Users Manual
* Depending on the software installed or your service provider or country,
some of the descriptions in this guide may not match your phone exactly.
* Depending on your country, your phone and accessories may appear
different from the illustrations in this guide.
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-xxxxxA
English. 11/2005. Rev. 1.0
SGH-P858
User’s Guide
Draft 3
2005. 11. 24
Drive safely at all times
Do not use a hand-held phone while driving. Park
the vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using them
in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.
Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or illegal.
Important safety precautions
1
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is forbidden
to use it, or when it may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear). Avoid
unnecessary contact with the antenna when the phone
is switched on.
Emergency call
Key in the emergency number for your present
location, then press .
Keep your phone away from small children
Keep the phone and all its parts, including accessories,
out of the reach of small children.
Accessories and batteries
Use only Samsung-approved accessories and
batteries. Use of any unauthorised accessories could
damage your phone and may be dangerous.
Use of authorised software
Use only Samsung-authorised software. The use of
any unauthorised software could damage your phone.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health and
safety information" on page 97.
• The phone could explode if the battery is
replaced with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.
2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone. To quickly
learn the basics for your phone, please refer to “Get
started” and “Step outside the phone.”
In this guide, the following instruction icons appear:
Indicates that you need to pay careful attention
to the subsequent information regarding safety or
phone features.
Indicates that you can get more information on
the referenced page.
→
Indicates that you need to press the Navigation
keys to scroll to the specified option and then
select it.
[
]
Indicates a key on the phone. For example,
[].
<
>
Indicates a soft key, whose function is displayed
on the phone screen. For example, <
Menu
>.
• Camera and camcorder
Use the camera module on your
phone to take a photo or record a
video.
Special
features of your phone
•MP3 player
Play MP3 music files using your
phone as an MP3 player.
•Bluetooth
Send photos, images, videos, and
other personal data, and connect
to other devices using free,
wireless Bluetooth technology.
3
Special features of your phone
•Web browser
Access the wireless web to get up-
do-the-minute information and a
wide variety of media content.
• Phone to TV
View photos and video clips
captured with the phone on your
TV screen.
• Image editor
Crop, resize, rotate, and decorate
your photos.
• Get Personal with photo caller
ID
See who’s calling you when their
very own photo displays.
• Name card
Create name cards with your
number and profile.
• Multimedia Message Service (MMS)
Send and receive MMS messages with a
combination of text, images, video, and audio.
•E-mail
Send and receive e-mails with images, video, and
audio attachments.
•Java
Enjoy Java
™
-based embedded
games and download new games.
•Organiser
Keep track of your daily, weekly,
and monthly schedule.
• Voice recorder
Record memos or sounds.
4
Contents
Unpack 6
Make sure you have each item
Your phone 6
Buttons, features, and locations
Get started 7
First steps to operating your phone
Install and charge the phone ................................... 7
Power on or off...................................................... 8
Access menu functions.......................................... 11
Customise your phone .......................................... 12
Make/Answer calls................................................ 13
Step outside the phone 14
Begin with your camera, music, and other special features
Use camera......................................................... 14
Play MP3s ........................................................... 15
Browse on the web............................................... 17
Use Phonebook .................................................... 18
Send messages.................................................... 19
View messages .................................................... 20
Use Bluetooth...................................................... 21
Use a memory card .............................................. 22
Enter text 24
Pinyin, Stroke, English word, ABC, Number, and Symbol
modes
Call functions 29
Advanced calling features
Menu functions 33
All menu options listed
Solve problems 95
Help and personal needs
Health and safety information 97
5
Overview of menu functions
To access Menu mode, press <
Menu
> in Idle mode.
1 Call records
p.33
1 Recent contacts
2 Missed calls
3 Dialled calls
4 Received calls
5 Delete all
6 Area code
7 Call time
8 Call costs
*
p.33
p.33
p.33
p.33
p.34
p.34
p.34
p.34
2 Phonebook
p.35
1 Contact list
2 FDN list
3 Add new contact
4 Group
5 Speed dial
6 My name card
7 Own number
8 Management
9 Service number
*
p.35
p.36
p.36
p.37
p.37
p.38
p.38
p.38
p.39
3 Applications
p.39
1 MP3 player
2 Voice recorder
3 Image editor
4 Java world
5 World time
6 Alarm
7 Calculator
8 Convertor
9 Timer
10 Stopwatch
11 SIM AT
*
p.39
p.42
p.43
p.44
p.45
p.46
p.46
p.47
p.47
p.48
p.48
4 Browser
p.48
1 Home
2 Fun club
3 Bookmarks
4 Go to URL
5 Clear cache
6 Profile settings
7 Current profile
p.48
p.49
p.50
p.50
p.51
p.51
p.52
5 Messages
p.52
1 Create new message
2 My messages
3 Templates
4 Delete all
5 Settings
6 Broadcast messages
7 Memory status
p.52
p.55
p.59
p.60
p.60
p.65
p.66
6 File manager
p.66
1 Images
2 Videos
3 Music
4 Sounds
5 Other files
6 Memory card
**
7 Memory status
p.66
p.69
p.70
p.70
p.71
p.73
p.73
7 Calendar
p.73
1 Month view
2 Week view
3 Day view
p.73
p.76
p.76
8 Camera
p.77
1 Take a photo
2 Record video
3 Go to photos
4 Go to videos
p.77
p.82
p.84
p.84
9 Settings
p.84
1 Time & Date
2 Phone settings
3 Display settings
4 Sound settings
5 Network services
6 Bluetooth
7 Security
8 Memory status
9 Reset settings
p.84
p.84
p.86
p.87
p.89
p.91
p.93
p.95
p.95
* Shows only if supported by your
SIM card.
** Shows only if a memory card
is inserted into the phone.
6
Unpack
Make sure you have each item
You can obtain various accessories from
your local Samsung dealer.
Phone Travel Adapter
Battery User’s Guide
• The items supplied with your
phone and the accessories at
your Samsung dealer may vary,
depending on your country or
service provider.
• Use the purchased accessories
only with your phone.
Your phone
Buttons, features, and locations
Headset jack
Dial key
Alphanumeric
keys
Earpiece
Display
Power on/off/
Menu exit key
Special
function keys
Right soft key
Microphone
Navigation keys
(Up/Down/Left/
Right)
Confirm key
Delete key MENU key
Camera lens
Volume keys
Flash
Memory
card slot
Left soft key
External
display
CAMERA key
Speaker
7
Get started
First steps to operating your phone
SIM card information
When you subscribe to a cellular network, you receive
a plug-in SIM (Subscriber Identity Module) card
loaded with your subscription details, such as your
PIN, and available optional services.
Install and charge the phone
Remove the battery.
If the
phone is already
on, first turn it off by
holding [ ].
Insert the SIM card.
Make sure that the gold-
coloured contacts on the
card face down into the
phone.
Install the battery. Plug the travel adapter
into the phone.
Plug the adapter into a standard AC wall outlet.
When the phone is completely charged (the
battery icon becomes still), unplug the adapter
from the power outlet.
8
Get started
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the battery low message displays, and
• the empty battery icon blinks.
In this case, you cannot use more consuming battery
features, such as camera and MP3 player.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
Power on or off
Remove the adapter from the phone.
Power on
Do not turn on
the phone when
mobile phone
use is prohibited.
1. Open the phone.
2. Press and hold
[]
to turn on
the phone.
3. If necessary, enter the PIN and
press <
OK
>.
Power off
1. Open the phone.
2. Press and hold
[]
.
9
Get started
Keys and display
Keys
Perform the function indicated on the bottom
line of the display.
In Idle mode, access menu options
directly.
p. 85
In Menu mode, scroll through menu options.
In Menu mode, select the highlighted menu
option or confirm input.
Make or answer a call.
In Idle mode, retrieve the resent numbers
dialled, missed, or received.
Delete characters from the display.
End a call.
Press and hold to switch the phone on and
off.
In Menu mode, cancel input and return the
phone to Idle mode.
Enter numbers, letters, and some special
characters.
In Idle mode, press and hold
[1]
to access
your voicemail server. Press and hold [
0
] to
enter an international call prefix.
Enter special characters.
In Idle mode, press and hold [
]
to activate
or deactivate Quiet mode. Press and hold
[
]
to enter a pause between numbers.
Adjust the phone volume.
In Idle mode, with the phone open, adjust
the keypad tone volume. With the phone
closed, to turn on the backlight.
In Menu mode, scroll through menu options.
In Idle mode, access Menu mode when held
down.
In Idle mode, access the
Camera
menu.
Press and hold to turn on the camera.
In Camera mode, take a photo or record a
video.
10
Get started
Display
Layout
Icons
Received signal strength
Call in progress
Out of your service area; you
cannot send or receive calls
GPRS network
Home Zone, if registered for the
appropriate service
Office Zone, if registered for the
appropriate service
Text and graphics
display messages,
instructions, and
information you enter.
Soft key function
indicators
show the current
functions assigned to
the soft keys.
Icons
display various icons.
Menu Contacts
Alarm set
New text message
New multimedia message
New e-mail
One of the message Inboxes is full
New voicemail
Call diverting feature active
Bluetooth feature active
Connected to Bluetooth
hands-free car kit or headset
Memory card inserted
Synchronised with a computer
Call ringer set to vibrate
Quiet mode
Battery power level
11
Get started
Access menu functions
Use the soft
keys
The roles of the soft keys vary
depending on the function you are
using. The bottom line of the
display indicates their current role.
Select Back
Press the left soft
key to select the
highlighted option.
Press the right soft
key to return to the
previous menu level.
Select an
option
1. Press the appropriate soft key.
2. Press the Navigation keys to
move to the next or previous
option.
3. Press <
Select
> or [ ] to
confirm the function displayed or
option highlighted.
4. To exit, choose either of the
following methods:
•Press <
Back
> to move up
one level.
• Press [ ] to return to Idle
mode.
Use shortcuts
Press the number key
corresponding to the option you
want.
12
Get started
Customise your phone
1. In Idle mode, press <
Menu
>
and select
Settings
→
Phone
settings
→
Language
.
2. Select a language.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Sound
settings
→
Incoming call
→
Ring tone
.
2. Press [Left] or [Right] to select
a ringer category.
3. Select a ringer melody.
4. Press <
Save
>.
Display
language
Call ringer
melody
You can set wallpaper for the idle
screen on the main display.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Display
settings
→
Wallpaper
→
Main
display
.
2. Select an image category.
3. Select an image.
4. Press <
Save
>.
You can switch the phone to Quite
mode to avoid disturbing other
people with your phone sounds.
Press and hold [ ] in Idle mode.
Idle mode
Wallpaper
Quiet mode
13
Get started
Make/Answer calls
You can protect the phone against
unauthorised use with a phone
password. The phone will require
the password on power-up.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Security
→
Change
password
.
2. Enter the default password,
00000000
, and press <
OK
>.
3. Enter a new 4- to 8-digit
password and press <
OK
>.
4. Enter the new password again
and press <
OK
>.
5. Select
Phone lock
.
6. Select
Enable
.
7. Enter the password and press
<
OK
>.
Phone lock
1. Enter an area code and phone
number.
2. Press [ ].
3. To end the call, press [ ].
1. When the phone is ringing,
press [ ].
2. To end the call, press [ ].
Press [Volume up/down].
Make a call
Answer a call
Adjust the
volume during
a call
14
Step outside the phone
Begin with your camera, music, and other special features
Use camera
1. Open the phone and hold it
horizontally.
2. Press and hold [
CAMERA
] to
turn on the camera.
The camera turns on and the
preview screen appears in
Landscape view mode.
3. Aim the lens at the subject.
4. Press [
CAMERA
] to take a
photo. The photo is saved
automatically.
5. Press
[]
to take another
photo.
Take a photo
1. In Idle mode, press <
Menu
>
and select
Camera
→
Go to
photos
.
2. Select the photo you want.
1. Open the phone and hold it
horizontally.
2. Press and hold [
CAMERA
] to
turn on the camera.
The camera turns on and the
preview screen appears in
Landscape view mode.
3. Press [
1
] to switch to Record
mode.
4. Press [
CAMERA
] to start
recording.
View a photo
Record a video
15
Step outside the phone
Play MP3s
5. Press [
CAMERA
] to stop
recording. The video is saved
automatically.
6. Press the right soft key to
record another video.
1. In Idle mode, press <
Menu
>
and select
Camera
→
Go to
videos
.
2. Select the video you want.
Play a video
Use the following methods:
• Download from the wireless
web
p. 48
• Download from a computer
using Samsung PC Studio
Samsung PC Studio User’s
Guide
• Receive via Bluetooth
p. 91
• Copy files to a memory card
and insert the card info the
phone
p. 22
Copy MP3 files
to the phone
16
Step outside the phone
1. In Idle mode, press <
Menu
>
and select
Applications
→
MP3 player
.
2. Press <
Options
> and select
Add music from
→
Phone
or
Memory card
.
3. Press
[] to
select the files
and press <
Add
>.
Create a play
list
1. From the MP3 player screen,
press
[]
.
2. During playback, use the
following keys:
•
:
pauses or resumes
playback.
• Up: opens the play list
•Left: moves back to the
previous file. Moves
backward in a file when held
down.
• Right: skips to the next file.
Skips forward in a file when
held down.
• Volume up/down: adjusts
the volume.
• Down: stops playback.
Play MP3 music
17
Step outside the phone
Browse on the web
Using a built-in web browser, you can get easy access
to the wireless web to get a variety of up-to-date
services and information and to enjoy downloads of
web content.
• In Idle mode, press
[]
and
select
Home
to access the
homepage.
• In Idle mode, press
[]
and
select
Recent page
to access
the web page you have last
visited.
Launch the
web browser
• To scroll through browser items,
press [Up] or [Down].
• To scroll page by page, press
[Volume up/down].
• To select an item, press < >.
• To return to the previous page,
press <
Back
> or [
C
].
• To return to the homepage,
press and hold [
C
].
• To access browser options,
press <
Menu
> and select
Menu
.
• To access page options, press
[].
Navigate the
web
18
Step outside the phone
Use Phonebook
To the phone’s memory:
1. In Idle mode, enter a phone
number and press <
Options
>.
2. Select
Save
→
Phone
→
a
number type.
3. Specify the contact information:
First name, Last name, Mobile,
Home, Office, Fax, Other, Email,
Graphic ID, Alert, Group, and
Notes.
4. Press
<
Save
> to save the
entry.
To the SIM card:
1. In Idle mode, enter a phone
number and press
<
Options
>.
2.
Select
Save
→
SIM
.
3. Enter a name.
4. Press
<
Save
>
to save the
entry.
Add an entry
1. In Idle mode, press
<
Contacts
>.
2. Enter the first few letters of the
name you want.
3. Select an entry.
4. Scroll to a number and press
[ ] to dial, or press
[]
to
edit contact information.
1. In Idle mode, press <
Menu
>
and select
Phonebook
→
My
name card
.
2. Specify your contact
information.
3. Press <
Save
> to save the
name card.
4. To send the name card, press
<
Options
> and select
Send
via
→
the sending method you
want.
Find an entry
Create and
send a name
card
19
Step outside the phone
Send messages
1. In Idle mode, press <
Menu
>
and select
Messages
→
Create
new message
→
Text
message
.
2. Enter the message text.
3. Press <
Options
> and select
Send only
or
Save and send
.
4. Enter destination numbers.
5. Press
[]
to send the
message.
1. In Idle mode, press <
Menu
>
and select
Messages
→
Create
new message
→
Multimedia
message
.
2. Select
Subject
.
Send a text
message (SMS)
Send a
multimedia
message
(MMS)
3. Enter the message subject and
press
[]
.
4. Select
Picture & Video
or
Sound
.
5. Add an image, video, or sound
from the phone’s memory or a
memory card.
6. Select
Message
.
7. Enter the message text and
press
[]
.
8. Press <
Options
> and select
Send
.
9. Press
[] to s
elect a
destination field.
10.Enter destination numbers or
addresses and press
[]
.
11.Press
<
Options
>
and select
Send
to send the message.
20
Step outside the phone
View messages
1. In Idle mode, press <
Menu
>
and select
Messages
→
Create
new message
→
Email
.
2. Select
Subject
.
3. Enter the e-mail subject and
press
[]
.
4. Select
Message
.
5. Enter the e-mail text and press
[]
.
6. Select
File attach
.
7. Add media files or document
files from the phone’s memory
or a memory card.
8. Press <
Options
> and select
Send
.
Send an e-mail
9. Press
[] to s
elect a
destination field.
10.Enter destination addresses and
press
[]
.
11.Press <
Options
> and select
Send
to send the message.
When a notification appears:
1. Press <
View
>.
2. Select the message from the
Inbox.
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messages
→
My
messages
→
Inbox
.
2. Select an SMS message.
View a text
message
21
Step outside the phone
Use Bluetooth
Your phone is equipped with Bluetooth technology
which enables you to connect the phone wirelessly to
other Bluetooth devices and exchange data with them,
talk hands-free, or control the phone remotely.
When a notification appears:
1. Press <
View
>.
2. Select the message from the
Inbox.
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messages
→
My
messages
→
Inbox
.
2. Select an MMS message.
1. In Idle mode, press <
Menu
>
and select
Messages
→
My
messages
→
Email
box
.
