Samsung Electronics Co SGHI450V PCS GSM/ EDGE Phone with Bluetooth User Manual C s and Settings Admi
Samsung Electronics Co Ltd PCS GSM/ EDGE Phone with Bluetooth C s and Settings Admi
Users Manual
9. User Manual
World Wide Web
http://www.samsungmobile.com
Printed in Korea
English. 08/2007. Rev. 1.0
SGH-i450V
User’s Guide
Draft
2007.08.18
* Depending on the software installed or your service provider or country, some of
the descriptions in this guide may not match your phone exactly.
* Depending on your country, your phone and accessories may appear different from
the illustrations in this guide.
* Bluetooth QD ID: B0XXXXX
This product includes software licensed from Symbian Ltd. © 1998-2007. Symbian and
Symbian OS are trademarks of Symbian Ltd.
Java™ and all Java-based marks are trademarks or registered trademarks of Sun
Microsystems, Inc.
Windows Media Player® is a registered trademark of Microsoft Corporation.
1
Contents
Important safety precautions ........................................... 4
C
HAPTER
1:
Getting started
What’s in the box?.......................................................... 7
Getting to know your phone............................................. 8
Inserting the USIM/SIM card...........................................11
Attaching the battery .....................................................12
Charging the battery......................................................14
Switching the phone on or off..........................................15
Using an optional memory card .......................................16
C
HAPTER
2:
General information
Indicators related to actions............................................18
Menu screen .................................................................19
Multimedia launcher.......................................................22
Actions common to all applications...................................23
Key lock mode ..............................................................26
Entering text.................................................................26
Using PC Studio.............................................................29
C
HAPTER
3:
Call functions
Making a call.................................................................31
Answering a call ............................................................34
Using options during a call ..............................................35
Viewing call logs............................................................36
C
HAPTER
4:
Contacts and Calendar
Contacts.......................................................................39
Calendar ......................................................................45
Contents
2
C
HAPTER
5:
Entertainment
Camera........................................................................50
Music player..................................................................55
RealPlayer ....................................................................58
Video Editor..................................................................60
Radio...........................................................................63
Games .........................................................................65
My files ........................................................................65
Mobile TV .....................................................................70
Flash Player ..................................................................71
C
HAPTER
6:
Message services
Messaging ....................................................................72
Voicemail......................................................................95
Vodafone Messenger ......................................................96
C
HAPTER
7:
Extra programs
Notes.........................................................................102
Calculator...................................................................102
Converter...................................................................104
Recorder ....................................................................106
Quickoffice..................................................................107
Adobe PDF..................................................................109
Voice Signal................................................................110
Clock .........................................................................114
GPS data....................................................................117
Landmarks..................................................................119
C
HAPTER
8:
Internet
Web...........................................................................121
live!...........................................................................126
Contents
3
C
HAPTER
9:
Settings
Profiles.......................................................................127
Themes......................................................................129
Configuration ..............................................................130
C
HAPTER
10:
Managers
File manager...............................................................146
Application manager ....................................................148
Device manager ..........................................................150
Activation key manager................................................152
Memory card manager..................................................153
C
HAPTER
11:
Connectivity
Bluetooth ...................................................................155
USB...........................................................................158
Remote synchronisation................................................159
Connection manager....................................................161
A
PPENDIX
A:
Troubleshooting
General problems ........................................................163
Call problems..............................................................165
Power and charging problems........................................166
Application problems....................................................168
A
PPENDIX
B:
Health and safety information
4
Important safety precautions
Read these guidelines before using your wireless phone.
Failure to comply with them may be dangerous or illegal.
Drive safely at all times
Do not use a hand-held phone while driving. Park your vehicle
first.
Switch off
the
phone when refuelling
Do not use the phone at a refuelling point (service station) or
near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using them in an
aircraft is both illegal and dangerous.
Switch off the phone near all medical equipment
Hospitals or health care facilities may be using equipment that
could be sensitive to external radio frequency energy. Follow
any regulations or rules in force.
Interference
All wireless phones may be subject to interference, which
could affect their performance.
Be aware of special regulations
Meet any special regulations in force in any area and always
switch off your phone whenever it is forbidden to use it, or
when it may cause interference or danger.
5
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to your ear). Avoid
unnecessary contact with the antenna when the phone is
switched on.
Emergency calls
Key in the emergency number for your present location, then
press .
Keep your phone away from small children
Keep the phone and all its parts, including accessories, out of
the reach of small children.
Accessories and batteries
Use only Samsung-approved batteries and accessories, such
as headsets and PC data cables. Use of any unauthorised
accessories could damage you or your phone and may be
dangerous.
CAUTION
:
• The phone could explode if the battery is replaced with an
incorrect type.
• Dispose of used batteries according to the manufacturer’s
instructions.
At very high volumes, prolonged listening to a headset
can damage your hearing.
6
Qualified service
Only qualified service personnel may install or repair your
phone. Failure to do so may invalidate the warranty.
For more detailed safety information, see “Health and safety
information” on page 172.
Notes
:
• While using your phone, data may be deleted or corrupted due
to system malfunctions or operating mistakes. Back up your
important data using external storage devices.
• Be careful not to remove the battery while storing data. Doing
this may delete or corrupt your data.
• Extremely high or low temperatures may cause errors in the
screen display or a system malfunction. The phone functions
best in a normal temperature range.
7
1
Getting started
Congratulations on the purchase of your new Smartphone! This
chapter helps you set up your phone, charge the phone’s
batteries, and familiarise yourself with its different
components.
What’s in the box?
Your package contains the following items:
• Phone
• Battery
• Travel adapter
• PC data cable
• Headset
• Quick Reference Guide
• PC Studio CD
1
• User’s Guide CD
In addition, you can obtain the following accessories for your
phone from your local Samsung dealer:
Note
: The items supplied with your phone and accessories
available at your Samsung dealer may vary, depending on
your country or service provider.
1. The PC Studio CD contains PC Studio, Add-on software, and applications.
• Standard/Extended battery • Headset
• PC data cable • PC Studio CD
• Travel adapter • Hand strap
• Car cradle • Memory card
• Stylish hands-free car kit
Getting started
8
Getting to know your phone
Front view
Navigation keys
(Up/Down/Left/Right)
Talk key
Display
Special function keys
End key
Right soft key
Confirm key
Alphanumeric keys
Volume keys
Left soft key
Menu access key
Delete key
Front camera lens
Memory card
slot
Mouthpiece
Earpiece
Touch wheel keys
Getting started
9
Rear view
Key Description
• Press and hold to turn the phone on or off.
•
Press to
access the Quick Menu list.
Press to perform the command shown on the
screen immediately above the keys.
• Press to open the main menu screen, which
contains a list of available features and
applications.
• Press and hold to open a window which shows
all of the currently running applications.
• Press to scroll through items on a screen.
• Press to move the cursor in a text input field.
Press to confirm your selection.
Mulfi-function jack
Power key
Rear camera lens
Headset jack
Camera key
Flash
Speaker
Battery cover
Getting started
10
• Press and hold to delete characters in a text
field.
• Press to delete contents in any application or
remove add-on applications.
• Press to make or answer a voice call.
• Press to access call logs.
Press to end a call or exit an application.
• Press to enter numbers and characters.
• Press and hold to access the voicemail
server in Standby mode.
• Press and hold to access Voice Signal in
Standby mode.
• Press to enter an international call prefix or
pauses when entering a phone number.
• Press and hold to display a list of symbols in a
text input field.
• Press to change the text input mode or case
in a text input field.
• Press and hold to activate or deactivate the
Silent profile.
• Press to adjust the key tone volume in
Standby mode.
• Press to adjust the earpiece volume during a
call.
• Press and hold to turn on the camera.
• Press to take a photo or record a video in
Camera mode.
Key Description
Getting started
11
Inserting the USIM/SIM card
When you subscribe to a cellular network, you are provided
with a plug-in USIM/SIM card loaded with your subscription
details, such as your PIN, any optional services available, and
much more.
• Keep all USIM/SIM cards out of the reach of small children.
• The USIM/SIM card and its contacts can easily be damaged
by scratches or bending, so be careful when handling the
card.
• When installing the USIM/SIM card, make sure that your
phone is switched off before removing the battery.
Inserting the USIM/SIM card
1. Remove the battery cover.
2. Insert the USIM/SIM card into the card holder, as shown.
Getting started
12
Removing the USIM/SIM card
Remove the card from the holder, as shown.
Attaching the battery
Your phone is powered by a rechargeable Li-ion battery. Use
only approved batteries and adapters. Ask your local Samsung
dealer for further details.
Note
: You must fully charge the battery before using your phone
for the first time. See page 14.
Attaching the battery
1. Remove the battery cover, if necessary.
Getting started
13
2. Insert the battery into the battery compartment, as shown.
3. Reattach the battery cover.
Removing the battery
1. If necessary, switch off the phone by pressing and holding
until the power-off image displays.
2. Remove the battery cover.
3. Lift the battery away from the phone.
Getting started
14
Charging the battery
Note
: The phone can be used while the battery is being charged,
but this causes the battery to charge more slowly.
1. Plug the connecter of the travel adapter into the jack on the
phone.
2. Plug the travel adapter into a standard AC power outlet.
3. When the battery is fully charged, unplug the travel adapter
from the power outlet and then remove it from the phone.
Getting started
15
Switching the phone on or off
1. Press and hold until the power-on image displays.
2. If the phone asks for a PIN, enter the PIN supplied with
your USIM/SIM card and press the
OK
soft key.
3. If the phone asks for a lock code, enter the code and press
the
OK
soft key. The default lock code is
00000000
. To
change the lock code, see page 134.
If you turn on the phone for the first time, the first setup
procedure begins.
4. Select your region.
5. Select your city.
6. Enter the current date and press the
OK
soft key.
7. Enter the current time and press the
OK
soft key.
The phone searches for your network, and after finding it,
the standby screen appears on the display. Now, you can
make or receive a call.
Note
: To change the display language, use the
Language
option in
Settings
→
Config.
→
General
→
Personalisation
. For further details, see page 132.
8. To switch off the phone, press and hold until the power-
off image displays.
Note
: If you have cancelled before finishing the region and time
setup, the setup procedure will start again the next time
you turn on the phone.
Getting started
16
Using an optional memory card
Using a memory card, you can store multimedia files, such as
video clips, music and sound files, photos, and messaging
data, and back up information from your phone’s memory.
Your phone is compatible with a microSD card.
Important!
: Use only compatible memory cards with your phone.
Using incompatible memory cards, such as Secure Digital (SD)
cards, may damage the card, as well as the phone, and data
stored on the card.
Inserting a memory card
1. Insert the card into the memory card slot with the label
facing up.
2. Push the card in until it locks into place. You will hear a
beep.
3. Close the memory card cover.
Getting started
17
Removing the memory card
1. Press and select
Remove memory card
.
2. Press the
Yes
soft key to confirm.
3. Open the card cover and push the card in to release it.
Then slide the card out of the card slot.
4. Press the
OK
soft key.
WARNING!
• Removing the memory card without following the procedure
above may cause damage to your data and memory card.
• If you need to reboot the phone while installing an application on
the memory card, do not remove the card until the reboot is
complete; otherwise the application files may be lost.
18
2
General information
Your phone provides various functions which are very handy for
daily use and for entertainment. This chapter gives you general
information for using the functions.
Indicators related to actions
One or more of the following icons may be shown when the
phone is in Standby mode:
Indicator Meaning
Shows the received signal status. The greater
the number of bars, the stronger the signal.
• : GSM/GPRS network
• : WCDMA network
• : HSDPA network
Indicates that you have an active alarm.
Indicates that a new message has been
received.
• : Message
• : Voicemail
• : Email
Appears when your phone is trying to send a
message.
Appears when a call diverting option is active.
If you have two phone lines, the appropriate
number appears on the indicator.
Indicates the currently selected line.
Appears when you missed a call.
General information
19
Menu screen
From the Menu screen, you can access all of the applications
for your phone. Press to open the Menu screen.
Opening applications or folders
Scroll to an application or a folder using the Navigation keys
and press to open it.
Appears when Bluetooth is active.
Appears when a headset is connected to your
phone.
Appears when your phone is connected to a PC
via USB.
Appears when you are in Home Zone, if
registered to an appropriate service.
Appears when the keypad is locked.
Appears when a memory card is inserted into
your phone.
Shows the remaining battery power level.
Indicator Meaning
General information
20
Closing applications
• Press ,
• Press the
Exit
soft key,
• Select
Options
→
Exit
, or
• Press the
Back
soft key as many times as you need to
return to Standby mode. Any unsaved data is saved
automatically.
Rearranging applications
You can rearrange applications or folders on the Menu screen,
and move applications into folders.
To change the location of an application on the Menu screen:
1. On the Menu screen, scroll to the application you want to
move.
2. Select
Options
→
Move
.
A check mark is placed on the selected application.
3. Move the selection to a desired location and press the
OK
soft key.
To move an application to a folder:
1. On the Menu screen, scroll to the application you want to
move.
2. Select
Options
→
Move to folder
.
3. Select a folder.
4. Press the
Move
soft key.
Note
: You can add a new folder by selecting
Options
→
New
folder
.
General information
21
Switching between applications
Your phone is a multi-tasking device, which means that it can
run multiple applications at the same time. If you switch to
another applications without closing the application you were
using, the previous one is inactive but still running.
If you have several applications open and want to switch from
one to another, press and hold . The application switching
window opens, showing applications that are currently
running.
Scroll to an application and press the
Select
soft key to go to
it or press to close it.
Adding applications
You can add applications to the Menu screen by downloading
its installation files from the wireless web.
To download an application, select
Options
→
Download
applications
from the Menu screen. You can select a
bookmark for a preset website for download or enter the URL
address of the website. After accessing the web site, search
for an application and follow the onscreen instructions.
You can also download applications to your PC and install them
in the phone using the PC Studio tool. Refer to the included
CD-ROM for the program.
General information
22
Multimedia launcher
When you slide down the front part of the phone, the phone
switches to Landscape mode and opens the multimedia
launcher screen.
From the multimedia launcher, you can quickly access the
applications in which you can enjoy music or videos: Music
player, Radio, and RealPlayer. For details about each
application, see the appropriate section in Chapter 5.
Using the touch wheel
In the multimedia launcher or applications accessed from the
multimedia launcher, you can use the touch wheel to scroll
through and selecting applications or options. (You can also
use the Navigation keys and .)
Note
: You need to touch or drag on the touch wheel with a little
pressure.
•
Scroll
: Drag your finger up or down on the touch wheel.
General information
23
You can also tap the upper part or lower part of the touch
wheel.
Note
: Depending on how hard you tap, the scroll speed will
differ.
•
Select
: Tap the middle of the touch wheel.
Actions common to all applications
Adding items
When you are in an application, select
Options
and then an
option for creating a new item, such as
Create message
,
New contact
,
New entry
, or
New note
. Options for creating
an item are different in each application.
For details on how to enter letters and numbers, see “Entering
text” on page 26.
General information
24
Opening items
To open an item on a list of files or folders, scroll to it and
press or select
Options
→
Open
.
Editing items
To edit an item, you may need to first open it for viewing. Then
select
Options
→
Edit
and change its contents.
Renaming items
To give a new name to a file or folder, scroll to it and select
Options
→
Rename
.
Removing or deleting items
Scroll to the item and select
Options
→
Delete
or press .
To delete multiple items at one time, you first need to mark
them. See the next section, “Marking items.”
Marking items
There are several ways to select items on a list:
• To select one item at a time, scroll to it and select
Options
→
Mark/Unmark
→
Mark
. A check mark is placed next to
the item.
• To select all of the items on the list, select
Options
→
Mark/Unmark
→
Mark all
.
• To unmark an item, scroll to it and select
Options
→
Mark/Unmark
→
Unmark
.
• To unmark all of the items, select
Options
→
Mark/Unmark
→
Unmark all
.
General information
25
Sending items
You can send items, such as contact information, pictures,
sounds, and calendar entries, via one of messaging services or
via Bluetooth connections.
1. Open an item and select
Options
→
Send
or
Send
business card
.
2. Select a method; the choices are
Via text message
,
Via
multimedia
,
Via e-mail
, and
Via Bluetooth
.
• To send the item in a text message, see page 73.
• To send the item in a multimedia message, see page 74.
• To send the item in an email, see page 77.
• To send the item via Bluetooth, see page 157.
Arranging items
You can arrange items, such as pictures, sounds, and
messages, into folders.
Creating folders
1. Select
Options
→
New folder
.
2. Enter a folder name and press
OK
soft key.
Moving items to an application folder
1. Scroll to an item and select
Options
→
Move to folder
(shown only if there are folders available).
2. Select a subfolder, if necessary.
3. Scroll to the location to which you want the item moved
and press the
Move
soft key.
General information
26
Key lock mode
When you close the phone, it locks the exposed keys to
prevent any unwanted phone operations from accidentally
pressing any of the keys.
To unlock the keypad, press the Unlock soft key and then .
Note
: You can set the phone to continue the current operation
when you close the phone by changing the
Slide down
setting in
Settings
→
Config.
→
Phone
→
Call
.
Entering text
You can enter text in two different ways: using the Traditional
text input mode traditionally used in mobile phones-pressing a
key repeatedly until the desired character displays, or
Predictive text input mode using the built-in dictionary.
Changing the text input mode
You can change the text input mode by pressing , as
follows:
• To select Traditional text input mode, press until the
indicator
Abc
displays. Alternatively, press and
select
Predictive text
→
Off
.
• To select Predictive text input mode, press until the
indicator
Abc
displays. Alternatively, press and
select
Activate predictive text
.
• To select Number mode, press until the indicator
123
displays. Alternatively, press and select
Number mode
.
• To select Symbol mode, press and hold . Alternatively,
press
and select More symbols
.
General information
27
Using Traditional text input mode
1. Press a number key until the character you want appears.
Note that there are more characters available for a number
key than are printed on the key.
2. Select the other letters in the same way.
Note
: If the next letter is located on the same key as the present
one, wait until the cursor appears or press the Right key to
end the time-out period, and then enter the letter.
Other Traditional text input operations
• To change cases,
ABC
(Uppercase),
Abc
(Initial capital),
and
abc
(Lowercase), press .
• To remove a character, press . Press and hold to clear
more than one character.
• Press to enter symbols.
• To insert a number quickly, press and hold the
corresponding number key.
• To insert a space, press .
Using Predictive text input mode
1. Enter the desired word by pressing the keys to .
Press each key only once for one letter. The word changes
each key press.
Note
: The word match is evolving. Wait until you have entered
the entire word before you check the result.
General information
28
2. When you have finished entering the word, check that it is
correct.
• If the word is correct, go to the next step.
• If the word is not correct, press to view other
matching words that the dictionary has found, one by
one.
To add a word to the dictionary, press the
Spell
soft key,
enter the word using Traditional text input, and press the
OK
soft key.
3. When the correct word displays, press or the Right key
so that the word is complete.
Other Predictive text mode operations
• To change cases,
ABC
(Uppercase),
Abc
(Initial capital),
and
abc
(Lowercase), press .
• To remove a character, press . Press and hold to
clear more than one character.
• To insert a number, press and hold the corresponding
number key.
• Press and then to enter the desired punctuation
marks.
Tip
: T9 mode tries to guess which commonly used punctuation
mark (
. , ? ! ’
) is needed. The order and availability of the
punctuation marks depend on the language being used.
• To view matching words that the dictionary has found one
by one, press when a word is active (underlined).
General information
29
Copying and pasting text
1. Press and select
Copy
.
2. Press the Left or Right key to move the cursor to the
position you want.
3. Press the
Start
soft key.
4. Press the Left or Right key to highlight text you want.
5. Press the
Copy
soft key.
6. Move the cursor to the position you want.
7. Press and select
Paste
to insert the text.
Using PC Studio
PC Studio, which is contained on the PC Studio CD-ROM, is a
Windows-based PIM (Personal Information Management) and
Sync Manager program. Using this program, you can manage
your contacts and schedule, synchronise your data between
the phone and the PC, and explore the phone’s file directory.
For further information on how to use the program, see the PC
Studio help.
Notes
:
• You need to set your phone’s USB mode to
PC Studio
. See page
158.
• PC Studio does not fully support Bluetooth dongles using the IVT
protocol stack. If you have problems using PC Studio with your
Bluetooth software on the PC, please check with the Bluetooth
dongle or PC manufacturer’s website for updates.
General information
30
Installing PC Studio
1. Insert the PC Studio CD into the CD-ROM drive of your
compatible PC.
2. Click
Install Samsung PC Studio
.
3. Select the language you want and follow the instructions on
the installation wizard screen.
Note
: The USB driver is automatically installed during PC Studio
installation.
31
3
Call functions
With your phone, you can make or answer video conference
calls as well as normal voice calls. This chapter gives you
information for using your phone’s call functions.
Making a call
1. In Standby mode, use the keypad to enter an area code and
phone number.
Press to remove a wrong number.
For an international call, press twice for the
international call prefix,
+
, (this character replaces the
international access code) and then enter the country code,
area code without
0
, and phone number.
Note
: Calls described here as international may in some cases
be made between regions of the same nation.
2. Press to make a call. To make a video call, select
Options
→
Call
→
Video call
.
Note
: To adjust the earpiece volume during a call, press
/
.
3. Press or the
End call
soft key to end the call.
Note
: Pressing always ends a call, even if another application
is active and displayed.
Call functions
32
Accessing dialling options
After entering a number, press the
Options
soft key. You can
access the following options:
•
Call
: makes a voice call or video call.
•
Send
: allows you to send a text message or multimedia
message to the number.
•
Save to Contacts
: allows you to save the number in
Contacts. For details, see page 39.
Making a call using Contacts
1. Press and select
Contacts
to open your contact list.
2. Select the name you want.
Note
: You can enter the first few letters of the name in the
search field at the bottom of the screen. Matching
contacts are listed.
3. Scroll to the number you want, if necessary.
4. Press or select
Options
→
Call
→
the call type you
want.
Name dialling
Once you have stored a number in Contacts, you can make a
phone call by saying the name that has been assigned to a
contact card. For details, see “Voice Signal” on page 110.
Call functions
33
Speed dialling
Once you have stored a number in Contacts, you can assign
the most frequently-used numbers to the speed dialling keys
to and then quickly and easily dial them with only one
keypress. See “Assigning speed dialling keys” on page 42.
Dialling using a pause
When you call an automated system, like a banking service,
you are required to enter a password or an account number.
Instead of manually entering the numbers each time, you can
enter the necessary DTMF tones separated by pauses before
dialling.
