Samsung Electronics Co SGHJ150 PCS GSM/EDGE Phone with Bluetooth User Manual J150
Samsung Electronics Co Ltd PCS GSM/EDGE Phone with Bluetooth J150
Users Manual
* Depending on the software installed or your service provider or country, some of the descriptions in this guide
may not match your phone exactly.
* Depending on your country, your phone and accessories may appear different from the illustrations in this guide.
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-17460A
English (EU). 01/2008. Rev. 1.0
SGH-J150
User’s Guide
2008.1.25
Draft 03
Important safety
precautions
Drive safely at all times
Do not use a hand-held phone while driving. Park
your vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using
them in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Failure to comply with the following
precautions may be dangerous or illegal.
Copyright information
• Bluetooth
®
is a registered trademark of
the Bluetooth SIG, Inc. worldwide.
Bluetooth QD ID: B013710
•Java
TM
is a trademark or registered
trademark of Sun Microsystems, Inc.
1
Be aware of special regulations
Meet any special regulations in force in any area
and always switch off your phone whenever it is
forbidden to use it, or when it may cause
interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to your ear).
Avoid unnecessary contact with the antenna when
the phone is switched on.
Emergency calls
Key in the emergency number for your present
location, then press .
Keep your phone away from small children
Keep the phone and all its parts, including
accessories, out of the reach of small children.
Accessories and batteries
Use only Samsung-approved batteries and
accessories, such as headsets and PC data cables.
Use of any unauthorised accessories could damage
you or your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health
and safety information" on page 39.
• The phone could explode if the battery is replaced
with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.
At very high volumes, prolonged listening
to a headset can damage your hearing.
2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone.
In this guide, the following instruction icons
appear:
Indicates that you need to pay careful
attention to the subsequent information
regarding safety or phone features.
→
Indicates that you need to press the
Navigation keys to scroll to the specified
option and then select it.
[ ] Indicates a key on the phone.
For example, [ ]
< > Indicates a soft key, whose function is
displayed on the phone screen. For
example, <
Menu
>
• Camera and camcorder
Use the camera module on your
phone to take a photo or record
a video.
Special
features of your phone
•Music player
Play music files using your
phone as a music player.
•Java
Enjoy Java-based embedded
games and download new
games.
3
•Image editor
Edit or decorate your photos.
• Digital data printing
Print images, messages, and
personal data directly from your
phone.
•FM radio
Listen to your favourite radio
stations anytime, anywhere.
•Offline mode
Switch your phone to Offline
mode to use its non-wireless
functions while on an airplane.
• Bluetooth
Transfer media files and
personal data, and connect to
other devices using wireless
Bluetooth technology.
•Web browser
Access the wireless web to get
up-to-the-minute information
and a wide variety of media
content.
• SOS message
Send SOS messages to your
family or friends for help in an
emergency.
4
Contents
Unpack 6
Make sure you have each item
Get started 6
First steps to operating your phone
Assemble and charge the phone ...................... 6
Power on or off.............................................. 7
Phone layout ................................................. 7
Keys and icons .............................................. 8
Access menu functions .................................. 11
Enter text .................................................... 12
Customise your phone................................... 13
Step outside the phone 16
Begin with call functions, camera, music player, web
browser and other special features
Make or answer calls ..................................... 16
Use the camera ............................................ 17
Play music................................................... 18
Listen to the FM radio ................................... 20
Browse the web ........................................... 22
Use Phonebook ............................................ 22
Send messages............................................ 23
View messages ............................................ 25
Use Bluetooth .............................................. 26
Menu functions 28
All menu options listed
Health and safety information 39
5
1 Call log
1 Recent contacts
2 Missed calls
3 Dialled calls
4 Received calls
5 Delete all
6 Call manager
2 Phonebook
1 Contact list
2 FDN contacts
3 Create contact
4 Group
5 Speed dial
6 My namecard
7 Own number
8 Management
9 Service number
1
3 Music
4 Browser
1 Home
2 Bookmarks
3 Enter URL
4 Clear cache
5 Profile settings
6 Current profile
5 Messages
1 Create new message
2 My messages
3 Templates
4 Delete by folder
5 Settings
6 SOS messages
7 Broadcast messages
8 Memory status
6 My files
1 Images
2 Videos
3 Music
4 Sounds
5 Games & more
6 My files
6 Other files
7 Memory card
2
8 Memory status
7 Calendar
8 Camera
9 FM radio
* Applications
1 Voice recorder
2 Image editor
3 Bluetooth
4 Memo
5 World clock
6 Calculator
7 Converter
8 Timer
9 Stopwatch
10 SIM application toolkit
1
0 Alarms
# Settings
1 Phone settings
2 Light settings
3 Display settings
4 Message settings
5 Call settings
6 Phonebook settings
7 Calendar settings
8 Browser settings
9 Music player settings
3
10 Network settings
11 Security settings
12 Setup wizard
13 Memory settings
14 Reset settings
1. Available only if supported by
your SIM card.
2. Available only if a memory
card is inserted.
3. Depending on your service
provider, Media player
settings may display instead
of this menu.
Overview of menu functions
To access Menu mode, press <
Menu
> in Idle mode.
6
Unpack
Make sure you have each item
• Phone
•Travel adapter
•Battery
• User’s Guide
You can obtain various accessories from your
local Samsung dealer.
Get started
First steps to operating your phone
Assemble and charge the phone
The items supplied with your phone and the
accessories available at your Samsung dealer
may vary, depending on your country or service
provider.
To AC pow er ou t let
7
Removing the battery cover
Power on or off
Phone layout
Front view
Switch on
1. Press and hold [ ].
2. If necessary, enter the PIN and
press <
OK
>.
3. When the setup wizard opens,
customise your phone
according to your preferences.
Switch off
Press and hold [ ].
Web access/
Confirm key
Earpiece
Dial key
Left soft key
Volume keys
Mouthpiece
Navigation keys
(Up/Down/Left/
Right)
Right soft key
Power/Menu
exit key
Delete key
Display
Special
function keys
Multi-function
jack
Camera key
Alphanumeric
keys
Get started
8
Rear view
Keys and icons
Keys
You can lock the keypad to prevent any
unwanted phone operations from accidentally
pressing any of the keys. In Idle mode, press
and hold [ ] and then <
Yes
>. To unlock the
keypad, press <
Unlock
> and then [ ].
Camera lens
Memory card slot
Perform the function indicated on
the bottom line of the display.
In Idle mode, access the following
menus directly:
• Up: My menu mode
• Down/Left/Right: your
favourite menus
In Menu mode, scroll through
menu options.
In Idle mode, launch the web
browser.
In Menu mode, select the
highlighted menu option or
confirm input.
