Samsung Electronics Co SGHX200 Single-Band PCS GSM Phone User Manual 1
Samsung Electronics Co Ltd Single-Band PCS GSM Phone 1
Users Manual
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-XXXXXA
English. 08/2005. Rev 1.1
*
Depending on the software installed or your service provider or country,
some of the descriptions in this guide may not match your phone exactly.
* Depending on your country, your phone and accessories may appear
different from the illustrations in this guide.
SGH-X200
User’s Guide
Draft
2005. 08. 05
Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or illegal.
Drive safely at all times
Do not use a hand-held phone while driving. Park
the vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using them
in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.
Important safety precautions
1
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is forbidden
to use it, or when it may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear). Avoid
unnecessary contact with the antenna when the phone
is switched on.
Emergency calls
Key in the emergency number for your present
location, then press .
Keep your phone away from small children
Keep the phone and all its parts, including accessories,
out of the reach of small children.
Accessories and batteries
Use only Samsung-approved accessories and
batteries. Use of any unauthorised accessories could
damage your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health and
safety information" on page 61.
• The phone could explode if the battery is
replaced with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.
2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone. To quickly
learn the basics for your phone, please refer to “Get
started” and “Step outside the phone.”
In this guide, the following instruction icons appear:
Indicates that you need to pay careful
attention to the subsequent information
regarding safety or phone features.
Indicates that you can get more information
on the referenced page.
→
Indicates that you need to press the
Navigation keys to scroll to the specified
option and then select it.
[ ]
Indicates a key on the phone. For example,
[]
< >
Indicates a soft key, whose function is
displayed on the phone screen. For example,
<
Menu
>
•Tri-band operation
Use your phone in worldwide GSM networks, in
any of 900, 1800, and 1900 bands.
Special
features of your phone
• Simple, compact design with Intenna
Samsung’s powerful intenna technology allows
the best call quality without an annoying
external antenna.
•IrDA
Send and receive Phonebook
and calendar data via an
infrared port.
3
Special features of your phone
•Web browser
Access the wireless web to get
current information and up-to-
the-minute a wide variety of
media content.
•Java
Enjoy Java
™
-based embedded
games and download new
games.
•Phonebook
Store home, office, or cellular
phone numbers for your entries.
• Multimedia Message Service (MMS)
Send and receive MMS messages with a
combination of text, images, and sounds.
• Calendar and to do list
Keep track of your daily and
monthly schedules and tasks.
•Alarm
Use your phone as an alarm
clock to wake you up in the
morning or notify you to an
event.
•Calculator
Perform basic calculations and
do currency conversions.
• Voice recorder
Record memos or sounds.
4
Contents
Unpack 6
Your phone 6
Buttons, features, and locations
Get started 7
First steps to operating your phone
Install and charge the phone..................................... 7
Power on or off........................................................ 8
Keys and display ..................................................... 9
Access menu functions ............................................ 11
Customise your phone............................................. 12
Make/Answer calls .................................................. 14
Step outside the phone 14
Begin with games, web, messages, and other special
features
Play games............................................................ 14
Browse the web...................................................... 15
Use Phonebook....................................................... 16
Send messages...................................................... 16
View messages....................................................... 18
Enter text 19
ABC, T9, Number, and Symbol mode
Call functions 22
Advanced calling features
Menu functions 27
All menu options listed
Solve problems 59
Help and personal needs
Health and safety information 60
Index 80
5
Overview of menu functions
To access Menu mode, press <
Menu
> in Idle mode.
1 SIM AT
p. 27
2
2 Call records
p. 27
1 Missed calls
2 Received calls
3 Dialled calls
4 Delete all
5 Call time
6 Call cost
*
p. 27
p. 28
p. 28
p. 28
p. 28
p. 28
3 Network services
p. 29
1 Call diverting
2 Call barring
3 Call waiting
4 Network selection
5 Caller ID
6 Closed user group
7 Band selection
p. 30
p. 30
p. 30
p. 30
p. 30
p. 31
p. 31
4 Sound settings
p. 32
1 Ring tone
2 Ring volume
3 Alert type
4 Keypad tone
5 Message tone
6 Alert on call
7 Folder tone
8 Power on/off
9 Extra tones
p. 32
p. 32
p. 32
p. 32
p. 32
p. 33
p. 33
p. 33
p. 33
5 Messages
p. 33
1 Text messages
2 Multimedia
messages
3 Push messages
p. 33
p. 38
p. 42
6 Funbox
p. 42
1 WAP browser
2 Games
3 Sounds
4 Images
5 Delete all
6 Memory status
p. 43
p. 45
p. 46
p. 46
p. 46
p. 46
7 Organiser
p. 46
1 Alarm
2 Calendar
3 Time & Date
4 Calculator
5 To do list
6 Voice memo
7 Currency exchange
p. 47
p. 47
p. 48
p. 48
p. 49
p. 50
p. 50
8 Phonebook
p. 51
1 Search
2 New entry
3 Group search
4 Edit group
5 Speed dial
6 Delete all
7 Memory status
8 SDN*
p. 51
p. 51
p. 52
p. 52
p. 52
p. 53
p. 53
p. 53
9 Phone settings
p. 54
1 Infrared activate
2 Display settings
3 Greeting message
4 Own number
5 Language
6 Security
7 Extra settings
8 Short cut
9 Reset settings
p. 54
p. 55
p. 56
p. 56
p. 56
p. 57
p. 58
p. 58
p. 58
*Shows only if supported by your
SIM card.
6
Unpack
Make sure you have each item
You can obtain various accessories from your local
Samsung dealer.
Your phone
Buttons, features, and locations
Phone Travel adapter
Battery User’s guide
The items supplied with your phone and the accessories
at your Samsung dealer may vary, depending on your
country or service provider.
Left soft key
Dial key
Special
function keys
Headset jack
Earpiece
Display
Power on/off/
Menu exit key
Alphanumeric
keys
Right soft key
Microphone
Navigation keys
(Up/Down/Left/
Right) Web access/
Confirm key
Cancel/Correct
key
Volume keys
Infrared port
7
Get started
First steps to operating your phone
SIM card information
When you subscribe to a cellular network, you receive
a plug-in SIM (Subscriber Identity Module) card
loaded with your subscription details, such as your
PIN, and available optional services.
Install and charge the phone
Remove the battery
cover.
If the
phone is already
on, first turn it off by
holding [ ].
Insert the SIM card.
Make sure that the
gold-coloured contacts
on the card face down
into the phone.
Install the battery. Replace the cover.
Plug the travel adapter
into the phone. Plug the adapter into
a standard AC wall
outlet.
8
Get started
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the battery low message displays, and
• the empty battery icon blinks.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
Power on or off
When the phone is completely charged (the
battery icon becomes still), unplug the adapter
from the power outlet.
Remove the adapter from the phone.
Power on
Do not turn on
the phone when
mobile phone
use is prohibited.
1. Open the phone.
2. Press and hold [ ] to turn on
the phone.
3. If necessary, enter the PIN and
press <
OK
>.
Power off
1. Open the phone.
2. Press and hold [ ].
9
Get started
Keys and display
Keys
Perform the function indicated on the bottom
line of the display.
In Idle mode, access your favourite menus
directly.
p. 58
In Menu mode, scroll through menu options.
In Idle mode, launch the web browser.
In Menu mode, select the highlighted menu
option or confirm input.
Make or answer a call.
In Idle mode, retrieve the recent numbers
dialled, missed, or received.
Delete characters from the display.
In Menu mode, return to the previous menu
level.
End a call.
Press and hold to switch the phone on or off.
In Menu mode, cancel input and return the
phone to Idle mode.
Enter numbers, letters, and some special
characters.
In Idle mode, press and hold
[1]
to access
your voicemail server. Press and hold [
0
] to
enter an international call prefix.
Enter special characters.
In Idle mode, press and hold
[]
to activate
or deactivate Silent mode. Press and hold
[]
to enter a pause between numbers.
Adjust the phone volume.
In Idle mode, adjust the keypad tone
volume.
10
Get started
Display
Layout
Icons
Received signal strength
Call in progress
Out of your service area; you
cannot send or receive calls
IrDA feature active
p. 54
Call diverting feature active
p. 29
Text and graphics
display messages,
instructions, and
information you enter.
Soft key function
indicators
show the current functions
assigned to the two soft
keys.
Icons
display various icons.
Menu Phonebook
Icons
(continued)
GPRS network
Roaming
New text message
New voicemail message
New multimedia message
Active Silent mode or call ringer set
to vibrate
p. 13, p. 32
Mute mode
p. 25
Alarm set
Battery power level
11
Get started
Access menu functions
Use the soft
keys
The roles of the soft keys vary
depending on the function you are
using. The bottom line of the
display indicates their current role.
Press the left soft
key to access
Menu mode.
Press the right soft
key to access the
Phonebook
menu.
Menu Phonebook
Select an
option
1. Press the appropriate soft key.
2. Press the Navigation keys to
move to the next or previous
option.
3. Press <
Select
>, <
OK
>, or
[
]
to confirm the function
displayed or option highlighted.
4. To exit, choose either of the
following methods:
• Press < > or [
C
] to move
up one level.
• Press [ ] to return to Idle
mode.
Use shortcuts
Press the number key
corresponding to the option you
want.
12
Get started
Customise your phone
1. In Idle mode, press <
Menu
>
and select
Phone settings
→
Language
.
2. Select a language.
1. In Idle mode, press <
Menu
>
and select
Sound settings
→
Ring tone
.
2. Select a ringtone.
3. Select
Ring volume
.
4. Adjust the volume level.
5. Press <
OK
>.
Display
language
Call ringer
melody and
volume
You can set wallpaper for the idle
screen.
1. In Idle mode, press <
Menu
>
and select
Phone settings
→
Display settings
→
Wallpaper
→
Wallpaper list
.
2. Select the image you want.
3. Press <
Select
>.
Idle mode
wallpaper
13
Get started
You can set the Navigation keys as
shortcuts to access your favourite
menus.
1. In Idle mode, press <
Menu
>
and select
Phone settings
→
Short cut
.
2. Select a key.
3. Select a menu to be assign to
the key.
You can switch the phone to Silent
mode to avoid disturbing other
people with your phone sounds.
Press and hold [ ] in Idle mode.
Menu
shortcuts
Silent mode
You can protect the phone against
unauthorised use with a phone
password. The phone will require
the password on power-up.
1. In Idle mode, press <
Menu
>
and select
Phone
settings
→
Security
→
Change
password
.
2. Enter the default password,
00000000
, and press <
OK
>.
3. Enter a new 4- to 8-digit
password and press <
OK
>.
4. Enter the new password again
and press <
OK
>.
5. Select
Phone lock
.
6. Select
Enable
.
7. Enter the password and press
<
OK
>.
Phone lock
14
Make/Answer calls
Step outside the phone
Begin with games, web, messages, and other special
features
Play games
1. Enter an area code and phone
number.
2. Press [ ].
3. To end the call, press [ ].
1. When the phone is ringing,
press [ ].
2. To end the call, press [ ].
Press [ / ].
Make a call
Answer a call
Adjust the
volume during
a call
1. In Idle mode, press <
Menu
>
and select
Funbox
→
Games
→
a game.
2. Select
START GAME
.
3. Select a game mode or press
any key to start the game.
Launch a game
15
Step outside the phone
Browse the web
Using a built-in web browser, you can get easy access
to the wireless web to get a variety of up-to-date
services and information and to enjoy downloads of
web content.
1. Press the Navigation keys to
move the selection.
2. Press [
1
] or [
3
] to make a
horizontal or vertical line of
three identical bubbles.
1. Press the Navigation keys to
move the selection to the
position you want to connect
the pipe.
2. Press [ ] to insert a pipe.
3. Repeat until you complete the
pipeline.
Play
BubbleSmile
Play Fun2Link
In Idle mode, press [ ].
• To scroll through browser items,
press [Up] or [Down].
• To select an item, press [ ].
• To return to the previous page,
press [
C
].
• To access browser options,
press and hold [ ].
Launch the
web browser
Navigate the
browser
16
Step outside the phone
Use Phonebook
Send messages
To the phone’s memory:
1. In Idle mode, enter a phone
number and press <
Save
>.
