Samsung Electronics Co SGHP207 Dual-Band GSM Phone User Manual
Samsung Electronics Co Ltd Dual-Band GSM Phone
Contents
- 1. Users Manual
- 2. Users Manual Addendum
Users Manual
SGH-p207 Series
P O R T A B L E T r i / D u a l - M o d e
T E L E P H O N E
User Guide
Please read this manual before operating your phone, and
keep it for future reference.
XA17.06_LMaxxx_010104_D1
Intellectual Property
All Intellectual Property, as defined below, owned by or which is other-
wise the property of Samsung or its respective suppliers relating to the
SAMSUNG Phone, including but not limited to, accessories, parts, or
software relating there to (the “Phone System”), is proprietary to Sam-
sung and protected under federal laws, state laws, and international
treaty provisions. Intellectual Property includes, but is not limited to,
inventions (patentable or unpatentable), patents, trade secrets, copy-
rights, software, computer programs, and related documentation and
other works of authorship. You may not infringe or otherwise violate
the rights secured by the Intellectual Property. Moreover, you agree that
you will not (and will not attempt to) modify, prepare derivative works
of, reverse engineer, decompile, disassemble, or otherwise attempt to
create source code from the software. No title to or ownership in the
Intellectual Property is transferred to you. All applicable rights of the
Intellectual Property shall remain with SAMSUNG and its suppliers.
Samsung Telecommunications America,
L.P.
U. S. Headquarters: Customer Care Center:
1301 East Lookout Drive 1601 E. Plano Parkway, Suite 150
Richardson, TX 75082 Plano, TX 75074
Tel: 972.761.7000 Toll Free Tel: 1.888.987.HELP (4357)
Fax: 972.761.7001 Fax: 972.801.6065
Internet Address: http://www.samsungusa.com
©2004 Samsung Telecommunications America, Inc. is a registered
trademark of Samsung Electronics America, Inc. and its related entities.
Licensed by Qualcomm Incorporated under one or more of the follow-
ing patents: U.S. Patent No. 4, 901, 307; 5, 056, 109; 5, 099, 204; 5,101,
501; 5, 103, 459; 5, 107, 225; 5, 109, 390.
Printed in South Korea
GH68-xxxxxA
Openwave® is a registered Trademark of Openwave, Inc.
RSA® is a registered TrademarSk RSA Security, Inc.
Disclaimer of Warranties; Exclusion of
Liability
EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CON-
TAINED ON THE WARRANTY PAGE ENCLOSED WITH THE
PRODUCT, THE PURCHASER TAKES THE PRODUCT "AS IS",
AND SAMSUNG MAKES NO EXPRESS OR IMPLIED WAR-
RANTY OF ANY KIND WHATSOEVER WITH RESPECT TO
THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE
MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS
FOR ANY PARTICULAR PURPOSE OR USE; THE DESIGN,
CONDITION OR QUALITY OF THE PRODUCT; THE PERFOR-
MANCE OF THE PRODUCT; THE WORKMANSHIP OF THE
PRODUCT OR THE COMPONENTS CONTAINED THEREIN;
OR COMPLIANCE OF THE PRODUCT WITH THE REQUIRE-
MENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT
PERTAINING THERETO. NOTHING CONTAINED IN THE
INSTRUCTION MANUAL SHALL BE CONSTRUED TO CRE-
ATE AN EXPRESS OR IMPLIED WARRANTY OF ANY KIND
WHATSOEVER WITH RESPECT TO THE PRODUCT. IN ADDI-
TION, SAMSUNG SHALL NOT BE LIABLE FOR ANY DAM-
AGES OF ANY KIND RESULTING FROM THE PURCHASE OR
USE OF THE PRODUCT OR ARISING FROM THE BREACH OF
THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPE-
CIAL OR CONSEQUENTIAL DAMAGES, OR LOSS OF ANTICI-
PATED PROFITS OR BENEFITS.
4
Table of Contents
Table of Contents
Important Safety Precautions....................................... 8
Section 1: Your Phone................................................. 10
Unpacking....................................................................................... 11
Illustration of Your Phone................................................................ 12
Command Keys.............................................................................. 14
Display Screen................................................................................. 16
Backlight.......................................................................................... 18
External Display............................................................................... 19
Camera............................................................................................ 19
Section 2: Getting Started........................................... 20
Installing the SIM card .................................................................... 21
Charging the Battery...................................................................... 24
Turning Your Phone on or off ........................................................ 26
Selecting Functions and Options.................................................. 27
Section 3: Call Functions ............................................ 30
Making a Call.................................................................................. 31
Answering a Call............................................................................. 33
Adjusting the Volume..................................................................... 34
Viewing Missed Calls ...................................................................... 34
Using the Call Log........................................................................... 36
Switching to Silent Mode................................................................ 41
Options During a Call..................................................................... 41
Section 4: Menu Navigation....................................... 48
Menu Navigation............................................................................ 49
Menu Outline................................................................................... 51
Section 5: Entering Text............................................... 56
Changing the Text Input Mode..................................................... 57
Using Alphabet Mode.................................................................... 58
Entering Numbers............................................................................ 59
Entering Symbols............................................................................. 59
Using T9 Mode................................................................................. 60
5Table of Contents
Section 6: Address Book............................................. 62
Adding a New Address Book Entry............................................... 63
Dialing a Number from Address Book .......................................... 66
Speed Dialing.................................................................................. 67
Finding an Entry in Address Book .................................................. 69
Editing a Caller Group.................................................................... 73
Checking the Memory Status........................................................ 74
Deleting Address Book Entries....................................................... 74
Section 7: Messaging.................................................. 76
Types of Messages.......................................................................... 77
Message Alerts................................................................................ 78
Creating and Sending New Messages......................................... 78
Retrieving New Messages.............................................................. 87
Viewing Messages .......................................................................... 88
Checking Voice Mails .................................................................... 96
Using Instant Messenger................................................................. 97
Changing Message Settings........................................................ 101
Checking Memory Status............................................................. 108
Deleting Messages........................................................................ 109
Section 8: Settings...................................................... 110
Changing Sound Settings ............................................................ 111
Changing Display Settings........................................................... 115
Changing Phone Settings............................................................ 118
Changing Connection Settings................................................... 121
Changing the Time and Date..................................................... 123
Changing Network Service Settings........................................... 126
Changing Security Settings.......................................................... 135
Resetting Settings.......................................................................... 138
Section 9: Multimedia ............................................... 140
Using the Camera......................................................................... 141
Using the Recorder....................................................................... 153
Playing Java Games .................................................................... 157
Section 10: WAP......................................................... 162
Launching the WAP Browser........................................................ 163
Accessing a WAP site................................................................... 163
Navigating the WAP Browser....................................................... 164
6
Table of Contents
Using Favorites............................................................................... 166
Downloading Media Content..................................................... 168
Clearing the Cache..................................................................... 170
Changing the Profile for Accessing the WAP............................ 171
Section 11: Personal Assistant.................................. 172
Using the Calendar....................................................................... 173
Using the To Do List ....................................................................... 177
Setting Alarms................................................................................ 180
Using the Calculator..................................................................... 183
Using the Currency Convertor..................................................... 184
Synchronizing PIM Data ............................................................... 185
Managing Your Phone................................................................. 188
Section 12: Additional Information.......................... 190
Accessories.................................................................................... 191
Access Codes............................................................................... 193
Section 13: Health and Safety Information............. 198
Exposure to Radio Frequency (RF) Signals................................. 199
For Body Operation...................................................................... 201
Precautions When Using Batteries............................................... 202
Road Safety................................................................................... 203
Operating Environment................................................................ 205
Electronic Devices........................................................................ 206
Potentially Explosive Environments ............................................. 208
Emergency Calls........................................................................... 209
Other Important Safety Information........................................... 210
Care and Maintenance .............................................................. 211
Acknowledging Special Precautions and the FCC and Industry
Canada Notice............................................................................. 212
Appendix A: CERTIFICATION INFORMATION (SAR).................... 214
Appendix B: Guide to Safe and Responsible Wireless Phone Use .
216
Appendix C: Consumer Update on Wireless Phones............... 220
STANDARD LIMITED WARRANTY................................................... 230
7Table of Contents
8
Important Safety Precautions
Read these guidelines before using your wireless phone.
Failure to comply with them may be dangerous or illegal.
Road Safety At All Times
Do not use a hand-held phone while driving; park the
vehicle first.
Switching Off When Refueling
Do not use the phone at a refueling point (service station) or
near fuels or chemicals.
Switching Off In An Aircraft
Wireless phones can cause interference. Using them in an
aircraft is both illegal and dangerous.
Switching Off Near All Medical Equipment
Switch off your phone near medical equipment. Hospitals or
health care facilities may be using equipment that could be
sensitive to external RF energy. Follow any regulations or
rules in force.
Interference
All wireless phones may be subject to interference, which
could affect their performance.
Special Regulations
Meet any special regulations in force in any area and always
switch off your phone whenever it is forbidden to use it, or
when it may cause interference or danger (in a hospital for
example).
Water Resistance
Your phone is not water-resistant. Keep it dry.
Important Safety Precautions
9
Sensible Use
Use only in the normal position (held to the ear). Avoid
unnecessary contact with the antenna when the phone is
switched on.
Emergency Call
Key in the emergency number for your present location,
then press the key. Give all necessary information as
accurately as possible. Do not end the call until given
permission to do so.
Keeping Small Children Away From Your Phone
Keep the phone and all its parts including accessories out of
the reach of small children.
Accessories and Batteries
Use only Samsung-approved accessories and batteries. Use
of any unauthorized accessories could damage your phone
and may be dangerous.
Use only Smsung-approved batteries and recharge your
battery only with Samsung-approved chargers.
Qualified Service
Only qualified service personnel may repair your phone.
For more detailed safety information, see “Health and
Safety Information” on page 198.
CAUTION
RISK OF EXPLOSION IF A BATTERY IS
REPLACED
BY AN INCORRECT TYPE.
DISPOSE USED BATTERIES ACCORDING TO
THE INSTRUCTIONS.
Section 1 : Your Phone
Section 1
10
Section 1: Your Phone
Topics Covered
• Unpacking
• Illustration of Your Phone
• Command Keys
• Display Screen
• Backlight
• External Display
• Camera
This section outlines some key features of your phone. It
also contains illustrations of the screen and the icons that
are displayed when the phone is in use.
Section 1 : Your Phone11
Unpacking
Your package contains the following items:
Your local Samsung dealer can provide you with additional
accessories including:
• Standard battery
• Simple hands-free car kit
• Cigarette lighter adapter
• Travel adapter
• Hand strap
• PC data link kit
• Ear microphone
Handset Travel Adapter
Battery User’s Manual
Section 1 : Your Phone
Section 1
12
Illustration of Your Phone
Open
Earpiece
Display
Power on/off/
Menu exit key
Soft key (left)
Navigation
(Up/Down/Left/
Right) keys
Cancel/
Correct key
WAP browser/
Menu confirm key
Special function
keys
Alphanumeric
keys
Microphone
Dial/Menu
confirm key
Camera key
Soft key (right)
Section 1 : Your Phone13
Closed
Headset jack
External display
Antenna
Camera key
Camera
Volume/Menu
browse keys
Service light
Command Keys
Section 1 : Your Phone
Section 1
14
Command Keys
(soft keys)
Performs the functions indicated by the screen
text on the bottom line of the display.
In Idle mode, allows you to access your favorite
menu options directly. For further details about
short cuts, see page 119.
When a menu is selected, the Up and Down keys
scroll through the menu options. The Left key
returns you to the previous menu level and the
Right key selects the highlighted menu option.
When entering text, moves the cursor.
In Idle mode, launches the WAP (Wireless
Application Protocol) browser.
In Menu mode, selects the highlighted menu
option or confirms your input.
In Idle mode, turns on the camera.
In Capture mode, takes a photo.
Makes or answers a call.
In Idle mode, when held down, recalls the last
number dialed, received, or missed.
In Menu mode, selects a menu option or stores
information that you have entered.
Section 1 : Your Phone15
Ends a call. Also switches the phone on and off
when held down.
In Menu mode, cancels your input and returns
the phone to Idle mode.
Deletes characters from the display.
In Menu mode, returns you to the previous menu
level.
In Idle mode, accesses your voice mail when held
down.
Enters numbers, letters, and some special
characters.
Enters special characters.
Performs various functions.
(on the right side of the phone)
In Idle mode, turns the camera on when held
down.
In Camera mode, takes a photo or records a
video.
(on the left side of the phone)
Adjusts the ringer volume when the phone is
ringing and the earpiece volume during a call.
In Idle mode, adjusts the keypad tone volume.
In Menu mode, scrolls through menu options.
Display Screen
Section 1 : Your Phone
Section 1
16
Display Screen
Layout
The display has 3 areas:
Icons
Shows the received signal strength. The greater the
number of bars, the stronger the signal.
Appears when you are out of your home area and
have logged onto a different network; for example,
when traveling in other countries.
Appears when you are connected to the GPRS
network.
Appears when a new text message has been received.
Appears when a new voice mail has been received.
Text and graphics
area
Menu Names
Icons
Soft key function
indicators
Display Screen
17 Section 1 : Your Phone
Appears when a new multimedia message has been
received.
Appears when both a new text message and a new
multimedia message have been received.
Appears when a new e-mail has been received.
Appears when a multimedia message is being sent.
Appears when you set an alarm to ring at a specified
time. For further details, see page 180.
Appears when you are out of your service area. When
it displays, you cannot make or receive calls.
Appears when a call is in progress.
Appears when you are connected to a WAP service.
Appears when the call forwarding feature is active.
For further details, see page 126.
Appears when you are in the Home Zone, if you have
subscribed to the appropriate service.
Appears when you are in the City Zone if you have
subscribed to the appropriate service.
Section 1 : Your Phone
Section 1
18
Backlight
The backlight illuminates the display and the keypad. When
you press any key or open the phone, the backlight comes
on. It goes off when no keys have been pressed within a
given period of time, depending on the setting in the Back
Light menu. For further details, see page 117.
Appears when Silent mode is active or you set the
phone to vibrate when you receive a call. For further
details, see page 41 and page 112 respectively.
Appears when Mute mode is active. For further
details, see page 43.
Appears when synchronization with a PC is in
progress.
Appears when synchronization with the remote
server is in progress.
Shows the level of your battery. The more bars you
see, the more power you have remaining.
External Display
19 Section 1 : Your Phone
External Display
Your phone has an external display on the front of the
phone. It indicates when you have an incoming call or a
message. It also alerts you at a specified time when you have
set an alarm. The backlight turns on and the corresponding
icon appears on the external display.
You can change the display type and the backlight time for
the external display in the Front LCD Display menu. For
further details, see page 116.
With the phone closed, you can take a photo using the
external display by pressing and holding the key on the
right side of the phone. See page 145.
Camera
The embedded camera module on the front of your phone
allows you to take a photo and record a video while on the
move.
For further details about the camera feature, see page 141.
Section 2 : Getting Started
Section 2
20
Section 2: Getting Started
Topics Covered
• Installing the SIM card
• Charging the Battery
• Turning Your Phone on or off
• Selecting Functions and Options
This section outlines how to get your phone ready to work.
You can get information on installing the SIM card and
battery, switching on the phone, and basic information on
selecting options and functions available on your phone.
Section 2 : Getting Started21
Installing the SIM card
When you subscribe to a cellular network, you are provided
with a plug-in SIM card loaded with your subscription
details, such as your PIN, any optional services available, and
so on.
Important!
• The plug-in SIM card and its contacts can be easily damaged by
scratches or bending, so be careful when handling, inserting, or
removing the card.
• Keep all SIM cards out of reach of small children.
To install the SIM card:
1. If necessary, switch off the phone by holding down the
key until the power-off image displays.
2. Remove the battery. To do so:
➀ Slide the battery lock toward the top of the phone and
hold it in that position.
➁ Lift the battery away, as shown.
Installing the SIM card
Section 2 : Getting Started
Section 2
22
3. Slide the SIM card into the SIM card socket, as shown,
so that the card locks into position.
Make sure the gold-colored contacts of the card face
down into the phone.
Note
: When you need to remove the SIM card, slide it upwards, as
shown, and take it out of the socket.
Installing the SIM card
23 Section 2 : Getting Started
4. Replace the battery so that the tabs on the end align with
the slots at the bottom of the phone.
5. Press the battery down until it clicks into place. Make
sure that the battery is properly installed before
switching on the power.
Section 2 : Getting Started
Section 2
24
Charging the Battery
Your phone is powered by a rechargeable Li-ion battery. A
travel charger comes with your phone for charging the
battery. Use only approved batteries and chargers. Ask your
local Samsung dealer for further details.
The travel charger allows you to use the phone while the
battery is charging, but this causes the phone to charge more
slowly.
Note
: You must fully charge the battery before using your phone
for the first time. A discharged battery recharges fully in
approximately 200 minutes.
To charge the battery:
1. With the battery in position on the phone, plug the
connector of the travel charger into the jack at the
bottom of the phone.
2. Plug the charger into a standard AC wall outlet.
Charging the Battery
25 Section 2 : Getting Started
3. When charging is finished, unplug the charger from the
power outlet and disconnect it from the phone by
pressing the buttons on both sides of the connector and
pulling the connector out.
Note
: You must unplug the charger before removing the battery
from the phone during charging; otherwise, the phone could be
damaged.
Low Battery Indicator
When the battery is weak and only a few minutes of talk
time remain, a warning tone sounds and a message repeats
at regular intervals on the display. In this case, your phone
will turn off the backlight to conserve the remaining battery
power.
When the battery level becomes too low, the phone
automatically turns off.
Section 2 : Getting Started
Section 2
26
Turning Your Phone on or off
Turning on Your Phone
1. Open the phone.
2. Press and hold the key until the power-on image
displays.
3. If the phone asks you to enter a password, enter it and
press the OK soft key or the key. The password is
preset to “00000000” at the factory. For further details,
see page 193.
4. If the phone asks for a PIN, enter the PIN and press the
OK soft key or the key. For further details, see page
194.
Once the phone is on, it searches for a network signal.
After locating a signal, the phone enters Idle mode. Now,
you can make and receive calls.
Note
: To change the display language, use the
Language
menu.
For further details, see page 118.
Turning off Your Phone
When you wish to switch off the phone, press and hold the
key until the power-off image displays.
Section 2 : Getting Started27
Selecting Functions and Options
Your phone offers a set of functions that allow you to use
and customize it. These functions are arranged in menus
and sub-menus, accessed using the two soft keys, and .
Each menu and sub-menu allows you to view and alter the
settings of a particular function.
Using the Soft Keys
The roles of the soft keys vary depending on the function
you are currently using; the labels on the bottom line of the
display just above each key indicate their current role.
Example:
Service Provider
07:30 AM
Mon May 31
Menu Names
Press the left soft key to
access Menu mode. Press the right soft key to
access the
Address
Book
menu.
Selecting Functions and Options
Section 2 : Getting Started
Section 2
28
Selecting Options
To view the various functions and options available and to
select the one you want:
1. Press the appropriate soft key.
Note
: When you access a list of options, your phone highlights the
currently active option. If, however, there are only two options, such as
On
/
Off
or
Enable
/
Disable
, your phone highlights the option that is
not currently active, so that you can select it directly.
2.
To Press the
select the:
• function displayed
• option highlighted
Select
soft key, Right key,
key, or key.
scroll through menus or
options Navigation keys or the
Volume keys on the left side
of the phone.
move back up one level in
the menu structure soft key, Left key, or
C
key.
exit the menu structure
without changing the
settings
key.
Section 2 : Getting Started29
Section 3 : Call Functions
Section 3
30
Section 3: Call Functions
Topics Covered
• Making a Call
• Answering a Call
• Adjusting the Volume
• Viewing Missed Calls
• Using the Call Log
• Switching to Silent Mode
• Options During a Call
This section outlines how to use your phone’s general call
functions, such as making and answering calls and using a
variety of options during a call.
Section 3 : Call Functions31
Making a Call
1. When the idle screen displays, enter the area code and
phone number.
2. Press the key to dial the number.
Note
: When you have activated the
Auto Redial
option in the
Extra Settings
menu, the phone will automatically redial up to 10
times if the person does not answer the call or is already on the
phone. For further details, see page 120.
Correcting the Number
Ending a Call
When you want to end your call, close the phone or press
the key.
To clear Press the
the last digit displayed
C
key.
any other digit in the
number Left or Right key until the cursor is
immediately to the right of the digit
to be cleared and press the
C
key.
You can also insert a missing digit
in the same way.
the whole display
C
key and hold it for more than one
second.
Making a Call
Section 3 : Call Functions
Section 3
32
Making an International Call
1. Press and hold the 0 key. The + character appears.
2. Enter the country code, area code, and phone number,
and press the key to dial the number.
Redialing the Last Number
The phone stores the numbers of the calls you’ve dialed,
received, or missed, if the call recipient or caller is identified.
For further details about the call log, see page 36.
In Idle mode, press and hold the key to redial the number
of the last call.
Making a Call from Address Book
You can store phone numbers that you use regularly on the
SIM card or in the phone’s memory. These entries are
collectively called Address Book.
Once you have stored a number in Address Book, you can
dial it by pressing a few keys. You can also assign your most
frequently-used numbers to number keys using the speed
dial feature.
For further details about the Address Book feature, see page
62.
Section 3 : Call Functions33
Answering a Call
When somebody calls you, the phone rings and displays an
incoming call image.
The caller’s phone number or name, if stored in Address
Book, displays.
1. If necessary, open the phone.
2. Press the key or the Accept soft key to answer the
incoming call.
When the Anykey Answer option in the Extra Settings
menu is activated, you can press any key to answer a call
except for the key and the Reject soft key. See page
119.
When the Active Folder option in the Extra Settings menu
is activated, you can simply open the phone to answer a
call.
Note
: To reject the call, press and hold the Volume keys before
opening the phone, or press the
Reject
soft key or the key.
3. End the call by pressing the key or closing the phone.
Note
: You can answer a call while using menu features. After
ending the call, the display returns to the function screen you were
using.
Section 3 : Call Functions
Section 3
34
Adjusting the Volume
During a call, if you want to adjust the earpiece volume, use
the Volume keys on the left side of the phone.
Press the key to increase the volume level and the key
to decrease the level.
In Idle mode, you can also adjust the keypad tone volume
using these keys.
Viewing Missed Calls
When you are unable to answer a call for any reason, you
can find out who called you.
The number of calls you’ve missed displays on the idle
screen immediately after a call is missed.
To view a missed call immediately:
1. If necessary, open the phone.
2. Press the View soft key or the key.
The number for the most recent missed call displays, if
available.
3.
To Press the
scroll through the missed
calls Up or Down key.
call the number displayed key.
edit or delete a missed call
number
Select
soft key or the key.
See the following sections.
Viewing Missed Calls
35 Section 3 : Call Functions
Editing a Missed Call Number
Note
: When the number for the missed call is not available, the
Edit
option does not display.
1. From the missed call view, press the Options soft key or
the key.
2. Select Edit.
3. Change the number.
Deleting a Missed Call
1. From the missed call view, press the Options soft key or
the key.
