Samsung Electronics Co SGHF300 Single-Band PCS GSM/ EDGE Phone with Bluetooth User Manual
Samsung Electronics Co Ltd Single-Band PCS GSM/ EDGE Phone with Bluetooth
Users Manual
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-XXXXXA
English (EU). 09/2006. Rev. 1.0
* Depending on the software installed or your service provider or country, some of the
descriptions in this guide may not match your phone exactly.
* Depending on your country, your phone and accessories may appear different from the
illustrations in this guide.
SGH-F300
User’s Guide
Draft_2nd
2006. 09. 04
Version: F300XXFH1
Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or
illegal.
Drive safely at all times
Do not use a hand-held phone while driving.
Park the vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point
(service station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using
them in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external
radio frequency energy. Follow any regulations
or rules in force.
Interference
All wireless phones may be subject to
interference, which could affect their
performance.
1
Important safety precautions
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is
forbidden to use it, or when it may cause
interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to your ear).
Avoid unnecessary contact with the antenna when
the phone is switched on.
Emergency calls
Key in the emergency number for your present
location, then press
.
Keep your phone away from small children
Keep the phone and all its parts, including
accessories, out of the reach of small children.
Accessories and batteries
Use only Samsung-approved batteries and
accessories, such as headsets and PC data cables.
Use of any unauthorised accessories could damage
you or your phone and may be dangerous.
Never disassemble your phone
Never disassemble the phone for any reason. The
battery pack could be damaged or electro-
conductive materials could get into the phone,
causing the serious damage the phone, as well as,
causing the pone to be combustible.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health
and safety information" on page 75.
• The phone could explode if the battery is replaced
with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.
At very high volumes, prolonged listening to a
headset can damage your hearing.
2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone. To quickly
learn the basics for your phone, please refer to “Get
started.”
In this guide, the following instruction icons appear:
Indicates that you need to pay careful
attention to the subsequent information
regarding safety or phone features.
Indicates that you can get more
information on the referenced page.
→
Indicates that you need to press the
Navigation keys to scroll to the specified
option and then select it.
[ ] Indicates a key on the phone.
For example, [ ]
< > Indicates a soft key, whose function is
displayed on the phone screen.
For example, <
Menu
>
• Multimedia gate
Use separated phone functions and
Multimedia player functions, switching your
phone’s dual display.
Special
features of your phone
• Synchronisation with Windows Media
Player
Transfer music files to your phone directly
from Windows Media Player.
•Music player
Play music files on your
phone. You can use other
phone functions while
listening to music.
• Camera and camcorder
Use the camera module on
your phone to take a photo or
record a video.
3
Special features of your phone
•FM radio
Listen to your favourite radio
stations anytime, anywhere.
• Voice recorder
Record memos or sounds.
• Offline mode
Switch your phone to Offline
mode to use its non-wireless
functions while on an
airplane.
• Bluetooth
Transfer media files and
personal data, and connect to
other devices using wireless
Bluetooth technology.
•Web browser
Access the wireless web to
get up-to-the-minute
information and a wide
variety of media content.
• Multimedia Message
Service (MMS)
Send and receive MMS
messages with a combination
of text, images, video, and
audio.
•SOS message
Send SOS messages to your
family or friends for help in an
emergency.
• Name card
Create name cards with your
number and profile.
Whenever introducing
yourself to others, use this
convenient electronic name
card.
• Organiser
Keep track of your daily,
weekly, and monthly
schedule.
4
Contents
Unpack 6
Make sure you have each item
Your phone 6
Keys, features, and locations
Get started 7
First steps to operating your phone
Assemble and charge the phone ............................ 7
Power on or off.................................................... 8
Switch between Phone mode and
Multimedia Player mode........................................ 9
Keys and icons .................................................... 9
Access menu functions ........................................ 12
Enter text .......................................................... 13
Customise your phone......................................... 15
Make/Answer calls .............................................. 16
Use a memory card............................................. 17
Reset the phone ................................................. 18
Multimedia player functions 18
Use multimedia functions: the music player, camera,
media album, FM radio, and voice recorder
Use Multimedia player keys ................................. 18
Play music......................................................... 20
Use the camera.................................................. 24
View photos and videos in Album.......................... 28
Listen to the FM radio ......................................... 29
Use the voice recorder ........................................ 31
Call functions 32
Advanced calling features
Menu functions 35
All menu options listed
Solve problems 73
Help and personal needs
Health and safety information 75
Index 81
5
Overview of menu functions
To access Menu mode, press <
MENU
> in Idle mode.
1 Call log
p. 35
1 Recent contacts
2 Missed calls
3 Dialled calls
4 Received calls
5 Delete all
6 Call time
7 Call costs
1
p. 35
p. 35
p. 35
p. 35
p. 35
p. 35
p. 36
2 Phonebook
p. 36
1 Contact list
2 Create contact
3 Group
4 Speed dial
5 My namecard
6 Own number
7 Management
8 Service number
1
p. 36
p. 37
p. 38
p. 38
p. 39
p. 39
p. 39
p. 39
3 Applications
p. 40
1 Voice recorder
2 World clock
3 Alarm
4 Timer
5 Stopwatch
6 Memo
7 SIM AT
1
p. 40
p. 41
p. 41
p. 41
p. 42
p. 42
p. 42
4 Browser
p. 43
1 Home
2 Enter URL
3 Bookmarks
4 Saved pages
5 History
6 Clear cache
7 Browser settings
p. 43
p. 44
p. 44
p. 44
p. 45
p. 45
p. 45
5 Messages
p. 45
1 Create message
2 My messages
3 Templates
4 Delete all
5 Settings
6 SOS messages
7 Memory status
p. 45
p. 47
p. 51
p. 51
p. 52
p. 53
p. 54
6 My Files
p. 54
1 Images
2 Videos
3 Music
4 Sound
5 Other files
6 Memory card
2
7 Memory status
p. 54
p. 55
p. 56
p. 57
p. 58
p. 58
p. 58
7 Calendar
p. 59
8 Camera
p. 61
9 Settings
p. 63
1 Time and date
2 Phone settings
3 Display settings
4 Sound settings
5 Light settings
6 Network services
7 Bluetooth
8 Security
9 Connection settings
10 Reset settings
p. 63
p. 63
p. 64
p. 65
p. 66
p. 66
p. 68
p. 70
p. 71
p. 72
1. Available only if supported by your SIM
card.
2. Available only if a memory card is
inserted.
6
Unpack
Make sure you have each item
• Phone
•Travel Adapter
•User’s Guide
You can obtain various accessories from
your local Samsung dealer.
The items supplied with your phone
and the accessories available at your
Samsung dealer may vary, depending
on your country or service provider.
Your phone
Keys, features, and locations
OK
Special
function keys
Camera lens
Phone display
Dial key
Alphanumeric
keys
Web access/
Confirm key
Left soft key
Microphone
Navigation keys
(Up/Down/Left/
Right)
Right soft key
Power on/off/
Menu exit key
Earpiece
Delete key Camera
7
Get started
First steps to operating your phone
SIM card information
When you subscribe to a cellular network, you
receive a plug-in SIM (Subscriber Identity Module)
card loaded with your subscription details, such as
your PIN and available optional services.
Assemble and charge the phone
Multimedia
player display
Right navigation/
soft key
Option key
Menu exit key
Volume keys
SIM card slot
Memory card
slot
Headset/
Adapter jack
Phone/
Multimedia
switch key
Keypad lock
switch
Left navigation/
soft key
Confirm key
Insert the SIM card.
• Make sure that the
gold-coloured contacts
on the card are face
down.
• Do not remove the
SIM card when the
phone is on.
Plug the travel
adapter into the
phone.
Get started
8
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the low battery message displays, and
• the empty battery icon blinks.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
Power on or off
Keypad lock
You can lock the keypad to prevent any unwanted
phone operations, from accidentally pressing any of
the keys.
In Idle mode, press up. To unlock the keypad,
press down.
Plug the adapter into a standard AC power
outlet.
When the phone is completely charged, unplug
the adapter from the power outlet and from the
phone.
Your phone’s battery is non-replaceable. When
the lifespan of the battery expires, bring the
phone to a Samsung service centre to replace the
battery.
Switch on
1. Press and hold [ ].
2. If necessary, enter the PIN
and press <
OK
>.
Switch off
Press and hold [ ].
Do not switch on the phone when mobile phone
use is prohibited.
9
Get started
Offline mode
You can switch the phone to Offline mode, in which
the phone functions requiring network connection
are deactivated. This mode is helpful when you want
to use your phone in a place where you are not
allowed to use mobile devices, such as in an airplane
or at a hospital.
To switch to Offline mode, press <
Menu
> and select
Settings
→
Phone settings
→
Offline mode
→
On
.
In Offline mode, you can use non-wireless functions,
such as games, calendar, camera, and music player.
Switch between Phone mode and
Multimedia Player mode
Your phone provides you with entertaining
multimedia functions, as well as traditional phone
functions.
When you switch on your phone, it goes into
traditional Phone mode using the small display on
the front side.
To switch the phone to Multimedia Player mode
multimedia player functions, press [ ]. The
larger screen on the rear side turns on.
Keys and icons
Phone keys
Perform the function indicated on the
bottom line of the display.
In Idle mode, access your favourite
menus directly.
p. 63
In Menu mode, scroll through menu
options.
In Idle mode, launch the web browser.
In Menu mode, select the highlighted
menu option or confirm input.
Delete characters from the display or
items in an application.
In Idle mode, press and hold to turn on
the camera.
Make or answer a call.
In Idle mode, retrieve the numbers
recently dialled, missed, or received.
Press and hold to switch the phone on
or off.
End a call.
In Menu mode, cancel input and return
the phone to Idle mode.
Get started
10
Multimedia player keys
Common keys
Icons
The following icons may appear on the top line of the
screen to indicate your phone’s status. Depending
on your country or service provider, the icons shown
on the display may vary
.
Enter numbers, letters, and some
special characters.
Enter special characters or perform
special functions.
Scroll through items or perform a
specific function, according to your
actions: dragging, pressing, or holding.
p. 18
Select the highlighted menu option or
confirm input.
Take a photo, record a video or voice
memo, or begin music playback.
Lock or unlock the keys.
Switch between Phone mode and
Multimedia Player mode.
Adjust the phone volume.
In Idle mode, adjust the key tone
volume.
During a call, adjust the earpiece
volume.
Received signal strength
Call in progress
Out of your service area; you cannot make
or receive calls
SOS message feature active
p. 53
Alarm set
p. 41
Music playback in progress
Music playback paused
SMS message
MMS message
11
Get started
Voicemail
Configuration message
Call diverting feature active
p. 67
Bluetooth active
p. 68
Bluetooth headset connected
p. 69
Browsing Internet
p. 43
Connected to secured web page
Browsing Internet on PC using phone as
modem
Synchronising data with PC Studio
GPRS network
Connecting to GPRS network
Transferring data in GPRS network
EDGE network
Connecting to EDGE network
Transferring data in EDGE network
Home Zone, if registered for the
appropriate service
Office Zone, if registered for the
appropriate service
Roaming network
Memory card inserted
p. 17
Mute mode, during a call
p. 34
Silent mode (Vibration)
Silent mode (Mute)
Call ringer set to vibrate
p. 65
Phone speaker active
Keypad locked
p. 8
Battery power level
Get started
12
Access menu functions
In Phone mode
In Multimedia Player mode
You can access menu functions and options by
touching or dragging on the multimedia player keys.
Further details are described in “Multimedia player
functions.”
p. 18
Use the soft
keys
The roles of the soft keys vary
depending on the function you
are using. The bottom line of the
display indicates their current
role.
Press the left
soft key to select
the highlighted
option.
Press the right
soft key to return
to the previous
menu level.
Select Back
Select an
option
1. Press a desired soft key.
2. Press the Navigation keys to
move to the next or previous
option.
3. Press <
Select>
, <
OK
>, or
[
OK
] to confirm the function
displayed or option
highlighted.
4. To exit, choose either of the
following methods:
• Press <
Back
> to move
up one level.
• Press [ ] to return to
Idle mode.
Use menu
numbers
Press the number key
corresponding to the option you
want.
13
Get started
Enter text
You can enter text for some features, such as
Messages, Phonebook, or Calendar, using AB mode,
T9 mode, Number mode, and Symbol mode.
Entering text is only available in Phone mode. If
you select an option requiring text input in
Multimedia Player mode, the screen will
automatically switch to the Phone mode display.
Change the
text input
mode
• Press and hold [ ] to switch
between T9 mode ( )
and AB mode ( ).
Depending on your country,
you may also be able to
access an input mode for your
specific language.
• Press [ ] to change case or
switch to Number mode
().
• Press and hold [ ] to switch
to Symbol mode ( ).
AB mode Entering a word in AB mode
Press the appropriate key until
the character you want appears
on the display.
To enter the same letter twice or
to enter a different letter on the
same key, press [Right] or wait
until the corsor moves to the
right. Then, enter the next letter.
Other AB mode operations
• Press [ ] to insert a space.
• Press the Navigation keys to
move the cursor.
•Press [
C
] to delete characters
one by one.
•Press and hold [
C
] to clear
the display
Get started
14
T9 mode Entering a word in T9 mode
1. Press [
2
] to [
9
]
to start
entering a word. Press each
key once for each letter.
2. Enter the whole word before
editing or deleting characters.
3. When the word displays
correctly, go to step 4.
Otherwise, press [
0
] to
display alternative word
choices for the keys that you
have pressed.
4. Press [ ] to insert a space
and enter the next word.
Other T9 mode operations
• Press [
1
] to enter periods or
apostrophes automatically.
• Press [ ] to insert a space.
• Press the Navigation keys to
move the cursor.
• Press [
C
] to delete characters
one by one.
• Press and hold [
C
] to clear
the display.
Adding a new word to the T9
dictionary
1. Enter the word that you want
to add.
2. Press [
0
] to display
alternative words for your key
presses. When there are no
more alternative words,
Add
appears.
3. Press <
Add
>.
4. Enter the word you want
using AB mode and press
<
OK
>.
Number mode
Press the keys corresponding to
the digits you want.
Symbol mode
1. Press [Up] or [Down] to
display the symbols you
want.
2. Press the corresponding
number key to select the
symbol you want.
3. Press [
OK
] to insert the
symbols.
15
Get started
Customise your phone
1. In Idle mode, press <
Menu
>
and select
Settings
→
Phone settings
→
Language
.
2. Select a language.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Sound settings
→
Incoming call
→
Ringtone
.
2. Select a ringtone category.
3. Select a ringtone.
4. Press <
Save
>.
In Idle mode, press [Volume] to
adjust the keytone volume.
You can change the colour for
the display components, such as
title bars and highlight bars.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Display settings
→
Skin
.
2. Select a colour pattern.
Display
language
Call ringer
melody
Keytone
volume
Menu mode
skin colour
You can set the Navigation keys
to function as shortcuts to
access your favourite menus.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Phone settings
→
Shortcuts
.
