Samsung Electronics Co SGHE360 Single-Band PCS GSM/ EDGE Phone with Bluetooth User Manual
Samsung Electronics Co Ltd Single-Band PCS GSM/ EDGE Phone with Bluetooth Users Manual
Users Manual
*
Depending on the software installed or your service provider or country,
some of the descriptions in this guide may not match your phone exactly.
* Depending on your country, your phone and accessories may appear
different from the illustrations in this guide.
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-xxxxxA
English. 09/2005. Drf 1.0
SGH-E360
User’s Guide
Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or illegal.
Drive safely at all times
Do not use a hand-held phone while driving. Park
the vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using them
in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.
Important safety precautions
1
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is forbidden
to use it, or when it may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear). Avoid
unnecessary contact with the antenna when the phone
is switched on.
Emergency calls
Key in the emergency number for your present
location, then press .
Keep your phone away from small children
Keep the phone and all its parts, including accessories,
out of the reach of small children.
Accessories and batteries
Use only Samsung-approved accessories and
batteries. Use of any unauthorised accessories could
damage your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health and
safety information" on page 86.
• The phone could explode if the battery is replaced
with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.
2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone. To quickly
learn the basics for your phone, please refer to “Get
started” and “Step outside the phone.”
In this guide, the following instruction icons appear:
Indicates that you need to pay careful attention
to the subsequent information regarding safety
or phone features.
Indicates that you can get more information on
the referenced page.
→
Indicates that you need to press the Navigation
keys to scroll to the specified option and then
select it.
[ ]
Indicates a key on the phone. For example,
[].
< >
Indicates a soft key, whose function is displayed
on the phone screen. For example, <
Menu
>
• Camera and camcorder
Use the camera module on your
phone to take a photo or record a
video.
Special
features of your phone
•FM radio
Listen to your favourite radio
channels anytime, anywhere.
•MP3 player
Play MP3 music files using your
phone as an MP3 player.
3
Special features of your phone
•Bluetooth
Transfer media files and personal
data and connect to other devices
using free, wireless Bluetooth
technology.
• Get personal with photo caller
ID
See who’s calling you when their
very own photo displays.
•Name card
Create name cards with your
number and profile.
•
Multimedia Message Service (MMS)
Send and receive MMS messages with a
combination of text, images, video, and audio.
•
E-mail
Send and receive e-mails with images, video, and
audio attachments.
•Web browser
Access the wireless web to get
current information and up-to-the-
minute a wide variety of media
content.
•Java
Enjoy Java
™
-based embedded
games and download new games.
•Calendar
Keep track of your daily, weekly,
and monthly schedule.
• Voice recorder
Record memos or sounds.
4
Contents
Unpack 6
Make sure you have each item
Your phone 6
Buttons, features, and locations
Get started 7
First steps to operating your phone
Install and charge the phone..................................... 7
Power on or off........................................................ 8
Keys and display ..................................................... 9
Access menu functions ............................................ 11
Customise your phone............................................. 12
Make/Answer calls .................................................. 14
Step outside the phone 14
Begin with your camera, MP3 player, web, and other special
features
Use the camera ...................................................... 14
Play MP3s.............................................................. 15
Browse the web...................................................... 16
Use Phonebook ...................................................... 17
Send messages...................................................... 18
View messages....................................................... 19
Use Bluetooth ........................................................ 20
Quickly launch menus by number ............................. 21
Enter text 22
ABC, T9, Number, and Symbol mode
Call functions 25
Advanced calling features
Menu functions 29
All menu options listed
Solve problems 84
Help and personal needs
Health and safety information 86
Index 107
5
Overview of menu functions
To access Menu mode, press <
Menu
> in Idle mode.
1 Call records
p. 29
1 Recent contacts
2 Missed calls
3 Dialled calls
4 Received calls
5 Delete all
6 Call time
7 Call costs
*
p. 29
p. 29
p. 29
p. 29
p. 30
p. 30
p. 30
2 Phonebook
p. 31
1 Contact list
2 FDN list
3 Add new contact
4 Group
5 Speed dial
6 My name card
7 Own number
8 Management
9 Service number
*
p. 31
p. 31
p. 32
p. 33
p. 33
p. 34
p. 34
p. 34
p. 35
3 Applications
p. 35
1 MP3 player
2 Voice recorder
3 Java world
4 FM radio
5 World time
6 Alarm
7 Calculator
8 Convertor
9 Timer
10 Stopwatch
11 SIM AT
*
p. 35
p. 37
p. 38
p. 39
p. 41
p. 41
p. 42
p. 42
p. 43
p. 43
p. 43
4 Browser
p. 43
1 Home
1 Bookmarks
2 Go to URL
3 Clear cache
4 Profile settings
5 Current profile
p. 44
p. 45
p. 45
p. 45
p. 45
p. 46
5 Messages
p. 47
1 Create new message
2 My messages
3 Templates
4 Delete all
5 Settings
6 Broadcast messages
7 Memory status
p. 47
p. 50
p. 54
p. 55
p. 55
p. 60
p. 60
6 File manager
p. 61
1 Images
2 Videos
3 Music
4 Sounds
5 Other files
6 Memory status
p. 61
p. 62
p. 63
p. 63
p. 64
p. 64
7 Calendar
p. 64
8 Camera
p. 67
9 Settings
p. 73
1 Time & Date
2 Phone settings
3 Display settings
4 Sound settings
5 Light settings
6 Network services
7 Bluetooth
8 Security
9 Memory status
10 Reset settings
p. 73
p. 73
p. 75
p. 76
p. 77
p. 78
p. 80
p. 82
p. 83
p. 84
* Shows only if supported by your
SIM card.
6
Unpack
Make sure you have each item
You can obtain various accessories from
your local Samsung dealer.
Phone Travel Adapter
Battery User’s Guide
The items supplied with your phone
and the accessories available at your
Samsung dealer may vary, depending
on your country or service provider.
Your phone
Buttons, features, and locations
Special
function keys
Earpiece
Display
Left soft key
Headset jack
Volume keys
Dial key
Alphanumeric
keys
Power on/off/
Menu exit key
Microphone
Right soft key
Navigation keys
(Up/Down/Left/
Right)
Web access/
Confirm key
Delete key
Camera key
Camera lens
MP3 player
control keys
External
display
7
Get started
First steps to operating your phone
SIM card information
When you subscribe to a cellular network, you receive
a plug-in SIM (Subscriber Identity Module) card
loaded with your subscription details, such as your
PIN, and available optional services.
Install and charge the phone
Remove the battery.
If the phone is already
on, first turn it off by
holding [ ].
Insert the SIM card.
Make sure that the gold-
coloured contacts on the
card face down into the
phone.
Install the battery. Plug the travel adapter
into the phone.
Plug the adapter into a standard AC wall outlet.
When the phone is completely charged (the
battery icon becomes still), unplug the adapter
from the power outlet.
8
Get started
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the low battery message displays, and
• the empty battery icon blinks.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
Power on or off
Remove the adapter from the phone.
Switch on
Do not turn on
the phone when
mobile phone
use is prohibited.
1. Open the phone.
2. Press and hold [ ] to turn on
the phone.
3. If necessary, enter the PIN and
press <
OK
>.
Switch off
1. Open the phone.
2. Press and hold [ ].
9
Get started
Keys and display
Keys
Perform the function indicated on the bottom
line of the display.
In Idle mode, access your favourite menus
directly.
p. 73
In Menu mode, scroll through menu options.
In Idle mode, launch the web browser.
In Menu mode, select the highlighted menu
option or confirm input.
Make or answer a call.
In Idle mode, retrieve the recent numbers
dialled, missed, or received.
Delete characters from the display.
End a call.
Press and hold to switch the phone on or off.
In Menu mode, cancel input and return the
phone to Idle mode.
Enter numbers, letters, and some special
characters.
In Idle mode, press and hold
[1]
to access
your voicemail server. Press and hold [
0
] to
enter an international call prefix.
Enter special characters.
In Idle mode, press and hold [ ] to activate
or deactivate Quiet mode. Press and hold
[ ] to enter a pause between numbers.
Adjust the phone volume.
In Idle mode, with the phone open, adjust
the keypad tone volume.
In Idle mode, press and hold to turn on the
camera.
In Camera mode, take a photo or record a
video.
Press and hold to display the function
selection screen to access the MP3 player or
the FM radio.
In the MP3 player, start or stop playback.
In the FM radio, turn the radio on or off.
10
Get started
Display
Move back to the previous file during
playback.
Scan through radio channels.
Skip to the next file during playback.
Scan through radio channels.
Layout
Icons
*
Received signal strength
Call in progress
Out of your service area; you
cannot make or receive calls
Text and graphics
display messages,
instructions, and
information you enter.
Soft key function
indicators
show the current functions
assigned to the soft keys.
Menu Contacts
Icons
display various icons.
Alarm set
New text message
New multimedia message
New e-mail
New voicemail
One of the message Inboxes is full
Call diverting feature active
Bluetooth active
Connected to Bluetooth hands-free
car kit or headset
GPRS network
Roaming network
Home Zone, if registered for the
appropriate service
Office Zone, if registered for the
appropriate service
Call ringer set to vibrate
Quiet mode
Mute mode, during a call
Battery power level
* Depending on your country or service provider, the icons
shown on the display may vary.
11
Get started
Access menu functions
Use the soft
keys
The roles of the soft keys vary
depending on the function you are
using. The bottom line of the
display indicates their current role.
Press the left
soft key to select
the highlighted
option.
Press the right
soft key to return
to the previous
menu level.
Select Back
Select an
option
1. Press the appropriate soft key.
2. Press the Navigation keys to
move to the next or previous
option.
3. Press <
Select
> or [ ] to
confirm the function displayed
or option highlighted.
4. To exit, choose either of the
following methods.
•Press <
Back
> to move up
one level.
• Press [ ] to return to Idle
mode.
Use shortcuts
Press the number key
corresponding to the option you
want. For the index numbers 10 and
11, press [
0
] and [ ] respectively.
12
Get started
Customise your phone
1. In Idle mode, press <
Menu
>
and select
Settings
→
Phone
settings
→
Language
.
2. Select a language.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Sound
settings
→
Incoming call
→
Ring tone
.
2. Select a ringtone category.
3. Select a ringtone.
4. Press <
Save
>.
Display
language
Call ringer
melody
You can set wallpaper for the idle
screen on each display.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Display
settings
→
Wallpaper
→
Main
display
or
Cover display
.
2. Select an image category.
3. Select an image.
4. Press <
Select
>.
5. Press <
Save
>.
You can change the colour for the
display components, such as title
bars and highlight bars.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Display
settings
→
Skin
.
2. Select a colour pattern.
Idle mode
wallpaper
Menu mode
skin colour
13
Get started
You can set the Navigation keys as
shortcuts to access your favourite
menus.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Phone
settings
→
Short cut
.
2. Select a key.
3. Select a menu to be assigned to
the key.
You can switch the phone to Quiet
mode to avoid disturbing other
people.
Press and hold [ ] in Idle mode.
Menu
shortcuts
Quiet mode
You can protect the phone against
unauthorised use with a phone
password. The phone will require
the password on power-up.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Security
→
Change
password
.
2. Enter the default password,
00000000
, and press <
OK
>.
3. Enter a new 4- to 8-digit
password and press <
OK
>.
4. Enter the new password again
and press <
OK
>.
5. Select
Phone lock
.
6. Select
Enable
.
7. Enter the password and press
<
OK
>.
Phone lock
14
Make/Answer calls
Step outside the phone
Begin with your camera, MP3 player, web, and other
special features
Use the camera
1. In Idle mode, enter an area
code and phone number.
2. Press [ ].
3. To end the call, press [ ].
1. When the phone is ringing,
press [ ].
2. To end the call, press [ ].
Press [ / ].
Make a call
Answer a call
Adjust the
volume during
a call
1. Open the phone.
2. In Idle mode, press and hold
[
]
to turn on the camera.
3. Aim the lens at the subject and
adjust the image.
4. Press [ ] to take a photo. The
photo is saved automatically.
5.
Pres
s [
C
] to
take another photo.
1. In Idle mode, press <
Menu
>
and select
File manager
→
Images
→
Photos
.
2. Select the photo you want.
Take a photo
View a photo
15
Step outside the phone
Play MP3s
1. In Idle mode, press and hold
[ ] to turn on the camera.
2. Press [
1
] to switch to Record
mode.
3. Press [ ] to start recording.
4. Press [ ] to stop recording.
The video is saved
automatically.
5. Press < > to record another
video.
1.
In Idle mode, press <
Menu
>
and select
File manager
→
Videos
→
Videos
.
2. Select the video you want.
Record a video
Play a video
Use these methods:
• Download from the wireless
web
p. 43
• Download from a computer
using the optional Samsung PC
Studio
Samsung PC Studio
User’s Guide
• Receive via Bluetooth
p. 82
1. In Idle mode, press <
Menu
>
and select
Applications
→
MP3 player
.
2. Press <
Options
> and select
Add to list
→
Add all
or
Add a
file
.
3. For
Add a file
, press [ ] to
select the files you want and
press <
Add
>.
Copy MP3 files
to the phone
Create a play
list
16
Step outside the phone
Browse the web
Using a built-in web browser, you can get easy access
to the wireless web to get a variety of up-to-date
services and information and to enjoy downloads of
web content.
4. Press <
Back
> to return to the
MP3 player screen.
1. From the MP3 player screen,
press [ ].
2. During playback, use the
following keys:
•: pauses or resumes
playback.
• Left: moves back to the
previous file. Moves
backward in a file when
pressed and held.
• Right: skips to the next file.
Skips forward in a file when
pressed and held.
• Up: opens the play list.
• / : adjusts the volume.
• Down: stops playback.
Play MP3 files
In Idle mode, press [ ].
• To scroll through browser items,
press [Up] or [Down].
• To select an item, press [ ].
• To return to the previous page,
press <
Back
> or [
C
].
• To access browser menu
options, press [ ] or select .
• To access web page options,
press [ ].
Launch the
web browser
Navigate the
web
17
Step outside the phone
Use Phonebook
To the phone’s memory:
1. In Idle mode, enter a phone
number and press <
Options
>.
2. Select
Save
→
Phone
→
a
number type.
3. Specify contact information:
First name, Last name, Mobile,
Home, Office, Fax, Other, Email,
Graphic ID, Alert, Group, and
Notes.
4. Press <
Save
> to save the
entry.
To the SIM card:
1. In Idle mode, enter a phone
number and press <
Options
>.
2. Select
Save
→
SIM
.
3. Enter a name.
4. Press [ ] to save the entry.
Add an entry
1. In Idle mode, press
<
Contacts
>.
2. Select an entry.
3. Scroll to a number and press
[]
to dial, or press [ ] to
edit contact information.
1. In Idle mode, press <
Menu
>
and select
Phonebook
→
My
name card
.
2. Specify your contact
information.
3. Press <
Save
> to save the
name card.
4. To send the name card to other
people, press <
Options
> and
select
Send via
→
a sending
method.
Find an entry
Create and
send a name
card
18
Step outside the phone
Send messages
1. In Idle mode, press <
Menu
>
and select
Messages
→
Create
new message
→
Text
message
.
2. Enter the message text.
3. Press <
Options
> and select
Save and send
or
Send only
.
4. Enter destination numbers.
5. Press [ ] to send the
message.
1. In Idle mode, press <
Menu
>
and select
Messages
→
Create
new message
→
Multimedia
message
.
2. Select
Subject
.
3. Enter the message subject and
press [ ].
Send a text
message (SMS)
Send a
multimedia
message
(MMS)
4. Select
Picture & Video
or
Sound
.
5. For
Pictures & Videos
, select
Pictures
or
Videos
and add an
image or video clip.
For
Sound
, select a sound
category and add a sound clip.
6. Select
Message
.
7. Enter the message text and
press [ ].
8. Press <
Options
> and select
Send
.
9. Enter destination numbers or
e-mail addresses.
10.Press [ ] to send the
message.
19
Step outside the phone
View messages
1. In Idle mode, press <
Menu
>
and select
Messages
→
Create
new message
→
Email
.
2. Select
Subject
.
3. Enter the e-mail subject and
press [ ].
4. Select
Message
.
5. Enter the e-mail text and press
[].
6. Select
File attach
.
