Samsung Electronics Co SGHE400 Tri Band GPRS Phone User Manual E400

Samsung Electronics Co Ltd Tri Band GPRS Phone E400

Contents

Revised User Guide

TRI BAND
GPRS TELEPHONE
SGH-E400
ELECTRONICS
* Some of the contents in this manual may differ from your phone,
depending on the software installed or your service provider.
Printed in Korea
Code No.: GH68-xxxxxA
English. 11/2002. Rev. 1.0
World Wide Web
http://www.samsungmobile.com
Draft version
(2003. 01.10)
23
Contents
Important Safety Precautions ...................... 7
Unpacking .................................................... 9
Your Phone ................................................ 10
Phone Layout................................................ 10
Display ........................................................ 13
Service Light ................................................ 16
Getting Started .......................................... 17
Installing the SIM Card .................................. 17
Charging the Battery ..................................... 19
Switching the Phone On or Off ........................ 23
Call Functions ............................................ 24
Making a Call................................................ 24
Adjusting the Volume .................................... 26
Answering a Call ........................................... 27
Viewing Missed Calls...................................... 28
Switching Quickly to Silent Mode ..................... 30
Selecting Functions and Options ................ 31
Example: Setting the Display Language............ 33
Phonebook ................................................. 35
Storing a Number with a Name ....................... 35
Using Phonebook Entry Options....................... 37
Searching for a Number in the Phonebook ........ 39
Editing a Caller Group .................................... 41
Speed-Dialling .............................................. 42
Checking Memory Status................................ 43
Contents
4
Entering Text ............................................. 44
Changing the Text Input Mode ........................ 45
Using the T9 Mode ........................................ 46
Using the Upper/Lower-Case
Character Mode ............................................ 47
Using the Symbol Mode.................................. 49
Using the Number Mode ................................. 49
Options During a Call ................................. 50
Putting a Call on Hold .................................... 50
Switching the Microphone Off (Mute) ............... 51
Muting/Sending Key Tones ............................. 52
Searching for a Number in the Phonebook ........ 52
Using the SMS Service ................................... 53
Answering a Second Call ................................ 53
Making a Multiparty Call ................................. 54
Using the Menus......................................... 56
Accessing Menu Functions by Scrolling ............. 56
Accessing Menu Functions by Using Shortcuts ... 57
List of Menu Functions ................................... 57
Messages ................................................... 62
Inbox
(Menu 1.1)................................................. 62
Outbox
(Menu 1.2) .............................................. 63
Write New
(Menu 1.3) ......................................... 65
Templates
(Menu 1.4) ......................................... 67
Settings
(Menu 1.5)............................................. 68
My Objects
(Menu 1.6) ........................................ 69
Memory Status
(Menu 1.7) .................................. 70
Voice Mail
(Menu 1.8) .......................................... 70
Broadcast
(Menu 1.9) .......................................... 71
Contents
5
Call Records ............................................... 73
Missed Calls
(Menu 2.1)....................................... 73
Received Calls
(Menu 2.2) ................................... 73
Dialled Calls
(Menu 2.3) ...................................... 74
Call Time
(Menu 2.4) ........................................... 74
Call Cost
(Menu 2.5)............................................ 75
Sound Settings........................................... 76
Ring Tone
(Menu 3.1) .......................................... 76
Ring Volume
(Menu 3.2)...................................... 76
Alert Type
(Menu 3.3) ......................................... 77
Keypad Tone
(Menu 3.4) ..................................... 77
Message Tone
(Menu 3.5) ................................... 78
Extra Tones
(Menu 3.6) ....................................... 79
Phone Settings........................................... 80
Infrared Activate
(Menu 4.1) ............................... 80
My Settings
(Menu 4.2) ....................................... 81
Greeting Message
(Menu 4.3).............................. 82
Own Number
(Menu 4.4) ..................................... 82
Language
(Menu 4.5) .......................................... 83
Security
(Menu 4.6)............................................. 83
Display Settings
(Menu 4.7)................................ 86
Extra Settings
(Menu 4.8) ................................... 88
Short Cut
(Menu 4.9) .......................................... 89
Reset Settings
(Menu 4.10) ................................. 89
Organiser ................................................... 90
Calendar
(Menu 5.1)............................................ 90
To Do List
(Menu 5.2).......................................... 92
Time & Date
(Menu 5.3) ...................................... 95
Alarm
(Menu 5.4) ................................................ 96
Calculator
(Menu 5.5) .......................................... 97
Currency Exchange
(Menu 5.6) ........................... 98
Contents
6
Network Services ....................................... 99
Call Diverting
(Menu 6.1) .................................... 99
Call Barring
(Menu 6.2) ...................................... 101
Call Waiting
(Menu 6.3) ...................................... 103
Network Selection
(Menu 6.4) ............................ 104
Caller ID
(Menu 6.5)........................................... 105
Closed User Group (CUG)
(Menu 6.6)................. 105
Band Selection
(Menu 6.7) ................................. 107
Funbox ..................................................... 108
Games
(Menu 7.1).............................................. 108
WAP Browser
(Menu 7.2).................................... 108
Downloads
(Menu 7.3)........................................ 108
Solving Problems ..................................... 111
Access Codes ........................................... 114
Phone Password.......................................... 114
PIN ........................................................... 115
PUK........................................................... 115
PIN2.......................................................... 116
PUK2 ......................................................... 116
Barring Password ........................................ 117
Health and Safety Information ................. 118
Exposure to Radio Frequency (RF) Signals ...... 118
Exposure to Radio-Frequency
Energy (SAR Information) ............................ 121
Precautions When Using Batteries.................. 123
Road Safety ............................................... 125
Operating Environment ................................ 127
Potentially Explosive Atmospheres................. 129
Emergency Calls ......................................... 130
Other Important Safety Information .............. 131
Care and Maintenance ................................. 132
Glossary ................................................... 134
Index ....................................................... 139
7
Important Safety
Precautions
Read these guidelines before using your wireless
phone. Failure to comply with them may be
dangerous or illegal. For more detailed safety
information, see “Health and Safety Information”
on page 118.
Road Safety at All Times
Do not use a hand-held phone while driving; park
the vehicle first.
Switching Off When Refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switching Off in Aircraft
Wireless phones can cause interference. Using them
in aircraft is both illegal and dangerous.
Switching Off in Hospitals
Switch off your phone near medical equipment.
Follow any regulations or rules in force.
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Special Regulations
Meet any special regulations in force in any area
and always switch off your phone whenever it is
forbidden to use it, or when it may cause
interference or danger (in a hospital for example).
Important Safety Precautions
8
Radio Frequency Exposure
The design of this phone complies with European
Union (EU) requirements relating to radio frequency
(RF) exposure. To maintain compliance with these
requirements, use only Samsung-supplied or
approved accessories. Use of non-approved
accessories may violate the requirements.
Sensible Use
Use only in the normal position (held to the ear).
Avoid unnecessary contact with the antenna when
the phone is switched on.
Accessories and Batteries
Use only Samsung-approved accessories and
batteries.
Qualified Service
Only qualified service personnel may install or
repair your phone.
9
Unpacking
Your package contains the following items:
In addition, you can obtain the following
accessories for your phone from your local
Samsung dealer:
• Desktop charger • Ear-microphone
• Simple hands-free kit • Car holder
• Standard/slim batteries
• Cigarette lighter adapter
Handset Travel Adapter/
Battery Charger
Battery Ear-Microphone
User’s Manual
Hand Strap
Software CD-ROM Data Cable
10
Your Phone
Phone Layout
The following illustrations show the main elements
of your phone.
Earpiece
Display
Soft key (right)
WAP Browser
key
Power on/off /
menu exit key
Alphanumeric
keys
Special
function keys
Navigation
keys
Volume/menu
browse keys
Soft key (left)
Dial/menu
confirmation key
IrDA port Microphone
Cancel/
correction key
Ear-microphone
jack
Antenna
External display
Service light
Your Phone
11
Key Description
In menu mode
, scroll through the menu
options and Phonebook memory.
In idle mode,
allow you to access your
favourite menu options directly; for
more information on shortcuts, see
page 89.
In menu mode
, return to the previous
menu level and select the current menu
respectively.
When entering text, move to the cursor
left and right respectively.
In idle mode, allow you to access your
favourite menu options directly; for
more information on shortcuts, see
page 89.
(soft keys)
Perform the functions indicated by the
text above them, on the bottom line of
the display.
In idle mode, launches the WAP
(Wireless Application Protocol) Browser
directly.
Deletes characters from the display.
In menu mode, returns to the previous
menu level.
Your Phone
12
Makes or answers a call.
When held down in idle mode, recalls
the last number dialled or received.
In menu mode, selects a menu function
or stores information that you have
entered, such as a name, in the phone
or SIM memory.
Ends a call. Also switches the phone on
and off when held down.
In menu mode, cancels your input and
returns to the idle mode.
When held down in idle mode, quickly
accesses your voice mail.
Enter numbers, letters and some
special characters.
Enter special characters.
Perform various functions.
(on the side of the phone)
During a call, adjust the earpiece
volume.
In idle mode, adjust the key volume.
In menu mode, scroll through the menu
options and Phonebook memory.
Key Description (continued)
Your Phone
13
Display
Display Layout
The display comprises three areas.
Area Description
First line Displays various icons (see
page 14).
Middle lines Display messages, instructions
and any information that you
enter (number to be dialled, for
example).
Last line Shows the functions currently
assigned to the two soft keys.
Icons
Text and
graphic area
Soft keys
Indications
Menu Name
Your Phone
14
Icons
Icon Description
Shows the received signal strength. The
greater the number of bars, the stronger
the signal.
Appears when a call is in progress.
Appears when you are connected to the
GPRS network.
Appears when you are out of your home
area and have registered with a different
network; for example, when travelling in
other countries.
Appears when you set an alarm to ring at
a specified time.
Appears when you are entering text to
indicate the current text input mode.
Appears when a new text message has
been received.
Appears when a new voice mail message
has been received.
Appears when the silent mode is active or
you set the
Alert Type
menu option
(
Menu 3.3
) so that the phone vibrates
when you receive a call; for further
details, see page 77.
Appears when the IrDA port is active. For
details, see page 80.
Your Phone
15
Backlight
A backlight illuminates the display and the keypad.
When you press any key or open the folder, the
backlight turns on and lights for a given period of
time, depending on the
Back Light
menu option.
Then it dims and finally turns off after one minute.
To specify the length of time for which the backlight
is active, set the
Back Light
menu option (
Menu
4.7.2
); see page 86 for further details.
You can also set the phone to use the backlight only
during a specified period of time, in the
Auto Light
menu option (
Menu 4.7.3
); see page 87 for
further details.
External Display
Your phone has an external display on the folder. It
indicates when you have an incoming call or a
message. It also alerts you when you have set an
alarm at the specified time by showing its backlight
and corresponding icon on it.
When the folder is closed, the display is off so that
you can use it as a mirror. If you want to turn the
display on, press and hold the or key on the left
side of the phone.
When a call comes in or you open the folder, the
display automatically turns on.
Appears when the mute mode is active.
Shows the level of your battery. The more
bars you see, the more power you have
left.
Icon Description
Your Phone
16
Service Light
The service light is below the external display of the
phone. It flashes when services are available on the
phone.
To activate or deactivate use of the service light, set
the
Service Light
menu option (
Menu
4.7.4
);
see page 87 for further details.
Service light
17
Getting Started
Installing the SIM Card
When you subscribe to a cellular network, you are
provided with a plug-in SIM card loaded with your
subscription details, such as your PIN, any optional
services available and so on.
Important!
The plug-in SIM card and its contacts
can be easily damaged by scratches
or bending, so be careful when
handling, inserting or removing the
card.
Keep all SIM cards out of the reach of
small children.
1. If necessary, switch off the phone by holding
down the key until the power-off image
displays.
2. Remove the battery. To do so:
➀ Pull the battery lock above the battery toward
the top of the phone and hold it in that
position.
➁ Lift the battery away, as shown.
➀
➁
Getting Started
18
3. Slide the SIM card into the SIM card socket so
that it locks the card in position.
Make sure that the cut corner is bottom left and
the gold contacts of the card face into the
phone.
Note
: When you need to remove the SIM card, slide
it, as shown, and take it out of the socket.
4. Place the battery so that the tabs on the end
align with the slot at the bottom of the phone.
Getting Started
19
5. Push the battery down until it clicks into place.
Make sure that the battery is properly installed
before switching the phone on.
Charging the Battery
Your phone is powered by a rechargeable Li-ion
battery. A travel adapter and a battery charger come
with your phone. Use only approved batteries and
chargers. Ask your local Samsung dealer for further
details.
Note
: You must fully charge the battery before using
your phone for the first time. A discharged
battery is fully recharged in approximately
200 minutes.
Using the Travel Adapter
The travel adapter allows you to use the phone while
the battery is charging, but this will cause the phone
to charge more slowly.
Getting Started
20
1. With the battery in position on the phone,
connect the lead from the travel adapter to the
bottom of the phone.
2. Connect the adapter to a standard AC wall
outlet.
3. When charging is finished, disconnect the
adapter from the power outlet and from the
phone by pressing the gray tabs on both sides of
the connector and pulling the connector out.
Getting Started
21
Using the Battery Charger
Using the battery charger, you can charge the
battery alone.
1. Insert the battery into the charger, ensuring that
the terminals on the battery are in contact with
those on the charger. Press the battery down
until it clicks into place.
2. Plug the connector of the travel adapter into the
jack at the bottom of the charger.
3. Plug the adapter into a standard AC wall outlet.
The LED on the charger will indicate the
charging progress with the following colours:
• Red: the battery is charging.
• Green: the battery is completely charged.
• Yellow: the battery is not correctly plugged in
or operating in a too high or too low
temperature.
Getting Started
22
4. When charging is finished, unplug the adapter
from both the power outlet and the charger.
5. Remove the battery from the charger.
Low Battery Indicator
When the battery is weak and only a few minutes of
talk time remain, you will hear a warning tone and
a message will be repeated at regular intervals on
the display:
If the battery level gets too low, the phone turns off
automatically.
