Samsung Electronics Co SGHP200 Single-Band PCS GSM/ EDGE Phone with WLAN User Manual
Samsung Electronics Co Ltd Single-Band PCS GSM/ EDGE Phone with WLAN Users Manual
Users Manual
* Depending on the software installed or your service provider or country,
some of the descriptions in this guide may not match your phone exactly.
* Depending on your country, your phone and accessories may appear
different from the illustrations in this guide.
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-xxxxxA
English (EU). 05/2006. Rev. 1.0
Draft
2006. 05. 17
SGH-P200
User’s Guide
Drive safely at all times
Do not use a hand-held phone while driving. Park the
vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using them in
an aircraft is both illegal and dangerous.
Switch off the phone near all medical equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or illegal.
1
Important safety precautions
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is forbidden
to use it, or when it may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear). Avoid
unnecessary contact with the antenna when the phone
is switched on.
Emergency calls
Key in the emergency number for your present
location, then press .
Keep your phone away from small children
Keep the phone and all its parts, including accessories,
out of the reach of small children.
Accessories and batteries
Use only Samsung-approved batteries and
accessories, such as headsets and PC data cables. Use
of any unauthorised accessories could damage you or
your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health and
safety information" on page 97.
• The phone could explode if the battery is replaced
with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.
At very high volumes, prolonged listening to a
headset can damage your hearing.
2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone. To quickly
learn the basics for your phone, please refer to “Get
started” and “Step outside the phone.”
In this guide, the following instruction icons appear:
Indicates that you need to pay careful attention
to the subsequent information regarding safety
or phone features.
Indicates that you can get more information on
the referenced page.
→
Indicates that you need to press the Navigation
keys to scroll to the specified option and then
select it.
[ ]
Indicates a key on the phone. For example, [ ].
< >
Indicates a soft key, whose function is displayed
on the phone screen. For example, <
Menu
>
• Wi-Fi (Wireless fidelity)
In available Wi-Fi zones, use high speed Internet,
Messaging, Call, and other network services.
Special
features of your phone
• Camera and camcorder
Use the camera module on your
phone to take a photo or record a
video.
• Music player
Play music files using your phone as
a music player.
3
Special features of your phone
• Photo printing
Print your photos to preserve your
best moments forever.
• Offline mode
Switch your phone to use its none-
wireless functions in an airplane.
•Web browser
Access the wireless web to get up-
to-the-minute information and a
wide variety of media content.
• Name card
Create name cards with your
number and profile. Whenever
introducing yourself to others, use
this convenient electronic name
card.
• Get personal with photo caller
ID
See who’s calling you when their
very own photo displays.
• Multimedia Message Service
(MMS)
Send and receive MMS messages
with a combination of text, image,
video, and audio.
•E-mail
Send and receive e-mails with
image, video, and audio
attachments.
•Java
Enjoy Java
™
-based embedded
games and download new games.
4
Contents
Unpack 6
Make sure you have each item
Your phone 6
Keys, features, and locations
Get started 7
First steps to operating your phone
Install and charge the phone ..................................... 7
Power on or off........................................................ 8
Keys and display ..................................................... 9
Access menu functions ............................................ 12
Use Shortcut icons .................................................. 13
Customise your phone............................................. 14
Make/Answer calls .................................................. 16
Step outside the phone 16
Begin with your camera, the music player, the web browser,
and other special features
Use the camera ...................................................... 16
Play music ............................................................. 17
Browse the web...................................................... 18
Use Address book ................................................... 19
Send messages ...................................................... 20
View messages....................................................... 22
Use Wi-Fi............................................................... 23
Enter text 24
ABC, T9, Number, and Symbol modes
Call functions 26
Advanced calling features
Menu functions 31
All menu options listed
Solve problems 95
Help and personal needs
Health and safety information 97
Index 104
5
1 Call history
p. 31
1 Recent contacts
2 Missed calls
3 Dialled calls
4 Received calls
5 Delete all
6 Call time
7 Call costs
*
p. 31
p. 31
p. 32
p. 32
p. 32
p. 32
p. 32
2 Address book
p. 33
1 Contact list
2 FDN contacts
*
3 Create contact
4 Group
5 Speed dial
6 My namecard
7 Own number
8 Management
9 Service number
*
p. 33
p. 34
p. 35
p. 36
p. 36
p. 37
p. 37
p. 37
p. 38
3 Settings
p. 38
1 Wi-Fi
2 Time and date
3 Phone settings
4 Display settings
5 Sound settings
6 Light settings
7 Network services
8 Security
9 Memory status
10 Reset settings
11 VOD settings
**
12 Key management
p. 38
p. 40
p. 40
p. 42
p. 43
p. 44
p. 45
p. 47
p. 49
p. 49
p. 49
p. 49
4 Camera
p. 50
1 Take photo
2 Record video
3 Go to My photos
4 Go to My video clips
p. 50
p. 53
p. 56
p. 56
5 Messaging
p. 56
1 Create new message
2 My messages
3 Templates
4 Delete list
5 Settings
6 Broadcast messages
7 Memory status
p. 56
p. 60
p. 64
p. 65
p. 65
p. 71
p. 72
6 Browser
p. 72
1 Home
2 Bookmarks
3 Enter URL
4 Clear cache
5 Profile settings
6 Current profile
p. 72
p. 73
p. 74
p. 74
p. 74
p. 75
7 Applications
p. 76
1 Music Player
2 Voice recorder
3 Image editor
4 Java world
5 SIM-AT
*
p. 76
p. 78
p. 79
p. 81
p. 82
8 Media album
p. 82
1 Images
2 Videos
3 Music
4 Sounds
5 Other files
6 Memory status
p. 83
p. 84
p. 85
p. 85
p. 86
p. 88
9 Planner
p. 88
1 Alarm
2 Calendar
3 World time
4 Calculator
5 Converter
6 Timer
7 Stopwatch
p. 88
p. 89
p. 93
p. 93
p. 94
p. 94
p. 94
* Shows only if supported by your
SIM card.
**
Shows only if supported by your
service provider.
Overview of menu functions
To access Menu mode, press <
Menu
> in Idle mode.
6
Unpack
Make sure you have each item
You can obtain various accessories from
your local Samsung dealer.
Phone Travel Adapter
Battery User’s Guide
The items supplied with your phone
and the accessories available at your
Samsung dealer may vary,
depending on your country or
service provider.
Your phone
Keys, features, and locations
7
Get started
First steps to operating your phone
SIM card information
When you subscribe to a cellular network, you receive
a plug-in SIM (Subscriber Identity Module) card
loaded with your subscription details, such as your
PIN, and available optional services.
Install and charge the phone
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the low battery message displays, and
• the empty battery icon blinks.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
Remove the battery.
If the phone is already
on, first turn it off by
pressing and holding
[].
Insert the SIM card.
Make sure that the gold-
coloured contacts on the
card are face down.
Install the battery. Plug the travel adapter
into the phone.
Plug the adapter into a standard AC wall outlet.
When the phone is completely charged (the battery
icon becomes still), unplug the adapter from the wall
outlet.
Remove the adapter from the phone.
8
Get started
Power on or off
Keypad lock
When you close the phone, the keypad lock feature
locks the exposed keys so that nothing will happen if
the keys are accidentally pressed.
To unlock the keypad, press <
Unlock
> and press
<
OK
>.
Offline mode
You can switch the phone to Offline mode, in which the
phone functions requiring network connection are
deactivated. This mode is helpful when you want to
use your phone in a place where you are not allowed
to use mobile devices, such as in an airplane and at a
hospital.
To switch to Offline mode, press <
Menu
> and select
Settings
→
Phone settings
→
Offline mode
→
On
.
In Offline mode, you can use non-wireless functions,
such as games, calendar, camera, and music player.
Switch on
Do not turn on
the phone when
mobile phone
use is prohibited.
1. Open the phone.
2. Press and hold [ ].
3. If necessary, enter the PIN and
press <
OK
>.
Switch off
1. Open the phone.
2. Press and hold [ ].
9
Get started
Keys and display
Keys
Soft keys
Perform the function indicated on the
bottom line of the display.
Navigation
keys
In Idle mode, press and hold to access your
favourite menus directly.
p. 40
In Menu mode, scroll through menu options.
Web
key
In Menu mode, select the highlighted menu
option or confirm input.
Send key
Make or answer a call.
In Idle mode, retrieve numbers recently
dialled, missed, or received.
C(Clear)
key
Delete characters from the display, or items
in an application.
End key
Press and hold to switch the phone on or
off.
End a call.
In Menu mode, cancel input and return the
phone to Idle mode.
Numeric
keys
Enter numbers, letters, and some special
characters.
In Idle mode, press and hold [
1
] to access
your voicemail server. Press and hold [
0
] to
enter an international call prefix.
Special
key
Enter special characters.