2. Select Delete.
You can press the key at any time to exit the missed call
feature.
Note
: You can access the missed call feature at any time by
selecting the
Missed Calls
menu. For further details, see page 36.
4.
To Press the
call the number key.
store the number
Save
soft key or the key and
enter a name and location. For
further details, see page 63.
Section 3 : Call Functions
Section 3
36
Using the Call Log
The phone stores the numbers of the calls you’ve dialed,
received, or missed, if the call recipient or caller is identified.
You can access these numbers from Idle mode or Menu
mode.
Note
: The number of call records the phone can store may vary,
depending on your SIM card.
Accessing the Call Log from Idle Mode
In Idle mode, press the key. A list of the most recent
numbers displays in the order you missed, dialed, or received
them.
T
oPress the
dial the number key or the key.
edit the number
Options
soft key and select
Edit
.
Change the number.
delete the number
Options
soft key and select
Delete
.
delete all of the numbers
on the Call Log list
Options
soft key and select
Delete All
. For details, see page
37.
Using the Call Log
37 Section 3 : Call Functions
Accessing Call Log from Menu Mode
Using the Recent Calls menu, you can view the calls you
have missed, received, or dialed.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Recent Calls and then select the type of calls you
want to view, either Missed Calls, Calls Received, or Calls
Made.
3. Select a call from the call log list.
The number or name, if available, displays together with
the time and date the call was missed, received, or dialed.
4. Press the key to dial the number.
By pressing the Options soft key or the key, you can
access the following options:
• Edit: allows you to edit the number, if available, and save it
in Address Book.
• Delete: deletes the call from the list.
5. When you have finished, press the key.
Deleting all Numbers in Call Log
You can delete all of the records in each call log separately.
You can also delete all of your call records at one time.
1. Access the call log list from Idle mode, press the Options
soft key and select Delete All.
Alternatively, enter the Recent Calls menu and select
Delete All.
Using the Call Log
Section 3 : Call Functions
Section 3
38
2. Scroll to the type of calls you want to delete and place a
check mark by pressing the key. Repeat this step to
select more call types.
To delete all of the records in the Call Log, select All
Calls.
3. Press the Delete soft key.
4. Press the Yes soft key or the key to confirm the
deletion.
5. When you have finished, press the key.
Viewing Call Times
You can check the length of your calls.
Note
: The actual time invoiced for calls by your service provider
may vary, depending on network features, such as rounding-off for
billing purposes.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Recent Calls → Call Time.
3. Scroll through the timers to check call times.
The following timers are available:
• Last Call: shows the length of the last call.
• Total Received: shows the total length of all calls you have
received since the timer was last reset.
• Total Made: shows the total length of all calls you have
made since the timer was last reset.
Using the Call Log
39 Section 3 : Call Functions
You can select Reset Timers to reset the call timers. You
must first enter the phone password and then press the
OK soft key or the key.
Note
: The password is preset to “00000000.” To change this
password, see page 136.
4. When you have finished, press the key.
Viewing Call Costs
You can check the cost of your calls. This feature may not be
available depending on your SIM card.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Recent Calls → Call Cost.
3. Scroll through the counters to check call costs.
The following counters are available:
• Last Call Cost: shows the cost of the last call you made.
• Total Cost: shows the total cost of all calls you have made
since the cost counter was last reset. If the total cost
exceeds the maximum cost set in the Set Max Cost option,
you can not make any calls until you reset the counter.
• Max Cost: shows the maximum cost set in the Set Max
Cost option.
In addition, you can use the following setting options:
• Reset Counters: allows you to reset the cost counters. You
must first enter your PIN2 (see page 195) and then press
the OK soft key or the key.
Using the Call Log
Section 3 : Call Functions
Section 3
40
• Set Max Cost: allows you to enter the maximum cost that
you authorize for your calls. You must first enter your
PIN2 (see page 195) and then press the OK soft key or the
key.
• Price/Unit: allows you to set the cost of one unit; this price
per unit is applied when calculating the cost of your calls.
You must first enter your PIN2 (see page 195) and then
press the OK soft key or the key.
4. When you have finished, press the key.
Section 3 : Call Functions41
Switching to Silent Mode
Silent mode is convenient when you wish to stop the phone
from making noise, in a theater for example.
In Idle mode, press and hold the key until the “Silent
Mode” message and the Vibration icon ( ) display.
In Silent mode, instead of making sounds, your phone will
vibrate, flash its light, or do nothing, depending on the
function and situation.
To exit and reactivate the previous sound settings, press and
hold the key again until “Exit Silent Mode” appears. The
Vibration icon no longer displays.
Note
: Activating Silent mode will not turn off the camera shutter
sound.
Options During a Call
Your phone provides a number of control functions that
you can use during a call.
Putting a Call on Hold
You can place the current call on hold whenever you want.
You can make another call while you have a call in progress
if your network supports this service.
To place a call on hold, simply press the Hold soft key. You
can reactivate the call whenever you want, by pressing the
Unhold soft key.
Options During a Call
Section 3 : Call Functions
Section 3
42
Making a Second Call
To make a call while you have a call in progress:
1. Enter the phone number that you wish to dial, or look it
up in Address Book.
2. Press the key to dial the second call.
The first call is automatically put on hold.
Alternatively,
1. Put the current call on hold by pressing the Hold soft key.
2. Make the second call in the normal way.
Answering a Second Call
You can answer an incoming call while you have a call in
progress, if this service is supported by the network and you
have set the Call Waiting menu to Activate; see page 130.
You are notified of an incoming call by a call waiting tone.
To answer a call while you have a call in progress:
1. Press the key to answer the incoming call. The first
call is automatically put on hold.
2. To switch between the two calls, press the Swap soft key.
3. To end a call on hold, press the Options soft key or the
key and select End Held Call.
To end the current call, press the key.
Options During a Call
43 Section 3 : Call Functions
Switching between Two Calls
When you have an active call and a call on hold, you can
switch between the two calls, activating the one on hold and
placing the other on hold.
To switch between the two calls, simply press the Swap soft
key.
The current call is placed on hold and the call on hold is
reactivated.
When you want to finish, end each call normally by pressing
the key.
Switching Off the Microphone (Mute)
You can temporarily switch off your phone’s microphone, so
that the other person cannot hear you.
Example: You wish to say something to person in the room,
but do not want the person on the phone to hear you.
To switch the microphone off temporarily:
1. Press the Options soft key or key.
2. Select Mute. The other person can no longer hear you.
To switch the microphone back on:
1. Press the Options soft key or key.
2. Select Unmute. The other person can hear you again.
Options During a Call
Section 3 : Call Functions
Section 3
44
Muting or Sending Key Tones
The Mute Keys and Send Keys options allow you to turn the
key tones off and on.
1. Press the Options soft key or key.
2. Select Mute Keys or Send Keys.
If the Mute Keys option is selected, your phone does not
transmit the DTMF (Dual Tone Multi-Frequency) tones
of the keys, which allows you to press keys without
hearing annoying key tones during a call.
To communicate with answering machines or
computerized telephone systems, the Send Keys option
must be selected.
Searching for a Number in Address Book
You can search for a number in Address Book during a call.
1. Press the Options soft key or key.
2. Select Address Book.
3. Enter the name that you wish to find.
The Address Book entries are listed starting with the
entry that most closely matches your input.
4. To view the highlighted entry, press the View soft key or
key.
For further details about the Address Book feature, see page
62.
Options During a Call
45 Section 3 : Call Functions
Making a Conference Call
A conference call is a network service that allows up to 6
people to take part simultaneously in a multi-party call.
For further details about subscribing to this service, contact
your service provider.
Setting Up a Conference Call
1. Call the first participant in the normal way.
Call the second participant in the normal way. The first
call is automatically put on hold.
2. To join the first participant to the conference call, press
the Options soft key or the key and select Join.
3. To add a new person to the conference call, call the new
person in the normal way and then press the Options soft
key or the key. Select Conference.
You can add incoming callers by answering the call and
pressing the Options soft key or the key, and selecting
Conference. Repeat as required.
Having a Private Conversation with One Participant
1. Press the Options soft key or the key and choose
Select One.
2. Highlight a person from the participant list by pressing
the Up or Down key, and press the Select soft key or the
key.
3. Select Private.
Now you can talk privately to that person. The other
participants can continue to converse with each other.
Options During a Call
Section 3 : Call Functions
Section 3
46
4. To return to the conference call, press the Options soft
key or the key and select Conference.
All of the conference call participants can now hear each
other.
Dropping One Participant
1. Press the Options soft key or the key and choose
Select One.
2. Highlight a person from the participant list by pressing
the Up or Down key, and press the Select soft key or the
key.
3. Select Remove.
The call with that participant ends, but you can continue
to talk to the other participants.
4. When you want to end the conference call, close the
phone or press the key.
Section 3 : Call Functions47
Section 4 : Menu Navigation
Section 4
48
Section 4: Menu Navigation
Topics Covered
• Menu Navigation
• Menu Outline
This section guides you through accessing the menu list to
use the functions available on your phone and gives you an
overview of the menu structure.
Section 4 : Menu Navigation49
Menu Navigation
Your phone offers a wide range of functions. These
functions are arranged in menus and sub-menus.
There are two ways to access a menu function.
• Navigating through the list
• Entering the shortcut number of the menu option
Navigating through the List
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Scroll using the Navigation keys to reach a main menu,
Settings for example. Press the Select soft key or the
key to enter the menu.
3. If the menu contains sub-menus, Phone Settings for
example, you can access them by scrolling using the Up
or Down key and pressing the Select soft key or the
key.
If the menu that you have selected contains further
options, repeat this step.
4. Scroll to an option and press the Select soft key or the
key to confirm the chosen setting.
Menu Navigation
Section 4 : Menu Navigation
Section 4
50
Using Shortcuts
The menu items, such as menus, sub-menus, and options are
numbered and can be accessed quickly by using their
shortcut numbers.
Simply press the Menu soft key and enter the number of the
menu you want.
Note
: The numbers assigned to each menu are indicated on the list
on page 51. They may not match the menu on your phone,
depending on the services supported by your SIM card.
Example: Accessing the Language menu.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Press the 9 key for Settings.
3. Press the 3 key for Phone Settings.
4. Press the 2 key for Language.
5. Scroll to an option and press the Select soft key or the
key to confirm the chosen setting.
Section 4 : Menu Navigation51
Menu Outline
The following list shows the menu structure and indicates
the number assigned to each option and the page where you
can find a description of each feature.
1. Recent Calls
(see page 36)
1.1 Missed Calls
1.2 Calls Received
1.3 Calls Made
1.4 Voice Mail
1.4.1 Connect to Voice Mail
1.4.2 Voice Mail Number
1.5 Delete All
1.6 Call Time
1.6.1 Last Call
1.6.2 Total Received
1.6.3 Total Made
1.6.4 Reset Timers
1.7 Call Cost
(dependant on the SIM card)
1.7.1 Last Call Cost
1.7.2 Total Cost
1.7.3 Max Cost
1.7.4 Reset Counters
1.7.5 Set Max Cost
1.7.6 Price/Unit
2. Messaging
(see page 76)
2.1 IM
2.2 Create
2.2.1 Text Message
2.2.2 Multimedia Message
2.2.3 Email
2.3 My Messages
2.3.1 Inbox
2.3.2 Email Inbox
2.3.3 Outbox
2.3.4 Draft
2.3.5 My Folders
2.4 Templates
Menu Outline
Section 4 : Menu Navigation
Section 4
52
2. Messaging
(continued)
2.5 Delete All
2.5.1 Inbox
2.5.2 Email Inbox
2.5.3 Outbox
2.5.4 Draft
2.6 Settings
2.6.1 IM
2.6.2 Text Message
2.6.3 Multimedia Message
2.6.4 Email
2.6.5 Push Message
2.6.6 Broadcast
2.7 Memory Status
2.7.1 Text Message
2.7.2 Multimedia Message
2.7.3 Email
3. Games
(see page 157)
3.1 Shop Games
4. Applications
(see page 172)
4.1 Alarm
4.1.1 Single Use Alarm
4.1.2 Daily Alarm
4.1.3 Wake-up Call
4.1.4 Remove Alarm
4.1.5 Autopower
4.2 Calendar
4.3 To Do List
4.4 Calculator
4.5 Currency Exchange
4.6 PIM Sync
4.6.1 Start Sync
4.6.2 View Result
4.6.3 Sync Settings
4.6.4 Profile
4.7 Device Management
4.7.1 Start DM
4.7.2 DM Settings
4.7.3 Profile
Menu Outline
53 Section 4 : Menu Navigation
5. MEdia Mall
(see page 168)
5.1 Shop Ringtones
5.2 Shop Games
5.3 Shop Graphics
5.4 Shop Multimedia
5.5 Shop Applications
5.6 MEdia Home
6. Multimedia
(see page 140)
6.1 Camera
6.1.1 Take Photos
6.1.2 Record Video
6.1.3 My Album
6.1.4 Delete All
6.1.5 Memory Status
6.2 Record Audio
6.2.1 Record
6.2.2 Audio List
6.2.3 Delete All
6.3 Memory Status
7. My MEdia
(see page 162)
7.1 MEdia Net
7.1.1 MEdia Net Home
7.1.2 Favorites Bookmark
7.1.3 http://
7.1.4 Settings
7.1.5 Clear Cache
7.2 Audio
7.3 Graphics
7.4 Delete All
8. Address Book
(see page 62)
8.1 Search
8.2 New Entry
8.3 Group Search
8.4 Group Edit
8.5 Speed Dial
8.6 Delete All
8.7 Own Number
8.8 Memory Status
Menu Outline
Section 4 : Menu Navigation
Section 4
54
9. Settings
(see page 110)
9.1 Sound Settings
9.1.1 Ring Tone
9.1.2 Ring Volume
9.1.3 Shop Ringtones
9.1.4 Alert Type
9.1.5 Keypad Tone
9.1.6 Message Tone
9.1.7 Folder Tone
9.1.8 Power On/Off
9.1.9 Alerts on Call
9.1.0 Extra Tones
9.2 Display Settings
9.2.1 Wallpaper
9.2.2 Front LCD Display
9.2.3 Shop Graphics
9.2.4 Menu Style
9.2.5 Back Light
9.2.6 Service Light
9.2.7 Graphic Logo
9.3 Phone Settings
9.3.1 Greeting Message
9.3.2 Language
9.3.3 Short Cut
9.3.4 Extra Settings
9.4 Connection Settings
9.5 Time & Date
9.5.1 Set Time
9.5.2 Set Date
9.5.3 World Time
9.5.4 Time Update
9.5.5 Auto Update
9.6 Network Services
9.6.1 Call Forwarding
9.6.2 Call Barring
(dependant on the SIM card)
9.6.3 Call Waiting
9.6.4 Network Selection
(dependant on the SIM card)
9.6.5 Caller ID
9.6.6 Closed User Group
(dependant on the SIM card)
9.6.7 Band Selection
Menu Outline
55 Section 4 : Menu Navigation
9. Settings
(continued)
9.7 Security
9.7.1 PIN Check
9.7.2 Change PIN
9.7.3 Phone Lock
9.7.4 Change Password
9.7.5 Privacy
9.7.6 SIM Lock
9.7.7 FDN Mode
9.7.8 Change PIN2
9.9 Reset Settings
Section 5 : Entering Text
Section 5
56
Section 5: Entering Text
Topics Covered
• Changing the Text Input Mode
• Using Alphabet Mode
• Entering Numbers
• Entering Symbols
• Using T9 Mode
When using your phone, you will often need to enter text,
such as when storing a name in Address Book, creating your
personal greeting, or scheduling events on your calendar.
This section gives you information about entering
alphanumeric characters by using your phone’s keypad.
Section 5 : Entering Text57
Changing the Text Input Mode
When you are in a field that allows characters to be entered,
you will notice the text input mode indicator on the display.
Example: Writing a text message
To select Press the right soft key until
Alphabet mode displays. See page 58.
Number mode
displays. See page 59.
Symbol mode the symbol list displays. See page 59.
T9 mode displays. See page 60.
Text input mode
indicator
Section 5 : Entering Text
Section 5
58
Using Alphabet Mode
Alphabet mode allow you to enter letters by pressing the key
labeled with the letter you want. Press the key once, twice,
three, or four times until the letter you want displays.
Entering a Word in Alphabet Mode
1. Press the key (1 to 0) labeled with the letter you want:
• Once for the first letter,
• Twice for the second letter, and so on
2. Select the other letters in the same way.
Note
: The cursor moves to the right when you press a key. When
entering the same letter twice or a different letter on the same key,
just wait for a few seconds for the cursor to move to the right
automatically, and then select the next letter. Or, press the Right
key to move the cursor immediately.
See the table below for available characters:
Entering Numbers
59 Section 5 : Entering Text
Tips for Using Alphabet Mode
• To insert a space, press the key.
• To shift case in Alphabet mode, use the key. There are
3 cases: Initial capital ( ), Capital lock ( ), and Lower
case ( ).
• You can move the cursor by using the Navigation keys. To
delete letters, press the C key. Press and hold the C key to
clear the display.
Entering Numbers
Number mode enables you to enter numbers. Press the key
corresponding to the digit you want to enter.
Entering Symbols
Symbol mode enables you to insert symbols and
punctuation marks.
To Press the
select a symbol corresponding number key.
display more symbols Up or Down key.
clear the symbol(s)
C
key.
insert the symbol(s) into your
message
OK
soft key or the key.
Section 5 : Entering Text
Section 5
60
Using T9 Mode
T9 mode allows you to enter words with only one keystroke
per letter. Each key on the keypad has more than one letter;
for example, pressing the 5 key can enter J, K, or L.
However, T9 mode automatically compares the series of
keystrokes you make with an internal linguistic dictionary to
determine the most likely word, thus requiring far fewer
keystrokes than the traditional Alphabet mode.
Entering a Word in T9 Mode
1. When you are in T9 mode, start entering a word by
pressing the 2 to 9 keys. Press each key only once for
each letter.
Example: To enter “Hello” in T9 mode, press the 4, 3, 5,
5, and 6 keys.
The word you are typing appears on the display. It may
change with each key that you press.
2. Enter the whole word before editing or deleting
keystrokes.
3. When the word displays correctly, go to step 4.
If the word doesn’t display correctly, press the 0 key or
the Up or Down key to display alternative word choices
for the keys that you have pressed.
Example: Both “Of” and “Me” use the 6 and 3 keys.
The phone displays the most commonly used choice
first.
4. Insert a space by pressing the key and start entering
the next word.
Using T9 Mode
61 Section 5 : Entering Text
Adding a New Word to the T9 Dictionary
If you cannot find the word you want, you can add the word
to the T9 dictionary for the next use.
1. After pressing the keys corresponding to the word you
want to add, press the 0 key or the Down key to display
the alternative words.
2. When there are no more alternative words, the display
shows Add on the bottom line. Press the Add soft key.
3. If necessary, clear the word using the C key and enter the
word you want to add using Alphabet mode. See page
58.
4. Press the OK soft key or the key.
The word is added to the T9 dictionary and becomes the
first word for the associated keypress series.
Tips for Using T9 Mode
• To enter periods, hyphens, or apostrophes, press the 1 key.
T9 mode applies grammar rules to ensure that correct
punctuation is used.
• To shift case in T9 mode, use the key. There are 3 cases:
Initial capital ( ), Capital lock ( ), and Lower case ( ).
• You can move the cursor by using the Left and Right keys.
To delete letters, press the C key. Press and hold the C key
to clear the display.
Section 6 : Address Book
Section 6
62
Section 6: Address Book
Topics Covered
• Adding a New Address Book Entry
• Dialing a Number from Address Book
• Speed Dialing
• Finding an Entry in Address Book
• Editing a Caller Group
• Checking the Memory Status
• Deleting Address Book Entries
This section gives you detailed information on using your
Address Book, which is a directory for storing and
managing your contact information. You can store phone
numbers and their corresponding names in both your SIM
card and your phone’s memory. They are physically separate
but are used as a single entity, Address Book.
Note
: Depending on your particular SIM card, the maximum
number of phone numbers the SIM card can store may differ.
Section 6 : Address Book63
Adding a New Address Book Entry
There are two ways to store a number:
• Using the Save soft key or the key in Idle mode
• Using the New Entry option in the Address Book menu
Storing a Number in Idle Mode
1. In Idle mode, enter the number you want to store.
Note
: If you make a mistake while entering a number, correct it
using the
C
key. For further details, see page 31.
2. When you are sure that it is correct, press the Save soft
key or the key.
3. Select an icon to identify the category in which the
number is to be stored. To select a category, press the
Left or Right key and press the Select soft key or the
key.
Three categories are available:
• : Mobile phone number
• : Office phone number
• : Home phone number
4. Select a memory location, either SIM Memory or Phone
Memory.
Note
: When you change phones, any numbers stored in your SIM
card are automatically available with the new phone, whereas any
numbers stored in the phone’s memory will need to be reentered.
Adding a New Address Book Entry
Section 6 : Address Book
Section 6
64
5. Enter a name and press the OK soft key or the key. For
further details about how to enter characters, see page
56.
To add the number to an existing name, select that name
from the list.
Storing a Number Using the New Entry Option
1. In Idle mode, press the Names soft key.
You can also press the Menu soft key to access Menu
mode and select Address Book.
2. Select New Entry.
3. Select an icon to identify the category of the number to
be stored by pressing the Left or Right key, and press the
Select soft key or the key.
Note
: The E-mail icon ( ) is available in this step. It allows you
to save an e-mail address instead of a phone number.
4. Select a memory location, either SIM Memory or Phone
Memory.
Note
: When you are saving an e-mail address, SIM Memory is not
available.
6.
To Press the
dial the number key or the key.
use the entry options
Options
soft key. For further
details, see page 70.
return to the idle screen key.
Adding a New Address Book Entry
65 Section 6 : Address Book
5. Enter a name and press the OK soft key or the key.
For further details about how to enter characters, see
page 56.
To add the number to an existing name, select that name
from the list.
6. Enter the number or address you want to store and press
the Save soft key or the key.
Storing Your Phone Number
You can store your own phone number(s) as a the memory
aid.
1. In Idle mode, press the Names soft key.
You can also press the Menu soft key to access Menu
mode and select Address Book.
2. Select Own Number.
3. Select the location in which you want to store a number.
4. Enter a phone number and press the OK soft key or the
key.
5. Enter a name and press the OK soft key or the key.
6. When you have finished, press the
key.
Section 6 : Address Book
Section 6
66
Dialing a Number from Address Book
Once you have stored phone numbers in Address Book, you
can dial them easily and quickly by using the location
numbers that were assigned to them in Address Book.
These numbers are assigned in the order in which they were
saved.
Note
: If you cannot remember a location number, you must go
into the
Search
option in the
Address Book
menu to search for
the entry by name. For details, see page 69.
Dialing a Number from the SIM Card
1. In Idle mode, enter the location number for the phone
number you want to dial and press the key.
2. You can press the Up or Down key to find other
numbers on the list.
3. Press the Dial soft key or the key when you have
selected the number you want.
