
Block number
: set the Blocked number list to
reject SMS messages from specific phone
numbers.
Multimedia message
(Menu 5.5.2)
You can configure MMS settings.
•
Send settings
: set up the options for sending
MMS messages:
Delivery report
: set the network to inform you
when messages have been delivered.
Address hiding
: set your address to be hidden
from the recipient’s phone.
Read reply
: request a report from each recipient
as to when your message was read by the
recipient.
Priority
: set the priority level of your messages.
Expiry date
: set the length of time your messages
are stored in the MMS server.
Delivery after
: set a time delay before messages
are sent.
Send size
: select a maximum size of attached
items allowed for messages.
•
Receive settings
: set up the options for receiving
MMS messages:
Anonymous reject
: reject messages from
unknown senders.
Advert allowed
: accept advertisements.
Report allowed
: set the network to inform the
sender when a message has been delivered to you.
Home reception
: determine if your phone
retrieves new messages automatically when you
are in your home service area.
56
Menu functions
Roaming reception
: determine if your phone
retrieves new messages automatically when you
are roaming on another network.
Home reception and Roaming reception have the
following options:
-
Automatic
: the phone automatically retrieves
messages from the server.
-
Reject
: the phone rejects all messages.
-
Manual
: the phone displays notifications. Use
the
Retrieve
option to manually download new
messages.
•
MMS profiles
: configure required network
settings for MMS.
Current profile
: select a profile.
Profile settings
: customise the options for each
profile:
-
Profile name
: assign a name to the MMS profile.
-
Server URL
: enter the address of your MMS
server.
-
Proxy
: connect to the GPRS network using the
proxy server.
-
GPRS settings
: customise the settings required
for connecting to the GPRS network.
when the proxy is set to
Enable
:
-
IP address
: enter the gateway address.
-
Port
: enter the port number.
-
APN
: enter the access point name used for the
address of the GPRS network.
-
Login ID
: enter the user ID.
-
Password
: enter the password.
when the proxy is set to
Disable
:
-
DNS1
: enter the primary address.
-
DNS2
: enter the secondary address.
-
APN
: enter the access point name used for the
address of the GPRS network.
-
Login ID
: enter the user ID.
-
Password
: enter the password.
Menu functions
Messages
(Menu 5)
57
-
Version
: select an available OMA version and
maximum size limit for sending or receiving
messages.
•
Block number
: set the Blocked number list to
reject MMS messages from specific phone
numbers.
Email
(Menu 5.5.3)
You can configure e-mails settings.
•
Send settings
: set up the options for sending
e-mails:
Send copy to self
: send a copy of your e-mail to
your e-mail account.
Delivery confirm
: set the network to inform you
when e-mails have been delivered.
Read confirm
: send a request for a reply along
with your e-mail.
Priority
: select the priority level of your e-mail.
Include signature
: attach your name, phone
number, or a simple memo to e-mails.
Edit name
: edit the name in your signature.
Edit telephone number
: edit the phone number
in your signature.
Edit note
: edit the tag line in your signature.
•
Receive settings
: set up the options for receiving
e-mails:
Check interval
: determine how often the phone
checks the server for incoming e-mails.
If you select
Not used
, you can use the Check
new mail feature to check your e-mail manually.
Read reply
: determine whether or not the phone
sends a read-reply for incoming e-mails.
If you select
Announce
, the phone reminds you to
send a read-reply.
Retrieve option
: set whether the phone
downloads e-mail headers only or e-mail headers
and bodies both.
Delete option
: determine whether e-mails are
deleted immediately or the next time you connect
to the server.
Depending on your service provider, it may not be
possible to support the maximum limit 295KB. In
this case, try again after changing the setting to
100KB.
58
Menu functions
Reject if over
: determine the maximum size for
incoming e-mails. Your phone will reject e-mails
that exceed the specified size.
Leave a copy of messages on the server
: leave
the copies of e-mails in the server after retrieving.
•
Email account
: set up your e-mail accounts and
select the one to be used:
Current account
: select an account.
Account settings
: configure up to five e-mail
accounts using different e-mail servers. The
options are available for each account:
-
In use
: select this option to use the account and
to display the account in
Email box
.
-
Account name
: enter a name for the currently
selected account.
-
User name
: enter a name to be displayed as the
sender’s name in your outgoing e-mails.
-
Email address
: enter your e-mail address.
-
Reply address
: enter your e-mil address to be
used when you send a reply.
-
User ID
: enter your e-mail ID.
-
Password
: enter your e-mail password.
-
SMTP server
: enter the IP address or host name
of the outgoing e-mail server.
-
SMTP port
: enter the SMTP port number.
-
Protocol type
: select the protocol for the
incoming e-mail server. The remaining options
depend on the protocol type setting.
When the protocol type is
POP3
:
-
POP3 server
:
enter the IP address or host name
of the server that receives your e-mail.
-
POP3 port
: enter the POP3 port number.
-
APOP login
: connect to the server by using the
APOP login scheme when this option is selected.
-
Secure connection
: use a secure connections
for e-mail service.
When the protocol type is
IMAP4
:
-
IMAP4 server
: enter the IP address or host
name of the server that receives your e-mail.
-
IMAP4 port
: enter the IMAP4 port number.
You cannot change e-mail account settings while
an e-mail is being sent or retrieved.
Menu functions
Messages
(Menu 5)
59
-
Include attachments
: select this option to
receive attachments with e-mails.
-
Max. Emails retrieved
: set the number of
headers you will retrieve from the server.
-
Secure connection
: use a secure connections
for e-mail service.
•
Email profile
: configure the network settings
required to send or receive e-mails.
Current profile
: select a profile.
Profile settings
: configure up to five e-mail
profiles. For each profile, the options are required
to connect to the GPRS network:
-
Profile name
: enter a name for the e-mail
profile.
-
APN
: enter the access point name used for the
GPRS network address.
-
Login ID
: enter the user ID.
-
Password
: enter the password.
-
DNS1
: enter the primary address.
-
DNS2
: enter the secondary address.
•
Block list
: specify e-mail addresses or subjects
you want to reject.
Push message
(Menu 5.5.4)
You can change the settings for receiving push
messages from the wireless web server.
•
Receive
: set how your phone receives push
messages.
•
Service center
: enter the address of the server
from which you want to receive push messages.
Broadcast messages
(Menu 5.6)
The cell broadcast service delivers short messages on
various topics such as the weather or traffic.
Use this menu to change the settings for the service
and to access broadcast messages.
•
Read
: open received messages.
The
Temporary
box saves network messages until
the phone is switched off.
You cannot change e-mail profile settings while an
e-mail is being sent or retrieved.
60
Menu functions
The
Archive
box saves network messages
indefinitely. Press <
Options
> and select
Save
when a text notification appears to save to the
Archive
box.
•
Receive
: enable or disable the reception of
broadcast messages.
•
Channel
: specify the channels from which you
receive broadcast messages.
•
Language
: select the language in which broadcast
messages display.
Please contact your service provider for details.
Memory status
(Menu 5.7)
Use this menu to view the memory status for text,
multimedia, e-mail, or push messages.
File manager
(Menu 6)
The
File manager
menu allows you to access images,
videos, voice memos, music files, sounds, and other
files stored in the phone’s memory or on a memory
card.
To access this menu, press <
Menu
> in Idle mode and
select
File manager
.
Images
(Menu 6.1)
This menu displays photos you have taken and images
you have downloaded, received in messages, or
imported from your computer.
Viewing an image
1. Select an image folder.
2. Select an image.
As a result of the DRM (Digital Rights Management)
system, some of the media items you download from
the Internet or receive by MMS may require a license
key to access them.
Menu functions
File manager
(Menu 6)
61
Viewing a slide show
You can view your images as a slide show, a sequential
presentation of each image in the current folder.
1. Select an image folder.
2. Press <
Options
> and select
Slide show
.
3. Select an interval option.
The slide show begins.
4. Press <
Back
> to stop the slide show.
Using image options
While viewing an image, press <
Options
> to access
the following options:
•
List
: return to the image list.
•
Send via
: send the file via MMS, e-mail, or
Bluetooth.
•
Set as
: set the file as your wallpaper or as a caller
ID image for a Phonebook entry.
•
Edit
: edit the image using the Image editor if it is
a photo taken by the camera on the phone.
•
Move to
: move the file to another folder.
•
Copy to card
: copy the selected files to a memory
card.
•
Delete
: delete the selected file.
•
Rename
: change the name of the file.
•
Slide show
: set all images to display as a slide
show. You can select a time interval between
images.
•
Share for Bluetooth
: share the selected file with
other Bluetooth devices or hide the file so that
other Bluetooth devices cannot access it.
•
Print via
: print the file by connecting the phone to
a printer via Bluetooth or USB.
•
Protection
: protect the file from being deleted.
•
Properties
: access the file properties.
Viewing a photo on a TV
You can use a TV to view the photos you have stored.
You first need to set the video system for your TV in
the
TV out
menu.
p. 79
62
Menu functions
1. With the TV switched on, connect your phone to
the TV with the TV out cable, as shown.
2. Switch the TV to External Input mode.
The display switches to TV Out mode and you can
view the phone’s display on the TV screen.
3. Access a photo in the
Photos
folder.
Videos
(Menu 6.2)
This menu displays video clips you have recorded,
downloaded, or received in messages, or imported
from your computer.