7. Add image, video, sound, music
files, or document files.
8. Press <
Options
> and select
Send
.
9. Enter e-mail addresses.
10.Press [ ] to send the e-mail.
Send an e-mail
When a notification appears:
1. Press <
View
>.
2. Select the message from the
Inbox.
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messages
→
My
messages
→
Inbox
.
2. Select an SMS message ( ).
When a notification appears:
1. Press <
View
>.
2. Press <
Options
> and select
Retrieve
.
3. Select the message from the
Inbox.
View a text
message
View a
multimedia
message
20
Step outside the phone
Use Bluetooth
Your phone is equipped with Bluetooth technology
which enables you to connect the phone wirelessly to
other Bluetooth devices and exchange data with them,
talk hands-free, or control the phone remotely.
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messages
→
My
messages
→
Inbox
.
2. Select an MMS message ( ).
1. In Idle mode, press <
Menu
>
and select
Messages
→
My
messages
→
Email box
.
2. Select
Check new mail
to
download new e-mails or
headers.
3. Select an e-mail or a header.
4. If you selected a header, press
<
Options
> and select
Retrieve
.
View a
multimedia
message
(continued)
View an e-mail
In Idle mode, press <
Menu
> and
select
Settings
→
Bluetooth
→
Activation
→
On
.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Bluetooth
→
My devices
→
Search new device
.
2. Select a device.
3. Enter a Bluetooth PIN or the
other device’s Bluetooth PIN, if
it has one, and press <
OK
>.
When the owner of the other
device enters the same code,
pairing is complete.
Turn on
Bluetooth
Search for and
pair with a
Bluetooth
device
21
Step outside the phone
Quickly launch menus by number
1. Access an application,
Phonebook
,
File manager
, or
Calendar
.
2. Scroll to an item.
3. Press <
Options
> and select
Send via
→
Bluetooth
.
4. Select a device.
5. If necessary, enter the
Bluetooth PIN and press <
OK
>.
To receive data via Bluetooth, your
phone’s Bluetooth feature must be
active.
If necessary, press <
Yes
> to
confirm the reception.
Send data
Receive data
You can quickly access the alarm,
calendar, and calculator applications
from the dialling screen.
1. For an alarm or scheduled
event, enter the time you want
as 4-digit in Idle mode.
For the calculator, enter the first
number you want to use.
2. Press one of the Navigation
keys.
You can access the following
applications:
Access
applications
Key Application
Up Alarm
p. 41
Down Calendar
p. 65
Left Calculator
p. 42
Right Convertor
p. 42
22
Enter text
ABC, T9, Number, and Symbol mode
You can enter text for some features, such as
Messages, Phonebook, or Calendar, using ABC mode,
T9 mode, Number mode, and Symbol mode.
Changing the text input mode
• Press the right soft key to change the text input
mode. ( : T9 mode, : ABC mode,
: Number mode, and : Symbol mode)
• Press and hold [ ] to switch to Symbol mode.
Using ABC mode
Press the appropriate key until the character you want
appears on the display.
(Creating an SMS message with GSM-alphabet encoding)
Characters in order displayed
Key Upper case Lower case
Enter text
23
Tips for using ABC mode
• To enter the same letter twice or to enter a
different letter on the same key, wait for the cursor
to move to the right automatically or press [Right].
Then, enter the next letter.
• Press [ ] to change the case. Lower case (No
indicator), Initial capital ( ), and Capital lock ( )
are available.
• Press [ ] to insert a space.
• Press the Navigation keys to move the cursor.
•Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
Using T9 mode
T9 is a predictive text input mode that allows you to
key in any character using single keystrokes.
Entering a word in T9 mode
1. Press [
2
] to [
9
]
to start entering a word. Press
each key once for each letter.
For example, press [
4
], [
3
], [
5
], [
5
], and [
6
] to
enter Hello in T9 mode.
T9 predicts the word that you are typing, and it
may change with each key that you press.
2. Enter the whole word before editing or deleting
characters.
3. When the word displays correctly, go to step 4.
Otherwise, press [
0
] to display alternative word
choices for the keys that you have pressed.
For example, Of and Me use [
6
] and [
3
].
4. Press [ ] to insert a space and enter the next
word.
Tips for using T9 mode
• Press [
1
] to enter periods or apostrophes
automatically.
• Press [ ] to change the case. Lower case (No
indicator), Initial capital ( ), and Capital lock ( )
are available.
• Press [ ] to insert a space.
• Press the Navigation keys to move the cursor.
• Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
24
Enter text
Adding a new word to the T9 dictionary
This feature may not be available for some languages.
1. Enter the word that you want to add.
2. Press [
0
] to display alternative words for your key
presses. When there are no more alternative
words,
Spell
appears on the bottom line.
3. Press <
Spell
>.
4. Enter the word you want using ABC mode and
press <
OK
>.
Using Number mode
Number mode enables you to enter numbers.
Press the keys corresponding to the digits you want.
Using Symbol mode
Symbol mode enables you to insert symbols.
To Press
display more symbols [Up] or [Down].
select a symbol the corresponding
number key.
clear the entered symbols [
C
].
insert the symbols <
OK
>.
25
Call functions
Advanced calling features
Making a call
1. In Idle mode, enter the area code and phone
number.
2. Press [ ].
Making an international call
1. In Idle mode, press and hold [
0
]. The
+
character
appears.
2. Enter the country code, area code, and phone
number, then press [ ].
Redialling recent numbers
1. In Idle mode, press [ ] to display the list of
recent numbers.
2. Scroll to the number you want and press [ ].
Making a call from Phonebook
Once you have stored a number in Phonebook, you
can dial the number by selecting it from Phonebook.
p. 31
You can also use the speed dial feature to assign your
most frequently called numbers to specific number
keys.
p. 33
You can quickly dial a number from the SIM card using
its location number assigned when stored.
1. In Idle mode, enter a location number and press
[].
2. Press [Left] or [Right] to scroll through other
numbers.
3. Press <
Dial
> or [ ] to dial the number you want.
Ending a call
Close the phone or press [ ].
• Press [
C
] to clear the last digit or press and hold
[
C
] to clear the whole display. You can move the
cursor to edit an incorrect digit.
• Press and hold [ ] to enter a pause between
numbers.
26
Call functions
Answering a call
When you receive an incoming call, the phone rings
and displays the incoming call image.
Press <
Accept
> or [ ] to answer the call.
Tips for answering a call
• When
Anykey
answer
is active, you can press
any key, except for <
Reject
> or [ ].
p. 75
• When
Active folder
is active, you can simply open
the phone.
p. 75
•Press <
Reject
> or [ ] to reject a call.
• Press and hold [ / ] to reject a call or mute the
ringer, depending on the
Volume key
setting.
p. 74
Viewing missed calls
If you have missed calls, the screen displays how
many calls you have missed.
1. Press <
View
>.
2. If necessary, scroll through the missed calls.
3. Press [ ] to dial the number you want.
Using the headset
Use the headset to make or answer calls without
holding the phone.
Connect the headset to the jack on the left side of the
phone. The button on the headset works as listed
below:
Options during a call
You can access a number of functions during a call.
Adjusting the volume during a call
Use [ / ] to adjust the earpiece volume during a call.
Press [ ] to increase the volume level and [ ] to
decrease the volume level.
To Press
redial the last call the button and then press
and hold it again.
answer a call and hold the button.
end a call and hold the button.
Call functions
27
Using the Speakerphone feature
Use the Speakerphone feature to talk and listen with
the phone a short distance away.
1. During a call, press [ ] to listen and talk to the
other person hands-free. The
icon appears.
2. Press [ ] again to return to normal phone
mode. The icon appears.
Placing a call on hold/Retrieving
Press <
Hold
> or <
Retrieve
> to place a call on hold
or retrieve the call.
Making a second call
You can make another call if your network supports it.
1. Press <
Hold
> to put the call on hold.
2. Make the second call in the normal way.
3. Press <
Swap
> to switch between the calls.
4. Press <
Options
> and select
End
held
call
to end
the call on hold.
5. To end the current call, press [ ].
Answering a second call
You can answer an incoming call while already on the
phone, if your network supports it and you have
activated the call waiting feature.
p. 79
1. Press [ ] to answer the call. The first call is
automatically put on hold.
2. Press <
Swap
> to switch between the calls.
3. Press <
Options
> and select
End
held
call
to end
the call on hold.
4. To end the current call, press [ ].
Using In-call options
Press <
Options
> to access the following options
during a call:
•
Voice clarity on
/
Voice clarity off
: switch off the
phone's microphone so that the other person on
the phone cannot hear you, or switch it back on.
•
Mute
/
Unmute
: switch off the phone’s microphone
so that the other person on the phone cannot hear
you, or switch it back on.
28
Call functions
•
Mute keys
/
Send keys
: switch the key tones on
or off.
•
Phonebook
: access the contact list.
•
Send DTMF
: send the DTMF (Dual tone multi-
frequency) tones as a group. The DTMF tones are
the tones used in phones for tone dialling,
sounding when you press the number keys. This
option is helpful for entering a password or an
account number when you call an automated
system, like a banking service.
•
Message
: create and send an SMS message or
access received messages.
p. 47
•
SIM service
: access special services, such as
news, weather forecasts, entertainment, and
location services, provided by your SIM card. This
option is available when you use a SIM card
supporting SIM AT menus.
•
Transfer
: transfer the currently active call to a
caller on hold. The two callers can talk to each
other, but you are disconnected from the call.
•
End held call
: disconnect the call currently on
hold.
•
Join
: set up a multi-party call by adding a caller
on hold to a currently active call. You can include
up to 5 people on a multi-party call.
•
Split
: have a private conversation with one multi-
party call participant. The other participants can
converse with each other. After the private
conversation, select
Join
to return to the
multi-party call.
•
Remove
: disconnect one multi-party call
participant.
•
Switch to headset
/
Switch to phone
: switch the
call to a Bluetooth headset or hands-free car kit or
back to the phone.
To communicate with answering machines or
computerised telephone systems,
Send keys
must be selected.
29
Menu functions
All menu options listed
Call records
(Menu 1)
Use this menu to view the calls you have dialled,
received, or missed, and the length of calls. You can
also check the cost of your calls,
if your SIM card
supports this function.
To access this menu, press <
Menu
> in Idle mode and
select
Call records
.
Recent contacts
(Menu 1.1)
This menu displays the most recent calls dialled,
received, or missed.
Accessing a call record
1. Press [Left] or [Right] to move to another call
type.
2. Press [Up] or [Down] to scroll through the call list.
3. Press [ ] to view the details of a call, or [ ] to
dial a number.
Using call record options
While viewing call details, press <
Options
> to access
the following options:
•
Save as contacts
: save the number to
Phonebook.
•
Send message
: send an SMS or MMS message to
the selected number.
•
Delete
: delete the selected call record or all
records.
Missed calls
(Menu 1.2)
This menu displays the most recent calls you did not
answer.
Dialled calls
(Menu 1.3)
This menu displays the most recent calls you have
dialled.
Received calls
(Menu 1.4)
This menu displays the most recent calls you have
received.
30
Menu functions
Delete all
(Menu 1.5)
Use this menu to delete all of the records in each call
type.
1. Press [ ] to select the call types to be cleared.
2. Press <
Delete
>.
3. Press <
Yes
> to confirm the deletion.
Call time
(Menu 1.6)
This menu displays the time log for calls made and
received. The actual time invoiced by your service
provider will vary.
•
Last
call
time
: check the length of your last call.
•
Total
sent
: check the total length of all the calls
you have dialled.
•
Total
received
: check the total length of all the
calls you have received.
•
Reset
timers
: reset the call timers. You need to
enter the phone password.
Call costs
(Menu 1.7)
This network feature displays the cost of calls. This
menu is available only if supported by your SIM card.
Note that this is not intended to be used for billing
purposes.
•
Last
call
cost
: check the cost of your last call.
•
Total
cost
: check the total cost of all of your calls.
If the total cost exceeds the maximum cost set in
Set
max
cost
, you must reset the counter before
you can make another call.
•
Max
cost
: check the maximum cost limit set in
Set
max
cost
.
•
Reset
counters
: reset the cost counters.
•
Set
max
cost
: set the maximum cost authorised
for your calls.
•
Price/Unit
: set the price per unit that is applied
when the cost of your calls is calculated.
The password is preset to
00000000
. You can
change this password.
p. 83
Menu functions
Phonebook
(Menu 2)
31
Phonebook
(Menu 2)
You can store phone numbers on your SIM card and in
your phone’s memory. The SIM card and phone’s
memory are physically separate, but they are used as
a single entity called Phonebook.
To access this menu, press <
Menu
> in Idle mode and
select
Phonebook
.
Contact list
(Menu 2.1)
Use this menu to search for numbers in Phonebook.
Finding an entry
1. Enter the first few letters of the name that you
want to find.
2. Select the name from the list.
3. Scroll to a number and press [ ] to dial, or press
[ ] to edit contact information.
Using Phonebook options
While viewing contact details, press <
Options
> to
access the following options:
•
Edit
: edit contact information.
•
Send message
: send an SMS or MMS message to
the selected number, or an e-mail to the selected
address.
•
Copy
: copy the contact to the phone’s memory, to
the SIM card, or the FDN list.
•
Send via
: send the contact via SMS, MMS, e-mail,
or Bluetooth.
•
Delete
: delete the selected contact.
•
Print via Bluetooth
: print the contact information
by connecting the phone to a printer via Bluetooth.
FDN list
(Menu 2.2)
Use this menu to create a list of contacts to be used in
FDN (Fixed Dialling Number) mode, in which the
phone allows outgoing calls only to the specified
phone numbers, if your SIM card supports this
feature. You can activate FDN mode in the
FDN mode
menu.
p. 83
32
Menu functions
Adding a contact
1. From the FDN list, press <
Options
> and select
Add
.
2. Enter your PIN2 and press <
OK
>.
3. Enter information about the contact:
•
Name
: assign a name.
•
Phone number
: add a number.
•
Location
: assign a location number.
4. Press <
Save
>.
Using contact options
You can access contact options by pressing
<
Options
> in Contact list.
Add new contact
(Menu 2.3)
Use this menu to add a new contact to Phonebook.
Storing a number in the phone’s memory
1. Select
Phone
.
2. Change the settings or enter information about the
contact.
•
First name
/
Last name
: assign a name.
•
Mobile
/
Home
/
Office
/
Fax
/
Other
: add a
number in any type.
•
Email
: assign an e-mail address.
•
Graphic ID
: assign an image to alert you to a
call from the person.
•
Alert
: assign a ringtone to alert you to a call
from the person.
•
Group
: assign the contact to a caller group.
•
Notes
: add a memo about the person.
3. Press <
Save
> to save the contact.
Storing a number on the SIM card
1. Select
SIM
.
2. Enter information about the contact.
•
Name
: assign a name.
•
Phone number
: add a number.
•
Location
: assign a location number.
3. Press <
Save
> to save the contact.
To assign a caller ID image, ringtone, or group,
the contact must be saved to the phone’s
memory.
Menu functions
Phonebook
(Menu 2)
33
Group
(Menu 2.4)
Use this menu to organise your contacts in caller
groups.
Adding members to a caller group
1. Select a group.
2. Press <
Options
> and select
Add
→
a contact. To
add more contacts, repeat this step.
Managing caller groups
While viewing the group list, press <
Options
> to
access the following options:
•
View
: display the members of the selected group.
•
Add
: add a new group.
•
Edit
: change the group properties.
•
Send message
: send an SMS, MMS, or e-mail
message to the group members you want.
•
Delete
: delete the selected group. Group
members, however, will not be deleted from
Phonebook.
Speed dial
(Menu 2.5)
Use this menu to assign a speed dial number (2 to 9)
for 8 of your most frequently called numbers.
Assigning speed dial numbers
1. Select a key location from
2
to
9
. Key
1
is reserved
for your voicemail server.
2. Select a contact from the contact list.
3. Select a number, if the contact has more than one
number.
Managing speed dial entries
From the Speed dial screen, press <
Options
> to
access the following options:
•
Add
: assign a number to an unassigned key.
•
View
: check the name and number assigned to a
key.
•
Change
: assign a different number to a key.
•
Remove
: clear the speed dial setting for a key.
