Users Manual
SGH-F310
Guide
2Important safety precautions
Drive safely at all times
Do not use the phone while driving. Park your
vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using
them in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Be aware of special regulations
Meet any special regulations in force in any area
and always switch off your phone whenever it is
forbidden to use it, or when it may cause
interference or danger.
Sensible use
Use only in the normal position (held to your ear).
Avoid unnecessary contact with the antenna when
the phone is switched on.
Water resistance
Your phone is not water-resistant. Keep it dry.
Emergency calls
Key in the emergency number for your present
location, then press SEND.
Keep your phone away from small children
Keep the phone and all its parts, including
accessories, out of the reach of small children.
Accessories and batteries
Use only Samsung and Bang & Olufsen approved
batteries and accessories, such as headsets and PC
data cables. Use of any unauthorised accessories
could damage you or your phone and may be
dangerous.
- The phone could explode if the battery is
replaced with an incorrect type.
- Dispose of used batteries according to the
manufacturer’s instructions.
At very high volumes, prolonged
listening to a headset can damage your
hearing.
Use of authorised software
Use only Samsung-authorised software. The use of
any unauthorised software could damage your
phone.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health
and safety information" on page 54.
Note! Failure to comply with the
following precautions may be dangerous
or illegal.
3
This Guide provides you with information about
how to use your phone.
In this guide, the following visual features appear:
Note! Indicates that you need to
pay careful attention to the
subsequent information
regarding safety or phone
features.
Indicates that you can get
more information on the
referenced page.
→Indicates that you need to
press the Navigation keys to
scroll to the specified option
and then select it.
BOLD Indicates a key on the
phone. For example, SEND.
Music player
Play music files on your
phone. You can use other
phone functions while
listening to music.
Synchronisation with
Windows Media Player
Transfer music files to your
phone directly from the
Windows Media Player.
Flight mode
Switch your phone to Flight
mode to use its non-
wireless functions while on
an aeroplane.
Bluetooth
Transfer media files and
personal data and connect
to other devices using
wireless Bluetooth
technology.
Web browser
Access the wireless web to
get up-to-the-minute
information and a wide
variety of media content.
Email
Send and receive emails
with image, video, and
audio attachments.
Multimedia Message
Service (MMS)
Send and receive
multimedia messages with
a combination of text,
images, video, and audio.
Name card
Create name cards with
your number and profile.
Whenever introducing
yourself to others, use this
convenient electronic name
card.
Voice recorder
Record memos or sounds.
Organiser
Keep track of your daily,
weekly, and monthly
schedule.
About this Guide and Special features
4Contents
Get started, 6
• Unpack
• Assemble and charge the phone
• Your phone - and overview
Functions used daily, 8
• Switch on or off
• Make or answer calls
• Access menu options
• Customise your phone
Step outside the phone, 10
•Play music
• Browse the web
• Use the Phonebook
• Send messages
• View messages
• Use Bluetooth
Enter text, 17
• Use ABC mode
•Use T9 mode
• Use My words mode
• Use Number mode
• Use Symbol mode
Call functions, 19
• Make a call
• Answer a call
• View missed calls
• Options during a call
Music player, 22
• Download music files to the phone
• Synchronise with Windows Media Player
•Play music
• Create your own playlist
• Use Music player options
• Change Music player settings
Messages, 25
Browser, 32
Organiser, 35
Library, 37
Phonebook, 39
Call log, 41
Applications, 42
Settings, 46
SIM services, 51
Solve problems, 52
Health and safety information, 54
Index, 58
Conditions of the guarantee, 61
Waste Electrical and Electronic
Equipment (WEEE), 62
5
Menu functions-overview
1 Messages
p. 25
1 Create message
2 Inbox
3 Email inbox
4 Drafts
5 Outbox
6 Sent
7 Templates
8 Archive messages
9 Settings
10 Memory status
p. 25
p. 27
p. 28
p. 28
p. 28
p. 29
p. 29
p. 29
p. 30
p. 31
2 Browser
p. 32
1 Home
2 Enter URL
3 Bookmarks
4 Saved pages
5 History
6 Advanced
7 Connection profiles
p. 32
p. 32
p. 33
p. 33
p. 33
p. 34
p. 34
3 Organiser
p. 35
1 Calendar
2 Appointment
3 Anniversary
4 Missed alarm events
p. 35
p. 36
p. 36
p. 36
4 Library
p. 37
1 Images
2 Sounds
3 Videos
4 Other files
5 Memory status
p. 37
p. 37
p. 38
p. 38
p. 38
5 Phonebook
p. 39
1 Contact list
2 Add new contact
3 Groups
4 My business card
5 Own number
6 Copy all to SIM
7 Copy all from SIM
8 Delete all
9 Settings
10 Memory status
p. 39
p. 39
p. 40
p. 40
p. 40
p. 40
p. 40
p. 40
p. 40
p. 40
6 Call log
p. 41
1 Recent calls
2 Missed calls
3 Dialled calls
4 Received calls
5 Remove all
6 Call duration
p. 41
p. 41
p. 41
p. 41
p. 41
p. 41
7 Applications
p. 42
1 Alarm
2 World clock
3 Calculator
4 Currency converter
5 Voice memo
6 Memo
7 To do
8 Media player
p. 42
p. 42
p. 43
p. 43
p. 43
p. 44
p. 44
p. 45
8 Settings
p. 46
1 Time & date
2 Phone settings
3 Display settings
4 Sound settings
5 Network services
6 Bluetooth
7 Security
8 Connection settings
9 DRM key management
10 Memory settings
11 Master reset
p. 46
p. 46
p. 47
p. 47
p. 47
p. 48
p. 49
p. 50
p. 50
p. 50
p. 50
9 SIM services
p. 51
To access Menu mode, press OK in Idle
mode.
6Get started
Unpack
Assemble and charge the phone
SIM card information
When you subscribe to a cellular network, you
receive a plug-in SIM (Subscriber Identity Module)
card loaded with your subscription details, such as
your pincode and available optional services. For 3G
services, you can purchase a USIM (Universal
Subscriber Identity Module) card.
Low battery indicator
When the battery is low:
- a warning tone sounds,
- the battery low message displays,
- the empty battery icon blinks.
If the battery level becomes too low, the phone
automatically switches off. Recharge your battery.
Phone Battery Travel adapter User’s Guide CD
14
25
36
You can begin the phone with this section. This
section describes how to install and charge the
phone and use the keys, and shows the
meaning of icons displayed on the display.
You can obtain various accessories from your
local Samsung and Bang & Olufsen retailers.
Note! The items supplied with your phone and the
accessories available at your Samsung and Bang &
Olufsen retailers may vary, depending on your
country or service provider.
1 Open the phone and pull out the stand.
Note! If the phone is already on, first switch it
off by pressing and holding END.
2 Lift the battery cover away, as shown.
3 Insert the SIM card.
Note! Make sure that the gold-coloured
contacts on the card face downwards.
4 Install the battery.
5 Align the cover with the bottom of the phone
and press the cover down, as shown
6 Plug the travel adapter into the phone.
7 Plug the adapter into a standard AC power
outlet.
8 When the phone is completely charged, unplug
the adapter from the power outlet and from the
phone.
7
Your phone - and overview
Phone and keys
1 OK key (Centre of wheel)
- In Idle mode, access Menu mode.
- In Menu mode, select a highlighted menu option
or confirm input.
- Switch on the display.
2 SEND key (Left green)
- Make or answer a call.
- In Idle mode, retrieve the numbers of recently
dialled, missed, or received calls.
3 BACK key
- In Idle mode, press and hold to lock the keys.
- In Menu mode, return to the previous menu
level.
4 Music player key
Tap to open Music player.
5 Display
6 Microphone
7 Headset/Adapter/PC data cable jack
8 Speaker
Your phone has a built-in stereo speaker which
allows you to listen to music.
9 C key
Delete characters from the display.
10 END key (Right red)
- Press and hold to switch the phone on and off.
- End a call.
- In Menu mode, cancel input and return the
phone to Idle mode.
11 Wheel
- In Idle mode, move the wheel clockwise or
counterclockwise to search for a Phonebook
entry.
- In Menu mode, scroll through menu options.
12 More key
In Idle mode, tap to access the Quick menu list.
13 Phone stand
Display
Your phone’s display has the following three areas:
-Icons display various icons.
-Text and graphics display messages,
instructions, and information you enter.
-Soft key function indicators show the current
functions assigned to the two soft keys.
Using the touch screen
Your phone has a sensitive touch screen. Using it,
you can open the dialling screen, open Music
player, access the Quick menu list, or access the
menu shortcut screen.
Icons
The following icons may appear on the top line of
the screen to indicate your phone’s status.
Depending on your country or service provider, the
icons shown on the display may vary.
2
1
3
4
5
6
7
10
8
9
13
12
11
Text and graphics
Icons
Soft key function
indicators
Strength of the received signal
Call in progress
Outside your service area or Flight
mode; you cannot make or receive calls
Roaming network
GPRS network
3G network
Home zone, if you have subscribed to
this service
City zone, if you have subscribed to this
service
Call diverting feature active
Bluetooth feature active
Music playback in progress
Bluetooth headset or hands-free car kit
connected
New text message
New multimedia message
New email
New voicemail
Alarm set
Quiet mode
Battery power level
8Functions used daily
Switch on or off
To switch the phone on
> Press and hold END.
> If necessary, enter the pincode and press OK.
> When you use the phone for the first time or
reset it, the setup wizard starts. Customise your
phone according to your preferences.
p. 9
Note! Do not switch on the phone where mobile
phone use is prohibited.
To switch the phone off
> Press and hold END.
Make or answer calls
To make a call
> In Idle mode, tap the centre of the display to
open the dialling screen.
> Enter an area code and phone number.
>Press SEND.
> To end the call, press END.
To answer a call
> When the phone rings, press SEND.
> To end the call, press END.
To adjust the volume during a call
Move the wheel clockwise or counterclockwise.
This section describes how to switch on
the phone, make calls, and customise
basic phone settings.
9
Access menu options
> Press OK to access Menu mode.
> Move the wheel clockwise or counterclockwise
to scroll through menus.
> Press OK to confirm a selection.
> To exit, either:
-Press C to move up one level.
-Press END to return to Idle mode.
Customise your phone
Setup wizard
When you switch on the phone for the first time, or
reset it, the phone guides you to set up your phone.
When you want to set up the phone, use the setup
wizard.
> In Idle mode, press More and select Welcome
sequence.
> Select a language and press OK.
>Press OK to continue customising your phone.
> Follow the onscreen instructions.
Display language
You can change the language to be used for the
display text.
> In Idle mode, press OK and select Settings →
Phone settings → Language.
> Select a language.
Ringtone setting for a call ringer
You can change the ringtone for a call ringer.
> In Idle mode, press OK and select Settings →
Sound settings → Ringtone.
> Select a ringtone.
Display item
You can select your display item for the idle screen.
> In Idle mode, press OK and select Settings →
Display settings → Idle display.
> Select a display item.
Key lock
You can lock the keys to prevent them from being
pressed accidentally.
To lock the keys, in Idle mode, press and hold
BACK. To unlock, press OK and select Yes.
Voicemails
You can access the voicemail server and listen to
the messages.
In Idle mode, press More and select Voice mail.
You are connected to the voicemail server.
Silent mode
You can switch the phone to Silent mode to avoid
disturbing other people.
In Idle mode, press an hold C, or press More and
select Silent mode.
Flight mode
You can switch the phone to Flight mode, in which
the phone functions requiring network connection
are deactivated.
In Idle mode, press More and select Flight mode.
Menu shortcuts
You can set menu shortcuts to be accessed from
Idle mode.
> In Idle mode, press More and select Shortcuts.
> Select an item.
> Select a menu.
To access a shortcut menu, tap the bottom of the
display and select a menu.
Phone lock
You can protect the phone against unauthorised
use with a phone password. The phone will require
the password when switched on.
> In Idle mode, press OK and select Settings →
Security → Change password.
> Enter the default password, 00000000, and
select Done.
> Enter a new 4- to 8-digit password and select
Done.
> Enter the new password again and select Done.
> Select Phone lock.
> Select Enable.
> Enter the password and select Done.
10 Step outside the phone
Play music
You can play music using the Music player.
Download music files to the phone
- Download from the web browser.
p. 32
- Download from a computer using the optional
Samsung PC Studio. See Samsung PC studio
User’s Guide.
- Receive via Bluetooth.
p. 48
- Synchronise with Windows Media player.
p. 22
Play music files
>Press Music to open Music player.
> Select a playlist and then a music file. The Music
player opens and plays the first file on the list.
> Use the following keys during playback:
-SEND: pause or resume playback.
-OK: open the playlist.
- Wheel: adjust the volume.
> Tap the left or right arrow on the screen to move
to the next or previous file.
>Press END to stop playback and close the player.
Browse the web
Using a built-in web browser, you can easily access
the wireless web to get a variety of up-to-date
services and information and to download web
content.
Launch the web browser
In Idle mode, press OK and select Browser →
Home. The homepage of your service provider
opens.
Navigate the web
- To scroll through browser items, move the wheel
clockwise or counterclockwise.
- To select a browser item, press OK and select
Select.
- To return to the previous page, press BACK.
- To access browser options, press More.
This section allows you to surf quickly
your phone using Music player, the web,
Phonebook, and other special features.
11
Use the Phonebook
You can save several phone numbers, emails, and
addresses in the Phonebook. Using the contact
information, you can call them or send messages
anytime.
Add a contact
> In Idle mode, tap the centre of the display to
open the dialling screen.
> Enter a phone number.
> Press More and select Add to new contact →
Phone or SIM.
>For Phone, select a number type.
> Specify contact information.
> Press More and select Save, or press More to
save the contact.
Find a contact
> In Idle mode, turn the wheel clockwise or
counterclockwise to access the Phonebook.
> Select the first character of the name you want
to find.
> Scroll to the contact.
> Press SEND to dial. If the name has more than
one number, select a number.
Create and send your name card
> In Idle mode, press OK and select Phonebook →
My business card.