9
In Idle mode, press and hold to
turn on the camera.
In Camera mode, take a photo or
record a video.
Delete characters from the display
or items in an application.
Make or answer a call.
In Idle mode, retrieve the
numbers recently dialled, missed,
or received.
Press and hold to switch the
phone on or off.
End a call.
In Menu mode, cancel input and
return the phone to Idle mode.
Enter numbers, letters, and some
special characters.
In Idle mode, press and hold [
1
]
to access your voice mail server.
Press and hold [
0
] to enter an
international call prefix.
Enter special characters or
perform special functions.
In Idle mode, press and hold [ ]
to activate or deactivate the Silent
profile.
Adjust the phone volume.
Get started
10
Icons
The following icons may appear on the screen
to indicate your phone’s status. Depending on
your country or service provider, the icons
shown on the display may vary.
Signal strength
Call in progress
Out of your service area or Offline
mode
SOS message feature active
Alarm set
GPRS (2.5G) network status
EDGE network status
Browsing Internet
Connected to secured web page
Call diverting active
Home Zone
Office Zone
Bluetooth active
Bluetooth hands-free car kit or
headset connected
One of the message Inboxes is full
New message:
• : Text message
• : Multimedia message
•: Email
• : Voice mail
11
Access menu functions
Memory card inserted
FM radio on
Profile settings:
•: Normal
• : Silent
• : Driving
• : Meeting
•: Outdoor
• : Offline
• : User created
Battery power level
Select an
option
1. Press a desired soft key.
2. Press the Navigation keys
to move to the next or
previous option.
3. Press <
Select
> or [
OK
] to
confirm the function
displayed or option
highlighted.
4. Press <
Back
> to move up
one level.
Press [ ] to return to Idle
mode.
Use menu
numbers
Press the number key
corresponding to the option
you want.
Get started
12
Enter text
Change the
text input
mode
• Press and hold [ ] to
switch between T9 mode
and ABC mode.
• Press [ ] to change case
or switch to Number mode.
• Press and hold [ ] to
switch to Symbol mode.
ABC mode
To enter a word:
Press the appropriate key until
the character you want
appears on the display.
T9 mode
To e nt e r a w or d:
1. Press [
2
] to [
9
]
to start
entering a word.
2. Enter the whole word
before editing or deleting
characters.
3. When the word displays
correctly, press [ ] to
insert a space.
Otherwise, press [
0
] to
display alternative word
choices.
Number
mode
Press the keys corresponding
to the digits you want.
13
Customise your phone
Symbol
mode
Press the keys corresponding
to the symbols you want.
Other
operations
• Press [
1
] to enter
punctuation marks or
special characters.
• Press [ ] to insert a space.
• Press the Navigation keys
to move the cursor.
• Press [
C
] to delete
characters one by one.
• Press and hold [
C
] to clear
the entire display.
1. In Idle mode, press
<
Menu
> and select
Settings
→
Phone
settings
→
Language
.
2. Select a language.
To change the profile
properties:
1. In Idle mode, press
<
Menu
> and select
Settings
→
Phone
settings
→
Phone
profiles
.
2. Scroll to the profile you are
using.
Display
language
Call ringer
melody
Get started
14
3. Press <
Options
> and
select
Edit
.
4. Select
Voice call
ringtone
.
5. Press [Left] or [Right] to
select a ringtone category.
6. Select a ringtone.
7. Press <
Options
> and
select
Save profile
.
To change the sound profile:
1. In Idle mode, press
<
Menu
> and select
Settings
→
Phone
settings
→
Phone
profiles
.
2. Select the profile you want.
In Idle mode, press [Volume]
to adjust the key tone volume.
1. In Idle mode, press
<
Menu
> and select
Settings
→
Display
settings
→
Home screen
→
Wallpaper
.
2. Select an image category.
3. Select an image.
4. Press <
Select
> and then
<
Save
>.
Key tone
volume
Idle mode
wallpaper
15
1. In Idle mode, press
<
Menu
> and select
Settings
→
Phone
settings
→
Shortcuts
.
2. Select a key.
3. Select a menu to be
assigned to the key.
You can activate the Silent
profile to avoid disturbing
other people. In Idle mode,
press and hold [ ].
Menu
shortcuts
Silent profile
1. In Idle mode, press
<
Menu
> and select
Settings
→
Security
settings
→
Phone lock
.
2. Select
On
.
3. Enter a new 4- to 8-digit
password and press
<
OK
>.
4. Enter the new password
again and press <
OK
>.
Phone lock
16
Step outside the phone
Begin with call functions, camera, music player,
web browser and other special features
Make or answer calls
1. In Idle mode, enter an area
code and phone number.
2. Press [ ].
Press [Volume] to adjust
the volume.
3. Press [ ] to end the call.
1. When the phone rings,
press [ ].
2. Press [ ] to end the call.
Make a call
Answer a call
During a call, press [
OK
] and
then <
Yes
> to activate the
speaker.
Press [
OK
] again to switch
back to the earpiece.
1. During a call, call the
second participant.
The first call is put on
hold.
2. Press <
Options
> and
select
Join
.
3. Repeat step 1 and 2 to add
more participants.
Use the
speakerphone
feature
Make a
multi-party
call
17
Use the camera
4. During a multi-party call:
• Press <
Options
> and
select
Split
to have a
private conversation
with one participant.
• Press <
Options
> and
select
Remove
to drop
one participant.
5. Press [ ] to end the
multi-party call.
1. In Idle mode, press and
hold [ ] to turn on the
camera.
2. Aim the lens at the subject
and make any desired
adjustments.
3. Press [ ] or [
OK
] to take
a photo. The photo is
saved automatically.
4. Press <
Back
> or [ ] to
take another photo.
Take a photo
Step outside the phone
18
Play music
1. In Idle mode, press
<
Menu
> and select
My
files
→
Images
→
My
photos
.
2. Select the photo you want.
1. In Idle mode, press and hold
[ ] to turn on the camera.
2. Press [
1
] to switch to
Recording mode.
3. Press [ ] or [
OK
] to start
recording.
4. Press < >, [ ] or [
OK
]
to stop recording. The video
is saved automatically.
5. Press <> or [ ] to
record another video.
View a photo
Record
a video
1. In Idle mode, press
<
Menu
> and select
My
files
→
Videos
→
My video
clips
.
2. Select the video you want.
Use these methods:
• Download from the wireless
web.
• Download from a computer
using the optional Samsung
PC Studio. See Samsung PC
Studio User’s Guide.
• Receive via Bluetooth.
• Copy to a memory card. See
the next section.
View a video
Prepare
music files
19
1. Insert a memory card
into the phone.