Dialling speed dial entries
In Idle mode, press and hold the appropriate key.
34
Menu functions
My name card
(Menu 2.6)
Use this menu to create a name card and send it to
other people.
Saving your name card
The procedure for creating your name card is the
same as the one for saving a phone number in the
phone’s memory.
p. 32
Using name card options
After saving your name card, press <
Options
> to
access the following options:
•
Edit
: edit the name card.
•
Send via
: send the name card via SMS, MMS,
e-mail, or Bluetooth.
•
Exchange namecard
: exchange name cards with
another person via Bluetooth.
•
Remove
: delete the name card.
•
Print via Bluetooth
: print the name card
information by connecting the phone to a printer
via Bluetooth.
Own number
(Menu 2.7)
Use this menu to check your phone numbers, or to
assign a name to each of the numbers. Changes made
here do not affect the actual subscriber numbers on
your SIM card.
Management
(Menu 2.8)
Use this menu to manage Phonebook entries.
•
Default saving
: select a default memory location
for saving contacts. If you select
Ask on saving
,
the phone will ask you to select a memory location
each time you save a number.
•
Copy all to phone
: copy all of the contacts stored
on the SIM card to the phone’s memory.
•
Sort by contacts
: sort your contacts by the first
name or last name.
•
Delete all
: delete all of the contacts from your
phone’s memory, your SIM card, or both.
•
Memory status
: check the number of contacts
you have stored in the phone’s memory and on the
SIM card.
Menu functions
Applications
(Menu 3)
35
Service number
(Menu 2.9)
Use this menu to view the list of Service Dialling
Numbers (SDN) assigned by your service provider,
including emergency numbers and numbers for
directory enquiries. This menu is available if your SIM
card supports SDN.
1. Scroll to the number you want and press <
View
>.
2. Press <
Dial
> or [ ].
Applications
(Menu 3)
Use this menu to play Java games or play music files.
You can also use convenient features, such as a voice
recorder, alarm clock, calculator, converter, stopwatch,
and FM radio.
To access this menu, press <
Menu
> in Idle mode and
select
Applications
.
MP3 player
(Menu 3.1)
Use this menu to enjoy music. First, you need to save
music files into your phone’s memory.
Downloading or receiving music files
Use these methods to save music files to your phone’s
memory:
• Download from the wireless web
p. 43
• Download from a computer using the optional
Samsung PC Studio
Samsung PC Studio User’s
Guide
• Via an active Bluetooth connection
p. 82
The downloaded or received files are stored in the
Music
folder.
p. 63
Creating a play list
1. From the MP3 player screen, press <
Options
>
and select
Add to list
.
2. Select either of the following options:
•
Add all
: add all of the files in the phone’s
memory to the play list.
•
Add a file
: add a specific file to the play list.
3. If you select
Add a file
, scroll to a file and press
<
Add
>.
4. Press <
Back
> to return to the MP3 player screen.
36
Menu functions
Playing music files
From the MP3 player screen, press [ ].
During playback, use the following keys:
Using MP3 player options
From the MP3 player screen, press <
Options
> to
access the following options:
•
Play
/
Pause
: begin or pause playback.
•
Send via
: send the current file via e-mail or
Bluetooth.
•
Open play list
: access the play list.
•
Set as
: set the file as your ringtone, as a ringtone
for a Phonebook entry, or as an alarm melody.
•
Delete
: delete the selected file.
•
Settings
: change the default settings for playing
music files.
Repeat mode
: select a repeat mode.
Shuffle
: set the MP3 player to play music at
random.
Visualisation
: change the playback animation.
Volume
: select a volume level.
•
Properties
: access the file properties.
Key Function
Pauses or resumes playback.
Left Moves back to the previous file. Moves
backward in a file when pressed and held.
Right Skips to the next file. Skips forward in a
file when pressed and held.
Up Opens the play list.
Down Stops playback.
/ Adjusts the volume level.
2
Changes the playback animation.
3
Changes the repeat mode.
6
Turns Shuffle mode on or off.
Menu functions
Applications
(Menu 3)
37
Accessing the play list
From the MP3 player screen, press [Up].
Press <
Options
> to access the following options:
•
Play
: play the currently selected file.
•
Add to list
: add files to the play list.
•
Move list
: move the selected file to the position
you want within the play list.
•
Remove
: remove the selected file or all files from
the play list.
Playing MP3 files with the phone closed
Press and hold [ ] and then [ ] to launch the
MP3 player. Use the following keys to control the MP3
player:
Voice recorder
(Menu 3.2)
Use this menu to record voice memos. A voice memo
can be up to one hour long.
Recording a voice memo
1. Press [ ] to start recording.
2. Speak into the microphone.
Press [ ] to pause or resume recording.
3. Press <
Stop
> or [Down] to end recording. The
voice memo is saved automatically.
4. Press [ ] to review the voice memo, or [Up] to
record a new memo.
Key Function
Begins or pauses playback.
Moves back to the previous file. Moves
backward in a file when pressed and held.
Skips to the next file. Skips forward in a
file when pressed and held.
/ Adjusts the volume.
Locks the exposed keys when pressed and
held to keep accidental presses from
affecting playback.
•: keys locked
• : keys unlocked
Stops playback.
Key Function
38
Menu functions
Playing a voice memo
1. From the Voice recorder screen, press <
Options
>
and select
Go to voice list
.
2. Select a voice memo.
During playback, use the following keys:
Changing the voice recorder settings
You can change the recording settings for the recorder.
Before recording a memo, press <
Options
> and
select
Settings
to access the following options:
•
Recording time
: select a recording time.
•
Volume
: select a volume level.
•
Default name
: change the default prefix of the
voice memo.
Java world
(Menu 3.3)
Use this menu to access the embedded Java games
and downloaded Java applications.
Accessing an embedded game
1. From the Java world screen, select
Downloads
.
2. Select a game.
Using Java game options
From the Java world screen, select
Downloads
and
press <
Options
> to access the following options:
•
Launch
: launch the selected game.
•
Application settings
: set a game to be continued
when a call comes in or an alarm sounds during
the game. You can also set the phone to exchange
game information with the network while playing
an online game or when you need to connect to
the Internet.
•
Delete
: delete the selected game.
•
Properties
: access the game properties.
Key Function
Pauses or resumes playback.
Left Moves backward in a memo.
Right Moves forward in a memo.
/ Adjusts the volume.
Down Stops playback.
Menu functions
Applications
(Menu 3)
39
Configuring Java settings
You can configure profile settings for accessing Java
services.
1. From the Java world screen, select
Settings
.
2. Change the following settings:
•
APN
: enter the access point name.
•
Login ID
: enter the user ID.
•
Password
: enter the password.
•
Proxy
: select whether or not you use a proxy
server to access network services. Depending
on this setting, options in
Proxy settings
vary.
•
Proxy settings
: provide you with the following
options:
When the proxy is set to
Enable
:
IP address
: enter the HTTP proxy IP address.
Port
: enter the proxy port number.
When the proxy is set to
Disable
:
DNS1
: enter the primary address.
DNS2
: enter the secondary address.
Checking memory status
You can view the total amount of memory for the
games as well as the amount of used memory.
From the Java world screen, select
Memory status
.
FM radio
(Menu 3.4)
Use this menu to access the FM radio on your phone.
First, you must connect your phone with the headset,
which serves as a radio antenna.
Finding and setting radio channels
1. Press [ ] to turn on the radio.
2. Press [Left] or [Right] to move to the frequency of
a radio channel.
The frequency moves by 0.1 MHz increments.
Otherwise, press and hold [Left] or [Right] to
automatically scan through and save available
radio frequencies.
3. Press <
Options
> and select
Add
.
4. Enter a name for the channel and press [ ].
40
Menu functions
5. Select the channel number to be assigned to the
frequency.
Listening to the radio
1. From the FM radio screen, scroll to a radio channel.
2. Press [ ] to turn on the radio.
Press [ / ] to adjust the volume.
3. To turn off the radio, press [ ].
Using radio options
On the FM radio screen, press <
Options
> to access
the following radio options:
•
FM radio on
/
FM radio off
: turn the radio on or
off.
•
Add
: add a radio channel. You can store up to 30
channels.
•
Edit
: edit the name or frequency for the channel.
•
Self-tuning
: let the phone automatically scan
through and save available radio frequencies.
•
Remove
: remove the selected channel or all
channels.
•
Pop-up alert
: set the phone to alert you to listen
to the radio at a specific time. When the pop-up
notification appears on the screen, press <
Listen
>
to turn on the specified radio channel.
•
Speaker on
/
Earphone on
: change the audio
mode to the phone’s speaker or headset.
•
Settings
: select the radio volume.
Listening to the radio with the phone closed
1. Press and hold [ ] and then [ ] to access
the radio.
2. Select a channel or frequency by pressing [ ] or
[ ] and press [ ] to turn on the radio.
Press [ / ] to adjust the volume.
3. Press and hold [ ] to turn off the radio.
• You can answer an incoming call or use other
phone functions while listening to the radio.
• The quality of the radio broadcast depends on
the radio station’s coverage in that particular
area.
Menu functions
Applications
(Menu 3)
41
World time
(Menu 3.5)
Use this menu to set your local time zone and find out
what time it is in another part of the world.
Setting your local time zone
1. From the world map, press [Left] or [Right] to
scroll to the city you want. As the time line moves,
the time and date of the given zone display.
2. Press [ ] to save the city as your local time
zone.
Viewing and setting a foreign time zone
1. From the world map, press [Down].
2. Press [Left] or [Right] to select the foreign time
zone you want.
3. Press [ ] to save the time zone.
Applying daylight savings time
1. From the world map, press <
Options
> and select
Set daylight saving time
.
2. Press [ ] to select the time zones you want.
3. Press <
Save
>.
Alarm
(Menu 3.6)
Use this menu to set alarms. The alert type for a
normal alarm corresponds to the call alert type
settings. A wake-up alarm is not affected by your
sound settings.
Setting an alarm
1. Select the type of alarm.
2. Set each alarm option:
•
Alarm
: activate the alarm.
•
Alarm time
: enter the time for the alarm to
ring.
•
AM/PM
: set
AM
or
PM
in 12-hour format.
•
Alarm day
: select the days you want.
•
Alarm tone
: select an alarm tone.
3. Press <
Save
>.
Stopping an alarm
• For a non-wake-up alarm, press any key.
• For a wake-up alarm, press <
OK
> or [ ].
Press any key, except <
OK
> and [ ], to cause
it to sound again after 5 minutes. You can do this a
maximum of 5 times.
42
Menu functions
Setting the alarm to ring even if the phone is
off
From the Alarm screen, select
Auto power
→
On
.
If the phone is off when it is time for the alarm to ring,
the phone switches on and sounds the alarm.
Calculator
(Menu 3.7)
Use this menu to perform basic arithmetic functions,
such as addition, subtraction, multiplication, and
division.
1. Enter the first number.
•Press <
.()
> to insert a decimal point or
bracket.
•
Press
[] or []
to move the cursor.
2. Press one of the Navigation keys to access the
math function you want.
3. Enter the second number.
4. Press [ ] to view the result.
5. If necessary, repeat from step 2 to continue the
calculation.
Convertor
(Menu 3.8)
Use this menu for common conversions, such as
currency and temperature.
Performing a conversion
1. Select a converter.
2. Press [Left] or [Right] to select the original unit
and press [Down].
3. Enter the value to be converted and press [Down].
• Press [ ] to insert a decimal point.
• Press [ ] to change the temperature to above
zero (+) or below zero (-).
4. Press [Left] or [Right] to select the unit to which
you want to convert.
The equivalent value for the amount you entered
displays.
Using converter options
Press <
Options
> to access the following options:
•
Clear
: clear the current values.
•
Reverse
: reverse the conversion.
•
Currency rates
: edit the currency rate list.
Menu functions
Browser
(Menu 4)
43
Timer
(Menu 3.9)
Use this menu to set a period of time for the phone to
count down. The phone will sound an alarm when the
specified period of time has expired.
Starting the timer
1. Press <
Set
>.
2. Enter the length of time you want to count down
and press <
OK
>.
3. Press [ ] to start counting down.
Stopping the timer
• Press any key when the timer rings.
• Press [ ] on the Timer screen to stop the timer
before it rings.
Stopwatch
(Menu 3.10)
Use this menu to measure elapsed time. The
maximum time is 10 hours.
1. Press [ ] to start the stopwatch.
2. Press [ ] to check an interval. You can repeat
this step for a total of 4 intervals.
SIM AT
(Menu 3.11)
This menu is available if you use a SIM AT card that
supports SIM Application Tool kit menus and provides
additional services, such as news, weather, sports,
entertainment, and location services. Available
services may vary, depending on your service
provider’s plans. For details, see your SIM card
instructions or contact your service provider.
Browser
(Menu 4)
The Wireless Application Protocol (WAP) browser on
your phone allows you to access the wireless web.
From the wireless web, you can access up-to-date
information and a wide variety of media content, such
as games, wallpapers, ringtones, and music files.
To access this menu, press <
Menu
> in Idle mode and
select
Browser
.
44
Menu functions
Home
(Menu 4.1)
Use this menu to connect your phone to the network
and load the homepage of the wireless web service
provider. You can also press [ ] in Idle mode.
Navigating the web browser
Using browser menu options
Press [ ] or select on the top of screen.
•
Back
: go back to the previous page.
•
Home
: return to the homepage.
•
Exit
: exit the web browser.
•
Reload
: reload the current page with updated
information.
•
Show URL
: display the URL address of the current
web page. You can also set the current page as the
homepage for the web browser.
•
About...
: access version and copyright information
about the browser.
Using web page options
From any web page, press [ ] to access the following
options:
•
Go to URL
: enter a URL address manually.
•
Bookmarks
: switch to the
Bookmarks
menu.
p. 45
•
Messages
: check the messages stored in the
My
Messages
folder. You can also create and send a
new SMS message.
p. 47
•
File manager
: switch to the
File manager
menu.
p. 61
Exiting the browser
Press [ ] to end the network connection and exit the
browser.
To Press
scroll through browser
items [Up] or [Down].
select a browser item [ ] or < >.
return to the previous
page <
Back
> or [
C
].
return to the homepage and hold [
C
].
Menu functions
Browser
(Menu 4)
45
Bookmarks
(Menu 4.2)
Use this menu to save URL addresses in order to
quickly access web pages.
Adding a bookmark
1. Select an empty location.
2. Enter a title for the bookmark and press [Down].
3. Enter a URL address and press [ ].
Accessing a bookmarked page
Selecting a bookmark item launches the web browser
and accesses the associated web page.
Using bookmark options
After saving an item, press <
Options
> to access the
following options:
•
Go
: access the bookmarked web page.
•
Edit
: edit the URL address and title of the
bookmark.
•
Delete
: delete the selected bookmark.
Go to URL
(Menu 4.3)
Use this menu to manually enter a URL address and
access the associated web page.
Clear cache
(Menu 4.4)
Use this menu to clear information stored in the cache,
which is the temporary memory that stores the web
pages you have recently accessed.
Profile settings
(Menu 4.5)
Use this menu to set up servers for the web browser.
Contact your service provider for details about your
setting options.
For each server, the following options are available:
•
Profile
name
: assign a name to the server profile.
•
Home
URL
: set the address of your homepage.
•
Bearer
: select a bearer for each type of network
address accessed.
46
Menu functions
•
Proxy
: select whether or not the phone uses a
proxy server to launch the web browser. Your
service provider can tell you if your network
requires a proxy server, and they can give you the
appropriate settings.
•
GPRS settings
: customise the following GPRS
network settings:
When the proxy is set to
Enable
:
Proxy IP
: enter the proxy IP address.
Proxy port
: enter the proxy port number.
APN
: enter the access point name of the GPRS
network gateway.
Login ID
: enter the user ID.
Password
: enter the password.
When the proxy is set to
Disable
:
DNS1
: enter the primary address.
DNS2
: enter the secondary address
.
APN
: enter the access point name of the GPRS
network gateway.
Login ID
: enter the user ID
.
Password
: enter the password
.
•
GSM settings
: customise the following GSM
network settings:
When the proxy is set to
Enable
:
Proxy IP
: enter the proxy IP address.
Proxy port
: enter the proxy port number.
Dial number
: enter the PPP server phone number.