In Idle mode, press and hold [ ] to activate
or deactivate Silent mode. Press and hold
[ ] to enter a pause between numbers.
10
Get started
Display
Volume
key
Adjust the phone volume.
In Idle mode, with the phone open, adjust
the key tone volume. With the phone
closed, press and hold to turn on the
display.
Camera
key
In Idle mode, press and hold to turn on the
camera.
In Camera mode, take a photo or record a
video.
Layout
Text and graphics
display messages,
instructions, and
information you enter.
Soft key function
indicators
show the current functions
assigned to the soft keys.
Menu Contacts
Icons
display various icons.
11
Get started
Icons
*
Received signal strength
Call in progress
Out of your service area; you
cannot make or receive calls
Alarm set
p. 88
New text message
New multimedia message
New e-mail
New voicemail
Call diverting feature active
p. 45
Connected with a computer via a
USB port
GPRS network
EDGE network
Home Zone, if registered for the
appropriate service
Office Zone, if registered for the
appropriate service
Roaming network
Silent mode (Vibration)
Silent mode (Mute)
Mute mode, during a call
Ringer type
p. 43
•None: Melody
•: Vibration
• : Melody and vibration
• : Vibration then melody
•:
Melody then vibration
Battery power level
* Depending on your country or service provider, the icons
shown on the display may vary.
12
Get started
Access menu functions
Use the soft
keys
The roles of the soft keys vary
depending on the function you are
using. The bottom line of the display
indicates their current role.
Press the left
soft key to select
the highlighted
option.
Press the right
soft key to return
to the previous
menu level.
Select an
option
1. Press a desired soft key.
2. Press the Navigation keys to
move to the next or previous
option.
3. Press <
Select
> or [ ] to
confirm the function displayed
or option highlighted.
4. To exit, choose either of the
following methods.
•Press <
Back
> to move up
one level.
• Press [ ] to return to Idle
mode.
Use shortcuts
Press the number key corresponding
to the option you want. For the index
numbers 10, 11 and 12, press [
0
],
[], and
[]
, respectively.
13
Get started
Use Shortcut icons
In Idle mode, there are icons on the left side of the
display, which give you easy access to popular menus.
• To move among the Shortcut
icons, press [Up] or [Down].
• To open a menu window, press
[ ] or [Right].
• To highlight a menu or access a
highlighted menu, press [ ].
• To return to the previous menu
level, press [Left].
• To close a menu window, press
[].
Navigate
around the idle
screen
•: access the
Call history
menu.
p. 31
• : create new SMS or MMS
messages, or view the
messages you have received.
Create new message
p. 56
Inbox
p. 60
Email inbox
p. 63
•
:
access the calendar
features.
p. 89
•
:
access the Orange
homepage or other web
services.
Shortcut icons
14
Get started
Customise your phone
1. In Idle mode, press <
Menu
>
and select
Settings
→
Phone
settings
→
Language
.
2. Select a language.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Sound
settings
→
Incoming call
→
Ring tone
.
2. Select a ringtone category.
3. Select a ringtone.
4. Press <
Save
>.
Display
language
Call ringer
melody
You can set wallpaper for the idle
screen on the display.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Display
settings
→
Wallpaper
→
Wallpaper
.
2. Select an image category.
3. Select an image.
4. Press <
Save
>.
You can change the colour for the
display components, such as title
bars and highlight bars.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Display
settings
→
Skin
.
2. Select a colour pattern.
Idle mode
wallpaper
Menu mode
skin colour
15
You can set the Navigation keys to
function as shortcuts to access your
favourite menus.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Phone
settings
→
Shortcuts
.
2. Select a key.
3. Select a menu to be assigned to
the key.
You can switch the phone to Silent
mode to avoid disturbing other
people.
Press and hold [ ] in Idle mode.
Menu
shortcuts
Silent mode
You can protect the phone against
unauthorised use with a phone
password. The phone will require the
password on power-up.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Security
→
Change
password
.
2. Enter the default password,
00000000
, and press <
OK
>.
3. Enter a new 4- to 8-digit
password and press <
OK
>.
4. Enter the new password again
and press <
OK
>.
5. Select
Phone lock
.
6. Select
Enable
.
7. Enter the password and press
<
OK
>.
Phone lock
16
Make/Answer calls
Step outside the phone
Begin with your camera, the music player, the web
browser, and other special features
Use the camera
1. In Idle mode, enter an area
code and phone number.
2. Press [ ].
3. To end the call, press [ ].
1. When the phone rings, press
[].
2. To end the call, press [ ].
Press [ / ].
Make a call
Answer a call
Adjust the
volume during
a call
1. Open the phone.
2. In Idle mode, press and hold
[
]
to turn on the camera.
3. Aim the lens at the subject and
make any desired adjustments.
4. Press [ ] or [ ] to take a
photo. The photo is saved
automatically.
5.
Pres
s <
Back
> to
take another
photo.
1. In Idle mode, press <
Menu
>
and select
Media album
→
Images
→
My photos
.
2. Select the photo you want.
Take a photo
View a photo
17
Step outside the phone
Play music
1. In Idle mode, press and hold
[ ] to turn on the camera.
2. Press [
1
] to switch to Record
mode.
3. Press [ ] or [ ] to start
recording.
4. Press < > or [ ] to stop
recording. The video is saved
automatically.
5. Press < > to record another
video.
1.
In Idle mode, press <
Menu
>
and select
Media album
→
Videos
→
My video clips
.
2. Select the video you want.
Record a video
Play a video
Use these methods:
• Download from the wireless
web
p. 72
• Download from a computer
using the optional Samsung PC
Studio
Samsung PC Studio
User’s Guide
1. In Idle mode, press <
Menu
>
and select
Applications
→
Music Player
.
2. Press <
Options
> and select
Add music
.
3. Press [ ] to select the files you
want and press <
Add
>.
Copy music
files to the
phone
Create a play
list
18
Step outside the phone
Browse the web
Using a built-in web browser, you can easily access the
wireless web to get a variety of up-to-date services
and information and to download web content.
1. From the music player screen,
press [ ].
2. During playback, use the
following keys:
•: pauses or resumes
playback.
• Left: returns to the previous
file.
• Right: skips to the next file.
• Up: opens the play list.
• / : adjusts the volume.
• Down: stops playback.
Play music files
1. In Idle mode, press [Up] or
[Down] to scroll to the icon.
2. Select
Orange home
.
• To scroll through browser items,
press [Up] or [Down].
• To select an item, press < >
or [ ].
• To return to the previous page,
press [
C
].
• To return to the homepage.
press and hold [
C
].
• To access browser options,
select or press
[].
• To use other phone menus,
press [ ].
Launch the
web browser
Navigate the
web
19
Step outside the phone
Use Address book
To the phone’s memory:
1. In Idle mode, enter a phone
number and press <
Options
>
to select <
Save
>.
2. Select
Phone
→
New
→
a
number type.
3. Specify contact information:
First name, Last name, Mobile,
Home, Office, Fax, Other, Email,
Graphic ID, Ringtone, Group,
and Notes.
4. Press <
Options
> and select
Save
to save the contact.
Add a contact
To t he S IM car d:
1. In Idle mode, enter a phone
number and press <
Options
>
to select <
Save
>.
2. Select
SIM
.
3. Enter a name.
4. Press <
Options
> and select
<
Save
> to save the contact.
1. In Idle mode, press
<
Contacts
>.
2. Enter the first few letters of the
name you want.
3. Select a contact.
4. Scroll to a number and press
[]
to dial, or press [ ] to
edit contact information.
Find a contact
20
Step outside the phone
Send messages
1. In Idle mode, press <
Menu
>
and select
Address book
→
My
namecard
.
2. Specify your contact
information.
3. Press <
Options
> and select
Save
to save the name card.
4. To send the name card, press
<
Options
> and select
Send
via
→
a sending method.
Create and
send a name
card
1. In Idle mode, press [Up] or
[Down] to scroll to the icon.
2. Select
New SMS
.
3. Enter the message text.
4. Press <
Options
> and select
Save and send
or
Send only
.
5. Enter destination numbers.
6. Press [ ] to send the message.
1. In Idle mode, press [Up] or
[Down] to scroll to the icon.
2. Select
New MMS
.
3. Select
Subject
.
4. Enter the message subject and
press [ ].
Send a text
message (SMS)
Send a
multimedia
message
(MMS)
21
Step outside the phone
5. Select
Image or video
or
Sound
.
6. For
Image or video
, select
Add image
or
Add video
and
add an image or a video clip.
For
Sound
, select
Add sound
and add a sound clip.
7. Select
Text
.
8. Enter the message text and
press [ ].
9. Press <
Options
> and select
Send
.
10. Enter destination numbers or
addresses.
11. Press [ ] to send the message.
1. In Idle mode, press <
Menu
>
and select
Messaging
→
Create new message
→
Email
.