2. Select a number type.
3. Select
Phone
.
4. Enter a name and press <
OK
>.
5. Press <
OK
> to save the entry.
To the SIM card:
1. In Idle mode, enter a phone
number and press <
Save
>.
2. Select a number type.
3. Select
SIM
.
4. Enter a name and press <
OK
>.
5. Press <
OK
> to save the entry.
Add an entry
1. In Idle mode, press
<
Phonebook
>
and select
Search
.
2. Select an entry.
3. Scroll to a number and press
[ ] to dial, or press
<
Options
> to access options.
1. In Idle mode, press <
Menu
>
and select
Messages
→
Text
messages
→
Write new
.
2. Enter the message text.
3. Press <
Options
> and select
Save and send
or
Send only
.
4. If you selected
Save and send
,
select a memory location.
5. Enter a destination number and
press <
OK
>.
Find an entry
Send a text
message (SMS)
17
Step outside the phone
1. In Idle mode, press <
Menu
>
and select
Messages
→
Multimedia messages
→
Write new
.
2. Enter the message subject
press <
OK
>.
3. Select
Add here
and add
message contents.
4. When you have finished, press
<
Options
> and select
Send
.
5. Select a destination type.
6. Select one of
Phone number
,
E-mail address
, or
Phonebook
.
Send a
multimedia
message
(MMS)
7. Enter a destination number or
address, or select a number
from Phonebook and press
<
OK
>.
8. To add other destinations,
select
Add destination
and
repeat from step 6.
9. To add destinations of other
types, press < > and repeat
from step 5.
10.When you have finished, select
Send message
.
18
Step outside the phone
View messages
When a notification appears:
1. Press <
View
>.
2. Select a message from the
Inbox.
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messages
→
Text
messages
→
Inbox
.
2. Select the message.
View a text
message
When a notification appears:
1. Press <
View
>.
2. Press <
Options
> and select
Retrieve
.
3. Select a message from the
Inbox.
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messages
→
Multimedia messages
→
Inbox
.
2. Select the message.
View a
multimedia
message
19
Enter text
ABC, T9, Number, and Symbol mode
You can enter text for some features such as
messaging, Phonebook, or Organiser, using ABC
mode, T9 mode, Number mode, and Symbol mode.
Changing the text input mode
The text input mode indicator displays when the
cursor is in a text field.
Press the right soft key to change the input mode:
•: ABC mode
•: T9 mode
•: Number mode
• None: Symbol mode
Using ABC mode
Press the appropriate key until the character you want
appears on the screen.
(Creating an SMS message with uni-code encoding)
Text input mode
indicator
Write new
Options
Characters in order displayed
Key
Upper case Lower case
space
20
Enter text
Tips for using ABC mode
• To enter the same letter twice or to enter a
different letter on the same key, wait for the cursor
to move to the right automatically or press [Right].
Then, enter the next letter.
• Press [ ] to insert a space.
• Press [ ] to change case. Initial capital ( ),
Capital lock ( ), and Lower case ( ) are
available.
• Press the Navigation keys to move the cursor.
•Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
• Depending on your country, you may be able to
access an input mode for your specific language by
holding [ ].
Using T9 mode
T9 is a predictive text input mode that allows you to
key in any character using single keystrokes.
Entering a word in T9 mode
1. Press [
2
] to [
9
]
to start entering a word. Press
each key once for each letter.
For example, press [
4
], [
3
], [
5
], [
5
], and [
6
] to
enter Hello in T9 mode.
T9 predicts the word that you are typing, and it
may change with each key that you press.
2. Enter the whole word before editing or deleting
characters.
3. When the word displays correctly, go to step 4.
Otherwise, press [
0
] to display alternative word
choices for the keys that you have pressed.
For example, Of and Me use [
6
] and [
3
].
4. Press [ ] to insert a space and enter the next
word.
Enter text
21
Tips for using T9 mode
•Press [
1
] to enter periods or apostrophes
automatically.
• Press [ ] to change case. Initial capital ( ),
Capital lock ( ), and Lower case ( ) are
available.
• Press [Left] or [Right] to move the cursor.
•Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
Adding a new word to the T9 dictionary
This feature may not be available for some languages.
1. Enter the word that you want to add.
2. Press [
0
] to display alternative words for your key
presses. When there are no more alternative
words,
Add
displays on the bottom line.
3. Press <
Add
>.
4. Enter the word you want using ABC mode and
press <
OK
>.
Using Number mode
Number mode enables you to enter numbers.
Press the keys corresponding to the digits you want.
Using Symbol mode
Symbol mode enables you to insert symbols.
To Press
display more symbols [Up] or [Down].
select a symbol the corresponding
number key.
clear the symbol(s) [
C
].
insert the symbol(s) <
OK
>.
22
Call functions
Advanced calling features
Making a call
1. In Idle mode, enter the area code and phone
number.
2. Press [ ].
Making an international call
1. In Idle mode, press and hold [
0
]. The
+
character
appears.
2. Enter the country code, area code, and phone
number, then press [ ].
Redialling recent numbers
1. In Idle mode, press [ ] to display the list of
recent numbers.
2. Scroll to the number you want and press [ ].
Making a call from Phonebook
Once you have stored a number in Phonebook, you
can dial the number by selecting it from
Phonebook.
p. 51
You can also use the speed dial feature to assign your
most frequently called numbers to specific number
keys.
p. 52
Dialling a number from the phone’s memory
1. In Idle mode, press and hold [
0
]. A + appears.
2. Enter the location number for the phone number
you want and press [ ].
3. Press [Up] or [Down] to scroll through other
numbers.
4. Press <
Dial
> or [ ] to dial the number you want.
• Press [
C
] to clear the last digit or press and hold
[
C
] to clear the whole display. You can move the
cursor to edit an incorrect digit.
• Press and hold [ ] to enter a pause between
numbers.
Call functions
23
Dialling a number from the SIM card
1. In Idle mode, enter the location number for the
phone number you want and press [ ].
2. Press [Up] or [Down] to scroll through other
numbers.
3. Press <
Dial
> or [ ] to dial the number you want.
Ending a call
Close the phone or press [ ].
Answering a call
When you receive an incoming call, the phone rings
and displays the incoming call image.
Press <
Accept
> or [ ] to answer the call.
Tips for answering a call
• When
Anykey
answer
is active, you can press
any key to answer a call, except for <
Reject
> or
[].
p. 58
• When
Active folder
is active, you can simply open
the phone.
p. 58
• Press <
Reject
> or [ ] to reject a call.
Viewing missed calls
If you have missed calls, the screen displays how
many calls you have missed.
1. Press <
View
>.
2. If necessary, scroll through the missed calls.
3. Press [ ] to dial the number you want.
Using the headset
Use the headset to make or answer calls without
holding the phone.
Connect the headset to the jack on the left side of the
phone.
24
Call functions
The button on the headset works as listed below:
Options during a call
You can access a number of functions during a call.
Adjusting the volume during a call
Use [ / ] to adjust the earpiece volume during a call.
Press [ ] to increase the volume level and [ ] to
decrease the volume level.
Placing a call on hold/Retrieving
Press <
Hold
> or <
Unhold
> to place the call on hold
or retrieve the call.
Making a second call
You can make another call if your network supports it.
1. Press <
Hold
> to put the call on hold.
2. Make the second call in the normal way.
3. Press <
Swap
> to switch between the calls.
4. Press <
Options
> and select
End
held
call
to end
the call on hold.
5. To end the current call, press [ ].
Answering a second call
You can answer an incoming call, if your network
supports it and you have activated the call waiting
feature.
p. 30
1. Press [ ] to answer the call. The first call is
automatically put on hold.
2. Press <
Swap
> to switch between the calls.
3. Press <
Options
> and select
End
held
call
to end
the call on hold.
4. To end the current call, press [ ].
To Press
redial the last call the button twice.
answer a call and hold the button.
end a call and hold the button.
Call functions
25
Using the Speakerphone feature
Use your phone as a speaker phone to talk and listen
with the phone a short distance away.
Press <
Options
> and select
Loud speaker ON
/
Loud
speaker OFF
.
Transferring a call
You can transfer the currently active call to a caller on
hold, if your network supports it. With this option, the
two callers can talk to each other, but you are
disconnected from the call.
Press <
Options
> and select
Transfer
.
Using the menu functions
Press <
Options
> and select
Menu
.
Switching off the microphone
(
Mute mode
)
You can temporarily switch off your phone’s
microphone so that the other person on the phone
cannot hear you.
Press <
Options
> and select
Mute
or
Unmute
.
Muting or sending key tones
You can turn the key tones off or on.
Press <
Options
> and select
Mute keys
or
Send
keys
.
Sending a sequence of DTMF tones
Dual tone multi-frequency (DTMF) tones are the tones
used in phones for tone dialling.
You can send DTMF tones as a group after entering the
entire number you need to send or retrieving a
number from Phonebook. This feature is helpful for
entering a password or an account number when you
call an automated system, like a banking service.
1. When connected with a teleservice system, press
<
Options
> and select
Send
DTMF
.
2. Enter the number you need to send and press
<
OK
>.
To communicate with answering machines or
computerised telephone systems,
Send keys
must
be selected.
26
Call functions
Using Phonebook
You can access the
Phonebook
menu to locate or
store entries.
p. 51
Press <
Options
> and select
Phonebook
.
Making a multi-party call
Use this feature to allow as many as six people to join
a multi-party call, or conference call.
Your service provider must support multi-party calls
for you to use this feature.
Setting up a multi-party call
1. Call the first participant.
2. Call the second participant. The first call is
automatically put on hold.
3. Press <
Options
> and select
Join
. The first
participant is added to the multi-party call.
4. If desired, call another person or answer an
incoming call.
5. Press <
Options
> and select
Join
.
6. Repeat steps 4 and 5 as desired.
Having a private conversation with one
participant
1. Press <
Options
> and select
Select one
.
2. Select a name or number from the participant list.
3. Select
Private
.
You can talk privately with that person, while the
other participants converse with each other.
4. To return to the multi-party call, press <
Options
>
and select
Join
.
Disconnecting one participant
1. Press <
Options
> and select
Select one
.
2. Select a name or number from the participant list.
3. Select
Remove
.
The participant is dropped from the call, but the
call continues with the other parties.
4. Press [ ] to end the multi-party call.
27
Menu functions
All menu options listed
SIM AT
(Menu 1)
This menu is available if you use a SIM AT card that
provides additional services, such as news, weather,
sports, entertainment, and location services. Available
services may vary, depending on your service
provider’s plans.
For details, see your SIM card instructions or contact
your service provider.
To access this menu, press <
Menu
> in Idle mode and
select
SIM AT
.
Call records
(Menu 2)
Use this menu to view the calls you have dialled,
received, or missed, the length of your calls, and the
cost of your calls.
To access this menu, press <
Menu
> in Idle mode and
select
Call records
.
Missed calls
(Menu 2.1)
This menu displays the most recently received calls
that you did not answer.
Accessing a call record
1. Select a call record.
2. Press [Up] or [Down] to move to another call
record.
3. Press [ ] to dial or, <
Options
> to access call
record options.
28
Menu functions
Using call record options
While viewing call details, press <
Options
> to access
the following options:
•
Edit
: change the number of the selected call
record.
•
Delete
: delete the selected call record.
Received calls
(Menu 2.2)
This menu displays the most recent calls you have
received.
Dialled calls
(Menu 2.3)
This menu displays the most recent calls you have
dialled.
Delete all
(Menu 2.4)
Use this menu to delete all of the records in each call
type.
1. Press [ ] to select the call types to be cleared.
2. Press <
Delete
>.
3. Press <
Yes
> twice to confirm the deletion.
Call time
(Menu 2.5)
This menu displays the time log for calls made and
received. The actual time invoiced by your service
provider will vary.
•
Last
call
time
: check the length of your last call.
•
Total
sent
: check the total length of all the calls
you have dialled.
•
Total
received
: check the total length of all the
calls you have received.
•
Reset
timers
: reset the call timers. You need to
enter the phone password.
Call cost
(Menu 2.6)
This network feature displays the cost of calls. This
menu is available only if your SIM card supports this
feature. Note that this is not intended to be used for
billing purposes.