Login ID
: enter the user ID.
Password
: enter the password.
Data call type
: select a data call type.
When the proxy is set to
Disable
:
DNS1
: enter the primary address.
DNS2
: enter the secondary address.
Dial number
: enter the PPP server phone number.
Login ID
: enter the user ID.
Password
: enter the password.
Data call type
: select a data call type.
Current profile
(Menu 4.6)
Use this menu to select a connection profile for
accessing the web browser.
Menu functions
Messages
(Menu 5)
47
Messages
(Menu 5)
Use the
Messages
menu to send and receive text
messages, multimedia messages, and e-mails. You
can also use push message and cell broadcast
message features.
To access this menu, press <
Menu
> in Idle mode and
select
Messages
.
Create new message
(Menu 5.1)
Use this menu to create and send messages.
Text message
(Menu 5.1.1)
Short Message Service (SMS) allows you to send or
receive text messages that may include simple
pictures, animated images, and melodies.
1. Enter your message.
2. Press <
Options
> to access the following options
for creating a message:
•
Insert
: add a template, Phonebook entry, or
bookmark to text.
•
Add picture
/
Add animation
/
Add melody
:
attach a simple image, animated image, or
melody.
•
Attach
: attach a Phonebook entry as a name
card or calender data as a data format
attachment.
•
Text style
: change the text attributes.
3. When you have finished, press <
Options
> and
select
Save and send
or
Send only
.
4. Enter a destination number.
To send the message to more than one recipient,
fill in additional destination fields.
5. Press [ ] to send the message.
The maximum number of characters allowed in a
message varies by service provider. If your
message exceeds the maximum number of
characters, the phone will split the message.
48
Menu functions
Multimedia message
(Menu 5.1.2)
Multimedia Message Service (MMS) delivers messages
containing a combination of text, image, video, and
audio, from phone to phone or from phone to e-mail.
1. Select the
Subject
line.
2. Enter the message subject and press [ ].
3. Select the
Picture & Video
or
Sound
line and add
an image, a video, or a sound file.
4. Select the
Message
line.
5. Enter the message text and press [ ].
6. Press <
Options
> to access the following options
for editing the message:
•
Edit
: edit the subject or text of your message.
•
Change image
/
Change video
/
Change
sound
: replace an added item.
•
Add page
: add pages. Move to each page by
pressing [Left] or [Right] on the message
screen.
•
Delete page
: delete an added page.
•
Edit page
: change the duration of page display
or move the page forward among the other
pages.
•
Attach
: attach a Phonebook entry as a name
card or calender data as a data format
attachment.
•
Remove subject
/
Remove media
/
Remove
sound
/
Remove message
: remove an added
item.
7. When you have finished, press <
Options
> and
select
Send
.
8. Enter a phone number or e-mail address.
To send the message to more than one recipient,
fill in additional destination fields.
9. Press [ ] to send the message.
• The maximum size allowed for a message can
differ, depending on your service provider.
• Depending on the file type or DRM (Digital
Rights Management) system, some files may
not be able to be forwarded.
Menu functions
Messages
(Menu 5)
49
Email
(Menu 5.1.3)
You can create and send e-mails that include text,
audio, and images. To use this feature, you need to
subscribe to an e-mail service and set up your e-mail
account and profile.
p. 58
1. Select the
Subject
line.
2. Enter the subject of your e-mail and press [ ].
3. Select the
Message
line.
4. Enter the e-mail text and press [ ].
5. Select the
File attach
line and select one of the
following options to add files:
•
Add image
/
Add videos
/
Add sounds
/
Add
music
: add media files stored in the phone’s
memory.
•
Other files
: add document files stored in the
Other files
folder.
•
Attach
: attach name cards or calender data as
data format attachments.
6. Press <
Options
> to access the following options
to edit the e-mail:
•
Edit
: edit the subject or text.
•
Remove subject
/
Remove message
: clear
the subject or text.
•
Remove
: delete the selected attachment or all
attachments.
•
Remove all attachments
: delete all
attachments.
7. When you have finished, press <
Options
> and
select
Send
.
8. Enter an e-mail address.
To send the e-mail to more than one recipient, fill
in additional destination fields.
9. Press [ ] to send the e-mail.
Depending on the file type or DRM (Digital
Rights Management) system, some files may
not be able to be forwarded.
50
Menu functions
My messages
(Menu 5.2)
Use this menu to access messages you have received,
sent, or which have failed in sending.
Inbox
(Menu 5.2.1)
This folder stores all of the messages you have
received, except for e-mails.
Viewing a message
The following icons may appear on the message list to
show the message type:
• SMS or delivery report for your sent messages
• MMS
• MMS notification ( : Being retrieved,
: Failed to retrieve)
• Push message from web servers.
• Configuration message, containing network
parameters from your service provider.
Using message options
While viewing a message, press <
Options
> to access
the following options:
SMS messages
•
Reply via
: reply to the sender via SMS or MMS.
•
Forward
: forward the message to other people.
•
Delete
: delete the message.
•
Move to phone
/
Move to SIM
: move the
message between the SIM card and the phone’s
memory.
•
Add to block list
: add the sender’s number to the
Block list to reject the messages from the sender.
•
Cut address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Cut media
: save media content from the message
to your phone’s memory.
• Depending on the DRM (Digital Rights
Management)
system, messages having web
content may not be
able to be forwarded.
• A
!
icon next to a message means that the
message is of high priority. A grey-coloured
message icon indicates low priority.
Menu functions
Messages
(Menu 5)
51
•
Print via Bluetooth
: print the message by
connecting the phone to a printer via Bluetooth.
•
Protection
: protect the message from being
deleted.
MMS messages
/
MMS notifications
•
Retrieve
: retrieve the MMS message from the
MMS server.
•
Reply via SMS
: reply to the sender via SMS.
•
Reply via MMS to
: reply to the sender or all
recipients via MMS.
•
Forward
: forward the message to other people.
•
Delete
: delete the message.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Cut media
: save media content from the message
to your phone’s memory.
•
Properties
: access the message properties.
Delivery reports
•
Delete
: delete the report.
Configuration messages
•
Install
: apply the configuration specified in the
message to your phone.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Delete
: delete the message.
•
Protection
: protect the message from being
deleted.
Push messages
•
Go to URL
: connect to the URL specified in the
message.
•
Delete
: delete the message.
•
Cut address
: extract URLs, e-mail addresses, or
phone numbers from the message.
Drafts
(Menu 5.2.2)
This folder stores messages you have saved to send at
a later time.
When you select an SMS or e-mail message, it opens
in Edit mode so that you can edit and/or send the
message.
52
Menu functions
When you select an MMS message, it opens in Preview
mode as would a message from the Inbox. To edit the
MMS message, press <
Options
> and select
Edit
.
Outbox
(Menu 5.2.3)
This folder stores messages that the phone is
attempting to send or has failed to send.
The following icons are available to show the message
status:
• SMS message failed to send
• MMS message being sent
• MMS message failed to send
• E-mail being sent
• E-mail failed to send
While viewing a message, press <
Options
> to access
the following options:
•
Open file
: open the attached file.
•
Save file
: save the attached file in the phone’s
memory.
•
Send again
: retry sending the message.
•
Forward
: forward the message to other people.
•
Delete
: delete the message.
•
Move to phone
/
Move to SIM
: move the
message between the SIM card and the phone’s
memory.
•
Protection
: protect the message from being
deleted.
•
Properties
: access the message properties.
•
Print via Bluetooth
: print the message by
connecting the phone to a printer via Bluetooth.
Sentbox
(Menu 5.2.4)
This folder stores messages that you have sent.
While viewing a message, press <
Options
> to access
the following options:
•
Open file
: open the attached file.
•
Save file
: save the attached file in the phone’s
memory.
•
Forward
: forward the message to other people.
•
Delete
: delete the message.
•
Move to phone
/
Move to SIM
: move the
message between the SIM card and the phone’s
memory.
Menu functions
Messages
(Menu 5)
53
•
Print via Bluetooth
: print the message by
connecting the phone to a printer via Bluetooth.
•
Properties
: access the message properties.
Email box
(Menu 5.2.5)
This folder stores e-mails that you have received.
Viewing an e-mail
1. Select an e-mail account.
2. Press <
Select
> when
Check new mail
displays.
The phone checks the e-mail server and downloads
new e-mails.
The following icons may appear on the list to show
the e-mail status:
• Retrieved from the server
• Being retrieved
• Failed to retrieve.
3. Select an e-mail or a header.
4. Press [ / ] to view other pages in the
e-mail.
Press and hold [ / ] to move to the first or last
page in the e-mail.
5. Press [ ] or [ ] to view the previous or next
e-mail.
Using e-mail options
While viewing the e-mail or header, press <
Options
>
to access the following options:
•
Retrieve
: retrieve the body of the e-mail from the
e-mail server.
•
Open file
: open the attached file.
•
Save file
: save the attached file in the phone’s
memory.
•
Reply to
: send a reply to the sender or to the
sender and all of the other recipients.
•
Forward
: forward the e-mail to other people.
•
Delete
: delete the e-mail.
•
Add to block list
: add the sender’s e-mail
address or subject to the Block list to reject
e-mails from that address or containing that
subject.
A
!
icon next to a message means that the
message is of high priority. A grey-coloured
message icon indicates low priority.
54
Menu functions
•
Cut address
: extract URLs, e-mail addresses, or
phone numbers from the e-mail.
•
Cut attachment
: save the attached files from the
e-mail to your phone’s memory.
•
Print via Bluetooth
: print the e-mail by
connecting the phone to a printer via Bluetooth.
•
Protection
: protect the e-mail from being deleted.
•
Properties
: access the e-mail properties.
My folders
(Menu 5.2.6)
Use this menu to view the messages you have moved
to this folder using the
Move to my folder
option
while viewing a message list.
Templates
(Menu 5.3)
Use this menu to make and use templates of
frequently used messages.
Text template
(Menu 5.3.1)
You can create SMS templates with the sentences you
use frequently so that you can retrieve and insert
them when composing an SMS, MMS, or e-mail
message.
Creating a template
1. Select an empty location.
2. Enter a message and press [ ].
Using template options
From the template list, press <
Options
> to access
the following options:
•
Edit
: edit the selected template.
•
Send message
: create and send a new message.
•
Delete
: delete the selected template.
MMS template
(Menu 5.3.2)
You can access embedded MMS templates or ones you
have saved so that you can use them in composing an
MMS message.
From the template list, press <
Options
> to access
the following options:
•
View
: open the selected template.
•
Send message
: create and send a new message.
•
Edit
: edit the selected template.
•
Add new
: add a new template.
Menu functions
Messages
(Menu 5)
55
•
Delete
: delete the selected template or all
templates, except for the embedded ones.
Delete all
(Menu 5.4)
Use this menu to delete messages in each message
folder all at once.
1. Press [ ] to select the message folders to be
cleared.
Pressing the key twice displays the message types
so that you can specify the ones to be cleared.
2. Press <
Delete
>.
3. Press [ ] to select the check box to delete
protected messages, and then press <
Yes
>.
4. Press <
Yes
> to confirm the deletion.
Settings
(Menu 5.5)
Use this menu to set up various options for using the
messaging service.
Text message
(Menu 5.5.1)
You can configure SMS settings.
•
Send settings
: set up the options for sending
SMS messages:
Reply path
: allow recipients to reply to you
through your SMS server.
Delivery report
: set the network to inform you
when your messages have been delivered.
Character support
: select a character encoding
type. If you select
Auto
, the phone switches the
encoding type from GSM-alphabet to Unicode if
you enter a Unicode character. Use of Unicode
encoding will reduce the maximum number of
characters in a message to about half. If this menu
is not shown, your phone provides automatic
character encoding by default.
Validity period
: set the length of time your
messages are stored in the SMS server.
Message type
: set the default message type. The
network can convert the messages into the
selected format.
Service centre
: store or change the number of
your SMS server.
56
Menu functions
•
Block number
: store the phone numbers from
which you want to reject messages.
Multimedia message
(Menu 5.5.2)
You can configure MMS settings.
•
Sending settings
: set up the options for sending
MMS messages:
Delivery report
: set the network to inform you
when your messages have been delivered.
Address hiding
: set your address to be hidden
from the recipient’s phone.
Read reply
: send a read-reply request along with
your messages.
Priority
: set the priority level of messages.
Expiry date
: set the length of time messages are
stored in the MMS server.
Delivery after
: set a time delay before messages
are sent.
Send size
: select a maximum size of attached
items allowed for messages.
•
Receive settings
: set up the options for receiving
MMS messages:
Anonymous reject
: reject messages from
unknown senders.
Advert allowed
: accept advertisements.
report allowed
: set the network to inform the
sender when a message has been delivered to you.
Home reception
: determine if your phone
retrieves new messages automatically when you
are in your home service area.
Roaming reception
: determine if your phone
retrieves new messages automatically when you
are roaming on another network.
Reception within home network or abroad has the
following options:
-
Automatic
: the phone automatically retrieves
messages from the server.
-
Reject
: the phone rejects all messages.
-
Manual
: the phone displays notifications. Use
the
Retrieve
option to manually download new
messages.
Menu functions
Messages
(Menu 5)
57
•
MMS profiles
: configure required network
settings for MMS.
Current profile
: select a profile.
Profile settings
: customise the options for each
profile:
-
Profile name
: assign a name to the MMS profile.
-
Server URL
: enter the address of your MMS
server.
-
Proxy
: connect to the GPRS network using the
proxy server.
-
GPRS settings
: customise the settings required
for connecting to the GPRS network.
when the proxy is set to
Enable
:
IP address
: enter the gateway address.
Port
: enter the port number.
APN
: enter the access point name used for the
address of the GPRS network.
Login ID
: enter the user ID.
Password
: enter the password.
when the proxy is set to
Disable
:
DNS1
: enter the primary address.
DNS2
: enter the secondary address.
APN
: enter the access point name used for the
address of the GPRS network.
Login ID
: enter the user ID.
Password
: enter the password.
-
Version
: select an available OMA version and
maximum size limit for sending or receiving
messages.
•
Block number
: set the Block number list to reject
MMS messages from specific phone numbers.
Email
(Menu 5.5.3)
You can configure default e-mail settings.
Depending on your service provider, it may not
be possible to support the maximum limit
295KB. In this case, try again after changing
the setting to 100KB.
You cannot change e-mail profile and account
settings while an e-mail is being sent or retrieved.
58
Menu functions
•
Send settings
: set up the options for sending
e-mails:
Send copy to self
: send a copy of your e-mails to
your e-mail account.
Delivery confirm
: set the network to inform you
when your e-mails have been delivered.
Read confirm
: send a read-reply request along
with e-mails.
Priority
: select the priority level of e-mails.
Include signature
: attach your name, phone
number or a simple memo to your e-mails.
Edit name
: edit the name in your signature.
Edit telephone number
: edit the phone number
in your signature.
Edit note
: edit the tag line in your signature.
•
Receive settings
: set up the options for receiving
e-mails:
Check interval
: determine how often the phone
checks the server for incoming e-mails. If you
select
Not used
, use the
Check new mail
feature
to receive new e-mails manually.
Read reply
: determine whether or not the phone
sends a read-reply for incoming e-mails. If you
select
Announce
, the phone asks you to send a
read-reply.
Retrieve option
: set whether the phone
downloads e-mail headers only or e-mail headers
and bodies both.
Delete option
: determine whether e-mails are
deleted immediately or the next time you connect
to the server.
Reject if over
: determine the maximum size for
incoming e-mails. Your phone will reject
e-mails that exceed the specified size.
Leave a copy of messages on server
: leave
copies of e-mails on the e-mail server after
retrieving.
•
Email account
: set up an e-mail account and
select an account to be used.
Current account
: select an account.
Account settings
: configure e-mail accounts
using different e-mail servers. Set the options for
each account:
Menu functions
Messages
(Menu 5)
59
-
In use
: select this option to use the account and
to display the account in the
Email box
folder.
-
Account name
: enter a name for the currently
selected account.
-
User name
: enter a user name.
-
Email address
: enter your e-mail address.
-
Reply address
: enter your e-mil address to be
used when the recipient sends a reply.
-
User ID
: enter your e-mail ID.
-
Password
: enter your e-mail password.
