Users Manual

World Wide Web

http://www.samsungmobile.com

Printed in Korea

Code No.:GH68-00000A

English. 05/2005. Rev 1.0

* Depending on the software installed or your service provider, some of the description in

this manual may not match from your phone.

* Depending on your country, your phone and accessories may appear different from the

illustrations in this manual.

SGH-E760

User’s Manual

Draft

2005. 05. 18

E760_PVO328

PRELIMARY

Important

safety

precautions

Failure to comply with the following

precautions may be dangerous or illegal.

Use road safety at all times

Do not use a hand-held phone while driving. Park

the vehicle first.

Switch off the phone when refuelling

Do not use the phone at a refuelling point (service

station) or near fuels or chemicals.

Switch off in an aircraft

Wireless phones can cause interference. Using them

in an aircraft is both illegal and dangerous.

Switch off the phone near all medical

equipment

Hospitals or health care facilities may be using

equipment that could be sensitive to external radio

frequency energy. Follow any regulations or rules in

force.

Important safety precautions

Interference

All wireless phones may be subject to interference,

which could affect their performance.

Be aware of special regulations

Meet any special regulations in force in any area and

always switch off your phone whenever it is forbidden

to use it, or when it may cause interference or danger.

Water resistance

Your phone is not water-resistant. Keep it dry.

Sensible use

Use only in the normal position (held to the ear). Avoid

unnecessary contact with the antenna when the phone

is switched on.

Emergency calls

Key in the emergency number for your present

location, then press .

Keep your phone away from small children

Keep the phone and all its parts, including accessories,

out of the reach of small children.

Accessories and batteries

Use only Samsung-approved accessories and

batteries. Use of any unauthorised accessories could

damage your phone and may be dangerous.

Qualified service

Only qualified service personnel may repair your

phone.

For more detailed safety information, see "Health and

safety information" on page 90.

• The phone could explode if the battery is

replaced with an incorrect type.

• Dispose of used batteries according to the

manufacturer’s instructions.

About this Guide

This User’s Guide provides you with condensed

information about how to use your phone. To quickly

learn the basics for your phone, please refer to “Get

started” and “Step outside the phone.”

In this guide, the following instruction icons appear:

Indicates that you need to pay careful attention

to the subsequent information regarding safety

or phone features.



Indicates that you can get more information on

the referenced page.

→

Indicates that you need to press the Navigation

keys to scroll to the specified option and then

select it.

[ ] Indicates a key on the phone. For example,

[]

< > Indicates a soft key, whose function is displayed

on the phone screen. For example, <

• Movement recognition

Your phone detects movement. It can carry out

certain commands based on how you move the

phone.

Special

features of your phone

• Camera and camcorder

Use the camera module on your

phone to take a photo or record a

video.

•MP3 player

Play MP3 music files using your

phone as a MP3 player.

Special features of your phone

•Bluetooth

Send photos, images, videos, and

other personal data, and connect

to other devices using free,

wireless Bluetooth technology.

• Get personal with photo caller

See who’s calling you when their

very own photo displays.

• Name card

Create name cards with your

number and profile. Whenever

introducing yourself to others, use

this convenient electronic name

card.

•Compase

Check the directions using a

compass.

• Multimedia Message Service (MMS)

Send and receive MMS messages with a

combination of text, images, video, and audio.

•E-mail

Send and receive e-mails with images, video, and

audio attachments.

•Java

Enjoy Java

™

-based embedded

games and download new games.

•Calendar

Keep track of your daily, weekly,

and monthly schedule.

• Voice recorder

Record memos or sounds.

Contents

Unpack 6

Make sure you have each item

Your phone 6

Buttons, features, and locations

Get started 7

First steps to operating your phone

Install and charge the phone ................................... 7

Power on or off ...................................................... 8

Keys and display .................................................... 9

Access menu functions.......................................... 11

Customise your phone .......................................... 12

Make/Answer calls................................................ 14

Step outside the phone 15

Begin with your camera, music, and other special features

Use camera ......................................................... 15

Play MP3s ........................................................... 16

Browse the web ................................................... 17

Use Phonebook .................................................... 18

Send messages.................................................... 19

View messages .................................................... 20

Use Bluetooth ...................................................... 21

Use compass ....................................................... 22

Enter text 23

ABC, T9, Number, and Symbol mode

Call functions 25

Advanced calling features

Menu functions 31

All menu options listed

Solve problems 88

Help and personal needs

Health and safety information 90

Index 97

Overview of menu functions

To access Menu mode, press <

> in Idle mode.

1 Call records



p.31

1 Current contacts

2 Missed calls

3 Dialled calls

4 Received calls

5 Delete all

6 Call time

7 Call costs



p.31



p.31



p.31



p.31



p.32



p.32



p.32

2 Phonebook



p.33

1 Contact list

2 FDN list

3 Add new contact

4 Group

5 Speed dial

6 My name card

7 Own number

8 Management

9 Service number



p.33



p.33



p.34



p.34



p.35



p.36



p.36



p.36



p.37

3 Applications



p.37

1 MP3 Player

2 Voice recorder

3 Java world

4 Games

5 World time

6 Compass

7 Alarm

8 PIM sync

9 Calculator

0 Convertor

* Timer

# Stopwatch

11 SIM-AT



p.37



p.39



p.41



p.42



p.42



p.42



p.43



p.43



p.44



p.44



p.45



p.45



p.46

4 Browser



p.46

1 Home

2 Bookmarks

3 Go to URL

4 Clear cache

5 Profile settings

6 Current profile



p.46



p.47



p.47



p.47



p.48



p.49

5 Messages



p.49

1 Create new message

2 My messages

3 Templates

4 Delete all

5 Settings

6 Broadcast messages

7 Memory status



p.49



p.52



p.58



p.59



p.59



p.64



p.65

6 File manager



p.65

1 Images

2 Videos

3 Music

4 Sounds

5 Other files

6 Memory status



p.65



p.66



p.67



p.67



p.68



p.68

7 Calendar



p.68

8 Camera



p.72

1 Take a photo

2 Record video



p.72



p.75

9 Settings



p.78

1 Time & Date

2 Phone settings

3 Display settings

4 Sound settings

5 Network services

6 Bluetooth

7 Security

8 Memory status

9 Reset settings



p.78



p.78



p.79



p.80



p.81



p.84



p.86



p.88



p.88

* Shows only if supported by your SIM

card.

Unpack

Make sure you have each item

You can obtain various accessories from

your local Samsung dealer.

Phone Travel Adapter

The items supplied with your phone

and the accessories at your Samsung

dealer may vary, depending on your

country or service provider.

Battery User’s Manual

Your phone

Buttons, features, and locations

Special

function keys

Camera key

Earpiece

Display

Power on/off/

Menu exit key

Right soft key

Microphone

Navigation keys

(Up/Down/Left/

Right)

WAP access/

Confirm key

Cancel/

Correct key

Camera

External

display

Left soft key

Headset jack

Volume keys

Dial key

Alphanumeric

keys

Get started

First steps to operating your phone

SIM card information

When you subscribe to a cellular network, you receive

a plug-in SIM (Subscriber Identity Module) card

loaded with your subscription details, such as your

PIN, and available optional services.

Install and charge the phone

Remove the battery.

If the

phone is already

on, first turn it off by

holding

[]

Insert the SIM card.

Make sure that the gold-

coloured contacts on the

card face down into the

phone.

1 2

Install the battery.

Plug the travel adapter

into the phone.

Plug the adapter into a standard AC wall outlet.

When the phone is completely charged (the battery

icon stops blinking), unplug the adapter from the

power outlet.

Get started

Low battery indicator

When the battery is low:

• a warning tone sounds,

• the battery low message displays, and

• the empty battery icon blinks.

If the battery level becomes too low, the phone

automatically turns off. Recharge your battery.

Power on or off

Remove the adapter from the phone.

Switch on

Do not turn on

the phone when

mobile phone

use is prohibited.

1. Open the phone.

2. Press and hold [ ] to turn on

the phone.

3. If necessary, enter the PIN and

press <

Switch off

1. Open the phone.

2. Press and hold [ ].

Get started

Keys and display

Key(s) Description

Perform the function indicated on the

bottom line of the display.

In Idle mode, access your favourite

menus, directly.



p. 78

In Menu mode, scroll through the menu

options.

In Idle mode, launch the Wireless

Application Protocol (WAP) browser.

In Menu mode, select the highlighted

menu option.

Delete characters from the display.

In Menu mode, return to the previous

menu level.

Key(s) Description

Send or answer a call.

In Idle mode, retrieve the recent

numbers dialled, missed, or received.

End a call.

Hold down to switch the phone on and

off.

In Menu mode, cancel input and return

the phone to Idle mode.

Enter numbers, letters, and some special

characters.

In Idle mode, hold

[1]

down to access

your voice mail server. Hold [

] down to

enter the international call prefix.

Enter special characters.

Hold [ ] down to activate or deactivate

Quiet mode. Hold [ ] down to enter a

pause between numbers.

Get started

Display

Key(s) Description

(on the left)

Adjust the phone volume.

In Idle mode, with the phone open,

adjust the keypad tone volume. With the

phone closed, hold down to activate the

external display.

(on the right)

In Idle mode, hold down to turn on the

camera.

In Camera mode, takes a photo or

records a video.

Layout

Icons

Received signal strength

Call in progress

Out of your service area; you cannot

send or receive calls

Alarm set

New text message

New multimedia message

Text and graphics

display messages,

instructions, and

information you enter.

Soft key function indicators

show the current functions

assigned to the two soft

keys.

Menu Contacts

Icons

display various icons.

Get started

Access menu functions

Icons

(continued)

New voicemail message

New e-mail received or being sent

One of the message Inboxes is full

Call diverting feature is active



p. 82

Bluetooth feature is active



p. 84

GPRS network

Home Zone, if you have registered

for the appropriate service

Office Zone, if you have registered

for the appropriate service

Call ringer set to vibrate



p. 80

Quiet mode is active



p. 81

Battery power level

* The icons shown on the display may vary, depending

on your country or service provider.

Use the soft

keys

The roles of the soft keys vary

depending on the function you are

using. The bottom line of the

display indicates their current role.

Press the left soft

key to access

Menu mode.

Press the right soft

key to access

Contact list

in the

Phonebook

menu.

Menu Contacts

Get started

Customise your phone

Select an

option

1. Press the appropriate soft key.

2. Press the Navigation keys to

move to the next or previous

option.

3. Press <

Select

> or [ ] to

confirm the function displayed

or option highlighted.

4. To exit, choose either of the

following methods.

• Press <

Back

> or [

] to

move up one level.

• Press [ ] to return to Idle

mode.

Use shortcuts

Press the number key

corresponding to the option you

want.

1. In Idle mode, press <

and select

Settings

→

Phone

settings

→

Language

2. Select a language.

1. In Idle mode, press <

and select

Settings

→

Sound

settings

→

Incoming call

→

Ringtone

2. Select a ringer category by

pressing [Left] or [Right].

3. Select the ringer melody you

want by pressing [Up] or

[Down].

4. Press <

Save

Display

language

Call ringer

melody

Get started

You can set your wallpaper for the

main or external display.

1. In Idle mode, press <

and select

Settings

→

Display

settings

→

Wallpaper

→

Main

display

2. Select an image category.

3. Select an image.

You can change the colour for the

display components, such as title

bars and highlight bars.

1. In Idle mode, press <

and select

Settings

→

Display

settings

→

Skin

2. Select a colour pattern.

Idle mode

wallpaper

Menu mode

skin colour

You can switch to Quiet mode to

avoid disturbing other people with

your phone sound.

Press and hold [ ] in Idle mode.

You can use the Navigation keys as

shortcut keys to access specific

menus directly from Idle mode.

To assign a menu to a key:

1. In Idle mode, press <

and select

Settings

→

Phone

settings

→

Short cut

2. Select a key.

3. Press <

Options

> and select

Change

4. Scroll to a menu to be assigned

to the key.

5. Press <

Save

Quiet mode

shortcuts

Make/Answer calls

You can protect the phone against

unauthorised use with a phone

password. The phone will require

the password on power-up.

1. In Idle mode, press <

and select

Settings

→

Security

→

Change

password

2. Enter the default password,

00000000

, and press <

3. Enter a new 4- to 8-digit

password and press <

4. Enter the new password again

and press <

5. Select

Phone lock

6. Select

Enable

7. Enter the password and press

Phone lock

1. In Idle mode, enter an area code

and phone number.

2. Press

[]

3. To end the call, press

[]

1. When the phone is ringing, press

[]

2. To end the call, press

[]

Press [ / ].

Make a call

Answer a call

Adjust the

volume during

a call

Step outside the phone

Begin with your camera, music, and other special features

Use camera

1. Open the phone.

2. If necessary, remove the

camera cover.

3. In Idle mode, press and hold

[ ] to turn on the camera.

4. Aim the lens at the subject and

adjust the image.

5. Press [ ] to take a photo.

The photo is saved

automatically.

6. Press [ ] to return to

Capture mode.

Take a photo

1. In Idle mode, <

> and

select

File manager

→

Images

→

Photos

2. Select

the photo you want

1. In Idle mode, press and hold

[ ] to turn on the camera.

2. Press [

] to switch to Record

mode.

3. Press [ ] to start recording.

4. Press [ ] to stop recording.

The video is saved

automatically.

5. Press the right soft key to

return to Record mode.

1. In Idle mode, <

> and

select

File manager

→

Videos

→

Video clips

2. Select the video clip you want.

View a photo

Record a video

Play a video

Step outside the phone

Play MP3s

Use these methods:

• Download from the wireless

web



p. 46

• Download from a computer

using EasyStudio II



EasyStudio II User’s Guide

• Receive via Bluetooth



p. 86

1. In Idle mode, press <

and select

Applications

→

MP3 Player

2. Press <

Options

> and select

Add to list

→

Add all

Add a

file

3. For

Add a file

, scroll to a file

and press <

Add

>. Repeat from

step 2.

Copy MP3 files

to the phone

Create a play

list

1. From the MP3 player screen,

press [ ].

2. During playback, use the

following keys:

•: Pauses or resumes

playback.

• Left: Goes back to the

previous file.

• Right: Skips to the next file.

• Up: Opens the play list.

• / : Adjusts the volume.

• Down: Stops playback.

Play MP3 file

Step outside the phone

Browse the web

Using a built-in WAP (Wireless Application Protocol)

browser, you can get easy access to the wireless web

to get a variety of up-to-date services and information

and to enjoy downloads of web content.

You can use the movement

recognition feature while playing a

music file with the phone closed.

• Move the phone to the left to

skip to the previous file.

• Move the phone to the right to

go back to the next file.

• Move the phone to down to

pause or resume playback.

• Move the phone as you would

when writing “X” to stop

playback.

Use the

movement

recognition

feature

In Idle mode, press [ ].

• To scroll through browser items,

press [Up] or [Down].

• To select an item, press < >.

• To return to the previous page,

press <

Back

> or [

• To access browser options,

press <

> and select

Launch the

browser

Navigate the

Web

Step outside the phone

Use Phonebook

To the phone’s memory:

1. In Idle mode, enter a phone

number and press [ ].

2. Select

Phone

→

a number type.

3. Specify the contact information:

Last name, First name, Mobile,

Home, Office, Fax, Other, Email,

Graphic ID, Alert, Group, and

Notes.

4. Press <

Save

> to save the

entry.

To t h e S I M c a rd :

1. In Idle mode, enter a phone

number and press [ ].

2. Select

SIM

3. Enter a name.

4. Press [ ] to save the entry.

Add an entry

1. In Idle mode, press

Contacts

2. Enter a name or scroll to an

entry.

3. Select an entry.

4. Select a number and press

[]

to dial, or press <

Options

> to

access options.

1. In Idle mode, press <

and select

Phonebook

→

name card

2. Specify your contact

information.

3. Press <

Save

> to save the

name card.

4. To send the name card to other

people, press <

Options

> and

select

Send via

→

the sending

method you want.

Find an entry

Create and

send a name

card

Step outside the phone

Send messages

1. In Idle mode, press <

and select

Messages

→

Create

new message

→

Text

message

2. Enter the message text.

3. Press <

Options

> and select

Save and send

Send only

4. Enter a destination number.

5. Press [ ] to send the

message.

1. In Idle mode, press <

and select

Messages

→

Create

new message

→

Multimedia

message

2. Select

Subject

3. Enter the message subject and

press [ ].

Send a text

message (SMS)

Send a

multimedia

message

(MMS)

4. Select

Picture & Video

Sound

and add a media file.

5. Select

Message

6. Enter the message text and

press [ ].

7. Press <

Options

> and select

Send

8. Enter a destination number.

9. Press [ ] to send the

message.

Step outside the phone

View messages

1. In Idle mode, press <

and select

Messages

→

Create

new message

→

2. Select

Subject

3. Enter the e-mail subject and

press [ ].

4. Select

Message

5. Enter the e-mail text and press

[].

6. Select

File attach

7. Add media files or other files.

8. Press <

Options

> and select

Send

9. Enter an e-mail address.

10. Press [ ] to send the

e-mail.

Send an e-mail

When a notification appears:

1. Press <

View

2. Select a message from the

Inbox.

From the Inbox:

1. In Idle mode, press <

and select

Messages

→

messages

→

Inbox

2. Select a text message.

When a notification appears:

1. Press <

View

2. Press <

Options

> and select

Retrieve

3. Select a message from the

Inbox.

View a text

message

View a

multimedia

message

Step outside the phone

Use Bluetooth

Your phone is equipped with Bluetooth technology

which enables you to connect the phone wirelessly to

other Bluetooth devices and exchange data with them,

talk hands-free, or control the phone remotely.

From the Inbox:

1. In Idle mode, press <

and select

Messages

→

messages

→

Inbox

2. Select an MMS message.

1. In Idle mode, press <

and select

Messages

→

messages

→

Email box

2. Select

Check new mail

retrieve an e-mail or a header.

