Samsung Electronics Co SGHS308 Triband GPRS Phone User Manual 00 S308 cover
Samsung Electronics Co Ltd Triband GPRS Phone 00 S308 cover
User Manual
ELECTRONICS
GSM TELEPHONE
SGH-S308
* Some of the contents in this manual may differ from your phone,
depending on the software installed or your service provider.
Printed in Korea
Code No.: GH68-xxxxxA
English. 12/2002. Rev. 1.0
2nd version
(2002,12,6)
www.samsungmobile.com
23
Contents
Important Safety Precautions . . . . . . . . 7
Unpacking . . . . . . . . . . . . . . . . . . . . . . . 9
Your Phone . . . . . . . . . . . . . . . . . . . . . 10
Phone Layout. . . . . . . . . . . . . . . . . . . . . 10
Display . . . . . . . . . . . . . . . . . . . . . . . . . 13
Service Light . . . . . . . . . . . . . . . . . . . . . 16
Getting Started . . . . . . . . . . . . . . . . . . 17
Installing the SIM Card . . . . . . . . . . . . . . 17
Charging a Battery . . . . . . . . . . . . . . . . . 19
Switching the Phone On or Off . . . . . . . . . 23
Call Functions . . . . . . . . . . . . . . . . . . . 24
Making a Call. . . . . . . . . . . . . . . . . . . . . 24
Adjusting the Volume . . . . . . . . . . . . . . . 26
Answering a Call . . . . . . . . . . . . . . . . . . 27
Viewing Missed Calls . . . . . . . . . . . . . . . . 28
Quickly Switching to Silent Mode . . . . . . . 30
Selecting Functions and Options . . . . . 31
Example: Setting the Display Language . . . 33
Phonebook . . . . . . . . . . . . . . . . . . . . . 35
Storing a Number with a Name. . . . . . . . . 35
Using Phonebook Entry Options . . . . . . . . 37
Searching for and Dialling a Number in the
Phonebook . . . . . . . . . . . . . . . . . . . . . . 39
Editing a Caller Group . . . . . . . . . . . . . . . 41
Speed-Dialling . . . . . . . . . . . . . . . . . . . . 42
Checking Memory Status . . . . . . . . . . . . . 43
5
4
Contents Contents
Entering Text. . . . . . . . . . . . . . . . . . . . 44
Changing the Text Input Mode . . . . . . . . . 45
Using the Chinese Pinyin Mode . . . . . . . . . 47
Using the Chinese Stroke Mode . . . . . . . . 49
Using the Quick English Mode. . . . . . . . . . 52
Using the English Mode . . . . . . . . . . . . . . 54
Using the Number Mode . . . . . . . . . . . . . 56
Using the Symbolic Mode . . . . . . . . . . . . 56
Using Help . . . . . . . . . . . . . . . . . . . . . . 56
Options During a Call. . . . . . . . . . . . . . 57
Putting a Call on Hold . . . . . . . . . . . . . . . 57
Switching the Microphone Off (Mute) . . . . . 58
Muting/Sending Key Tones . . . . . . . . . . . . 59
Searching for a Number in the Phonebook . 59
Using the SMS Service . . . . . . . . . . . . . . 60
Answering a Second Call . . . . . . . . . . . . . 60
Making a Multiparty Call . . . . . . . . . . . . . 61
Using the Menus . . . . . . . . . . . . . . . . . 63
Accessing Menu Functions by Scrolling. . . . 63
Accessing Menu Functions by Using
Shortcuts . . . . . . . . . . . . . . . . . . . . . . . 64
List of Menu Functions . . . . . . . . . . . . . . 64
Messages. . . . . . . . . . . . . . . . . . . . . . . 69
Read Messages (Menu 1.1) . . . . . . . . . . . 69
Write Messages (Menu 1.2). . . . . . . . . . . 71
Templates (Menu 1.3) . . . . . . . . . . . . . . 73
Setup (Menu 1.4) . . . . . . . . . . . . . . . . . 73
Broadcast (Menu 1.5) . . . . . . . . . . . . . . 75
Voice Mail (Menu 1.6) . . . . . . . . . . . . . . 76
My Contents (Menu 1.7) . . . . . . . . . . . . . 77
Memory Status (Menu 1.8) . . . . . . . . . . . 77
Call Records. . . . . . . . . . . . . . . . . . . . . 78
Missed Calls (Menu 2.1) . . . . . . . . . . . . . 78
Received Calls (Menu 2.2) . . . . . . . . . . . 78
Dialled Calls (Menu 2.3) . . . . . . . . . . . . . 79
Delete All (Menu 2.4) . . . . . . . . . . . . . . . 79
Call Time (Menu 2.5) . . . . . . . . . . . . . . . 79
Call Cost (Menu 2.6) . . . . . . . . . . . . . . . 80
Sound Settings . . . . . . . . . . . . . . . . . . 81
Ring Tone (Menu 3.1) . . . . . . . . . . . . . . 81
Ring Volume (Menu 3.2). . . . . . . . . . . . . 81
Alert Type (Menu 3.3) . . . . . . . . . . . . . . 82
Keypad Tone (Menu 3.4) . . . . . . . . . . . . 82
Message Tone (Menu 3.5) . . . . . . . . . . . . 83
Folder Tone (Menu 3.6) . . . . . . . . . . . . . 84
Power On/Off (Menu 3.7) . . . . . . . . . . . . 84
Extra Tones (Menu 3.8) . . . . . . . . . . . . . 84
Phone Settings . . . . . . . . . . . . . . . . . . 86
Infrared Activate (Menu 4.1) . . . . . . . . . . 86
My Settings (Menu 4.2) . . . . . . . . . . . . . 87
Greeting Message (Menu 4.3) . . . . . . . . . 88
Own Number (Menu 4.4) . . . . . . . . . . . . 88
Language (Menu 4.5). . . . . . . . . . . . . . . 89
Security (Menu 4.6). . . . . . . . . . . . . . . . 89
Display Settings (Menu 4.7) . . . . . . . . . . 92
Extra Settings (Menu 4.8). . . . . . . . . . . . 94
Short Cut (Menu 4.9). . . . . . . . . . . . . . . 95
Reset Settings (Menu 4.10). . . . . . . . . . . 95
Organiser . . . . . . . . . . . . . . . . . . . . . . 96
Calendar (Menu 5.1) . . . . . . . . . . . . . . . 96
To Do List (Menu 5.2) . . . . . . . . . . . . . . 98
Time & Date (Menu 5.3) . . . . . . . . . . . . 101
Alarm (Menu 5.4) . . . . . . . . . . . . . . . . 102
Calculator (Menu 5.5). . . . . . . . . . . . . . 103
Currency Exchange (Menu 5.6) . . . . . . . 104
Network Services. . . . . . . . . . . . . . . . 105
Call Diverting (Menu 6.1) . . . . . . . . . . . 105
Call Barring (Menu 6.2) . . . . . . . . . . . . 107
Call Waiting (Menu 6.3) . . . . . . . . . . . . 109
Network Selection (Menu 6.4) . . . . . . . . 110
Caller ID (Menu 6.5) . . . . . . . . . . . . . . 111
Closed User Group (CUG) (Menu 6.6) . . . 111
Band Selection (Menu 6.7) . . . . . . . . . . 113
7
6
Contents
Important Safety
Precautions
Read these guidelines before using your wireless
phone. Failure to comply with them may be
dangerous or illegal. For more detailed safety
information, see "Health and Safety Information"
on page 123.
Road Safety at All Times
Do not use a hand-held phone while driving;
park the vehicle first.
Switching Off When Refuelling
Do not use the phone at a refuelling point
(service station) or near fuels or chemicals.
Switching Off in Aircraft
Wireless phones can cause interference. Using
them in aircraft is both illegal and dangerous.
Switching Off in Hospitals
Switch off your phone near medical equipment.
Follow any regulations or rules in force.
Interference
All wireless phones may be subject to
interference, which could affect their
performance.
Special Regulations
Meet any special regulations in force in any area
and always switch off your phone whenever it is
forbidden to use it, or when it may cause
interference or danger (in a hospital for
example).
Funbox . . . . . . . . . . . . . . . . . . . . . . . 114
Games (Menu 7.1). . . . . . . . . . . . . . . . 114
WAP Browser (Menu 7.2) . . . . . . . . . . . 114
Downloads (Menu 7.3) . . . . . . . . . . . . . 114
Solving Problems . . . . . . . . . . . . . . . . 116
Access Codes . . . . . . . . . . . . . . . . . . . 119
Phone Password . . . . . . . . . . . . . . . . . . 119
PIN . . . . . . . . . . . . . . . . . . . . . . . . . . 120
PUK . . . . . . . . . . . . . . . . . . . . . . . . . . 120
PIN2. . . . . . . . . . . . . . . . . . . . . . . . . . 121
PUK2 . . . . . . . . . . . . . . . . . . . . . . . . . 121
Barring Password . . . . . . . . . . . . . . . . . 122
Health and Safety Information. . . . . . 123
Precautions When Using Batteries. . . . . . 126
Road Safety. . . . . . . . . . . . . . . . . . . . . 128
Operating Environment. . . . . . . . . . . . . 130
Potentially Explosive Atmospheres. . . . . . 132
Emergency Calls. . . . . . . . . . . . . . . . . . 133
Other Important Safety Information. . . . 134
Care and Maintenance. . . . . . . . . . . . . . 135
Glossary. . . . . . . . . . . . . . . . . . . . . . 142
Quick Reference Card. . . . . . . . . . . . 147
9
8
Important Safety Precautions
Unpacking
Your package contains the following items.
Sensible Use
Use only in the normal position (held to the ear).
Avoid unnecessary contact with the antenna
when the phone is switched on.
Accessories and Batteries
Use only Samsung-approved accessories and
batteries.
Qualified service
Only qualified service personnel may install or
repair your phone.
Handset
Batteries
Battery Charger
User’s Manuals
PC Link CD-ROM
Data Cable
Travel Adapter
Ear-microphone
Handstrap
11
10
Your Phone
Your Phone
Phone Layout
The following illustrations show the main
elements of your phone
Key Description
In the menu mode, scroll through the
menu options and the phonebook
memory.
In the idle mode, allow you to access
your favourite menu options directly
(for more information on shortcuts, see
page 95).
In the menu mode, return to the
previous menu level and select the
current menu respectively.
When entering text, move the cursor to
the left and right respectively.
In the idle mode, the key enters the
Read Messages menu and the key
enters the Ring Tone menu.
Perform the functions indicated by the
text above them (on the bottom line of
the display).
In the idle mode, launches the
WAP(Wireless Application Protocol)
Browser directly.
Deletes characters from the display.
In the menu mode, returns to the
previous menu level.
Earpiece
Display
Navigation keys
Folder
Soft key (right)
WAP Browser
key
Power on/off /
menu exit key
Alphanumeric
keys
Special function
keys
Volume/menu
browse keys
Soft key (left)
Dial/menu
confirmation key
Cancel/
correction key
Microphone
IrDA port
Antenna
Service Light
External display
(Soft keys)
13
12
Your Phone Your Phone
Key Description (Continued)
Makes or answers a call.
When held down in the idle mode,
recalls the last number dialled or
received.
In the menu mode, selects a menu
function or stores information that you
have entered (such as a name) in the
phone or SIM memory.
Ends a call. Also switches the phone on
and off when held down.
In the menu mode, cancels your input
and returns to the idle mode.
When held down in the idle mode,
accesses your voice mail.
Enter numbers, letters and some
special characters.
Enter special characters.
Perform the various functions.
(on the side of the phone)
During a call, adjust the earpiece
volume.
In the idle mode, adjust the key
volume.
In the menu mode, scroll through the
menu options and the phonebook
memory.
Display
Display Layout
The display comprises three areas.
Area Description
First line Displays various icons (see page
14).
Middle lines Display messages, instructions
and any information that you
enter (number to be dialled, for
example).
Last line Shows the functions currently
assigned to the two soft keys.
Menu Name
Text and
graphic area
Soft keys
Icons
15
14
Your Phone Your Phone
Icons
Icon Description
Shows the received signal strength. The
greater the number of bars, the
stronger the signal.
Appears when a call is in progress.
Appears when you are connected to the
GPRS network.
Appears when the Silent mode is active
or you set the Alert Type menu option
(Menu 3.3), so that the phone vibrates
when you receive a call; for further
details, see page 82.
Appears when a new text message has
been received.
Appears when a new voice mail
message has been received.
Appears when you are entering text to
indicate the current text input mode.
Appears when you set an alarm to ring
at a specified time.
Shows the level of your battery. The
more bars you see, the more power you
have left.
Appears when the IrDA port is active.
For details, see page 86.
Appears when you are out of your
home area and have registered with a
different network; for example, when
travelling in other countries.
Appears when the Mute mode is active.
Backlight
A backlight illuminates the display and keypad.
When you press any key or open the folder, the
backlight lights on. It turns off if no key is
pressed within a given period of time, depending
on the Back Light menu option (Menu 4.7.2).
To specify the length of time for which the
backlight is active, set the Back Light menu
option (Menu 4.7.2); see page 92 for further
details.
You can also set the phone to use the backlight
only during a specified period time, in the Auto
Light menu option (Menu 4.7.3); see page 93
for further details.
External Display
Your phone has an external display on the folder.
It indicates when you have an incoming call or a
message. It also alerts you when you have set
an alarm at the specified time by showing its
backlight and corresponding icon on it.
When the folder is closed, the display is off so
that you can use it as a mirror. If you want to
turn the display on, press and hold the or
key on the side of the phone.
When a call comes in or you open the folder, the
display automatically turns on.
17
16
Your Phone
Service Light
The service light is above the external LCD on
the folder. It flashes when services are available
on the phone.
To activate or deactivate use of the service light,
set the Service Light menu option (Menu
4.7.4); see page 93 for further details.
Service light
Getting Started
Installing the SIM Card
When you subscribe to a cellular network, you
are provided with a plug-in SIM card loaded with
your subscription details, such as your PIN, any
optional services available and so on.
Important! The plug-in SIM card and its
contacts can be easily damaged by
scratches or bending, so be careful
when handling, inserting or
removing the card.
Keep all SIM cards out of the reach
of small children.
1. If necessary, switch off the phone by holding
down the key until the power-off image
displays.
2. Remove the battery. To do so:
➀Pull the battery lock above the battery
toward the top of the phone and hold it in
that position.
➁Lift the battery away, as shown.
19
Getting StartedGetting Started
3. Slide the SIM card into the SIM card socket so
that it locks the card in position.
Make sure that the cut corner is top right and
the gold contacts of the card face into the
phone.
Note: When you need to remove the SIM card,
slide it, as shown, and take it out of the
socket.
