Samsung Electronics Co SGHL170 PCS GSM/EDGE Phone with Bluetooth User Manual U100

Samsung Electronics Co Ltd PCS GSM/EDGE Phone with Bluetooth U100

Users Manual

* Depending on the software installed or your service provider or country, some of the descriptions in this guide
may not match your phone exactly.
* Depending on your country, your phone and accessories may appear different from the illustrations in this guide.
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-XXXXXA
English (EU). 09/2008. Rev. 1.0
SGH-L170
User’s Guide
Copyright information
•Bluetooth
®
is a registered trademark of the
Bluetooth SIG, Inc. worldwide.
Bluetooth QD ID: B0XXXXX
•Java
TM
is a trademark or registered trademark of
Sun Microsystems, Inc.
• Picsel and Picsel Viewer
TM
are trademarks of Picsel
Technologies, Inc.
• Windows Media Player
®
is a registered trademark of
Microsoft Corporation.
Important safety
precautions
Drive safely at all times
Do not use a hand-held phone while driving. Park
your vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using
them in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Failure to comply with the following
precautions may be dangerous or illegal.
1
Be aware of special regulations
Meet any special regulations in force in any area
and always switch off your phone whenever it is
forbidden to use it, or when it may cause
interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to your ear).
Avoid unnecessary contact with the antenna when
the phone is switched on.
Emergency calls
Key in the emergency number for your present
location, then press .
Keep your phone away from small children
Keep the phone and all its parts, including
accessories, out of the reach of small children.
Accessories and batteries
Use only Samsung-approved batteries and
accessories, such as headsets and PC data cables.
Use of any unauthorised accessories could damage
you or your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health
and safety information" on page 39.
• The phone could explode if the battery is replaced
with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.
At very high volumes, prolonged listening
to a headset can damage your hearing.
2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone.
In this guide, the following instruction icons
appear:
Indicates that you need to pay careful
attention to the subsequent information
regarding safety or phone features.
→
Indicates that you need to press the
Navigation keys to scroll to the specified
option and then select it.
[ ] Indicates a key on the phone.
For example, [ ]
< > Indicates a soft key, whose function is
displayed on the phone screen. For
example, <
Menu
>
• Camera and camcorder
Use the camera module on your
phone to take a photo or record
a video.
Special
features of your phone
• Synchronisation with
Windows Media Player
Transfer music files to your
phone directly from the Windows
Media Player.
• Music player
Play music files using your
phone as a music player. You can
use other phone functions while
listening to music.
3
• Image editor
Edit or decorate your photos.
• Photo printing
Print your photos to preserve
your best moments forever.
•Phone to TV
View photos and video clips
captured with the phone on your
TV screen.
• Offline mode
Switch your phone to Offline
mode to use its non-wireless
functions while on an aeroplane.
•Bluetooth
Transfer media files and
personal data, and connect to
other devices using wireless
Bluetooth technology.
• File viewer
Open documents in various
formats on the phone without
corruption.
• Multimedia Message Service
(MMS)
Send and receive MMS
messages with a combination of
text, images, video, and audio.
•SOS message
Send SOS messages to your
family or friends for help in an
emergency.
4
Contents
Unpack 6
Make sure you have each item
Get started 6
First steps to operating your phone
Assemble and charge the phone ..................... 6
Power on or off.............................................. 7
Phone layout ................................................. 8
Keys and icons .............................................. 9
Access menu functions .................................. 12
Enter text .................................................... 13
Customise your phone................................... 14
Step outside the phone 16
Begin with call functions, camera, music player, web
browser, and other special features
Make or answer calls ..................................... 16
Use the camera ............................................ 18
Play music................................................... 19
Browse the web ........................................... 21
Use Phonebook ............................................ 22
Send messages ............................................ 23
View messages ............................................ 24
Use Bluetooth .............................................. 25
Menu functions 28
All menu options listed
Health and safety information 39
5
1 Call log
1 Recent contacts
2 Missed calls
3 Dialled calls
4 Received calls
5 Sent messages
6 Received messages
7 Delete all
8 Call manager
2 Phonebook
1 Contact list
2 Create contact
3 Group
4 Speed dial
5 My namecard
6 Own numbers
7 Management
8 Service number
1
3 Music player
4 Browser
1 Home
2 Enter URL
3 Bookmarks
4 Browser
4 Saved pages
5 History
6 Clear cache
7 Browser settings
8 Streaming settings
2
5 Messages
1 Create message
2 My messages
3 Templates
4 Delete all
5 Settings
6 SOS Messages
7 Memory status
6 My files
1 Images
2 Videos
3 Music
4 Sounds
5 Other files
6 Memory status
7 Calendar
8 Camera
9 Yahoo! ready/Google/
Bluetooth/Java world
‡
* Applications
‡‡
1 Smart search
2 Voice recorder
3 Image editor
4 Image stamp
5 Bluetooth
‡
6 Java world
‡
7 World clock
8 Calculator
9 Converter
10 Timer
11 Stopwatch
12 Memo
13 SIM application toolkit
1
0 Alarms
# Settings
1 Time and date
2 Phone settings
3 Display settings
4 Sound settings
# Settings
5 Light settings
6 Setup wizard
7 Network services
8 Security
9 Connection settings
10 Memory status
11 Reset settings
1. Available only if supported
by your SIM card.
2. Available only if supported
by your service provider.
‡ If the Yahoo! ready and
Google services are not
available, Bluetooth or
Java world will display in
menu 9 instead of
appearing in Applications.
‡‡If the Yahoo! ready and
Google services are not
available, the order of
submenus will change.
Overview of menu functions
To access Menu mode, press <
Menu
> in Idle mode.
6
Unpack
Make sure you have each item
• Phone
•Travel adapter
•Battery
•User’s Guide
You can obtain various accessories from your
local Samsung dealer.
Get started
First steps to operating your phone
Assemble and charge the phone
The items supplied with your phone and the
accessories available at your Samsung dealer
may vary, depending on your country or service
provider.
To A C
ower
7
Removing the battery cover
Power on or off
Switch on
1. Press and hold [ ].
2. If necessary, enter the
PIN and press <
OK
>.
3. When you use the
phone for the first time
or reset it, the setup
wizard starts.
Customise your phone
according to your
preferences.
Switch off
Press and hold [ ].
Get started
8
Phone layout
Front view
Rear view
Mouthpiece
Navigation keys
(Up/Down/Left/
Right)
Power/Menu
exit key
Right soft key
Delete/Cancel key
Earpiece
Special
function keys
Display
Left soft key
Volume keys
Dial key
Alphanumeric
keys
Web access/
Confirm key
You can lock the keypad to prevent any
unwanted phone operations from accidentally
pressing any of the keys. In Idle mode, press
and hold [ ] and then <
Yes
>. To unlock the
keypad, press <
Unlock
> and then [ ].
Camera key
Multi-function
jack
Camera lens
9
Keys and icons
Keys
Perform the function indicated on the
bottom line of the display.
In Idle mode, access the following
menus:
• Up: My menu mode
• Down/Left/Right: your favourite
menus
In Menu mode, scroll through menu
options.
In Idle mode, launch the web
browser.
In Menu mode, select the highlighted
menu option or confirm input.
Make or answer a call.