**Warning**
Low Battery
Menu Name
Getting Started
23
Switching the Phone On or Off
1. Open the folder.
2. Hold down the key until the phone
switches on.
3. If the phone asks you to enter the phone
password, enter the password and press the
OK
soft key. The phone password is preset to
“00000000” at the factory. For further details,
see page 114.
4. If the phone asks for a PIN, enter the PIN and
press the
OK
soft key. For further details, see
page 115.
The phone searches for your network and when
it finds the network, the idle screen, illustrated
below, appears on each display. Now, you can
make or receive a call.
Note
: The display language is preset to English at the
factory. To change the language, use the
Language
menu option (
Menu 4.5
); for
further details, refer to page 83.
5. When you wish to switch the phone off, hold
down the key until the power-off image is
displayed.
Service Provider
07:30
Wed 06 Mar
Menu Name
07:30
Wed/06
24
Call Functions
Making a Call
When the idle screen is displayed, enter the area
code and phone number, and press the key.
Note:
If you have checked the
Auto Redial
option
in the
Extra Settings
menu (
Menu 4.8
),
the phone automatically redials up to ten times
when the person does not answer the call or is
already on the phone; see page 88 for further
details.
Making a International Call
1. Press and hold down the key.
The
+
character appears.
2. Enter the country code, area code and phone
number and press the key.
Correcting the Number
To clear... Press...
the last digit
displayed
the key.
any other digit in
the number
the or key until the cursor
is immediately to the right of
the digit to be cleared. Press
the key. You can also
insert a missing digit simply by
pressing the appropriate key.
the whole display and hold down the key for
more than one second.
Call Functions
25
Ending a Call
When you want to finish your call, briefly press the
key.
Redialling the Last Number
The phone stores the numbers you dialled, received
or missed if the caller is identified; see “Call
Records” on page 73 for further details.
To recall any of these numbers:
1. If you have typed any characters on the display,
clear the display by holding down the key
for more than one second.
2. Press the key to display a list of the last
numbers in the order in which the calls were
made.
3. Use the and keys to scroll through the
numbers until the required number highlights.
4. T
o... Press the...
dial the number
highlighted
key.
edit the number
highlighted
Edit
soft key. Change the
number as required,
referring to “Correcting
the Number” on page 24
for further details.
Call Functions
26
Making a Call from the Phonebook
You can store the phone numbers that you use
regularly in the SIM card or the phone’s memory,
which are collectively called the Phonebook. Simply
select the required name to recall the associated
number. For further details on the Phonebook
features, refer to page 35.
Adjusting the Volume
During a call, if you want to adjust the earpiece
volume, use the and keys on the left side of the
phone.
Press the key to increase and the key to
decrease the volume.
In idle mode with the folder open, you can adjust
the key volume using the and keys.
Call Functions
27
Answering a Call
When someone calls you, the phone alerts you by
ringing and displaying the following screen:
If the caller can be identified, the caller’s phone
number or name, if stored in your Phonebook,
displays.
1. If necessary, open the folder. Press the key
or the
Accept
soft key to answer the incoming
call.
If the
Anykey Answer
option in the
Extra
Settings
menu (
Menu 4.8
) is checked, you
can press any key to answer a call, except for
the key and the
Reject
soft key (see
page 88).
If the
Active Folder
option in the
Extra
Settings
menu (
Menu 4.8
) is checked, you
can answer the call simply by opening the folder
(see page 88).
Note
: To reject an incoming call, press and hold the
volume keys on the left side of the phone
before opening the folder.
2. End the call by closing the folder or pressing
the key.
Note
: You can answer a call while using the
Phonebook or menu features.
xxx-xxxx
Accept Reject
Call Functions
28
Viewing Missed Calls
If you are unable to answer a call for any reason,
you can find out who is calling you, if this service is
available. So that you can call the person back, if
necessary.
The number of missed calls displays on the idle
screen immediately after a call is missed.
To view the missed call immediately:
1. If the phone is closed, open the folder.
2. Press the
View
soft key.
The number corresponding to the most recent
missed call displays, if available.
3. To.... Press the...
scroll through the
missed calls
or key.
call the number
displayed
key.
edit or delete a
missed call number
Select
soft key (see
the following page).
Call Functions
29
Editing a Missed Call Number
Note
: If the number corresponding to the missed call
is not available, the
Edit Number
option is
not displayed.
1. Press the
Options
soft key.
2. Press the or key to highlight the
Edit
Number
option.
3. Press the
Select
soft key.
4. Change the number as required.
Deleting a Missed Call
1. Press the
Options
soft key.
2. If necessary, press the or key to
highlight the
Delete
option.
3. Press the
Select
soft key.
You can press the key at any time to exit the
Missed Call feature.
Note
: You can access the Missed Call feature at any
time by selecting the
Missed Calls
menu
option (
Menu 2.1
); for further details, see
page 73.
5. To... Press the...
call the number key.
store the
number
Save
soft key and enter the
name and location required
(for further details, refer to
page 35).
Call Functions
30
Switching Quickly to Silent Mode
The silent Mode is convenient when discretion is
required and you wish to stop the phone from
making any noise, in a theatre for example.
In idle mode, to switch your phone quickly to silent
mode, simply press and hold down the key
until the “Silent Mode” message and the vibration
icon ( ) are displayed.
In silent mode, your phone changes the sound
settings as follows.
To exit the silent mode and reactivate the previous
Sound Settings, press and hold the key again
until “Exit Silent Mode” appears. The vibration icon
() is no longer displayed.
Option New Setting
Alert Type (Menu 3.3) Vibration
Keypad Tone (Menu 3.4)OFF
SMS Tone (Menu 3.5.1) Light Only
Error Tone (Menu 3.6.1)OFF
31
Selecting Functions
and Options
Your phone offers a set of functions that allow you
to customise it. These functions are arranged in
menus and sub-menus, accessed via the two soft
keys marked and . Each menu and sub-menu
allows you to view and alter the settings of a
particular function.
The roles of the soft keys vary according to the
current context; the label on the bottom line of the
display just above each key indicates its current
role.
Example:
Options 918
Press the left soft
key to access the
available options.
Press the right soft
key to change the
text input mode.
Selecting Functions and Options
32
To view the various functions/options available and
select the one required:
1. Press the appropriate soft key.
In some functions, you may be asked for a
password or PIN. Enter the required code and press
the
OK
soft key.
2. To... Press the...
select the:
• Function displayed
• Option highlighted
Select
soft key or
the key.
view the next function
or highlight the next
option in a list
key or key on the
left side of the phone.
move back to the
previous function or
option in a list
key or key on the
left side of the phone.
move back up one
level in the structure
key, soft key or
key.
exit the structure
without changing the
settings
key.
Selecting Functions and Options
33
Example: Setting the Display
Language
1. When the idle screen displays, press the
Menu
soft key to access the menus.
2. Scroll through the menus until you reach the
Phone Settings
menu, by pressing the
or key.
3. To select the
Phone Settings
menu, press the
Select
soft key or the key.
Service Provider
07:30
Wed 06 Mar
Menu Name
4
Select
4.1
Phone Settings
Select
Infrared Activ...
My Settings
Greeting Me...
Own Number
Language
Security
If the menu name is too
long for the display, it is
scrolled when highlighted.
Selecting Functions and Options
34
4. Scroll through the sub-menus until you reach
the
Language
sub-menu, by pressing the
or key.
5. To view the languages available, press the
Select
soft key or the key.
The current setting highlights.
6. Scroll through the list of languages until the
appropriate one highlights, by pressing the
or key.
7. Press the
Select
soft key or the key to
confirm your selection.
8. Press the or key twice to exit the menu
structure.
4.5
Phone Settings
Infrared Activ...
My Settings
Greeting Me...
Own N
Language
Security
Shows the current
setting
English
Select
4.5.2
Current language
Language
English
Italiano
Français
Español
Nederlands
Deutsch
Select
35
Phonebook
You can store phone numbers and their
corresponding names in the memory of your SIM
card. In addition, you can store up to 500 numbers
in the phone memory. The SIM card and phone
memories, although physically separate, are used
as a single entity, called the Phonebook.
Storing a Number with a Name
There are two ways to store a number:
• Using the
Save
soft key in idle mode
• Using the
New Entry
option in the Phonebook
menu
Storing a Number in Idle mode
As soon as you start to enter a number,
Save
appears above the left soft key to allow you to store
the number in the Phonebook.
1. Enter the number you want to store.
Note
: If you make a mistake while entering a
number, correct it using the key. For
further details, refer to page 24.
2. To save the number, press the
Save
soft key.
3. Select an icon to identify the category of number
to be stored. Three categories are available:
(mobile phone number), (office number)
and (home number). To select the category,
press the or key, followed by the Select soft
key.
Phonebook
36
4. Enter a name and press the
OK
soft key.
The maximum length of a name depends on
your SIM card. For information on how to enter
characters, see page 44.
The phone now displays the first free location in
the last memory used to save a number and
name. If that memory is full, the first free
location in the other memory is displayed.
Note
: If you change phones, any numbers stored
in your SIM card memory will automatically
be available with the new phone, whereas
any numbers stored in the phone memory
must be restored.
5. Press the right soft key, labelled
To Card
or
To
Phone
to toggle between the phone and card
memories.
6. If you do not want to save the number and
name in the suggested location, press the
key to clear the location number and enter your
preferred location by pressing the number keys.
7. Press the
OK
soft key to store the name and
number.
After storing, the phone displays the Phonebook
entry or name just created.
8. To... Press the...
use the entry options
Options
soft key.
return to the idle screen key.
Phonebook
37
Storing a Number Using the Phonebook
Menu
1. When the idle screen is displayed, press the
Name
soft key.
2. Scroll to
New Entry
by pressing the or
key and press the
Select
soft key.
3. Select an icon to identify the category of the
number to be stored.
Note
: The E-mail icon ( ) is available in this
step. It allows you to save an E-mail
address instead of a phone number.
4. Continue the procedure from Step 4 on page 36
to store the number.
Using Phonebook Entry Options
While accessing any Phonebook entry, press the
Options
soft key to access the options for the
entry.
To... Press the...
select the
highlighted option
Select
soft key or the key.
highlight a
different option
or key until the
required option highlights.
Phonebook
38
The following options are available:
Paste
: allows you to paste the selected number
into the normal dialling mode. Use this option to
dial a number similar to one in the Phonebook, a
different extension in the same office, for example.
Use the key to change the number as
required; refer to page 24 for further details. When
you are ready to dial, press the key.
Edit
:
allows you to edit the selected name and
number.
Erase
: allows you to erase the selected name and
number from the Phonebook. You are asked to
confirm that you wish to erase the name and
number by pressing the
Yes
soft key.
Copy
: allows you to copy the selected number to
another location. Use this option to store a number
similar to one already in the memory; once copied,
edit the number and store it in the Phonebook.
Caller Group
: allows you to organise your
Phonebook entries in up to 10 caller groups so that
the phone alerts you in a specific way when a
person from one of your groups calls you. Select
one of the ten groups available.
To remove an entry from a group, select the
No
Group
option.
For more information on how to change caller group
properties, see page 41.
Add Entry
: allows you to add a new number in
a different category (mobile, office, home or
E-mail) to the currently selected name. A
Phonebook entry or name can contain up to four
number, one in each category.
Phonebook
39
Searching for a Number in the
Phonebook
After storing numbers in the Phonebook, you can
search for them in two ways: by name and by caller
group.
Searching for a Number by Name
1. When the idle screen is displayed, press the
Name
soft key.
2. Press the
Select
soft key when
Search
highlights. You are asked to enter a name.
3. Enter the first few letters of the name that you
wish to find.
The Phonebook entries are listed, starting with
the first entry matching your input. This entry
also highlights.
5. Once you have found the required entry, press
the key to dial the number, or press the
Options
soft key to access the Phonebook
entry options; for further details, see page 37.
4. To... Press the...
view the highlighted
entry
View
soft key.
select a different
entry
or key until the
required entry highlights.
look for a name
starting with a
different letter
key labelled with the
required letter.
Phonebook
40
Searching for a Number by Caller Group
1. When the idle screen is displayed, press the
Name
soft key.
2. Scroll to
Group Search
by pressing the
or key and press the
Select
soft key. You
are asked to enter a group name.
3. Enter the first few letters of the group name that
you wish to find.
The caller groups are listed, starting with the
first group matching your input. The group also
highlights.
4. Scroll to the required group by pressing the
or key and press the
View
soft key.
The Phonebook entries in the selected caller
group are listed.
6. Once you have found the required entry, press
the key to dial the number, or press the
Options
soft key to access the Phonebook
entry options; for further details, see page 37.
5. To... Press the...
view the
highlighted entry
View
soft key.
select a different
entry
or key until the
required entry highlights.
Phonebook
41
Editing a Caller Group
1. When the idle screen is displayed, press the
Name
soft key.
2. Scroll to
Group Edit
by pressing the or
key and press the
Select
soft key.
3. Enter the first few letters of the required group
name or scroll through the group list by pressing
the or key.
4. When the required group highlights, press the
Options
soft key.
5. Select each option and change the settings, as
required. The following options are available:
•
Call ring tone
: allows you to select a ring
tone to be used when you receive a voice call
from a person in the group.
•
SMS tone
: allows you to select a ring tone to
be used when you receive a text message
from a person in the group.
•
Graphic
: allows you to select a graphic icon
to be displayed when you receive a voice call
from a person in the group.
•
Group Name
: allows you to assign a name to
the group; for further details on how to enter
characters, see page 44.
6. When you finish changing the settings, press the
or key.
Phonebook
42
Speed-Dialling
Once you have stored phone numbers in the SIM
card, you can set up to eight speed-dial entries and
then dial them easily whenever you want, simply by
pressing the associated number key.
Setting Up Speed-Dial Entries
1. When the idle screen is displayed, press the
Name
soft key.
2. Scroll to
Speed Dial
by pressing the or
key and press the
Select
soft key.
3. Select the key to which you wish to assign the
speed-dialling feature, from to keys,
and press the
OK
soft key.
Note
: If you have already assigned a number to
the key, the
Options
soft key replaces the
OK
soft key. Go to Step 6.
4. Select the required Phonebook entry from the
list and press the
View
soft key.
