SGHE870 User Manual HTML Version

Users Manual

World Wide Web

http://www.samsungmobile.com

Printed in Korea

Code No.:GH68-xxxxxA

English. 12/2005. Rev. 1.0.

* Depending on the software installed or your service provider or country,

some of the descriptions in this guide may not match your phone exactly.

* Depending on your country, your phone and accessories may appear

different from the illustrations in this guide.

SGH-E870

User’s Guide

Draft

2005. 11. 09

(Version:E870XXEK1)

Important

safety

precautions

Failure to comply with the following

precautions may be dangerous or illegal.

Drive safely at all times

Do not use a hand-held phone while driving. Park

the vehicle first.

Switch off the phone when refuelling

Do not use the phone at a refuelling point (service

station) or near fuels or chemicals.

Switch off in an aircraft

Wireless phones can cause interference. Using them

in an aircraft is both illegal and dangerous.

Switch off the phone near all medical

equipment

Hospitals or health care facilities may be using

equipment that could be sensitive to external radio

frequency energy. Follow any regulations or rules in

force.

Important safety precautions

Interference

All wireless phones may be subject to interference,

which could affect their performance.

Be aware of special regulations

Meet any special regulations in force in any area and

always switch off your phone whenever it is forbidden

to use it, or when it may cause interference or danger.

Water resistance

Your phone is not water-resistant. Keep it dry.

Sensible use

Use only in the normal position (held to the ear). Avoid

unnecessary contact with the antenna when the phone

is switched on.

Emergency calls

Key in the emergency number for your present

location, then press .

Keep your phone away from small children

Keep the phone and all its parts, including accessories,

out of the reach of small children.

Accessories and batteries

Use only Samsung-approved accessories and

batteries. Use of any unauthorised accessories could

damage your phone and may be dangerous.

Qualified service

Only qualified service personnel may repair your

phone.

For more detailed safety information, see "Health and

safety information" on page 97.

• The phone could explode if the battery is replaced

with an incorrect type.

• Dispose of used batteries according to the

manufacturer’s instructions.

About this Guide

This User’s Guide provides you with condensed

information about how to use your phone. To quickly

learn the basics for your phone, please refer to “Get

started” and “Step outside the phone.”

In this guide, the following instruction icons appear:

Indicates that you need to pay careful attention

to the subsequent information regarding safety

or phone features.



Indicates that you can get more information on

the referenced page.

→

Indicates that you need to press the Navigation

keys to scroll to the specified option and then

select it.

[ ]

Indicates a key on the phone. For example,

[]

< >

Indicates a soft key, whose function is displayed

on the phone screen. For example, <

• Camera and camcorder

Use the camera module on your

phone to take a photo or record a

video.

Special

features of your phone

•MP3 player

Play MP3 files using your phone as

an MP3 player.

• File viewer

Open documents in various formats

on the phone without corruption.

•Web browser

Access the wireless web to get up-

to-the-minute information and a

wide variety of media content.

Special features of your phone

• Image editor

Crop, resize, rotate, and decorate

your photos.

• Voice commands

Experience a new level of voice

command capability that allows for

easy hands-free use. You can select

menus, control camera settings,

enter alarms, as well as make phone

calls without any key presses.

•Bluetooth

Transfer media files and personal

data and connect to other devices

using free, wireless Bluetooth

technology.

• Photo printing

Print your photos to preserve your best moments

forever.

• Multimedia Message Service (MMS)

Send and receive MMS messages with a

combination of text, image, video, and audio.

•E-mail

Send and receive e-mails with image, video, and

audio attachments.

• Phone to TV

View photos and video clips

captured with the phone on your TV

screen.

•Java

Enjoy Java

™

-based embedded

games and download new games.

•VibeTonz™

Use the enhanced vibration feature,

which allows the phone to vibrate

rhythmically.

Contents

Unpack 6

Make sure you have each item

Your phone 6

Buttons, features, and locations

Get started 7

First steps to operating your phone

Install and charge the phone ..................................... 7

Power on or off........................................................ 8

Keys and display ..................................................... 9

Access menu functions ............................................ 11

Customise your phone............................................. 12

Make/Answer calls .................................................. 14

Step outside the phone 15

Begin with your camera, the MP3 player, the web, and other

special features

Use the camera ...................................................... 15

Play MP3s .............................................................. 16

Browse the web...................................................... 17

Use Phonebook ...................................................... 17

Send messages ...................................................... 19

View messages....................................................... 20

Use Bluetooth ........................................................ 22

Use Voice Commands.............................................. 23

Use a memory card................................................. 24

Enter text 26

AB, T9, Number, and Symbol mode

Call functions 28

Advanced calling features

Menu functions 32

All menu options listed

Solve problems 95

Help and personal needs

Health and safety information 97

Index 104

Overview of menu functions

To access Menu mode, press <

> in Idle mode.

1 Call log



p. 32

1 Recent contacts

2 Missed calls

3 Dialled calls

4 Received calls

5 Delete all

6 Call time

7 Call cost



p. 32



p. 33



p. 33



p. 33



p. 33



p. 33



p. 34

2 Phonebook



p. 34

1 Contact list

2 Add new contact

3 Group

4 Speed dial

5 My name card

6 Own number

7 Management

8 Service number



p. 34



p. 35



p. 35



p. 36



p. 37



p. 37



p. 37



p. 38

3 Applications



p. 38

1 MP3 player

2 Voice recorder

3 Image editor

4 Java world

5 World clock

6 Alarm

7 Voice Commands

8 Calculator

9 Converter

10 Timer

11 Stopwatch

12 Key management

13 SIM AT



p. 38



p. 41



p. 42



p. 44



p. 44



p. 45



p. 46



p. 48



p. 48



p. 48



p. 49



p. 49



p. 49

4 Browser



p. 49

1 Home

2 Enter URL

3 Bookmarks

4 Saved pages

5 History

6 Clear cache

7 Browser settings



p. 50



p. 51



p. 51



p. 52



p. 52



p. 52



p. 52

5 Messaging



p. 52

1 Create message

2 My messages

3 Templates

4 Delete all

5 Settings

6 Memory status



p. 52



p. 55



p. 59



p. 60



p. 61



p. 66

6 File manager



p. 66

1 Images

2 Videos

3 Music

4 Sounds

5 Other files

6 Memory card

7 Memory status



p. 66



p. 68



p. 69



p. 70



p. 70



p. 72



p. 72

7 Calendar



p. 72

8 Camera



p. 76

9 Settings



p. 83

1 Time and date

2 Phone settings

3 Display settings

4 Sound settings

5 Light settings

6 Network services

7 Bluetooth

8 Security

9 Connection settings

10 Reset settings



p. 83



p. 83



p. 84



p. 85



p. 87



p. 87



p. 90



p. 92



p. 93



p. 95

* Shows only if supported by your

SIM card.

** Shows only if a memory card is

inserted.

Unpack

Make sure you have each item

You can obtain various accessories from

your local Samsung dealer.

Phone Travel Adapter

Battery User’s Guide

The items supplied with your phone

and the accessories at your Samsung

dealer may vary, depending on your

country or service provider.

Your phone

Buttons, features, and locations

Camera key

Earpiece

Power on/off/

Menu exit key

Microphone

Camera lens

Flash

External

display

Right soft key

Navigation keys

(Up/Down/Left/

Right)

Web access/

Confirm key

Delete key

Memory card

slot

Special

function keys

Left soft key

Headset jack

Volume keys

Dial key

Alphanumeric

keys

Display

Get started

First steps to operating your phone

SIM card information

When you subscribe to a cellular network, you receive

a plug-in SIM (Subscriber Identity Module) card

loaded with your subscription details, such as your

PIN, and available optional services.

Install and charge the phone

Remove the battery.

If the phone is already

on, first turn it off by

holding [ ].

Insert the SIM card.

Make sure that the gold-

coloured contacts on the

card face down into the

phone.

Install the battery. Replace the cover.

Plug the travel adapter into the phone.

Get started

Low battery indicator

When the battery is low:

• a warning tone sounds,

• the low battery message displays, and

• the empty battery icon blinks.

If the battery level becomes too low, the phone

automatically turns off. Recharge your battery.

Power on or off

When the phone is completely charged (the

battery icon becomes still), unplug the adapter

from the power outlet.

Remove the adapter from the phone.

Switch on

Do not turn on

the phone when

mobile phone

use is prohibited.

1. Open the phone.

2. Press and hold [ ] to turn on

the phone.

3. If necessary, enter the PIN and

press <

Switch off

1. Open the phone.

2. Press and hold [ ].

Get started

Keys and display

Keys

Perform the function indicated on the bottom

line of the display.

In Idle mode, access your favourite menus

directly.



p. 83

In Menu mode, scroll through menu options.

In Idle mode, launch the web browser.

In Menu mode, select the highlighted menu

option or confirm input.

Make or answer a call.

In Idle mode, retrieve the recent numbers

dialled, missed, or received.

Delete characters from the display, or an

item in an application.

End a call.

Press and hold to switch the phone on or off.

In Menu mode, cancel input and return the

phone to Idle mode.

Enter numbers, letters, and some special

characters.

In Idle mode, press and hold

[1]

to access

your voicemail server. Press and hold [

] to

enter an international call prefix.

Enter special characters.

In Idle mode, press and hold [ ] to activate

or deactivate Quiet mode. Press and hold

[ ] to enter a pause between numbers.

Adjust the phone volume.

In Idle mode, with the phone open, adjust

the keypad tone volume.

With the phone closed, press and hold [

]

to get a verbal time check. Press and hold

[

]

to turn on the external display or

flashlight.

In Idle mode, press and hold to turn on the

camera.

In Camera mode, take a photo or record a

video.

Get started

Display

Layout

Icons

Received signal strength

Call in progress

Out of your service area; you

cannot make or receive calls

GPRS network

Connecting to GPRS network

Connected to Internet

Text and graphics

display messages,

instructions, and

information you enter.

Soft key function

indicators

show the current functions

assigned to the soft keys.

Menu Contacts

Icons

display various icons.

Roaming network

New message

New e-mail

New voicemail

Call diverting feature active

Home Zone, if registered for the

appropriate service

Office Zone, if registered for the

appropriate service

Bluetooth active

Connected to Bluetooth hands-free

car kit or headset

Synchronised with PC

MP3 playback in progress

MP3 playback paused

Get started

Access menu functions

Memory card inserted

Alarm set

Ringer type setting



p. 85

• : VibeTonz & Melody

•

None

Melody

•: VibeTonz

• : VibeTonz then Melody

Quiet mode (VibeTonz)

Quiet mode (Mute)

Mute mode, during a call

Battery power level

* Depending on your country or service provider, the

icons shown on the display may vary.

Use the soft

keys

The roles of the soft keys vary

depending on the function you are

using. The bottom line of the

display indicates their current role.

Press the left

soft key to select

the highlighted

option.

Press the right

soft key to return

to the previous

menu level.

Select Back

Get started

Customise your phone

Select an

option

1. Press the appropriate soft key.

2. Press the Navigation keys to

move to the next or previous

option.

3. Press <

Select

> or [ ] to

confirm the function displayed

or option highlighted.

4. To exit, choose either of the

following methods.

• Press <

Back

> to move up

one level.

• Press [ ] to return to Idle

mode.

Use shortcuts

Press the number key

corresponding to the option you

want. For the index numbers 10, 11

and 12, press [

], [ ] and [ ],

respectively.

1. In Idle mode, press <

and select

Settings

→

Phone

settings

→

Language

2. Select a language.

1. In Idle mode, press <

and select

Settings

→

Sound

settings

→

Incoming call

→

Ringtone

2. Select a ringtone category.

3. Select a ringtone.

4. Press <

Save

Display

language

Call ringer

melody

Get started

You can set wallpaper for the idle

screen on each display.

1. In Idle mode, press <

and select

Settings

→

Display

settings

→

Wallpaper

→

Main

display

Cover display

2. Select an image or a video

category.

3. Select an image or a video.

4. Press <

Select

5. Press <

Save

You can change the colour for the

display components, such as title

bars and highlight bars.

1. In Idle mode, press <

and select

Settings

→

Display

settings

→

Skin

2. Select a colour pattern.

Idle mode

wallpaper

Menu mode

skin colour

You can set the Navigation keys as

shortcuts to access your favourite

menus.

1. In Idle mode, press <

and select

Settings

→

Phone

settings

→

Shortcuts

2. Select a key.

3. Select a menu to be assigned to

the key.

You can switch the phone to Quiet

mode to avoid disturbing other

people.

Press and hold [ ] in Idle mode.

shortcuts

Quiet mode

Get started

Make/Answer calls

You can protect the phone against

unauthorised use with a phone

password. The phone will require

the password on power-up.

1. In Idle mode, press <

and select

Settings

→

Security

→

Change

password

2. Enter the default password,

00000000

, and press <

3. Enter a new 4- to 8-digit

password and press <

4. Enter the new password again

and press <

5. Select

Phone lock

6. Select

Enable

7. Enter the password and press

Phone lock

1. In Idle mode, enter an area

code and phone number.

2. Press [ ].

3. To end the call, press [ ].

1. When the phone is ringing,

press [ ].

2. To end the call, press [ ].

Press [ / ].

Make a call

Answer a call

Adjust the

volume during

a call

Step outside the phone

Begin with your camera, the MP3 player, the web, and

other special features

Use the camera

1. Open the phone.

2. In Idle mode, press and hold

[

]

to turn on the camera.

3. Aim the lens at the subject and

adjust the image.

4. Press [ ] to take a photo. The

photo is saved automatically.

Pres

s <

Preview

> to

take

another photo.

1. In Idle mode, press <

and select

File manager

→

Images

→

Photos

2. Select the photo you want.

Take a photo

View a photo

1. In Idle mode, press and hold

[ ] to turn on the camera.

2. Press [

] to switch to Record

mode.

3. Press [ ] to start recording.

4. Press [ ] or < > to stop

recording. The video is saved

automatically.

5. Press <

Preview

> to record

another video.

In Idle mode, press <

and select

File manager

→

Videos

→

Video clips

2. Select the video you want.

Record a video

Play a video

Step outside the phone

Play MP3s

Use these methods:

• Download from the wireless

web



p. 49

• Download from a computer

using the optional Samsung PC

Studio



Samsung PC Studio

User’s Guide

• Receive via Bluetooth



p. 92

• Copy to a memory card and

insert the card into the phone.



p. 24

1. In Idle mode, press <

and select

Applications

→

MP3 player

2. Press <

Options

> and select

Add music from

→

Phone

Memory card

Copy MP3 files

to the phone

Create a play

list

3. Press [ ] to select the files

you want and press <

Select

4. Press <

Back

> to return to the

MP3 player screen.

1. From the MP3 player screen,

press [ ].

2. During playback, use the

following keys:

•: pauses or resumes

playback.

• Left: moves back to the

previous file.

• Right: skips to the next file.

• Up: opens the play list.

• / : adjusts the volume.

• Down: stops playback.

Play MP3 files

Step outside the phone

Browse the web

Using a built-in web browser, you can get easy access

to the wireless web to get a variety of up-to-date

services and information and to enjoy downloads of

web content.

Use Phonebook

In Idle mode, press [ ].

• To scroll through browser items,

press [Up] or [Down].

• To select an item, press [ ].

• To return to the previous page,

press <

Back

• To move to the next page, press

Options

> and select

→

Forward

• To access options, press

Options

Launch the

web browser

Navigate the

web

To the phone’s memory:

1. In Idle mode, enter a phone

number and press <

Options

2. Select

Save contact

→

Phone

→

a number type.

3. Specify contact information:

First name, Last name, Mobile,

Home, Office, Fax, Other, Email,

Caller ID, Ringtone, Group, and

Memo.

4. Press <

Save

> to save the

entry.

Add an entry

Step outside the phone

To the S I M c a r d :

1. In Idle mode, enter a phone

number and press <

Options

2. Select

Save contact

→

SIM

3. Enter a name.

4. Press <

Save

> to save the

entry.

1. In Idle mode, press

Contacts

2. Enter the first few letters of the

name you want.

3. Select a contact.

4. Scroll to a number and press

[]

to dial, or press [ ] to

edit contact information.

Add an entry

(continued)

Find an entry

1. In Idle mode, press <

and select

Phonebook

→

name card

2. Specify your contact

information.

3. Press <

Save

> to save the

name card.

4. To send the name card to other

people, press <

Options

> and

select

Send via

→

a sending

method.

Create and

send a name

card

Step outside the phone

Send messages

1. In Idle mode, press <

and select

Messaging

→

Create message

→

Text

message

2. Enter the message text.

3. Press <

Options

> and select

Save and send

Send only

4. Enter destination numbers.

5. Press [ ] to send the

message.

1. In Idle mode, press <

and select

Messaging

→

Create message

→

Multimedia message

2. Select

Subject

3. Enter the message subject and

press [ ].

Send a text

message (SMS)

Send a

multimedia

message

(MMS)

4. Select

Image and video

Sound

5. For

Image and video

, select

Add image

Add video

and

add an image or video clip.

For

Sound

, select

Add sound

and add a sound clip.

6. Select

Message

7. Enter the message text and

press [ ].