2. Select
Subject
.
3. Enter the e-mail subject and
press [ ].
4. Select
Message
.
5. Enter the e-mail text and press
[].
6. Select
File attach
.
7. Add image, video, sound, music
files, or document files.
8. Press <
Options
> and select
Send
.
9. Enter e-mail addresses.
10. Press [ ] to send the e-mail.
Send an e-mail
22
Step outside the phone
View messages
1. In Idle mode, press [Up] or
[Down] to scroll to the icon.
2. Select
Unread Message
.
3. Select an SMS message ( )
from the Inbox.
1. In Idle mode, press [Up] or
[Down] to scroll to the icon.
2. Select
Unread Message
.
3. Select an MMS message ( )
from the Inbox.
View a text
message
View a
multimedia
message
1. In Idle mode, press [Up] or
[Down] to scroll to the icon.
2. Select
Unread Email
.
3. Select
Check new mail
to
download new e-mails of
headers.
4. Select an e-mail or a header.
5. If you selected a header, press
<
Options
> and select
Retrieve
to view the body of
the e-mail.
View an e-mail
23
Step outside the phone
Use Wi-Fi
Your phone is equipped with the Wi-Fi (Wireless
Fidelity) technology, enabling you to access your
network by connecting to a Wi-Fi access point. You can
use the high speed Call, Messaging, Internet, and
other network features available in Wi-Fi zones.
In Idle mode, press <
Menu
> and
select
Settings
→
Wi-Fi
→
Preferences →
Wi-Fi preferred
.
1. In Idle mode, press
<
Menu
>
and select
Wi-Fi
→
Available
Networks
.
2. Selec an AP from the list.
3. If necessarry, enter the
password to be required for
connecting to the selected AP
and press
<
Save
>.
Activate the
Wi-Fi feature
Search for and
connec to an
AP
24
Enter text
ABC, T9, Number, and Symbol modes
You can enter text for some features, such as
Messaging, Address book, or Planner, using ABC
mode, T9 mode, Number mode, and Symbol mode.
Changing the text input mode
• Press and hold [ ] to switch between T9 mode
() and ABC mode ().
• Press [ ] to change case or switch to Number
mode ( ).
• Press and hold [ ] to switch to Symbol mode
().
Using ABC mode
Press the appropriate key until the character you want
appears on the display.
(Creating an SMS message with GSM-alphabet encoding)
Key Characters in order displayed
Upper case Lower case
25
Enter text
Other ABC mode operations
• To enter the same letter twice or to enter a
different letter on the same key, wait for the cursor
to move to the right automatically or press [Right].
Then, enter the next letter.
• Press [ ] to insert a space.
• Press the Navigation keys to move the cursor.
•Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the entire display.
Using T9 mode
T9 is a predictive text input mode that allows you to
key in any character using single keystrokes.
Entering a word in T9 mode
1. Press [
2
] to [
9
]
to start entering a word. Press
each key once for each letter.
For example, press [
4
], [
3
], [
5
], [
5
], and [
6
] to
enter Hello in T9 mode.
T9 predicts the word that you are typing, and it
may change with each key that you press.
2. Enter the whole word before editing or deleting
characters.
3. When the word displays correctly, go to step 4.
Otherwise, press [
0
] to display alternative word
choices for the keys that you have pressed.
For example, Of and Me use [
6
] and [
3
].
4. Press [ ] to insert a space and enter the next
word.
Other T9 mode operations
• Press [
1
] to enter periods or apostrophes
automatically.
• Press [ ] to insert a space.
• Press the Navigation keys to move the cursor.
• Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the entire display.
Adding a new word to the T9 dictionary
This feature may not be available for some languages.
1. Enter the word that you want to add.
2. Press [
0
] to display alternative words for your key
presses. When there are no more alternative
words,
Spell
appears on the bottom line.
26
3. Press <
Spell
>.
4. Enter the word you want using ABC mode and
press <
Add
>.
Using Number mode
Number mode enables you to enter numbers.
Press the keys corresponding to the digits you want.
Using Symbol mode
Symbol mode enables you to insert symbols.
Call functions
Advanced calling features
Making a call
1. In Idle mode, enter the area code and phone
number.
2. Press [ ].
3. When you want to end the call, press [ ].
Making an international call
1. In Idle mode, press and hold [
0
]. The
+
character
appears.
2. Enter the country code, area code, and phone
number, then press [ ].
To Press
display more symbols [Up] or [Down].
select a symbol the corresponding
number key.
clear the entered symbols [
C
].
insert the symbols <
OK
>.
• Press [
C
] to clear the last digit or press and
hold [
C
] to clear the entire display. You can
move the cursor to edit an incorrect digit.
• Press and hold [ ] to enter a pause between
numbers.
27
Call functions
Redialling recent numbers
1. In Idle mode, press [ ] to display the list of
recent numbers.
2. Scroll to the number you want and press [ ].
Making a call from Address book
Once you have stored a number in Address book, you
can dial the number by selecting it from Address
book.
p. 33
You can also use the speed dial feature to assign your
most frequently dialled numbers to specific number
keys.
p. 36
You can quickly dial a number from the SIM card using
its location number assigned when stored.
1. In Idle mode, enter a location number and press
[].
2. Press [Left] or [Right] to scroll through other
numbers.
3. Press <
Dial
> or [ ] to dial the number you want.
Answering a call
When you receive a call, the phone rings and displays
the incoming call image.
Press <
Accept
> or [ ] to answer the call.
Tips for answering a call
• When
Anykey
answer
is active, you can press
any key, except for <
Reject
> and [ ].
p. 42
• Press <
Reject
> or [ ] to reject a call.
• When
Up
in
Slide settings
is set to
Accept call
,
you can simply open the phone.
p. 40
• Press and hold [ / ] to reject a call or mute the
ringer, depending on the
Volume key
setting.
p. 41
Viewing missed calls
If you have missed calls, the icon displays how
many calls you have missed.
1. In Idle mode, press [Up] or [Down] to scroll to the
icon.
28
Call functions
2. Select
Missed calls
.
3. If necessary, scroll through the missed calls.
4. Press [ ] to dial the number you want.
Using the headset
Use the headset to make or answer calls without
holding the phone.
Connect the headset to the jack on the right side of
the phone. The button on the headset works as
follows:
Options during a call
You can access a number of functions during a call.
Adjusting the volume during a call
Use [ / ] to adjust the earpiece volume during a call.
Press [ ] to increase the volume level and [ ] to
decrease the volume level.
Placing a call on hold/Retrieving
Press <
Hold
> to place a call on hold, or press
<
Retrieve
> to retrieve the call.
Making a second call
You can make another call if your network supports
this function.
1. Press <
Hold
> to put the call on hold.
2. Make the second call in the normal way.
3. Press <
Swap
> to switch between the calls.
4. Press <
Options
> and select
End
held
call
to end
the call on hold.
5. To end the current call, press [ ].
To Press
redial the last call the button and then press
and hold it again.
answer a call and hold the button.
end a call and hold the button.
29
Call functions
Answering a second call
You can answer an incoming call while already on the
phone, if your network supports this function and you
have activated the call waiting feature.
p. 46
1. Press [ ] to answer the call. The first call is
automatically put on hold.
2. Press <
Swap
> to switch between the calls.
3. Press <
Options
> and select
End
held
call
to end
the call on hold.
4. To end the current call, press [ ].
Using the speakerphone feature
Use the phone as a speakerphone to talk and listen
with the phone a short distance away.
Press [ ] and then <
Yes
> to activate the
speakerphone feature. Press [ ] again to switch back
to the earpiece.
Using In-call options
Press <
Options
> to access the following options
during a call:
•
Voice clarity off
/
Voice clarity on
: remove
extraneous noise and increase call quality so that
the person with whom you are speaking can hear
you clearly even if you are in a noise place.
•
Mute
/
Unmute
: switch off the phone's microphone
so that the other person on the phone cannot hear
you, or switch it back on.
•
Mute keys
/
Send keys
: switch the key tones off
or on.
If you are using the speakerphone feature, you
must first deactivate it in order to use the Voice
Clarity feature.
To communicate with answering machines or
computerised telephone systems,
Send keys
must be selected.
30
Call functions
•
Phonebook
: access the contact list.
•
Send DTMF
: send the DTMF (Dual tone multi-
frequency) tones as a group. The DTMF tones are
the tones used in phones for tone dialling,
sounding when you press the number keys. This
option is helpful for entering a password or an
account number when you call an automated
system, like a banking service.
•
Message
: create and send an SMS message or
access received messages.
•
SIM service
: access special services, such as
news, weather forecasts, entertainment, and
location services, provided by your SIM card.
•
Transfer
: transfer the currently active call to a
caller on hold. The two callers can talk to each
other, but you are disconnected from the call.