5. Select the required number if the entry has
more than one number, by pressing the
or key and press the
Select
soft key.
6. Once you have assigned a number to the
selected key, the following options are available:
Change
: allows you to assign a different
number to the key.
Erase
: allows you to clear the setting so that no
number is assigned to the key.
Phonebook
43
Erase All
: allows you to clear the settings for
all keys so that no numbers are assigned to any
of the keys.
Number
: allows you to view the number
assigned to the key.
7. When you finish setting the options, press the
or key.
Speed-Dialling from the Phonebook
To speed-dial the numbers assigned to keys,
to , press and hold down the appropriate key.
Note
: Memory location 1 is reserved for your Voice
Mail server number.
Checking Memory Status
You can check how many names and numbers are
stored in the Phonebook; SIM card and phone
memories. You can also see the capacity of both
memories.
1. When the idle screen is displayed, press the
Name
soft key.
2. Select the
Memory Status
option.
3. Press the and keys to view the number of
the existing and remaining entries in the card
and phone memories.
44
Entering Text
When using your phone, you will often need to
enter text. For example, when storing a name in the
Phonebook, creating your personal greeting or
scheduling events in your calendar. You can enter
alphanumeric characters by using your phone’s
keypad.
Your phone has the following text input modes.
• T9 mode
This mode allows you to enter words with only
one keystroke per letter. Each key on the keypad
has more than one letter – when you press the
key once, J, K or L displays. The T9 mode
automatically compares your keystrokes with an
internal linguistic dictionary to determine the
correct word, thus requiring far fewer keystrokes
than the traditional upper/lower-case character
modes.
• Upper/lower-case character modes
These modes allow you to enter letters by
pressing the key labelled with the required letter
once, twice, three or four times until the letter
displays.
• Symbol mode
This mode allows you to enter various symbols
and special characters.
• Number mode
This mode allows you to enter numbers.
Entering Text
45
Changing the Text Input Mode
When you are in a field that allows characters to be
entered, you will notice the text input mode
indicator on the display.
To select the... Press the soft key
until...
T9 mode displays.
See page 46.
Upper-case character
mode
displays.
See page 47.
Lower-case character
mode
displays.
See page 47.
Number mode displays.
See page 49.
Symbol mode displays.
See page 49.
916
Options
HI
Text input
mode indicator
Entering Text
46
Using the T9 Mode
The T9 predictive text input mode allows you to key
in any character using single keystrokes. This text
input mode is based on a built-in dictionary.
1. When you are in T9 predictive text input mode,
start entering a word by pressing keys to
. Press each key only once for one letter.
Example: to enter HELLO in the T9 mode,
press , , , and .
The word that you are typing appears on the
display. It may change with each key that you
press.
2. Enter the whole word before editing or deleting
the keystrokes.
3. If the word is correct, start entering the next
word.
Otherwise, press the , or key
repeatedly to display alternative word choices
for the keys that you have pressed.
Example: both OF and ME have the sequence
, . The phone displays the
most commonly used choice first.
4. Put a space between each word by pressing the
key.
•To type words not found in the T9 mode, change
the text input mode to the upper/lower-case
character input mode. Words typed in these
modes are automatically added to the T9
dictionary so that you can type them next time
using the T9 mode.
Entering Text
47
•To enter full stops, hyphens or apostrophes, press
the key. The T9 mode applies grammar rules
to ensure that the correct punctuation is used.
Example: is used twice to display two
punctuation marks:
•To shift the case in T9 mode, use the key.
•You can move the cursor by using the and
keys. To delete letters, press the key. Press
and hold down the key to clear the display.
Using the Upper/Lower-Case
Character Mode
Use the to keys to enter your text.
1. Press the keys labelled with the required letter:
- Once for the first letter
- Twice for the second letter
- And so on
2. Select the other letters in the same way.
Note
: The cursor moves to the right when you press a
different key. When entering the same letter
twice or a different letter on the same key, just
wait for a few seconds for the cursor to move
to the right automatically, and then select the
next letter.
L E T ’ S E A T .
Entering Text
48
Refer to the table below for more information about
the characters available.
•To insert a space, press the key.
•You can move the cursor by using the and
keys. To delete letters, press the
key. Press
and hold down the
key to clear the display.
Characters in the Order Displayed
Key
Space
Upper CaseUpper Case Lower Case
Entering Text
49
Using the Symbol Mode
The Symbol mode enables you to insert symbols
into a text message.
Use the navigation keys to scroll to the desired
symbol and then press
OK
soft key to insert the
highlighted symbol into your message.
Using the Number Mode
The Number mode enables you to enter numbers
into a text messages. Press the keys corresponding
to the desired digits, and manually switch back to
the text input mode of choice.
918
OK
50
Options During a Call
Your phone provides a number of control functions
that you can use during a call.
Putting a Call on Hold
You can place the current call on hold whenever you
want. You can make another call while you have a
call in progress if your network supports this
service. If you have an active call and a call on hold,
you may switch between the two calls, changing the
one on hold to active and placing the other on hold.
To place a call on hold, simply press the
Hold
soft
key. You can reactivate the call whenever you want,
by pressing the
Unhold
soft key.
To make a call while you have a call in progress:
1. Key in the phone number that you wish to dial or
look it up in the Phonebook.
2. Press the key to dial the second call.
The first call is automatically put on hold.
Or alternatively,
1. Put the current call on hold by pressing the
Hold
soft key.
2. Make the second call in the normal way.
To switch between the two calls, simply press the
Swap
soft key.
The current call is placed on hold and the call on
hold is reactivated so that you can continue
conversing with the other party.
When you have finished, end each call normally by
pressing the key.
Options During a Call
51
Switching the Microphone Off (Mute)
You can temporarily switch your phone’s
microphone off so that the other party cannot hear
you.
Example: You wish to say something to another
person in the room but do not want the
other party to hear you.
To switch the microphone off temporarily:
1. Press the
Options
soft key.
2. If necessary, press the key to highlight the
Mute
option.
3. Press the
OK
soft key.
The other party can no longer hear you.
To switch the microphone back on:
1. Press the
Options
soft key.
2. If necessary, press the key to highlight the
Unmute
option.
3. Press the
OK
soft key.
The other party can hear you again.
Options During a Call
52
Muting/Sending Key Tones
These options allow you to turn the key tones off or
on. If the
Mute keys
option is selected, your
phone does not transmit the key tones. It allows
you to press keys without hearing annoying key
tones during a call.
Note:
To communicate with answering machines or
computerised telephony systems, the
Send
keys
option must be selected.
Searching for a Number in the
Phonebook
You can search for a number in the Phonebook
during a call.
1. Press the
Options
soft key.
2. Press the key to highlight the
Phonebook
option.
3. Press the
OK
soft key.
The Phonebook entries are listed.
4. Enter the name that you wish to find.
If you enter the first few letters of the name, the
Phonebook entries are listed, starting with the
first entry matching your input. The entry also
highlights.
5. To view the highlighted entry, press the
View
soft key.
For further details on the Phonebook feature, refer
to page 35.
Options During a Call
53
Using the SMS Service
If you receive an SMS (Short Message Service)
message during a call, the message icon ( )
flashes on the display. The
SMS Service
option
enables you to use this feature.
Read Messages
: allows you to read the messages
that you have received.
Write Messages
: allows you to write a message.
For further details on the SMS service, refer to
page 62.
Answering a Second Call
You can answer an incoming call while you have a
call in progress, if your network supports this
service and you have set the
Call Waiting
menu
option (
Menu 6.3
) to
Activate
(see page 103).
You will be notified of an incoming call by a call
waiting tone.
To answer a call while you have a call in progress:
1. Press the key to answer the incoming call.
The first call is automatically put on hold.
2. To switch between the two calls, press the
Swap
soft key.
To end the call on hold, press the
Options
soft
key and select the
End Held Call
option.
3. To end the current call, press the key.
Options During a Call
54
Making a Multiparty Call
A multiparty call is a network service that allows up
to six people to take part simultaneously in a
multiparty or conference call. For more information,
contact your service provider.
Setting up the Multiparty Call
1. Call the first participant in the normal way.
2. Call the second participant in the normal way.
The first call is automatically put on hold.
3. To join the first participant to the multiparty call,
press the
Options
soft key and select the
Join
option.
4. To add a new person to the multiparty call, call
the person in the normal way, and then press
the
Options
soft key and select the
Join
option.
You can add incoming callers by answering the call
and pressing
Options
, followed by
Join
. Repeat as
required.
Having a Private Conversation With One
Participant
1. Press the
Options
soft key and choose the
Select one
option.
The list of call participants appears.
2. Highlight the required person, by pressing
the or key, followed by the
Select
soft
key or the key.
Options During a Call
55
3. Select the
Private
option.
Now you can talk privately with that person. The
other participants can still converse with each
other.
4. To return to the multiparty call, press the
Options
soft key and select
Join
.
All the multiparty call participants can now hear
each other.
Dropping One Participant
1. Press the
Options
soft key and choose the
Select one
option.
The list of call participants appears.
2. Select a person from the list by pressing the
or key, followed by the
Select
soft key or
the key.
3. Select
Remove
.
The call ends with that participant, but you can
continue to talk with the other participants.
4. End the multiparty call by closing the folder or
pressing the key.
56
Using the Menus
The phone offers a range of functions that allow you
to tailor it to your needs. These functions are
arranged in menus and sub-menus.
The menus and sub-menus can be accessed by
scrolling with the navigation keys or by using the
shortcuts.
Accessing Menu Functions by Scrolling
1. In idle mode, press the
Menu
soft key to access
menu mode.
2. Scroll with the or key to reach the
required main menu,
Phone Settings
for
example. Press the
Select
soft key or the key
to enter the menu.
3. If the menu contains any sub-menus,
Language
for example, you can access them
by scrolling with the or key and pressing
the
Select
soft key.
If the menu that you have selected contains
further options, repeat this step.
4. To... Press the...
scroll through the
menus
or key or use the
and keys on the left
side of the phone.
confirm the chosen
setting
Select
soft key or the
key.
return to the
previous menu level
soft key or the key.
exit the menu
without changing
the settings
key.
Using the Menus
57
Accessing Menu Functions by
Using Shortcuts
The menu items, menu, sub-menus and options,
are numbered and can be accessed quickly by using
their shortcut number. The shortcut number is
shown on the bottom right next to the soft key
on the display. Simply press the
Menu
soft key and
key in the required number.
Note
: The numbers assigned to each menu option are
indicated in the list on page 57. They may not
match the menu number on the phone,
depending on the services supported by your
SIM card.
Example: Accessing the
Language
option.
1. Press the
Menu
soft key.
2. Press for
Phone Settings
.
3. Press for
Language
.
The languages available displays.
List of Menu Functions
The following illustration shows the menu structure
available and indicates the:
• number assigned to each option
• page on which you can find a description of each
feature
Note
: If you use a SIM AT card that provides
additional services, the
SIM AT
menu (
8
)
displays first when you press the
Menu
soft
key to enter menu mode. For further details,
refer to your SIM card instructions.
Using the Menus
58
1. Messages
(see page 62)
1.1 Inbox
1.2 Outbox
1.3 Write New
1.4 Templates
1.5 Settings
1.5.1 Setting 1
*
1.5.2 Setting 2
*
1.5.3 Setting 3
*
1.5.4 Common Setting
1.6 My Objects
1.6.1 My EMS Melody
1.6.2 My EMS Picture
1.6.3 My EMS Animation
1.6 4 Delete All
1.7 Memory Status
1.7.1 SIM memory
1.7.2 PHONE memory
1.7.3 CB memory\
1.7.4 Delete All
1.8 Voice Mail
1.8.1 Connect to Voice Server
1.8.2 Voice Server Number
1.9 Broadcast
1.9.1 Read
1.9.2 Receive
1.9.3 Channel List
1.9.4 Language
2. Call Records
(see page 73)
2.1 Missed Calls
2.2 Received Calls
2.3 Dialled Calls
2.4 Call Time
2.4.1 Last Call Time
2.4.2 Total Sent
2.4.3 Total Received
2.4.4 Reset Timers
* Shown only if supported by your SIM card.
Using the Menus
59
2. Call Records
(continued)
2.5 Call Cost
*
2.5.1 Last Call Cost
2.5.2 Total Cost
2.5.3 Max Cost
2.5.4 Reset Counters
2.5.5 Set Max Cost
2.5.6 Price/Unit
3. Sound Settings
(see page 76)
3.1 Ring Tone
3.2 Ring Volume
3.3 Alert Type
3.4 Keypad Tone
3.5 Message Tone
3.5.1 SMS Tone
3.5.2 SMS-CB Tone
3.6 Extra Tones
3.6.1 Error Tone
3.6.2 Minute Minder
3.6.3 Connect Tone
4. Phone Settings
(see page 80)
4.1 Infrared Activate
4.2 My Settings
4.2.1 Wallpaper
4.2.2 Colour Theme
4.2.3 Menu Style
4.3 Greeting Message
4.4 Own Number
4.5 Language
4.6 Security
4.6.1 PIN Check
4.6.2 Change PIN
4.6.3 Phone Lock
4.6.4 Change Password
4.6.5 SIM Lock
4.6.6 FDN Mode*
4.6.7 Change PIN2*
* Shown only if supported by your SIM card.