2. In Idle mode, press
<
Menu
> and select
Settings
→
Phone
settings
→
PC
connections
→
Mass
storage
.
3. Connect your phone and
PC with an optional PC
data cable.
4. Select
Open folder to
view files
when a pop-
up window appears on
your PC.
Copy music
files
5. Copy files from the PC to
the memory card.
6. When you have finished,
disconnect the phone from
the PC.
1. In Idle mode, press
<
Menu
> and select
Music
.
2. Press <
Options
> and
select
Add music from
→
a memory location.
3. Press [
OK
] to select the
files you want and press
<
Add
>.
Create a
playlist
Step outside the phone
20
Listen to the FM radio
1. In Idle mode, press
<
Menu
> and select
Music
.
2. Press [
OK
] to play music
files.
3. During playback, use the
following keys:
•
OK
: pause or resume
playback.
• Left: restart playback.
Press to return to the
previous file within 3
seconds after the
playback has started.
Press and hold to scan
backward in a file.
• Right: skip to the next
file. Press and hold to
scan forward in a file.
Play music
files
• Up: open the playlist.
• Volume: adjust the
volume.
4. Press [Down] to stop
playback.
1. Plug the connecter of the
headset, which serves as a
radio antenna, into the
multi-function jack on the
phone.
2. In Idle mode, press
<
Menu
>
and select
FM
radio
.
Listen to
the radio
21
3. Press [
OK
] to turn on the
radio.
4. When you turn on the FM
radio for the first time,
press <
Yes
> to start
automatic tuning.
Available radio stations are
automatically saved.
5. Press [Up] or [Down] to
select a stored radio
station.
Alternatively, press [Left]
or [Right] to find the radio
station you want.
6. Press [
OK
] to turn off the
radio.
By automatic tuning:
1. From the radio screen,
press <
Options
> and
select
Self-tuning
.
2. Press <
Yes
> to confirm.
Available radio stations are
automatically saved.
By manual setup:
1. From the radio screen,
press [Left] or [Right] to
find the radio station you
want.
2. Press <
Options
> and
select
Add to Favourites
.
Store radio
stations
Step outside the phone
22
Browse the web Use Phonebook
In Idle mode, press [
OK
]. The
homepage of your service
provider opens.
• To scroll through browser
items, press [Up] or
[Down].
• To select an item, press
<> or [
OK
].
• To return to the previous
page, press <
Back
> or [
C
].
• To return to the homepage,
press and hold [
C
].
• To access browser options,
press <
Options
>.
Launch the
web browser
Navigate the
web
1. In Idle mode, enter a phone
number and press
<
Options
>.
2. Select
Save
→
a memory
location
→
New
.
3. For
Phone
, select a number
type.
4. Specify contact information.
5. Press <
Save
> or [
OK
] to
save the contact.
1. In Idle mode, press
<
Contacts
>.
2. Enter the first few letters of
the name you want.
Add a contact
Find a contact
23
Send messages
3. Select a contact.
4. Scroll to a number and
press [ ] to dial, or press
[
OK
] to edit contact
information.
1. In Idle mode, press
<
Menu
> and select
Messages
→
Create new
message
→
Text
message
.
2. Enter the message text.
3. Press <
Options
> and
select
Send only
or
Save
and send
.
Send a text
message
4. Enter destination numbers.
5. Press [
OK
] to send the
message.
1. In Idle mode, press
<
Menu
> and select
Messages
→
Create new
message
→
Multimedia
message
.
2. Select
Subject
.
3. Enter the message subject
and press [
OK
].
4. Select
Image or video
and
add an image or a video
clip.
5. Select
Music or sound
and
add a music or a sound clip.
Send a
multimedia
message
Step outside the phone
24
6. Select
Text
.
7. Enter the message text and
press [
OK
].
8. Press <
Options
> and
select
Send
.
9. Enter destination numbers
or email addresses.
10.Press [
OK
] to send the
message.
1. In Idle mode, press
<
Menu
>
and select
Messages
→
Create new
message
→
Email
.
2. Select
Subject
.
Send an email
3. Enter the email subject and
press [
OK
].
4. Select
Message
.
5. Enter the email text and
press [
OK
].
6. Select
File attach
.
7. Add image, video, sound,
music, or document files.
8. Press <
Options
> and
select
Send
.
9. Enter email addresses.
10.Press [
OK
] to send the
email.
25
View messages
1. In Idle mode, press
<
Menu
> and select
Messages
→
My
messages
→
Inbox
.
2. Select a text message.
1. In Idle mode, press
<
Menu
> and select
Messages
→
My
messages
→
Inbox
.
2. Select a multimedia
message.
View a text
message
View a
multimedia
message
1. In Idle mode, press
<
Menu
> and select
Messages
→
My
messages
→
Email
inbox
.
2. Select
Check new mail
.
3. Select an email or a
header.
4. If you selected a header,
press <
Options
> and
select
Retrieve
to view the
body of the email.
View an email
Step outside the phone
26
Use Bluetooth
Your phone is equipped with Bluetooth
technology, enabling you to connect the phone
wirelessly to other Bluetooth devices and
exchange data with them, talk hands-free, or
control the phone remotely.
1. In Idle mode, press
<
Menu
> and select
Applications
→
Bluetooth
→
Activation
→
On
.
2. Select
My phone’s
visibility
→
On
to allow
other devices to locate
your phone.
Turn on
Bluetooth
1. In Idle mode, press
<
Menu
> and select
Applications
→
Bluetooth
→
My devices
→
Search new device
.
2. Select a device.
3. Enter a Bluetooth PIN or
the other device’s
Bluetooth PIN, if it has one,
and press <
OK
>.
4. When the owner of the
other device enters the
same code, pairing is
complete.
Search for
and pair with
a Bluetooth
device
27
1. Access an application, such
as
Phonebook
,
My files
,
Calendar
, or
Memo
.
2. Select an item.
3. Press <
Options
> and
select
Send via
→
Bluetooth
.
4. For sending a contact,
select which data you want
to send.
5. Search for and select a
device.
6. If necessary, enter a
Bluetooth PIN and press
<
OK
>.
Send data
1. If necessary, enter the
Bluetooth PIN and press
<
OK
>.
2. Press <
Yes
> to confirm
that you are willing to
receive.
Receive data
28
Menu functions
All menu options listed
This section provides brief explanations of
menu functions on your phone.
Call log
Phonebook
Menu Description
Recent
contacts,
Missed calls,
Dialled calls,
Received calls
Check the most recent calls
dialled, received, or missed.
Delete all Delete all of the records in
each call type.
Call manager
→
Call time
Check the time record for
calls made and received.