> Specify your contact information.
> Press More and select Save business card to
save the name card.
> To send the name card, access My business card
again. Press More and select Send business
card via → a sending method.
Send messages
You can send text, multimedia, and email
messages.
Send a text message (SMS)
> In Idle mode, press OK and select Messages →
Create message → Text message.
> Enter the message text.
>Press OK and select Send message.
> Add a destination number by selecting a contact
from the Phonebook or entering a phone
number.
>Press More and select Send to send the
message.
Send a multimedia message (MMS)
> In Idle mode, press OK and select Messages →
Create message → Multimedia message.
> Select Subject.
> Enter the message subject.
>Press More and select Done to save the subject.
> Select Image or video and add an image or a
video clip.
> Select Sound and add a sound clip.
> Select Message.
> Enter the message text.
>Press More and select Done to save the
message.
> Select the Attach file(s) field and add an item to
be added.
> When you have finished, press More and select
Send.
> Add a destination number or email address by
selecting a contact from the Phonebook or
entering a phone number or email address.
> Select a contact or a caller group from
Phonebook, or enter a phone number or email
address.
>Press More and select Send to send the
message.
Send an email
> In Idle mode, press OK and select Messages →
Create message → Email.
> Select Subject.
> Enter the subject of your email.
>Press More and select Done.
> Select Message.
> Enter the email text.
>Press More and select Done.
> Select Attach file(s) → an item to be added.
>Press More and select Send.
> Add a destination email address by selecting a
contact from the Phonebook or entering an
email address.
>Press More and select Send to send the email.
>> Step outside the phone
12
View messages
You can receive messages from other people and
save them in your phone.
View a text message
When a notification appears:
>Press OK.
> Select the message from the Inbox.
From the Inbox:
> In Idle mode, press OK and select Messages →
Inbox.
> Scroll to a message ( ) and press OK.
View a multimedia message
When a notification appears:
>Press OK and select Retrieve.
> Select the message from the Inbox.
From the Inbox:
> In Idle mode, press OK and select Messages →
Inbox.
> Scroll to a message ( ) and press OK.
View an email
> In Idle mode, press OK and select Messages →
Email box.
> Select an account.
>Press OK when Check for new email is
displayed to download an email or a header.
> Scroll to an email or a header and press SEND.
> If you selected a header, press OK and select
Retrieve.
Use Bluetooth
Your phone is equipped with Bluetooth technology,
enabling you to connect the phone wirelessly to
other Bluetooth devices and exchange data with
them, talk hands-free, or control the phone
remotely.
Activate Bluetooth
> In Idle mode, press OK and select Settings →
Bluetooth → Turn on → On.
> Select My phone’s visibility → On to allow
other devices to find your phone.
Search for and pair with a Bluetooth device
> In Idle mode, press OK and select Settings →
Bluetooth → My devices → New search.
> Select a device.
> Enter a Bluetooth pincode or the other device’s
Bluetooth pincode, if it has one, and select
Done.
When the owner of the other device enters the
same pincode, pairing is complete.
Send data
> Access an application, such as Phonebook,
Library, Organiser, Memo, or To do.
> Scroll to an item.
>Press More and select Send via, Send business
card via, or Send this business card →
Bluetooth.
> Select a device.
> If necessary, enter the Bluetooth pincode and
select Done.
Receive data
> When a device attempts to access your phone,
select Yes to permit the connection.
> If necessary, select Yes to confirm that you are
willing to receive.
13
>> Step outside the phone
14
15
Enter text
Use ABC mode
When you enter the text input field, ABC mode is
selected.
Entering a word in ABC mode
Move to the appropriate character set and press
OK until the character you want appears on the
screen.
- Once for the first letter.
- Twice for the second letter.
- And so on.
Other ABC mode operations
- To enter the same letter twice or to enter a
different letter on the same key, wait for the
cursor to move to the right automatically or turn
the wheel clockwise. Then enter the next letter.
- Tap the soft key to change case.
- Select the Insert Space marker ( ) to insert a
space.
-Press C to delete characters one by one. Press and
hold C to clear the entire display.
Use T9 mode
T9 is a predictive text input mode that allows you to
key in any character using single keystrokes.
Enter a word in T9 mode
> Select the appropriate character set once for
each letter.
T9 predicts the word that you are typing, and it
may change with each key that you press.
> Enter the whole word before editing or deleting
characters.
> When the word displays correct, select to
insert a space. Otherwise, tap the Match soft
key to display alternative word choices for the
keys that you have pressed.
Other T9 mode operations
- Select the Full stop marker (.) to enter a full stop.
- Select the Comma marker (,) to enter a comma.
- Tap the soft key to change case.
- Select the Insert Space marker ( ) to insert a
space.
- Press C to delete characters one by one. Press and
hold C to clear the entire display.
When you are in a field that allows
characters to be entered, you will notice
the text input mode indicator on the
display.
You can enter text in some features,
such as Messages, Phonebook, or
Calendar, using ABC mode, T9 mode,
My words mode, Number mode, and
Symbol mode.
You can change the text input mode
using the following methods:
- To switch to T9 mode, press More and
select T9.
- To switch My words mode, press More
and select My words.
- To switch to Number mode, press
More and select Number input, or
tap the 123 soft key in the left hand
corner of the screen.
- To switch to Symbol mode, press More
and select Symbol input, or tap the
&:@ soft key in the left hand corner of
the screen.
- To switch back to T9 mode or ABC
mode, press More and select Text
input, or tap the abc soft key in the
left hand corner of the screen.
>> Enter text
16
Use My words mode
My words mode enables you to preset words or
phrases so that you can quickly and easily insert
them into your text while creating a message.
Note! This mode is available only when T9 mode is
activated.
To add a word or phrase to the My words
list
This feature may not be available for some
languages.
>Select Create.
> Enter the word you want using ABC mode.
>Press More and select T9 to switch to T9 mode.
>Press More again and select Add word.
The word or phrase is added to the My words
list.
Use Number mode
Number mode enables you to enter numbers. Press
the keys corresponding to the digits you want.
Use Symbol mode
Symbol mode enables you to insert symbols.
- To scroll through symbols, move the wheel
clockwise or counterclockwise.
- To insert the selected symbol in the message,
press OK.
17
Call functions
Make a call
Calls are made from the dialling screen.
To make a call
> In Idle mode, tap the centre of the display to
open the dialling screen.
> Enter the area code, and phone number using
the wheel.
Notes!
- Press C to clear the last digit or press and hold
C to clear the whole display.
- To enter a pause, press More and select
Pause.
>Press SEND.
> When you want to end the call, press END.
To make an international call
> On the dialling screen, select +.
> Enter the country code, area code, and phone
number, then press SEND.
To redial recent numbers
> In Idle mode, press SEND to display the list of
recent numbers.
> Scroll to the number you want and press SEND.
To make a call from the Phonebook
Once you have stored a number in the Phonebook,
you can dial the number by selecting it from the
Phonebook.
p. 37
You can quickly dial a number from the SIM card
using the location number assigned to it when you
stored it.
> On the dialling screen, enter a location number
and select .
>Press SEND to dial the number.
This section describes call-related
functions.You can make calls in serveral
ways or use In-call options.
>> Call functions
18
Answer a call
When you receive an incoming call, the phone
rings.
Press SEND, or press More and select Accept to
answer the call.
Tips for answering a call
-Press END, or press More and select Reject call
to reject a call.
-Press C to mute the ringer for an incoming call.
View missed calls
If you have missed calls, the screen displays how
many calls you have missed.
>Press OK.
> If necessary, scroll through the missed calls.
>Press SEND to dial the number you want.
Options during a call
You can access a number of functions during a call.
To adjust the volume during a call
Use the wheel to adjust the volume during a call.
Turn the wheel clockwise to increase the volume
and counterclockwise to decrease the volume.
To place a call on hold or retrieve
Press More and select Hold to place a call on hold,
or select Retrieve call to retrieve a call on hold.
To make a second call
You can make another call while your first call is on
hold if your network supports this function.
> Press More and select Hold to put the call on
hold.
> Make the second call in the normal way.
> Press More and select Switch calls to switch
between the calls.
> Press More and select End held to end the call
on hold.
> To end the current call, press END.
To answer a second call
You can answer an incoming call while already on
the phone, if your network supports this function
and you have activated the call waiting feature.
p. 46
> Press SEND to answer the call. The first call is
automatically put on hold.
> Press More and select Switch calls to switch
between the calls.
> Press More and select End held to end the call
on hold.
> To end the current call, press END.
19
To use In-call options
During a call, press More to access the following
options:
-Switch to headset or Switch to phone: switch
the call to a Bluetooth headset or hands-free car
kit, or back to the phone.
-Hold/Retrieve call: place the current call on hold
or retrieve the call on hold.
-Mute or Unmute: switch the phone's
microphone off or on. When the microphone is
switched off, the person on the other end of the
line will not be able to hear you.
-Mute key tone or Unmute key tone: switch
the DTMF tones on or off. The DTMF tones are
the tones used in phones for tone dialling,
sounding when you press the number keys.
Note! T
o communicate with answering machines or
computerised telephone systems,
Unmute key
tone
must be selected.
-Send message: send a text message to the
person with whom you are talking.
-Send DTMF: send the DTMF (Dual tone multi-
frequency) tones as a group. This option is
helpful for entering, for example, a password or
an account number for an automated banking
service.
-New call: make a new call.
-Phonebook: access the Phonebook list.
-View contact derails: access contact
information, if the number is saved in
Phonebook.
-Calendar: access the calendar to check your
schedule or enter new appointments.
-Memo: create a memo.
-Swap calls: transfer the currently active call to a
caller on hold. The two callers can talk to each
other, but you are disconnected from the call.
-Join calls: set up a multi-party call by adding a
caller on hold to a currently active call. You can
include up to 6 people on a multi-party call.
-Select one call: select one of multi-party call
participants. You can then use the following
options:
Private: have a private conversation with the
selected participant. The other participants can
converse with each other. After the private
conversation, select Join calls to return both
private participants to the multi-party call.
End call: disconnect the selected participant.
20 Music player
Download music files to the phone
You have the following ways to download music
files and save them to your phone.
- Download from the web browser.
p. 30
- Download from a PC using the optional Samsung
PC Studio. See Samsung PC studio User’s Guide.
-Receive via an active Bluetooth connection.
p. 46
- Synchronise with Windows Media player.
p. 20
Downloaded or received files are stored in the
Music player library.
Synchronise with Windows Media
Player
You can copy music files to your phone by
synchonising with Windows Media Player 11 on a
PC.
> In Idle mode, press OK and select Settings →
Phone settings → Transfer mode → MTP.
> Connect your phone and PC with an optional PC
data cable.
> Select Synchronize media files to this device
when a pop-up window appears on your PC.
> Set the phone to synchronise with only the
current library and click Finish.
> Click Edit Playlist.
> Select the music files you want and click OK.
> Click Start Sync.
> When synchronisation is finished, disconnect the
phone from the PC
The Music player allows you to play
music files, audiobooks, podcast files in
your phone. You can open Music player
and listen to music while using other
applications.
To open Music player, press Music.
21
Play music
> In Idle mode, press Music.
> Select a playlist and then a music file. The Music
player opens and plays the first file on the list.
> Use the following keys during playback:
-SEND: pause or resume playback.
-OK: open the playlist.
- Wheel: adjust the volume.
> Tap the left or right arrow on the screen to move
to the next or previous file.
> Press END to stop playback and close the player.
Create your own playlist
> In Idle mode, press Music.
> Select a playlist and then a music file.
>Press More and select Add to playlist.
> Select Add to a new playlist.
> Enter a playlist name, and press More and select
Done.
The playlist is saved in Playlists.
Use Music player options
During playback, press More to access the
following options:
-Pause or Play: pause or resume playback.
-Music library home: open the playlists.
-Add to favourites: add the file to the
Favourites folder.
-Add to playlist: add the file to a playlist.
-Go to artist: open the album list of the artist
currently playing.
-Play via: play the file via Bluetooth stereo
headset or phone speaker.
-Delete track: delete the file.
-Repeat: turn the repeat mode on or off.
-Send via: send the file via MMS, email, or
Bluetooth.
-Track details: access the file information.
>> Music player
22
Change Music player settings
In Idle mode, press Music and select Settings to
access the following options:
-Music menu order: change the playlist order or
delete playlists.
-Index line searching: set the phone to find
music files using the first character of a file name.
-Default volume: select a default music player
volume.
23
Messages
Create message
(Menu 1.1)
Use this menu to create and send text messages,
multimedia messages, or emails.
Text message
(Menu 1.1.1)
This menu allows you to create and send text
messages via Short Message Service (SMS).
To create and send a text message
> Enter your message.
Note! The maximum number of characters
allowed in a text message depends on the
encoding setting. If your message exceeds the
maximum number of characters, the phone will
split the message.
> When you have finished entering, press More
and select Send message.
> Add destination numbers by selecting from the
following:
Add from Phonebook: select a phone number
from the Phonebook.
Enter number: enter a phone number.
Add from Group: select a caller group from the
Phonebook.
>Press More and select Send to send the
message.
Options while composing a text message
Press More to access the following options:
-Select: confirm or select the currently highlighted
item.
-Send message: move to the destination input
field.
-Save as draft: save the message in the Drafts
folder.
-Insert item: insert a template, contact’s phone
number, or bookmark item.
-Symbol input or Number input: switch to
Symbol mode or Number mode.
-T9: activate or deactivate T9 mode.
-Auto complete: set the phone to predict and
display the word you are entering. The word
choices are stored in the T9 dictionary.
-Add word: add a word to the My words list.
-My words: access the My words list.
-Input language: change the input language.
Multimedia message
(Menu 1.1.1)
Multimedia Message Service (MMS) delivers
messages containing a combination of text, image,
and audio, from phone to phone or from phone to
email.
To create an send a multimedia message
> Select the Subject field.
> Enter the subject of your message.
>Press More and select Done to save the subject.
> Select the Image or video field and add an
image or a video clip.
Notes!
- The maximum size allowed for an MMS
message can differ depending on your service
provider.
