Samsung Electronics Co SGHE736 Dual-Band GSM Phone with Bluetooth User Manual
Samsung Electronics Co Ltd Dual-Band GSM Phone with Bluetooth Users Manual
Users Manual
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-08508A
English. 10/2005. Rev 1.0
* Depending on the software installed or your service provider, some
of the description in this manual may differ from your phone.
* Depending on your country, your phone and accessories may
appear different from the illustrations in this manual.
SGH-E736
User’s Manual
Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or illegal.
Use road safety at all times
Do not use a hand-held phone while driving. Park
the vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using them
in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.
Important safety precautions
1
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is forbidden
to use it, or when it may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear). Avoid
unnecessary contact with the antenna when the phone
is switched on.
Emergency calls
Key in the emergency number for your present
location, then press .
Keep your phone away from small children
Keep the phone and all its parts, including accessories,
out of the reach of small children.
Accessories and batteries
Use only Samsung-approved accessories and
batteries. Use of any unauthorised accessories could
damage your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health and
safety information" on page 90.
• The phone could explode if the battery is
replaced with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.
2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone. To quickly
learn the basics for your phone, please refer to “Get
started” and “Step outside the phone.”
In this guide, the following instruction icons appear:
Indicates that you need to pay careful
attention to the subsequent information
regarding safety or phone features.
Indicates that you can get more information
on the referenced page.
→
Indicates that you need to press the
Navigation keys to scroll to the specified
option and then select it.
[ ] Indicates a key on the phone. For example,
[]
< > Indicates a soft key, whose function is
displayed on the phone screen. For example,
<
Menu
>
• Camera and camcorder
Use the camera module on your
phone to take a photo or record a
video.
Special
features of your phone
•MP3 player
Play MP3 music files using your
phone as a MP3 player.
•Bluetooth
Send photos, images, videos, and
other personal data, and connect
to other devices using free,
wireless Bluetooth technology.
3
Special features of your phone
• Get personal with photo caller
ID
See who’s calling you when their
very own photo displays.
• Name card
Create name cards with your
number and profile. Whenever
introducing yourself to others, use
this convenient electronic name
card.
•WAP browser
Access the wireless web and access
various services and up-to-the-
minute information.
• Multimedia Message Service (MMS)
Send and receive MMS messages with a
combination of text, images, video, and audio.
•E-mail
Send and receive e-mails with images, video, and
audio attachments.
•Java
Enjoy Java
™
-based embedded
games and download new games.
•Calendar
Keep track of your daily, weekly,
and monthly schedule.
• Voice recorder
Record memos or sounds.
4
Contents
Unpack 6
Make sure you have each item
Your phone 6
Buttons, features, and locations
Get started 7
First steps to operating your phone
Install and charge the phone ................................... 7
Power on or off ...................................................... 8
Keys and display .................................................... 9
Access menu functions.......................................... 11
Customise your phone .......................................... 12
Make/Answer calls................................................ 14
Step outside the phone 15
Begin with your camera, music, and other special features
Use camera ......................................................... 15
Play MP3s ........................................................... 16
Browse the web ................................................... 17
Use Phonebook .................................................... 17
Send messages.................................................... 18
View messages .................................................... 20
Use Bluetooth ...................................................... 21
Enter text 22
ABC, T9, Number, and Symbolic mode
Call functions 24
Advanced calling features
Menu functions 30
All menu options listed
Solve problems 89
Help and personal needs
Health and safety information 90
Index 112
5
Overview of menu functions
To access Menu mode, press <
Menu
> in Idle mode.
1 Call records
p.30
1 Current contacts
2 Missed calls
3 Dialled calls
4 Received calls
5 Delete all
6 Call time
7 Call costs
*
p.30
p.30
p.30
p.30
p.31
p.31
p.31
2 Phonebook
p.32
1 Contact list
2 FDN list
*
3 Add new contact
4 Group
5 Speed dial
6 My name card
7 Own number
8 Management
9 Service number
*
p.32
p.33
p.33
p.34
p.34
p.35
p.35
p.36
p.36
3 Applications
p.36
1 MP3 Player
2 Voice recorder
3 Java world
4 World time
5 Alarm
6 Calculator
7 Convertor
8 Timer
9 Stopwatch
10 SIM-AT*
p.37
p.39
p.40
p.41
p.42
p.42
p.43
p.43
p.44
p.44
4 Browser
p.44
1 Home
2 Bookmarks
3 Go to URL
4 Clear cache
5 Profile settings
6 Current profile
p.44
p.45
p.46
p.46
p.46
p.47
5 Messages
p.47
1 Create new message
2 My messages
3 Templates
4 Delete all
5 Settings
6 Broadcast messages
7 Memory status
p.47
p.50
p.56
p.57
p.57
p.62
p.63
6 File manager
p.63
1 Images
2 Videos
3 Music
4 Sounds
5 Other files
6 Memory status
p.63
p.64
p.64
p.65
p.66
p.66
7 Calendar
p.66
8 Camera
p.70
9 Settings
p.77
1 Time & Date
2 Phone settings
3 Display settings
4 Sound settings
5 Network services
6 Bluetooth
7 Security
8 Memory status
9 Reset settings
p.77
p.78
p.79
p.80
p.81
p.84
p.86
p.88
p.88
* Shows only if supported by your SIM
card.
6
Unpack
Make sure you have each item
You can obtain various accessories from
your local Samsung dealer.
Phone Travel Adapter
The items supplied with your phone
and the accessories at your Samsung
dealer may vary, depending on your
country or service provider.
Battery User’s Manual
Your phone
Buttons, features, and locations
Special
function keys
Camera key
Earpiece/
Speaker
Display
Power on/off/
Menu exit key
Soft key (right)
Microphone
Navigation keys
(Up/Down/Left/
Right)
WAP access/
Confirm key
Cancel/Correct
key
Camera
MP3 player
control keys
External
display
Soft key (left)
Headset jack
Volume keys
Dial key
Alphanumeric
keys
7
Get started
First steps to operating your phone
SIM card information
When you subscribe to a cellular network, you receive
a plug-in SIM (Subscriber Identity Module) card
loaded with your subscription details, such as your
PIN, and available optional services.
Install and charge the phone
Remove the battery.
If the
phone is already
on, first turn it off by
holding
[]
.
Insert the SIM card.
Make sure that the gold-
coloured contacts on the
card face down into the
phone.
1 2
Install the battery.
Plug the travel adapter
into the phone.
Plug the adapter into a standard AC wall outlet.
When the phone is completely charged (the battery
icon stops blinking), unplug the adapter from the
power outlet.
34
5
6
8
Get started
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the battery low message displays, and
• the empty battery icon blinks.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
Power on or off
Remove the adapter from the phone.
7
Switch on
Do not turn on
the phone when
mobile phone
use is prohibited.
1. Open the phone.
2. Press and hold [ ] to turn on
the phone.
3. If necessary, enter the PIN and
press <
OK
>.
Switch off
1. Open the phone.
2. Press and hold [ ].
9
Get started
Keys and display
Key(s) Description
Perform the function indicated on the bottom
line of the display.
In Idle mode, access your favourite menus,
directly.
p. 78
In Menu mode, scroll through the menu
options.
In Idle mode, launch the Wireless
Application Protocol (WAP) browser.
In Menu mode, select the highlighted menu
option.
Delete characters from the display.
In Menu mode, return to the previous menu
level.
Send or answer a call.
In Idle mode, retrieve the recent numbers
dialled, missed, or received.
End a call.
Hold down to switch the phone on and off.
In Menu mode, cancel input and return the
phone to Idle mode.
Enter numbers, letters, and some special
characters.
In Idle mode, hold
[1]
down to access your
voice mail server. Hold [
0
] down to enter the
international call prefix.
Enter special characters.
Hold [
]
down to activate or deactivate
Quiet mode.
Hold
[ ] down to enter a pause.
(on the left)
Adjust the phone volume.
In Idle mode, with the phone open, adjust
the keypad tone volume. With the phone
closed, hold down to turn on the backlight.
(on the right)
In Idle mode, hold down to turn on the
camera.
In Camera mode, take a photo or record a
video.
10
Get started
Display
Key(s) Description
(on the front)
Hold down to display the function selection
screen to access the MP3 player.
In the MP3 player, start or stop playback.
(on the front)
Return to the previous file during playback.
(on the front)
Skip to the next file during playback.
Layout
Icons
*
Received signal strength
Call in progress
Out of your service area; you cannot
send or receive calls
Alarm set
New text message
New multimedia message
New voicemail message
Text and graphics
display messages,
instructions, and
information you enter.
Soft key function indicators
show the current functions
assigned to the two soft
keys.
Menu Contacts
Icons
display various icons.
11
Get started
Access menu functions
Icons
(continued)
New e-mail received or being sent
One of the message Inboxes is full
Call diverting feature is active
p. 81
Bluetooth feature is active
p. 84
GPRS network
Home Zone, if you have registered
for the appropriate service
Office Zone, if you have registered
for the appropriate service
Call ringer set to vibrate
p. 80
Quiet mode is active
p. 81
Battery power level
* The icons shown on the display may vary, depending
on your country or service provider.
Use the soft
keys
The roles of the soft keys vary
depending on the function you are
using. The bottom line of the
display indicates their current role.
Press the left soft
key to access
Menu mode.
Press the right soft
key to access
Contact list
in the
Phonebook
menu.
Menu Contacts
12
Get started
Customise your phone
Select an
option
1. Press the appropriate soft key.
2. Press the Navigation keys to
move to the next or previous
option.
3. Press <
Select
> or [ ] to
confirm the function displayed
or option highlighted.
4. To exit, choose either of the
following methods.
• Press <
Back
> or <
C
> to
move up one level.
• Press [ ] to return to Idle
mode.
Use shortcuts
Press the number key
corresponding to the option you
want.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Phone
settings
→
Language
.
2. Select a language.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Sound
settings
→
Incoming call
→
Ring tone
.
2. Press [Left] or [Right] to select
a ringer category.
3. Press [Up] or [Down] to scroll
through ringer melodies.
4. Select a ringer melody you
want.
5. Press <
Save
>.
Display
language
Call ringer
melody
13
Get started
You can set your wallpaper for the
main or external display.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Display
settings
→
Wallpaper
→
Main
display
or
Sub clock
.
2. Select an image category and
then an image.
For
Sub clock
, you can select
Digital clock
to be displayed
on the external display.
3. Press [ ].
You can change the colour for the
display components, such as title
bars and highlight bars.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Display
settings
→
Skin
.
2. Select a colour pattern.
Idle mode
wallpaper
Menu mode
skin colour
You can switch to Quiet mode to
avoid disturbing other people with
your phone sound.
Press and hold
[
]
in Idle mode.
You can use the Navigation keys as
shortcut keys to access specific
menus directly from Idle mode.
To assign a menu to a key:
1. In Idle mode, press <
Menu
>
and select
Settings
→
Phone
settings
→
Short cut
.
2. Select a key.
3. Press <
Options
> and select
Change
.
4. Scroll to a menu to be assigned
to the key.
5. Press <
Save
>.
Quiet mode
Menu
shortcuts
14
Make/Answer calls
You can protect the phone against
unauthorised use with a phone
password. The phone will require
the password on powerup.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Security
→
Change
password
.
2. Enter the default password,
“00000000” and press <
OK
>.
3. Enter a new 4- to 8- digit
password and press <
OK
>.
4. Enter the new password again
and press <
OK
>.
5. Select
Phone lock
.
6. Select
Enable
.
7. Enter the password and press
<
OK
>.
Phone lock
1. In Idle mode, enter an area code
and phone number.
2. Press
[]
.
3. To end the call, press
[]
.
1. When the phone is ringing, press
[]
.
2. To end the call, press
[]
.
Press [ / ].
Make a call
Answer a call
Adjust the
volume during
a call
15
Step outside the phone
Begin with your camera, music, and other special features
Use camera
1. Open the phone.
2. In Idle mode, press and hold
[ ] to turn on the camera.
3. Aim the lens at the subject and
adjust the image.
4. Press [ ] to take a photo. The
photo is saved automatically.
5. Press [ ] to return to
Capture mode.
1. In Capture mode, press the left
soft key and select
Go to
photos
.
2. Select
a photo you want
.
Take a photo
View a photo
1. In Capture mode, press [
1
] to
switch to Record mode.
2. Press [ ] to start recording.
3. Press [ ] to stop recording.
The video is saved
automatically.
4. Press the right soft key to
return to Record mode.
1. In Record mode,
press the left
soft key and select
Go to
videos
.
2. Select a video clip you want.
Record a video
Play a video
16
Step outside the phone
Play MP3s
Use these methods:
• Download from the wireless
web
p. 44
• Download from a computer
using Samsung PC Studio II
Samsung PC Studio II User’s
Guide
• Receive via Bluetooth
p. 86
1. In Idle mode, press <
Menu
>
and select
Applications
→
MP3 Player
.
2. Press <
Options
> and select
Add to list
→
Add all
or
Add a
file
.
3. For
Add a file
, scroll to a
specific file and press <
Add
>.
Repeat from step 2.
Copy MP3 files
to the phone
Create a play
list
1. From the MP3 player screen,
press [ ].
2. During playback, use the
following keys:
• [ ]: pauses/resumes
playback.
• [Left]: goes back to the
previous file. Moves
backward through a file
when held down.
• [Right]: skips to the next
file. Moves forward through
a file when held down.
• [Up]: opens the play list.
• [Down]: stops playback.
• [ / ]: adjusts the volume.
Play MP3 file
17
Step outside the phone
Browse the web
Using a built-in WAP (Wireless Application Protocol)
browser, you can get easy access to the wireless web
to get a variety of up-to-date services and information
and to enjoy downloads of web content.
Use Phonebook
In Idle mode, press [ ].
• To scroll through browser items,
press [Up] or [Down].
• To select an item, press < >.
• To return to the previous page,
press <
Back
> or [
C
].
• To return to the home page,
hold [
C
] down.
• To access browser options,
press [ ] or select on the
top of the screen.
Launch the
browser
Navigate with
the WAP
browser
To the phone’s memory:
1. In Idle mode, enter a phone
number and press [ ].
2. Select
Phone
→
a number type.
3. Specify the contact information:
First name, Last name, Mobile,
Home, Office, Fax, Other, Email,
Graphic ID, Alert, Group, and
Notes.
4. Press [ ] to save the entry.
To t he S IM c ar d :
1. In Idle mode, enter a phone
number and press [ ].
2. Select
SIM
.
3. Enter a name.
4. Press [ ] to save the entry.
Add an entry
18
Step outside the phone
Send messages
1. In Idle mode, press
<
Contacts
>.
2. Enter a name or scroll to an
entry.
3. Select an entry.
4. Select a number and press
[]
to dial, or press
<
Options
> to access options.
1. In Idle mode, press <
Menu
>
and select
Phonebook
→
My
name card
.
2. Specify your contact
information.
3. Press [ ] to save the name
card.
4. To send the name card to other
people, press <
Options
> and
select
Send via
→
SMS
/
MMS
/
Email
/
Bluetooth
.
Find an entry
Create and
send a name
card
1. In Idle mode, press <
Menu
>
and select
Messages
→
Create
new message
→
Text
message
.
2. Enter the message text.
3. Press <
Options
> and select
Save and send
or
Send only
.
4. Enter a destination number.
5. Press [ ] to send the
message.
1. In Idle mode, press <
Menu
>
and select
Messages
→
Create
new message
→
Multimedia
message
.
2. Select
Subject
.
3. Enter the message subject and
press [ ].
Send a text
message (SMS)
Send a
multimedia
message
(MMS)
19
Step outside the phone
4. Select
Picture & Video
→
Pictures
or
Videos
→
a
category.
5. Select a photo and press
<
Add
>.
If you select a video clip, press
the left soft key and select
Add
.
6. Select
Sound
→
a category.
7. Select a sound and press
<
Add
>.
8. Select
Message
.
9. Enter the message text and
press [ ].
10. Press <
Options
> and select
Send
.
11. Enter a destination phone
number or e-mail address.
12. Press [ ] to send the
message.
Send a
multimedia
message
(MMS)
(continued)
1. In Idle mode, press <
Menu
>
and select
Messages
→
Create
new message
→
Email
.
2. Select
Subject
.
3. Enter the e-mail subject and
press [ ].
4. Select
Message
.
5. Enter the e-mail text and press
[].
6. Select
File attach
.
7. Add images, videos, sounds, or
music files.
8. Press <
Options
> and select
Send
.
9. Enter an e-mail address.
10. Press [ ] to send the
e-mail.
Send an e-mail
20
Step outside the phone
View messages
-
When a notification appears:
1. Press <
View
>.
2. Select a message from the
Inbox.
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messages
→
My
messages
→
Inbox
.
2. Select a message.
When a notification appears:
1. Press <
View
>.
2. Select a message from the
Inbox.
View a text
message
View a
multimedia
message
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messages
→
My
messages
→
Inbox
.
2. Select a message.
1. In Idle mode, press <
Menu
>
and select
Messages
→
My
messages
→
Email box
.
2. Select
Check new mail
to
retrieve an e-mail or a header.
3. Select an e-mail or a header.
4. If you selected a header, press
<
Options
> and select
Retrieve
.
View a
multimedia
message
(continued)
View an e-mail
21
Step outside the phone
Use Bluetooth
Your phone is equipped with Bluetooth technology
which enables you to connect the phone wirelessly to
other Bluetooth devices and exchange data with them,
talk hands-free, or control the phone remotely.
In Idle mode, press <
Menu
> and
select
Settings
→
Bluetooth
→
Activation
→
On
.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Bluetooth
→
My devices
→
Search new device
.