-
SMTP server
: enter the IP address or host name
of the outgoing e-mail server.
-
SMTP port
: enter the SMTP port number.
-
Protocol type
: select the protocol for the
incoming e-mail server. The remaining options
depend on the protocol type setting.
When the protocol type is
POP3
:
-
POP3 server
:
enter the IP address or host name
of the server that receives your e-mail.
-
POP3 port
: enter the POP3 port number.
-
APOP login
: connect to the server by using the
APOP login scheme.
When the protocol type is
IMAP4
:
-
IMAP4 server
: enter the IP address or host
name of the server that receives your e-mail.
-
IMAP4 port
: enter the IMAP4 port number.
-
Include attachments
: select this option to
receive attachments with e-mails.
-
Max. Emails retrieved
: set the number of
headers you will retrieve from the server.
•
Email profile
: select a connection profile to be
used for e-mail services.
Current profile
: select a profile.
Profile settings
: configure up to five e-mail
profiles. For each profile, the options are required
to connect to the GPRS network:
-
Profile name
: enter a name for the e-mail
profile.
You cannot change e-mail profile settings while an
e-mail is being sent or retrieved.
60
Menu functions
-
APN
: enter the access point name used for the
GPRS network address.
-
Login ID
: enter the user ID.
-
Password
: enter the password.
-
DNS1
: enter the primary address.
-
DNS2
: enter the secondary address.
•
Block list
: specify e-mail addresses or subjects
you want to reject.
Push message
(Menu 5.5.4)
You can change the settings for receiving push
messages from the wireless web server.
•
Receive
: set how your phone receives push
messages.
•
Service centre
: enter the address of the server
from which you want to receive push messages.
B
roadcast messages
(Menu 5.6)
The Cell Broadcast service delivers short messages on
various topics, such as weather, sports, or traffic.
Use this menu to change the settings for the service
and to access broadcast messages.
•
Read
: open received messages.
The
Temporary
box saves network messages until
the phone is switched off.
The
Archive
box saves network messages
indefinitely. Press <
Options
> and select
Save
to
save messages to the
Archive
box when a text
notification appears.
•
Receive
: enable or disable the reception of
broadcast messages.
•
Channel
: specify the channels from which you
receive broadcast messages.
When you select
Respective channels
, you can
set up a list of active CB channels.
•
Language
: select the language(s) in which
broadcast messages display.
Please contact your service provider for details.
Memory status
(Menu 5.7)
Use this menu to view the amount of memory
currently in use in each folder.
Menu functions
File manager
(Menu 6)
61
File manager
(Menu 6)
The
File manager
menu allows you to access images,
videos, music files, and sound files stored in the
phone’s memory.
To access this menu, press <
Menu
> in Idle mode and
select
File manager
.
Images
(Menu 6.1)
This menu displays photos you have taken and images
you have downloaded, received in messages, or
imported from your computer.
Viewing an image
1. Select an image folder.
2. Select an image.
Viewing a slide show
You can view your photos as a slide show, a sequential
presentation of each photo in the current folder.
1. Select
Photos
.
2. Press <
Options
> and select
Slide show
.
3. Select an interval option.
The slide show begins.
4. Press <
Cancel
> to stop the slide show.
Using image options
While viewing an image, press <
Options
> to access
the following options:
•
List
: return to the image list.
•
Send via
: send the file via MMS, e-mail, or
Bluetooth.
•
Set as
: set the image as wallpaper for the displays
or as a caller ID image for a Phonebook entry.
•
Edit
: decorate the photo by adding emoticons or
applying a frame or special effect.
•
Delete
: delete the file.
As a result of the Digital Rights Management (DRM)
system, some of the media items you download from
the Internet or receive by MMS may require a license
key to access them.
62
Menu functions
•
Rename
: change the file name.
•
Move to favourite images
/
Move to
: move the
file to another folder.
•
Share for Bluetooth
: share the file or all files
with other Bluetooth devices.
•
Print via Bluetooth
: print the image by
connecting the phone to a printer via Bluetooth.
•
Protection
: protect the file from being deleted.
•
Properties
: access the file properties.
Videos
(Menu 6.2)
This menu displays video clips you have recorded,
downloaded, received in messages, or imported from
your computer.
Playing a video clip
1. Select a video folder.
2. Select a video clip.
During playback, use the following keys:
Using video options
From a video screen, press < > to access the
following options:
•
Play
: play the file.
•
Send via
: send the file via MMS, e-mail, or
Bluetooth.
•
Delete
: delete the file.
•
Rename
: change the file name.
•
Move to favourite videos
/
Move to
: move the
file to another folder.
Video clips recorded on other devices, such as
camcorders, may not play correctly.
Key Function
Pauses or resumes playback.
Left Moves backward in a file.
Right Skips forward in a file.
/ Adjusts the volume.
Down Stops playback.
Menu functions
File manager
(Menu 6)
63
•
Share for Bluetooth
: share the file with other
Bluetooth devices.
•
Protection
: protect the file from being deleted.
•
Properties
: access the file properties.
Music
(Menu 6.3)
This menu displays MP3 files you have downloaded or
imported from your computer.
Select a file. The MP3 player opens.
p. 36
Sounds
(Menu 6.4)
This menu displays voice memos you have recorded,
and sound files you have downloaded, received in
messages, or imported from your computer.
Playing a sound clip
1. Select a sound folder.
2. Select a sound clip. For a voice memo, see
Voice
recorder
.
p. 38
Using sound options
From a sound screen, press <
Options
> to access the
following options:
•
List
: return to the sound list.
•
Send via
: send the file via MMS, e-mail, or
Bluetooth.
•
Set as
: set the sound as your call ringtone, a
ringtone for a Phonebook entry, or alarm melody.
•
Delete
: delete the file.
•
Rename
: change the file name.
•
Move to favourite sounds
/
Move to
downloaded sounds
: move the file to another
folder.
•
Share for Bluetooth
: share the file with other
Bluetooth devices.
•
Protection
: protect the file from being deleted.
•
Properties
: access the file properties.
64
Menu functions
Other files
(Menu 6.5)
Files that you have received but which are not
supported by your phone are stored in this folder. You
cannot open these files on the phone. Unsupported file
formats include *.doc, *.ppt, and *.txt.
Memory status
(Menu 6.6)
Use this menu to view memory information for media
items in the phone’s memory.
Calendar
(Menu 7)
The
Calendar
menu enables you to keep track of your
schedule.
To access this menu, press <
Menu
> in Idle mode and
select
Calendar
.
Consulting the calendar
When you enter the
Calendar
menu, the calendar in
Month view appears with today’s date indicated by a
blue box.
Selecting a day
• Press [Left] or [Right] to move by day.
• Press [Up] or [Down] to move by week.
• Press [ / ] to move by month.
Using calendar options
Press <
Options
> to access the following options:
•
View mode
: change the view mode of the
calendar.
p. 67
•
Create
: add a new event.
next section
•
Go to
: select today’s date or enter a specific date.
•
Sort by
: sort items by type of event.
•
Delete
: delete the items stored on the calendar by
using various deleting options.
•
Missed alarm events
: view events whose alarms
you have missed.
•
Memory status
: access memory information for
the event items stored on the calendar.
Menu functions
Calendar
(Menu 7)
65
Creating an event
You can store scheduled events, anniversaries,
miscellaneous events, and To do items on the
calendar. More than one event per day can be stored.
Entering a new scheduled event
1. Select a date on the calendar.
2. Press <
Options
> and select
Create
→
Schedule
or
Miscellaneous
.
3. Enter information or change the settings:
•
Subject
: enter a title for the event.
•
Details
: enter event details.
•
Start date
and
Start time
: enter the starting
date and time for the event.
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
•
End date
and
End time
: enter the ending date
and time for the event.
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
•
Location
: (for
Schedule
) enter information
about the event location.
•
Alarm
: set an alarm for the event.
•
before
: set how long before the event the
alarm is to alert you.
•
Alarm tone
: select an alarm tone.
•
Repeat
: (for
Schedule
) set the event to recur
and select a repeat unit.
•
until
: (for
Schedule
) set the ending date, if
the event will recur.
4. Press <
Save
> to save the event.
Entering a new anniversary
1. Select a date on the calendar.
2. Press <
Options
> and select
Create
→
Anniversary
.
3. Enter information or change the settings:
•
Occasion
: enter information about the
anniversary.
•
Date
: enter the date.
•
Alarm
: select to set an alarm for the
anniversary.
•
before
: set how long before the event the
alarm is to alert you.
66
Menu functions
•
Alarm time
: enter the time for the alarm to
ring.
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
•
Alarm tone
: select an alarm tone.
•
Repeat every year
: set the phone to remind
you of the anniversary every year.
4. Press <
Save
> to save the event.
Entering a To do item
1. Select a date on the calendar.
2. Press <
Options
> and select
Create
→
To do
.
3. Enter information or change the settings:
•
To do
: enter information about the item.
•
Start date
: enter the starting date.
•
Due date
: enter the ending date.
•
Priority
: select a priority level.
4. Press <
Save
> to save the event.
Viewing an event
Once you have scheduled events, the event icons and
the number of events for a specific day appears at the
bottom of the calendar.
Accessing an event
1. Select a date on the calendar to display the events
for the day.
2. Select an event to view its details.
3. Press [Left] or [Right] to access the other events
scheduled for the selected day.
Using event options
While viewing an event, press <
Options
> to access
the following options:
•
Edit
: edit the event.
•
Create
: add a new event.
•
Send via
: send the event via SMS, MMS, e-mail,
or Bluetooth.
• Scheduled event • Anniversary
• To do item • Miscellaneous event
Menu functions
Camera
(Menu 8)
67
•
View mode
: change the view mode of the
calendar.
•
Done
/
Undone
: change the status of the to-do
item.
•
Delete
: delete the event.
•
Print via Bluetooth
: print the event by
connecting the phone to a printer via Bluetooth.
Viewing an event in a different mode
You can change the calendar display to Day view or
Week view. Press <
Options
> and select
View mode
→
a view mode.
Day view
You can view events for the selected date. Select an
event to view its details.
The following icons may display to indicate the event
status:
• Alarm set
• Recurring event
• To do item priority (Red: high, Blue: normal,
Grey: low)
• Completed To do item
Week view
You can view events for the selected week. A cell on
the timetable indicates the presence of a schedule
item. Select a cell in the day you want.
Camera
(Menu 8)
You can use the camera module embedded in your
phone to take photos and record videos.
To access this menu, press <
Menu
> in Idle mode and
select
Camera
, or press and hold
[
]
.
Taking a photo
You can take photos in various modes. The camera
produces JPEG photos.
• Do not take photos of people without their
permission.
• Do not take photos in a place where cameras are
not allowed.
• Do not take photos in a place where you may
interfere with another person’s privacy.
68
Menu functions
Taking a photo with the phone open
1. Access the
Camera
menu or press and hold [
]
to turn on the camera.
2. Adjust the image to be captured.
• Press < > to access camera options.
next section
• Use the keypad to change the camera settings
or switch to other modes.
p. 69
3. Press [
]
to take a photo. The photo is saved in
the
Photos
folder.
Using camera options in Capture mode
In Capture mode, press < > to access the following
options:
•
Record video
: switch to Record mode.
•
Shooting mode
: take a photo in the following
modes:
Single shot
: take a photo in normal mode. You
can select whether or not the camera automatically
saves a photo.
Multi shot
: take a series of action stills. You can
select the number of photos the camera will take
and the shooting speed.
•
Effects
: change the colour tone or apply a special
effect.
•
Frames
: apply a decorative frame.
•
Timer
: set a time delay before the camera takes a
photo.
•
Go to photos
: access the
Photos
folder.
•
Settings
: change the default settings for taking a
photo.
Size
: select an image size.
When you take a photo in direct sunlight or in bright
conditions, shadows may appear on the photo.
4.
To Press
access photo options <
Options
>.
p. 69
delete the photo <
Delete
> and then
<
Yes
>.
return to Capture mode [
C
].
Menu functions
Camera
(Menu 8)
69
Quality
: select an image quality setting.
View finder
: select a preview screen.
Shutter sound
: select the sound that you hear
when you press the shutter release, [
]
.
Zoom sound
: turn the sound effect for zooming
on or off.
Brightness sound
: turn the sound effect for
brightness adjustment on or off.
Default name
: change the default prefix of the
photo name.
•
Camera short cuts
: view the functions of the
keys you can use in Capture mode.
Using the keypad in Capture mode
You can use the keypad to customise your camera
settings in Capture mode.
Using photo options
After saving a photo, press <
Options
> to access the
following options:
•
Take another
: return to Capture mode.
Key Function
Left/Right Adjusts the image brightness.
Up/Down Zooms in or out.
Flips the image vertically.
Shows the mirror image.
1
Switches to Record mode.
p. 70
2
Changes the image size.
3
Changes the image quality.
4
Changes the shooting mode.
5
Changes the colour tone or applies a
special effect.
7
Selects a decorative frame.
8
Sets the timer.
9
Goes to the
Photos
folder.
Changes the preview screen.
Key Function
70
Menu functions
•
Send via
: send the file via MMS, e-mail, or
Bluetooth.
•
Set as
: set the photo as wallpaper for the displays
or as a caller ID image for a Phonebook entry.
•
Delete
: delete the file.
•
Multi shot delete all
: delete one of the
multi-shot photos.
•
Rename
: change the file name.
•
Go to photos
: access the
Photos
folder.
p. 61
•
Share for Bluetooth
: share the selected file or all
files with other Bluetooth devices.
•
Print via Bluetooth
: print the image by
connecting the phone to a printer via Bluetooth.
•
Protection
: protect the file from being deleted.
•
Properties
: access the file properties.
Taking a photo with the phone closed
1. Press and hold [
]
.
2. If necessary, press [ ] to highlight .
4. Press [
]
to take a photo. The photo is
automatically saved.
Recording a video
You can record a video of what is displayed on the
camera screen and save it.
Recording a video with the phone open
1. In Capture mode, press [
1
].
2. Adjust the image to be captured.
• Press < > to access camera options.
next section
• Use the keypad to change the camera settings
or switch to other modes.
p. 72
3. Press [
]
to start recording.
3.
To Press
flip the image vertically [ ].
show the mirror image [ ].
adjust the brightness [ ].
zoom in or out [ ].
Menu functions
Camera
(Menu 8)
71
4. Press [
]
or < > to stop recording. The video is
automatically saved in the
Videos
folder.
Using camera options in Record mode
In Record mode, press < > to access the following
options:
•
Take photo
: switch to Capture mode.
•
Effects
: change the colour tone or apply a special
effect.
•
Timer
: set a time delay before the camera starts
recording.
•
Go to videos
: access the
Videos
folder.
•
Settings
: change the following settings for
recording a video:
Recording mode
: select a video recording mode.
Select
Limit of
MMS
to record a video suitable for
messaging or for setting as wallpaper.
Select
Normal
to record a video within the limit of
the currently available memory.
Size
: select a file size.
Quality
: select an image quality setting.
Audio rec.
: record audio with a video clip.
Zoom sound
: turn the sound effect for zooming
on or off.
Brightness sound
: turn the sound effect for
brightness adjustment on or off.
Default name
: change the default prefix of the
video name.
•
Camera short cuts
: view the functions of the
keys you can use in Record mode.
5.
To Press
play back the video clip [ ].
access video options < >.
p. 72
delete the video clip [
C
] and then <
Yes
>.
return to Record mode < >.
72
Menu functions
Using the keypad in Record mode
You can use the keypad to customise your camera
settings in Record mode:
Using video options
After saving a video clip, press < > to access the
following options:
•
Record another
: return to Record mode.
•
Send via
: send the file via MMS, e-mail, or
Bluetooth.
•
Rename
: change the file name.
•
Go to videos
: access the
Videos
folder.
p. 62
•
Protection
: protect the file from being deleted.
•
Properties
: access the file properties.
Recording a video with the phone closed
1. Press and hold [
]
.
2. If necessary, press [ ] to highlight .
Key Function
Left/Right Adjusts the image brightness.
Up/Down Zooms in or out.
Flips the image vertically.
Shows the mirror image.
1
Switches to Capture mode.
p. 67
2
Changes the file size.
3
Changes the image quality.
4
Changes the video recording mode.
5
Changes the colour tone or applies a
special effect.