Playing a video clip
1. Select a video folder.
2. Select a video clip.
During playback, you can use the following keys:
• Depending on your particular TV model, the
location and shape of the video input and
audio output ports may vary. Match cable
connector and TV port colours.
• Do not plug in connectors with a wet hand.
Depending on the video’s system, the image
vibrates or in some other may be less than optimal.
Video clips recorded on other devices, such as
camcorders, may not play correctly.
Key Function
Pauses or resumes playback.
Up Opens the play list.
Left Goes to the previous file. Moves
backward in a file when pressed
and held.
Menu functions
File manager
(Menu 6)
63
Viewing a video clip on a TV
You can use a TV to view the video clips you have
stored.
p. 61
Music
(Menu 6.3)
This menu displays MP3 music files you have
downloaded, or received in messages, or imported
from your computer.
1. Select a sound folder.
2. Select a file. The MP3 player opens.
p. 36
Sounds
(Menu 6.4)
This menu displays the voice memos you have
recorded, and sound files you have downloaded,
received in messages, or imported from your
computer.
Playing a sound clip
1. Select a sound folder.
2. Select a sound clip. For a voice memo, see
Voice
recorder
.
p. 38
During playback, you can use the following keys:
Right Skips to the next file. Skips
forward in a file when pressed
and held.
/ Adjusts the volume.
Down Stops playback.
Key Function
Key Description
Up/Down/
/Adjusts the volume.
Left Goes to the previous file.
Right Skips to the next file.
64
Menu functions
From a sound screen, press <
Options
> to access the
following options:
•
List
: return to the sound list.
•
Send via
: send the selected file via MMS, e-mail,
or Bluetooth.
•
Set as
: set the file as your ringtone, as a alert
melody for a Phonebook entry, or as a alarm
melody.
•
Move to
: move the file to another folder.
•
Copy to card
: copy the files to a memory card.
•
Delete
: delete the file.
•
Rename
: change the name of the file.
•
Share for Bluetooth
: share the files with other
Bluetooth devices or hide the files so that other
Bluetooth devices cannot access them.
•
Protection
: protect the file from being deleted.
•
Properties
: access the file properties.
Other files
(Menu 6.5)
Use this menu to view various document files and files
stored in the phone’s memory without corruption.
Viewing a file
The following file formats are available:
• Documents: Microsoft Word, Microsoft Excel,
Microsoft PowerPoint, Adobe PDF, Plain text, HTML
• Images: BMP, GIF, JPEG, PNG, WMF, EMF
1. Select a file folder.
2. Select a file.
Use the following keys to view the document:
Depending on the file size or memory capacity of
Picsel File Viewer, a file may not open properly.
Keys Function
/ Zoom in or out.
Up/Down/
Left/Right Pans around the page.
Menu functions
File manager
(Menu 6)
65
Using document options
While viewing a document, press <
Options
> to
access the following options:
•
Normal screen view
/
Full screen view
: change
the display of the file viewer.
•
Zoom
: zoom in or out.
•
Fit to
: fit the document to the page size, screen
width, or screen height.
•
Go to
: move to another page of the document.
•
Rotate
: rotate the document.
•
Screen panning
/
Normal panning
: change the
panning mode to by screen or by preset picsel.
•
Show control bar
/
Hide control bar
: show or
hide control bar of the file viewer.
•
Send via
: send the file via MMS, e-mail, or
Bluetooth.
•
Move to card
: move files to a memory card.
•
Copy to card
: copy files to a memory card.
•
Delete
: delete the selected file.
•
Rename
: change the name of the file.
Fits the document to the page size.
1
Changes the panning mode.
2
Returns to the first page.
4
Goes to the previous page.
5
Rotates the page.
6
Goes to the next page.
7
Changes the view mode to the
screen width.
8
Moves to the last page.
9
Changes the view mode to the
screen height.
Changes the view mode.
Shows or hides the control bar. This
key is only available in Full screen
mode.
Keys Function
66
Menu functions
•
Print via
: print the file by connecting the phone to
a printer via Bluetooth or USB.
•
Share for Bluetooth
: share the files with other
Bluetooth devices or hide the files so that other
Bluetooth devices cannot access them.
•
Protection
: protect the file from being deleted.
•
Properties
: access the file properties.
Memory card
(Menu 6.6)
Use this menu to access the files stored on a memory
card. This menu is shown only when a memory card is
inserted into the phone.
Memory status
(Menu 6.7)
You can check the total amount of memory for media
items and the amount of memory currently in use in
each media box.
Calendar
(Menu 7)
The Calendar feature enables you to keep track of
your schedule.
To access this menu, press <
Menu
> in Idle mode and
select
Calendar
.
Month view
(Menu 7.1)
Use this menu to keep track of your monthly schedule.
Consulting the calendar
When you access the
Month view
menu, the calendar
in Month view appears with today’s date indicated by a
green box.
Selecting a day
• Press [Left] or [Right] to move by day.
• Press [Up] or [Down] to move by week.
• Press [ / ] to move by month.
Using calendar options
Press <
Options
> to access the following options:
•
View mode
: change the view mode of the
calendar.
Menu functions
Calendar
(Menu 7)
67
•
Create
: add a new event.
•
Go to
: go to the current date or a specific date.
•
Sort by
: sort items by type of event.
•
Delete
: delete events using various deleting
options.
•
Missed alarm events
: access events whose
alarms you have missed.
•
Memory status
: access the memory information
for the event items stored on the calendar.
Creating an event
You can store scheduled events, anniversaries, and To
do items on the calendar. More than one event per day
can be stored.
Entering a new scheduled event
1. Select a date on the calendar.
2. Press <
Options
> and select
Create
→
Schedule
or
Miscellaneous
.
3. Enter information or change the settings:
•
Subject
: enter a title for the event.
•
Details
: enter event details.
•
Start date
and
Start time
: enter the starting
date and time for the event.
•
AM
/
PM
: select
AM
or
PM
in 12-hour time
format.
•
End date
and
End time
: enter the ending date
and time for the event.
•
AM
/
PM
: select
AM
or
PM
in 12-hour time
format.
•
Location
: (for
Schedule
) enter information
about the event location.
•
Alarm
: select to set an alarm for the event.
•
before
: set how long before the event the
alarm is to alert you.
•
Alarm tone
: select an alarm tone.
•
Repeat
: (for
Schedule
) select to set the event
to recur.
•
until
: (for
Schedule
) select a repeat unit and
set the date to end repeating.
4. Press <
Save
> to save the event.
68
Menu functions
Entering a new anniversary
1. Select a date on the calendar.
2. Press <
Options
> and select
Create
→
Anniversary
.
3. Enter information or change the settings:
•
Occasion
: enter information about the
anniversary.
•
Date
: enter the date.
•
Alarm
: select to set an alarm for the
anniversary.
•
before
: set how long before the event the
alarm is to alert you.
•
Alarm time
: enter the time for the alarm to
ring.
•
AM
/
PM
: select
AM
or
PM
in 12-hour time
format.
•
Alarm tone
: select an alarm tone.
•
Repeat every year
: set the phone to remind
you of the anniversary every year.
4. Press <
Save
> to save the event.
Entering a To-do item
1. Select a date on the calendar.
2. Press <
Options
> and select
Create
→
To do
.
3. Enter information or change the settings:
•
To do
: enter information about the task.
•
Start date
: enter the starting date.
•
Due date
: enter the ending date.
•
Priority
: select a priority level.
4. Press <
Save
> to save the event.
Viewing an event
Once you have scheduled events, the event icons and
the number of events for a specific day appears at the
bottom of the calendar.
Accessing an event
1. Select a date on the calendar to display the events
for that day.
2. Select an event to view its details.
• Scheduled events • Anniversaries
• To-do items • Miscellaneous events
Menu functions
Calendar
(Menu 7)
69
3. Press [Left] or [Right] to access the other events
scheduled for the selected day.
Using event options
While viewing an event, press <
Options
> to access
the following options:
•
Edit
: edit the event.
•
Create
: add a new event.
•
Send via
: send the event via SMS, MMS, e-mail,
or Bluetooth.
•
View mode
: change the view mode of the
calendar.
•
Done
/
Undone
: change the status of the to-do
item.
•
Delete
: delete the event.
•
Print via Bluetooth
: print the event by
connecting the phone to a printer via Bluetooth.
Week view
(Menu 7.2)
You can view events for the selected week. A cell on
the timetable indicates the presence of event
information. Blue boxes indicate scheduled events,
and green boxes indicate miscellaneous event.
Select the cell that contains the event you want.
Day view
(Menu 7.3)
You can view events for the selected date. For an
anniversary, you can view the remaining dates for the
anniversary on the event list.
Select an event to view its details.
The following icons will be displayed according to the
event’s type and status:
• Alarm set
• Recurring event
• Completed to-do item
• To-do item priority (Red: high, Blue: normal,
and Grey: low)
70
Menu functions
Camera
(Menu 8)
You can use the camera module embedded in your
phone to take photos and record videos.
To access this menu, press <
Menu
> in Idle mode and
select
Camera
.
Take a photo
(Menu 8.1)
The camera produces JPEG photos.
Taking a photo
1. If the phone is closed, open the phone.
2. Access the
Take a photo
menu. The image to be
captured appears on the display.
3. Adjust the image by rotating the camera lens and
aiming it at the subject.
• Press < > to use the camera options. See the
next section.