2. Select
Check new mail
.
3. Select an e-mail or header.
4. If you selected a header, press
<
Options
> and select
Retrieve
.
View a
multimedia
message
View an e-mail
In Idle mode, press <
Menu
> and
select
Settings
→
Bluetooth
→
Activation
→
On
.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Bluetooth
→
My devices
→
Search new device
.
2. Select a device.
3. Enter a Bluetooth PIN or the
other device’s Bluetooth PIN, if
it has one, and press <
OK
>.
When the owner of the other
device enters the same code,
the pairing is complete.
Turn on
Bluetooth
Search for and
pair with a
Bluetooth
device
22
Step outside the phone
Use a memory card
You can use an optional microSD to enlarge your
phone’s memory capacity.
1. Access an application,
Phonebook
,
File manager
, or
Calendar
.
2. Select the item you want to
send.
3. Press <
Options
> and select
Send
via
→
Bluetooth
.
4. Select a device.
5. If necessary, enter the
Bluetooth PIN and press <
OK
>.
To receive data via Bluetooth, your
phone’s Bluetooth feature must be
active.
If necessary, press <
Yes
> to
confirm that you are willing to
receive.
Send data
Receive data
• Frequent erasing and writing
will shorten a memory card’s
lifespan.
• Do not remove a memory card
from the phone or turn off the
phone while data is being
accessed or transferred. This
could result in loss of data and/
or damage to the card or phone.
• Do not subject memory cards to
strong shocks.
• Do not touch memory card
terminals with your fingers or
metal objects. If dirty, wipe the
card with a soft cloth.
Important
memory card
information
23
Step outside the phone
• Keep memory cards away from
small children or pets.
• Do not expose memory cards in
a place subject to electro static
discharge and/or electrical
noise.
• Use the memory card supplied
with your phone or ones
purchased from a Samsung
dealer.
1. Slide a memory card into the
memory card slot, with the
label side face down.
2. Press the card until it locks into
place.
Insert a
memory card
1. Press the memory card so that
it is disengaged from the
phone.
2. Slide the card out of the slot.
Using a card adaptor and a USB
card reader/writer, you can read
the card on a computer.
1. Insert a memory card into a
card adaptor, and then the
adaptor into a cardreader/
writer.
2. Plug the USB connector of the
adapter into the USB port on
your computer.
Remove the
memory card
Use a card
adapter
24
Enter text
Pinyin, Stroke, English word, ABC, Number, and Symbol
modes
You can enter text for some features, such as
Messages, Phonebook, or Calendar, using Pinyin, and
Stroke modes for Chinese, and English word and ABC
modes for English. You can also enter numbers and
symbols.
Changing the text input mode
• Press the right soft key and select the text input
mode you want.
• Press and hold the right soft key to switch between
Pinyin mode and S Stroke mode, or between
English word mode and ABC mode.
• Press and hold [ ] to switch to Symbol mode.
Using Chinese Pinyin mode
Pinyin is a system to enter Chinese words by spelling
them phonetically (how they sound) using the Latin
alphabet. With the Pinyin input method, you can enter
Chinese characters by keying in the Pinyin string using
the phone’s keypad.
Entering characters in Pinyin mode
1. Press the keys corresponding to the phonetic
spelling, referring to the letters printed on the
keys.
Example
: To enter “ ,” press [
6
] and [
4
] to
enter “ni.”
2. Press [Left] or [Right] to select alternative pinyins
for the keys you have pressed.
3. If you cannot find the character you want from the
display, press [Up] or [Down] to scroll through the
word choices.
4. Press [
1
] to activate the character selection field.
A number, from 1 to 5, is added to each character.
5. Press the number key corresponding to the
character you want.
Enter text
25
Rapid character entry
To enter the word “zhong guo ( )”, enter the first
character using the following keystrokes; [
9
], [
4
],
[
6
], [
6
], [
1
], and [
1
]. You do not have to complete
the Pinyin spelling to include “guo ( ).” The character
displays automatically.
Tips for using Pinyin mode
• Press [ ] to insert a space between characters.
• Press and hold [ ] to start a new line.
• Press [Left] or [Right] to move the cursor.
•Press [
C
]
to clear letters one by one. Press and
hold [
C
] to clear the entire display.
Using Chinese Stroke mode
This mode allows you to enter individual Chinese
strokes, in written order, from top to bottom, and from
left to right.
The Chinese strokes are classified into five basic
categories; heng, shu, pie, dian, and zhe. The basic
strokes are printed on keys [
1
] to [
5
] on the keypad.
Refer to the following table:
Entering strokes and characters in Stroke
mode
1. Press the keys that correspond to a character’s
component strokes. Press keys in the order that
you would write the strokes, using one press per
stroke.
Example
: To enter “ ,” press [
5
] to enter “ ”
and [
3
] to enter “ .”
Category Key Strokes represented in each category
26
2. Press [Up] or [Down] to scroll through the choices.
3. To select a character and add it to your message,
press the corresponding key, [
7
] to [
0
].
Rapid character entry
Try entering the characters “zhong guo ( )” using
the following keystrokes: [
2
], [
8
], and [
7
]. Even
though “zhong guo ( )” is a twelve stroke
character, your phone allows you to enter the
complete pair in only three key presses.
Tips for Stroke mode
• Press [ ] to insert a space between characters.
• Press and hold [ ] to start a new line.
• Press [Left] or [Right] to move the cursor.
•Press [
C
]
to clear letters one by one. Press and
hold [
C
] to clear the entire display.
Using English word mode
This mode allows your to enter English by using T9
technology. T9 is a predictive text input mode that
allows you to key in any character using single
keystrokes.
Entering a word in English word mode
1. Press [
2
] to [
9
]
to start entering a word. Press
each key once for each letter.
Example
: Press [
4
], [
3
], [
5
], [
5
], and [
6
] to
enter Hello.
T9 predicts the word that you are typing, and it
may change with each key that you press.
2. Enter the whole word before editing or deleting the
characters.
3. When the word displays correctly, go to step 4.
Otherwise, press [
0
] to display alternative word
choices for the keys that you have pressed.
For example, Of and Me use [
6
] and [
3
].
4. Press
[
]
to insert a space and enter the next
word.
If you are uncertain of the stroke
order
, press
[
6
] in place of each questionable stroke.
Continue entering strokes until the character
displays or until you finish the character.
Enter text
27
Tips for using English word mode
•Press [
1
] to enter periods or apostrophes
automatically.
• Press [ ] to change case. Lower case (No
indicator), Initial capital ( ), and Capital lock ( )
are available.
• Press [ ] to insert a space.
• Press the Navigation keys to move the cursor.
•Press [
C
] to delete characters one by one. Press
and hold [
C
]
to clear the entire display.
Adding a new word to the T9 dictionary
This feature may not be available for some languages.
1. Enter the word that you want to add.
2. Press [
0
] to display alternative words for your key
presses. When there are no more alternative
words,
Add word
displays on the bottom line.
3. Press <
Add word
>.
4. Enter the word you want using ABC mode and
press <
Save
>.
Using ABC mode
Press the appropriate key until the character you want
appears on the display.
Characters in order displayed
Key Upper case Lower case
28
Enter text
Tips for using ABC mode
• To enter the same letter twice or to enter a
different letter on the same key, wait for the cursor
to move to the right automatically or press [Right].
Then, enter the next letter.
• Press [ ] to insert a space.
• Press and hold [ ] to start a new line.
• Press [ ] to change case. Lower case (No
indicator), Initial capital ( ), and Capital lock ( )
are available.
• Press the Navigation keys to move the cursor.
•Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
Using Number mode
Number mode enables you to enter numbers.
Press the keys corresponding to the digits you want.
Using Symbol mode
Symbol mode enables you to insert symbols.
To Press
display more symbols [Up] or [Down].
select a symbol the corresponding
number key.
clear the entered symbols [
C
].
insert the symbols <
OK
>.
29
Call functions
Advanced calling features
Making a call
1. In Idle mode, enter the area code and phone
number.
2. Press [ ].
Making an international call
1. In Idle mode, press and hold [
0
]. The
+
character
appears.
2. Enter the country code, area code, and phone
number, then press [ ].
Redialling recent numbers
1. In Idle mode, press [ ] to display the list of
recent numbers.
2. Scroll to the number you want and press [ ].
Making a call from Phonebook
Once you have stored a number in Phonebook, you
can dial the number by selecting it from
Phonebook.
p. 35
You can also use the speed dial feature to assign your
most frequently called numbers to specific number
keys.
p. 37
You can quickly dial a number from the SIM card using
its location number assigned when stored.
1. In Idle mode, enter the location number for the
phone number you want and press [ ].
2. Press [Left] or [Right] to scroll through other
numbers.
3. Press <
Dial
> or [ ] to dial the number you want.
Ending a call
Close the phone or press [ ].
• Press [
C
] to clear the last digit or press and hold
[
C
] to clear the whole display. You can move the
cursor to edit an incorrect digit.
• Press and hold [ ] to enter a pause between
numbers.
30
Call functions
Answering a call
When you receive an incoming call, the phone rings
and displays the incoming call image.
Press [ ] or <
Accept
> to answer the call.
Tips for answering a call
• When
Anykey
answer
is active, you can press
any key to answer a call, except for [ ] and
<
Reject
>.
p. 85
• When
Active folder
is active, you can simply open
the phone.
p. 86
• Press and hold [Volume up/down] to reject a call
or mute the call ringer, depending on the
Volume
key
setting.
p. 85
Viewing missed calls
If you have missed calls, the screen displays how
many calls you have missed.
1. Press <
View
>.
2. If necessary, scroll through the missed calls.
3. Press [ ] to dial the number you want.
Using the headset
Use the headset to make or answer calls without
holding the phone.
Connect the headset to the jack on the left side of the
phone. The button on the headset work as listed
below:
Options during a call
You can access a number of functions during a call.
Adjusting the volume during a call
Use [Volume up/down] to adjust the earpiece volume
during a call.
Press [Volume up] to increase the volume level and
[Volume down] to decrease the volume level.
To Press
redial the last call the button twice.
answer a call and hold the button.
end a call and hold the button.
Call functions
31
Placing a call on hold/Retrieving
Press <
Hold
> or <
Retrieve
> to place a call on hold
or retrieve the call.
Making a second call
You can make another call if your network supports it.
1. Press <
Hold
> to put the call on hold.
2. Make the second call in the normal way.
3. Press <
Swap
> to switch between the calls.
4. Press <
Options
> and select
End
held
call
to end
the call on hold.
5. To end the current call, press [ ].
Answering a second call
You can answer an incoming call while already on the
phone, if your network supports it and you have
activated the call waiting feature.
p. 90
1. Press [ ] to answer the call. The first call is
automatically put on hold.
2. Press <
Swap
> to switch between the calls.
3. Press <
Options
> and select
End
held
call
to end
the call on hold.
4. To end the current call, press [ ].
Using the Speakerphone feature
Use the loudspeaker to talk and listen with the phone
a short distance away.
Press [ ] to activate the Speakerphone feature.
Press the key again to switch back to the earpiece.
Using In-call options
Press <
Options
> to access the following options
during a call:
•
Voice clarity on
/
Voice clarity off
: remove
extraneous noise and increases call quality so that
the person with whom you are speaking can hear
you clearly event if you are in a noise place.
•
Mute
/
Unmute
: switch off the phone's microphone
so that the other person on the phone cannot hear
you, or switch it back on.
32
Call functions
•
Mute keys
/
Send keys
: switch the key tones on
or off.
•
Phonebook
: access the contact list.
•
Send DTMF
: send the DTMF (Dual tone multi-
frequency) tones as a group. The DTMF tones are
the tones used in phones for tone dialling,
sounding when you press the number keys. This
option is helpful for entering a password or an
account number when you call an automated
system, like a banking service.
•
Message
: read an incoming message and send a
new message.
•
Join
: set up a multi-party call by adding a caller
on hold to a currently active call. You can include
up to five people on a multi-party call.
•
Split
: have a private conversation with one multi-
party call participant. The other participants can
converse with each other. After the private
conversation, select
Join
to return to the
multi-party call.
•
Transfer
: transfer the currently active call to a
caller on hold. The two callers can talk to each
other, but you are disconnected from the call.
•
Remove
: disconnect one multi-party call
participant.
•
End held call
: disconnect the call currently on
hold.
•
SIM service
: access special services, such as
news, weather forecasts, entertainment, and
location services, provided by your SIM card. This
option is available when you use a SIM card
supporting SIM Application Tool kit menus.
•
Switch to headset
/
Switch to phone
: switch the
call to a Bluetooth stereo headset or hands-free
car kit, or back to the phone.
To communicate with answering machines or
computerised telephone systems,
Send
keys
must be selected
.
33
Menu functions
All menu options listed
Call records
(Menu 1)
Use this menu to view the calls you have dialled,
received, or missed, the length of your calls. You can
also check the cost of your calls, if your SIM card
supports it.
To access this menu, press <
Menu
> in Idle mode and
select
Call records
.
Recent contacts
(Menu 1.1)
This menu displays the most recent calls dialled,
received, or missed.
Accessing a call record
1. Press [Left] or [Right] to select a call type.
2. Press [Up] or [Down] to scroll through the call list.
3. Press [ ] to view the details of a call, or press
[ ] to dial a number.
Using call record options
While viewing the call details, press <
Options
> to
access the following options:
•
Save as contacts
: save the number in
Phonebook.
•
Send message
: send an SMS or MMS message.
•
Delete
: delete the selected call record or all call
records.
Missed calls
(Menu 1.2)
This menu displays the most recently received calls
that you did not answer.
Dialled calls
(Menu 1.3)
This menu displays the most recent calls you have
dialled.
Received calls
(Menu 1.4)
This menu displays the most recent calls you have
received.
34
Menu functions
Delete all
(Menu 1.5)
Use this menu to delete all of the records in each call
type.
1. Press [ ] to select the call types to be cleared.
2. Press <
Delete
>.
3. Press <
Yes
> to confirm the deletion.
Area code
(Menu 1.6)
Use this menu to look up a national or international
area code.
1. Select an area code type.
2. Enter a name for the city, castle, or country you
want to find.
If necessary, press <
Change
> to change the text
input mode.
3. Select the entry you want.
4. If you select a castle, select one of the cities that
belong to the selected castle.
5. When the selected area code appears on the
Dialling mode screen, enter the rest of the phone
number you want.
6. Press <
Save
> to save the number to Phonebook,
or press [ ] to dial it.
Call time
(Menu 1.7)
This menu displays the time log for calls made and
received. The actual time invoiced by your service
provider will vary.
•
Last
call
time
: check the length of your last call.
•
Total
sent
: check the total length of all the calls
you have dialled.
•
Total
received
: check the total length of all the
calls you have received.
•
Reset
timers
: reset the call timers. You need to
enter the phone password.
Call costs
(Menu 1.8)
This network feature displays the cost of calls. This
menu is available only if your SIM card supports this
feature. Note that this is not intended to be used for
billing purposes.
The password is preset to
00000000
. You can
change this password.
p. 94
Menu functions
Phonebook
(Menu 2)
35
•
Last
call
cost
: check the cost of your last call.
•
Total
cost
: check the total cost of all of your calls.
If the total cost exceeds the maximum cost set in
Set
max
cost
, you must reset the counter before
you can make another call.
•
Max
cost
: check the maximum cost limit set in
Set
max
cost
.
•
Reset
counters
: reset the cost counters.
•
Set
max
cost
: set the maximum cost authorised
for your calls.
•
Price/Unit
: set the price per unit that is applied
when the cost of your calls is calculated.
Phonebook
(Menu 2)
You can store phone numbers on your SIM card and in
your phone’s memory. The SIM card and phone’s
memory are physically separate, but they are used as
a single entity called Phonebook.
To access this menu, press <
Menu
> in Idle mode and
select
Phonebook
.
Contact list
(Menu 2.1)
Use this menu to search for numbers in Phonebook.
Finding an entry
1. Enter the first few letters of the name that you
want to find.
If necessary, press <
Change
> to change the text
input mode.
2. Select the name you want from the list.
3. Scroll to a number and press [ ] to dial, or press
[ ] to edit contact information.
Using Phonebook options
While viewing contact details, press <
Options
> to
access the following options:
•
Edit
: edit contact information.
•
Send message
: send an SMS or MMS to the
selected number, or e-mail to the selected e-mail
address.
Press <
Contacts
> in Idle mode to quickly access
this menu.
36
Menu functions
•
Copy
: copy the number to the phone’s memory,
SIM card, or FDN list.
•
Send via
: send the contact via SMS, MMS, e-mail,
or Bluetooth.
•
Delete
: delete the contact.
•
Print via Bluetooth
: print the contact information
by connecting the phone to a printer via Bluetooth.
FDN list
(Menu 2.2)
Use this menu to create a list of contacts to be used in
FDN (Fixed Dialling Number) mode, in which the
phone allows outgoing calls only to the specified
phone numbers, if your SIM card supports this
feature. You can activate FDN mode in the
FDN mode
menu.
p. 94
Adding a contact
1. From the FDN list, press <
Options
> and select
Add
.
2. Enter your PIN2 and press <
OK
>.