3. Select an e-mail or a header.

4. If you selected a header, press

Options

> and select

Retrieve

View an e-mail

In Idle mode, press <

> and

select

Settings

→

Bluetooth

→

Activation

→

1. In Idle mode, press <

and select

Settings

→

Bluetooth

→

My devices

→

Search new device

2. Select a device.

3. Enter a Bluetooth PIN code or

the other device’s Bluetooth PIN

code, if it has one, and press

When the owner of the other

device enters the same code,

pairing is complete.

Turn on

Bluetooth

Search for and

pair with a

Bluetooth

device

Step outside the phone

Use compass

Your phone is equipped with the compass feature

which enables you to check directions.

1. Access an application.

2. Scroll to an item.

3. Press <

Options

> and select

Send

via

→

Bluetooth

4. Select a device.

5. If necessary, enter the

Bluetooth PIN and press <

To receive data via Bluetooth, your

phone’s Bluetooth feature must be

active.

If necessary, press <

Yes

> to

confirm the reception.

Send data

Receive data

1. In Idle mode, press <

and select

Applications

→

Compass

2. Press <

Cal.

Calibrate

directions

Enter text

ABC, T9, Number, and Symbol mode

You can enter text for some features such as

messaging, Phonebook, or Calendar, using ABC mode,

T9 mode, Number mode, and Symbol mode.

Changing the text input mode

The text input mode indicator appears when the cursor

is in a text field.

• Press the right soft key to change the text input

mode. ( : T9 mode, : ABC mode, :

Number mode, and : Symbolic mode)

• Press and hold [ ] to switch to Symbolic mode.

Using ABC mode

Press the appropriate key until the character you want

appears on the screen.

Tips for using ABC mode

• To enter the same letter twice or to enter a

different letter on the same key, wait for the cursor

to move to the right automatically or press [Right].

Then, enter the next letter.

Key Characters in order displayed

Upper case Lower case

. , - ? ! ’ @ : 1

A B C 2 a b c 2

D E F 3 d e f 3

G H I 4 g h i 4

J K L 5 j k l 5

M N O 6 m n o 6

P Q R S 7 p q r s 7

T U V 8 t u v 8

W X Y Z 9 w x y z 9

Enter text

• Press [ ] to change case. Lower case (No

indicator), Initial capital ( ), and Capital lock ( )

are available.

• Press [ ] to insert a space.

• Press the Navigation keys to move the cursor.

•Press [

] to delete characters one by one. Press

and hold [

] to clear the display.

Using T9 mode

T9 is a predictive text input mode that allows you to

key in any character using single keystrokes.

Entering a word in T9 mode

1. Press [

] to [

]

to start entering a word. Press

each key once for each letter.

For example, press [

], [

], and [

] to

enter HELLO in T9 mode.

T9 predicts the word that you are typing, and it

may change with each key that you press.

2. Enter the whole word before editing or deleting

characters.

3. When the word displays correctly, go to step 4.

Otherwise, press [

] to display alternative word

choices for the keys that you have pressed.

For example, OF and ME use [

] and [

4. Press [ ] to insert a space and enter the next

word.

Tips for using T9 mode

• Press [

] to enter periods or apostrophes

automatically.

• Press [ ] to change case. Lower case (No

indicator), Initial capital ( ), and Capital lock ( )

are available.

• Press [ ] to insert a space.

• Press the Navigation keys to move the cursor.

• Press [

] to delete characters one by one. Press

and hold [

] to clear the display.

Adding a new word to the T9 dictionary

This feature may not be available for some languages.

1. Enter the word that you want to add.

2. Press [

] to display alternative words for your key

presses. When there are no more alternative

words,

Spell

appears on the bottom line.

3. Press <

Spell

4. Enter the word you want using ABC mode and

press <

Using Number mode

Number mode enables you to enter numbers.

Press the keys corresponding to the digits you want.

Using Symbol mode

Symbol mode enables you to insert symbols.

Call functions

Advanced calling features

Making a call

1. In Idle mode, enter the area code and phone

number.

2. Press [ ].

Making an international call

1. In Idle mode, press and hold [

]. The

character

appears.

2. Enter the country code, area code, and phone

number, then press [ ].

Redialling recent numbers

1. In Idle mode, press [ ] to display the list of

recent numbers.

To Press

display more symbols [Up] or [Down].

select a symbol the corresponding

number key.

clear the entered symbol(s) [

insert the symbol(s) <

• Press

[

]

to clear the last digit or press and hold

[

]

to clear the whole display. You can move the

cursor to edit an incorrect digit.

• Press and hold

[ ] to enter a pause between

numbers.

Call functions

2. Scroll to the number you want and press [ ].

Making a call from Phonebook

Once you have stored a number in Phonebook, you

can dial the number by selecting it from

Phonebook.



p. 33

You can also use the speed dial feature to assign your

most frequently called numbers to specific number

keys.



p. 35

Dialling a number from the SIM card

1. In Idle mode, enter the location number for the

phone number you want and press [ ].

2. Find the number you want.

3. Press <

Dial

> or [ ] to dial the number you want.

Ending a call

Close the phone or press [ ].

Answering a call

When you receive an incoming call, the phone rings

and displays the incoming call image.

Press <

> or [ ] to answer the call.

Tips for answering a call

• When

Anykey

answer

in the

Extra

settings

menu is active, you can press any key, except for

Reject

>, [ ], or [ / ].



p. 79

• When

Active folder

in the

Extra

settings

is active, you can simply open the phone.



p. 79

• Press <

Reject

> or [ ] to reject a call.

• Press and hold [ / ] to reject the incoming call or

mute the ringer, depending on the

Side key

setting.



p. 79

Viewing missed calls

If you have missed calls, the screen displays how

many calls you have missed.

1. Press <

View

2. If necessary, scroll through the missed calls.

3. Press [ ] to dial the number you want.

Call functions

Using the headset

Use the headset to make or answer calls without

holding the phone.

Connect the headset to the jack on the left side of the

phone.

The buttons on the headset work as listed below:

Options during a call

You can access a number of functions during a call.

Adjusting the volume during a call

Use [ / ] to adjust the earpiece volume during a call.

Press [ ] to increase the volume level and [ ] to

decrease the volume level.

Using the external speaker

Use the optional external speaker to talk and listen

with the phone a short distance away. First, you must

plug the speaker into the phone.

1. During a call, press [ ] to listen and talk to the

other person hands-free. The icon appears.

2. Press [ ] again to return to normal phone

mode. The icon appears.

Placing a call on hold/Retrieving

Press <

Hold

> or <

Retrieve

> to place a call on hold

or retrieve the call.

Making a second call

You can make another call if your network supports it.

1. Press <

Hold

> to put the call on hold.

2. Make the second call in the normal way.

3. Press <

Swap

> to switch between the calls.

4. Press <

Options

> and select

End

held

call

to end

the call on hold.

5. To end the current call, press [ ].

To Press

redial the last call and hold the button twice.

answer a call the button.

end a call the button.

Call functions

Answering a second call

You can answer an incoming call while already on the

phone, if your network supports it and you have

activated the call waiting feature.



p. 83

1. Press [ ] to answer the call. The first call is

automatically put on hold.

2. Press <

Swap

> to switch between the calls.

3. Press <

Options

> and select

End

held

call

to end

the call on hold.

4. To end the current call, press [ ].

Transferring a call

You can transfer the currently active call to a caller on

hold, if your network supports it. With this option, the

two callers can talk to each other, but you are

disconnected from the call.

Press <

Options

> and select

Transfer

Using a Bluetooth headset

Use an optional Bluetooth headset to talk on the

phone without holding the phone to your ear. To use

this feature, you first need to register your headset

and connect it to the phone.



p. 84

Press <

Options

> and select

Switch to headset

Switch to phone

Using the voice clarity feature

This feature increases the microphone’s sensitivity so

that the person with when you are speaking can hear

you clearly even though you may be whispering.

Press <

Options

> and select

Voice clarity on

Voice clarity off

Switching off the microphone

(Mute mode)

You can temporarily switch off your phone’s

microphone so that the person on the phone cannot

hear you.

Press <

Options

> and select

Mute

Unmute

Call functions

Muting or sending key tones

You can turn the key tones off or on.

Press <

Options

> and select

Mute keys

Send

keys

Using Phonebook

You can access the

Phonebook

menu to locate or

store entries.



p. 33

Press <

Options

> and select

Phonebook

Sending a sequence of DTMF tones

Dual tone multi-frequency (DTMF) tones are the tones

used in phones for tone dialling.

You can send DTMF tones as a group after entering the

entire number you need to send or retrieving a

number from Phonebook. This feature is helpful for

entering a password or an account number when you

call an automated system, like a banking service.

1. When connected with a teleservice system, press

Options

> and select

Send DTMF

2. Enter the number you need to send and press

Using the messaging feature

You can create and send an SMS message or access

received messages.



p. 49

Press <

Options

> and select

Message

Using SIM services

The

SIM service

menu is available if you use a SIM

card in your phone. A SIM card provides services such

as news, weather, sports, entertainment, and location

services.

For details, see your SIM card instructions or contact

your service provider.

To communicate with answering machines or

computerised telephone systems,

Send keys

must be

selected.

Call functions

Making a multi-party call

Use this feature to allow as many as six people to join

a multi-party call, or conference call.

Your service provider must support multi-party calls

for you to use this feature.

Setting up a multi-party call

1. Call the first participant.

2. Call the second participant. The first call is

automatically put on hold.

3. Press <

Options

> and select

Join

. The first

participant is added to the multi-party call.

4. If desired, call another person or answer an

incoming call.

5. Press <

Options

> and select

Join

6. Repeat steps 4 and 5 as desired.

Having a private conversation with one

participant

1. Press <

Options

> and select

Private

2. Select a name or number from the participant list.

You can talk privately with that person, while the

other participants converse with each other.

3. To return to the multi-party call, press <

Options

and select

Join

Dropping one participant

1. Press <

Options

> and select

Remove

2. Select a name or number from the participant list.

The participant is dropped from the call, but the

call continues with the other parties.

3. Close the phone or press [ ] to end the multi-

party call.

Menu functions

All menu options listed

Call records

(Menu 1)

Use this menu to view the calls you have dialled,

received, or missed, the length of your calls, and the

cost of your calls.

To access this menu, press <

> in Idle mode and

select

Call records

Current contacts

(Menu 1.1)

This menu displays the most recent calls dialled,

received, or missed.

Accessing a call record

1. Press [Left] or [Right] to select a call type.

2. Press [Up] or [Down] to scroll to a call record.

3. Press [ ] to view the details of a call, or [ ]

to dial the number.

Using call record options

While viewing the call record list, press <

Options

> to

access the following options:

•

Details

: access the properties of the call record.

•

Call

: dial the displayed number.

•

Save as contacts

: save the phone number to

Phonebook.

•

Send message

: send an SMS or MMS message.

•

Delete

: delete the selected call record or all

records.

Missed calls

(Menu 1.2)

This menu displays the most recent calls that you did

not answer.

Dialled calls

(Menu 1.3)

This menu displays the most recent calls you have

dialled.

Received calls

(Menu 1.4)

This menu displays the most recent calls you have

received.

Menu functions

Delete all

(Menu 1.5)

Use this menu to delete all of the records in each call

type.

1. Press [ ] to check the call record(s) to be

cleared.

2. Press <

Delete

3. Press <

Yes

> to confirm the deletion.

Call time

(Menu 1.6)

This menu displays the time log for calls made and

received. The actual time invoiced by your service

provider will vary.

•

Last

call

time

: check the length of your last call.

•

Total

sent

: check the total length of all the calls

you have dialled.

•

Total

received

: check the total length of all the

calls you have received.

•

Reset timers

: reset the call timers. You need to

enter the phone password.

Call costs

(Menu 1.7)

This network feature displays the cost of calls. This

menu is available only if your SIM card supports this

feature. Note that this is not intended to be used for

billing purposes.

•

Last

call

cost

: check the cost of your last call.

•

Total

cost

: check the total cost of all of your calls.

If the total cost exceeds the maximum cost set in

Set

max

cost

, you must reset the counter before

you can make another call.

•

Max

cost

: check the maximum cost limit set in

Set

max

cost

•

Reset

counters

: reset the cost counters.

•

Set

max

cost

: set the maximum cost authorised

for your calls.

•

Price/Unit

: set the price per unit that is applied

when the cost of your calls is calculated.

The password is preset to

00000000

. You can

change this password.



p. 87

Menu functions

Phonebook

(Menu 2)

Phonebook

(Menu 2)

You can store phone numbers on your SIM card and in

your phone’s memory. The SIM card and phone’s

memory are physically separate, but they are used as

a single entity called Phonebook.

To access this menu, press <

> in Idle mode and

select

Phonebook

Contact list

(Menu 2.1)

Use this menu to search for numbers in Phonebook.

Finding an entry

1. Enter the first few letters of the name that you

want to find.

2. Select the name you want from the list.

3. Press [ ] to dial the number, or <

Options

> to

access Phonebook options.

Using Phonebook options

While viewing the contact details, press <

Options

> to

access the following options:

•

Edit

: edit the contact information.

•

Send message

: send an SMS, MMS, or e-mail

message.

•

Copy

: copy the selected number to the phone’s

memory, the SIM card, or the FDN list.

•

Send via

: send the contact via SMS, MMS, e-mail,

or Bluetooth.

•

Delete

: delete the selected contact.

•

Print via bluetooth

: print the contact information

by connecting the phone to a printer via Bluetooth.

FDN list

(Menu 2.2)

Use this menu to create a list of contacts to be used in

FDN (Fixed Dialling Number) mode, in which the

phone allows outgoing calls only to the specified

phone numbers, if your SIM card supports this

feature. You can activate FDN mode in the

FDN mode

menu.



p. 87

Press <

Contacts

> in Idle mode to quickly access this

menu.

Menu functions

Adding a contact

1. From the FDN list, press <

Options

> and select

Add

2. Enter your PIN2 and press <

3. Follow the procedure in “Storing a number on the

SIM card.”

Using contact options

You can access contact options by pressing

Options

> while viewing a contact.



p. 33

Add new contact

(Menu 2.3)

Use this menu to add a new contact to Phonebook.

Storing a number in the phone’s memory

1. Select

Phone

2. Change the settings or enter information about the

contact.

•

Last name

First name

: assign a name.

•

Mobile

Home

Office

Fax

Other

: add a

number in any category.

•

: assign an e-mail address.

•

Graphic ID

: assign an image as a caller ID

image to alert you to a call from the person.

•

Alert

: assign a ringer melody to alert you to a

call from the person.

•

Group

: assign the person to a caller group.

•

Notes

: add a memo about the person.

3. Press <

Save

> to save the contact.

Storing a number on the SIM card

1. Select

SIM

2. Enter a name and press [Down].

3. Enter a phone number and press [Down].

4. If necessary, change the location number.

5. Press <

Save

> to save the contact.

Group

(Menu 2.4)

Use this menu to organise your contacts in caller

groups.

If you select the

Graphic ID

Alert

, or

Group

line,

the contact most be saved to the phone’s memory.

Menu functions

Phonebook

(Menu 2)

Adding members to a caller group

1. Select a group.

2. Press <

Add

>. The list of contacts stored in your

phone’s memory is displayed.

3. Select a contact you want to add to the selected

group.

4. To add more members, press <

Options

> and

select

Add

→

a contact. Repeat this as desired.

Managing caller groups

While viewing the group list, press <

Options

> to

access the following options:

•

View

: display the members of the selected group.

•

Add

: add a new group.

•

Edit

: edit the properties of the selected group.

•

Send message

: send an SMS, MMS, or e-mail

message to the member(s) you want.

•

Delete

: delete the selected group or all groups.

Group members, however, are not deleted from

Phonebook.

Speed dial

(Menu 2.5)

Use this menu to assign a speed dial number (2 to 9)

for eight of your most frequently called numbers.

Assigning speed dial numbers

1. Select a key location from

. [

] is reserved

for your voice mail server.

2. Select a contact you want.

3. If the contact has more than one number, select

the number you want.

Managing speed dial entries

From the Speed dial screen, press <

Options

> to

access the following options:

•

Add

: assign a number to an unassigned key.

•

View

: display the number assigned to the key.

•

Change

: assign a different number to the

assigned key.

•

Remove

: clear the speed dial setting.

Dialling speed dial entries

Press and hold the appropriate key in Idle mode.

Menu functions

My name card

(Menu 2.6)

Use this menu to create your name card and send it to

other people.

Saving your name card

The procedure for creating your name card is the

same as the one for saving a phone number in the

phone’s memory.



p. 34

Using name card options

After saving your name card, press <

Options

> to

access the following options:

•

Edit

: edit the name card.

•

Send via

: send the name card via SMS, MMS,

e-mail, or Bluetooth.

•

Exchange namecard

: exchange name cards with

another person via Bluetooth.

•

Remove

: delete the name card.

•

Print via bluetooth

: print the name card by

connecting the phone to a printer via Bluetooth.

Own number

(Menu 2.7)

Use this feature to check your phone numbers, or to

assign a name to each of the numbers. Changes made

here do not affect the actual subscriber numbers in

your SIM card.

Management

(Menu 2.8)

Use this menu to manage Phonebook.

•

Default saving

: select a default memory location

to save contacts.

If you select

Ask on saving

, the phone will ask

you to select a memory location when saving a

number.

•

Copy all to phone

: copy all of the contacts stored

in the SIM card to the phone’s memory.

•

Sort by contacts

: sort your contacts by the first

name or last name.

•

Delete all

: delete all of the contacts from your

phone’s memory, or your SIM card.

1.Press [ ] to check the location(s) to be

cleared.