• Use the keypad to change the camera settings
or switch to other modes.
p. 72
4. Press [ ] to take a photo. The photo is saved in
the
Photos
folder.
Using camera options in Capture mode
In Capture mode, press < > to access the following
options:
•
Record video
: switch to Record mode.
• Do not take photos of people without their
permission.
• Do not take photos in a place where cameras are not
allowed.
• Do not take photos in a place where you may
interfere with another person’s privacy.
When you take a photo in direct sunlight or in bright
conditions, shadows may appear on the photo.
5.
To Press
scroll through the image [Left] or [Right]
use photo options <
Options
>.
p. 72
delete the photo [
C
] and then <
Yes
>.
return to Capture mode <
Back
>.
Menu functions
Camera
(Menu 8)
71
•
Shooting mode
: take a photo in the following
modes:
Single shot
: take a photo in the normal mode.
You can select whether or not the camera
automatically saves a photo.
Multi shot
: take a series of action stills. You can
select the number and speed of photos the camera
will take.
Mosaic shot
: take several stills and save them in
one frame. You can select the layout.
•
Effects
: change the colour tone or apply a special
effect.
•
Frames
: apply a decorative frame.
•
Flash
: determine the use of the flash.
•
Timer
: set a time delay before the camera takes a
photo.
•
Go to photos
: display the photos stored in the
Photos
folder.
•
Settings
: change the default settings for taking a
photo.
Function
: change the following image settings:
-
Size
: select an image size.
-
Quality
: select an image quality.
-
View finder
: select a preview mode.
-
Scene programs
: use Night shot mode.
-
Metering exposure
: select a method to
determine the exposure of an image, based on a
specific area of the image.
-
White balance
: adjust the colour balance of the
photo. You can make your photo appear warmer
or cooler.
-
ISO
: change the ISO setting, which controls the
sensitivity of your camera. For low light
situations, lower the ISO number to increase
image quality. The higher the ISO number, the
faster the camera shutter functions and the more
sensitive the camera is to light. Higher ISO
settings may bring some distortion to an image.
Setup
: change the following camera settings:
-
Shutter sound
: select the sound that you hear
when you press the shutter, [ ].
72
Menu functions
-
Zoom sound
: turn the sound effect for zooming
on or off.
-
Brightness sound
: turn the sound effect for
brightness adjustment on or off.
-
Default name
: change the default prefix of the
photo name.
•
Camera short cuts
: view the functions of the
keys you can use in Capture mode.
Using the keypad in Capture mode
You can use the keypad to customise your camera
settings in Capture mode.
Using photo options
After saving a photo, press <
Options
> to access the
following options:
•
Take another
: return to Capture mode.
•
Send via
: send the file via MMS, e-mail, or
Bluetooth.
Key Function
Flips the image vertically.
Left/Right Adjusts the image brightness.
Up/Down Zooms in or out.
1
Switches to Record mode.
p. 73
2
Changes the image size.
3
Changes the image quality.
4
Changes the shooting mode and the
number of photos.
5
Changes the colour tone or applies a
special effect.
6
Changes the ISO setting.
7
Selects a decorative frame.
8
Sets the timer.
9
Goes to the
Photos
folder.
0
Determines the use of the flash.
Changes the preview mode.
Changes the white balance setting.
Key Function
Menu functions
Camera
(Menu 8)
73
•
Set as
: set the photo as your wallpaper or as a
caller ID image for a Phonebook entry.
•
Edit
: edit the image using the Image editor.
p. 39
•
Delete
: delete the file.
•
Rename
: change the name of the file.
•
Go to photos
: access the
Photos
folder.
p. 60
•
Share for Bluetooth
: share the selected file or all
files with other Bluetooth devices or hide the
selected file or all files so that other Bluetooth
devices cannot access them.
•
Print via
: print the file by connecting the phone to
a printer via Bluetooth or USB.
•
Protection
: protect the file from being deleted.
•
Properties
: access the file properties.
Record video
(Menu 8.2)
You can record a video of what is displayed on the
camera screen and save it as a .3gp file.
Recording a video
1. Access the
Record video
menu.
2. Adjust the image by rotating the camera lens and
aiming it at the subject.
• Press < > to use the camera options. See the
next section.
• Use the keypad to change the camera settings
or switch to other modes.
p. 74
3. Press [ ] to start recording.
To pause or resume, press [ ].
4. Press the right soft key. The video is saved in the
Videos
folder.
5.
To Press
play back the video clip [ ].
use video options the left soft key.
p. 75
delete the video [
C
] and then <
Yes
>.
return to Record mode the right soft key.
74
Menu functions
Using camera options in Record mode
In Record mode, press < > to access the following
options:
•
Take a photo
: switch to Capture mode.
•
Effects
: change the colour tone or apply a special
effect.
•
Flash
: determine the use of the flash.
•
Timer
: set a time delay before the camera starts
recording a video.
•
Go to videos
: access the
Videos
folder.
•
Settings
: change the following settings for
recording a video:
Recording mode
: select a video recording mode.
Select
Normal
to record a video within the limit of
the currently available memory.
Select
Limit of
MMS
to record a video suitable for
an MMS message.
Size
: select an image size.
Quality
: select an image quality.
View finder
: select a preview mode.
Audio rec
.: turn on or off the audio.
White balance
: adjust the colour balance of the
image. You can make you video appear warmer or
cooler.
Scene programs
: use Night shot mode.
Zoom sound
: turn the sound effect for zooming
on or off.
Brightness sound
: turn the sound effect for
brightness adjustment on or off.
Default name
: change the default prefix of the
video name.
•
Camcorder short cuts
: view the functions of the
keys you can use in Record mode.
Using the keypad in Record mode
You can use the keypad to customise your camera
settings in Record mode:
Key Function
Flips the image vertically.
Left/Right Adjusts the image brightness.
Menu functions
Camera
(Menu 8)
75
Using video options
After saving a video clip, press the left soft key to
access the following options:
•
Record another
: return to Record mode.
•
Send via
: send the file via MMS, e-mail,
Bluetooth.
•
Set as
: set the file as your wallpaper or as a caller
ID image for a Phonbook entry.
•
Delete
: delete the file.
•
Rename
: change the name of the file.
•
Go to videos
: access to the
Videos
folder.
p. 62
•
Share for Bluetooth
: share the file with other
Bluetooth devices or hide the file so that other
Bluetooth devices cannot access it.
•
Protection
: protect the file from being deleted.
•
Properties
: access the file properties.
Go to photos
(Menu 8.3)
Use this menu to access a list of photos you have
taken.
p. 60
Up/Down Zooms in or out.
1
Switches to Capture mode.
p. 70
2
Changes the image size.
3
Changes the image quality.
4
Changes the video recording mode.
5
Changes the colour tone or applies a
special effect.
6
Turns on or off the audio.
7
Switches to Night shot mode.
8
Sets the timer.
9
Goes to the
Videos
folder.
0
Determines the use of the flash.
Changes the preview mode.
Changes the white balance setting.
Key Function
76
Menu functions
Go to videos
(Menu 8.4)
Use this menu to access a list of videos you have
recorded.
p. 62
Settings
(Menu 9)
The
Settings
menu provides you with various setting
options to customise the phone to your preferences
and needs. You can also reset the settings to their
default values.
To access this menu, press <
Menu
> in Idle mode and
select
Settings
.
Time & Date
(Menu 9.1)
Use this menu to set the current time and date on
your phone. Before setting the time and date, specify
time zone in the
World time
menu.
p. 40
•
Set time
: enter the current time.
•
AM/PM
: select
AM
or
PM
in 12-hour time format.
•
Time format
: select the time format.
•
Set date
: enter the current date.
•
Date format
: select the date format.
•
Week start day
: set which day of the week the
calendar starts with.
•
Auto update
: select to receive time information
from your network.
Phone settings
(Menu 9.2)
Many different features of your phone’s system can be
customised to suit your preferences.
Language
(Menu 9.2.1)
Use this menu to select one of several languages for
the display text.
Greeting message
(Menu 9.2.2)
Use this menu to enter the greeting that is displayed
briefly when the phone is switched on.
Menu functions
Settings
(Menu 9)
77
Slide settings
(Menu 9.2.3)
Use this menu to set how the phone reacts when you
open it for an incoming call, and when you close it
while using a function.
•
Up
: set whether or not to answer a call by opening
the phone.
•
Down
: set whether or not the phone maintains
the menu you are using when you close the phone.
Short cut
(Menu 9.2.4)
You can use the Navigation keys as shortcut keys to
access specific menus directly from Idle mode. Use
this menu to change these shortcut assignments.
Assigning a shortcut to a key
1. Select the key to be used as a shortcut key.
2. Select the menu that will be assigned to the key.
Using shortcut options
Press <
Options
> to access the following options:
•
Change
: change a shortcut menu.
•
Remove
: deactivate the shortcut assignment to
the selected key.
•
Remove all
: deactivate all shortcut assignments.
Volume key
(Menu 9.2.5)
Use this menu to set whether the phone mutes the call
ringer or rejects a call if you press and hold [ / ]
when a call comes in.
USB settings
(Menu 9.2.6)
Use this menu to select a USB mode.
•
Modem
: select to use your phone as a modem.
•
Mass storage
: select to access a memory card, if
a memory card is inserted.
•
Pictbridge
: select to connect your phone to a
PictBridge-compatible printer.
When you set
Down
to
Continue operation
, the
keypad lock works only in Idle mode.