Call manager
→
Call costs
Check the cost of your calls,
if supported by your SIM
card.
Call manager
→
Reject list
Make a list of the phone
numbers of callers to reject.
Menu Description
Contact list Search for contact
information stored in
Phonebook.
Menu Description
29
Music
Listen to music. You can also make your own
music playlists.
FDN contacts Create a list of contacts to be
used in FDN (Fixed Dialling
Number) mode, in which the
phone allows outgoing calls
only to the specified phone
numbers, if your SIM card
supports this feature.
Create contact Add a new contact to
Phonebook.
Group Organise your contacts in
caller groups.
Speed dial Assign a speed dial number
for your most frequently
dialled numbers.
My namecard Create a name card and
send it to other people.
Menu Description
Own number Check your phone numbers,
or assign a name to each of
the numbers.
Management Manage contacts in
Phonebook or change the
default settings for
Phonebook.
Service
number
View the SDN (Service
Dialling Number) list
assigned by your service
provider, if supported by
your SIM card.
Menu Description
Menu functions
30
Browser
Messages
Menu Description
Home Connect your phone to the
network and load the
homepage of the wireless
web service provider.
Bookmarks Save URL addresses in order
to quickly access web pages.
Enter URL Enter a URL address and
access the associated web
page.
Clear cache Clear the cache, which is a
temporary memory site that
stores recently accessed web
pages.
Profile settings Set up connection profiles for
the web browser.
Current profile Select a connection profile to
be used for accessing the
wireless web.
Menu Description
Create new
message
Create and send text,
multimedia, or email
messages.
My messages Access messages that you
have received, sent, or that
have failed during sending.
Templates Make and use templates of
frequently used messages or
passages.
Menu Description
31
My files
Delete by
folder
Delete messages in each
message folder all at once.
Settings Set up various options for
using the messaging
services.
SOS messages Specify options for sending
and receiving an SOS
message. You can send an
SOS message by pressing
[Volume] 4 times when the
exposed keys are locked.
Broadcast
messages
Access the received
broadcast messages or
change the settings for
receiving broadcast
messages.
Menu Description
Memory status Check information about the
memory currently in use.
Menu Description
Images,
Videos, Music,
Sounds, Other
files
Access media files and other
files stored in the phone’s
memory.
Games & more Access the embedded Java
games.
Memory card Access the files stored on a
memory card. This menu is
only available when you
insert a memory card into
the phone.
Menu Description
Menu functions
32
Calendar
Keep track of your schedule.
Camera
Use the camera embedded in your phone to
take photos and record videos.
FM radio
Listen to music or news via the FM radio on
your phone.
Applications
Memory status Check information about the
memory currently in use.
Menu Description
Menu Description
Voice recorder Record voice memos and any
other sounds.
Image editor Edit your photos using
various editing tools.
Bluetooth Connect the phone wirelessly
to other Bluetooth devices.
Memo Make memos for things that
are important and manage
them.
World clock Set your local time zone and
find out the current time in
another part of the world.
Calculator Perform arithmetic functions.
33
Alarms
Set a wake-up alarm to wake you up in the
morning or an alarm to alert you to an event at
a specific time.
Settings
Converter Do conversions, such as
length and temperature.
Timer Set a period of time for the
phone to count down.
Stopwatch Measure elapsed time.
SIM
application
toolkit
Use a variety of additional
services offered by your
service provider. Depending
on your SIM card, this menu
may be available but labelled
differently.
Menu Description
Menu Description
Phone settings
→
Phone
profiles
Change the sound settings of
the phone for different
events or situations.
Phone settings
→
Language
Select a language for the
display text.
Phone settings
→
Shortcuts
Use the Navigation keys as
shortcuts to access specific
menus directly from Idle
mode. [Up] is fixed as a
shortcut to My menu mode.
Phone settings
→
Time and
date
Change the time and date
displayed on your phone.
Menu functions
34
Phone settings
→
Auto keypad
lock
Set the phone to lock the
keypad automatically when
the display turns off.
Phone settings
→
Volume key
Set how the phone reacts if
you press and hold [Volume]
when a call comes in.
Phone settings
→
Show caller
information
Set the phone to display or
block caller information on all
missed calls and incoming
messages.
Phone settings
→
My menu
Set up a menu of your own
using your favourite menu
items, which can be easily
accessed by pressing [Up] in
Idle mode.
Menu Description
Phone settings
→
PC
connections
Select a USB mode that will
be used when you connect
your phone to another device
via USB interface.
Light settings
→
Backlight
time
Select the length of time the
backlight or display stays on
when the phone is not used.
Light settings
→
Brightness
Adjust the brightness of the
display for varying lighting
conditions.
Light settings
→
Keypad light
Set how the phone controls
the use of the keypad light.
Display
settings
→
Home screen
Set up the idle screen on the
display.
Menu Description
35
Display
settings
→
My
theme
Select a skin colour pattern
for Menu mode.
Display
settings
→
Text
display
Change the display settings
for the text displayed on the
idle screen.
Display
settings
→
Pop
up list menu
Display the pop-up list that
shows the menu options.
Display
settings
→
Dialling display
Customise the settings for
the display while dialling.
Display
settings
→
Greeting
message
Enter the greeting that is
displayed briefly when the
phone is switched on.
Menu Description
Display
settings
→
Menu
transition
effect
Select a transition when you
move between menus in
Menu mode.
Message
settings
Set up various options for
using the messaging
services.
Call settings Set options for call functions.
Phonebook
settings
→
Speed dial
Assign speed dial numbers
for your most frequently
dialled numbers.
Phonebook
settings
→
Save new
contacts to
Select a default memory
location for saving contacts.
Menu Description
Menu functions
36
Phonebook
settings
→
Own
number
Check your phone numbers,
or assign a name to each of
the numbers.
Calendar
settings
→
Starting day
Select which day of the week
the calendar starts with.
Calendar
settings
→
Default view
by
Select the default calendar
view mode.
Browser
settings
Create and customise the
profiles containing the
settings for connecting your
phone to the network.
Menu Description
Music player
settings/Media
player settings
Depending on your service
provider, you may have one
of these menus:
•
Music player settings
:
change the default
settings for playing music.
•
Media player settings
:
change the default
settings for playing music.
Also, select a connection
profile for accessing a
video streaming server.
Network
settings
→
Select network
Select the network to be
used while roaming outside
of your home area, or let the
network be chosen
automatically.
Menu Description
37
Network
settings
→
Network mode
Change to an appropriate
band when you travel
abroad.
Security
settings
→
Phone lock
Activate your phone
password to protect your
phone against unauthorised
use.
Security
settings
→
SIM
lock
Set the phone to work only
with the current SIM card by
assigning a SIM lock
password.