2. Select a device.
3. Enter a Bluetooth PIN code or
the other device’s Bluetooth PIN
code, if it has one, and press
<
OK
>.
When the owner of the other
device enters the same code,
pairing is complete.
Turn on
Bluetooth
Search for and
pair with a
Bluetooth
device
1. Access an application.
2. Scroll to an item.
3. Press <
Options
> and select
Send
via
→
Bluetooth
.
4. Select a device.
5. If necessary, enter the
Bluetooth PIN and press <
OK
>.
To receive data via Bluetooth, your
phone’s Bluetooth feature must be
active.
If necessary, press <
Yes
> to
confirm the reception.
Send data
Receive data
22
Enter text
ABC, T9, Number, and Symbolic mode
You can enter text for some features such as
messaging, Phonebook, or Calendar, using ABC mode,
T9 mode, Number mode, and Symbolic mode.
Changing the text input mode
The text input mode indicator appears when the cursor
is in a text field.
• Press the right soft key to change the text input
mode. ( : T9 mode, : ABC mode, :
Number mode, and : Symbolic mode)
• Press and hold [ ] to switch to Symbolic mode.
Using ABC mode
Press the appropriate key until the character you want
appears on the screen.
Tips for using ABC mode
• To enter the same letter twice or to enter a
different letter on the same key, wait for the cursor
to move to the right automatically or press [Right].
Then, enter the next letter.
Enter text
23
• Press [ ] to change case. Lower case (No
indicator), Initial capital ( ), and Capital lock ( )
are available.
• Press [ ] to insert a space.
• Press the Navigation keys to move the cursor.
•Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
Using T9 mode
T9 is a predictive text input mode that allows you to
key in any character using single keystrokes.
Entering a word in T9 mode
1. Press [
2
] to [
9
]
to start entering a word. Press
each key once for each letter.
For example, press [
4
], [
3
], [
5
], [
5
], and [
6
] to
enter HELLO in T9 mode.
T9 predicts the word that you are typing, and it
may change with each key that you press.
2. Enter the whole word before editing or deleting
characters.
3. When the word displays correctly, go to step 4.
Otherwise, press [
0
] to display alternative word
choices for the keys that you have pressed.
For example, OF and ME use [
6
] and [
3
].
4. Press [ ] to insert a space and enter the next
word.
Tips for using T9 mode
• Press [
1
] to enter periods or apostrophes
automatically.
• Press [ ] to change case. Lower case (No
indicator), Initial capital ( ), and Capital lock ( )
are available.
• Press [ ] to insert a space.
• Press the Navigation keys to move the cursor.
• Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
Adding a new word to the T9 dictionary
This feature may not be available for some languages.
1. Enter the word that you want to add.
24
2. Press [
0
] to display alternative words for your key
presses. When there are no more alternative
words,
Spell
appears on the bottom line.
3. Press <
Spell
>.
4. Enter the word you want using ABC mode and
press <
OK
>.
Using Number mode
Number mode enables you to enter numbers.
Press the keys corresponding to the digits you want.
Using Symbolic mode
Symbolic mode enables you to insert symbols.
Call functions
Advanced calling features
Making a call
1. In Idle mode, enter the area code and phone
number.
2. Press [ ].
Making an international call
1. In Idle mode, press and hold [
0
]. The
+
character
appears.
2. Enter the country code, area code, and phone
number, then press [ ].
Redialling recent numbers
1. In Idle mode, press [ ] to display the list of
recent numbers.
2. Scroll to the number you want and press [ ].
To Press
display more symbols [Up] or [Down].
select a symbol the corresponding
number key.
clear the entered symbol(s) [
C
].
insert the symbol(s) <
OK
>.
Press
[
C
]
to clear the last digit or press and hold
[
C
]
to clear the whole display. You can move the
cursor to edit an incorrect digit.
Call functions
25
Making a call from Phonebook
Once you have stored a number in Phonebook, you
can dial the number by selecting it from
Phonebook.
p. 32
You can also use the speed dial feature to assign your
most frequently called numbers to specific number
keys.
p. 34
Dialling a number from the SIM card
1. In Idle mode, enter the location number for the
phone number you want and press [ ].
2. Press [Left] or [Right] to scroll through other
numbers.
3. Press <
Dial
> or [ ] to dial the number you want.
Ending a call
Close the phone or press [ ].
Answering a call
When you receive an incoming call, the phone rings
and displays the incoming call image.
Press <
Accept
> or [ ] to answer the call.
Tips for answering a call
• When
Anykey
answer
in the
Extra
settings
menu is active, you can press any key, except for
<
Reject
>, [ ], or [ / ].
p. 79
• When
Active folder
in the
Extra
settings
menu
is active, you can simply open the phone.
p. 79
• Press <
Reject
> or [ ] to reject a call.
• Depending on the setting in the
Side key
menu,
press and hold [ / ] to mute a call ringer or
reject a call.
p. 78
Viewing missed calls
If you have missed calls, the screen displays how
many calls you have missed.
1. Press <
View
>.
2. If necessary, scroll through the missed calls.
3. Press [ ] to dial the number you want.
26
Call functions
Using the headset
Use the headset to make or answer calls without
holding the phone.
Connect the headset to the jack on the left side of the
phone.
The buttons on the headset work as listed below:
Options during a call
You can access a number of functions during a call.
Adjusting the volume during a call
Use [ / ] to adjust the earpiece volume during a call.
Press [ ] to increase the volume level and [ ] to
decrease the volume level.
Using the external speaker
Use the optional external speaker to talk and listen
with the phone a short distance away. First, you must
plug the speaker into the phone.
1. During a call, press [ ].
2. When a pop-up message appears, press <
Yes
>.
3. Press [ ] again to return to normal phone
mode.
Placing a call on hold/Retrieving
Press <
Hold
> or <
Retrieve
> to place a call on hold
or retrieve the call.
Making a second call
You can make another call if your network supports it.
1. Press <
Hold
> to put the call on hold.
2. Make the second call in the normal way.
3. Press <
Swap
> to switch between the calls.
4. Press <
Options
> and select
End
held
call
to end
the call on hold.
5. To end the current call, press [ ].
To Press
redial the last call and hold the button twice.
answer a call the button.
end a call the button.
Call functions
27
Answering a second call
You can answer an incoming call while already on the
phone, if your network supports it and you have
activated the call waiting feature.
p. 83
1. Press [ ] to answer the call. The first call is
automatically put on hold.
2. Press <
Swap
> to switch between the calls.
3. Press <
Options
> and select
End
held
call
to end
the call on hold.
4. To end the current call, press [ ].
Transferring a call
You can transfer the currently active call to a caller on
hold, if your network supports it. With this option, the
two callers can talk to each other, but you are
disconnected from the call.
Press <
Options
> and select
Transfer
.
Using a Bluetooth headset
Use an optional Bluetooth headset to talk on the
phone without holding the phone to your ear. To use
this feature, you first need to register your headset
and connect it to the phone.
p. 84
Press <
Options
> and select
Switch to headset
or
Switch to phone
.
Using the voice clarity feature
This feature increases the microphone’s sensitivity so
that the person with when you are speaking can hear
you clearly even though you may be whispering.
Press <
Options
> and select
Voice clarity on
or
Voice clarity off
.
Switching off the microphone
(Mute mode)
You can temporarily switch off your phone’s
microphone so that the person on the phone cannot
hear you.
Press <
Options
> and select
Mute
or
Unmute
.
28
Call functions
Muting or sending key tones
You can turn the key tones off or on.
Press <
Options
> and select
Mute keys
or
Send
keys
.
Using Phonebook
You can access the
Phonebook
menu to locate or
store entries.
p. 32
Press <
Options
> and select
Phonebook
.
Sending a sequence of DTMF tones
Dual tone multi-frequency (DTMF) tones are the tones
used in phones for tone dialling.
You can send DTMF tones as a group after entering the
entire number you need to send or retrieving a
number from Phonebook. This feature is helpful for
entering a password or an account number when you
call an automated system, like a banking service.
1. When connected with a teleservice system, press
<
Options
> and select
Send DTMF
.
2. Enter the number you need to send and press
<
OK
>.
Using the messaging feature
You can create and send an SMS message or access
received messages.
p. 47
Press <
Options
> and select
Message
.
Using SIM services
The
SIM service
menu is available if you use a SIM
card in your phone. A SIM card provides services such
as news, weather, sports, entertainment, and location
services.
For details, see your SIM card instructions or contact
your service provider.
To communicate with answering machines or
computerised telephone systems,
Send keys
must
be selected.
Call functions
29
Making a multi-party call
Use this feature to allow as many as six people to join
a multi-party call, or conference call.
Your service provider must support multi-party calls
for you to use this feature.
Setting up a multi-party call
1. Call the first participant.
2. Call the second participant. The first call is
automatically put on hold.
3. Press <
Options
> and select
Join
. The first
participant is added to the multi-party call.
4. If desired, call another person or answer an
incoming call.
5. Press <
Options
> and select
Join
.
6. Repeat steps 4 and 5 as desired.
Having a private conversation with one
participant
1. Press <
Options
> and select
Private
.
2. Select a name or number from the participant list.
You can talk privately with that person, while the
other participants converse with each other.
3. To return to the multi-party call, press <
Options
>
and select
Join
.
Dropping one participant
1. Press <
Options
> and select
Remove
.
2. Select a name or number from the participant list.
The participant is dropped from the call, but the
call continues with the other parties.
3. Close the phone or press [ ] to end the multi-
party call.
30
Menu functions
All menu options listed
Call records
(Menu 1)
Use this menu to view the calls you have dialled,
received, or missed, and the length of your calls.
To access this menu, press <
Menu
> in Idle mode and
select
Call records
.
Current contacts
(Menu 1.1)
This menu displays the most recent calls dialled,
received, or missed.
Accessing a call record
1. Press [Left] or [Right] to select a call type.
2. Press [Up] or [Down] to scroll to a call record.
3. Press [ ] to view the details of a call, or [ ]
to dial the number.
Using call record options
While viewing the call record list, press <
Options
> to
access the following options:
•
Details
: show the details of the selected call.
•
Call
: dial the displayed number.
•
Save as contacts
: save the phone number to
Phonebook.
•
Send message
: send an SMS or MMS message.
•
Delete
: delete the selected call record or all
records.
Missed calls
(Menu 1.2)
This menu displays the most recent calls that you did
not answer.
Dialled calls
(Menu 1.3)
This menu displays the most recent calls you have
dialled.
Received calls
(Menu 1.4)
This menu displays the most recent calls you have
received.
Menu functions
Call records
(Menu 1)
31
Delete all
(Menu 1.5)
Use this menu to delete all of the records in each call
type.
1. Press [ ] to check the call record(s) to be
cleared.
2. Press <
Delete
>.
3. Press <
Yes
> to confirm the deletion.
Call time
(Menu 1.6)
This menu displays the time log for calls made and
received. The actual time invoiced by your service
provider will vary.
•
Last
call
time
: check the length of your last call.
•
Total
sent
: check the total length of all the calls
you have dialled.
•
Total
received
: check the total length of all the
calls you have received.
•
Reset timers
: reset the call timers. You need to
enter the phone password.
Call costs
(Menu 1.7)
This network feature displays the cost of calls. This
menu is available only if your SIM card supports this
feature. Note that this is not intended to be used for
billing purposes.
•
Last
call
cost
: check the cost of your last call.
•
Total
cost
: check the total cost of all of your calls.
If the total cost exceeds the maximum cost set in
Set
max
cost
, you must reset the counter before
you can make another call.
•
Max
cost
: check the maximum cost limit set in
Set
max
cost
.
•
Reset
counters
: reset the cost counters. You
need to enter your PIN2.
•
Set
max
cost
: set the maximum cost authorised
for your calls. You need to enter your PIN2.
•
Price/Unit
: set the price per unit that is applied
when the cost of your calls is calculated. You need
to enter your PIN2.
The password is preset to
00000000
. You can
change this password.
p. 87
32
Menu functions
Phonebook
(Menu 2)
You can store phone numbers on your SIM card and in
your phone’s memory. The SIM card and phone’s
memory are physically separate, but they are used as
a single entity called Phonebook.
To access this menu, press <
Menu
> in Idle mode and
select
Phonebook
.
Contact list
(Menu 2.1)
Use this menu to search for numbers in Phonebook.
Finding an entry
1. Enter the first few letters of the name that you
want to find.
2. Select the name you want from the list.
3. Press [ ] to dial the number, or <
Options
> to
access Phonebook options.
Using Phonebook options
While viewing the contact details, press <
Options
> to
access the following options:
•
Edit
: edit the contact information.
•
Send via
: send the contact via SMS, MMS, e-mail,
or Bluetooth.
•
Delete
: delete the selected contact.
•
Print via bluetooth
: print the contact information
by connecting the phone to a printer via Bluetooth.
While viewing the contact list, press <
Options
> to
access the following options:
•
View
: display details about the contact.
•
Send message
: send an SMS, MMS, or e-mail
message.
•
Add new contact
: add a new contact to
Phonebook.
•
Delete
: delete the selected contact or all contacts.
•
Language select
: select a language to be used in
the text input mode.
Press <
Contacts
> in Idle mode to quickly access
this menu.
Menu functions
Phonebook
(Menu 2)
33
FDN list
(Menu 2.2)
Use this menu to create a list of contacts to be used in
FDN (Fixed Dialling Number) mode, in which the
phone allows outgoing calls only to the specified
phone numbers, if your SIM card supports this
feature. You can activate FDN mode in the
FDN mode
menu
.
p. 87
Adding a contact
1. Press <
Options
> and select
Add
.
2. Enter your PIN2 and press <
OK
>.
3. Enter a name and phone number, or press
<
Options
> and select
Contact list
to retrieve a
contact from Phonebook.
4. If necessary, change the location number.
5. Press <
Save
> to save the contact.
Using contact options
Scroll to a contact and press <
Options
> to access
options.
”Using Phonebook options”
Add new contact
(Menu 2.3)
Use this menu to add a new contact to Phonebook.
Storing a number in the phone’s memory
1. Select
Phone
.
2. Change the settings or enter information about the
contact.
•
First name
/
Last name
: assign a name.
•
Mobile
/
Home
/
Office
/
Fax
/
Other
: add a
number in any category.
•
Email
: assign an e-mail address.
•
Graphic ID
: assign an image as a caller ID
image to alert you to a call from the person.
•
Alert
: assign a ringer melody to alert you to a
call from the person.
•
Group
: assign the person to a caller group.
•
Notes
: add a memo about the person.
3. Press [ ] to save the contact.
The settings specified in
Graphic ID
and
Alert
are given priority over group settings.
34
Menu functions
Storing a number on the SIM card
1. Select
SIM
.
2. Enter a name and a phone number.
3. If necessary, change the location number.
4. Press [ ] to save the contact.
Group
(Menu 2.4)
Use this menu to organise your contacts in caller
groups.
Creating a new caller group
1. Press <
Options
> and select
Add
.
2. Enter a name for the group.
3. Select the
Graphic ID
line to assign an image.
4. Select the
Alert
line to assign a ringer melody.
5. Press <
Save
> to save the group.
Adding members to a caller group
1. Select a group.
2. Press <
Add
>. The list of contacts stored in your
phone’s memory is displayed.
3. Select a contact you want to add to the selected
group.
4. To add more members, press <
Options
> and
select
Add
→
a contact. Repeat this as desired.
Managing caller groups
While viewing the group list, press <
Options
> to
access the following options:
•
View
: display the members of the selected group.
•
Add
: add a new group.
•
Edit
: edit the properties of the selected group.
•
Send message
: send an SMS, MMS, or e-mail
message to the member(s) you want.
•
Delete
: delete the selected group. Group
members, however, are not deleted from
Phonebook.
Speed dial
(Menu 2.5)
Use this menu to assign a speed dial number (2 to 9)
for eight of your most frequently called numbers.
Menu functions
Phonebook
(Menu 2)
35
Assigning speed dial numbers
1. Select a key location from
2
to
9
. [
1
] is reserved
for your voice mail server.
2. Select a contact you want.
3. If the contact has more than one number, select
the number you want.
Managing speed dial entries
From the Speed dial screen, press <
Options
> to
access the following options:
•
View
: display the number assigned to the key.
•
Change
: assign a different number to the
assigned key.
•
Remove
: clear the speed dial setting.
Dialling speed dial entries
Press and hold the appropriate key in Idle mode.
My name card
(Menu 2.6)
Use this menu to create a name card and send it to
other people.
Saving your name card
The procedure for creating your name card is the
same as the one for saving a phone number in the
phone’s memory.
p. 33
Using name card options
After saving your name card, press <
Options
> to
access the following options:
•
Edit
: edit the name card.
•
Send via
: send the name card via SMS, MMS,
e-mail, or Bluetooth.
•
Exchange namecard
: exchange name cards with
another person via Bluetooth.
•
Remove
: delete the name card.
•
Print via Bluetooth
: print the name card by
connecting the phone to a printer via Bluetooth.
Own number
(Menu 2.7)
Use this feature to check your phone numbers, or to
assign a name to each of the numbers. Changes made
here do not affect the actual subscriber numbers in
your SIM card.
36
Menu functions
Management
(Menu 2.8)
Use this menu to manage Phonebook.
•
Default saving
: select a default memory location
to save contacts.
If you select
Ask on saving
, the phone will ask
you to select a memory location when saving a
number.
•
Copy all to phone
: copy all of the contacts stored
in the SIM card to the phone’s memory.
•
Sort by contacts
: sort your contacts by the first
name or last name.
•
Delete all
: delete all of the contacts from your
phone’s memory, your SIM card, or the FDN list.