8. Press <

Options

> and select

Send

9. Enter destination numbers or

addresses.

10. Press [ ] to send the

message.

Step outside the phone

View messages

1. In Idle mode, press <

and select

Messaging

→

Create message

→

2. Select

Subject

3. Enter the e-mail subject and

press [ ].

4. Select

Message

5. Enter the e-mail text and press

[].

6. Select

File attached

7. Add image, video, sound, music

files, or document files.

8. Press <

Options

> and select

Send

9. Enter e-mail addresses.

10. Press [ ] to send the e-mail.

Send an e-mail

When a notification appears:

1. Press <

View

2. Select the message from the

Inbox.

From the Inbox:

1. In Idle mode, press <

and select

Messaging

→

messages

→

Inbox

2. Select an SMS message ( ).

View a text

message

Step outside the phone

When a notification appears:

1. Press <

View

2. Press <

Options

> and select

Retrieve

3. Select the message from the

Inbox.

From the Inbox:

1. In Idle mode, press <

and select

Messaging

→

messages

→

Inbox

2. Select an MMS message ( ).

View a

multimedia

message

1. In Idle mode, press <

and select

Messaging

→

messages

→

Email inbox

2. Select an account.

3. Press <

Yes

> to download new

e-mails or headers.

4. Select an e-mail or a header.

5. If you selected a header, press

Options

> and select

Retrieve

View an e-mail

Step outside the phone

Use Bluetooth

Your phone is equipped with Bluetooth technology

which enables you to connect the phone wirelessly to

other Bluetooth devices and exchange data with them,

talk hands-free, or control the phone remotely.

In Idle mode, press <

> and

select

Settings

→

Bluetooth

→

Activation

→

1. In Idle mode, press <

and select

Settings

→

Bluetooth

→

My devices

→

Search for new devices

2. Select a device.

3. Enter a Bluetooth PIN or the

other device’s Bluetooth PIN, if

it has one, and press <

When the owner of the other

device enters the same code,

pairing is complete.

Turn on

Bluetooth

Search for and

pair with a

Bluetooth

device

1. Access an application,

Phonebook

File manager

, or

Calendar

2. Scroll to an item.

3. Press <

Options

> and select

Send via

→

Bluetooth

4. Select a device.

5. If necessary, enter the

Bluetooth PIN and press <

To receive data via Bluetooth, your

phone’s Bluetooth feature must be

active.

If necessary, press <

Yes

> to

confirm the reception.

Send data

Receive data

Step outside the phone

Use Voice Commands

Your phone can recognise specific voice commands in

order to dial a number or search for names in

Phonebook, or access menus. Your phone recognises

only English, French, German, Italian, Spanish, and

Russian.

1. In Idle mode, press <

and select

Applications

→

Voice Commands

→

Name

dial

2. At the voice prompt, say a

name.

3. If necessary, say “Next” or

“Previous” to select the name

you want.

4. If the name has more than one

number, press [Left] or [Right]

to select the number you want.

5. Say nothing for 3 seconds or

press [ ] and the phone will

dial the currently selected

number.

Dial a name

1. In Idle mode, press <

and select

Applications

→

Voice Commands

→

Name

2. At the voice prompt, say a

name.

3. If necessary, say “Next” or

“Previous” to select the name

you want.

4. Say nothing for 3 seconds or

press [ ] and the phone will

display contact information.

Search for a

name

Step outside the phone

Use a memory card

You can use an optional microSD memory card to

enlarge your phone’s memory capacity.

1. In Idle mode, press <

and select

Applications

→

Voice Commands

→

Direct

2. At the voice prompt, say a

menu name, for example,

Phonebook.

3. Say nothing for 3 seconds or

press [ ] and the phone will

open the menu.

Access a menu

• Frequent erasing and writing will

shorten a card’s lifespan.

• Do not remove a card from the

phone or turn off the phone

while data is being accessed or

transferred. This could result in

loss of data and/or damage to

the card or phone.

• Do not subject cards to strong

shocks.

• Do not touch card terminals with

your fingers or metal objects. If

dirty, wipe the card with a soft

cloth.

Important

memory card

information

Step outside the phone

• Keep cards away from small

children or pets.

• Do not expose cards in a place

subject to electro static

discharge and/or electrical

noise.

1. Insert the card into the card

slot, with the label side face

down.

2. Push the card in with your

thumb until it locks into place.

Insert a

memory card

Using a card adapter and a USB

card reader/writer, you can read

the card on a PC.

1. Insert a memory card into a

card adapter, and then the

adapter into a card reader/

writer.

2. Plug the USB connecter of the

card reader/writer into the USB

port on your PC.

3. Access the appropriate memory

disk and copy to and from the

card.

If a file name is more than 32

characters, the file will not display

on the phone.

Use a card

adapter

Enter text

AB, T9, Number, and Symbol mode

You can enter text for some features, such as

Messaging, Phonebook, or Calendar, using AB mode,

T9 mode, Number mode, and Symbol mode.

Changing the text input mode

• Press and hold [ ] to switch between T9 mode

( ) and AB mode ( ). Depending on your

country, you may also be able to access an input

mode for your specific language.

• Press [ ] to change case or switch to Number

mode ( ).

• Press and hold [ ] to switch to Symbol mode.

Using AB mode

Press the appropriate key until the character you want

appears on the display.

(Creating an SMS message with GSM-Alphabet encoding)

Characters in order displayed

Key Upper case Lower case

Enter text

Tips for using AB mode

• To enter the same letter twice or to enter a

different letter on the same key, wait for the cursor

to move to the right automatically or press [Right].

Then, enter the next letter.

• Press [ ] to insert a space.

• Press the Navigation keys to move the cursor.

•Press [

] to delete characters one by one. Press

and hold [

] to clear the display.

Using T9 mode

T9 is a predictive text input mode that allows you to

key in any character using single keystrokes.

Entering a word in T9 mode

1. Press [

] to [

]

to start entering a word. Press

each key once for each letter.

For example, press [

], [

], and [

] to

enter Hello in T9 mode.

T9 predicts the word that you are typing, and it

may change with each key that you press.

2. Enter the whole word before editing or deleting

characters.

3. When the word displays correctly, go to step 4.

Otherwise, press [

] to display alternative word

choices for the keys that you have pressed.

For example, Of and Me use [

] and [

4. Press [ ] to insert a space and enter the next

word.

Tips for using T9 mode

• Press [

] to enter periods or apostrophes

automatically.

• Press [ ] to insert a space.

• Press the Navigation keys to move the cursor.

• Press [

] to delete characters one by one. Press

and hold [

] to clear the display.

Adding a new word to the T9 dictionary

This feature may not be available for some languages.

1. Enter the word that you want to add.

2. Press [

] to display alternative words for your key

presses. When there are no more alternative

words,

Add

appears on the bottom line.

3. Press <

Add

4. Enter the word you want using AB mode and press

Using Number mode

Number mode enables you to enter numbers.

Press the keys corresponding to the digits you want.

Using Symbol mode

Symbol mode enables you to insert symbols.

Call functions

Advanced calling features

Making a call

1. In Idle mode, enter the area code and phone

number.

2. Press [ ].

Making an international call

1. In Idle mode, press and hold [

]. The

character

appears.

2. Enter the country code, area code, and phone

number, then press [ ].

Redialling recent numbers

1. In Idle mode, press [ ] to display the list of

recent numbers.

2. Scroll to the number you want and press [ ].

To Press

display more symbols [Up] or [Down].

select a symbol the corresponding

number key.

clear the entered symbols [

insert the symbols <

• Press [

] to clear the last digit or press and hold

[

] to clear the whole display. You can move the

cursor to edit an incorrect digit.

• Press and hold [ ] to enter a pause between

numbers.

Call functions

Making a call from Phonebook

Once you have stored a number in Phonebook, you

can dial the number by selecting it from

Phonebook.



p. 34

You can also use the speed dial feature to assign your

most frequently called numbers to specific number

keys.



p. 36

You can quickly dial a number from the SIM card using

its location number assigned when stored.

1. In Idle mode, enter a location number and press

[].

2. Press [Left] or [Right] to scroll through other

numbers.

3. Press <

Dial

> or [ ] to dial the number you want.

Voice dialling

You can dial a number stored in Phonebook by

speaking the associated name into the microphone.



p. 46

Ending a call

Close the phone or press [ ].

Answering a call

When you receive an incoming call, the phone rings

and displays the incoming call image.

Press <

> or [ ] to answer the call.

Tips for answering a call

• When

Anykey

answer

is active, you can press

any key, except for <

Reject

> and [ ].



p. 84

• When

Active flip

is active, you can simply open

the phone.



p. 84

• Press <

Reject

> or [ ] to reject a call.

• Press and hold [ / ] to reject a call or mute the

ringer, depending on the

Volume key

setting.



p. 84

Viewing missed calls

If you have missed calls, the screen displays how

many calls you have missed.

1. Press <

View

2. If necessary, scroll through the missed calls.

3. Press [ ] to dial the number you want.

Call functions

Using the headset

Use the headset to make or answer calls, or to start

the voice dialling feature without holding the phone.

Connect the headset to the jack on the left side of the

phone. The button on the headset works as listed

below:

Options during a call

You can access a number of functions during a call.

Adjusting the volume during a call

Use [ / ] to adjust the earpiece volume during a call.

Press [ ] to increase the volume level and [ ] to

decrease the volume level.

Placing a call on hold/Retrieving

Press <

Hold

> or <

Retrieve

> to place a call on hold

or retrieve the call.

Making a second call

You can make another call if your network supports it.

1. Press <

Hold

> to put the call on hold.

2. Make the second call in the normal way.

3. Press <

Swap

> to switch between the calls.

4. Press <

Options

> and select

End

held

call

to end

the call on hold.

5. To end the current call, press [ ].

Answering a second call

You can answer an incoming call while already on the

phone, if your network supports it and you have

activated the call waiting feature.



p. 88

1. Press [ ] to answer the call. The first call is

automatically put on hold.

2. Press <

Swap

> to switch between the calls.

To Press

redial the last call the button twice.

answer a call the button.

end a call the button.

start voice dialling and hold the button.



p. 46

Call functions

3. Press <

Options

> and select

End

held

call

to end

the call on hold.

4. To end the current call, press [ ].

Using the Speakerphone feature

Use your phone as a speaker phone to talk and listen

with the phone a short distance away.

Press [ ] and then <

Yes

> to activate the

Speakerphone feature. Press [ ] again to switch

back to the earpiece.

Using In-call options

Press <

Options

> to access the following options

during a call:

•

Speaker on

Normal

: turn on the Speakerphone

feature or switch back to Normal mode.

•

Switch to headset

Switch to phone

: switch the

call to a Bluetooth headset or hands-free car kit or

back to the phone.

•

: access the phone's menu functions.

•

Voice on

Voice off

: switch off the phone's

microphone so that the other person on the phone

cannot hear you, or switch it back on.

•

Mute keys

Send keys

: switch the key tones on

or off.

•

Send DTMF

: send the DTMF (Dual tone multi-

frequency) tones as a group. The DTMF tones are

the tones used in phones for tone dialling,

sounding when you press the number keys. This

option is helpful for entering a password or an

account number when you call an automated

system, like a banking service.

•

Phonebook

: access the contact list.

•

End held call

: disconnect the call currently on

hold.

•

Transfer

: transfer the currently active call to a

caller on hold. The two callers can talk to each

other, but you are disconnected from the call.

To communicate with answering machines or

computerised telephone systems,

Send keys

must be selected.

•

Join

: set up a multi-party call by adding a caller

on hold to a currently active call. You can include

up to 5 people on a multi-party call.

•

Select one

: select one of multi-party call

participants. You can then use the following

options:

Private

: have a private conversation with one

multi-party call participant. The other participants

can converse with each other. After the private

conversation, select

Join

to return to the

multi-party call.

Remove

: disconnect one multi-party call

participant.

Menu functions

All menu options listed

Call log

(Menu 1)

Use this menu to view the calls you have dialled,

received, or missed, and the length of calls. You can

also check the cost of your calls,

if your SIM card

supports this function.

To access this menu, press <

> in Idle mode and

select

Call log

Recent contacts

(Menu 1.1)

This menu displays the most recent calls dialled,

received, or missed.

Accessing a call record

1. Press [Left] or [Right] to move to another call

type.

2. Press [Up] or [Down] to scroll through the call list.

Menu functions

Call log

(Menu 1)

3. Press [ ] to view the details of a call, or [ ] to

dial a number.

Using call record options

While viewing call details, press <

Options

> to access

the following options:

•

Call

: edit the number and dial it.

•

Save contact

: save the number to Phonebook.

•

Send message

: send an SMS or MMS message to

the selected number.

•

Delete

: delete the selected call record or all

records.

Missed calls

(Menu 1.2)

This menu displays the most recent calls you did not

answer.

Dialled calls

(Menu 1.3)

This menu displays the most recent calls you have

dialled.

Received calls

(Menu 1.4)

This menu displays the most recent calls you have

received.

Delete all

(Menu 1.5)

Use this menu to delete all of the records in each call

type.

1. Press [ ] to select the call types to be cleared.

2. Press <

Delete

3. Press <

Yes

> to confirm the deletion.

Call time

(Menu 1.6)

This menu displays the time log for calls made and

received. The actual time invoiced by your service

provider will vary.

•

Last

call

time

: check the length of your last call.

•

Total

dialled calls

: check the total length of all

the calls you have dialled.

•

Total

received calls

: check the total length of all

the calls you have received.

Menu functions

To reset the call timers, press <

Reset

>. You need to

enter the phone password.

Call cost

(Menu 1.7)

This network feature displays the cost of calls. This

menu is available only if supported by your SIM card.

Note that this is not intended to be used for billing

purposes.

•

Last

call

cost

: check the cost of your last call.

•

Total

cost

: check the total cost of all of your calls.

If the total cost exceeds the maximum cost set in

Set

max.

cost

, you must reset the counter before

you can make another call.

•

Max.

cost

: check the maximum cost limit set in

Set

max.

cost

•

Reset

counters

: reset the cost counters.

•

Set

max.

cost

: set the maximum cost authorised

for your calls.

•

Price/Unit

: set the price per unit that is applied

when the cost of your calls is calculated.

Phonebook

(Menu 2)

You can store phone numbers on your SIM card and in

your phone’s memory. The SIM card and phone’s

memory are physically separate, but they are used as

a single entity called Phonebook.

To access this menu, press <

> in Idle mode and

select

Phonebook

Contact list

(Menu 2.1)

Use this menu to search for numbers in Phonebook.

Finding an entry

1. Enter the first few letters of the name that you

want to find.

2. Select the name from the list.

3. Scroll to a number and press [ ] to dial, or press

[ ] to edit contact information.

Using Phonebook options

While viewing contact details, press <

Options

> to

access the following options:

•

Edit

: edit contact information.

The password is preset to

00000000

. You can

change this password.



p. 93

Menu functions

Phonebook

(Menu 2)

•

Send message

: send an SMS or MMS message to

the selected number, or an e-mail to the selected

address.

•

Copy to

: copy the contact to the phone’s memory

or to the SIM card.

•

Send via

: send the contact via SMS, MMS, e-mail,

or Bluetooth.

•

Delete

: delete the selected contact.

Add new contact

(Menu 2.2)

Use this menu to add a new contact to Phonebook.

Storing a number in the phone’s memory

1. Select

Phone

2. Change the settings or enter information about the

contact.

•

First name

Last name

: assign a name.

•

Mobile

Home

Office

Fax

Other

: add a

number in any type.

•

: assign an e-mail address.

•

Caller ID

: assign an image or video to alert

you to a call from the person.

•

Ringtone

: assign a ringtone to alert you to a

call from the person.

•

Group

: assign the number to a caller group.

•

Memo

: add a memo about the person.

3. Press <

Save

> to save the contact.

Storing a number on the SIM card

1. Select

SIM

2. Enter information about the contact.

•

Name

: assign a name.

•

Phone number

: add a number.

•

Location

: assign a location number.

3. Press <

Save

> to save the contact.

Group

(Menu 2.3)

Use this menu to organise your contacts in caller

groups.

To assign a caller ID image or video, ringtone, or

group, the contact must be saved to the phone’s

memory.

Menu functions

Creating a new caller group

1. Press <

Options

> and select

Add

2. Enter a name for the group.

3. Select the caller ID line and set an image or video.

4. Select the ringtone line and set a melody.

5. Press <

Save

> to save the group.

Adding members to a caller group

1. Select a group.

2. Press <

Add

3. Press [ ] to select the contacts to be added.

4. Press <

Select

Managing caller groups

While viewing the group list, press <

Options

> to

access the following options:

•

View

: display the members of the selected group.

•

Add

: add a new group.

•

Edit

: change the group properties.

•

Send message

: send an SMS, MMS, or e-mail

message to the group members you want.

•

Delete

: delete the selected group or all groups.

Group members, however, will not be deleted from

Phonebook.

Speed dial

(Menu 2.4)

Use this menu to assign a speed dial number (2 to 9)

for 8 of your most frequently called numbers.

Assigning speed dial numbers

1. Select a key location from

. Key

is reserved

for your voicemail server.