4. Place the battery so that the tabs on the end
align with the slot at the bottom of the phone.
18
5. Push the battery down until it clicks into
place. Make sure that the battery is properly
installed before switching the phone on.
Charging a Battery
Your phone is powered by a rechargeable Li-ion
battery. A travel adapter and a battery charger
are provided with your phone. Use only
approved batteries and chargers. Ask your local
Samsung dealer for further details.
Note: You must fully charge the battery before
using your phone for the first time. A
discharged battery is fully recharged in
approximately 200 minutes.
Using the Battery Charger
Using the battery charger, you can charge the
battery alone.
1. Insert the battery into the charger, ensuring
that the terminals on the battery are in
contact with those on the charger. Press the
battery down until it clicks into place.
21
Getting Started
20
Getting Started
2. Plug the connector of the travel adapter into
the jack at the bottom of the charger.
3. Plug the adapter into a standard AC wall
outlet.
The LED on the charger will indicate the
charging progress with the following colours:
• Red: the battery is charging
• Green: the battery is completely charged
• Yellow: the battery is not correctly plugged
in or operating in a too high or too low
temperature.
4. When charging is finished, unplug the adapter
from both the power outlet and the charger.
5. Take the battery out of the charger.
Using the Travel Adapter
The travel adapter allows you to use the phone
while the battery is charging, but this will cause
the phone to charge more slowly.
1. With the battery in position on the phone,
plug the connector of the travel adapter into
the jack at the bottom of the phone.
2. Plug the adapter into a standard AC wall
outlet.
23
Getting Started
22
Getting Started
Low Battery Indicator
When the battery is weak and only a few
minutes of talk time remain, you will hear a
warning tone and a message will be repeated at
regular intervals on the display:
If the battery level gets too low, the phone turns
off automatically.
Note: Do not remove the battery from the phone
without unplugging the adapter while it is
charging. If you do this, the phone may be
damaged.
**Warning**
Low Battery
Menu Name
Switching the Phone On or Off
1. Open the folder.
2. Hold down the key until the phone
switches on.
3. If the phone asks you to enter the phone
password, enter the password and press the
OK soft key. The phone password is preset to
“00000000” at the factory. For further details,
see page 119.
4. If the phone asks for a PIN, enter the PIN and
press the OK soft key. For further details, see
page 120.
The phone searches for your network and
when it finds the network, the idle screen,
illustrated below, appears on each display.
Now, you can make or receive a call.
Note: The display language is preset to English
at the factory. To change the language,
use the Language menu option (Menu
4.5); for further details, refer to page 89.
5. When you wish to switch the phone off, hold
down the key until the power-off image
is displayed.
Service Provider
7:30
Wed 06 Mar
Menu Name
07:30
Wed/06
3. When charging is finished, unplug the adapter
from both the power outlet and the phone by
pressing the grey tabs on both sides of the
connector and pulling the connector out.
25
24
Call Functions
Making a Call
When the idle screen displays, enter the area
code and phone number, and press the key.
Note: If you have checked the Auto Redial option
in the Extra Settings menu (Menu 4.8),
the number is redialled automatically up to
ten times when the person does not answer
the call or is already on the phone; see page
85 for further details.
Making an International Call
1. Press and hold the 0key.
The +character appears.
2. Enter the country code, area code and phone
number and press the key.
Correcting the Number
To clear Press
the last digit the Ckey.
displayed
any other digit the or key until the cursor
in the number is immediately to the right of
the digit to be cleared. Press
the Ckey. You can also
insert a missing digit simply
by pressing the appropriate
key.
the whole display and hold the Ckey for more
than one second.
Ending a Call
When you want to finish your call, briefly press
the key.
Redialling the Last Number
The phone stores the numbers you dialled,
received or missed if the caller is identified; see
“Call Records” on page 78 for further details.
To recall any of these numbers:
1. If you have typed any characters on the
display, clear the display by holding the Ckey
for more than one second.
2. Press the key to display a list of the last
numbers in order of time in which the call was
made.
3. Use the and keys to scroll through
the numbers until the required number is
highlighted.
4. To Press
dial the number the key.
highlighted
edit the number the Edit soft key. Change
highlighted the number as required,
referring to “Correcting the
Number” on page 24 for
further details.
Call Functions
27
Call Functions
Answering a Call
When someone calls you, the phone alerts you
by ringing and displaying the following screen:
If the caller can be identified, the caller's phone
number or name, if stored in your phonebook, is
displayed.
1. If necessary, open the folder. Press the
key or the Accept soft key to answer the
incoming call.
If the Anykey Answer option in the Extra
Settings menu (Menu 4.8) is checked, you
can press any key to answer a call, except for
the key, and the Reject soft key (see
page 94).
If the Active Folder option in the Extra
Settings menu (Menu 4.8) is checked, you
can answer the call simply by opening the
folder (see page 94).
Note: To reject an incoming call, press and hold
the volume keys on the left side of the
phone without opening the folder.
2. End the call by closing the folder or pressing
the key.
Note: You can answer a call while using the
phonebook or menu features.
26
Call Functions
Making a Call from the Phonebook
You can store the phone numbers that you use
regularly in the SIM card or the phone's
memory, which are collectively called the
Phonebook. Simply select the required name to
recall the associated number. For further details
on the Phonebook features, refer to page 35.
Adjusting the Volume
During a call, if you want to adjust the earpiece
volume, use the and keys on the left side
of the phone.
Press the key to increase and the key to
decrease the volume.
In the idle mode with the folder open, you can
adjust the key volume using the and keys.
Accept Reject
29
Call Functions
28
Call Functions
Editing a Missed Call Number
Note: If the number corresponding to the missed
call is not available, the Edit Number option
is not displayed.
1. Press the Options soft key.
2. If necessary, press the or key to
highlight the Edit Number option.
3. Press the Select soft key.
4. Change the number as required.
5. To Press the
call the number key.
store the number Save soft key and
enter the name and
location required (for
further details, refer to
page 35).
Deleting a Missed Call
1. Press the Options soft key.
2. If necessary, press the or key to
highlight the Delete option.
3. Press the Select soft key.
You can press the key at any time to exit
the Missed Call feature.
Note: You can access the Missed Call feature at
any time by selecting the Missed Calls
menu option (Menu 2.1); for further details,
see page 78.
Viewing Missed Calls
If you are unable to answer a call for any
reason, you can find out who is calling you, if
this service is available. So that you can call the
person back, if necessary.
The number of missed calls displays on the idle
screen immediately after a call is missed.
To view the missed call immediately:
1. If the phone is closed, open the folder.
2. Press the View soft key.
The number corresponding to the most recent
missed call displays, if available.
3. To Press the
scroll through the or key.
missed calls
call the number key.
displayed
edit or delete a Select soft key (see
missed call number the next page).
31
30
Call Functions
Selecting Functions
and Options
Your phone offers a set of functions that allow
you to customise it. These functions are
arranged in menus and sub-menus, accessed via
the two soft keys marked and . Each menu
and sub-menu allows you to view and alter the
settings of a particular function.
The roles of the soft keys vary according to the
current context; the label on the bottom line of
the display just above each key indicates its
current role.
Example:
Press the left
soft key to
access the main
menu mode.
Press the right soft
key to access the
Phonebook menu.
Quickly Switching to Silent Mode
Silent mode is convenient when discretion is
required and you wish to stop the phone from
making any noise, in a theatre for example.
In the idle mode, to switch your phone quickly
to the silent mode, simply press and hold the
key until the "Silent Mode" message and
vibration icon ( ) are displayed.
In the silent mode, your phone changes the
sound settings as follows:
Option New Setting
Alert Type (Menu 3.3)Vibration
Keypad Tone (Menu 3.4)OFF
SMS Tone (Menu 3.5.1)Light Only
Error Tone (Menu 3.8.1)OFF
To exit the silent mode and reactivate the
previous Sound Settings, press and hold the
key again until "Exit Silent Mode" appears. The
vibration icon ( ) is no longer displayed.
Menu Name
Service Provider
7:30
Wed 06 Mar
33
Selecting Functions and Options
32
Selecting Functions and Options
Example: Setting the Display
Language
1. When the idle screen displays, press the
Menu soft key to access the menus.
2. Scroll through the menus until you reach the
Phone Settings menu, by pressing the
or key.
4
3. To select the Phone Settings menu, press
the Select soft key or the key.
4.1
If the menu name is too
long for the display, it is
scrolled when highlighted.
To view the various functions/options available
and select the required one:
1. Press the appropriate soft key.
2. To Press the
select the: Select soft key or
• Function displayed the key.
or
• Option highlighted
view the next function key or key on
or highlight the next the left side of the
option in a list phone.
move back to the key or key on
previous function or the left side of the
option in a list phone.
move back up one key, soft key or
level in the structure C key.
exit the structure key.
without changing
the settings
In some functions, you may be asked for a
password or PIN. Enter the required code and
press the OK soft key.
Service Provider
7:30
Wed 06 Mar
Menu Name
Select
Sound Settin...
Phone Settings
Phone Settings
Organiser
Phone Settin...
Infrared Activa
My Settings
Greeting Me...
Own Number
Language
Select
35
34
Selecting Functions and Options
4. Scroll through the sub-menus until you reach
the Language sub-menu, by pressing the
or key.
4.5
5. To view the languages available, press the
Select soft key or the key. The current
setting highlights.
4.5.1
6. Scroll through the list of languages until the
appropriate one is highlighted, by pressing
the or key.
7. Press the Select soft key or the key to
confirm your selection.
8. Press the Cor key twice to exit the menu
structure.
Current language
Shows the current
setting.
Phone Settings
Infrared Activ..
My Settings
Greeting Me...
Own N
Language
English
Chinese S
Chinese T
Language
English
Select
Select
Select
Phonebook
You can store phone numbers and their
corresponding names in the memory of your SIM
card. The SIM card and phone memories,
although physically separate, are used as a
single entity, called the phonebook.
Storing a Number with a Name
There two ways to store a number:
• Using the Save soft key in idle mode
• Using the New Entry option in the Phonebook
menu
Storing a Number in Idle mode
As soon as you start to enter a number, Save
appears above the left soft key to allow you to
store the number in the phonebook.
1. Enter the number you want to store.
Note: If you make a mistake while entering a
number, correct it using the Ckey. For
further details, refer to page 24.
2. To save the number, press the Save soft key.
3. Select an icon to identify the category of
number to be stored. Three categories are
available: (mobile phone number),
(office number) and (home number). To
select the category, press the or key,
followed by the Select soft key.
37
36
PhonebookPhonebook
4. Enter a name and press the OK soft key.
The maximum length of a name depends on
your SIM card. For information on how to
enter characters, see page 44.
5. Press the OK soft key to confirm your input.
The phone now displays the first free location
in the last memory used to save a number
and name. If that memory is full, the first free
location in the other memory is displayed.
Note: If you change phones, any numbers stored
in your SIM card memory will automatically
be available with the new phone, whereas
any numbers stored in the phone memory
must be restored.
6. Press the right soft key, labelled To Card or
To Phone to toggle between the phone and
card memories.
7. If you do not want to save the number and
name in the suggested location, press the C
key to clear the location number and enter
your preferred location by pressing the
number keys.
8. Press the OK soft key to store the name and
number.
After storing, the phone displays the
phonebook entry or name just created.
9. To Press the
use the entry options Options soft key.
return to the idle key.
screen
Storing a Number using the Phonebook
Menu
1. When the idle screen displays, press the
Name soft key.
2. Scroll to New Entry by pressing the or
key and press the Select soft key.
3. Select an icon to identify the category of the
number to be stored.
Note: The E-mail icon ( ) is available in this
step. It allows you to save an e-mail
address instead of a phone number.
4. Continue the procedure from Step 4 on page
36 to store the number.
Using Phonebook Entry Options
While accessing any phonebook entry, press the
Options soft key to access the options for the
entry.
To Press the
select the highlighted Select soft key or the
option key.
highlight a different or key until
option the required option
highlights.
39
Phonebook
38
Phonebook
The following options are available.
Paste: allows you to paste the selected number
into the normal dialling mode. Use this option to
dial a number similar to one in the phonebook, a
different extension in the same office, for
example.
Use the Ckey to change the number as
required; refer to page 24 for further details.
When you are ready to dial, press the key.
Edit: allows you to edit the phonebook entry.
Select One Entry to change one number in the
selected name. If you change the name, the
number is saved separately. Select All Entry to
change the name of the entry.
Erase: allows you to erase the selected name
and number from the Phonebook. You are asked
to confirm that you wish to erase the name and
number by pressing the Yes soft key.
Copy: allows you to copy the selected number
to another location. Use this option to store a
number similar to one already in the memory;
once copied, edit the number and store it in the
phonebook.
Caller Group: allows you to organise your
phonebook entries in up to 10 caller groups so
that the phone alerts you in a specific way when
a person from one of your groups calls you.
Select one of the ten groups available.
To remove an entry from a group, select the No
Group option.
For more information on how to change caller
group properties, see page 41.
Add Entry: allows you to add a new number in
a different category (mobile, office, home or
E-mail) to the currently selected name. A
phonebook entry or name can contain up to four
number, one in each category.
Searching for and Dialling a
Number in the Phonebook
After storing numbers in the phonebook, you can
search for them in two ways: by name and by
caller group.
Searching for a Number by Name
1. When the idle screen is displayed, press the
Name soft key.
2. Press the Select soft key when Search
highlights. You are asked to enter a name.
3. Enter the first few letters of the name that
you wish to find.
The phonebook entries are listed, starting with
the first entry matching your input. This entry
is also highlighted.
4. To Press the
view the highlighted View soft key.
entry
select a different entry or key until
the required entry
highlights.
look for a name key labelled with the
starting with a required letter.
different letter
5. Find the required number under the name by
pressing the or key.
41
Phonebook
6. Once you have found the required entry,
press the key to dial the number, or
press the Options soft key to access the
phonebook entry options; for further details,
see page 35.
Editing a Caller Group
1. When the idle screen displays, press the
Name soft key.
2. Scroll to Group Edit by pressing the or
key and press the Select soft key.
3. Enter the first few letters of the required
group name or scroll through the group list by
pressing the or key.
4. When the desired group is highlighted, press
the Options soft key. The following options
are available:
Call ring tone: allows you to select the ring
melody to be used when you receive a voice
call from a person in the group.
SMS tone: allows you to select the ring tone
to be used when you received a text message
from a person in the group.
Graphic: allows you to select the graphic icon
to be displayed when you receive a voice call
from a person in the group.
Group Name: allows you to assign a name to
the group; for further details about how to
enter characters, see page 44.
5. Select the desired option by pressing the
or key, followed the Select soft key, and
change the setting.