In Idle mode, retrieve the numbers
recently dialled, missed, or received.
Delete characters from the display or
items in an application.
Press and hold to switch the phone
on or off.
End a call.
In Menu mode, cancel input and
return the phone to Idle mode.
Enter numbers, letters, and some
special characters.
In Idle mode, press and hold [
1
] to
access your voicemail server. Press
and hold [
0
] to enter an international
call prefix.
Get started
10
Icons
The following icons may appear on the top line
of the screen to indicate your phone’s status.
Depending on your country or service provider,
the icons shown on the display may vary.
Enter special characters or perform
special functions.
In Idle mode, press and hold [ ] to
activate or deactivate the Silent
mode. Press and hold [ ] to enter a
pause between numbers.
Adjust the phone volume.
In Idle mode, press and hold to turn
on the camera.
In Camera mode, take a photo or
record a video.
Signal strength
GPRS (2.5G) network
Connecting to GPRS (2.5G)
network
Transferring data in GPRS (2.5G)
network
EDGE network
Connecting to EDGE network
Transferring data in EDGE network
11
Call in progress
Out of your service area or Offline
mode
SOS message feature active
Alarm set
Browsing Internet
Roaming network
Call diverting active
Home Zone
Office Zone
Keys locked
Bluetooth hands-free car kit or
headset connected
Bluetooth active
Synchronised with PC
Ringer type:
•: Melody
•: Vibration
• : Vibration then melody
• : Vibration and melody
• : Increasing melody
Silent mode (Mute)
Silent mode (Vibration)
Mute mode, during a call
Get started
12
Access menu functions
New message:
• : Text message or
Multimedia message
•: Email
•: Voicemail
Battery power level
Select an
option
1. Press a desired soft key.
2. Press the Navigation keys
to move to the next or
previous option.
3. Press <
Select
>, <
OK
>, or
[] to confirm the
function displayed or option
highlighted.
4. Press <
Back
> to move up
one level.
Press [ ] to return to Idle
mode.
Use menu
numbers
Press the number key
corresponding to the option
you want.
13
Enter text
Change the
text input
mode
• Press and hold [ ] to
switch between T9 mode
( ) and ABC mode
().
• Press [ ] to change case or
switch to Number mode
().
• Press and hold [ ] to
switch to Symbol mode.
ABC mode
To enter a word :
Press the appropriate key until
the character you want
appears on the display.
T9 mode
To enter a word :
1. Press [
2
] to [
9
]
to start
entering a word.
2. Enter the whole word
before editing or deleting
characters.
3. When the word displays
correctly, press [ ] to
insert a space.
Otherwise, select a word
from the alternative word
choices.
Number
mode
Press the keys corresponding
to the digits you want.
Symbol mode
Press the corresponding
number key to select a
symbol.
Get started
14
Customise your phone
Other
operations
•Press [
1
] to enter
punctuation marks or
special characters.
• Press [ ] to insert a space.
• Press the Navigation keys
to move the cursor.
•Press [
C
] to delete
characters one by one.
•Press and hold [
C
] to clear
the entire display.
1. In Idle mode, press
<
Menu
> and select
Settings
→
Phone
settings
→
Language
.
2. Select a language.
1. In Idle mode, press
<
Menu
> and select
Settings
→
Sound
settings
→
Incoming call
→
Ring tone
.
2. Select a ringtone category.
3. Select a ringtone.
4. Press <
Save
>.
Display
language
Call ringer
melody
15
In Idle mode, press [Volume]
to adjust the key tone volume.
1. In Idle mode, press
<
Menu
> and select
Settings
→
Display
settings
→
Wallpaper
.
2. Press [Left] or [Right] to
select
Normal
.
3. Select
Main display
.
4. Select an image category.
5. Select an image or a video
clip.
6. Press <
Select
>.
7. Press <
Save
>.
Key tone
volume
Idle mode
wallpaper
1. In Idle mode, press
<
Menu
> and select
Settings
→
Display
settings
→
Menu style
→
Skin
.
2. Select a colour pattern.
1. In Idle mode, press
<
Menu
> and select
Settings
→
Phone
settings
→
Shortcuts
.
2. Select a key.
3. Select a menu to be
assigned to the key.
Menu mode
skin colour
Menu
shortcuts
16
Step outside the phone
Begin with call functions, camera, music player,
web browser, and other special features
Make or answer calls
You can switch the phone to
Silent mode to avoid disturbing
other people. In Idle mode,
press and hold [ ].
1. In Idle mode, press
<
Menu
> and select
Settings
→
Security
→
Phone lock
.
2. Select
Enable
.
3. Enter a new 4- to 8-digit
password and press <
OK
>.
4. Enter the new password
again and press <
OK
>.
Silent mode
Phone lock
1. In Idle mode, enter an area
code and phone number.
2. Press [ ].
Press [Volume] to adjust
the volume.
3. Press [ ] to end the call.
1. When the phone rings,
press [ ].
2. Press [ ] to end the call.
Make a call
Answer a call
17
During a call, press [ ]
and then <
Yes
> to activate
the speaker.
Press [ ] again to switch
back to the earpiece.
1. During a call, call the
second participant.
The first call is put on hold.
2. Press <
Options
> and
select
Join
.
3. Repeat step 1 and 2 to add
more participants.
Use the
speakerphone
feature
Make a
multi-party
call
4. During a multi-party call:
•Press <
Options
> and
select
Select one
→
Private
to have a
private conversation
with one participant.
•Press <
Options
> and
Select one
→
Remove
to drop one participant.
5. Press [ ] to end the
multi-party call.
Step outside the phone
18
Use the camera
1. In Idle mode, press and
hold [Camera] to turn on
the camera.
2. Aim the lens at the subject
and make any desired
adjustments.
3. Press [ ] or [Camera]
to take a photo. The photo
is saved automatically.
4.
Pres
s <
Preview
> to take
another photo.
1. In Idle mode, press
<
Menu
> and select
My files
→
Images
→
My
photos
.
2. Select the photo you want.
Take a photo
View a photo
1. In Idle mode, press and
hold [Camera] to turn on
the camera.
2. Press [
1
] to switch to
Record mode.
3. Press [ ] or [Camera]
to start recording.
4. Press [ ], < >, or
[Camera] to stop recording.
The video is saved
automatically.
5. Press <
Preview
> to record
another video.
Record a
video
19
Play music
1. In Idle mode, press
<
Menu
> and select
My
files
→
Videos
→
My
video
clips
.
2. Select the video you want.
Use these methods:
• Download from the wireless
web.
• Download from a computer
using the optional Samsung
PC Studio. See Samsung PC
Studio User’s Guide.
View a video
Copy music
files to the
phone
• Receive via Bluetooth.
• Synchronise music files with
Windows Media Player. See
the next section.
You can copy music files to
your phone by synchronising
with Windows Media Player 11.
1. In Idle mode, press
<
Menu
> and select
Settings
→
Phone
settings
→
USB settings
→
Media player
.
2. Connect your phone and PC
with an optional PC data
cable.
Synchronise
with Windows
Media Player
Step outside the phone
20
3. Select
Sync digital media
files to this device
when a
pop-up window appears on
your PC.
4. Enter the name of your
phone and click
Finish
.
5. Select and drag the music
files you want to the sync
list.
6. Click
Start Sync
.