2. Select a contact from the contact list.

3. Select a number, if the contact has more than one

number.

Managing speed dial entries

From the Speed dial screen, press <

Options

> to

access the following options:

•

Add

: assign a number to an unassigned key.

•

View

: check the name and number assigned to a

key.

•

Change

: assign a different number to a key.

Menu functions

Phonebook

(Menu 2)

•

Remove

: clear the speed dial setting for a key.

Dialling speed dial entries

In Idle mode, press and hold the appropriate key.

My name card

(Menu 2.5)

Use this menu to create a name card and send it to

other people.

Saving your name card

The procedure for creating your name card is the

same as the one for saving a phone number in the

phone’s memory.



p. 35

Using name card options

After saving your name card, press <

Options

> to

access the following options:

•

Edit

: edit the name card.

•

Send via

: send the name card via SMS, MMS,

e-mail, or Bluetooth.

•

Exchange contact details

: exchange name cards

with another person via Bluetooth.

•

Delete

: delete the name card.

Own number

(Menu 2.6)

Use this feature to check your phone numbers, or to

assign a name to each of the numbers. Changes made

here do not affect the actual subscriber numbers on

your SIM card.

Management

(Menu 2.7)

Use this menu to manage Phonebook entries.

•

Saving location

: select a default memory location

for saving contacts. If you select

Always ask

, the

phone will ask you to select a memory location

each time you save a number.

•

Copy all to

: copy all of the contacts stored on the

SIM card to the phone’s memory, or vice versa.

•

Delete all

: delete all of the contacts from your

phone’s memory, your SIM card, or both.

•

Memory status

: check the number of contacts

you have stored in the phone’s memory and on the

SIM card.

Menu functions

Service number

(Menu 2.8)

Use this menu to view the list of Service Dialling

Numbers (SDN) assigned by your service provider,

including emergency numbers and numbers for

directory enquiries. This menu is available if your SIM

card supports SDN.

1. Scroll to the number you want and press <

View

2. Press <

Dial

> or [ ].

Applications

(Menu 3)

Use this menu to play music files, play Java games, or

edit photos. You can also use convenient features,

such as a voice command, voice recorder, alarm clock,

calculator, converter, and stopwatch.

To access this menu, press <

> in Idle mode and

select

Applications

MP3 player

(Menu 3.1)

Use this menu to enjoy music. First, you need to save

music files into your phone’s memory or on a memory

card. You can play MP3, AAC, and M4A files from the

phone’s memory, and MP3 files from the memory card.

To enjoy high quality music, you can use an optional

Bluetooth stereo headset.

Downloading or receiving music files

Use these methods to save music files to your phone’s

memory:

• Download from the wireless web



p. 49

• Download from a computer using the optional

Samsung PC Studio



Samsung PC Studio User’s

Guide

• Via an active Bluetooth connection



p. 92

• Copy to a memory card and insert the card into the

phone.



p. 25

The downloaded or received files are stored in the

Music

folder.



p. 69

Normal headsets are not compatible with the MP3

player.

Menu functions

Applications

(Menu 3)

Creating a play list

1. From the MP3 player screen, press <

Options

and select

Add music from

→

Phone

Memory

card

2. Press [ ] to select the files to be added and

press <

Select

3. Press <

Back

> to return to the MP3 player screen.

Playing music files

1. From the MP3 player screen, press <

Options

and select

Play

2. Select

Phone

to use the phone speaker.

Select

A/V headset

to use a Bluetooth headset,

and then search for and connect to the headset.

During playback, use the following keys:

Using MP3 player options

From the MP3 player screen, press <

Options

> to

access the following options:

•

Play

Pause

: begin or pause playback.

•

Transfer to phone

: switch the sound output to

the phone speaker.

•

Open

: access the play list of the current album or

album list. On the album list, you can set up

multiple albums.

Key Function

Pauses or resumes playback.

Left Moves back to the previous file.

Right Skips to the next file.

Up Opens the play list.

Down Stops playback.

/ Adjusts the volume level.

Turns 3D sound on or off.

Changes the playback animation.

Changes the repeat mode.

Changes the equaliser mode.

Changes the skin type.

Turns Shuffle mode on or off.

Key Function

Menu functions

•

Go to Music

: access the

Music

folder.

•

Send via

: send the file via e-mail or Bluetooth.

•

Set as

: set the file as your ringtone or as a

ringtone for a Phonebook entry.

•

Activate key

: get a licence key when the key for

the selected DRM files expires.

•

Remove from playlist

: remove the selected file

from the play list.

•

Settings

: change the default settings for playing

music files.

Repeat mode

: select a repeat mode.

Shuffle

: set the MP3 player to play music at

random.

MP3 overrides other sounds

: set the MP3 player

to continue playback even if you exit it.

Equaliser

: select an equaliser setting.

3D sound

: turn 3D sound on or off.

Visualisation

: change the playback animation.

Skin

: select a skin type.

Volume

: select a volume level.

•

Details

: access the file properties.

•

Key management

: manage the licence keys you

have acquired.

Accessing the play list

From the MP3 player screen, press [Up].

Press <

Options

> to access the following options:

•

Play

: play the currently selected file.

•

Add music from

: add files to the play list.

•

Go to album list

: access the album list.

•

Move to

: move the selected file to another album.

•

Copy to

: copy the selected file to another album.

•

Move track in playlist

: move the selected file to

the position you want within the play list.

•

Activate key

: get a licence key when the key for

the selected DRM file expires.

•

Remove

: remove the selected file or all files from

the play list.

•

Details

: access the file properties.

•

Key management

: manage the licence keys you

have acquired.

Menu functions

Applications

(Menu 3)

Playing MP3 files with the phone closed

Press and hold [ ] to launch the MP3 player. Use the

following keys to control the MP3 player:

Voice recorder

(Menu 3.2)

Use this menu to record voice memos. A voice memo

can be up to one hour long.

Recording a voice memo

1. Press [ ] to start recording.

2. Speak into the microphone.

Press [ ] to pause or resume recording.

3. Press <

Stop

> or [Down] to end recording. The

voice memo is saved automatically.

4. Press [ ] to review the voice memo, or [Up] to

record a new memo.

Playing a voice memo

1. From the Voice recorder screen, press <

Options

and select

Go to voice recorder files

2. Select a voice memo.

During playback, use the following keys:

Key Function

Begins or pauses playback. Close the MP3

player when held down.

Moves back to the previous file.

Skips to the next file.

/ Adjusts the volume.

Locks the exposed keys when held down

to keep accidental presses from affecting

playback.

Key Function

Pauses or resumes playback.

Left Moves backward in a memo.

Right Moves forward in a memo.

/ Adjusts the volume.

Down Stops playback.

Menu functions

Changing the recording mode

You can change the recording mode of the voice

recorder. The maximum recording time is determined

by this setting. Before recording a memo, press

Options

> and select

Settings

→

a recording mode:

•

Limit for multimedia message

: record a voice

memo for adding to an MMS message.

•

Limit for email

: record a voice memo for adding

to an e-mail.

•

Maximum 1 hour

: record a voice memo of up to

one hour.

Image editor

(Menu 3.3)

Use this menu to edit your photos using various

editing tools.

Applying an effect

1. Press <

Options

> and select

New image

→

Open

Take photo

2. Select a photo or take a new photo.

3. Press <

Options

> and select

Effects

→

an effect

option.

4. Press <

Done

5. Press <

Options

> and select

Save as

6. Enter a new file name and press <

Transforming

1. Select a photo or take a new photo.

2. Press <

Options

> and select

Transform

→

option:

•

Resize

: change the photo size.

•

Rotate

: rotate the photo 90 degrees.

•

Flip

: flip the photo.

3. Press <

Done

4. Press <

Options

> and select

Save as

5. Enter a new file name and press <

Cropping

1. Select a photo or take a new photo.

2. Press <

Options

> and select

Crop

3. Move the cropping frame to the area of the image

you want.

Press <

Options

> and select

Resize

to change the

frame size.

Menu functions

Applications

(Menu 3)

4. Press <

Options

> and select

Done

5. Press <

Options

> and select

Save as

6. Enter a new file name and press <

Adding visual features

You can decorate photos by adding a frame, an image,

or a note.

1. Select a photo or take a new photo.

2. Press <

Options

> and select

Insert

→

a feature

type.

3. Select an item or enter text to be inserted.

4. Adjust the position of the inserted item and press

Done

5. Press <

Options

> and select

Save as

6. Enter a new file name and press <

Merging a stamp effect

This editing tool allows you to make an outline stamp

of a photo and then merge it with another photo. You

can use this tool to create your own photo postcard by

taking a photo of a handwritten message and merging

it with a photo.

1. Select a photo or take a new photo.

2. Press <

Options

> and select

Merge stamp

. The

background photo appears in the box next to .

3. Press <

Options

> and select

Add image

4. Add a photo by selecting or taking a photo. The

added photo appears in the box next to . This

will be the stamp.

5. Press <

Options

> and select

Merge

. The stamp

photo is added to the background photo as an

outline.

6. Press <

Options

> to access the following stamp

edit options:

•

Resize

: change the stamp size.

•

Move

: change the position of the stamp.

•

Rotate

: rotate the stamp.

•

Stamp colour

: change the stamp colour.

•

Shadow on

: apply a shadow to the stamp.

7. When you have finished, press <

Options

> and

select

Done

8. Press <

Options

> and select

Save as

9. Enter a new file name and press <

Menu functions

Java world

(Menu 3.4)

Use this menu to access the embedded Java games

and downloaded Java applications.

Accessing an embedded game

1. Select

My games

→

a game.

2. If necessary, press [ ].

Using Java application options

From the application list, press <

Options

> to access

the following options:

•

Start

: launch the selected application.

•

Move to

: move the application to another folder.

•

Delete

: delete the selected application or all

applications, except for the embedded games.

•

Lock

Unlock

: lock the application to protect it

from being deleted, or unlock the application.

•

Details

: access the application properties.

•

Permissions

: set permission settings for services

charging you additional costs, such as network

access and SMS.

•

Upgrade

: upgrade the application to the latest

version.

•

Send information via SMS

: send the URL

containing the application via SMS.

•

Memory status

: access memory information for

applications.

•

Settings

: select a connection profile to be used for

applications requiring network access. You can also

add or edit a profile.



p. 93

World clock

(Menu 3.5)

Use this menu to set your local time zone and find out

what time it is in another part of the world.

Viewing world time

1. From the world map, press [Left] or [Right] to

scroll to the city you want. As the time line moves,

the time and date of the given zone display.

2. Press [ ] to save the city as your local time

zone.

Menu functions

Applications

(Menu 3)

Applying daylight savings time

1. From the world map, press <

Options

> and select

Set daylight saving time

2. Press [ ] to select the time zones you want.

3. Press <

Save

Alarm

(Menu 3.6)

Use this menu to set alarms. The alert type for a

normal alarm corresponds to the call alert type

settings. A wake-up alarm is not affected by your

sound settings.

Setting an alarm

1. Select the type of alarm.

2. Set each alarm option:

•

Alarm

: activate the alarm.

•

Alarm time

: enter the time for the alarm to

ring.

•

AM/PM

: select

in 12-hour format.

•

Repeat

: select a repeat option.

•

Alarm tone

: select an alarm tone.

3. Press <

Save

Setting an alarm verbally

You can use voice commands to set an alarm by

saying an alarm time.

1. Scroll to the type of alarm.

2. Press [ ] to activate the voice commands feature.

3. After the voice prompt, say the following voice

commands for the alarm time:

Your phone recognises only English, French,

German, Italian, Spanish, and Russian.

To Say

enter the hour for

an alarm

One to Twelve.

enter the minute for

an alarm

o’clock (for :00), Ten,

fifteen, Twenty, Thirty,

Forty, Forty five, or Fifty.

select AM or PM AM, PM, in the morning, in

the afternoon, in the

evening, or at night.

Menu functions

For example:

• To set an alarm for 7 AM, say “Seven AM” or

“Seven o’clock in the morning.”

• To set an alarm for 7:30 PM, say “Seven thirty

PM” or “Seven thirty in the evening.”

The phone recognises your voice command and

saves the alarm.

Stopping an alarm

• For a non-wake-up alarm, press any key.

• For a wake-up alarm, press <

Confirm

> or [ ].

Press any key, except <

Confirm

> and [ ], to

cause it to sound again after 5 minutes. You can do

this a maximum of 5 times.

Setting the alarm to ring even if the phone is

off

From the Alarm screen, select

Auto power

→

If the phone is off when it is time for the alarm to ring,

the phone switches on and sounds the alarm.

Voice Commands

(Menu 3.7)

Your phone provides a set of powerful voice-enabled

features that enhance its hands-free capabilities.

Name dial

(Menu 3.7.1)

Use this menu to make a phone call by saying any

name in Phonebook.

1. At the voice prompt, say a name.

Speak into the microphone for best results.

The phone recognises your voice command and

displays the search results.

2. If the phone displays 3 possible results, say “Next”

following the voice prompt until you hear the name

you want.

To go back to the name recited previously, say

“Previous.”

3. Say nothing for 3 seconds or press [ ] and the

phone will dial the currently selected number.

Your phone recognises only English, French,

German, Italian, Spanish, and Russian.

Menu functions

Applications

(Menu 3)

Name search

(Menu 3.7.2)

Use this menu to access a contact by saying any name

that is in Phonebook.

The procedures for name searching are the same as

for name dialling.

Direct menu

(Menu 3.7.3)

Use this menu to access the primary menus, such as

Phonebook and Camera, as well as the

Name dial

and

Name search

menus, directly, by saying the name of

the menu.

The procedures for opening menus are the same as for

name dialling.

Settings

(Menu 3.7.4)

Use this menu to customise various settings for the

voice commands feature.

•

Voice

Commands

: enable or disable the voice

command feature.

•

Command timeout

: set a time limit for your

phone to wait for your voice command.

•

Result display

: set how many candidates the

phone displays for a voice command search.

•

Voice guides

: turn on or off the voice messages

that guide you through the voice command

procedure.

•

Guides volume

: adjust the volume for the voice

guide messages.

•

Sensitivity level

: adjust the sensitivity with

which your phone recognises a voice command.

•

Activate names

: select Phonebook entries to be

dialled or accessed by voice command.

•

Activate menus

: select menu items to be

accessed by voice command. Selecting a primary

menu displays the submenus which are assigned

to the selected primary menu.

Help

(Menu 3.7.5)

Use this menu to view instructions for the voice

commands feature and customising its settings.

You can quickly access this menu by pressing and

holding the right soft key in Idle mode.

You can quickly access this menu by pressing and

holding the left soft key in Idle mode.

Menu functions

Calculator

(Menu 3.8)

Use this menu to perform basic arithmetic functions,

such as addition, subtraction, multiplication, and

division.

1. Enter the first number.

•Press <

.()

> to insert a decimal point or

bracket.

•

Press

[] or []

to move the cursor.

2. Press one of the Navigation keys to access the

math function you want.

3. Enter the second number.

4. Press [ ] to view the result.

5. If necessary, repeat from step 2 to continue the

calculation.

Converter

(Menu 3.9)

Use this menu for common conversions, such as

currency and temperature.

1. Select a converter.

2. Press [Left] or [Right] to select the original unit

and press [Down].

3. Enter the value to be converted and press [Down].

• Press [ ] to insert a decimal point.

• Press [ ] to change the temperature to above

zero (+) or below zero (-).

4. Press [Left] or [Right] to select the unit to which

you want to convert.

The equivalent value for the amount you entered

displays.

Timer

(Menu 3.10)

Use this menu to set a period of time for the phone to

count down. The phone will sound an alarm when the

specified period of time has expired.

Starting the timer

1. Press <

Set

2. Enter the length of time you want to count down

and press <

3. Press [ ] to start counting down.

For the currency converter, you can view and set

currency rates by pressing <

View rate

Menu functions

Browser

(Menu 4)

Stopping the timer

• Press any key when the timer rings.

• Press [ ] on the Timer screen to stop the timer

before it rings.

Stopwatch

(Menu 3.11)

Use this menu to measure elapsed time. The

maximum time is 10 hours.

1. Press [ ] to start the stopwatch.

2. Press [ ] to check an interval. You can repeat

this step for a total of 4 intervals.

Key management

(Menu 3.12)

Use this menu to manage the licence keys you have

acquired to activate media contents locked by DRM

systems.

Press <

Options

> to access the following options:

•

View

: open the corresponding media content.

•

Delete

: delete the selected licence key.

•

Go to My Messages

: access the message

containing the media content.

•

Go to My Items

: access the corresponding file

folder.

•

Details

: access the properties of the licence key.

SIM AT

(Menu 3.13)

This menu is available if you use a SIM AT card that

supports SIM Application Tool kit menus and provides

additional services, such as news, weather, sports,

entertainment, and location services. Available

services may vary, depending on your service

provider’s plans. For details, see your SIM card

instructions or contact your service provider.

Browser

(Menu 4)

The Wireless Application Protocol (WAP) browser on

your phone allows you to access the wireless web.

From the wireless web, you can access up-to-date

information and a wide variety of media content, such

as games, wallpapers, ringtones, and music files.

