Samsung Electronics Co SGHX105 Single-Band PCS GSM Phone User Manual
Samsung Electronics Co Ltd Single-Band PCS GSM Phone Users Manual
Users Manual
TRI BAND
GPRS TELEPHONE
SGH-X105
* Some of the contents in this manual may differ from your phone,
depending on the software installed or your service provider.
Printed in Korea
Code No.: GH68-xxxxxA
English. 04/2003. Rev. 1.0
World Wide Web
http://www.samsungmobile.com
Draft Version
(2003. 04. 09)
2
Contents
3
Contents
Important Safety Precautions .......................... 7
Unpacking ........................................................ 9
Your Phone..................................................... 10
Phone Layout .................................................... 10
Display............................................................. 13
Service Light..................................................... 15
Getting Started............................................... 16
Installing the SIM Card....................................... 16
Charging the Battery.......................................... 18
Switching the Phone On or Off............................. 20
Locking or Unlocking the keypad.......................... 21
Call Functions................................................. 22
Making a Call .................................................... 22
Adjusting the Volume ......................................... 24
Answering a Call................................................ 24
Viewing Missed Calls .......................................... 25
Quickly Switching to the Silent Mode .................... 27
Selecting Functions and Options..................... 28
Phonebook ..................................................... 30
Storing a Number with a Name............................ 30
Using Phonebook Entry Options ........................... 33
Searching for a Number in Phonebook .................. 34
Editing a Caller Group ........................................ 36
Speed-dialing.................................................... 37
Deleting All of the Phonebook Entries ................... 39
Checking the Memory Status............................... 40
Entering Text.................................................. 41
Changing the Text Input Mode ............................ 42
Using the T9 Mode ............................................. 43
Using the Alphabet Mode .................................... 44
Using the Symbol Mode ...................................... 46
Using the Number Mode ..................................... 46
Contents
4
Options During a Call...................................... 47
Putting a Call on Hold......................................... 47
Switching the Microphone Off (Mute).................... 48
Muting/Sending Key Tones.................................. 49
Searching for a Number in Phonebook .................. 49
Using the Message Service.................................. 50
Answering a Second Call..................................... 50
Making a Multi-party Call .................................... 51
Using the Menus............................................. 53
Accessing a Menu Function by Scrolling ................ 53
Accessing a Menu Function by Using its Shortcut ... 54
List of Menu Functions........................................ 54
Text Message ................................................. 60
Inbox
(Menu 1.1)....................................................... 60
Outbox
(Menu 1.2) .................................................... 62
Write New
(Menu 1.3) ............................................... 63
Templates
(Menu 1.4) ............................................... 66
Settings
(Menu 1.5)................................................... 66
My Objects
(Menu 1.6) .............................................. 68
Memory Status
(Menu 1.7) ........................................ 69
Voice Mail
(Menu 1.8) ................................................ 70
Broadcast
(Menu 1.9) ................................................ 71
Location Service
(Menu 1.10) .................................... 72
Picture Message ............................................. 75
Inbox
(Menu 2.1)....................................................... 75
Outbox
(Menu 2.2) .................................................... 78
Draft
(Menu 2.3)........................................................ 79
Write New
(Menu 2.4) ............................................... 79
Template
(Menu 2.5) ................................................. 83
Delete All
(Menu 2.6)................................................. 83
Setup
(Menu 2.7) ...................................................... 84
Call Records ................................................... 85
Missed Calls
(Menu 3.1)............................................. 85
Incoming Calls
(Menu 3.2)......................................... 85
Outgoing Calls
(Menu 3.3) ......................................... 86
Delete All
(Menu 3.4)................................................. 86
Call Time
(Menu 3.5) ................................................. 87
Call Cost
(Menu 3.6).................................................. 87
Contents
5
Sound Settings ............................................... 89
Ring Tone
(Menu 4.1) ................................................ 89
Ring Volume
(Menu 4.2) ............................................ 89
Alert Type
(Menu 4.3)................................................ 90
Keypad Tone
(Menu 4.4) ........................................... 90
Message Tone
(Menu 4.5) ......................................... 91
Power On/Off
(Menu 4.6)........................................... 92
Extra Tones
(Menu 4.7) ............................................. 92
Phone Settings ............................................... 93
My Settings
(Menu 5.1) ............................................. 93
Greeting Message
(Menu 5.2).................................... 94
Own Number
(Menu 5.3) ........................................... 95
Language
(Menu 5.4) ................................................ 95
Security
(Menu 5.5)................................................... 95
Display Settings
(Menu 5.6)...................................... 99
Extra Settings
(Menu 5.7) ....................................... 101
Short Cut
(Menu 5.8)............................................... 102
Reset Settings
(Menu 5.9) ....................................... 102
Organizer ..................................................... 103
Calendar
(Menu 6.1)................................................ 103
To Do List
(Menu 6.2) .............................................. 106
Time & Date
(Menu 6.3) .......................................... 109
Alarm
(Menu 6.4) .................................................... 110
Calculator
(Menu 6.5) .............................................. 111
Currency Exchange
(Menu 6.6) ............................... 112
Network Services ......................................... 113
Call Forwarding
(Menu 7.1) ..................................... 113
Call Waiting
(Menu 7.2) ........................................... 115
Network Selection
(Menu 7.3) ................................. 115
Caller ID
(Menu 7.4) ................................................ 116
Band Selection
(Menu 7.5) ...................................... 117
Funbox ......................................................... 118
T-Zones
(Menu 8.1)................................................. 118
Downloads
(Menu 8.2)............................................. 123
Solving Problems.......................................... 126
Contents
6
Access Codes................................................ 129
Phone Password ............................................... 129
PIN................................................................. 130
PUK ................................................................ 130
PIN2 ............................................................... 131
PUK2 .............................................................. 131
Health and Safety Information ..................... 132
Exposure to Radio Frequency (RF) Signals ........... 132
For Body Operation........................................... 134
Precautions When Using Batteries ....................... 135
Road Safety ..................................................... 136
Operating Environment ..................................... 138
Electronic Devices............................................. 139
Potentially Explosive Atmospheres ...................... 141
Emergency Calls............................................... 142
Other Important Safety Information .................... 143
Care and Maintenance ....................................... 144
Acknowledging Special Precautions and
the FCC and Industry Canada Notice ................... 145
Appendix A: CERTIFICATION INFORMATION
(SAR) ........................................................... 147
Appendix B: Guide to Safe and
Responsible Wireless Phone Use .................. 149
Appendix C: Consumer Update on
Wireless Phones ........................................... 153
Glossary ....................................................... 163
Index ........................................................... 168
Quick Reference Card ................................... 173
7
Important Safety
Precautions
Read these guidelines before using your wireless
phone. Failure to comply with them may be
dangerous or illegal.
Road Safety at All Times
Do not use a hand-held phone while driving; park
the vehicle first.
Switching Off When Refueling
Do not use the phone at a refueling point (service
station) or near fuels or chemicals.
Switching Off in Aircraft
Wireless phones can cause interference. Using them
in aircraft is both illegal and dangerous.
Switching Off in Hospitals
Switch off your phone near medical equipment.
Follow any regulations or rules in force.
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Special Regulations
Meet any special regulations in force in any area
and always switch off your phone whenever it is
forbidden to use it, or when it may cause
interference or danger (in a hospital for example).
Important Safety Precautions
8
Sensible Use
Use only in the normal position (held to the ear).
Avoid unnecessary contact with the antenna when
the phone is switched on.
Emergency Call
Ensure the phone is switched on and in service. Key
in the emergency number for your present location,
then press the key. If certain features are in
use, deactivate those features before you can make
an emergency call. Give all the necessary
information as accurately as possible. Do not cut off
the call until given permission to do so.
Water Resistance
Your phone is not water-resistance. Keep it dry.
Accessories and Batteries
Use only Samsung-approved accessories and
batteries.
Qualified Service
Only qualified service personnel may install or
repair your phone.
For more detailed safety information, see “Health
and Safety Information” on page 132.
9
Unpacking
Your package contains the following items:
In addition, you can obtain the following
accessories for your phone from your local
Samsung dealer:
• Ear-microphone
•Travel adapter
• Battery charger
• Standard/slim batteries
• Simple hands-free kit
• Cigarette lighter adapter
• Car holder
• Data kit
Handset Travel Adapter
Battery User’s Manual
10
Your Phone
Phone Layout
The following illustrations show the main elements
of your phone:
Earpiece
Display
Soft key (right)
Power on/off /
menu exit key
Alphanumeric
keys
Special
function keys
Volume/menu
browse keys
Dial/menu
confirmation key
Soft key (left)
Navigation
(Left/Right/Up/
Down) keys
Microphone
Cancel/
WAP Browser
key
Service light
Ear-microphone
jack
Your Phone
11
Key
Description
In Menu Mode, scroll through the menu
options and the Phonebook memory.
In Idle Mode, allow you to access your
favorite menu options directly. For
further details about shortcuts, see
page 102.
In Menu Mode, returns to the previous
menu level and selects the current
menu respectively.
When entering text, move the cursor to
the left and right respectively.
In Idle Mode, allow you to access your
favorite menu options directly. For
further details about shortcuts, see
page 102.
(soft keys)
Perform the functions indicated by the
text above them, on the bottom line of
the display.
In Idle Mode, launches the WAP
(Wireless Application Protocol) browser
directly.
When entering number or text deletes
characters from the display and returns
to the previous menu level.
Your Phone
12
Makes or answers a call.
In Idle Mode, recalls the last number
dialed or received when held down.
In Menu Mode, selects a menu function
or stores information that you have
entered, such as a name in the phone
or SIM memory.
Ends a call. Also switches the phone on
and off when held down.
In Menu Mode, cancels your input and
returns to Idle Mode.
In Idle Mode, quickly accesses your
voice mail when held down.
Enter numbers, letters and some
special characters.
Enter special characters.
Perform various functions.
(on the left side of the phone)
During a call, adjust the earpiece
volume.
In Idle Mode, adjust the keypad tone
volume.
In Menu Mode, scroll through the menu
options and the Phonebook memory.
Key Description
(continued)
Your Phone
13
Display
Display Layout
The display has three areas:
Area Description
First line Displays various icons. See
page 14.
Middle lines Display messages, instructions
and any information that you
enter, such as number to be
dialed.
Last line Shows the functions currently
assigned to the two soft keys.
Icons
Text and
graphic area
Soft key
indications
Menu Ph.Book
Your Phone
14
Icons
Icon Description
Shows the received signal strength. The
greater the number of bars, the stronger
the signal.
Appears when a call is in progress.
Appears when you are connected to the
GPRS network.
Appears when you are out of your home
area and have logged on a different
network; for example, when traveling in
other countries.
Appears when a new text message has
been received.
Appears when a new voice mail message
has been received.
Appears when you set an alarm to ring at a
specified time.
Appears when the silent mode is active or
when you set the Alert Type menu option
(Menu 4.3) so that the phone vibrates
when you receive a call. For further details,
see page 27 and page 90 respectively.
Appears when the mute mode is active.
Shows the level of your battery. The more
bars you see, the more power you have
left.
Your Phone
15
Backlight
A backlight illuminates the display and the keypad.
When you press any key, the backlight turns on and
remains for a given period of time, depending on
the Back Light menu option. The display turns off
after one minute to conserve your battery power.
To specify the length of time the backlight is active,
set the Back Light menu option (Menu 5.6.2).
See page 99 for further details.
You can also set the phone to use the backlight only
during a specified period of time, in the Auto Light
menu option (Menu 5.6.3). See page 99 for further
details.
Service Light
The service light on the top left-hand corner of the
phone. It flashes when services are available on the
phone.
To activate or deactivate the use of the service
light, set the Service Light menu option (Menu
5.6.4). See page 100 for further details.
Service light
16
Getting Started
Installing the SIM Card
When you subscribe to a cellular network, you are
provided with a plug-in SIM card loaded with your
subscription details, such as your PIN, any optional
services available and so on.
Important! The plug-in SIM card and its contacts
can be easily damaged by scratches
or bending, so be careful when
handling, inserting or removing the
card.
Keep all SIM cards out of the reach of
small children.
1. If necessary, switch off the phone by holding
down the key until the power-off image
displays.
2. Remove the battery. To do so:
➀ Press down the catch above the battery and
hold it in this position.
➁ Slide the battery and lift it away, as shown.
➁
➀
Getting Started
17
3. Slide the SIM card into the SIM card socket so
that it locks the card into position.
Make sure that the notched corner is top left and
the gold contacts of the card face into the
phone.
Note
: When you need to remove the SIM card,
slide it, as shown, and take it out of the
socket.
4. Place the battery back, taking care to match the
tabs on the battery with the grooves on the
phone.
Getting Started
18
5. Slide the battery towards the top of the phone
until it clicks into place. Make sure that the
battery is properly installed before switching on
the power.
Charging the Battery
Your phone is powered by a rechargeable Li-ion
battery. A travel adapter comes with your phone for
charging the battery. Use only approved batteries
and chargers. Ask your local Samsung dealer for
further details.
The travel adapter allows you to use the phone
while the battery is charging, but this causes the
phone to charge more slowly.
Note
: You must fully charge the battery before using
your phone for the first time. A discharged
battery is fully recharged in approximately
200 minutes.
1. With the battery in position on the phone, plug
the connector of the travel adapter into the jack
at bottom of the phone.
Getting Started
19
2. Plug the adapter into a standard AC wall outlet.
3. When charging is finished, unplug the adapter
from the power outlet and from the phone by
pressing the gray tabs on both sides of the
connector and pulling the connector out.
Note
: You must unplug the adapter before removing
the battery from the phone during charging;
otherwise, the phone could be damaged.
Low Battery Indicator
When the battery is weak and only a few minutes of
talk time remain, you hear a warning tone and a
message repeats at regular intervals on the display.
When the battery level gets too low, the phone
automatically turns off.
Getting Started
20
Switching the Phone On or Off
1. Hold down the key until the phone switches
on.
2. If the phone asks you to enter the phone
password, enter the password and press the OK
soft key. The phone password is preset to
“00000000” at the factory. For further details,
see page 129.
3. If the phone asks for a PIN, enter the PIN and
press the OK soft key. For further details, see
page 130.
The phone searches for your network and, after
finding it, the idle screen, illustrated below,
appears on the display. Now, you can make or
receive a call.
Note
: The display language is preset to English at
the factory. To change the language, use
the
Language
menu option (
Menu 5.5
).
For further details, see page 95.
4. When you wish to switch the phone off, hold
down the key until the power-off image
displays.
If you lock the keypad, before switching the
phone off, you should unlock the keypad by
pressing the
UnLock
soft key and the key.
Service Provider
07:30AM
Wed Mar 06
Menu Ph.Book
Getting Started
21
Locking or Unlocking the keypad
You can lock the keypad to avoid pressing keys by
mistake.
In Idle Mode, press and hold the key until the
icon and “Keypad Locked” appear on the display.
You can answer incoming calls using any keys, even
if you lock the keypad. When you receive a call in
the key lock mode, the keypad is automatically
unlocked. After the call, the key lock mode is
canceled.
You can dial emergency calls even if you lock the
keypad. Press an emergency number. When the
confirming message appears, select Yes by
pressing the left soft key or the key. When you
end the call, your phone returns to the key lock
mode after the period of time specified in the Auto
Key Lock menu option.
To exit the key lock mode, press the UnLock soft
key and then press the key again. “Keypad
Unlocked” appears and the icon no longer
displays.
You can also set the phone to automatically lock the
keypad in the Auto Key Lock menu option (Menu
4.2.3). For further details, see page 94.
22
Call Functions
Making a Call
When the idle screen displays, enter the area code
and phone number, and press the key.
Note
: If you checked the
Auto Redial
option in the
Extra Settings
menu (
Menu 5.7
), the
phone automatically redials up to ten times
when the person does not answer the call or is
already on the phone. See page 101 for further
details.
Making an International Call
1. Press and hold the 0 key.
The + character appears.
2. Enter the country code, area code and phone
number and press the key.
Correcting the Number
To clear Press the
the last digit
displayed
key.
any other digit
in the number
Left or Right key until the cursor
is immediately to the right of
the digit to be cleared. Press the
key. You can also insert a
missing digit simply by pressing
the appropriate key.
the whole
display
key and hold it for more
than one second.
Call Functions
23
Ending a Call
When you want to finish your call, briefly press the
key.
Redialing the Last Number
The phone stores the numbers you dialed, received
or missed if the caller is identified. See “Call
Records” on page 85 for further details.
To recall any of these numbers:
1. If you have typed characters on the display,
press the key to return to Idle Mode.
2. Press the key to display a list of the last
numbers in the order in which the calls were
made.
3. Use the Up and Down keys to scroll through the
numbers until the number you want highlights.
4. T
o Press the
dial the number key.
delete the number Options soft key and
select Delete.
edit the number Options soft key and
select Edit Number.
Change the number as
required, referring to
“Correcting the Number”
on page 22 for further
details.
delete all of the
numbers on the
Redial list
Options soft key and
select Delete All. For
details, see page 86.
Call Functions
24
Making a Call from Phonebook
You can store the phone numbers that you use
regularly in the SIM card or the phone’s memory,
which are collectively called Phonebook. Simply
select a name to recall the associated number. For
further details about the Phonebook features, see
page 30.
Adjusting the Volume
During a call, if you want to adjust the earpiece
volume, use the and keys on the left side of the
phone.
Press the key to increase the volume level and
the key to decrease the level.
In Idle Mode, you can also adjust the keypad tone
volume using the these keys.
Answering a Call
When somebody calls you, the phone rings and
shows the incoming call animation.
When the caller can be identified, the caller’s phone
number, or name if stored in your Phonebook,
displays.
1. Press the key or the Accept soft key to
answer the incoming call.