6. When you finish changing the settings, press
the Cor key.
40
Phonebook
6. Once you have found the required entry,
press the key to dial the number, or
press the Options soft key to access the
phonebook entry options; for further details,
see page 37.
Searching a Number by Caller Group
1. When the idle screen displays, press the
Name soft key.
2. Scroll to Group Search by pressing the
or key and press the Select soft key. You
are asked to enter a group name.
3. Enter the first few letters of the group name
that you wish to find.
The caller groups are listed, starting with the
first group matching your input. The group
also highlights.
4. Scroll to the required group by pressing the
or key and press the View soft key.
The phonebook entries in the selected caller
group are listed.
5. To Press the
view the highlighted View soft key.
entry
select a different entry or key until
the required entry
highlights.
look for a name key labelled with the
starting with a required letter.
different letter
43
Phonebook
42
Phonebook
Erase All: allows you to clear the settings for
all keys so that no numbers are assigned to
any of the keys.
Number: allows you to view the number
assigned to the key.
7. When you finish setting the options, press the
Cor key.
Speed-Dialling from the Phonebook
To speed-dial the numbers assigned to keys 2to
9, press and hold the appropriate key.
Note: Memory location 1 is reserved for your Voice
Mail server number.
Checking Memory Status
You can check how many names and numbers
are stored in the phonebook; SIM card and
phone memories. You can also see the capacity
of both memories.
1. When the idle screen displays, press the
Name soft key.
2. Select the Memory Status option.
3. Press the or key to view the number
of the existing and remaining entries in the
card and phone memories.
Speed-Dialling
Once you have stored phone numbers in the SIM
card, you can set up to eight speed-dial entries
and then dial them easily whenever you want,
simply by pressing the associated number key.
Setting Up Speed-Dial Entries
1. When the idle screen is displayed, press the
Name soft key.
2. Scroll to Speed Dial by pressing the or
key and press the Select soft key.
3. Select the key to which you wish to assign the
speed-dialling feature from 2to 9keys and
press the OK soft key.
Note: If you have already assigned a number to
the key, the Options soft key replaces the
OK soft key. Go to Step 6.
4. Select the required phonebook entry from the
list and press the View soft key.
5. Select the required number if the entry has
more than one number, by pressing the
or key and press the Select soft key.
6. Once you have assigned a number to the
selected key, the following options are
available:
Change: allows you to assign a different
number to the key.
Erase: allows you to clear the setting so that
no number is assigned to the key.
45
Entering Text
44
Changing the Text Input Mode
When you are in a field that allows characters to
be entered, you will notice the text input mode
indicator on the display.
Example: Entering a name for a phonebook
entry
You can change between Chinese and English
input methods or to numbers input. To change to
another text input mode:
1. Press the right soft key, labelled with the
current mode.
2. Scroll to the desired mode with the and
keys.
3. To select the displayed mode, press the
Confirm soft key.
Enter Name
Input Mode
Pinyin
CHN S Stroke
Quick English
English
CHN T Stroke
OK PY Mode
Confirm
Text input mode
indicator
Entering Text
The phone allows you to enter characters for
messages and names in Chinese and English. To
enter Chinese text, the phone provides several
widely used pronunciation based (Pinyin) and
character shape based (Stroke) input methods to
meet the preferences of different users, allowing
for greater convenience and ease of use.
You can also enter any combination of Chinese
characters, alphabets, numbers, and special
symbols including punctuation marks.
The following text input modes are available on
your phone:
• Pinyin mode
• Chinese Simplified Stroke mode
• Quick English mode
• English mode
• Chinese Traditional Stroke mode
• Number mode
• Symbolic mode
• Help mode
Directions for using each of the text input modes
appear later in this section.
47
Entering Text
46
Entering Text
Note: If you want to exit the menu without
changing to a new mode, press the right
soft key.
4. You will find the selected text input mode
indicator at the bottom of the display.
Using the Chinese Pinyin Mode
Pinyin is a system to mark Chinese
pronunciation in Latin alphabets. With the pinyin
input method, you can enter Chinese characters
by keying in the pinyin string from the phone
keypad and the phone automatically presents
the matching alternatives.
This mode allows you to enter Pinyin characters
with only one key press per letter.
Typing Characters in the Pinyin Mode
1. Press keys corresponding to the phonetic
spelling, referring to the alphabets printed on
the keys. Notice that the choices in the
Character Selection Map change.
Example: Typing in the Pinyin mode
• Chinese Pinyin mode →PY Mode
• Chinese Simplified Stroke mode → S STR
• Quick English mode →ENG
• English mode →ABC
• Chinese Traditional Stroke mode →T STR
• Number mode →NUM
• Symbolic mode →SYM Mode
• Help mode →HELP Mode
2. If you cannot find the character on the
display, scroll through choices in the
Character Selection map by pressing the
key. To move back, press the key.
When the character you are typing appears in
the Character Selection Map, you may select
it, without completing the Pinyin spelling for
the character.
Enter Name
OK S STR
Enter Name
OK PY Mode
Character Selection Map
Key Stroke Area
Press and
to enter “li”
49
Entering Text
48
Entering Text
3. To select a character, press the 1 key to
activate the Character Selection Map. A
number (7 to ) is added to the beginning of
a corresponding character. With the Character
Selection Map being activated, a normal press
on the 7 key to the key selects the
corresponding character.
Inserting a Space
To insert a space between characters, press the
key when the cursor blinks in the Text Area.
Scrolling
To move the cursor to the left or to the right
through your text message, press the or
key.
Clearing Strokes and Characters
Press the Ckey one or more times to remove
key stokes to the left. When the Key Stroke Area
is empty, pressing the Ckey removes characters
from the Text Area.
Rapid Character Entry
Rapid character entry is easy in any mode, using
the Character Selection Map. As you enter
characters, your phone predicts the next
character you might want and presents choices
in the Character Selection Map area. When a
desired character appears, you may select it as
described in Step 3 on page 48.
For example, if you want to type the word
“zhong guo ( )” and entered the first
character using the following keystrokes; 9, 4, 6,
6, 1 and 7, you don’t need to complete the
Pinyin spelling to include “guo ( ).” With no
extra typing, the character is displayed
conveniently in the Character Selection Map for
you to choose.
Using the Chinese Stroke Mode
This mode allows you to enter individual Chinese
strokes, in written order, from top to bottom and
from left to right. Your phone provides Chinese
Simplified Stroke mode and Chinese Traditional
Stroke mode.
The two modes work similarly, but the
characters that appear on the display may differ.
Even though there are many different strokes
used to create Chinese characters, the strokes
are classified into 5 basic categories; heng, shu,
pie, dian and zhe. The basic strokes are printed
on the keypad, on the keys 1to 5.
To enter a stroke, press the key printed with the
stroke that most closely represents the exact
stroke you desire.
Enter Name
OK PY Mode
Press to
select “ ”
51
Entering Text
50
Entering Text
The table shows the stroke/key relationship: 2. The phone displays your strokes in the Key
Stroke Area and offers character choices in
the Character Selection Map. As you enter
strokes, notice that the choices in the
Character Selection Map change. To scroll
through choices in the Character Selection
Map, press the key. To move back, press
the key.
3. When the character you are typing appears in
the Character Selection Map, you may select
it without finishing the stroke sequence for
the character. Characters displayed in the
Character Selection Map correspond to the
keys 7to on the keypad. To select a
character from the Character Selection Map
and add it to your message, press the
corresponding key (7to ).
Note: If you are uncertain of the order of one or
more strokes, press the 6key in place of
each questionable stroke. Continue entering
strokes until the character is displayed in the
Character Selection Map or until you finish
the character.
Inserting a Space
To insert a space between characters, press the
key when the cursor blinks in the Text Area.
Scrolling
To move the cursor to the left or to the right
through your text message, press the or
key.
Typing Stokes and Characters in
Stroke Mode
1. To type a character, press keys corresponding
to its component strokes. Press keys on the
phone in order that you would write the
strokes, using one press per desired stroke.
Example: Typing in Chinese Simplified
Stroke mode
Enter Name
OK T STR
Character Selection Map
Press to select “ ”
Key Stroke Area
Press and
to enter “ ”
53
Entering Text
52
Entering Text
Clearing Strokes and Characters
Press the C key one or more times to remove
strokes to the left. When the Key Stroke Area is
empty, pressing the Ckey removes characters
from the Text Area.
Rapid Character Entry
Rapid character entry is easy in any mode, using
the Character Selection Map. As you enter
characters, your phone predicts the next
character you might want and presents choices
in the Character Selection Map area. When a
desired character appears, you may select it as
described in Step 3 on page 49.
In most cases, you will see the desired character
in the Character Selection Map area before you
have entered all of the strokes to build it.
For example, try typing the twelve stroke
character pair “ ” using the following
keystrokes; 2, 8, and 7. Even though “ ” is a
twelve stroke character pair, your phone enables
you to type it in only three key presses!
Using the Quick English Mode
This mode allows you to enter English words
with only one key press per letter. Each key on a
keypad has more than one letter - a single press
on the 5 key could be J, K, or L. The Quick
English mode automatically compares your key
presses to an internal linguistic database to
determine the correct word.
The mode requires far fewer keystrokes than the
traditional multi-tap method, English mode.
1. Press keys on the phone just once per desired
letter. For example, to enter “HELLO,” press
, , , and .
The word that you are typing appears on the
display. It may change with each key that you
press.
2. Type to the end of the word before editing or
deleting any keystrokes.
3. If the word is correct, put a space by pressing
the key and start entering the next word.
Otherwise, press the 0, or key
repeatedly to display alternative word choices
for the keys that you pressed.
Example: Both “OF” and “ME” have the
sequence of 6and 3. The phone displays the
most commonly used choice first.
To type words not found in the Quick English
mode, change the text input mode to English.
Smart Punctuation
To enter full stops, hyphens or apostrophes,
press the 1key. The Quick English mode applies
grammar rules to ensure that the correct
punctuation is used.
Example: The 1key is used twice to display two
punctuation marks:
L E T ’ S E A T .
55
Entering Text
54
Entering Text
Changing the Case
To change the case of the letters, use the
key. The Capital Lock mode is indicated by
and the Small Caps mode is indicated by .
Scrolling
You can move the cursor through the text by
using the and keys.
Clearing Letters and Words
To delete letters, press the Ckey. Press and hold
the Ckey to clear the display.
Using the English Mode
When typing in the English mode, you should
press key labelled with the required character:
-Once for the first character
-Twice for the second character
and so on.
For example, you need to press the 2key three
times to display the character “C” and the 5key
two times to display the character “K.” For this
reason, this method is called Multi-tap typing.
The cursor moves to the right when you press a
different key. When entering the same letter
twice or a different letter on the same key, just
wait for a few seconds for the cursor to move to
the right automatically, and then select the next
letter.
You can put a space between each word by
pressing the key.
Refer to the table below for more information
about the characters available in the English
mode.
Changing the Case
To change the case of the letters, use the
key. The Capital Lock mode is indicated by
and the Small Caps mode is indicated by .
Scrolling
You can move the cursor through the text by
using the and keys.
Clearing Letters and Words
To delete letters, press the Ckey. Press and hold
the Ckey to clear the display.
Characters in the Order Displayed
Upper Case
Key
Space
Lower Case
57
Options During a Call
Your phone provides a number of control
functions that you can use during a call.
Putting a Call on Hold
You can place the current call on hold whenever
you want. You can make another call while you
have a call in progress if your network supports
this service. If you have an active call and a call
on hold, you may switch between the two calls,
changing the one on hold to active and placing
the other on hold.
To place a call on hold, simply press the Hold
soft key. You can reactivate the call whenever
you want, by pressing the Unhold soft key.
To make a call while you have a call in progress:
1. Enter the phone number that you wish to dial
or look it up in the phonebook.
2. Press the key to dial the second call.
The first call is automatically put on hold.
Or alternatively,
1. Put the current call on hold by pressing the
Hold soft key.
2. Make the second call in the normal way.
To switch between the two calls, simply press
the Swap soft key.
The current call is placed on hold and the call on
hold is reactivated so that you can continue
conversing with the other party.
When you have finished, end each call normally
by pressing the key.
56
Entering Text
Using the Number Mode
The Number mode enables you to enter numbers
in a text message (a telephone number for
example). Press the keys corresponding to the
required digits before manually switching back to
the appropriate text input mode.
Using the Symbolic Mode
The symbol mode enables you to insert symbols
in a text message.
Use the navigation keys to scroll to the desired
symbol and then press the OK soft key to insert
the highlighted symbol into your message.
Using Help
On-screen help is available by selecting Help
from the Input Mode menu. Use the and
keys to scroll through the Help information.
Symbolic
OK SYM Mode
59
Options During a Call
58
Options During a Call
Muting/Sending Key Tones
These options allow you to turn the key tones off
or on. If the Mute keys option is selected, your
phone does not transmit the key tones. It allows
you to press keys without hearing annoying key
tones during a call.
Note: To communicate with answering machines or
computerised telephony systems, the Send
keys option must be selected.
Searching for a Number in the
Phonebook
You can search for a number in the Phonebook
during a call.
1. Press the Options soft key.
2. Press the key to highlight the Phonebook
option.
3. Press the OK soft key.
The phonebook entries are listed.
4. Enter the name that you wish to find.
If you enter the first few letters of the name,
the phonebook entries are listed, starting with
the first entry matching your input. The entry
also highlights.
5. To view the highlighted entry, press the View
soft key.
For a more information on the Phonebook feature,
refer to page 35.
Switching the Microphone Off (Mute)
You can temporarily switch your phone's
microphone off so that the other party cannot
hear you.
Example: You wish to say something to another
person in the room but do not want
the other party to hear you.
To switch the microphone off temporarily:
1. Press the Options soft key.
2. If necessary, press the key to highlight
the Mute option.
3. Press the OK soft key.
The other party can no longer hear you.
To switch the microphone back on:
1. Press the Options soft key.
2. If necessary, press the key to highlight
the Unmute option.
3. Press the OK soft key.
The other party can hear you again.
61
Options During a Call
60
Options During a Call
Making a Multiparty Call
A multiparty call is a network service that allows
up to six people to take part simultaneously in a
multiparty or conference call. For more
information, contact your service provider.
Setting up the Multiparty Call
1. Call the first participant in the normal way.
2. Call the second participant in the normal way.
The first call is automatically put on hold.
3. To join the first participant to the multiparty
call, press the Options soft key and select
the Join option.
4. To add a new person to the multiparty call,
call the person in the normal way, and then
press the Options soft key and select the
Join option.
You can add incoming callers by answering the
call and pressing Options, followed by Join.
Repeat as required.
Having a Private Conversation With
One Participant
1. Press the Options soft key and choose the
Select one option.
