Samsung Electronics Co SGHX300 Single-Band PCS GSM Phone User Manual 1
Samsung Electronics Co Ltd Single-Band PCS GSM Phone 1
Users Manual
9. User Manual
* Depending on the software installed or your service provider or country,
some of the descriptions in this guide may not match your phone exactly.
* Depending on your country, your phone and accessories may appear
different from the illustrations in this guide.
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-09035A
English. 01/2006. Rev. 1.0
SGH-X300
User’s Guide
Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or illegal.
Drive safely at all times
Do not use a hand-held phone while driving. Park
the vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using them
in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.
Important safety precautions
1
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is forbidden
to use it, or when it may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear). Avoid
unnecessary contact with the antenna when the phone
is switched on.
Emergency calls
Key in the emergency number for your present
location, then press .
Keep your phone away from small children
Keep the phone and all its parts, including accessories,
out of the reach of small children.
Accessories and batteries
Use only Samsung-approved accessories and
batteries. Use of any unauthorised accessories could
damage your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health and
safety information" on page 64.
• The phone could explode if the battery is
replaced with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.
2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone. To quickly
learn the basics for your phone, please refer to “Get
started” and “Step outside the phone.”
In this guide, the following instruction icons appear:
Indicates that you need to pay careful
attention to the subsequent information
regarding safety or phone features.
Indicates that you can get more information
on the referenced page.
→
Indicates that you need to press the
Navigation keys to scroll to the specified
option and then select it.
[ ]
Indicates a key on the phone.
For example,
[]
< >
Indicates a soft key, whose function is
displayed on the phone screen.
For example, <
Menu
>
•Tri-band operation
Use your phone in worldwide GSM networks, in
any of 900, 1800, and 1900 bands.
Special
features of your phone
•FM radio
Listen to your favourite radio
stations anytime, anywhere.
•IrDA
Send and receive Phonebook
entries via an infrared port.
3
Special features of your phone
•Web browser
Access the wireless web to get
up-to-the-minute information
and a wide variety of media
content.
•Java
Enjoy Java
™
-based embedded
games and download new
games.
•Phonebook
Store home, office, or cellular
phone numbers for your entries.
• Multimedia Message Service (MMS)
Send and receive MMS messages with a
combination of text, images, and sounds.
• Calendar and to do list
Keep track of your daily and
monthly schedules and tasks.
•Alarm
Use your phone as an alarm
clock to wake you up in the
morning or notify you to an
event.
•Calculator
Perform basic calculations and
do currency conversions.
• Voice recorder
Record memos or sounds.
4
Contents
Unpack 6
Make sure you have each item
Your phone 6
Buttons, features, and locations
Get started 7
First steps to operating your phone
Install and charge the phone..................................... 7
Power on or off........................................................ 8
Keys and display ..................................................... 9
Access menu functions ............................................ 11
Customise your phone............................................. 12
Make/Answer calls .................................................. 14
Step outside the phone 14
Begin with games, the web, the FM radio, and other special
features
Play games............................................................ 14
Browse the web...................................................... 15
Listen to the FM radio ............................................. 15
Use Phonebook ...................................................... 16
Send messages...................................................... 17
View messages....................................................... 18
Enter text 19
ABC, T9, Number, and Symbol mode
Call functions 22
Advanced calling features
Menu functions 26
All menu options listed
Solve problems 62
Help and personal needs
Health and safety information 64
Index 71
5
Overview of menu functions
To access Menu mode, press <
Menu
> in Idle mode.
1 SIM AT
p. 29
2
2 Call records
p. 29
1 Missed calls
2 Received calls
3 Dialled calls
4 Delete all
5 Call time
6 Call cost*
p. 29
p. 30
p. 30
p. 30
p. 30
p. 31
3 Network services
p. 31
1 Call diverting
2 Call barring
3 Call waiting
4 Network selection
5 Caller ID
6 Closed user group
7 Band selection
p. 31
p. 32
p. 32
p. 33
p. 33
p. 33
p. 34
4 Sound settings
p. 34
1 Ring tone
2 Ring volume
3 Alert type
4 Keypad tone
5 Message tone
6 Folder tone
7 Alert on call
8 Power on/off
9 Extra tones
p. 34
p. 34
p. 34
p. 35
p. 35
p. 35
p. 35
p. 35
p. 35
5 Messages
p. 36
1 Text messages
2 Multimedia
messages
3 Push messages
p. 36
p. 41
p. 45
6 Funbox
p. 45
1 WAP browser
2 Games
3 Sounds
4 Images
5 Delete all
6 Memory status
p. 45
p. 48
p. 49
p. 49
p. 49
p. 49
7 Organiser
p. 50
1 Alarm
2 Calendar
3 Time & Date
4 Calculator
5 To do list
6 Voice memo
7 Currency exchange
p. 50
p. 51
p. 52
p. 52
p. 53
p. 53
p. 54
8 FM Radio
p. 55
9 Phone settings
p. 56
1 Infrared activate
2 Display settings
3 Greeting message
4 Own number
5 Language
6 Security
7 Extra settings
8 Volume key
9 Short cut
0 Reset settings
p. 56
p. 58
p. 59
p. 59
p. 59
p. 59
p. 61
p. 61
p. 61
p. 61
Press <
Phonebook
> in Idle
mode.
Phonebook
p. 26
1 Search
2 New entry
3 Group search
4 Edit group
5 Speed dial
6 Delete all
7 Memory status
8 SDN
*
* Shows only if supported by your
SIM card.
p. 26
p. 26
p. 27
p. 27
p. 28
p. 28
p. 28
p. 29
6
Unpack
Make sure you have each item
You can obtain various accessories from
your local Samsung dealer.
Phone Travel Adapter
Battery User’s Guide
The items supplied with your phone
and the accessories available at your
Samsung dealer may vary, depending
on your country or service provider.
Your phone
Buttons, features, and locations
Left soft key
Dial key
Special
function keys
Display
Power on/off/
Menu exit key
Alphanumeric
keys
Right soft key
Microphone
Navigation keys
(Up/Down/
Left/Right)
Web access/
Confirm key
Cancel/Correct
key
Volume keys
Infrared port
Earpiece
Headset
jack
External
display
7
Get started
First steps to operating your phone
SIM card information
When you subscribe to a cellular network, you receive
a plug-in SIM (Subscriber Identity Module) card
loaded with your subscription details, such as your
PIN, and available optional services.
Install and charge the phone
Remove the battery
cover.
If the
phone is already
on, first turn it off by
holding [ ].
Insert the SIM card.
Make sure that the
gold-coloured contacts
on the card face down
into the phone.
Install the battery. Replace the cover.
Plug the travel adapter into the phone.
Plug the adapter into a standard AC wall outlet.
8
Get started
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the battery low message displays, and
• the empty battery icon blinks.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
Power on or off
When the phone is completely charged (the
battery icon becomes still), unplug the adapter
from the power outlet.
Remove the adapter from the phone.
Power on
Do not turn on
the phone when
mobile phone
use is
prohibited.
1. Open the phone.
2. Press and hold [ ] to turn on
the phone.
3. If necessary, enter the PIN
and press <
OK
>.
Power off
1. Open the phone.
2. Press and hold [ ].
9
Get started
Keys and display
Keys
Perform the function indicated on the
bottom line of the display.
In Idle mode, access your favourite menus
directly.
p. 61
In Menu mode, scroll through menu
options.
In Idle mode, launch the web browser.
In Menu mode, select the highlighted menu
option or confirm input.
Make or answer a call.
In Idle mode, retrieve numbers recently
dialled, missed, or received.
Delete characters from the display.
In Menu mode, return to the previous
menu level.
End a call.
Press and hold to switch the phone on or
off.
In Menu mode, cancel input and return the
phone to Idle mode.
Enter numbers, letters, and some special
characters.
In Idle mode, press and hold
[1]
to access
your voicemail server. Press and hold [
0
] to
enter an international call prefix.
Enter special characters.
In Idle mode, press and hold
[]
to
activate or deactivate Silent mode. Press
and hold
[]
to enter a pause between
numbers.
Adjust the phone volume.
In Idle mode, with the phone open, adjust
the keypad tone volume. With the phone
closed, press and hold to turn on the
backlight of the external display.
10
Get started
Display
Layout
Icons
*
Received signal strength
Call in progress
Out of your service area; you
cannot make or receive calls
GPRS network
Roaming
Call diverting feature active
p. 31
Text and graphics
display messages,
instructions, and
information you enter.
Soft key function
indicators
show the current
functions assigned to
the soft keys.
Icons
display various icons.
Menu Phonebook
IrDA feature active
p. 56
Silent mode or call ringer set to
vibrate
p. 13, p. 34
Mute mode
p. 25
New text message
New voicemail message
New multimedia message
Alarm set
p. 50
Battery power level
* Depending on your country or service provider, the icons
shown on the display may vary.
11
Get started
Access menu functions
Use the soft
keys
The roles of the soft keys vary
depending on the function you are
using. The bottom line of the
display indicates their current role.
Press the left soft
key to select the
highlighted option.
Press the right sof
t
key to return to th
e
previous menu
level
Select
Select an
option
1. Press the appropriate soft key.
2. Press the Navigation keys to
move to the next or previous
option.
3. Press <
Select
> or [
]
to
confirm the function displayed
or option highlighted.
4. To exit, choose either of the
following methods:
•Press <> or [
C
] to move
up one level.
• Press [ ] to return to Idle
mode.
Use shortcuts
Press the number key
corresponding to the option you
want.
12
Get started
Customise your phone
1. In Idle mode, press <
Menu
>
and select
Phone settings
→
Language
.
2. Select a language.
1. In Idle mode, press <
Menu
>
and select
Sound settings
→
Ring tone
.
2. Select a ringtone.
3. Select
Ring volume
.
4. Adjust the volume level.
5. Press <
OK
>.
Display
language
Call ringer
melody and
volume
You can set wallpaper for the idle
screen.
1. In Idle mode, press <
Menu
>
and select
Phone settings
→
Display settings
→
Wallpaper
→
Wallpaper list
.
2. Select the image name you
want.
3. Scroll through images until you
find the one you want.
4. Press <
Select
>.
Idle mode
wallpaper
13
Get started
You can set [Up], [Left], and
[Right] to function as shortcuts to
access your favourite menus.
1. In Idle mode, press <
Menu
>
and select
Phone settings
→
Short cut
.
2. Select a key.
3. Select a menu to be assigned to
the key.
You can switch the phone to Silent
mode to avoid disturbing other
people.
Press and hold [ ] in Idle mode.
Menu
shortcuts
Silent mode
You can protect the phone against
unauthorised use with a phone
password. The phone will require
the password on power-up.
1. In Idle mode, press <
Menu
>
and select
Phone
settings
→
Security
→
Change
password
.
2. Enter the default password,
00000000
, and press <
OK
>.
3. Enter a new 4- to 8-digit
password and press <
OK
>.
4. Enter the new password again
and press <
OK
>.
5. Select
Phone lock
.
6. Select
Enable
.
7. Enter the password and press
<
OK
>.
Phone lock
14
Make/Answer calls
Step outside the phone
Begin with games, the web, the FM radio, and other
special features
Play games
1. Enter an area code and phone
number.
2. Press [ ].
3. To end the call, press [ ].
1. When the phone is ringing,
press [ ].
2. To end the call, press [ ].
Press [ / ].
Make a call
Answer a call
Adjust the
volume during
a call
1. In Idle mode, press <
Menu
>
and select
Funbox
→
Games
→
a game.
2. Scroll to
START GAME
and
press [ ].
3. Select a game mode or press
any key to start the game.
4. To end the game, press [ ]
and then <
Yes
>.
Launch a
game
15
Step outside the phone
Browse the web
Using a built-in web browser, you can easily access the
wireless web to get a variety of up-to-date services
and information and to download web content.
Listen to the FM radio
In Idle mode, press [ ].
• To scroll through browser items,
press [Up] or [Down].
• To select an item, press [ ].
• To return to the previous page,
press [
C
].
• To access browser options,
press and hold [ ] or [ ].