Note
: DTMF tones are the tones you hear when you press the
number keys. DTMF tones allow you to communicate with
computerised telephone systems, for example, voicemail
servers or telebanking systems.
1. Enter the phone number you want to dial, such as a bank’s
teleservice number.
2. Press repeatedly to insert a pause.
You can insert two types of pauses:
•
P
: inserts a pause of approximately two seconds
between numbers. The numbers following “p” are sent
automatically.
•
w
: inserts a manual pause between numbers. To send
numbers following “w,” you must press the
Send
soft
key.
3. Enter a number to be sent after the pause, such as your
account number, PIN, etc.
Call functions
34
4. Repeat steps 2 and 3 to add more pauses and numbers, if
necessary.
5. Press to make a call.
6. After connecting, wait for a prompt from the system and
press at each prompt, if applicable.
The DTMF tones are sent.
Answering a call
1. To answer an incoming call, open the phone, if necessary,
and press or select
Options
→
Answer
.
• To reject the call, press . The caller will hear a “line
busy” tone.
• To mute the call ringer, press the
Silence
soft key.
Note
: If the Silent profile is active (see page 127),
Send
message
displays in place of
Silence
to allows you
to reject a call.
• Depending on the
Side volume key
setting, press and
hold
/
to mute the call ringer or reject the call. See
page 138.
2. To end the call, press or the
End call
soft key.
Note
:
To adjust the phone tones for different environments
and situations, for example, when you want your phone
to be silent, see “Profiles” on page 127
.
Call functions
35
Using options during a call
While a call is in progress, you can access the following options
by pressing the
Options
soft key:
Note
: Depending on the status of your call, for example, having a
second call or a call on hold, available options vary.
•
Activate loudspeaker
/
Activate handset
: switches to
Speakerphone mode or back to Normal mode.
•
Swap
: switches between the active call and the call on
hold.
•
End active call
: ends the currently active call.
•
End all calls
: ends all of the active call and the call on
hold.
•
Hold
: puts the current call on hold.
•
Unhold
: reactivates the call on hold.
•
Mute
: switches your phone’s microphone off so that the
other person on the phone cannot hear you.
•
Unmute
: switches your phone’s microphone on.
•
New call
: makes a new call. When you select this option,
the current call is placed on hold.
•
Conference
: makes a conference call. You can have a
conversation with up to 5 participants.
•
Private
: (during a conference call) allows you to talk
privately to one conference call participant. When the list of
call participants appears, select one and press the
Private
soft key.
•
Drop participant
: (during a conference call) allows you to
disconnect one conference call participant. When the list of
call participants appears, select one and press the
Drop
soft key.
Call functions
36
•
Transfer
: connects an incoming call or a call on hold with
an active call and disconnects you from both calls.
•
Open active standby
: returns the display to the Standby
screen while on a call.
•
Send MMS
: allows you to send a multimedia message.
•
Send DTMF
: allows you to send DTMF tones for numbers,
such as passwords or bank account numbers. You can
check or correct the numbers before sending.
•
Whisper On
/
Whispher Off
: turns on or off Whisper
mode. Whisper mode automatically increases the
microphone’s sensitivity to allow the other person to hear
your voice even though you may be whispering.
•
Switch to video call
: switches the current call to the video
call.
Viewing call logs
In the Calls application, you can monitor phone calls, call
duration, and packet data connections registered by the
phone.
Press to open the Menu, and then select
Calls
.
Recent calls
The phone records the phone numbers of missed, received,
and dialled calls. The phone registers missed or received calls
only if the network supports these functions.
Call functions
37
Accessing dialled, received, and missed call logs
1. Select
Recent calls
from the Calls main view.
2. Select a call log type.
3. Select a call log to view its details.
Note
:
You can quickly access dialled numbers by pressing
in Standby mode.
Erasing recent call logs
• To clear all recent call logs, select
Options
→
Clear recent
calls
.
• To clear the selected call type’s logs, open the call type
whose contents you want to erase and select
Options
→
Clear list
.
• To clear an individual call log, open a log type, scroll to the
log, and press or select
Options
→
Delete
.
Call duration
From the Calls main view, select
Call duration
to view the
duration of the last call, dialled or received calls, and total
calls.
Note
: The actual time invoiced for calls by your service provider
may vary, depending upon network features, rounding-off
for billing, etc.
To reset the timers, scroll to the timer type you want and
select
Options
→
Clear timers
. For this, you need to enter
the lock code. The default lock code is
00000000
.
Call functions
38
Packet data
You can check how much data, measured in bytes, has been
transferred to and from your phone.
From the Calls main view, select
Packet data
. The display
shows the counters for all sent and received data, separately.
To reset the counters, select
Options
→
Clear counters
. For
this, you need to enter the lock code. The default lock code is
00000000
.
Communication log
You can check the sender or recipient’s name or phone number
for each communication event.
From the Calls main view, press the Right key and select a
connection log from the list to view its details.
Note
: Sub-events, such as a
text message
sent in more than
one part and packet data connections, are logged as one
communication event.
Erasing communication logs
To erase all of the log contents permanently, select
Options
→
Clear log
.
Setting log duration
From the call log list, select
Options
→
Settings
→
Log
duration
. Select the length of time you want. Log events
remain in the phone’s memory for a specified number of days,
after which they are automatically erased to free up memory.
If you select
No log
, no log contents will be stored.
39
4
Contacts and Calendar
Contacts
In Contacts, you can store and manage a person’s contact
information, such as a name, phone numbers, and addresses,
as a contact card.
Press to open the Menu, and then select
Contacts
.
Creating contact cards
You can create contact cards and save them selectively in your
phone’s memory or the USIM/SIM card.
Creating a new contact card in the phone’s memory
1. From the contact list, select
Options
→
New contact
. An
empty contact card opens.
2. Fill in the fields you want.
3. To assign a caller ID image to the contact card, select
Options
→
Add thumbnail
, and then select an image.
4. To add information fields, select
Options
→
Add detail
→
a
detail item type, and then enter the appropriate
information.
You can delete a field by selecting
Options
→
Delete
detail
. To change the field name, select
Options
→
Edit
label
.
5. Press the
Done
soft key to save the contact card.
Contacts and Calendar
40
Creating a contact card on the USIM/SIM card
1. From the contact list, and select
Options
→
SIM contacts
→
SIM directory
.
To create a contact card which can be used in Fixed Dialling
mode, select
Fixed dial contacts
.
2. On the SIM directory screen, select
Options
→
New SIM
contact
.
3. Enter a name and a phone number in each field.
4. Press the
Done
soft key to save the contact card.
Note
: Once you have stored numbers on the USIM/SIM card, you
can retrieve them by entering their location numbers,
which are automatically assigned in the order in which the
numbers were stored, and pressing . For example,
pressing and then in Standby mode shows the
first number stored on the USIM/SIM card.
Assigning your own number
You can register your phone number and name on the USIM/
SIM card.
1. From the contact list, select
Options
→
SIM contacts
→
SIM directory
.
2. Select
Options
→
My numbers
.
3. Select the location you want.
4. Enter a name and a phone number.
5. Press the
Done
soft key to save the number.
Contacts and Calendar
41
Copying contact cards
• To copy contact cards from the USIM/SIM card to your
phone’s memory, select
Options
→
SIM contacts
→
SIM
directory
. Scroll to the contact you want to copy and select
Options
→
Copy to Contacts
.
• To copy contact cards from the phone’s memory to your
USIM/SIM card, select the contact you want and select
Options
→
Copy to SIM directory
.
• To copy contact cards to or from a memory card, scroll to
the contact you want and select
Options
→
Copy
→
To
memory card
or
From memory card
.
Options when viewing contacts
To view details of a contact card, select the card from the
contact list.
Contact information view shows all information on the contact
card. If you have added an image to the contact card, the
thumbnail image displays on the top left of the screen. The
name field is always displayed in the contact information view,
but other fields are displayed if they contain information.
Changing contact information
1. From the contact list, select the contact card you want to
edit.
2. Select
Options
→
Edit
.
3. Enter new information for the contact.
4. Press the
Done
soft key to save your changes.
Contacts and Calendar
42
Assigning default numbers and addresses
If a person has several phone numbers or email addresses,
you can define the default number and address.
1. Open a contact card and select
Options
→
Defaults
.
2. Scroll to a default number option to be set and press the
Assign
soft key.
3. Select one of the numbers stored in the selected contact
card.
4. Press the
Back
soft key.
The number is set to a default number for the selected
type. For example, if you select a number for
Video call
number
, it becomes default for making a video call.
When you return to the contact card view, you will see the
default phone number underlined. On the contact list, a
type icon of the default phone number appears.
Assigning speed dialling keys
Speed dialling is a quick way to call frequently-used numbers.
You can assign eight phone numbers to speed dialling keys
to . Number
1
is reserved for the voicemail server.
To assign a number to a key:
1. Open the contact card.
2. Scroll to the phone number you want and select
Options
→
Assign speed dial
.
3. Scroll to a number key and press the
Assign
soft key.
Contacts and Calendar
43
4. If speed dialling is not activated, press the
Yes
soft key.
When you return to the contact card view, you will see the
speed dial icon on the right side of the number.
To dial by speed dialling:
Make sure that the speed dialling setting is activated (see page
138), and press and hold the number key assigned to the
number you want in Standby mode.
Adding a ringtone for a contact card
You can set a ringtone for each contact card and group. When
a person calls you, the phone plays the chosen ringtone if the
person’s contact information is saved in Contacts.
1. Open a contact card.
2. Select
Options
→
Ringing tone
.
3. Select the ringtone you wish to use for the contact or
group.
Note
: For an individual contact, the phone always uses the
ringtone that was assigned last. If you first change a group
ringtone and then the ringtone of a single contact that
belongs to that group, the ringtone of the contact is used
the next time the contact calls you.
Synchronising contacts with other devices
You can synchronise contact information between the phone
and other Bluetooth devices using the default sync profile.
From the contact list, press the
Options
soft key and select
Synchronisation
→
Start
.
Contacts and Calendar
44
Managing contact cards by group
You can create contact groups, which can, for example, be
used as distribution lists for sending text messages and
emails.
Creating contact groups
1. From the contact list, press the Right key to open the group
list.
2. Select
Options
→
New group
.
3. Enter a name for the group and press the
OK
soft key.
4. Select the group you just created and select
Options
→
Add members
.
5. Select the contacts you want to add and press the
OK
soft
key.
6. Press the
Back
soft key to return to the group list.
Editing contact groups
From the group list, scroll to a group and:
• To change the group name, select
Options
→
Rename
.
• To assign a ringtone to the group, select
Options
→
Ringing tone
.
• To remove members from the group, access the group’s
member list, and select
Options
→
Remove from group
.
• To delete the group, select
Options
→
Delete
.
Contacts and Calendar
45
Calendar
In Calendar, you can keep track of appointments, meetings,
birthdays, anniversaries, and other events. You can also set a
calendar alarm to remind you of upcoming events.
Press to open the Menu, and then select
Organiser &
Tools
→
Calendar
.
Creating calendar entries
1. On the monthly calendar, scroll to the date you want.
2. Select
Options
→
New entry
and select:
•
Meeting
to remind you of an appointment that has a
specific date and time.
•
Memo
to write a general memo for a day.
•
Anniversary
to remind you of birthdays or special
dates. Anniversary entries are repeated every year.
•
To-do
to write a task note.
3. Fill in the fields.
On the
Synchronisation
field, you can specify how your
phone deals with the entry in synchronisation with a PC. If
you select
Private
, after synchronisation the particular
calendar entry can be seen only by you. If you select
Public
, the calendar entry is visible to those who have
access to view your calendar online. If you select
None
,
the calendar entry will not be copied to your PC when you
synchronise your calendar.
4. Press the
Done
soft key to save the entry.
Contacts and Calendar
46
Viewing Calendar
You can view the calendar in the month, week, or day view.
Month view
When you access Calendar, you will see your appointments in
the month view. You can change the default view screen. See
page 49.
If you are viewing another view, press repeatedly or select
Options
→
Month view
. In the month view, today’s date is
underlined and dates that have calendar entries are marked
with icons at the bottom right corner.
• To move to the day view, select the date you want to open.
• To go to a certain date, select
Options
→
Go to date
. Enter
the date and press the
OK
soft key.
Tip
: Pressing in the month or week view highlights today’s
date.
Week view
To switch to the week view, press repeatedly or select
Options
→
Week view
. In the week view, today’s date is
underlined.
To view or edit an entry, select the cell that has the entry to
switch to the day view and select the entry you want. The
following entry icons are available in the week view.
• No icon: Meeting
In the week view, the synchronisation indicators display in
different colours; green for
Private
, gray for
Public
, and
pink for
None
.
•: Memo
• : Anniversary
•: To-do
Contacts and Calendar
47
Day view
In the month view or week view, select the date you want to
switch to the day view.
In the day view, calendar entries for the selected day appear.
The entries are grouped according to their starting times. Day
notes and anniversaries are placed at the top of the list.
Editing calendar entries
1. From the day view, select an entry.
2. Edit the entry fields.
To add a description about a meeting entry, select
Options
→
Add description
. You can create a new description note
or select one of the existing notes.
3. Press the
Done
soft key.
Stopping a calendar alarm
The alarm duration is one minute. When the alarm sounds,
press the
Stop
soft key to stop the calendar alarm or the
Silence
soft key to mute the alarm. If you press the
Silence
soft key, the
Snooze
soft key appears. Press the key to stop
the alarm and cause it to sound again after a specified time.
Contacts and Calendar
48
Deleting calendar entries
When deleting calendar entries, you will have options to delete
specific entries.
Deleting one entry
1. From the day view, select an entry.
2. Select
Options
→
Delete
.
3. When you delete a repeating entry, choose one of the
following options:
•
All occurrences
: all entries are deleted.
•
This entry only
: only the currently selected entry is
deleted.
Deleting all entries
1. From the month view, select
Options
→
Delete entry
.
2. Select one of the following options:
•
Before date
: deletes all of the entries stored for the
dates before a specified date.
•
All entries
: deletes all of the entries stored in Calendar.
3. Specify the date you want and press the
OK
soft key, or
press the
Yes
soft key to confirm the deletion.
Contacts and Calendar
49
Changing calendar settings
From any view, select
Options
→
Settings
to access the
following options:
•
Calendar alarm tone
: allows you to select a personalised
alarm tone.
Note
: The volume for the calendar alarm tone depends on the
current profile setting.
•
Alarm snooze time
: allows you to set a snooze time for
calendar alarms.
•
Default view
: allows you to select the view that is shown
when you first open Calendar.
•
Week starts on
: allows you to change the starting day of
the week view.
•
Week view title
: allows you to change the title of the
week view to be the week number or the date.
50
5
Entertainment
This chapter provides you with information about applications
in which you can enjoy the use of multimedia files.
Camera
You can take photos of people or events or record video clips
with sound while on the move.
Important
:
• Do not take photos or record videos of people without their
permission.
• Do not take photos or record videos in places where cameras are
not allowed.
• Do not take photos or record videos in places where it may
interfere with another person’s privacy.
Using the camera
The camera produces JPEG photos. JPEG is a standardised
image compression format. JPEG files can be viewed with most
common image viewers, image editors, and web browsers. You
can recognise these files by their JPG extensions.
Taking a photo
1. In Standby mode, press and hold . You can also press
and then select
Camera
.
The camera turns on and the display activates as a
viewfinder in Wide View mode.
2. Locate the image you want by moving the phone and
aiming the camera lens at the subject.
Entertainment
51
3. Make the desired adjustments.
Use the following keys to change the camera setting
options:
• Left/Right keys: zooms in or out.
• Down key: switches to Camcorder Preview mode.
• : switches between Sequence mode ( ) and
Normal mode.
• : changes the flash mode. ( : Auto, : Night)
• : changes the memory where the photo is saved.
( : phone’s memory, : memory card)
• : allows you to adjust the brightness.
• : allows you to change the white balance mode.
• : allows you to change the colour tone.
• : set the time delay before taking a photo.
• : opens the
Images
folder in My files.
• : allows you to change the camera settings. For
details, see page 54.
• : hides or shows the icons on the Camera Preview
screen.
4. When the image you want to capture appears on the
screen, press or .
Do not move the phone before the camera starts to save
the photo.
After the photo has been saved, press the
Options
soft key to
access the following options:
•
Image mode
: switches to Camera Preview mode.
•
Video mode
: switches to Camcorder Preview mode.
•
Delete
: deletes the photo.
•
Send
: allows you to send the photo to other people.
Entertainment
52
•
Use image
: sets the photo as wallpaper for Standby mode
or as the caller ID image for a contact card.
•
Rename image
: allows you to change the name of the
photo.
•
Go to My files
: opens the
Images
folder in My files.
•
Settings
: allows you to change the camera settings. See
page 54.
•
Exit
: turns off the camera.
Note
: The resolution of a digitally zoomed
is lower than
that of a non-zoomed
, but the image remains the
same size. You may notice the difference in image quality if
you view the
on a PC.
Using the camcorder
You can record video clips. Depending on the image quality
setting, recorded video clips are in MP4 or H263 format.
Recording a video clip
1. From the camera viewfinder, press the Down key.
The camcorder viewfinder is activated in Wide View mode.
2. Locate the image you want by moving the phone and
aiming the camera lens at the subject.
3. Make the desired adjustments.
Use the following keypad to change the camcorder setting
options:
• Left/Right keys: zooms in or out.
• Up key: switches to Camera Preview mode.
• : mutes ( ) or unmutes the audio.
Entertainment
53
• : changes the flash mode. ( : Auto, : Night)
• : changes the memory where the video clip is saved.
( : phone’s memory, : memory card)
• : allows you to adjust the brightness.
• : allows you to change the white balance mode.
• : allows you to change the colour tone.
• : opens the
Video clips
folder in My files.
• : allows you to change the camera settings. For
details, see page 54.
• : hides or show the icons on the Camera Preview
mode screen.
4. Press or to start recording. The timer on the screen
shows you the elapsed time.
To pause recording at any time, press the
Pause
soft key or
. To resume, press the Continue soft key or .
5. Press the Stop soft key or to stop recording.
After the video clip has been saved, press the
Options
soft
key to access the following options:
•
Image mode
: switches to Camera Preview mode.
•
Video mode
: switches to Camcorder Preview mode.
•
Play
: plays the video clip.
•
Delete
: deletes the video clip.
•
Send
: allows you to send the video clip to other people.
•
Rename
: allows you to change the name of the video clip.
•
Go to My files
: opens the
Video clips
folder in My files.
•
Settings
: allows you to change the camcorder settings.
See the next section.
•
Exit
: turns off the camcorder.
Entertainment
54
Changing camera settings
You can configure the default camera settings. These settings
will be applied to all subsequent photos or video clips.
On the viewfinder screen, select
Options
→
Settings
to
access the following options:
•
: Set the default settings for taking photos.
Image quality
: Select an image quality. The better the
image quality, the more memory the image consumes.
Show captured image
: Set whether the camera shows
the taken photo before saving it, or saves the photo
automatically.
Image resolution
: Select an image resolution setting.
Default image name
: Set the default name format for
storing photos.
Memory in use
: Select the default memory location for
saving photos.
Light metering
: Select your preferred light metering
system. Light metering provides better exposure balance in
your images. If you select
Spot
, it measures light in the
centre of the frame. Use
Matrix
for general shooting.
•
Video
: Set the default settings for recording videos.
Length
: Select the recording time limit. If you select
Short
, the phone records a video of up to 300 KB, which is
the limit for sending a multimedia message. If you select
Maximum
, the phone can record up to 1 hour if there is
sufficient memory.
Video resolution
: Select a video resolution setting.
Default video name
: Set the default name format for
storing video clips.
Memory in use
: Select the default memory location for
saving video clips.
Entertainment
55
Music player
Using Music player, you can play music files. You can download
MP3 files from the wireless web or transfer ones from a PC by
using PC Studio or a memory card.
Open the multimedia launcher and select
Music Player
. You
can also press to open the Menu, and then select
Entertainment
→
Music
→
Music player
.
Using the music library
The music player provides you with the music library
containing the default playlists. Each playlist sorts music files
on your phone’s memory or memory card by its specific
category.
1. From the music player screen, select
Options
→
Music
library
.
2. Select
Options
→
Update Music library
.
3. Select the playlist you want.
4. Select
Options
→
Play
to begin playing music.
Playing music files
From the music player screen, press or to play the
first music file on the playlist.
While playing music files:
• To pause or resume playback, press .
• To adjust the volume, press the Left or Right key. You can
also press / or
/
.
Entertainment
56
• To skip to the previous or next file on the playlist, press the
Up or Down key, or / .
• To scan forward or backward in a file, press and hold the Up
or Down key, or / .
• To stop playback, press .
Creating a playlist
You can create your own playlist with your favourite music
files.
1. Open the music library and select
Track lists
.
2. Select
Options
→
New track list
.
3. Enter a list name and press the
OK
soft key.
4. Open the added playlist and select
Options
→
Add tracks
.
5. Scroll to a music file and select
Options
→
Select
.
6. Repeat steps 4 and 5 to add more music files.
You can remove a file by selecting
Options
→
Remove
from track list
.
7. When you have finished, select
Options
→
Play
to begin
playing music.
Using music player options
On the music player screen, press the
Options
soft key. You
can access the following options:
•
Music library
: opens the music library.
•
Open ‘Now playing’
: opens the playlist currently playing.
Entertainment
57
•
Download tracks
: launches the web browser so that you
can download music files.
•
Random play
: allows you to set the music player to play
tracks in random.
•
Loop
: allows you to set the music player to play one track
or all tracks repeatedly.
•
Equaliser
: allows you to select preset equaliser settings to
enhance the music you listen to. The equaliser setting takes
effect only when you are listening to music through a
headset.
•
Add to track list
: allows you to add the current music file
to another playlist.
•
Use tone
: sets the current music file as your call ringtone
or a ringtone for a contact.
•
Play in background
: closes the music player, leaving
music still playing in the background.
•
View details
: shows the properties of the currently
selected file.
•
Exit
: closes the music player.
Accessing online music services
You can download various music files or enjoy your favourite
music by using an online playlist from Vodafone live!, a web-
based services provided by Vodafone.
From the Music main view, select
Music store
to access a
preset music download service, or
My wishlist
to access your
online playlist.
Entertainment
58
RealPlayer
With RealPlayer, you can play media files, such as music files,
video files, sound files, and streaming live contents from the
wireless web, stored in the phone’s memory or on the memory
card, if you use one.