3. Enter a name and press [Down].
4. Enter a phone number and press [Down].
5. Enter a location number.
6. Press <
Save
>.
Using contact options
You can access contact options by pressing
<
Options
> while viewing contact details. Refer to
“Using Phonebook options.”
Add new contact
(Menu 2.3)
Use this menu to add a new contact to Phonebook.
Storing a number in the phone’s memory
1. Select
Phone
.
2. Change the settings or enter information about the
contact.
•
Last name
/
First name
: assign a name.
•
Mobile
/
Home
/
Office
/
Fax
/
Other
: add a
number in any category.
•
Email
: assign an e-mail address.
•
Graphic ID
: assign an image to alert you to a
call from the person.
•
Alert
: assign a ringtone to alert you to a call
from the person.
Menu functions
Phonebook
(Menu 2)
37
•
Group
: assign the contact to a caller group.
•
Notes
: add a memo about the person.
3. Press <
Save
> to save the contact.
Storing a number on the SIM card
1. Select
SIM
.
2. Enter information about the contact.
•
Name
: assign a name.
•
Phone number
: enter a number.
•
Location
: assign a location number.
3. Press <
Save
> to save the contact.
Group
(Menu 2.4)
Use this menu to organise your contacts in caller
groups.
Adding members to a caller group
1. Select a group.
2. Press <
Add
>.
3. Press [ ] to select the contacts to be added.
4. Press <
Options
> and select
Add
.
Managing caller groups
From the group list, press <
Options
> to access the
following options:
•
View
: display the members of the selected group.
•
Add
: add a new group.
•
Edit
: change the group properties.
•
Send message
: send an SMS, MMS, or e-mail to
the group members you want.
•
Delete
: delete the selected group. Group
members, however, will be deleted from
Phonebook.
Speed dial
(Menu 2.5)
Use this menu to assign speed dial numbers (2 to 9)
for 8 of your most frequently called numbers.
Assigning speed dial entries
1. Select a key location from
2
to
9
. Key
1
is reserved
for your voicemail server.
To assign a caller ID image, ringtone, or group,
the contact must be saved to the phone’s
memory.
38
Menu functions
2. Select the contact you want from the contact list.
3. Select a number, if the contact has more than one
number.
Managing speed dial entries
While viewing the Speed dial screen, press
<
Options
> to access the following options:
•
Add
: assign a number to an unassigned key.
•
View
: check the number assigned to the key.
•
Change
: assign a different number to a key.
•
Remove
: clear the speed dial setting for a key.
Dialling speed dial entries
In Idle mode, press and hold the appropriate key.
My name card
(Menu 2.6)
Use this menu to create a name card and send it to
other people.
Saving your name card
The procedure for creating your name card is the
same as the one for saving a phone number in the
phone’s memory.
p. 36
Using name card options
Press <
Options
> to access the following options:
•
Edit
: edit the name card.
•
Send via
: send the name card via SMS, MMS,
e-mail, or Bluetooth.
•
Exchange namecard
: exchange the name cards
with another person via Bluetooth.
•
Remove
: remove the name card.
•
Print via Bluetooth
: print the name card by
connecting the phone to a printer via Bluetooth.
Own number
(Menu 2.7)
Use this feature to check your phone numbers, or to
assign a name to each of the numbers. Changes made
here do not affect the actual subscriber numbers on
your SIM card.
Management
(Menu 2.8)
Use this menu to manage Phonebook.
Menu functions
Applications
(Menu 3)
39
•
Default saving
: select a default memory location
to save contacts. If you select
Ask on saving
, the
phone will ask you to select a memory location
when saving a number.
•
Copy all to phone
: copy all of the contacts stored
on the SIM card to the phone’s memory.
•
Delete all
: delete all of the contacts from your
phone’s memory, your SIM card, or FDN list.
•
Memory status
: check the number of contacts
you have stored in the phone’s memory, the SIM
card, and the FDN list.
Service number
(Menu 2.9)
Use this menu to view the list of Service Dialling
Numbers (SDN) assigned by your service provider,
including emergency numbers and numbers for
directory enquiries. This menu is available if your SIM
card supports SDN.
1. Scroll to the number you want and press <
View
>.
2. Press <
Dial
> or [ ].
Applications
(Menu 3)
Use this menu to play music files, to record voice
memos, to edit photos, to play Java games, and to set
time zones and alarms. You can also use the phone as
a calculator, convertor, timer, and stopwatch.
To access this menu, press <
Menu
> in Idle mode and
select
Applications
.
MP3 player
(Menu 3.1)
Use this menu to enjoy music. First, you need to save
MP3 files in your phone’s memory.
Downloading or receiving MP3 music files
Use the following methods to save MP3 files to your
phone:
• Download from the wireless web
p. 48
• Download from a computer using the Samsung PC
Studio program
Samsung PC Studio User’s
Guide
• Receive via Bluetooth
p. 91
• Copy to a memory card and insert the card into the
phone.
p. 22
40
Menu functions
The downloaded or received files are stored in the
Music
folder.
p. 70
Creating a play list
Add the MP3 files to the play list.
1. From the MP3 player screen, press <
Options
>
and select
Add music from
→
Phone
or
Memory
card
.
2. Press [ ] to select the files to be added.
3. Press <
Add
>.
Playing MP3 files
1. From the MP3 player screen, press <
Options
>
and select
Play via
.
2. Select
Phone
to use the phone speaker.
Select
A/V headset
to use a Bluetooth stereo
headset and then search for and connect to the
headset.
During playback, use the following keys:
Key Function
Pauses or resumes playback.
Left Moves back to the previous file. Moves
backward in a file when held down.
Right Skips to the next file. Skips forward in a
file when held down.
Up Opens the play list of the current album.
Volume up/
down Adjusts the volume.
Down Stops playback.
1
Changes the equalizer type.
2
Change the playback animation.
3
Changes the repeat mode.
4
Turns 3D sound on or off.
5
Selects a skin type.
6
Turns Shuffle mode on or off.
Key Function
Menu functions
Applications
(Menu 3)
41
Using MP3 player options
During playback, press <
Options
> to access the
following options:
•
Pause
/
Play
: pause or resume playback.
•
Transfer to A/V headset
: switch the sound
output to a Bluetooth stereo headset.
•
Open
: access the play list of the current album, or
album list. On the album list, you can set up
multiple albums.
•
Remove from play list
: remove the playing file
from the play list.
•
Settings
: change the default settings for playing
music files.
Repeat
: select a repeat mode.
Shuffle
: turn Shuffle mode on or off.
Equalize
: select an equalizer type.
3D sound
: turn 3D sound on or off.
Visualization
: change the playback animation.
MP3 skin
: select a skin type.
Volume
: select a volume.
•
Properties
: access the file properties.
Accessing the play list
From the MP3 player screen, press [Up].
Press <
Options
> to access the following options:
•
Play via
: play the currently selected file.
•
Add music from
: add files to the play list.
•
Go to Album list
: access the album list.
•
Move to
: move the file to another play list.
•
Copy to
: copy the file to another play list.
•
Change order
: move the file to the position you
want within the play list.
•
Remove
: remove the selected file or all files from
the play list.
•
Properties
: access the file properties.
7
Repeat a section of your choice.
Pressing this key begins a search for the
starting point. To search for the end
point, press this key again. To stop
repeating, press this key.
Key Function
42
Menu functions
Voice recorder
(Menu 3.2)
Use this menu to record voice memos. A voice memo
can be up to one hour long.
Recording a voice memo
1. Press [ ] to start recording.
2. Speak into the microphone.
Press [ ] to pause or resume the recording.
3. When you finish, press <
Save
> or [Down] to end
recording. The voice memo is automatically saved.
4. Press [ ] to review the voice memo, or press
[Up] to record a new voice memo.
Using voice memo options
After recording a voice memo, press <
Options
> to
access the following options:
•
Play
: play the voice memo.
•
Record
: record a new voice memo.
•
Go to voice list
: access the voice memos you
have recorded.
•
Send via
: send the voice memo via MMS, e-mail,
or Bluetooth.
•
Set as
: set the file as your ringtone, a ringtone for
a Phonebook entry, or alarm tone.
•
Move to
: move to another folder or a memory
card.
•
Copy to card
: copy the voice memo to a memory
card.
•
Delete
: delete the voice memo.
•
Rename
: change the name of the voice memo.
•
Share for Bluetooth
: share the files with other
Bluetooth devices.
•
Protection
: protect the voice memo from being
deleted.
Playing a voice memo
1. From the Voice recorder screen, press <
Options
>
and select
Go to voice list
.
2. Select a voice memo. The memo plays.
During playback, use the following keys:
Key Function
Pauses or resumes playback.
Menu functions
Applications
(Menu 3)
43
Changing recorder settings
You can change the default settings for recording a
voice memo. Before recording a voice memo, press
<
Options
> and select
Settings
.
•
Recording time
: select a recording time.
•
Volume
: select a volume level.
•
Default name
: change the default prefix of voice
memos.
•
Visualization
: select a playback animation.
Image editor
(Menu 3.3)
Use this menu to edit your photos using various
editing tools.
Applying an effect
1. Press <
Options
> and select
New image
→
Open
or
Take a photo
.
2. Select a photo or take a new photo, and press
<
Load
>.
3. Press <
Options
> and select
Effects
→
an effect
option.
4. Press <
Done
>.
5. Press <
Options
> and select
Save as
.
6. Press <
Yes
>.
7. Enter a new file name and press [ ].
Transforming
1. Select a photo or take a new photo, and press
<
Load
>.
2. Press <
Options
> and select
Transform
→
an
option:
•
Rotate
: rotate the photo 90 degrees.
•
Flip
: flip the photo.
3. Press the Navigation keys to rotate or flip the
photo.
Left Moves backward in a memo.
Right Skips forward in a memo.
Volume up/
down Adjusts the volume.
Down Stops playback.
Key Function
44
Menu functions
4. Press <
Done
>.
5. Press <
Options
> and select
Save as
.
6. Press <
Yes
>.
7. Enter a new file name and press [ ].
Adjusting an effect
1. Select a photo or take a new photo, and press
<
Load
>.
2. Press <
Options
> and select
Adjust
→
an effect.
3. Press [Left] or [Right] to adjust the image
brightness, contrast, or colour.
4. Press <
Done
>.
5. Press <
Options
> and select
Save as
.
6. Press <
Yes
>.
7. Enter a new file name and press [ ].
Adding visual features
You can decorate photos by adding a frame or an
image.
1. Select a photo or take a new photo, and press
<
Load
>.
2. Press <
Options
> and select
Insert
→
a feature
type.
3. Select an item be inserted.
4. Press [Left] or [Right] to access the other items
and press <
Select
> to select the displayed item.
5. Adjust the position of the inserted item using the
Navigation keys.
6. Press <
Done
>.
7. Press <
Options
> and select
Save as
.
8. Press <
Yes
>.
9. Enter a new file name and press [ ].
Java world
(Menu 3.4)
Use this menu to access and play Java games and to
change the network settings required for accessing
Java services.
Using Java application options
From the application list, press <
Options
> to access
the following options:
•
Start
: launch the selected application.
Menu functions
Applications
(Menu 3)
45
•
Delete
: delete the selected application or all
applications, except for the embedded games.
•
Properties
: access the application properties.
•
Permission
: set permission settings for services
charging you additional costs, such as network
access and SMS.
•
Upgrade
: upgrade the application to the latest
version.
•
Send information via SMS
: send the URL
containing the application via SMS.
•
Memory status
: access memory information for
applications.
•
Network settings
: select a connection profile to
be used for applications requiring network access.
You can also create or edit a profile.
next
section
Changing Java settings
From the application list, press <
Options
> and select
Network settings
to access the following options:
•
APN
: enter the access point name.
•
Login ID
: enter the login ID.
•
Password
: enter the login password.
•
Proxy
: select whether or not you use a proxy
server to access network services. Depending on
this setting, options in
Proxy settings
vary.
•
Proxy settings
: provide you with the following
options:
When the proxy is set to
Enable
:
IP address
: enter the HTTP proxy address.
Port
: enter the port number.
When the proxy is set to
Disable
:
DNS1
: enter the primary DNS address.
DNS2
: enter the secondary DNS address.
World time
(Menu 3.5)
Use this menu to find out what time it is in another
part of the world.
Viewing world time
1. From the world map, press [Left] or [Right] to
select the city that corresponds to your home time
zone. As the time line moves, the time and date of
the given zone display.
46
Menu functions
2. Press [ ] to save the time zone.
Applying Daylight Savings Time
1. From the world map, press <
Options
> and select
Set daylight saving time
.
2. Press [ ] to select the time zones you want.
3. Press <
Save
>.
Alarm
(Menu 3.6)
Use this menu to set alarms to sound at a specific
time. A wake-up alarm is not affected by your sound
setting.
Setting an alarm
1. Select the type of alarm.
2. Set each alarm option:
•
Alarm
: activate the alarm.
•
Alarm time
: enter the time for the alarm to
sound.
•
AP/PM
: select
AM
or
PM
in 12-hour format.
•
Alarm day
: select the days on which the alarm
rings.
•
Alarm tone
: select an alarm tone.
3. Press <
Save
>.
Stopping an alarm
When the alarm sounds, choose either of the following
options to stop the alarm:
• Press <
Confirm
>.
• Press <
Snooze
> to stop and cause the wake-up
alarm after 5 minutes. You can do this a maximum
of 5 times.
Setting the alarm to sound even if the phone is
off
From the Alarm screen, select
Auto power
→
On
.
If the phone is off when it is time for the alarm to ring,
the phone switches on and sounds the alarm.
Calculator
(Menu 3.7)
Use this menu to perform basic arithmetic functions
such as addition, subtraction, multiplication, and
division.
1. Enter the first number.
•Press <
.()
> to insert a decimal point or
bracket.
Menu functions
Applications
(Menu 3)
47
• Press [ ] or [ ] to move the cursor.
2. Press one of the Navigation keys to access the
math function you want.
3. Enter the second number.
4. Press [ ] to view the result.
5. If necessary, repeat from step 2 to continue the
calculation.
Convertor
(Menu 3.8)
Use this menu for common conversions, such as
length and weight.
Performing a conversion
1. Select the convertor type you want.
2. Press [Left] or [Right] to select the original unit
and press [Down].
3. Enter the value to be converted and press [Down].
• Press [ ] to insert a decimal point.
• Press [ ] to change the temperature to above
zero (+) or below zero (-).
4. Press [Left] or [Right] to select the unit you want
to convert to.
The equivalent value for the amount you entered
displays.
Using convertor options
Press <
Options
> to access the following options:
•
Clear
: clear the current values.
•
Reverse
: reverse the conversion.
Timer
(Menu 3.9)
Use this menu to set a period of time for the phone to
count down. The phone will sound an alarm when the
specified period of time has expired.
Starting the timer
1. Press <
Set
>.
2. Enter the length of time you want to count down
and press <
OK
>.
3. Press [ ] to start counting down.
Stopping the timer
• Press any key to stop the timer when it sounds.
48
Menu functions
• Press [ ] on the Timer screen to stop the timer
before it sounds.
Stopwatch
(Menu 3.10)
Use this menu to measure elapsed time. The precision
of the stopwatch is one one-hundredth of a second.
1. Press [ ] to start the timer.
2. Press [ ] to check an interval. You can repeat
this step for a total of 4 intervals.
SIM AT
(Menu 3.11)
This menu is available if you use a SIM AT card that
provides additional services, such as news, weather,
sports, entertainment, and location services. Available
services may vary, depending on your service
provider’s plans. For details, see your SIM card
instructions or contact your service provider.
Browser
(Menu 4)
The Wireless Application Protocol (WAP) on your
phone allows you to access the wireless web. From the
wireless web, you can access updated information and
a wide variety of media content, such as wallpapers,
ringtones, and music files.
To access this menu, press <
Menu
> in Idle mode and
select
Browser
.
Home
(Menu 4.1)
Use this menu to connect your phone to the network
and load the homepage of the wireless web service
provider. You can also press [ ] in Idle mode and
select
Home
.
Navigating the web browser
To Press
scroll through browser items [Up] or [Down].
scroll page by page [Volume up/down].
select a browser item < >.
Menu functions
Browser
(Menu 4)
49
Using browser options
From any web page, press <
Menu
> and select
Menu
.
•
Back
: go back to the previous page.
•
Home
: go back to the homepage.
•
Exit
: exit the web browser.
•
Reload
: reload the current page.
•
Show URL
: display the URL address of the current
web page. You can also set the current page as the
homepage for the web browser.
•
About...
: access the properties of your web
browser.
Using page options
From any web page, press [ ] to access the following
options:
•
Go to URL
: enter a URL address manually.
•
Bookmarks
: switch to the
Bookmarks
menu.
•
Messages
: check the message stored in the
My
messages
folder. You can also create and send a
new SMS message.
p. 52
•
File manager
: switch to the
File manager
menu.
p. 66
Accessing the web page you have last visited
In Idle mode, press [ ] and select
Recent page
.
Exiting the web browser
Press [ ] to end the network connection and exit the
browser.
Fun club
(Menu 4.2)
Use this menu to access Samsung Fun Club, the preset
web site providing Samsung mobile phone users with
attractive download services of updated ringtones and
wallpapers.