7. When synchronisation is
finished, disconnect the
phone from the PC.
1. In Idle mode, press
<
Menu
> and select
Music
player
.
2. Select a play list
→
a music
file.
3. During playback, use the
following keys:
• : pause or resume
playback.
• Left: restart playback.
Press to return to the
previous file within 3
seconds after playback
has started. Press and
hold to move backward
in a file.
Play music
files
21
Browse the web
• Right: skip to the next
file. Press and hold to
move forward in a file.
• Volume: adjust the
volume.
4. Press [Down] to stop
playback.
1. From the music player
screen, select
Playlists
.
2. Press <
Options
> and
select
Create playlist
.
3. Enter the name of the
playlist and press <
Save
>.
4. Select the added playlist.
Create your
playlist
5. Press <
Options
> and
select
Add
→
a source.
6. Select a playlist, or select
files you want and press
<
Add
>.
7. Press [ ] to play music.
In Idle mode, press [ ].
The homepage of your service
provider opens.
Launch the
web browser
Step outside the phone
22
Use Phonebook
• To scroll through browser
items, press [Up] or
[Down].
• To select an item, press
[].
• To return to the previous
page, press <
Back
>.
• To access browser options,
press <
Options
>.
1. In Idle mode, enter a phone
number and press
<
Options
>.
2. Select
Save contact
→
a
memory location
→
New
.
Navigate
the web
Add a contact
3. For
Phone
, select a number
type.
4. Specify contact information.
5. Press <
Save
> to save the
contact.
1. In Idle mode, press
<
Contacts
>.
2. Enter the first few letters of
the name you want.
3. Select a contact.
4. Scroll to a number and
press [ ] to dial, or press
[ ] to edit contact
information.
Find a
contact
23
Send messages
1. In Idle mode, press
<
Menu
> and select
Messages
→
Create
message
→
Message
.
2. Enter destination numbers
and press [Down].
3. Enter the message text.
4. Press <
Options
> and select
Send
to send the message.
1. In Idle mode, press
<
Menu
> and select
Messages
→
Create
message
→
Message
.
Send a text
message
Send a
multimedia
message
2. Enter destination numbers
or addresses.
3. Press <
Options
> and
select
Input field
.
4. Press [ ] to select the
input field items and press
<
Save
>.
5. Press <
Yes
>.
6. Fill in the fields.
For attaching files, press
<
Options
> and select
Add
attachment
.
7. Press <
Options
> and
select
Send
to send the
message.
Step outside the phone
24
View messages
1. In Idle mode, press
<
Menu
> and select
Messages
→
Create
message
→
Email
.
2. Enter email addresses and
press [Down].
3. Enter the email subject.
4. Press <
Options
> and
select
Input field
.
5. Press [ ] to select the
input field items and press
<
Save
>.
6. Fill in the fields.
For attaching files, press
<
Options
> and select
Add
item
or
Create item
→
an
item.
Send an email
7. Press <
Options
> and
select
Send
to send the
email.
1. In Idle mode, press
<
Menu
> and select
Messages
→
My
messages
→
Inbox
.
2. Select a text message.
1. In Idle mode, press
<
Menu
> and select
Messages
→
My
messages
→
Inbox
.
2. Select a multimedia
message.
View a text
message
View a
multimedia
message
25
Use Bluetooth
Your phone is equipped with Bluetooth
technology, enabling you to connect the phone
wirelessly to other Bluetooth devices and
exchange data with them, talk hands-free, or
control the phone remotely.
1. In Idle mode, press
<
Menu
> and select
Messages
→
My
messages
→
Email inbox
.
2. Select an account.
3. Press <
Options
> and
select
Check for new
email
.
4. Select an email or a header.
5. If you selected a header,
press <
Options
> and
select
Retrieve
to view the
body of the email.
View an
email
1. In Idle mode, press
<
Menu
> and select
Applications
‡
→
Bluetooth
→
Activation
→
On
.
‡
Bluetooth
is available under
Applications
if the Yahoo!
ready or Google service is
available.
2. Select
My phone’s
visibility
→
On
to allow
other devices to locate your
phone.
Turn on
Bluetooth
Step outside the phone
26
1. In Idle mode, press
<
Menu
> and select
Applications
‡
→
Bluetooth
→
My devices
→
Search for new devices
.
‡
Bluetooth
is available under
Applications
if the Yahoo!
ready or Google service is
available.
2. Select a device.
3. Enter a Bluetooth PIN or the
other device’s Bluetooth
PIN, if it has one, and press
<
OK
>.
When the owner of the
other device enters the
same code, pairing is
complete.
Search for
and pair with
a Bluetooth
device
1. Access an application, such
as
Phonebook
,
My files
,
Calendar
, or
Memo
.
2. Select an item.
3. Press <
Options
> and
select
Send via
→
Bluetooth
.
4. For sending a contact,
select which data you want
to send.
5. Search for and select a
device.
6. If necessary, enter the
Bluetooth PIN and press
<
OK
>.
Send data
27
1. When a device attempts to
access your phone, press
<
Yes
> to permit the
connection.
2. If necessary, press <
Yes
>
to confirm that you are
willing to receive.
Receive data
28
Menu functions
All menu options listed
This section provides brief explanations of
menu functions on your phone.
Call log
Phonebook
Menu Description
Recent contacts,
Missed calls,
Dialled calls,
Received calls
Check the most recent calls
dialled, received, or
missed.
Sent messages,
Received
messages
View the record of the most
recent messages sent or
received.
Delete all Delete all of the records in
each call type.
Call manager
→
Call time
Check the time record for
calls made and received.
Call manager
→
Call cost
Check the cost of your
calls, if supported by your
SIM card.
Call manager
→
Reject list
Make a list of the phone
numbers of callers to
reject.
Menu Description
Contact list Search for contact
information stored in
Phonebook.
Menu Description
29
Music player
Access and listen to all music files sorted by
criteria. You can also make your own music
playlists.
Create contact Add a new contact to
Phonebook.
Group Organise your contacts in
caller groups.
Speed dial Assign a speed dial number
for your most frequently
dialled numbers.
My namecard Create a name card and
send it to other people.
Own numbers Check your phone
numbers, or assign a name
to each of the numbers.
Menu Description
Management Manage contacts in
Phonebook or change the
default settings for
Phonebook.
Service number View the SDN (Service
Dialling Number) list
assigned by your service
provider, if supported by
your SIM card.
Menu Description
Menu functions
30
Browser
Messages
Menu Description
Home Connect your phone to the
network and load the
homepage of the wireless
web service provider.
Enter URL Enter a URL address and
access the associated web
page.
Bookmarks Save URL addresses in
order to quickly access web
pages.
Saved pages Access the list of pages you
have saved while online.
History Access the list of pages you
have accessed recently.
Clear cache Clear the cache, which is a
temporary memory site
that stores recently
accessed web pages.
Browser settings Select a connection profile
to be used for accessing
the wireless web.
Streaming
settings
Select a connection profile
to be used for accessing a
streaming server.
Menu Description
Create message Create and send text,
multimedia, or email
messages.
Menu Description
31
My files
Calendar
Keep track of your schedule.
My messages Access messages that you
have received, sent, or that
have failed during sending.
Templates Make and use templates of
frequently used messages
or passages.