Dialing a Number from the Phone’s Memory
1. In Idle mode, press and hold the 0 key. A + appears.
2. Enter the location number of the phone number you
want and press the key.
3. You can press the Up or Down key to find other
numbers on the list.
4. Press the Dial soft key or the key when you have
selected the number you want.
Section 6 : Address Book67
Speed Dialing
You can assign up to 8 phone numbers from Address Book
that you use most frequently to the number keys (2 to 9),
and then dial them easily whenever you want, simply by
pressing and holding the associated number key.
Setting Up Speed Dial Entries
1. In Idle mode, press the Names soft key.
You can also press the Menu soft key to access Menu
mode and select Address Book.
2. Select Speed Dial.
3. Select the key to which you wish to assign the speed
dialing number, from the 2 to 9 keys.
Note
: Memory location 1 is reserved for your voice mail server
number.
4. Select a name from the Address Book list.
5. Select a number, if the name has more than one.
The speed dial setting is saved.
6. When you have finished, press the key.
Speed Dialing
To quickly dial the numbers assigned to the 2 to 9 keys, press
and hold the appropriate key in Idle mode.
Speed Dialing
Section 6 : Address Book
Section 6
68
Changing a Number Assigned to a Key
1. In Idle mode, press the Names soft key.
You can also press the Menu soft key to access Menu
mode and select Address Book.
2. Select Speed Dial.
3. Select the key you want to change.
4. Press the Options soft key or the key, and select
Change.
5. Select a number to assign.
6. When you have finished, press the
key.
Deleting Speed Dial Entries
1. In Idle mode, press the Names soft key.
You can also press the Menu soft key to access Menu
mode and select Address Book.
2. Select Speed Dial.
3. Select the key whose number assignment you want to
delete.
4. Press the Options soft key or the key and select Delete.
If you want to delete all of the speed dial settings, select
Delete All.
5. Press the Yes soft key to confirm the deletion.
6. When you have finished, press the
key.
Section 6 : Address Book69
Finding an Entry in Address Book
After storing numbers in Address Book, you can search for
them in two ways: by name and by caller group.
Finding a Number by Name
1. In Idle mode, press the Names soft key.
You can also press the Menu soft key to access Menu
mode and select Address Book.
2. Select Search.
3. Enter the first few letters of the name.
The Address Book entries are listed, highlighting the
entry that most closely matches your input.
5. Once you have found the entry, press the key or the
key to dial the number.
Alternatively, press the Options soft key to access the
Address Book entry options. For further details, see the
next section.
4.
To Press the
view the highlighted entry
Select
soft key or the key.
select a different entry Up or Down key until the
entry you want highlights.
look for a name starting
with a different letter key labeled with the letter you
want.
Finding an Entry in Address Book
Section 6 : Address Book
Section 6
70
Using Address Book Entry Options
While accessing any Address Book entry, press the Options
soft key to access the options for the entry.
The following options are available:
Edit
:
allows you to edit the name and/or number.
Select One Entry to change the name and/or phone number
for the selected entry. If you change the name, the number is
saved separately with the new name.
Select All Entry to change only the name of the entry.
Send Message: allows you to send an SMS or MMS message
to the selected phone number. For details, see page 78 and
page 81 respectively.
If you have selected an e-mail address, you can send an
e-mail. For details, see page 84.
Multimedia Caller ID: allows you to assign a particular caller
ring tone and caller image to be played and displayed when
you receive a call from the selected number.
• Graphics: You can select a photo from the Photo Album
or an image from the Graphics folder, or take a new photo
using the camera. For details about using the camera, see
page 141. Once you have set an image for a caller or
group, if you want to view the caller ID image, select View.
• Video: You can select a video clip from the Photo Album
or record a new video using the camera. For details about
using the camera, see page 141. Once you have set a video
clip for a caller or group, if you want to view the video clip
for the caller ID, select View.
Finding an Entry in Address Book
71 Section 6 : Address Book
• Audio: You can select a ring tone from the default ringer
melodies or downloaded sound clips from the Audio
folder.
• Delete Caller ID: cancels the Caller ID settings for the
number.
Paste: allows you to paste the number into the normal
dialing mode. Use this option to dial a number similar to one
in Address Book, such as a different extension in the same
office. When you are ready to dial, press the key.
Delete: allows you to delete the selected number from
Address Book. You are asked to confirm that you wish to
delete the name and number by pressing the Yes soft key or
the key.
Copy: allows you to copy the number to another location.
You can select the memory location, either SIM or Phone,
and the location number.
Caller Group: allows you to organize your Address Book
entries in caller groups so that the phone alerts you in a
specific way when a person from one of your groups calls
you. Select one of 10 groups available.
To remove an entry from a group, select the No Group
option.
For further details about how to change caller group
properties, see page 73.
Add Entry: allows you to add a new number to the currently
selected name.
Finding an Entry in Address Book
Section 6 : Address Book
Section 6
72
Finding a Number by Caller Group
1. In Idle mode, press the Names soft key.
You can also press the Menu soft key to access Menu
mode and select Address Book.
2. Select Group Search.
3. Enter the first few letters of the group name.
The caller groups are listed, starting with the group that
most closely matches your input.
4. If necessary, scroll to a group by pressing the Up or
Down key and press the Select soft key or the key.
6. Once you have found the entry, press the key or the
key to dial the number.
Alternatively, press the Options soft key to access the
Address Book entry options; for further details, see page
70.
5.
To Press the
view the highlighted entry
View
soft key or the key.
select a different entry Up or Down key until the
entry you want highlights.
Section 6 : Address Book73
Editing a Caller Group
1. In Idle mode, press the Names soft key.
You can also press the Menu soft key to access Menu
mode and select Address Book.
2. Select Group Edit.
3. Find the group you want and press the Options soft key
or the key.
4. Select each option and change the settings, as you want.
The following options are available:
• Call Ring Tone: allows you to set a ring tone to be used
when you receive a voice call from a member of that
group.
• SMS Tone: allows you to set a ring tone to be used when
you receive a message from a member of that group.
• Graphic: allows you to set a graphic icon to be displayed
when you receive a voice call from a member of that
group.
• Group Name: allows you to assign a name to the group.
For further details about how to enter characters, see page
56.
5. When you have finished, press the key.
Section 6 : Address Book
Section 6
74
Checking the Memory Status
You can check how many names and numbers are stored in
Address Book, both in the SIM card and in the phone’s
memory. You can also see the capacity of both memories.
1. In Idle mode, press the Names soft key.
You can also press the Menu soft key to access Menu
mode and select Address Book.
2. Select Memory Status.
The display shows the number of entries you have saved
and the total number of entries you can save in each
memory. The sliding scale shows the proportion of
locations currently in use and free in each memory.
3. When you have finished, press the key.
Deleting Address Book Entries
You can delete entries in Address Book one by one, or all of
the entries in the selected memory or both memories.
Deleting an Address Book entry
1. In Idle mode, press the Names soft key.
You can also press the Menu soft key to access Menu
mode and select Address Book.
2. Select Search and then select a name.
3. Select a number, if the name has more than one number.
4. Press the Options soft key and then select Delete.
Deleting Address Book Entries
75 Section 6 : Address Book
5. Press the Yes soft key to confirm the deletion.
If there is only one number for the selected name, the
name is deleted.
If the name has more than one number, only the selected
number is deleted.
6. When you have finished, press the key.
Deleting all Entries
1. In Idle mode, press the Names soft key.
You can also press the Menu soft key to access Menu
mode and select Address Book.
2. Select Delete All.
3. Scroll to the memory you want to empty, All, SIM
Memory, or Phone Memory, and press the key to place
a check mark.
4. When you have finished marking, press the Delete soft
key to delete the entries in the selected memory
location(s).
5. Enter the phone password and press the OK soft key or
the key.
Note
: The password is preset to “00000000” at the factory. To
change this password, see page 136.
6. Press the OK soft key or the key to confirm the
deletion.
7. When you have finished, press the key.
Section 7 : Messaging
Section 7
76
Section 7: Messaging
Topics Covered
• Types of Messages
• Message Alerts
• Creating and Sending New Messages
• Retrieving New Messages
• Viewing Messages
• Checking Voice Mails
• Using Instant Messenger
• Changing Message Settings
• Checking Memory Status
• Deleting Messages
This section explains how to use your phone’s various
messaging functions, which allow you to send or receive
traditional text messages (SMS), multimedia messages
(MMS), voice mails, Cell Broadcast (CB) messages, and
e-mails. You can also have a conversation with other people
using Instant Messenger.
Section 7 : Messaging77
Types of Messages
You can use the following types of message services on your
phone:
• SMS (Short Message Service), which allows you to send
and receive traditional text messages, phone to phone. You
can also use EMS (Enhanced Message Service), which
allows you to send and receive enhanced SMS messages
containing simple pictures, melodies, and animated
images.
• MMS (Multimedia Message Service), which allows you to
send and receive multimedia messages containing images,
audio clips, video clips, and combinations of these items,
phone to phone, or phone to e-mail.
• Voice mail, which enables callers to leave messages for you,
if you cannot answer their calls for any reason (dependant
on your service provider).
• E-mail service, which allows you to send an e-mail and
view received e-mails on the phone.
• Instant Messaging (IM), which is a way of sending short,
simple messages that are delivered immediately to users
online at that moment.
You can also receive Cell Broadcast (CB) messages from
your service provider and push messages from the WAP
(Wireless Application Protocol) server.
Note
: Your phone is suited for messaging functions. However, if it
doesn’t work correctly, change the message settings according to
your service provider’s instructions.
Section 7 : Messaging
Section 7
78
Message Alerts
When you receive a new message, the phone alerts you by:
• Displaying a corresponding icon ( for SMS, for
MMS, for voice mail, and for e-mail).
• Displaying a notification message.
• Sounding a specified alert tone (see page 112).
Creating and Sending New Messages
This section guides you through the procedures for sending
various types of messages.
Creating and Sending a Simple Text Message
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Messaging → Create → Text Message. The Write
New screen appears.
3. Create your message.
For further details about entering characters, see page 56.
Note
: You can save the message in the
Draft
folder or one of the
folders in
My Folders
by pressing the
Options soft key and
selecting
Save
.
4. Press the key.
Creating and Sending New Messages
79 Section 7 : Messaging
5. Enter a destination number.
To add more destinations, press the OK soft key and
enter another number. You can add up to ?? destinations.
You can retrieve an entry or entry group from Address
Book by pressing the Options soft key. To delete the
selected number or group, select Delete Destination.
6. When you have finished, press the key to send it.
7. Press the Yes soft key or the key to confirm sending.
Creating and Sending an Enhanced Text
Message
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Messaging → Create → Text Message. The Write
New screen appears.
3. Create your message.
For more information about entering characters, see
page 56.
4. While entering the message text, press the Options soft
key to access the following options to enhance your
message:
• Add Entry: allows you to add a message template, an
Address Book entry, or a URL address from the Favorites
folder to the message text.
• Text Format: allows you to format the text style.
Creating and Sending New Messages
Section 7 : Messaging
Section 7
80
• Language: allows you to change the language to be used
in T9 input mode.
• Add Object: allows you to add one of a variety of default
media items, such as simple pictures, melodies, or
animated images. You can also add an Address Book entry
(vCard) and memos from Calendar (vCalendar).
Notes
:
• You can save the message in the
Draft
folder or one of the folders
in
My Folders
by pressing the
Options soft key and
selecting
Save
.
• When you add media items to a message, the number of
characters you can enter decreases.
5. Complete the message and follow the procedure from
step 5 on page 78.
Creating a Long Text Message
When you write a text
message, the phone automatically splits
it into several messages if your message exceeds the
maximum number of characters allowed for sending. The
number of split messages to be sent is shown each time your
message splits.
Creating and Sending New Messages
81 Section 7 : Messaging
Creating and Sending an MMS Message
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Messaging → Create → Multimedia Message.
3. Enter the subject of your message and press the Next
soft key or the key.
For further details about entering characters, see page 56.
4. When Add Here highlights, press the Options soft key or
the key and add message contents using one of the
following options:
• Add Text: enter the message text.
• Add My Photo: allows you to add an image or photo. You
can take a new photo or add one of the photos stored in
the phone’s memory. For further details about using the
camera, see page 141.
• Add My Video: allows you to add a video clip. You can
record a new video clip or add one of video clips stored in
the phone’s memory.
• Add Picture: allows you to add a picture. You can add an
image stored in the Graphics folder. You can add
downloaded images if they are in the correct format and
your service provider supports them.
• Add Sound: allows you to add a sound file. You can record
a new audio clip or add an existing audio clip, or select one
of sound clips stored in the Audio folder.
• Send: allows you to send the message.
• Save: saves the message to the Draft or Templates folder.
Creating and Sending New Messages
Section 7 : Messaging
Section 7
82
• Settings: allows you to change the message settings. For
further details about each setting option, see page 103.
After changing the settings, you need to press the soft
key or the C key to go to back to the message screen.
• Add Destination: allows you to enter destination numbers
or addresses. See steps 8 to 13. After adding them, you
need to press the soft key or the C key to go to back to
the message screen.
• Preview: shows the message you created.
Note
: You can add text, an image, a picture and a sound only once
for each page.
5. Repeat step 4 until you have finished creating your
message.
6. If you want to change the added items, scroll to the one
you want and press the Options soft key or the key.
The following options are available:
Note
: Available options vary depending on whether the item you
select on the message screen is text, an image, a sound, or the Page
field.
• Edit Text/Picture/Sound: allows you to change the text, or
exchange an image or sound for another one.
• Add Page: allows you to add more pages. After you add a
page, you can move to different pages using the Left or
Right key on the message screen. The display shows you
the current page number and the memory space used for
the page.
• Delete: deletes the item from your message.
Creating and Sending New Messages
83 Section 7 : Messaging
• Duration: allows you to set when and how long text, an
image, a sound, or a page displays on the message
presentation screen. If the duration you set is shorter than
the content duration (for example, the length of a sound
clip) for a particular page, the content duration is
automatically decreased.
• Send: allows you to send the message.
• Save: saves the message in the Draft or Templates folder.
• Settings: allows you to change the message settings. For
further details about each setting option, see page 103.
• Add Destination: allows you to enter destination
addresses. See steps 8 to 13.
• Preview: shows the message you created.
7. When you have finished creating the message, press the
Options soft key and choose Send.
8. Select a destination type, To, Cc, or Bcc.
9. Choose one of the following options:
• Phone Number: allows you to enter the phone number
you want.
• E-Mail Address: allows you to enter the e-mail address of
the recipient.
• Phone Book: allows you to retrieve an entry from Address
Book.
10.Enter a number or an e-mail address, or select an entry
from Address Book.
11.When the correct number or address displays, press the
OK soft key or the key.
Creating and Sending New Messages
Section 7 : Messaging
Section 7
84
12. To add another destination, select Add Destination and
repeat from step 9.
If you want to edit the destinations, select the one you
want. You can change or delete it.
13. To enter additional numbers or addresses to other
destination types, press the soft key or the C key and
repeat steps 8 through 12.
You can enter up to 10 destinations each for To, Cc, and
Bcc.
14. When you have finished entering destinations, select
Send.
Creating and Sending an E-mail
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Messaging → Create → Email.
3. Enter the subject of your e-mail and press the OK soft
key or the key.
For further details about entering characters, see page 56.
4. Enter the e-mail text and press the Options soft key or
the key.
The following options are available:
• Add Attachments: enables you to attach Address Book
entries, memos stored on your calendar, photos, videos,
pictures, or sounds.
Creating and Sending New Messages
85 Section 7 : Messaging
After selecting the file type you want to add, choose an
item from the list. You can add up to 9 items. After
adding, press the soft key or the C key to go back to the
e-mail screen.
If you want to remove an attached item, select
Attachment View and select it on the list. Press the
View soft key and then the Discard soft key.
• Send: sends the e-mail.
• Save: saves the e-mail in the Draft folder or one of the
folders defined in My Folders.
• Add Destination: allows you to add destination addresses.
See steps 6 to 10. After adding, press the soft key or C
key to go back to the e-mail screen.
• Information: shows the e-mail subject, the list of the
recipients you have added, if any, and message text.
5. When you have finished creating the e-mail, choose
Send.
6. Select a destination type, To, Cc, or Bcc.
7. Choose one of the following options:
• Direct Enter: allows you to directly enter the e-mail address
you want.
• Phone Book: allows you to retrieve an e-mail address from
Address Book.
• History: allows you to retrieve an e-mail address from the
messages you have sent or received.
8. Enter an e-mail address or select one from Address
Book.
9. To add more addresses, select To, Cc, or Bcc.
Creating and Sending New Messages
Section 7 : Messaging
Section 7
86
10. When there is an e-mail address already entered in the
selected destination type, select Add Destination. Repeat
from steps 7 and 8.
If you want to edit the destinations, select the one you
want. You can change or delete it.
11. When you are finished adding destinations, select Send E-
Mail. Your phone sends the e-mail.
Using Message Templates
You can create templates for your most commonly used
phrases, sentences, or message. You can then retrieve and
use them at will. You can change the templates at any time,
or send one as a message immediately.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Messaging → Templates. The template list
appears.
3. Select an empty location or a text template and press the
Options soft key to access the following options:
• Edit Message: allows you to add a new template or change
the selected template.
• Send Message: allows you to send an SMS message using
the template. For further details about sending SMS
message, see page 78.
• Delete: deletes the template you select or all of the
templates.
4. When you have finished, press the key.
Section 7 : Messaging87
Retrieving New Messages
While text messages from other phones are delivered
directly to your phone, MMS messages and e-mails will be
stored in the Inbox folder of the message server and the
server will alert you to their arrival. You will need to retrieve
new messages from the server to read them on the phone.
Retrieving an MMS Message
When a new MMS message comes in, the display shows the
MMS Message icon ( ) and a text notification, along with
the sender’s number.
1. Press the View soft key or the key to view brief
information about the message, such as the sender’s
number, the message size, and the subject.
If you want to view the message later, press the Exit soft
key.
2. Press the Options soft key or the key and select
Retrieve.
Your phone retrieves the message from the server and
displays it.
3. To scroll through the message, press the Up or Down
key.
4. When you have finished, press the key.
Viewing Messages
Section 7 : Messaging
Section 7
88
Retrieving an E-mail
When a new e-mail comes in, the display shows the E-mail
icon ( ) and a text notification.
1. Press the View soft key or the key to view e-mail
information.
2. Press the Options soft key or the key and select
Retrieve.
Your phone retrieves the new e-mails from the server
and displays them on the Email Inbox list.
3. To read an e-mail, select it on the list. For details, see the
next page.
4. When you have finished, press the key.
Viewing Messages
Your phone provides you with 4 message folders:
• Inbox: stores incoming SMS, MMS, CB, and WAP
messages.
• Email Inbox: stores incoming e-mails.
• Outbox: stores the messages and e-mails your phone has
failed to send.
• Draft: stores the messages and e-mails you have saved
without sending or attempting to send.
You can create up to 5 message folders to manage your
messages and e-mails. See page 94.
Viewing Messages
89 Section 7 : Messaging
Viewing a Message
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Messaging → My Messages and then select the
message folder you want. The message list opens.
The icons to the left of the message destination indicate
the message type ( for SMS, for MMS, and for
E-mail) and sending status ( for Sent for Unsent).
The icons to the right of the message subject indicates
the memory location ( for SIM and for Phone) and
the lock status ( for Locked and for Unlocked).
From the message list, you can access the following
options by pressing the Options soft key.
• Delete: allows you to delete the selected message.
• Delete All: allows you to delete all messages or selected
message(s) in the folder.
• Move: allows you to move the message from the phone’s
memory to the SIM card and vice versa. This option is
available for a SMS message.
3. Select a message on the list. The message content
displays.
For an MMS message, the display presents the message
and then switches to the message view screen.
4. Press the Up or Down key to scroll through the message
screen. For an MMS message, press the Left or Down
key to scroll to other pages, if the message has more than
one.
You can access the message options by pressing the
Options soft key. For details, see the next section.
Viewing Messages
Section 7 : Messaging
Section 7
90
5. Press the or key to move to the previous or next
message.
6. When you have finished, press the key.
Using Message Options
While viewing a message, press the Options soft key to
access the message options:
Note
: Depending on the status of the selected message, available
options vary.
Options for Incoming Messages
SMS Message
• Delete: deletes the message.
• Send: sends the message.
• Text Reply: allows you to send an message as your reply.
• Call Back: dials the number of the message.
• Cut Address: extracts the sender's number or address and
URL, e-mail addresses, and phone numbers from the
message text.
• Move to Phone: moves the message from the SIM card to
the phone’s memory.
• Move to SIM: moves the message from the phone’s
memory to the SIM card.
• Select Object: extracts media contents from the message
so that you can save them in the phone's memory.
Viewing Messages
91 Section 7 : Messaging
Multimedia Message
• Delete: deletes the message.
• Reply: allows you to send an message as your reply.
• Cut Address: extracts the sender's number or address and
URL, e-mail addresses, and phone numbers from the
message text.
• Call Back: dials the number of the message.
• Forward: sends the message to other destinations.
• Save Picture: extracts pictures from the message so that
you can save them in the phone's memory.
• Save Sound: extracts melodies from the message so that
you can save them in the phone's memory.
• Properties: shows information about the message.
MMS Notification
• Retrieve: retrieves the message from the message server.
• Delete: deletes the message.
• More Properties: shows information about the message,
including the validity period, MMS version, or content
location and so on.
E-Mail Message
• Delete: deletes the e-mail.
• Reply: allows you to send an e-mail as your reply.
• Forward: sends the e-mail to other destinations.
• Cut Address: extracts the sender's number or address and
URL, e-mail addresses, and phone numbers from the e-
mail text.
Viewing Messages
Section 7 : Messaging
Section 7
92
• Attachments: shows the files attached to the e-mail.
• Disconnect: disconnects the connection with the server.
• Properties: shows information about the e-mail.
E-Mail Header
• Retrieve: retrieves the entire e-mail from the e-mail server.
This option is shown with the e-mail header.
• Delete: deletes the e-mail.
• Disconnect: disconnects the connection with the server.
Options for Outgoing Messages
SMS Message
• Forward: (Sent) sends the message to another destination.
• Send Again: (Failed) resends the message to the specified
destination.
• Send: (Draft) sends the message.
• Cut Address: extracts the recipient’s number and URL, e-
mail addresses, or phone numbers from the message text.
• Delete: deletes the message.
• Lock/Unlock: locks the message to keep it from being
deleted or unlocks the message.
• Properties: shows information about the message.
MMS Message
• Forward: (Sent) sends the received message to another
destination.
• Send Again: (Failed) resends the sent message to the
specified destination.
Viewing Messages
93 Section 7 : Messaging
• Send: (Draft) sends the draft message.
• Cut Address: extracts the recipient’s number and URL, e-
mail addresses, or phone numbers from the message text.
• Delete: deletes the message.
• Lock/Unlock: locks the message to keep it from being
deleted or unlocks the message.
• Properties: shows information about the message.
E-mail
• Forward: (Sent) sends the e-mail to another destination.
• Send Again: (Failed) resends the e-mail to the specified
destination.