To access this menu, press <

> in Idle mode and

select

Browser

Menu functions

Home

(Menu 4.1)

Use this menu to connect your phone to the network

and load the homepage of the wireless web service

provider. You can also press [ ] in Idle mode.

Navigating the web

Using page options

From any web page, press <

Options

> to access the

following options:

•

Go to

: access the linked web page.

•

Go to homepage

: return to the homepage.

•

Keys to buy

: send a request for buying a licence

key for a DRM file. This option will be available only

when you access the web browser from a message

containing a DRM file.

•

Enter URL

: enter a URL address manually.

•

: move backward or forward through pages in

history.

•

Reload

: reload the current page with updated

information.

•

Bookmarks

: bookmark the current page or access

the bookmark list.

•

Send URL

: send the URL of the current page via

SMS or e-mail.

•

To DesktopView

To SmartFitView

: change the

display mode of the browser.

•

Save

: save the selected image or page.

•

Page details

: access the page properties.

•

Browser options

: change the various settings for

the browser.

To Press

scroll through browser

items

[Up] or [Down].

select a browser item [ ], or <

Options

and select

Go to

return to the previous

page

Back

>, or <

Options

and select

→

Back

move to the next page <

Options

> and select

→

Forward

Menu functions

Browser

(Menu 4)

Cache

: change the cache mode or clear the cache.

The cache is a temporary memory that stores

recently accessed web pages.

: change the cookie acceptance mode or

delete cookies. Cookies are pieces of personal

information sent to a web server while navigating

the web.

Preferences

: change the browser display and

sound settings.

Certificates

: access certificate information.

About browser

: access version and copyright

information about the browser.

Exiting the browser

Press [ ] to end the network connection and exit

the browser.

Enter URL

(Menu 4.2)

Use this menu to manually enter a URL address and

access the associated web page.

You can add the entered URL to the bookmark list by

selecting

Add bookmark

Bookmarks

(Menu 4.3)

Use this menu to save URL addresses in order to

quickly access web pages.

Adding a bookmark

1. Press <

Add

>. If a bookmark has already been

saved, press <

Options

> and select

Add

bookmark

2. Enter a title for the bookmark and press [Down].

3. Enter a URL address and press <

Save

Accessing a bookmarked page

Selecting a bookmark item launches the web browser

and accesses the associated web page.

Using bookmark options

After saving an item, press <

Options

> to access the

following options:

•

Go to

: access the bookmarked web page.

•

Go to homepage

: access the homepage.

•

Enter URL

: enter a URL address manually.

•

Edit bookmark

: edit the URL address and title of

the bookmark.

Menu functions

•

Add bookmark

: add a new bookmark.

•

Send URL

: send the URL address of the bookmark

via SMS or e-mail.

•

Delete

: delete the selected bookmark or all

bookmarks.

Saved pages

(Menu 4.4)

You can access the list of pages you have saved while

online.

If you select a link on the page, the phone switches to

online to access the linked page.

History

(Menu 4.5)

You can access the list of pages you have accessed

recently.

Select a URL from the list to access the corresponding

web page.

Clear cache

(Menu 4.6)

Use this menu to clear information stored in the cache.

Browser settings

(Menu 4.7)

Use this menu to select a connection profile to be used

for accessing the wireless web.

You can also create or

edit a profile.



p. 93

Messaging

(Menu 5)

Use the

Messaging

menu to send and receive text

messages, multimedia messages, and e-mails. You

can also use push message and cell broadcast

message features.

To access this menu, press <

> in Idle mode and

select

Messaging

Create message

(Menu 5.1)

Use this menu to create and send messages.

Text message

(Menu 5.1.1)

Short Message Service (SMS) allows you to send or

receive text messages that may include simple

pictures, animated images, and melodies.

Menu functions

Messaging

(Menu 5)

1. Enter your message.

2. Press <

Options

> to access the following options

for creating a message:

•

Insert

: add a template, Phonebook entry, or

bookmark to text.

•

Add image

Add animation

Add melody

attach a simple image, an animated image, or

a melody.

•

Attach

: attach a name card or calender data

as a data format attachment.

•

Text style

: change the text attributes.

3. When you have finished, press <

Options

> and

select

Save and send

Send only

4. Enter a destination number.

To send the message to more than one recipient,

fill in additional destination fields.

5. Press [ ] to send the message.

Multimedia message

(Menu 5.1.2)

Multimedia Message Service (MMS) delivers messages

containing a combination of text, image, video, and

audio, from phone to phone or from phone to e-mail.

1. Select the

Subject

line.

2. Enter the message subject and press [ ].

3. Select the

Image and video

Sound

line and

add an image, a video, or a sound file.

4. Select the

Message

line.

5. Enter the message text and press [ ].

6. Press <

Options

> to access the following options

for editing the message:

•

Edit

: edit the subject or text.

•

Change image

Change video

Change

sound

: replace an added item.

The maximum number of characters allowed in a

message varies by service provider. If your

message exceeds the maximum number of

characters, the phone will split the message.

• The maximum size allowed for a message can

differ, depending on your service provider.

• Depending on the file type or DRM (Digital

Rights Management) system, some files may

not be able to be forwarded.

Menu functions

•

Add memory card

: add a file stored on a

memory card, if inserted.

•

Add page

: add pages. Move to each page by

pressing [Left] or [Right].

•

Delete page

: delete an added page.

•

Edit page

: change the duration of page display

or move the page forward among the other

pages.

•

Attach

: attach a Phonebook entry as a name

card or calender data as a data format

attachment, or a document file stored in the

Other files

folder.

•

Remove subject

Remove message

Remove media

Remove sound

Remove

remove an added item.

7. When you have finished, press <

Options

> and

select

Send

8. Enter a phone number or an e-mail address.

To send the message to more than one recipient,

fill in additional destination fields.

9. Press [ ] to send the message.

(Menu 5.1.3)

You can create and send e-mails that include text,

audio, and images.

1. Select the

Subject

line.

2. Enter the subject of your e-mail and press [ ].

3. Select the

Message

line.

4. Enter the e-mail text and press [ ].

5. Select the

File attached

line and select one of the

following options to add files:

•

Add image

Add video

Add sound

Add

music

: add media files stored in the phone’s

memory.

•

Other files

: add document files stored in the

Other files

folder.

•

Memory card

: add files stored on a memory

card, if inserted.

•

Attach

: attach Phonebook entries as name

cards or calender data as data format

attachments.

Depending on the file type or DRM (Digital

Rights Management) system, some files may

not be able to be forwarded.

Menu functions

Messaging

(Menu 5)

6. Press <

Options

> to access the following options

to edit the e-mail:

•

Edit

: edit the subject or text.

•

Remove subject

Remove message

: clear

the subject or text.

•

Remove attachment

: delete the selected

attachment.

•

Remove all attachments

: delete all

attachments.

7. When you have finished, press <

Options

> and

select

Send

8. Enter an e-mail address.

To send the e-mail to more than one recipient, fill

in additional destination fields.

9. Press [ ] to send the e-mail.

My messages

(Menu 5.2)

Use this menu to access messages you have received,

sent, or which have failed in sending.

Inbox

(Menu 5.2.1)

This folder stores all of the messages you have

received, except for e-mails.

Viewing a message

The following icons may appear on the message list to

show the message type:

• SMS

• MMS

• MMS notification ( : Being retrieved,

: Failed to retrieve)

• Voicemail

• Push message from web servers

• Configuration message, containing network

parameters from your service provider

• CB (Cell broadcast) message from your

service provider

• Delivery report for your sent messages

• Depending on the DRM (Digital Rights

Management)

system, messages having web

content may not be

able to be forwarded.

• A

icon next to a message means that the

message is of high priority. A grey-coloured

message icon indicates low priority.

Menu functions

Using message options

While viewing a message, press <

Options

> to access

the following options:

SMS messages

•

Reply via

: reply to the sender via SMS or MMS.

•

Forward

: forward the message to other people.

•

Delete

: delete the message.

•

Move to phone

Move to SIM

: move the

message between the SIM card and the phone’s

memory.

•

Copy entry

: extract URLs, e-mail addresses, or

phone numbers from the message.

•

Copy media

: save media content from the

message to your phone’s memory.

•

Protection

: protect the message from being

deleted. You can protect only those messages

stored in the phone’s memory.

•

Block number

: add the sender’s number to the

Block list to reject the messages from the sender.

MMS messages

MMS notifications

•

Retrieve

: retrieve the MMS message from the

MMS server.

•

Reply via text message

: reply to the sender via

SMS.

•

Reply via multimedia message to

: reply to the

sender via MMS.

•

Forward

: forward the message to other people.

•

Delete

: delete the message.

•

Copy

entry

: extract URLs, e-mail addresses, or

phone numbers from the message.

•

Copy media

: save media content from the

message to your phone’s memory.

•

Protection

: protect the message from being

deleted.

•

Details

: access the message properties.

Configuration messages

•

Install

: apply the configuration specified in the

message to your phone.

•

Delete

: delete the message.

Menu functions

Messaging

(Menu 5)

•

Protection

: protect the message from being

deleted.

Push messages

•

Go to URL

: connect to the URL specified in the

message.

•

Copy

entry

: extract URLs, e-mail addresses, or

phone numbers from the message.

•

Delete

: delete the message.

•

Protection

: protect the message from being

deleted.

CB messages

•

Save

: save the message to the phone’s memory.

•

Copy entry

: extract URLs, e-mail addresses, or

phone numbers from the message.

•

Delete

: delete the message.

Delivery reports

•

Copy

entry

: extract URL, e-mail addresses, or

phone numbers from the report.

•

Delete

: delete the message.

•

Protection

: protect the report from being deleted.

Drafts

(Menu 5.2.2)

This folder stores messages you have saved to send at

a later time.

When you select a message, it opens in Edit mode so

that you can edit and send the message.

Outbox

(Menu 5.2.3)

This folder stores messages that the phone is

attempting to send or has failed to send.

The following icons are available to show the message

status:

• Being sent

• Failed to send

While viewing a message, press <

Options

> to access

the following options:

•

Send again

: retry sending the message.

•

Forward

: forward the message to other people.

You can select whether or not to include

attachments in the message.

•

Copy entry

: extract URLs, e-mail addresses, or

phone numbers from the message.

Menu functions

•

Delete

: delete the message.

•

Protection

: protect the message from being

deleted.

•

Details

: access the message properties.

Sent messages

(Menu 5.2.4)

This folder stores messages that you have sent.

While viewing a message, press <

Options

> to access

the following options:

•

Forward

: forward the message to other people.

You can select whether or not to include

attachments in the message.

•

Copy entry

: extract URLs, e-mail addresses, or

phone numbers from the message.

•

Delete

: delete the message.

•

Protection

: protect the message from being

deleted.

•

Details

: access the message properties.

Email inbox

(Menu 5.2.5)

This folder stores e-mails that you have received.

Viewing an e-mail

1. Select an e-mail account.

2. Press <

Yes

> when

Check for new email

displays, or press <

Options

> and select

Check

for new mail

. The phone checks the e-mail server

and downloads new e-mails.

The following icons may appear on the list to show

the e-mail status:

• Retrieved from the server

• Being retrieved

• Failed to retrieve

3. Select an e-mail or a header.

4. Press [Left] or [Right] to view other pages in the

e-mail.

5. Press [ ] or [ ] to view the previous or next

e-mail.

icon next to a message means that the

message is of high priority. A grey-coloured

message icon indicates low priority.

Menu functions

Messaging

(Menu 5)

Using e-mail options

While viewing the e-mail or header, press <

Options

to access the following options:

•

Retrieve

: retrieve the body of the e-mail from the

e-mail server.

•

: send a reply to the sender or to the sender

and all of the other recipients.

•

Forward

: forward the e-mail to other people.

•

Delete

: delete the e-mail.

•

Add to filtering list

: add the sender’s e-mail

address or subject to the Block list to reject

e-mails from that address or containing that

subject.

•

Copy entry

: extract URLs, e-mail addresses, or

phone numbers from the e-mail.

•

Copy media

: save the attached files from the

e-mail to your phone’s memory.

•

Protection

: protect the e-mail from being deleted.

•

Details

: access the e-mail properties.

My folders

(Menu 5.2.6)

Use this menu to create new folders and organise your

messages.

Creating a new folder

1. Press <

Yes

2. Enter a folder name and press <

Using folder options

On the folder list, press <

Options

> to access the

following options:

•

Open

: open the selected folder.

•

Add folder

: add a new folder.

•

Rename folder

: change the folder name.

•

Delete

: delete the selected folder.

Templates

(Menu 5.3)

Use this menu to make and use templates of

frequently used messages.

Menu functions

Text templates

(Menu 5.3.1)

You can create SMS templates with the sentences you

use frequently so that you can retrieve and insert

them when composing an SMS message.

Creating a template

1. Select an empty location.

2. Enter a message and press <

Using template options

From the template list, press <

Options

> to access

the following options:

•

Edit

: edit the selected template.

•

Send message

: create and send a new message.

•

Delete

: delete the selected template.

•

Add new

: add a new template.

Multimedia message templates

(Menu 5.3.2)

You can access embedded MMS templates or ones you

have saved so that you can use them when composing

an MMS message.

From the template list, press <

Options

> to access

the following options:

•

View

: open the selected template.

•

Edit

: edit the template.

•

Send

: create and send a new message.

•

Delete

: delete the selected template or all

templates, except for the embedded ones.

Delete all

(Menu 5.4)

Use this menu to delete messages in each message

folder all at once.

1. Press [ ] to select the message folders to be

cleared.

Pressing the key twice displays the message types

so that you can specify the ones to be cleared.

2. Press <

Delete

3. Press [ ] to select the check box to delete

protected messages, and then press <

Yes

4. Press <

Yes

> to confirm the deletion.

Menu functions

Messaging

(Menu 5)

Settings

(Menu 5.5)

Use this menu to set up various options for using the

messaging service.

Text message

(Menu 5.5.1)

You can configure SMS settings.

•

Send settings

: set up the options for sending

SMS messages:

Reply path

: allow recipients to reply to you

through your SMS server.

Delivery report

: set the network to inform you

when your messages have been delivered.

Character support

: select a character encoding

type. If you select

Automatic

, the phone switches

the encoding type from GSM-Alphabet to Uni-Code

if you enter a Unicode character. Use of Unicode

encoding will reduce the maximum number of

characters in a message to about half. If this menu

is not shown, your phone provides automatic

character encoding by default.

Bearer selection

: select either

GSM

GPRS

preferred

, depending on your network.

•

Receipt settings

: select the view mode for

displaying received SMS messages on your phone.

Normal view

: the phone displays messages in

normal view mode.

3D vivid view

: the phone converts message text

to 3D vivid graphics. This option is available only

when the message consists of a single page.

•

Block number

: store the phone numbers from

which you want to reject messages.

•

Current profile

: check or select an SMS setting

profile.

•

Profile settings

: set the properties of each

profile.

Service centre

: store or change the number of

your SMS server.

Default destination

: enter the default

destination. It will be automatically entered on the

recipient list.

Default type

: set the default message type. The

network can convert the messages into the

selected format.

Menu functions

Default validity

: set the length of time your

messages are stored in the SMS server.

Setting name

: enter a profile name.

Multimedia message

(Menu 5.5.2)

You can configure MMS settings.

•

Sending settings

: set up the options for sending

MMS messages:

Delivery report

: set the network to inform you

when your messages have been delivered.

Hide address

: set your address to be hidden from

the recipient’s phone.

Read reply

: send a read-reply request along with

your messages.

Priority

: set the priority level of messages.

Expiry date

: set the length of time messages are

stored in the MMS server.

Delivery time

: set a time delay before messages

are sent.

Outgoing message size

: select a maximum size

of attached items allowed for messages.

•

Retrieve settings

: set up the options for

receiving MMS messages:

Reject unknown senders

: reject messages from

unknown senders.

Allow adverts

: accept advertisements.

Allow information

: accept information

messages.

Allow reports

: set the network to inform the

sender when a message has been delivered to you.

Recep. in home network

: determine if your

phone retrieves new messages automatically when

you are in your home service area.

Reception when abroad

: determine if your

phone retrieves new messages automatically when

you are roaming on another network.

Reception within home network or abroad has the

following options:

Manual

: the phone displays notifications. Use

the

Retrieve

option to manually download new

messages.

Automatic

: the phone automatically retrieves

messages from the server.

Menu functions

Messaging

(Menu 5)

Reject

: the phone rejects all messages.

•

Profile

: select a connection profile to be used for

MMS. You can also create or edit a profile.



p. 93

(Menu 5.5.3)

You can configure default e-mail settings.

•

Sending settings

: set up the options for sending

e-mails:

Send copy to self

: send a copy of your e-mails to

your e-mail account.

Delivery receipt

: set the network to inform you

when your e-mails have been delivered.

Read reply

: send a read-reply request along with

e-mails.

Reply-To address

: set an e-mail address to

receive read-reply messages from recipients.

Priority

: select the priority level of e-mails.

Include signature

: attach your name, phone

number, a simple memo, or a tag line to your

e-mails.

Edit name

: edit the name in your signature.

Edit number

: edit the phone number in your

signature.

Edit note

: edit the tag line in your signature.