Files with extensions .3gp, .mp4, .rm, .ram, .ra, and .rv are
supported by RealPlayer.
Open the multimedia launcher and select
RealPlayer
. You can
also press to open the Menu, and then select
Entertainment
→
RealPlayer
.
Playing media files
You can play any music or video file, or play a file directly from
the wireless web.
Playing media files from the phone’s memory or the
memory card
1. Select
Options
→
Open
and select:
•
Most recent clips
to play one of the most recent files or
playlist played. Select a file from the list.
•
Saved clip
to play a file saved in the phone’s memory or
on the memory card, if available. Select a memory and
then select a file.
2. Use the following options during playback:
If you are playing a video file:
• To adjust the volume, press
/
.
• To move backward or forward through a file, press and
hold the Up or Down key.
• To pause playback, press the
Pause
soft key.
Entertainment
59
• To resume playback, select
Options
→
Continue
. To
view the video on a full screen, select
Continue in full
screen
.
• To stop playback, press the
Stop
soft key.
If you are playing a music file, see page 55.
Playing streaming live content from the wireless web
In RealPlayer, you can open an rtsp://URL address or http link
to a .ram file, a text file containing an rtsp link.
1. Select a streaming link from the web browser or a file
containing the address for the streaming content.
The display shows a confirmation message for connecting
to the server.
2. Press the
Yes
soft key to confirm.
Once you are connected to the server, playback begins with
buffering of the streaming content.
3. While playing:
• To adjust the volume, press
/
.
• To pause playback, press the
Pause
soft key.
• To resume playback, select
Options
→
Resume
.
• To stop playback, press the
Stop
soft key.
Changing RealPlayer settings
To change the video player settings, select
Options
→
Settings
to access the following options:
•
Video
: allows you to change the settings for playing
videos.
Contrast
: Adjust the brightness of video clips by pressing
the Left or Right key.
Loop
: Select
On
to play video clips repeatedly.
Entertainment
60
•
Streaming
: allows you to change the settings for
accessing a streaming server.
Proxy
: Set up the proxy server to be used for streaming
content.
-
Use proxy
: Select whether or not a proxy is used. If you
want to use a proxy server, select
Yes
and specify the
following entries.
-
Proxy server address
: Enter a proxy server address.
-
Proxy port number
: Enter a proxy server port number.
Network
: Change items from the following list of network
settings:
-
Default access point
: Enter the default access point for
connecting to a network.
-
Online time
: Select the length of time RealPlayer stays
online when inactive. After the specified period of
inactivity,
RealPlayer
will be disconnected from the
server.
-
Lowest UDP port
: Enter the lowest number of the
server's port range.
-
Highest UDP port
: Enter the highest number of the
server's port range.
Video Editor
With Video Editor, you can edit or make videos by combining
photos or videos.
Press to open the Menu, and then select
Entertainment
→
Video Editor
.
Entertainment
61
Cropping a video
1. From the Video Editor main view, select
Edit video
.
2. Select a video file.
3. Press to start playback.
4. Mark the beginning and end of the new video:
• Press the
Start
soft key at the point where you want the
new video to begin.
• Press the
End
soft key at the point where you want the
new video to end.
5. Select
Options
→
Settings
and change the properties for
saving the video file, such as image quality, name prefix,
and storage location.
6. When you have finished, select
Options
→
Save
.
After saving the new video, the phone plays the video
automatically.
Adding audio to a video
1. From the Video Editor main view, select
Edit video
.
2. Select a video file.
3. Press to start playback.
4. Select
Options
→
Audio
and choose one of the following
options:
•
Audio dubbing
: Add one of the sounds you have saved.
•
Live dubbing
: Add audio by recording a new sound.
Entertainment
62
5. Select
Options
→
Settings
and change the properties for
saving the video file, such as image quality, name prefix,
and storage location.
6. When you have finished, select
Options
→
Save
.
Making a slide show
You can combine photos to make a slide show with your
favourite photos.
1. From the Video Editor main view, select
Make photo mo...
2. Select the photos you want and press the
Done
soft key.
3. Use the following options:
• To change the color tone or apply a special effect, select
Options
→
Effect
.
• To insert a photo or a text slide, select
Options
→
Insert
→
an option.
• To change how your slide show plays from one video clip
or photo to the next, select
Options
→
Transition
.
• To add audio to your slide show, select
Options
→
Narration
.
• To set the intervals between slides, select
Options
→
Duration
.
• To change the properties for saving the video file, such
as image quality, name prefix, and storage location,
select
Options
→
Settings
.
4. When you have finished, select
Options
→
Save
.
Entertainment
63
Making a storyboard
You can combine photos and videos to make a storyboard.
1. From the Video Editor main view, select
Storyboard
.
2. Select the photos and videos you want and press the
Done
soft key.
You can use the same options as when making a slide
show. See the previous section.
3. When you have finished, select
Options
→
Save
.
Radio
You can listen to your favourite music stations and news by
using the FM radio on your phone.
Listening to the FM radio
First, you must connect your phone to the headset, which
serves as a radio antenna.
1. Plug a headset into the headset jack or multi-function jack
on the phone, according to the connecter type.
2. Open the multimedia launcher and select
Radio
. You can
also press to open the Menu, and then select
Entertainment
→
Music
→
Radio
.
3. Select or to scan through available radio stations.
4. While listening to the radio:
• To access a radio station by manually entering the
frequency, select
Options
→
Manual tuning
.
• To adjust the volume level, press
/
.
Entertainment
64
• To switch sound output to the phone speaker, select
Options
→
Activate loudspeaker
.
• To access other functions while listening to the radio,
select
Options
→
Play in background
.
Setting up your favourite radio station list
For quick access to them at a later time, set up a station list by
using the automatic tuning feature that saves all available
stations or by manually saving the stations you want. Once
you have set up a station list, you can access the stations by
selecting or from the radio screen.
Saving radio stations by automatic tuning
1. From the radio screen, select
Options
→
Stations
to
access the station list.
2. Select
Options
→
Auto-s
ave stations
.
3. Press the
Yes
soft key to confirm replacing existing
stations.
4. When you have finished, press the
Back
soft key.
Saving a radio station manually
1. From the radio screen, scroll to the radio station you want.
2. Select
Options
→
Save station
.
3. Select an empty location.
4. Enter a station name and press the
OK
soft key.
Entertainment
65
Games
You can download various games from a preset website
provided by Vodafone and play games on your phone.
Downloading games
1. Press to open the Menu, and then select
My
Applications
→
Game Store
.
2. Search for the game you want and follow the onscreen
instructions to download and install the game.
When the game is installed correctly, it will be displayed in
the My Applications main view.
Playing games
Select the game you want to play from the My Applications
main view. How to play may differ from game to game.
My files
Use My files to review and organise your images, sound clips,
video clips, streaming live contents from the wireless web, and
RAM files.
Press to open the Menu, and then select
My files
.
Opening files
In a folder, select any file to open it. Each file will open in its
corresponding application as follows:
• Images - open in the image viewer. See the next section.
Entertainment
66
• Video clips, RAM files, and streaming live content - open
and play in RealPlayer.
• Music files - open and play in the music player.
• Sound clips - open and play in the music player.
• Presentations (SVG or Flash SWF files) - open and play in
SVG Viewer or Flash Lite Player.
To view all of the media files, select
All files
from the My files
main view.
Viewing images
In this folder, you can access photos you have taken using the
camera and images you have downloaded from the wireless
web or received in multimedia messages.
Viewing an image
1. On the My files main view, select
Images
.
2. Select an image file.
3. Press the Left or Right key to view the next or previous
image in the current folder.
Using options in an image view
You can use the following options while you are viewing an
image:
• To zoom in or out, select
Options
→
Zoom in
or
Zoom
out
.
• To view the image on a full screen, select
Options
→
Full
screen
. To return to the normal view, press the right soft
key, or select the left soft key and select
Normal screen
.
• To pan the image to the direction you want when you are
zooming in, press the Navigation keys.
Entertainment
67
• To rotate the image 90 degrees, select
Options
→
Rotate
→
Left
or
Right
.
• To set the image as wallpaper for the standby screen, select
Options
→
Use image
→
Set as wallpaper
.
• To set the image as a caller ID image for a contact card,
select
Options
→
Use image
→
Assign to contact
.
• To print the image by connecting your phone with a
compatible printer via USB, select
Options
→
Print
→
PictBridge
.
Note
: PictBridge lets you create a direct USB connection from
your phone to the printer, so you can print images
directly without using a PC.
• To add printing information to the image, select
Options
→
Print
→
DPOF
. This option is only available for images
stored on a memory card.
Note
: As these options are only for viewing, changes made in the
image view are not saved.
Using the keypad shortcuts
In an image view, you can use the following keys:
• , : rotates the image 90 degrees counterclockwise
or clockwise.
• , , , : pans the image to the direction you
want while zooming in. These keys function as the
Navigation keys.
• , : zooms in or out.
• : switches the viewer to Full Screen mode or back to
Normal mode.
Entertainment
68
Playing videos
In this folder, you can access video clips you have recorded
using the camera, or video files you have downloaded from the
wireless web or received in multimedia messages.
1. On the My files main view, select
Video clips
.
2. Select a video clip.
RealPlayer opens and begins playback. For details, see
page 58.
Listening to music
In this folder, you can access music files you have downloaded
from the wireless web or received in multimedia messages.
.mp3 and .aac files are supported.
1. On the My files main view, select
Tracks
.
2. Select a file or playlist.
For a playlist, select
Play
. The music player opens and
begins playback. For details, see page 55.
Playing sounds
In this folder, you can access voice memos you have recorded,
and sound files you have downloaded from the wireless web or
received in multimedia messages. .ra, .wav, .midi, .mmf, and
.amr files are supported.
1. On the My files main view, select
Sound clips
.
2. If necessary, select the subfolder you want.
3. Select a sound clip.
The music player opens and begins playback. For details,
see page 55.
Entertainment
69
Accessing links for multimedia streaming
In this folder, you can access RTSP links, allowing you to
access streaming audio and video services.
Adding a new link
1. On the My files main view, select
Streaming links
.
2. Select
Options
→
New link
.
3. Select a memory location, if you inserted a memory card
into the phone.
4. Enter the link name and press the Down key.
5. Enter the URL string you want and press the
OK
soft key.
Accessing a link
1. From the link list, select a link.
2. Press the
Yes
soft key to confirm the connection to the
server.
Downloading files
You can download files from the wireless web. The downloaded
files will be saved in an appropriate folder visible in My files.
Select
Downl. graphics
,
Downld. videos
,
Downld. tracks
,
or
Downld. sounds
from the top of each list. The web
browser opens, allowing you to choose a bookmark for the
website from which to download or enter a URL address of the
website.
Entertainment
70
Mobile TV
In Mobile TV, you can watch various TV channels via a mobile
TV service provided by Vodafone.
Press to open the Menu, and then select
Entertainment
→
Mobile TV
.
Subscribing to the TV service
You need to subscribe to an appropriate TV service. From the
Mobile TV main view, select
Subscribe
and follow the
onscreen instructions.
Searching for TV channels
1. From the Mobile TV main view, select
All channels
. The
phone displays a list of all TV channels.
2. Select the channels you want to watch.
Watching TV
1. From the Mobile TV main view, select
Mobile TV
.
2. From your favourite channel list, select the channel you
want.
3. While watching TV:
• To move to the previous or next channel, press the Up or
Down key.
• To adjust the volume, press
/
.
• To save the image of the current screen, select
Options
→
Capture
.
• To record the program, select
Options
→
Record
.
Entertainment
71
Flash Player
You can play flash movie files on your phone. The phone
supports .swf files.
Press to open the Menu, and then select
My Applications
→
Flash Player
.
Playing a flash file
Select a file from the list. During playback, you can use the
following options:
• To adjust the volume, press
/
.
• To pause playback, select
Options
→
Pause
.
• To resume playback, press the
Resume
soft key.
• To view the video on a full screen, select
Options
→
Full
screen
.
• To stop playback, select
Options
→
Stop
.
72
6
Message services
Your phone provides you with various messaging service
applications:
•Messaging
•Voicemail
• Vodafone Messenger (Instant messaging service)
Messaging
In Messaging, you can create, send, receive, and manage:
• text messages,
• multimedia messages,
•emails,
• audio messages,
• postcards, and
• smart messages: special text messages containing data.
In addition, you can receive service messages and cell
broadcast messages, and send service commands.
Press to open the Menu, and then select
Messaging
.
Message folders
When you open Messaging, the
New message
function and a
list of the following default message folders appears:
•
Inbox
: This folder stores all received messages, except for
emails and cell broadcast messages.
•
My folders
: You can access message templates or organise
your messages into folders.
Message services
73
•
Vodafone Mail
(Mailbox): When you open this folder, you
can either connect to your remote mailbox to retrieve new
emails or view previously retrieved emails offline.
•
Drafts
: This folder stores draft messages that have not
been sent.
•
Sent
: This folder stores the most recent messages that
have been sent successfully.
•
Outbox
: This folder is a temporary storage place for
messages waiting to be sent.
•
Reports
: This folder stores delivery reports for sent
text
message
s and multimedia messages. You can request the
network to send a delivery report by setting the
Receive
report
option of the message setting options.
Notes
:
• Receiving a delivery report for a multimedia message that has
been sent to an
email
address might not be possible.
• Messages or data that have been sent via Bluetooth are not
saved in the
Drafts
or
Sent
folder.
Creating messages
Composing and sending text messages
1. Select
New
message
→
Text message
.
2. Press to select recipients from Contacts, or enter the
phone number of the recipient. Add a semicolon (;) to
separate each recipient.
Message services
74
3. Press the Down key and enter the message text.
• To add a message template, select
Options
→
Insert
→
Template
.
• To set the options for sending the message, select
Options
→
Sending options
. See page 88.
Note
: If your text exceeds 160 characters, it is sent as two or
more messages, and sending the message may cost
you more.
4. Select
Options
→
Send
to send the message.
Composing and sending multimedia messages
A multimedia message can contain a combination of text and
video clips, or text, images, and sound clips in one page, but
not a combination of images and video clips in one page. You
can send multimedia messages phone to phone or phone to
email.
This function can be used only if it is supported by your service
provider. Only devices that offer compatible multimedia
message or email features can receive and display multimedia
messages.
Notes
:
• Before using the multimedia message service, you need to
define an access point. See page 143.
• When you are sending a multimedia message to any phone
other than an SGH-i450, you should use smaller image sizes
than 160 X 120 and sound clips that are no longer than 1
minute.
1. Select
New message
→
Multimedia message
.
2. Press to select the recipients from Contacts, or enter
the phone number of the recipient. Add a semicolon(;) to
separate each recipient.
Message services
75
3. Press the Down key and enter the message subject.
4. Press the Down key and enter the message text.
5. Add objects to the multimedia message in any order you
want.
• To add a media file, select
Options
→
Insert object
→
a
media type
→
a file.
• To add a new item, select
Options
→
Insert new
→
a
media type. You can take a new photo, record a voice
memo or video clip, or add a new slide.
Note
: To add a video file, the resolution of the video must
be 176 x 144 or lower.
• To remove an added item, select
Options
→
Remove
→
the item you want.
• To change the message layout, select
Options
→
Place
text last
or
Place text first
.
• To view the created message, select
Options
→
Preview
.
• To access added items, select
Options
→
Objects
.
• To enter additional information, select
Options
→
Address fields
→
CC
or
Subject
.
• To set the options for sending the message, select
Options
→
Sending options
. See page 89.
Note
: You can add an image and a sound, or a video to a slide.
When you add more than one item in a media type, a
new slide is automatically added. You can scroll through
the slide by pressing the Up or Down key or selecting
Options
→
Move
→
a slide.
6. Select
Options
→
Send
to send the message.
Message services
76
Composing and sending audio messages
You can compose and send a message after recording a voice
memo.
1. Select
New message
→
Audio message
.
2. Select
Options
→
Insert sound clip
→
an adding option.
3. Record a new voice memo or select a sound file from My
files.
4. Press the Up key, and press to select the recipient(s)
from Contacts, or enter the email address of the recipient in
the
To
field. Add a semicolon (;) to separate each recipient.
5. Select
Options
→
Send
to send the message.
Composing and sending a postcard
You can send a postcard via the postal service, if your country
supports it. The postal service will print your message as an
actual postcard and deliver it to a recipient.
Note
: Depending on the country, this feature may be unavailable
and be labelled differently.
1. Select
New message
→
live! Postcard
.
2. Select
Options
→
Edit address
.
3. Enter information and the postal address of the recipient
and press the
Done
soft key.
4. Select
Options
→
Greeting text
.
5. Enter the message text and press the
Done
soft key.
6. Select
Options
→
Insert image
→
Existing
or
New
.
Message services
77
7. Select an image or take a new photo.
8. Select
Options
→
Send
.
9. Press the
Send
soft key to send the postcard.
Composing and sending emails
You can send emails that include text, images, sound clips,
video clips, or other attachments. Before using the email
service for the first time, you need to define a mailbox by
using
Mailboxes
of the email setting options. See page 91.
1. Select
New message
→
E-mail
.
2. Press to select the recipient(s) from Contacts, or enter
the email address of the recipient in the
To
field. Add a
semicolon (;) to separate each recipient.
If you want to send a copy of your email to someone, press
the Down key and enter the address in the
Cc
field.
3. Press the Down key and enter the email subject.
4. Press the Down key and enter the email text.
• To add an attachment to the email, select
Options
→
Insert
→
a media type
→
a file.
• You can also add an attachment to an email by selecting
Options
→
Attachments
. The attachment list opens
where you can add, view, and remove attachments.
• To remove an attachment, open the attachment list,
scroll to the attachment, and select
Options
→
Remove
.
• To set the options for sending the email, select
Options
→
Sending options
. See page 91.
5. Select
Options
→
Send
to send the email.
Message services
78
Inbox - receiving messages
Messages and data can be received using text message or
multimedia message service, or via Bluetooth connections.
Opening a received message
When you receive a message, press the
Show
soft key to
open the message. Press the
Exit
soft key to close the note. If
you have more than one new message, press the
Show
soft
key to open
Inbox
to see the message headings.
Viewing messages in Inbox
In
Inbox
, the message icons tell you what kind of a message
it is. Here are some of the icons that you may see:
• for an unread
text message
,
• for an unread smart message which may include a
business card or a calendar entry,
•
for a multimedia message notification,
•
for an unread multimedia message,
• for an unread service message,
• for data received via Bluetooth connections, and
• for a message of unknown type
To read a message:
1. Select a message from the list.
2. Use the Up or Down key to move up and down in a
message.
3. Press the Left or Right key to move to the previous or next
message in the folder.
Message services
79
Options in different message viewers
To use message options, press the
Options
soft key in a
message view. Available options depend on the type of the
message you have opened:
•
Save
: saves the received file to
My files
.
•
Save business card
: saves the received contact card in
Contacts
.
•
Save to Contacts
: saves the selected number in the
message to Contacts.
•
Save to Calendar
: saves the memo in a smart message to
Calendar
.
•
Play
:
plays the sound, video, or presentation from a
multimedia message.
•
Reply
: allows you to send a reply to the sender.
•
Forward
: copies the message contents to an editor.
•
Delete
: deletes a message.
•
Call
: calls the sender by pressing .
•
Create message
: sends a message to the selected
numbers.
•
Copy
: copies the selected number so that you can paste it
when composing a message or creating a contact card.
•
Automatic find off
: deactivates the links of the URLs,
phone numbers and, email addresses.
•
View
: displays an image in a multimedia message.
•
Objects
: displays a list of multimedia objects in a
multimedia message.
Important
: Multimedia message objects may contain viruses or
otherwise be harmful to your phone or PC. Do not open any
attachment if you are not sure of the trustworthiness of the
sender. For more information, see “Certificate management” on
page 135.
Message services
80
•
Message details
: shows detailed information about a
message.
•
Move to folder
: moves message(s) to
My folders
or one
of the folders you have created. See “Moving items to an
application folder” on page 25.
•
Exit
: exits the Messaging application.
Receiving smart messages
Your phone can receive many kinds of smart messages, which
are text messages that contain data (also called Over-The-Air,
(OTA messages). To open a received smart message, open
Inbox
and select a smart message ( ).
•
Picture message
: to save a picture in the
Picture msgs
.
folder for later use, select
Options
→
Save
.
•
Business card
: to save contact information, select
Options
→
Save business card
.
Note
: If certificates or sound files are attached to business
cards, they are not saved.
•
Ringing tone
: to save a ringtone to
My files, select
Options
→
Save
.
•
Operator logo
: to save a logo, select
Options
→
Save
. The
operator logo can now be seen in Standby mode instead of
the network operator’s own identification.
•
Calendar entry
: to save an entry to Calendar, select
Options
→
Save to Calendar
.
•
WAP message
: to save a bookmark or setting, select
Options
→
Save to bookmarks
or
Save to settings
. If
the message contains both browser access point settings
and bookmarks, select
Options
→
Save all
to save the
data.
•
E-mail notification
: tells you how many new emails you
have in your remote mailbox.
Message services
81
In addition, you can receive an SMS service number, voicemail
server number, sync profile settings, access point settings, and
so on. To save the settings, select
Options
→
Save
,
Save to
voice mail
,
Save to settings
or
Save to e-mail sett.
Service messages
Service messages are notifications of, for example, news
headlines, and they may contain a text message or an address
for a browser service. For availability and subscription, contact
your service provider.
Service providers can update an existing service message
every time a new service message is received. When service
messages expire, they are deleted automatically.
1. In
Inbox
, select a service message ( ).
2. To download or view the service, press
Download
message
. The note
Downloading message
displays. The
phone starts to make a data connection, if needed.
3. Press the
Back
soft key to return to
Inbox
.
My folders
In My folders, you can organise your messages into folders,
create new folders, and rename and delete folders. For more
information, see “Moving items to an application folder” on
page 25.
You can also create and store text templates in this folder. Use
text templates to avoid rewriting messages that you send
often. Select
Templates
and:
• To create a new template, select
Options
→
New
template
.
• To send a message using a template, select
Options
→
Send
→
a sending method.
Message services
82
Vodafone Mail (Mailbox)
When you open this folder, you can connect to your Mailbox:
• to retrieve new email headings or messages, or
• to view your previously retrieved email headings or
messages offline.
Note
: When you create a new mailbox, the name you give to the
mailbox automatically appears in the Messaging main view.
You can have up to 6 mailboxes.