Launch the
web browser
Navigate the
web
1. Plug the connector of the
supplied headset into the jack
on the right side of the phone.
2. In Idle mode, press [Down].
3. Press <
Options
> and select
Power on/off
→
On
.
4. Press [Left] or [Right] to find
available radio stations.
5. To turn off the radio, disconnect
the headset from the phone.
Listening to
the radio
16
Step outside the phone
Use Phonebook
1. From the station list on the FM
Radio screen, select an empty
location.
2. Select
Add
.
3. Enter the station title and press
<
OK
>.
4. Enter the frequency of the
station and press <
OK
>.
5. Select a location in which you
want to store the station.
Storing a
radio station
1. In Idle mode, enter a phone
number and press <
Save
>.
2. Select a number type.
3. Select
Phone
or
SIM
.
4. Enter a name and press <
OK
>.
5. Press <
OK
> to save the entry.
1. In Idle mode, press
<
Phonebook
>
and select
Search
.
2. Enter the first few letters of the
name you want.
3. Select an entry.
4. Scroll to a number and press
[ ] to dial, or press
<
Options
> to access options.
Add an entry
Find an entry
17
Step outside the phone
Send messages
1. In Idle mode, press <
Menu
>
and select
Messages
→
Text
messages
→
Write new
.
2. Enter the message text.
3. Press <
Options
> and select
Save and send
or
Send only
.
4. If you selected
Save and send
,
select a memory location.
5. Enter a destination number and
press <
OK
>.
1. In Idle mode, press <
Menu
>
and select
Messages
→
Multimedia messages
→
Write new
.
2. Enter the message subject
press <
OK
>.
3. Select
Add here
.
Send a text
message
(SMS)
Send a
multimedia
message
(MMS)
4. Select an adding option and add
message contents.
5. When you have finished, press
<
Options
> and select
Send
.
6. Select a destination type.
7. Select one of
Phone number
,
E-mail address
, or
Phonebook
.
8. Enter a destination number or
address and press <
OK
>, or
select a number from
Phonebook.
9. To add other destinations,
select
Add destination
and
repeat from step 7.
10.When you have finished, select
Send message
.
18
Step outside the phone
View messages
When a notification appears:
1. Press <
View
>.
2. Select the message from the
Inbox.
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messages
→
Text
messages
→
Inbox
.
2. Select a message.
When a notification appears:
1. Press <
View
>.
2. Press <
Options
> and select
Retrieve
.
3. Select the message from the
Inbox.
View a text
message
View a
multimedia
message
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messages
→
Multimedia messages
→
Inbox
.
2. Select a message.
19
Enter text
ABC, T9, Number, and Symbol mode
You can enter text in some features, such as
Messages, Phonebook, or Organiser, using ABC mode,
T9 mode, Number mode, and Symbol mode.
Changing the text input mode
The text input mode indicator displays when the
cursor is in a text field
Example
: Writing an SMS message
Press the right soft key to change the input mode:
•: ABC mode
•: T9 mode
•: Number mode
• None: Symbol mode
Using ABC mode
Press the appropriate key until the character you want
appears on the display.
(Creating an SMS message with GSM-alphabet encoding)
Write new
Options Text input mode
indicator
Characters in order displayed
Key Upper case Lower case
space
20
Enter text
Other ABC mode operations
• To enter the same letter twice or to enter a
different letter on the same key, wait for the cursor
to move to the right automatically or press [Right].
Then, enter the next letter.
• Press [ ] to insert a space.
• Press [ ] to change case. Initial capital ( ),
Capital lock ( ), and Lower case ( ) are
available.
• Press the Navigation keys to move the cursor.
•Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
• Depending on your country, you may be able to
access an input mode for your specific language by
press and holding [ ].
Using T9 mode
T9 is a predictive text input mode that allows you to
key in any character using single keystrokes.
Entering a word in T9 mode
1. Press [
2
] to [
9
]
to start entering a word. Press
each key once for each letter.
For example, press [
4
], [
3
], [
5
], [
5
], and [
6
] to
enter Hello in T9 mode.
T9 predicts the word that you are typing, and it
may change with each key that you press.
2. Enter the whole word before editing or deleting
characters.
3. When the word displays correctly, go to step 4.
Otherwise, press [
0
] to display alternative word
choices for the keys that you have pressed.
For example, Of and Me use [
6
] and [
3
].
4. Press [ ] to insert a space and enter the next
word.
Enter text
21
Other T9 mode operations
•Press [
1
] to enter periods or apostrophes
automatically.
• Press [ ] to change case. Initial capital ( ),
Capital lock ( ), and Lower case ( ) are
available.
• Press [Left] or [Right] to move the cursor.
•Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
Adding a new word to the T9 dictionary
This feature may not be available for some languages.
1. Enter the word that you want to add.
2. Press [
0
] to display alternative words for your key
presses. When there are no more alternative
words,
Add
displays on the bottom line.
3. Press <
Add
>.
4. Enter the word you want using ABC mode and
press <
OK
>.
Using Number mode
Number mode enables you to enter numbers.
Press the keys corresponding to the digits you want.
Using Symbol mode
Symbol mode enables you to insert symbols.
To Press
display more symbols [Up] or [Down].
select a symbol the corresponding
number key.
clear the symbol(s) [
C
].
insert the symbol(s) <
OK
>.
22
Call functions
Advanced calling features
Making a call
1. In Idle mode, enter the area code and phone
number.
2. Press [ ].
Making an international call
1. In Idle mode, press and hold [
0
]. The
+
character
appears.
2. Enter the country code, area code, and phone
number, then press [ ].
Redialling recent numbers
1. In Idle mode, press [ ] to display the list of
recent numbers.
2. Scroll to the number you want and press [ ].
Making a call from Phonebook
Once you have stored a number in Phonebook, you
can dial the number by selecting it from
Phonebook.
p. 26
You can also use the Speed dial feature to assign your
most frequently called numbers to specific number
keys.
p. 28
You can quickly dial a number from Phonebook using
its location number assigned when stored.
To dial a number from the phone’s memory:
1. In Idle mode, press and hold [
0
]. The
+
character
appears.
2. Enter the location number for the phone number
you want and press [ ].
3. Press [Up] or [Down] to scroll through other
numbers, if necessary.
• Press [
C
] to clear the last digit or press and hold
[
C
] to clear the whole display. You can move the
cursor to edit an incorrect digit.
• Press and hold [ ] to enter a pause between
numbers.
Call functions
23
4. Press <
Dial
> or [ ] to dial the number you want.
To dial a number from the SIM card:
1. In Idle mode, enter the location number for the
phone number you want and press [ ].
2. Press [Up] or [Down] to scroll through other
numbers, if necessary.
3. Press <
Dial
> or [ ] to dial the number you want.
Ending a call
Close the phone or press [ ].
Answering a call
When you receive an incoming call, the phone rings
and displays the incoming call image.
Press <
Accept
> or [ ] to answer the call.
Tips for answering a call
• When
Anykey
answer
is active, you can press
any key to answer a call, except for <
Reject
> and
[].
p. 61
• When
Active folder
is active, you can simply open
the phone.
p. 61
• Press <
Reject
> or [ ] to reject a call.
• Press and hold [ / ] to reject a call or mute the
ringer, depending on the
Volume key
setting.
p. 61
Viewing missed calls
If you have missed calls, the screen displays how
many calls you have missed.
1. Press <
View
>.
2. If necessary, scroll through the missed calls.
3. Press [ ] to dial the number you want.
24
Call functions
Using the headset
Use the headset to make or answer calls without
holding the phone.
Connect the headset to the jack on the right side of
the phone. The button on the headset works as
follows:
Options during a call
You can access a number of functions during a call.
Adjusting the volume during a call
Use to adjust the earpiece volume during a call.
Press [ ] to increase the volume level and [ ] to
decrease the volume level.
Placing a call on hold/Retrieving
Press <
Hold
> or <
Unhold
> to place the call on hold
or retrieve the call.
Making a second call
You can make another call if your network supports
this function.
1. Press <
Hold
> to put the call on hold.
2. Make the second call in the normal way.
3. Press <
Swap
> to switch between the calls.
4. To end the current call, press [ ].
Answering a second call
You can answer an incoming call, if your network
supports this function and you have activated the Call
waiting feature.
p. 32
1. Press [ ] to answer the call. The first call is
automatically put on hold.
2. Press <
Swap
> to switch between the calls.
3. To end the current call, press [ ].
To Press
redial the last call the button twice.
answer a call the button.
end a call the button.
Call functions
25
Using the speakerphone feature
Use the speakerphone feature to talk and listen with
the phone a short distance away.
Press [ ] and then <
Yes
> to activate the
speakerphone feature. Press the key again to switch
back to the earpiece.
Using In-call options
Press <
Options
> to access the following options
during a call:
•
Menu
: access the phone's menu functions.
•
Mute
/
Unmute
: switch off the phone's microphone
so that the other person on the phone cannot hear
you, or switch it back on.
•
Mute keys
/
Send keys
: switch the key tones on
or off.
•
Send DTMF
: send the DTMF (Dual tone
multi-frequency) tones as a group. The DTMF
tones are the tones used in phones for tone
dialling, sounding when you press the number
keys. This option is helpful for entering a password
or an account number when you call an automated
system, like a banking service.
•
Phonebook
: access the contact list.
•
Join
: set up a multi-party call by adding a caller
on hold to a currently active call. You can include
up to 5 people on a multi-party call.
•
Select one
: select one of multi-party call
participants. You can then use the following
options:
Private
: have a private conversation with one
multi-party call participant. The other participants
can converse with each other. After the private
conversation, select
Join
to return to the
multi-party call.
Remove
: disconnect one multi-party call
participant.
To communicate with answering machines or
computerised telephone systems,
Send keys
must be selected.
26
Menu functions
All menu options listed
Phonebook
You can store phone numbers on your SIM card and in
your phone’s memory. The SIM card and phone’s
memory are physically separate, but they are used as
a single entity called Phonebook.
To access this menu, press <
Phonebook
> in Idle
mode.
Search
Use this menu to search for numbers in Phonebook.
Finding an entry
1. Enter the first few letters of the name that you
want to find.
2. Select a name from the list.
3. Scroll to a number and press [ ] to dial, or press
<
Options
> to access Phonebook options.
Using Phonebook options
While viewing an entry, press <
Options
> to access
the following options:
•
Paste
: paste the selected number into the dialling
screen.
•
Edit
: edit entry information.
•
Delete
: delete the selected entry from the name.
•
Copy
: copy the number to the phone’s memory or
to the SIM card.
•
Caller group
: assign the selected number to a
caller group.
•
Add entry
: add a new entry to the selected name.
•
Send via IrDA
: send the selected number or all
numbers in entry via the infrared port.
p. 56
New entry
Use this menu to add a new entry to Phonebook.
Storing an entry in the phone’s memory
1. Select an entry type.
• : Mobile phone number
Menu functions
Phonebook
27
• : Office phone number
• : Home phone number
• : E-mail address; an e-mail address can be
stored only in the phone’s memory.
2. Select
Phone
.
3. Enter a name and press <
OK
>.
4. Enter a number or an e-mail address and press
<
Save
>.
5. Change the location number, if you want, and
press <
OK
>.
Storing an entry on the SIM card
1. Select an entry type.
2. Select
SIM
.
3. Enter a name and press <
OK
>.
4. Enter a number and press <
Save
>
5. Change the location number, if you want, and
press <
OK
>.
Group search
Use this menu to search for your numbers in
Phonebook in caller groups.
1. Enter the first few letters of the group name.
2. Select a group.
3. Select the name you want.
4. Press [ ] to dial the number or <
Options
> to
access Phonebook options.
Edit group
Use this menu to edit your caller groups’ properties.
Select a group and change the group settings by using
the following options:
•
Call ring tone
: set a ringtone for incoming calls
from the group members.
•
SMS tone
: set a ringtone for incoming messages
from the group members.
•
Graphic
: set a graphic icon for incoming calls from
the group members.
•
Group name
: assign a name to the group.
