Users Manual
SGH-F278i
user manual
ii
using this
manual
This user manual has been specially designed to
guide you through the functions and features of your
mobile phone. To get started quickly,
refer to “introducing your mobile phone,”
“assembling and preparing your mobile phone,”
and “using basic functions.”
Instructional icons
Before you start, familiarise yourself with the icons
you will see in this manual:
Warning
—situations that could cause
injury to yourself or others
Caution
—situations that could cause
damage to your phone or other
equipment
Note
—notes, usage tips, or additional
information
X
Refer to
—pages with related information;
for example:
X
p. 12 (represents “see
page 12”)
using this manual
iii
Copyright information
Rights to all technologies and products that
comprise this device are the property of their
respective owners:
• Bluetooth® is a registered trademark of the
Bluetooth SIG, Inc. worldwide—Bluetooth QD
ID: B0xxxxx.
• Java™ is a trademark of Sun Microsystems, Inc.
• Windows Media player® is a registered trademark
of Microsoft Corporation.
•
→
Followed by
—the order of options or
menus you must select to perform a step;
for example: Press <Menu> →
Messages → Create new message
(represents Menu, followed by
Messages, followed by Create new
message)
[ ]
Square brackets
—phone keys; for
example: [ ] (represents the Power/
Menu exit key)
<>
Angled brackets
—softkeys that control
different functions at each screen; for
example: <OK> (represents the OK
softkey)
2
Health and
safety
information
Exposure to Radio Frequency (RF)
Signals
Certification Information (SAR)
Your wireless phone is a radio transmitter and
receiver. It is designed and manufactured not to
exceed the exposure limits for radio frequency (RF)
energy set by the Federal Communications
Commission (FCC) of the U.S. government. These
FCC exposure limits are derived from the
recommendations of two expert organizations, the
National Counsel on Radiation Protection and
Measurement (NCRP) and the Institute of Electrical
and Electronics Engineers (IEEE). In both cases, the
recommendations were developed by scientific and
engineering experts drawn from industry,
government, and academia after extensive reviews
of the scientific literature related to the biological
effects of RF energy.
Health and safety information
3
The exposure limit set by the FCC for
wireless mobile phones employs a unit of
measurement known as the Specific
Absorption Rate (SAR). The SAR is a
measure of the rate of absorption of RF
energy by the human body expressed in
units of watts per kilogram (W/kg). The
FCC requires wireless phones to comply
with a safety limit of 1.6 watts per
kilogram (1.6 W/kg). The FCC exposure
limit incorporates a substantial margin of
safety to give additional protection to the
public and to account for any variations in
measurements.
SAR tests are conducted using standard
operating positions accepted by the FCC
with the phone transmitting at its highest
certified power level in all tested frequency
bands. Although the SAR is determined at
the highest certified power level, the actual
SAR level of the phone while operating can
be well below the maximum value. This is
because the phone is designed to operate
at multiple power levels so as to use only
the power required to reach the network.
In general, the closer you are to a wireless
base station antenna, the lower the power
output.
Before a new model phone is available for
sale to the public, it must be tested and
certified to the FCC that it does not exceed
the exposure limit established by the FCC.
Tests for each model phone are performed
in positions and locations (e.g. at the ear
and worn on the body) as required by the
FCC.
4
Health and safety information
The highest reported SAR values of the SGH-F278I
are:
[GSM850]
Head:0.263 W/kg; Body-worn: 0.392 W/kg
[GSM1900]
Head:0.362 W/kg; Body-worn: 0.881 W/kg
Body worn operation, this model phone has been
tested and meets the FCC RF exposure guidelines
whenused with a Samsung accessory designated
for this product or when used with an accessory that
contains no metal and that positions the handset a
minimum of 1.5 cm from the body.
Non-compliance with the above restrictions may
result in violation of FCC RF exposure guidelines.
SAR information on this and other model phones
can be viewed on-line at www.fcc.gov/oet/fccid.
This site uses the phone FCC ID number,
A3LSGHF278I Sometimes it may be necessary to
remove the battery pack to find the number. Once
you have the FCC ID number for a particular phone,
follow the instructions on the website and it should
provide values for typical or maximum SAR for a
particular phone. Additional product specific SAR
information can also be obtained at www.fcc.gov/
cgb/sar.
Health and safety information
5
UL Certified Travel Adapter
The Travel Adaptor for this phone has met applicable
UL safety requirements. Please adhere to the
following safety instructions per UL
guidelines.FAILURE TO FOLLOW THE
INSTRUCTIONS OUTLINED MAY LEAD TO
SERIOUS PERSONAL INJURY AND POSSIBLE
PROPERTY DAMAGEIMPORTANT SAFETY
INSTRUCTIONS - SAVE THESE
INSTRUCTIONS.DANGER - TO REDUCE THE RISK
OF FIRE OR ELECTRIC SHOCK, CAREFULLY
FOLLOW THESE INSTRUCTIONS.FOR
CONNECTION TO A SUPPLY NOT IN NORTH
AMERICA, USE AN ATTACHMENT PLUG ADAPTOR
OF THE PROPER CONFIGURATION FOR THE
POWER OUTLET. THIS POWER UNIT IS INTENDED
TO BE CORRECTLY ORIENTATED IN A VERTICAL
OR HORIZONTAL OR FLOOR MOUNT POSITION.
Consumer Information on Wireless
Phones
The U.S. Food and Drug Administration (FDA)
has published a series of Questions and
Answers for consumers relating to radio
frequency (RF) exposure from wireless
phones. The FDA publication includes the
following information:
What kinds of phones are the subject
of this update?
The term wireless phone refers here to hand-held
wireless phones with built-in antennas, often called
“cell,” “mobile,” or “PCS” phones. These types of
wireless phones can expose the user to measurable
radio frequency energy (RF) because of the short
distance between the phone and the user's head.
These RF exposures are limited by Federal
Communications Commission safety guidelines that
6
Health and safety information
were developed with the advice of FDA and other
federal health and safety agencies. When the phone
is located at greater distances from the user, the
exposure to RF is drastically lower because a
person's RF exposure decreases rapidly with
increasing distance from the source. The so-called
“cordless phones,” which have a base unit
connected to the telephone wiring in a house,
typically operate at far lower power levels, and thus
produce RF exposures well within the FCC's
compliance limits.
Do wireless phones pose a health
hazard?
The available scientific evidence does not show that
any health problems are associated with using
wireless phones. There is no proof, however, that
wireless phones are absolutely safe. Wireless
phones emit low levels of radio frequency energy
(RF) in the microwave range while being used. They
also emit very low levels of RF when in the stand-by
mode. Whereas high levels of RF can produce
health effects (by heating tissue), exposure to low
level RF that does not produce heating effects
causes no known adverse health effects. Many
studies of low level RF exposures have not found
any biological effects. Some studies have suggested
that some biological effects may occur, but such
findings have not been confirmed by additional
research. In some cases, other researchers have
had difficulty in reproducing those studies, or in
determining the reasons for inconsistent results.
Health and safety information
7
What is FDA's role concerning the
safety of wireless phones?
Under the law, FDA does not review the safety of
radiation-emitting consumer products such as
wireless phones before they can be sold, as it does
with new drugs or medical devices. However, the
agency has authority to take action if wireless
phones are shown to emit radio frequency energy
(RF) at a level that is hazardous to the user. In such a
case, FDA could require the manufacturers of
wireless phones to notify users of the health hazard
and to repair, replace or recall the phones so that the
hazard no longer exists.
Although the existing scientific data do not justify
FDA regulatory actions, FDA has urged the wireless
phone industry to take a number of steps, including
the following:
“Support needed research into possible biological
effects of RF of the type emitted by wireless phones;
“Design wireless phones in a way that minimizes any
RF exposure to the user that is not necessary for
device function; and
“Cooperate in providing users of wireless phones
with the best possible information on possible
effects of wireless phone use on human health.