Delete all Delete messages in each
message folder all at once.
Settings Set up various options for
using the messaging
services.
SOS Messages Specify options for sending
and receiving an SOS
message. You can send an
SOS message by pressing
[Volume] 4 times in Idle
mode when the phone is
locked.
Menu Description
Memory status Check the amount of
memory currently in use in
each message folder.
Menu Description
Images, Videos,
Music, Sounds,
Other files
Access media files and
other files stored in the
phone’s memory.
Memory status Check memory information
for media items.
Menu Description
Menu functions
32
Camera
Use the camera embedded in your phone to
take photos and record videos.
Yahoo! ready/Google/Bluetooth/
Java world
Depending on your country or service provider,
you may have one of these four menus here:
•
Yahoo! ready
: Launch the Yahoo search
engine to find information, news, images, or
local services from around the web. You can
also use the messenger service.
•
Google
: Launch the Google search engine to
find information, news, images, or local
services from around the web.
•
Bluetooth
: Connect the phone wirelessly to
other Bluetooth devices.
•
Java world
: Access Java games and
applications.
Applications
Menu Description
Smart search Quickly search your phone
for any stored information
by category. You can
access all the results
directly from the search
screen.
Voice recorder Record voice memos and
any other sounds.
Image editor Edit your photos using
various editing tools.
Image stamp Make an outline stamp of a
photo and merge it with
another photo.
33
‡ If the Yahoo! ready and Google services are not available
depending on your country or service provider,
Bluetooth
or
Java world
will move to menu 9.
Bluetooth
‡
Connect the phone
wirelessly to other
Bluetooth devices.
Java world
‡
Access Java games and
applications.
World clock Set your local time zone
and find out the current
time in another part of the
world.
Calculator Perform arithmetic
functions.
Converter Do conversions, such as
length and temperature.
Timer Set a period of time for the
phone to count down.
Menu Description
Stopwatch Measure elapsed time.
Memo Make memos for things
that are important and
manage them.
SIM application
toolkit
Use a variety of additional
services offered by your
service provider. This menu
is available only if
supported by your SIM
card.
Menu Description
Menu functions
34
Alarms
Set a wake-up call to wake you up in the
morning or an alarm to alert you to an event at
a specific time.
Settings
Menu Description
Time and date Change the time and date
displayed on your phone.
Phone settings
→
Language
Select a language for the
display text.
Phone settings
→
Greeting
message
Enter the greeting that is
displayed briefly when the
phone is switched on.
Phone settings
→
Shortcuts
Use the Navigation keys as
shortcuts to access specific
menus directly from Idle
mode. [Up] is fixed as a
shortcut to My menu mode.
Phone settings
→
My menu
Set up a menu of your own
using your favourite menu
items, which can be easily
accessed by pressing [Up]
in Idle mode.
Phone settings
→
Auto keypad
lock
Set the phone to lock the
keypad automatically when
the display turns off.
Phone settings
→
Volume key
Set how the phone reacts if
you press and hold
[Volume] when a call
comes in.
Menu Description
35
Phone settings
→
Extra settings
Change additional settings
for using the phone.
Phone settings
→
Offline mode
Switch the phone to Offline
mode, in which the phone
functions requiring network
connection are deactivated.
Phone settings
→
USB settings
Select a USB mode that will
be used when you connect
your phone to a PC via USB
interface.
Display settings
→
Wallpaper
Set up the idle screen on
the main display.
Display settings
→
Menu style
Select a display style for
the main menu screen or
select a skin colour pattern
for Menu mode.
Menu Description
Display settings
→
Text display
Change the display settings
for the text.
Display settings
→
Brightness
Adjust the brightness of
the display for varying
lighting conditions.
Display settings
→
Dialling
display
Customise the settings for
the display while dialling.
Display settings
→
Clock display
Select a clock type to be
displayed on the idle
screen.
Display settings
→
Show caller
information
Set the phone to display
missed call notifications
with the most recently
missed caller’s information.
Menu Description
Menu functions
36
Display settings
→
TV-out
settings
Select a video system for
your TV to view the phone
display on the TV screen.
Sound settings
→
Incoming call
Change the sound settings
for incoming calls.
Sound settings
→
Keypad tone
Select the tone that the
phone sounds when you
press a key.
Sound settings
→
Keypad
vibration
Set the phone to vibrate
when you press the keys.
Sound settings
→
Message tone
Change the sound settings
for incoming messages
individually according to
message type.
Menu Description
Sound settings
→
Power on/off
tone
Set the phone to sound
when it is switched on or
off.
Sound settings
→
Silent mode
Set how the phone acts to
alert you to a specific event
while in Silent mode.
Sound settings
→
Extra tones
Customise additional tones
for the phone.
Light settings
→
Backlight time
Select the length of time
the backlight or display
stays on when the phone is
not used.
Light settings
→
Sunlight mode
Select whether the phone
changes the tone of its
display colour to improve
visibility.
Menu Description
37
Light settings
→
Keypad light
Set how the phone controls
the use of the keypad light.
Setup wizard Quickly customise basic
settings of your phone.
Select the option you want
for each setting by
following the onscreen
instructions.
Network
services
→
Call
diverting
Set the phone to reroute
incoming calls to a phone
number that you specify.
Network
services
→
Call
barring
Set the phone to restrict
calls.
Menu Description
Network
services
→
Call
waiting
Set the phone to inform
you when someone is
calling you while on
another call.
Network
services
→
Network
selection
Select the network to be
used while roaming outside
of your home area, or let
the network be chosen
automatically.
Network
services
→
Caller
ID
Set the phone to hide your
phone number from the
person you are calling.
Network
services
→
Voice
mail server
Store the number of the
voicemail server and
access your voicemails.
Menu Description
Menu functions
38
Network
services
→
Closed user
group
Set calls to be restricted to
a selected user group.
Security
→
PIN
check
Activate your PIN to
protect your SIM card
against unauthorised use.
Security
→
Change PIN
code
Change the PIN.
Security
→
Phone lock
Activate your phone
password to protect your
phone against
unauthorised use.
Security
→
Change
password
Change the phone
password.
Menu Description
Security
→
Privacy
Lock access to messages,
files, or all menu functions
on the phone, except for
call functions.
Security
→
SIM
lock
Set the phone to work only
with the current SIM card
by assigning a SIM lock
password.
Security
→
Fixed
dialling mode
Set the phone to restrict
calls to a limited set of
phone numbers, if
supported by your SIM
card.
Security
→
Change PIN2
code
Change your current PIN2,
if supported by your SIM
card.
Menu Description
39
Health and safety information
Exposure to Radio Frequency (RF)
Signals
Certification Information (SAR)
Your wireless phone is a radio transmitter
and receiver. It is designed and
manufactured not to exceed the exposure
limits for radio frequency (RF) energy set by
the Federal Communications Commission
(FCC) of the U.S. government. These FCC
exposure limits are derived from the
recommendations of two expert
organizations, the National Counsel on
Radiation Protection and Measurement
(NCRP) and the Institute of Electrical and
Electronics Engineers (IEEE). In both cases,
the recommendations were developed by
Security
→
Mobile tracker
Set the phone to send the
preset tracking message to
your family or friends when
someone tries to use your
phone with another SIM
card. This feature may be
unavailable due to certain
features supported by your
service provider.