•
Last
call
cost
: check the cost of your last call.
The password is preset to
00000000
. You can
change this password.
p. 57
Menu functions
Network services
29
•
Total
cost
: check the total cost of all of your calls.
If the total cost exceeds the maximum cost set in
Set
max
cost
, you must reset the counter before
you can make another call.
•
Max
cost
: check the maximum cost limit set in
Set
max
cost
.
•
Reset
counters
: reset the cost counters.
•
Set
max
cost
: set the maximum cost authorised
for your calls.
•
Price/Unit
: set the price per unit that is applied
when the cost of your calls is calculated.
Network services
(Menu 3)
Use this menu to access network services. Please
contact your service provider to check their availability
and subscribe to them, if you wish.
To access this menu, press <
Menu
> in Idle mode and
select
Network services
.
Call diverting
(Menu 3.1)
This network service reroutes incoming calls to a
phone number that you specify.
1. Select a call diverting option:
•
Divert always
: divert all calls.
•
Busy
: divert calls when you are on another
call.
•
No
reply
: divert calls when you do not answer
the phone.
•
Unreachable
: divert calls when you are not in
an area covered by your service provider or
when your phone is switched off.
•
Cancel
all
: cancel all call diverting options.
2. Select the type of calls to be diverted.
3. To activate call diverting, press <
Activate
>.
Otherwise, press <
Options
> and select
Remove
.
4. Enter the number to which calls are to be diverted
and press <
OK
>.
30
Menu functions
5. If you selected
No reply
, select the length of time
the network delays before diverting a call and
press <
Select
>.
Call barring
(Menu 3.2)
This network service allows you to restrict your calls.
1. Select a call barring option:
•
All
outgoing
: prohibit all outgoing calls.
•
International
: prohibit international calls.
•
International
except
to
home
: only allow
calls to numbers within the current country
when you are abroad, and to your home
country.
•
All
incoming
: prohibit incoming calls.
•
Incoming
while
abroad
: prohibit incoming
calls when you use your phone outside of your
home country.
•
Cancel
all
: cancel all call barring settings,
allowing calls to be sent and received normally.
•
Change barring password
: change the call
barring password obtained from your service
provider.
2. Select the type of calls to be barred.
3. Press <
Activate
>. To deactivate call barring,
press <
Deactivate
>.
4. Enter the call barring password supplied by your
service provider and press <
OK
>.
Call waiting
(Menu 3.3)
This network service informs you when someone is
trying to reach you while you are on another call.
1. Select the type of calls to which the call waiting
option will apply.
2. Press <
Activate
>. To deactivate call waiting,
press <
Deactivate
>.
Network selection
(Menu 3.4)
This network service allows you to either automatically
or manually select the network used when roaming
outside of your home area.
You can select a network other than your home
network only if there is a valid roaming agreement
between the two.
Menu functions
Network services
31
•
Automatic
: connect to the first available network
when roaming.
•
Manual
: select the network you want.
Caller ID
(Menu 3.5)
This network service allows you to prevent your phone
number from being displayed on the phone of the
person being called. However, some networks do not
allow the user to change this setting.
•
Default
: use the default setting provided by the
network.
•
Hide
number
: ensure your number does not
display on the other person’s phone.
•
Send
number
: send your number each time you
make a call.
Closed user group
(Menu 3.6)
Use this menu to set incoming and outgoing calls to be
restricted to a selected user group. For details about
how to create a closed user group, contact your
service provider.
•
Index list
: list, add, or delete CUG index
numbers. Press <
Options
> to access the options
for setting up an index list.
•
Outside access
: enable calls to numbers other
than those in the Closed user group. This feature
depends on the nature of your CUG subscription.
•
Default group
: enable the default CUG, if you
have set one with your service provider. When
making a call, you are given the option of using
your default CUG, instead of selecting one from the
list.
Band selection
(Menu 3.7)
For the phone to make and receive phone calls, it
must register with an available network. Your phone
can handle any of the following types of networks:
GSM 1900 and Combined GSM 900/1800.
The country where you purchased your phone
determines the default band that it uses. When you
travel abroad, you must remember to change to an
appropriate band.
32
Menu functions
Sound settings
(Menu 4)
Use this menu to customise various sound settings.
To access this menu, press <
Menu
> in Idle mode and
select
Sound settings
.
Ring tone
(Menu 4.1)
Use this menu to select a ringtone for the call ringer.
You can select one of the default ring melodies or
downloaded sounds.
Ring volume
(Menu 4.2)
Use this menu to adjust the ringtone volume.
Alert type
(Menu 4.3)
Use this menu to specify how you are to be informed
of incoming calls.
•
Light only
: the service light flashes; the phone
neither rings nor vibrates.
•
Melody
: the phone rings using the selected
ringtone.
•
Vibration
: the phone vibrates but not rings.
•
Vibra+melody
: the phone vibrates three times
and then starts ringing.
Keypad tone
(Menu 4.4)
Use this menu to select the tone that the phone
sounds when you press a key.
Message tone
(Menu 4.5)
Use this menu to change the sound settings for
incoming SMS messages, MMS messages, and CB
messages individually.
•
SMS tone
: specify how you are informed of new
SMS messages.
•
SMS-CB tone
: specify how you are informed of
new cell broadcast (CB) messages.
•
MMS tone
: specify how you are informed of new
MMS messages.
You can adjust the keypad tone volume using
[/]
in Idle mode.
Menu functions
Messages
(Menu 5)
33
•
Repetition
: set how often the phone informs you
of new messages.
Alert on call
(Menu 4.6)
Use this menu to select whether or not the phone
informs you when you receive a new message or when
the time for an alarm comes during a call.
Folder tone
(Menu 4.7)
Use this menu to select the tone that the phone
sounds when you open or close the phone.
Power on/off
(Menu 4.8)
Use this menu to select the melody that the phone
plays when it is switched on or off.
Extra tones
(Menu 4.9)
Use this menu to customise additional tones for the
phone.
•
Error tone
: set the phone to beep when you make
a mistake.
•
Minute
minder
: set the phone to beep every
minute during an outgoing call to keep you
informed of the length of your call.
•
Connect
tone
: set the phone to beep when an
outgoing call is connected to the system.
Messages
(Menu 5)
Use the
Messages
menu to send and receive short
messages, and multimedia messages. You can also
use push message, voicemail, and cell broadcast
message features.
To access this menu, press <
Menu
> in Idle mode and
select
Messages
.
Text messages
(Menu 5.1)
Short Message Service (SMS) allows you to send or
receive text messages including simple pictures,
melodies, and animated images.
34
Menu functions
Inbox
(Menu 5.1.1)
Use this menu to view received text messages.
While viewing a message, press <
Options
> to access
the following options:
•
Delete
: delete the message.
•
Send
: forward the message to other people.
•
Text reply
: reply to the sender.
•
Call
back
: call the sender.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Move to phone
: move the message from the SIM
card to the phone’s memory.
•
Move to SIM
: move the message from the
phone’s memory to the SIM card.
•
Select objects
: save images or sounds from the
message into your phone.
Outbox
(Menu 5.1.2)
Use this menu to view sent or saved text messages.
While viewing a message, press <
Options
> to access
the following options:
•
Delete
: delete the message.
•
Send
: forward the message to other people.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Move to phone
: move the message from the SIM
card to the phone’s memory.
•
Move to SIM
: move the message from the
phone’s memory to the SIM card.
•
Select objects
: save images or sounds from the
message into your phone.
Menu functions
Messages
(Menu 5)
35
Write new
(Menu 5.1.3)
Use this menu to create and send text messages.
1. Enter your message.
2. Press <
Options
> to access the following options:
•
Text formatting
: change the text attributes.
•
Add objects
: add a sound, melody, picture, or
animated image to the message.
•
Add templates
: retrieve a text template.
•
Add emoticon
: retrieve an emoticon.
•
Add phonebook
: add a Phonebook entry.
•
Add bookmark
: add a web page’s address.
•
Language
: change the language used in T9
input mode.
3. Press <
Options
> and select
Send only
,
Save
and send
or
Save only
.
4. If you select
Save and send
or
Save only
, select
a memory location.
5. Enter a destination number.
6. Press <
OK
>
to send the message.
Templates
(Menu 5.1.4)
Use this menu to create SMS templates with the
sentences you use frequently so that you can retrieve
and insert them when composing an SMS message.
While viewing the templates list, press <
Options
> to
access the following options:
•
Edit
: edit the template.
•
Send message
: send the template as an SMS
message.
•
Delete
: delete the template.
Emoticon templates
(Menu 5.1.5)
Your phone provides preset emoticons so that you can
use when writing a message. Use this menu to create
or edit emoticons.
The maximum number of characters allowed in
a short message varies by service provider. If
your message exceeds the maximum number of
characters, the phone will split the message.
36
Menu functions
While viewing the emoticon list, press <
Options
> to
access the following options:
•
Add
: add a new emoticon.
•
Edit
: edit the selected emoticon.
•
Send
: send a message using the emoticon.
•
Delete
: delete the emoticon.
Settings
(Menu 5.1.6)
Use this menu to customise the SMS settings.
•
Setting x
(where
x
is the setting group number):
each group has its own submenu.
Service centre
: store or changes the number of
your message centre.
Default destination
: store a default destination
number.
Default type
: set the default message type.
Default validity
: set the length of time your
messages are stored in the SMS server.
Setting name
: change the name of the setting
group.
•
Common setting
: the following options are
available:
Reply path
: allow the recipient to reply to you
through your message centre.
Delivery reports
: set the network to inform you
when your message has been delivered.
Bearer selection
: select the
GSM
or
GPRS
preferred
bearer type.
Character support
: select a character encoding
type. If you select
Automatic
, the phone switches
the encoding type from GSM-alphabet to uni-code
if you enter a uni-code character. Use of uni-code
encoding will reduce the maximum number of
characters in a message to about half. If this menu
is not shown, your phone provides the automatic
character encoding by default.
The setting options available in this menu may vary
depending on your service provider.
Menu functions
Messages
(Menu 5)
37
Delete all
(Menu 5.1.7)
Use this menu to delete all of SMS messages in each
message box.
1. Press [ ] to select the message boxes to be
cleared.
2. Press <
Delete
>.
3. Press <
Yes
> twice to confirm the deletion.
Memory status
(Menu 5.1.8)
Use this menu to check the number of SMS messages
you have stored and total number of SMS messages
you can store in each memory type.
Voice mail
(Menu 5.1.9)
Use this menu to store the number of the voicemail
server and access your voicemails.
•
Connect to voice server
: connect to the voice
server to allow you to listen to your messages. You
can also connect to the voicemail server by
pressing and holding [
1
] in Idle mode.
•
Voice server number
: change the voicemail
server name or number.
Broadcast
(Menu 5.1.0)
The Cell Broadcast service delivers short messages on
various topics such as the weather or traffic.
Use this menu to change the settings for the service
and access broadcast messages.
•
Read
: open received messages.
The
Volatile
box saves network messages until
the phone is switched off.
The
Archive
box saves network messages
indefinitely. Press <
Options
> and select
Save
when a text notification appears. The message is
saved in the
Archive
box.
You must enter the voice server number before you
can access your voicemails. Your service provider
can give the voice server number.
38
Menu functions
•
Receive
: select to receive broadcast messages, or
not.
•
Channel
list
: specify the channels from which you
receive broadcast messages.
•
Language
: select the preferred languages in
which broadcast messages display.
Please contact your service provider for details.
Multimedia messages
(Menu 5.2)
Multimedia Message Service (MMS) delivers messages
containing a combination of text, picture, and sound,
from phone to phone or from phone to e-mail.
Inbox
(Menu 5.2.1)
This menu displays MMS messages that you have
received. The following icons tell you the message
status:
• Read notification
• Unread notification
• Retrieving from the server
• Processing your request
• Failed to send
• Read
• Unread
While viewing a message, press <
Options
> to access
the following message options:
•
Delete
: delete the message.
•
Reply
: reply to the sender.
•
Callback
: call the sender.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Forward
: forward the message to other people.
•
Save picture
: save an image from the message
into the
Images
folder.