28
Menu functions
Speed dial
Use this menu to assign speed dial numbers (2 to 9) to
eight of your most frequently called numbers.
Assigning speed dial entries
1. Select a key location from
2
to
9
. Key
1
is reserved
for your voicemail server.
2. Select a name from the Phonebook list.
3. Select the number you want.
Managing speed dial entries
From the Speed dial list, press <
Options
> to access
the following options:
•
Change
: assign a different number to a key.
•
Delete
: clear the speed dial setting for a key.
•
Delete all
: clear the speed dial settings for all
keys.
•
Number
: check the number assigned to a key.
Dialling speed dial entries
In Idle mode, press and hold the appropriate key.
Delete all
Use this menu to delete all of the entries from your
phone’s memory, your SIM card, or both.
1. Press [ ] to select the memory locations to be
cleared.
2. Press <
Delete
>.
3. Enter the phone password and press <
OK
>.
4. Press <
Yes
> twice to confirm the deletion.
Memory status
Use this menu to check the number of entries you
have stored in the phone’s memory and on the SIM
card.
The password is preset to
00000000
. You can
change this password.
p. 60
Menu functions
SIM AT
(Menu 1)
29
SDN
Use this menu to view the list of Service Dialling
Numbers (SDN) assigned by your service provider,
including emergency numbers and numbers for
directory enquiries. This menu is available if your SIM
card supports SDN.
Scroll to the number you want and press <
Dial
> or
[].
SIM AT
(Menu 1)
This menu is available if you use a SIM AT card that
supports SIM Application Toolkit menus and provides
additional services, such as news, weather, sports,
entertainment, and location services. Available
services may vary, depending on your service
provider’s plans. For details, see your SIM card
instructions or contact your service provider.
To access this menu, press <
Menu
> in Idle mode and
select
SIM AT
.
Call records
(Menu 2)
Use this menu to view the calls you have dialled,
received, or missed, and the length of calls. You can
also check the cost of your calls,
if your SIM card
supports this function.
To access this menu, press <
Menu
> in Idle mode and
select
Call records
.
Missed calls
(Menu 2.1)
This menu displays the most recent calls you did not
answer.
Accessing a call record
1. Select a call record.
2. Press [Up] or [Down] to move to another call
record.
3. Press [ ] to dial, or <
Options
> to access call
record options.
30
Menu functions
Using call record options
While viewing call details, press <
Options
> to access
the following options:
•
Edit
: change the number of the selected call
record.
•
Delete
: delete the selected call record.
Received calls
(Menu 2.2)
This menu displays the most recent calls you have
received.
Dialled calls
(Menu 2.3)
This menu displays the most recent calls you have
dialled.
Delete all
(Menu 2.4)
Use this menu to delete all of the records in each call
type.
1. Press [ ] to select the call types to be cleared.
2. Press <
Delete
>.
3. Press <
Yes
> twice to confirm the deletion.
Call time
(Menu 2.5)
This menu displays the time log for calls made and
received. The actual time invoiced by your service
provider will vary.
•
Last
call time
: check the length of your last call.
•
Total
sent
: check the total length of all the calls
you have dialled.
•
Total
received
: check the total length of all the
calls you have received.
•
Reset
timers
: reset the call timers. You need to
enter the phone password.
The password is preset to
00000000
. You can
change this password.
p. 60
Menu functions
Network services
(Menu 3)
31
Call cost
(Menu 2.6)
This network feature displays the cost of calls. This
menu is available only if your SIM card supports this
feature. Note that this is not intended to be used for
billing purposes.
•
Last
call
cost
: check the cost of your last call.
•
Total
cost
: check the total cost of all of your calls.
If the total cost exceeds the maximum cost set in
Set
max
cost
, you must reset the counter before
you can make another call.
•
Max
cost
: check the maximum cost limit set in
Set
max
cost
.
•
Reset
counters
: reset the cost counters.
•
Set
max
cost
: set the maximum cost authorised
for your calls.
•
Price/Unit
: set the price per unit that is applied
when the cost of your calls is calculated.
Network services
(Menu 3)
Use this menu to access network services. Please
contact your service provider to check their availability
and subscribe to them, if you wish.
To access this menu, press <
Menu
> in Idle mode and
select
Network services
.
Call diverting
(Menu 3.1)
This network service reroutes incoming calls to a
phone number that you specify.
1. Select a call diverting option:
•
Divert always
: divert all calls.
•
Busy
: divert calls when you are on another
call.
•
No
reply
: divert calls when you do not answer
the phone.
•
Unreachable
: divert calls when you are not in
an area covered by your service provider or
when your phone is switched off.
•
Cancel
all
: cancel all call diverting options.
32
Menu functions
2. Select the type of calls to be diverted.
3. Press <
Activate
>. To deactivate call diverting,
press <
Options
> and select
Remove
.
4. Enter the number to which calls are to be diverted
and press <
OK
>.
5. If you selected
No reply
, select the length of time
the network delays before diverting a call.
Call barring
(Menu 3.2)
This network service allows you to restrict your calls.
1. Select a call barring option:
•
All
outgoing
: prohibit all outgoing calls.
•
International
: prohibit international calls.
•
International
except
home
: only allow calls
to numbers within the current country when
you are abroad, and to your home country.
•
All
incoming
: prohibit incoming calls.
•
Incoming
while
abroad
: prohibit incoming
calls when you use your phone outside of your
service area.
•
Cancel
all
: cancel all call barring settings,
allowing calls to be sent and received normally.
•
Change barring password
: change the call
barring password obtained from your service
provider.
2. Select the type of calls to be barred.
3. Press <
Activate
>. To deactivate call barring,
press <
Deactivate
>.
4. Enter the call barring password supplied by your
service provider and press <
OK
>.
Call waiting
(Menu 3.3)
This network service informs you when someone is
trying to reach you while you are on another call.
1. Select the type of calls to which the call waiting
option will apply.
2. Press <
Activate
>. To deactivate call waiting,
press <
Deactivate
>.
Menu functions
Network services
(Menu 3)
33
Network selection
(Menu 3.4)
This network service allows you to select the network
used when roaming outside of your home area, or let
the network to be chosen automatically.
You can select a network other than your home
network only if there is a valid roaming agreement
between the two.
Caller ID
(Menu 3.5)
This network service allows you to prevent your phone
number from being displayed on the phone of the
person being called. If you select
Default
, the phone
will use the default setting provided by the network.
Closed user group
(Menu 3.6)
Use this menu to set incoming and outgoing calls to be
restricted to a selected user group. For details about
how to create a closed user group, contact your
service provider.
•
Index list
: list, add, or delete CUG index
numbers. Press <
Options
> to access the options
for setting up an index list.
•
Outside access
: enable calls to numbers other
than those in the Closed user group. This feature
depends on the nature of your CUG subscription.
•
Default group
: enable the default CUG, if you
have set one with your service provider. When
making a call, you are given the option of using
your default CUG, instead of selecting one from the
list.
Some networks do not allow the user to change this
setting.
34
Menu functions
Band selection
(Menu 3.7)
For the phone to make and receive phone calls, it
must register with an available network. Your phone
can handle any of the following types of networks:
GSM 1900 and Combined GSM 900/1800.
The country where you purchased your phone
determines the default band that it uses. When you
travel abroad, you must remember to change to an
appropriate band.
Sound settings
(Menu 4)
Use this menu to customise various sound settings.
To access this menu, press <
Menu
> in Idle mode and
select
Sound settings
.
Ring tone
(Menu 4.1)
Use this menu to select a ringtone for the call ringer.
You can select one of the embedded ringtones or
downloaded sounds.
Ring volume
(Menu 4.2)
Use this menu to adjust the ringtone volume.
Alert type
(Menu 4.3)
Use this menu to specify how you are to be informed
of incoming calls.
•
Melody
: the phone rings using the selected
ringtone.
•
Vibration
: the phone vibrates but not rings.
•
Vibra+melody
: the phone vibrates three times
and then starts ringing.
Menu functions
Sound settings
(Menu 4)
35
Keypad tone
(Menu 4.4)
Use this menu to select the tone that the phone
sounds when you press a key.
Message tone
(Menu 4.5)
Use this menu to change the sound settings for
incoming SMS messages, MMS messages, and cell
broadcast (CB) messages individually.
•
SMS tone
: specify how you are informed of new
SMS messages.
•
SMS-CB tone
: specify how you are informed of
new CB messages.
•
MMS tone
: specify how you are informed of new
MMS messages.
•
Repetition
: set whether or not the phone repeats
alerting you to new messages. If you selected
Periodic
, the phone alerts you every 2 minutes
until you view the message.
Folder tone
(Menu 4.6)
Use this menu to select the tone that the phone
sounds when you open or close the phone.
Alert on call
(Menu 4.7)
Use this menu to select whether or not the phone
informs you when you receive a new message or when
the time for an alarm comes during a call.
Power on/off
(Menu 4.8)
Use this menu to select the melody that the phone
plays when it is switched on or off.
Extra tones
(Menu 4.9)
Use this menu to customise additional tones for the
phone.
•
Error tone
: set the phone to beep when you make
a mistake.
•
Minute
minder
: set the phone to beep every
minute during an outgoing call to keep you
informed of the length of your call.
You can adjust the keypad tone volume using
[/]
in Idle mode.
36
Menu functions
•
Connect
tone
: set the phone to beep when an
outgoing call is connected to the system.
Messages
(Menu 5)
Use the
Messages
menu to send and receive short
messages, and multimedia messages. You can also
access push messages from web servers.
To access this menu, press <
Menu
> in Idle mode and
select
Messages
.
Text messages
(Menu 5.1)
Short Message Service (SMS) allows you to send or
receive text messages including simple pictures,
melodies, and animated images.
Inbox
(Menu 5.1.1)
Use this menu to access SMS messages you have
received.
While viewing a message, press <
Options
> to access
the following options:
•
Delete
: delete the message.
•
Send
: forward the message to other people.
•
Text reply
: reply to the sender.
•
Call
back
: make a call to the sender.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Move to phone
/
Move to SIM
: move the
message between the SIM card and the phone’s
memory.
•
Select objects
: save images or sounds from the
message into your phone’s memory.
Outbox
(Menu 5.1.2)
Use this menu to access SMS messages that you have
sent or have saved to send at a later time.
While viewing a message, press <
Options
> to access
the following options:
•
Delete
: delete the message.
•
Send
: forward the message to other people.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
Menu functions
Messages
(Menu 5)
37
•
Move to phone
/
Move to SIM
: move the
message between the SIM card and the phone’s
memory.
•
Select objects
: save images or sounds from the
message into your phone’s memory.
Write new
(Menu 5.1.3)
Use this menu to create and send an SMS message.
1. Enter your message.
2. Press <
Options
> to access the following options:
•
Send only
: just send the message.
•
Save and send
: save the message in
Outbox
and then send it.
•
Save only
: save the message in
Outbox
to
send it later.
•
Text formatting
: change the text attributes.
•
Add objects
: add a sound, melody, picture, or
animated image to the message.
•
Add templates
: add one of text templates.
•
Add emoticon
: add one of preset emoticons.
•
Add phonebook
: add a phone number or
e-mail address from Phonebook.
•
Add bookmark
: add a web page’s address
from the Favorite list.
•
Language
: change the language to be used in
T9 mode.
3. When you have finished, press <
Options
> and
select
Send only
or
Save and send
.
4. If you selected
Save and send
, select a memory
location.
5. Enter a destination number.
6. Press <
OK
>
to send the message.
The maximum number of characters allowed in
a short message varies by service provider. If
your message exceeds the maximum number of
characters, the phone will split the message.
38
Menu functions
Templates
(Menu 5.1.4)
Use this menu to create templates with the sentences
you use frequently so that you can retrieve and insert
them when composing an SMS message.
Creating a template
1. Select an empty location.
2. Select
Edit
.
3. Enter a message and press <
OK
>.
Using template options
From the template list, press <
Options
> to access
the following options:
•
Edit
: create a new template or edit the selected
template.
•
Send message
: create and send a new message
using the template.