1.Press [ ] to check the location(s) to be
cleared.
2.Press <
Delete
> and then <
Yes
>.
If you select
FDN
, you need to enter the PIN2.
3.Enter the phone password and press <
OK
>.
•
Memory status
: display the number of contacts
you have stored in Phonebook.
Service number
(Menu 2.9)
This menu is available if your SIM card supports
Service Dialling Numbers (SDN). Use this menu to
view the list of SDNs assigned by your service
provider, including emergency numbers, directory
enquiries, and voice mail numbers.
Scroll to the number you want and press <
Dial
> or
[].
Applications
(Menu 3)
Use this menu to play Java games, to play music files,
to record a voice memo, to set time zones and alarms,
or to use your phone as a calculator, timer, convertor,
or stopwatch.
To access this menu, press <
Menu
> in Idle mode and
select
Applications
.
The password is preset to
00000000
. You
can change this password.
p. 87
Menu functions
Applications
(Menu 3)
37
MP3 Player
(Menu 3.1)
Use this menu to enjoy music. First, you need to save
MP3 files in your phone’s memory.
Downloading or receiving music files
Use these methods to save MP3 files to your phone’s
memory:
• Download from the wireless web
p. 44
• Download from a computer using the Samsung PC
Studio II program
Samsung PC Studio II User’s
Guide
• Via an active Bluetooth connection
p. 86
The downloaded or received files are stored in the
Music
folder.
p. 64
Creating a play list
Add MP3 files to the play list.
1. From the MP3 player screen, press <
Options
>
and select
Add to list
.
2. Select either of the following options:
•
Add all
: add all of the files in the phone’s
memory to the play list.
•
Add a file
: add a specific file to the play list.
3. If you selected
Add a file
, scroll to a file and press
<
Add
>.
4. Press <
Back
> to go back to the MP3 player
screen.
Playing music files
From the MP3 player screen, press [ ].
During playback, use the following keys:
Keys Function
Pauses or resumes playback.
Left Goes to the previous file. Moves backward
through a file when held down.
Right Skips to the next file. Moves forward
through a file when held down.
Up Opens the play list.
Down Stops playback.
/ Adjusts the volume level.
38
Menu functions
Using music file options
From the MP3 player screen, press <
Options
> to
access the following options:
•
Play
: play music files.
•
Send via
: send music files via e-mail or Bluetooth.
•
Open play list
: display the play list.
•
Set as
: set the file as your ring tone, alarm
melody, or a caller alert melody for a Phonebook
entry.
•
Delete
: remove the music file from the phone’s
memory.
•
Settings
: change the default settings for playing
music files.
Repeat mode
: select a repeat mode.
Shuffle
: set the MP3 player to play music in
random order.
Visualization
: select an equalizer type.
Skin
: select a skin type.
Volume
: select a volume level.
•
Properties
: view the file properties.
Accessing the play list
1. From the MP3 player screen, press <
Options
>
and select
Open play list
to access the play list.
2. Press <
Options
> to access the following options:
•
Play
: play the selected file.
•
Add to list
: add files to the play list.
•
Move list
: move the selected file to the
position you want within the play list.
•
Remove
: remove the selected file or all of the
files from the play list.
Playing MP3 files with the phone closed
1. Press and hold [ ] and then [ ] to open the
MP3 player.
2. Press [ ] to start playing music.
2
Changes an equalizer type.
3
Changes the repeat mode.
5
Changes an equalizer colour.
6
Turns shuffle mode on or off.
Keys Function
Menu functions
Applications
(Menu 3)
39
During playback,
• Use the following keys to control the MP3 player:
•Press and hold [
]
to lock the exposed keys to
keep accidental presses from affecting playback.
The key lock icon ( ) appears on the bottom line.
Voice recorder
(Menu 3.2)
Use this menu to record voice memos. A voice memo
can be up to one hour long.
Recording a voice memo
1. Press [ ] to start recording.
2. Speak into the microphone.
Press [ ] to pause or resume the recording.
3. When you finish, press <
Save
>. The voice memo
is saved automatically.
Playing a voice memo
1. From the Voice record screen, press <
Options
>
and select
Go to voice list
.
2. Select a voice memo. The memo plays.
Keys Function
Pauses or resumes playback.
Returns to the previous file. Moves
backward through a file when held
down.
Skips to the next file. Moves forward
through a file when held down.
/ Adjusts the volume.
4.
To Press
return to Record mode [Up].
play back the voice memo [ ].
access voice memo
options
<
Options
>.
p. 65
return to the previous
level
<
Back
>.
40
Menu functions
During playback, use the following keys:
Using voice memo options
From the Voice record screen, press <
Options
> to
access the following options:
•
Record
: record a new voice memo.
•
Settings
: configure the following settings for a
voice memo:
Recording time
: select the recording time.
Volume
: select the voice memo volume to be
used during playback.
Default name
: specify a default saving prefix for
the voice memo.
•
Go to voice list
: go to the list of voice memos you
have recorded.
Java world
(Menu 3.3)
Use this menu to access and play Java games and to
set up a profile for accessing Java services.
Using Java game options
1. From the Java world screen, select
Downloads
and scroll to a game.
2. Press <
Options
> to access the following options:
•
Launch
: launch the selected game.
•
Application settings
: set a game to be
continued when a call comes in or an alarm
sounds during the game. You can also set the
phone to exchange game information with the
network while playing an online game or when
you need to connect to the Internet.
•
Delete
: delete the selected game.
•
Properties
: view the game properties.
Keys Function
Pauses or resumes playback.
Left Moves backward.
Right Moves forward.
Up Returns to Record mode.
Down Stops playback.
/ Adjusts the volume.
Menu functions
Applications
(Menu 3)
41
Configuring Java settings
You can configure profile settings for accessing Java
services.
From the Java world screen, select
Settings
.
The following settings are available:
•
APN
: enter the access point name.
•
Login ID
: enter the user ID.
•
Password
: enter the password.
•
Proxy
: select whether or not you use a proxy
server to access network services. Depending on
this setting, options in
Proxy settings
vary.
•
Proxy settings
: provide you with the following
options:
When the proxy is set to
Enable
:
IP address
: enter the HTTP proxy IP address.
Port
: enter the proxy port number.
When the proxy is set to
Disable
:
DNS1
: enter the primary DNS address.
DNS2
: enter the secondary DNS address.
Checking memory status
You can view the total amount of memory for the Java
games as well as the amount of used memory.
From the Java world screen, select
Memory status
.
World time
(Menu 3.4)
Use this menu to set your local time zone and find out
what time it is in another part of the world.
Setting your local time zone
1. From the world map, press [Left] or [Right] to
select the city that corresponds to your home time
zone. As the time line moves, the time and date of
the given zone display.
2. Press [ ] to save the time zone.
Viewing and setting a foreign time zone
1. From the world map, press [Down].
2. Press [Left] or [Right] to select the foreign time
zone you want.
3. Press [ ] to save the time zone.
42
Menu functions
Applying Daylight Savings Time (DST)
1. From the world map, press <
Options
> and select
Set daylight saving time
.
2. Press [ ] to check the time zone(s) you want.
3. Press <
Save
>.
Alarm
(Menu 3.5)
Use this menu to set alarms to sound at specific times.
Setting an alarm
1. Select the type of alarm.
2. Press [Left] or [Right] to select
On
and press
[Down].
3. Enter the time for the alarm to sound and press
[Down].
4. Press [Left] or [Right] to select
AM
or
PM
in 12-
hour time format and press [Down].
5. Select the day(s) on which you want to the alarm
to ring.
6. Select the
Alarm tone
line and select an alarm
melody.
7. Press <
Save
> and then <
Yes
> to set the alarm.
Stopping an alarm
• When an alarm sounds, press <
OK
> or any key.
• When a wake-up call alarm sounds, press <
OK
> or
[ ] to stop the alarm.
Otherwise, press <
Snooze
> or any key to stop
the alarm and cause it to sound again after 5
minutes. You can do this a maximum of five times.
Setting the alarm to ring even if the phone is
off
From the Alarm screen, select
Auto power
→
On
.
If the phone is off when it is time for the alarm to ring,
the phone is switched on and sounds the alarm.
Calculator
(Menu 3.6)
Use this menu to perform basic arithmetic functions,
such as addition, subtraction, multiplication, and
division.
1. Enter the first number.
Press the left soft key to insert a decimal point or
brackets.
Press [ ] or [ ] to move the cursor
.
Menu functions
Applications
(Menu 3)
43
2. Select the operation for your calculation by
pressing one of the Navigation keys according to
the illustration on the display.
3. Enter the second number.
4. Press [ ] to view the result.
Convertor
(Menu 3.7)
Use this menu for common conversions, such as
temperature.
Performing a conversion
1. Select the convertor type you want.
2. Press [Left] or [Right] to select the original unit
and press [Down].
3. Enter the value to be converted.
• Press [ ] to insert a decimal point.
• Press [ ] to change the temperature to above
zero (+) or below zero (-).
4. Press [Down].
5. Press [Left] or [Right] to select the unit you want
to convert to.
The equivalent value for the amount you entered
displays.
Using convertor options
Press <
Options
> to access the following options:
•
Clear
: clear the current values.
•
Reverse
: reverse the conversion.
Timer
(Menu 3.8)
Use this menu to set a period of time for the phone to
count down. The phone will sound an alarm when the
specified period of time has expired.
Starting the timer
1. Press <
Set
>.
2. Enter the length of time you want to count down
and press <
OK
>.
3. Press [ ] to start counting down.
Stopping the timer
• Press <
Back
> or any key when the timer rings.
• Press [ ] on the Timer screen to stop the timer
before it rings.
44
Menu functions
Stopwatch
(Menu 3.9)
Use this menu to measure elapsed time. The precision
of the stopwatch is one one-hundredth of a second.
The maximum measurement time is 10 hours.
1. Press [ ] to start the stopwatch.
2. Press [ ] to check an interval. You can repeat
this step for a total of 4 intervals.
3. To reset the stopwatch, press <
Reset
>.
SIM-AT
(Menu 3.10)
This menu is available if you use a SIM-AT card that
provides additional services, such as news, weather,
sports, entertainment, and location services. Available
services may vary, depending on your services
provider’s plans.
For details, see your SIM card instructions or contact
your service provider.
Browser
(Menu 4)
The Wireless Application Protocol (WAP) browser on
your phone allows you to access the wireless web.
Using the WAP browser, you can access up-to-date
information and a wide variety of media content, such
as wallpapers, ring tones, and music files.
To access this menu, press <
Menu
> in Idle mode and
select
Browser
.
Home
(Menu 4.1)
Use this menu to connect your phone to the network
and load the home page of the wireless web service
provider. You can also press [ ] in Idle mode.
Navigating with the WAP browser
To Press
scroll through browser items [Up] or [Down].
select a browser item < >.
return to the previous page <
Back
> or [
C
].
return to the home page and hold [
C
].
Menu functions
Browser
(Menu 4)
45
Selecting and using the browser menu options
Press [ ] or select on the top of the screen.
•
Back
: go back to the previous page.
•
Home
: go back to the home page.
•
Exit
: exit the WAP browser.
•
Reload
: reload the current page.
•
Show URL
: display the URL address of the current
web page. You can also set the current page as the
home page for the WAP browser.
•
About...
: view the WAP browser certificate and
version information.
Using WAP page options
From any WAP page, press [ ] to access the following
options:
•
Go to URL
: enter a URL address manually.
•
Bookmarks
: switch to the
Bookmarks
menu.
Menu 4.2
•
Messages
: check the
Inbox
,
Outbox
, and
Draft
box in the
My messages
menu. You can also
create and send a new SMS message.
p. 50
•
File manager
: switch to the
File manger
menu.
p. 63
Exiting the WAP browser
Press [ ] to exit the browser.
Bookmarks
(Menu 4.2)
Use this menu to save URL addresses in order to
quickly access websites.
Adding a bookmark
1. Select an empty location.
2. Enter a name for the bookmark.
3. Enter a URL address and press [ ].
Accessing a bookmarked page
Scroll to a bookmark item and press [ ].
Using bookmark options
Scroll to a bookmark and press <
Options
> to access
the following options:
•
Go
: access the bookmarked website.
•
Edit
: edit the address and name of the bookmark.
•
Delete
: delete the selected bookmark.
46
Menu functions
Go to URL
(Menu 4.3)
Use this menu to manually enter the URL address of a
website and access the website.
Clear cache
(Menu 4.4)
Use this menu to clear the cache, a temporary
memory that stores recently accessed web pages.
Profile settings
(Menu 4.5)
Use this menu to set up servers for the WAP browser.
Contact your service provider for details about your
setting options.
For each server, the following options are available:
•
Profile
name
: assign a name to the server profile.
•
Home
URL
: set the address of your home page.
•
Bearer
: select a bearer for each type of network
address accessed.
•
Proxy
: select whether or not the phone uses a
proxy server to launch the WAP browser. Your
service provider can tell you if your network
requires a proxy server, and they can give you the
appropriate settings.
•
GPRS settings
: customise the following GPRS
network settings:
When the proxy is set to
Enable
:
Proxy IP
: enter the proxy IP address.
Proxy port
: enter the proxy port number.
APN
: enter the access point name of the GPRS
network gateway.
Login ID
: enter the user ID.
Password
: enter the password.
When the proxy is set to
Disable
:
DNS 1
: enter the primary address.
DNS 2
: enter the secondary address
.
APN
: enter the access point name of the GPRS
network gateway.
Login ID
: enter the user ID
.
Password
: enter the password
.
•
GSM settings
: customise the following GSM
network settings:
Menu functions
Messages
(Menu 5)
47
When the proxy is set to
Enable
:
Proxy IP
: enter the proxy IP address.
Proxy port
: enter the proxy port number.
Dial number
: enter the PPP server phone number.
Login ID
: enter the user ID.
Password
: enter the password.
Data call type
: select a data call type.
When the proxy is set to
Disable
:
DNS 1
: enter the primary address.
DNS 2
: enter the secondary address.
Dial number
: enter the PPP server phone number.
Login ID
: enter the user ID.
Password
: enter the password.
Data call type
: select a data call type.
Current profile
(Menu 4.6)
Use this menu to select a connection profile for
accessing the WAP browser.
Messages
(Menu 5)
Use the
Messages
menu to send and receive text
messages, multimedia messages, and e-mails. You
can also use WAP push message and cell broadcast
message features.
To access this menu, press <
Menu
> in Idle mode and
select
Messages
.
Create new message
(Menu 5.1)
Use this menu to create and send SMS, MMS, or
e-mail messages.
Text message
(Menu 5.1.1)
Short Message Service (SMS) allows you to send or
receive text messages that may include pictures,
animated images, and melodies.
The maximum number of characters allowed in a
text message varies by service provider. If your
message exceeds the maximum number of
characters, the phone will split the message.
48
Menu functions
1. Enter your message.
2. Press <
Options
> to access one of the following
options:
•
Save and send
: both save a copy of the
message and send the message.
•
Send only
: send the message.
•
Insert
: add a template, Phonebook entry, or
bookmark.
•
Add picture
/
Add animation
/
Add melody
:
attach a picture, animated image, or melody.
•
Attach
: attach a name card or calender data
as a data format attachment.
•
Save to
: save the message in the
Draft
or
My
folder
box.
•
Language select
: change the language used
in the text input mode.
•
Text style
: change the text attributes.
3. When you have finished, press <
Options
> and
select
Save and send
or
Send only
.
4. Enter a destination number.
To send the message to more than one recipient,
press [Down] and fill in additional destination
fields.
5. Press [ ] to send the message.
Multimedia message
(Menu 5.1.2)
Multimedia Message Service (MMS) allows you to send
or receive multimedia messages containing a
combination of text, image, video, and audio, from
phone to phone or from phone to e-mail.
1. Select the
Subject
line.
2. Enter the message subject and press [ ].
3. Select the
Picture & Video
line.
4. Select
Pictures
or
Videos
and select a category.
5. Select a photo and press <
Add
>.
If you select a video clip, press the left soft key
and select
Add
.
6. Select the
Sound
line.
Menu functions
Messages
(Menu 5)
49
7. Select a category and a sound file, and press
<
Add
>.
8. Select the
Message
line.
9. Enter the message text and press [ ].
10. While composing the message, press <
Options
>
to access the following options:
•
Add
: add a message subject or text.
•
Edit
: edit the message subject or text.
•
Add image/Add video/Add sound
: add a
photo, video, or sound. Depending on the file
type or DRM (Digital Rights Management)
system, some files may not be able to be
forwarded.
•
Change image
/
Change video
/
Change
sound
: change an added photo, video, or
sound.
•
Preview
: display the message you have
created.
•
Send
: send the message.
•
Save to
: save the message in the
Draft
or
My
folder
box. You can also save the message as
an MMS template.
•
Add page
: add pages. Move to each page by
pressing [Left] or [Right] on the message
screen.
•
Delete page
: delete an added page.
•
Edit page
: change the duration of page display
or move the page forward.
•
Attach
: attach a name card or calender data.
•
Remove subject
/
Remove message
: clear
the subject or text.
•
Remove media
/
Remove sound
: remove an
added photo, video, or sound.
11. When you have finished, press <
Options
> and
select
Send
.
12. Enter a phone number or e-mail address.
To send the message to more than one recipient,
press [Down] and fill in additional destination
fields.
The maximum size allowed for an MMS message
can differ depending on the country. If you
cannot attach another file, add another page.
Depending on the field status or selected field,
available options vary.
50
Menu functions
13. Press [ ] to send the message.
Email
(Menu 5.1.3)
You can send e-mails that include text and media files,
such as images, videos, and audio. To use this feature,
you need to subscribe to an e-mail service and set up
your e-mail account and profile.
p. 61, p. 62
1. Select the
Subject
line.