•
End held call
: disconnect the call currently on
hold.
•
Join
: set up a multi-party call by adding a caller
on hold to a currently active call. You can include
up to 5 people on a multi-party call.
•
Split
: have a private conversation with the
selected participant. The other participants can
converse with each other. After the private
conversation, select
Join
to return both private
participants to the multi-party call.
•
Remove
: disconnect the selected participant.
31
Menu functions
All menu options listed
Call history
(Menu 1)
Use this menu to view the calls you have dialled,
received, or missed, and the length of the calls. You
can also check the cost of your calls,
if your SIM card
supports this function.
To access this menu, press <
Menu
> in Idle mode and
select
Call history
.
Recent contacts
(Menu 1.1)
This menu displays the most recent calls dialled,
received, or missed.
Missed calls
(Menu 1.2)
This menu displays the most recent calls you did not
answer.
Dialled calls
(Menu 1.3)
This menu displays the most recent calls you have
dialled.
Received calls
(Menu 1.4)
This menu displays the most recent calls you have
received.
Delete all
(Menu 1.5)
Use this menu to delete all of the records in each call
type.
Call time
(Menu 1.6)
This menu displays the time log for calls made and
received. The actual time invoiced by your service
provider will vary.
Call costs
(Menu 1.7)
This network feature displays the cost of calls. This
menu is available only if supported by your SIM card.
32
Menu functions
Address book
(Menu 2)
You can store phone numbers on your SIM card and in
your phone’s memory. The SIM card and phone’s
memory are physically separate but they are used as a
single entity called Address book.
To access this menu, press <
Menu
> in Idle mode and
select
Address book
.
Contact list
(Menu 2.1)
Use this menu to search for numbers in Address book.
FDN contacts
(Menu 2.2)
Use this menu to create a list of contacts to be used in
FDN (Fixed Dialling Number) mode, in which the
phone allows outgoing calls only to the specified
phone numbers, if your SIM card supports this
feature. You can activate FDN mode in the
FDN mode
menu.
p. 48
Create contact
(Menu 2.3)
Use this menu to add a new contact to Address book.
33
Menu functions
Address book
(Menu 2)
Group
(Menu 2.4)
Use this menu to organise your contacts in caller
groups.
Speed dial
(Menu 2.5)
Use this menu to assign a speed dial number (2 to 9)
for 8 of your most frequently dialled numbers.
My namecard
(Menu 2.6)
Use this menu to create a name card and send it to
other people.
Own number
(Menu 2.7)
Use this feature to check your phone numbers, or to
assign a name to each of the numbers. Changes made
here do not affect the actual subscriber numbers on
your SIM card.
Management
(Menu 2.8)
Use this menu to manage contacts in Address book.
Service number
(Menu 2.9)
Use this menu to view the list of Service Dialling
Numbers (SDN) assigned by your service provider,
including emergency numbers and numbers for
directory enquiries. This menu is available if your SIM
card supports SDN.
34
Menu functions
Settings
(Menu 3)
The
Settings
menu provides you with various setting
options to customise the phone to your preferences
and needs. You can also reset the settings to their
default status.
To access this menu, press <
Menu
> in Idle mode and
select
Settings
.
Wi-Fi
(Menu 3.1)
You can access your service provider’s network by
connecting to an access point (AP) via Wi-Fi in
available Wi-Fi zones.
With the Wi-Fi feature enabled, your phone connects
to an unlicensed wireless network within range of a
Wi-Fi zone. When you leave the Wi-Fi zone, the phone
automatically connects to a cellular network.
Time and date
(Menu 3.2)
Use this menu to change the time and date displayed
on your phone.
Phone settings
(Menu 3.3)
Many different features of your phone’s system can be
customised to suit your preferences.
35
Menu functions
Settings
(Menu 3)
Display settings
(Menu 3.4)
Use this menu to change settings for the display and
backlight.
Sound settings
(Menu 3.5)
Use this menu to customise various sound settings.
Light settings
(Menu 3.6)
Use this menu to change settings for the light.
Network services
(Menu 3.7)
Use this menu to access network services. Please
contact your service provider to check their availability
and subscribe to them, if you wish.
Security
(Menu 3.8)
Use this menu to protect the phone against
unauthorised use by managing the several access
codes of your phone and SIM card.
If you enter an incorrect PIN/PIN2 three times,
the SIM card is blocked. To unblock it, you need
to enter your PUK/PUK2 (Personal Unblocking
Key). The codes are supplied by your service
provider.
36
Menu functions
Memory status
(Menu 3.9)
Use this menu to check the amount of memory being
used for storing data in
Shared memory
,
Messaging
,
Media album,
Calendar
,
Address
book
, and
JAVA world
.
Reset settings
(Menu 3.10)
Use this menu to reset the phone’s settings you have
changed.
VOD Settings
(Menu 3.11)
Use this menu to select a connection profile to be used
for accessing a video streaming server. This menu may
not be shown depending on your service provider.
Key management
(Menu 3.12)
Use this menu to manage the licence keys you have
acquired to activate media contents locked by DRM
systems.
37
Menu functions
Camera
(Menu 4)
Camera
(Menu 4)
You can use the camera module embedded in your
phone to take photos and record videos.
To access this menu, press <
Menu
> in Idle mode and
select
Camera
, or press [].
Take photo
(Menu 4.1)
You can take photos in various modes. The camera
produces JPEG photos.
Record video
(Menu 4.2)
You can record a video of what is displayed on the
camera screen and save it.
Go to My photos
(Menu 4.3)
Use this menu to access a list of photos you have
taken.
p. 83
Go to My video clips
(Menu 4.4)
Use this menu to access a list of videos you have
recorded.
p. 84
Messaging
(Menu 5)
Use the
Messaging
menu to send and receive text
messages, multimedia messages, and e-mails. You
can also access push messages and cell broadcast
messages.
To access this menu, press <
Menu
> in Idle mode and
select
Messaging
.
Cr
eate new message
(Menu 5.1)
Use this menu to create and send messages.
My messages
(Menu 5.2)
• Do not take photos of people without their
permission.
• Do not take photos in a place where cameras are
not allowed.
• Do not take photos in a place where you may
interfere with another person’s privacy.
When you take a photo in direct sunlight or in bright
conditions, shadows may appear on the photo.
38
Menu functions
Use this menu to access messages you have received,
sent, or which have failed in sending.
Templates
(Menu 5.3)
Use this menu to make and use templates of
frequently used messages or passages.
Delete list
(Menu 5.4)
Use this menu to delete messages in each message
folder all at once.
Settings
(Menu 5.5)
Use this menu to set up various options for using the
message service.
Broadcast messages
(Menu 5.6)
The cell broadcast service delivers short messages on
various topics such as the weather or traffic.
Memory Status
(Menu 5.7)
Use this menu to view the number of messages or the
amount of memory currently in use of each message
type in each folder.
You can also access a message box by selecting it
from this menu.
39
Menu functions
Browser
(Menu 6)
Browser
(Menu 6)
The Wireless Application Protocol (WAP) browser on
your phone allows you to access the wireless web.
From the wireless web, you can access up-to-date
information and a wide variety of media content, such
as games, wallpapers, ringtones, and music files.
To access this menu, press <
Menu
> in Idle mode and
select
Browser
.
Home
(Menu 6.1)
Use this menu to connect your phone to the network
and load the homepage of the wireless web service
provider.
Bookmarks
(Menu 6.2)
Use this menu to save URL addresses in order to
quickly access web pages.
Enter URL
(Menu 6.3)
Use this menu to manually enter a URL address and
access the associated web page.
Clear cache
(Menu 6.4)
Use this menu to clear information stored in the cache,
which is the temporary memory that stores the web
pages you have recently accessed.
40
Menu functions
Profile settings
(Menu 6.5)
Use this menu to set up servers for the web browser.
Contact your service provider for details about your
settings options.
Current profile
(Menu 6.6)
Use this menu to activate one of the proxy servers you
have set up.
Applications
(Menu 7)
Use this menu to play music files, record voice
memos, play Java games, or edit photos.
To access this menu, press <
Menu
> in Idle mode and
select
Applications
.
Music Player
(Menu 7.1)
Use this menu to enjoy music. First, you need to save
music files into your phone’s memory.
41
Menu functions
Media album
(Menu 8)
Voice recorder
(Menu 7.2)
Use this menu to record voice memos. A voice memo
can be up to one hour long.
Image editor
(Menu 7.3)
Use this menu to edit your photos using an assortment
of editing tools.
Java world
(Menu 7.4)
Use this menu to access the embedded Java games
and downloaded Java applications.
SIM-AT
(Menu 7.5)
This menu is available if you use a SIM-AT card that
supports SIM Application Toolkit menus and provides
additional services, such as news, weather, sports,
entertainment, and location services. Available
services may vary, depending on your service
provider’s plans. For details, see your SIM card
instructions or contact your service provider.