- The DRM (Digital Rights Management) system
and the file type determine which files can or
cannot be forwarded.
> Select the Sound field and add a sound clip.
> Select the Message field.
> Enter the message text.
>Press More and select Done to save the
message.
> Select the Attach file(s) field and add an item to
be added.
> When you have finished, press More and select
Send.
> Add destination numbers or email addresses by
selecting from the following:
Add from Phonebook: select a phone number
or email address from the Phonebook.
Enter number: enter a phone number.
Enter email: enter an email address.
Add from Group: select a caller group from the
Phonebook.
>Press More and select Send to send the
message.
You can send and receive text messages,
multimedia messages, and emails. You
can also access push messages and
broadcast messages.
To access this menu, press OK in Idle
mode and select Messages.
>> Messages
24
Options while composing a multimedia
message
Press More to access the following options.
Depending on the selected field, some options vary.
-Add subject or Add message: add the message
subject or text.
-Add image or video or Add sound: add a
media file stored in the phone’s memory.
-Attach: attach a name card or calender data as a
data format attachment, or a file stored in the
Other files folder.
-Send: send the message.
-Preview: view the message as it will be shown
on the recipient’s phone.
-Save as draft: save the message in the Drafts
folder.
-Edit subject or Edit message: edit the subject or
text of the message.
-Clear subject or Clear message: delete the
subject or text.
-Change image, Change video, or Change
sound: replace an added item.
-Clear image, Clear video, or Clear sound:
remove an added item.
-Add page: add pages. Move to each page by
tapping the Left or Right arrow on the screen.
-Delete page: delete a page.
-Page duration: change the duration of page
display.
-Go to next page or Go to previous page:
move to the next or previous page.
-View file:
-Change attachment: replace an attached item.
-Remove attachment: remove an attached item.
-Remove all attachment: remove all attached
items.
Email
(Menu 1.1.3)
You can send emails that include text, images, and
audio. To use this feature, you need to subscribe to
an email service and set up your email account and
profile.
p. 29
To create and send an email
> Select the Subject field.
> Enter the subject of your email.
>Press More and select Done.
> Select the Message field.
> Enter the email text.
>Press More and select Done.
> Select the Attach file(s) field → an item to be
added.
> Add images, sounds, name cards, calendar data,
memos, or tasks.
Note! The DRM (Digital Rights Management)
system and the file type determine which files
can or cannot be forwarded.
> When you have finished, press More and select
Send.
> Add email addresses by selecting from the
following:
Add from Phonebook: select an email address
from the Phonebook.
Enter email: enter an email address.
Add from Group: select a caller group from the
Phonebook.
>Press More and select Send to send the email.
Options while composing an email
While composing an email, press OK to access the
following options:
-Add subject or Add message: add the email
subject or text.
-Edit subject or Edit message: edit the email
subject or text.
-Images, Sounds, Videos: add images, sounds,
or videos.
-Business cards: add name cards as a data format
attachment.
-Appointment, Anniversary, Memo, or To do:
add calendar data as a data format attachment.
-Other files: add files in a format which your
phone does not support.
-View: open the selected attachment.
-Send: send the email.
-Change attachment: change the selected
attachment.
-Remove attachment: delete the selected
attachment.
-Remove all attachments: delete all attachments
from the message.
-Save as draft: save the message in the Drafts
folder.
25
Inbox
(Menu 1.2)
Use this menu to access all messages you have
received, except for emails.
The following icons may appear on the message list
to show the message type:
Tex t message (SMS)
Multimedia message (MMS) or Delivery report
for your sent messages
MMS notification
( : Being retrieved,
: Failed to be retrieved)
Push messages from web servers
Configuration messages, containing network
parameters from your service provider
Broadcast messages from your service provider
Notes!
- The DRM (Digital Rights Management) system
limits the forwarding of some messages
containing web content. They are indicated by
.
- A ! icon next to a message means that a message
is of high priority. A grey-coloured message icon
is of low priority.
To view a message
> Scroll to the message you want.
>Press OK.
To use message options
While viewing a message, press More to access the
following options:
Text messages
-Reply: send a reply to the sender.
-Forward: forward the message to other people.
-Delete: delete the message.
-Extract details: extract URLs, email addresses, or
phone numbers from the message.
-Add to new contact: save the sender’s number
in the Phonebook.
-Add to existing contact: save the sender’s
number to an existing Phonebook entry.
-Save to Archive: save the message to the
Archive message folder.
Multimedia messages
-Retrieve: (for MMS notification) retrieve the
message from the server.
-Reply: send a reply to the sender.
-Forward: forward the message to other people.
-Delete: delete the message.
-Extract details: extract URLs, email addresses, or
phone numbers from the message.
-Extract media: save media content from the
message in your phone’s memory.
Configuration messages
-Install: apply the configuration specified in the
message to your phone.
-Delete: delete the message.
Push messages
-Go to URL: connect to the URL specified in the
message.
-Delete: delete the message.
-Extract details: extract URLs, email addresses, or
phone numbers from the message.
Broadcast messages
-Save: save the message to the phone’s memory.
-Extract details: extract URLs, email addresses, or
phone numbers from the message.
-Delete: delete the message.
Delivery report
-Extract address: extract URLs, email addresses,
or phone numbers from the report.
-Delete: delete the report.
>> Messages
26
Email box
(Menu 1.3)
Use this menu to access emails that you have
received.
To view an email
> Select an email account.
>Press OK when Check for new email displays,
or press More and select Check for new email.
The phone checks for new emails and
downloads received emails.
The following icons may appear on the list to
show the email status:
- : Retrieved from the server
- : Being retrieved
- : Failed to be retrieved
Note!
A
! icon next to a message means that a
message is of high priority. A grey-coloured
message icon is of low priority.
> Scroll to an email or header and press SEND.
> If the email has more than one page, turn the
wheel clockwise or counterclockwise to scroll
through pages one by one.
> Select an attached file to view or play it.
To use email options
While viewing the email or header, press OK to
access the following options:
-Reply: send a reply message.
-Forward: forward the email to other people.
-Retrieve: (for headers) retrieve the body of the
email from the email server.
-Delete: delete the selected email.
-Delete all: delete all emails.
-Add to filtering list: add the sender’s email
address or subject to the Block list to reject emails
from that address or containing that subject.
-Extract details: extract URLs, email addresses, or
phone numbers from the message.
-Extract media: save media content from the
message in your phone’s memory.
-Details: access the email properties.
Drafts
(Menu 1.4)
Use this menu to access messages that you have
saved to send at a later time.
Select a message from the list. The message opens
in Edit mode.
Outbox
(Menu 1.4)
Use this menu to access messages that the phone is
attempting to send or has failed to send.
While viewing a message, press More to access the
following options:
-Send again: resend the message.
-Edit: edit and send the message.
-Delete: delete the selected message.
-Save to Archive: save the message to the
Archive message folder.
27
Sent
(Menu 1.5)
Use this menu to access messages that you have
sent successfully.
While viewing a message, press More to access the
following options:
-Forward: forward the message to other people.
-Delete: delete the selected message.
-Save to Archive: save the message to the
Archive message folder.
Templates
(Menu 1.6)
Use this menu to make and use templates of
frequently used messages or passages.
To create a template
> Select Create.
> Enter a message.
>Press More and select Save template.
To use template options
From the template list, press More to access the
following options:
-Edit: edit the selected template.
-Send message: send a new text message using
the template.
-Create new: create a new template.
-Delete: delete the selected template.
-Delete all: delete all templates.
Archive messages
(Menu 1.7)
This message folder stores text messages that you
do not want them to be deleted. You can move
messages to this folder by using the Save to
Archive option from the other message folders.
From the message list, press More to access the
following options:
-View: open the message.
-Edit: edit and send the message.
-Send: send a new text message.
-Reply: send a reply to the sender.
-Forward: forward the email to other people.
-Delete: delete the message.
-Delete all: delete all messages.
-Add to new contact: save the sender’s number
in the Phonebook.
-Add to existing contact: add the sender’s
number to an existing Phonebook entry.
>> Messages
28
Settings
(Menu 1.8)
Use this menu to select various options for using
the messaging services.
Text message
(Menu 1.8.1)
You can change default SMS settings.
-Settings x (where x is the setting group number):
set the properties of each profile. Press More and
select Edit to access the following options.
Center address: store or change the number of
your SMS server.
Expiration: set the length of time your messages
are stored in the SMS server.
Default type: set the default message type. The
network can convert messages into the selected
format.
Name: enter a profile name.
-Sending options: set the following options for
sending a text message:
Reply path: allow the recipient to reply to you
through your message server.
Delivery report: set the network to inform you
when your message has been delivered.
Network selection: select either CS only (GSM)
or PS preferred (GPRS), depending on your
network.
Keep a copy: leave copies of your messages in
the Sent folder after sending.
Character support: select a character encoding
type. When you select Automatic, the phone
switches the encoding type from GSM-alphabet
to Unicode if you enter a Unicode character.
Using Unicode encoding will reduce the
maximum number of characters in a message to
about half. If this menu is not shown, your phone
provides automatic character encoding by
default.
Multimedia message
(Menu 1.8.2)
You can change default MMS settings.
-Sending options: set up the following options
for sending a multimedia message:
Priority: set the priority level of your messages.
Validity period: set the length of time your
messages are stored in the MMS server.
Delivery time: set a time delay before messages
are sent.
Hide address: set your address to be hidden
from the recipient’s phone.
Delivery report: set the network to inform you
when your message has been delivered.
Read report: determine whether or not your
phone sends a read-reply request.
Keep a copy: leave copies of your messages in
the Sent folder after sending.
-Receiving options: set up the following options
for receiving a multimedia message:
Home network: determine if your phone
retrieves new messages automatically when you
are in your home service area.
Roaming network: determine if your phone
retrieves new messages automatically when you
are roaming in another network.
Reception within your home network or abroad
has the following options:
-Autodownload: the phone automatically
retrieves messages from the server.
-Restricted: the phone receives notifications
first from the server. When you attempt to
retrieve new messages, the phone informs you
of additional charges.
-Manual: the phone displays notifications. Use
the Retrieve option to manually retrieve new
messages.
Delivery report: set the network to inform the
sender when a new message has been delivered.
Read report: determine whether or not your
phone sends a read-reply.
Anonymous: reject messages from unknown
senders.
-MMS profiles: select a connection profile to be
used for MMS.
Note!
You can edit a profile using the
Connection
settings
menu.
p. 48
-Message class: set up the options for creating
MMS messages:
Message class: select the type of message
content you will add or the message size.
-Text: you can add only text of up to 30 KB.
-Image basic: you can add any type of item,
except for video, of up to 30 KB.
-Image rich: you can add any type of item,
except for video, of up to 100 KB.
-Video basic: you can add any type of item of
up to 100 KB.
-Video rich: you can add any type of items of
up to 300 KB.
Creation mode: select an MMS creation mode:
-Free: you can create a message with any type
of content and of any size.
-Restricted: you can create a message with the
specified type of content and the size specified
by default.
-Warning: you can create a message with any
type of content and of any size, but the phone
will inform you when the content and size
exceed the maximum.
Email
(Menu 1.8.3)
You can configure default email settings.
Note!
You cannot change email profile settings while an
email is being sent or retrieved.
-Sending options: set up the following options
for sending an email:
From: set the sender name.
Sending account: select the default email
account.
Priority: select the priority level of emails.
Keep a copy: send copies of your emails to your
email account.
Send confirmation: set the network to inform
you when your emails are delivered.
Read reply: send a read-reply request along with
your emails.
Add my namecard: allow your contact
information to be attached to emails. You must
create a name card.
p. 38
Add my signature: attach your name, phone
number, or a memo to your email.
-Receiving options: set up the following options
for receiving an email:
Retrieving option: set whether the phone
downloads the entire email or only the headers.
Reject if over: determine the maximum size for
incoming emails.
Check interval: determine how often the phone
checks the server for incoming emails. If this
option is set to Do not use, you can use the
Check for new email option to check your
email manually.
Read reply: determine whether or not your
phone sends a read-reply. When this option is set
to On, the phone prompts you to send a read-
reply to the sender.
Block address: specify email addresses to be
rejected, and activate or deactivate mail blocking.
Block subject: specify subjects to be rejected,
and activate or deactivate mail blocking.
29
-Email profiles: select a connection profile to be
used for email services.
Note!
You can edit a profile using the
Connection
settings
menu.
p. 48
-Email accounts: select an account to be used or
set up an email account. Press More and select
Edit to access the following properties for each
account:
Account name: enter a name for the currently
selected account.
SMTP server: enter the IP address or host name
of the outgoing email server.
SMTP port: enter the SMTP port number.
Use SSL: activate the use of the SSL (Secured
Sockets Layer) protocol.
Retrieve server type: select the protocol for the
incoming email server. The remaining options
depend on the protocol type setting.
Retrieve server: enter the IP address or host
name of the POP3 or IMAP4 server.
Retrieve port: enter the POP3 or IMAP4 port
number.
Use SSL: activate the use of the SSL (Secured
Sockets Layer) protocol.
Retrieving option without attachment:
(IMAP4 protocol only) set whether the phone
retrieves messages with attachments or not.
Retrieve count: (IMAP4 protocol only) set the
number of email headers the phone retrieves
from the server at any one time.
Leave a copy of messages on the server: leave
copies of emails on the email server after
retrieving.
My address: set your email address.
User name: enter the POP3 or IMAP4 user
name.
Password: enter the POP3 or IMAP4 password.
POP3/IMAP4 before SMTP: connect to the
POP3 or IMAP4 server for authentication before
connecting to the SMTP server to send e-mails.
Use SMTP authentication: enable SMTP
authentication, which requires the user to log in
before sending emails.
Push message
(Menu 1.8.4)
You can change the settings for receiving push
messages from the wireless web server.
-Receive: set how your phone receives push
messages.
-Service center: enter the address of the server
from which you want to receive push messages,
when the Receive option is set to Optional.
Broadcast
(Menu 1.8.5)
You can change the settings for receiving broadcast
messages.