2. Select a key.
3. Select a menu to be assigned
to the key.
You can switch the phone to
Silent mode to avoid disturbing
other people.
In Idle mode, press and hold
[].
Menu shortcuts
Silent mode
Get started
16
Make/Answer calls
You can protect the phone
against unauthorised use with a
phone password. The phone will
require the password when
turned on.
1. In Idle mode, press
<
Menu
> and select
Settings
→
Security
→
Change password
.
2. Enter the default password,
00000000
, and press
<
OK
>.
3. Enter a new 4- to 8-digit
password and press <
OK
>.
4. Enter the new password
again and press <
OK
>.
5. Select
Phone lock
.
6. Select
Enable
.
7. Enter the password and
press <
OK
>.
Phone lock
1. In Idle mode, enter an area
code and phone number.
2. Press [ ].
3. To end the call, press [ ].
1. When the phone rings, press
[].
2. To end the call, press [ ].
Press [Volume].
Make a call
Answer a call
Adjust the
volume during
a call
17
Get started
Use a memory card
• Frequent erasing and writing
will shorten a card’s lifespan.
• Do not remove a card from
the phone or turn off the
phone while data is being
accessed or transferred. This
could result in loss of data
and/or damage to the card
or phone.
• Do not subject cards to
strong shocks.
• Do not touch card terminals
with your fingers or metal
objects. If dirty, wipe the
card with a soft cloth.
• Keep cards away from small
children or pets.
• Do not expose cards in a
place subject to electro-
static discharge and/or
electrical noise.
Important
memory card
information
1. Insert the card into the card
slot, with the label side face
up.
2. Press the card until it locks
into place.
1. Press the card so that it is
disengaged from the phone.
2. Remove the card from the
slot.
Insert a
memory card
Remove the
memory card
18
Reset the phone
If your phone freezes for any reason while using a
phone function, you can easily reset it.
Multimedia player functions
Use multimedia functions: the music player, camera,
media album, FM radio, and voice recorder
Use Multimedia player keys
How to use
Press and hold the reset button
inside the hole on the left of the
phone, using a sharp tool.
Reset the
phone
Drag
Drag your
finger in the
direction of
the arrow.
Scroll up or down on a list.
Depending on your drag
speed, the scroll interval
may vary.
Scroll left or right through
tabs.
Press
Lightly press
and release
the key.
Perform the following
options:
• : Opens an option
list.
• : Functions as the
left soft/navigation key.
• : Functions as the
right soft/navigation
key.
• : Closes the current
menu function.
19
Multimedia player functions
Access menus or options
Press
• Scrolls one by one on a
list.
• Selects a check box or
radio button.
• Controls a progressive
bar.
Hold
Press and
hold
.
Scrolls up or down on a list
or moves backward or
forward in a file
continuously until you
release your finger from
the key.
1. In Idle mode, drag left or
right on the key to scroll
through menu icons:
Music
player
,
Camera
,
Album
,
FM radio
, and
Voice
recorder
.
Access menu
functions
Multimedia
player
functions
2. Press [
OK
] to access the
highlighted menu.
3. Press [ ] to exit the menu.
1. In a menu, press [ ] to
open an option list.
2. Scroll up or down by
dragging up or down on the
key or pressing on a corner
of the key.
3. Press [
OK
] to confirm the
highlighted option.
4. After change the setting,
press [ ] ( ) to save your
changes.
5. Press [ ] to close the
option list.
When the Multimedia Player mode display turns
off, press [
OK
] to turn the display on.
Select an
option
Multimedia player functions
20
Play music
You can play .mp3, .aac, .aac+,
and .wma files. Use these
methods:
• Download from the wireless
web
p. 43
• Download from a computer
using the optional Samsung
PC Studio
Samsung PC
Studio User’s Guide
• Receive via Bluetooth
p. 70
• Copy from a memory card
and insert the card into the
phone
p. 17
• Synchronise music files with
Windows Media Player
next section
Copy music
files to the
phone
You can copy music files to your
phone by synchronising with
Windows Media Player 10.
1. In Phone’s Idle mode, press
<
Menu
> and select
Settings
→
Phone settings
→
USB settings
→
MTP
1
.
2. Connect your phone and
computer with an optional PC
data cable.
3. Select
Synchronize media
files to this device
when a
pop-up window appears on
your PC.
4. Select the
Sync
tab.
5. Click
Edit Playlist
.
6. Select the music files you
want and click
OK
.
7. Click
Start Sync
.
8. When synchronisation is
finished, disconnect the
phone from the PC.
1. MTP (Media Transfer Protocol) is a protocol for
transferring WMDRM (Window Media Digital Rights
Management) media content with license keys, defined
by Microsoft Corporation.
Synchronise
with Windows
Media Player
21
Multimedia player functions
1. In Multimedia Player’s Idle
mode, access
Music player
.
Music starts automatically.
2. During playback, use the
following options:
•Press [
OK
] to pause or
resume playback.
• Press to return to the
previous file.
•Hold [ ] to move
backward in a file.
• Press [ ] to skip to the
next file.
•Hold [ ] to move
forward in a file.
• Press [Volume] to adjust
the volume.
• Drag to the left or right
on the key to access the
all music list or check the
music player settings.
3. Press [ ] to stop playback.
1. From the music player
screen, press [ ] to open
the option list.
2. Select
Play via
→
Bluetooth headset
. The
screen switches to Phone
mode display.
Play music files
Use an optional
Bluetooth
stereo headset
3. Select your Bluetooth stereo
headset.
4. Enter the headset’s
Bluetooth PIN,
0000
, and
press <
OK
>.
5. Press [ ] to return
the screen to the Multimedia
player display.
6. Press [
OK
] to begin
playback. Sound output
switches to the headset.
1. From the music player
screen, press [ ] to open
the option list.
2. Select
Open playlist
.
3. Press [ ] and select
Add to
favourite list
→
Multiple
.
4. Press [
OK
] to select the
music files you want.
5. When you have finished,
press [ ] to access your
favourite music list.
6. Press [
OK
] to begin
playback.
Set up your
favourite music
list
Multimedia player functions
22
1. From the music player
screen, press [ ] to open
the option list.
2. Select
Open playlist
.
3. Press [ ] to access the
favourite music list.
4. Select
Create playlist
.
5. Press [ ] and select
Add
music from
→
a source
category.
6. Press [
OK
] to select the
music files you want.
7. When you have finished,
press [ ].
8. To change the track order,
press [ ] and select
Move
track in playlist
.
9. Select the file you want.
10. Move the file to the position
you want by dragging up or
down on the key.
11. Press [ ] to save the
changes and return to the
play list you just created.
12. Press [
OK
] to begin
playback.
Create a play
list
While you using the music
player, music files are sorted
automatically on the most
played music list or recent music
list. In addition to play lists you
have created, use those play list
to listen to your favourite music
easily and quickly.
1. From the music player
screen, press [ ] to open
the option list.
2. Select
Open playlist
.
3. Press [ ] to access the
favourite music list.
4. Press [ ] and select
Open
→
the play list you want.
5. Press [
OK
] to begin
playback.
Select a play
list
23
Multimedia player functions
From the music player screen,
press [ ]. Depending on the
current play list, available
options vary:
•
Transfer to phone
/
Bluetooth stereo headset
:
switch sound output to the
phone speaker or a Bluetooth
stereo headset.
•
Play via
: begin playback via
the phone speaker or a
Bluetooth stereo headset.
•
Stop
: stop playback.
•
Add to Favourites
: add the
current file to your favourite
music list.
•
Add to other list
: add the
current file to another play
list.
•
Remove from playlist
:
remove the current file from
the play list.
•
Open playlist
: open the
current play list.
•
Activate key
: get a new
license key from the
corresponding website.
Use player
options
•
Details
: access the file
properties.
•
Key management
: manage
license keys.
•
Settings
: customise the
music player settings.
next section
From the music player screen,
press [ ] and select
Settings
.
•
Repeat mode
: select a
repeat mode type.
•
Shuffle
: set the music
player to play tracks in
random order.
•
Music overrides other
sounds
: set the music
player to continue playback
when you exit it.
•
Equaliser type
: select an
equaliser setting.
•
3D sound
: turn 3D sound on
or off.
•
Album art
: set the music
player to display album
information.
Customise
music player
settings
Multimedia player functions
24
Use the camera
• Do not take photos of people without their
permission.
• Do not take photos in a place where cameras
are not allowed.
• Do not take photos in a place where you may
interfere with another person’s privacy.
• When you take a photo in direct sunlight or in
bright conditions, shadows may appear on the
photo.
1. In Idle mode, access
Camera
. The display is
activated as a viewfinder.
2. Aim the lens at the subject
and make any desired
adjustments.
next section
3. Press [
OK
] to take a photo.
The photo is saved
automatically.
4. Press [ ] to return to the
viewfinder, or press [ ] to
delete the photo.
Take a photo
In Capture mode, adjust the
image to be captured:
• Press [Volume Up] to flip the
image vertically.
• Press [Volume Down] to view
the mirror image.
• Drag up or down on the right
side of the key to adjust the
brightness.
• Drag up or down on the left
side of the key to zoom in or
out.
• Press [ ] to switch the
viewfinder to the Phone
mode display.
• Press [ ] or drag to the
right on the key to access an
option list and change the
camera settings.
• Press [ ] to switch to
Record mode.
p. 26
Adjust a
camera image
25
Multimedia player functions
1. In Capture mode, press [ ]
to open the option list.
2. Select
Shooting mode
→
Multi-shot
→
the number
of photos.
3. Aim the lens at the subject
and make any desired
adjustments.
4. Press [
OK
] to take a photo.
5. Press [ ] to return to the
viewfinder, or press [ ] to
delete the photo.
1. In Capture mode, press [ ]
to open the option list.
2. Select
Shooting mode
→
Mosaic shot
→
a layout.
3. Aim the lens at the subject
and make any desired
adjustments.
4. Press [
OK
] for each shot
until you fill all sections of
the photo.
5. Press [ ] to return to the
viewfinder, or press [ ] to
delete the photo.
Take a multi-
shot photo
Take a mosaic
In Capture mode, press [ ] to
open the option list.
•
Shooting mode
: take a
photo using several modes.
•
Size
: select an image size.
•
Timer
: set a time delay
before the camera takes a
photo.
•
Effects
: change the colour
tone or apply a special effect.
•
Frames
: apply a decorative
frame.
•
White balance
: adjust the
colour temperature of the
camera.
•
ISO
: change the ISO setting,
which controls the sensitivity
of your camera. For low light
situations, select a higher
ISO number.
•
Viewfinder mode
: select a
preview screen.
In Capture mode, drag to the
right on the key to open the
option list.
•
Quality
: select an image
quality setting.
Customise the
camera
settings
Multimedia player functions
26
•
Single shot mode
: set
whether the camera saves
photos automatically in
Single Shot mode.
•
Multi-shot mode
: select
the shooting speed in Multi
Shot mode.
•
Shutter sound
: select the
sound that you hear when
you press the shutter release
key.
•
Zoom sound
: turn the
sound effect for zooming on
or off.
•
Brightness sound
: turn the
sound effect for brightness
adjustment on or off.
1. In Capture mode, drag to
the left on the key to open
the
My photos
list.
2. Select a photo from the list.
3. Press [ ] or [ ] or drag
to the left or right on the
key to view other photos.
View photos
Recording
videos is only
available in
Multimedia
Player mode.
1. In Capture mode, press [ ]
to switch to Record mode.
2. Aim the lens at the subject
and make any desired
adjustments.
3. Press [
OK
] to start
recording.
4. Press [
OK
] to stop recording.
The video is saved
automatically.
5. Press [
OK
] to review the
video.
6. Press [ ] to return to the
viewfinder, or press [ ] to
delete the video.
In Record mode, adjust the
image to be recorded:
• Press [Volume Up] to flip the
image vertically.
• Press [Volume Down] to view
the mirror image.
• Drag up or down on the right
side of the key to adjust the
brightness.
• Drag up or down on the left
side of the key to zoom in or
out.
Record a video
Adjust a
camcorder
27
Multimedia player functions
• Press [ ] to switch the
viewfinder to the Phone
mode display.
• Press [ ] or drag to the
right on the key to access an
option list and change the
camcorder settings.
• Press [ ] to switch to
Capture mode.
p. 24
In Record mode, press [ ] to
open the option list.
•
Size
: select a frame size.
•
Timer
: set a time delay
before the camera starts
recording.
•
Effects
: change the colour
tone or apply a special effect.
•
Frames
: apply a decorative
frame.
•
White balance
: adjust the
colour temperature of the
camera.
•
Record audio on/off
:
record a video with audio.
•
Recording mode
: select a
video recording mode
•
Viewfinder mode
: select a
preview screen.
Customise the
camcorder
settings
In Record mode, drag to the
right on the key to open the
option list.
•
Quality
: select an image
quality setting.
•
Zoom sound
: turn the
sound effect for zooming on
or off.
•
Brightness sound
: turn the
sound effect for brightness
adjustment on or off.
1. In Record mode, drag to the
left on the key to open the
My video clips
list.
2. Select a video clip from the
list.
Play videos
Multimedia player functions
28
View photos and videos in Album
1. In Idle mode, access
Album
. By default, the
Images screen opens.
2. Select an image folder.
3. Select a photo.
4. Press [
OK
] to view the
photo on a full screen.
5. Press [ ] or [ ] or drag
to the left or right on the
key to view other photos.
1. From the Images screen,
select a photo folder.
2. Select a photo.
3. Press [ ] to open the
option list.
4. Select
Slide show
→
an
interval between photos.
The slide show begins.
View photos
View photos as
a slide show
1. In Idle mode, access
Album
.
2. Drag to the left or right on
the key to access
Videos
.
3. Select a video folder.
4. Select a video file. The video
plays.
5. During playback, use the
following options:
•Press [
OK
] to pause or
resume playback.
• Press [ ] to move to
the previous file.
•Hold [ ] to move
backward in a file.
• Press [ ] to move to
the next file.
•Hold [ ] to move
forward in a file.
• Press [Volume] or drag
up or down on the key to
adjust the volume.
6. Press [ ] to stop playback.
Play videos
29
Multimedia player functions
Listen to the FM radio
To listen to the FM radio, you must connect a
headset, which serves as a radio antenna, to your
phone.
From a video list, press [ ] and
select
Settings
.
•
View mode settings
: set
the video player to play video
clips on a full screen.
•
Brightness settings
: adjust
the brightness of the video
player screen.
1. Plug the connecter of the
supplied headset into the
headset/adapter jack.
2. In Idle mode, access
FM
radio
.
3. Press [
OK
] to turn on the FM
radio.
4. Press [ ] or [ ] to scan
the frequencies to find
available radio stations.
Customise
video player
settings
Listen to the
FM radio
5. While listening to the FM
radio:
• Press [Volume] or drag
up or down on the key to
adjust the volume.