If the Anykey Answer option in the Extra
Settings menu (Menu 5.7) is checked, you can
press any key to answer a call except for
the key and the Reject soft key. See
page 101.
Call Functions
25
2. End the call by pressing the key.
Notes
:
•You can answer a call while using Phonebook or menu
features.
•You can answer a call in the key lock mode. After the
call, the mode is canceled.
Viewing Missed Calls
When you are unable to answer a call for any
reason, you can find out who is calling you, if this
service is available, so that you can call the person
back.
The number of missed calls displays on the idle
screen immediately after a call is missed.
To view the missed call immediately:
1. Press the View soft key.
The number corresponding to the most recent
missed call displays, if available.
2. To Press the
scroll through the
missed calls
Up or Down key.
call the number
displayed
key.
edit or delete a missed
call number
Select soft key. See
below.
Call Functions
26
Editing a Missed Call Number
Note
: When the number corresponding to the missed
call is not available, the
Edit Number
option
does not display.
1. Press the Options soft key.
2. Press the Up or Down key to highlight the Edit
Number option.
3. Press the Select soft key.
4. Change the number, as required.
Deleting a Missed Call
1. Press the Options soft key.
2. If necessary, press the Up or Down key to
highlight the Delete option.
3. Press the Select soft key.
You can press the key at any time to exit the
Missed Call feature.
Note
: You can access the Missed Call feature at any
time by selecting the
Missed Calls
menu
option (
Menu 3.1
). For further details, see
page 85.
5. To Press the
call the number key.
store the
number
Save soft key and enter
the name and location
required. For further
details, see page 30.
Call Functions
27
Quickly Switching to the Silent Mode
Silent Mode is convenient when discretion is
required and you wish to stop the phone from
making noise, in a theater for example.
In Idle Mode, press and hold the key until the
“Silent Mode” message and the Vibration icon ( )
display.
In the silent mode, your phone changes the sound
settings as follows:
To exit and reactivate the previous sound settings,
press and hold the key again until “Exit Silent
Mode” appears. The Vibration icon ( ) no longer
displays.
Option New Setting
Alert Type (Menu 4.3) Vibration
Keypad Tone (Menu 4.4) Off
Message Tone (Menu 4.5) Light Only
Power On/Off Tone
(Menu 4.6)
Off
Error Tone (Menu 4.7.1) Off
28
Selecting Functions
and Options
Your phone offers a set of functions that allow you
to customize it. These functions are arranged in
menus and sub-menus, accessed via the two soft
keys marked and . Each menu and sub-menu
allows you to view and alter the settings of a
particular function.
The roles of the soft keys vary according to the
current context; the label on the bottom line of the
display just above each key indicates its current
role.
Example:
Menu Ph.Book
Service Provider
07:30AM
Wed Mar 06
Press the left soft
key to access Menu
Mode.
Press the right soft
key to access the
Phonebook feature.
Selecting Functions and Options
29
To view various functions/options available and
select the one required:
1. Press the appropriate soft key.
In some functions, you may be asked for a
password or PIN. Enter the required code and press
the OK soft key.
2. To Press the
select the:
• function displayed
• option highlighted
Select soft key or
the Right key.
view the next function
or highlight the next
option on a list
Down key or key on
the left side of the
phone.
move back to the
previous function or
option on a list
Up key or key on
the left side of the
phone.
move back up one
level in the structure
Left key, soft key
or key.
exit the structure
without changing the
settings
key.
30
Phonebook
You can store phone numbers and their
corresponding names in the memory of your SIM
card. In addition, you can store up to 500 numbers
in the phone’s memory. The SIM card and phone
memories, although physically separate, are used
as a single entity, called Phonebook.
Storing a Number with a Name
There are two ways to store a number:
• Using the Save soft key in Idle Mode
• Using the New Entry option in the Phonebook
menu
Storing a Number in Idle Mode
As soon as you start to enter a number, Save
appears above the left soft key to allow you to store
the number in Phonebook.
1. Enter the number you want to store.
Note
: If you make a mistake while entering a
number, correct it using the
key. For
further details, see page 22.
2. When you are sure that it is correct, press the
Save
soft key.
3. Select an icon to identify the category of the
number to be stored. Three categories are
available:
• : Mobile phone number
• : Office number
• : Home number
To select the category, press the Left or Right
key and press the Select soft key.
Phonebook
31
4. Select a memory location, either SIM or Phone,
by pressing the Up or Down key and press the
Select soft key.
Note
: If you change phones, any numbers stored
in your SIM card memory will automatically
be available with the new phone, whereas
any numbers stored in the phone’s memory
must be reentered.
5. Enter a name and press the OK soft key.
The maximum length of a name depends on
your SIM card. For further details about how to
enter characters, see page 41.
6. If you do not want to save the number and
name in the suggested location, press the
key to clear the location number and enter your
preferred location by pressing the number keys.
7. Press the OK soft key to store the name and
number.
After storing, the phone displays the Phonebook
entry or name just created.
8. To Press the
use the entry options Options soft key. For
further details, see
page 33.
return to the idle
screen
key.
Phonebook
32
Storing a Number Using the Phonebook
Menu
1. When the idle screen displays, press the
Ph.Book soft key.
2. Scroll to New Entry by pressing the Up or Down
key and press the Select soft key.
3. Select an icon to identify the category of the
number to be stored by pressing the Left or
Right key, and press the Select soft key.
Note
: The E-mail icon ( ) is available in this
step. It allows you to save an E-mail
address instead of a phone number.
4. Select a memory location, either SIM or Phone,
by pressing the Up or Down key and press the
Select soft key
5. Enter a name and press the
OK
soft key.
The maximum length of a name depends on
your SIM card. For further details about how to
enter characters, see page 41.
6. Enter the number you want to store and press
the Save soft key.
7. Continue the procedure from Step 6 on page 31
to store the number.
Phonebook
33
Using Phonebook Entry Options
While accessing any Phonebook entry, press the
Options soft key to access the options for the
entry.
The following options are available:
Paste: allows you to paste the number into the
normal dialing mode. Use this option to dial a
number similar to one in Phonebook, such as a
different extension in the same office.
Use the key to change the number as
required; see page 22 for further details. When you
are ready to dial, press the key.
Edit:
allows you to edit the name and number.
Delete: allows you to delete the name and number
from Phonebook. You are asked to confirm that you
wish to delete the name and number by pressing
the Yes soft key.
Copy: allows you to copy the number to another
location. Use this option to store a number similar
to one already in the memory; once copied, edit the
number and store it in Phonebook.
To Press the
select the
highlighted option
Select soft key or the Right
key.
highlight a
different option
Up or Down key until the
option you want highlights.
Phonebook
34
Caller Group: allows you to organize your
Phonebook entries in up to 10 caller groups so that
the phone alerts you in a specific way when a
person from one of your groups calls you. Select
one of the ten groups available.
To remove an entry from a group, select the No
Group option.
For further details about how to change caller group
properties, see page 36.
Add Entry: allows you to add a new number to the
selected name.
Searching for a Number in
Phonebook
After storing numbers in Phonebook, you can
search for them in two ways; by name and by caller
group.
Searching for a Number by Name
1. When the idle screen displays, press the
Ph.Book soft key.
2. Press the Select soft key when Search
highlights. You are asked to enter a name.
3. Enter the first few letters of the name that you
want to find.
The Phonebook entries are listed, starting with
the first entry matching your input.
Phonebook
35
5. Once you have found the entry, press the
key to dial the number, or press the Options
soft key to access the Phonebook entry options;
for further details, see page 33.
Searching for a Number by Caller Group
1. When the idle screen displays, press the
Ph.Book soft key.
2. Scroll to Group Search by pressing the Up or
Down key and press the Select soft key. You are
asked to enter a group name.
3. Enter the first few letters of the group name that
you want to find.
The caller groups are listed, starting with the
first group matching your input.
4. If necessary, scroll to a group by pressing the Up
or Down key and press the View soft key.
The Phonebook entries in the caller group are
listed.
4. To Press the
view the highlighted
entry
View soft key.
select a different
entry
Up or Down key until
the entry highlights.
look for a name
starting with a
different letter
key labeled with the
letter you want to
enter.
Phonebook
36
6. Once you have found the entry, press the
key to dial the number, or press the Options
soft key to access the Phonebook entry options;
for further details, see page 33.
Editing a Caller Group
1. When the idle screen displays, press the Name
soft key.
2. Scroll to Group Edit by pressing the Up or
Down key and press the Select soft key.
3. Scroll through the group list by pressing the Up
or Down key.
4. When the group you want highlights, press the
Options soft key.
5. Select each option and change the settings, as
required. The following options are available:
• Call Ring Tone: allows you to set a ring tone
to be used when you receive a voice call from
a person in the group.
• SMS Tone: allows you to set a ring tone to be
used when you receive a text message from a
person in the group.
5. To Press the
view the highlighted
entry
View soft key.
select a different
entry
Up or Down key until
the entry you want
highlights.
Phonebook
37
• Graphic: allows you to set a graphic icon to
be displayed when you receive a voice call
from a person in the group.
• Group Name: allows you to assign a name to
the group. For further details about how to
enter characters, see page 41.
6. When you finish changing the settings, press the
or key.
Speed-dialing
Once you have stored phone numbers in the SIM
card, you can set up to eight speed-dial entries and
then dial them easily whenever you want, simply by
pressing the associated number key.
Setting Up Speed-dial Entries
1. When the idle screen displays, press the
Ph.Book soft key.
2. Scroll to Speed Dial by pressing the Up or
Down key and press the Select soft key.
3. Select the key to which you wish to assign the
speed-dialing number, from 2 to 9 keys, and
press the OK soft key.
Note
: If you have already assigned a number to
the key, the
Options
soft key replaces the
OK
soft key. Go to Step 6.
4. Select a Phonebook entry from the list and press
the View soft key.
Phonebook
38
5. Select a number, if the entry has more than one
number by pressing the Up or Down key and
press the Select soft key.
6. Once you have assigned a number to the key,
you can use the following options by pressing
the Options soft key:
• Change: allows you to assign a different
number to the key.
• Delete: allows you to clear the setting so that
no number is assigned to the key.
• Delete All: allows you to clear the settings for
all keys so that no numbers are assigned to
any of the keys.
• Number: allows you to view the number
assigned to the key.
7. When you finish setting the options, press the
or key.
Speed-dialing from Phonebook
To speed-dial the numbers assigned to keys, 2 to 9,
press and hold the appropriate key.
Note
: Memory location 1 is reserved for your Voice
Mail server number.
Phonebook
39
Deleting All of the Phonebook Entries
You can delete all of entries in the selected memory
or both memories.
1. When the idle screen displays, press the
Ph.Book soft key.
2. Scroll to Delete All by pressing the Up or Down
key and press the Select soft key.
3. To place a check mark on the memory you want
to empty, All, SIM or Phone, press the Mark
soft key.
You can remove the check mark by pressing the
Unmark soft key.
4. When you are finished marking, press the
Delete soft key to delete the entries in the
selected memory.
5. Enter the phone password and press the OK soft
key.
Note
: The password is preset to “00000000” at
the factory. To change it, see page 97.
6. When the confirming message appears, press
the Yes soft key.
7. When you finish deleting, press the or
key.
Phonebook
40
Checking the Memory Status
You can check how many names and numbers are
stored in Phonebook; SIM card and phone
memories. You can also see the capacity of both
memories.
1. When the idle screen displays, press the
Ph.Book soft key.
2. Select the Memory Status option by pressing
the Up or Down key and press the Select soft
key.
3. Press the Up or Down key to view the number of
existing and remaining entries in the card and
phone memories.
4. When you finish checking, press the or
key.
41
Entering Text
When using your phone, you will often need to
enter text, such as when storing a name in
Phonebook, creating your personal greeting or
scheduling events on your calendar. You can enter
alphanumeric characters by using your phone’s
keypad.
Your phone has the following text input modes:
• T9 mode
This mode allows you to enter words with only
one keystroke per letter. Each key on the keypad
has more than one letter – when you press the 5
key once, J, K or L displays. The T9 mode
automatically compares your keystrokes with an
internal linguistic dictionary to determine the
correct word, thus requiring far fewer keystrokes
than the traditional alphabet mode.
•Alphabet mode
These modes allow you to enter letters by
pressing the key labeled with the letter you want
to enter once, twice, three or four times until it
displays.
• Symbol mode
This mode allows you to enter various symbols
and special characters.
•Number mode
This mode allows you to enter numbers.
Entering Text
42
Changing the Text Input Mode
When you are in a field that allows characters to be
entered, you will notice the text input mode
indicator on the display.
Example: Writing a text message
To select the Press the right soft key
until
T9 mode T9 displays.
See page 43.
Alphabet mode abc displays.
See page 44.
Symbol mode the symbol list displays.
See page 46.
Number mode ??? displays.
See page 46.
Text input
mode indicator
918
Edit Field
Options T9
temporary
Entering Text
43
Using the T9 Mode
The T9 predictive text input mode allows you to key
in any character using single keystrokes. This text
input mode is based on a built-in dictionary.
To enter a word in the T9 mode:
1. When you are in the T9 predictive text input
mode, start entering a word by pressing the
keys 2 to 9. Press each key only once for one
letter.
Example: To enter “HELLO” in the T9 mode,
press the 4, 3, 5, 5 and 6 keys.
The word that you are typing appears on the
display. It may change with each key that you
press.
2. Enter the whole word before editing or deleting
the keystrokes.
3. If the word is correct, start entering the next
word.
Otherwise, press the 0, Up or Down key
repeatedly to display alternative word choices
for the keys that you have pressed.
Example: Both “OF” and “ME” have the
sequence 6 and 3. The phone displays
the most commonly used choice first.
4. Put a space between words by pressing the
key.
•To type words not found in the T9 mode, change
the text input mode to the alphabet mode.
Entering Text
44
•To enter full stops, hyphens or apostrophes, press
the 1 key. The T9 mode applies grammar rules to
ensure that the correct punctuation is used.
Example: The 1 key is used twice to display two
punctuation marks:
•To shift the case in the T9 mode, use the key.
There are three cases; Lower case (No indicator),
Initial Capital ( ) and Capital lock ( ).
•You can move the cursor by using the Left and
Right keys. To delete letters, press the key.
Press and hold the key to clear the display.
Using the Alphabet Mode
Use the 1 to 0 keys to enter your text.
1. Press the keys labeled with the required letter:
- Once for the first letter
- Twice for the second letter
- And so on
2. Select the other letters in the same way.
Note
: The cursor moves to the right when you press a
different key. When entering the same letter
twice or a different letter on the same key, just
wait for a few seconds for the cursor to move
to the right automatically, and then select the
next letter.
L E T ’ S E A T .
Entering Text
45
Refer to the table below for further details about the
characters available.
•To insert a space, press the key.
•To shift the case in the alphabet mode, use the
key. There are three cases; Lower case (No
indicator), Initial Capital ( ) and Capital lock
( ).
•You can move the cursor by using the Left and
Right keys. To delete letters, press the key.
Press and hold the key to clear the display.
Characters in the Order Displayed
Key Lower CaseUpper Case
Space
Entering Text
46
Using the Symbol Mode
The symbol mode enables you to insert symbols
into a text message.
Using the Number Mode
The number mode enables you to enter numbers
into a text message. Press the keys corresponding
to the digits you want to enter.
To Press the
select a symbol corresponding number
key.
display more symbols Up or Down key.
insert the symbol(s)
into your message
OK soft key.
cancel your input and
return to the previous
mode
Back soft key.
1 2 3
4 5 6
7 8 9
;:
SYMBOL
temporary
OK Back
47
Options During a Call
Your phone provides a number of control functions
that you can use during a call.
Putting a Call on Hold
You can place the current call on hold whenever you
want. You can make another call while you have a
call in progress if your network supports this
service. When you have an active call and a call on
hold, you may switch between the two calls,
changing the one on hold to active and placing the
other on hold.
To place a call on hold, simply press the Hold soft
key. You can reactivate the call whenever you want,
by pressing the Unhold soft key.
To make a call while you have a call in progress:
1. Enter the phone number that you wish to dial or
look it up in Phonebook.
2. Press the key to dial the second call.
The first call is automatically put on hold.
Or alternatively,
1. Put the current call on hold by pressing the Hold
soft key.
2. Make the second call in the normal way.
To switch between the two calls, simply press the
Swap soft key.
The current call is placed on hold and the call on
hold is reactivated so that you can continue
conversing with the other person.
When you want to finish, end each call normally by
pressing the key.
Options During a Call
48
Switching the Microphone Off (Mute)
You can temporarily switch your phone’s
microphone off so that the other person cannot
hear you.
Example: You wish to say something to another
person in the room but do not want the
other person to hear you.
To switch the microphone off temporarily:
1. Press the Options soft key.
2. If necessary, press the Down key to highlight
the Mute option.
3. Press the OK soft key.
The other person can no longer hear you.
To switch the microphone back on:
1. Press the Options soft key.
2. If necessary, press the Down key to highlight
the Unmute option.
3. Press the OK soft key.
The other person can hear you again.
Options During a Call
49
Muting/Sending Key Tones
These options allow you to turn the key tones off or
on. If the Mute Keys option is selected, your phone
does not transmit the key tones. It allows you to
press keys without hearing annoying key tones
during a call.
Note
: To communicate with answering machines or
computerized telephone systems, the
Send
Keys
option must be selected.
Searching for a Number in
Phonebook
You can search for a number in Phonebook during a
call.
1. Press the Options soft key.
2. Press the Down key to highlight the Phonebook
option.
3. Press the OK soft key.
The Phonebook entries are listed.
4. Enter the name that you wish to find.
If you enter the first few letters of the name, the
Phonebook entries are listed, starting with the
first entry matching your input.
5. To view the highlighted entry, press the View
soft key.