• Send: (Draft) sends the e-mail.
• Cut Address: extracts the recipient’s number and URL, e-
mail addresses or phone numbers from the text.
• Delete: deletes the message.
• Lock/Unlock: locks the message to keep it from being
deleted or unlocks the message.
• Properties: shows information about the e-mail.
Viewing Messages
Section 7 : Messaging
Section 7
94
Managing Your Own Message Folders
You can create up to 5 message folders to store messages
separately from the default message folders.
Creating a Message Folder
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Messaging → My Messages.
3. From the message folder list, highlight My Folders and
press the Options soft key.
4. Select Create Folder.
5. Enter a folder name and press the OK soft key or the
key.
6. When you have finished, press the key.
Renaming a Message Folder
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Messaging → My Messages → My Folders. The list
of message folders you have defined opens.
3. Scroll the folder you want to rename.
4. Press the Options soft key and select Rename Folder.
5. Clear the current name and enter a new name.
6. Press the OK soft key or the key.
7. When you have finished, press the key.
Viewing Messages
95 Section 7 : Messaging
Deleting a Message Folder
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Messaging → My Messages → My Folders. The list
of message folders you have defined opens.
3. Scroll the folder you want to delete.
4. Press the Options soft key and select Delete Folder.
5. Press the OK soft key or the key to confirm the
deletion.
6. If the phone asks if you want to delete protected
messages, press the OK soft key or the key.
7. When you have finished, press the key.
Section 7 : Messaging
Section 7
96
Checking Voice Mails
You can access your voice mailbox, if this service is
provided by your network.
Accessing the Voice Mailbox
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Recent Calls → Voice Mail → Connect to Voice
Mail → Voice Mail. Your phone dials the specified
number of the voice mail center.
3. When connected, follow the voice prompts from the
voice mail center.
Changing the Voice Mail Number
Your SIM card gives you the service number of the voice
mail center by default. However, you may need to change
the number.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Recent Calls → Voice Mail → Voice Mail Number
→ Voice Mail. The current number displays.
3. Press the Edit soft key or the key.
4. Enter a new number and press the OK soft key or the
key.
5. When you have finished, press the key.
Section 7 : Messaging97
Using Instant Messenger
Instant Messenger (IM) is a way of sending short, simple
messages that are delivered immediately to users online at
that moment.
Before using this feature, you need to subscribe to a
messenger service. For further details, contact your service
provider.
Note
: By default, your phone is suited for using your service
provider’s messenger service. You can change the default
community. See page 101.
Starting Your Messenger
1. In Idle mode, press the Menu soft key to access Menu
mode.
1. Select Messaging → IM → Sign On. You are logged into
the default community.
2. Select Buddy List. The subscribers of the messenger
service displays.
3. Select the person you want to talk to.
4. Start the conversation with the person by writing a
message and pressing the key to send it.
During a conversation, you can access the following
options by pressing the Options soft key.
• Send: sends the entered message.
• Template: allows you to add a template into your message.
Using Instant Messenger
Section 7 : Messaging
Section 7
98
• Emoticon: allows you to add an emoticon into your
message.
• Save Conversation: saves your conversation so that you
can view the conversation offline.
• End Conversation: ends the current conversation.
• Go To Contact List: shows the list of the contacts.
• Add Buddy: allows you to add the current contact to your
IM contact list.
• Block IM: blocks a message from the currently selected
contact.
• Exit: exits the option list.
5. To end the conversation, press the Options soft key and
select End Conversation.
To disconnect from the community, press the Options
soft key and select Sign Off.
Using Instant Messenger
99 Section 7 : Messaging
Using the Buddy List
On the conversation screen online, select Buddy List to open
the list of contacts you have set up.
Press the Options soft key to access the following options:
Note
: Depending on the item highlighted on the list, available
options vary.
Show/Hide List: displays the list of the contacts or hide them
from the list.
View: displays the conversation.
Send IM: allows you to send a message to the currently
selected contact.
Send IM to: allows you to send a message to another contact
you want.
Add Buddy: allows you to add a new contact to the list.
Delete Buddy: allows you to remove contacts from the list.
Block IM: allows you to block the message from the selected
contact.
Refresh: reloads the contact list with updated status.
My Presence: allows you to set whether your online or
offline status is shown on other contacts' devices.
Set Alert: allows you to turn the sound on or off to alert you
when a message comes in or the status of a contact changes.
Sign Off: signs out of the community.
Using Instant Messenger
Section 7 : Messaging
Section 7
100
Expiry Date: allows you to select the length of time your
messages are stored in the message center after they are
sent.
Exit: exits the option list.
Viewing the Conversation Logs
You can view the log of your conversations in the Instant
Messenger.
Online or offline, select Conversation Logs to open the
conversation log list. Select a log you want to view.
On the log view, you can access the following options by
pressing the Options soft key:
Send Log: sends the conversation log by SMS or MMS
message.
Cut Address: extracts the address of the contact from the
log.
Delete: deletes the log.
Properties: shows information about the log.
Exit: exits the option list.
Section 7 : Messaging101
Changing Message Settings
You can set up various options for using messaging services.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Messaging ➝ Settings.
3. Select the type of messages for which you want to
change the settings.
For details on each setting option, see the next sections.
IM
The following options are available:
Default Community: allows you to select the community you
want to join by default.
Community Settings: allows you to change the community
settings for using the Instant Messenger.
Profile: allows you to select a connection profile for using the
Instant Messenger.
Auto Sign On: allows you to set whether or not you
automatically sign on to the default community when you
access the Instant Messenger.
Changing Message Settings
Section 7 : Messaging
Section 7
102
Text Message
The following options are available:
Sending Profile: allows you to select a setting group to be
used for SMS messaging. You can also set up default
message information in each setting group. A setting group
is a collection of settings required to send messages. The
number of setting groups available depends on the capacity
of your SIM card.
To edit a setting group, scroll to a group and press the
Options soft key and select Edit. The following setting
options are available:
• Service Center: allows you to store or change the number
of your message center, which is required when sending
messages. You must obtain this number from your service
provider.
• Default Destination: allows you to store a default
destination number. The number automatically displays on
the Destination screen when you create a message.
• Default Type (dependant on the SIM card): allows you to
set the default message type to Text, Fax, E-mail, or Paging.
The network can convert the messages into the selected
format.
• Default Validity (dependant on the SIM card): allows you to
set the length of time your text messages are stored in the
message centre while attempts are made to deliver them.
• Setting Name: allows you to give a name to the setting
group currently being defined.
Changing Message Settings
103 Section 7 : Messaging
Reply Path (dependant on the SIM card): allows the recipient
of your message to send you a reply through your message
center, if your network supports this service.
Delivery Report (dependant on the SIM card): allows you to
activate or deactivate the report function. When this
function is activated, the network informs you as to whether
or not your message has been delivered.
Bearer Selection: allows you to select either GSM or GPRS,
depending on your network.
Character Support: allows you to select a character encoding
type, GSM-Alphabet, Uni-code, or Automatic.
Preferred Memory: allows you to select a default memory
where your outgoing or incoming messages are stored.
Save Sent Message: allows you to set the phone to save your
sent messages in the Outbox folder.
Multimedia Message
The following options are available:
Setup: provides you with various message settings.
• Delivery Report: when this option is enabled, the network
informs you as to whether or not your message has been
delivered.
• Read Reply: when this option is enabled, your phone sends
a request for a reply along with your message to the
recipient.
• Auto Download: you can set whether or not your phone
retrieves new incoming messages from the MMS server
without notifications.
Changing Message Settings
Section 7 : Messaging
Section 7
104
• Message Acceptance: you can specify the category of
messages you want to receive. Select All to receive all
messages.
• Hide ID: you can set your phone number not to be
displayed on the recipient’s phone.
• Expiry Date: you can select the length of time your
messages are stored in the message center after they are
sent.
• Delivery Time: you can set a time delay before the phone
sends your messages.
• Priority: you can select the priority level of your messages.
• Report Allowed: when this option is enabled, the sender of
an incoming message receives a delivery report from the
network.
• Page Duration: you can set the length of time one page of
an outgoing message displays on the message presentation
screen. After a specified time, the display automatically
scrolls to the next page.
Profile: selects a connection profile to be used for sending
and receiving MMS messages. You can also change the
profile. The following options are available:
• Profile Name: enter a name that you wish to assign to the
MMS server.
• Connection URL: enter the address of your MMS server.
• Security: select a data transmission mode. Choose Secure
to protect your data against unauthorised access;
otherwise, select Non-secure.
Changing Message Settings
105 Section 7 : Messaging
• Proxy Setting: enter the gateway address required to
connect to the MMS server.
• User Name: enter the user ID required to connect to the
MMS server.
• Password: enter the password required to connect to the
MMS server.
• APN: enter the access point name used for the address of
the MMS server.
E-mail
The following options are available:
Account: you can configure up to 10 e-mail accounts using
different service providers. The most recently accessed
account is automatically activated for sending or receiving e-
mail messages.
When you select an account, the following options are
available:
• Account Name: enter a name for the current account.
• Name: enter the name to be displayed in your outgoing
messages as the sender name.
• E-Mail Address: enter your e-mail address and the Reply-to
address to which you want replies sent.
• Protocol Type: specify an e-mail protocol type for the
incoming server, either POP3 or IMAP4. Contact your e-
mail service provider for more information.
For the IMAP4 protocol, you can set whether or not the
phone retrieves e-mails with attachments. You can also
select the number of e-mail headers you want to retrieve.
Changing Message Settings
Section 7 : Messaging
Section 7
106
• Incoming Server: enter the IP address or domain name of
the server to be used for receiving messages. Your e-mail
service provider can give you this information.
• User ID: enter your e-mail ID.
• Password: enter your e-mail password.
• Outgoing Server: enter the IP address or domain name of
the server to be used for sending messages. Your e-mail
service provider can give you this information.
Check Interval: you can select how often the phone checks
the server for incoming messages.
Signature: you can attach your name, phone number, a
simple memo, or a tag line as a signature to be attached to
your e-mails.
Send Copy to Self: you can set whether or not your phone
sends a copy of outgoing e-mails to your e-mail address.
Delivery Report: you can activate or deactivate the report
function. When this function is activated, the network
informs you as to whether or not your e-mail has been
delivered.
Read Reply: you can set whether or not your phone sends a
request for a reply along with your message to the recipient.
Server Delete: you can set whether or not your e-mails are
deleted from the server after retrieval.
Blocking: you can set up the mail filter to block spam mails.
You can select e-mail addresses or subjects.
Profile: you can select a connection profile to be used for
sending and receiving e-mails.
Changing Message Settings
107 Section 7 : Messaging
Push Message
The following options are available:
Receive: you can select which push messages the phone
receives or rejects from the WAP server. You can select All
to receive all push messages or None not to receive any
messages.
Black List: allows you to make a list of the URL addresses
from which you don’t want to receive push messages.
White List: allows you to make a list of the URL addresses
from which you want to receive push messages.
Broadcast
The following options are available:
Receive: allows you to enable or disable the reception of
broadcast messages.
Channel List: allows you to indicate the channels from which
you wish to receive broadcast messages. The following
options are available:
• Select: use to enable or disable channels on the list by
marking or unmarking them, respectively. A check mark
displays in front of each selected channel.
• Add Channel: use to enter the ID and title for a new
channel.
• Delete: use to remove a channel from the list.
• Edit: use to change the ID and title of an existing channel.
Language: allows you to select the language in which to
display cell broadcast messages.
Please contact your service provider for further details.
Section 7 : Messaging
Section 7
108
Checking Memory Status
You can the amount of memory available and remaining for
storing messages.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Messaging → Memory Status.
3. Select the message type you want.
• Text Message: the display shows the number of SMS
messages you have saved, or the total number of SMS
messages you can save in the phone's memory and the
SIM card, separately. On the bottom, you can see the
number of messages stored in each message box by
pressing the Next soft key.
• Multimedia Message: the display shows the amount of
memory currently in use and memory available for MMS
messages, including the amount of memory currently in
use in each message box.
• Email: the display shows the amount of memory currently
in use and memory available for e-mails, including the
amount of memory currently in use in each message box.
4. When you have finished, press the key.
Section 7 : Messaging109
Deleting Messages
You can delete the messages in each message folder one by
one, or all at once. You can also delete all of your messages
at one time.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Messaging → Delete All.
You can also scroll to a message folder, press the Options
soft key and select Delete All.
3. Select the message folder you want to empty.
4. Scroll to the message you want to delete and place a
check mark by pressing the key. Repeat this step to
select more messages.
To delete all of the messages in the folder, select All
Messages.
5. Press the Delete soft key.
6. When the phone asks if you want to include protected
messages, press the key.
If you don’t want this, deselect the check box.
7. Press the Yes soft key or the key to confirm the
deletion.
8. When you have finished, press the key.
Section 8 : Settings
Section 8
110
Section 8: Settings
Topics Covered
• Changing Sound Settings
• Changing Display Settings
• Changing Phone Settings
• Changing Connection Settings
• Changing the Time and Date
• Changing Network Service Settings
• Changing Security Settings
• Resetting Settings
This section explains how to customize your phone to fit
your needs and preferences.
Section 8 : Settings111
Changing Sound Settings
You can customize the settings related to various sounds for the
phone, such as the call ringer, key tone, power on/off tone,
folder tone, and so on.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Settings → Sound Settings.
3. Select a menu and then change the setting. If the menu
has submenus, repeat this.
For details of each menu, see the next sections.
Note
: If Silent mode is active (see page 41), your phone will
automatically deactivate the mode when you select an option.
4. When you have finished, press the key.
Ring Tone
This menu allows you to select a ring melody. You can
choose between many different melodies and tones.
If you have downloaded sounds from the Internet or the
EasyStudio II program, you can access them from this
menu.
Note
: You can access the web site preset by your service provider
to download melodies by selecting
Shop Ringtones
in the
Sound
Settings
or
MEdia Mall
menu. Once you have downloaded
melodies, they are saved in the
Audio
folder. To access
downloaded ring tones, see page 168.
Changing Sound Settings
Section 8 : Settings
Section 8
112
Ring Volume
This menu allows you to adjust the ring volume to one of 5
levels.
Alert Type
This menu allows you to specify how you are to be informed
of incoming calls. The following options are available:
Light Only: the service light flashes.
Melody: the phone rings using the ring melody selected in
the Ring Tone menu.
Vibration: the phone vibrates but does not ring.
Vibration+Melody: the phone first vibrates three times and
then starts ringing.
Keypad Tone
This menu allows you to select the tone that the phone
sounds when you press a key. To turn the sound off, select
Off.
Message Tone
This menu allows you to select how the phone informs you
that a new SMS, MMS, or CB message has been received.
For each message tone, the following options are available:
Tone (dependant on the SIM card): you can select a message
tone.
Changing Sound Settings
113 Section 8 : Settings
Mode: you can select a type of message alert.
• Off: the phone does not use the SMS tone.
• Tone: the phone sounds the selected message tone.
• Vibration: the phone vibrates.
• Light Only: the service light flashes.
Repetition: you can select how often the phone informs you
of a new message.
• Once: the phone alerts you to a new message just once, at
the time of its receipt.
• Periodic: the phone alerts you to a new message every 2
minutes until you open the message.
Folder Tone
This menu allows you to select the tone that the phone
sounds when you open or close the phone. To turn the
sound off, select Off.
Power On/Off
This menu allows you to select the melody that the phone
sounds when it is switched on and off. To deactivate the
sound, select Off.
Alerts on Call
This menu allows you to choose whether or not the phone
sounds when you receive a new message or when the time
for an alarm comes during a call.
Changing Sound Settings
Section 8 : Settings
Section 8
114
Extra Tones
You can customize additional tones for the phone.
The following options are available:
Error Tone: sets whether or not the phone informs you when
you have made a mistake.
Minute Minder: sets whether or not the phone beeps every
minute during an outgoing call to keep you informed of the
length of your call.
Connect Tone: sets whether or not the phone beeps when
your call is connected to the system.
To turn a given tone Press the
on
On
soft key or the key. A check
mark displays in front of the option.
off
Off
soft key or the key. The check
mark no longer displays.
Section 8 : Settings115
Changing Display Settings
You can customize the settings for the displays and the lights.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Settings → Display Settings.
3. Select a menu and then change the setting. If the menu
has submenus, repeat this.
For details of each menu, see the next sections.
4. When you have finished, press the key.
Wallpaper
This menu allows you to change the background image or
change the settings for the text display in Idle mode.
The following options are available:
Wallpaper List: you can select a background image to be
displayed on the idle screen.
1. Select a source image category, Preinstalled Images or
Downloaded Images.
2. Scroll through the list by pressing the Up or Down key.
You have various preset images available. You can also
select a blank background or any images downloaded
from the Internet and the EasyStudio II program, or
received in messages.
Once you have set a photo as wallpaper, it is designated
as My Photo in the Downloaded Images option.
3. Select an image. The image displays.
Changing Display Settings
Section 8 : Settings
Section 8
116
4. You can scroll to other images by pressing the Up or
Down key from the image preview screen.
5. When the image you want displays, press the Select soft
key or key to display it on the idle screen.
Note
: You can access the web site preset by your service provider
to download images by selecting
Shop Graphics
in the
Display
Settings
or
MEdia Mall
menu. Once you have downloaded images,
they are saved in the
Graphics
folder. To access downloaded
images. See page 168.
Text Display: you can specify whether or not the phone
displays the time and date on the idle screen.
Text Color: you can select the color of the text to be
displayed on the idle screen. This option is available when
the text display is enabled.
Front LCD Display
This menu allows you to change the settings for the external
display.
The following options are available:
Display Type: you can select what the external display shows,
the clock only, or the time and date in a digital or an
analogue clock.
Light Timer: you can select the length of time the external
display stays on when you close the phone.
Menu Style
This menu allows you to select the menu display style. You
can choose either Grid Style, Page Style, or Bar Style.
Changing Display Settings
117 Section 8 : Settings
Back Light
You can select the length of time the backlight stays on. The
backlight turns on when you press a key, you open the
phone, or you receive a call or message, and remains on for
the specified length of time.
In the Dim option, you can select the length of time the
phone is in Dimming mode, in which the backlight of the
display dims for the specified length of time. To deactivate
Dimming mode, select Off.
Service Light
The service light in front of the phone flashes at regular
intervals to indicate when service is available on the phone.
Use the Dim option to select the length of time the
backlight dims.
Graphic Logo
This menu allows you to display your service provider’s logo
instead of its name.
Section 8 : Settings
Section 8
118
Changing Phone Settings
You can customize the settings for the phone system.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Settings ➝ Phone Settings.
3. Select a menu and then change the setting. If the menu
has submenus, repeat this.
For details of each menu, see the next sections.
4. When you have finished, press the key.
Greeting Message
This menu allows you to set a greeting to be displayed
briefly when the phone is switched on.
For further details about how to enter characters, see page
56.
Language
You can select a display language. When the language option
is set to Automatic, the language is automatically selected
according to the language of the SIM card used.
Note
:
Depending on your country, service provider, or software
version of the phone, the
Automatic
option may not display.
Changing Phone Settings
119 Section 8 : Settings
Short Cut
You can assign the Navigation keys to the menus you most
often use. In Idle mode, they allow you to access specific
menus directly.
To assign a shortcut to a key:
1. From the Phone Settings menu screen, select Short Cut.
2. Select one of the Navigation keys to be used as a
shortcut key.
3. Select the menu to be assigned to the key.
4. Press
the key or
the Select soft key.
Note
: To deactivate a shortcut key, select the
None
option.
Extra Settings
You can turn the automatic redialing or answering features
on or off.
To turn a feature Press the
on
On
soft key or the key. A check
mark displays in front of the option.
off
Off
soft key or the key. The check
mark no longer displays.
Changing Phone Settings
Section 8 : Settings
Section 8
120
The following options are available:
Auto Redial: when this option is checked, the phone makes
up to ten attempts to redial a phone number after an
unsuccessful call.
Note
: The intervals between call attempts varies.
Active Folder: when this option is checked, you can simply
open the phone to answer a call. When it is unchecked, you
must open the phone and press a key to answer a call,
depending on the setting of the Anykey Answer option. See
below.
Anykey Answer: when this option is checked, you can
answer an incoming call by pressing any key, except the
key or the Reject soft key. To reject the call, press the key
or the Reject soft key.
When this option is unchecked, you must press the key
or Accept soft key to answer a call.
Section 8 : Settings121
Changing Connection Settings
You can customize the profiles containing the settings for
connecting your phone to the network. You need these
settings to use the WAP browser or Instant Messenger, or to
send MMS messages or e-mails, and to synchronize your
PIM data.
No
te: Your phone is suited for connecting to the network by
default. If you change the MMS settings without first checking with
your service provider, the WAP, MMS, and e-mail features may not
work properly.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Settings → Connection Settings.
3. Select the profile you want to change.
For each profile, the following options available:
• Profile Name: enter a name that you wish to assign to the
profile.
• Homepage URL: enter the address of the WAP homepage
of your service provider.
• Bearer: select the network bearer type for data
transmission, either GPRS or Data. The following options
depend on this setting.
When Bearer is set to GPRS.
• Proxy Setting: enter the IP address of the proxy server.
• User Name: enter the user ID required to connect to the
network.
Changing Connection Settings
Section 8 : Settings
Section 8
122
• Password: enter the password required to connect to the
network.
• APN: enter the access point name used for the address of
the network.
• Proxy Status: activate or deactivate the proxy server.
• Primary DNS: enter the primary DNS (Domain Name
Server) address.
• Secondary DNS: enter the secondary DNS address.
When Bearer is set to Data.
• Proxy Setting: enter the IP address of the proxy server.
• Login Name: enter the user ID required to connect to the
network.
• Password: enter the password required to connect to the
network.
• Data Call Type: select a data call type, Analog or ISDN.
• Proxy Status: activate or deactivate the proxy server.
• Primary DNS: enter the primary DNS (Domain Name
Server) address.
• Secondary DNS: enter the secondary DNS address.
For further details, contact your service provider.
4. When you have finished, press the key.
Section 8 : Settings123
Changing the Time and Date
You can change the settings for the time and date display.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Settings → Time & Date.
3. Select a menu and then change the setting. If the menu
has submenus, repeat this.
For details of each menu, see the next sections.
4. When you have finished, press the key.
Set Time
You can enter the current time. You can choose the time
format in the Time Format menu. See the next page.
Note
: Before setting the time, you must specify your time zone in
the
World Time
menu.
Set Date
You can enter the month, day, and year.
Changing the Time and Date
Section 8 : Settings
Section 8
124
World Time
You can find out what time it is another part of world and
set your time zone.
Viewing the world time
Press the Left or Right key on the world map.
The screen shows the:
• selected city name.
• current time and date in the city.
• time difference between the selected city, and your city if
you have set your home time zone (see the next section for
further details).
• city selected as your time zone.
Selecting the Home Time Zone
1. From the world map, select the city corresponding to
your time zone by pressing the Left or Right key.
2. Press the Set soft key or the key.
Time Update
You can change the time format to 12 Hours or 24 Hours.