-Receive: select the reception of broadcast
messages.
-Channel list: indicate the channels from which
you wish to receive broadcast messages. Please
contact your service provider for further details.
-Language: select the preferred languages in
which broadcast messages display.
Memory status
(Menu 1.9)
Use this menu to view the maximum memory and
available memory for each message type.
30 Browser
Home
(Menu 2.1)
Use this menu to connect your phone to the
network and load the homepage of the wireless
web service provider.
To navigate the web
- To scroll though browser items, move the wheel
clockwise or counterclockwise.
- To select a browser item, press OK.
- To return to the previous page, press BACK.
- To close the browser, press END.
To use browser options
From any web page, press More to access the
following options:
-Open: access the linked web page.
-Forward: move forward one page (if available in
browser history).
-Back: move backward one page (if available in
browser history).
-Reload: reload the current page with updated
information.
-Page size: change the browser display font.
-Home: return to the homepage.
-Add to bookmarks: add a new bookmark for
the current web page.
-View bookmarks: display the bookmark list.
-Enter URL: enter a URL address manually.
-Send URL via text message: Send the URL
address of the current web page via SMS.
-Save: save a selected image or the current web
page.
-Saved pages: access the list of pages you have
saved while online.
-History: access the list of pages you have
accessed recently.
-Advanced: change the browser display settings.
-Details: access details for the current web page.
Enter URL
(Menu 2.2)
Use this menu to manually enter the URL address of
a website and access the website.
The WAP (Wireless Application Protocol)
browser on your phone allows you to
access the wireless web. Using the web
browser, you can access and download
up-to-date information and a wide
variety of media content.
To access this menu, press OK in Idle
mode and select Browser.
31
Bookmarks
(Menu 2.3)
Use this menu to save URL addresses in order to
access websites quickly.
To add a bookmark
> Select Create, or press More and select Create.
> Select Title.
> Enter a name for the bookmark.
> Press More and select Done.
> Select URL.
> Enter a URL address, and press More and select
Done.
> Press More and select Save.
To access a bookmarked page
Scroll to a bookmark item and press OK, or press
More and select Open.
To use bookmark options
After saving an item, press More to access the
following options:
-Open: access the bookmarked website.
-Edit bookmark: edit the URL address and name
of the bookmark.
-Create: add a new bookmark.
-Send URL via text message: send the selected
bookmark via SMS.
-Delete: delete the selected bookmark.
-Delete all: delete all bookmarks.
-Details: access details for the selected
bookmark.
Saved pages
(Menu 2.4)
Use this menu to access the list of pages you have
saved while online.
Select a page name from the list to view the
corresponding web page offline.
From the saved page list, press More to access the
following options:
-View: access the selected web page.
-Rename: change the name for the selected web
page.
-Delete: delete the selected web page.
-Delete all: delete all web pages.
History
(Menu 2.5)
Use this menu to access the list of pages you have
accessed recently.
Select a page from the list to access the
corresponding web page.
From the history list, press More to access the
following options:
-Open: access the selected web page.
-Delete: delete the selected web page.
-Delete all: delete all web pages.
>> Browser
32
Advanced
(Menu 2.6)
Use this menu to clear the cache or delete cookies
or to change the browser display settings.
-Clear cache: clear the cache. The cache is a
temporary memory site that stores recently
accessed web pages.
-Delete cookies: delete cookies. Cookies are
pieces of personal information sent to a web
server while navigating the web.
-Cookie options: set whether or not cookies are
stored. If you select Prompt, the phone will ask
you to save the cookies of the current page.
-Preferences: change the browser display and
sound settings.
-About browser: access version and copyright
information about the browser.
Connection profiles
(Menu 2.7)
Use this menu to select or edit a connection profile
for accessing the wireless web.
Note!
You can create or edit a profile using the
Connection settings
menu.
p. 48
33
Organiser
Calendar
(Menu 3.1)
Use this menu to keep track of your schedule.
To select a day on the calendar
When you select Calendar, the calendar is
displayed with today’s date highlighted.
Turn the wheel clockwise or counterclockwise to
move by day.
To enter an appointment
> Select a date on the calendar.
> Select Create → Appointments.
> Enter information or change the settings:
-Title: enter the title of the appointment.
-Details: enter information about the
appointment.
-Location: enter information about the location
of the appointment.
-Start date and Start time: enter the starting
date and time.
-End date and End time: enter the ending
date and time.
-Alarm: select how long before the
appointment the alarm is to alert you. If you do
not want an alarm for the appointment, select
Off.
-Repeat: set the appointment to recur. If you
do not want the appointment to recur, select
Off.
-Expiry: change the expiry setting.
>Press More and select Save appointment to
save the appointment.
To enter an anniversary
> Select a date on the calendar.
>Select Create → Anniversaries.
> Enter information or change the settings:
-Occasion: enter information about the
anniversary.
-Date: enter the date.
-Alarm: select how long before the anniversary
the alarm is to alert you. If you do not want an
alarm for the anniversary, select Off.
-Alarm time: enter the time for the alarm to
sound.
-Repeat every year: set the phone to remind
you of the anniversary every year.
>Press More and select Save anniversary to save
the anniversary.
To view an item
> Select a date on the calendar to display the items
for the day.
> Select an item to view its details.
While viewing an items, press More to access the
following options:
-Edit: edit the item.
-Send via: send the item via MMS, email, or
Bluetooth.
-Delete: delete an item.
The Organiser feature enables you to
keep track of your schedule and tasks, to
view alarms you have recently missed,
and to make memos.
To access this menu, press OK in Idle
mode and select Organiser.
>> Organiser
34
To use calendar options
On the calendar, press More to access the
following options:
-View: open the selected item.
-Create: add a new item.
-Week view: switch to the week view screen.
-Day view: switch to the day view screen.
-Go to date: go to the specific date you entered.
-Event list: sort items by type of item.
-Delete: delete all items stored on the selected
date.
-Delete month: delete all items stored on the
selected month.
-Delete range: delete items for a specific period.
-Memory status: check memory information for
the calendar.
To view items in a different mode
By default, the calendar appears in Month view.
You can change the calendar display to Day view or
Week view. Press More and select Week view or
Day view.
Day view
You can view items scheduled for the selected date.
Select an item to view its details.
Week view
Use this menu to view items for the selected week.
The light grey cells on the timetable indicate items
scheduled for the week. Select the date that
contains the item you want.
Appointment
(Menu 3.2)
This menu displays appointments you have created
on the calendar.
Anniversary
(Menu 3.3)
Use this menu to view anniversaries you have
created on the calendar. If you have set the Alarm
option, the xx icon appears.
Missed alarm events
(Menu 3.4)
When you are unable to acknowledge an alarm for
a scheduled item, the phone stores a missed event
alarm until you confirm it.
35
Library
Images
(Menu 4.1)
Use this menu to access images you have
downloaded or received in messages.
To view an image
> Select an image folder.
>Select the image you want.
> Turn the wheel clockwise or counterclockwise to
view other images.
To view a slide show
You can view your photos as a slide show, a
sequential presentation of each photo in the
current folder.
> Select an image folder.
>Press More and select Slide show. The slide
show begins.
>Press BACK to stop the slide show.
To use image options
While viewing an image, press More to access the
following options:
-View: open the selected image.
-Send via: send the file via MMS or email.
-Set as caller ID: set the image as a caller ID
image for a Phonebook entry.
-Delete: delete the file.
-Delete all: delete all files.
-Move: move the file to another image folder.
-Rename: change the file name.
-Slide show: view all images in the current folder
as a slide show.
-Protect file or Protect file: lock the file to
prevent it from being deleted, and renamed, or
unlock the file.
-Details: view the file properties.
Sounds
(Menu 4.2)
Use this menu to access voice memos you have
recorded and sounds you have downloaded or
received in messages.
To play a sound
> Select a sound folder.
> Scroll to the sound you want.
>Press More and select Play.
If you are playing a voice memo you have
recorded, see Voice memo.
p. 41
To use sound options
From the sound list, press More to access the
following options:
-Play: play the selected file.
-Play via: play the selected file via the phone
speaker or a Bluetooth stereo headsest.
-Send via: send the file via MMS or email.
-Delete: delete the file.
-Delete all: delete all files.
-Move: move the file to another sound folder.
-Rename: change the file name.
-Protect file or Unprotect file: lock the file to
prevent it from being deleted, and renamed, or
unlock the file.
-Details: view the file properties.
The Library menu allows you to access
images, sounds, and other files in the
phone’s memory.
To access this menu, press OK in Idle
mode and select Library.
>> Library
36
Videos
(Menu 4.3)
Use this menu to access video files you have
downloaded or received in messages.
To play a video file
> Scroll to the video file you want.
>Press More and select Play.
To use video options
From the video file list, press More to access the
following options:
-Play: play the sound file.
-Send via: send the file via MMS or email.
-Delete: delete the file.
-Delete all: delete all files.
-Rename: change the file name.
-Protect file or Unprotect file: lock the file to
prevent it from being deleted, and renamed, or
unlock the file.
-Details: view the file properties.
Other files
(Menu 4.4)
Use this menu to access any other files than image,
video, music, and sound files. Your phone provides
you with Picsel File Viewer to allow you to view
various document files. Available file formats are
doc, xls, ppt, pdf, and txt.
To view a document
Select a file. Picsel File Viewer runs and opens the
document.
To use document options
While viewing a file, press More to access the
following options:
-Zoom: zoom in or out.
-Fit to: fit the document to the page size, screen
width, or screen height.
-Go to: move to another page of the document.
-Rotate: rotate the document.
-Send via: send the file via MMS, email, or
Bluetooth.
-Delete: delete the file.
-Rename: change the file name.
-Protect file or Unprotect file: lock the file to
prevent it from being deleted, and renamed, or
unlock the file.
-Details: view the file properties.
Memory status
(Menu 4.5)
You can check the total amount of memory for
media items and the amount of memory currently
in use.
37
Phonebook
Contact list
(Menu 5.1)
Use this menu to search for contact information in
the Phonebook.
To find a contact
> Scroll to the first character of the name you want
to find and press OK.
> Scroll to the contact.
> To view contact information, press More and
select View.
To dial a number, press SEND or OK. If the
contact has more than one phone number, select
a number.
To use Phonebook options
While viewing contact information, press More to
access the following options:
Note! Depending on the number type you select,
options may vary.
-Edit: edit contact information.
-Call: dial the number.
-Send message via: send an SMS or MMS
message to the selected number.
-Delete: delete the selected contact from the
Phonebook.
-Send business card via: send the contact as a
data format attachment via MMS, email, or
Bluetooth.
-Add to group: add the selected contact to a
group.
-Copy to SIM or Copy to phone: copy the
contact to the phone’s memory or to the SIM
card.
Add new contact
(Menu 5.2)
Use this menu to add new contacts to the
Phonebook.
> Select a memory location.
> Change the settings or enter information about
the contact:
-Name: assign a name.
-Mobile: enter a mobile phone number.
-Home: enter a home phone number.
-Office: enter a work phone number.
-Email: assign an email address.
-Caller ID: assign an image as a caller ID image
to alert you to a call from the person.
-Group: assign the contact to a caller group.
-Date of birth: enter the person’s birthday.
-Address: assign a postal address.
-Note: add a note about the contact.
>Press More and select Save to save the contact.
You can store phone numbers in your
phone’s memory and copy them to the
SIM card. The SIM card and phone’s
memory are physically separated, but
they are used as a single entity called
Phonebook.
To access this menu, press OK in Idle
mode and select Phonebook.
>> Phonebook
38
Groups
(Menu 5.3)
Use this menu to organise your contacts in caller
groups.
To create a new caller group
> Select Create group.
> Enter a name for the group.
>Press More and select Done.
To add members to a caller group
> Select a group.
> Select the contact you want to add to the group.
To use caller group options
From the group list, press More to access the
following options:
-View members: display the members of the
selected group.
-Add member: add members to the selected
group.
-Rename group: change the name of the group.
-Delete: delete the selected group. Group
members, however, will not be deleted from the
Phonebook.
-Delete all: delete all groups.
-Create group: add a new group.
My business card
(Menu 5.3)
Use this menu to create your name card and send it
to other people.
To save your name card
The procedure for creating your name card is the
same as the one for saving a number in the phone’s
memory.
p. 37
To use name card options
After saving your name card, press More to access
the following options:
-Send business card via: send the name card as a
data format attachment via MMS, email, or
Bluetooth.
-Send this number via: send the selected
number via SMS, MMS, or email.
-Edit: edit the name card.
-Remove business card: delete the name card.
Own number
(Menu 5.4)
Use this feature to check your phone numbers, or
to assign a name to each of the numbers. Changes
made here do not affect the actual subscriber
numbers on your SIM card.
Copy all to SIM
(Menu 5.5)
Use this menu to copy all of the contacts in the
phone’s memory to the SIM card.
Contacts will be displayed twice in your Phonebook
list. If necessary, you can delete the contacts in your
phone’s memory to avoid any confusion.
Copy all from SIM
(Menu 5.6)
Use this menu to copy all of the contacts on the
SIM card to the phone’s memory.
Delete all
(Menu 5.7)
Use this menu to delete all of the contacts in your
phone’s memory and on the SIM card.
Settings
(Menu 5.8)
Use this menu to change the default settings for
the phonebook.
-Searching mode: change the sort order of the
contact list.
-Default contacts view: set the memory location
from which the phonebook show entries.
Memory status
(Menu 5.9)
Use this menu to display the number of contacts
you have stored in the Phonebook.
39
Call log
Recent calls
(Menu 6.1)
This menu displays the most recent calls dialled,
received, or missed.
To access a call log
> Turn the wheel clockwise or counterclockwise to
scroll through the call log list.
> To view the details of a call, press More and
select Details.
To dial a number, press SEND.
To use call log options
From the call log list, press More to access the
following options:
-Details: view the details of a call.
-Call: dial the number.
-Send message via: send a text or multimedia
message to the selected number.
-Use number: use the number for editing and
saving it.
-Add to new contact: save the number in the
Phonebook.
-Add to existing contact: add the number to an
existing Phonebook entry.