• Press [ ] and select
Add to preset
channels
to add the
current station to the
channel list.
6. Press [
OK
] or remove the
headset from the phone to
turn the FM radio off.
1. From the FM radio screen,
press [ ] to open the
option list.
2. Select
Speaker On
. Sound
output switches to the
phone speaker.
3. To switch back to the
headset, press [ ] and
select
Earphone On
.
Switch between
the phone
speaker and
headset
Multimedia player functions
30
Using self-tunning:
1. From the FM radio screen,
drag to the left on the key.
2. Select
Self tuning
. The
phone saves available
stations.
Adding radio stations manually:
1. From the FM radio screen,
drag to the left on the key.
2. Select
Add more
.
3. Select
Auto
and scroll
through available stations
and press [
OK
] when you
find the station you want.
Select
Manual
, scroll to the
frequency of the station you
want, and press [
OK
].
4. When you have finished,
press [ ] to return to the
FM radio screen.
Set up a radio
station list
1. From the FM radio screen,
drag to the right on the key.
2. Select
Preset channels
only
→
On
to set the FM
radio to only scrolls through
the radio stations stored on
the channel list.
3. Press [ ] or [ ] to scroll
to the station you want to
listen to.
You can set the FM radio to turn
on with the station you want at a
specified time.
1. From the FM radio screen,
drag to the left on the key to
open channel list.
2. Scroll to a saved radio
station.
3. Press [ ] and select
Programme reminder
. The
screen switches to the Phone
mode display.
4. Select an alert number.
5. Select
On
from the
Alarm
line and set each option.
Listen to the
saved stations
Set a radio
alert
31
Multimedia player functions
Use the voice recorder
6. Press <
Save
> to save the
alert settings.
7. When you have finished,
press <
Back
>. The screen
switches back to the
Multimedia player mode
display.
When the specified time for a
radio alert comes, a pop-up
window appears indicating the
specified frequency. Press [ ]
to listen to the corresponding
radio station.
1. In Idle mode, access
Voice
recorder
.
2. Press [
OK
] to start
recording.
3. Speak into the microphone.
4. When you have finished
recording, press [ ]. The
voice memo is automatically
saved.
5. Press [
OK
] to review the
voice memo, or press [ ] to
record other voice memos.
Record a
voice memo
1. From the voice recorder
screen, press [ ] to open
the option list.
2. Select
Go to My voice clips
.
3. Select a voice memo. The
voice memo plays.
4. During playback, use the
following options:
•Press [
OK
] to pause or
resume playback.
• Press [ ] to move to the
previous memo.
•Hold [ ] to move
backward in the memo.
• Press [ ] to move to the
next memo.
•Hold [ ] to move
forward in the memo.
• Press [Volume] or drag
up or down on the key to
adjust the volume.
5. Press [ ] to stop playback.
Review a
voice memo
32
Call functions
Advanced calling features
Making a call
1. In Idle mode, enter the area code and phone
number.
2. Press [ ].
3. When you want to end the call, press [ ].
Making an international call
1. In Idle mode, press and hold [
0
]. The
+
character appears.
2. Enter the country code, area code, and phone
number, then press [ ].
Redialling recent numbers
1. In Idle mode, press [ ] to display the list of
recent numbers.
2. Scroll to the number you want and press [ ].
Making a call from Phonebook
Once you have stored a number in Phonebook, you
can dial the number by selecting it from Phonebook.
p. 36
You can also use the speed dial feature to assign
your most frequently dialled numbers to specific
number keys.
p. 38
You can quickly dial a number from the SIM card
using its location number assigned when stored.
1. In Idle mode, enter a location number and press
[].
2. Press [Left] or [Right] to scroll through other
numbers.
3. Press <
Dial
> or [ ] to dial the number you
want.
Answering a call
When you receive an incoming call, the phone rings
and displays the incoming call image.
Press <
Accept
> or [ ] to answer the call.
Tips for answering a call
• When
Anykey
answer
is active, you can press
any key, except for <
Reject
> and [ ].
p. 64
• Press <
Reject
> or [ ] to reject a call.
• Press and hold [Volume] to reject a call or mute
the ringer, depending on the
Volume key
setting.
p. 64
• Press [
C
] to clear the last digit or press and
hold [
C
] to clear the whole display.
• Press and hold [ ] to enter a pause
between numbers.
33
Call functions
Viewing missed calls
If you have missed calls, the screen displays how
many calls you have missed.
1. Press <
View
>.
2. If necessary, scroll through the missed calls.
3. Press [ ] to dial the number you want.
Using the headset
Use the headset to make or answer calls without
holding the phone.
Connect the headset to the jack on the left side of
the phone. The button on the headset works as
follows:
Options during a call
You can access a number of functions during a call.
Adjusting the volume during a call
Use [Volume] to adjust the earpiece volume during a
call.
Press [Volume Up] to increase the volume level and
[Volume Down] to decrease the volume level.
Placing a call on hold/Retrieving
Press <
Hold
> to place a call on hold, or press
<
Retrieve
> to retrieve the call.
Making a second call
You can make another call if your network supports
this function.
1. Press <
Hold
> to put the call on hold.
2. Make the second call in the normal way.
3. Press <
Swap
> to switch between the calls.
4. Press <
Options
> and select
End
held
call
to
end the call on hold.
5. To end the current call, press [ ].
Answering a second call
You can answer an incoming call while already on
the phone, if your network supports this function
and you have activated the call waiting feature.
p. 67
1. Press [ ] to answer the call. The first call is
automatically put on hold.
2. Press <
Swap
> to switch between the calls.
3. Press <
Options
> and select
End
held
call
to
end the call on hold.
4. To end the current call, press [ ].
To Press
redial the last call the button twice.
answer a call the button.
end a call the button.
Call functions
34
Using In-call options
Press <
Options
> to access the following options
during a call:
•
Mute
/
Unmute
: switch off the phone's
microphone so that the other person on the
phone cannot hear you, or switch it back on.
•
Phonebook
: access the contact list.
•
Mute keys
/
Send keys
: switch the key tones off
or on.
•
Send DTMF
: send the DTMF (Dual tone multi-
frequency) tones as a group. The DTMF tones are
the tones used in phones for tone dialling,
sounding when you press the number keys. This
option is helpful for entering a password or an
account number when you call an automated
system, like a banking service.
•
Create message
: send an SMS message to the
person with whom you are talking, or access
received or sent messages.
•
Call transferred to BT
/
Call transferred to
phone
: transfer the call to a Bluetooth headset
or hands-free car kit, or back to the phone. To
use this feature, you first need to connect your
headset or car kit to the phone.
p. 69
•
SIM service
: access special services, such as
news, weather forecasts, entertainment, and
location services, provided by your SIM card.
This option is available when you use a SIM card
supporting SIM Application Toolkit menus.
•
Join
: set up a multi-party call by adding a caller
on hold to a currently active call. You can include
up to 5 people on a multi-party call.
•
Split
: have a private conversation with one
multi-party call participant. The other
participants can converse with each other. After
the private conversation, select
Join
to return
both private participants to the multi-party call.
•
Remove
: disconnect one multi-party call
participant.
To communicate with answering machines or
computerised telephone systems,
Send keys
must be selected.
35
Menu functions
All menu options listed
Call log
(Menu 1)
Use this menu to view the calls you have dialled,
received, or missed, and the length of the calls. You
can also check the cost of your calls,
if your SIM
card supports this function.
To access this menu, press <
Menu
> in Idle mode
and select
Call log
.
Recent contacts
(Menu 1.1)
This menu displays the most recent calls dialled,
received, or missed.
Accessing a call log
1. Press [Up] or [Down] to scroll through the call
list.
2. Press [
OK
] to view the details of a call, or [ ]
to dial a number.
Using call log options
While viewing call details, press <
Options
> to
access the following options:
•
Call
: edit the number and dial it.
•
Add to Phonebook
: save the number to
Phonebook.
•
Send
: send an SMS or MMS message to the
selected number.
•
Delete
: delete the selected call log or all logs.
Missed calls
(Menu 1.2)
This menu displays the most recent calls you did not
answer.
Dialled calls
(Menu 1.3)
This menu displays the most recent calls you have
dialled.
Received calls
(Menu 1.4)
This menu displays the most recent calls you have
received.
Delete all
(Menu 1.5)
Use this menu to delete all of the records in each call
type.
1. Press [
OK
] to select the call types to be cleared.
2. Press <
Delete
>.
3. Press <
Yes
> to confirm the deletion.
Call time
(Menu 1.6)
This menu displays the time log for calls made and
received. The actual time invoiced by your service
provider will vary.
•
Last
call
time
: check the length of your last
call.
Menu functions
36
•
Total
dialled calls
: check the total length of all
the calls you have dialled.
•
Total
received calls
: check the total length of
all the calls you have received.
To reset the call timers, press <
Reset
>. You need to
enter the phone password.
Call costs
(Menu 1.7)
This network feature displays the cost of calls. This
menu is available only if supported by your SIM
card. Note that this is not intended to be used for
billing purposes.
•
Last
call
cost
: check the cost of your last call.
•
Total
cost
: check the total cost of all of your
calls. If the total cost exceeds the maximum cost
set in
Set
max.
cost
, you must reset the
counter before you can make another call.
•
Max.
cost
: check the maximum cost limit.
•
Reset
counters
: reset the cost counters.
•
Set
max.
cost
: set the maximum cost
authorised for your calls.
•
Price/Unit
: set the price per unit that is applied
when the cost of your calls is calculated.
Phonebook
(Menu 2)
You can store phone numbers on your SIM card and
in your phone’s memory. The SIM card and phone’s
memory are physically separate, but they are used
as a single entity called Phonebook.
To access this menu, press <
Menu
> in Idle mode
and select
Phonebook
.
Contact list
(Menu 2.1)
Use this menu to search for contacts in Phonebook.
Finding a contact
1. Enter the first few letters of the name that you
want to find.
2. Select a contact from the list.
3. Scroll to a number and press [ ] to dial, or
press [
OK
] to edit contact information.
Finding a contact in Idle mode
You can find contacts in Idle mode, by the spelling of
a contact name. The phone searches for the contact
names starting with the letters labelled on any of the
keys you pressed.
1. In Idle mode, press the number keys containing
the letters you want.
The password is preset to
00000000
. You can
change this password.
p. 70
You can quickly access this menu by pressing
<
Contacts
> in Idle mode.
37
Menu functions
Phonebook
(Menu 2)
2. Press [
OK
], or press <
Options
> and select
Search as spelling
.
The phone searches Phonebook for the matching
contacts and shows results.
Using Phonebook options
From the contact list, press <
Options
> to access
the following options:
•
View
: view contact information of the selected
cotnact.
•
Send message
: send an SMS or MMS message
to the selected number, or an MMS message to
the selected address.
•
Create contact
: add a new contact to
Phonebook.
•
Send via
: send the contact via SMS, MMS, or
Bluetooth.
•
Delete
: delete the selected contact or all
contacts.
•
Switch screens
: switch the screen to the
Multimedia Player mode display. You can scroll
through contacts by dragging on the key.
Create contact
(Menu 2.2)
Use this menu to add a new contact to Phonebook.
Storing a contact in the phone’s memory
1. Select
Phone
.
2. Change the settings or enter information about
the contact.
•
First name
/
Last name
: assign a name.
•
Mobile
/
Home
/
Office
/
Fax
/
Other
: add a
number in any type.
•
Email
: assign an e-mail address.
•
Caller ID
: assign an image to alert you to a
call from the person.
•
Ringtone
: assign a ringtone to alert you to a
call from the person.
•
Group
: assign the number to a caller group.
•
Note
: add a memo about the person.
3. Press <
Save
> to save the contact.
Storing a contact on the SIM card
1. Select
SIM
.
2. Enter information about the contact.
•
Name
: assign a name.
•
Phone number
: add a number.
•
Location
: assign a location number.
3. Press <
Save
> to save the contact.
If you press [ ] to make a call in Multimedia
Player mode, the screen switches back to the
Phone mode display.
To assign a caller ID image or video, ringtone,
or group, the contact must be saved to the
phone’s memory.
Menu functions
38
Group
(Menu 2.3)
Use this menu to organise your contacts in caller
groups.
Creating a new caller group
1. Press <
Options
> and select
Create group
.
2. Enter a name for the group.
3. Select the caller ID line and set an image or a
video clip.
4. Select the ringtone line and set a ring tone.
5. Press <
Save
> to save the group.
Adding members to a caller group
1. Select a group.
2. Press <
Add
>.
3. Press [
OK
] to select the contacts to be added.
4. Press <
Select
>.
Managing caller groups
While viewing the group list, press <
Options
> to
access the following options:
•
View
: display the members of the selected
group.
•
Create group
: add a new group.
•
Edit
: change the group properties.
•
Send message
: send an SMS or MMS message
to the group members you want.
•
Delete
: delete the selected group or all groups.
Group members, however, will not be deleted
from Phonebook.
Speed dial
(Menu 2.4)
Use this menu to assign a speed dial number (2 to
9) for 8 of your most frequently dialled numbers.
Assigning speed dial numbers
1. Select a key location from
2
to
9
. Key
1
is
reserved for your voicemail server.
2. Select a contact from the contact list.
3. Select a number, if the contact has more than
one number.
Managing speed dial entries
From the Speed dial screen, press <
Options
> to
access the following options:
•
Add
: assign a number to an unassigned key.
•
View
: check the name and number assigned to
a key.
•
Change
: assign a different number to a key.
•
Remove
: clear the speed dial setting for a key.
Dialling speed dial numbers
In Idle mode, press and hold the appropriate key.
39
Menu functions
Phonebook
(Menu 2)
My namecard
(Menu 2.5)
Use this menu to create a name card and send it to
other people.
Saving your name card
The procedure for creating your name card is the
same as the one for saving a phone number in the
phone’s memory.
p. 37
Using name card options
After saving your name card, press <
Options
> to
access the following options:
•
Edit
: edit the name card.
•
Send via
: send the name card via SMS, MMS, or
Bluetooth.
•
Exchange namecard
: exchange name cards
with another person via Bluetooth.
•
Delete
: delete the name card.
Own number
(Menu 2.6)
Use this feature to check your phone numbers, or to
assign a name to each of the numbers. Changes
made here do not affect the actual subscriber
numbers on your SIM card.
Management
(Menu 2.7)
Use this menu to manage contacts in Phonebook.
•
Save new contact to
: select a default memory
location for saving contacts. If you select
Always ask
, the phone will ask you to select a
memory location each time you save a number.
•
Copy all to
: copy all of the contacts stored on
the SIM card to the phone’s memory, or vice
versa.
•
Delete all
: delete all of the contacts from your
phone’s memory, your SIM card, or both.
•
Memory status
: check the number of contacts
you have stored in the phone’s memory and on
the SIM card.