7
Mutes or unmutes audio.
8
Sets the timer.
9
Goes to the
Videos
folder.
3.
To Press
flip the image vertically [ ].
show the mirror image [ ].
adjust the brightness [ ].
zoom in or out [ ].
Menu functions
Settings
(Menu 9)
73
4. Press [
]
to start recording.
5. Press [
]
to stop recording. The video clip is
automatically saved.
Settings
(Menu 9)
The
Settings
menu provides you with various setting
options to customise the phone to your preferences
and needs. You can also reset the settings to their
default status.
To access this menu, press <
Menu
> in Idle mode and
select
Settings
.
Time & Date
(Menu 9.1)
Use this menu to change the time and date displayed
on your phone. Before setting the time and date,
specify your time zone in the
World time
menu.
p. 41
•
Set time
: enter the current time.
•
AM/PM
: select
AM
or
PM
in 12-hour time format.
•
Time format
: select a time format.
•
Set date
: enter the current date.
•
Date format
: select the date format.
Phone settings
(Menu 9.2)
Many different features of your phone’s system can be
customised to suit your preferences.
Language
(Menu 9.2.1)
Use this menu to select one of several languages for
the display text.
Greeting message
(Menu 9.2.2)
Use this menu to enter the greeting that is displayed
briefly when the phone is switched on.
Short cut
(Menu 9.2.3)
You can use the Navigation keys as shortcuts to access
specific menus directly from Idle mode. Use this menu
to assign a shortcut to a key.
Assigning a shortcut menu
1. Select a key to be used as a shortcut key.
2. Select the menu to be assigned to the key.
74
Menu functions
Using shortcut options
Press <
Options
> to access the following options:
•
Change
: assign or change a shortcut menu.
•
Remove
: deactivate the shortcut assignment to
the selected key.
•
Remove all
: deactivate all shortcut assignments.
Advanced shortcut
(Menu 9.2.4)
Use this menu to activate the Advanced shortcut
feature. You can quickly access the alarm, calendar,
and calculator applications from the dialling screen.
Activating the Advanced shortcut feature
1. On the Advanced screen, select
On
.
2. Press <
Save
>.
Using the Advanced shortcut feature
1. For an alarm or scheduled event, enter the time
you want as 4-digit in Idle mode.
For the calculator, enter the first number you want
to use.
2. Press one of the Navigation keys.
You can access the following applications:
Volume key
(Menu 9.2.5)
Use this menu to set whether the phone mutes the call
ringer or rejects a call if you press and hold [ / ]
when a call comes in.
Extra settings
(Menu 9.2.6)
You can turn the automatic redialling or answering
feature on or off, and lock the external keys.
•
Auto redial
: set the phone to make up to ten
attempts to redial a phone number after an
unsuccessful call.
Key Application
Up Alarm
p. 41
Down Calendar
p. 65
Left Calculator
p. 42
Right Convertor
p. 42
Menu functions
Settings
(Menu 9)
75
•
Anykey
answer
: answer an incoming call by
pressing any key, except [ ] or <
Reject
>.
•
Voice clarity
: remove extraneous noise and
increase call quality so that the person with whom
you are speaking can hear you clearly even if you
are in a noisy place.
•
Active folder
: answer an incoming call by opening
the phone.
•
Cover keylock
: lock the exposed keys to keep
accidental presses from affecting your phone’s
operation when the phone is closed.
Display settings
(Menu 9.3)
Use this menu to change settings for the display.
Wallpaper
(Menu 9.3.1)
You can set up the idle screen on both displays.
•
Main display
: select an image to be displayed on
the main display.
•
Cover display
: change the settings for the
external display:
Clock
: select a clock type.
Cover title
: set a message to be displayed on the
external display.
Wallpaper images
: change the wallpaper image
for the external display.
Text display
(Menu 9.3.2)
Use this menu to change the display settings for the
text displayed on the idle screen.
•
Text position
: select a text position. If you don’t
want to display text in Idle mode, select
Off
.
•
Text style
: select a font style.
•
Text colour
: select a font colour.
Dialling display
(Menu 9.3.3)
Use this menu to select a font size of colour, or
background colour for the numbers entered while
dialling.
Calendar
(Menu 9.3.4)
Use this menu to display the calendar of the current
month on the idle screen.
Skin
(Menu 9.3.5)
You can select a skin colour pattern for Menu mode.
76
Menu functions
LCD brightness
(Menu 9.3.6)
You can adjust the brightness of the display for
varying lighting conditions.
Show caller information
(Menu 9.3.7)
Use this menu to set the phone to display missed call
notifications with the most recently missed caller’s
information. To set the external display to show caller
information, select
With cover display
.
Sound settings
(Menu 9.4)
Use this menu to customise various sound settings.
Incoming call
(Menu 9.4.1)
Use this menu to change the sound settings for
incoming calls.
•
Ring tone
: select a ringtone to be used for the call
ringer.
•
Volume
: select a ringtone volume.
•
Alert type
: specify how you are to be informed of
incoming calls.
Keypad tone
(Menu 9.4.2)
Use this menu to select the tone that the phone
sounds when you press a key.
Message tone
(Menu 9.4.3)
Use this menu to change the sound settings for
incoming SMS messages, MMS messages, e-mails,
and CB messages.
•
Tone
: select one of several message tones.
•
Alert type
: specify how you are to be informed
when a message comes in.
•
Repetition
: specify how often the phone informs
you of a new message.
Power on/off
(Menu 9.4.4)
Use this menu to select the melody that the phone
sounds when it is switched on or off.
Folder tone
(Menu 9.4.5)
Use this menu to select the tone that the phone
sounds when you open or close the phone.
You can adjust the keypad tone volume using
[ / ] in Idle mode.
Menu functions
Settings
(Menu 9)
77
Quiet mode
(Menu 9.4.6)
Use this menu to set how the phone acts to alert you
to a specific event while in Quiet mode.
Extra tones
(Menu 9.4.7)
Use this menu to customise additional tones for the
phone.
•
Minute
minder
: set the phone to beep every
minute during an outgoing call to keep you
informed of the length of your call.
•
Connection
tone
: set the phone to beep when an
outgoing call connects to the system.
•
Alerts on call
: set the phone to beep when you
receive a new message or when the time for an
alarm comes during a call.
•
Indicative
tones
: set the phone to beep when
you have made a mistake or something wrong
happens on the phone.
Light settings
(Menu 9.5)
Use this menu to change settings for the backlight.
Backlight
(Menu 9.5.1)
You can change the settings for backlight or icons for
the external display.
•
Main LCD on
: select the length of time the
backlight stays on.
•
Main LCD dim
: select the length of time the
display stays on in Dim mode after the backlight
turns off. After a specified time, the display turns
off.
•
Show cover indicators
: set whether or not the
icons are shown on the external display after the
display turns off.
Keypad light
(Menu 9.5.2)
You can set how the phone controls the use of the
keypad light.
•
Use at any time
: the keypad light is always used.
•
Use at night time
: the keypad light is used only
between 5:00 PM and 9:00 AM.
78
Menu functions
•
Use at custom time
: specify the time period that
the keypad light is used.
Network services
(Menu 9.6)
Use this menu to access network services. Please
contact your service provider to check their availability
and subscribe to them, if you wish.
Call diverting
(Menu 9.6.1)
This network service reroutes incoming calls to a
phone number that you specify.
1. Select a call diverting option:
•
Divert always
: divert all calls.
•
Busy
: divert calls when you are on another
call.
•
No
reply
: divert calls when you do not answer
the phone.
•
Unreachable
: divert calls when you are not in
an area covered by your service provider or
when your phone is switched off.
•
Cancel
all
: cancel all call diverting options.
2. Select the type of calls to be diverted.
3. Select
Activate
. To deactivate call diverting, select
Deactivate
.
4. Move to the
Divert to
line.
5. Enter the number to which calls are to be diverted.
6. If you selected
No reply
, move to the
Seconds
line and select the length of time the network
delays before diverting a call.
7. Press <
Select
>.
Call barring
(Menu 9.6.2)
This network service allows you to restrict your calls.
1. Select a call barring option:
•
All
outgoing
: prohibit all outgoing calls.
•
International
: prohibit international calls.
•
International except home
: only allow calls
to numbers within the current country when
you are abroad, and to your home country.
•
All
incoming
: prohibit incoming calls.
•
Incoming
while
abroad
: prohibit incoming
calls when you use your phone outside of your
home country.
Menu functions
Settings
(Menu 9)
79
•
Cancel
all
: cancel all call barring settings,
allowing calls to be sent and received normally.
•
Change barring password
: change the call
barring password obtained from your service
provider.
2. Select the type of calls to be barred.
3. Select
Activate
. To deactivate call barring, select
Deactivate
.
4. Enter the call barring password supplied by your
service provider and press <
Select
>.
Call waiting
(Menu 9.6.3)
This network service informs you when someone is
trying to reach you while you are on another call.
1. Select the type of calls to which call waiting option
will apply.
2. Select
Activate
and press <
Select
>. To
deactivate call waiting, select
Deactivate
.
Network selection
(Menu 9.6.4)
This network service allows you to either automatically
or manually select the network to be used while
roaming outside of your home area. You can select a
network other than your home network only if there is
a valid roaming agreement between the two.
Caller ID
(Menu 9.6.5)
This network service allows you to prevent your phone
number from being displayed on the phone of the
person being called. If you select
Default
, the phone
will use the default setting provided by the network.
Voice mail server
(Menu 9.6.6)
Use this menu to store the number of the voicemail
server and access your voicemails.
•
Connect to voice mail
: connect to the voicemail
server to listen to your messages.
Some networks may not allow you to change this
setting.
You must store the voicemail server number before
accessing the server. Your service provider can give
you the number.
80
Menu functions
•
Voice server number
: enter the voicemail server
number.
Band selection
(Menu 9.6.7)
For the phone to make and receive phone calls, it
must register with an available network. Your phone
can handle any of the following types of networks:
GSM 1900 and Combined GSM 900/1800.
The country where you purchased your phone
determines the default band that it uses. When you
travel abroad, you may need to change to an
appropriate band.
Bluetooth
(Menu 9.7)
Using the Bluetooth feature, you can connect the
phone wirelessly to other Bluetooth devices and
exchange data with them, talk hands-free, or control
the phone remotely.
Bluetooth technology allows free wireless connections
between all Bluetooth-compliant devices within a
range of 10 meters. Since the devices communicate
using radio waves, they do not need to be in line of
sight to each other.
Setting up the Bluetooth feature
The
Bluetooth
menu provides the following options:
•
Activation
: activate or deactivate the Bluetooth
feature.
•
My devices
: search for connectable Bluetooth
devices.
•
My phone’s visibility
: allow other Bluetooth
devices to search for your phone.
•
My phone’s name
: assign a Bluetooth device
name to your phone, which is then displayed on
other devices.
•
Secure mode
: determine if the phone asks for
your confirmation when other devices access your
data.
• If there are obstacles between the devices, the
operating distance may be reduced.
• It is recommended that you don’t use the
Bluetooth feature while using multimedia
features,
such as voice recorder, camera, and MP3 player,
or vice versa, for better performance.
• Some devices may not be compatible with your
phone.
Menu functions
Settings
(Menu 9)
81
•
Bluetooth services
: display available Bluetooth
services.
Searching for and pairing with a Bluetooth
device
1. From the Bluetooth setting options, select
My
devices
.
2. Select
Search new device
.
After searching, a list of devices to which you can
connect displays. The following icons indicate the
type of device:
The colour of the icon indicates the status of the
the device:
• Grey for unpaired devices
• Blue for paired devices
• Red for devices that are currently connected to
your phone
3. Select a device.
4. Enter a Bluetooth PIN and press <
OK
>. This code
is used just once and you don’t need to memorise
it.
When the owner of the other device enters the
same code, pairing is complete.
Using device options
From the device list, press <
Options
> to access the
following options:
•
Connect
: connect to a headset or hands-free car
kit.
•
Disconnect
: end the connection with the
connected device.
•
Browse files
: search for data from the device and
import data directly to your phone.
•
Service list
: access the Bluetooth service list of
the device.
•
Rename
: rename the paired device.
• Computer• Mobile phone
• Printer • Unknown device
• PDA • Headset/Hands-free car kit
Some devices, especially headsets or hands-free car
kits, may have a fixed Bluetooth PIN, such as
0000
.
If the other device has a code, you must enter it.
82
Menu functions
•
Authorize device
/
Unauthorized device
:
determine whether or not the phone asks you to
permit connection when other devices try to
connect to your phone.
•
Delete
: remove the selected device or all devices
from the list.
Sending data via Bluetooth
1. Activate the Bluetooth feature.
2. Select the application in which the item you want
to send is stored.
3. Scroll to the item you want and press <
Options
>.
4. Select
Send
via
→
Bluetooth
.
The phone searches for devices within range and
displays a list of available devices.
5. Select a device.
6. If necessary, enter the Bluetooth PIN needed for
pairing and press <
OK
>.
Receiving data via Bluetooth
To receive data via Bluetooth, your phone’s Bluetooth
feature must be active.
If an unauthorised Bluetooth device sends data to your
phone, the phone displays a confirmation message. To
receive data, press <
Yes
>.
Security
(Menu 9.8)
Use this menu to protect the phone against
unauthorised use by managing the several access
codes of your phone and SIM card.
PIN check
(Menu 9.8.1)
The 4- to 8-digit PIN (Personal Identification Number)
protects your SIM card against unauthorised use.
When this feature is enabled, the phone requires your
PIN each time it is switched on.
If you enter an incorrect PIN/PIN2 three times in
succession, the SIM card is blocked. To unblock it
you need to enter your PUK/PUK2 (Personal
Unblocking Key). The codes are supplied by your
service provider.
Menu functions
Settings
(Menu 9)
83
Change PIN
(Menu 9.8.2)
Use this menu to change your PIN. The PIN check
feature must be enabled to change the PIN.
Phone lock
(Menu 9.8.3)
Use this menu to lock the phone from unauthorised
use.
When this feature is enabled, you must enter a 4- to
8-digit phone password each time the phone is
switched on.
The password is preset to
00000000
. To change the
password, use the
Change password
menu.
Change password
(Menu 9.8.4)
Use this menu to change your phone password.
Privacy
(Menu 9.8.5)
Use this menu to lock access to messages, files, or all
menu functions on the phone, except for call
functions.
When a privacy option is enabled, you must enter the
phone password to access the locked items or
functions.
SIM lock
(Menu 9.8.6)
This menu allows your phone to work only with the
current SIM by assigning a SIM lock code. You must
enter the SIM lock code to use a different SIM card.
FDN mode
(Menu 9.8.7)
If supported by your SIM card, Fixed Dialling Number
(FDN) mode restricts your outgoing calls to a limited
set of phone numbers. When this feature is enabled,
you can make calls only to phone numbers stored on
the SIM card.
Change PIN2
(Menu 9.8.8)
If supported by your SIM card, use this menu to
change your current PIN2.
Memory status
(Menu 9.9)
Use this menu to check the amount of memory being
used for storing data in
Messages
,
File manager
,
Calendar
,
Phonebook
, and
JAVA world
. You can
also check the shared memory for MMS, Email, and
File manager.
84
Reset settings
(Menu 9.10)
Use this menu to reset the phone’s settings you have
changed.
1. Press [ ] to select the setting categories to be
reset.
2. Press <
Reset
>.
3. Press <
Yes
> to confirm the reset.
4. Enter the phone password and press <
OK
>.
Solve problems
Help and personal needs
To save the time and expense of an unnecessary service
call, perform the simple checks in this section before
contacting a service professional.
When you switch on your phone, the following
messages may appear:
“Insert SIM”
• Be sure that the SIM card is correctly installed.
“Enter password”
• The automatic locking function has been enabled.
You must enter the phone’s password before you
can use the phone.
“Enter PIN”
• You are using your phone for the first time. You
must enter the PIN supplied with the SIM card.
• The PIN check feature is enabled. Every time the
phone is switched on, the PIN has to be entered.
To disable this feature, use the
PIN check
menu.
The password is preset to
00000000
. You can
change this password.
p. 83
85
Solve problems
“Enter PUK”
• The PIN has been entered incorrectly three times
in succession, and the SIM card is now blocked.
Enter the PUK supplied by your service provider.