The list of call participants appears.
2. Highlight the required person, by pressing the
or key, followed by the Select soft
key or the key.
Using the SMS Service
If you receive an SMS (Short Message Service)
message during a call, the message icon ( )
flashes on the display. The SMS Service option
enables you to use this feature.
Read Messages: allows you to read the
messages that you have received.
Write Messages: allows you to write a message.
For further details on the SMS service, refer to
page 71.
Answering a Second Call
You can answer an incoming call while you have a
call in progress, if your network supports this
service and you have set the Call Waiting menu
option (Menu 6.3) to Activate (see page 109).
You will be notified of an incoming call by a call
waiting tone.
To answer a call while you have a call in
progress:
1. Press the key to answer the incoming call.
The first call is automatically put on hold.
2. To switch between the two calls, press the
Swap soft key.
To end the call on hold, press the Options soft
key and select the End Held Call option.
3. To end the current call, press the key.
63
62
Options During a Call
Using the Menus
The phone offers a range of functions that allow
you to tailor it to your needs. These functions are
arranged in menus and sub-menus.
The menus and sub-menus can be accessed by
scrolling with the navigation keys or by using the
shortcuts.
Accessing Menu Functions by Scrolling
1. In idle mode, press the Menu soft key to
access menu mode.
2. Scroll with the or key to reach the
required main menu, Phone Settings for
example. Press the Select soft key or the
key to enter the menu.
3. If the menu contains any sub-menus,
Language for example, you can access them
by scrolling with the or key and
pressing the Select soft key.
If the menu that you have selected contains
further options, repeat this step.
4. To Press the
scroll through the or key or
menus use the and keys
on the left side of the
phone.
confirm the chosen Select soft key or the
setting key.
return to the soft key or the key.
previous menu level
exit the menu key.
without changing
the settings
3. Select the Private option.
Now you can talk privately with that person.
The other participants can still converse with
each other.
4. To return to the multiparty call, press the
Options soft key and select Join.
All the multiparty call participants can now
hear each other.
Dropping One Participant
1. Press the Options soft key and choose the
Select one option.
The list of call participants appears.
2. Select a person from the list by pressing the
or key, followed by the Select soft
key or the key.
3. Select Remove.
The call ends with that participant, but you
can continue to talk with the other
participants.
4. End the multiparty call by closing the phone
or pressing the key.
65
Using the Menus
64
Using the Menus
Accessing Menu Functions by Using
Shortcuts
The menu items, menu, sub-menus and options,
are numbered and can be accessed quickly by
using their shortcut number. The shortcut number
is shown in the bottom right next to the soft
key on the display. Simply press the Menu soft
key and enter the required number.
Note: The numbers assigned to each menu option
are indicated in the list on page 65. They
may not match the menu number on the
phone, depending on the services supported
by your SIM card.
Example: Accessing the Language option.
1. Press the Menu soft key.
2. Press for Phone Settings.
3. Press for Language.
The languages available displays directly.
List of Menu Functions
The following illustration shows the menu
structure available and indicates the:
• Number assigned to each option
• Page on which you can find a description of
each feature
Note: If you use a SIM AT card that provides
additional services, the SIM AT menu (8)
displays first when you press the Menu soft
key to enter menu mode. For further details,
refer to your SIM card instructions.
1. Messages (see page 69)
1.1 Read Messages
1.1.1 Inbox
1.1.2 Outbox
1.2 Write Messages
1.3 Templates
1.4 Setup
1.4.1 Setting 1*
1.4.2 Setting 2*
1.4.3 Common Setting
1.5 Broadcast
1.5.1 Read
1.5.2 Receive
1.5.3 Channel List
1.5.4 Language
1.6 Voice Mail
1.6.1 Connect to Voice Server
1.6.2 Voice Server
1.7 My Contents
1.7.1 My EMS Melody
1.7.2 My EMS Picture
1.7.3 My EMS Animation
1.8 Memory Status
1.8.1 SIM memory
1.8.2 PHONE memory
1.8.3 CB memory
1.8.4 Delete All
2. Call Records (see page 78)
2.1 Missed Calls
2.2 Received Calls
2.3 Dialled Calls
2.4 Delete All
2.4.1 Missed Calls
2.4.2 Received Calls
2.4.3 Dialled Calls
* Shown only if supported by your SIM card.
67
Using the Menus
4. Phone Settings (continued)
4.6 Security
4.6.1 PIN Check
4.6.2 Change PIN
4.6.3 Phone Lock
4.6.4 Change Password
4.6.5 SIM Lock
4.6.6 FDN Mode*
4.6.7 Change PIN2*
4.7 Display Settings
4.7.1 Contrast
4.7.2 Back Light
4.7.3 Auto Light
4.7.4 Service Light
4.7.5 Graphic Logo
4.8 Extra Settings
4.8.1 Auto Redial
4.8.2 Active Folder
4.8.3 Anykey Answer
4.9 Short Cut
4.10 Reset Settings
5. Organiser (see page 96)
5.1 Calendar
5.2 To Do List
5.3 Time & Date
5.3.1 Set Time
5.3.2 Set Date
5.3.3 World Time
5.3.4 Time Format
5.4 Alarm
5.5 Calculator
5.6 Currency Exchange
6. Network Services
6.1 Call Diverting
6.1.1 Divert Always
6.1.2 Busy
6.1.3 No Reply
6.1.4 Unreachable
6.1.5 Cancel All
66
Using the Menus
2. Call Records (continued)
2.5Call Time
2.5.1 Last Call Time
2.5.2 Total Sent
2.5.3 Total Received
2.5.4 Reset Timers
2.6Call Cost*
2.6.1 Last Call Cost
2.6.2 Total Cost
2.6.3 Max Cost
2.6.4 Reset Counters
2.6.5 Set Max Cost
2.6.6 Price/Unit
3. Sound Settings (see page 81)
3.1 Ring Tone
3.2 Ring Volume
3.3 Alert Type
3.4 Keypad Tone
3.5 Message Tone
3.5.1 SMS Tone
3.5.2 SMS-CB Tone
3.6 Folder Tone
3.7 Power On/Off
3.8 Extra Tones
3.8.1 Error Tone
3.8.2 Minute Minder
3.8.3 Connect Tone
4. Phone Settings (see page 86)
4.1 Infrared Activate
4.2 My Settings
4.2.1 Wallpaper
4.2.2 Menu Style
4.3 Greeting Message
4.4 Own Number
4.5 Language
* Shown only if supported by your SIM card.
69
68
Using the Menus
Messages
The SMS (Short Message Service) function is a
network service that may not be supported by
your network. You can send messages by a text,
fax, Email and paging messaging systems,
provided that these services are supported by
your network. To send text messages by phone,
you must obtain the number of the SMS centre
from your service provider.
When the message icon ( ) appears, you have
received new text messages. If the message
memory is full, an error message displays and
you cannot receive any new messages. Use the
Delete option in the Read Messages menu
(Menu 1.1) to delete obsolete messages.
Read Messages (Menu 1.1)
Two message boxes are available.
Inbox: used to store the messages that you
have received.
Outbox: used to store the messages that you
have already sent or will send.
Reading a Message
1. Select the required box and press the Select
soft key.
The list of messages in the box displays with
the sender or recipient's phone number or
name, if it is available in your phonebook.
2. Select the required message and press the
View soft key to view the message contents.
6. Network Services (continued)
6.2 Call Barring
6.2.1 All Outgoing
6.2.2 International
6.2.3 International Except to Home
6.2.4 All Incoming
6.2.5 Incoming While Abroad
6.2.6 Cancel All
6.2.7 Change Barring Password
6.3 Call Waiting
6.3.1 Voice Calls
6.3.2 Data Calls
6.3.3 Cancel All
6.4 Network Selection
6.4.1 Automatic
6.4.2 Manual
6.5 Caller ID
6.5.1 Default
6.5.2 Hide Number
6.5.3 Send Number
6.6 Closed User Group
6.6.1 Index List
6.6.2 Outside Access
6.6.3 Default Group
6.6.4 Deactivate*
6.7 Band Selection
7. Fun Box (see page 114)
7.1 Games
7.2 WAP Browser
7.3 Downloads
7.3.1 Sounds
7.3.2 Picture
* Shown only if the Closed User Group Feature is active.
71
Messages
70
Messages
Write Messages (Menu 1.2)
In this menu, you can write and send a text
message.
Note: You can enter up to 918 alphanumeric
characters for your message. If you add
objects to the message, the number of
characters you can enter will be decreased.
Creating a Simple Text Message
1. Create your message.
Note: For more information about entering
characters, refer to page 44.
2. When you finish entering the message, press
the Options soft key. The following options
are available:
Send Only: allows you to send the message.
The message is deleted after sending.
Save and Send: allows you to save a copy of
the message and then send the message to
the required destination. You can read the
message in your outbox using the Read
Messages option.
Save Only: allows you to save the message
so that it can be sent later. You can read the
message in your outbox using the Read
Messages option.
Add Object: allows you to add the required
sound, picture or animation to the message.
Select the category of the object to be added;
Sound, Melody, Picture and Animation are
available. In each category, you can select
various factory-set items or choose items
received from other sources, such as the
Internet or other phones.
3. To scroll through the message, press the
or key.
While reading a message, you can choose the
following options by pressing the Options soft
key.
Delete: allows you to delete obsolete messages.
Text Reply (inbox only): allows you to reply to
the sender by sending a text message. You can
also change the SMS centre number, if required.
Call Back (inbox only): allows you to call the
sender back.
Cut Number: allows you to extract a number
from the message, if it has one, so that you can
call the number or save it in your phonebook.
Send: allows you to send a message that you
have received or saved. For more information on
how to send a message, see page 71.
Edit Message: allows you to edit a message.
Select Objects: allows you to save the objects,
such as sounds or images, from the message
into your phone. You can use the objects when
writing a message; for details, see page 72.
Note: The options available vary, depending on the
message status (new/old, not sent or sent
for example).
73
Messages
72
Messages
Templates (Menu 1.3)
Using this menu, you can preset up to five
messages that you use most frequently. Scroll
through the template list using the and
keys. When the required message template
highlights, press the Options soft key.
Edit: allows you to write a new message or edit
the selected message.
Note: For further information on how to enter
characters, refer to page 44.
Send Message: allows you to recall the selected
message. Once you have completed the
message, you can send, save and send, or simply
save it. For further details on how to send a
message, see page 71.
Delete: allows you to delete the selected
message. You are asked to confirm the deletion
by pressing the Yes soft key.
Setup (Menu 1.4)
In this menu, you can set up default SMS
information. A setting group is a collection of
settings required to send messages. The number
of setting groups available depends on the
capacity of your SIM card.
Setting x (where xis the setting group
number): each group has its own sub-menu.
Service Centre: allows you to store or change the
number of your SMS centre, which is required
when sending messages. You must obtain this
number from your service provider.
Add Template: allows you to apply one of
the preset message templates to the text.
Select one of the five messages predefined
via the Templates menu option (Menu 1.3);
for further details, see page 71.
3. When you finish entering your message, press
the Options soft key and select Send Only
or Save and Send.
If you want just to save the message, select
Save Only. After saving the message, the
phone returns to the Messages menu.
4. Enter a destination number. Pressing the
Name soft key allows you to search the
Phonebook for a number.
5. Press the OK soft key. The message is sent.
75
Messages
74
Messages
Broadcast (Menu 1.5)
This network service allows you to receive text
messages on various topics, such as the weather
or traffic. Messages display immediately they are
received, provided that:
• The phone is in idle mode
• The Receive option is set to Enable
•The message channel is currently active in the
channel list
The following options are available.
Read: lets you view the received message.
Volatile displays the messages from the
network, but loses its contents as soon as the
phone is switched off. Scroll through the
message by using the and keys. While
reading a message, press the Save soft key to
store the message in the Archive box for later
retrieval.
Receive: allows you to enable or disable the
reception of broadcast messages.
Channel List: allows you to indicate the
channels from which you wish to receive
broadcast messages. The following options are
available.
Select: use to enable or disable channels in the
list by marking or unmarking them respectively.
A check mark displays in front of each selected
channel.
Add Channel: use to enter the ID and title for a
new channel.
Delete: use to remove a channel from the list.
Edit: use to change the ID and title of an
existing channel.
Default Type: allows you to set the default
message type-Text, Fax, Email and Paging. The
network can convert the messages into the
selected format.
Default Validity: allows you to set the length of
time for which your text messages are stored at
the message centre while attempts are made to
deliver them.
Setting Name: allows you to give a name to the
setting group currently being defined.
Common Setting: the following options are
available.
Reply Path: allows the recipient of your SMS
message to send you a reply message via your
message centre, if your network supports with
this service.
Delivery Reports: allows you to activate or
deactivate the report function. When this
function is activated, the network informs you
whether your message has been delivered or
not.
Bearer Selection: allows you to choose between
GSM and GPRS.
77
Messages
76
Messages
My Contents (Menu 1.7)
After saving any objects received in messages into
your phone memory, using the Select Object
option (see page 70), you can see the objects in
this menu.
To delete the objects in this menu, press the
Delete soft key.
You can forward the objects to other people by
including message and/or use them for your ring
tone or background them in a image.
Three categories of objects are available:
• My EMS Melody
• My EMS Picture
• My EMS Animation
Memory Status (Menu 1.8)
This menu shows how many messages are
currently stored in the SIM, phone and CB
memories.
You can delete all of the messages in each
message box using the Delete All option (Menu
1.8.4).
When the desired message box highlights, press
the Select soft key. When a confirming message
displays, press the Yes soft key to delete. If not,
press the No soft key.
Language: allows you to select your preferred
language to display cell broadcast messages.
Please contact your service provider for more
information.
Voice Mail (Menu 1.6)
This menu provides you with a way of accessing
your voice mailbox, if your network supports this
service.
The following options are available.
Connect to Voice Server: before using this
feature, you must enter the voice server number
obtained from your service provider (see menu
option 1.6.2). You can then select this option
and simply press the OK soft key to listen to
your messages.
To quickly connect to the voice server, press and
hold down the 1key in the idle mode.
Voice Server: allows you to change the voice
mail server number, if necessary.
To Press the
enter the server corresponding numeric
number keys.
correct a digit Ckey.
move the cursor to or key.
the left/right without
clearing the digit
save the number OK soft key.
Note: Voice Mail is a network feature. Please
contact your service provider for more
information.
79
Call Records
78
Dialled Calls (Menu 2.3)
This option lets you view the last 20 numbers
you dialled.
The number and name, if available, display
together with the date and time at which the call
was made. By pressing the Options soft key,
you can:
• Delete the number
• Edit the number and save it in the phonebook
Delete All (Menu 2.4)
You can delete all of the call records in each call
type; missed, received, dialled calls.