Media album
(Menu 8)
The
Media album
menu allows you to access images,
videos, music files, and sound clips stored in the
phone’s memory.
To access this menu, press <
Menu
> in Idle mode and
select
Media album
.
Tips for Digital Rights Management
As a result of the Digital Rights Management (DRM)
system, some of the media items you download from
the Internet or receive by MMS may require a licence
key to access them.
You can acquire the key from the website which owns
the rights to the content; use the
Activate key
option.
Note the following icons on the list:
• : Forwardable item with a valid key.
• : Forwardable item without a valid key.
• : Unforwardable item with a valid key.
• : Unforwardable item without a valid key.
42
Menu functions
Your service provider supports only count-based or
unlimited-access DRM files.
Images
(Menu 8.1)
This menu displays photos you have taken and images
you have downloaded, or received in messages.
Videos
(Menu 8.2)
This menu displays video clips you have recorded,
downloaded, or received in messages.
Music
(Menu 8.3)
This menu displays music files you have downloaded.
Sounds
(Menu 8.4)
This menu displays voice memos you have recorded,
and sound clips you have downloaded, received in
messages, or imported from your computer.
Other files
(Menu 8.5)
Use this menu to view, without corruption, various
document files and files stored in the phone’s memory.
Available file formats are Microsoft Word, Adobe PDF,
Plain text, and so on.
Memory status
(Menu 8.6)
Use this menu to view memory information for media
items in the phone’s memory. You can also access a
media box by selecting it from this menu.
Video clips recorded on other devices, such as
camcorders, may not play correctly.
43
Menu functions
Planner
(Menu 9)
Planner
(Menu 9)
The
Planner
menu enables you to keep track of your
schedule. You can also use convenient features, such
as an alarm, world time, calculator, converter, timer,
and stopwatch.
To access this menu, press <
Menu
> in Idle mode and
select
Planner
.
Alarm
(Menu 9.1)
Use this menu to set alarms. The alert type for a
normal alarm corresponds to the call alert type
settings. A wake-up alarm is not affected by your
sound settings.
Calendar
(Menu 9.2)
Use this menu to keep track of your monthly schedule.
44
Menu functions
World time
(Menu 9.3)
Use this menu to find out the current time in another
part of the world.
Calculator
(Menu 9.4)
Use this menu to perform basic arithmetic functions,
such as addition, subtraction, multiplication, and
division.
45
Solve problems
Planner
(Menu 9)
Converter
(Menu 9.5)
Use this menu for common conversions, such as
currency and temperature.
Timer
(Menu 9.6)
Use this menu to set a period of time for the phone to
count down. The phone sounds an alarm when the
specified period of time expires.
Stopwatch
(Menu 9.7)
Use this menu to measure elapsed time. The
maximum time is 10 hours.
Solve problems
Help and personal needs
To save the time and expense of an unnecessary service
call, perform the simple checks in this section before
contacting a service professional.
When you switch on your phone, the following
messages may appear:
“Insert SIM”
• Be sure that the SIM card is correctly installed.
“Enter password”
• The automatic locking function has been enabled.
You must enter the phone’s password before you
can use the phone.
“Enter PIN”
• You are using your phone for the first time. You
must enter the PIN supplied with the SIM card.
• The PIN check feature is enabled. Every time the
phone is switched on, the PIN has to be entered.
To disable this feature, use the
PIN check
menu.
46
Solve problems
“Enter PUK”
• The PIN has been entered incorrectly three times
and the SIM card is now blocked. Enter the PUK
supplied by your service provider.
“No service,” “Network failure,” or “Not done”
displays
• The network connection has been lost. You may be
in a weak signal area. Move and try again.
• You are trying to access an option for which you
have no subscription with your service provider.
Contact the service provider for further details.
You have entered a number but it was not dialled
• Be sure that you have pressed [ ].
• Be sure that you have accessed the right cellular
network.
• Be sure that you have not set an outgoing call
barring option.
Your correspondent cannot reach you
• Be sure that your phone is switched on. ([ ]
pressed for more than one second.)
• Be sure that you are accessing the correct cellular
network.
• Be sure that you have not set an incoming call
barring option.
Your correspondent cannot hear you speaking
• Be sure that you have switched on the
microphone.
• Be sure that you are holding the phone close
enough to your mouth. The microphone is located
at the bottom of the phone.
The phone starts beeping and “Battery low”
flashes on the display
• Your battery is insufficiently charged. Recharge the
battery.
The audio quality of the call is poor
• Check the signal strength indicator on the display
( ). The number of bars indicates the signal
strength from strong ( ) to weak ( ).
• Try moving the phone slightly or moving closer to a
window if you are in a building.
47
Health and safety information
Planner
(Menu
No number is dialled when you re-call a Address
book entry
•Use the
Contact list
menu to ensure the number
has been stored correctly.
• Re-store the number, if necessary.
The battery does not charge properly or the
phone sometimes turns itself off
• Wipe the charging contacts both on the phone and
on the battery with a clean soft cloth.
If the above guidelines do not help you to solve
the problem, take note of:
• The model and serial numbers of your phone
•Your warranty details
• A clear description of the problem
Then contact your local dealer or Samsung after-sales
service.
Health and safety information
xposure to Radio Frequency (RF) Signals
Certification Information (SAR)
Your wireless phone is a radio transmitter and receiver.
It is designed and manufactured not to exceed the
exposure limits for radio frequency (RF) energy set by
the Federal Communications Commission (FCC) of the
U.S. government. These FCC exposure limits are
derived from the recommendations of two expert
organizations, the National Counsel on Radiation
Protection and Measurement (NCRP) and the Institute
of Electrical and Electronics Engineers (IEEE). In both
cases, the recommendations were developed by
scientific and engineering experts drawn from
industry, government, and academia after extensive
reviews of the scientific literature related to the
biological effects of RF energy.
48
Health and safety information
The exposure limit set by the FCC for wireless mobile
phones employs a unit of measurement known as the
Specific Absorption Rate (SAR). The SAR is a measure
of the rate of absorption of RF energy by the human
body expressed in units of watts per kilogram (W/kg).
The FCC requires wireless phones to comply with a
safety limit of 1.6 watts per kilogram (1.6 W/kg). The
FCC exposure limit incorporates a substantial margin
of safety to give additional protection to the public and
to account for any variations in measurements.
SAR tests are conducted using standard operating
positions accepted by the FCC with the phone
transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is
determined at the highest certified power level, the
actual SAR level of the phone while operating can be
well below the maximum value. This is because the
phone is designed to operate at multiple power levels
so as to use only the power required to reach the
network. In general, the closer you are to a wireless
base station antenna, the lower the power output.
When approval test is done, no Samsung supplied
accessories are avialable but maybe available later
after approval.
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that
it does not exceed the exposure limit established by
the FCC. Tests for each model phone are performed in
positions and locations (e.g. at the ear and worn on
the body) as required by the FCC.
The highest SAR values for this model phone as
reported to the FCC are: GSM900 Head:0.xxxW/Kg;
GSM1800 Head:0.xxxW/Kg; GSM1900 Head: 0.xxx
W/Kg, Body-worn: 0.xxx W/Kg.
For body worn operation, this model phone has been
tested and meets the FCC RF exposure guidelines
whenused with a Samsung accessory designated for
this product or when used with an accessory that
contains no metal and that positions the handset a
minimum of 1.5 cm from the body.
Non-compliance with the above restrictions may result
in violation of FCC RF exposure guidelines.
49
Health and safety information
Planner
(Menu
SAR information on this and other model phones can
be viewed on-line at www.fcc.gov/oet/fccid. This site
uses the phone FCC ID number, A3LSGHP200.
Sometimes it may be necessary to remove the battery
pack to find the number. Once you have the FCC ID
number for a particular phone, follow the instructions
on the website and it should provide values for typical
or maximum SAR for a particular phone. Additional
product specific SAR information can also be obtained
at www.fcc.gov/cgb/sar.
Consumer Information on Wireless Phones
The U.S. Food and Drug Administration (FDA) has
published a series of Questions and Answers for
consumers relating to radio frequency (RF) exposure
from wireless phones. The FDA publication includes
the following information:
What kinds of phones are the subject of this
update?
The term wireless phone refers here to hand-held
wireless phones with built-in antennas, often called
“cell,” “mobile,” or “PCS” phones. These types of
wireless phones can expose the user to measurable
radio frequency energy (RF) because of the short
distance between the phone and the user's head.
These RF exposures are limited by Federal
Communications Commission safety guidelines that
were developed with the advice of FDA and other
federal health and safety agencies. When the phone is
located at greater distances from the user, the
50
Health and safety information
exposure to RF is drastically lower because a person's
RF exposure decreases rapidly with increasing
distance from the source. The so-called “cordless
phones,” which have a base unit connected to the
telephone wiring in a house, typically operate at far
lower power levels, and thus produce RF exposures
well within the FCC's compliance limits.