2.Press <

Delete

> and then <

Yes

Menu functions

Applications

(Menu 3)

3.Enter the phone password and press <

•

Memory status

: display the number of contacts

you have stored in Phonebook.

Service number

(Menu 2.9)

This menu is available if your SIM card supports

Service Dialling Numbers (SDN). Use this menu to

view the list of SDNs assigned by your service

provider, including emergency numbers, directory

enquiries, and voice mail numbers.

Scroll to the number you want and press <

Dial

> or

[].

Applications

(Menu 3)

Use this menu to play Java games, to play music files,

to record a voice memo, to set time zones and alarms,

or to use your phone as a compass, calculator, timer,

convertor, or stopwatch. You can also syncronise PIM

data.

To access this menu, press <

> in Idle mode and

select

Applications

MP3 Player

(Menu 3.1)

Use this menu to enjoy music. First, you need to save

MP3 files in your phone’s memory.

Downloading or receiving music files

Use these methods to save MP3 files to your phone’s

memory:

• Download from the wireless web



p. 46

• Download from a computer using the EasyStudio II

program



EasyStudio II User’s Guide

• Receive via Bluetooth



p. 86

• Copy files to the supplied memory card and insert

the card into the phone.

Creating a play list

Add MP3 files to the play list so you can play them.

1. From the MP3 player screen, press <

Options

and select

Add to list

2. Select either of the following options:

The password is preset to

00000000

. You can

change this password.



p. 87

Menu functions

•

Add all

: add all of the files in the phone’s

memory to the play list.

•

Add a file

: add a file to the play list.

3. If you selected

Add a file

, scroll to a file and press

Add

4. Press <

Back

> to go back to the MP3 player

screen.

Playing music files

From the MP3 player screen, press [ ].

During playback, use the following keys:

Using the movement recognition feature

Your phone is a motion sensitive phone. This means

that you can move the phone to perform the following

tasks, instead of keying in commands.

• Move the phone to the left to skip to the previous

file.

• Move the phone to the right to go back to the next

file.

• Move the phone down to pause or resume

playback.

• Move the phone as you would when writing “X” to

stop playback.

Using player options

From the MP3 player screen, press <

Options

> to

access the following options:

•

Play via

: select how to listen to music.

Keys Function

Pauses or resumes playback.

Left Goes to the previous file.

Right Skips to the next file.

Up Opens the play list.

/ Adjusts the volume level.

Changes an equalizer type.

Changes the repeat mode.

Switch to Shuffle mode.

Down Stops playback.

Keys Function

Menu functions

Applications

(Menu 3)

•

Send via

: send the selected files via e-mail or

Bluetooth.

•

Open play list

: display the play list.

•

Set as

: set the music file as your ringtone, alarm

melody, or a caller alert melody for a Phonebook

entry.

•

Delete

: delete the file.

•

Settings

: change the default settings for playing

music files.

Repeat

: select a repeat mode.

Shuffle

: set the MP3 player to play music in

random order.

Volume

: select a volume level.

Lock volume key

: lock [ / ] to prevent

accidental key presses from affecting playback.

Equalizer value

: select an equaliser type.

•

Properties

: access the file properties.

Using play list options

From the MP3 player screen, press [Up] to access the

play list and press <

Options

> to access the following

options:

•

Play via

: select how to listen to music.

•

Add to list

: add files to the play list.

•

Move list

: move the file to the position you want

within the play list.

•

Remove

: remove the file from the play list.

•

Remove all

: remove all files from the play list.

Voice recorder

(Menu 3.2)

Use this menu to record voice memos. A voice memo

can be up to one hour long.

Recording a voice memo

1. Press [ ] to start recording.

2. Speak into the microphone.

Press [ ] to pause or resume the recording.

3. When you finish, press <

Stop

>. The voice memo

is saved automatically.

Playing a voice memo

1. From the Voice record screen, press <

Options

and select

Go to voice list

2. Select a voice memo. The memo plays.

Menu functions

During playback, use the following keys:

Using voice memo options

From the Voice record screen, press <

Options

> to

access the following options:

•

Record

: record a new voice memo.

•

Play

: play the voice memo.

•

Send via

: send the voice memo via MMS, e-mail,

or Bluetooth.

•

Set as

: set the voice memo as your ringtone,

alarm melody, or a caller alert melody for a

Phonebook entry.

•

Delete

: delete the voice memo.

•

Rename

: change the name of the voice memo.

•

Move to favourite

: move the voice memo to the

Favourite sounds

folder.

•

Share for bluetooth

: share the selected voice

memo or all voice memos with other Bluetooth

devices.

•

Protection

: protect the voice memo from being

deleted.

•

Properties

: access the properties of the voice

memo.

•

Settings

: configure the following settings for a

voice memo:

Recording time

: select the recording time.

Volume

: select the voice memo volume to be

used during playback.

Default name

: change the default prefix of the

voice memo.

Equalizer value

: select an equalizer type.

•

Go to voice list

: go to the list of voice memos you

have recorded.

Keys Function

Pauses or resumes playback.

Left Moves backward in the voice memo.

Right Moves forward in the voice memo.

Up Returns to Record mode.

/ Adjusts the volume.

Down Stops playback.

Menu functions

Applications

(Menu 3)

Java world

(Menu 3.3)

Use this menu to access and play Java games and to

set up a profile for accessing Java services.

Using Java game options

From the Java world screen, select

Downloads

and

press <

Options

> to access the following options:

•

Launch

: launch the selected game.

•

Application settings

: set a game to be continued

when a call comes in or an alarm sounds during

the game. You can also set the phone to exchange

game information with the network while playing

an online game or when you need to connect to

the Internet.

•

Delete

: delete the selected game.

•

Properties

: access the game properties.

Configuring Java settings

You can configure profile settings for accessing Java

services.

1. From the Java world screen, select

Settings

2. Change the following settings:

•

APN

: enter the access point name.

•

: enter the user ID.

•

Password

: enter the password.

•

Proxy

: select whether or not you use a proxy

server to access network services. Depending

on this setting, options in

Proxy settings

vary.

•

Proxy settings

: provide you with the following

options:

When the proxy is set to

Enable

IP address

: enter the HTTP proxy IP address.

Port

: enter the proxy port number.

When the proxy is set to

Disable

DNS1

: enter the primary DNS address.

DNS2

: enter the secondary DNS address.

Checking memory status

You can view the total amount of memory for the Java

games as well as the amount of used memory.

From the Java world screen, select

Memory status

Menu functions

Games

(Menu 3.4)

Use this menu to play games using the movement

recognition feature.

World time

(Menu 3.5)

Use this menu to set your local time zone and find out

what time it is in another part of the world.

Setting your local time zone

1. From the world map, press [Left] or [Right] to

select the city that corresponds to your home time

zone. As the time line moves, the time and date of

the given zone display.

2. Press [ ] to save the time zone.

Viewing and setting a foreign time zone

1. From the world map, press [Down].

2. Press [Left] or [Right] to select the foreign time

zone you want.

3. Press [ ] to save the time zone.

Applying Daylight Savings Time (DST)

1. From the world map, press <

Options

> and select

Set daylight saving time

2. Press [ ] to check the time zone(s) you want.

3. Press <

Save

Compass

(Menu 3.6)

Use this menu to check the directions and change the

settings for using the compass feature.

Calibrating directions

1. From the Compass screen, select

Calibration

2. Press <

Cal.

Changing the compass settings

From the Compass screen, select

Settings

•

Coordinates

: set the standard for the calibration,

Megnetic north

North

•

Skin

: change the view mode of the compass,

General analog mode or Luminous analog mode.

Menu functions

Applications

(Menu 3)

Alarm

(Menu 3.7)

Use this menu to set alarms to sound at specific times.

Setting an alarm

1. Select the type of alarm.

2. Press [Left] or [Right] to select

and press

[Down].

3. Enter the time for the alarm to sound and press

[Down].

4. Press [Left] or [Right] to select

12-hour time format and press [Down].

5. Select a repeat option from the Repeat line.

6. Select the

Alarm tone

line and select an alarm

melody.

7. Press <

Save

> and then <

Yes

> to set the alarm.

Stopping an alarm

•Press <

> or any key to confirm the alarm.

•Press <

Snooze

> to stop the wake-up alarm for 5

minutes. You can do this a maximum of 5 times.

Setting the alarm to ring even if the phone is

off

From the Alarm screen, select

Auto power

→

If the phone is off when it is time for the alarm to ring,

the phone is switched on and sounds the alarm.

PIM sync

(Menu 3.8)

You can synchronise personal information with

corresponding PC applications by using a Widesync

program.

Creating a synchronisation profile

1. Press <

Yes

> to confirm the creating.

2. Set up the following information for the profile:

•

Profile name

: enter the setting name.

•

Sync category

: select the application(s) you

want to synchronize.

•

Sync type

: select a synchronisation type.

3. When you finished, press <

Save

Menu functions

Starting synchronization

1. Make sure that your PC has the Widesync program

installed and the phone and the PC are connected

by a USB.

2. From the PIM sync screen, select a profile and

press <

Options

3. Select

Start sync

. The synchronization begins.

Changing the PIM sync options

From the PIM Sync screen, press <

Options

> to

access the following options:

•

Start sync

: start a synchronisation by the

currently selected profile.

•

View result

: show the result of the last

synchronisation.

•

New sync profile

: create a new profile.

•

Edit sync profile

: change the properties of the

currently selected profile.

•

Delete

: delete the selected profile or all of

profiles.

Calculator

(Menu 3.9)

Use this menu to perform basic arithmetic functions,

such as addition, subtraction, multiplication, and

division.

1. Enter the first number.

Press the left soft key to insert a decimal point or

brackets.

2. Enter the operation for your calculation by pressing

the Navigation keys.

3. Enter the second number.

4. Press [ ] to view the result.

Convertor

(Menu 3.0)

Use this menu for common conversions, such as

currency and temperature.

Performing a conversion

1. Select the convertor type you want.

Press [ ] or [ ] to move the cursor

Menu functions

Applications

(Menu 3)

2. Press [Left] or [Right] to select the original unit

and press [Down].

3. Enter the value to be converted.

• Press [ ] to insert a decimal point.

• Press [ ] to change the temperature to above

zero (+) or below zero (-).

4. Press [Down].

5. Press [Left] or [Right] to select the unit you want

to convert to.

The equivalent value for the amount you entered

displays.

Using convertor options

Press <

Options

> to access the following options:

•

Clear

: clear the current values.

•

Reverse

: reverse the conversion.

•

Currency rates

: edit the currency rate list.

Timer

(Menu 3. )

Use this menu to set a period of time for the phone to

count down. The phone will sound an alarm when the

specified period of time has expired.

Starting the timer

1. Press <

Set

2. Enter the length of time you want to count down

and press <

3. Press [ ] to start counting down.

Stopping the timer

• Press <

Back

> or any key when the timer rings.

• Press [ ] on the Timer screen to stop the timer

before it rings.

Stopwatch

(Menu 3. )

Use this menu to measure elapsed time. The precision

of the stopwatch is one one-hundredth of a second.

The maximum measurement time is 10 hours.

1. Press [ ] to start the stopwatch.

2. Press [ ] to check an interval. You can repeat

this step for a total of 4 intervals.

3. To reset the stopwatch, press <

Reset

Menu functions

SIM-AT

(Menu 3.11)

This menu is available if you use a SIM card that

provides additional services, such as news, weather,

sports, entertainment, and location services. Available

services may vary, depending on your service

provider’s plans.

For details, see your SIM card instructions or contact

your service provider.

Browser

(Menu 4)

The Wireless Application Protocol (WAP) browser on

your phone allows you to access the wireless web.

Using the WAP browser, you can access up-to-date

information and a wide variety of media content, such

as wallpapers, ringtones, and music files.

To access this menu, press <

> in Idle mode and

select

Browser

Home

(Menu 4.1)

Use this menu to connect your phone to the network

and load the homepage of the wireless web service

provider. You can also press [ ] in Idle mode.

Navigating the WAP browser

Using browser menu options

Form any WAP page, press <

> and select

•

Back

: go back to the previous page.

•

Home

: go back to the homepage.

•

Exit

: exit the WAP browser.

•

Reload

: reload the current page.

To Press

scroll through browser items [Up] or [Down].

select a browser item < >.

return to the previous page <

Back

> or [

Menu functions

Browser

(Menu 4)

•

Show URL

: display the URL address of the current

webpage. You can also set the current page as the

homepage for the WAP browser.

•

About

: access version information for your WAP

browser.

Using WAP page options

From any WAP page, press [ ] to access the following

options:

•

Go to URL

: enter a URL address manually.

•

Bookmarks

: switch to the

Bookmarks

menu.



p. 47

•

Messages

: check the messages stored in the

messages

folder. You can also create and send a

new SMS message.



p. 52

•

File manager

: switch to the

File manager

menu.



p. 65

Exiting the WAP browser

Press [ ] to exit the browser.

Bookmarks

(Menu 4.2)

Use this menu to save URL addresses in order to

quickly access websites.

Adding a bookmark

1. Select an empty location.

2. Enter a name for the bookmark.

3. Enter a URL address and press [ ].

Accessing a bookmarked page

Scroll to a bookmark item and press [ ].

Using bookmark options

After saving an item, press <

Options

> to access the

following options:

•

: access the bookmarked website.

•

Edit

: edit the bookmark.

•

Delete

: delete the selected bookmark.

Go to URL

(Menu 4.3)

Use this menu to manually enter the URL address of a

website and access the website.

Clear cache

(Menu 4.4)

Use this menu to clear the cache, a temporary

memory that stores recently accessed web pages.

Menu functions

Profile settings

(Menu 4.5)

Use this menu to set up servers for the WAP browser.

Contact your service provider for details about your

setting options.

For each server, the following options are available:

•

Profile

name

: assign a name to the server profile.

•

Home

URL

: set the address of your homepage.

•

Bearer

: select a bearer for each type of network

address accessed.

•

Proxy

: select whether or not the phone uses a

proxy server to launch the WAP browser. Your

service provider can tell you if your network

requires a proxy server, and they can give you the

appropriate settings.

•

GPRS settings

: customise the following GPRS

network settings:

When the proxy is set to

Enable

Proxy IP

: enter the proxy IP address.

Proxy port

: enter the proxy port number.

APN

: enter the access point name of the GPRS

network gateway.

: enter the user ID.

Password

: enter the password.

When the proxy is set to

Disable

DNS1

: enter the primary address.

DNS2

: enter the secondary address

APN

: enter the access point name of the GPRS

network gateway.

: enter the user ID

Password

: enter the password

•

GSM settings

: customise the following GSM

network settings:

When the proxy is set to

Enable

Proxy IP

: enter the proxy IP address.

Proxy port

: enter the proxy port number.

Dial number

: enter the PPP server phone number.

: enter the user ID.

Password

: enter the password.

Data call type

: select a data call type.

Menu functions

Messages

(Menu 5)

When the proxy is set to

Disable

DNS1

: enter the primary address.

DNS2

: enter the secondary address.

Dial number

: enter the PPP server phone number.

: enter the user ID.

Password

: enter the password.

Data call type

: select a data call type.

Current profile

(Menu 4.6)

Use this menu to select a connection profile for

accessing the WAP browser.

Messages

(Menu 5)

Use the

Messages

menu to send and receive text

messages, multimedia messages, and e-mails. You

can also use WAP push message and cell broadcast

message features.

To access this menu, press <

> in Idle mode and

select

Messages

Create new message

(Menu 5.1)

Use this menu to create and send SMS, MMS, or

e-mail messages.

Text message

(Menu 5.1.1)

Short Message Service (SMS) allows you to send or

receive text messages that may include pictures,

animated images, and melodies.

1. Enter your message.

2. Press <

Options

> to access one of the following

options:

•

Insert

: add a template, Phonebook entry, or

bookmark.

•

Add picture

Add animation

Add melody

add a picture, animated image, or melody to

the message.

•

Attach

: attach a name card or calender memo.

The maximum number of characters allowed in a text

message varies by your service provider. If your

message exceeds the maximum number of characters,

the phone will split the message.

Menu functions

•

Save to

: save the message in the

Draft

folder

box.

•

Text style

: change the text attributes.

3. When you have finished, press <

Options

> and

select

Save and send

Send only

4. Enter a destination number.

To send the message to more than one recipient,

press [Down] and fill in additional destination

fields.

5. Press [ ] to send the message.

Multimedia message

(Menu 5.1.2)

Multimedia Message Service (MMS) allows you to send

or receive multimedia messages containing a

combination of text, image, video, and audio, from

phone to phone or from phone to e-mail.

1. Select the

Subject

line.

2. Enter the message subject and press [ ].

3. Select the

Picture & Video

Sound

line add a

media file.

4. Select the

Message

line.

5. Enter the message text and press [ ].

6. Press <

Options

> to access the following options:

•

Edit

: edit the message subject or text.

•

Add image

Add video

Add sound

: add

image, video, or sound file.

•

Change image

Change video

Change

sound

: change an added photo, video, or

sound.

•

Preview

: display the message you have

created.

•

Save to

: save the message in the

Draft

folder

MMS template

box.

•

Add page

: add pages. Move to each page by

pressing [Left] or [Right] on the message

screen.

•

Delete page

: delete an added page.

The maximum size allowed for an MMS message

can differ depending on the country. If you cannot

attach another file, add another page.

Menu functions

Messages

(Menu 5)

•

Edit page

: set the page duration or move the

current page to the next or previous page.

•

Attach

: attach a name card or calender data.

•

Remove subject

Remove message

: clear

the subject or text.

•

Remove picture

Remove video

Remove

sound

: remove an added photo, video, or

sound.

7. When you have finished, press <

Options

> and

select

Send

8. Enter a phone number or e-mail address.

To send the message to more than one recipient,

press [Down] and fill in additional destination

fields.