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at
the federal level. The following agencies belong to
this working group:
• “National Institute for Occupational Safety and
Health
• “Environmental Protection Agency
• “Federal Communications Commission
• “Occupational Safety and Health Administration
• “National Telecommunications and Information
Administration
8
Health and safety information
The National Institutes of Health participates in some
interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless
phones with the Federal Communications
Commission (FCC). All phones that are sold in the
United States must comply with FCC safety
guidelines that limit RF exposure. FCC relies on FDA
and other health agencies for safety questions about
wireless phones.
FCC also regulates the base stations that the
wireless phone networks rely upon. While these
base stations operate at higher power than do the
wireless phones themselves, the RF exposures that
people get from these base stations are typically
thousands of times lower than those they can get
from wireless phones. Base stations are thus not the
primary subject of the safety questions discussed in
this document.
What are the results of the research
done already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws
in their research methods. Animal experiments
investigating the effects of radio frequency energy
(RF) exposures characteristic of wireless phones
have yielded conflicting results that often cannot be
repeated in other laboratories. A few animal studies,
however, have suggested that low levels of RF could
accelerate the development of cancer in laboratory
animals. However, many of the studies that showed
increased tumor development used animals that had
been genetically engineered or treated with cancer-
causing chemicals so as to be pre-disposed to
develop cancer in absence of RF exposure. Other
studies exposed the animals to RF for up to 22
hours per day. These conditions are not similar to the
conditions under which people use wireless phones,
Health and safety information
9
so we don't know with certainty what the results of
such studies mean for human health.
Three large epidemiology studies have been
published since December 2000. Between them,
the studies investigated any possible association
between the use of wireless phones and primary
brain cancer, glioma, meningioma, or acoustic
neuroma, tumors of the brain or salivary gland,
leukemia, or other cancers. None of the studies
demonstrated the existence of any harmful health
effects from wireless phones RF exposures.
However, none of the studies can answer questions
about long-term exposures, since the average
period of phone use in these studies was around
three years.
What research is needed to decide
whether RF exposure from wireless
phones poses a health risk?
A combination of laboratory studies and
epidemiological studies of people actually using
wireless phones would provide some of the data that
are needed. Lifetime animal exposure studies could
be completed in a few years. However, very large
numbers of animals would be needed to provide
reliable proof of a cancer promoting effect if one
exists. Epidemiological studies can provide data that
is directly applicable to human populations, but ten
or more years' follow-up may be needed to provide
answers about some health effects, such as cancer.
This is because the interval between the time of
exposure to a cancer-causing agent and the time
tumors develop - if they do - may be many, many
years. The interpretation of epidemiological studies is
hampered by difficulties in measuring actual RF
exposure during day-to-day use of wireless phones.
Many factors affect this measurement, such as the
angle at which the phone is held, or which model of
phone is used.
10
Health and safety information
What is FDA doing to find out more
about the possible health effects of
wireless phone RF?
FDA is working with the U.S. National Toxicology
Program and with groups of investigators around the
world to ensure that high priority animal studies are
conducted to address important questions about the
effects of exposure to radio frequency energy (RF).
FDA has been a leading participant in the World
Health Organization international Electromagnetic
Fields (EMF) Project since its inception in 1996. An
influential result of this work has been the
development of a detailed agenda of research
needs that has driven the establishment of new
research programs around the world. The Project
has also helped develop a series of public
information documents on EMF issues.
FDA and Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative
Research and Development Agreement (CRADA) to
do research on wireless phone safety. FDA provides
the scientific oversight, obtaining input from experts
in government, industry, and academic
organizations. CTIA-funded research is conducted
through contracts to independent investigators. The
initial research will include both laboratory studies
and studies of wireless phone users. The CRADA
will also include a broad assessment of additional
research needs in the context of the latest research
developments around the world.
Health and safety information
11
What steps can I take to reduce my
exposure to radio frequency energy
from my wireless phone?
If there is a risk from these products - and at this
point we do not know that there is - it is probably
very small. But if you are concerned about avoiding
even potential risks, you can take a few simple steps
to minimize your exposure to radio frequency energy
(RF). Since time is a key factor in how much
exposure a person receives, reducing the amount of
time spent using a wireless phone will reduce RF
exposure.
• “If you must conduct extended conversations by
wireless phone every day, you could place more
distance between your body and the source of
the RF, since the exposure level drops off
dramatically with distance. For example, you
could use a headset and carry the wireless phone
away from your body or use a wireless phone
connected to a remote antenna.
Again, the scientific data do not demonstrate
that wireless phones are harmful. But if you
are concerned about the RF exposure from
these products, you can use measures like
those described above to reduce your RF
exposure from wireless phone use.
What about children using wireless
phones?
The scientific evidence does not show a danger to
users of wireless phones, including children and
teenagers. If you want to take steps to lower
exposure to radio frequency energy (RF), the
measures described above would apply to children
and teenagers using wireless phones. Reducing the
time of wireless phone use and increasing the
distance between the user and the RF source will
reduce RF exposure.
Some groups sponsored by other national
governments have advised that children be
discouraged from using wireless phones at all. For
12
Health and safety information
example, the government in the United Kingdom
distributed leaflets containing such a
recommendation in December 2000. They noted
that no evidence exists that using a wireless phone
causes brain tumors or other ill effects. Their
recommendation to limit wireless phone use by
children was strictly precautionary; it was not based
on scientific evidence that any health hazard exists.
Do hands-free kits for wireless phones
reduce risks from exposure to RF
emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason
to believe that hands-free kits reduce risks. Hands-
free kits can be used with wireless phones for
convenience and comfort. These systems reduce
the absorption of RF energy in the head because the
phone, which is the source of the RF emissions, will
not be placed against the head. On the other hand,
if the phone is mounted against the waist or other
part of the body during use, then that part of the
body will absorb more RF energy. Wireless phones
marketed in the U.S. are required to meet safety
requirements regardless of whether they are used
against the head or against the body. Either
configuration should result in compliance with the
safety limit.
Health and safety information
13
Do wireless phone accessories that
claim to shield the head from RF
radiation work?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason
to believe that accessories that claim to shield the
head from those emissions reduce risks. Some
products that claim to shield the user from RF
absorption use special phone cases, while others
involve nothing more than a metallic accessory
attached to the phone. Studies have shown that
these products generally do not work as advertised.
Unlike “hand-free” kits, these so-called “shields” may
interfere with proper operation of the phone. The
phone may be forced to boost its power to
compensate, leading to an increase in RF
absorption. In February 2002, the Federal trade
Commission (FTC) charged two companies that sold
devices that claimed to protect wireless phone users
from radiation with making false and unsubstantiated
claims. According to FTC, these defendants lacked
a reasonable basis to substantiate their claim.
What about wireless phone
interference with medical equipment?
Radio frequency energy (RF) from wireless phones
can interact with some electronic devices. For this
reason, FDA helped develop a detailed test method
to measure electromagnetic interference (EMI) of
implanted cardiac pacemakers and defibrillators
from wireless telephones. This test method is now
part of a standard sponsored by the Association for
the Advancement of Medical instrumentation (AAMI).
The final draft, a joint effort by FDA, medical device
manufacturers, and many other groups, was
completed in late 2000. This standard will allow
manufacturers to ensure that cardiac pacemakers
and defibrillators are safe from wireless phone EMI.
FDA has tested wireless phones and helped
develop a voluntary standard sponsored by the
Institute of Electrical and Electronic Engineers (IEEE).
This standard specifies test methods and
performance requirements for hearing aids and
wireless phones so that no interference occurs
when a person uses a compatible phone and a
14
Health and safety information
compatible hearing aid at the same time. This
standard was approved by the IEEE in 2000.
FDA continues to monitor the use of wireless phones
for possible interactions with other medical devices.
Should harmful interference be found to occur, FDA
will conduct testing to assess the interference and
work to resolve the problem.