Viewing emails
When you open a mailbox, you can choose whether you want
to view the previously retrieved emails and email headings
offline, or connect to the email server.
Viewing emails when online
Select
Options
→
Connect
to connect to your mailbox. When
you are online, you are continuously connected to your
mailbox via a packet data connection.
Note
: If you are using the POP3 protocol,
email
s are not updated
automatically in Online mode. To see the newest
email
s,
you need to disconnect and then make a new connection to
your mailbox.
Viewing emails when offline
When your phone is not connected to your mailbox, you view
emails offline. This mode may help you to save on connection
costs, but you can access only previously retrieved emails.
Message services
83
Retrieving emails from a mailbox
1. If you are offline, select
Options
→
Connect
to start a
connection to your mailbox.
2. When you have an open connection to your mailbox, select
Options
→
Retrieve e-mail
.
•
New
to retrieve all new emails to your phone.
•
All
to retrieve all messages from the mailbox.
3. After you have retrieved the emails, you can continue
viewing them online, or select
Options
→
Disconnect
to
end the connection and view the emails offline.
Opening emails
Select the email you want to view.
• If the email has not been retrieved and you are offline, you
are asked to retrieve emails. Press the
Yes
soft key.
• If you are online, the email is automatically retrieved from
the mailbox. Note that the data connection is left open after
the email has been retrieved. Select
Options
→
Disconnect
to end the data connection.
Viewing email attachments
Open an email that has an attachment indicator ( ) and select
Options
→
Attachments
.
Important
:
Email
attachments may contain viruses or otherwise
be harmful to your phone or PC. Do not open any attachment if
you are not sure of the trustworthiness of the sender. For more
information, see “Certificate management” on page 135.
Message services
84
Opening an attachment
From the attachment list, select a file. The file opens in the
corresponding application.
Saving an attachment
From the attachment list, scroll to the file you want and select
Options
→
Save
. The file is saved in the corresponding
application.
Deleting emails
• To delete an email from the phone while still retaining it in
your mailbox. Select
Options
→
Delete
→
Phone only
.
Note
: Although you delete the message content, the email
heading stays in your phone. To remove the heading as
well, you need to first delete the email from your
remote mailbox and then make a connection to the
remote mailbox again to update the status.
• To delete an email both from the phone and from your
mailbox. Select
Options
→
Delete
→
Phone and server
.
Note
: If you are offline, the email is first deleted from your
phone. During the next connection, it is automatically
deleted from your mailbox. If you are using the POP3
protocol, emails marked to be deleted will be removed only
after you have closed the connection to your mailbox.
To cancel deleting an email both from the phone and from the
server, scroll to an email that has been marked to be deleted
during the next connection, and select
Options
→
Undelete
.
Message services
85
Outbox
Outbox
is a temporary storage place for messages that are
waiting to be sent.
Status of the messages in Outbox
•
Sending
: A connection is being made and the message is
being sent.
•
Waiting
: For example, if there are two similar types of
messages in Outbox, one of them is waiting until the first
one is sent.
•
Resend at
(time): Sending has failed. The phone tries to
send the message again after a time-out period. Select
Option
→
Send
if you want to restart the sending
immediately.
•
Deferred
: Sending places on hold. The phone tries to send
the message at a specified time.
•
Failed
: Sending has failed. The maximum number of
sending attempts has been reached.
Messages are placed in Outbox when your phone is outside the
network coverage area. You can also schedule emails to be
sent the next time you connect to your mailbox.
Reports
In
Reports
, you can view delivery reports for your text
messages and multimedia messages, if you set the
Receive
report
option to
Yes
in the
Text message
and
Multimedia
message
settings.
Note
: No delivery reports can be received for messages sent to
email addresses.
Message services
86
• To call a message recipient, scroll to the delivery report and
press or select
Options
→
Call
.
• To clear all reports, select
Options
→
Clear delivery
reports
.
Cell broadcast
You can access CB (cell broadcast) messages on various
topics, such as the weather or traffic conditions, received from
your service provider by selecting
Options
→
Cell broadcast
in the Messaging main view. For available topics and relevant
topic numbers, contact your service provider.
Opening a CB message
When you open the
Cell broadcast
folder, the screen shows:
• the status of the topic:
for subscribed messages
for unsubscribed messages
• the topic number, topic name, and whether it has been
flagged for Hotmark. You are notified when messages
belonging to a flagged topic have arrived.
Setting up a topic list
• To add a topic, select
Options
→
Topic
→
Add manually
.
Then enter the topic name and number.
• To change the name and number of a topic, scroll to it and
select
Options
→
Topic
→
Edit
.
• To remove a topic, scroll to the topic and select
Options
→
Topic
→
Delete
. To delete all topics, select
Options
→
Topic
→
Delete all
.
Message services
87
• To subscribe to a topic, scroll to the topic and select
Options
→
Subscribe
. To cancel the subscription to the
topic, select
Options
→
Cancel subscription
.
• To receive a notification when a message related to a topic
arrives, scroll to the topic and select
Options
→
Hotmark
.
To remove the hotmark setting, select
Options
→
Remove
hotmark
.
Note
: A packet data (GPRS) connection may prevent cell
broadcast reception. Contact your service provider for the
correct GPRS settings.
Viewing messages on a USIM/SIM card
Sometimes, text messages may be stored on the USIM/SIM
card, depending on their specifications.
Before you can view the messages stored on the USIM/SIM
card, you need to copy them to a folder on your phone.
1. In the Messaging main view, select
Options
→
SIM
messages
.
2. Select
Options
→
Mark/Unmark
→
Mark
or
Mark all
to
place a check mark on messages.
3. Select
Options
→
Copy
.
4. Select a folder. Go to the folder to view the messages.
Message services
88
Using the service command editor
You can send requests, such as activation commands for
network services, known as USSD commands, to your service
provider. For more information, contact your service provider.
To send a request:
• In Standby mode or when you have an active call, enter the
command number(s) and press , or
• If you need to enter letters as well as numbers in a request,
select
Options
→
Service command
from the Messaging
main view.
Messaging settings
The settings for the messaging services have been divided into
groups according to the different message types. Select the
settings you want to edit.
Settings for text messages
From the Messaging main view, select
Options
→
Settings
→
Text message
to open the following list of settings:
•
Message centres
: This option lists all of the SMS centres
that have been defined. You can add a new SMS centre by
selecting
Options
→
New message centre
.
•
Message centre in use
: You can set which SMS centre is
used for delivering
text message
s.
•
Character encoding
: Select a character encoding type.
Using
Full support
(Unicode) will reduce the maximum
number of characters in a message to about half.
•
Receive report
: When this network service is set to
Yes
,
the network informs you when a message has been
delivered.
Message services
89
•
Message validity
: If the recipient of a message cannot be
reached within the specified validity period, the message is
removed from the SMS centre. Select how long messages
are stored in the SMS centre.
Maximum time
is the
maximum amount of time allowed by the network for the
message to remain active.
•
Message sent as
: You can convert your
text message
s to
another format. For further information, contact your
service provider.
Note
: Change this option only if you are sure that your service
centre is able to convert
text message
s into other
formats.
•
Preferred connection
: Select a network connection type
to be used for sending text messages. See “Packet data” on
page 144.
•
Reply via same centre
: When this network service is set
to
Yes
, the recipient’s reply message is sent using the
same SMS centre. Note that this may not work between all
service providers.
Settings for multimedia messages
From the Messaging main screen, select
Options
→
Settings
→
Multimedia message
to open the following list of settings:
•
Image size
: Select the size of images in multimedia
messages. The options are
Small
(max. 160 x 120 pixels)
and
Large
(max. 640 x 480 pixels). When you send a
message to an email address, the image size is set to
Small
.
•
MMS creation mode
: Select the mode for creating
multimedia messages
Restricted
: the phone will not allow you to add
unsupported files or exceed the size limit.
Message services
90
Guided
: the phone will alert you when the message size
has exceeded the limit or you have added an unsupported
file.
Free
: you can add files in any type and size.
•
Access point in use
(Must be defined): Select which
access point is used as the preferred connection for the
multimedia message centre.
Note
: If you receive multimedia message settings in a smart
message and save them, the received settings are
automatically used for the preferred connection. See
“Receiving smart messages” on page 80.
•
Multimedia retrieval
: Select how you receive multimedia
messages.
Always automatic
to receive multimedia messages
regardless of where you are.
Auto in home netw.
to receive multimedia messages only
when you are in your home network.
Manual
to receive multimedia messages manually.
Off
if you do not want to receive multimedia messages or
advertisements.
Important
: When you are outside your home network,
sending and receiving multimedia messages may cost you
more. If the settings
Auto in home netw.
or
Always
automatic
have been selected, your phone can make an
active GPRS connection without your knowledge.
•
Allow anon. msgs.
: Set whether or not to receive
messages from anonymous senders.
•
Receive adverts
: Set whether or not to receive
multimedia message advertisements.
Message services
91
•
Receive report
: When this network service is set to
Yes
,
the network informs you when your message has been
delivered.
Note
: It may not be possible to receive a delivery report for a
multimedia message that has been sent to an email
address.
•
Deny report sending
: Select
Yes
if you do not want the
network to send delivery reports for received multimedia
messages.
•
Message validity
: If the recipient of a message cannot be
reached within the specified validity period, the message is
removed from the MMS centre. Set how long messages are
stored in the MMS centre.
Maximum time
is the maximum
amount of time allowed by the network for the message to
remain active.
Settings for emails
From the Messaging main screen, select
Options
→
Settings
→
E-mail
.
Select
Mailbox in use
, to select the mailbox you want to use.
Select
Mailboxes
to open a list of mailboxes that have been
defined. If no mailbox has been defined, press the
Yes
soft
key to confirm creating a mailbox. Set the following mailbox
parameters for each mailbox:
Connection settings
•
Incoming e-mail
: Customise the setting for receiving
emails.
User name
: Enter your user name, given to you by your
mail service provider.
Message services
92
Password
: Enter your password. If you leave this field
blank, you are prompted for the password when you try to
connect to your remote mailbox.
Incoming mail server
(Must be defined): The IP address
or host name of the mail server that receives your emails.
Access point in use
(Must be defined): This is the access
point used for the mailbox. Choose one from the list. For
more information on how to create an access point, see
also “Connection settings” on page 142.
Mailbox name
: Enter a name for the mailbox.
Mailbox type
: Select a mail server type.
Security (ports)
: Select a security type. Any amount of
data and messages can be sent securely.
Port
: Set a port number.
APOP secure login
(for POP3): Select
On
to authenticate
users on login to the POP3 server.
•
Outgoing e-mail
: Customise the setting for sending
emails.
My e-mail address
(Must be defined): Enter your email
address.
User name
: Enter your user name, given to you by your
mail service provider.
Password
: Enter your password. If you leave this field
blank, you are prompted for the password when you try to
connect to your remote mailbox.
Outgoing mail server
(Must be defined): The IP address
or host name of the mail server that sends your emails.
Access point in use
(Must be defined): This is the access
point used for the mailbox. Choose one from the list. For
more information on how to create an access point, see
also “Connection settings” on page 142.
Message services
93
Security (ports)
: Select a security type. Any amount of
data and messages can be sent securely.
Port
: Set a port number.
User settings
•
My name
: Enter your display name.
•
Send message
: Set whether to send e- mails immediately
or to send at the next connection.
•
Send copy to self
: Select
Yes
to save a copy of the email
to your mailbox and to the address defined in
My e-mail
address
.
•
Include signature
: Select
Yes
if you want to attach a
signature to your emails, and to enter or edit a signature
text.
•
New e-mail alerts
: Set whether the phone displays an
indicator icon when you receive a new email.
Retrieval settings
•
E-mail to retrieve
: Select whether to only retrieve email
headers from the server.
•
Retrieval amount
: Limit the number of email headers you
want to retrieve from the server.
•
IMAP4 folder path
(for IMAP4): Set the folder path you
want to synchronise with the server.
•
Folder subscriptions
(for IMAP4): Update the message
folder list to be synchronised.
Automatic retrieval
•
E-mail notifications
: Set whether to receive a notification
from the server when you receive a new email.
•
E-mail retrieval
: Set whether or not the phone
automatically retrieves emails from the server.
Message services
94
Settings for service messages
From the Messaging main view, select
Options
→
Settings
→
Service message
: The following list of settings opens:
•
Service messages
: Set whether or not to receive service
messages.
•
Download messages
: Choose
Automatically
if you want
the phone to automatically download service messages
when it is connected to the server, or
Manually
if you want
to manually connect to the server.
Settings for cell broadcast messages
Check with your service provider to see if Cell Broadcast (CB)
messaging is available and what the available topics and
related topic numbers are. From the Messaging main view,
select
Options
→
Settings
→
Cell broadcast
to change the
settings:
•
Reception
: Select
On
to receive CB messages.
•
Language
: Select
All
to receive cell broadcast messages in
every possible language, or
Selected
to choose in which
languages you wish to receive CB messages. If the
language you want is not found on the list, select
Other
.
•
Topic detection
: Select
On
to save a topic number
automatically when you receive a CB message that does
not belong to any of the existing topics. The topic number
is saved to the topic list and shown without a name.
Other settings
From the Messages main screen, select
Options
→
Settings
→
Other
to open the following list of settings:
•
Save sent messages
: Select
Yes
to save a copy of every
text message
, multimedia message, or email that you
have sent. Messages will be saved to the
Sent
folder.
Message services
95
•
Number of saved msgs.
: Define how many sent
messages can be saved to the
Sent
folder at a time. When
the limit is exceeded, the older messages will be deleted.
•
Memory in use
: Select a memory location to be used for
storing messages.
Voicemail
You can access the voicemail server to check new voicemails.
Press
to open the Menu, and then select
Settings
→
Call
mailbox
.
Connecting to the voicemail server
The service number of the voicemail centre is preset by your
service provider. If not, you first need to define the number of
your voicemail server. Enter the number obtained from your
service provider and press the
OK
soft key.
Now, you can access the voicemail server by selecting
Voice
mailbox
from the Call mailbox main view. You can also press
and hold in Standby mode. Follow instructions from the
server to check your voicemails.
Changing the voicemail server number
If you need to change the number of the voicemail server,
select
Options
→
Change number
from the Call mailbox
main view. Enter a new number and press the
OK
soft key.
Message services
96
Vodafone Messenger
Notes
:
• This feature can be used only if it is supported by your service
provider. Only phones that offer compatible instant messaging
features can receive and display instant messages.
• Depending on the country, this feature may be labelled
differently.
Vodafone Messenger is a way of sending text messages that
are delivered over TCP/IP protocols to online users (network
service). Your contact list shows you when the contacts on the
list are online and available to participate in a conversation.
Press to open the Menu, and then select
My Applications
→
Vodafone Messenger
.
Notes
:
• Depending on the network, the active chat session may
consume the phone’s battery faster and you may need to
connect the phone to a adapter.
• For using the Vodafone Messenger service, you need to set up a
server and other settings. See page 101.
Connecting to the Vodafone Messenger
service
When you access Vodafone Messenger, the phone prompts you
to define a server. If you have closed this prompt, select
Options
→
Log in
to log in to the Vodafone Messenger
service. Enter the user ID and password and press the
OK
soft
key.
To disconnect from the service, select
Log out
.
Message services
97
Starting a chat session
You can start a chat with your friends by various methods.
Starting from the conversation list
From the Vodafone Messenger main view, select
Conversations
to view the list of new and read instant
messages or invitations to conversations during an active chat
session. indicates new instant messages and indicates
invitations.
On the conversation list, scroll to a conversation, press the
Options
soft key and select:
•
Open
to open the conversation to start a chat session.
•
New conversation
to start a new conversation. You can
select a participant from the Conversations list or enter the
participant's ID manually, and then the phone sends an
invitation to her/him.
•
Block options
→
Add to blocked list
to block messages
from the current participiant. Select
Add ID to list
manually
to add a contact to the blocking list or
View
blocked list
to view blocked contacts. To unblock the
contact, select
Unblock
.
•
Change own availability
to change your connection
status.
•
Close conversation
to close the selected conversation.
•
Log out
to log out from the service.
•
Settings
to customise options for conversations or servers.
•
Exit
to close the Vodafone Messenger application.
Message services
98
Starting from the contact list
From the Vodafone Messenger main view, select
IM contacts
to view the contacts that you have added.
If you have received a new message from a contact, it is
indicated by . The status of each contact displays by the
following indicators.
• indicates an online contact.
• indicates an offline contact in the phone’s Contacts
directory.
• indicates a blocked contact.
• No indicator means that the contact is unknown.
Select a contact or select
Options
→
Open conversation
to
start a chat.
For details, see “Managing IM contacts” on page 100.
Chatting with contacts
After joining a chat session, you can write your message and
press to send it. Your message displays on the message
list and the reply message displays below your message.
During a conversation, press the
Options
soft key and select:
•
Insert smiley
to enter a preset smiley.
•
Send image
to send an image to the current contact.
•
Save to Notes
to record your conversation as a note and
save it in Notes.
•
Block options
→
Add to blocked list
to block messages
from the current participant. Select
Add ID to list
manually
to add a contact to the blocking list or
View
blocked list
to view blocked contacts. To unblock the
contact, select
Unblock
.
•
Change own availability
to change your connection
status.
Message services
99
Ending a chat session
To end the chat session, select
Options
→
Close
conversation
.
Accepting or rejecting an invitation
In Standby mode, when you have connected to the chat
service and you receive an invitation, “1 new chat message” is
displayed. Press the
Show
soft key to read it.
If you receive more than one invitation, the number of
messages followed by new invitations received is displayed.
Press the
Show
soft key, scroll to the invitation you want to
view, and press the
OK
soft key.
• To join a private group conversation, select
Options
→
Join
. Enter the screen name that you want to use in the
conversation.
• To reject or delete the invitation, select
Options
→
Reject
or
Delete
.
Reading an instant message
When you have connected to the chat service and you receive
a message from a person who is not taking part in the
conversation, “1 new chat message” is displayed. Press the
Show
soft key to read it and start a conversation.
New messages received during an active session are held in
Conversations
in the Vodafone Messenger application.
If the message is from a person whose contact information is
not on the IM contact list, the sender’s ID is shown. If the
contact information can be found in the phone’s memory and
the phone recognises it, the sender’s name is shown. To save a
new contact, select
Options
→
Add to IM contact
.
Message services
100
Managing IM contacts
On the IM contact list, you can save information about chat
participants, check their availability, and set tracking to
recognise when they log into or out of the Vodafone Messenger
service.
When you open the IM contact list, the saved chat participants
display. Select
Options
, and:
•
New IM contact
to create a new contact or search for a
contact from the server or other lists.
•
New contacts list
to add new contact list.
Scroll to a contact, and press to start to chat, or press the
Options
soft key and select:
•
Open contact details
to view the selected contact details.
You can also edit the details.
•
Edit
to change the contact information.
•
Blocking options
→
Add to blocked list
to block the
messages from the selected contact. Select
Add ID to list
manually
to add a contact to the blocking list or
View
blocked list
to view the blocked contacts. To unblock the
contact, select
Unblock
.
Customising settings for Vodafone
Messenger
To change the settings for chatting, select
Options
→
Settings
. The following options are available:
•
Preferences
: allows you to change the settings for using
Vodafone Messenger.
Sort IM contacts
: Select the order of the IM contact list.
Offline contacts
: Set whether to display offline contacts
on the IM contact list.
Message services
101
Own message colour
: Select a text colour for your
messages.
Received msg colour
: Select a text colour for other
contacts’ messages.
Show date/time info
: Set whether the phone displays
the current time next to each message.
IM alert tone
: Select a message ringtone for incoming
instant messages.
•
Servers
: allows you to create a new server or edit an
existing server. To add a new server, select
Options
→
New
server
.
Server name
: Enter a name for the server.
Access point in use
: Select an access point. You can add
or edit an access point; for details, see page 143.
Web address
: Enter your web address.
User ID
: Enter your user ID.
Password
: Enter your password.
Note
: You can get the web address, user ID, and password
from your network operator or service provider.
•
Default server
: Select the server you want to use.
•
IM login type
: You can change the login mode setting.
Select:
Automatic
to automatically log in to the service when you
switch on the phone, regardless of your location.
Auto in home netw.
to automatically log in to the service
when you are in your home network.
On app. start-up
to automatically log in to the service
when you access Vodafone Messenger.
Manual
to display a confirmation message when you
access Vodafone Messenger.
102
7
Extra programs
Notes
In Notes, you can create text notes that are not associated
with items in Calendar, Contacts, or To-do.
Press to open the Menu, and then select
Organiser &
Tools
→
Notes
.
Creating a note
1. Select
Options
→
New note
. Pressing an alphanumeric key
also opens a note editor.
2. Enter the note text.
3. When you are finished, press the
Done
soft key. The most
recently saved note is placed in the first position, displaying
the time the note was made.
Synchronising notes with other devices
You can synchronise notes between the phone and other
Bluetooth devices using the default sync profile. From the note
list, select
Options
→
Synchronisation
→
Start
.
Calculator
In Calculator, you can perform general mathematical functions,
such as addition, subtraction, multiplication, and division.
Press to open the Menu, and then select
Organiser &
Tools
→
Calculator
.
Extra programs
103
Performing a calculation
1. Enter the first number of your calculation.
2. Scroll to the function you want using the Navigation keys
and press .
3. Enter the second number.
4. If necessary, repeat steps 2 and 3.
5. To get the result, select .
Note
: Calculator has limited accuracy and rounding errors may
occur, especially in long division.
Other calculator operations
• To insert a decimal, press .
• To change a function, for example from + to -, press
until the function you want is selected on the screen.
• Press to clear the result of the previous calculation.
• Select
Options
→
Memory
→
Save
to save a number to
the memory, indicated by
M
. To retrieve the number from
the memory, select
Options
→
Memory
→
Recall
.
• To delete the number from the memory, select
Options
→
Memory
→
Clear
.
• To delete all of the calculations on the sheet, select
Options
→
Clear screen
.
• To retrieve the result of the last calculation, select
Options
→
Last result
.
Extra programs
104
Converter
In Converter, you can convert measurements such as
Length
from one unit (Yards) to another (Metres).
Press to open the Menu, and then select
Organiser &
Tools
→
Converter
.
Note
: Converter has limited accuracy and rounding errors may
occur.
Converting units
Note
: For currency conversions, you first need to set the currency
rates. See page 105.
1. Select
Type
to open a list of measurement units.
2. Select the measurement type you want to use.
3. Select the first
Unit
field to open a list of available units.
4. Select the unit
from which you want to convert.