•

Reception settings

: set up the options for

receiving e-mails:

Check interval

: determine how often the phone

checks the server for incoming e-mails. If you

select

Do not notify

, use the

Check for new

option to receive new e-mails manually.

Read reply

: determine whether or not the phone

sends a read-reply for incoming e-mails. If you

select

Reply reminder

, the phone asks you to

send a read-reply.

Reject if larger than

: determine the maximum

size for incoming e-mails. Your phone will reject

e-mails that exceed the specified size.

Download method

: set whether the phone

downloads e-mail headers only or e-mail headers

and bodies both.

You cannot change e-mail profile and account

settings while an e-mail is being sent or retrieved.

Menu functions

Leave copy of messages on server

: leave

copies of e-mails on the e-mail server after

retrieving.

•

Block list

: specify e-mail addresses or subjects

you want to reject.

•

Email account

: set up an e-mail account and

select an account to be used.

Current account

: check or select an account.

Account settings

: configure e-mail accounts

using different e-mail servers. Set the options for

each account:

Account name

: enter a name for the currently

selected account.

User name

: enter a user name.

Email address

: enter your e-mail address.

SMTP server

: enter the IP address or host name

of the outgoing e-mail server.

SMTP port

: enter the SMTP port number.

Connect to POP3

(

IMAP

)

server first

: connect

to the POP3 or IMAP server before connecting to

the SMTP server to send e-mails.

Protocol type

: select the protocol for the

incoming e-mail server. The remaining options

depend on the protocol type setting.

When the protocol type is

POP3

POP3 server

enter the IP address or host name

of the server that receives your e-mail.

POP3 port

: enter the POP3 port number.

User ID

: enter the POP3 user name.

Password

: enter the POP3 password.

Use SMTP authentication

: enable SMTP

authentication, which requires the user to login

before sending e-mails.

Same as POP3

: select if you want the SMTP

server to have the same parameters as the POP3

server.

SMTP user ID

: enter the SMTP user name.

SMTP password

: enter the SMTP password.

APOP login

: connect to the server by using the

APOP login scheme.

Secure connection

: use a secure connection for

the e-mail service.

Menu functions

Messaging

(Menu 5)

When the protocol type is

IMAP4

IMAP4 server

: enter the IP address or host

name of the server that receives your e-mail.

IMAP4 port

: enter the IMAP4 port number.

User ID

: enter the IMAP4 user name.

Password

: enter the IMAP4 password.

Use SMTP authentication

: enable SMTP

authentication, which requires the user to login

before sending e-mails.

Same as IMAP4

: select if you want the SMTP

server to have the same parameters as the

IMAP4 server.

SMTP user ID

: enter the SMTP user name.

SMTP password

: enter the SMTP password.

Include attachments

: select this option to

receive attachments with e-mails.

Email retrieval limit(1-100)

: set the number

of headers you will retrieve from the server.

Secure connection

: use a secured connection

for e-mail service.

•

Email profile

: select a connection profile to be

used for e-mail services. You can also create or

edit a profile.



p. 93

Push message

(Menu 5.5.4)

You can change the settings for receiving push

messages from the wireless web server.

•

Receive

: set how your phone receives push

messages. If you select

Black list

, the phone will

not accept messages from the specified addresses

on the Black list.

•

Black list

: manage blocked server addresses.

Broadcast

(Menu 5.5.5)

You can change the settings for receiving CB

messages.

•

Receive

: select to receive CB messages, or not.

•

Channel list

: indicate the channels from which

you wish to receive CB messages. Please contact

your service provider for further details.

•

Language

: select the preferred languages in

which CB messages display.

Menu functions

Memory status

(Menu 5.6)

Use this menu to view the amount of memory

currently in use in each message folder.

File manager

(Menu 6)

The

File manager

menu allows you to access images,

videos, music files, and sound files stored in the

phone’s memory or on a memory card.

To access this menu, press <

> in Idle mode and

select

File manager

Tips for Digital Rights Management

As a result of the Digital Rights Management (DRM)

system, some of the media items you download from

the Internet or receive by MMS may require a licence

key to access them.

You can acquire the key from the website which owns

the rights to the content; use the

Activate key

option.

Note the following icons on the list:

• : Forwardable item with a valid key.

• : Forwardable item without a valid key.

• : Unforwardable item with a valid key.

• : Unforwardable item without a valid key.

Your service provider supports only count-based or

unlimited-access DRM files.

Images

(Menu 6.1)

This menu displays photos you have taken and images

you have downloaded, received in messages, or

imported from a computer.

Viewing an image

1. Select an image folder.

2. Select an image.

Viewing a slide show

You can view your photos as a slide show, a sequential

presentation of each photo in the current folder.

1. Select

Photos

2. Press <

Options

> and select

Slide show

Menu functions

File manager

(Menu 6)

3. Select an interval option.

The slide show begins.

4. Press <

Stop

> to stop the slide show.

Using image options

While viewing an image, press <

Options

> to access

the following options:

•

List

: return to the image list.

•

Send via

: send the file via MMS, e-mail, or

Bluetooth.

•

Set as

: set the image as wallpaper for the displays

or as a caller ID image for a Phonebook entry.

•

Activate key

: get a licence key when the key for

the selected DRM file expires.

•

Edit

: edit the image using the Image editor if it is

a photo taken by the camera on the phone.



p. 42

•

Delete

: delete the file.

•

Rename

: change the file name.

•

Move to

: move the file to another folder or to a

memory card.

•

Copy to memory card

: copy the file to a memory

card.

•

Visible to Bluetooth

: share the file or all files

with other Bluetooth devices.

•

Protection

: protect the file from being deleted.

•

Print via Bluetooth

: print the file by connecting

the phone to a printer via Bluetooth.

•

Details

: access the file properties.

•

Key management

: manage the licence keys you

have acquired.

Printing an image

You can print images via Bluetooth.

1. Select an image.

2. Press <

Options

> and select

Print via

Bluetooth

3. Select a Bluetooth printer.



p. 91

4. Press <

> to print it.

To cancel printing, press <

Cancel

Menu functions

Viewing an image on a TV

You can use a TV to view the images you have stored.

You first need to set the video system for your TV in

the

TV-out settings

menu.



p. 85

1. With the TV switched on, connect your phone to

the TV with the TV out cable, as shown.

2. Switch the TV to External Input mode.

The display switches to TV Out mode and you can

view the phone’s display on the TV screen.

3. Select a photo in the

Photos

folder.

Videos

(Menu 6.2)

This menu displays video clips you have recorded,

downloaded, received in messages, or imported from

a computer.

Playing a video clip

1. Select a video folder.

2. Select a video clip.

During playback, use the following keys:

• Depending on your particular TV model, the

location and shape of the video input and

audio output ports may vary. Match cable

connector and TV port colours.

• Do not plug in connectors with a wet hand.

Depending on the video’s system, the image

vibrates or in some other may be less than

optimal.

Video clips recorded on other devices, such as

camcorders, may not play correctly.

Key Function

Pauses or resumes playback.

Left Moves back to the previous file. Moves

backward in a file when held down.

Menu functions

File manager

(Menu 6)

Using video options

After playback, press <

Options

> to access the

following options:

•

List

: return to the video list.

•

Send via

: send the file via MMS, e-mail, or

Bluetooth.

•

Set as

: set the video clip, if saved as a 3GP file, as

wallpaper for the main display or as a caller ID

image for a Phonebook entry.

•

Activate key

: get a licence key when the key for

the selected DRM file expires.

•

Delete

: delete the file.

•

Rename

: change the file name.

•

Move to

: move the file to another folder or to a

memory card.

•

Copy to memory card

: copy the file to a memory

card.

•

Visible to Bluetooth

: share the file or all files

with other Bluetooth devices.

•

Protection

: protect the file from being deleted.

•

Details

: access the file properties.

•

Key management

: manage the licence keys you

have acquired.

Viewing a video clip on a TV

You can use a TV to view the video clips you have

stored.



p. 68

Music

(Menu 6.3)

This menu displays MP3 files you have downloaded or

imported from a computer.

Select a file. The MP3 player opens.



p. 39

Right Skips to the next file. Moves forward

in a file when held down.

/ Adjusts the volume.

Down Stops playback.

Key Function

When you play a file from this menu, without first

adding it to the play list in the MP3 player,

backround play is not supported.

Menu functions

Sounds

(Menu 6.4)

This menu displays voice memos you have recorded,

and sound files you have downloaded, received in

messages, or imported from a computer.

Playing a sound clip

1. Select a sound folder.

2. Select a sound clip. For a voice memo, see

Voice

recorder



p. 41

Using sound options

From a sound screen, press <

Options

> to access the

following options:

•

List

: return to the sound list.

•

Send via

: send the file via MMS, e-mail, or

Bluetooth.

•

Set as

: set the file as your ringtone or as a

ringtone for a Phonebook entry.

•

Activate key

: get a licence key when the key for

the selected DRM file expires.

•

Delete

: delete the file.

•

Rename

: change the file name.

•

Move to

: move the file to another folder or to a

memory card.

•

Copy to memory card

: copy the file to a memory

card.

•

Visible to Bluetooth

: share the files with other

Bluetooth devices.

•

Protection

: protect the file from being deleted.

•

Details

: access the file properties.

•

Key management

: manage the licence keys you

have acquired.

Other files

(Menu 6.5)

Use this menu to view various document files and files

stored in the phone’s memory without corruption.

Available file formats are DOC, XLS, PPT, PDF, and TXT.

Viewing a file

Select a file. Picsel File Viewer runs to open the

document.

Menu functions

File manager

(Menu 6)

Use the following keys to view the document:

Using document options

While viewing a document, press <

Options

> to

access the following options:

•

Full screen view

Normal view

: change the

display to Full screen view or Normal screen view.

•

Zoom

: zoom in or out.

•

Fit to

: fit the document to the page size, screen

width, or screen height.

•

Go to

: move to another page of the document.

•

Rotate

: rotate the document.

•

Screen panning

Normal panning

: change the

panning mode to by screen or by preset pixel.

•

Show controller

Hide controller

: show

or hide

the shortcut tool bar of the file viewer.

•

Send via

: send the file via MMS, e-mail, or

Bluetooth.

•

Move to memory card

: move the file to a

memory card.

•

Copy to memory card

: copy the file to a memory

card.

•

Delete

: delete the selected file.

• Depending on the file size or memory capacity of

Picsel File Viewer, a file may not open properly.

• If a document file contains languages

unsupported by Picsel File Viewer, the content of

the document will not display correctly.

Key Function

Up/Down/

Left/Right

Pans around the page.

Fits the document to the page size.

/ Zooms in.

Returns to the first page.

/ Zooms out.

Returns to the previous page.

Rotates the document.

Moves to the next page.

Moves to the last page.

Changes the display to Full screen

view or Normal screen view.

Menu functions

•

Rename

: change the file name.

•

Visible to Bluetooth

: share the file or all files

with other Bluetooth devices.

•

Protection

: protect the file from being deleted.

•

Details

: access the file properties.

•

Shortcuts

: view the functions of the keys you can

use in Picsel File Viewer.

Memory card

(Menu 6.6)

Use this menu to access the files stored in a memory

card. This menu is shown only when a memory card is

inserted into the phone.

Memory status

(Menu 6.7)

Use this menu to view memory information for media

items in the phone’s memory or on a memory card.

For the phone’s memory, press [Left] or [Right] to

view the memory status by size or number of items.

Calendar

(Menu 7)

The

Calendar

menu enables you to keep track of your

schedule.

To access this menu, press <

> in Idle mode and

select

Calendar

Consulting the calendar

When you enter the

Calendar

menu, the calendar in

Month view appears with today’s date indicated by a

blue box.

Selecting a day

• Press [Left] or [Right] to move by day.

• Press [Up] or [Down] to move by week.

• Press [ / ] to move by month.

Using calendar options

Press <

Options

> to access the following options:

•

View mode

: change the view mode of the

calendar.



p. 75

•

Create

: add a new event.



next section

•

Go to

: select today’s date or enter a specific date.

Your phone is preset to use FAT16-formatted

memory cards. If you insert a FAT32-formatted

memory card, the phone will ask you to reformat the

memory card. If you do not, you will not be able to

access the card from the phone.

Menu functions

Calendar

(Menu 7)

•

Sort by

: sort items by type of event.

•

Delete

: delete the items stored on the calendar by

using various deleting options.

•

Missed alarm events

: view events whose alarms

you have missed.

•

Memory status

: access memory information for

the event items stored on the calendar.

Creating an event

You can store scheduled events, anniversaries,

memos, and To do items on the calendar. More than

one event per day can be stored.

Entering a new scheduled event

1. Select a date on the calendar.

2. Press <

Options

> and select

Create

→

Schedule

3. Enter information or change the settings:

•

Subject

: enter a title for the event.

•

Details

: enter event details.

•

Start date

and

Start time

: enter the starting

date and time for the event.

•

AM/PM

: select

in 12-hour time

format.

•

End date

and

End time

: enter the ending date

and time for the event.

•

AM/PM

: select

in 12-hour time

format.

•

Location

: enter information about the event

location.

•

Alarm

: set an alarm for the event.

•

Before

: set how long before the event the

alarm is to alert you.

•

Alarm tone

: select an alarm tone.

•

Repeat

: set the event to recur and select a

repeat option.

•

Until

: set the ending date, if the event will

recur.

4. Press <

Save

> to save the event.

You can delete recurring events in Day view only.

Menu functions

Entering a new anniversary

1. Select a date on the calendar.

2. Press <

Options

> and select

Create

→

Anniversary

3. Enter information or change the settings:

•

Occasion

: enter information about the

anniversary.

•

Date

: enter the date.

•

Alarm

: select to set an alarm for the

anniversary.

•

Before

: set how long before the event the

alarm is to alert you.

•

Alarm time

: enter the time for the alarm to

ring.

•

AM/PM

: select

in 12-hour time

format.

•

Alarm tone

: select an alarm tone.

•

Repeat every year

: set the phone to remind

you of the anniversary every year.

4. Press <

Save

> to save the event.

Entering a memo

1. Select a date on the calendar.

2. Press <

Options

> and select

Create

→

Memo

3. Enter a memo and press <

Save

Entering a To do item

1. Select a date on the calendar.

2. Press <

Options

> and select

Create

→

To do

3. Enter information or change the settings:

•

To do

: enter information about the item.

•

Start date

: enter the starting date.

•

Due date

: enter the ending date.

•

Select priority

: select a priority level.

4. Press <

Save

> to save the event.

Viewing an event

Once you have scheduled events, the event icons and

the number of events for a specific day appears at the

bottom of the calendar.

• Scheduled event • Anniversary

• To do item • Memo

Menu functions

Calendar

(Menu 7)

Accessing an event

1. Select a date on the calendar to display the events

for the day.

2. Select an event to view its details.

3. Press [Left] or [Right] to access the other events

scheduled for the selected day.

Using event options

While viewing an event, press <

Options

> to access

the following options:

•

Edit

: edit the event.

•

Create

: add a new event.

•

Send via

: send the event via SMS, MMS, e-mail,

or Bluetooth.

•

View mode

: change the view mode of the

calendar.

•

Delete

: delete the event.

•

Memory status

: access memory information for

the events stored on the calendar.

Viewing an event in a different mode

You can change the calendar display to Day view or

Week view. Press <

Options

> and select

View mode

→

a view mode.

Day view

You can view events for the selected date. Select an

event to view its details.

The following icons may display to indicate the event

status:

• Alarm set

• Recurring event

• To do item priority (Red: high, Blue: normal,

Grey: low)

• Completed To do item

Week view

You can view events for the selected week. A cell on

the timetable indicates the presence of a schedule

item. Select a cell in the day you want.

Menu functions

Camera

(Menu 8)

You can use the camera module embedded in your

phone to take photos and record videos.

To access this menu, press <

> in Idle mode and

select

Camera

, or press and hold

[

]

in Idle mode.

Taking a photo

You can take photos in various modes. The camera

produces JPEG photos.

1. Access the

Camera

menu or press and hold [

]

to turn on the camera.

2. Adjust the image to be captured.

• Press < > to access camera options.



next section

• Use the keypad to change the camera settings

or switch to other modes.



p. 77

3. Press [

]

to take a photo. The photo is saved in

the

Photos

folder.

Using camera options in Capture mode

In Capture mode, press < > to access the following

options:

•

Record video

: switch to Record mode.

•

Shooting mode

: take a photo in the following

modes:

Single shot

: take a photo in normal mode. You

can select whether or not the camera automatically

saves a photo.

Multi-shot

: take a series of action stills. You can

select the number of photos the camera will take

and the shooting speed.

• Do not take photos of people without their

permission.

• Do not take photos in a place where cameras are

not allowed.

• Do not take photos in a place where you may

interfere with another person’s privacy.

When you take a photo in direct sunlight or in bright

conditions, shadows may appear on the photo.

To Press

access photo options <

Options



p. 79

delete the photo [

] and then <

Yes

return to Capture mode <

Preview

Menu functions

Camera

(Menu 8)

Mosaic shot

: take several stills and save them in

one frame. You can select the layout.

•

Effects

: change the colour tone or apply a special

effect.