•
Delete
: delete the selected template.
Emoticon templates
(Menu 5.1.5)
Your phone provides preset emoticons so that you can
retrieve and insert them when composing an SMS
message. Use this menu to create or edit emoticons.
Creating an emoticon
1. Select a category.
2. Press <
Options
> and select
Add
.
3. Enter an emoticon and press <
Save
>.
Using emoticon options
From the emoticon list, press <
Options
> to access
the following options:
•
Add
: add a new emoticon.
•
Edit
: edit the selected emoticon.
•
Send
: create and send a new message using the
emoticon.
•
Delete
: delete the selected emoticon.
Menu functions
Messages
(Menu 5)
39
Settings
(Menu 5.1.6)
Use this menu to customise the SMS settings.
•
Setting x
(where
x
is the setting group number):
set the properties of each setting group. The group
accessed last is activated for sending or receiving
subsequent messages.
Service centre
: store or changes the number of
your message centre.
Default destination
: store a default destination
number. It will be displayed in the Destination
field.
Default type
: set the default message type. The
network can convert the messages into the
selected format.
Default validity
: set the length of time your
messages are stored in the SMS server.
Setting name
: change the name of the setting
group.
•
Common settings
: the following options are
available:
Reply path
: allow recipients to reply to you
through your SMS server.
Delivery reports
: set the network to inform you
when your messages have been delivered.
Bearer selection
: select either
GSM
or
GPRS
preferred
, depending on your network.
Character support
: select a character encoding
type. If you select
Automatic
, the phone switches
the encoding type from GSM-alphabet to Uni-code
if you enter a uni-code character.
Use of uni-code encoding will reduce the maximum
number of characters in a message to about half. If
this menu is not shown, your phone provides the
automatic character encoding by default.
Delete all
(Menu 5.1.7)
Use this menu to delete SMS messages in each
message folder all at once.
1. Press [ ] to select the message folders to be
cleared.
The setting options available in this menu may vary
depending on your service provider.
40
Menu functions
2. Press <
Delete
>.
3. Press <
Yes
> twice to confirm the deletion.
Memory status
(Menu 5.1.8)
Use this menu to check the number of SMS messages
you have stored in each folder.
Voice mail
(Menu 5.1.9)
Use this menu to store the number of the voicemail
server and access your voicemails.
•
Connect to voice server
: connect to the
voicemail server to allow you to listen to your
messages. You can also connect to the voicemail
server by pressing and holding [
1
] in Idle mode.
•
Voice server number
: change the voicemail
server number.
Broadcast
(Menu 5.1.0)
Your phone receives Cell Broadcast (CB) messages,
which are messages related to various topics, such as
weather forecast, traffic, and news report, from
network. Use this menu to access broadcast messages
or change the settings for the service.
•
Read
: open received CB messages.
The
Volatile
box saves messages until the phone
is switched off.
The
Archive
box saves messages indefinitely.
Press <
Options
> and select
Save
when a text
notification appears or while viewing a CB message
in the Volatile box. The message is saved in the
Archive
box.
•
Receive
: select to receive CB messages, or not.
•
Channel
list
: specify the channels from which you
receive CB messages.
•
Language
: select the preferred languages in
which CB messages display.
Please contact your service provider for details.
You must enter the voicemail server number before
accessing the server. Your service provider can give
you the number.
Menu functions
Messages
(Menu 5)
41
Multimedia messages
(Menu 5.2)
Multimedia Message Service (MMS) delivers messages
containing a combination of text, an image, and an
audio, from phone to phone or from phone to e-mail.
Inbox
(Menu 5.2.1)
Use this menu to access MMS messages that you have
received. The following icons tell you the message
status:
• Read notification
• Unread notification
• Retrieving from the server
• Processing your request
• Failed to retrieve
• Read message
• Unread message
While viewing a message, press <
Options
> to access
the following message options:
Notifications
•
Retrieve
: retrieve the message from the MMS
server.
•
Delete
: delete the notification.
•
More properties
: access the message properties.
Messages
•
Delete
: delete the message.
•
Reply
: reply to the sender.
•
Call back
: make a call to the sender.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Forward
: forward the message to other people.
•
Save picture
: save an image from the message
into the
Images
folder.
•
Save sound
: save a sound from the message into
the
Sounds
folder.
•
Properties
: access the message properties.
Outbox
(Menu 5.2.2)
Use this menu to access MMS messages that you have
sent. The following icons tell you the message status:
• Being sent
• Sent
42
Menu functions
• Failed to send
• To be sent
While viewing a message, press <
Options
> to access
the following options:
•
Delete
: delete the message.
•
Cut address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Send
: send or resend the message.
•
Edit message
: edit the message.
•
Properties
: access the message properties.
Draft
(Menu 5.2.3)
Use this menu to access MMS messages you have
saved to send at a later time.
You can view a message and use the options the same
as in
Outbox
.
Write new
(Menu 5.2.4)
Use this menu to create and send an MMS message.
1. Enter the message subject and press <
OK
>.
2. Press <
Options
> to access the following options:
•
Add text
: add message text.
•
Add picture
: add a picture to the message.
•
Add sound
: add a sound clip to the message.
•
Send
: send the message.
•
Save
: save the message in
Draft
or
Templates
.
•
Settings
: change the message settings.
p. 44
•
Add destination
: enter destination numbers
or addresses.
•
Preview
: view the message as it will be shown
on the recipient’s phone.
3. After adding items, highlight one and press
<
Options
> to access the following options for
editing the message:
•
Edit text
/
Edit picture
/
Edit sound
: edit the
text, picture, or sound.
The maximum size allowed for a message can
differ, depending on your service provider.
Menu functions
Messages
(Menu 5)
43
•
Add page
: add pages. Move to each page by
pressing [Left] or [Right].
•
Delete
: remove the added item.
•
Duration
: set how long one page displays.
After the specified time, the display
automatically scrolls to the next page.
4. When you have finished, press <
Options
> and
select
Send
.
5. Select a destination type (To, Cc, Bcc).
6. Select one of
Phone number
,
E-mail address
, or
Phonebook
.
7. Enter a phone number or an e-mail address and
press <
OK
>, or select one from Phonebook.
8. To add more destinations, select
Add destination
and repeat from step 6.
9. To enter additional numbers or addresses to other
destination types, press < >and repeat from step
5.
10. When you have finished, select
Send message
.
Templates
(Menu 5.2.5)
Use this menu to access MMS templates you have
saved as templates so that you can use them for
composing an MMS message.
From the template list, press <
OK
> to access the
following options:
•
Edit message
: create and send a new message
using the template.
•
Delete
: delete the selected template.
Delete all
(Menu 5.2.6)
Use this menu to delete MMS messages in each
message folder all at once.
1. Press [ ] to select the message boxes to be
cleared.
2. Press <
Delete
>.
3. Press <
Yes
> twice to confirm the deletion.
Memory status
(Menu 5.2.7)
Use this menu to check the amount of memory
currently in use in each message box.
44
Menu functions
Setup
(Menu 5.2.8)
Use this menu to customise the MMS settings.
•
Delivery report
: set the network to inform you
when your messages have been delivered.
•
Read reply
: send a read-reply request along with
your messages.
•
Auto download
: set whether or not your phone
retrieves new incoming messages from the MMS
server without notifications.
•
Message acceptance
: select the categories of
messages you want to receive.
•
Hide ID
: set whether to hide your phone number
from the recipient’s phone.
•
Expiry date
: set the length of time your messages
are stored in the message server.
•
Delivery time
: set the time
delay before
messages are sent.
•
Priority
: set the priority level of your messages.
•
Report allowed
: set the network to inform the
sender when a message has been delivered to you.
•
Page duration
: set how long one page in your
outgoing messages displays. After a specified time,
the display automatically scrolls to the next page.
MMS profile
(Menu 5.2.9)
You can configure required network connection
settings for MMS. The profile accessed last is
automatically activated for sending or receiving
subsequent messages.
For each profile, set the following parameters:
•
Profile name
: assign a name to the MMS profile.
•
Connection URL
: enter the URL address of your
MMS server.
•
Security
: select a security mode for data
transmission.
•
IP address
: enter the IP address of the MMS
server.
•
User name
: enter the login ID.
Check with your service provider before you
change any MMS settings on your phone.
Menu functions
Funbox
(Menu 6)
45
•
Password
: enter the login password.
•
APN
: enter the access point name of the MMS
server.
Push messages
(Menu 5.3)
Use this menu to access push messages from the
wireless web server or change the settings for
receiving push messages.
•
Inbox
: view push messages you have received.
•
Receive
: determine whether or not your phone
receives push messages.
Never
: the phone rejects push messages.
Always
: the phone receives all push messages.
•
Delete all
: delete all push messages.
Funbox
(Menu 6)
The
Funbox
menu allows you to use the web browser,
play Java games, and access images and sounds
stored in the phone’s memory.
To access this menu, press <
Menu
> in Idle mode and
select
Funbox
.
WAP browser
(Menu 6.1)
The Wireless Application Protocol (WAP) browser on
your phone allows you to access the wireless web.
From the wireless web, you can access up-to-date
information and a wide variety of media content, such
as games, wallpapers, and ringtones.
Home
(Menu 6.1.1)
Use this menu to connect your phone to the network
and load the homepage of the wireless web service
provider. You can also press [ ] in Idle mode.
46
Menu functions
Navigating the web browser
Using page options
From any web page, press and hold [ ] or [ ] to
access the following options; when you access page
options by [ ], some options are not available:
•
Bookmarks
: bookmark the current page or access
the Favorite list.
•
Reload
: reload the current page with updated
information.
•
Home
: return to the homepage.
•
Go to URL
: enter a URL address manually.
•
Show URL
: view the URL address of the current
web page.
•
Edit home
: change the page to be used for your
homepage.
•
Security info
: access security information.
•
Clear cache
: delete information stored in the
cache. The cache is a temporary memory site that
stores recently accessed web pages.
•
Inbox
: read messages received from a web
server.
•
Show image
: view the images on the current web
page in order.
Exiting the web browser
Press [ ] to end the network connection and exit the
browser.
Favorite
(Menu 6.1.2)
Use this menu to save URL addresses as bookmarks in
order to quickly access web pages.
Adding a bookmark
1. Select an empty location.
2. Enter a URL address and press <
Enter
>.
3. Enter a title for the bookmark and press <
Enter
>.
To Press
scroll through browser items [Up] or [Down].
select a browser item [ ].
return to the previous page [
C
].
Menu functions
Funbox
(Menu 6)
47
Using bookmark options
After saving an item, press <
Options
> to access the
following options:
•
Go
to URL
: access the bookmarked web page.
•
Edit
: edit the URL address and title of the
bookmark.
•
Delete
: delete the bookmark.
http://
(Menu 6.1.3)
Use this menu to manually enter a URL address and
access the associated web page.
Settings
(Menu 6.1.4)
Use this menu to set up connection profiles to be used
for the web browser. The profile accessed last is
automatically activated for accessing the wireless web.
For each server, set the following parameters:
•
Profile
name
: enter a profile name.
•
Homepage
URL
: enter the URL address of the
page to be used as your homepage.
•
Security
: select a security mode for data
transmission.
•
Bearer
: select the network bearer type;
GPRS
or
Data
. Remaining options depend on the bearer
setting.
When the bearer is set to
GPRS
:
•
IP address
: enter the IP address of the proxy
server.
•
User name
: enter the login ID.
•
Password
: enter the login password.
•
APN
: enter the access point name of the GPRS
network gateway.
When the bearer is set to
Data
:
•
IP address
: enter the IP address of the proxy
server.
•
Login name
: enter the login ID.
Check with your service provider before you change
any browser settings on your phone.
48
Menu functions
•
Password
: enter the login password.
•
Dial-up number
: enter the PPP phone number.
•
Data call type
: select a call type for data
transmission.
Clear cache
(Menu 6.1.5)
Use this menu to clear information stored in the cache.
Games
(Menu 6.2)
You can download Java applications from various
sources using the web browser, and store them in your
phone. Use this menu to access and play Java games.