Service number
(Menu 2.8)
Use this menu to view the list of Service Dialling
Numbers (SDN) assigned by your service provider,
including emergency numbers and numbers for
directory enquiries. This menu is available if your
SIM card supports SDN.
1. Scroll to the number you want and press
<
View
>.
2. Press <
Dial
> or [ ].
Menu functions
40
Applications
(Menu 3)
Use this menu to play music files or play Java
games. You can also use convenient features, such
as voice recorder, alarm clock, calculator, converter,
and stopwatch.
To access this menu, press <
Menu
> in Idle mode
and select
Applications
.
Voice recorder
(Menu 3.1)
Use this menu to record voice memos. A voice
memo can be up to one hour long.
Recording a voice memo
1. Press [
OK
] to start recording.
2. Speak into the microphone.
Press [
OK
] to pause or resume recording.
3. Press <
Stop
> or [Down] to end recording. The
voice memo is saved automatically.
4. Press [
OK
] to review the voice memo.
Playing a voice memo
1. From the Voice recorder screen, press
<
Options
> and select
Go to My voice clips
.
2. Select a voice memo.
During playback, use the following keys:
Using voice memo options
After recording or playing a voice memo, press
<
Options
> to access the following options:
•
Play
: play the selected voice memo in Review
mode.
•
Record
: record a new voice memo.
•
Go to My voice clips
: access the voice memo
list.
•
Send via
: send the file via MMS or Bluetooth.
•
Delete
: delete the file.
•
Rename
: change the file name.
•
Details
: access the file properties.
•
Lock
/
Unlock
: lock the file to prevent it from
being deleted, or unlock the file.
•
Details
: access the file properties.
Key Function
OK
Pauses or resumes playback.
Left Returns to the previous memo. Moves
backward in a memo when held down.
Right Skips to the next memo. Skips forward
in a memo when held down.
Volume Adjusts the volume.
Down Stops playback.
41
Menu functions
Applications
(Menu 3)
World clock
(Menu 3.2)
Use this menu to set your local time zone and find
out the current time in another part of the world.
Viewing world time
1. Press [Up] or [Down] twice.
2. Press [Left] or [Right] to scroll to the city you
want. As the time line moves, the time and date
of the given zone display
3. Press [
OK
] to save the city as your local time
zone.
Applying daylight saving time
1. From the world time list, press <
Options
> and
select
Apply daylight saving time
.
2. Press [
OK
] to select the time zones you want.
3. Press <
Save
>.
Alarm
(Menu 3.3)
Use this menu to set alarms. The alert type for a
normal alarm corresponds to the call alert type
settings. A wake-up alarm is not affected by your
sound settings.
Setting an alarm
1. Select the type of alarm.
2. Set each alarm option:
•
Alarm
: activate the alarm.
•
Alarm time
: enter the time for the alarm to
ring.
•
AM/PM
: set
AM
or
PM
in 12-hour format.
•
Repeat
: select a repeat option.
•
Alarm tone
: select an alarm tone.
3. Press <
Save
>.
Stopping an alarm
• For a non-wake-up alarm, press any key.
• For a wake-up alarm, press <
Confirm
> or [
OK
].
Press any key, except for <
Confirm
> and [
OK
],
to cause it to sound again after 5 minutes. You
can do this a maximum of 5 times.
Deactivating an alarm
1. Select the alarm you want to deactivate.
2. Select
Off
on the
Alarm
line.
3. Press <
Save
>.
Setting alarms to sound when the phone is
off
From the Alarm screen, select
Auto power
→
On
.
If the phone is off when it is time for the alarm to
sound, the phone switches on and sounds the alarm.
Timer
(Menu 3.4)
Use this menu to set a period of time for the phone
to count down. The phone sounds an alarm when
the specified period of time expires.
Starting the timer
1. Press <
Set
>.
Menu functions
42
2. Enter the length of time you want to count down
and press <
OK
>.
3. Press [
OK
] to start counting down.
Stopping the timer
• Press any key when the timer alert appears.
•Press [
OK
] on the timer screen to stop the timer
before it rings.
Stopwatch
(Menu 3.5)
Use this menu to measure elapsed time. The
maximum time is 10 hours.
1. Press [
OK
] to start the stopwatch.
2. Press [
OK
] to check an interval. You can repeat
this step for a total of 4 intervals.
Memo
(Menu 3.6)
Use this menu to make memos of things that are
important, and manage them.
Creating a memo
1. Press <
Options
> and select
Create
.
2. Enter the memo text and press [
OK
].
Viewing a memo
1. Select the memo you want to view.
2. Press [Left] or [Right] to view other memos.
Using memo options
While viewing memo details, press <
Options
> to
access the following options:
•
Edit
: change the memo text.
•
Send via
: send the selected memo via SMS,
MMS, or Bluetooth.
•
Delete
: delete the memo.
•
Memory status
: check how many memos you
have created.
SIM AT
(Menu 3.7)
This menu is available if you use a SIM AT card that
supports SIM Application Toolkit menus and provides
additional services, such as news, weather, sports,
entertainment, and location services. Available
services may vary, depending on your service
provider’s plans. For details, see your SIM card
instructions or contact your service provider.
43
Menu functions
Browser
(Menu 4)
Browser
(Menu 4)
The Wireless Application Protocol (WAP) browser on
your phone allows you to access the wireless web.
From the wireless web, you can access up-to-date
information and a wide variety of media content,
such as games, wallpapers, ringtones, and music
files.
To access this menu, press <
Menu
> in Idle mode
and select
Browser
.
Home
(Menu 4.1)
Use this menu to connect your phone to the network
and load the homepage of the wireless web service
provider. You can also press [
OK
] in Idle mode. The
screen switches to the Multimedia Player mode
display and the homepage opens.
Navigating the web
From the web browser:
• Drag on the key to scroll through browser items.
•Press [
OK
], or [ ] and select
Open
to select a
browser item.
• Press [ ] and select
Go
→
Back
to return to the
previous page.
• Press [ ] and select
Go
→
Forward
to move to
the next page.
Using page options
From any web page, press [ ] to access the
following options:
•
Open
: access the linked web page.
•
Go to homepage
: return to the homepage.
•
Keys to buy
: send a request for buying a licence
key for a DRM file. This option will be available
only when you access the web browser from a
message containing a DRM file.
•
Enter URL
: enter a URL address manually.
•
Go
: move backward or forward through pages in
history.
•
Reload
: reload the current page with updated
information.
•
Bookmarks
: bookmark the current page or
access the bookmark list.
•
Copy URL to
: send the URL of the current page
via SMS. The screen switches back to the Phone
mode display, allowing you to compse a
message.
•
To SmartFit view
/
To Desktop view
: change
the display mode of the browser.
•
Save
: save the selected image or page.
•
Page details
: access the page properties.
•
Browser options
: change the various settings
for the browser.
Cache
: change the cache mode or clear the
cache. The cache is a temporary memory site
that stores recently accessed web pages.
Web browsing is only available in the Multimedia
Player mode display. When you select an option
for accessing a website in Phone mode, the screen
automatically switches.
Menu functions
44
Cookies
: change the cookie acceptance mode or
delete cookies. Cookies are pieces of personal
information sent to a web server while
navigating the web.
Preferences
: change the browser display and
sound settings.
Certificates
: access certificate information.
About browser
: access version and copyright
information about the browser.
•
Exit
: closes the web browser.
Exiting the browser
Press [ ] and select
Exit
to end the network
connection and close the browser. The screen will
switch to the Phone mode display.
Enter URL
(Menu 4.2)
Use this menu to manually enter a URL address and
access the associated web page.
You can add the entered URL to the bookmark list by
selecting
Add bookmark
.
Bookmarks
(Menu 4.3)
Use this menu to save URL addresses in order to
quickly access web pages.
Adding a bookmark
1. Press <
Add
>. If a bookmark has already been
saved, press <
Options
> and select
Add
bookmark
.
2. Enter a title for the bookmark and press [Down].
3. Enter a URL address and press <
Save
>.
Accessing a bookmarked page
Selecting a bookmark item launches the web
browser and accesses the associated web page.
Using bookmark options
From the Bookmarks screen, press <
Options
> to
access the following options:
•
Open
: access the bookmarked web page.
•
Go to homepage
: access the homepage.
•
Enter URL
: enter a URL address manually.
•
Edit bookmark
: edit the URL address and title
of the bookmark.
•
Add bookmark
: add a new bookmark.
•
Send URL
: send the URL address of the
bookmark via SMS.
•
Delete
: delete the selected bookmark or all
bookmarks.
Saved pages
(Menu 4.4)
You can access the list of pages you have saved
while online.
If you select a link on the page, the screen switches
to the Multimedia Player mode display and the
phone switches to online to access the linked page.
45
Menu functions
Messages
(Menu 5)
History
(Menu 4.5)
You can access the list of pages you have accessed
recently.
Select a URL from the list to access the
corresponding web page. The screen switches to the
Multimedia Player mode display.
Clear cache
(Menu 4.6)
Use this menu to clear information stored in the
cache, a temporary memory site that stores recently
accessed web pages.
Browser settings
(Menu 4.7)
Use this menu to select a connection profile to be
used for accessing the wireless web. You can also
create or edit a profile.
p. 71
Messages
(Menu 5)
Use the
Messages
menu to send and receive text
messages and multimedia messages. You can also
access push messages and cell broadcast messages.
To access this menu, press <
Menu
> in Idle mode
and select
Messages
.
Create message
(Menu 5.1)
Use this menu to create and send messages.
Text message
(Menu 5.1.1)
Short Message Service (SMS) allows you to send or
receive text messages that may include simple
pictures, animated images, and melodies.
Creating and sending an SMS message
1. Enter your message and press [
OK
].
2. Enter a destination number.
To send the message to more than one recipient,
fill in additional destination fields.
3. Press [
OK
] to send the message.
• The maximum number of characters
allowed in a message varies by service
provider. If your message exceeds the
maximum number of characters, the phone
will split the message.
• You can use various options by pressing
<
Options
>.
next section
Menu functions
46
Using options while composing an SMS
message
While composing a message, press <
Options
> to
access the following options:
•
Send only
: just send the message.
•
Save and send
: send the message and then
save it in the
Sentbox
folder.
•
Insert
: add a template, Phonebook entry, or
bookmark.
•
Add image
/
Add animation
/
Add melody
:
attach a simple image, an animated image, or a
melody.
•
Attach
: attach a Phonebook entry as a name
card or a calendar data as a data format
attachment.
•
Save in
: save the message in another message
folder.
•
Input language
: change the language to be
used in T9 input mode.
•
Text style
: change the text attributes.
•
Input method
: change the text input mode.
Multimedia message
(Menu 5.1.2)
Multimedia Message Service (MMS) delivers
messages containing a combination of text, image,
video, and audio, from phone to phone or from
phone to e-mail.
Creating and sending an MMS message
1. Select the
Subject
line.
2. Enter the message subject and press [
OK
].
3. Select the
Image or video
line.
4. Select
Add image
or
Add video
and add an
image or a video clip.
5. Select the
Sound
line.
6. Select
Add sound
and add a sound clip.
7. Select the
Message
line.
8. Enter the message text and press [
OK
].
9. When you have finished, press <
Options
> and
select
Send
.
10. Enter a phone number or an e-mail address.
To send the message to more than one recipient,
fill in additional destination fields.
11. Press [
OK
] to send the message.
You can use various options by pressing
<
Options
> in each field.
next section
• The maximum size allowed for a message
can differ, depending on your service
provider.
• Depending on the file type or DRM (Digital
Rights Management) system, some files
may not be able to be forwarded.
47
Menu functions
Messages
(Menu 5)
Using options while composing an MMS
message
While composing a message, press <
Options
> to
access the following options:
•
Add
: add the message subject or message text.
•
Add image
/
Add video
/
Add sound
: add a
image, video clip, or sound clip.
•
Change image
/
Change video
/
Change sound
:
replace an added item.
•
Edit
: edit the message subject or text.
•
Preview
: view the message as it will be shown
on the recipient’s phone.
•
View
: open the selected attachment.
•
Send
: send the message.
•
Save in
: save the message in another message
folder.
•
Add page
: add pages. Move to each page by
pressing [Left] or [Right].
•
Delete page
: delete an added page.
•
Edit page
: change the duration of page display
or move the page forward among the other
pages.
•
Attach
: attach a Phonebook entry as a name
card, a calender data as a data format
attachment, or a document file stored in the
Other files
folder.
•
Remove subject
/
Remove message
/
Remove
media
/
Remove sound
/
Remove
: remove an
added item.
My messages
(Menu 5.2)
Use this menu to access messages you have
received, sent, or which have failed in sending.
Inbox
(Menu 5.2.1)
This folder stores all of the messages you have
received.
Viewing a message
The following icons may appear on the message list
to show the message type:
• SMS
• MMS
• MMS notification ( : Being retrieved,
: Failed to retrieve)
• Voicemail
• Push message from web servers or
Configuration message containing network
parameters from your service provider
• CB (Cell broadcast) message from your
service provider
• Delivery report for your sent messages
• Depending on the DRM (Digital Rights
Management)
system, messages having web
content may not be
able to be forwarded.
• A
!
icon next to a message means that the
message is of high priority. A grey-coloured
message icon indicates low priority.
Menu functions
48
Using message options
While viewing a message, press <
Options
> to
access the following options:
SMS messages
•
Reply via text message
: reply to the sender
via SMS.
•
Reply via multimedia message to
: reply to
the sender via MMS.
•
Switch screens
: switch the message screen to
the Multimedia Player mode display. You can
then drag up or down on the key to scroll up or
down on the message screen, or drag left or
right on the key to view other messages.
To return to the Phone mode display, press
[].
•
Forward
: forward the message to other people.
•
Delete
: delete the message.
•
Move to phone
/
Move to SIM
: move the
message between the SIM card and the phone’s
memory.
•
Cut address
: extract URL addresses, e-mail
addresses, or phone numbers from the message.
•
Cut media
: save media content from the
message to your phone’s memory.
•
Lock
/
Unlock
: lock the message to prevent it
from being deleted, or unlock the message. You
can protect only those messages stored in the
phone’s memory.
•
Add to Block list
: add the sender’s number to
the block list to reject the messages from the
sender.
MMS messages
•
Retrieve
: retrieve the MMS message from the
MMS server.
•
Reply via text message
: reply to the sender
via SMS.
•
Reply via multimedia message to
: reply to
the sender or all of the recipients of the
message, including the sender, via MMS.
•
Switch screens
: switch the message screen to
the Multimedia Player mode display. You can
then drag up or down on the key to scroll up or
down on the message screen, or drag left or
right on the key to view other messages.
To return to the Phone mode display, press
[].
•
Forward
: forward the message to other people.
•
Delete
: delete the message.
•
Cut address
: extract URL addresses, e-mail
addresses, or phone numbers from the message.
•
Attached items
: save media content from the
message to your phone’s memory.