5. Scroll to the first
Amount
field and enter the value you
want to convert.
Press to add a decimal and press for the
+
,
—
(for
temperature), and
E
(exponent) symbols.
6. Select the second
Unit
field and select the unit to which
you want to convert.
The second
Amount
field changes automatically to show
the converted value.
Extra programs
105
Setting a base currency and exchange rates
Before you can make currency conversions, you need to
choose a base currency (usually your domestic currency) and
enter exchange rates.
Note
: The rate of the base currency is always 1. The base
currency determines the conversion rates of the other
currencies.
1. Select
Currency
as the measurement type and select
Options
→
Currency rates
.
2. To change the base currency, scroll to the currency (usually
your domestic currency) and select
Options
→
Set as base
currency
. Press the
Yes
soft key to confirm.
Note
: When you change the base currency, all previously set
exchange rates are reset to
1
and you need to enter
new rates.
3. Enter a new rate, that is, how many units of the currency
equal one unit of the base currency you have selected.
To rename each field, select
Options
→
Rename currency
.
Enter a currency name and press the
OK
soft key.
4. Repeat step 3 to set up the currency list as needed.
You can add more currencies by selecting
Options
→
Add
currency
.
5. When you have finished, press the
Done
soft key.
6. Press the
Yes
soft key to save changes.
Extra programs
106
Recorder
Recorder allows you to record and play voice memos.
Press to open the Menu, and then select
Organiser &
Tools
→
Recorder
.
Note
: Obey all local laws governing recording of calls. Do not use
this feature illegally.
To record a voice memo:
1. Press to start recording when highlights.
• To pause recording, press the
Pause
soft key or select
.
• To resume recording, press the
Record
soft key or select
.
2. To stop recording, press the
Stop
soft key or select .
The recorded sound clip is automatically saved in the
Sounds
folder in My files.
After a sound clip has been saved:
• To play back the sound clip, select .
• To fast forward, select .
• To fast rewind, select .
• To access previously saved sound clips in My files, select
Options
→
Go to My files
.
• To change the recording quality or the saving location,
select
Options
→
Settings
.
Extra programs
107
Quickoffice
Quickoffice allows you to open documents on the phone
without any file-conversion or loss of content. You can view
.doc, .xls, and .ppt files.
Press to open the Menu, and then select
Organiser &
Tools
→
Quickoffice
.
Viewing a document
1. Press the Left or Right key to access a document viewer,
Quickword
,
Quicksheet
, or
Quickpoint
, according to the
file format of the document you want to open.
A list of the documents stored in the phone’s memory
opens.
2. Select the document you want to view.
Options in a document view
You can use the following options while viewing a document.
Depending on the file format of the document, available
options may vary.
• To zoom in or out, select
Options
→
Zoom
→
an option.
• To searching for a word from a document, select
Options
→
Search options
→
Find
. Then enter a key word and press
the
Find
soft key. To continue searching, select
Options
→
Search options
→
Find next
.
• To move between the top and the bottom of the document
in Quickword, select
Options
→
Go to
→
an option.
Extra programs
108
• To set the display to automatically scroll through the
document in Quickword, select
Options
→
Start auto-
scroll
.
• To move to other sheet in a document in Quicksheet, select
Options
→
Worksheet
. Then press the Left or Right key to
move between worksheets.
• To resize the column or row in Quicksheet, select
Options
→
Resize
→
an option. Then press the Navigation keys to
resize.
• To pan through a sheet in Quicksheet, select
Options
→
Pan
, and press the Navigation keys.
• To view the document on a full screen in Quickpoint, select
Options
→
Full screen
.
Updating a viewer application
You can upgrade a viewer application, if available, or check the
other Quickoffice programs from a preset website.
Press the Right key to access
Quickmanager
select one of the
following options:
•
Updates and upgrades
: allows you to check if there is a
new version of a viewer program to upgrade the program
on your phone.
•
Quickoffice products
: allows you to view the online
catalogue that introduces other Quickoffice products.
•
Offers and promotions
: allows you to obtain free
downloads and trails for other products offered by the
Quickoffice manufacturer.
Extra programs
109
Adobe PDF
Your phone has the Adobe Reader program to allow you to
open Acrobat PDF documents.
Press to open the Menu, and then select
Organiser &
Tools
→
Adobe PDF
.
Viewing a document
1. From the Adobe PDF main view, select
Options
→
Browse
for file
.
2. Select a memory location.
3. Select a folder and then a file.
4. Press the Navigation keys to scroll through the document.
Options in a document view
You can use the following options while viewing a document:
• To zoom in or out, select
Options
→
Zoom
→
an option.
• To search for a word from the document, select
Options
→
Find
→
Text
. Then enter a key word and press the
OK
soft
key. To continue searching, select
Options
→
Find
→
Next
.
• To view the document on a full screen or rotate the
document, select
Options
→
View
→
an option.
• To move to another page in the document, select
Options
→
Go to
→
an option.
Extra programs
110
Changing the Adobe PDF settings
To change the default setting for Adobe PDF, select
Options
→
Settings
. The following options are available:
•
Default zoom %
: allows you to change the default zoom
rate.
•
View mode
: allows you to change the default view mode.
•
Save settings on exit
: allows you to set whether to save
your settings when you close Adobe PDF.
Voice Signal
Your phone provides a set of powerful voice-enabled features
that enhance the hands-free capabilities of your phone.
Using Voice Signal, you can:
• make a call by saying any name in Contacts, without having
to train the system to recognise names.
• retrieve contact information for a person from Contacts by
saying the person’s name.
• launch applications by voice.
• send a text message.
In Standby mode, press and hold , or press to open
the Menu and then select
Organiser & Tools
→
Voice Signal
.
When the phone prompts you with “Say a command,” say one
of the commands:
• Call <Name or number>
• Send SMS <Name>
•Look up <Name>
• Open <Application>
Extra programs
111
Name dialling
You can make a phone call by saying the name that has been
assigned to a contact card in Contacts.
Note
: To use the Name Dial feature, the name and number that
you want to dial must be in Contacts. For details, see page
39.
1. Go to Voice Signal. The Voice Signal main screen opens and
the phone says “Say a command.”
2. After a beep, say “Call” and then a person’s name stored in
Contacts to make a call by voice command; for example,
say “Call James Bond.” This will save you a step for name
dialling.
3. If there are similar names, the phone displays the 3 best
candidates and then recites the name that most closely
matches your command and the first available number
type. If the name or type is not what you wanted, say “No”.
Repeat until you hear what you want.
4. Say “Yes” when you hear what you want.
Searching for contacts
Voice Signal lets you retrieve contact information for any name
in Contacts by saying that name. Your phone displays the
information.
To view contact information by saying the name:
1. Go to Voice Signal. The Voice Signal main screen opens and
the phone prompts you, saying “Say a command.”
Extra programs
112
2. After a beep sounds, say “Look up” and then the full name
of the contact card, the first name followed by the last
name.
3. If there are similar names, the phone displays the 3 best
candidates and then recites the name that most closely
matches your command and the first available number
type. If the name or type is not what you wanted, say “No”.
Repeat until you hear what you want.
4. Say “Yes” when you hear what you want.
Opening applications by voice
Voice Signal lets you use your voice to launch applications on
your phone. By default, you can launch any applications
displayed on the Voice Signal screen by voice. You can
customise the application list by adding or removing the
applications to be launched by voice.
To set up application list for voice launch:
1. From the Voice Signal main screen, select
Settings
→
Application Launcher
.
2. Select the applications you want.
3. Press the
Back
soft key.
To open an application by saying the name of the application:
1. Go to Voice Signal. The Voice Signal main screen opens and
the phone prompts you, saying “Say a command.”
2. Say “Open” and then the name of the application that you
want to open; for example, say “Open Contacts.”
The phone opens the application.
Extra programs
113
Sending a text message
Voice Signal lets you open a message editor to send a text
message to a mobile phone number stored in Contacts.
1. Go to Voice Signal. The Voice Signal main screen opens and
the phone prompts you, saying “Say a command.”
2. Say “Send SMS” and then the name of the recipient.
3. When an editor opens with the recipient entered, write your
message. See “Composing and sending text messages” on
page 73.
Changing the voice recognition settings
To change the settings for using Voice Signal, press the
Settings
soft key. The following options are available:
•
Choice Lists
: Set the phone to require confirmation of
your voice commands.
•
Sensitivity
: Adjust the sensitivity level of your phone to
better recognise your voice commands.
•
Digit Dialing
: Set the phone to better recognise your
commands for digit dialling.
Select Location
: Select your location. Depending on this
setting, recognition results may differ according to your
accents and pronunciations.
Adapt Digits
: Adapt your phone to recognise your vocal
style and pronunciation for each digit. Follow the audio
prompts to adapt the phone.
Reset Digits
: return to default settings.
•
Sound
: configure sound settings for the voice recognition
feature.
Prompts
: turn on or off audio prompts.
Extra programs
114
Digits
: set whether the phone asks for digit command
confirmation.
Names
: set whether the phone asks for name command
confirmation.
Name settings
: adjust the speaking speed and volume for
your name commands.
•
Language
: Select a language to be used in Voice Signal for
recognising commands and playing voice guides, as well as
displaying options.
•
Application Launcher
: Specify applications that can be
launched by voice commands.
•
Contacts Update
: Select whether or not Voice Signal is
automatically updated according to changes in Contacts, or
manually update contact database in Voice Signal.
•
About
: Access version information about Voice Signal.
Clock
In Clock, you can set up the display of the time and date
information and check the time in other cities all over the
world. You can also set an alarm to ring at a specified time.
Press to open the Menu, and then select
Organiser &
Tools
→
Clock
.
Changing clock settings
To change the time or date, select
Options
→
Settings
. The
following setting options are available:
•
Time
: Enter the current time. If the time format is set to
12-hour
, you can change
am
or
pm
by pressing any one of
the number keys and .
•
Time zone
: Select your local time zone.
Extra programs
115
•
Date
: Enter the current date.
•
Date format
: Select the date format.
•
Date separator
: Select a separator for the date display.
•
Time format
: Select the time format.
•
Time separator
: Select a separator for the time display.
•
Clock type
: Select a clock type to be displayed on the top
of the standby screen.
•
Clock alarm tone
: Select an alarm ringtone.
•
Alarm snooze time
: Select the default time interval for
alarms to repeat.
•
Workdays
: Select the days of the week you want alarm to
work.
•
Network operator time
: Select
On
if you want the mobile
phone network to update the time and date, and time zone
information to your phone.
Setting an alarm
1. Press the Right key on the home clock screen to access the
Alarm screen.
2. Select
Options
→
New alarm
.
3. Set each alarm option.
4. Press the
Done
soft key.
Deactivating alarms
To deactivate an alarm, select the alarm you want and select
Options
→
Remove alarm
. If the alarm is a repeating alarm,
select
Options
→
Deactivate alarm
.
Extra programs
116
Turning off the alarm
When the time for an alarm comes and the alarm tone sounds:
• Press the
Stop
soft key.
• Press the
Snooze
soft key or to stop the alarm and
cause it after a specified time. You can do this a maximum
of 5 times.
Note
: The volume for the clock alarm tone is not affected by the
current profile setting.
Viewing the world clock
You can check the current time in other cities or countries in
the world. To view time in other cities, you must add the cities
you want to the world clock list.
Setting up the world clock
1. Press the Right key twice on the home clock screen.
2. Select
Options
→
Add city
.
3. Select the city you want.
Note
: Enter the first few letters of the country or city from the
cities list. This will search for countries and cities by
their first few letters. For example, entering “p” will
match “France, Paris” as well as “Paraguay, Asuncion,”
as both contain entries that start with “p.”
4. Repeat steps 2 and 3 to add more cities, if necessary.
To remove the city from the list, select
Options
→
Remove
.
5. When you have finished, press the
Exit
soft key.
Extra programs
117
Setting the home zone
You can set a city on the world clock list as the home city. The
time and date of the selected city displays on the home clock
screen. Scroll to the city you want and select
Options
→
Set
as current city
.
GPS data
GPS data is a GPS-based navigation and positioning
application. You can get road guides to a specific destination or
information about your current location, or calculate the
distance of your trip.
Press to open the Menu, and then select
Organiser &
Tools
→
GPS data
.
Selecting a connection method
Before accessing the GPS service, you need to activate
Bluetooth connections to a GPS wireless module or network-
based connections. By using those connections, the phone can
send or receive location information.
From the GPS data main view, select
Options
→
Positioning
settings
. Then enable or disable Bluetooth GPS connections
and network-based connections, according to the connection
method you will use.
Each time you open GPS data, the phone will initiate a
Bluetooth connection to a GPS wireless module or to a GPS
network. For a Bluetooth connection, search for and connect to
a device.
Extra programs
118
Getting a road guide
1. From the GPS data main view, select
Navigation
.
2. Select
Options
→
Set destination
→
Coordinates
.
3. Enter the latitude and longitude of your destination and
press the
OK
soft key.
The phone displays the direction to your destination, and
additional navigating information for your trip, such as the
estimate of the remaining time before you reach the
destination, and your current speed.
During navigating, select
Options
→
Save position
to
save your current position as a landmark. You can check
the saved position by accessing Landmarks.
4. When you have finished, select
Options
→
Stop
navigation
.
Checking your current position
From the GPS data main view, select
Position
. The phone
shows information about your current position, such as
latitude, longitude, altitude, etc.
Calculating the distance of a trip
1. From the GPS data main view, select
Trip distance
.
2. Select
Options
→
Start
. The phone starts counting the
distance and time.
3. When you have finished your trip, select
Options
→
Stop
.
and check the calculated information about the trip.
Extra programs
119
Landmarks
In Landmarks, you can mark your current position or specific
places and use the marked places as road guides.
Press to open the Menu, and then select
Organiser &
Tools
→
Landmarks
.
Adding a landmark
1. From the Landmarks main view, select
Options
→
New
landmark
, and select:
•
Current position
: Select to add a landmark for your
current position.
•
Enter manually
: Select to manually specify a place.
2. If applicable, enter information about the place you want to
mark and press the
Done
soft key.
The phone sends a request for position information for the
specified place and the landmark item is added.
Managing landmarks
• To access position information of a landmark, select the
landmark from the list.
• To change information of a landmark, select it from the list
and select
Options
→
Edit
.
• To view landmarks sorted by categories, press the Right
key and select a category.
• To change an icon assigned to a landmark, scroll to it from
the list and select
Options
→
Landmark ico
n
.
120
8
Internet
This chapter describes how to get access to the wireless web
and how to use the web browser applications.
Your phone has the following browser applications:
•
Web
- A web browser for accessing various types of
information, entertainment, and other services provided by
various Internet Service Provider(ISP)s.
•
live!
: A preset link to the portal site of Vodafone.
To connect to the wireless web,
• the wireless network you use must support data calls,
• the data service must be activated for your USIM/SIM card,
• you must obtain an Internet Access Point from an Internet
Service Provider, and
• you must define the proper web browser settings. See page
125.
Note
: Your phone is preset by default for access to the wireless
web, so that you can easily use the Internet Service. If the
web browser does not work properly, you can download and
update the browser settings from your service provider’s
website.
Your ISP can give you instructions on how to configure the
browser settings. Follow the instructions carefully.
Internet
121
Web
Various service providers on the wireless web maintain pages
specifically designed for mobile phones, offering services such
as news and weather reports, banking, travel information,
entertainment, and games. With the web browser, you can
view these services as web pages written in WML, XHTML
pages written in HTML, or a mixture of both.
Press to open the Menu, and then select
My Internet
→
Web
.
Note
: Check the availability of services, pricing, and tariffs with
your service provider. Service providers can also give you
instructions on how to use their services.
Making a connection
Once you have stored all the required connection settings, you
can access browser pages.
There are three different ways to access browser pages:
• Select the homepage of your service provider,
• Select a bookmark from the Bookmarks view, or
• Enter the address of a browser service. The address field at
the bottom is immediately activated. After you have
entered the address, press .
Notes
:
• If the security indicator displays during a connection, the
data transmission between the phone and the browser gateway
or server is encrypted.
• When the system memory becomes too low, the web browser
may be unable to load web pages with complex contents. When
“Out of memory” appears, close the unnecessary applications to
free up the system memory before restarting the web browser.
Internet
122
Viewing bookmarks
You can bookmark the web pages you visit frequently and
quickly access one of the bookmarked pages at a later time. To
access the bookmark list while browsing, press and hold
or select
Options
→
Bookmarks
. From the bookmark list, you
will see bookmarks for different kinds of web pages.
• : The starting page defined for the access point.
• : The folder of automatic bookmarks. When you have
activated the
Auto. bookmarks
option (see page
126), the web pages you have visited will be
automatically bookmarked and the bookmarks will be
saved in this folder.
• : A folder you created.
• : A default folder. You cannot delete folders of this type.
• : A web feed folder.
•: A bookmark.
Adding bookmarks manually
1. In the Bookmarks view, select
Options
→
Bookmark
manager
→
Add bookmark
.
2. Fill in the fields. The default access point is assigned to the
bookmark, if none is selected.
3. Select
Options
→
Save
to save the bookmark.
Adding a bookmark folder
1. In the Bookmarks view, select
Options
→
Bookmark
manager
→
New folder
.
2. Enter a folder name and press the
OK
soft key.
Internet
123
Browsing
On a web page, links appear underlined in blue. Images that
act as links have a blue border around them.
Keys and commands used in browsing
• To open a link, press or select
Options
→
Open link
.
• To scroll, use the Navigation keys.
• To display or hide the tool bar, press and hold .
(Frequently used links), (Forward), (Home), (Page
overview), (Reload), (Find), or (Stop) are
available.
• To return to the homepage, press or select
Options
→
Navigation options
→
Homepage
.
• To go to the previous page while browsing, press the
Back
soft key. If the
Back
soft key is not available, select
Options
→
Navigation options
→
History
to view
screenshots of the pages you have visited during the
current browsing session.
• To check boxes and make selections, press .
• To retrieve the latest content from the server, select
Options
→
Navigation options
→
Reload
.
• To zoom in or out on the browser display, press or
or select
Options
→
Zooming options
→
a zoom rate.
• To save the current web page to access offline, select
Options
→
Advanced
→
Save page
.
• To save a bookmark while browsing, select
Options
→
Save as bookmark
.
• To send the URL of the current web page to other people,
select
Options
→
Advanced
→
Send
→
a sending option.
• To find a phone number, email address, or text from web
pages, press or select
Options
→
Find
→
an item.
Internet
124
• To change the display to Wide View mode, select
Options
→
Rotate screen
.
• To view page information, name and version, session, and
security details of the current browser page, select
Options
→
Advanced
→
Page info
.
Viewing saved pages
If you regularly browse pages containing information which
does not change very often, for example a train timetable, you
can save and then browse those pages when offline.
To open the list of saved pages, select
Saved pages
in the
Bookmarks view. The following icons are available on the
Saved pages view:
• : A saved web page.
• : A folder containing saved web pages.
Select a page item to open it. To start a connection to the web
service and retrieve the page again, select
Options
→
Navigation options
→
Reload
.
Downloading items
You can download items such as ringtones, images, operator
logos, and video clips through the mobile browser. You may be
charged for downloading items.
Once downloaded, items are handled by the respective
applications on your phone; for example, a downloaded picture
will be saved in
Images
.
Note
: Digital Rights Management (DRM) is a system for
protecting the copyright of digital content that is
distributed online. Copyright protections may prevent some
images, ringtones, and other content from being copied,
modified, transferred, or forwarded.
Internet
125
Ending a connection
Select
Options
→
Advanced
→
Disconnect
, or press the
Exit
soft key. The phone ends the network connection.
Deleting data in the browser memory
You can delete data transmitted while browsing the wireless
web, such as cookies, data in the cache, history and form, or
password data. Select
Options
→
Clear privacy data
→
an
item.
Changing browser settings
You can select the default access point for web connections
and set up the browser display. Select
Options
→
Settings
.
•
General
: Customise general browser settings.
Access point
: Change the default access point. For more
information, see “Access points” on page 143.
Homepage
: Set a web page to be used as your homepage.
History list
: Set the browser to keep a list of the pages
you have accessed.
Security warnings
: Enable or disable viewing the security
warnings you may get during browsing.
Java
/
ECMA script
: Enable or disable the Java/ECMA script
for the browser display.
•
Page
: Customise page display settings.
Load content
: Choose what kind of contents you want to
view while you are browsing.
Screen size
: Select the display type for the web browser.
To view the browser on a full screen, choose
Full screen
.
Internet
126
Default encoding
: To display text correctly on a web
page, select the appropriate character encoding type.
Block pop-ups
: Set whether to block pop-ups on web
pages.
Automatic reload
: Set whether the browser automatically
updates each page when changes are made from servers.
Font size
: Select the text size to be used on a web page.
•
Privacy
: Customise settings for saving private data you
have transmitted to servers while browsing.
Auto. bookmarks
: You can turn on or off the automatic
completion of address in the Bookmarks view. To hide the
Auto. bookmarks
folder in the Bookmarks view, select
Hide folder
.
Form data saving
: Set the browser to save the form data
and password you entered and send for using certain
services.
Cookies
: Enable or disable the transmission of cookies.
•
Web feeds
: Set whether the browser display automatically
updates when changes are made from the servers.
live!
Using live!, you can access the web-based service provided by
Vodafone.
Press to open the Menu, and then select
live!
The preset
web links to various services provided by Vodafone are
available.
For further details about navigating the browser, see “Web” on
page 121.
127
9
Settings
You can customise your phone to suit your preferences and
needs.
Profiles
In Profiles, you can adjust and customise the phone tones for
different events, environments, or caller groups.
Press to open the Menu, and then select
Settings
→
Profiles
.
Changing profiles
On the profile list, scroll to the profile you want and select
Options
→
Activate
.
You can quickly change the profile by pressing . Select the
profile you want to activate.
You will see the currently selected profile at the top of the
display in Standby mode. If the
General
profile is in use, only
the current date is shown.
Personalising profiles
You can change properties of a profile as your need and
preferences.
1. Scroll to the profile you want and select
Options
→
Personalise
.
Settings
128
2. Scroll to the setting you want to change and press to
open the choices:
•
Ringing tone
: Choose a ringtone for voice calls.
Note
:
You can change ringtones in two places: Profiles or
Contacts. See “Adding a ringtone for a contact card”
on page 43.
•
Video call tone
: Select a ringtone for video calls.
•
Ringing type
: Select an alert type. When
Ascending
is
selected, the ringing volume starts from level one and
increases to the set volume level.