Accessing an embedded game
1. Select the game you want on the Games list.
On the startup screen of the game, you can access
the following options:
•
START GAME
: start a new game.
•
CONTINUE
: continue the last game you
played.
•
HIGH SCORE
: view the high score table. This
option may not be available for some games.
•
HOW TO PLAY
: view how to play the game
and the key functions for the game.
•
OPTION
: switch on or off the game sound.
2. Select
START GAME
or
CONTINUE
to start a
game.
3. Follow the onscreen instructions.
Viewing game information
Scroll to the game you want and press <
Info
>.
Changing the DNS settings
You may need to change the DNS (Domain Name
Server) setting of the Java server at your service
provider’s instructions.
1. Select
Setting
on the Games list.
2. Enter the primary address and press <
OK
>.
3. Enter the secondary address and press <
OK
>.
Java services may not be available, depending on
your service provider.
Menu functions
Funbox
(Menu 6)
49
Sounds
(Menu 6.3)
Use this menu to access sounds downloaded from the
wireless web or received in messages.
While reviewing a file, press <
Options
> to access the
following options:
•
Rename
: change the file name.
•
Delete
: delete the file.
•
Set as ring tone
: set the sound as your call
ringtone.
Images
(Menu 6.4)
Use this menu to access images downloaded from the
wireless web or received in messages.
While reviewing a file, press <
Options
> to access the
following options:
•
Rename
: change the file name.
•
Delete
: delete the file.
•
Set as wallpaper
: set the image as wallpaper for
the idle screen.
Delete all
(Menu 6.5)
Use this menu to delete all of the downloaded items in
the
Games
,
Sounds
, and
Images
folders.
1. Press [ ] to select the folders to be cleared.
2. Press <
Delete
>.
3. Press <
Yes
> twice to confirm the deletion.
Memory status
(Menu 6.6)
Use this menu to check the total amount of memory
for media items and the amount of memory currently
in use in each media box.
50
Menu functions
Organiser
(Menu 7)
The
Organiser
menu enables you to keep track of
your schedule and tasks, and to record voice memos.
You can also set the time and date and use convenient
features, such as an alarm clock, a calculator, and a
currency converter.
To access this menu, press <
Menu
> in Idle mode and
select
Organiser
.
Alarm
(Menu 7.1)
Use this menu to set alarms to sound at a specific
time.
Setting an alarm
1. Select the type of alarm.
2. Enter the time for the alarm to sound.
Press <
Options
> and select
Alarm tone
to
change the alarm tone.
3. Press [ ].
4. Select
AM
or
PM
in 12-hour time format.
5. If you selected
Morning call
in step 1, select a
schedule for the alarm to work.
Stopping an alarm
When the alarm sounds, press any key.
Deactivating alarms
When you do not need an alarm to sound any longer,
you can deactivate it.
• To remove an alarm set, select it from the Alarm
screen, press <
Options
>, and select
Remove
alarm
.
• To remove all alarm sets, select
Remove alarm
from the Alarm screen.
Setting the alarm to sound even if the phone
is off
From the Alarm screen, select
Autopower
→
Enable
.
If the phone is off when it is time for the alarm to
sound, the phone switches on and sounds the alarm.
Menu functions
Organiser
(Menu 7)
51
Calendar
(Menu 7.2)
Use this menu to write memos on your schedule or set
alarms to act as a reminder.
When you access the
Calendar
menu, the calendar in
Month view appears with today’s date highlighted.
Selecting a day
• Press [Left] or [Right] to move by day.
• Press [Up] or [Down] to move by week.
• Press [ / ] to move by month.
Using calendar options
From the calendar, press <
Options
> to access the
following options:
•
Search all
: view all of the memos you have
created.
•
Delete all
: delete all memos.
•
Go to date
: enter the specific date you want to
access.
•
Exit
: exit the
Calendar
menu.
Entering a new memo
1. Select a date on the calendar.
2. Enter your memo and press <
OK
>.
3. Press [ ] to set an alarm to sound on the chosen
day. Otherwise, press <
Skip
>.
4. Enter the time for the alarm to sound.
Press <
Melody
> to change the alarm tone.
5. Press [ ].
6. Select
AM
or
PM
in 12-hour format.
The colour of the date on the calendar changes to
green to indicate that a memo exists for that date.
Viewing a memo
1. Select a date which has memos on the calendar.
If more than one memo exists, they will display in
order of their alarm times.
2. Press [Left] or [Right] to access the other memos
scheduled for the selected day.
52
Menu functions
Using calendar memo options
While viewing a memo, press <
Options
> to access
the following options:
•
New
: add a new memo.
•
Edit
: edit the selected memo.
•
Alarm
: set an alarm for the memo.
•
Delete
: delete the memo.
•
Copy to
: copy the memo to another date.
•
Move to
: change the date of the memo.
Time & Date
(Menu 7.3)
Use this menu to change the time and date displayed
on your phone. Before setting the time and date,
specify your time zone in
World time
.
•
Set time
: enter the current time.
•
Set date
: enter the current date.
•
World time
: set your local time zone and find out
what time it is in another part of the world.
•
Time format
: select 12-hour or 24-hour time
format.
Calculator
(Menu 7.4)
Use this menu to perform basic arithmetic functions
such as addition, subtraction, multiplication, and
division.
1. Enter the first number.
•Press <
.()
> to insert a decimal point or a
bracket.
•
Press
[
] or [ ] to move the cursor.
2. Press the Navigation keys to access the math
function you want.
3. Enter the second number.
4. Press [ ] to view the result.
5. If necessary, repeat from step 2 to continue the
calculation.
To apply daylight savings time to time zones,
press <
Options
> and select
Set daylight
saving time
.
Menu functions
Organiser
(Menu 7)
53
To do list
(Menu 7.5)
Use this menu to create tasks and manage them.
Creating a task
1. Press <
New
>.
2. Enter a task and press <
OK
>.
3. Select a priority level.
4. Enter your deadline and press [ ].
Viewing the task
When you access the
To do list
menu, the tasks
display with a check mark, if the task has been done,
and a priority level indicator; for High, for
Normal, and for Low.
While viewing a task, press <
Options
> to access the
following options:
•
New
: add a new task.
•
Mark
: change the status of the selected task.
•
Edit
: edit the task.
•
Sort
: sort the tasks by priority or status.
•
Copy
: copy the selected task.
•
Copy to calendar
: copy the task to the calendar
as a memo.
•
Delete
: delete the task.
•
Delete all
: delete all tasks.
•
Exit
: exit the
To do list
menu.
Voice memo
(Menu 7.6)
Use this menu to record and play voice memos.
Voice record
(Menu 7.6.1)
You can record a voice memo of up to 30 seconds.
1. Press <
Record
> to start recording.
2. Speak into the microphone.
3. When you have finished, press <
Stop
>. The
following options display:
•
Replay
: play back your memo.
•
Re-record
: discard the memo and record
another one.
You can change the status of a specific task by
pressing [
]
.
54
Menu functions
•
Save
: save the memo.
•
Quit
: cancel your recording and exit the
Voice
record
menu.
4. Select
Save
to save the voice memo.
5. Enter a name of the voice memo and press <
OK
>.
Memo list
(Menu 7.6.2)
You can access the list of voice memos you have
recorded.
Press <
Options
> to access the following options:
•
Play
: play the selected voice memo.
•
Send
: send the voice memo as part of an MMS
message.
•
Rename
: change the file name.
•
Information
: access the file properties.
•
Delete
: delete the voice memo.
Delete all
(Menu 7.6.3)
You can delete all of the voice memos you have
recorded at one time.
Memory status
(Menu 7.6.4)
You can check the total amount of memory currently
in use for storing voice memos and the number of
voice memos.
Currency exchange
(Menu 7.7)
Use this menu to do currency conversions.
1. Enter the rate of foreign currency and press
<
OK
>.
2. Enter the amount of the source currency you want
to convert and press <
OK
>.
The amount you entered and its equivalent value
in the foreign currency display.
Menu functions
FM Radio
(Menu 8)
55
FM Radio
(Menu 8)
Use this menu to listen to music or news via the FM
radio on your phone.
To access this menu, press <
Menu
> in Idle mode and
select
FM radio
, or press [Down].
Turning on and listening to the radio
First, you must connect your phone with the headset,
which serves as a radio antenna.
1. Plug the connector of the supplied headset into the
jack on the right side of the phone.
2. From the FM Radio screen, press <
Options
> and
select
Power on/off
→
On
.
3. Press [Left] or [Right] to find the radio station you
want.
You can also press and hold [Left] or [Right] to
scan through available radio stations.
4. To exit the
FM Radio
menu without turning off the
radio, press [ ]. This enables you to access other
functions while listening to the radio.
Setting up a radio station list
You can store your favourite radio stations to quickly
access them without searching through noisy
frequencies.
1. Connect the headset to the phone and turn on the
radio.
2. Select an empty location and select
Add
.
3. Enter a title for the station you want and press
<
OK
>.
4. Enter the frequency of the station and press
<
OK
>.
5. Select a location in which you want to store the
station.
6. Repeat from step 2 to store other stations.
To listen to the stored stations, press [Up] or [Down]
from the FM Radio screen.
Turning off the radio
To turn off the radio, press <
Options
> from the radio
screen and select
Power on/off
→
Off
, or disconnect
the headset.
56
Menu functions
Using radio options
On the FM radio screen, press <
Options
> to access
the following options:.
•
Power on/off
: turn the radio on or off.
•
Add
: store a radio station.
•
Edit
: edit the title or frequency for a saved radio
station.
•
Self tuning
: let the phone automatically scan
through and save available radio stations.
•
Remove
: remove the selected station or all
stations.
•
Pop-up alert
: set the phone to alert you to listen
to the radio at a specified time. When the pop-up
notification appears on the screen, press <
Listen
>
to turn on the specified radio station.
•
Settings
: change the radio settings.
Volume
: select the radio volume.
Mode
: change the audio mode to the phone’s
speaker or headset.
Phone settings
(Menu 9)
The
Phone settings
menu provides you with various
setting options to customise the phone to your
preferences and needs. You can also reset the settings
to their default status.
To access this menu, press <
Menu
> in Idle mode and
select
Phone settings
.
Infrared activate
(Menu 9.1)
Use this menu to send or receive data to or from IrDA-
compatible computers or phones through the infrared
port.
Connecting with a computer
Select
With PC
to use the IrDA feature with a
computer.
To use an infrared connection, you must:
• configure and activate an IrDA-compliant infrared
port on your PC.
Menu functions
Phone settings
(Menu 9)
57
• activate the infrared feature on the phone; the
IrDA icon ( ) appears on the top line of the
display.
• align the IrDA port on the phone with the IrDA port
on your phone computer or another phone.
The connection is ready for data transmission.
If there is no communication between your phone and
the IrDA-compliant device within 30 seconds
activating the feature, it is automatically deactivated.
Receiving Phonebook data from another
phone
1. Align the IrDA ports on both phones with each
other.
2. Select
With other phone
from the
Infrared
activate
menu.
3. When the list of the received data displays, select
one of the two options:
To save an individual item:
a. Select the item you want from the list.
b. Press <
Options
> and select
Save
to save the
data.
Otherwise, select
Discard
to delete the data.
To sa v e al l d a t a :
a. From the item list, press <
Options
> to select
one of the following options:
•
Save all vCard
: save all Phonebook entries.
•
Discard all vCard
: delete all Phonebook
entries.
b. Press <
Save
> to save the entries.
Sending your Phonebook to another phone
1. Align the IrDA ports on both phones with each
other.
2. Access
Phonebook
→
Search
.
58
Menu functions
3. Select a name.
4. Scroll to a number or e-mail address.
5. Press <
Options
> and select
Send via IrDA
.
6. Select a sending option.
•
Selected data
: send the selected number.
•
All data
: send all of the numbers and e-mail
addresses in the name.
The number is sent to the other phone.
Deactivating the infrared port
To end the IrDA connection and deactivate the infrared
port, select
Deactivate infrared
from the
Infrared
activate
menu.