2. Enter the subject of your e-mail and press [ ].
3. Select the
Message
line.
4. Enter the e-mail text and press [ ].
5. Select the
File attach
line.
6. Press <
Options
> and add media files to your
e-mail by using the following options:
•
Add image
/
Add videos
/
Add sounds
/
Add
music
: add photos, videos, sounds, or music
files.
Depending on the file type or DRM (Digital
Rights Management) system, some files may not
be able to be forwarded
.
•
Other files
: add files in unsupported format.
•
Attach
: add name cards or calendar data.
7. While composing the e-mail, press <
Options
> to
access the following options:
•
Edit
: edit the subject or text.
•
View
: open the attached file.
•
Send
: send the e-mail.
•
Save to
: save the e-mail in the
Draft
or
My
folder
box.
•
Remove subject
/
Remove message
: clear
the subject or text.
•
Remove
: delete the selected attachment or all
attachments.
•
Remove all attachments
: delete all
attachments.
8. When you have finished, press <
Options
> and
select
Send
.
9. Enter an e-mail address.
To send the e-mail to more than one recipient,
press [Down] and fill in additional destination
fields.
10. Press [ ] to send the e-mail.
My messages
(Menu 5.2)
Use this menu to store all of the messages you have
received, sent, failed to send, or saved to send it later.
Menu functions
Messages
(Menu 5)
51
Inbox
(Menu 5.2.1)
This folder stores all of the messages you have
received, except for e-mails and CB messages.
Viewing a message at the time of its receipt
When a message has been received, the phone alerts
you by:
• Displaying a message icon with text notification
• Sounding a tone or vibrating, depending on the
message alert setting.
To read a message immediately, press <
View
> and
select a message from the Inbox.
Viewing a message in the Inbox
The following icons may appear on the message list;
depending on the message type or status, icons may
vary:
• SMS/WAP push messages/Delivery report
• MMS
• MMS notification
While viewing the message list, press <
Options
> to
access the following options:
•
View
: open the message.
•
Retrieve
: retrieve the MMS message from the
server.
•
Reply via SMS
: send a reply message via SMS.
•
Reply via MMS to
: send a reply message via
MMS.
•
Forward
: forward the message to other people.
•
Delete
: delete the selected message or all
messages.
•
Move to my folder
: move the message to the
My
folder
box.
• Depending on the DRM (Digital Rights
Management, you may not be able to forward
some messages. They are indicated by the
icon.
•
An
!
icon next to a message icon indicates high
priority. A grey-coloured message icon
indicates low priority.
52
Menu functions
•
Move to phone
/
SIM
: move the SMS message to
the phone’s memory or the SIM card.
•
Sort by
: change the sort order of the messages.
•
Protection
: protect the message from being
deleted.
•
Properties
: view the message properties.
Using message options
While viewing a message, press <
Options
> to access
the following options:
SMS messages
•
Reply via
: send a reply message via SMS or MMS.
•
Forward
: forward the message to other people.
•
Delete
: delete the message.
•
Move to phone
/
SIM
: move the SMS message to
the phone’s memory or the SIM card.
•
Add to block list
: add the sender’s number to the
Block number
list.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Protection
: protect the message from being
deleted.
•
Print via bluetooth
: print the selected message
by connecting the phone to a printer via Bluetooth.
MMS messages
•
Reply via SMS
: send a reply message via SMS.
•
Reply via MMS to
: send a reply message via
MMS.
•
Forward
: forward the message to another person.
•
Delete
: delete the selected message or all
messages.
•
Add to block list
: add the sender’s number to the
Block number list.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Cut media
: save media content from the message
into your phone’s memory.
•
Properties
: view the message properties.
WAP push messages
•
Go to URL
: connect to the URL from which the
message is sent.
Menu functions
Messages
(Menu 5)
53
•
Cut address
: extract URL, e-mail addresses, or
phone numbers from the message.
•
Delete
: delete the message.
Delivery report messages
•
Cut address
: extract URL, e-mail addresses, or
phone numbers from the message.
•
Delete
: delete the message.
•
Protection
: protect the message from being
deleted.
Draft
(Menu 5.2.2)
This folder stores messages you have saved to send at
a later time.
Press <
Options
> to access the following options:
•
View
: display the message.
•
Edit
: edit the message.
•
Send
: send the message.
•
Delete
: delete the selected message or all
messages.
•
Move to my folder
: move the message to the
My
folder
box.
•
Move to phone
/
SIM
: move the SMS message to
the phone’s memory or the SIM card.
•
Sort by
: change the sort order of the messages.
•
Protection
: protect the message from being
deleted.
•
Properties
: view the message properties.
Outbox
(Menu 5.2.3)
This folder stores messages that the phone is
attempting to send or has failed to send.
In this folder, the following icons are available:
• Messages that the phone is sending
• Messages that the phone has failed to send
While viewing a message or the message list, press
<
Options
> to access the following options:
•
View
: display the message.
•
Send
(
again
): send the message.
•
Forward
: forward the message to other people.
•
Edit
: edit the message.
•
Delete
: delete the selected message or all
messages.
54
Menu functions
•
Move to my folder
: move the message to the
My
folder
box.
•
Move to phone
/
SIM
: move the SMS message to
the phone’s memory or the SIM card.
•
Sort by
: change the sort order of the messages.
•
Print via bluetooth
: print the selected message
by connecting the phone to a printer via Bluetooth.
•
Protection
: protect the message from being
deleted.
Sentbox
(Menu 5.2.4)
This folder stores messages that you have sent.
While viewing a message or from the message list,
press <
Options
> to access the following options:
•
Open file
: open the selected file.
•
Save file
: save the selected file.
•
View
: display the message.
•
Forward
: forward the message to other people.
•
Delete
: delete the selected message or all
messages.
•
Move to my folder
: move the message to the
My
folders
box.
•
Move to phone
/
SIM
: move the SMS message to
the phone’s memory or the SIM card.
•
Sort by
: change the sort order of the messages.
•
Protection
: protect the message from being
deleted.
•
Properties
: view the message properties.
Email box
(Menu 5.2.5)
This folder stores e-mails that you have received.
1. Select an e-mail account.
2. Press <
Yes
> when
Check new mail
is displayed
to get new mails from the server.
The phone checks for new e-mails and retrieves
received e-mails.
The following icons may appear on the message
list; depending on the e-mail states, icons may
vary:
• has been read
• has not been read
• is being retrieved from the server
• has not been retrieved
Menu functions
Messages
(Menu 5)
55
3. Scroll to an e-mail or header and press [ ].
4. If the e-mail has more than one page, press [ / ]
to scroll through pages one by one.
Press and hold [ / ] to move to the first or last
page.
5. Select an attached file to view or play it.
6. Press [ ] or [ ] to move to the previous or next
e-mail.
While viewing the e-mail content or e-mail list, press
<
Options
> to access the following options:
•
View
: display the e-mail.
•
Retrieve
: retrieve one or all e-mails from the
e-mail server.
•
Reply to
: send a reply message to the sender or
to all of the other recipients.
•
Forward
: forward the e-mail.
•
Mark as read
: mark the e-mail as read.
•
Delete selection
: delete the selected e-mail.
•
Delete all
: delete all e-mails.
•
Move to my folder
: move the retrieved e-mail to
the
My folder
box.
•
Sort by
: sort the e-mails by size, subject, data, or
senders’ e-mail addresses.
•
Protection
: protect the e-mail from being deleted.
•
Properties
: view the e-mail properties.
While viewing a header or e-mail, press <
Options
> to
access the following options:
•
Retrieve
: retrieve one or all e-mails.
•
Open file
: open the attached file.
•
Save file
: save the attached file in the phone’s
memory.
•
Reply to
: send a reply message to the sender or
to the sender and all of the other recipients.
•
Forward
: forward the e-mail.
•
Delete
: delete the e-mail.
An
!
icon next to a message icon indicates
high priority. A grey-coloured message icon
indicates low priority.
Options may vary depending on the status of the
e-mail.
56
Menu functions
•
Add to block list
: add the sender’s e-mail
address or the e-mail subject to the
Block list
.
•
Cut address
: extract e-mail addresses, URLs, and
phone numbers from the e-mail.
•
Cut attachment
: save the selected attachment or
all attachments from the e-mail into your phone’s
memory.
•
Print via bluetooth
: print the selected e-mail by
connecting the phone to a printer via Bluetooth.
•
Protection
: protect the e-mail from being deleted.
•
Properties
: view the e-mail properties.
My folder
(Menu 5.2.6)
Use this menu to store and manage your messages.
Press <
Options
> to access the following options:
•
View
: display the message.
•
Edit
: edit the message.
•
Send
: send the message.
•
Delete
: delete the selected message or all
messages.
•
Sort by
: change the sort order of messages.
•
Protection
: protect the message from being
deleted.
•
Properties
: view the message properties.
Templates
(Menu 5.3)
Use this menu to create, edit, or send text or
multimedia templates.
Text template
(Menu 5.3.1)
Use this menu to preset frequently used text
messages.
1. Select an empty location.
2. Enter a message and press [ ].
3. Press <
Options
> to access the following options:
•
Edit
: edit the template.
•
Send message
: send a new message using
the template.
•
Delete
: delete the template.
MMS template
(Menu 5.3.2)
Your phone has 11 preset MMS messages, which
cannot be deleted. You can create a new MMS
template and send the template.
Menu functions
Messages
(Menu 5)
57
Scroll to an MMS template and press [ ] to display
the template.
While viewing a message, press <
Options
> to access
the following options:
•
Replay
: replay the template.
•
Send
: send the template.
•
Edit
: edit the template.
•
Delete
: delete the template.
While viewing the template list, press <
Options
> to
access the following options:
•
View
: display the template.
•
Send message
: send the template.
•
Edit
: edit the template.
•
Add new
: add a new template.
•
Delete
: delete the selected template or all
templates.
Delete all
(Menu 5.4)
Use this menu to delete messages in each message
folder one by one, or all at once. You can also delete
all messages in all folders at one time.
Settings
(Menu 5.5)
Use this menu to set up various options for using the
messaging service.
Text message
(Menu 5.5.1)
You can configure the default SMS settings for sending
messages.
Send settings
: set up the following options:
•
Reply path
: allow the recipient to reply to you
through your message centre.
•
Delivery report
: set the network to inform you
when your message has been delivered.
•
Character support
: select a character encoding
type. If you select
Auto
, the phone switches the
encoding type from
GSM-alphabet
to
Unicode
if
you enter a
Unicode
character. Use of
Unicode
encoding will reduce the maximum number of
characters in a message to about half.
If this menu is not shown, your phone provides the
Auto
character encoding by default.
•
Validity period
: set the length of time your
messages are stored in the SMS centre.
58
Menu functions
•
Message type
: set the default message type. The
network can convert the messages into the
selected format.
•
Service centre
: store or change the number of
your message centre.
Block number
: specify phone numbers from which
messages will not be accepted. Numbers specified
here are also included in the MMS blocking list.
Multimedia message
(Menu 5.5.2)
You can configure the default MMS settings for sending
or receiving messages.
Send settings:
set up the following options for
sending multimedia messages:
•
Delivery report
: set the network to inform you
when your message has been delivered.
•
Address hiding
: set your address to be hidden
from the recipient’s phone.
•
Read reply
: determine whether or not the phone
sends a read-reply request.
•
Priority
: set the priority level of your outgoing
messages.
•
Expiry Date
: set the length of time your
messages are stored in the MMS centre.
•
Delivery after
: set a time delay before messages
are sent.
•
Send size
: select maximum size of attached items
allowed for an MMS message.
Receive settings
: set up the following options for
receiving multimedia messages:
•
Anonymous reject
: reject messages from
anonymous senders.
•
Advert allowed
: accept advertisements.
•
Report allowed
: send a delivery report from the
network to the sender.
•
Home reception
: determine if your phone
retrieves new messages automatically when you
are in your home service area.
•
Roaming reception
: determine if your phone
retrieves new messages automatically when you
are roaming in another network.
Home reception
and
Roaming reception
have
the following options:
Menu functions
Messages
(Menu 5)
59
- Automatic
: the phone automatically retrieves
messages from the server.
- Reject
: the phone rejects all messages.
- Manual
: the phone displays notifications. Use
the
Retrieve
option to manually download new
messages.
MMS profiles
: configure required network settings for
MMS. The last profile accessed is automatically
activated for sending or receiving subsequent
messages.
•
Current profile
: select a profile.
•
Profile settings
: customise the following options
for each profile:
Profile name
: assign a name to the MMS profile.
Server URL
: enter the address of your MMS
server.
Proxy
: connect to the GPRS network using the
proxy server.
GPRS settings
: customise the settings required
for connecting to the GPRS network.
-
IP address
: (when the proxy is set to
Enable
)
enter the IP address.
-
Port
: (when the proxy is set to
Enable
) enter
the port number.
-
DNS1
: (when the proxy is set to
Disable
) enter
the primary address.
-
DNS2
: (when the proxy is set to
Disable
) enter
the secondary address.
-
APN
: enter the access point name used for the
address of the GPRS network.
-
Login ID
: enter the user ID.
-
Password
: enter the password.
Version
: select an available OMA version and
maximum size limit for sending or receiving
messages.
Check with your service provider before you change
any MMS settings on your phone.
Depending on your service provider, it may not
be possible to support the maximum limit
295KB. In this case, try again after changing
the setting to 100KB.
60
Menu functions
Block number
: specify phone numbers from which
messages will not be accepted. Numbers specified
here are also included in the SMS blocking list.
Email
(Menu 5.5.3)
You can configure the default network settings that
are required to send or receive e-mails.
Send settings
: set up the following options for
sending e-mails.
•
Send copy to self
: send a copy of your e-mail to
your own e-mail address.
•
Delivery confirm
: set the network to inform you
when your e-mail has been delivered.
•
Read confirm
: send a request for a reply along
with your e-mail.
•
Priority
: select the priority level of your outgoing
e-mail.
•
Include signature
: select to attach your name,
phone number, or a simple memo to your e-mail
using the
Edit name
,
Edit telephone number
,
and
Edit note
options.
•
Edit name
: enter your name.
•
Edit telephone number
: enter your phone
number.
•
Edit note
: enter a simple memo.
Receive settings
: set up the following options for
receiving e-mails.
•
Check interval
: determine how often the phone
checks the server for incoming e-mails.
If you set this option to
Not used
, you can use the
Check new mail
feature to check your e-mail
manually.
•
Read reply
: determine whether or not the phone
sends a read-reply request.
When this option is set to
Announce
, the phone
reminds you to send a read-reply request with
your e-mail address.
•
Retrieve option
: determine whether the phone
retrieves headers only or the entire e-mail.
You cannot change e-mail profile settings while an
e-mail is being sent or retrieved.
Menu functions
Messages
(Menu 5)
61
•
Delete option
: determine whether e-mails are
deleted immediately or the next time you connect
to the server.
•
Reject if over
: determine the maximum size for
incoming e-mails. Your phone will reject e-mails
that exceed the specified size.
•
Leave a copy of messages on the server
: leave
copies of e-mails after retrieving.
Email account
: set up your e-mail account(s) and
select the one to be used:
•
Current account
: select an account.
•
Account settings
: configure up to five e-mail
accounts using different e-mail servers.
The following options are available for each
account:
In use
: select this option to use the account and
to display the account in
Email box
.
Account name
: enter a name for the currently
selected account.
User name
: enter a name to be displayed as the
sender’s name in your outgoing e-mails.
Email address
: enter your e-mail address.
Reply address
: enter the e-mail address to which
you want recipients to send reply messages.
User ID
: enter your e-mail ID.
Password
: enter your e-mail password.
SMTP server
: enter the IP address or domain
name of the outgoing e-mail server.
SMTP port
: enter the SMTP port number.
Protocol type
: select the protocol for the
incoming e-mail server. The remaining options
depend on the protocol type setting.
When the protocol type is
POP3
:
POP3 server
:
enter the IP address or domain
name of the server that receives your e-mail.
POP3 port
: enter the POP3 port number.
APOP login
: connect to the server by using the
APOP login scheme when this option is selected.
You cannot change e-mail account settings while an
e-mail is being sent or retrieved. Your e-mail
service provider can give you the information
needed for the below settings.
62
Menu functions
When the protocol type is
IMAP4
:
IMAP4 server
: enter the IP address or domain
name of the server that receives your e-mail.
IMAP4 port
: enter the IMAP4 port number.
Include attachments
: select this option to
receive attachments with e-mails.
Max. Emails retrieved
: set the number of
headers you will retrieve from the server.
Email profile
: configure the network settings
required to send or receive e-mails.
•
Current profile
: select a profile.
•
Profile settings
: configure up to five e-mail
profiles. For each profile, the following options are
required to connect to the GPRS network:
Profile name
: enter a name for the e-mail profile.
APN
: enter the access point name used for the
GPRS network address.
Login ID
: enter the user ID.
Password
: enter the password.
DNS1
: enter the primary address.
DNS2
: enter the secondary address.
Block list
: specify e-mail addresses from which
messages will not be accepted. You can also specify
message subjects that you will not accept.
Push message
(Menu 5.5.4)
You can change the settings for receiving WAP push
messages from the wireless web server. The following
options are available:
•
Receive
: set how your phone receives WAP push
messages.
•
Service centre
: specify the address of the server
from which you want to receive WAP push
messages, the
Receive
option is set to
SMS-C
specific
.
Broadcast messages
(Menu 5.6)
The Cell Broadcast service delivers short messages on
various topics, such as weather, sports, or traffic.