Using the Menus
60
4. Phone Settings
(continued)
4.7 Display Settings
4.7.1 Contrast
4.7.2 Back Light
4.7.3 Auto Light
4.7.4 Service Light
4.7.5 Graphic Logo
4.8 Extra Settings
4.8.1 Auto Redial
4.8.2 Active Folder
4.8.3 Anykey Answer
4.9 Short Cut
4.10 Reset Settings
5. Organiser
(see page 90)
5.1 Calendar
5.2 To Do List
5.3 Time & Date
5.3.1 Set Time
5.3.2 Set Date
5.3.3 World Time
5.3.4 Time Format
5.4 Alarm
5.5 Calculator
5.6 Currency Exchange
6. Network Services
(see page 99)
6.1 Call Diverting
6.1.1 Divert Always
6.1.2 Busy
6.1.3 No Reply
6.1.4 Unreachable
6.1.5 Cancel All
6.2 Call Barring
6.2.1 All Outgoing
6.2.2 International
6.2.3 International Except to Home
6.2.4 All Incoming
6.2.5 Incoming While Abroad
6.2.6 Cancel All
6.2.7 Change Barring Password
Using the Menus
61
6. Network Services
(continued)
6.3 Call Waiting
6.3.1 Voice Calls
6.3.2 Data Calls
6.3.3 Cancel All
6.4 Network Selection
6.4.1 Automatic
6.4.2 Manual
6.5 Caller ID
6.5.1 Default
6.5.2 Hide Number
6.5.3 Send Number
6.6 Closed User Group
6.6.1 Index List
6.6.2 Outside Access
6.6.3 Default Group
6.6.4 Deactivate
*
6.7 Band Selection
7. Funbox
(see page 108)
7.1 Games
7.2 WAP Browser
7.3 Downloads
7.3.1 Games & More
7.3.2 Sounds
7.3.3 Pictures
7.3.4 DNS Setting
*Shown only if the Closed User Group Feature is active.
62
Messages
The SMS (Short Message Service) function is a
network service that may not be supported by your
network. You can send messages by a text, fax,
Email and paging messaging systems, provided that
these services are supported by your network. To
send text messages by phone, you must obtain the
number of the SMS centre from your service
provider.
When the message icon ( ) appears, you have
received new text messages. If the memory is full,
an error message displays and you cannot receive
any new messages. Use the
Delete
option in each
message box to delete obsolete ones.
Inbox
(Menu 1.1)
This message box is used to store the messages
that you have received.
When you enter this menu, the list of messages in
the box displays with the senders’ phone numbers
or names, if available in your Phonebook.
1. Select a message from the list and press the
View
soft key to read the message contents.
2. To scroll through the contents, press the or
key.
3. To scroll to the previous or next messages, press
the or key.
While reading a message, you can choose the
following options by pressing the
Options
soft key.
Delete
: allows you to delete the message.
Messages
63
Send
: allows you to send a message that you have
received or saved. For more information on how to
send a message, see page 65.
Reply
: allows you to reply to the sender by
sending a text message. You can also change the
SMS centre number, if required.
Call Back
: allows you to call the sender back.
Cut Address
: allows you to extract URL or
e-mail addresses or a phone numbers from the
message text, so that you can save them in your
phone’s memory.
Edit:
allows you to change the message.
Move
: allows you to move the message to another
memory location, from the SIM card memory to the
phone memory or vice versa.
Select Objects
: allows you to save the media
items, such as sounds or images, from the message
into your phone. You can use the objects when
writing a message; for details, see page 66.
Outbox
(Menu 1.2)
This message box is used to store the messages
that you have already sent or will send.
When you enter this menu, the list of messages in
the box displays with the recipients’ phone numbers
or names, if available in your Phonebook.
1. Select a message from the list and press the
View
soft key to read the message contents.
2. To scroll through the contents, press the or
key.
Messages
64
3. To scroll to the previous or next messages, press
the or key.
While reading a message, you can choose the
following options by pressing the
Options
soft key.
Delete
: allows you to delete the message.
Send
: allows you to send a message that you have
received or saved. For more information on how to
send a message, see page 65.
Cut Address
: allows you to extract URL or
e-mail addresses or a phone numbers from the
message text, so that you can save them in your
phone’s memory.
Edit:
allows you to change the message.
Move
: allows you to move the message to another
memory location, from the SIM card memory to the
phone memory or vice versa.
Select Objects
: allows you to save the media
items, such as sounds or images, from the message
into your phone. You can use the objects when
writing a message; for details, see page 66.
Messages
65
Write New
(Menu 1.3)
In this menu, you can write and send a text
message.
Note
: You can enter up to 918 alphanumeric
characters for your message. If you add
objects to the message, the number of
characters you can enter will be decreased.
Creating a Simple Text Message
1. Create your message.
Note
: For more information about entering
characters, refer to page 44.
2. When you finish entering the message, press
the
Options
soft key. The following options are
available:
•
Send Only
: allows you to send the message.
The message is deleted after sending.
•
Save and Send
: allows you to save a copy of
the message and then send the message to
the required destination. You can read the
message in your Outbox using the
Read
Messages
option.
•
Save Only
: allows you to save the message
so that it can be sent later. You can read the
message in your Outbox using the
Read
Messages
option.
• For more information about
Text
Formatting
,
Add Objects
,
Add
Templates
,
Add Phonebook
,
Add
Bookmark
and
Language
options, see
“Creating a Message using the Options” on
page 66.
Messages
66
3. Select
Send Only
or
Save and Send
, and
press the
Select
soft key.
If you only want to save the message, select
Save Only
. After saving the message, the
phone returns to the
Messages
menu.
4. Enter a destination number and press the
OK
soft key. The message is sent.
Creating a Message using the Options
1. Create a message.
2. Press the
Options
soft key.
3. Select one of the following options as required
by using the and keys and pressing the
Select
soft key.
•
Text Formatting
: allows you to format the
style of the text. For the
Size
attribute, the
Normal
,
Large
and
Small
sizes are
available. For the
Underline
and
Strikethrough
attributes, select
On
or
Off
.
The attributes can be combined.
•
Add Objects
: allows you to add the required
sound, melody picture or animation to the
message. Select the category of the object to
be added. In each category, you can select the
various factory-set items or choose an item
received from other sources, such as the
Internet or other phones.
•
Add Templates
: allows you to apply one of
the preset message templates to the text.
Select one of the five messages predefined in
the
Templates
menu option (
Menu 1.4
); for
further details, see page 67.
Messages
67
•
Add Phonebook
: allows you to add a
Phonebook entry in your message. Select one
from the list.
•
Add Bookmark
: allows you to add a web
page’s address stored in your Favorites list
(
Menu 7.2.2
). Select one from the list.
•
Language
: allows you to change the
language to be used in T9 input mode. Select
the language to be used.
4. Complete the message, and send or save it by
following the procedure from Step 2 on page 65.
Templates
(Menu 1.4)
Using this menu, you can preset up to five
messages that you use most frequently. Scroll
through the template list using the and
keys. When the required message template
highlights, press the
Options
soft key.
Edit
: allows you to write a new message or edit the
selected message.
Note
: For further information on how to enter
characters, refer to page 44.
Send Message
: allows you to recall the selected
message. Once you have completed the message,
you can send, save and send, or simply save it. For
further details on how to send a message, see
page 65.
Delete
: allows you to delete the selected message.
You are asked to confirm the deletion by pressing
the
Yes
soft key.
Messages
68
Settings
(Menu 1.5)
In this menu, you can set up default SMS
information. A setting group is a collection of
settings required to send messages. The number of
setting groups available depends on the capacity of
your SIM card.
Setting x
(where
x
is the setting group number):
each group has its own sub-menu.
Service Centre: allows you to store or change the
number of your SMS centre, which is required when
sending messages. You must obtain this number
from your service provider.
Default Destination: allows you to store the default
destination number. The number will automatically
display on the Destination screen when you create a
message.
Default Type: allows you to set the default message
type-Text, Fax, Email and Paging. The network can
convert the messages into the selected format.
Default Validity: allows you to set the length of time
for which your text messages are stored at the
message centre while attempts are made to deliver
them.
Setting Name: allows you to give a name to the
setting group currently being defined.
Common Setting
: The following options are
available:
Reply Path: allows the recipient of your SMS
message to send you a reply message via your
message centre, if your network supports with this
service.
Messages
69
Delivery Reports: allows you to activate or
deactivate the report function. When this function is
activated, the network informs you whether your
message has been delivered or not.
Bearer Selection: allows you to choose between
GSM
and
GPRS
.
My Objects
(Menu 1.6)
After saving any objects received in messages into
your phone memory, using the
Select Objects
option (see page 63), you can see the objects in
this menu.
Three categories of objects are available:
• My EMS Melody
• My EMS Picture
• My EMS Animation
To delete the objects in this menu, press the
Delete
soft key.
You can forward the objects to other people by
including message and/or use them for your ring
tone or background them in a image.
You can delete all of the items using the
Delete All
option (
Menu 1.6.4
).
Messages
70
Memory Status
(Menu 1.7)
This menu shows how many messages are currently
stored in the SIM, phone and CB memories.
You can delete all of the messages in each message
box using the
Delete all
option (
Menu 1.7.4
).
Select the message box,
Inbox
,
Outbox
or
CB
Message
, To delete all of your messages at one
time by selecting
All Messages
.
When a confirming message displays, press the
Yes
soft key to confirm.
Voice Mail
(Menu 1.8)
This menu provides you with a way of accessing
your voice mailbox, if your network supports this
service.
The following options are available:
Connect to Voice Server
: before using this
feature, you must enter the voice server number
obtained from your service provider (see menu
option
1.8.2
). You can then select this option and
simply press the
OK
soft key to listen to your
messages.
To quickly connect to the voice server, press and
hold down the key in idle mode.
Voice Server Number
: allows you to change the
voice mail server number, if necessary.
To... Press the...
enter the server
number
corresponding numeric
keys.
correct a digit key.
Messages
71
Note
: Voice Mail is a network feature. Please contact
your service provider for more information.
Broadcast
(Menu 1.9)
This network service allows you to receive text
messages on various topics, such as the weather or
traffic. Messages display immediately they are
received, provided that:
• the phone is in idle mode
• the
Receive
option is set to
Enable
• the message channel is currently active in the
channel list
The following options are available:
Read
: lets you view the received message.
Volatile
displays the messages from the network,
but loses its contents as soon as the phone is
switched off. Scroll through the message by using
the and keys. While reading a message,
press the
Save
soft key to store the message in the
Archive
box for later retrieval.
Receive
: allows you to enable or disable the
reception of broadcast messages.
move the cursor
to the left/right
without clearing
the digit
or key.
To... Press the...
Messages
72
Channel List
: allows you to indicate the channels
from which you wish to receive broadcast
messages. The following options are available.
Select: use to enable or disable channels in the list
by marking or unmarking them respectively. A
check mark displays in front of each selected
channel.
Add Channel: use to enter the ID and title for a new
channel.
Delete: use to remove a channel from the list.
Edit: use to change the ID and title of an existing
channel.
Language
: allows you to select your preferred
language to display cell broadcast messages.
Please contact your service provider for more
information.
73
Call Records
In this menu, you can view the following phone
calls that are:
•missed
• received
• dialled
Note
: You can access all numbers in the three types
of call records by pressing the
key in idle
mode.
Missed Calls
(Menu 2.1)
This option lets you view the last 20 numbers of the
calls you received, but did not answer.
The number and name, if available, display
together with the date and time at which the call
was received. By pressing the
Options
soft key,
you can:
•edit the number, if available, and dial it or save it
in the Phonebook
• delete the call from the list
Received Calls
(Menu 2.2)
This option lets you view the last 20 numbers at the
calls received.
The number and name, if available, display
together with the date and time at which the call
was received. By pressing the
Options
soft key,
you can:
•edit the number, if available, and dial it or save it
in the Phonebook
• delete the call from the list
Call Records
74
Dialled Calls
(Menu 2.3)
This option lets you view the last 20 numbers you
dialled.
The number and name, if available, display
together with the date and time at which the call
was made. By pressing the
Options
soft key, you
can:
• delete the number
• edit the number and save it in the Phonebook
Call Time
(Menu 2.4)
This option lets you view the timers for calls made
and received.
The following timers are available:
Last Call Time
: length of the last call.
Total Sent
: total length of all calls made since the
timer was last reset.
Total Received
: total length of all calls received
since the timer was last reset.
Reset Timers
: option used to reset the call
timers; you must first enter the phone password
(see page 114) and then press the
OK
soft key.
Note
:
The actual time invoiced for calls by your
service provider may vary, depending on
network features, rounding-off for billing
purposes and so forth.
Call Records
75
Call Cost
*
(Menu 2.5)
This network feature lets you view the cost of calls.
The following options are available:
Last Call Cost
: cost of the last call made.
Total Cost
: total cost of all calls made since the
cost counter was last reset. If the total cost exceeds
the maximum cost set in the
Set Max Cost
option,
you can no longer make any calls until you reset the
counter.
Max Cost
: maximum cost set in the
Set Max
Cost
option (see below).
Reset Counters
: option used to reset the cost
counter; you must first enter your PIN2 (see
page 116) and then press the
OK
soft key.
Set Max Cost
: option used to enter the maximum
cost that you authorise for your calls.
Price/Unit
: option used to set the cost of one
unit; this price per unit is applied when calculating
the cost of your calls.
* Shown only if supported by your SIM card.
76
Sound Settings
You can use the Sound Settings feature to
customise various settings, such as the:
• ring melody, volume and type
• sounds made when you press a key, make an
error or receive a message
Note
: When the phone is in silent mode (see
page 30), you cannot change the sound
settings.
Ring Tone
(Menu 3.1)
This option allows you to select the required ring
melody.
You can choose between many different melodies.
Each time you select a melody, it displays for a few
seconds. If you have downloaded any sounds from
the Internet or EasyGPRS programme or received
any ring tone messages, you can view the list in
this menu.
Ring Volume
(Menu 3.2)
This option allows you to adjust the ring volume to
one of five levels.
Use the and keys or the and keys on the
left side of the phone.
Sound Settings
77
Alert Type
(Menu 3.3)
This option allows you to specify how you are to be
informed of any incoming calls.
The following options are available:
Light only
: only the backlight is switched on; the
phone neither rings nor vibrates.
Melody
: the phone rings using the ring melody
selected in the
Ring Tone
menu option
(
Menu 3.1
); see page 76.
Vibration
: the phone vibrates but does not ring.
Vibra+Melody
: the phone first vibrates three
times and then starts ringing.
Keypad Tone
(Menu 3.4)
This option allows you to select the tone that the
keypad generates when you press a key.
The following options are available:
OFF
: the keys do not make any sound.
Tone
: each key, when pressed, makes a different
sound.
Beep
: each key, when pressed, makes the same
sound.
Sound Settings
78
Message Tone
(Menu 3.5)
This option allows you to select how the phone
informs you that a new message has been received.
SMS Tone
This option allows you to select how the phone
informs you that a new SMS message has been
received.
The following options are available:
OFF
: the phone does not use the SMS tone.