Display settings
(Menu 9.2)
Use this menu to change settings for the display and
light.
Wallpaper
(Menu 9.2.1)
You can change the background image and the
settings for the text of Idle mode.
•
Wallpaper list
: select a background image.
•
Text display
: determine the phone displays the
time and date.
•
Text colour
: select a text colour.
Brightness
(Menu 9.2.2)
You can adjust the brightness of the display for
varying lighting conditions.
Contrast
(Menu 9.2.3)
You can adjust the contrast of the brightness for the
main display and external display. Adjust this setting
with the display brightness to see the display clearly in
different lighting conditions.
Menu functions
Phone settings
(Menu 9)
59
Backlight
(Menu 9.2.4)
You can select the length of time the backlight or
display stays on.
•
Backlight on
: select the length of time the
backlight stays on.
•
Backlight dim
: select the length of time the
display is in Dim mode after the backlight turns off.
After a specified time, the display turns off.
Graphic logo
(Menu 9.2.5)
Use this menu to set the phone to display a graphic
icon instead of your service provider’s logo on the idle
screen. This is only available if a graphic icon has been
received in a message.
Dialling font colour
(Menu 9.2.6)
Use this menu to select a font colour for the numbers
entered while dialling.
Greeting message
(Menu 9.3)
Use this menu to enter the greeting that is displayed
briefly when the phone is switched on.
Own number
(Menu 9.4)
Use this feature to check your phone numbers, or to
assign a name to each of the numbers. Changes made
here do not affect the actual subscriber numbers on
your SIM card.
Language
(Menu 9.5)
Use this menu to select one of several languages for
the display text. If you select
Automatic
, the phone
uses the same language as the SIM card.
Security
(Menu 9.6)
Use this menu to protect the phone against
unauthorised use by managing the several access
codes of your phone and SIM card.
If you enter an incorrect PIN/PIN2 three times in
succession, the SIM card is blocked. To unblock it,
you need to enter your PUK/PUK2 (Personal
Unblocking Key). The codes are supplied by your
network operator.
60
Menu functions
PIN check
(Menu 9.6.1)
The 4- to 8-digit PIN (Personal Identification Number)
protects your SIM card against unauthorised use.
When this feature is enabled, the phone requires your
PIN each time it is switched on.
Change PIN
(Menu 9.6.2)
Use this menu to change your PIN. The PIN check
feature must be enabled to change the PIN.
Phone lock
(Menu 9.6.3)
Use this menu to lock the phone from unauthorised
use. When this feature is enabled, you must enter a 4-
to 8-digit phone password each time the phone is
switched on.
The password is preset to
00000000
. To change the
password, use the
Change password
menu.
Change password
(Menu 9.6.4)
Use this menu to change your phone password.
Privacy
(Menu 9.6.5)
Use this menu to lock your media content, including
MMS messages, voice memos, images, and sounds.
1. Press [ ] to select the items to be locked.
2. Press <
OK
> to lock the marked items.
3. Enter the phone password and press <
OK
>.
To access a locked item, you need to enter the phone
password.
SIM lock
(Menu 9.6.6)
This menu allows your phone to work only with the
current SIM by assigning a SIM lock code. You must
enter the SIM lock code to use a different SIM card.
FDN mode
(Menu 9.6.7)
If supported by your SIM card, Fixed Dialling Number
(FDN) mode restricts your outgoing calls to a limited
set of phone numbers. When this feature is enabled,
you can make calls only to phone numbers stored on
the SIM card.
Menu functions
Phone settings
(Menu 9)
61
Change PIN2
(Menu 9.6.8)
If supported by your SIM card, the Change PIN2
feature changes your current PIN2.
Extra settings
(Menu 9.7)
You can turn the automatic redialling or answering
feature on or off.
•
Auto redial
: set the phone to make up to ten
attempts to redial a phone number after an
unsuccessful call.
•
Active folder
: answer an incoming call by opening
the phone.
•
Anykey
answer
: answer an incoming call by
pressing any key, except <
Reject
> or [ ].
Volume key
(Menu 9.8)
Use this menu to set whether the phone mutes the call
ringer or rejects a call if you press and hold [ / ]
when a call comes in.
Short cut
(Menu 9.9)
You can use the Navigation keys as shortcut keys to
access specific menus directly from Idle mode. Use
this menu to change the shortcut assignments for
[Up], [Left], and [Right]. [Down] is fixed as a shortcut
to
FM Radio
.
1. Select a key to be used as a shortcut key.
2. Select a menu to be assigned to the key.
Reset settings
(Menu 9.0)
Use this menu to reset the phone to its default
settings.
Enter the 4- to 8-digit phone password and press
<
OK
>.
The password is preset to
00000000
. You can
change this password.
p. 60
62
Solve problems
Help and personal needs
To save the time and expense of an unnecessary
service call, perform the simple checks in this section
before contacting a service professional.
When you switch on your phone, the following
messages may appear:
“Insert SIM card”
• Be sure that the SIM card is correctly installed.
“Phone locked”
• The automatic locking function has been enabled.
You must enter the phone’s password before you
can use the phone.
“Enter PIN”
• You are using your phone for the first time. You
must enter the PIN supplied with the SIM card.
• The PIN check feature is enabled. Every time the
phone is switched on, the PIN has to be entered.
To disable this feature, use the
PIN check
menu.
“Enter PUK”
• The PIN code has been entered incorrectly three
times in succession, and the SIM card is now
blocked. Enter the PUK supplied by your service
provider.
“No service,” “Network failure,” or “Not done”
displays
• The network connection has been lost. You may be
in a weak signal area. Move and try again.
• You are trying to access an option for which you
have no subscription with your service provider.
Contact the service provider for further details.
You have entered a number but it was not dialled
• Be sure that you have pressed [ ].
• Be sure that you have accessed the right cellular
network.
• Be sure that you have not set an outgoing call
barring option.
63
Solve problems
Your correspondent cannot reach you
• Be sure that your phone is switched on. ([ ]
pressed for more than one second.)
• Be sure that you are accessing the correct cellular
network.
• Be sure that you have not set an incoming call
barring option.
Your correspondent cannot hear you speaking
• Be sure that you have switched on the
microphone.
• Be sure that you are holding the phone close
enough to your mouth. The microphone is located
at the bottom of the phone.
The phone starts beeping and “Warning Low
battery” flashes on the display
• Your battery is insufficiently charged. Recharge the
battery.
The audio quality of the call is poor
• Check the signal strength indicator on the display
( ). The number of bars indicates the signal
strength from strong ( ) to weak ( ).
• Try moving the phone slightly or moving closer to a
window if you are in a building.
No number is dialled when you re-call a
Phonebook entry
•Use the
Search
menu to ensure the number has
been stored correctly.
• Re-store the number, if necessary.
The battery doesn’t charge properly or the phone
sometimes turns itself off
• Wipe the charging contacts both on the phone and
on the battery with a clean soft cloth.
If the above guidelines do not help you to solve
the problem, take note of:
• The model and serial numbers of your phone
•Your warranty details
• A clear description of the problem
Then contact your local dealer or Samsung after-sales
service.
64
Health and safety information
Exposure to Radio Frequency (RF) Signals
Certification Information (SAR)
Your wireless phone is a radio transmitter and receiver.
It is designed and manufactured not to exceed the
exposure limits for radio frequency (RF) energy set by
the Federal Communications Commission (FCC) of the
U.S. government. These FCC exposure limits are
derived from the recommendations of two expert
organizations, the National Counsel on Radiation
Protection and Measurement (NCRP) and the Institute
of Electrical and Electronics Engineers (IEEE). In both
cases, the recommendations were developed by
scientific and engineering experts drawn from
industry, government, and academia after extensive
reviews of the scientific literature related to the
biological effects of RF energy.
The exposure limit set by the FCC for wireless mobile
phones employs a unit of measurement known as the
Specific Absorption Rate (SAR). The SAR is a measure
of the rate of absorption of RF energy by the human
body expressed in units of watts per kilogram (W/kg).
The FCC requires wireless phones to comply with a
safety limit of 1.6 watts per kilogram (1.6 W/kg). The
FCC exposure limit incorporates a substantial margin
of safety to give additional protection to the public and
to account for any variations in measurements.
SAR tests are conducted using standard operating
positions accepted by the FCC with the phone
transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is
determined at the highest certified power level, the
actual SAR level of the phone while operating can be
well below the maximum value. This is because the
phone is designed to operate at multiple power levels
so as to use only the power required to reach the
network. In general, the closer you are to a wireless
base station antenna, the lower the power output.
65
Health and safety information
When approval test is done, no Samsung supplied
accessories are avialable but maybe available later
after approval.
“Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that
it does not exceed the exposure limit established by
the FCC. Tests for each model phone are performed in
positions and locations (e.g. at the ear and worn on
the body) as required by the FCC. The highest SAR
values for this model phone as reported to the FCC are
Head: 0.823 W/Kg, Body-worn 0.246 W/Kg. For body
worn operation, this model phone has been tested and
meets the FCC RF exposure guidelines when used with
a Samsung accessory designated for this product or
when used with an accessory that contains no metal
and that positions the handset a minimum of 1.5 cm
from the body.”
Non-compliance with the above restrictions may result
in violation of FCC RF esposure guidelines.
SAR information on this and other model phones can
be viewed on-line at www.fcc.gov/oet/fccid. This site
uses the phone FCC ID number, A3LSGHX300.
Sometimes it may be necessary to remove the battery
pack to find the number. Once you have the FCC ID
number for a particular phone, follow the instructions
on the website and it should provide values for typical
or maximum SAR for a particular phone. Additional
product specific SAR information can also be obtained
at www.fcc.gov/cgb/sar.
66
Health and safety information
Consumer Information on Wireless Phones
The U.S. Food and Drug Administration (FDA) has
published a series of Questions and Answers for
consumers relating to radio frequency (RF) exposure
from wireless phones. The FDA publication includes
the following information:
What kinds of phones are the subject of this
update?
The term wireless phone refers here to hand-held
wireless phones with built-in antennas, often called
“cell,” “mobile,” or “PCS” phones. These types of
wireless phones can expose the user to measurable
radio frequency energy (RF) because of the short
distance between the phone and the user's head.
These RF exposures are limited by Federal
Communications Commission safety guidelines that
were developed with the advice of FDA and other
federal health and safety agencies. When the phone is
located at greater distances from the user, the
exposure to RF is drastically lower because a person's
RF exposure decreases rapidly with increasing
distance from the source. The so-called “cordless
phones,” which have a base unit connected to the
telephone wiring in a house, typically operate at far
lower power levels, and thus produce RF exposures
well within the FCC's compliance limits.
Do wireless phones pose a health hazard?
The available scientific evidence does not show that
any health problems are associated with using
wireless phones. There is no proof, however, that
wireless phones are absolutely safe. Wireless phones
emit low levels of radio frequency energy (RF) in the
microwave range while being used. They also emit
very low levels of RF when in the stand-by mode.
Whereas high levels of RF can produce health effects
(by heating tissue), exposure to low level RF that does
not produce heating effects causes no known adverse
health effects. Many studies of low level RF exposures
have not found any biological effects. Some studies
have suggested that some biological effects may
occur, but such findings have not been confirmed by
additional research. In some cases, other researchers
have had difficulty in reproducing those studies, or in
determining the reasons for inconsistent results.
67
Health and safety information
What is FDA's role concerning the safety of
wireless phones?
Under the law, FDA does not review the safety of
radiation-emitting consumer products such as wireless
phones before they can be sold, as it does with new
drugs or medical devices. However, the agency has
authority to take action if wireless phones are shown
to emit radio frequency energy (RF) at a level that is
hazardous to the user. In such a case, FDA could
require the manufacturers of wireless phones to notify
users of the health hazard and to repair, replace or
recall the phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA
regulatory actions, FDA has urged the wireless phone
industry to take a number of steps, including the
following:
• “Support needed research into possible biological
effects of RF of the type emitted by wireless
phones;
• “Design wireless phones in a way that minimizes
any RF exposure to the user that is not necessary
for device function; and
• “Cooperate in providing users of wireless phones
with the best possible information on possible
effects of wireless phone use on human health.