For further details about the Phonebook feature,
see page 30.
Options During a Call
50
Using the Message Service
If you receive an SMS (Short Message Service)
message during a call, the Message icon ( )
flashes on the display. The SMS Service option
enables you to use this feature.
For further details about the Message feature, see
page 60.
Answering a Second Call
You can answer an incoming call while you have a
call in progress, if your network supports this
service and you have set the Call Waiting menu
option (Menu 7.2) to Activate; see page 115. You
are notified of an incoming call by a call waiting
tone.
To answer a call while you have a call in progress:
1. Press the key to answer the incoming call.
The first call is automatically put on hold.
2. To switch between the two calls, press the Swap
soft key.
3. To end the call on hold, press the Options soft
key and select the End Held Call option.
To end the current call, press the key.
Options During a Call
51
Making a Multi-party Call
A multi-party call is a network service that allows
up to six people to take part simultaneously in a
multi-party or conference call. For further details,
contact your service provider.
Setting up the Multi-party Call
1. Call the first participant in the normal way.
2. Call the second participant in the normal way.
The first call is automatically put on hold.
3. To join the first participant to the multi-party
call, press the Options soft key and select the
Join option. Press the OK soft key.
4. To add a new person to the multi-party call, call
the person in the normal way and press the
Options soft key. Select the Join option and
press the OK soft key.
You can add incoming callers by answering the call,
pressing the Options soft key, and selecting the
Join option. Repeat as required.
Having a Private Conversation With One
Participant
1. Press the Options soft key and choose the
Select One option. Press the OK soft key.
The list of call participants appears.
2. Highlight a person from the list by pressing
the Up or Down key, and press the Select soft
key or the key.
Options During a Call
52
3. When the Private option highlights, press the
OK soft key.
Now you can talk privately with that person. The
other participants can still converse with each
other.
4. To return to the multi-party call, press the
Options soft key and select the Join option.
Press the OK soft key.
All the multi-party call participants can now hear
each other.
Dropping One Participant
1. Press the Options soft key and choose the
Select One option. Press the OK soft key.
The list of call participants appears.
2. Highlight a person from the list by pressing
the Up or Down key, and press the Select soft
key or the key.
3. Press the Down key to select the Remove
option and press the OK soft key.
The call ends with that participant, but you can
continue to talk with the other participants.
4. When you want to end the multi-party call,
press the key.
53
Using the Menus
The phone offers a range of functions that allow you
to tailor it to your needs. These functions are
arranged in menus and sub-menus.
The menus and sub-menus can be accessed by
scrolling with the navigation keys or by using the
shortcuts.
Accessing a Menu Function by Scrolling
1. In Idle Mode, press the Menu soft key to access
Menu Mode.
2. Scroll with the Up or Down key to reach a main
menu, Phone Settings for example. Press the
Select soft key or the Right key to enter the
menu.
3. If the menu contains any sub-menus,
Language for example, you can access them by
scrolling with the Up or Down key and pressing
the Select soft key or the Right key.
If the menu that you have selected contains
further options, repeat this step.
4. To Press the
scroll through the
menus
Up or Down key, or use
the and keys on the
left side of the phone.
confirm the chosen
setting
Select soft key or the
Right key.
return to the previous
menu level
soft key or the Left
key.
exit the menu without
changing the settings
key.
Using the Menus
54
Accessing a Menu Function by Using
its Shortcut
The menu items, such as menu, sub-menus and
options, are numbered and can be accessed quickly
by using their shortcut numbers. The shortcut
number is shown on the bottom right next to the
soft key on the display. Simply press the Menu soft
key and enter the required number.
Note
: The numbers assigned to each menu option are
indicated on the list on page 55. They may not
match the menu number on the phone,
depending on the services supported by your
SIM card.
Example: Accessing the Language option.
1. Press the Menu soft key.
2. Press the 5 key for Phone Settings.
3. Press the 5 key for Language.
The languages available display.
List of Menu Functions
The following list shows the menu structure
available and indicates the number assigned to
each option and the page where you can find a
description of each feature.
Note
: If you use a SIM AT card that provides
additional services, the
SIM AT
menu (9)
displays when you press the
Menu
soft key to
enter Menu Mode. For further details, see your
SIM card instructions.
Using the Menus
55
1. Text Message
(see page 60)
1.1 Inbox
1.2 Outbox
1.
3 W
rite New
1.4 Templates
1.5 Settings
1.5.1 Setting 1
*
1.5.2 Setting 2
*
1.5.3 Common Settings
1.6 My Objects
1.6.1 My EMS Melody
1.6.2 My EMS Picture
1.6.3 My EMS Animation
1.6.4 Delete All
1.7 Memory Status
1.7.1 SIM Memory
1.7.2 PHONE Memory
1.7.3 CB Memory
1.7.4 Delete All
1.8 Voice Mail
1.8.1 Connect to Voice Server
1.8.2 Voice Server Number
1.9 Broadcast
1.9.1 Read
1.9.2 Receive
1.9.3 Channel List
1.9.4 Language
1.10 Location Service
1.10.1 Services
1.10.2 Setting
1.10.3 Send Location
2. Picture Message
(see page 75)
2.1 Inbox
2.2 Outbox
2.3 Draft
2.4 Write New
2.5 Template
2.6 Delete All
* Shown only if supported by your SIM card.
Using the Menus
56
2. Picture Message
(continued)
2.7 Setup
2.7.1 Auto Download
2.7.2 Hide ID
2.7.3 Delivery Report
2.7.4 Read Report
2.7.5 Message Acceptance
2.7.6 Expiry Date
2.7.7 Delivery Time
2.7.8 Priority
2.7.9 Report Allowed
2.7.10 Page Duration
3. Call Records
(see page 85)
3.1 Missed Calls
3.2 Incoming Calls
3.3 Outgoing Calls
3.4 Delete All
3.5 Call Time
3.5.1 Last Call
3.5.2 Total Outgoing
3.5.3 Total Incoming
3.5.4 Reset Timers
3.6 Call Cost
*
3.6.1 Last Call Cost
3.6.2 Total Cost
3.6.3 Max Cost
3.6.4 Reset Counters
3.6.5 Set Max Cost
3.6.6 Price/Unit
* Shown only if supported by your SIM card.
Using the Menus
57
4. Sound Settings
(see page 89)
4.1 Ring Tone
4.2 Ring Volume
4.3 Alert Type
4.4 Keypad Tone
4.5 Message Tone
4.5.1 SMS Tone
4.5.2 SMS-CB Tone
4.6 Power On/Off
4.7 Extra Tones
5. Phone Settings
(see page 93)
5.1 My Settings
5.1.1 Wallpaper
5.1.2 Menu Style
5.1.3 Auto Key Lock
5.2 Greeting Message
5.3 Own Number
5.4 Language
5.5 Security
5.5.1 PIN Check
5.5.2 Change PIN
5.5.3 Phone Lock
5.5.4 Change Password
5.5.5 SIM Lock
5.5.6 FDN Mode
*
5.5.7 Change PIN2*
5.6 Display Settings
5.6.1 Brightness
5.6.2 Back Light
5.6.3 Auto Light
5.6.4 Service Light
5.6.5 Graphic Logo
5.7 Extra Settings
* Shown only if supported by your SIM card.
Using the Menus
58
5. Phone Settings
(continued)
5.8 Short Cut
5.8.1 Key Up
5.8.2 Key Down
5.8.3 Key Right
5.8.4 Key Left
5.9 Reset Settings
6. Organizer
(see page 103)
6.1 Calendar
6.2 To Do List
6.3 Time & Date
6.3.1 Set Time
6.3.2 Set Date
6.3.3 World Time
6.3.4 Time Format
6.4 Alarm
6.4.1 Once Alarm
6.4.2 Daily Alarm
6.4.3 Morning Call
6.4.4 Remove Alarm
6.4.3 Autopower
6.5 Calculator
6.6 Currency Exchange
7. Network Services
(see page 113)
7.1 Call Forwarding
7.1.1 Forward Always
7.1.2 Busy
7.1.3 No Reply
7.1.4 Unreachable
7.1.5 Cancel All
7.3 Call Waiting
7.4 Network Selection
7.5 Caller ID
7.7 Band Selection
Using the Menus
59
8. Funbox
(see page 118)
8.1 WAP Browser
8.1.1 Home
8.1.2 Favorite
8.1.3 Clear Cache
8.1.4 Push Message
8.2 Downloads
8.2.1 Games & More
8.2.2 Sounds
8.2.3 Pictures
60
Text Message
The SMS (Short Message Service) function is a
network service that may not be supported by your
network. You can send messages using text, fax,
e-mail and paging messaging systems, provided
that these services are supported by your network.
To send text messages by phone, you must obtain
the number of the SMS center from your service
provider.
When the Message icon ( ) appears, you have
received new text messages. If the memory is full,
an error message displays and you cannot receive
any new messages. Use the Delete option in each
message box to delete obsolete ones.
When you receive a new message in the key lock
mode, you can’t view it without unlocking the
keypad. Press the UnLock soft key and the key
to unlock.
Inbox
(Menu 1.1)
This message box is used to store the messages
that you have received.
When you enter this menu, the list of messages in
the box displays with the senders’ phone numbers
or names, if available in your Phonebook.
1. Select a message from the list and press the
View soft key to read the message contents.
2. To scroll through the contents, press the Up or
Down key.
3. To scroll to the previous or next message, press
the or key.
Text Message
61
While reading a message, you can choose the
following options by pressing the Options soft key:
Delete: allows you to delete the message.
Send: allows you to resend the message. For
further details about how to send a message, see
page 63.
Reply: allows you to reply to the sender by sending
a text message.
Call Back: allows you to call the sender back.
Cut Address: allows you to extract the destination
number and URL/e-mail addresses or phone
numbers from the message text, so that you can
save them in your Phonebook.
Move To Phone/SIM: allows you to move the
message to another memory location, from the SIM
card to the phone’s memory or vice versa.
Select Objects: allows you to save media objects,
such as sounds or images, from the message into
your phone. You can use the objects when writing a
message. For details, see page 65.
Text Message
62
Outbox
(Menu 1.2)
This message box is used to store the messages
that you have already sent or will send.
When you enter this menu, the list of messages in
the box displays with the recipients’ phone numbers
or names, if available in your Phonebook.
1. Select a message from the list and press the
View soft key to read the message contents.
2. To scroll through the contents, press the Up or
Down key.
3. To scroll to the previous or next message, press
the or key.
While reading a message, you can choose the
following options by pressing the Options soft key:
Delete: allows you to delete the message.
Send: allows you to resend the message. For
further details about how to send a message, see
page 63.
Cut Address: allows you to extract the destination
number and URL /e-mail addresses or phone
numbers from the message text, so that you can
save them in your Phonebook.
Move To Phone/SIM: allows you to move the
message to another memory location, from the SIM
card to the phone’s memory or vice versa.
Select Objects: allows you to save media objects,
such as sounds or images, from the message into
your phone. You can use the objects when writing a
message. For details, see page 65.
Text Message
63
Write New
(Menu 1.3)
In this menu option, you can write and send a text
message.
Note
: You can enter up to 918 alphanumeric
characters for your message. When you add
media objects to the message, the number of
characters you can enter decreases.
Creating a Simple Text Message
1. Create your message.
Note
: For further details about entering
characters, see page 41.
2. When you finish entering the message, press
the Options soft key. The following options are
available:
• Send Only: allows you to send the message.
The message is deleted after sending.
• Save and Send: allows you to save a copy of
the message and then send the message. You
can read the message in your Outbox.
• Save Only: allows you to save the message
so that it can be sent later. You can read the
message in your Outbox.
• For further details about Text Formatting,
Add Objects, Add Templates, Add
Phonebook, Add Bookmark and Language
options, see “Creating a Message Using the
Options” on page 64.
Text Message
64
3. Select Send Only or Save and Send, and press
the Select soft key.
If you want to just save the message, select
Save Only. After saving the message, the
phone returns to the Messages menu.
4. If you select a save option, choose the memory
where the message is saved and press the OK
soft key.
5. Enter a destination number and press the OK
soft key.
The message is sent.
When the phone fails to send the message, it
asks you if you want to retry. Press the OK soft
key to confirm. Otherwise, press the Exit soft
key.
Creating a Message Using the Options
1. Create a message.
2. Press the Options soft key.
3. Select one of the following options by using the
Up and Down keys and pressing the Select soft
key:
• Text Formatting: allows you to format the
style of the text. For the Size attribute,
Normal, Large and Small sizes are available.
For the Underline and Strikethrough
attributes, select On or Off. The attributes can
be combined.
Text Message
65
• Add Objects: allows you to add the required
sound, melody, picture or animation to the
message. Select the category of the object to
be added. In each category, you can select the
various factory-set items or choose an item
received from other sources, such as the
Internet or other phones.
• Add Templates: allows you to apply one of
the preset message templates to the text.
Select one of five messages stored in the
Templates menu option (Menu 1.4). For
further details, see page 66.
• Add Phonebook: allows you to add a
Phonebook entry in your message. Select one
from the list.
• Add Bookmark: allows you to add a web
page’s address stored in your Favorite list
(Menu 8.1.2). Select one from the list.
• Language: allows you to change the language
to be used in the T9 input mode. Select the
language to be used.
4. Complete the message, and send or save it by
following the procedure from Step 2 on page 63.
Text Message
66
Templates
(Menu 1.4)
Using this menu, you can preset up to five
messages that you use most frequently.
Scroll through the template list using the Up and
Down keys. When the message template you want
highlights, press the Options soft key.
The following options are available:
Edit: allows you to write a new message or edit the
message.
Note
: For further details about how to enter
characters, see page 41.
Send Message: allows you to recall the message.
Once you have completed the message, you can
send, save and send, or simply save it. For further
details about how to send a message, see page 63.
Delete: allows you to delete the message. You are
asked to confirm the deletion by pressing the Yes
soft key.
Settings
(Menu 1.5)
In this menu, you can set up default SMS
information. A setting group is a collection of
settings required to send messages. The number of
setting groups available depends on the capacity of
your SIM card.
Note
: The last setting you accessed is automatically
activated for sending messages.
Text Message
67
Setting x (where x is the setting group number):
each group has its own sub-menu.
Service Center: allows you to store or change the
number of your SMS center, which is required when
sending messages. You must obtain this number
from your service provider.
Default Destination: allows you to store the default
destination number. The number will automatically
display on the Destination screen when you create a
message.
Default Type: allows you to set the default message
type to Text, Fax, Email or Paging. The network
can convert the messages into the selected format.
Default Validity: allows you to set the length of time
your text messages are stored at the message
center while attempts are made to deliver them.
Setting Name: allows you to give a name to the
setting group currently being defined.
Common Setting: The following options are
available:
Reply Path: allows the recipient of your SMS
message to send you a reply message via your
message center, if your network supports this
service. You can enable or disable this option by
pressing the ON or OFF soft key.
Delivery Reports: allows you to activate or
deactivate the report function. When this function is
activated, the network informs you whether or not
your message has been delivered. You can enable
or disable this option by pressing the ON or OFF
soft key.
Bearer Selection: allows you to choose either GSM
or GPRS, depending on your network.
Text Message
68
My Objects
(Menu 1.6)
In this menu option, you can see the media objects
you saved from messages into your phone’s
memory by using the Select Objects option.
Three categories of objects are available:
•My EMS Melody
•My EMS Picture
•My EMS Animation
To delete an item, press the Delete soft key while
you are reviewing it.
You can delete all of the items using the Delete All
option (Menu 1.6.4).
When a confirming message displays, press the Yes
soft key to confirm.
To Press the
select a message
box to clear
Up or Down key. To delete
all of your messages,
select All.
place a check mark Mark soft key.
remove the check
mark
Unmark soft key.
delete the marked
messages
Delete soft key.
Text Message
69
Memory Status
(Menu 1.7)
This menu option shows how many messages are
currently stored in the SIM, phone and CB (cell
broadcast) memories.
You can delete all of the messages in each message
box using the Delete All option (Menu 1.7.4).
When a confirming message displays, press the Yes
soft key to confirm.
To Press the
select a message
box to clear
Up or Down key. To delete
all of your messages,
select All Messages.
place a check mark Mark soft key.
remove the check
mark
Unmark soft key.
delete the marked
messages
Delete soft key.
Text Message
70
Voice Mail
(Menu 1.8)
This menu provides you with a way of accessing
your voice mailbox, if your network supports this
service.
The following options are available:
Connect to Voice Server: before using this
feature, you must enter the voice server number
obtained from your service provider (see menu
option 1.8.2). You can then select a server number
from the list and press the OK soft key to listen to
your messages.
You can quickly connect to the voice server by
pressing and holding the 1 key in Idle Mode.
Voice Server Number: allows you to change the
voice mail server number, if necessary.
Note
: Voice Mail is a network feature. Please contact
your service provider for further details.
To Press the
enter the server
number
corresponding numeric
keys.
correct a digit key.
move the cursor to the
left/right without clearing
the digit
Left or Right key.
Text Message
71
Broadcast
(Menu 1.9)
This network service allows you to receive text
messages on various topics, such as the weather or
traffic. Messages display as soon as they are
received, provided that:
• the phone is in Idle Mode.
• the Receive option is set to Enable.
• the message channel is currently active on the
channel list.
The following options are available:
Read: lets you view the received message.
Volatile displays the messages from the network,
but loses its contents as soon as the phone is
switched off. Scroll through the message by using
the Up and Down keys. While reading a message,
press the Save soft key to store the message in the
Archive box for later retrieval.
Receive: allows you to enable or disable the
reception of broadcast messages.
Channel List: allows you to indicate the channels
from which you wish to receive broadcast
messages. The following options are available:
Select: use to enable or disable channels on the list
by marking or unmarking them respectively. A
check mark displays in front of each selected
channel.