Additional information on the safety of RF exposures
from various sources can be obtained from the
following organizations:
• FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
• Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
• Occupational Safety and Health
Administration's (OSHA):
http://www.osha.gov/SLTC/
radiofrequencyradiation/index.html
• National institute for Occupational Safety
and Health (NIOSH):
http://www.cdc.gov/niosh/emfpg.html
• World health Organization (WHO):
http://www.who.int/peh-emf/
• International Commission on Non-
Ionizing Radiation Protection:
http://www.icnirp.de
• National Radiation Protection Board (UK):
http://www.nrpb.org.uk
• Updated 4/3/2002: US food and Drug
Administration
http://www.fda.gov/cellphones
Health and safety information
15
Road Safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime.
But an important responsibility accompanies the
benefits of wireless phones, one that every user
must uphold.
When driving a car, driving is your first responsibility.
When using your wireless phone behind the wheel
of a car, practice good common sense and
remember the following tips:
1. Get to know your wireless phone and its
features, such as speed dial and redial. If
available, these features help you to place
your call without taking your attention off
the road.
2. When available, use a hands-free device.
If possible, add an additional layer of
convenience and safety to your wireless
phone with one of the many hands free
accessories available today.
3. Position your wireless phone within easy
reach. Be able to access your wireless
phone without removing your eyes from
the road. If you get an incoming call at an
inconvenient time, let your voice mail
answer it for you.
4. Let the person you are speaking with
know you are driving; if necessary,
suspend the call in heavy traffic or
hazardous weather conditions. Rain,
sleet, snow, ice and even heavy traffic
can be hazardous.
5. Do not take notes or look up phone
numbers while driving. Jotting down a “to
do” list or flipping through your address
book takes attention away from your
primary responsibility, driving safely.
6. Dial sensibly and assess the traffic; if
possible, place calls when you are not
moving or before pulling into traffic.
16
Health and safety information
Try to plan calls when your car will be
stationary. If you need to make a call
while moving, dial only a few numbers,
check the road and your mirrors, then
continue.
7. Do not engage in stressful or emotional
conversations that may be distracting.
Make people you are talking with aware
you are driving and suspend
conversations that have the potential to
divert your attention from the road.
8. Use your wireless phone to call for help.
Dial 9-1-1 or other local emergency
number in the case of fire, traffic accident
or medical emergencies. Remember, it is
a free call on your wireless phone!
9. Use your wireless phone to help others in
emergencies. If you see an auto accident,
crime in progress or other serious
emergency where lives are in danger, call
9-1-1 or other local emergency number,
as you would want others to do for you.
10. Call roadside assistance or a special non-
emergency wireless assistance number
when necessary. If you see a broken-
down vehicle posing no serious hazard, a
broken traffic signal, a minor traffic
accident where no one appears injured,
or a vehicle you know to be stolen, call
roadside assistance or other special non-
emergency number.
Health and safety information
17
“The wireless industry reminds you to
use your phone safely when driving.”
For more information, please call 1-888-901-SAFE,
or visit our web-site www.wow-com.com
Provided by the Cellular Telecommunications &
Internet Association
Operating Environment
Remember to follow any special regulations in force
in any area and always switch your phone off
whenever it is forbidden to use it, or when it may
cause interference or danger. When connecting the
phone or any accessory to another device, read its
user's guide for detailed safety instructions. Do not
connect incompatible products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation
of the equipment and for the safety of personnel, it is
recommended that the equipment should only be
used in the normal operating position (held to your
ear with the antenna pointing over your shoulder).
18
Health and safety information
Using Your Phone Near Other
Electronic Devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against
the RF signals from your wireless phone. Consult the
manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be
maintained between a wireless phone and a
pacemaker to avoid potential interference with the
pacemaker.
These recommendations are consistent with the
independent research and recommendations of
Wireless Technology Research.
Persons with pacemakers:
• should always keep the phone more than
15 cm
(6 inches) from their pacemaker when
the phone is switched on.
• should not carry the phone in a breast
pocket.
• should use the ear opposite the
pacemaker to minimize potential
interference.
If you have any reason to suspect that interference is
taking place, switch your phone off immediately.
Health and safety information
19
Hearing Aid Compatibility with Mobile
Phones
When some mobile phones are used near some
hearing devices (hearing aids and cochlear
implants), users may detect a buzzing, humming, or
whining noise. Some hearing devices are more
immune than others to this interference noise, and
phones also vary in the amount of interference they
generate.
The wireless telephone industry has developed
ratings for some of their mobile phones, to assist
hearing device users in finding phones that may be
compatible with their hearing devices. Not all phones
have been rated. Phones that are rated have the
rating on their box or a label on the box.
The ratings are not guarantees. Results will vary
depending on the user’s hearing device and hearing
loss. If your hearing device happens to be vulnerable
to interference, you may not be able to use a rated
phone successfully. Trying out the phone with your
hearing device is the best way to evaluate it for your
personal needs.
M-Ratings: Phones rated M3 or M4 meet FCC
requirements and are likely to generate less
interference to hearing devices than phones that are
not labeled. M4 is the better/higher of the two
ratings.
T-Ratings: Phones rated T3 or T4 meet FCC
requirements and are likely to be more usable with a
hearing device°Øs telecoil (± Switch± or ±Telephone
Switch±) than unrated phones. T4 is the better/
higher of the two ratings. (Note that not all hearing
devices have telecoils in them.)Hearing devices may
also be measured for immunity to this type of
interference. Your hearing device manufacturer or
hearing health professional may help you find results
for your hearing device. The more immune your
hearing aid is, the less likely you are to experience
interference noise from mobile phones.
20
Health and safety information
Other Medical Devices
If you use any other personal medical devices,
consult the manufacturer of your device to determine
if it is adequately shielded from external RF energy.
Your physician may be able to assist you in obtaining
this information. Switch your phone off in health care
facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care
facilities may be using equipment that could be
sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle. You should
also consult the manufacturer of any equipment that
has been added to your vehicle.
Posted Facilities
Switch your phone off in any facility where posted
notices require you to do so.
Potentially Explosive Environments
Switch your phone off when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause
an explosion or fire resulting in bodily injury or even
death.
Users are advised to switch the phone off while at a
refueling point (service station). Users are reminded
of the need to observe restrictions on the use of
radio equipment in fuel depots (fuel storage and
distribution areas), chemical plants or where blasting
operations are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
Health and safety information
21
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas
(such as propane or butane), areas where the air
contains chemicals or particles, such as grain, dust
or metal powders, and any other area where you
would normally be advised to turn off your vehicle
engine.
Emergency Calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well
as user programmed functions, which cannot
guarantee connection in all conditions. Therefore,
you should never rely solely on any wireless phone
for essential communications (medical emergencies,
for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not
be possible on all wireless phone networks or when
certain network services and/or phone features are
in use. Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your
present location (for example, 911 or
22
Health and safety information
other official emergency number).
Emergency numbers vary by location.
3. Press .
If certain features are in use (call barring, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult this document and your local cellular service
provider.
When making an emergency call, remember to give
all the necessary information as accurately as
possible. Remember that your phone may be the
only means of communication at the scene of an
accident; do not cut off the call until given
permission to do so.
Restricting Children's access to your
Phone
Your phone is not a toy. Children should not be
allowed to play with it because they could hurt
themselves and others, damage the phone or make
calls that increase your phone bill.
Health and safety information
23
FCC Notice and Cautions
FCC Notice
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) this device
may not cause harmful interference, and
(2) this device must accept any
interference received, including
interference that may cause undesired
operation. This equipment has been tested
and found to comply with the limits for a
Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed
to provide reasonable protection against
harmful interference in a residential
installation.This equipment generates,
uses and can radiate radio frequency
energy and,if not installed and used in
accordance with the instructions, may
cause harmful interference to radio
communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user
is encouraged to try to correct the
interference by one or more of the
following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
equipment and receiver.
24
Health and safety information
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV
technician for help The phone may cause
TV or radio interference if used in close
proximity to receiving equipment. The
FCC can require you to stop using the
phone if such interference cannot be
eliminated.
Vehicles using liquefied petroleum gas
(such as propane or butane) must comply
with the National Fire Protection Standard
(NFPA-58). For a copy of this standard,
contact the National Fire Protection
Association, One Battery march Park,
Quincy, MA 02269, Attn: Publication Sales
Division.