Use this menu to change the settings for the service
and to access broadcast messages.
You cannot change e-mail profile settings while an
e-mail is being sent or retrieved.
Menu functions
File manager
(Menu 6)
63
•
Read
: open received messages.
The
Temporary
box saves network messages until
the phone is switched off.
The
Archive
box saves network messages
indefinitely. Press <
Options
> and select
Save
to
save messages to the
Archive
box when a text
notification appears.
•
Receive
: enable or disable the reception of
broadcast messages.
•
Channel
: specify the channels from which you
receive broadcast messages.
When you select
Respective channels
, you can
set up a list of active CB channels.
•
Language
: select the language(s) in which
broadcast messages display.
Please contact your service provider for details.
Memory status
(Menu 5.7)
Use this menu to view the maximum memory and
available memory for each message type. You can also
view the memory currently in use in each folder.
File manager
(Menu 6)
The
File manager
menu allows you to access images,
videos, music files, and sound files stored in the
phone’s memory.
To access this menu, press <
Menu
> in Idle mode and
select
File manager
.
Images
(Menu 6.1)
This menu displays photos you have taken and images
downloaded or received in messages.
Viewing an image
1. Select an image folder.
2. Scroll to an image and press [ ].
Using image options
While viewing an image or the image list, press
<
Options
> to access options.
p. 73
According to the DRM (Digital Rights Management)
system, web content may not be able to be
forwarded. The content is indicated by the
icon
.
64
Menu functions
Videos
(Menu 6.2)
This menu displays video clips you have recorded,
downloaded, or received in messages.
Playing a video clip
1. Select a video folder.
2. Scroll to a clip and press [ ].
p. 76
Using video options
While viewing the video list, press <
Options
> to
access the following options.
•
Play
: play the video clip.
•
Send via
: send the video clip via MMS, e-mail, or
Bluetooth.
•
Delete
: delete the selected video clip or all video
clips.
•
Rename
: change the name of the video clip.
•
Move to favourite videos
: move the file to the
Favourite videos
folder.
•
Share for Bluetooth
: set whether or not to
prevent this file from being accessed from other
Bluetooth devices.
•
Protection
: protect the video clip from being
deleted.
•
Properties
: view the video clip properties.
Music
(Menu 6.3)
This menu displays MP3 files you have downloaded,
received in messages, or imported from your
computer.
Playing a music file
Scroll to a file and press [ ].
p. 37
Using music options
While viewing the music list, press <
Options
> to
access the following options:
•
Play
: play the files.
•
Send via
: send the file via e-mail or Bluetooth.
•
Add play list
: add the file to the play list.
•
Set as
: set the file as your ring tone, alarm tone,
or a caller alert melody for a Phonebook entry.
Video clips recorded on other devices, such as
camcorders, may not play correctly.
Menu functions
File manager
(Menu 6)
65
•
Delete
: delete the selected file or all files.
•
Settings
: change the default settings for playing
music files.
p. 38
•
Rename
: change the file name.
•
Share for Bluetooth
: set whether or not to
prevent this file from being accessed from other
Bluetooth devices.
•
Protection
: protect the file from being deleted.
•
Properties
: view the file properties.
Sounds
(Menu 6.4)
This menu displays sound files you have recorded,
downloaded, or received in messages.
Playing a sound clip
1. Select a sound folder.
2. Scroll to a clip and press [ ].
p. 39
Using sound options
While viewing the sound list, press <
Options
> to
access the following options:
•
Play
: play the sound clip.
•
Send via
: send the sound clip via MMS,
e-mail, or Bluetooth.
•
Set as
: set the sound clip as your ring tone, alarm
melody, or a caller alert melody for a Phonebook
entry.
•
Delete
: delete the selected sound clip or all sound
clips.
•
Rename
: change the name of the sound clip.
•
Move to favourite
(
sounds
): move the sound
clip to the
Favourite sounds
folder.
•
Share for Bluetooth
: set whether or not to
prevent the sound clip from being accessed by
other Bluetooth devices.
•
Protection
: protect the sound clip from being
deleted.
•
Properties
: view the sound clip properties.
66
Menu functions
Other files
(Menu 6.5)
Files that you have received but which are not
supported by your phone are stored in this folder. You
cannot open these files on the phone. Unsupported file
formats include *.doc, *.ppt, and *.txt.
While viewing the file list, press [ ] to access the
following options:
•
Send via
: send the file via e-mail or Bluetooth.
•
Delete
: delete the selected file or all files.
•
Rename
: change the file name.
•
Share for Bluetooth
: set whether or not to
prevent this file from being accessed from other
Bluetooth devices.
•
Protection
: protect the file from being deleted.
•
Properties
: view the file properties.
Memory status
(Menu 6.6)
You can check the total amount of memory for media
items and the amount of memory currently in use in
each media box.
Calendar
(Menu 7)
The calendar feature enables you to keep track of your
schedule and to-do list, and to view missed alarm
events.
To access this menu, press <
Menu
> in Idle mode and
select
Calendar
.
Consulting the calendar
When you enter the
Calendar
menu, the calendar in
Month view appears with today’s date highlighted.
The number of events for the specific day appears at
the bottom of the calendar. The following icons
indicate the type of event:
Press <
Options
> to access the following options:
•
View mode
: change the view mode of the
calendar.
•
Create
: add a new event.
•
Go to
: go to the current date or enter a specific
date.
• Scheduled event • Anniversary
• To-do item • Miscellaneous
Menu functions
Calendar
(Menu 7)
67
•
Sort by
: sort items by the type of event.
•
Delete
: delete the event(s).
•
Missed alarm events
: view events whose alarms
you have missed.
•
Memory status
: view the memory status for
items stored in the phone’s memory.
Creating an event
You can schedule events on the calendar.
Entering a new scheduled event
1. Scroll to a date on the calendar.
2. Press <
Options
> and select
Create
→
Schedule
.
3. Enter information or change the settings in the
following entry fields:
•
Subject
: enter the event subject.
•
Details
: enter event details.
•
Start date
and
Start time
: enter the starting
date and time for the event.
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
•
End date
and
End time
: enter the ending date
and time for the event.
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
•
Location
: enter information about the event
location.
•
Alarm
: select to set an alarm for the event.
•
before
: set how long before the event the
alarm is to alert you.
•
Alarm tone
: select an alarm tone.
•
Repeat
: select to set the event to recur and a
repeat unit.
•
Until
: if the event will recur, set the ending
date.
4. Press <
Save
> to save the event.
Entering a new anniversary
1. Select a date on the calendar.
2. Press <
Options
> and select
Create
→
Anniversary
.
3. Enter information or change the settings in the
following entry fields:
•
Occasion
: enter information about the
anniversary.
•
Date
: enter the date.
68
Menu functions
•
Alarm
: select to set an alarm for the
anniversary.
•
before
: set how long before the event the
alarm is to alert you.
•
Alarm time
: enter the time for the alarm to
sound.
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
•
Alarm tone
: select an alarm tone.
•
Repeat every year
: select to set the phone to
remind you of the anniversary every year.
4. Press <
Save
> to save the event.
Entering a new
Miscellaneous
1. Select a date on the calendar.
2. Press <
Options
> and select
Create
→
Miscellaneous
.
3. Enter information or change the settings in the
following entry fields:
•
Subject
: enter the title of the event.
•
Details
: enter event details.
•
Start date
and
Start time
: enter the starting
date and time for the event.
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
•
End date
and
End time
: enter the ending date
and time for the event.
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
•
Alarm
: set an alarm for the event.
•
before
: set how long before the event the
alarm is to alert you.
•
Alarm tone
: select an alarm tone.
4. Press <
Save
> to save the event.
Entering a to-do item
1. Select a date on the calendar.
2. Press <
Options
> and select
Create
→
To do
.
3. Enter information or change the settings in the
following entry fields:
•
To do
: enter information about the task.
•
Start date
: enter the starting date.
•
Due date
: enter the ending date.
•
Priority
: select a priority level of the task.
4. Press <
Save
> to save the event.
Menu functions
Calendar
(Menu 7)
69
Viewing an event
Square brackets on a calendar date indicate the
following type of events scheduled for that day:
1. Select a date on the calendar to display the events
for the day.
2. Select an event to view its details.
While viewing an event or the event list, press
<
Options
> to access the following options:
•
View
: display the event details.
•
Edit
: edit the event.
•
Create
: add a new event.
•
Send via
: send the event via SMS, MMS,
e-mail, or Bluetooth.
•
View mode
: change the view mode of the
calendar.
•
Done
/
Undone
: mark the to-do item as done, or
not.
•
Sort by
: sort items by the type of event.
•
Delete
: delete the event(s).
•
Print via bluetooth
: print the selected event by
connecting the phone to a printer via Bluetooth.
•
Missed alarm events
: view events whose alarms
you have missed.
•
Memory status
: view the memory status for
items stored in the phone’s memory.
Viewing an event in different mode
By default, the calendar appears in Month view mode.
Press <
Options
> and select
View mode
to change
the mode.
Day view
You can view events for the selected date. Select an
event to view its details.
The following icons will be displayed according to the
event’s type and status:
• Alarm set
• Recurring event
• Completed to-do item
• Blue: Scheduled event • Orange: Anniversary
• Red: To-do item • Green: Miscellaneous
70
Menu functions
• To-do priority; its colour indicates the priority
level (Red: high, Blue: normal, and Grey: low)
Week view
You can view miscellaneous and scheduled events for
the selected week.
A cell on the timetable indicates the presence of event
information. Select the cell that contains the event you
want.
Viewing a
missed alarm event
When you are unable to acknowledge an alarm, the
phone displays a missed alarm notification.
•Press <
View
> to view the corresponding event.
•Press <
Exit
>.
Accessing missed alarm events
1. Press <
Options
> and select
Missed alarm
events
.
2. Select an event.
Using missed alarm options
From the event list, press <
Options
> to access the
following options:
•
View
: display the event details.
•
Delete
: delete the event.
•
Delete all
: delete all events.
Camera
(Menu 8)
You can use the camera module embedded in your
phone to take photos and record videos.
To access this menu, press <
Menu
> in Idle mode and
select
Camera
, or press and hold
[
]
.
Taking a photo
You can take photos in various modes using the
phone. The camera produces JPEG photos.
• Do not take photos of people without their
permission.
• Do not take photos in a place where cameras are
not allowed.
• Do not take photos in a place where you may
interfere with another person’s privacy.
When you take a photo in direct sunlight or in bright
conditions, shadows may appear on the photo.
Menu functions
Camera
(Menu 8)
71
Taking a photo with the phone open
1. Access the
Camera
menu to turn on the camera.
The image to be captured appears on the display.
2. Adjust the image by aiming the camera lens at the
subject.
• Press the left soft key to access camera
options. See the next section.
• Use the keypad to change camera settings or
switch to other modes.
p. 72
3. Press [
]
to take a photo. The photo is saved in
the
Photos
folder.
Using camera options in Capture mode
In Capture mode, press the left soft key to access the
following options:
•
Record video
: switch to Record mode.
p. 74
•
Shooting mode
: take a photo in the following
modes:
Single shot
: take a photo in normal mode.
Multi shot
: take a series of action stills. Select the
number of photos the camera will take and the rate
at which the photos are taken.
Mosaic shot
: take several stills and save them in
one frame. Select the number of still images the
camera will take.
•
Effects
: change the colour tone or apply a special
effect to the photo.
•
Frames
: apply a decorative frame to the photo.
•
Timer
: set a time delay before the camera takes a
photo.
•
Go to photos
: go to the
Photos
folder.
•
Settings
: change the default settings for taking a
photo.
Size
: select an image size.
Quality
: select an image quality setting.
View finder
: select a preview screen.
4.
To Press
use photo options <
Options
>.
p. 73
delete the photo <
Delete
> and then
<
Yes
>.
return to Capture mode [ ].
72
Menu functions
ISO
: change the ISO setting, which controls the
sensitivity of your camera. For low light situations,
lower the ISO number to increase the quality.
The higher the ISO number, the faster the camera
shutter functions and the more sensitive the
camera is to light. Higher ISO settings may bring
some distortion to an image.
Spot focus
: adjust the exposure based on a
specific area of the image. Select
On
to display the
spot focus frame in the middle of the image, and
change the exposure according to the brightness of
the image fragment in the frame.
Shutter sound
: select the sound that you hear
when you press the shutter release, [
]
.
Zoom sound
: turn on or off the sound that you
hear when zooming in.
Brightness sound
: turn on or off the sound that
you hear when adjusting the image brightness.
Default name
: change the default prefix of the
photo name.
•
Camera short cuts
: view the functions of the
keys you can use.
Using the keypad in Capture mode
You can use the keypad to customise your camera
settings in Capture mode.
Keys Function
Flips the image vertically.
Shows the mirror image.
Left/Right Adjusts the brightness of the image.
Up/Down Zooms in or out.
1
Switches to Record mode.
p. 74
2
Changes the image size.
3
Changes the image quality.
4
Changes the camera mode.
5
Changes the colour tone or applies a
special effect to the photo.
6
Reduces the distortion on the image to
maximise detail and sharpness.
Menu functions
Camera
(Menu 8)
73
Using photo options
After taking a photo, press <
Options
> to access the
following options:
•
Take another
: return to Capture mode to take
another photo.
•
Send via
: send the photo via MMS, e-mail, or
Bluetooth.
•
Set as
: set the photo as your wallpaper for the
displays or as a caller ID image for a Phonebook
entry.
•
Delete
: delete the photo.
•
Rename
: change the name of the photo.
•
Go to photos
: go to the
Photos
folder.
•
Share for Bluetooth
: set whether or not to
prevent the photo from being accessed from other
Bluetooth devices.
•
Print via Bluetooth
: print the selected photo by
connecting the phone to a printer via Bluetooth.
•
Protection
: protect the photo from being deleted.
•
Properties
: view the photo properties.
Viewing a photo
1. In Capture mode, press the left soft key and select
Go to photos
.
2. Scroll to a photo and press [ ].
While viewing a photo or the photo list, press
<
Options
> to access the following options:
•
List
: return to the photo list.
•
View
: view the photo on the full screen.
•
Send via
: send the photo via MMS, e-mail, or
Bluetooth.
•
Set as
: set the photo as your wallpaper for the
displays or as a caller ID image for a Phonebook
entry.
7
Selects a decorative frame.
8
Sets the timer.
9
Goes to the
Photos
folder
Changes the preview screen.
Keys Function
74
Menu functions
•
Edit
: decorate the photo by adding emoticons or
applying a frame or special effect.
•
Delete
: delete the photo.
•
Rename
: change the name of the photo.
•
Move to favourite images
: move the photo to
the
Favourite images
folder.
•
Slide show
: display all photos in turn as a slide
show. Select the length of time for which each
photo is displayed.
•
Share for Bluetooth
: set whether or not to
prevent the photo from being accessed from other
Bluetooth devices.
•
Print via Bluetooth
: print the selected photo by
connecting the phone to a printer via Bluetooth.
•
Protection
: protect the photo from being deleted.
•
Properties
: view the photo properties.
Taking a photo with the phone closed
1. Press and hold [
]
.
2. If necessary, press [ ] to display .
3. Adjust the image by aiming the camera lens at the
subject.
5. Press [
]
to take a photo. The photo is
automatically saved in the
Photos
folder.
Recording a video
You can record a video of what is displayed on the
camera screen and save it.
Recording a video with the phone open
1. In Capture mode, press [
1
] to switch to Record
mode.
2. Adjust the image by aiming the camera lens at the
subject.
• Press the left soft key to access camera
options. See the next section.
4.
To Press
flip the image vertically [ ].
show the mirror image [ ].
adjust the brightness of
the image
[].
zoom in [ ].
Menu functions
Camera
(Menu 8)
75
• Use the keypad to change camera settings or
switch to other modes.
p. 76
3. Press [
]
to start recording.
4. Press [
]
or the right soft key to stop recording.
The video is automatically saved in the
Videos
folder.
Using camera options in Record mode
In Record mode, press the left soft key to access the
following options:
•
Take a photo
: switch to Capture mode.
p. 70
•
Effects
: change the colour tone or apply a special
effect to a video.
•
Timer
: set a time delay before the camera starts
recording.
•
Go to videos
: go to the
Videos
folder.
•
Settings
: change the following settings for
recording a video:
Recording mode
: select a video recording mode.
Select
Limit for
MMS
to record a video suitable
for an MMS message. The video clip is saved in
3GP format.
Select
Normal
to record a video within the limit of
the currently available memory.
Size
: select a frame size.
Quality
: select an image quality setting.
Audio rec.
: record audio with a video clip.
Zoom sound
: turn on or off the sound that you
hear when zooming in.
Brightness sound
: turn on or off the sound that
you hear when adjusting the video image
brightness.
Default name
: change the default prefix of the
video clip name.
•
Camcorder short cuts
: view the functions of the
keys you can use.
5.
To Press
play back the video clip [ ].
use video options the left soft key.
p. 76
delete the video clip [
C
] and then <
Yes
>.
return to Record mode the right soft key.
76
Menu functions
Using the keypad in Record mode
You can use the keypad to customise your camera
settings in Record mode:
Using video options
After recording a video clip, press the left soft key to
access the following options:
•
Record another
: return to Record mode.
•
Send via
: send the video clip via MMS, e-mail, or
Bluetooth.
•
Delete
: delete the video clip.
•
Rename
: change the name of the video clip.
•
Go to videos
: go to the
Videos
folder.
•
Share for Bluetooth
: share the selected file or all
file with other Bluetooth devices.
•
Protection
: protect the video clip from being
deleted.
•
Properties
: view the video clip properties.
Playing a video clip
Keys Function
Flips the image vertically.