9. Press [ ] to send the message.

(Menu 5.1.3)

You can send e-mails that include text and media files,

such as images, videos, and audio. To use this feature,

you need to subscribe to an e-mail service and set up

your e-mail account and profile.



p. 63

1. Select the

Subject

line.

2. Enter the subject of your e-mail and press [ ].

3. Select the

Message

line.

4. Enter the e-mail text and press [ ].

5. Scroll to the

File attach

line.

6. Press <

Options

> to access the following options:

•

Add image

Add videos

Add sounds

Add

music

: add photos, videos, or sounds.

Depending on the file type or DRM (Digital Rights

Management) system, some files may not be able

to be forwarded

•

Other files

: add files in unsupported format.

•

Attach

: add a name card or calendar memo.

7. Press <

Options

> to access the following options:

•

Edit

: edit the subject or text.

•

View

: open the attached file.

•

Save to

: save the e-mail in the

Draft

folder

box.

•

Remove subject

Remove message

: clear

the subject or text.

•

Remove

: delete the selected attachment or all

attachments.

Menu functions

8. When you have finished, press <

Options

> and

select

Send

9. Enter an e-mail address.

To send the e-mail to more than one recipient,

press [Down] and fill in additional destination

fields.

10. Press [ ] to send the e-mail.

My messages

(Menu 5.2)

Use this menu to store all of the messages you have

received, sent, failed to send, or saved to send it later.

Inbox

(Menu 5.2.1)

This folder stores all types of the messages you have

received, except for e-mails. MMS, SMS, voicemail,

WAP push message from the WAP server, configuration

messages and cell broadcast messages are stored

here.

Configuration messages, which are send from your

service provider, contain network parameters to let

you easily apply network settings to your phone.

Viewing a message at the time of its receipt

When a message has been received, the phone alerts

you by:

• Displaying a message icon with text notification

• Sounding a tone or vibrating, depending on the

message alert setting

To read a message immediately, press <

View

> and

select a message from the Inbox.

For an MMS notification, press <

Options

> and select

Retrieve

. The message is downloaded from the MMS

server to the phone’s memory.

Viewing a message in the Inbox

The following icons may appear on the message list;

depending on the message type or status, icons may

vary:

• SMS • MMS

• MMS notification • ??? Voicemail

• Configuration • WAP push

• Delivery report

Menu functions

Messages

(Menu 5)

While viewing the message list, press <

Options

> to

access the following options:

•

View

: open the message.

•

Reply via SMS

: send a reply message via SMS.

•

Reply via MMS to

: send a reply message via

MMS.

•

Retrieve

: retrieve the MMS message from the

server.

•

Forward

: forward the message to other people.

•

Connect

: connect to the voice mail server.

•

Delete

: delete the selected message or all

messages.

•

Move to My folder

: move the message to the

folder

box.

•

Move to phone

Move to SIM

: move the

message to the phone’s memory or the SIM card.

•

Sort by

: change the sort order of the list.

•

Print via bluetooth

: print the message by

connecting the phone to a print via Bluetooth.

•

Protection

: protect the message from being

deleted.

•

Properties

: access the message properties.

Using message options

While viewing a message, press <

Options

> to access

the following options:

SMS messages

•

Reply via

: send a reply message via SMS or MMS.

•

Forward

: forward the message to other people.

•

Delete

: delete the message.

•

Move to phone

Move to SIM

: move the SMS

message to the phone’s memory or the SIM card.

•

Add to block list

: add the sender’s number to the

Block number list.

•

Cut

address

: extract URLs, e-mail addresses, or

phone numbers from the message.

• Depending on the DRM (Digital Rights

Management, you may not be able to forward

some messages. They are indicated by the

icon.

• An

icon next to a message icon indicates high

priority. A grey-coloured message icon

indicates low priority.

Menu functions

•

Cut media

: save media content from the message

into your phone’s memory.

•

Protection

: protect the message from being

deleted.

MMS messages

MMS notifications

•

Retrieve

: retrieve the MMS message.

•

Reply via SMS

: send a reply message via SMS.

•

Reply via MMS to

: send a reply message via

MMS.

•

Forward

: forward the message to another person.

•

Delete

: delete the selected message or all

messages.

•

Add to block list

: add the sender’s number to the

Block number list.

•

Cut

address

: extract URLs, e-mail addresses, or

phone numbers from the message.

•

Cut media

: save media content from the message

into your phone’s memory.

•

Protection

: protect the message from being

deleted.

•

Properties

: access the message properties.

Configuration messages

•

Install

: apply the configuration specified in the

message to your phone.

•

Cut address

: extract URLs, e-mail addresses, or

phone numbers from the message.

•

Delete

: delete the message.

WAP push messages

•

Go to URL

: connect to the URL from which the

message is sent.

•

Add to block list

: add the sender’s e-mail

address to the Block address list.

•

Delete

: delete the message.

•

Cut address

: extract URLs, e-mail addresses, or

phone numbers from the message.

•

Protection

: protect the message from being

deleted.

Delivery report messages

•

Delete

: delete the message.

•

Cut address

: extract URLs, e-mail addresses, or

phone numbers from the message.

Menu functions

Messages

(Menu 5)

•

Protection

: protect the message from being

deleted.

Cell broadcast messages

•

Save

: save the messages.

•

Delete

: delete the message.

•

Cut address

: extract URLs, e-mail addresses, or

phone numbers from the message.

Draft

(Menu 5.2.2)

This folder stores messages you have saved to send at

a later time.

Press <

Options

> to access the following options:

•

View

: open the message.

•

Edit

: edit the message.

•

Delete

: delete the selected message or all

messages.

•

Move to my folder

: move the message to the

folder

box.

•

Move to phone

Move to SIM

: move the

message to the phone’s memory or the SIM card.

•

Sort by

: change the sort order of the list.

•

Print via bluetooth

: print the message by

connecting the phone to a print via Bluetooth.

•

Protection

: protect the message from being

deleted.

•

Properties

: access the message properties.

Outbox

(Menu 5.2.3)

This folder stores messages that the phone is

attempting to send or has failed to send.

While viewing a message or the message list, press

Options

> to access the following options:

•

Cancel sending

: cancel sending the message, if

the message is being sent.

•

View

: open the message.

•

Edit

: edit the message.

•

Open file

: open the attached file.

•

Save file

: save the attached file in the phone’s

memory.

•

Forward

: forward the message to other people.

•

Send

Send again

: resend the message.

Menu functions

•

Delete

: delete the selected message or all

messages.

•

Move to my folder

: move the message to the

folder

box.

•

Move to phone

Move to SIM

: move the

message to the phone’s memory or the SIM card.

•

Sort by

: change the sort order of the list.

•

Print via bluetooth

: print the message by

connecting the phone to a printer via Bluetooth.

•

Protection

: protect the message from being

deleted.

•

Properties

: access the message properties.

Sent box

(Menu 5.2.4)

This folder stores messages that you have sent.

You can access message options by pressing

Options

> while viewing a message or the message

list.



p. 55

Email box

(Menu 5.2.5)

This folder stores e-mails that you have received.

1. Select an e-mail account.

2. Press <

Select

> when

Check new mail

displayed to get new e-mails from the server.

The phone checks for new e-mails and retrieves

received e-mails.

The following icons may appear on the message

list; depending on the e-mail states, icons may

vary:

• has not been read

• is being retrieved from the server

• has not been retrieved

3. Scroll to an e-mail or header and press [ ].

4. If the e-mail has more than one page, press [ / ]

to scroll through pages one by one.

Press and hold [ / ] to move to the first or last

page.

5. Select an attached file to view or play it.

Press [ ] or [ ] to move to the previous or next

e-mail.

icon next to a message icon indicates high

priority. A grey-coloured message icon indicates

low priority.

Menu functions

Messages

(Menu 5)

While viewing the e-mail content or e-mail list, press

Options

> to access the following options:

•

View

: open the e-mail.

•

Check new mail

: download new e-mails or

headers from the e-mail server.

•

Reply to

: send a reply message to the sender or

to all recipients.

•

Forward

: forward the e-mail.

•

Mark as read/Mark as unread

: mark the e-mail

as read or as unread.

•

Delete selected

: delete the selected e-mail from

the phone’s memory, or the phone’s memory and

the server.

•

Delete all

: delete all e-mails from the phone’s

memory, or the phone’s memory and the server.

•

Add to block list

: add the sender’s e-mail

address or the e-mail subject to the Block list.

•

Open file

: open the attached file.

•

Save file

: save the attached file in the phone’s

memory.

•

Delete all

: delete all e-mails.

•

Move to My Folders

: move the retrieved e-mail

to the

My folder

box.

•

Sort by

: change the sort order of the list.

•

Protection

: protect the e-mail from being deleted.

•

Properties

: access the e-mail properties.

While viewing a header or e-mail, press <

Options

> to

access the following options:

•

Retrieve

: retrieve the body of the e-mail.

•

Reply to

: send a reply message to the sender or

to all recipients.

•

Forward

: forward the e-mail to other people.

•

Mark as read/Mark as unread

: mark the

selected e-mail or all e-mails as read or as unread.

•

Delete

: delete the e-mail.

•

Add to block list

: add the sender’s e-mail

address or the e-mail subject to the Block list.

•

Cut address

: extract e-mail addresses, URLs, and

phone numbers from the e-mail.

Options may vary, depending on the status of the

e-mail.

Menu functions

•

Cut attachment

: save the attachments from the

e-mail into your phone’s memory.

•

Protection

: protect the e-mail from being deleted.

•

Properties

: access the e-mail properties.

My folder

(Menu 5.2.6)

Use this menu to view the message you have moved

using the

Move to My folder

option while reading a

message.

While viewing the message list, press <

Options

> to

access the following options:

•

View

: open the message.

•

Edit

: edit the message.

•

Send

: send the message.

•

Delete

: delete the selected message or all

messages.

•

Sort by

: change the sort order of list.

•

Protection

: protect the message from being

deleted.

•

Properties

: access the message properties.

Templates

(Menu 5.3)

Use this menu to create, edit, or send text or

multimedia templates.

Text template

(Menu 5.3.1)

Use this menu to preset frequently used text

messages.

From the template list, press <

Options

> to access

the following options:

•

Edit

: edit the template.

•

Send message

: send the template as an SMS,

MMS, or e-mail.

•

Add new

: add a new template.

•

Delete

: delete the template.

MMS template

(Menu 5.3.2)

When you access this menu, you can view the list of

templates.

From the template list, press <

Options

> to access

the following options:

•

View

: open the template.

Menu functions

Messages

(Menu 5)

•

Send

: send the template as an MMS message.

•

Edit

: edit the template.

•

New

: add a new template.

•

Delete

: delete the selected template or all

templates.

Delete all

(Menu 5.4)

Use this menu to delete all of the messages in each

message folder one by at once.

1. Press [ ] to check the message box(es) you

want.

2. Press <

Delete

3. Press <

Yes

> to confirm the election.

Settings

(Menu 5.5)

Use this menu to set up various options for using the

messaging service.

Text message

(Menu 5.5.1)

You can configure the SMS settings.

•

Send settings

: set up the following options:

Reply path

: allow the recipient to reply to you

through your message centre.

Delivery report

: set the network to inform you

when your message has been delivered.

Character support

: select a character encoding

type. If you select

Auto

, the phone switches the

encoding type from

GSM-alphabet

Unicode

you enter a

Unicode

character. Use of

Unicode

encoding will reduce the maximum number of

characters in a message to about half.

If this menu is not shown, your phone provides the

Auto

character encoding by default.

Bearer

: select a bearer type.

Validity period

: set the length of time your

messages are stored in the SMS centre.

Message type

: set the default message type.

Service centre

: store or change the number of

your message centre.

•

Block number

: specify phone numbers from

which messages will not be accepted.

Menu functions

•

SMS profile

: set the following properties in a

profile:

Service centre

: store or change the number of

your message centre.

Default destination

: set the default destination

number.

Default type

: set the default message type.

Validity period

: set the length of time your

messages are stored in the SMS centre.

Setting name

: enter a profile name.

•

Block address

: specify e-mail addresses from

which messages will not be accepted.

Multimedia message

(Menu 5.5.2)

You can configure the MMS settings.

•

Send settings

: set up the following options for

sending MMS messages:

Priority

: set the priority level of your outgoing

messages.

Validity period

: set the length of time your

messages are stored in the MMS centre.

Delivery after

: set a time delay before messages

are sent.

Address hiding

: set your address to be hidden

from the recipient’s phone.

Delivery report

: set the network to inform you

when your message has been delivered.

Read reply

: determine whether or not the phone

sends a read-reply request.

•

Receive settings

: set up the following options for

receiving multimedia messages:

Home reception

: determine if your phone

retrieves new messages automatically when you

are in your home service area.

Roaming reception

: determine if your phone

retrieves new messages automatically when you

are roaming in another network.

Home reception and Roaming reception have the

following options:

Automatic

: the phone automatically retrieves

messages from the server.

Reject

: the phone rejects all messages.

Menu functions

Messages

(Menu 5)

Manual

: the phone displays notifications. Use

the

Retrieve

option to manually download new

messages.

Anonymous reject

: reject messages from

anonymous senders.

Adverts reject

: reject advertisements.

Report allowed

: send a delivery report from the

network to the sender.

•

Block number

: specify phone numbers from

which messages will not be accepted.

•

MMS profiles

: configure required network

settings for MMS.

Current profile

: select a connection profile to be

used for MMS.

Profile settings

: customise the following options

for each profile:

Profile name

: assign a name to the MMS profile.

Server URL

: enter the address of your MMS

server.

Proxy

: connect to the GPRS network using the

proxy server.

GPRS settings

: customise the settings required

for connecting to the GPRS network.

IP address

: (when the proxy is set to

Enable

)

enter the IP address.

Port

: (when the proxy is set to

Enable

) enter

the port number.

DNS1

: (when the proxy is set to

Disable

)

enter the primary address.

DNS2

: (when the proxy is set to

Disable

)

enter the secondary address.

APN

: enter the access point name used for the

address of the GPRS network.

: enter the user ID.

Password

: enter the password.

•

Version

: select an available OMA version and

maximum size limit for sending or receiving

messages.

Depending on your service provider, it may not be

possible to support the maximum limit 295KB. In

this case, try again after changing the setting to

100KB.

Menu functions

(Menu 5.5.3)

You can configure the e-mail settings.

•

Send settings

: set up the following options for

sending e-mails.

Send copy to self

: send a copy of your e-mail to

your own e-mail address.

Delivery confirm

: set the network to inform you

when your e-mail has been delivered.

Read confirm

: send a request for a reply along

with your e-mail.

Priority

: select the priority level of your outgoing

e-mail.

Include signature

: select to attach your name,

phone number, or a simple memo to your e-mail.

Edit name

: enter your name.

Edit telephone number

: enter your phone

number.

Edit note

: enter a simple memo.

•

Receive settings

: set up the following options for

receiving e-mails.

Check interval

: determine how often the phone

checks the server for incoming e-mails.

If you set this option to

Not used

, you can use the

Check new mail

feature to check your e-mail

manually.

Read reply

: determine whether or not the phone

sends a read-reply request.

When this option is set to

Announce

, the phone

reminds you to send a read-reply request with

your e-mail address.

Retrieve option

: determine whether the phone

retrieves headers only or the entire e-mail.

Delete option

: determine whether e-mails are

deleted immediately or the next time you connect

to the server.

Reject if over

: determine the maximum size for

incoming e-mails. Your phone will reject e-mails

that exceed the specified size.

Leave a copy of messages on the server

: leave

copies of e-mails after retrieving.

Menu functions

Messages

(Menu 5)

•

Block list

: specify e-mail addresses from which

messages will not be accepted. You can also

specify message subjects that you will not accept.

•

Email account

: set up your e-mail account(s) and

select the one to be used:

Current account

: select an account to be used for

e-mails.

Account settings

: configure up to five e-mail

accounts using different e-mail servers.

The following options are available for each

account:

In use

: select this option to use the account and

to display the account in the

E-mail box

Account name

: enter a name for the currently

selected account.

User name

: enter a name to be displayed as the

sender’s name in your outgoing e-mails.

Email address

: enter your e-mail address.

Reply address

: enter the e-mail address to

which you want recipients to send reply

messages.

User ID

: enter your e-mail ID.

Password

: enter your e-mail password.

SMTP server

: enter the IP address or domain

name of the outgoing e-mail server.

SMTP port

: enter the SMTP port number.

Protocol type

: select the protocol for the

incoming e-mail server. The remaining options

depend on the protocol type setting.

When the protocol type is

POP3

POP3 server

enter the IP address or domain

name of the server that receives your e-mail.

POP3 port

: enter the POP3 port number.

APOP login

: connect to the server by using the

APOP login scheme when this option is selected.

When the protocol type is

IMAP4

IMAP4 server

: enter the IP address or domain

name of the server that receives your e-mail.

IMAP4 port

: enter the IMAP4 port number.

Include attachments

: select this option to

receive attachments with e-mails.

Menu functions

MAX retrieve E-mail

: set the number of

headers you will retrieve from the server.

•

Email profile

: configure the network settings

required to send or receive e-mails.

Current profile

: select a profile to be used for

e-mails.

Profile settings

: configure up to five e-mail

profiles. For each profile, the following options are

required to connect to the GPRS network:

Profile name

: enter a name for the e-mail

profile.

APN

: enter the access point name used for the

GPRS network address.

: enter the user ID.

Password

: enter the password.

DNS1

: enter the primary address.

DNS2

: enter the secondary address.

Push message

(Menu 5.5.4)

You can change the settings for receiving WAP push

messages from the wireless web server. The following

options are available:

•

Receive

: set how your phone receives WAP push

messages.

•

Service centre

: specify the address of the server

from which you want to receive WAP push

messages.

Broadcast messages

(Menu 5.6)

The Cell Broadcast service delivers short messages on

various topics, such as weather, sports, or traffic.

Use this menu to change the settings for the service

and to access broadcast messages.