Changing the Time and Date
125 Section 8 : Settings
Auto Update
You can receive time information from your service
provider’s network.
Off: you need to manually set the time and date according to
the current time zone using the Set Time menu.
On: the phone automatically updates the time and date
according to the current time zone using the network
service.
Confirm First: the phone asks for a confirmation before the
update.
Note
: Automatic updates of time and date do not change the time
you have set for alarm settings or calendar memos.
Section 8 : Settings
Section 8
126
Changing Network Service Settings
You can customize the settings for network features, such as
call forwarding, call barring, call waiting, and network and
band selection.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Settings → Network Services.
3. Select a menu and then change the setting. If the menu
has submenus, repeat this.
For details of each menu, see the next sections.
4. When you have finished, press the key.
Call Forwarding
This network service enables incoming calls to be rerouted
to a number that you specify.
Example: You may wish to forward your business calls to a
colleague while you are on holiday.
Setting Call Forwarding Options
1. From the Network Services menu screen, select Call
Forwarding.
2. Select one of the following call forwarding options.
• Forward Always: all calls are forwarded.
• Busy: calls are forwarded when you are already on another
call.
Changing Network Service Settings
127 Section 8 : Settings
• No Reply: calls are forwarded when you do not answer the
phone.
• Unreachable: calls are forwarded when you are not in an
area covered by your service provider or when your phone
is switched off.
• Cancel All: all call forwarding options are canceled.
3. Select the type of calls, Voice Calls or Data Calls.
The current status displays. If the option has already
been set, the number to which the calls are forwarded
displays.
4. Press the Activate soft key or the key.
5. Enter the number to which the calls are to be forwarded
and press the OK soft key or the key.
To enter an international code, press and hold the 0 key
until the + sign displays.
6. If you selected No Reply in step 2, select the length of
time the network delays before forwarding a call.
The phone sends your settings to the network and the
network’s acknowledgement displays.
Changing the Phone Number for Call Forwarding
1. From the Network Services menu screen, select Call
Forwarding.
2. Select one of the call forwarding options.
3. Select the type of calls, Voice Calls or Data Calls.
4. Press the Options soft key and select Change.
Changing Network Service Settings
Section 8 : Settings
Section 8
128
5. Enter the number to which the calls are to be forwarded.
To enter an international code, press and hold the 0 key
until the + sign displays.
6. Press the OK soft key or key.
The phone sends your settings to the network and the
network’s acknowledgement displays.
Deactivating Specific Call Forwarding Settings
1. From the Network Services menu screen, select Call
Forwarding.
2. Select one of the call forwarding options.
3. Select the type of calls, Voice Calls or Data Calls.
4. Press the Options soft key and select Remove.
The phone sends your settings to the network and the
network’s acknowledgement displays.
Call Barring
The call barring network service allows you to restrict your
calls.
Setting Call Barring Options
1. From the Network Services menu screen, select Call
Barring.
2. Select one of the following call barring options.
• All Outgoing: calls cannot be made.
• International: international calls cannot be made.
Changing Network Service Settings
129 Section 8 : Settings
• International Except to Home: when abroad, calls can be
made only to numbers within the current country and to
your home country, which is the country where your home
network provider is located.
• All Incoming: calls cannot be received.
• Incoming While Abroad: calls cannot be received when
you are using your phone outside of your home country.
• Cancel All: all call barring settings are deactivated; calls
can be made and received normally.
• Change Barring Password: you can set and change the call
barring password obtained from your service provider. See
page 130.
3. Select the type of calls, Voice Calls or Data Calls.
4. Press the Activate soft key or the key.
5. Enter the call barring password supplied by your service
provider.
The phone sends your settings to the network and the
network’s acknowledgement displays.
Deactivating Specific Call Barring Settings
1. From the Network Services menu screen, select Call
Barring.
2. Select the call barring option to be deactivated.
3. Select the type of calls to which this option applies.
4. Press the Deactivate soft key or the key.
Changing Network Service Settings
Section 8 : Settings
Section 8
130
5. Enter the call barring password supplied by your service
provider.
The phone sends your settings to the network and the
network’s acknowledgement displays.
Changing the Barring Password
1. From the Network Services menu screen, select Call
Barring.
2. Select Change Barring Password.
3. Enter the current password and press the OK soft key or
the key.
4. Enter a new password and press the OK soft key or the
key.
5. Enter the new password to confirm and press the OK
soft key or the key.
The phone sends your settings to the network and the
network’s acknowledgement displays.
Call Waiting
This network service informs you when someone is trying
to reach you during another call.
You can specify individual call waiting options for voice calls
and/or data calls.
Setting Call Waiting Options
1. From the Network Services menu screen, select Call
Waiting.
Changing Network Service Settings
131 Section 8 : Settings
2. Select the type of calls, Voice Calls or Data Calls.
The screen informs you whether call waiting is activated
or deactivated.
3. Press the Activate soft key or the key to activate the
call waiting feature.
The phone sends your settings to the network and the
network’s acknowledgement displays.
Deactivating Call Waiting Settings
1. From the Network Services menu screen, select Call
Waiting.
2. Select the type of calls, Voice Calls or Data Calls.
3. You can deactivate all Call Waiting settings by selecting
the Cancel All option.
4. Press the Deactivate soft key or the key.
The phone sends your settings to the network and the
network’s acknowledgement displays.
Network Selection
The network selection feature enables you to either
automatically or manually select the network used when
roaming outside of your home area.
Note
: You can select a network other than your home network
only if there is a valid roaming agreement between the two.
1. From the Network Services menu screen, select Network
Selection.
Changing Network Service Settings
Section 8 : Settings
Section 8
132
2. Select the option you want.
If you select Automatic, you are connected to the first
available network when roaming.
If you select Manual, go to step 3.
3. Select the network you want. The phone will scan for
that network and you will be connected.
Caller ID
You can prevent your phone number from being displayed
on the phone of the person being called.
Note
: Some networks do not allow you to change this setting.
The following options are available:
Default: the default setting provided by the network is used.
Hide Number: your number does not display on the other
person’s phone.
Send Number: your number is sent each time you make a
call.
Closed User Group
This network service allows incoming and outgoing calls to
be restricted to a selected user group. You can create up to
10 user groups.
For details about how to create and use a closed user group,
contact your service provider.
Example: A company lends SIM cards to its employees and
wants to restrict outgoing calls to members of the same
team.
Changing Network Service Settings
133 Section 8 : Settings
When you select the Closed User Group menu, you enter the
CUG function. You can now access the following options:
Index List: lets you list, add, or delete CUG index numbers.
If there is no CUG index stored, you are prompted to add a
new index when you select this option. Once you have
added a CUG index, the list of current CUG indexes
appears.
Add a new CUG index as advised by your service provider,
or delete a group.
Outside Access: lets you enable or disable calls to numbers
other than those in the Closed user group. This feature
depends on the nature of your CUG subscription. Please
check with your service provider.
Default Group: you may set a default CUG with your service
provider. If you have done so, you can enable the Default
Group option on your phone. When making a call, you are
given the option of using your default CUG, instead of
selecting one from the list.
To Press the
scroll through existing
CUG indexes Up or Down key.
add a new CUG index
Options
soft key or the key, select
the
Add
option, and enter the index.
delete a CUG index
Options
soft key or the key and
select the
Delete
option.
activate a CUG index
Options
soft key or the key and
select the
Activate
option.
Changing Network Service Settings
Section 8 : Settings
Section 8
134
Deactivate: deactivates the CUG function. This menu
appears only when the default group is enabled or a CUG
index is selected.
Band Selection
For the phone to make and receive phone calls, it must
register with an available network. Your phone can handle
any of the following types of networks:
• GSM 1800
• GSM 850/1900
The country where you purchased your phone determines
the default band that it uses. When you travel abroad, you
must remember to change to an appropriate band.
1. From the Network Services menu screen, select Band
Selection.
2. Select the appropriate option.
3. Press the Yes soft key or the key to confirm the
selected network band.
To cancel the selection, press the No soft key.
When you select a new band, your phone displays a
confirmation message and then automatically searches for
all available networks. Your phone registers with a preferred
network within the band.
Section 8 : Settings135
Changing Security Settings
The security feature enables you to restrict the use of your
phone by others and to restrict the types of calls made.
Various codes and passwords are used to protect the
features of your phone.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Settings → Security.
3. Select a menu and then change the setting. If the menu
has submenus, repeat this.
For details of each menu, see the next sections.
4. When you have finished, press the key.
PIN Check
When the PIN check feature is enabled, you must enter your
PIN each time you switch on the phone. Consequently, any
person who does not have your PIN cannot use your phone
without your approval.
Change PIN
This feature allows you to change your current PIN,
provided that the PIN check feature is enabled.
Changing Security Settings
Section 8 : Settings
Section 8
136
Phone Lock
When the phone lock feature is enabled, the phone is locked
and you must enter the 4- to 8-digit phone password each
time the phone is switched on.
Note
: The password is preset to “00000000” at the factory. To
change the phone password, see the
Change Password
menu.
Change Password
The change password feature allows you to change your
current phone password to a new one.
The password is preset to “00000000” at the factory.
Privacy
Using this menu, you can lock your media contents, such as
MMS messages, e-mails, photos, video clips, recorded audio
clips, and downloaded images and sound clips. Once you
have locked the contents, you must enter the phone’s
password to access the associated menus.
1. From the Security menu screen, select Privacy.
2. Scroll to an item to lock and press the key to place or
remove a check mark. Repeat this to select more items.
To lock all contents, select All.
3. Press the OK soft key to lock the marked items.
Changing Security Settings
137 Section 8 : Settings
4. When the phone asks for the password, enter the
password and press the OK soft key or the key.
Note
: The password is preset to “00000000” at the factory. To
change this password, see page 136.
SIM Lock
When the SIM lock feature is enabled, your phone only
works with the current SIM card.
FDN Mode
FDN (Fixed Dial Number) mode, if supported by your SIM
card, allows you to restrict your outgoing calls to a limited
set of phone numbers stored in Address Book. To use this
mode, you must enter your PIN2.
Note
: Not all SIM cards have a PIN2. If your SIM card does not,
this menu does not display.
Change PIN2
The change PIN2 feature allows you to change your current
PIN2 to a new one.
Note
: Not all SIM cards have a PIN2. If your SIM card does not,
this menu does not display.
Section 8 : Settings
Section 8
138
Resetting Settings
You can easily reset your phone to its default settings.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Settings → Reset Settings.
3. Enter the 4- to 8-digit password and press the OK soft
key or the key.
Note
: The password is preset to “00000000.” To change this
password, see page 136.
4. When you have finished, press the key.
Section 8 : Settings139
Section 9 : Multimedia
Section 9
140
Section 9: Multimedia
Topics Covered
• Using the Camera
• Using the Recorder
• Playing Java Games
This section explains how to use multimedia files on your
phone. You can take photos or record video clips using the
built-in camera, record audio clips, and play Java games.
Section 9 : Multimedia141
Using the Camera
Using the camera module in your phone, you can take
photos of people or events while on the move. Additionally,
you can send photos to other people as part of an MMS
message, or set a wallpaper or caller ID image.
You can also record videos using your phone as a
camcorder.
CAUTION
:
• Do not take photos of people without their permission.
• Do not take photos in places where cameras are not allowed.
• Do not take photos in places where you may interfere with
another person’s privacy.
Taking Photos
Your camera produces JPEG photos.
Note
: When you take a photo in direct sunlight or in bright
conditions, shadows may appear on the photo.
Taking a Photo With the Phone Open
1. In Idle mode, press and hold the key to turn on the
camera.
You can also press the Menu soft key to access Menu
mode and select Multimedia → Camera → Take Photos.
2. Adjust the image by aiming the camera at the subject.
Press the left soft key to access the camera options. For
details, see page 142.
You can use the keypad to quickly change the camera
options. For details, see page 144.
Using the Camera
Section 9 : Multimedia
Section 9
142
3. Press the key or the key to take the photo.
The phone saves the photo in the Photo Album.
Using Camera Options
In Capture mode, you can access various camera options by
pressing the left soft key.
The following options are available:
Shooting Mode: allows you to take a photo in various modes.
Once you have changed the mode, the corresponding
indicator appears at the top right of the display.
• Single Shot: allows you to take a photo. When you select
Take & Save, the phone saves and displays the taken photo,
and allows you to access options after taking a photo.
When you select Automatic Save, the phone saves the
photo and immediately returns to Capture mode after
taking a photo.
4.
To Press the
use the photo options
Options
soft key or the key. For
details, see page 149.
delete the photo
C
key
return to Capture mode soft key.
return to Idle mode key.
Using the Camera
143 Section 9 : Multimedia
• Multi Shot: allows you to take a series of action stills. Select
the capture speed, High or Normal, and the number of
photos the camera will take. When you press the or
key, the camera takes photos successively. After taking the
photos, press the Save All soft key to save all of the photos
in a separate folder, or select the photo(s) you want and
press the Save soft key.
• Mosaic Shot: allows you to take several stills and save them
in a single frame. Select the type of frame you want. The
images will be saved in the frame as a composite of the
multiple stills taken.
Effects: allows you to change the color tone or apply a special
effect to the photo.
Frames: allows you to apply a decorative frame. Select a
frame from the list using the Navigation keys.
Flash: turns the flash on or off.
Timer: allows you to set a time delay before the camera takes
the photo. Select the length of delay you want. When you
press the or key, the timer starts and the camera takes
the photo after the specified time.
Go to Photos:
allows you to go to the
Photo Album
menu or
Video Album
menu. See page 149.
Settings: allows you to change the image settings. These
settings are saved for subsequent shots.
• Size: allows you to set the image size to 640x480, 320x240,
176x160 (for Mobile), or 160x120.
• Quality: allows you to select the image quality, Super Fine,
Fine, Normal, or Economy.
Using the Camera
Section 9 : Multimedia
Section 9
144
• Viewfinder Mode: allows you to select the default view type
of Capture mode. Select Full Screen to view an image on
the full screen or Economy to view an image in actual
ratio.
• Shutter Sound: allows you to select a tone for the shutter
sound.
Short Cuts: shows the help screen to give you information
for using the keys in Capture mode.
Using the Keypad in Capture Mode
You can use the following keys to change view or camera
settings when you are in Capture mode:
Key Function
/ zooms in or out.
/ adjusts the image brightness.
flips the image vertically.
shows the mirror image.
1
switches to Record mode. See page 146.
2
changes the image size.
3
changes the image quality.
4
changes the camera shot mode.
5
changes the color tone or applies a special effect
to the photo.
6
reduces the distortion on the image to maximize
detail and sharpness.
Using the Camera
145 Section 9 : Multimedia
Taking a Photo or Recording a Video With the Phone
Closed
1. With the phone closed, press and hold the key on the
right of the phone.
The image to be captured appears on the external
display.
2. Adjust the image by aiming the camera at the subject.
Press the key to scroll through the camera options.
The following options are available:
• Capture/Record mode: switches the Camera mode.
• Verticality: flips the image vertically.
• Brightness: changes the image brightness.
• Zoom In/Out: zooms in or out.
Press the key to change the settings for the selected
camera option.
3. Press the key.
Your phone automatically saves the photo or the video
clip and returns to Capture mode.
7
selects a decorative frame.
8
sets a time delay.
9
switches to
Photo Album
. See page 149.
0
turns the flash on or off.
switches the display between Full Screen mode
and Economy mode.
Key Function
Using the Camera
Section 9 : Multimedia
Section 9
146
Recording Videos
1. In Idle mode, press the Menu soft key to access Menu
mode and select Multimedia → Camera → Record Video.
2. Adjust the image by aiming the camera at the subject.
Press the left soft key to access the camera options. For
details, see page 147.
You can use the keypad to quickly change the camera
options. For details, see page 148.
3. Press the key to start recording.
While recording, you can cancel by pressing the Cancel
soft key or the C key.
4. When you have finished recording, press the key or
the Stop soft key. The video clip is saved and appears on
the display.
5.
To Press the
use the video options
Options
soft key. For details, see
page 150.
delete the video clip
C key
return to Record mode soft key.
return to Idle mode key.
Using the Camera
147 Section 9 : Multimedia
Using Camera Options for Video
In Record mode, you can use various options for the camera
by pressing the left soft key.
The following options are available:
Effects: allows you to change the color tone or apply special
effects to the video.
Flash:
turns the flash on or off.
Timer: allows you to set a time delay before the camera starts
recording a video. Select the length of delay you want. When
you press the or key, the timer starts and the camera
begins recording a video after the specified time.
Go to Videos:
allows you to go to the
Video Album
menu. See
page 149.
Settings: allows you to change the image settings. These
settings are saved for subsequent recordings.
• Recording Mode: allows you to select a recording mode.
Depending on the selected recording mode, the maximum
file size of a video clip differs.
Normal records video clips for saving. You can record
video clips of up to about 1 hour.
Limit for MMS records video clips for adding them to MMS
messages or e-mails. You can record video clips of up to
about 35 seconds, economy quality, in the 176✕144 or
128✕96 size.
• Size: allows you to set the image size to either
SubQCIF(128x96) or QCIF(176x144).
• Video Quality: allows you to select the image quality, Super
Fine, Fine, Normal, and Economy.
Using the Camera
Section 9 : Multimedia
Section 9
148
Short Cuts: shows the help screen to give you information
for using the keys in Record mode.
Using the Keypad in Record Mode
You can use the following keys to customize your camera
settings when you are in Record mode:
Key Function
/ zooms in or out.
/ adjusts the image brightness.
flips the image vertically.
shows the mirror image.
1
switches to Capture mode. See page 141.
2
changes the image size.
3
changes the image quality.
4
changes the recording mode.
5
changes the color tone or applies a special effect
to the video.
7
turns the audio on or off.
8
sets a time delay.
9
switches to
Video Album
. See page 150.
0
turns the flash on or off.
switches the display between Full Screen mode
and Economy mode.
Using the Camera
149 Section 9 : Multimedia
Viewing Photos
In Idle mode, press the Menu soft key and select Multimedia
→ Camera → My Album → Photo Album.
When you access this menu, your phone displays the list of
photos, and you can view their thumbnail images.
To view a photo on the full screen, scroll to it and press the
key. To go back to Thumbnail mode, press the soft key
or C key.
Press the Options soft key to use the following options:
View: opens the photo on the full screen.
Display Mode: allows you to change the view mode to List
view or Thumbnail view.
Send Via MMS: allows you to send the photo as part of an
MMS message or e-mail. For further details, see page 81 and
page 84, respectively.
Set As: allows you to set the photo as your wallpaper for the
main display or the external display, or as a caller ID image
for an entry in Address Book.
Delete: allows you to delete the photo(s).
Rename: allows you to change the name of the photo.
Move to Favorite Images:
Slide Show: allows you to select a time interval between each
photo to display photos in a slide show.
Share: allows you to upload to an online photo album.
Protection: allows you to protect the photo from being
deleted. Protected items are indicated by the icon on the
list.
Properties: shows the properties of the photo.
Using the Camera
Section 9 : Multimedia
Section 9
150
Playing Videos
In Idle mode, press the Menu soft key and select Multimedia
→ Camera → My Album → Video Album.
When you access this menu, your phone displays the list of
video clips, and you can view their thumbnail images. Scroll
to a video clip and press the key to begin playing the clip.
Press the Options soft key to use the following options:
Play: plays the video clip on the full screen.
Display Mode: allows you to change the view mode to List
view or Thumbnail view.
Send Via: allows you to send the video clip as part of an
MMS message or e-mail. For further details, see page 81 and
page 84, respectively.
Delete: allows you to delete the video clip.
Rename: allows you to change the name of the video clip.
Move to Favorite Videos:
Share: allows you to upload to an online photo album.
To Press the
pause/resume playback key.
move backward Left key.
move forward Right key.
mute/unmute audio left soft key
adjust the volume level volume key
stop right soft key.
Using the Camera
151 Section 9 : Multimedia
Protection: allows you to protect the video clip from being
deleted. Protected items are indicated by the icon on the
list.
Properties: shows the properties of the video clip.
Checking the Memory Status
You can check the amount of the memory currently in use
and the memory remaining for the photo and video albums.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Multimedia → My Album → Memory Status.
The display shows the total amount of memory available
for photos, and video clips, and the amount of memory
currently in use in each album, separately.
3. When you have finished, press the key.
Deleting Photos and Video Clips
You can delete photos or videos clips one by one or all at
once.
Deleting a Photo or Video Clip
1. From the Photo Album or Video Album, select the
photo or video you want to delete.
2. Press the Options soft key and select Delete.
3. Choose Selected.
To delete all the items in the current album, select All.
4. When you have finished, press the key.
Using the Camera
Section 9 : Multimedia
Section 9
152
Deleting all Photos and Video Clips
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Multimedia → Camera → Delete All.
3. Scroll to the album you want to clear or place a check
mark by pressing the Mark or Unmark soft key.
To delete all of the items, select All.
4. Press the Delete soft key.
A confirmation message appears.
5. Press the Yes soft key to confirm the deletion.
6. If you have selected All, the phone asks if you want to
reset numbering for file names. Press the Yes or No soft
key
If you have selected an album, the items in the album are
deleted, except for the protected ones.
7. When you have finished, press the key.
Section 9 : Multimedia153
Using the Recorder
You can record audio clips. After recording, you can send
the audio clip to other people via the Multimedia Message
Service or E-mail Service.
Recording an Audio Clip
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Multimedia → Record Audio → Record. The
display shows a 30-second timer.
3. To start recording, press the Record soft key or the
key.
4. Record an audio clip by speaking into the microphone or
playing a desired sound near the microphone.
5. When you press the Stop soft key or the key, or when
the recording time expires, the following options display:
• Replay: plays back your recording.
• Re-record: discards the recording and enables you to
record another one.
• Save: allows you to save the recording.
• Quit: cancels your recording and exits the Record menu.
6. To save the audio clip, choose Save.
7. Press the C key to clear the default name, if necessary,
and enter a name for the audio clip.
For further details about how to enter characters, see
page 56.
Using the Recorder
Section 9 : Multimedia
Section 9
154
8. Press the OK soft key or the key.
The audio clip is saved and then the display shows
information about the clip.
You can press the Options soft key or the key to
access the following options:
• Send: allows you to send the audio clip to other people as
part of an MMS message or e-mail. For further details, see
page 81 and page 84, respectively.
• Rename: allows you to change the name of the audio clip.
• Delete: allows you to delete the audio clip.
9. When you have finished, press the key.
Reviewing Audio Clips
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Multimedia → Record Audio → Audio List.
3. Scroll to an audio clip and press the Options soft key or
the key. The following options are available:
• Play: plays the audio clip.
• Send: allows you to send the audio clip to other people as
part of an MMS message or e-mail. For further details, see
page 81 and page 84, respectively.
• Rename: allows you to change the name of the audio clip.
• Information: displays information about the audio clip.
• Delete: allows you to delete the audio clip.
Using the Recorder
155 Section 9 : Multimedia
4. Select Play to review the audio clip.
After playback, the displays returns to the audio list.
5. When you have finished, press the key.
Deleting Audio Clips
You can delete your audio clips one by one or all at one time.