Add Channel: use to enter the ID and title for a new
channel.
Delete: use to remove a channel from the list.
Edit: use to change the ID and title of an existing
channel.
Text Message
72
Language: allows you to select your preferred
language to display cell broadcast messages.
Please contact your service provider for further
details.
Location Service
(Menu 1.10)
In this menu, you can use the location service,
which enables emergency call centers to locate you
using the EOTD (Enhanced Observed Time
Difference) feature.
The EOTD feature uses up to four cellular base
stations to measure the arrival times of the call at
various cellular antennas and pinpoints a cellular
phone location. Emergency call centers can then
locate a landline phone with saving the lives of
those unaware of where they are or too injured or
panicked to provide any details.
Services
(Menu 1.10.1)
You can configure various settings required when
sending your location information to service
centers.
For each service setting, the following options are
available:
Service Name
: allows you to store the service
center name that you want to use.
Service Number
: allows you to store the number
of your service center required for emergency
dialing.
Text Message
73
Service MO Set
: allows you to set whether or not
the phone sends information about your location to
the center.
Service MT Set
: allows you to set whether or not
your phone allows the center to scan information
about your location.
Service Periodic Set
: allows you to set your
phone to send your location information to the
service center at specified intervals.
Service Type
: allows you to select how your
phone sends your location to the service center.
Select
Only SMS
to send by SMS messages only.
Select
VoiceCall&SMS
to send by voice calls
along with SMS messages.
Setting
(Menu 1.10.2)
In this menu, you can change the default settings
required when using the location service. These
settings are for the EOTD system. For further
details, contact your service provider.
The following options are available:
SMLC Address
: allows you to store the address of
the system that processes your information and
sends it to your service center.
EOTD Setting
: allows you to select whether or not
you use the location service. To use the service, you
must set this option to
Enable
.
MO Setting
: allows you to set whether or not the
system sends information about your location to the
service center. To use the location service, you must
set this option to
Enable
.
Text Message
74
MT Setting
: allows you to set whether or not your
phone allows the system to scan information about
your location.
Periodic Setting
: allows you to set the system to
send your location information to the service center
at specified intervals.
Send Location
(Menu 1.10.3)
You can select one of the service centers that you
set up in the
Service
menu option. Your phone will
sends information about your location to the
specified center.
75
Picture Message
Multimedia Message Service (MMS) is a messaging
service very similar to Short Message Service
(SMS). It provides automatic and immediate
delivery of personal multimedia messages from
phone to phone or from phone to e-mail.
In addition to the familiar text content of text
messages, multimedia messages can contain
images, graphics, voice and audio clips. An MMS
message is a multimedia presentation in a single
entry. It is not a text file with attachments.
Using the MMS feature, your phone can receive
multimedia messages. You can also send picture
messages, which are short messages that contain
images, such as your photos or graphics you
downloaded from the Internet. This function is
available only if it is supported by your service
provider. Only phones that offer picture message
features can receive and display picture messages.
Inbox
(Menu 2.1)
Viewing a Message When You Receive it
When a new multimedia message comes in, the
display shows the text notification along with the
sender’s number.
1. Press the View soft key to view the message.
The display shows brief information about the
message, such as the sender’s number, the
message size and the subject.
If you want to view the message later in the
Inbox, press the Exit soft key.
Picture Message
76
2. To scroll through the message information,
press the Up or Down key.
While viewing the information, press the Options
soft key to use the following options:
Retrieve: shows you the message contents.
Delete: deletes the message.
More Information: shows you detailed
information about the message.
Viewing a Received Message in the Inbox
When you access the Inbox menu option (Menu
2.1), the list of multimedia messages you received
displays with the senders’ phone numbers, if they
are available in your Phonebook, or subjects. The
icons on the left tells you the status of the
messages.
•: Messages you already read.
•: Messages you haven’t read yet.
1. Select a message and press the Select soft key
to view the message.
2. To scroll through the message, press the Up or
Down key.
3. Press the OK soft key on the message
presentation screen.
While viewing a message, you can choose the
Message options by pressing the Options soft key.
If you are viewing a new message, the options are
the same as when you view a message as soon as
you receive it. See the previous section.
Picture Message
77
When you are reviewing a message, the following
options are available:
Delete: deletes the message.
Reply: allows you to reply to the sender by sending
a text or picture message.
Callback: allows you to call the sender back.
Cut Number: allows you to extract the destination
number from the message, so that you can call the
number or save it in your Phonebook.
Forward: allows you to forward the message to
another person.
Save Picture: allows you to save an image from
the message into your phone. Images are stored in
the Pictures folder in the Downloads menu option
(Menu 8.2).
Save Sound: allows you to save a sound from the
message into the Sounds folder in the Downloads
menu option (Menu 8.2).
Information: shows you information about the
message, such as subject, sender’s address,
message size, status and priority.
Picture Message
78
Outbox
(Menu 2.2)
When you access this menu option, the list of the
picture messages you sent or saved displays. The
icons on the left tells you the status of the
messages.
•: Messages currently being sent
•: Messages sent
•: Messages your phone couldn’t send
•: Messages to be send
•: Messages deferred
1. Select a message and press the Select soft key
to view the message contents.
2. To scroll through the message, press the Up or
Down key.
3. Press the OK soft key on the message
presentation screen.
While viewing a message, you can choose the
following options by pressing the Options soft key:
Delete: deletes the message.
Cut Number: allows you to extract the destination
number from the message, so that you can call the
number save it in your Phonebook.
Send: allows you to resend the message.
Edit Message: allows you to change the message
contents, sound, picture or text.
Information: shows you information about the
message, such as subject, recepient’s address,
message size, status and priority.
Picture Message
79
Draft
(Menu 2.3)
After creating a picture message, you can store it in
this message box for later sending. Or, if you are
interrupted while making a message by an
incoming call or message, your message is
automatically saved in this box.
For further details about viewing a message, see
“Outbox” on page 78.
Write New
(Menu 2.4)
This menu option allows you to create a new picture
message and then send it to multiple destinations.
Creating and Sending a Picture Message
1. Enter the subject of your message and press the
OK soft key.
For further details about entering characters,
see page 41.
2. When Add Here highlights, press the Options
soft key and add the message contents using
one of the following options:
• Add Text: Enter the message text and press
the OK soft key.
• Add Picture: allows you to add a picture
stored in the Pictures folder in the
Downloads menu option (Menu 8.2). Choose
a picture and press the Select soft key.
Picture Message
80
• Add Sound: allows you to add a sound. You
can record a new voice memo or use a sound
stored in the Sounds folder in the
Downloads menu option (Menu 8.2).
• Send: allows you to send the message. Use
this option when you finish creating the
message. This option is activated after you
add a content to the message.
• Save: saves the message in the Draft (Menu
2.3) or Templates (Menu 2.5) box for later
use. This option is activated after you add a
content to the message.
• Settings: allows you to change the message
settings. For further details about each setting
option, see page 84. After changing, you need
to press the soft key or the key to go
to back to the options screen.
• Add Destination: allows you to enter
destination addresses. See steps 7 to 10. After
adding, you need to press the soft key or
the key to go to back to the options
screen.
• Preview: shows your message as it will
display on the recipient’s phone.
Note
: You can use the adding options only one
time for one page.
3. When the added content displays, press the
Down key to highlight Add Here.
4. Repeat steps 2 and 3 until you finish creating
your message.
Picture Message
81
5. If you want to change the added items, press
the Up or Down key to highlight one and press
the Options soft key. The following options are
available:
• Edit Text/Picture/Sound: allows you to
change text or replace the image or sound
with another one.
• Add Page: allows you to add more pages. You
can move to each page using the Left or Right
key when Page highlights on the message
screen.
• Delete: deletes the item from your message.
• Duration: allows you to set how long one
page displays. After a specified length of time,
the display scrolls to the next page.
• Send: allows you to send the message.
• Save: saves the message in the Draft (Menu
2.3) or Templates (Menu 2.5) box for later
use.
• Settings: allows you to change the message
settings. For further details about each setting
options, see page 84.
• Add Destination: allows you to enter
destination addresses. See steps 7 to 10.
• Preview: shows your message as it will
display on the recipient’s phone.
Note
: The options available are different
depending on the item selected on the
message screen.
6. When you finish creating the message, choose
Send from the options and press the Select soft
key.
Picture Message
82
7. Choose one of the following options and press
the Select soft key:
• Phone Number: allows you to enter the
phone number you want.
• E-Mail: allows you to enter the e-mail address
of the recipient to send the message as an
e-mail.
• Phone Book: allows you to recall a number
from your Phonebook.
8. Enter a number or an e-mail address, or select
a number in Phonebook.
9. When the correct number or address displays,
press the OK soft key.
10. To send the message to multiple destinations,
select Add Destination and press the Select
soft key.
11. Repeat steps 7 to 10. You can enter up to
10(??) destinations.
If you want to edit the destinations, select one
and press the Select soft key. You can change
or delete it.
12. When you are finished entering the
destinations, select Send Message and press
the Select soft key.
Your phone sends the message.
Picture Message
83
Template
(Menu 2.5)
This menu option stores up to five messages you
saved as templates. You can make a new message
using the text of them.
Scroll through the template list using the Up and
Down keys. When the message template you want
highlights, press the Select soft key. The message
text displays.
Press the OK soft key to use the following options:
Edit Message: allows you to send a message using
the template. For further details about how to send
a message, see page 79.
Delete: allows you to delete the message. You are
asked to confirm the deletion by pressing the Yes
soft key.
Delete All
(Menu 2.6)
This menu option allows you to delete all of the
picture messages in each message box, Inbox,
Outbox and Draft.
When a confirming message displays, press the Yes
soft key to confirm.
Picture Message
84
Setup
(Menu 2.7)
You can change the default settings for sending or
receiving picture messages.
The following options are available:
Auto Download: You can set whether or not, your
phone automatically downloads the pictures or
sounds from the messages. When you select Ask,
the phone asks you to download the items when
you read the message(??).
Hide ID: When this option is checked, your phone
number dose not display on the recipient’s phone.
Delivery Report: When this option is checked, the
network informs you whether or not your message
has been delivered.
Read Report: When this option is checked, (??).
Message Acceptance: You can specify the
category of messages you want to receive.
Expiry Date: You can select the length of time your
messages are stored at the message center after
they were sent.
Delivery Time: You can set the delay time before
the phone sends your messages.
Priority: You can select the priority level of your
messages.
Report Allowed: You can set whether or not (??).
Page Duration: You can set how long one page of
the received message displays. After a specified
time, the display automatically scrolls to the next
page.
85
Call Records
In this menu, you can view the:
• calls you missed, received or dialed.
• length of your calls.
• cost of your calls.
Note
: You can access the numbers in the three types
of call records by pressing the
key in Idle
Mode.
Missed Calls
(Menu 3.1)
This option lets you view the last 20 numbers of the
calls you received, but did not answer.
The number and name, if available, display
together with the date and time when the call was
received.
By pressing the Options soft key, you can:
• delete the call from the list.
•edit the number, if available, and dial it or save it
in Phonebook.
Incoming Calls
(Menu 3.2)
This option lets you view the last 20 numbers of the
calls you received.
The number and name, if available, display
together with the date and time when the call was
received.
By pressing the Options soft key, you can:
• delete the call from the list.
•edit the number, if available, and dial it or save it
in Phonebook.
Call Records
86
Outgoing Calls
(Menu 3.3)
This option lets you view the last 20 numbers you
dialed.
The number and name, if available, display
together with the date and time when the call was
made.
By pressing the Options soft key, you can:
• delete the call from the list.
• edit the number and dial it or save it in
Phonebook.
Delete All
(Menu 3.4)
This menu option allows you to delete all of the
records in each call type. You can also delete all of
your call records at one time.
When a confirming message displays, press the Yes
soft key to confirm.
To Press the
select a call type to
clear
Up or Down key. To delete
all of your call records,
select All Calls.
place a check mark Mark soft key.
remove the check
mark
Unmark soft key.
delete the marked
messages
Delete soft key.
Call Records
87
Call Time
(Menu 3.5)
This option lets you view the timers for calls made
and received.
The following timers are available:
Last Call: length of the last call.
Total Outgoing: total length of all calls made since
the timer was last reset.
Total Incoming: total length of all calls received
since the timer was last reset.
Reset Timers: option used to reset the call timers.
You must first enter the phone password (see
page 129) and then press the OK soft key.
Note
:
The actual time invoiced for calls by your
service provider may vary, depending on
network features, rounding-off for billing
purposes and others.
Call Cost
(Menu 3.6)
This network feature lets you view the cost of calls.
This option may not be shown depending on your
SIM card.
The following options are available:
Last Call Cost: cost of the last call made.
Total Cost: total cost of all calls made since the
cost counter was last reset. If the total cost exceeds
the maximum cost set in the Set Max Cost option,
you can no longer make any calls until you reset the
counter.
Call Records
88
Max Cost: maximum cost set in the Set Max Cost
option. See below.
Reset Counters: option used to reset the cost
counter. You must first enter your PIN2 (see
page 131) and then press the OK soft key.
Set Max Cost: option used to enter the maximum
cost that you authorize for your calls. You must first
enter your PIN2 (see page 131) and then press the
OK soft key.
Price/Unit: option used to set the cost of one unit;
this price per unit is applied when calculating the
cost of your calls. You must first enter your PIN2
(see page 131) and then press the OK soft key.
89
Sound Settings
You can use the Sound Settings feature to
customize various settings, such as the:
• ring melody, volume and type.
• sounds made when you press a key, receive a
message or switch your phone on/off.
•alert tone made every minute during a call, when
you make an error or when your call is connected
to the system.
Note
: When the phone is in the silent mode (see
page 27), you cannot change the sound
settings.
Ring Tone
(Menu 4.1)
This option allows you to select a ring melody.
You can choose between many different melodies.
Each time you select a melody, it plays for a few
seconds. If you have downloaded sounds from the
Internet, you can use them in this menu.
Ring Volume
(Menu 4.2)
This option allows you to adjust the ring volume to
one of five levels.
Use the Up and Down keys or the and keys on
the left side of the phone to increase or decrease
the volume.
Sound Settings
90
Alert Type
(Menu 4.3)
This option allows you to specify how you are to be
informed of incoming calls.
The following options are available:
Light Only: the service light flashes; the phone
neither rings nor vibrates.
Melody: the phone rings using the ring melody
selected in the Ring Tone menu option
(Menu 4.1); see page 89.
Vibration: the phone vibrates but does not ring.
Vibra+Melody: the phone first vibrates three
times and then starts ringing.
Keypad Tone
(Menu 4.4)
This option allows you to select a tone that the
phone sounds when you press a key.
You can select an option from Cool, Piano, Tone
and Beep. To turn the sound off, select Off.
Sound Settings
91
Message Tone
(Menu 4.5)
This option allows you to select how the phone
informs you that a new message has been received.
SMS Tone
(Menu 4.5.1)
This option allows you to select how the phone
informs you that a new SMS message has been
received.
The following options are available:
Off: the phone does not use the SMS tone.
Light Only: the service light flashes.
Vibration: the phone vibrates.
Single Beep: the phone beeps once.
SMS Tone x: the phone uses one of several SMS
tones.
SMS-CB Tone
(Menu 4.5.2)
This option allows you to select how the phone
informs you that a new cell broadcast (CB) message
has been received.
The following options are available:
Off: the phone does not use the CB tone.
Light Only: the service light flashes.
Vibration: the phone vibrates.
Single Beep: the phone beeps once.
SMS-CB Tone x: the phone uses one of several CB
tones.
Sound Settings
92
Power On/Off
(Menu 4.6)
This option allows you to select a melody that the
phone sounds when it is switched on and off.
You can choose either Classical or Cheerful. To
turn the sound off, select Off.
Extra Tones
(Menu 4.7)
You can customize additional tones used for the
phone.
The following options are available:
Error Tone: sets whether or not the phone informs
you when you make a mistake.
Minute Minder: sets whether or not the phone
beeps every minute during an outgoing call to keep
you informed of the length of your call.
Connect Tone: sets your phone to beep when your
call is connected to the system.
To turn a given
tone
Press the
on ON soft key.
A check mark displays in
front of the option.
off OFF soft key again.
The check mark no longer
displays.
93
Phone Settings
Many different features of your phone can be
customized to suit your preferences. All of these
features are accessed in the Phone Settings
menu.
My Settings
(Menu 5.1)
You can change the background image and the
display style of Menu Mode according to your
preference.
Wallpaper
(Menu 5.1.1)
This menu option allows you to change the
background image to be displayed in Idle Mode.
To change the background image:
1. Scroll through the list by pressing the Up or
Down key.
You have various preset images available. You
can also select the blank background and any
images downloaded from the Internet.
2. Press the Select soft key when the image you
want highlights.
3. When the image displays, press the Select soft
key to display it on the idle screen.
4. To display the current date and time on the
wallpaper image, press the Yes soft key.
To display only the image, press the No soft key.
Phone Settings
94
Menu Style
(Menu 5.1.2)
This menu option allows you to select the menu
display style. You can choose either Film Style or
Page Style.
Auto Key Lock
(Menu 5.1.3)
This menu option allows you to set the phone to
automatically lock the keys if no key is pressed
within a given period of time. This feature is useful
to avoid pressing keys by mistake.
To use this feature, select the length of time the
phone waits before it locks the keypad.
15 Sec
,
30 Sec
,
1 Min
and
2 Min
are available.
If you do not want to use this feature, select
Off
.
Note
: You can manually lock the keypad. For further
details, see page 21.
Greeting Message
(Menu 5.2)
This menu option allows you to set a greeting to be
displayed briefly when the phone is switched on.
For further details about how to enter characters,
see page 41.