•
Save sound
: save a sound from the message into
the
Sounds
folder.
•
Properties
: access the message properties.
When you select a notification, you can access
Retrieve
to retrieve the message from the MMS
server.
Menu functions
Messages
(Menu 5)
39
Outbox
(Menu 5.2.2)
This menu displays MMS messages that you have
sent. The following icons tell you the message status:
• Being sent
• Sent
• Failed to send
• To be sent
• Deferred
While viewing a message, press <
Options
> to access
the following options:
•
Delete
: delete the message.
•
Cut address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Send
: send or resend the message.
•
Edit message
: edit the message.
•
Properties
: access the message properties.
Draft
(Menu 5.2.3)
After creating a multimedia message, you can store it
in this message box for sending later.
You can view a message and use the options the same
as in
Outbox
.
Write new
(Menu 5.2.4)
You can create and send an MMS message.
1. Enter the message subject and press <
OK
>.
2. Press <
Options
> and add message contents using
one of the following options:
•
Add text
: add message text.
•
Add picture
: add a picture to the message.
•
Add sound
: add a sound clip to the message.
•
Save
: save the message in the
Draft
or
Templates
box.
•
Settings
: change the message settings.
•
Add destination
: enter destination numbers
or addresses.
40
Menu functions
•
Preview
: view the message you created.
3. If you want to change the added items, highlight
one and press <
Options
> to access the following
options:
•
Edit text
/
Edit picture
/
Edit sound
: edit the
text, picture, or sound.
•
Add page
: add pages. Move to each page by
pressing [Left] or [Right] on the message
screen.
•
Delete
: delete the item from your message.
•
Duration
: set how long one page displays.
After the specified time, the display
automatically scrolls to the next page.
4. When you have finished, select
Send
from the
options.
5. Select a destination type (To, Cc, Bcc).
6. Select one of
Phone number
,
E-mail address
, or
Phonebook
.
7. Enter a phone number or an e-mail address, or
select a number from Phonebook and press <
OK
>.
8. To add more destinations, select
Add destination
and repeat from step 6.
9. To enter additional numbers or addresses to other
destination types, press < >and repeat from step
5.
10.When you have finished, select
Send message
.
Templates
(Menu 5.2.5)
Use this menu to store MMS messages you saved as
templates so that you can use them to create new
messages.
While viewing a message template, press <
Options
>
to access the following options:
•
Edit message
: send the message using the
template.
•
Delete
: delete the template.
The maximum size allowed for a message can
differ, depending on your service provider.
Menu functions
Messages
(Menu 5)
41
Delete all
(Menu 5.2.6)
Use this menu to delete all of MMS messages in each
message box.
1. Press [ ] to select the message boxes to be
cleared.
2. Press <
Delete
>.
3. Press <
Yes
> twice to confirm the deletion.
Memory status
(Menu 5.2.7)
Use this menu to view the amount of memory
available for MMS messages and memory currently in
use in each message box.
Setup
(Menu 5.2.8)
You can customise the settings for sending and
receiving MMS messages.
•
Delivery report
: set the network to inform you
when your message has been delivered.
•
Read reply
: request a reply from the recipient.
•
Auto download
: set whether or not your phone
retrieves new incoming messages from the MMS
server without notifications.
•
Message acceptance
: select the category of
messages you want to receive.
•
Hide ID
: hide your phone number on the
recipient’s phone.
•
Expiry date
: set the length of time your messages
are stored in the message centre.
•
Delivery time
: set the time
delay before
messages are sent.
•
Priority
: set the priority level of your messages.
•
Report allowed
: send a delivery report from the
network to the sender.
•
Page duration
: set how long one page in your
outgoing messages displays. After a specified time,
the display automatically scrolls to the next page.
42
Menu functions
MMS profile
(Menu 5.2.9)
You can configure required network settings for MMS.
The last profile accessed is automatically activated for
sending or receiving subsequent messages.
•
Profile name
: assign a name to the MMS profile.
•
Connection URL
: enter the address of your MMS
server.
•
Security
: select a data transmission mode.
•
IP address
: enter the gateway address.
•
User name
: enter the user ID.
•
Password
: enter the password.
•
APN
: enter the access point name used for the
address of the MMS server.
Push messages
(Menu 5.3)
Use this menu to access messages from the web
server.
•
Inbox
: view push messages you have received.
•
Receive
: determine whether or not your phone
receives push messages.
Never
: the phone rejects push messages.
Always
: the phone receives all push messages.
•
Delete all
: delete all push messages.
Funbox
(Menu 6)
The
Funbox
menu allows you to use the web browser,
play Java games, and access images and sounds
stored in the phone’s memory.
To access this menu, press <
Menu
> in Idle mode and
select
Funbox
.
Check with your service provider before you change
any MMS settings on your phone.
Menu functions
Funbox
(Menu 6)
43
WAP browser
(Menu 6.1)
The Wireless Application Protocol (WAP) browser on
your phone allows you to access the wireless web.
From the wireless web, you can access up-to-date
information and a wide variety of media content, such
as games, wallpapers, and ringtones.
Home
(Menu 6.1.1)
Use this menu to connect your phone to the network
and load the homepage of the wireless web service
provider. You can also press [ ] in Idle mode.
Navigating with the web browser
Using page options
From any web page, press and hold [ ] to access the
following options:
•
Reload
: reload the current page with updated
information.
•
Home
: return to the homepage.
•
Go to URL
: enter a URL address manually.
•
Show URL
: view the URL address of the current
web page.
•
Edit home
: change the page to be used for your
homepage.
•
Clear cache
: delete information stored in the
cache.
•
Inbox
: read messages received from a web
server.
Exiting the web browser
Press [ ] to exit the browser.
To Press
scroll through browser items [Up] or [Down].
select a browser item [ ].
return to the previous page [
C
].
44
Menu functions
Favorite
(Menu 6.1.2)
Use this menu to save URL addresses in order to
quickly access web pages.
Adding a bookmark
1. Select an empty location.
2. Enter a URL address and press <
Enter
>.
3. Enter a title for the bookmark and press <
Enter
>.
Accessing a bookmarked page
Selecting a bookmark item launches the web browser
and accesses the associated web page.
Using bookmark options
After saving an item, press <
Options
> to access the
following options:
•
Go
to URL
: access the website.
•
Edit
: edit the URL address and title of the
bookmark.
•
Delete
: delete the bookmark.
http://
(Menu 6.1.3)
Use this menu to manually enter a URL address and
access the associated web page.
Settings
(Menu 6.1.4)
Use this menu to set up servers for the web browser.
Contact your service provider for details about your
settings options.
For each server, the following options are available:
•
Profile
name
: assign a name to the server profile.
•
Homepage
URL
: set the address of your
homepage.
•
Security
: select a data transmission mode.
•
Bearer
: select a bearer for each type of network
address accessed;
GPRS
or
Data
.
When the bearer is set to
GPRS
:
•
IP address
: enter the web gateway address.
•
User name
: enter the user ID.
•
Password
: enter the password.
Menu functions
Funbox
(Menu 6)
45
•
APN
: enter the access point name of the GPRS
network gateway.
When the bearer is set to
Data
:
•
IP address
: enter the web gateway address.
•
Login name
: enter the user ID.
•
Password
: enter the password.
•
Dial-up number
: enter the PPP server phone
number.
•
Data call type
: select a data call type.
Clear cache
(Menu 6.1.5)
Use this menu to clear the cache, which is the
temporary memory that stores the web pages you
have recently accessed.
Games
(Menu 6.2)
You can download Java applications from various
sources using the web browser, and store them in your
phone.
Launching a game
1. Select the game you want on the Games list.
2. On the startup screen of the game, you can access
the following options:
•
START GAME
: start a new game.
•
CONTINUE
: continue the last game you
played.
•
HIGH SCORE
: view the high score table. This
option may not be available for some games.
•
HOW TO PLAY
: view how to play the game
and the key functions for the game.
•
OPTION
: switch on or off the game sound.
3. Press [ ] to confirm your selection.
Viewing game information
Scroll to the game you want and press <
Info
>.
Changing the DNS settings
You may need to change the DNS setting of the Java
server at your service provider’s instructions.
1. Select
Setting
on the Games list.
2. Enter the primary DNS address and press <
OK
>.
Java services may not available, depending on your
service provider.
46
Menu functions
3. Enter the secondary DNS address and press
<
OK
>.
Sounds
(Menu 6.3)
This menu displays sounds downloaded from the
wireless web or received in messages.
While accessing a sound, press <
Options
> to access
the following options:
•
Rename
: change the sound name.
•
Delete
: delete the sound.
•
Set as ring tone
: set the sound as your ringtone.
Images
(Menu 6.4)
This menu displays images downloaded from the
wireless web or received in messages.
While accessing an image, press <
Options
> to access
the following options:
•
Rename
: change the image name.
•
Delete
: delete the image.
•
Set as wallpaper
: set the image as your
wallpaper for the idle screen.
Delete all
(Menu 6.5)
Use this menu to delete all of the downloaded items in
the
Games
,
Sounds
, and
Images
folders.
1. Press [ ] to select the folders to be cleared.
2. Press <
Delete
>.
3. Press <
Yes
> twice to confirm the deletion.
Memory status
(Menu 6.6)
Use this menu to check the total amount of memory
for media items and the amount of memory currently
in use in each media box.
Organiser
(Menu 7)
The Organiser feature enables you to keep track of
your schedule and tasks, and to record voice memos.
You can also set the time and date and use convenient
features, such as an alarm clock, a calculator, and a
currency converter.
To access this menu, press <
Menu
> in Idle mode and
select
Organiser
.
Menu functions
Organiser
(Menu 7)
47
Alarm
(Menu 7.1)
Use this menu to set alarms to ring at a specific time.
Setting an alarm
1. Select the type of alarm.
2. Enter the time for the alarm to sound and press
[].
3. Select
AM
or
PM
in 12-hour time format.
4. If you selected
Morning call
in step 1, choose
Monday to friday
or
Monday to saturday
.
Stopping an alarm
• When the alarm sounds, press any key.
• To remove an alarm set, access it, press
<
Options
> and select
Remove alarm
.
• To remove all alarm sets, select
Remove alarm
from the Alarm screen.
Setting the alarm to ring even if the phone is
off
From the Alarm screen, select
Autopower
→
Enable
.
If the phone is off when it is time for the alarm to ring,
the phone switches on and sounds the alarm.
Calendar
(Menu 7.2)
Use this menu to consult the calendar, write memos,
or set alarms to act as a reminder.
Writing a memo
1. Select a date on the calendar.
2. Enter your memo and press <
OK
>.
3. Press [ ] to set an alarm to ring on the chosen
day.
Otherwise, press <
Skip
>.
4. Enter the time for the alarm and press [ ].
To select an alarm melody, press <
Melody
>.
5. Select
AM
or
PM
in 12-hour format.
The colour of the date on the calendar changes to
pink to indicate that a memo exists for that date.
48
Menu functions
Viewing a memo
1. Select a date which has memos from the calendar.
2. Press [Up] or [Down] to view other memos
scheduled for that day.
Using calendar memo options
On the calendar screen, press <
Options
> to access
the following options:
•
Search all
: view all of the memos you created.
•
Delete all
: delete all memos.
•
Go to date
: go to a specific date.
•
Exit
: exit the
Calendar
menu.
While viewing a memo, press <
Options
> to access
the following options:
•
New
: add a new memo.
•
Edit
: edit the memo.
•
Alarm
: set an alarm for the memo.
•
Delete
: delete the memo.
•
Copy to
: copy the memo to another date.
•
Move to
: change the date of the memo.
Time & Date
(Menu 7.3)
Use this menu to change the time and date displayed
on your phone. Before setting the time and date,
specify your time zone in
World time
.
•
Set time
: enter the current time.
•
Set date
: enter the current date.
•
World time
: set your local time zone and find out
what time it is in another part of the world.
•
Time format
: select 12-hour or 24-hour time
format.
Calculator
(Menu 7.4)
Use this menu to perform basic arithmetic functions
such as addition, subtraction, multiplication, and
division.
1. Enter the first number.
•Press <
.()
> to insert a decimal point or a
bracket.