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at
the federal level. The following agencies belong to this
working group:
• “National Institute for Occupational Safety and
Health
• “Environmental Protection Agency
• “Federal Communications Commission
• “Occupational Safety and Health Administration
• “National Telecommunications and Information
Administration
The National Institutes of Health participates in some
interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless
phones with the Federal Communications Commission
(FCC). All phones that are sold in the United States
must comply with FCC safety guidelines that limit RF
68
Health and safety information
exposure. FCC relies on FDA and other health agencies
for safety questions about wireless phones.
FCC also regulates the base stations that the wireless
phone networks rely upon. While these base stations
operate at higher power than do the wireless phones
themselves, the RF exposures that people get from
these base stations are typically thousands of times
lower than those they can get from wireless phones.
Base stations are thus not the primary subject of the
safety questions discussed in this document.
What are the results of the research done
already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws in
their research methods. Animal experiments
investigating the effects of radio frequency energy
(RF) exposures characteristic of wireless phones have
yielded conflicting results that often cannot be
repeated in other laboratories. A few animal studies,
however, have suggested that low levels of RF could
accelerate the development of cancer in laboratory
animals. However, many of the studies that showed
increased tumor development used animals that had
been genetically engineered or treated with cancer-
causing chemicals so as to be pre-disposed to develop
cancer in absence of RF exposure. Other studies
exposed the animals to RF for up to 22 hours per day.
These conditions are not similar to the conditions
under which people use wireless phones, so we don't
know with certainty what the results of such studies
mean for human health.
Three large epidemiology studies have been published
since December 2000. Between them, the studies
investigated any possible association between the use
of wireless phones and primary brain cancer, glioma,
meningioma, or acoustic neuroma, tumors of the brain
or salivary gland, leukemia, or other cancers. None of
the studies demonstrated the existence of any harmful
health effects from wireless phones RF exposures.
However, none of the studies can answer questions
about long-term exposures, since the average period
of phone use in these studies was around three years.
69
Health and safety information
What research is needed to decide whether RF
exposure from wireless phones poses a health
risk?
A combination of laboratory studies and
epidemiological studies of people actually using
wireless phones would provide some of the data that
are needed. Lifetime animal exposure studies could be
completed in a few years. However, very large
numbers of animals would be needed to provide
reliable proof of a cancer promoting effect if one
exists. Epidemiological studies can provide data that is
directly applicable to human populations, but ten or
more years' follow-up may be needed to provide
answers about some health effects, such as cancer.
This is because the interval between the time of
exposure to a cancer-causing agent and the time
tumors develop - if they do - may be many, many
years. The interpretation of epidemiological studies is
hampered by difficulties in measuring actual RF
exposure during day-to-day use of wireless phones.
Many factors affect this measurement, such as the
angle at which the phone is held, or which model of
phone is used.
What is FDA doing to find out more about the
possible health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology
Program and with groups of investigators around the
world to ensure that high priority animal studies are
conducted to address important questions about the
effects of exposure to radio frequency energy (RF).
FDA has been a leading participant in the World Health
Organization international Electromagnetic Fields
(EMF) Project since its inception in 1996. An influential
result of this work has been the development of a
detailed agenda of research needs that has driven the
establishment of new research programs around the
world. The Project has also helped develop a series of
public information documents on EMF issues.
FDA and Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative
Research and Development Agreement (CRADA) to do
research on wireless phone safety. FDA provides the
scientific oversight, obtaining input from experts in
government, industry, and academic organizations.
CTIA-funded research is conducted through contracts
70
Health and safety information
to independent investigators. The initial research will
include both laboratory studies and studies of wireless
phone users. The CRADA will also include a broad
assessment of additional research needs in the
context of the latest research developments around
the world.
What steps can I take to reduce my exposure
to radio frequency energy from my wireless
phone?
If there is a risk from these products - and at this
point we do not know that there is - it is probably very
small. But if you are concerned about avoiding even
potential risks, you can take a few simple steps to
minimize your exposure to radio frequency energy
(RF). Since time is a key factor in how much exposure
a person receives, reducing the amount of time spent
using a wireless phone will reduce RF exposure.
• “If you must conduct extended conversations by
wireless phone every day, you could place more
distance between your body and the source of the
RF, since the exposure level drops off dramatically
with distance. For example, you could use a
headset and carry the wireless phone away from
your body or use a wireless phone connected to a
remote antenna.
Again, the scientific data do not demonstrate that
wireless phones are harmful. But if you are concerned
about the RF exposure from these products, you can
use measures like those described above to reduce
your RF exposure from wireless phone use.
What about children using wireless phones?
The scientific evidence does not show a danger to
users of wireless phones, including children and
teenagers. If you want to take steps to lower exposure
to radio frequency energy (RF), the measures
described above would apply to children and
teenagers using wireless phones. Reducing the time of
wireless phone use and increasing the distance
between the user and the RF source will reduce RF
exposure.
Some groups sponsored by other national
governments have advised that children be
discouraged from using wireless phones at all. For
Health and safety information
Phone
71
example, the government in the United Kingdom
distributed leaflets containing such a recommendation
in December 2000. They noted that no evidence exists
that using a wireless phone causes brain tumors or
other ill effects. Their recommendation to limit
wireless phone use by children was strictly
precautionary; it was not based on scientific evidence
that any health hazard exists.
Do hands-free kits for wireless phones reduce
risks from exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that hands-free kits reduce risks. Hands-free
kits can be used with wireless phones for convenience
and comfort. These systems reduce the absorption of
RF energy in the head because the phone, which is the
source of the RF emissions, will not be placed against
the head. On the other hand, if the phone is mounted
against the waist or other part of the body during use,
then that part of the body will absorb more RF energy.
Wireless phones marketed in the U.S. are required to
meet safety requirements regardless of whether they
are used against the head or against the body. Either
configuration should result in compliance with the
safety limit.
Do wireless phone accessories that claim to
shield the head from RF radiation work?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that accessories that claim to shield the head
from those emissions reduce risks. Some products
that claim to shield the user from RF absorption use
special phone cases, while others involve nothing
more than a metallic accessory attached to the phone.
Studies have shown that these products generally do
not work as advertised. Unlike “hand-free” kits, these
so-called “shields” may interfere with proper operation
of the phone. The phone may be forced to boost its
power to compensate, leading to an increase in RF
absorption. In February 2002, the Federal trade
Commission (FTC) charged two companies that sold
devices that claimed to protect wireless phone users
from radiation with making false and unsubstantiated
72
Health and safety information
claims. According to FTC, these defendants lacked a
reasonable basis to substantiate their claim.
What about wireless phone interference with
medical equipment?
Radio frequency energy (RF) from wireless phones can
interact with some electronic devices. For this reason,
FDA helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted
cardiac pacemakers and defibrillators from wireless
telephones. This test method is now part of a standard
sponsored by the Association for the Advancement of
Medical instrumentation (AAMI). The final draft, a joint
effort by FDA, medical device manufacturers, and
many other groups, was completed in late 2000. This
standard will allow manufacturers to ensure that
cardiac pacemakers and defibrillators are safe from
wireless phone EMI. FDA has tested wireless phones
and helped develop a voluntary standard sponsored by
the Institute of Electrical and Electronic Engineers
(IEEE). This standard specifies test methods and
performance requirements for hearing aids and
wireless phones so that no interference occurs when a
person uses a compatible phone and a compatible
hearing aid at the same time. This standard was
approved by the IEEE in 2000.
FDA continues to monitor the use of wireless phones
for possible interactions with other medical devices.
Should harmful interference be found to occur, FDA
will conduct testing to assess the interference and
work to resolve the problem.
Additional information on the safety of RF exposures
from various sources can be obtained from the
following organizations:
• FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
• Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
• Occupational Safety and Health Administration's
(OSHA):
http://www.osha.gov/SLTC/
radiofrequencyradiation/index.html
Health and safety information
Phone
73
• National institute for Occupational Safety and
Health (NIOSH):
http://www.cdc.gov/niosh/emfpg.html
• World health Organization (WHO):
http://www.who.int/peh-emf/
• International Commission on Non-Ionizing
Radiation Protection:
http://www.icnirp.de
• National Radiation Protection Board (UK):
http://www.nrpb.org.uk
• Updated 4/3/2002: US food and Drug
Administration
http://www.fda.gov/cellphones
Road Safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime.
But an important responsibility accompanies the
benefits of wireless phones, one that every user must
uphold.
When driving a car, driving is your first responsibility.
When using your wireless phone behind the wheel of a
car, practice good common sense and remember the
following tips:
1. Get to know your wireless phone and its features,
such as speed dial and redial. If available, these
features help you to place your call without taking
your attention off the road.
2. When available, use a hands-free device. If
possible, add an additional layer of convenience
and safety to your wireless phone with one of the
many hands free accessories available today.
74
Health and safety information
3. Position your wireless phone within easy reach. Be
able to access your wireless phone without
removing your eyes from the road. If you get an
incoming call at an inconvenient time, let your
voice mail answer it for you.
4. Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy
traffic or hazardous weather conditions. Rain,
sleet, snow, ice and even heavy traffic can be
hazardous.
5. Do not take notes or look up phone numbers while
driving. Jotting down a “to do” list or flipping
through your address book takes attention away
from your primary responsibility, driving safely.
6. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan calls when your car
will be stationary. If you need to make a call while
moving, dial only a few numbers, check the road
and your mirrors, then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting. Make
people you are talking with aware you are driving
and suspend conversations that have the potential
to divert your attention from the road.
8. Use your wireless phone to call for help. Dial 9-1-1
or other local emergency number in the case of
fire, traffic accident or medical emergencies.
Remember, it is a free call on your wireless phone!
9. Use your wireless phone to help others in
emergencies. If you see an auto accident, crime in
progress or other serious emergency where lives
are in danger, call 9-1-1 or other local emergency
number, as you would want others to do for you.
10. Call roadside assistance or a special non-
emergency wireless assistance number when
necessary. If you see a broken-down vehicle
posing no serious hazard, a broken traffic signal, a
minor traffic accident where no one appears
injured, or a vehicle you know to be stolen, call
roadside assistance or other special non-
emergency number.
Health and safety information
Phone
75
“The wireless industry reminds you to use your
phone safely when driving.”
For more information, please call 1-888-901-SAFE, or
visit our web-site www.wow-com.com
Provided by the Cellular Telecommunications &
Internet Association
Operating Environment
Remember to follow any special regulations in force in
any area and always switch your phone off whenever it
is forbidden to use it, or when it may cause
interference or danger. When connecting the phone or
any accessory to another device, read its user's guide
for detailed safety instructions. Do not connect
incompatible products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation of
the equipment and for the safety of personnel, it is
recommended that the equipment should only be used
in the normal operating position (held to your ear with
the antenna pointing over your shoulder).
Using Your Phone Near Other Electronic
Devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against the
RF signals from your wireless phone. Consult the
manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be maintained
between a wireless phone and a pacemaker to avoid
potential interference with the pacemaker.
These recommendations are consistent with the
independent research and recommendations of
Wireless Technology Research.
Persons with pacemakers:
• should always keep the phone more than 15 cm
(6 inches) from their pacemaker when the phone is
switched on.
• should not carry the phone in a breast pocket.
76
Health and safety information
• should use the ear opposite the pacemaker to
minimize potential interference.
If you have any reason to suspect that interference is
taking place, switch your phone off immediately.
Hearing Aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you
may wish to consult your hearing aid manufacturer to
discuss alternatives.
Other Medical Devices
If you use any other personal medical devices, consult
the manufacturer of your device to determine if it is
adequately shielded from external RF energy. Your
physician may be able to assist you in obtaining this
information. Switch your phone off in health care
facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care facilities
may be using equipment that could be sensitive to
external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle. You should also
consult the manufacturer of any equipment that has
been added to your vehicle.
Posted Facilities
Switch your phone off in any facility where posted
notices require you to do so.