Connection
settings
Create and customise the
profiles containing the
settings for connecting
your phone to the network.
Memory status Check memory information
for each items in the
phone’s memory.
Reset settings Reset the phone’s settings
you have changed.
Menu Description
Health and safety information
40
scientific and engineering experts drawn
from industry, government, and academia
after extensive reviews of the scientific
literature related to the biological effects of
RF energy.
The exposure limit set by the FCC for
wireless mobile phones employs a unit of
measurement known as the Specific
Absorption Rate (SAR). The SAR is a
measure of the rate of absorption of RF
energy by the human body expressed in
units of watts per kilogram (W/kg). The FCC
requires wireless phones to comply with a
safety limit of 1.6 watts per kilogram (1.6
W/kg). The FCC exposure limit incorporates
a substantial margin of safety to give
additional protection to the public and to
account for any variations in measurements.
SAR tests are conducted using standard
operating positions accepted by the FCC with
the phone transmitting at its highest
certified power level in all tested frequency
bands. Although the SAR is determined at
the highest certified power level, the actual
SAR level of the phone while operating can
be well below the maximum value. This is
because the phone is designed to operate at
multiple power levels so as to use only the
power required to reach the network. In
general, the closer you are to a wireless
base station antenna, the lower the power
output.
Before a new model phone is available for
sale to the public, it must be tested and
certified to the FCC that it does not exceed
41
the exposure limit established by the FCC.
Tests for each model phone are performed in
positions and locations (e.g. at the ear and
worn on the body) as required by the FCC.
The highest SAR values for this model phone
as reported to the FCC are:
GSM 1900 Mode(Part 24)
• Head:0.897 W/Kg.
• Body-worn: 0.345 W/Kg.
For body worn operation, this model phone
has been tested and meets the FCC RF
exposure guidelines whenused with a
Samsung accessory designated for this
product or when used with an accessory that
contains no metal and that positions the
handset a minimum of 1.5 cm from the
body.
Non-compliance with the above restrictions
may result in violation of FCC RF exposure
guidelines. SAR information on this and
other model phones can be viewed on-line at
www.fcc.gov/oet/fccid. This site uses the
phone FCC ID number, A3LSGHL170.
Sometimes it may be necessary to remove
the battery pack to find the number. Once
you have the FCC ID number for a particular
phone, follow the instructions on the website
and it should provide values for typical or
maximum SAR for a particular phone.
Additional product specific SAR information
can also be obtained at www.fcc.gov/cgb/
sar.
Health and safety information
42
Consumer Information on Wireless
Phones
The U.S. Food and Drug Administration
(FDA) has published a series of Questions
and Answers for consumers relating to radio
frequency (RF) exposure from wireless
phones. The FDA publication includes the
following information:
What kinds of phones are the subject
of this update?
The term wireless phone refers here to
hand-held wireless phones with built-in
antennas, often called “cell,” “mobile,” or
“PCS” phones. These types of wireless
phones can expose the user to measurable
radio frequency energy (RF) because of the
short distance between the phone and the
user's head. These RF exposures are limited
by Federal Communications Commission
safety guidelines that were developed with
the advice of FDA and other federal health
and safety agencies. When the phone is
located at greater distances from the user,
the exposure to RF is drastically lower
because a person's RF exposure decreases
rapidly with increasing distance from the
source. The so-called “cordless phones,”
which have a base unit connected to the
telephone wiring in a house, typically
operate at far lower power levels, and thus
produce RF exposures well within the FCC's
compliance limits.
43
Do wireless phones pose a health
hazard?
The available scientific evidence does not
show that any health problems are
associated with using wireless phones. There
is no proof, however, that wireless phones
are absolutely safe. Wireless phones emit
low levels of radio frequency energy (RF) in
the microwave range while being used. They
also emit very low levels of RF when in the
stand-by mode. Whereas high levels of RF
can produce health effects (by heating
tissue), exposure to low level RF that does
not produce heating effects causes no
known adverse health effects. Many studies
of low level RF exposures have not found
any biological effects. Some studies have
suggested that some biological effects may
occur, but such findings have not been
confirmed by additional research. In some
cases, other researchers have had difficulty
in reproducing those studies, or in
determining the reasons for inconsistent
results.
What is FDA's role concerning the
safety of wireless phones?
Under the law, FDA does not review the
safety of radiation-emitting consumer
products such as wireless phones before
they can be sold, as it does with new drugs
or medical devices. However, the agency has
authority to take action if wireless phones
are shown to emit radio frequency energy
(RF) at a level that is hazardous to the user.
In such a case, FDA could require the
manufacturers of wireless phones to notify
Health and safety information
44
users of the health hazard and to repair,
replace or recall the phones so that the
hazard no longer exists.
Although the existing scientific data do not
justify FDA regulatory actions, FDA has
urged the wireless phone industry to take a
number of steps, including the following:
• “Support needed research into possible
biological effects of RF of the type
emitted by wireless phones;
• “Design wireless phones in a way that
minimizes any RF exposure to the user
that is not necessary for device function;
and
• “Cooperate in providing users of wireless
phones with the best possible
information on possible effects of
wireless phone use on human health.
FDA belongs to an interagency working
group of the federal agencies that have
responsibility for different aspects of RF
safety to ensure coordinated efforts at the
federal level. The following agencies belong
to this working group:
•“National Institute for Occupational
Safety and Health
• “Environmental Protection Agency
• “Federal Communications Commission
• “Occupational Safety and Health
Administration
• “National Telecommunications and
Information Administration
The National Institutes of Health participates
in some interagency working group
activities, as well.
45
FDA shares regulatory responsibilities for
wireless phones with the Federal
Communications Commission (FCC). All
phones that are sold in the United States
must comply with FCC safety guidelines that
limit RF exposure. FCC relies on FDA and
other health agencies for safety questions
about wireless phones.
FCC also regulates the base stations that the
wireless phone networks rely upon. While
these base stations operate at higher power
than do the wireless phones themselves, the
RF exposures that people get from these
base stations are typically thousands of
times lower than those they can get from
wireless phones. Base stations are thus not
the primary subject of the safety questions
discussed in this document.
What are the results of the research
done already?
The research done thus far has produced
conflicting results, and many studies have
suffered from flaws in their research
methods. Animal experiments investigating
the effects of radio frequency energy (RF)
exposures characteristic of wireless phones
have yielded conflicting results that often
cannot be repeated in other laboratories. A
few animal studies, however, have
suggested that low levels of RF could
accelerate the development of cancer in
laboratory animals. However, many of the
studies that showed increased tumor
development used animals that had been
genetically engineered or treated with
cancer-causing chemicals so as to be pre-
Health and safety information
46
disposed to develop cancer in absence of RF
exposure. Other studies exposed the
animals to RF for up to 22 hours per day.
These conditions are not similar to the
conditions under which people use wireless
phones, so we don't know with certainty
what the results of such studies mean for
human health.
Three large epidemiology studies have been
published since December 2000. Between
them, the studies investigated any possible
association between the use of wireless
phones and primary brain cancer, glioma,
meningioma, or acoustic neuroma, tumors
of the brain or salivary gland, leukemia, or
other cancers. None of the studies
demonstrated the existence of any harmful
health effects from wireless phones RF
exposures. However, none of the studies can
answer questions about long-term
exposures, since the average period of
phone use in these studies was around three
years.