Do wireless phones pose a health hazard?
The available scientific evidence does not show that
any health problems are associated with using
wireless phones. There is no proof, however, that
wireless phones are absolutely safe. Wireless phones
emit low levels of radio frequency energy (RF) in the
microwave range while being used. They also emit
very low levels of RF when in the stand-by mode.
Whereas high levels of RF can produce health effects
(by heating tissue), exposure to low level RF that does
not produce heating effects causes no known adverse
health effects. Many studies of low level RF exposures
have not found any biological effects. Some studies
have suggested that some biological effects may
occur, but such findings have not been confirmed by
additional research. In some cases, other researchers
have had difficulty in reproducing those studies, or in
determining the reasons for inconsistent results.
What is FDA's role concerning the safety of
wireless phones?
Under the law, FDA does not review the safety of
radiation-emitting consumer products such as wireless
phones before they can be sold, as it does with new
drugs or medical devices. However, the agency has
authority to take action if wireless phones are shown
to emit radio frequency energy (RF) at a level that is
hazardous to the user. In such a case, FDA could
require the manufacturers of wireless phones to notify
users of the health hazard and to repair, replace or
recall the phones so that the hazard no longer exists.
51
Health and safety information
Planner
(Menu
Although the existing scientific data do not justify FDA
regulatory actions, FDA has urged the wireless phone
industry to take a number of steps, including the
following:
• “Support needed research into possible biological
effects of RF of the type emitted by wireless
phones;
• “Design wireless phones in a way that minimizes
any RF exposure to the user that is not necessary
for device function; and
• “Cooperate in providing users of wireless phones
with the best possible information on possible
effects of wireless phone use on human health.
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at
the federal level. The following agencies belong to this
working group:
• “National Institute for Occupational Safety and
Health
• “Environmental Protection Agency
• “Federal Communications Commission
• “Occupational Safety and Health Administration
• “National Telecommunications and Information
Administration
The National Institutes of Health participates in some
interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless
phones with the Federal Communications Commission
(FCC). All phones that are sold in the United States
must comply with FCC safety guidelines that limit RF
exposure. FCC relies on FDA and other health agencies
for safety questions about wireless phones.
FCC also regulates the base stations that the wireless
phone networks rely upon. While these base stations
operate at higher power than do the wireless phones
themselves, the RF exposures that people get from
these base stations are typically thousands of times
lower than those they can get from wireless phones.
52
Health and safety information
Base stations are thus not the primary subject of the
safety questions discussed in this document.
What are the results of the research done
already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws in
their research methods. Animal experiments
investigating the effects of radio frequency energy
(RF) exposures characteristic of wireless phones have
yielded conflicting results that often cannot be
repeated in other laboratories. A few animal studies,
however, have suggested that low levels of RF could
accelerate the development of cancer in laboratory
animals. However, many of the studies that showed
increased tumor development used animals that had
been genetically engineered or treated with cancer-
causing chemicals so as to be pre-disposed to develop
cancer in absence of RF exposure. Other studies
exposed the animals to RF for up to 22 hours per day.
These conditions are not similar to the conditions
under which people use wireless phones, so we don't
know with certainty what the results of such studies
mean for human health.
Three large epidemiology studies have been published
since December 2000. Between them, the studies
investigated any possible association between the use
of wireless phones and primary brain cancer, glioma,
meningioma, or acoustic neuroma, tumors of the brain
or salivary gland, leukemia, or other cancers. None of
the studies demonstrated the existence of any harmful
health effects from wireless phones RF exposures.
However, none of the studies can answer questions
about long-term exposures, since the average period
of phone use in these studies was around three years.
What research is needed to decide whether RF
exposure from wireless phones poses a health
risk?
A combination of laboratory studies and
epidemiological studies of people actually using
wireless phones would provide some of the data that
are needed. Lifetime animal exposure studies could be
completed in a few years. However, very large
numbers of animals would be needed to provide
reliable proof of a cancer promoting effect if one
exists. Epidemiological studies can provide data that is
directly applicable to human populations, but ten or
53
Health and safety information
Planner
(Menu
more years' follow-up may be needed to provide
answers about some health effects, such as cancer.
This is because the interval between the time of
exposure to a cancer-causing agent and the time
tumors develop - if they do - may be many, many
years. The interpretation of epidemiological studies is
hampered by difficulties in measuring actual RF
exposure during day-to-day use of wireless phones.
Many factors affect this measurement, such as the
angle at which the phone is held, or which model of
phone is used.
What is FDA doing to find out more about the
possible health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology
Program and with groups of investigators around the
world to ensure that high priority animal studies are
conducted to address important questions about the
effects of exposure to radio frequency energy (RF).
FDA has been a leading participant in the World Health
Organization international Electromagnetic Fields
(EMF) Project since its inception in 1996. An influential
result of this work has been the development of a
detailed agenda of research needs that has driven the
establishment of new research programs around the
world. The Project has also helped develop a series of
public information documents on EMF issues.
FDA and Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative
Research and Development Agreement (CRADA) to do
research on wireless phone safety. FDA provides the
scientific oversight, obtaining input from experts in
government, industry, and academic organizations.
CTIA-funded research is conducted through contracts
to independent investigators. The initial research will
include both laboratory studies and studies of wireless
phone users. The CRADA will also include a broad
assessment of additional research needs in the
context of the latest research developments around
the world.
What steps can I take to reduce my exposure
to radio frequency energy from my wireless
phone?
If there is a risk from these products - and at this
point we do not know that there is - it is probably very
54
Health and safety information
small. But if you are concerned about avoiding even
potential risks, you can take a few simple steps to
minimize your exposure to radio frequency energy
(RF). Since time is a key factor in how much exposure
a person receives, reducing the amount of time spent
using a wireless phone will reduce RF exposure.
• “If you must conduct extended conversations by
wireless phone every day, you could place more
distance between your body and the source of the
RF, since the exposure level drops off dramatically
with distance. For example, you could use a
headset and carry the wireless phone away from
your body or use a wireless phone connected to a
remote antenna.
Again, the scientific data do not demonstrate that
wireless phones are harmful. But if you are concerned
about the RF exposure from these products, you can
use measures like those described above to reduce
your RF exposure from wireless phone use.
What about children using wireless phones?
The scientific evidence does not show a danger to
users of wireless phones, including children and
teenagers. If you want to take steps to lower exposure
to radio frequency energy (RF), the measures
described above would apply to children and
teenagers using wireless phones. Reducing the time of
wireless phone use and increasing the distance
between the user and the RF source will reduce RF
exposure.
Some groups sponsored by other national
governments have advised that children be
discouraged from using wireless phones at all. For
example, the government in the United Kingdom
distributed leaflets containing such a recommendation
in December 2000. They noted that no evidence exists
that using a wireless phone causes brain tumors or
other ill effects. Their recommendation to limit
wireless phone use by children was strictly
precautionary; it was not based on scientific evidence
that any health hazard exists.
Do hands-free kits for wireless phones reduce
risks from exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that hands-free kits reduce risks. Hands-free
kits can be used with wireless phones for convenience
55
Health and safety information
Planner
(Menu
and comfort. These systems reduce the absorption of
RF energy in the head because the phone, which is the
source of the RF emissions, will not be placed against
the head. On the other hand, if the phone is mounted
against the waist or other part of the body during use,
then that part of the body will absorb more RF energy.
Wireless phones marketed in the U.S. are required to
meet safety requirements regardless of whether they
are used against the head or against the body. Either
configuration should result in compliance with the
safety limit.
Do wireless phone accessories that claim to
shield the head from RF radiation work?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that accessories that claim to shield the head
from those emissions reduce risks. Some products
that claim to shield the user from RF absorption use
special phone cases, while others involve nothing
more than a metallic accessory attached to the phone.
Studies have shown that these products generally do
not work as advertised. Unlike “hand-free” kits, these
so-called “shields” may interfere with proper operation
of the phone. The phone may be forced to boost its
power to compensate, leading to an increase in RF
absorption. In February 2002, the Federal trade
Commission (FTC) charged two companies that sold
devices that claimed to protect wireless phone users
from radiation with making false and unsubstantiated
claims. According to FTC, these defendants lacked a
reasonable basis to substantiate their claim.
What about wireless phone interference with
medical equipment?