•

Frames

: apply a decorative frame.

•

Flash

: determine the use of the flash.

•

Timer

: set a time delay before the camera takes a

photo.

•

Go to photos

: access the

Photos

folder.

•

Settings

: change the default settings for taking a

photo.

Size

: select an image size.

Quality

: select an image quality setting.

Viewfinder

: select a preview screen.

Shutter sound

: select the sound that you hear

when you press the shutter release, [

]

Zoom sound

: turn the sound effect for zooming

on or off.

Brightness sound

: turn the sound effect for

brightness adjustment on or off.

White balance

: adjust the colour balance of the

image. You can make your photo appear warmer

or cooler.

ISO

: change the ISO setting, which controls the

sensitivity of your camera. For low light situations,

select a higher ISO number. The higher the ISO

number, the faster the camera shutter functions

and the more sensitive the camera is to light.

Higher ISO settings may bring some distortion to

an image.

•

Shortcuts

: view the functions of the keys you can

use in Capture mode.

Using the keypad in Capture mode

You can use the keypad to customise your camera

settings in Capture mode.

Key Function

Left/Right Adjusts the image brightness.

Up/Down Zooms in or out.

Flips the image vertically.

Menu functions

Using voice commands in Capture mode

You can use voice commands to customise your

camera settings in Capture mode.

1. In Capture mode, press [ ] to activate the voice

commands feature.

2. After the voice prompt, say the following voice

commands for camera settings:

Shows the mirror image.

Switches to Record mode.



p. 80

Changes the image size.

Changes the image quality.

Changes the shooting mode.

Changes the colour tone or applies a

special effect.

Changes the ISO setting.

Selects a decorative frame.

Sets the timer.

Goes to the

Photos

folder.

Changes the preview screen.

Determines the use of the flash.

Changes the white balance.

Key Function

Your phone recognises only English, French,

German, Italian, Spanish, and Russian.

To Say

zoom in or out Zoom in, Zoom in max,

Zoom out, or Zoom out max.

apply a special

effect

Gray scale, Negative, Sepia,

Antique, Moonlight, Fog, or

Effect none.

use the flash Flash shooting only, Flash

permanent, or Flash off.

Menu functions

Camera

(Menu 8)

For example:

• To zoom in, say “Zoom in.”

• To increase the image size, say “Size up.”

• To turn the flash off, say “Flash off.”

Using photo options

After saving a photo, press <

Options

> to access the

following options:

•

View

: access one of the multi-shot photos.

•

Take another

: return to Capture mode.

•

Send via

: send the file via MMS, e-mail, or

Bluetooth.

•

Set as

: set the photo as wallpaper for the displays

or as a caller ID image for a Phonebook entry.

•

Edit

: edit the photo using the Image editor.



p. 42

•

Delete

: delete the file.

•

Rename

: change the file name.

•

Go to photos

: access the

Photos

folder.



p. 66

•

Protection

: protect the file from being deleted.

•

Print via Bluetooth

: print the file by connecting

the phone to a printer via Bluetooth.



p. 67

•

Details

: access the file properties.

set the timer Timer three seconds, Timer

five seconds, Timer ten

seconds, or Timer off.

change the image

size

Size up or Size down.

change the image

quality

Quality normal, Quality

economy, Quality fine, or

Quality super fine.

change the preview

screen

Full screen, Standard ratio,

Full screen guideline,

or Full screen indicator.

To Say

Menu functions

Taking a photo with the phone closed

1. Press and hold [

]

2. If necessary, press [ ] to highlight .

4. Press [

]

to take a photo. The photo is

automatically saved.

Recording a video

You can record a video of what is displayed on the

camera screen and save it.

1. In Capture mode, press [

2. Adjust the image to be captured.

• Press < > to access camera options.



next section

• Use the keypad to change the camera settings

or switch to other modes.



p. 81

3. Press [

]

to start recording.

4. Press [

]

or < > to stop recording. The video is

automatically saved in the

Video clips

folder.

Using camera options in Record mode

In Record mode, press < > to access the following

options:

•

Take photo

: switch to Capture mode.

•

Effects

: change the colour tone or apply a special

effect.

To Press

flip the image vertically [ ].

show the mirror image [ ].

turn the flash on or off and hold [ / ].

adjust the brightness [ ].

zoom in or out [ ].

To Press

play back the video clip [ ].

access video options <

Options



p. 82

delete the video clip [

] and then <

Yes

return to Record mode <

Preview

Menu functions

Camera

(Menu 8)

•

Flash

: determine the use of the flash.

•

Timer

: set a time delay before the camera starts

recording.

•

Go to videos

: access the

Video clips

folder.

•

Settings

: change the following settings for

recording a video:

Recording mode

: select a video recording mode.

Select

Limit for

MMS/Wallpaper/Caller ID

record a video suitable for messaging or for setting

as wallpaper or caller ID image. The video clip is

saved in 3GP format.

Select

Normal

to record a video within the limit of

the currently available memory. The video clip is

saved in MP4 format.

Size

: select a frame size.

Quality

: select an image quality setting.

Viewfinder

: select a preview screen.

Audio record

: record audio with a video clip.

Zoom sound

: turn the sound effect for zooming

on or off.

Brightness sound

: turn the sound effect for

brightness adjustment on or off.

White balance

: adjust the colour balance of the

image. You can make your video appear warmer or

cooler.

•

Shortcuts

: view the functions of the keys you can

use in Record mode.

Using the keypad in Record mode

You can use the keypad to customise your camera

settings in Record mode.

Key Function

Left/Right Adjusts the image brightness.

Up/Down Zooms in or out.

Flips the image vertically.

Shows the mirror image.

Switches to Capture mode.



p. 76

Changes the frame size.

Menu functions

Using video options

After saving a video clip, press <

Options

> to access

the following options:

•

Record another

: return to Record mode.

•

Send via

: send the file via MMS, e-mail, or

Bluetooth.

•

Set as

: set the video clip, if saved as a 3GP file, as

wallpaper for the main display or as a caller ID

image for a Phonebook entry.

•

Delete

: delete the file.

•

Rename

: change the file name.

•

Go to videos

: access the

Video clips

folder.



p. 68

•

Protection

: protect the file from being deleted.

•

Details

: access the file properties.

Recording a video with the phone closed

1. Press and hold [

]

2. If necessary, press [ ] to highlight .

Changes the image quality.

Changes the video recording mode.

Changes the colour tone or applies a

special effect.

Mutes or unmutes audio.

Sets the timer.

Goes to the

Video clips

folder.

Changes the preview screen.

Determines the use of the flash.

Changes the white balance.

Key Function

To Press

flip the image vertically [ ].

show the mirror image [ ].

turn the flash on or off and hold [ / ].

adjust the brightness [ ].

zoom in or out [ ].

Menu functions

Settings

(Menu 9)

4. Press [

]

to start recording.

5. Press [

]

to stop recording. The video clip is

automatically saved.

Settings

(Menu 9)

The

Settings

menu provides you with various setting

options to customise the phone to your preferences

and needs. You can also reset the settings to their

default status.

To access this menu, press <

> in Idle mode and

select

Settings

Time and date

(Menu 9.1)

Use this menu to change the time and date displayed

on your phone. Before setting the time and date,

specify your time zone in the

World clock

menu.



p. 44

•

Set time

: enter the current time.

•

AM/PM

: select

in 12-hour time format.

•

Time format

: select a time format.

•

Set date

: enter the current date.

•

Calendar starting day

: set which day of the

week the calendar starts with.

Phone settings

(Menu 9.2)

Many different features of your phone’s system can be

customised to suit your preferences.

Language

(Menu 9.2.1)

Use this menu to select one of several languages for

the display text.

Greeting message

(Menu 9.2.2)

Use this menu to enter the greeting that is displayed

briefly when the phone is switched on.

Shortcuts

(Menu 9.2.3)

You can use the Navigation keys as shortcuts to access

specific menus directly from Idle mode. Use this menu

to assign a shortcut to a key.

Assigning a shortcut menu

1. Select a key to be used as a shortcut key.

2. Select a menu to be assigned to the key.

Menu functions

Using shortcut options

Press <

Options

> to access the following options:

•

Change

: assign or change a shortcut menu.

•

Remove

: deactivate the shortcut assignment to

the selected key.

•

Remove all

: deactivate all shortcut assignments.

Volume key

(Menu 9.2.4)

Use this menu to set whether the phone mutes the call

ringer or rejects a call if you press and hold [ / ]

when a call comes in.

Extra settings

(Menu 9.2.5)

You can turn the automatic redialling or answering

feature on or off, and lock the external keys.

•

Auto redial

: set the phone to make up to ten

attempts to redial a phone number after an

unsuccessful call.

•

Active flip

: answer an incoming call by opening

the phone.

•

Anykey

answer

: answer an incoming call by

pressing any key, except for <

Reject

> and [ ].

•

Cover keypad lock

: lock the exposed keys to

keep accidental presses from affecting your

phone’s operation when the phone is closed.

Display settings

(Menu 9.3)

Use this menu to change settings for the display and

backlight.

Wallpaper

(Menu 9.3.1)

You can set up the idle screen on both displays.

•

Main display

: select an image or video clip to be

displayed on the main display.

•

Cover display

: select an image to be displayed on

the external display.

•

Text position

: select a text position. If you don’t

want to display text in Idle mode, select

Off

•

Text mode

: select a font style.

•

Text colour

: select a font colour.

•

Graphic logo

: set the phone to display a graphic

icon instead of the service provider’s logo on the

idle screen. This is only available if a graphic icon

has been received in a message.

Menu functions

Settings

(Menu 9)

Main menu style

(Menu 9.3.2)

You can select a display style for the main menu

screen.

Skin

(Menu 9.3.3)

You can select a skin colour pattern for Menu mode.

Brightness

(Menu 9.3.4)

You can adjust the brightness of the display for

varying lighting conditions.

Dialling display

(Menu 9.3.5)

Use this menu to select a font colour for the numbers

entered while dialling.

Show caller information

(Menu 9.3.6)

Use this menu to set the phone to display missed call

notifications with the most recently missed caller’s

information. To set the external display to show caller

information, select

With cover display

TV-out settings

(Menu 9.3.7)

Use this menu to select the video system for a TV.

Sound settings

(Menu 9.4)

Use this menu to customise various sound settings.

Incoming call

(Menu 9.4.1)

Use this menu to change the sound settings for

incoming calls.

•

Alert type

: specify how you are to be informed of

incoming calls.

•

Ringtone

: select a ringtone to be used for the call

ringer.

•

Volume

: select a ringtone volume.

Keypad tone

(Menu 9.4.2)

Use this menu to select the tone that the phone

sounds when you press a key.

Message tone

(Menu 9.4.3)

Use this menu to change the sound settings for

incoming SMS messages, MMS messages, e-mails,

and CB messages individually.

You can adjust the keypad tone volume using

[/]

in Idle mode.

Menu functions

•

Alert type

: specify how you are to be informed

when a message comes in.

•

Tone

: select one of several message tones.

•

Repetition

: specify how often the phone informs

you of a new message.

Power on/off

(Menu 9.4.4)

Use this menu to select the melody that the phone

sounds when it is switched on or off.

•

Alert type

: specify how you are to be informed of

power-on or power-off.

•

Tone

: select the tone that the phone sounds when

the phone is switched on or off.

Flip tone

(Menu 9.4.5)

Use this menu to select the tone that the phone

sounds when you open or close the phone.

•

Alert type

: specify how you are to be informed

when you open or close the phone.

•

Tone

: select the tone that the phone sounds when

you open or close the phone.

Quiet mode

(Menu 9.4.6)

Use this menu to set how the phone acts to alert you

to a specific event while in Quiet mode.

Extra tones

(Menu 9.4.7)

Use this menu to customise additional tones for the

phone.

•

Minute

minder

: set the phone to beep every

minute during an outgoing call to keep you

informed of the length of your call.

•

Connection

tone

: set the phone to beep when an

outgoing call connects to the system.

•

Alert on call

: set the phone to beep when you

receive a new message or when the time for an

alarm comes during a call.

•

Indicative

tone

: set the phone to beep when you

have made a mistake or something wrong happens

on the phone.

Menu functions

Settings

(Menu 9)

Light settings

(Menu 9.5)

Use this menu to change settings for the light.

Backlight

(Menu 9.5.1)

You can select the length of time the backlight stays

on or the length of time the display stays on in Dim

mode, in which the backlight is off.

•

Main display normal

: select the length of time

the backlight stays on.

•

Main display dim

: select the length of time the

display stays on in Dim mode after the backlight

turns off. After a specified time, the display turns

off.

•

Show cover indicators

: set whether or not the

cover display icons are shown on the external

display.

Keypad light

(Menu 9.5.2)

Use this menu to set how the phone controls the use

of the keypad light.

•

Any time

: the keypad light is always used.

•

Night time

: the keypad light is used only between

5:00 PM and 9:00 AM.

•

Custom time

: specify the time period that the

keypad light is used.

Network services

(Menu 9.6)

Use this menu to access network services. Please

contact your service provider to check their availability

and subscribe to them, if you wish.

Call diverting

(Menu 9.6.1)

This network service reroutes incoming calls to a

phone number that you specify.

1. Select a call diverting option:

•

Divert always

: divert all calls.

•

Busy

: divert calls when you are on another

call.

•

: divert calls when you do not answer

the phone.

•

Unreachable

: divert calls when you are not in

an area covered by your service provider or

when your phone is switched off.

Menu functions

•

Cancel

all

: cancel all call diverting options.

2. Select the type of calls to be diverted.

3. Select

Activate

. To deactivate call diverting, select

Deactivate

4. Move to the

Divert to

line.

5. Enter the number to which calls are to be diverted.

6. If you selected

No reply

, move to the

Seconds

line and select the length of time the network

delays before diverting a call.

7. Press <

Select

Call barring

(Menu 9.6.2)

This network service allows you to restrict your calls.

1. Select a call barring option:

•

All

outgoing calls

: prohibit all outgoing calls.

•

International

: prohibit international calls.

•

International except home

: only allow calls

to numbers within the current country when

you are abroad, and to your home service area.

•

All

incoming calls

: prohibit incoming calls.

•

Incoming

while

abroad

: prohibit incoming

calls when you use your phone outside of your

home service area.

•

Cancel

all

: cancel all call barring settings,

allowing calls to be sent and received normally.

•

Change barring password

: change the call

barring password obtained from your service

provider.

2. Select the type of calls to be barred.

3. Select

Activate

. To deactivate call barring, select

Deactivate

4. Enter the call barring password supplied by your

service provider and press <

Select

Call waiting

(Menu 9.6.3)

This network service informs you when someone is

trying to reach you while you are on another call.

1. Select the type of calls to which call waiting option

will apply.

2. Select

Activate

and press <

Select

>. To

deactivate call waiting, select

Deactivate

Menu functions

Settings

(Menu 9)

Network selection

(Menu 9.6.4)

This network service allows you to either automatically

or manually select the network to be used while

roaming outside of your home area. You can select a

network other than your home network only if there is

a valid roaming agreement between the two.

Caller ID

(Menu 9.6.5)

This network service allows you to prevent your phone

number from being displayed on the phone of the

person being called. If you select

Default

, the phone

will use the default setting provided by the network.

Voice mail server

(Menu 9.6.6)

Use this menu to store the number of the voicemail

server and access your voicemails.

•

Connect to voice server

: connect to the

voicemail server to listen to your messages.

•

Voice server number

: enter the voicemail server

number.

Closed user group

(Menu 9.6.7)

Use this menu to set incoming and outgoing calls to be

restricted to a selected user group. For details about

how to create a closed user group (CUG), contact your

service provider.

•

Index list

: add, delete, or activate CUG index

numbers.

•

Outside access

: enable calls to numbers other

than those in the closed user group. This feature

depends on the nature of your CUG subscription.

•

Default group

: enable the default CUG, if you

have set one with your service provider. When

making a call, you are given the option of using

your default CUG, instead of selecting one from the

list.

Some networks may not allow you to change this

setting.

You must store the voicemail server number before

accessing the server. Your service provider can give

you the number.

Menu functions

Band selection

(Menu 9.6.8)

For the phone to make and receive phone calls, it

must register with an available network. Your phone

can handle any of the following types of networks:

GSM 1900 and Combined GSM 900/1800.

The country where you purchased your phone

determines the default band that it uses. When you

travel abroad, you may need to change to an

appropriate band.

Bluetooth

(Menu 9.7)

Using the Bluetooth feature, you can connect the

phone wirelessly to other Bluetooth devices and

exchange data with them, talk hands-free, or control

the phone remotely.

Bluetooth technology allows free wireless connections

between all Bluetooth-compliant devices within a

range of 10 meters. Since the devices communicate

using radio waves, they do not need to be in line of

sight to each other.

Setting up the Bluetooth feature

The

Bluetooth

menu provides the following options:

•

Activation

: activate or deactivate the Bluetooth

feature.

•

My devices

: search for connectable Bluetooth

devices.

•

My phone’s visibility

: allow other Bluetooth

devices to search for your phone.

•

My phone’s name

: assign a Bluetooth device

name to your phone, which is then displayed on

other devices.