•

Read

: open received messages.

The

Temporary

box saves network messages until

the phone is switched off.

The

Archive

box when a text

notification appears.

•

Receive

: enable or disable the reception of

broadcast messages.

Menu functions

File manager

(Menu 6)

•

Channel

: specify the channels from which you

receive broadcast messages.

•

Language

: select the language in which broadcast

messages display.

Please contact your service provider for details.

Memory status

(Menu 5.7)

Use this menu to view the maximum memory and

available memory for each message type. You can also

view the memory currently in use in each folder.

File manager

(Menu 6)

The

File manager

menu allows you to access images,

videos, music files, sound files, and other files stored

in the phone’s memory.

To access this menu, press <

> in Idle mode and

select

File manager

Images

(Menu 6.1)

This menu displays photos you have taken and images

downloaded or received in messages.

Viewing an image

1. Select an image folder.

2. Scroll to an image and press [ ].

Using image options

While viewing an image, press <

Options

> to access

the following options:

•

List

: go to the image list.

•

Send via

: send the photo via MMS, e-mail, or

Bluetooth.

•

Set as

: set the photo as your wallpaper for the

external or main display, or as a caller ID image for

a Phonebook entry.

•

Edit

: decorate the photo by adding emoticons or

applying a frame or special effect.

•

Delete

: delete the file.

•

Rename

: change the name of the file.

According to the DRM (Digital Rights Management)

system, web content may not be able to be forwarded.

The content is indicated by the

icon

Menu functions

•

Move to favourite images

: move the file to the

Favourite images

folder.

•

Slide show

: set all images to display as a slide

show.

•

Share for bluetooth

: share the selected file or all

files with other Bluetooth devices.

•

Print via

: print the photo by connecting the phone

to a printer via Bluetooth or USB cable.

•

Protection

: protect the photo from being deleted.

•

Properties

: access the file properties.

Videos

(Menu 6.2)

This menu displays video clips you have recorded,

downloaded, or received in messages.

Playing a video clip

1. Select a video folder.

2. Scroll to a video clip and press [ ].

During playback, you can use the following keys:

Using video options

From the play screen, press <

Options

> to access the

following options.

•

Play

: play the file.

•

Send via

: send the file via MMS, e-mail, or

Bluetooth.

•

Delete

: delete the selected file or all files.

•

Rename

: change the name of the file.

•

Move to favourite videos

: move the file to the

Favourite videos

folder.

Video clips recorded on other devices, such as

camcorders, may not play correctly.

Keys Function

Pauses or resumes playback.

Up Opens the play list.

Left Move backward in a file when held down.

Right Skips forward in a file when held down.

Down Stops playback.

Menu functions

File manager

(Menu 6)

•

Share for bluetooth

: share the selected file or all

files with other Bluetooth devices.

•

Protection

: protect the file from being deleted.

•

Properties

: access the file properties.

Music

(Menu 6.3)

This menu displays music files you have downloaded,

received in messages, or imported from your

computer.

Playing a music file

Scroll to a file and press [ ].



p. 38

Using music options

From the player screen, press <

Options

> to access

the options.



p. 38

Sounds

(Menu 6.4)

This menu displays sound files you have recorded,

downloaded, or received in messages.

Playing a sound clip

1. Select a sound folder.

To access voice memos, scroll to the

Voice

memos

folder.



p. 39

2. Scroll to a clip and press [ ].



p. 39

During playback, you can use the following keys:

Using sound options

From the player screen, press <

Options

> to access

options.



p. 38

Keys Function

Pauses or resumes playback.

Left Moves backward in a file.

Right Moves forward in a file.

/ Adjusts the volume.

Down Stops playback.

Menu functions

Other files

(Menu 6.5)

Files that you have received but which are not

supported by your phone are stored in this folder. You

cannot open these files on the phone. Unsupported file

formats include *.doc, *.ppt, and *.txt.

While viewing the file list, press <

Options

> to access

the following options:

•

Send via

: send the file via e-mail or Bluetooth.

•

Delete

: delete the selected file or all files.

•

Rename

: change the name of the file.

•

Share for bluetooth

: share the selected file or all

files with other Bluetooth devices.

•

Protection

: protect the file from being deleted.

•

Properties

: access the file properties.

Memory status

(Menu 6.6)

You can check the total amount of memory for media

items and the amount of memory currently in use in

each media box.

Calendar

(Menu 7)

The calendar feature enables you to keep track of your

schedule and task, and to view missed alarm events.

To access this menu, press <

> in Idle mode and

select

Calendar

Consulting the calendar

When you enter the

Calendar

menu, the calendar in

Month view appears with today’s date highlighted.

The number of events for the specific day appears at

the bottom of the calendar. The following icons

indicate the type of event:

Press <

Options

> to access the following options:

•

View mode

: change the view mode of the

calendar.

•

Create

: add a new event.

•

Go to

: go to the current date or a specific date.

• Scheduled event • Anniversary

• Task • Miscellaneous

Menu functions

Calendar

(Menu 7)

•

Sort by

: sort items by the type of event.

•

Delete

: access the following deleting options:

Selected

: delete the items stored on the currently

selected date.

: delete the items stored on the specific

dates.

This month

: delete all of the items stored on the

current month.

All

: delete all events.

•

Missed alarm events

: view events whose alarms

you have missed.

•

Memory status

: access the memory status for

items stored in the phone’s memory.

Creating an event

You can schedule events on the calendar.

Entering a new scheduled event

1. Scroll to a date on the calendar.

2. Press <

Options

> and select

Create

→

Schedule

Miscellaneous

3. Enter information or change the settings in the

following entry fields:

•

Subject

: enter the event subject.

•

Details

: enter event details.

•

Start date

and

Start time

: enter the starting

date and time for the event.

•

AM/PM

: select

in 12-hour time

format.

•

End date

and

End time

: enter the ending date

and time for the event.

•

AM/PM

: select

in 12-hour time

format.

•

Location

: (for

Schedule

) enter information

about the event location.

•

Alarm

: select to set an alarm for the event and

set the time for the alarm. You can also select

an alarm tone.

•

Repeat

: (for

Schedule

) select to set the event

to recur. You can select a repeat unit and set

the date to end repeating.

4. Press <

Save

> to save the event.

Menu functions

Entering a new anniversary

1. Select a date on the calendar.

2. Press <

Options

> and select

Create

→

Anniversary

3. Enter information or change the settings in the

following entry fields:

•

Occasion

: enter information about the

anniversary.

•

Date

: enter the date.

•

Alarm

: select to set an alarm for the

anniversary. You can set the number of days

before the event date, the time for the alarm to

sound, and an alarm tone.

•

AM/PM

: select

in 12-hour time

format.

•

Repeat every year

: select to set the phone to

remind you of the anniversary every year.

4. Press <

Save

> to save the event.

Entering a task

1. Select a date on the calendar.

2. Press <

Options

> and select

Create

→

To do

3. Enter information or change the settings in the

following entry fields:

•

To do

: enter information about the task.

•

Start date

: enter the starting date.

•

Due date

: enter the ending date.

•

Priority

: select a priority level of the task.

4. Press <

Save

> to save the event.

Viewing an event

Square brackets on a calendar date indicate the

following type of events scheduled for that day:

1. Select a date on the calendar to display the events

for the day.

2. Select an event to view its details.

While viewing an event, press <

Options

> to access

the following options:

•

Edit

: edit the event.

• Blue: Scheduled event • Orange: Anniversary

• Red: Task • Green: Miscellaneous

Menu functions

Calendar

(Menu 7)

•

Create

: add a new event.

•

Send via

: send the event via SMS, MMS,

e-mail, or Bluetooth.

•

View mode

: change the view mode of the

calendar.

•

Done

Undone

: change the status of the selected

task.

•

Delete

: delete the event.

•

Print via bluetooth

: print the selected event by

connecting the phone to a printer via Bluetooth.

Viewing an event in different mode

By default, the calendar appears in Month view mode.

Press <

Options

> and select

View mode

to change

the mode.

Day view

You can view events for the selected date. Select an

event to view its details.

The following icons will be displayed according to the

event’s type and status:

• Alarm set

• Recurring event

• Completed to-do item

• To-do priority; its colour indicates the priority

level (Red: high, Blue: normal, and Grey: low)

Week view

You can view miscellaneous and scheduled events for

the selected week.

A cell on the timetable indicates the presence of event

information. Select the cell that contains the event you

want.

Viewing a

missed alarm event

When you are unable to acknowledge an alarm, the

phone displays a missed alarm notification.

• Press <

View

> to view the corresponding event.

• Press <

Exit

Accessing missed alarm events

1. Press <

Options

> and select

Missed alarm

events

2. Select an event.

Menu functions

Using missed alarm options

From the event list, press <

Options

> to access the

following options:

•

View

: display the event details.

•

Delete

: delete the event.

•

Delete all

: delete all events.

Camera

(Menu 8)

You can use the camera module embedded in your

phone to take photos and record videos.

To access this menu, press <

> in Idle mode and

select

Camera

, or press and hold

[

]

Take a photo

(Menu 8.1)

You can take photos in various modes using the

phone. The camera produces JPEG photos.

Taking a photo with the phone open

1. If necessary, remove the camera cover.

2. Access the take a photo menu or press and hold

[

]

to turn on the camera.

The image to be captured appears on the display.

3. Adjust the image by aiming the camera lens at the

subject.

• Press the left soft key to access camera

options. See the next section.

• Use the keypad to change camera settings or

switch to other modes.

4. Press [

]

to take a photo. The photo is saved in

the

Photos

folder.

• Do not take photos of people without their

permission.

• Do not take photos in a place where cameras are

not allowed.

• Do not take photos in a place where you may

interfere with another person’s privacy.

When you take a photo in direct sunlight or in bright

conditions, shadows may appear on the photo.

To Press

use photo options <

Options



p. 75

Menu functions

Camera

(Menu 8)

Using camera options in Capture mode

In Capture mode, press the left soft key to access the

following options:

•

Record video

: switch to Record mode.



p. 75

•

Shooting mode

: take a photo in the following

modes:

Single shot

: take a photo in normal mode.

Multi shot

: take a series of action stills. You can

select the number of still images the camera will

take.

Mosaic shot

: take several stills and save them in

one frame. You can select the layout.

•

Effects

: change the colour tone or apply a special

effect to the photo.

•

Frames

: apply a decorative frame to the photo.

•

Flash

: set the flash setting.

•

Timer

: set a time delay before the camera takes a

photo.

•

Go to Photos

: go to the

Photos

folder.

•

Settings

: change the default settings for taking a

photo.

Size

: select an image size.

Photo quality

: select an image quality setting.

View finder

: select a preview mode, either Full

screen mode or Standard ratio mode with actual

ratio.

ISO

: change the ISO setting, which controls the

sensitivity of your camera. For low light situations,

lower the ISO number to increase the quality.

The higher the ISO number, the faster the camera

shutter functions and the more sensitive the

camera is to light. Higher ISO settings may bring

some distortion to an image.

delete the photo <

Delete

> and then

Yes

return to Capture mode [ ].

To Press

Menu functions

Spot focus

: adjust the exposure based on a

specific area of the image. Select

to display the

spot focus frame in the middle of the image, and

change the exposure according to the brightness of

the image fragment in the frame.

Shutter sound

: select the sound that you hear

when you press the shutter release, [

] or

[

Zoom sound

: turn on or off the sound that you

hear when zooming in.

Brightness sound

: turn on or off the sound that

you hear when adjusting the image brightness.

Default name

: change the default prefix of the

photo name.

•

Camera short cuts

: view the functions of the

keys you can use.

Using the keypad in Capture mode

You can use the keypad to customise your camera

settings in Capture mode.

Keys Function

Flips the image vertically.

Shows the mirror image.

Left/Right Adjusts the brightness of the image.

Up/Down Zooms in or out.

Switches to Record mode.

Changes the image size.

Changes the image quality.

Changes the shooting mode and the

number of photos.

Changes the colour tone or applies a

special effect to the photo.

Reduces the distortion on the image to

maximise detail and sharpness.

Selects a decorative frame.

Sets the timer.

Goes to the

Photos

folder.

Keys Function

Menu functions

Camera

(Menu 8)

Using photo options

After taking a photo, press <

Options

> to access the

following options:

•

Take another

: return to Capture mode.

•

Send via

: send the photo via MMS, e-mail, or

Bluetooth.

•

Set as

: set the photo as your wallpaper for the

external or main display or as a caller ID image for

a Phonebook entry.

•

Delete

: delete the photo.

•

Rename

: change the name of the photo.

•

Go to Photos

: go to the

Photos

folder.

•

Share for bluetooth

: share the photo with other

Bluetooth devices.

•

Print via

: print the selected photo by connecting

the phone to a printer via Bluetooth or USB cable.

•

Protection

: protect the photo from being deleted.

•

Properties

: access the photo properties.

Taking a photo with the phone closed

1. Press and hold [

]

2. Adjust the image by aiming the camera lens at the

subject.

•Press [

]

to flip the image vertically.

•Press [

]

to show the mirror image.

3. Press [

]

to take a photo. The photo is

automatically saved in the

Photos

folder.

Record video

(Menu 8.2)

You can record a video of what is displayed on the

camera screen and save it.

1. If necessary, remove the camera cover.

2. Access the

Record video

menu.

3. Adjust the image by aiming the camera lens at the

subject.

• Press the left soft key to access camera

options. See the next section.

Set the flash setting.

Changes the preview screen.

Keys Function

Menu functions

• Use the keypad to change camera settings or

switch to other modes.



p. 77

4. Press [

]

to start recording.

5. Press [

]

to stop recording. The video is

automatically saved in the

Videos

folder.

Using camera options in Record mode

In Record mode, press the left soft key to access the

following options:

•

Take a photo

: switch to Capture mode.

•

Effects

: change the colour tone or apply a special

effect to a video.

•

Flash

: set the flash setting.

•

Timer

: set a time delay before the camera starts

recording.

•

Go to Videos

: go to the

Videos

folder.

•

Settings

: change the following settings for

recording a video:

Recording mode

: select a video recording mode.

Select

Limit for

MMS

to record a video suitable

for an MMS message.

Select

Normal

to record a video within the limit of

the currently available memory.

Size

: select a frame size.

Quality

: select an image quality.

Audio rec.

: turn on or off the audio.

Zoom sound

: turn on or off the sound that you

hear when zooming in.

Brightness sound

: turn on or off the sound that

you hear when adjusting the video image

brightness.

Default name

: change the default prefix of the

video clip name.

•

Camcorder short cuts

: view the functions of the

keys you can use.

To Press

play back the video clip [ ].

use video options the left soft key.



p. 77

delete the video clip [

] and then <

Yes

return to Record mode the right soft key.

Menu functions

Camera

(Menu 8)

Using the keypad in Record mode

You can use the keypad to customise your camera

settings in Record mode:

Using video options

After recording a video clip, press the left soft key to

access the following options:

•

Record another

: return to Record mode.

•

Send via

: send the video clip via MMS, e-mail, or

Bluetooth.

•

Delete

: delete the video clip.

•

Rename

: change the name of the video clip.

•

Go to Videos

: go to the

Videos

folder.

•

Protection

: protect the video clip from being

deleted.

•

Properties

: access the properties of the video

clip.

Keys Function

Flips the image vertically.

Shows the mirror image.

Left/Right Adjusts the brightness of the image.

Up/Down Zooms in or out.

Switches to Capture mode.

Changes the frame size.

Changes the image quality.

Changes the video recording mode.

Changes the colour tone or applies a

special effect to the video image.

Reduces the distortion on the image to

maximise detail and sharpness.

Turn on or off the audio.

Sets the timer.

Goes to the

Videos

folder.

sets the flash setting.

Keys Function

Menu functions

Settings

(Menu 9)

Use this menu to customise your phone settings. You

can also reset the settings to their default values.

To access this menu, press <

> in Idle mode and

select

Settings

Time & Date

(Menu 9.1)

Use this menu to set the current time and date on

your phone. Before setting the time and date, specify

your time zone in the

World time

menu.



p. 42

•

Set time

: enter the current time.

•

AM/PM

: select

in 12-hour time format.

•

Time format

: select the time format.

•

Set date

: enter the current date.

•

Date format

: select the date format.

Phone settings

(Menu 9.2)

Many different features of your phone’s system can be

customised to suit your preferences.

Language

(Menu 9.2.1)

Use this menu to select one of several languages for

the display text.

Greeting message

(Menu 9.2.2)

Use this menu to enter the greeting that is displayed

briefly when the phone is switched on.

Short cut

(Menu 9.2.3)

You can use the Navigation keys as shortcut keys to

access specific menus directly from Idle mode. Use

this menu to assign a shortcut menu to a key.

Assigning a menu to a key

1. Select a key to be used as a shortcut key.

2. Press <

Options

> and select

Change

3. Scroll to a menu to be assigned to the key.

4. Press <

Save

Using shortcut options

Press <

Options

> to access the following options:

•

Change

: assign or change a shortcut menu.

Menu functions

Settings

(Menu 9)

•

Remove

: deactivate the shortcut assignment.

•

Remove all

: deactivate all shortcut assignments.

Side key

(Menu 9.2.4)

Use this menu to set how the phone reacts when you

press and hold [ / ] when a call comes in.

•

Mute

: the keys mute the call ringer.

•

Reject

: the keys reject the incoming call.

Extra settings

(Menu 9.2.5)

You can turn the automatic redialling or answering

feature on or off.

•

Auto redial

: set the phone to make up to ten

attempts to redial a phone number after an

unsuccessful call.

•

Anykey

answer

: answer an incoming call by

pressing any key, except [ ], <

Reject

and [ / ].

When this option is not selected, you must press

[] or <

> to answer a call.

•

Voice clarity

: increase the microphone’s

sensitivity to allow the other person on the phone

to hear your voice clearly, even though you may be

whispering.