•
Lock
/
Unlock
: lock the message to prevent it
from being deleted, or unlock the message.
•
Details
: access the message properties.
49
Menu functions
Messages
(Menu 5)
Configuration messages
•
Install
: apply the configuration specified in the
message to your phone.
•
Switch screens
: switch the message screen to
the Multimedia Player mode display. You can
then drag up or down on the key to scroll up or
down on the message screen, or drag left or
right on the key to view other messages.
To return to the Phone mode display, press
[].
•
Delete
: delete the message.
•
Lock
/
Unlock
: lock the message to prevent it
from being deleted, or unlock the message.
Push messages
•
Go to URL
: connect to the URL address specified
in the message.
•
Switch screens
: switch the message screen to
the Multimedia Player mode display. You can
then drag up or down on the key to scroll up or
down on the message screen, or drag left or
right on the key to view other messages.
To return to the Phone mode display, press
[].
•
Cut address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Delete
: delete the message.
•
Lock
/
Unlock
: lock the message to prevent it
from being deleted, or unlock the message.
Broadcast messages
•
Save
: save the message to the phone’s memory.
•
Switch screens
: switch the message screen to
the Multimedia Player mode display. You can
then drag up or down on the key to scroll up or
down on the message screen, or drag left or
right on the key to view other messages.
To return to the Phone mode display, press
[].
•
Cut address
: extract URL addresses, e-mail
addresses, or phone numbers from the message.
•
Delete
: delete the message.
Delivery reports
•
Switch screens
: switch the message screen to
the Multimedia Player mode display. You can
then drag up or down on the key to scroll up or
down on the message screen, or drag left or
right on the key to view other messages.
To return to the Phone mode display, press
[].
•
Cut address
: extract URL addresses, e-mail
addresses, or phone numbers from the report.
•
Delete
: delete the report.
•
Lock
/
Unlock
: lock the message to prevent it
from being deleted, or unlock the message.
Menu functions
50
Drafts
(Menu 5.2.2)
This folder stores messages you have saved to send
at a later time.
When you select a message, it opens in Edit mode
so that you can edit and send the message.
Outbox
(Menu 5.2.3)
This folder stores messages that the phone is
attempting to send or has failed to send.
While viewing a message, press <
Options
> to
access the following options:
•
Send again
: retry sending the message.
•
Switch screens
: switch the message screen to
the Multimedia Player mode display. You can
then drag up or down on the key to scroll up or
down on the message screen, or drag left or
right on the key to view other messages.
To return to the Phone mode display, press
[].
•
Forward
: forward the message to other people.
•
Cut address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Delete
: delete the message.
•
Move to phone
/
Move to SIM
: move the
message between the SIM card and the phone’s
memory.
•
Lock
/
Unlock
: lock the message to prevent it
from being deleted, or unlock the message.
•
Details
: access the message properties.
Sentbox
(Menu 5.2.4)
This folder stores messages that you have sent.
While viewing a message, press <
Options
> to
access the following options:
•
Switch screens
: switch the message screen to
the Multimedia Player mode display. You can
then drag up or down on the key to scroll up or
down on the message screen, or drag left or
right on the key to view other messages.
To return to the Phone mode display, press
[].
•
Forward
: forward the message to other people.
•
Cut address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Delete
: delete the message.
•
Move to phone
/
Move to SIM
: move the
message between the SIM card and the phone’s
memory.
•
Lock
/
Unlock
: lock the message to prevent it
from being deleted, or unlock the message.
•
Details
: access the message properties.
My folders
(Menu 5.2.5)
Use this menu to create new folders and organise
your messages.
Creating a folder
1. Press <
Yes
>.
2. Enter a folder name and press <
OK
>.
51
Menu functions
Messages
(Menu 5)
Using folder options
On the folder list, press <
Options
> to access the
following options:
•
Open
: open the selected folder.
•
Create folder
: add a new folder.
•
Rename folder
: change the folder name.
•
Delete
: delete the selected folder.
Templates
(Menu 5.3)
Use this menu to make and use templates of
frequently used messages or passages.
Text message templates
(Menu 5.3.1)
You can create SMS templates with the sentences
you use frequently so that you can retrieve and
insert them when composing an SMS message.
Creating a template
1. Select an empty location.
2. Enter a message and press <
OK
>.
Using template options
From the template list, press <
Options
> to access
the following options:
•
Edit
: edit the selected template.
•
Send message
: create and send a new
message using the selected template.
•
Delete
: delete the selected template.
•
Add new
: add a new template.
Multimedia message templates
(Menu 5.3.2)
You can access embedded MMS templates or ones
you have saved so that you can use them when
composing an MMS message.
From the template list, press <
Options
> to access
the following options:
•
View
: open the selected template.
•
Edit
: create and send a new message using the
selected template.
•
Send message
: send the selected template.
•
Delete
: delete the selected template or all
templates, except for the embedded ones.
Delete all
(Menu 5.4)
Use this menu to delete messages in each message
folder all at once.
1. Press [
OK
] to select the message folders to be
cleared.
Pressing the key twice displays the message
types so that you can specify the ones to be
cleared.
2. Press <
Delete
>.
3. Press [
OK
] to select the check box to delete
protected messages, and then press <
Yes
>.
4. Press <
Yes
> to confirm the deletion.
Menu functions
52
Settings
(Menu 5.5)
Use this menu to set up various options for using the
messaging service.
Text messages
(Menu 5.5.1)
You can configure SMS settings.
•
Send settings
: set up the options for sending
SMS messages:
Reply path
: allow recipients to reply to you
through your SMS server.
Delivery report
: set the network to inform you
when your messages have been delivered.
Character support
: select a character encoding
type. When you select
Automatic
, the phone
switches the encoding type from GSM-Alphabet
to UniCode if you enter a Unicode character.
Use of Unicode encoding will reduce the
maximum number of characters in a message to
about half. If this menu is not shown, your phone
provides automatic character encoding by
default.
Bearer selection
: select either
GSM
or
GPRS
preferred
, depending on your network.
•
Block number
: store the phone numbers from
which you want to reject messages.
•
Current profile
: check or select an SMS setting
profile.
•
Profile settings
: set the properties of each
profile.
Service centre
: store or change the number of
your SMS server.
Default destination
: enter the default
destination. It will be automatically entered on
the recipient list.
Default type
: set the default message type. The
network can convert the messages into the
selected format.
Default validity
: set the length of time your
messages are stored in the SMS server.
Setting name
: enter a profile name.
Multimedia messages
(Menu 5.5.2)
You can configure MMS settings.
•
Sending options
: set up the options for sending
MMS messages:
Send delivery reciept
: set the network to
inform you when your messages have been
delivered.
Hide address
: set your address to be hidden
from the recipient’s phone.
Send read receipt
: send a read-reply request
along with your messages.
Priority
: set the priority level of messages.
Expiry date
: set the length of time messages
are stored in the MMS server.
Delivery time
: set a time delay before
messages are sent.
Outgoing message size
: select a maximum
size allowed for composing messages.
53
Menu functions
Messages
(Menu 5)
•
Retrieving options
: set up the options for
receiving MMS messages:
Reject unknown senders
: reject messages
from unknown senders.
Allow adverts
: accept advertisements.
Allow information
: accept information
messages.
Allow report
: set the network to inform the
sender when a message has been delivered to
you.
Recep. in home network
: determine if your
phone retrieves new messages automatically
when you are in your home service area.
Reception when abroad
: determine if your
phone retrieves new messages automatically
when you are roaming on another network.
Reception within home network or abroad has
the following options:
Manual
: the phone displays notifications. Use
the
Retrieve
option to manually download new
messages.
Automatic
: the phone automatically retrieves
messages from the server.
Reject
: the phone rejects all messages.
•
Block list
: store phone numbers and e-mail
addresses from which you want to reject
messages.
•
Multimedia message profiles
: select a
connection profile to be used for MMS. You can
also create or edit a profile.
p. 71
Push messages
(Menu 5.5.3)
You can change the settings for receiving push
messages from the wireless web server.
•
Receive
: set how your phone receives push
messages. If you select
Black list
, the phone
will not accept messages from the specified
addresses on the Black list.
•
Black list
: manage blocked server addresses.
Broadcast messages
(Menu 5.5.4)
You can change the settings for receiving broadcast
messages.
•
Receive
: select to receive broadcast messages,
or not.
•
Channel list
: indicate the channels from which
you wish to receive broadcast messages. Please
contact your service provider for further details.
•
Language
: select the preferred languages in
which broadcast messages display.
SOS messages
(Menu 5.6)
In an emergency, you can send an SOS message to
your family or friends for help. You can also receive
an SOS message from other people who are in an
emergency. Use this menu to specify options for
sending and receiving an SOS message.
•
Sending options
: set the options for sending an
SOS message:
Menu functions
54
Sending SOS
: activate or deactivate the SOS
message feature. To send an SOS message,
press [Volume] 4 times in Idle mode.
Recipients
: specify the phone numbers to which
you want to send SOS messages.
Repeats
: set the number of times the phone
repeats sending SOS messages.
Message
: check the preset SOS message text.
•
Receiving options
: set whether or not the
phone uses the preset alert type (siren and alert
message) for incoming SOS messages. If you
select
No
, the phone uses the message ringer
setting.
Memory status
(Menu 5.7)
Use this menu to view the amount of memory
currently in use in each message folder.
My files
(Menu 6)
The
My files
menu allows you to access images,
videos, music files, sound files, and other files
stored in the phone’s memory or on a memory card.
To access this menu, press <
Menu
> in Idle mode
and select
My files
.
Tips for Digital Rights Management
As a result of the Digital Rights Management (DRM)
system, some of the media items you download
from the Internet or receive by MMS may require a
licence key to access them.
You can acquire the key from the website which
owns the rights to the content; use the
Activate
key
option.
Note the following icons on the list:
• : Forwardable item with a valid key.
• : Forwardable item without a valid key.
• : Unforwardable item with a valid key.
• : Unforwardable item without a valid key.
Your service provider supports only count-based or
unlimited-access DRM files.
Images
(Menu 6.1)
This menu displays photos you have taken and
images you have downloaded, received in
messages, or imported from a computer.
While the phone is attempting to send an
SOS message, turns to red and you
cannot access menu functions in this mode.
To use the phone as
normal, press [ ]
when the icon turns to blue.
You can view the onscreen help by pressing
<
Options
> from the sending option list and
selecting
Help
.
55
Menu functions
My files
(Menu 6)
Viewing an image
1. Select an image folder.
2. Select an image.
3. Press [Up] or [Down] to view other photos.
Viewing a slide show
You can view your photos as a slide show, a
sequential presentation of each photo in the current
folder.
1. Select
My
photos
.
2. Press <
Options
> and select
Slide show
.
3. Select an interval option.
The slide show begins.
4. Press <
Stop
> to stop the slide show.
Using image options
While viewing an image, press < > to access the
following options:
•
List
: return to the image list.
•
Send via
: send the file via MMS or Bluetooth.
•
Set as
: set the image as a caller ID image for a
Phonebook entry.
•
Activate key
: get a licence key when the key
for the selected DRM file expires.
•
Delete
: delete the file.
•
Rename
: change the file name.
•
Move to Favourite images
/
Move to
Downloaded images
/
Move to Photos
/
Move
to Memory card
: move the file to another folder
in a phone's memory or on a memory card.
•
Copy to memory card
: copy the file to a
memory card.
•
Bluetooth visibility
: share the file or the files
you want with other Bluetooth devices.
•
Lock
/
Unlock
: lock the file to prevent it from
being deleted, or unlock the file.
•
Details
: access the file properties.
•
Key management
: manage the licence keys
you have acquired.
Videos
(Menu 6.2)
This menu displays video clips you have recorded,
downloaded, received in messages, or imported
from a computer.
Playing a video clip
1. Select a video folder.
2. Select a video clip.
During playback, use the following keys:
Video clips recorded on other devices, such as
camcorders, may not play correctly.
Key Function
OK
Pauses or resumes playback.
Left Moves backward in a file when held
down.
Right Moves forward in a file when held down.
Volume Adjusts the volume.
Menu functions
56
Using video options
After playback, press <
Options
> to access the
following options:
•
Send via
: send the file via MMS or Bluetooth.
•
Activate key
: get a new licence key when the
key for the selected DRM file expires.
•
Delete
: delete the file.
•
Rename
: change the file name.
•
Move to Favourite videos
/
Move to
Downloaded videos
/
Move to Video clips
/
Move to Memory card
: move the file to
another folder in a phone's memory or on a
memory card.
•
Copy to memory card
: copy the file to a
memory card.
•
Bluetooth visibility
: share the selected file or
the files you want with other Bluetooth devices.
•
Lock
/
Unlock
: lock the file to prevent it from
being deleted, or unlock the file.
•
Details
: access the file properties.
•
Key management
: manage the licence keys
you have acquired.
Music
(Menu 6.3)
This menu displays music files you have downloaded
or imported from a computer.
Playing music
Select a file.
During playback, use the following keys:
Using music options
While playing a music file, press <
Options
> to
access the following options:
•
Pause
/
Play
: pause or resume playback.
•
Transfer to Bluetooth stereo headset
/
Transfer to phone
: switch sound output to a
Bluetooth stereo headset or back to the phone
speaker.
•
Send via
: send the file via Bluetooth.
•
Set as
: set the file as your ringtone or a ringtone
for a Phonebook entry.
Up Returns to the video list.
Down Stops playback.
Key Function
Key Function
OK
Pauses or resumes playback.
Left Moves to the previous file when held
down.
Right Moves to the next file when held down.
Volume Adjusts the volume.
Down Stops playback.
57
Menu functions
My files
(Menu 6)
•
Activate key
: get a licence key when the key
for the selected DRM file expires.
•
Delete
: delete the file.
•
Move to memory card
: move the file to a
memory card. This option is only available when
you insert a memory card into the phone.
•
Copy to memory card
: copy the file to a
memory card.
•
Rename
: change the file name.
•
Bluetooth visibility
: share the selected file or
the files you want with other Bluetooth devices.
•
Lock
/
Unlock
: lock the file to prevent it from
being deleted, or unlock the file.
•
Details
: access the file properties.
•
Key management
: manage the licence keys
you have acquired.
Sounds
(Menu 6.4)
This menu displays voice memos you have recorded,
and sound files you have downloaded, received in
messages, or imported from a computer.
Playing a sound clip
1. Select a sound folder.
2. Select a sound clip. For a voice memo, see
Voice
recorder
.
p. 40
Using sound options
While playing a sound clip, press <
Options
> to
access the following options:
•
List
: return to the sound list.
•
Send via
: send the file via MMS or Bluetooth.
•
Set as
: set the file as your ringtone or as a
ringtone for a Phonebook entry.
•
Activate key
: get a new licence key when the
key for the selected DRM file expires.
•
Delete
: delete the file.
•
Rename
: change the file name.