•

Secure mode

: determine if the phone asks for

your confirmation when other devices access your

data.

• If there are obstacles between the devices, the

operating distance may be reduced.

• It is recommended that you don’t use the

Bluetooth feature while using multimedia

features,

such as voice recorder, camera, and MP3 player,

or vice versa, for better performance.

• Some devices may not be compatible with your

phone.

Menu functions

Settings

(Menu 9)

•

Bluetooth services

: display available Bluetooth

services.

Searching for and pairing with a Bluetooth

device

1. From the Bluetooth setting options, select

devices

2. Select

Search for new devices

After searching, a list of devices to which you can

connect displays. The following icons indicate the

type of device:

The colour of the icon indicates the status of the

the device:

• Grey for unpaired devices

• Blue for paired devices

• Red for devices that are currently connected to

your phone

3. Select a device.

4. Enter a Bluetooth PIN and press <

>. This code

is used just once and you don’t need to memorise

it.

When the owner of the other device enters the

same code, pairing is complete.

Using device options

From the device list, press <

Options

> to access the

following options:

•

Connect

: connect to a headset or hands-free car

kit.

•

Disconnect

: end the connection with the

connected device.

•

Browse files

: search for data from the device and

import data directly to your phone.

•

Service list

: access the Bluetooth service list of

the device.

•

Rename

: rename the paired device.

• Stereo headset • Printer

• Computer • PDA

• Mobile phone • Unknown device

• Mono headset/Hands-free car kit

Some devices, especially headsets or hands-free car

kits, may have a fixed Bluetooth PIN, such as

0000

If the other device has a code, you must enter it.

Menu functions

•

Authorise device

Unauthorised device

determine whether or not the phone asks you to

permit connection when other devices try to

connect to your phone.

•

Delete

: remove the selected device or all devices

from the list.

Sending data via Bluetooth

1. Activate the Bluetooth feature.

2. Select the application in which the item you want

to send is stored.

3. Scroll to the item you want and press <

Options

4. Select

Send

via

→

Bluetooth

The phone searches for devices within range and

displays a list of available devices.

5. Select a device.

6. If necessary, enter the Bluetooth PIN needed for

pairing and press <

Receiving data via Bluetooth

To receive data via Bluetooth, your phone’s Bluetooth

feature must be active.

1. If an unauthorised Bluetooth device sends data to

your phone, press <

Yes

> to allow the device to

access your phone.

2. Press <

Yes

> to receive data.

Security

(Menu 9.8)

Use this menu to protect the phone against

unauthorised use by managing the several access

codes of your phone and SIM card.

PIN check

(Menu 9.8.1)

The 4- to 8-digit PIN (Personal Identification Number)

protects your SIM card against unauthorised use.

When this feature is enabled, the phone requires your

PIN each time it is switched on.

If you enter an incorrect PIN/PIN2 three times in

succession, the SIM card is blocked. To unblock it

you need to enter your PUK/PUK2 (Personal

Unblocking Key). The codes are supplied by your

service provider.

Menu functions

Settings

(Menu 9)

Change PIN code

(Menu 9.8.2)

Use this menu to change your PIN. The PIN check

feature must be enabled to change the PIN.

Phone lock

(Menu 9.8.3)

Use this menu to lock the phone from unauthorised

use.

When this feature is enabled, you must enter a 4- to

8-digit phone password each time the phone is

switched on.

The password is preset to

00000000

. To change the

password, use the

Change password

menu.

Change password

(Menu 9.8.4)

Use this menu to change your phone password.

Privacy

(Menu 9.8.5)

Use this menu to lock access to messages, media files,

or all menu functions on the phone, except for call

functions.

When a privacy option is enabled, you must enter the

phone password to access the locked items or

functions.

SIM lock

(Menu 9.8.6)

This menu allows your phone to work only with the

current SIM by assigning a SIM lock code. You must

enter the SIM lock code to use a different SIM card.

Fixed dialling mode

(Menu 9.8.7)

If supported by your SIM card, Fixed Dialling Number

(FDN) mode restricts your outgoing calls to a limited

set of phone numbers. When this feature is enabled,

you can make calls only to phone numbers stored on

the SIM card.

Change PIN2 code

(Menu 9.8.8)

If supported by your SIM card, use this menu to

change your current PIN2.

Connection settings

(Menu 9.9)

Use this menu to create and customise the profiles

containing the settings for connecting your phone to

the network. You need these settings to use the web

browser or send MMS messages or e-mails.

Menu functions

Creating a profile

1. Press <

New

>. If a profile has already been saved,

press <

Options

> and select

Add new

connection

2. Specify each information:

•

Profile name

: enter a profile name.

•

Homepage URL

: enter the URL address of the

page to be used as your homepage.

•

Proxy

: activate or deactivate the proxy server.

•

IP address

: enter the IP address of the proxy

server.

•

Port

: enter the port number of the proxy

server.

•

Linger time

: set a time period after which the

network is disconnected if there has been no

new data traffic in that time.

•

DNS

: activate or deactivate the DNS (Domain

Name Server) addresses.

•

DNS1

and

DNS2

: enter the primary and

secondary DNS addresses.

•

Bearer

: select the network bearer type.

•

Advanced settings

: change the advanced

options. Depending on the bearer setting,

available options vary.

When the bearer is set to

GPRS

APN

: enter the access point name.

: enter the login ID.

Password

: enter the login password.

When the bearer is set to

GSM

Dial number

: enter the PPP phone number.

: enter the login ID.

Password

: enter the login password.

Data call type

: select a call type for data

transmission.

3. Press <

Save

> to save the profile.

Your phone is suited for connecting to the network

by default. If you change the settings without first

checking with your service provider, the web

browser, MMS, and e-mail features may not work

properly.

Using profile options

Press <

Options

> to access the following options:

•

Edit

: edit the selected profile.

•

Delete

: delete the profile.

•

Add new connection

: add a new profile.

Reset settings

(Menu 9.10)

Use this menu to reset the phone’s settings you have

changed.

1. Press [ ] to select the setting categories to be

reset.

2. Press <

Reset

3. Press <

Yes

> to confirm the reset.

4. Enter the phone password and press <

Solve problems

Help and personal needs

To save the time and expense of an unnecessary service

call, perform the simple checks in this section before

contacting a service professional.

When you switch on your phone, the following

messages may appear:

“Insert SIM”

• Be sure that the SIM card is correctly installed.

“Enter password”

• The automatic locking function has been enabled.

You must enter the phone’s password before you

can use the phone.

“Enter PIN”

• You are using your phone for the first time. You

must enter the PIN supplied with the SIM card.

• The PIN check feature is enabled. Every time the

phone is switched on, the PIN has to be entered.

To disable this feature, use the

PIN check

menu.

The password is preset to

00000000

. You can

change this password.



p. 93

Solve problems

“Enter PUK”

• The PIN has been entered incorrectly three times

in succession, and the phone is now blocked. Enter

the PUK supplied by your service provider.

“No service,” “Network failure,” or “Not done”

displays

• The network connection has been lost. You may be

in a weak signal area. Move and try again.

• You are trying to access an option for which you

have no subscription with your service provider.

Contact the service provider for further details.

You have entered a number but it was not dialled

• Be sure that you have pressed [ ].

• Be sure you have accessed the right cellular

network.

• Be sure that you have not set an outgoing call

barring option.

Your correspondent cannot reach you

• Be sure that your phone is switched on. ([ ]

pressed for more than one second.)

• Be sure that you are accessing the correct cellular

network.

• Be sure that you have not set an incoming call

barring option.

Your correspondent cannot hear you speaking

• Be sure that you have switched on the

microphone.

• Be sure that you are holding the phone close

enough to your mouth. The microphone is located

at the bottom of the phone.

The phone starts beeping and “Warning

Low

battery” flashes on the display

• Your battery is insufficiently charged. Recharge the

battery.

The audio quality of the call is poor

• Check the signal strength indicator on the display

( ). The number of bars indicates the signal

strength from strong ( ) to weak ( ).

• Try moving the phone slightly or moving closer to a

window if you are in a building.

No number is dialled when you re-call a

Phonebook entry

•Use the

Contact list

menu to ensure the number

has been stored correctly.

• Re-store the number, if necessary.

The battery doesn’t charge properly or the phone

sometimes turns itself off

• Wipe the charging contacts both on the phone and

on the battery with a clean soft cloth.

If the above guidelines do not help you to solve

the problem, take note of:

• The model and serial numbers of your phone

•Your warranty details

• A clear description of the problem

Then contact your local dealer or Samsung after-sales

service.

Health and safety information

Exposure to Radio Frequency (RF) Signals

Certification Information (SAR)

Your wireless phone is a radio transmitter and receiver. It

is designed and manufactured not to exceed the exposure

limits for radio frequency (RF) energy set by the Federal

Communications Commission (FCC) of the U.S.

government. These FCC exposure limits are derived from

the recommendations of two expert organizations, the

National Counsel on Radiation Protection and

Measurement (NCRP) and the Institute of Electrical and

Electronics Engineers (IEEE). In both cases, the

recommendations were developed by scientific and

engineering experts drawn from industry, government,

and academia after extensive reviews of the scientific

literature related to the biological effects of RF energy.

The exposure limit set by the FCC for wireless mobile

phones employs a unit of measurement known as the

Specific Absorption Rate (SAR). The SAR is a measure of

the rate of absorption of RF energy by the human body

expressed in units of watts per kilogram (W/kg). The FCC

Health and safety information

requires wireless phones to comply with a safety limit of

1.6 watts per kilogram (1.6 W/kg). The FCC exposure limit

incorporates a substantial margin of safety to give

additional protection to the public and to account for any

variations in measurements.

SAR tests are conducted using standard operating

positions with the phone transmitting at its highest

certified power level in all tested frequency bands.

Although the SAR is determined at the highest certified

power level, the actual SAR level of the phone while

operating can be well below the maximum value. This is

because the phone is designed to operate at multiple

power levels so as to use only the power required to reach

the network. In general, the closer you are to a base

station, the lower the power output of the phone.

Before a new model phone is available for sale to the

public, it must be tested and certified to the FCC that it

does not exceed the limit estabilished by the FCC. Tests

are performed in positions and locations(e.g.at the ear

and worn on the body) as required by the FCC.

The highest SAR values for this model phone as to the FCC

are Head:0.547 W/Kg, Body-worn:0.106 W/Kg. For body

worn operations, this model phone has been tested and

meets the FCC RF exposure guidelines when used with a

Samsung accessory designated for this product orwhen

used with an accessory that contains no metal and that

positions the handset a minimum 1.5cm from the body.

Non-compliance with the above restrictions may result in

violation of FCC RF exposure guidelines.Sometimes it may

be necessary to remove the battery pack to find the

number. Once you have the FCC ID number for a

particular phone, follow the instructions on the website

and it should provide values for typical or maximum SAR

for a particular phone. Additional product specific SAR

information can also be obtained at www.fcc.gov/cgb/sar.

Consumer Information on Wireless Phones

he U.S. Food and Drug Administration (FDA) has

published a series of Questions and Answers for

consumers relating to radio frequency (RF) exposure from

wireless phones. The FDA publication includes the

following information:

Health and safety information

What kinds of phones are the subject of this

update?

The term wireless phone refers here to hand-held wireless

phones with built-in antennas, often called “cell”, ”mobile”,

“PCS” phones. These types of wireless phones can expose

the user to measurable radio frequency energy (RF)

because of the short distance between the phone and the

user's head. These RF exposures are limited by Federal

Communications Commission safety guidelines that were

developed with the advice of FDA and other federal health

and safety agencies. When the phone is located at greater

distances from the user, the exposure to RF is drastically

lower because a person's RF exposure decreases rapidly

with increasing distance from the source. The so-called

“cordless phones”, which have a base unit connected to

the telephone wiring in a house, typically operate at far

lower power levels, and thus produce RF exposures well

within the FCC's compliance limits.

Do wireless phones pose a health hazard?

he available scientific evidence does not show that any

health problems are associated with using wireless

phones. There is no proof, however, that wireless phones

are absolutely safe. Wireless phones emit low levels of

radio frequency energy (RF) in the microwave range while

being used. They also emit very low levels of RF when in

the stand-by mode. Whereas high levels of RF can produce

health effects (by heating tissue), exposure to low level RF

that does not produce heating effects causes no known

adverse health effects. Many studies of low level RF

exposures have not found any biological effects. Some

studies have suggested that some biological effects may

occur, but such findings have not been confirmed by

additional research. In some cases, other researchers

have had difficulty in reproducing those studies, or in

determining the reasons for inconsistent results.

What is FDA's role concerning the safety of

wireless phones?

Under the law, FDA does not review the safety of

radiation-emitting consumer products such as wireless

phones before they can be sold, as it does with new drugs

or medical devices. However, the agency has authority to

take action if wireless phones are shown to emit radio

frequency energy (RF) at a level that is hazardous to the

user. In such a case, FDA could require the manufacturers

of wireless phones to notify users of the health hazard and

to repair, replace or recall the phones so that the hazard

no longer exists.Although the existing scientific data do

not justify FDA regulatory actions, FDA has urged the

100

Health and safety information

wireless phone industry to take a number of steps,

including the following:

• “Support needed research into possible biological

effects of RF of the type emitted by wireless phones;

• ”Design wireless phones in a way that minimizes any

RF exposure to the user that is not necessary for

device function; and

• “Cooperate in providing users of wireless phones with

the best possible information on possible effects of

wireless phone use on human health.

FDA belongs to an interagency working group of the

federal agencies that have responsibility for different

aspects of RF safety to ensure coordinated efforts at the

federal level. The following agencies belong to this

working group:

• “National Institute for Occupational Safety and Health.

• ”Environmental Protection Agency.

• “Federal Communications Commission.

• “Occupational Safety and Health Administration.

• “National Telecommunications and Information

Administration

The National Institutes of Health participates in some

interagency working group activities, as well.

FDA shares regulatory responsibilities for wireless phones

with the Federal Communications Commission (FCC). All

phones that are sold in the United States must comply

with FCC safety guidelines that limit RFexposure. FCC

relies on FDA and other health agencies for safety

questions about wireless phones.

FCC also regulates the base stations that the wireless

phone networks rely upon. While these base stations

operate at higher power than do the wireless phones

themselves, the RF exposures that people get from these

base stations are typically thousands of times lower than

those they can get from wireless phones. Base stations

are thus not the primary subject of the safety questions

discussed in this document.

What are the results of the research done

already?

The research done thus far has produced conflicting

results, and many studies have suffered from flaws in their

research methods. Animal experiments investigating the

effects of radio frequency energy (RF) exposures

characteristic of wireless phones have yielded conflicting

results that often cannot be repeated in other laboratories.

A few animal studies, however, have suggested that low

101

Health and safety information

levels of RF could accelerate the development of cancer in

laboratory animals. However, many of the studies that

showed increased tumor development used animals that

had been genetically engineered or treated with cancer-

causing chemicals so as to be pre-disposed to develop

cancer in absence of RF exposure. Other studies exposed

the animals to RF for up to 22 hours per day. These

conditions are not similar to the conditions under which

people use wireless phones, so we don't know with

certainty what the results of such studies mean for human

health.Three large epidemiology studies have been

published since December 2000. Between them, the

studies investigated any possible association between the

use of wireless phones and primary brain cancer, glioma,

meningioma, or acoustic neuroma, tumors of the brain or

salivary gland, leukemia, or other cancers. None of the

studies demonstrated the existence of any harmful health

effects from wireless phones RF exposures. However, none

of the studies can answer questions about long-term

exposures, since the average period of phone use in these

studies was around three years.

What research is needed to decide whether

RF exposure from wireless phones poses a

health risk?

A combination of laboratory studies and epidemiological

studies of people actually using wireless phones would

provide some of the data that are needed. Lifetime animal

exposure studies could be completed in a few years.

However, very large numbers of animals would be needed

to provide reliable proof of a cancer promoting effect if

one exists. Epidemiological studies can provide data that

is directly applicable to human populations, but ten or

more years' follow-up may be needed to provide answers

about some health effects, such as cancer. This is because

the interval between the time of exposure to a cancer-

causing agent and the time tumors develop - if they do -

may be many, many years. The interpretation of

epidemiological studies is hampered by difficulties in

measuring actual RF exposure during day-to-day use of

wireless phones. Many factors affect this measurement,

such as the angle at which the phone is held, or which

model of phone is used.

102

Health and safety information

What is FDA doing to find out more about the

possible health effects of wireless phone RF?

FDA is working with the U.S. National Toxicology Program

and with groups of investigators around the world to

ensure that high priority animal studies are conducted to

address important questions about the effects of exposure

to radio frequency energy (RF).FDA has been a leading

participant in the World Health Organization international

Electromagnetic Fields (EMF) Project since its inception in

1996. An influential result of this work has been the

development of a detailed agenda of research needs that

has driven the establishment of new research programs

around the world. The Project has also helped develop a

series of public information documents on EMF issues.FDA

and Cellular Telecommunications & Internet Association

(CTIA) have a formal Cooperative Research and

Development Agreement (CRADA) to do research on

wireless phone safety. FDA provides the scientific

oversight, obtaining input from experts in government,

industry, and academic organizations. CTIA-funded

research is conducted through contracts to independent

investigators. The initial research will include both

laboratory studies and studies of wireless phone users.