78
Menu functions
Extra settings
(Menu 9.2.7)
You can turn the automatic redialing or answering
features on or off.
•
Auto redial
: set the phone to make up to ten
attempts to redial a phone number after an
unsuccessful call.
•
Anykey
answer
: answer an incoming call by
pressing any key, except [ ] or <
Reject
>.
•
Voice clarity
: remove extraneous noise and
increase call quality so that the person with whom
you are speaking can hear you clearly even if you
are in a noisy place.
Display settings
(Menu 9.3)
Use this menu to change settings for the display and
light.
Wallpaper
(Menu 9.3.1)
You can change the background image that is
displayed in Idle mode.
Main menu style
(Menu 9.3.2)
You can select a display style for the main menu
screen.
Text display
(Menu 9.3.3)
You can change the display settings for the text
displayed on the idle screen.
•
Text position
: select a position. If you do not
want text to display in Idle mode, select
Off
.
•
Text style
: select a font style.
•
Text colour
: select a font colour.
Skin
(Menu 9.3.4)
You can select a skin colour pattern for Menu mode.
LCD brightness
(Menu 9.3.5)
You can adjust the brightness of the display for
varying lighting conditions.
Backlight
(Menu 9.3.6)
You can select the length of time the backlight stays
on or the length of time the display stays on in Dim
mode, in which the backlight is off.
Menu functions
Settings
(Menu 9)
79
•
On
: select the length of time the backlight stays
on.
•
Dim
: select the length of time the display stays on
in Dim mode after the backlight turns off. After a
specified time, the display turns off.
Service display
(Menu 9.3.7)
Use this menu to select a clock type to be displayed on
the diaplay after the backlight turns off.
Dialing display
(Menu 9.3.8)
Use this menu to select a font size or colour, or
background colour for the numbers entered while
dialling.
Calendar
(Menu 9.3.9)
Use this menu to display the calendar of the current
month on the idle screen.
Show caller information
(Menu 9.3.10)
Use this menu to set the phone to display missed call
notifications with the most recently missed caller’s
information.
TV out
(Menu 9.3.11)
Use this menu to select the video system for a TV.
Sound settings
(Menu 9.4)
Use this menu to customise various sound settings.
Incoming call
(Menu 9.4.1)
Use this menu to select a volume level and alert type
for incoming calls.
•
Ring tone
: select a ringtone for the call ringer.
•
Volume
: select a ringer volume.
•
Alert type
: specify how you are to be informed of
incoming calls.
Keypad tone
(Menu 9.4.2)
Use this menu to select the tone that the phone
sounds when you press a key.
You can adjust the keypad tone volume using
[
/
]
in Idle mode.
80
Menu functions
Message tone
(Menu 9.4.3)
Use this menu to set up the ringer for incoming SMS
messages, MMS messages, e-mails, and CB messages
individually.
•
Tone
: select one of several message tones.
•
Alert type
: specify how you are informed when a
message comes in.
•
Repetition
: specify how often the phone informs
you of a new message.
Power on/off
(Menu 9.4.4)
Use this menu to select the melody that the phone
sounds when it is switched on or off.
Slide tone
(Menu 9.4.5)
Use this menu to select the tone that the phone
sounds when you open or close the phone.
Quiet mode
(Menu 9.4.6)
Use this menu to set how the phone acts to alert you
to a specific event in Quiet mode.
Extra tones
(Menu 9.4.7)
Use this menu to customise additional tones for the
phone.
•
Minute
minder
: set the phone to beep every
minute during an outgoing call to keep you
informed of the length of your call.
•
Connection
tone
: set the phone to beep when an
outgoing call is connected to the system.
•
Alerts on call
: set the phone to beep when you
receive a new message or when the time for an
alarm comes during a call.
•
Indicative
tones
: set the phone to beep when a
pop-up window displays.
Network services
(Menu 9.5)
Use this menu to access network services. Please
contact your service provider to check their availability
and subscribe to them, if you wish.
Call diverting
(Menu 9.5.1)
This network service reroutes incoming calls to a
phone number that you specify.
Menu functions
Settings
(Menu 9)
81
1. Select a call diverting option:
•
Divert always
: divert calls.
•
Busy
: divert calls when you are on another
call.
•
No
reply
: divert calls when you do not answer
the phone.
•
Unreachable
: divert calls when you are not in
an area covered by your service provider or
when your phone is switched off.
•
Cancel
all
: cancel all call diverting options.
2. Select the type of calls to be diverted.
3. To activate call diverting, select
Activate
.
Otherwise, select
Deactivate
.
4. Move to the
Divert to
line.
5. Enter the number to which calls are to be diverted
and press <
OK
>.
6. If you selected
No reply
, move to the
Sec
line and
select the length of time the network delays before
diverting a call.
Call barring
(Menu 9.5.2)
This network service allows you to restrict your calls.
1. Select a call barring option:
•
All
outgoing
: prohibit outgoing calls.
•
International
: prohibit international calls.
•
International
except
home
: only allow calls
to numbers within the current country when
you are abroad, and to your home country.
•
All
incoming
: prohibit incoming calls.
•
Incoming
while
abroad
: prohibit incoming
calls when you use your phone outside of your
home country.
•
Cancel
all
: cancel all call barring settings,
allowing to be sent and received normally.
•
Change barring password
: change the call
barring password obtained from your service
provider.
2. Select the type of calls to be barred.
3. Press <
Activate
>. To deactivate call barring,
press <
Deactivate
>.
4. Enter the call barring password supplied by your
service provider and press <
OK
>.
82
Menu functions
Call waiting
(Menu 9.5.3)
This network service informs you when someone is
trying to reach you while you are on another call.
1. Select the type of calls to which the call waiting
option will apply.
2. Press <
Activate
>. To deactivate call waiting,
press <
Deactivate
>.
Network selection
(Menu 9.5.4)
This network service allows you to either automatically
or manually select the network used when roaming
outside of your home area.
You can select a network other than your home
network only if there is a valid roaming agreement
between the two.
Caller ID
(Menu 9.5.5)
This network service allows you to prevent your phone
number from being displayed on the phone of the
person being called. However, some networks do not
allow the user to change this setting.
If you select
Default
, the phone will use the default
setting provided by the network.
Voice mail server
(Menu 9.5.6)
Use this menu to store the number of the voice mail
server and access your voice mails.
•
Connect to voice mail
: connect to the voice mail
server to allow you to listen to your messages.
•
Voice server number
: enter the voice mail
server number.
Band selection
(Menu 9.5.7)
For the phone to make and receive phone calls, it
must register with an available network.
Your phone can handle any of the following types of
networks: Combined GSM 900/1800, Combined GSM
850/1900, and GSM 850/900/1800/1900.
The country where you purchased your phone
determines the default band that it uses. When you
travel abroad, you must remember to change to an
appropriate band.
Your service provider can give you the voice mail server
number.
Menu functions
Settings
(Menu 9)
83
Bluetooth
(Menu 9.6)
Using Bluetooth wireless, you can connect the phone
wirelessly to other Bluetooth devices and exchange
data with them, talk hands-free, or control the phone
remotely.
Bluetooth technology allows free wireless connections
between all Bluetooth-compliant devices within a
range of 10 metres. Since the devices communicate
using radio waves, they do not need to be in line of
sight to each other.
Setting up the Bluetooth feature
The
Bluetooth
menu provides the following options:
•
Activation
: activate or deactivate the Bluetooth
feature.
•
My devices
: search for connectable Bluetooth
devices. See the next section.
•
My phone’s visibility
: allow other Bluetooth
devices to connect to your phone.
•
My phone’s name
: assign a Bluetooth device
name to your phone, which is then displayed on
other devices.
•
Secure mode
: determine if the phone asks for
your confirmation when other devices access your
data.
•
Bluetooth services
: display available Bluetooth
services.
Searching for and pairing with a Bluetooth
device
1. From the Bluetooth setting options, select
My
devices
.
2. Select
Search new device
.
• If there are obstacles between the devices, the
maximum operating distance may be reduced.
• It is recommended that you can don’t use the
Bluetooth feature while using multimedia features
such as voice recorder, camera, and media player, or
vice versa for better performance.
• Some devices may not be compatible with your
phone.
84
Menu functions
After searching, a list of devices to which you can
connect displays. The following icons indicate the
kind of device:
The colour of the icon indicates the status of the
device:
• Grey for unpaired devices
• Blue for paired devices
• Red for devices that are currently connected to
your phone
3. Select a device.
4. Enter a Bluetooth PIN and press <
OK
>.
This code
is used just once and you don’t need to memorise it.
When the owner of the other device enters the
same code, pairing is finished.
Using device options
From the device list, press <
Options
> to access the
following options:
•
Connect
: connect to the currently selected device.
You need to enter the Bluetooth PIN code.
•
Disconnect
: end the connection with the device.
•
Browse files
: search for data from the device and
import data directly to your phone.
•
Service list
: access the Bluetooth service list of
the device.
•
Rename
: rename the paired device.
•
Authorize device
/
Unauthorize device
:
determine if the phone asks you to permit
connection when other devices try to connect to
your phone.
•
Delete
: delete the selected device or all devices.
• Headset • Mobile phone
• Computer • PDA
• Unknown device • Printer
• Hands-free car kit • A/V headset
Some devices, especially headsets or hands-free car
kits, may have a fixed Bluetooth PIN, such as
0000
. If
the other device has one, you must enter the code.