Deleting an Audio Clip
1. Access the audio list (see page 154) and scroll to the
audio clip you want to delete.
2. Press the Options soft key or the key and then select
Delete.
3. Press the OK soft key or the key to confirm the
deletion.
4. When you have finished, press the key.
Deleting all Audio Clips
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Multimedia → Record Audio → Delete All.
3. Press the OK soft key or the key to confirm the
deletion.
4. When you have finished, press the key.
Using the Recorder
Section 9 : Multimedia
Section 9
156
Checking the Memory Status
You can check the amount of the memory currently in use
and the memory remaining for the camera and recorder.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Multimedia → Memory Status.
The display shows the total amount of memory available
for photos, and video clips, or audio clips, and the
amount of memory currently in use in each album and
the audio list, separately.
3. When you have finished, press the key.
Section 9 : Multimedia157
Playing Java Games
Using the Games menu, you can download MIDlets (Java
applications that run on mobile phones) from various
sources using the WAP Browser and enjoy them on your
phone. When you access the Games menu, the list of the
default games appears.
Note
: Java services may not be available, depending upon your
service provider.
Launching a Game
Note
: The
procedure described below is for the default games. For
downloaded games, the procedure may be different.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Games and select the game you want to play.
For some games, you need to press a key (any key) to
access the game options.
3. Select START or New Game to launch the game and
follow the instructions on the screen.
4. While you are playing a game:
To Press the
adjust the volume Volume keys.
stop the game and return
to the startup screen
C
key.
Playing Java Games
Section 9 : Multimedia
Section 9
158
5. When you have finished, press the
key.
6. Press the Yes soft key to confirm the exit.
Downloading New Games
You can buy and download games from the web site preset
by your service provider.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Games → Shop Games.
You are sent to the preset web site.
3. Find the game you want and follow the instructions on
the screen to buy the game.
Once you have downloaded games, they are added to the
Games list.
Viewing Properties of a Game
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Games and scroll to the game you want.
3. Press the Options soft key and select Properties.
The displays shows the game information, such as the
file size, application version, its vendor, and Java VM
version.
4. Press the Up or Down key to scroll through the
information.
5. When you have finished, press the
key.
Playing Java Games
159 Section 9 : Multimedia
Checking the Memory Status
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Games and scroll to the game you want.
3. Press the Options soft key and select Memory Status.
The display shows the total amount of memory available
for games and the amount of memory currently in use
and free. You will also see the number of games you have
downloaded.
4. When you have finished, press the key.
Deleting Games
You can delete downloaded games one by one or all at one
time.
Deleting a Game
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Games and scroll to the game you want to delete.
3. Press the Options soft key and select Delete.
4. Press the Yes soft key or the key to confirm the
deletion.
5. When you have finished, press the
key.
Playing Java Games
Section 9 : Multimedia
Section 9
160
Deleting all Games
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Games.
3. Press the Options soft key and select Delete All.
4. Press the Yes soft key or the key to confirm the
deletion.
5. When you have finished, press the
key.
Section 9 : Multimedia161
Section 10 : WAP
Section 10
162
Section 10: WAP
Topics Covered
• Launching the WAP Browser
• Accessing a WAP site
• Navigating the WAP Browser
• Using Favorites
• Downloading Media Content
• Clearing the Cache
• Changing the Profile for Accessing the WAP
Your phone is equipped with a WAP (Wireless Application
Protocol) browser which allows you to access Internet
service specified for mobile phones. This section explains
how to access the WAP services of your service provider
and navigate the WAP browser.
Section 10 : WAP163
Launching the WAP Browser
1. In Idle mode, press the key to launch the WAP
browser.
You can also press the Menu soft key to access Menu
mode and select My MEdia → MEdia Net → MEdia Net
Home.
Your phone connects to the network and loads the
homepage of the Wireless Web service provider. The
content of the startup homepage depends on your
Wireless Web service provider.
2. To scroll through the screen, use the Up and Down keys.
For further details about navigation, see the next section.
3. To exit the browser at any time, simply press the key
or press and hold the key.
Accessing a WAP site
There are several ways to access a WAP site:
• Selecting a link on the browser
• Using a bookmark item in the Favorites folder; use the
Favorites option on the browser menu list (see page 165)
or the Favorites Bookmark menu (see page 166)
• Entering a URL address manually; use the Goto URL option
on the browser menu list (see page 165) or the
http:// menu (in Menu mode, select My MEdia → MEdia
Net → http://)
Section 10 : WAP
Section 10
164
Navigating the WAP Browser
Entering Text in the WAP Browser
When you are prompted to enter text, the currently active
text input mode is indicated on the screen. To change the
text input mode, press the key one or more times.
The following modes are available:
Upper-case Character Mode (A): allows you to enter upper-
case English characters.
Lower-case Character Mode (a): allows you to enter lower-
case English characters.
Note
: You can enter symbols in upper- or lower-case character
mode by pressing the
1
key.
To Press the
scroll through browser
items Up or Down key.
select a browser item
key, or press the
Options
soft key
and choose
Select
.
select a numbered item corresponding numeric key.
return to the previous
page
C
key, or press the
Options
soft key
and choose
Back
.
access the browser menu
list
Menu
soft key. For further details
about the options, see page 165.
return to the startup
homepage
Menu
soft key and select the
Home
option.
Navigating the WAP Browser
165 Section 10 : WAP
T9 Mode (T9): allows you to enter English characters by
pressing one key per letter. In this mode, you can use only
the 0 key to display alternative words. To change case, press
the key.
Number Mode (1): allows you to enter numbers.
Selecting and Using Menu Options
Various menus are available when you are using the WAP
Browser to navigate the Wireless Web.
To access a menu option, press the Menu soft key. A menu
list displays.
Note
: The menus may vary, depending on your version of the WAP
Browser.
The following options are available:
Favorites: shows the bookmarks list. You can bookmark the
current page or access previously bookmarked pages.
Reload: reloads the current page.
Home: takes you back at any time to the homepage of the
Wireless Web service provider.
Goto URL: allows you to manually enter the URL address of a
WAP site. After entering an address, press the OK soft key to
go there directly.
Show URL: displays the URL address of the page to which
you are currently connected. It also enables you to set the
current site as the startup homepage.
Clear Cache: deletes the information stored in the cache.
The cache stores the most recently accessed pages.
Using Favorites
Section 10 : WAP
Section 10
166
Inbox: allows you to read messages received from a WAP
server.
Show Images: shows the image on the current page. Press
the Next soft key to view the next images.
Text message: allows you to send an SMS message.
Certificates: shows the certificates downloaded via SSL
(Secure Sockets Layer) protocol.
Using Favorites
While navigating the WAP browser, you can bookmark a site
to quickly and easily access it at a future time. The URL
addresses of the bookmarked sites are stored in the Favorites
Bookmark folder.
Storing a URL Address
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select My MEdia → MEdia Net → Favorites Bookmark.
3. Select an empty location.
4. Enter the address and press the Enter soft key or the
key.
For further details about how to enter characters, see
page 56.
5. Enter a name for the bookmark and press the Enter soft
key or the key.
6. When you have finished, press the
key.
Using Favorites
167 Section 10 : WAP
Accessing a WAP Site Using Favorites
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select My MEdia → MEdia Net → Favorites Bookmark.
3. Select a bookmark item on the Favorite list.
4. Select Goto URL. You are sent to the corresponding WAP
site.
Editing a Bookmark
1. From the Favorite list, select the bookmark you want to
change.
2. Select Edit.
3. Change the address and the name, as you would when
storing a new one.
4. When you have finished, press the
key.
Deleting a Bookmark
1. From the Favorite list, select the bookmark you want to
delete.
2. Select Delete.
3. Press the Yes soft key or the key to confirm the
deletion.
4. When you have finished, press the
key.
Section 10 : WAP
Section 10
168
Downloading Media Content
You can buy a variety of multimedia files, such as ring tones,
graphics, applications, MMS contents, and so on, using the
WAP browser and download them to your phone’s memory.
Your phone has embedded links to WAP sites providing you
with download services, preset by your service provider.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select MEdia Mall → Shop Ringtones, Shop Games, Shop
Graphics, Shop Multimedia, or Shop Applications,
depending on the type of item(s) you want to buy.
To access the homepage of the online shopping mall,
select MEdia Home.
3. Find the item you want to download and follow the
instructions on the screen to buy it.
Note
: This content is delivered to you in MMS messages. You can
retrieve the messages from the server and then save the items in
your phone’s memory. You cannot forward these messages to other
people or add the saved items to an MMS message.
Using Downloaded Media Content
Once you have downloaded media content from the
Wireless Web, it is automatically saved in the folder
corresponding to the downloaded file type. You can access
these items from the My MEdia menu.
1. In Idle mode, press the Menu soft key to access the
Menu mode.
Downloading Media Content
169 Section 10 : WAP
2. Select My MEdia → Audio or Graphics, depending on the
type of item(s) you want to access.
3. Select the item you want to access from the list.
Note
:
Shop Ringtones
or
Shop Graphics
allows you to access the
preset web site to download more items.
While reviewing the item, you can access the following
options by pressing the Options soft key:
Rename: allows you to change the name of the item.
Delete: allows you delete the item.
Set as Wallpaper: sets the image as wallpaper for the idle
screen. This option is shown in the Graphics folder.
Set as Ringtone: sets the sound as your call ringer. This
option is shown in the Audio folder.
Properties: shows information about the item.
Deleting All Downloaded Media Content
You can clear media content folders one by one or all at one
time.
1. In Idle mode, press the Menu soft key to access the
Menu mode.
2. Select My MEdia → Delete All.
3. Select a media folder you want to clear. To clear all
folders, select All.
4. Press the Delete soft key.
Clearing the Cache
Section 10 : WAP
Section 10
170
5. Press the OK soft key to confirm the deletion.
6. Press the OK soft key to confirm the deletion again.
7. When you have finished, press the
key.
Clearing the Cache
The cache is the phone’s temporary memory in which the
most recently accessed WAP pages are stored. You should
clear the cache if you have accessed or have tried to access
confidential information.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select My MEdia → MEdia Net → Clear Cache.
3. Press the Yes soft key or the key to confirm the
deletion.
4. When you have finished, press the key.
Section 10 : WAP171
Changing the Profile for Accessing the
WAP
You can change the connection profile to be used for
accessing the WAP browser.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select My MEdia → MEdia Net → Settings.
3. Select a connection profile.
Note
: For details about setting up a profile, see page 121.
4. When you have finished, press the key.
Section 11 : Personal Assistant
Section 11
172
Section 11: Personal Assistant
Topics Covered
• Using the Calendar
• Using the To Do List
• Setting Alarms
• Using the Calculator
• Using the Currency Convertor
• Synchronizing PIM Data
This section explains how to use your phone’s PIM
(Personal Information Management) applications, such as
Alarm, Calendar, To Do List, Calculator, and Currency
Convertor. You can also synchronize your PIM data or your
phone’s network settings with the remote server or a PC.
Section 11 : Personal Assistant173
Using the Calendar
With the Calendar feature, you can:
• write memos to keep track of your schedule.
• consult the calendar and check your memos.
• set alarms to act as reminders.
Writing a Memo
You can create up to 100 memos for the calendar. More
than one memo can be written for one day.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Applications → Calendar. The calendar displays
with today’s day highlighted in blue.
3. Scroll to a date on the calendar by pressing the
Navigation keys and press the key.
Alternatively, press the Options soft key and select Go to
Date. You can manually enter a specific date and press
the OK soft key or the key.
Note
: To skip to the previous or next month, press the Volume
keys on the left side of the phone.
The New Memo screen displays allowing you to enter
your memo. If there is a memo already set, you need to
press the New soft key.
4. Enter your memo and then press the OK soft key or the
key.
For further details about how to enter characters, see
page 56.
Using the Calendar
Section 11 : Personal Assistant
Section 11
174
5. If you want an alarm to ring on the chosen day, press the
Yes soft key or the key. Continue to the next step.
Otherwise, press the No soft key. The memo is saved.
6. Enter the time for the alarm and press the key.
Note
: Your phone is preset to a 12-hour format. To change the
format, see page 124.
You can also select the melody for the alarm by pressing
the Melody soft key.
7. If applicable, select AM or PM.
The color of the date on the calendar changes to green
to indicate that a memo exists for that date.
8. When you have finished, press the key.
If you have set the alarm to ring in step 5, the phone plays
the selected alarm melody when the time for the memo
comes. Press the View soft key or the key to access the
memo. Alternatively, press the Exit soft key or the key to
stop the alarm.
Consulting the Calendar
Viewing Memos on a Selected Date
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Applications → Calendar.
3. Select the date for which you have entered the memo(s)
you want to view.
If there is more than one memo for that date, the latest
memo displays.
Using the Calendar
175 Section 11 : Personal Assistant
4. Press the Up or Down key to scroll to the previous or
next memo.
If you want to make a new memo for that date, press the
New soft key.
You can use the memo options. For details, see “Using
the Memo Options.”
5. When you have finished, press the key.
Viewing All of the Memos on the Calendar
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Applications → Calendar.
3. Press the Options soft key and select Search All.
4. Press the Up or Down key to scroll through the memos.
For details about memo options, see “Using the Memo
Options.”
5. When you have finished, press the key.
Using the Memo Options
From the memo detail view, you can access the memo
options by pressing the Options soft key.
• Edit: allows you to change the memo text.
• Alarm: allows you to set an alarm to ring at a specified time
to remind you of the memo. If you have already set an
alarm for that memo, you can change or delete the alarm.
• Delete: allows you to delete the memo.
• Copy to: allows you to copy the memo to another date.
• Move to: allows you to change the date of the memo.
Using the Calendar
Section 11 : Personal Assistant
Section 11
176
Deleting Memos
You can delete memos on the calendar one by one or all at
one time.
Deleting a Memo
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Applications → Calendar.
3. Select the date on which the memo you want to delete is
stored.
4. If there is more than one memo for that date, find the
memo you want.
5. Press the Options soft key and select Delete.
6. Press the OK soft key to confirm the deletion.
7. When you have finished, press the key.
Deleting All Memos
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Applications → Calendar.
3. Press the Options soft key and select Delete All.
4. Press the OK soft key to confirm the deletion.
5. Press the OK soft key to confirm the deletion again.
6. When you have finished, press the key.
Section 11 : Personal Assistant177
Using the To Do List
To Do List allows you to:
• enter a list of tasks to be done.
• assign priorities and deadlines to the tasks.
• sort the tasks by priority and status.
Creating the To Do List
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Applications → To Do List.
3. Press the New soft key or the key.
4. Enter the first task.
For further details about how to enter characters, see
page 56.
5. Press the OK soft key or the key.
6. Select a priority level of high, normal, or low.
7. Enter your deadline and press the OK soft key or the
key.
If you don’t want to set a deadline, press the Skip soft
key.
8. When you have finished, press the key.
Using the To Do List
Section 11 : Personal Assistant
Section 11
178
Adding Tasks to the To Do List
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Applications → To Do List.
3. Press the Options soft key and select New.
4. Follow from step 4 on page 177 to add a task.
Viewing the To Do List
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Applications → To Do List.
The tasks display with a check mark if the task has been
done, and a priority level indicator; for High, for
Normal, and for Low.
Note
: You can change the status of a specific task by pressing the
key. The task is marked as completed as of the current time and
date.
3. Scroll to a task from the list and press the key to view
the details for the task.
You can access the To Do List options by pressing the
Options soft key. For details, see page 179.
4. You can scroll through the tasks using the Up and Down
keys, if necessary.
5. When you have finished, press the key.
Using the To Do List
179 Section 11 : Personal Assistant
Using To Do List Options
From the To Do List detail view, you can access the
following options by pressing the Options soft key:
New: allows you to create a new task.
Mark: allows you to change the status of a task. Select the
appropriate status (Done or Undo).
Edit: allows you to edit a task. You can change the text,
priority, and/or deadline for the task.
Sort: allows you to sort the existing tasks by priority or status.
Select the sort criterion (High, Low, Done, or Undo).
Copy: allows you to copy a task.
Copy to Calendar: allows you to copy a task to the calendar
as a memo. You can also change the text and deadline for
the task and/or set an alarm.
Delete: deletes a task.
Delete All: allows you to delete all tasks.
Send VTodo: allows you to send the task to another phone as
part of an SMS message.
Exit: exits the To Do List menu.
Section 11 : Personal Assistant
Section 11
180
Setting Alarms
You can set an alarm to ring at a specific time. You can also
set the phone to switch on automatically and sound the
alarm even if the phone is switched off when the time
comes.
Setting an Alarm
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Applications → Alarm.
3. Select an alarm type.
• Single Use Alarm: the alarm rings only once and is then
deactivated.
• Daily Alarm: the alarm rings every day at the same time.
• Wake-up Call: the alarm rings to wake you up in the
morning.
4. Enter the time for the alarm to sound.
Note
: Your phone is preset to a 12-hour format. To change the
format, see page 124.
To change the alarm tone, press the Options soft key and
select Alarm Tone. Select an alarm tone from the list.
5. Press the OK soft key or the key.
6. If applicable, select AM or PM.
7. If you selected Wake-up Call in step 3, select a repeat
option, Monday to Friday or Monday to Saturday.
Setting Alarms
181 Section 11 : Personal Assistant
8. When you have finished, press the key.
When the time for an alarm comes, press any key to stop the
alarm.
Setting Autopower Alarms
You can set the phone to sound the alarm when the time for
an alarm comes, even if the phone is switched off.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Applications → Alarm → Autopower.
3. Select Enable to activate the autopower feature. The
phone will automatically switch on to sound the alarm
when the alarm time comes.
If the menu option is set to Disable and the phone is
switched off at the specified time, the alarm will not
sound.
4. When you have finished, press the key.
Deactivating Alarms
You can deactivate set alarms one by one or all at one time.
Deactivating an Alarm
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Applications → Alarm.
3. Select the alarm you want to remove.
Setting Alarms
Section 11 : Personal Assistant
Section 11
182
4. Press the Options soft key and select Remove Alarm.
5. When you have finished, press the key.
Deactivating All Alarms
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Applications → Alarm → Remove Alarm.
3. Press the OK soft key or the key to confirm the
deactivation.
4. When you have finished, press the key.
Section 11 : Personal Assistant183
Using the Calculator
You can use the phone as a calculator. The calculator
provides basic arithmetic functions: addition, subtraction,
multiplication, and division.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Applications → Calculator.
3. Enter the first number using the numeric keys.
Notes
:
• To insert a decimal point or a bracket, press the left soft key until
the symbol you want displays.
• To move the cursor, press the
or key.
4. Enter the operation for your calculation by pressing the
Navigation keys, according to the illustration on the
display.
5. Enter the second number.
6. Repeat steps 4 and 5 as many times as required.
7. To view the result, press the key.
8. When you have finished, press the key.
Section 11 : Personal Assistant
Section 11
184
Using the Currency Convertor
You can do currency conversions.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Applications → Currency Exchange.
3. Enter the current exchange rate of your source currency
to the foreign currency and press the OK soft key or the
key.
You can insert a decimal point by pressing the key.
4. Enter the amount of your source currency you want to
convert and press the OK soft key or the key.
The amount you entered and its equivalent value in the
foreign currency display.
5. When you have finished, press the key.
Section 11 : Personal Assistant185
Synchronizing PIM Data
You can synchronize personal information stored in
Address Book, Calendar, and To Do List with
corresponding PC applications by using the EasyStudio II
program supplied with your phone. You can also
synchronize with the remote server over a network
connection.
Starting Synchronization
1. If you are trying to synchronize your phone with your
PC, make sure that your PC has the EasyStudio II
program installed and the phone and the PC are
connected by a USB cable.
2. In Idle mode, press the Menu soft key to access Menu
mode.
3. Select Applications → PIM Sync → Start Sync. The
synchronization begins.
Viewing Synchronization Log
You can view the last synchronization and its result for each
application: Address Book, Calendar, and To do List.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Applications → PIM Sync → View Result.
Synchronizing PIM Data
Section 11 : Personal Assistant
Section 11
186
3. Press the Next soft key to view the sync result for the
application you want.
The displays shows the date the synchronization was
performed, the duration, the result, and the number of
items added, replaced, or deleted.
4. When you have finished, press the key.
Changing Synchronization Settings
You can configure synchronization settings and then just
select a setting group to be used for synchronization.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Applications → PIM Sync → Sync Settings.
3. Select a sync setting group.
The following options are available:
• Name: allows you to enter the name of the setting group.
• Category: allows you to select the application(s) you want
to synchronize. Select All to synchronize all of the items in
each application.
• Type: allows you to select the synchronization type, either
Normal Sync or Recovery Sync.
Normal Sync: the phone and PC/remote server
exchange only newly added, changed, or deleted data.
Recovery Sync: the phone sends all of its data to the
PC/remote server and the PC/remote server sends
only data that the phone does not contain.
Synchronizing PIM Data
187 Section 11 : Personal Assistant
• Protocol: allows you to select the terminal you want to
synchronize the phone with, either the network or a PC.
• Server: allows you to set up the remote server to be
synchronized with your phone. The following options are
available:
URL: enter the URL address of the remote server.
Sync DB: enter the database path for each application
on the server. For details, contact your remote server
provider.
User ID: enter the user ID for connecting to the server.
Password: enter the password.
4. When you have finished, press the key.
Changing the Profile for Synchronization
For synchronization with the remote server, you need to
select a profile to be used for a network connection.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Applications → PIM Sync → Profile.
3. Select a connection profile.
Note
: For details about setting up a profile, see page 121.
4. When you have finished, press the key.
Section 11 : Personal Assistant
Section 11
188
Managing Your Phone
You can synchronize your phone with the remote server of
your service provider or your PC to configure your phone's
various settings or update the phone’s firmware.
Starting Synchronization for Your Phone's
Configuration
1. If you are trying to synchronize your phone with your
PC, make sure that the phone and the PC are connected
by the USB cable.
2. In Idle mode, press the Menu soft key to access Menu
mode.
3. Select Applications → Device Management → Start DM.
A connection between your phone and the PC or remote
server is established and configuration begins.
Changing Device Management Settings
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Applications → Device Management → DM
Settings.
3. Select a DM setting group.
The following options are available:
• Name: allows you to enter the name of the setting group.
• Protocol: allows you to select the terminal with which you
want to synchronize the phone, either the network or a
PC.
Managing Your Phone
189 Section 11 : Personal Assistant
• Server: allows you to set up the remote server to be
synchronized with your phone. The following options are
available:
URL: enter the URL address of the remote server.
User ID: enter the user ID for connecting to the server.
Password: enter the password.
4. When you have finished, press the key.
Changing the Profile for Synchronization
For performing a server synchronization, you need to select
a profile for a network connection.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Applications → Device Management → Profile.
3. Select a connection profile.
Note
: For details about setting up a profile, see page 121.
4. When you have finished, press the key.
Section 12 : Additional Information
Section 12
190
Section 12: Additional
Information
Topics Covered
• Accessories
• Access Codes
This section give you information on accessories available
for your phone and various access codes which can be used
to protect your phone from unauthorized use.