Call Time (Menu 2.5)
This option lets you view the timers for calls
made and received.
The following timers are available:
Last Call Time: length of the last call.
Total Sent: total length of all calls made since
the timer was last reset.
Total Received: total length of all calls received
since the timer was last reset.
Reset Timers: option used to reset the call
timers; you must first enter the phone password
(see page 119) and then press the OK soft key.
Note: The actual time invoiced for calls by your
service provider may vary, depending on
network features, rounding-off for billing
purposes and so forth.
Call Records
In this menu, you can view the following phone
calls that are:
• Missed
• Received
• Dialled
Note: You can access all numbers in the three
types of call records by pressing the key
in idle mode.
Missed Calls (Menu 2.1)
This option lets you view the last 20 numbers of
the calls you received, but did not answer.
The number and name, if available, display
together with the date and time at which the call
was received. By pressing the Options soft key,
you can:
• Edit the number if available and dial it or save
it in the phonebook
• Delete the call from the list
Received Calls (Menu 2.2)
This option lets you view the last 20 numbers at
the calls received.
The number and name, if available, display
together with the date and time at which the call
was received. By pressing the Options soft key,
you can:
• Edit the number if available and dial it or save
it in the phonebook
• Delete the call from the list
81
80
Call Records
Sound Settings
You can use the Sound Settings feature to
customise various settings, such as the:
• Ring melody, volume and type
• Sounds made when you press a key, make an
error or receive a message
Note: When the phone is in silent mode (see page
30), you cannot change the sound settings.
Ring Tone (Menu 3.1)
This option allows you to select the required ring
melody.
You can choose between many different
melodies. Each time you select a melody, it
displays for a few seconds. If you have
downloaded any sounds from the Internet or
EasyGPRS programme or received any ring tone
messages, you can view the list in this menu.
Ring Volume (Menu 3.2)
This option allows you to adjust the ring volume
to one of five levels.
Use the and keys or the and keys
on the left side of the phone.
Call Cost*(Menu 2.6)
This network feature lets you view the cost of
calls.
The following options are available:
Last Call Cost: cost of the last call made.
Total Cost: total cost of all calls made since the
cost counter was last reset. If the total cost
exceeds the maximum cost set in the Set Max
Cost option, you can no longer make any calls
until you reset the counter.
Max Cost: maximum cost set in the Set Max
Cost option (see below).
Reset Counters: option used to reset the cost
counter; you must first enter your PIN2 (see
page 121) and then press the OK soft key.
Set Max Cost: option used to enter the
maximum cost that you authorise for your calls.
Price/Unit: option used to set the cost of one
unit; this price per unit is applied when
calculating the cost of your calls.
* Shown only if supported by your SIM card.
83
Sound Settings
82
Sound Settings
Message Tone (Menu 3.5)
This option allows you to select how the phone
informs you that a new message has been
received.
SMS Tone
This option allows you to select how the phone
informs you that a new SMS message has been
received.
The following options are available:
OFF: the phone does not use the SMS tone.
Light Only: the service light at the top of the
phone flashes.
Vibration: the phone vibrates.
Single Beep: the phone beeps once.
SMS Tone x: the phone uses an SMS tone. You
are provided with several SMS tones.
SMS CB Tone
This option allows you to select how the phone
informs you that a new cell broadcast (CB)
message has been received.
The following options are available:
OFF: the phone does not use the CB tone.
Light Only: the service light at the top of the
phone flashes.
Vibration: the phone vibrates.
Single Beep: the phone beeps once.
SMS CB Tone x: the phone uses a CB tone. You
are provided with several CB tones.
Alert Type (Menu 3.3)
This option allows you to specify how you are to
be informed of any incoming calls.
The following options are available:
Light only: only the backlight is switched on;
the phone neither rings nor vibrates.
Melody: the phone rings using the ring melody
selected in the Ring Tone menu option (Menu
3.1); see page 81.
Vibration: the phone vibrates but does not ring.
Vibra+Melody: the phone first vibrates three
times and then starts ringing.
Keypad Tone (Menu 3.4)
This option allows you to select the tone that the
keypad generates when you press a key.
You can select an option from OFF, Cool, Piano,
Tone and Beep.
To turn off the sound, select OFF.
85
Sound Settings
84
Sound Settings
The following options are available:
Error Tone: sets whether the phone informs
you that you make a mistake or not.
Minute Minder: sets whether the phone must
beep every minute during an outgoing call to
keep you informed of the length of your call.
Connect Tone: sets your phone to beep when
the person you are calling answers the phone.
Folder Tone (Menu 3.6)
This option allows you to turn on or off the
sounds that the phone generates when you open
the folder.
You can choose from Off, Future and Crystal.
To turn off the sound, select Off.
Power On/Off (Menu 3.7)
This option allows you to turn on or off the
sounds that the phone generates when it is
switched on and off.
You can choose from Off, Classical and
Cheerful. To turn off the sound, select Off.
Extra Tones (Menu 3.8)
You can customise various other tones used by
the phone.
To turn a given Press the
tone
On ON soft key.
A check mark displays in
front of the option.
Off OFF soft key.
The check mark no longer
displays.
87
Phone Settings
86
My Settings (Menu 4.2)
You can change the background image and the
colour of the components on the display
according to your preference.
Wallpaper
This option allows you to change the background
image to be displayed in idle mode.
To change the background image:
1. Scroll through the list by pressing the or
key.
You have various preset images available. You
can also select the blank background and any
images downloaded from the Internet or the
EasyGPRS programme.
2. Press the Select soft key when the required
image highlights.
The selected image displays.
3. After viewing the image, press the Select soft
key to display it on the idle screen.
Menu Style
This option allows you to select the menu display
style. You can choose between Folder Style and
Page Style.
Phone Settings
Many different features of your phone can be
customised to suit your preferences. All of these
features are accessed in the Phone Settings
menu.
Infrared Activate (Menu 4.1)
This feature allows you to send or receive
data/fax through the infrared port. To use an
infrared connection, you must:
• Configure and activate an IrDA-compliant
infrared port on your PC
• Activate the infrared feature on the phone; the
IrDA icon ( ) appears on the top line of the
display
• Align the IrDA port on the phone with the IrDA
port on your computer
15
The connection is ready for data transmission.
If there is no communication between your phone
and the IrDA-compliant device within 30 seconds
of activating the feature, it is automatically
deactivated.
Note: For the best performance, use an optional
data link cable.
IrDA port
IrDA port
89
Phone Settings
88
Phone Settings
Greeting Message (Menu 4.3)
This option allows you to set a greeting to be
displayed briefly when the phone is switched on.
The current message displays
To Press the
clear the existing Ckey and hold it down
message until the message is
cleared.
enter a new appropriate alphanumeric
message keys.
change the text right soft key labelled with
input mode the current input mode.
save the new OK soft key.
message
For further details on how to enter characters,
refer to page 44.
Own Number (Menu 4.4)
This feature allows you to:
• Assign a name to each of your own phone
numbers registered on your SIM card.
• Edit the names and numbers.
This function is a memory aid, which you can
use to check your own phone numbers if you
need to do so.
Any changes made here do not in any way affect
the actual subscriber numbers on your SIM card.
Language (Menu 4.5)
You can select a display language. English,
Chinese S (Simplified Chinese) and Chinese T
(Traditional Chinese) are available.
Security (Menu 4.6)
The Security feature enables you to restrict the
use of your phone to:
• The people of your choice
• The types of calls of your choice
Various codes and passwords are used to protect
the features of your phone. They are described
in the following sections (see also pages 119-
122).
PIN Check
When the PIN Check feature is enabled, you
must enter your PIN each time you switch the
phone on. Consequently, any person who does
not have your PIN cannot use your phone
without your approval.
Note: Before disabling the PIN Check feature, you
must enter your PIN.
To change your PIN, refer to the Change PIN
menu option (Menu 4.6.2).
The following options are available:
Disable: the phone connects directly to the
network when you switch it on.
Enable: you must enter the PIN each time the
phone is switched on.
91
Phone Settings
SIM Lock
When the SIM Lock feature is enabled, your
phone only works with the current SIM. You
must enter the SIM lock code.
Once you have entered the lock code, you are
asked to confirm it by entering it again.
To unlock the SIM, you must enter the SIM lock
code.
FDN Mode
The FDN (Fixed Dial Number) mode, if supported
by your SIM card, allows you to restrict your
outgoing calls to a limited set of phone numbers.
The following options are available:
Disable: you can call any number.
Enable: you can only call phone numbers stored
in the phonebook. You must enter your PIN2.
Note: Not all SIM cards have a PIN2. If your SIM
card does not, this menu option is not
displayed.
To change your PIN2, refer to the Change PIN2
menu option (Menu 4.6.7) below.
Change PIN2
The Change PIN2 feature allows you to change
your current PIN2 to a new one. You must enter
the current PIN2 before you can specify a new
one.
Once you have entered a new PIN2, you are
asked to confirm it by entering it again.
Note: Not all SIM cards have a PIN2. If your SIM
card does not, this menu option is not
displayed.
90
Phone Settings
Change PIN
This feature allows you to change your current
PIN to a new one, provided that the PIN Check
feature is enabled. You must enter the current
PIN before you can specify a new one.
Once you have entered a new PIN, you are
asked to confirm it by entering it again.
Phone Lock
When the Phone Lock feature is enabled, the
phone is locked and you must enter the 8-digit
phone password each time the phone is switched
on.
The password is preset to "00000000" at the
factory. To change the phone password, refer to
the Change Password menu option (Menu
4.6.4) below.
Once the correct password has been entered,
you can use the phone until you switch it off.
The following options are available:
Disable: you are not asked to enter the phone
password when you switch the phone on.
Enable: you are required to enter the phone
password when you switch the phone on.
Change Password
The Change Password feature allows you to
change your current phone password to a new
one. You must enter the current password before
you can specify a new one.
The password is preset to "00000000" at the
factory. Once you have entered a new password,
you are asked to confirm it by entering it again.
93
Phone Settings
92
Phone Settings
Auto Light
Using this feature, you can specify the time for
which the backlight is to be used. This feature
helps conserve your battery power.
The following options are available.
Disable: the backlight is used according to the
setting in the Back Light menu option (Menu
4.7.2); see page 92.
Enable: the backlight is used only during the
specified period of time. Set the required length
of time in hours and minutes, using the
appropriate number keys.
Service Light
This option allows you to select whether or not
the service light on the folder is used or in which
colour it flashes.
Select the required colour from red, green, blue,
yellow, cyan, violet and white. When the phone
is ready for use, the service light will flash in the
appropriate colour.
If you do not wish to use the service light, select
Off.
Graphic Logo
This option allows you to display your operator's
logo instead of its name.
On: the operator logo stored in your phone is
displayed in idle mode; if no logo has been
stored, the operator name is displayed.
Off: the operator name is displayed in idle
mode.
Display Settings (Menu 4.7)
Contrast
This option allows you to adjust the brightness
of the display screens to make them lighter or
darker.
To adjust the display contrast:
1. Select the LCD to be adjusted, Main LCD or
Front LCD, and press the Select soft key.
2. Adjust the contrast by using the and
keys or the and keys on the left side of
the phone.
3. When you are satisfied, press the OK soft key
to save the selection.
Back Light
This option allows you to select the length of
time for which the backlight is on. The backlight
comes on when you press a key or receive a call
or message and lights up for the specified length
of time. 15 seconds,30 seconds,1 minute,3
minutes and 10 minutes are available.
If you do not want to use the backlight, select
OFF.
95
Phone Settings
94
Phone Settings
Short Cut (Menu 4.9)
The up and down navigation keys can be used
as shortcut keys. When held down in the idle
mode, they allow you to access specific menu
options directly.
To assign a shortcut to a key:
1. Select the key to be used as a shortcut key
by pressing the or key, followed by
the Select soft key.
Key up ()
Key down ()
2. Select the menu option to be assigned to the
key by pressing the or key.
Note: To deactivate a shortcut key, select None.
3. Press the Select soft key to save the
selection.
Reset Settings (Menu 4.10)
You can easily reset your phone to its default
settings. To reset your phone:
1. Select the Reset Settings menu option.
2. Enter the 8-digit phone password and press
the OK soft key.
Note: The password is preset to "00000000". To
change this password, refer to page 90.
Extra Settings (Menu 4.8)
You can turn the automatic redialling or
answering features on or off.
To turn a Press the
feature
On ON soft key.
A check mark displays in front of
the option.
Off OFF soft key.
The check mark no longer
displays.
The following options are available:
Auto Redial: when this option is checked, the
phone makes up to ten attempts to redial a
phone number after an unsuccessful call.
Note: The interval between two call attempts
varies.
Active Folder: when this option is checked, you
can simply open the folder to answer a call.
When it is unchecked, you must open the folder
and press a key, depending on the setting of the
Anykey Answer option (see below).
Anykey Answer: when this option is checked,
you can answer an incoming call by pressing any
key, except the key and the Reject soft
key. To reject the call, press the key or
the Reject soft key.
When this option is unchecked, you can only
press the key or Accept soft key.
97
Organiser
96
Writing a Memo
To write or edit a memo on a specific date:
1. Select the required date in the calendar, using
the navigation keys.
Note: To skip to the previous or next month, press
the and keys on the left side of the
phone.
2. Press the Select soft key.
An empty memo screen displays to allow you
to enter your memo.
3. Enter your memo and then press the OK soft
key.
Note: For further details on how to enter
characters, refer to page 44.
You are asked if you wish to set an alarm.
4. If you want an alarm to ring on the chosen
day, press the Yes soft key.
Otherwise, press the No soft key.
5. If you pressed the Yes soft key, set the time
for the alarm and press the OK soft key.
The colour of the date is changed to green to
indicate that a memo exists.
Editing a Memo
If you select a day for which a memo already
exists, you can press the Edit soft key to edit
the memo displayed.
Note: For further details about how to enter
characters, refer to page 44.
Organiser
The Organiser feature enables you to:
• View the calendar and organise your schedule.
• Define a list of things to do.
• Set the current date and time.
• Set an alarm so that the phone rings at a
specific time to remind you of an appointment,
for example.
• Use the phone as a calculator for basic
mathematical equations or currency exchange
operations.
Calendar (Menu 5.1)
With the Calendar feature, you can:
• Consult the calendar
• Write memos to keep track of your schedule
and trigger an alarm if necessary
Consulting the Calendar
When you select the Calendar menu option
(Menu 5.1), the calendar displays. The following
options are available when you press the
Options soft key.
Search all: displays all of the memos,
regardless of the day and starting with the
oldest. To scroll through the memos, press the
or key.