Radio frequency energy (RF) from wireless phones can
interact with some electronic devices. For this reason,
FDA helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted
cardiac pacemakers and defibrillators from wireless
telephones. This test method is now part of a standard
sponsored by the Association for the Advancement of
Medical instrumentation (AAMI). The final draft, a joint
effort by FDA, medical device manufacturers, and
many other groups, was completed in late 2000. This
standard will allow manufacturers to ensure that
56
Health and safety information
cardiac pacemakers and defibrillators are safe from
wireless phone EMI. FDA has tested wireless phones
and helped develop a voluntary standard sponsored by
the Institute of Electrical and Electronic Engineers
(IEEE). This standard specifies test methods and
performance requirements for hearing aids and
wireless phones so that no interference occurs when a
person uses a compatible phone and a compatible
hearing aid at the same time. This standard was
approved by the IEEE in 2000.
FDA continues to monitor the use of wireless phones
for possible interactions with other medical devices.
Should harmful interference be found to occur, FDA
will conduct testing to assess the interference and
work to resolve the problem.
Additional information on the safety of RF exposures
from various sources can be obtained from the
following organizations:
• FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
• Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
• Occupational Safety and Health Administration's
(OSHA):
http://www.osha.gov/SLTC/
radiofrequencyradiation/index.html
• National institute for Occupational Safety and
Health (NIOSH):
http://www.cdc.gov/niosh/emfpg.html
• World health Organization (WHO):
http://www.who.int/peh-emf/
• International Commission on Non-Ionizing
Radiation Protection:
http://www.icnirp.de
• National Radiation Protection Board (UK):
http://www.nrpb.org.uk
• Updated 4/3/2002: US food and Drug
Administration
http://www.fda.gov/cellphones
57
Health and safety information
Planner
(Menu
Road Safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime.
But an important responsibility accompanies the
benefits of wireless phones, one that every user must
uphold.
When driving a car, driving is your first responsibility.
When using your wireless phone behind the wheel of a
car, practice good common sense and remember the
following tips:
1. Get to know your wireless phone and its features,
such as speed dial and redial. If available, these
features help you to place your call without taking
your attention off the road.
2. When available, use a hands-free device. If
possible, add an additional layer of convenience
and safety to your wireless phone with one of the
many hands free accessories available today.
3. Position your wireless phone within easy reach. Be
able to access your wireless phone without
removing your eyes from the road. If you get an
incoming call at an inconvenient time, let your
voice mail answer it for you.
4. Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy
traffic or hazardous weather conditions. Rain,
sleet, snow, ice and even heavy traffic can be
hazardous.
5. Do not take notes or look up phone numbers while
driving. Jotting down a “to do” list or flipping
through your address book takes attention away
from your primary responsibility, driving safely.
6. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan calls when your car
will be stationary. If you need to make a call while
moving, dial only a few numbers, check the road
and your mirrors, then continue.
58
Health and safety information
7. Do not engage in stressful or emotional
conversations that may be distracting. Make
people you are talking with aware you are driving
and suspend conversations that have the potential
to divert your attention from the road.
8. Use your wireless phone to call for help. Dial 9-1-1
or other local emergency number in the case of
fire, traffic accident or medical emergencies.
Remember, it is a free call on your wireless phone!
9. Use your wireless phone to help others in
emergencies. If you see an auto accident, crime in
progress or other serious emergency where lives
are in danger, call 9-1-1 or other local emergency
number, as you would want others to do for you.
10. Call roadside assistance or a special non-
emergency wireless assistance number when
necessary. If you see a broken-down vehicle
posing no serious hazard, a broken traffic signal, a
minor traffic accident where no one appears
injured, or a vehicle you know to be stolen, call
roadside assistance or other special non-
emergency number.
“The wireless industry reminds you to use your
phone safely when driving.”
For more information, please call 1-888-901-SAFE, or
visit our web-site www.wow-com.com
Provided by the Cellular Telecommunications &
Internet Association
Operating Environment
Remember to follow any special regulations in force in
any area and always switch your phone off whenever it
is forbidden to use it, or when it may cause
interference or danger. When connecting the phone or
any accessory to another device, read its user's guide
for detailed safety instructions. Do not connect
incompatible products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation of
59
Health and safety information
Planner
(Menu
the equipment and for the safety of personnel, it is
recommended that the equipment should only be used
in the normal operating position (held to your ear with
the antenna pointing over your shoulder).
Using Your Phone Near Other Electronic
Devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against the
RF signals from your wireless phone. Consult the
manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be maintained
between a wireless phone and a pacemaker to avoid
potential interference with the pacemaker.
These recommendations are consistent with the
independent research and recommendations of
Wireless Technology Research.
Persons with pacemakers:
• should always keep the phone more than 15 cm
(6 inches) from their pacemaker when the phone is
switched on.
• should not carry the phone in a breast pocket.
• should use the ear opposite the pacemaker to
minimize potential interference.
If you have any reason to suspect that interference is
taking place, switch your phone off immediately.
Hearing Aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you
may wish to consult your hearing aid manufacturer to
discuss alternatives.
Other Medical Devices
If you use any other personal medical devices, consult
the manufacturer of your device to determine if it is
adequately shielded from external RF energy. Your
physician may be able to assist you in obtaining this
information. Switch your phone off in health care
facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care facilities
60
Health and safety information
may be using equipment that could be sensitive to
external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle. You should also
consult the manufacturer of any equipment that has
been added to your vehicle.
Posted Facilities
Switch your phone off in any facility where posted
notices require you to do so.
Potentially Explosive Environments
Switch your phone off when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause an
explosion or fire resulting in bodily injury or even
death.
Users are advised to switch the phone off while at a
refueling point (service station). Users are reminded of
the need to observe restrictions on the use of radio
equipment in fuel depots (fuel storage and distribution
areas), chemical plants or where blasting operations
are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas (such
as propane or butane), areas where the air contains
chemicals or particles, such as grain, dust or metal
powders, and any other area where you would
normally be advised to turn off your vehicle engine.
Emergency Calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well as
user programmed functions, which cannot guarantee
connection in all conditions. Therefore, you should
never rely solely on any wireless phone for essential
communications (medical emergencies, for example).
61
Health and safety information
Planner
(Menu
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not be
possible on all wireless phone networks or when
certain network services and/or phone features are in
use. Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location (for example, 911 or other official
emergency number). Emergency numbers vary by
location.
3. Press .
If certain features are in use (call barring, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult this document and your local cellular service
provider.
When making an emergency call, remember to give all
the necessary information as accurately as possible.
Remember that your phone may be the only means of
communication at the scene of an accident; do not cut
off the call until given permission to do so.
Restricting Children's access to your Phone
Your phone is not a toy. Children should not be allowed
to play with it because they could hurt themselves and
others, damage the phone or make calls that increase
your phone bill.
62
Health and safety information
FCC Notice and Cautions
FCC Notice
The phone may cause TV or radio interference if used
in close proximity to receiving equipment. The FCC
• This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
• This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses and
can radiate radio frequency energy and,
if not installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try
to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment
and receiver.
-Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV
technician for help.
63
Health and safety information
Planner
(Menu
can require you to stop using the phone if such
interference cannot be eliminated.
Vehicles using liquefied petroleum gas (such as
propane or butane) must comply with the National Fire
Protection Standard (NFPA-58). For a copy of this
standard, contact the National Fire Protection
Association, One Battery march Park, Quincy, MA
02269, Attn: Publication Sales Division.
Cautions
Changes or modifications made in the radio phone, not
expressly approved by Samsung, will void the user’s
authority to operate the equipment.
Only use approved batteries, antennas and chargers.
The use of any unauthorized accessories may be
dangerous and void the phone warranty if said
accessories cause damage or a defect to the phone.
Although your phone is quite sturdy, it is a complex
piece of equipment and can be broken. Avoid
dropping, hitting, bending or sitting on it.
Other Important Safety Information
• Only qualified personnel should service the phone
or install the phone in a vehicle. Faulty installation
or service may be dangerous and may invalidate
any warranty applicable to the device.
• Check regularly that all wireless phone equipment
in your vehicle is mounted and operating properly.
• Do not store or carry flammable liquids, gases or
explosive materials in the same compartment as
the phone, its parts or accessories.
• For vehicles equipped with an air bag, remember
that an air bag inflates with great force. Do not
place objects, including both installed or portable
wireless equipment in the area over the air bag or
in the air bag deployment area. If wireless
equipment is improperly installed and the air bag
inflates, serious injury could result.
• Switch your phone off before boarding an aircraft.
The use of wireless phone in aircraft is illegal and
may be dangerous to the aircraft's operation.
64
Health and safety information
• Failure to observe these instructions may lead to
the suspension or denial of telephone services to
the offender, or legal action, or both.
Product Performance
Getting the Most Out of Your Signal Reception
The quality of each call you make or receive depends
on the signal strength in your area. Your phone
informs you of the current signal strength by
displaying a number of bars next to the signal strength
icon. The more bars displayed, the stronger the signal.
If you're inside a building, being near a window may
give you better reception.
Understanding the Power Save Feature
If your phone is unable to find a signal after 15
minutes of searching, a Power Save feature is
automatically activated. If your phone is active, it
periodically rechecks service availability or you can
check it yourself by pressing any key.