Light Only
: the service light above the external
display flashes.
Vibration
: the phone vibrates.
Single Beep
: the phone beeps once.
SMS Tone x
: the phone uses an SMS tone. You
are provided with several SMS tones.
SMS CB Tone
This option allows you to select how the phone
informs you that a new cell broadcast (CB) message
has been received.
The following options are available:
OFF
: the phone does not use the CB tone.
Light Only
: the service light above the external
display flashes.
Vibration
: the phone vibrates.
Single Beep
: the phone beeps once.
SMS CB Tone x
: the phone uses a CB tone. You
are provided with several CB tones.
Sound Settings
79
Extra Tones
(Menu 3.6)
You can customise various other tones used by the
phone.
The following options are available:
Error Tone
: sets whether the phone informs you
that you make a mistake or not.
Minute Minder
: sets whether the phone must
beep every minute during an outgoing call to keep
you informed of the length of your call.
Connect Tone
: sets your phone to beep when the
person you are calling answers the phone.
To turn a given
tone...
Press the...
on
ON
soft key.
A check mark is displayed in
front of the option.
off
OFF
soft key again.
The check mark is no longer
displayed.
80
Phone Settings
Many different features of your phone can be
customised to suit your preferences. All of these
features are accessed in the Phone Settings
menu.
Infrared Activate
(Menu 4.1)
This feature allows you to send or receive data/fax
through the infrared port. To use an infrared
connection, you must:
•configure and activate an IrDA-compliant infrared
port on your PC
• activate the infrared feature on the phone; the
IrDA icon ( ) appears on the top line of the
display
• align the IrDA port on the phone with the IrDA
port on your computer
The connection is ready for data transmission.
If there is no communication between your phone
and the IrDA-compliant device within 30 seconds of
activating the feature, it is automatically
deactivated.
Note
: For the best performance, use the data link
cable supplied in your SGH-E400 kit.
15
IrDA port
IrDA port
Phone Settings
81
My Settings
(Menu 4.2)
You can change the background image and the
colour of the components on the display according
to your preference.
Wallpaper
This option allows you to change the background
image to be displayed in idle mode.
To change the background image:
1. Scroll through the list by pressing the or
key.
You have various preset images available. You
can also select the blank background and any
images downloaded from the Internet or the
EasyGPRS programme.
2. Press the
Select
soft key when the required
image highlights.
The selected image displays.
3. After viewing the image, press the
Select
soft
key to display it on the idle screen.
Colour Theme
You can change the colour setting of the display
components, such as text, soft key display area or
the menu names and icons. Five different colour
settings are available.
Select the required setting and press the
Select
soft key, followed by
OK
to confirm the highlight
colour and colour theme.
Phone Settings
82
Menu Style
This option allows you to select the menu display
style. You can choose between
Folder Style
and
Page Style
.
Greeting Message
(Menu 4.3)
This option allows you to set a greeting to be
displayed briefly when the phone is switched on.
When you select this menu option, the current
message displays.
For further details on how to enter characters, refer
to page 44.
Own Number
(Menu 4.4)
This feature allows you to:
• assign a name to each of your own phone
numbers registered on your SIM card
• edit the names and numbers
This function is a memory aid, which you can use to
check your own phone numbers if you need to do so.
Any changes made here do not in any way affect
the actual subscriber numbers on your SIM card.
To... Press the...
clear the existing
message
key and hold it down
until the message is cleared.
enter a new
message
appropriate alphanumeric
keys.
change the text
input mode
soft key.
Phone Settings
83
Language
(Menu 4.5)
You can select a display language. When the
language option is set to
Automatic
, the language
is automatically selected according to the language
of the SIM card used.
Security
(Menu 4.6)
The Security feature enables you to restrict the use
of your phone to:
• the people of your choice
• the types of calls of your choice
Various codes and passwords are used to protect
the features of your phone. They are described in
the following sections (see also pages 114-117).
PIN Check
When the PIN Check feature is enabled, you must
enter your PIN each time you switch the phone on.
Consequently, any person who does not have your
PIN cannot use your phone without your approval.
Note
: Before disabling the PIN Check feature, you
must enter your PIN.
To change your PIN, refer to the
Change PIN
menu option (
Menu 4.6.2
).
The following options are available:
Disable
: the phone connects directly to the
network when you switch it on.
Enable
: you must enter the PIN each time the
phone is switched on.
Phone Settings
84
Change PIN
This feature allows you to change your current PIN
to a new one, provided that the PIN Check feature
is enabled. You must enter the current PIN before
you can specify a new one.
Once you have entered a new PIN, you are asked to
confirm it by entering it again.
Phone Lock
When the Phone Lock feature is enabled, the phone
is locked and you must enter the 8-digit phone
password each time the phone is switched on.
The password is preset to “00000000” at the
factory. To change the phone password, refer to the
Change Password
menu option (
Menu 4.6.4
)
below.
Once the correct password has been entered, you
can use the phone until you switch it off.
The following options are available:
Disable
: you are not asked to enter the phone
password when you switch the phone on.
Enable
: you are required to enter the phone
password when you switch the phone on.
Change Password
The Change Password feature allows you to change
your current phone password to a new one. You
must enter the current password before you can
specify a new one.
The password is preset to “00000000” at the
factory. Once you have entered a new password,
you are asked to confirm it by entering it again.
Phone Settings
85
SIM Lock
When the SIM Lock feature is enabled, your phone
only works with the current SIM. You must enter
the SIM lock code.
Once you have entered the lock code, you are
asked to confirm it by entering it again.
To unlock the SIM, you must enter the SIM lock
code.
FDN Mode
The FDN (Fixed Dial Number) mode, if supported by
your SIM card, allows you to restrict your outgoing
calls to a limited set of phone numbers.
The following options are available:
Disable
: you can call any number.
Enable
: you can only call phone numbers stored in
the Phonebook. You must enter your PIN2.
Note
: Not all SIM cards have a PIN2. If your SIM card
does not, this menu option is not displayed.
To change your PIN2, refer to the
Change PIN2
menu option (
Menu 4.6.7
) below.
Change PIN2
The Change PIN2 feature allows you to change your
current PIN2 to a new one. You must enter the
current PIN2 before you can specify a new one.
Once you have entered a new PIN2, you are asked
to confirm it by entering it again.
Note
: Not all SIM cards have a PIN2. If your SIM card
does not, this menu option is not displayed.
Phone Settings
86
Display Settings
(Menu 4.7)
Contrast
This option allows you to adjust the brightness of
the display screens to make them lighter or darker.
To adjust the display contrast:
1. Select the LCD to be adjusted,
Main LCD
or
Front LCD
, and press the
Select
soft key.
2. Adjust the contrast by using the and
keys or the and keys on the left side of the
phone.
3. When you are satisfied, press the
OK
soft key to
save the selection.
Back Light
You can select whether or not the phone uses the
backlight. A marginal increase in standby/talk time
can be achieved by turning the backlight off.
Select the length of time for which the backlight is
on. The backlight comes on when you press a key
or receive a call or message and lights up for the
specified length of time. Then it dims and finally
switches off after one minute.
If you do not want to use the backlight, select
OFF
.
Phone Settings
87
Auto Light
Using this feature, you can specify the time for
which the backlight is to be used. This feature helps
conserve your battery power.
The following options are available:
Disable
: the backlight is used according to the
setting in the
Back Light
menu option
(
Menu 4.7.2
); see page 86.
Enable
: the backlight is used only during the
specified period of time. Set the time when the
phone will turn on the light and turn it off, using the
appropriate number keys.
Service Light
This option allows you to select whether or not the
service light is used or in which colour it flashes.
Select the required colour from red, green, blue,
yellow, cyan, violet and white. When the phone is
ready for use, the service light will flash in the
appropriate colour.
If you do not wish to use the service light,
select
Off
.
Graphic Logo
This option allows you to display your operator’s
logo instead of its name.
On
: the operator logo stored in your phone is
displayed in idle mode; if no logo has been stored,
the operator name is displayed.
Off
: the operator name is displayed in idle mode.
Phone Settings
88
Extra Settings
(Menu 4.8)
You can turn the automatic redialling or answering
features on or off.
The following options are available:
Auto Redial
: when this option is checked, the
phone makes up to ten attempts to redial a phone
number after an unsuccessful call.
Note
: The interval between two call attempts varies.
Active Folder
: when this option is checked, you
can simply open the folder to answer a call.
When it is unchecked, you must open the folder and
press a key, depending on the setting of the
Anykey Answer
option (see below).
Anykey Answer
: when this option is checked,
you can answer an incoming call by pressing any
key, except the key and the
Reject
soft key.
To reject the call, press the key or the
Reject
soft key.
When this option is unchecked, you can only press
the key or
Accept
soft key.
To turn a
feature...
Press the...
on
ON
soft key.
A check mark is displayed in
front of the option.
off
OFF
soft key.
The check mark is no longer
displayed.
Phone Settings
89
Short Cut
(Menu 4.9)
The navigation keys can be used as shortcut keys.
When held down in idle mode, they allow you to
access specific menu options directly.
To assign a shortcut to a key:
1. Select the key to be used as a shortcut key by
pressing the or key, followed by the
Select
soft key.
•
Key up
()
•
Key down
()
•
Key right
()
•
Key left
()
2. Select the menu option to be assigned to the
key by pressing the or key.
Note
: To deactivate a shortcut key, select the
None
option.
3. Press the
Select
soft key to save the selection.
Reset Settings
(Menu 4.10)
You can easily reset your phone to its default
settings. To reset your phone:
1. Select the
Reset Settings
menu option.
2. Enter the 8-digit phone password and press the
OK
soft key.
Note
: The password is preset to “00000000” at the
factory. To change this password, refer to
page 84.
90
Organiser
The Organiser feature enables you to:
• view the calendar and organise your schedule.
• define a list of things to do.
• set the current date and time.
•set an alarm so that the phone rings at a specific
time to remind you of an appointment, for
example.
• use the phone as a calculator for basic
mathematical equations or currency exchange
operations.
Calendar
(Menu 5.1)
With the Calendar feature, you can:
• consult the calendar
•write memos to keep track of your schedule and
trigger an alarm if necessary
Consulting the Calendar
When you select the
Calendar
menu option
(
Menu
5.1
), the calendar displays. The following
options are available when you press the
Options
soft key.
Search all
: displays all of the memos, regardless
of the day and starting with the oldest. To scroll
through the memos, press the or key.
Delete all
: allows you to delete all of the memos.
You are asked to confirm your action.
Go to date
: allows you to go to a specific date.
Exit
: exits the Calendar feature and returns to idle
mode.
Organiser
91
Writing a Memo
To write or edit a memo on a specific date:
1. Select the required date in the calendar, using
the navigation keys.
Note
: To skip to the previous or next month,
press
the and keys
on the left side of
the phone.
2. Press the
Select
soft key.
An empty memo screen displays to allow you to
enter your memo.
3. Enter your memo and then press the
OK
soft
key.
Note
: For further details on how to enter
characters, refer to page 44.
You are asked if you wish to set an alarm.
4. If you want an alarm to ring on the chosen day,
press the
Yes
soft key.
Otherwise, press the
No
soft key.
5. If you pressed the
Yes
soft key, set the time for
the alarm and press the
OK
soft key.
The colour of the date is changed to green to
indicate that a memo exists.
Editing a Memo
If you select a day for which a memo already exists,
you can press the
Edit
soft key to edit the memo
displayed.
Note
: For further details about how to enter
characters, refer to page 44.
Organiser
92
Once you have finished editing the memo, press the
OK
soft key. The following options are available
when you press the
Options
soft key:
Alarm
: allows you to set an alarm to ring on the
chosen day.
Erase
: allows you to delete the memo.
Copy to
: allows you to copy the memo to another
date and/or time.
Move to
: allows you to change the date and/or
time of the memo.
To Do List
(Menu 5.2)
This feature allows you to:
• enter a list of tasks to be done.
• assign a priority and a deadline to each task.
• sort the tasks by priority and status mark.
Creating the To Do List
1. Press the
New
soft key.
2. Enter the first task.
Note
: You can enter up to 40 characters. For
further details on how to enter characters,
see page 44.
3. Press the
OK
soft key.
4. Select high, normal or low priority using the
or key and press the
Select
soft key.
Organiser
93
5. Enter your deadline.
If you do not want to set a deadline, press the
Skip
soft key.
6. Press the
OK
soft key.
Editing the To Do List
If tasks are already defined in the To Do List when
you select the
To Do List
menu option
(
Menu
5.2
), the current contents are displayed
with the status mark and priority; three stars for
high, two for normal and one for low.
The following options are available:
To... Then...
view the details
for a specific task
• highlight the task.
• press the
View
soft key.
change the status
of a specific task
• highlight the task.
• press the key to mark
the task as completed as of
the current date and time.
or
• highlight the task.
• press the
Options
soft key.
• select the
Mark
option.
• select the appropriate status
(
Done
or
Undo
).
create a new task • press the
Options
soft key.
• select the
New
option.
• enter the text, priority and
deadline for the task.
Organiser
94
edit an existing
task
• highlight the task.
• press the
Options
soft key.
• select the
Edit
option.
• change the text, priority and
deadline for the task.
sort the existing
tasks by priority
or status
• press the
Options
soft key.
• select the
Sort
option.
• select the sort criterion
(
High
,
Low
,
Done
or
Undo
).
copy a task • highlight the task.
• press the
Options
soft key.
• select the
Copy
option.
• change the text, priority and
deadline for the task as
required.
copy a task to the
calendar
• highlight the task.
• press the
Options
soft key.
• select the
Copy to
calendar
option.
• change the text and deadline
for the task and set the
alarm as required.
delete a task • highlight the task.
• press the
Options
soft key.
• select the
Delete
option.
delete all tasks • press the
Options
soft key.
• select the
Delete all
option.
• confirm the deletion by
pressing
OK
.
exit the To Do list • press the
Options
soft key.
• select the
Exit
option.
To... Then...
Organiser
95
Time & Date
(Menu 5.3)
This option allows you to change the current time
and date displayed. You can also use this option to
find out what time it is and another part of the
world.
The following options are available:
Set Time
: allows you to enter the current time.