•
Press
[
] or [ ] to move the cursor.
Menu functions
Organiser
(Menu 7)
49
2. Press the Navigation keys to access the math
function you want.
3. Enter the second number.
4. Press [ ] to view the result.
5. If necessary, repeat from step 2 to continue the
calculation.
To do list
(Menu 7.5)
Use this menu to create tasks and manage them.
Creating a task
1. Press <
New
>.
2. Enter the first task and press <
OK
>.
3. Select a priority level.
4. Enter your deadline and press [ ].
Viewing the task
When you select the To do list menu, the tasks display
with a check mark, if the task has been done, and a
priority level indicator; for High, for Normal,
and for Low.
While viewing a task or the task list, press <
Options
>
to access the following options:
•
New
: add a new task.
•
Mark
: change the status of the task.
•
Edit
: edit the task.
•
Sort
: sort the task by priority or status.
•
Copy
: copy the task.
•
Copy to calendar
: copy the task to the calendar
as a memo.
•
Delete
: delete the task.
•
Delete all
: delete all tasks.
•
Exit
: exit the
To do list
menu.
To change the status of a specific task, press [
]
.
50
Menu functions
Voice memo
(Menu 7.6)
Use this menu to record voice memos. A voice memo
can be up to 30 seconds.
Voice record
(Menu 7.6.1)
1. Press <
Record
> to start recording.
2. Speak into the microphone.
3. When you press <
Stop
>, or if the recording time
expires, the following options display:
•
Replay
: play back your memo.
•
Re-record
: discard the memo and record
another one.
•
Save
: save the memo.
•
Quit
: cancel your recording and exit the
Voice
memo
menu.
4. Select
Save
to save the voice memo.
5. Enter a name of the voice memo and press <
OK
>.
Memo list
(Menu 7.6.2)
Use this menu to access the list of voice memos you
have recorded.
Press <
Options
> to access the following options:
•
Play
: play back your voice memo.
•
Send
: send the voice memo via MMS.
•
Rename
: change the name of the voice memo.
•
Information
: access the properties of the voice
memo.
•
Delete
: delete the voice memo.
Delete all
(Menu 7.6.3)
Use this menu to delete all of the voice memos you
have recorded at one time.
Memory status
(Menu 7.6.4)
You can check the total amount of memory and the
amount of memory currently in use for voice memos.
Currency exchange
(Menu 7.7)
Use this menu to do currency conversions.
1. Enter the rate of foreign currency and press
<
OK
>.
Menu functions
Phonebook
(Menu 8)
51
2. Enter the amount of the source currency you want
to convert and press <
OK
>.
The amount you entered and its equivalent value
in the foreign currency display.
Phonebook
(Menu 8)
You can store phone numbers on your SIM card and in
your phone’s memory. The SIM card and phone’s
memory are physically separate, but they are used as
a single entity called Phonebook.
To access this menu, press <
Menu
> in Idle mode and
select
Phonebook
, or press <
Phonebook
>.
Search
(Menu 8.1)
Use this menu to search for numbers in Phonebook.
Finding an entry
1. Enter the first few letters of the name that you
want to find.
2. Select an entry from the Phonebook list.
3. Scroll to a number and press [ ] to dial, or press
<
Options
> to access Phonebook options.
Using Phonebook options
While viewing an entry, press <
Options
> to access
the following options:
•
Paste
: paste the number into the normal dialling
mode.
•
Edit
: edit entry information.
•
Delete
: delete the number.
•
Copy
: copy the number to the phone’s memory or
SIM card.
•
Caller group
: assign a caller group.
•
Add entry
: add a new entry.
•
Send via IrDA
: send the entry via infrared port.
New entry
(Menu 8.2)
Use this menu to add a new entry to Phonebook.
Storing an entry in the phone’s memory
1. Select a number type.
52
Menu functions
2. Select
Phone
.
3. Enter a name and press <
OK
>.
4. Enter a number or an e-mail address and press
<
Save
>.
5. Change the location number, if you want, and
press <
OK
>.
Storing an entry on the SIM card
1. Select a number type.
2. Select
SIM
.
3. Enter a name and press <
OK
>.
4. Enter a number and press <
Save
>
5. Change the location number, if you want, and
press <
OK
>.
Group search
(Menu 8.3)
Use this menu to search your entries in Phonebook in
caller groups.
1. Enter the first few letters of the group name.
2. Select a group and press <
View
>.
3. Select the name you want.
4. Press [ ] to dial the number or <
Options
> to
access Phonebook options.
Edit group
(Menu 8.4)
Use this menu to edit your caller groups’ properties.
From the group list, press <
Options
> to access the
following options:
•
Call ring tone
: set a ringtone for incoming calls
from the group.
•
SMS tone
: set a ringtone for incoming messages
from the group.
•
Graphic
: set a graphic icon for incoming calls from
the group.
•
Group name
: assign a name to the group.
Speed dial
(Menu 8.5)
Use this menu to assign speed dial numbers (2 to 9) to
eight of your most frequently called numbers.
Menu functions
Phonebook
(Menu 8)
53
Assigning speed dial entries
1. Select a key location from
2
to
9
. Key
1
is reserved
for your voicemail server.
2. Select an entry from the Phonebook list.
3. Select a number, if the entry has more than one
number.
Managing speed dial entries
While viewing the Speed dial screen, press
<
Options
> to access the following options:
•
Change
: assign a different number to a key.
•
Delete
: delete the speed dial setting for a key.
•
Delete all
: delete the speed dial settings for all
keys.
•
Number
: check the name and number assigned to
a key.
Dialling speed dial entries
Press and hold the appropriate key in Idle mode.
Delete all
(Menu 8.6)
Use this menu to delete all of the entries from
Phonebook.
1. Press [ ] to select the locations to be cleared.
2. Press <
Delete
>.
3. Enter the phone password and press <
OK
>.
4. Press <
Yes
> twice to confirm the deletion.
Memory status
(Menu 8.7)
Use this menu to check the total number of entries
you can store and the number of the entries you have
stored in the phone’s memory or on the SIM card.
SDN
(Menu 8.8)
This menu is available if your SIM card supports
Service Dialling Numbers (SDN). Use this menu to
view the list of SDNs assigned by your service
provider, including emergency numbers, directory
enquiries, and voicemail numbers.
Scroll to the number you want and press <
Dial
> or
[].
54
Menu functions
Phone settings
(Menu 9)
Use this menu to customise your phone settings. You
can also reset the settings to their default values.
To access this menu, press <
Menu
> in Idle mode and
select
Phone settings
.
Infrared activate
(Menu 9.1)
Use this menu to send or receive data to or from IrDA-
compatible computers or phones through the infrared
port.
With PC
(Menu 9.1.1)
Use this menu to use the infrared feature with a
computer.
To use an infrared connection, you must:
• configure and activate an IrDA-compliant infrared
port on your PC.
• activate the infrared feature on the phone; the
IrDA icon ( ) appears on the top line of the
display.
• align the IrDA port on the phone with the IrDA port
on your phone computer or another phone.
The connection is ready for data transmission.
If there is no communication between your phone and
the IrDA-compliant device within 30 seconds
activating the feature, it is automatically deactivated.
With other phone
(Menu 9.1.2)
Use this menu to send or receive Phonebook entries
from another compliant phone.
Receiving data from another phone
1. Align the IrDA ports on both phones with each
other.
Menu functions
Phone settings
(Menu
55
2. When the list of the received data displays, select
one of the two options:
To save an individual item:
1. Select the item you want from the list.
2. Press <
Options
> and select
Save
to save the
data.
Otherwise, select
Discard
to delete the data.
To save all data:
1. From the item list, press <
Options
> to select
one of the following options:
•
Save all vCard
: save all Phonebook entries.
•
Discard all vCard
: delete all Phonebook
entries.
•
Exit
: exit the IrDA function.
2. When FDN (Fixed Dialling Number) mode is
enabled on your phone, enter the PIN2 and
press <
OK
>.
3. Press <
Save
> to save the entries.
Sending your Phonebook
You can send Phonebook entries via IrDA connection.
Display settings
(Menu 9.2)
Use this menu to change settings for the display and
light.
Wallpaper
(Menu 9.2.1)
You can change the background image and the
settings for the text of Idle mode.
•
Wallpaper list
: select a background image.
•
Text display
: determine the phone displays the
time and date.
•
Text colour
: select a text colour.
Brightness
(Menu 9.2.2)
You can adjust the brightness of the display for
varying lighting conditions.
56
Menu functions
Contrast
(Menu 9.2.3)
You can adjust the contrast of the display for varying
lighting conditions.
Backlight
(Menu 9.2.4)
You can select the length of time the backlight and the
display stay on.
•
Backlight on
: select the length of time the
backlight stays on.
•
Backlight dim
: select the length of time the
display is in Dimming mode after the backlight
turns off. After a specified time, the display turns
off.
Service light
(Menu 9.2.5)
The service LED on the front of the phone indicates
when service is available on the phone. Use this menu
to set whether or not the service light is used.
Graphic logo
(Menu 9.2.6)
Use this menu to display your service provider’s logo
instead of its name.
Dialling font colour
(Menu 9.2.7)
Use this menu to select a font colour for the numbers
entered while dialling.
Greeting message
(Menu 9.3)
Use this menu to enter the greeting that is displayed
briefly when the phone is switched on.
Own number
(Menu 9.4)
Use this feature to check your phone numbers, or to
assign a name to each of the numbers. Changes made
here do not affect the actual subscriber numbers on
your SIM card.
Language
(Menu 9.5)
Use this menu to select one of several languages for
the display text.
Menu functions
Phone settings
(Menu
57
Security
(Menu 9.6)
Use this menu to protect the phone against
unauthorised use by managing the several access
codes of your phone and SIM card.
PIN check
(Menu 9.6.1)
The 4-to 8-digit PIN (Personal Identification Number)
protects your SIM card against unauthorised use.
When this feature is enabled, the phone requires your
PIN each time it is switched on.
Change PIN
(Menu 9.6.2)
Use this menu to change your PIN. The PIN check
feature must be enabled to use this feature.
Phone lock
(Menu 9.6.3)
The Phone lock feature locks the phone from
unauthorised use.
When this feature is enabled, you must enter a 4- to
8-digit phone password each time the phone is
switched on.
The password is preset to
00000000
. To change the
password, use the
Change password
menu.
Change password
(Menu 9.6.4)
Use this menu to change your phone password.
Privacy
(Menu 9.6.5)
Use this menu to lock your media contents, including
MMS messages, voice memos, images, and sounds.
1. Press [ ] to select the items to be locked.
2. Press <
OK
> to lock the marked items.
3. Enter the phone password and press <
OK
>.
To access a locked item, you need to enter the phone
password.
If you enter an incorrect PIN/PIN2 three times in
succession, the SIM card is blocked. To unblock it
you need to enter your PUK/PUK2 (Personal
Unblocking Key). The codes are supplied by your
network operator.
58
Menu functions
SIM lock
(Menu 9.6.6)
The SIM lock feature allows your phone to work only
with the current SIM by assigning a SIM lock code. You
must enter the SIM lock code to use a different SIM
card.
FDN mode
(Menu 9.6.7)
If supported by your SIM card, Fixed Dialling Number
(FDN) mode restricts your outgoing calls to a limited
set of phone numbers. When this feature is enabled,
you can make calls only to phone numbers stored on
the SIM card.
Change PIN2
(Menu 9.6.8)
If supported by your SIM card, the Change PIN2
feature changes your current PIN2.
Extra settings
(Menu 9.7)
You can turn the automatic redialling or answering
feature on or off.
•
Auto redial
: set the phone to make up to ten
attempts to redial a phone number after an
unsuccessful call.
•
Active folder
: answer an incoming call by opening
the phone.
•
Anykey
answer
: answer an incoming call by
pressing any key, except <
Reject
> or [ ].
Short cut
(Menu 9.8)
You can use the Navigation keys as shortcut keys to
access specific menus directly from Idle mode. Use
this menu to change the shortcut assignments for the
keys.
1. Select a key to be used as a shortcut key.
2. Select a menu to be assigned to the key.
Reset settings
(Menu 9.9)
Use this menu to reset the phone’s settings you have
changed.