You can download:
• images and ringtones via SMS.
• 4-level greyscale and colour images.
return to the previous page <
Back
> or [
C
].
return to the homepage and hold [
C
].
To Press
50
Menu functions
• 64 polyphonic melodies.
• information and electronic catalogues for Samsung
Electronics products.
SFC home
(Menu 4.2.1)
Selecting this menu loads the Samsung Fun Club
homepage. You can also press [ ] in Idle mode
and select
SFC home
.
Service area
(Menu 4.2.2)
Each time you move to China or HongKong, you need
to change this setting to use the SFC service,
according to the area where you are.
Bookmarks
(Menu 4.3)
Use this menu to save URL addresses to quickly access
a website.
Adding a bookmark
1. Select an empty location.
2. Press [ ] to select the
Name
field.
3. Enter a name for the bookmark and press [ ].
4. Press [ ] to select the
URL
field.
5. Enter a URL address and press [ ].
6. Press <
Save
> to save the bookmark.
Accessing a bookmarked page
Scroll to a bookmark item and press [ ].
Using bookmark options
Press <
Options
> to access the following options:
•
Go
: access the website.
•
Edit
: edit the address and name of the bookmark.
•
Delete
: delete the selected bookmark or all
bookmarks.
Go to URL
(Menu 4.4)
Use this menu to manually enter the URL address of a
website and access the website.
When you access Samsung Fun Club for the first
time, please launch the web browser first, then
access Samsung Fun Club. This service requires
WAP subscription and may be unavailable
depending on your local system and services.
Menu functions
Browser
(Menu 4)
51
Clear cache
(Menu 4.5)
Use this menu to clear the cache, which is the
temporary memory that stores the web pages you
have recently accessed.
Profile settings
(Menu 4.6)
Use this menu to set up profiles for connecting your
phone to the web browser. Contact your service
provider for details about your settings options.
For each server, the following options are available:
•
Profile
name
: assign a name to the server profile.
•
Home
URL
: enter the address of your homepage.
•
Bearer
: select the network bearer type.
•
Proxy
: activate or deactivate the proxy server.
Your service provider can tell you if your network
requires a proxy server, and they can give you the
appropriate settings.
•
GPRS settings
: customise the following GPRS
network settings:
When the proxy is set to
Enable
:
Proxy IP
: enter the proxy IP address.
Proxy port
: enter the proxy port number.
APN
: enter the access point name of the GPRS
network gateway.
Login ID
: enter the login ID.
Password
: enter the login password.
When the proxy is set to
Disable
:
DNS1
: enter the primary address.
DNS2
: enter the secondary address
.
APN
: enter the access point name of the GPRS
network gateway.
Login ID
: enter the login ID
.
Password
: enter the login password
.
•
GSM settings
: customise the following GSM
network settings:
When the proxy is set to
Enable
:
Proxy IP
: enter the proxy IP address.
Proxy port
: enter the proxy port number.
Dial number
: enter the PPP server phone number.
Login ID
: enter the login ID.
Password
: enter the login password.
52
Menu functions
Data call type
: select a call type for data
transmission.
When the proxy is set to
Disable
:
DNS1
: enter the primary DNS address.
DNS2
: enter the secondary DNS address.
Dial number
: enter the PPP server phone number.
Login ID
: enter the login ID.
Password
: enter the login password.
Data call type
: select a call type for data
transmission.
Current profile
(Menu 4.7)
Use this menu to activate one of the proxy servers you
have set up.
Messages
(Menu 5)
Use the
Messages
menu to send and receive short
messages, multimedia messages, and e-mails. You
can also use push message, voicemail, and Cell
broadcast message features.
To access this menu, press <
Menu
> in Idle mode and
select
Messages
.
Create new message
(Menu 5.1)
Use this menu to create and send text messages,
multimedia messages, or e-mails.
Text message
(Menu 5.1.1)
Short Message Service (SMS) allows you to send or
receive text messages including pictures, audio clips,
and animated images.
1. Enter your message.
The maximum number of characters allowed in
a short message varies by service provider. If
your message exceeds the maximum number of
characters, the phone will split the message.
Menu functions
Messages
(Menu 5)
53
2. Press <
Options
> to access the following options
for creating a message:
•
Send only
: send the message.
•
Save and send
: save a copy of the message in
the
Draft
box and send the message.
•
Insert
: insert a message template, contact, or
bookmark.
•
Add picture
/
Add animation
/
Add melody
:
add a picture, animated image, or a melody to
the message.
•
Attach
: add a name card or a calendar data as
a data attachment.
•
Save to
: save the message in the
Draft
box or
My folder
box.
•
Text style
: change the text attributes.
3. When you have finished, press <
Options
> and
select
Send only
or
Save and send
.
4. Enter a destination number.
To send the message to more than one recipient,
fill in the destination fields.
5. Press [ ] to send the message.
Multimedia message
(Menu 5.1.2)
Multimedia Message Service (MMS) delivers messages
containing a combination of text, image, video, and
sound, from phone to phone or from phone to e-mail.
1. Select the
Subject
line.
2. Enter the subject of your message and press
[].
3. Select the
& Video
or
Sound
line.
4. Add an image, a video, or a sound file.
5. Select the
Message
line.
6. Enter your message and press [ ].
7. Press <
Options
> to access the following options
for editing the message:
•
Edit
: edit the subject or text of your message.
• The maximum size allowed for an MMS
message can differ depending on your service
provider.
• Depending on the file type or DRM (Digital
Rights Management) system, some files may
not be able to be forwarded.
54
Menu functions
•
Change image
/
Change video
/
Change
sound
: change the added image, video, or
sound to another one.
•
Preview
: view the message as it will be shown
on the recipient’s phone.
•
Send
: send the message.
•
Save to
: save the message in the
Draft
box,
My folder
box or
Templates
box.
•
Add page
: add pages. Move to each page by
pressing [Left] or [Right] on the message
screen.
•
Delete page
: delete the added page.
•
Edit page
: set the page duration or move the
current page to the previous page.
•
Attach
: add a name card or calendar data as a
data attachment.
•
Remove subject
/
Remove media
/
Remove
sound
/
Remove message
: remove the
subject, image, video, sound, or text.
8. When you have finished, press <
Options
> and
select
Send
.
9. Press [ ] to select a destination field.
10.Enter a phone number or e-mail address and press
[].
To send the message to more than one recipient,
fill in additional destination fields.
11.Press <
Options
> and select
Send
to send the
message.
Email
(Menu 5.1.3)
You can send and receive e-mails that include text,
audio, and images. To use this feature, you need to
subscribe to an e-mail service and set up your e-mail
profile and account.
p. 64
1. Select the
Subject
line
2. Enter the subject of your e-mail and press [ ].
3. Select the
Message
line
4. Enter the e-mail text and press [ ].
5. Select the
File attach
line.
6. Select one of the following options:
•
Add image
/
Add videos
/
Add sounds
/
Add
music
/
Add other files
: add images, videos,
sounds, music files, or document files.
Menu functions
Messages
(Menu 5)
55
•
Add from memory card
: access a memory
card, if inserted into the phone, and add files.
•
Send
: send the message.
•
Save to
: save the message in the
Draft
box or
My folder
box.
•
Attach
: add name cards or calendar data as a
data format attachment.
7. Scroll to the item you want to edit and press
<
Options
> to access the following options:
•
Edit
: edit the subject or text.
•
View
: display or play the attached file.
•
Send
: send the message.
•
Save to
: save the message in the
Draft
box or
My folder
box.
•
Remove subject
/
Remove message
: clear
the subject or text.
•
Remove
: delete the selected attachment or all
attachments.
8. When you have finished, press <
Options
> and
select
Send
.
9. Press [ ] to select a destination field.
10.Enter an e-mail address and press [ ].
To send the e-mail to more than one recipient, fill
in additional destination fields.
11.Press <
Options
> and select
Send
to send the
e-mail.
My messages
(Menu 5.2)
Use this menu to access messages you have received,
sent, or failed to send.
Inbox
(Menu 5.2.1)
This folder stores all of the messages you have
received, except for e-mails.
Viewing a message
The following icons may appear on the message list to
show the message type:
• SMS
• MMS notification
• MMS
• Push message from the web servers/
Configuration message, containing network
parameters from your service provider
• Delivery report for your sent messages
56
Menu functions
Using message options
While viewing a message, press <
Options
> to access
the following options:
SMS messages
•
Reply via
: reply to the sender via SMS or MMS.
•
Forward
: forward the message to other people.
•
Delete
: delete the message.
•
Move to phone
/
Move to SIM
: move the
message between the SIM card and the phone’s
memory.
•
Add to block list
: add the sender’s number to the
blocking list.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Cut media
: save media content from the message
into your phone’s memory.
•
Print via Bluetooth
: print the message by
connecting the phone to a printer via Bluetooth.
•
Protection
: protect the message from being
deleted. You can protect only messages stored in
the phone’s memory.
MMS notifications/MMS messages
•
Retrieve
: retrieve the MMS message from the
server.
•
Reply via SMS
: send to the sender via SMS.
•
Reply via MMS to
: send to the sender via MMS.
•
Forward
: forward the message to other people.
•
Delete
: delete the message.
•
Add to block list
: add the sender’s number to the
blocking list.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Cut media
: save media content from the message
into your phone’s memory.
• According to the DRM (Digital Rights
Management) system, messages having web
content may not be able to be forwarded.
• A
!
icon next to a message means that the
message is of high priority. A grey-coloured
message icon indicates low priority.
Menu functions
Messages
(Menu 5)
57
•
Cut attach
: save media content from the message
into your phone’s memory.
•
Properties
: access the message properties.
Push messages
•
Go to URL
: connect to the URL specified in the
message.
•
Delete
: delete the message.
•
Cut address
: extract URL, e-mail addresses, or
phone numbers from the message.
Delivery report
•
Delete
: delete the message.
Configuration messages
•
Install
: apply the configuration value in the
message to the phone.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Print via Bluetooth
: print the message by
connecting the phone to a printer via Bluetooth.
•
Delete
: delete the message.
Draft
(Menu 5.2.2)
This folder stores messages you have saved to send at
a later time.
When you select an SMS or e-mail message, it opens
in Edit mode so that you can edit and send the
message.
When you select an MMS message, it opens in Preview
mode as would a message from the Inbox. To edit the
MMS message, press <
Options
> and select
Edit
.
Outbox
(Menu 5.2.3)
This folder stores messages that the phone is
attempting to send or has failed to send.
While viewing a message, press <
Options
> to access
the following options:
•
Open file
: open the attached file.
•
Save file
: save the attached file in your phone’s
memory.
•
Send again
: resend the message.
•
Forward
: forward the message to other people.
•
Delete
: delete the message.
58
Menu functions
•
Move to phone
/
Move to SIM
: move the
message between the SIM card and the phone’s
memory.
•
Print via Bluetooth
: print the message by
connecting the phone to a printer via Bluetooth.
•
Protection
: protect the message from being
deleted.
•
Properties
: access the message properties.
Sentbox
(Menu 5.2.4)
This folder stores messages that you have sent.
While viewing a message, press <
Options
> to access
the following options:
•
Open file
: open the attached file.
•
Save file
: save the attached file in your phone’s
memory.
•
Forward
: forward the message to other people.
•
Delete
: delete the message.
•
Move to phone
/
Move to SIM
: move the
message between the SIM card and the phone’s
memory.
•
Cut address
: extract URL, e-mail addresses, or
phone numbers from the message.
•
Print via Bluetooth
: print the message by
connecting the phone to a printer via Bluetooth.
•
Protection
: protect the message from being
deleted.
•
Properties
: access the message properties.
Email box
(Menu 5.2.5)
This folder stores e-mails that you have received.
Viewing an e-mail
1. Press <
Select
> when
Check new Email
is
displayed to get new e-mails from the server.
The phone checks for new e-mails and downloads
received e-mails. The icons tell you the status of
each e-mail:
• Retrieved from the server
• Being retrieved
• Failed to retrieve.
A
!
icon next to a message means that the
message is of high priority. A grey-coloured
message icon indicates low priority.
Menu functions
Messages
(Menu 5)
59
2. Scroll to an e-mail or header.
3. If the e-mail has more than one page, press
[Volume up/down] to scroll through pages one by
one.
Press and hold [Volume up/down] to move to the
first or last page.
4. Select an attached file to view or play it.
5. Press [ ] or [ ] to scroll to the next or previous
e-mail.
Using e-mail options
While viewing a header or e-mail, press <
Options
> to
access the following options:
•
Retrieve
: retrieve the body of the e-mail from the
e-mail server.
•
Open file
: open the attached file.
•
Save file
: save the attached file in your phone’s
memory.
•
Reply to
: send a reply to the sender or to the
sender and all of the recipients.
•
Forward
: forward the e-mail to other people.
•
Delete
: delete the e-mail from the phone’s
memory or from both the phone’s memory and the
e-mail server.
•
Add to block list
: add the sender’s e-mail
address or subjects to the blocking list.
•
Cut address
: extract URL, e-mail addresses, or
phone numbers from the e-mail.
•
Move to my folder
: move the e-mail to the
My
folder
box.
•
Protection
: protect the message from being
deleted.
•
Properties
: access the e-mail properties.
My folder
(Menu 5.2.6)
Use this menu to access the messages you have
moved this folder using the
Move to my folder
option
while viewing a message list.
Templates
(Menu 5.3)
Use this menu to make and use templates of
frequently used messages.
60
Menu functions
Text template
(Menu 5.3.1)
You can create SMS templates with the sentences you
use frequently so that you can retrieve and insert
them when composing an SMS message.
Creating a template
1. Select an empty location.
2. Enter a message and press [ ].
Using template options
From the text template list, press <
Options
> to
access the following options:
•
Edit
: edit the template.
•
Send message
: create and send a new message.
•
Delete
: delete the template.
MMS Template
(Menu 5.3.2)
You can access embedded MMS templates or ones you
have saved so that you can use them in composing an
MMS message.
From the MMS template list, press <
Options
> to
access the following options:
•
View
: open the template.
•
Send message
: create and send a new message.
•
Edit
: edit the selected template.
•
Add new
: add a new template.
•
Delete
: delete the selected template or all
templates, except for embedded ones.
Delete all
(Menu 5.4)
Use this menu to delete messages in each message
folder at once.
1. Press [ ] to select the message boxes or
message types to be cleared.
2. Press <
Delete
>.
3. Press <
Yes
> to confirm the deletion.
Settings
(Menu 5.5)
Use this menu to set up various options for using the
messaging service.
Text message
(Menu 5.5.1)
You can configure SMS settings.
•
Send settings
: set up the following options for
sending SMS messages:
Menu functions
Messages
(Menu 5)
61
Reply path
: allow recipients to reply to you
through your SMS server.
Delivery report
: set the network to inform you
when your messages have been delivered.
Validity period
: set the length of time your
messages are stored in the SMS server.
Message type
: set the default message type. The
network can convert messages into the selected
format.
Service centre
: store or change the number of
your message server.
•
Block number
: specify phone numbers from
which messages will not be accepted.
Multimedia message
(Menu 5.5.2)
You can configure MMS settings.
•
Send settings
: set up the following options for
sending MMS messages:
Delivery report
: set the network to inform you
when your messages have been delivered.
Address hiding
: set your address to be hidden
from the recipient’s phone.
Read reply
: request a read-reply request along
with your messages.
Priority
: set the priority level of messages.
Expiry date
: set the length of time messages are
stored in the MMS server.
Delivery after
: set a time delay before messages
are sent.
Send size
: select a maximum size of attached
items allowed for messages.
•
Receive settings
: set up the following options for
receiving MMS messages:
Anonymous reject
: reject messages from
unknown senders.
Advert allowed
: accept advertisements.
Report allowed
: set the network to inform the
sender when a message has been delivered to you.
Home reception
: determine if your phone
retrieves new messages automatically when you
are in your home service area.
Roaming reception
: determine if your phone
retrieves new messages automatically when you
are roaming in another network.
62
Menu functions
Home reception
and
Roaming reception
have
the following options:
•
Automatic
: the phone automatically retrieves
messages from the server.
•
Reject
: the phone rejects all messages.
•
Manual
: the phone displays notifications. Use
the
Retrieve
option to manually download new
messages.
•
MMS profiles
: configure required network
settings for MMS.
Current profile
: select a profile.
Profile settings
: customise the following options
for each profile:
-
Profile name
: assign a name to the MMS profile.
-
Server URL
: enter the address of your MMS
server.
-
Proxy
: connect to the GPRS network using the
proxy server.
-
GPRS settings
: customise the settings required
for connecting to the GPRS network.
IP address
: (when the proxy is set to
Enable
)
enter the gateway address.
Port
: (when the proxy is set to
Enable
) enter
the port number.
DNS1
: (when the proxy is set to
Disable
) enter
the primary DNS address.
DNS2
: (when the proxy is set to
Disable
) enter
the secondary DNS address.
APN
: enter the access point name used for the
address of the GPRS network.
Login ID
: enter the user ID.
Password
: enter the password.
-
Version
: select an available OMA version and
maximum size limit for sending or receiving
messages.
•
Block number
: specify phone numbers from
which messages will not be accepted.