Cautions
Changes or modifications made in the radio
phone, not expressly approved by
Samsung, will void the user authority to
operate the equipment.
Only use approved batteries, antennas
andchargers. The use of any unauthorized
accessories may be dangerous and void
the phone warranty if said accessories
cause damage or a defect to the phone.
Although your phone is quite sturdy, it is a
complex piece of equipment and can be
broken. Avoid dropping, hitting, bending or
sitting on it.
Health and safety information
25
Other Important Safety
Information
• Only qualified personnel should service
the phone or install the phone in a
vehicle. Faulty installation or service may
be dangerous and may invalidate any
warranty applicable to the device.
• Check regularly that all wireless phone
equipment in your vehicle is mounted and
operating properly.
• Do not store or carry flammable liquids,
gases or explosive materials in the same
compartment as the phone, its parts or
accessories.
• For vehicles equipped with an air bag,
remember that an air bag inflates with
great force. Do not place objects,
including both installed or portable
wireless equipment in the area over the
air bag or in the air bag deployment area.
If wireless equipment is improperly
installed and the air bag inflates, serious
injury could result.
• Switch your phone off before boarding an
aircraft. The use of wireless phone in
aircraft is illegal and may be dangerous to
the aircraft's operation.
• Failure to observe these instructions may
lead to the suspension or denial of
telephone services to the offender, or
legal action, or both.
26
Health and safety information
Product Performance
Getting the Most Out of Your Signal
Reception
The quality of each call you make or receive
depends on the signal strength in your area.
Your phone informs you of the current signal
strength by displaying a number of bars next
to the signal strength icon. The more bars
displayed, the stronger the signal.
If you're inside a building, being near a
window may give you better reception.
Understanding the Power Save Feature
If your phone is unable to find a signal after
15 minutes of searching, a Power Save
feature is automatically activated. If your
phone is active, it periodically rechecks
service availability or you can check it
yourself by pressing any key.
Anytime the Power Save feature is activated,
a message displays on the screen. When a
signal is found, your phone returns to
standby mode.
Maintaining Your Phone's Peak
Performance
For the best care of your phone, only
authorized personnel should service your
phone and accessories. Faulty service may
void the warranty.
There are several simple guidelines to
operating your phone properly and
maintaining safe, satisfactory service.
• Hold the phone with the antenna raised,
fully-extended and over your shoulder.
Health and safety information
27
• Try not to hold, bend or twist the phone's
antenna.
• Don't use the phone if the antenna is
damaged.
• Speak directly into the phone's receiver.
• Avoid exposing your phone and
accessories to rain or liquid spills. If your
phone does get wet, immediately turn the
power off and remove the battery. If it is
inoperable, call Customer Care for
service.
Availability of Various Features/
Ring Tones
Many services and features are network
dependent and may require additional
subscription and/or usage charges. Not all
features are available for purchase or use in
all areas. Downloadable Ring Tones may be
available at an additional cost. Other
conditions and restrictions may apply. See
your service provider for additional
information.
28
Health and safety information
Battery Standby and Talk Time
Standby and talk times will vary depending
on phone usage patterns and conditions.
Battery power consumption depends on
factors such as network configuration, signal
strength, operating temperature, features
selected, frequency of calls, and voice, data,
and other application usage patterns.
Battery Precautions
• Never use any charger or battery that is
damaged in any way.
• Use the battery only for its intended
purpose.
• If you use the phone near the network's
base station, it uses less power; talk and
standby time are greatly affected by the
signal strength on the cellular network
and the parameters set by the network
operator.
• Battery charging time depends on the
remaining battery charge and the type of
battery and charger used. The battery
can be charged and discharged hundreds
of times, but it will gradually wear out.
When the operation time (talk time and
Health and safety information
29
standby time) is noticeably shorter than
normal, it is time to buy a new battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries
and recharge your battery only with
Samsung-approved chargers. When a
charger is not in use, disconnect it from
the power source. Do not leave the
battery connected to a charger for more
than a week, since overcharging may
shorten its life.
• Extreme temperatures will affect the
charging capacity of your battery: it may
require cooling or warming first.
• Do not leave the battery in hot or cold
places, such as in a car in summer or
winter conditions, as you will reduce the
capacity and lifetime of the battery.
Always try to keep the battery at room
temperature. A phone with a hot or cold
battery may temporarily not work, even
when the battery is fully charged. Li-ion
batteries are particularly affected by
temperatures below 0 °C (32 °F).
• Do not short-circuit the battery.
Accidental short- circuiting can occur
when a metallic object (coin, clip or pen)
causes a direct connection between the +
and - terminals of the battery (metal
strips on the battery), for example when
you carry a spare battery in a pocket or
bag. Short-circuiting the terminals may
damage the battery or the object causing
the short-circuiting.
30
Health and safety information
• Dispose of used batteries in accordance
with local regulations. In some areas, the
disposal of batteries in household or
business trash may be prohibited. For
safe disposal options for Li-Ion batteries,
contact your nearest Samsung authorized
service center. Always recycle. Do not
dispose of batteries in a fire.
Care and Maintenance
Your phone is a product of superior design
and craftsmanship and should be treated
with care. The suggestions below will help
you fulfill any warranty obligations and allow
you to enjoy this product for many years.
• Keep the phone and all its parts and
accessories out of the reach of small
children.
• Keep the phone dry. Precipitation,
humidity and liquids contain minerals that
will corrode electronic circuits.
• Do not use the phone with a wet hand.
Doing so may cause an electric shock to
you or damage to the phone.
Health and safety information
31
• Do not use or store the phone in dusty,
dirty areas, as its moving parts may be
damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of
electronic devices, damage batteries, and
warp or melt certain plastics.
• Do not store the phone in cold areas.
When the phone warms up to its normal
operating temperature, moisture can
form inside the phone, which may
damage the phone's electronic circuit
boards.
• Do not drop, knock or shake the phone.
Rough handling can break internal circuit
boards.
• Do not use harsh chemicals, cleaning
solvents or strong detergents to clean the
phone. Wipe it with a soft cloth slightly
dampened in a mild soap-and-water
solution.
• Do not paint the phone. Paint can clog the
device's moving parts and prevent proper
operation.
• Do not put the phone in or on heating
devices, such as a microwave oven, a
stove or a radiator. The phone may
explode when overheated.
• When the phone or battery gets wet, the
label indicating water damage inside the
phone changes color. In this case, phone
repairs are no longer guaranteed by the
manufacturer's warranty, even if the
warranty for your phone has not expired.
• If your phone has a flash or light, do not
use it too close to the eyes of people or
animals. This may cause damage to their
eyes.
32
Health and safety information
• Use only the supplied or an approved
replacement antenna. Unauthorized
antennas or modified accessories may
damage the phone and violate regulations
governing radio devices.
If the phone, battery, charger or any
accessory is not working properly, take it to
your nearest qualified service facility. The
personnel there will assist you, and if
necessary, arrange for service.
33
introducing your
mobile phone
In this section, learn about your mobile phone’s
layout, keys, display, and icons.
Unpack
Check your product box for the following items:
• Mobile phone
• Battery
• Travel adapter (charger)
•User manual
• The items supplied with your phone may vary
depending on the software and accessories
available in your region or offered by your
service provider.
You can obtain additional accessories from
your local Samsung dealer.
• Use only Samsung-approved software.
Pirated or illegal software may cause damage
or malfunctions that are not covered by
manufacture’s warranty.
34
introducing your mobile phone
Phone layout
The front of your phone includes the following keys
and features:
The rear of your phone includes the following keys
and features:
Speaker
Power/Menu
exit key
Alphanumeric
keys
Special
function keys
Left softkey
Dial key
Volume key
Memory card slot
Mouthpiece
4-way navigation key
Display
Confirm key
Right softkey
Delete key
Music
player key
Earpiece
FM radio key
Speaker
Closing the phone automatically locks the
exposed keys to prevent you from accidentally
pressing them. To unlock these keys, press
<Unlock>
→
<OK>
.