Security
settings
→
PIN
lock
Activate your PIN to protect
your SIM card against
unauthorised use.
Menu Description
Security
settings
→
Privacy lock
Lock access to call logs,
contacts, messages, or files.
Security
settings
→
Fixed dialling
mode
Set the phone to restrict calls
to a limited set of phone
numbers, if supported by
your SIM card.
Security
settings
→
Change
password
Change the phone password.
Security
settings
→
Change PIN
code
Change the PIN.
Menu Description
38
Security
settings
→
Change PIN2
code
Change your current PIN2, if
supported by your SIM card.
Security
settings
→
Mobile tracker
Set the phone to send the
preset tracking message to
your family or friends when
someone tries to use your
phone with another SIM
card. This feature may be
unavailable due to certain
features supported by your
service provider.
Menu Description
Setup wizard Quickly customise basic
settings of your phone.
Select the option you want
for each setting by following
the onscreen instructions.
Memory
settings
Change the settings related
with the memory and check
information about the
memory currently in use. You
can also clear the memory.
Reset settings Reset the phone’s settings
you have changed.
Menu Description
39
40
Health and safety information
Exposure to Radio Frequency (RF) Signals
Certification Information (SAR)
Your wireless phone is a radio transmitter and receiver.
It is designed and manufactured not to exceed the
exposure limits for radio frequency (RF) energy set by
the Federal Communications Commission (FCC) of the
U.S. government. These FCC exposure limits are
derived from the recommendations of two expert
organizations, the National Counsel on Radiation
Protection and Measurement (NCRP) and the Institute
of Electrical and Electronics Engineers (IEEE). In both
cases, the recommendations were developed by
scientific and engineering experts drawn from industry,
government, and academia after extensive reviews of
the scientific literature related to the biological effects
of RF energy.
The exposure limit set by the FCC for wireless mobile
phones employs a unit of measurement known as the
Specific Absorption Rate (SAR). The SAR is a measure
of the rate of absorption of RF energy by the human
body expressed in units of watts per kilogram (W/kg).
The FCC requires wireless phones to comply with a
safety limit of 1.6 watts per kilogram (1.6 W/kg). The
FCC exposure limit incorporates a substantial margin of
safety to give additional protection to the public and to
account for any variations in measurements.
SAR tests are conducted using standard operating
positions accepted by the FCC with the phone
transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is
determined at the highest certified power level, the
actual SAR level of the phone while operating can be
well below the maximum value. This is because the
phone is designed to operate at multiple power levels so
as to use only the power required to reach the network.
In general, the closer you are to a wireless base station
antenna, the lower the power output.
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that it
does not exceed the exposure limit established by the
41
FCC. Tests for each model phone are performed in
positions and locations (e.g. at the ear and worn on the
body) as required by the FCC.
The highest SAR values for this model phone as
reported to the FCC are: GSM1900 Head: 0.569 W/Kg,
Body-worn: 0.68 W/Kg.
For body worn operation, this model phone has been
tested and meets the FCC RF exposure guidelines
whenused with a Samsung accessory designated for
this product or when used with an accessory that
contains no metal and that positions the handset a
minimum of 1.5 cm from the body.
Non-compliance with the above restrictions may result
in violation of FCC RF exposure guidelines.
SAR information on this and other model phones can be
viewed on-line at www.fcc.gov/oet/fccid. This site uses
the phone FCC ID number, A3LSGHJ150 Sometimes it
may be necessary to remove the battery pack to find
the number. Once you have the FCC ID number for a
particular phone, follow the instructions on the website
and it should provide values for typical or maximum
SAR for a particular phone. Additional product specific
SAR information can also be obtained at www.fcc.gov/
cgb/sar.
Consumer Information on Wireless Phones
The U.S. Food and Drug Administration (FDA) has
published a series of Questions and Answers for
consumers relating to radio frequency (RF) exposure
from wireless phones. The FDA publication includes the
following information:
What kinds of phones are the subject of this
update?
The term wireless phone refers here to hand-held
wireless phones with built-in antennas, often called
“cell,” “mobile,” or “PCS” phones. These types of
wireless phones can expose the user to measurable
radio frequency energy (RF) because of the short
distance between the phone and the user's head. These
RF exposures are limited by Federal Communications
Commission safety guidelines that were developed with
the advice of FDA and other federal health and safety
agencies. When the phone is located at greater
distances from the user, the exposure to RF is
Health and safety information
42
drastically lower because a person's RF exposure
decreases rapidly with increasing distance from the
source. The so-called “cordless phones,” which have a
base unit connected to the telephone wiring in a house,
typically operate at far lower power levels, and thus
produce RF exposures well within the FCC's compliance
limits.
Do wireless phones pose a health hazard?
The available scientific evidence does not show that any
health problems are associated with using wireless
phones. There is no proof, however, that wireless
phones are absolutely safe. Wireless phones emit low
levels of radio frequency energy (RF) in the microwave
range while being used. They also emit very low levels
of RF when in the stand-by mode. Whereas high levels
of RF can produce health effects (by heating tissue),
exposure to low level RF that does not produce heating
effects causes no known adverse health effects. Many
studies of low level RF exposures have not found any
biological effects. Some studies have suggested that
some biological effects may occur, but such findings
have not been confirmed by additional research. In
some cases, other researchers have had difficulty in
reproducing those studies, or in determining the
reasons for inconsistent results.
What is FDA's role concerning the safety of
wireless phones?
Under the law, FDA does not review the safety of
radiation-emitting consumer products such as wireless
phones before they can be sold, as it does with new
drugs or medical devices. However, the agency has
authority to take action if wireless phones are shown to
emit radio frequency energy (RF) at a level that is
hazardous to the user. In such a case, FDA could
require the manufacturers of wireless phones to notify
users of the health hazard and to repair, replace or
recall the phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA
regulatory actions, FDA has urged the wireless phone
industry to take a number of steps, including the
following:
• “Support needed research into possible biological
effects of RF of the type emitted by wireless phones;
43
• “Design wireless phones in a way that minimizes
any RF exposure to the user that is not necessary
for device function; and
• “Cooperate in providing users of wireless phones
with the best possible information on possible
effects of wireless phone use on human health.
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at the
federal level. The following agencies belong to this
working group:
• “National Institute for Occupational Safety and
Health
• “Environmental Protection Agency
• “Federal Communications Commission
• “Occupational Safety and Health Administration
• “National Telecommunications and Information
Administration
The National Institutes of Health participates in some
interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless
phones with the Federal Communications Commission
(FCC). All phones that are sold in the United States
must comply with FCC safety guidelines that limit RF
exposure. FCC relies on FDA and other health agencies
for safety questions about wireless phones.