-Remove: delete the call log.
-Remove all: delete all of the call logs.
Missed calls
(Menu 6.2)
This menu displays the most recent calls you have
received but not answered.
Dialled calls
(Menu 6.3)
This menu displays the most recent calls you have
dialled.
Received calls
(Menu 6.4)
This menu displays the most recent calls you have
received.
Remove all
(Menu 6.5)
Use this menu to delete all of the call logs.
Call duration
(Menu 6.6)
This menu displays the time log for calls made and
received. The actual time invoiced by your service
provider will vary.
Note! To reset call time, press More and select
Reset all call durations.
Use this menu to view the calls you have
dialled, received, or missed, and the
length of the calls.
To access this menu, press OK in Idle
mode and select Call log.
40 Applications
Alarm
(Menu 7.1)
Use this menu to set alarms to sound at a specific
time. A wake-up alarm is not affected by your
sound settings.
To set an alarm
> Select Alarm 1.
> Specify the alarm settings:
-Name: enter the alarm name.
-Activation: activate the alarm using the
wheel.
-Time: enter the time for the alarm to sound
using the wheel.
-Repeat: select a repeat option.
-Alarm notification: select an alarm ringtone.
-Auto power-up: set the phone to switch on
and sound the alarm when it is time for the
alarm.
>Press More and select Save.
To stop an alarm
When the alarm sounds, choose either of the
following options to stop the alarm:
- Select Confirm or press any key.
- Select Snooze to pause the alarm for 5 minutes.
You can do this a maximum of 5 times.
To deactivate an alarm
> Select the alarm you want to deactivate.
> Select Off on the Activation line.
>Press More and select Save.
World clock
(Menu 7.2)
Use this menu to find out the current time in
another part of the world.
From the world map, turn the wheel clockwise or
counterclockwise to select the city you want. As the
time line moves, the current time and date of the
selected zone display.
Use this menu to record voice memos, to
set alarms, or to use the phone as a
world clock, calculator, and converter.
You can also synchronise personal data
in the phone’s memory with data stored
on a PC.
To access this menu, press OK in Idle
mode and select Applications.
41
Calculator
(Menu 7.3)
Use this menu to perform basic arithmetic
functions, such as addition, subtraction,
multiplication, and division.
> Enter the first number.
To insert a decimal point, scroll to the decimal
point mark (.) using the wheel and press OK.
> Move the wheel clockwise or counterclockwise
to access the math function you want and press
OK.
> Enter the second number.
> To view the result, press OK when the equal sign
(=) is selected.
> If necessary, repeat from step 2 to continue the
calculation.
Currency converter
(Menu 7.4)
Use this menu to convert currency values.
> Select Unit in the upper line and select the
original unit using the wheel.
> Move down and select the input field.
> Enter the value to be converted and press More
and select Done.
To insert a decimal point, scroll to the decimal
point mark (.) using the wheel and press OK.
> Select Unit in the lower line and select the unit
to which you want to convert.
The equivalent value for the amount you entered
displays.
Note!
You can edit the currency rate by pressing and
selecting
Set currency rate
.
Voice memo
(Menu 7.5)
Use this menu to record voice memos. A voice
memo can be up to one hour long.
To record and save a voice memo
>Press OK, or press More and select Start
recording to start recording.
> Speak into the microphone.
To pause recording, press More and select
Pause recording.
To resume recording, press More and select
Resume recording.
> When you have finished, press OK, or More and
select Stop recording. The voice memo is saved
automatically.
To play a voice memo
> From the voice memo screen, press More and
select Go to voice memos.
> Select a voice memo. The voice memo plays.
During playback,
- To adjust the volume, move the wheel clockwise
or counterclockwise.
- To pause playback, press OK. To resume
playback, press OK again.
- To stop playback, press More and select Stop.
>> Applications
42
To use voice memo options
From the voice memo list, press More to access the
following options:
-Play: play the voice memo.
-Send via: send the file via MMS or email.
-Delete: delete the file.
-Delete all: delete all files.
-Move: move the file to another folder.
-Rename: change the file name.
-Protect file or Unprotect file: lock the file to
prevent it from being deleted and renamed.
-Details: view the file properties.
To change voice memo settings
You can select a recording time before starting
recording.
From the Voice memo screen, press More and
select Settings to access the following options:
-Maximum (60 minutes): record a voice memo
up to one hour long.
-Suitable for messages: record a voice memo for
adding to a multimedia message.
-Suitable for email: record a voice memo for
adding to an email.
Memo
(Menu 7.6)
Use this menu to make memos for things that are
important and manage them.
To enter a memo
> Select Create.
>Enter a memo.
>Press More and select Done to save the memo.
To use memo options
From the memo list, press More to access the
following options:
-View: view the memo details.
-Create: create a new memo.
-Send via: send the memo via MMS, email, or
Bluetooth.
-Delete: delete the selected memo.
-Delete all: delete all memos.
-Memory status: check how many memos you
have created.
To do
(Menu 7.7)
Use this menu to create and manage tasks you
have created.
To enter a task
> Select Create, or press More and select Create.
> Enter information or change the settings:
-Title: enter information about the task.
-Date: enter the date.
-Due date: enter the date when the task is due.
-Priority: select a priority level.
> Press More and select Save to save the task.
The icon indicates that the task priority is high.
A check mark appears in the status check box if the
task has been completed. To change the task
status, on the task list, press More and select Mark
as done or Mark as not done.
To use task options
From the task list, press More to access the
following options:
-View: view the task details.
-Mark as done or Mark as not done: change
the task status.
-Create: create a new task.
-Send via: send the task via MMS, email, or
Bluetooth.
-Delete: delete the selected task.
-Delete all: delete all tasks.
-Memory status: check how many tasks you have
created.
43
Media player
(Menu 7.8)
You can play video files stored in your phone’s
memory using the media player.
To save video files in the phone
You can play mp4, 3gp, and WMV files on your
phone. Use the following methods to save video
files to your phone’s memory:
- Download from the web browser.
p. 30
- Download from a PC using the optional Samsung
PC Studio. See Samsung PC studio User’s Guide.
- Receive via an active Bluetooth connection.
p. 46
- Synchronise with Windows Media player.
p. 20
Downloaded or received files are stored in the
Videos folder in Library.
To play a video file
> Select the Videos folder.
> Scroll to the file you want to play. The media
player opens.
Use the following functions during playback:
- To pause or resume playback, press OK.
- To move backward in a file, tap and hold the left
arrow on the display.
- To move forward in a file, tap and hold the right
arrow on the display.
- To adjust the volume, use the wheel.
To use media player options
From the media player screen, press More to access
the following options:
-Play or Pause: begin or pause playback.
-Stop: stop playback.
-Send via: send the current file via MMS, email,
or Bluetooth.
-Delete: delete the file.
44 Settings
Time & date
(Menu 8.1)
Use this menu to change the time and date settings
for your phone.
-Time: enter the current time using the wheel.
-Date: enter the current date using the wheel.
-Time zone: set the home time zone. Select the
city that corresponds to your home zone.
-Time format: select 12-hour or 24-hour time
format using the wheel.
-Daylight saving: apply daylight saving time.
Phone settings
(Menu 8.2)
Many different features of your phone’s system can
be customised to suit your preferences.
Language
(Menu 8.2.1)
Use this menu to select a language for the display
text.
Transfer mode
(Menu 8.2.2)
Use this menu to select a USB mode that will be
used when you connect your phone to a PC via USB
interface.
-PC Studio: you can use the Samsung PC Studio
programme to synchronise data and transfer
media files between the phone and a PC.
-MTP: you can use Media transfer mode to
transfer WMDRM (Windows Media Digital Rights
Management) content with licence keys directly
from the Windows Media Player 10 or later to
the phone. You can also get new licence keys for
the DRM files that have expired licence keys.
-Mass storage: you can connect the phone to a
PC, as you would use an external memory disk
drive.
Auto redial
(Menu 8.2.3)
Use this menu to set up the phone to redial a
phone number after an unsuccessful call. Ten
attempts can be preset.
Auto keylock
(Menu 8.2.4)
Use this menu set the phone to lock the keys
automatically after display turns off.
Use this menu to customise your phone
settings. You can also reset the settings
to their default values.
To access this menu, press OK in Idle
mode and select Settings.
45
Display settings
(Menu 8.3)
Use this menu to change settings for the display
and backlight.
Idle display
(Menu 8.3.1)
Use this menu to select a display item for the Idle
screen.
Brightness
(Menu 8.3.2)
Use this menu to adjust the brightness of the
display for varying lighting conditions.
Backlight
(Menu 8.3.3)
Use this menu to select the length of time the
backlight of the display stays on.
Dim
(Menu 8.3.4)
Use this menu to select the length of time the
display is in Dim mode after the backlight turns off.
After a specified time has elapsed, the display turns
off.
Sound settings
(Menu 8.4)
Use this menu to customise sound settings to suit
your preferences.
-Ringtone: select a ringtone for the call ringer.
-Ring volume: select a ringtone volume.
-Ringtone type: specify how you are to be
informed of incoming calls.
Melody: the phone rings using the selected
ringtone.
Vibration: the phone vibrates but does not
ring.
Vibration & melody: the phone vibrates and
rings at the same time.
Mute: the phone mutes the call ringer.
-Message tone: select a ringtone for incoming
messages.
-Message volume: select a ringtone volume for
incoming messages.
-Message alert type: specify how you are to be
informed of incoming messages.
-Alerts on call: set the phone to beep when you
receive a new message, or when an alarm is
triggered during a call.
-Quiet mode: specify how the phone alerts you
to a specific event in Quiet mode.
Network services
(Menu 8.5)
Use this menu to access network services. Please
contact your service provider to check their
availability.
Call diverting
(Menu 8.5.1)
This network service reroutes incoming calls to a
phone number that you specify.
> Select the type of calls to be diverted.
> Select a call diverting option:
-Always divert: divert all calls.
-When busy: divert calls when you are busy
with another call.
- When no reply: divert calls when you do not
answer the phone.
-When unreachable: divert calls when you are
not in an area covered by your service provider
or when your phone is switched off.
-Cancel all: cancel all call diverting options.
> Select On the upper line. To deactivate call
diverting, select Off.
>Select the Diverts to line.
> Enter the number to which calls are to be
diverted, and press More and select Done.
> If you selected When no reply, move to the
Waiting time line and select the amount of
time the network waits before diverting a call.
>> Settings
46
Call barring
(Menu 8.5.2)
This network service allows you to restrict your
calls.
> Select the type of calls to be barred.
> Select a call barring option:
-All outgoing calls: prohibit outgoing calls.
-Outgoing int’l calls: prohibit international
calls.
-Int’l call exc. Home: only allow calls to
numbers within the current country when you
are abroad, and to your home country.
-All incoming calls: prohibit incoming calls.
-Incoming while roaming: prohibit incoming
calls when you use your phone outside of your
home service area.
-Cancel all: cancel all call barring settings.
> Select On the upper line. To deactivate call
barring, select Off.
> Select the Password line.
> Enter the call barring password supplied by your
service provider, and press More and select
Done.
Call waiting
(Menu 8.5.3)
This network service informs you when someone is
trying to reach you while you have another call.
> Select the type of calls to which the call waiting
option will apply.
> Select On. To deactivate call waiting, select Off.
Network selection
(Menu 8.5.4)
This network service allows you to manually select
the network to be used while roaming outside of
your home area, or to let the network be chosen
automatically.
You can select a network other than your home
network only if there is a valid roaming agreement
between the two.
Caller ID
(Menu 8.5.5)
This network service allows you to prevent your
phone number from being displayed on the phone
of the person being called. If you select Network
default, the phone will use the default setting
provided by the network.
Note! Some networks do not allow the user to
change this setting.
Voicemail
(Menu 8.5.6)
Use this menu to store or change the number of
the voicemail server.
Note!
You must enter the voicemail
server
number
before you can access your voicemails.
Your service
provider
can give the voicemail
server
number.
Band selection
(Menu 8.5.7)
For the phone to make and receive phone calls, it
must register with an available network. Your
phone can handle any of the following types of
networks: GSM 1900, Combined GSM 900 or
1800, and UMTS.
The country where you purchased your phone
determines the default band that it uses. When you
travel abroad, you must remember to change to an
appropriate band.
Bluetooth
(Menu 8.6)
Using the Bluetooth feature, you can connect the
phone wirelessly to other Bluetooth devices and
exchange data with them, talk hands-free, or
control the phone remotely.
Bluetooth technology allows free wireless
connection between all Bluetooth-compliant
devices within a range of 10 meters. Since the
devices communicate using radio waves, they do
not need to be in line of sight to each other.
Notes!:
- If there are obstacles between the devices, the
operating distance may be reduced.
- It is recommended that you do not use the
Bluetooth feature while using multimedia
features such as voice recorder and camera, or
vice versa.
- Some devices, especially those that are not tested
or approved by Bluetooth SIG, may be
incompatible with your phone.
To set up the Bluetooth feature
The Bluetooth menu provides the following
options:
-Turn on or Turn off: activate or deactivate the
Bluetooth feature.
-My devices: search for connectable Bluetooth
devices.
-My phone’s visibility: allow other Bluetooth
devices to search for your phone.
-My phone’s name: assign a Bluetooth device
name to your phone, which is then displayed on
other devices.
-Secure mode: determine if the phone asks for
your confirmation when other devices access
your data.
-Bluetooth services: display available Bluetooth
services.
47
To search for and pairing with a
Bluetooth device
>From the Bluetooth menu, select My devices.
> Select New search.
After searching, a list of devices to which you
can connect displays. The following icons
indicate the type of device:
The colour of the icon indicates the status of the
device:
- Grey for unpaired devices.
- Blue for paired devices.
- Red for devices that are currently connected to
your phone.
> Select a device.
> Enter a Bluetooth pincode and select Done.
This
code is used just once and you do not need to
memorise it.
When the owner of the other device enters the
same code, pairing is complete.
Note!
Some devices, especially headsets or hands-free
car kits, may have a fixed Bluetooth
pincode
, such as
0000
. If the other device has a code, you must enter it.