The CRADA will also include a broad assessment of

additional research needs in the context of the latest

research developments around the world.

What steps can I take to reduce my exposure

to radio frequency energy from my wireless

phone?

If there is a risk from these products - and at this point we

do not know that there is - it is probably very small. But if

you are concerned about avoiding even potential risks,

you can take a few simple steps to minimize your

exposure to radio frequency energy (RF). Since time is a

key factor in how much exposure a person receives,

reducing the amount of time spent using a wireless phone

will reduce RF exposure.

• “If you must conduct extended conversations by

wireless phone every day, you could place more

distance between your body and the source of the RF,

since the exposure level drops off dramatically with

distance. For example, you could use a headset and

carry the wireless phone away from your body or use a

wireless phone connected to a remote antenna.

Again, the scientific data do not demonstrate that wireless

phones are harmful. But if you are concerned about the RF

exposure from these products, you can use measures like

those described above to reduce your RF exposure from

wireless phone use

103

Health and safety information

What about children using wireless phones?

The scientific evidence does not show a danger to users of

wireless phones, including children and teenagers. If you

want to take steps to lower exposure to radio frequency

energy (RF), the measures described above would apply

to children and teenagers using wireless phones. Reducing

the time of wireless phone use and increasing the distance

between the user and the RF source will reduce RF

exposure.Some groups sponsored by other national

governments have advised that children be discouraged

from using wireless phones at all. For example, the

government in the United Kingdom distributed leaflets

containing such a recommendation in December 2000.

They noted that no evidence exists that using a wireless

phone causes brain tumors or other ill effects. Their

recommendation to limit wireless phone use by children

was strictly precautionary; it was not based on scientific

evidence that any health hazard exists.

Do hands-free kits for wireless phones reduce

risks from exposure to RF emissions?

Since there are no known risks from exposure to RF

emissions from wireless phones, there is no reason to

believe that hands-free kits reduce risks. Hands-free kits

can be used with wireless phones for convenience and

comfort. These systems reduce the absorption of RF

energy in the head because the phone, which is the source

of the RF emissions, will not be placed against the head.

On the other hand, if the phone is mounted against the

waist or other part of the body during use, then that part

of the body will absorb more RF energy. Wireless phones

marketed in the U.S. are required to meet safety

requirements regardless of whether they are used against

the head or against the body. Either configuration should

result in compliance with the safety limit.

Do wireless phone accessories that claim to

shield the head from RF radiation work?

Since there are no known risks from exposure to RF

emissions from wireless phones, there is no reason to

believe that accessories that claim to shield the head from

those emissions reduce risks. Some products that claim to

shield the user from RF absorption use special phone

cases, while others involve nothing more than a metallic

accessory attached to the phone. Studies have shown that

these products generally do not work as advertised. Unlike

°×hand-free°± kits, these so-called °×shields°± may

interfere with proper operation of the phone. The phone

104

Health and safety information

may be forced to boost its power to compensate, leading

to an increase in RF absorption. In February 2002, the

Federal trade Commission (FTC) charged two companies

that sold devices that claimed to protect wireless phone

users from radiation with making false and

unsubstantiated claims. According to FTC, these

defendants lacked a reasonable basis to substantiate their

claim.

What about wireless phone interference with

medical equipment?

Radio frequency energy (RF) from wireless phones can

interact with some electronic devices. For this reason, FDA

helped develop a detailed test method to measure

electromagnetic interference (EMI) of implanted cardiac

pacemakers and defibrillators from wireless telephones.

This test method is now part of a standard sponsored by

the Association for the Advancement of Medical

instrumentation (AAMI). The final draft, a joint effort by

FDA, medical device manufacturers, and many other

groups, was completed in late 2000. This standard will

allow manufacturers to ensure that cardiac pacemakers

and defibrillators are safe from wireless phone EMI. FDA

has tested wireless phones and helped develop a

voluntary standard sponsored by the Institute of Electrical

and Electronic Engineers (IEEE). This standard specifies

test methods and performance requirements for hearing

aids and wireless phones so that no interference occurs

when a person uses a compatible phone and a compatible

hearing aid at the same time. This standard was approved

by the IEEE in 2000.

FDA continues to monitor the use of wireless phones for

possible interactions with other medical devices. Should

harmful interference be found to occur, FDA will conduct

testing to assess the interference and work to resolve the

problem.

Additional information on the safety of RF exposures from

various sources can be obtained from the following

organizations:

• FCC RF Safety Program:

http://www.fcc.gov/oet/rfsafety/.

• Environmental Protection Agency (EPA):

http://www.epa.gov/radiation/.

• Occupational Safety and Health Administration's

(OSHA):

http://www.osha.gov/SLTC/

radiofrequencyradiation/index.html

Health and safety information

Settings

105

• National institute for Occupational Safety and

Health (NIOSH):

http://www.cdc.gov/niosh/emfpg.html .

• World health Organization (WHO):

http://www.who.int/peh-emf/.

• International Commission on Non-Ionizing

Radiation Protection:

http://www.icnirp.de.

• National Radiation Protection Board (UK):

http://www.nrpb.org.uk.

• Updated 4/3/2002: US food and Drug

Administration

http://www.fda.gov/cellphone

Precautions when using batteries

• Never use a charger or battery that is damaged in any

way.

• Use the battery only for its intended purpose.

• If you use the phone near the network’s base station,

it uses less power. Talk and standby time are greatly

affected by the signal strength on the cellular network

and the parameters set by the network operator.

• Battery charging time depends on the remaining

battery charge, the type of battery, and the charger

used. The battery can be charged and discharged

hundreds of times, but it will gradually wear out. When

the operation time is noticeably shorter than normal, it

is time to buy a new battery.

• If left unused, a fully charged battery will discharge

itself over time.

• Use only Samsung-approved batteries, and recharge

your battery only with Samsung-approved chargers.

Disconnect the charger from the power source when it

is not in use. Do not leave the battery connected to a

charger for more than a week, since overcharging may

shorten its life.

106

Health and safety information

• Extreme temperatures will affect the charging capacity

of your battery: it may require cooling or warming

first.

• Do not leave the battery in hot or cold places because

the capacity and lifetime of the battery will be

reduced. Try to keep the battery at room temperature.

A phone with a hot or cold battery may not work

temporarily, even when the battery is fully charged.

Li-ion batteries are particularly affected by

temperatures below 0°C (32°F).

• Do not short-circuit the battery. Accidental short-

circuiting can occur when a metallic object like a coin,

clip or pen causes a direct connection between the +

and – terminals of the battery (metal strips on the

battery). For example, do not carry a spare battery in

a pocket or bag where the battery may contact metal

objects. Short-circuiting the terminals may damage

the battery or the object causing the short-circuiting.

• Dispose of used batteries in accordance with local

regulations. Always recycle. Do not dispose of

batteries in a fire.

Road safety

Your wireless phone gives you the powerful ability to

communicate by voice, almost anywhere, anytime. But an

important responsibility accompanies the benefits of

wireless phones, one that every user must uphold.

When you are driving a car, driving is your first

responsibility. When using your wireless phone while

driving, follow local regulations in the country or region

you are in.

Operating environment

Remember to follow any special regulations in force in the

area you are in, and always switch off your phone

whenever it is forbidden to use it, or when it may cause

interference or danger.

When connecting the phone or any accessory to another

device, read its user’s guide for detailed safety

instructions. Do not connect incompatible products.

As with other mobile radio transmitting equipment, users

are advised that for the satisfactory operation of the

equipment and for the safety of personnel, it is

recommended that the equipment should only be used in

the normal operating position (held to your ear with the

antenna pointing over your shoulder).

Health and safety information

Settings

107

Electronic devices

Most modern electronic equipment is shielded from radio

frequency (RF) signals. However, certain electronic

equipment may not be shielded against the RF signals

from your wireless phone. Consult the manufacturer to

discuss alternatives.

Pacemakers

Pacemaker manufacturers recommend that a minimum

distance of 15 cm (6 inches) be maintained between a

wireless phone and a pacemaker to avoid potential

interference with the pacemaker. These recommendations

are consistent with the independent research and

recommendations of Wireless Technology Research. If you

have any reason to suspect that interference is taking

place, switch off your phone immediately.

Hearing aids

Some digital wireless phones may interfere with some

hearing aids. In the event of such interference, you may

wish to consult your hearing aid manufacturer to discuss

alternatives.

Other medical devices

If you use any other personal medical devices, consult the

manufacturer of your device to determine if it is

adequately shielded from external RF energy.

Your physician may be able to assist you in obtaining this

information.

Switch off your phone in health care facilities when

regulations posted in these areas instruct you to do so.

Vehicles

RF signals may affect improperly installed or inadequately

shielded electronic systems in motor vehicles. Check with

the manufacturer or its representative regarding your

vehicle.

You should also consult the manufacturer of any

equipment that has been added to your vehicle.

Posted facilities

Switch off your phone in any facility where posted notices

require you to do so.

108

Health and safety information

Potentially explosive environments

Switch off your phone when in any area with a potentially

explosive atmosphere, and obey all signs and instructions.

Sparks in such areas could cause an explosion or fire

resulting in bodily injury or even death.

Users are advised to switch off the phone while at a

refuelling point (service station). Users are reminded of

the need to observe restrictions on the use of radio

equipment in fuel depots (fuel storage and distribution

areas), chemical plants, or where blasting operations are

in progress.

Areas with a potentially explosive atmosphere are often

but not always clearly marked. They include the areas

below decks on boats, chemical transfer or storage

facilities, vehicles using liquefied petroleum gas, such as

propane or butane, areas where the air contains chemicals

or particles, such as grain, dust or metal powders, and any

other area where you would normally be advised to turn

off your vehicle engine.

Emergency calls

This phone, like any wireless phone, operates using radio

signals, wireless, and landline networks as well as user-

programmed functions, which cannot guarantee

connection in all conditions. Therefore, you should never

rely solely on any wireless phone for essential

communications like medical emergencies.

To make or receive calls, the phone must be switched on

and in a service area with adequate signal strength.

Emergency calls may not be possible on all wireless phone

networks or when certain network services and/or phone

features are in use. Check with local service providers.

To make an emergency call:

1. Switch on the phone.

2. Key in the emergency number for your present

location. Emergency numbers vary by location.

3. Press

[]

Certain features like Call Barring may need to be

deactivated before you can make an emergency call.

Consult this document and your local cellular service

provider.

Health and safety information

Settings

109

FCC Notice and Cautions

FCC Notice

The phone may cause TV or radio interference if used in

close proximity to receiving equipment. The FCC can

require you to stop using the phone if such interference

cannot be eliminated.

Vehicles using liquefied petroleum gas (such aspropane

or butane) must comply with the National Fire

Protection Standard (NFPA-58). For a copy of this

standard, contact the National Fire Protection

Association, One Battery march Park, Quincy, MA

02269, Attn: Publication Sales Division.

Cautions

Changes or modifications made in the radio phone, not

expressly approved by Samsung, will void the user’s

authority to operate the equipment.

Only use approved batteries, antennas and chargers.

The use of any unauthorized accessories may be

dangerous and void the phone warranty if said

accessories cause damage or a defect to the phone.

Although your phone is quite sturdy, it is a complex

piece of equipment and can be broken. Avoid dropping,

hitting, bending or sitting on it.

Other important safety information

• Only qualified personnel should service the phone or

install the phone in a vehicle. Faulty installation or

service may be dangerous and may invalidate any

warranty applicable to the device.

• Check regularly that all wireless phone equipment in

your vehicle is mounted and operating properly.

• Do not store or carry flammable liquids, gases, or

explosive materials in the same compartment as the

phone, its parts, or accessories.

• For vehicles equipped with an air bag, remember that

an air bag inflates with great force. Do not place

objects, including installed or portable wireless

equipment, in the area over the air bag or in the air

bag deployment area. Improperly installed wireless

equipment could result in serious injury if the air bag

inflates.

• Switch off your phone before boarding an aircraft. It is

dangerous and illegal to use wireless phones in an

aircraft because they can interfere with the operation

of the aircraft.

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) this device may not cause harmful interference,

and (2) this device must accept any interference

received, including interference that may cause

undesired operation.

110

Health and safety information

• Failure to observe these instructions may lead to the

suspension or denial of telephone services to the

offender, or legal action, or both.

Care and maintenance

Your phone is a product of superior design and

craftsmanship and should be treated with care. The

suggestions below will help you fulfill any warranty

obligations and allow you to enjoy this product for many

years.

• Keep your phone and all its parts and accessories out

of the reach of small children and pets. They may

accidentally damage these things or choke on small

parts.

• Keep the phone dry. Precipitation, humidity, and

liquids contain minerals that corrode electronic

circuits.

• Do not use the phone with a wet hand. Doing so may

cause an electric shock to you or damage to the

phone.

• Do not use or store the phone in dusty, dirty areas, as

its moving parts may be damaged.

• Do not store the phone in hot areas. High

temperatures can shorten the life of electronic

devices, damage batteries, and warp or melt certain

plastics.

• Do not store the phone in cold areas. When the phone

warms up to its normal operating temperature,

moisture can form inside the phone, which may

damage the phone’s electronic circuit boards.

• Do not drop, knock, or shake the phone. Rough

handling can break internal circuit boards.

• Do not use harsh chemicals, cleaning solvents, or

strong detergents to clean the phone. Wipe it with a

soft cloth slightly dampened in a mild soap-and-water

solution.

• Do not paint the phone. Paint can clog the device’s

moving parts and prevent proper operation.

• Do not put the phone in or on heating devices, such as

a microwave oven, stove, or radiator. The phone may

explode when overheated.

• When the phone or battery gets wet, the label

indicating water damage inside the phone changes

colour. In this case, phone repairs are no longer

guaranteed by the manufacturer's warranty, even if

the warranty for your phone has not expired.

Health and safety information

Settings

111

• If your phone has a flash or light, do not use it too

close to the eyes of people or animals. This may cause

damage to their eyes.

• Use only the supplied or an approved replacement

antenna. Unauthorised antennas or modified

accessories may damage the phone and violate

regulations governing radio devices.

• If the phone, battery, charger, or any accessory is not

working properly, take it to your nearest qualified

service facility. The personnel there will assist you, and

if necessary, arrange for service.

104

Index

AB mode, text input •

Active flip •

Alarm •

Answering

call •

second call •

Anykey answer •

Auto redial •

Background image •

Backlight, set

display •

keypad •

Band selection •

Barring, calls •

Battery

charging •

low indicator •

precautions •

Bluetooth

receiving, data •

sending, data •

settings •

Broadcast messages •

Browser, web •

Calculator •

Calendar •

Call cost •

Call log

dialled •

missed •

received •

Call time •

Caller groups •

Caller ID •

Calls

answering •

barring •

diverting •

holding •

redialling •

rejecting •

transferring •

waiting •

Camera

photos •

videos •

CB (Cell Broadcast) messages •

Characters, enter •

Configuration messages •

Connection tone •

Converter •

Creating messages

e-mail •

MMS •

SMS •

CUG (Closed User Group) •

Date, set •

Deleting

call log •

e-mail •

events •

MMS •

phonebook •

SMS •

Dialled calls •

Dialling font, set •

Dialling, voice •

Display

brightness •

icons •

language •

layout •

settings •

Diverting, calls •

Document files •

DRM (Digital Rights

Management) •

DTMF tones, send •

E-mails

creating/sending •

deleting •

setting •

viewing •

Emergency calls •

101

FDN (Fixed Dialling Number)

mode •

File manager •

File viewer •

Flip tone •

105

Index

Games •

Greeting message •

Health and safety •

Holding, call •

Icons, description •

Image editor •

Image printing •

Images, downloaded •

Inbox, messages

e-mail •

MMS/SMS •

International calls •

Internet •

Java applications •

Keypad lock •

Keypad tones

selecting •

sending/muting •

volume •

Language, select •

Last number, redial •

Light settings •

Locking

cover keypad •

menu functions •

phone •

SIM card •

Low battery indicator •

Memory card

accessing files •

installing •

Memory status

downloaded items •

file manager •

messages •

phonebook

Menu style •

Message tone •

Messages

cell broadcast •

configuration •

e-mail •

greeting •

MMS •

push •

SMS •

Minute minder •

Missed calls •

MMS messages

creating/sending •

deleting •

setting •

viewing •

MP3 player •

Multiparty-call •

Music, downloaded •

Name card •

Names

dialling •

entering •

searching •

Network band, select •

Network selection •

Network services •

Outbox, messages •

Password

call barring •

phone •

Phone

care and maintenance •

102

display •

icons •

locking •

password •

resetting •

switching on/off •

unpacking •

Phonebook

adding •

deleting •

finding •

managing •

options •

speed dialling •

Photos

editing •

printing •

taking •

viewing •

Samsung Electronics Co SGHE870 Single-Band PCS GSM/ EDGE Phone with Bluetooth User Manual

Samsung Electronics Co Ltd Single-Band PCS GSM/ EDGE Phone with Bluetooth

Users Manual

Navigation menu

Namespaces

Views

Navigation