To Press the
clear the existing
message
key and hold it down
until the message is
cleared.
enter a new
message
appropriate alphanumeric
keys.
change the text
input mode
right soft key.
Phone Settings
95
Own Number
(Menu 5.3)
This feature allows you to:
• assign a name to each of your own phone
numbers registered on your SIM card.
• edit the names and numbers.
This function is a memory aid, which you can use to
check your own phone numbers if you need to do so.
Any changes made here do not in any way affect
the actual subscriber numbers on your SIM card.
Language
(Menu 5.4)
You can select a display language. When the
language option is set to Automatic, the language
is automatically selected according to the language
of the SIM card used.
Security
(Menu 5.5)
The Security feature enables you to restrict the use
of your phone to the people and the types of calls of
your choice.
Various codes and passwords are used to protect
the features of your phone. They are described in
the following sections. See also pages 129-131.
Phone Settings
96
PIN Check
(Menu 5.5.1)
When the PIN Check feature is enabled, you must
enter your PIN each time you switch the phone on.
Consequently, any person who does not have your
PIN cannot use your phone without your approval.
Note
: Before disabling the PIN Check feature, you
must enter your PIN.
To change your PIN, see the Change PIN menu
option (Menu 5.5.2).
The following options are available:
Disable: the phone connects directly to the
network when you switch it on.
Enable: you must enter the PIN each time the
phone is switched on.
Change PIN
(Menu 5.5.2)
This feature allows you to change your current PIN
to a new one, provided that the PIN Check feature
is enabled. You must enter the current PIN before
you can specify a new one.
Once you have entered a new PIN, you are asked to
confirm it by entering it again.
Phone Settings
97
Phone Lock
(Menu 5.5.3)
When the Phone Lock feature is enabled, the phone
is locked and you must enter the 8-digit phone
password each time the phone is switched on.
The password is preset to “00000000” at the
factory. To change the phone password, see the
Change Password menu option (Menu 5.5.4)
below.
Once the correct password has been entered, you
can use the phone until you switch it off.
The following options are available:
Disable: you are not asked to enter the phone
password when you switch the phone on.
Enable: you are required to enter the phone
password when you switch the phone on.
Change Password
(Menu 5.5.4)
The Change Password feature allows you to change
your current phone password to a new one. You
must enter the current password before you can
specify a new one.
The password is preset to “00000000” at the
factory. Once you have entered a new password,
you are asked to confirm it by entering it again.
Phone Settings
98
SIM Lock
(Menu 5.5.5)
When the SIM Lock feature is enabled, your phone
only works with the current SIM card. You must
enter the SIM lock code.
Once you have entered the lock code, you are
asked to confirm it by entering it again.
To unlock the SIM, you must enter the SIM lock
code.
FDN Mode
(Menu 5.5.6)
The FDN (Fixed Dial Number) mode, if supported by
your SIM card, allows you to restrict your outgoing
calls to a limited set of phone numbers.
The following options are available:
Disable: you can call any number.
Enable: you can only call phone numbers stored in
Phonebook. You must enter your PIN2.
Note
: Not all SIM cards have a PIN2. If your SIM card
does not, this menu option is not displayed.
To change your PIN2, see the Change PIN2 menu
option (Menu 5.5.7) below.
Change PIN2
(Menu 5.5.7)
The Change PIN2 feature allows you to change your
current PIN2 to a new one. You must enter the
current PIN2 before you can specify a new one.
Once you have entered a new PIN2, you are asked
to confirm it by entering it again.
Note
: Not all SIM cards have a PIN2. If your SIM card
does not, this menu option is not displayed.
Phone Settings
99
Display Settings
(Menu 5.6)
Brightness
(Menu 5.6.1)
This menu option allows you to adjust the
brightness of the display screen to see it better in
different lighting conditions.
Adjust the brightness by using the Up or Down keys
or the and keys on the left side of the phone.
Back Light
(Menu 5.6.2)
You can select whether or not the phone uses the
backlight. A marginal increase in standby/talk time
can be achieved by turning the backlight off.
Select the length of time the backlight is on. The
backlight turns on when you press a key or receive
a call or message and remains for the specified
length of time. The display switches off after one
minute.
If you do not want to use the backlight, select Off.
Auto Light
(Menu 5.6.3)
Using this feature, you can specify the time for
which the backlight is to be used. This feature helps
you to conserve your battery power.
The following options are available:
Disable: the backlight is used according to the
setting in the Back Light menu option
(Menu 5.6.2); see page 99.
Phone Settings
100
Enable: the backlight is used only during the
specified period of time. Set the time when the
phone turns the light on and then turns it off, using
the appropriate number keys.
Service Light
(Menu 5.6.4)
This menu option allows you to select whether or
not the service light is used or in which color it
flashes.
Select one from the seven color settings available.
When the phone is ready for use, the service light
flashes in the appropriate color.
If you do not wish to use the service light,
select Off.
Graphic Logo
(Menu 5.6.5)
This menu option allows you to display your
operator’s logo instead of its name.
Off: the operator name displays in Idle Mode.
On: the operator logo stored in your phone displays
in Idle Mode; if no logo has been stored, the
operator name displays.
Phone Settings
101
Extra Settings
(Menu 5.7)
You can turn the automatic redialing or answering
features on or off.
The following options are available:
Auto Redial: when this option is checked, the
phone makes up to ten attempts to redial a phone
number after an unsuccessful call.
Note
: The interval between two call attempts varies.
Anykey Answer: when this option is checked, you
can answer an incoming call by pressing any key,
except the key and the Reject soft key. To
reject the call, press the key or the Reject
soft key.
When this option is unchecked, you can only press
the key or Accept soft key.
To turn a feature Press the
on ON soft key.
A check mark displays in
front of the option.
off OFF soft key.
The check mark no longer
displays.
Phone Settings
102
Short Cut
(Menu 5.8)
The navigation keys can be used as shortcut keys.
In Idle Mode, they allow you to access specific
menu options directly.
To assign a shortcut to a key:
1. Select the key to be used as a shortcut key by
pressing the Up or Down key, and press the
Select soft key.
• Key Up
• Key Down
• Key Right
• Key Left
2. Select the menu option to be assigned to the
key by pressing the Up or Down key.
Note
: To deactivate a shortcut key, select the
None
option.
3. Press the Select soft key to save the selection.
Reset Settings
(Menu 5.9)
You can easily reset your phone to its default
settings. To reset your phone:
1. Select the Reset Settings menu option.
2. Enter the 8-digit phone password and press the
OK soft key.
Note
: The password is preset to “00000000.” To
change this password, see page 97.
103
Organizer
The Organizer feature enables you to:
• view the calendar and organize your schedule.
• define a list of things to do.
• set the current date and time.
•set an alarm so that the phone rings at a specific
time, such as to remind you of an appointment.
• use the phone as a calculator for basic
mathematical equations or currency exchange
operations.
Calendar
(Menu 6.1)
With the Calendar feature, you can:
• consult the calendar.
•write memos to keep track of your schedule.
• trigger an alarm, if necessary.
Consulting the Calendar
When you select the Calendar menu option (Menu
6.1), the calendar displays with today’s date
highlighted. The following options are available
when you press the Options soft key:
Search All: displays all of the memos, starting with
the oldest, regardless of the day. To scroll through
the memos, press the Up or Down key.
Delete All: allows you to delete all of the memos.
You are asked to confirm your action.
Go to Date: allows you to go to a specific date.
Exit: exits the Calendar feature and returns to Idle
Mode.
Organizer
104
Writing a Memo
To write or edit a memo on a specific date:
1. Select a date on the calendar, using the
navigation keys.
Note
: To skip to the previous or next month,
press
the or key
on the left side of the
phone.
2. Press the Select soft key.
An empty memo screen displays to allow you to
enter your memo.
3. Enter your memo and then press the OK soft
key.
Note
: For further details about how to enter
characters, see page 41.
You are asked if you wish to set an alarm.
4. If you want an alarm to ring on the chosen day,
press the Yes soft key.
Otherwise, press the No soft key.
5. If you pressed the Yes soft key, set the time for
the alarm and press the OK soft key.
You can also select the melody for the alarm by
pressing the Melody soft key.
6. If you use the 12-hour time format, select AM
or PM and press the OK soft key.
Note
: The time format is preset to
12 Hours
by
default. You can change it in the
Time
Format
menu option (
Menu 6.3.4)
.
The color of the date on the calendar changes to
green to indicate that a memo exists.
Organizer
105
Viewing a Memo
When you select a day for which a memo already
exists on the calendar, the latest memo of the day
displays.
If more than one memo is stored, press the Up or
Down key to scroll to the previous or next memo.
Press the New soft key to add a new memo to the
day.
You can use the following options by pressing the
Option soft key:
Edit: allows you to change the memo text.
Alarm: allows you to set an alarm to ring at the
specified time to inform you of the memo. If you
already set, you can change or delete the alarm.
Delete: allows you to delete the memo.
Copy to: allows you to copy the memo to another
date.
Move to: allows you to change the date of the
memo.
Organizer
106
To Do List
(Menu 6.2)
This feature allows you to:
• enter a list of tasks to be done.
• assign a priority and a deadline to each task.
• sort the tasks by priority and status mark.
Creating the To Do List
1. Press the New soft key.
2. Enter the first task.
Note
: For further details about how to enter
characters, see page 41.
3. Press the OK soft key.
4. Select high, normal or low priority using the Up
and Down keys and press the Select soft key.
5. Enter your deadline and press the OK soft key.
If you do not want to set a deadline, press the
Skip soft key.
Editing the To Do List
When you select the To Do List menu option
(Menu 6.2), the current contents display with the
status mark and priority; for High, for
Normal and for Low.
Organizer
107
To view the
details for a
specific task
➀ highlight the task.
➁ press the View soft key.
➂ scroll through the tasks
using the Up and Down
keys, if necessary.
To change the
status of a
specific task
➀ highlight the task.
➁ press the key to mark the
task as completed as of the
current date and time.
or
➀ highlight the task.
➁ press the Options soft key.
➂ select the Mark option.
➃ select the appropriate status
(Done or Undo).
To create a new
task
➀ press the Options soft key.
➁ select the New option.
➂ enter the text, priority and/
or deadline for the task.
To edit an
existing
task
➀ highlight the task.
➁ press the Options soft key.
➂ select the Edit option.
➃ change the text, priority
and/or deadline for the task,
as required.
To sort the
existing
tasks by priority
or status
➀ press the Options soft key.
➁ select the Sort option.
➂ select the sort criterion
(High, Low, Done or
Undo).
Organizer
108
To copy a task ➀ highlight the task.
➁ press the Options soft key.
➂ select the Copy option.
➃ change the text, priority
and/or deadline for the task,
as required.
To copy a task to
the calendar
➀ highlight the task.
➁ press the Options soft key.
➂ select the Copy to
Calendar option.
➃ change the text and deadline
for the task and set the
alarm, as required.
To delete a task ➀ highlight the task.
➁ press the Options soft key.
➂ select the Delete option.
To delete all
tasks
➀ press the Options soft key.
➁ select the Delete All option.
➂ confirm the deletion by
pressing the OK soft key.
To exit the To Do
list
➀ press the Options soft key.
➁ select the Exit option.
Organizer
109
Time & Date
(Menu 6.3)
This option allows you to change the current time
and date displayed. You can also use this option to
find out what time it is in another part of the world.
The following options are available:
Set Time: allows you to enter the current time. You
can choose the time format in the Time Format
menu option (Menu 6.3.4). See below.
Note
: Before setting the time, you must specify your
time zone, in the
World Time
menu option
(
Menu 6.3.3
).
Set Date: allows you to enter the day, month and
year.
World Time: allows you to find out what time it is
in another part of the world, using the Left and
Right keys.
The screen shows the:
• city name.
• current date and time.
• time difference between the selected city and
your city if you have set the local time (see below
for further details) or GMT (by default).
To select your time zone:
1. Select the city corresponding to your time zone
by pressing the Left or Right key one or more
times. The local date and time display.
2. Press the Set soft key.
Time Format: allows you to change the time
format to
24 Hours
or 12 Hours.
Organizer
110
Alarm
(Menu 6.4)
This feature allows you to:
• set the alarm to ring at a specific time.
•set the phone to switch on automatically and ring
the alarm even if the phone is switched off
(Autopower menu option set to Enable).
The following options are available:
Once Alarm: the alarm rings only once and is then
deactivated.
Daily Alarm: the alarm rings every day at the
same time.
Morning Call: the alarm rings to wake you up in
the morning.
To set an alarm:
1. Choose the type of alarm to be set and press the
Select soft key.
2. Enter the time for the alarm to sound and press
the OK soft key.
If you want to use the alarm options, press the
Options soft key. The following options are
available:
• Remove Alarm: deactivates the current
alarm.
• Alarm Sound Set: allows you to select the
alarm melody.
3. If you use the 12-hour time format, select AM
or PM and press the OK soft key.
Note
: The time format is preset to
12 Hours
by
default. You can change it in the
Time
Format
menu option (
Menu 6.3.4
).
Organizer
111
4. If you select Morning Call in Step 1, choose the
repeat option, Monday to Friday or Monday
to Saturday, and press the Select soft key.
To stop the alarm when it rings, press the Exit soft
key.
Remove Alarm: deactivates all alarm settings.
Note
: You can also stop the alarm even if your phone
is in the key lock mode. After you check the
alarm, the key lock mode is canceled.
Autopower: when this option is set to Enable, the
alarm rings at the specified time, even if the phone
is switched off.
If the menu option is set to Disable and the phone
is switched off at the specified time, the alarm does
not ring.
Calculator
(Menu 6.5)
With this feature, you can use the phone as a
calculator. The calculator provides the basic
arithmetic functions; addition, subtraction,
multiplication and division.
1. Enter the first number using the numeric keys.
Notes
:
• To delete mistakes or clear the display, press the
key.
• To include a decimal point or a bracket, press the
left soft key until the symbol you want displays.
2. Press the right soft key until the required
arithmetic symbol appears; + (addition),
- (subtraction), (multiplication), / (division).
Organizer
112
3. Enter the second number.
4. To view the result, press the key.
5. Repeat steps 2 to 4 as many times as required.
Currency Exchange
(Menu 6.6)
Using this menu option, you can make currency
conversions.
1. Enter the current exchange rate of your source
currency and press the
OK
soft key.
You can insert a decimal point by pressing
the key
.
2. Enter the amount to convert and press the OK
soft key.
The amount you entered and its equivalent
value display.
3. Press the Exit soft key to exit the currency
convertor.
113
Network Services
These menu functions are network services. Please
contact your service provider to check their
availability and subscribe to them, if you wish.
Call Forwarding
(Menu 7.1)
This network service enables incoming calls to be
rerouted to the number that you specify.
Example:You may wish to forward your business
calls to a colleague while you are on
holiday.
Call forwarding can be set up in the following ways:
Forward Always: all calls are forwarded.
Busy: calls are forwarded when you are already on
another call.
No Reply: calls are forwarded when you do not
answer the phone.
Unreachable: calls are forwarded when you are
not in an area covered by your service provider.
Cancel All: all call forwarding options are canceled.
You can specify individual forwarding options for
each of the following call types:
•Voice calls only
• Data calls only
Network Services
114
To set your call forwarding options:
1. Select the type of call forwarding by pressing
the Up or Down key, and then press the Select
soft key.
2. Select the type of calls to be forwarded by
pressing the Up or Down key, and then press the
Select soft key.
The current status displays. If the option has
already been set, the number to which the calls
are forwarded displays.
4. Enter the number to which the calls are to be
forwarded and press the OK soft key.
To enter an international code, press the 0 key
until the + sign displays.
The phone sends your settings to the network
and the network’s acknowledgement displays.
You can deactivate all call forwarding settings by
selecting the Cancel All option.
3. To Press the
activate call
forwarding
Activate soft key.
Go to Step 4.
change the
call number
Change soft key.
Go to Step 4.
deactivate call
forwarding
Remove soft key.
Network Services
115
Call Waiting
(Menu 7.2)
This network service informs you when someone is
trying to reach you during another call.
You can specify individual call waiting options for
each of the following call types:
•Voice calls only
• Data calls only
To set your call waiting options:
1. Select the type of calls to which the call waiting
option is to be applied by pressing the Up or
Down key, and then press the Select soft key.
The screen informs you whether call waiting is
activated or deactivated.
2. You can activate or deactivate the call waiting
feature as necessary by using the Activate or
Deactivate soft key respectively.
To return to the previous screen, press the Exit
soft key.
You can also deactivate all call waiting settings by
selecting the Cancel All option.
Network Selection
(Menu 7.3)
The Network Selection feature enables you to
automatically or manually select the network used
when roaming outside of your home area.
Note
: You can select a network other than your home
network only if there is a valid roaming
agreement between them.
Network Services
116
To indicate to automatically or manually select the
network when roaming:
1. When Network Selection displays, press the
Select soft key.
2. Press the Up or Down key until the appropriate
option highlights and then press the OK soft
key.
If you select Automatic, you are connected to
the first available network when roaming.
If you select Manual, the phone scans for the
available networks. Go to Step 3.
3. Press the Up or Down key until the preferred
network highlights and then press the OK soft
key.
You are connected to that network.
Caller ID
(Menu 7.4)
You can prevent your phone number from being
displayed on the phone of the person being called.
Note
: Some networks do not allow the user to change
this setting.
The following options are available:
Default: the default setting provided by the
network is used.
Hide Number: your number does not display on
the other person’s phone.
Send Number: your number is sent each time you
make a call.
Network Services
117
Band Selection
(Menu 7.5)
For the phone to make and receive phone calls, it
must register with one of the available networks.
Your phone can handle either of the following types
of networks:
•GSM 900
•GSM 1800
• Combined GSM 900/1800
•GSM 1900
The country where you purchased your phone
determines the default band that it uses. When you
travel abroad, you must remember to change to an
appropriate band.