To use device options
From the paired device list, scroll to a device you
want and press More to access the following
options:
-Connect: connect to the headset or hands-free
car kit.
-Disconnect: end the connection with the
connected device.
-Browse files: search for data from the device
and import data directly to your phone.
-Service list: display the Bluetooth service list for
the selected device.
-Rename: change the name of the device.
-Authorise device or Unauthorise device:
determine whether or not the phone asks you to
permit connection when other devices try to
connect to your phone.
-Delete: remove the selected device from the
device list.
-Delete all: remove all devices from the device
list.
To send data via Bluetooth
> Activate the Bluetooth feature.
> Select an application, such as Phonebook,
Library, Organiser, Memo, or To do, in which
the item you want to send is stored.
> Scroll to the item you want.
>Press More and select Send via, Send business
card via, or Send this business card →
Bluetooth.
> For sending a contact, select which data you
want to send.
> Select a device.
> If necessary, enter the Bluetooth pincode needed
for pairing and select Done.
To receive data via Bluetooth
To receive data via Bluetooth, your phone’s
Bluetooth feature must be active and its visibility
must be enabled.
> If an unauthorised Bluetooth device sends data
to your phone, select Yes to allow the device to
access your phone.
> Select Yes to receive data.
Security
(Menu 8.7)
Use this menu to protect the phone against
unauthorised use.
Note!
If you enter an incorrect PIN /PIN2 three times, the
SIM card is blocked. To unblock it, you need to enter your
PUK/PUK2 (Personal Unblocking Key). The codes are
supplied by your network operator.
PIN check
(Menu 8.7.1)
The 4- to 8-digit PIN (Personal Identification
Number) protects your SIM card against
unauthorised use. When this feature is enabled, the
phone requires your PIN each time it is switched on.
Change PIN
(Menu 8.7.2)
Use this menu to change your pincode. The
pincode check feature must be enabled to use this
feature.
Phone lock
(Menu 8.7.3)
This feature locks the phone from unauthorised
use.
When this feature is enabled, you must enter a 4-
to 8-digit phone password each time the phone is
switched on.
Note! The password is preset to 00000000. To
change the password, use the Change password
menu.
Change password
(Menu 8.7.4)
Use this menu to change your phone password.
Privacy
(Menu 8.7.5)
Use this menu to lock all menu options on the
phone, except call functions.
When this feature is enabled, you must enter the
phone password to access menu functions.
SIM lock
(Menu 8.7.6)
The SIM lock feature allows your phone to work
only with the current SIM by assigning a SIM lock
code. You must enter the SIM lock code to use a
different SIM card.
- Mobile phone
- Computer
- Headset or hands-free car kit
- PDA
- Printer
- Unknown device
>> Settings
48
Connection settings
(Menu 8.8)
Use this menu to create and customise the profiles
containing the settings for connecting your phone
to the network. You need these settings to use the
web browser or send MMS messages or emails.
Note!
Your phone is set up by default for connecting to
the network. If you change the settings without first
checking with your service provider, the web browser,
MMS, and email features may not work properly.
To create a profile
>Select Create. If a profile has previously been
saved, press More and select New connection.
> Set profile parameters:
-Set name: enter a name for the profile.
-Access name: edit the access point name used
for the address of the GPRS network gateway.
-Auth type: choose the type of authentication
used.
-User ID: enter the user ID.
-Password: enter the user password.
-Protocol: select the protocol among HTTP,
WAP, and Other.
-Home URL: enter the URL address of the page
to be used as your homepage.
-Gateway address: (WAP only) enter the
gateway address of the proxy server.
-Proxy address and Port: (HTTP only) set the
proxy server address and port.
-Secure connection: (WAP only) turn the
secure mode on or off.
-Linger time (sec.): set a time period after
which the network is disconnected if there has
been no new data traffic in that time.
-Static IP: specify if you want to manually enter
an IP address; see the Local phone IP option. If
you want the IP address to be automatically
assigned by the server, select Off.
-Local phone IP: enter the IP address obtained
from the service provider, if you selected Static
IP.
-Static DNS: specify if you want to manually
enter the DNS (Domain Name Server) address;
see the Server 1 option. If you want the
address to be automatically assigned by the
server, select Off.
-Server 1: enter the DNS addresses.
-Traffic class: select the traffic class.
>Press More and select Save to save the profile.
To use profile options
Press More to access the following options:
-Edit: edit the profile.
-New connection: add a new profile.
-Delete: delete the selected profile.
-Delete all: delete all profiles.
DRM key management
(Menu 8.9)
Use this menu to manage the licence keys you have
acquired to activate media files locked by DRM
systems.
Press More to access the following options:
-Play/ view: open the corresponding item.
-Delete: delete the selected licence key.
-Delete all: delete all licence keys.
-Details: access the properties of the licence key.
Memory settings
(Menu 8.10)
Use this menu to check the amount of memory
being used for storing data and clear the memory.
Master reset
(Menu 8.11)
Use this menu to reset all the settings in your phone
at the same time.
> Select Yes.
> Enter the phone password and select Done.
Note!
The password is preset to
00000000
. You can
change this password.
p. 47
The phone automatically switches itself off and
then back on.
49
SIM services
This menu is available if you use a SIM card that
supports SIM Application Toolkit menus and
provides additional services, such as news, weather,
sports, entertainment, and location services.
Available services may vary, depending on your
service provider’s plans.
For details, see your SIM card instructions or
contact your service provider.
To access this menu, press OK in Idle
mode and select SIM services.
50 Solve problems
When you switch on your phone, the following
messages may appear:
“Please insert SIM card”
- Make sure that the SIM card is correctly installed.
“Enter Password”
- The automatic locking function has been
enabled. You must enter the phone’s password
before you can use the phone.
“Enter PIN”
- You are using your phone for the first time. You
must enter the PIN supplied with the SIM card.
- The PIN check feature is enabled. Every time the
phone is switched on, the PIN has to be entered.
To disable this feature, use the PIN check menu.
“Enter PUK”
- The PIN was entered incorrectly three times, and
the SIM card is now blocked. Enter the PUK
supplied by your service provider.
“No service” or “Network failure” displays
- The network connection has been lost. You may
be in a weak signal area. Move and try again.
- You are trying to access an option for which you
have no subscription with your service provider.
Contact the service provider for further details.
You have entered a number but it was not
dialled
- Make sure that you have pressed SEND.
- Make sure that you have accessed the right
cellular network.
- Make sure that you have not set an outgoing call
barring option.
A caller cannot reach you
- Make sure that your phone is switched on. (Press
END for more than one second.)
- Make sure that you are accessing the right
cellular network.
- Make sure that you have not set an incoming call
barring option.
To save the time and expense of an
unnecessary service call, perform the
simple checks in this section before
contacting a service professional.
51
Your voice is not heard at the other end
- Make sure that you have switched on the
mouthpiece.
- Make sure that you are holding the phone close
enough to your mouth. The microphone is
located at the bottom of the phone.
The phone beeps and “Low battery” flashes on
the display
- Your battery is insufficiently charged. Recharge
the battery.
The audio quality of the call is poor
- Check the signal strength indicator on the display
( ). The number of bars indicates the signal
strength from strong ( ) to weak ( ).
- Try moving the phone slightly or moving closer to
a window if you are in a building.
No number is dialled when you re-call a
Phonebook entry
- Use the Contact list menu to ensure the number
has been stored correctly.
- Store the number again, if necessary.
The battery does not charge properly or the
phone sometimes switches itself off
- Wipe the charging contacts both on the phone
and on the battery with a clean soft cloth.
If the above guidelines do not help you to
solve the problem, take note of:
- The model and serial numbers of your phone.
- Your warranty details.
- A clear description of the problem.
Then contact your local retailer.
52 Health and safety information
SAR certification information
Exposure to Radio Frequency (RF)
Signals
Certification Information (SAR)
Your wireless phone is a radio transmitter and
receiver. It is designed and manufactured not
to exceed the exposure limits for radio
frequency (RF) energy set by the Federal
Communications Commission (FCC) of the
U.S. government. These FCC exposure limits
are derived from the recommendations of two
expert organizations, the National Counsel on
Radiation Protection and Measurement
(NCRP) and the Institute of Electrical and
Electronics Engineers (IEEE). In both cases,
the recommendations were developed by
scientific and engineering experts drawn from
industry, government, and academia after
extensive reviews of the scientific literature
related to the biological effects of RF energy.
The exposure limit set by the FCC for wireless
mobile phones employs a unit of
measurement known as the Specific
Absorption Rate (SAR). The SAR is a measure
of the rate of absorption of RF energy by the
human body expressed in units of watts per
kilogram (W/kg). The FCC requires wireless
phones to comply with a safety limit of 1.6
watts per kilogram (1.6 W/kg). The FCC
exposure limit incorporates a substantial
margin of safety to give additional protection
to the public and to account for any variations
in measurements.
SAR tests are conducted using standard
operating positions accepted by the FCC with
the phone transmitting at its highest certified
power level in all tested frequency bands.
Although the SAR is determined at the
highest certified power level, the actual SAR
level of the phone while operating can be well
below the maximum value. This is because
the phone is designed to operate at multiple
power levels so as to use only the power
required to reach the network. In general, the
closer you are to a wireless base station
antenna, the lower the power output.
Before a new model phone is available for
sale to the public, it must be tested and
certified to the FCC that it does not exceed
the exposure limit established by the FCC.
Tests for each model phone are performed in
positions and locations (e.g. at the ear and
worn on the body) as required by the FCC.
The highest SAR values for this model phone
as reported to the FCC are : Mode Head:
0.465W/Kg, Body-worn: 0.582W/Kg.
For body worn operations, this model phone
has been testde and meets the FCC exposure
guidelines when used with a Samsung
accessory designated for this product or when
used with an accessroy that contains no
metal and that positons the handset a
minimum 1.5 cm from the body.
Non-compliance with the above restrictions
may result in violation of FCC RF exposure
guidelines.
SAR information on this and other model
phones can be viewed on-line at
www.fcc.gov/oet/fccid. This site uses the
phone FCC ID number A3LSGHF310.
Sometimes it may be necessary to remove
the battery pack to find the number. Once you
have the FCC ID number for a particular
phone, follow the instructions on the website
and it should provide values for typical or
maximum SAR for a particular phone.
Additional product specific SAR information
can also be obtained at www.fcc.gov/cgb/sar.
53
Consumer Information on Wireless
Phones
The U.S. Food and Drug Administration (FDA)
has published a series of Questions and
Answers for consumers relating to radio
frequency (RF) exposure from wireless
phones. The FDA publication includes the
following information:
What kinds of phones are the subject of
this update?
The term wireless phone refers here to hand-
held wireless phones with built-in antennas,
often called “cell,” “mobile,” or “PCS” phones.
These types of wireless phones can expose
the user to measurable radio frequency
energy (RF) because of the short distance
between the phone and the user's head.
These RF exposures are limited by Federal
Communications Commission safety
guidelines that were developed with the
advice of FDA and other federal health and
safety agencies. When the phone is located at
greater distances from the user, the exposure
to RF is drastically lower because a person's
RF exposure decreases rapidly with increasing
distance from the source. The so-called
“cordless phones,” which have a base unit
connected to the telephone wiring in a house,
typically operate at far lower power levels,
and thus produce RF exposures well within
the FCC's compliance limits.
Do wireless phones pose a health
hazard?
The available scientific evidence does not
show that any health problems are associated
with using wireless phones. There is no proof,
however, that wireless phones are absolutely
safe. Wireless phones emit low levels of radio
frequency energy (RF) in the microwave
range while being used. They also emit very
low levels of RF when in the stand-by mode.
Whereas high levels of RF can produce health
effects (by heating tissue), exposure to low
level RF that does not produce heating effects
causes no known adverse health effects.
Many studies of low level RF exposures have
not found any biological effects. Some studies
have suggested that some biological effects
may occur, but such findings have not been
confirmed by additional research. In some
cases, other researchers have had difficulty in
reproducing those studies, or in determining
the reasons for inconsistent results.
What is FDA's role concerning the
safety of wireless phones?
Under the law, FDA does not review the
safety of radiation-emitting consumer
products such as wireless phones before they
can be sold, as it does with new drugs or
medical devices. However, the agency has
authority to take action if wireless phones are
shown to emit radio frequency energy (RF) at
a level that is hazardous to the user. In such a
case, FDA could require the manufacturers of
wireless phones to notify users of the health
hazard and to repair, replace or recall the
phones so that the hazard no longer exists.
Although the existing scientific data do not
justify FDA regulatory actions, FDA has urged
the wireless phone industry to take a number
of steps, including the following:
• “Support needed research into possible
biological effects of RF of the type emitted
by wireless phones;
• “Design wireless phones in a way that
minimizes any RF exposure to the user
that is not necessary for device function;
and
• “Cooperate in providing users of wireless
phones with the best possible information
on possible effects of wireless phone use
on human health.
FDA belongs to an interagency working group
of the federal agencies that have
responsibility for different aspects of RF
safety to ensure coordinated efforts at the
federal level. The following agencies belong to
this working group:
• “National Institute for Occupational Safety
and Health
• “Environmental Protection Agency
• “Federal Communications Commission
• “Occupational Safety and Health
Administration
• “National Telecommunications and
Information Administration
The National Institutes of Health participates
in some interagency working group activities,
as well.
FDA shares regulatory responsibilities for
wireless phones with the Federal
Communications Commission (FCC). All
phones that are sold in the United States
must comply with FCC safety guidelines that
limit RF exposure. FCC relies on FDA and
other health agencies for safety questions
about wireless phones.
FCC also regulates the base stations that the
wireless phone networks rely upon. While
these base stations operate at higher power
than do the wireless phones themselves, the
RF exposures that people get from these base
stations are typically thousands of times
lower than those they can get from wireless
phones. Base stations are thus not the
primary subject of the safety questions
discussed in this document.
What are the results of the research
done already?