•
Ringing volume
: Set the volume level for the ringtone
and message alert tones.
•
Message alert tone
: Choose a ringtone for messages.
•
E-mail alert tone
: Choose a ringtone for emails.
•
Vibrating alert
: Set the phone to vibrate at incoming
voice calls and messages.
•
Keypad tones
: Set the volume level for keypad tones.
•
Warning tones
: Set the phone to sound a warning
tone, for example, when the battery is running out of
power.
•
Alert for
: Set the phone to ring only upon calls from
phone numbers that belong to a selected contact group.
Phone calls coming from the people outside the selected
group have a silent alert.
•
Profile name
: Change a profile name. The General
profile cannot be renamed.
3. When you are finished, press the
Back
soft key.
Settings
129
Creating a new profile
You can create a new profile by selecting
Options
→
Create
new
. For further details about personalising each option, see
page 127.
Using the Offline profile
The
Offline
profile lets you use the phone without connecting
to the GSM wireless network to use the phone’s applications.
Important
: In Offline mode, you cannot make any calls,
excluding emergency calls, or use other features that require
network coverage.
To leave the Offline profile, activate any other profile. The
phone re-enables GSM wireless transmissions, providing there
is sufficient signal strength.
Themes
In Theme, you can personalise the look of your phone’s display
by activating a theme.
Press to open the Menu, and then select
Settings
→
Themes
.
Applying a theme
1. Select a category.
You will see a list of the available themes.
•
General
: You can select a skin for the phone’s display.
Settings
130
•
Menu view
: You can select a display type for Menu
mode.
•
Wallpaper
: You can select a background image for the
Standby screen.
2. Select the theme you want from the theme list. The
currently active theme is indicated by a check mark.
Downloading themes
You can download themes from the web browser. Select
Download themes
from the general theme or menu view
item. Then you can enter a URL address or bookmark for the
web site providing you with theme downloads.
Configuration
The Configuration application provides you with various
options to customize your phone.
Press to open the Menu, and then select
Settings
→
Config.
General settings
From the Configuration main view, select
General
to change
the general phone settings.
Personalisation
You can customise the settings for the display, lights, and
sounds on your phone.
Settings
131
Display
•
Brightness
: Use to change the brightness of the display.
•
Font size
: Select a font size for text display.
•
Welcome note / logo
: You can change the welcome note
or image which displays briefly each time you switch on the
phone. Select
Text
to enter a welcome note or
to
select an image in the phone’s memory or on the memory
card, if you use one.
•
Backlight on time
: A backlight illuminates the main
display, and the keypad. When you press any key or open
the phone, the backlight turns on. In this menu, you can
select the maximum length of time the backlight stays on.
•
Dim time
: After the backlight turns off, your phone enters
Dimming mode and then the display turns off. Select the
maximum length of time the display stays in Dimming
mode.
•
Touch key lock time
: Select the length of time the touch
keys on the phone is active.
Standby mode
•
Active standby
: When this setting is activated, the
shortcuts to your favourite applications display so that you
can quickly access them from the Standby screen. Also,
scheduler information displays on the screen.
•
Shortcuts
: You can change the shortcuts that appear over
the left and right soft keys in Standby mode.
•
Active standby apps.
: You can select applications that
can be opened from the active standby screen. This option
is available only when
Active standby
is activated.
•
News ticker
: You can change the settings for receiving
news from the network. Depending on your country, this
option may be unavailable.
Settings
132
Tones
You can change the sound settings for the currently selected
profile. For details, see “Personalising profiles” on page 127.
Themes
•
General
: You can select a skin for the phone’s display.
•
Menu view
: You can select a display type for Menu mode.
•
Wallpaper
: You can select a background image for the
Standby screen.
Language
•
Phone language:
You can change the language for the
display text of your phone. This change also affects the
format used for the date and time and the separators used,
for example, in calculations. If you select
Automatic
, the
phone selects the language according to the information on
your USIM/SIM card. After you have changed the phone
language, you must restart the phone.
Note
:
Changing the settings for
Phone
language
or
Writing
language
affects every application in your phone.
•
Writing language
: You can change the writing language
for writing on your phone. Changing the language affects:
- the characters available when you press any key ( to
),
- the predictive text dictionary used, and
- the special characters that are available when you press
and . For example, you are using a phone where
the phone language is in English but you want to enter all
of your messages to French. After you change the
language, the special characters or punctuation marks
used in the French language are available.
Settings
133
•
Predictive text
: You can activate or deactivate T9 text
input mode for all of the text editors in the phone.
Note
:
Predictive text
is not available for all languages.
Date and time
You can change the current time and date, and set the options
for the time display and alarms. For details, see “Changing
clock settings” on page 114.
Enhancement
You can change the headset or hands-free car kit settings. The
following options are available for each accessory:
•
Default profile
: Select the profile you want to be activated
each time when you connect a headset to your phone or
your phone is used as the hands-free car kit.
•
Automatic answer
: Set the phone to answer an incoming
call automatically after 5 seconds when you connect a
headset to your phone or your phone is used as the
hands-free car kit.
Security
The Security settings allow you to protect your phone and
USIM/SIM card from unauthorised use. Following options are
available:
Phone and SIM card
•
PIN code request
: When this setting is activated, the PIN
code is requested each time the phone is switched on.
Settings
134
•
PIN code
: The 4- to 8-digit PIN (Personal Identification
Number) code protects your USIM/SIM card against
unauthorised use. The PIN code is usually supplied with the
USIM/SIM card. After 3 consecutive incorrect PIN code
entries, the PIN code is blocked. If the PIN code is blocked,
you need to unblock the PIN code by entering the PUK (PIN
Unblocking Key) code.
•
PIN2 code
: The 4- to 8-digit PIN2 code, supplied with
some USIM/SIM cards, is required to access some
functions, such as call cost counters.
•
Phone autolock period
: You can set an autolock period, a
time-out after which the phone is automatically locked and
can be used only if the correct lock code is entered.
Note
: When the phone is locked, you may be able to call the
emergency number programmed in your phone (e.g.,
112 or other official emergency numbers).
To unlock the phone, in Standby mode, press the
Unlock
soft key, enter the lock code, and press the
OK
soft key.
•
Lock code
: You can change the lock code used to lock the
phone and keypad to avoid unauthorised use.
Note
: The factory setting for the
lock
code is
00000000
. To
avoid unauthorised use of your phone, change the
lock
code.
•
Lock if SIM card changed
: You can set your phone to ask
for the lock code when an unknown USIM/SIM card is
inserted into the phone. The phone maintains a list of
USIM/SIM cards that are recognised as the owner’s cards.
Settings
135
•
Closed user group
(network service): You can specify a
group of people whom you can call and who can call you.
For more information, contact your service provider. Select
Default
to activate the default group agreed on with the
service provider or
On
to use another group (you need to
know the group index number).
Note
: When calls are limited to Closed user groups, calls may
be possible to certain emergency numbers in some
networks (e.g., 112 or other official emergency
numbers).
•
Confirm SIM services
(network service): You can set the
phone to display confirmation messages when you are
using a USIM/SIM card service.
Important
: Even if the use of certificates makes the risks
involved in remote connections and software installation
considerably smaller, they must be used correctly in order for you
to benefit from increased security. The existence of a certificate
does not offer any protection by itself; the certificate manager
must contain correct, authentic, or trusted certificates for
increased security to be available.
Certificate management
Digital certificates are used to verify the origin of browser
pages and installed Digital certificates are needed if you:
• want to connect to an online bank or another site or remote
server for actions that involve transferring confidential
information, or
• want to minimise the risk of viruses or other malicious
software, and be sure of the authenticity of software when
downloading and installing software.
In the Certificate management main view, you will see a list of
authority certificates that have been stored in your phone.
Settings
136
Press the Right key to see a list of personal certificates, if
available.
• Authority certificates are used by some services, such as
banking services, for checking signature or server
certificates or other authority certificates.
• Personal certificates are issued to users by a certifying
authority.
To view certificate details - checking authenticity:
You can only be sure of the correct identity of a browser
gateway or a server when the signature and the period of
validity of a browser gateway or server certificate have been
checked.
To check certificate details, scroll to a certificate, and press
or select
Options
→
Certificate details
.
To change the trust settings of an authority certificate:
Scroll to an authority certificate and select
Options
→
Trust
configuration
. Depending on the certificate, a list of the
applications that can use the selected certificate is shown.
•
Internet
: The certificate is able to certify web servers.
•
Online certif. check
: The certificate is able to certify the
access to a certificate on the Certificate Revocate list.
•
VPN
: The certificate is able to certify VPN (Virtual Private
Network) connections.
Security module
You can mange security modules for various features on your
phone.
Factory config.
You can reset some of the settings to their original values. To
do this, you need to enter the
lock code
. After resetting the
settings, you must restart the phone.
Settings
137
Positioning
You can customise select a method to let other devices locate
your phone’s position.
Phone settings
From the Settings main view, select
Phone
to change the
call-related settings.
Call
You can customise the general settings for making and
answering a calls. The following options are available:
•
Send my caller ID
: This network service allows you to set
your phone number to be displayed or hidden from the
person whom you are calling. If you select
Set by
network
, the value may be set by your network operator
or service provider when you make a subscription.
•
Call waiting
: This network service allows the network to
notify you of a new incoming call while you have a call in
progress. Select
Activate
to request the network to
activate call waiting,
Cancel
to request the network to
deactivate call waiting, or
Check status
to check if the
function is active or not.
•
Reject call with SMS
: When this setting is activated, the
phone rejects incoming calls by sending a specified
message. Sending a message will cost you extra charge.
•
Message text
: Enter the text to be sent for rejecting
incoming calls.
•
Image in video call
: You can set the phone to send a
specified still image during a video call, instead of the
camcorder image. Select
Use selected
and choose an
image.
Settings
138
•
Automatic redial
: When this setting is activated, your
phone makes a maximum of 10 attempts to connect the
call after an unsuccessful call attempt. Press to stop
automatic redialling.
•
Show call duration
: Activate this setting if you want the
phone to briefly display the duration of each call.
•
Summary after call
: When this setting is activated, the
phone displays the call details after ending a call.
•
Speed dialling
: When this setting is activated, the
numbers assigned to the speed dialling keys, to ,
can be dialled by pressing and holding the corresponding
key. See also “Assigning speed dialling keys” on page 42.
•
Anykey answer
: When this setting is activated, you can
answer an incoming call by briefly pressing any key, except
/ , , , and .
•
Alert during call
: When this settings is activated, you will
hear an alert during a call if a message is received or an
alarm is triggered.
•
Side volume key
: You can set whether the phone mutes
the call ringer or rejects a call when you press and hold
/ as the call comes in.
•
Slide up
: Set whether a call is automatically answered
when you open your phone.
•
Slide down
: set whether or not the phone maintains the
menu you are using when you close the phone.
•
Line in use
(network service): This setting is shown only if
the USIM/SIM card supports two subscriber numbers, that
is two phone lines. Select which phone line you want to use
for making calls and sending
text message
s. Calls on both
lines can be answered, irrespective of the selected line.
Note
: You will not be able to make calls if you select Line 2 and
have not subscribed to this network service. To prevent line
selection, set
Line in use
to
Disable
.
Settings
139
Call divert
Call diverting is a network service that allows you to direct
your incoming calls to another number, for example, to your
voicemail server number.
1. Select the call type to be diverted.
2. Scroll to one of the following diverting options.
•
All voice
calls
/
All data and video calls
: all calls are
diverted.
•
If busy
: calls are diverted when you are already on
another call.
•
If not answered
: calls are diverted when you do not
answer the phone.
•
If out of reach
: calls are diverted when your phone is
out of a service area.
•
If not available
: calls are diverted when your phone is
turned off.
3. Select
Options
→
Activate
to request the network to
activate call diverting. Otherwise, select
Cancel
to
deactivate the selected diverting option.
To check whether or not diverting is activated, select
Check
status
.
4. If applicable, select whether to divert calls to a voicemail
box or other number.
5. Enter the number and press the
OK
soft key.
6. If you selected
If not answered
or
If not available
, set a
period of time the network delays before diverting a call.
Settings
140
Call barring
Call barring is a network service that allows you to restrict
making and receiving of calls with your phone. For this
function, you need a barring password, which is given by your
service provider.
1. Scroll to one of the following barring options.
•
Outgoing calls
: calls cannot be made.
•
International calls
: international calls cannot be
made.
•
International calls except to home country
: When
abroad, calls can be made only to numbers within the
current country and to your home country.
•
Incoming calls
: calls cannot be received.
•
Incoming calls when abroad
: calls cannot be received
when you are using your phone outside of your home
service area.
2. Select
Options
→
Activate
to request the network to
activate call barring, or
Cancel
to deactivate the selected
barring option.
To check if calls are barred or not, select
Check status
.
Note
: Select
Options
→
Edit barring password
to change
the supplied barring password.
3. Enter the barring password and press the
OK
soft key.
Note
: When calls are barred, calls may be possible to certain
emergency numbers in some networks (e.g., 112 or other
official emergency numbers).
Settings
141
Network
You can customise settings for network services supported by
your service provider. The following options are available:
•
Network mode
: Select the network mode in which your
phone operates.
Dual mode
: the phone operates in the GSM or UMTS
network automatically.
UMTS
: the phone operates in UMTS (3G) networks. You
can get higher speed quality than on lower generation
networks, and use advanced data and information services,
such as video calls.
GSM
: the phone operates in the GSM 900/1800 or 1900
network.
•
Operator selection
: Choose
Automatic
to set the phone
to automatically search for and select one of the cellular
networks available in your area, or
Manual
to select the
desired network manually from a list of networks. The
selected network must have a roaming agreement with
your home network, that is, the operator whose USIM/SIM
card is in your phone.
Tip
: A roaming agreement is an agreement between two or
more network service providers to enable the users of one
service provider to use the services of other service
providers.
•
Cell info display
: Select
On
to set the phone to indicate
when it is used in a cellular network based on Micro Cellular
Network (MCN) technology and to activate the reception of
cell information.
Settings
142
Connection settings
From the Configuration main view, select
Connection
to
change the settings for connections to other devices or the
network.
Bluetooth
You can change the setting options for Bluetooth connections:
•
Bluetooth
: Activate or deactivate the Bluetooth feature.
•
My phone’s visibility
: Select
Shown to all
to allow other
Bluetooth devices to search for your phone or select
Hidden
to set your phone to be hidden from other
Bluetooth devices.
•
My phone’s name
: Change your phone’s Bluetooth name,
which is displayed on other devices.
USB
You can change the setting options for USB connections:
•
USB mode:
Select a mode for USB connections.
Media player
: You can synchronise your phone with
Windows Media Player.
PC Studio
: You can connect your phone to the PC Studio
program to synchronise data or transfer files.
Data transfer
: You can use the phone as a memory card
reader/writer to copy files to or from a memory card. This
function is available when you insert a memory card into
the phone.
•
Ask on connection
: The phone will ask you which function
you want to use on connecting the phone to a PC.
Settings
143
Access points
You can create a new access point or edit existing ones.
Note
: you may receive access point settings in a smart message
from a service provider. See “Receiving smart messages”
on page 80.
Select an access point to be edited from the list or select
Options
→
New access point
. Then, fill in the following
fields:
Note
: Follow the instructions given to you by your service
provider very carefully.
•
Connection name
: Enter a descriptive name for the
connection.
•
Data bearer
: Select a network bearer.
•
Access point name
: The access point name is needed to
establish a connection to the network. You obtain the
access point name from your service provider.
•
User name
: Enter a user name if required by the service
provider. The user name may be needed to make a data
connection, and is usually provided by the service provider.
The user name is often case-sensitive.
•
Prompt password
: If you must enter a new password
every time you log on to a server, or if you do not want to
save your password to the phone, choose
Yes
.
•
Password
: A password may be needed to make a data
connection, and is usually provided by the service provider.
Enter the password. Be careful as it may often case-
sensitive.
•
Authentication
: Choose a user authentication mode,
Normal
or
Secure
.
Settings
144
•
Homepage
: Depending on what you are setting up, enter
either the URL address of the web service or the address of
the multimedia messaging centre.
If you select
Options
→
Advanced configuration
, you can
set the following options:
•
Network type
: Change a network type to either
IPv6
or
IPv4
.
•
Phone IP address
(IPv4): Enter the IP address of your
phone.
•
DNS address
: For IPv4, enter the DNS (Domain Name
Server) addresses. For IPv6, you can select one of the
following options:
Automatic
: The phone receives the DNS addresses from
the DHCP server.
Well-known
: The phone connects to a local DNS server
using the well-known IPv6 site-local unicast addresses.
User defined
: You can manually enter the DNS addresses.
•
Proxy server address
: Enter the IP address of the proxy
server.
•
Proxy port number
: Enter the port number of the proxy
server.
Note
:
If you need to change the settings above, contact your
Internet service provider to obtain these parameters.
Packet data
The packet data settings affect all access points using a packet
data connection.
•
Packet data connection
: If you select
When available
and you are in a network that supports packet data, the
phone registers to the GPRS network. Starting an active
packet data connection, for example, to send and receive
email, is quicker.
Settings
145
If you select
When needed
, the phone uses a packet data
connection only if you start an application or action that
needs it. The GPRS connection is closed once it is not used
by any application.
Note
:
If there is no GPRS coverage and you have chosen
When available
, the phone periodically tries to
establish a packet data connection.
•
Access point
: The access point name is needed when you
want to use your phone as a packet data modem for your
PC. For more information on modem connections, see the
Help files for One Touch Access feature of PC Studio on the
CD-ROM.
•
High speed packet access
: Enabe high-speed packet
access connections. You can send or receive data more
quickly than with packet data connections.
Configurations
You may receive parameters for network settings by message
from your service provider so that you can apply the
parameters simply by opening the message. A configuration
message can contain the settings for the web browser, instant
messaging, multimedia messaging, and streaming video
services. In this menu, you can access configuration messages
you have received.
Select the configuration message you want to open. To apply
the configuration to the corresponding menu, select
Options
→
Save
.
Application settings
From the Configuration main view, select
Applications
to
change the settings for applications on your phone.
For details, see the section containing the descriptions for the
corresponding application.
146
10
Managers
This chapter gives you information about using manager
applications to allow you to manage multimedia files, add-on
applications, and your phone and memory card.
File manager
In File manager, you can browse, open, and manage files and
folders in the phone’s memory or on the memory card, if you
use one.
Press to open the Menu, and then select
Settings
→
File
mgr.
Press the Right key to see the folders on the memory card, if
you use one.
Organising files
You can browse, open, and create folders, mark, copy, and
move items to folders. See “Actions common to all
applications” on page 23.
Viewing an items details
After scrolling to a folder or a file, select
Options
→
View
details
. The detailed information about the selected item
displays.
Managers
147
Viewing memory consumption
You can view information on the current memory consumption
for the phone’s memory or memory card.
1. Press the Left or Right key to move from one memory tab
to another.
2. Select
Options
→
Memory details
.
The phone calculates the approximate amount of memory
currently in use and free memory.
Note
: If the phone’s memory capacity is getting low, remove
some files, or move them to the memory card, if you use
one, or to your PC by using PC Studio.
Searching for items
You can search for a name, file, or folder by using the search
field.
1. Select
Options
→
Find
.
2. Select the memory location to search.
3. Enter a keyword in the text field and press the
Find
soft
key. The phone immediately starts to search for matches
and highlights the best match.
To make the search more accurate, enter more letters. The
phone highlights the item that best matches your input.
4. When you find the correct item, press to open it.
Managers
148
Application manager
In Application manager, you can install new Symbian operating
system applications (SIS files) and Java™ applications. You
can also update and uninstall applications from the phone, and
monitor installation history.
Press to open the Menu, and then select
Settings
→
App.
mgr.
When you open Application manger, you will see a list of:
• installation packages that have been saved to the phone’s
memory (indicated by ),
• partially installed applications, and
• fully installed applications that you can remove.
Note
: Your phone supports J2ME™ Java applications. Do not
download PersonalJava™ applications to your phone as
they cannot be installed.
General information for installing
applications
You can install applications that are specifically intended for
this phone and suitable for the Symbian operating system.
Note
: If you install an application that is not intended specifically
for this phone, it may function and look different from what
was originally intended.
Managers
149
Applications may be downloaded to your phone during
browsing, received as attachments in multimedia messages or
emails, or received via Bluetooth from another compatible
device, for example, a phone or a PC. If you are using PC
Studio to transfer an application, place the application in the
Installed files
folder in File manager.
Important
: Only install software from sources that offer
adequate protection against viruses and other harmful software.
To increase protection, the application installation system uses
digital signatures and certificates for applications. Do not
install the application if Application manager gives a security
warning during installation.
Installing applications
Open Application manager, scroll to an application installation
package, and select
Options
→
Install
to start the
installation.
Alternatively, search the phone’s memory or the memory card
and select an installation package. The installation starts.
Some applications may give the option of partial installation,
allowing you to select the particular components of the
application that you want to install. If you are installing an
application without a digital signature or a certificate, the
phone warns you of the risks. Continue the installation only if
you are absolutely sure of the origin and contents of the
application.
Installation settings
You can change the settings for application installation. From
the Application manager main view, select
Options
→
Configuration
.
Managers
150
•
Software installation
: Select whether or not to allow
software installation.
•
Online certificate check
: Select whether or not the
phone must check online certificates for installing
applications.
•
Default web address
: Enter the URL address of the
default web page for checking online certificates.
Removing applications
1. Scroll to an application and select
Options
→
Remove
.
2. Press the
Yes
soft key.
If another application depends on the application that you
removed, the other application may stop working. Refer to the
documentation of the installed application for details.
Device manager
Device manager allows a third party, such as your service
provider, to assist you directly with phone settings. You can
start a configuration session from your phone or accept or
reject server-initiated synchronisation attempts.
This feature is network-dependent and may not be available on
all phones. Contact your service provider for information and
availability.
To access Device manager, press to open the Menu, and
then select
Settings
→
Device mgr.
Managers
151
Creating a new profile
A device manager profile must be defined before you are
connected to a server.
Press the Right key to access the profile list, and select
Options
→
New server profile
.
•
Server name
: Device manager server name.
•
Server ID
: Remote device manager server ID.
•
Server password
: Password used in server alerts. Enter
the password that must be provided by the device manager
server when synchronising with your phone.
•
Access point
: Internet access point your phone uses to
establish the server connection. Choose from the list of
access points defined in your phone.
•
Host address
: Device management server URL.
•
Port
: Device management server port.