Depending on your service provider, it may
not be possible to support the maximum limit
295KB. In this case, try again after changing
the setting to 100KB.
Menu functions
Messages
(Menu 5)
63
Email
(Menu 5.5.3)
You can configure default network settings that are
required to send or receive e-mails.
•
Send settings
: set up the following options for
sending e-mails:
Send copy to self
: send a copy of your e-mail to
your own e-mail address.
Delivery confirm
: set the network to inform you
when your e-mails have been delivered.
Read confirm
: send a reply request along with
your e-mail.
Priority
: select the priority level of e-mail.
Include signature
: attach your name, phone
number, or simple memo or tag line to your e-mail.
•
Receive settings
: set up the following options for
receiving e-mails:
Check interval
: determine how often the phone
checks the server for incoming e-mails. If you
select
Not used
, use the Check new Email feature
to receive new e-mails manually.
Read reply
: determine whether or not the phone
sends a read-reply for incoming e-mails. When you
select
Announce
, the phone asks you to send a
read-reply.
Retrieve option
: determine whether the phone
downloads headers only or the e-mail headers and
bodies both.
Delete option
: determine whether e-mails are
deleted immediately or the next time you connect
to the server.
Reject if over
: determine the maximum size for
incoming e-mails. Your phone will reject e-mails
that exceed the specified size.
Leave a copy of messages on the server
: leave
copies of e-mails after retrieving.
•
Email account
: set up your e-mail account(s) and
select the one to be used:
You cannot change e-mail profile settings while an
e-mail is being sent or retrieved.
You cannot change e-mail account settings
while an e-mail is being sent or retrieved. Your
e-mail service provider can give you the
information needed for the below settings.
64
Menu functions
Current account
: select an account.
Account settings
: configure e-mail accounts
using different e-mail servers. Set the options for
each account:
-
In use
: select this option to use the account and
to display the account in
Email box
.
-
Account name
: enter a name for the currently
selected account.
-
User name
: enter a user name.
-
Email address
: enter your e-mail address.
-
Reply address
: enter the e-mail address to
which you want recipients to send reply
messages.
-
User ID
: enter your e-mail ID.
-
Password
: enter your e-mail password.
-
SMTP server
: enter the IP address or host
name of the outgoing e-mail server.
-
SMTP port
: enter the SMTP port number.
-
Protocol type
: select the protocol for the
incoming e-mail server. The remaining options
depend on the protocol type setting.
-
POP3 server
/
IMAP4 server
: enter the IP
address or host name of the server that receives
your e-mail.
-
POP3 port
/
IMAP4 port
: enter the POP3/IMAP4
port number.
-
APOP login
: (for POP3 protocol) connect to the
server by using the APOP login scheme when
this option is selected.
-
Include attachments
: (for IMAP4 protocol)
select this option to receive attachments with
e-mails.
-
Max. Emails retrieved
: (for IMAP4 protocol)
set the number of headers you will retrieve from
the server.
-
Secure connection
: use a secure connection
for e-mail service.
•
Email profile
: configure the network settings
required to send or receive e-mails.
Current profile
: select a profile.
You cannot change e-mail profile settings while
an e-mail is being sent or retrieved.
Menu functions
Messages
(Menu 5)
65
Profile settings
: configure up to five e-mail
profiles. For each profile, the following options are
required to connect to the GPRS network:
-
Profile name
: enter a name for the e-mail
profile.
-
APN
: enter the access point name used for the
GPRS network address.
-
Login ID
: enter the User ID.
-
Password
: enter the password.
-
DNS1
: enter the primary address.
-
DNS2
: enter the secondary address.
•
Block list
: specify phone numbers from which
e-mails will not be accepted. You can also specify
e-mail addresses from which you will not accept.
Push message
(Menu 5.5.4)
You can change the settings for receiving push
messages from the wireless web server.
•
Receive
: set how your phone receives push
messages.
•
Service centre
: enter the address of the server
from which you want to receive push messages,
when the
Receive
option is set to the
SMS-C
specific
.
Broadcast messages
(Menu 5.6)
Use this menu to change the settings for receiving CB
messages.
•
Read
: open received messages.
The
Archive
box saves network messages
indefinitely. Press <
Options
> and select
Save
to
save messages to the
Archive
box when a text
notification appears.
The
Temporary
box saves network messages until
the phone is switched off.
•
Receive
: enable or disable the reception of
broadcast messages.
•
Channel
: specify the channels from which you
receive broadcast messages.
•
Language
: select the languages in which
broadcast messages display.
Please contact your service provider for details.
66
Menu functions
Memory status
(Menu 5.7)
Use this menu to view the amount of memory
currently in use in each folder.
File manager
(Menu 6)
The
File manager
menu allows you to access images,
videos, voice memos, music files, sounds, and
document files stored in the phone’s memory or a
memory card.
To access this menu, press <
Menu
> in Idle mode and
select
File manager
.
Images
(Menu 6.1)
This menu displays photos you have taken and images
you have downloaded, received in messages, or
imported from your computer.
Viewing an image
1. Select an image folder.
2. Select an image.
Viewing a slide show
You can view your photos as a slide show, a sequential
presentation of each photo in the current folder.
1. Select the
Photos
folder.
2. Press <
Options
> and select
Slide show
.
3. Select a time interval between photos.
The slide show begins.
4. Press <
Back
> to stop the slide show and return to
the file list.
Printing an image via a USB connection
You can print images by connecting your phone to a
printer via a USB cable. You first need to select
Pictbridge
in the
USB settings
menu.
p. 85
1. Select an image.
2. Press <
Options
> and select
Print via
→
USB
.
3. Connect a USB cable to your phone and your
printer and press <
OK
>.
Menu functions
File manager
(Menu 6)
67
4. Specify the following printing settings:
•
Page size
: select a page size.
•
Number of copies
: select the number of
copies to be printed.
•
Page format
: select a page format.
•
Pages per sheet
: select a page layout.
•
Print date
: set the current date to be printed.
•
Border
: set a page border to be printed.
5. Press <
OK
> to preview the image.
6. Press <
Print
> to print it.
To cancel printing, press <
Cancel
>.
Printing an image via Bluetooth
You can print images via a Bluetooth-compatible
printer.
1. Press <
Options
> and select
Print via
→
Bluetooth
.
2. Press [
] to select the images to be printed and
press <
OK
>.
3. Select a printer.
4. Specify the following printing settings:
•
Frame
: set a frame to be printed.
•
Page size
: select a page size.
•
Image size
: select an image size.
•
Number of copies
: select the number of
copies to be printed.
•
Print quality
: select an image quality.
5. Press <
OK
> to preview the image.
6. Press <
Print
> to print it.
To cancel printing, press <
Cancel
>.
Viewing an image on a TV
You can view the images you have stored via a TV
screen. You first need to set the video system for your
TV in the
TV-out
menu.
p. 87
1. With the TV switched on, connect your phone to
the TV with the TV out cable, as shown.
68
Menu functions
2. Switch the TV to External Input mode.
The display switches to TV Out mode and you can
view the phone’s display on the TV screen.
3. Access the video clip in the
Images
folder.
Using image options
From the image list, press <
Options
> to access the
following options:
•
View
: display the image.
•
Display mode
: change the display view mode.
•
Send via
: send the image via MMS, e-mail, or
Bluetooth.
•
Set as
: set the image as a wallpaper image or a
caller ID image for a Phonebook entry.
•
Edit
: edit the image using the Image editor, if it is
a photo taken by the camera on the phone.
p. 43
•
Move to
: move the file to another folder or to a
memory card.
•
Copy to
card
: copy the file to a memory card.
•
Delete
: delete the selected file or all files.
•
Rename
: change the file name.
•
Sort by
: change the sort order of files.
•
Slide show
: set all photos to display as a slide
show.
• Depending on your particular TV model, the
location and shape of the video input and
audio output ports may vary. Match cable
connector and TV port colours.
• Do not plug in connectors with a wet hand.
• Depending on the video’s system, the image
vibrates or in some other way be less than
optimal.
• Depending on the video quality, some video
files may not display.
• You cannot use the Bluetooth stereo headset
and the zooming feature in TV Out mode.
• When you receive a call while in TV Out
mode, the phone will not display the caller’s
information and will play the default ringtone,
not the specified call ringer, to protect
the other person’s privacy.
Menu functions
File manager
(Menu 6)
69
•
Share for Bluetooth
: share the file with other
Bluetooth devices.
•
Print via
: print the file by connecting the phone to
a print via Bluetooth or USB.
•
Protection
: protect the file from being deleted.
•
Properties
: access the file properties.
Videos
(Menu 6.2)
This menu displays video clips you have recorded and
videos you have downloaded, received in messages, or
imported from your computer.
Playing a video clip
1. Select a video folder.
2. Select a video clip. The file plays.
During playback, you can use the following keys:
Using video options
From the video list, press <
Options
> to access the
following options:
•
Play
: play the selected file.
•
Display mode
: change the display view mode.
•
Send via
: send the file via MMS, e-mail, or
Bluetooth.
•
Set as caller ID
: set the file as a caller ID image
for a Phonebook entry.
•
Move to
: move the file to another folder or a
memory card.
Key Function
Pauses or resumes playback.
Left Moves back to the previous file. Moves
backward in a file when held down.
Right Skips to the next file. Skips forward in
a file when held down.
Up Opens the file list.
Volume up/
down Adjusts the volume.
Down Stops playback.
Key Function
70
Menu functions
•
Copy to card
: copy the file to a memory card, if
one has been inserted.
•
Delete
: delete selected the file or all files.
•
Rename
: change the file name.
•
Sort by
: change the sort order of files.
•
Share for Bluetooth
: share the file or all files
with other Bluetooth devices.
•
Protection
: protect the file from being deleted.
•
Properties
: access the file properties.
Viewing a video clip
You can view the video clips you have stored via a TV
screen. You first need to set the video system for your
TV in the
TV out
option.
p. 87
Music
(Menu 6.3)
This menu displays MP3 music files you have
downloaded, received in messages, or imported from
your computer.
Playing a music file
1. Select a folder.
2. Select a file. For a file in the
Music
folder, see
MP3
player
.
p. 40
Sounds
(Menu 6.4)
This menu displays voice memos you have recorded
and sound clips you have downloaded, received in
messages, or imported from your computer.
Playing a sound clip
1. Select a sound folder.
2. Select a sound clip. For a voice memo, see
Voice
recorder
.
p. 42
Using sound options
From the sound list, press <
Options
> to access the
following options:
•
Play
: play the file.
•
Send via
: send the file via MMS, e-mail, or
Bluetooth.
•
Set as
: set the sound clip as your ringtone, a
ringtone for a Phonebook entry, or alarm tone.
Menu functions
File manager
(Menu 6)
71
•
Move to
: move the file to another folder or a
memory card.
•
Copy to card
: copy the file to a memory card.
•
Delete
: delete the selected file or all files.
•
Rename
: change the file name.
•
Sort by
: change the sort order of files.
•
Share for Bluetooth
: share the files with the
Bluetooth devices.
•
Protection
: protect the file from being deleted.
•
Properties
: access the file properties.
Other files
(Menu 6.5)
Use this menu to view various document files and
image files stored in the phone’s memory or a memory
card without corruption.
The following file formats are available:
• Documents: Microsoft Word, Microsoft Excel,
Microsoft PowerPoint, Adobe PDF, Plain text, HTML
•Images: GIF, JPEG
Viewing a document
Select a document. Picsel File Viewer runs to open the
file.
While viewing a document, use the following keys:
• Depending on the file size or memory capacity of
the Picsel File Viewer, a file may not open
properly.
• If a document file contains languages
unsupported by the file viewer, the content of the
document will not display correctly.
Key Function
Up/Down/
Left/Right Pans around the page.
Volume
up/down Zooms in or out.
Fits the document to the page size.
1
Changes the panning mode.
2
Returns to the first page.
72
Menu functions
Using document options
While viewing a document, press <
Options
> to
access the following options:
•
Normal screen view
/
Full screen view
: changed
the display ti Full screen view or Normal screen
view.
•
Zoom
: zoom in or out.
•
Fit to
: fit the page to the width or height of the
screen or contents in a page.
•
Go to
: go to another page in the file.
•
Rotate
: rotate the page 90 degrees.
•
Screen panning
/
Normal panning
: switch
between Screen panning mode and Normal
panning mode.
•
Show control bar
/
Hide control bar
: display or
hide the control bar of the file viewer.
•
Send via
: send the file via MMS, e-mail, or
Bluetooth.
•
Move to card
: move the file to a memory card.
•
Copy to card
: copy the file to a memory card.
•
Delete
: delete the file.
•
Rename
: change the file name.
•
Share for Bluetooth
: share the file or all files
with other Bluetooth devices.
4
Returns to the previous page.
5
Rotates the document.
6
Moves to the next page.
7
Changes the view mode to the screen
width.
8
Moves to the last page.
9
Changes the view mode to the screen
height.
Changes the display to Full screen
view or Normal screen view.
Displays or hides the control bar. This
key is only available in Full screen
mode.
Key Function
Menu functions
Calendar
(Menu 7)
73
•
Print via
: print the file by connecting the phone to
a printer via Bluetooth or USB.
•
Protection
: protect the file from being deleted.
•
Properties
: access the file properties.
Memory card
(Menu 6.6)
Use this menu to access the files stored in a memory
card. This menu is shown only when a memory card is
inserted into the phone.
Memory status
(Menu 6.7)
You can check the total amount of memory for media
items and the amount of memory currently in use in
each media box.
Calendar
(Menu 7)
The Calendar feature enables you to keep track of
your schedule and tasks and to view missed alarm
events.
To access this menu, press <
Menu
> in Idle mode and
select
Calendar
.
Month view
(Menu 7.1)
Use this menu to keep track of your monthly schedule.
Consulting the calendar
When you access the
Calendar
menu, the calendar in
Month view appears with today’s date indicated by a
green box and displays the date in lunar calendar at
the bottom of the calendar.
Selecting a day
• Press [Left] or [Right] to move by day.
• Press [Up] or [Down] to move by week.
• Press [Volume up/down] to move by month.
Using calendar options
Your phone is preset to use FAT16-formatted
memory cards. If you insert a FAT32-formatted
memory card, the phone will ask you to reformat the
memory card. If you do not, you will not be able to
access the card from the phone.
74
Menu functions
Press <
Options
> to access the following options:
•
View mode
: change the view mode of the
calendar.
•
Create
: add a new event.
•
Go to
: select today’s date or enter a specific date.
•
Sort by
: soft items by the type of event.
•
Delete
: delete events using various deleting
options.
•
Missed alarm events
: access events whose
alarms you have missed.
•
Memory status
: access memory information for
the event items stored on the calendar.
Creating an event
You can store scheduled events, miscellaneous events,
anniversaries, and tasks on the calendar. More than
one event per day can be stored.
Entering a new scheduled event/miscelllaneous
event
1. Select a date on the calendar.
2. Press <
Options
> and select
Create
→
Schedule
or
Miscellaneous
.
3. Enter information or change the settings:
•
Subject
: enter the title of the event.
•
Details
: enter event details.
•
Start date
and
Start time
: enter the starting
date and time for the event.
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
•
End date
and
End time
: enter the ending date
and time for the event.
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
•
Location
: (for
Schedule
) enter information
about the event location.
•
Alarm
: set an alarm for the event.
•
before
: set how long before the event the
alarm is to alert you.
•
Alarm tone
: select the alarm tone.
•
Repeat
: (for
Schedule
) select to set the event
to recur.
•
until
: set the ending date, if the event will
recur.
4. Press <
Save
> to save the event.
Menu functions
Calendar
(Menu 7)
75
Entering a new anniversary
1. Select a date on the calendar.
2. Press <
Options
> and select
Create
→
Anniversary
.
3. Enter information or change the settings:
•
Occasion
: enter information about the
anniversary.
•
Date
: enter the date.
•
Alarm
: set an alarm for the event.
•
before
: set how long before the event the
alarm is to alert you.
•
Alarm time
: enter an alarm time.
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
•
Alarm tone
: select the alarm tone.
•
Repeat every year
: you can set the phone to
remind you of the anniversary every year.
4. Press <
Save
> to save the event.
Entering a new task
1. Select a date on the calendar.
2. Press <
Options
> and select
Create
→
To do
.
3. Enter information or change the settings:
•
To do
: enter information about the task.
•
Start date
: enter the starting date.
•
Due date
: enter the ending date.
•
Priority
: select a priority level.
4. Press <
Save
> to save the event.
Viewing an event
Once you have stored events, the event icons and the
number of events for a specific day appear at the
bottom of the calendar.
1. Select a date on the calendar to display the events
for that day.
2. Select an event to view its details.
3. Press [Left] or [Right] to access the other events
for the selected day.
Using event options
While viewing an event, press <
Options
> to access
the following options:
• Scheduled events • Anniversaries
• Tasks • Miscellaneous events
76
Menu functions
•
Edit
: edit the event.
•
Create
: add a new event.
•
Send via
: send the event via SMS, MMS, e-mail,
or Bluetooth.
•
View mode
: change the view mode of the
calendar.
•
Done
/
Undone
: (for To do) change the status of
the event.
•
Delete
: delete the event.
•
Print via Bluetooth
: print the event by
connecting the phone to a printer via Bluetooth.