1. When Band Selection displays, press the
Select soft key.
2. Press the Up or Down key until the appropriate
option, GSM 900/1800 or GSM 1900,
highlights and press the OK soft key.
When you select a new band, your phone displays a
confirmation message and then automatically
searches for all of the available networks. Your
phone registers with a preferred network within the
band.
118
Funbox
The Funbox menu contains several fun options.
T-Zones
(Menu 8.1)
Your phone is equipped with a WAP (Wireless
Application Protocol) browser to allow you to access
and navigation the Wireless Web via your phone.
Home
(Menu 8.1.1)
Selecting this option connects the phone to the
network and loads the homepage of the Wireless
Web service provider. You can also press the
key in Idle Mode.
The content of the WAP Browser startup home page
depends on your Wireless Web service provider. To
scroll through the screen, use the Up and Down
keys.
Note
: To access the startup home page from any
other screen in the WAP browser, use the
Home
option. For further details about the
WAP Browser menus, see page 120.
Exiting the WAP Browser
To exit the browser at any time, simply press the
key.
Funbox
119
Navigating the WAP Browse
r
Entering Text in the WAP Browser
When you are prompted to enter text, the current
text entry mode is indicated on the screen.
For further details about each text input mode, see
page 41.
To Press the
scroll through and
select browser
items
Up or Down key until the
symbol points to the
required item, and then press
the OK soft key to confirm
the selection.
select a numbered
item
corresponding numeric key.
return to the
previous page
Back soft key or the
key.
return to the
startup homepage
key and select the Home
option. For further details
about this option, see
page 120.
To change
modes
press the key one or more
times.
To enter a
space
press the
key.
To edit text
➀ set the cursor to the right of
the character(s) to be
corrected.
➁ press the key as required.
➂ enter the correct character(s).
Funbox
120
Selecting and Using Browser Menu Options
Various menu options are available when you are
using the WAP Browser to navigate the Wireless
Web.
To access a menu option:
1. Press and hold the key.
A menu displays.
2. Highlight a menu option by pressing the Up or
Down key.
3. Select an option by pressing the Select soft key.
4. If necessary, select the secondary option using
the Up and Down keys, and press the Select
soft key to confirm.
Note
: The menus may vary, depending on your
version of the WAP browser.
The following menu options are available:
Reload: reloads the current page.
Home: takes you back at any time to the home
page of the Wireless Web service provider.
Go to URL: allows you to manually enter the URL
address of the required Web page. After entering an
address, press the OK
soft key to go there directly.
Show URL: displays the URL address of the site to
which you are currently connected. It also enables
you to set the current site as the startup home
page.
Funbox
121
Edit Home: allows you to change the startup home
page manually. Enter the required URL and press
the
OK
soft key. For further details about entering
text, see page 41.
Inbox: allows you to read messages received from
the web server.
Favorite
(Menu 8.1.2)
This option allows you to store the URL addresses of
your favorite web sites. You can access this menu
directly by pressing and holding the
key while
using the WAP browser.
To store a URL address:
1. Select an empty location and press the Options
soft key.
2. Enter the address and press the Enter
soft key.
3. Enter a name for the favorite item and press the
Enter soft key.
To Press the
set the current
page as your
startup home page
Option soft key, select the
Save to Home option and
press the
Select
soft key.
set a bookmark for
the current page
Option soft key, select the
Save to Bookmark option
and press the
Select
soft
key.
cancel your setting Back soft key.
Funbox
122
After saving favorite items, you can use the
following options by pressing the Options soft key:
Goto URL: quickly accesses you to the site.
Edit: allows you to edit the address.
Delete: deletes the address.
Clear Cache
(Menu 8.1.2)
You can clear the information stored in the cache,
the phone’s temporary memory which stores the
most recently accessed Web pages.
Press the Yes
soft key to confirm the deletion.
Otherwise, press the No
soft key.
Push Message
(Menu 8.1.3)
In this menu option, you can receive and access
web messages from the server.
The following options are available:
Inbox: allows you to read the messages received
from the web server.
Receive: allows you to set whether or not your
phone receives web messages.
Delete All: allows you to delete all of the web
messages.
Funbox
123
Downloads
(Menu 8.2)
You can download MIDlets (Java applications
running on mobile phones) from various sources
using the WAP Browser and store them in your
phone. You can view the list of MIDlets stored on
the Games & More screen.
Note
: Java services may be unavailable depending
upon the service provider.
Games & More
(Menu 8.2.1)
This menu option allows you to launch a MIDlet and
access various menu options.
Launching a MIDlet
To launch a MIDlet:
1. From the Downloads screen, select the Games
& More option.
2. Scroll to the MIDlet you want and press the
Launch soft key.
3. Start the MIDlet using the soft keys.
Using the Menus
From the Main Screen, press the Menu soft key to
access the following options. They are shown only
when a MIDlet has been downloaded:
Launch: launches the MIDlet.
Info: displays information about the MIDlet, such
as file size, application version, vendor, and location
of the jad file, which is the MIDlet description file.
Funbox
124
Remove: removes the MIDlet. When the
confirmation message appears, press the Remove
soft key. To cancel your selection, press the Cancel
soft key.
Update: accesses the server and updates the
MIDlet.
Application Setting: ???
About: shows the copyright information of the
MIDlet.
Entering Text
For entering text while using a MIDlet, the following
input modes are available:
Upper-case character (A): allows you to enter
upper-case English characters.
Lower-case character (a): allows you to enter
lower-case English characters.
Note
: In the upper/lower-case character mode, you
can enter
symbols
by pressing the
1 or 0 key
until the symbol you want displays
.
Number (1): allows you to enter numbers.
Symbol: allows you to enter symbols. After
highlighting a symbol by pressing the navigation
keys, press the key to insert it.
T9 ( ): allows you to enter English characters by
pressing one key per letter. In this mode, you can
change the case by pressing the 0 key.
To change the text input mode, press the key
until the appropriate indicator appears on the soft
key area of the display.
Funbox
125
Sounds
(Menu 8.2.2)
In this menu option, you can view the list of sounds
downloaded from the web server. You can set the
downloaded sounds as the current ring tone or send
them to other phones.
When the memory is full, a warning message
displays and the phone rejects additional sounds
until you delete the obsolete ones.
Pictures
(Menu 8.2.3)
In this menu option, you can view the list of
pictures downloaded from the web server. You can
set the downloaded pictures as the current
background image or send them to other phones.
When the memory is full, a warning message
displays and the phone rejects additional pictures
until you delete the obsolete ones.
126
Solving Problems
Before contacting the after-sales service, perform
the following simple checks. They may save you the
time and expense of an unnecessary service call.
When you switch your phone on, the
following messages may appear
Insert SIM Card
• Check that the SIM card is correctly installed.
Phone Locked Enter Password
•The automatic locking function has been enabled.
You must enter the phone’s password before you
can use the phone.
Enter PIN
•You are using your phone for the first time. You
must enter the Personal Identification Number
(PIN) supplied with the SIM card.
•The PIN Check feature is enabled. Every time the
phone is switched on, the PIN has to be entered.
To disable this feature, use the PIN Check menu
option (Menu 5.6.1).
Enter PUK
•The PIN code was entered incorrectly three times
in succession and the phone is now blocked.
Enter the PUK supplied by your network operator.
Solving Problems
127
“No service,” “Network failure” or “Not
done” displays
•The network connection was lost. You may be in a
weak signal area (in a tunnel or surrounded by
buildings). Move and try again.
•You are trying to access an option for which you
have not taken out a subscription with your
service provider. Contact the service provider for
further details.
You have entered a number but it was
not dialed
•Have you pressed the key?
• Are you accessing the right cellular network?
Your correspondent cannot reach you
•Is your phone switched on (the key pressed
for more than one second)?
• Are you accessing the right cellular network?
Your correspondent cannot hear you
speaking
•Have you switched off the microphone?
• Are you holding the phone close enough to your
mouth? The microphone is located at the bottom
of the phone.
Solving Problems
128
The phone starts beeping and
“**Warning** Low Battery” flashes on
the display
• The battery is insufficiently charged. Replace the
battery and recharge it.
The audio quality of the call is poor
•Check the signal strength indicator on the display
( ); the number of bars indicates the signal
strength from strong ( ) to weak ( ).
•Try moving the phone slightly or moving closer to
a window if you are in a building.
No number is dialed when you recall a
Phonebook entry
•Check that the number has been stored correctly,
by using the Phonebook Search feature.
•Re-store the number, if necessary.
If the above guidelines do not help you to solve
the problem, take a note of:
• the model and serial numbers of your phone
• your warranty details
• a clear description of the problem
Then contact your local dealer or Samsung after-
sales service.
129
Access Codes
There are several access codes that are used by
your phone and its SIM card. These codes help you
protect the phone against unauthorized use.
When requested for any of the codes explained
below, enter the appropriate code (displayed as
asterisks) and press the OK soft key. If you make a
mistake, press the key one or more times until
the incorrect digit is cleared and then continue
entering the correct code.
The access codes, except for the PUK and PUK2
codes can be changed using the Security menu
option (Menu 5.6). See page 95 for further details.
Important! Avoid using access codes resembling
emergency numbers, such as 911, so
that you do not dial an emergency
number accidentally.
Phone Password
The Phone Lock feature uses the phone password to
protect your phone against unauthorized use. The
phone password is supplied with the phone and is
preset to “00000000” at the factory.
To See
activate/deactivate the
Phone Lock feature
page 97
(Menu 5.6.3).
change the phone
password
page 96
(Menu 5.6.4).
Access Codes
130
PIN
The Personal Identification Number or PIN (4 to
8 digits) protects your SIM card against
unauthorized use. It is usually supplied with the
SIM card.
If you enter an incorrect PIN three times in
succession, the code is disabled and cannot be used
until you re-enable it by entering the PUK (see
below).
PUK
The 8-digit PUK (PIN Unblocking Key) is required to
change a disabled PIN. The PUK may be supplied
with the SIM card. If not, or you have lost it,
contact your service provider.
To re-enable your PIN:
1. Enter the PUK and press the OK soft key.
2. Enter a new PIN of your choice and press the OK
soft key.
3. When the Confirm New PIN message displays,
enter the same code again and press the OK
soft key.
If you enter an incorrect PUK ten times in
succession, the SIM card becomes invalid. Contact
your service provider for a new card.
To See
activate/deactivate the
PIN Check feature
page 96
(Menu 5.6.1).
change the PIN page 96
(Menu 5.6.2).
Access Codes
131
PIN2
The PIN2 (4 to 8 digits), supplied with some SIM
cards, is required to access specific functions, such
as setting the maximum cost of a call. These
functions are available if supported by your SIM
card.
If you enter an incorrect PIN2 three times in
succession, the code is disabled and you cannot
access the functions until you re-enable it by
entering the PUK2.
To change the PIN2, see page 98 (Menu 5.6.7).
PUK2
The 8-digit PUK2 (PIN Unblocking Key 2), supplied
with some SIM cards, is required to change a
disabled PIN2. If you lose the code, contact your
service provider.
To re-enable your PIN2:
1. Enter the PUK2 and press the OK soft key.
2. Enter a new PIN2 of your choice and press the
OK soft key.
3. When the Confirm PIN2 message displays,
enter the same code again and press the OK
soft key.
If you enter an incorrect PUK2 ten times in
succession, you will not be able to access the
functions requiring the PIN2. Contact your service
provider for a new card.
132
Health and Safety
Information
Exposure to Radio Frequency (RF)
Signals
Your wireless phone is a radio transmitter and
receiver. It is designed and manufactured not to
exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal
Communications Commission (FCC) of the U.S.
Government. These limits are part of
comprehensive guidelines and establish permitted
levels of RF energy for the general population. The
guidelines are based on the safety standards that
were developed by independent scientific
organizations through periodic and through
evaluation of scientific studies.
The standards include a substantial safety margin
designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless phones employs
a unit of measurement known as Specific
Absorption Rate (SAR). The SAR limit
recommended by the FCC is 1.6W/kg.
*
* In the U.S. and Canada, the SAR limit for mobile phones used by
the public is 1.6 watts/kg (W/kg) averaged over one gram of
tissue. The standard incorporates a substantial margin of safety
to give additional protection for the public and to account for any
variations in measurements.
Health and Safety Information
133
SAR tests are conducted using standard operating
positions specified by the FCC with the phone
transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is
determined at the highest certified power level, the
actual SAR level of the phone while operating can
be well below the maximum value. This is because
the phone is designed to operate at multiple power
levels so as to use only the power required to reach
the network. In general, the closer you are to a
wireless base station antenna, the lower the power
output of the phone.
Before a new model phone is available for sale to
the public, it must be tested and certified to the
FCC that it does not exceed the limit established by
the government-adopted requirement for safe
exposure. The tests are performed in positions and
locations (e.g., at the ear and worn on the body) as
required by the FCC for each model. While there
may be differences between the SAR levels of
various phones and at various positions, they all
meet the government requirement.
The FCC has granted an Equipment Authorization
for this model phone with all reported SAR levels
evaluated as in compliance with the FCC RF
exposure guidelines. SAR information on this model
phone is on file with the FCC and can be found
under the Display Grant section of http://
www.fcc.gov/oet/fccid after searching on FCC ID
printed in the label on the phone.
FCC certification information for this model phone is
attached separation paper.
Health and Safety Information
134
For Body Operation
This device was tested for typical body-worn operations
with the back of the phone kept 1.5 cm. from the body.
To maintain compliance with FCC RF exposure require-
ments, use only belt-clips, holsters or similar accessories
that maintain a 1.5 cm. separation distance between the
user's body and the back of the phone, including the
antenna. The use of belt-clips, holsters and similar
accessories should not contain metallic components in
its assembly. The use of accessories that do not satisfy
these requirements may not comply with FCC RF
exposure requirements, and should be avoided.
For more Information concerning exposure to radio
frequency signals, see the following websites:
Federal Communications Commission (FCC)
http://www.fcc.gov/rfsafety
Cellular Telecommunications Industry Association
(CTIA): http://www.wow-com.com
U.S.Food and Drug Administration (FDA)
http://www.fda.gov/cdrh/consumer
World Health Organization (WHO)
http://www.who.int/peh-emf/en
Health and Safety Information
135
Precautions When Using Batteries
•Never use any charger or battery that is damaged
in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network’s base
station, it uses less power; talk and standby time
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
• Battery charging time depends on the remaining
battery charge and the type of battery and
charger used. The battery can be charged and
discharged hundreds of times, but it will
gradually wear out. When the operation time
(talk time and standby time) is noticeably shorter
than normal, it is time to buy a new battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not in use,
disconnect it from the power source. Do not leave
the battery connected to a charger for more than
a week, since overcharging may shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling or
warming first.
• Do not leave the battery in hot or cold places,
such as in a car in summer or winter conditions,
as you will reduce the capacity and lifetime of the
battery. Always try to keep the battery at room
temperature. A phone with a hot or cold battery
may temporarily not work, even when the battery
is fully charged. Li-ion batteries are particularly
affected by temperatures below 0 °C (32 °F).
Health and Safety Information
136
•Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object (coin,
clip or pen) causes a direct connection between
the + and – terminals of the battery (metal strips
on the battery), for example when you carry a
spare battery in a pocket or bag. Short-circuiting
the terminals may damage the battery or the
object causing the short-circuiting.
•Dispose of used batteries in accordance with local
regulations. Always recycle. Do not dispose of
batteries in a fire.
Road Safety
Your wireless phone gives you the powerful ability
to communicate by voice, almost anywhere,
anytime. But an important responsibility
accompanies the benefits of wireless phones, one
that every user must uphold.
When driving a car, driving is your first
responsibility. When using your wireless phone
behind the wheel of a car, practice good common
sense and remember the following tips:
1. Get to know your wireless phone and its
features, such as speed dial and redial. If
available, these features help you to place your
call without taking your attention off the road.
2. When available, use a hands-free device. If
possible, add an extra layer of convenience and
safety to your wireless phone with one of the
many hands-free accessories available today.
Health and Safety Information
137
3. Position your wireless phone within easy reach.
Be able to access your wireless phone without
removing your eyes from the road. If you get an
incoming call at an inconvenient time, let your
voice mail answer it for you.
4. Let the person you are speaking with know you
are driving; if necessary, suspend the call in
heavy traffic or hazardous weather conditions.
Rain, sleet, snow, ice and even heavy traffic can
be hazardous.
5. Do not take notes or look up phone numbers
while driving. Jotting down a To Do list or
flipping through your phonebook takes your
attention away from your primary responsibility,
driving safely.
6. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan calls when your
car will be stationary. If you need to make a call
while moving, dial only a few numbers, check
the road and your mirrors, then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting. Make the
people with whom you are talking aware that
you are driving and suspend conversations that
have the potential to divert your attention from
the road.
8. Use your wireless phone to call for help. Dial the
emergency number in the case of fire, traffic
accident or medical emergencies. Remember, it
is a free call on your wireless phone!
9. Use your wireless phone to help others in
emergencies. If you see a car accident, crime in
progress or other serious emergency where
lives are in danger, call the emergency number,
as you would want others to do for you.
Health and Safety Information
138
10. Call roadside assistance or a special non-
emergency wireless assistance number when
necessary. If you see a broken-down vehicle
posing no serious hazard, a broken traffic
signal, a minor traffic accident where no one
appears injured, or a vehicle you know to be
stolen, call roadside assistance or any other
special non-emergency wireless number.
Operating Environment
Remember to follow any special regulations in force
in any area and always switch off your phone
whenever it is forbidden to use it, or when it may
cause interference or danger.
When connecting the phone or any accessory to
another device, read its user’s guide for detailed
safety instructions. Do not connect incompatible
products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation
of the equipment and for the safety of personnel, it
is recommended that the equipment should only be
used in the normal operating position (held to your
ear with the antenna pointing over your shoulder).