“No service,” “Network failure,” or “Not done”
displays
• The network connection has been lost. You may be
in a weak signal area. Move and try again.
• You are trying to access an option for which you
have no subscription with your service provider.
Contact the service provider for further details.
You have entered a number but it was not dialled
• Be sure that you have pressed [ ].
• Be sure you have accessed the right cellular
network.
• Be sure that you have not set an outgoing call
barring option.
Your correspondent cannot reach you
• Be sure that your phone is switched on. ([ ]
pressed for more than one second.)
• Be sure that you are accessing the correct cellular
network.
• Be sure that you have not set an incoming call
barring option.
Your correspondent cannot hear you speaking
• Be sure that you have switched on the
microphone.
• Be sure that you are holding the phone close
enough to your mouth. The microphone is located
at the bottom of the phone.
The phone starts beeping and “Low battery”
flashes on the display
• Your battery is insufficiently charged. Recharge the
battery.
The audio quality of the call is poor
• Check the signal strength indicator on the display
( ). The number of bars indicates the signal
strength from strong ( ) to weak ( ).
• Try moving the phone slightly or moving closer to a
window if you are in a building.
86
No number is dialled when you re-call a
Phonebook entry
•Use the
Contacts list
menu to ensure the number
has been stored correctly.
• Re-store the number, if necessary.
The battery doesn’t charge properly or the phone
sometimes turns itself off
• Wipe the charging contacts both on the phone and
on the battery with a clean soft cloth.
If the above guidelines do not help you to solve
the problem, take note of:
• The model and serial numbers of your phone
•Your warranty details
• A clear description of the problem
Then contact your local dealer or Samsung after-sales
service.
Health and safety information
Exposure to Radio Frequency (RF) Signals
Certification Information (SAR)
Your wireless phone is a radio transmitter and receiver.
It is designed and manufactured not to exceed the
exposure limits for radio frequency (RF) energy set by
the Federal Communications Commission (FCC) of the
U.S. government. These FCC exposure limits are
derived from the recommendations of two expert
organizations, the National Counsel on Radiation
Protection and Measurement (NCRP) and the Institute
of Electrical and Electronics Engineers (IEEE). In both
cases, the recommendations were developed by
scientific and engineering experts drawn from
industry, government, and academia after extensive
reviews of the scientific literature related to the
biological effects of RF energy.
87
Health and safety information
The exposure limit set by the FCC for wireless mobile
phones employs a unit of measurement known as the
Specific Absorption Rate (SAR). The SAR is a measure
of the rate of absorption of RF energy by the human
body expressed in units of watts per kilogram (W/kg).
The FCC requires wireless phones to comply with a
safety limit of 1.6 watts per kilogram (1.6 W/kg). The
FCC exposure limit incorporates a substantial margin
of safety to give additional protection to the public and
to account for any variations in measurements.
SAR tests are conducted using standard operating
positions accepted by the FCC with the phone
transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is
determined at the highest certified power level, the
actual SAR level of the phone while operating can be
well below the maximum value. This is because the
phone is designed to operate at multiple power levels
so as to use only the power required to reach the
network. In general, the closer you are to a wireless
base station antenna, the lower the power output.
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that
it does not exceed the exposure limit established by
the FCC. Tests for each model phone are performed in
positions and locations (e.g. at the ear and worn on
the body) as required by the FCC. Body-worn
operations are restricted to Samsung-supplied,
approved, or non- Samsung designated accessories
that have no metal and must provide at least 1.5 cm
separation between the device, including its antenna
(whether extended or retracted) and the user's body.
Non-compliance with the above restrictions may result
in violation of FCC RF exposure guidelines.
The FCC has granted an Equipment Authorization for
this mobile phone with all reported SAR levels
evaluated as in compliance with the FCC RF exposure
guidelines. The maximum SAR values for this model
phone as reported to the FCC are:
GSM 1900
•Head: 1.08 W/Kg.
• Body-worn: 0.344 W/Kg.
88
Health and safety information
SAR information on this and other model phones can
be viewed on-line at www.fcc.gov/oet/fccid. To find
information that pertains to a particular model phone,
this site uses the phone FCC ID number A3LSGHE360
which is usually printed somewhere on the case of the
phone. Sometimes it may be necessary to remove the
battery pack to find the number. Once you have the
FCC ID number for a particular phone, follow the
instructions on the website and it should provide
values for typical or maximum SAR for a particular
phone. Additional product specific SAR information can
also be obtained at www.fcc.gov/cgb/sar.
Consumer Information on Wireless Phones
The U.S. Food and Drug Administration (FDA) has
published a series of Questions and Answers for
consumers relating to radio frequency (RF) exposure
from wireless phones. The FDA publication includes
the following information:
What kinds of phones are the subject of this
update?
The term wireless phone refers here to hand-held
wireless phones with built-in antennas, often called
“cell,” “mobile,” or “PCS” phones. These types of
wireless phones can expose the user to measurable
radio frequency energy (RF) because of the short
distance between the phone and the user's head.
These RF exposures are limited by Federal
Communications Commission safety guidelines that
were developed with the advice of FDA and other
federal health and safety agencies. When the phone is
located at greater distances from the user, the
exposure to RF is drastically lower because a person's
RF exposure decreases rapidly with increasing
89
Health and safety information
distance from the source. The so-called “cordless
phones,” which have a base unit connected to the
telephone wiring in a house, typically operate at far
lower power levels, and thus produce RF exposures
well within the FCC's compliance limits.
Do wireless phones pose a health hazard?
The available scientific evidence does not show that
any health problems are associated with using
wireless phones. There is no proof, however, that
wireless phones are absolutely safe. Wireless phones
emit low levels of radio frequency energy (RF) in the
microwave range while being used. They also emit
very low levels of RF when in the stand-by mode.
Whereas high levels of RF can produce health effects
(by heating tissue), exposure to low level RF that does
not produce heating effects causes no known adverse
health effects. Many studies of low level RF exposures
have not found any biological effects. Some studies
have suggested that some biological effects may
occur, but such findings have not been confirmed by
additional research. In some cases, other researchers
have had difficulty in reproducing those studies, or in
determining the reasons for inconsistent results.
What is FDA's role concerning the safety of
wireless phones?
Under the law, FDA does not review the safety of
radiation-emitting consumer products such as wireless
phones before they can be sold, as it does with new
drugs or medical devices. However, the agency has
authority to take action if wireless phones are shown
to emit radio frequency energy (RF) at a level that is
hazardous to the user. In such a case, FDA could
require the manufacturers of wireless phones to notify
users of the health hazard and to repair, replace or
recall the phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA
regulatory actions, FDA has urged the wireless phone
industry to take a number of steps, including the
following:
• “Support needed research into possible biological
effects of RF of the type emitted by wireless
phones;
• “Design wireless phones in a way that minimizes
any RF exposure to the user that is not necessary
for device function; and
90
Health and safety information
• “Cooperate in providing users of wireless phones
with the best possible information on possible
effects of wireless phone use on human health.
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at
the federal level. The following agencies belong to this
working group:
• “National Institute for Occupational Safety and
Health
• “Environmental Protection Agency
• “Federal Communications Commission
• “Occupational Safety and Health Administration
• “National Telecommunications and Information
Administration
The National Institutes of Health participates in some
interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless
phones with the Federal Communications Commission
(FCC). All phones that are sold in the United States
must comply with FCC safety guidelines that limit RF
exposure. FCC relies on FDA and other health agencies
for safety questions about wireless phones.
FCC also regulates the base stations that the wireless
phone networks rely upon. While these base stations
operate at higher power than do the wireless phones
themselves, the RF exposures that people get from
these base stations are typically thousands of times
lower than those they can get from wireless phones.
Base stations are thus not the primary subject of the
safety questions discussed in this document.
What are the results of the research done
already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws in
their research methods. Animal experiments
investigating the effects of radio frequency energy
(RF) exposures characteristic of wireless phones have
yielded conflicting results that often cannot be
repeated in other laboratories. A few animal studies,
however, have suggested that low levels of RF could
accelerate the development of cancer in laboratory
animals. However, many of the studies that showed
91
Health and safety information
increased tumor development used animals that had
been genetically engineered or treated with cancer-
causing chemicals so as to be pre-disposed to develop
cancer in absence of RF exposure. Other studies
exposed the animals to RF for up to 22 hours per day.
These conditions are not similar to the conditions
under which people use wireless phones, so we don't
know with certainty what the results of such studies
mean for human health.
Three large epidemiology studies have been published
since December 2000. Between them, the studies
investigated any possible association between the use
of wireless phones and primary brain cancer, glioma,
meningioma, or acoustic neuroma, tumors of the brain
or salivary gland, leukemia, or other cancers. None of
the studies demonstrated the existence of any harmful
health effects from wireless phones RF exposures.
However, none of the studies can answer questions
about long-term exposures, since the average period
of phone use in these studies was around three years.
What research is needed to decide whether RF
exposure from wireless phones poses a health
risk?
A combination of laboratory studies and
epidemiological studies of people actually using
wireless phones would provide some of the data that
are needed. Lifetime animal exposure studies could be
completed in a few years. However, very large
numbers of animals would be needed to provide
reliable proof of a cancer promoting effect if one
exists. Epidemiological studies can provide data that is
directly applicable to human populations, but ten or
more years' follow-up may be needed to provide
answers about some health effects, such as cancer.
This is because the interval between the time of
exposure to a cancer-causing agent and the time
tumors develop - if they do - may be many, many
years. The interpretation of epidemiological studies is
hampered by difficulties in measuring actual RF
exposure during day-to-day use of wireless phones.
Many factors affect this measurement, such as the
angle at which the phone is held, or which model of
phone is used.
92
Health and safety information
What is FDA doing to find out more about the
possible health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology
Program and with groups of investigators around the
world to ensure that high priority animal studies are
conducted to address important questions about the
effects of exposure to radio frequency energy (RF).
FDA has been a leading participant in the World Health
Organization international Electromagnetic Fields
(EMF) Project since its inception in 1996. An influential
result of this work has been the development of a
detailed agenda of research needs that has driven the
establishment of new research programs around the
world. The Project has also helped develop a series of
public information documents on EMF issues.
FDA and Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative
Research and Development Agreement (CRADA) to do
research on wireless phone safety. FDA provides the
scientific oversight, obtaining input from experts in
government, industry, and academic organizations.
CTIA-funded research is conducted through contracts
to independent investigators. The initial research will
include both laboratory studies and studies of wireless
phone users. The CRADA will also include a broad
assessment of additional research needs in the
context of the latest research developments around
the world.
What steps can I take to reduce my exposure
to radio frequency energy from my wireless
phone?
If there is a risk from these products - and at this
point we do not know that there is - it is probably very
small. But if you are concerned about avoiding even
potential risks, you can take a few simple steps to
minimize your exposure to radio frequency energy
(RF). Since time is a key factor in how much exposure
a person receives, reducing the amount of time spent
using a wireless phone will reduce RF exposure.
• “If you must conduct extended conversations by
wireless phone every day, you could place more
distance between your body and the source of the
RF, since the exposure level drops off dramatically
with distance. For example, you could use a
Health and safety information
Settings
93
headset and carry the wireless phone away from
your body or use a wireless phone connected to a
remote antenna.
Again, the scientific data do not demonstrate that
wireless phones are harmful. But if you are concerned
about the RF exposure from these products, you can
use measures like those described above to reduce
your RF exposure from wireless phone use.
What about children using wireless phones?
The scientific evidence does not show a danger to
users of wireless phones, including children and
teenagers. If you want to take steps to lower exposure
to radio frequency energy (RF), the measures
described above would apply to children and
teenagers using wireless phones. Reducing the time of
wireless phone use and increasing the distance
between the user and the RF source will reduce RF
exposure.
Some groups sponsored by other national
governments have advised that children be
discouraged from using wireless phones at all. For
example, the government in the United Kingdom
distributed leaflets containing such a recommendation
in December 2000. They noted that no evidence exists
that using a wireless phone causes brain tumors or
other ill effects. Their recommendation to limit
wireless phone use by children was strictly
precautionary; it was not based on scientific evidence
that any health hazard exists.
Do hands-free kits for wireless phones reduce
risks from exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that hands-free kits reduce risks. Hands-free
kits can be used with wireless phones for convenience
and comfort. These systems reduce the absorption of
RF energy in the head because the phone, which is the
source of the RF emissions, will not be placed against
the head. On the other hand, if the phone is mounted
against the waist or other part of the body during use,
then that part of the body will absorb more RF energy.
Wireless phones marketed in the U.S. are required to
meet safety requirements regardless of whether they
94
Health and safety information
are used against the head or against the body. Either
configuration should result in compliance with the
safety limit.
Do wireless phone accessories that claim to
shield the head from RF radiation work?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that accessories that claim to shield the head
from those emissions reduce risks. Some products
that claim to shield the user from RF absorption use
special phone cases, while others involve nothing
more than a metallic accessory attached to the phone.
Studies have shown that these products generally do
not work as advertised. Unlike “hand-free” kits, these
so-called “shields” may interfere with proper operation
of the phone. The phone may be forced to boost its
power to compensate, leading to an increase in RF
absorption. In February 2002, the Federal trade
Commission (FTC) charged two companies that sold
devices that claimed to protect wireless phone users
from radiation with making false and unsubstantiated
claims. According to FTC, these defendants lacked a
reasonable basis to substantiate their claim.
What about wireless phone interference with
medical equipment?
Radio frequency energy (RF) from wireless phones can
interact with some electronic devices. For this reason,
FDA helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted
cardiac pacemakers and defibrillators from wireless
telephones. This test method is now part of a standard
sponsored by the Association for the Advancement of
Medical instrumentation (AAMI). The final draft, a joint
effort by FDA, medical device manufacturers, and
many other groups, was completed in late 2000. This
standard will allow manufacturers to ensure that
cardiac pacemakers and defibrillators are safe from
wireless phone EMI. FDA has tested wireless phones
and helped develop a voluntary standard sponsored by
the Institute of Electrical and Electronic Engineers
(IEEE). This standard specifies test methods and
performance requirements for hearing aids and
wireless phones so that no interference occurs when a
Health and safety information
Settings
95
person uses a compatible phone and a compatible
hearing aid at the same time. This standard was
approved by the IEEE in 2000.
FDA continues to monitor the use of wireless phones
for possible interactions with other medical devices.
Should harmful interference be found to occur, FDA
will conduct testing to assess the interference and
work to resolve the problem.
Additional information on the safety of RF exposures
from various sources can be obtained from the
following organizations:
• FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
• Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
• Occupational Safety and Health Administration's
(OSHA):
http://www.osha.gov/SLTC/
radiofrequencyradiation/index.html
• National institute for Occupational Safety and
Health (NIOSH):
http://www.cdc.gov/niosh/emfpg.html
• World health Organization (WHO):
http://www.who.int/peh-emf/
• International Commission on Non-Ionizing
Radiation Protection:
http://www.icnirp.de
• National Radiation Protection Board (UK):
http://www.nrpb.org.uk
• Updated 4/3/2002: US food and Drug
Administration
http://www.fda.gov/cellphones
96
Health and safety information
Road Safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime.
But an important responsibility accompanies the
benefits of wireless phones, one that every user must
uphold.
When driving a car, driving is your first responsibility.
When using your wireless phone behind the wheel of a
car, practice good common sense and remember the
following tips:
1. Get to know your wireless phone and its features,
such as speed dial and redial. If available, these
features help you to place your call without taking
your attention off the road.
2. When available, use a hands-free device. If
possible, add an additional layer of convenience
and safety to your wireless phone with one of the
many hands free accessories available today.
3. Position your wireless phone within easy reach. Be
able to access your wireless phone without
removing your eyes from the road. If you get an
incoming call at an inconvenient time, let your
voice mail answer it for you.
4. Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy
traffic or hazardous weather conditions. Rain,
sleet, snow, ice and even heavy traffic can be
hazardous.
5. Do not take notes or look up phone numbers while
driving. Jotting down a “to do” list or flipping
through your address book takes attention away
from your primary responsibility, driving safely.
6. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan calls when your car
will be stationary. If you need to make a call while
moving, dial only a few numbers, check the road
and your mirrors, then continue.