Menu functions
Settings
(Menu 9)
85
Sending data via Bluetooth
1. Activate the Bluetooth feature.
2. Select the application in which the item you want
to send is stored.
3. Scroll to the item you want and press <
Options
>.
4. Select
Send
via
→
Bluetooth
.
The phone searches for devices within range and
displays a list of available devices.
5. Select a device.
6. If necessary, enter the Bluetooth PIN needed for
pairing and press <
OK
>.
Receiving data via Bluetooth
To receive data via Bluetooth, your phone’s Bluetooth
feature must be active.
If an unauthorised Bluetooth device sends data to your
phone, the phone displays a confirmation message. To
receive data, press <
Yes
>.
Security
(Menu 9.7)
Use this menu to protect the phone against
unauthorised use by managing the several access
codes of your phone and SIM card.
PIN check
(Menu 9.7.1)
The 4- to 8-digit PIN (Personal Identification Number)
protects your SIM card against unauthorised use.
When this feature is enabled, the phone requires your
PIN each time it is switched on.
Change PIN
(Menu 9.7.2)
Use this menu to change your PIN code. The PIN check
feature must be enabled to use this feature.
Phone lock
(Menu 9.7.3)
The Phone lock feature locks the phone from
unauthorised use.
If you enter an incorrect PIN/PIN2 three times in
succession, the SIM card is blocked. To unblock it, you
need to enter your PUK/PUK2 (Personal Unblocking
Key). The codes are supplied by your network operator.
86
Menu functions
When this feature is enabled, you must enter a 4- to
8-digit phone password each time the phone is
switched on.
The password is preset to
00000000
. To change the
password, use the
Change password
menu.
Change password
(Menu 9.7.4)
Use this menu to change your phone password.
Privacy
(Menu 9.7.5)
Use this menu to lock your media contents, including
messages, media files, and document files.
1. Press [ ] to check the items to lock.
2. Press <
Save
> to lock the marked items.
3. Enter the phone password and press <
OK
>.
To access a locked item, you need to enter the phone
password.
SIM lock
(Menu 9.7.6)
The SIM lock feature allows your phone to work only
with the current SIM by assigning a SIM lock code. You
must enter the SIM lock code to use a different SIM
card.
FDN mode
(Menu 9.7.7)
If supported by your SIM card, Fixed Dialling Number
(FDN) mode restricts your outgoing calls to a limited
set of phone numbers. When this feature is enabled,
you can make calls only to phone numbers stored on
the SIM card.
Change PIN2
(Menu 9.7.8)
If supported by your SIM card, the Change PIN2
feature changes your current PIN2.
Memory status
(Menu 9.8)
Use this menu to check the amount of memory being
used for storing data in
Shared memory
,
Messages
,
File manager
,
Calendar
,
Phonebook
, and
JAVA
world
.
Reset settings
(Menu 9.9)
Use this menu to reset the phone settings, display
settings, and sound settings individually.
87
1. Press [ ] to check the setting categories to be
reset.
2. Press <
Reset
> to reset the marked items and
then <
Yes
>.
3. Enter the phone password and press <
OK
>.
Key management
(Menu 9.10)
Use this menu to manage the license keys you have
acquired to activate media contents locked by DRM
systems.
Press <
Options
> to access the following options:
•
View
/
Play
/
Execute
: open or play the
corresponding media content.
•
Delete
: delete the selected licence key or all
licence keys.
•
Go to my messages
/
Go to my files
: access the
message containing the media content or the file
list.
•
Details
: access the properties of the licence key.
Solve problems
Help and personal needs
To save the time and expense of an unnecessary
service call, perform the simple checks in this section
before contacting a service professional.
When you switch on your phone, the following
messages may appear:
“Insert SIM”
• Be sure that the SIM card is correctly installed.
“Phone lock”
• The automatic locking function has been enabled.
You must enter the phone’s password before you
can use the phone.
“Enter PIN”
• You are using your phone for the first time. You
must enter the PIN supplied with the SIM card.
• The PIN check feature is enabled. Every time the
phone is switched on, the PIN has to be entered.
To disable this feature, use the
PIN check
menu.
The password is preset to
00000000
. You can
change this password
p. 86
88
Solve problems
“Enter PUK”
• The PIN code has been entered incorrectly three
times in succession, and the phone is now blocked.
Enter the PUK supplied by your service provider.
“No Service,” “Network Failure,” or “Not Done”
displays
• The network connection has been lost. You may be
in a weak signal area. Move and try again.
• You are trying to access an option for which you
have no subscription with your service provider.
Contact the service provider for further details.
You have entered a number but it was not dialled
• Be sure that you have pressed [ ].
• Be sure that you have accessed the right cellular
network.
• Be sure that you have not set an outgoing call
barring option.
Your correspondent cannot reach you
• Be sure that your phone is switched on. ([ ]
pressed for more than one second.)
• Be sure that you are accessing the correct cellular
network.
• Be sure that you have not set an incoming call
barring option.
Your correspondent cannot hear you speaking
• Be sure that you have switched off the
microphone.
• Be sure that you are holding the phone close
enough to your mouth. The microphone is located
at the bottom of the phone.
The phone starts beeping and “Battery low”
flashes on the display
• Your battery is insufficiently charged. Recharge the
battery.
The audio quality of the call is poor
• Check the signal strength indicator on the display
( ). The number of bars indicates the signal
strength from strong ( ) to weak ( ).
89
• Try moving the phone slightly or moving closer to a
window if you are in a building.
No number is dialled when you re-call a Contacts
entry
• Use the Contact Search feature to ensure the
number has been stored correctly.
• Re-store the number, if necessary.
The battery doesn’t charge properly or the phone
sometimes turns itself off
• Wipe the charging contacts both on the phone and
on the battery with a clean soft cloth.
If the above guidelines do not help you to solve
the problem, take note of:
• The model and serial numbers of your phone
•Your warranty details
• A clear description of the problem
Then contact your local dealer or Samsung after-sales
service.
Health and safety information
90
Health and safety information
Exposure to Radio Frequency (RF) Signals
Certification Information (SAR)
Your wireless phone is a radio transmitter and receiver.
It is designed and manufactured not to exceed the
exposure limits for radio frequency (RF) energy set by
the Federal Communications Commission (FCC) of the
U.S. government. These FCC exposure limits are
derived from the recommendations of two expert
organizations, the National Counsel on Radiation
Protection and Measurement (NCRP) and the Institute
of Electrical and Electronics Engineers (IEEE). In both
cases, the recommendations were developed by
scientific and engineering experts drawn from
industry, government, and academia after extensive
reviews of the scientific literature related to the
biological effects of RF energy.
The exposure limit set by the FCC for wireless mobile
phones employs a unit of measurement known as the
Specific Absorption Rate (SAR). The SAR is a measure
of the rate of absorption of RF energy by the human
body expressed in units of watts per kilogram (W/kg).
The FCC requires wireless phones to comply with a
safety limit of 1.6 watts per kilogram (1.6 W/kg). The
FCC exposure limit incorporates a substantial margin
of safety to give additional protection to the public and
to account for any variations in measurements.
SAR tests are conducted using standard operating
positions accepted by the FCC with the phone
transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is
determined at the highest certified power level, the
actual SAR level of the phone while operating can be
well below the maximum value. This is because the
phone is designed to operate at multiple power levels
so as to use only the power required to reach the
network. In general, the closer you are to a wireless
base station antenna, the lower the power output.
NorthAmerica_Cingular_T-mobile.fm Page 9 Monday, September 26, 2005 2:42 AM
Health and safety information
91
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that
it does not exceed the exposure limit established by
the FCC. Tests for each model phone are performed in
positions and locations (e.g. at the ear and worn on
the body) as required by the FCC. Body-worn
operations are restricted to Samsung-supplied,
approved, or non- Samsung designated accessories
that have no metal and must provide at least 1.5 cm
separation between the device, including its antenna
(whether extended or retracted) and the user's body.
Non-compliance with the above restrictions may result
in violation of FCC RF exposure guidelines.
The FCC has granted an Equipment Authorization for
this mobile phone with all reported SAR levels
evaluated as in compliance with the FCC RF exposure
guidelines. The maximum SAR values for this model
phone as reported to the FCC are:
1900
• Head: 0.36 W/Kg.
• Body-worn: 0.41 W/Kg.
SAR information on this and other model phones can
be viewed on-line at www.fcc.gov/oet/fccid. This site
uses the phone FCC ID number, A3LSGHD820.
Sometimes it may be necessary to remove the battery
pack to find the number. Once you have the FCC ID
number for a particular phone, follow the instructions
on the website and it should provide values for typical
or maximum SAR for a particular phone. Additional
product specific SAR information can also be obtained
at www.fcc.gov/cgb/sar.
사본 - NorthAmerica_Cingular_T-mobile.fm Page 10 Monday, September 26, 2005 6:47 AM
92
Health and safety information
Consumer Information on Wireless Phones
The U.S. Food and Drug Administration (FDA) has
published a series of Questions and Answers for
consumers relating to radio frequency (RF) exposure
from wireless phones. The FDA publication includes
the following information:
What kinds of phones are the subject of this
update?
The term wireless phone refers here to hand-held
wireless phones with built-in antennas, often called
“cell,” “mobile,” or “PCS” phones. These types of
wireless phones can expose the user to measurable
radio frequency energy (RF) because of the short
distance between the phone and the user's head.