•
Move to Favourite sounds
/
Move to
Downloaded sounds
/
Move to Voice recorder
files
/
Move to Memory card
: move the file to
another folder in a phone's memory or on a
memory card
•
Copy to memory card
: copy the file to a
memory card.
•
Bluetooth visibility
: share the selected file or
the files you want with other Bluetooth devices.
•
Lock
/
Unlock
: lock the file to prevent it from
being deleted, or unlock the file.
•
Details
: access the file properties.
•
Key management
: manage the licence keys
you have acquired.
Menu functions
58
Other files
(Menu 6.5)
Files that you have received but which are not
supported by your phone are stored in this folder.
You cannot open these files on the phone.
From the file list, press <
Options
> to access the
following options:
•
Send via
: send the file via Bluetooth.
•
Delete
: delete the selected file or all files.
•
Rename
: change the file name.
•
Move to memory card
: move the file to a
memory card.
•
Copy to memory card
: copy the file to a
memory card.
•
Rename
: change the file name.
•
Bluetooth visibility
: share the selected file or
the files you want with other Bluetooth devices.
•
Lock
/
Unlock
: lock the file to prevent it from
being deleted, or unlock the file.
•
Details
: access the file properties.
Memory card
(Menu 6.6)
Use this menu to access the files stored on a
memory card. This menu is only available when you
insert a memory card into the phone.
Memory status
(Menu 6.7)
You can check the total amount of memory and the
amount of memory currently in use in each media
box.
You can also access a media box by selecting it from
this menu.
Your phone is preset to use FAT16-formatted
memory cards. If you insert a FAT32-formatted
memory card, the phone will ask you to reformat
the memory card. If you do not, you will not be
able to access the card from the phone.
59
Menu functions
Calendar
(Menu 7)
Calendar
(Menu 7)
Use this menu to keep track of your schedule.
To access this menu, press <
Menu
> in Idle mode
and select
Calendar
.
Creating an item
You can store appointments, anniversaries, and
tasks on the calendar. More than one item per day
can be stored.
Entering an appointment
1. Press <
Options
> and select
Create
→
Appointment
.
2. Enter information or change the settings:
•
Subject
: enter a title for the appointment.
•
Details
: enter the appointment details.
•
Start date
and
Start time
: enter the
starting date and time for the appointment.
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
•
End date
and
End time
: enter the ending
date and time for the appointment.
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
•
Location
: enter information about the
appointed location.
•
Alarm
: select to set an alarm for the
appointment.
•
Before
: set how long before the anniversary
the alarm is to alert you.
•
Alarm time
: enter the time for the alarm to
ring.
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
•
Alarm tone
: select an alarm tone.
•
Repeat
: set the appointment to recur and
select a repeat unit.
•
Until
: set the ending date, if the
appointment will recur.
3. Press <
Save
> to save the appointment.
Entering an anniversary
1. Press <
Options
> and select
Create
→
Anniversary
.
2. Enter information or change the settings:
•
Occasion
: enter information about the
anniversary.
•
Date
: enter the date.
•
Alarm
: select to set an alarm for the
anniversary.
•
Before
: set how long before the anniversary
the alarm is to alert you and set a unit for
your setting.
•
Alarm time
: enter the time for the alarm to
ring.
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
•
Alarm tone
: select an alarm tone.
•
Repeat every year
: set the phone to
remind you of the anniversary every year.
3. Press <
Save
> to save the anniversary.
Menu functions
60
Entering a task
1. Press <
Options
> and select
Create
→
Task
.
2. Enter information or change the settings:
•
Task
: enter information about the task.
•
Start date
: enter the starting date.
•
Due date
: enter the ending date.
•
Select priority
: select a priority level.
3. Press <
Save
> to save the task.
Viewing an item
1. Select a date to display the items for that day.
The list of items schelduled for the selected day
appears. The following icons indicats each item
type:
• : Appointment
• : Anniversary
•: Task
2. Select an item to view its details.
3. Press [Left] or [Right] to access the other items
scheduled for the selected day.
While viewing an item, press <
Options
> to access
the following options:
•
Edit
: edit the item.
•
Create
: add a new item.
•
Send via
: send the item via SMS, MMS, or
Bluetooth.
•
Delete
: delete the item.
•
Memory status
: access memory information for
the items stored on the calendar.
Using calendar options
On the item list, press <
Options
> to access the
following options:
•
View
: check the items scheduled for the
selected day.
•
Create
: add a new item.
•
Send via
: send the item via SMS, MMS, or
Bluetooth.
•
Event list
: sort items by type of item.
•
Delete
: delete the items stored on the calendar
by using various deleting options.
•
Missed alarm events
: view items whose
alarms you have missed.
•
Memory status
: access memory information for
the items stored on the calendar.
You can delete recurring items in Day view
only.
61
Menu functions
Camera
(Menu 8)
Camera
(Menu 8)
You can use the camera module embedded in your
phone to take photos.
To access this menu, press <
Menu
> in Idle mode
and select
Camera
, or press and hold [ ].
Taking a photo
You can take photos in various modes. The camera
produces JPEG photos.
Taking a photo
1. Access the
Camera
menu or press and hold
[
]
to turn on the camera.
2. Make any desired adjustments.
• Press < > to switch the screen to the
Multimedia Player mode display.
p. 24
• Press [Left] or [Right] to adjust the
brightness.
• Press [Up] or [Down] to zoom in or out.
• Press [Volume UP] to flip the image vertically.
• Press [Volume UP] to view the mirror image.
3. Press [
OK
] to take a photo. The photo is saved in
the
My photos
folder.
Using photo options
After saving a photo, press < > to access the
following options:
•
Viewfinder
: return to Capture mode.
•
Send via
: send the file via MMS or Bluetooth.
•
Set as
: set the photo as a caller ID image for a
Phonebook entry.
•
Delete
: delete the file.
•
Rename
: change the file name.
•
Go to My photos
: access the
My photos
folder.
p. 54
•
Lock
/
Unlock
: lock the file to prevent it from
being deleted, or unlock the file.
•
Details
: access the file properties.
You can only initiate recording videos in
Multimedia Player mode. Switch the screen to
use the Phone mode display for recording videos.
4.
To Press
access photo options < >.
p. 61
delete the photo [
C
] and then <
Yes
>.
return to Capture
mode
<>.
Menu functions
62
Recording a video
You can record a video of what is displayed on the
camera screen and save it.
Recording a video
You can only switch to Record mode in Multimedia
Player mode.
1. In Multimedia Player mode, access
Camera
.
2. Press [ ] to switch the screen to the Phone
mode display.
3. Make any desired adjustments.
• Press < > to switch the screen to the
Multimedia Player mode display.
p. 26
• Press [Left] or [Right] to adjust the
brightness.
• Press [Up] or [Down] to zoom in or out.
• Press [Volume UP] to flip the image vertically.
• Press [Volume UP] to view the mirror image.
4. Press [
OK
] to start recording.
5. Press [
OK
] to stop recording. The video is
automatically saved in the
My video clips
folder.
Using video options
After saving a video clip, press < > to access the
following options:
•
Viewfinder
: return to Record mode.
•
Send via
: send the file via MMS or Bluetooth.
•
Set as
: set the video clip, if saved as a 3gp file,
as a caller ID image for a Phonebook entry.
•
Delete
: delete the file.
•
Rename
: change the file name.
•
Go to My video clips
: access the
My video
clips
folder.
p. 55
•
Lock
/
Unlock
: lock the file to prevent it from
being deleted, or unlock the file.
•
Details
: access the file properties.
6.
To Press
play back the video clip [
OK
].
access video options < >.
p. 62
delete the video [
C
] and then <
Yes
>.
return to Record mode <
Preview
>.
63
Menu functions
Settings
(Menu 9)
Settings
(Menu 9)
The
Settings
menu provides you with various
setting options to customise the phone to your
preferences and needs. You can also reset the
settings to their default status.
To access this menu, press <
Menu
> in Idle mode
and select
Settings
.
Time and date
(Menu 9.1)
Use this menu to change the time and date
displayed on your phone. Before setting the time
and date, specify your time zone in the
World clock
menu.
p. 41
•
Time
: enter the current time.
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
•
Time format
: select a time format.
•
Date
: enter the current date.
•
Date format
: select a date format.
•
Calendar starting day
: set which day of the
week the calendar starts with.
•
Auto update
: activate the auto time update
feature. Your phone will read the MCC (Mobile
Country Code) from the network and
automatically update the current time for the
country that you are in when you travel abroad.
Phone settings
(Menu 9.2)
Many different features of your phone’s system can
be customised to suit your preferences.
Language
(Menu 9.2.1)
Use this menu to select a language for the display
text. If you select
Automatic
, the phone uses the
same language as the SIM card.
Greeting message
(Menu 9.2.2)
Use this menu to enter the greeting that is displayed
briefly when the phone is switched on.
Shortcuts
(Menu 9.2.3)
You can use the Navigation keys as shortcuts to
access specific menus directly from Idle mode. Use
this menu to assign a shortcut to a key.
Assigning a shortcut menu
1. Select a key to be used as a shortcut key.
2. Select a menu to be assigned to the key.
Using shortcut options
Press <
Options
> to access the following options:
•
Change
: assign or change a shortcut menu.
•
Remove
: deactivate the shortcut assignment to
the selected key.
•
Remove all
: deactivate all shortcut
assignments.
Time information may not be updated when
you move to one time zone to another within a
country.
Some menus may not be available, depending on
your service provider.
Menu functions
64
Volume key
(Menu 9.2.4)
Use this menu to set whether the phone mutes the
call ringer or rejects a call if you press and hold
[Volume] when a call comes in.
Extra settings
(Menu 9.2.5)
You can turn the automatic redialling or answering
feature on or off.
•
Auto redial
: set the phone to make up to ten
attempts to redial a phone number after an
unsuccessful call.
•
Anykey
answer
: answer an incoming call by
pressing any key, except for <
Reject
> and
[].
Offline mode
(Menu 9.2.6)
Use this menu to switch the phone to Offline mode
or back to Online mode.
USB setting
(Menu 9.2.7)
Use this menu to select a USB mode that will be
used when you connect your phone to a PC via USB
interface.
•
MTP
: you can use MTP (Media Transfer Protocol)
mode to transfer WMDRM (Window Media Digital
Rights Management) content with licence keys
directly from the Windows Media Player 10 to the
phone. You can also get new licence keys for the
DRM files that have expired licence keys.
•
PC studio
: you can the Samsung PC Studio
programme to synchronise data and transfer
media files between the phone and a PC.
Display settings
(Menu 9.3)
Use this menu to change settings for the display and
backlight.
Skin
(Menu 9.3.1)
You can select a skin colour pattern for Menu mode.
Brightness
(Menu 9.3.2)
You can adjust the brightness of the displays for
varying lighting conditions.
Dialing display
(Menu 9.3.3)
Use this menu to select a font colour for the
numbers, and background colour of the display while
dialling.
Show caller information
(Menu 9.3.4)
Use this menu to set the phone to display missed
call notifications with the most recently missed
caller’s information.
65
Menu functions
Settings
(Menu 9)
Sound settings
(Menu 9.4)
Use this menu to customise various sound settings.
Incoming call
(Menu 9.4.1)
Use this menu to change the sound settings for
incoming calls.
•
Ringtone
: select a ringtone to be used for the
call ringer.
•
Volume
: select a ringtone volume.
•
Alert type
: specify how you are to be informed
of incoming calls.
Keypad tone
(Menu 9.4.2)
Use this menu to select the tone that the phone
sounds when you press a key.
Message tone
(Menu 9.4.3)
Use this menu to change the sound settings for
incoming SMS messages, MMS messages, and
broadcast messages individually.
•
Tone
: select one of several message tones.
•
Alert type
: specify how you are to be informed
when a message comes in.
•
Repetition
: specify how often the phone
informs you of a new message.
Power on/off
(Menu 9.4.4)
Use this menu to select the melody that the phone
sounds when it is switched on or off.
Silent mode
(Menu 9.4.5)
Use this menu to set how the phone acts to alert you
to a specific event while in Silent mode.
Extra tones
(Menu 8.4.6)
Use this menu to customise additional tones for the
phone.
•
Minute
minder
: set the phone to beep every
minute during an outgoing call to keep you
informed of the length of your call.
•
Connection
tone
: set the phone to beep when
an outgoing call connects to the system.
•
Alert on call
: set the phone to beep when you
receive a new message or when the time for an
alarm comes during a call.
•
Indicative
tone
: set the phone to beep when a
pop-up window displays.
You can adjust the key tone volume using
[Volume] in Idle mode.
66
Solve problems
Help and personal needs
To save the time and expense of an unnecessary
service call, perform the simple checks in this
section before contacting a service professional.
When you switch on your phone, the following
messages may appear:
“Please insert SIM card”
• Be sure that the SIM card is correctly installed.
“Phone lock”
• The automatic locking function has been
enabled. You must enter the phone’s password
before you can use the phone.
“PIN lock”
• You are using your phone for the first time. You
must enter the PIN supplied with the SIM card.
• The PIN locking feature is enabled. Every time
the phone is switched on, the PIN has to be
entered. To disable this feature, use the
PIN
lock
menu.
“PUK lock”
• The PIN code was entered incorrectly three
times, and the SIM card is now blocked. Enter
the PUK supplied by your service provider.
“No service” or “Service unavailable” displays
• The network connection has been lost. You may
be in a weak signal area. Move and try again.
• You are trying to access an option for which you
have no subscription with your service provider.
Contact the service provider for further details.
You have entered a number but it was not
dialled
• Be sure that you have pressed [ ].
• Be sure that you have accessed the right cellular
network.
• Be sure that you have not set an outgoing call
barring option.
Your correspondent cannot reach you
• Be sure that your phone is switched on. ([ ]
pressed for more than one second.)
• Be sure that you have accessed the right cellular
network.
• Be sure that you have not set an incoming call
barring option.
Your correspondent cannot hear you speaking
• Be sure that he microphone is switched on.
• Be sure that you are holding the phone close
enough to your mouth. The microphone is
located at the bottom of the phone.
67
The phone starts beeping and “Low battery”
flashes on the display
• Your battery is insufficiently charged. Recharge
the battery.
The audio quality of the call is poor
• Check the signal strength indicator on the
display ( ). The number of bars indicates the
signal strength from strong ( ) to weak ( ).
• Try moving the phone slightly or moving closer
to a window if you are in a building.
No number is dialled when you re-call a
Phonebook entry
•Use the
Search contact
feature to ensure the
number has been stored correctly.
• Re-store the number, if necessary.
The battery does not charge properly or the
phone sometimes turns itself off
• Wipe the charging contacts both on the phone
and on the battery with a clean soft cloth.
If the above guidelines do not help you to solve
the problem, take note of:
• The model and serial numbers of your phone
•Your warranty details
• A clear description of the problem
Then contact your local dealer or Samsung after-
sales service.