Section 12 : Additional Information191
Accessories
You can buy the following accessories from your local
Samsung dealer.
Standard/Extended Battery
The Li-ion 80/1000 mAh battery provides up to ?? hours of
continuous talk time or up to ?? hours of continuos standby
time.
Travel Adapter
The compact and lightweight travel adapter gives you a
convenient way to charge your phone while on the road.
Battery Charger
The battery charger charges the battery alone. If you have an
extra battery, you can charge it without the phone.
Simple Handsfree Car Kit
This allows you to operate your phone hands-free so that
you can drive safely. The Simple Handsfree car kit contains a
car cradle, a car charger, and a straight headset.
Car Charger
This charger allows you to connect your phone to the
cigarette lighter of your car to charge the phone using your
car’s battery.
Car Cradle
The car cradle holds your phone safely while you are driving.
Accessories
Section 12 : Additional Information
Section 12
192
Straight Headset
The straight headset allows you to make or receive a call
without holding your phone, while you are on the walk or
driving. Also, you can enjoy music in public places without
annoying other people.
PC Link CD
This CD-ROM contains the EasyStudio II program, which
allows you to manage your personal information, such as
Address Book, Schedule, or To Do List, synchronize these
data with your phone’s corresponding applications, and
download multimedia files like ring tones, and images, to the
phone.
PC Data Cable
This cable connects your phone to a PC via a USB port.
PC Link Kit
The PC Link Kit contains a PC link CD and a PC cable.
Section 12 : Additional Information193
Access Codes
There are several access codes that are used by your phone
and its SIM card. These codes help you protect the phone
against unauthorized use.
When requested for any of the codes explained below, enter
the appropriate code (displayed as asterisks) and press the
OK soft key or the key. If you make a mistake, press the C
key until the incorrect digit is cleared and then continue
entering the correct code.
The access codes, except for the PUK and PUK2 codes can
be changed using the Security menu. See page 135 for
further details.
Important!
Avoid using access codes resembling emergency numbers, such as
911, to prevent accidental dialing of an emergency number.
Phone Password
The phone lock feature uses the phone password to protect
your phone against unauthorized use. The phone password
is supplied with the phone and is preset to “00000000” at
the factory.
To See
activate/deactivate the phone
lock feature page 136.
change the phone password page 136.
Access Codes
Section 12 : Additional Information
Section 12
194
PIN
The Personal Identification Number or PIN (4 to 8 digits)
protects your SIM card against unauthorized use. It is
usually supplied with the SIM card.
If you enter an incorrect PIN three times in succession, the
code is disabled and cannot be used until you re-enable it by
entering the PUK. See below.
PUK
The 8-digit PUK (PIN Unblocking Key) is required to
change a disabled PIN. The PUK may be supplied with the
SIM card. If not, contact your service provider.
To re-enable your PIN:
1. Enter the PUK and press the OK soft key or the key.
2. Enter a PIN of your choice and press the OK soft key or
the key.
3. When the Confirm New PIN message displays, enter the
same code again and press the OK soft key or the key.
When you enter an incorrect PUK ten times in succession,
the SIM card becomes invalid. Contact your service provider
for a new card.
To See
activate/deactivate the PIN
check feature page 135.
change the PIN page 135.
Access Codes
195 Section 12 : Additional Information
PIN2
The PIN2 (4 to 8 digits), supplied with some SIM cards, is
required to access specific functions, such as setting the
maximum cost of a call. These functions are available if
supported by your SIM card.
If you enter an incorrect PIN2 three times in succession, the
code is disabled and you cannot access the functions until
you re-enable it by entering the PUK2.
To change the PIN2, see page 137.
PUK2
The 8-digit PUK2 (PIN Unblocking Key 2), supplied with
some SIM cards, is required to change a disabled PIN2. If
you lose the code, contact your service provider.
To re-enable your PIN2:
1. Enter the PUK2 and press the OK soft key or the key.
2. Enter a new PIN2 of your choice and press the OK soft
key or the key.
3. When the Confirm PIN2 message displays, enter the same
code again and press the OK soft key or the key.
When you enter an incorrect PUK2 ten times in succession,
you are not able to access the functions requiring the PIN2.
Contact your service provider for a new card.
Access Codes
Section 12 : Additional Information
Section 12
196
Barring Password
A 4-digit barring password is required when you use the Call
Barring function. You can obtain the password from your
service provider when you subscribe to this function.
You can change this password in the Call Barring menu. See
page 128 for further details.
Note
: The Call Barring function may not be available depending on
your particular SIM card.
Section 12 : Additional Information197
Section 13 : Health and Safety Information
Section 13
198
Section 13: Health and Safety
Information
Topics Covered
• Exposure to Radio Frequency (RF) Signals
• For Body Operation
• Precautions When Using Batteries
• Road Safety
• Operating Environment
• Electronic Devices
• Potentially Explosive Environments
• Emergency Calls
• Other Important Safety Information
• Care and Maintenance
• Acknowledging Special Precautions and the FCC and Industry
Canada Notice
This section give you important information on your health
and safety while using your mobile phone.
Section 13 : Health and Safety Information199
Exposure to Radio Frequency (RF)
Signals
Your wireless phone is a radio transmitter and receiver. It is
designed and manufactured not to exceed the emission
limits for exposure to radio frequency (RF) energy set by the
Federal Communications Commission (FCC) of the U.S.
Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for
the general population. The guidelines are based on the
safety standards that were developed by independent
scientific organizations through periodic and through
evaluation of scientific studies.
The standards include a substantial safety margin designed
to assure the safety of all persons, regardless of age and
health.
The exposure standard for wireless phones employs a unit
of measurement known as Specific Absorption Rate (SAR).
The SAR limit recommended by the FCC is 1.6W/kg.*
SAR tests are conducted using standard operating positions
specified by the FCC with the phone transmitting at its
highest certified power level in all tested frequency bands.
Although the SAR is determined at the highest certified
power level, the actual SAR level of the phone while
operating can be well below the maximum value. This is
because the phone is designed to operate at multiple power
levels so as to use only the power required to reach the
* In the U.S. and Canada, the SAR limit for mobile phones used by
the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue.
The standard incorporates a substantial margin of safety to give
additional protection for the public and to account for any varia-
tions in measurements.
Section 13 : Health and Safety Information
Section 13
200
network. In general, the closer you are to a wireless base
station antenna, the lower the power output of the phone.
Before a new model phone is available for sale to the public,
it must be tested and certified to the FCC that it does not
exceed the limit established by the government adopted
requirement for safe exposure. The tests are performed in
positions and locations (e.g., at the ear and worn on the
body) as required by the FCC for each model. While there
may be differences between the SAR levels of various
phones and at various positions, they all meet the
government requirement.
The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as in
compliance with the FCC RF exposure guidelines. The
maximum SAR values for this model phone as reported to
the FCC are:
• Head : GSM850:0.681 W/kg., PCS:0.802 W/kg.
• Body-worn : GSM850:0.774 W/kg., PCS:0.629 W/kg.
SAR information on this model phone is on file with the
FCC and can be found under the Display Grant section of
http://www.fcc.gov/oet/fccid after searching on FCC ID
A3LSGHP207.
201 Section 13 : Health and Safety Information
For Body Operation
To maintain compliance with FCC RF exposure requirements,
use only belt-clips, holsters or similar accessories that
maintain a 1.5 cm. separation distance between the user's body
and the back of the phone, including the antenna. The use of
belt-clips, holsters and similar accessories should not contain
metallic components in its assembly. The use of accessories
that do not satisfy these requirements may not comply with
FCC RF exposure requirements, and should be avoided.
For more Information concerning exposure to radio
frequency signals, see the following websites:
Federal Communications Commission (FCC)
http://www.fcc.gov
Cellular Telecommunications Industry Association (CTIA):
http://www.wow-com.com
U.S.Food and Drug Administration (FDA)
http://www.fda.gov/cdrh/consumer
World Health Organization (WHO)
http://www.who.int/peh-emf/en
Section 13 : Health and Safety Information
Section 13
202
Precautions When Using Batteries
• Never use any charger or battery that is damaged in any
way.
• Use the battery only for its intended purpose.
• If you use the phone near the network’s base station, it
uses less power; talk and standby time are greatly affected
by the signal strength on the cellular network and the
parameters set by the network operator.
• Battery charging time depends on the remaining battery
charge, the type of battery and the charger used. The
battery can be charged and discharged hundreds of times,
but it will gradually wear out. When the operation time
(talk time and standby time) is noticeably shorter than
normal, it is time to buy a new battery.
• If left unused, a fully charged battery will discharge itself
over time.
• Use only Samsung-approved batteries and recharge your
battery only with Samsung-approved chargers. When a
charger is not in use, disconnect it from the power source.
Do not leave the battery connected to a charger for more
than a week, since overcharging may shorten its life.
• Extreme temperatures will affect the charging capacity of
your battery: it may require cooling or warming first.
• Do not leave the battery in hot or cold places, such as in a
car in summer or winter conditions, as you will reduce the
capacity and lifetime of the battery. Always try to keep the
battery at room temperature. A phone with a hot or cold
battery may temporarily not work, even when the battery
is fully charged. Li-ion batteries are particularly affected by
temperatures below 0 °C (32 °F).
203 Section 13 : Health and Safety Information
• Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object (coin, clip or
pen) causes a direct connection between the + and –
terminals of the battery (metal strips on the battery), for
example when you carry a spare battery in a pocket or bag.
Short-circuiting the terminals may damage the battery or
the object causing the short-circuiting.
• Dispose of used batteries in accordance with local
regulations. Always recycle. Do not dispose of batteries in
a fire.
Road Safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime. But an
important responsibility accompanies the benefits of
wireless phones, one that every user must uphold.
When driving a car, driving is your first responsibility. When
using your wireless phone behind the wheel of a car, practice
good common sense and remember the following tips:
• Get to know your wireless phone and its features, such as
speed dial and redial. If available, these features help you
to place your call without taking your attention off the
road.
• When available, use a hands-free device. If possible, add an
extra layer of convenience and safety to your wireless
phone with one of the many hands-free accessories
available today.
• Position your wireless phone within easy reach. Be able to
access your wireless phone without removing your eyes
from the road. If you get an incoming call at an
inconvenient time, let your voice mail answer it for you.
Section 13 : Health and Safety Information
Section 13
204
• Let the person you are speaking with know you are driving;
if necessary, suspend the call in heavy traffic or hazardous
weather conditions. Rain, sleet, snow, ice, and even heavy
traffic can be hazardous.
• Do not take notes or look up phone numbers while
driving. Jotting down a To Do list or flipping through your
Address Book takes your attention away from your
primary responsibility, driving safely.
• Dial sensibly and assess the traffic; if possible, place calls
when you are not moving or before pulling into traffic.
Try to plan calls when your car will be stationary. If you
need to make a call while moving, dial only a few numbers,
check the road and your mirrors, then continue.
• Do not engage in stressful or emotional conversations that
may be distracting. Make the people with whom you are
talking aware that you are driving and suspend
conversations that have the potential to divert your
attention from the road.
• Use your wireless phone to call for help. Dial the
emergency number in the case of fire, traffic accident or
medical emergencies. Remember, it is a free call on your
wireless phone!
• Use your wireless phone to help others in emergencies. If
you see a car accident, crime in progress or other serious
emergency where lives are in danger, call the emergency
number, as you would want others to do for you.
• If you see a broken-down vehicle posing no serious hazard,
a broken traffic signal, a minor traffic accident where no
one appears injured, or a vehicle you know to be stolen,
call roadside assistance or any other special non-
emergency wireless number.
205 Section 13 : Health and Safety Information
Operating Environment
Remember to follow any special regulations in force in any
area and always switch off your phone whenever it is
forbidden to use it, or when it may cause interference or
danger.
When connecting the phone or any accessory to another
device, read its user’s guide for detailed safety instructions.
Do not connect incompatible products.
As with other mobile radio transmitting equipment, users
are advised that for the satisfactory operation of the
equipment and for the safety of personnel, it is
recommended that the equipment should only be used in
the normal operating position (held to your ear with the
antenna pointing over your shoulder).
Section 13 : Health and Safety Information
Section 13
206
Electronic Devices
Most modern electronic equipment is shielded from radio
frequency (RF) signals. However, certain electronic
equipment may not be shielded against the RF signals from
your wireless phone. Consult the manufacturer to discuss
alternatives.
Pacemakers
Pacemaker manufacturers recommend that a minimum
distance of 15 cm (6 inches) be maintained between a
wireless phone and a pacemaker to avoid potential
interference with the pacemaker. These recommendations
are consistent with the independent research and
recommendations of Wireless Technology Research.
Persons with pacemakers:
• should always keep the phone more than 15 cm (6 inches)
from their pacemaker when the phone is switched on.
• should not carry the phone in a breast pocket.
• should use the ear opposite the pacemaker to minimize
potential interference.
If you have any reason to suspect that interference is taking
place, switch off your phone immediately.
Hearing Aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you may wish
to consult your hearing aid manufacturer to discuss
alternatives.
207 Section 13 : Health and Safety Information
Other Medical Devices
If you use any other personal medical devices, consult the
manufacturer of your device to determine if it is adequately
shielded from external RF energy. Your physician may be
able to assist you in obtaining this information. Switch off
your phone in health care facilities when any regulations
posted in these areas instruct you to do so. Hospitals or
health care facilities may be using equipment that could be
sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles. Check with
the manufacturer or its representative regarding your
vehicle. You should also consult the manufacturer of any
equipment that has been added to your vehicle. You should
also consult the manufacturer of any equipment that has
been added to your vehicle.
Posted Facilities
Switch off your phone in any facility where posted notices
require you to do so.
Section 13 : Health and Safety Information
Section 13
208
Potentially Explosive Environments
Switch off your phone when in any area with a potentially
explosive atmosphere and obey all signs and instructions.
Sparks in such areas could cause an explosion or fire
resulting in bodily injury or even death.
Users are advised to switch off the phone while at a
refueling point (service station). Users are reminded of the
need to observe restrictions on the use of radio equipment
in fuel depots (fuel storage and distribution areas), chemical
plants or where blasting operations are in progress.
Areas with a potentially explosive atmosphere are often but
not always clearly marked. They include the areas below
deck on boats, chemical transfer or storage facilities, vehicles
using liquefied petroleum gas (such as propane or butane),
areas where the air contains chemicals or particles, such as
grain, dust or metal powders, and any other area where you
would normally be advised to turn off your vehicle engine.
209 Section 13 : Health and Safety Information
Emergency Calls
This phone, like any wireless phone, operates using radio
signals, wireless and landline networks as well as user-
programmed functions, which cannot guarantee connection
in all conditions. Therefore, you should never rely solely on
any wireless phone for essential communications (medical
emergencies, for example).
Remember, to make or receive any calls the phone must be
switched on and in a service area with adequate signal
strength. Emergency calls may not be possible on all
wireless phone networks or when certain network services
and/or phone features are in use. Check with local service
providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present location
(for example, 911 or other official emergency number).
Emergency numbers vary by location.
3. Press the key.
If certain features are in use (call barring, for example), you
may first need to deactivate those features before you can
make an emergency call. Consult this document and your
local cellular service provider.
When making an emergency call, remember to give all the
necessary information as accurately as possible. Remember
that your phone may be the only means of communication
at the scene of an accident; do not end the call until given
permission to do so.
Section 13 : Health and Safety Information
Section 13
210
Other Important Safety Information
• Only qualified personnel should service the phone or
install the phone in a vehicle. Faulty installation or service
may be dangerous and may invalidate any warranty
applicable to the device.
• Check regularly that all wireless phone equipment in your
vehicle is mounted and operating properly.
• Do not store or carry flammable liquids, gases, or
explosive materials in the same compartment as the
phone, its parts or accessories.
• For vehicles equipped with an air bag, remember that an
air bag inflates with great force. Do not place objects,
including both installed or portable wireless equipment in
the area over the air bag or in the air bag deployment area.
If wireless equipment is improperly installed and the air
bag inflates, serious injury could result.
• Switch off your phone before boarding an aircraft. The use
of wireless phones in aircraft is illegal and may be
dangerous to the aircraft’s operation.
• Failure to observe these instructions may lead to the
suspension or denial of telephone services to the offender,
or legal action, or both.
211 Section 13 : Health and Safety Information
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for many
years:
• Keep the phone and all its parts and accessories out of the
reach of small children’s.
• Keep the phone dry. Precipitation, humidity and liquids
contain minerals that will corrode electronic circuits.
• Do not use the phone with a wet hand. Doing so may
cause an electric shock to you or damage to the phone.
• Do not use or store the phone in dusty, dirty areas, as its
moving parts may be damaged.
• Do not store the phone in hot areas. High temperatures
can shorten the life of electronic devices, damage batteries,
and warp or melt certain plastics.
• Do not store the phone in cold areas. When the phone
warms up to its normal operating temperature, moisture
can form inside the phone, which may damage the phone’s
electronic circuit boards.
• Do not drop, knock or shake the phone. Rough handling
can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents or strong
detergents to clean the phone. Wipe it with a soft cloth
slightly dampened in a mild soap-and-water solution.
• Do not paint the phone. Paint can clog the device’s moving
parts and prevent proper operation.
Section 13 : Health and Safety Information
Section 13
212
• Do not put the phone in or on heating devices, such as a
microwave oven, a stove or a radiator. The phone may
explode when overheated.
• Use only the supplied or an approved replacement
antenna. Unauthorized antennas or modified accessories
may damage the phone and violate regulations governing
radio devices.
• If the phone, battery, charger or any accessory is not
working properly, take it to your nearest qualified service
facility. The personnel there will assist you, and if
necessary, arrange for service.
Acknowledging Special Precautions
and the FCC and Industry Canada
Notice
Cautions
Modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.
FCC Compliance Information
This device complies with Part 15 of FCC Rules. Operation
is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received.
Including interference that may cause undesired operation.
213 Section 13 : Health and Safety Information
Information to User
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/ TV technician
for help.
Section 13 : Health and Safety Information
Section 13
214
Appendix A: CERTIFICATION
INFORMATION (SAR)
THIS MODEL PHONE MEETS THE
GOVERNMENT’S REQUIREMENTS FOR
EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It is
designed and manufactured not to exceed the emission
limits for exposure to radio frequency (RF) energy set by the
Federal Communications Commission of the U.S.
Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for
the general population. The guidelines are based on safety
standards that were developed by independent scientific
organizations through periodic and thorough evaluation of
scientific studies. The standards include a substantial safety
margin designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless mobile phones employs
a unit of measurement known as the Specific Absorption
Rate (SAR). The SAR limit set by the FCC is 1.6 W/kg. SAR
Tests are conducted using standard operating positions
accepted by the FCC with the phone transmitting at its
highest certified power level in all tested frequency bands.
Although the SAR is determined at the highest certified
power level, the actual SAR level of the phone while
operating can be well below the maximum value. This is
because the phone is designed to operate at multiple power
levels so as to use only the power required to reach the
network. In general, the closer you are to a wireless base
station antenna, the lower the power output.
215 Section 13 : Health and Safety Information
Before a new model phone is available for sale to the public,
it must be tested and certified to the FCC that it does not
exceed the limit established by the government adopted
requirement for safe exposure. The tests are performed in
positions and locations(e.g., at the ear and worn on the
body) as required by the FCC for each model.
The highest SAR values of this model phone as reported to
FCC are Head: 0.681W/kg, Body-worn: 0.774W/kg in GSM
850 and Head: 0.802W/kg, Body-worn: 0.629W/kg in GSM
1900.
The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as in
compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC
and can be found under the Display Grant section of http:/
/www.fcc.gov/oet/fccid after searching on FCC ID
A3LSGHP207.
In the United States and Canada, the SAR limit for mobile phones
used by the public is 1.6 watts/kilogram (W/kg) averaged over one
gram of tissue. The standard incorporates a substantial ma gin of
safety to give additional protection for the public and to account for
any variations in measurements.
Section 13 : Health and Safety Information
Section 13
216
Appendix B: Guide to Safe and
Responsible Wireless Phone Use
Cellular Telecommunications & Internet Association
“Safety is the most important call you will ever make.”
A Guide to Safe and Responsible Wireless Phone Use
TENS OF MILLIONS OF PEOPLE IN THE U.S.
TODAY TAKE ADVANTAGE OF THE UNIQUE
COMBINATION OF CONVENIENCE, SAFETY AND
VALUE DELIVERED BY THE WIRELESS
TELEPHONE. QUITE SIMPLY, THE WIRELESS
PHONE GIVES PEOPLE THE POWERFUL ABILITY
TO COMMUNICATE BY VOICE-ALMOST
ANYWHERE, ANYTIME-WITH THE BOSS, WITH A
CLIENT, WITH THE KIDS, WITH EMERGENCY
PERSONNEL OR EVEN WITH THE POLICE. EACH
YEAR, AMERICANS MAKE BILLIONS OF CALLS
FROM THEIR WIRELESS PHONES, AND THE
NUMBERS ARE RAPIDLY GROWING.
But an important responsibility accompanies those benefits,
one that every wireless phone user must uphold. When
driving a car, driving is your first responsibility. A wireless
phone can be an invaluable tool, but good judgment must be
exercised at all times while driving a motor vehicle whether
on the phone or not.
The basic lessons are ones we all learned as teenagers.
Driving requires alertness, caution and courtesy. It requires a
heavy dose of basic common sense-keep your head up, keep
your eyes on the road, check your mirrors frequently and
watch out for other drivers.
217 Section 13 : Health and Safety Information
It requires obeying all traffic signs and signals and staying
within the speed limit. It means using seat belts and
requiring other passengers to do the same.
But with wireless phone use, driving safely means a little
more. This brochure is a call to wireless phone users
everywhere to make safety their first priority when behind
the wheel of a car. Wireless telecommunications is keeping
us in touch, simplifying our lives, protecting us in
emergencies and providing opportunities to help others in
need. When it comes to the use of wireless phones, safety is
your most important call.
Wireless Phone “Safety Tips”
Below are safety tips to follow while driving and using a
wireless phone which should be easy to remember:
1. Get to know your wireless phone and its features such as
speed dial and redial. Carefully read your instruction
manual and learn to take advantage of valuable features
most phones offer, including automatic redial and
memory. Also, work to memorize the phone keypad so
you can use the speed dial function without taking your
attention off the road.
2. When available, use a hands free device. A number of
hands free wireless phone accessories are readily
available today. Whether you choose an installed
mounted device for your wireless phone or a speaker
phone accessory, take advantage of these devices if
available to you.
3. Position your wireless phone within easy reach. Make
sure you place your wireless phone within easy reach and
where you can grab it without removing your eyes from
the road. If you get an incoming call at an inconvenient
time, if possible, let your voice mail answer it for you.
Section 13 : Health and Safety Information
Section 13
218
4. Suspend conversations during hazardous driving
conditions or situations. Let the person you are speaking
with know you are driving; if necessary, suspend the call
in heavy traffic or hazardous weather conditions. Rain,
sleet, snow and ice can be hazardous, but so is heavy
traffic. As a driver, your first responsibility is to pay
attention to the road.