•

Active folder

: answer an incoming call by opening

the phone.

•

Cover keylock

: lock the exposed key to keep

accidental presses from affecting performance

while playing music files.

Display settings

(Menu 9.3)

Use this menu to change settings for the display and

light.

Wallpaper

(Menu 9.3.1)

You can set up the idle screen on both displays.

•

Main display

: select an image to be displayed on

the main display.

•

Cover display

: select an image or enter text to be

displayed on the external display.

Text display

(Menu 9.3.2)

You can customise the text appearance for the idle

screen.

•

Text position

: select a text position on the

display. If you don’t want to display text in Idle

mode, select

Off

Menu functions

•

Text style

: select a text style.

•

Text colour

: select a text colour.

Calendar

(Menu 9.3.3)

Use this menu to display the calendar of the current

month on the idle screen.

Skin

(Menu 9.3.4)

You can select a skin colour for Menu mode.

LCD brightness

(Menu 9.3.5)

You can adjust the brightness of the display for

varying lighting conditions.

Backlight

(Menu 9.3.6)

You can select the length of time the backlight stays

on and the display is on in Dim mode, in which the

backlight is off.

•

Main LCD on

: select the length of time the

backlight is on.

•

Main LCD dim

: select the length of time the

display is in Dim mode after the backlight turns off.

After a specified time, the display turns off.

•

Show cover indicators

: set whether or not the

cover display icons are shown on the external

display.

Sound settings

(Menu 9.4)

Use this menu to customise various sound settings.

Incoming call

(Menu 9.4.1)

Use this menu to select a volume and alert type for

incoming calls.

•

Ringtone

: select a ringtone for the call ringer.

•

Volume

: select a ringer volume.

•

Alert type

: specify how you are to be informed of

incoming calls.

Keypad tone

(Menu 9.4.2)

Use this menu to select the tone that the phone

sounds when you press a key.

You can adjust the keypad tone volume using

[/]

in Idle mode.

Menu functions

Settings

(Menu 9)

Message tone

(Menu 9.4.3)

Use this menu to set up the ringer for incoming

messages and e-mails.

•

Tone

: select one of several message tones.

•

Alert type

: specify how you are to be informed of

any incoming messages.

•

Repetition

: specify how often the phone informs

you of a new message.

Power on/off

(Menu 9.4.4)

Use this menu to select the melody that the phone

sounds when it is switched on or off.

Folder tone

(Menu 9.4.5)

Use this menu to select the tone that the phone

sounds when you open or close the phone.

Quiet mode

(Menu 9.4.6)

Use this menu to set how the phone acts to alert you

to a specific event in Quiet mode, instead of making

sounds.

•

Vibration

: set the phone to vibrate.

•

Mute

: mute all sound settings.

Extra tones

(Menu 9.4.7)

Use this menu to customise additional tones for the

phone.

•

Minute

minder

: set the phone to beep every

minute during an outgoing call to keep you

informed of the length of your call.

•

Connection

tone

: set the phone to beep when it

is connected to the system.

•

Alerts on call

: set the phone to beep when you

receive a new message or when the time for an

alarm comes during a call.

•

Indicative tone

: set the phone to beep when a

pop-up window appears to indicate that your

phone has completed an operation or that an error

occurs.

Network services

(Menu 9.5)

Use this menu to access network services. Please

contact your service provider to check their availability

and subscribe to them, if you wish.

Menu functions

Call diverting

(Menu 9.5.1)

This network service reroutes incoming calls to a

phone number that you specify.

1. Select a call diverting option:

•

Divert always

: divert all calls.

•

Busy

: divert calls when you are on another

call.

•

: divert calls when you do not answer

the phone.

•

Unreachable

: divert calls when you are not in

an area covered by the network or when your

phone is switched off.

•

Cancel

all

: cancel all call diverting options.

2. Select the type of calls to be diverted.

3. Select

Activate

. To activate call diverting, select

Deactivate

4. Move to the

Divert to

line.

5. Enter the number to which calls are to be diverted

and press <

6. If you selected

No reply

, move to the

Sec

line and

select the length of time the network delays before

diverting a call.

Call barring

(Menu 9.5.2)

This network service allows you to restrict your calls.

1. Select a call barring option:

•

All

outgoing

: prohibit all outgoing calls.

•

International

: prohibit international calls.

•

International

except

home

: only allow

calls to numbers within the current country.

•

All

incoming

: prohibit incoming calls.

•

Incoming

while

abroad

: prohibit incoming

calls when you use your phone outside of your

home country.

•

Cancel

all

: cancel all call barring settings,

allowing calls to be sent and received normally.

•

Change barring password

: change the call

barring password.

2. Select the type of calls to be barred.

3. Select

Activate

. To deactivate call barring, select

Deactivate

4. Enter the call barring password and press <

Menu functions

Settings

(Menu 9)

Call waiting

(Menu 9.5.3)

This network service informs you when someone is

trying to reach you while you are on another call.

1. Select the type of calls to which the call waiting

option will apply.

2. Select

Activate

. To deactivate call waiting, select

Deactivate

Network selection

(Menu 9.5.4)

This network service allows you to either automatically

or manually select the network to be used while

roaming outside of your home area.

You can select a network other than your home

network only if there is a valid roaming agreement

between the two.

•

Automatic

: connect to the first available network

when roaming.

•

Manual

: select the network you want.

Caller ID

(Menu 9.5.5)

This network service allows you to prevent your phone

number from being displayed on the phone of the

person being called. However, some networks do not

allow the user to change this setting.

•

Default

: use the default setting provided by the

network.

•

Hide

number

: ensure your number does not

display on the other person’s phone.

•

Send

number

: send your number each time you

make a call.

Voice mail server

(Menu 9.5.6)

Use this menu to store the number of the voice mail

server and access your voice mails.

•

Connect to voice mail

: connect to the voice mail

server to allow you to listen to your messages. You

can also connect to the voice mail server by

pressing and holding [

] in Idle mode.

•

Voice server number

: edit the name and number

for the voice mail server.

You must enter the voice server number before you can

access your voice mails. Your service provider can give

you the voice server number.

Menu functions

Band selection

(Menu 9.5.7)

For the phone to make and receive phone calls, it

must register with an available network. Your phone

can handle any of the following types of networks:

Combined GSM 900/1800, GSM 1900, and Tri band

(GSM 900/1800/1900).

The country where you purchased your phone

determines the default band that it uses. When you

travel abroad, you may need to change to an

appropriate band.

When you select a new band, your phone

automatically searches for all available networks. Your

phone registers with a preferred network within the

band.

Bluetooth

(Menu 9.6)

Use this menu to activate the Bluetooth feature.

Using the Bluetooth feature, you can connect the

phone wirelessly to other Bluetooth devices and

exchange data with them, talk hands-free, or control

the phone remotely.

Bluetooth technology allows free wireless connections

between all Bluetooth-compliant devices within a

range of 10 meters. Since the devices communicate

using radio waves, they do not need to be in line of

sight to each other.

Setting up the Bluetooth feature

The

Bluetooth

menu provides the following options:

•

Activation

: activate or deactivate the Bluetooth

feature.

•

My devices

: search for connectable Bluetooth

devices. See the next section.

•

My phone’s visibility

: allow other Bluetooth

devices to search for your phone.

•

My phone’s name

: assign a Bluetooth device

name to your phone, which is then displayed on

other devices.

• You cannot use the Bluetooth feature while using

multimedia features such as voice recorder,

camera, and MP3 player, or vice versa.

• Some devices may not be compatible with your

phone.

Menu functions

Settings

(Menu 9)

•

Secure mode

: determine if the phone asks for

your confirmation when other devices access your

data.

•

Bluetooth services

: display available Bluetooth

services.

Searching for and pairing with a Bluetooth

device

1. From the Bluetooth setting options, select

devices

2. Select

Search new device

After searching, a list of devices to which you can

connect displays. The following icons indicate the

kind of device:

The colour of the icon indicates the status of the

the device:

• Grey for unpaired devices

• Blue for paired devices

• Red for devices that are currently connected to

your phone

3. Select a device.

4. Enter a Bluetooth PIN code and press <

This

code is used just once and you don’t need to

memorise it.

When the owner of the other device enters the

same code, pairing is complete.

Using device options

From the device list, press <

Options

> to access the

following options:

•

Connect

Disconnect

: connect to the currently

selected device, or end the connection.

•

Browse files

: search for data from the device and

import data directly to your phone.

• Hands-free or

headset

• Mobile phone

• Computer • PDA

• Printer • Unknown device

Some devices, especially headsets or hands-free car

kits, may have a fixed Bluetooth PIN, such as

0000

. If

the other device has a code, you must enter it.

Options may vary depending on the paired device.

Menu functions

•

Service list

: display available Bluetooth services

for the selected device.

•

Rename

: rename the paired device.

•

Authorize device

Unauthorize device

determine whether or not the phone asks you to

permit connection when the device tries to connect

to your phone.

•

Delete

: remove the selected device or all

displayed devices from the device list.

Sending data via Bluetooth

1. Activate the Bluetooth feature.

2. Select the application in which the item you want

to send is stored.

3. Scroll to the item you want and press <

Options

4. Select

Send

via

→

Bluetooth

The phone searches for devices within range and

displays a list of available devices.

5. Select a device.

6. If necessary, enter the Bluetooth PIN needed for

pairing and press <

Receiving data via Bluetooth

To receive data via Bluetooth, your phone’s Bluetooth

feature must be active.

If an unauthorised Bluetooth device sends data to your

phone, the phone displays a confirmation message. To

receive data, press <

Yes

Security

(Menu 9.7)

Use this menu to protect the phone against

unauthorised use by managing the several access

codes of your phone and SIM card.

PIN check

(Menu 9.7.1)

The 4- to 8-digit PIN (Personal Identification Number)

protects your SIM card against unauthorised use.

When this feature is enabled, the phone requires your

PIN each time it is switched on.

If you enter an incorrect PIN/PIN2 three times in

succession, the SIM card is blocked. To unblock it, you

need to enter your PUK/PUK2 (Personal Unblocking

Key). The codes are supplied by your network operator.

Menu functions

Settings

(Menu 9)

Change PIN

(Menu 9.7.2)

Use this menu to change your PIN. The PIN check

feature must be enabled to use this feature.

Phone lock

(Menu 9.7.3)

This feature locks the phone from unauthorised use.

When this feature is enabled, you must enter a 4- to

8-digit phone password each time the phone is

switched on.

The password is preset to

00000000

. To change the

password, use the

Change password

menu.

Change password

(Menu 9.7.4)

Use this menu to change your phone password. The

password is preset to

00000000

Privacy

(Menu 9.7.5)

Use this menu to lock your media contents, including

MMS messages, e-mails, images, videos, music files,

and sounds.

1. Press [ ] to check the item(s) to lock.

2. Press <

Save

> to lock the marked items.

3. Enter the phone password and press <

To access a locked item, you need to enter the phone

password. The password is preset to

00000000

SIM lock

(Menu 9.7.6)

The SIM lock feature allows your phone to work only

with the current SIM by assigning a SIM lock code. You

must enter the SIM lock code to use a different SIM

card.

FDN mode

(Menu 9.7.7)

If supported by your SIM card, Fixed Dialling Number

(FDN) mode restricts your outgoing calls to a limited

set of phone numbers. When this feature is enabled,

you can make calls only to phone numbers specified in

the FDN list.



p. 33

To activate this feature, you must enter your PIN2.

Change PIN2

(Menu 9.7.8)

If supported by your SIM card, the change PIN2

feature changes your current PIN2.

Memory status

(Menu 9.8)

Use this menu to check the amount of memory being

used for storing data in

Messages

File manager

Calendar

Phonebook

, and

JAVA world

. You can

also check

Shared memory

for MMS, Email, and File

manager.

Reset settings

(Menu 9.9)

Use this menu to reset the phone settings, display

settings, and sound settings individually. You can also

reset all of the settings in your phone at the same

time.

1. Press [ ] to check the setting category(ies) to

be reset.

2. Press <

Reset

> to reset the marked items.

3. Press <

Yes

> to confirm the reset.

4. Enter the phone password and press <

Solve problems

Help and personal needs

To save the time and expense of an unnecessary service

call, perform the simple checks in this section before

contacting a service professional.

When you switch on your phone, the following

messages may appear:

“Insert SIM card”

• Be sure that the SIM card is correctly installed.

“Phone lock”

• The automatic locking function has been enabled. You

must enter the phone’s password before you can use

the phone.

“Enter PIN”

• You are using your phone for the first time. You must

enter the PIN supplied with the SIM card.

• The PIN check feature is enabled. Every time the

phone is switched on, the PIN has to be entered. To

disable this feature, use the

PIN check

menu.

The password is preset to

00000000

. To

change the password, use the

Change

password

menu.



p. 87

Solve problems

“Enter PUK”

• The PIN code has been entered incorrectly three times

in succession, and the phone is now blocked. Enter the

PUK supplied by your service provider.

“No service,” “Network failure,” or “Not done”

displays

• The network connection has been lost. You may be in a

weak signal area. Move and try again.

• You are trying to access an option for which you have

no subscription with your service provider. Contact the

service provider for further details.

You have entered a number but it was not dialled

• Be sure that you have pressed [ ].

• Be sure that you have accessed the right cellular

network.

• Be sure that you have not set an outgoing call barring

option.

Your correspondent cannot reach you

• Be sure that your phone is switched on. ([ ] pressed

for more than one second.)

• Be sure that you are accessing the correct cellular

network.

• Be sure that you have not set an incoming call barring

option.

Your correspondent cannot hear you speaking

• Be sure that you have switched on the microphone.

• Be sure that you are holding the phone close enough

to your mouth. The microphone is located at the

bottom of the phone.

The phone starts beeping and “Battery low”

flashes on the display

• Your battery is insufficiently charged. Recharge the

battery.

The audio quality of the call is poor

• Check the signal strength indicator on the display

( ). The number of bars indicates the signal

strength from strong ( ) to weak ( ).

• Try moving the phone slightly or moving closer to a

window if you are in a building.

No number is dialled when you re-call a

Phonebook entry

• Use the Contact list feature to ensure the number has

been stored correctly.

• Re-store the number, if necessary.

The battery doesn’t charge properly or the phone

sometimes turns itself off

Wipe the charging contacts both on the phone and on the

battery with a clean soft cloth.

If the above guidelines do not help you to solve

the problem, take note of:

• The model and serial numbers of your phone

• Your warranty details

• A clear description of the problem

• Then contact your local dealer or Samsung after-sales

service.

125

Health and Safety

Information

Exposure to Radio Frequency (RF) Signals

Your wireless phone is a radio transmitter and receiver.

It is designed and manufactured not to exceed the

emission limits for exposure to radio frequency (RF)

energy set by the Federal Communications Commission

(FCC) of the U.S. Government. These limits are part of

comprehensive guidelines and establish permitted

levels of RF energy for the general population. The

guidelines are based on the safety standards that were

developed by independent scientific organizations

through periodic and through evaluation of scientific

studies.

The standards include a substantial safety margin

designed to assure the safety of all persons, regardless

of age and health.

The exposure standard for wireless phones employs a

unit of measurement known as Specific Absorption

Rate (SAR). The SAR limit set by the FCC is 1.6W/kg *.

*In the U.S. and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kg (W/kg)

averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give

additional protection for the public and to account for any variations in measurements.

safety-end-NorthA 1/27/03 2:05 PM Page 125

HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonnHHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn

SAR tests are conducted using standard operating

positions specified by the FCC with the phone

transmitting at its highest certified power level in all

tested frequency bands. Although the SAR is

determined at the highest certified power level, the

actual SAR level of the phone while operating can be

well below the maximum value. This is because the

phone is designed to operate at multiple power levels

so as to use only the power required to reach the

network. In general, the closer you are to a wireless

base station antenna, the lower the power output of

the phone.

Before a new model phone is available for sale to the

public, it must be tested and certified to the FCC that

it does not exceed the limit established by the

government-adopted requirement for safe exposure.

The tests are performed in positions and locations

(e.g., at the ear and worn on the body) as required by

the FCC for each model. While there may be

differences between the SAR levels of various phones

and at various positions, they all meet the government

requirement.

The FCC has granted an Equipment Authorization for this

model phone with all reported SAR levels evaluated as in

compliance with the FCC RF exposure guidelines. SAR

information on this model phone is on file with the FCC

and can be found under the Display Grant section of

http://www.fcc.gov/oet/fccid after searching on FCC ID

printed in the label on the phone.

FCC certification information for this model phone is

attached separation paper.

For Body Operation

For body worn operation, this model phone has been

tested and meets the FCC RF exposure guidelines when

used with a Samsung-supplied or approved accessory

designated for this product or when used with and

accessory that contains no metal and that positions the

handset a minimum from the body.

The minimum distance for this model phone is written in

the FCC certification information from the body.

None compliance with the above conditions may violate

FCC RF exposure guidelines.

For more Information concerning exposure to radio

frequency signals, see the following websites:

Federal Communications Commission (FCC)

http://www.fcc.gov/rfsafety

Cellular Telecommunications Industry Association (CTIA):

http://www.wow-com.com

U.S.Food and Drug Administration (FDA)

http://www.fda.gov/cdrh/consumer

World Health Organization (WHO)

http://www.who.int/peh-emf/en

safety-end-NorthA 1/27/03 2:05 PM Page 126

HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn

• Do not leave the battery in hot or cold places, such

as in a car in summer or winter conditions, as you

will reduce the capacity and lifetime of the battery.

Always try to keep the battery at room

temperature. A phone with a hot or cold battery

may temporarily not work, even when the battery

is fully charged. Li-ion batteries are particularly

affected by temperatures below 0 °C (32 °F).