The research done thus far has produced
conflicting results, and many studies have
suffered from flaws in their research
methods. Animal experiments investigating
the effects of radio frequency energy (RF)
exposures characteristic of wireless phones
have yielded conflicting results that often
cannot be repeated in other laboratories. A
few animal studies, however, have suggested
that low levels of RF could accelerate the
development of cancer in laboratory animals.
However, many of the studies that showed
increased tumor development used animals
that had been genetically engineered or
treated with cancer-causing chemicals so as
to be pre-disposed to develop cancer in
absence of RF exposure. Other studies
exposed the animals to RF for up to 22 hours
per day. These conditions are not similar to
the conditions under which people use
wireless phones, so we don't know with
certainty what the results of such studies
mean for human health.
Three large epidemiology studies have been
published since December 2000. Between
them, the studies investigated any possible
association between the use of wireless
phones and primary brain cancer, glioma,
meningioma, or acoustic neuroma, tumors of
the brain or salivary gland, leukemia, or other
cancers. None of the studies demonstrated
the existence of any harmful health effects
from wireless phones RF exposures. However,
none of the studies can answer questions
about long-term exposures, since the average
period of phone use in these studies was
around three years.
What research is needed to decide
whether RF exposure from wireless
phones poses a health risk?
A combination of laboratory studies and
epidemiological studies of people actually
using wireless phones would provide some of
the data that are needed. Lifetime animal
exposure studies could be completed in a few
years. However, very large numbers of
animals would be needed to provide reliable
proof of a cancer promoting effect if one
exists. Epidemiological studies can provide
data that is directly applicable to human
populations, but ten or more years' follow-up
may be needed to provide answers about
some health effects, such as cancer. This is
because the interval between the time of
exposure to a cancer-causing agent and the
time tumors develop - if they do - may be
many, many years. The interpretation of
epidemiological studies is hampered by
difficulties in measuring actual RF exposure
during day-to-day use of wireless phones.
Many factors affect this measurement, such
as the angle at which the phone is held, or
which model of phone is used.
What is FDA doing to find out more
about the possible health effects of
wireless phone RF?
FDA is working with the U.S. National
Toxicology Program and with groups of
investigators around the world to ensure that
>> Health and safety information
54
high priority animal studies are conducted to
address important questions about the effects
of exposure to radio frequency energy (RF).
FDA has been a leading participant in the
World Health Organization international
Electromagnetic Fields (EMF) Project since its
inception in 1996. An influential result of this
work has been the development of a detailed
agenda of research needs that has driven the
establishment of new research programs
around the world. The Project has also helped
develop a series of public information
documents on EMF issues.
FDA and Cellular Telecommunications &
Internet Association (CTIA) have a formal
Cooperative Research and Development
Agreement (CRADA) to do research on
wireless phone safety. FDA provides the
scientific oversight, obtaining input from
experts in government, industry, and
academic organizations. CTIA-funded
research is conducted through contracts to
independent investigators. The initial
research will include both laboratory studies
and studies of wireless phone users. The
CRADA will also include a broad assessment
of additional research needs in the context of
the latest research developments around the
world.
What steps can I take to reduce my
exposure to radio frequency energy
from my wireless phone?
If there is a risk from these products - and at
this point we do not know that there is - it is
probably very small. But if you are concerned
about avoiding even potential risks, you can
take a few simple steps to minimize your
exposure to radio frequency energy (RF).
Since time is a key factor in how much
exposure a person receives, reducing the
amount of time spent using a wireless phone
will reduce RF exposure.
• “If you must conduct extended
conversations by wireless phone every
day, you could place more distance
between your body and the source of the
RF, since the exposure level drops off
dramatically with distance. For example,
you could use a headset and carry the
wireless phone away from your body or
use a wireless phone connected to a
remote antenna.
Again, the scientific data do not demonstrate
that wireless phones are harmful. But if you
are concerned about the RF exposure from
these products, you can use measures like
those described above to reduce your RF
exposure from wireless phone use.
What about children using wireless
phones?
The scientific evidence does not show a
danger to users of wireless phones, including
children and teenagers. If you want to take
steps to lower exposure to radio frequency
energy (RF), the measures described above
would apply to children and teenagers using
wireless phones. Reducing the time of
wireless phone use and increasing the
distance between the user and the RF source
will reduce RF exposure.
Some groups sponsored by other national
governments have advised that children be
discouraged from using wireless phones at
all. For example, the government in the
United Kingdom distributed leaflets
containing such a recommendation in
December 2000. They noted that no evidence
exists that using a wireless phone causes
brain tumors or other ill effects. Their
recommendation to limit wireless phone use
by children was strictly precautionary; it was
not based on scientific evidence that any
health hazard exists.
Do hands-free kits for wireless phones
reduce risks from exposure to RF
emissions?
Since there are no known risks from exposure
to RF emissions from wireless phones, there
is no reason to believe that hands-free kits
reduce risks. Hands-free kits can be used with
wireless phones for convenience and comfort.
These systems reduce the absorption of RF
energy in the head because the phone, which
is the source of the RF emissions, will not be
placed against the head. On the other hand, if
the phone is mounted against the waist or
other part of the body during use, then that
part of the body will absorb more RF energy.
Wireless phones marketed in the U.S. are
required to meet safety requirements
regardless of whether they are used against
the head or against the body. Either
configuration should result in compliance with
the safety limit.
Do wireless phone accessories that
claim to shield the head from RF
radiation work?
Since there are no known risks from exposure
to RF emissions from wireless phones, there
is no reason to believe that accessories that
claim to shield the head from those emissions
reduce risks. Some products that claim to
shield the user from RF absorption use special
phone cases, while others involve nothing
more than a metallic accessory attached to
the phone. Studies have shown that these
products generally do not work as advertised.
Unlike “hand-free” kits, these so-called
“shields” may interfere with proper operation
of the phone. The phone may be forced to
boost its power to compensate, leading to an
increase in RF absorption. In February 2002,
the Federal trade Commission (FTC) charged
two companies that sold devices that claimed
to protect wireless phone users from radiation
with making false and unsubstantiated
claims. According to FTC, these defendants
lacked a reasonable basis to substantiate
their claim.
What about wireless phone
interference with medical equipment?
Radio frequency energy (RF) from wireless
phones can interact with some electronic
devices. For this reason, FDA helped develop
a detailed test method to measure
electromagnetic interference (EMI) of
implanted cardiac pacemakers and
defibrillators from wireless telephones. This
test method is now part of a standard
sponsored by the Association for the
Advancement of Medical instrumentation
(AAMI). The final draft, a joint effort by FDA,
medical device manufacturers, and many
other groups, was completed in late 2000.
This standard will allow manufacturers to
ensure that cardiac pacemakers and
defibrillators are safe from wireless phone
EMI. FDA has tested wireless phones and
helped develop a voluntary standard
sponsored by the Institute of Electrical and
Electronic Engineers (IEEE). This standard
specifies test methods and performance
requirements for hearing aids and wireless
phones so that no interference occurs when a
person uses a compatible phone and a
compatible hearing aid at the same time. This
standard was approved by the IEEE in 2000.
FDA continues to monitor the use of wireless
phones for possible interactions with other
medical devices. Should harmful interference
be found to occur, FDA will conduct testing to
assess the interference and work to resolve
the problem.
Additional information on the safety of RF
exposures from various sources can be
obtained from the following organizations:
• FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
• Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
• Occupational Safety and Health
Administration's (OSHA):
http://www.osha.gov/SLTC/
radiofrequencyradiation/index.html
• National institute for Occupational Safety
and Health (NIOSH):
http://www.cdc.gov/niosh/emfpg.html
• World health Organization (WHO):
http://www.who.int/peh-emf/
• International Commission on Non-Ionizing
Radiation Protection:
http://www.icnirp.de
• National Radiation Protection Board (UK):
http://www.nrpb.org.uk
• Updated 4/3/2002: US food and Drug
Administration
http://www.fda.gov/cellphones
55
Road Safety
Your wireless phone gives you the powerful
ability to communicate by voice, almost
anywhere, anytime. But an important
responsibility accompanies the benefits of
wireless phones, one that every user must
uphold.
When driving a car, driving is your first
responsibility. When using your wireless
phone behind the wheel of a car, practice
good common sense and remember the
following tips:
1. Get to know your wireless phone and its
features, such as speed dial and redial. If
available, these features help you to place
your call without taking your attention off
the road.
2. When available, use a hands-free device.
If possible, add an additional layer of
convenience and safety to your wireless
phone with one of the many hands free
accessories available today.
3. Position your wireless phone within easy
reach. Be able to access your wireless
phone without removing your eyes from
the road. If you get an incoming call at an
inconvenient time, let your voice mail
answer it for you.
4. Let the person you are speaking with
know you are driving; if necessary,
suspend the call in heavy traffic or
hazardous weather conditions. Rain, sleet,
snow, ice and even heavy traffic can be
hazardous.
5. Do not take notes or look up phone
numbers while driving. Jotting down a “to
do” list or flipping through your address
book takes attention away from your
primary responsibility, driving safely.
6. Dial sensibly and assess the traffic; if
possible, place calls when you are not
moving or before pulling into traffic. Try to
plan calls when your car will be stationary.
If you need to make a call while moving,
dial only a few numbers, check the road
and your mirrors, then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting.
Make people you are talking with aware
you are driving and suspend
conversations that have the potential to
divert your attention from the road.
8. Use your wireless phone to call for help.
Dial 9-1-1 or other local emergency
number in the case of fire, traffic accident
or medical emergencies. Remember, it is a
free call on your wireless phone!
9. Use your wireless phone to help others in
emergencies. If you see an auto accident,
crime in progress or other serious
emergency where lives are in danger, call
9-1-1 or other local emergency number,
as you would want others to do for you.
10.Call roadside assistance or a special non-
emergency wireless assistance number
when necessary. If you see a broken-
down vehicle posing no serious hazard, a
broken traffic signal, a minor traffic
accident where no one appears injured, or
a vehicle you know to be stolen, call
roadside assistance or other special non-
emergency number.
“The wireless industry reminds you to
use your phone safely when driving.”
For more information, please call 1-888-901-
SAFE, or visit our web-site www.wow-
com.com
Provided by the Cellular Telecommunications
& Internet Association
Operating Environment
Remember to follow any special regulations in
force in any area and always switch your
phone off whenever it is forbidden to use it,
or when it may cause interference or danger.
When connecting the phone or any accessory
to another device, read its user's guide for
detailed safety instructions. Do not connect
incompatible products.
As with other mobile radio transmitting
equipment, users are advised that for the
satisfactory operation of the equipment and
for the safety of personnel, it is
recommended that the equipment should
only be used in the normal operating position
(held to your ear with the antenna pointing
over your shoulder).
Using Your Phone Near Other
Electronic Devices
Most modern electronic equipment is shielded
from radio frequency (RF) signals. However,
certain electronic equipment may not be
shielded against the RF signals from your
wireless phone. Consult the manufacturer to
discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be
maintained between a wireless phone and a
pacemaker to avoid potential interference
with the pacemaker.
>> Health and safety information
56
These recommendations are consistent with
the independent research and
recommendations of Wireless Technology
Research.
Persons with pacemakers:
• should always keep the phone more than
15 cm
(6 inches) from their pacemaker when the
phone is switched on.
• should not carry the phone in a breast
pocket.
• should use the ear opposite the
pacemaker to minimize potential
interference.
If you have any reason to suspect that
interference is taking place, switch your
phone off immediately.
Hearing Aids
Some digital wireless phones may interfere
with some hearing aids. In the event of such
interference, you may wish to consult your
hearing aid manufacturer to discuss
alternatives.
Other Medical Devices
If you use any other personal medical
devices, consult the manufacturer of your
device to determine if it is adequately
shielded from external RF energy. Your
physician may be able to assist you in
obtaining this information. Switch your phone
off in health care facilities when any
regulations posted in these areas instruct you
to do so. Hospitals or health care facilities
may be using equipment that could be
sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in
motor vehicles. Check with the manufacturer
or its representative regarding your vehicle.
You should also consult the manufacturer of
any equipment that has been added to your
vehicle.
Posted Facilities
Switch your phone off in any facility where
posted notices require you to do so.
Potentially Explosive Environments
Switch your phone off when in any area with
a potentially explosive atmosphere and obey
all signs and instructions. Sparks in such
areas could cause an explosion or fire
resulting in bodily injury or even death.
Users are advised to switch the phone off
while at a refueling point (service station).
Users are reminded of the need to observe
restrictions on the use of radio equipment in
fuel depots (fuel storage and distribution
areas), chemical plants or where blasting
operations are in progress.
Areas with a potentially explosive atmosphere
are often but not always clearly marked. They
include below deck on boats, chemical
transfer or storage facilities, vehicles using
liquefied petroleum gas (such as propane or
butane), areas where the air contains
chemicals or particles, such as grain, dust or
metal powders, and any other area where you
would normally be advised to turn off your
vehicle engine.
Emergency Calls
This phone, like any wireless phone, operates
using radio signals, wireless and landline
networks as well as user programmed
functions, which cannot guarantee connection
in all conditions. Therefore, you should never
rely solely on any wireless phone for essential
communications (medical emergencies, for
example).
Remember, to make or receive any calls the
phone must be switched on and in a service
area with adequate signal strength.
Emergency calls may not be possible on all
wireless phone networks or when certain
network services and/or phone features are in
use. Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your
present location (for example, 911 or
other official emergency number).
Emergency numbers vary by location.
3. Press .
If certain features are in use (call barring, for
example), you may first need to deactivate
those features before you can make an
emergency call. Consult this document and
your local cellular service provider.
When making an emergency call, remember
to give all the necessary information as
accurately as possible. Remember that your
phone may be the only means of
communication at the scene of an accident;
do not cut off the call until given permission
to do so.
Restricting Children's access to your
Phone
Your phone is not a toy. Children should not
be allowed to play with it because they could
hurt themselves and others, damage the
phone or make calls that increase your phone
bill.
FCC Notice and Cautions
FCC Notice
The phone may cause TV or radio interference
if used in close proximity to receiving
equipment. The FCC can require you to stop
using the phone if such interference cannot
be eliminated.