Week view
(Menu 7.2)
You can view events for the selected week. A cell on
the timetable indicates the presence of a schedule
item. Select a cell in the day you want.
Day view
(Menu 7.3)
You can view events for the selected date. Select an
event to view its details.
The following icons may display to indicate the event
status:
• Alarm set
• Recurring event
• Completed to-do
• To-do priority (Red: high, Blue: normal, and
Grey: low)
Menu functions
Camera
(Menu 8)
77
Camera
(Menu 8)
You can use the camera module embedded in your
phone to take photos and record videos.
To access this menu, press <
Menu
> in Idle mode and
select
Camera
.
Take a photo
(Menu 8.1)
Use this menu to take photos in various modes. The
camera produces JPEG photos.
Taking a photo with the phone open
1. When the camera turns on, the preview screen
appears in Landscape view.
2. Hold the phone horizontally.
3. Adjust the image to be captured.
•Press [
]
or [
MENU
]
to access camera
options.
p. 78
• Use the keypad to change the camera settings
or switch to other modes.
p. 79
4. Press [
CAMERA
] or [ ] to take a photo. The
photo is saved in the
Photos
folder.
5. Press [ ] to take another photo.
Taking a photo with the display reversed
1. Open the phone and turn the display to the left and
close the phone, as shown.
The camera turns on and the preview screen opens
in Landscape view.
• Do not take photos of people without their
permission.
• Do not take photos in a place where cameras are
not allowed.
• Do not take photos in a place where you may
interfere with another person’s privacy.
When you take a photo in direct sunlight or in bright
conditions, shadows may appear on the photo.
78
Menu functions
2. Hold the phone horizontally.
Make sure that the lens is not blocked by your
fingers.
3. Adjust the image to be captured.
•Press [
MENU
]
to access camera options. Press
[Volume up/down] to scroll through the options
and press [
CAMERA
] to select the highlighted
option.
next section
• Press [Volume up/down] to zoom in or out.
4. Press [
CAMERA
] to take a photo. The photo is
saved in the
Photos
folder.
5. Press [
MENU
] to take another photo.
Using camera options in Capture mode
In Capture mode, press [
]
or [
MENU
]
to access the
following options:
•
Record video
: switch to Record mode.
•
Shooting mode
: take a photo in the following
modes:
Single shot
: take a photo in normal mode. You
can select whether or not the camera automatically
saves a photo.
Multi shot
: take a series of action stills. You can
select the number of still images the camera will
take and shooting speed.
Mosaic shot
: take several stills and save them in
one frame. You can select the layout.
•
Effects
: change the colour tone or apply a special
effect.
•
Frames
: apply a decorative frame.
•
Flash
: determine the use of the flash.
•
Timer
: set a time delay before the camera takes a
photo.
•
Go to photos
: access the photos you have taken.
Menu functions
Camera
(Menu 8)
79
•
Settings
: change the default settings for taking a
photo.
Function
: change the following image settings:
-
Size
: select an image size.
-
Quality
: select an image quality.
-
View finder
: select a preview screen mode.
-
Scene programs
: select a scene mode, normal
shot or night shot mode.
-
Metering exposure
: select a method to
determine the exposure of an image, based on a
specific area of the image.
-
White balance
: change the white balance
setting to adjust the colour balance of the photo,
according to your circumstance.
-
ISO
: change the ISO setting, which controls the
sensitivity of your camera. For low light
situations, select a higher ISO number. The
higher the ISO number, the faster the camera
shutter functions and the more sensitive the
camera is to light. Higher ISO settings may bring
some distortion to an image.
Setup
: change the following camera settings:
-
Shutter sound
: select the sound that you hear
when you press the shutter release.
-
Zoom sound
: turn the sound effect for zooming
on or off.
-
Brightness sound
: turn the sound effect for
brightness adjustment of or off.
-
Default name
: change the default prefix of the
photo name.
•
Camera short cuts
: view the functions of the
keys you can use in Capture mode.
Using the keypad in Capture mode
You can use the keypad to customise your camera
settings in Capture mode.
Key Function
Volume up/
down Zooms in or out.
Left Shows the mirror image.
Right Flips the image vertically.
80
Menu functions
Using photo options
After saving a photo, press the left soft key or
[
CAMERA
] to access the following options:
•
Take another
: switch to Capture mode.
•
Send via
: send the file via MMS, e-mail, or
Bluetooth.
•
Set as
: set the photo as wallpaper for the displays
or caller ID image for a Phonebook entry.
•
Edit
: edit the photo using the Image editor.
p. 43
•
Delete
: delete the photo.
•
Rename
: change the file name.
•
Go to photos
: access the
Photos
folder.
•
Share for Bluetooth
: share the files with other
Bluetooth devices.
•
Print via
: print the photo by connecting the phone
to a printer via Bluetooth or USB.
•
Protection
: protect the file from being deleted.
•
Properties
: access the file properties.
Up/Down Adjusts the brightness of the image.
1
Switches to Record mode.
p. 82
2
Changes the image size.
3
Changes the image quality.
4
Changes the shooting mode and the
number of photos.
5
Changes the colour tone or applies a
special effect.
6
Changes the ISO setting.
7
Selects a decorative frame.
8
Sets the timer.
9
Accesses to the
Photos
folder.
0
Changes the flash setting.
Changes a preview screen mode.
Changes the white balance.
Key Function
Menu functions
Camera
(Menu 8)
81
Record video
(Menu 8.2)
You can record a video of what is displayed on the
camera screen and save it.
Recording a video with the phone open
1. When the camera turns on, the preview screen
appears in Landscape view.
2. Hold the phone horizontally.
3. Adjust the image to be captured.
•Press [
]
or [
MENU
]
to access camera
options.
p. 82
• Use the keypad to change the camera settings
or switch to other modes.
p. 82
4. Press [
CAMERA
] or [ ] to start recording.
5. Press [
CAMERA
] or [ ] to stop recording. The
video is saved in the
Videos
folder and the phone
automatically plays back the video.
Recording a video with the display reversed
1. Turn the display to the left and close the phone,
referring to “Taking a photo with the display
reversed.”
The camera turns on and the preview screen opens
in Landscape view.
2. Hold the phone horizontally.
Make sure that the lens is not blocked by your
fingers.
3. Press [
MENU
] and press [
CAMERA
] to select
Record video
.
4. Adjust the image to be captured.
•Press [
MENU
]
to access camera options. Press
[Volume up/down] to scroll through the options
and press [
CAMERA
] to select the highlighted
option.
next section
• Use the keypad to change the camera settings
or switch to other modes.
p. 82
5. Press [
CAMERA
] to start recording.
6. Press [
CAMERA
] to stop recording. The video is
automatically saved in the
Videos
folder.
82
Menu functions
Using camera options in Record mode
In Record mode, press [
]
or [
MENU
]
to access the
following options:
•
Take a photo
: switch to Capture mode.
•
Effects
: change the colour tone or apply a special
effect to a video.
•
Flash
: set the flash setting.
•
Timer
: set a time delay before the camera starts
recording a video.
•
Go to videos
: access the
Videos
folder.
•
Settings
: change the following settings for
recording a video:
Recording mode
: select a video recording mode.
Select
Limit of
MMS
to record a video suitable for
an MMS message.
Select
Normal
to record a video within the limit of
the currently available memory.
Size
: select an image size.
Quality
: select an image quality.
View finder
: select a preview mode, either Full
screen mode or normal mode with actual ratio.
Audio rec
.: turn on or off the audio.
White balance
: adjust the colour balance of the
image. You can make your video appear warmer or
cooler.
Scene programs
: select a scene mode, normal
shot or night shot mode.
Zoom sound
: turn the zoom control sound on or
off.
Brightness sound
: turn the brightness control
sound on or off.
Default name
: change the default prefix of the
video name.
•
Camcorder short cuts
: view the functions of the
keys you can use in Record mode.
Using the keypad in Record mode
You can use the keypad to customise your camera
settings in Record mode:
Key Function
Volume up/
down Zooms in or out.
Menu functions
Camera
(Menu 8)
83
Using video options
After saving a video, press [
]
or [
CAMERA
] to
access the following options:
•
Record another
: switch to Record mode.
•
Send via
: send the file via MMS, e-mail, or
Bluetooth.
•
Set as caller ID
: set the video as a caller ID
image for a Phonebook entry.
•
Delete
: delete the photo.
•
Rename
: change the file name.
•
Go to videos
: access the
Videos
folder.
•
Share for Bluetooth
: share the files with other
Bluetooth devices.
•
Protection
: protect the file from being deleted.
•
Properties
: access the file properties.
Left Shows the mirror image.
Right Flips the image vertically.
Up/Down Adjusts the brightness of the image.
1
Switches to Capture mode.
p. 77
2
Changes the image size.
3
Changes the image quality.
4
Changes the video recording mode.
5
Changes the colour tone or applies a
special effect.
6
Turns the audio on or off.
7
Changes a scene mode.
8
Sets the timer.
9
Accesses to the
Videos
folder.
0
Changes the flash setting.
Key Function
Changes the white balance.
Key Function
84
Menu functions
Go to photos
(Menu 8.3)
Use this menu to go to the
Photos
folder to access the
photos you have taken.
p. 66
Go to videos
(Menu 8.4)
Use this menu to go to the
Videos
folder to access the
videos you have recorded.
p. 69
Settings
(Menu 9)
Use this menu to customise your phone settings. You
can also reset the settings to their default values.
To access this menu, press <
Menu
> in Idle mode and
select
Settings
.
Time & Date
(Menu 9.1)
Use this menu to change the time and date displayed
on your phone. Before setting the time and date,
specify your time zone in the
Home zone
option.
•
Time
: enter the current time.
•
Home zone
: select your local time zone.
1. Press [Left] or [Right] to move to the city
corresponding to your time zone.
2. To apply daylight saving time, press [ ] to
select
Set daylight saving time
.
3. Press <
Save
> and then <
Yes
>.
•
AM/PM
: select
AM
or
PM
in 12-hour time format.
•
Time format
: select the 12-hour or 24-hour time
format.
•
Set date
: enter the current date.
•
Date format
: select a date format.
•
Week start day
: set which day of the week the
calendar starts with.
•
Auto update
: select to receive time information
from your network.
Phone settings
(Menu 9.2)
Many different features of your phone’s system can be
customised to suit your preferences.
Menu functions
Settings
(Menu 9)
85
Language
(Menu 9.2.1)
Use this menu to select a language for the display
text.
Greeting message
(Menu 9.2.2)
Use this menu to enter the greeting that is displayed
briefly when the phone is switched on.
Short cut
(Menu 9.2.3)
You can use the Navigation keys as shortcut keys to
access specific menus directly from Idle mode. Use
this menu to assign a shortcut to a key.
Assigning a shortcut to a key
1. Select the key to be used as a shortcut key.
2. Select the menu that will be assigned to the key.
Using shortcut options
Press <
Options
> to access the following options:
•
Change
: assign or change a shortcut menu.
•
Remove
: deactivate the shortcut assignment to
the selected key.
•
Remove all
: deactivate all shortcut assignments.
Volume key
(Menu 9.2.4)
Use this menu to set whether the phone mutes the call
ringer or rejects a call if you press and hold [Volume
up/down] when a call comes in.
USB settings
(Menu 9.2.5)
Use this menu to select a USB mode for connecting
the phone to a computer via a USB cable.
•
Modem
: you can use the phone as a modem.
•
Mass storage
: you can use the phone as an
external memory disk, if a memory card is inserted
into the phone.
•
Pictbridge
: you can connect the phone to a
Pictbridge-compatible printer.
Extra settings
(Menu 9.2.6)
You can turn the automatic redialling or answering
features on or off, or activate the voice clarity feature.
•
Auto redial
: set the phone to make up to ten
attempts to redial a phone number after an
unsuccessful call.
•
Anykey
answer
: answer an incoming call by
pressing any key, except for [ ] and <
Reject
>.
86
Menu functions
When this option is selected, you must press [ ]
or <
Accept
> to answer a call.
•
Voice clarity
: removes extraneous noise and
increases call quality so that the person with whom
you are speaking can hear you clearly even if you
are in a noisy place.
•
Active folder
: answer an incoming call by opening
the phone.
Offline mode
(Menu 9.2.7)
Use this menu to turn off the network features, such
as call functions, so that you can use the phone in a
flight. To alert you to turn on or off Offline mode,
select
On
in the
Asking popup
option.
Display settings
(Menu 9.3)
Use this menu to change settings for the display and
light.
Wallpaper
(Menu 9.3.1)
You can change the idle screen on the main and
external display.
•
Main display
: select an image to be displayed on
the main display.
•
Cover display
: select an image or enter text to be
displayed on the external display.
Text display
(Menu 9.3.2)
You can change the display settings for the text
displayed on the idle screen.
•
Text position
: select a position. If you do not
want text to display in Idle mode, select
Off
.
•
Text style
: select a text style.
•
Text colour
: select a text colour.
Skin
(Menu 9.3.3)
You can select a skin colour pattern for Menu mode.
LCD brightness
(Menu 9.3.4)
You can adjust the brightness of the display for
varying lighting conditions.
Menu functions
Settings
(Menu 9)
87
Backlight
(Menu 9.3.5)
You can select the length of time the backlight and the
display stay on.
•
Main LCD on
: select the length of time the
backlight stays on at times of inactivity.
•
Main LCD dim
: select the length of time the
display stays in Dimming mode after the backlight
turns off. After a specified time, the display turns
off.
•
Show cover indicators
: set whether or not the
icons are shown on the external display.
•
During charging
: set whether or not the display
stays in Dimming mode while charging.
Dialling display
(Menu 9.3.6)
Use this menu to customise the settings for the screen
and number while dialling.
•
Font size
: select a font size.
•
Font colour
: select a font colour.
•
Background colour
: select a background colour.
Calendar
(Menu 9.3.7)
Use this menu to display the current calendar on the
idle screen.
Show caller information
(Menu 9.3.8)
Use this menu to set the phone to display missed call
notifications with the most recently missed caller’s
information. To set the external display to show caller
information, select
With cover display
.
TV-out
(Menu 9.3.9)
Use this menu to select the default video system for a
TV.
Sound settings
(Menu 9.4)
Use this menu to customise various sound settings.
Incoming call
(Menu 9.4.1)
Use this menu to select a volume level and alert type
for incoming calls.
•
Ring tone
: select a ringtone for the call ringer.
•
Volume
: select a ringer volume.
88
Menu functions
•
Alert type
: specify how you are to be informed of
incoming calls.
Melody
: the phone rings using the selected
ringtone.
Vibration
: the phone vibrates but not rings.
Vibration then melody
: the phone vibrates three
times and then starts ringing.
Keypad tone
(Menu 9.4.2)
Use this menu to select the tone that the phone
sounds when you press a key.
Message tone
(Menu 9.4.3)
Use this menu to set up the ringer for incoming
messages and e-mails.
•
Tone
: select one of several message tones.
•
Alert type
: specify how you are informed of any
incoming messages.
•
Repetition
: specify how often the phone informs
you of a new message.
Power on/off
(Menu 9.4.4)
Use this menu to select the melody that the phone
sounds when it is switched on or off.
Folder tone
(Menu 9.4.5)
Use this menu to select the tone that the phone
sounds when you open or close the phone.
On-time alarm
(Menu 9.4.6)
Use this menu to set the phone to sound an alert
every hour on the hour.
Quiet mode
(Menu 9.4.7)
Use this menu to set how the phone acts to alert you
to a specific event while in Quiet mode.
Extra tones
(Menu 9.4.8)
Use this menu to customise additional tones for the
phone.
•
Minute
minder
: set the phone to beep every
minute during an outgoing call to keep you
informed of the length of your call.
•
Connection
tone
: set the phone to beep when an
outgoing call is connected to the system.
You can adjust the keypad tone volume using
[Volume up/down]
in Idle mode.
Menu functions
Settings
(Menu 9)
89
•
Alerts on call
: set the phone to beep when you
receive a new message or when the time for an
alarm comes during a call.
•
Indicative
tones
: set the phone to beep when a
pop-up window displays.
Network services
(Menu 9.5)
Use this menu to access network services. Please
contact your service provider to check their availability
and subscribe to them, if you wish.
Call diverting
(Menu 9.5.1)
This network service reroutes incoming calls to a
phone number that you specify.
1. Select a call diverting option:
•
Divert always
: divert calls.
•
Busy
: divert calls when you are on another
call.
•
No
reply
: divert calls when you do not answer
the phone.
•
Unreachable
: divert calls when you are not in
an area covered by your service provider or
when your phone is switched off.
•
Cancel
all
: cancel all call diverting options.
2. Select the type of calls to be diverted.
3. Select
Activate
. To deactivate call diverting, select
Deactivate
.
4. Move to the
Divert to
line.
5. Enter the number to which calls are to be diverted
and press <
OK
>.
6. If you selected
No reply
, move to the
Sec
line and
select the length of time the network delays before
diverting a call.
Call barring
(Menu 9.5.2)
This network service allows you to restrict your calls.
1. Select a call barring option:
•
All
outgoing
: prohibit outgoing calls.
•
International
: prohibit international calls.
•
International
except
home
: only allow calls
to numbers within the current country when
you are abroad, and to your home country.