FCC also regulates the base stations that the wireless
phone networks rely upon. While these base stations
operate at higher power than do the wireless phones
themselves, the RF exposures that people get from
these base stations are typically thousands of times
lower than those they can get from wireless phones.
Base stations are thus not the primary subject of the
safety questions discussed in this document.
What are the results of the research done
already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws in
their research methods. Animal experiments
investigating the effects of radio frequency energy (RF)
exposures characteristic of wireless phones have
Health and safety information
44
yielded conflicting results that often cannot be repeated
in other laboratories. A few animal studies, however,
have suggested that low levels of RF could accelerate
the development of cancer in laboratory animals.
However, many of the studies that showed increased
tumor development used animals that had been
genetically engineered or treated with cancer-causing
chemicals so as to be pre-disposed to develop cancer in
absence of RF exposure. Other studies exposed the
animals to RF for up to 22 hours per day. These
conditions are not similar to the conditions under which
people use wireless phones, so we don't know with
certainty what the results of such studies mean for
human health.
Three large epidemiology studies have been published
since December 2000. Between them, the studies
investigated any possible association between the use
of wireless phones and primary brain cancer, glioma,
meningioma, or acoustic neuroma, tumors of the brain
or salivary gland, leukemia, or other cancers. None of
the studies demonstrated the existence of any harmful
health effects from wireless phones RF exposures.
However, none of the studies can answer questions
about long-term exposures, since the average period of
phone use in these studies was around three years.
What research is needed to decide whether RF
exposure from wireless phones poses a health
risk?
A combination of laboratory studies and epidemiological
studies of people actually using wireless phones would
provide some of the data that are needed. Lifetime
animal exposure studies could be completed in a few
years. However, very large numbers of animals would
be needed to provide reliable proof of a cancer
promoting effect if one exists. Epidemiological studies
can provide data that is directly applicable to human
populations, but ten or more years' follow-up may be
needed to provide answers about some health effects,
such as cancer. This is because the interval between the
time of exposure to a cancer-causing agent and the
time tumors develop - if they do - may be many, many
years. The interpretation of epidemiological studies is
hampered by difficulties in measuring actual RF
exposure during day-to-day use of wireless phones.
Many factors affect this measurement, such as the
45
angle at which the phone is held, or which model of
phone is used.
What is FDA doing to find out more about the
possible health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology
Program and with groups of investigators around the
world to ensure that high priority animal studies are
conducted to address important questions about the
effects of exposure to radio frequency energy (RF).
FDA has been a leading participant in the World Health
Organization international Electromagnetic Fields (EMF)
Project since its inception in 1996. An influential result
of this work has been the development of a detailed
agenda of research needs that has driven the
establishment of new research programs around the
world. The Project has also helped develop a series of
public information documents on EMF issues.
FDA and Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative Research
and Development Agreement (CRADA) to do research
on wireless phone safety. FDA provides the scientific
oversight, obtaining input from experts in government,
industry, and academic organizations. CTIA-funded
research is conducted through contracts to independent
investigators. The initial research will include both
laboratory studies and studies of wireless phone users.
The CRADA will also include a broad assessment of
additional research needs in the context of the latest
research developments around the world.
What steps can I take to reduce my exposure
to radio frequency energy from my wireless
phone?
If there is a risk from these products - and at this point
we do not know that there is - it is probably very small.
But if you are concerned about avoiding even potential
risks, you can take a few simple steps to minimize your
exposure to radio frequency energy (RF). Since time is
a key factor in how much exposure a person receives,
reducing the amount of time spent using a wireless
phone will reduce RF exposure.
• “If you must conduct extended conversations by
wireless phone every day, you could place more
distance between your body and the source of the
Health and safety information
46
RF, since the exposure level drops off dramatically
with distance. For example, you could use a headset
and carry the wireless phone away from your body
or use a wireless phone connected to a remote
antenna.
Again, the scientific data do not demonstrate that
wireless phones are harmful. But if you are concerned
about the RF exposure from these products, you can
use measures like those described above to reduce your
RF exposure from wireless phone use.
What about children using wireless phones?
The scientific evidence does not show a danger to users
of wireless phones, including children and teenagers. If
you want to take steps to lower exposure to radio
frequency energy (RF), the measures described above
would apply to children and teenagers using wireless
phones. Reducing the time of wireless phone use and
increasing the distance between the user and the RF
source will reduce RF exposure.
Some groups sponsored by other national governments
have advised that children be discouraged from using
wireless phones at all. For example, the government in
the United Kingdom distributed leaflets containing such
a recommendation in December 2000. They noted that
no evidence exists that using a wireless phone causes
brain tumors or other ill effects. Their recommendation
to limit wireless phone use by children was strictly
precautionary; it was not based on scientific evidence
that any health hazard exists.
Do hands-free kits for wireless phones reduce
risks from exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that hands-free kits reduce risks. Hands-free
kits can be used with wireless phones for convenience
and comfort. These systems reduce the absorption of
RF energy in the head because the phone, which is the
source of the RF emissions, will not be placed against
the head. On the other hand, if the phone is mounted
against the waist or other part of the body during use,
then that part of the body will absorb more RF energy.
Wireless phones marketed in the U.S. are required to
meet safety requirements regardless of whether they
47
are used against the head or against the body. Either
configuration should result in compliance with the
safety limit.
Do wireless phone accessories that claim to
shield the head from RF radiation work?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that accessories that claim to shield the head
from those emissions reduce risks. Some products that
claim to shield the user from RF absorption use special
phone cases, while others involve nothing more than a
metallic accessory attached to the phone. Studies have
shown that these products generally do not work as
advertised. Unlike “hand-free” kits, these so-called
“shields” may interfere with proper operation of the
phone. The phone may be forced to boost its power to
compensate, leading to an increase in RF absorption. In
February 2002, the Federal trade Commission (FTC)
charged two companies that sold devices that claimed
to protect wireless phone users from radiation with
making false and unsubstantiated claims. According to
FTC, these defendants lacked a reasonable basis to
substantiate their claim.
What about wireless phone interference with
medical equipment?
Radio frequency energy (RF) from wireless phones can
interact with some electronic devices. For this reason,
FDA helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted cardiac
pacemakers and defibrillators from wireless telephones.
This test method is now part of a standard sponsored
by the Association for the Advancement of Medical
instrumentation (AAMI). The final draft, a joint effort by
FDA, medical device manufacturers, and many other
groups, was completed in late 2000. This standard will
allow manufacturers to ensure that cardiac pacemakers
and defibrillators are safe from wireless phone EMI. FDA
has tested wireless phones and helped develop a
voluntary standard sponsored by the Institute of
Electrical and Electronic Engineers (IEEE). This
standard specifies test methods and performance
requirements for hearing aids and wireless phones so
that no interference occurs when a person uses a
Health and safety information
48
compatible phone and a compatible hearing aid at the
same time. This standard was approved by the IEEE in
2000.
