SGH-M320L
User’s Guide
Some of the contents in this guide may differ from your phone depending on the
software of the phone or your service provider.
Bluetooth QD ID : B0XXXXX
Draft 01
2008. 03. 13
SW: M320LVHHC1
Installing the SIM card and battery
1. Remove the battery cover and insert the SIM card.
2. Install the battery and reattach the battery cover.
Battery cover
Battery
Charging the battery
1. Plug the supplied travel adapter into the phone and a power outlet.
2. When charging is finished, unplug the travel adapter.
Note
: Do not remove the battery from the phone without unplugging the
travel adapter first. Otherwise, the phone may be damaged.
With the triangle
facing up
Phone layout and key functions
Power/End key
Turns the phone on or
off when held down.
Also, ends a call.
Silent mode key
X
Silent mode
Delete key
Deletes characters from
the display or items in an
application.
Dial key
Makes and answers a call.
In Idle mode, retrieves
the most recent calls.
Volume keys
In Idle mode, adjust the
keypad tone volume.
Send an SOS message
when pressed 4 times
with the phone closed.
X
SOS mode
Alphanumeric keys
Web access/
Confirm key
In Idle mode, accesses
the web browser.
In Menu mode, selects
the highlighted option or
confirms input.
Voice mail server key
In Idle mode, accesses
your voice mail server
when held down.
4-way navigation keys
In Idle mode, access the
following menus or
functions directly:
•
Up
:
Camera
•
Down
/
Left
/
Right
: your
favorite menus
In Menu mode, scroll
through menu options.
Soft keys
Perform functions
indicated by the text
above the key.
Display
Your phone is in Idle mode when you are not on a call or using a menu.
You must be in Idle mode to dial a phone number.
Silent
mode
Press and hold in Idle mode to disable all sounds on the
phone. To exit, press and hold this key again.
SOS
mode
With the phone closed, press the Volume keys 4 times to send
an SOS message to preset phone numbers. Once the SOS
message is sent, the phone will change to SOS mode and will
receive calls only from the registered recipients. Upon receiving
a call from the SOS message recipients, the phone will
automatically answer the call. Press to exit SOS mode.
Menu Contacts
Text and graphics
Soft key function indicators
Icons
Your phone displays the following status indicators on the top of the
screen:
Switching on or off the phone
1. Press and hold for more than one second to switch on the phone.
2. Press and hold for more than two seconds to switch off the phone.
Changing the display language
1. In Idle mode, press the
Menu
soft key.
2. Select
Settings
→
Phone settings
→
Language
.
3. Select a language.
Making a call
1. In Idle mode, enter an area code and phone number, and press .
2. Press to end the call.
Answering a call
1. When the phone rings, press the
Accept
soft key or to answer a
call.
Press the
Reject
soft key or to reject the call.
2. Press to end the call.
Adjusting the volume
1. In Idle mode, press the
Menu
soft key.
2. Select
Settings
→
Sound settings
→
Incoming call
→
Call alert
volume
.
3. Press
Left
or
Right
to adjust the volume level.
4. Press the
Save
soft key.
While a call is in progress, press the Volume keys to adjust the earpiece
volume.
Changing a ringtone for calls
1. In Idle mode, press the
Menu
soft key.
2. Select
Settings
→
Sound settings
→
Incoming call
→
Ringtone
.
3. Select a ringtone category
→
a ringtone and press the
Save
soft key.
Redialing recent numbers
1. In Idle mode, press .
2. Press
Left
or
Right
to select a call type.
3. Press
Up
or
Down
to scroll to the number you want.
4. Press to dial the number.
Using the menus
In Idle mode, press the
Menu
soft key
to enter the main menu.
To exit the menu
without changing
the menu settings,
press this key.
Labels at the bottom corners of the display show the
current soft key functions. Press the left soft key ( )
or right soft key ( ) to perform the function indicated.
Use the 4-way navigation keys as shortcuts to access
your favorite menus.
Up
is fixed as a shortcut to
Camera
.
1. In Idle mode, press the
Menu
soft key.
2. Select
Settings
→
Phone settings
→
Shortcuts
.
3. Select a key.
4. Select a menu to be assigned to the key.
To select or modify a menu or feature:
1. In Idle mode, press the
Menu
soft key.
2. Press the Navigation keys to reach a desired menu and then press
the
Select
soft key or .
3. If the menu contains any submenus, locate the one you want by
pressing the Navigation keys. Press the
Select
soft key or to
enter the submenu.
If the selected menu contains additional submenus, repeat this
step.
4. Press the Navigation keys to find the setting of your choice.
5. Press the
Select
soft key or to confirm your chosen setting.
Shortcut numbers
You can quickly access the menu you want by using shortcut numbers.
The shortcut number displays in front of the menu name in Menu
mode.
Menu map
1. Call log
1.1 Recent contacts
1.2 Missed calls
1.3 Dialled calls
1.4 Received calls
1.5 Delete all
1.6 Call manager
2. Phonebook
2.1 Contact list
2.2 Create contact
2.3 Group
2.4 Speed dial
2.5 My namecard
2.6 Own numbers
2.7 Management
2.8 Service number*
3. Applications
3.1 Alarm
3.2 Voice recorder
3.3 FM radio
3.4 Java world
3.5 Memo
3.6 World clock
3.7 Calculator
3.8 Converter
3.9 Timer
3.10 Stopwatch
3.11 SIM application
toolkit
*
4. Browser
4.1 Home
4.2 Enter URL
4.3 Bookmarks
4.4 Clear cache
4.5 Browser settings
5. Messages
5.1 Create message
5.2 My messages
5.3 Templates
5.4 Delete all
5.5 Settings
5.6 SOS messages
5.7 Memory status
6. My files
6.1 Images
6.2 Sounds
6.3 Other files
6.4 Memory status
7. Calendar
8. Camera
9. Settings
9.1 Time and date
9.2 Phone settings
9.3 Display settings
9.4 Sound settings
9.5 Light settings
9.6 Network services
9.7 Bluetooth
9.8 Security
9.9 Connection
settings
9.10 Memory status
9.11 Reset settings
* Available only if supported
by your SIM card.