Battery cover
Camera key
Multifunction jack**
Camera lens
* For 3.5 mm headset
** For 20 pin headset
Speaker
Headset Jack*
introducing your mobile phone
35
Keys
Key Function
Softkeys Perform actions indicated at the
bottom of the display
4-way
navigation
In Idle mode, access My Menu mode
(up) or user-defined menus (left/right/
down); In Idle mode, scroll through
menu options
Confirm
In Idle mode, access the list of web
browser menus; In Menu mode,
select the highlighted menu option or
confirm an input
FM radio Launch the FM radio
Music
player Launch the music player
Dial
Make or answer a call; In Idle mode,
retrieve recently dialled, missed, or
received numbers
Delete Delete characters or items in an
application
Power/
Menu exit
Turn the phone on and off (press and
hold); End a call; In Menu mode,
cancel input and return to Idle mode
Alpha-
numeric
Enter numbers, letters, and special
characters; In Idle mode, press and
hold [1] to access voice mails and [0]
to enter an international call prefix
Key Function
36
introducing your mobile phone
Display
Your phone’s display consists of three areas:
Special
function
Enter special characters or perform
special functions; In Idle mode, press
and hold [ ] for the Silent profile;
Press and hold [ ] to enter a pause
between numbers
Volume Adjust the phone’s volume
Camera
In Idle mode, turn on the camera
(press and hold); In Camera mode,
take a photo or record a video
Key Function
Icon line
Displays various icons
Text and graphic area
Displays messages,
instructions, and information
you enter
Softkey line
Displays the current actions
assigned to each softkey
introducing your mobile phone
37
Icons
Learn about the icons that appear on your display.
Icon Definition
Signal strength
GPRS network status
• Blue: GPRS network connected
• Red: Transferring data via GPRS network
EDGE network status
• Blue: EDGE network connected
• Red: Transferring data via EDGE network
Call in progress
No service available
SOS message feature activated
Memory card inserted
Call diverting activated
Bluetooth activated
Bluetooth hands-free car kit or headset
connected
Music playback in progress
Music playback paused
Alarm activated
Normal profile activated
Silent profile activated
Driving profile activated
Meeting profile activated
Outdoor profile activated
Icon Definition
38
introducing your mobile phone
Offline profile activated
New text message (SMS)
New multimedia message (MMS)
New email message
New voice mail message
FM radio on
Battery power level
Icon Definition
39
assembling and
preparing your
mobile phone
Get started by assembling and setting up
your mobile phone for its first use.
Install the SIM card and battery
When you subscribe to a cellular service, you will
receive a Subscriber Identity Module, or SIM card,
with subscription details, such as your personal
identification number (PIN) and optional services.
To install the SIM card and battery,
1. Remove the battery cover.
If the phone is on, press and hold [ ] to turn it
off.
40
assembling and preparing your mobile phone
2. Insert the SIM card. 3. Insert the battery.
4. Replace the battery cover.
Place the SIM card in the phone with the gold-
coloured contacts facing down.
assembling and preparing your mobile phone
41
Charge the battery
Before using the phone for the first time, you must
charge the battery.
1. Open the cover to the multifunction jack on the
side of the phone.
2. Plug the small end of the travel adapter into the
multifunction jack.
3. Plug the large end of the travel adapter into a
power outlet.
4. When the battery is fully charged (the icon is
no longer moving), unplug the travel adapter from
the power outlet.
5. Unplug the
travel
adapter from the phone.
6. Close the cover to the multifunction jack.
With the triangle facing up
Improperly connecting the travel adapter can
cause serious damage to the phone. Any
damages by misuse are not covered by the
warranty.
42
assembling and preparing your mobile phone
Insert a memory card (optional)
To store additional multimedia files, you must insert a
memory card. Your phone accepts microSD™
memory cards up to 2 GB (depending on memory
card manufacturer and type).
1. Open the cover to the memory card slot on the
side of the phone.
2. Insert a memory card with the label side facing
up.
3. Push the memory card in the memory card slot
until it locks in place.
To remove the memory card, push it gently until it
disengages from the phone, and then pull the
memory card out of the memory card slot.
About the low battery indicator
When your battery is low, the phone will emit a
warning tone and a low battery message. The
battery icon will also be empty and blinking. If
the battery level becomes too low, the phone
will automatically power off. Recharge your
battery to continue using your phone.
43
using basic
functions
Learn how to perform basic operations and use the
main features of your mobile phone.
Turn your phone on and off
To turn your phone on,
1. Slide open the phone.
2. Press and hold [ ].
3. Enter your PIN and press <OK> (if necessary).
4. When the setup wizard opens, customise your
phone as desired by following the screen.
To turn your phone off, repeat steps 1 and 2 above.
Switch to the Offline profile
By switching to the Offline profile, you can use your
phone’s non-network services in areas where
wireless devices are prohibited, such as aeroplanes
and hospitals.
44
using basic functions
To switch to the Offline profile, in Menu mode, select
Settings → Phone settings → Phone profiles →
Offline.
Access menus
To access your phone’s menus,
1. In Idle mode, press <Menu> to access Menu
mode.
2. Use the navigation key to scroll to a menu or
option.
3. Press <Select>, <OK>, or the Confirm key to
confirm the highlighted option.
4. Press <Back> to move up one level; Press [ ]
to return to Idle mode.
Use My Menu mode
Use My Menu mode to easily access your favourite
menus.
1. In Idle mode, scroll up.
2. Scroll to the menu you want and press the
Confirm key.
To assign menus,
1. In Menu mode, select Settings → Phone
settings → My menu.
2. Select a location and scroll to the menu you
want.
3. Press <Save>.
4. Repeat steps 2 and 3 to assign more menus (if
necessary).
Follow all posted warnings and directions from
official personnel when in areas where wireless
devices are prohibited.
45
using basic functions
Use multimedia shortcuts
You can quickly access multimedia applications by
sliding the phone down.
In Idle mode, you can enjoy multimedia contents,
such as FM radio, music, and video with the
enhanced sound quality via the speaker.
Customise your phone
Get more from your phone by customising it to
match your preferences.
Adjust the volume of the key tones
In Idle mode, press the Volume key to adjust the key
tone volume.
Switch to or from the Silent profile
In Idle mode, press and hold [ ] to silence or
unsilence your phone.
Change your ringtone
1. In Menu mode, select Settings → Phone
settings → Phone profiles.
2. Scroll to the profile you are using.
3. Press <Options> → Edit → Voice call ringtone.
46
using basic functions
4. Select a ringtone category → a ringtone.
5. Press <Options> → Save profile.
To switch to another profile, select it from the list.
Select a wallpaper (Idle mode)
1. In Menu mode, select Settings → Display
settings → Home screen → Wallpaper.
2. Select an image category → an image.
3. Press <Save>.
Select a skin colour (Menu mode)
1. In Menu mode, select Settings → Display
settings → My theme.
2. Select a colour pattern.
Set menu shortcuts
1. In Menu mode, select Settings → Phone
settings → Shortcuts.
2. Select a key to use as a shortcut.
3. Select a menu to assign to the shortcut key.
Lock your phone
1. In Menu mode, select Settings → Security
settings → Phone lock.
2. Select On.
3. Enter a new 4- to 8-digit password and press
<OK>.
4. Enter the new password again and press <OK>.
47
using basic functions
Use basic call functions
Learn to make or answer calls and use basic call
functions.
Make a call
1. In Idle mode, enter an area code and a phone
number.
2. Press [ ] to make a call.
3. To end the call, press [ ].
Answer a call
1. When a call comes in, press [ ].
2. To end the call, press [ ].
Make an IP call
1. In Idle mode, enter an area code and a phone
number.
2. Press <Options> → IP call.
The default IP call prefix appears before the
phone number.
3. To end the call, press [ ].
Adjust the volume
To adjust the volume during a call, press the Volume
key.
You can change to another prefix and add new
IP call prefix.
48
using basic functions
Use the speakerphone feature
1. During a call, press the Confirm key → <Yes> to
activate the speaker.
2. To switch back to the earpiece, press the
Confirm key again.