These RF exposures are limited by Federal
Communications Commission safety guidelines that
were developed with the advice of FDA and other
federal health and safety agencies. When the phone is
located at greater distances from the user, the
exposure to RF is drastically lower because a person's
RF exposure decreases rapidly with increasing
distance from the source. The so-called “cordless
phones,” which have a base unit connected to the
telephone wiring in a house, typically operate at far
lower power levels, and thus produce RF exposures
well within the FCC's compliance limits.
Do wireless phones pose a health hazard?
The available scientific evidence does not show that
any health problems are associated with using
wireless phones. There is no proof, however, that
wireless phones are absolutely safe. Wireless phones
emit low levels of radio frequency energy (RF) in the
microwave range while being used. They also emit
very low levels of RF when in the stand-by mode.
Whereas high levels of RF can produce health effects
(by heating tissue), exposure to low level RF that does
not produce heating effects causes no known adverse
health effects. Many studies of low level RF exposures
have not found any biological effects. Some studies
have suggested that some biological effects may
occur, but such findings have not been confirmed by
additional research. In some cases, other researchers
have had difficulty in reproducing those studies, or in
determining the reasons for inconsistent results.
NorthAmerica_Cingular_T-mobile.fm Page 11 Monday, September 26, 2005 2:42 AM
Health and safety information
93
What is FDA's role concerning the safety of
wireless phones?
Under the law, FDA does not review the safety of
radiation-emitting consumer products such as wireless
phones before they can be sold, as it does with new
drugs or medical devices. However, the agency has
authority to take action if wireless phones are shown
to emit radio frequency energy (RF) at a level that is
hazardous to the user. In such a case, FDA could
require the manufacturers of wireless phones to notify
users of the health hazard and to repair, replace or
recall the phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA
regulatory actions, FDA has urged the wireless phone
industry to take a number of steps, including the
following:
• “Support needed research into possible biological
effects of RF of the type emitted by wireless
phones;
• “Design wireless phones in a way that minimizes
any RF exposure to the user that is not necessary
for device function; and
• “Cooperate in providing users of wireless phones
with the best possible information on possible
effects of wireless phone use on human health.
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at
the federal level. The following agencies belong to this
working group:
• “National Institute for Occupational Safety and
Health
• “Environmental Protection Agency
• “Federal Communications Commission
• “Occupational Safety and Health Administration
• “National Telecommunications and Information
Administration
The National Institutes of Health participates in some
interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless
phones with the Federal Communications Commission
(FCC). All phones that are sold in the United States
must comply with FCC safety guidelines that limit RF
NorthAmerica_Cingular_T-mobile.fm Page 12 Monday, September 26, 2005 2:42 AM
94
Health and safety information
exposure. FCC relies on FDA and other health agencies
for safety questions about wireless phones.
FCC also regulates the base stations that the wireless
phone networks rely upon. While these base stations
operate at higher power than do the wireless phones
themselves, the RF exposures that people get from
these base stations are typically thousands of times
lower than those they can get from wireless phones.
Base stations are thus not the primary subject of the
safety questions discussed in this document.
What are the results of the research done
already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws in
their research methods. Animal experiments
investigating the effects of radio frequency energy
(RF) exposures characteristic of wireless phones have
yielded conflicting results that often cannot be
repeated in other laboratories. A few animal studies,
however, have suggested that low levels of RF could
accelerate the development of cancer in laboratory
animals. However, many of the studies that showed
increased tumor development used animals that had
been genetically engineered or treated with cancer-
causing chemicals so as to be pre-disposed to develop
cancer in absence of RF exposure. Other studies
exposed the animals to RF for up to 22 hours per day.
These conditions are not similar to the conditions
under which people use wireless phones, so we don't
know with certainty what the results of such studies
mean for human health.
Three large epidemiology studies have been published
since December 2000. Between them, the studies
investigated any possible association between the use
of wireless phones and primary brain cancer, glioma,
meningioma, or acoustic neuroma, tumors of the brain
or salivary gland, leukemia, or other cancers. None of
the studies demonstrated the existence of any harmful
health effects from wireless phones RF exposures.
However, none of the studies can answer questions
about long-term exposures, since the average period
of phone use in these studies was around three years.
NorthAmerica_Cingular_T-mobile.fm Page 13 Monday, September 26, 2005 2:42 AM
Health and safety information
95
What research is needed to decide whether RF
exposure from wireless phones poses a health
risk?
A combination of laboratory studies and
epidemiological studies of people actually using
wireless phones would provide some of the data that
are needed. Lifetime animal exposure studies could be
completed in a few years. However, very large
numbers of animals would be needed to provide
reliable proof of a cancer promoting effect if one
exists. Epidemiological studies can provide data that is
directly applicable to human populations, but ten or
more years' follow-up may be needed to provide
answers about some health effects, such as cancer.
This is because the interval between the time of
exposure to a cancer-causing agent and the time
tumors develop - if they do - may be many, many
years. The interpretation of epidemiological studies is
hampered by difficulties in measuring actual RF
exposure during day-to-day use of wireless phones.
Many factors affect this measurement, such as the
angle at which the phone is held, or which model of
phone is used.
What is FDA doing to find out more about the
possible health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology
Program and with groups of investigators around the
world to ensure that high priority animal studies are
conducted to address important questions about the
effects of exposure to radio frequency energy (RF).
FDA has been a leading participant in the World Health
Organization international Electromagnetic Fields
(EMF) Project since its inception in 1996. An influential
result of this work has been the development of a
detailed agenda of research needs that has driven the
establishment of new research programs around the
world. The Project has also helped develop a series of
public information documents on EMF issues.
FDA and Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative
Research and Development Agreement (CRADA) to do
research on wireless phone safety. FDA provides the
scientific oversight, obtaining input from experts in
government, industry, and academic organizations.
CTIA-funded research is conducted through contracts
NorthAmerica_Cingular_T-mobile.fm Page 14 Monday, September 26, 2005 2:42 AM
96
Health and safety information
to independent investigators. The initial research will
include both laboratory studies and studies of wireless
phone users. The CRADA will also include a broad
assessment of additional research needs in the
context of the latest research developments around
the world.
What steps can I take to reduce my exposure
to radio frequency energy from my wireless
phone?
If there is a risk from these products - and at this
point we do not know that there is - it is probably very
small. But if you are concerned about avoiding even
potential risks, you can take a few simple steps to
minimize your exposure to radio frequency energy
(RF). Since time is a key factor in how much exposure
a person receives, reducing the amount of time spent
using a wireless phone will reduce RF exposure.
• “If you must conduct extended conversations by
wireless phone every day, you could place more
distance between your body and the source of the
RF, since the exposure level drops off dramatically
with distance. For example, you could use a
headset and carry the wireless phone away from
your body or use a wireless phone connected to a
remote antenna.
Again, the scientific data do not demonstrate that
wireless phones are harmful. But if you are concerned
about the RF exposure from these products, you can
use measures like those described above to reduce
your RF exposure from wireless phone use.
What about children using wireless phones?
The scientific evidence does not show a danger to
users of wireless phones, including children and
teenagers. If you want to take steps to lower exposure
to radio frequency energy (RF), the measures
described above would apply to children and
teenagers using wireless phones. Reducing the time of
wireless phone use and increasing the distance
between the user and the RF source will reduce RF
exposure.
Some groups sponsored by other national
governments have advised that children be
discouraged from using wireless phones at all. For
NorthAmerica_Cingular_T-mobile.fm Page 15 Monday, September 26, 2005 2:42 AM
Health and safety information
97
example, the government in the United Kingdom
distributed leaflets containing such a recommendation
in December 2000. They noted that no evidence exists
that using a wireless phone causes brain tumors or
other ill effects. Their recommendation to limit
wireless phone use by children was strictly
precautionary; it was not based on scientific evidence
that any health hazard exists.
Do hands-free kits for wireless phones reduce
risks from exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that hands-free kits reduce risks. Hands-free
kits can be used with wireless phones for convenience
and comfort. These systems reduce the absorption of
RF energy in the head because the phone, which is the
source of the RF emissions, will not be placed against
the head. On the other hand, if the phone is mounted
against the waist or other part of the body during use,
then that part of the body will absorb more RF energy.
Wireless phones marketed in the U.S. are required to
meet safety requirements regardless of whether they
are used against the head or against the body. Either
configuration should result in compliance with the
safety limit.
Do wireless phone accessories that claim to
shield the head from RF radiation work?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that accessories that claim to shield the head
from those emissions reduce risks. Some products
that claim to shield the user from RF absorption use
special phone cases, while others involve nothing
more than a metallic accessory attached to the phone.
Studies have shown that these products generally do
not work as advertised. Unlike “hand-free” kits, these
so-called “shields” may interfere with proper operation
of the phone. The phone may be forced to boost its
power to compensate, leading to an increase in RF
absorption. In February 2002, the Federal trade
Commission (FTC) charged two companies that sold
devices that claimed to protect wireless phone users
from radiation with making false and unsubstantiated
NorthAmerica_Cingular_T-mobile.fm Page 16 Monday, September 26, 2005 2:42 AM
98
Health and safety information
claims. According to FTC, these defendants lacked a
reasonable basis to substantiate their claim.
What about wireless phone interference with
medical equipment?