Entering text
Changing the text input mode
• Press and hold to switch between T9 mode and ABC mode.
• Press to change case or switch to Number mode.
• Press and hold to switch to Symbol mode.
T9 mode
1. Press
2
to
9
to start entering a word. Press each key once for one
letter.
The word you are entering appears on the display. It may change with
each keypress. Finish entering the word before editing or deleting any
keystrokes.
Example: To enter “Hello” in T9 mode, press
4
,
3
,
5
,
5
, and
6
.
2. To display alternate word choices, press
0
.
3. Press to insert a space and enter the next word.
ABC mode
Press the keys labeled with the letter you want once for the first letter,
twice for the second letter, and so on.
For example, press
2
three times to enter “C” and
5
two times to enter
“K.”
Icon Description
Signal strength
GPRS (2.5G) network
Connecting to GPRS
(2.5G) network
Tra ns fer ring da ta in
GPRS (2.5G) network
Call in progress
Out of your service area
or Offline mode
Connected to secured
web page
Connected with PC
Call diverting active
Home Zone
Office Zone
Roaming network
New message
New voice mail
SOS message feature
active
Bluetooth active
Bluetooth hands-free car
kit or headset connected
Alarm set
FM radio on
Silent mode (Vibration)
Silent mode (Mute)
Call ringer set to vibrate
Whisper mode, during a
call
Mute mode, during a call
Battery power level
Icon Description
Number mode
Press the keys corresponding to the digits you want.
Symbol mode
Press the keys corresponding to the symbol you want and press the
OK
soft key. You can press the Navigation keys to scroll to a symbol set.
Tips for entering text
• To move the cursor, press the Navigation keys.
• To delete characters one by one, press
C
. To delete all of the characters,
press and hold
C
.
• To insert a space between characters, press .
• To enter punctuation marks in T9 mode or ABC mode, press
1
.
Sending an SMS message
1. In Idle mode, press the
Menu
soft key.
2. Select
Messages
→
Create message
→
Text message
.
3. Enter the message text.
4. Press the
Options
soft key and add items using the following options:
•
Insert
: add text templates, Phonebook entries, or bookmark items.
•
Add image
: add images.
•
Add animation
: add emotions or animations.
•
Add melody
: add sounds.
•
Attach
: attach a contact, calendar item, memo, or task.
5. Press the
Options
soft key and select
Send only
or
Save and send
.
6. Enter a destination number.
7. Press
to send the message.
Taking a photo
1. In Idle mode, press
Up
.
2. Aim the lens at the subject and make any desired adjustments.
3. Press to take a photo.
4. Press the
Preview
soft key to take another photo, or press
C
to delete
the photo.
Quick feature reference
This section provides brief explanations of features on your phone.
Menu Description
Menu > Call log
> Recent contacts,
Missed calls, Dialled
calls, or Received
calls
View the most recent calls you have dialed,
received, or missed.
Menu > Call log
> Delete all
Delete the call logs in each call type, or all logs
at once.
Menu
> Call log
> Call manager
View the duration of recent calls you have dialed
and received, and the cost of your calls, if
supported by your SIM card. Also, make a list of
the phone numbers from which you want to
reject calls.
Menu > Phonebook
> Contact list
Search for contacts in Phonebook.
Menu > Phonebook
> Create contact
Add a new contact to Phonebook.
Menu
> Phonebook
> Group
Create a group and select a ringtone and image
for incoming calls from members of a group.
Also, change the group name.
Menu > Phonebook
> Speed dial
Assign speed dial numbers of your most
frequently dialed numbers.
Menu > Phonebook
> My namecard
Create a name card and send it to other people.
Menu > Phonebook
> Own numbers
Check your phone numbers or assign a name to
them.
Menu Description
Menu
> Phonebook
> Management
Copy all contacts on the SIM card to the phone’s
memory, or delete all Phonebook contacts. You
can also check memory information for
Phonebook contacts.
Menu > Phonebook
> Service number
Access the list of service numbers assigned by
your service provider.
Menu > Applications
> Alarm
Set an alarm to sound at a specific time.
Menu > Applications
> Voice recorder
Record voice memos and listen to them.
Menu
> Applications
> FM radio
Listen to music or news via the FM radio on your
phone. First, you must connect your phone with
the headset, which serves as a radio antenna.
Menu > Applications
> Java world
Access the embedded Java games and
downloaded Java applications.
Menu > Applications
> Memo
Make memos for things that are important and
manage them.
Menu > Applications
> World clock
Set your local time zone and find out the current
time in another part of the world.
Menu > Applications
> Calculator
Perform basic arithmetic functions.
Menu Description
Menu > Applications
> Converter
Do conversions such as currency and
temperature.
Menu > Applications
> Timer
Set a period of time for the phone to count
down.
Menu > Applications
> Stopwatch
Measure elapsed time.
Menu > Applications
> SIM application
toolkit
Use a variety of additional service offered by
your service provider. Depending on your SIM
card, this may available but labelled differently.
Menu > Browser
> Home
Connect your phone to the network and load the
homepage of the wireless web service provider.
Menu > Browser
> Enter URL
Enter a URL address in order to quickly access
web pages.
Menu > Browser
> Bookmarks
Save URL addresses in order to quickly access
web pages.
Menu > Browser
> Clear cache
Clear the cache, which is a temporary memory
site that stores recently accessed web pages.
Menu > Browser
> Browser settings
Select a connection profile to be used for
accessing the wireless web.
Menu > Messages
> Create message
> Text message or
Multimedia message
Create and send messages to other mobile
phones.