Use the headset
By plugging the supplied 20 pin headset into the
phone’s multifunction jack, you can make and
answer calls:
• To redial the last call, press the headset button,
and then press and hold it again.
• To answer a call, press and hold the headset
button.
• To end a call, press and hold the headset button.
Send and view messages
Learn to send or view text (SMS), multimedia (MMS),
or email messages.
Send a text message
1. In Menu mode, select Messages → Create new
message → Text message.
2. Enter your message text.
X
p. 50
3. Press <Options> → Send only or Save and
send.
4. Enter a destination number.
5. Press the Confirm key to send the message.
49
using basic functions
Send a multimedia message
1. In Menu mode, select Messages → Create new
message → Multimedia message.
2. Select Subject.
3. Enter a subject and press the Confirm key.
4. Select Image or video or Music or sound and
add an item.
5. Select Text.
6. Enter your message text and press the Confirm
key.
7. Press <Options> → Send.
8. Enter a destination number or an email address.
9. Press the Confirm key to send the message.
Send an email
1. In Menu mode, select Messages → Create new
message → Email.
2. Select Subject.
3. Enter a subject and press the Confirm key.
4. Select Message.
5. Enter your email text and press the Confirm key.
6. Select File attach and attach a file (if necessary).
7. Press <Options> → Send.
8. Enter an email address.
9. Press the Confirm key to send the email.
50
using basic functions
Enter text
When entering text, you can change the text input
mode:
• Press [ ] to change the text input mode.
• Press [ ] to change case in ABC or ENG mode.
• Press and hold [ ] to switch to Symbol mode.
Enter text in one of the following modes:
Mode Function
Pinyin
1. Press the appropriate alphanumeric
keys to enter pinyins.
2. Scroll left or right to select a pinyin.
3. Press the Confirm key. A number
appears by each character.
4. Scroll up or down until the character you
want appears.
5. Press an alphanumeric key to enter the
corresponding character.
Stroke
1. Press [
1
] through [
5
] to enter strokes.
Press [
6
] when you are unsure which
stroke to enter. This will insert a
placeholder.
2. Press the Confirm key. A number
appears by each character.
3. Scroll up or down until the character you
want appears.
4. Press an alphanumeric key to enter the
corresponding character.
ABC
Press the appropriate alphanumeric key until
the character you want appears on the
display.
Mode Function
51
using basic functions
View text or multimedia messages
1. In Menu mode, select Messages → My
messages → Inbox.
2. Select a text or multimedia message.
View an email
1. In Menu mode, select Messages → My
messages → Email inbox → Check new mail.
2. Select an email or a header.
3. If you selected a header, press <Options> →
Retrieve to view the body of the email.
ENG
1. Press the appropriate alphanumeric
keys to enter an entire word.
2. When the word displays correctly, press
[
0
] to insert a space. If the correct word
does not display, scroll up or down to an
alternate word.
Number
Press the appropriate alphanumeric key to
enter a number.
Symbol
Press the appropriate alphanumeric key to
select a symbol.
Mode Function
52
using basic functions
Add and find contacts
Learn the basics of using the Phonebook feature.
Add a new contact
1. In Idle mode, enter a phone number and press
<Options>.
2. Select Save → a memory location (phone or
SIM) → New.
3. Select a number type (if necessary).
4. Enter contact information.
5. Press <Options> → Save, or <Save> to add
the contact to memory.
Find a contact
1. In Menu mode, select Phonebook → Contact
list.
2. Enter the first few letters of the name you want to
find.
3. Select the contact’s name from the search list.
Once you have found a contact, you can:
• call the contact by pressing [ ]
• edit the contact information by pressing the
Confirm key
53
using basic functions
Use basic camera functions
Learn the basics to capture and view photos and
videos.
Capture photos
1. In Idle mode, press and hold the Camera key to
turn on the camera.
2. Rotate the phone anti-clockwise to landscape
view.
3. Aim the lens at the subject and make any
adjustments.
4. Press the Confirm key or Camera key to take a
photo.
The photo is saved automatically.
5. Press < > or the Camera key to take another
photo (step 3).
View photos
In Menu mode, select My files → Images → My
photos → a photo file.
Capture videos
1. In Idle mode, press and hold the Camera key to
turn on the camera.
2. Press [1] to switch to Recording mode.
3. Rotate the phone anti-clockwise to landscape
view.
4. Aim the lens at the subject and make any
adjustments.
5. Press the Confirm key or Camera key to start
recording.
6. Press the Confirm key, < >, or the Camera key
to stop recording.
The video is saved automatically.
7. Press < > or the Camera key to record another
video (step 4).
54
using basic functions
View videos
In Menu mode, select My files → Videos → My
video clips → a video file.
Listen to music
Learn how to listen to music via the music player or
FM radio.
Listen to the FM radio
1. Plug the supplied headset into the phone.
2. In Menu mode, select FM radio.
You can also press [FM] in Idle mode, or slide
down the front part of your phone and select FM
radio.
3. Press the Confirm key to start the radio.
4. Press <Yes> to start automatic tuning.
The radio scans and saves available stations
automatically.
The first time you access the
FM radio
, you
will be prompted to start automatic tuning.
55
using basic functions
5. Scroll up or down to a stored radio station.
6. To turn off the FM radio, press the Confirm key.
Listen to music files
Start by transferring files to your phone or memory
card:
• Download from the wireless web.
X
Browse the
web
• Download from a PC with the optional Samsung
PC Studio.
X
p. 61
• Receive via Bluetooth.
X
p. 66
• Copy to your memory card.
X
p. 62
• Synchronise with Windows Media Player 11.
X
p. 62
After transferring music files to your phone or
memory card,
1. In Menu mode, select Music → Music player.
You can also press [ ] in Idle mode, or slide
down the front part of your phone and select
Music.
2. Select a music category → a music file.
3. Control playback using the following keys:
Key Function
Confirm
Pause or resume playback
Volume
Adjust the volume up or down
Navigation
• Left: Restart playback; Skip
backward (press within 3
seconds); Scan backward in a file
(press and hold)
• Right: Skip forward; Scan forward
in a file (press and hold)
• Up: Open the playlist
• Down: Stop playback
56
using basic functions
Browse the web
Learn to access and bookmark your favourite web
pages.
Browse web pages
1. In Idle mode, press the Confirm key and select
Home to launch your service provider’s
homepage.
2. Navigate web pages using the following keys:
Bookmark your favourite web pages
1. In Menu mode, select Browser → Bookmarks.
2. Select an empty location.
3. Enter a page title and a web address (URL).
4. Press <Save>.
Key Function
Navigation
Scroll up or down on a web page
Confirm
Select an item
<
Back
>
Return to the previous page
<
Options
>
Access a list of browser options
57
using advanced
functions
Learn how to perform advanced operations and use
additional features of your mobile phone.
Use advanced call functions
Learn about your phone’s additional calling
capabilities.
View and dial missed calls
Your phone will display calls you have missed on the
display. To dial the number of a missed call,
1. Press <View>.
2. Scroll to the missed call you want to dial.
3. Press [ ] to dial.
Call a recently dialled number
1. In Idle mode, press [ ] to display a list of
recent numbers.
2. Scroll to the number you want and press [ ] to
dial.
58
using advanced functions
Hold a call or retrieve a held call
Press <Hold> to place a call on hold or press
<Retrieve> to retrieve a held call.
Dial a second call
If your network supports this function, you can dial
another number during a call:
1. Press <Hold> to place the first call on hold.
2. Enter the second number to dial and press [ ].
3. Press <Swap> to switch between the two calls.
4. To end the call on hold, press <Options> → End
held call.
5. To end the current call, press [ ].
Answer a second call
If your network supports this function, you can
answer a second incoming call:
1. Press <Accept> to answer the second call.
The first call is automatically placed on hold.
2. Press <Swap> to switch between the calls.
Make a multiparty call (conference call)
1. Call the first party you want to add to the
multiparty call.
2. While connected to the first party, call the
second party.
The first party is automatically placed on hold.