FDA continues to monitor the use of wireless phones for
possible interactions with other medical devices. Should
harmful interference be found to occur, FDA will conduct
testing to assess the interference and work to resolve
the problem.
• Additional information on the safety of RF exposures
from various sources can be obtained from the
following organizations:
• FCC RF Safety Program:
• http://www.fcc.gov/oet/rfsafety/
• Environmental Protection Agency (EPA):
• http://www.epa.gov/radiation/
• Occupational Safety and Health Administration's
(OSHA):
• http://www.osha.gov/SLTC/
radiofrequencyradiation/index.html
• National institute for Occupational Safety and Health
(NIOSH):
• http://www.cdc.gov/niosh/emfpg.html
• World health Organization (WHO):
• http://www.who.int/peh-emf/
• International Commission on Non-Ionizing Radiation
Protection:
• http://www.icnirp.de
• National Radiation Protection Board (UK):
• http://www.nrpb.org.uk
• Updated 4/3/2002: US food and Drug
Administration
• http://www.fda.gov/cellphones
49
Road Safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime. But
an important responsibility accompanies the benefits of
wireless phones, one that every user must uphold.
When driving a car, driving is your first responsibility.
When using your wireless phone behind the wheel of a
car, practice good common sense and remember the
following tips:
1. Get to know your wireless phone and its features,
such as speed dial and redial. If available, these
features help you to place your call without taking
your attention off the road.
2. When available, use a hands-free device. If possible,
add an additional layer of convenience and safety to
your wireless phone with one of the many hands
free accessories available today.
3. Position your wireless phone within easy reach. Be
able to access your wireless phone without
removing your eyes from the road. If you get an
incoming call at an inconvenient time, let your voice
mail answer it for you.
4. Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy
traffic or hazardous weather conditions. Rain, sleet,
snow, ice and even heavy traffic can be hazardous.
5. Do not take notes or look up phone numbers while
driving. Jotting down a “to do” list or flipping
through your address book takes attention away
from your primary responsibility, driving safely.
6. Dial sensibly and assess the traffic; if possible, place
calls when you are not moving or before pulling into
traffic. Try to plan calls when your car will be
stationary. If you need to make a call while moving,
dial only a few numbers, check the road and your
mirrors, then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting. Make people
you are talking with aware you are driving and
suspend conversations that have the potential to
divert your attention from the road.
Health and safety information
50
8. Use your wireless phone to call for help. Dial 9-1-1
or other local emergency number in the case of fire,
traffic accident or medical emergencies. Remember,
it is a free call on your wireless phone!
9. Use your wireless phone to help others in
emergencies. If you see an auto accident, crime in
progress or other serious emergency where lives are
in danger, call 9-1-1 or other local emergency
number, as you would want others to do for you.
10.Call roadside assistance or a special non-emergency
wireless assistance number when necessary. If you
see a broken-down vehicle posing no serious
hazard, a broken traffic signal, a minor traffic
accident where no one appears injured, or a vehicle
you know to be stolen, call roadside assistance or
other special non-emergency number.
“The wireless industry reminds you to use
your phone safely when driving.”
For more information, please call 1-888-901-SAFE, or
visit our web-site www.wow-com.com
Provided by the Cellular Telecommunications & Internet
Association
Operating Environment
Remember to follow any special regulations in force in
any area and always switch your phone off whenever it
is forbidden to use it, or when it may cause interference
or danger. When connecting the phone or any accessory
to another device, read its user's guide for detailed
safety instructions. Do not connect incompatible
products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation of
the equipment and for the safety of personnel, it is
recommended that the equipment should only be used
in the normal operating position (held to your ear with
the antenna pointing over your shoulder).
51
Using Your Phone Near Other Electronic
Devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against the
RF signals from your wireless phone. Consult the
manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a minimum
distance of 15 cm (6 inches) be maintained between a
wireless phone and a pacemaker to avoid potential
interference with the pacemaker.
These recommendations are consistent with the
independent research and recommendations of Wireless
Technology Research.
Persons with pacemakers:
• should always keep the phone more than 15 cm
(6 inches) from their pacemaker when the phone is
switched on.
• should not carry the phone in a breast pocket.
• should use the ear opposite the pacemaker to
minimize potential interference.
If you have any reason to suspect that interference is
taking place, switch your phone off immediately.
Hearing Aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you
may wish to consult your hearing aid manufacturer to
discuss alternatives.
Other Medical Devices
If you use any other personal medical devices, consult
the manufacturer of your device to determine if it is
adequately shielded from external RF energy. Your
physician may be able to assist you in obtaining this
information. Switch your phone off in health care
facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care facilities
may be using equipment that could be sensitive to
external RF energy.
Health and safety information
52
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle. You should also
consult the manufacturer of any equipment that has
been added to your vehicle.
Posted Facilities
Switch your phone off in any facility where posted
notices require you to do so.
Potentially Explosive Environments
Switch your phone off when in any area with a
potentially explosive atmosphere and obey all signs and
instructions. Sparks in such areas could cause an
explosion or fire resulting in bodily injury or even death.
Users are advised to switch the phone off while at a
refueling point (service station). Users are reminded of
the need to observe restrictions on the use of radio
equipment in fuel depots (fuel storage and distribution
areas), chemical plants or where blasting operations
are in progress.
Areas with a potentially explosive atmosphere are often
but not always clearly marked. They include below deck
on boats, chemical transfer or storage facilities, vehicles
using liquefied petroleum gas (such as propane or
butane), areas where the air contains chemicals or
particles, such as grain, dust or metal powders, and any
other area where you would normally be advised to turn
off your vehicle engine.
53
Emergency Calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well as
user programmed functions, which cannot guarantee
connection in all conditions. Therefore, you should
never rely solely on any wireless phone for essential
communications (medical emergencies, for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not be
possible on all wireless phone networks or when certain
network services and/or phone features are in use.
Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location (for example. 911 or other official
emergency number). Emergency numbers vary by
location
3. Press [ ] .
If certain features are in use (call barring, for example),
you may first need to deactivate those features before
you can make an emergency call. Consult this
document and your local cellular service provider.
When making an emergency call, remember to give all
the necessary information as accurately as possible.
Remember that your phone may be the only means of
communication at the scene of an accident; do not cut
off the call until given permission to do so.
Restricting Children's access to your Phone
Your phone is not a toy. Children should not be allowed
to play with it because they could hurt themselves and
others, damage the phone or make calls that increase
your phone bill.