Menu Description
Menu > Messages
> My messages
Access messages that you have received, sent,
or that you have failed in sending.
Menu > Messages
> Templates
Preset templates of frequently used messages.
Menu > Messages
> Delete all
Delete messages in each message folder, or all
messages at once.
Menu > Messages
> Settings
Set options for using messaging services.
Menu > Messages
> SOS messages
Activate the SOS message feature. Enter
recipients and select the repeat mode.
Menu > Messages
> Memory status
Check information about the memory currently
in use.
Menu > My files
> Images, Sounds,
Other files
Access media files and other files stored in the
phone’s memory.
Menu > My files
> Memory status
Check information about the memory currently
in use.
Menu > Calendar Keep track of daily or monthly schedule.
Menu > Camera Take photos in various modes.
Menu > Settings
> Time and date
Set the current time and date manually or set
your local time zone.
Menu Description
Menu > Settings
> Phone settings
> Language
Select a language to be used for the display
text.
Menu > Settings
> Phone settings
> Greeting message
Enter the greeting message to be displayed
when the phone is switched on.
Menu > Settings
> Phone settings
> Shortcuts
Set the Navigation keys as shortcuts to access
your favorite menus directly.
Menu > Settings
> Phone settings
> Volume key
Set whether the phone mutes the call ringer or
rejects a call if you press and hold the Volume
keys when a call comes in.
Menu > Settings
> Phone settings
> Extra settings
Set the automatic redialing feature or the
answering method.
Menu
> Settings
> Phone settings
> Offline mode
Switch the phone to Offline mode. This mode is
helpful when you want to use your phone in a
place where you are not allowed to use mobile
devices, such as in an airplane and at a hospital.
Menu > Settings
> Display settings
Change the settings for the display.
Menu > Settings
> Sound settings
Change the settings for the various sounds.
Menu Description
Menu > Settings
> Light settings
Change the settings for the backlight and
keypad light.
Menu > Settings
> Network services
Access network services offered by your service
provider.
Menu
> Settings
> Bluetooth
Connect the phone wirelessly to other Bluetooth
devices and exchange data with them, talk
hands-free, or control the phone remotely.
Menu > Settings
> Security > PIN
check
Activate your PIN to protect your SIM card
against unauthorized use.
Menu > Settings
> Security
> Change PIN code
Change the PIN.
Menu > Settings
> Security
> Phone lock
Activate your phone password to protect your
phone against unauthorized use.
Menu > Settings
> Security
> Change password
Change the phone password.
Menu > Settings
> Security > Privacy
Lock access to messages, files, or all menu
functions on the phone, except for call functions.
Menu > Settings
> Security > SIM lock
Set the phone to work only with the current SIM
card by assigning a SIM lock password.
Menu Description
Menu > Settings
> Security
> Fixed dialling mode
Set the phone to restrict calls to a limited set of
phone numbers, if supported by your SIM card.
Menu > Settings
> Security
> Change PIN2 code
Change your current PIN2, if supported by your
SIM card.
Menu
> Settings
> Security
> Mobile tracker
Track your phone when it is stolen or lost. When
someone tries to use your phone with other SIM
card, the phone will automatically send the
preset tracking message to your family or
friends. This feature may be unavailable due to
certain features supported by your service
provider.
Menu > Settings
> Connection settings
Create and customize the profiles containing the
settings for connecting your phone to the
network.
Menu > Settings
> Memory status
Check information about the memory currently
in use.
Menu > Settings
> Reset settings
Reset the phone to the factory default settings.
Menu Description
Important safety precautions
Read these guidelines before using your wireless phone. Failure to comply
with them may be dangerous or illegal.
Drive safely at all times
Do not use a hand-held phone while driving; park your vehicle first.
Switching off when refueling
Do not use the phone at a refueling point (service station) or near fuels or
chemicals.
Switching off in an aircraft
Wireless phones can cause interference. Using them in an aircraft is both
illegal and dangerous.
Switching off near all medical equipment
Hospitals and health care facilities may be using equipment that could be
sensitive to external RF energy. Follow any regulations or rules in force.
Interference
All wireless phones may be subject to interference, which could affect their
performance.
Special regulations
Follow any special regulations in force in any area and always switch off
your phone whenever it is forbidden to use it.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to your ear). Avoid unnecessary
contact with the antenna when the phone is switched on.
Emergency calls
Key in the emergency number for your present location, then press .
Do not end the call until given permission to do so.
Small children and your phone
Keep the phone and all its parts including accessories out of reach of small
children.
Accessories and batteries
Use only Samsung-approved batteries and accessories, such as headsets
and PC data cables. Use of any unauthorized accessories could damage
your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your phone.
Risk of explosion if a battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
At very high volume, prolonged listening to a headset can
damage your hearing.
CAUTION
SAR information
Your wireless phone is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal Communications Commission
(FCC) of the U.S. Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for the general
population. The guidelines are based on the safety standards that were
developed by independent scientific organizations through periodic and
thorough evaluation of scientific studies.
The standards include a substantial safety margin designed to assure the
safety of all persons, regardless of age and health.
The exposure standard for wireless phones employs a unit of
measurement known as Specific Absorption Rate (SAR). The SAR limit set
by the FCC is 1.6 W/kg
*
. The highest SAR values for this model phone as
reported to the FCC are GSM 850 Head: x.xx W/kg, Body-worn: x.xx W/
kg, GSM 1800 Head: x.xx W/kg, Body-worn: x.xx W/kg, and GSM 1900
Head: x.xx W/kg, Body-worn: x.xxx W/kg.
*
In the U.S. and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kg
(W/kg) averaged over one gram of tissue. The standard incorporates a substantial margin of
safety to give additional protection for the public and to account for any variations in
measurements.