• Do not short-circuit the battery. Accidental short-

circuiting can occur when a metallic object (coin,

clip or pen) causes a direct connection between

the + and – terminals of the battery (metal strips

on the battery), for example when you carry a

spare battery in a pocket or bag. Short-circuiting

the terminals may damage the battery or the

object causing the short-circuiting.

• Dispose of used batteries in accordance with local

regulations. Always recycle. Do not dispose of

batteries in a fire.

Road Safety

Your wireless phone gives you the powerful ability to

communicate by voice, almost anywhere, anytime.

But an important responsibility accompanies the

benefits of wireless phones, one that every user

must uphold.

When driving a car, driving is your first responsibility.

When using your wireless phone behind the wheel of

a car, practice good common sense and remember

the following tips.

HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn

Precautions When Using Batteries

• Never use any charger or battery that is damaged in

any way.

• Use the battery only for its intended purpose.

• If you use the phone near the network’s base

station, it uses less power; talk and standby time

are greatly affected by the signal strength on the

cellular network and the parameters set by the

network operator.

• Battery charging time depends on the remaining

battery charge and the type of battery and charger

used. The battery can be charged and discharged

hundreds of times, but it will gradually wear out.

When the operation time (talk time and standby

time) is noticeably shorter than normal, it is time to

buy a new battery.

• If left unused, a fully charged battery will discharge

itself over time.

• Use only Samsung-approved batteries and recharge

your battery only with Samsung-approved chargers.

When a charger is not in use, disconnect it from the

power source. Do not leave the battery connected to

a charger for more than a week, since overcharging

may shorten its life.

• Extreme temperatures will affect the charging

capacity of your battery: it may require cooling or

warming first.

safety-end-NorthA 1/27/03 2:05 PM Page 128

HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonnHHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn

7. Do not engage in stressful or emotional

conversations that may be distracting. Make the

people with whom you are talking aware that you

are driving and suspend conversations that have

the potential to divert your attention from the

road.

8. Use your wireless phone to call for help. Dial the

emergency number in the case of fire, traffic

accident or medical emergencies. Remember, it is

a free call on your wireless phone!

9. Use your wireless phone to help others in

emergencies. If you see a car accident, crime in

progress or other serious emergency where lives

are in danger, call the emergency number, as you

would want others to do for you.

10. Call roadside assistance or a special non-

emergency wireless assistance number when

necessary. If you see a broken-down vehicle

posing no serious hazard, a broken traffic signal,

a minor traffic accident where no one appears

injured, or a vehicle you know to be stolen, call

roadside assistance or any other special non-

emergency wireless number.

1. Get to know your wireless phone and its features,

such as speed dial and redial. If available, these

features help you to place your call without taking

your attention off the road.

2. When available, use a hands-free device. If

possible, add an extra layer of convenience and

safety to your wireless phone with one of the

many hands-free accessories available today.

3. Position your wireless phone within easy reach. Be

able to access your wireless phone without

removing your eyes from the road. If you get an

incoming call at an inconvenient time, let your

voice mail answer it for you.

4. Let the person you are speaking with know you are

driving; if necessary, suspend the call in heavy

traffic or hazardous weather conditions. Rain,

sleet, snow, ice and even heavy traffic can be

hazardous.

5. Do not take notes or look up phone numbers while

driving. Jotting down a To Do list or flipping

through your phonebook takes your attention away

from your primary responsibility, driving safely.

6. Dial sensibly and assess the traffic; if possible,

place calls when you are not moving or before

pulling into traffic. Try to plan calls when your car

will be stationary. If you need to make a call while

moving, dial only a few numbers, check the road

and your mirrors, then continue.

safety-end-NorthA 1/27/03 2:05 PM Page 130

HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonnHHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn

Wireless Technology Research.

Persons with pacemakers:

• Should always keep the phone more than 15 cm (6

inches) from their pacemaker when the phone is

switched on

• Should not carry the phone in a breast pocket

• Should use the ear opposite the pacemaker to

minimize potential interference

If you have any reason to suspect that interference is

taking place, switch off your phone immediately.

Hearing Aids

Some digital wireless phones may interfere with

some hearing aids. In the event of such interference,

you may wish to consult your hearing aid

manufacturer to discuss alternatives.

Other Medical Devices

If you use any other personal medical devices,

consult the manufacturer of your device to determine

if it is adequately shielded from external RF energy.

Your physician may be able to assist you in obtaining

this information. Switch off your phone in health care

facilities when any regulations posted in these areas

instruct you to do so. Hospitals or health care

facilities may be using equipment that could be

sensitive to external RF energy.

Vehicles

RF signals may affect improperly installed or

inadequately shielded electronic systems in motor

vehicles. Check with the manufacturer or its

Operating Environment

Remember to follow any special regulations in force

in any area and always switch off your phone

whenever it is forbidden to use it, or when it may

cause interference or danger.

When connecting the phone or any accessory to

another device, read its user’s guide for detailed

safety instructions. Do not connect incompatible

products.

As with other mobile radio transmitting equipment,

users are advised that for the satisfactory operation

of the equipment and for the safety of personnel, it is

recommended that the equipment should only be

used in the normal operating position (held to your

ear with the antenna pointing over your shoulder).

Electronic Devices

Most modern electronic equipment is shielded from

radio frequency (RF) signals. However, certain

electronic equipment may not be shielded against

the RF signals from your wireless phone. Consult the

manufacturer to discuss alternatives.

Pacemakers

Pacemaker manufacturers recommend that a

minimum distance of 15 cm (6 inches) be maintained

between a wireless phone and a pacemaker to avoid

potential interference with the pacemaker. These

recommendations are consistent with the

independent research and recommendations of

safety-end-NorthA 1/27/03 2:05 PM Page 132

HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonnHHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn

Emergency Calls

This phone, like any wireless phone, operates using

radio signals, wireless and landline networks as well

as user-programmed functions, which cannot guarantee

connection in all conditions. Therefore, you should

never rely solely on any wireless phone for essential

communications (medical emergencies, for example).

Remember, to make or receive any calls the phone

must be switched on and in a service area with

adequate signal strength. Emergency calls may not be

possible on all wireless phone networks or when

certain network services and/or phone features are in

use. Check with local service providers.

To make an emergency call, proceed as follows.

1. If the phone is not on, switch it on.

2. Key in the emergency number for your present

location. Emergency numbers vary by

location.

3. Press the <SEND> key.

If certain features are in use (call barring, for example),

you may first need to deactivate those features before

you can make an emergency call. Consult this

document and your local cellular service provider.

When making an emergency call, remember to give all

the necessary information as accurately as possible.

Remember that your phone may be the only means of

communication at the scene of an accident; do not cut

off the call until given permission to do so.

representative regarding your vehicle.

You should also consult the manufacturer of any

equipment that has been added to your vehicle.

Posted Facilities

Switch off your phone in any facility where posted

notices require you to do so.

Potentially Explosive Atmospheres

Switch off your phone when in any area with a

potentially explosive atmosphere and obey all signs

and instructions. Sparks in such areas could cause an

explosion or fire resulting in bodily injury or even

death.

Users are advised to switch off the phone while at a

refueling point (service station). Users are reminded

of the need to observe restrictions on the use of

radio equipment in fuel depots (fuel storage and

distribution areas), chemical plants or where blasting

operations are in progress.

Areas with a potentially explosive atmosphere are

often but not always clearly marked. They include

below deck on boats, chemical transfer or storage

facilities, vehicles using liquefied petroleum gas

(such as propane or butane), areas where the air

contains chemicals or particles, such as grain, dust

or metal powders, and any other area where you

would normally be advised to turn off your vehicle

engine.

safety-end-NorthA 1/27/03 2:05 PM Page 134

HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonnHHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn

Care and Maintenance

Your phone is a product of superior design and

craftsmanship and should be treated with care. The

suggestions below will help you fulfill any warranty

obligations and allow you to enjoy this product for

many years.

• Keep the phone and all its parts and accessories

out of the reach of small children’s.

• Keep the phone dry. Precipitation, humidity and

liquids contain minerals that will corrode

electronic circuits.

• Do not touch the phone with a wet hand while it is

charging. Doing so may cause an electric shock to

you or damage to the phone.

• Do not use or store the phone in dusty, dirty areas,

as its moving parts may be damaged.

• Do not store the phone in hot areas. High

temperatures can shorten the life of electronic

devices, damage batteries, and warp or melt

certain plastics.

• Do not store the phone in cold areas. When the

phone warms up to its normal operating

temperature, moisture can form inside the phone,

which may damage the phone’s electronic circuit

boards.

Other Important Safety Information

• Only qualified personnel should service the phone or

install the phone in a vehicle. Faulty installation or

service may be dangerous and may invalidate any

warranty applicable to the device.

• Check regularly that all wireless phone equipment in

your vehicle is mounted and operating properly.

• Do not store or carry flammable liquids, gases or

explosive materials in the same compartment as the

phone, its parts or accessories.

• For vehicles equipped with an air bag, remember

that an air bag inflates with great force. Do not

place objects, including both installed or portable

wireless equipment in the area over the air bag or in

the air bag deployment area. If wireless equipment

is improperly installed and the air bag inflates,

serious injury could result.

• Switch off your phone before boarding an aircraft.

The use of wireless phones in aircraft may be

dangerous to the operation of the aircraft, and is

illegal.

• Failure to observe these instructions may lead to the

suspension or denial of telephone services to the

offender, or legal action, or both.

safety-end-NorthA 1/27/03 2:05 PM Page 136

HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonnHHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn

• Do not drop, knock or shake the phone. Rough

handling can break internal circuit boards.

• Do not use harsh chemicals, cleaning solvents or

strong detergents to clean the phone. Wipe it with a

soft cloth slightly dampened in a mild soap-and-water

solution.

• Do not paint it. Paint can clog the device’s moving

parts and prevent proper operation.

• Do not put the phone in or on heating devices, such as

a microwave oven, a stove or a radiator. The phone

may explode when overheated.

• Use only the supplied or an approved replacement

antenna. Unauthorized antennas or modified

accessories may damage the phone and violate

regulations governing radio devices.

• If the phone, battery, charger or any accessory is not

working properly, take it to your nearest qualified

service facility. The personnel there will assist you,

and if necessary, arrange for service.

Acknowledging Special Precautions and the FCC

and Industry Canada Notice

Cautions

Modifications not expressly approved by the party

responsible for compliance could void the user's authority

to operate the equipment. FCC Compliance Information

This device complies with Part 15 of FCC Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received.

Including interference that may cause undesired

operation.

Information to User

This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to part 15

of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation.

This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications. However, there is

no guarantee that interference will not occur in a

particular installation. If this equipment does cause

harmful interference to radio or television reception,

which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the

interference by one or more of the following measures:

safety-end-NorthA 1/27/03 2:05 PM Page 138

AAppppeennddiixx

Appendix A: CERTIFICATION INFORMATION (SAR)

THIS MODEL PHONE MEETS THE GOVERNMENT’S

REQUIREMENTS FOR

EXPOSURE TO RADIO WAVES.

Your wireless phone is a radio transmitter and receiver.

It is designed and manufactured not to exceed the

emission limits for exposure to radio frequency(RF)

energy set by the Federal Communications Commission

of the U.S. Government. These limits are part of

comprehensive guidelines and establish permitted

levels of RF energy for the general population. The

guidelines are based on safety standards that were

developed by independent scientific organizations

through periodic and thorough evaluation of scientific

studies. The standards include a substantial safety

margin designed to assure the safety of all persons,

regardless of age and health.

The exposure standard for wireless mobile phones

employs a unit of measurement known as the Specific

Absorption Rate(SAR). The SAR limit set by the FCC is

1.6 W/kg. SAR Tests are conducted using standard

operating positions accepted by the FCC with the

phone transmitting at its highest certified power level

in all tested frequency bands. Although the SAR is

determined at the highest certified power level, the

actual SAR level of the phone while operating can be

well below the maximum value. This is because the

phone is designed to operate at multiple power levels

so as to use only the power required to reach the

network. In general, the closer you are to a wireless

base station antenna, the lower the power output.

HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment

and receiver.

• Connect the equipment into an outlet on a circuit

different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/ TV

technician for help.

safety-end-NorthA 1/27/03 2:05 PM Page 140

143

Appendix B: Guide to Safe and Responsible Wireless

Phone Use

Cellular Telecommunications & Internet Association

“Safety is the most important call you will ever make.”

A Guide to Safe and Responsible Wireless Phone Use

TENS OF MILLIONS OF PEOPLE IN THE U.S. TODAY TAKE

ADVANTAGE OF THE UNIQUE COMBINATION OF

CONVENIENCE, SAFETY AND VALUE DELIVERED BY THE

WIRELESS TELEPHONE. QUITE SIMPLY, THE WIRELESS

PHONE GIVES PEOPLE THE POWERFUL ABILITY TO

COMMUNICATE BY VOICE-ALMOST ANYWHERE,

ANYTIME-WITH THE BOSS, WITH A CLIENT, WITH THE

KIDS, WITH EMERGENCY PERSONNEL OR EVEN WITH

THE POLICE. EACH YEAR, AMERICANS MAKE BILLIONS

OF CALLS FROM THEIR WIRELESS PHONES, AND THE

NUMBERS ARE RAPIDLY GROWING.

But an important responsibility accompanies those

benefits, one that every wireless phone user must

uphold. When driving a car, driving is your first

responsibility. A wireless phone can be an invaluable

tool, but good judgment must be exercised at all times

while driving a motor vehicle-whether on the phone or

not.

The basic lessons are ones we all learned as teenagers.

Driving requires alertness, caution and courtesy. It

requires a heavy dose of basic common sense-keep your

head up, keep your eyes on the road, check your mirrors

frequently and watch out for other drivers. It requires

obeying all traffic signs and signals and staying within

the speed limit. It means using seatbelts and requiring

other passengers to do the same.

142

Before a new model phone is available for sale to the

public, it must be tested and certified to the FCC that it

does not exceed the limit established by the government-

adopted requirement for safe exposure. The tests are

performed in positions and locations(e.g., at the ear and

worn on the body) as required by the FCC for each

model.

The highest SAR values for this model phone as reported

to the FCC are Head: 0.852W/Kg, Body-worn: 0.318W/Kg.

Body-worn operations are restricted to Samsung-

supplied, approved or none Samsung designated

accessories that have no metal and must provide at least

1.5cm separation between the device, including its

antenna whether extended or retracted, and the user’s

body. None compliance to the above restrictions may

violate FCC RF exposure guidelines

The FCC has granted an Equipment Authorization for this

model phone with all reported SAR levels evaluated as

in compliance with the FCC RF exposure guidelines. SAR

information on this model phone is on file with the FCC

and can be found under the Display Grant section of

http://www.fcc.gov/oet/fccid after searching on FCC ID

A3LSGHE760.

In the United States and Canada, the SAR limit for

mobile phones used by the public is 1.6

watts/kilogram(W/kg) averaged over one gram of tissue.

The standard incorporates a substantial margin of safety

to give additional protection for the public and to

account for any variations in measurements.

AAppppeennddiixxAAppppeennddiixx

safety-end-NorthA 1/27/03 2:05 PM Page 142

100

145

4. Suspend conversations during hazardous driving

conditions or situations. Let the person you are speaking

with know you are driving; if necessary, suspend the call

in heavy traffic or hazardous weather conditions. Rain,

sleet, snow and ice can be hazardous, but so is heavy

traffic. As a driver, your first responsibility is to pay

attention to the road.

5. Do not take notes or look up phone numbers while

driving. If you are reading an address book or business

card, or writing a “to do” list while driving a car, you are

not watching where you are going. It’s common sense.

Don’t get caught in a dangerous situation because you

are reading or writing and not paying attention to the

road or nearby vehicles.

6. Dial sensibly and assess the traffic; if possible, place

calls when you are not moving or before pulling into

traffic. Try to plan your calls before you begin your trip or

attempt to coincide your calls with times you may be

stopped at a stop sign, red light or otherwise stationary.

But if you need to dial while driving, follow this simple

tip-dial only a few numbers, check the road and your

mirrors, then continue.

7. Do not engage in stressful or emotional conversations

that may be distracting. Stressful or emotional

conversations and driving do not mix-they are distracting

and even dangerous when you are behind the wheel of a

car. Make people you are talking with aware you are

driving and if necessary, suspend conversations which

have the potential to divert your attention from the road.

144

But with wireless phone use, driving safely means a

little more. This brochure is a call to wireless phone

users everywhere to make safety their first priority when

behind the wheel of a car. Wireless telecommunications

is keeping us in touch, simplifying our lives, protecting us

in emergencies and providing opportunities to help

others in need. When it comes to the use of wireless

phones, safety is your most important call.

Wireless Phone “Safety Tips”

Below are safety tips to follow while driving and using a

wireless phone which should be easy to remember.

1. Get to know your wireless phone and its features such

as speed dial and redial. Carefully read your instruction

manual and learn to take advantage of valuable features

most phones offer, including automatic redial and

memory. Also, work to memorize the phone keypad so

you can use the speed dial function without taking your

attention off the road.

2. When available, use a hands free device. A number of

hands free wireless phone accessories are readily

available today. Whether you choose an installed

mounted device for your wireless phone or a speaker

phone accessory, take advantage of these devices if

available to you.

3. Position your wireless phone within easy reach. Make

sure you place your wireless phone within easy reach

and where you can grab it without removing your eyes

from the road. If you get an incoming call at an

inconvenient time, if possible, let your voice mail answer

it for you.

AAppppeennddiixxAAppppeennddiixx

safety-end-NorthA 1/27/03 2:05 PM Page 144

101

146

8. Use your wireless phone to call for help. Your wireless

phone is one of the greatest tools you can own to

protect yourself and your family in dangerous situations-

with your phone at your side, help is only three numbers

away. Dial 9-1-1 or other local emergency number in the

case of fire, traffic accident, road hazard or medical

emergency. Remember, it is a free call on your wireless

phone!