Potentially Explosive Environments
Switch your phone off when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause an
explosion or fire resulting in bodily injury or even
death.
Users are advised to switch the phone off while at a
refueling point (service station). Users are reminded of
the need to observe restrictions on the use of radio
equipment in fuel depots (fuel storage and distribution
Health and safety information
Phone
77
areas), chemical plants or where blasting operations
are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas (such
as propane or butane), areas where the air contains
chemicals or particles, such as grain, dust or metal
powders, and any other area where you would
normally be advised to turn off your vehicle engine.
Emergency Calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well as
user programmed functions, which cannot guarantee
connection in all conditions. Therefore, you should
never rely solely on any wireless phone for essential
communications (medical emergencies, for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not be
possible on all wireless phone networks or when
certain network services and/or phone features are in
use. Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location (for example, 911 or other official
emergency number). Emergency numbers vary by
location.
3. Press .
If certain features are in use (call barring, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult this document and your local cellular service
provider.
When making an emergency call, remember to give all
the necessary information as accurately as possible.
Remember that your phone may be the only means of
communication at the scene of an accident; do not cut
off the call until given permission to do so.
78
Health and safety information
Restricting Children's access to your Phone
Your phone is not a toy. Children should not be allowed
to play with it because they could hurt themselves and
others, damage the phone or make calls that increase
your phone bill.
FCC Notice and Cautions
FCC Notice
The phone may cause TV or radio interference if used
in close proximity to receiving equipment. The FCC
can require you to stop using the phone if such
interference cannot be eliminated.
Vehicles using liquefied petroleum gas (such as
propane or butane) must comply with the National Fire
Protection Standard (NFPA-58). For a copy of this
standard, contact the National Fire Protection
Association, One Battery march Park, Quincy, MA
02269, Attn: Publication Sales Division.
Cautions
Changes or modifications made in the radio phone, not
expressly approved by Samsung, will void the user’s
authority to operate the equipment.
Only use approved batteries, antennas and chargers.
The use of any unauthorized accessories may be
dangerous and void the phone warranty if said
accessories cause damage or a defect to the phone.
Although your phone is quite sturdy, it is a complex
piece of equipment and can be broken. Avoid
dropping, hitting, bending or sitting on it.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
Health and safety information
Phone
79
Other Important Safety Information
• Only qualified personnel should service the phone
or install the phone in a vehicle. Faulty installation
or service may be dangerous and may invalidate
any warranty applicable to the device.
• Check regularly that all wireless phone equipment
in your vehicle is mounted and operating properly.
• Do not store or carry flammable liquids, gases or
explosive materials in the same compartment as
the phone, its parts or accessories.
• For vehicles equipped with an air bag, remember
that an air bag inflates with great force. Do not
place objects, including both installed or portable
wireless equipment in the area over the air bag or
in the air bag deployment area. If wireless
equipment is improperly installed and the air bag
inflates, serious injury could result.
• Switch your phone off before boarding an aircraft.
The use of wireless phone in aircraft is illegal and
may be dangerous to the aircraft's operation.
• Failure to observe these instructions may lead to
the suspension or denial of telephone services to
the offender, or legal action, or both.
80
Health and safety information
Product Performance
Getting the Most Out of Your Signal Reception
The quality of each call you make or receive depends
on the signal strength in your area. Your phone
informs you of the current signal strength by
displaying a number of bars next to the signal strength
icon. The more bars displayed, the stronger the signal.
If you're inside a building, being near a window may
give you better reception.
Understanding the Power Save Feature
If your phone is unable to find a signal after 15
minutes of searching, a Power Save feature is
automatically activated. If your phone is active, it
periodically rechecks service availability or you can
check it yourself by pressing any key.
Anytime the Power Save feature is activated, a
message displays on the screen. When a signal is
found, your phone returns to standby mode.
Understanding How Your Phone Operates
Your phone is basically a radio transmitter and
receiver. When it's turned on, it receives and transmits
radio frequency (RF) signals. When you use your
phone, the system handling your call controls the
power level. This power can range from 0.006 watts to
0.2 watts in digital mode.
Maintaining Your Phone's Peak Performance
For the best care of your phone, only authorized
personnel should service your phone and accessories.
Faulty service may void the warranty.
There are several simple guidelines to operating your
phone properly and maintaining safe, satisfactory
service.
• Hold the phone with the antenna raised, fully-
extended and over your shoulder.
• Try not to hold, bend or twist the phone's antenna.
• Don't use the phone if the antenna is damaged.
• Speak directly into the phone's receiver.
Health and safety information
Phone
81
• Avoid exposing your phone and accessories to rain
or liquid spills. If your phone does get wet,
immediately turn the power off and remove the
battery. If it is inoperable, call Customer Care for
service.
Availability of Various Features/Ring
Tones
Many services and features are network dependent
and may require additional subscription and/or usage
charges. Not all features are available for purchase or
use in all areas. Downloadable Ring Tones may be
available at an additional cost. Other conditions and
restrictions may apply. See your service provider for
additional information.
Battery Standby and Talk Time
Standby and talk times will vary depending on phone
usage patterns and conditions. Battery power
consumption depends on factors such as network
configuration, signal strength, operating temperature,
features selected, frequency of calls, and voice, data,
and other application usage patterns.
Battery Precautions
• Never use any charger or battery that is damaged
in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network's base
station, it uses less power; talk and standby time
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
• Battery charging time depends on the remaining
battery charge and the type of battery and charger
used. The battery can be charged and discharged
hundreds of times, but it will gradually wear out.
When the operation time (talk time and standby
time) is noticeably shorter than normal, it is time
to buy a new battery.
• If left unused, a fully charged battery will
discharge itself over time.
82
Health and safety information
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not in use,
disconnect it from the power source. Do not leave
the battery connected to a charger for more than a
week, since overcharging may shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling or
warming first.
• Do not leave the battery in hot or cold places, such
as in a car in summer or winter conditions, as you
will reduce the capacity and lifetime of the battery.
Always try to keep the battery at room
temperature. A phone with a hot or cold battery
may temporarily not work, even when the battery
is fully charged. Li-ion batteries are particularly
affected by temperatures below 0 °C (32 °F).
• Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object (coin,
clip or pen) causes a direct connection between the
+ and - terminals of the battery (metal strips on
the battery), for example when you carry a spare
battery in a pocket or bag. Short-circuiting the
terminals may damage the battery or the object
causing the short-circuiting.
• Dispose of used batteries in accordance with local
regulations. In some areas, the disposal of
batteries in household or business trash may be
prohibited. For safe disposal options for Li-Ion
batteries, contact your nearest Samsung
authorized service center. Always recycle. Do not
dispose of batteries in a fire.
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for
many years.
• Keep the phone and all its parts and accessories
out of the reach of small children.
• Keep the phone dry. Precipitation, humidity and
liquids contain minerals that will corrode electronic
circuits.
Health and safety information
Phone
83
• Do not use the phone with a wet hand. Doing so
may cause an electric shock to you or damage to
the phone.
• Do not use or store the phone in dusty, dirty areas,
as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the phone,
which may damage the phone's electronic circuit
boards.
• Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the phone. Wipe it with
a soft cloth slightly dampened in a mild soap-and-
water solution.
• Do not paint the phone. Paint can clog the device's
moving parts and prevent proper operation.
• Do not put the phone in or on heating devices,
such as a microwave oven, a stove or a radiator.
The phone may explode when overheated.
• When the phone or battery gets wet, the label
indicating water damage inside the phone changes
color. In this case, phone repairs are no longer
guaranteed by the manufacturer's warranty, even
if the warranty for your phone has not expired.
• If your phone has a flash or light, do not use it too
close to the eyes of people or animals. This may
cause damage to their eyes.
• Use only the supplied or an approved replacement
antenna. Unauthorized antennas or modified
accessories may damage the phone and violate
regulations governing radio devices.
• If the phone, battery, charger or any accessory is
not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
84
Index
A
ABC mode, text input • 19
Active folder • 61
Alarm • 50
Answering
call • 23
second call • 24
Anykey answer • 61
Auto redial • 61
B
Background image • 58
Backlight, set • 59
Band selection • 34
Barring, calls • 32
Battery
charging • 7
low indicator • 8
precautions • 65
Brightness, display • 58
Broadcast messages • 40
Browser, web • 45
C
Calculator • 52
Calendar • 51
Call cost • 31
Call records
dialled • 30
missed • 29
received • 30
Call time • 30
Caller group
editing • 27
searching • 27
Caller ID • 33
Calls answering • 23
barring • 32
diverting • 31
holding • 24
making • 22
redialling • 22
rejecting • 23
waiting • 32
CB (Cell Broadcast) messages •
40
Characters, enter • 19
Connection tone • 36
Contrast, display • 58
Creating messages
MMS • 42
SMS • 37
CUG (Closed User Group) • 33
Currency converter • 54
D
Date, set • 52
Deleting
calendar memos • 52
call records • 30
downloaded items • 49
MMS • 41, 42, 43
phonebook • 26, 28
SMS • 36, 43
tasks • 53
voice memos • 54
Delivery reports, message • 44
Dialled calls • 30
Dialling font, set • 59
Display
backlight, set • 59
brightness • 58
contrast • 58
icons • 10
language • 59
layout • 10
settings • 58
Diverting calls • 31
DTMF tones, send • 25
E
Emergency calls • 68
Emoticons • 38
F
FDN (Fixed Dialling Number)
mode • 60
FM radio • 55
Folder tone • 35
Funbox • 45
G
Games • 48
Greeting message • 59
H
Health and safety • 64
Holding, call • 24
I
Icons, description • 10
85
Index
Images, downloaded • 49
Inbox, messages
MMS • 41
SMS • 36
Infrared port • 56
International calls • 22
Internet • 45
J
Java applications • 48
K
Keypad tones
selecting • 35
sending/muting • 25
volume • 35
L
Language, select • 59
Last number, redial • 22
Locking
media content • 60
phone • 60
SIM card • 60
Low battery indicator • 8
M
Memory status
downloaded items • 49
messages • 43
phonebook • 28
Message tone • 35
Messages
cell broadcast • 40
greeting • 59
MMS • 41
push • 45
SMS • 36
voice • 40
Minute minder • 35
Missed calls • 29
MMS messages
creating/sending • 42
deleting • 41, 42
setting • 44
viewing • 41
Multiparty-call • 25
N
Names
entering • 19
searching • 26
Network band, selection • 33
Network services • 31
Numbers
searching 26
storing • 26
O
Organiser • 50
Outbox, messages
MMS • 41
SMS • 36
P
Password
call barring • 32
phone • 60
Phonecare and maintenance •
69
display • 10
icons • 10
locking • 13, 60
password • 60
resetting • 61
switching on/off • 8
unpacking • 6
Phonebook
adding • 26
deleting • 26, 28
finding • 26
options • 26
speed dialling • 28
PIN, change • 60
PIN2, change • 61
Power on/off tone • 35
Privacy • 60
Problems, solve • 62
Push messages • 45
R
Radio • 55
Received calls • 30
Redialling
automatically • 61
manually • 22
Resetting phone • 61
Ringer
incoming calls • 34
messages • 35
Road safety • 66
Roaming • 33
S
Safety
information • 64
precautions • 1
SDN (Service Dialling
Numbers) • 29
Security, calls • 59
Sent messages
MMS • 41
SMS • 36
86
Index
Shortcut • 13, 61
Silent mode • 13
SIM card
inserting • 7
locking • 60
SMS messages
creating/sending • 37
deleting • 36, 39
setting • 39
viewing • 36
Sound settings • 34
Sounds, downloaded • 49
Speakerphone • 25
Speed dial • 28
Switching on/off
microphone • 25
phone • 8
T
T9 mode, text input • 20
Templates
emoticon • 38
MMS • 43
SMS • 38
Text, enter • 19
Time, set • 52
V
Voice memos • 53
Voicemail server • 40
Volume key, set • 61
W
Waiting call • 32
Wallpaper • 58
Web browser
access • 45
bookmarks • 46
World time • 52