• This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) this device
may not cause harmful interference, and
(2) this device must accept any
interference received, including
interference that may cause undesired
operation.
• This equipment has been tested and found
to comply with the limits for a Class B
digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation. This equipment generates,
uses and can radiate radio frequency
energy and,f not installed and used in
accordance with the instructions, may
cause harmful interference to radio
communications.However, there is no
guarantee that interference will not occur
in a particular installation.If this equipment
does cause harmful interference to radio or
television reception, which can be
determined by turning the equipment off
and on, the user is encouraged to try to
correct theinterference by one or more of
the following measures:-Reorient or
relocate the receiving antenna. -Increase
the separation between the equipment and
receiver.-Connect the equipment into an
outlet on a circuit different from that to
which the receiver is connected. -Consult
the dealer or an experienced radio/TV
technician for help.
57
Vehicles using liquefied petroleum gas (such
as propane or butane) must comply with the
National Fire Protection Standard (NFPA-58).
For a copy of this standard, contact the
National Fire Protection Association, One
Battery march Park, Quincy, MA 02269, Attn:
Publication Sales Division.
Cautions
Changes or modifications made in the radio
phone, not expressly approved by Samsung, will
void the user’s authority to operate the
equipment.
Only use approved batteries, antennas and
chargers. The use of any unauthorized
accessories may be dangerous and void the
phone warranty if said accessories cause
damage or a defect to the phone.
Although your phone is quite sturdy, it is a
complex piece of equipment and can be
broken. Avoid dropping, hitting, bending or
sitting on it.
Other Important Safety Information
• Only qualified personnel should service
the phone or install the phone in a vehicle.
Faulty installation or service may be
dangerous and may invalidate any
warranty applicable to the device.
• Check regularly that all wireless phone
equipment in your vehicle is mounted and
operating properly.
• Do not store or carry flammable liquids,
gases or explosive materials in the same
compartment as the phone, its parts or
accessories.
• For vehicles equipped with an air bag,
remember that an air bag inflates with
great force. Do not place objects,
including both installed or portable
wireless equipment in the area over the
air bag or in the air bag deployment area.
If wireless equipment is improperly
installed and the air bag inflates, serious
injury could result.
• Switch your phone off before boarding an
aircraft. The use of wireless phone in
aircraft is illegal and may be dangerous to
the aircraft's operation.
• Failure to observe these instructions may
lead to the suspension or denial of
telephone services to the offender, or
legal action, or both.
Product Performance
Getting the Most Out of Your Signal
Reception
The quality of each call you make or receive
depends on the signal strength in your area.
Your phone informs you of the current signal
strength by displaying a number of bars next
to the signal strength icon. The more bars
displayed, the stronger the signal.
If you're inside a building, being near a
window may give you better reception.
Understanding the Power Save Feature
If your phone is unable to find a signal after
15 minutes of searching, a Power Save
feature is automatically activated. If your
phone is active, it periodically rechecks
service availability or you can check it
yourself by pressing any key.
Anytime the Power Save feature is activated,
a message displays on the screen. When a
signal is found, your phone returns to standby
mode.
Maintaining Your Phone's Peak
Performance
For the best care of your phone, only
authorized personnel should service your
phone and accessories. Faulty service may
void the warranty.
There are several simple guidelines to
operating your phone properly and
maintaining safe, satisfactory service.
• Hold the phone with the antenna raised,
fully-extended and over your shoulder.
• Try not to hold, bend or twist the phone's
antenna.
• Don't use the phone if the antenna is
damaged.
• Speak directly into the phone's receiver.
>> Health and safety information
58
• Avoid exposing your phone and
accessories to rain or liquid spills. If your
phone does get wet, immediately turn the
power off and remove the battery. If it is
inoperable, call Customer Care for service.
Availability of Various Features/
Ring Tones
Many services and features are network
dependent and may require additional
subscription and/or usage charges. Not all
features are available for purchase or use in
all areas. Downloadable Ring Tones may be
available at an additional cost. Other
conditions and restrictions may apply. See
your service provider for additional
information.
Battery Standby and Talk Time
Standby and talk times will vary depending
on phone usage patterns and conditions.
Battery power consumption depends on
factors such as network configuration, signal
strength, operating temperature, features
selected, frequency of calls, and voice, data,
and other application usage patterns.
Battery Precautions
• Never use any charger or battery that is
damaged in any way.
• Use the battery only for its intended
purpose.
• If you use the phone near the network's
base station, it uses less power; talk and
standby time are greatly affected by the
signal strength on the cellular network
and the parameters set by the network
operator.
• Battery charging time depends on the
remaining battery charge and the type of
battery and charger used. The battery can
be charged and discharged hundreds of
times, but it will gradually wear out. When
the operation time (talk time and standby
time) is noticeably shorter than normal, it
is time to buy a new battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not
in use, disconnect it from the power
source. Do not leave the battery
connected to a charger for more than a
week, since overcharging may shorten its
life.
• Extreme temperatures will affect the
charging capacity of your battery: it may
require cooling or warming first.
• Do not leave the battery in hot or cold
places, such as in a car in summer or
winter conditions, as you will reduce the
capacity and lifetime of the battery.
Always try to keep the battery at room
temperature. A phone with a hot or cold
battery may temporarily not work, even
when the battery is fully charged. Li-ion
batteries are particularly affected by
temperatures below 0 °C (32 °F).
• Do not short-circuit the battery. Accidental
short- circuiting can occur when a metallic
object (coin, clip or pen) causes a direct
connection between the + and - terminals
of the battery (metal strips on the
battery), for example when you carry a
spare battery in a pocket or bag. Short-
circuiting the terminals may damage the
battery or the object causing the short-
circuiting.
• Dispose of used batteries in accordance
with local regulations. In some areas, the
disposal of batteries in household or
business trash may be prohibited. For safe
disposal options for Li-Ion batteries,
contact your nearest Samsung authorized
service center. Always recycle. Do not
dispose of batteries in a fire.
Care and Maintenance
Your phone is a product of superior design
and craftsmanship and should be treated with
care. The suggestions below will help you
fulfill any warranty obligations and allow you
to enjoy this product for many years.
• Keep the phone and all its parts and
accessories out of the reach of small
children.
• Keep the phone dry. Precipitation,
humidity and liquids contain minerals that
will corrode electronic circuits.
• Do not use the phone with a wet hand.
Doing so may cause an electric shock to
you or damage to the phone.
• Do not use or store the phone in dusty,
dirty areas, as its moving parts may be
damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of
electronic devices, damage batteries, and
warp or melt certain plastics.
• Do not store the phone in cold areas.
When the phone warms up to its normal
operating temperature, moisture can form
inside the phone, which may damage the
phone's electronic circuit boards.
• Do not drop, knock or shake the phone.
Rough handling can break internal circuit
boards.
• Do not use harsh chemicals, cleaning
solvents or strong detergents to clean the
phone. Wipe it with a soft cloth slightly
dampened in a mild soap-and-water
solution.
• Do not paint the phone. Paint can clog the
device's moving parts and prevent proper
operation.
• Do not put the phone in or on heating
devices, such as a microwave oven, a
stove or a radiator. The phone may
explode when overheated.
• When the phone or battery gets wet, the
label indicating water damage inside the
phone changes color. In this case, phone
repairs are no longer guaranteed by the
manufacturer's warranty, even if the
warranty for your phone has not expired.
• If your phone has a flash or light, do not
use it too close to the eyes of people or
animals. This may cause damage to their
eyes.
• Use only the supplied or an approved
replacement antenna. Unauthorized
antennas or modified accessories may
damage the phone and violate regulations
governing radio devices.
• If the phone, battery, charger or any
accessory is not working properly, take it
to your nearest qualified service facility.
The personnel there will assist you, and if
necessary, arrange for service.
59
• When the phone or battery gets wet, the label
indicating water damage inside the phone
changes colour. In this case, phone repairs are no
longer guaranteed by the manufacturer's
warranty, even if the warranty for your phone has
not expired.
• If your phone has a flash or light, do not use it
too close to the eyes of people or animals. This
may cause damage to their eyes.
• Use only the supplied or an approved
replacement antenna. Unauthorised antennas or
modified accessories may damage the phone and
violate regulations governing radio devices.
• If the phone, battery, charger, or any accessory is
not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
59
F
Forwarding
email • 28
multimedia message • 27
text message • 27
H
Health and safety • 54
Holding, call • 20
I
Icons, description • 7
Images
deleting • 37
viewing • 37
Inbox, messages
email • 28
text and multimedia message • 27
International calls • 19
Internet • 32
K
Key tones, send or mute • 21
L
Language, select • 46
Last number, redial • 19
Locking
menu functions • 49
phone • 49
SIM card • 49
M
Memo • 44
Memory status
calendar • 36
library • 38
memo • 44
messages • 31
phonebook • 40
to do • 44
Message ringtone • 47
Messages
broadcast • 27, 31
configuration • 27
email • 26, 28
multimedia message • 25, 27
push • 27, 31
text message • 25, 27
Missed alam events • 36
Missed calls • 41
MMS messages
creating and sending • 25
deleting • 27
setting • 30
viewing • 27
Music player
downloading files • 22
playing • 23
synchronising • 22
Muting
key tones • 21
microphone • 21
N
Name card • 40
Names
entering • 17
searching • 39
Network band, select • 48
Network selection • 48
Network services • 47
O
Outbox, messages • 28
P
Password
call barring • 48
phone • 49
Phone
care and maintenance • 57
display • 7
icons • 7
keys • 7
locking • 49
password • 49
resetting • 50
switching on or off • 8
unpacking • 6
Phonebook
adding • 39
copying • 40
deleting • 39
editing • 39
finding • 39
options • 39
Photos
deleting • 37
viewing • 37
PIN, change • 49
Privacy • 49
Problems, solve • 52
Push messages
setting • 31
viewing • 27
Q
Quiet mode
entering • 9
setting • 47
R
Received calls • 41
Received messages
email • 28
multimedia message • 27
text message • 27
Recent calls • 41
Redialling
automatically • 46
manually • 19
Resetting phone • 50
Ringtone
call • 47
message • 47
Road safety • 55
Roaming • 48
S
Safety
information • 54
precautions • 2
Security, calls • 49
Sent messages • 29
SIM card
inserting • 6
locking • 49
SMS messages
creating and sending • 25
deleting • 27
setting • 30
viewing • 27
Solving problems • 52
>> Index
60
Sound settings • 47
Sounds
deleting • 37
playing • 37
Switching on or off
key tones • 21
microphone • 21
phone • 8
Synchronising with Windows Media Player • 22
T
T9 mode, text input • 17
Templates • 29
Text input mode, change • 17
Text, enter • 17
Time, set • 46
Transferring, calls • 21
U
USB mode, select • 46
V
Videos
deleting • 38
playing • 38
Voice memos
playing • 43
recording • 43
Voicemail server
connecting • 9
editing • 48
Volume
call ringtone • 47
message ringtone • 47
W
Waiting call • 48
Web browser, access • 32
World clock • 42
61
Conditions of the guarantee
Each Bang & Olufsen product
purchased from an authorised Bang &
Olufsen retailer carries a guarantee
against defects in workmanship and
materials.
The guarantor is the authorised Bang
& Olufsen retailer or subsequently the
national Bang & Olufsen
representative. The guarantee period
is 24 months.
The guarantee covers the repair costs
(i.e. spare parts and labour costs) for
the product. The guarantee also
covers accessories. There is a 24-
month right of claim on replaced and
repaired parts.
The guarantee applies to the country
of purchase. It will however also be
met by authorized Bang & Olufsen
dealers in other countries. However, as
Bang & Olufsen telephone products
are designed to function in the
country for which they were
produced, the guarantee applies to
that country only. This is due to the
variations in transmission standards
and legal approvals from country to
country.
The guarantee does not cover damage
due to accidents, including damage by
lightning, fire, water, transport, misuse
or negligence.
Bang & Olufsen is not responsible for
any indirect loss, or any consequential
loss.
The guarantee does not cover costs of
rental of replacement products and
modifications required to adapt the
product to different voltage or
broadcasting standards. The
replacement of e.g., batteries is not
covered by the guarantee.
The guarantee is void if the product is
repaired or modified other than by a
person authorised by Bang & Olufsen
or if the serial number has been
removed from the product.
If you intend to use your audio/video
product in another country, we
recommend that you obtain
information from your dealer on
voltage and radio and television
standards in the country you intend to
move to. The dealer will advice you of
possible modifications.
In Japan, North America, South
America, Taiwan and South Korea, it is
not possible to have repairs or
modifications made to television sets
or video recorders which have not
been produced especially for use in
these countries.
For the guarantee to be valid, a
document is normally required stating
the following:
• name of product and type number
• serial number
• date of purhase/delivery
• guarantee period
• stamp and signature of an
authorised Bang & Olufsen retailer
62
Waste Electrical and Electronic
Equipment (WEEE)
Environmental protection
The European Parliament and the
Council of the European Union have
issued the Waste Electrical and
Electronic Equip¦ment Directive. The
purpose of the Directive is the
prevention of waste of electrical and
electronic equipment, and to promote
the reuse and recycling and other
forms of recovery of such waste. As
such the Directive concerns producers,
distributors and consumers.
The WEEE directive requires that both
manufacturers and end-consumers
dispose of electrical and electronic
equipment and parts in an
environmentally safe manner, and that
equipment and waste are reused or
recovered for their materials or energy.
Electrical and electronic equipment
and parts must not be disposed of
with ordinary household refuse; all
electrical and electronic equipment
and parts must be collected and
disposed of separately.
Products and equipment which must
be collected for reuse, recycling and
other forms of recovery are marked
with the pictogram shown.
When disposing of electrical and
electronic equipment by use of the
collection systems available in your
country, you protect the environment,
human health and contribute to the
prudent and rational use of natural
resources. Collecting electrical and
electronic equipment and waste
prevents the potential contamination
of nature with the hazardous
substances which may be present in
electrical and electronic products and
equipment.
Your Bang & Olufsen retailer will assist
with and advise you of the correct way
of disposal in your country.