•
User name
: Your user name for this profile.
•
Password
: Your password for this profile.
•
Allow configuration
: To allow device management on this
server, select
Yes
.
•
Auto-accept all requests
: Automatic or approved device
management on this server. Select
Yes
to allow
synchronisation without your verification, or select
No
to
verify each synchronisation attempt.
•
Network authentication
: Set whether to use
authentication for accessing the network.
Starting a configuration
To check it there is available updates, select
Options
→
Check
for updates
.
To start a configuration session, select
Options
→
Start
configuration
and then press the
Yes
soft key.
Managers
152
Activation key manager
For some media content, you may need to purchase activation
keys that allow you to access them according to the Digital
Rights Management (DRM) system. You can purchase these
keys from the websites that own the rights.
Activation key manager allows you to manage the activation
keys you have purchased. Press to open the Menu, and the
select
Organiser & Tools
→
Actv. keys
.
Accessing activation keys
1. Select the folder you want.
•
Valid keys
: show all activation keys.
•
Invalid keys
: shows expired activation keys.
•
Not in use
: shows the activation keys of media files,
which are currently not in the phone’s memory.
2. Select the activation key you want. The details for the key
appears.
Activating expired activation keys
You can reactivate expired keys by accessing the website of
the rights issuer and buying the rights.
1. Access the
Invalid keys
folder.
2. Scroll to the key you want to reactivate.
3. Select
Options
→
Restore activation keys
.
4. Press the
Yes
soft key.
5. Follow the onscreen instructions.
Managers
153
Memory card manager
You can manage your memory card from the Memory
application. Press to open the Menu, and then select
Settings
→
Memory
.
Important
:
• Keep all memory cards out of the reach of small children.
• As your phone’s system supports only FAT16 and FAT32 formats,
you must format the card as FAT16 or FAT32 to use the memory
card with the phone.
Backing up and restoring information
• To back up information from your phone’s memory to the
memory card, select
Options
→
Back up phone memory
.
When a confirmation message appears, press the
Yes
soft
key.
• To restore information from the memory card to the
phone’s memory, select
Options
→
Restore from card
.
When a confirmation message appears, press the
Yes
soft
key.
Renaming the memory card
You can change the memory card name. Select
Options
→
Memory card name
. Enter the name you want and press the
OK
soft key.
Managers
154
Setting a memory card password
You can set a password to lock your memory card against
unauthorised use. Once a password has been set, you need to
enter the password when using the memory card on other
devices.
Note
: Once a password for the memory card has been set,
devices that do not support a feature related to the
memory card password, such as Microsoft Windows,
cannot read the card. You first need to remove the
password on the phone.
To set, change, or remove your password:
Select
Options
→
Set password
,
Change password
, or
Remove password
.
For every option, you are asked to enter and confirm your
password. The password can be up to 8 characters long.
Checking memory consumption
You can check the memory consumption of different data
groups and the available memory for installing new
applications or software on your memory card.
Select
Options
→
Memory details
.
Formatting the memory card
You must format the memory card before you can use it for
the first time.
Select
Options
→
Format memory card
. When a
confirmation message appears, press the
Yes
soft key.
155
11
Connectivity
You can transfer data from your phone to a compatible device,
for example, a phone or PC, via Bluetooth or a PC data cable.
Bluetooth
Bluetooth is a short-range wireless communications
technology. Devices with Bluetooth capabilities can exchange
data over a distance of about 10 metres (30 feet) without
requiring a wired connection.
Using Bluetooth, you can send or receive data, such as
business cards and calendar notes, to and from devices.
Notes
:
• Some devices may not be compatible with your phone.
• If there are obstacles between the devices, the maximum
operating distance may be reduced.
Setting up Bluetooth
To use a Bluetooth connection, press to open the Menu,
and then select
Settings
→
Bluetooth
.
You can access the following Bluetooth functions:
•
Bluetooth
: Activate or deactivate the Bluetooth feature.
•
My phone’s visibility
: Select
Shown to all
to allow other
Bluetooth devices to search for your phone or select
Hidden
to set your phone to be hidden from other
Bluetooth devices.
•
My phone’s name
: Change your phone’s Bluetooth name,
which is displayed on other devices.
Connectivity
156
Searching for and pairing with a Bluetooth
device
1. On the Bluetooth screen, press the Right key to move to
the paired device list.
2. Select
Options
→
New paired device
to search for a new
device.
After searching for connectable devices, a list of devices
you can connect to displays. The following icons on the left
of the devices indicate the type of device:
• : Mobile phone
•: PC
• : Headset
• : Hands-free car kit
• : Audio device
• : Unknown device
3. Select a device with which to connect.
4. Enter a Bluetooth PIN code and press the
OK
soft key. This
code is used just once and you do not need to memorise it.
When the owner of the other device enters the same code,
pairing is complete.
Note
: The users of Bluetooth-enabled devices must agree on
the Bluetooth PIN code, and use the same code for both
devices in order to pair them. Some devices, especially
headsets or hands-free kits, may have a fixed Bluetooth
PIN, such as 0000. If the other device has one, you
must enter the code.
5. When you are asked to set the device to be authorised,
press the
Yes
soft key to confirm. Otherwise, press the
No
soft key.
Connectivity
157
Using device options
When you press the
Options
soft key on the paired device list,
you can access the following options:
•
New paired device
: searches for other devices to pair
with.
•
Connect
: connects a headset or hands-free car kit to your
phone.
•
Assign short name
: allows you to assign a short name to
a device.
•
Set as authorised
/
Set as unauthorised
: set whether or
not the phone asks you to permit connection when other
devices try to connect to your phone.
•
Delete
: deletes the selected device.
•
Delete all
: deletes all paired devices.
•
Exit
: exits the Bluetooth application.
Receiving data via Bluetooth
Make sure that your phone’s Bluetooth feature is active and
the phone is set to be detected by other devices. When
receiving data via Bluetooth, you are asked if you want to
accept the data. If you accept it, the item is placed in the
Inbox
folder in Messaging. Messages received via Bluetooth
are indicated by .
Sending data via Bluetooth
1. Make sure that the Bluetooth feature is active.
2. Locate the item you want to send in an application, such as
Calendar, Contacts, My files, or File manager.
Connectivity
158
3. Scroll to the item and select
Options
→
Send
or
Send
business card
→
Via Bluetooth
.
4. Select the device you want from the list.
If the device to which you want to send does not appear on
the list, search for and pair with the device by proceeding
from step 2 on page 156.
5. If necessary, enter a PIN code and press the
OK
soft key.
USB
You can set which function is activated when you connect your
phone to a PC with a PC data cable.
1. Press to open the Menu, and then select
Settings
→
USB
.
2. Select the option you want:
•
USB mode
: Select a mode for USB connections.
Media player
: You can synchronise your phone with
Windows Media Player.
PC Studio
: You can connect your phone to the PC Studio
program to synchronise data or transfer files.
Data transfer
: You can use the phone as a memory
card reader/writer to copy files to or from a memory
card. This function is available when you insert a
memory card into the phone.
•
Ask on connection
: The phone will ask you which
function you want to use on connecting the phone to a
PC.
3. Press the
Exit
soft key.
Connectivity
159
Remote synchronisation
The Sync application enables you to synchronise your calendar,
notes, messages, or contacts with other devices via Bluetooth,
or server on the wireless web.
Press to open the Menu, and then select
Organiser &
Tools
→
Sync
.
Creating a new synchronisation profile
1. Select
Options
→
New sync profile
.
2. Choose whether you want to use the default setting values
or copy the values from an existing profile.
3. Define the following:
•
Sync profile name
: Enter a name for the profile.
•
Applications
: Select applications to be synchronised.
Select
Options
→
Edit sync profile
and change the
application settings.
Included in sync
: Select applications to be
synchronised.
Remote database
: Set the path for the database in the
remote server.
Synchronisation type
: select a synchronisation type.
•
Connection settings
: Customise the settings for
connecting to a network.
Server version
: Select a version of the synchronisation
protocol.
Server ID
: Enter a synchronisation server ID.
Connectivity
160
Data bearer
: Select
Internet
to synchronise with a
server on the wireless web. Select
Bluetooth
to
synchronise with a Bluetooth device. Some of the
following options depend on the data bearer setting.
Access point
(Internet): Select the access point you
want to use for the data connection.
Host address
: Enter the URL address of the server on
the wireless web. Contact your service provider or
system administrator for the correct values.
Port
(Internet): Enter the port number of the server.
Contact your service provider or system administrator
for the correct values.
User name
: Enter your user ID for the synchronisation
server. Contact your service provider or system
administrator for your correct ID.
Password
: Enter your password. Contact your service
provider or system administrator for the correct
password.
Allow sync requests
: You can set whether or not you
accept synchronisation request received from this server.
Accept all sync requests
: You can set whether or not
your phone asks for your confirmation before accepting
synchronisation from this server.
Network authentication
(Internet): Enable or Disable
authentication for accessing HTTP servers.
4. Press the
Back
soft key to save the settings.
Connectivity
161
Synchronising data
1. In the Sync main view, scroll to a profile and select
Options
→
Synchronise
. The status of the synchronisation
is shown at the bottom of the screen.
2. If you select a profile with Bluetooth, connect to a device.
After synchronisation is complete, select
Options
→
View log
to open a log file showing the synchronisation status
(complete or incomplete) and how many calendar, notes, or
contact entries have been changed.
Connection manager
In Connection manager, you can identify the status of multiple
data connections, view details on the amount of data sent and
received, and end unused connections.
Press to open the Menu, and then select
Settings
→
Conn. mgr.
Viewing connection details
To view the details of a connection, scroll to a connection and
select
Options
→
Details
.
•
Name
: the name of the Internet Access Point (IAP) in use,
or
Modem connection
if the connection is a dial-up
connection.
•
Bearer
: the type of data connection; Data call or Packet
data.
•
Status
: the current status of the connection.
Connectivity
162
•
Received
: the amount of data, in bytes, received by the
phone.
•
Sent
: the amount of data, in bytes, sent from the phone.
•
Duration
: the length of time the connection has been
open.
•
Speed
: the current speed of both sending and receiving
data in KB/s (kilobytes per second).
•
Name
: the access point name used.
•
Shared
(not shown if the connection is not shared): the
number of applications using the same connection.
Ending connections
Scroll to a connection and select
Options
→
Disconnect
to
end that connection only. Press the
Yes
soft key to confirm.
163
12
Appendix A: Troubleshooting
General problems
Problem Description & Solution
“Insert SIM card”
displays Check that the USIM/SIM card has been
correctly installed.
“No network
coverage,”
“Unable to
connect. No
network
coverage.” or
“Message sending
failed” displays
• The network connection has been lost.
You may be in a weak signal area (in a
tunnel or surrounded by buildings).
Move and try again.
• You are trying to access an option for
which you have not taken out a
subscription with your service provider.
Contact the service provider for further
details.
The bars of the
signal icon ( )
disappear
• If you have just turned on your phone,
wait for about 2 minutes, until your
phone finds the network and receives a
signal.
• If you are in a tunnel or in an elevator,
the phone may not be able to receive
the network signal properly. Move to an
open place.
• This may appear when you move
between different service areas. It is
normal.
The display is not
clear In direct sunlight, you may not be able to
see the display clearly. Moving to a place
with different light should solve this
problem.
164
White lines
appear on the
display
This may happen if you turn on the phone
after a long period of disuse, or after
removing the battery without turning off
the phone. This is not related to the
phone’s life or performance. The display
should correct itself shortly.
“Locked” displays The automatic locking feature has been
enabled. You must press the
Unlock
soft
key and enter the lock code before you
can use the phone. To disable this
feature, go to
Settings
→
Config.
→
General
→
Security
→
Phone and SIM
card
and set
Phone autolock period
to
None
.
“PIN code”
appears • You are using your phone for the first
time. You must enter the Personal
Identification Number (PIN) supplied
with the USIM/SIM card.
• The PIN code request feature has been
enabled. Each time the phone is
switched on, the PIN has to be entered.
To disable this feature, go to
Settings
→
Config.
→
General
→
Security
→
Phone and SIM card
and set
PIN
code request
to
Off
.
“PUK code”
appears The PIN code was entered incorrectly
three times in succession and the phone
is now blocked. Enter the PUK supplied by
your service provider.
Problem Description & Solution
Troubleshooting
165
Call problems
I forgot the
security, PIN, or
PUK codes
The default
lock code
is
00000000
. If
you forget or lose the code, contact your
phone dealer. If you forget or lose a PIN
or PUK code, or if you have not received
such a code, contact your service
provider.
Problem Description & Solution
I have entered a
number but it was
not dialled
• Be sure that you have pressed .
• Check if your wireless connection to
your mobile service provider is
switched on and the signal from the
network is unobstructed.
• You may have set an outgoing call
barring option.
My correspondent
cannot reach me • Be sure that your phone is switched on.
• Check if your wireless connection to
your mobile service provider is
switched on and the signal from the
network is unobstructed.
• You may have set an incoming call
barring option.
My correspondent
cannot hear me
speaking
• Be sure that you have not switched off
the microphone.
• Be sure that you are holding the phone
close enough to your mouth. The
microphone is located at the bottom of
the phone.
Problem Description & Solution
166
Power and charging problems
The audio quality
of the call is poor • Adjust the voice volume by pressing
/
.
• Check the signal strength indicator on
the display ( ); the number of bars
indicates the signal strength, from
strong to weak.
• Try moving the phone slightly or
moving closer to a window if you are in
a building.
Calls to and from
the phone are not
connected
properly, and are
easily
disconnected.
• Signals from the network are weak.
Move to another area.
• Touching the antenna area, the top of
the phone may lower the call quality.
Be careful not to touch the top of the
phone while using the phone.
Problem Description & Solution
“Battery low”
appears on the
display
Battery power is very low. Recharge the
battery.
Charging does not
start • Disconnect the phone from the travel
adapter, remove the battery, and then
replace it. Try charging again.
• If the problem persists, clean the metal
contacts on the battery and the phone.
• If the actions above do not clear the
problem, contact a Samsung service
representative.
Problem Description & Solution
Troubleshooting
167
The phone
malfunctions or
does not function
Remove the battery and then replace it.
Turn on the phone. If the problem
persists, contact a Samsung service
representative.
The battery’s
standby time is
shorter than
expected
• Batteries are subject to wear and tear.
Standby time may grow shorter as
time passes.
• Leaving a fully charged battery in a
cold or hot place for a long period of
time may reduce battery life.
• Standby time depends on where you
use the phone. The actual time may
vary from the battery’s specifications.
Is it OK if I leave
the phone
connected to the
power outlet after
it is fully charged
We recommend that you disconnect the
phone from the travel adapter or unplug
the adapter from the power outlet.
The phone
becomes hot This may happen when you are on the
phone or when you use applications,
such as games, the web browser, or the
camera, because the phone needs more
power at those times. This does not
affect the phone’s life or performance.
The battery level
seem sufficient,
but the phone
does not turn on
• Remove the battery from the phone
and reinstall it. Then turn on the
phone.
• Clean the metal contacts both on the
battery and on the phone. Reinstall the
battery and turn on the phone.
Problem Description & Solution
168
Application problems
The phone turns
off when the travel
adapter is
connected
Dust on the contacts may cause
unexpected power-off or charging
problems. Clean the metal contacts both
on the battery and on the phone.
Problem Description & Solution
“Not enough
memory to
perform operation.
Delete some data
first.” or “Memory
low. Delete some
data.” displays
To view what kind of data you have and
how much memory the different data
groups consume, go to File manager and
select
Options
→
Memory details
.
Delete old items from applications. If
necessary, make a backup copy of your
data using PC Studio or the memory
card.
Application does
not respond Open the application switching window
by pressing and holding . Then scroll
to the application and press to close
the application. Open it again.
Web
“No valid access
point defined.
Define one in
Services settings.”
displays
Insert proper browser settings. Contact
your service provider for instructions.
Problem Description & Solution
Troubleshooting
169
Calendar
Week numbers are
missing If you have changed the Calendar
settings so that the week starts on a day
other than Monday, the week numbers
will not be shown.
Camera
Images seem
smudged Check that the camera lens protection
window is clean.
The phone is
unable to connect
to the wireless
web
• Check if you have set up and are
connected to an Internet service
provider.
• Check if your wireless connection to
your mobile service provider is
switched on and the signal from the
GPRS network is unobstructed.
• Verify with your service provider that
your user name and password are
correct.
• Verify with your Internet service
provider that the network you are
trying to connect is available, or try to
connect it from another PC.
Contacts
No number is
dialled when you
recall a contact
card
• Check that a number has been stored
in the contact card.
• Re-store the number, if necessary.
Problem Description & Solution
170
Bluetooth
I cannot end a
Bluetooth
connection
If another device is connected to your
phone, you can either end the
connection using the other device or by
deactivating Bluetooth. Go to
Bluetooth
and select
Bluetooth
→
Off
.
I cannot find my
friend’s Bluetooth-
enabled device
• Check that both have activated
Bluetooth.
• Check that the distance between the
two devices is not over 10 meters or
that there are no walls or other
obstructions between the devices.
• Check that the other device is not in
Hidden
mode.
• Check that both devices are
compatible.
Calls
The
communication log
appears empty
You may have activated a filter, and no
communication events fitting that filter
have been logged. To see all events,
press the Right key from the Calls main
view and select
Options
→
Filter
→
All
communication
.
Messaging
I cannot select a
contact card when
creating a
message
If the contact card does not have a
phone number or email address, you
cannot select it. Add the missing
information to the contact card in
Contacts.
Problem Description & Solution
Troubleshooting
171
If the above guidelines do not help you to solve the problem,
take note of:
• the model and serial numbers of your phone
• your warranty details
• a clear description of the problem
• Then contact your local dealer or Samsung after-sales
service.
PC connectivity
A problem occurs
when connecting
the phone to a PC
• Make sure that PC Studio has been
installed and is running on your PC.
See the User’s Guide for PC Studio on
the CD-ROM for further information
on how to use PC Studio.
• Check if USB mode is set to
PC
Studio
.
Problem Description & Solution
172
Appendix B: Health and
safety information
Exposure to Radio Frequency (RF) Signals
Certification Information (SAR)
Your wireless phone is a radio transmitter and receiver. It is
designed and manufactured not to exceed the exposure limits
for radio frequency (RF) energy set by the Federal
Communications Commission (FCC) of the U.S. government.
These FCC exposure limits are derived from the
recommendations of two expert organizations, the National
Counsel on Radiation Protection and Measurement (NCRP) and
the Institute of Electrical and Electronics Engineers (IEEE). In
both cases, the recommendations were developed by scientific
and engineering experts drawn from industry, government,
and academia after extensive reviews of the scientific
literature related to the biological effects of RF energy. The
exposure limit set by the FCC for wireless mobile phones
employs a unit of measurement known as the Specific
Absorption Rate (SAR).
The SAR is a measure of the rate of absorption of RF energy by
the human body expressed in units of watts per kilogram (W/
kg). The FCC requires wireless phones to comply with a safety
limit of 1.6 watts per kilogram (1.6 W/kg). The FCC exposure
limit incorporates a substantial margin of safety to give
additional protection to the public and to account for any
variations in measurements.
SAR tests are conducted using standard operating positions
accepted by the FCC with the phone transmitting at its highest
certified power level in all tested frequency bands. Although
the SAR is determined at the highest certified power level, the
actual SAR level of the phone while operating can be well
below the maximum value. This is because the phone is
designed to operate at multiple power levels so as to use only
the power required to reach the network. In general, the
closer you are to a wireless base station antenna, the lower
the power output.
Health and safety information
173
Before a new model phone is available for sale to the public, it
must be tested and certified to the FCC that it does not exceed
the exposure limit established by the FCC. Tests for each
model phone are performed in positions and locations (e.g. at
the ear and worn on the body) as required by the FCC.
The highest SAR values for this model phone as reported to
the FCC are:
GSM1900 Head: 0.457W/Kg, Body-worn: 0.454W/Kg.
For body worn operation, this model phone has been tested
and meets the FCC RF exposure guidelines whenused with a
Samsung accessory designated for this product or when used
with an accessory that contains no metal and that positions
the handset a minimum of 1.5 cm from the body.
Non-compliance with the above restrictions may result in
violation of FCC RF exposure guidelines. SAR information on
this and other model phones can be viewed on-line at
www.fcc.gov/oet/fccid. This site uses the phone FCC ID
number, A3LSGHI450V. Sometimes it may be necessary to
remove the battery pack to find the number. Once you have
the FCC ID number for a particular phone, follow the
instructions on the website and it should provide values for
typical or maximum SAR for a particular phone. Additional
product specific SAR information can also be obtained at
www.fcc.gov/cgb/sar.
Consumer Information on Wireless Phones
The U.S. Food and Drug Administration (FDA) has published a
series of Questions and Answers for consumers relating to
radio frequency (RF) exposure from wireless phones. The FDA
publication includes the following information:
What kinds of phones are the subject of this update?
The term wireless phone refers here to hand-held wireless
phones with built-in antennas, often called “cell,” “mobile,” or
“PCS” phones. These types of wireless phones can expose the
user to measurable radio frequency energy (RF) because of
the short distance between the phone and the user's head.
These RF exposures are limited by Federal Communications
174
Commission safety guidelines that were developed with the
advice of FDA and other federal health and safety agencies.
When the phone is located at greater distances from the user,
the exposure to RF is drastically lower because a person's RF
exposure decreases rapidly with increasing distance from the
source. The so-called “cordless phones,” which have a base
unit connected to the telephone wiring in a house, typically
operate at far lower power levels, and thus produce RF
exposures well within the FCC's compliance limits.
Do wireless phones pose a health hazard?
The available scientific evidence does not show that any health
problems are associated with using wireless phones. There is
no proof, however, that wireless phones are absolutely safe.
Wireless phones emit low levels of radio frequency energy (RF)
in the microwave range while being used. They also emit very
low levels of RF when in the stand-by mode. Whereas high
levels of RF can produce health effects (by heating tissue),
exposure to low level RF that does not produce heating effects
causes no known adverse health effects. Many studies of low
level RF exposures have not found any biological effects. Some
studies have suggested that some biological effects may occur,
but such findings have not been confirmed by additional
research. In some cases, other researchers have had difficulty
in reproducing those studies, or in determining the reasons for
inconsistent results.
What is FDA's role concerning the safety of wireless
phones?
Under the law, FDA does not review the safety of radiation-
emitting consumer products such as wireless phones before
they can be sold, as it does with new drugs or medical devices.