What research is needed to decide
whether RF exposure from wireless
phones poses a health risk?
A combination of laboratory studies and
epidemiological studies of people actually
using wireless phones would provide some
of the data that are needed. Lifetime animal
exposure studies could be completed in a
few years. However, very large numbers of
animals would be needed to provide reliable
proof of a cancer promoting effect if one
exists. Epidemiological studies can provide
data that is directly applicable to human
47
populations, but ten or more years' follow-
up may be needed to provide answers about
some health effects, such as cancer. This is
because the interval between the time of
exposure to a cancer-causing agent and the
time tumors develop - if they do - may be
many, many years. The interpretation of
epidemiological studies is hampered by
difficulties in measuring actual RF exposure
during day-to-day use of wireless phones.
Many factors affect this measurement, such
as the angle at which the phone is held, or
which model of phone is used.
What is FDA doing to find out more
about the possible health effects of
wireless phone RF?
FDA is working with the U.S. National
Toxicology Program and with groups of
investigators around the world to ensure
that high priority animal studies are
conducted to address important questions
about the effects of exposure to radio
frequency energy (RF).
FDA has been a leading participant in the
World Health Organization international
Electromagnetic Fields (EMF) Project since
its inception in 1996. An influential result of
this work has been the development of a
detailed agenda of research needs that has
driven the establishment of new research
programs around the world. The Project has
also helped develop a series of public
information documents on EMF issues.
FDA and Cellular Telecommunications &
Internet Association (CTIA) have a formal
Cooperative Research and Development
Health and safety information
48
Agreement (CRADA) to do research on
wireless phone safety. FDA provides the
scientific oversight, obtaining input from
experts in government, industry, and
academic organizations. CTIA-funded
research is conducted through contracts to
independent investigators. The initial
research will include both laboratory studies
and studies of wireless phone users. The
CRADA will also include a broad assessment
of additional research needs in the context
of the latest research developments around
the world.
What steps can I take to reduce my
exposure to radio frequency energy
from my wireless phone?
If there is a risk from these products - and
at this point we do not know that there is - it
is probably very small. But if you are
concerned about avoiding even potential
risks, you can take a few simple steps to
minimize your exposure to radio frequency
energy (RF). Since time is a key factor in
how much exposure a person receives,
reducing the amount of time spent using a
wireless phone will reduce RF exposure.
• “If you must conduct extended
conversations by wireless phone every
day, you could place more distance
between your body and the source of the
RF, since the exposure level drops off
dramatically with distance. For example,
you could use a headset and carry the
wireless phone away from your body or
use a wireless phone connected to a
remote antenna.
49
Again, the scientific data do not demonstrate
that wireless phones are harmful. But if you
are concerned about the RF exposure from
these products, you can use measures like
those described above to reduce your RF
exposure from wireless phone use.
What about children using wireless
phones?
The scientific evidence does not show a
danger to users of wireless phones,
including children and teenagers. If you
want to take steps to lower exposure to
radio frequency energy (RF), the measures
described above would apply to children and
teenagers using wireless phones. Reducing
the time of wireless phone use and
increasing the distance between the user
and the RF source will reduce RF exposure.
Some groups sponsored by other national
governments have advised that children be
discouraged from using wireless phones at
all. For example, the government in the
United Kingdom distributed leaflets
containing such a recommendation in
December 2000. They noted that no
evidence exists that using a wireless phone
causes brain tumors or other ill effects. Their
recommendation to limit wireless phone use
by children was strictly precautionary; it was
not based on scientific evidence that any
health hazard exists.
Health and safety information
50
Do hands-free kits for wireless phones
reduce risks from exposure to RF
emissions?
Since there are no known risks from
exposure to RF emissions from wireless
phones, there is no reason to believe that
hands-free kits reduce risks. Hands-free kits
can be used with wireless phones for
convenience and comfort. These systems
reduce the absorption of RF energy in the
head because the phone, which is the source
of the RF emissions, will not be placed
against the head. On the other hand, if the
phone is mounted against the waist or other
part of the body during use, then that part
of the body will absorb more RF energy.
Wireless phones marketed in the U.S. are
required to meet safety requirements
regardless of whether they are used against
the head or against the body. Either
configuration should result in compliance
with the safety limit.
Do wireless phone accessories that
claim to shield the head from RF
radiation work?
Since there are no known risks from
exposure to RF emissions from wireless
phones, there is no reason to believe that
accessories that claim to shield the head
from those emissions reduce risks. Some
products that claim to shield the user from
RF absorption use special phone cases, while
others involve nothing more than a metallic
accessory attached to the phone. Studies
have shown that these products generally do
not work as advertised. Unlike “hand-free”
51
kits, these so-called “shields” may interfere
with proper operation of the phone. The
phone may be forced to boost its power to
compensate, leading to an increase in RF
absorption. In February 2002, the Federal
trade Commission (FTC) charged two
companies that sold devices that claimed to
protect wireless phone users from radiation
with making false and unsubstantiated
claims. According to FTC, these defendants
lacked a reasonable basis to substantiate
their claim.
What about wireless phone
interference with medical equipment?
Radio frequency energy (RF) from wireless
phones can interact with some electronic
devices. For this reason, FDA helped develop
a detailed test method to measure
electromagnetic interference (EMI) of
implanted cardiac pacemakers and
defibrillators from wireless telephones. This
test method is now part of a standard
sponsored by the Association for the
Advancement of Medical instrumentation
(AAMI). The final draft, a joint effort by FDA,
medical device manufacturers, and many
other groups, was completed in late 2000.
This standard will allow manufacturers to
ensure that cardiac pacemakers and
defibrillators are safe from wireless phone
Health and safety information
52
EMI. FDA has tested wireless phones and
helped develop a voluntary standard
sponsored by the Institute of Electrical and
Electronic Engineers (IEEE). This standard
specifies test methods and performance
requirements for hearing aids and wireless
phones so that no interference occurs when
a person uses a compatible phone and a
compatible hearing aid at the same time.
This standard was approved by the IEEE in
2000.
FDA continues to monitor the use of wireless
phones for possible interactions with other
medical devices. Should harmful
interference be found to occur, FDA will
conduct testing to assess the interference
and work to resolve the problem.
Additional information on the safety of RF
exposures from various sources can be
obtained from the following organizations:
• FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
• Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
• Occupational Safety and Health
Administration's (OSHA):
http://www.osha.gov/SLTC/
radiofrequencyradiation/index.html
• National institute for Occupational Safety
and Health (NIOSH):
http://www.cdc.gov/niosh/emfpg.html
• World health Organization (WHO):
http://www.who.int/peh-emf/
53
• International Commission on Non-
Ionizing Radiation Protection:
http://www.icnirp.de
• National Radiation Protection Board
(UK):
http://www.nrpb.org.uk
• Updated 4/3/2002: US food and Drug
Administration
http://www.fda.gov/cellphones
Road Safety
Your wireless phone gives you the powerful
ability to communicate by voice, almost
anywhere, anytime. But an important
responsibility accompanies the benefits of
wireless phones, one that every user must
uphold.