3. When connected to the second party, press
<Options> → Join.
59
using advanced functions
4. Repeat steps 1 and 2 to add more parties (if
necessary).
5. To end the multiparty call, press [ ].
Call an international number
1. In Idle mode, press and hold [0] to insert the +
character.
2. Enter the complete number you want to dial
(country code, area code, and phone number),
and then press [ ] to dial.
Call a contact from Phonebook
You can call numbers directly from Phonebook using
stored contacts.
X
p. 52
1. In Menu mode, select Phonebook → Contact
list.
2. Scroll to the number you want to dial and press
[] to dial.
Use advanced Phonebook functions
Learn to create namecards, set speed dial numbers,
and create groups of contacts.
Create a namecard
1. In Menu mode, select Phonebook → My
namecard.
2. Enter your personal details and press <Options>
→ Save or the Confirm key.
Set speed dial numbers
1. In Menu mode, select Phonebook → Speed
dial.
2. Scroll to a number you want to set (2-9) and
press the Confirm key.
You can send your namecard by attaching it to
a message or email or transferring it via the
Bluetooth wireless feature.
60
using advanced functions
3. Select a contact → a number (if necessary) to
assign to the number.
The contact is saved to the speed dial number.
Create a group of contacts
By creating groups of contacts, you can assign
ringtones and caller ID photos to each group or send
messages and emails to an entire group. Start by
creating a group:
1. In Menu mode, select Phonebook → Group.
2. Press <Options> → Add.
3. Enter a group name and scroll down.
4. To set the caller ID image, press the Confirm key
→ an image category → an image → <Select>.
5. To set a group ringtone, scroll down and press
the Confirm key → a ringtone category → a
ringtone.
6. Press <Save>.
Use advanced messaging functions
Learn to create templates and use templates to
create new messages.
Create a text template
1. In Menu mode, select Messages → Templates
→ Text template.
2. Select an empty location to open a new template
window.
3. Enter your text and press the Confirm key to save
the template.
You can now call this contact from Idle mode
by pressing and holding the assigned speed
dial number.
61
using advanced functions
Create a multimedia template
1. Create a multimedia message, with a subject
and desired attachments, to use as your
template.
X
p. 48
2. From the message screen, press <Options> →
Save in → Templates.
The message is now saved as a multimedia
template with a preset name, such as ‘Birthday.’
Insert text templates in new messages
1. In Menu mode, select Messages → Create new
message → Text message.
2. Press <Options> → Insert → Text template →
a template.
Create a message from a multimedia
template
1. In Menu mode, select Messages → Templates
→ Multimedia message templates.
2. Scroll to the template you want and press
<Options> → Edit.
Your template opens as a new multimedia
message.
Use advanced music functions
Learn to prepare music files, create playlists, and
store radio stations.
Copy music files via Samsung PC Studio
1. In Menu mode, select Settings → Phone
settings → PC connections → Samsung PC
studio.
62
using advanced functions
2. Using an optional PC data cable, connect the
multifunction jack on your phone to a PC.
3. Run Samsung PC Studio and copy files from the
PC to the phone.
Refer to Samsung PC Studio help for more
information.
Copy music files to a memory card
1. Insert a memory card.
2. In Menu mode, select Settings → Phone
settings → PC connections → Mass storage.
3. Using an optional PC data cable, connect the
multifunction jack on your phone to a PC.
When connected, a pop-up window will appear
on the PC.
4. Select Open folder to view files in the pop-up
window on the PC.
5. Copy files from the PC to the memory card.
Synchronise your phone with Windows
Media Player
1. In Menu mode, select Settings → Phone
settings → PC connections → Media player.
2. Using an optional PC data cable, connect the
multifunction jack on your phone to a PC with
Windows Media Player installed.
When connected, a pop-up window will appear
on the PC.
3. Select Sync digital media files to this device in
the pop-up window on the PC.
4. Edit or enter your phone's name in the pop-up
window (if necessary), and then click Finish.
5. Select and drag the music files you want to the
sync list.
6. Click Start Sync.
63
using advanced functions
Create a playlist
1. In Menu mode, select Music → Music player →
Playlists.
2. Press <Options> → Create playlist.
3. Enter a title for your new playlist and press the
Confirm key.
4. Select the new playlist.
5. Press <Options> → Add → Tracks.
6. Select the files you want to include and press
<Add>.
Customise your music player settings
Learn to adjust the playback and sound settings for
your music player.
1. In Menu mode, select Music → Music player.
2. Press <Options> → Settings.
3. Adjust the settings to customise your music
player.
4. Press <Save>.
Store radio stations automatically
1. Plug the supplied headset into the phone.
2. In Menu mode, select FM radio.
3. Press the Confirm key to start the radio.
4. Press <Options> → Self-tuning.
5. Press <Yes> to confirm (if necessary).
The radio scans and saves available stations
automatically.
64
using advanced functions
Find information of music
Learn to access an online music service and get
information about the songs you hear while on the
move.
1. In Menu mode, select Music → Music
recognition → Music recognition.
Your phone connects to the server.
2. When your phone is successfully registered,
press <Record> to record a part of music you
want to find.
Some service providers may not support this
service and the database may not have
information for all songs.
65
using tools and
applications
Learn how to work with your mobile phone’s tools
and additional applications.
Use the Bluetooth wireless feature
Learn about your phone’s ability to connect to other
wireless devices for exchanging data and using
hands-free features.
Turn on the Bluetooth wireless feature
1. In Menu mode, select Applications →
Bluetooth.
2. Press <Options> → Settings.
3. Scroll down to Activation.
4. Scroll left or right to On.
5. To allow other devices locate your phone, scroll
down and scroll left or right to On.
6. Press <Save>.
66
using tools and applications
Find and pair with other Bluetooth-
enabled devices
1. In Menu mode, select Applications →
Bluetooth → Search new device.
2. Scroll to a device and press <Select>.
3. Enter a PIN for the Bluetooth wireless feature or
the other device’s Bluetooth PIN, if it has one,
and press <OK>.
When the owner of the other device enters the
same code or accepts the connection, pairing is
complete.
Send data using the Bluetooth wireless
feature
1. Select the file or item from one of your phone’s
applications that you want to send.
2. Press <Options> → Send via → Bluetooth
(when sending contact data, specify which data
to send).
Receive data using the Bluetooth
wireless feature
1. Enter the PIN for the Bluetooth wireless feature
and press <OK> (if necessary).
2. Press <Yes> to confirm that you are willing to
receive data from the device (if necessary).
67
using tools and applications
Activate and send an SOS message
When you have an emergency, you can send an
SOS message asking for help.
1. In Menu mode, select Messages → SOS
messages → Sending options.
2. Scroll left or right to On.
3. Scroll down and press the Confirm key to open
the recipient list.
4. Press the Confirm key to open your contact list.
5. Select a contact.
6. Select a number (if necessary).
7. When you are finished selecting contacts, press
the Confirm key to save the recipients.
8. Scroll down and set the number of times to
repeat the SOS message.
9. Press <Save> → <Yes>.
To send an SOS message, the phone must be
closed and the keys locked. With the phone closed,
press the Volume key four times.
Record and play voice memos
Learn to operate your phone’s voice recorder.
Record a voice memo
1. In Menu mode, select Applications → Voice
recorder.
2. Press the Confirm key to start recording.
3. Speak your memo into the microphone.
4. When you are finished speaking, scroll down or
press <Save>.
Once you send an SOS message, all phone
functions will be suspended until you press
[].
68
using tools and applications
Play a voice memo
1. From the voice recorder screen, press
<Options> → Go to My voice clips.
2. Select a file.
3. Control the playback using the following keys:
Use Java-powered games and
applications
Learn to use games and applications powered by
award-winning Java technology.
Download games or applications
1. In Menu mode, select Applications → Java
world → Download games.
Your phone connects to the website preset by
your service provider.
2. Search for a game or application and download it
to the phone.
Play games
1. In Menu mode, select Applications → Java
world.
2. Select a game from the list and follow the
on-screen instructions.