Enter the 4- to 8-digit phone password and press
<
OK
>.
The password is preset to
00000000
. You can
change this password.
p. 57
59
Solve problems
Help and personal needs
To save the time and expense of an unnecessary service
call, perform the simple checks in this section before
contacting a service professional.
When you switch on your phone, the
following messages may appear:
“Insert SIM card”
• Be sure that the SIM card is correctly installed.
“Phone locked Enter password”
• The automatic locking function has been enabled.
You must enter the phone’s password before you
can use the phone.
“Enter PIN”
• You are using your phone for the first time. You
must enter the PIN supplied with the SIM card.
• The PIN check feature is enabled. Every time the
phone is switched on, the PIN has to be entered.
To disable this feature, use the
PIN check
menu.
“Enter PUK”
• The PIN code has been entered incorrectly three
times in succession, and the phone is now blocked.
Enter the PUK supplied by your service provider.
“No service,” “Network failure,” or “Not
done” displays
• The network connection has been lost. You may be
in a weak signal area. Move and try again.
• You are trying to access an option for which you
have no subscription with your service provider.
Contact the service provider for further details.
You have entered a number but it was not
dialled
• Be sure that you have pressed [ ].
• Be sure you have accessed the right cellular
network.
• Be sure that you have not set an outgoing call
barring option.
Your correspondent cannot reach you
• Be sure your phone is switched on. ([ ] pressed
for more than one second.)
60
No number is dialled when you re-call a Contacts
entry
•Use the
Contacts list
menu to ensure the number
has been stored correctly.
• Re-store the number, if necessary.
The battery doesn’t charge properly or the phone
sometimes turns itself off
• Wipe the charging contacts both on the phone and
on the battery with a clean soft cloth.
If the above guidelines do not help you to solve
the problem, take note of:
• The model and serial numbers of your phone
•Your warranty details
• A clear description of the problem
Then contact your local dealer or Samsung after-sales
service.
Health and safety information
Exposure to Radio Frequency (RF) Signals
Your wireless phone is a radio transmitter and receiver. It
is designed and manufactured not to exceed the emission
limits for exposure to radio frequency (RF) energy set by
the Federal Communications Commission (FCC) of the
U.S. Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for
the general population. The guidelines are based on the
safety standards that were developed by independent
scientific organizations through periodic evaluation of
scientific studies.
The standards include a substantial safety margin
designed to assure the safety of all persons, regardless of
age and health.
The exposure standard for wireless phones employs a unit
of measurement known as Specific Absorption Rate (SAR).
The SAR limit recommended by the FCC is 1.6W/kg.
*
SAR tests are conducted using standard operating
positions specified by the FCC with the phone transmitting
at its highest certified power level in all tested frequency
61
Health and safety information
bands. Although the SAR is determined at the highest
certified power level, the actual SAR level of the phone
while operating can be well below the maximum value.
This is because the phone is designed to operate at
multiple power levels so as to use only the power required
to reach the network. In general, the closer you are to a
wireless base station antenna, the lower the power output
of the phone.
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that it
does not exceed the limit established by the government
adopted requirement for safe exposure. The tests are
performed in positions and locations (e.g., at the ear and
worn on the body) as required by the FCC for each model.
While there may be differences between the SAR levels of
various phones and at various positions, they all meet the
government requirement.
The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as in
compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC
and can be found under the Display Grant section of http:/
/www.fcc.gov/oet/fccid after searching on FCC ID printed
in the label on the phone.
For Body Operation
For body worn operation, this model phone has been
tested and meets the FCC RF exposure guidelines when
used with a Samsung-supplied or approved accessory
designated for this product or when used with an
accessory that contains no metal and that positions the
handset a minimum distance from the body.
The minimum distance for this model phone from the body
is written in the FCC certification information. None
compliance with the above conditions may violate FCC RF
exposure guidelines.
For more Information concerning exposure to radio
frequency signals, see the following websites:
Federal Communications Commission (FCC)
http://www.fcc.gov
*
In the U.S. and Canada, the SAR limit for mobile phones used
by the public is 1.6 watts/kg (W/kg) averaged over one gram
of tissue. The standard incorporates a substantial margin of
safety to give additional protection for the public and to
account for any variations in measurements.
62
Health and safety information
Cellular Telecommunications Industry Association (CTIA):
http://www.wow-com.com
U.S.Food and Drug Administration (FDA)
http://www.fda.gov/cdrh/consumer
World Health Organization (WHO)
http://www.who.int/peh-emf/en
Precautions When Using Batteries
• Never use any charger or battery that is damaged in
any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network’s base station,
it uses less power; talk and standby time are greatly
affected by the signal strength on the cellular network
and the parameters set by the network operator.
• Battery charging time depends on the remaining
battery charge, the type of battery and the charger
used. The battery can be charged and discharged
hundreds of times, but it will gradually wear out. When
the operation time (talk time and standby time) is
noticeably shorter than normal, it is time to buy a new
battery.
• If left unused, a fully charged battery will discharge
itself over time.
• Use only Samsung-approved batteries and recharge
your battery only with Samsung-approved chargers.
When a charger is not in use, disconnect it from the
power source. Do not leave the battery connected to a
charger for more than a week, since overcharging may
shorten its life.
• Extreme temperatures will affect the charging capacity
of your battery: it may require cooling or warming
first.
• Do not leave the battery in hot or cold places, such as
in a car in summer or winter conditions, as you will
reduce the capacity and lifetime of the battery. Always
try to keep the battery at room temperature. A phone
with a hot or cold battery may temporarily not work,
even when the battery is fully charged. Li-ion batteries
are particularly affected by temperatures below 0 °C
(32 °F).
• Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object (coin, clip
or pen) causes a direct connection between the + and
– terminals of the battery (metal strips on the
battery), for example when you carry a spare battery
in a pocket or bag. Short-circuiting the terminals may
damage the battery or the object causing the short-
circuiting.
63
Health and safety information
• Dispose used batteries in accordance with local
regulations. Always recycle. Do not dispose batteries
in a fire.
Road Safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime. But an
important responsibility accompanies the benefits of
wireless phones, one that every user must uphold.
When driving a car, driving is your first responsibility.
When using your wireless phone behind the wheel of a car,
practice good common sense and remember the following
tips:
• Get to know your wireless phone and its features, such
as speed dial and redial. If available, these features
help you to place your call without taking your
attention off the road.
• When available, use a hands-free device. If possible,
add an extra layer of convenience and safety to your
wireless phone with one of the many hands-free
accessories available today.
• Position your wireless phone within easy reach. Be
able to access your wireless phone without removing
your eyes from the road. If you get an incoming call at
an inconvenient time, let your voice mail answer it for
you.
• Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy traffic
or hazardous weather conditions. Rain, sleet, snow, ice
and even heavy traffic can be hazardous.
• Do not take notes or look up phone numbers while
driving. Jotting down a To Do list or flipping through
your phonebook takes your attention away from your
primary responsibility, driving safely.
• Dial sensibly and assess the traffic; if possible, place
calls when you are not moving or before pulling into
traffic. Try to plan calls when your car will be
stationary. If you need to make a call while moving,
dial only a few numbers, check the road and your
mirrors, then continue.
• Do not engage in stressful or emotional conversations
that may be distracting. Make the people to whom you
are talking aware that you are driving and suspend
conversations that have the potential to divert your
attention from the road.
• Use your wireless phone to call for help. Dial the
emergency number in the case of fire, traffic accident
or medical emergencies. Remember, it is a free call on
your wireless phone!
• Use your wireless phone to help others in
emergencies. If you see a car accident, crime in
progress or other serious emergency where lives are
64
Health and safety information
in danger, call the emergency number, as you would
want others to do for you.
• If you see a broken-down vehicle posing no serious
hazard, a broken traffic signal, a minor traffic accident
where no one appears injured, or a vehicle you know
to be stolen, call roadside assistance or any other
special non-emergency wireless number.
Operating Environment
Remember to follow any special regulations in force in any
area and always switch your phone off whenever it is
forbidden to use it, or when it may cause interference or
danger.
When connecting the phone or any accessory to another
device, read its user’s guide for detailed safety
instructions. Do not connect incompatible products.
As with other mobile radio transmitting equipment, users
are advised that for the satisfactory operation of the
equipment and for the safety of personnel, it is
recommended that the equipment should only be used in
the normal operating position (held to your ear with the
antenna pointing over your shoulder).
Electronic Devices
Most modern electronic equipment is shielded from radio
frequency (RF) signals. However, certain electronic
equipment may not be shielded against the RF signals
from your wireless phone. Consult the manufacturer to
discuss alternatives.
Pacemakers
• Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be maintained
between a wireless phone and a pacemaker to avoid
potential interference with the pacemaker. These
recommendations are consistent with the independent
research and recommendations of Wireless Technology
Research.
• Persons with pacemakers:
• should always keep the phone more than 15 cm (6
inches) from their pacemaker when the phone is
switched on.
• should not carry the phone in a breast pocket.
• should use the ear opposite the pacemaker to
minimize potential interference.
If you have any reason to suspect that interference is
taking place, switch your phone off immediately.
65
Health and safety information
Hearing Aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you may
wish to consult your hearing aid manufacturer to discuss
alternatives.
Other Medical Devices
If you use any other personal medical devices, consult the
manufacturer of your device to determine if it is
adequately shielded from external RF energy. Your
physician may be able to assist you in obtaining this
information. Switch your phone off in health care facilities
when any regulations posted in these areas instruct you to
do so. Hospitals or health care facilities may be using
equipment that could be sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles. Check with
the manufacturer or its representative regarding your
vehicle. You should also consult the manufacturer of any
equipment that has been added to your vehicle. You
should also consult the manufacturer of any equipment
that has been added to your vehicle.
Posted Facilities
Switch your phone off in any facility where posted notices
require you to do so.
Potentially Explosive Environments
Switch your phone off when in any area with a potentially
explosive atmosphere and obey all signs and instructions.
Sparks in such areas could cause an explosion or fire
resulting in bodily injury or even death.
Users are advised to switch the phone off while at a
refueling point (service station). Users are reminded of the
need to observe restrictions on the use of radio equipment
in fuel depots (fuel storage and distribution areas),
chemical plants or where blasting operations are in
progress.
Areas with a potentially explosive atmosphere are often
but not always clearly marked. They include the areas
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas (such as
propane or butane), areas where the air contains
chemicals or particles, such as grain, dust or metal
powders, and any other area where you would normally be
advised to turn off your vehicle engine.
66
Health and safety information
Emergency Calls
This phone, like any wireless phone, operates using radio
signals, wireless and landline networks as well as user-
programmed functions, which cannot guarantee
connection in all conditions. Therefore, you should never
rely solely on any wireless phone for essential
communications (medical emergencies, for example).
Remember, to make or receive any calls the phone must
be switched on and in a service area with adequate signal
strength. Emergency calls may not be possible on all
wireless phone networks or when certain network services
and/or phone features are in use. Check with local service
providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location (for example, 911 or other official emergency
number). Emergency numbers vary by location.
3. Press
[]
.
If certain features are in use (call barring, for example),
you may first need to deactivate those features before you
can make an emergency call. Consult this document and
your local cellular service provider.
When making an emergency call, remember to give all the
necessary information as accurately as possible.
Remember that your phone may be the only means of
communication at the scene of an accident; do not cut off
the call until given permission to do so.
Other Important Safety Information
• Only qualified personnel should service the phone or
install the phone in a vehicle. Faulty installation or
service may be dangerous and may invalidate any
warranty applicable to the device.
• Check regularly that all wireless phone equipment in
your vehicle is mounted and operating properly.
• Do not store or carry flammable liquids, gases or
explosive materials in the same compartment as the
phone, its parts or accessories.
• For vehicles equipped with an air bag, remember that
an air bag inflates with great force. Do not place
objects, including both installed or portable wireless
equipment in the area over the air bag or in the air
bag deployment area. If wireless equipment is
improperly installed and the air bag inflates, serious
injury could result.
67
Health and safety information
• Switch your phone off before boarding an aircraft. The
use of wireless phones in aircraft is illegal and may be
dangerous to the aircraft’s operation.