When driving a car, driving is your first
responsibility. When using your wireless
phone behind the wheel of a car, practice
good common sense and remember the
following tips:
1. Get to know your wireless phone and its
features, such as speed dial and redial. If
available, these features help you to
place your call without taking your
attention off the road.
2. When available, use a hands-free device.
If possible, add an additional layer of
convenience and safety to your wireless
phone with one of the many hands free
accessories available today.
3. Position your wireless phone within easy
reach. Be able to access your wireless
phone without removing your eyes from
Health and safety information
54
the road. If you get an incoming call at
an inconvenient time, let your voice mail
answer it for you.
4. Let the person you are speaking with
know you are driving; if necessary,
suspend the call in heavy traffic or
hazardous weather conditions. Rain,
sleet, snow, ice and even heavy traffic
can be hazardous.
5. Do not take notes or look up phone
numbers while driving. Jotting down a
“to do” list or flipping through your
address book takes attention away from
your primary responsibility, driving
safely.
6. Dial sensibly and assess the traffic; if
possible, place calls when you are not
moving or before pulling into traffic. Try
to plan calls when your car will be
stationary. If you need to make a call
while moving, dial only a few numbers,
check the road and your mirrors, then
continue.
7. Do not engage in stressful or emotional
conversations that may be distracting.
Make people you are talking with aware
you are driving and suspend
conversations that have the potential to
divert your attention from the road.
8. Use your wireless phone to call for help.
Dial 9-1-1 or other local emergency
number in the case of fire, traffic
accident or medical emergencies.
Remember, it is a free call on your
wireless phone!
55
9. Use your wireless phone to help others in
emergencies. If you see an auto
accident, crime in progress or other
serious emergency where lives are in
danger, call 9-1-1 or other local
emergency number, as you would want
others to do for you.
10. Call roadside assistance or a special non-
emergency wireless assistance number
when necessary. If you see a broken-
down vehicle posing no serious hazard, a
broken traffic signal, a minor traffic
accident where no one appears injured,
or a vehicle you know to be stolen, call
roadside assistance or other special non-
emergency number.
“The wireless industry reminds you to
use your phone safely when driving.”
For more information, please call 1-888-
901-SAFE, or visit our web-site www.wow-
com.com
Provided by the Cellular Telecommunications
& Internet Association
Operating Environment
Remember to follow any special regulations
in force in any area and always switch your
phone off whenever it is forbidden to use it,
or when it may cause interference or danger.
When connecting the phone or any
accessory to another device, read its user's
guide for detailed safety instructions. Do not
connect incompatible products.
Health and safety information
56
As with other mobile radio transmitting
equipment, users are advised that for the
satisfactory operation of the equipment and
for the safety of personnel, it is
recommended that the equipment should
only be used in the normal operating
position (held to your ear with the antenna
pointing over your shoulder).
Using Your Phone Near Other
Electronic Devices
Most modern electronic equipment is
shielded from radio frequency (RF) signals.
However, certain electronic equipment may
not be shielded against the RF signals from
your wireless phone. Consult the
manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that
a minimum distance of 15 cm (6 inches) be
maintained between a wireless phone and a
pacemaker to avoid potential interference
with the pacemaker.
These recommendations are consistent with
the independent research and
recommendations of Wireless Technology
Research.
Persons with pacemakers:
• should always keep the phone more than
15 cm
(6 inches) from their pacemaker when
the phone is switched on.
• should not carry the phone in a breast
pocket.
57
• should use the ear opposite the
pacemaker to minimize potential
interference.
If you have any reason to suspect that
interference is taking place, switch your
phone off immediately.
Hearing Aids
Some digital wireless phones may interfere
with some hearing aids. In the event of such
interference, you may wish to consult your
hearing aid manufacturer to discuss
alternatives.
Other Medical Devices
If you use any other personal medical
devices, consult the manufacturer of your
device to determine if it is adequately
shielded from external RF energy. Your
physician may be able to assist you in
obtaining this information. Switch your
phone off in health care facilities when any
regulations posted in these areas instruct
you to do so. Hospitals or health care
facilities may be using equipment that could
be sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in
motor vehicles. Check with the
manufacturer or its representative regarding
your vehicle. You should also consult the
manufacturer of any equipment that has
been added to your vehicle.
Posted Facilities
Switch your phone off in any facility where
posted notices require you to do so.
Health and safety information
58
Potentially Explosive Environments
Switch your phone off when in any area with
a potentially explosive atmosphere and obey
all signs and instructions. Sparks in such
areas could cause an explosion or fire
resulting in bodily injury or even death.
Users are advised to switch the phone off
while at a refueling point (service station).
Users are reminded of the need to observe
restrictions on the use of radio equipment in
fuel depots (fuel storage and distribution
areas), chemical plants or where blasting
operations are in progress.
Areas with a potentially explosive
atmosphere are often but not always clearly
marked. They include below deck on boats,
chemical transfer or storage facilities,
vehicles using liquefied petroleum gas (such
as propane or butane), areas where the air
contains chemicals or particles, such as
grain, dust or metal powders, and any other
area where you would normally be advised
to turn off your vehicle engine.
Emergency Calls
This phone, like any wireless phone,
operates using radio signals, wireless and
landline networks as well as user
programmed functions, which cannot
guarantee connection in all conditions.
Therefore, you should never rely solely on
any wireless phone for essential
communications (medical emergencies, for
example).
Remember, to make or receive any calls the
59
phone must be switched on and in a service
area with adequate signal strength.
Emergency calls may not be possible on all
wireless phone networks or when certain
network services and/or phone features are
in use. Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your
present location (for example, 911 or
other official emergency number).
Emergency numbers vary by location.
3. Press .
If certain features are in use (call barring,
for example), you may first need to
deactivate those features before you can
make an emergency call. Consult this
document and your local cellular service
provider.
When making an emergency call, remember
to give all the necessary information as
accurately as possible. Remember that your
phone may be the only means of
communication at the scene of an accident;
do not cut off the call until given permission
to do so.
Restricting Children's access to your
Phone
Your phone is not a toy. Children should not
be allowed to play with it because they could
hurt themselves and others, damage the
phone or make calls that increase your
phone bill.
Health and safety information
60
FCC Notice and Cautions
FCC Notice
• This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) this device may
not cause harmful interference, and (2) this
device must accept any interference received,
including interference that may cause
undesired operation.
• This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.This
equipment generates, uses and can radiate
radio frequency energy and,if not installed
and used in accordance with the
instructions, may cause harmful interference
to radio communications.
• This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.This
equipment generates, uses and can radiate
radio frequency energy and,if not installed
and used in accordance with the
instructions, may cause harmful interference
to radio communications.
61
The phone may cause TV or radio interference if
used in close proximity to receiving equipment.
The FCC can require you to stop using the
phone if such interference cannot be eliminated.
Vehicles using liquefied petroleum gas
(such as propane or butane) must comply
with the National Fire Protection Standard
(NFPA-58). For a copy of this standard,
contact the National Fire Protection
Association, One Battery march Park,
Quincy, MA 02269, Attn: Publication Sales
Division.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does
cause harmful interference to radio or
television reception, which can be
determined by turning the equipment
off and on, the user is encouraged to try
to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving
antenna.
-Increase the separation between the
equipment and receiver.
-Connect the equipment into an outlet
on a circuit different from that to which
the receiver is conected.