Solve problems
Settings
(Menu 9)
21
Solve problems
Help and personal needs
To save the time and expense of an unnecessary service
call, perform the simple checks in this section before
contacting a service professional.
When you switch on your phone, the following
messages may appear:
“Insert SIM”
• Be sure that the SIM card is correctly installed.
“Phone lock”
• The automatic locking function has been enabled.
You must enter the phone’s password before you
can use the phone.
“Enter PIN”
• You are using your phone for the first time. You
must enter the PIN supplied with the SIM card.
• The PIN check feature is enabled. Every time the
phone is switched on, the PIN has to be entered.
To disable this feature, use the
PIN check
menu.
“Enter PUK”
• The PIN code has been entered incorrectly three
times in succession, and the phone is now blocked.
Enter the PUK supplied by your service provider.
“No service,” “Network failure,” or “Not done”
displays
• The network connection has been lost. You may be
in a weak signal area. Move and try again.
• You are trying to access an option for which you
have no subscription with your service provider.
Contact the service provider for further details.
You have entered a number but it was not dialled
• Be sure that you have pressed [ ].
• Be sure that you have accessed the right cellular
network.
• Be sure that you have not set an outgoing call
barring option.
Your correspondent cannot reach you
• Be sure that your phone is switched on. ([ ]
pressed for more than one second.)
22
Solve problems
• Be sure that you are accessing the correct cellular
network.
• Be sure that you have not set an incoming call
barring option.
Your correspondent cannot hear you speaking
• Be sure that you have switched on the
microphone.
• Be sure that you are holding the phone close
enough to your mouth. The microphone is located
at the bottom of the phone.
The phone starts beeping and “Battery low”
flashes on the display
• Your battery is insufficiently charged. Recharge the
battery.
The audio quality of the call is poor
• Check the signal strength indicator on the display
( ). The number of bars indicates the signal
strength from strong ( ) to weak ( ).
• Try moving the phone slightly or moving closer to a
window if you are in a building.
No number is dialled when you re-call a
Phonebook entry
• Use the Contact list feature to ensure the number
has been stored correctly.
• Re-store the number, if necessary.
The battery doesn’t charge properly or the phone
sometimes turns itself off
• Wipe the charging contacts both on the phone and
on the battery with a clean soft cloth.
If the above guidelines do not help you to solve
the problem, take note of:
• The model and serial numbers of your phone
•Your warranty details
• A clear description of the problem
Then contact your local dealer or Samsung after-sales
service.
Health and safety information
23
Health and safety information
Exposure to radio frequency
(RF) signals
Certification Information (SAR)
Your wireless phone is a radio transmitter and receiver. It
is designed and manufactured not to exceed the exposure
limits for radio frequency (RF) energy set by the Federal
Communications Commission (FCC) of the U.S.
government. These FCC exposure limits are derived from
the recommendations of two expert organizations, the
National Counsel on Radiation Protection and
Measurement (NCRP) and the Institute of Electrical and
Electronics Engineers (IEEE). In both cases, the
recommendations were developed by scientific and
engineering experts drawn from industry, government,
and academia after extensive reviews of the scientific
literature related to the biological effects of RF energy.
The exposure limit set by the FCC for wireless mobile
phones employs a unit of measurement known as the
Specific Absorption Rate (SAR). The SAR is a measure of
the rate of absorption of RF energy by the human body
expressed in units of watts per kilogram (W/kg). The FCC
requires wireless phones to comply with a safety limit of
1.6 watts per kilogram (1.6 W/kg). The FCC exposure limit
incorporates a substantial margin of safety to give
additional protection to the public and to account for any
variations in measurements.
SAR tests are conducted using standard operating
positions accepted by the FCC with the phone transmitting
at its highest certified power level in all tested frequency
bands. Although the SAR is determined at the highest
certified power level, the actual SAR level of the phone
while operating can be well below the maximum value.
This is because the phone is designed to operate at
multiple power levels so as to use only the power required
to reach the network. In general, the closer you are to a
wireless base station antenna, the lower the power
output.
24
Health and safety information
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that it
does not exceed the exposure limit established by the
FCC. Tests for each model phone are performed in
positions and locations (e.g. at the ear and worn on the
body) as required by the FCC.
The highest SAR values for this model phone as reported
to the FCC are :
GSM850 Head: 0.486 W/Kg, Body-worn: 0.35 W/Kg.
GSM1900 Head: 0.609 W/Kg, Body-worn: 0.416 W/Kg.
For body worn operations, this model phone has been
testde and meets the FCC exposure guidelines when used
with a Samsung accessory designated for this product or
when used with an accessroy that contains no metal and
that positons the handset a minimum 1.5 cm from the
body.
Non-compliance with the above restrictions may result in
violation of FCC RF exposure guidelines.
SAR information on this and other model phones can be
viewed on-line at www.fcc.gov/oet/fccid. This site uses the
phone FCC ID number A3LSGHM320L.
Sometimes it may be necessary to remove the battery
pack to find the number. Once you have the FCC ID
number for a particular phone, follow the instructions on
the website and it should provide values for typical or
maximum SAR for a particular phone. Additional product
specific SAR information can also be obtained at
www.fcc.gov/cgb/sar.
Consumer Information on Wireless Phones
The U.S. Food and Drug Administration (FDA) has
published a series of Questions and Answers for
consumers relating to radio frequency (RF) exposure from
wireless phones. The FDA publication includes the
following information:
What kinds of phones are the subject of this update?
The term wireless phone refers here to hand-held wireless
phones with built-in antennas, often called “cell,” “mobile,”
or “PCS” phones. These types of wireless phones can
Health and safety information
25
expose the user to measurable radio frequency energy
(RF) because of the short distance between the phone and
the user's head. These RF exposures are limited by
Federal Communications Commission safety guidelines
that were developed with the advice of FDA and other
federal health and safety agencies. When the phone is
located at greater distances from the user, the exposure to
RF is drastically lower because a person's RF exposure
decreases rapidly with increasing distance from the
source. The so-called “cordless phones,” which have a
base unit connected to the telephone wiring in a house,
typically operate at far lower power levels, and thus
produce RF exposures well within the FCC's compliance
limits.