•
All
incoming
: prohibit incoming calls.
90
Menu functions
•
Incoming
while
abroad
: prohibit incoming
calls when you use your phone outside of your
home country.
•
Cancel
all
: cancel all call barring settings,
allowing to be sent and received normally.
•
Change barring password
: change the call
barring password obtained from your service
provider.
2. Select the type of calls to be barred.
3. Select
Activate
. To deactivate call barring, select
Deactivate
.
4. Enter the call barring password supplied by your
service provider and press <
OK
>.
Call waiting
(Menu 9.5.3)
This network service informs you when someone is
trying to reach you while you are on another call.
1. Select the type of calls to which the call waiting
option will apply.
2. Select
Activate
. To deactivate call waiting, select
Deactivate
.
Network selection
(Menu 9.5.4)
This network service allows you to either automatically
or manually select the network used when roaming
outside of your home area. You can select a network
other than your home network only if there is a valid
roaming agreement between the two.
Caller ID
(Menu 9.5.5)
This network service allows you to prevent your phone
number from being displayed on the phone of the
person being called. If you select
Default
, the phone
will use the default setting provided by the network.
Voice mail server
(Menu 9.5.6)
Use this menu to store the number of the voicemail
server and access your voicemails.
Some networks do not allow the user to change
this setting.
You must enter the voice server number before you
can access your voicemails. Your service provider
can give this number.
Menu functions
Settings
(Menu 9)
91
•
Connect to voice mail
: connect to the voicemail
server to listen to your messages. You can also
connect to the voicemail server by pressing and
holding [
1
] in Idle mode.
•
Voice server number
: change the voicemail
server number and server name.
Band selection
(Menu 9.5.7)
For the phone to make and receive phone calls, it
must register with an available network. Your phone
can handle any of the following types of networks:
GSM 1900, Combined GSM 900/1800, and GSM 900/
1800/1900.
The country where you purchased your phone
determines the default band that it uses. When you
travel abroad, you must remember to change to an
appropriate band.
Bluetooth
(Menu 9.6)
Using Bluetooth wireless, you can connect the phone
wirelessly to other Bluetooth devices and exchange
data with them, talk hands-free, or control the phone
remotely.
Bluetooth technology allows free wireless connections
between all Bluetooth-compliant devices within a
range of 10 metres. Since the devices communicate
using radio waves, they do not need to be in line of
sight to each other.
Setting up the Bluetooth feature
The
Bluetooth
menu provides the following options:
•
Activation
: activate or deactivates the Bluetooth
feature.
•
My devices
: search for connectable Bluetooth
devices. See the next section.
•
My phone’s visibility
: allow other Bluetooth
devices to search for your phone.
• If there are obstacles between the devices, the
maximum operating distance may be reduced.
• It is recommended that you don't use the
Bluetooth feature while using multimedia features
such as voice recorder, camera, and Media player,
or vice versa for a good performance.
• Some devices may not be compatible with your
phone.
92
Menu functions
•
My phone’s name
: assign a Bluetooth device
name to your phone, which is then displayed on
other devices.
•
Secure mode
: determine if the phone asks for
your confirmation when other devices access your
data.
•
Bluetooth services
: display available Bluetooth
services.
Searching for and pairing with a Bluetooth
device
1. From the Bluetooth setting options, select
My
devices
.
2. Select
Search new device
.
After searching, a list of devices to which you can
connect displays. The following icons indicate the
type of device:
The colour of the icon indicates the status of the
device:
• Grey for unpaired devices
• Blue for paired devices
• Red for devices that are currently connected to
your phone
3. Select a device.
4. Enter a Bluetooth PIN and press <
OK
>.
This code
is used just once and you don’t need to memorise it.
When the owner of the other device enters the
same code, pairing is finished.
Using device options
From the device list, press <
Options
> to access the
following options:
•
Connect
: connect to a headset or hands-free car
kit.
• Mobile phone• PDA
• Computer • Headset
• Hands-free car kit • Unknown device
• Printer
Some devices, especially headsets or hands-free
car kits, may have a fixed Bluetooth PIN, such as
0000
. If the other device has one, you must enter
the code.
Menu functions
Settings
(Menu 9)
93
•
Disconnect
: end the connection with the
connected device.
•
Browse files
: search for data from the device and
import data directly to your phone.
•
Service list
: access the Bluetooth service list of
the device.
•
Rename
: rename the selected device.
•
Authorize device
/
Unauthorize device
:
determine if the phone asks you to permit
connection when other devices try to connect to
your phone.
•
Delete
: delete the selected device or all devices
from the list.
Sending data via Bluetooth
1. Activate the Bluetooth feature.
2. Select the application in which the item you want
to send is stored.
3. Press <
Options
> and select
Send
via
→
Bluetooth
.
The phone searches for devices within range and
displays a list of available devices.
4. Select a device.
5. If necessary, enter the Bluetooth PIN needed for
pairing and press <
OK
>.
Receiving data via Bluetooth
To receive data via Bluetooth, your phone’s Bluetooth
feature must be active.
If an unauthorised Bluetooth device sends data to your
phone, press <
Yes
> to receive data.
Security
(Menu 9.7)
Use this menu to protect the phone against
unauthorised use by managing the several access
codes of your phone and SIM card.
If you enter an incorrect PIN/PIN2 three times in
succession, the SIM card is blocked. To unblock it,
you need to enter your PUK/PUK2 (Personal
Unblocking Key). The codes are supplied by your
network operator.
94
Menu functions
PIN check
(Menu 9.7.1)
The 4-to 8-digit PIN (Personal Identification Number)
protects your SIM card against unauthorised use.
When this feature is enabled, the phone requires your
PIN each time it is switched on.
Change PIN
(Menu 9.7.2)
Use this menu to change your PIN. The PIN Check
feature must be enabled to use this feature.
Phone lock
(Menu 9.7.3)
The Phone Lock feature locks the phone from
unauthorised use.
When this feature is enabled, you must enter a 4- to
8-digit phone password each time the phone is
switched on.
The password is preset to
00000000
. To change the
password, use the
Change password
menu.
Change password
(Menu 9.7.4)
Use this menu to change your phone password.
Privacy
(Menu 9.7.5)
Use this menu to lock access to images, videos, music
files, sounds, messages, or other files in the phone’s
memory or a memory card.
1. Press [ ] to select the items to lock.
2. Press <
Save
> to lock the marked items.
3. Enter the phone password and press <
OK
>.
To access a locked item, you need to enter the phone
password.
SIM Lock
(Menu 9.7.6)
The SIM Lock feature allows your phone to work only
with the current SIM by assigning a SIM lock code. You
must enter the SIM lock code to use a different SIM
card.
FDN mode
(Menu 9.7.7)
If supported by your SIM card, Fixed Dialling Number
(FDN) mode restricts your outgoing calls to a limited
set of phone numbers. When this feature is enabled,
you can make calls only to phone numbers stored on
the SIM card.
95
Change PIN2
(Menu 9.7.8)
If supported by your SIM card, use this menu to
change your current PIN2.
Memory status
(Menu 9.8)
Use this menu to check the amount of memory for
messages, media items, calendar items, contacts, and
Java applications. You can also check the shared
memory for MMS, Email, File manager.
Reset settings
(Menu 9.9)
Use this menu to reset the phone settings, display
settings, and sound settings individually. You can also
reset all settings in your phone at the same time.
1. Press [ ] to select the setting categories to be
reset.
2. Press <
Reset
> to reset the marked items.
3. Press <
Yes
>.
4. Enter the phone password and press <
OK
>.
Solve problems
Help and personal needs
To save the time and expense of an unnecessary
service call, perform the simple checks in this section
before contacting a service professional.
When you switch on your phone, the following
messages may appear:
“Insert SIM”
• Be sure that the SIM card is correctly installed.
“Phone lock”
• The automatic locking function has been enabled.
You must enter the phone’s password before you
can use the phone.
“Enter PIN”
• You are using your phone for the first time. You
must enter the PIN supplied with the SIM card.
• The PIN check feature is enabled. Every time the
phone is switched on, the PIN has to be entered.
To disable this feature, use the
PIN check
menu.
The password is preset to
00000000
. You can
change this password
p. 94
96
Solve problems
“Enter PUK”
• The PIN code has been entered incorrectly three
times in succession, and the SIM card is now
blocked. Enter the PUK supplied by your service
provider.
“No Service,” “Network Failure,” or “Not
Done” displays
• The network connection has been lost. You may be
in a weak signal area. Move and try again.
• You are trying to access an option for which you
have no subscription with your service provider.
Contact the service provider for further details.
You have entered a number but it was not
dialled
• Be sure that you have pressed [ ].
• Be sure you have accessed the right cellular
network.
• Be sure that you have not set an outgoing call
barring option.
Your correspondent cannot reach you
• Be sure your phone is switched on. ([ ] pressed
for more than one second.)
• Be sure you are accessing the correct cellular
network.
• Be sure that you have not set an incoming call
barring option.
Your correspondent cannot hear you speaking
• Be sure that you have switched off the
microphone.
• Be sure that you are holding the phone close
enough to your mouth. The microphone is located
at the bottom of the phone.
The phone starts beeping and “Battery low”
flashes on the display
• Your battery is insufficiently charged. Recharge the
battery.
The audio quality of the call is poor
• Check the signal strength indicator on the display
( ). The number of bars indicates the signal
strength from strong ( ) to weak ( ).
97
• Try moving the phone slightly or moving closer to a
window if you are in a building.
No number is dialled when you re-call a
Phonebook entry
• Use the Contact Search feature to ensure the
number has been stored correctly.
• Re-store the number, if necessary.
The battery doesn’t charge properly or the
phone sometimes turns itself off
• Wipe the charging contacts both on the phone and
on the battery with a clean soft cloth.
If the above guidelines do not help you to
solve the problem, take note of:
• The model and serial numbers of your phone
•Your warranty details
• A clear description of the problem
Then contact your local dealer or Samsung after-sales
service.
Health and safety information
Exposure to Radio Frequency (RF) Signals
Certification Information (SAR)
Your wireless phone is a radio transmitter and receiver.
It is designed and manufactured not to exceed the
exposure limits for radio frequency (RF) energy set by
the Federal Communications Commission (FCC) of the
U.S. government. These FCC exposure limits are
derived from the recommendations of two expert
organizations, the National Counsel on Radiation
Protection and Measurement (NCRP) and the Institute
of Electrical and Electronics Engineers (IEEE). In both
cases, the recommendations were developed by
scientific and engineering experts drawn from
industry, government, and academia after extensive
reviews of the scientific literature related to the
biological effects of RF energy.
98
Health and safety information
The exposure limit set by the FCC for wireless mobile
phones employs a unit of measurement known as the
Specific Absorption Rate (SAR). The SAR is a measure
of the rate of absorption of RF energy by the human
body expressed in units of watts per kilogram (W/kg).
The FCC requires wireless phones to comply with a
safety limit of 1.6 watts per kilogram (1.6 W/kg). The
FCC exposure limit incorporates a substantial margin
of safety to give additional protection to the public and
to account for any variations in measurements.
SAR tests are conducted using standard operating
positions accepted by the FCC with the phone
transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is
determined at the highest certified power level, the
actual SAR level of the phone while operating can be
well below the maximum value. This is because the
phone is designed to operate at multiple power levels
so as to use only the power required to reach the
network. In general, the closer you are to a wireless
base station antenna, the lower the power output.
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that
it does not exceed the limit estabilished by the FCC.
Tests are performed in positions and locations(e.g. at
the ear and worn on the body) as required by the FCC.
The highest SAR values for this model phone as
reported to the FCC are Head: 0.619 W/Kg, Body-
worn: 0.300 W/Kg
For body worn operation, this model phone has been
tested and meets the FCC RF exposure guidelines
whenused with a Samsung accessory designated for
this product or when used with an accessory that
contains no metal and that positions the handset a
minimum of 1.5 cm from the body
Non-compliance with the above restrictions may result
in violation of FCC RF esposure guidelines.
SAR information on this and other model phones can
be viewed on-line at www.fcc.gov/oet/fccid. This site
uses the phone FCC ID number, A3LSGHP858.
Sometimes it may be necessary to remove the battery
pack to find the number. Once you have the FCC ID
number for a particular phone, follow the instructions
on the website and it should provide values for typical
or maximum SAR for a particular phone. Additional
Health and safety information
99
product specific SAR information can also be obtained
at www.fcc.gov/cgb/sar.
Consumer Information on Wireless Phones
The U.S. Food and Drug Administration (FDA) has
published a series of Questions and Answers for
consumers relating to radio frequency (RF) exposure
from wireless phones. The FDA publication includes
the following information:
What kinds of phones are the subject of this
update?
The term wireless phone refers here to hand-held
wireless phones with built-in antennas, often called
“cell,” “mobile,” or “PCS” phones. These types of
wireless phones can expose the user to measurable
radio frequency energy (RF) because of the short
distance between the phone and the user's head.
These RF exposures are limited by Federal
Communications Commission safety guidelines that
were developed with the advice of FDA and other
federal health and safety agencies. When the phone is
located at greater distances from the user, the
exposure to RF is drastically lower because a person's
RF exposure decreases rapidly with increasing
distance from the source. The so-called “cordless
phones,” which have a base unit connected to the
telephone wiring in a house, typically operate at far
lower power levels, and thus produce RF exposures
well within the FCC's compliance limits.
Do wireless phones pose a health hazard?
The available scientific evidence does not show that
any health problems are associated with using
wireless phones. There is no proof, however, that
wireless phones are absolutely safe. Wireless phones
emit low levels of radio frequency energy (RF) in the
microwave range while being used. They also emit
very low levels of RF when in the stand-by mode.
Whereas high levels of RF can produce health effects
(by heating tissue), exposure to low level RF that does
not produce heating effects causes no known adverse
health effects. Many studies of low level RF exposures
have not found any biological effects. Some studies
have suggested that some biological effects may
occur, but such findings have not been confirmed by
additional research. In some cases, other researchers
100
Health and safety information
have had difficulty in reproducing those studies, or in
determining the reasons for inconsistent results.
What is FDA's role concerning the safety of
wireless phones?
Under the law, FDA does not review the safety of
radiation-emitting consumer products such as wireless
phones before they can be sold, as it does with new
drugs or medical devices. However, the agency has
authority to take action if wireless phones are shown
to emit radio frequency energy (RF) at a level that is
hazardous to the user. In such a case, FDA could
require the manufacturers of wireless phones to notify
users of the health hazard and to repair, replace or
recall the phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA
regulatory actions, FDA has urged the wireless phone
industry to take a number of steps, including the
following:
• “Support needed research into possible biological
effects of RF of the type emitted by wireless
phones;
• “Design wireless phones in a way that minimizes
any RF exposure to the user that is not necessary
for device function; and
• “Cooperate in providing users of wireless phones
with the best possible information on possible
effects of wireless phone use on human health.
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at
the federal level. The following agencies belong to this
working group:
• “National Institute for Occupational Safety and
Health
• “Environmental Protection Agency
• “Federal Communications Commission
• “Occupational Safety and Health Administration
• “National Telecommunications and Information
Administration
The National Institutes of Health participates in some
interagency working group activities, as well.
Health and safety information
101
FDA shares regulatory responsibilities for wireless
phones with the Federal Communications Commission
(FCC). All phones that are sold in the United States
must comply with FCC safety guidelines that limit RF
exposure. FCC relies on FDA and other health agencies
for safety questions about wireless phones.
FCC also regulates the base stations that the wireless
phone networks rely upon. While these base stations
operate at higher power than do the wireless phones
themselves, the RF exposures that people get from
these base stations are typically thousands of times
lower than those they can get from wireless phones.
Base stations are thus not the primary subject of the
safety questions discussed in this document.
What are the results of the research done
already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws in
their research methods. Animal experiments
investigating the effects of radio frequency energy
(RF) exposures characteristic of wireless phones have
yielded conflicting results that often cannot be
repeated in other laboratories. A few animal studies,
however, have suggested that low levels of RF could
accelerate the development of cancer in laboratory
animals. However, many of the studies that showed
increased tumor development used animals that had
been genetically engineered or treated with cancer-
causing chemicals so as to be pre-disposed to develop
cancer in absence of RF exposure. Other studies
exposed the animals to RF for up to 22 hours per day.
These conditions are not similar to the conditions
under which people use wireless phones, so we don't
know with certainty what the results of such studies
mean for human health.
Three large epidemiology studies have been published
since December 2000. Between them, the studies
investigated any possible association between the use
of wireless phones and primary brain cancer, glioma,
meningioma, or acoustic neuroma, tumors of the brain
or salivary gland, leukemia, or other cancers. None of
the studies demonstrated the existence of any harmful
health effects from wireless phones RF exposures.
However, none of the studies can answer questions
102
Health and safety information
about long-term exposures, since the average period
of phone use in these studies was around three years.
What research is needed to decide whether RF
exposure from wireless phones poses a health
risk?
A combination of laboratory studies and
epidemiological studies of people actually using
wireless phones would provide some of the data that
are needed. Lifetime animal exposure studies could be
completed in a few years. However, very large
numbers of animals would be needed to provide
reliable proof of a cancer promoting effect if one
exists. Epidemiological studies can provide data that is
directly applicable to human populations, but ten or
more years' follow-up may be needed to provide
answers about some health effects, such as cancer.