Health and safety information
Exposure to Radio Frequency (RF)
Signals
Certification Information (SAR)
Your wireless phone is a radio transmitter and
receiver. It is designed and manufactured not to
exceed the exposure limits for radio frequency (RF)
energy set by the Federal Communications
Commission (FCC) of the U.S. government. These
FCC exposure limits are derived from the
recommendations of two expert organizations, the
National Counsel on Radiation Protection and
Measurement (NCRP) and the Institute of Electrical
and Electronics Engineers (IEEE). In both cases, the
recommendations were developed by scientific and
engineering experts drawn from industry,
government, and academia after extensive reviews
of the scientific literature related to the biological
effects of RF energy.
The exposure limit set by the FCC for wireless
mobile phones employs a unit of measurement
known as the Specific Absorption Rate (SAR). The
SAR is a measure of the rate of absorption of RF
energy by the human body expressed in units of
watts per kilogram (W/kg). The FCC requires
wireless phones to comply with a safety limit of 1.6
watts per kilogram (1.6 W/kg). The FCC exposure
limit incorporates a substantial margin of safety to
68
Health and safety information
give additional protection to the public and to
account for any variations in measurements.
SAR tests are conducted using standard operating
positions accepted by the FCC with the phone
transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is
determined at the highest certified power level, the
actual SAR level of the phone while operating can be
well below the maximum value. This is because the
phone is designed to operate at multiple power
levels so as to use only the power required to reach
the network. In general, the closer you are to a
wireless base station antenna, the lower the power
output.
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC
that it does not exceed the exposure limit
established by the FCC. Tests for each model phone
are performed in positions and locations (e.g. at the
ear and worn on the body) as required by the FCC.
Body-worn operations are restricted to Samsung-
supplied, approved, or non- Samsung designated
accessories that have no metal and must provide at
least 1.5 cm separation between the device,
including its antenna (whether extended or
retracted) and the user's body. Non-compliance with
the above restrictions may result in violation of FCC
RF exposure guidelines.
The FCC has granted an Equipment Authorization for
this mobile phone with all reported SAR levels
evaluated as in compliance with the FCC RF
exposure guidelines. The maximum SAR values for
this model phone as reported to the FCC are:
1900
• Head: 1.07 W/Kg.
• Body-worn: 0.312 W/Kg.
SAR information on this and other model phones can
be viewed on-line at www.fcc.gov/oet/fccid. This site
uses the phone FCC ID number, A3LSGHF300.
Sometimes it may be necessary to remove the
battery pack to find the number. Once you have the
FCC ID number for a particular phone, follow the
instructions on the website and it should provide
values for typical or maximum SAR for a particular
phone. Additional product specific SAR information
can also be obtained at www.fcc.gov/cgb/sar.
Consumer Information on Wireless
Phones
The U.S. Food and Drug Administration (FDA) has
published a series of Questions and Answers for
consumers relating to radio frequency (RF) exposure
from wireless phones. The FDA publication includes
the following information:
What kinds of phones are the subject of this
update?
The term wireless phone refers here to hand-held
wireless phones with built-in antennas, often called
“cell,” “mobile,” or “PCS” phones. These types of
69
Health and safety information
wireless phones can expose the user to measurable
radio frequency energy (RF) because of the short
distance between the phone and the user's head.
These RF exposures are limited by Federal
Communications Commission safety guidelines that
were developed with the advice of FDA and other
federal health and safety agencies. When the phone
is located at greater distances from the user, the
exposure to RF is drastically lower because a
person's RF exposure decreases rapidly with
increasing distance from the source. The so-called
“cordless phones,” which have a base unit connected
to the telephone wiring in a house, typically operate
at far lower power levels, and thus produce RF
exposures well within the FCC's compliance limits.
Do wireless phones pose a health hazard?
The available scientific evidence does not show that
any health problems are associated with using
wireless phones. There is no proof, however, that
wireless phones are absolutely safe. Wireless
phones emit low levels of radio frequency energy
(RF) in the microwave range while being used. They
also emit very low levels of RF when in the stand-by
mode. Whereas high levels of RF can produce health
effects (by heating tissue), exposure to low level RF
that does not produce heating effects causes no
known adverse health effects. Many studies of low
level RF exposures have not found any biological
effects. Some studies have suggested that some
biological effects may occur, but such findings have
not been confirmed by additional research. In some
cases, other researchers have had difficulty in
reproducing those studies, or in determining the
reasons for inconsistent results.
What is FDA's role concerning the safety of
wireless phones?
Under the law, FDA does not review the safety of
radiation-emitting consumer products such as
wireless phones before they can be sold, as it does
with new drugs or medical devices. However, the
agency has authority to take action if wireless
phones are shown to emit radio frequency energy
(RF) at a level that is hazardous to the user. In such
a case, FDA could require the manufacturers of
wireless phones to notify users of the health hazard
and to repair, replace or recall the phones so that
the hazard no longer exists.
Although the existing scientific data do not justify
FDA regulatory actions, FDA has urged the wireless
phone industry to take a number of steps, including
the following:
• “Support needed research into possible biological
effects of RF of the type emitted by wireless
phones;
• “Design wireless phones in a way that minimizes
any RF exposure to the user that is not
necessary for device function; and
70
Health and safety information
• “Cooperate in providing users of wireless phones
with the best possible information on possible
effects of wireless phone use on human health.
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at
the federal level. The following agencies belong to
this working group:
• “National Institute for Occupational Safety and
Health
• “Environmental Protection Agency
• “Federal Communications Commission
• “Occupational Safety and Health Administration
• “National Telecommunications and Information
Administration
The National Institutes of Health participates in
some interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless
phones with the Federal Communications
Commission (FCC). All phones that are sold in the
United States must comply with FCC safety
guidelines that limit RF exposure. FCC relies on FDA
and other health agencies for safety questions about
wireless phones.
FCC also regulates the base stations that the
wireless phone networks rely upon. While these
base stations operate at higher power than do the
wireless phones themselves, the RF exposures that
people get from these base stations are typically
thousands of times lower than those they can get
from wireless phones. Base stations are thus not the
primary subject of the safety questions discussed in
this document.
What are the results of the research done
already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws
in their research methods. Animal experiments
investigating the effects of radio frequency energy
(RF) exposures characteristic of wireless phones
have yielded conflicting results that often cannot be
repeated in other laboratories. A few animal studies,
however, have suggested that low levels of RF could
accelerate the development of cancer in laboratory
animals. However, many of the studies that showed
increased tumor development used animals that had
been genetically engineered or treated with cancer-
causing chemicals so as to be pre-disposed to
develop cancer in absence of RF exposure. Other
studies exposed the animals to RF for up to 22 hours
per day. These conditions are not similar to the
conditions under which people use wireless phones,
so we don't know with certainty what the results of
such studies mean for human health.
Three large epidemiology studies have been
published since December 2000. Between them, the
studies investigated any possible association
between the use of wireless phones and primary
brain cancer, glioma, meningioma, or acoustic
neuroma, tumors of the brain or salivary gland,
Health and safety information
• “Cooperate in providing users of wireless phones
with the best possible information on possible
effects of wireless phone use on human health.
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at
the federal level. The following agencies belong to
this working group:
• “National Institute for Occupational Safety and
Health
• “Environmental Protection Agency
• “Federal Communications Commission
• “Occupational Safety and Health Administration
• “National Telecommunications and Information
Administration
The National Institutes of Health participates in
some interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless
phones with the Federal Communications
Commission (FCC). All phones that are sold in the
United States must comply with FCC safety
guidelines that limit RF exposure. FCC relies on FDA
and other health agencies for safety questions about
wireless phones.
FCC also regulates the base stations that the
wireless phone networks rely upon. While these
base stations operate at higher power than do the
wireless phones themselves, the RF exposures that
people get from these base stations are typically
thousands of times lower than those they can get
from wireless phones. Base stations are thus not the
primary subject of the safety questions discussed in
this document.
What are the results of the research done
already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws
in their research methods. Animal experiments
investigating the effects of radio frequency energy
(RF) exposures characteristic of wireless phones
have yielded conflicting results that often cannot be
repeated in other laboratories. A few animal studies,
however, have suggested that low levels of RF could
accelerate the development of cancer in laboratory
animals. However, many of the studies that showed
increased tumor development used animals that had
been genetically engineered or treated with cancer-
causing chemicals so as to be pre-disposed to
develop cancer in absence of RF exposure. Other
studies exposed the animals to RF for up to 22 hours
per day. These conditions are not similar to the
conditions under which people use wireless phones,
so we don't know with certainty what the results of
such studies mean for human health.
Three large epidemiology studies have been
published since December 2000. Between them, the
studies investigated any possible association
between the use of wireless phones and primary
brain cancer, glioma, meningioma, or acoustic
neuroma, tumors of the brain or salivary gland,
72
Health and safety information
What steps can I take to reduce my exposure
to radio frequency energy from my wireless
phone?
If there is a risk from these products - and at this
point we do not know that there is - it is probably
very small. But if you are concerned about avoiding
even potential risks, you can take a few simple steps
to minimize your exposure to radio frequency
energy (RF). Since time is a key factor in how much
exposure a person receives, reducing the amount of
time spent using a wireless phone will reduce RF
exposure.
• “If you must conduct extended conversations by
wireless phone every day, you could place more
distance between your body and the source of
the RF, since the exposure level drops off
dramatically with distance. For example, you
could use a headset and carry the wireless phone
away from your body or use a wireless phone
connected to a remote antenna.
Again, the scientific data do not demonstrate that
wireless phones are harmful. But if you are
concerned about the RF exposure from these
products, you can use measures like those described
above to reduce your RF exposure from wireless
phone use.
What about children using wireless phones?
The scientific evidence does not show a danger to
users of wireless phones, including children and
teenagers. If you want to take steps to lower
exposure to radio frequency energy (RF), the
measures described above would apply to children
and teenagers using wireless phones. Reducing the
time of wireless phone use and increasing the
distance between the user and the RF source will
reduce RF exposure.
Some groups sponsored by other national
governments have advised that children be
discouraged from using wireless phones at all. For
example, the government in the United Kingdom
distributed leaflets containing such a
recommendation in December 2000. They noted
that no evidence exists that using a wireless phone
causes brain tumors or other ill effects. Their
recommendation to limit wireless phone use by
children was strictly precautionary; it was not based
on scientific evidence that any health hazard exists.
Do hands-free kits for wireless phones reduce
risks from exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason
to believe that hands-free kits reduce risks. Hands-
free kits can be used with wireless phones for
convenience and comfort. These systems reduce the
absorption of RF energy in the head because the
phone, which is the source of the RF emissions, will
not be placed against the head. On the other hand,
if the phone is mounted against the waist or other
part of the body during use, then that part of the
body will absorb more RF energy. Wireless phones
73
Health and safety information
marketed in the U.S. are required to meet safety
requirements regardless of whether they are used
against the head or against the body. Either
configuration should result in compliance with the
safety limit.
Do wireless phone accessories that claim to
shield the head from RF radiation work?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason
to believe that accessories that claim to shield the
head from those emissions reduce risks. Some
products that claim to shield the user from RF
absorption use special phone cases, while others
involve nothing more than a metallic accessory
attached to the phone. Studies have shown that
these products generally do not work as advertised.
Unlike “hand-free” kits, these so-called “shields”
may interfere with proper operation of the phone.
The phone may be forced to boost its power to
compensate, leading to an increase in RF
absorption. In February 2002, the Federal trade
Commission (FTC) charged two companies that sold
devices that claimed to protect wireless phone users
from radiation with making false and
unsubstantiated claims. According to FTC, these
defendants lacked a reasonable basis to substantiate
their claim.
What about wireless phone interference with
medical equipment?
Radio frequency energy (RF) from wireless phones
can interact with some electronic devices. For this
reason, FDA helped develop a detailed test method
to measure electromagnetic interference (EMI) of
implanted cardiac pacemakers and defibrillators
from wireless telephones. This test method is now
part of a standard sponsored by the Association for
the Advancement of Medical instrumentation
(AAMI). The final draft, a joint effort by FDA,
medical device manufacturers, and many other
groups, was completed in late 2000. This standard
will allow manufacturers to ensure that cardiac
pacemakers and defibrillators are safe from wireless
phone EMI. FDA has tested wireless phones and
helped develop a voluntary standard sponsored by
the Institute of Electrical and Electronic Engineers
(IEEE). This standard specifies test methods and
performance requirements for hearing aids and
wireless phones so that no interference occurs when
a person uses a compatible phone and a compatible
hearing aid at the same time. This standard was
approved by the IEEE in 2000.
FDA continues to monitor the use of wireless phones
for possible interactions with other medical devices.
Should harmful interference be found to occur, FDA
will conduct testing to assess the interference and
work to resolve the problem.
Additional information on the safety of RF exposures
from various sources can be obtained from the
following organizations:
74
Health and safety information
• FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
• Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
• Occupational Safety and Health Administration's
(OSHA):
http://www.osha.gov/SLTC/
radiofrequencyradiation/index.html
• National institute for Occupational Safety and
Health (NIOSH):
http://www.cdc.gov/niosh/emfpg.html
• World health Organization (WHO):
http://www.who.int/peh-emf/
• International Commission on Non-Ionizing
Radiation Protection:
http://www.icnirp.de
• National Radiation Protection Board (UK):
http://www.nrpb.org.uk.
• Updated 4/3/2002: US food and Drug
Administration
http://www.fda.gov/cellphones
Road Safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime.
But an important responsibility accompanies the
benefits of wireless phones, one that every user
must uphold.
When driving a car, driving is your first
responsibility. When using your wireless phone
behind the wheel of a car, practice good common
sense and remember the following tips:
1. Get to know your wireless phone and its
features, such as speed dial and redial. If
available, these features help you to place your
call without taking your attention off the road.
2. When available, use a hands-free device. If
possible, add an additional layer of convenience
and safety to your wireless phone with one of the
many hands free accessories available today.
3. Position your wireless phone within easy reach.
Be able to access your wireless phone without
removing your eyes from the road. If you get an
incoming call at an inconvenient time, let your
voice mail answer it for you.
4. Let the person you are speaking with know you
are driving; if necessary, suspend the call in
heavy traffic or hazardous weather conditions.
Rain, sleet, snow, ice and even heavy traffic can
be hazardous.
5. Do not take notes or look up phone numbers
while driving. Jotting down a °×to do°± list or
flipping through your address book takes
attention away from your primary responsibility,
driving safely.
6. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan calls when your car
75
Health and safety information
will be stationary. If you need to make a call
while moving, dial only a few numbers, check the
road and your mirrors, then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting. Make
people you are talking with aware you are
driving and suspend conversations that have the
potential to divert your attention from the road.
8. Use your wireless phone to call for help. Dial 9-1-
1 or other local emergency number in the case of
fire, traffic accident or medical emergencies.
Remember, it is a free call on your wireless
phone!