Do wireless phones pose a health hazard?
The available scientific evidence does not show that any
health problems are associated with using wireless
phones. There is no proof, however, that wireless phones
are absolutely safe. Wireless phones emit low levels of
radio frequency energy (RF) in the microwave range while
being used. They also emit very low levels of RF when in
the stand-by mode. Whereas high levels of RF can produce
health effects (by heating tissue), exposure to low level RF
that does not produce heating effects causes no known
adverse health effects. Many studies of low level RF
exposures have not found any biological effects. Some
studies have suggested that some biological effects may
occur, but such findings have not been confirmed by
additional research. In some cases, other researchers
have had difficulty in reproducing those studies, or in
determining the reasons for inconsistent results.
What is FDA's role concerning the safety of wireless
phones?
Under the law, FDA does not review the safety of
radiation-emitting consumer products such as wireless
phones before they can be sold, as it does with new drugs
or medical devices. However, the agency has authority to
take action if wireless phones are shown to emit radio
frequency energy (RF) at a level that is hazardous to the
user. In such a case, FDA could require the manufacturers
of wireless phones to notify users of the health hazard and
to repair, replace or recall the phones so that the hazard
no longer exists.
Although the existing scientific data do not justify FDA
regulatory actions, FDA has urged the wireless phone
26
Health and safety information
industry to take a number of steps, including the
following:
• “Support needed research into possible biological
effects of RF of the type emitted by wireless phones;
• “Design wireless phones in a way that minimizes any
RF exposure to the user that is not necessary for
device function; and
• “Cooperate in providing users of wireless phones with
the best possible information on possible effects of
wireless phone use on human health.
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at the
federal level. The following agencies belong to this
working group:
• “National Institute for Occupational Safety and Health
• “Environmental Protection Agency
• ”Federal Communications Commission
• ”Occupational Safety and Health Administration.
• ”National Telecommunications and Information
Administration
The National Institutes of Health participates in some
interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless phones
with the Federal Communications Commission (FCC). All
phones that are sold in the United States must comply
with FCC safety guidelines that limit RF exposure. FCC
relies on FDA and other health agencies for safety
questions about wireless phones.
FCC also regulates the base stations that the wireless
phone networks rely upon. While these base stations
operate at higher power than do the wireless phones
themselves, the RF exposures that people get from these
base stations are typically thousands of times lower than
those they can get from wireless phones. Base stations
are thus not the primary subject of the safety questions
discussed in this document.
What are the results of the research done already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws in their
research methods. Animal experiments investigating the
effects of radio frequency energy (RF) exposures
Health and safety information
27
characteristic of wireless phones have yielded conflicting
results that often cannot be repeated in other laboratories.
A few animal studies, however, have suggested that low
levels of RF could accelerate the development of cancer in
laboratory animals. However, many of the studies that
showed increased tumor development used animals that
had been genetically engineered or treated with cancer-
causing chemicals so as to be pre-disposed to develop
cancer in absence of RF exposure. Other studies exposed
the animals to RF for up to 22 hours per day. These
conditions are not similar to the conditions under which
people use wireless phones, so we don't know with
certainty what the results of such studies mean for human
health.
Three large epidemiology studies have been published
since December 2000. Between them, the studies
investigated any possible association between the use of
wireless phones and primary brain cancer, glioma,
meningioma, or acoustic neuroma, tumors of the brain or
salivary gland, leukemia, or other cancers. None of the
studies demonstrated the existence of any harmful health
effects from wireless phones RF exposures. However, none
of the studies can answer questions about long-term
exposures, since the average period of phone use in these
studies was around three years.
What research is needed to decide whether RF
exposure from wireless phones poses a health risk?
A combination of laboratory studies and epidemiological
studies of people actually using wireless phones would
provide some of the data that are needed. Lifetime animal
exposure studies could be completed in a few years.
However, very large numbers of animals would be needed
to provide reliable proof of a cancer promoting effect if
one exists. Epidemiological studies can provide data that
is directly applicable to human populations, but ten or
more years' follow-up may be needed to provide answers
about some health effects, such as cancer. This is because
the interval between the time of exposure to a cancer-
causing agent and the time tumors develop - if they do -
may be many, many years. The interpretation of
epidemiological studies is hampered by difficulties in
measuring actual RF exposure during day-to-day use of
wireless phones. Many factors affect this measurement,
such as the angle at which the phone is held, or which
model of phone is used.
28
Health and safety information
What is FDA doing to find out more about the
possible health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology Program
and with groups of investigators around the world to
ensure that high priority animal studies are conducted to
address important questions about the effects of exposure
to radio frequency energy (RF).
FDA has been a leading participant in the World Health
Organization international Electromagnetic Fields (EMF)
Project since its inception in 1996. An influential result of
this work has been the development of a detailed agenda
of research needs that has driven the establishment of
new research programs around the world. The Project has
also helped develop a series of public information
documents on EMF issues.
FDA and Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative Research
and Development Agreement (CRADA) to do research on
wireless phone safety. FDA provides the scientific
oversight, obtaining input from experts in government,
industry, and academic organizations. CTIA-funded
research is conducted through contracts to independent
investigators. The initial research will include both
laboratory studies and studies of wireless phone users.
The CRADA will also include a broad assessment of
additional research needs in the context of the latest
research developments around the world.
What steps can I take to reduce my exposure to
radio frequency energy from my wireless phone?
If there is a risk from these products - and at this point we
do not know that there is - it is probably very small. But if
you are concerned about avoiding even potential risks,
you can take a few simple steps to minimize your
exposure to radio frequency energy (RF). Since time is a
key factor in how much exposure a person receives,
reducing the amount of time spent using a wireless phone
will reduce RF exposure.