You can choose the time format in the
Time
Format
menu option (
Menu 5.3.4
).
Note
: Before setting the time, you must specify your
time zone, in the
World Time
menu option
(
Menu 5.3.3
).
Set Date
: allows you to enter the day, month and
year.
World Time
: allows you to find out what time it is
and another part of the world, using the and
keys.
The screen shows the:
• city name
• current date and time
• time difference between the selected city and
your city if you have set the local time (see below
for further details) or GMT (by default)
To select your time zone:
1. Select the city corresponding to your time zone
by pressing the or key one or more times.
The local date and time are displayed.
2. Press the
Set
soft key.
Time Format
: allows you to change the time
format to
24 Hours
or
12 Hours
.
Organiser
96
Alarm
(Menu 5.4)
This feature allows you to:
• set the alarm to ring at a specific time
•set the phone to switch on automatically and ring
the alarm even if the phone is switched off
(
Autopower
menu option set to
Enable
)
The following options are available:
Once Alarm
: the alarm rings only once and is
then deactivated.
Daily Alarm
: the alarm rings every day at the
same time.
Morning Call
: the alarm rings to wake you up in
the morning.
To set an alarm:
1. Choose the type of alarm to be set.
2. Enter the required time and day of the week, if
applicable.
3. Press the
OK
soft key.
4. If you select
Morning Call
in Step 1, select the
repeat option:
Monday to Friday
or
Monday
to Saturday
.
Remove Alarm
: deactivates all alarm settings.
Autopower
: if this option is set to
Enable
, the
alarm will ring at the specified time, even when the
phone is switched off.
If the menu option is set to
Disable
and the phone
is switched off at the specified time, the alarm does
not ring.
Organiser
97
To stop the alarm when it rings, open the phone
and press the
Exit
soft key.
When setting or viewing an alarm, the following
options are available when you press the
Options
soft key:
Remove Alarm
: deactivates the current alarm.
Alarm Sound Set
: allows you to select the alarm
melody.
Calculator
(Menu 5.5)
With this feature, you can use the phone as a
calculator. The calculator provides the basic
arithmetic functions; addition, subtraction,
multiplication and division.
Using the Calculator
1. Enter the first number using the numeric keys.
2. Press the right soft key until the required
arithmetic symbol appears:
+
(addition),
-
(subtraction), (multiplication),
/
(division).
3. Enter the second number.
4. Repeat steps 1 to 3 as many times as required.
Notes
:
• To erase any mistakes or clear the display, press the
key.
• To include a decimal point or a bracket, press the left
soft key until the required symbol is displayed.
Organiser
98
5. To calculate the result, press the key.
Currency Exchange
(Menu 5.6)
Using this menu option, you can make currency
conversions.
1. Enter the current exchange rate of your source
currency and press the
OK
soft key.
You can insert a decimal point by pressing
the key
.
2. Enter the amount for which you wish to conduct
the currency conversion and press the
OK
soft
key.
The exchange rate amount you entered and
equivalent value display.
3. Press the
Exit
soft key to exit the currency
convertor.
99
Network Services
These menu functions are network services. Please
contact your service provider to check their
availability and subscribe to them, if you wish.
Call Diverting
(Menu 6.1)
This network service enables incoming calls to be
rerouted to the number that you specify.
Example:You may wish to divert your business calls
to a colleague while you are on holiday.
Call diverting can be set up in the following ways:
Divert Always
: all calls are diverted.
Busy
: calls are diverted if you are already on
another call.
No Reply
: calls are diverted if you do not answer
the phone.
Unreachable
: calls are diverted if you are not in
an area covered by your service provider.
Cancel All
: all call diverting options are cancelled.
You can specify individual diverting options for each
of the following call types:
•Voice calls only
• Data calls only
Example:You can divert voice calls to your
colleague if you are already using the
phone.
Network Services
100
To set your call diverting options:
1. Select the type of call diverting required by
pressing the or key until the appropriate
option highlights, and then press the
Select
soft key.
2. Select the type of calls to be diverted by
pressing the or key until the appropriate
option highlights and then press the
Select
soft
key.
The current status displays. If the option has
already been set, the number to which the calls
are diverted displays.
4. Enter the number to which the calls are to be
diverted and press
OK
.
To enter an international code, press the
key until the
+
sign displays.
The phone sends your settings to the network
and the network’s acknowledgement displays.
You can deactivate all call diverting settings by
selecting the
Cancel All
option.
3. To... Press the...
activate call
diverting
Activate
soft key.
Go to Step 4.
change the
call number
Change
soft key.
Go to Step 4.
deactivate call
diverting
Remove
soft key.
Network Services
101
Call Barring
(Menu 6.2)
The call barring network service allows you to
restrict your calls.
Call barring can be set up in the following ways:
All Outgoing
: calls cannot be made.
International
: international calls cannot be
made.
International Except to Home
: when abroad,
calls can be made only to numbers within the
current country and to your home country, which is
the country where your home network provider is
located.
All Incoming
: calls cannot be received.
Incoming While Abroad
: calls cannot be
received when you are using your phone outside of
your home service area.
Cancel All
: all call barring settings are
deactivated; calls can be made and received
normally.
You can specify individual barring options for each
of the following call types:
•Voice calls only
• Data calls only
To set your call barring options:
1. Select the type of call barring required by
pressing the or key until the appropriate
option highlights and then press the
Select
soft
key.
2. Select the type of calls to be barred by pressing
the or key until the appropriate option
highlights and then press the
Select
soft key.
Network Services
102
3. Press the
Activate
soft key to confirm your
settings.
4. Enter your call barring password supplied by
your service provider.
The phone sends your settings to the network
and the network’s acknowledgement displays.
To deactivate specific call barring settings:
1. Select the call barring option to be deactivated.
2. Select the type of call to which this option
applies.
3. Press the
Deactivate
soft key.
4. Enter your call barring password supplied by
your service provider.
The phone sends your settings to the network
and the network’s acknowledgement displays
You can also deactivate all call barring settings by
selecting the
Cancel All
option.
Change Barring Password
: you can set and
change the call barring password obtained from
your service provider using this option. You must
enter the current password before you can specify a
new one.
Once you have entered a new password, you are
asked to confirm it by entering it again.
Network Services
103
Call Waiting
(Menu 6.3)
This network service enables you to be informed
when someone is trying to reach you during
another call.
You can specify individual call waiting options for
each of the following call types:
•Voice calls only
• Data calls only
To set your call waiting options:
1. Select the type of calls to which the call waiting
option is to be applied by pressing the or
key until the appropriate option highlights and
then press the
Select
soft key.
The screen informs you whether call waiting is
activated or deactivated.
2. You can activate or deactivate the call waiting
feature as necessary by using the
Activate
or
Deactivate
soft key respectively.
To return to the previous screen, press the
Exit
soft key.
You can also deactivate all call waiting settings by
selecting the
Cancel All
option.
Network Services
104
Network Selection
(Menu 6.4)
The Network Selection feature enables you to
automatically or manually select the network used
when roaming outside of your home area.
Note
: You can select a network other than your home
network only if it has a valid roaming agree-
ment with your home network.
To indicate automatically or manually select the
network when roaming:
1. When
Network Selection
displays, press the
Select
soft key.
2. Press the or key until the appropriate
option highlights and then press the
OK
soft
key.
If you select
Automatic
, you are connected to
the first available network when roaming.
If you select
Manual
, the phone scans for the
available networks. Go to Step 3.
3. Press the or key until the preferred
network highlights and then press the
OK
soft
key.
You are connected to that network.
Network Services
105
Caller ID
(Menu 6.5)
You can prevent your phone number from being
displayed on the phone of the person being called.
Note
: Some networks do not allow the user to change
this setting.
The following options are available:
Default
: the default setting provided by the
network is used.
Hide Number
: your number is not displayed on
the other person’s phone.
Send Number
: your number is sent each time you
make a call.
Closed User Group (CUG)
(Menu 6.6)
This network service allows incoming and outgoing
calls to be restricted to a selected user group. You
may be a member of up to ten user groups.
For details on how to create, activate and use a
closed user group, contact your service provider.
Example: A company lends SIM cards to its
employees and wants to restrict outgoing
calls to members of the same team.
Activating a Closed User Group
If you select the
Closed User Group
menu, you
can enter the CUG function. You can now access the
following options after pressing the
Select
soft key.
Index List
: lets you list, add or delete CUG index
numbers. The list of current CUG indexes appears.
Network Services
106
Add a new CUG index as advised by your service
provider or delete a selected group.
Outside Access
: lets you enable or disable calls
to numbers other than those nominated for the
Closed User Group. This feature depends on the
nature of your CUG subscription. Please check with
your service provider.
Default Group
: you may set a default CUG with
your service provider. If you have done so, you can
enable the
Default Group
option on your phone.
When making a call, you are given the option of
using your default CUG, instead of selecting one
from the list.
Deactivate
: deactivates the CUG function. This
menu appears only when the default group is
enabled or a CUG index is selected.
To... Press the...
scroll the through
the existing CUG
indexes
or key.
add a new CUG
index
Options
soft key, select the
Add
option and enter the
index.
delete a CUG
index
Options
soft key and select
the
Delete
option.
activate a CUG
index
Options
soft key and select
the
Activate
option.
Network Services
107
Band Selection
(Menu 6.7)
For the phone to make and receive phone calls, it
must register with one of the available networks.
Your phone can handle any of the following types of
network:
•GSM 900
•GSM 1800
• Combined GSM 900/1800
•GSM 1900
The country where you purchased your phone
determines the default band that it uses. When you
travel abroad, you must remember to change to an
appropriate band.
1. When
Band Selection
displays, press the
Select
soft key.
2. Press the or key until the appropriate
option (
GSM 900/1800
or
GSM 1900
)
highlights and press the
OK
soft key.
When you select a new band, your phone displays a
confirmation message and then automatically
searches for all of the available networks. Your
phone registers with a preferred network within the
selected band.
108
Funbox
The
Funbox
menu contains several fun options.
Games
(Menu 7.1)
You can enjoy three games with your phone.
Scroll to the required game, using the and
keys and press the
Select
soft key. For further
details on the game, refer to the on-screen help.
WAP Browser
(Menu 7.2)
Your phone is equipped with a WAP Browser to
allow you to access and navigate the Wireless Web.
For further details on the
WAP Browser
menu,
refer to the WAP Browser User’s Manual supplied
with your phone.
Downloads
(Menu 7.3)
You can download MIDlets (Java applications
running on mobile phones) from various sources
using the WAP Browser and store them in your
phone. You can view the list of MIDlets stored on
the Games & More screen.
Note
: Java services may be unavailable depending
upon the service provider.
Games & More
This menu option allows you to launch a MIDlet and
access various menu options.
For more details on how to download MIDlets in the
WAP Browser, refer to the WAP Browser User’s
Manual supplied with your phone.
Funbox
109
Launching a MIDlet
To launch a MIDlet:
1. From the Downloads screen, select the
Games
& More
option.
2. Scroll to the desired MIDlet and press the
Launch
soft key.
Using the Menus
From the Main Screen, press the
Menu
soft key to
access the following options:
Info
*
: displays information about the selected
MIDlet, such as the file size, application version,
vendor, and the location of the jad file, which is the
MIDlet description file.
Remove
*
: removes the selected MIDlet. When the
confirmation message appears, press the
Remove
soft key. To cancel your selection, press the
Cancel
soft key.
Update
*
: accesses the server and updates the
selected MIDlet.
Entering Text
When entering URL addresses, the following input
modes are available:
ABC
: allows you to enter upper-case English
characters.
abc
: allows you to enter lower-case English
characters.
123
: allows you to enter numbers.
Sym
: allows you to enter symbols. After
highlighting the required symbol by pressing the
navigation keys, press the key to insert it.
* Shown only when a MIDlet has been downloaded.
Funbox
110
To change the text input mode, press the key
until the appropriate indicator appears on the soft
key area of the display.
Sounds
In this menu, you can view the list of sounds
downloaded from the server. You can set the
downloaded sounds as the current ring tone, but
cannot send the sounds to other phones.
When the memory is full, a warning message
displays and the phone rejects additional sounds
until you erase obsolete ones.
Pictures
In this menu, you can view the list of pictures
downloaded from the server. You can set the
downloaded pictures as the current background
image, but cannot send them to other phones.
When the memory is full, a warning message
displays and the phone rejects additional pictures
until you erase obsolete ones.
DNS Setting
The DNS (Domain Name Server) address of the Java
server is preset at the factory, but sometimes you
may need to change it. In this menu, you can
determine whether the address is automatically
updated or not.
Automatic
: the server will automatically transmit
the address to your phone if it is changed.
Manual
: you can manually change the address.
111
Solving Problems
Before contacting the after-sales service, perform
the following simple checks. They may save you the
time and expense of an unnecessary service call.
When you switch your phone on, the
following messages may appear
Insert SIM Card
• Check that the SIM card is correctly installed.
Phone Locked Enter Password
•The automatic locking function has been enabled.
You must enter the phone’s password before you
can use the phone.
Enter PIN
•You are using your phone for the first time. You
must enter the Personal Identification Number
supplied with the SIM card.
•The PIN Check feature is enabled. Every time the
phone is switched on, the PIN has to be entered.
To disable this feature, use the
PIN Check
menu
option (
Menu 6.6.1
).
Enter PUK
•The PIN code was entered wrongly three times in
succession and the phone is now blocked. Enter
the PUK supplied by your network operator.
Solving Problems
112
“No service,” “Network failure” or “Not
done” is displayed
•The network connection was lost. You may be in a
weak signal area (in a tunnel or surrounded by
buildings). Move and try again.
•You are trying to access an option for which you
have not taken out a subscription with your
service provider. Contact the service provider for
further details.
You have entered a number but it was
not dialled
•Have you pressed the key?
• Are you accessing the right cellular network?
•You may have set an outgoing call barring option.
Your correspondent cannot reach you
•Is your phone switched on (the key pressed
for more than one second)?
• Are you accessing the right cellular network?
•You may have set an incoming call barring option.
Your correspondent cannot hear you
speaking
•Have you switched off the microphone?
• Are you holding the phone close enough to your
mouth? The microphone is located at the bottom
of the phone.