9. Use your wireless phone to help others in

emergencies. Your wireless phone provides you a perfect

opportunity to be a “Good Samaritan” in your community.

If you see an auto accident, crime in progress or other

serious emergency where lives are in danger, call 9-1-1

or other local emergency number, as you would want

others to do for you.

10. Call roadside assistance or a special wireless non-

emergency assistance number when necessary. Certain

situations you encounter while driving may require

attention, but are not urgent enough to merit a call for

emergency services. But you still can use your wireless

phone to lend a hand. If you see a broken-down vehicle

posing no serious hazard, a broken traffic signal, a minor

traffic accident where no one appears injured or a

vehicle you know to be stolen, call roadside assistance

or other special non-emergency wireless number.

Careless, distracted individuals and people driving

irresponsibly represent a hazard to everyone on the road.

Since 1984, the Cellular Telecommunications Industry

Association and the wireless industry have conducted

educational outreach to inform wireless phone users of

147

their responsibilities as safe drivers and good citizens.

As we approach a new century, more and more of us will

take advantage of the benefits of wireless telephones.

And, as we take to the roads, we all have a

responsibility to drive safely.

“The wireless industry reminds you to use your phone

safely when driving.”

Cellular Telecommunications & Internet Association

For more information, please call 1-888-901-SAFE.

For updates: http://www.wow-

com.com/consumer/issues/driving/articles.cfm?ID=85

AAppppeennddiixxAAppppeennddiixx

safety-end-NorthA 1/27/03 2:05 PM Page 146

102

149

low level RF that does not produce heating effects

causes no known adverse health effects. Many studies

of low level RF exposures have not found any biological

effects. Some studies have suggested that some

biological effects may occur, but such findings have not

been confirmed by additional research. In some cases,

other researchers have had difficulty in reproducing

those studies, or in determining the reasons for

inconsistent results.

3. What is FDA’s role concerning the safety of wireless

phones?

Under the law, FDA does not review the safety of

radiation-emitting consumer products such as wireless

phones before they can be sold, as it does with new

drugs or medical devices. However, the agency has

authority to take action if wireless phones are shown to

emit radiofrequency energy (RF) at a level that is

hazardous to the user. In such a case, FDA could require

the manufacturers of wireless phones to notify users of

the health hazard and to repair, replace or recall the

phones so that the hazard no longer exists.

Although the existing scientific data do not justify FDA

regulatory actions, FDA has urged the wireless phone

industry to take a number of steps, including the

following:

Support needed research into possible biological effects

of RF of the type emitted by wireless phones;

Design wireless phones in a way that minimizes any RF

exposure to the user that is not necessary for device

function; and

Cooperate in providing users of wireless phones with the

148

Appendix C: Consumer Update on Wireless Phones

U.S. Food and Drug Administration

1. What kinds of phones are the subject of this update?

The term wireless phone refers here to hand-held

wireless phones with built-in antennas, often called cell,

mobile, or PCS phones. These types of wireless phones

can expose the user to measurable radiofrequency

energy (RF) because of the short distance between the

phone and the user s head. These RF exposures are

limited by Federal Communications Commission safety

guidelines that were developed with the advice of FDA

and other federal health and safety agencies. When the

phone is located at greater distances from the user, the

exposure to RF is drastically lower because a person’s RF

exposure decreases rapidly with increasing distance

from the source. The so-called “cordless phones,” which

have a base unit connected to the telephone wiring in a

house, typically operate at far lower power levels, and

thus produce RF exposures well within the FCC’s

compliance limits.

2. Do wireless phones pose a health hazard?

The available scientific evidence does not show that any

health problems are associated with using wireless

phones. There is no proof, however, that wireless phones

are absolutely safe. Wireless phones emit low levels of

radiofrequency energy (RF) in the microwave range while

being used. They also emit very low levels of RF when in

the stand-by mode. Whereas high levels of RF can

produce health effects (by heating tissue), exposure to

AAppppeennddiixxAAppppeennddiixx

safety-end-NorthA 1/27/03 2:05 PM Page 148

103

151

4. What is FDA doing to find out more about the possible

health effects of wireless phone RF?

FDA is working with the U.S. National Toxicology

Program and with groups of investigators around the

world to ensure that high priority animal studies are

conducted to address important questions about the

effects of exposure to radiofrequency energy (RF).

FDA has been a leading participant in the World Health

Organization International Electromagnetic Fields (EMF)

Project since its inception in 1996. An influential result

of this work has been the development of a detailed

agenda of research needs that has driven the

establishment of new research programs around the

world. The Project has also helped develop a series of

public information documents on EMF issues.

FDA and the Cellular Telecommunications & Internet

Association (CTIA) have a formal Cooperative Research

and Development Agreement (CRADA) to do research on

wireless phone safety. FDA provides the scientific

oversight, obtaining input from experts in government,

industry, and academic organizations. CTIA-funded

research is conducted through contracts to independent

investigators. The initial research will include both

laboratory studies and studies of wireless phone users.

The CRADA will also include a broad assessment of

additional research needs in the context of the latest

research developments around the world.

5. What steps can I take to reduce my exposure to

radiofrequency energy from my wireless phone?

150

best possible information on possible effects of wireless

phone use on human health

FDA belongs to an interagency working group of the

federal agencies that have responsibility for different

aspects of RF safety to ensure coordinated efforts at the

federal level. The following agencies belong to this

working group:

National Institute for Occupational Safety and Health

Environmental Protection Agency

Federal Communications Commission

Occupational Safety and Health Administration

National Telecommunications and Information

Administration

The National Institutes of Health participates in some

interagency working group activities, as well.

FDA shares regulatory responsibilities for wireless

phones with the Federal Communications Commission

(FCC). All phones that are sold in the United States must

comply with FCC safety guidelines that limit RF exposure.

FCC relies on FDA and other health agencies for safety

questions about wireless phones.

FCC also regulates the base stations that the wireless

phone networks rely upon. While these base stations

operate at higher power than do the wireless phones

themselves, the RF exposures that people get from these

base stations are typically thousands of times lower than

those they can get from wireless phones. Base stations

are thus not the primary subject of the safety questions

discussed in this document.

AAppppeennddiixxAAppppeennddiixx

safety-end-NorthA 1/27/03 2:05 PM Page 150

104

153

Some groups sponsored by other national governments

have advised that children be discouraged from using

wireless phones at all. For example, the government in

the United Kingdom distributed leaflets containing such

a recommendation in December 2000. They noted that no

evidence exists that using a wireless phone causes brain

tumors or other ill effects. Their recommendation to limit

wireless phone use by children was strictly

precautionary; it was not based on scientific evidence

that any health hazard exists.

7. Do hands-free kits for wireless phones reduce risks

from exposure to RF emissions?

Since there are no known risks from exposure to RF

emissions from wireless phones, there is no reason to

believe that hands-free kits reduce risks. Hands-free kits

can be used with wireless phones for convenience and

comfort. These systems reduce the absorption of RF

energy in the head because the phone, which is the

source of the RF emissions, will not be placed against

the head. On the other hand, if the phone is mounted

against the waist or other part of the body during use,

then that part of the body will absorb more RF energy.

Wireless phones marketed in the U.S. are required to

meet safety requirements regardless of whether they are

used against the head or against the body. Either

configuration should result in compliance with the safety

limit.

8. Do wireless phone accessories that claim to shield the

head from RF radiation work?

152

If there is a risk from these products—and at this point

we do not know that there is—it is probably very small.

But if you are concerned about avoiding even potential

risks, you can take a few simple steps to minimize your

exposure to radiofrequency energy (RF). Since time is a

key factor in how much exposure a person receives,

reducing the amount of time spent using a wireless

phone will reduce RF exposure.

If you must conduct extended conversations by wireless

phone every day, you could place more distance between

your body and the source of the RF, since the exposure

level drops off dramatically with distance. For example,

you could use a headset and carry the wireless phone

away from your body or use a wireless phone connected

to a remote antenna

Again, the scientific data do not demonstrate that

wireless phones are harmful. But if you are concerned

about the RF exposure from these products, you can use

measures like those described above to reduce your RF

exposure from wireless phone use.

6. What about children using wireless phones?

The scientific evidence does not show a danger to users

of wireless phones, including children and teenagers. If

you want to take steps to lower exposure to

radiofrequency energy (RF), the measures described

above would apply to children and teenagers using

wireless phones. Reducing the time of wireless phone

use and increasing the distance between the user and

the RF source will reduce RF exposure.

AAppppeennddiixxAAppppeennddiixx

safety-end-NorthA 1/27/03 2:05 PM Page 152

105

155

FDA has tested hearing aids for interference from

handheld wireless phones and helped develop a

voluntary standard sponsored by the Institute of

Electrical and Electronic Engineers (IEEE). This standard

specifies test methods and performance requirements for

hearing aids and wireless phones so that that no

interference occurs when a person uses a compatible

phone and a compatible hearing aid at the same time.

This standard was approved by the IEEE in 2000.

FDA continues to monitor the use of wireless phones for

possible interactions with other medical devices. Should

harmful interference be found to occur, FDA will conduct

testing to assess the interference and work to resolve

the problem.

10. What are the results of the research done already?

The research done thus far has produced conflicting

results, and many studies have suffered from flaws in

their research methods. Animal experiments

investigating the effects of radiofrequency energy (RF)

exposures characteristic of wireless phones have yielded

conflicting results that often cannot be repeated in other

laboratories. A few animal studies, however, have

suggested that low levels of RF could accelerate the

development of cancer in laboratory animals. However,

many of the studies that showed increased tumor

development used animals that had been genetically

engineered or treated with cancer-causing chemicals so

as to be pre-disposed to develop cancer in the absence

of RF exposure. Other studies exposed the animals to RF

for up to 22 hours per day. These conditions are not

similar to the conditions under which people use

wireless phones, so we don t know with certainty what

154

Since there are no known risks from exposure to RF

emissions from wireless phones, there is no reason to

believe that accessories that claim to shield the head

from those emissions reduce risks. Some products that

claim to shield the user from RF absorption use special

phone cases, while others involve nothing more than a

metallic accessory attached to the phone. Studies have

shown that these products generally do not work as

advertised. Unlike “hand-free” kits, these so-called

“shields” may interfere with proper operation of the

phone. The phone may be forced to boost its power to

compensate, leading to an increase in RF absorption. In

February 2002, the Federal trade Commission (FTC)

charged two companies that sold devices that claimed to

protect wireless phone users from radiation with making

false and unsubstantiated claims. According to FTC,

these defendants lacked a reasonable basis to

substantiate their claim.

9. What about wireless phone interference with medical

equipment?

Radiofrequency energy (RF) from wireless phones can

interact with some electronic devices. For this reason,

FDA helped develop a detailed test method to measure

electromagnetic interference (EMI) of implanted cardiac

pacemakers and defibrillators from wireless telephones.

This test method is now part of a standard sponsored by

the Association for the Advancement of Medical

instrumentation (AAMI). The final draft, a joint effort by

FDA, medical device manufacturers, and many other

groups, was completed in late 2000. This standard will

allow manufacturers to ensure that cardiac pacemakers

and defibrillators are safe from wireless phone EMI.

AAppppeennddiixxAAppppeennddiixx

safety-end-NorthA 1/27/03 2:05 PM Page 154

106

156

the results of such studies mean for human health.

Three large epidemiology studies have been published

since December 2000. Between them, the studies

investigated any possible association between the use of

wireless phones and primary brain cancer, glioma,

meningioma, or acoustic neuroma, tumors of the brain or

salivary gland, leukemia, or other cancers. None of the

studies demonstrated the existence of any harmful

health effects from wireless phone RF exposures.

However, none of the studies can answer questions

about long-term exposures, since the average period of

phone use in these studies was around three years.

11. What research is needed to decide whether RF

exposure from wireless phones poses a health risk?

A combination of laboratory studies and epidemiological

studies of people actually using wireless phones would

provide some of the data that are needed. Lifetime

animal exposure studies could be completed in a few

years. However, very large numbers of animals would be

needed to provide reliable proof of a cancer promoting

effect if one exists. Epidemiological studies can provide

data that is directly applicable to human populations, but

10 or more years follow-up may be needed to provide

answers about some health effects, such as cancer. This

is because the interval between the time of exposure to

a cancer-causing agent and the time tumors develop - if

they do - may be many, many years. The interpretation of

epidemiological studies is hampered by difficulties in

measuring actual RF exposure during day-to-day use of

wireless phones. Many factors affect this measurement,

such as the angle at which the phone is held, or which

model of phone is used.

12. Which other federal agencies have responsibilities

related to potential RF health effects?

Additional information on the safety of RF exposures from

various sources can be obtained from the following

organizations.

FCC RF Safety Program:

http://www.fcc.gov/oet/rfsafety/

Environmental Protection Agency (EPA):

http://www.epa.gov/radiation/

Occupational Safety and Health Administration’s (OSHA):

http://www.osha-

slc.gov/SLTC/radiofrequencyradiation/index.html

National Institute for Occupational Safety and Health

(NIOSH):

http://www.cdc.gov/niosh/emfpg.html

World health Organization (WHO):

http://www.who.int/peh-emf/

International Commission on Non-Ionizing Radiation

Protection:

http://www.icnirp.de

National Radiation Protection Board (UK):

http://www.nrpb.org.uk

Updated 4/3/2002: US Food and Drug Administration

http://www.fda.gov/cellphones

AAppppeennddiixxAAppppeennddiixx

safety-end-NorthA 1/27/03 2:05 PM Page 156

107

Index

Alarm • 43

Answering

call • 26

second call • 28

Anykey answer • 79

Auto redial • 79

Backlight time, set • 80

Band selection • 84

Barring, calls • 82

Battery

charging • 7

low indicator • 8

precautions • 91

Bluetooth

receiving, data • 86

sending, data • 86

settings • 84

Browser, WAP • 46

Calculator • 44

Calendar • 68, 80

Call cost • 32

Call records

dialled • 31

missed • 31

received • 31

Call time • 32

Caller group, managing • 35

Caller ID • 83

Calls

answering • 26

barring • 82

diverting • 82

holding • 27

redialling • 25

rejecting • 26

waiting • 83

Camera

photos • 72

videos • 75

CB (Cell Broadcast) messages •

Characters, enter • 23

Conference call • 30

Connection tone • 81

Convertor • 44

Creating calendar

anniversaries • 70

events • 69

to-do items • 70

Creating messages

e-mail • 51

MMS • 50

SMS • 49

Deleting

call records • 31

events • 71

messages • 53

missed alarms • 72

phonebook 36

photos • 65

Dialled calls • 31

Display

language • 78

settings • 79

Diverting, calls • 82

DTMF tones, send • 29

E-mails

creating/sending • 51

setting • 62

viewing • 56

Emergency calls • 94

FDN (Fixed Dialling Number)

mode

creating contact list • 33

setting • 87

File manager • 65

Games • 41

Greeting message • 78

Health and safety • 910

Holding, call • 27

Icons, description • 10

Images, downloaded • 65

Inbox, messages

e-mail • 56

MMS • 54

SMS • 53

Input mode, change • 23

International calls • 25

Java world • 41

108

Index

Key tone volume • 80

Keypad tones

muting/sending • 29

selecting • 80

Language, select • 78

Last number, redial • 25

Locking

media contents • 87

phone • 87

SIM card • 87

Low battery indicator • 8

Memory status

calendar data • 69

downloaded items • 68

games 41

phonebook 37

shared memory • 88

Message tone • 81

Messages

configuration • 54

e-mail • 51

greeting • 78

MMS • 50

SMS • 49

web • 54

Minute minder • 81

Missed alarm events • 71

Missed calls • 31

MMS messages

creating/sending • 50

deleting • 54

setting • 60

viewing • 52

MP3 player

downloading • 37

options • 38

playing • 38

Multi-party calls • 30

Music, downloaded • 67

Muting

key tones • 29

microphone • 28

My name card • 36

Names

entering • 23

searching • 33

Network band, select • 84

Network selection • 83

Outbox, messages • 55

Password

call barring • 82

phone • 87

Phone

care and maintenance •

display • 10

icons • 10

locking • 87

password • 87

resetting • 88

switching on/off • 8

unpacking • 6

Phonebook

copying • 33

deleting • 36

editing • 33

managing • 36

options • 33

speed-dialling • 35

Photos

deleting • 65

taking • 72

viewing • 75

PIM sync • 43

PIN, change • 87

PIN2, change • 87

Power on/off tone • 81

Printing

contact • 33

events • 71

name card • 36

photo • 66, 75

Privacy • 87

Problems, solve • 88

Quiet mode • 81

Received calls • 31

Received messages

e-mail • 56

Recording

videos • 75

voice memos • 39

Redialling

automatically • 79

109

Index

manually • 25

Resetting phone • 88

Ringer

incoming calls • 80

messages • 81

Road safety • 92

Roaming • 83

Safety

information • 91

Security, calls • 86

Sent messages • 56

SIM card

inserting • 7

locking • 87

SMS messages

creating/sending • 49

deleting • 53

viewing • 52

Sound settings • 80

Sounds, downloaded • 67

Speed-dial • 35

Stopwatch • 45

Switching on/off

microphone • 28

phone • 8

Template

MMS 58

text • 58

Text, enter • 23

Timer • 45

Videos

recording • 75

Voice clarity, microphone • 28

Voice mail server

connecting • 83

editing • 83

Voice memos

playing • 39

recording • 39

Voice recorder • 39

Waiting call • 83

WAP browser

access • 46

bookmarks • 47

cache, clear • 47

World time • 42

110

Samsung Electronics Co SGHE760 Single-Band PCS GSM Phone w/ Bluetooth Transmitter User Manual

Samsung Electronics Co Ltd Single-Band PCS GSM Phone w/ Bluetooth Transmitter Users Manual

Users Manual

Navigation menu

Namespaces

Views

Navigation