Anytime the Power Save feature is activated, a
message displays on the screen. When a signal is
found, your phone returns to standby mode.
65
Health and safety information
Planner
(Menu
Understanding How Your Phone Operates
Your phone is basically a radio transmitter and
receiver. When it's turned on, it receives and transmits
radio frequency (RF) signals. When you use your
phone, the system handling your call controls the
power level. This power can range from 0.006 watts to
0.2 watts in digital mode.
Maintaining Your Phone's Peak Performance
For the best care of your phone, only authorized
personnel should service your phone and accessories.
Faulty service may void the warranty.
There are several simple guidelines to operating your
phone properly and maintaining safe, satisfactory
service.
• Hold the phone with the antenna raised, fully-
extended and over your shoulder.
• Try not to hold, bend or twist the phone's antenna.
• Don't use the phone if the antenna is damaged.
• Speak directly into the phone's receiver.
• Avoid exposing your phone and accessories to rain
or liquid spills. If your phone does get wet,
immediately turn the power off and remove the
battery. If it is inoperable, call Customer Care for
service.
Availability of Various Features/Ring
Tones
Many services and features are network dependent
and may require additional subscription and/or usage
charges. Not all features are available for purchase or
use in all areas. Downloadable Ring Tones may be
available at an additional cost. Other conditions and
restrictions may apply. See your service provider for
additional information.
Battery Standby and Talk Time
Standby and talk times will vary depending on phone
usage patterns and conditions. Battery power
consumption depends on factors such as network
configuration, signal strength, operating temperature,
66
Health and safety information
features selected, frequency of calls, and voice, data,
and other application usage patterns.
Battery Precautions
• Never use any charger or battery that is damaged
in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network's base
station, it uses less power; talk and standby time
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
• Battery charging time depends on the remaining
battery charge and the type of battery and charger
used. The battery can be charged and discharged
hundreds of times, but it will gradually wear out.
When the operation time (talk time and standby
time) is noticeably shorter than normal, it is time
to buy a new battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not in use,
disconnect it from the power source. Do not leave
the battery connected to a charger for more than a
week, since overcharging may shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling or
warming first.
• Do not leave the battery in hot or cold places, such
as in a car in summer or winter conditions, as you
will reduce the capacity and lifetime of the battery.
Always try to keep the battery at room
temperature. A phone with a hot or cold battery
may temporarily not work, even when the battery
is fully charged. Li-ion batteries are particularly
affected by temperatures below 0 °C (32 °F).
• Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object (coin,
clip or pen) causes a direct connection between the
+ and - terminals of the battery (metal strips on
the battery), for example when you carry a spare
67
Health and safety information
Planner
(Menu
battery in a pocket or bag. Short-circuiting the
terminals may damage the battery or the object
causing the short-circuiting.
• Dispose of used batteries in accordance with local
regulations. In some areas, the disposal of
batteries in household or business trash may be
prohibited. For safe disposal options for Li-Ion
batteries, contact your nearest Samsung
authorized service center. Always recycle. Do not
dispose of batteries in a fire.
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for
many years.
• Keep the phone and all its parts and accessories
out of the reach of small children.
• Keep the phone dry. Precipitation, humidity and
liquids contain minerals that will corrode electronic
circuits.
• Do not use the phone with a wet hand. Doing so
may cause an electric shock to you or damage to
the phone.
• Do not use or store the phone in dusty, dirty areas,
as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
68
Health and safety information
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the phone,
which may damage the phone's electronic circuit
boards.
• Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the phone. Wipe it with
a soft cloth slightly dampened in a mild soap-and-
water solution.
• Do not paint the phone. Paint can clog the device's
moving parts and prevent proper operation.
• Do not put the phone in or on heating devices,
such as a microwave oven, a stove or a radiator.
The phone may explode when overheated.
• When the phone or battery gets wet, the label
indicating water damage inside the phone changes
color. In this case, phone repairs are no longer
guaranteed by the manufacturer's warranty, even
if the warranty for your phone has not expired.
• If your phone has a flash or light, do not use it too
close to the eyes of people or animals. This may
cause damage to their eyes.
• Use only the supplied or an approved replacement
antenna. Unauthorized antennas or modified
accessories may damage the phone and violate
regulations governing radio devices.
• If the phone, battery, charger or any accessory is
not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
69
Index
A
ABC mode, text input • 24
Address book
adding • 35
deleting • 34, 37
finding • 33
managing • 37
options • 34
speed dialling • 36
Alarm • 88
Answering
call • 27
second call • 29
Anykey answer • 42
Auto redial • 42
B
Background image • 42
Backlight, set
display • 44
keypad • 44
Band selection • 47
Barring, calls • 45
Battery
charging • 7
low indicator • 8
precautions • 98
Broadcast messages • 61, 71
Browser, web • 72
C
Calculator • 93
Calendar • 88
Call costs • 32
Call log
dialled • 32
missed • 31
received • 32
Call time • 32
Calls
answering • 27
barring • 45
diverting • 45
holding • 28
redialling • 27
rejecting • 27
transferring • 30
waiting • 46
Camera
photos • 50
videos • 53
CB (Cell Broadcast) messages •
61, 71
Characters, enter • 24
Configuration messages • 60
Connection tone • 44
Converter • 94
Creating messages
e-mail • 59
MMS • 57
SMS • 56
D
Date, set • 40
Deleting
call log • 31
contacts • 34, 37
e-mail • 63, 65
events • 92
MMS • 61, 63, 65
SMS • 61, 63, 65
Dialled calls • 32
Dialling font, set • 43
Display
brightness • 43
icons • 11
language • 40
layout • 10
settings • 42
Diverting, calls • 45
Document files • 86
DRM (Digital Rights
Management) • 82
DTMF tones, send • 30
E
E-mails
creating/sending • 59
deleting • 63
setting • 68
viewing • 63
Emergency calls • 101
F
FDN (Fixed Dialling Number)
mode • 48
FDN contacts • 34
File viewer • 86
Flip tone • 43
70
Index
G
Games • 81
H
Health and safety • 97
Holding, call • 28
I
Icons, description • 11
Image editor • 79
Images, downloaded • 83
Inbox, messages
e-mail • 63
MMS/SMS • 60
International calls • 26
Internet • 72
J
Java applications • 81
K
Keypad tones
selecting • 43
sending/muting • 29
L
Language, select • 40
Last number, redial • 27
Light settings • 44
Locking
menu functions • 48
phone • 47
SIM card • 48
Low battery indicator • 8
M
Media album • 82
Memory status
Address book • 37
downloaded items • 88
file manager • 88
messages • 72
Message tone • 43
Messages
cell broadcast • 61, 71
e-mail • 59, 63
MMS • 57, 61
push • 61, 71
SMS • 56, 60
Minute minder • 44
Missed calls • 31
MMS messages
creating/sending • 57
deleting • 61
setting • 66
viewing • 60
Mobile tracker • 48
Multiparty-call • 30
Music player • 76
Music, downloaded • 85
N
Name card • 37
Names
entering • 24
searching • 33
Network band, select • 47
Network selection • 46
Network services • 45
Numbers
searching • 33
storing • 35
O
Offline mode • 42
Outbox, messages • 62
P
Password
call barring • 45
phone • 47
Phone
care and maintenance •
102
display • 10
icons • 10
locking • 47
password • 47
resetting • 49
switching on/off • 8
unpacking • 6
Photos
editing • 79
taking • 50
viewing • 83
PIN, change • 47
PIN2, change • 48
Power on/off tone • 43
Privacy • 48
Problems, solve • 95
Push messages • 61, 71
R
Received calls • 32
Received messages
e-mail • 63
MMS/SMS • 60
Recording
videos • 53
voice memos • 78
Redialling
71
Index
automatically • 42
manually • 27
Resetting phone • 49
Ringer
incoming calls • 43
messages • 43
Road safety • 99
S
Safety
information • 97
precautions • 3, 1
Security, calls • 47
Sent messages • 62
Shortcut • 40
Silent mode
entering • 15
setting • 44
SIM card
inserting • 7
locking • 48
Skin colour • 42
SMS messages
creating/sending • 56
deleting • 61
setting • 65
viewing • 60
Sound settings • 43
Sounds, downloaded • 85
Speakerphone • 29
Speed dial • 36
Stopwatch • 94
Switching on/off
microphone • 29
phone • 8
T
T9 mode, text input • 25
Templates, message • 64
Text, enter • 24
Time, set • 40
Timer • 94
V
Videos
playing • 84
recording • 53
Voice clarity • 42
Voice recorder
playing • 78
recording • 78
W
Waiting call • 46
Wallpaper • 42
Web browser
access • 72
bookmarks • 73
Wi-Fi • 38
World clock • 93