Solving Problems
113
The phone starts beeping and
“**Warning** Low Battery” flashes on
the display
• The battery is insufficiently charged. Replace the
battery and recharge it.
The audio quality of the call is poor
•Check the signal strength indicator on the display
( ); the number of bars indicates the signal
strength from strong ( ) to weak ( ).
•Try moving the phone slightly or moving closer to
a window if you are in a building.
No number is dialled when you recall a
Phonebook entry
•Check that the number has been stored correctly,
by using the Phonebook Search feature.
•Re-store the number, if necessary.
If the above guidelines do not help you to solve
the problem, take a note of:
• The model and serial numbers of your phone
• Your warranty details
• A clear description of the problem
Then contact your local dealer or Samsung after-
sales service.
114
Access Codes
There are several access codes that are used by
your phone and its SIM card. These codes help you
protect the phone against unauthorised use.
When requested for any of the codes explained
below, key in the appropriate code (displayed as
asterisks) and press the
OK
soft key. If you make a
mistake, press the key one or more times until
the incorrect digit is cleared and then continue
entering the correct code.
The access codes, except for the PUK and PUK2
codes can be changed using
Security
menu
options (
Menu 4.6
). See page 83 for further
details.
Important!
Avoid using access codes resembling
emergency numbers, such as 112, so
that you do not dial an emergency
number accidentally.
Phone Password
The Phone Lock feature uses the phone password to
protect your phone against unauthorised use. The
phone password is supplied with the phone and is
preset to 00000000 at the factory.
To... Refer to...
activate/deactivate the
Phone Lock feature
Page 84
(
Menu 4.6.3
).
change the phone
password
Page 84
(
Menu 4.6.4
).
Access Codes
115
PIN
The
P
ersonal
I
dentification
N
umber or PIN (4 to
8 digits) protects your SIM card against unauthorised
use. It is usually supplied with the SIM card.
If you enter an incorrect PIN three times in
succession, the code is disabled and cannot be used
until you re-enable it by entering the PUK (see
below).
PUK
The 8-digit PUK (
P
IN
U
nblocking
K
ey) is required to
change a disabled PIN. The PUK may be supplied
with the SIM card. If not, or you have lost it,
contact your service provider.
To re-enable your PIN:
1. Key in the PUK and press the
OK
soft key.
2. Enter a new PIN of your choice and press the
OK
soft key.
3. When the
Confirm New PIN
message
displays, key in the same code again and press
the
OK
soft key.
If you enter an incorrect PUK ten times in
succession, the SIM card becomes invalid. Contact
your service provider for a new card.
To... Refer to...
activate/deactivate the
PIN Check feature
Page 83
(
Menu 4.6.1
).
change the PIN Page 84
(
Menu 4.6.2
).
Access Codes
116
PIN2
The PIN2 (4 to 8 digits), supplied with some SIM
cards, is required to access specific functions, such
as setting the maximum cost of a call. These
functions are available if supported by your SIM
card.
If you enter an incorrect PIN2 three times in
succession, the code is disabled and you cannot
access the functions until you re-enable it by
entering the PUK2.
To change the PIN2, refer to page 85
(
Menu 4.6.7
).
PUK2
The 8-digit PUK2 (
P
IN
U
nblocking
K
ey
2
), supplied
with some SIM cards, is required to change a
disabled PIN2. If you lose the code, contact your
service provider.
To re-enable your PIN2:
1. Key in the PUK2 and press the
OK
soft key.
2. Enter a new PIN2 of your choice and press the
OK
soft key.
3. When the
Confirm PIN2
message displays,
key in the same code again and press the
OK
soft key.
If you enter an incorrect PUK2 ten times in
succession, you will not be able to access the
functions requiring the PIN2. Contact your service
provider for a new card.
Access Codes
117
Barring Password
The 4-digit barring password is required when you
use the Call Barring function. You obtain the
password from your service provider when you
subscribe to this function. See page 102 for further
details.
118
Health and Safety
Information
Exposure to Radio Frequency (RF)
Signals
Your wireless phone is a radio transmitter and
receiver. It is designed and manufactured not to
exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal
Communications Commission (FCC) of the U.S.
Government. These limits are part of
comprehensive guidelines and establish permitted
levels of RF energy for the general population. The
guidelines are based on the safety standards
previously set by both U.S. and international
standards bodies:
•American National Standards Institute (ANSI)
IEEE. C95.1-1992
•National Council on Radiation Protection and
Measurement (NCRP). Report 86. 1986
• International Commission on Non-Ionizing
Radiation Protection (ICNIRP) 1996
•Ministry of Health (Canada), Safety Code 6.
The standards include a substantial safety margin
designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless phones employs
a unit of measurement known as Specific
Absorption Rate (SAR). The SAR limit
recommended by the FCC is 1.6W/kg .
*
* In the U.S. and Canada, the SAR limit for mobile phones
used by the public is 1.6 watts/kg (W/kg) averaged over one
gram of tissue. The standard incorporates a substantial
margin of safety to give additional protection for the public
and to account for any variations in measurements.
Health and Safety Information
119
SAR tests are conducted using standard operating
positions specified by the FCC with the phone
transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is
determined at the highest certified power level, the
actual SAR level of the phone while operating can
be well below the maximum value. This is because
the phone is designed to operate at multiple power
levels so as to use only the power required to reach
the network. In general, the closer you are to a
wireless base station antenna, the lower the power
output of the phone.
Before a phone model is available for sale to the
public, it must be tested and certified to the FCC
that it does not exceed the limit established by the
government-adopted requirement for safe
exposure. The tests are performed in positions and
locations (e.g., at the ear and worn on the body) as
required by the FCC for each model. The highest
SAR value for this model phone when tested for use
at the ear is 0.655W/Kg and when worn on the
body, as described in this user guide, is 0.315W/Kg
(Body-worn measurements differ among phone
models, depending upon available accessories and
FCC requirements). While there may be differences
between the SAR levels of various phones and at
various positions, they all meet the government
requirement for safe exposure.
The FCC has granted an Equipment Authorization
for this model phone with all reported SAR levels
evaluated as in compliance with the FCC RF
emission guidelines. SAR information on this model
phone is on file with the FCC and can be found
under the Display Grant section of http://
www.fcc.gov/oet/fccid after searching on FCC ID
A3LSGHE400.
Health and Safety Information
120
The device can be used in a body worn
configuration using accessories which are providing
a distance of at least 5 mm to the body and do not
contain metal parts.
For additional information concerning exposure to
radio frequency signals, see the following websites:
Federal Communications Commission
(FCC)
RF Safety program (select “Information on Human
Exposure to RF Fields from Cellular and PCS Radio
Transmitters”):
http://www.fcc.gov/oet/rfsafety
Cellular Telecommunications Industry
Association
(CTIA): http://www.wow-com.com
World Health Organization
(WHO)
International Commission on Non-lonizing Radiation
Protection (select Qs & As):
http://www.who.int/emf
United Kingdom, National Radiological
Protection Board:
http://www.nrpb.org.uk
U.S.Food and Drug Administration
(FDA)
Center for Devices and Radiological Health:
http://www.fda.gov/cdrh/consumer/
Health and Safety Information
121
Exposure to Radio-Frequency
Energy (SAR Information)
This phone meets European Union (EU)
requirements concerning exposure to radio waves.
Your mobile phone is a radio transmitter and
receiver. It is designed and manufactured, so as not
to exceed the limits for exposure to radio-frequency
(RF) energy, as recommended by the EU Council.
These limits are part of comprehensive guidelines
and establish permitted levels of RF energy for the
general population. The guidelines were developed
by independent scientific organisations through
periodic and thorough evaluation of scientific
studies. The limits include a substantial safety
margin designed to ensure the safety of all persons,
regardless of age and health.
The exposure standard for mobile phones employs
a unit of measurement known as SAR (Specific
Absorption Rate). The SAR limit recommended by
the EU Council is 2.0W/kg.
*
* The SAR limit for mobile phones used by the public is
2.0 watts/kilogram (W/kg) averaged over ten gram of
body tissue. The limit incorporates a substantial margin of
safety to give additional protection for the public and to
account for any variations in measurements. The SAR
values may vary depending on national reporting
requirements and the network band.
Health and Safety Information
122
SAR tests are conducted using standard operating
positions with the phone transmitting at its highest
certified power level in all tested frequency bands.
Although the SAR is determined at the highest
certified power level, the actual SAR level of the
phone while operating can be well below the
maximum value. This is because the phone is
designed to operate at multiple power levels so as
to use only the power required to reach the
network. In general, the closer you are to a base
station, the lower the power output of the phone.
The highest SAR value for this model phone when
tested for compliance against the standard was
1.36 W/kg. While there may be differences between
the SAR levels of various phones and various
positions, they all meet the EU requirements for RF
exposure.
Health and Safety Information
123
Precautions When Using Batteries
Your phone is powered by a rechargeable Li-ion
standard battery.
•Never use any charger or battery that is damaged
in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network’s base
station, it uses less power; talk and standby time
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
• Battery charging time depends on the remaining
battery charge and the type of battery and
charger used. The battery can be charged and
discharged hundreds of times, but it will
gradually wear out. When the operation time
(talk time and standby time) is noticeably shorter
than normal, it is time to buy a new battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not in use,
disconnect it from the power source. Do not leave
the battery connected to a charger for more than
a week, since overcharging may shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling or
warming first.
• Do not leave the battery in hot or cold places,
such as in a car in summer or winter conditions,
Health and Safety Information
124
as you will reduce the capacity and life-time of
the battery. Always try to keep the battery at
room temperature. A phone with a hot or cold
battery may temporarily not work, even when the
battery is fully charged. Li-ion batteries are
particularly affected by temperatures below 0 °C
(32 °F).
•Do not short-circuit the battery. Accidental short
circuiting can occur when a metallic object (coin,
clip or pen) causes a direct connection between
the + and – terminals of the battery (metal strips
on the battery), for example when you carry a
spare battery in a pocket or bag. Short-circuiting
the terminals may damage the battery or the
object causing the short-circuit.
•Dispose of used batteries in accordance with local
regulations. Always recycle. Do not dispose of
batteries in a fire.
Health and Safety Information
125
Road Safety
Your wireless phone gives you the powerful ability
to communicate by voice, almost anywhere,
anytime. But an important responsibility
accompanies the benefits of wireless phones, one
that every user must uphold.
When driving a car, driving is your first
responsibility. When using your wireless phone
behind the wheel of a car, practice good common
sense and remember the following tips.
1. Get to know your wireless phone and its
features, such as speed dial and redial. If
available, these features help you to place your
call without taking your attention off the road.
2. When available, use a hands-free device. If
possible, add an extra layer of convenience and
safety to your wireless phone with one of the
many hands-free accessories available today.
3. Position your wireless phone within easy reach.
Be able to access your wireless phone without
removing your eyes from the road. If you get an
incoming call at an inconvenient time, let your
voice mail answer it for you.
4. Let the person you are speaking with know you
are driving; if necessary, suspend the call in
heavy traffic or hazardous weather conditions.
Rain, sleet, snow, ice and even heavy traffic can
be hazardous.
5. Do not take notes or look up phone numbers
while driving. Jotting down a To Do list or
flipping through your Phonebook takes your
attention away from your primary responsibility,
driving safely.
Health and Safety Information
126
6. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan calls when your
car will be stationary. If you need to make a call
while moving, dial only a few numbers, check
the road and your mirrors, then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting. Make the
people with whom you are talking aware that
you are driving and suspend conversations that
have the potential to divert your attention from
the road.
8. Use your wireless phone to call for help. Dial the
emergency number in the case of fire, traffic
accident or medical emergencies. Remember, it
is a free call on your wireless phone!
9. Use your wireless phone to help others in
emergencies. If you see a car accident, crime in
progress or other serious emergency where
lives are in danger, call the emergency number,
as you would want others to do for you.
10. Call roadside assistance or a special non-
emergency wireless assistance number when
necessary. If you see a broken-down vehicle
posing no serious hazard, a broken traffic
signal, a minor traffic accident where no one
appears injured, or a vehicle you know to be
stolen, call roadside assistance or any other
special non-emergency wireless number.
Health and Safety Information
127
Operating Environment
Remember to follow any special regulations in force
in any area and always switch off your phone
whenever it is forbidden to use it, or when it may
cause interference or danger.
When connecting the phone or any accessory to
another device, read its user’s guide for detailed
safety instructions. Do not connect incompatible
products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation
of the equipment and for the safety of personnel, it
is recommended that the equipment should only be
used in the normal operating position (held to your
ear with the antenna pointing over your shoulder).
Electronic Devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against
the RF signals from your wireless phone. Consult
the manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be
maintained between a wireless phone and a
pacemaker to avoid potential interference with the
pacemaker. These recommendations are consistent
with the independent research and recommen-
dations of Wireless Technology Research.
Health and Safety Information
128
Persons with pacemakers:
• Should always keep the phone more than 15 cm
(6 inches) from their pacemaker when the phone
is switched on
• Should not carry the phone in a breast pocket
• Should use the ear opposite the pacemaker to
minimise potential interference
If you have any reason to suspect that interference
is taking place, switch off your phone immediately.
Hearing Aids
Some digital wireless phones may interfere with
some hearing aids. In the event of such inter-
ference, you may wish to consult your hearing aid
manufacturer to discuss alternatives.
Other Medical Devices
If you use any other personal medical devices,
consult the manufacturer of your device to
determine if it is adequately shielded from external
RF energy. Your physician may be able to assist you
in obtaining this information. Switch off your phone
in health care facilities when any regulations posted
in these areas instruct you to do so. Hospitals or
health care facilities may be using equipment that
could be sensitive to external RF energy.
Health and Safety Information
129
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle.
You should also consult the manufacturer of any
equipment that has been added to your vehicle.
Posted Facilities
Switch off your phone in any facility where posted
notices require you to do so.
Potentially Explosive Atmospheres
Switch off your phone when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause
an explosion or fire resulting in bodily injury or even
death.