However, the agency has authority to take action if wireless
phones are shown to emit radio frequency energy (RF) at a
level that is hazardous to the user. In such a case, FDA could
require the manufacturers of wireless phones to notify users of
the health hazard and to repair, replace or recall the phones so
that the hazard no longer exists.
Although the existing scientific data do not justify FDA
regulatory actions, FDA has urged the wireless phone industry
to take a number of steps, including the following:
Health and safety information
175
• “Support needed research into possible biological effects of
RF of the type emitted by wireless phones;
• “Design wireless phones in a way that minimizes any RF
exposure to the user that is not necessary for device
function; and
• “Cooperate in providing users of wireless phones with the
best possible information on possible effects of wireless
phone use on human health.
FDA belongs to an interagency working group of the federal
agencies that have responsibility for different aspects of RF
safety to ensure coordinated efforts at the federal level. The
following agencies belong to this working group:
• “National Institute for Occupational Safety and Health
• “Environmental Protection Agency
• “Federal Communications Commission
• “Occupational Safety and Health Administration
• “National Telecommunications and Information
Administration
The National Institutes of Health participates in some
interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless phones with
the Federal Communications Commission (FCC). All phones
that are sold in the United States must comply with FCC safety
guidelines that limit RF exposure. FCC relies on FDA and other
health agencies for safety questions about wireless phones.
FCC also regulates the base stations that the wireless phone
networks rely upon. While these base stations operate at
higher power than do the wireless phones themselves, the RF
exposures that people get from these base stations are
typically thousands of times lower than those they can get
from wireless phones. Base stations are thus not the primary
subject of the safety questions discussed in this document.
What are the results of the research done already?
The research done thus far has produced conflicting results,
and many studies have suffered from flaws in their research
methods. Animal experiments investigating the effects of radio
frequency energy (RF) exposures characteristic of wireless
phones have yielded conflicting results that often cannot be
176
repeated in other laboratories. A few animal studies, however,
have suggested that low levels of RF could accelerate the
development of cancer in laboratory animals. However, many
of the studies that showed increased tumor development used
animals that had been genetically engineered or treated with
cancer-causing chemicals so as to be pre-disposed to develop
cancer in absence of RF exposure. Other studies exposed the
animals to RF for up to 22 hours per day. These conditions are
not similar to the conditions under which people use wireless
phones, so we don't know with certainty what the results of
such studies mean for human health.
Three large epidemiology studies have been published since
December 2000. Between them, the studies investigated any
possible association between the use of wireless phones and
primary brain cancer, glioma, meningioma, or acoustic
neuroma, tumors of the brain or salivary gland, leukemia, or
other cancers. None of the studies demonstrated the existence
of any harmful health effects from wireless phones RF
exposures. However, none of the studies can answer questions
about long-term exposures, since the average period of phone
use in these studies was around three years.
What research is needed to decide whether RF exposure
from wireless phones poses a health risk?
A combination of laboratory studies and epidemiological
studies of people actually using wireless phones would provide
some of the data that are needed. Lifetime animal exposure
studies could be completed in a few years. However, very large
numbers of animals would be needed to provide reliable proof
of a cancer promoting effect if one exists. Epidemiological
studies can provide data that is directly applicable to human
populations, but ten or more years' follow-up may be needed
to provide answers about some health effects, such as cancer.
This is because the interval between the time of exposure to a
cancer-causing agent and the time tumors develop - if they do
- may be many, many years. The interpretation of
epidemiological studies is hampered by difficulties in
measuring actual RF exposure during day-to-day use of
wireless phones. Many factors affect this measurement, such
as the angle at which the phone is held, or which model of
phone is used.
Health and safety information
177
What is FDA doing to find out more about the possible
health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology Program and
with groups of investigators around the world to ensure that
high priority animal studies are conducted to address
important questions about the effects of exposure to radio
frequency energy (RF).
FDA has been a leading participant in the World Health
Organization international Electromagnetic Fields (EMF)
Project since its inception in 1996. An influential result of this
work has been the development of a detailed agenda of
research needs that has driven the establishment of new
research programs around the world. The Project has also
helped develop a series of public information documents on
EMF issues.
FDA and Cellular Telecommunications & Internet Association
(CTIA) have a formal Cooperative Research and Development
Agreement (CRADA) to do research on wireless phone safety.
FDA provides the scientific oversight, obtaining input from
experts in government, industry, and academic organizations.
CTIA-funded research is conducted through contracts to
independent investigators. The initial research will include both
laboratory studies and studies of wireless phone users. The
CRADA will also include a broad assessment of additional
research needs in the context of the latest research
developments around the world.
What steps can I take to reduce my exposure to radio
frequency energy from my wireless phone?
If there is a risk from these products - and at this point we do
not know that there is - it is probably very small. But if you are
concerned about avoiding even potential risks, you can take a
few simple steps to minimize your exposure to radio frequency
energy (RF). Since time is a key factor in how much exposure
a person receives, reducing the amount of time spent using a
wireless phone will reduce RF exposure.
• “If you must conduct extended conversations by wireless
phone every day, you could place more distance between
your body and the source of the RF, since the exposure
level drops off dramatically with distance. For example, you
could use a headset and carry the wireless phone away
178
from your body or use a wireless phone connected to a
remote antenna.
Again, the scientific data do not demonstrate that wireless
phones are harmful. But if you are concerned about the RF
exposure from these products, you can use measures like
those described above to reduce your RF exposure from
wireless phone use.
What about children using wireless phones?
The scientific evidence does not show a danger to users of
wireless phones, including children and teenagers. If you want
to take steps to lower exposure to radio frequency energy
(RF), the measures described above would apply to children
and teenagers using wireless phones. Reducing the time of
wireless phone use and increasing the distance between the
user and the RF source will reduce RF exposure.
Some groups sponsored by other national governments have
advised that children be discouraged from using wireless
phones at all. For example, the government in the United
Kingdom distributed leaflets containing such a
recommendation in December 2000. They noted that no
evidence exists that using a wireless phone causes brain
tumors or other ill effects. Their recommendation to limit
wireless phone use by children was strictly precautionary; it
was not based on scientific evidence that any health hazard
exists.
Do hands-free kits for wireless phones reduce risks
from exposure to RF emissions?
Since there are no known risks from exposure to RF emissions
from wireless phones, there is no reason to believe that
hands-free kits reduce risks. Hands-free kits can be used with
wireless phones for convenience and comfort. These systems
reduce the absorption of RF energy in the head because the
phone, which is the source of the RF emissions, will not be
placed against the head. On the other hand, if the phone is
mounted against the waist or other part of the body during
use, then that part of the body will absorb more RF energy.
Wireless phones marketed in the U.S. are required to meet
safety requirements regardless of whether they are used
Health and safety information
179
against the head or against the body. Either configuration
should result in compliance with the safety limit.
Do wireless phone accessories that claim to shield the
head from RF radiation work?
Since there are no known risks from exposure to RF emissions
from wireless phones, there is no reason to believe that
accessories that claim to shield the head from those emissions
reduce risks. Some products that claim to shield the user from
RF absorption use special phone cases, while others involve
nothing more than a metallic accessory attached to the phone.
Studies have shown that these products generally do not work
as advertised. Unlike “hand-free” kits, these so-called “shields”
may interfere with proper operation of the phone. The phone
may be forced to boost its power to compensate, leading to an
increase in RF absorption. In February 2002, the Federal trade
Commission (FTC) charged two companies that sold devices
that claimed to protect wireless phone users from radiation
with making false and unsubstantiated claims. According to
FTC, these defendants lacked a reasonable basis to
substantiate their claim.
What about wireless phone interference with medical
equipment?
Radio frequency energy (RF) from wireless phones can interact
with some electronic devices. For this reason, FDA helped
develop a detailed test method to measure electromagnetic
interference (EMI) of implanted cardiac pacemakers and
defibrillators from wireless telephones. This test method is
now part of a standard sponsored by the Association for the
Advancement of Medical instrumentation (AAMI). The final
draft, a joint effort by FDA, medical device manufacturers, and
many other groups, was completed in late 2000. This standard
will allow manufacturers to ensure that cardiac pacemakers
and defibrillators are safe from wireless phone EMI. FDA has
tested wireless phones and helped develop a voluntary
standard sponsored by the Institute of Electrical and Electronic
Engineers (IEEE). This standard specifies test methods and
performance requirements for hearing aids and wireless
phones so that no interference occurs when a person uses a
180
compatible phone and a compatible hearing aid at the same
time. This standard was approved by the IEEE in 2000.
FDA continues to monitor the use of wireless phones for
possible interactions with other medical devices. Should
harmful interference be found to occur, FDA will conduct
testing to assess the interference and work to resolve the
problem.
Additional information on the safety of RF exposures from
various sources can be obtained from the following
organizations:
• FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
• Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
• Occupational Safety and Health Administration's (OSHA):
http://www.osha.gov/SLTC/radiofrequencyradiation/
index.html
• National institute for Occupational Safety and Health
(NIOSH):
http://www.cdc.gov/niosh/emfpg.html
• World health Organization (WHO):
http://www.who.int/peh-emf/
• International Commission on Non-Ionizing Radiation
Protection:
http://www.icnirp.de
• National Radiation Protection Board (UK):
http://www.nrpb.org.uk
• Updated 4/3/2002: US food and Drug Administration
http://www.fda.gov/cellphones
Road Safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime. But an
important responsibility accompanies the benefits of wireless
phones, one that every user must uphold.
Health and safety information
181
When driving a car, driving is your first responsibility. When
using your wireless phone behind the wheel of a car, practice
good common sense and remember the following tips:
1. Get to know your wireless phone and its features, such as
speed dial and redial. If available, these features help you
to place your call without taking your attention off the road.
2. When available, use a hands-free device. If possible, add
an additional layer of convenience and safety to your
wireless phone with one of the many hands free accessories
available today.
3. Position your wireless phone within easy reach. Be able to
access your wireless phone without removing your eyes
from the road. If you get an incoming call at an
inconvenient time, let your voice mail answer it for you.
4. Let the person you are speaking with know you are driving;
if necessary, suspend the call in heavy traffic or hazardous
weather conditions. Rain, sleet, snow, ice and even heavy
traffic can be hazardous.
5. Do not take notes or look up phone numbers while driving.
Jotting down a “to do” list or flipping through your address
book takes attention away from your primary responsibility,
driving safely.
6. Dial sensibly and assess the traffic; if possible, place calls
when you are not moving or before pulling into traffic. Try
to plan calls when your car will be stationary. If you need to
make a call while moving, dial only a few numbers, check
the road and your mirrors, then continue.
7. Do not engage in stressful or emotional conversations that
may be distracting. Make people you are talking with aware
you are driving and suspend conversations that have the
potential to divert your attention from the road.
8. Use your wireless phone to call for help. Dial 9-1-1 or other
local emergency number in the case of fire, traffic accident
or medical emergencies. Remember, it is a free call on your
wireless phone!
9. Use your wireless phone to help others in emergencies. If
you see an auto accident, crime in progress or other serious
emergency where lives are in danger, call 9-1-1 or other
182
local emergency number, as you would want others to do
for you.
10.Call roadside assistance or a special non-emergency
wireless assistance number when necessary. If you see a
broken-down vehicle posing no serious hazard, a broken
traffic signal, a minor traffic accident where no one appears
injured, or a vehicle you know to be stolen, call roadside
assistance or other special non-emergency number.
“The wireless industry reminds you to use your phone
safely when driving.”
For more information, please call 1-888-901-SAFE, or visit our
web-site www.wow-com.com
Provided by the Cellular Telecommunications & Internet
Association
Operating Environment
Remember to follow any special regulations in force in any
area and always switch your phone off whenever it is forbidden
to use it, or when it may cause interference or danger. When
connecting the phone or any accessory to another device, read
its user's guide for detailed safety instructions. Do not connect
incompatible products.
As with other mobile radio transmitting equipment, users are
advised that for the satisfactory operation of the equipment
and for the safety of personnel, it is recommended that the
equipment should only be used in the normal operating
position (held to your ear with the antenna pointing over your
shoulder).
Using Your Phone Near Other Electronic
Devices
Most modern electronic equipment is shielded from radio
frequency (RF) signals. However, certain electronic equipment
may not be shielded against the RF signals from your wireless
phone. Consult the manufacturer to discuss alternatives.
Health and safety information
183
Pacemakers
Pacemaker manufacturers recommend that a minimum
distance of 15 cm (6 inches) be maintained between a wireless
phone and a pacemaker to avoid potential interference with
the pacemaker.
These recommendations are consistent with the independent
research and recommendations of Wireless Technology
Research.
Persons with pacemakers:
• should always keep the phone more than 15 cm (6 inches)
from their pacemaker when the phone is switched on.
• should not carry the phone in a breast pocket.
• should use the ear opposite the pacemaker to minimize
potential interference.
If you have any reason to suspect that interference is taking
place, switch your phone off immediately.
Hearing Aids
Some digital wireless phones may interfere with some hearing
aids. In the event of such interference, you may wish to
consult your hearing aid manufacturer to discuss alternatives.
Other Medical Devices
If you use any other personal medical devices, consult the
manufacturer of your device to determine if it is adequately
shielded from external RF energy. Your physician may be able
to assist you in obtaining this information. Switch your phone
off in health care facilities when any regulations posted in
these areas instruct you to do so. Hospitals or health care
facilities may be using equipment that could be sensitive to
external RF energy.
184
Vehicles
RF signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles. Check with the
manufacturer or its representative regarding your vehicle. You
should also consult the manufacturer of any equipment that
has been added to your vehicle.
Posted Facilities
Switch your phone off in any facility where posted notices
require you to do so.
Potentially Explosive Environments
Switch your phone off when in any area with a potentially
explosive atmosphere and obey all signs and instructions.
Sparks in such areas could cause an explosion or fire resulting
in bodily injury or even death.
Users are advised to switch the phone off while at a refueling
point (service station). Users are reminded of the need to
observe restrictions on the use of radio equipment in fuel
depots (fuel storage and distribution areas), chemical plants or
where blasting operations are in progress.
Areas with a potentially explosive atmosphere are often but
not always clearly marked. They include below deck on boats,
chemical transfer or storage facilities, vehicles using liquefied
petroleum gas (such as propane or butane), areas where the
air contains chemicals or particles, such as grain, dust or metal
powders, and any other area where you would normally be
advised to turn off your vehicle engine.
Emergency Calls
This phone, like any wireless phone, operates using radio
signals, wireless and landline networks as well as user
programmed functions, which cannot guarantee connection in
all conditions. Therefore, you should never rely solely on any
Health and safety information
185
wireless phone for essential communications (medical
emergencies, for example).
Remember, to make or receive any calls the phone must be
switched on and in a service area with adequate signal
strength. Emergency calls may not be possible on all wireless
phone networks or when certain network services and/or
phone features are in use. Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present location (for
example, 911 or other official emergency number).
Emergency numbers vary by location.
3. Press .
If certain features are in use (call barring, for example), you
may first need to deactivate those features before you can
make an emergency call. Consult this document and your local
cellular service provider.
When making an emergency call, remember to give all the
necessary information as accurately as possible. Remember
that your phone may be the only means of communication at
the scene of an accident; do not cut off the call until given
permission to do so.
Restricting Children's access to your Phone
Your phone is not a toy. Children should not be allowed to play
with it because they could hurt themselves and others,
damage the phone or make calls that increase your phone bill.
186
FCC Notice and Cautions
FCC Notice
The phone may cause TV or radio interference if used in close
proximity to receiving equipment. The FCC can require you to
stop using the phone if such interference cannot be eliminated.
Vehicles using liquefied petroleum gas (such as propane or
butane) must comply with the National Fire Protection
Standard (NFPA-58). For a copy of this standard, contact the
National Fire Protection Association, One Battery march Park,
Quincy, MA 02269, Attn: Publication Sales Division.
• This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device
must accept any interference received, including interference
that may cause undesired operation.
• This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and,if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more
of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for
help.
Health and safety information
187
Cautions
Changes or modifications made in the radio phone, not expressly
approved by Samsung, will void the user’s authority to operate
the equipment.
Only use approved batteries, antennas and chargers. The use
of any unauthorized accessories may be dangerous and void
the phone warranty if said accessories cause damage or a
defect to the phone.
Although your phone is quite sturdy, it is a complex piece of
equipment and can be broken. Avoid dropping, hitting,
bending or sitting on it.
Other Important Safety Information
• Only qualified personnel should service the phone or install
the phone in a vehicle. Faulty installation or service may be
dangerous and may invalidate any warranty applicable to
the device.
• Check regularly that all wireless phone equipment in your
vehicle is mounted and operating properly.
• Do not store or carry flammable liquids, gases or explosive
materials in the same compartment as the phone, its parts
or accessories.
• For vehicles equipped with an air bag, remember that an air
bag inflates with great force. Do not place objects,
including both installed or portable wireless equipment in
the area over the air bag or in the air bag deployment area.
If wireless equipment is improperly installed and the air
bag inflates, serious injury could result.
• Switch your phone off before boarding an aircraft. The use
of wireless phone in aircraft is illegal and may be dangerous
to the aircraft's operation.
• Failure to observe these instructions may lead to the
suspension or denial of telephone services to the offender,
or legal action, or both.
188
Product Performance
Getting the Most Out of Your Signal Reception
The quality of each call you make or receive depends on the
signal strength in your area. Your phone informs you of the
current signal strength by displaying a number of bars next to
the signal strength icon. The more bars displayed, the stronger
the signal.
If you're inside a building, being near a window may give you
better reception.
Understanding the Power Save Feature
If your phone is unable to find a signal after 15 minutes of
searching, a Power Save feature is automatically activated. If
your phone is active, it periodically rechecks service
availability or you can check it yourself by pressing any key.
Anytime the Power Save feature is activated, a message
displays on the screen. When a signal is found, your phone
returns to standby mode.
Maintaining Your Phone's Peak Performance
For the best care of your phone, only authorized personnel
should service your phone and accessories. Faulty service may
void the warranty.
There are several simple guidelines to operating your phone
properly and maintaining safe, satisfactory service.
• Hold the phone with the antenna raised, fully-extended and
over your shoulder.
• Try not to hold, bend or twist the phone's antenna.
• Don't use the phone if the antenna is damaged.
• Speak directly into the phone's receiver.
• Avoid exposing your phone and accessories to rain or liquid
spills. If your phone does get wet, immediately turn the
power off and remove the battery. If it is inoperable, call
Customer Care for service.
Health and safety information
189
Availability of Various Features/Ring Tones
Many services and features are network dependent and may
require additional subscription and/or usage charges. Not all
features are available for purchase or use in all areas.
Downloadable Ring Tones may be available at an additional
cost. Other conditions and restrictions may apply. See your
service provider for additional information.
Battery Standby and Talk Time
Standby and talk times will vary depending on phone usage
patterns and conditions. Battery power consumption depends
on factors such as network configuration, signal strength,
operating temperature, features selected, frequency of calls,
and voice, data, and other application usage patterns.
Battery Precautions
• Never use any charger or battery that is damaged in any
way.
• Use the battery only for its intended purpose.
• If you use the phone near the network's base station, it
uses less power; talk and standby time are greatly affected
by the signal strength on the cellular network and the
parameters set by the network operator.
• Battery charging time depends on the remaining battery
charge and the type of battery and charger used. The
battery can be charged and discharged hundreds of times,
but it will gradually wear out. When the operation time (talk
time and standby time) is noticeably shorter than normal, it
is time to buy a new battery.
• If left unused, a fully charged battery will discharge itself
over time.
• Use only Samsung-approved batteries and recharge your
battery only with Samsung-approved chargers. When a
charger is not in use, disconnect it from the power source.
Do not leave the battery connected to a charger for more
than a week, since overcharging may shorten its life.
190
• Extreme temperatures will affect the charging capacity of
your battery: it may require cooling or warming first.
• Do not leave the battery in hot or cold places, such as in a
car in summer or winter conditions, as you will reduce the
capacity and lifetime of the battery. Always try to keep the
battery at room temperature. A phone with a hot or cold
battery may temporarily not work, even when the battery is
fully charged. Li-ion batteries are particularly affected by
temperatures below 0 °C (32 °F).
• Do not short-circuit the battery. Accidental short- circuiting
can occur when a metallic object (coin, clip or pen) causes
a direct connection between the + and - terminals of the
battery (metal strips on the battery), for example when you
carry a spare battery in a pocket or bag. Short-circuiting
the terminals may damage the battery or the object
causing the short-circuiting.
• Dispose of used batteries in accordance with local
regulations. In some areas, the disposal of batteries in
household or business trash may be prohibited. For safe
disposal options for Li-Ion batteries, contact your nearest
Samsung authorized service center. Always recycle. Do not
dispose of batteries in a fire.
Care and Maintenance
Your phone is a product of superior design and craftsmanship
and should be treated with care. The suggestions below will
help you fulfill any warranty obligations and allow you to enjoy
this product for many years.
• Keep the phone and all its parts and accessories out of the
reach of small children.
• Keep the phone dry. Precipitation, humidity and liquids
contain minerals that will corrode electronic circuits.
• Do not use the phone with a wet hand. Doing so may cause
an electric shock to you or damage to the phone.
• Do not use or store the phone in dusty, dirty areas, as its
moving parts may be damaged.
Health and safety information
191
• Do not store the phone in hot areas. High temperatures can
shorten the life of electronic devices, damage batteries, and
warp or melt certain plastics.
• Do not store the phone in cold areas. When the phone
warms up to its normal operating temperature, moisture
can form inside the phone, which may damage the phone's
electronic circuit boards.
• Do not drop, knock or shake the phone. Rough handling can
break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents or strong
detergents to clean the phone. Wipe it with a soft cloth
slightly dampened in a mild soap-and-water solution.
• Do not paint the phone. Paint can clog the device's moving
parts and prevent proper operation.
• Do not put the phone in or on heating devices, such as a
microwave oven, a stove or a radiator. The phone may
explode when overheated.
• When the phone or battery gets wet, the label indicating
water damage inside the phone changes color. In this case,
phone repairs are no longer guaranteed by the
manufacturer's warranty, even if the warranty for your
phone has not expired.
• If your phone has a flash or light, do not use it too close to
the eyes of people or animals. This may cause damage to
their eyes.
• Use only the supplied or an approved replacement antenna.
Unauthorized antennas or modified accessories may
damage the phone and violate regulations governing radio
devices.
• If the phone, battery, charger or any accessory is not
working properly, take it to your nearest qualified service
facility. The personnel there will assist you, and if
necessary, arrange for service.