• “If you must conduct extended conversations by
wireless phone every day, you could place more
distance between your body and the source of the RF,
since the exposure level drops off dramatically with
distance. For example, you could use a headset and
carry the wireless phone away from your body or use a
wireless phone connected to a remote antenna.
Again, the scientific data do not demonstrate that wireless
phones are harmful. But if you are concerned about the RF
Health and safety information
29
exposure from these products, you can use measures like
those described above to reduce your RF exposure from
wireless phone use.
What about children using wireless phones?
The scientific evidence does not show a danger to users of
wireless phones, including children and teenagers. If you
want to take steps to lower exposure to radio frequency
energy (RF), the measures described above would apply
to children and teenagers using wireless phones. Reducing
the time of wireless phone use and increasing the distance
between the user and the RF source will reduce RF
exposure.
Some groups sponsored by other national governments
have advised that children be discouraged from using
wireless phones at all. For example, the government in the
United Kingdom distributed leaflets containing such a
recommendation in December 2000. They noted that no
evidence exists that using a wireless phone causes brain
tumors or other ill effects. Their recommendation to limit
wireless phone use by children was strictly precautionary;
it was not based on scientific evidence that any health
hazard exists.
Do hands-free kits for wireless phones reduce risks
from exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that hands-free kits reduce risks. Hands-free kits
can be used with wireless phones for convenience and
comfort. These systems reduce the absorption of RF
energy in the head because the phone, which is the source
of the RF emissions, will not be placed against the head.
On the other hand, if the phone is mounted against the
waist or other part of the body during use, then that part
of the body will absorb more RF energy. Wireless phones
marketed in the U.S. are required to meet safety
requirements regardless of whether they are used against
the head or against the body. Either configuration should
result in compliance with the safety limit.
Do wireless phone accessories that claim to shield
the head from RF radiation work?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that accessories that claim to shield the head from
those emissions reduce risks. Some products that claim to
shield the user from RF absorption use special phone
30
Health and safety information
cases, while others involve nothing more than a metallic
accessory attached to the phone. Studies have shown that
these products generally do not work as advertised. Unlike
“hand-free” kits, these so-called “shields” may interfere
with proper operation of the phone. The phone may be
forced to boost its power to compensate, leading to an
increase in RF absorption. In February 2002, the Federal
trade Commission (FTC) charged two companies that sold
devices that claimed to protect wireless phone users from
radiation with making false and unsubstantiated claims.
According to FTC, these defendants lacked a reasonable
basis to substantiate their claim.
What about wireless phone interference with
medical equipment?
Radio frequency energy (RF) from wireless phones can
interact with some electronic devices. For this reason, FDA
helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted cardiac
pacemakers and defibrillators from wireless telephones.
This test method is now part of a standard sponsored by
the Association for the Advancement of Medical
instrumentation (AAMI). The final draft, a joint effort by
FDA, medical device manufacturers, and many other
groups, was completed in late 2000. This standard will
allow manufacturers to ensure that cardiac pacemakers
and defibrillators are safe from wireless phone EMI. FDA
has tested wireless phones and helped develop a
voluntary standard sponsored by the Institute of Electrical
and Electronic Engineers (IEEE). This standard specifies
test methods and performance requirements for hearing
aids and wireless phones so that no interference occurs
when a person uses a compatible phone and a compatible
hearing aid at the same time. This standard was approved
by the IEEE in 2000.
FDA continues to monitor the use of wireless phones for
possible interactions with other medical devices. Should
harmful interference be found to occur, FDA will conduct
testing to assess the interference and work to resolve the
problem.
Additional information on the safety of RF exposures from
various sources can be obtained from the following
organizations:
• FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
• Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
Health and safety information
31
• Occupational Safety and Health Administration's
(OSHA):
http://www.osha.gov/SLTC/radiofrequencyradiation/
index.html
• National institute for Occupational Safety and Health
(NIOSH):
http://www.cdc.gov/niosh/emfpg.html
• World health Organization (WHO):
http://www.who.int/peh-emf/
• International Commission on Non-Ionizing Radiation
Protection:
http://www.icnirp.de
• National Radiation Protection Board (UK):
http://www.nrpb.org.uk
• Updated 4/3/2002: US food and Drug Administration
http://www.fda.gov/cellphones
Road Safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime. But an
important responsibility accompanies the benefits of
wireless phones, one that every user must uphold.
When driving a car, driving is your first responsibility.
When using your wireless phone behind the wheel of a car,
practice good common sense and remember the following
tips:
1. Get to know your wireless phone and its features, such
as speed dial and redial. If available, these features
help you to place your call without taking your
attention off the road.
2. When available, use a hands-free device. If possible,
add an additional layer of convenience and safety to
your wireless phone with one of the many hands free
accessories available today.
3. Position your wireless phone within easy reach. Be
able to access your wireless phone without removing
your eyes from the road. If you get an incoming call at
an inconvenient time, let your voice mail answer it for
you.
4. Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy traffic
or hazardous weather conditions. Rain, sleet, snow, ice
and even heavy traffic can be hazardous.
5. Do not take notes or look up phone numbers while
driving. Jotting down a “to do” list or flipping through
your address book takes attention away from your
primary responsibility, driving safely.
32
Health and safety information
6. Dial sensibly and assess the traffic; if possible, place
calls when you are not moving or before pulling into
traffic. Try to plan calls when your car will be
stationary. If you need to make a call while moving,
dial only a few numbers, check the road and your
mirrors, then continue.
7. Do not engage in stressful or emotional conversations
that may be distracting. Make people you are talking
with aware you are driving and suspend conversations
that have the potential to divert your attention from
the road.