Delete all: allows you to delete all of the
memos. You are asked to confirm your action.
Go to date: allows you to go to a specific date.
Exit: exits the Calendar feature and returns to
idle mode.
99
Organiser
98
Organiser
6. Press the OK soft key.
Editing the To Do List
If tasks are already defined in the To Do List
when you select the To Do List menu option
(Menu 5.2), the current contents are displayed
with the status mark and priority; three stars for
high, two for normal and one for low.
The following options are available:
To Then
view the details • highlight the task.
for a specific task • press the View soft key.
change the status • highlight the task.
of a specific task • press the key to mark
the task as completed as
of the current date and
time.
or
• highlight the task.
• press the Options soft key.
• select the Mark option.
• select the appropriate
status from Done and
Undo.
create a new • press the Options soft key.
task • select the New option.
• enter the text, priority and
deadline for the task.
edit an existing • highlight the task.
task • press the Options soft key.
• select the Edit option.
• change the text, priority
and deadline for the task.
Once you have finished editing the memo, press
the OK soft key. The following options are
available when you press the Options soft key.
Alarm: allows you to set an alarm to ring on the
chosen day.
Erase: allows you to delete the memo.
Copy to: allows you to copy the memo to
another date and/or time.
Move to: allows you to change the date and/or
time of the memo.
To Do List (Menu 5.2)
This feature allows you to:
• Enter a list of tasks to be done.
• Assign a priority and a deadline to each task.
• Sort the tasks by priority and status mark.
Creating the To Do List
1. Press the New soft key.
2. Enter the first task.
Note: You can enter up to 40 characters. For
further details on how to enter characters,
see page 44.
3. Press the OK soft key.
4. Select high, normal or low priority using the
or key and press the Select soft key.
5. Enter your deadline.
If you do not want to set a deadline, press
the Skip soft key.
101
Organiser
100
Organiser
Time & Date (Menu 5.3)
This option allows you to change the current
time and date displayed. You can also use this
option to find out what time it is and another
part of the world.
The following options are available:
Set Time: allows you to enter the current time.
You can choose the time format in the Time
Format menu option (Menu 5.3.4).
Note: Before setting the time, you must specify
your time zone, in the World Time menu
option (Menu 5.3.3).
Set Date: allows you to enter the day, month
and year.
World Time: allows you to find out what time it
is and another part of the world, using the and
keys.
The screen shows the:
• City name.
• Current date and time.
• Time difference between the selected city and
your city if you have set the local time (see
below for further details) or GMT (by default).
To select your time zone:
1. Select the city corresponding to your time
zone by pressing the or key one or more
times.
2. The local date and time are displayed.
3. Press the Set soft key.
Time Format: allows you to change the time
format to 24 Hours or 12 Hours.
To... Then...
sort the existing • press the Options soft key.
tasks by priority • select the Sort option.
or status • select the sort criterion
from High, Low, Done and
Undo.
copy a task • highlight the task.
• press the Options soft key.
• select the Copy option.
• change the text, priority
and deadline for the task as
required.
copy a task to • highlight the task.
the calendar • press the Options soft key.
• select the Copy to
calendar option.
• change the text and
deadline for the task and
set alarm as required.
delete a task • highlight the task.
• press the Options soft key.
• select the Delete option.
delete all tasks • press the Options soft key.
• select the Delete all
option.
• confirm the deletion by
pressing the OK soft key.
exit the To Do list • press the Options soft key.
• select the Exit option.
103
Organiser
102
Organiser
When setting or viewing an alarm, the following
options are available when you press the
Options soft key.
Remove Alarm: deactivates the current alarm.
Alarm Sound Set: allows you to select the
alarm melody.
Calculator (Menu 5.5)
With this feature, you can use the phone as a
calculator. The calculator provides the basic
arithmetic functions: addition, subtraction,
multiplication and division.
Using the Calculator
1. Enter the first number using the numeric
keys.
2. Press the right soft key until the required
arithmetic symbol appears: +(addition), -
(subtraction), x(multiplication), /(division).
3. Enter the second number.
4. Repeat Steps 1 to 3 as many times as
required.
Notes:
• To erase any mistakes and clear the display, press
the Ckey.
• To include a decimal point or a bracket, press the
left soft key until the required symbol is
displayed.
5. To calculate the result, press the key.
Alarm (Menu 5.4)
This feature allows you to:
• Set the alarm to ring at a specific time
• Set the phone to switch on automatically and
ring the alarm even if the phone is switched off
(Autopower menu option set to Enable)
The following options are available:
Once Alarm: the alarm rings only once and is
then deactivated.
Daily Alarm: the alarm rings every day at the
same time.
Morning Call: the alarm rings to wake you up in
the morning.
To set an alarm:
1. Choose the type of alarm to be set.
2. Enter the required time and day of the week,
if applicable.
3. Press the OK soft key.
4. If you select Morning Call in Step 1, select
the repeat option: Monday to Friday or
Monday to Saturday.
Remove Alarm: deactivates all alarm settings.
Autopower: if this option is set to Enable, the
alarm will ring at the specified time, even when
the phone is switched off.
If the menu option is set to Disable and the
phone is switched off at the specified time, the
alarm does not ring.
To stop the alarm when it rings, open the phone
and press the Exit soft key.
105
104
Organiser
Network Services
These menu functions are network services.
Please contact your service provider to check
their availability and subscribe to them, if you
wish.
Call Diverting (Menu 6.1)
This network service enables incoming calls to
be rerouted to the number that you specify.
Example: You may wish to divert your business
calls to a colleague while you are on
holiday.
Call diverting can be set up in the following
ways:
Divert Always: all calls are diverted.
Busy: calls are diverted if you are already on
another call.
No Reply: calls are diverted if you do not
answer the phone.
Unreachable: calls are diverted if you are not in
an area covered by your service provider.
Cancel All: all call diverting options are
cancelled.
You can specify individual diverting options for
each of the following call types:
• Voice calls only
• Data calls only
Example: You can divert voice calls to your
colleague if you are already using the
phone.
Currency Exchange (Menu 5.6)
Using this menu option, you can make currency
conversions.
1. Enter the current exchange rate of your
source currency and press the OK soft key.
You can insert a decimal point by pressing the
key.
2. Enter the amount for which you wish to
conduct the currency conversion and press
the OK soft key.
The exchange rate amount you entered and
equivalent value are displayed.
3. Press the Exit soft key to exit the currency
convertor.
107
Network Services
106
Network Services
Call Barring (Menu 6.2)
The call barring network service allows you to
restrict your calls.
Call barring can be set up in the following ways:
All Outgoing: calls cannot be made.
International: international calls cannot be
made.
International Except to Home: when abroad,
calls can be made only to numbers within the
current country and to your home country, which
is the country where your home network
provider is located.
All Incoming: calls cannot be received.
Incoming While Abroad: calls cannot be
received when you are using your phone outside
of your home service area.
Cancel All: all call barring settings are
deactivated; calls can be made and received
normally.
You can specify individual barring options for
each of the following call types.
• Voice calls only
• Data calls only
To set your call diverting options:
1. Select the type of call diverting required by
pressing the or key, and then press
the Select soft key.
2. Select the type of calls to be diverted by
pressing the or key, and then press
the Select soft key.
The current status displays. If the option has
already been set, the number to which the
calls are diverted displays.
3. To Press the
activate call Activate soft key and
diverting go to Step 4.
change the call Change soft key and
number go to Step 4.
deactivate call Remove soft key.
diverting
4. Enter the number to which the calls are to be
diverted and press OK.
To enter the international code, press the
key until the +sign displays.
The phone sends your settings to the network
and the network's acknowledgement displays.
You can deactivate all call diverting settings by
selecting the Cancel All option.
109
Network Services
108
Network Services
Change Barring Password: you can set and
change the call barring password obtained from
your service provider using this option. You must
enter the current password before you can
specify a new one.
Once you have entered a new password, you are
asked to confirm it by entering it again.
Call Waiting (Menu 6.3)
This network service enables you to be informed
when someone is trying to reach you during
another call.
You can specify individual call waiting options for
each of the following call types:
• Voice calls only
• Data calls only
To set your call waiting options:
1. Select the type of calls to which the call
waiting option is to be applied by pressing the
or key, and then press the Select soft
key.
The screen informs you whether call waiting
is activated or deactivated.
2. You can activate or deactivate the call waiting
feature as necessary by using the Activate or
Deactivate soft key respectively.
To return to the previous screen, press the
Exit soft key.
You can also deactivate all call waiting settings
by selecting the Cancel All option.
To set your call barring options:
1. Select the type of call barring required by
pressing the or key, and then press
the Select soft key.
2. Select the type of calls to be barred by
pressing the or key, and then press
the Select soft key.
3. Press the Activate soft key to confirm your
settings.
4. Enter your call barring password supplied by
your service provider.
The phone sends your settings to the network
and the network's acknowledgement displays.
To deactivate specific call barring settings:
1. Select the call barring option to be
deactivated.
2. Select the type of call to which this option
applies.
3. Press the Deactivate soft key.
4. Enter your call barring password supplied by
your service provider.
The phone sends your settings to the network
and the network's acknowledgement displays
You can also deactivate all call barring settings
by selecting the Cancel All option.
111
Network Services
110
Network Services
Caller ID (Menu 6.5)
You can prevent your phone number from being
displayed on the phone of the person being
called.
Note: Some networks do not allow the user to
change this setting.
The following options are available:
Default: the default setting provided by the
network is used.
Hide Number: your number is not displayed on
the other person's phone.
Send Number: your number is sent each time
you make a call.
Closed User Group (CUG) (Menu 6.6)
This network service allows incoming and
outgoing calls to be restricted to a selected user
group. You may be a member of up to ten user
groups. For details on how to create, activate
and use a closed user group, contact your
service provider.
Example: A company lends SIM cards to its
employees and wants to restrict
outgoing calls to members of the same
team.
Activating a Closed User Group
If you select the Closed User Group menu, you
can enter the CUG function. You can now access
the following options after pressing the Select
soft key.
Index List: lets you list, add or delete CUG
index numbers. The list of current CUG indexes
appears.
Network Selection (Menu 6.4)
The Network Selection feature enables you to
automatically or manually select the network
used when roaming outside of your home area.
Note: You can select a network other than your
home network only if it has a valid roaming
agree-ment with your home network.
To indicate automatically or manually select the
network when roaming:
1. When Network Selection displays, press the
Select soft key.
2. Press the or key until the appropriate
option highlights and then press the OK soft
key.
If you select Automatic, you are connected
to the first available network when roaming.
If you select Manual, the phone scans for the
available networks. Go to Step 3.
3. Press the or key until the preferred
network highlights and then press the OK soft
key.
You are connected to that network.
113
Network Services
112
Network Services
Band Selection (Menu 6.7)
For the phone to make and receive phone calls,
it must register with one of the available
networks. Your phone can handle any of the
following types of network:
• GSM 900
• GSM 1800
• Combined GSM 900/1800
• GSM 1900
The country where you purchased your phone
determines the default band that it uses. When
you travel abroad, you must remember to
change to an appropriate band.
1. When Band Selection displays, press the
Select soft key.
2. Press the or key until the appropriate
option (GSM 900/1800 or GSM 1900)
highlights and press the OK soft key.
When you select a new band, your phone
displays a confirmation message and then
automatically searches for all of the available
networks. Your phone registers with a preferred
network within the selected band.
Add a new CUG index as advised by your service
provider or delete a selected group.
To Press the
scroll through or key.
the existing
CUG indexes
add a new CUG Options soft key, select the
index Add option and enter the
index.
delete a CUG Options soft key and select
index the Delete option.
activate a CUG Options soft key and select
index the Activate option.
Outside Access: lets you enable or disable calls
to numbers other than those nominated for the
Closed User Group. This feature depends on the
nature of your CUG subscription. Please check
with your service provider.
Default Group: you may communicate a default
CUG to your service provider. If you have done
so, you can enable the Default Group option on
your phone. When making a call, you are given
the option of using your default CUG, instead of
selecting one from the list.
Deactivate: deactivates the CUG function. This
menu appears only when the default group is
enabled or a CUG index is selected.
115
Fun Box
114
Fun Box
The Funbox menu contains several fun options.
Games (Menu 7.1)
You can enjoy two games with your phone.
Scroll to the required game, using the and
keys and press the Select soft key. For
further details on the game, refer to the on-
screen help.
WAP Browser (Menu 7.2)
Your phone is equipped with a WAP Browser to
allow you to access and navigate the Wireless
Web.
For further details on the WAP Browser menu,
refer to the WAP Browser User's Manual supplied
with your phone.
Downloads (Menu 7.3)
Sounds
In this menu, you can view the list of sounds
downloaded from the server. You can set the
downloaded sounds as the current ring tone, but
cannot send the sounds to other phones.
When the memory is full, a warning message
displays and the phone rejects additional sounds
until you erase obsolete ones.
Pictures
In this menu, you can view the list of pictures
downloaded from the server. You can set the
downloaded pictures as the current background
image, but cannot send them to other phones.
When the memory is full, a warning message
displays and the phone rejects additional
pictures until you erase obsolete ones.
117
Solving Problems
"No service," "Network failure" or
"Not done" is displayed
• The network connection was lost. You may be
in a weak signal area (in a tunnel or
surrounded by buildings). Move and try again.
• You are trying to access an option for which
you have not taken out a subscription with
your service provider. Contact the service
provider for further details.
You have entered a number but it was
not dialled
• Have you pressed the key?
• Are you accessing the right cellular network?
• You may have set an outgoing call barring
option.
Your correspondent cannot reach you
• Is your phone switched on (the key
pressed for more than one second)?
• Are you accessing the right cellular network?
• You may have set an incoming call barring
option.
Your correspondent cannot hear you
speaking
• Have you switched off the microphone?
• Are you holding the phone close enough to
your mouth? The microphone is located at the
bottom of the phone.
Solving Problems
Before contacting the after-sales service,
perform the following simple checks. They may
save you the time and expense of an
unnecessary service call.
When you switch your phone on, the
following messages may appear
Insert SIM Card
• Check that the SIM card is correctly installed.
Phone Locked Enter Password
• The automatic locking function has been
enabled. You must enter the phone's password
before you can use the phone.
Enter PIN
• You are using your phone for the first time.
You must enter the Personal Identification
Number supplied with the SIM card.
• The PIN Check feature is enabled. Every time
the phone is switched on, the PIN has to be
entered. To disable the feature, use the PIN
Check menu option(Menu 4.6.1).
Enter PUK
• The PIN code was entered incorrectly three
times in succession and the phone is now
blocked. Enter the PUK supplied by your
network operator.
116
119
118
Solving Problems
Access Codes
There are several access codes that are used by
your phone and its SIM card. These codes help
you protect the phone against unauthorised use.