Radio frequency energy (RF) from wireless phones can
interact with some electronic devices. For this reason,
FDA helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted
cardiac pacemakers and defibrillators from wireless
telephones. This test method is now part of a standard
sponsored by the Association for the Advancement of
Medical instrumentation (AAMI). The final draft, a joint
effort by FDA, medical device manufacturers, and
many other groups, was completed in late 2000. This
standard will allow manufacturers to ensure that
cardiac pacemakers and defibrillators are safe from
wireless phone EMI. FDA has tested wireless phones
and helped develop a voluntary standard sponsored by
the Institute of Electrical and Electronic Engineers
(IEEE). This standard specifies test methods and
performance requirements for hearing aids and
wireless phones so that no interference occurs when a
person uses a compatible phone and a compatible
hearing aid at the same time. This standard was
approved by the IEEE in 2000.
FDA continues to monitor the use of wireless phones
for possible interactions with other medical devices.
Should harmful interference be found to occur, FDA
will conduct testing to assess the interference and
work to resolve the problem.
Additional information on the safety of RF exposures
from various sources can be obtained from the
following organizations:
• FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
• Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
• Occupational Safety and Health Administration's
(OSHA):
http://www.osha.gov/SLTC/
radiofrequencyradiation/index.html
NorthAmerica_Cingular_T-mobile.fm Page 17 Monday, September 26, 2005 2:42 AM
Health and safety information
99
• National institute for Occupational Safety and
Health (NIOSH):
http://www.cdc.gov/niosh/emfpg.html
• World health Organization (WHO):
http://www.who.int/peh-emf/
• International Commission on Non-Ionizing
Radiation Protection:
http://www.icnirp.de
• National Radiation Protection Board (UK):
http://www.nrpb.org.uk
• Updated 4/3/2002: US food and Drug
Administration
http://www.fda.gov/cellphones
Road Safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime.
But an important responsibility accompanies the
benefits of wireless phones, one that every user must
uphold.
When driving a car, driving is your first responsibility.
When using your wireless phone behind the wheel of a
car, practice good common sense and remember the
following tips:
1. Get to know your wireless phone and its features,
such as speed dial and redial. If available, these
features help you to place your call without taking
your attention off the road.
2. When available, use a hands-free device. If
possible, add an additional layer of convenience
and safety to your wireless phone with one of the
many hands free accessories available today.
NorthAmerica_Cingular_T-mobile.fm Page 18 Monday, September 26, 2005 2:42 AM
101
Health and safety information
3. Position your wireless phone within easy reach. Be
able to access your wireless phone without
removing your eyes from the road. If you get an
incoming call at an inconvenient time, let your
voice mail answer it for you.
4. Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy
traffic or hazardous weather conditions. Rain,
sleet, snow, ice and even heavy traffic can be
hazardous.
5. Do not take notes or look up phone numbers while
driving. Jotting down a “to do” list or flipping
through your address book takes attention away
from your primary responsibility, driving safely.
6. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan calls when your car
will be stationary. If you need to make a call while
moving, dial only a few numbers, check the road
and your mirrors, then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting. Make
people you are talking with aware you are driving
and suspend conversations that have the potential
to divert your attention from the road.
8. Use your wireless phone to call for help. Dial 9-1-1
or other local emergency number in the case of
fire, traffic accident or medical emergencies.
Remember, it is a free call on your wireless phone!
9. Use your wireless phone to help others in
emergencies. If you see an auto accident, crime in
progress or other serious emergency where lives
are in danger, call 9-1-1 or other local emergency
number, as you would want others to do for you.
10.Call roadside assistance or a special non-
emergency wireless assistance number when
necessary. If you see a broken-down vehicle
posing no serious hazard, a broken traffic signal, a
minor traffic accident where no one appears
injured, or a vehicle you know to be stolen, call
roadside assistance or other special non-
emergency number.
NorthAmerica_Cingular_T-mobile.fm Page 19 Monday, September 26, 2005 2:42 AM
Health and safety information
102
“The wireless industry reminds you to use your
phone safely when driving.”
For more information, please call 1-888-901-SAFE, or
visit our web-site www.wow-com.com
Provided by the Cellular Telecommunications &
Internet Association
Operating Environment
Remember to follow any special regulations in force in
any area and always switch your phone off whenever it
is forbidden to use it, or when it may cause
interference or danger. When connecting the phone or
any accessory to another device, read its user's guide
for detailed safety instructions. Do not connect
incompatible products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation of
the equipment and for the safety of personnel, it is
recommended that the equipment should only be used
in the normal operating position (held to your ear with
the antenna pointing over your shoulder).
Using Your Phone Near Other Electronic
Devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against the
RF signals from your wireless phone. Consult the
manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be maintained
between a wireless phone and a pacemaker to avoid
potential interference with the pacemaker.
These recommendations are consistent with the
independent research and recommendations of
Wireless Technology Research.
Persons with pacemakers:
• should always keep the phone more than 15 cm
(6 inches) from their pacemaker when the phone is
switched on.
• should not carry the phone in a breast pocket.
NorthAmerica_Cingular_T-mobile.fm Page 20 Monday, September 26, 2005 2:42 AM
103
Health and safety information
• should use the ear opposite the pacemaker to
minimize potential interference.
If you have any reason to suspect that interference is
taking place, switch your phone off immediately.
Hearing Aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you
may wish to consult your hearing aid manufacturer to
discuss alternatives.
Other Medical Devices
If you use any other personal medical devices, consult
the manufacturer of your device to determine if it is
adequately shielded from external RF energy. Your
physician may be able to assist you in obtaining this
information. Switch your phone off in health care
facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care facilities
may be using equipment that could be sensitive to
external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle. You should also
consult the manufacturer of any equipment that has
been added to your vehicle.
Posted Facilities
Switch your phone off in any facility where posted
notices require you to do so.
Potentially Explosive Environments
Switch your phone off when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause an
explosion or fire resulting in bodily injury or even
death.
Users are advised to switch the phone off while at a
refueling point (service station). Users are reminded of
the need to observe restrictions on the use of radio
equipment in fuel depots (fuel storage and distribution
NorthAmerica_Cingular_T-mobile.fm Page 21 Monday, September 26, 2005 2:42 AM
104
areas), chemical plants or where blasting operations
are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas (such
as propane or butane), areas where the air contains
chemicals or particles, such as grain, dust or metal
powders, and any other area where you would
normally be advised to turn off your vehicle engine.
Emergency Calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well as
user programmed functions, which cannot guarantee
connection in all conditions. Therefore, you should
never rely solely on any wireless phone for essential
communications (medical emergencies, for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not be
possible on all wireless phone networks or when
certain network services and/or phone features are in
use. Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location (for example, 911 or other official
emergency number). Emergency numbers vary by
location.
3. Press .
If certain features are in use (call barring, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult this document and your local cellular service
provider.
When making an emergency call, remember to give all
the necessary information as accurately as possible.
Remember that your phone may be the only means of
communication at the scene of an accident; do not cut
off the call until given permission to do so.
NorthAmerica_Cingular_T-mobile.fm Page 22 Monday, September 26, 2005 2:42 AM
105
Health and safety information
Restricting Children's access to your Phone
Your phone is not a toy. Children should not be allowed
to play with it because they could hurt themselves and
others, damage the phone or make calls that increase
your phone bill.
FCC Notice and Cautions
FCC Notice
The phone may cause TV or radio interference if used
in close proximity to receiving equipment. The FCC
can require you to stop using the phone if such
interference cannot be eliminated.
Vehicles using liquefied petroleum gas (such as
propane or butane) must comply with the National Fire
Protection Standard (NFPA-58). For a copy of this
standard, contact the National Fire Protection
Association, One Battery march Park, Quincy, MA
02269, Attn: Publication Sales Division.
Cautions
Changes or modifications made in the radio phone, not
expressly approved by Samsung, will void the user’s
authority to operate the equipment.
Only use approved batteries, antennas and chargers.
The use of any unauthorized accessories may be
dangerous and void the phone warranty if said
accessories cause damage or a defect to the phone.
Although your phone is quite sturdy, it is a complex
piece of equipment and can be broken. Avoid
dropping, hitting, bending or sitting on it.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
NorthAmerica_Cingular_T-mobile.fm Page 23 Monday, September 26, 2005 2:42 AM
106
Other Important Safety Information
• Only qualified personnel should service the phone
or install the phone in a vehicle. Faulty installation
or service may be dangerous and may invalidate
any warranty applicable to the device.
• Check regularly that all wireless phone equipment
in your vehicle is mounted and operating properly.
• Do not store or carry flammable liquids, gases or
explosive materials in the same compartment as
the phone, its parts or accessories.
• For vehicles equipped with an air bag, remember
that an air bag inflates with great force. Do not
place objects, including both installed or portable
wireless equipment in the area over the air bag or
in the air bag deployment area. If wireless
equipment is improperly installed and the air bag
inflates, serious injury could result.
• Switch your phone off before boarding an aircraft.
The use of wireless phone in aircraft is illegal and
may be dangerous to the aircraft's operation.
• Failure to observe these instructions may lead to
the suspension or denial of telephone services to
the offender, or legal action, or both.
Product Performance
Getting the Most Out of Your Signal Reception
The quality of each call you make or receive depends
on the signal strength in your area. Your phone
informs you of the current signal strength by
displaying a number of bars next to the signal strength
icon. The more bars displayed, the stronger the signal.