8. Use your wireless phone to call for help. Dial 9-1-1 or
other local emergency number in the case of fire,
traffic accident or medical emergencies. Remember, it
is a free call on your wireless phone!
9. Use your wireless phone to help others in
emergencies. If you see an auto accident, crime in
progress or other serious emergency where lives are
in danger, call 9-1-1 or other local emergency number,
as you would want others to do for you.
10. Call roadside assistance or a special non-emergency
wireless assistance number when necessary. If you
see a broken-down vehicle posing no serious hazard, a
broken traffic signal, a minor traffic accident where no
one appears injured, or a vehicle you know to be
stolen, call roadside assistance or other special non-
emergency number.
“The wireless industry reminds you to use your
phone safely when driving.”
For more information, please call 1-888-901-SAFE, or visit
our web-site www.wow-com.com
Provided by the Cellular Telecommunications & Internet
Association
Operating Environment
Remember to follow any special regulations in force in any
area and always switch your phone off whenever it is
forbidden to use it, or when it may cause interference or
danger. When connecting the phone or any accessory to
another device, read its user's guide for detailed safety
instructions. Do not connect incompatible products.
As with other mobile radio transmitting equipment, users
are advised that for the satisfactory operation of the
equipment and for the safety of personnel, it is
recommended that the equipment should only be used in
the normal operating position (held to your ear with the
antenna pointing over your shoulder).
Health and safety information
33
Using Your Phone Near Other Electronic
Devices
Most modern electronic equipment is shielded from radio
frequency (RF) signals. However, certain electronic
equipment may not be shielded against the RF signals
from your wireless phone. Consult the manufacturer to
discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a minimum
distance of 15 cm (6 inches) be maintained between a
wireless phone and a pacemaker to avoid potential
interference with the pacemaker.
These recommendations are consistent with the
independent research and recommendations of Wireless
Technology Research.
Persons with pacemakers:
• should always keep the phone more than 15 cm (6
inches) from their pacemaker when the phone is
switched on.
• should not carry the phone in a breast pocket.
• should use the ear opposite the pacemaker to
minimize potential interference.
If you have any reason to suspect that interference is
taking place, switch your phone off immediately.
Hearing Aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you may
wish to consult your hearing aid manufacturer to discuss
alternatives.
Other Medical Devices
If you use any other personal medical devices, consult the
manufacturer of your device to determine if it is
adequately shielded from external RF energy. Your
physician may be able to assist you in obtaining this
information. Switch your phone off in health care facilities
when any regulations posted in these areas instruct you to
do so. Hospitals or health care facilities may be using
equipment that could be sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles. Check with
the manufacturer or its representative regarding your
vehicle. You should also consult the manufacturer of any
equipment that has been added to your vehicle.
34
Health and safety information
Posted Facilities
Switch your phone off in any facility where posted notices
require you to do so.
Potentially Explosive Environments
Switch your phone off when in any area with a potentially
explosive atmosphere and obey all signs and instructions.
Sparks in such areas could cause an explosion or fire
resulting in bodily injury or even death.
Users are advised to switch the phone off while at a
refueling point (service station). Users are reminded of the
need to observe restrictions on the use of radio equipment
in fuel depots (fuel storage and distribution areas),
chemical plants or where blasting operations are in
progress.
Emergency Calls
This phone, like any wireless phone, operates using radio
signals, wireless and landline networks as well as user
programmed functions, which cannot guarantee
connection in all conditions. Therefore, you should never
rely solely on any wireless phone for essential
communications (medical emergencies, for example).
Remember, to make or receive any calls the phone must
be switched on and in a service area with adequate signal
strength. Emergency calls may not be possible on all
wireless phone networks or when certain network services
and/or phone features are in use. Check with local service
providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location (for example, 911 or other official emergency
number). Emergency numbers vary by location.
3. Press [SEND].
If certain features are in use (call barring, for example),
you may first need to deactivate those features before you
can make an emergency call. Consult this document and
your local cellular service provider.
When making an emergency call, remember to give all the
necessary information as accurately as possible.
Remember that your phone may be the only means of
communication at the scene of an accident; do not cut off
the call until given permission to do so.
Restricting Children's access to your Phone
Health and safety information
35
Your phone is not a toy. Children should not be allowed to
play with it because they could
FCC Notice and Cautions
FCC Notice
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio
frequency energy and,f not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation.If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and
on, the user is encouraged to try to correct
theinterference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
The phone may cause TV or radio interference if used in
close proximity to receiving equipment. The FCC can
require you to stop using the phone if such interference
cannot be eliminated.
Vehicles using liquefied petroleum gas (such as propane or
butane) must comply with the National Fire Protection
Standard (NFPA-58). For a copy of this standard, contact
the National Fire Protection Association, One Battery
36
Health and safety information
march Park, Quincy, MA 02269, Attn: Publication Sales
Division.
Cautions
Changes or modifications made in the radio phone, not
expressly approved by Samsung, will void the user°Øs
authority to operate the equipment.
Only use approved batteries, antennas and chargers. The
use of any unauthorized accessories may be dangerous
and void the phone warranty if said accessories cause
damage or a defect to the phone.
Although your phone is quite sturdy, it is a complex piece
of equipment and can be broken. Avoid dropping, hitting,
bending or sitting on it.
Other Important Safety Information.
• Only qualified personnel should service the phone or
install the phone in a vehicle. Faulty installation or
service may be dangerous and may invalidate any
warranty applicable to the device.
• Check regularly that all wireless phone equipment in
your vehicle is mounted and operating properly.
• Do not store or carry flammable liquids, gases or
explosive materials in the same compartment as the
phone, its parts or accessories.
• For vehicles equipped with an air bag, remember that
an air bag inflates with great force. Do not place
objects, including both installed or portable wireless
equipment in the area over the air bag or in the air
bag deployment area. If wireless equipment is
improperly installed and the air bag inflates, serious
injury could result.