• Failure to observe these instructions may lead to the
suspension or denial of telephone services to the
offender, or legal action, or both.
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for many
years:
• Keep your phone and all its parts and accessories out
of the reach of small children and pets. They may
inadvertently damage these things or choke on small
parts.
• Keep the phone dry. Precipitation, humidity and liquids
contain minerals that will corrode electronic circuits.
• Do not use the phone with a wet hand. Doing so may
cause an electric shock to you or damage to the
phone.
• Do not use or store the phone in dusty, dirty areas, as
its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt certain
plastics.
• Do not store the phone in cold areas. When the phone
warms up to its normal operating temperature,
moisture can form inside the phone, which may
damage the phone’s electronic circuit boards.
• Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the phone. Wipe it with a
soft cloth slightly dampened in a mild soap-and-water
solution.
• Do not paint the phone. Paint can clog the device’s
moving parts and prevent proper operation.
• Do not put the phone in or on heating devices, such as
a microwave oven, a stove or a radiator. The phone
may explode when overheated.
• When the phone or battery gets wet, the label
indicating water damage inside the phone changes
colour. In this case, phone repairs are no longer
guaranteed by the manufacturer's warranty, even if
the warranty for your phone has not expired.
68
Health and safety information
• If your phone has a flash or light, do not use it too
close to the eyes of people or animals. This may cause
damage to their eyes.
• Use only the supplied or an approved replacement
antenna. Unauthorized antennas or modified
accessories may damage the phone and violate
regulations governing radio devices.
• If the phone, battery, charger or any accessory is not
working properly, take it to your nearest qualified
service facility. The personnel there will assist you, and
if necessary, arrange for service.
Acknowledging Special Precautions and
the FCC and Industry Canada Notice
Cautions
Modifications not expressly approved by the party
responsible for compliance could void the user's authority
to operate the equipment.
FCC Compliance Information
This device complies with Part 15 of FCC Rules. Operation
is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received.
• Including interference that may cause undesired
operation.
Information to User
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
69
Health and safety information
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/ TV
technician for help.
Appendix A: CERTIFICATION
INFORMATION (SAR)
THIS MODEL PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It
is designed and manufactured not to exceed the emission
limits for exposure to radio frequency (RF) energy set by
the Federal Communications Commission of the U.S.
Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for
the general population. The guidelines are based on safety
standards that were developed by independent scientific
organizations through periodic and thorough evaluation of
scientific studies. The standards include a substantial
safety margin designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless mobile phones
employs a unit of measurement known as the Specific
Absorption Rate (SAR). The SAR limit set by the FCC is 1.6
W/kg. SAR Tests are conducted using standard operating
positions accepted by the FCC with the phone transmitting
at its highest certified power level in all tested frequency
bands. Although the SAR is determined at the highest
certified power level, the actual SAR level of the phone
while operating can be well below the maximum value.
This is because the phone is designed to operate at
multiple power levels so as to use only the power required
to reach the network. In general, the closer you are to a
wireless base station antenna, the lower the power
output.
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that it
does not exceed the limit established by the government
adopted requirement for safe exposure. The tests are
performed in positions and locations(e.g., at the ear and
worn on the body) as required by the FCC for each model.
The highest SAR values of this model phone as reported to
FCC are Head: 1.44W/kg, Body-worn: 0.677W/kg in GSM
1900.
Body-worn operations are restricted to Samsung-supplied,
approved or none Samsung designated accessories that
have no metal and must provide at least 1.5cm separation
between the device, including its antenna whether
70
H ealth and safety information
extended or retracted, and the user’s body. None
compliance to the above restrictions may violate FCC RF
exposure guidelines.
The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as in
compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC
and can be found under the Display Grant section of http:/
/www.fcc.gov/oet/fccid after searching on FCC ID
A3LSGHX200.
In the United States and Canada, the SAR limit for mobile
phones used by the public is 1.6 watts/kilogram (W/kg)
averaged over one gram of tissue. The standard incorpo-
rates a substantial ma gin of safety to give additional
protection for the public and to account for any variations
in measurements.
Appendix B: Guide to Safe and Responsible
Wireless Phone Use
Cellular Telecommunications & Internet Association
“Safety is the most important call you will ever make.”
A Guide to Safe and Responsible Wireless
Phone Use
TENS OF MILLIONS OF PEOPLE IN THE U.S. TODAY TAKE
ADVANTAGE OF THE UNIQUE COMBINATION OF
CONVENIENCE, SAFETY AND VALUE DELIVERED BY THE
WIRELESS TELEPHONE. QUITE SIMPLY, THE WIRELESS
PHONE GIVES PEOPLE THE POWERFUL ABILITY TO
COMMUNICATE BY VOICE-ALMOST ANYWHERE, ANYTIME-
WITH THE BOSS, WITH A CLIENT, WITH THE KIDS, WITH
EMERGENCY PERSONNEL OR EVEN WITH THE POLICE.
EACH YEAR, AMERICANS MAKE BILLIONS OF CALLS FROM
THEIR WIRELESS PHONES, AND THE NUMBERS ARE
RAPIDLY GROWING.
But an important responsibility accompanies those
benefits, one that every wireless phone user must uphold.
When driving a car, driving is your first responsibility.
A wireless phone can be an invaluable tool, but good
judgment must be exercised at all times while driving a
motor vehicle whether on the phone or not.
The basic lessons are ones we all learned as teenagers.
Driving requires alertness, caution and courtesy. It
requires a heavy dose of basic common sense-keep your
71
Health and safety information
head up, keep your eyes on the road, check your mirrors
frequently and watch out for other drivers. It requires
obeying all traffic signs and signals and staying within the
speed limit. It means using seat belts and requiring other
passengers to do the same.
But with wireless phone use, driving safely means a little
more. This brochure is a call to wireless phone users
everywhere to make safety their first priority when behind
the wheel of a car. Wireless telecommunications is keeping
us in touch, simplifying our lives, protecting us in
emergencies and providing opportunities to help others in
need. When it comes to the use of wireless phones, safety
is your most important call.
Wireless Phone “Safety Tips”
Below are safety tips to follow while driving and using a
wireless phone which should be easy to remember:
1. Get to know your wireless phone and its features such
as speed dial and redial. Carefully read your
instruction manual and learn to take advantage of
valuable features most phones offer, including
automatic redial and memory. Also, work to memorize
the phone keypad so you can use the speed dial
function without taking your attention off the road.
2. When available, use a hands free device. A number of
hands free wireless phone accessories are readily
available today. Whether you choose an installed
mounted device for your wireless phone or a speaker
phone accessory, take advantage of these devices if
available to you.
3. Position your wireless phone within easy reach. Make
sure you place your wireless phone within easy reach
and where you can grab it without removing your eyes
from the road. If you get an incoming call at an
inconvenient time, if possible, let your voice mail
answer it for you.
4. Suspend conversations during hazardous driving
conditions or situations. Let the person you are
speaking with know you are driving; if necessary,
suspend the call in heavy traffic or hazardous weather
conditions. Rain, sleet, snow and ice can be
hazardous, but so is heavy traffic. As a driver, your
first responsibility is to pay attention to the road.
5. Do not take notes or look up phone numbers while
driving. If you are reading an address book or
business card, or writing a “to do” list while driving a
car, you are not watching where you are going. It’s
common sense. Don’t get caught in a dangerous
situation because you are reading or writing and not
paying attention to the road or nearby vehicles.
72
Health and safety information
6. Dial sensibly and assess the traffic; if possible, place
calls when you are not moving or before pulling into
traffic. Try to plan your calls before you begin your trip
or attempt to coincide your calls with times you may
be stopped at a stop sign, red light or otherwise
stationary. But if you need to dial while driving, follow
this simple tip-dial only a few numbers, check the road
and your mirrors, then continue.
7. Do not engage in stressful or emotional conversations
that may be distracting. Stressful or emotional
conversations and driving do not mix-they are
distracting and even dangerous when you are behind
the wheel of a car. Make people you are talking with
aware you are driving and if necessary, suspend
conversations which have the potential to divert your
attention from the road.
8. Use your wireless phone to call for help. Your wireless
phone is one of the greatest tools you can own to
protect yourself and your family in dangerous
situations-with your phone at your side, help is only
three numbers away. Dial 9-1-1 or other local
emergency number in the case of fire, traffic accident,
road hazard or medical emergency. Remember, it is a
free call on your wireless phone!
9. Use your wireless phone to help others in
emergencies. Your wireless phone provides you a
perfect opportunity to be a “Good Samaritan” in your
community. If you see an auto accident, crime in
progress or other serious emergency where lives are
in danger, call 9-1-1 or other local emergency number,
as you would want others to do for you.
10. Call roadside assistance or a special wireless non
emergency assistance number when necessary.
Certain situations you encounter while driving may
require attention, but are not urgent enough to merit a
call for emergency services. But you still can use your
wireless phone to lend a hand. If you see a broken-
down vehicle posing no serious hazard, a broken traffic
signal, a minor traffic accident where no one appears
injured or a vehicle you know to be stolen, call
roadside assistance or other special non-emergency
wireless number.
Careless, distracted individuals and people driving
irresponsibly represent a hazard to everyone on the road.
Since 1984, the Cellular Telecommunications Industry
Association and the wireless industry have conducted
educational outreach to inform wireless phone users of
their responsibilities as safe drivers and good citizens. As
we approach a new century, more and more of us will take
73
Health and safety information
advantage of the benefits of wireless telephones. And, as
we take to the roads, we all have a responsibility to drive
safely.
“The wireless industry reminds you to use your phone
safely when driving.”
Cellular Telecommunications & Internet Association For
more information, please call 1-888-901-SAFE.
For updates: http://www.wow-com.com/consumer/issues/
driving/articles.cfm?ID =85
Appendix C: Consumer Update on Wireless
Phones
U.S. Food and Drug Administration
1. What kinds of phones are the subject of this update?
The term wireless phone refers here to hand-held wireless
phones with built-in antennas, often called cell, mobile, or
PCS phones. These types of wireless phones can expose
the user to measurable radio frequency energy (RF)
because of the short distance between the phone and the
user s head. These RF exposures are limited by Federal
Communications Commission safety guidelines that were
developed with the advice of FDA and other federal health
and safety agencies. When the phone is located at greater
distances from the user, the exposure to RF is drastically
lower because a person’s RF exposure decreases rapidly
with increasing distance from the source. The so-called
“cordless phones,” which have a base unit connected to
the telephone wiring in a house, typically operate at far
lower power levels, and thus produce RF exposures well
within the FCC’s compliance limits.
2. Do wireless phones pose a health hazard?
The available scientific evidence does not show that any
health problems are associated with using wireless
phones. There is no proof, however, that wireless phones
are absolutely safe. Wireless phones emit low levels of
radio frequency energy (RF) in the microwave range while
being used. They also emit very low levels of RF when in
the stand-by mode. Whereas high levels of RF can produce
health effects (by heating tissue), exposure to low level RF
that does not produce heating effects causes no known
adverse health effects. Many studies of low level RF
exposures have not found any biological effects. Some
studies have suggested that some biological effects may
occur, but such findings have not been confirmed by
additional research. In some cases, other researchers
have had difficulty in reproducing those studies, or in
determining the reasons for inconsistent results.
74
Health and safety information
What is FDA’s role concerning the safety of wireless
phones?
Under the law, FDA does not review the safety of radiation
emitting consumer products such as wireless phones
before they can be sold, as it does with new drugs or
medical devices. However, the agency has authority to
take action if wireless phones are shown to emit radio
frequency energy (RF) at a level that is hazardous to the
user. In such a case, FDA could require the manufacturers
of wireless phones to notify users of the health hazard and
to repair, replace or recall the phones so that the hazard
no longer exists.