Health and safety information
54
FCC Notice and Cautions
•This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) this device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
•This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate
radio frequency energy and,
if not installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is
encouraged to try to correct the interference by
one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment
and receiver.
-Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
-Consult the dealer or an experienced radio/TV
technician for help.
55
The phone may cause TV or radio interference if used in
close proximity to receiving equipment. The FCC can
require you to stop using the phone if such interference
cannot be eliminated.
Vehicles using liquefied petroleum gas (such as propane
or butane) must comply with the National Fire
Protection Standard (NFPA-58). For a copy of this
standard, contact the National Fire Protection
Association, One Battery march Park, Quincy, MA
02269, Attn: Publication Sales Division.
Cautions
Changes or modifications made in the radio phone, not
expressly approved by Samsung, will void the user’s
authority to operate the equipment.
Only use approved batteries, antennas and chargers.
The use of any unauthorized accessories may be
dangerous and void the phone warranty if said
accessories cause damage or a defect to the phone.
Although your phone is quite sturdy, it is a complex
piece of equipment and can be broken. Avoid dropping,
hitting, bending or sitting on it.
Other Important Safety Information
• Only qualified personnel should service the phone or
install the phone in a vehicle. Faulty installation or
service may be dangerous and may invalidate any
warranty applicable to the device.
• Check regularly that all wireless phone equipment in
your vehicle is mounted and operating properly.
• Do not store or carry flammable liquids, gases or
explosive materials in the same compartment as the
phone, its parts or accessories.
• For vehicles equipped with an air bag, remember
that an air bag inflates with great force. Do not
place objects, including both installed or portable
wireless equipment in the area over the air bag or in
the air bag deployment area. If wireless equipment
is improperly installed and the air bag inflates,
serious injury could result.
• Switch your phone off before boarding an aircraft.
The use of wireless phone in aircraft is illegal and
may be dangerous to the aircraft's operation.
Health and safety information
56
• Failure to observe these instructions may lead to the
suspension or denial of telephone services to the
offender, or legal action, or both.
Product Performance
Getting the Most Out of Your Signal Reception
The quality of each call you make or receive depends on
the signal strength in your area. Your phone informs
you of the current signal strength by displaying a
number of bars next to the signal strength icon. The
more bars displayed, the stronger the signal.
If you're inside a building, being near a window may
give you better reception.
Understanding the Power Save Feature
If your phone is unable to find a signal after 15 minutes
of searching, a Power Save feature is automatically
activated. If your phone is active, it periodically
rechecks service availability or you can check it yourself
by pressing any key.
Anytime the Power Save feature is activated, a
message displays on the screen. When a signal is
found, your phone returns to standby mode.
Maintaining Your Phone's Peak Performance
For the best care of your phone, only authorized
personnel should service your phone and accessories.
Faulty service may void the warranty.
There are several simple guidelines to operating your
phone properly and maintaining safe, satisfactory
service.
• Hold the phone with the antenna raised, fully-
extended and over your shoulder.
• Try not to hold, bend or twist the phone's antenna.
• Don't use the phone if the antenna is damaged.
• Speak directly into the phone's receiver.
• Avoid exposing your phone and accessories to rain
or liquid spills. If your phone does get wet,
immediately turn the power off and remove the
battery. If it is inoperable, call Customer Care for
service.
57
Availability of Various Features/Ring
Tones
Many services and features are network dependent and
may require additional subscription and/or usage
charges. Not all features are available for purchase or
use in all areas. Downloadable Ring Tones may be
available at an additional cost. Other conditions and
restrictions may apply. See your service provider for
additional information.
Battery Standby and Talk Time
Standby and talk times will vary depending on phone
usage patterns and conditions. Battery power
consumption depends on factors such as network
configuration, signal strength, operating temperature,
features selected, frequency of calls, and voice, data,
and other application usage patterns.
Battery Precautions
• Never use any charger or battery that is damaged in
any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network's base
station, it uses less power; talk and standby time
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
• Battery charging time depends on the remaining
battery charge and the type of battery and charger
used. The battery can be charged and discharged
hundreds of times, but it will gradually wear out.
When the operation time (talk time and standby
time) is noticeably shorter than normal, it is time to
buy a new battery.
• If left unused, a fully charged battery will discharge
itself over time.
• Use only Samsung-approved batteries and recharge
your battery only with Samsung-approved chargers.
Health and safety information
58
When a charger is not in use, disconnect it from the
power source. Do not leave the battery connected to
a charger for more than a week, since overcharging
may shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling or
warming first.
• Do not leave the battery in hot or cold places, such
as in a car in summer or winter conditions, as you
will reduce the capacity and lifetime of the battery.
Always try to keep the battery at room temperature.
A phone with a hot or cold battery may temporarily
not work, even when the battery is fully charged. Li-
ion batteries are particularly affected by
temperatures below 0 °C (32 °F).
• Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object (coin, clip
or pen) causes a direct connection between the +
and - terminals of the battery (metal strips on the
battery), for example when you carry a spare
battery in a pocket or bag. Short-circuiting the
terminals may damage the battery or the object
causing the short-circuiting.
• Dispose of used batteries in accordance with local
regulations. In some areas, the disposal of batteries
in household or business trash may be prohibited.
For safe disposal options for Li-Ion batteries, contact
your nearest Samsung authorized service center.
Always recycle. Do not dispose of batteries in a fire.
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for many
years.
• Keep the phone and all its parts and accessories out
of the reach of small children.
• Keep the phone dry. Precipitation, humidity and
liquids contain minerals that will corrode electronic
circuits.
59
• Do not use the phone with a wet hand. Doing so
may cause an electric shock to you or damage to
the phone.
• Do not use or store the phone in dusty, dirty areas,
as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt certain
plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the phone,
which may damage the phone's electronic circuit
boards.
• Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the phone. Wipe it with a
soft cloth slightly dampened in a mild soap-and-
water solution.
• Do not paint the phone. Paint can clog the device's
moving parts and prevent proper operation.
• Do not put the phone in or on heating devices, such
as a microwave oven, a stove or a radiator. The
phone may explode when overheated.
• When the phone or battery gets wet, the label
indicating water damage inside the phone changes
color. In this case, phone repairs are no longer
guaranteed by the manufacturer's warranty, even if
the warranty for your phone has not expired.
• If your phone has a flash or light, do not use it too
close to the eyes of people or animals. This may
cause damage to their eyes.
• Use only the supplied or an approved replacement
antenna. Unauthorized antennas or modified
accessories may damage the phone and violate
regulations governing radio devices.
• If the phone, battery, charger or any accessory is
not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