-Consult the dealer or an experienced
radio/TV technician for help
Health and safety information
62
Cautions
Changes or modifications made in the
radio phone, not expressly approved by
Samsung, will void the user’s authority to
operate the equipment.
Only use approved batteries, antennas
andchargers.
The use of any unauthorized accessories
may be dangerous and void the phone
warranty if said accessories cause
damage or a defect to the phone.
Although your phone is quite sturdy, it is a
complex piece of equipment and can be
broken. Avoid dropping, hitting, bending
or sitting on it.
Other Important Safety
Information
• Only qualified personnel should service
the phone or install the phone in a
vehicle. Faulty installation or service may
be dangerous and may invalidate any
warranty applicable to the device.
• Check regularly that all wireless phone
equipment in your vehicle is mounted
and operating properly.
• Do not store or carry flammable liquids,
gases or explosive materials in the same
compartment as the phone, its parts or
accessories.
• For vehicles equipped with an air bag,
remember that an air bag inflates with
great force. Do not place objects,
63
including both installed or portable
wireless equipment in the area over the
air bag or in the air bag deployment
area. If wireless equipment is improperly
installed and the air bag inflates, serious
injury could result.
• Switch your phone off before boarding an
aircraft. The use of wireless phone in
aircraft is illegal and may be dangerous
to the aircraft's operation.
• Failure to observe these instructions may
lead to the suspension or denial of
telephone services to the offender, or
legal action, or both.
Product Performance
Getting the Most Out of Your Signal
Reception
The quality of each call you make or receive
depends on the signal strength in your area.
Your phone informs you of the current signal
strength by displaying a number of bars next
to the signal strength icon. The more bars
displayed, the stronger the signal.
If you're inside a building, being near a
window may give you better reception.
Health and safety information
64
Understanding the Power Save
Feature
If your phone is unable to find a signal after
15 minutes of searching, a Power Save
feature is automatically activated. If your
phone is active, it periodically rechecks
service availability or you can check it
yourself by pressing any key.
Anytime the Power Save feature is activated,
a message displays on the screen. When a
signal is found, your phone returns to
standby mode.
Understanding How Your Phone
Operates
Your phone is basically a radio transmitter
and receiver. When it's turned on, it receives
and transmits radio frequency (RF) signals.
When you use your phone, the system
handling your call controls the power level.
This power can range from 0.006 watts to
0.2 watts in digital mode.
Maintaining Your Phone's Peak
Performance
For the best care of your phone, only
authorized personnel should service your
phone and accessories. Faulty service may
void the warranty.
There are several simple guidelines to
operating your phone properly and
maintaining safe, satisfactory service.
• Hold the phone with the antenna raised,
fully-extended and over your shoulder.
• Try not to hold, bend or twist the phone's
antenna.
65
• Don't use the phone if the antenna is
damaged.
• Speak directly into the phone's receiver.
• Avoid exposing your phone and
accessories to rain or liquid spills. If your
phone does get wet, immediately turn
the power off and remove the battery. If
it is inoperable, call Customer Care for
service.
Availability of Various Features/
Ring Tones
Many services and features are network
dependent and may require additional
subscription and/or usage charges. Not all
features are available for purchase or use in
all areas. Downloadable Ring Tones may be
available at an additional cost. Other
conditions and restrictions may apply. See
your service provider for additional
information.
Battery Standby and Talk Time
Standby and talk times will vary depending
on phone usage patterns and conditions.
Battery power consumption depends on
factors such as network configuration, signal
strength, operating temperature, features
selected, frequency of calls, and voice, data,
and other application usage patterns.
Health and safety information
66
Battery Precautions
• Never use any charger or battery that is
damaged in any way.
• Use the battery only for its intended
purpose.
• If you use the phone near the network's
base station, it uses less power; talk and
standby time are greatly affected by the
signal strength on the cellular network
and the parameters set by the network
operator.
• Battery charging time depends on the
remaining battery charge and the type of
battery and charger used. The battery
can be charged and discharged hundreds
of times, but it will gradually wear out.
When the operation time (talk time and
standby time) is noticeably shorter than
normal, it is time to buy a new battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries
and recharge your battery only with
Samsung-approved chargers. When a
charger is not in use, disconnect it from
the power source. Do not leave the
battery connected to a charger for more
than a week, since overcharging may
shorten its life.
• Extreme temperatures will affect the
charging capacity of your battery: it may
require cooling or warming first.
• Do not leave the battery in hot or cold
places, such as in a car in summer or
winter conditions, as you will reduce the
67
capacity and lifetime of the battery.
Always try to keep the battery at room
temperature. A phone with a hot or cold
battery may temporarily not work, even
when the battery is fully charged. Li-ion
batteries are particularly affected by
temperatures below 0 °C (32 °F).
• Do not short-circuit the battery.
Accidental short- circuiting can occur
when a metallic object (coin, clip or pen)
causes a direct connection between the
+ and - terminals of the battery (metal
strips on the battery), for example when
you carry a spare battery in a pocket or
bag. Short-circuiting the terminals may
damage the battery or the object causing
the short-circuiting.
• Dispose of used batteries in accordance
with local regulations. In some areas, the
disposal of batteries in household or
business trash may be prohibited. For
safe disposal options for Li-Ion batteries,
contact your nearest Samsung
authorized service center. Always
recycle. Do not dispose of batteries in a
fire.
Care and Maintenance
Your phone is a product of superior design
and craftsmanship and should be treated
with care. The suggestions below will help
you fulfill any warranty obligations and allow
you to enjoy this product for many years.
Health and safety information
68
• Keep the phone and all its parts and
accessories out of the reach of small
children.
• Keep the phone dry. Precipitation,
humidity and liquids contain minerals
that will corrode electronic circuits.
• Do not use the phone with a wet hand.
Doing so may cause an electric shock to
you or damage to the phone.
• Do not use or store the phone in dusty,
dirty areas, as its moving parts may be
damaged.
• Do not store the phone in hot areas.
High temperatures can shorten the life of
electronic devices, damage batteries,
and warp or melt certain plastics.
• Do not store the phone in cold areas.
When the phone warms up to its normal
operating temperature, moisture can
form inside the phone, which may
damage the phone's electronic circuit
boards.
• Do not drop, knock or shake the phone.
Rough handling can break internal circuit
boards.
• Do not use harsh chemicals, cleaning
solvents or strong detergents to clean
the phone. Wipe it with a soft cloth
slightly dampened in a mild soap-and-
water solution.
• Do not paint the phone. Paint can clog
the device's moving parts and prevent
proper operation.
69
• Do not put the phone in or on heating
devices, such as a microwave oven, a
stove or a radiator. The phone may
explode when overheated.
• When the phone or battery gets wet, the
label indicating water damage inside the
phone changes color. In this case, phone
repairs are no longer guaranteed by the
manufacturer's warranty, even if the
warranty for your phone has not expired.
• If your phone has a flash or light, do not
use it too close to the eyes of people or
animals. This may cause damage to their
eyes.
• Use only the supplied or an approved
replacement antenna. Unauthorized
antennas or modified accessories may
damage the phone and violate
regulations governing radio devices.
• If the phone, battery, charger or any
accessory is not working properly, take it
to your nearest qualified service facility.
The personnel there will assist you, and
if necessary, arrange for service.

Navigation menu