• Switch your phone off before boarding an aircraft. The
use of wireless phone in aircraft is illegal and may be
dangerous to the aircraft's operation.
• Failure to observe these instructions may lead to the
suspension or denial of telephone services to the
offender, or legal action, or both.
Product Performance
Getting the Most Out of Your Signal Reception
The quality of each call you make or receive depends on
the signal strength in your area. Your phone informs you
of the current signal strength by displaying a number of
Health and safety information
37
bars next to the signal strength icon. The more bars
displayed, the stronger the signal.
If you're inside a building, being near a window may give
you better reception.
Understanding the Power Save Feature
If your phone is unable to find a signal after 15 minutes of
searching, a Power Save feature is automatically
activated. If your phone is active, it periodically rechecks
service availability or you can check it yourself by pressing
any key.
Anytime the Power Save feature is activated, a message
displays on the screen. When a signal is found, your phone
returns to standby mode.
Understanding How Your Phone Operates
Your phone is basically a radio transmitter and receiver.
When it's turned on, it receives and transmits radio
frequency (RF) signals. When you use your phone, the
system handling your call controls the power level. This
power can range from 0.006 watts to 0.2 watts in digital
mode.
Maintaining Your Phone's Peak Performance
For the best care of your phone, only authorized personnel
should service your phone and accessories. Faulty service
may void the warranty.
There are several simple guidelines to operating your
phone properly and maintaining safe, satisfactory service.
• Hold the phone with the antenna raised, fully-
extended and over your shoulder.
• Try not to hold, bend or twist the phone's antenna.
• Don't use the phone if the antenna is damaged.
• Speak directly into the phone's receiver.
• Avoid exposing your phone and accessories to rain or
liquid spills. If your phone does get wet, immediately
turn the power off and remove the battery. If it is
inoperable, call Customer Care for service.
Availability of Various Features/Ring
Tones
Many services and features are network dependent and
may require additional subscription and/or usage charges.
Not all features are available for purchase or use in all
38
Health and safety information
areas. Downloadable Ring Tones may be available at an
additional cost. Other conditions and restrictions may
apply. See your service provider for additional information.
Battery Standby and Talk Time
Standby and talk times will vary depending on phone
usage patterns and conditions. Battery power
consumption depends on factors such as network
configuration, signal strength, operating temperature,
features selected, frequency of calls, and voice, data, and
other application usage patterns.
Battery Precautions.
• Never use any charger or battery that is damaged in
any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network's base station,
it uses less power; talk and standby time are greatly
affected by the signal strength on the cellular network
and the parameters set by the network operator.
• Battery charging time depends on the remaining
battery charge and the type of battery and charger
used. The battery can be charged and discharged
hundreds of times, but it will gradually wear out. When
the operation time (talk time and standby time) is
noticeably shorter than normal, it is time to buy a new
battery.
• If left unused, a fully charged battery will discharge
itself over time.
• Use only Samsung-approved batteries and recharge
your battery only with Samsung-approved chargers.
When a charger is not in use, disconnect it from the
power source. Do not leave the battery connected to a
charger for more than a week, since overcharging may
shorten its life.
• Extreme temperatures will affect the charging capacity
of your battery: it may require cooling or warming
first.
• Do not leave the battery in hot or cold places, such as
in a car in summer or winter conditions, as you will
reduce the capacity and lifetime of the battery. Always
try to keep the battery at room temperature. A phone
with a hot or cold battery may temporarily not work,
even when the battery is fully charged. Li-ion batteries
are particularly affected by temperatures below 0 °C
(32 °F).
Health and safety information
39
• Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object (coin, clip
or pen) causes a direct connection between the + and
- terminals of the battery (metal strips on the
battery), for example when you carry a spare battery
in a pocket or bag. Short-circuiting the terminals may
damage the battery or the object causing the short-
circuiting.
• Dispose of used batteries in accordance with local
regulations. In some areas, the disposal of batteries in
household or business trash may be prohibited. For
safe disposal options for Li-Ion batteries, contact your
nearest Samsung authorized service center. Always
recycle. Do not dispose of batteries in a fire.
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for many
years.
• Keep the phone and all its parts and accessories out of
the reach of small children.
• Keep the phone dry. Precipitation, humidity and liquids
contain minerals that will corrode electronic circuits.
• Do not use the phone with a wet hand. Doing so may
cause an electric shock to you or damage to the
phone.
• Do not use or store the phone in dusty, dirty areas, as
its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt certain
plastics.
• Do not store the phone in cold areas. When the phone
warms up to its normal operating temperature,
moisture can form inside the phone, which may
damage the phone's electronic circuit boards.
• Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the phone. Wipe it with a
soft cloth slightly dampened in a mild soap-and-water
solution.
• Do not paint the phone. Paint can clog the device's
moving parts and prevent proper operation.
40
Health and safety information
• Do not put the phone in or on heating devices, such as
a microwave oven, a stove or a radiator. The phone
may explode when overheated.
• When the phone or battery gets wet, the label
indicating water damage inside the phone changes
color. In this case, phone repairs are no longer
guaranteed by the manufacturer's warranty, even if
the warranty for your phone has not expired.
• If your phone has a flash or light, do not use it too
close to the eyes of people or animals. This may cause
damage to their eyes.
• Use only the supplied or an approved replacement
antenna. Unauthorized antennas or modified
accessories may damage the phone and violate
regulations governing radio devices.
• If the phone, battery, charger or any accessory is not
working properly, take it to your nearest qualified
service facility. The personnel there will assist you, and
if necessary, arrange for service.
E760-2.fm Page 40 Tuesday, August 21, 2007 5:05 PM
C
M
Y
CM
MY
CY
CMY
K
DoC.pdf 2007-05-21 오후 3:36:39DoC.pdf 2007-05-21 오후 3:36:39
M320L