Shows the mirror image.
Left/
Right
Adjusts the brightness of the image.
Up/
Down
Zooms in or out.
1
Switches to Capture mode.
p. 70
2
Changes the frame size.
3
Changes the image quality.
4
Changes the video recording mode.
5
Changes the colour tone or applies a special
effect to the video image.
6
Reduces the distortion on the image to
maximise detail and sharpness.
7
Mutes or unmutes the audio.
8
Sets the timer.
9
Goes to the
Videos
folder.
Keys Function
Menu functions
Settings
(Menu 9)
77
1. In Record mode, press the left soft key and select
Go to videos
.
2. Scroll to a video clip and press [ ].
During playback, use the following buttons on the
display:
After playing back the video clip, press the left soft key
to access the following options:
•
Play
: play the video clip.
•
Send via
: send the video clip via MMS, e-mail, or
Bluetooth.
•
Delete
: delete the video clip.
•
Rename
: change the name of the video clip.
•
Move to favourite videos
: move the video clip to
the
Favourite videos
folder.
•
Share for Bluetooth
: set whether or not to
prevent the video clip from being accessed from
other Bluetooth devices.
•
Protection
: protect the video clip from being
deleted.
•
Properties
: view the video clip properties.
Settings
(Menu 9)
Use this menu to customise your phone settings. You
can also reset the settings to their default values.
To access this menu, press <
Menu
> in Idle mode and
select
Settings
.
Time & Date
(Menu 9.1)
Use this menu to set the current time and date on
your phone. Before setting the time and date, specify
your time zone in the
World time
menu.
p. 41
•
Set time
: enter the current time.
Keys Function
Pauses or resumes playback.
Down Stops playback.
Left Skips backward through a file.
Right Skips forward through a file.
/ Adjusts the volume.
78
Menu functions
•
AM/PM
: select
AM
or
PM
in 12-hour time format.
•
Time format
: select the time format.
•
Set date
: enter the current date.
•
Date format
: select the date format.
Phone settings
(Menu 9.2)
Many different features of your phone’s system can be
customised to suit your preferences.
Language
(Menu 9.2.1)
Use this menu to select one of several languages for
the display text.
Greeting message
(Menu 9.2.2)
Use this menu to enter the greeting that is displayed
briefly when the phone is switched on.
Short cut
(Menu 9.2.3)
You can use the Navigation keys as shortcut keys to
access specific menus directly from Idle mode. Use
this menu to assign a shortcut menu to a key.
Assigning a menu to a key
1. Select a key to be used as a shortcut key.
2. Press <
Options
> and select
Change
.
3. Scroll to a menu to be assigned to the key.
4. Press <
Save
>.
Using shortcut options
Press <
Options
> to access the following options:
•
Change
: assign or change a shortcut menu.
•
Remove
: deactivate the shortcut assignment.
•
Remove all
: deactivate all shortcut assignments.
Side key
(Menu 9.2.4)
Use this menu to set what the phone does when you
press and hold [ / ] during an incoming call.
•
Mute
: mute the call ringer.
•
Reject
: reject the incoming call.
Extra settings
(Menu 9.2.5)
You can turn the automatic redialling or answering
feature on or off, and lock the exposed keys.
•
Auto redial
: set the phone to make up to ten
attempts to redial a phone number after an
unsuccessful call.
Menu functions
Settings
(Menu 9)
79
•
Anykey
answer
: answer an incoming call by
pressing any key, except [ ], <
Reject
>,
and [ / ].
When this option is not selected, you must press
[] or <
Accept
> to answer a call.
•
Voice clarity
: increase the microphone’s
sensitivity to allow the other person on the phone
to hear your voice clearly, even though you may be
whispering.
•
Active folder
: answer an incoming call by opening
the phone.
•
Cover keylock
: lock the exposed keys to keep
accidental presses from affecting the phone’s
operation with the phone closed.
Display settings
(Menu 9.3)
Use this menu to change settings for the display and
light.
Wallpaper
(Menu 9.3.1)
You can set up the idle screen on both displays.
•
Main display
: select an image to be displayed on
the main display.
•
Sub clock
: select an image or enter text to be
displayed on the external display.
Text display
(Menu 9.3.2)
You can customise the text appearance for the idle
screen.
•
Text position
: select a text position on the
display. If you don’t want to display text in Idle
mode, select
Off
.
•
Text style
: select a text style.
•
Text colour
: select a text colour.
Calendar
(Menu 9.3.3)
Use this menu to display the calendar of the current
month on the idle screen.
Skin
(Menu 9.3.4)
You can select a skin colour for Menu mode.
LCD brightness
(Menu 9.3.5)
You can adjust the brightness of the display for
varying lighting conditions.
80
Menu functions
LCD contrast
(Menu 9.3.6)
You can adjust the contrast of the display for varying
lighting conditions.
Backlight
(Menu 9.3.7)
You can select the length of time the backlight stays
on and the display is on in Dim mode, in which the
backlight is off.
•
Main LCD on
: select the length of time the
backlight is on.
•
Main LCD dim
: select the length of time the
display is in Dim mode after the backlight turns off.
After a specified time, the display turns off.
Dialing font colour
(Menu 9.3.8)
Use this menu to display numbers in colours when
entering a phone number for dialling.
Show caller information
(Menu 9.3.9)
Use this menu to show a caller’s phone number, or
name if saved in Phonebook, on the main display after
you have missed a call. You can also select
With
cover display
to show caller information on the
external display.
Sound settings
(Menu 9.4)
Use this menu to customise various sound settings.
Incoming call
(Menu 9.4.1)
Use this menu to select a volume and alert type for
incoming calls.
•
Ring tone
: select a ring tone for the call ringer.
•
Volume
: select a ringer volume.
•
Alert type
: specify how you are to be informed of
incoming calls.
Melody
: the phone rings using the selected ring
tone.
Vibration
: the phone vibrates but not rings.
Vibration then melody
: the phone vibrates three
times and then starts ringing.
Keypad tone
(Menu 9.4.2)
Use this menu to select the tone that the phone
sounds when you press a key.
You can adjust the keypad tone volume using
[/]
in Idle mode.
Menu functions
Settings
(Menu 9)
81
Message tone
(Menu 9.4.3)
Use this menu to set up the ringer for incoming
messages and e-mails.
•
Tone
: select one of several message tones.
•
Alert type
: specify how you are to be informed of
any incoming messages.
•
Repetition
: specify how often the phone informs
you of a new message.
Power on/off
(Menu 9.4.4)
Use this menu to select the melody that the phone
sounds when it is switched on or off.
Folder tone
(Menu 9.4.5)
Use this menu to select the tone that the phone
sounds when you open or close the phone.
Quiet mode
(Menu 9.4.6)
Use this menu to set how the phone acts to alert you
to a specific event in Quiet mode, instead of making
sounds.
•
Vibration
: set the phone to vibrate.
•
Mute
: mute all sound settings.
Extra tones
(Menu 9.4.7)
Use this menu to customise additional tones for the
phone.
•
Minute
minder
: set the phone to beep every
minute during an outgoing call to keep you
informed of the length of your call.
•
Connection
tone
: set the phone to beep when it
is connected to the system.
•
Alerts on call
: set the phone to beep when you
receive a new message or when the time for an
alarm comes during a call.
•
Indicative tones
: set the phone to beep when a
pop-up window appears to indicate that your
phone has completed an operation or that an error
occurs.
Network services
(Menu 9.5)
Use this menu to access network services. Please
contact your service provider to check their availability
and subscribe to them, if you wish.
Call diverting
(Menu 9.5.1)
82
Menu functions
This network service reroutes incoming calls to a
phone number that you specify.
1. Select a call diverting option:
•
Divert always
: divert all calls.
•
Busy
: divert calls when you are on another
call.
•
No
reply
: divert calls when you do not answer
the phone.
•
Unreachable
: divert calls when you are not in
an area covered by the network or when your
phone is switched off.
•
Cancel
all
: cancel all call diverting options.
2. Select the type of calls to be diverted.
3. Select
Activate
. To deactivate call diverting, select
Deactivate
.
4. Move to the
Divert to
line.
5. Enter the number to which calls are to be diverted
and press <
OK
>.
6. If you selected
No reply
, move to the
Sec
line and
select the length of time the network delays before
diverting a call.
Call barring
(Menu 9.5.2)
This network service allows you to restrict your calls.
1. Select a call barring option:
•
All
outgoing
: prohibit all outgoing calls.
•
International
: prohibit international calls.
•
International
except
to
home
: only allow
calls to numbers within the current country and
to your home country.
•
All
incoming
: prohibit incoming calls.
•
Incoming
while
abroad
: prohibit incoming
calls when you use your phone outside of your
home country.
•
Cancel
all
: cancel all call barring settings,
allowing calls to be sent and received normally.
•
Change barring password
: change the call
barring password.
2. Select the type of calls to be barred.
3. Select
Activate
. To deactivate call barring, Select
Deactivate
.
4. Enter the call barring password and press <
OK
>.
Menu functions
Settings
(Menu 9)
83
Call waiting
(Menu 9.5.3)
This network service informs you when someone is
trying to reach you while you are on another call.
1. Select the type of calls to which the call waiting
option will apply.
2. Select
Activate
. To deactivate call waiting, Select
Deactivate
.
Network selection
(Menu 9.5.4)
This network service allows you to either automatically
or manually select the network to be used while
roaming outside of your home area.
You can select a network other than your home
network only if there is a valid roaming agreement
between the two.
•
Automatic
: connect to the first available network
when roaming.
•
Manual
: select the network you want.
Caller ID
(Menu 9.5.5)
This network service allows you to prevent your phone
number from being displayed on the phone of the
person being called. However, some networks do not
allow the user to change this setting.
•
Default
: use the default setting provided by the
network.
•
Hide
number
: ensure your number does not
display on the other person’s phone.
•
Send
number
: send your number each time you
make a call.
Voice mail server
(Menu 9.5.6)
Use this menu to store the number of the voice mail
server and access your voice mails.
•
Connect to voice mail
: connect to the voice mail
server to allow you to listen to your messages. You
can also connect to the voice mail server by
pressing and holding [
1
] in Idle mode.
•
Voice server number
: edit the name and number
for the voice mail server.
You must enter the voice server number before you
can access your voice mails. Your service provider
can give you the voice server number.
84
Menu functions
Band selection
(Menu 9.5.7)
For the phone to make and receive phone calls, it
must register with an available network. Your phone
can handle any of the following types of networks:
Combined GSM 850/1900, GSM 1800, and Tri band
(GSM 850/1800/1900).
The country where you purchased your phone
determines the default band that it uses. When you
travel abroad, you may need to change to an
appropriate band.
When you select a new band, your phone
automatically searches for all available networks. Your
phone registers with a preferred network within the
band.
Bluetooth
(Menu 9.6)
Use this menu to activate the Bluetooth feature.
Using the Bluetooth feature, you can connect the
phone wirelessly to other Bluetooth devices and
exchange data with them, talk hands-free, or control
the phone remotely.
Bluetooth technology allows free wireless connections
between all Bluetooth-compliant devices within a
range of 10 meters. Since the devices communicate
using radio waves, they do not need to be in line of
sight to each other.
Setting up the Bluetooth feature
The
Bluetooth
menu provides the following options:
•
Activation
: activate or deactivate the Bluetooth
feature.
•
My devices
: search for connectable Bluetooth
devices.
•
My phone’s visibility
: allow other Bluetooth
devices to search for your phone.
•
My phone’s name
: assign a Bluetooth device
name to your phone, which is then displayed on
other devices.
• You cannot use the Bluetooth feature while using
multimedia features such as voice recorder,
camera, and MP3 player, or vice versa.
• Some devices may not be compatible with your
phone.
Menu functions
Settings
(Menu 9)
85
•
Secure mode
: determine if the phone asks for
your confirmation when other devices access your
data.
•
Bluetooth services
: display available Bluetooth
services.
Searching for and pairing with a Bluetooth
device
1. From the Bluetooth setting options, select
My
devices
.
2. Select
Search new device
.
If you have searched for devices before, the phone
displays
More devices
along with the devices you
have searched for previously. To search for new
devices, select
More devices
.
After searching, a list of devices to which you can
connect displays. The following icons indicate the
kind of device:
The colour of the icon indicates the status of the
the device:
• Grey for unpaired devices
• Blue for paired devices
• Red for devices that are currently connected to
your phone
3. Select a device.
4. Enter a Bluetooth PIN code and press <
OK
>.
This
code is used just once and you don’t need to
memorise it.
When the owner of the other device enters the
same code, pairing is complete.
Using device options
From the device list, press <
Options
> to access the
following options:
• Hands-free or
headset
• Mobile phone
• Computer • PDA
• Printer • Unknown device
Some devices, especially headsets or hands-free
car kits, may have a fixed Bluetooth PIN, such as
0000
. If the other device has a code, you must
enter it.
Options may vary depending on the paired device.
86
Menu functions
•
Connect
/
Disconnect
: connect to the currently
selected device, or end the connection.
•
Browse files
: search for data from the device and
import data directly to your phone.
•
Service list
: display available Bluetooth services
for the selected device.
•
Rename
: rename the paired device.
•
Authorize device
/
Unauthorize device
:
determine whether or not the phone asks you to
permit connection when the device tries to connect
to your phone.
•
Delete
: remove the selected device or all
displayed devices from the device list.
Sending data via Bluetooth
1. Activate the Bluetooth feature.
2. Select the application in which the item you want
to send is stored.
3. Scroll to the item you want and press <
Options
>.
4. Select
Send
via
→
Bluetooth
.
The phone searches for devices within range and
displays a list of available devices.
5. Select a device.
6. If necessary, enter the Bluetooth PIN needed for
pairing and press <
OK
>.
Receiving data via Bluetooth
To receive data via Bluetooth, your phone’s Bluetooth
feature must be active.
If an unauthorised Bluetooth device sends data to your
phone, the phone displays a confirmation message. To
receive data, press <
Yes
>.
Security
(Menu 9.7)
Use this menu to protect the phone against
unauthorised use by managing the several access
codes of your phone and SIM card.
If you enter an incorrect PIN /PIN 2 three times in
succession, the SIM card is blocked. To unblock it
you need to enter your PUK/PUK2 (Personal
Unblocking Key). The codes are supplied by your
network operator.
Menu functions
Settings
(Menu 9)
87
PIN check
(Menu 9.7.1)
The 4- to 8-digit PIN (Personal Identification Number)
protects your SIM card against unauthorised use.
When this feature is enabled, the phone requires your
PIN each time it is switched on.
Change PIN
(Menu 9.7.2)
Use this menu to change your PIN. The PIN check
feature must be enabled to use this feature.
Phone lock
(Menu 9.7.3)
This feature locks the phone from unauthorised use.
When this feature is enabled, you must enter a 4- to
8-digit phone password each time the phone is
switched on.
The password is preset to
00000000
. To change the
password, use the
Change password
menu.
Change password
(Menu 9.7.4)
Use this menu to change your phone password. The
password is preset to
00000000
.
Privacy
(Menu 9.7.5)
Use this menu to lock your media contents, including
MMS messages, images, videos, music files, and
sounds.
1. Press [ ] to check the item(s) to lock.
2. Press <
Save
> to lock the marked items.
3. Enter the phone password and press <
OK
>.
To access a locked item, you need to enter the phone
password. The password is preset to
00000000
.
SIM lock
(Menu 9.7.6)
The SIM lock feature allows your phone to work only
with the current SIM by assigning a SIM lock code. You
must enter the SIM lock code to use a different SIM
card.
FDN mode
(Menu 9.7.7)
If supported by your SIM card, Fixed Dialling Number
(FDN) mode restricts your outgoing calls to a limited
set of phone numbers. When this feature is enabled,
you can make calls only to phone numbers specified in
the FDN list.
p. 33
88
Menu functions
To activate this feature, you must enter your PIN2.
Change PIN2
(Menu 9.7.8)
If supported by your SIM card, the change PIN2
feature changes your current PIN2.
Memory status
(Menu 9.8)
Use this menu to check the amount of memory being
used for storing data in
Shared memory
,
Messages
,
File manager
,
Calendar
,
Phonebook
, and
Java
world
. You can also check the shared memory for
MMS, Email, and File manager.
Reset settings
(Menu 9.9)
Use this menu to reset the phone settings, display
settings, and sound settings individually. You can also
reset all of the settings in your phone at the same
time.
1. Press [ ] to check the setting category(ies) to
be reset.
2. Press <
Reset
> to reset the marked items.
3. Press <
Yes
> to confirm the reset.
4. Enter the phone password and press <
OK
>.
The password is preset to
00000000
. To
change the password, use the
Change
password
menu.
p. 87
Solve problems
Settings
(Menu 9)
89
Solve problems
Help and personal needs
To save the time and expense of an unnecessary service
call, perform the simple checks in this section before
contacting a service professional.
When you switch on your phone, the following
messages may appear:
“Insert SIM card”
• Be sure that the SIM card is correctly installed.
“Phone lock”
• The automatic locking function has been enabled. You
must enter the phone’s password before you can use
the phone.
“Enter PIN”
• You are using your phone for the first time. You must
enter the PIN supplied with the SIM card.
• The PIN check feature is enabled. Every time the
phone is switched on, the PIN has to be entered. To
disable this feature, use the
PIN check
menu.
“Enter PUK”
• The PIN code has been entered incorrectly three times
in succession, and the phone is now blocked. Enter the
PUK supplied by your service provider.
“No service,” “Network failure,” or “Not done”
displays
• The network connection has been lost. You may be in a
weak signal area. Move and try again.