When requested for any of the codes explained
below, enter the appropriate code (displayed as
asterisks) and press the OK soft key. If you
make a mistake, press the Ckey one or more
times until the incorrect digit is cleared and then
continue entering the correct code.
The access codes, except for the PUK and PUK2
codes can be changed using Security menu
options (Menu 4.6). See page 89 for further
details.
Important! Avoid using access codes
resembling emergency numbers,
such as 112, so that you do not dial
an emergency number accidentally.
Phone Password
The Phone Lock feature uses the phone
password to protect your phone against
unauthorised use. The phone password is
supplied with the phone and is preset to
“00000000” at the factory.
To Refer to
activate/deactivate the page 90
Phone Lock feature (Menu 4.6.3).
change the phone page 90
password (Menu 4.6.4).
The phone starts beeping and
"**Warning** Low Battery" flashes on
the display
• The battery is insufficiently charged. Replace
the battery and recharge it.
The audio quality of the call is poor
• Check the signal strength indicator on the
display ( ); the number of bars indicates
the signal strength from strong ( ) to weak
().
• Try moving the phone slightly or moving closer
to a window if you are in a building.
No number is dialled when you recall a
phonebook entry
• Check that the number has been stored
correctly, by using the Phonebook Search
feature.
• Re-store the number, if necessary.
If the above guidelines do not help you to solve
the problem, take a note of:
• The model and serial numbers of your phone
• Your warranty details
• A clear description of the problem
Then contact your local dealer or Samsung
after-sales service.
121
120
Access Codes
PIN2
The PIN2 (4 to 8 digits), supplied with some SIM
cards, is required to access specific functions,
such as setting the maximum cost of a call.
These functions are available if supported by
your SIM card.
If you enter an incorrect PIN2 three times in
succession, the code is disabled and you cannot
access the functions until you re-enable it by
entering the PUK2.
To change the PIN2, refer to page 91
(Menu 4.6.7).
PUK2
The 8-digit PUK2 (PIN Unblocking Key 2),
supplied with some SIM cards, is required to
change a disabled PIN2. If you lose the code,
contact your service provider.
To re-enable your PIN2:
1. Enter the PUK2 and press the OK soft key.
2. Enter a new PIN2 of your choice and press
the OK soft key.
3. When the Confirm PIN2 message displays,
enter the same code again and press the OK
soft key.
If you enter an incorrect PUK2 ten times in
succession, you will not be able to access the
functions requiring the PIN2. Contact your
service provider for a new card.
Access Codes
PIN
The Personal Identification Number or PIN (4 to
8 digits) protects your SIM card against
unauthorised use. It is usually supplied with the
SIM card.
If you enter an incorrect PIN three times in
succession, the code is disabled and cannot be
used until you re-enable it by entering the PUK
(see below).
To Refer to
activate/deactivate the page 89
PIN Check feature (Menu 4.6.1).
change the PIN page 90
(Menu 4.6.2)
PUK
The 8-digit PUK (PIN Unblocking Key) is
required to change a disabled PIN. The PUK may
be supplied with the SIM card. If not, or you
have lost it, contact your service provider.
To re-enable your PIN:
1. Enter the PUK and press the OK soft key.
2. Enter a new PIN of your choice and press the
OK soft key.
3. When the Confirm New PIN message
displays, enter the same code again and press
the OK soft key.
If you enter an incorrect PUK ten times in
succession, the SIM card becomes invalid.
Contact your service provider for a new card.
123
122
Access Codes
Barring Password
The 4-digit barring password is required when
you use the Call Barring function. You obtain the
password from your service provider when you
subscribe to this function. See page 109 for
further details.
Health and Safety
Information
Exposure to Radio Frequency (RF)
Signals
Your wireless phone is a radio transmitter and
receiver. It is designed and manufactured not to
exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal
Communications Commission (FCC) of the U.S.
Government. These limits are part of
comprehensive guidelines and establish permitted
levels of RF energy for the general population. The
guidelines are based on the safety standards
previously set by both U.S. and international
standards bodies:
• American National Standards Institute (ANSI)
IEEE. C95.1-1992
• National Council on Radiation Protection and
Measurement (NCRP). Report 86. 1986
• International Commission on Non-Ionizing
Radiation Protection (ICNIRP) 1996
• Ministry of Health (Canada), Safety Code 6.
The standards include a substantial safety margin
designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless phones employs
a unit of measurement known as Specific
Absorption Rate (SAR). The SAR limit
recommended by the FCC is 1.6W/kg.
*
* In the U.S. and Canada, the SAR limit for mobile phones
used by the public is 1.6 watts/kg (W/kg) averaged over one
gram of tissue. The standard incorporates a substantial
margin of safety to give additional protection for the public
and to account for any variations in measurements.
Health and Safety Information
124
SAR tests are conducted using standard operating
positions specified by the FCC with the phone
transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is
determined at the highest certified power level, the
actual SAR level of the phone while operating can
be well below the maximum value. This is because
the phone is designed to operate at multiple power
levels so as to use only the power required to reach
the network. In general, the closer you are to a
wireless base station antenna, the lower the power
output of the phone.
Before a phone model is available for sale to the
public, it must be tested and certified to the FCC
that it does not exceed the limit established by the
government-adopted requirement for safe
exposure. The tests are performed in positions and
locations (e.g., at the ear and worn on the body) as
required by the FCC for each model. The highest
SAR value for this model phone when tested for use
at the ear is 0.971W/Kg and when worn on the
body, as described in this user guide, is 0.245W/Kg
(Body-worn measurements differ among phone
models, depending upon available accessories and
FCC requirements). While there may be differences
between the SAR levels of various phones and at
various positions, they all meet the government
requirement for safe exposure.
The FCC has granted an Equipment Authorization
for this model phone with all reported SAR levels
evaluated as in compliance with the FCC RF
emission guidelines. SAR information on this model
phone is on file with the FCC and can be found
under the Display Grant section of
http://www.fcc.gov/oet/fccid after searching on
FCC ID A3LSGHV205.
Health and Safety Information
125
For body worn operation, to maintain compliance
with FCC RF exposure guidelines, use only
Samsung- approved accessories. When carrying the
phone while it is on, use the specific Samsung-
supplied or approved carrying case, holster, or
other body-worn accessory.
Use of non-Samsung-approved accessories may
violate FCC RF exposure guidelines and should be
avoided.
For additional information concerning exposure to
radio frequency signals, see the following websites:
Federal Communications Commission
(FCC)
RF Safety program (select “Information on Human
Exposure to RF Fields from Cellular and PCS Radio
Transmitters”):
http://www.fcc.gov/oet/rfsafety
Cellular Telecommunications Industry
Association
(CTIA): http://www.wow-com.com
World Health Organization
(WHO)
International Commission on Non-lonizing Radiation
Protection (select Qs & As):
http://www.who.int/emf
United Kingdom, National Radiological
Protection Board:
http://www.nrpb.org.uk
U.S.Food and Drug Administration
(FDA)
Center for Devices and Radiological Health:
http://www.fda.gov/cdrh/consumer/
Health and Safety Information
126
Precautions When Using Batteries
• Never use any charger or battery that is damaged
in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network’s base
station, it uses less power; talk and standby time
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
• Battery charging time depends on the remaining
battery charge and the type of battery and
charger used. The battery can be charged and
discharged hundreds of times, but it will
gradually wear out. When the operation time
(talk time and standby time) is noticeably shorter
than normal, it is time to buy a new battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not in use,
disconnect it from the power source. Do not leave
the battery connected to a charger for more than
a week, since overcharging may shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling or
warming first.
Health and Safety Information
127
• Do not leave the battery in hot or cold places,
such as in a car in summer or winter conditions,
as you will reduce the capacity and lifetime of the
battery. Always try to keep the battery at room
temperature. A phone with a hot or cold battery
may temporarily not work, even when the battery
is fully charged. Li-ion batteries are particularly
affected by temperatures below 0 °C (32 °F).
• Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object (coin,
clip or pen) causes a direct connection between
the + and – terminals of the battery (metal strips
on the battery), for example when you carry a
spare battery in a pocket or bag. Short-circuiting
the terminals may damage the battery or the
object causing the short-circuiting.
• Dispose of used batteries in accordance with local
regulations. Always recycle. Do not dispose of
batteries in a fire.
Health and Safety Information
128
Road Safety
Your wireless phone gives you the powerful ability
to communicate by voice, almost anywhere,
anytime. But an important responsibility
accompanies the benefits of wireless phones, one
that every user must uphold.
When driving a car, driving is your first
responsibility. When using your wireless phone
behind the wheel of a car, practice good common
sense and remember the following tips:
1. Get to know your wireless phone and its
features, such as speed dial and redial. If
available, these features help you to place your
call without taking your attention off the road.
2. When available, use a hands-free device. If
possible, add an extra layer of convenience and
safety to your wireless phone with one of the
many hands-free accessories available today.
3. Position your wireless phone within easy reach.
Be able to access your wireless phone without
removing your eyes from the road. If you get an
incoming call at an inconvenient time, let your
voice mail answer it for you.
4. Let the person you are speaking with know you
are driving; if necessary, suspend the call in
heavy traffic or hazardous weather conditions.
Rain, sleet, snow, ice and even heavy traffic can
be hazardous.
5. Do not take notes or look up phone numbers
while driving. Jotting down a To Do list or
flipping through your Phonebook takes your
attention away from your primary responsibility,
driving safely.
Health and Safety Information
129
6. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan calls when your
car will be stationary. If you need to make a call
while moving, dial only a few numbers, check
the road and your mirrors, then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting. Make the
people with whom you are talking aware that
you are driving and suspend conversations that
have the potential to divert your attention from
the road.
8. Use your wireless phone to call for help. Dial the
emergency number in the case of fire, traffic
accident or medical emergencies. Remember, it
is a free call on your wireless phone!
9. Use your wireless phone to help others in
emergencies. If you see a car accident, crime in
progress or other serious emergency where
lives are in danger, call the emergency number,
as you would want others to do for you.
10. Call roadside assistance or a special non-
emergency wireless assistance number when
necessary. If you see a broken-down vehicle
posing no serious hazard, a broken traffic
signal, a minor traffic accident where no one
appears injured, or a vehicle you know to be
stolen, call roadside assistance or any other
special non-emergency wireless
number.appears injured, or a vehicle you know
to be stolen, call roadside assistance or any
other special non-emergency wireless number.
Health and Safety Information
130
Operating Environment
Remember to follow any special regulations in force
in any area and always switch off your phone
whenever it is forbidden to use it, or when it may
cause interference or danger.
When connecting the phone or any accessory to
another device, read its user’s guide for detailed
safety instructions. Do not connect incompatible
products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation
of the equipment and for the safety of personnel, it
is recommended that the equipment should only be
used in the normal operating position (held to your
ear with the antenna pointing over your shoulder).
Electronic Devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against
the RF signals from your wireless phone. Consult the
manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be
maintained between a wireless phone and a
pacemaker to avoid potential interference with the
pacemaker. These recommendations are consistent
with the independent research and
recommendations of Wireless Technology Research.
Health and Safety Information
131
Persons with pacemakers:
• Should always keep the phone more than 15 cm (6
inches) from their pacemaker when the phone is
switched on
• Should not carry the phone in a breast pocket
• Should use the ear opposite the pacemaker to
minimize potential interference
If you have any reason to suspect that interference is
taking place, switch off your phone immediately.
Hearing Aids
Some digital wireless phones may interfere with
some hearing aids. In the event of such interference,
you may wish to consult your hearing aid
manufacturer to discuss alternatives.
Other Medical Devices
If you use any other personal medical devices,
consult the manufacturer of your device to determine
if it is adequately shielded from external RF energy.
Your physician may be able to assist you in obtaining
this information. Switch off your phone in health care
facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care
facilities may be using equipment that could be
sensitive to external RF energy.
Health and Safety Information
132
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle.
You should also consult the manufacturer of any
equipment that has been added to your vehicle.
Posted Facilities
Switch off your phone in any facility where posted
notices require you to do so.
Potentially Explosive Atmospheres
Switch off your phone when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause
an explosion or fire resulting in bodily injury or even
death.
Users are advised to switch off the phone while at a
refueling point (service station). Users are
reminded of the need to observe restrictions on the
use of radio equipment in fuel depots (fuel storage
and distribution areas), chemical plants or where
blasting operations are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas
(such as propane or butane), areas where the air
contains chemicals or particles, such as grain, dust
or metal powders, and any other area where you
would normally be advised to turn off your vehicle
engine.
Health and Safety Information
133
Emergency Calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well
as user-programmed functions, which cannot
guarantee connection in all conditions. Therefore,
you should never rely solely on any wireless phone
for essential communications (medical
emergencies, for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not
be possible on all wireless phone networks or when
certain network services and/or phone features are
in use. Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location. Emergency numbers vary by location.
3. Press the key.
If certain features are in use (call barring, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult this document and your local cellular
service provider.
When making an emergency call, remember to give
all the necessary information as accurately as
possible. Remember that your phone may be the
only means of communication at the scene of an
accident; do not cut off the call until given
permission to do so.
Health and Safety Information
134
Other Important Safety Information
• Only qualified personnel should service the phone
or install the phone in a vehicle. Faulty
installation or service may be dangerous and may
invalidate any warranty applicable to the device.
• Check regularly that all wireless phone
equipment in your vehicle is mounted and
operating properly.
• Do not store or carry flammable liquids, gases or
explosive materials in the same compartment as
the phone, its parts or accessories.
• For vehicles equipped with an air bag, remember
that an air bag inflates with great force. Do not
place objects, including both installed or portable
wireless equipment in the area over the air bag or
in the air bag deployment area. If wireless
equipment is improperly installed and the air bag
inflates, serious injury could result.
• Switch off your phone before boarding an aircraft.
The use of wireless phones in aircraft may be
dangerous to the operation of the aircraft, and is
illegal.
• Failure to observe these instructions may lead to
the suspension or denial of telephone services to
the offender, or legal action, or both.
Health and Safety Information
135
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for
many years.
• Keep the phone and all its parts and accessories
out of the reach of small children’s.
• Keep the phone dry. Precipitation, humidity and
liquids contain minerals that will corrode
electronic circuits.
• Do not touch the phone with wet hands while it is
charging. Doing so may give you an electric
shock or damage the phone.
• Do not use or store the phone in dusty, dirty
areas, as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the
phone, which may damage the phone’s electronic
circuit boards.
• Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the phone. Wipe it
with a soft cloth slightly dampened in a mild
soap-and-water solution.
Health and Safety Information
136
• Do not paint the phone. Paint can clog the
device’s moving parts and prevent proper
operation.