If you're inside a building, being near a window may
give you better reception.
Understanding the Power Save Feature
If your phone is unable to find a signal after 15
minutes of searching, a Power Save feature is
automatically activated. If your phone is active, it
periodically rechecks service availability or you can
check it yourself by pressing any key.
Anytime the Power Save feature is activated, a
message displays on the screen. When a signal is
found, your phone returns to standby mode.
NorthAmerica_Cingular_T-mobile.fm Page 24 Monday, September 26, 2005 2:42 AM
107
Health and safety information
Understanding How Your Phone Operates
Your phone is basically a radio transmitter and
receiver. When it's turned on, it receives and transmits
radio frequency (RF) signals. When you use your
phone, the system handling your call controls the
power level. This power can range from 0.006 watts to
0.2 watts in digital mode.
Maintaining Your Phone's Peak Performance
For the best care of your phone, only authorized
personnel should service your phone and accessories.
Faulty service may void the warranty.
There are several simple guidelines to operating your
phone properly and maintaining safe, satisfactory
service.
• Hold the phone with the antenna raised, fully-
extended and over your shoulder.
• Try not to hold, bend or twist the phone's antenna.
• Don't use the phone if the antenna is damaged.
• Speak directly into the phone's receiver.
• Avoid exposing your phone and accessories to rain
or liquid spills. If your phone does get wet,
immediately turn the power off and remove the
battery. If it is inoperable, call Customer Care for
service.
Availability of Various Features/Ring
Tones
Many services and features are network dependent
and may require additional subscription and/or usage
charges. Not all features are available for purchase or
use in all areas. Downloadable Ring Tones may be
available at an additional cost. Other conditions and
restrictions may apply. See your service provider for
additional information.
Battery Standby and Talk Time
Standby and talk times will vary depending on phone
usage patterns and conditions. Battery power
consumption depends on factors such as network
configuration, signal strength, operating temperature,
features selected, frequency of calls, and voice, data,
and other application usage patterns.
NorthAmerica_Cingular_T-mobile.fm Page 25 Monday, September 26, 2005 2:42 AM
Health and safety information
108
Battery Precautions
• Never use any charger or battery that is damaged
in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network's base
station, it uses less power; talk and standby time
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
• Battery charging time depends on the remaining
battery charge and the type of battery and charger
used. The battery can be charged and discharged
hundreds of times, but it will gradually wear out.
When the operation time (talk time and standby
time) is noticeably shorter than normal, it is time
to buy a new battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not in use,
disconnect it from the power source. Do not leave
the battery connected to a charger for more than a
week, since overcharging may shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling or
warming first.
• Do not leave the battery in hot or cold places, such
as in a car in summer or winter conditions, as you
will reduce the capacity and lifetime of the battery.
Always try to keep the battery at room
temperature. A phone with a hot or cold battery
may temporarily not work, even when the battery
is fully charged. Li-ion batteries are particularly
affected by temperatures below 0 °C (32 °F).
• Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object (coin,
clip or pen) causes a direct connection between the
+ and - terminals of the battery (metal strips on
the battery), for example when you carry a spare
battery in a pocket or bag. Short-circuiting the
terminals may damage the battery or the object
causing the short-circuiting.
NorthAmerica_Cingular_T-mobile.fm Page 26 Monday, September 26, 2005 2:42 AM
109
Health and safety information
• Dispose of used batteries in accordance with local
regulations. In some areas, the disposal of
batteries in household or business trash may be
prohibited. For safe disposal options for Li-Ion
batteries, contact your nearest Samsung
authorized service center. Always recycle. Do not
dispose of batteries in a fire.
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for
many years.
• Keep the phone and all its parts and accessories
out of the reach of small children.
• Keep the phone dry. Precipitation, humidity and
liquids contain minerals that will corrode electronic
circuits.
• Do not use the phone with a wet hand. Doing so
may cause an electric shock to you or damage to
the phone.
• Do not use or store the phone in dusty, dirty areas,
as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the phone,
which may damage the phone's electronic circuit
boards.
• Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the phone. Wipe it with
a soft cloth slightly dampened in a mild soap-and-
water solution.
NorthAmerica_Cingular_T-mobile.fm Page 27 Monday, September 26, 2005 2:42 AM
Health and safety information
110
• Do not paint the phone. Paint can clog the device's
moving parts and prevent proper operation.
• Do not put the phone in or on heating devices,
such as a microwave oven, a stove or a radiator.
The phone may explode when overheated.
• When the phone or battery gets wet, the label
indicating water damage inside the phone changes
color. In this case, phone repairs are no longer
guaranteed by the manufacturer's warranty, even
if the warranty for your phone has not expired.
• If your phone has a flash or light, do not use it too
close to the eyes of people or animals. This may
cause damage to their eyes.
• Use only the supplied or an approved replacement
antenna. Unauthorized antennas or modified
accessories may damage the phone and violate
regulations governing radio devices.
• If the phone, battery, charger or any accessory is
not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
NorthAmerica_Cingular_T-mobile.fm Page 28 Monday, September 26, 2005 2:42 AM
111
Index
A
ABC mode, text input • 23
Alarm • 41
Answering
call • 26
second call • 27
Anykey answer • 78
Auto redial • 78
B
Background image • 78
Backlight time, set • 78
Band selection • 82
Barring, calls • 81
Battery
charging • 7
low indicator • 8
precautions • 90
Bluetooth
receiving, data • 85
sending, data • 85
settings • 83
Broadcast messages • 59
Browser, web • 43
C
Calculator • 41
Call costs • 31
Call records
dialled • 30
missed • 30
received • 30
Call time • 30
Caller group • 33
Caller ID • 82
Calls answering • 26
barring • 81
diverting • 80
holding • 27
redialling • 26
rejecting • 26
waiting • 82
Camera
photos • 70
videos • 73
CB (Cell Broadcast) messages •
59
Characters, enter • 23
Connection tone • 80
Converter • 42
Creating messages
e-mail • 48
MMS • 47
SMS • 47
Creating organiser
anniversaries • 68
events • 67
miscellaneous • 67
tasks • 68
D
Deleting
call records • 29
contacts • 35
e-mail • 53, 54
events • 69
MMS • 50, 51, 54
SMS • 50, 51, 54
Dialled calls • 30
Display
brightness • 78
icons • 10
language • 76
layout • 10
settings • 78
Diverting, calls • 80
Document files • 64
DRM (Digital Rights
Management) • 60
DTMF tones, send • 28
E
E-mails
creating/sending • 48
setting • 57
viewing • 52
Emergency calls • 93
F
FDN (Fixed Dialling Number)
mode • 86
File manager • 60
File viewer • 64
G
Games • 39, 40
Greeting message • 76
H
Health and safety • 89
112
Index
Holding, call • 27
I
Icons, description • 10
Image editor • 39
Images, downloaded • 60
Inbox, messages
e-mail • 52
MMS/SMS • 49
Input mode, change • 23
International calls • 25
Internet • 43
K
Key management • 87
Keypad tones
selecting • 79
sending/muting • 28
volume • 79
L
Language, select • 76
Last number, redial • 26
Locking
media contents • 86
phone • 85
SIM card • 86
Low battery indicator • 8
M
Memory card • 21
Memory status
camera • 60
contacts • 35
file manager • 66
messages • 60
phone • 86
Menu style • 78
Message tone • 80
Messages
cell broadcast • 59
configuration • 51
e-mail • 48
greeting • 76
MMS • 47
push • 50
SMS • 47
Minute minder • 80
Missed calls • 30
MMS messages
creating/sending • 47
deleting • 50
setting • 55
viewing • 49
MP3 player • 36
Music, downloaded • 63
N
Name card • 34
Names
entering • 23
searching • 31
Network band, select • 82
Network selection • 82
Network services • 80
O
Organiser • 66
Outbox, messages • 51
P
Password
call barring • 81
phone • 86
Phonecare and maintenance •
94
display • 10
icons • 10
locking • 85
password • 86
resetting • 86
switching on/off • 8
unpacking • 6
Phonebook
adding • 32
copying • 32
deleting • 35
editing • 31
managing • 35
options • 31
speed-dialling • 34
Photos
deleting • 61
editing • 39
options • 61
taking • 70
viewing • 60
PIN, change • 85
PIN2, change • 86
Power on/off tone • 80
Privacy • 86
Problems, solve • 87
Push messages • 50, 59
R
Received calls • 30
Received messages
e-mail • 52
MMS/SMS • 49
Recording
videos • 73
voice memos • 38
Redialling
automatically • 78
113
Index
manually • 26
Resetting phone • 86
Ringer
incoming calls • 79
messages • 80
Road safety • 91
Roaming • 82
S
Safety
information • 89
precaution • 1
Security, calls • 85
Sentbox, messages • 52
SIM card
inserting • 7
locking • 86
Skin • 78
Slide settings • 77
SMS messages
creating/sending • 47
deleting • 50
setting • 54
viewing • 50
Sound settings • 79
Sounds, downloaded • 63
Speed-dial • 34
Stopwatch • 43
Switching on/off
microphone • 28
phone • 8
T
Templates, message • 53
Text, enter • 23
Timer • 42
TV out • 79
V
Videos
playing • 62
recording • 73
Voice memos
playing • 38
recording • 38
Voicemail server • 82
W
Waiting call • 82
Wallpaper • 78
Web browser
access • 43
bookmarks • 44
World time • 40