• You are trying to access an option for which you have
no subscription with your service provider. Contact the
service provider for further details.
You have entered a number but it was not dialled
• Be sure that you have pressed [ ].
• Be sure that you have accessed the right cellular
network.
• Be sure that you have not set an outgoing call barring
option.
Your correspondent cannot reach you
• Be sure that your phone is switched on. ([ ] pressed
for more than one second.)
• Be sure that you are accessing the correct cellular
network.
• Be sure that you have not set an incoming call barring
option.
Your correspondent cannot hear you speaking
• Be sure that you have switched on the microphone.
• Be sure that you are holding the phone close enough
to your mouth. The microphone is located at the
bottom of the phone.
90
The phone starts beeping and “Battery low”
flashes on the display
• Your battery is insufficiently charged. Recharge the
battery.
The audio quality of the call is poor
• Check the signal strength indicator on the display
( ). The number of bars indicates the signal
strength from strong ( ) to weak ( ).
• Try moving the phone slightly or moving closer to a
window if you are in a building.
No number is dialled when you re-call a
Phonebook entry
• Use the Contact list feature to ensure the number has
been stored correctly.
• Re-store the number, if necessary.
If the above guidelines do not help you to solve
the problem, take note of:
• The model and serial numbers of your phone
• Your warranty details
• A clear description of the problem
Then contact your local dealer or Samsung after-sales
service.
Health and safety information
Exposure to radio frequency (RF) signals
Your wireless phone is a radio transmitter and receiver.
It is designed and manufactured not to exceed the
emission limits for exposure to radio frequency (RF)
energy set by the Federal Communications
Commission (FCC) of the U.S. Government. These
limits are part of comprehensive guidelines and
establish permitted levels of RF energy for the general
population. The guidelines are based on the safety
standards that were developed by independent
scientific organizations through periodic and through
evaluation of scientific studies.
The standards include a substantial safety margin
designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless phones employs a
unit of measurement known as Specific Absorption
Rate (SAR). The SAR limit recommended by the FCC is
1.6W/kg.
*
Health and safety information
91
SAR tests are conducted using standard operating
positions specified by the FCC with the phone
transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is
determined at the highest certified power level, the
actual SAR level of the phone while operating can be
well below the maximum value. This is because the
phone is designed to operate at multiple power levels
so as to use only the power required to reach the
network. In general, the closer you are to a wireless
base station antenna, the lower the power output of
the phone.
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that
it does not exceed the limit established by the
government adopted requirement for safe exposure.
The tests are performed in positions and locations
(e.g., at the ear and worn on the body) as required by
the FCC for each model. While there may be
differences between the SAR levels of various phones
and at various positions, they all meet the government
requirement.
The FCC has granted an Equipment Authorization for
this model phone with all reported SAR levels
evaluated as in compliance with the FCC RF exposure
guidelines. SAR information on this model phone is on
file with the FCC and can be found under the Display
Grant section of http://www.fcc.gov/oet/fccid after
searching on FCC ID printed in the label on the phone.
For body operation
For body worn operation, this model phone has been
tested and meets the FCC RF exposure guidelines
when used with a Samsung-supplied or approved
accessory designated for this product or when used
with and accessory that contains no metal and that
positions the handset a minimum from the body.
The minimum distance for this model phone is written
in the FCC certification information from the body.
None compliance with the above conditions may
violate FCC RF exposure guidelines.
* In the U.S. and Canada, the SAR limit for mobile phones
used by the public is 1.6 watts/kg (W/kg) averaged
over one gram of tissue. The standard incorporates a
substantial margin of safety to give additional
protection for the public and to account for any
variations in measurements.
92
For more Information concerning exposure to radio
frequency signals, see the following websites:
Federal Communications Commission (FCC)
http://www.fcc.gov
Cellular Telecommunications Industry Association
(CTIA):
http://www.wow-com.com
U.S.Food and Drug Administration (FDA)
http://www.fda.gov/cdrh/consumer
World Health Organization (WHO)
http://www.who.int/peh-emf/en
Precautions when using batteries
• Never use any charger or battery that is damaged
in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network’s base
station, it uses less power; talk and standby time
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
• Battery charging time depends on the remaining
battery charge, the type of battery and the charger
used. The battery can be charged and discharged
hundreds of times, but it will gradually wear out.
When the operation time (talk time and standby
time) is noticeably shorter than normal, it is time
to buy a new battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not in use,
disconnect it from the power source. Do not leave
the battery connected to a charger for more than a
week, since overcharging may shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling or
warming first.
• Do not leave the battery in hot or cold places, such
as in a car in summer or winter conditions, as you
will reduce the capacity and lifetime of the battery.
Always try to keep the battery at room
Health and safety information
93
temperature. A phone with a hot or cold battery
may temporarily not work, even when the battery
is fully charged. Li-ion batteries are particularly
affected by temperatures below 0 °C (32 °F).
• Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object (coin,
clip or pen) causes a direct connection between the
+ and – terminals of the battery (metal strips on
the battery), for example when you carry a spare
battery in a pocket or bag. Short-circuiting the
terminals may damage the battery or the object
causing the short-circuiting.
• Dispose of used batteries in accordance with local
regulations. Always recycle. Do not dispose of
batteries in a fire.
Road safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime.
But an important responsibility accompanies the
benefits of wireless phones, one that every user must
uphold.
When driving a car, driving is your first responsibility.
When using your wireless phone behind the wheel of a
car, practice good common sense and remember the
following tips:
• Get to know your wireless phone and its features,
such as speed dial and redial. If available, these
features help you to place your call without taking
your attention off the road.
• When available, use a hands-free device. If
possible, add an extra layer of convenience and
safety to your wireless phone with one of the many
hands-free accessories available today.
• Position your wireless phone within easy reach. Be
able to access your wireless phone without
removing your eyes from the road. If you get an
incoming call at an inconvenient time, let your
voice mail answer it for you.
• Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy
traffic or hazardous weather conditions. Rain,
sleet, snow, ice, and even heavy traffic can be
hazardous.
94
Health and safety information
• Do not take notes or look up phone numbers while
driving. Jotting down a To Do list or flipping
through your Address Book takes your attention
away from your primary responsibility, driving
safely.
• Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan calls when your car
will be stationary. If you need to make a call while
moving, dial only a few numbers, check the road
and your mirrors, then continue.
• Do not engage in stressful or emotional
conversations that may be distracting. Make the
people with whom you are talking aware that you
are driving and suspend conversations that have
the potential to divert your attention from the
road.
• Use your wireless phone to call for help. Dial the
emergency number in the case of fire, traffic
accident or medical emergencies. Remember, it is
a free call on your wireless phone!
• Use your wireless phone to help others in
emergencies. If you see a car accident, crime in
progress or other serious emergency where lives
are in danger, call the emergency number, as you
would want others to do for you.
• If you see a broken-down vehicle posing no serious
hazard, a broken traffic signal, a minor traffic
accident where no one appears injured, or a
vehicle you know to be stolen, call roadside
assistance or any other special non-emergency
wireless number.
Operating environment
Remember to follow any special regulations in force in
any area and always switch off your phone whenever it
is forbidden to use it, or when it may cause
interference or danger.
When connecting the phone or any accessory to
another device, read its user’s guide for detailed
safety instructions. Do not connect incompatible
products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation of
the equipment and for the safety of personnel, it is
Health and safety information
95
recommended that the equipment should only be used
in the normal operating position (held to your ear with
the antenna pointing over your shoulder).
Electronic devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against the
RF signals from your wireless phone. Consult the
manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be maintained
between a wireless phone and a pacemaker to avoid
potential interference with the pacemaker. These
recommendations are consistent with the independent
research and recommendations of Wireless Technology
Research.
Persons with pacemakers:
• should always keep the phone more than 15 cm (6
inches) from their pacemaker when the phone is
switched on.
• should not carry the phone in a breast pocket.
• should use the ear opposite the pacemaker to
minimize potential interference.
If you have any reason to suspect that interference is
taking place, switch off your phone immediately.
Hearing aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you
may wish to consult your hearing aid manufacturer to
discuss alternatives.
Other medical devices
If you use any other personal medical devices, consult
the manufacturer of your device to determine if it is
adequately shielded from external RF energy. Your
physician may be able to assist you in obtaining this
information. Switch off your phone in health care
facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care facilities
may be using equipment that could be sensitive to
external RF energy.
96
Health and safety information
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle. You should also
consult the manufacturer of any equipment that has
been added to your vehicle. You should also consult
the manufacturer of any equipment that has been
added to your vehicle.
Posted facilities
Switch off your phone in any facility where posted
notices require you to do so.
Potentially explosive environments
Switch off your phone when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause an
explosion or fire resulting in bodily injury or even
death.
Users are advised to switch off the phone while at a
refueling point (service station). Users are reminded of
the need to observe restrictions on the use of radio
equipment in fuel depots (fuel storage and distribution
areas), chemical plants or where blasting operations
are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include the
areas below deck on boats, chemical transfer or
storage facilities, vehicles using liquefied petroleum
gas (such as propane or butane), areas where the air
contains chemicals or particles, such as grain, dust or
metal powders, and any other area where you would
normally be advised to turn off your vehicle engine.
Emergency calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well as
user-programmed functions, which cannot guarantee
connection in all conditions. Therefore, you should
never rely solely on any wireless phone for essential
communications (medical emergencies, for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not be
possible on all wireless phone networks or when
Health and safety information
97
certain network services and/or phone features are in
use. Check with local service providers.
To make an emergency call:
If the phone is not on, switch it on.
1. Key in the emergency number for your present
location (for example, 911 or other official
emergency number). Emergency numbers vary by
location.
2. Press .
If certain features are in use (call barring, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult this document and your local cellular service
provider.
When making an emergency call, remember to give all
the necessary information as accurately as possible.
Remember that your phone may be the only means of
communication at the scene of an accident; do not end
the call until given permission to do so.
Other important safety information
• Only qualified personnel should service the phone
or install the phone in a vehicle. Faulty installation
or service may be dangerous and may invalidate
any warranty applicable to the device.
• Check regularly that all wireless phone equipment
in your vehicle is mounted and operating properly.
• Do not store or carry flammable liquids, gases, or
explosive materials in the same compartment as
the phone, its parts or accessories.
• For vehicles equipped with an air bag, remember
that an air bag inflates with great force. Do not
place objects, including both installed or portable
wireless equipment in the area over the air bag or
in the air bag deployment area. If wireless
equipment is improperly installed and the air bag
inflates, serious injury could result.
• Switch off your phone before boarding an aircraft.
The use of wireless phones in aircraft is illegal and
may be dangerous to the aircraft’s operation.
98
Health and safety information
• Failure to observe these instructions may lead to
the suspension or denial of telephone services to
the offender, or legal action, or both.
Care and maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for
many years:
• Keep the phone and all its parts and accessories out of
the reach of small children’s.
• Keep the phone dry. Precipitation, humidity and
liquids contain minerals that will corrode electronic
circuits.
• Do not use the phone with a wet hand. Doing so
may cause an electric shock to you or damage to
the phone.
• Do not use or store the phone in dusty, dirty areas,
as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the phone,
which may damage the phone’s electronic circuit
boards.
• Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the phone. Wipe it with
a soft cloth slightly dampened in a mild soap-and-
water solution.
• Do not paint the phone. Paint can clog the device’s
moving parts and prevent proper operation.
• Do not put the phone in or on heating devices,
such as a microwave oven, a stove or a radiator.
The phone may explode when overheated.
• Use only the supplied or an approved replacement
antenna. Unauthorized antennas or modified
accessories may damage the phone and violate
regulations governing radio devices.
Health and safety information
Settings
99
• If the phone, battery, charger or any accessory is
not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
Acknowledging special precautions
and the FCC and industry canada
notice
Cautions
Modifications not expressly approved by the party
responsible for compliance could void the user's authority
to operate the equipment.
FCC Compliance information
This device complies with Part 15 of FCC Rules. Operation
is subject to the following two conditions:
1.
This device may not cause harmful interference, and
2.
This device must accept any interference received.
Including interference that may cause undesired
operation.
Information to user
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation.
100
Health and safety information
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/ TV
technician for help.
Appendix A: CERTIFICATION
INFORMATION (SAR)
THIS MODEL PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It
is designed and manufactured not to exceed the emission
limits for exposure to radio frequency (RF) energy set by
the Federal Communications Commission of the U.S.
Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for
the general population. The guidelines are based on safety
standards that were developed by independent scientific
organizations through periodic and thorough evaluation of
scientific studies. The standards include a substantial
safety margin designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless mobile phones
employs a unit of measurement known as the Specific
Absorption Rate (SAR). The SAR limit set by the FCC is 1.6
W/kg. SAR Tests are conducted using standard operating
positions accepted by the FCC with the phone transmitting
at its highest certified power level in all tested frequency
bands. Although the SAR is determined at the highest
Health and safety information
Settings
101
certified power level, the actual SAR level of the phone
while operating can be well below the maximum value.
This is because the phone is designed to operate at
multiple power levels so as to use only the power required
to reach the network. In general, the closer you are to a
wireless base station antenna, the lower the power
output.
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that it
does not exceed the limit established by the government
adopted requirement for safe exposure. The tests are
performed in positions and locations(e.g., at the ear and
worn on the body) as required by the FCC for each model.
The highest SAR values of this model phone as reported to
FCC are GSM850 Head: 0.884W/kg, Body-worn: 0.480W/
kg; GSM1900 Head: 0.287W/kg, Body-worn: 0.250 W/kg.
Body-worn operations are restricted to Samsung-supplied,
approved or none Samsung designated accessories that
have no metal and must provide at least 1.5cm separation
between the device, including its antenna whether
extended or retracted, and the user’s body. None
compliance to the above restrictions may violate FCC RF
exposure guidelines.
The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as in
compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC
and can be found under the Display Grant section of http:/
/www.fcc.gov/oet/fccid after searching on FCC ID
A3LSGHE736.
In the United States and Canada, the SAR limit for mobile
phones used by the public is 1.6 watts/kilogram (W/kg)
averaged over one gram of tissue. The standard
incorporates a substantial ma gin of safety to give
additional protection for the public and to account for any
variations in measurements.
E730-2.fm Page 101 Tuesday, September 27, 2005 5:49 PM
102
Health and safety information
Appendix B: Guide to safe and
responsible wireless phone use
Cellular Telecommunications & Internet Association
“Safety is the most important call you will ever make.”
A guide to safe and responsible wireless phone
use
TENS OF MILLIONS OF PEOPLE IN THE U.S. TODAY TAKE
ADVANTAGE OF THE UNIQUE COMBINATION OF
CONVENIENCE, SAFETY AND VALUE DELIVERED BY THE
WIRELESS TELEPHONE. QUITE SIMPLY, THE WIRELESS
PHONE GIVES PEOPLE THE POWERFUL ABILITY TO
COMMUNICATE BY VOICE-ALMOST ANYWHERE, ANYTIME-
WITH THE BOSS, WITH A CLIENT, WITH THE KIDS, WITH
EMERGENCY PERSONNEL OR EVEN WITH THE POLICE.
EACH YEAR, AMERICANS MAKE BILLIONS OF CALLS FROM
THEIR WIRELESS PHONES, AND THE NUMBERS ARE
RAPIDLY GROWING.
But an important responsibility accompanies those
benefits, one that every wireless phone user must uphold.
When driving a car, driving is your first responsibility. A
wireless phone can be an invaluable tool, but good
judgment must be exercised at all times while driving a
motor vehicle whether on the phone or not.
The basic lessons are ones we all learned as teenagers.
Driving requires alertness, caution and courtesy. It
requires a heavy dose of basic common sense-keep your
head up, keep your eyes on the road, check your mirrors
frequently and watch out for other drivers.
It requires obeying all traffic signs and signals and staying
within the speed limit. It means using seat belts and
requiring other passengers to do the same.
But with wireless phone use, driving safely means a little
more. This brochure is a call to wireless phone users
everywhere to make safety their first priority when behind
the wheel of a car. Wireless telecommunications is keeping
us in touch, simplifying our lives, protecting us in
emergencies and providing opportunities to help others in
need. When it comes to the use of wireless phones, safety
is your most important call.
Wireless phone “Safety Tips”
Below are safety tips to follow while driving and using a
wireless phone which should be easy to remember:
Health and safety information
Settings
103
1.
Get to know your wireless phone and its features such
as speed dial and redial. Carefully read your
instruction manual and learn to take advantage of
valuable features most phones offer, including
automatic redial and memory. Also, work to memorize
the phone keypad so you can use the speed dial
function without taking your attention off the road.
2.
When available, use a hands free device. A number of
hands free wireless phone accessories are readily
available today. Whether you choose an installed
mounted device for your wireless phone or a speaker
phone accessory, take advantage of these devices if
available to you.
3.
Position your wireless phone within easy reach. Make
sure you place your wireless phone within easy reach
and where you can grab it without removing your eyes
from the road. If you get an incoming call at an
inconvenient time, if possible, let your voice mail
answer it for you.
4.
Suspend conversations during hazardous driving
conditions or situations. Let the person you are
speaking with know you are driving; if necessary,
suspend the call in heavy traffic or hazardous weather
conditions. Rain, sleet, snow and ice can be
hazardous, but so is heavy traffic. As a driver, your
first responsibility is to pay attention to the road.
5.
Do not take notes or look up phone numbers while
driving. If you are reading an address book or
business card, or writing a “to do” list while driving a
car, you are not watching where you are going. It’s
common sense. Don’t get caught in a dangerous
situation because you are reading or writing and not
paying attention to the road or nearby vehicles.
6.