• Do not put the phone in or on heating devices,
such as a microwave oven, a stove or a radiator.
The phone may explode when overheated.
• Use only the supplied or an approved
replacement antenna. Unauthorized antennas or
modified accessories may damage the phone and
violate regulations governing radio devices.
• If the phone, battery, charger or any accessory is
not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
IMPORTANT SAFETY
INSTRUCTIONS - SAVE THESE
INSTRUCTIONS.
DANGER- TO REDUCE THE RISK
OF FIRE OR ELECTRIC SHOCK,
CAREFULLY FOLLOW THESE
INSTRUCTIONS.
FOR CONNECTION TO A SUPPLY
NOT IN THE U.S. A., USE AN
ATTACHMENT PLUG ADAPTOR
OF THE PROPER
CONFIGURATION FOR THE
POWER OUTLET.
Health and Safety Information
137
Acknowledging Special Precautions and
the FCC and Industry Canada Notice
Cautions
Modifications not expressly approved by the party
responsible for compliance could void the user's
authority to operate the equipment.
FCC Compliance Information
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference,
and
2. This device must accept any interference
received.
Including interference that may cause undesired
operation.
Information to User
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation.
This equipment generates, uses and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications.
Health and Safety Information
138
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by one
or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/ TV
technician for help.
Health and Safety Information
139
STANDARD LIMITED WARRANTY
What is Covered and For How Long?
SAMSUNG
TELECOMMUNICATIONS AMERICA, L.P. (“SAMSUNG”) warrants
to the original purchaser (“Purchaser”) that SAMSUNG’s Phones
and accessories (“Products”) are free from defects in material
and workmanship under normal use and service for the period
commencing upon the date of purchase and continuing for the
following specified period of time after that date:
What is Not Covered?
This Limited Warranty is conditioned
upon proper use of Product by Purchaser. This Limited Warranty
does not cover: (a) defects or damage resulting from accident,
misuse, abuse, neglect, unusual physical, electrical or
electromechanical stress, or modification of any part of Product,
including antenna, or cosmetic damage; (b) equipment that has
the serial number removed or made illegible; (c) any plastic
surfaces or other externally exposed parts that are scratched or
damaged due to normal use; (d) malfunctions resulting from
the use of Product in conjunction with accessories, products, or
ancillary/peripheral equipment not furnished or approved by
SAMSUNG; (e) defects or damage from improper testing,
operation, maintenance, installation, or adjustment; (f)
installation, maintenance, and service of Product, or (g) Product
used or purchased outside the United States or Canada. This
Limited Warranty covers batteries only if battery capacity falls
below 80% of rated capacity or the battery leaks, and this
Limited Warranty does not cover any battery if (i) the battery
has been charged by a battery charger not specified or
approved by SAMSUNG for charging the battery, (ii) any of the
seals on the battery are broken or show evidence of tampering,
or (iii) the battery has been used in equipment other than the
SAMSUNG phone for which it is specified.
What are SAMSUNG’s Obligations?
During the applicable
warranty period, SAMSUNG will repair or replace, at SAMSUNG’s
sole option, without charge to Purchaser, any defective
component part of Product. To obtain service under this Limited
Warranty, Purchaser must return Product to an authorized
phone service facility in an adequate container for shipping,
accompanied by Purchaser’s sales receipt or comparable
substitute proof of sale showing the date of purchase, the serial
number of Product and the sellers’ name and address. To obtain
assistance on where to deliver the Product, call Samsung
Customer Care at 1-888-987-4357. Upon receipt, SAMSUNG
will promptly repair or replace the defective Product. SAMSUNG
may, at SAMSUNG’s sole option, use rebuilt, reconditioned, or
new parts or components when repairing any Product or replace
Phone 1 Year
Batteries 1 Year
Leather Case/ Pouch 90 Days
Holster 90 Days
Other Phone Accessories 1 Year
Health and Safety Information
140
Product with a rebuilt, reconditioned or new Product. Repaired/
replaced leather cases, pouches and holsters will be warranted
for a period of ninety (90) days. All other repaired/replaced
Product will be warranted for a period equal to the remainder of
the original Limited Warranty on the original Product or for 90
days, whichever is longer. All replaced parts, components,
boards and equipment shall become the property of SAMSUNG.
If SAMSUNG determines that any Product is not covered by this
Limited Warranty, Purchaser must pay all parts, shipping, and
labor charges for the repair or return of such Product.
What Are the Limits On SAMSUNG’s Liability?
EXCEPT
AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED
HEREIN, PURCHASER TAKES THE PRODUCT “AS IS,” AND
SAMSUNG MAKES NO WARRANTY OR REPRESENTATION AND
THERE ARE NO CONDITIONS, EXPRESS OR IMPLIED,
STATUTORY OR OTHERWISE, OF ANY KIND WHATSOEVER WITH
RESPECT TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO:
• THE MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS
FOR ANY PARTICULAR PURPOSE OR USE;
• WARRANTIES OF TITLE OR NON-INFRINGEMENT;
• DESIGN, CONDITION, QUALITY, OR PERFORMANCE OF THE
PRODUCT;
• THE WORKMANSHIP OF THE PRODUCT OR THE
COMPONENTS CONTAINED THEREIN; OR
• COMPLIANCE OF THE PRODUCT WITH THE REQUIREMENTS
OF ANY LAW, RULE, SPECIFICATION OR CONTRACT
PERTAINING THERETO.
NOTHING CONTAINED IN THE INSTRUCTION MANUAL SHALL
BE CONSTRUED TO CREATE AN EXPRESS WARRANTY OF ANY
KIND WHATSOEVER WITH RESPECT TO THE PRODUCT. ALL
IMPLIED WARRANTIES AND CONDITIONS THAT MAY ARISE BY
OPERATION OF LAW, INCLUDING IF APPLICABLE THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE HEREBY LIMITED TO THE SAME
DURATION OF TIME AS THE EXPRESS WRITTEN WARRANTY
STATED HEREIN. SOME STATES/PROVINCES DO NOT ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS,
SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU. IN
ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR ANY
DAMAGES OF ANY KIND RESULTING FROM THE PURCHASE,
USE, OR MISUSE OF, OR INABILITY TO USE THE PRODUCT OR
ARISING DIRECTLY OR INDIRECTLY FROM THE USE OR LOSS
OF USE OF THE PRODUCT OR FROM THE BREACH OF THE
EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL,
CONSEQUENTIAL OR SIMILAR DAMAGES, OR LOSS OF
ANTICIPATED PROFITS OR BENEFITS, OR FOR DAMAGES
ARISING FROM ANY TORT (INCLUDING NEGLIGENCE OR
GROSS NEGLIGENCE) OR FAULT COMMITTED BY SAMSUNG, ITS
AGENTS OR EMPLOYEES, OR FOR ANY BREACH OF CONTRACT
OR FOR ANY CLAIM BROUGHT AGAINST PURCHASER BY ANY
OTHER PARTY. SOME STATES/PROVINCES DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF INCIDENTAL OR
Health and Safety Information
141
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR
EXCLUSION MAY NOT APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND
YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY FROM
STATE TO STATE/PROVINCE TO PROVINCE. THIS LIMITED
WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE
ORIGINAL PURCHASER OF THIS PRODUCT AND STATES
PURCHASER’S EXCLUSIVE REMEDY. IF ANY PORTION OF THIS
LIMITED WARRANTY IS HELD ILLEGAL OR UNENFORCEABLE BY
REASON OF ANY LAW, SUCH PARTIAL ILLEGALITY OR
UNENFORCEABILITY SHALL NOT AFFECT THE ENFORCEABILITY
FOR THE REMAINDER OF THIS LIMITED WARRANTY WHICH
PURCHASER ACKNOWLEDGES IS AND WILL ALWAYS BE
CONSTRUED TO BE LIMITED BY ITS TERMS OR AS LIMITED AS
THE LAW PERMITS.
THE PARTIES UNDERSTAND THAT THE PURCHASER MAY USE
THIRD-PARTY SOFTWARE OR EQUIPMENT IN CONJUNCTION
WITH THE PRODUCT. SAMSUNG MAKES NO WARRANTIES OR
REPRESENTATIONS AND THERE ARE NO CONDITIONS,
EXPRESS OR IMPLIED, STATUTORY OR OTHERWISE, AS TO THE
QUALITY, CAPABILITIES, OPERATIONS, PERFORMANCE OR
SUITABILITY OF ANY THIRD-PARTY SOFTWARE OR EQUIPMENT,
WHETHER SUCH THIRD-PARTY SOFTWARE OR EQUIPMENT IS
INCLUDED WITH THE PRODUCT DISTRIBUTED BY SAMSUNG OR
OTHERWISE, INCLUDING THE ABILITY TO INTEGRATE ANY
SUCH SOFTWARE OR EQUIPMENT WITH THE PRODUCT. THE
QUALITY, CAPABILITIES, OPERATIONS, PERFORMANCE AND
SUITABILITY OF ANY SUCH THIRD-PARTY SOFTWARE OR
EQUIPMENT LIE SOLELY WITH THE PURCHASER AND THE
DIRECT VENDOR, OWNER OR SUPPLIER OF SUCH THIRD-PARTY
SOFTWARE OR EQUIPMENT, AS THE CASE MAY BE.
This Limited Warranty allocates risk of Product failure between
Purchaser and SAMSUNG, and SAMSUNG’s Product pricing
reflects this allocation of risk and the limitations of liability
contained in this Limited Warranty. The agents, employees,
distributors, and dealers of SAMSUNG are not authorized to
make modifications to this Limited Warranty, or make additional
warranties binding on SAMSUNG. Accordingly, additional
statements such as dealer advertising or presentation, whether
oral or written, do not constitute warranties by SAMSUNG and
should not be relied upon.
Samsung Telecommunications America, L.P.
1130 East Arapaho Road
Richardson, Texas 75081
Phone: 1-800-SAMSUNG
Phone: 1-888-987-HELP (4357)
©2002 Samsung Telecommunications America. All rights
reserved.
No reproduction in whole or in part allowed without prior written
approval.
Specifications and availability subject to change without notice.
[080802]
Glossary
GPRS (General Packet Radio Service)
New non-voice value-added service that allows
information to be sent and received across a
mobile telephone network. GPRS guaranties
continuous connection to the Internet for mobile
phone and computer users. It is based on the
Global System for Mobile Communication (GSM)
circuit-switched cellular phone connections and
the Short Message Service (SMS).
GSM (Global System for Mobile
Communication)
International standard for cellular
communication, guaranteeing compatibility
between the various network operators. GSM
covers most European countries and many other
parts of the world.
Line Identification Services (Caller ID)
Services allowing subscribers to view or block
the telephone numbers of callers.
Multiparty Calling
Ability to establish a conference call involving up
to five additional parties.
Phone Password
Security code used to unlock the phone when
you have selected the option to lock it
automatically each time it switches on.
Glossary
To help you understand the main technical terms
and abbreviations used in this booklet and take
full advantage of the features on your mobile
phone, here are a few definitions.
Active Folder
Ability to answer a call simply by opening the
phone.
Call Barring
Ability to restrict outgoing and incoming calls.
Call Diverting
Ability to reroute calls to another number.
Call Holding
Ability to put one call on standby while
answering or making another call; you can then
switch between the two calls, as required.
Call Waiting
Ability to inform users that they have an
incoming call when engaged on another call.
143
142
Glossary Glossary
SMS (Short Message Service)
Network service sending and receiving messages
to and from another subscriber without having to
speak to the correspondent. The message
created or received can be displayed, received,
edited or sent.
Soft Keys
Two keys marked and on the phone, the
purpose of which:
• Varies according to the function that you are
currently using
• Is indicated on the bottom line of the display
just above the corresponding key
Tri Band
Ability to handle any of the following types of
network: GSM 900, GSM 1800, combined GSM
900/ 1800 and GSM 1900 MHz bands, for
greater call success and wider roaming.
Your phone automatically searches for the last
network used. If, for any reason, this network is
unavailable, your phone will attempt to register
with a different network.
Voice Mail
Computerised answering service that
automatically answers your calls when you are
not available, plays a greeting (optionally in your
own voice) and records a message.
PIN (Personal Identification Number)
Security code that protects the phone against
unauthorised use. The PIN is supplied by the
service provider with the SIM card. It may be a
four to eight-digit number and can be changed,
as required.
PUK (PIN Unblocking Key)
Security code used to unlock the phone when an
incorrect PIN has been entered three times in
succession. The eight-digit number is supplied by
the service provider with the SIM card.
Roaming
Use of your phone when you are outside your
home area (when travelling for example).
SDN (Service Dialling Numbers)
Telephone numbers supplied by your network
provider and giving access to special services,
such as voice mail, directory inquiries, customer
support and emergency services.
SIM (Subscriber Identification Module)
Card containing a chip with all the information
required to operate the phone (network and
memory information, as well as the subscriber’s
personal data). The SIM card fits into a small
slot on the back of the phone and is protected
by the battery.
145
144
SGH-S308 GSM Telephone
Quick Reference Card
Switch On/Off Press and hold the
key.
Makes a Call ➀Enter the number.
➁Press the key.
End a Call Briefly press the
key.
View Missed ➀Open the folder and
Calls Immediately press the View soft
After Missing key.
Them ➁Scroll with the
and keys
through the missed
calls.
➂To return the call,
press the key.
Access the ➀ Press the Menu soft
Menu key in the idle mode.
Function ➁Scroll with the and
keys through the
list of the menus until
you reach the required
menu.
➂Press the Select soft
key.
➃Scroll with he and
keys through the
list of the options until
the required one is
selected.
➄Press the Select soft
key.
• Each of the two soft keys ( and )
perform the function indicated by the
text above it (on the bottom line of the
display.)
147
146
Store ➅Press the OKsoft key.
Numbers ➆Press the OK soft key.
in the ➇If necessary, change the
Phonebook location.
(continued...) ➈Press the OK soft key.
➉ Press the key to
return to the idle mode.
Search for a ➀Press the Name soft key.
Number ➁Select the Search option.
in the ➂Enter the name.
Phonebook ➃To scroll through the
names, press the or
key.
➄Press the View soft key.
➅To scroll through the
numbers, press the or
key.
➆Press the key to dial.
Answer a Open the phone
Call or
press the key.
Adjust the Press the or key
Volume on the left side of the
phone.
Choose ➀Select the Alert Type
the Alert menu option (3.3)
Type ➁Select an option:
Light Only,Melody,
Vibration or
Vibra+Melody.
➂Press the OK soft key.
Store a ➀Enter the number.
Number ➁Press the Save soft
in the key.
Phonebook ➂Select an icon for a
category.
➃Press the Select soft key.
➄Enter a name.
148