This is because the interval between the time of
exposure to a cancer-causing agent and the time
tumors develop - if they do - may be many, many
years. The interpretation of epidemiological studies is
hampered by difficulties in measuring actual RF
exposure during day-to-day use of wireless phones.
Many factors affect this measurement, such as the
angle at which the phone is held, or which model of
phone is used.
What is FDA doing to find out more about the
possible health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology
Program and with groups of investigators around the
world to ensure that high priority animal studies are
conducted to address important questions about the
effects of exposure to radio frequency energy (RF).
FDA has been a leading participant in the World Health
Organization international Electromagnetic Fields
(EMF) Project since its inception in 1996. An influential
result of this work has been the development of a
detailed agenda of research needs that has driven the
establishment of new research programs around the
world. The Project has also helped develop a series of
public information documents on EMF issues.
FDA and Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative
Research and Development Agreement (CRADA) to do
Health and safety information
103
research on wireless phone safety. FDA provides the
scientific oversight, obtaining input from experts in
government, industry, and academic organizations.
CTIA-funded research is conducted through contracts
to independent investigators. The initial research will
include both laboratory studies and studies of wireless
phone users. The CRADA will also include a broad
assessment of additional research needs in the
context of the latest research developments around
the world.
What steps can I take to reduce my exposure
to radio frequency energy from my wireless
phone?
If there is a risk from these products - and at this
point we do not know that there is - it is probably very
small. But if you are concerned about avoiding even
potential risks, you can take a few simple steps to
minimize your exposure to radio frequency energy
(RF). Since time is a key factor in how much exposure
a person receives, reducing the amount of time spent
using a wireless phone will reduce RF exposure.
• “If you must conduct extended conversations by
wireless phone every day, you could place more
distance between your body and the source of the
RF, since the exposure level drops off dramatically
with distance. For example, you could use a
headset and carry the wireless phone away from
your body or use a wireless phone connected to a
remote antenna.
Again, the scientific data do not demonstrate that
wireless phones are harmful. But if you are concerned
about the RF exposure from these products, you can
use measures like those described above to reduce
your RF exposure from wireless phone use.
What about children using wireless phones?
The scientific evidence does not show a danger to
users of wireless phones, including children and
teenagers. If you want to take steps to lower exposure
to radio frequency energy (RF), the measures
described above would apply to children and
teenagers using wireless phones. Reducing the time of
wireless phone use and increasing the distance
104
Health and safety information
between the user and the RF source will reduce RF
exposure.
Some groups sponsored by other national
governments have advised that children be
discouraged from using wireless phones at all. For
example, the government in the United Kingdom
distributed leaflets containing such a recommendation
in December 2000. They noted that no evidence exists
that using a wireless phone causes brain tumors or
other ill effects. Their recommendation to limit
wireless phone use by children was strictly
precautionary; it was not based on scientific evidence
that any health hazard exists.
Do hands-free kits for wireless phones reduce
risks from exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that hands-free kits reduce risks. Hands-free
kits can be used with wireless phones for convenience
and comfort. These systems reduce the absorption of
RF energy in the head because the phone, which is the
source of the RF emissions, will not be placed against
the head. On the other hand, if the phone is mounted
against the waist or other part of the body during use,
then that part of the body will absorb more RF energy.
Wireless phones marketed in the U.S. are required to
meet safety requirements regardless of whether they
are used against the head or against the body. Either
configuration should result in compliance with the
safety limit.
Do wireless phone accessories that claim to
shield the head from RF radiation work?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that accessories that claim to shield the head
from those emissions reduce risks. Some products
that claim to shield the user from RF absorption use
special phone cases, while others involve nothing
more than a metallic accessory attached to the phone.
Studies have shown that these products generally do
not work as advertised. Unlike “hand-free” kits, these
so-called “shields” may interfere with proper operation
of the phone. The phone may be forced to boost its
Health and safety information
105
power to compensate, leading to an increase in RF
absorption. In February 2002, the Federal trade
Commission (FTC) charged two companies that sold
devices that claimed to protect wireless phone users
from radiation with making false and unsubstantiated
claims. According to FTC, these defendants lacked a
reasonable basis to substantiate their claim.
What about wireless phone interference with
medical equipment?
Radio frequency energy (RF) from wireless phones can
interact with some electronic devices. For this reason,
FDA helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted
cardiac pacemakers and defibrillators from wireless
telephones. This test method is now part of a standard
sponsored by the Association for the Advancement of
Medical instrumentation (AAMI). The final draft, a joint
effort by FDA, medical device manufacturers, and
many other groups, was completed in late 2000. This
standard will allow manufacturers to ensure that
cardiac pacemakers and defibrillators are safe from
wireless phone EMI. FDA has tested wireless phones
and helped develop a voluntary standard sponsored by
the Institute of Electrical and Electronic Engineers
(IEEE). This standard specifies test methods and
performance requirements for hearing aids and
wireless phones so that no interference occurs when a
person uses a compatible phone and a compatible
hearing aid at the same time. This standard was
approved by the IEEE in 2000.
FDA continues to monitor the use of wireless phones
for possible interactions with other medical devices.
Should harmful interference be found to occur, FDA
will conduct testing to assess the interference and
work to resolve the problem.
Additional information on the safety of RF exposures
from various sources can be obtained from the
following organizations:
• FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
• Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
106
Health and safety information
• Occupational Safety and Health Administration's
(OSHA):
http://www.osha.gov/SLTC/
radiofrequencyradiation/index.html
• National institute for Occupational Safety and
Health (NIOSH):
http://www.cdc.gov/niosh/emfpg.html
• World health Organization (WHO):
http://www.who.int/peh-emf/
• International Commission on Non-Ionizing
Radiation Protection:
http://www.icnirp.de
• National Radiation Protection Board (UK):
http://www.nrpb.org.uk
• Updated 4/3/2002: US food and Drug
Administration
http://www.fda.gov/cellphones
Road Safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime.
But an important responsibility accompanies the
benefits of wireless phones, one that every user must
uphold.
When driving a car, driving is your first responsibility.
When using your wireless phone behind the wheel of a
car, practice good common sense and remember the
following tips:
1. Get to know your wireless phone and its features,
such as speed dial and redial. If available, these
features help you to place your call without taking
your attention off the road.
2. When available, use a hands-free device. If
possible, add an additional layer of convenience
and safety to your wireless phone with one of the
many hands free accessories available today.
3. Position your wireless phone within easy reach. Be
able to access your wireless phone without
removing your eyes from the road. If you get an
Health and safety information
107
incoming call at an inconvenient time, let your
voice mail answer it for you.
4. Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy
traffic or hazardous weather conditions. Rain,
sleet, snow, ice and even heavy traffic can be
hazardous.
5. Do not take notes or look up phone numbers while
driving. Jotting down a “to do” list or flipping
through your address book takes attention away
from your primary responsibility, driving safely.
6. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan calls when your car
will be stationary. If you need to make a call while
moving, dial only a few numbers, check the road
and your mirrors, then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting. Make
people you are talking with aware you are driving
and suspend conversations that have the potential
to divert your attention from the road.
8. Use your wireless phone to call for help. Dial 9-1-1
or other local emergency number in the case of
fire, traffic accident or medical emergencies.
Remember, it is a free call on your wireless phone!
9. Use your wireless phone to help others in
emergencies. If you see an auto accident, crime in
progress or other serious emergency where lives
are in danger, call 9-1-1 or other local emergency
number, as you would want others to do for you.
10.Call roadside assistance or a special non-
emergency wireless assistance number when
necessary. If you see a broken-down vehicle
posing no serious hazard, a broken traffic signal, a
minor traffic accident where no one appears
injured, or a vehicle you know to be stolen, call
roadside assistance or other special non-
emergency number.
“The wireless industry reminds you to use your
phone safely when driving.”
For more information, please call 1-888-901-SAFE, or
visit our web-site www.wow-com.com
108
Health and safety information
Provided by the Cellular Telecommunications &
Internet Association
Operating Environment
Remember to follow any special regulations in force in
any area and always switch your phone off whenever it
is forbidden to use it, or when it may cause
interference or danger. When connecting the phone or
any accessory to another device, read its user's guide
for detailed safety instructions. Do not connect
incompatible products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation of
the equipment and for the safety of personnel, it is
recommended that the equipment should only be used
in the normal operating position (held to your ear with
the antenna pointing over your shoulder).
Using Your Phone Near Other Electronic
Devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against the
RF signals from your wireless phone. Consult the
manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be maintained
between a wireless phone and a pacemaker to avoid
potential interference with the pacemaker.
These recommendations are consistent with the
independent research and recommendations of
Wireless Technology Research.
Persons with pacemakers:
• should always keep the phone more than 15 cm
(6 inches) from their pacemaker when the phone is
switched on.
• should not carry the phone in a breast pocket.
Health and safety information
109
• should use the ear opposite the pacemaker to
minimize potential interference.
If you have any reason to suspect that interference is
taking place, switch your phone off immediately.
Hearing Aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you
may wish to consult your hearing aid manufacturer to
discuss alternatives.
Other Medical Devices
If you use any other personal medical devices, consult
the manufacturer of your device to determine if it is
adequately shielded from external RF energy. Your
physician may be able to assist you in obtaining this
information. Switch your phone off in health care
facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care facilities
may be using equipment that could be sensitive to
external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle. You should also
consult the manufacturer of any equipment that has
been added to your vehicle.
Posted Facilities
Switch your phone off in any facility where posted
notices require you to do so.
Potentially Explosive Environments
Switch your phone off when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause an
explosion or fire resulting in bodily injury or even
death.
Users are advised to switch the phone off while at a
refueling point (service station). Users are reminded of
the need to observe restrictions on the use of radio
equipment in fuel depots (fuel storage and distribution
110
Health and safety information
areas), chemical plants or where blasting operations
are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas (such
as propane or butane), areas where the air contains
chemicals or particles, such as grain, dust or metal
powders, and any other area where you would
normally be advised to turn off your vehicle engine.
Emergency Calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well as
user programmed functions, which cannot guarantee
connection in all conditions. Therefore, you should
never rely solely on any wireless phone for essential
communications (medical emergencies, for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not be
possible on all wireless phone networks or when
certain network services and/or phone features are in
use. Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location (for example, 911 or other official
emergency number). Emergency numbers vary by
location.
3. Press .
If certain features are in use (call barring, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult this document and your local cellular service
provider.
When making an emergency call, remember to give all
the necessary information as accurately as possible.
Remember that your phone may be the only means of
communication at the scene of an accident; do not cut
off the call until given permission to do so.
Health and safety information
111
Restricting Children's access to your Phone
Your phone is not a toy. Children should not be allowed
to play with it because they could hurt themselves and
others, damage the phone or make calls that increase
your phone bill.
FCC Notice and Cautions
FCC Notice
The phone may cause TV or radio interference if used
in close proximity to receiving equipment. The FCC
can require you to stop using the phone if such
interference cannot be eliminated.
Vehicles using liquefied petroleum gas (such as
propane or butane) must comply with the National Fire
Protection Standard (NFPA-58). For a copy of this
standard, contact the National Fire Protection
Association, One Battery march Park, Quincy, MA
02269, Attn: Publication Sales Division.
Cautions
Changes or modifications made in the radio phone, not
expressly approved by Samsung, will void the user’s
authority to operate the equipment.
Only use approved batteries, antennas and chargers.
The use of any unauthorized accessories may be
dangerous and void the phone warranty if said
accessories cause damage or a defect to the phone.
Although your phone is quite sturdy, it is a complex
piece of equipment and can be broken. Avoid
dropping, hitting, bending or sitting on it.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
112
Health and safety information
Other Important Safety Information
• Only qualified personnel should service the phone
or install the phone in a vehicle. Faulty installation
or service may be dangerous and may invalidate
any warranty applicable to the device.
• Check regularly that all wireless phone equipment
in your vehicle is mounted and operating properly.
• Do not store or carry flammable liquids, gases or
explosive materials in the same compartment as
the phone, its parts or accessories.
• For vehicles equipped with an air bag, remember
that an air bag inflates with great force. Do not
place objects, including both installed or portable
wireless equipment in the area over the air bag or
in the air bag deployment area. If wireless
equipment is improperly installed and the air bag
inflates, serious injury could result.
• Switch your phone off before boarding an aircraft.
The use of wireless phone in aircraft is illegal and
may be dangerous to the aircraft's operation.
• Failure to observe these instructions may lead to
the suspension or denial of telephone services to
the offender, or legal action, or both.
Product Performance
Getting the Most Out of Your Signal Reception
The quality of each call you make or receive depends
on the signal strength in your area. Your phone
informs you of the current signal strength by
displaying a number of bars next to the signal strength
icon. The more bars displayed, the stronger the signal.
If you're inside a building, being near a window may
give you better reception.
Understanding the Power Save Feature
If your phone is unable to find a signal after 15
minutes of searching, a Power Save feature is
automatically activated. If your phone is active, it
periodically rechecks service availability or you can
check it yourself by pressing any key.
Health and safety information
113
Anytime the Power Save feature is activated, a
message displays on the screen. When a signal is
found, your phone returns to standby mode.
Understanding How Your Phone Operates
Your phone is basically a radio transmitter and
receiver. When it's turned on, it receives and transmits
radio frequency (RF) signals. When you use your
phone, the system handling your call controls the
power level. This power can range from 0.006 watts to
0.2 watts in digital mode.
Maintaining Your Phone's Peak Performance
For the best care of your phone, only authorized
personnel should service your phone and accessories.
Faulty service may void the warranty.
There are several simple guidelines to operating your
phone properly and maintaining safe, satisfactory
service.
• Hold the phone with the antenna raised, fully-
extended and over your shoulder.
• Try not to hold, bend or twist the phone's antenna.
• Don't use the phone if the antenna is damaged.
• Speak directly into the phone's receiver.
• Avoid exposing your phone and accessories to rain
or liquid spills. If your phone does get wet,
immediately turn the power off and remove the
battery. If it is inoperable, call Customer Care for
service.
Availability of Various Features/Ring
Tones
Many services and features are network dependent
and may require additional subscription and/or usage
charges. Not all features are available for purchase or
use in all areas. Downloadable Ring Tones may be
available at an additional cost. Other conditions and
restrictions may apply. See your service provider for
additional information.
Battery Standby and Talk Time
Standby and talk times will vary depending on phone
usage patterns and conditions. Battery power
114
Health and safety information
consumption depends on factors such as network
configuration, signal strength, operating temperature,
features selected, frequency of calls, and voice, data,
and other application usage patterns.
Battery Precautions
• Never use any charger or battery that is damaged
in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network's base
station, it uses less power; talk and standby time
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
• Battery charging time depends on the remaining
battery charge and the type of battery and charger
used. The battery can be charged and discharged
hundreds of times, but it will gradually wear out.
When the operation time (talk time and standby
time) is noticeably shorter than normal, it is time
to buy a new battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not in use,
disconnect it from the power source. Do not leave
the battery connected to a charger for more than a
week, since overcharging may shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling or
warming first.
• Do not leave the battery in hot or cold places, such
as in a car in summer or winter conditions, as you
will reduce the capacity and lifetime of the battery.
Always try to keep the battery at room
temperature. A phone with a hot or cold battery
may temporarily not work, even when the battery
is fully charged. Li-ion batteries are particularly
affected by temperatures below 0 °C (32 °F).
• Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object (coin,
clip or pen) causes a direct connection between the
Health and safety information
115
+ and - terminals of the battery (metal strips on
the battery), for example when you carry a spare
battery in a pocket or bag. Short-circuiting the
terminals may damage the battery or the object
causing the short-circuiting.
• Dispose of used batteries in accordance with local
regulations. In some areas, the disposal of
batteries in household or business trash may be
prohibited. For safe disposal options for Li-Ion
batteries, contact your nearest Samsung
authorized service center. Always recycle. Do not
dispose of batteries in a fire.
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for
many years.
• Keep the phone and all its parts and accessories
out of the reach of small children.
• Keep the phone dry. Precipitation, humidity and
liquids contain minerals that will corrode electronic
circuits.
• Do not use the phone with a wet hand. Doing so
may cause an electric shock to you or damage to
the phone.
• Do not use or store the phone in dusty, dirty areas,
as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the phone,
which may damage the phone's electronic circuit
boards.
• Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the phone. Wipe it with
116
Health and safety information
a soft cloth slightly dampened in a mild soap-and-
water solution.
• Do not paint the phone. Paint can clog the device's
moving parts and prevent proper operation.
• Do not put the phone in or on heating devices,
such as a microwave oven, a stove or a radiator.
The phone may explode when overheated.
• When the phone or battery gets wet, the label
indicating water damage inside the phone changes
color. In this case, phone repairs are no longer
guaranteed by the manufacturer's warranty, even
if the warranty for your phone has not expired.
• If your phone has a flash or light, do not use it too
close to the eyes of people or animals. This may
cause damage to their eyes.
• Use only the supplied or an approved replacement
antenna. Unauthorized antennas or modified
accessories may damage the phone and violate
regulations governing radio devices.
• If the phone, battery, charger or any accessory is
not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