Key Function
Confirm
Pause or resume playback
Volume
Adjust the volume up or down
Navigation
• Left: Scan backward in a file
• Right: Scan forward in a file
• Down: Stop playback
Available games may vary, depending on your
service provider or region. Game controls and
options may vary.
69
using tools and applications
Launch applications
1. In Menu mode, select Applications → Java
world → an application.
2. Press <Options> to access a list of various
options and settings for your application.
Edit images
Learn to edit images and apply fun effects.
Apply effects to images
1. In Menu mode, select Applications → Image
editor.
2. Press <Options> → New image → Open or
Take a photo.
3. Select an image or take a new photo.
4. Press <Load> or < >.
5. Press <Options> → Effects → an effect option.
6. Press <Done> to apply the effect.
7. When you are finished applying effects, press
<Options> → Save as → <Yes>.
8. Enter a new file name for the image and press
the Confirm key.
Adjust an image
1. In Menu mode, select Applications → Image
editor.
2. Press <Options> → New image → Open or
Take a photo.
3. Select an image or take a new photo.
4. Press <Load> or < >.
5. Press <Options> → Adjust → an adjustment
option (brightness, contrast, or colour).
70
using tools and applications
6. Using the navigation key, adjust the image as
desired and press <Done>.
7. Press <Options> → Save as → <Yes>.
8. Enter a new file name for the image and press
the Confirm key.
Transform an image
1. In Menu mode, select Applications → Image
editor.
2. Press <Options> → New image → Open or
Take a photo.
3. Select an image or take a new photo.
4. Press <Load> or < >.
5. Press <Options> → Transform → Rotate or
Flip.
6. Using the navigation key, adjust the image as
desired and press <Done>.
7. Press <Options> → Save as → <Yes>.
8. Enter a new file name for the image and press
the Confirm key.
Insert a visual feature
1. In Menu mode, select Applications → Image
editor.
2. Press <Options> → New image → Open or
Take a photo.
3. Select an image or take a new photo.
4. Press <Load> or < >.
5. Press <Options> → Insert → a visual feature
(frame, clip art, or emoticon).
6. Select a visual feature to add and press the
Confirm key.
7. Press <Select>.
71
using tools and applications
8. Using the navigation key, relocate the visual
feature (if necessary).
9. Press <Done>.
10. Press <Options> → Save as → <Yes>.
11. Enter a new file name for the image and press
the Confirm key.
Shake and play
Learn to enjoy beatbox rhythms and games with the
innovative motion recognition feature that detects
movements, such as shaking your phone.
1. In Menu mode, select Applications → Shake
and play → an application.
2. Play with the beatbox, roll the dice, and choose a
random number in a lottery game.
Create and view world clocks
Learn to view the time in another country or city and
set world clocks to appear on your display.
Create world clocks
1. In Menu mode, select Applications → World
clock.
2. Scroll down to the middle clock.
3. Scroll left or right to a time zone.
4. Scroll down to the bottom clock.
5. Scroll left or right to a time zone.
6. Press <Options> → Save to create your world
clocks.
To set daylight saving time. Press <
Options
>
→
Apply daylight saving time
→
time zones
→
<
Save
>.
72
using tools and applications
Add a world clock to your display
In Dual Clock Display mode, you can view clocks
with two different time zones on your display.
After you have created world clocks,
1. In Menu mode, select Applications → World
clock.
2. Scroll to a world clock you want to add and
press <Options> → Mark as second clock.
3. Press <Options> → Display settings.
4. Scroll left or right to a clock type.
5. Press <Save>.
Set and use alarms
Learn to set and control alarms for important events.
Set a new alarm
1. In Menu mode, select Alarms.
2. Select an empty alarm location.
3. Set alarm details.
4. Press <Save>.
The auto power-up feature sets the phone to
automatically turn on and sound the alarm at
the designated time if the phone is turned off.
73
using tools and applications
Stop an alarm
When the alarm sounds,
• Press any key to stop an alarm without snooze.
• Press <Confirm> or the Confirm key to stop an
alarm with snooze, or press <Snooze> or any key
to silence the alarm for the snooze period.
Deactivate an alarm
1. In Menu mode, select Alarms.
2. Select the alarm you want to deactivate.
3. Scroll down (if necessary).
4. Scroll left or right to Off.
5. Press <Save>.
Use the calculator
1. In Menu mode, select Applications →
Calculator.
2. Use the keys that correspond to the calculator
display to perform basic mathematical
operations.
Convert currencies or
measurements
1. In Menu mode, select Applications →
Converter → a conversion type.
2. Enter the currencies or measurements and units
in the appropriate fields.
74
using tools and applications
Set a countdown timer
1. In Menu mode, select Applications → Timer.
2. Press <Set>.
3. Enter the length of time to count down and press
<OK>.
4. Press the Confirm key to begin or pause the
countdown.
5. When the timer expires, press <OK> to stop the
alert.
Use the stopwatch
1. In Menu mode, select Applications →
Stopwatch.
2. Press the Confirm key to begin and record lap
times.
3. When you are finished, press <Stop>.
4. Press <Reset> to clear recorded times.
Create a text memo
1. In Menu mode, select Applications → Memo.
2. Press <Create>.
3. Enter your memo text and press the Confirm key.
75
using tools and applications
Manage your calendar
Learn to change the calendar view and create
events.
Change the calendar view
1. In Menu mode, select Calendar.
2. Press <Options> → View by → Day or Week.
Create an event
1. In Menu mode, select Calendar.
2. Press <Options> → Create → an event type.
3. Enter the details of the event as required.
4. Press <Save>.
a
troubleshooting
If you are having trouble with your mobile phone, try these troubleshooting procedures before contacting a service
professional.
When you turn on your phone, the following
messages may appear:
Message Try this to solve the problem:
Insert SIM Ensure that the SIM card is installed
correctly.
Phone lock
When the phone lock feature is
enabled, you must enter the password
you set for the phone.
Enter PIN
When using the phone for the first time
or when the PIN requirement is
enabled, you must enter the PIN
supplied with the SIM card. You can
disable this feature by using the
PIN
lock
menu.
Enter PUK
Your SIM card is blocked, usually as a
result of entering your PIN incorrectly
several times. You must enter the PUK
supplied by your service provider.
Message Try this to solve the problem:
b
troubleshooting
Your phone displays “No network”, “Network
unavailable”, or “Not done.”
• When you are in areas with weak signals or poor
reception, you may lose reception. Move to
another area and try again.
• You cannot access some options without a
subscription. Contact your service provider for
more details.
You enter a number, but the call is not dialled.
• Ensure that you have pressed the Dial key: [ ].
• Ensure that you have accessed the right cellular
network.
• Ensure that you have not set call barring for the
phone number.
Another caller cannot reach you.
• Ensure that your phone is turned on.
• Ensure that you have accessed the right cellular
network.
• Ensure that you have not set call barring for the
phone number.
Another caller cannot hear you speaking.
• Ensure that you are not covering the built-in
microphone.
• Ensure that the microphone is close to your
mouth.
• If using a headset, ensure that it is properly
connected.
c
troubleshooting
The phone beeps and the battery icon flashes.
Your battery is low. Recharge or replace the battery to
continue using the phone.
The audio quality of the call is poor.
• Ensure that you are not blocking the phone’s
internal antenna.
• When you are in areas with weak signals or poor
reception, you may lose reception. Move to
another area and try again.
You select a contact to call, but the call is not
dialled.
• Ensure that the correct number is stored in the
contact list.
• Re-enter and save the number, if necessary.
The battery does not charge properly or
sometimes the phone turns itself off.
• The battery terminals may be dirty. Wipe both
gold-coloured contacts with a clean, soft cloth
and try charging the battery again.
• If the battery will no longer charge completely,
dispose of the old battery properly and replace it
with a new battery.
Your phone is hot to the touch.
When you use several applications at once, your
phone requires more power and may heat up.
This is normal and should not affect your phone’s
lifespan or performance.
Some of the contents in this manual may differ from your phone depending on the software of the phone or your service provider.
World Wide Web
http://www.samsungmobile.com