Health and Safety Information
139
Electronic Devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against
the RF signals from your wireless phone. Consult
the manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be
maintained between a wireless phone and a
pacemaker to avoid potential interference with the
pacemaker. These recommendations are consistent
with the independent research and
recommendations of Wireless Technology Research.
Persons with pacemakers:
• should always keep the phone more than 15 cm
(6 inches) from their pacemaker when the phone
is switched on
• should not carry the phone in a breast pocket
• should use the ear opposite the pacemaker to
minimize potential interference
If you have any reason to suspect that interference
is taking place, switch off your phone immediately.
Hearing Aids
Some digital wireless phones may interfere with
some hearing aids. In the event of such
interference, you may wish to consult your hearing
aid manufacturer to discuss alternatives.
Health and Safety Information
140
Other Medical Devices
If you use any other personal medical devices,
consult the manufacturer of your device to
determine if it is adequately shielded from external
RF energy. Your physician may be able to assist you
in obtaining this information. Switch off your phone
in health care facilities when any regulations posted
in these areas instruct you to do so. Hospitals or
health care facilities may be using equipment that
could be sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle.
You should also consult the manufacturer of any
equipment that has been added to your vehicle.
You should also consult the manufacturer of any
equipment that has been added to your vehicle.
Posted Facilities
Switch off your phone in any facility where posted
notices require you to do so.
Health and Safety Information
141
Potentially Explosive Atmospheres
Switch off your phone when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause
an explosion or fire resulting in bodily injury or even
death.
Users are advised to switch off the phone while at a
refueling point (service station). Users are
reminded of the need to observe restrictions on the
use of radio equipment in fuel depots (fuel storage
and distribution areas), chemical plants or where
blasting operations are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas
(such as propane or butane), areas where the air
contains chemicals or particles, such as grain, dust
or metal powders, and any other area where you
would normally be advised to turn off your vehicle
engine.
Health and Safety Information
142
Emergency Calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well
as user-programmed functions, which cannot
guarantee connection in all conditions. Therefore,
you should never rely solely on any wireless phone
for essential communications (medical
emergencies, for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not
be possible on all wireless phone networks or when
certain network services and/or phone features are
in use. Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location (for example, 999 or other official
emergency number). Emergency numbers vary
by location.
3. Press the key.
If certain features are in use (call barring, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult this document and your local cellular
service provider.
When making an emergency call, remember to give
all the necessary information as accurately as
possible. Remember that your phone may be the
only means of communication at the scene of an
accident; do not cut off the call until given
permission to do so.
Health and Safety Information
143
Other Important Safety Information
•Only qualified personnel should service the phone
or install the phone in a vehicle. Faulty
installation or service may be dangerous and may
invalidate any warranty applicable to the device.
• Check regularly that all wireless phone
equipment in your vehicle is mounted and
operating properly.
•Do not store or carry flammable liquids, gases or
explosive materials in the same compartment as
the phone, its parts or accessories.
•For vehicles equipped with an air bag, remember
that an air bag inflates with great force. Do not
place objects, including both installed or portable
wireless equipment in the area over the air bag or
in the air bag deployment area. If wireless
equipment is improperly installed and the air bag
inflates, serious injury could result.
•Switch off your phone before boarding an aircraft.
The use of wireless phones in aircraft may be
dangerous to the operation of the aircraft, and is
illegal.
•Failure to observe these instructions may lead to
the suspension or denial of telephone services to
the offender, or legal action, or both.
Health and Safety Information
144
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for
many years
•Keep the phone and all its parts and accessories
out of the reach of small children’s.
•Keep the phone dry. Precipitation, humidity and
liquids contain minerals that will corrode
electronic circuits.
•Do not touch the phone with a wet hand while it
is charging. Doing so may cause an electric shock
to you or damage to the phone.
• Do not use or store the phone in dusty, dirty
areas, as its moving parts may be damaged.
•Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the
phone, which may damage the phone’s electronic
circuit boards.
•Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
•Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the phone. Wipe it
with a soft cloth slightly dampened in a mild
soap-and-water solution.
Health and Safety Information
145
• Do not paint the phone. Paint can clog the
device’s moving parts and prevent proper
operation.
• Do not put the phone in or on heating devices,
such as a microwave oven, a stove or a radiator.
The phone may explode when overheated.
• Use only the supplied or an approved
replacement antenna. Unauthorized antennas or
modified accessories may damage the phone and
violate regulations governing radio devices.
•If the phone, battery, charger or any accessory is
not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
Acknowledging Special Precautions and
the FCC and Industry Canada Notice
Cautions
Modifications not expressly approved by the party
responsible for compliance could void the user's
authority to operate the equipment.
FCC Compliance Information
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference,
and
2. This device must accept any interference
received.
Including interference that may cause undesired
operation.
Health and Safety Information
146
Information to User
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation.
This equipment generates, uses and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by one
or more of the following measures:
•Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
•Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/ TV
technician for help.
Appendix A: CERTIFICATION INFORMATION (SAR)
147
Appendix A: CERTIFICATION
INFORMATION (SAR)
THIS MODEL PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and
receiver. It is designed and manufactured not to
exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal
Communications Commission of the U.S.
Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF
energy for the general population. The guidelines are
based on safety standards that were developed by
independent scientific organizations through periodic
and thorough evaluation of scientific studies. The
standards include a substantial safety margin
designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless mobile phones
employs a unit of measurement known as the
Specific Absorption Rate (SAR). The SAR limit set by
the FCC is 1.6 W/kg. SAR Tests are conducted using
standard operating positions accepted by the FCC
with the phone transmitting at its highest certified
power level in all tested frequency bands. Although
the SAR is determined at the highest certified power
level, the actual SAR level of the phone while
operating can be well below the maximum value.
This is because the phone is designed to operate at
multiple power levels so as to use only the power
required to reach the network. In general, the closer
you are to a wireless base station antenna, the lower
the power output.
Appendix A: CERTIFICATION INFORMATION (SAR)
148
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that
it does not exceed the limit established by the
government-adopted requirement for safe exposure.
The tests are performed in positions and
locations(e.g., at the ear and worn on the body) as
required by the FCC for each model.
The highest SAR values for this model phone as
reported to the FCC are Head: 0.491W/Kg, Body-worn:
0.38W/Kg.
The FCC has granted an Equipment Authorization for
this model phone with all reported SAR levels
evaluated as in compliance with the FCC RF exposure
guidelines. SAR information on this model phone is
on file with the FCC and can be found under the
Display Grant section of
http://www.fcc.gov/oet/fccid after searching on FCC
ID A3LSGHX105.
In the United States and Canada, the SAR limit for mobile
phones used by the public is 1.6 watts/kilogram (W/kg)
averaged over one gram of tissue. The standard incorporates a
substantial margin of safety to give additional protection for the
public and to account for any variations in measurements.
Appendix B: Guide to Safe and Responsible Wireless
149
Appendix B: Guide to Safe and
Responsible Wireless Phone Use
Cellular Telecommunications & Internet Association
“Safety is the most important call you will ever
make.”
A Guide to Safe and Responsible Wireless
Phone Use
TENS OF MILLIONS OF PEOPLE IN THE U.S. TODAY
TAKE ADVANTAGE OF THE UNIQUE COMBINATION
OF CONVENIENCE, SAFETY AND VALUE DELIVERED
BY THE WIRELESS TELEPHONE. QUITE SIMPLY, THE
WIRELESS PHONE GIVES PEOPLE THE POWERFUL
ABILITY TO COMMUNICATE BY VOICE-ALMOST
ANYWHERE, ANYTIME-WITH THE BOSS, WITH A
CLIENT, WITH THE KIDS, WITH EMERGENCY
PERSONNEL OR EVEN WITH THE POLICE. EACH
YEAR, AMERICANS MAKE BILLIONS OF CALLS FROM
THEIR WIRELESS PHONES, AND THE NUMBERS ARE
RAPIDLY GROWING.
But an important responsibility accompanies those
benefits, one that every wireless phone user must
uphold. When driving a car, driving is your first
responsibility. A wireless phone can be an invaluable
tool, but good judgment must be exercised at all
times while driving a motor vehicle-whether on the
phone or not. The basic lessons are ones we all
learned as teenagers. Driving requires alertness,
caution and courtesy. It requires a heavy dose of
basic common sense-keep your head up, keep your
eyes on the road, check your mirrors frequently and
watch out for other drivers. It requires obeying all
traffic signs and signals and staying within the speed
limit. It means using seat belts and requiring other
passengers to do the same.
Appendix B: Guide to Safe and Responsible Wireless
150
But with wireless phone use, driving safely means a
little more. This brochure is a call to wireless phone
users everywhere to make safety their first priority
when behind the wheel of a car. Wireless
telecommunications is keeping us in touch,
simplifying our lives, protecting us in emergencies
and providing opportunities to help others in need.
When it comes to the use of wireless phones, safety
is your most important call.
Wireless Phone “Safety Tips”
Below are safety tips to follow while driving and
using a wireless phone which should be easy to
remember:
1. Get to know your wireless phone and its features
such as speed dial and redial. Carefully read your
instruction manual and learn to take advantage of
valuable features most phones offer, including
automatic redial and memory. Also, work to
memorize the phone keypad so you can use the
speed dial function without taking your attention
off the road.
2. When available, use a hands free device. A
number of hands free wireless phone accessories
are readily available today. Whether you choose
an installed mounted device for your wireless
phone or a speaker phone accessory, take
advantage of these devices if available to you.
3. Position your wireless phone within easy reach.
Make sure you place your wireless phone within
easy reach and where you can grab it without
removing your eyes from the road. If you get an
incoming call at an inconvenient time, if possible,
let your voice mail answer it for you.
Appendix B: Guide to Safe and Responsible Wireless
151
4. Suspend conversations during hazardous driving
conditions or situations. Let the person you are
speaking with know you are driving; if necessary,
suspend the call in heavy traffic or hazardous
weather conditions. Rain, sleet, snow and ice can
be hazardous, but so is heavy traffic. As a driver,
your first responsibility is to pay attention to the
road.
5. Do not take notes or look up phone numbers
while driving. If you are reading an address book
or business card, or writing a “to do” list while
driving a car, you are not watching where you are
going. It’s common sense. Don’t get caught in a
dangerous situation because you are reading or
writing and not paying attention to the road or
nearby vehicles.
6. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan your calls before
you begin your trip or attempt to coincide your
calls with times you may be stopped at a stop
sign, red light or otherwise stationary. But if you
need to dial while driving, follow this simple tip-
dial only a few numbers, check the road and your
mirrors, then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting. Stressful
or emotional conversations and driving do not
mix-they are distracting and even dangerous
when you are behind the wheel of a car. Make
people you are talking with aware you are driving
and if necessary, suspend conversations which
have the potential to divert your attention from
the road.
Appendix B: Guide to Safe and Responsible Wireless
152
8. Use your wireless phone to call for help. Your
wireless phone is one of the greatest tools you
can own to protect yourself and your family in
dangerous situations-with your phone at your
side, help is only three numbers away. Dial 9-1-1
or other local emergency number in the case of
fire, traffic accident, road hazard or medical
emergency. Remember, it is a free call on your
wireless phone!
9. Use your wireless phone to help others in
emergencies. Your wireless phone provides you a
perfect opportunity to be a “Good Samaritan” in
your community. If you see an auto accident,
crime in progress or other serious emergency
where lives are in danger, call 9-1-1 or other local
emergency number, as you would want others to
do for you.
10.Call roadside assistance or a special wireless non-
emergency assistance number when neceµssary.
Certain situations you encounter while driving
may require attention, but are not urgent enough
to merit a call for emergency services. But you
still can use your wireless phone to lend a hand.
If you see a broken-down vehicle posing no
serious hazard, a broken traffic signal, a minor
traffic accident where no one appears injured or a
vehicle you know to be stolen, call roadside
assistance or other special non-emergency
wireless number.
Careless, distracted individuals and people driving
irresponsibly represent a hazard to everyone on the
road. Since 1984, the Cellular Telecommunications
Industry Association and the wireless industry have
conducted educational outreach to inform wireless
phone users of their responsibilities as safe drivers
and good citizens. As we approach a new century,
more and more of us will take advantage of the
benefits of wireless telephones. And, as we take to
the roads, we all have a responsibility to drive safely.
Appendix C: Consumer Update on Wireless Phones
153
“The wireless industry reminds you to use your
phone safely when driving.”
Cellular Telecommunications & Internet Association
For more information, please call 1-888-901-SAFE.
For updates: http://www.wow-com.com/consumer/
issues/driving/articles.cfm?ID=85
Appendix C: Consumer Update on
Wireless Phones
U.S. Food and Drug Administration
1. What kinds of phones are the subject of this
update?
The term wireless phone refers here to hand-held
wireless phones with built-in antennas, often called
cell, mobile, or PCS phones. These types of wireless
phones can expose the user to measurable radio
frequency energy (RF) because of the short distance
between the phone and the user s head. These RF
exposures are limited by Federal Communications
Commission safety guidelines that were developed
with the advice of FDA and other federal health and
safety agencies. When the phone is located at
greater distances from the user, the exposure to RF
is drastically lower because a person’s RF exposure
decreases rapidly with increasing distance from the
source. The so-called “cordless phones,” which have
a base unit connected to the telephone wiring in a
house, typically operate at far lower power levels,
and thus produce RF exposures well within the FCC’s
compliance limits.
Appendix C: Consumer Update on Wireless Phones
154
2. Do wireless phones pose a health hazard?
The available scientific evidence does not show that
any health problems are associated with using
wireless phones. There is no proof, however, that
wireless phones are absolutely safe. Wireless phones
emit low levels of radio frequency energy (RF) in the
microwave range while being used. They also emit
very low levels of RF when in the stand-by mode.
Whereas high levels of RF can produce health effects
(by heating tissue), exposure to low level RF that
does not produce heating effects causes no known
adverse health effects. Many studies of low level RF
exposures have not found any biological effects.
Some studies have suggested that some biological
effects may occur, but such findings have not been
confirmed by additional research. In some cases,
other researchers have had difficulty in reproducing
those studies, or in determining the reasons for
inconsistent results.
3. What is FDA’s role concerning the safety of
wireless phones?
Under the law, FDA does not review the safety of
radiation-emitting consumer products such as
wireless phones before they can be sold, as it does
with new drugs or medical devices. However, the
agency has authority to take action if wireless
phones are shown to emit radio frequency energy
(RF) at a level that is hazardous to the user. In such
a case, FDA could require the manufacturers of
wireless phones to notify users of the health hazard
and to repair, replace or recall the phones so that the
hazard no longer exists.
Although the existing scientific data do not justify
FDA regulatory actions, FDA has urged the wireless
phone industry to take a number of steps, including
the following:
Appendix C: Consumer Update on Wireless Phones
155
Support needed research into possible biological
effects of RF of the type emitted by wireless phones;
Design wireless phones in a way that minimizes any
RF exposure to the user that is not necessary for
device function; and
Cooperate in providing users of wireless phones with
the best possible information on possible effects of
wireless phone use on human health
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at
the federal level. The following agencies belong to
this working group:
National Institute for Occupational Safety and Health
Environmental Protection Agency
Federal Communications Commission
Occupational Safety and Health Administration
National Telecommunications and Information
Administration
The National Institutes of Health participates in some
interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless
phones with the Federal Communications
Commission (FCC). All phones that are sold in the
United States must comply with FCC safety
guidelines that limit RF exposure. FCC relies on FDA
and other health agencies for safety questions about
wireless phones.
FCC also regulates the base stations that the wireless
phone networks rely upon. While these base stations
operate at higher power than do the wireless phones
themselves, the RF exposures that people get from
these base stations are typically thousands of times
lower than those they can get from wireless phones.
Base stations are thus not the primary subject of the
safety questions discussed in this document.
Appendix C: Consumer Update on Wireless Phones
156
4. What is FDA doing to find out more about the
possible health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology
Program and with groups of investigators around the
world to ensure that high priority animal studies are
conducted to address important questions about the
effects of exposure to radio frequency energy (RF).
FDA has been a leading participant in the World
Health Organization International Electromagnetic
Fields (EMF) Project since its inception in 1996. An
influential result of this work has been the
development of a detailed agenda of research needs
that has driven the establishment of new research
programs around the world. The Project has also
helped develop a series of public information
documents on EMF issues.
FDA and the Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative
Research and Development Agreement (CRADA) to
do research on wireless phone safety. FDA provides
the scientific oversight, obtaining input from experts
in government, industry, and academic
organizations. CTIA-funded research is conducted
through contracts to independent investigators. The
initial research will include both laboratory studies
and studies of wireless phone users. The CRADA will
also include a broad assessment of additional
research needs in the context of the latest research
developments around the world.
Appendix C: Consumer Update on Wireless Phones
157
5. What steps can I take to reduce my exposure to
radio frequency energy from my wireless phone?
If there is a risk from these products—and at this
point we do not know that there is—it is probably
very small. But if you are concerned about avoiding
even potential risks, you can take a few simple steps
to minimize your exposure to radio frequency energy
(RF). Since time is a key factor in how much
exposure a person receives, reducing the amount of
time spent using a wireless phone will reduce RF
exposure.
If you must conduct extended conversations by
wireless phone every day, you could place more
distance between your body and the source of the
RF, since the exposure level drops off dramatically
with distance. For example, you could use a headset
and carry the wireless phone away from your body or
use a wireless phone connected to a remote antenna
Again, the scientific data do not demonstrate that
wireless phones are harmful. But if you are
concerned about the RF exposure from these
products, you can use measures like those described
above to reduce your RF exposure from wireless
phone use.