Dial sensibly and assess the traffic; if possible, place
calls when you are not moving or before pulling into
traffic. Try to plan your calls before you begin your trip
or attempt to coincide your calls with times you may
be stopped at a stop sign, red light or otherwise
stationary. But if you need to dial while driving, follow
this simple tip-dial only a few numbers, check the road
and your mirrors, then continue.
7.
Do not engage in stressful or emotional conversations
that may be distracting. Stressful or emotional
conversations and driving do not mix-they are
distracting and even dangerous when you are behind
the wheel of a car. Make people you are talking with
aware you are driving and if necessary, suspend
conversations which have the potential to divert your
attention from the road.
104
Health and safety information
8.
Use your wireless phone to call for help. Your wireless
phone is one of the greatest tools you can own to
protect yourself and your family in dangerous
situations-with your phone at your side, help is only
three numbers away. Dial 9-1-1 or other local
emergency number in the case of fire, traffic accident,
road hazard or medical emergency. Remember, it is a
free call on your wireless phone!
9.
Use your wireless phone to help others in
emergencies. Your wireless phone provides you a
perfect opportunity to be a “Good Samaritan” in your
community. If you see an auto accident, crime in
progress or other serious emergency where lives are
in danger, call 9-1-1 or other local emergency number,
as you would want others to do for you.
10.
Call roadside assistance or a special wireless non
emergency assistance number when necessary.
Certain situations you encounter while driving may
require attention, but are not urgent enough to merit a
call for emergency services. But you still can use your
wireless phone to lend a hand. If you see a broken-
down vehicle posing no serious hazard, a broken traffic
signal, a minor traffic accident where no one appears
injured or a vehicle you know to be stolen, call
roadside assistance or other special non-emergency
wireless number.
Careless, distracted individuals and people driving
irresponsibly represent a hazard to everyone on the road.
Since 1984, the Cellular Telecommunications Industry
Association and the wireless industry have conducted
educational outreach to inform wireless phone users of
their responsibilities as safe drivers and good citizens. As
we approach a new century, more and more of us will take
advantage of the benefits of wireless telephones.
And, as we take to the roads, we all have a responsibility
to drive safely.
“The wireless industry reminds you to use your phone
safely when driving.”
Cellular Telecommunications & Internet Association For
more information, please call 1-888-901-SAFE.
For updates: http://www.wow-com.com/consumer/issues/
driving/articles.cfm?ID =85
Health and safety information
Settings
105
Appendix C: consumer update
on wireless phones
U.S. Food and Drug Administration
1.
What kinds of phones are the subject of this update?
The term wireless phone refers here to hand-held wireless
phones with built-in antennas, often called cell, mobile, or
PCS phones. These types of wireless phones can expose
the user to measurable radio frequency energy (RF)
because of the short distance between the phone and the
user s head. These RF exposures are limited by Federal
Communications Commission safety guidelines that were
developed with the advice of FDA and other federal health
and safety agencies. When the phone is located at greater
distances from the user, the exposure to RF is drastically
lower because a person’s RF exposure decreases rapidly
with increasing distance from the source. The so-called
“cordless phones,” which have a base unit connected to
the telephone wiring in a house, typically operate at far
lower power levels, and thus produce RF exposures well
within the FCC’s compliance limits.
2.
Do wireless phones pose a health hazard?
The available scientific evidence does not show that any
health problems are associated with using wireless
phones. There is no proof, however, that wireless phones
are absolutely safe. Wireless phones emit low levels of
radio frequency energy (RF) in the microwave range while
being used. They also emit very low levels of RF when in
the stand-by mode. Whereas high levels of RF can produce
health effects (by heating tissue), exposure to low level RF
that does not produce heating effects causes no known
adverse health effects. Many studies of low level RF
exposures have not found any biological effects. Some
studies have suggested that some biological effects may
occur, but such findings have not been confirmed by
additional research. In some cases, other researchers
have had difficulty in reproducing those studies, or in
determining the reasons for inconsistent results.
3.
What is FDA’s role concerning the safety of wireless
phones?
Under the law, FDA does not review the safety of radiation
emitting consumer products such as wireless phones
before they can be sold, as it does with new drugs or
medical devices. However, the agency has authority to
take action if wireless phones are shown to emit radio
106
Health and safety information
frequency energy (RF) at a level that is hazardous to the
user. In such a case, FDA could require the manufacturers
of wireless phones to notify users of the health hazard and
to repair, replace or recall the phones so that the hazard
no longer exists.
Although the existing scientific data do not justify FDA
regulatory actions, FDA has urged the wireless phone
industry to take a number of steps, including the
following:
• Support needed research into possible biological
effects of RF of the type emitted by wireless phones;
• Design wireless phones in a way that minimizes any
RF exposure to the user that is not necessary for
device function; and
• Cooperate in providing users of wireless phones with
the best possible information on possible effects of
wireless phone use on human health
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at the
federal level. The following agencies belong to this
working group:
• National Institute for Occupational Safety and Health
• Environmental Protection Agency Federal
Communications Commission
• Occupational Safety and Health Administration
• National Telecommunications and Information
Administration
• The National Institutes of Health participates in some
interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless phones
with the Federal Communications Commission (FCC). All
phones that are sold in the United States must comply
with FCC safety guidelines that limit RF exposure. FCC
relies on FDA and other health agencies for safety
questions about wireless phones.
FCC also regulates the base stations that the wireless
phone networks rely upon. While these base stations
operate at higher power than do the wireless phones
themselves, the RF exposures that people get from these
base stations are typically thousands of times lower than
those they can get from wireless phones. Base stations
are thus not the primary subject of the safety questions
discussed in this document.
4.
What is FDA doing to find out more about the possible
health effects of wireless phone RF?
Health and safety information
Settings
107
FDA is working with the U.S. National Toxicology Program
and with groups of investigators around the world to
ensure that high priority animal studies are conducted to
address important questions about the effects of exposure
to radio frequency energy (RF).
FDA has been a leading participant in the World Health
Organization International Electromagnetic Fields (EMF)
Project since its inception in 1996. An influential result of
this work has been the development of a detailed agenda
of research needs that has driven the establishment of
new research programs around the world. The Project has
also helped develop a series of public information
documents on EMF issues.
FDA and the Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative Research
and Development Agreement (CRADA) to do research on
wireless phone safety. FDA provides the scientific
oversight, obtaining input from experts in government,
industry, and academic organizations. CTIA-funded
research is conducted through contracts to independent
investigators. The initial research will include both
laboratory studies and studies of wireless phone users.
The CRADA will also include a broad assessment of
additional research needs in the context of the latest
research developments around the world.
5.
What steps can I take to reduce my exposure to radio
frequency energy from my wireless phone?
If there is a risk from these products—and at this point we
do not know that there is—it is probably very small. But if
you are concerned about avoiding even potential risks,
you can take a few simple steps to minimize your
exposure to radio frequency energy (RF). Since time is a
key factor in how much exposure a person receives,
reducing the amount of time spent using a wireless phone
will reduce RF exposure.
If you must conduct extended conversations by wireless
phone every day, you could place more distance between
your body and the source of the RF, since the exposure
level drops off dramatically with distance. For example,
you could use a headset and carry the wireless phone
away from your body or use a wireless phone connected to
a remote antenna
Again, the scientific data do not demonstrate that wireless
phones are harmful. But if you are concerned about the RF
exposure from these products, you can use measures like
108
Health and safety information
those described above to reduce your RF exposure from
wireless phone use.
6.
What about children using wireless phones?
The scientific evidence does not show a danger to users of
wireless phones, including children and teenagers. If you
want to take steps to lower exposure to radio frequency
energy (RF), the measures described above would apply
to children and teenagers using wireless phones. Reducing
the time of wireless phone use and increasing the distance
between the user and the RF source will reduce RF
exposure.
Some groups sponsored by other national governments
have advised that children be discouraged from using
wireless phones at all. For example, the government in the
United Kingdom distributed leaflets containing such a
recommendation in December 2000. They noted that no
evidence exists that using a wireless phone causes brain
tumors or other ill effects. Their recommendation to limit
wireless phone use by children was strictly precautionary;
it was not based on scientific evidence that any health
hazard exists.
7.
Do hands-free kits for wireless phones reduce risks
from exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that hands-free kits reduce risks. Hands-free kits
can be used with wireless phones for convenience and
comfort. These systems reduce the absorption of RF
energy in the head because the phone, which is the source
of the RF emissions, will not be placed against the head.
On the other hand, if the phone is mounted against the
waist or other part of the body during use, then that part
of the body will absorb more RF energy. Wireless phones
marketed in the U.S. are required to meet safety
requirements regardless of whether they are used against
the head or against the body. Either configuration should
result in compliance with the safety limit.
8.
Do wireless phone accessories that claim to shield the
head from RF radiation work?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that accessories that claim to shield the head from
those emissions reduce risks. Some products that claim to
shield the user from RF absorption use special phone
cases, while others involve nothing more than a metallic
accessory attached to the phone. Studies have shown that
Health and safety information
Settings
109
these products generally do not work as advertised. Unlike
“hand-free” kits, these so-called “shields” may interfere
with proper operation of the phone. The phone may be
forced to boost its power to compensate, leading to an
increase in RF absorption. In February 2002, the Federal
trade Commission (FTC) charged two companies that sold
devices that claimed to protect wireless phone users from
radiation with making false and unsubstantiated claims.
According to FTC, these defendants lacked a reasonable
basis to substantiate their claim.
9.
What about wireless phone interference with medical
equipment?
Radio frequency energy (RF) from wireless phones can
interact with some electronic devices. For this reason, FDA
helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted cardiac
pacemakers and defibrillators from wireless telephones.
This test method is now part of a standard sponsored by
the Association for the Advancement of Medical
instrumentation (AAMI). The final draft, a joint effort by
FDA, medical device manufacturers, and many other
groups, was completed in late 2000. This standard will
allow manufacturers to ensure that cardiac pacemakers
and defibrillators are safe from wireless phone EMI.
FDA has tested hearing aids for interference from
handheld wireless phones and helped develop a voluntary
standard sponsored by the Institute of Electrical and
Electronic Engineers (IEEE). This standard specifies test
methods and performance requirements for hearing aids
and wireless phones so that no interference occurs when a
person uses a compatible phone and a compatible hearing
aid at the same time. This standard was approved by the
IEEE in 2000.
FDA continues to monitor the use of wireless phones for
possible interactions with other medical devices. Should
harmful interference be found to occur, FDA will conduct
testing to assess the interference and work to resolve the
problem.
10.
What are the results of the research done already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws in their
research methods. Animal experiments investigating the
effects of radio frequency energy (RF) exposures
characteristic of wireless phones have yielded conflicting
results that often cannot be repeated in other laboratories.
110
Health and safety information
A few animal studies, however, have suggested that low
levels of RF could accelerate the development of cancer in
laboratory animals. However, many of the studies that
showed increased tumor development used animals that
had been genetically engineered or treated with cancer
causing chemicals so as to be pre-disposed to develop
cancer in the absence of RF exposure. Other studies
exposed the animals to RF for up to 22 hours per day.
These conditions are not similar to the conditions under
which people use wireless phones, so we don t know with
certainty what the results of such studies mean for human
health.
Three large epidemiology studies have been published
since December 2000. Between them, the studies
investigated any possible association between the use of
wireless phones and primary brain cancer, gioma,
meningioma, or acoustic neuroma, tumors of the brain or
salivary gland, leukemia, or other cancers. None of the
studies demonstrated the existence of any harmful health
effects from wireless phone RF exposures. However, none
of the studies can answer questions about long-term
exposures, since the average period of phone use in these
studies was around three years.
11.
What research is needed to decide whether RF
exposure from wireless phones poses a health risk?
A combination of laboratory studies and epidemiological
studies of people actually using wireless phones would
provide some of the data that are needed. Lifetime animal
exposure studies could be completed in a few years.
However, very large numbers of animals would be needed
to provide reliable proof of a cancer promoting effect if
one exists. Epidemiological studies can provide data that
is directly applicable to human populations, but 10 or
more years follow-up may be needed to provide answers
about some health effects, such as cancer. This is because
the interval between the time of exposure to a cancer-
causing agent and the time tumors develop - if they do -
may be many, many years. The interpretation of
epidemiological studies is hampered by difficulties in
measuring actual RF exposure during day-to-day use of
wireless phones. Many factors affect this measurement,
such as the angle at which the phone is held, or which
model of phone is used.
12.
Which other federal agencies have responsibilities
related to potential RF health effects?
Health and safety information
Settings
111
Additional information on the safety of RF exposures from
various sources can be obtained from the following
organizations.
FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
Occupational Safety and Health Administration’s (OSHA):
http://www.osha-slc.gov/SLTC/radiofrequencyradiation/
index.html
National Institute for Occupational Safety and Health
(NIOSH):
http://www.cdc.gov/niosh/topics/emf/
World health Organization (WHO):
http://www.who.int/peh-emf/
International Commission on Non-Ionizing Radiation
Protection:
http://www.icnirp.de
Health Protection Agency(UK):
http://www.hpa.org.uk/radiation/
Updated 4/3/2002: US Food and Drug Administration
http://www.fda/gov/cellphones
112
Index
A
ABC mode, text input • 22
Alarm • 42
Answering
call • 25
second call • 27
Anykey answer • 79
Auto redial • 78
B
Backlight time, set • 80
Band selection • 84
Barring, calls • 82
Battery
charging • 7
low indicator • 8
Bluetooth
receiving, data • 86
sending, data • 86
settings • 84
Browser, WAP • 44
C
Calculator • 42
Calendar • 66, 79
Call cost • 31
Call records
dialled • 30
missed • 30
received • 30
Call time • 31
Caller group
creating • 34
managing • 34
Caller ID • 83
Calls
answering • 25
barring • 82
diverting • 81
holding • 26
redialling • 24
rejecting • 25
transferring • 27
waiting • 83
Camera
options • 71
photos • 70
videos • 74
CB (Cell Broadcast) messages •
62
Characters, enter • 22
Conference call • 29
Connection tone • 81
Convertor • 43
Creating calendar
anniversaries • 67
events • 67
miscellaneous • 68
to-do items • 68
Creating messages
e-mail • 50
MMS • 48
SMS • 48
D
Deleting
call records • 30
e-mails • 55
events • 69
messages • 51
missed alarms • 70
phonebook 36
photos • 74
video clips • 77
Delevery report • 53
Delivery reports, message • 57
Dialled calls • 30
Display
language • 78
settings • 79
Diverting, calls • 81
DTMF tones, send • 28
E
E-mails
creating/sending • 50
deleting • 55
setting • 60
viewing • 54
F
FDN (Fixed Dialling Number)
mode
creating contact list • 33
setting • 87
File manager • 63
Forwarding
e-mails • 55
MMS messages • 52
G
Games • 40
Greeting message • 78
H
Health and safety • 90
Holding, call • 26
113
Index
I
Icons, description • 10
Images, downloaded • 63
Inbox, messages
e-mail • 54
MMS • 52
SMS • 52
International calls • 24
J
Java world • 40
K
Key tone volume • 80
Keypad tones
muting/sending • 28
selecting • 80
L
Language, select • 78
Last number, redial • 24
Locking
exposed keys • 79
media contents • 87
phone • 87
SIM card • 87
Low battery indicator • 8
M
Memory status
calendar data • 67
downloaded items • 66
games 41
phonebook 36
shared memory • 88
Message tone • 81
Messages
e-mail • 50
greeting • 78
MMS • 48
SMS • 47
Minute minder • 81
Missed alarm events • 70
Missed calls • 30
MMS messages
creating/sending • 48
deleting • 52
setting • 58
viewing • 51
MMS template
accessing • 57
saving • 49
MP3 player
downloading • 37
options • 38
playing • 37
Multi-party calls • 29
Music, downloaded • 64
Muting
key tones • 28
microphone • 27
My name card • 35
N
Names
entering • 22
searching • 32
Network band, select • 84
Network selection • 83
O
Outbox, messages • 53
Own number • 35
P
Password
call barring • 82
change• 87
phone • 87
Phone
display • 10
icons • 10
locking • 87
password • 87
resetting • 88
switching on/off • 8
unpacking • 6
Phonebook
deleting • 36
editing • 32
managing • 36
options • 32
speed-dialling • 34
Photos
deleting • 74
options • 73
taking • 70
viewing • 73
PIN, change • 87
PIN2, change • 88
Power on/off tone • 81
Printing
contact • 32
events • 69
name card • 35
photo • 73, 74
Privacy • 87
Problems, solve • 89
114
Index
Q
Quiet mode • 81
R
Received calls • 30
Received messages
e-mail • 54
Recording
videos • 74
voice memos • 39
Redialling
automatically • 78
manually • 24
Resetting phone • 88
Ringer
incoming calls • 80
messages • 81
Roaming • 83
S
Safety
information • 90
Security, calls • 86
Sent messages • 54
SIM card
inserting • 7
locking • 87
SMS messages
creating/sending • 47
deleting • 51
viewing • 51
Sound settings • 80
Sounds, downloaded • 65
Speed-dial • 34
Stopwatch • 44
Switching on/off
microphone • 27
phone • 8
T
Template
MMS 56
text • 56
Text input mode, change • 22
Text, enter • 22
Timer • 43
Tone
connect • 81
folder • 81
keypad • 80
message • 81
minute minder • 81
power on/off • 81
Transferring, calls • 27
V
Videos
deleting • 77
playing • 76
recording • 74
Voice clarity, microphone • 27
Voice mail server
connecting • 83
editing • 83
Voice memos
playing • 39
recording • 39
Voice recorder • 39
W
Waiting call • 83
WAP browser
access • 44
bookmarks • 45
cache, clear • 46
World time • 41