5. Do not take notes or look up phone numbers while
driving. If you are reading an address book or business
card, or writing a “to do” list while driving a car, you are
not watching where you are going. It’s common sense.
Don’t get caught in a dangerous situation because you
are reading or writing and not paying attention to the
road or nearby vehicles.
6. Dial sensibly and assess the traffic; if possible, place calls
when you are not moving or before pulling into traffic.
Try to plan your calls before you begin your trip or
attempt to coincide your calls with times you may be
stopped at a stop sign, red light or otherwise stationary.
But if you need to dial while driving, follow this simple
tip-dial only a few numbers, check the road and your
mirrors, then continue.
7. Do not engage in stressful or emotional conversations
that may be distracting. Stressful or emotional
conversations and driving do not mix-they are distracting
and even dangerous when you are behind the wheel of a
car. Make people you are talking with aware you are
driving and if necessary, suspend conversations which
have the potential to divert your attention from the road.
219 Section 13 : Health and Safety Information
8. Use your wireless phone to call for help. Your wireless
phone is one of the greatest tools you can own to protect
yourself and your family in dangerous situations-with
your phone at your side, help is only three numbers away.
Dial 9-1-1 or other local emergency number in the case
of fire, traffic accident, road hazard or medical
emergency. Remember, it is a free call on your wireless
phone!
9. Use your wireless phone to help others in emergencies.
Your wireless phone provides you a perfect opportunity
to be a “Good Samaritan” in your community. If you see
an auto accident, crime in progress or other serious
emergency where lives are in danger, call 9-1-1 or other
local emergency number, as you would want others to do
for you.
10. Call roadside assistance or a special wireless non
emergency assistance number when necessary. Certain
situations you encounter while driving may require
attention, but are not urgent enough to merit a call for
emergency services. But you still can use your wireless
phone to lend a hand. If you see a broken-down vehicle
posing no serious hazard, a broken traffic signal, a minor
traffic accident where no one appears injured or a vehicle
you know to be stolen, call roadside assistance or other
special non-emergency wireless number.
Careless, distracted individuals and people driving
irresponsibly represent a hazard to everyone on the road.
Since 1984, the Cellular Telecommunications Industry
Association and the wireless industry have conducted
educational outreach to inform wireless phone users of their
responsibilities as safe drivers and good citizens. As we
approach a new century, more and more of us will take
advantage of the benefits of wireless telephones.
Section 13 : Health and Safety Information
Section 13
220
And, as we take to the roads, we all have a responsibility to
drive safely.
“The wireless industry reminds you to use your phone safely
when driving.”
Cellular Telecommunications & Internet Association For
more information, please call 1-888-901-SAFE.
For updates: http://www.wow-com.com/consumer/issues/
driving/articles.cfm?ID =85
Appendix C: Consumer Update on
Wireless Phones
U.S. Food and Drug Administration
1. What kinds of phones are the subject of this update?
The term wireless phone refers here to hand-held
wireless phones with built-in antennas, often called cell,
mobile, or PCS phones. These types of wireless phones
can expose the user to measurable radio frequency
energy (RF) because of the short distance between the
phone and the user s head. These RF exposures are
limited by Federal Communications Commission safety
guidelines that were developed with the advice of FDA
and other federal health and safety agencies. When the
phone is located at greater distances from the user, the
exposure to RF is drastically lower because a person’s RF
exposure decreases rapidly with increasing distance from
the source. The so-called “cordless phones,” which have
a base unit connected to the telephone wiring in a house,
typically operate at far lower power levels, and thus
produce RF exposures well within the FCC’s compliance
limits.
221 Section 13 : Health and Safety Information
2. Do wireless phones pose a health hazard?
The available scientific evidence does not show that any
health problems are associated with using wireless
phones. There is no proof, however, that wireless phones
are absolutely safe. Wireless phones emit low levels of
radio frequency energy (RF) in the microwave range
while being used. They also emit very low levels of RF
when in the stand-by mode. Whereas high levels of RF
can produce health effects (by heating tissue), exposure
to low level RF that does not produce heating effects
causes no known adverse health effects. Many studies of
low level RF exposures have not found any biological
effects. Some studies have suggested that some
biological effects may occur, but such findings have not
been confirmed by additional research. In some cases,
other researchers have had difficulty in reproducing
those studies, or in determining the reasons for
inconsistent results.
3. What is FDA’s role concerning the safety of wireless
phones?
Under the law, FDA does not review the safety of
radiation emitting consumer products such as wireless
phones before they can be sold, as it does with new
drugs or medical devices. However, the agency has
authority to take action if wireless phones are shown to
emit radio frequency energy (RF) at a level that is
hazardous to the user. In such a case, FDA could require
the manufacturers of wireless phones to notify users of
the health hazard and to repair, replace or recall the
phones so that the hazard no longer exists.
Section 13 : Health and Safety Information
Section 13
222
Although the existing scientific data do not justify FDA
regulatory actions, FDA has urged the wireless phone
industry to take a number of steps, including the
following:
• Support needed research into possible biological effects of
RF of the type emitted by wireless phones;
• Design wireless phones in a way that minimizes any RF
exposure to the user that is not necessary for device
function; and
• Cooperate in providing users of wireless phones with the
best possible information on possible effects of wireless
phone use on human health
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at the
federal level. The following agencies belong to this
working group:
• National Institute for Occupational Safety and Health
• Environmental Protection Agency Federal
Communications Commission
• Occupational Safety and Health Administration
• National Telecommunications and Information
Administration
• The National Institutes of Health participates in some
interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless
phones with the Federal Communications Commission
(FCC). All phones that are sold in the United States must
comply with FCC safety guidelines that limit RF
exposure. FCC relies on FDA and other health agencies
for safety questions about wireless phones.
223 Section 13 : Health and Safety Information
FCC also regulates the base stations that the wireless
phone networks rely upon. While these base stations
operate at higher power than do the wireless phones
themselves, the RF exposures that people get from these
base stations are typically thousands of times lower than
those they can get from wireless phones. Base stations
are thus not the primary subject of the safety questions
discussed in this document.
4. What is FDA doing to find out more about the possible
health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology
Program and with groups of investigators around the
world to ensure that high priority animal studies are
conducted to address important questions about the
effects of exposure to radio frequency energy (RF).
FDA has been a leading participant in the World Health
Organization International Electromagnetic Fields
(EMF) Project since its inception in 1996. An influential
result of this work has been the development of a
detailed agenda of research needs that has driven the
establishment of new research programs around the
world. The Project has also helped develop a series of
public information documents on EMF issues.
FDA and the Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative Research
and Development Agreement (CRADA) to do research
on wireless phone safety. FDA provides the scientific
oversight, obtaining input from experts in government,
industry, and academic organizations. CTIA-funded
research is conducted through contracts to independent
investigators. The initial research will include both
laboratory studies and studies of wireless phone users.
Section 13 : Health and Safety Information
Section 13
224
The CRADA will also include a broad assessment of
additional research needs in the context of the latest
research developments around the world.
5. What steps can I take to reduce my exposure to radio
frequency energy from my wireless phone?
If there is a risk from these products—and at this point
we do not know that there is—it is probably very small.
But if you are concerned about avoiding even potential
risks, you can take a few simple steps to minimize your
exposure to radio frequency energy (RF). Since time is a
key factor in how much exposure a person receives,
reducing the amount of time spent using a wireless
phone will reduce RF exposure.
If you must conduct extended conversations by wireless
phone every day, you could place more distance between
your body and the source of the RF, since the exposure
level drops off dramatically with distance. For example,
you could use a headset and carry the wireless phone
away from your body or use a wireless phone connected
to a remote antenna
Again, the scientific data do not demonstrate that
wireless phones are harmful. But if you are concerned
about the RF exposure from these products, you can use
measures like those described above to reduce your RF
exposure from wireless phone use.
6. What about children using wireless phones?
The scientific evidence does not show a danger to users
of wireless phones, including children and teenagers. If
you want to take steps to lower exposure to radio
frequency energy (RF), the measures described above
would apply to children and teenagers using wireless
225 Section 13 : Health and Safety Information
phones. Reducing the time of wireless phone use and
increasing the distance between the user and the RF
source will reduce RF exposure.
Some groups sponsored by other national governments
have advised that children be discouraged from using
wireless phones at all. For example, the government in
the United Kingdom distributed leaflets containing such
a recommendation in December 2000. They noted that
no evidence exists that using a wireless phone causes
brain tumors or other ill effects. Their recommendation
to limit wireless phone use by children was strictly
precautionary; it was not based on scientific evidence
that any health hazard exists.
7. Do hands-free kits for wireless phones reduce risks from
exposure to RF emissions?
• Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that hands-free kits reduce risks. Hands-free kits
can be used with wireless phones for convenience and
comfort. These systems reduce the absorption of RF
energy in the head because the phone, which is the source
of the RF emissions, will not be placed against the head.
On the other hand, if the phone is mounted against the
waist or other part of the body during use, then that part
of the body will absorb more RF energy. Wireless phones
marketed in the U.S. are required to meet safety
requirements regardless of whether they are used against
the head or against the body. Either configuration should
result in compliance with the safety limit.
Section 13 : Health and Safety Information
Section 13
226
8. Do wireless phone accessories that claim to shield the
head from RF radiation work?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that accessories that claim to shield the head
from those emissions reduce risks. Some products that
claim to shield the user from RF absorption use special
phone cases, while others involve nothing more than a
metallic accessory attached to the phone. Studies have
shown that these products generally do not work as
advertised. Unlike “hand-free” kits, these so-called
“shields” may interfere with proper operation of the
phone. The phone may be forced to boost its power to
compensate, leading to an increase in RF absorption. In
February 2002, the Federal trade Commission (FTC)
charged two companies that sold devices that claimed to
protect wireless phone users from radiation with making
false and unsubstantiated claims. According to FTC,
these defendants lacked a reasonable basis to
substantiate their claim.
9. What about wireless phone interference with medical
equipment?
Radio frequency energy (RF) from wireless phones can
interact with some electronic devices. For this reason,
FDA helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted cardiac
pacemakers and defibrillators from wireless telephones.
This test method is now part of a standard sponsored by
the Association for the Advancement of Medical
instrumentation (AAMI). The final draft, a joint effort
by FDA, medical device manufacturers, and many other
227 Section 13 : Health and Safety Information
groups, was completed in late 2000. This standard will
allow manufacturers to ensure that cardiac pacemakers
and defibrillators are safe from wireless phone EMI.
FDA has tested hearing aids for interference from
handheld wireless phones and helped develop a
voluntary standard sponsored by the Institute of
Electrical and Electronic Engineers (IEEE). This
standard specifies test methods and performance
requirements for hearing aids and wireless phones so
that no interference occurs when a person uses a
compatible phone and a compatible hearing aid at the
same time. This standard was approved by the IEEE in
2000.
FDA continues to monitor the use of wireless phones
for possible interactions with other medical devices.
Should harmful interference be found to occur, FDA
will conduct testing to assess the interference and work
to resolve the problem.
10.What are the results of the research done already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws in
their research methods. Animal experiments
investigating the effects of radio frequency energy (RF)
exposures characteristic of wireless phones have yielded
conflicting results that often cannot be repeated in other
laboratories. A few animal studies, however, have
suggested that low levels of RF could accelerate the
development of cancer in laboratory animals. However,
many of the studies that showed increased tumor
development used animals that had been genetically
engineered or treated with cancer causing chemicals so
as to be pre-disposed to develop cancer in the absence of
Section 13 : Health and Safety Information
Section 13
228
RF exposure. Other studies exposed the animals to RF
for up to 22 hours per day. These conditions are not
similar to the conditions under which people use wireless
phones, so we don t know with certainty what the results
of such studies mean for human health.
Three large epidemiology studies have been published
since December 2000. Between them, the studies
investigated any possible association between the use of
wireless phones and primary brain cancer, gioma,
meningioma, or acoustic neuroma, tumors of the brain
or salivary gland, leukemia, or other cancers. None of the
studies demonstrated the existence of any harmful health
effects from wireless phone RF exposures. However,
none of the studies can answer questions about long-
term exposures, since the average period of phone use in
these studies was around three years.
11. What research is needed to decide whether RF exposure
from wireless phones poses a health risk?
A combination of laboratory studies and epidemiological
studies of people actually using wireless phones would
provide some of the data that are needed. Lifetime
animal exposure studies could be completed in a few
years. However, very large numbers of animals would be
needed to provide reliable proof of a cancer promoting
effect if one exists. Epidemiological studies can provide
data that is directly applicable to human populations, but
10 or more years follow-up may be needed to provide
answers about some health effects, such as cancer. This
is because the interval between the time of exposure to a
cancer-causing agent and the time tumors develop - if
they do - may be many, many years. The interpretation of
epidemiological studies is hampered by difficulties in
229 Section 13 : Health and Safety Information
measuring actual RF exposure during day-to-day use of
wireless phones. Many factors affect this measurement,
such as the angle at which the phone is held, or which
model of phone is used.
12. Which other federal agencies have responsibilities related
to potential RF health effects?
Additional information on the safety of RF exposures
from various sources can be obtained from the following
organizations.
FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
Occupational Safety and Health Administration’s (OSHA):
http://www.osha-slc.gov/SLTC/radiofrequencyradiation/
index.html
National Institute for Occupational Safety and Health
(NIOSH):
http://www.cdc.gov/niosh/emfpg.html
World health Organization (WHO):
http://www.who.int/peh-emf/
International Commission on Non-Ionizing Radiation
Protection:
http://www.icnirp.de
National Radiation Protection Board (UK):
http://www.nrpb.org.uk
Updated 4/3/2002: US Food and Drug Administration http://
www.fda.gov/cellphones
Section 13 : Health and Safety Information
Section 13
230
STANDARD LIMITED WARRANTY
What is Covered and For How Long? SAMSUNG
TELECOMMUNICATIONS AMERICA, L.P.
(SAMSUNG) warrants to the original purchaser
("Purchaser") that SAMSUNG’s Phones and accessories
("Products") are free from defects in material and
workmanship under normal use and service for the period
commencing upon the date of purchase and continuing for
the following specified period of time after that date:
Phone 1 Year
Batteries 1 Year
Leather Case/Pouch 90 Days
Holster 90 Days
Other Phone Accessories 1 Year
What is Not Covered? This Limited Warranty is
conditioned upon proper use of Product by Purchaser. This
Limited Warranty does not cover: (a) defects or damage
resulting from accident, misuse, abuse, neglect, unusual
physical, electrical or electromechanical stress, or
modification of any part of Product, including antenna, or
cosmetic damage; (b) equipment that has the serial number
removed or made illegible; (c) any plastic surfaces or other
externally exposed parts that are scratched or damaged due
to normal use; (d) malfunctions resulting from the use of
Product in conjunction with accessories, products, or
ancillary/peripheral equipment not furnished or approved
by SAMSUNG; (e) defects or damage from improper
testing, operation, maintenance, installation, or adjustment;
(f) installation, maintenance, and service of Product, or (g)
Product used or purchased outside the United States or
Canada.
231 Section 13 : Health and Safety Information
This Limited Warranty covers batteries only if battery
capacity falls below 80% of rated capacity or the battery
leaks, and this Limited Warranty does not cover any battery
if (i) the battery has been charged by a battery charger not
specified or approved by SAMSUNG for charging the
battery, (ii) any of the seals on the battery are broken or
show evidence of tampering, or (iii) the battery has been
used in equipment other than the SAMSUNG phone for
which it is specified.
What are SAMSUNG’s Obligations? During the
applicable warranty period, SAMSUNG will repair or
replace, at SAMSUNG’s sole option, without charge to
Purchaser, any defective component part of Product. To
obtain service under this Limited Warranty, Purchaser must
return Product to an authorized phone service facility in an
adequate container for shipping, accompanied by
Purchaser’s sales receipt or comparable substitute proof of
sale showing the date of purchase, the serial number of
Product and the sellers’ name and address. To obtain
assistance on where to deliver the Product, call Samsung
Customer Care at 1-888-987-4357. Upon receipt,
SAMSUNG will promptly repair or replace the defective
Product. SAMSUNG may, at SAMSUNG’s sole option, use
rebuilt, reconditioned, or new parts or components when
repairing any Product or replace Product with a rebuilt,
reconditioned or new Product. Repaired/replaced leather
cases, pouches and holsters will be warranted for a period of
ninety (90) days. All other repaired/replaced Product will be
warranted for a period equal to the remainder of the original
Limited Warranty on the original Product or for 90 days,
whichever is longer. All replaced parts, components, boards
and equipment shall become the property of SAMSUNG.
If SAMSUNG determines that any Product is not covered
by this Limited Warranty, Purchaser must pay all parts,
Section 13 : Health and Safety Information
Section 13
232
shipping, and labor charges for the repair or return of such
Product.
What Are the Limits On SAMSUNG’s Liability?
EXCEPT AS SET FORTH IN THE EXPRESS
WARRANTY CONTAINED HEREIN, PURCHASER
TAKES THE PRODUCT “AS IS,” AND SAMSUNG
MAKES NO WARRANTY OR REPRESENTATION
AND THERE ARE NO CONDITIONS, EXPRESS OR
IMPLIED, STATUTORY OR OTHERWISE, OF ANY
KIND WHATSOEVER WITH RESPECT TO THE
PRODUCT, INCLUDING BUT NOT LIMITED TO:
THE MERCHANTABILITY OF THE PRODUCT OR
ITS FITNESS FOR ANY PARTICULAR PURPOSE OR
USE;
WARRANTIES OF TITLE OR NON-
INFRINGEMENT;
DESIGN, CONDITION, QUALITY, OR
PERFORMANCE OF THE PRODUCT;
THE WORKMANSHIP OF THE PRODUCT OR THE
COMPONENTS CONTAINED THEREIN; OR
COMPLIANCE OF THE PRODUCT WITH THE
REQUIREMENTS OF ANY LAW, RULE,
SPECIFICATION OR CONTRACT PERTAINING
THERETO.
NOTHING CONTAINED IN THE INSTRUCTION
MANUAL SHALL BE CONSTRUED TO CREATE AN
EXPRESS WARRANTY OF ANY KIND
WHATSOEVER WITH RESPECT TO THE PRODUCT.
ALL IMPLIED WARRANTIES AND CONDITIONS
THAT MAY ARISE BY OPERATION OF LAW,
INCLUDING IF APPLICABLE THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND
233 Section 13 : Health and Safety Information
FITNESS FOR A PARTICULAR PURPOSE, ARE
HEREBY LIMITED TO THE SAME DURATION OF
TIME AS THE EXPRESS WRITTEN WARRANTY
STATED HEREIN. SOME STATES/PROVINCES DO
NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS, SO THE ABOVE
LIMITATION MAY NOT APPLY TO YOU. IN
ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR
ANY DAMAGES OF ANY KIND RESULTING FROM
THE PURCHASE, USE, OR MISUSE OF, OR
INABILITY TO USE THE PRODUCT OR ARISING
DIRECTLY OR INDIRECTLY FROM THE USE OR
LOSS OF USE OF THE PRODUCT OR FROM THE
BREACH OF THE EXPRESS WARRANTY,
INCLUDING INCIDENTAL, SPECIAL,
CONSEQUENTIAL OR SIMILAR DAMAGES, OR
LOSS OF ANTICIPATED PROFITS OR BENEFITS, OR
FOR DAMAGES ARISING FROM ANY TORT
(INCLUDING NEGLIGENCE OR GROSS
NEGLIGENCE) OR FAULT COMMITTED BY
SAMSUNG, ITS AGENTS OR EMPLOYEES, OR FOR
ANY BREACH OF CONTRACT OR FOR ANY CLAIM
BROUGHT AGAINST PURCHASER BY ANY OTHER
PARTY. SOME STATES/PROVINCES DO NOT
ALLOW THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO
THE ABOVE LIMITATION OR EXCLUSION MAY
NOT APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS, AND YOU MAY ALSO HAVE OTHER
RIGHTS, WHICH VARY FROM STATE TO STATE/
PROVINCE TO PROVINCE. THIS LIMITED
WARRANTY SHALL NOT EXTEND TO ANYONE
OTHER THAN THE ORIGINAL PURCHASER OF
Section 13 : Health and Safety Information
Section 13
234
THIS PRODUCT AND STATES PURCHASER’S
EXCLUSIVE REMEDY. IF ANY PORTION OF THIS
LIMITED WARRANTY IS HELD ILLEGAL OR
UNENFORCEABLE BY REASON OF ANY LAW,
SUCH PARTIAL ILLEGALITY OR
UNENFORCEABILITY SHALL NOT AFFECT THE
ENFORCEABILITY FOR THE REMAINDER OF THIS
LIMITED WARRANTY WHICH PURCHASER
ACKNOWLEDGES IS AND WILL ALWAYS BE
CONSTRUED TO BE LIMITED BY ITS TERMS OR AS
LIMITED AS THE LAW PERMITS.
THE PARTIES UNDERSTAND THAT THE
PURCHASER MAY USE THIRD-PARTY SOFTWARE
OR EQUIPMENT IN CONJUNCTION WITH THE
PRODUCT. SAMSUNG MAKES NO WARRANTIES
OR REPRESENTATIONS AND THERE ARE NO
CONDITIONS, EXPRESS OR IMPLIED, STATUTORY
OR OTHERWISE, AS TO THE QUALITY,
CAPABILITIES, OPERATIONS, PERFORMANCE OR
SUITABILITY OF ANY THIRD-PARTY SOFTWARE
OR EQUIPMENT, WHETHER SUCH THIRD-PARTY
SOFTWARE OR EQUIPMENT IS INCLUDED WITH
THE PRODUCT DISTRIBUTED BY SAMSUNG OR
OTHERWISE, INCLUDING THE ABILITY TO
INTEGRATE ANY SUCH SOFTWARE OR
EQUIPMENT WITH THE PRODUCT.
THE QUALITY, CAPABILITIES, OPERATIONS,
PERFORMANCE AND SUITABILITY OF ANY SUCH
THIRD-PARTY SOFTWARE OR EQUIPMENT LIE
SOLELY WITH THE PURCHASER AND THE
DIRECT VENDOR, OWNER OR SUPPLIER OF SUCH
THIRD-PARTY SOFTWARE OR EQUIPMENT, AS
THE CASE MAY BE.
235 Section 13 : Health and Safety Information
This Limited Warranty allocates risk of Product failure
between Purchaser and SAMSUNG, and SAMSUNG’s
Product pricing reflects this allocation of risk and the
limitations of liability contained in this Limited Warranty.
The agents, employees, distributors, and dealers of
SAMSUNG are not authorized to make modifications to
this Limited Warranty, or make additional warranties binding
on SAMSUNG. Accordingly, additional statements such as
dealer advertising or presentation, whether oral or written,
do not constitute warranties by SAMSUNG and should not
be relied upon.
Samsung Telecommunications America, L.P.
1301 East Lookout Drive
Richardson, TX 75082
Phone: 1-800-SAMSUNG
Phone: 1-888-987-HELP (4357)
©2004 Samsung Telecommunications America. All rights
reserved.
No reproduction in whole or in part allowed without prior
written approval.
Specifications and availability subject to change without
notice. [080802]