6. What about children using wireless phones?
The scientific evidence does not show a danger to
users of wireless phones, including children and
teenagers. If you want to take steps to lower
exposure to radio frequency energy (RF), the
measures described above would apply to children
and teenagers using wireless phones. Reducing the
time of wireless phone use and increasing the
distance between the user and the RF source will
reduce RF exposure.
Appendix C: Consumer Update on Wireless Phones
158
Some groups sponsored by other national
governments have advised that children be
discouraged from using wireless phones at all. For
example, the government in the United Kingdom
distributed leaflets containing such a
recommendation in December 2000. They noted that
no evidence exists that using a wireless phone
causes brain tumors or other ill effects. Their
recommendation to limit wireless phone use by
children was strictly precautionary; it was not based
on scientific evidence that any health hazard exists.
7. Do hands-free kits for wireless phones reduce
risks from exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason
to believe that hands-free kits reduce risks. Hands-
free kits can be used with wireless phones for
convenience and comfort. These systems reduce the
absorption of RF energy in the head because the
phone, which is the source of the RF emissions, will
not be placed against the head. On the other hand, if
the phone is mounted against the waist or other part
of the body during use, then that part of the body
will absorb more RF energy. Wireless phones
marketed in the U.S. are required to meet safety
requirements regardless of whether they are used
against the head or against the body. Either
configuration should result in compliance with the
safety limit.
Appendix C: Consumer Update on Wireless Phones
159
8. Do wireless phone accessories that claim to
shield the head from RF radiation work?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason
to believe that accessories that claim to shield the
head from those emissions reduce risks. Some
products that claim to shield the user from RF
absorption use special phone cases, while others
involve nothing more than a metallic accessory
attached to the phone. Studies have shown that
these products generally do not work as advertised.
Unlike “hand-free” kits, these so-called “shields” may
interfere with proper operation of the phone. The
phone may be forced to boost its power to
compensate, leading to an increase in RF absorption.
In February 2002, the Federal trade Commission
(FTC) charged two companies that sold devices that
claimed to protect wireless phone users from
radiation with making false and unsubstantiated
claims. According to FTC, these defendants lacked a
reasonable basis to substantiate their claim.
9. What about wireless phone interference with
medical equipment?
Radio frequency energy (RF) from wireless phones
can interact with some electronic devices. For this
reason, FDA helped develop a detailed test method
to measure electromagnetic interference (EMI) of
implanted cardiac pacemakers and defibrillators from
wireless telephones. This test method is now part of
a standard sponsored by the Association for the
Advancement of Medical instrumentation (AAMI).
The final draft, a joint effort by FDA, medical device
manufacturers, and many other groups, was
completed in late 2000. This standard will allow
manufacturers to ensure that cardiac pacemakers
and defibrillators are safe from wireless phone EMI.
Appendix C: Consumer Update on Wireless Phones
160
FDA has tested hearing aids for interference from
handheld wireless phones and helped develop a
voluntary standard sponsored by the Institute of
Electrical and Electronic Engineers (IEEE). This
standard specifies test methods and performance
requirements for hearing aids and wireless phones so
that no interference occurs when a person uses a
compatible phone and a compatible hearing aid at
the same time. This standard was approved by the
IEEE in 2000.
FDA continues to monitor the use of wireless phones
for possible interactions with other medical devices.
Should harmful interference be found to occur, FDA
will conduct testing to assess the interference and
work to resolve the problem.
10.What are the results of the research done
already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws
in their research methods. Animal experiments
investigating the effects of radio frequency energy
(RF) exposures characteristic of wireless phones
have yielded conflicting results that often cannot be
repeated in other laboratories. A few animal studies,
however, have suggested that low levels of RF could
accelerate the development of cancer in laboratory
animals. However, many of the studies that showed
increased tumor development used animals that had
been genetically engineered or treated with cancer-
causing chemicals so as to be pre-disposed to
develop cancer in the absence of RF exposure. Other
studies exposed the animals to RF for up to 22 hours
per day. These conditions are not similar to the
conditions under which people use wireless phones,
so we don t know with certainty what the results of
such studies mean for human health.
Appendix C: Consumer Update on Wireless Phones
161
Three large epidemiology studies have been
published since December 2000. Between them, the
studies investigated any possible association
between the use of wireless phones and primary
brain cancer, gioma, meningioma, or acoustic
neuroma, tumors of the brain or salivary gland,
leukemia, or other cancers. None of the studies
demonstrated the existence of any harmful health
effects from wireless phone RF exposures. However,
none of the studies can answer questions about long-
term exposures, since the average period of phone
use in these studies was around three years.
11.What research is needed to decide whether RF
exposure from wireless phones poses a health
risk?
A combination of laboratory studies and
epidemiological studies of people actually using
wireless phones would provide some of the data that
are needed. Lifetime animal exposure studies could
be completed in a few years. However, very large
numbers of animals would be needed to provide
reliable proof of a cancer promoting effect if one
exists. Epidemiological studies can provide data that
is directly applicable to human populations, but 10 or
more years follow-up may be needed to provide
answers about some health effects, such as cancer.
This is because the interval between the time of
exposure to a cancer-causing agent and the time
tumors develop - if they do - may be many, many
years. The interpretation of epidemiological studies is
hampered by difficulties in measuring actual RF
exposure during day-to-day use of wireless phones.
Many factors affect this measurement, such as the
angle at which the phone is held, or which model of
phone is used.
Appendix C: Consumer Update on Wireless Phones
162
12.Which other federal agencies have
responsibilities related to potential RF health
effects?
Additional information on the safety of RF exposures
from various sources can be obtained from the
following organizations.
FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
Occupational Safety and Health Administration’s
(OSHA):
http://www.osha-slc.gov/SLTC/
radiofrequencyradiation/index.html
National Institute for Occupational Safety and Health
(NIOSH):
http://www.cdc.gov/niosh/emfpg.html
World health Organization (WHO):
http://www.who.int/peh-emf/
International Commission on Non-Ionizing Radiation
Protection:
http://www.icnirp.de
National Radiation Protection Board (UK):
http://www.nrpb.org.uk
163
Glossary
To help you understand the main technical terms
and abbreviations used in this booklet and take full
advantage of the features on your mobile phone,
here are a few definitions.
Active Flip
Ability to answer a call simply by opening the
phone.
Call Barring
Ability to restrict outgoing and incoming calls.
Call Forwarding
Ability to reroute calls to another number.
Call Holding
Ability to put one call on standby while answering or
making another call; you can then switch between
the two calls, as required.
Call Waiting
Ability to inform users that they have an incoming
call when engaged on another call.
Caller Line Identification Services (Caller ID)
Services allowing subscribers to view or block the
telephone numbers of callers.
Glossary
164
GPRS (General Packet Radio Service)
New non-voice value-added service that allows
information to be sent and received across a mobile
telephone network. GPRS guaranties continuous
connection to the Internet for mobile phone and
computer users. It is based on the Global System
for Mobile Communication (GSM) circuit-switched
cellular phone connections and the Short Message
Service (SMS).
GSM (Global System for Mobile
Communication)
International standard for cellular communication,
guaranteeing compatibility between the various
network operators. GSM covers most European
countries and many other parts of the world.
Java
Programming language generating applications that
can run on all hardware platforms, whether small,
medium or large, without modification. It has been
promoted for and geared heavily to the Web, both
for public Web sites and Intranets. When a Java
program runs from a Web page, it is called a Java
applet. When it is run on a mobile phone or pager, it
is called a MIDlet.
Glossary
165
MMS (Multimedia Message Service)
A message service for the mobile environment,
standardized by the WAP Forum and the 3rd
Generation Partnership Program (3GPP). For phone
users, MMS is similar to Short Message Service
(SMS)-it provides automatic, immediate delivery of
user-created content from phone to phone. The
message addressing used is primarily phone
numbers, thus the traffic goes from phone to
phone. MMS also provides support for e-mail
addressing, so that messages can also be sent by
e-mail. In addition to the text content of SMS, MMS
messages can contain still images, voice or audio
clips, and later also video clips and presentation
information.
Multi-party Calling
Ability to establish a conference call involving up to
five additional people.
Phone Password
Security code used to unlock the phone when you
have selected the option to lock it automatically
each time it switches on.
PIN (Personal Identification Number)
Security code that protects the phone against
unauthorized use. The PIN is supplied by the
service provider with the SIM card. It may be a four
to eight-digit number and can be changed, as
required.
Glossary
166
PUK (PIN Unblocking Key)
Security code used to unlock the phone when an
incorrect PIN has been entered three times in
succession. The eight-digit number is supplied by
the service provider with the SIM card.
Roaming
Use of your phone when you are outside your home
area (when traveling for example).
SDN (Service Dialing Numbers)
Telephone numbers supplied by your network
provider and giving access to special services, such
as voice mail, directory inquiries, customer support
and emergency services.
SIM (Subscriber Identification Module)
Card containing a chip with all the information
required to operate the phone (network and
memory information, as well as the subscriber’s
personal data). The SIM card fits into a small slot
on the back of the phone and is protected by the
battery.
SMS (Short Message Service)
Network service sending and receiving messages to
and from another subscriber without having to
speak to the correspondent. The message created
or received can be displayed, received, edited or
sent.
Glossary
167
Soft Keys
Two keys marke
d and
on the phone, the
purpose of which:
•varies according to the function that you are
currently using.
•is indicated on the bottom line of the display just
above the corresponding key.
Tri Band
Ability to handle any of the following types of
network; GSM 900, GSM 1800, combined GSM 900/
1800 and GSM 1900 MHz bands, for greater call
success and wider roaming.
Your phone automatically searches for the last
network used. If, for any reason, this network is
unavailable, your phone will attempt to register
onto a different network.
Voice Mail
Computerized answering service that automatically
answers your calls when you are not available,
plays a greeting (optionally in your own voice) and
records a message.
168
Index
A
Access codes •
129
Accessories •
9
Alarm, set (6.4) •
110
Alert type, set (4.3) •
90
Alphabet mode •
44
Anykey Answer, set •
101
Auto light, set •
99
Auto redial, set •
101
Autopower alarm •
111
B
Background image •
93
Backlight •
15
,
99
Band selection (7.5) •
117
Battery
charging •
18
installing •
17
low battery indicator •
19
precaution •
135
removing •
16
Brightness, display •
99
Broadcast, messages (1.9)
71
Browser, WAP •
118
C
Calculator (6.5) •
111
Calendar (6.1) •
103
Caller ID (7.4) •
116
Calls
cost (3.6) •
87
emergency •
142
ending •
23
holding •
47
incoming (3.2) •
85
international •
22
making •
22
missed •
25
,
85
multi-party •
51
outgoing (3.3) •
86
records (3) •
85
redialing automatically •
101
time (3.5) •
87
via phonebook •
34
waiting •
50
waiting•
115
Card, SIM
installing •
16
locking •
98
Care •
144
CB messages •
71
Changing
password (5.6.4) •
97
PIN (5.6.2) •
96
PIN2 (5.6.7) •
98
Characters
changing mode •
42
entering •
41
Conference call •
51
Connect tone •
92
Copying
memos •
105
phonebook numbers •
33
tasks •
108
Cost of call •
87
Currency exchange (6.6) •
112
D
Date setting (6.3.2) •
109
Deleting
all call records •
86
all memos •
103
all messages •
69
,
83
all objects •
68
all phonebook •
39
all tasks •
108
memos •
105
missed calls •
26
,
85
objects •
68
phonebook numbers •
33
received messages •
61
,
77
sent messages •
62
,
78
tasks •
108
Dialed calls •
86
Index
169
Display
brightness •
99
icons •
14
language, change •
95
layout •
13
Draft, picture messages •
79
E
Earpiece volume •
24
Editing
memos •
105
missed calls •
26
,
85
phonebook numbers •
33
tasks •
107
to do list •
106
Emergency calls •
142
EOTD •
73
Error tone •
92
F
FDN mode (5.6.6) •
98
Fixed Dial Number mode •
98
Fun Box (8) •
118
Functions, select •
28
G
Games •
123
Graphic logo •
100
Greeting message (5.3) •
94
Groups, caller •
36
I
Icons, description •
14
Inbox
picture message •
75
text message •
60
Incoming calls (3.2) •
85
Infrared Activate (5.1) •
93
Internet •
118
IrDA port •
93
J
Java service •
123
K
Key lock
auto •
94
manual •
21
Keypad tones
selecting •
90
sending/muting •
49
volume, adjust •
24
Keys
description •
11
location •
10
shortcut •
102
L
Language (5.5) •
95
Last number, redial •
23
Length of calls •
87
,
92
Letters
changing mode •
42
entering •
41
Light
backlight •
15
,
99
service •
15
,
100
Location, setting •
73
Locking
phone (5.6.3) •
97
SIM card (5.6.5) •
98
Low battery indicator •
19
M
Maintenance •
144
Memory status
phonebook •
40
text message •
69
Memos
copying •
105
deleting •
105
viewing •
105
writing •
104
Index
170
Menus
accessing by scroll •
53
accessing by shortcuts •
54
list •
54
Message tone (4.5) •
91
Messages
broadcast
71
greeting
94
MMS •
75
picture •
75
SMS •
60
voice •
70
Microphone, mute •
48
MIDlet, launch •
123
Minute minder •
92
Missed calls (3.1) •
25
,
85
Morning call •
110
Multimedia messages •
75
Multi-party calls
dropping •
52
making •
51
private conversation •
51
Muting
all sounds •
48
key tones •
49
microphone •
48
N
Names
entering •
41
searching/dialing •
34
storing •
30
Network selection (7.3) •
115
Network services (7) •
113
Numbers
copying phonebook •
33
deleting •
33
fixed dial •
98
own •
95
pasting phonebook •
33
searching/dialing •
34
storing •
30
O
Options, select •
28
Organizer (6) •
103
Outbox
picture message •
78
text message •
62
Outgoing calls (3.3) •
86
Own number (5.4) •
95
P
Password
phone
changing •
97
description •
129
Phone
lock (5.6.3) •
97
password •
129
settings (6) •
93
switching on/off •
20
Phonebook
copying •
33
deleting •
33
editing •
33
options •
33
pasting •
33
searching/dialing •
34
speed-dialing •
37
storing numbers/names
•
30
Picture messages
deleting all •
83
draft •
79
reading
75
sending •
79
setting •
80
templates •
83
PIN
changing •
96
checking •
96
description •
130
PIN2
changing •
98
description •
131
Problems, solve •
126
PUK •
130
PUK2 •
131
Index
171
R
Received calls •
85
Received messages
picture •
75
text •
60
Redialing
automatically •
101
last number •
23
Reset settings (5.10) •
102
Ring
tone (4.1) •
89
type, alert (4.3) •
90
volume (4.2) •
89
Roaming •
115
S
Safety
information •
132
precautions •
7
Schedule •
103
Selecting functions/options •
28
Sent messages
picture •
78
text •
62
Service light •
15
,
100
Shortcut (5.9) •
102
Silent mode •
28
SIM card
installing •
16
locking •
98
SIM Lock (5.6.5) •
98
SMS message •
50
,
60
Soft keys, use •
28
Sound settings (4) •
89
Speed-dialing •
37
Switching on/off
microphone •
48
phone •
20
T
T9 mode •
43
Tasks, to do list
creating •
106
editing •
106
Templates
picture •
83
text •
66
Text
changing mode •
42
entering •
41
Text messages
memory status •
69
reading •
60
,
62
sending •
63
setting •
66
templates •
66
Time
call •
87
format (6.3.4) •
109
setting (6.3.1) •
109
world (6.3.3) •
109
To do list (6.2) •
106
Tone
connect •
92
error •
92
keypad •
90
message •
91
ring •
89
Travel adapter •
18
V
Vibration •
90
Voice mail (1.8) •
70
Voice server •
70
Volume, adjust
earpiece •
24
keypad tone •
24
ring •
89
W
Waiting call •
115
Wallpaper •
93
WAP Browser (8.1) •
118
World time (6.3.3) •
109
172
173
Access
the Menu
Functions
➀Press the
Menu
soft key.
➁Scroll with the Up and
Down keys through the
list of the menus until you
reach the required menu.
➂Press the
Select
soft key.
➃Scroll with the Up and
Down keys through the
list of the options until the
required one is selected.
➄Press the
Select
soft key.
Each of the two soft keys ( and )
perform the function indicated by the
text above it, on the bottom line of the
display.
Switch On/
Off
Press and hold the
key.
Make a Call ➀Key in the number.
➁Press the key.
End a Call Briefly press the key.
View Missed
Calls
Immediately
after Missing
Them
➀Press the
View
soft
key.
➁Scroll with the Up and
Down keys through the
missed calls.
➂To return the call, press
the key.
Tri Band SGH-X105 GPRS Telephone
Quick Reference Card
174
Answer a
Call
Press the key.
Adjust the
Volume
Press the or key on the
left side of the phone.
Choose the
Alert Type
➀Select the
Alert Type
menu option (Menu
5.3
).
➁Select an option:
•
Light Only
•
Melody
•
Vibration
•
Vibra+Melody
➂
Press the
Select
soft key.
Store
Numbers in
Phonebook
➀Enter the number and
press the Save soft key.
➁Select an icon for label.
➂Press the
Select
soft key.
➃Select a memory.
➄Press the
Select
soft key.
Store
Numbers in
Phonebook
(continued)
➅Enter the name.
➆Press the
OK
soft key.
➇If necessary, change the
location number.
➈Press the
OK
soft key.
➉Press the key to
return to Idle Mode.
Search for a
Number in
Phonebook
➀Press the
Ph.Book
soft
key.
➁Select the
Search
option.
➂Enter the first few letters
of the name.
➃To scroll through the
names, press the Up and
Down keys.
➄Press the
View
soft key.
➅To scroll through the
numbers, press the Up
and Down keys.
➆Press the key to dial.