Users are advised to switch off the phone while at a
refuelling point (service station). Users are
reminded of the need to observe restrictions on the
use of radio equipment in fuel depots (fuel storage
and distribution areas), chemical plants or where
blasting operations are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas
(such as propane or butane), areas where the air
contains chemicals or particles, such as grain, dust
or metal powders, and any other area where you
would normally be advised to turn off your vehicle
engine.
Health and Safety Information
130
Emergency Calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well
as user-programmed functions, which cannot
guarantee connection in all conditions. Therefore,
you should never rely solely on any wireless phone
for essential communications (medical
emergencies, for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not
be possible on all wireless phone networks or when
certain network services and/or phone features are
in use. Check with local service providers.
To make an emergency call, proceed as follows.
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location (for example, 112 or any other official
emergency number). Emergency numbers vary
by location.
3. Press the key.
If certain features are in use (call barring, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult this document and your local cellular
service provider.
When making an emergency call, remember to give
all the necessary information as accurately as
possible. Remember that your phone may be the
only means of communication at the scene of an
accident; do not cut off the call until given
permission to do so.
Health and Safety Information
131
Other Important Safety Information
•Only qualified personnel should service the phone
or install the phone in a vehicle. Faulty
installation or service may be dangerous and may
invalidate any warranty applicable to the device.
• Check regularly that all wireless phone
equipment in your vehicle is mounted and
operating properly.
•Do not store or carry flammable liquids, gases or
explosive materials in the same compartment as
the phone, its parts or accessories.
•For vehicles equipped with an air bag, remember
that an air bag inflates with great force. Do not
place objects, including both installed or portable
wireless equipment in the area over the air bag or
in the air bag deployment area. If wireless
equipment is improperly installed and the air bag
inflates, serious injury could result.
•Switch off your phone before boarding an aircraft.
The use of wireless phones in aircraft may be
dangerous to the operation of the aircraft, and is
illegal.
•Failure to observe these instructions may lead to
the suspension or denial of telephone services to
the offender, or legal action, or both.
Health and Safety Information
132
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for
many years.
•Keep the phone and all its parts and accessories
out of the reach of small children’s.
•Keep the phone dry. Precipitation, humidity and
liquids contain minerals that will corrode
electronic circuits.
•Do not touch the phone with a wet hand while it
is charging. Doing so may cause an electric shock
to you or damage to the phone.
•Do not use or store the phone in dusty, dirty
areas, as its moving parts may be damaged.
•Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
•Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the
phone, which may damage the phone’s electronic
circuit boards.
•Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
•Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the phone. Wipe it
with a soft cloth slightly dampened in a mild
soap-and-water solution.
Health and Safety Information
133
• Do not paint the phone. Paint can clog the
device’s moving parts and prevent proper
operation.
• Use only the supplied or an approved
replacement antenna. Unauthorised antennas or
modified accessories may damage the phone and
violate regulations governing radio devices.
•If the phone, battery, charger or any accessory is
not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
134
Glossary
To help you understand the main technical terms
and abbreviations used in this booklet and take full
advantage of the features on your mobile phone,
here are a few definitions.
Active Folder
Ability to answer a call simply by opening the
phone.
Call Barring
Ability to restrict outgoing and incoming calls.
Call Diverting
Ability to reroute calls to another number.
Call Holding
Ability to put one call on standby while answering or
making another call; you can then switch between
the two calls, as required.
Call Waiting
Ability to inform users that they have an incoming
call when engaged on another call.
Glossary
135
GPRS (General Packet Radio Service)
New non-voice value-added service that allows
information to be sent and received across a mobile
telephone network. GPRS guaranties continuous
connection to the Internet for mobile phone and
computer users. It is based on the Global System
for Mobile Communication (GSM) circuit-switched
cellular phone connections and the Short Message
Service (SMS).
GSM (Global System for Mobile
Communication)
International standard for cellular communication,
guaranteeing compatibility between the various
network operators. GSM covers most European
countries and many other parts of the world.
Java
Programming language generating applications that
can run on all hardware platforms, whether small,
medium or large, without modification. It has been
promoted for and geared heavily to the Web, both
for public Web sites and Intranets. When a Java
program runs from a Web page, it is called a Java
applet. When it is run on a mobile phone or pager, it
is called a MIDlet.
Line Identification Services (Caller ID)
Services allowing subscribers to view or block the
telephone numbers of callers.
Glossary
136
Multiparty Calling
Ability to establish a conference call involving up to
five additional parties.
Phone Password
Security code used to unlock the phone when you
have selected the option to lock it automatically
each time it switches on.
PIN (Personal Identification Number)
Security code that protects the phone against
unauthorised use. The PIN is supplied by the
service provider with the SIM card. It may be a four
to eight-digit number and can be changed, as
required.
PUK (PIN Unblocking Key)
Security code used to unlock the phone when an
incorrect PIN has been entered three times in
succession. The eight-digit number is supplied by
the service provider with the SIM card.
Roaming
Use of your phone when you are outside your home
area (when travelling for example).
Glossary
137
SDN (Service Dialling Numbers)
Telephone numbers supplied by your network
provider and giving access to special services, such
as voice mail, directory inquiries, customer support
and emergency services.
SIM (Subscriber Identification Module)
Card containing a chip with all the information
required to operate the phone (network and
memory information, as well as the subscriber’s
personal data). The SIM card fits into a small slot
on the back of the phone and is protected by the
battery.
SMS (Short Message Service)
Network service sending and receiving messages to
and from another subscriber without having to
speak to the correspondent. The message created
or received can be displayed, received, edited or
sent.
Soft Keys
Two keys marke
d and
on the phone, the
purpose of which:
•Varies according to the function that you are
currently using
•Is indicated on the bottom line of the display just
above the corresponding key
Glossary
138
Tri Band
Ability to handle any of the following types of
network: GSM 900, GSM 1800, combined GSM 900/
1800 and GSM 1900 MHz bands, for greater call
success and wider roaming.
Your phone automatically searches for the last
network used. If, for any reason, this network is
unavailable, your phone will attempt to register
with a different network.
Voice Mail
Computerised answering service that automatically
answers your calls when you are not available,
plays a greeting (optionally in your own voice) and
records a message.
139
A
Access codes •
114
Accessories •
9
Active folder •
88
Alarm (5.4) •
96
Alert type (3.3) •
77
Answering
a call •
27
a second call •
53
Anykey Answer •
88
Auto light •
87
Auto power alarm •
96
Auto redial (4.5)
88
B
Background image •
81
Backlight •
15
,
86
Band selection (6.7) •
107
Barring
calls (6.2) •
101
password •
102
,
117
Battery
charging •
19
low battery indicator •
22
precautions •
123
Battery charger •
21
Broadcast (1.5) •
71
C
Calculator (5.5) •
97
Calendar (5.1) •
90
Caller ID (6.5) •
105
Calls
answering
a call •
27
a second call •
53
barring (6.2) •
101
cost (2.5) •
75
dialled (2.3) •
74
diverting (6.1) •
99
emergency •
130
ending •
25
holding •
50
international •
24
making •
24
missed •
28
,
73
multiparty •
54
received (2.2) •
73
records (2) •
73
redialling automatically •
88
time (2.4) •
74
via phonebook •
39
waiting (6.3) •
53
,
103
Card
installing the SIM •
17
Care •
132
Changing
barring password •
102
password (4.6.4) •
84
PIN (4.6.2) •
84
PIN2 (4.6.7) •
85
Characters
changing mode •
45
entering •
44
Charging battery •
19
Closed User Group (6.6) •
105
Colour Theme •
81
Conference call •
54
Connect
to voice server •
70
tone •
79
Contrast (4.7.1) •
86
Copying
memos •
92
phonebook number •
38
task •
94
Correcting numbers •
24
Cost of call •
75
CUG •
105
Currency exchange (5.6) •
98
Index
Index
140
D
Date setting (5.3.2) •
95
Deleting
memos •
92
missed calls •
29
phonebook number •
38
received messages •
62
sent messages •
64
tasks •
94
Dialled calls (2.3) •
74
Display
contrast •
86
icons •
14
layout •
13
setting language •
83
Diverting calls (6.1) •
99
Downloads (7.3) •
108
E
Earpiece volume •
26
Editing
memos •
91
messages •
63
,
64
missed calls •
29
,
73
phonebook number •
38
tasks •
94
to do list •
93
Emergency calls •
130
Error tone •
79
F
FDN mode (4.6.6) •
85
Fixed Dial Number mode •
85
Fun Box (7) •
108
Functions, select •
31
G
Game (7.1) •
108
Greeting message (4.3) •
82
Groups
caller •
41
user •
105
H
Holding calls •
50
I
Icons, description •
14
Identifying a caller •
27
Infrared Activate (4.1) •
80
Internet •
108
IrDA port •
80
K
Key tones
adjusting volume •
26
muting •
52
selecting (3.4) •
77
sending •
52
Keypad tone (3.4) •
77
Keys
description •
11
location •
10
shortcut •
89
L
Language (4.5) •
83
Last number, redial •
25
Length of calls •
74
,
79
Letters
changing mode •
45
entering •
44
Light
backlight •
15
,
86
service •
16
,
87
Locking
phone (4.6.3) •
84
SIM card (4.6.5) •
85
Low battery indicator •
22
Lower-case characters, enter
•
47
M
Maintenance •
132
Memory status
message (1.7) •
70
phonebook •
43
Index
141
Memos
copying •
92
deleting •
92
editing •
91
writing •
91
Menus
accessing by scroll •
56
accessing by shortcuts •
57
list •
57
Message tone (3.5) •
78
Messages
broadcast (1.9) •
71
inbox (1.1) •
62
outbox (1.2) •
63
settngs (1.5) •
68
templates (1.4) •
67
voice mail (1.8) •
70
write new (1.3) •
65
Microphone mute •
51
Minute minder •
79
Missed calls (1.1) •
28
,
73
Morning call •
96
Multiparty calls
dropping •
55
making •
54
private conversation •
54
Muting
key tones •
52
microphone •
51
My objects (1.6) •
69
N
Names
entering •
44
searching/dialling •
39
storing •
35
Network selection (6.4) •
104
Network services (7) •
99
Numbers
copying phonebook •
38
correcting •
24
erasing •
38
fixed dial •
85
own •
82
pasting phonebook •
38
searching/dialling •
39
storing •
35
O
Options, select •
31
Organiser (5) •
90
Own number (4.4) •
82
P
Password
barring
changing •
102
code •
117
phone
changing •
84
code •
114
Phone
lock (4.6.3) •
84
password •
114
settings (4) •
80
Phonebook
copying •
38
editing •
38
erasing •
38
options •
37
pasting •
38
searching/dialling •
39
speed-dialling •
42
storing numbers/names
•
35
PIN
changing •
84
checking •
83
code •
115
PIN2
changing •
85
code •
116
Problems, solve •
111
PUK •
115
PUK2 •
116
R
Read messages
received (1.1) •
62
sent (1.2) •
63
Received calls (2.2) •
73
Index
142
Redialling
automatically •
88
last number •
25
Reset setting (4.10) •
89
Ring
tone (3.1) •
76
type (3.3) •
77
volume (3.2) •
76
Roaming •
104
S
Safety
information •
118
precautions •
7
Schedule •
90
Searching in phonebook •
39
Security (6) •
99
Selecting functions/options •
31
Sending
key tones •
52
messages •
65
Service light •
16
,
87
Setting
alarm (5.4) •
96
date (5.3.2) •
95
language (4.5) •
83
time (5.3.1) •
95
Shortcut (4.9) •
89
Silent mode •
31
SIM card
installing •
17
locking •
85
SIM Lock (4.6.5) •
85
SMS
message icon•
62
settings •
68
using •
53
,
62
Soft keys •
31
Solving problems •
111
Sound settings (3) •
76
Speed-dialling •
42
Switching on/off
microphone •
51
phone •
23
T
T9 mode •
46
Tasks
defining •
92
editing •
93
Templates (1.4) •
67
Text
changing mode •
45
entering •
44
Time
call •
74
format (5.3.4) •
95
setting (5.3.1) •
95
world (5.3.3) •
95
To do list (5.2) •
92
Tone
connect •
79
error •
79
keypad •
77
message •
78
ring •
76
Travel adapter •
19
U
Unpacking •
9
Upper-case characters, enter •
47
User group •
105
V
Vibration •
77
Voice mail (1.8) •
70
Voice server •
70
Volume
adjusting •
26
selecting the ring •
76
W
Waiting call •
53
,
103
WAP Browser (7.2) •
108
World time (5.3.3) •
95
Write messages (1.3) •
65
Writing memos •
91
143
Access the
Menu
Functions
➀Press the
Menu
soft key.
➁Scroll with the and
keys through the list of
the menus until you reach
the required menu.
➂Press the
Select
soft key.
➃Scroll with the and
keys through the list of
the options until the
required one is selected.
➄Press the
Select
soft key.
• Each of the two soft keys ( and )
perform the function indicated by the
text above it (on the bottom line of the
display).
Switch On/Off Press and hold the
key.
Make a Call ➀Key in the number.
➁Press the key.
End a Call Briefly press the key.
View Missed
Calls
Immediately
After Missing
Them
➀Open the phone and
press the
View
soft
key.
➁Scroll with the and
keys through the
missed calls.
➂To return the call, press
the key.
Tri Band SGH-E400 GPRS Telephone
Quick Reference Card
144
Answer a
Call
Open the phone
or
Press the key.
Adjust the
Volume
Press the or key on the
left side of the phone.
Choose
the Alert
Type
➀Select the
Alert Type
menu option (
3.3
).
➁Select an option:
•
Light only
•
Melody
•
Vibration
•
Vibra+Melody
➂
Press the
Select
soft key.
Store
Numbers in
the
Phonebook
➀Key in the number.
➁Press the
Save
soft key.
➂Select an icon for label.
➃Press the
Select
soft
key.
➄Enter the name.
➅Press the
OK
soft key.
➆If necessary, change the
location.
➇Press the
OK
soft key.
➈Press the key to
return to idle mode.
Search for a
Number in
the
Phonebook
➀Press the
Name
soft
key.
➁Select the
Search
option.
➂Enter the start of the
name.
➃To scroll through the
names, press the or
key.
➄Press the
View
soft key.
➅To scroll through the
numbers, press the
or key.
➆Press the key to dial.

Navigation menu