9. Use your wireless phone to help others in
emergencies. If you see an auto accident, crime
in progress or other serious emergency where
lives are in danger, call 9-1-1 or other local
emergency number, as you would want others to
do for you.
10. Call roadside assistance or a special non-
emergency wireless assistance number when
necessary. If you see a broken-down vehicle
posing no serious hazard, a broken traffic signal,
a minor traffic accident where no one appears
injured, or a vehicle you know to be stolen, call
roadside assistance or other special non-
emergency number.
“The wireless industry reminds you to use your
phone safely when driving.”
For more information, please call 1-888-901-SAFE,
or visit our web-site www.wow-com.com
Provided by the Cellular Telecommunications &
Internet Association
Operating Environment
Remember to follow any special regulations in force
in any area and always switch your phone off
whenever it is forbidden to use it, or when it may
cause interference or danger. When connecting the
phone or any accessory to another device, read its
user's guide for detailed safety instructions. Do not
connect incompatible products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation
of the equipment and for the safety of personnel, it
is recommended that the equipment should only be
used in the normal operating position (held to your
ear with the antenna pointing over your shoulder).
Using Your Phone Near Other Electronic
Devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against
the RF signals from your wireless phone. Consult the
manufacturer to discuss alternatives.
Pacemakers
76
Health and safety information
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be
maintained between a wireless phone and a
pacemaker to avoid potential interference with the
pacemaker.
These recommendations are consistent with the
independent research and recommendations of
Wireless Technology Research.
Persons with pacemakers:
• should always keep the phone more than 15 cm
(6 inches) from their pacemaker when the phone
is switched on.
• should not carry the phone in a breast pocket.
• should use the ear opposite the pacemaker to
minimize potential interference.
If you have any reason to suspect that interference
is taking place, switch your phone off immediately.
Hearing Aids
Some digital wireless phones may interfere with
some hearing aids. In the event of such
interference, you may wish to consult your hearing
aid manufacturer to discuss alternatives.
Other Medical Devices
If you use any other personal medical devices,
consult the manufacturer of your device to
determine if it is adequately shielded from external
RF energy. Your physician may be able to assist you
in obtaining this information. Switch your phone off
in health care facilities when any regulations posted
in these areas instruct you to do so. Hospitals or
health care facilities may be using equipment that
could be sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle. You should
also consult the manufacturer of any equipment that
has been added to your vehicle.
Posted Facilities
Switch your phone off in any facility where posted
notices require you to do so.
Potentially Explosive Environments
Switch your phone off when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause
an explosion or fire resulting in bodily injury or even
death.
Users are advised to switch the phone off while at a
refueling point (service station). Users are reminded
of the need to observe restrictions on the use of
radio equipment in fuel depots (fuel storage and
distribution areas), chemical plants or where
blasting operations are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
77
Health and safety information
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas
(such as propane or butane), areas where the air
contains chemicals or particles, such as grain, dust
or metal powders, and any other area where you
would normally be advised to turn off your vehicle
engine.
Emergency Calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well
as user programmed functions, which cannot
guarantee connection in all conditions. Therefore,
you should never rely solely on any wireless phone
for essential communications (medical emergencies,
for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not
be possible on all wireless phone networks or when
certain network services and/or phone features are
in use. Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location (for example, 911 or other official
emergency number). Emergency numbers vary
by location.
3. Press .
If certain features are in use (call barring, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult this document and your local cellular service
provider.
When making an emergency call, remember to give
all the necessary information as accurately as
possible. Remember that your phone may be the
only means of communication at the scene of an
accident; do not cut off the call until given
permission to do so.
Restricting Children's access to your Phone
Your phone is not a toy. Children should not be
allowed to play with it because they could hurt
themselves and others, damage the phone or make
calls that increase your phone bill.
FCC Notice and Cautions
78
Health and safety information
FCC Notice
The phone may cause TV or radio interference if
used in close proximity to receiving equipment. The
FCC can require you to stop using the phone if such
interference cannot be eliminated.
Vehicles using liquefied petroleum gas (such as
propane or butane) must comply with the National
Fire Protection Standard (NFPA-58). For a copy of
this standard, contact the National Fire Protection
Association, One Battery march Park, Quincy, MA
02269, Attn: Publication Sales Division.
Cautions
Changes or modifications made in the radio phone,
not expressly approved by Samsung, will void the
user’s authority to operate the equipment.
Only use approved batteries, antennas and
chargers. The use of any unauthorized accessories
may be dangerous and void the phone warranty if
said accessories cause damage or a defect to the
phone.
• This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) this device may not
cause harmful interference, and (2) this
device must accept any interference
received, including interference that may
cause undesired operation.
• This equipment has been tested and found
to comply with the limits for a Class B
digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation. This equipment generates,
uses and can radiate radio frequency
energy and,if not installed and used in
accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur in
a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be
determined by turning the equipment off
and on, the user is encouraged to try to
correct the interference by one or more of
the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment
and receiver.
-Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV
technician for help
79
Health and safety information
Although your phone is quite sturdy, it is a complex
piece of equipment and can be broken. Avoid
dropping, hitting, bending or sitting on it.
Other Important Safety Information
• Only qualified personnel should service the
phone or install the phone in a vehicle. Faulty
installation or service may be dangerous and
may invalidate any warranty applicable to the
device.
• Check regularly that all wireless phone
equipment in your vehicle is mounted and
operating properly.
• Do not store or carry flammable liquids, gases or
explosive materials in the same compartment as
the phone, its parts or accessories.
• For vehicles equipped with an air bag, remember
that an air bag inflates with great force. Do not
place objects, including both installed or portable
wireless equipment in the area over the air bag
or in the air bag deployment area. If wireless
equipment is improperly installed and the air bag
inflates, serious injury could result.
• Switch your phone off before boarding an
aircraft. The use of wireless phone in aircraft is
illegal and may be dangerous to the aircraft's
operation.
• Failure to observe these instructions may lead to
the suspension or denial of telephone services to
the offender, or legal action, or both.
Product Performance
Getting the Most Out of Your Signal Reception
The quality of each call you make or receive depends
on the signal strength in your area. Your phone
informs you of the current signal strength by
displaying a number of bars next to the signal
strength icon. The more bars displayed, the stronger
the signal.
If you're inside a building, being near a window may
give you better reception.
Understanding the Power Save Feature
If your phone is unable to find a signal after 15
minutes of searching, a Power Save feature is
automatically activated. If your phone is active, it
periodically rechecks service availability or you can
check it yourself by pressing any key.
Anytime the Power Save feature is activated, a
message displays on the screen. When a signal is
found, your phone returns to standby mode.
Understanding How Your Phone Operates
Your phone is basically a radio transmitter and
receiver. When it's turned on, it receives and
transmits radio frequency (RF) signals. When you
use your phone, the system handling your call
controls the power level. This power can range from
0.006 watts to 0.2 watts in digital mode.
80
Health and safety information
Maintaining Your Phone's Peak Performance
For the best care of your phone, only authorized
personnel should service your phone and
accessories. Faulty service may void the warranty.
There are several simple guidelines to operating
your phone properly and maintaining safe,
satisfactory service.
• Hold the phone with the antenna raised, fully-
extended and over your shoulder.
• Try not to hold, bend or twist the phone's
antenna.
• Don't use the phone if the antenna is damaged.
• Speak directly into the phone's receiver.
• Avoid exposing your phone and accessories to
rain or liquid spills. If your phone does get wet,
immediately turn the power off and remove the
battery. If it is inoperable, call Customer Care for
service.
Availability of Various Features/Ring
Tones
Many services and features are network dependent
and may require additional subscription and/or
usage charges. Not all features are available for
purchase or use in all areas. Downloadable Ring
Tones may be available at an additional cost. Other
conditions and restrictions may apply. See your
service provider for additional information.
Battery Standby and Talk Time
Standby and talk times will vary depending on
phone usage patterns and conditions. Battery power
consumption depends on factors such as network
configuration, signal strength, operating
temperature, features selected, frequency of calls,
and voice, data, and other application usage
patterns.
Battery Precautions
• Never use any charger or battery that is
damaged in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network's base
station, it uses less power; talk and standby time
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
• Battery charging time depends on the remaining
battery charge and the type of battery and
charger used. The battery can be charged and
discharged hundreds of times, but it will
gradually wear out. When the operation time
(talk time and standby time) is noticeably
shorter than normal, it is time to buy a new
battery.
• If left unused, a fully charged battery will
discharge itself over time.
81
Health and safety information
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not in use,
disconnect it from the power source. Do not
leave the battery connected to a charger for
more than a week, since overcharging may
shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling
or warming first.
• Do not leave the battery in hot or cold places,
such as in a car in summer or winter conditions,
as you will reduce the capacity and lifetime of
the battery. Always try to keep the battery at
room temperature. A phone with a hot or cold
battery may temporarily not work, even when
the battery is fully charged. Li-ion batteries are
particularly affected by temperatures below 0 °C
(32 °F).
• Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object (coin,
clip or pen) causes a direct connection between
the + and - terminals of the battery (metal strips
on the battery), for example when you carry a
spare battery in a pocket or bag. Short-circuiting
the terminals may damage the battery or the
object causing the short-circuiting.
• Dispose of used batteries in accordance with
local regulations. In some areas, the disposal of
batteries in household or business trash may be
prohibited. For safe disposal options for Li-Ion
batteries, contact your nearest Samsung
authorized service center. Always recycle. Do not
dispose of batteries in a fire.
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for
many years.
• Keep the phone and all its parts and accessories
out of the reach of small children.
• Keep the phone dry. Precipitation, humidity and
liquids contain minerals that will corrode
electronic circuits.
• Do not use the phone with a wet hand. Doing so
may cause an electric shock to you or damage to
the phone.
• Do not use or store the phone in dusty, dirty
areas, as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the
82
Health and safety information
phone, which may damage the phone's
electronic circuit boards.
• Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the phone. Wipe it
with a soft cloth slightly dampened in a mild
soap-and-water solution.
• Do not paint the phone. Paint can clog the
device's moving parts and prevent proper
operation.
• Do not put the phone in or on heating devices,
such as a microwave oven, a stove or a radiator.
The phone may explode when overheated.
• When the phone or battery gets wet, the label
indicating water damage inside the phone
changes color. In this case, phone repairs are no
longer guaranteed by the manufacturer's
warranty, even if the warranty for your phone
has not expired.
• If your phone has a flash or light, do not use it
too close to the eyes of people or animals. This
may cause damage to their eyes.
• Use only the supplied or an approved
replacement antenna. Unauthorized antennas or
modified accessories may damage the phone and
violate regulations governing radio devices.
• If the phone, battery, charger or any accessory is
not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
83
Index
A
AB mode, text input •
16
Alarm •
44
Answering
call •
31
second call •
32
Anykey answer •
81
Auto redial •
80
B
Backlight, set
display •
83
keypad •
83
Barring, calls •
85
Battery
charging •
7
inserting •
8
precautions •
98
Bluetooth
receiving, data •
89
sending, data •
89
settings •
87
Broadcast messages •
56
,
62
Browser, web •
47
C
Calendar •
70
Call cost •
36
Call log
dialled •
35
missed •
35
received •
35
Call time •
36
Caller groups •
39
Caller ID •
82
,
86
Calls
answering •
31
barring •
85
diverting •
84
holding •
32
redialling •
30
rejecting •
31
waiting •
85
Camera
photos •
73
videos •
76
CB (Cell Broadcast) messages •
56
,
62
Configuration messages •
54
Connection tone •
83
Creating messages
MMS •
52
SMS •
51
CUG (Closed User Group) •
86
D
Date, set •
79
Deleting
call log •
34
e-mail •
57
,
59
events •
72
MMS •
55
,
57
,
59
phonebook •
38
,
41
SMS •
54
,
57
,
59
Dialled calls •
35
Dialling font, set •
81
Display
brightness •
81
icons •
13
language •
80
layout •
12
settings •
81
Diverting, calls •
84
Document files •
69
DRM (Digital Rights Management)
•
64
DTMF tones, send •
33
E
Emergency calls •
103
F
FDN (Fixed Dialling Number) mode
•
91
File manager •
64
G
Greeting message •
80
H
Health and safety •
97
Holding, call •
32
I
Icons, description •
13
Images, downloaded •
64
Inbox, messages
MMS/SMS •
53
Inserting
battery •
8
SIM card •
7
International calls •
30
Internet •
47
84
Index
K
Key functions •
10
Keypad lock •
9
Keypad tones
selecting •
82
sending/muting •
33
L
Language, select •
80
Last number, redial •
30
Light settings •
83
Locking
keypad •
9
menu functions •
91
phone •
90
SIM card •
91
M
Memory status
downloaded items •
70
file manager •
70
messages •
63
phonebook
41
Menu
accessing •
14
overview •
5
Message tone •
82
Messages
cell broadcast •
56
,
62
configuration •
56
greeting •
80
MMS •
52
,
55
push •
56
,
62
SMS •
51
,
54
SOS •
63
Minute minder •
83
Missed calls •
35
MMS messages
creating/sending •
52
deleting •
55
setting •
61
viewing •
53
Mobile tracker •
91
Multiparty-call •
33
Music, downloaded •
67
N
Name card •
40
Names
searching •
37
Network selection •
86
Network services •
84
O
Offline mode •
9
Outbox, messages •
57
P
Password
call barring •
85
phone •
90
Phone
care and maintenance •
104
charging •
7
display •
12
icons •
12
keys •
10
locking •
90
overview •
6
password •
90
resetting •
94
switching on/off •
9
unpacking •
6
Phonebook
adding •
38
deleting •
38
,
41
finding •
37
managing •
41
options •
37
speed dialling •
40
Photos
taking •
73
viewing •
64
PIN, change •
90
PIN2, change •
91
Power on/off tone •
82
Privacy •
91
Problems, solve •
95
Push messages •
56
,
62
Q
Quiet mode
entering •
19
setting •
83
R
Received calls •
35
Received messages
MMS/SMS •
53
Recording
videos •
76
voice memos •
42
Redialling
automatically •
80
manually •
30
Resetting phone •
94
Ringer
incoming calls •
82
messages •
82
85
Index
Road safety •
100
Roaming •
86
S
Safety
information •
97
precautions •
1
Security, calls •
90
Sent messages •
57
Shortcut •
80
SIM card
inserting •
7
,
8
locking •
91
SMS messages
creating/sending •
51
deleting •
54
setting •
60
viewing •
53
Solving problems •
95
SOS messages •
63
Sound settings •
82
Sounds, downloaded •
68
Speed dial •
40
Stopwatch •
46
Switching on/off
phone •
9
T
Templates, message •
58
Time, set •
79
Timer •
45
V
Videos
playing •
66
recording •
76
Voice recorder
playing •
42
recording •
42
Voicemail server •
86
W
Waiting call •
85
Web browser
access •
47
bookmarks •
49
World time •
44