Although the existing scientific data do not justify FDA
regulatory actions, FDA has urged the wireless phone
industry to take a number of steps, including the
following:
• Support needed research into possible biological
effects of RF of the type emitted by wireless phones;
• Design wireless phones in a way that minimizes any
RF exposure to the user that is not necessary for
device function; and
• Cooperate in providing users of wireless phones with
the best possible information on possible effects of
wireless phone use on human health
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at the
federal level. The following agencies belong to this
working group:
• National Institute for Occupational Safety and Health
• Environmental Protection Agency Federal
Communications Commission
• Occupational Safety and Health Administration
• National Telecommunications and Information
Administration
• The National Institutes of Health participates in some
interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless phones
with the Federal Communications Commission (FCC). All
phones that are sold in the United States must comply
with FCC safety guidelines that limit RF exposure. FCC
relies on FDA and other health agencies for safety
questions about wireless phones.
FCC also regulates the base stations that the wireless
phone networks rely upon. While these base stations
operate at higher power than do the wireless phones
themselves, the RF exposures that people get from these
75
Health and safety information
base stations are typically thousands of times lower than
those they can get from wireless phones. Base stations
are thus not the primary subject of the safety questions
discussed in this document.
3. What is FDA doing to find out more about the possible
health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology Program
and with groups of investigators around the world to
ensure that high priority animal studies are conducted to
address important questions about the effects of exposure
to radio frequency energy (RF).
FDA has been a leading participant in the World Health
Organization International Electromagnetic Fields (EMF)
Project since its inception in 1996. An influential result of
this work has been the development of a detailed agenda
of research needs that has driven the establishment of
new research programs around the world. The Project has
also helped develop a series of public information
documents on EMF issues.
FDA and the Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative Research
and Development Agreement (CRADA) to do research on
wireless phone safety. FDA provides the scientific
oversight, obtaining input from experts in government,
industry, and academic organizations. CTIA-funded
research is conducted through contracts to independent
investigators. The initial research will include both
laboratory studies and studies of wireless phone users.
The CRADA will also include a broad assessment of
additional research needs in the context of the latest
research developments around the world.
4. What steps can I take to reduce my exposure to radio
frequency energy from my wireless phone?
If there is a risk from these products—and at this point we
do not know that there is—it is probably very small. But if
you are concerned about avoiding even potential risks,
you can take a few simple steps to minimize your
exposure to radio frequency energy (RF). Since time is a
key factor in how much exposure a person receives,
reducing the amount of time spent using a wireless phone
will reduce RF exposure.
If you must conduct extended conversations by wireless
phone every day, you could place more distance between
your body and the source of the RF, since the exposure
level drops off dramatically with distance. For example,
you could use a headset and carry the wireless phone
away from your body or use a wireless phone connected to
a remote antenna
76
Health and safety information
Again, the scientific data do not demonstrate that wireless
phones are harmful. But if you are concerned about the RF
exposure from these products, you can use measures like
those described above to reduce your RF exposure from
wireless phone use.
5. What about children using wireless phones?
The scientific evidence does not show a danger to users of
wireless phones, including children and teenagers. If you
want to take steps to lower exposure to radio frequency
energy (RF), the measures described above would apply
to children and teenagers using wireless phones. Reducing
the time of wireless phone use and increasing the distance
between the user and the RF source will reduce RF
exposure.
Some groups sponsored by other national governments
have advised that children be discouraged from using
wireless phones at all. For example, the government in the
United Kingdom distributed leaflets containing such a
recommendation in December 2000. They noted that no
evidence exists that using a wireless phone causes brain
tumors or other ill effects. Their recommendation to limit
wireless phone use by children was strictly precautionary;
it was not based on scientific evidence that any health
hazard exists.
6. Do hands-free kits for wireless phones reduce risks
from exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that hands-free kits reduce risks. Hands-free kits
can be used with wireless phones for convenience and
comfort. These systems reduce the absorption of RF
energy in the head because the phone, which is the source
of the RF emissions, will not be placed against the head.
On the other hand, if the phone is mounted against the
waist or other part of the body during use, then that part
of the body will absorb more RF energy. Wireless phones
marketed in the U.S. are required to meet safety
requirements regardless of whether they are used against
the head or against the body. Either configuration should
result in compliance with the safety limit.
7. Do wireless phone accessories that claim to shield the
head from RF radiation work?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that accessories that claim to shield the head from
those emissions reduce risks. Some products that claim to
shield the user from RF absorption use special phone
cases, while others involve nothing more than a metallic
77
Health and safety information
accessory attached to the phone. Studies have shown that
these products generally do not work as advertised. Unlike
“hand-free” kits, these so-called “shields” may interfere
with proper operation of the phone. The phone may be
forced to boost its power to compensate, leading to an
increase in RF absorption. In February 2002, the Federal
trade Commission (FTC) charged two companies that sold
devices that claimed to protect wireless phone users from
radiation with making false and unsubstantiated claims.
According to FTC, these defendants lacked a reasonable
basis to substantiate their claim.
8. What about wireless phone interference with medical
equipment?
Radio frequency energy (RF) from wireless phones can
interact with some electronic devices. For this reason, FDA
helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted cardiac
pacemakers and defibrillators from wireless telephones.
This test method is now part of a standard sponsored by
the Association for the Advancement of Medical
instrumentation (AAMI). The final draft, a joint effort by
FDA, medical device manufacturers, and many other
groups, was completed in late 2000. This standard will
allow manufacturers to ensure that cardiac pacemakers
and defibrillators are safe from wireless phone EMI.
FDA has tested hearing aids for interference from
handheld wireless phones and helped develop a voluntary
standard sponsored by the Institute of Electrical and
Electronic Engineers (IEEE). This standard specifies test
methods and performance requirements for hearing aids
and wireless phones so that no interference occurs when a
person uses a compatible phone and a compatible hearing
aid at the same time. This standard was approved by the
IEEE in 2000.
FDA continues to monitor the use of wireless phones for
possible interactions with other medical devices. Should
harmful interference be found to occur, FDA will conduct
testing to assess the interference and work to resolve the
problem.
9. What are the results of the research done already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws in their
research methods. Animal experiments investigating the
effects of radio frequency energy (RF) exposures
characteristic of wireless phones have yielded conflicting
results that often cannot be repeated in other laboratories.
A few animal studies, however, have suggested that low
levels of RF could accelerate the development of cancer in
laboratory animals. However, many of the studies that
showed increased tumor development used animals that
78
Health and safety information
had been genetically engineered or treated with cancer
causing chemicals so as to be pre-disposed to develop
cancer in the absence of RF exposure. Other studies
exposed the animals to RF for up to 22 hours per day.
These conditions are not similar to the conditions under
which people use wireless phones, so we don t know with
certainty what the results of such studies mean for human
health.
Three large epidemiology studies have been published
since December 2000. Between them, the studies
investigated any possible association between the use of
wireless phones and primary brain cancer, gioma,
meningioma, or acoustic neuroma, tumors of the brain or
salivary gland, leukemia, or other cancers. None of the
studies demonstrated the existence of any harmful health
effects from wireless phone RF exposures. However, none
of the studies can answer questions about long-term
exposures, since the average period of phone use in these
studies was around three years.
10. What research is needed to decide whether RF
exposure from wireless phones poses a health risk?
A combination of laboratory studies and epidemiological
studies of people actually using wireless phones would
provide some of the data that are needed. Lifetime animal
exposure studies could be completed in a few years.
However, very large numbers of animals would be needed
to provide reliable proof of a cancer promoting effect if
one exists. Epidemiological studies can provide data that
is directly applicable to human populations, but 10 or
more years follow-up may be needed to provide answers
about some health effects, such as cancer. This is because
the interval between the time of exposure to a cancer-
causing agent and the time tumors develop - if they do -
may be many, many years. The interpretation of
epidemiological studies is hampered by difficulties in
measuring actual RF exposure during day-to-day use of
wireless phones. Many factors affect this measurement,
such as the angle at which the phone is held, or which
model of phone is used.
11. Which other federal agencies have responsibilities
related to potential RF health effects?
Additional information on the safety of RF exposures from
various sources can be obtained from the following
organizations.
FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
79
Health and safety information
Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
Occupational Safety and Health Administration’s (OSHA):
http://www.osha-slc.gov/SLTC/radiofrequencyradiation/
index.html
National Institute for Occupational Safety and Health
(NIOSH):
http://www.cdc.gov/niosh/emfpg.html
World health Organization (WHO):
http://www.who.int/peh-emf/
International Commission on Non-Ionizing Radiation
Protection:
http://www.icnirp.de
National Radiation Protection Board (UK):
http://www.nrpb.org.uk
Updated 4/3/2002: US Food and Drug Administration
http://www.fda.gov/cellphones
80
Index
A
ABC mode, text input • 19
Active folder • 58
Alarm • 47
Answering
call • 23
second call • 24
Anykey answer • 58
Auto redial • 58
B
Background image • 55
Backlight time, set • 56
Band selection • 31
Barring, calls • 30
Battery
charging • 7
low indicator • 8
precautions • 62
Broadcast messages • 37
Browser, web • 43
C
Calculator • 48
Calendar • 47
Call cost • 28
Call records
dialled • 28
missed • 27
received • 28
Call time • 28
Caller ID • 31
Calls answering • 23
barring • 30
holding • 24
redialling • 22
rejecting • 23
transferring • 25
waiting • 30
CB (Cell Broadcast) messages •
37
Characters, enter • 19
Connection tone • 33
Converter • 50
Creating messages
MMS • 39
SMS • 35
CUG (Closed User Group) • 31
D
Date, set • 48
Deleting
call records • 27
MMS • 38, 39, 41
phonebook • 53
SMS • 34, 41
Delivery reports, message • 41
Dialled calls • 28
Dialling font, set • 56
Display
backlight, set • 56
brightness • 55
contrast • 56
icons • 10
language • 56
layout • 10
service light, set • 56
settings • 55
Diverting calls • 29
DTMF tones, send • 25
E
Emergency calls • 65
F
FDN (Fixed Dialling Number)
mode • 58
Folder tone • 33
Funbox • 42
G
Games • 45
Greeting message • 56
H
Health and safety • 61
Holding, call • 24
I
Icons, description • 10
Images, downloaded • 46
Inbox, messages
MMS • 38
SMS • 34
Infrared port • 54
International calls • 22
Internet • 43
J
Java applications • 45
81
Index
K
Keypad tones
selecting • 32
sending/muting • 25
volume • 32
L
Language, select • 56
Last number, redial • 22
Locking
menu functions • 57
phone • 57
SIM card • 58
Low battery indicator • 8
M
Memory status
downloaded items • 46
messages • 41
phonebook • 53
Message tone • 32
Messages
cell broadcast • 37
greeting • 56
MMS • 38
push • 42
SMS • 33
voice • 37
Minute minder • 33
Missed calls • 27
MMS messages
creating/sending • 39
deleting • 39
setting • 41
viewing • 38
Multiparty-calls • 26
N
Names
entering • 19
searching • 51
Network band, selection • 30
Network services • 29
O
Organiser • 46
Outbox, messages
MMS • 39
SMS • 34
P
Password
call barring • 30
phone • 57
Phonecare and maintenance •
66
display • 10
icons • 10
locking • 13, 57
password • 57
resetting • 58
switching on/off • 8
unpacking • 6
Phonebook
adding • 51
deleting • 53
finding • 51
options • 51
speed dialling • 52
PIN, change • 57
PIN2, change • 58
Power on/off tone • 33
Privacy • 57
Problems, solve • 59
Push messages • 42
R
Received calls • 28
Recording, voice memos • 50
Redialling
automatically • 58
manually • 22
Resetting phone • 58
Ringer
incoming calls • 32
messages • 32
Road safety • 63
Roaming • 30
S
Safety
information • 61
SDN (Service Dialling
Numbers) • 53
Security, calls • 57
Sent messages
MMS • 38, 39
SMS • 34
Service light • 56
Shortcut • 13, 58
Silent mode • 13
SIM card
inserting • 7
locking • 58
82
Index
SMS messages
creating/sending • 35
deleting • 37
setting • 36
viewing • 34
Sound settings • 32
Sounds, downloaded • 46
Speakerphone • 25
Speed dial • 52
Switching on/off
microphone • 25
phone • 8
T
T9 mode, text input • 20
Templates
MMS • 39
SMS • 35
Text, enter • 19
Time, set • 48
V
Voice memos • 50
Voicemail server • 37
W
Waiting call • 30
Wallpaper • 55
Web browser
access • 43
bookmarks • 44
World time • 47