Health and safety information
Settings
97
7. Do not engage in stressful or emotional
conversations that may be distracting. Make
people you are talking with aware you are driving
and suspend conversations that have the potential
to divert your attention from the road.
8. Use your wireless phone to call for help. Dial 9-1-1
or other local emergency number in the case of
fire, traffic accident or medical emergencies.
Remember, it is a free call on your wireless phone!
9. Use your wireless phone to help others in
emergencies. If you see an auto accident, crime in
progress or other serious emergency where lives
are in danger, call 9-1-1 or other local emergency
number, as you would want others to do for you.
10.Call roadside assistance or a special non-
emergency wireless assistance number when
necessary. If you see a broken-down vehicle
posing no serious hazard, a broken traffic signal, a
minor traffic accident where no one appears
injured, or a vehicle you know to be stolen, call
roadside assistance or other special non-
emergency number.
“The wireless industry reminds you to use your
phone safely when driving.”
For more information, please call 1-888-901-SAFE, or
visit our web-site www.wow-com.com
Provided by the Cellular Telecommunications &
Internet Association
Operating Environment
Remember to follow any special regulations in force in
any area and always switch your phone off whenever it
is forbidden to use it, or when it may cause
interference or danger. When connecting the phone or
any accessory to another device, read its user's guide
for detailed safety instructions. Do not connect
incompatible products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation of
the equipment and for the safety of personnel, it is
recommended that the equipment should only be used
in the normal operating position (held to your ear with
the antenna pointing over your shoulder).
98
Health and safety information
Using Your Phone Near Other Electronic
Devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against the
RF signals from your wireless phone. Consult the
manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be maintained
between a wireless phone and a pacemaker to avoid
potential interference with the pacemaker.
These recommendations are consistent with the
independent research and recommendations of
Wireless Technology Research.
Persons with pacemakers:
• should always keep the phone more than 15 cm
(6 inches) from their pacemaker when the phone is
switched on.
• should not carry the phone in a breast pocket.
• should use the ear opposite the pacemaker to
minimize potential interference.
If you have any reason to suspect that interference is
taking place, switch your phone off immediately.
Hearing Aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you
may wish to consult your hearing aid manufacturer to
discuss alternatives.
Other Medical Devices
If you use any other personal medical devices, consult
the manufacturer of your device to determine if it is
adequately shielded from external RF energy. Your
physician may be able to assist you in obtaining this
information. Switch your phone off in health care
facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care facilities
may be using equipment that could be sensitive to
external RF energy.
Health and safety information
Settings
99
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle. You should also
consult the manufacturer of any equipment that has
been added to your vehicle.
Posted Facilities
Switch your phone off in any facility where posted
notices require you to do so.
Potentially Explosive Environments
Switch your phone off when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause an
explosion or fire resulting in bodily injury or even
death.
Users are advised to switch the phone off while at a
refueling point (service station). Users are reminded of
the need to observe restrictions on the use of radio
equipment in fuel depots (fuel storage and distribution
areas), chemical plants or where blasting operations
are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas (such
as propane or butane), areas where the air contains
chemicals or particles, such as grain, dust or metal
powders, and any other area where you would
normally be advised to turn off your vehicle engine.
Emergency Calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well as
user programmed functions, which cannot guarantee
connection in all conditions. Therefore, you should
never rely solely on any wireless phone for essential
communications (medical emergencies, for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not be
100
Health and safety information
possible on all wireless phone networks or when
certain network services and/or phone features are in
use. Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location (for example, 911 or other official
emergency number). Emergency numbers vary by
location.
3. Press .
If certain features are in use (call barring, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult this document and your local cellular service
provider.
When making an emergency call, remember to give all
the necessary information as accurately as possible.
Remember that your phone may be the only means of
communication at the scene of an accident; do not cut
off the call until given permission to do so.
Restricting Children's access to your Phone
Your phone is not a toy. Children should not be allowed
to play with it because they could hurt themselves and
others, damage the phone or make calls that increase
your phone bill.
FCC Notice and Cautions
FCC Notice
The phone may cause TV or radio interference if used
in close proximity to receiving equipment. The FCC
can require you to stop using the phone if such
interference cannot be eliminated.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
Health and safety information
Settings
101
Vehicles using liquefied petroleum gas (such as
propane or butane) must comply with the National Fire
Protection Standard (NFPA-58). For a copy of this
standard, contact the National Fire Protection
Association, One Battery march Park, Quincy, MA
02269, Attn: Publication Sales Division.
Cautions
Changes or modifications made in the radio phone, not
expressly approved by Samsung, will void the user’s
authority to operate the equipment.
Only use approved batteries, antennas and chargers.
The use of any unauthorized accessories may be
dangerous and void the phone warranty if said
accessories cause damage or a defect to the phone.
Although your phone is quite sturdy, it is a complex
piece of equipment and can be broken. Avoid
dropping, hitting, bending or sitting on it.
Other Important Safety Information
• Only qualified personnel should service the phone
or install the phone in a vehicle. Faulty installation
or service may be dangerous and may invalidate
any warranty applicable to the device.
• Check regularly that all wireless phone equipment
in your vehicle is mounted and operating properly.
• Do not store or carry flammable liquids, gases or
explosive materials in the same compartment as
the phone, its parts or accessories.
• For vehicles equipped with an air bag, remember
that an air bag inflates with great force. Do not
place objects, including both installed or portable
wireless equipment in the area over the air bag or
in the air bag deployment area. If wireless
equipment is improperly installed and the air bag
inflates, serious injury could result.
• Switch your phone off before boarding an aircraft.
The use of wireless phone in aircraft is illegal and
may be dangerous to the aircraft's operation.
• Failure to observe these instructions may lead to
the suspension or denial of telephone services to
the offender, or legal action, or both.
102
Health and safety information
Product Performance
Getting the Most Out of Your Signal Reception
The quality of each call you make or receive depends
on the signal strength in your area. Your phone
informs you of the current signal strength by
displaying a number of bars next to the signal strength
icon. The more bars displayed, the stronger the signal.
If you're inside a building, being near a window may
give you better reception.
Understanding the Power Save Feature
If your phone is unable to find a signal after 15
minutes of searching, a Power Save feature is
automatically activated. If your phone is active, it
periodically rechecks service availability or you can
check it yourself by pressing any key.
Anytime the Power Save feature is activated, a
message displays on the screen. When a signal is
found, your phone returns to standby mode.
Understanding How Your Phone Operates
Your phone is basically a radio transmitter and
receiver. When it's turned on, it receives and transmits
radio frequency (RF) signals. When you use your
phone, the system handling your call controls the
power level. This power can range from 0.006 watts to
0.2 watts in digital mode.
Maintaining Your Phone's Peak Performance
For the best care of your phone, only authorized
personnel should service your phone and accessories.
Faulty service may void the warranty.
There are several simple guidelines to operating your
phone properly and maintaining safe, satisfactory
service.
• Hold the phone with the antenna raised, fully-
extended and over your shoulder.
• Try not to hold, bend or twist the phone's antenna.
• Don't use the phone if the antenna is damaged.
• Speak directly into the phone's receiver.
Health and safety information
Settings
103
• Avoid exposing your phone and accessories to rain
or liquid spills. If your phone does get wet,
immediately turn the power off and remove the
battery. If it is inoperable, call Customer Care for
service.
Availability of Various Features/Ring
Tones
Many services and features are network dependent
and may require additional subscription and/or usage
charges. Not all features are available for purchase or
use in all areas. Downloadable Ring Tones may be
available at an additional cost. Other conditions and
restrictions may apply. See your service provider for
additional information.
Battery Standby and Talk Time
Standby and talk times will vary depending on phone
usage patterns and conditions. Battery power
consumption depends on factors such as network
configuration, signal strength, operating temperature,
features selected, frequency of calls, and voice, data,
and other application usage patterns.
Battery Precautions
• Never use any charger or battery that is damaged
in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network's base
station, it uses less power; talk and standby time
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
• Battery charging time depends on the remaining
battery charge and the type of battery and charger
used. The battery can be charged and discharged
hundreds of times, but it will gradually wear out.
When the operation time (talk time and standby
time) is noticeably shorter than normal, it is time
to buy a new battery.
• If left unused, a fully charged battery will
discharge itself over time.
104
Health and safety information
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not in use,
disconnect it from the power source. Do not leave
the battery connected to a charger for more than a
week, since overcharging may shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling or
warming first.
• Do not leave the battery in hot or cold places, such
as in a car in summer or winter conditions, as you
will reduce the capacity and lifetime of the battery.
Always try to keep the battery at room
temperature. A phone with a hot or cold battery
may temporarily not work, even when the battery
is fully charged. Li-ion batteries are particularly
affected by temperatures below 0 °C (32 °F).
• Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object (coin,
clip or pen) causes a direct connection between the
+ and - terminals of the battery (metal strips on
the battery), for example when you carry a spare
battery in a pocket or bag. Short-circuiting the
terminals may damage the battery or the object
causing the short-circuiting.
• Dispose of used batteries in accordance with local
regulations. In some areas, the disposal of
batteries in household or business trash may be
prohibited. For safe disposal options for Li-Ion
batteries, contact your nearest Samsung
authorized service center. Always recycle. Do not
dispose of batteries in a fire.
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for
many years.
Health and safety information
Settings
105
• Keep the phone and all its parts and accessories
out of the reach of small children.
• Keep the phone dry. Precipitation, humidity and
liquids contain minerals that will corrode electronic
circuits.
• Do not use the phone with a wet hand. Doing so
may cause an electric shock to you or damage to
the phone.
• Do not use or store the phone in dusty, dirty areas,
as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the phone,
which may damage the phone's electronic circuit
boards.
• Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the phone. Wipe it with
a soft cloth slightly dampened in a mild soap-and-
water solution.
• Do not paint the phone. Paint can clog the device's
moving parts and prevent proper operation.
• Do not put the phone in or on heating devices,
such as a microwave oven, a stove or a radiator.
The phone may explode when overheated.
• When the phone or battery gets wet, the label
indicating water damage inside the phone changes
color. In this case, phone repairs are no longer
guaranteed by the manufacturer's warranty, even
if the warranty for your phone has not expired.
• If your phone has a flash or light, do not use it too
close to the eyes of people or animals. This may
cause damage to their eyes.
106
Health and safety information
• Use only the supplied or an approved replacement
antenna. Unauthorized antennas or modified
accessories may damage the phone and violate
regulations governing radio devices.
• If the phone, battery, charger or any accessory is
not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
107
Index
A
ABC mode, text input • 22
Active folder • 75
Alarm • 41
Answering
call • 26
second call • 27
Anykey answer • 75
Auto redial • 74
B
Background image • 75
Backlight time, set
display • 77
keypad • 77
Band selection • 80
Barring, calls • 78
Battery
charging • 7
low indicator • 8
Bluetooth
receiving, data • 82
sending, data • 82
settings • 80
Broadcast messages • 60
Browser, web • 43
C
Calculator • 42
Calendar • 64
Call cost • 30
Call log
dialled • 29
missed • 29
received • 29
Call time • 30
Caller ID • 76, 79
Calls answering • 26
barring • 78
diverting • 78
holding • 27
redialling • 25
rejecting • 26
transferring • 28
waiting • 79
Camera
photos • 67
videos • 70
CB (Cell Broadcast) messages •
60
Characters, enter • 22
Configuration messages • 50
Connection tone • 77
Converter • 42
Creating messages
e-mail • 49
MMS • 48
SMS • 47
D
Date, set • 73
Deleting
call log • 30
e-mail • 52, 53, 55
events • 67
MMS • 51, 52, 55
phonebook • 31, 34
SMS • 50, 52, 55
Dialled calls • 29
Dialling display, set • 75
Display
backlight, set • 77
brightness • 76
icons • 10
language • 73
layout • 10
settings • 75
Diverting, calls • 78
DRM (Digital Rights
Management) • 61
DTMF tones, send • 28
E
E-mails
creating/sending • 49
deleting • 53
setting • 57
viewing • 53
F
FDN (Fixed Dialling Number)
mode • 83
File manager • 61
FM radio • 39
Folder tone • 76
G
Games • 38
Greeting message • 73
H
Health and safety • 86
Holding, call • 27
108
Index
I
Icons, description • 10
Images, downloaded • 61
Inbox, messages
e-mail • 53
MMS/SMS • 50
International calls • 25
Internet • 43
J
Java applications • 38
K
Keypad lock • 75
Keypad tones
selecting • 76
sending/muting • 28
volume • 76
L
Language, select • 73
Last number, redial • 25
Light settings • 77
Locking
cover keypad • 75
menu functions • 83
phone • 83
SIM card • 83
Low battery indicator • 8
M
Memory status
downloaded items • 64
file manager • 64
games 39
messages • 60
phonebook 34
shared memory • 83
Message tone • 76
Messages
cell broadcast • 60
configuration • 51
e-mail • 49, 53
greeting • 73
MMS • 48, 51
push • 51, 60
SMS • 47, 50
Minute minder • 77
Missed calls • 29
MMS messages
creating/sending • 48
deleting • 51
setting • 56
viewing • 50
MP3 player • 35
Multiparty-call • 28
Music, downloaded • 63
N
Name card • 34
Names
entering • 22
searching • 31
Network band, select • 80
Network selection • 79
Network services • 78
O
Outbox, messages • 52
P
Password
call barring • 79
phone • 83
Phonedisplay • 10
icons • 10
locking • 83
password • 83
resetting • 84
switching on/off • 8
unpacking • 6
Phonebook
adding • 32
deleting • 31, 34
finding • 31
managing • 34
options • 31
speed dialling • 33
Photos
taking • 67
viewing • 61
PIN, change • 83
PIN2, change • 83
Power on/off tone • 76
Privacy • 83
Problems, solve • 84
Push messages • 51, 60
Q
Quiet mode
entering • 13
setting • 77
R
Received calls • 29
Received messages
e-mail • 53
MMS/SMS • 50
Recording
videos • 70
voice memos • 37
Redialling
automatically • 74
manually • 25
109
Index
Resetting phone • 84
Ringer
incoming calls • 76
messages • 76
Roaming • 79
S
Safety
information • 86
precautions • 1
Security, calls • 82
Sent messages • 52
Shortcut • 73
SIM card
inserting • 7
locking • 83
Skin colour • 75
SMS messages
creating/sending • 47
deleting • 50
setting • 55
viewing • 50
Sound settings • 76
Sounds, downloaded • 63
Speed dial • 33
Stopwatch • 43
Switching on/off
microphone • 27
phone • 8
T
T9 mode, text input • 23
Templates, message • 54
Text, enter • 22
Time, set • 73
Timer • 43
V
Videos
playing • 62
recording • 70
Voice recorder
playing • 38
recording • 37
Voicemail server • 79
W
Waiting call • 79
Wallpaper • 75
Web browser
access • 43
bookmarks • 45
World time • 41
Declaration of Conformity (R&TTE)
For the following product:
GSM900/GSM1800/GSM1900
Portable Cellular Telephone
(Product description)
SGH-E360
(Model name)
Manufactured at:
Samsung Electronics Co., Ltd, 94-1 Imsoo-Dong, Gumi City,
Kyung Buk, Korea, 730-350
(factory name, address
*
)
to which this declaration relates, is in conformity with the following
standards and/or other normative documents.
Safety :
EMC :
:
:
SAR :
Network :
We hereby declare the [all essential radio test suites have been
carried out and that] the above named product is in conformity to all
the essential requirements of Directive 1999/5/EC.
The conformity assessment procedure referred to in Article 10 and
detailed in Annex[
IV
] of Directive 1999/5/EC has been followed with
the involvement of the following Notified Body(ies):
BABT, Balfour House, Churchfield Road,
Walton-on-Thames, Surrey, KT12 2TD, UK
Identification mark: 0168
The technical documentation kept at:
Samsung Electonics Euro QA Lab.
which will be made available upon request.
(Representative in the EU)
Samsung Electronics Euro QA Lab.
Blackbushe Business Park, Saxony Way,
Yateley, Hampshire, GU46 6GG, UK
2005. 08. 01
Yong-Sang Park/S. Manager
(place and date of issue) (name and signature of authorised person)
* It is not the address of Samsung Service Centre. For the address or the phone number
of Samsung Service Centre, see the warranty card or contact the retailer where you
purchased your phone.
